Conair A1-4 Technical information
WARNING - Reliance on this Manual Could Result in Severe Bodily Injury or Death!
This manual is out-of-date and is provided only for its technical information, data and capacities. Portions of this manual
detailing procedures or precautions in the operation, inspection, maintenance and repair of the product forming the subject
matter of this manual may be inadequate, inaccurate, and/or incomplete and cannot be used, followed, or relied upon.
Contact Conair at info@conairgroup.com or 1-800-654-6661 for more current information, warnings, and materials about
more recent product manuals containing warnings, information, precautions, and procedures that may be more adequate
than those contained in this out-of-date manual.
Portable
Chillers
Water-cooled models PCW-1.5 to PCW-30
and
Air-cooled models PCA1.5 to PCA-30
Installation
Operation
Maintenance
Troubleshooting
Instant Access
Parts and Service
(800) 458-1960
(814) 437-6861
www.conairnet.com
The Conair Group, Inc.
One Conair Drive
Pittsburgh, PA 15202
Phone: (412) 312-6000
Fax: (412) 312-6227
UGH024/1103
Please record your
equipment’s model and
serial number(s) and
the date you received it
in the spaces provided.
It’s a good idea to record the model and serial number(s) of
your equipment and the date you received it in the User
Guide. Our service department uses this information, along
with the manual number, to provide help for the specific
equipment you installed.
Please keep this User Guide and all manuals, engineering
prints and parts lists together for documentation of your
equipment.
Date:
Manual Number:
UGH024/1103
Serial number(s):
Model number(s):
Power specifications:
Amps
Volts
Phase
Cycle
DISCLAIMER: The Conair Group, Inc., shall not be liable for errors
contained in this User Guide or for incidental, consequential damages in connection with the furnishing, performance or use of this
information. Conair makes no warranty of any kind with regard to
this information, including, but not limited to the implied warranties
of merchantability and fitness for a particular purpose.
Copyright 2003
THE CONAIR GROUP, INC.
All rights reserved
INTRODUCTION . . . . . . . . . . . . . . . . . . .1-1
Purpose of the User Guide . . . . . . . . . . . . . . . . . . . . . . . . .1-2
How the Guide is Organized . . . . . . . . . . . . . . . . . . . . . . .1-2
Your Responsibility as a User . . . . . . . . . . . . . . . . . . . . . .1-2
ATTENTION: Read this so no one gets hurt . . . . . . . . . . .1-3
TABLE OF
CONTENTS
DESCRIPTION . . . . . . . . . . . . . . . . . . . .2-1
What is the Portable Chiller? . . . . . . . . . . . . . . . . . . . . . . .2-2
Typical Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
How it Works: Water-cooled Portable Chillers . . . . . . . . .2-4
How it Works: Air-cooled Portable Chillers . . . . . . . . . . .2-6
Portable Chiller Features . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
Pump Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10
INSTALLATION . . . . . . . . . . . . . . . . . . . .3-1
Unpacking the Boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
Preparing for Installation . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Making Process Plumbing Connections . . . . . . . . . . . . . . .3-5
Filling the Chiller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6
Checking Refrigerant Charge . . . . . . . . . . . . . . . . . . . . . . .3-8
Connecting the Main Power Source . . . . . . . . . . . . . . . . . .3-9
Checking Electrical Connections . . . . . . . . . . . . . . . . . . .3-10
TIC CONTROL______________________________________
Checking Pump Rotation . . . . . . . . . . . . . . . . . . . . . . . . .3-11
Checking the Compressor . . . . . . . . . . . . . . . . . . . . . . . .3-11
Checking the Sight Glass . . . . . . . . . . . . . . . . . . . . . . . . .3-12
PLC CONTROL______________________________________
Initially Warming the Chiller . . . . . . . . . . . . . . . . . . . . . .3-13
Checking Pump Rotation . . . . . . . . . . . . . . . . . . . . . . . . .3-14
Checking for Leaks . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-15
Initially Running the Chiller . . . . . . . . . . . . . . . . . . . . . .3-16
Stopping the Chiller . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-17
OPERATION . . . . . . . . . . . . . . . . . . . . . .4-1
TIC Control Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
PLC Control Features . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Before Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4
TIC CONTROL______________________________________
Starting/Stopping the Chiller . . . . . . . . . . . . . . . . . . . . . . .4-7
Changing Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8
Changing the Setpoint Temperature . . . . . . . . . . . . . . . . . .4-8
Menue features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8
Tuning the Chiller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10
PLC CONTROL______________________________________
Powering Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-17
Running/Stopping the Chiller . . . . . . . . . . . . . . . . . . . . . .4-18
Viewing Chiller Status Screens . . . . . . . . . . . . . . . . . . . .4-18
UGH024/1103
Portable Chillers
i
TABLE OF
CONTENTS
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . .CONT’D
PLC CONTROL______________________________________
Programming Settings . . . . . . . . . . . . . . . . . . . . . . . . . . .4-21
Changing Setpoint Temperature . . . . . . . . . . . . . . . . . . . .4-22
Resetting PID Settings . . . . . . . . . . . . . . . . . . . . . . . . . . .4-23
Changing High Temperature Deviation . . . . . . . . . . . . . .4-24
Setting Percent Glycol . . . . . . . . . . . . . . . . . . . . . . . . . . .4-25
Setting Fan Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-27
Selecting the Temperature Scale . . . . . . . . . . . . . . . . . . . .4-28
Setting Auto Tune Mode . . . . . . . . . . . . . . . . . . . . . . . . .4-29
Setting Discharge Pressure Setpoint . . . . . . . . . . . . . . . . .4-31
Setting PID Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-32
Manually Starting/Stopping the Pump . . . . . . . . . . . . . . .4-33
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Maintenance Features . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
Preventative Maintenance Schedule . . . . . . . . . . . . . . . . . .5-4
PLC Control Entering Maintenance Screens . . . . . . . . . . .5-6
Checking Electrical Connections . . . . . . . . . . . . . . . . . . . .5-7
Cleaning the Evaporator or Water-cooled Condenser . . . . .5-8
Cleaning the Air-cooled Condenser . . . . . . . . . . . . . . . . . .5-9
Checking the Refrigerant Charge . . . . . . . . . . . . . . . . . . .5-10
Checking Reservoir Level . . . . . . . . . . . . . . . . . . . . . . . .5-11
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Before Beginning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
A Few Words of Caution . . . . . . . . . . . . . . . . . . . . . . . . . .6-3
Identify the Cause of a Problem . . . . . . . . . . . . . . . . . . . . .6-3
TIC Control Input/Output . . . . . . . . . . . . . . . . . . . . . . . . .6-4
TIC Control Answering an Alarm . . . . . . . . . . . . . . . . . . .6-5
TIC Control Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-6
TIC Control Alarm Conditions . . . . . . . . . . . . . . . . . . . . . .6-8
PLC Control Answering Alarms . . . . . . . . . . . . . . . . . . . .6-16
PLC Control Alarm Conditions . . . . . . . . . . . . . . . . . . . .6-17
PLC Control Alarm Errors . . . . . . . . . . . . . . . . . . . . . . . .6-20
PLC Control Alarm History Screens . . . . . . . . . . . . . . . .6-21
PLC Control Alarm Screen Legend . . . . . . . . . . . . . . . . .6-22
PLC Control Control Problems . . . . . . . . . . . . . . . . . . . .6-23
PLC Control Alarm Conditions . . . . . . . . . . . . . . . . . . . .6-25
Checking and Replacing Switches . . . . . . . . . . . . . . . . . .6-44
Replacing the RTD . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-45
Removing Pump Components . . . . . . . . . . . . . . . . . . . . .6-46
Replacing Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-47
Replacing the Contactor . . . . . . . . . . . . . . . . . . . . . . . . . .6-48
APPENDIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
Maintenance Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1
Pressure Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1
Overhead Plumbing Details . . . . . . . . . . . . . . . . . . . . . . . .D-1
TIC Control Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-1
PARTS
ii
AND
DIAGRAMS . . . . . . . . . . . . . . . . . . . . .P/D-1
Portable Chillers
UGH024/1103
INTRODUCTION
l Purpose of the User Guide . . . .1-2
l How the Guide is Organized . . .1-2
l Your responsibility as a user . .1-2
l ATTENTION: Read this so
no one gets hurt . . . . . . . . . . .1-3
Portable Chillers
UGH024/1103
1-1
PURPOSE OF
THE USER
GUIDE
HOW THE
GUIDE IS
ORGANIZED
YOUR
RESPONSIBILITY
AS A USER
This User Guide describes Conair’s Portable Chillers and
explains step-by-step how to install, operate, maintain and
repair this equipment.
Before installing this product, please take a few moments to
read the User Guide and review the diagrams and safety information in the instruction packet. You also should review manuals covering associated equipment in your system. This
review won’t take long, and it could save you valuable installation and operating time later.
Symbols have been used to help organize the User Guide and
call your attention to important information regarding safe
installation and operation.
Symbols within triangles warn of conditions that could
be hazardous to users or could damage equipment.
Read and take precautions before proceeding.
1
Numbers within shaded squares indicate tasks or steps
to be performed by the user.
u
A diamond indicates the equipment’s response to an
action performed by the user.
r
l
An open box marks items in a checklist.
A shaded circle marks items in a list.
You must be familiar with all safety procedures concerning
installation, operation and maintenance of this equipment.
Responsible safety procedures include:
l Thorough review of this User Guide, paying particular
attention to hazard warnings, appendices and related diagrams.
l Thorough review of the equipment itself, with careful
attention to voltage sources, intended use and warning
labels.
l Thorough review of instruction manuals for associated
equipment.
l Step-by-step adherence to instructions outlined in this
User Guide.
1-2
INTRODUCTION
Portable Chillers
UGH024/1103
We design equipment with the user’s safety in mind. You can
avoid the potential hazards identified on this machine by following the procedures outlined below and elsewhere in the
User Guide.
ATTENTION:
READ THIS
SO NO
ONE GETS HURT
WARNING: Improper installation, operation, or servicing may result in equipment damage or personal injury.
This equipment should only be installed, adjusted, and serviced by qualified technical personnel who are familiar with the construction, operation, and potential hazards of this type of
machine.
All wiring, disconnects and fuses should be
installed by qualified electrical technicians in
accordance with electrical codes in your region.
Always maintain a safe ground. Do not operate
the equipment at power levels other than what is
specified on the machine serial tag and data
plate.
WARNING: Electrical hazard
Before performing any work on this item, disconnect and lock out electrical power sources to
prevent injury from unexpected energization or
startup.
CAUTION: Hot Surfaces
Always protect yourself from hot surfaces when
working on the Portable Chiller, especially when
working on or around the compressor and condenser. These devices can reach up to 160°F
(71°C). Allow these devices to cool before performing any maintenance or troubleshooting.
CAUTION: Ventilation hazard
The unit requires a clean and well ventilated
operating environment. Do not place anything on
top of the unit while operating. Units with fans
require unrestricted outlet air flow.
Water-cooled units require a minimum of one
foot clearance around the perimeter for serviceability. Air-cooled units require a minimum of two
feet clearance around the perimeter for serviceability and proper air flow.
UGH024/1103
Portable Chillers
INTRODUCTION
1-3
WARNING: Hazardous substance
When burned, Freon R22 refrigerant forms
Phosgene gas. If the chiller is placed in the
vicinity of equipment with combustible systems,
the combustion air intake must be ducted in
from the outside and sealed in such a manner
as to prevent any refrigerant from entering the
combustion chamber. Refer to the Material
Safety Data Sheet for Freon R22 included in the
appendix. This sheet explains the potential hazards and how to avoid them.
1-4
INTRODUCTION
Portable Chillers
UGH024/1103
DESCRIPTION
l What is the Portable Chiller? . . .2-2
l Typical Applications . . . . . . . . . .2-3
l Limitations . . . . . . . . . . . . . . . . .2-3
l How it Works: Water-cooled
Portable Chiller . . . . . . . . . . .2-4
l How it Works: Air-cooled
Portable Chiller . . . . . . . . . . .2-6
l Portable Chiller Features . . . . . .2-8
l Pump Curves . . . . . . . . . . . . . .2-10
Portable Chillers
UGH024/1103
2-1
WHAT IS THE
PORTABLE
CHILLER?
The Conair Portable Chillers provide self-contained sources of
chilled water and are available in either water- or air-cooled
models with ranges from 1.5 Hp to 30 Hp (approximate
capacities of 1.5 tons to 30 tons of refrigeration). Pump selections are available to match most process flow and pressure
requirements.
The normal temperature range of discharge chilled water is
20°F to 70°F (7°C to 21°C). For applications requiring 40°F
and lower mix glycol with the water to the correct percentage.
Conair Portable Chillers are designed to provide chilled fluid
for industrial applications requiring 24-hour-a-day performance. Units are totally self-contained for easy, economical
installation. All parts wetted by the process are non-ferrous.
To operate, simply connect the power source, process piping
and fill with water or with industrial grade ethylene glycol or
propylene glycol (but not automotive antifreeze).
These chillers are ideal for machine-side cooling to maintain
process temperatures in an injection molding machine or
extruder and wherever you need a small, moveable cooling
unit. Nominal capacities range from 1.44 to 30 tons for the
water-cooled models and 1.18 to 30 tons for the air-cooled
models. Capacities are based on standard pump sizes and
delivering 50°F (10°C) water.
Operation of these units differ only in the medium used to
remove heat from the refrigerant in the condensers. Watercooled models use 85°F (29°C) or lower cooling water from a
tower, well, or city service; air-cooled models use 95°F
(35°C) maximum ambient air; and high ambient models use
120°F (49°C) maximum ambient air.
Choose Water-cooled Portable Chillers where tower water or
another inexpensive water source is available. Choose Aircooled models for maximum portability of the unit or if water
is unavailable.
Brazed plate condensers are standard equipment on all watercooled models. Air-cooled models use copper-fin tube condensers.
All standard voltages are available.
2-2
DESCRIPTION
Portable Chillers
UGH024/1103
The Conair Portable Chillers can be used anywhere a reliable
source of process cooling water - with stable temperature control - is required.
TYPICAL
APPLICATIONS
These portable chillers are available for cooling injection
molding, blow molding, thermoforming, extrusion, air compressors, metal plating, anodizing, degreasing, heatset/web
offset printing presses, and dryer after-coolers.
Roll the air-cooled model next to the heat source, connect it,
and plug it in. They can operate almost anywhere.
The water-cooled models require a source of condenser water.
Normally used in conjunction with a recirculating evaporative
cooling tower system, the units have slightly better operating
energy efficiencies.
Conair Portable Chillers are designed to provide chilled water
for industrial applications requiring 24-hour-a-day performance. Units are self-contained and easy to install and maintain. Choose the Conair Portable Chillers based on the cooling
load and the capacity of the unit. Pick your Conair Portable
Chillers based on:
LIMITATIONS
l Cooling load
Choose a portable chiller that has 10% more capacity
than the process load.
l Location
Choose a water-cooled model if the unit will be located
in an air-conditioned area. Choose the water-cooled
model if a source of condenser water is readily available
(i.e. cooling tower water). Do not locate the portable
chiller outside unless the unit is specially modified.
l Temperature
The portable chiller needs to provide a cooling temperature less than 70°F (21°C).
Use this information as a general guide. Consult your Conair
representative for assistance when choosing a Conair Portable
Chiller.
UGH024/1103
Portable Chillers
DESCRIPTION
2-3
Process circulation
HOW IT WORKS:
WATER-COOLED PORTABLE CHILLERS
2
1
3
Type 1
3
1
2
3
1
2
2-4
Type 3
DESCRIPTION
Portable Chillers
Type 2
1
Hot fluid from the process enters the
chiller through the From Process valve
into the pump reservoir.
2
Pump draws water from pump reservoir
and moves it through the strainer and
flow switch to the evaporator.
3
Fluid is chilled in the evaporator and
exits through the To Process valve and
tube, returning to the process.
UGH024/1103
Refrigerant circulation
HOW
IT WORKS:
WATER-COOLED PORTABLE CHILLERS
1
The evaporator extracts heat from the process fluid, causing the refrigerant to vaporize (evaporate) into a gas.
2
Vaporized refrigerant travels from the evaporator to the
compressor, where the low pressure vapor is compressed
into a high-pressure, high-temperature vapor.
3
The high-pressure, high-temperature vapor from the condenser to the receiver.
4
The high pressure vapor travels from the condenser to
the receiver. Water tower or city water removes heat from
the vapor, condensing it to a high-pressure liquid.
5
High-pressure liquid is metered back to the evaporator by
the expansion valve (TXV), changing it to a low-pressure,
low-temperature liquid.
3
4
3
4
1
Type 1
2
4
3
5
1
Type 2
1
Type 3
UGH024/1103
Portable Chillers
DESCRIPTION
2-5
Process circulation
HOW IT WORKS:
AIR-COOLED PORTABLE CHILLERS
1
3
Type 1
2
3
1
2
Type 2
3
1
1
2
Type 3
2
3
2-6
DESCRIPTION
Portable Chillers
Hot fluid from the process enters the chiller
through the From Process valve into the pump
reservoir.
Pump moves fluid from pump reservoir through
evaporator where it is chilled.
Fluid is chilled in the evaporator and exits
through the To Process valve and tube, returning
to the process.
UGH024/1103
HOW
IT WORKS:
AIR-COOLED PORTABLE CHILLERS
Refrigerant circulation
1
The evaporator extracts heat from the process fluid, causing the refrigerant to vaporize (evaporate) into a gas.
2
Vaporized refrigerant travels to the compressor, where the
low pressure vapor is compressed into a high-pressure,
high-temperature vapor.
3
The high pressure vapor travels from the compressor
through the condenser, where the fan cools and condenses the vapor into a high-temperature, high-pressure liquid.
4
High-pressure, high-temperature liquid is metered back to
the evaporator by the expansion valve (TXV), changing it
to a low-pressure, low-temperature liquid.
4
3
2
3
2
1
Type 1
2
1
Type 2
3
4
4
1
Type 3
Shown with one condenser removed for clarity.
UGH024/1103
Portable Chillers
DESCRIPTION
2-7
PORTABLE
CHILLER
FEATURES
Water-cooled Models
Hot Gas Bypass valve
Hot Gas Bypass valve
Relief valve
Condenser
Relief valve
Compressor
Receiver
Liquid line
solenoid
valve
TX valve
Process pump
Evaporator
Pump reservoir
Filter dryer
Type 1
Liquid line
solenoid valve
Type 3
Receiver
Process pump
Relief valve
Compressor
Condenser
Recirculation
pump
Filter dryer
TX valve
Liquid line
solenoid valve
Pump
reservoir
Process
pump
Evaporator
Type 2
2-8
DESCRIPTION
Portable Chillers
UGH024/1103
PORTABLE
CHILLER
FEATURES
Air-cooled Models
Hot Gas Bypass valve
Condenser
Fans
Compressor
Condenser
Fan
Receiver
Process
pump
Type 1
Filter dryer
Evaporator
Pump reservoir
Fan
Evaporator
Type 2
Hot Gas
Bypass
valve
Process pump
Condenser
Compressor
Temperature sensor
TX valve
Process pump
Type 3
Pump reservoir
UGH024/1103
Evaporator
Recirculation pump
Portable Chillers
DESCRIPTION
2-9
PUMP CURVES
SINGLE PUMP
15 Hp
10 Hp
5 Hp
3 Hp-PCW/A 3,5,7.5,10 & 15 only
3 Hp-PCW/A 20 & 25 only
7.5 Hp
2 Hp
1Hp
1.5 Hp
0.75 Hp
Flow Rate (gpm)
SPECIFICATION NOTES
These pump curves are non-overloading using the service factor of the motors.
Specifications may change without notice. Check with your Conair representative for the most current
information.
2-10
DESCRIPTION
Portable Chillers
UGH024/1103
1-7.5 Hp
PUMP CURVES
DUAL PUMP
5 Hp-PCW/A-5 & 7 only
5 Hp-PCW/A-15 only
3 Hp-PCW/A-3 only
7.5 Hp
3 Hp-PCW/A-5,7.5,10,15 & 20 only
1 Hp
1.5 Hp
2 Hp-PCW/A-3 only
5 Hp-PCW/A-10,15,20,25 & 30 only
Flow Rate (gpm)
10-20 Hp
25 Hp-PCW/A-10 & 15 only
20 Hp-PCW/A-10 & 15 only
15 Hp-PCW/A-15 only
10 Hp-PCW/A-10 & 15 only
15 Hp-PCW/A-20, 25 & 30 only
10 Hp-PCW/A-20, 25 & 30 only
Flow Rate (gpm)
SPECIFICATION NOTES
These pump curves are non-overloading using the service factor of the motors.
Specifications may change without notice. Check with your Conair representative for the most current information.
UGH024/1103
Portable Chillers
DESCRIPTION
2-11
INSTALLATION
l Unpacking the Boxes . . . . . . . . . .3-2
l Warnings and Cautions . . . . . . . . .3-3
l Preparing for Installation . . . . . . .3-4
l Making Process Plumbing
Connections . . . . . . . . . . . . . . . .3-5
l Filling the Chiller . . . . . . . . . . . . . .3-6
l Checking Refrigerant Charge . . . .3-8
l Connecting the Main
Power Source . . . . . . . . . . . . . . .3-9
l Checking Electrical Connections 3-10
TIC CONTROL
l Checking Pump Rotation . . . . . .3-11
l Checking the Compressor . . . . . .3-11
l Checking the Sight Glass . . . . . .3-11
l Initially Warming the Chiller . . . .3-12
PLC CONTROL
l Initially Warming the Chiller . . .
l Checking Pump Rotation . . . . .
l Checking for Leaks . . . . . . . . . .
l Initially Running the Chiller . . . .
l Stopping the Chiller . . . . . . . . . .
Portable Chillers
UGH024/1103
.3-13
.3-14
.3-15
.3-16
.3-17
3-1
UNPACKING THE
BOXES
The portable chiller comes fully assembled in a single crate.
The Air cooled units are shipped without the casters attached.
The casters must be attached during unpacking.
CAUTION: Lifting
Conair Portable Chillers are designed to easily
roll on casters. If, for some reason you need to
lift the chiller, take all precautions to avoid personal injury or damage to the chiller. Lift the
chiller using a forklift or hoist with straps that
have been positioned at the chillers’ center of
gravity. Do not try to lift the unit manually.
1
Carefully uncrate the chiller and its
components.
2
Remove all packing material, protective paper,
tape, and plastic. Compare contents to the shipping
papers to ensure that you have all the parts.
3
Carefully inspect all components to make sure
no damage occurred during shipping. If any damage is
found, notify the shipping agent immediately. Check all
wire terminal connections, bolts, and any other electrical
connections, which may have come loose during shipping. Check for pinched wires and kinked hoses.
4
5
Cut the bands holding the chiller on the pallet.
With a forklift lift the chiller high enough to
attach the casters, if shipped unattached. Thread the casters into the threaded plates on each corner of the unit.
6
Record serial numbers and specifications
for the chiller in the blanks provided on the back of the
User Guide’s title page. This information will be helpful
if you ever need service or parts.
3-2
INSTALLATION
Portable Chillers
UGH024/1103
WARNING: Improper installation, operation, or servicing may result in equipment damage or personal injury.
This equipment should only be installed, adjusted, and serviced by qualified technical personnel who are familiar with the construction, operation, and potential hazards of this type of
machine.
WARNINGS AND
CAUTIONS
All wiring, disconnects and fuses should be
installed by qualified electrical technicians in
accordance with electrical codes in your region.
Always maintain a safe ground. Do not operate
the equipment at power levels other than what is
specified on the machine data plate.
CAUTION: Hot Surfaces
Always protect yourself from hot surfaces when
working on the Portable chiller, especially when
working on or around the compressor and condenser. These devices can reach up to 160°F
(71°C). Allow these devices to cool before performing any maintenance or troubleshooting.
CAUTION: Ventilation
The unit requires a clean and well ventilated
operating environment. Do not place anything
on top of the unit while operating.
Units require enough clearance around the
perimeter for access doors to open completely.
Air-cooled units require a minimum of two feet
clearance around the perimeter for proper air
flow.
WARNING: Refrigerant hazard
Only certified refrigerant technicians should
examine and correct problems involving the
refrigerant circuit.
WARNING: Hazardous substance
When burned, Freon R22 refrigerant forms
Phosgene gas. If the chiller is placed in the
vicinity of equipment with combustible systems,
the combustion air intake must be ducted in
from the outside and sealed in such a manner
as to prevent any refrigerant from entering the
combustion chamber. Refer to the Material
Safety Data Sheet for Freon R22. This sheet
explains the potential hazards and how to avoid
them.
UGH024/1103
Portable Chillers
INSTALLATION
3-3
PREPARING FOR
INSTALLATION
Plan the location for the chiller and prepare the area properly.
Position the chiller as close to the process machine as possible. Place the chiller in position near the process machine so
that fluid lines can be connected from the process machine to
the chiller and back.
Chiller
Process machine
Alternate
locations
Make sure the area where the chiller is installed has:
l
A grounded power source.
Check the chiller’s serial tag for the correct amps, voltage, phase, and cycle. All wiring should be completed by
qualified personnel and comply with your region’s electrical codes.
l
Clearance for safe operation and maintenance.
Make sure there is two feet clearance around the chiller
for proper operation. After positioning lock casters to prevent chiller from moving. For maintenance and servicing,
be sure there is enough clearance to remove all access
panels completely.
24 inches
(610 mm)
24 inches
(610 mm)
24 inches
(610 mm)
24 inches
(610 mm)
l
3-4
INSTALLATION
Available water source.
If installing a water-cooled unit, makes sure water source
is plumbed to chiller installation location. High points in
plumbing require vent valves; low points require drain
valves.
Portable Chillers
UGH024/1103
Warm fluid from process equipment enters the chiller at the
From Process valve and chilled fluid returns to the process
equipment through the To Process valve.
1
Remove the shipping plastic pipe plug from
the female connections on the back of the portable chiller.
2
Make sure the male pipe threads are clean
3
4
Wrap threads with Teflon or pipe dope.
MAKING
PROCESS
PLUMBING
CONNECTIONS
and new.
Connect the From Process valve (Factory
Optional) on the back of the chiller to the From
Process tubing. Start by hand until the threads engage and
then tighten with a pipe wrench. Tighten only enough to
prevent leaks; do not over-tighten!
5
Connect the To Process valve (Factory
Optional) on the back of the chiller to the return
tubing. Start by hand until the threads engage and then
tighten with a pipe wrench. Tighten only enough to prevent leaks; do not over-tighten!
For the Water-cooled Chillers connect the water source for
cooling to the Condenser Water inlet on the back of the
chiller. Connect the Condenser Water outlet for returning
water.
Condenser
Water outlet
(water-cooled only)
Condenser
Water inlet
(water-cooled only)
To Process
From
Process
Chillers to
YY tons
Chillers to
XX tons
For overhead piping installations, see Overhead Plumbing
Details, in the Appendix.
UGH024/1103
Portable Chillers
INSTALLATION
3-5
FILLING THE
CHILLER
The chiller is shipped without coolant. The chiller is filled
manually during installation. Use water as the coolant down to
40°F (4°C). Below 40°F and down to 20°F (-7°C), use an ethylene glycol or propylene glycol solution (see Percent Glycol
vs. Temperature chart).
To fill with water:
NOTE: If your chiller has the
optional auto-fill reservoir, the
level switch will automatically
fill the reservoir with water as
needed.
1
2
Attach water hose to Fill/Drain valve.
3
Open the Fill/Drain valve and fill chiller
4
5
Close the Fill/Drain valve.
6
Disconnect water hose from Fill/Drain valve.
Close the To Process and From Process
valves.(Factory Optional)
to the fill mark on the Water Level gauge. If the chiller is
overfilled, the excess water spills out the vent tube.
DO NOT OVERFILL.
Check the coolant level.
When the chiller is turned on the coolant level drops as
the coolant begins to circulate, filling the connected
plumbing. Check the coolant level on the back of the
chiller. The coolant level shows on the water level gauge.
Make sure coolant level is filled to the mark on the
gauge. Add more if needed.
To Process
valve
Water level
gauge
From Process
valve
Fill/Drain valve
3-6
INSTALLATION
Portable Chillers
UGH024/1103
To fill with glycol solution:
1
Mix the glycol to the proper percentage.
Use the table to determine the percentage (by volume) of
glycol needed for the process temperature (in °F) you
require. Mix the proper percentage of glycol with water.
FILLING THE
CHILLER
CONTINUED
Recommended Percentages of Glycol for
Chilled Water Freeze Protection
Discharge water % Propylene
% Ethylene
Temperature
Glycol
Glycol
Above 45°F
0
0
40°F
20
15
35°F
25
20
30°F
35
30
25°F
40
35
20°F
45
40
Below 20°F
Consult Factory
2
Close the To Process and From Process valves.
(Factory Optional)
3
Open the Fill/Drain valve and fill chiller
4
5
Close the Fill/Drain valve.
6
Set the Chiller control for ‘Percent Glycol’.
to the fill mark on the Water Level gauge. If the chiller is
overfilled, the excess fluid spills out the vent tube. DO
NOT OVERFILL.
Check the coolant level.
The coolant level drops as the coolant begins to circulate
and fill the connected plumbing. Check the coolant level
on the back of the chiller. The coolant level shows on the
water level gauge. Make sure coolant level is filled to the
mark on the gauge. Add more if needed.
Set the percent glycol using the PLC control (see Setting
Percent Glycol,section4). Do this step after main power is
connected to the chiller and initial startup has already
been performed.
UGH024/1103
Portable Chillers
INSTALLATION
3-7
CHECKING
REFRIGERANT
CHARGE
All chillers are fully charged with refrigerant at the factory.
Your chiller’s model nameplate identifies the type and amount
of total refrigerant charge required.
Check refrigerant charge while the chiller is running. Check
the refrigerant charge through the sight glass. For watercooled models open the side panel for a short period of time
(15 seconds maximum) and check the sight glass; for aircooled models, locate the sight glass through the wire mesh
side panel. Use a flashlight, if necessary, and check the sight
glass:
l Under full load conditions, the refrigerant should be
clear (no bubbles).
l Under low load conditions, when the hot-gas bypass
valves are operating, bubbles may be visible in the
sight glass. This is normal.
If the charge is low and the unit is under warranty, contact
Conair service. Otherwise have a local, certified refrigeration
technician add refrigerant to the system.
WARNING: Refrigerant hazard
Only certified refrigerant technicians should
examine and correct problems involving the
refrigerant circuit.
WARNING: Hazardous substance
When burned, Freon R22 refrigerant forms
Phosgene gas. If the chiller is placed in the
vicinity of equipment with combustible systems,
the combustion air intake must be ducted in
from the outside and sealed in such a manner
as to prevent any refrigerant from entering the
combustion chamber. Refer to the Material
Safety Data Sheet for Freon R22. This sheet
explains the potential hazards and how to avoid
them.
Sight
glass
3-8
INSTALLATION
Portable Chillers
UGH024/1103
WARNING: Improper installation, operation, or servicing may result in equipment damage or personal injury.
This equipment should only be installed, adjusted, and serviced by qualified technical personnel who are familiar with the construction, operation, and potential hazards of this type of
machine.
CONNECTING
THE MAIN
POWER
SOURCE
All wiring, disconnects and fuses should be
installed by qualified electrical technicians in
accordance with electrical codes in your region.
Always maintain a safe ground. Do not operate
the equipment at power levels other than what is
specified on the machine serial tag and data
plate.
WARNING: Electrical hazard
Before performing any work on this item, disconnect and lock out electrical power sources to
prevent injury from unexpected energization or
startup.
1
2
Open the chiller’s electrical enclosure.*
Connect the power wires to the terminals
(See the wiring diagrams that came with your machine).
Route the power cable through the hole in the side of the
chiller to the electrical enclosure.
3
Check terminal screws to make sure wires are
secure. Gently tug each wire; if wire is loose, use a
screwdriver to tighten the terminal.
4
Connect the ground wire to grounding lug.
Grounding lug
* Overload modules on UL panel only.
UGH024/1103
Portable Chillers
INSTALLATION
3-9
CHECKING
ELECTRICAL
CONNECTIONS
WARNING: Electrical hazard
Before performing any work on this item, disconnect and lock out electrical power sources to
prevent injury from unexpected energization or
startup.
1
2
Open electrical enclosure.*
Check the short-to-ground with an ohm meter.
Connect the ohm meter to each of the three terminal
screws and to the grounding lug. Test all three for resistance. The minimum resistance to ground should be 1
megohm. If it resistance is less that 1 megohm there is a
leak in the system.
Optional motor
starter protectors
with “UL” option
Grounding lug
3
Close the electrical enclosure.
The chiller is now ready for initial startup. Follow the rest of
the installation steps for the control you have (TIC or PLC).
* Overload modules on UL panel only.
3-10
INSTALLATION
Portable Chillers
UGH024/1103
Check the rotation of the pump. Compare pump rotation to
arrow direction on pump. If pump is not turning in proper
direction, disconnect main power to chiller, swap any two
incoming power wires; reapply main power. Check for leaks
inside the chiller cabinet; fix any leaks and dry the inside of
the chiller before proceeding.
TIC CONTROL
CHECKING
PUMP ROTATION
If alarm light comes on check the alarm description and follow troubleshooting guide for repair.
Press the on/off and enter buttons simultaneously to turn on
Pump. Press the on/off and enter buttons simultaneously to
turn off pump.
Inspect the compressor. If the compressor is running backwards, disconnect the Chiller from the main power supply,
switch any two incoming main power leads, and reapply main
power supply. Wait three minutes. The compressor should
now be running in the proper direction.
Compressor rotatation only needs to be checked if using a 7.5
ton unit or higher. Pump rotation if done correctly by reversing leads at the incoming power will provide proper rotation
for the rest of the three phase motors. You will not be able to
see compressor rotation unless you have refrigeration gauges.
NOTE: If correct pump rotation was established, the compressor rotation will be correct. Both the pump and compressor are phased together during manufacture.
Check the water level gauge on the back of the chiller. If the
fluid level is low, follow the steps to add fluid. See Filling the
Chiller, section 3.
Document number
Document name
TIC CONTROL
CHECKING THE
SCROLL
COMPRESSOR
ONLY MODELS
PCW 7.5, 10, AND 15
AND
PCA 7.5, 10
AND
13
TIC CONTROL
CHECKING THE
WATER LEVEL
GAUGE
INSTALLATION
3-11
PLC CONTROL
INITIALLY
WARMING THE
CHILLER
WARNING: Initial startup
Do not press any buttons after initially applying
power to the chiller. Let the chiller set, undisturbed, for a minimum of 8 hours before starting
the chiller. This is necessary to allow the
crankcase heater to warm properly, and to prevent the refrigerant from pooling in the compressor.
1
Turn on main power source.
The control boots up and when finished, the screen displays the Portable Chiller model number and the six-digit
serial number.
Conair Chiller
PCW - 30 123456
2
Press the Start Chiller button.
Check the Pump and Compressor lights on the control
panel; they should turn on and off as the pump and compressor cycle on and off. The To Process temperature displays on the control. The To Process temperature is realtime temperature. It should change as the chiller runs and
cools the fluid.
After starting the chiller, you need to check pump rotation, the
compressor, and the sight glass. If the chiller is not working
properly at any time, press the red Stop button to turn off the
chiller.
3-12
INSTALLATION
Portable Chillers
UGH024/1103
After the initial warm up, check for proper pump rotation. If
the pump rotation is correct, all other 3-phase components will
be in the proper rotation and do not need checked.
Manually turn on the pump from the main screen:
1
PLC CONTROL
CHECKING THE
PUMP ROTATION
Press the arrow pointing to Run on the screen.
STATUS
SETUP RUN ALM
press arrow
2
Use the Scroll arrows to scroll through
Run screens to the Manual Pump screen.
Manual Pump
ON OFF
press arrow
3
Press the ON arrow.
The pump should begin running. Open the chiller cabinet
and check the rotation of the pump. The pump should be
turning clockwise. If the pump is not turning or is turning
counterclockwise, press the Stop Chiller button, disconnect the main power to the chiller and swap any two main
incoming wires. Reapply main power to the unit, scroll to
the Manual pump screen and again turn on the pump.
Pump should now be turning clockwise. If an alarm
occurs, see Answering Alarms, in the Troubleshooting
section. If alarm continues or reoccurs, call your Conair
Service representative.
4
Press the Escape/Previous Screen button.
The control returns to the main screen.
UGH024/1103
Portable Chillers
INSTALLATION
3-13
PLC C ONTROL
CHECKING FOR
LEAKS
After checking pump rotation, continue with startup by checking the chiller for leaks. Do this by turning on only the pump
from the control and letting the pump run while checking the
inside of the chiller.
1
Press the Next arrow on the control to move
to the Main screen.
The Main screen displays:
STATUS
2
SETUP RUN ALM
Press the Run arrow on the screen.
STATUS
SETUP RUN ALM
press arrow
3
Press the Scroll arrows to scroll to the Manual
Pump screen. The Manual Pump screen displays:
Manual Pump
ON OFF
press arrow
4
Press the Pump ON arrow.
With the pump running check inside the chiller for leaks.
If you find leaks:
1
Press the Stop Chiller button on the
2
Disconnect the chiller from the main power
control panel.
supply and repair any leaks. Dry any moisture inside the
chiller.
3
3-14
INSTALLATION
Reconnect the main power supply.
Portable Chillers
UGH024/1103
Only after you have checked for leaks and checked for pump
rotation should you run the chiller. To initially run the chiller,
from the main screen:
1
Press the Run arrow.
STATUS
SETUP RUN ALM
PLC CONTROL
INITIALLY
RUNNING THE
CHILLER
press arrow
The Run screen displays:
RUN STOP PUMPDOWN
press arrow
2
Press the RUN arrow.
Verify that the chiller begins to run. Check that the
Compressor lights and the Process Pump light on the control panel are lit.
3
If you get an alarm message on the display:
If you get a Compressor 1, 2 Rotation Error message,
press the Stop Chiller button, unplug chiller from main
power supply, switch any two incoming main power
leads, and apply main power supply. Wait for the required
warmup time and then press Run arrow.
4
Press the Escape/Previous button to
return to the Main screen.
UGH024/1103
Portable Chillers
INSTALLATION
3-15
STOPPING THE
PLC CHILLER
To stop the chiller, press the Stop Chiller button on the control
panel.
The compressor shuts off after a pumpdown and the pump
shuts off 10 seconds later. This allows the chiller to pump
down the refrigerant system and store the refrigerant in the
receiver (water-cooled models) or condenser (air-cooled models. This prolongs the life of the compressor.
NOTE: If you want to restart the chiller immediately after
stopping it, pressing the Run arrow on the display starts the
pump (the Process Pump light on the control panel lights) but
the compressor will not turn on for three minutes. After three
minutes the compressor turns on and the Compressor light on
the control panel lights. This allows Compressors internal
temperatures to lower, making restart easier, and prolonging
the life of the compressor.
If the chiller is not working properly at any time, stop the
chiller and refer to the Troubleshooting section. If you do not
encounter any problems, proceed to the Operation section.
3-16
INSTALLATION
Portable Chillers
UGH024/1103
OPERATION
l TIC Control Features . . . . . . . . . . . . . . . . . .4-2
l PLC Control Features . . . . . . . . . . . . . . . . .4-3
l Before Starting . . . . . . . . . . . . . . . . . . . . . .4-4
TIC CONTROL
l Control Features . . . . . . . . . . . . . . . . . . . . .4-5
l Changing the Setpoint
Temperature . . . . . . . . . . . . . . . . . . . . . . .4-6
l Stopping/Starting the Chiller . . . . . . . . . . . .4-6
l Menu Features . . . . . . . . . . . . . . . . . . . . . . .4-8
l Changing the Settings . . . . . . . . . . . . . . . . .4-9
l Tuning the Chiller . . . . . . . . . . . . . . . . . . . .4-9
PLC CONTROL
l Powering Up . . . . . . . . . . . . . . . . . . . . . . .4-17
l Running/Stopping the Chiller . . . . . . . . . .4-17
l Viewing Chiller Status Screens . . . . . . . . .4-18
l Programming Settings . . . . . . . . . . . . . . .4-21
l Changing Setpoint
Temperature . . . . . . . . . . . . . . . . . . . . . .4-22
l Resetting PID Settings . . . . . . . . . . . . . . .4-23
l Changing High Temperature
Deviation . . . . . . . . . . . . . . . . . . . . . . . .4-24
l Setting Percent Glycol . . . . . . . . . . . . . . . .4-25
l Setting Fan Setpoints . . . . . . . . . . . . . . . .4-27
l Selecting the
Temperature Scale . . . . . . . . . . . . . . . . .4-28
l Setting Auto Tune Mode . . . . . . . . . . . . . .4-29
l Setting Discharge
Pressure Setpoint . . . . . . . . . . . . . . . . .4-31
l Selecting PID Values . . . . . . . . . . . . . . . . .4-32
l Manually Starting/
Stopping the Pump . . . . . . . . . . . . . . . .4-33
Portable Chillers
UGH024/1103
4-1
TIC CONTROL
FEATURES
The TIC control lets you view the status of the chiller and
change settings.
Display
3-digit screen shows Process temperature,
Alpha Alarms and Operation indicators.
Indicator light shows hot gas unloading.
Main Menu
Contents
Setpoint Procedure
Alarm Codes
Informs user of
types of alarms
Status Lights
For Pump, Hot Gas Bypass
and Compressor
On/Off Button
Powers on/off the
chiller
Raise Button
Increases values, and
steps up through menus.
Enter
Press to enter or change
setpoint, and to index to
the next menu.
Lower Button
3-Digit Alpha/numeric display for temperatures and
alarms
4-2
OPERATION
Portable Chillers
Decreases values; and
steps down through
menus.
UGH024/1103
PLC CONTROL
FEATURES
Display Screen
Shows status, setup
and run modes
Option Arrows
Status Lights
Show the status of the compressors, process pump, and
alarm/shutdown
Choose parameters displayed on the screen
Scroll through the display
screens
PLC Indicator Lights
Show power, program
and service indications
Stop Chiller Button
Press to stop chiller
UGH024/1103
Up / Down Scroll
Arrows
Navigation Buttons
Save new settings,
reset alarms and return
to main screen
Numerical Keypad
Choose and change
numerical values
Portable Chillers
OPERATION
4-3
BEFORE
STARTING
Before you start daily operation of the chiller, you need to
perform scheduled preventative maintenance. Necessary maintenance is describe in the Maintenance section of this Users
Guide.
WARNING: Electrical hazard
Be sure that power to the chiller is OFF when
doing any maintenance on the chiller. Follow all
safety rules when performing any maintenance
on this equipment.
Daily maintenance includes:
l Checking electrical connections
l Checking process fluid level in the pump tank
l Checking the condenser coil for debris (air-cooled
only)
l Verifying pump discharge pressure
l Inspecting piping for leaks.
NOTE: The daily, weekly, monthly, and annual maintenance
procedures are detailed in the Maintenance section. Go there
for the detailed maintenance descriptions.
Before starting the chiller be sure to:
l Open the To Process valve (Factory Optional)
to the full open position.
l Open the From Process valve (Factory Optional)
to the 3/4 open position. You will need to adjust this
valve when the chiller is running to obtain the desired
pump discharge pressure. To find the approximate
water flow, refer to the Pump Curves in Description
section.
l Open the supply valve
if the chiller has the optional Auto-fill reservoir.
To Process valve
(Factory Optional)
From Process valve
(Factory Optional)
You are ready to use your Chiller. Proceed to the steps for
your type of control: TIC or PLC.
4-4
OPERATION
Portable Chillers
UGH024/1103
Menus on the Controller:
The controller has information available in 5 areas. Four of
them are user accessible. These are: the Main Menu, the
Setpoint Menu, the Configuration menu and the Alarm Page.
The service page also has additional parameters that are
accessible in cases of need.
GENERAL TIC
CONTROL
FEATURES
Relaying Control information via three modes:
The controller relays information via three modes.
1. The status lights indicate the state of the machine and its
control components. In the chiller these are Pump, Hot gas
valve, and Compressor.
2. The digital indication of the process in temperatures and
times.
3. The alpha abbreviation of the process parameters to isolate
the variables and the alarms from each other.
Main Menu
The main menu is the normal operating page. The controller
always defaults to this page after a certain amount of inactivity (buttons being pushed). The first screen is the process variable. This is a user selectable parameter and could be the to
process, from process or an average temperature. The rest of
the variables are accessed in a circular queue using only the
up and down arrow keys.
The parameters include:
Process Variable- in the units selected on the Configuration
page. This parameter has its decimal fixed to whole numbers
only.
Machine State - For the Chiller this is on/off.
The To Process temperature - in units selected as above. This
parameter has its decimal fixed at 0.1º
The From Process temperature - in units selected above. This
parameter has its decimal fixed at 0.1º
There are two additional temperature indicators available for the
chiller and must be purchased separately. If installed they will
indicate only the temperature of the media to which they are
exposed. These were intended to display condensing media temperature to the chiller operator however they could display any
temperature in the operating range of 0-250ºF. These temperature displays are also shown as whole numbers. If these are
not connected;
is displayed.
UGH024/1103
Portable Chiller
OPERATION
4-5
RESETTING THE
TIC CONTROL
AND POWER UP
TIC CONTROL
FEATURES
CHANGING THE
SETPOINT (SET)
When powered, the chiller control automatically performs a
bootup routine. When the bootup routine is complete, the display will alternate between “rst” and the actual to process
temperature. To reset the control on power up, press the up
and down arrow keys simultaneously for 1 second. This will
reset the control and return it to he operating mode it was in
before the power was disconnected, this may have been running mode. If so and the chiller must be stopped, immediately
press the stop/start button after resetting the control. The
chiller is now ready to accept a setpoint and begin operation.
Setpoint
The Setpoint menu only has one parameter, which is the setpoint. This setpoint temperature is the water temperature that
is required to be supplied by the chiller. The setpoint range of
the chiller is 20°F - 65°F, however the standard settings will
only allow the operator to set as low as 45°F. If a temperature
lower than 45°F is required the low setpoint limit (LtS) and
the low setpoint alarm (SPL) must be adjusted accordingly.
These parameters are discussed in later pages. Additionally, an
industrial Glycol will need added to chilled water solution to
prevent freezing. See Chart in Filling the Chiller, Section 3.
To set the temperature setpoint:
To return to the To
Temperature screen from any
other screen, you must wait
(do not push buttons during
this time)for the control to time
out to home page “process
temp”
1
Press the Enter button until “SEt” is displayed.
2
Press Enter again to display value of
Setpoint,
3
To raise and lower the setpoint temperature. Each time you press the arrow the temperature
changes one unit. Stop when you reach the temperature you want. This value is in the units chosen ºF or ºC.
See Changing Units, Section 4.
4
4-6
OPERATION
Press the Enter button, to accept the new setpoint temperature. The display returns to the actual
process temperature. If the Enter button is not
pressed the change in setpoint is not retained and any
changes required must be reentered and confirmed.
Portable Chiller
UGH024/1103
Starting/Stopping the Chiller
Press the Stop/Start Chiller button.
Check the Pump and Compressor lights on the control panel;
they should turn on and off as the pump and compressor cycle
on and off. The To Process temperature displays on the control, and is the real-time temperature. It should change as the
chiller runs and cools the fluid. This is what the chiller controls.
STARTING/
STOPPING THE
CHILLER
To safely stop the chiller at any time, press the Stop/Start
Chiller button on the control panel. The compressor should
stop immediately but the pump runs for 2.5 seconds.
The chiller remains on, but stopped. The display screen on the
control remains on.
NOTE: When you press the Stop/Start Chiller button, the
pump and compressor both stop. If you want to restart immediately by pressing the Stop/Start Chiller button, the pump
will turn on but the compressor will not turn on for three minutes. The Process Pump light on the control panel will light
immediately. After three minutes the compressor turns on and
the Compressor light on the control panel lights.
TIC CONTROL
CHANGING
ADJUSTABLE
PARAMETERS
The control allows you to change 13 settings:
l
l
l
l
l
l
l
l
l
l
l
l
l
l
Temperature Units-UN
Lower Setpoint Limit-LtS
Process Variable-PUS
Tuning the Chiller-PiT
Low Pressure Alarm-LP1
Deviation temperature ignore time-Dtt
Flow Switch time-FS1
Low Temperature Alarm Setpoint-SPL
High temp alarm-HtA
High temp safety-HtS
Deviation temperature-Dt
High temperature setpoint
Alarm Bell Acknowledge time-AAT
Software revision-CO1 (read only)
Settings are factory preset and will fit most applications. Once
your system parameters are established these values are rarely
accessed and changed. If you have any problems or questions,
call your Conair Service representative.
UGH024/1103
Portable Chiller
OPERATION
4-7
TIC CONTROL
CHANGING THE
TEMPERATURE
UNITS (UN)
TIC CONTROL
CHANGING
THE LOW SETPOINT LIMIT
(LTS)
To return to the To Process
Temperature screen from any
other screen, press and hold the
button for at least 5 seconds until the temperature displays.
NOTE: Setpoint will show down
to 20°F but it is limited by the
variable to 40°F unless
changed.
4-8
OPERATION
The Temperature units parameter allows selection of the displayed temperature units. The available selection is either
degrees Celsius or Fahrenheit. ºC or ºF depicts this.
1
Press the Enter key unit the default configuration page UN is displayed.
2
3
Press Enter again to show ºC or ºF.
4
Press Enter to accept the units.
Toggle between the up/down to select
your desired units.
The default low temperature limit for the to process fluid is
factory set at 45 °F. This temperature limit is the lowest temperature you can operate the chiller at with out add Glycol. If
you want to operate below this factory setting, you will need
to adjust this setting accordingly. Additionally, you will need
to add the correct percent of Glycol to the process water side
of the system and adjust the (SPL). See Filling the Chiller,
Section 3.
Once the chiller is filled with the correct percent of Glycol
proceed to set the Low Setpoint Limit.
1
Press the Enter key unit the default configuration page UN is displayed.
2
Toggle up/down keys until LtS displays
on the screen. LtS flashes, along with the
current low limit temperature.
3
Press Enter and Press up/down until you
get to the desired value.
4
Press Enter to accept the new value.
Portable Chiller
UGH024/1103
The Process variable selector allows the operator to select the
controlled temperature from the following: To Process, From
Process and Average. The default is the average temperature
and the tuning parameters are set up for this. If the chiller is
used in a no tank system then the From process temperature
should be selected.
Depending on system size select the appropriate tuning parameter set, See Tuning the Chiller.
TIC CONTROL
CHANGING
THE PROCESS
VARIABLE (PUS)
This features allows the operator to select the controlled temperature from the following: To process, From process and
Average. The default is set at Average.
1
Press the Enter until the default configuration
page UN.
2
Toggle up/down keys until until PUS
flashes on the display
3
Press Enter and use the up/down keys to
select “to” fro” or A”.
4
Press Enter to accept the units.
The controller has three pre-configured tuning parameter sets,
one of which should allow optimum temperature control.
Following is a description of each of the choices available to
an operator:
Slow Responding system:
Select the slow setting “SLO” for large systems*. More than
1,700 pounds (200 gallons) of water and more than 14,000
lbs of steel might be considered a large system. This setting
has the smallest proportional band (1ºF), which allows larger
changes in the control output when the process temperature is
far from setpoint. This should reduce cycling around the setpoint.
Normal Responding System:
Normal “nOr” is the factory default tuning setting, as it will
cover the majority of applications. This setting is appropriate
for systems* with 250 to 1,700 pounds (30-200 gallons) of
water and 2,000 to 14,000 pounds of steel. The default value
for the normal proportional band is 2ºF.
UGH024/1103
Portable Chiller
TIC TUNING
THE CHILLER
(PIT)
NOTE: Normal paratmeter is the factory
default setting
Continued
OPERATION
4-9
TIC TUNING
THE CHILLER
(PIT)
CONTINUED
Fast Responding System:
Select the fast setting “FSt” for small systems*. Less than 250
pounds of water (30 gallons) and 2,000 pounds of steel might
be considered a small system. This setting has the largest proportional band (4ºF), which allows a fast response to small
deviations between the process variable and setpoint. This
system is typical for small chillers with small molds or other
process machinery. If improperly set up, the configuration
might cause oscillation around the setpoint temperature.
Setup Menu
To access the Setup Menu,
TIC CONTROL
CHANGING THE
LOW PRESSURE
ALARM IGNORE
TIME (LP1)
4-10
OPERATION
1
Press and hold the “enter” key for approximately
five seconds, until the service menu is active.
2
Toggle the Up/Down keys until “PiT” is dis
played. Press the “enter” key once to see the cur
rent tuning setting.
3
Toggle the Up/Down arrow keys to the desired
SLO, nOr or FSt setting. Press “enter” again to
save this value. If at any time not key is pressed for 10
seconds the control will return to “Home Page”, dis
playing the process variable. If the unit is in any alarm
condition, you must clear it before you can adjust the
tuning selector.
This feature allows you to set the time from when a low
refrigerant pressure alarm is sensed to when the alarm signals.
The range for this alarm is 0-60 seconds standard default
value is 5 seconds. This default value should be adequate for
all systems and should not need adjusted. This alarm can
cycle up to three times per hour before a latching shutdown
occurs. Once a latching shutdown occurs “PAL” will flash on
screen and the unit will need reset.
1
Press the Enter key until the default configuration page Un appears on the screen.
2
Toggle up/down keys until until LP1 flashes on the display
3
Press Enter and use the up/down keys to
select your desired amount of time.
4
Press Enter to accept the units
Portable Chiller
UGH024/1103
The deviation temperature ignore time is the time from when
a deviation from setpoint is sensed until it is displayed. The
deviation from setpoint occurs when the actual temperature of
the fluid is some value away from the setpoint (value is set by
dt).
The deviation temperature ignore time range is 0-600 seconds, the default is 300 seconds and should be sufficient for
most applications.
1
Press the Enter key until the default configuration page Un appears on the screen.
2
Toggle up/down keys until until Dtt flashes
on the display
3
Press Enter and use the up/down keys to
select your desired amount of time.
4
Press Enter to accept the units.
This feature ensures that there is adequate flow through the
evaporator before allowing the compressor to start. The value
set in this parameter is the time after start-up. The control will
wait for the flow switch to be made before shutting down. If
shut down occurs FAL will flash on the control and request
the unit to be reset. Proceed to troubleshooting section if this
occurs. The range is 0-20 seconds, the default value is 10 seconds and should be adequate for most applications.
1
Press the Enter key until the default configuration page Un appears on the screen.
2
Toggle up/down keys until until FS1 flashes on the display
3
Press Enter and use the up/down keys to select
your desired amount of time.
4
Press Enter to accept the units
UGH024/1103
Portable Chillers
TIC CONTROL
CHANGING THE
DEVIATION
TEMPERATURE
IGNORE TIME
(DTT)
TIC CONTROL
SETTING THE
FLOW SWITCH
DELAY TIME
(FS1)
OPERATION
4-11
TIC CONTROL
CHANGING
THE LOW
TEMPERATURE
ALARM SETPOINT
(SPL)
The low limit temperature alarm setpoint is the setpoint that
protects the chiller from undershooting past the required
process water temperature. The range for this setting is 19.479 and the default is 39. For most applications this value will
need set about 3°F below the LTS value.
1
2
Press Menu button until UN is displayed.
Press Enter again to display value of Low
Limit Setpoint to raise and lower the low limitsetpoint temperature. Each time you press the arrow
the temperature changes one unit. Stop when you
reach the temperature you want.
3
Press the Enter button, to accept the new setpoint temperature. The display returns to the actual
process temperature.
TIC CONTROL
SETTING THE
HIGH TEMPERATURE ALARM
(HTA)
TIC CONTROL
SETTING THE
HIGH TEMPERATURE SAFETY
(HTS)
4-12
OPERATION
This feature will indicate when the chilled water system temperature is above an acceptable level. This alarm will be indicated by a flashing HtA. This is not a shutdown alarm only a
indicator. The setpoint range is 50-95 and the default is 85°F
which should be adequate for most applications.
1
2
Press Menu button until UN is displayed.
Toggle up/down key until HtA flashes on
the display.
3
Press Enter and use the up/down keys to
select your desired amount of time.
4
Press Enter to accept the units.
The High temperature safety is the highest temperature the
process water temperature can get before a shutdown. If shutdown occurs it will be indicated by a flashing (THS). Range
for this parameter is 75-95 and default value is 95°F.
1 Press Menu button until UN is displayed.
2
Toggle up/down key until HtS flashes on
the display.
3
Press Enter and use the up/down keys to
select your desired amount of time.
4
Press Enter to accept the units.
Portable Chillers
UGH024/1103
This is the temperature value that the actual temperature can
be away from the setpoint. If the actual temperature is more
than the deviation value away from the setpoint the Dtt will
initiate and a passive alarm dtA will occur 300 seconds later.
1
2
Press the Enter key until the default configuration page Un appears on the screen.
Toggle up/down buttons until display
flashes dt, press “Enter”. Use the up/down
buttons to set your desired deviations setpoint temperature.
3
TIC CONTROL
CHANGING THE
DEVIATION
FROM SETPOINT
TEMPERATURE
(DT)
Press the Mode/Enter button, to accept the
new setpoint temperature.
The Alarm Acknowledge timer (AAT) sets the time that an
alarm can be acknowledged and silence without being satisfied. The default value of this parameter is 0 minutes. In this
case the alarm silence does nothing and alarms can only be
cleared after the alarm condition is nullified. The range of
times that can be programmed is 0-60 minutes.
1
Press the Enter key for 5 seconds to show
the default configuration page UN.
2
Toggle up/down keys until until AAT flashes on the display
3
Press Enter and use the up/down keys to
select your desired amount of time.
TIC CONTROL
CHANGING THE
ALARM
ACKNOWLEDGE
TIMER (AAT )
NOTE: In the vary rare case that none of these
settings provide adequate control, please consult
the Conair service to further adapt these variables.
UGH024/1103
Portable Chillers
OPERATION
4-13
TIC C ONTROL
READING THE
SOFTWARE VERSION (co1)
TIC ALARMS
The Version of the software is depicted by the c “xx” parameter. This “read only” parameter and depicts the version of the
software that has been downloaded into the controller. This
number will be a paramount importance in obtaining service
support. EX CØ1 is version 01 of the chiller program.
Alarm Stage
When the controller senses an alarm, the specific alarm flashes alternating with the actual process variable on the display.
These alarms must be cleared when a safe condition exists. In
addition when a power up condition exists the display will
flash RST to alert the operation that the controller must be
reset before operation can continue/begin.
The final area that informs the user is the alarm stage. All
alarms are indicated by flashing “on” LED.
There are three types of alarms that are resident in the controller.
First type of Alarm
First is the annunciating cycling type. This alarm will flash its
code opposite to the process variable but does not shut the
compressor down. These alarms are:
DtA: The deviation from setpoint alarm energizes when the
displayed temperature is above or below the setpoint by more
than the deviation temperature setting (dT) and for longer than
the deviation temperature ignore time(dtt).
TAH: This is a warning alarm only and will flash when the
process temperature gets above this alarm setting (htA).
Second type of Alarm
Second type annunciating type will cycle three times in one
hour before latching and requiring reset. The low refrigerant
pressure alarm PAL is this type of alarm. The bell and strobe
will energize while the system is in low pressure but turn off
when the pressure switch is satisfied.
Continued
4-14
OPERATION
Portable Chillers
UGH024/1103
.
PAL: (Pressure alarm low) flashes when the low refrigerant
pressure switch has sensed low pressure for more than the low
pressure ignore time (lpl). This is a cycling alarm up to three
times per hour.
TIC ALARMS
CONTINUED
Third type of Alarm
Third type of alarm is a latching type. This alarm shuts down
the compressor on t he first trip and must be manually reset
upon correction of the fault condition. This high pressure and
sensor failure alarms are of this type.
The indicators that flash when the unit is in alarm are:
RSt: Flashes on restoration of power after a power loss.
PSH: Flashes on the Refrigerant high-pressure switch. This is
a latching alarm and the high-pressure switch might
require to be manually reset before this alarm can be acknowledged.
SF2: Indicates that the To process temperature sensor is
indicating out of range.
Continued
UGH024/1103
Portable Chillers
OPERATION
4-15
TIC ALARMS
CONTINUED
THS: Indicates that the compressor has shut down due to
high temperatures to the process that could damage the compressor (Hts)
FAL: (Flow alarm low) flashes when the process water flow
switch has detected a low flow condition for longer than the
low flow ignore timer (fsl).
TAL: The low temperature alarm shuts down the compressor
when the leaving water temperature sensor detects a temperature below the low temperature alarm setpoint(spl).
The final alarm is the compressor maintanence alarm. The
alarm flashes the run light but does not indicate on the display.
4-16
OPERATION
UGH024/1103
Portable Chillers
Plug in the power cord to restore power after any required
maintenance. The chiller requires 15 minutes warmup time
after it is plugged in for the crankcase heater to warm up.
1
PLC CONTROL
POWERING UP
Turn on the main power.
The chiller control automatically performs its bootup routine. The screen displays the Portable Chiller model number along with the serial number
Conair Chiller
PCW - 30 123456
PCA or PCW
identifies Air-cooled or
Water-cooled model
30
nominal tonnage
XXXXXX
6-digit factory assigned
serial number
the Scroll arrow to move to the
2 Press
Main screen.
The main screen displays:
STATUS
SETUP RUN ALM
The main screen lets you:
l view the status of the water level, process temperature, process setpoint, suction pressure, percent glycol,
low temperature cutout and discharge pressure.
l view and change the setups for temperature setpoint,
Autotune mode, high temperature deviation, and percent glycol solution
l run or stop the chiller
l view alarm information
l perform maintenance with password clearance
3
Press the arrow pointing to the selection
you want displayed on the screen.
STATUS
SETUP RUN ALM
Choose a selection
Portable Chillers
UGH024/1103
OPERATION
4-17
PLC CONTROL
VIEWING
STATUS
SCREENS
After you have viewed all the Status screens and made any
necessary changes to the Setup screens, you are ready to run
the Chiller. To run the chiller from the main screen:
1
Press the Run arrow on the Main screen.
STATUS
SETUP RUN ALM
press arrow
2
Press the RUN arrow.
RUN STOP
PUMPDOWN
press arrow
In Run mode the compressor cycles off at 4° below the
setpoint if the load is too low for the hot gas to keep the
compressor from shutting down. If the compressor shuts
down it will not restart until after 3 minutes and only if
temperature is at least 1°F above setpoint.
If you want to stop the chiller and continue to run the
pump, choose PUMPDOWN.
3
Press the Escape/Previous Screen button.
The control returns to the main screen.
To stop the chiller at any time, press the red Stop Chiller button on the control.
The chiller control and display screen remain on, but the
pump and compressor stop.
If you want to restart immediately, the pump will turn on but
the compressor will not turn on for three minutes. The
Process Pump light on the control panel will light immediately
and the compressor light will flash. After three minutes the
compressor turns on and the Compressor light on the control
4-18
OPERATION
Portable Chillers
UGH024/1103
The Status screens are read-only screens. You cannot make
changes to these screens. To view the status screens:
1
Press the Status arrow on the Main screen.
STATUS
SETUP RUN ALM
PLC CONTROL
VIEWING
STATUS
SCREENS
Press arrow
2
Use the scroll arrows to scroll through
the status screens.
Verify that the readings each screen displays are
the ones you want. You cannot change the readings of the screens from the Status screens. You can
change to status of:
l
l
The Status button does not
let you change the status,
only view it.
Setpoint temperature
Percent Ethylene Glycol by volume
by going to the Setup screens. You can not change the
other readings; they are read-only screens, reporting environmental conditions.
3
Press the Escape/Previous button at any time
to return to the main screen.
NOTE: Normal setpoint operating range is 40 - 70°F. If
glycol is added to the chiller and the percent glycol is entered into the control, the PLC automatically adjusts the setpoint operating range.
UGH024/1103
Portable Chillers
OPERATION
4-19
PLC CONTROL
VIEWING STATUS
SCREENS
CONTINUED
Temperature
Set Point
45 F
45 F
From Process Temp
60 F
From Process Temp
Shows the temperature of the fluid entering the chiller. Can
display in degrees Fahrenheit or Celsius.
Chiller % Loading
90%
Percent chiller load
Shows the current percent of chiller capacity being used.
This percentage is a read-only value and changes as the
chiller cycles.
Water Level
Level Okay
Water level
Displays the current water level status. Screen displays
Level Okay, or Level Low. If the level is low, see Filling
the Chiller, in the Installation section.
COMP 1 = ON
COMP 2 = OFF
IN SERV
IN SERV
Suction Pressure 1
70 PSIG
% E.G. BY VOL0
LOW TEMP CUTOUT
Compressors (for units with dual compressors, 20 ton+)
Displays the activation status of the two refrigeration circuits, compressor 1 and compressor 2. ON is activated;
OFF is disabled. Lists In/Out of Service for each.
Refrigerant suction pressure
Shows the status of the refrigerant suction pressure in PSIG
for compressor(s) 1 and 2, if chiller has dual compressors.
NOTE: Typical refrigerant suction pressure is between 55
PSIG and 95 PSIG.
Discharge Pressure 2
250 PSIG
4-20
Status screens include:
Temperature
Displays the To Process temperature and the Setpoint temperature. To change the Setpoint temperature, go to
Changing Setpoint Temperature, in the Operation section.
Refrigerant Discharge pressure
View the status of the refrigerant discharge pressure in
PSIG for compressor(s) 1 and 2, if chiller has dual compressors. Typical discharge pressure is between 190 PSIG
and 325 PSIG.
40 F
OPERATION
Percent Ethylene Glycol by Volume and
Low Temperature Cutout
Displays the percentage of ethylene glycol or propylene
glycol solution (by volume) in the chiller in degrees
Fahrenheit. Changing the percent glycol automatically
changes the low temperature cutout.
Portable Chillers
UGH024/1103
The PLC control allows you to program various parameters
for the Chiller:
l Temperature Setpoint
The temperature you want the To Process liquid.
l High Temperature Deviation
Set the number of degrees the temperature can rise
above the setpoint temperature without an alarm.
l Percent Glycol by Volume
Use when you use an ethylene glycol or propylene glycol solution to lower the To Process temperature.
Changing the percent glycol automatically changes and
displays the low temperature cutout, in °F.
l Fans (Air-cooled only)
Set the upper and lower temperatures for the fans to
cycle. This screen is password protected.
PLC CONTROL
PROGRAMMING
SETTINGS
If you do not need to change
any settings on the control,
go to Running the Chiller.
To program settings from the Main screen:
1
Press the Setup arrow.
STATUS
SETUP RUN ALM
press arrow
The first Setup screen displays:
Temperature
Setpoint
2
45 F
45 F
Press the Up and Down Scroll arrows to
scroll through the Setup screens. Stop at the one you
want to change.
UGH024/1103
Portable Chillers
OPERATION
4-21
PLC CONTROL
CHANGING
SETPOINT
TEMPERATURE
Use the Temperature Setpoint to set the temperature you want
the water to be exiting the chiller at the To Process valve.
To display the Setpoint temperature from the Main screen,
press the Setup arrow. The Setpoint screen displays:
Setpoint
500 F
10 C
number
flashes
The current setpoint temperature displays in both Fahrenheit
(F) and Celsius (C). The temperature in °F flashes.
1
Press the arrows to change the setpoint
temperature. Pressing the (-) arrow lowers the temperature by one degree; pressing the (+) arrow increases the
temperature by one degree. Pressing the arrows automatically changes both scales.
Setpoint
50 F
10 C
Press arrows
OR
Use the numeric keypad
to set the temperature setpoint. Press the numbers for the
temperature you want, then press the Enter button to save.
2
4-22
OPERATION
Press the scroll arrows to move to the next
setup screen, or press Escape/ Previous Screen button to
return to the main screen.
Portable Chillers
UGH024/1103
Use the PID reset to return the control to the factory settings.
Use this if the autotune does not give good values or good
values are lost.
To reset PID from the main screen:
1
PLC CONTROL
RESETTING PID
SETTINGS
Press the Setup arrow.
STATUS
SETUP RUN ALM
Press arrow
2
Press the Scroll arrows to scroll through
the Setup screens. Stop when you get to the PID
Reset screen. Use this screen to reset the PID controls, set the discharge pressure setpoint (DPS) for
water-cooled chillers, and to set the on/off discharge
pressure setpoints for the air-cooled chillers with the VFD
option.
3
Press the PID Reset arrow.
PID Reset DPS
FANS
Press arrow
4
Press the scroll arrows to move to the
next setup screen, or press Escape/ Previous Screen
button to return to the main screen.
UGH024/1103
Portable Chillers
OPERATION
4-23
PLC CONTROL
CHANGING HIGH
TEMPERATURE
DEVIATION
Decide how many degrees above the setpoint you want the
chiller to deviate before an alarm occurs.
To set the high temperature deviation:
1
Press the Setup arrow.
STATUS
SETUP RUN ALM
press arrow
Continue to press the arrow to scroll through the Setup
screens. Stop when you get to the High Temp Dev screen.
The current high temperature deviation number displays
along with the - and +. The number flashes on the screen.
High Temp Dev
20
number flashes
2
Press the - or + arrows to set the high
deviation to the appropriate number. Each press of the (-)
arrow decreases the high deviation by one unit; each press
of the (+) arrow increases the high deviation by one unit.
Stop when you reach the number you want. The allowable
range is 3 - 20°F.
High Temp Dev
18
Press arrows
OR
Use the numeric keypad to enter the number
for the high deviation. After using the keypad press the
Enter button to save.
3 Press the Scroll arrows to scroll to the
the next Setup screen, or press the Escape/Previous
Screen button to return to the main screen.
4-24
OPERATION
Portable Chillers
UGH024/1103
To set the percent ethylene glycol or propylene glycol solution
determine the temperature of the process fluid you want.
Use water as the coolant for chilling the process fluid down to
40°F (4°C). Below 40°F and down to 20°F (-7°C), use a glycol solution.
Use the table to choose the proper percentage of glycol solution for the required temperature.
Recommended Percentages of Glycol for
Chilled Water Freeze Protection
Discharge water % Propylene
% Ethylene
Temperature
Glycol
Glycol
Above 45°F
0
0
40°F
20
15
35°F
25
20
30°F
35
30
25°F
40
35
20°F
45
40
Below 20°F
Consult Factory
PLC CONTROL
SETTING
PERCENT
GLYCOL
NOTE: If you are using
water as the coolant, set
the Percent Glycol to
zero on the control.
This screen is password
protected. You must
have clearance to enter
and change this setting.
After choosing the temperature you want, mix the glycol solution to the proper percentage and fill the chiller according to
the directions in Filling with Glycol Coolant, in the
Installation section.
Program the percentage glycol solution into the control. From
the main screen:
1
Press the Setup arrow.
STATUS
SETUP RUN ALM
press arrow
Continued
UGH024/1103
Portable Chillers
OPERATION
4-25
PLC CONTROL
SETTING
PERCENT
GLYCOL
2
Press the Up/Down Scroll arrows to scroll
through the setup screens.
Stop when you get to the Percent Glycol screen:
CONTINUED
% E.G. BY VOL
Low Temp Cutout
NOTE: If you are using
water as the coolant, set
the Percent Glycol to
zero on the control.
0%
36F
number
flashes
The screen displays the percent of glycol by volume currently used. This number is flashing. The screen also displays the low temperature cutout (If the To Process fluid
drops below this temperature, an alarm condition occurs
and the compressor shuts off.)
3
Use the numeric keypad to set the percent
glycol. Make sure the percent you enter is the same as the
percent mixture you added to the chiller. See Filling the
Chiller, in the Installation section.
NOTE: This screen has password protection. You can
change the percent glycol only if you have clearance. A
screen displays: $316 Password level invalid...
The password screen then displays, asking for the password. Enter the password (999). You now have password
access for five minutes. Otherwise, press the Escape button to return to the Main screen.
4
4-26
OPERATION
Press the Scroll arrows to scroll to the
the next Setup screen, or press the Escape/Previous
Screen button to return to the main screen.
Portable Chillers
UGH024/1103
For the Air-cooled Portable Chillers you can choose the condenser pressures in PSIG at which the fan cycles on and off.
To set the Fan Setpoints from the main screen:
1
Press the Setup arrow.
STATUS
PLC CONTROL
SETTING FAN
SETPOINTS
SETUP RUN ALM
Press arrow
2
Press the Scroll arrows to scroll through the
Setup screens. Stop when you get to the PID Reset
screen.
3
Press the Fans arrow.
PID Reset DPS
FANS
Note: This screen is
password protected. You
must have clearance to
enter and change this
setting.
Press arrow
A screen displays asking for the password. Use the
Keypad to enter the password (999) and then press the
Enter button. The Fan Setpoint screen displays:
Fan
limits
ON
OFF
250
190
number
flashes
The screen shows the upper and lower condenser pressure
limits for the fan. The ON pressure flashes. Use the keypad to change this number. Then press Enter button to
save the new number.
4
Press the Scroll arrow to move to the OFF
setting. The OFF number flashes:
Fan
limits
ON
OFF
245
190
number
flashes
Use the keypad to change the OFF number.
UGH024/1103
Portable Chillers
Continued
OPERATION
4-27
PLC CONTROL
SETTING FAN
SETPOINTS
5
Press Enter to save the change.
6
Press the Escape/Previous Screen button
to return to the main screen.
Fan setpoints are not saved in retentive memory and are lost
when power is disconnected. Factory default values are
reloaded on power up.
SELECTING THE
TEMPERATURE
SCALE
You can choose to display the temperature in either Fahrenheit
or Celsius. To select the temperature scale:
1
Press the Setup arrow.
STATUS
SETUP RUN ALM
Press arrow
2
Press the Scroll arrows to scroll through the
Setup screens. Stop when you get to the Select Scale
screen. The current choice is listed.
Select Scale
Fahrenheit
C
F
Press arrow
3
4-28
OPERATION
Press the arrow for the scale you want, F or C.
Note that the High Temperature Deviation value and the
Alarm History Temperatures are displayed in Fahrenheit
scale regardless of which scale is selected on this screen.
Portable Chillers
UGH024/1103
Use the Auto Tune Mode to maintain the temperature setpoint
and minimize overshooting it. To set Auto Tune the chiller
must be in Run mode. To run the Chiller from the main
screen:
1
Press the Run arrow on the Main screen.
STATUS
PLC CONTROL
SETTING AUTO
TUNE MODE
SETUP RUN ALM
press arrow
2
Note: This screen is password protected. You must
have clearance to enter and
change settings on this
screen.
Press the RUN arrow.
RUN STOP
PUMPDOWN
press arrow
3
Press the Escape/Previous Screen button.
The control returns to the main screen.
To display the AutoTune Mode from the main screen:
1
Press the Setup arrow.
STATUS
SETUP RUN ALM
Press arrow
2
Press the Scroll arrows to scroll
3
Press the Maintenance arrow.
to the Maintenance screen.
Maintenance
Press arrow
UGH024/1103
Portable Chillers
OPERATION
4-29
PLC CONTROL
SETTING AUTO
TUNE MODE
The password screen displays.
4
Use the keypad to enter the password.
5
Press the Enter button to enter the
6
Press the Scroll arrows to scroll to the
7
Press the Tune arrow.
The factory-set password is 999.
CONTINUED
password.
Tune screen.
TUNE
TUNE
ABORT
Press arrow
When the control begins tuning the screen displays TUNING message. The auto-tuning sequence takes about 15
seconds. The screen displays the ‘TUNE Tuning’ message. When tuning is complete, the screen displays the
TUNE message. Press the Abort arrow to stop the autotuning sequence and return to the last good PID values.
8
4-30
OPERATION
Press the Escape/Previous Screen button
to exit the Maintenance screens and return to the
main screen.
Portable Chillers
UGH024/1103
You can select the discharge pressure setpoints in PSIG. To set
the discharge pressure setpoints from the main screen:
1
Press the Setup arrow.
STATUS
SETUP RUN ALM
Press arrow
2
PLC CONTROL
SETTING
DISCHARGE
PRESSURE
SETPOINT
Press the Scroll arrows to scroll through the
Setup screens. Stop when you get to the PID Reset
screen.
PID Reset DPS
FANS
Press arrow
3
Press the DPS arrow.
The Discharge Pressure Setpoint screen displays.
Press SP
Press PV
225 PSIG
240 PSIG
The pressure setpoint (SP) and the pressure process variable (PV), both in PSIG are listed. Change the value of
the pressure setpoint by entering the new number with the
Select Value buttons.
The discharge pressure can be set between 100 and 350
PSIG.
4
Press the Enter button to accept the
new value.
UGH024/1103
Portable Chillers
OPERATION
4-31
PLC CONTROL
SELECTING PID
VALUES
The PID values are set at the factory to default settings. The
values should be changed only if the water regulator valve or
the VFD are unable to maintain discharge pressure. To set the
discharge pressure setpoints from the main screen:
1
Press the Setup arrow.
STATUS
SETUP RUN ALM
Press arrow
2
Press the Scroll arrows to scroll through the
Setup screens. Stop when you get to the PID Reset
screen.
PID Reset DPS
FANS
Press arrow
3
Press the PID Reset arrow.
The PID values for Gain and Reset time display. The gain
is dimensionless (i.e. has no units) and the integral value,
or Reset time, is measured in seconds. There are no upper
or lower limits for these settings.
Press Gain:
Press Reset:
5
180 S
Use the Select Values buttons to change the gain and reset.
4
Press the Enter button to accept the
new value. If the PID values need to be restored to
the factory default settings scroll to the Reset Factory PID
screen from the Setup screen.
Reset Factory PID
Press arrow
Press the Reset arrow. Gain restores to 2 and Reset
restores to 180 seconds.
4-32
OPERATION
Portable Chillers
UGH024/1103
To run or stop the pump from the main screen:
1
Press the arrow pointing to Run on the screen.
STATUS
SETUP RUN ALM
press arrow
PLC CONTROL
MANUALLY
STARTING/
STOPPING THE
PUMP
The first Run screen displays.
2
Use the Scroll arrows to scroll through
3
Press the arrow pointing to your choice.
Run screens to the Manual Pump screen.
If the pump is running and you want to stop it, press the
arrow pointing to Off. Alternate: pressing red extended
head button stops the pump if that is all that is running. If
the pump is stopped and you want to run it, press the
arrow pointing to On.
Manual Pump
ON OFF
Select one
4
Press the Escape/Previous Screen button.
The control returns to the main screen.
UGH024/1103
Portable Chillers
OPERATION
4-33
MAINTENANCE
l Maintenance Features . . . . . . . .5-2
l Warnings and Cautions . . . . . . .5-3
l Preventative Maintenance
Schedule . . . . . . . . . . . . . . . . .5-4
l PLC Control Entering
Maintenance Screens . . . . . . .5-6
l Checking Electrical
Connections . . . . . . . . . . . . . .5-7
l Cleaning the Evaporator or
Water-cooled Condenser . . . .5-8
l Cleaning the Air-cooled
Condenser . . . . . . . . . . . . . . . .5-9
l Checking the Refrigerant
Charge . . . . . . . . . . . . . . . . . .5-10
l Checking Reservoir Level . . . .5-11
Portable Chillers
UGH024/1103
5-1
MAINTENANCE
FEATURES
Conair Series PCA/PCW need regular, scheduled maintenance
for peak performance.
To maintain the best performance of the chiller, it must be
cleaned and inspected regularly. Maintenance includes a daily,
monthly, and semi-annual schedule.
Use this maintenance schedule as a guide. You may need to
shorten the time of the maintenance schedule, depending on
how often you use the chiller. Among the features that require
preventative maintenance are:
l
l
l
l
l
l
l
l
l
5-2
MAINTENANCE
the refrigerant system
electrical cables, terminals, and control lights
the condenser, condenser filter strainer at inlet
caster locks
temperature and pressure readings
process fluid level
efficiency
evaporator, filter strainer at evaporator inlet
cooling water treatment system (if used)
Portable Chillers
UGH024/1103
Follow all cautions and warnings when working on the equipment.
WARNING: Improper installation, operation, or servicing may result in
equipment damage or personal injury.
WARNING AND
CAUTIONS
This equipment should only be installed, adjusted, and serviced by qualified technical personnel who are familiar with the construction, operation, and potential hazards of this type of
machine.
All wiring, disconnects, and fuses should be
installed by qualified electrical technicians in
accordance with electrical codes in your region.
WARNING: Electrical hazard
Before performing any work on this item, disconnect and lock out electrical power sources to
prevent injury from unexpected energization or
startup. Be sure that power to the chiller is OFF
when doing any maintenance on the chiller.
Follow all safety rules when performing any
maintenance on this equipment.
CAUTION: Hot Surfaces
Always protect yourself from hot surfaces when
working on the Portable Chiller, especially when
working on or around the compressor and condenser. These devices can reach up to 160°F
(71°C). Allow these devices to cool before performing any maintenance or troubleshooting.
WARNING: Refrigerant hazard
Only certified refrigerant technicians should
examine and correct problems involving the
refrigerant circuit.
WARNING: Hazardous substance
When burned, Freon R22 refrigerant forms
Phosgene gas. If the chiller is placed in the
vicinity of equipment with combustible systems,
the combustion air intake must be ducted in
from the outside and sealed in such a manner
as to prevent any refrigerant from entering the
combustion chamber. Refer to the Material
Safety Data Sheet for Freon R22 included in the
Appendix. This sheet explains the potential hazards and how to avoid them.
UGH024/1103
Portable Chillers
MAINTENANCE
5-3
PREVENTATIVE
MAINTENANCE
SCHEDULE
To maintain the best performance, follow the maintenance schedule and record
information in the
Maintenance Log in the
Appendix.
l Daily, or as often as needed
r
Checking process fluid level in the pump tank
Check the process fluid level in the water level gauge
on the back of the chiller. If low, see Filling the
Chiller, in the Installation section.
r
Verifying pump discharge pressure
While the pump is running, check that the pump pressure gauges are within range. To change the pressure
open or close the From Process valve.
r
Inspecting piping for leaks
Check to see that pipes are not leaking. Look for
standing water on the floor or inside the chiller cabinet.
r
Inspecting the condenser coil for debris
(air-cooled models only). Remove the wire mesh side
panel in front of the condenser coil. Remove any
debris from the coils.
l Weekly, or as often as needed
r
Checking temperature and pressure readings
Check that the temperature and pressure display on the
control screen, and that the pressure gauge indicates
normal operation.
r
Checking efficiency
Review the performance data on the Maintenance Log
found in the Appendix. If you notice a decrease in
efficiency over time, check all heat transfer surfaces of
the evaporator and condenser for fouling. Clean as
needed.
r
Checking refrigerant site glass
There should not be any bubbles. See Checking
Refrigerant Charge, in the Maintenance section.
r
Checking reservoir level
Check the water level gauge on the back of the chiller.
If fluid level is low, fill. See Checking Reservoir
Level, in the Maintenance section.
l Monthly
r
5-4
MAINTENANCE
Inspecting cooling water treatment system
If your chiller uses a cooling water treatment system,
maintain proper chemical levels and follow the recommendations of your water treatment specialist. Change
Portable Chillers
UGH024/1103
r
Checking electrical connections, amps, volts
Make sure electrical connections are properly seated.
See Checking Electrical Connections, in the
Maintenance section. Check fan, compressor, and
pump amps and volts.
r
Cleaning
Wipe all external surfaces to maintain performance.
r
Inspecting condenser
Check the condenser for adequate air flow or water
flow. Check the condenser face for dirt and clogging.
If dirt or clogs are present, clean the condenser. See
Cleaning the Evaporator or Water-cooled Condenser,
and Cleaning the Air-cooled Condenser, in the
Maintenance section. If your unit has an optional filter
at the air inlet of the Air-cooled condenser coil, check,
clean, and replace as needed.
r
Inspecting the control panel
Check for loose wires, burned contacts, and signs of
overheated wires. Check that all panel lights illuminate. See Checking Electrical Connections section.
r
Checking refrigerant charge
With the compressor running, check the sight glass
between the receiver and evaporator for proper refrigerant condition. See Checking Refrigerant Charge, in
the Maintenance section.
r
Cleaning process fluid strainer
Remove cap and clean any debris out of strainer.
Replace cap.
PREVENTATIVE
MAINTENANCE
SCHEDULE
To maintain the best performance, follow the maintenance schedule and record
information in the
Maintenance Log in the
Appendix.
l Annually
r
Cleaning the evaporator or water-cooled condenser
See Cleaning the Evaporator or Water-cooled
Condenser, in the Maintenance section.
UGH024/1103
Portable Chillers
MAINTENANCE
5-5
PLC CONTROL
ENTERING
MAINTENANCE
SCREENS
Use the Maintenance screens to view cycling information. the
cycle screens display the total cycles or hours since the initial
assembly of the chiller. These numbers are only reset through
the Conair screens by Conair Service personnel. To view the
cycle information:
1
Press the Setup arrow.
STATUS
The Maintenance screens are
password protected. You
must have clearance to enter
and change settings on these
screens.
SETUP RUN ALM
Press arrow
2
If the control buttons are not
used for 5 minutes, the PLC
defaults to the Temperature/
Setpoint screen. You must
then re-enter the password to
use the Maintenance
screens.
Press the Scroll arrows to scroll through the
Setup screens. Stop when you get to the Maintenance
screen:
Maintenance
Press arrow
3
Press the Maintenance arrow.
4
Scroll through the Maintenance screens.
5
The password screen displays. Use the keypad to enter
the maintenance password, 999, then press the Enter button.
They include:
l Cycle screens - view the cycle times for
chiller components
l Tuning screens - initiate PID auto tune
sequence for the hot gas bypass control for the compressor
l Compressor service screen - (dual compressor models only) choose the lead compressor (1 by default), and
take a compressor in or out of service (IN by default)
l Conair factory screen - (unavailable to user)
Press the Escape/Previous Screen button
to exit the Maintenance screens and return to the
main screen. The password stays in effect for 5 minutes
after using it; after 5 minutes the screens return to the
5-6
MAINTENANCE
Portable Chillers
UGH024/1103
WARNING: Electrical hazard
Before performing any work on this item, disconnect and lock out electrical power sources
to prevent injury from unexpected energization
or startup.
CHECKING
ELECTRICAL
CONNECTIONS
WARNING: Improper installation,
operation, or servicing may result in
equipment damage or personal injury.
This equipment should only be installed, adjusted, and serviced by qualified technical personnel who are familiar with the construction, operation, and potential hazards of this type of
machine.
All wiring, disconnects, and fuses should be
installed by qualified electrical technicians in
accordance with electrical codes in your region.
1
Be sure the main power is disconnected
2
Open the electrical enclosure.
3
Inspect all wires and connections.
4
5
Close the electrical enclosure door.
and the chiller is locked out. Always disconnect and lockout the main power source before opening the unit for
servicing.
Look for loose wires, burned contacts, and signs of overheated wires. Compare the PLC wiring to the wiring diagrams you received with your chiller. Have a qualified
electrician make any necessary repairs or replacements.
Always refer to the wiring
diagrams you received with
your chiller to locate specific electrical components.
Inspect the exterior power cords.
Cords should not be crimped, exposed, or rubbing against
the frame. If the main power cord runs along the floor,
make sure it is positioned where it could not rest in pooling water or could not be run over and cut by wheels or
casters.
UGH024/1103
Portable Chillers
MAINTENANCE
5-7
CLEANING THE
EVAPORATOR
OR WATER-
Minerals and other contaminant’s produce deposits, scales,
slime, or algae on the heat transfer surfaces exposed to water.
Fouled surfaces result in decreased cooling capacity.
Implement a water treatment program to slow the fouling.
CAUTION: Hot Surfaces
Always protect yourself from hot surfaces when
working on the Portable Chiller, especially when
working on or around the compressor and condenser. These devices can reach up to 160 °F
(71 °C). Allow these devices to cool before performing any maintenance or troubleshooting.
COOLED
CONDENSER
Water quality should be maintained at a pH of 7.4, but not less
that 6.0 for proper heat exchanger life.
To clean:
In
1
Prepare a 5% solution of Phosphoric acid
2
3
Shut the From Process valve.
4
Connect 1/2-inch tubing to the 1/2-inch
5
Back-flush the solution through the
6
Flush the heat exchanger and the chiller
7
Reconnect the chiller pump to the
or Oxalic acid. Do not heat the acid solution.
Disconnect the pump from the heat exchanger.
Install a cap in the opening of the heat exchanger where
the pump was connected.
connections of the heat exchanger.
heat exchanger and the chiller.
Out
Out
In
piping with fresh water after cleaning.
heat exchanger. Remove the cap in the heat exchanger
and reconnect the hose from the pump.
Heat
Exchanger
1/2 inch connection on
outside of chiller cabinet
Fluid circuit
Acid solution
To Process connection
5-8
MAINTENANCE
Portable Chillers
UGH024/1103
WARNING: Electrical hazard
Before performing any work on this item, disconnect and lock out electrical power sources to
prevent injury from unexpected energization or
startup.
CLEANING THE
AIR-COOLED
CONDENSER
CAUTION: Hot Surfaces
Always protect yourself from hot surfaces when
working on the Portable Chiller, especially when
working on or around the compressor and condenser. These devices can reach up to 160°F
(71°C). Allow these devices to cool before performing any maintenance or troubleshooting.
The air-cooled condenser can accumulate dirt and clog quickly if it is run in a dusty or dirty environment. A clogged condenser increases refrigerant discharge pressure, lowers performance, and may cause the fan motors and compressor to overheat.
1
Inspect the coils.
2
3
Clean the dirty coils with a soft brush.
Use a flashlight to check between coil surfaces.
Flush with cool water or a commercial
coil cleaner that is compatible with aluminum alloys.
If your unit has the optional air filter supplied by Conair,
clean it using water or air. Replace as needed.
UGH024/1103
Portable Chillers
MAINTENANCE
5-9
CHECKING THE
REFRIGERANT
CHARGE
All chillers are fully charged with refrigerant at the factory.
Your chiller’s model nameplate identifies the type and amount
of total refrigerant charge required.
WARNING: Refrigerant hazard
Only certified refrigerant technicians should
examine and correct problems involving the
refrigerant circuit.
WARNING: Hazardous substance
When burned, Freon R22 refrigerant forms
Phosgene gas. If the chiller is placed in the
vicinity of equipment with combustible systems,
the combustion air intake must be ducted in
from the outside and sealed in such a manner
as to prevent any refrigerant from entering the
combustion chamber. Refer to the Material
Safety Data Sheet for Freon R22 included in the
Appendix. This sheet explains the potential hazards and how to avoid them.
Check refrigerant charge while the chiller is running. Check
the refrigerant charge through the sight glass. Use a flashlight,
if necessary, and check the liquid-line sight glass:
l
Under full load conditions, the refrigerant should
be clear (no bubbles).
l Under low load conditions, when the hot-gas
bypass valves are operating, bubbles may be visible in
the sight glass. This is normal.
If the charge is low and the Chiller is under warranty, contact
Conair service; or have a local, certified refrigeration technician add refrigerant to the system.
Sight
glass
5-10
MAINTENANCE
Portable Chillers
UGH024/1103
WARNING: Electrical hazard
Before performing any work on this item, disconnect and lock out electrical power sources to
prevent injury from unexpected energization or
startup.
CHECKING
RESERVOIR
LEVEL
Check the fluid level in the reservoir. The meniscus in the
sight glass on the back of the chiller should be in line with the
mark on the sight glass.
To manually fill the reservoir:
1
2
Disconnect and lockout power to the chiller.
Locate the fill/drain valve
on the back of the chiller.
3
Refill the reservoir.
Monitor the level using the water level gauge on the back
of the chiller. Because the Portable Chiller can use either
pure water or a glycol solution, make sure your are
adding the correct fluid for your application.
Auto-fill port
Water level gauge
Fill/Drain valve
If you have the optional make-up water level float switch, it
will automatically control the fluid level.
UGH024/1103
Portable Chillers
MAINTENANCE
5-11
TROUBLESHOOTING
l Before Beginning . . . . . . . . . . . . . . . . . . . . .6-2
l A Few Words of Caution . . . . . . . . . . . . . . .6-3
l Identifying the Cause
of a Problem . . . . . . . . . . . . . . . . . . . . . .6-3
l TIC Control Input / Output . . . . . . . . . . . . . .6-4
l TIC Control Answering an Alarm . . . . . . . .6-5
l TIC Control Problems . . . . . . . . . . . . . . . . .6-6
l TIC Control Mechanical Conditions . . . . . .6-8
l PLC Control Answering Alarms . . . . . . . .6-16
l PLC Control Alarm Conditions . . . . . . . . .6-17
l PLC Control Alarm Errors . . . . . . . . . . . . .6-20
l PLC Control Alarm History Screens . . . . .6-21
l PLC Control Alarm Screen Legend . . . . . .6-22
l PLC Control Control Problems . . . . . . . . .6-23
l PLC Control Alarm Conditions . . . . . . . . .6-25
l Checking and Replacing
Switches . . . . . . . . . . . . . . . . . . . . . . . . .6-44
l Replacing the RTD . . . . . . . . . . . . . . . . . . .6-45
l Removing Pump Components . . . . . . . . .6-46
l Replacing Fuses . . . . . . . . . . . . . . . . . . . .6-47
l Replacing the Contactor . . . . . . . . . . . . . .6-48
Portable Chillers
UGH024/1103
6-1
BEFORE
BEGINNING
You can avoid most problems by following the recommended
installation, operation and maintenance procedures outlined in
this User Guide. If you have a problem, this section will help
you determine the cause and tell you how to fix it.
Before you begin troubleshooting:
r Find any wiring, piping, and assembly diagrams that
were shipped with your equipment. These are the best
reference for correcting a problem. The diagrams will
note any custom features or options not covered in this
User Guide.
r Verify that you have all instructional materials related
to the chiller. Additional details about troubleshooting
and repairing specific components are found in these
materials.
r Check that you have manuals for other equipment connected in the system. Troubleshooting may require
investigating other equipment attached to, or connected with the chiller.
6-2
TROUBLESHOOTING
Portable Chillers
UGH024/1103
WARNING: Improper installation, operation, or servicing may result in
equipment damage or personal injury.
A FEW WORDS
OF CAUTION
This equipment should only be installed, adjusted, and serviced by qualified technical personnel who are familiar with the construction, operation, and potential hazards of this type of
machine.
All wiring, disconnects, and fuses should be
installed by qualified electrical technicians in
accordance with electrical codes in your region.
WARNING: Electrical hazard
Before performing any work on this item, disconnect and lock out electrical power sources to
prevent injury from unexpected energization or
startup.
WARNING: Refrigerant hazard
Only certified refrigerant technicians should
examine and correct problems involving the
refrigerant circuit.
CAUTION: Hot Surfaces
Always protect yourself from hot surfaces when
working on the Portable Chiller, especially when
working on or around the compressor and condenser. These devices can reach up to 160°F
(71°C). Allow these devices to cool before performing any maintenance or troubleshooting.
The Troubleshooting section covers problems directly related
to the operation and maintenance of the Portable Chiller.
Additional troubleshooting help can be found in the documentation manuals included with this User Guide.
Types of conditions you may see include control problems
(not lighting, or lighting and not running), and alarm conditions.
UGH024/1103
Portable Chillers
IDENTIFYING
THE CAUSE OF
A PROBLEM
TROUBLESHOOTING
6-3
TIC CONTROL
INPUT/OUTPUT
As part of troubleshooting you need to know the status of the
inputs and outputs. Open the electrical enclosure and check
the status of the inputs and outputs. When they are in normal
range, the numbers are highlighted. If the number is not highlighted, it is out of range.
I
Inputs
1 2
3 4
5
6
DAY
Outputs
Always refer to the wiring
diagrams you received
with your chiller to locate
specific electrical components.
Input
1
2
4
5
6
7
8
9
10
11
12
6-4
O
1
8
9 10 11 12
TIME
3
4
5
6
7
8
In this example, inputs 7 and 8 are highlighted; they are in
normal position. The unhighlighted numbers are out of range.
Refer to the wiring diagram and the following table for the
switch status:
Description
Chiller Stop
Chiller Start
Flow Switch
Compressor Running
Pump Running
Suction Pressure Switch
Discharge Pressure Switch
Low Temperature Deviation
Optional Auto-Fill Level Switch
Pressure Differential Switch
(7.5, 10, 15 ton only)
Optional Alarm Silence
TROUBLESHOOTING
2
7
Portable Chillers
Output
1
2
3
4
5
6
7
8
Description
Compressor Starter
Compressor Run Lamp
Pump Starter
Pump Run Lamp
Alarm Lamp
Optional Auto-Fill Solenoid
Optional Alarm Bell
Optional Alarm Strobe
UGH024/1103
When an alarm condition occurs, the alarm light on the control panel lights. It stays lit until the alarm condition is corrected. If you have the optional audible alarm, pressing the
Enter button silences the audible alarm.
To find out what is causing the alarm, check the indicator
lights on the control panel for the pump and compressor status. If the pump and compressor are both off, check the water
tank level, flow valves, and the pump. If the pump is on and
the compressor is off, check the compressor, suction pressure
and discharge pressure.
TIC CONTROL
ANSWERING AN
ALARM
Pump
Status
Compressor
Status
Alarm Condition
Description
Flow Fault
There is no flow of the process fluid at the
pump discharge. The water level in the
pump tank is low.
OFF
OFF
Pump Overload
There is a high amperage condition; the
pump is drawing too much current.
OFF
OFF
Compressor Overload
There is a high amperage condition; the
compressor is drawing too much current.
ON
OFF
High Discharge Pressure
The refrigerant pressure, as measured at the ON
compressor outlet is high.
OFF
Low Suction Pressure
The refrigerant pressure, as measured at the ON
inlet of the compressor is low.
OFF
Refer to the Troubleshooting tables and the wiring diagrams to
correct the alarm condition.
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-5
TIC CONTROL
PROBLEMS
Look here if the control panel is not lit, or if the power is on
and the Portable Chiller will not run.
Symptom
Possible cause
Solution
The control is not lit
and the chiller is not
working.
Power is not reaching the
chiller.
p Check the power cord and
plug. Make sure the cord and
plug are properly connected.
p Make sure the main disconnect switch is on.
p Check fuses and breakers.
Replace or reset as required.
The correct power is not
reaching the unit
Check the voltage specification on the chiller nameplate.
There is a problem with
the TIC control.
p Check fuses and replace
as needed.
p Check the power to the
temperature controller.
Reconnect or replace as needed.
p Check the TIC indicator
lights and replace as needed.
There is a problem with
the control panel.
6-6
TROUBLESHOOTING
Portable Chillers
The control panel may have
failed. Contact Conair Service.
UGH024/1103
TIC CONTROL
PROBLEMS
Symptom
Possible cause
Solution
The control is lit and
there is no alarm
condition. The compressor hums, but
does not run.
The input voltage is
incorrect
Check the main supply voltage. It must be within 10% of
the nameplate rating.
There is a phase loss.
p Check the fuses on the
main power supply.
p Check the phase-to-phase
voltages.
p Check phase continuity
through the compressor contactor.
p Check the wiring at the
compressor.
Replace or repair as needed.
Look here when the Alarm/Shutdown light on the control
panel is lit. See Answering an Alarm, in the Troubleshooting
section before going to these tables.
TIC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Flow fault (pump
and compressor are
off)
Water level in tank is low. Fill tank to proper level. See
Checking Reservoir Level, in
the Maintenance section.
Inspect for leaks in the process
piping. Repair as necessary.
See Making Plumbing
Connections, in the Installation
section.
UGH024/1103
Solution
Portable Chillers
TROUBLESHOOTING
6-7
TIC CONTROL
ALARM
CONDITIONS
Possible cause
Solution
High Deviation
Load too high for chiller.
Reduce load on chiller; if not
able to reduce load, choose a
chiller with more capacity.
Low Deviation
Insufficient loadfor the
chiller
The chille rneeds to loaded by
at last 25 % of the chiller
capacity for correct operation;
adjust as necessary.
Low Condensed water
temperature or low
ambient air tempera
ture. This will create a
low in discharge pres
sure.
This will create a low in discharge pressure which negatively affects the system.
Adjust as necessary.
Alarm
Deviation from
Setpoint Alarm
(DtA)
6-8
TROUBLESHOOTING
Portable Chillers
UGH024/1103
TIC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
High temperature
temp > 75°F Alarm
Shutdown “tAH”
Load too high for chiller.
Reduce load on chiller; if not
able to reduce load, choose a
chiller with more capacity.
Refrigeration circuit not
working properly.
Check refrigerant circuit. See
Checking Refrigerant charge,
Section 3.
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-9
TIC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
Low Suction
Pressure (pump is
running and compressor is off)
“PAL”
No or low flow with a
failed flow switch and
Sensor.
o
Compressor suction valve
is closed.
Open valve.
No load on the Chiller.
Check process load for
required load. Chiller may be
oversized.
Check To Process and
From Process valves to see
if they are open.
o Check Flow switch and
Sensor. Replace as needed.
The Evaporator is fouled. Clean Evaporator. See
Cleaning the Evaporator or
Water-cooled Condenser, in the
Maintenance section.
The Evaporator is frozen. o
Check RTD; Replace as
needed.
o Check minimum allowable setpoint for percent
glycol used.
There is a refrigerant
leak.
The pressure switch is
faulty.
6-10
TROUBLESHOOTING
Portable Chillers
Check for oil in chiller cabinet
and bubbles in refrigerant site
glass. Consult Conair Service
for repair.
See Checking Pressure
Switches, in the
Troubleshooting section.
UGH024/1103
TIC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
High Discharge
Pressure (pump is
running, compressor
is off) PSH must be
manually reset by
depressing reset button on top of switch
in chiller and
acknowledge on face
of controller
Clogged/dirty air-cooled
condenser.
Clean the coil. See Cleaning
the Air-cooled Condenser, in
the Maintenance section.
Blocked air flow to aircooled condenser.
Move chiller or unblock air
passageway.
Low condenser water
flow or water too warm
to water-cooled condenser.
Check required flow; see
Specifications in the
Description section.
Blocked condenser water
line or valve closed.
Unblock line; open valve.
Water-cooled condenser
fouled.
Clean the condenser. See
Cleaning the Air-cooled
Condenser, and Cleaning the
Evaporator or Water-cooled
Condenser, in the Maintenance
section.
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-11
TIC C ONTROL
ALARM
CONDITIONS
6-12
Alarm
Possible cause
Solution
High Discharge
Pressure, cont’d
PSH
Compressor discharge
valve closed.
Open valve.
Overcharged with refrigerant.
See Checking the Refrigerant
Charge in the Maintenance
section.
Faulty water regulating
valve.
Repair or replace the valve.
Faulty pressure switch.
See Checking the Pressure
Switches, in the
Troubleshooting section.
TROUBLESHOOTING
Portable Chillers
UGH024/1103
TIC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
Sensor Failure SF2
The process temperature
sensor failed
Check with OHM meter and
see if the resistance matches
the table below. Replace if
needed.
Sensor wiring is incorrect
or failed
Check all wiring from terninal
strip to sensor in question.
Repair as necessary.
°F (°C)
-40 (-40)
-31 (-35)
-22 (-30)
-13 (-25)
-4 (-20)
5 (-15)
14 (-10)
23 (-5)
32 (0)
41 (5)
50 (10)
59 (15)
68 (20)
77 (25)
86 (30)
95 (35)
104 (40)
UGH024/1103
Resistance
in Ohms
613
640
668
697
727
758
789
822
855
889
924
960
997
1035
1074
1113
1153
°F (°C)
113 (45)
122 (50)
131 (55)
140 (60)
149 (65)
158 (70)
167 (75)
176 (80)
185 (85)
194 (90)
203 (95)
212 (100)
221 (105)
230 (110)
239 (115)
248 (120)
------
Portable Chillers
Resistance
in Ohms
1195
1237
1279
1323
1368
1413
1459
1506
1554
1602
1652
1702
1753
1804
1856
1908
------
TROUBLESHOOTING
6-13
TIC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
High Temperature
Safety Temp >95 F
alarm
The hot gas bypass valve
is not working properly
(possibly stuck open)
Shut isolation valve to the Hot
Gas Bypass solenoid. If the To
Process temperature starts to
go down, the solenoid valve is
faulty. Have a certified refrigeration technician replace the
solenoid valve.
Load is too high for the
chiller.
Remove some load from the
process.
Fluid is not flowing
between the supply outlet
and return outlet.
Check for plugged pipes,
closed valves, or failed flow
switch.
The compressor is not
running.
Check to see if Compressor
light is lit on the control. If it
is not, check compressor overload in compressor terminal
box. Check power to compressor and power to compressor
contactor.
Failed RTD or
See Checking the Temperature
Temperature Transmitter. Transmitter and RTD in the
Troubleshooting section.
6-14
TROUBLESHOOTING
Portable Chillers
UGH024/1103
TIC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
Flow fault (pump
and compressor are
off) “FAL”
The To Process and/or
From Process valves are
closed.
Open valve(s).
The Optional Process
Fluid strainer is clogged.
Clean the strainer.
Water level in reservoir is
low.
Fill the reservoir. See Making
Process Plumbing
Connections, in the Installation
section.
The evaporator is fouled.
Clean Evaporator. See
Cleaning the Evaporator or
Water-cooled Condenser, in the
Maintenance section.
Pump is not running.
Check overload module.
Replace as needed. See
Replacing Overload Modules,
in the Troubleshooting section.
Pump is running backwards.
Switch any two of the three
main power leads to the pump.
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-15
TIC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
Low Temperature
Alarm (tAL)
Insufficient load for the
chiller
The chiller needs to be loaded
by at least 25 % of the chiller
capacity for correct operation
adjust as necessary.
Creates a low refrigerant disLow condensed water
temperature or low ambi- charge pressure which nega
tively affects the system.
ent air temperature
Adjust as necessary.
6-16
TROUBLESHOOTING
Portable Chillers
UGH024/1103
TIC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
Pump Overload
(pump and compressor are off)
Must be manually
reset in control
enclosure.
Overload set incorrectly.
Check table on wiring diagram
for correct amperage. Adjust
overload accordingly.
Low supply voltage.
o
Faulty contactor
Check line and load side of
contactor. It should be less
than 5 volt drop across the
contactor. If it is not, replace
the contactor. See Replacing
the Contactor in the
Troubleshooting section.
Faulty overload module.
Check amp draw of circuit. If
it is under the rated setting,
replace the overload module.
See Replacing Overload
Modules, in the
Troubleshooting section.
UGH024/1103
Check supply voltage.
Supply voltage to contactor
should be +- 10% of nameplate voltage.
o Check wire terminations
and connections. Tighten if
loose.
Portable Chillers
TROUBLESHOOTING
6-17
TIC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
SOLUTION
Compressor
Overload (pump is
running and compressor is off) Not
displayed on alarm
compressor light lit
but compressor not
on.
Low supply voltage.
o
Faulty contactor.
Check line and load side of
contactor. It should be less
than 5 volt drop across the
contactor. If it is not, replace
the contactor. See Replacing
the Contactor in the
Troubleshooting section.
Faulty overload module.
Check amp draw of circuit. If
it is under the rated setting,
replace the overload module.
See Replacing Overload
Modules, in the
Troubleshooting section.
Leads are backwards.
Swap any two of the three
main power leads to the compressor.
The compressor failed.
Contact Conair Service.
Compressor fault.
6-18
TROUBLESHOOTING
Portable Chillers
Check supply voltage.
Supply voltage to contactor
should be +- 10% of nameplate voltage.
o Check wire terminations
and connections. Tighten if
loose.
UGH024/1103
When an alarm condition occurs, the Alarm light on the control panel lights and the control screen displays the alarm message.
Low Suction Pressure
PLC CONTROL
ANSWERING
ALARMS
Before an alarm can be reset with the acknowledge key, the
alarm condition must be cleared. Refer to the Alarm table and
the Troubleshooting tables to troubleshoot the alarm condition(s). After correcting the condition, remove the alarm from
the screen. Press and hold the Alarm Silence/Reset button for
a minimum of 3 seconds to remove alarm from screen. To
begin running the chiller again, press the Run button on the
Main screen.
STATUS
SETUP RUN ALM
Press arrow
If there is a fault affecting compressor operation such as overload, high or low discharge pressure, compressor fault, etc.,
there is a three-minute delay before the compressor can be
started. The compressor light will flash quickly indicating that
manual reset is necessary. The manual reset should be performed only after the alarm condition has been diagnosed and
corrected. The manual reset will start the compressor provided
all other permissive are enabled. To manually reset the compressor, press the Alarm Silence button and the Enter button
simultaneously.
To view a list of the last 10 alarms, refer to Alarm History
Screens, in the Troubleshooting section of this manual. Alarms
are numbered and listed in order of occurrence, starting with
the most recent.
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-19
PLC CONTROL
ALARM
CONDITIONS
Low Temperature Cutout
Higm Temp Safety
(Temp >95 ° F)
High Temperature Deviation
Low Water Tank Level
Flow Fault
Low Suction Pressure
Low Suction Pressure 2
6-20
TROUBLESHOOTING
Before an alarm can be reset with the acknowledge key, the
alarm condition must be cleared. To acknowledge an alarm is
press and hold the Shift button for 3 seconds.
When the temperature falls below the Low To Process
Temperature cut out, the compressor shuts off. The Alarm
light illuminates and the PLC displays "Low Temperature
Cutout". The process or recirculation pump remains running
until the Stop button is pressed.
When the To Process Temperature increases to 95°F (35°C)
the compressor shuts off. The Alarm light illuminates and the
PLC displays "High Temp Safety (Temp>95°F)". The process
pump remains running until the Stop button is pressed.
If the temperature rises above the setpoint a high temperature
deviation occurs. The degrees Fahrenheit deviation is a variable from 3 to 20, adjustable on a Setup screen. If a high deviation is present the Alarm light illuminates and the PLC displays "High Temperature Deviation". The alarm can be
cleared after the temperature drops below the high temperature deviation setpoint or the high deviation is changed to a
larger value and the alarm is acknowledged. Acknowledge the
alarm by pressing the Stop Chiller button.
If the low water level switch indicates a low water level, the
compressor and process pump will shut down. The "alarm"
light illuminates and the PLC indicates "Low Water Tank
Level". The process pump will remain running until the Stop
button is pressed.
If the flow switch (FS-1) detects a low flow condition, the
compressor and process pump will be shut down. The "alarm"
light illuminates and the PLC indicates "Flow Fault". The
process pump will remain running until the Stop button is
pressed.
When the refrigerant suction pressure (PT-1) goes below 28
PSIG the compressor will be shut off. The "alarm" light illuminates and the PLC indicates "Low Suction Pressure" for the
compressor on a single compressor system and compressor 1
on a dual compressor system. The PLC will indicate "Low
Suction Pressure 2" for compressor 2 on a dual compressor
system. The process pump will remain running until the Stop
button is pressed.
Portable Chillers
UGH024/1103
PLC CONTROL
ALARM
CONDITIONS
CONT’D
If refrigerant discharge pressure (PT-2) goes above 270 psig
(for water-cooled models) or 350 psig (for air-cooled models)
the compressor shuts down. The Alarm light illuminates and
the PLC indicates "High Discharge Pressure" for the compressor on a single compressor system and compressor 1 on a dual
compressor system. The PLC will indicate "High Discharge
Pressure 2" for compressor 2 on a dual compressor system.
The process pump will remain running until the Stop button is
pressed.
If the compressor overloads and trips the MSP, the compressor
shuts down. The Alarm light illuminates and PLC indicates
"Compressor Overload" for the compressor on a single compressor system and compressor 1 on a dual compressor system. The PLC indicates "Compressor 2 Overload" for compressor 2 on a dual compressor system. The MSP must be
reset inside the control panel. The process pump remains running until the Stop button is pressed.
If the process or recirculation pump overloads and trips the
MSP, the compressor and pump(s) shut down. The MSP must
be reset inside the control panel. The Alarm light illuminates
and PLC indicates "Pump Overload" for a process pump overload.
The 3.5 and 5 hp compressors (used on PCW-3.5, PCW-5,
PCA-3.5 and PCA-5) have a high discharge refrigerant temperature switch (TSHH-1). If the switch detects a high discharge temperature the compressor shuts off immediately. The
alarm light illuminates and the PLC indicates "High Discharge
Temperature". The process pump remains running until the
Stop button is pressed.
Each chiller has a differential pressure switch (PDS-2) on the
evaporator. This switch indicates a high-pressure drop through
the Evaporator and strainer, usually the result of a dirt strainer
or fouled evaporator. When this condition is detected, the
alarm light (and strobe) illuminate and the PLC indicates
"Evaporator Filter Fault". The compressor and pump(s) continue to run. Press the Enter button to clear the message from
the screen. The message continues to display every 60 minutes.
UGH024/1103
Portable Chillers
High Discharge Pressure
High Discharge Pressure 2
Compressor Overload
Compressor Overload 2
Pump Overload
High Discharge Temperature
Evaporator Filter Fault
TROUBLESHOOTING
6-21
PLC CONTROL
ALARM
CONDITIONS
CONT’D
Condenser Filter Fault
Comp 1 Rotation Error
Comp 2 Rotation Error
Water-cooled chillers have a differential pressure switch
(PDS-1) on the condenser water. This switch indicates a highpressure drop through the condenser and strainer, usually the
result of a dirt strainer or fouled condenser. The alarm light
(and strobe) illuminate and the PLC displays the message
"Condenser Filter Fault". The compressor and pump(s) continue to run. Press the Enter button to clear the message from
the screen. The message continues to display every 60 minutes.
The 7.5 HP and larger compressors have a High Temperature
Protector Module to protect the compressor from high internal
temperatures, overcurrent conditions and phase imbalance. On
single compressor systems (and dual compressor systems with
only one compressor enabled), when the normally closed contact opens, it shuts off the compressor immediately and the
contact remains open for 30 minutes. The PLC indicates
"Comp 1 Rotation Error" on single compressor systems and
for compressor 1 on dual compressor systems. A fault on compressor 2 on a dual compressor system displays "Comp 2
Rotation Fault". When the contact closes and the fault is
acknowledged, the compressor will restart. On dual compressor units, if the lead compressor's Protector Module contact
opens, the lag compressor becomes the lead compressor and
the alarm is displayed. When the 30-minute delay has expired
and the alarm is acknowledged, the compressor that had faulted remains the lag compressor. If the lag compressor's
Protector Module contact opens, the compressor shuts off and
the alarm is initiated. This alarm can be cleared after the 30minute delay and the alarm is acknowledged.
To clear the alarm(s) press and hold the Shift button for three
seconds. To start the chiller once the 3-minute compressor
down time has expired, press the Run button on the Run
Screen.
The alarms are logged in an alarm history table. The last 5
alarms (except the high temp deviation alarm) are recorded
and display on the Alarm screen, along with the alarm number, To Process temperature set point, the actual To Process
temp, the Refrigerant Discharge Pressure, Refrigerant Suction
Pressure, and the time since the last alarm condition. An additional 2 alarm histories are displayed in the Conair Factory
screens.
6-22
TROUBLESHOOTING
Portable Chillers
UGH024/1103
PLC CONTROL ALARM ERRORS
Alarm Message
Description
Flow Fault
There is low process fluid flow at the pump discharge.
Low Suction Pressure
The refrigerant pressure, measured at the inlet of compressor 1, is low.
High Discharge Pressure
The refrigerant pressure, measured at the inlet of compressor 1, is high.
Process Pump Overload
High amperage condition; the pump is drawing too much current.
High Temperature Safety
Temp >95° F
The To Process fluid temperature is above 95 °F, measured at the evaporator outlet.
Low Temperature Cutout
If the To Process fluid temperature falls °5 below the minimum setpoint
(measured at the evaporator outlet) the compressor shuts off to allow the
temperature to rise.
Compressor Overload
High amperage condition; compressor 1 is drawing too much current.
High Temperature
Temperature >75°F for 5 min
To Process fluid temperature is above 75 °F (measured at the evaporator
outlet) after the compressor has been running for five minutes at startup.
Evaporator Filter Fault
The filter in the process water line is clogged.
Condenser Filter Fault
The filter in the condenser water line is clogged (water-cooled models).
High Discharge Pressure 2
The refrigerant pressure, measured at compressor 2 outlet, is high.
Low Suction Pressure 2
The refrigerant pressure, measured at compressor 2 outlet, is low.
Compressor 2 Overload
High amperage condition; compressor 2 is drawing too much current.
Compressor 2 Rotation Fault
Compressor 2 is wired incorrectly. Two of the lead wires need switched.
Fan Overload
High amperage condition; the fan motor is drawing too much current.
Discharge Pressure Sensor
Failure
The sensor is incorrectly reading discharge pressure.
Discharge Pressure 2 Sensor
Fault
Sensor 2 is incorrectly reading discharge pressure.
Fan VFD Alarm
The variable frequency drive on the fan failed.
Recirc Pump Overload
High amperage condition; the recirculation pump is drawing too much
current.
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-23
PLC CONTROL
ALARM
HISTORY
SCREENS
The alarm history screens display the last 10 alarms that have
occurred. They are listed in the order of newest to oldest.
Scroll through the alarm history screens by pressing the scroll
arrows. The Next arrow takes you back in time. The alarm
screen displays the alarm number (1-10) and an alarm description. Pressing the Select Option arrows allows the operator to
view the pressures and temperatures at time of the alarm.
1 Hi Dis Press - Compl
PRESS
TEMP
Press arrows to
view pressure
and temperature
When PRESS is selected discharge pressure information at the
time of the alarm displays.
Discharge Press
351 PSIG
RET
Press arrow to
return to previous
alarm screen
Pressing the Escape key returns to the main menu. Pressing
the Next arrow displays the suction pressure at time of the
alarm.
Suction Pressure
57 PSIG
RET
Press arrow to
return to previous
alarm screen
For dual compressor units, the suction and discharge pressures
at time of alarm of the second compressor are also captured.
These can be viewed by pressing the scroll arrows.
To Process
Temperature 51 F
RET
Press arrow to
return to previous
alarm screen
When Temp is selected from the alarm screen, the To Process
Temperature at the time of the alarm displays. Pressing the
RET select option key returns to the alarm.
Pressing the Next arrow displays the From Process
Temperature at the time of the alarm. Scroll through the four
temperature values by pressing the Prev and Next arrows.
6-24
TROUBLESHOOTING
Portable Chillers
UGH024/1103
PLC CONTROL ALARM SCREEN LEGEND
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-25
PLC CONTROL
PROBLEMS
Symptom
Possible cause
Solution
The control is not lit
and the chiller is not
working.
Power is not reaching the p Check the power cord and
chiller.
plug. Make sure the cord and
plug are properly connected.
p Make sure the main disconnect switch is on.
p Check fuses and breakers.
Replace or reset as required.
See Replacing Fuses, in the
Troubleshooting section.
The correct power is not
reaching the unit
Check the voltage specification on the chiller nameplate.
There is a problem with
the PLC.
p Check fuses and replace
as needed. See Replacing
Fuses, in the Troubleshooting
section.
p Check the cable between
the control panel and the PLC;
reconnect or replace as needed.
p Check the PLC indicator
lights: Power and Program
Run lights should be lit.
Contact Conair Service if status is not normal.
There is a problem with
the control panel.
6-26
TROUBLESHOOTING
Portable Chillers
The control panel may have
failed. Contact Conair Service.
UGH024/1103
PLC CONTROL
PROBLEMS
CONT’D
Symptom
Possible cause
Solution
The control is lit and
there is no alarm
condition. The compressor hums, but
does not run.
The input voltage is
incorrect
Check the main supply voltage. It must be within 10% of
the nameplate rating.
There is a phase loss.
p Check the fuses on the
main power supply. Replace or
reset as required. See
Replacing Fuses, in the
Troubleshooting section.
p Check the phase-to-phase
voltages.
p Check phase continuity
through the compressor contactor.
p Check the wiring at the
compressor.
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-27
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Low Water Tank
Level alarm
Water level in tank is low. Fill tank to proper level. See
Checking Reservoir Level, in
the Maintenance section.
Inspect for leaks in the process
piping. Repair as necessary.
See Making Plumbing
Connections, in the Installation
section.
Failed Level switch.
Solution
Check level gauge and compare it to status of the level
switch by checking continuity
of switch in electrical enclosure. Refer to wiring diagrams.
Clean switch; replace as needed.
IF CHILLER HAS
AUTO-FILL OPTION:
6-28
Solenoid valve faulty.
Check level gauge and compare it to status of the level
switch by checking continuity
of switch in electrical enclosure. Refer to wiring diagrams.
Clean switch; replace as needed.
Water supply valve
closed.
Open supply valve.
Input wiring to PLC
incorrect.
Check wiring diagrams and
compare to wiring to PLC;
correct as needed.
TROUBLESHOOTING
Portable Chillers
UGH024/1103
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
Flow Fault alarm
The To Process and From
Process valves are closed.
Open valve(s).
The Process fluid strainer Clean the strainer.
is clogged.
UGH024/1103
Water level in reservoir is
low and float switch
failed.
Fill the reservoir. See Making
Process Plumbing
Connections, in the Installation
section.
The evaporator is fouled.
Clean Evaporator. See
Cleaning the Evaporator or
Water-cooled Condenser, in the
Maintenance section.
Pump is not running.
Check the overload module.
Reset or replace as needed.
See Replacing Overload
Modules, in the
Troubleshooting section.
Pump is running backwards; no pump pressure
is indicated on pump discharge pressure gauge.
Switch any two of the three
main power leads.
Evaporator is frozen.
Apply warm air to the evaporator to thaw.
Portable Chillers
TROUBLESHOOTING
6-29
PLC CONTROL
ALARM
CONDITIONS
Alarm
Low Suction
Pressure alarm
Possible cause
Solution
No or low flow with a
failed flow switch and
RTD.
Check To Process and From Process
valves to see if they are open. Check
Flow switch and RTD. Replace as needed.
Compressor suction valve
is closed.
Open valve.
The Evaporator is fouled.
Clean Evaporator. See Cleaning the
Evaporator or Water-cooled Condenser, in
the Maintenance section.
Evaporator frozen.
p Check flow switch, RTD, temperature transmitter and low temperature
cutout on temperature controller.
Replace as needed.
p Check PLC control for proper percent ethylene glycol or propylene glycol solution. Change percent glycol setpoint, if needed. Add glycol if needed.
Faulty TXV solenoid.
Check wiring, voltage, coil and relay (see
electrical drawings); replace as needed.
Refrigerant leak.
Check for oil in chiller cabinet and bubbles in refrigerant sight glass. Consult
Conair Service for repair.
Faulty pressure transduc- See Checking the Pressure Transducer, in
the Troubleshooting section.
er.
6-30
Condenser air or water
too cold.
Check air/water temperature. Water
should be 65 F or higher; air temperature
should be 60 F or higher.
Wiring incorrect.
Use wiring diagrams and check wiring.
Correct as needed.
TROUBLESHOOTING
Portable Chillers
UGH024/1103
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
High Discharge
Pressure alarm
Clogged/dirty air-cooled con- Clean the coil. See Cleaning the Airdenser.
cooled Condenser, in the Maintenance
section.
Solution
Blocked air flow to air-cooled Move chiller or unblock air passageway.
condenser.
Low condenser water flow or Check required flow; see Specifications in
water too warm to waterthe Description section.
cooled condenser.
Blocked condenser water line Unblock line; open valve. Check and
or valve closed.
clean filter strainer.
Condenser fouled.
Clean the condenser. See Cleaning the
Air-cooled Condenser, and Cleaning the
Evaporator or Water-cooled Condenser, in
the Maintenance section.
Fan motor not running.
Check fan cycling operation settings.
Motor may be bad. See Drive manual
electrical information accompanying this
user guide.
Faulty liquid line solenoid
valve.
Check voltage. Replace valve as needed.
Compressor discharge valve Open valve.
closed (if supplied).
UGH024/1103
Overcharged with refrigerant.
See Checking the Refrigerant Charge, in
the Maintenance section.
Faulty water regulating
valve.
Repair or replace the valve.
Faulty pressure transducer.
See Checking the Pressure Transducer, in
the Troubleshooting section.
Input wiring to PLC incorrect.
Check wiring diagrams and compare to
wiring to PLC; correct as needed.
Portable Chillers
TROUBLESHOOTING
6-31
PLC CONTROL
ALARM
CONDITIONS
6-32
Alarm
Possible cause
Solution
Comp 1 Rotation
Error alarm
Compressor 1 is wired
incorrectly.
Shut off chiller supply voltage.
Switch any two leads:
l at compressor if it was
replaced.
l
at main terminal block if
new unit installation.
Turn chiller on.
High pressure transducer
is faulty.
See Checking the Pressure
Transducer, in the
Troubleshooting section.
TROUBLESHOOTING
Portable Chillers
UGH024/1103
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
Pump Overload
alarm
Overload set incorrectly.
Check table on wiring diagram
for correct full load amperage
(FLA) draw. Adjust overload
accordingly.
Low supply voltage.
o
Faulty contactor
Check line and load side of
contactor. It should be less
than 5 volt drop across the
contactor. If it is not, replace
the contactor. See Replacing
the Contactor in the
Troubleshooting section.
Check supply voltage.
Supply voltage to contactor
should be +- 10% of nameplate voltage.
o Check wire terminations
and connections. Tighten if
loose.
Faulty overload module.
Control voltage is incorrect.
UGH024/1103
Check amp draw of circuit. If
it is under the rated setting,
replace the overload module.
See Replacing Overload
Modules, in the
Troubleshooting section.
Check 24VDC required for
contactor auxiliary input. If
control voltage is OK replace
PLC.
Portable Chillers
TROUBLESHOOTING
6-33
PLC C ONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
High Temperature
Safety Temp >95 F
alarm
The hot gas bypass valve
is not working properly
(possibly stuck open)
Shut isolation valve to the Hot
Gas Bypass solenoid. If the To
Process temperature starts to
go down, the solenoid valve is
faulty. Have a certified refrigeration technician replace the
solenoid valve.
Load is too high for the
chiller.
Remove some load from the
process.
Fluid is not flowing
between the supply outlet
and return outlet.
Check for plugged pipes,
closed valves, or failed flow
switch.
The compressor is not
running.
Check to see if Compressor
light is lit on the control. If it
is not, check compressor overload in compressor terminal
box. Check power to compressor and power to compressor
contactor.
Failed RTD or
See Checking the Temperature
Temperature Transmitter. Transmitter and RTD in the
Troubleshooting section.
6-34
TROUBLESHOOTING
Portable Chillers
UGH024/1103
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
Low Temperature
Cutout alarm
The hot gas bypass valve
is not working properly
(possibly stuck closed).
If the To Process temperature
starts to go down, the solenoid
valve is faulty. Have a certified
refrigeration technician replace
the solenoid valve.
Check voltage to coil; replace
coil if needed.
Fluid flow is insufficient.
Check for plugged pipes,
closed valves, or failed flow
switch.
Failed RTD or
Temperature Transmitter.
See Checking the Temperature
Transmitter and RTD, in the
Troubleshooting section.
Hot Gas Bypass valve
relay failed.
Replace as needed (see electrical drawings.)
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-35
PLC CONTROL
ALARM
CONDITIONS
6-36
Alarm
Possible cause
SOLUTION
Compressor
Overload alarm
Overload set incorrectly.
Check table on wiring diagram
for correct rated load amperage
(RLA) draw. Adjust overload
accordingly.
Low supply voltage.
o
Faulty contactor
Check line and load side of
contactor. It should be less
than 5 volt drop across the
contactor. If it is not, replace
the contactor. See Replacing
the Contactor in the
Troubleshooting section.
Faulty overload module.
Check amp draw of circuit. If
it is under the rated setting,
replace the overload module.
See Replacing Overload
Modules, in the
Troubleshooting section.
TROUBLESHOOTING
Portable Chillers
Check supply voltage.
Supply voltage to contactor
should be +- 10% of nameplate voltage.
o Check wire terminations
and connections. Tighten if
loose.
UGH024/1103
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
High Temperature
Temp > 75°F for
5 min alarm
Load too high for chiller.
Reduce load on chiller; if not
able to reduce load, choose a
chiller with more capacity.
Refrigeration circuit not
working properly.
Check refrigerant circuit. See
Checking Refrigerant Charge,
in the Installation section.
Compressor malfunctioned.
Check voltage to compressor.
Check contact points on contactor. Replace if needed.
Refrigeration charge low.
Check temperature on suction
line; it should be less than 60
°F. Check refrigerant sight
glass for bubbles. Charge with
refrigerant if needed.
Temperature sensor is
faulty (for A/W2-3.5 and
A/W2-5 models only).
Replace temperature sensor
mounted on the discharge side
of the compressor (trip point is
260 °F).
High Discharge
Temperature alarm
(models 3.5 and 5
HP models only)
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-37
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
Evaporator Filter
Fault alarm
Clogged strainer.
Clean strainer; replace as needed.
Evaporator fouled.
6-38
TROUBLESHOOTING
Clean Evaporator. See Cleaning
the Evaporator or Water-cooled
Condenser, in the Maintenance
section.
A valve is closed in the
process water flow piping.
Check valves; open if closed.
There is a PLC voltage
problem.
Check voltage (see electrical
drawings).
The differential pressure
switch is faulty.
Check wiring and voltage;
replace switch as needed.
Other piping obstruction.
Check that all piping is large
enough to carry fluid. Replace
any piping or conduit that is too
small. Clean any clogs.
Portable Chillers
UGH024/1103
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
Condenser Filter
Fault alarm
(Water-cooled models only)
Clogged strainer.
Clean strainer; replace as needed.
The differential pressure
switch is faulty.
Check wiring and voltage; replace
switch as needed.
Other piping obstruction.
Check that all piping is large
enough to carry fluid. Replace
any piping or conduit that is too
small. Clean any clogs.
Condenser fouled.
Clean Condenser. See Cleaning
the Evaporator or Water-cooled
Condenser, in the Maintenance
section.
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-39
PLC CONTROL
ALARM
CONDITIONS
6-40
Alarm
Possible cause
Solution
High Discharge
Pressure 2 alarm
Clogged/dirty air-cooled
condenser.
Clean the coil. See Cleaning the
Air-cooled Condenser, in the
Maintenance section.
Blocked air flow to aircooled condenser.
Move chiller or unblock air passageway.
Low condenser water flow
or water too warm to watercooled condenser.
Check required flow; see
Specifications in the Description
section.
Blocked condenser water
line or valve closed.
Unblock line; open valve. Check
and clean filter strainer.
Condenser fouled.
Clean the condenser. See Cleaning
the Air-cooled Condenser, and
Cleaning the Evaporator or Watercooled Condenser, in the
Maintenance section.
Fan motor not running.
Check fan cycling operation settings. Motor may be bad. See Drive
manual electrical information
accompanying this user guide.
Faulty liquid line solenoid
valve.
Check voltage. Replace valve as
needed.
Compressor discharge valve
closed (if supplied).
Open valve.
Overcharged with refrigerant.
See Checking the Refrigerant
Charge, in the Maintenance section.
Faulty water regulating
valve.
Repair or replace the valve.
Faulty pressure transducer.
See Adjusting the Pressure
Transducer, in the Troubleshooting
section.
TROUBLESHOOTING
Portable Chillers
UGH024/1103
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
Low Suction
Pressure 2 alarm
No or low flow with a
failed flow switch and
RTD.
Check To Process and From Process
valves to see if they are open. Check
Flow switch and RTD. Replace as
needed.
Compressor suction valve Open valve.
is closed.
The Evaporator is fouled. Clean Evaporator. See Cleaning the
Evaporator or Water-cooled Condenser,
in the Maintenance section.
p Check flow switch, RTD, temperature transmitter and low temperature
cutout on temperature controller.
Replace as needed.
p Check PLC control for proper percent ethylene glycol or propylene
glycol solution. Change percent glycol setpoint, if needed. Add glycol if
needed.
Evaporator frozen.
Faulty TXV solenoid.
Check wiring, voltage, coil and relay
(see electrical drawings); replace as
needed.
Refrigerant leak.
Check for oil in chiller cabinet and
bubbles in refrigerant sight glass.
Consult Conair Service for repair.
Faulty pressure transduc- See Checking the Pressure Transducer,
er.
in the Troubleshooting section.
UGH024/1103
Condenser air or water
too cold.
Check air/water temperature. Water
should be 65 F or higher; air temperature should be 60 F or higher.
Wiring incorrect.
Use wiring diagrams and check wiring.
Correct as needed.
Portable Chillers
TROUBLESHOOTING
6-41
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
SOLUTION
Compressor Fault
alarm
Compressor module protector fault.
See compressor manual
accompanying this user guide.
If necessary, call your Conair
Service Representative.
Compressor malfunctioned.
Call your Conair Service
Representative.
Compressor 2 Fault
alarm
6-42
TROUBLESHOOTING
Portable Chillers
UGH024/1103
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
SOLUTION
Compressor 2
Overload alarm
Overload set incorrectly.
Check table on wiring diagram for
correct rated load amperage
(RLA) draw. Adjust overload
accordingly.
Low supply voltage.
o
Faulty contactor
Check line and load side of contactor. It should be less than 5 volt
drop across the contactor. If it is
not, replace the contactor. See
Replacing the Contactor in the
Troubleshooting section.
Faulty overload module.
Check amp draw of circuit. If it is
under the rated setting, replace the
overload module. See Replacing
Overload Modules, in the
Troubleshooting section.
Check supply voltage. Supply
voltage to contactor should be
+- 10% of nameplate voltage.
o Check wire terminations and
connections. Tighten if loose.
Control voltage is incorrect. Check 24VDC required for contactor auxiliary input. If control
voltage is OK replace PLC.
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-43
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
Solution
Compressor 2
Rotation Fault alarm
Compressor 2 is wired
incorrectly.
Shut off chiller supply voltage.
Switch any two leads:
l
at main terminal block if
new unit installation.
l at compressor if it was
replaced.
Turn chiller on.
High pressure transducer
is faulty.
Check discharge pressure on
the Status screen.
See Checking the Pressure
Transducer, in the
Troubleshooting section.
6-44
TROUBLESHOOTING
Portable Chillers
UGH024/1103
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause Solution
Fan Overload alarm
Access door is open.
Close access door.
Overload switch has been Reset overload switch.
manually shut off.
Overload set incorrectly. Check table on wiring diagram for
correct full load amperage (FLA)
draw. Adjust overload accordingly.
Low supply voltage.
o
Faulty contactor
Check line and load side of contactor. It should be less than 5 volt drop
across the contactor. If it is not,
replace the contactor. See Replacing
the Contactor in the Troubleshooting
section.
Check supply voltage. Supply
voltage to contactor should be +10% of nameplate voltage.
o Check wire terminations and
connections. Tighten if loose.
Faulty overload module. Check amp draw of circuit. If it is
under the rated setting, replace the
overload module. See Replacing
Overload Modules, in the
Troubleshooting section.
Control voltage is incorrect.
UGH024/1103
Check 24VDC required for contactor auxiliary input. If control voltage
is OK replace PLC.
Portable Chillers
TROUBLESHOOTING
6-45
PLC CONTROL
ALARM
CONDITIONS
Alarm
Possible cause
SOLUTION
Discharge Pressure
Sensor Failure alarm
Wiring bad.
Check wiring; correct as needed.
There is RF interference.
Check for any electromagnetic
interference (for example, from
radios). Remove any objects
causing the problem.
The sensor has been dam- Check discharge pressure status.
aged.
See Checking the Pressure
Transducer, in the Maintenance
section. Repair or replace the
sensor.
Wiring bad.
Check wiring; correct as needed.
There is RF interference.
Check for any electromagnetic
interference (for example, from
radios). Remove any objects
causing the problem.
Discharge Pressure
Sensor 2 Failure
alarm
The sensor has been dam- Check discharge pressure status.
aged.
See Checking the Pressure
Transducer, in the Maintenance
section. Repair or replace the
sensor.
6-46
TROUBLESHOOTING
Portable Chillers
UGH024/1103
WARNING: Electrical hazard
Before performing any work on this unit, disconnect and lock out electrical power sources to
prevent injury from unexpected energization or
startup.
CHECKING AND
REPLACING
SWITCHES
There is a flow switch in the process fluid line to verify flow.
To replace a flow switch:
1
Disconnect and lockout power to the chiller.
2
Open the electrical enclosure and locate the
3
Check the switch.
connection for the correct switch on the terminal switch.
Refer to the wiring diagrams you received with your
chiller to find the correct terminals.
Check continuity within the switch and make sure it corresponds to the condition of the switch. Clean the switch
if needed.
4
Replace the switches as needed.
Drain the tank to replace the switch(es).
To check a flow switch:
1
Slide the top of the switch housing over until
the N.O. (normally open) shows when electrical cover is
placed back on.
Always refer to the wiring
diagrams that came with
your chiller to locate specific
electrical components.
Flow switch
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-47
REPLACING
RTD PLC
THE
ONLY
To replace the RTD:
1
Disconnect and lockout power to the chiller.
2
Disconnect the To Process tubing from the
To Process connection.
Fill / Drain
valve
Fill / Drain
valve
To Process
connection
3
Open the Drain/Fill valve and drain water
from the unit so the water level is lower that the RTD.
Always refer to the
wiring diagrams you
received with your
chiller to locate specific
electrical components.
4
Open the side of the chiller.
5
Disconnect the RTD wiring from the
transmitter electrical box. Refer to the wiring diagram.
6
Remove the RTD.
Loosen the compression nut to slide the RTD out of the
evaporator.
7
Install the new RTD.
The new RTD should be inserted in the evaporator so that
the tip is extended completely through the evaporator.
8
Wire the RTD. to the temperature transmitter
to the TIC control in the top electrical enclosure, or to
the temperature transmitter (PLC control) and the electrical box.
Temperature
transmitter
electrical box
Sensor
Sensor
6-48
TROUBLESHOOTING
Portable Chillers
UGH024/1103
The pump’s wet end (impeller, motor, and seal assembly) can
be removed for service.
1
2
Disconnect and lockout power to the chiller.
REMOVING
PUMP
COMPONENTS
Open the drain/fill valve and
drain the water from the chiller.
Open
this
side
Open
this
side
Fill / Drain
valve
3
4
Open the side of the chiller.
5
Remove the pump assembly.
6
Inspect, clean, and replace pump parts
Remove the bolts connecting the pump
assembly to the pump housing.
Carefully slide it sideways away from the pump tank to
avoid damage.
as needed. Separate the pump assembly from the pump
volute (casing) by prying the flanges and pulling apart.
Follow the disassembly and reassembly procedures in the
pump manufacturer’s manual that accompanies this User
Guide.
UGH024/1103
Portable Chillers
TROUBLESHOOTING
6-49
REPLACING
FUSES
WARNING: Electrical hazard
Before performing any work on this unit, disconnect and lock out electrical power sources
to prevent injury from unexpected energization
or startup.
To replace fuses:
Always refer to the wiring diagrams you received with your
chiller to locate specific electrical components.
Control transformer
primary fuses*
1
Disconnect and lockout power to the chiller.
2
Open the electrical enclosure and locate
3
Remove and replace fuses.
4
Restore power to the chiller.
the fuses. Refer to the wiring diagram for the exact location.
Control transformer
secondary fuse
Control transformer
primary fuses*
Control transformer
secondary fuse
*Optional.
6-50
TROUBLESHOOTING
Portable Chillers
UGH024/1103
WARNING: Electrical hazard
Before performing any work on this unit, disconnect and lock out electrical power sources to
prevent injury from unexpected energization or
startup.
To replace contactor for the pump or compressor:
1
Disconnect and lockout power to the chiller.
2
Open the electrical enclosure and locate
3
Disconnect the wiring from the contactor.
REPLACING THE
CONTACTOR
the correct contactor. Refer to the wiring diagrams you
received with your chiller.
Make sure you label each wire so you can correctly install
the new unit.
4
Remove the contactor by snapping off
5
6
Snap in the new contactor on the DIN rail.
the DIN rail mounting.
Always refer to the wiring
diagrams that came with
your chiller to locate specific
electrical components.
Reconnect the wiring and reconnect power
to the chiller.
Pump
contactor
Compressor
contactor
Pump
contactor
UGH024/1103
Portable Chillers
Fan contactor
TROUBLESHOOTING
6-51
Conair has made the largest investment in customer support in
the plastics industry. Our service experts are available to help
with any problem you might have installing and operating
your equipment. Your Conair sales representative also can
help analyze the nature of your problem, assuring that it did
not result from misapplication or improper use.
WE’RE HERE
TO HELP
To contact Customer Service personnel, call:
HOW TO
CONTACT
CUSTOMER
SERVICE
From outside the United States, call: 814-437-6861
You can commission Conair service personnel to provide onsite service by contacting the Customer Service Department.
Standard rates include an on-site hourly rate, with a one-day
minimum plus expenses.
If you do have a problem, please complete the
following checklist before calling Conair:
r
Make sure you have all model, serial and parts list
numbers for your particular equipment. Service
personnel will need this information to assist you.
r
Make sure power is supplied to the equipment.
r
Make sure that all connectors and wires within
and between control systems and related
components have been installed correctly.
r
Check the troubleshooting guide of this manual
for a solution.
r
Thoroughly examine the instruction manual(s)
for associated equipment, especially controls.
Each manual may have its own troubleshooting
guide to help you.
r
Check that the equipment has been operated as
described in this manual.
r
Check accompanying schematic drawings for
information on special considerations.
SERVICE INFORMATION
BEFORE YOU
CALL ...
Additional manuals and
prints for your Conair
equipment may be
ordered through the
Customer Service or
Parts Departments for
a nominal fee.
APPENDIX A-1
EQUIPMENT
GUARANTEE
Conair guarantees the machinery and equipment on this
order, for a period as defined in the quotation from date of
shipment, against defects in material and workmanship
under the normal use and service for which it was recommended (except for parts that are typically replaced after
normal usage, such as filters, liner plates, etc.). Conair’s
guarantee is limited to replacing, at our option, the part or
parts determined by us to be defective after examination.
The customer assumes the cost of transportation of the
part or parts to and from the factory.
PERFORMANCE
WARRANTY
Conair warrants that this equipment will perform at or
above the ratings stated in specific quotations covering the
equipment or as detailed in engineering specifications,
provided the equipment is applied, installed, operated and
maintained in the recommended manner as outlined in our
quotation or specifications.
Should performance not meet warranted levels, Conair at
its discretion will exercise one of the following options:
l
Inspect the equipment and perform alterations or
adjustments to satisfy performance claims. (Charges
for such inspections and corrections will be waived
unless failure to meet warranty is due to misapplication, improper installation, poor maintenance practices
or improper operation.)
l
Replace the original equipment with other Conair
equipment that will meet original performance claims
at no extra cost to the customer.
l
Refund the invoiced cost to the customer. Credit is
subject to prior notice by the customer at which time a
Return Goods Authorization Number (RGA) will be
issued by Conair’s Service Department. Returned
equipment must be well crated and in proper operating
condition, including all parts. Returns must be prepaid.
Purchaser must notify Conair in writing of any claim and
provide a customer receipt and other evidence that a claim
is being made.
WARRANTY
LIMITATIONS
A-2
APPENDIX
Except for the Equipment Guarantee and Performance
Warranty stated above, Conair disclaims all other warranties with respect to the equipment, express or
implied, arising by operation of law, course of dealing,
usage of trade or otherwise, including but not limited to
the implied warranties of merchantability and fitness for
a particular purpose.
WARRANTY INFORMATION
MAINTENANCE
LOG
Date
Reading
Maintenance Item
Compressor 1 Amps,
100% loaded
Compressor 2 Amps,
100% loaded
Discharge Pressure 1
Discharge Pressure 2
Suction pressure 1
Suction pressure 2
Evaporator water out
temperature
Process Water Pressure
Condenser 1 Water
Temperature, In/Out
Condenser 2 Water
Temperature, In/Out
Condenser Water Pressure,
In/Out
Condenser 1 Fan Amps
Condenser 2 Fan Amps
Process Pump Amps
Recirculation Pump Amps
Unit Volts
Primary
Secondary
Condenser Air Temp In
Condenser Air Temp Out
Oil Level
Super Heat
Temperature Setpoint
RTD Temperatures (4)
UGH024/1103
Portable Chillers
APPENDIX B-1
PRESSURE
TABLES
Evaporator and Piping
Pressure Drops
Size 1
PCA/PCW-7.5
PCA/PCW-2
PCA/PCW-1.5
PCA/PCW-3
PCA/PCW-4
PCA/PCW-10, PCA-13
PCA/PCW-5
PCW-15
Flow Rate, GPM
PCA/PCW-10
PCA/PCW-7.5
Size 2
PCA/PCW-5
PCA/PCW-5
PCA/PCW-20
PCA/PCW-15
PCA/PCW-3.5
Flow Rate, GPM
UGH024/1103
Portable Chillers
APPENDIX C-1
PRESSURE
TABLES
Evaporator and Piping
Pressure Drops
PCA/PCW-10
PCA/PCW-5
PCA/PCW-7.5
PCA/PCW-5
PCA/PCW-20
PCA/PCW-15
PCA/PCW-3.5
Flow Rate, GPM
C-2 APPENDIX
Portable Chillers
UGH024/1103
PRESSURE
TABLES
Condenser and Piping
Pressure Drops
Size 1
PCW-1.5
PCW-2 PCW-3
PCW-7.5
PCW-4 PCW-5
PCW-10 PCW-15
Flow Rate, GPM
PCA/PCW-10
PCA/PCW-7.5
Size 2
PCA/PCW-5
PCA/PCW-5
PCA/PCW-20
PCA/PCW-15
PCA/PCW-3.5
Flow Rate, GPM
UGH024/1103
Portable Chillers
APPENDIX C-3
Overhead piping installations above process connections
require installing a check valve in the To Process line and a 12
inch (305 mm) riser with check valve and vacuum break in
the From Process line to prevent siphoning when shutting
down. Install a vent tube to 12 inches (305 mm) above the
highest system point to prevent over pressurization. Maximum
height of piping above process connections is 10 ft (3 m).
vacuum break
OVERHEAD
PLUMBING
DETAILS
internal vent; 1 ft above
highest water level
check valve
12 in. riser
Condenser
Water outlet
(water-cooled only)
Condenser
Water inlet
(water-cooled only)
To Process valve
From Process valve
back view
UGH024/1103r
Portable Chillers
APPENDIX
D-1
PARTS & DIAGRAMS
UGH024/1103
Portable Chillers
P/D-1
