Table of Contents

Texas Instruments (TI) offers complete interface solutions with a full line of highperformance products . These products, which range from digital isolators to

USB hub controllers, are tailored to meet your design challenges . And, TI makes designing easier by providing leading-edge support tools such as training, a broad selection of evaluation modules (EVMs), application notes, comprehensive technical documentation and more . TI also offers samples and small orders (shipped within 24 hours via

TI authorized distributors) that will help you accelerate your time-to-market .

Included in this selection guide you will find featured products, design considerations, graphical representations of portfolios and parametric tables .

Introduction

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

LVDS, xECL, CML . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Multipoint-LVDS (M-LVDS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Digital Isolators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Industrial Serializers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

RS-485/422 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

RS-232 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

UARTs (Universal Asynchronous Receiver/Transmitters) . . . . . . . . . . . . . . . . . . . 17

CAN (3 .3-V and 5-V High-Speed CAN Transceivers) . . . . . . . . . . . . . . . . . . . . . . 19

FlatLink™ 3G . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

SerDes (Serial Gigabit Transceivers and LVDS) . . . . . . . . . . . . . . . . . . . . . . . . . . 21

DVI/PanelBus™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

TMDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

USB Hub Controllers and Peripheral Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Universal Serial Bus (USB) Power Managers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

PCI Express

®

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

PCI Bridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

CardBus Power Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Power Distribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

1394 (FireWire

®

) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

ESD/EMI Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

I

2

C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Voltage-Level Translation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

High-Speed Optoelectronics Devices and Equalizers . . . . . . . . . . . . . . . . . . . . . 42

Cross-Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Interface Guide

Texas Instruments 1Q 2009

Introduction

Texas Instruments (TI) provides complete interface solutions that empower you to differentiate your products and accelerate time-to-market.

Our expertise in high-speed, mixed-signal circuits, system-on-a-chip integration and advanced product development processes ensures you will receive the silicon, support tools, software and technical documentation to create and deliver the best products on time and at competitive prices. Included in this selection guide you will find design considerations, technical overviews, graphic representation of portfolios, parametric tables and resource information on the following families of devices:

LVDS: (p. 4) TIA/EIA-644A specification designed for differential transmission delivering signaling rates into the Gbps range and power in the mW range with low EMI to the telecommunication and consumer markets.

xECL: (p. 4) Emitter coupled logic (xECL), high-speed differential interface technology designed for low jitter and skew.

CML: (p. 4) Current-mode logic (CML), high-speed differential interface technology.

M-LVDS: (p. 8) TIA/EIA-899 specification with all the benefits of LVDS applicable to multipoint bus architecture in backplanes. Used often for clock distribution, e.g., AdvancedTCA.

Digital Isolators: (p. 10) The new ISO72x highspeed digital isolators use state-of-the-art integrated capacitive coupling and silicon-dioxide isolation barrier to provide up to 150-Mbps signaling rate with only 1-ns jitter, best-of-class noise immunity and high reliability.

Industrial Serializers: (p. 11) In combination with galvanic isolators these devices complete the interface between high voltage signals on the field-side and the low-voltage signals on the controller side.

RS-485/422: (p. 12) Robust TIA/EIA-485 and

TIA/ EIA-422 specifications specially designed for harsh, industrial environments transmitting a differential signal up to 50 Mbps or 1.2 km.

RS-232: (p. 14) TIA/EIA-232 specification defining single-ended interface between data terminal equipment (DTE) and data circuit-terminating equipment (DCE).

UARTs: (p. 17) Universal Asynchronous Receiver/

Transmitters are the key logic component of serial communication utilizing RS232, RS485/422 or

LVDS transceivers to transmit or receive between remote devices performing parallel to serial conversion in the transmit process and serial to parallel conversion in the receive process.

CAN: (p. 19) Controller Area Network (ISO11898) specification commonly used in automotive and industrial applications describes differential signaling at a rate up to 1 Mbps on a 40-meter bus with multipoint topology.

FlatLink™ 3G: (p. 20) A new family of serializers and deserializers designed for mobile phone displays.

SerDes: (p. 21) Serializers and deserializers in the gigabit range designed to bridge large numbers of data bits over a small number of data lines in telecommunication applications.

DVI/PanelBus™: (p. 23) The Digital Visual

Interface Specification, DVI, is an industry standard developed by the Digital Display Working

Group (DDWG) for high-speed digital connection to digital displays. DVI uses transition-minimized

DC balanced (TMDS) data signaling.

TMDS: (p. 25) Transition minimized differential signaling is the electrical interface used by DVI and HDMI.

USB Hub Controllers and Peripheral Devices:

(p. 26) The USB standard was established to make connecting PCs, peripherals and consumer electronics flexible and easy. The hub controller manages USB port connect/disconnect activities and a peripheral controller enables USB connectivity of a peripheral device to either a host or hub.

USB Power Managers: (p. 28) TI products, like

TPS204xA and TPS205xA, are designed to meet all the USB 1.0 and 2.0 requirements for currentlimiting and power switching to reliably control the power on the voltage bus.

PCI Express

®

: (p. 30) The PCI Express architecture is a robust, scalable, flexible, and cost-effective serial I/O interconnect, enabling dedicated point-to-point connectivity between peripherals.

PCI Bridges: (p. 33) A peripheral component interconnect (PCI) bridge provides a highperformance connection path between either two

PCI buses or a PCI component and one or more

DSP devices.

Power Distribution Switches: (pp. 34-35) The

CardBus controller uses the card detect and voltage sense pins to determine a PC card’s voltage requirements and then directs the

PCMCIA power switch to enable the proper voltages. Standard PC cards require that V

CC be switched between ground, 3.3 V, and 5 V, while V

PP

is switched between ground, 3.3 V, 5 V, and 12 V. CardBay sockets have the standard requirements for V

CC and 5 V to V

PP

V

CORE

, but require ground, 3.3 V,

, and ground, 1.8 V, or 3.3 V to

. Other PC card applications may simply not

while still having the standard need 12 V or V

PP requirements for V

CC

. Therefore, consider the voltage requirements of the application when selecting a PCMCIA power switch.

1394: (p. 36) IEEE 1394 (FireWire

®

) high-speed interconnection enables simple, low-cost, highbandwidth, real-time data connectivity between computers, peripherals and consumer electronics.

ESD/EMI Protection: (p. 39) Transient voltage suppressors which protect multiple interfaces from ESD/EMI and electrical noise transients.

The majority of devices comply with the

IEC-61000-4-2 ESD protection specification.

I

2

C : (p. 40) The I

2

C bus is useful for many of today’s microcontroller- and microprocessor-based systems or other systems linking many I/O devices.

Voltage-Level Translation : (p. 41) TI offers a full spectrum of products to achieve voltagelevel translation, including dual-supply level translators; FET switches; and devices with over-voltage tolerance, TTL-compatible inputs and open-drain outputs.

3

Texas Instruments 1Q 2009

Interface Guide

4

LVDS, xECL, CML

Design Considerations

Signaling Rate — TI offers repeaters/ translators and crosspoint switches with signaling rates up to 4 .0 Gbps .

Jitter — Reducing jitter, the deviation of a signal timing event from its ideal position, has become a priority for ensuring reliability in high-speed data buses .

Skew — Excessive skew, the time delta between the actual and expected arrival time of a clock signal, can limit the maximum bandwidth performance and lead to data sampling errors . Low skew specifications make high-speed interconnect devices excellent for signal buffering .

Power Consumption — Low-voltage differential signaling (LVDS) offers a low-power alternative to ECL and PECL devices . Current-mode drivers in LVDS produce a constant current, which allows power consumption to be relatively independent of frequency .

The constant current driver delivers about 3 .5 mA to a 100-Ω load .

Technical Information

• LVDS is based on the TIA/EIA-644A standard conceived to provide a generalpurpose electrical-layer specification for drivers and receivers connected in a point-to-point or multidrop interface .

16 Channels

10 Channels

8 Channels

L

VDS387

L

VDS389

Quads

L

VDS047

L

VDS31

L

VDS3487

L

VDS391

LVDS386

LVDS388A

LVDS048A/348

LVDS32/33

LVDS3486

LVDS390

LVDS117

LVDS116

CDCLVD110

L

VDS108

LVDS109

LVDS104

LVDS105

Duals

L

VDS9638

Singles

L

VDS1

Transmitters

LVDS9637

LVDS34

LVDS2

Receivers

LVDS049

LVDS050

LVDS051

LVDS1050

LVDS179

LVDS180

Transceivers

CML100

LVDS100

LVDS101

LVDS16 LVP16

LVDS17 LVP17

LVDS18 LVP18

LVDS19 LVP19

LVDS20 LVP20

Repeaters/

Translators

LVDS22

LVCP22

LVCP23

LVDS122

LVCP402

LVDS250

Crosspoint

Switches

Resources

For a complete list of resources (evaluation modules, data sheets and application notes), visit interface.ti.com

Literature

Number Description

Application Notes

SLLA014A

SLLA030C

SLLA031A

SLLA034A

SLLA038B

SLLA053B

SLLA054A

SLLA065

SLLA082B

SLLA100

SLLA101

SLLA103

SLLA104

SLLA105

SLLA107

SLLA147

Low-Voltage Differential Signaling (LVDS) Design Notes (Rev. A)

Reducing Electromagnetic Interference with LVDS (Rev. C)

Using an LVDS Receiver with TIA/EIA-422 Data (Rev. A)

Slew Rate Control of LVDS Circuits (Rev. A)

Interface Circuits for TIA/EIA-644 (LVDS) (Rev. B)

Performance of LVDS with Different Cables (Rev. B)

LVDS Multidrop Connections (Rev. A)

A Comparison of LinBiCMOS and CMOS Process Technologies in LVDS ICs

Active Fail-Safe in TI's LVDS Receivers (Rev. B)

Increase Current Drive Using LVDS

Interfacing Different Logic with LVDS Receivers

LVPECL and LVDS Power Comparison

Suggestions for LVDS Connections

DSP to DSP Link Using LVDS

Live Insertion with Differential Interface Products

Suitable LVDS Architectures

Literature Number Description

Application Notes

SCAA059

SCAA062

Part Number

AC-Coupling Between Differential LVPECL, LVDS, HSTL, and CML

DC-Coupling Between Differential LVPECL, LVDS, HSTL, and CML

Description Price*

Evaluation Modules (EVM)

SN65LVDS31-32EVM Evaluation Module for LVDS31 and LVDS32

SN65LVDS31-32BEVM Evaluation Module for LVDS31 and LVDS32B

SN65LVDS31-33EVM Evaluation Module for LVDS31 and LVDS33

SN65LVDS386EVM SN65LVDS386 Evaluation Module

SN65LVDS387EVM

SN65LVDS100EVM

SN65LVDS20EVM

SN65CML20EVM

SN65LVDS387 Evaluation Module

SN65LVDS100 Evaluation Module

SN65LVDS20 Evaluation Module

SN65CML20 Evaluation Module

49.00

49.00

49.00

49.00

49.00

49.00

99.00

49.00

SN65LVCP22-23EVM SN65LVCP22 Evaluation Module

SN65LVDS122EVM SN65LVDS122 Evaluation Module

SN65LVDS250EVM SN65LVDS250 Evaluation Module

25.00

49.00

49.00

Note: IBIS models are available at

interface.ti.com

*Suggested resale price in U.S. dollars.

Interface Selection Guide

Texas Instruments 1Q 2009

LVDS, xECL, CML

PECL/ECL Buffers/Translators Selection Guide

Device

SN65EL11

SN65EL16

No of

Rx

2

1

1

1

No of

Tx

Input

Signal

Output

Signal Frequency

ECL/PECL ECL/PECL 1.25 GHz

ECL TTL 2 GHz

SN65ELT20

SN65ELT21

1

1

1

1

TTL

TTL

PECL

PECL

500 Hz

150 Hz

SN65ELT22

SN65ELT23

SN65EPT22

SN65LVEL11

SN65LVELT22

SN65LVELT23

SN65LVEP11

2

2

2

2

2

2

2

2

2

2

1

1

2

2

TTL

TTL

PECL

PECL

LVTTL

ECL

LVTTL

LVPECL

LVPECL

ECL

LVPECL

LVTTL

ECL/PECL ECL/PECL

500 Hz

150 Hz

1.25 GHz

1.5 GHz

400 Hz

100 Hz

3 GHz

820

300

0

120

0

350

0

420

265

350

350

0

240

Tpd typ

(pS)

265

250

I

CC

Max

(mA)

32

23

16

25

22

35

56

26

29

29

29

ESD

HDM

(kV)

3

3

3

3

3

3

3

3

3

3

3

Supply

Voltage

(V)

5.0

5.0

5.0

5.0

5.0

5.0

Package(s)

8SOIC, 8TSSOP

8SOIC, 8TSSOP

8SOIC, 8TSSOP

8SOIC, 8TSSOP

8SOIC, 8TSSOP

8SOIC, 8TSSOP

Pinout

MC10EL11, MC100EL11

MC10EL16, MC100EL16

MC10ELT20, MC100ELT20

MC10ELT21, MC100ELT21

MC10ELT22, MC100ELT22

MC10EL23, MC100EL23

3.3

8SOIC, 8TSSOP

2.5-3.3

8SOIC, 8TSSOP

3.3

3.3

8SOIC, 8TSSOP

MC10LVEL23, MC100LVEL23

MC10LVEL11, MC100LVEL11

MC10LVEL22, MC100LVEL22

8SOIC, 8TSSOP MC10LVELT23, MC100LVELT23

2.5-3.3

8SOIC, 8TSSOP MC10LVEP11, MC100LVEP11

Price*

Web

Web

Web

Web

Web

Web

Web

Web

Web

Web

Web

LVDS/LVPECL/CML Repeaters/Translators and Crosspoints Selection Guide

Device

1

Description

Crosspoint Switch Family

No. of

Tx

No. of

Rx

Input

Signal

Output

Signal

Signaling

Rate

(Mbps)

Jitter

Max

(ps)

Part-to-

Part

Skew

Max

Tx tpd

Typ

(ns)

Rx typd Typ

(ns)

I

CC

Max

(mA)

ESD

HBM

(kV) Package(s) Price*

SN65LVCP22 2X2 Crosspoint Switch:

LVDS Outputs

SN65LVCP23

SN65LVCP40

2X2 Crosspoint Switch:

LVPECL Outputs

Dual 1:2 Mux with Equalizer and Pre-Emphasis

SN65LVCP402

2X2 Crosspoint Switch with

Rx-Eq

SN65LVCP404

4X4 Crosspoint Switch with

Rx-Eq

SN65LVDS122

2

2X2 Crosspoint Switch:

LVDS Output

SN65LVDS250

2

4X4 Crosspoint Switch:

LVDS Output

Repeaters/Translators

2

2

6

2

4

2

4

2

2

6

2

4

2

4

LVPECL,

LVDS, CML

LVPECL,

LVDS, CML

LVPECL,

LVDS, CML

CML

CML

LVPECL,

LVDS, CML

LVPECL,

LVDS, CML

LVDS

LVPECL

CML

VML

VML

LVDS

LVDS

1000

1300

4000

4250

4250

1500

2000

105

100

30

30

30

65

50

100

100

500

300

300

150

150

0.65

0.65

1

0.5

0.5

0.9

0.9

0.65

0.65

1

0.5

0.5

0.9

0.9

85

65

254

115

220

100

145

5

5

4

4

4

4

3

16SOIC,

16TSSOP

2.70

16SOIC,

16TSSOP

5.20

48QFN 17.40

24QFN

48QFN

7.15

10.55

16SOIC,

16TSSOP

4.75

38TSSOP 8.30

SN65CML100 LVDS/LVPECL/CML-to-CML

Repeater/Translator

SN65LVDS100 LVDS/LVPECL/CML to LVDS Repeater/Translator

SN65LVDS101 LVDS/LVPECL/CML-to-

LVPECL

Repeater/Translator

SN65LVDS16/17 2.5-V/3.3-V Oscillator Gain

Stage/Buffer (single ended/ diff inputs)

SN65LVDS18/19 2.5-V/3.3-V Oscillator Gain

Stage/Buffer (single ended/ diff inputs)

SN65LVDS20 2.5-V/3.3-V LVDS Repeater with Enable

SN65LVP16/17 2.5-V/3.3-V Oscillator Gain

Stage/Buffer

(single ended/diff inputs)

SN65LVP18/19 2.5-V/3.3-V Oscillator Gain

Stage/Buffer

(single ended/diff inputs)

SN65LVP20 2.5-V/3.3-V LVPECL

1

1

1

1

1

1

1

1

1

1

1

1

1

1

LVPECL,

LVDS, CML

LVPECL,

LVDS, CML

LVPECL,

LVDS, CML

LVPECL

LVPECL

LVPECL

LVPECL

LVPECL

CML

LVDS

LVPECL

LVDS

LVDS

LVDS

LVPECL

LVPECL

1500

2000

2000

2000

1000

4000

2000

1000

70

65

65

10

10

45

10

10

100

100

100

130

130

130

130

130

0.8

0.8

0.9

0.63

0.63

0.63

0.63

0.63

12

30

90

48

36

45

30

20

5

5

5

2

2

3

2

2

8SOIC,

8VSSOP

8SOIC,

8VSSOP

8SOIC,

8VSSOP

8QFN

8QFN

8QFN

8QFN

8QFN

2.55

2.55

2.55

2.55

1.95

3.30

2.55

1.95

1 1 LVPECL LVPECL 4000 10 130 0.63

— 45 3 8QFN 4.40

1

Supply voltage for all devices listed above is 3.3 V.

2

Integrated termination available (100-Ω) – SN65LVDTxxx.

New products are listed in bold red.

*Suggested resale price in U.S. dollars in quantities of 1,000.

Texas Instruments 1Q 2009

Interface Selection Guide

5

6

LVDS, xECL, CML

LVDS Selection Guide

Device

Single Family

SN65LVDS1

SN65LVDS2

SN65LVDS179

SN65LVDS180

Dual Family

SN65LVDS9638

SN65LVDS9637

SN65LVDS049

SN65LVDS050

SN65LVDS051

SN65LVDS1050

SN65LVDS22

Quad Family

SN65LVDS047

Description

Driver

Receiver

Full-Duplex Transceiver, No Enables

Full-Duplex Transceiver, with Enables

Driver

Receiver

Transceiver, Driver and Receiver Enable

Transceiver, Driver and Receiver Enable

Transceiver, Driver Enable Only

Transceiver with 2.7-V Supply

Multiplexed LVDS Repeater

SN65LVDS31

SN65LVDS3487

SN65LVDS391

SN65LVDS048A

SN65LVDS32

SN65LVDS3486

Driver with Flow-Through Pinout

Driver, AM26LS31 Footprint

Driver, MC34987 Footprint

Driver with Flow-Through Pinout

Receiver with Flow-Through Pinout

Receiver, AM26LS32 Footprint

Receiver, MC3486 Footprint

SN65LVDS390

8-Channel Family

SN65LVDS389

SN65LVDS388A

1

Receiver with Flow-Through Pinout

Driver

Receiver

16-Channel Family

SN65LVDS387 Driver

SN65LVDS386 Receiver

1

Integrated termination available (100-Ω) – SN65LVDTx.

No. of

Tx

8

16

1

1

1

2

2

2

2

2

2

4

4

4

4

4

4

4

4

2

2

2

2

2

2

8

16

No. of

Rx

1

1

1

Input

Signal

LVTTL

LVDS

LVDS, LVTTL

LVDS, LVTTL

LVTTL

LVDS

LVTTL

LVDS

LVTTL

LVTTL

LVTTL

LVTTL

LVDS

LVDS

LVDS

LVDS

LVTTL

LVDS

LVDS, LVTTL

LVDS, LVTTL

LVDS, LVTTL

LVDS, LVTTL

LVDS

LVDS

LVTTL

LVDS

LVTTL

LVDS

LVDS

LVDS

LVDS

LVTTL

LVTTL

LVTTL

LVTTL

Output

Signal

Signaling

Rate

(Mbps)

Part-to-

Part

Skew Max

(ps)

Tx tpd

Typ

(ns)

LVDS

LVTTL

LVTTL, LVDS

LVTTL, LVDS

630

400

400Tx/150Rx

400Tx/150Rx

LVDS

LVTTL

LVTTL, LVDS

LVDS, LVTTL

LVDS, LVTTL

LVTTL, LVDS

LVDS

400

400Tx/150Rx

400

400Tx/150Rx

400Tx/150Rx

400Tx/150Rx

250

800

1000

100

1.7

1.3

1.7

1.7

1.7

4

1.7

1.7

1.7

1.7

400

400

400

630

400

400Tx/150Rx

400Tx/150Rx

630

630

630

630

630

1500

1000

1500

1000

1000

800

800

1500

1000

1000

1000

1000

1.8

1.7

1.7

1.7

1.7

1.7

Interface Guide

Texas Instruments 1Q 2009

LVDS Selection Guide

Device

Single Family

SN65LVDS1

SN65LVDS2

SN65LVDS179

SN65LVDS180

Dual Family

SN65LVDS9638

SN65LVDS9637

SN65LVDS049

SN65LVDS050

SN65LVDS051

SN65LVDS1050

SN65LVDS22

Quad Family

SN65LVDS047

Description

Driver

Receiver

Full-Duplex Transceiver, No Enables

Full-Duplex Transceiver, with Enables

Driver

Receiver

Transceiver, Driver and Receiver Enable

Transceiver, Driver and Receiver Enable

Transceiver, Driver Enable Only

Transceiver with 2.7-V Supply

Multiplexed LVDS Repeater

SN65LVDS31

SN65LVDS3487

SN65LVDS391

SN65LVDS048A

SN65LVDS32

SN65LVDS3486

Driver with Flow-Through Pinout

Driver, AM26LS31 Footprint

Driver, MC34987 Footprint

Driver with Flow-Through Pinout

Receiver with Flow-Through Pinout

Receiver, AM26LS32 Footprint

Receiver, MC3486 Footprint

SN65LVDS390

8-Channel Family

SN65LVDS389

SN65LVDS388A

1

Receiver with Flow-Through Pinout

Driver

Receiver

16-Channel Family

SN65LVDS387 Driver

SN65LVDS386 Receiver

No. of

Tx

8

16

1

1

1

2

2

2

2

2

2

4

4

4

4

4

4

4

4

2

2

2

2

2

2

8

16

No. of

Rx

1

1

1

Input

Signal

LVTTL

LVDS

LVDS, LVTTL

LVDS, LVTTL

LVTTL

LVDS

LVTTL

LVDS

LVTTL

LVTTL

LVTTL

LVTTL

LVDS

LVDS

LVDS

LVDS

LVTTL

LVDS

LVDS, LVTTL

LVDS, LVTTL

LVDS, LVTTL

LVDS, LVTTL

LVDS

LVDS

LVTTL

LVDS

LVTTL

LVDS

LVDS

LVDS

LVDS

LVTTL

LVTTL

LVTTL

LVTTL

Output

Signal

Signaling

Rate

(Mbps)

Part-to-

Part

Skew Max

(ps)

Tx tpd

Typ

(ns)

LVDS

LVTTL

LVTTL, LVDS

LVTTL, LVDS

630

400

400Tx/150Rx

400Tx/150Rx

LVDS

LVTTL

LVTTL, LVDS

LVDS, LVTTL

LVDS, LVTTL

LVTTL, LVDS

LVDS

400

400Tx/150Rx

400

400Tx/150Rx

400Tx/150Rx

400Tx/150Rx

250

800

1000

100

1.7

1.3

1.7

1.7

1.7

4

1.7

1.7

1.7

1.7

400

400

400

630

400

400Tx/150Rx

400Tx/150Rx

630

630

630

630

630

1500

1000

1500

1000

1000

800

800

1500

1000

1000

1000

1000

1.8

1.7

1.7

1.7

1.7

1.7

LVDS, xECL, CML

7

LVDS Selection Guide

Device

Single Family

SN65LVDS1

SN65LVDS2

SN65LVDS179

SN65LVDS180

Dual Family

SN65LVDS9638

SN65LVDS9637

SN65LVDS049

SN65LVDS050

SN65LVDS051

SN65LVDS1050

SN65LVDS22

Quad Family

SN65LVDS0 47

SN65LVDS31

SN65LVDS3487

SN65LVDS391

SN65LVDS048A

SN65LVDS32

SN65LVDS3486

SN65LVDS390

8-Channel Family

SN65LVDS389

SN65LVDS388A

1

16-Channel Family

SN65LVDS387

SN65LVDS386

Rx tpd Typ

(ns)

2.4

2.1

2.1

2.5

2.1

1.9

3.7

3.7

3.7

4

2.6

3.7

3.7

2.5

2.5

I

CC

Max

(mA)

26

35

35

26

15

18

18

18

13

10

35

20

20

20

20

70

40

8

7

12

12

95

70

ESD

HBM

(kV)

8

15

10

8

8

8

8

15

10

12

12

12

12

8

8

15

15

12

12

15

15

15

15

Supply

Voltage

(V)

3.3

3.3

3.3

3.3

3.3

3.3

3.3

3.3

3.3

3.3

3.3

3.3

3.3

2.7

3.3

3.3

3.3

3.3

3.3

3.3

3.3

3.3

3.3

8HTSSOP, 8SOIC, 8VSSOP

8HTSSOP, 8SOIC, 8VSSOP

16TSSOP

16SOIC, 16TSSOP

16SOIC, 16TSSOP

16TSSOP

16SOIC, 16TSSOP

16SOIC, 16TSSOP

16SOIC, 16TSSOP, 16SOP

16SOIC

16SOIC, 16TSSOP

16SOIC, 16TSSOP

16SOIC, 16TSSOP, 16SOP

16SOIC

16SOIC, 16TSSOP

1

Integrated termination available (100-Ω) – SN65LVDTx.

*Suggested resale price in U.S. dollars in quantities of 1,000.

Package(s)

8SOIC, 5SOP

8SOIC, 5SOP

8SOIC, 8VSSOP

14SOIC, 14TSSOP

38TSSOP

38TSSOP

64TSSOP

64TSSOP

1.30

1.50

1.50

1.50

1.30

1.50

1.50

1.50

1.15

1.15

1.00

2.00

2.00

2.00

2.80

2.90

2.90

5.55

5.55

Price*

0.47

0.47

1.35

1.35

Texas Instruments 1Q 2009

Interface Guide

8

Multipoint-LVDS (M-LVDS)

M-LVDS Features

• TIA/EIA-899 standard

• Driver output current

11 .3 mA vs . 3 .5 mA (LVDS)

• Receiver thresholds

50 mV vs . 100 mV (LVDS)

• Driver edge rate control

1 ns min allows ease-of-stub design

• Contention provisions

Driver short circuit limited to 43 mA

Drivers, receivers and disabled devices must limit their bus voltage from 0 to 2 .4 V

Drivers are tested with 32 contending nodes

M-LVDS Devices from TI

• TIA/EIA-899 standard compliant guarantees true multipoint

• Type 1 receivers: 25-mV hysteresis to prevent oscillation

• Type 2 receivers: internal failsafe

(no external bias network)

• –1-V to 3.4-V common mode

• 3.3-V supply operation

M-LVDS for ATCA

• Synchronous ATCA clock signals

(8 kHz, 19 .22 MHz and user defined

<100 MHz) use M-LVDS .

V

ID

Type 1

High

Low

Receiver types.

Type 2

High

2.4 V

Low

2.4 V

Transition Region

150 mV

50 mV

0 mV

–50 mV

700 Mbps

600 Mbps

500 Mbps

LVDM179

LVDM180

400 Mbps

LVDM176

LVDM050

LVDM051

LVDM320

LVDM1676

LVDM1677

300 Mbps

200 Mbps

100 Mbps

LVDM22

MLVD201

MLVD203

MLVD206

MLVD207

MLVD2

MLVD3

MLVD047A

LVDM31

MLVD080

MLVD082

MLVD128

MLVD129

MLVD200A

MLVD202A

MLVD204A

MLVD205A

Single Dual Quad 8-Channel 16-Channel

Interface Guide

Texas Instruments 1Q 2009

Multipoint-LVDS (M-LVDS)

M-LVDS Selection Guide

Device

1

SN65MLVD2

SN65MLVD3

SN65MLVD200A

SN65MLVD201

No.

of

Tx

1

1

— 1

— 1

1

1

No.

of

Rx

Rx

Type

1

1

1

2

Half/

Full

Duplex Input Signal Output Signal

M-LVDS

M-LVDS

LVTTL

LVTTL

Half LVTTL, M-LVDS LVTTL, M-LVDS

Half LVTTL, M-LVDS LVTTL, M-LVDS

Signaling

Rate

(Mbps)

Part-to-

Part Skew

Max (ps)

Tx tpd

Typ

(ns)

Rx tpd

Typ

(ns)

200

200

100

200

1000

1000

1000

1000

2.5

1.5

3.6

4

I

CC

Max

(mA)

24

24

25

25

8

8

9

9

ESD

HBM

(kV) Package(s)

TIA/

EIA-899

Standard

Compliance Price*

8SON

8SON

8SOIC

8SOIC

4

4

4

4

1.95

1.95

1.55

1.85

SN65MLVD202A

SN65MLVD203

SN65MLVD204A

SN65MLVD205A

SN65MLVD206

SN65MLVD207

1

1

1

1

1

1

1

1

1

1

1

1

1

1

2

2

2

2

Full

Full

Half

Full

Half

Full

LVTTL, M-LVDS LVTTL, M-LVDS

LVTTL, M-LVDS LVTTL, M-LVDS

LVTTL, M-LVDS LVTTL, M-LVDS

LVTTL, M-LVDS LVTTL, M-LVDS

LVTTL, M-LVDS LVTTL, M-LVDS

LVTTL, M-LVDS LVTTL, M-LVDS

100

200

100

100

200

200

1000

1000

1000

1000

1000

1000

2.5

1.5

2.5

2.5

1.5

1.5

3.6

4

3.6

3.6

4

4

24

24

24

24

24

24

8

8

8

8

8

8

14SOIC

14SOIC

8SOIC

14SOIC

8SOIC

14SOIC

4

4

4

4

4

4

SN65MLVD047

SN65MLVD128

SN65MLVD129

SN65MLVD080

4

8

8

0

1

2

Half

LVTTL

LVTTL

LVTTL

M-LVDS

M-LVDS

M-LVDS

200

200

200

1000

800

800

1.5

1.5

1.5

1.5

1.5

60

140

140

12

8

8

16SOIC,

16TSSOP

48TSSOP

48TSSOP

4

4

4

1.45

3.80

3.80

SN65MLVD082

SN65LVDM179

SN65LVDM050

2

8

8

1

2

8

8

1

2

1

2

Half

Half

Full

Full

LVTTL, LVDS

LVTTL, LVDS

LVTTL, LVDM

LVTTL, LVDM

LVTTL, M-LVDS

LVTTL, M-LVDS

LVTTL, LVDM

LVTTL, LVDM

250

250

500

500

1000

1000

1000

1000

2.4

2.4

1.7

1.7

6

6

3.7

3.7

180

180

15

27

8

8

12

12

64TSSOP

64TSSOP

8SOIC,

8VSSOP

16SOIC,

16TSSOP

16SOIC,

16TSSOP

4

4

4.75

4.75

1.70

2.20

SN65LVDM22 2 2 — — LVDM LVDM 250 — 4 4 27 12 — 2.50

SN65LVDM31 4 0 —

SN65LVDM1676 16 16 —

Half

LVCMOS

LVTTL, LVDM

LVDM

LVTTL, LVDM

150

630

1000

1000

2.3

2.5

3

40

175

12

15

16SOIC

64TSSOP

1.55

7.75

1

Supply voltage for all devices listed above is 3.3 V and temperature range is –40 to 85°C.

New products are listed in bold red.

2

Automotive version available, temperature range of –40 to 125°C

*Suggested resale price in U.S. dollars in quantities of 1,000.

1.55

1.85

1.55

1.55

1.85

1.85

Resources

For a complete list of resources (evaluation modules, data sheets and application notes), visit interface.ti.com

Literature Number

Application Notes

SLLA106

Description

TIA/EIA-485 and M-LVDS, Power and Speed Comparison

SLLA088A

SLLA108

SLLA121

SLLA119

SLLA127

SLLA067A

Transmission at 200 Mbps in VME Card Cage Using LVDM (Rev. A)

Introduction to M-LVDS (TIA/EIA-899)

Interoperability of M-LVDS and BusLVDS

Wired-Logic Signaling with M-LVDS

M-LVDS Signaling Rate Versus Distance

Comparing Bus Solutions

Part Number Description

Evaluation Modules (EVMs)

MLVD20xEVM

SN65LVDM31-32BEVM

M-LVDS Evaluation Module

SN65LVDM31-32EVM Evaluation Module

Price*

99.00

49.00

Note: IBIS models are available at

interface.ti.com

*Suggested resale price in U.S. dollars.

Texas Instruments 1Q 2009

Interface Guide

9

10

Digital Isolators

Design Considerations

Reliability — Proven reliability of silicondioxide (SiO

2)

insulation; stable over temperature and moisture; life span

> 25 years .

Highest Noise Immunity — Only TI uses differential signals to cross the isolation barrier . Giving the highest immunity from external magnetic and electric fields to prevent data corruption .

Signaling Rate — TI offers digital isolators with the highest signaling rates of up to

200 Mbps . With the lowest skew and pulse distortion of only 1 ns .

Lowest Jitter — To ensure signal integrity, jitter reduction is a priority . ISO72xx products offer the lowest jitter with 1-ns jitter at 150-Mbps PRBS NRZ data input .

Low pulse skew

(pulse-width distortion)

• –40° to 125°C operation

• Low-input current requirement of 10 µA

• Fail-safe output

Technical Information

The ISO72xx is a family of digital isolators using the industry’s first application of silicon-based digital capacitive isolation technology . Digital buffers capacitively couple data signals through a dual

SiO

2

insulation barrier, which provides galvanic isolation of up to 4000 V .

The device receives digital inputs and provides clean digital outputs while preventing noise currents and/or excessive voltages from entering the local ground .

TI produces the SiO

2

insulation in TI isolation devices in semiconductor fabrication process producing a near zero defect glass insulation layer . Then the input signal crosses this isolation barrier, as a differential signal to insure the highest immunity to external noise .

All these features come together to make the longest lasting, most reliable isolation devices on the market .

Key Features

• 4000-V peak

isolation

UL 1577, IEC 60747-5-2

(VDE 0884, Rev . 2)

IEC 61010-1 and CSA approved

50-kV/µs transient immunity

• Signaling rate: 0 Mbps to 200 Mbps

Passes DC single levels

100

62

10

200

TI ISO Life Expectancy vs. Voltage

85

59

40

28

43

Tj = 85C

31

Tj = 150C

20

15

400 600

Vpeak (continuous)

800

23

11

1000

Device

Digital Isolators

ISO721/M

ISO722/M

ISO150

ISO7220/A/B/C/M

ISO7221/A/B/C/M

ISO7230/A /C/M

ISO7231/A/C/M

ISO7240/A/C/M

ISO7241/A/C/M

ISO7242/A/C/M

ISO3082/ISO3088

ISO3080/ISO3086

ISO15/

ISO13

ISO35/

ISO33

ISO1176

ISO1050

AMC1203

Description

Single Channel (TTL)

Single Channel, OUT EN

Dual Channel Configurable

Dual Channel

Dual Channel

Triple Channel

Triple Channel

Quad Channel

Quad Channel (TTL)

Quad Channel

Isolated Half Duplex RS-485

Isolated Full Duplex RS-485

Isolated Half Duplex RS-485

Isolated Full Duplex RS-485

Isolated PROFIBUS

Isolated CAN Transceiver

Isolated 2nd-Order ∆∑ Modulator

Isolation

Rating

(UL, VDE, CSA)

4000 V

4000 V

2400 Vrms

4000 V

4000 V

4000 V

4000 V

4000 V

4000 V

4000 V

4000 V

4000 V

4000 V

4000 V

4000 V

4000 V

4000 V

Channel

Direction

1/0

1/0

Config

2/0

1/1

3/0

2/1

4/0

3/1

2/2

2/1

2/1

2/1

2/1

2/1

1/1

N/A

Data Rate (Max)

Mbps

100/150

100/150

80

1/5/25/150

1/5/25/150

1/25/150

1/25/150

1/25/150

1/25/150

1/25/150

0.2/20

0.2/20

1/20

1/20

40 Mbps

1 Mbps

10 Mbps

Transient

Immunity

(Min) (kV/µs)

25

25

1.6

25

25

25

25

25

25

25

25

25

25

25

25

25

25

Supply

Voltage

(V)

3.3, 5

3.3, 5

5

3.3, 5

3.3, 5

3.3, 5

3.3, 5

3.3, 5

3.3, 5

3.3, 5

5

5

3.3

3.3

5

5

5

Price*

1.40

1.40

8.10

0.95

0.95

1.50

1.50

1.90

1.90

1.90

3.25

3.25

3.00

3.00

3.35

2.00

2.50

*Suggested resale price in U.S. dollars in quantities of 1,000. Preview products are listed in bold blue.

Interface Guide

Texas Instruments 1Q 2009

Industrial Serializers

Industrial Serializers

The new industrial serializers convert eight digital inputs, ranging from 0 V to

34 V, into a single data stream on SPI interface, which simplifies the design and saves 60% overall board space for industrial automation and test and measurement equipment . The device’s adjustable input current limit allows the use of a single resistor to set the maximum input current in the range of

200 µA to 5 mA, which reduces systemlevel power dissipation by more than

50% typical industrial applications .

There are also other features like an integrated voltage regulator and adjustable debounce glitch filter to make your system design simpler and more cost effective . Devices can be cascaded together for systems with greater than 160 inputs .

11

Device Description

Industrial Eight-Channel Digital Serializes

SN65HVS880 Nominal 24-V systems

SN65HVS882

SN65HVS884

10-V to 34-V digital-input

0-V to 34-V serializer with parity

Operating

Voltage

(V)

18 to 30

10 to 34

10 to 34

I/O

Voltage

(V)

0 to 30

0 to 34

0 to 34

Parity

No

No

Yes

Input

Data Rate

(Mbps)

1

1

1

Temperature

Range

Max

–40 to 85

–40 to 125

–40 to 125

Low

Voltage

Detector

Yes – 15 V

No

No

Price*

2.75

3.00

3.10

*Suggested resale price in U.S. dollars in quantities of 1,000. Preview products are listed in bold blue.

Signal

Conditioning

&

Serialization

Isolation

Signal

Conditioning

&

Serialization

SN65HVS882

Solution

Embedded Pr

Field

Supply

(0 V to 34 V)

Field

Ground

RLIM

Voltage

Regulator

Adjustable

Input Current

5 V

Thermal

Protection

Debounce

Select

Input

Return

(0 V to 34 V)

Input

Return

Current

Sense

Voltage

Sense

&

Channel 0

Debounce

Filter

Channel 7

5 V Output

(50 mA)

Over Temp

Debounce 0

Debounce 1

Serial Input

Load Pulse

Clock Enable

Clock

Serial Output

SN65HVS882, the industry’s first eight-channel, 34-V digital-input serializer.

Texas Instruments 1Q 2009

Interface Guide

RS-485/422

Design Considerations

Interoperability — In general, RS-485 is a superset of RS-422 . Compliance with the TIA/EIA standard will ensure reliable data communication in a variety of networks, including Modbus, INTERBUS,

PROFIBUS, BACnet and a variety of proprietary protocols .

Robustness — RS-485 is a robust interface standard for use in industrial environments . It features a wide common mode range of –7 V to 12 V. Parts from

TI are available with ESD protection up to 30 kV .

Reliability — Integrated fail-safe circuitry protects the bus from interpreting noise as valid data when short-circuit, opencircuit or idle line fault conditions occur .

Speed and Distance — Low noise coupling of differential signaling with twisted-pair cabling and wide common-mode voltage range allows data exchange at signaling rates of up to 50 Mbps or to distances of several kilometers at lower rates .

Line Loading — RS-422 is capable of supporting one driver and up to 10 receivers on the bus line . Standard

RS-485 is capable of supporting up to

32 unit loads or nodes on the bus line .

However, there are reduced unit load devices available that can support up to

256 devices .

Termination — A multipoint bus architecture requires termination at both ends of the bus line . The termination resistors must be within 20 percent of the characteristic impedance of the cable and can vary from 90 W to 120 W .

Technical Information

• The main difference between RS-422 and RS-485 is the multidrop and multipoint bus architecture—that is, one driver to many receivers and many drivers to many receivers, respectively .

• Typical signaling rates and distances for these standards are up to 10 Mbps or up to 1 .2 km . TI offers devices capable of reaching signaling rates of up to 50 Mbps .

Resources

For a complete list of resources (evaluation modules, data sheets and application notes), visit interface.ti.com

Literature Number

Application Notes

Description

SLLA036B

SLLA070C

SLLA112

SLLA177

Interface Circuits for TIA/EIA-485 (RS-485)

422 and 485 Standards Overview and System Configurations

RS-485 for E-Meter Applications

PROFIBUS Electrical-Layer Solutions

SLLA169

SLLA143

Use Receiver Equalization to Extend RS-485 Data Communications

RS-485 for Digital Motor Control Applications

Note: IBIS models are available at interface.ti.com

Interface Guide

Texas Instruments 1Q 2009

RS-485/422

RS-422/485 Selection Guide

No. of

Dr/Rx

1/1

Supply

(V)

3.3

3 to 5

5

Device

HVD12/11/10

HVD32 /31 /30

HVD35 /34 /33

Features

3.3-V Supply – Low/Mid High-Speed Slew-Rate Control

3.3-V Supply, No Enables

3.3-V Supply, with Enables

HVD08

HVD178x 0/1/2

HVD178x 5/6/7

HVD1794

HVD308x 2/5/8E

ISO308x 2/8

HVD485E

HVD1176

HVD22/21/20

HVD24/23

LBC176A

LBC184

Wide Supply Range: 3V to 5.5V

±70-V Protected, Wide Supply Range: 3V to 5.5V

±70-V Protected, Wide –20V to +25V Common Mode

±70-V Protected, Bus-Pin Invert/Wide Common

Ultra-Low Power, Optimized for Low & High Speeds

±4-kV Isolated RS-485 Optimized for Low & High Speeds

Half Duplex Transceiver

PROFIBUS Transceiver, EN 50170

±27-V Protected and –20V to +25V Common Mode

Receiver Equalization Allows Faster to Go Further

Low Power, Fast Signaling, ESD Protection

ESD Protection IEC 4-2 Air, Contact & IEC 4-5 Surge

LBC182

HVD1791

ESD Protection HBM, IEC4-2 Air and Contact

±70-V Protected, Wide –20V to +25V Common Mode

HVD308x 0/3/6E Ultra-Low Power, Optimized for Low & High Speeds

Signaling

Rate

(Mbps)

1 / 10 / 32

25 / 5 / 1

25 / 5 / 1

10

.115 / 1 / 10

.115 / 1 / 10

.115 / 1 / 10

0.2 / 1 / 20

0.2 / 20

10

40

0.5 / 5 / 25

3 / 25

30

0.25

0.25

0.115

0.2 / 1 / 20

ESD

(kV)

15

15

15

15

16

16

16

15

16

15

10

16

16 Short, Open, Idle

12

30

Receiver

Fail-Safe

Short, Open, Idle

Short, Open, Idle

Short, Open, Idle

Short, Open, Idle

Short, Open, Idle

Short, Open, Idle

Short, Open, Idle

Short, Open, Idle

Short, Open, Idle

Open

Short, Open, Idle

Short, Open, Idle

Open

Open

15 Open

16 Short, Open, Idle

15 Short, Open, Idle

Nodes

256

256

256

128

256

256

256

256

32

128

256

320

256

256

Package(s)

8-PDIP/SOIC

8-SOIC

14-SOIC

8-PDIP/SOIC

8-PDIP/SOIC

8-PDIP/SOIC

8-PDIP/SOIC

Price*

1.30

1.35

1.35

256 8-PDIP/SOIC/MSOP 0.90

256 16-Wide SOIC 2.60

64 8-PDIP/SOIC/MSOP 0.70

160 8-SOIC 1.55

8-PDIP/SOIC

8-PDIP/SOIC

8-PDIP/SOIC

8-PDIP/SOIC

8-PDIP/SOIC

14-SOIC

14-SOIC

ISO308x 0/6

LBC180A

±4-kV Isolated, Optimized for Low & High Speeds

High Signaling Rate, w/Enables

0.2 / 20

30

16 Short, Open, Idle

12 Short, Open, Idle

256

32

16-Wide SOIC

14-PDIP/SOIC

2.60

1.35

4/0

3.3

5

LBC172A, 174A

AM26LV31E

LBC173A, 175A

Quad Drivers, High Signaling Rate

Quad Drivers, High Signaling Rate, IEC4-2 ESD

Quad Receivers, High Signaling Rate, Low Power

30

64

50

13

15

6

Short, Open, Idle

32

10

32

16-PDIP/SOIC

16-SO/SOIC/

TSSOP/QFN

16-PDIP/SOIC

2.40

0.90

1.40

0/4

3.3

AM26LV32E Quad Receivers, High Signaling Rate, IEC4-2 ESD 64 15 Short, Open, Idle —

16-SO/SOIC/

TSSOP/QFN

1.01

9/9 5

HVD09

9-Channel Parallel Bus Transceivers 20 12 Open 32 56-TSSOP 3.50

1

These devices use the temperature prefixes: SN55 = military (–55° C to 125° C); SN65 = industrial (–40° C to 85° C); SN75 = commercial (0° C to 70° C). New products are listed in bold red.

*Suggested resale price in U.S. dollars in quantities of 1,000.

1.40

1.80

1.20

1.30

1.05

1.90

1.10

1.90

1.85

1.85

1.85

13

ControlNet

TM

Transceiver

Device

SN65HVD61

Description

ControlNet™ Transceiver

Supply

Voltage

(V)

5

I

CC

(max)

(mA)

65

Operating Temp

Range

(°C)

–40 to 100

Package

14 SOIC

Texas Instruments 1Q 2009

Interface Guide

14

RS-232

RS232: IEC6100-4-2 (Level 4)

ESD-Protected Devices

TI offers new RS-232 devices with system-level IEC61000-4-2 electrostatic discharge (ESD) protection . This protection makes the RS-232 interface immune to damage from ESD strikes that may occur while the system is up and running, such as when a connection to the RS-232 cable is made . These devices are drop-in replacements and are functionally identical to the existing industry-standard solutions, providing a seamless transition in the qualification process . These devices meet the requirements for low-power, high-speed applications such as portable/consumer, telecom and computing equipment .

TI offers these new devices in the

NiPdAu Pb-Free finish, which eliminates tin whiskers that might compromise long-term system reliability . TI offers the space-saving QFN package on select devices in addition to its already extensive RS-232 portfolio .

Key Features

• No external ESD device needed with these system-level ESD ratings:

±15-kV human-body model (HBM)

±8-kV IEC61000-4-2, contact discharge

±15-kV IEC61000-4-2, air-gap discharge

• Improved drop-in replacement of popular RS-232 devices

• Data rates meet or exceed today’s high-speed-application requirements

• Flexible power-saving options enable longer battery life

• Wide portfolio permits selection of the right form, fit and functionality

• Industry-leading interface product space with assured source of supply

• NiPdAu Pb-Free solution provides whisker-free, reliable package options

• Space-saving QFN package options for portable applications

Applications

• The three-driver, five-receiver

TRS3243E is most popular in applications like PCs, notebooks and servers .

• The TRS3238E/37E offer complementary five-driver, threereceiver solutions . These two devices are popular in PC peripheral applications like data cables, printers, modems, industrial control, etc .

• The TRS3227E/23E/22E/21E are popular in portable handheld applications due to their reduced bit count, package size and low power consumption .

• Higher-speed versions like the

SNx5C3232E/23E/22E/21E meet today’s higher throughput needs through the serial interface .

• The TRS232E and TRS213 provide a higher noise margin for more rugged environments such as industrial control .

TS5V330

TS3V330

Analog MUX

TVP5146 or 5150A

ADSL

Cable

Modem

SDRAM Flash

Video

In

EMIF

TMS320DM64x™

Video

Out

EMAC

JTAG PCI

PCI

Bus

Host CPU

McASP

USB 1394 IR RS-232

Video DAC

THS8200

THS8135

AMP for THS8135 only

Audio DAC

TLV320DAC26

TS5A23157

Analog

MUX

Volume

Control

Headphone

Speaker

Modem 802.11

1284

DVI

Interface Guide

Personal video recorder application block diagram.

MAX3

243

E

Texas Instruments 1Q 2009

RS-232

15

RS-232 Selection Guide

Device

Data Rate

(kbps) Drivers Receivers

120

120

120

120

120

1000

120

120

120

120

1000

1000

1000

1000

1000

1000

460

250

250

1000

120

120

120

120

120

120

120

120

120

120

120

250

250

250

250

1000

250

1000

250

500

120

120

120

120

120

200

4

4

3

3

5

3

3

4

2

5

2

2

3

3

3

3

2

1

5

6

3

1

4

1

1

2

4

5

5

1

2

3

2

3

2

1

2

4

4

5

4

2

TRS3253E

TRS3318E

TRS3386E

TRSF23243

TRSF3221E

TRSF3222E

TRSF3223E

TRSF3232

TRSF3238E

TRSF3243

TRSF3253

GD65232

GD75232

GD75323

LT1030

MC1488

MC1489

MC1489A

SN65C1154

SN65C1406

SN75150

SN75154

SN75155

SN751701

SN75185

SN75186

SN75188

SN75189

SN75189A

SN75196

SN752232

TRS202E

TRS207

TRS208

TRS211

TRS213

TRS222

TRS232E

TRS3221E

TRS3222E

TRS3223E

TRS3227E

TRS3232E

TRS3237E

TRS3238E

TRS3243E

4

4

4

3

5

3

5

5

2

3

2

2

5

2

5

5

2

1

5

1

4

4

1

1

4

3

10

3

3

1

2

5

2

3

2

1

2

5

5

3

4

2

ESD

HBM (kV)

IEC61000-4-2

±15

±15

±15

15

±15

IEC61000-4-2

IEC61000-4-2

IEC61000-4-2

IEC61000-4-2

IEC61000-4-2

IEC61000-4-2

IEC61000-4-2

IEC61000-4-2

IEC61000-4-2

IEC61000-4-2

IEC61000-4-2

IEC61000-4-2

±15

IEC61000-4-2

IEC61000-4-2

IEC61000-4-2

±15

IEC61000-4-2

±15

±15

2

2

10

2

10

Supply

Voltage(s) (V)

5

5

5

5

5

5

5

5

5

5

5

5

5

5

5

3.3 or 5

5

5

5

5

5

5

5

5

5

5

±9, 5

±9, 5

±12, 5

±5

±9

5

5

±12, 5

±12

5 or 12

±12

±5, 9, 12

±12, 5

±12, 5

±9

5

5

±12, 5

5

I

(max) (mA)

15

1

1

20

20

20

20

10

10

1

1

1

1

CC

0.3

1

1

1

1

1

1

1

1

1

1

1

2

1

38

30

32

25

26

26

22

35

14

11.9

30

25

26

26

20

±50

Package(s)

16PDIP, 16SOIC, 16TSSOP

24SOIC, 24SSOP

24SOIC, 24SSOP

28SOIC, 28SSOP

28SOIC, 28SSOP

18PDIP, 18SOIC

16PDIP, 16SOIC, 16TSSOP

16SSOP, 16TSSOP

20SOIC, 20SSOP, 20TSSOP

20SOIC, 20SSOP, 20TSSOP

16SSOP

16SOIC, 16SSOP, 16TSSOP

28SOIC, 28SSOP, 28TSSOP

28SOIC, 28SSOP, 28TSSOP

28SOIC, 28SSOP, 28TSSOP, 32QFN

32QFN

20SSOP, 20TSSOP

20SOIC, 20TSSOP

48SSOP, 48TSSOP

16SSOP, 16TSSOP

20SOIC, 20SSOP, 20TSSOP

20SOIC, 20SSOP, 20TSSOP

16SOIC, 16SSOP, 16TSSOP

28SOIC, 28SSOP

28SOIC, 28SSOP, 28TSSOP

28SOIC, 28SSOP, 28TSSOP

20PDIP, 20SOIC, 20SSOP, 20TSSOP

20PDIP, 20SOIC, 20SSOP, 20TSSOP

20SOIC

14PDIP, 14SOIC

14PDIP

14PDIP

14PDIP

20PDIP

16SOIC

8PDIP, 8SOIC

16PDIP, 16SO, 16SOIC

8PDIP, 8SOIC

8SO

20PDIP, 20SOIC, 20SSOP, 20TSSOP

24SOIC

14PDIP, 14SO, 14SOIC

14PDIP, 14SO, 14SOIC

14PDIP, 14SO, 14SOIC

20PDIP, 20SOIC

48SSOP, 48TSSOP

1.62

0.29

0.27

0.41

1.44

1.44

1.44

1.26

1.62

1.62

Web

1.68

1.92

3.42

1.26

1.20

0.96

1.33

1.20

0.88

Price*

0.54

1.08

1.08

1.08

1.08

1.26

0.58

0.88

1.28

1.12

0.45

1.80

0.22

0.22

0.22

0.68

0.90

0.20

0.25

0.29

3.42

1.80

0.72

0.72

0.72

1.30

*Suggested resale price in U.S. dollars in quantities of 1,000.

Texas Instruments 1Q 2009

Interface Guide

16

RS-232

RS-232 Selection Guide (Continued)

Device

Data Rate

(kbps) Drivers Receivers

SN75C1154

SN75C1406

SN75C185

SN75C188

SN75C189

SN75C189A

SN75C198

SN75C23243

SN75LBC187

SN75LBC241

SN75LP1185

SN75LP196

SN75LPE185

SN75LV4737A

120

120

120

120

120

120

120

250

120

100

256

256

256

128

TL145406

UA9636A

UC5170C

UC5180C

120

120

120

120

3

2

UC5181C 120 —

*Suggested resale price in U.S. dollars in quantities of 1,000.

8

3

8

3

5

3

4

3

3

4

6

3

4

4

3

5

3

5

5

5

5

4

4

10

4

3

5

ESD

HBM (kV)

15

15

15

4

15

2

2

2

2

Supply

Voltage(s) (V)

5

5

5, ±12

5, ±12

5, ±12

3 or 5

±12, 5

±12, 5

±12, 5

±12

5

5

±12

3.3 or 5

±12, 5

±12

4.75 to 5.25

4.75 to 5.25

I

CC

(max) (mA)

1

1

30

8

1

20.7

0.7

0.7

0.32

0.02

0.45

0.75

0.16

20

36

35

35

Package(s)

20PDIP, 20SO, 20SOIC

16PDIP, 16SO, 16SOIC

20PDIP, 20SOIC

14PDIP, 14SO, 14SOIC, 14SSOP

14PDIP, 14SO, 14SOIC

14PDIP, 14SO, 14SOIC, 14SSOP

14PDIP, 14SOIC

48SSOP, 48TSSOP

28SSOP

28SOIC

20PDIP, 20SOIC, 20SSOP

20PDIP, 20SOIC, 20SSOP, 20TSSOP

24PDIP, 24SOIC, 24SSOP, 24TSSOP

28SSOP

16PDIP, 16SOIC

8PDIP, 8SOIC

28PLCC

28PLCC

28PLCC

Price*

3.60

2.16

1.78

1.78

1.89

2.61

0.31

0.31

2.25

3.42

0.76

0.86

1.08

0.31

0.94

0.36

3.15

3.00

3.15

Interface Guide

Analog

Phone Line

2-to-4 Wire

Interface

Antenna

CATV

RF

FE

RF

FE

Satellite

RF

FE

Plug

AC

Adapter

Tuner

Tuner

Tuner

Voice

CODEX

ADC

ADC

ADC

803.11

DVI/TMDS

1394 PHY

ADSL/

Cable MODEM

RS-232

Keypad

SDRAM

FLASH

LCD

Display

USB Plug

LED

IrDA

CPU

OFDM

QAM

QPSK

DEMOD

LAN

Port

Smart Card

MMC SD

PCI

Interface

Stereo Audio Line In

L

R

Video Processor

PCI/IF

EMIF

Video Port

EMAC

SDRAM FLASH

Video

Encoder

Camera

Stereo Audio

CODEC

3-Ch

DAC

Bluetooth

Controller

TV CH3-4 MOD

3-Ch

Amp

®

L

R

Video Input

Video

Decoder

Video Port Video Port

3-Ch

DAC

3-Ch

Amp

PDA interface application block diagram.

Texas Instruments 1Q 2009

UARTs (Universal Asynchronous Receiver/Transmitters)

Design Considerations

The UART is a key component of an asynchronous serial communications system . For example, all internal modems have their own UARTs . In this application, parallel data within the computer is converted by the UART to serial data before being transferred to the modem . In addition to PC/peripheral communication, UARTs can be used for chip-to-chip communications .

As data transfer speeds have increased to support applications such as telecommunication base stations, cell phones, PCs, fax servers and rack modems, the transmission rate of the

UART has become critical to preventing system bottlenecks . When a fast external modem is used, designers should be sure the computer’s UART can handle the modem’s maximum transmission rate . For example, the TL16C550D

UART contains a 16-byte buffer, enabling it to support higher sustained transmission rates than the older 8250

UART . To reduce software buffering and data overruns, TI has added its patented hardware autoflow control to all new designs and most existing

UARTs . Most UARTs allow the divisor to be programmed from 1 to 65,535 and sometimes with an added predivisor factor of 1, 4, 16 or 64 .

To accommodate the requirements of diverse applications, TI offers a wide portfolio of parallel-to-serial and serialto-parallel UARTs in highly integrated, space-saving configurations that allow designers to increase system performance while decreasing space requirements .

As one of the world’s leading highvolume semiconductor manufacturers,

TI offers designers and OEMs the satisfaction of knowing they are backed by a supplier with the resources to meet their needs . These include a dedicated marketing and technical support team to assist with any issues .

Key Features

• Single-, dual- and quad-channel devices

• 16- and 64-byte FIFOs available

• 5-, 3.3-, 2.5- and 1.8-V supply

• Clock rates up to 24/20/16-MHz for

1 .5/1 .25/1 .0-Mbps data transfer rates

• Hardware and software autoflow control

• Programmable sleep mode and low-power mode

• Industrial temperature characterization

17

4

2

TL16C452

TL16C554A

TL16C2552

TL16C2550

TL16C552A

TL16C2752

1

TL16C451

TL16C450

TL16C550D

TL16C550C

No FIFO

UART family of products.

16-Byte

FIFO Memory Size

Texas Instruments 1Q 2009

TL16C754B

TL16C754C

TL16C2752

TL16C752B

TL16C750

64-Byte

TL16PC564B

TL16PIR552A

TIR1000

Special

Functions

Interface Guide

18

UARTs (Universal Asynchronous Receiver/Transmitters)

Device Channel(s) FIFOs

Voltage

(V)

Characterized

Temp. (°C)

Universal Asynchronous Receiver/Transmitters (UARTs)

TL16C2550 2 16-Byte 1.8/2.5/3.3/5 –40 to 85

Package(s) Description Price*

TL16C2552

TL16C2752

TL16C450

TL16C451

TL16C452

TL16C550C

TL16C550D

1

1

2

2

2

1

1

16-Byte

64-Byte

None

None

None

16-Byte

16-Byte

1.8/2.5/3.3/5

1.8/2.5/3.3/5

5

5

5

3.3/5

2.5/3.3/5

TL16C552A

TL16C554A

TL16C750

TL16C752B

TL16C754B

TL16C752C

TL16C754C

TL16PC564B/BLV

TL16PIR552

2

4

1

2

4

2

4

1

2

16-Byte

16-Byte

16/64-

Byte

64-Byte

64-Byte

64-Byte

64-Byte

16/64-Byte

16-Byte

5

5

5

3.3

3.3/5

1.8/2.5/3.3/5

1.8/2.5/3.3/5

3.3/5

5

*Suggested resale price in U.S. dollars in quantities of 1,000.

–40 to 85

0 to 70

0 to 70

0 to 70

–40 to 85

–40 to 85

–40 to 85

–40 to 85

–40 to 85

–40 to 85

–40 to 85

–40 to 85

–40 to 85

0 to 70

0 to 70

32 QFN, 44 PLCC,

48 TQFP

Dual UART with Programmable Auto-RTS and Auto-CTS

32 QFN, 44 PLCC Dual UART with Programmable Auto-RTS and Auto-CTS

44 PLCC Dual UART with Customizable Trigger Levels

40 DIP, 44 PLCC Single UART

68 PLCC Single UART with Parallel Port

68 PLCC

40 DIP, 44 PLCC,

48 LQFP, 48 TQFP

Dual UART with Parallel Port

Single UART with Hardware Autoflow Control

32 QFN

48 LQFP, 48 TQFP

Single UART with Hardware Autoflow Control

68 PLCC, 80 TQFP Dual UART with Parallel Port

68 PLCC, 80 LQFP Quad UART with Hardware Autoflow Control

44 PLCC, 64 LQFP Single UART with Hardware Autoflow Control, Low-Power Modes

Bus

Interface

Control and

Status Block

2.80

1.75

3.85

6.00

3.70

48 LQFP, 48 TQFP Dual UART with Hardware Autoflow Control, Low-Power Modes

68 PLCC, 80 LQFP Dual UART with Hardware Autoflow Control, Low-Power Modes

32 QFN, 48 TQFP Dual UART with 64-Byte FIFO

3.10

8.35

7.50

64 LQFP Quad UART with Hardware Autoflow Control, Low-Power Modes 6.75

100 BGA, 100 LQFP Single UART with PCMCIA Interface 5.90/6.10

80 QFP Dual UART with Selectable IR & 1284 Modes 6.10

Asynchronous Communications Element

TL16C255x

Get samples, datasheets and app reports at:

www.ti.com/ sc/device/TL16C2550

The TL16C255X family incorporates the functionality of two TL16C550D UARTs, each UART having its own register set and FIFOs . The two UARTs share only the data bus interface and clock source .

Otherwise, they operate independently .

Another name for the UART function is asynchronous communications element

(ACE), and these terms will be used interchangeably .

Key Features

• Programmable auto-RTS and auto-CTS

• In auto-CTS mode, CTS controls transmitter

• In auto-RTS mode, RCV FIFO contents, and threshold control RTS

• Serial and modem control outputs drive an RJ11 cable directly when equipment is on the same power drop

• Capable of running with all existing

TL16C450 software

• After reset, all registers are identical to the TL16C450 register set

• Up to 24-MHz clock rate for up to

1 .5-Mbaud operation with V

CC

1-Mbaud operation with V

CC

625-kbaud operation with V

CC

= 5 V

• Up to 20-MHz clock rate for up to

1 .25-Mbaud operation with V

CC

= 3 .3 V

• Up to 16-MHz clock rate for up to

= 2 .5 V

• Up to 10-MHz clock rate for up to

= 1 .8 V

• In the TL16C450 mode, hold and shift registers eliminate the need for precise synchronization between the CPU and serial data

• Programmable baud rate generator allows division of any input reference clock by 1 to (2 16 –1) and generates an internal 16x clock

• Standard asynchronous communication bits (start, stop, and parity) added to or deleted from the serial data stream

• 5-V, 3.3-V, 2.5-V, and 1.8-V operation

• Independent receiver clock input

• Transmit, receive, line status, and data set interrupts independently controlled

Applications

• Point-of-sale terminals

• Gaming terminals

• Portable applications

• Router control

• Cellular data

• Factory automation

UART_CLK

Transmitter

FIFO 64-Byte

Modem Control Signals

Control Signals

Status Signals

Divisor

Control Signals

Status Signals

Receiver

FIFO 64-Byte

Transmitter

Block Logic

Baud Rate

Generator

Receiver

Block Logic

TX

TL16C754B, TI’s high-performance, four-channel UART device.

RX

Vote Logic

TX

3.00

Web

1.50

2.50

2.55

1.75

TX

Interface Guide

Texas Instruments 1Q 2009

CAN (3.3-V and 5-V High-Speed CAN Transceivers)

Design Considerations

Bus Protection — Features such as short-circuit protection, thermal shutdown protection, glitch-free powerup and power-down protection, high-

ESD protection, wide common-mode range that provides for common-mode noise rejection, and current-limiting circuitry to protect the transceivers and system from damage during a fault condition have been incorporated into these devices .

Electromagnetic Compatibility —

An important requirement for products intended for networking applications is that they behave in a way that does not interfere with the operation of other nearby components or systems . TI offers specially designed and tested transceivers for EM compatibility without malfunction or degradation of performance in rugged EM environments .

Compatibility in this definition means both immunity to external EM fields, and the limited strength of generated EM fields .

Supply Voltage — In addition to 5-V transceivers, TI offers 3 .3-V transceivers that accomplish the same tasks with less than half the power and save on the cost of an additional voltage regulator in 3 .3-V powered applications .

Technical Information

• ISO11898 specifies the physical-layer implementation of CAN .

• This specification describes a twisted wire pair bus with 120-W characteristic impedance (Zo) and differential signaling rate of up to 1 Mbps on a

40-meter bus with multi-drop topology .

CAN Transceiver Selection Guide

Supply

Voltage I/O Levels Device

5 V

5-V CMOS

3.3-V TTL

3.3-V TTL

5-V TTL

5-V TTL

SN65HVD251

Description

Improved PCA82C250 and PCA82C251

SN65HVD252

Low Propagation Delay/DeviceNet Compliant,

Highest IEC ESD CAN Device

SN65HVD253

Low Propagation Delay/DeviceNet Compliant,

Highest IEC ESD, With Auto Baud Loop-Back

SN65HVD1040

Improved TJA1040 with Better ESD Bus Wake Up

3.3-V TTL

3.3-V TTL

SN65HVD1050 Improved TJA1050 with Better ESD

SN65HVD230

SN65HVD231

Standby Mode

Sleep Mode

Short-Circuit

Protection (V)

–27 to 40

–27 to 40

–27 to 40

–27 to 40

–27 to 40

–4 to 16

–4 to 16

ESD

(kV)

±14

IEC

IEC

±14

±8

±16

±16

Operating Temp

Range (°C)

–40 to 125

–40 to 125

–40 to 125

–40 to 125

–40 to 125

–40 to 85

–40 to 85

Price*

0.90

0.75

0.80

0.70

0.55

1.45

1.45

3.3 V

3.3-V TTL

3.3-V TTL

SN65HVD232

SN65HVD233

Cost Effective

Standby Mode, Diagnostic Loop-Back

–4 to 16

–36 to 36

±16

±16

–40 to 85

–40 to 125

1.10

1.50

3.3-V TTL

3.3-V TTL

SN65HVD234

SN65HVD235

Standby Mode, Sleep Mode

Standby Mode, Autobaud Loop-Back

–36 to 36

–36 to 36

±16

±16

–40 to 125

–40 to 125

1.45

1.50

*Suggested resale price in U.S. dollars in quantities of 1,000. New products are listed in bold red.

Preview products are listed in bold blue.

Standard Compliant Protocols

CAN is a serial communications bus for robust real-time control applications that is rapidly gaining the attention of industrial process, test, measurement and control engineers worldwide . It has excellent error detection and confinement capabilities, and has the flexibility to operate either as a primary backbone data communications network, as a secondary local embedded system, or as both . The engineering community is just now exploring the limits of what this bus can do when coupled with newly developed intelligent sensing technologies .

Texas Instruments 1Q 2009

Besides CAN’s high reliability, another of the main advantages of CAN when compared to alternative networks, is the availability of higher layer protocols

(HLPs) . There are many CAN-related system development packages prepared for these HLPs – hardware interface cards and easy-to-use software packages that provide system designers with a wide range of design and diagnostic tools . These components provide for the rapid development of complex control applications without building each node of a system network from scratch .

The HLP relieves a developer from the burden of dealing with CAN-specific details such as bit-timing and implementation functions . It provides standardized communication objects for real-time data with Process Data Objects (PDOs) and Service Data Objects (SDOs), and provides special functions such as a time stamp, a sync message, and emergency shut-down procedures as well as network management, boot-up commands, and error management .

Among the most popular HLPs are

CANopen, CANkingdom and DeviceNet with applications ranging from medical equipment to process control and assembly line coordination .

Interface Guide

19

20

Flatllink

TM

3G

FlatLink™ 3G – Display SerDes for Mobile Phones

FlatLink 3G uses low EMI subLVDS to carry 24-bit color RGB data from applications processors, such as OMAP™ from TI, to the LCD driver . It caters to screen resolutions from QVGA to XGA .

FPC cabling typically interconnects the serializer transmitter with the display .

Compared to parallel signaling, FlatLink

3G outputs significantly reducing the EMI of the interconnect by over 20 dB . The electromagnetic emission of the device itself is very low and meets the SAE

J1752/3 ‘M’-specification .

Flatlink™ 3G

1

4

7

*

2

5

8

0

3

6

9

#

LCD

Driver

LVDS302

CLK DATA

LVDS301

Application

Processor with

RGB

Video

Interface

Resolution (W x H)

QVGA

CIF+

HVGA

VGA

WVGA

SVGA

XGA

320

800

640

480

1024

480

800

1024

240

640

352

352

480

250

320

640

320

800

600

768

320

200

416

440

XGA

SVGA

VGA

Tx

LVDS301

Rx

LVDS302

HVGA

QVGA

3-Ch

Tx

LVDS303

Rx

LVDS304

2-Ch

Tx

LVDS305

Rx

LVDS306

1-Ch

Application

Processor with

Integrated

MIPI CSI-1

Receiver

Camera

RGB

LVDS315

FPC

FlatLink™ 3G Selection Guide

Device Description

SN65LVDS301 QVGA-XGA Serializer Transmitter

SN65LVDS302 QVGA-XGA Deserializer Receiver

SN65LVDS303

QVGA-VGA Serializer Transmitter

SN65LVDS304

QVGA-VGA Deserializer Receiver

SN65LVDS305

QVGA-HVGA Serializer Transmitter

SN65LVDS306

QVGA-HVGA Deserializer Receiver

SN65LVDS315

Camera CSI-1 Converter

Number of

Parallel

Outputs

27

27

27

8

Number of

Parallel

Inputs

27

27

27

Data

Throughout

(MB/s)

1755

1755

810

810

405

405

208

PLL Frequency

(MHz)

4 to 65

4 to 65

4 to 30

4 to 30

4 to 15

4 to 15

3.5 to 26

Serial Data

Receiver

Channels

3

2

1

Serial Data

Transmitter

Channels

3

2

1

1

Price*

*Suggested resale price in U.S. dollars in quantities of 1,000. New products are listed in bold red.

1.90

1.90

1.70

1.70

1.55

1.55

2.10

Interface Guide

Texas Instruments 1Q 2009

SerDes (Serial Gigabit Transceivers and LVDS)

21

The serial gigabit transceiver family of devices from TI provides low power dissipation while enabling multigigabit transmission over copper backplanes, cable and optical links . The transceivers can be used in a variety of applications, including Gigabit Ethernet, 10 Gigabit

Ethernet modules, synchronous optical network (SONET) OC-48 and OC-192 based equipment, wireless infrastructure backplanes and general-purpose backplane applications .

General

Purpose

TLK3101

TLK2711

TLK2701

TLK2501

TLK1501

TLK4015

TLK2521

TLK1521

TLK4120

TLK4250

SerDes

Portfolio

EPON

TLK1211

TLK2541

Gigabit

Ethernet/FC

TLK1201AI

TLK1221

TNETE2201

TLK2208B

TLK2226

TLK2201BI

TLK2201AJR

10 Gigabit

Ethernet

TLK3114SC

TLK3104SA

TLK3104SC

TLK3118

TLK3132

TLK3134

TLK10021

LVDS

SN65LVDS93/94

SN65LVDS95/96

SN65LV1023A/1224B

SN75LVDS82/83

SN75LVDS84A/86

SN75LVDT1422

SerDes Solutions – Frontplane/Backplane

TLK1201AI/TLK2226/TLK2208B

Low-Power 1-GbE Transceiver

1 to 1 .6 Gbps

(Backplane/Frontplane)

Line Module

Photodiode

TIA*

PA*

DSP

Controller

Frontplane

SerDes

Laser

Diode

LD*

Clock

Buffer

MAC

Framer/

Mapper

Memory

NPU/

ASICs

Power

Management

Backplane

SerDes

Reference

Clock

PLL Multiplier

Clock

Buffer

*TIA, PA and LD are in development and not currrently available .

TLK3134

TLK2208B

TLK2226

TLK1201AI

10-Gigabit Ethernet Backplane Device XAUI (4 x 3.125 Gbps)

8-Channel Gigabit Ethernet Xcvr (8 x 1 to 1.3 Gbps)

6-Channel Gigabit Ethernet Xcvr (6 x 1 to 1.3 Gbps)

— 1- to 1.6-Gbps Gigabit Ethernet-Compliant SerDes

TLK3101/TLK2501/TLK1501 — 600-Mbps to 3.2-Gbps General-Purpose Backplane SerDes

SN65LV1023A/1224B

— 100 to 660 Mbps – 10:1 LVDS SerDes

Texas Instruments 1Q 2009

Interface Guide

22

SerDes (Serial Gigabit Transceivers and LVDS)

SerDes (Serial Gigabit Transceivers) Selection Guide

Device

General Purpose

TLK1501

Function

Single-Ch. 16:1 SerDes

Data Rate

0.6-1.5 Gbps

TLK2501

TLK2701

1.6-2.5 Gbps

1.6-2.5 Gbps

TLK2711

TLK3101

TLK2521

TLK1521

TLK4120

TLK4250

TLK4015

EPON

TLK1211

Single-Ch. 16:1 SerDes

Single-Ch.

16:1 SerDes

Single-Ch.

16:1 SerDes

Single-Ch. 16:1 SerDes

Single-Ch.

18:1 SerDes

Single-Ch.

18:1 SerDes

Four-Ch. 18:1 Serdes

Four-Ch. 18:1 Serdes

Four-Ch. of 16:1 Xcvr

Single-Ch. 10:1 Gigabit Ethernet

1.6-2.5 Gbps

2.5-3.125 Gbps

1.0-2.5 Gbps

0.6-1.3 Gbps

0.5-1.3 Gbps

1.0-2.5 Gbps

0.6-1.5 Gbps/Ch.

0.6-1.3 Gbps

TLK2541

Single-Ch. 20:1 Txcr

Gigabit Ethernet/FibreChannel

TLK1201AI Single-Ch. 10:1 Gigabit

Ethernet Xcvr Gbps

TLK2201BI

TLK2201AJR

TLK2208B

Single-Ch.

10:1 Gigabit

Ethernet Xcvr

Single-Ch.10:1 Gigabit

Ethernet Xcvr

Eight-Ch. of 10:1 Gigabit

Ethernet Xcvr

1.0-2.6 Gbps

0.6-1.3

1.2-1.6 Gbps

1.0-1.6 Gbps

1.0-1.3 Gbps

Serial I/F

1

1 CML

1 CML

1 CML

1 VML

1 VML

1 VML

1 VML

4 VML

4 VML

4X CML

1 LVPECL

1 LVPECL

1 LVPECL

1 LVPECL

1 LVPECL

Parallel I/F

16 LVTTL

16 LVTTL

16 LVTTL

16 LVTTL

16 LVTTL

18 LVTTL

18 LVTTL

18 LVTTL

18 LVTTL

16 LVTTL/Ch.

10 LVTTL

20 LVTTL

10 LVTTL

10 LVTTL

10 LVTTL

8 VML

TLK2226 Six-Ch. 16:1 Gigabit

Ethernet Xcvr

10 Gigabit (XAUI) Ethernet

TLK3104SA

TLK3104SC

TLK3114SC

Four-Ch. of

10/8:1 Xcvr

Four-Ch. of

4.1: Xcvr

Four-Ch. of

10/8:1: Xcvr

TLK3118

TLK3134

Four-Ch. 10/8:1 Xcvr w/

(XAUI) Full Redundancy

Four-Ch. Multi-Rate Xcvr

TLK3132

TLK10021

LVDS Serdes

SN65LVDS93/94

SN65LVDS95/96

Two-Ch. Multi-Rate Xcvr

Four XAUI to XFI

1.0-1.3 Gbps

Four-Ch. 28:4 TX/RX Chipset 140-455 Mbps/Ch.

Three-Ch. 21:3 TX/RX Chipset 140-455 Mbps/Ch.

6 VML

2.5-3.125 Gbps 4X 3.125 Gbps

LVPECL (XAUI)

3.0-3.125 Gbps 4X

LVPECL

2.5-3.125 Gbps 4X 3.125 Gbps

LVPECL (XAUI)

2.5-3.125 Gbps/Ch. 4X 3.125 Gbps

LVPECL (XAUI)

0.6-3.75 Gbps 4X 3.125 Gbps

CML (XAUI)

0.6-3.75 Gbps

10 Gbps

2X 3.125 CML

1 XFI

5 LVDS

4 LVDS

4/5-Bit/Ch. (Nibble

DDR Mode), 8/10-Bit/Ch.

(Multiplex Ch. Mode)

4/5-Bit RTBI or RGMII

4X 10/8-Bit

SSTL/HSTL

20X622

LVDS Lines

4X 10/8-Bit

SSTL/HSTL (XGMII)

8/10 HSTLx4

(XGMII)

8/10 HSTLx4

(XGMII)

8/10 HSTLx2

4 XAUI

28 LVTTL

28 LVTTL

SN65LV1023A/1224B Single-Ch. 10:1 TX/RX Chipset

SN75LVDT1422 14:1 Xcvr SerDes

SN75LVDS82/83

100-660 Mbps

140 Mbps-1.4 Gbps

Four-Ch. 28:4 TX/RX Chipset 0.651 to 1.428 Gbps

SN75LVDS84A/86 Three-Ch. 21:3 TX/RX Chipset 0.42 to 1.428 Gbps

1

CML = Current Mode Logic; VML = Voltage Mode Logic.

*Suggested resale price in U.S. dollars in quantities of 1,000.

1 LVDS

1 LVDS

4 LVDS

3 LVDS

10 LVTTL

14-Bit LVTTL

28 LVTTL

21 LVTTL

Power

200 mW

300 mW

300 mW

350 mW

350 mW

<550 mW

<350 mW

<350 mW

<550 mW

1 W

200 mW

625 mW

200 mW

200 mW

200 mW

1 W

<1.5 W

700 mW/Ch.

700 mW/Ch.

600 mW/Ch.

<2 W

400 mW/Ch.

400 mW/Ch.

800 mW

Special Features

Built-In Testability

Built-In Testability

Built-In Testability and K Character Control

MicroStar Junior™ BGA

Packaging

8.40

12.60

12.60

10.50

Built-In Testability

Low Power and

Built-In Equalization

Low Power and

Built-In Equalization

16.85

12.60

10.50

Four-Channel Version of TLK1521 24.00

Four-Channel Version of TLK2521 32.00

Four-Channel Version of TLK1501 29.40

Fast Relock for PON

Supports Independent 1 and

2.5-Gbps Tx/Rx EPON OLT Channels

Industrial Temperature

JTAG; 5-Bit DDR Mode,

Industrial Temperature

Qualified

MicroStar Junior

5 mm x 5 mm LGA

JTAG, MDIO Supported

MDIO Supported

100-FX Mode Support

Web

Web

JTAG; Programmable

Pre-Emphasis and XAUI I/F

JTAG, 8b/10b On/Off

IEEE 802.3ae Backplane

Transceiver Compliant

69.30

126.00

57.75

Full Redundancy for

Four Channels (XAUI)

80.00

Built-In Ref. Clock Jitter Cleaner 35.00

Built-In Ref. Clock Jitter Cleaner

Built-In Testability

Price*

4.85

4.65

4.25

31.50

19.65

Web

Web

250 mW/Chip

250 mW/Chip

Supports Up to 1.82 Gbps

Throughout

Supports Up to 1.82 Gbps

Throughout

3.45

3.45

<400 mW Low Power Solution 4.60

<300 mW Supports Spread Spectrum Clocking 3.70

250 mW/Chip Commercial Temp 2.25

250 mW/Chip Commercial Temp 2.10

New products are listed in bold red.

Preview products are listed in bold blue.

Interface Guide

Texas Instruments 1Q 2009

DVI/PanelBus

TM

23

Design Considerations

The Digital Visual Interface (DVI)

Specification, is an industry standard developed by the Digital Display Working

Group (DDWG) for high-speed digital connection to digital displays . DVI uses transition-minimized DC balanced data signaling . Single link supports up to

165 Mpixels/s – UXGA FPDs, SXGA

DCRTs, 720p and 1080i HDTVs .

High Bandwidth Digital Content

Protection (HDCP)

• Content protection for video sent over DVI

• Implementation of HDCP requires a license from the Digital Content

Protection Licensing, L .L .C .

(www.digital-cp.com)

HDCP Elements

• Authentication is a process for verifying that a device is authorized (e .g . licensed) to handle protected content .

• Encryption prevents eavesdropping of protected content .

• Renewability enables revocation of compromised devices .

TX

Keys

I

2

C

Application

Program

Content

TMDS

Decode

HDCP

Encrypt

I

2

C

Slave IF

DVI Link

Controller

I

2

C Master

SW

Driver

DVI/HDCP implementation.

DVI TX

(PC’s DVI Output)

RX

Keys

I

2

C

TMDS

Decode

I

2

C

Slave IF

HDCP

Encrypt

Content

DVI RX

(Displays DVI Input)

EDID

PROM

PanelBus

TM

(DVI) Transmitters and Receivers

Device

TFP401

TFP401A

TFP403

TFP410

Voltage

(V)

3.3

3.3

3.3

3.3

Recvr./Trans.

Channels

3

3

3

3

Parallel

Outputs

48

48

48

6

Data

Speed

(Mbps)

495

495

495

495

I

CC

(mA)

400

400

400

250

Package

64 HTQFP

Description

100 HTQFP DVI Receiver, 165 MHz

100 HTQFP DVI Receiver, 165 MHz, HSYNC Jitter Immunity

100 HTQFP DVI Receiver

DVI Transmitter, 165 MHz

TFP501

TFP510

3.3

3.3

3

3

48

6

495

495

400

250

100 HTQFP

64 HTQFP

DVI Receiver, 165 MHz Plus HDCP

DVI Transmitter, 165 MHz Plus HDCP

*Suggested resale price in U.S. dollars in quantities of 1,000.

Price*

4.00

4.00

5.45

3.00

Web

Web

Texas Instruments 1Q 2009

Interface Guide

24

DVI/PanelBus

TM

PanelBus™ HDCP Digital Receiver

TFP501

Get samples, datasheets and app reports at:

www.ti.com/sc/device/ TFP501

The TFP501 is a TI PanelBus flat panel display product, part of a comprehensive family of end-to-end DVI 1 .0-compliant solutions . The TFP501 supports display resolutions up to UXGA, including the standard HDTV formats, in 24-bit truecolor pixel format . The TFP501 offers design flexibility to drive one or two pixels per clock, support TFT or DSTN panels and provide an option for timestaggered pixel outputs for reduced ground-bounce .

• Encrypted external HDCP device key storage for exceptional security and ease of implementation

• True color, 24 bits/pixel, 48-bit dual-pixel output mode; 16 .7/M colors at one or two pixels per clock

• 4x oversampling for reduced bit-error rates and better performance over longer cables

• Supports hot-plug detection

• Packaging: 100-pin TQFP PowerPAD™

Key Features

• Supports UXGA resolution (output pixel rates up to 165 MHz)

• Digital visual interface (DVI) and highbandwidth digital content protection

(HDCP) specification compliant

Applications

• Desktop LCD monitors

• DLP

®

and LCD projectors

• Digital TVs

TFP501 block diagram.

TI PanelBus™ Digital Transmitters

TFP510

Get samples, datasheets and app reports at:

www.ti.com/sc/device/ TFP510

The TFP510 provides a universal interface allowing a glueless connection to most commonly available graphics controllers . Some of the advantages of this universal interface include selectable bus widths, adjustable signal levels and differential and single-ended clocking .

The DVI interface supports flat panel display resolutions up to UXGA at

165 MHz in 24-bit true color pixel format .

• Fully differential and single-ended input clocking modes

• Standard Intel

®

12-bit digital video port compatible as on Intel 81x chipsets

• Programmable using I

2

C serial interface

• Monitor detection through hot-plug and receiver detection

• Packaging: 64-pin TQFP PowerPAD™

Applications

• Set-top boxes

• DVD recorders/players

Key Features

• Digital visual interface (DVI) compliant

• Supports resolutions from VGA to UXGA

(25-MHz to 165-MHz pixel rates)

• Universal graphics controller interface

• 12-bit, dual-edge and 24-bit, singleedge input modes

• Adjustable 1.1-V to 1.8-V and standard

3 .3-V CMOS input signal levels

IDCK

DATA[23:0]

DE

VSYNC

HSYNC

V

REF

EDGE/

HTPLG

MSEN

PD

ISEL/RST

BSEL/SCL

DSEL/SDA

MDA/DK2

MCL/DK1

Universal Input

12-/24-Bit

I/F

Data

Format

I C Slave I/F f or DDC

T.M.D.S. Transmitter

Encoder Serializer

Encoder

Serializer

Encoder Serializer

Control

I C Master I/F for EEPROM

TFP510 block diagram.

HDCP

Encryption

HDCP

Cipher

1.8-V Regulators with Bypass

Capacitors

PLL

TFADJ

TX2

TX1

TX0

TXC

Interface Guide

Texas Instruments 1Q 2009

TMDS (for HDMI and DVI)

Transition Minimized Differential

Signaling (TMDS) is the electrical level standard used to transmit Digital Visual

Interface (DVI) and High-Definition

Multimedia Interface (HDMI) data .

Design Considerations

Intra-Pair Skew – The time difference between the true and complementary signals of a given differential pair should be kept as small as possible .

Residual Jitter – The difference in the amount of measured jitter between the test point and the signal source . It is the allowable maximum residual jitter equivalent to the minimum jitter budget between transmitter and receiver .

TMDS

ESD – External connectors being exposed to the outside world are especially susceptible to electrostatic discharge . A higher ESD rating provides improved protection .

25

PC

STB

DVD

TMDS361 3-to-1 Mux.

Rx1

Allows Distant Connection to Connector Socket

Rx

TV

TV

Game

Console

STB

DVD

PC

TMDS442 4-to-2 Mux.

Rx1

Rx2

Main Picture

TV

Picture in


TMDS141 HDMI Hider.

Device

TMDS141

TMDS361

TMDS442

Description

HDMI Hider

3-to-1 DVI/HDMI Switch

4-to-2 DVI/HDMI Switch

No. of

Inputs

1

3

4

No. of

Outputs

1

1

2

Intra-Pair (ps)

Skew

(max)

50

40

50

Inter-Pair

Skew

(max) (ps)

100

100

100

I

CC

(max)

(mA)

150

215

550

ESD

HBM

(kV)

5

12

5

Package(s)

40QFN

64TQFP

128TQFP

TS3DV416

TS3DV520E

2-to-1 Switch for HDMI/DVI

2-to-1 Switch for HDMI/DVI

2

2

1

1

0.6

0.6

2

14

*Suggested resale price in U.S. dollars in quantities of 1,000.

48TSSOP, 48TVSOP

56QFN, 42QFN

Price*

1.75

Web

3.45

0.90

1.05

Texas Instruments 1Q 2009

Interface Guide

26

USB Hub Controllers and Peripheral Devices

Universal Serial Bus (USB)

The USB standard defines a bus product that requires a host controller and enables plug-and-play connectivity .

The most recently released final specification, USB 2 .0, defines high speed and allows complete backward compatibility with USB 1 .1 .

USB products fall into three categories: hubs, host controllers and peripherals .

USB 1 .1 supported speeds of up to

12 Mbps and cables up to 5 meters long for these devices . USB 2 .0 extends the connection speed to 480

Mbps to support next-generation peripherals of higher-performance PCs and applications . USB 2 .0 officially defines three speeds: low (1.5 Mbps), full (12 Mbps) and high (480 Mbps) .

The lowest speed is ideal for human interface devices such as a mouse, game pad or keyboard; while full speed is well suited for “data dumps” to the

PC via digital still cameras, PDA cradles and flash-card readers . Modems, printers, scanners and storage drives are just a few of the items that can take advantage of USB’s highest speed specification .

The USB On-The-Go (OTG) supplement to USB 2 .0 specifies a new class of devices aimed at the portable market . USB OTG defines devices that can operate as standard

USB peripherals when connected to a standard USB host controller .

However, these same devices can operate as reduced-function host controllers to support selected

USB OTG peripheral devices . Endequipment manufacturers can specify what type of peripherals their devices will support when in OTG host mode .

This new specification allows easy sharing of contact information between

USB OTG PDAs and cell phones or printing of photographs directly from an OTG-enabled digital still camera without a PC .

Technical Information

Speed

• The USB 2.0 standard defines three speeds: low speed (LS) 1.5 Mbps, full speed (FS) 12 Mbps and high speed (HS) 480 Mbps . It requires full backward and forward compatibility for devices and cables . All three modes offer both asynchronous and isochronous (real-time) data transmission over a simple and inexpensive 4-wire cable to meet requirements of peripherals including keyboards, mice, printers, speakers, scanners, external storage devices and digital still cameras .

Transfer Type

• USB 2.0 defines four types of transfers: bulk, control, interrupt and isochronous . Bulk transfer is intended for applications such as printers, scanners and mass storage, where latency isn’t critical but accuracy is . All devices must include control transfers for configuration . Interrupt transfer is for devices such as mice, keyboards and game pads that must receive the host’s or device’s attention periodically . Isochronous transfer offers guaranteed delivery time but no error-checking or automatic retransmission of data received with errors, making it the better choice for audio or video applications .

RS232/lrDA Serial-to-USB Converter

TUSB3410

Get samples, datasheets, evaluation modules and app reports at:

www.ti.com/sc/device/ TUSB3410

USB-to-Serial Bridge

The TUSB3410 provides an easy way to move a serial-based legacy device to a fast, flexible USB interface by bridging between a USB port and an enhanced UART serial port . The

TUSB3410 contains all the necessary logic to communicate with the host computer using the USB bus .

Key Features

• USB full-speed compliant: data rate of 12 Mbps

• 8052 microcontroller with 16 Kbytes of RAM that can be loaded from the host or from external onboard memory via an I

2 C bus

• Integrated, enhanced UART features including:

Programmable software/hardware flow control

Automatic RS-485 bus transceiver control, with and without echo

Software-selectable baud rate from

50 to 921 .6 kbaud

Built-in, two-channel DMA controller for USB/UART bulk I/O

• Evaluation module to jump-start

USB development or for use as a complete USB-to-RS232 converter

Host

(PC or OTG DRD)

Out

USB

In

TUSB3410

S

OUT

S

IN

Legacy

Serial

Peripheral

Applications

• Handheld meters

• Health metrics/monitors

• Any legacy serial device that needs to be upgraded to USB

TUSB3410 data flow.

Interface Guide

Texas Instruments 1Q 2009

USB Hub Controllers and Peripheral Devices

27

USB Devices

USB Hub Controllers

TUSB2036

TUSB2046B

TUSB2077A

TUSB2136

TUSB5052

USB family of products.

USB Peripherals

TUSB3210

TUSB3410

TUSB6250

USB OTG

TUSB6020

USB PHY

TUSB1105

TUSB1106

TUSB2551

USB Selection Guide

Device Speed

USB Hub Controllers

TUSB2036 Full (1.1)

TUSB2046B

TUSB2077A

TUSB2136

TUSB5052

Full (1.1)

Full (1.1)

Full (1.1)

Full (1.1)

Ports I

2

C

2/3

4

7

1/2

1-5

Voltage

(V)

No

No

No

Yes

Yes

Voltage

(V)

3.3

3.3

3.3

3.3

3.3

Remote

Wakeup

Package

32 LQFP

32 LQFP

48 LQFP

64 LQFP

100 LQFP

Description

2/3-Port Hub for USB with Optional Serial EEPROM Interface

4-Port Hub for USB with Optional Serial EEPROM Interface

7-Port USB Hub with Optional Serial EEPROM Interface

2-Port Hub with Integrated General-Purpose Function Controller

5-Port Hub with Integrated Bridge to Two Serial Ports

Price*

1.15

1.20

1.95

3.25

5.10

Device

USB Peripherals

TUSB3210

TUSB3410

TUSB6015

TUSB6250

Speed

Full

Full

High

Full, High

3.3

3.3

1.5, 1.8, 3.3

3.3

Voltage

(V)

Yes

Yes

Yes

Yes

Package

64 LQFP

32 LQFP

80 BGA

80 TQFP

Local Bus

Interface

Description

USB Full-Speed General-Purpose Device Controller

USB-to-Serial Converter (RS-232, RS-485)

USB 2.0 High-Speed to Muxed NOR Flash Bridge Controller

USB 2.0 High-Speed, Low-Power ATA/ATAPI Bridge Solution

Price*

2.50

2.25

2.80

Device Speed

USB On-The-Go (OTG)

TUSB6020 High 1.5, 1.8, 3.3

Package(s)

80 QFP VLYNQ™

Description

USB 2.0 High-Speed On-The-Go to Local Bus Interface Controller

Price*

Web

Device

USB Transceivers

TUSB1105

TUSB1106

TUSB2551

Speed

Full, Low

Full, Low

Full, Low

Voltage

(V)

1.6, 3.6

1.6, 3.6

1.6, 3.6

Package(s)

16RTZ, 16RGT

16RTZ, 16PW

14PW, 16RGT

Single ended

Input

Yes

No

No

Description

USB Transceivers

USB Transceivers

USB Transceivers

*Suggested resale price in U.S. dollars in quantities of 1,000.

USB Port Protection –

Transient voltage suppressor protects USB 1.1 devices from ESD and electrical noise transients.

Device Description

USB Port Protection

SN65220 Single Suppressor

SN65240 Dual Suppressor

SN75240 Dual Suppressor

*Suggested resale price in U.S. dollars in quantities of 1,000.

Temp Range

(°C)

–40 to 85

–40 to 85

0 to 70

Price*

0.33

0.41

0.38

Price*

Web

Web

Web

Resources

For a complete list of resources (evaluation modules, data sheets and application notes), visit interface.ti.com

Literature Number Description

Application Notes

SLLA122 Selection and Specification of Crystals for Texas Instruments USB

2.0 Devices

SLLA154 VIDs, PIDs and Firmware: Design Decisions When Using TI USB

Device Controllers

SLLU043

SLLA170B

SLLAA276

TUSB3410 UART Evaluation Board

USB/Serial Applications Using TUSB3410/5052 and the VCP Software

MSP430 USB Connectivity Using TUSB3410

Texas Instruments 1Q 2009

Interface Guide

28

Universal Serial Bus (USB) Power Managers

Design Considerations

USB High-Power Peripheral Switch with Dual Current Limit + LDO

TPS2140/41/50/51

The TPS2140/41/50/51 target high-power

USB peripherals such as ADSL modems .

The devices contain a power switch and an LDO . The dual-current-limiting switch allows the use of high-value capacitance to stabilize the voltage from the USB bus .

Dual Power Switch + LDO for USB

Bus-Powered Peripherals and Hubs

TPS2148/49 – TPS2148 is a complete power management solution for USB bus-powered peripherals such as zip

Power

Supply

5 V

GND

TPS2550

IN OUT

GND

EN

ILIM

FAULT

Port EN

Fault In

USB

Controller

DP1

DM1

R

ILIM

15 kΩ

Typical application diagram.

5 V

GND

Port 1

D+

D–

drives, while TPS2149 is for USB buspowered hubs, such as keyboards with integrated hubs . TPS2148/9 each combine a 3 .3-V LDO and dual power switch in a single MSOP package . The

TPS2148 switch configuration allows power and board capacitance segmentation to meet USB system current requirements . The TPS2149 switches manage two independent or four ganged USB ports .

4-Port USB Hub Power Controllers

TPS207x – The TPS207x family provides the complete power solution for 4-port self-powered, bus-powered or hybrid

USB hubs by incorporating current-limited switches for four ports, a 3 .3-V 100-mA

LDO, a 5-V LDO controller for self power

(TPS2070, TPS2071) and a DP0 line control to signal an attach to the host .

USB Current-Limiting Power Switches

Power switches are used to intelligently turn power on/off and provide fault protection . They are ideal for power sequencing or segmentation and when controlled allocation of power is needed to circuit blocks, modules, add-in cards or cabled connections .

Universal serial bus (USB) ports are great examples of where this intelligent protection is vital for protecting your power supply and achieving regulatory compliance . TI’s family of low-cost power switches are ideal for USB port designs .

To minimize voltage drop, select devices with the lowest r

DS(on) on-resistance .

or Drain-to-Source

Power Distribution Switches

The low-cost and low r

DS(on)

currentlimiting power switch families meet all the USB power management requirements for controlling downstream ports, and include additional features to improve the design reliability .

4

3

2

1

TPS2048A

TPS2058A

TPS2044B

TPS2054B

TPS2047B

TPS2057A

TPS2043B

TPS2053B

TPS2063

TPS2067

TPS2046B

TPS2056A

TPS2045A

TPS2055A

TPS2049

TPS2042B

TPS2052B

TPS2041B

TPS2051B

TPS2550 Adjustable

TPS2062

TPS2066

TPS2061

TPS2065

0.5

1 1.5

Typical Current Limit (A) r

DS(on)

= 70 mW

Low-cost power switch matrix.

TPS2060

TPS2064

TPS2068

TPS2069

2

New

Typical

Package

Options:

SOIC

MSOP

SOT23

Enable

Polarity

Reverse

Blocking

High

Yes

TPS2030 TPS2031 TPS2032 TPS2033 TPS2034

Low

Yes

TPS2020

TPS2021 TPS2022 TPS2023 TPS2024

Low

No

TPS2010A

TPS2011A TPS2012A TPS2013A

0.2

0.6

1.0

1.5

Low r

Typical Current Limit (A) r

DS(on)

= 33 mΩ

DS(on)

power switch roadmap.

2.0

Dual power switch + LDO for USB bus-powered peripherals and hubs.

Interface Guide

Texas Instruments 1Q 2009

Universal Serial Bus (USB) Power Managers

USB Power Switch Selection Guide

Device

Number of FETs

I

(min) (A)

USB Power Distribution Switches

TPS2010A 1 0.22

TPS2011A

TPS2012A

TPS2013A

TPS2020/30

TPS2021/31

TPS2022/32

TPS2023/33

TPS2024/34

TPS2041B/51B

TPS2042B/52B

TPS2043B/53B

TPS2044B/54B

TPS2045A/55A

TPS2046B/56A

TPS2047B/57A

TPS2048A/58A

TPS2049

TPS2550/51

TPS2060/4

TPS2061/5

TPS2062A/6

TPS2063/7

TPS2068/9

TPS2080/1/21

TPS2085/6/71

2

1

2

1

1

3

4

2

4

3

1

4

1

2

2

3

1

1

1

1

1

1

1

1

1

0.3 ea

0.3 ea

0.1

0.1 to 1.1

1.5 ea

1.1

1.1 ea

1.1 ea

1.5

0.7 ea

0.7 ea

2.2

0.7

0.7 ea

0.7 ea

0.7 ea

0.3

0.3 ea

0.66

1.1

1.65

0.22

0.66

1.1

1.65

r

DS(on)

(mW)

70

70

80

80

70

70

70

80

80

400

85

70

80

80

33

70

70

70

33

33

33

30

30

30

30

33

V

IN

Range

(V)

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.5 to 6.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

2.7 to 5.5

Supply

Current

(µA)

65

43

85

85

50

43

50

160

160

43

130

75

80

80

73

43

50

65

73

73

73

73

73

73

73

73

OC Logic

Output

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

No

No

No

No

Yes

OT Logic

Output

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

No

No

No

No

Yes

Enable

L/H

L/H

L

L/H

L/H

L/H

L/H

L/H

L/H

L/H

L/H

L/H

2H, 1L/1H, 2L

4H, 2L/2H, 4L

L/H

L/H

L/H

L/H

L/H

L/H

L/H

L

L

L

L

L/H

Predecessor

TPS2010

TPS2011

TPS2012

TPS2013

TPS2014

TPS2015

TPS2041/51/41A/51A

TPS2042/52/42A/52A

TPS2043/53/43A/53A

TPS2044/54/44A/54A

TPS2045/55

TPS2046/46A/56

TPS2047/47A/57

TPS2048/58

TPS2041/51/41A/51A

TPS2062

Price*

TPS2090/1/21 2 0.3 ea 80 2.7 to 5.5

85 Yes Yes 2H, 1L/1H, 2L — 0.65

TPS2095/6/71 4 0.3 ea 80 2.7 to 5.5

85 Yes Yes 4H, 2L/2H, 4L — 1.05

1

Can be configured as power MUX ICs. New products are listed in bold red.

*Suggested resale price in U.S. dollars in quantities of 1,000.

Bus Powered Self Powered

Device Application

Number of

FETs

Switch

Enable

Bus Power

Indicator

(BPMODE)

(min)

(V)

V

IN

(max)

( V) r

DS(on) per FET

(typ) (mW)

Current

Limit

(min) (A) r

DS(on) per FET

(typ)

(mW)

Current

Limit

(min) (A)

LDO

Controller

(A) LDO Price*

USB Power Controllers

TPS2070 USB 4-Port Hub 8 L 1L 4.5

5.5

560 0.12

107 0.6

5 V, 3 A 3.3 V, 100 mA 2.55

TPS2071 USB 4-Port Hub

TPS2074 USB 4-Port Hub

8

8

L

L

1H

1L

4.5

4.5

5.5

5.5

560

500

0.12

0.12

107

100

0.6

0.6

5 V, 3 A

3.3 V, 100 mA

3.3 V, 100 mA

2.55

2.55

TPS2075 USB 4-Port Hub

TPS2140 USB Peripheral

TPS2141 USB Peripheral

TPS2150 USB Peripheral

TPS2151 USB Peripheral

TPS2145 DSP, PDA

TPS2147 DSP, PDA

1

2

2

1

1

8

1

TPS2148 USB Peripheral

TPS2149 USB 2-Port Hub

TPS2155 DSP, PDA

TPS2157 DSP, PDA

2

2

2

2

TPS2158 USB Peripheral

TPS2159 USB 2-Port Hub

2

2

*Suggested resale price in U.S. dollars in quantities of 1,000.

H

H

H

H

L

L

H

L

L

L

H

L

L

1H

2.9

2.9

2.9

2.9

2.9

2.9

4.5

5.5

2.7

5.5

4 5.5

2.7

5.5

4 5.5

2.9

5.5

2.9

5.5

5.5

5.5

5.5

5.5

5.5

5.5

340

340

340

340

340

340

500

70

70

70

70

340

340

0.2

0.2

0.2

0.2

0.2

0.2

0.12

0.1 & 1.2

0.1 & 1.2

0.1 & 1.2

0.1 & 1.2

0.2

0.2

100

0.6

3.3 V, 100 mA 2.55

Adj. 0.9 to 3.3 V, 250 mA 1.10

Adj. 0.9 to 3.3 V, 250 mA 1.10

Adj. 0.9 to 3.3 V, 250 mA 1.10

Adj. 0.9 to 3.3 V, 250 mA 1.10

3.3 V, 200 mA 1.15

3.3 V, 200 mA 1.10

3.3 V, 200 mA

3.3 V, 200 mA

3.3 V, 200 mA

3.3 V, 200 mA

3.3 V, 200 mA

3.3 V, 200 mA

0.99

0.95

1.15

1.10

0.99

0.95

Texas Instruments 1Q 2009

Interface Guide

1.20

0.60

0.75

0.90

0.60

0.65

1.05

1.00

0.60

0.65

0.90

1.20

0.50

0.70

1.05

1.05

1.05

1.05

0.50

0.70

0.90

0.75

0.75

0.75

0.75

1.05

29

30

PCI Express

®

Design Considerations

PCI Express

®

(PCIe) takes the best features and ideas behind PCI and combines them with more than 10 years of industry “lessons learned .” The result is a robust, scalable, flexible, costeffective I/O interconnect that will serve the industry for many years to come .

Key Features

• PCIe architecture is an industry standard high-performance, general-purpose serial I/O interconnect designed for use in enterprise, desktop, mobile, communications and embedded platforms .

• It is PCI-compatible by using the established PCI software programming models . PCIe facilitates a smooth transition to new hardware and allows software to evolve and leverage the advantages of PCIe features .

• Gen I has a scalable bandwidth of

8 GBps at its initial signaling rate of

2 .5 GHz . With the release of Gen II, higher transfer rates are achieved using higher frequency signaling technologies .

• Supports multiple interconnect widths via x1, x2, x4, x8, x12, x16 and x32 lane configurations aggregated to match application bandwidth needs .

• Serves new and innovative, hot-plug/ hot-swap add-in card and module devices .

• Delivers unique, advanced features such as power management, quality of service and other native functions not available in other I/O architectures .

PCI Express-PCI

Bridge

PCI Express

PCI/PCI-X

PCI Express

Endpoint

PCI Express

PCI Express

®

topology.

CPU

Root

Complex

PCI Express ®

PCI Express

Bridge

XIO2000A

PCI Express

Switch

XIO3130

PCI Express

Endpoint

XIO2200A

XIO2213A

Current TI PCI Express

®

portfolio.

Memory

PCI

Express

Legacy

Endpoint

PCI Express

Switch

PCI

Express

PCI

Express

PCI Express

Endpoint

PCI Express

Endpoint

PCI Express

®

Portfolio

PCI Express

PHY

XIO1100

PCI Express

Signal

Switch

TS2PCIE2212

TS2PCIE412

Interface Guide

Texas Instruments 1Q 2009

PCI Express

®

31

4-Lane, 4-Port PCIe Switch

XIO3130

Get samples, datasheets, evaluation modules and app reports at:

www.ti.com/sc/device/ XIO3130

TI’s XIO3130 is an integrated PCIe fan-out switch solution with one upstream x1 port and three downstream x1 ports . This highperformance, integrated solution provides the latest in PCIe switch technology . It features cut-through architecture and integrated reference clock buffers for downstream ports . The XIO3130 is fully-compliant with the PCI Express Base Specification Rev . 1 .1 .

It supports Advanced Error Reporting as defined in the PCIe base specifications and is backwards compatible with the PCI Local

Bus Specification, Rev . 2 .3 .

PCIe Hot-Swap Manager

TPS2363

Get samples and datasheets at:

www.ti.com/sc/device/ TPS2363

In complex, high-reliability systems, it may be necessary to allow for insertion and removal of PCIe peripherals while the bus voltage is active . A hot-swap power-management solution is required in these designs to ensure inserting and removing these does not damage the bus or the card – or cause the system or other peripherals to reset as a result of bus voltage droops or spikes .

Key Features

• PCIe fan-out switch with x1 upstream port and three x1 downstream ports

• Fully compliant with PCIe Base Specification, Rev. 1.1

• Cut-through architecture

• Built-in adaptive equalizer in each of the four ports

• Wake-event and beacon support

• Support for D1, D2, D3 hot

, and D3 cold

• Active State Power Management (ASPM)

• Uses both L0s and L1

• Low-power PCIe transmitter mode (pre-emphasis disabled)

• Integrated AUX power switch drains VAUX power only when main power is “off”

• Integrated hot-plug support

• Integrated REFCLK buffers for switch downstream ports

• Advanced error Reporting to assist with system debug tools

• 3.3-V Multifunction I/O pins (e.g., for hot-plug status-and-control, or general-purpose I/Os)

• Listed in PCI-SIG compliance list

Target Market

The primary purpose of the XIO3130 as a fan-out device is efficiently expanding the chipset’s computing resources to multiple I/O ports and enhancing system functionality and flexibility . Target applications for the XIO3130 include PCs, servers, storage, industrial control and backplane .

2.5 Gbps 2.5 Gbps

12 V

3.3 V

AUXINA

Direct Mode

Control A

Switches A

SMBus

Switches B

Direct Mode

Control B

AUXINB x1 PCI Express

®

Upstream PHY Interface

Digital Link Layer

Transaction Layer:

Crossbar Switch & Packet Control

The TPS2363 is a host-side, dual-slot PCIe hot-swap controller that provides this functionality . The TPS2363 has an onboard SMBus interface for control and monitoring functions and sense resistor programmable current limits for the 3 .3-V and 12-V supplies .

Key Features

• Meets PCIe hot-plug requirements

• Programmable 12-V current limit

• Inrush current limiting

• SMBus interface and direct mode available

• VAUX internal FET

• General-purpose inputs

• Available in a 48-pin TQFP package; fits between the

PCIe connectors

By 1 50 mΩ

By 4/8 20 mΩ

By 16 10 mΩ

AUXHIA

FORCEONA

AUXENA

ONA

GPIA1

GPIA2

A2

A1

A0

SDA

SCL

GPIB1

GPIB2

AUXHIB

ONB

AUX ENB

FORCEONB

13 mΩ

PFB 48 PIN

TQFP

G33A OUT33A

INT

FILTER A

RFILTERA/B

FILTER B

AUXINA

AUXINB

12 V AOUT

3.3 V AOUT

VAUXA

PGOODA

FAULTA

Interrupt

FAULTB

PGOODB

VAUXB

12 V

12 V BOUT

Port Logic Port Logic Port Logic

By 1 50 mΩ

By 4/8 20 mΩ

By 16 10 mΩ

13 mΩ

3.3 V BOUT

3.3 V

PHY Port 0 PHY Port 1 PHY Port 2

Typical application diagram.

Texas Instruments 1Q 2009

Interface Guide

32

PCI Express

PCIe Signal Switch

TS2PCIE412

Get samples and datasheets at:

www.ti.com/sc/device/ TS2PCIE412

The PCIE412 is a x1 4-channel PCIe 2:1

Multiplexer/Demultiplexer passive FET one PCIe data lane between two possible destinations or two PCIe data lanes to one destination . Each representing differential pairs of receive (RX) and transmit (TX) signals can be routed through a single PCB skew and operates at a signal-processing bandwidth speed of 2 .5 Gbps . The device is controlled with one select input pin which controls the data path of the mux/demux and can be connected to any GPIO in the system, using an external voltage divider system .

Key Features

• Compatible with PCIe Gen-1 Standard

• Low R

ON

and C

ON

assuring maximum signal transfer while maintaining low distortion

• Low Crosstalk of –40 dB minimizing transmission noise

• Low channel-to-channel and bit-to-bit skew optimizing synchronization on the signal path

• 42-pin QFN package

Target markets

Target applications include computing

(desktop and notebook), servers and telecom or where PCIe is used .

PCI Express Selection Guide

Device

Supply

Voltage (V)

PCI Express PHY

XIO1100 3.3, 1.8, 1.5

PCIe

x1

Parallel Bus

Width

8, 16

A

0

A

1

A

2

A

3

2

3

6

7

A

4

A

5

A

6

A

7

11

12

15

1 6

SEL

9

Control Logic

33

32

31

29

28

27

26

25

24

23

22

38

37

36

35

34

0

B

2

1

B

2

2

B

2

3

B

2

4

B

1

5

B

1

6

B

1

7

B

1

4

B

2

5

B

2

6

B

2

7

B

2

0

B

1

1

B

1

2

B

1

3

B

1

TS2PCIE412 functional diagram.

Expected release date, March 2009.

Speed (max)

(Gbps)

MicroStar BGA™

Packaging Package Description

Device

Supply

Voltage (V)

PCI Express Bridge

XIO2000A 3.3, 1.5

PCIe

x1

PCI Bus

Masters

6

2.5

Yes 100 BGA x1 PCI Express PHY, Compliant with the PCI

Express Base Specification Revision 1.1

Wake/Beacon

Support

MicroStar BGA™

Packaging Package Description

PCIe FIFO (KB)

Yes Yes 175 BGA

201 BGA x1 PCI Express to PCI Bus Translation Bridge

Speed (max)

(Mbps)

MicroStar BGA™

Packaging Package Description Device

Supply

Voltage (V)

PCI Express Endpoints

XIO2200A 3.3, 1.5

XIO2213A 3.3, 1.95, 1.5

x1 x1

9

8

400

800

Yes

No

175 BGA

176 BGA

PCI Express to PCI Bus Translation Bridge with

1394a OHCI and Two-Ports

167 BGA PCI Express to 1394b OHCI with Three-Port PHY

Price

*

7.00

Price

*

10.50

Price

*

7.75

8.70

Device

Supply

Voltage (V)

PCI Express Packet Switch

XIO3130 3.3, 1.5

PCIe

x1

Downstream

PCIe Ports

3

Wake/Beacon

Support

Yes

MicroStar

BGA™

Packaging

Yes

Package Description

196 BGA x1 PCI Express 4-Port Fanout Packet Switch

Price

*

Call

Device

No. of

Inputs

No. of

Outputs

Supply

Voltage

Range (V) r

ON

(typ)

(Ω) tpd (typ) (ns)

MicroStar

BGA™

Packaging Package Description Price

*

PCI Express Signal Switches**

TS2PCIE2212

TS2PCIE412

2

2

1

1

1.7 - 1.9

1.5 - 2.1

10

12.5

0.25

0.25

No

No

48 BGA 2-Channel PCIe 2:1 Multiplexer/Demultiplexer

Passive FET Switch

42 QFN 4-Channel PCIe 2:1 Multiplexer/Demultiplexer

Passive FET Switch

1.61

Preview

*Suggested resale price in U.S. dollars in quantities of 1,000. Preview products are listed in bold blue.

**For additional TI switches, visit www.ti.com/switches

Interface Guide

Texas Instruments 1Q 2009

PCI Bridges

Design Considerations

Peripheral Component Interconnect (PCI) is an interconnection system between a microprocessor and attached devices in which expansion slots are spaced closely for high-speed operation . A PCI-to-PCI bridge is a high-performance connection path between two PCI buses that allows bridge transactions to occur concurrently on both buses . Burst-mode transfers maximize data throughput while the two bus traffic paths through the bridge act independently . In future systems, many PCI bus structures will be replaced by the new serial PCI Express architecture . TI is actively developing a portfolio of PCI Express products to address this market .

Key Features

• Two 32-bit, 33- or 66-MHz buses

• Configurable for PCI powermanagement interface specification

• CompactPCI hot-swap functionality

• 3.3-V core logic with 3.3- to 5-V PCI signaling compatibility

• Intel

®

bridge compatibility

• Transparent bridging

CPU

Host Bus

Memory

Host

Bridge

PCI Bus 0

PCI

Device

PCI

Device

Technical Information

Capabilities

• TI’s PCI2050B is a 32-bit, 66-MHz bridge with internal two-tier arbitration for up to 9 secondary bus masters and support for an external secondary bus . There are independent read/ write buffers for each direction and 10 secondary PCI clock outputs .

Functionality

• The PCI2250 is a 33-MHz bridge similar to the PCI2050B but supports

4 secondary bus masters and 5 secondary PCI clock outputs .

PCI Bridges

PCI2050B

PCI2250

PCI2060

PCI bridge family of products.

PCI2050B

PCI Bus 1

PCI Bus 2

PCI2050B

PCI

Device

PCI Option Slot

Typical PCI-to-PCI bridge system application.

PCI

Device

PCI Option Card

PCI Option Card

(Option)

33

PCI Bridges Selection Guide

Device

PCI Bridges

Intel-

Compatible

Part No.

Speed

(MHz)

PCI2050B 21150bc 66

Expansion

Interface

(Bits)

PCI2250 21152ab 33

PCI2060 — 66

*Suggested resale price in U.S. dollars in quantities of 1,000.

32

32

32

Hot

Swap

MicroStar

BGA™

Packaging

Voltage

(V)

Yes

Friendly

Yes

Yes

No

Yes

Package(s) Description

3.3, 5

3.3, 5

3.3, 5

208 LQFP,

208 QFP, 257 BGA

176 LQFP,

160 QFP

257 BGA

32-Bit, 66-MHz, 9-Master PCI-to-PCI Bridge

32-Bit, 33-MHz PCI-to-PCI Bridge, Compact

PCI Hot-Swap Friendly, 4-Master

32-Bit, 66-MHz, 9-Master, Asynchronous

PCI-to-PCI Bridge

Price

*

9.50

6.10

9.50

Resources

For a complete list of resources (evaluation modules, data sheets and application notes), visit interface.ti.com

Application Notes

Application Notes

Literature Number Description

Literature Number Description

SCPA029A Adding Debounce Logic to /HSSwitch Terminal

SCPA030 Interfacing the PCI2040 to the TMS320VC5420 DSP

SLLA067 Comparing Bus Solutions

SPRA679 Texas Instruments TMS320VC5409/5421 DSP to PCI Bus

SCPA027 Connecting ENUM Terminal to an External Open-Drain Buffer

Texas Instruments 1Q 2009

Interface Guide

34

CardBus Power Switches

Design Considerations

ExpressCard Power Switches

The TPS2231 and TPS2236 ExpressCard power interface switches provide the total power management solution required by the ExpressCard specification . The

TPS2231 and TPS2236 ExpressCard power interface switches distribute 3 .3 V,

AUX and 1 .5 V to the ExpressCard socket .

Each voltage rail is protected with integrated current-limiting circuitry . The

TPS2231 supports systems with singleslot ExpressCard/34 or ExpressCard/54 sockets . The TPS2236 supports systems with dual-slot ExpressCard sockets .

PCMCIA/CardBus Power Switches

Standard PC cards require that V

CC

be switched between ground, 3 .3 V and 5 V, while V

PP

is switched between ground,

3 .3 V, 5 V and 12 V . CardBay sockets have the standard requirements for

V

CC

, but require ground, 3 .3 V and 5 V to V

CC

V

, and ground, 1 .8 V or 3 .3 V to

CORE

. Other PC card applications may simply not need 12 V or V

PP

while still having the standard requirements for

V

CC

. Therefore, consider the voltage requirements of the application when selecting a PCMCIA power switch .

Power MUX ICs

Power MUX ICs are designed to transition from a main power supply to an auxiliary source when the main supply shuts down

(e .g ., switching from battery operation to a wall adapter) .

For more information on these and other switches, please see the USB current-limiting power switches on page 28.

Current-Limiting Power Switches

Power switches are used to intelligently turn power on and off, while providing fault protection . They are useful anywhere controlled allocation of power is needed to circuit blocks, modules, add-in cards or cabled connections .

They are ideal for power sequencing or segmentation .

To minimize voltage drop, select devices with the lowest r

DS(on) on-resistance .

or Drain-to-Source

Interface Guide

TPS2211A

• Fully integrated V

CC

and V

PP switching for single-slot PC card interface

• Low r

DS(on)

• 3.3-V low-voltage mode

• Short-circuit and thermal protection

• Compatible with 3.3-V, 5-V and 12-V

PC cards

12 V

5 V

3.3 V

0.1 mF

+

0.1 mF

+

0.1 mF

+

12 V

TPS2211A

AVCC

AVCC

AVCC

AVPP

5 V

5 V

3.3 V

3.3 V

GND

VCCD0

VCCD1

VPPD0

VPPD1

OC

SHDN

0.1 mF

0.1 mF

To CPU

V

CC1

V

CC2

V pp1

V pp2

PC Card

Connector

PCMCIA

Controller

VCC_EN0

VCC_EN1

VPP_EN0

VPP_EN1

CS

ExpressCard Power Switch ICs

Device Ports

TPS2231 1

3-V r

DS

(on)

(mΩ)

45

TPS2236 2 45

Shutdown Signal From CPU

Typical PC card power-distribution application.

Interface

Parallel

Parallel

Current Limit (Min) (A)

2.5

2.5

PCMCIA/CardBus Power Switch Matrix ICs

Current Limit (min) (A)

0.3

0.7

3.3 V, 5 V, 12 V, V

PP

Dual —

Single TPS2212

1.0

2.5

TPS2224(A), TPS2226(A), TPS2204A, TPS2206A, TPS2205 —

TPS2204A, TPS2210A, TPS2211(A), TPS2220A, TPS2220B TPS2231

12 V, 5 V, 12 V, V

PP

Dual

Single

No V

PP

Dual

— TPS2223A

TPS2044B/54B —

TPS2044B/54B —

TPS2236

Power MUX ICs

Configuration

IN1

IN2

Device

TPS2100/1

TPS2102/3

TPS2104/5

TPS2110A

TPS2111A

TPS2112A

TPS2113A

TPS2114A

TPS2115A

I

OUT

(mA)

IN1: 500, IN2: 10

IN1: 500, IN2: 100

IN1: 500, IN2: 100

Adj. 310 to 750

Adj. 630 to 1250

Adj. 310 to 750

Adj. 630 to 1250

Adj. 310 to 750

Adj. 630 to 1250

Transition

Manual

Manual

Manual

Auto/Manual

Auto/Manual

Auto

Auto

Auto/Manual

Auto/Manual

Comments

SOT-23, 0 to 70°C

SOT-23, 0 to 70°C

SOT-23, –40 to 85°C

TSSOP

TSSOP

TSSOP, Status Pin

TSSOP, Status Pin

TSSOP, Status Pin

TSSOP, Status Pin

CableCARD™ Power Requirements

Many consumer set-top boxes today require the implementation of CableCARD compliant slots, similar to PCMCIA Type II cards . These CableCARD-compliant slots enable third-party equipment to be used with telecommunications service provider networks . TI’s TPS2223A, TPS2221 and other switches are ideal to provide the various power requirements for many

CableCARD applications .

Host

Power

Source

Host

Control

Logic

3.3 V

5 V

TPS2223A

V

CC

V

PP1

V

PP2

DATA

CLOCK

LATCH

SHDN

FAULT

GND

Typical CableCARD application.

CableCARD™

Texas Instruments 1Q 2009

Power Distribution

(PCMCIA/CardBus Power Switches, Current-Limiting Power Switches and Power MUX ICs)

35

TPS2204A

TPS2220B

TPS2223A

TPS2224A

TPS2226A

TPS2206A

TPS2205

TPS2211A

TPS2212

TPS2231

TPS2044B or 54B

TPS2221

TPS2228

Device Interface

PCMCIA/CardBus Switch Matrix ICs

TPS2210A 3-Line Serial

3-Line Serial

3-Line Serial

3-Line Serial

3-Line Serial

3-Line Serial

3-Line Serial

8-Line Parallel

4-Line Parallel

4-Line Parallel

4-Line Parallel

Parallel

Interface Parallel

Interface Serial

Number of Ports

1

1 or 2

1

2

1

1

2

2

2

2

1

2

1

2

3.3-V r

DS(on)

I

(typ) (mW)

OS

68

80

72

72

85

70

70

160

85

85

85

85

85

85

5.0-V r

DS(on)

(typ) (mW)

80

97

97

95

100

57

160

95

95

95

95

95

95

I

OS

(min) (A)

1

1

2.5

0.7

1

0.3

1

1

1

1

1

1

1

1

Predecessor

TPS2214/14A

TPS2220A

TPS2214/14A

TPS2206, TPS2216/16A

TPS2206, TPS2216/16A

TPS2201

TPS2211

TPS2044/44A, TPS2054/54A

Price*

Device

Power MUX ICs

TPPM0301/2

Number

of

Inputs

3

r

IN1 ds(on)

(mΩ)

r

IN2 ds(on)

(mΩ)

IN1 Output

Current

(mA)

IN2

Output

Current

(mA)

IN1

Supply

Current

(µA)

IN2

Supply

Current

(µA)

Input

Voltage

Range (V)

Transition Time

IN1 to IN2

(µs)

IN2 to IN1

(µs) Transition Price*

TPPM0303

TPS2100/1

TPS2102/3

TPS2104/5

2

2

3

2

250

1300

400

250

500

400

250

10

100

2500

2500

10

250

250

0.75

3 to 5.5

3 to 5.5

2.7 to 4.0

4

900

Autoswitch 1.60

Autoswitch 1.07

L/H enable 0.59

TPS2110A/2A/4A 2

250

250

120

1300

1300

120

500

500

312 to 750

100

312 to

750

14

18

85

0.75

0.75

85

2.7 to 4.0

2.7 to 5.5

2.8 to 5.5

3

3

40

700

700

40

L/H enable

L/H enable

Autoswitch

0.69

0.85

0.70

TPS2111A/3A/5A 2 84 84

625 to

1250

625 to

1250

85 85 2.8 to 5.5

40 40 Autoswitch 0.70

*Suggested resale price in U.S. dollars in quantities of 1,000. New products are listed in bold red.

1.00

1.00

1.85

3.10

2.10

2.90

0.75

1.45

0.85

1.95

0.85

1.80

1.95

2.10

Integrated ExpressCard

®

Power Interface Switch

TPS2231

Get samples, datasheets, evaluation modules and app reports at:

www.ti.com/sc/device/ TPS2231

Key Features

• Meets PC card standard for

ExpressCard technology

• TTL-logic compatible inputs

• Short-circuit and thermal protection

• 50-µA (typ) quiescent current on 3.3-V auxiliary input (single)

Host

Power

Source

ExpressCard ®

Host

Chipset/

Logic

Circuits

TPS2231

3.3 V

AUX_IN

3.3 V

AUX_OUT

3.3 V

IN

1.5 V

IN

3.3 V

OUT

1.5 V

OUT

SHDN

STBY

SYSRST

OC

GND

PERST

CPPE

CPUSB

RCLKEN

REFCLK+

REFCLK–

Typical ExpressCard

®

power-distribution application.

Texas Instruments 1Q 2009

Interface Guide

36

1394 (FireWire

®

)

Overview

IEEE 1394 high-speed interconnection enables simple, low-cost, high-bandwidth real-time data connectivity between many types of electronic equipment . As a multimedia network standard, 1394 is ideally suited for consumer electronics, computers and peripherals .

It is also ideal for situations that benefit from true peer-to-peer operation and maximum flexibility . 1394 is self-configuring, has strong power management/distribution capabilities and robust error-detection that make it a leading choice in control applications, especially those that also need to accommodate streaming multimedia .

The new 1394b technology enables higher performance (STP, UTP, POF, GOF and Coax), longer distance (STP, UTP, POF, GOF and Coax) and a variety of cable media to fit any application (STP, UTP, POF, GOF and Coax), making it ideal for home networking and high-speed data transfer applications . For example, 1394b is capable of 400 Mbps over coax or unshielded twisted pair Category 5 cable (called

CAT5 or UTP5) . For high-speed applications, TI offers a 1394b chip set that enable speeds up to 800 Mbps for applications such as video-on-demand or backing up a RAID array . TI 1394b is backward compatible to 1394a .

Design Considerations

Physical-Layer Selection Issues

• The 1394 PHY layer should support the minimum number of nodes or ports required by the end product . Having two ports permits spanning to other devices on the bus through daisychaining . Three or more nodes enable branching or hub capabilities .

• The suspend/resume feature of the

PHY layer lets two currently inactive ports achieve low-power states while maintaining their connection status . It also permits them to quickly resume operation as soon as they detect an applied port bias voltage .

• Another aspect of the link layer that should be considered is the amount of data-buffer memory supported .

Typically, the more bandwidth an application requires, or the more simultaneous isochronous/ asynchronous traffic that needs to be supported, the larger the buffer memories must be .

• Will the end product need DC isolation at the 1394 interface? The cable doesn’t provide a DC-isolated path from node to node . In cases where there’s a possibility for the various equipment connected across 1394 to be at different ground potentials or different power domains, the grounds may need to be isolated from each other to prevent excessive currents and noise . However, the ground signal on the 1394 cable must not be DC-isolated from the PHY powerdistribution ground plane . Thus when

DC isolation between units is required at the 1394 interface, it is frequently performed at the PHY- and link-layer interfaces—often through the use of special I/O cells that allow for capacitive coupling of the PHY-link signals .

Link-Layer Selection Issues

• What kind of data needs to be transferred? Some link controllers are designed to implement specific data protocols over 1394, such as the serial bus protocol 2 (SBP-2) for mass storage or IEC 61883-4 for MPEG-2 transport, and some are designed as general purpose .

• What is being interfaced to 1394? If the system has PCI, consider one of the

PCI/OHCI links . Applications involving streaming compressed audio/video most likely need a link from the iceLynx family . Other TI links have interfaces for external processors/memory or are dedicated for a peripheral function

(camera/storage) .

• As the number of simultaneous isochronous channels present goes up, or the bit rate of an individual stream increases, the receive buffer needs to be larger .

• While the EIA-775 specification requires a minimum speed of 200 Mbps at the

1394 interface, using 400-Mbps PHYs is recommended . Slower nodes present on the bus can be a source of speed traps . Almost all 1394 silicon available today is already 400-Mbps capable .

Interface Guide

• For audio/visual (A/V) applications, different types of A/V data require different formatting and transmission methods on 1394 . Specifically identifying which types of A/V to be supported is fundamental to choosing the right 1394 chip set for the digital set-top box (DSTB) or digital TV (DTV) design . Standards define how to carry

MPEG-2 transport streams in both digital video broadcasting (DVB) format and in DirecTV format, which have different packetization schemes .

Technical Information

• 1394-1995 is an IEEE designation for a high-performance serial bus . A revision to this standard has been published as IEEE 1394a-2000, and clarifies and adds to portions of the IEEE 1394-1995 standard . The 1394b standard increases the speed of 1394 to 800,

1600 and 3200 Mbps, as well as providing new connection options such as plastic optical fiber (POF), glass optical fiber (GOF) and UTP-5 . This serial bus defines both a backplane

(for example, VME, FB+) physical layer and a point-to-point, cable-connected virtual bus . The backplane version operates at 12 .5, 25 or 50 Mbps, whereas the cable version supports data rates of 100, 200, 400, 800 and

1,600 Mbps across the cable medium supported in the current standard .

Both versions are totally compatible at the link layer and above . The interface standard defines transmission method, media and protocol .

Texas Instruments 1Q 2009

1394 (FireWire

Technical Information (Continued)

• Applications of the cable version are the integration of I/O connectivity of personal computers, peripherals, and consumer electronics using a low-cost, scalable, high-speed serial interface .

The 1394 standard provides services such as real-time I/O and live connect/ disconnect capability for devices including storage (HDD, CD-ROM,

CDRW, MO, ZIP, RAID, SAN, etc .), printers, scanners, cameras, set-top boxes, HDTVs and camcorders .

Key Features

• Real-time streaming of audio and video

• High-speed: up to 400 Mbps with IEEE

1394-1995 and 1394a-2000, up to 1, 2 and 4 Gbps with 1394b

• Plug-and-play hot pluggable

• Peer-to-peer communication

• Small, durable and flexible cable and connectors

• Memory-mapped architecture

• Seamless I/O interconnect 1394b

Advantages

• Faster: speeds from 800 Mbps to

3200 Mbps

• Longer distances: 100 meters with

GOF and Cat5; 50 meters with POF

• TI 1394b is bi-lingual: communicates in 1394a and 1394b modes

• More cabling options: STP, Cat5,

POF, GOF

• More efficient: BOSS arbitration

• More user-friendly: loop-free build allows any topology and redundancy

1394 Selection Guide

Device Ports

Voltage

(V)

1394 Physical Layer Controllers

Data Rate

(Mbps)

TSB41AB1

TSB41AB2

TSB41AB3

TSB41BA3B

TSB41LV04A

TSB41LV06A

TSB81BA3D

TSB43AB21A

TSB43AB22A

TSB43AB23

1

2

3

3

4

6

3

1

2

3

3.3

3.3

3.3

3.3

3.3

3.3

1.8, 3.3

3.3

3.3

3.3

TSB83AA22C

TSB83AA23

XIO2200A

XIO2213A

2

3

2

3

1.95, 3.3

1.95, 3.3

1.8, 3.3

1.95, 3.3

*Suggested resale price in U.S. dollars in quantities of 1,000.

Up to 800

Up to 800

Up to 400

Up to 800

Up to 400

Up to 400

Up to 400

Up to 400

Up to 400

Up to 400

Up to 800

Up to 400

Up to 400

Up to 400

Package(s) Description

48/64 HTQFP IEEE 1394a 1-Port Cable Transceiver/Arbiter

64 HTQFP IEEE 1394a 2-Port Cable Transceiver/Arbiter

80 HTQFP IEEE 1394a 3-Port Cable Transceiver/Arbiter

80 TQFP

80 HTQFP

100 HTQFP

80 HTQFP

128 TQFP

128 TQFP

128 TQFP

1394b-2002 3-Port Physical Layer Device

IEEE 1394a 4-Port Cable Transceiver/Arbiter

IEEE 1394a 6-Port Cable Transceiver/Arbiter

High-Performance 1394b s800 3-Port Cable Transceiver/Arbiter

PCI-Based 1394a OHCI Link Layer with Integrated 1394a Phy

PCI-Based 1394a OHCI Link Layer with Integrated 1394a Phy

PCI-Based 1394a OHCI Link Layer with Integrated 1394a Phy

168 BGA

167 BGA

176 BGA

176 BGA

PCI-Based 1394b OHCI Link Layer with Integrated 1394b Phy

PCI-Based 1394b OHCI Link Layer with Integrated 1394b Phy

PCIe-Based 1394a OHCI Link Layer with Integrated 1394a Phy

PCIe-Based 1394b OHCI Link Layer with Integrated 1394b Phy

®

)

1394b Advantages

• Faster: speeds from 800 Mbps to

3200 Mbps

• Longer distances: 100 meters with

GOF and CAT5; 50 meters with POF

• TI 1394b is bi-lingual: communicates in

1394a and 1394b modes

• More cabling options: STP, CAT5,

POF, GOF

• More efficient: BOSS arbitration

• More user-friendly: loop-free build allows any topology and redundancy

37

Price*

1.50

1.85

3.00

6.50

6.50

6.40

5.55

3.60

3.80

4.25

8.50

9.00

7.50

8.70

Texas Instruments 1Q 2009

Interface Guide

38

1394 (FireWire

®

)

IEEE 1394b 3-Port Cable Transceiver/Arbiter

TSB81BA3D

Get samples, datasheets, evaluation modules and app reports at:

www.ti.com/sc/device/ TSB81BA3D

Key Features

• Compliant with IEEE 1394b-2002, IEEE

1394a-2000 and 1394-1995 standards

• Three bilingual 1394 ports

1394b (Beta) Mode at s400 and s800

1394a (Data Strobe -DS) Mode at s100, s200 and s400

• Interoperable with link-layer controllers using 3 .3-V supplies and other 1394

PHYs using 1.8-V, 3.3-V and 5-V supplies

Applications

• Storage devices

• Consumer electronics

• 1394b PC ports

CPS

LPS

CNA

PINT

PCLK

LCLK

LREQ

CTL0

CTL1

D0

D1

D2

D3

D4

D5

D6

D7

RESETz

LKON/DS2

BMODE

PD

PC0

PC1

PC2

SE

SM

DS0

DS1

TESTM

TESTW

Link

Interface

I/O

Received Data

Decoder/Retimer

Arbitration and Control

State Machine

Logic

Bias Voltage and

Current

Generator

Bilingual

Cable Port 0

Bilingual

Cable Port 1

Bilingual

Cable Port 2

R0

R1

TPBIAS0

TPBIAS1

TPBIAS2

TPA0+

TPA0−

TPB0+

TPB0−

TPA1+

TPA1−

TPB1+

TPB1−

TPA2+

TPA2−

TPB2+

TPB2−

Crystal Oscillator,

PLL System, and Transmit

Clock Generator

XI

Voltage

Regulator

Transmit

Data

Encoder

TSB81BA3D block diagram.

Interface Guide

Texas Instruments 1Q 2009

ESD/EMI Protection

Design Considerations

I/O Pin Capacitance – The allowable bandwidth through an ESD protection device is directly correlated to the I/O Pin

Capacitance of the protection device . TI’s portfolio offers a wide range of ESD/EMI protection devices that cover a multitude of end applications and protected ports .

I/O capacitance of our devices range from

35 pF for lower speed applications down to <1 pF for high speed applications .

Breakdown Voltage – The breakdown voltage of an ESD protection device is defined as the maximum voltage allowed to pass across the internal diodes of the monolithic circuit, prior to it breaking down and dissipating the energy safely to ground . Different applications require certain breakdown voltages, and TI’s portfolio addresses this with our broad product offering .

ESD/EMI Selection Guide

Device

SN65220

SN65240

# Channels

2

4

SN75240

TPD4E002

TPD2E001

TPD3E001

TPD4E001

TPD6E001

TPD4E004

TPD6E004

TPD4S009

6

4

6

4

3

4

4

4

2

TPD8S009

TPD12S520

TPD12S521

8

12

12

I/O Capaciance

(pF)

35

35

1.5

1.6

1.5

1.5

1.6

0.9

35

11

1.5

0.9

0.9

0.9

V

BR

(min)

(V)

7

7

11

6

6

9

11

11

7

6

11

9

9

9

Package(s)

DSBGA-4

SOT23-6

PDIP-8

TSSOP-8

PDIP-8

TSSOP-8

SOT-5

SOT-5

SON-6

SOT-5

SON-6

SOT-6

SON-6

QFN-10

QFN-12

SOT-6

SON-6

QFN-8

SOT23-6

SC70-6

SON-6

SON-15

TSSOP-38

TSSOP-38

Description

USB 2.0 FS

USB 2.0 FS

USB 2.0 FS

USB 2.0 HS

USB 2.0 HS

USB 2.0 HS, USB 2.0 OTG

USB 2.0 HS, Ethernet, FireWire, eSATA

USB 2.0 HS, Ethernet, FireWire, eSATA

USB 2.0 HS, Ethernet, FireWire, eSATA

USB 2.0 HS, Ethernet, FireWire, eSATA eSATA, LVDS Signaling

HDMI, DisplayPort

HDMI

HDMI

Layout Features – Many of the ESD protection devices offered by TI include unique package and pin layouts to make board routing easier for designers .

There are a number of products which, in addition to providing popular pitch options, offer flow-through routing features and layout option to only populate the ESD chip if the system requires additional system-level protection .

39

Texas Instruments 1Q 2009

Interface Guide

I

2

C Products

Design Considerations

Why use I

2

C I/O expanders?

• Advantages:

Easy board routing

Board-space savings

Pin savings

Low cost

Industry standard

• Applications:

Useful with processors with few I/Os

Increase feature set without going to larger processor

Keypad control

Typical Application

SOC

ASIC

CPU

MCU

V

CC

V

CC

PCF8574A

P0

INT

SDA

P1

P2

P3

GCL

A0

A1

A2

P4

P5

P6

P7

Push

Button

Temperature Sensor

Battery Status

Reset Signals

Status

LEDs

SV

Buffer/Repeaters

Device

No. of

Outputs

P82B715

P82B96

PCA9515A

PCA9517

PCA9518

I/O Expanders

2

2

5

2

2

f

SCLK

(max)

(kHz) Package(s)

400

400

400

400

400

8PDIP, 8SOIC

8MSOP, 8PDIP, 8SOIC, 8TSSOP

8MSOP, 8PDIP, 8SOIC, 8SON, 8TSSOP

8MSOP, 8SOIC

20SOIC, 20SSOP, 20SSOP/QSOP, 20TSSOP

Description

I

2

C Bus Extender

Dual Bidirectional Bus Buffer

Dual Bidirectional I

2

C Bus and SMBus Repeater

Level-Translating I

2

C Bus Repeater

Expandable Five-Channel I

2

C Hub

Device

PCA6107

PCA9534

PCA9534A

PCA9535

PCA9536

PCA9538

PCA9539

PCA9554A

PCA9555

PCA9557

PCF8574

PCF8574A

PCF8575

PCF8575C

TCA6408

TCA6416

TCA6424

TCA6507

I/O Bits

8

8

8

16

16

16

8

8

8

4

8

16

8

16

8

16

24

7

f

SCLK

(max)

(kHz) Package(s)

400

400

400

400

400

400

400

400

400

400

400

400

400

400

400

400

400

400

Description

18SOIC

16QFN, 16SOIC, 16SSOP, 16TSSOP, 16TVSOP

16QFN, 16SOIC, 16SSOP, 16SSOP/QSOP, 16TSSOP, 16TVSOP

Remote 8-Bit I

2

C and SMBus Low-Power I/O Expander with Interrupt

Output, Reset, and Configuration Registers

Remote 8-Bit I

2

C and Low-Power I/O Expander with Interrupt Output and Configuration Registers

Remote 8-Bit I

2

C and Low-Power I/O Expander with Interrupt Output and Configuration Registers

24QFN, 24SOIC, 24SSOP, 24SSOP/QSOP, 24TSSOP, 24TVSOP, 24VQFN Remote 16-Bit I

2

C and SMBus, Low-Power I/O Expander with Interrupt

Output and Configuration Registers

8DSBGA, 8MSOP, 8SOIC

16SOIC, 16SSOP, 16TSSOP, 16TVSOP

Remote 4-Bit I

2

C and SMBus I/O Expander with Configuration Registers

Remote 8-Bit I

2

C and SMBus Low-Power I/O Expander with Interrupt

Output, Reset, and Configuration Registers

24QFN, 24SOIC, 24SSOP, 24SSOP/QSOP, 24TSSOP, 24TVSOP, 24VQFN Remote 16-Bit I

2

C and SMBus, Low-Power I/O Expander with Interrupt

Output, Reset and Configuration Registers

16QFN, 16SOIC, 16SSOP, 16SSOP/QSOP, 16TSSOP, 16TVSOP Remote 8-Bit I

2

C and SMBus I/O Expander with Interrupt Output and

Configuration Registers

24QFN, 24SOIC, 24SSOP, 24SSOP/QSOP, 24TSSOP, 24TVSOP, 24VQFN Remote 16-Bit I

2

C And SMBus I/O Expander with Interrupt Output and

Configuration Registers

16QFN, 16SOIC, 16SSOP, 16TSSOP, 16TVSOP

16PDIP, 16QFN, 16SOIC, 20QFN, 20TSSOP, 20TVSOP

16PDIP, 16SOIC, 20QFN, 20TSSOP, 20TVSOP

Remote 8-Bit I

2

C and SMBus Low-Power I/O Expander with Reset and

Configuration Registers

Remote 8-Bit I/O Expander for I

2

C-Bus

Remote 8-Bit I/O Expander for I

2

C-Bus

24QFN, 24SOIC, 24SSOP, 24SSOP/QSOP, 24TSSOP, 24TVSOP, 24VQFN Remote 16-Bit I

2

C and SMBus I/O Expander with Interrupt Output

24SOIC, 24SSOP, 24SSOP/QSOP, 24TSSOP, 24TVSOP, 24VQFN

16QFN, 16TSSOP, 20BGA Microstar Junior™

24BGA Microstar Junior, 24QFN, 24TSSOP

32QFN

12BGA Microstar Junior, 12QFN, 14TSSOP

Remote 16-Bit I

2

C and SMBus I/O Expander with Interrupt Output

Low-Voltage 8-Bit I

2

C and SMBus I/O Expander with Interrupt Output,

Reset, and Configuration Register

Low-Voltage 16-Bit I

2

C and SMBus I/O Expander with Interrupt Output,

Reset, and Configuration Registers

Low-Voltage 24-Bit I

2

C and SMBus I/O Expander with Interrupt Output

Reset and Configuration Registers

Low-Voltage 7-Bit I

2

Shutdown

C and SMBus LED Driver with Intensity Control and

Switches/Multiplexers

Device

PCA9543A

PCA9544A

PCA9545A

tpd

(max) (ns)

0.3, 1

0.3, 1

0.3, 1

PCA9546A

PCA9548A

Translator

PCA9306

0.3, 1

0.3, 1

1.5

f

SCLK

(max)

(kHz)

400

400

400

400

400

Package(s)

14SOIC, 14TSSOP

Description

Two-Channel I

2

C Bus Switch with Interrupt Logic and Reset

4-Channel I

2

C and SMBus Multiplexer with Interrupt Logic 20BGA Microstar Junior, 20QFN, 20SOIC, 20TSSOP, 20TVSOP

20BGA Microstar Junior, 20QFN, 20SOIC, 20TSSOP, 20TVSOP 4-Channel I

2

Functions

C and SMBus Multiplexer with Interrupt Logic and Reset

16QFN, 16SOIC, 16TSSOP, 16TVSOP, 20BGA Microstar Junior, 20TVSOP 4-Channel I

2

C and SMBus Multiplexer with Reset Functions

24SOIC, 24SSOP, 24TSSOP, 24TVSOP, 24VQFN 8-Channel I

2

C Switch with Reset

400 8SM8, 8US8 Dual Bidirectional I

2

C Bus and SMBus Voltage-Level Translator

Interface Guide

Texas Instruments 1Q 2009

Voltage-Level Translation

Design Considerations

Supply voltages continue to migrate to lower nodes to support today’s low-power, high-performance applications . While some devices are capable of running at lower supply nodes, others might not have this capability . To have switching capability between these devices, the output of each driver must be compliant with the input of the receiver that it is driving .

• Provide migration paths from old architectures to new architectures

V

CC

A* V

CC

B*

For two devices to have switching capability:

• V

OH

of the driver must be greater than the V

IH

• V

OL

V

IL

of the receiver

of the driver must be less than the

of the receiver

• The output voltage from the driver must not exceed the I/O voltage tolerance of the receiver

ASIC

TI Level

Translation

Solution

I/O

Devices

*V

CC

A not equal to V

CC

B

Typical situation in which a level translator is needed.

SN74AVC8T245

SN74AVC16T245

SN74AVC20T245

SN74AVC24T245

SN74AVC32T245

SN74AVCH4T245

SN74AVCH8T245

SN74AVCH16T245

SN74AVCH20T245

SN74AVCH24T245

SN74AVCH32T245

SN74AVC4T774

SN74LVC1T45

SN74LVC2T45

SN74LVC8T245

SN74LVCH8T245

SN74LVC16T245

SN74LVCH16T245

Device

TXB0101

TXB0102

TXB0104

TXB0104-Q1

TXB0106

TXB0108

TXS0101

TXS0102

TXS0104E

TXS0108E

SN74AVC1T45

SN74AVC2T45

SN74AVCH1T45

SN74AVCH2T45

SN74AVC2T245

SN74AVC4T245

Why use a voltage-level translator?

• Easily interface between subsystems operating with different supply voltages

Single Supply Translators

Device Bits

SN74AUP1T57

SN74AUP1T58

SN74AUP1T97

SN74AUP1T98

Dual Supply Translators

3

3

3

3

Trans Low (V)

2.5

2.5

2.5

2.5

1.8

1.8

1.8

1.8

1.2

1.2

1.2

1.8

1.8

1.2

1.2

1.2

1.2

1.2

1.2

1.2

1.2

1.2

1.2

1.2

1.2

1.2

1.2

1.8

1.8

1.8

1.2

1.2

Trans Low

(V)

1.2

1.2

1.2

1.2

1.2

1.2

16

16

8

8

4

1

24

32

2

4

8

16

20

8

16

20

24

32

2

2

2

1

4

4

8

1

2

1

Bits

1

4

6

2

4

8

Trans High (V)

3.3

3.3

3.3

3.3

5

5

5

5

3.3

3.3

3.3

5

5

3.3

3.3

3.3

3.3

3.3

3.3

3.3

3.3

3.3

Trans High (V)

5

5

5

5

5

5

3.3

3.3

3.3

3.3

3.3

5

5

5

5

3.3

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.65 to 5.5

1.65 to 5.5

1.65 to 5.5

1.65 to 5.5

1.65 to 5.5

1.65 to 5.5

V

CC

A (V)

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.65 to 3.6

1.65 to 3.6

1.65 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

V

CC

(V)

2.3 - 3.6

2.3 - 3.6

2.3 - 3.6

2.3 - 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.65 to 5.5

1.65 to 5.5

1.65 to 5.5

1.65 to 5.5

1.65 to 5.5

1.65 to 5.5

V

CC

B (V)

1.65 to 5.5

1.65 to 5.5

1.65 to 5.5

1.65 to 5.5

1.65 to 5.5

1.65 to 5.5

2.3 to 5.5

2.3 to 5.5

2.3 to 5.5

1.65 to 5.5

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

1.2 to 3.6

DIR Pins

No

No

No

No

Bus Hold

No

No

No

No

OE Pins

No

No

No

No

2

2

1

1

1

No

6

4

No

2

2

2

1

2

6

1

2

4

No

No

No

1

2

1

1

1

1

No

OE Pins

1

1

1

1

1

1

No

Yes

No

Yes

Yes

Yes

No

No

No

Yes

Yes

Yes

Yes

No

No

No

No

No

No

Yes

Yes

No

No

No

No

No

No

No

Bus

Hold

No

No

No

No

No

No

2

2

1

1

4

1

6

4

1

2

2

2

1

2

6

1

2

4

1

2

1

1

2

Auto

Auto

Auto

Auto

1

DIR Pins

Auto

Auto

Auto

Auto

Auto

Auto

t pd

(max) (ns)

6.2

6.2

6.2

6.2

4.2

4.2

4.2

4.2

2.7

2.7

2.4

3.9

3.9

2.9

2.5

2.7

2.9

2.5

2.7

2.9

2.7

2.7

t pd

(max) (ns)

4.5

4.5

4

7

4

4

2.4

2.8

2.4

2.4

2.9

7.5

4.6

4.6

4.8

2.8

Texas Instruments 1Q 2009

Interface Guide

41

42

High-Speed Optoelectronics Devices and Equalizers

High-Speed Optoelectronics

Devices and Equalizers

Physical-media-dependent (PMD) electronics from Texas Instruments

(TI) provide optical component and systems developers with key building blocks such as laser diode drivers, transimpedance amplifiers, post amplifiers, and equalizers . TI solutions provide wide data rate range support while minimizing power, PCB real estate, and implementation cost .

Laser Drivers

• Data rates ranging from 155 Mbps up to 11 .3 Gbps .

• Automatic power control (APC), temperature compensation of modulation and bias currents

• Fault detection and current monitors

Transimpedance Amplifiers

• Data rates of up to 11.3 Gbps

• Low input-referred noise

• Transimpedance between 2.6 and 7 kΩ with low power dissipation

Post Amplifiers

• Data rates of up to 11.3 Gbps

• Loss-of signal (LOS) detection

• Received-signal-strength indicator (RSSI)

Equalizers

• Data rates up to 11.3 Gbps

• Devices compensate for channel loss of active cables and printed circuit board traces up to 30 dB at the receive side

• Loss-of-signal (LOS) detection

Photodiode

Transimpedance

Amplifier

Post

Amplifier

Optical

Fiber

Laser

TIA

Photodiode

PA

Copper

Cable or

Backplane

Equalizer

EQ

PA

LD

Laser

Driver

Post

Amplifier

Optical network signal chain.

Copper network signal chain.

Laser Drivers

Device

ONET1101L

ONET1191V

ONET4201LD

ONET4211LD

ONET4291VA

ONET8501V

Post Amplifiers

Data Rate (typ)

(Gbps)

Up to 11.3

Up to 11.3

0.155 to 4.25

0.155 to 4.25

1 to 4.25

Up to 11.3

V

CC

(V) (typ)

3.3

3.3

3.3

3.3

3.3

3.3

Modulation Current

(mA)

85

45

85

85

11.5

24

Bias (mA)

100

20

100

100

11

20

Rise and Fall

Time (typ) (μs) DJ (typ) (ps)

25

25

55

35

35

24

5

4

15

15

7

4

Package

24VQFN

20QFN

24VQFN

24VQFN

20QFN

20QFN

Device

ONET1191P

ONET4201PA

ONET4251PA

ONET4291PA

ONET8501P

ONET8501T

ONET8511T

ONET8531T

Equalizers

Data Rate (typ)

(Gbps)

Up to 11.3

0.155 to 4.25

1 to 4.25

1 to 4.25

2 to 11.3

V

CC

(V) (typ)

3.3

3.3

3.3

3.3

3.3

ONET8501PB 2 to 11.3

Transimpedance Amplifiers

Device

ONET2511TA

ONET2591TA

ONET4291TA

3.3

Data Rate

(typ) (Gbps) V

CC

(V) (typ) Transimpedance (kΩ)

2.5

3.3

4

Up to 2.5

Up to 4.25

3.3

3.3

2.6

3.2

5

Up to 12.5

Up to 11.3

Up to 12.5

3.3

3.3

3.3

7

5.5

4.5

V

IN

(min) (typ) (mV

PP

)

2.5

3

50

2

6

Input Referred Noise

(typ) (nArms)

470

280

465

900

1000

900

I

VCC

(typ) (mA)

33

35

35

46

48

50

I

VCC

(typ)

(mA)

25

14

17

28

46

28

Part Number

Data Rate

(typ) (Gbps) V

CC

(V) (typ) V

IN

(max) (mV

PP

) V

OD

(typ) (mV

PP

)

I

VCC

(max)

(mA)

DJ (typ) (ps)

6

8

4

3

4

3

Power (typ)

(mW)

110

115

115

152

160

165

Package

16QFN

16QFN

16QFN

16QFN

16QFN

16QFN

DJ (typ) (ps) Power (typ) (mW) Package(s)

25

8.5

10

83

46

56

DIE

DIE, WAFER

DIE, WAFER

6

8

6

93

151

93

DIE

DIE

DIE

DJ (typ) (ps) RJ (typ) (ps) Package

TLK1101E

TLK6201EA

Up to 11.3

Up to 6.25

3.3

3.3

1600

2000

300/600/900

800/1200

110

67

12 (with 27-dB loss @ 5 GHz)

12 (with 18-dB loss @ 3 GHz)

1 (with 27-dB loss

@ 5 GHz)

1 (with 18-dB loss

@ 3 GHz)

20QFN

16QFN

Interface Guide

Texas Instruments 1Q 2009

The following products have similar functionality:

Part Number TI Replacement

AGERE

BDG1A

BDG1A

TB5D1M

TB5D2H

ST16C2552

ST16C450

ST16C452

ST16C550

ST16C550

ST16C552

ST16C552

ST16C552A

ST16C552A

ST16C554

ST16C554D

ST16C554D

ST16C580

ST16C654

ST16C654D

BDGLA

BPNGA

BRF1A

BRF2A

BRS2A

BRS2B

BTF1A

AGILENT

HDMP1636/1646

ALLEGRO

A2525

A2526

A2535

A2536

ANALOG DEVICES (ADI)

ADM1485

ADM1486

ADM3485E

ADM483E

ADM483E

ADM485

ADM485

ADM485

ADM485

ADM488

ADM489

CMP

CMPWR025

CYPRESS

AN-213x

EUREKA

EP600

EXAR

ST16C2450

ST16C2550

ST16C2550

TB5D2H

TB5D1M

TB5R1

TB5R1

TB5R2

TB5R2

TB5T1

TNETE2201B

TPS2051A

TPS2052A

TPS2041A

TPS2042A

SN75LBC176A*

SN65HVD1176*

SN75HVD10*

SN65HVD3082E

SN75LBC176A*

SN65HVD3085E*

SN65HVD485E*

SN75LBC176A*

SN75176B*

SN75LBC179A*

SN75LBC180A*

TPS210x

TUSB3410

TL16C550C

TL16C452

TL16C552A

TL16C752B*

TL16C552A*

TL16C450*

TL16C452*

TL16C550B

TL16C550C

TL16C552

TL16C552A

TL16C552

TL16C552A

TL16C554A

TL16C554

TL16C554A

TL16C550C

TL16C754B

TL16C754B

Part Number TI Replacement

EXAR (cont.)

ST68C554

XR16L2750

TL16C554A

TL16C752B

Ei16C552

Ei16C552

Ei16C554

Ei16C554

IMPX

IMP2525

IMP2525A

IMP2526

INFINEON

TLE6250

TLE6250

FIN1031

FIN1032

FIN1047

FIN1048

FIN1049

FIN1101

FIN1102

FIN1104

GTLP1616

GTLP16612

GTLP16612

GTLP16T1655

GTLP18T612

GTLP6C817

GTLP8T306

FTDI

FT232BM

GOLDSTAR

GM16C550

GM16C550

HYNIX (LG)

GD75232

IMP

Ei16C450

Ei16C550

XR16L2751

XR16L2752

XR16L651

XR16L784

TL16C752B

TL16C752B

TL16C750

TL16C754B

FAIRCHILD SEMICONDUCTOR

FIN1001 SN65LVDS1*

FIN1002 SN65LVDS2*

FIN1017

FIN1018

FIN1019

FIN1022

FIN1025

FIN1026

FIN1027

FIN1028

SN65LVDS1*

SN65LVDS2*

SN65LVDS180

SN65LVCP22*

SN65LVDS9638

SN65LVDS9637

SN65LVDS9638*

SN65LVDS9637*

SN65LVDS31*

SN65LVDS32*

SN65LVDS047*

SN65LVDS048A*

SN65LVDS049

SN65LVDS100

SN65LVCP22

SN65LVDS125

SN74GTLPH1616

SN74GTLPH1612

SN74GTLPH16612

SN74GTLPH1655

SN74GTLPH16912

SN74GTLP817

SN74GTLPH306

TUSB3410

TL16C550B*

TL16C550C*

GD75232*

TL16C450

TL16C550C

TL16C552

TL16C552A

TL16C554

TL16C554A

TPS2051A

TPS2051A

TPS2052A

SN65HVD251

SN65HVD1050

Texas Instruments 1Q 2009

Cross-Reference Guide

Part Number TI Replacement

INTEL

21150AB/AC

21150BC

PCI2050*

PCI2050B*

LT1381

LT1785

LTC1472

LTC1480

LTC1481

LTC1482

LTC1483

LTC1484

LTC1485

LTC1487

ICL3232

ICL3232E

ICL3238

ICL3238E

ICL3243

ICL3243E

ISL1483

ISL1483

ISL1487

ISL1487

ISL1487E

ISL1487E

ISL1487L

ISL1487L

21152

INTERSIL

HIN211

HIN211E

HIN232

HIN232E

HIN241

HIN241E

ICL232

ICL3221

ICL3221E

ICL3222

ICL3222E

ICL3223

ICL3223E

PCI2250*

SN75LBC241

SN75LBC241

TRS232*

TRS232E*

SN75LBC241

SN75LBC241

TRS232*

TRS3221*

TRS3221E*

TRS3222*

TRS3222E*

TRS3223*

TRS3223E*

TRS3232*

TRS3232E*

TRS3238*

TRS3238E*

TRS3243*

TRS3243E*

SN65HVD3082E*

SN65LBC184*

SN65HVD06*

SN65HVD21*

SN65HVD06*

SN65HVD21*

SN65HVD3082E*

SN65LBC184*

ISL8483

ISL8485

ISL8485

ISL8488

SN65HVD3082E*

SN65HVD06*

SN65HVD21*

SN65LBC179A*

ISL8489

ISL8490

SN65LBC180A*

SN65LBC179A*

ISL8491 SN65LBC180A*

LINEAR TECHNOLOGY CORP. (LTC)

LT1030

LT1081

LT1181A

LT1030

TRS232

TRS232

TRS232

SN75LBC184*

TPS2211A

SN75HVD11*

SN75LBC176A*

SN75LBC176A*

SN75LBC176A*

SN75LBC176A*

SN65LBC176A*

SN65HVD3082E*

*Drop-in, pin-compatible devices

Interface Guide

43

44

Cross-Reference Guide

The following products have similar functionality:

MAX1487E

MAX1487E

MAX1600/MAX1603

MAX1601/MAX1604

MAX1602

MAX1607

MAX202

MAX211

MAX232

MAX241

MAX3040

MAX3041

MAX3042B

MAX3043

MAX3044

MAX3045B

MAX3050

MAX3053

MAX3053

MAX3057

MAX3082

MAX3082E

LTC487

LTC487

LTC487

LTC488

LTC488

LTC488

LTC489

LTC489

LTC489

LTC490

LTC491

MAXIM

MAX1487

MAX1487

LTC1519

LTC1685

LTC1686

LTC1687

LTC1688

LTC1689

LTC1690

LTC1796

LTC485

LTC485

LTC485

LTC485

LTC486

LTC486

LTC486

Part Number TI Replacement

LINEAR TECHNOLOGY CORP. (LTC) (cont.)

LTC1487

LTC1518

SN75HVD07*

SN75LBC173A*

SN75LBC175A*

SN65HVD1176*

SN75LBC179A*

SN75LBC180A*

SN75LBC172A*

SN75LBC174A*

SN75LBC179A*

SN65HVD251*

SN65HVD3085E*

SN65HVD485E*

SN75LBC176A*

SN75176B*

SN75172*

SN75ALS172A*

SN75LBC172A*

SN75174*

SN75ALS174A*

SN75LBC174A*

SN75173*

SN75ALS173*

SN75LBC173A*

SN75175*

SN75ALS175*

SN75LBC175A*

SN75LBC179A*

SN75LBC180A*

SN65HVD3082E*

SN75HVD06*

SN65HVD3082E*

SN75HVD06*

TPS2205

TPS2205

TPS2211A

TPS2041A

TRS202*

TRS211*

TRS232*

SN75LBC241

SN75LBC174A*

SN75LBC174A*

SN75LBC174A*

SN75LBC172A*

SN75LBC172A*

SN75LBC172A*

SN65HVD251*

SN65HVD251

SN65HVD251*

SN65HVD251*

SN65HVD3082E*

SN65HVD3082E*

Part Number TI Replacement

MAXIM (cont.)

MAX3085

MAX3085E

SN65HVD3085E*

SN65HVD3085E*

MAX481E

MAX483/E

MAX483

MAX483E

MAX485/E

MAX485

MAX485E

MAX487

MAX487

MAX487E

MAX488

MAX488E

MAX489

MAX489E

MAX490

MAX490E

MAX491

MAX491E

MAX625

MAX780

MAX869L

MAX890L

MAX3243E

MAX3362

MAX3443E

MAX3463

MAX3464

MAX3464

MAX3483

MAX3483E

MAX3485

MAX3485E

MAX3486

MAX3486E

MAX481/E

MAX481

MAX3088

MAX3088E

MAX3093E

MAX3095E

MAX3221

MAX3221E

MAX3222

MAX3222E

MAX3223

MAX3223E

MAX3232

MAX3232E

MAX3238

MAX3238E

MAX3243

SN75LBC176A*

SN65HVD3082E*

SN75LBC176*

SN75LBC176A*

SN65HVD3085E*

SN75LBC176*

SN75LBC176A*

SN75HVD07*

SN75LBC182*

SN65HVD3082E*

SN75LBC179*

SN75LBC179A*

SN75LBC180*

SN75LBC180A*

SN75LBC179*

SN75LBC179A*

SN75LBC180*

SN75LBC180A*

TPS2044A/54A

TPS2205

TPS2024/34

TPS2022/32

SN65HVD3088E*

SN65HVD3088E*

SN75LBC173A*

SN75LBC175A*

TRS3221*

TRS3221E*

TRS3222*

TRS3222E*

TRS3223*

TRS3223E*

TRS3232*

TRS3232E*

TRS3238*

TRS3238E*

TRS3243*

TRS3243E*

SN75HVD10*

SN75LBC184*

SN65HVD1176*

SN65HVD3082E*

SN75HVD05*

SN75HVD12*

SN75HVD12*

SN75HVD11*

SN75HVD11*

SN75HVD12*

SN75HVD12*

SN65HVD3088E*

SN75LBC176*

Interface Guide

Part Number TI Replacement

MAXIM (cont.)

MAX9110

MAX9111

SN65LVDS1*

SN65LVDS2*

SN65LVDS180

SN65LVDS104*

SN65LVDS105*

SN65LVDS2*

SN65LVDS9637

SN65LVDS048A

SN65LVDS122

SN65LVDS122

SN65LVCP22

SN65LVDS047*

SN65LVDS348*

SN65LVDS100

SN65LVDS100

SN65LV1023*

SN65LVDS9638*

SN65LVDS9637*

SN65LVDS2

SN65LVDS048A*

SN65LVDT048A*

SN65LVDS047*

SN65LVDS31*

SN65LVDS32*

SN65LVDT32*

SN65LVDS2

SN65LVCP22

SN65LVDS100

SN65LVDS100

SN65LVDS9637*

SN65MLVD201

SN65LV1021*

SN65LV1224*

SN65LV1212*

SN65LVCP23

NS65LVCP23

SN65LVDS101

SN65LVDS100

SN65LVDS100

SN65LVDS101

MAX9206

MAX9207

MAX9208

MAX9320

MAX9320A

MAX9321B

MAX9374

MAX9374A

MAX9375

MICROCHIP

MCP2551

MCP2120

MICREL

MIC2505

MIC2506

MIC2507

MIC2514

MIC2524

MIC2525

MIC2526

MIC2527

MAX9164

MAX9169

MAX9170

MAX9171

MAX9172

MAX9173

MAX9174

MAX9175

MAX9177

MAX9178

MAX9179

MAX9180

MAX9181

MAX9205

MAX9112

MAX9113

MAX9115

MAX9121

MAX9122

MAX9123

MAX9124

MAX9125

MAX9126

MAX9130

MAX9152

MAX9155

MAX9156

MAX9159

MAX9163

SN65HVD251*

TIR1000

TPS2024/34

TPS2042A/52A

TPS2044A/54A

TPS210x

TPS2044A/54A

TPS2041A/51A

TPS2042A/52A

TPS2044A/54A

*Drop-in, pin-compatible devices

Texas Instruments 1Q 2009

The following products have similar functionality:

Part Number TI Replacement

MICREL (cont.)

MIC2564A TPS2216A

NATIONAL SEMICONDUCTOR

DS14185

DS14196

SN75185*

SN75196

DS1487

DS1488

SN75HVD06*

SN75188

DS90CP22

DS90CR215

DS90CR216

DS90CR283

DS90CR284

DS90LT012A

DS90LV001

DS90LV0101A

DS90LV011A

DS90LV012A

DS90LV017

DS90LV017A

DS90LV018A

DS90LV018A

DS90LV019

DS90LV027A

DS90LV028A

DS90LV031

DS3697

DS36C278

DS36C279

DS36C280

DS36F95

DS40MB200

DS42MB200

DS485

DS485

DS485

DS485

DS75176B

DS75176B

DS75176B

DS90CP04

DS1489

DS14C232

DS14C88

DS14C89A

DS25CP102

DS25CP104

DS25MB200

DS36276

DS3695

DS3695

DS3695

DS3695

DS3697

DS3697

SN65LVCP22*

SN65LVDS95*

SN65LVDS96*

SN65LVDS93*

SN65LVDS94*

SN65LVDS3*

SN65LVDS100*

SN65MLVD201

SN65LVDS1*

SN65LVDS2*

SN65LVDS1*

SN65LVDS1*

SN65LVDS2*

SN65LVDT2*

SN65LVDS179

SN65LVDS9638*

SN65LVDS9637*

SN65LVDM31*

SN75189

TRS232

SN75C188

SN75C189A

SN65LVCP402

SN65LVCP404

SN65LVCP40*

SN75HVD05*

SN65HVD3088E*

SN75LBC176A*

SN75ALS176*

SN75176B*

SN75179*

SN75ALS179*

SN75LBC179*

SN75HVD06*

SN75HVD06*

SN75HVD06*

SN75LBC176*

SN65LVCP40*

SN65LVCP40*

SN65HVD3088E*

SN75LBC176A*

SN75ALS176*

SN75176B*

SN75LBC176A*

SN75ALS176*

SN75176B*

SN65LVDS125

Part Number TI Replacement

NATIONAL SEMICONDUCTOR (cont.)

DS90LV031

DS90LV031A

SN65LVDS31*

SN65LVDM31*

DS92LV1224

DS92LV16

DS92LV18

DS92LV222

DS92LV222

DS92LV222A

DS92LV222A

DS96173

DS96173

DS96173

DS96174

DS96174

DS96174

DS96175

DS96175

DS96175

DS96176

DS96176

DS96176

DS96176

DS9636

DS96F174C

DS92LV010A

DS92LV010A

DS92LV010A

DS92LV010A

DS92LV090

DS92LV090

DS92LV090A

DS92LV090A

DS92LV1010

DS92LV1021

DS92LV1021

DS92LV1021

DS92LV1023

DS92LV1212A

DS90LV031A

DS90LV031B

DS90LV031B

DS90LV032

DS90LV032A

DS90LV047

DS90LV047A

DS90LV048

DS90LV048A

DS90LV049

DS90LV1021

DS90LV1023

DS90LV1023

DS90LV1212A

DS90LV1224

SN65LV1224B*

TLK2521

TLK2521

SN65LVCP22

SN65LVDM22

SN65LVCP22

SN65LVDM22

SN75173*

SN75ALS173*

SN75LBC173A*

SN75174*

SN75ALS174A*

SN75LBC174A*

SN75LBC175A*

SN75ALS175*

SN75175*

SN65HVD3088E*

SN75LBC176A*

SN75ALS176*

SN75176B*

DS9636

SN75174*

SN65LVDS31*

SN65LVDM31*

SN65LVDS31*

SN65LVDS32*

SN65LVDS32*

SN65LVDS047*

SN65LVDS047*

SN65LVDS048A*

SN65LVDS048A*

SN65LVDS049*

SN65LV1021*

SN65LV1023*

SN65LV1023A*

SN65LV1212*

SN65LV1224A*

SN65MLVD200*

SN65MLVD201*

SN65MLVD204*

SN65MLVD206*

SN65LVDM976

SN65LVDM977

SN65LVDM976

SN65LVDM977

SN65MLVD201

SN65LV1021*

SN65LV1023A*

SN65LVDS151

SN65LV1023A*

SN65LV1212*

Texas Instruments 1Q 2009

Cross-Reference Guide

Part Number TI Replacement

NATIONAL SEMICONDUCTOR (cont.)

DS96F174C

DS96F174C

SN75ALS174A*

SN75LBC174A*

PI90LV001

PI90LV019

PI90LV02

PI190LV03

PI90LV051

PI90LV179

PI90LV180

PI90LV3486

PI90LV3487

PI90LV3487

PI90LV9637

PI90LV9638

PI90LVB001

PI90LVB010

PI90LVB03

PI90LVB047A

PI90LVB180

PI90LVB387

PI90LVB9638

PI90LVT02

PI90LVT02

MC100ELT23

MC100ELT23

MC100LVEL11

MC1488

MC1489

MC1489A

MC14C89AB

MC3488A

OXFORD

OXCF950

PERICOM

PI7C8150A

PI7C8150A

PI7C8152A

DS96F175C

DS96F175C

DS96F175C

PC16550D

PC16550D

PC16552D

SC28L194

SC28L92

SC68C562C1A

ON SEMI

MC100EL11

MC100EL16

MC100ELT20

MC100ELT21

MC100ELT22

SN75175*

SN75ALS175*

SN75LBC175A*

TL16C550B

TL16C550C*

TL16C552A

TL16C554A*

TL16C552A*

TL16C552A*

SN65EL11*

SN65EL16*

SN65ELT20*

SN65ELT21*

SN65ELT22*

SN65ELT23*

SN65EPT22*

SN65LVEL11*

SN75188*

SN75189*

SN75189A*

SN75C189A

UA9636A

TL16PC564B

PCI2050*

PCI2050B*

PCI2250*

SN65LVDS1*

SN65LVDS180

SN65LVDS2*

SN65LVDS100

SN65LVDS051*

SN65LVDS179*

SN65LVDS180*

SN65LVDS3486*

SN65LVDS3487

SN65LVDS3487*

SN65LVDS9637*

SN65LVDS9638*

SN65LVDS1

SN65MLVD201

SN65LVDS100

SN65LVDS047

SN65LVDM180*

SN65LVDS387

SN65LVDS9638

SN65LVDS2*

SN65LVDT2*

*Drop-in, pin-compatible devices

Interface Guide

45

46

Cross-Reference Guide

The following products have similar functionality:

SC16C550

SC16C554

SC16C554

SC16C650A

SC16C652

SC16C654

SC16C752

SC16C2550

SC16C2552

SC28L194

SC28L91

PI90LV032A

PI90LV047A

PI90LV048A

PI90LV050

PI90LV386

PI90LV387

PI90LVB022

PI90LVB047A

PI90LVB050

PI90LVB051

PI90LVB179

PI90LVB180

PI90LVB180

PI90LVB180

PI90LVB180

PHILIPS

PCA82C250

PCA82C251

PI90LVT3486

PI90LVT386

PI90LVT9637

PI90LVT9637

PI90LV017A

PI90LV018A

PI90LV019

PI90LV019

PI90LV019

PI90LV019

PI90LV022

PI90LV022

PI90LV027A

PI90LV028A

PI90LV031A

Part Number TI Replacement

PERICOM (cont.)

PI90LVT048A

PI90LVT3486

SN65LVDT348

SN65LVDT3486*

SN65LVDS32*

SN65LVDS047*

SN65LVDS048*

SN65LVDS050*

SN65LVDS386*

SN65LVDS387*

SN65LVDM22

SN65LVDM31

SN65LVDM050*

SN65LVDM051*

SN65LVDM179*

SN65MLVD202*

SN65MLVD203*

SN65MLVD205*

SN65MLVD207*

SN65LVDT3486B*

SN65LVDT386*

SN65LVDT9637*

SN65LVDT9637B*

SN65LVDS1*

SN65LVDS2*

SN65MLVD200*

SN65MLVD201*

SN65MLVD204*

SN65MLVD206*

SN65LVCP22

SN65LVDS122

SN65LVDS9638*

SN65LVDS9637*

SN65LVDS31*

SN65HVD251*

SN65HVD251*

TL16C55C*

TL16C554*

TL16C554A*

TL16C550

TL16C752

TL16C754

TL16C752B*

TL16C752B

TL16C752B

TL16C554A

TL16C550C

Part Number TI Replacement

PHILIPS (cont.)

SC28L92

SC68C562C1A

TL16C552A

TL16C552A

SP232A

SP3222E

SP3222EB

SP3222EU

SP3223E

SP3223EB

SP3223EU

SP3232E

SP3232EB

SP3232EU

SP3238E

SP3243E

SP3243EB

SP3243EU

SP3481

SP3483

SP3485

SP3494

SCC2691

SCC2692

SCC68692

SCN2681

TL16C450

TL16C452*

TL16C452*

TL16C452*

TJA1040

TJA1050

PLX

PCI6150

SN65HVD1040*

SN65HVD1050*

PCI6150

PCI6140

PROLIFIC

PL-2303

SEMTECH

SC5825

PCI2050*

PCI12050B*

PCI2250*

TUSB3410

SC5826

SILICON LABORATORIES

TPS2041A/51A

TPS2041A/52A

CP2101

CP2102

SILICON/VISHAY

Si9711

TUSB3410

TUSB3410

TPS2211A

TPS2211A Si9712

SILICON SYSTEM

73M550

SIPEX

SP211

TL16C550C*

SN75LBC241

TRS232

TRS3222

TRS3222

SNx5C3222

TRS3223

TRS3223

SNx5C3223

TRS3232

TRS3232

SNx5C3232

TRS3238

TRS3243

TRS3243

SNx5C3243

SN75HVD11*

SN75HVD12*

SN75HVD11*

SN75HVD10*

Part Number TI Replacement

SIPEX (cont.)

SP481

SP481

SN65HVD3088E*

SN75LBC176*

SP485E

SP485E

SP486E

SP487

SP487E

SP488

SP488A

SP488E

SP489

SP489A

SP489E

SP490

SP490E

SP491

SP491E

STM

ST232

ST3222

SP481

SP481

SP481E

SP481E

SP481R

SP483

SP483

SP483

SP483

SP483E

SP483E

SP485

SP485

SP485

SP485

ST3222E

ST3232

ST3232E

ST3243

ST3243E

ST75185

ST75C185

VITESSE

VSC7123

VSC7132-01

TRS232*

TRS3222*

TRS3222E*

TRS3232*

TRS3232E*

TRS3243*

TRS3243E*

SN75185

SN75C185*

TLK2201

SN65LVCP15

SN65HVD3088E*

SN75LBC176A*

SN75LBC172A*

SN75LBC174*

SN75LBC174A*

SN75LBC173*

SN75LBC173A*

SN75LBC173A*

SN75LBC175*

SN75LBC175A*

SN75LBC175A*

SN75LBC179*

SN75LBC179A*

SN75LBC180*

SN75LBC180A*

SN75ALS176*

SN75176B*

SN65HVD3088E*

SN75LBC176A*

SN65HVD3088E*

SN65HVD3082E*

SN75LBC176*

SN75ALS176*

SN75176B*

SN65HVD3088E*

SN75LBC176A*

SN65HVD3088E*

SN75LBC176*

SN75ALS176*

SN75176B*

*Drop-in, pin-compatible devices

Interface Guide

Texas Instruments 1Q 2009

Notes

47

Texas Instruments 1Q 2009

Interface Guide

TI Worldwide Technical Support

Internet

TI Semiconductor Product Information Center

Home Page

support.ti.com

TI Semiconductor KnowledgeBase Home Page

support.ti.com/sc/knowledgebase

Product Information Centers

Americas

Phone +1(972) 644-5580

Brazil

Mexico

Phone 0800-891-2616

Phone 0800-670-7544

Fax +1(972)927-6377

Internet support.ti.com/sc/pic/americas.htm

Europe, Middle East, and Africa

Phone

European Free Call 00800-ASK-TEXAS

(00800 275 83927)

International

Russian Support

+49 (0) 8161 80 2121

+7 (4) 95 98 10 701

Note: The European Free Call (Toll Free) number is not active in all countries. If you have technical

difficulty calling the free call number, please use the international number above.

Fax

Internet

+49 (0) 8161 80 2045 support.ti.com/sc/pic/euro.htm

Japan

Fax

International +81-3-3344-5317

Domestic 0120-81-0036

Internet

International support.ti.com/sc/pic/japan.htm

Domestic www.tij.co.jp/pic

Asia

Phone

International

Domestic

Australia

+91-80-41381665

Toll Free Number

1-800-999-084

China 800-820-8682

Hong Kong 800-96-5941

India

Indonesia

Korea

Malaysia

1-800-425-7888

001-803-8861-1006

080-551-2804

1-800-80-3973

New Zealand 0800-446-934

Philippines 1-800-765-7404

Singapore

Taiwan

800-886-1028

0800-006800

Fax

Thailand 001-800-886-0010

+886-2-2378-6808

Email [email protected] or [email protected]

Internet support.ti.com/sc/pic/asia.htm

D093008

Safe Harbor Statement

This publication may contain forward-looking statements that involve a number of risks and uncertainties. These “forward- looking statements” are intended to qualify for the safe harbor from liability established by the Private Securities Litigation Reform Act of 1995. These forwardlooking statements generally can be identified by phrases such as

TI or its management “believes,” “expects,” “anticipates,” “foresees,”

“forecasts,” “estimates” or other words or phrases of similar import.

Similarly, such statements herein that describe the company’s products, business strategy, outlook, objectives, plans, intentions or goals also are forward-looking statements. All such forward-looking statements are subject to certain risks and uncertainties that could cause actual results to differ materially from those in forward-looking statements. Please refer to TI’s most recent Form 10-K for more information on the risks and uncertainties that could materially affect future results of operations. We disclaim any intention or obligation to update any forward-looking statements as a result of developments occurring after the date of this publication.

Important Notice: The products and services of Texas

Instruments Incorporated and its subsidiaries described herein are sold subject to TI’s standard terms and conditions of sale.

Customers are advised to obtain the most current and complete information about TI products and services before placing orders.

TI assumes no liability for applications assistance, customer’s applications or product designs, software performance, or infringement of patents. The publication of information regarding any other company’s products or services does not constitute TI’s approval, warranty or endorsement thereof.

The platform bar, ControlNet, FlatLink, Panel Bus, DLP, PowerPAD, VLYNQ,

MicroStar BGA and MicroStar Junior are trademarks of Texas Instruments.

The Bluetooth word mark and logos are owned by the Bluetooth Sig, Inc., and any use of such marks by Texas Instruments is under license. All other trademarks are the property of their respective owners.

© 2008 Texas Instruments Incorporated

Printed in U.S.A. by Texoma Print Services, Durant, OK

Required Clearance

Cert no. XXX-XXX-000

FSC logo to be inserted by FSC-certified printer.

14950 F .A .A . Blvd .

Fort Worth, Texas 76155

Address service requested

PRSRT STD

U .S . POSTAGE

PAID

DALLAS, TEXAS

PERMIT NO .

2758

SSZT009D

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete. All products are sold subject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI deems necessary to support this warranty. Except where mandated by government requirements, testing of all parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for their products and applications using TI components. To minimize the risks associated with customer products and applications, customers should provide adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right, copyright, mask work right, or other TI intellectual property right relating to any combination, machine, or process in which TI products or services are used. Information published by TI regarding third-party products or services does not constitute a license from TI to use such products or services or a warranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of TI information in TI data books or data sheets is permissible only if reproduction is without alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for such altered documentation. Information of third parties may be subject to additional restrictions.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that product or service voids all express and any implied warranties for the associated TI product or service and is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.

TI products are not authorized for use in safety-critical applications (such as life support) where a failure of the TI product would reasonably be expected to cause severe personal injury or death, unless officers of the parties have executed an agreement specifically governing such use. Buyers represent that they have all necessary expertise in the safety and regulatory ramifications of their applications, and acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products and any use of TI products in such safety-critical applications, notwithstanding any applications-related information or support that may be provided by TI. Further, Buyers must fully indemnify TI and its representatives against any damages arising out of the use of TI products in such safety-critical applications.

TI products are neither designed nor intended for use in military/aerospace applications or environments unless the TI products are specifically designated by TI as military-grade or "enhanced plastic." Only products designated by TI as military-grade meet military specifications. Buyers acknowledge and agree that any such use of TI products which TI has not designated as military-grade is solely at the Buyer's risk, and that they are solely responsible for compliance with all legal and regulatory requirements in connection with such use.

TI products are neither designed nor intended for use in automotive applications or environments unless the specific TI products are designated by TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated products in automotive applications, TI will not be responsible for any failure to meet such requirements.

Following are URLs where you can obtain information on other Texas Instruments products and application solutions:

Products

Amplifiers

Data Converters

DSP

Clocks and Timers

Interface

Logic

Power Mgmt

Microcontrollers amplifier.ti.com

dataconverter.ti.com

dsp.ti.com

www.ti.com/clocks interface.ti.com

logic.ti.com

power.ti.com

microcontroller.ti.com

RFID www.ti-rfid.com

RF/IF and ZigBee® Solutions www.ti.com/lprf

Applications

Audio

Automotive

Broadband

Digital Control

Medical

Military

Optical Networking

Security

Telephony

Video & Imaging

Wireless www.ti.com/audio www.ti.com/automotive www.ti.com/broadband www.ti.com/digitalcontrol www.ti.com/medical www.ti.com/military www.ti.com/opticalnetwork www.ti.com/security www.ti.com/telephony www.ti.com/video www.ti.com/wireless

Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265

Copyright © 2008, Texas Instruments Incorporated

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
