Introduction
Playing the Piano
Music Menu
CA97 / CA67
Owner’s Manual
Recorder
Settings
Appendix
Thank you for purchasing this Kawai Concert Artist CA97/CA67 digital piano.
This owner’s manual contains important information regarding the instrument’s usage and operation.
Please read all sections carefully, keeping this manual handy for future reference.
About this Owner’s Manual
Before attempting to play this instrument, please read the Introduction section from page 10 of this owner’s manual. This section
explains the name and function of each part, how to connect the power cable, and how to turn on the power.
The Playing the Piano section (page 16) provides an overview of the instrument’s commonly used functions, allowing the CA97/CA67
digital piano to be enjoyed almost immediately after being connected, while the Music Menu section (page 36) includes information
regarding the built-in demonstration songs, Piano Music pieces, Lesson and Finger Exercise features, and Concert Magic function.
The Recorder section (page 48) provides instructions on how to record and play back pieces stored both in the instrument’s internal
memory, and also MP3/WAV audio files saved to a USB memory device. The Settings section (page 63) details the various options
and settings that can be used to adjust the sound and operation of the instrument.
Finally, the Appendix section (page 132) includes lists for all internal sounds, songs, and drum rhythms, assembly instructions for the
CA67 model, MIDI reference information, and full specification details.
About Illustrations
All illustrations used within this owner’s manual depict the CA97 model unless stated otherwise.
Important Safety Instructions
SAVE THESE INSTRUCTIONS
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS
WARNING
CAUTION
TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS : RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR.
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the leterature
accompanying the product.
Examples of Picture Symbols
denotes that care should be taken.
The example instructs the user to take care not to allow fingers to be trapped.
denotes a prohibited operation.
The example instructs that disassembly of the product is prohibited.
denotes an operation that should be carried out.
The example instructs the user to remove the power cord plug from the AC outlet.
Read all the instructions before using the product.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prongs are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or object
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
Règles de sécurité
(Supplémentairespour le Canada)
CONSERVEZ CES INSTRUCTIONS
AVERTISSEMENT
CAUTION
POUR REDUIRE LES RISQUES
D’INCENDIE OU D’ELECTROCUTION,
PROTEGEZ CET APPAREIL DE LA
PLUIE OU DE L’HUMIDITE.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS : RISQUE DE CHOC ELECTRIQUE
- NE PAS OUVRIR.
POUR REDUIRE LES RISQUES D’INCENDIE OU D’ELECTROCUTION, NE DEMONTEZ PAS LE COUVERCLE
(OU L’ARRIERE). A L’INTERIEUR, AUCUNE PARTIE N’EST REPARABLE PAR L’UTILISATEUR.
POUR LA MAINTENANCE, ADRESSEZ-VOUS A DU PERSONNEL QUALIFIE.
Le symbole de l’éclair avec une pointe de flèche à
l’intérieur d’un triangle équilatéral met en garde
l’utilisateur contre la présence de tension
dangereuse, non isolée, à l’intérieur de l’appareil,
dont l’amplitude peut être suffisante pour induire un
risque d’électrocution d’une personne.
Le point d’exclamation à l’intérieur d’un triangle
équilatéral alerte l’utilisateur de la présence de règles
d’utilisation et d’entretien importantes dans la notice
qui accompagne l’appareil.
Exemples de symboles graphiques
Indique que des précautions doivent être prises.
L’exemple indique à l’utilisateur qu’il doit faire attention à ne pas se faire coincer les doigts.
Indique une manipulation interdite.
L’exemple indique que le démontage de l’appareil est interdit.
Indique qu’une manipulation doit être effectuée.
L’exemple indique à l’utilisateur qu’il doit débrancher le câble d’alimentation de la prise secteur.
AVERTISSEMENT
Indique un risque potentiel qui peut entraîner
la mort, ou de graves lésions, si l’appareil
n’est pas manipulé correctement.
L’introduction d’eau, d’aiguilles ou d’épingles à
cheveux, peut provoquer une panne ou un
court-circuit. Ce produit doit être mis à l’abri des
écoulements ou projections d’eau. Ne jamais
placer sur le produit des objets contenant des
liquides, tels que des vases ou autres récipients.
Faite attention de ne pas introduire un
produit étranger à l’intérieur
de l’appareil.
Ce produit n’est pas totalement déconnecté du circuit électrique
lorsqu’il est mis hors tension par le bouton d’arrêt. Si l’appareil
ne doit pas être utilisé pendant une longue période, débranchez
le câble d’alimentation de la prise secteur.
Si vous ne le faisiez pas la foudre pourrait
provoquer un incendie.
Si vous ne le faisiez pas, la surchauffe de
l’appareil pourrait provoquer un incendie.
Il est recommandé de placer l’instrument à proximité de la prise de courant et de positionner le câble d’alimentation
secteur de sorte qu’il puisse être débranché rapidement en cas d’urgence, le courant électrique étant toujours
présent tant que la prise est branchée même si le bouton de mise en marche est en position Arrêt.
[Seuls les produits avec 3P fiche]
INSTRUCTIONS DE MISE À LA TERRE
Ce produit doit être mis à la terre. En cas de défaillance matérielle ou de panne, la mise à la terre fournit un chemin de moindre
résistance au courant électrique afin de réduire le risque d’électrocution. Ce produit est équipé d’un câble avec un conducteur de
protection et une fiche de mise à la terre. La fiche doit être branchée dans une prise appropriée correctement installée et mise à la
terre conformément à tous les codes et règlements locaux.
DANGER - La connexion incorrecte du conducteur de protection peut présenter un risque d’électrocution.
Consultez un électricien ou un réparateur qualifié si vous avez des doutes en ce qui concerne la mise à la terre du produit. Ne
modifiez pas la fiche fournie avec le produit – si elle n’est pas adaptée à la prise, faites installer une prise correcte par un électricien
qualifié.
PRECAUTION
Indique un risque potentiel qui peut entraîner la détérioration,
ou des dommages, pour l’appareil ou ses propriétés, si celui-ci
n’est pas manipulé correctement.
Description de la l'emplacement de la reference (Le cas échéant):
Anglais phrase: The nameplate label is located on the underside of the instruments, as indicated below.
Français phrase: La reference commerciale est inscrite sur une etiquette en dessous de votre instrument, conformement
a l’indication ci-dessous.
Votre piano doit être placé à un endroit tel que sa position n’altère pas sa propre ventilation. Gardez une
distance minimum de 5 cm autour de l’instrument pour une aération suffisante.
WARNING - When using electric products, basic precautions should always be followed, including the following.
WARNING
The product should be connected to
an AC outlet of the specified voltage.
Indicates a potential hazard that could result in death or
serious injury if the product is handled incorrectly.
120V
230V
240V
� If you are going to use an AC power cord,
make sure that its has the correct plug shape
and conforms to the specified power voltage.
� Failure to do so may result in fire.
Do not insert or disconnect the power
cord plug with wet hands.
Doing so may cause electric shock.
Take care not to allow any foreign
matter to enter the product.
Entry of water, needles or hair pins may result
in breakdown or short-circuit.
The product shall not be exposed to dripping or
splashing. No objects filled with liquids, such as
vases, shall be placed on the product.
The chair must be used properly (it must be
used only when playing the product).
� Do not play with it or stand on it.
� Only one person is allowed to sit on it.
� Do not sit on it when opening the lid.
� Re-tighten the bolts occasionally.
Doing so may cause the chair to fall over or your
fingers to be trapped, resulting in injury.
When using the headphones, do not
listen for long periods of
time at high volume levels.
Doing so may result in hearing problems.
Do not lean against the keyboard.
Doing so may cause the product to fall over,
resulting in injury.
Do not disassemble, repair or modify
the product.
Doing so may result in product breakdown, electric
shock or short-circuit.
When disconnecting the AC power cord's
plug, always hold the plug
and pull it to remove it.
� Pulling the AC power cord itself may damage
the cord, causing a fire, electric shock or
short-circuit.
The product is not completely disconnected from the
power supply even when the power switch is turned
off. If the product will not be used for a long time,
unplug the AC power cord from the AC outlet.
� Failure to do so may cause fire in case of
lightning.
� Failure to do so may over-heat the product,
resulting in fire.
This product may be equipped with a polarized line plug (one blade wider
than the other). This is a safety feature.
If you are unable to insert the plug into the outlet, contact an electrician to
replace your obsolete outlet.
Do not defeat the safety purpose of the plug.
This product shall be near the AC outlet and the power cord plug in a position so that it can readily be
disconnected in an emergency because electricity is always charging while the plug is in the AC outlet
even in a power switch off condition.
CAUTION
Indicates a potential hazard that could result in injury or
damage to the product or other property if the product
is handled incorrectly.
Do not use the product in the following areas.
� Areas, such as those near windows, where the product is
exposed to direct sunlight
� Extremely hot areas, such as near a heater
� Extremely cold areas, such as outside
� Extremely humid areas
� Areas where a large amount of sand or dust is present
� Areas where the product is exposed to excessive
vibrations
Using the product in such areas may result in
product breakdown.
Use the product only in moderate climates (not
in tropical climates).
When you close the keyboard cover,
close it gently.
Closing it roughly may trap your fingers,
resulting in injury.
Before connecting cords, make sure
that the power to this product
and other devices is turned
OFF.
OFF
Failure to do so may cause breakdown of this
product and other devices.
Do not drag the product on the floor.
Take care not to drop the product.
Please lift up the product when moving it.
Please note that the product is heavy and must
be carried by more than two persons.
Dropping the product may result in breakdown.
Do not place the product near electrical
appliances such as TVs and radios.
� Doing so may cause the product to generate
noise.
� If the product generates noise, move the
product sufficiently away from the electrical
appliance or connect it to another AC outlet.
When connecting the AC power cord
and other cords, take care
not to get them tangled.
Failure to do so may damage them, resulting in
fire, electric shock or short-circuit.
Do not wipe the product with benzene
or thinner.
� Doing so may result in discoloration or deformation
of the product.
� When cleaning the product, put a soft cloth in
lukewarm water, squeeze it well, then wipe the
product.
Do not stand on the product or exert
excessive force.
� Doing so may cause the product to become
deformed or fall over, resulting in breakdown
or injury.
Do not place naked flame, such as lighted
candles on the product.
Doing so may cause the illumination to fall over,
resulting in fire.
Ensure that the ventilation is not
impeded by covering the ventilation
openings with items, such as newspaper,
table-cloths, curtains, etc.
Failure to do so may over-heat the product,
resulting in fire.
The product should be located so that its location or position does not interfere with its proper ventilation. Ensure a
minimum distance of 5cm around the product for sufficient ventilation.
The product should be serviced by qualified service personnel when:
� The power supply cord or the plug has been damaged.
� Objects have fallen, or liquid has been spilled into the product.
� The product has been exposed to rain.
� The product does not appear to operate normally or exhibits a marked change in performance.
�The product has been dropped, or the enclosure damaged.
Notes on Repair
Should an abnormality occur in the product, immediately turn the power OFF, disconnect the power cord plug, and then
contact the shop from which the product was purchased.
CAUTION:
To prevent electric shock, match wide blade of plug to wide slot, fully insert.
ATTENTION:
Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la borne correspondante de la prise et
pousser jusqu'au fond.
An information on Disposal for users
If your product is marked with this recycling symbol it means that, at the end of its life, you must dispose of it
separately by taking it to an appropriate collection point.
You should not mix it with general household waste. Disposing of this product correctly will prevent potential negative
effects on the environment and human health which could otherwise arise due to inappropriate waste handling.
For further details, please contact your local authority.
(European Union only)
Instruction for AC power cord (U.K.)
IMPORTANT
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE.
BLUE :
NEUTRAL
BROWN : LIVE
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED.
Do not plug either terminal of the power cord to the the ground od AC outlet on the wall.
Canadian Radio Interference Regulations
This instrument complies with the limits for a class B digital apparatus, pursuant to the Radio Interference Regulations,
C.R.C., c. 1374.
FCC Information (U.S.A)
CAUTION : Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Declaration of Conformity
Products :
Model Number :
Responsible Party Name :
Address :
Telephone
The nameplate label is located on
the underside of the instrument, as
indicated below.
Electronic Piano
CA97/CA67
Kawai America Corporation
2055 East University Drive Rancho
Dominguez, CA 90220
310-631-1771
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
This applies only to products distributed by Kawai America Corporation.
Nameplate
Table of Contents
Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . 3
Concert Magic. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
  1. Performing a Concert Magic song . . . . . . . . . . . . . . . . . 44
  2. Concert Magic demo mode . . . . . . . . . . . . . . . . . . . . . . . 45
Introduction
Welcome to the Concert Artist. . . . . . . . . . . . . . . . . . . . . . . 10
  1. Feature Highlights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
  2. Owner’s Manual Conventions . . . . . . . . . . . . . . . . . . . . . 11
Part Names and Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting Up the Piano. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Adjusting the Volume / Using Headphones. . . . . . . . . 15
Playing the Piano
Using the Pedals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Selecting Sounds. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
  4. Concert Magic song arrangement types . . . . . . . . . . . 47
Recorder
Song Recorder (Internal Memory). . . . . . . . . . . . . . . . . . . . . 48
  1. Recording a song. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
  2. Playing a song. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
  3. Internal Recorder Edit menu. . . . . . . . . . . . . . . . . . . . . . . 51
  4. Erasing a part/song. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
  5. Converting a song to an audio file . . . . . . . . . . . . . . . . . 53
Audio Record/Playback (USB Memory) . . . . . . . . . . . . . . . 54
  1. Recording a MP3/WAV audio file. . . . . . . . . . . . . . . . . . . 54
Dual Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
  2. Playing an MP3/WAV audio file . . . . . . . . . . . . . . . . . . . . 56
Split Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
  3. Playing a MIDI song file . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Four Hands Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
  4. USB Recorder Edit menu. . . . . . . . . . . . . . . . . . . . . . . . . . 60
Reverb. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Effects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Virtual Technician. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
  1. Smart Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
  2. Advanced Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Metronome / Drum Rhythms. . . . . . . . . . . . . . . . . . . . . . . . 30
  5. Converting a MIDI song to an audio file . . . . . . . . . . . . 61
  6. Overdubbing a MP3/WAV audio file. . . . . . . . . . . . . . . . 62
Settings
Function menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Basic Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
  1. Key Transpose. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Registration Memories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
  2. Song Transpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
  1. Selecting a Registration memory. . . . . . . . . . . . . . . . . . 32
  3. Tone Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
  2. Storing a Registration memory. . . . . . . . . . . . . . . . . . . . 33
    User Tone Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
  3. Registration Edit menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
  4. Speaker Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Panel Lock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
  5. Line In Level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Music Menu
  6. Wall EQ (CA97 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
  7. Tuning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Demo Songs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
  8. Damper Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Piano Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
  9. Split . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Lesson Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
  1. Selecting a lesson book/song . . . . . . . . . . . . . . . . . . . . . 38
  2. Listening to the selected lesson song. . . . . . . . . . . . . . 39
  3. Lesson Function settings. . . . . . . . . . . . . . . . . . . . . . . . . . 40
  4. Repeating sections of a lesson song . . . . . . . . . . . . . . . 41
  5. Recording a lesson song practice. . . . . . . . . . . . . . . . . . 42
8
  3. Concert Magic settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
  6. Finger Exercises. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
10. Four Hands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
11. LCD Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
12. Startup Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
13. Factory Reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
14. Auto Power Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Settings (cont.)
Settings (cont.)
Virtual Technician Settings. . . . . . . . . . . . . . . . . . . . . . . . . . 80
USB MIDI (USB to Host connector). . . . . . . . . . . . . . . . . . 118
  1. Touch Curve. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
USB Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
    User Touch Curve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
  1. Load Song . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
  2. Voicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
  2. Load Registration All. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
    User Voicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
  3. Load Registration Single. . . . . . . . . . . . . . . . . . . . . . . . . 122
  3. Damper Resonance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
  4. Load Startup Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
  4. Damper Noise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
  5. Save Internal Song. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
  5. String Resonance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
  6. Save SMF Song. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
  6. Undamped String Resonance . . . . . . . . . . . . . . . . . . . . . 89
  7. Save Registration All. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
  7. Cabinet Resonance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
  8. Save Registration Single . . . . . . . . . . . . . . . . . . . . . . . . . 127
  8. Key-off Effect. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
  9. Save Startup Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
  9. Fall-back Noise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
10. Rename File. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
10. Hammer Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
11 Delete File. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
11. Topboard Simulation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
12 Format USB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
12. Decay Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
13. Minimum Touch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
14. Stretch Tuning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
    User Tuning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
15. Temperament. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
    User Temperament. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
16. Temperament Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
17. Key Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
    User Key Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Appendix
Assembly Instructions (CA67 only). . . . . . . . . . . . . . . . . . . . 132
Connecting to Other Devices. . . . . . . . . . . . . . . . . . . . . . . 136
Jack Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Headphone Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Demo Song List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
18. Half-Pedal Adjust. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Sound List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
19. Soft Pedal Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Program Change Number List. . . . . . . . . . . . . . . . . . . . . . 142
Phones Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Drum Rhythm List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
  1. SHS Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
  2. Phones Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
  3. Phones Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
MIDI Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
MIDI Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
MIDI Exclusive Data Format . . . . . . . . . . . . . . . . . . . . . . . . 146
MIDI Implementation Chart . . . . . . . . . . . . . . . . . . . . . . . . 147
User Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
  1. MIDI Channel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
  2. Send Program Change Number . . . . . . . . . . . . . . . . . . 113
  3. Local Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
  4. Transmit Program Change Numbers. . . . . . . . . . . . . . 115
  5. Multi-timbral Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
  6. Channel Mute. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
9
Welcome to the Concert Artist
1 Feature Highlights
Grand Feel II wooden-key action with Ebony & Ivory Touch key surfaces, counterweights, and ‘Let-Off’ mechanism
The CA97 and CA67 digital pianos utilise Kawai’s latest Grand Feel II wooden-key keyboard action, which draws upon over
85 years of acoustic piano craftsmanship to provide an exceptionally realistic playing experience.
Introduction
As with a grand piano, all eighty-eight black and white keys are crafted entirely from long pieces of wood, pivoting on a
central balance pin in a smooth, seesaw-like motion. The Grand Feel II keys are longer than any other digital piano keyboard
action, with the pivot point distance matching that of a Kawai grand piano. When the front of a key is pressed down, the
rear rises, throwing a hammer which plays the note. These metal hammers have been micro-engineered to optmise their
centre of gravity, and are graded in size and weight to replicate the heavier bass and lighter treble notes of an acoustic grand
piano. The forward and backward movements of each hammer are precisely measured using triple-sensor technology,
providing faster key repetition, improved responsiveness, and enhanced playing realism.
In addition to grade-weighted hammers, the Grand Feel II action also features counterweights placed within each key. As
with an acoustic piano, these finely balanced weights help to lighten the touch of the keyboard during pianissimo passages,
while adding a feel of greater substance when playing with force. The Grand Feel II keyboard action even reproduces the
subtle let-off sensation felt when playing the keys of a grand piano very softly, satisfying the expectations of even the most
discerning pianists.
Finally, the Grand Feel II keyboard action features Kawai’s Ebony & Ivory Touch key surfaces. These finely textured materials
gently absorb moisture to assist playing control, and possess a natural, matte finish that is smooth, but not slippery.
Shigeru Kawai SK-EX, SK-5, and Kawai EX instruments reproduced with Harmonic Imaging sound technology
The CA97 & CA67 digital pianos capture the magnificent tone of Kawai’s flagship Shigeru Kawai SK-EX full concert, and Shigeru
Kawai SK-5 medium-sized grand pianos. Widely regarded as the ‘premier pianos of Japan’, Shigeru Kawai instruments grace
the stages of concert halls and musical institutions throughout the world, and are prized for their exceptional tonal clarity.
In addition, the CA97 & CA67 also feature the distinctive sound of Kawai’s highly acclaimed EX concert grand piano, which
has frequently been selected by professional pianists in such prestigious events as the Chopin, Tchaikovsky, and Rubinstein
international piano competitions, among others.
All three instruments have been carefully recorded, meticulously analysed, and faithfully reproduced with full 88-key
sampling using Harmonic Imaging™ sound technology. This unique process accurately recreates the broad dynamic range
of the original grand pianos, affording pianists an extraordinary level of expressiveness ranging from the softest pianissimo
to the strongest, boldest fortissimo.
Strong selection of additional instrument sounds
Supplementing the realistic acoustic piano voices, the CA97 & CA67 digital pianos also feature an excellent selection of
additional instrument sounds, ranging from electric pianos and drawbar and church organs, to strings, human choirs, and
even atmospheric synth-style pads, inviting musicians to add greater variety to their performances.
Furthermore, the Dual playing mode also allows two different sounds, such as grand piano and strings, to be layered
together, while the Split and Four Hands modes divide the keyboard into two independent sections. The volume balances
for each playing mode can also be adjusted quickly and easily using the real-time panel controls.
Virtual Technician adjustments to personalise the instrument’s character
The CA97 & CA67 digital pianos’ Virtual Technician feature allows various characteristics of the selected acoustic piano,
electric piano, or harpsichord sound to be shaped at the touch of a button, with settings to adjust voicing and regulation,
string, damper, and cabinet resonances, and subtle hammer, damper, and key release noises. It is even possible to adjust the
precise tuning and volume of individual notes, before storing one’s personalised instrument configuration to memory.
USB to Device functionality, with MP3/WAV file recording and playback
The CA97 & CA67 digital pianos are equipped with USB connectors that not only allow these instruments to be connected
to a computer for MIDI use, but also to load and save data to USB memory devices directly. This ‘USB to Device’ feature
allows instrument settings or recorded songs stored in internal memory to be saved to USB for posterity, or standard MIDI
files (SMF) downloaded from the internet to be conveniently played back without additional hardware.
10
USB memory devices can also be used to play back MP3 or WAV audio files, allowing musicians to learn the chords or
melody for a new piece, or to simply play along with their favourite songs. It is even possible to save performances as MP3
or WAV files for emailing to friends and family, listening to on the move, or for further editing using an audio workstation.
Wide range of connectivity options
The CA97 & CA67 digital pianos features a variety of connectivity options, with Line-level output jacks that allow the
instrument to be enjoyed in larger settings such as churches and schools. Standard MIDI and ‘USB to Host’ connectors
ensure flexibility when using computers and other electronic instruments, while the stereo Line-in connector provides a
convenient method of mixing in audio from a laptop, tablet, or other digital device.
Introduction
2 Owner’s Manual Conventions
This owner’s manual utilises a number of illustrative conventions in order to explain the CA97/CA67 digital piano’s
various functions. The examples below provide an overview of the button LED indicator states and press types,
and the appearance of difference kinds of text.
Button LED indicator states
LED indicator off:
Sound/Function is not selected.
LED indicator on:
Sound/Function is selected.
LED indicator flashing:
Sound/Function is selected in a
temporary state.
Button press types
×4
×2
Normal press:
Select a sound or function.
Press multiple times:
Cycle through sounds or settings.
ld
ho
ld
ho
Press and hold:
Select a function’s settings, or
store registration memories etc.
Press twice:
Select a sound or function.
Press and hold, then press X:
Combine two sounds.
Text appearance
Normal instruction and explanation text
is written in regular type at 9 pt. size.
Captions explaining the LCD display
or button functions, are written in
bold type at 8.5 pt. size.
* Notes about functions are marked with an
asterisk and written in 8 pt. size.
Reminders about previous operations are
written in italic type at 9 pt. size.
Example operations are written in italic type
at 8 pt. size, and enclosed within a grey box.
11
Part Names and Functions
c
Introduction
a
d
e
f
g
h
i
b
j
k
l
m
n
12
o
p
q
a POWER button
i PLAY/STOP button
This switch is used to turn the instrument on/off. Be sure to turn
off the instrument after playing.
This button is used to start/stop the playback of demonstration
songs, Piano Music pieces, and Lesson and Finger Exercises, and
to start/stop the recording and playback of recorder songs, and
MP3/WAV audio files.
i REC button
b MASTER VOLUME slider
This button is used to record performances to internal memory
or a USB memory device as MP3/WAV audio files.
This slider controls the master volume level of the instrument’s
built-in speakers or headphones, if connected.
j SOUND buttons
* The MASTER VOLUME slider will not affect the volume level of the LINE
OUT connectors.
c LCD display
The LCD display provides useful information such as the
currently selected sound name, settings values, and the status
of other functions when active. An example of the main play
screen is shown below.
Headphones status
Transpose
status
USB device
status
Selected
sound
Music menu
Virtual Technician
Function/Settings menu
* A protective plastic film is attached to the display during production.
Please remove this film before attempting to play the instrument.
d
FUNCTION button
These buttons are used to select one of three functions/options
shown at the bottom of the LCD display.
Introduction
* The CA97/CA67 digital piano features a power saving mode that
can turn off the instrument automatically after a specified period of
inactivity. For more information, please refer to the ‘Auto Power Off’
setting on page 79.
These buttons are used to select the sound(s) that will be heard
when playing the keyboard of the CA97/CA67 digital piano.
Multiple sounds are assigned to each category button, and can
be selected by pressing the same button repeatedly.
These buttons are also used to select Registration memories.
k REGISTRATION button
This button is used to store and recall one of the sixteen different
registration memories. Each registration can store sound, reverb
and effects settings, as well as various other panel options.
l USB to DEVICE port
This port is used to connect a FAT or FAT32 formatted USB
memory device to the instrument in order to load/save recorded
song data, registration memories, and MP3/WAV/SMF files etc.
m PHONES jacks
These jacks are used to connect stereo headphones to the
CA97/CA67 digital piano. 1/4” and 1/8” connectors are provided
for convenience, and both can be used simultaneously, allowing
two pairs of headphones to be connected at the same time.
n LINE IN STEREO jack
This jack is used to connect the 1/8” stereo output from smart
phones, tablets, computers, or other electronic audio eqipment
to the CA97/CA67 digital piano’s amplifier and speakers.
The input level can be adjusted by using the LEVEL knob.
o LINE OUT jacks
e ARROW buttons
These buttons are used to navigate around the various menus
and screens, adjust values, and answer on-screen prompts.
f EFFECTS button
These jacks are used to connect the stereo output (Left/Right
1/4” phone plug) of the CA97/CA67 digital piano to external
amplifiers, mixers, recording devices, and similar equipment.
The output level can be adjusted by using the LEVEL knob.
p USB to HOST port
This button is used to turn effects for the selected sound on/off,
to select the different effect types, and to adjust their settings.
This port is use to connect the CA97/CA67 digital piano to a
computer using a USB ‘B to A’ type cable in order to send and
receive MIDI data.
g REVERB button
q MIDI IN / OUT jacks
This button is used to turn reverb for the selected sound on/off,
to select the different reverb types, and to adjust their settings.
h METRONOME button
This button is used to turn the metronome function on/off, and
also to adjust the tempo, time signature (or beat), and volume
settings.
These jacks are used to connect the CA97/CA67 digital piano
to external MIDI devices such as other musical instruments or a
computer in order to send and receive MIDI data.
* For more information about the instrument’s connectors and jacks,
please refer to ‘Connecting to Other Devices’ on page 136.
13
Setting Up the Piano
1. Connecting the power cable to the instrument
CA67
Connect the included power cable to the ‘AC IN’ inlet located on
the back side of instrument in the bottom left corner.
Connect the included power cable to the ‘AC IN’ inlet located on
the right hand side, towards the back of the instrument.
2. Connecting the power cable to an outlet
3. Turning on the power
Connect the instrument’s power cable to an AC outlet.
Press the POWER SWITCH located on the right hand side of the
front panel.
Introduction
CA97
Power lamp
Adjusting the pedal support bolt
A pedal support bolt is attached at the base of the pedal board
to aid stability when the pedals are pushed. Turn the bolt anticlockwise until it makes contact with the floor and supports the
pedals firmly.
The instrument will turn on, and the words ‘SK ConcertGrand’ will
be shown in the LCD display, indicating that the SK Concert Grand
sound is selected, and the instrument is ready to be played.
* The CA97/CA67 digital piano features a power saving mode that
can turn off the instrument automatically after a specified period of
inactivity. For more information, please refer to the ‘Auto Power Off’
setting on page 79.
14
Adjusting the Volume / Using Headphones
Adjusting the volume
The MASTER VOLUME slider controls the volume level of the
instrument’s speakers, or headphones if connected.
Move the slider up to increase the volume, and down to decrease
the volume.
* The MASTER VOLUME slider will not affect the volume level of the LINE
OUT connectors.
Increase
volume
Introduction
Use this slider to set the volume to a comfortable listening level
– the middle is often a good starting point.
Decrease
volume
* The LINE OUT level can be adjusted by using the LEVEL knob. Please
refer to page 137 for more information.
* The maximum volume level of the speakers can be reduced by
using the ‘Speaker Volume’ setting. Please refer to page 69 for more
information.
Using headphones
Use the jacks located beneath the keyboard on the left hand
side, to connect stereo headphones to the CA97/CA67 digital
piano. 1/4” and 1/8” connectors are provided for convenience.
Two pairs of headphones can be connected and used
simultaneously.
When a pair of headphones is connected, sound will not be
produced by the speakers. In addition, the PHONES indicator in
the LCD display will be highlighted.
Headphones connected
* The maximum volume level of the headphones output and other
headphone characteristics can be adjusted by using the settings
in the ‘Phones Settings’ menu. Please refer to page 106 for more
information.
Attaching the headphone hook (optional)
A headphone hook is included with the CA97/CA67 digital piano
and can be used to hang headphones when not in use.
If desired, attach the headphone hook to the underside of the
keyboard as shown in the illustration opposite..
* For more information, please refer to the ‘Assembly Instructions’ on
page 132.
15
sectionthe Pedals
Using
As with a grand piano, the CA97/CA67 digital piano features three pedals: sustain, sostenuto, and soft.
Sustain pedal (right pedal)
Depressing this pedal sustains the sound after one’s hands have
been lifted from the keyboard – greatly enriching the piano
sound, while also assisting smooth ‘legato’ passages.
The sustain pedal is capable of responding to half pedaling.
Soft pedal
Sostenuto pedal
Playing the Piano
Sustain pedal
Soft pedal (left pedal)
Sostenuto pedal (centre pedal)
Depressing this pedal softens the sound, reducing its volume.
Depressing this pedal after playing the keyboard and before
releasing the keys, sustains the sound of only those notes that
have been played. Any keys that are subsequently played after
the sostenuto pedal is depressed will not be sustained.
When the rotary speaker effect is selected, the soft pedal is also
used to alternate the speed of the rotary simulation between
‘Slow’ and ‘Fast’ effect modes.
Pedal support bolt
A pedal support bolt is attached at the base of the pedal board
to aid stability when the pedals are pushed.
Turn the bolt anti-clockwise until it makes contact with the floor
and supports the pedals firmly. If the pedal support bolt does
not make contact with the floor, the pedal board may become
damaged.
Pedal support bolt
When moving the instrument, always adjust or remove the pedal
support bolt, then readjust when the instrument is in its new position.
Caring for the pedals
If the surface of the pedals becomes dirty, clean the pedals using a dry dish-washing sponge.
Do not attempt to clean the pedals using rust-removing solvents, abrasives or files.
Grand Feel Pedal System
The CA97/C65 digital piano features the Grand Feel Pedal System, which replicates the sustain, soft, and sostenuto pedal weighting
of Kawai’s EX Concert Grand piano. It is also possible to adjust the sensitivity of the sustain/damper pedal, and the effectiveness of
the soft pedal using the ‘Half-Pedal Adjust’ and ‘Soft Pedal Depth’ settings.
* For more information, please refer to page 104.
16
section Sounds
Selecting
The CA97/CA67 digital piano features a wide selection of realistic instrument sounds suitable for various musical
styles. Sounds are arranged into eight categories, with several sounds assigned to each category button. For a
complete listing of available instrument sounds, please refer to page 141 of this owner’s manual.
By default, the ‘SK Concert Grand’ sound will be selected automatically when the instrument is turned on.
Selecting a sound
Press the desired SOUND button.
The LED indicator for the button will turn on to indicate that this
category has been selected, and the name of the sound will be
shown in the LCD display.
Playing the Piano
LED indicator on:
Sound category is selected.
Example: To select the E.PIANO category, press
the E.PIANO button.
Changing the sound
Several sounds are assigned to each category button.
Press the selected category button repeatedly to cycle through
the different sound variations.
×3
Example: To select the ‘SK-5 Grand Piano’ sound,
press the PIANO 1 button three times.
The  or  buttons can also be used to select sounds and cycle
through the different sound variations.
17
Dual Mode
The Dual Mode function allows two sounds to be layered together, creating a more complex sound.
For example, a piano sound layered with strings, or a church organ combined with a choir, etc.
1. Entering Dual mode
Press and hold a SOUND button to select the main sound, then
press another SOUND button to select the layered sound.
Playing the Piano
Main
sound
ld
ho
The LED indicators for both SOUND buttons will turn on to
indicate that Dual Mode is in use, and the respective sound
names will be shown in the LCD display.
Layered
sound
2a. Changing the main/layered sounds: Method 1
To select a different variation for the layered sound:
Press and hold the main SOUND button, then press the layered
SOUND button repeatedly to cycle through the different sound
variations.
×2
ld
ho
Example: To change the layered ‘Slow Strings’ sound to
the ‘Warm Strings’ sound, press and hold the PIANO 1
button, then press the STRINGS button twice.
To select a different variation for the main sound:
Press and hold the layered SOUND button, then press the main
SOUND button repeatedly to cycle through the different sound
variations.
×3
ld
ho
Example: To change the main ‘SK Concert Grand’ sound
to the ‘Jazz Clean’ sound, press and hold the STRINGS
button, then press the PIANO 1 button three times.
2b. Changing the main/layered sounds: Method 2
It is also possible to change the main/layered sound without
pressing and holding buttons.
 buttons:
Change sound variation.
Press the  or  buttons to move the selection cursor over the
main sound or layered sound.
Press the  or  buttons to cycle through the different sound
variations.
18
 buttons:
Move selection cursor.
Dual Mode settings
The Dual Mode settings menu allows characteristics of the combined sound to be adjusted.
Dual Mode settings
Dual Mode setting
Description
Default setting
Balance
Adjust the volume balance between the main and layered sounds.
9-9
Layer Octave Shift
Raise/lower the pitch of the layered sound in octave steps.
0
Dynamics
Adjust the dynamic sensitivity of the layered sound relative to the main sound.
10
Entering the Dual Mode settings menu
Press the
Playing the Piano
While the Dual Mode screen is shown in the LCD display:
FUNCTION button (EDIT).
The Dual Mode settings menu will be shown in the LCD display.
* Preferred Dual Mode settings can be stored to a Registration memory
for convenient recall. Please refer to page 77 for more information.
Adjusting Dual Mode settings
After entering the Dual Mode settings menu:
Press the  or  buttons to move the selection cursor over the
desired setting.
 buttons:
Adjust selected setting.
Press the  or  buttons to adjust the selected setting.
* To reset the current setting to the default value, press the  and 
buttons simultaneously.
 buttons:
Move selection cursor.
Cycling between Dual, Split, and Four Hands modes
When Dual Mode is selected, press the
FUNCTION button to cycle between Split, Four Hands, and Dual modes.
Exiting Dual, Split, and Four Hands modes
Press the
FUNCTION button (EXIT) to exit Dual, Split, and Four Hands modes.
19
Split Mode
The Split Mode function divides the keyboard into two sections, allowing each section to be played with a different
sound. For example, a bass sound in the lower section, and a piano sound in the upper section.
1. Entering Split mode
After entering Dual Mode (page 18):
Press the
FUNCTION button (SPLIT).
The Split Mode screen will be shown in the LCD display.
LED indicator on:
Upper section sound.
* The default split point is set between keys B3 and C4.
Playing the Piano
The upper section and lower section sound names will be
shown in the LCD display. The LED indicator for the upper
section sound button will turn on, and the LED indicator for the
lower section sound button will start to flash.
Upper
section
sound
Lower
section
sound
* By default, the lower section will be set to the ‘Wood Bass’ sound.
LED indicator flashing:
Lower section sound.
2a. Changing the upper/lower section sounds: Method 1
To select a different sound for the upper section:
To select a different sound for the lower section:
Press the desired SOUND button.
Press and hold the FUNCTION button (4HAND), then press the
desired SOUND button.
×2
* Preferred Split Mode upper/lower section sound combinations can be
stored to a Registration memory for convenient recall. Please refer to
page 77 for more information.
×3
ld
ho
Example: To select the ‘Blues Organ' sound for
the upper section, press the ORGAN button twice.
Example: To select the 'W. Bass & Ride' sound for the
lower section, press and hold the 1 FUNCTION button,
then press the BASS & GUITAR button three times.
2b. Changing the upper/lower section sounds: Method 2
It is also possible to change the upper/lower section sound without
pressing and holding buttons.
 buttons:
Change sound variation.
Press the  or  buttons to move the selection cursor over the
upper section or lower section sound.
Press the  or  buttons to cycle through the different sound
variations.
 buttons:
Move selection cursor.
20
3. Changing the split point
Press and hold the FUNCTION button (4HAND), then press the
desired split key on the keyboard.
The name of the pressed key will briefly be shown in the LCD
display, and will become the new split point.
ho
ld
Lower section
Upper section
New split point
Playing the Piano
Split Mode settings
The Split Mode settings menu allows characteristics of the Split Mode sound and operation to be adjusted.
Split Mode settings
Split Mode setting
Description
Default setting
Balance
Adjust the volume balance between the upper and lower sections.
9-9
Lower Octave Shift
Raise/lower the pitch of the lower section sound in octave steps.
0
Lower Pedal
Enable/disable the sustain pedal for the lower section sound.
Off
Entering the Split Mode settings menu
While the Split Mode screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
The Split Mode settings menu will be shown in the LCD display.
* Preferred Split Mode settings can be stored to a Registration memory
for convenient recall. Please refer to page 77 for more information.
Adjusting Split Mode settings
After entering the Split Mode settings menu:
Press the  or  buttons to move the selection cursor over the
desired setting.
 buttons:
Adjust selected setting.
Press the  or  buttons to adjust the selected setting.
* To reset the current setting to the default value, press the  and 
buttons simultaneously.
 buttons:
Move selection cursor.
21
Four Hands Mode
The Four Hands Mode function divides the keyboard into two sections in a similar way to that of the Split Mode
function. However, with Four Hands Mode enabled, the octave/pitch of each section is automatically adjusted to
create two separate 44-key instruments with the same playing range. Furthermore, the sustain (right) pedal and
soft (left) pedal act as separate sustain pedals for the respective upper and lower sections, allowing two people to
perform piano duets using a single instrument.
1. Entering Four Hands mode
After entering Dual Mode (page 18):
Press the FUNCTION button (SPLIT) once to enter Split Mode,
then press the
FUNCTION button (4HAND) again to select
Four Hands Mode.
Playing the Piano
* The default four hands mode split point is set between keys E4 and F4.
The Four Hands Mode screen and right/left section sound
names will be shown in the LCD display.
Right
section
sound
Left
section
sound
* By default, the right and left sections will both be set to the ‘SK
Concert Grand’ sound.
2a. Changing the right/left section sounds: Method 1
To select a different sound for the right section:
To select a different sound for the left section:
Press the desired SOUND button.
Press and hold the FUNCTION button (DUAL), then press the
desired SOUND button.
ld
ho
Example: To select the 'Classic E.P.' sound for the
right section, press the E.PIANO button.
* Preferred Four Hands Mode right/left section sound combinations
can be stored to a Registration memory for convenient recall. Please
refer to page 77 for more information.
Example: To select the 'Pop Grand' sound for the
left section, press and hold the 1 FUNCTION button,
then press the PIANO2 button.
2b. Changing the right/left section sounds: Method 2
It is also possible to change the right/left section sound without
pressing and holding buttons.
 buttons:
Change sound variation.
Press the  or  buttons to move the selection cursor over the
right section or left section sound.
Press the  or  buttons to cycle through the different sound
variations.
22
 buttons:
Move selection cursor.
3. Changing the Four Hands mode split point
Press and hold the FUNCTION button (DUAL), then press the
desired split key on the keyboard.
The name of the pressed key will briefly be shown in the LCD
display, and will become the new split point.
ho
ld
Left section
Right section
New split point
Playing the Piano
Four Hands Mode settings
The Four Hands Mode settings menu allows characteristics of the Four Hands Mode sound to be adjusted.
Four Hands Mode settings
Four Hands Mode setting
Description
Default setting
Balance
Adjust the volume balance between the right and left sections.
9-9
Right Octave Shift
Raise/lower the pitch of the right section sound in octave steps.
–2
Left Octave Shift
Raise/lower the pitch of the left section sound in octave steps.
+2
Entering the Four Hands Mode settings menu
While the Four Hands Mode screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
The Four Hands Mode settings menu will be shown in the LCD
display.
* Changes made to the Four Hands Mode settings will not affect the
Split Mode settings, and vice versa.
* Preferred Four Hands Mode settings can be stored to a Registration
memory for convenient recall. Please refer to page 77 for more
information.
Adjusting Four Hands Mode settings
After entering the Four Hands Mode settings menu:
Press the  or  buttons to move the selection cursor over the
desired setting.
 buttons:
Adjust selected setting.
Press the  or  buttons to adjust the selected setting.
* To reset the current setting to the default value, press the  and 
buttons simultaneously.
 buttons:
Move selection cursor.
23
Reverb
Reverb adds reverberation to the sound, simulating the acoustic environment of a recital room, stage, or concert
hall. Some sound types, such as acoustic piano, enable reverb automatically in order to improve acoustic realism.
The CA97/CA67 digital piano features six different reverb types.
Playing the Piano
Reverb types
Reverb type
Description
Room
Simulates the ambiance of a small rehearsal room.
Lounge
Simulates the ambience of piano lounge.
Small Hall
Simulates the ambiance of a small hall.
Concert Hall
Simulates the ambiance of a concert hall or theater.
Live Hall
Simulates the ambiance of a live hall or stage.
Cathedral
Simulates the ambiance of a large cathedral.
1. Turning Reverb on/off
Press the REVERB button to turn reverb on/off.
The LED indicator for the REVERB button will turn on to indicate
when reverb is in use, and the current status will briefly be
shown in the LCD display.
Reverb
status
Reverb
type
Reverb settings
The Reverb settings menu allows the type and characteristics of the reverb to be adjusted.
Reverb settings
24
Reverb setting
Description
Range
Type
Changes the type of environment.
–
Depth
Adjusts the depth of the environment (i.e. amount of reverberation to apply).
1~10
Time
Adjusts the decay length/speed of the reverberation.
1~10
Entering the Reverb settings menu
Press and hold the REVERB button.
The Reverb settings menu will be shown in the LCD display.
ld
ho
Adjusting Reverb settings
Press the  or  buttons to move the selection cursor over the
desired setting.
 buttons:
Adjust selected setting.
Playing the Piano
After entering the Reverb settings menu:
Press the  or  buttons to adjust the selected setting.
* To reset the current setting to the default value, press the  and 
buttons simultaneously.
 buttons:
Move selection cursor.
Exiting the Reverb settings menu
Press the
menu.
FUNCTION button (EXIT) to exit the Reverb settings
* Reverb settings are independent for each sound variation.
* Any changes made to the reverb type, settings, or on/off status will
remain until the power is turned off.
* Preferred reverb settings can be stored to a Registration memory for
convenient recall. Please refer to page 77 for more information.
25
Effects
In addition to reverb, various other effects can be applied to the selected sound, altering the tonal character
and feeling of the instrument. As with reverb, some sound types enable certain effects automatically in order to
enhance tonal quality. The CA97/CA67 digital piano features 19 different effect types, with 2 combination effects,
and 3 additional amplified effects.
Playing the Piano
Effect types
Effect type
Description
Mono Delay
Applies an echo effect to the sound, playing through both speakers simultaneously.
Ping Delay
Applies a ‘ping pong’ echo effect to the sound, giving the impression that it is ‘bouncing’ from left to right.
Triple Delay
Similar in principle to Ping Delay, but with an additional centre echo.
Chorus
Layers a slightly detuned version of the sound over the original, thus enriching its tonal character.
Classic Chorus
Similar in principle to Chorus, but intended for vintage electric piano sounds.
Ensemble
Applies a three-phase chorus to the sound, providing additional richness.
Tremolo
Continuously varies the volume at a constant speed, adding a vibrato type effect to the sound.
Classic Tremolo
Similar in principle to Tremolo, but intended for vintage electric piano sounds.
Vibrato Tremolo
Similar in principle to Tremolo, but with an additional Vibrato effect applied.
Auto Pan
Alternates the sound output from left to right across the stereo field using a sine wave.
Classic Auto Pan
Similar in principle to Auto Pan, but intended for vintage electric piano sounds.
Phaser
Applies a cyclic phase change to the sound, giving the impression that the sound is moving.
Classic Phaser
Similar in principle to Phaser, but intended for vintage electric piano sounds.
Rotary (1~6)
Simulates the sound of a rotary speaker commonly used with vintage electronic organs.
There are three different levels of overdrive, with and without a Chorus effect.
* The soft pedal can be used to alternate the speed of the rotary simulation between ‘Slow’ and ‘Fast’ effect modes.
Combination Effects
Different combinations of the above effects, applied simultaneously.
* Combination effect types: Phaser+Chorus, Phaser+AutoPan
Amplified Effects
A selection of the above effects, with a vintage electric piano speaker effect applied.
* Amplified effect types: Tremolo+Amp, Auto Pan+Amp, Phaser+Amp
1. Turning Effects on/off
Press the EFFECTS button to turn effects on/off.
The LED indicator for the EFFECTS button will turn on to indicate
when effects are in use, and the current status will briefly be
shown in the LCD display.
Effect
type
Effect
status
Effects settings
Effect type
Effect setting
Description
Mono Delay / Ping Delay / Triple Delay
Dry / Wet
Adjust the intensity of the delay.
Time
Adjust the interval of time between each delay.
Dry / Wet
Adjust the intensity of the chorus.
Speed
Adjust the speed of the chorus.
Chorus / Ensemble
26
Effect type
Effect setting
Description
Classic Chorus
Mono / Stereo
Toggle between a Mono or Stereo effect.
Speed
Adjust the speed of the chorus.
Dry / Wet
Adjust the intensity of the tremolo.
Speed
Adjust the speed of the tremolo.
Dry / Wet
Adjust the intensity of the pan.
Speed
Adjust the speed of the pan.
Dry / Wet
Adjust the intensity of the phaser.
Speed
Adjust the speed of the phaser.
Accel. Speed
Adjust the acceleration speed between slow and fast modes.
Rotary Speed
Adjust the speed of the rotary speaker.
Dry / Wet
Adjust the intensity of the effects.
Speed
Adjust the speed of the effects.
Tremolo / Classic Tremolo / Vibrato Tremolo
Auto Pan / Classic Auto Pan
Phaser / Classic Phaser
Rotary
Combination Effects / Amplified Effects
Playing the Piano
Effects settings (cont.)
Entering the Effects settings menu
Press and hold the EFFECTS button.
The Effects settings menu will be shown in the LCD display.
ld
ho
Adjusting Effects settings
After entering the Effects settings menu:
Press the  or  buttons to move the selection cursor over the
desired setting.
 buttons:
Adjust selected setting.
Press the  or  buttons to adjust the selected setting.
* To reset the current setting to the default value, press the  and 
buttons simultaneously.
 buttons:
Move selection cursor.
Exiting the Effects settings menu
Press the
menu.
FUNCTION button (EXIT) to exit the Effects settings
* Effects settings are independent for each sound variation.
* Any changes made to the effects type, settings, or on/off status will
remain until the power is turned off.
* Preferred effects settings can be stored to a Registration memory for
convenient recall. Please refer to page 77 for more information.
27
Virtual Technician
In addition to the reverb and effects functions, the overall character of the CA97/CA67 acoustic piano sounds can
also be dramatically adjusted using the instrument’s Virtual Technician feature. There are two methods of using
the Virtual Technician: Smart Mode and Advanced Mode.
1 Smart Mode
In Smart Mode, the Virtual Technician intelligently performs a collection of adjustments for the player, based on
ten preset attributes such as ‘Soft’ or ‘Strong’, ‘Brilliant’ or ‘Gloomy’. This mode is recommended for musicians that
wish to enjoy different piano characteristics, without delving into the individual parameters of Advanced Mode.
1. Entering Virtual Technician Smart Mode
Playing the Piano
While the normal playing mode screen is shown in the LCD display:
Press the
FUNCTION button (VT).
The Virtual Technician menu will be shown in the LCD display,
and Smart Mode will be selected automatically.
Press the
FUNCTION button (EDIT).
The list of Smart Mode presets will be shown in the LCD display.
* Smart Mode will be disabled by default (‘Off’ preset). When disabled,
the Advanced Mode Virtual Technician parameter settings will used.
2. Selecting the Virtual Technician preset
While the Smart Mode presets screen is shown in the LCD display:
Press the  or  buttons to select the desired Virtual Technician
Smart Mode preset.
 buttons:
Select Virtual Technician preset
* Smart Mode presets are independent for each sound variation.
The Virtual Technician adjustments will be applied to the
selected sound immediately.
28
* The selected Smart Mode preset will be used for the current sound
variation until the power is turned off. However, it is possible to store
a Smart Mode preset to a sound. For more information, please refer
to the instructions on the following page.
Showing the Virtual Technician Help screen
Press the
FUNCTION button (HELP).
A brief explanation about the currently selected Virtual
Technician preset will be shown in the LCD display.
Press the  or  buttons to scroll through the explanation if
necessary.
Playing the Piano
Press the FUNCTION button (BACK) to return to the Virtual
Technician preset selection screen.
Storing the Virtual Technician preset to the selected sound
After selecting the Smart Mode preset:
Press the
FUNCTION button (STORE).
The selected Smart Mode preset will be saved to the current
sound variation, and a confirmation message will briefly be
shown in the LCD display.
* The stored Smart Mode preset will be retained after the power is
turned off, and will be used automatically whenever the sound
variation is selected.
2 Advanced Mode
In Advanced Mode, the player is given full control over every aspect of the piano’s configuration, allowing precise
adjustments over hammer hardness, action regulation, cabinet size, and a variety of other acoustic characteristics.
This mode is recommended for musicians that enjoy fine-tuning individual details of the piano sound in order to
suit their personal preferences.
* For more information about the individual Virtual Technician parameters, please refer to page 80.
Entering Virtual Technician Advanced Mode
While the normal playing mode screen is shown in the LCD display:
Press and hold the
FUNCTION button (VT).
ld
ho
The Virtual Technician Settings menu will be shown in the LCD
display, allowing parameters to be adjusted in Advanced Mode.
* It is also possible to access Advanced Mode via the Virtual Technician
menu, or by selecting Virtual Tech. in the Function menus.
* It is also possible to make adjustments to a Smart Mode preset by
selecting it, and then entering Advanced Mode. However, any
adjustments cannot be re-stored back to the Smart Mode preset list.
29
Metronome / Drum Rhythms
The Metronome function provides a steady beat to aid practicing the piano at a consistent tempo. In addition to
regular metronome beats, the CA97/CA67 digital piano also features a variety of drum rhythms to accompany most
playing styles and musical genres.
For a complete listing of available drum rhythms, please refer to page 144 of this owner’s manual.
Turning the Metronome on/off
Press the METRONOME button.
The LED indicator for the METRONOME button will turn on to
indicate that the metronome function is in use, and a 1/4 beat
will start to count.
Playing the Piano
The current metronome tempo in beats per minute (BPM) and
beat of the bar will also be shown in the LCD display.
Tempo
Beat
Press the METRONOME button again to stop the metronome.
The LED indicator for the METRONOME button will turn off.
Metronome settings
The Metronome settings menu allows the tempo, beat, and volume of the metronome to be adjusted.
Metronome settings
Metronome setting
Description
Range
Tempo
Adjust the tempo of the metronome beat / drum rhythm in beats per minute (BPM).
10~400 bpm
Beat
Volume
Change the metronome beat (time signature) / drum rhythm.
* There are ten different time signature available: 1/4, 2/4, 3/4, 4/4, 5/4, 3/8, 6/8, 7/8, 9/8, and 12/8.
Adjusts the volume of the metronome beat / drum rhythm.
Entering the Metronome settings menu
Press and hold the METRONOME button.
The Metronome settings menu will be shown in the LCD
display.
ld
ho
30
–
1~10
Adjusting Metronome settings
After entering the Metronome settings menu:
Press the  or  buttons to move the selection cursor over the
desired setting.
 buttons:
Adjust selected setting.
Press the  or  buttons to adjust the selected setting.
* To reset the current setting to the default value, press the  and 
buttons simultaneously.
 buttons:
Move selection cursor.
Drum rhythms
Playing the Piano
As an alternative to the simple metronome count, it is also possible
to select a drum pattern from one of 100 different rhythm styles.
Enter the Metronome settings menu and select the Beat setting.
Press the  or  buttons to cycle through the available beats
until reaching the ‘8 Beat 1’ drum rhythm.
Drum
rhythm
 buttons:
Select drum rhythm.
Continue to press the  or  buttons to select the desired
drum rhythm.
* For a complete listing of available drum rhythms, please refer to page
144 of this owner’s manual.
Exiting the Metronome settings menu
Press the
FUNCTION button (EXIT) to exit the Metronome
settings menu.
* Any changes made to the metronome tempo, beat, or volume
settings will remain until the power is turned off.
* Preferred metronome settings can be stored to a Registration
memory for convenient recall. Please refer to page 77 for more
information.
Recording with the metronome
It is also possible to record songs with the metronome activated. This is useful when recording parts separately, or wishing to
maintain correct timing throughout complex passages. Note that the standard metronome ‘click’ will not be heard when the song
is played back.
* For more information about the instrument’s Recorder function, please refer to page 48.
31
Registration Memories
The Registration function allows the current instrument setup (sound selections, split point, reverb and effect
settings, and various other panel options) to be stored to a memory and conveniently recalled at the touch of
a button. There are two banks (‘A’ and ‘B’) for each registration button, allowing up to 16 different registration
memories to be stored.
Registrations can also be loaded/saved to a USB memory device. Please refer to pages 122/127 for more information.
Functions and Settings stored in Registration memories
Functions
Settings
Selected sound (including primary sound for each category)
Basic Settings (Tone Control, Tuning, Damper Hold)
Dual Mode / Split Mode / Four Hands Mode (including settings)
Virtual Technician Settings
Reverb, Effects (Type, Settings)
MIDI Settings
Playing the Piano
Metronome (Beat, Tempo, Volume)
* Changes made to the Auto Power Off setting will be stored to User
Memory automatically.
1 Selecting a Registration memory
Entering Registration mode
Press the REGISTRATION button.
The LED indicator for the REGISTRATION button will turn on to
indicate that the registration function is in use.
Selecting a Registration memory
When the registration function is in use:
Press the FUNCTION button to toggle between registration
memory bank ‘A’ and ‘B’.
Press a SOUND button to select the desired registration memory.
The name of the selected registration memory will be shown in
the LCD display.
Registration
name
Select
Bank A/B
Exiting Registration mode
Press the REGISTRATION button.
The LED indicator for the REGISTRATION button will turn off,
and the button panel will return to normal operation.
32
Example: To select registration memory B-3 (when
bank ‘A’ is selected), press the FUNCTION button,
then press the E.PIANO (memory 3) button.
2 Storing a Registration memory
1. Entering Registration Store mode
While the normal playing mode screen is shown in the LCD display:
Press and hold the REGISTRATION button.
ld
ho
The registration memory (SOUND) buttons will start to flash.
2. Selecting the Registration memory
Playing the Piano
Press the or FUNCTION buttons to select the registration
memory bank ‘A’ and ‘B’, then press a registration memory
(SOUND) button.
The Registration name screen will be shown in the LCD display.
Example: To store the current instrument setup
to memory A-2, press the FUNCTION button,
then press the PIANO 2 (memory 2) button.
3. Naming the Registration memory
Enter a name for the registration memory by pressing the
 or  buttons to cycle through the alphanumeric characters,
and the  or  buttons to move the cursor.
 buttons:
Move selection cursor.
 buttons:
Select character.
4. Storing the Registration to memory
Press the
FUNCTION button (STORE) to confirm the store
operation, or the FUNCTION button (EXIT) to cancel.
Upon storing, a beep will sound and a confirmation message
will briefly be shown in the LCD display.
STORE
EXIT
* The stored registration will remain in memory after the instrument
is turned off, or if the instrument’s power cable is disconnected from
the wall outlet.
The current instrument setup will be stored to the selected
registration memory with the specified name.
33
Registration Memories
3 Registration Edit menu
The Registration Edit menu allows the currently selected registration memory to be opened in normal playing
mode (for further adjustment, or simply to check which sounds are used etc.), or to be saved to USB memory.
Entering the Registration Edit menu
When the registration function is in use:
Press the
FUNCTION button (EDIT).
The Registration Edit menu will be shown in the LCD display.
Opening the Registration
Playing the Piano
Press the  or  buttons to select the Open Registration
function, then press the FUNCTION button (OK).
 buttons:
Move selection cursor.
The currently selected registration memory will be opened
in normal playing mode, allowing additional changes and
adjustments to be made.
Saving the current Registration memory to USB
Press the  or  buttons to select the Save Registration
function, then press the FUNCTION button (OK).
 buttons:
Move selection cursor.
The Save Regist Single function of the USB Menu will be shown
in the LCD display, with the current registration selected.
* Please refer to the Save Registration Single instructions on page
127.
Resetting all Registration memories
Press and hold the REGISTRATION and REC buttons, then turn the instrument’s power off/on.
All registrations will be reset to the factory default settings.
34
Panel Lock
The Panel Lock function allows the state of all panel buttons to be temporarily locked, preventing sounds and other
settings from being changed. This function may prove useful in teaching environments, ensuring that students are
not distracted by changing sounds etc.
1. Activating the Panel Lock
Press the  and  buttons simultaneously.
The Panel Lock screen will be shown in the LCD display, and the
instrument will stop responding to panel button presses.
Playing the Piano
* When activated, the Panel Lock will remain until the power is turned
off.
* While Panel Lock is activated, the LED indicators for all buttons will
turn off.
2. Deactivating the Panel Lock
While the Panel Lock is activated:
Press and hold the
FUNCTION button (UNLOCK).
A message will be shown in the LCD display to indicate that
the Panel Lock has been deactivated, and the instrument will
resume responding to panel button presses as normal.
35
Demo Songs
The Demo function provides an excellent introduction to the varied capabilities of CA97/CA67 digital piano. There
are over 30 different demonstration songs available, highlighting the instruments’ rich selection of high quality
sounds and its power speaker system.
For a complete listing of demonstration songs, please refer to page 140 of this owner’s manual.
Entering Demo mode
Press the
FUNCTION button (MUSIC).
The Music Menu will be shown in the LCD display. Demo mode
will be selected automatically.
Press the
FUNCTION (ENTER) or PLAY/STOP buttons.
or
Music Menu
The LED indicator for the PIANO 1 button will start to flash, and
the ‘SK Concert Grand’ demo song will start to play.
Selecting a demo song
While Demo mode is selected:
Press a SOUND button to select a sound category.
The first demo song of the sound category will start to play.
Press the  or  buttons to cycle through the demo songs in
the selected sound category, and the  or  buttons to cycle
through the different sound categories.
 buttons:
Select demo song
* When the selected song has finished, the next demo song in the
category will begin to play automatically.
Stopping the demo song and exiting Demo mode
Press the FUNCTION (BACK) or PLAY/STOP buttons while the
song demo is playing.
The LED indicator for the selected SOUND button will stop
flashing, and the song demo will stop playing.
Press the
36
FUNCTION (EXIT) button to exit the Music Menu.
 buttons:
Select sound category
Piano Music
In addition to the sound demonstration songs, the CA97/CA67 digital piano also features a selection of popular
classical piano works from the Baroque and Romantic periods. Notated scores are provided in the separate ‘Classical
Piano Collection’ book*, assisting the musical appreciation and study of each piece.
* Depending on market area.
For a complete listing of Piano Music pieces, please refer to the separate ‘Internal Song Lists’ booklet.
Entering Piano Music mode
Press the FUNCTION button (MUSIC), then press the  or 
buttons to select Piano Music mode.
Press the
FUNCTION (ENTER) or PLAY/STOP buttons.
The LED indicator for the PIANO 1 button will start to flash, and
the piece ‘Tambourin’ by Rameau will start to play.
Music Menu
Selecting a piano music piece
While Piano Music mode is selected:
Press the  or  buttons to cycle through the different piano
music pieces.
The title and composer of the selected piece will be shown in
the LCD display.
Title
Composer
* The balance of the left hand and right hand parts can be adjusted by
pressing the FUNCTION (EDIT) button, and adjusting the Balance
setting.
Replaying the selected piano music piece
When the selected piano music piece has finished:
Press the PLAY/STOP button to replay the piano music piece.
Stopping the piano music piece and exiting Piano Music mode
Press the FUNCTION (BACK) or PLAY/STOP buttons while the
piano music piece is playing.
The LED indicator for the PLAY/STOP button will turn off, and
the piano music piece will stop playing.
Press the
FUNCTION (EXIT) button to exit the Music Menu.
37
Lesson Function
The Lesson function allows budding pianists to practice the piano using a selection of built-in song books and
finger exercises. The left and right hand parts of each piece can be practiced separately, adjusting the tempo to
perfect difficult passages, before being recorded for self-evaluation.
Built-in lesson mode song books
Alfred Lesson Books
Classical Lesson Books
Alfred’s Premier Piano Course Lesson 1A
Burgmüller 25 (25 Etudes Faciles, Opus 100)
Alfred’s Premier Piano Course Lesson 1B
Czerny 30 (Etudes de Mécanisme, Opus 849)
Alfred’s Basic Piano Library Lesson Book Level 1A
Czerny 100 (Hundert Übungsstücke, Opus 139)
Alfred’s Basic Piano Library Lesson Book Level 1B
Beyer 106 (Vorschule im Klavierspiel, Opus 101)
Alfred’s Basic Adult Piano Course Lesson Book Level 1
J.S. Bach: Inventionen
* Lesson books sold separately – please refer to the separate ‘Internal
Song Lists’ booklet for more information.
Sonatinen Album 1
Chopin Walzer (Chopin waltzes series 1-19)
1 Selecting a lesson book/song
Music Menu
1. Entering lesson mode
Press the FUNCTION button (MUSIC), then press the  or 
buttons to select Lesson Mode.
Press the
FUNCTION button (ENTER) to enter lesson mode.
The name of the selected lesson book, song, and current bar
will be shown in the LCD display.
2. Selecting a lesson book/song
Press the  or  buttons to move the selection cursor over the
lesson book name or song title.
 buttons:
Select lesson book/song.
Press the  or  buttons to cycle through the different lesson
books and song titles.
Book name
Song title
It is also possible to select songs by pressing and holding the
FUNCTION button (EDIT), then pressing the relevant key on
the keyboard.
38
 buttons:
Move selection cursor.
* Please refer to the separate ‘Internal Song Lists’ booklet for a
complete listing of available lesson books/songs and corresponding
key numbers.
2 Listening to the selected lesson song
This page will explain how to play and stop the selected lesson song, and change the playback position.
1. Playing the lesson song
After selecting a lesson book and song:
Press the PLAY/STOP button.
The LED indicator for the PLAY/STOP button will turn on, and a
one bar count-in will be heard before the song starts to play.
* If the first bar of the song begins on an ‘up’ beat (i.e. pickup notes),
the first bar number will be shown as zero in the LCD display.
* The metronome will not continue after the count-in bar, but can be
turned on manually by pressing the METRONOME button.
2. Changing the playback position (Bar)
 buttons:
Change playback position.
Music Menu
Press the  or  buttons to move the selection cursor over the
third line of the LCD display (Bar).
Press the  or  buttons to rewind or cue the playback position
(Bar) of the current song.
Current bar
 buttons:
Move selection cursor.
It is also possible to rewind or cue the playback position without
selecting ‘Bar’, by pressing the REVERB or EFFECTS buttons.
To reset the playback position to the first bar of the song, press
the REVERB and EFFECTS buttons simultaneously.
Stopping and resuming the lesson song
While the lesson song is playing:
Press the PLAY/STOP button to stop the lesson song playback.
Press the PLAY/STOP button once again to resume playback
from the stopped position.
3. Exiting lesson mode
Press the
FUNCTION (EXIT) button to exit the Music Menu.
39
Lesson Function
3 Lesson Function settings
The Lesson Function settings menu allows the left and right-hand part volumes of the current lesson song to be
adjusted, allowing each part to be practiced separately. It is also possible to adjust the playback tempo of the
current lesson song, allowing difficult passages to be practised more conveniently.
Lesson Function settings
Lesson Function setting
Description
Default setting
Balance
Adjust the volume balance between the left and right-hand parts.
9-9
Tempo
Adjust the playback tempo of the current lesson song in beats per minute (BPM).
Song specific
Entering the Lesson Function settings menu
After selecting a lesson book and song:
Press the
FUNCTION button (EDIT).
Music Menu
The Lesson Function settings menu will be shown in the LCD
display.
Adjusting the left/right-hand part volume
Press the  or  buttons to move the selection cursor over the
Balance setting, then press the  or  buttons to adjust the
volume of the left/right-hand part volume.
 buttons:
Adjust left/right-hand volume.
Increasing the volume of the left-hand part will reduce the
volume of the right-hand part, and vice versa.
Example: To practice the right-hand part while listening
to the left-hand part, set the volume balance to 9 - 1.
*If the Beyer lesson book is selected, increasing the left-hand value will
decrease the volume of the student’s part, while increasing the righthand value will decrease the volume of the teacher’s part.
Adjusting the playback tempo of the lesson song
Press the  or  buttons to move the selection cursor over the
Tempo setting, then press the  or  buttons to adjust the
playback tempo of the lesson song.
* To reset the playback tempo of the selected lesson song to the default
value, press the  and  buttons simultaneously.
40
 buttons:
Adjust playback tempo.
4 Repeating sections of a lesson song
The ‘A-B Loop’ feature of the Lesson Function allows sections of the selected lesson song to be ‘looped’ between
two points in order to practise difficult passages continuously.
1. Playing the lesson song
After selecting a lesson book and song:
Press the PLAY/STOP button.
The LED indicator for the PLAY/STOP button will turn on, and a
one bar count-in will be heard before the song starts to play.
2. Specifying the start point (A) of the loop
Press the FUNCTION button (A-B) to specify the start point
of the loop.
Music Menu
The LED indicator for the FUNCTION button will start to flash,
indicating that the start point (A) of the loop has been set.
Point ‘A’ set
3. Specifying the end point (B) of the loop
Press the FUNCTION button (A-B) again to specify the end
point of the loop.
The LED indicator for the
FUNCTION button will turn on,
indicating that the end point of the (B) of the loop has been set.
Point ‘B’ set:
loop active
The defined ‘A-B’ section of the lesson song will repeat (loop),
allowing the passage to be practiced continuously.
* The Balance and Tempo lesson function settings can continue to be
adjusted while the A-B loop is in operation.
4. Cancelling the ‘A-B’ loop
Press the
loop.
FUNCTION button (A-B) once again to cancel the
The LED indicator for the FUNCTION button will turn off, and
the lesson song will resume normal playback.
41
Lesson Function
5 Recording a lesson song practice
The Lesson Function’s Record feature allows the left or right-hand parts of the selected lesson song to be recorded
to internal memory, and then played back for self-evaluation.
1. Starting the lesson song recording
After selecting a lesson book and song:
Press the REC button.
The LED indicators for the REC and PLAY/STOP buttons will turn
on to indicate that recording mode is in use.
* It may be desirable to adjust the Balance and Tempo lesson function
settings before starting the recording.
A one bar count-in will be heard before the lesson song starts
to play and record.
Music Menu
2. Stopping the lesson song recording
Press the PLAY/STOP button.
The LED indicators for the REC and PLAY/STOP buttons will turn
off, and the lesson song recording and playback will stop.
3. Playing back the recorded lesson song
Press the PLAY/STOP button again.
The LED indicator for the PLAY/STOP button will turn on, and a
one bar count-in will be heard before the recorded lesson song
starts to play.
* The Balance and Tempo lesson function settings can continue to be
adjusted while the recorded lesson song practise is playing.
Press the PLAY/STOP button.
The LED indicator for the PLAY/STOP button will turn off, and the
recorded lesson song will stop playing.
42
*The ‘A-B’ loop function cannot be used when recording a lesson song
practice.
* Press the REC and PLAY/STOP buttons simultaneously to erase the
recorded lesson song practice. The recorded practice will be erased
automatically when a different lesson song is selected.
6 Finger Exercises
The lesson function also includes a selection of finger exercises for practicing major and minor scales, arpeggios,
chords, cadences, and Hanon exercises, with notated scores provided in the separate ‘Finger Exercises’ book.
The CA97/CA67 digital piano can also evaluate one’s practice, analysing note accuracy, timing evenness, and note
volume consistency, before displaying results for each category. Using this function, players can objectively review
their performances, and concentrate on improving a particular area of their technique.
1. Selecting and recording a Hanon finger exercise
While Lesson mode is in use:
Select the Hanon lesson book, then select a song number.
* It may be desirable to adjust the Balance and Tempo lesson function
settings before starting the recording.
Press the REC button.
Music Menu
The LED indicators for the REC and PLAY/STOP buttons will turn on to indicate that recording mode is in use.
A one bar count-in will be heard before the finger exercise starts to play and record.
2. Evaluating the recorded finger exercise
Press the PLAY/STOP button
The LED indicators for the REC and PLAY/STOP buttons will turn
off, and the finger exercise recording and playback will stop.
The recorded practice will be evaluated for note accuracy,
timing evenness, and volume consistency, with the results
shown alternately in the LCD display.
* Press the REC and PLAY/STOP buttons simultaneously to erase the
recorded lesson song practice. The recorded practice will be erased
automatically when a different lesson song is selected.
3. Playing back the recorded finger exercise
Press the PLAY/STOP button again.
The LED indicator for the PLAY/STOP button will turn on, and
a one bar count-in will be heard before the recorded finger
exercise starts to play.
Press the PLAY/STOP button once again.
The LED indicator for the PLAY/STOP button will turn off, and the
recorded finger exercise song will stop playing.
* Press  or  buttons to cycle through the evaluation results. The
recorded finger exercise can be replayed even after cancelling the
evaluation result screen.
43
Concert Magic
The Concert Magic function allows complete beginners to enjoy playing the piano by simply selecting one of the
176 pre-programmed songs, then tapping the keyboard with a steady rhythm and tempo.
For a complete listing of available Concert Magic songs, please refer to the separate ‘Internal Song Lists’ booklet.
1 Performing a Concert Magic song
The 176 Concert Magic songs are divided into banks ‘A’ and ‘B’, with each bank containing 88 songs.
1. Entering Concert Magic mode
Press the FUNCTION button (MUSIC), then press the  or 
buttons to select Concert Magic.
Press the
FUNCTION button (ENTER) to enter Concert Magic.
Music Menu
The bank, number, and name of the selected Concert Magic
song will be shown in the LCD display.
2. Selecting a Concert Magic song
While Concert Magic mode is in use:
Press and hold the FUNCTION button (EDIT), then press the
key to which the Concert Magic song (bank ‘A’) is assigned.
* To select a song from bank ‘B’, press the same key again. Repeatedly
pressing the same key will alternate between banks ‘A’ and ‘B’.
3. Performing the selected Concert Magic song
Press a key on the keyboard.
The song will advance with every key that is pressed. Pressing
the keys gently will produce a soft sound, while pressing heavily
will produce a loud sound.
As the song advances, the  symbols shown in the LCD will be
replaced by  symbols. This is called the Note Navigator.
44
ld
ho
A Concert Magic song from bank ‘A’ will be selected, with the
song number and name shown in the LCD display.
4. Changing the Concert Magic playback sound
Press a SOUND button to change the sound used for the Concert
Magic song (melody and accompaniment parts).
It is also possible to select independent sounds for the melody and
accompaniment parts:
Press the FUNCTION button (SPLIT), to enable Concert Magic
split mode.
Press a SOUND button to change the melody sound.
Press and hold the FUNCTION button (SPLIT), then press a
SOUND button to change the accompaniment sound.
ld
ho
5. Exiting Concert Magic mode
Press the
FUNCTION button (BACK), to exit Concert Magic mode.
2 Concert Magic demo mode
Music Menu
This function allows all of the Concert Magic songs to be played back randomly or in designated categories.
Random playback
Enter Concert Magic mode and select the desired song.
Press the PLAY/STOP button.
All 176 Concert Magic songs will be played in a random order
until the PLAY/STOP button is pressed again.
Category playback
Enter Concert Magic mode and select the desired song.
Press and hold the
PLAY/STOP button.
FUNCTION button (EDIT), then press the
ld
ho
Songs in the same category as the selected song, will be played
in sequential order until the PLAY/STOP button is pressed again.
Example: If the song ‘Row, Row, Row Your Boat’ is selected, all
other songs in the ‘Children’s Songs’ category will be played.
45
Concert Magic
3 Concert Magic settings
The Concert Magic settings menu allows the playback tempo, playing mode, and volume balance to be adjusted.
Concert Magic settings
Concert Magic setting
Description
Default setting
Tempo
Adjust the playback tempo of the Concert Magic song in beats per minute (BPM).
Song specific
Mode
Change the Concert Magic playing mode (see below).
Normal
Balance
Adjust the volume balance between the melody and accompaniment parts.
9-9
Entering the Concert Magic settings menu
While Concert Magic mode is in use:
Press the
FUNCTION button (EDIT).
Music Menu
The Concert Magic settings menu will be shown in the LCD
display.
Adjusting Concert Magic settings
After entering the Concert Magic settings menu:
Press the  or  buttons to move the selection cursor over the
desired setting.
 buttons:
Adjust selected setting.
Press the  or  buttons to adjust the selected setting.
* To reset the current setting to the default value, press the  and 
buttons simultaneously.
 buttons:
Move selection cursor.
Steady Beat mode
Steady Beat mode allows all Concert Magic songs to be played by simply tapping any key with a constant steady
beat, regardless of the song arrangement type.
46
4 Concert Magic song arrangement types
Concert Magic songs are divided into three different arrangement types, each requiring a different level of skill to
be performed correctly.
* The Concert Magic arrangement type is for each song is indicated in the ‘Internal Song Lists’ booklet as ‘EB’, ‘MP’, or ‘SK’.
Easy Beat
EB
These are the easiest songs to play. To perform them, simply tap out a constant steady beat on any key on the keyboard.
The following example shows the notated score for ‘Für Elise’, indicating that a constant, steady rhythm should be maintained
throughout the song. This is the distinguishing characteristic of an Easy Beat song.
Key on:
X X
X X X X X X
X X X X X X
X X X X
X X
Melody Play
Music Menu
MP
These songs are also relatively easy to play, especially if they are familiar to the player. To perform them, tap out the rhythm of the
melody on any key of the keyboard. Singing along as the rhythm is tapped can be helpful.
The following example shows the notated score for ‘Twinkle, Twinkle, Little Star’.
* When performing fast Concert Magic songs, it may be easier to tap different keys with two alternating fingers in order to play at a greater speed.
Key on: X
X
X
X
X
X
X
X
X
X
X
X
X
X
SK
Skillful
These songs range in difficulty from moderately difficult to difficult. To perform them, tap out the rhythm of both the melody and the
accompaniment notes on any key of the keyboard. The Note Navigator will be very helpful when playing the Skillful type songs.
The following example shows the notated score for ‘Waltz of the Flowers’.
Key on
X
X
X
X
X
X
X X
X
X
X
X
X
47
Song Recorder (Internal Memory)
The CA97/CA67 digital piano allows up to 10 different songs to be recorded, stored in internal memory, and played
back at the touch of a button. Each song consists of two separate tracks – referred to as ‘parts’ – that can be recorded
and played back independently. This allows the left-hand part of a song to be recorded first on one track, and the
right-hand part to be recorded later on the other track.
1 Recording a song
1. Entering song recorder mode
Press the REC button.
The LED indicator for the REC button will start to flash, and the
Internal Recorder record screen will appear with the currently
selected song and part number shown in the LCD display.
* If a USB memory device is connected, press the
(INT) to select the internal song recorder.
FUNCTION button
2. Selecting the song/part to be recorded
Press the  or  buttons to move the selection cursor over the
song memory or part.
 buttons:
Select song memory/part.
Press the  or  buttons to change the selected song memory
or part to be recorded.
Recorder
If a part has already been recorded, a * symbol will be shown.
 buttons:
Move selection cursor.
Part has been recorded
When recording part 1 and part 2 separately, select the song and part number
carefully in order to prevent accidentally overwriting a previously recorded part.
3. Starting the song recorder
Press a key on the keyboard, or the PLAY/STOP button.
The LED indicators for the REC and PLAY/STOP buttons will turn
on, and recording will start.
or
The current bar and beat will also be shown in the LCD display.
Recording
Metronome
tempo/beat
(if enabled)
48
* Pressing the PLAY/STOP button allows a rest period or empty bar to be
inserted at the beginning of the song.
* Press the METRONOME button before or during the recording to
turn on the metronome. The metronome ‘click’ sound will not be
recorded.
4. Stopping the song recorder
Press the PLAY/STOP button.
The LED indicators for the PLAY/STOP and REC buttons will turn
off, the recorder will stop, and the part/song will be stored in
internal memory.
After a few seconds, the Internal Recorder play screen will be
shown in the LCD display, indicating that the song is ready for
playback.
Stopped
Part
Recorded
* The maximum recording capacity is approximately 90,000 notes, with
button and pedal presses also counted as one note.
* If the maximum recording capacity is reached during recording, the
recorder will stop automatically.
* Recorder songs will remain in memory after the power is turned off.
To play back the recorded song, please refer to the ‘Playing a Song’
instructions on page 50.
Recording a second part
To record a second part, repeat the above instructions, selecting the part that has not been recorded to.
Recording with the metronome
It is also possible to record songs with the metronome activated. This is useful when recording parts separately, or wishing to
maintain correct timing throughout complex passages. Note that the standard metronome click will not be heard when the song
is played back.
Recorder
* For more information about the instrument’s Metronome function, please refer to page 30.
Changing panel settings while recording
In some cases, it may be desirable to make changes to the selected sound or style while recording a song. The tables below list the
various functions which will and will not be remembered during recording.
Panel operations remembered during recording
Panel operations NOT remembered during recording*
Changes made to the sound type. (SOUND buttons etc.)
Changes made to the reverb settings.
Switching between dual/split modes.
Changes made to the effects settings.
Changes made to the tempo.
Changes made to the volume balance in dual/split mode.
Changes made to transpose, tuning, touch, etc.
* Desired effects, reverb, and tempo settings etc. should be prepared
before recording a new song.
5. Exiting song recorder mode
Press the
FUNCTION button (EXIT), to exit the Internal
Recorder and return to normal operation.
49
Song Recorder (Internal Memory)
2 Playing a song
This function is used to playback recorder songs stored in internal memory. To playback a song/part immediately
after recording, start this process from step 2.
1. Entering song play mode
Press the PLAY/STOP button.
The LED indicator for the PLAY/STOP button will turn on, and the
Internal Recorder play screen will be shown in the LCD display.
Stopped
Part
Recorded
* If a USB memory device is connected, press the
(INT) to select the internal song recorder.
2. Selecting the song/part(s) to be played back
Press the  or  buttons to move the selection cursor over the
song memory or part.
 buttons:
Select song memory/part.
Press the  or  buttons to change the selected song memory
(1-10) or part (1, 2, or 1&2) to be played back.
If a part has already been recorded, a * symbol will be shown.
Recorder
 buttons:
Move selection cursor.
Part has been recorded
3. Starting/stopping song playback
Press the PLAY/STOP button.
The LED indicator for the PLAY/STOP buttons will turn on, and
the selected song/parts will start to play.
* The selected part can be changed during song playback.
* To adjust the playback tempo of the recorded song, press and hold
the METRONOME button, then press the  or  buttons.
Press the PLAY/STOP button again.
The LED indicator for the PLAY/STOP button will turn off and the
song will stop playing.
5. Exiting song play mode
Press the
FUNCTION button (EXIT), to exit the Internal
Recorder and return to normal operation.
50
FUNCTION button
3 Internal Recorder Edit menu
The Internal Recorder Edit menu features settings that allow the pitch of the keyboard or song to be adjusted in
semi-tone steps. This menu also includes functions to delete the song, or convert the song to an audio file.
Internal Recorder menu
Internal Recorder function
Description
Default setting
Key Transpose
Raise or lower the pitch of the keyboard in semi-tone steps.
0 (C)
Song Transpose
Raise or lower the pitch of the recorder song in semi-tone steps.
0
Erase
Erase a part of a recorder song from memory (see page 52).
–
Audio Convert
Convert a recorder song to an MP3/WAV audio file (see page 53).
–
Entering the Internal Recorder menu
While the Internal Recorder play screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
The Internal Recorder menu will be shown in the LCD display.
After entering the Internal Recorder edit menu:
Press the  or  buttons to move the selection cursor over the
desired setting.
Recorder
Adjusting the Internal Recorder settings/functions
 buttons:
Adjust selected setting.
Press the  or  buttons to adjust the selected setting.
* To reset the current setting to the default value, press the  and 
buttons simultaneously.
 buttons:
Move selection cursor.
Exiting the Internal Recorder menu
Press the
FUNCTION button (BACK), to exit the Internal
Recorder menu and return to normal operation.
51
Song Recorder (Internal Memory)
4 Erasing a part/song
This function is used to erase recorder parts that may have been recorded incorrectly or songs that are no longer
listened to. Once a part/song has been erased from memory it cannot be recovered.
1. Selecting the Erase function
After entering the Internal Recorder edit menu (see page 51):
Press the  or  buttons to move the selection cursor over the
Erase function.
 buttons:
Move selection cursor.
Press the
function.
FUNCTION button (ENTER) to select the Erase
2. Selecting the song/part to be erased
Press the  or  buttons to move the selection cursor over the
song memory or part.
 buttons:
Select song memory/part.
Press the  or  buttons to change the selected song memory
(1-10) or part (1, 2, or 1&2) to be erased.
If a part has already been recorded, a * symbol will be shown.
 buttons:
Move selection cursor.
Recorder
3. Erasing the selected song/part
Press the
and part.
FUNCTION button (OK) to Erase the selected song
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the erase operation.
Press the
FUNCTION button (YES) to confirm the erase
operation, or the FUNCTION button (NO) to cancel.
YES: Erase
Erasing all recorder songs from memory
Press and hold the PLAY/STOP and REC buttons, then turn the
instrument’s power off/on.
All recorder songs stored in memory will be erased.
ld
ho
ld
ho
52
NO: Cancel
5 Converting a song to an audio file
This function allows recorder songs stored in internal memory to be played back and saved (converted) as an audio
file to a USB device in either MP3 or WAV format.
1. Selecting the Convert to Audio function
After entering the Internal Recorder edit menu (see page 51):
Press the  or  buttons to move the selection cursor over the
Convert to Audio function.
 buttons:
Move selection cursor.
Press the FUNCTION button (ENTER) to select the Convert to
Audio function.
2. Selecting the song/part to be converted
Press the  or  buttons to move the selection cursor over the
song memory or part.
 buttons:
Select song memory/part.
Press the  or  buttons to change the selected song memory
(1-10) or part (1, 2, or 1&2) to be converted.
If a part has already been recorded, a * symbol will be shown.
FUNCTION button (OK) to continue.
 buttons:
Move selection cursor.
Recorder
Press the
3. Selecting the audio file format
Press the  or  buttons to select the desired file format for the
converted song.
 buttons:
Select audio recorder format.
It is also possible to adjust the recording gain at this stage.
* For more information about the instrument’s audio recorder gain
setting, please refer to page 54.
4. Starting the conversion
Press the PLAY/STOP button, or a key on the keyboard.
The LED indicator for the PLAY/STOP and REC buttons will turn
on, the selected song will play, and the convert to audio process
will start.
* Notes played on the keyboard will also be recorded to the audio file.
Naming and saving the converted audio file
Please follow the ‘Recording a MP3/WAV audio file’ instructions on page 55 from step 4.
53
Audio Record/Playback (USB Memory)
1 Recording a MP3/WAV audio file
The CA97/CA67 digital piano is also capable of recording performances as digital audio – saving the data to a USB
memory device in either MP3 or WAV format. This useful function allows professional quality recordings to be
produced directly on the instrument – without the need for additional sound equipment – then emailed to friends
and family, listened to away from the instrument, or edited and remixed further using an audio workstation.
In addition, the LINE IN audio will also be mixed and recorded to the MP3/WAV audio file.
Audio Recorder format specifications
Audio format
Specifications
Bitrate
MP3
44.1 kHz, 16 bit, Stereo
256 kbit/s (fixed)
WAV
44.1 kHz, 16 bit, Stereo
1,411 kbit/s (uncompressed)
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.
MP3 codec is Copyright (c) 1995-2007, SPIRIT.
1. Entering USB recorder mode
Connect a USB memory device to the USB port.
Press the REC button.
The LED indicator for the REC button will start to flash, and the
USB Recorder format screen will be shown in the LCD display.
2. Selecting the USB recorder file format
Recorder
Press the  or  buttons to select the desired USB recorder
audio file format (WAV or MP3).
 buttons:
Select audio recorder format.
* MP3 audio files require less storage space than WAV audio files.
* A 1 GB USB memory device can store over 12 hours of MP3 audio data.
Adjusting the recording volume (Gain)
Press the FUNCTION button (GAIN).
The gain adjustment screen and recording level meter will be
shown in the LCD display.
* The gain setting can be adjusted within the range of 0 dB~+15 dB.
Press the  or  buttons to adjust the recorder gain setting.
54
* To reset the gain setting to the default level, press the  and 
buttons simultaneously.
* Express caution when increasing the gain setting, as higher levels may
result in distorted recordings.
* The gain meter will also display the sound level of the LINE IN audio.
3. Starting the USB recorder
Press a key on the keyboard, or the PLAY/STOP button.
or
The LED indicators for the REC and PLAY/STOP buttons will turn
on, and recording will start.
The current recording time will also be shown in the LCD display.
Recording
Time
* Pressing the PLAY/STOP button allows a rest period or empty bar to be
inserted at the beginning of the song.
* Press the METRONOME button before or during the recording to
turn on the metronome. The metronome ‘click’ sound will not be
recorded, however drum patterns will be recorded.
4. Stopping the USB recorder, saving the file
Press the PLAY/STOP button.
The LED indicators for the PLAY/STOP and REC buttons will turn
off, and recording will stop
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the save operation.
Press the
FUNCTION button (YES) to confirm the save
operation, or the FUNCTION button (NO) to cancel.
NO: Cancel
Recorder
YES: Save
5. Naming the recorded audio file, confirming save
After confirming the save operation:
Press the  or  buttons to cycle through the alphanumeric
characters, and the  or  buttons to move the cursor.
 buttons:
Move selection cursor.
 buttons:
Select character.
Press the
FUNCTION button (OK) to confirm the save
operation, or the FUNCTION button (BACK) to cancel.
The recorded audio file will be saved with the specified name.
OK: Save
After a few seconds, the USB Recorder play screen will be
shown in the LCD display, indicating that the audio is ready for
playback.
To play back the recorded audio file, please refer to the ‘Playing an
MP3/WAV audio File’ instructions on page 56.
BACK: Cancel
* ‘MP3 Song 01’ or ‘WAV Song 01’ will be used as the default name for the
recorded audio files, with the number increasing automatically.
* The recorded audio file will be saved in the root folder of the USB
memory device. It is not possible to save the file in a different folder.
55
Audio Record/Playback (USB Memory)
2 Playing an MP3/WAV audio file
The CA97/CA67 digital piano is also capable of playing MP3 and WAV audio files stored on a USB memory device
directly through the instrument’s speaker system. This function is particularly useful when attempting to learn the
chords or melody to a new piece, or to simply play along with one’s favorite song.
Audio Player supported format specifications
Audio format
Specifications
Bitrate
MP3
32 kHz/44.1 kHz/48 kHz, Mono/Stereo
8-320 kbit/s (fixed & variable)
WAV
32 kHz/44.1 kHz/48 kHz, Mono/Stereo, 16 bit
-
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.
MP3 codec is Copyright (c) 1995-2007, SPIRIT.
Preparing the USB memory device
First, prepare a selection of MP3 or WAV audio files, copying the
data to a USB memory device.
* USB devices should be formatted to use the ‘FAT’ or ‘FAT32’ filesystems.
Please refer to page 137 for more information.
1. Entering USB playback mode
Connect a USB memory device to the USB port.
Press the PLAY/STOP button.
Recorder
The LED indicator for the the PLAY/STOP button will turn on,
and the Song Browser screen will be shown in the LCD display.
Song Browser screen
The Song Browser screen provides a listing of relevant files and
folders stored on the connected USB device.
The icon is used to represent an audio/song file.
The icon is used to represent a folder.
The icon is used to represent the current/previous folder.
An example of a typical file/folder listing screen is shown below.
Please note that the visible screen height has been extended for
the purpose of this illustration.
56
 buttons:
Move selection cursor.
FUNCTION button:
Select file/enter folder.
Current/previous folder
* Files and folders will be listed in alphabetical order, with folders shown
at the top of the screen.
Folders
* When the USB Recorder play function is selected, only MP3, WAV, and
MID files will be shown.
Files
* The LCD display is capable of showing filenames with a maximum
length of 12 characters (+3 character suffix). Filenames longer than 12
characters will be truncated automatically.
2. Selecting an audio file
Press the  or  buttons to move the selection cursor, then
press the FUNCTION button (SELECT) to select the audio file.
The USB Recorder play screen will be shown in the LCD display.
3. Playing the selected audio file
Press the PLAY/STOP button.
The selected audio file will start to play, and information about
the file will be shown in the LCD display.
Audio file,
artist/song
Playback
volume
Playing
position
* If the selected audio file contains embedded metadata (e.g. ID3 tags)
such as artist name and song title, this information will be also be
shown beside the filename.
Controlling audio file playback
While the audio file is playing:
Press the PLAY/STOP button to pause and resume playback.
 buttons:
Rewind/advance playing position.
Press the  or  buttons to rewind or advance the playing
position of the audio file.
* The playback volume can be adjusted within the range of 1~128.
Press the FUNCTION button (A-B) twice to set the start and
end points of the A-B loop.
* Pressing the A-B button for a third time will turn off the loop.
 buttons:
Adjust playback volume.
Recorder
Press the  or  buttons to adjust the playback volume of the
audio file.
* There may be a noticeable difference in volume between audio file
playback and the CA97/CA67 keyboard sound. When playing back
audio data, please adjust the volume of the audio file as desired.
USB Recorder Edit menu
The USB Recorder Edit menu allows the playback mode (Single, 1-Repeat, All-Repeat, Random) to be changed, and the pitch of the keyboard
to be transposed in semi-tone steps. Please refer to page 60 for more information.
Overdub function
The Overdub function allows the sound of the CA97/CA67 to be recorded (overdubbed) to an existing MP3 or WAV audio file.
Please refer to page 62 for more information.
4. Exiting USB playback mode
Press the
FUNCTION button (BACK) to exit USB playback
mode and return to normal operation.
57
Audio Record/Playback (USB Memory)
3 Playing a MIDI song file
The CA97/CA67 digital piano also supports the playback of Standard MIDI File (SMF) files and CA97/CA67 recorder
songs stored on a USB memory device, allowing a vast selection of widely accessible music to be heard through the
instrument’s exquisite Harmonic Imaging XL sound engine.
Song Player supported format specifications
Song format
Specifications
MID
Format 0, Format 1
KS0
Kawai Song file
Preparing the USB memory device
First, prepare a selection of MID (SMF) song files, copying the
data to a USB memory device.
* USB devices should be formatted to use the ‘FAT’ or ‘FAT32’ filesystems.
Please refer to page 137 for more information.
1. Entering USB playback mode
Connect a USB memory device to the USB port.
Press the PLAY/STOP button.
Recorder
The LED indicator for the the PLAY/STOP button will turn on,
and the Song Browser screen will be shown in the LCD display.
Song Browser screen
The Song Browser screen provides a listing of relevant files and
folders stored on the connected USB device.
The icon is used to represent an audio/song file.
The icon is used to represent a folder.
The icon is used to represent the current/previous folder.
An example of a typical file/folder listing screen is shown below.
Please note that the visible screen height has been extended for
the purpose of this illustration.
Current/previous folder
Folders
Files
58
 buttons:
Move selection cursor.
FUNCTION button:
Select file/enter folder.
* Files and folders will be listed in alphabetical order, with folders shown
at the top of the screen.
* When the USB Recorder play function is selected, only MP3, WAV, and
MID files will be shown.
* The LCD display is capable of showing filenames with a maximum
length of 12 characters (+3 character suffix). Filenames longer than 12
characters will be truncated automatically.
2. Selecting a MIDI file
Press the  or  buttons to move the selection cursor, then
press the FUNCTION button (SELECT) to select the MIDI file.
The USB Recorder play screen will be shown in the LCD display.
3. Playing the selected MIDI file
Press the PLAY/STOP button.
The selected MIDI file will start to play, and information about
the file will be shown in the LCD display.
MIDI file,
artist/song
Playback
volume
Playing
position
* The CA97/CA67 digital piano does not contain the full General MIDI/
GM2 sound bank selection. Consequently, some SMF song files may
not be reproduced entirely accurately when played through the
instrument.
Controlling MIDI file playback
While the MIDI file is playing:
Press the PLAY/STOP button to pause and resume playback.
 buttons:
Rewind/advance playing position.
Press the  or  buttons to rewind or advance the playing
position of the MIDI file.
* The playback volume can be adjusted within the range of 1~128.
 buttons:
Adjust playback volume.
Recorder
Press the  or  buttons to adjust the playback volume of the
MIDI file.
Press the FUNCTION button (A-B) twice to set the start and
end points of the A-B loop.
* Pressing the A-B button for a third time will turn off the loop.
USB Recorder Edit menu
The USB Recorder Edit menu allows the playback mode (Single, 1-Repeat, All-Repeat, Random) to be changed, the tempo of the MIDI song
to be adjusted, and the pitch of the keyboard or song to be transposed in semi-tone steps. Please refer to page 60 for more information.
Convert MIDI to Audio function
The Convert MIDI to Audio function allows MIDI files or CA97/CA67 recorder songs stored on a USB memory device to be converted to MP3/
WAV audio files. Please refer to page 61 for more information.
Exiting USB playback mode
Press the
FUNCTION button (BACK) to exit USB playback
mode and return to normal operation.
59
Audio Record/Playback (USB Memory)
4 USB Recorder Edit menu
The USB Recorder Edit menu allows the playback mode of the audio/MIDI file to be changed to one of four types.
This menu also features settings to adjust the MIDI song playback tempo, and to transpose the pitch of the keyboard
or MIDI song in semi-tone steps.
USB Recorder menu
USB Recorder function
Description
Default setting
Play Mode
Change the audio/MIDI file playback mode (see below).
Single
Tempo
Adjust the playback tempo of the MIDI song in beats per minute (BPM).
–
Key Transpose
Raise or lower the pitch of the keyboard in semi-tone steps.
0 (C)
Song Transpose
Raise or lower the pitch of the recorder/MIDI song in semi-tone steps.
0
* Tempo and Song Transpose settings will not be shown when an audio file is selected.
Play Mode settings
Play Mode setting
Description
Single
The selected audio/MIDI file will be played once.
1-Repeat
The selected audio/MIDI file will be repeated.
All-Repeat
All audio/MIDI files in the current folder will be played repeatedly.
Random
All audio/MIDI files in the current folder will be played in random order.
Entering the USB Recorder menu
Recorder
While the USB Recorder screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
The USB Recorder menu will be shown in the LCD display.
Adjusting the USB Recorder settings
After entering the USB Recorder menu:
Press the  or  buttons to move the selection cursor over the
desired setting.
 buttons:
Adjust selected setting.
Press the  or  buttons to adjust the selected setting.
* To reset the current setting to the default value, press the  and 
buttons simultaneously.
60
 buttons:
Move selection cursor.
5 Converting a MIDI song file to an MP3/WAV audio file
This function allows MIDI files or CA97/CA67 recorder songs stored on a USB memory device to be played back and
saved (converted) as an audio file (to the USB device) in either MP3 or WAV format.
1. Selecting the MIDI song to be converted
While the Song Browser Player screen is shown in the LCD display:
Press the  or  buttons to move the selection cursor over the
desired MIDI file, then press the REC button.
The LED indicator for the REC button will start to flash, and the
Convert MIDI to Audio screen will be shown in the LCD display.
2. Selecting the audio file format
With the Format setting selected, press the  or  buttons to
select the desired USB recorder audio file format (WAV or MP3).
 buttons:
Select audio recorder format.
* It is also possible to record a new song directly to the USB device (i.e.
not convert the previously selected song to an audio file) by changing
the Mode setting to ‘New Song’.
Recorder
3. Starting the conversion
Press the PLAY/STOP button, or a key on the keyboard.
The LED indicator for the PLAY/STOP and REC buttons will turn
on, the selected song will play, and the convert to audio process
will start.
* Notes played on the keyboard will also be recorded to the audio file.
When the end of the song is reached, the save confirmation
screen will be shown in the LCD display.
Naming and saving the converted audio file
Please follow the ‘Recording a MP3/WAV audio file’ instructions on page 55 from step 3.
61
Audio Record/Playback (USB Memory)
6 Overdubbing a MP3/WAV audio file
This function allows the sound of the CA97/CA67 to be recorded (overdubbed) to an existing MP3 or WAV audio file.
In addition, the CA97 digital piano also supports mixing the LINE IN audio with the overdubbed MP3/WAV file.
* This function records/overdubs to a copy of the selected file – the original audio file will not be modified.
1. Selecting the audio file to be overdubbed
While the Song Browser Player screen is shown in the LCD display:
Press the  or  buttons to move the selection cursor over the
desired MP3/WAV file, then press the REC button.
The LED indicator for the REC button will start to flash, and the
Overdubbing screen will be shown in the LCD display.
2. Selecting the audio file format
With the Format setting selected, press the  or  buttons to
select the desired USB recorder audio file format (WAV or MP3).
 buttons:
Select audio recorder format.
Recorder
* It is also possible to record a new audio file directly to the USB device
(i.e. not overdub the previously selected audio file) by changing the
Mode setting to ‘New Song’.
3. Starting the recording/overdubbing
Press the PLAY/STOP button, or a key on the keyboard.
The LED indicator for the PLAY/STOP and REC buttons will
turn on, the selected audio file will play, and the recording/
overdubbing process will start.
Notes played on the keyboard will be recorded to the audio file.
* The playback volume of the selected audio file will automatically be
set to 100, in order to prevent a distorted recording.
When the end of the MP3/WAV is reached, the save confirmation
screen will be shown in the LCD display.
Naming and saving the overdubbed audio file
Please follow the ‘Recording a MP3/WAV audio file’ instructions on page 55 from step 3.
62
Function menus
The Function menus contain a variety of options to adjust the CA97/CA67 digital piano’s operation and sound.
Settings are grouped by category, providing convenient access to relevant controls. Once adjusted, settings can
be stored to one of the instrument’s 16 registration memories, or selected as the default power-on settings with the
Startup Setting function (page 77).
Entering the Function menus
While the normal playing mode screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
The Function menus will be shown in the LCD display.
Press the  or  buttons to cycle through the different menus.
Press the
FUNCTION button (ENTER) to enter the selected
Function menu.
 buttons:
Move selection cursor.
FUNCTION button:
Select function.
Exiting the Function menus
Press the FUNCTION button (EXIT) to exit the Function menus
and return to normal operation.
Overview of Function menus
1. Basic Settings
3. Phones Settings
Key Transpose, Song Transpose, Tone Control, Speaker Volume,
SHS Mode, Phones Type, Phones Volume
Line In Level, Wall EQ*, Tuning, Damper Hold, Split, Four Hands,
LCD Contrast, Startup Setting, Factory Reset, Auto Power Off
4. MIDI Settings
2. Virtual Technician Settings
Settings
MIDI Channel, Send Program Change No., Local Control,
Transmit Program Change No., Multi-timbral Mode, Channel Mute
Touch Curve, Voicing, Damper Resonance, Damper Noise,
String Resonance, Undamped String Resonance, Cabinet Resonance,
5. USB Functions
Key-off Effect, Fallback Noise, Hammer Delay, Topboard Simulation,
Load Song, Load Registration All, Load Registration Single,
Decay Time, Minimum Touch, Stretch Tuning, Temperament,
Load Startup Setting, Save Internal Song, Save SMF Song,
Temperament Key, Key Volume, Half-Pedal Adjust, Soft Pedal Depth
Save Registration All, Save Registration Single, Save Startup Setting,
* CA97 only.
Rename File, Delete File, Format USB
63
Basic Settings
The Basic Settings menu contains settings to adjust the pitch, tuning, and general sound of the instrument.
This menu also allows favourite panel settings to be stored, or reset back to the original factory configuration.
Basic Settings
No.
Setting
Description
Default setting
1
Key Transpose
Raise or lower the pitch of the keyboard in semi-tone steps.
0 (C)
2
Song Transpose
Raise or lower the pitch of the recorder/MIDI song in semi-tone steps.
0
3
Tone Control
Change the EQ settings of the instrument’s sound.
Off
4
Speaker Volume
Change the maximum volume level of the speaker output.
Normal
5
Line In Level
Adjust the input volume of the Line In connectors.
0 dB.
6
Wall EQ*
Optimise the instrument’s speaker system based on instrument placement.
Off
7
Tuning
Raise or lower the pitch of the instrument in 0.5 Hz steps.
440.0 Hz
8
Damper Hold
Change the effect of pressing the sustain pedal on organ, string, etc. sounds.
Off
9
Split
Enable the ‘Split Mode’ function.
Off
10
Four Hands
Enable the ‘Four Hands Mode’ function.
Off
11
LCD Contrast
Adjust the contrast of the instrument’s LCD display.
5
12
Startup Setting
Store current panel settings as the default (power-on) configuration.
-
13
Factory Reset
Restore all panel settings to the original factory configuration.
-
14
Auto Power Off
Enable/disable the instrument’s Auto Power Off energy saving function.
-
* The Wall EQ setting is available on the CA97 model only. Settings page numbers shown will differ on the CA67 model.
* Default settings will be shown in the first LCD display illustration (i.e. Step 1) for each setting explanation below.
Entering the Basic Settings menu
While the normal playing mode screen is shown in the LCD display:
Press the
FUNCTION button (ENTER).
Settings
The Function menus will be shown in the LCD display.
Press the FUNCTION button (ENTER) again to enter the Basic
Settings menu.
Selecting and adjusting the desired setting
After entering the Basic Settings menu:
Press the  or  buttons to move the selection cursor over the
desired setting.
 buttons:
Adjust selected setting.
Press the  or  buttons to adjust the selected setting.
* To reset the current setting to the default value, press the  and 
buttons simultaneously.
64
 buttons:
Move selection cursor.
1 Key Transpose
The Key Transpose setting allows the pitch of the CA97/CA67 digital piano keyboard to be raised or lowered in semitone steps. This is particularly useful when accompanying instruments tuned for different keys, or when a song
learned in one key must be played in another key. When transposed, the song can be played in the original key, yet
heard in a different key.
1. Selecting the Key Transpose setting
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Key Transpose setting.
2. Adjusting the Key Transpose value
Press the  or  buttons to increase or decrease the value of
the Key Transpose setting.
* The keyboard pitch can be raised or lowered by up to 12 semi-tones.
* To reset the Key Transpose setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the Key Transpose setting will remain until the
power is turned off.
* Preferred Key Transpose settings can be stored to the Startup Setting
memory for convenient recall. Please refer to page 77 for more
information.
Current Transpose state
If the Key Transpose setting is set to a value other than 0 (C),
the TRANSPOSE indicator shown in the normal playing mode
screen will be highlighted.
Transpose
enabled
Settings
3. Exiting the Key Transpose setting
Press the FUNCTION button (BACK) to exit the Key Transpose
setting and return to the Function Menus screen.
65
Basic Settings
2 Song Transpose
The Song Transpose setting allows the pitch of MIDI files or CA97/CA67 recorder songs stored on a USB memory
device to be raised or lowered in semi-tone steps when played back.
1. Selecting the Song Transpose setting
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Song Transpose setting.
2. Adjusting the Song Transpose value
Press the  or  buttons to increase or decrease the value of
the Song Transpose setting.
* The song pitch can be raised or lowered by up to 12 semi-tones.
* To reset the Song Transpose setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the Song Transpose setting will remain until the
power is turned off.
* Preferred Song Transpose settings can be stored to the Startup
Setting memory for convenient recall. Please refer to page 77 for
more information.
3. Exiting the Song Transpose setting
Settings
Press the FUNCTION button (BACK) to exit the Song Transpose
setting and return to the Function Menus screen.
66
3 Tone Control
The Tone Control setting allows the overall sound character of the CA97/CA67 digital piano to be adjusted to provide
the best sound quality within the area that the instrument is located. There are five different preset EQ settings
available, with an additional ‘User’ setting allowing finer control over the different frequency bands.
Tone Control setting
Tone Control type
Description
Off (default)
Tone control adjustment is not applied.
Brilliance
Adjusts the overall brightness of the sound, independently of the Virtual Technician ‘Voicing’ parameter.
Loudness
Emphasises frequencies to retain the instrument’s sound character when playing at low volume levels.
Bass Boost
Emphasises low-range frequencies, creating a deeper sound.
Treble Boost
Emphasises high-range frequencies, creating a brighter sound.
Mid Cut
Reduces mid-range frequencies, creating a clearer sound.
User
Allows the low, mid, and high-range frequency bands to be adjusted separately.
1. Selecting the Tone Control setting
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Tone Control setting.
2. Changing the Tone Control type
Press the  or  buttons to cycle through the different Tone
Control types.
* To reset the Tone Control setting to the default type, press the
 and  buttons simultaneously.
* Any changes made to the Tone Control setting will remain until the
power is turned off.
Settings
* Preferred Tone Control settings can be stored to the Startup Setting
memory for convenient recall. Please refer to page 77 for more
information.
3. Exiting the Tone Control setting
Press the FUNCTION button (BACK) to exit the Tone Control
setting and return to the Function Menus screen.
Adjusting the Brilliance level
When the Brilliance tone control type is selected:
Press the FUNCTION button (EDIT), then press the  or 
buttons to increase/decrease the value of the Brilliance setting.
 buttons:
Adjust Brilliance setting.
* The Brilliance value can be adjusted within the range of –10~+10.
Press the
FUNCTION button (BACK) to exit the Brilliance
setting and return to the Tone Control setting.
67
Basic Settings
User Tone Control
The User Tone Control option allows finer control over the instrument’s sound character, allowing the volume of
four frequency bands to be adjusted individually. It is also possible to adjust the frequency range of the mid-low
and mid-high frequency bands.
User Tone Control setting
No. User Tone Control
Description
1
Low
Adjusts the volume of the low range frequency band (20~100 Hz).
2
Mid-low Frequency
Adjusts the frequency of the mid-low band (355~3150 Hz).
Mid-low dB
Adjusts the volume of the mid-low range frequency band.
Mid-high Frequency
Adjusts the frequency of the mid-high band (355~3150 Hz).
Mid-high db
Adjusts the volume of the mid-high range frequency band.
High
Adjusts the volume of the high range frequency band (5000~20000 Hz).
3
4
1. Selecting the User Tone Control setting
After selecting the Tone Control setting (page 67):
Press the  or  buttons to select the User Tone Control type,
then press the FUNCTION button (EDIT).
The User Tone Control screen will be shown in the LCD display.
2. Selecting and adjusting the User Tone Control settings
Press the  or  buttons to select the User Tone Control
setting.
Press the  or  buttons to increase or decrease the value of
the selected User Tone Control setting.
* Each User Tone Control band can be adjusted within the range of
–6 dB~+6 dB.
Settings
* To reset the User Tone Control setting to the default type, press the
 and  buttons simultaneously.
* Any changes made to the User Tone Control setting will remain until
the power is turned off.
* Preferred User Tone Control settings can be stored to the Startup
Setting memory for convenient recall. Please refer to page 77 for
more information.
3. Exiting the User Tone Control setting
Press the
FUNCTION button (BACK) to exit the User Tone
Control setting and return to the Tone Control setting.
68
4 Speaker Volume
The Speaker Volume setting allows the maximum volume level of the CA97/CA67 digital piano’s speaker output to
be reduced, providing finer adjustment control over the master volume. This setting can also function as a volume
limiter, preventing the instrument from being played too loudly in the home or classroom etc.
* This setting does not affect the headphones or Line Out volume.
Speaker Volume setting
Speaker Volume
Description
Normal (default)
The instrument’s speakers will output sound at the normal volume level.
Low
The instrument’s speakers will output sound at a reduced volume level.
1. Selecting the Speaker Volume setting
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Speaker Volume setting.
2. Changing the Speaker Volume type
Press the  or  buttons to alternate between ‘Normal’ and
‘Low’ Speaker Volume settings.
* To reset the Speaker Volume setting to the default setting, press the
 and  buttons simultaneously.
* Any changes made to the Speaker Volume setting will remain until the
power is turned off.
* Preferred Speaker Volume settings can be stored to the Startup
Setting memory for convenient recall. Please refer to page 77 for
more information.
3. Exiting the Speaker Volume setting
Settings
Press the FUNCTION button (BACK) to exit the Speaker Volume
setting and return to the Function Menus screen.
69
Basic Settings
5 Line In Level
The Line In Level setting allows the volume level of the instrument’s Line In input jacks to be adjusted digitally. This
setting may be useful when using the USB Recorder function and attempting to balance an external audio source
with the instrument’s sound.
* The Line In Level can also be adjusted by using the LEVEL knob, located on the jack panel. Please refer to page 137 for more information.
1. Selecting the Line In Level setting
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Line In Level setting.
2. Adjusting the Line In Level value
Press the  or  buttons to increase or decrease the value of
the Line In Level setting.
* The Line In Level can be adjusted within the range of –10 dB~+10 dB.
* To reset the Line In Level setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the Line In Level setting will remain until the
power is turned off.
* Preferred Line In Level settings can be stored to the Startup Setting
memory for convenient recall. Please refer to page 77 for more
information.
3. Exiting the Line In Level setting
Press the FUNCTION button (BACK) to exit the Line In Level
setting and return to the Function Menus screen.
Settings
Line In Level setting vs Line In LEVEL knob
The CA97/CA67 digital piano provides two methods of adjusting the level of the Line In audio: the Line In LEVEL knob (located beside
the Line In jacks on the jack panel), and the Line In Level setting. The LEVEL knob is used to adjust the analogue volume of the sound
entering the instrument, while the Line In Level setting adjusts the digital volume of the sound once it is ‘inside’ the instrument.
To ensure the Line In audio is of a high quality, it is recommended to set the volume of the external audio device (for example a
tablet) to a high level, then adjust the instrument’s Line In LEVEL knob to a comfortable level, without distortion. If it is necessary to
further increase or decrease the volume of the external audio, the Line In Level setting can then be used as desired.
70
6 Wall EQ (CA97 only)
The Wall EQ setting optimises the sound character of the soundboard speaker depending on whether the CA97
digital piano (back) is placed beside a wall, or in an area away from a wall.
* This setting does not affect the headphones or Line Out output.
Wall EQ setting
Wall EQ
Description
Off (default)
Optimise the speaker system for placing the CA97 digital piano in an area away from a wall.
On
Optimise the speaker for placing the CA97 digital piano beside a wall.
1. Selecting the Wall EQ setting
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Wall EQ setting.
2. Changing the Wall EQ setting
Press the  or  buttons to turn the Wall EQ setting on or off.
* To reset the Wall EQ setting to the default setting, press the  and 
buttons simultaneously.
* Any changes made to the Wall EQ setting will remain until the power
is turned off.
* Preferred Wall EQ settings can be stored to the Startup Setting memory
for convenient recall. Please refer to page 77 for more information.
Settings
3. Exiting the Wall EQ setting
Press the FUNCTION button (BACK) to exit the Wall EQ setting
and return to the Function Menus screen.
71
Basic Settings
7 Tuning
The Tuning setting allows the overall pitch of the CA97/CA67 digital piano to be raised and lowered in 0.5 Hz steps,
and may therefore prove useful when playing with other instruments.
1. Selecting the Tuning setting
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Tuning setting.
2. Adjusting the Tuning value
Press the  or  buttons to increase or decrease the value of
the Tuning setting.
* The Tuning value can be adjusted within the range of 427.0~453.0 Hz.
* To reset the Tuning setting to the default value, press the  and 
buttons simultaneously.
* Any changes made to the Tuning setting will remain until the power
is turned off.
* Preferred Tuning settings can be stored to the Startup Setting
memory for convenient recall. Please refer to page 77 for more
information.
3. Exiting the Tuning setting
Settings
Press the FUNCTION button (BACK) to exit the Tuning setting
and return to the Function Menus screen.
72
8 Damper Hold
The Damper Hold setting is used to determine whether sounds such as organ or strings should be sustained
continuously when the sustain (damper) pedal is pressed, or whether these sounds should decay, naturally.
Damper Hold setting
Damper Hold
Description
Off (default)
Organ, strings, etc. sounds will gradually decay, even while the sustain pedal is pressed.
On
Organ, strings, etc. sounds will be sustained continuously while the sustain pedal is pressed.
1. Selecting the Damper Hold setting
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Damper Hold setting.
2. Changing the Damper Hold setting
Press the  or  buttons to turn the Damper Hold setting on
or off.
* To reset the Damper Hold setting to the default setting, press the
 and  buttons simultaneously.
* Any changes made to the Damper Hold setting will remain until the
power is turned off.
* Preferred Damper Hold settings can be stored to the Startup Setting
memory for convenient recall. Please refer to page 77 for more
information.
3. Exiting the Damper Hold setting
Settings
Press the FUNCTION button (BACK) to exit the Damper Hold
setting and return to the Function Menus screen.
73
Basic Settings
9 Split
The Split setting provides an alternative method to enabling the Split Mode function, and may prove useful in
teaching environments or situations where the function should be enabled automatically every time the CA97/
CA67 digital piano is turned on.
When enabled, all Split Mode control operations are identical to those explained on page 20.
Split setting
Split
Description
Off (default)
Split Mode will be turned off by default.
On
Split Mode will be turned on by default.
1. Selecting the Split setting
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Split setting.
2. Changing the Split setting
Press the  or  buttons to turn the Split setting on or off.
* To reset the Split setting to the default setting, press the  and 
buttons simultaneously.
* Any changes made to the Split setting will remain until the power is
turned off.
* Preferred Split settings can be stored to the Startup Setting memory
for convenient recall. Please refer to page 77 for more information.
Settings
3. Exiting the Split setting
Press the FUNCTION button (BACK) to exit the Split setting
and return to the Function Menus screen.
74
10 Four Hands
The Four Hands setting provides an alternative method to enabling the Four Hands Mode function, and may prove
useful in teaching environments or situations where the function should be enabled automatically every time the
CA97/CA67 digital piano is turned on.
When enabled, all Four Hands Mode control operations are identical to those explained on page 22.
Four Hands setting
Four Hands
Description
Off (default)
Four Hands Mode will be turned off by default.
On
Four Hands Mode will be turned on by default.
1. Selecting the Four Hands setting
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Four Hands setting.
2. Changing the Four Hands setting
Press the  or  buttons to turn the Four Hands setting on or
off.
* To reset the Four Hands setting to the default setting, press the
 and  buttons simultaneously.
* Any changes made to the Four Hands setting will remain until the
power is turned off.
* Preferred Four Hands settings can be stored to the Startup Setting
memory for convenient recall. Please refer to page 77 for more
information.
Settings
3. Exiting the Four Hands setting
Press the FUNCTION button (BACK) to exit the Four Hands
setting and return to the Function Menus screen.
75
Basic Settings
11 LCD Contrast
The LCD Contrast setting is used to adjust the contrast of the LCD display. The contrast of the display becomes
sharper as the value increases.
1. Selecting the LCD Contrast setting
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the LCD Contrast setting.
2. Adjusting the LCD Contrast value
Press the  or  buttons to increase or decrease the value of
the LCD Contrast setting.
* The LCD Contrast value can be adjusted within the range of 0~10.
* To reset the LCD Contrast setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the LCD Contrast setting will remain until the
power is turned off.
* Preferred LCD Contrast settings can be stored to the Startup Setting
memory for convenient recall. Please refer to page 77 for more
information.
3. Exiting the LCD Contrast setting
Settings
Press the FUNCTION button (BACK) to exit the LCD Contrast
setting and return to the Function Menus screen.
76
12 Startup Setting
The Startup Setting function allows preferred panel functions/settings to be stored in the instrument’s memory,
and automatically recalled as the default settings every time the CA97/CA67 digital piano is turned on.
* Startup Settings can also be saved to and loaded from USB memory devices. Please refer to pages 128/123 for more information.
Functions/Settings stored in the Startup Setting memory
Functions
Settings
Selected sound (including primary sound for each category)
Basic Settings
Dual Mode / Split Mode / Four Hands Mode (including settings)
Virtual Technician Settings
Reverb, Effects (Type, Settings)
MIDI Settings
Metronome (Beat, Tempo, Volume)
Headphone Settings
* Changes made to the Auto Power Off setting will be stored to the Startup Setting memory automatically.
1. Selecting the Startup Setting function
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Startup Setting function.
2. Storing current settings to the Startup Setting memory
Press the REC button.
A confirmation message will be shown in the LCD display, and
the current panel settings will be stored to the Startup Setting
memory.
Settings
* The Factory Reset function can be used to restore all settings to their
default values. Please refer to page 78 for more information.
3. Exiting the User Memory function
Press the FUNCTION button (BACK) to exit the Startup Setting
function and return to the Function Menus screen.
77
Basic Settings
13 Factory Reset
The Factory Reset function clears any settings stored using the User Memory function, restoring the CA97/CA67
digital piano to its factory default settings.
* This function will not clear registration memories or recorder songs stored in internal memory.
1. Selecting the Factory Reset function
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Factory Reset setting.
2. Restoring factory settings
Press the REC button.
A confirmation message will be shown in the LCD display, and
the all settings will be restored to their default values.
3. Exiting the Factory Reset function
Settings
Press the FUNCTION button (BACK) to exit the Factory Reset
function and return to the Function Menus screen.
78
14 Auto Power Off
The Auto Power Off setting can be used to automatically turn off the instrument after a specified period of inactivity.
This function may be enabled by default, depending on the market location.
* This setting will be stored automatically, and recalled every time the instrument is turned on.
Auto Power Off settings
Auto Power Off
Description
Off
The Auto Power Off function is disabled.
30 min.
The instrument will turn off automatically after 30 minutes of inactivity.
60 min.
The instrument will turn off automatically after 60 minutes of inactivity.
120 min.
The instrument will turn off automatically after 120 minutes of inactivity.
* The default Auto Power Off setting varies depending on market area.
1. Selecting the Auto Power Off setting
After entering the Basic Settings menu (page 64):
Press the  or  buttons to select the Auto Power Off setting.
2. Changing the Auto Power Off setting
Press the  or  buttons to change the Auto Power Off setting.
Settings
* The Auto Power Off setting will be stored automatically, and recalled
every time the instrument is turned on.
3. Exiting the Auto Power Off setting
Press the FUNCTION button (BACK) to exit the Auto Power Off
setting and return to the Function Menus screen.
79
Virtual Technician Settings
The Virtual Technician settings of the CA97/CA67 digital piano allow the player to adjust advanced parameters
such as hammer hardness, action regulation, cabinet size, and a variety of other acoustic characteristics, in order to
suit their personal preferences. Virtual Technician settings are adjusted and stored independently for each sound,
variation, allowing flexible control over the characteristics of each piano voice.
* The table below indicates which Virtual Technician settings affect to all sounds, or acoustic piano and electric piano sounds only.
Virtual Technician Settings
No.
Setting
Description
All
AP
EP
Default
1
Touch Curve
Adjust the touch sensitivity of the keyboard.

Normal
2
Voicing
Adjust the tonal character of the instrument.

Normal
User Voicing
Adjust the individual voicing of each of the 88 keys.

3
Damper Resonance
4
Damper Noise
5
6
–
Adjust the resonance that is heard when pressing the damper pedal.

5
Adjust the sound that is heard when pressing the damper pedal.

5
String Resonance
Adjust the resonance that is heard when notes are held.

5
Undamped Str. Res.
Adjust the resonance produced by the topmost undamped strings.

5
7
Cabinet Resonance
Adjust the resonance produced by the piano cabinet itself.

8
Key-off Effect
Adjust the sound that is heard when keys are released.

9
Fall-back Noise
Adjust the sound that is heard when the key action falls back.

5
10
Hammer Delay
Adjust the delay of the hammer striking strings when playing pianissimo.

Off
11
Topboard Simulation
Adjust the position of the grand piano topboard.

Open 3
12
Decay Time
Adjust the decay time of the piano sound while the keys are pressed.
13
Minimum Touch
Adjust the minimum key velocity required to produce a sound.
14
Stretch Tuning
Adjust the level of stretch tuning for equal temperaments.

Normal
–
1

5
5



1
User Tuning
Adjust the individual tuning of each of the 88 keys.

15
Temperament
Adjust the tuning system to suit Renaissance and Baroque periods etc.

Equal Temp.
User Temperament
Adjust the tuning of each note in the scale to a custom temperament.

–
16
Temperament Key
Adjust the key of the selected tuning system.

C
17
Key Volume
Adjust the volume balance of the keyboard.

Normal
–
User Key Volume
Adjust the individual volume of each of the 88 keys.

18
Half-Pedal Adjust
Adjust the point at which the damper pedal begins to sustain the sounds.

5
19
Soft Pedal Depth
Adjust the depth/effectiveness of the soft pedal.

3
* Default settings will be shown in the first LCD display illustration (i.e. Step 1) for each setting explanation below.
Settings
Entering the Virtual Technician menu
While the normal playing mode screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
The Function menus will be shown in the LCD display.
Press the  or  buttons to select the Virtual Technician menu.
Press the FUNCTION button (ENTER) again to enter the Virtual
Technician menu.
80
 buttons:
Move selection cursor.
* It is also possible to enter the Virtual Technician menu by pressing and
holding the FUNCTION button (VT) on the normal playing screen.
Selecting and adjusting the desired setting
After entering the Virtual Technician menu:
 buttons:
Adjust selected setting.
Press the  or  buttons to move the selection cursor over the
desired setting.
Press the  or  buttons to adjust the selected setting.
 buttons:
Move selection cursor.
* To reset the current Virtual Technician setting to the default value,
press the  and  buttons simultaneously.
Showing the Virtual Technician Help screen
Press the
FUNCTION button (HELP).
A brief explanation about the currently selected Virtual
Technician parameter will be shown in the LCD display.
Press the  or  buttons to scroll through the explanation if
necessary.
Press the FUNCTION button (BACK) to return to the Virtual
Technician menu.
Storing the Virtual Technician setting to the selected sound
After adjusting a Virtual Technician parameter:
FUNCTION button (STORE).
The adjusted Virtual Technician parameter setting will be used
as the default setting for the currently selected sound, and a
confirmation message will briefly be shown in the LCD display.
Settings
Press the
* Virtual Technician settings are adjusted and stored independently for
each sound variation.
* Only values for the currently selected Virtual Technician setting will
be stored. In order to store all of the Virtual Technician settings
simultaneously, it is recommended to use a Registration memory
(page 32) or the Startup Setting memory (page 77).
About Stored Virtual Technician settings
As mentioned above, the Virtual Technician settings are adjusted and stored independently for each sound. This allows different
Virtual Technician adjustments to be made for each piano voice. For example, it may be desirable to voice the SK Concert Grand
piano a little brighter than the EX Concert Grand piano, or increase the Damper, String, and Cabinet Resonances of the SK-5 Grand
while leaving the Pop Piano unchanged.
81
Virtual Technician Settings
1 Touch Curve
As with an acoustic piano, the CA97/CA67 digital piano produces a louder sound when the keys are struck with
force, and a softer sound when the keys are played gently. The volume and tonal character change in relation to the
strength and velocity of playing – on a digital piano this system is referred to as ‘touch sensitivity’.
The Touch Curve setting allows the touch sensitivity of the keyboard to be conveniently adjusted. There are six
different preset touch curve settings available, with an additional ‘User’ setting allowing performers to customise
the instrument’s keyboard responsiveness to suit their individual playing style.
The default ‘Normal’ setting is designed to accurately recreate the touch of a Kawai concert grand piano. However,
if the keyboard feels too light, or fortissimo playing is achieved too easily, it may be desirable to select a heavier
touch curve. Alternatively, if the keyboard feels too heavy, or fortissimo playing is too difficult to achieve, it may be
desirable to select a lighter touch curve.
* This Virtual Technician setting will affect all sounds.
Touch Curve types
Touch Curve
Description
Light +
Requires less striking force to achieve a forte note. For players with a very delicate touch.
A louder volume is produced even when playing with a soft touch. For those still developing finger strength.
Light
* This touch curve is recommended for children and organ players.
Normal (default)
Reproduces the standard touch sensitivity of an acoustic piano.
Heavy
Requires a heavier touch to produce a loud volume. Ideally suited to those with stronger fingers.
Heavy +
Requires considerably more striking force to achieve a loud volume.
A constant volume is produced regardless of how hard the keys are struck.
Off (constant)
* This touch curve intended for playing sounds of instruments that have a fixed dynamic range (e.g. organ and harpsichord).
User
A custom touch curve, created to suit an individual’s personal playing style.
Touch Curve graph
f
a
b
c
d
e
Soft
Sound Volume
Loud
Settings
The illustration below provides a visual representation of the different Touch Curve settings.
Gentle
82
Keyboard Pressure
Strong
No.
Touch Curve
a
Light +
b
Light
c
Normal (default)
d
Heavy
e
Heavy +
f
Off (constant)
1. Selecting the Touch Curve setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Touch Curve setting.
2. Changing the Touch Curve type
Press the  or  buttons to cycle through the different Touch
Curve types.
* To reset the Touch Curve setting to the default type, press the  and 
buttons simultaneously.
* Any changes made to the Touch Curve type or User Touch setting will
remain until the power is turned off.
* Preferred Touch Curve settings can be stored to the sound’s memory,
or a Registration memory for convenient recall. Please refer to pages
81 and 32 for more information.
3. Exiting the Touch Curve setting
Press the FUNCTION button (BACK) to exit the Touch Curve
setting and return to the Function Menus screen.
User Touch Curve
Creating a User Touch Curve
After selecting the Touch Curve setting:
Press the  or  buttons to select the User touch curve, then
press the REC button.
* User touch curves are created and stored independently for each
sound variation.
Settings
A message will be shown, prompting for the keyboard to be
played.
Play the piano dynamically from very soft to very loud, allowing
the instrument to examine the personal playing technique.
* More than one attempt may be required in order to create an accurate
User Touch Curve.
* Reducing the master volume fader to the lowest position before
creating the User Touch Curve may help to reduce user distractions,
thus improving accuracy.
Press the PLAY/STOP button.
The new User Touch Curve will be stored to the User touch type,
and selected automatically.
* If desired, press the FUNCTION button (STORE) to ensure the User
touch type is retained after the instrument’s power is turned off.
83
Virtual Technician Settings
2 Voicing
On an acoustic piano, the shape, density, and texture of the hammers all influence on the tonal character of the
instrument’s sound. Technicians utilise a variety of tools such as needles, files, and brushes to manipulate these
hammer felts, with the ultimate goal of achieving a balanced tonal character across the keyboard.
The Voicing setting recreates various hammer properties, allowing the overall tonal character of the CA97/CA67
digital piano to be adjusted. There are six different preset voicing settings available (applied uniformly to all keys),
with an additional ‘User’ setting allowing players to perform custom adjustments on each individual key.
While the default ‘Normal’ voicing setting should be appropriate for a broad range of musical genres, it may be
desirable to select a softer, more mellow tonal character for romantic pieces, or a brighter, more aggressive tone
for modern styles.
* This Virtual Technician setting will affect all sounds.
Voicing types
Voicing type
Description
Normal (default)
The normal tonal character of an acoustic piano throughout the entire dynamic range.
Mellow 1
A softer, more mellow tonal character throughout the entire dynamic range.
Mellow 2
An even soften tonal character than Mellow 1.
Dynamic
A tonal character that changes dramatically from mellow to bright, depending on the strength of key strike.
Bright 1
A bright tonal character throughout the entire dynamic range.
Bright 2
An even brighter tonal character than Bright 1.
User
A custom tonal character, allowing each key to be individually voiced.
1. Selecting the Voicing setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Voicing setting.
Settings
2. Changing the Voicing type
Press the  or  buttons to cycle through the different Voicing
types.
* To reset the Voicing setting to the default type, press the  and 
buttons simultaneously.
* Any changes made to the Voicing setting will remain until the power
is turned off.
* Preferred Voicing settings can be stored to the sound’s memory, or a
Registration memory for convenient recall. Please refer to pages 81
and 33 for more information.
3. Exiting the Voicing setting
Press the FUNCTION button (BACK) to exit the Voicing setting
and return to the Function Menus screen.
84
User Voicing
The User Voicing function allows each of the 88 keys to be voiced individually.
1. Selecting the User Voicing type
After selecting the Voicing setting:
Press the  or  buttons to select the User Voicing type.
* User Voicing is performed and stored independently for each sound
variation.
Press the
FUNCTION button (EDIT).
The User Voicing screen will be shown in the LCD display.
2. Selecting the note, adjusting the User Voicing value
Press the  or  buttons to select the desired note to be
adjusted.
* To select a note directly, press and hold the
(+ KEY) then press the desired key.
FUNCTION button
Press the  or  buttons to adjust the User Voicing value for the
selected note.
* The User Voicing value can be adjusted within the range of –5~+5, with
lower values creating a mellower sound and higher values creating a
brighter sound.
* To reset the User Voicing setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the User Voicing setting will remain until the
power is turned off.
* Preferred User Voicing settings can be stored to the sound’s memory,
or a Registration memory for convenient recall. Please refer to pages
81 and 33 for more information.
Settings
3. Exiting the User Voicing function
Press the FUNCTION button (BACK) to exit the User Voicing
screen and return to the Voicing setting.
85
Virtual Technician Settings
3 Damper Resonance
Pressing the damper pedal of an acoustic piano raises all dampers, allowing the strings to vibrate freely. When a
note or chord is played on the piano with the sustain pedal pressed, not only will the strings of the notes played
vibrate, but also the strings of other notes, vibrating in sympathetic resonance.
The CA97/CA67 digital piano recreates this phenomenon, with the Damper Resonance setting allowing the volume
of this resonance sound to be adjusted.
* This Virtual Technician setting will affect acoustic piano sounds only.
1. Selecting the Damper Resonance setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Damper Resonance
setting.
2. Adjusting the Damper Resonance volume
Press the  or  buttons to increase or decrease the volume of
the Damper Resonance setting.
* The Damper Resonance volume can be adjusted within the range
of Off, 1~10, with higher values resulting in a more pronounced
resonance.
* To reset the Damper Resonance setting to the default value, press the
 and  buttons simultaneously..
* Any changes made to the Damper Resonance setting will remain until
the power is turned off.
* Preferred Damper Resonance settings can be stored to the sound’s
memory, or a Registration memory for convenient recall. Please refer
to pages 81 and 33 for more information.
3. Exiting the Damper Resonance setting
Settings
Press the
FUNCTION button (BACK) to exit the Damper
Resonance setting and return to the Function Menus screen.
86
4 Damper Noise
When the damper pedal of an acoustic piano is pressed and released, it is often possible to hear the sound of the
damper head touching and releasing the strings.
The CA97/CA67 digital piano reproduces this sound, with the Damper Noise setting allowing the volume of this
sound to be adjusted. The speed at which the damper pedal is pressed will also influence the prominence of the
damper noise, with fast pedalling creating a very pronounced sound.
* This Virtual Technician setting will affect acoustic piano sounds only.
1. Selecting the Damper Noise setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Damper Noise setting.
2. Adjusting the Damper Noise volume
Press the  or  buttons to increase or decrease the volume of
the Damper Noise setting.
* The Damper Noise volume can be adjusted within the range of
Off, 1~10, with higher values resulting in a more pronounced noise.
* To reset the Damper Noise setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the Damper Noise setting will remain until the
power is turned off.
* Preferred Damper Noise settings can be stored to the sound’s memory,
or a Registration memory for convenient recall. Please refer to pages
81 and 33 for more information.
3. Exiting the Damper Noise setting
Settings
Press the FUNCTION button (BACK) to exit the Damper Noise
setting and return to the Function Menus screen.
87
Virtual Technician Settings
5 String Resonance
String Resonance refers to a phenomenon that exists in acoustic pianos whereby the strings of held notes resonate
‘sympathetically’ with other notes of the same harmonic overtone series.
The CA97/CA67 digital piano recreates this phenomenon, with the String Resonance setting allowing the volume
of this resonance to be adjusted.
* This Virtual Technician setting will affect acoustic piano sounds only.
Demonstrating String Resonance
To experience the string resonance phenomenon, gently hold down the ‘C’ key as shown in the illustration below, then play (strike
and release quickly) any of the keys marked with a  symbol. In addition to the sound of each note played, it should also be possible
to hear the strings of the first ‘C’ key resonating ‘sympathetically’, thus demonstrating String Resonance.
C
F G
B
F G
C
E
ho
ld
C
A
1. Selecting the String Resonance setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the String Resonance
setting.
2. Adjusting the String Resonance volume
Press the  or  buttons to increase or decrease the volume of
the String Resonance setting.
Settings
* The String Resonance volume can be adjusted within the range
of Off, 1~10, with higher values resulting in a more pronounced
resonance.
* To reset the String Resonance setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the String Resonance setting will remain until
the power is turned off.
* Preferred String Resonance settings can be stored to the sound’s
memory, or a Registration memory for convenient recall. Please refer
to pages 81 and 33 for more information.
3. Exiting the String Resonance setting
Press the
FUNCTION button (BACK) to exit the String
Resonance setting and return to the Function Menus screen.
88
G
C
E
G
A
C D E
G
C
6 Undamped String Resonance
The dampers of an acoustic piano span almost the full width of the keyboard. However, the topmost 18 keys
(approximately 1.5 octaves) do not incorporate dampers, as the shorter strings for these treble notes decay quickly
and therefore do not need to be dampened.
Damped Strings
A0
Undamped Strings
G6
C8
As a result, the strings of these ‘undamped’ treble notes are free to vibrate in sympathetic resonance with those of
lower keys – independently of the damper pedal position – helping to enrich the sound with additional harmonics
and tonal colour.
The CA97/CA67 digital piano recreates this phenomenon, with the Undamped String Resonance setting allowing
the volume of this resonance sound to be adjusted.
* This Virtual Technician setting will affect acoustic piano sounds only.
1. Selecting the Undamped String Resonance setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Undamped String
Resonance setting.
2. Adjusting the Undamped String Resonance volume
Press the  or  buttons to increase or decrease the volume of
the Undamped String Resonance setting.
Settings
* The Undamped String Resonance volume can be adjusted within the
range of Off, 1~10, with higher values resulting in a more pronounced
resonance.
* To reset the Undamped String Resonance setting to the default value,
press the  and  buttons simultaneously.
* Any changes made to the Undamped String Resonance setting will
remain until the power is turned off.
* Preferred Undamped String Resonance settings can be stored to the
sound’s memory, or a Registration memory for convenient recall.
Please refer to pages 81 and 33 for more information.
3. Exiting the Undamped String Resonance setting
Press the
FUNCTION button (BACK) to exit the Undamped
String Resonance setting and return to the Function Menus
screen.
89
Virtual Technician Settings
7 Cabinet Resonance
While the fundamental sound of an acoustic piano is produced by vibrating strings, transmitting energy through
a spruce soundboard, the cabinet of the instrument itself also contributes a variety of subtle tonal characteristics
that enrich the playing and listening experience. The keybed, inner and outer rim, iron plate, and beams all play a
role in disseminating sound energy, which in turn gives the piano a living, breathing quality.
The CA97/CA67 digital piano recreates these natural acoustic characteristics, with the Cabinet Resonance setting
allowing the volume of this resonance sound to be adjusted.
* This Virtual Technician setting will affect acoustic piano sounds only.
1. Selecting the Cabinet Resonance setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Cabinet Resonance
setting.
2. Adjusting the Cabinet Resonance volume
Press the  or  buttons to increase or decrease the volume of
the Cabinet Resonance setting.
* The Cabinet Resonance volume can be adjusted within the range of
1~10, with higher values resulting in a more pronounced resonance.
* To reset the Cabinet Resonance setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the Cabinet Resonance setting will remain until
the power is turned off.
* Preferred Cabinet Resonance settings can be stored to the sound’s
memory, or a Registration memory for convenient recall. Please refer
to pages 81 and 33 for more information.
3. Exiting the Cabinet Resonance setting
Settings
Press the
FUNCTION button (BACK) to exit the Cabinet
Resonance setting and return to the Function Menus screen.
90
8 Key-off Effect
When playing an acoustic piano – particularly in the bass region of the keyboard – if a key is played with force and
released quickly, it is often possible to hear the faint sound of the damper touching the strings immediately before
the vibrations are stopped.
In addition, the speed at which keys are lifted will also affect the character of the sound. For example, when lifting
the keys quickly (e.g. staccato playing) the ‘release’ portion of the sound will be noticeably shorter than when
lifting the keys slowly (e.g. legato playing).
The CA97/CA67 digital piano reproduces both characteristics, with the Key-off Effect setting allowing the volume of
the key-off sound to be adjusted, and the key-off release speed detection to be turned on or off.
* This Virtual Technician setting will affect acoustic piano and electric piano sounds.
1. Selecting the Key-off Effect setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Key-off Effect setting.
2. Adjusting the Key-off Effect volume
Press the  or  buttons to increase or decrease the volume of
the Key-off Effect setting.
* The Key-off Effect volume can be adjusted within the range of
Off, 1~10, with higher values resulting in a more pronounced effect.
* When the Key-Off Effect setting is set to Off, the key-off release speed
detection will also be disabled, and the speed at which keys are lifted
will not affect the character of the sound.
* To reset the Key-off Effect setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the Key-off Effect setting will remain until the
power is turned off.
Settings
* Preferred Key-off Effect settings can be stored to the sound’s memory,
or a Registration memory for convenient recall. Please refer to pages
81 and 33 for more information.
3. Exiting the Key-off Effect setting
Press the FUNCTION button (BACK) to exit the Key-off Effect
setting and return to the Function Menus screen.
91
Virtual Technician Settings
9 Fall-back Noise
When playing an acoustic piano, it is often possible to hear the faint sound of the keyboard action returning (i.e.
‘falling back’) to the neutral position after a key is released.
The CA97/CA67 digital piano reproduces this sound, with the Fall-back Noise setting allowing the volume of this
sound to be adjusted.
While the default value is intended to simulate the natural volume level of the keys as they return to their neutral
position, it may occasionally be desirable to adjust the volume of this sound. For example, reducing the volume
when playing very soft pieces, where the fall-back noise may become too prominent.
* This Virtual Technician setting will affect acoustic piano and harpsichord sounds.
1. Selecting the Fall-back Noise setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Fall-back Noise setting.
2. Adjusting the Fall-back Noise volume
Press the  or  buttons to increase or decrease the volume of
the Fall-back Noise setting.
* The Fall-back Noise volume can be adjusted within the range of
Off, 1~10, with higher values resulting in a more pronounced noise.
* To reset the Fall-back Noise setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the Fall-back Noise setting will remain until the
power is turned off.
* Preferred Fall-back Noise settings can be stored to the sound’s
memory, or a Registration memory for convenient recall. Please refer
to pages 81 and 33 for more information.
Settings
3. Exiting the Fall-back Noise setting
Press the FUNCTION button (BACK) to exit the Fall-back Noise
setting and return to the Function Menus screen.
92
10 Hammer Delay
When playing pianissimo passages using an acoustic piano, there may be a perceived delay between a key being
pressed and the hammer striking the strings.
If desired, the CA97/CA67 digital piano can recreate this delay, with the Hammer Delay setting allowing the delay
length to be adjusted.
While the default value of ‘Off’ is intended to replicate a well-regulated concert grand piano, with an immediate
connection between the keyboard and hammers, some players may find it desirable to introduce a minor delay, in
order to mimic different types of piano or instruments with a slightly worn keyboard action.
* This Virtual Technician setting will affect acoustic piano sounds only.
1. Selecting the Hammer Delay setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Hammer Delay setting.
2. Adjusting the Hammer Delay value
Press the  or  buttons to increase or decrease the value of
the Hammer Delay setting.
* The Hammer Delay value can be adjusted within the range of
Off, 1~10, with higher values resulting in an increased delay.
* To reset the Hammer Delay setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the Hammer Delay setting will remain until the
power is turned off.
* Preferred Hammer Delay settings can be stored to the sound’s
memory, or a Registration memory for convenient recall. Please refer
to pages 81 and 33 for more information.
Settings
3. Exiting the Hammer Delay setting
Press the FUNCTION button (BACK) to exit the Hammer Delay
setting and return to the Function Menus screen.
93
Virtual Technician Settings
11 Topboard Simulation
When playing an acoustic grand piano, the position of the instrument’s topboard (lid) affects both the volume and
‘openness’ of the tone produced. A fully open topboard allows sound waves to reflect off the polished lid surface
and project into the room, while a closed lid has the opposite effect, resulting in a darker, more opaque tone.
The CA97/CA67 digital piano simulates these characteristics, with four different topboard positions.
* This Virtual Technician setting will affect acoustic piano sounds only.
Topboard positions
Topboard position
Description
Open 3 (default)
Simulates the character of a fully open topboard, with maximum sound projection.
Open 2
Simulates the character of a half open topboard, with reduced sound projection.
Open 1
Simulates the character of a partially open topboard, with limited sound projection.
Closed
Simulates the character of a closed topboard, with minimum sound projection.
1. Selecting the Topboard setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Topboard setting.
2. Changing the Topboard position
Press the  or  buttons to cycle through the different
Topboard types.
* To reset the Topboard setting to the default position, press the
 and  buttons simultaneously.
* Any changes made to the Topboard setting will remain until the
power is turned off.
Settings
* Preferred Topboard settings can be stored to the sound’s memory, or
a Registration memory for convenient recall. Please refer to pages 81
and 33 for more information.
3. Exiting the Topboard setting
Press the
FUNCTION button (BACK) to exit the Topboard
setting and return to the Function Menus screen.
94
12 Decay Time
When playing an acoustic grand piano, the length of the instrument influences the speed at which held notes decay,
with longer grand pianos (i.e. longer strings) characterised by longer decay times.
The CA97/CA67 digital piano simulates this characteristic, with the Decay Time setting allowing the length of decay
while keys are pressed to be adjusted.
* This Virtual Technician setting will affect all sounds.
1. Selecting the Decay Time setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Decay Time setting.
2. Adjusting the Decay Time volume
Press the  or  buttons to increase or decrease the value of
the Decay Time setting.
* The Decay Time value can be adjusted within the range of
1~10, with larger values resulting in increased decay times.
* To reset the Decay Time setting to the default value, press the  and 
buttons simultaneously.
* Any changes made to the Decay Time setting will remain until the
power is turned off.
* Preferred Decay Time settings can be stored to the sound’s memory,
or a Registration memory for convenient recall. Please refer to pages
81 and 33 for more information.
3. Exiting the Decay Time setting
Settings
Press the FUNCTION button (BACK) to exit the Decay Time
setting and return to the Function Menus screen.
95
Virtual Technician Settings
13 Minimum Touch
The Minimum Touch setting allows the minimum key velocity required to produce a sound to be adjusted. By
default, this setting recreates the extremely fine touch sensitivity of a concert grand piano, allowing a very soft
sound to be produced with the slightest of key touches. However, it may be desirable to reduce this sensitivity,
when wishing to recreate the sensitivity of a small grand piano or an upright piano.
* This Virtual Technician setting will affect acoustic piano and electric piano sounds.
1. Selecting the Minimum Touch setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Minimum Touch setting.
2. Adjusting the Minimum Touch value
Press the  or  buttons to increase or decrease the value of
the Minimum Touch setting.
* The Minimum Touch value can be adjusted within the range of 1~20,
with larger values requiring greater key force in order to produce a
sound. For example, a value of 10 will require the keyboard to be
played with a velocity of 10 or above in order to produce a sound.
* To reset the Minimum Touch setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the Minimum Touch setting will remain until
the power is turned off.
* Preferred Minimum Touch settings can be stored to the sound’s
memory, or a Registration memory for convenient recall. Please refer
to pages 81 and 33 for more information.
3. Exiting the Minimum Touch setting
Settings
Press the
FUNCTION button (BACK) to exit the Minimum
Touch setting and return to the Function Menus screen.
96
14 Stretch Tuning
Stretch tuning is a piano-specific tuning method used by acoustic piano technicians in which the lower octaves
are tuned slightly flatter and the upper octaves are tuned slightly sharper to match the natural harmonics of an
acoustic piano.
The Stretch Tuning setting allows the degree of stretch tuning to be adjusted when Equal temperament is selected,
or for stretch tuning to be completely disabled. It is also possible to create custom tuning methods by adjusting the
pitch of each individual key.
* This Virtual Technician setting will affect all sounds.
Stretch Tuning setting
Stretch Tuning
Description
Off
Stretch tuning is disabled.
Normal (default)
Normal stretch tuning is applied.
Wide
Wide stretch tuning is applied.
User
A custom tuning method, allowing the pitch of each key to be individual tuned.
1. Selecting the Stretch Tuning setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Stretch Tuning setting.
2. Changing the Stretch Tuning type
Press the  or  buttons to alternate between ‘Normal’ and
‘Wide’ Stretch Tuning settings.
* To reset the Stretch Tuning setting to the default type, press the
 and  buttons simultaneously.
Settings
* Any changes made to the Stretch Tuning setting will remain until the
power is turned off.
* Preferred Stretch Tuning settings can be stored to the sound’s
memory, or a Registration memory for convenient recall. Please refer
to pages 81 and 33 for more information.
3. Exiting the Stretch Tuning setting
Press the FUNCTION button (BACK) to exit the Stretch Tuning
setting and return to the Function Menus screen.
97
Virtual Technician Settings
User Tuning
The User Tuning function allows each of the 88 keys to be tuned individually.
1. Selecting the User Tuning type
After selecting the Stretch Tuning setting (page 97):
Press the  or  buttons to select the User Tuning type.
* User Tuning is performed and stored independently for each sound
variation.
Press the
FUNCTION button (EDIT).
The User Tuning screen will be shown in the LCD display.
2. Selecting the note, adjusting the User Tuning value
Press the  or  buttons to select the desired note to be
adjusted.
* To select a note directly, press and hold the
(+ KEY) then press the desired key.
FUNCTION button
Press the  or  buttons to adjust the User Tuning value for the
selected note.
* The User Tuning value can be adjusted within the range of –50~+50.
A value of +20 indicates a pitch increase of 20 cents.
* To reset the User Tuning setting to the default value, press the  and 
buttons simultaneously.
* Any changes made to the User Tuning setting will remain until the
power is turned off.
* Preferred User Tuning settings can be stored to the sound’s memory,
or a Registration memory for convenient recall. Please refer to pages
81 and 33 for more information.
Settings
3. Exiting the User Tuning function
Press the FUNCTION button (BACK) to exit the User Tuning
tuning screen and return to the Stretch Tuning setting.
98
15 Temperament
The Temperament setting allows the tuning system used by the CA97/CA67 digital piano to be changed from the
modern ‘Equal Temperament’ standard to one of the various temperaments popularised during the Renaissance and
Baroque periods. It is also possible to create customised temperaments using the User Temperament function.
* This Virtual Technician setting will affect all sounds.
Temperament types
Temperament type
Equal Temperament (default)
(Equal)
Pure Temperament
(Pure Major/Pure Minor)
Pythagorean Temperament
(Pythagorean)
Meantone Temperament
(Meantone)
Werckmeister Temperament
(Werckmeister)
Kirnberger Temperament
(Kirnberger)
User Temperament
(User)
Description
This temperament is the most popular tuning method, and divides the scale into twelve equal semitones. This produces the same chordal intervals in all twelve keys, and has the advantage of limitless
modulation of the key. However, the tonality of each key becomes less characteristic and no chord is
in pure consonance.
This temperament, which eliminates dissonances for thirds and fifths, is still popular in choral music
because of its perfect harmony. Any key modulation will result in dissonances.
* The key of the temperament, and major/minor setting must be correctly matched.
This temperament, which uses mathematical ratios to eliminate dissonance for fifths, is very limited
for use with chords, but produces very characteristic melodic lines.
This temperament, which uses a mean between a major and minor whole tone to eliminate
dissonance for thirds, was devised to eliminate the lack of consonances experienced with certain fifths
for the Mersenne pure temperament.
It produces chords that are more beautiful than those played with equal temperament.
These two temperaments are placed in between Meantone and Pythagorean. For music with few
accidentals, this temperament produces the beautiful chords of the mean tone, but as accidentals
increase, the temperament produces the characteristic melodies of the Pythagorean temperament.
It is used primarily for classical music written in the Baroque era to revive the original characteristics.
A custom temperament, created by raising or lowering the pitch of each note in the scale.
1. Selecting the Temperament setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Temperament setting.
Settings
2. Changing the Temperament type
Press the  or  buttons to cycle through the different
Temperament types.
* To reset the Temperament setting to the default type, press the
 and  buttons simultaneously.
* Any changes made to the Temperament setting will remain until the
power is turned off.
* Preferred Temperament settings can be stored to the sound’s memory,
or a Registration memory for convenient recall. Please refer to pages
81 and 33 for more information.
3. Exiting the Temperament setting
Press the FUNCTION button (BACK) to exit the Temperament
setting and return to the Function Menus screen.
99
Virtual Technician Settings
User Temperament
The User Temperament function allows custom temperaments to be created.
1. Selecting the User Temperament
After selecting the Temperament setting (page 99):
Press the  or  buttons to select the User temperament, then
press the FUNCTION button (EDIT).
The User Temperament screen will be shown in the LCD display.
2. Selecting the note, adjusting the user temperament value
Press the  or  buttons to select the desired note to be
adjusted.
Press the  or  buttons to adjust the User Temperament value
for the selected note.
* The User Temperament value can be adjusted within the range of
–50~+50. A value of +20 indicates a pitch increase of 20 cents.
* To reset the User Temperament setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the User Temperament setting will remain until
the power is turned off.
* Preferred User Temperament settings can be stored to the sound’s
memory, or a Registration memory for convenient recall. Please refer
to pages 81 and 33 for more information.
3. Exiting the User Temperament function
Settings
Press the
FUNCTION button (BACK) to exit the User
Temperament screen and return to the Temperament setting.
100
16 Temperament Key
The Temperament Key setting allows the key of the selected temperament to be specified. When using a
temperament other than Equal temperament, use this setting to specify the key signature of the piece.
* This Virtual Technician setting will affect all sounds.
* This setting will only affect the ‘balance’ of the tuning system, the pitch of the keyboard will remain unchanged.
1. Selecting the Temperament Key setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Temperament Key setting.
2. Adjusting the Temperament Key
After selecting a temperament other than Equal temperament
types (page 99):
Press the  or  buttons to change the Temperament Key.
* The Temperament Key can be set within the range of C to B.
* To reset the Temperament Key setting to the default key, press the
 and  buttons simultaneously.
* Any changes made to the Temperament Key setting will remain until
the power is turned off.
* Preferred Temperament Key settings can be stored to the sound’s
memory, or a Registration memory for convenient recall. Please refer
to pages 81 and 33 for more information.
3. Exiting the Temperament Key setting
Settings
Press the FUNCTION button (BACK) to exit the Temperament
Key setting and return to the Function Menus screen.
101
Virtual Technician Settings
17 Key Volume
The Key Volume setting allows the volume of different regions of the keyboard to be subtly reduced. There are four
different damping presets available, with an additional ‘User’ setting allowing players to perform subtle volume
adjustments on each individual key.
While the default ‘Normal’ key volume setting should be appropriate for a broad range of musical genres, it may
be desirable to experiment with different damping presets, or the User setting to attenuate or amplify the volume
of individual keys.
* This Virtual Technician setting will affect all sounds.
Key Volume types
Key Volume
Description
Normal (default)
An evenly balanced volume throughout the keyboard.
High Damping
Gradually reduces the volume of the keyboard towards the treble region.
Low Damping
Gradually reduces the volume of the keyboard towards the bass region.
High & Low Damping
Gradually reduces the volume of the keyboard in both the treble and bass regions.
Center Damping
Gradually reduces the volume of the keyboard in the central region.
User
A custom keyboard volume, allowing the volume of each key to be individually adjusted.
1. Selecting the Key Volume setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Key Volume setting.
2. Changing the Key Volume type
Settings
Press the  or  buttons to cycle through the different Key
Volume types.
* To reset the Key Volume setting to the default type, press the  and 
buttons simultaneously.
* Any changes made to the Key Volume setting will remain until the
power is turned off.
* Preferred Key Volume settings can be stored to the sound’s memory,
or a Registration memory for convenient recall. Please refer to pages
81 and 33 for more information.
3. Exiting the Key Volume function
Press the FUNCTION button (BACK) to exit the Key Volume
adjustment screen and return to the Functions Menus screen.
102
User Key Volume
The User Key Volume settings allows the volume of each of the 88 keys to be adjusted individually.
1. Selecting the User Key Volume type
After entering the Key Voicing setting:
Press the  or  buttons to select the User Key Volume type.
* User Key Volume is performed and stored independently for each
sound variation.
Press the
FUNCTION button (EDIT).
The User Key Volume screen will be shown in the LCD display.
2. Selecting the note, adjusting the User Key Volume value
Press the  or  buttons to select the desired note to be
adjusted.
* To select a note directly, press and hold the
(+ KEY) then press the desired key.
FUNCTION button
Press the  or  buttons to adjust the User Key Volume value for
the selected note.
* The User Key Volume value can be adjusted within the range of
–50~+50, with lower values attenuating the sound and higher values
amplifying the sound.
* To reset the User Key Volume setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the User Key Volume setting will remain until
the power is turned off.
* Preferred User Key Volume settings can be stored to the sound’s
memory, or a Registration memory for convenient recall. Please refer
to pages 81 and 33 for more information.
Settings
3. Exiting the User Key Volume function
Press the
FUNCTION button (BACK) to exit the User Key
Volume screen and return to the Key Volume setting.
103
Virtual Technician Settings
18 Half-Pedal Adjust
The Half-Pedal Adjust setting allows the point at which the damper/sustain pedal becomes effective (i.e. when
the dampers of the piano begin to lift from the strings) to be adjusted. This setting may be useful for pianists that
habitually rest their right foot on the damper/sustain pedal, but do not necessarily wish to sustain the sound.
* This Virtual Technician setting will affect all sounds.
1. Selecting the Half-Pedal Adjust setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Half-Pedal Adjust
setting.
2. Adjusting the Half-Pedal Adjust value
Press the  or  buttons to increase or decrease the value of
the Half-Pedal Adjust setting.
* The Half-Pedal Adjust value can be adjusted within the range of
1~10, with higher values resulting in a later damper pedal point.
* To reset the Half-Pedal Adjust setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the Half-Pedal Adjust setting will remain until
the power is turned off.
* Preferred Half-Pedal Adjust settings can be stored to the sound’s
memory, or a Registration memory for convenient recall. Please refer
to pages 81 and 33 for more information.
3. Exiting the Half-Pedal Adjust setting
Settings
Press the
FUNCTION button (BACK) to exit the Half-pedal
Point setting and return to the Function Menus screen.
104
19 Soft Pedal Depth
The Soft Pedal Depth setting adjusts the extent to which the soft (left) pedal of the CA97/CA67 digital piano softens
the sound of played notes.
While the default value is intended to replicate the effectiveness of a concert grand Una Corda pedal, it may be
desirable for players to increase or decrease the value of this setting to suit their playing style.
On an acoustic piano, pressing this Una Corda pedal shifts the keyboard action slightly to the right, causing the
hammers to strike two strings instead of the usual three, thus reducing the volume of each note.
* This Virtual Technician setting will affect all sounds.
1. Selecting the Soft Pedal Depth setting
After entering the Virtual Technician menu (page 80):
Press the  or  buttons to select the Soft Pedal Depth setting.
2. Adjusting the Soft Pedal Depth value
Press the  or  buttons to increase or decrease the value of
the Soft Pedal Depth setting.
* The Soft Pedal Depth value can be adjusted within the range of
1~10, with higher values resulting in a softer sound.
* To reset the Soft Pedal Depth setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the Soft Pedal Depth setting will remain until
the power is turned off.
* Preferred Soft Pedal Depth settings can be stored to the sound’s
memory, or a Registration memory for convenient recall. Please refer
to pages 81 and 33 for more information.
3. Exiting the Soft Pedal Depth setting
Settings
Press the
FUNCTION button (BACK) to exit the Soft Pedal
Depth setting and return to the Function Menus screen.
105
Phones Settings
The Phones Settings menu contains settings to select the SHS (Spatial Headphone Sound) mode, the type of
headphones to be used, and the output volume of the connected headphones.
Phones Settings
No.
Setting
Description
Default setting
1
SHS Mode
Select the desired SHS (Spatial Headphone Sound) mode.
Normal
2
Phones Type
Select the type of headphones to be used with the instrument.
Normal
3
Phones Volume
Change the maximum volume level of the headphones output.
Normal
* Default settings will be shown in the first LCD display illustration (i.e. Step 1) for each setting explanation below.
Entering the Phones Settings menu
While the normal playing mode screen is shown in the LCD display:
Press the
FUNCTION button (ENTER).
The Function menus will be shown in the LCD display.
Press the  or  buttons to select the Phone Settings menu.
Press the FUNCTION button (ENTER) again to enter the Phones
Settings menu.
Selecting and adjusting the desired setting
After entering the Basic Settings menu:
Settings
Press the  or  buttons to move the selection cursor over the
desired setting.
 buttons:
Adjust selected setting.
Press the  or  buttons to adjust the selected setting.
* To reset the current setting to the default value, press the  and 
buttons simultaneously.
106
 buttons:
Move selection cursor.
1 SHS Mode
Spatial Headphone Sound (SHS) is a special feature of the CA97/CA67 digital piano that enhances the depth and
realism of the acoustic piano sound when listening through headphones or earphones.
The SHS Mode setting allows the player to select from one of three different acoustic presets that adjust the spatial
positioning of the sound, while also helping to reduce auditory fatigue when using earphones or headphones for
extended periods of time.
* This setting does not affect the speaker or Line Out sound.
SHS Mode setting
SHS Mode
Description
Off
Disable the Spatial Headphone Sound feature.
Forward
Front focused, somewhat narrow spatial positioning.
Normal (default)
Naturally balanced spatial positioning that is neither forward nor wide.
Wide
Wide, very open spatial positioning.
1. Selecting the SHS Mode setting
After entering the Phones Settings menu (page 106):
Press the  or  buttons to select the SHS Mode setting.
2. Changing the SHS Mode setting
Press the  or  buttons to cycle through the different SHS
Mode types types.
* To reset the SHS Mode setting to the default setting, press the  and 
buttons simultaneously.
* Any changes made to the SHS Mode setting will remain until the
power is turned off.
Settings
* Preferred SHS Mode settings can be stored to the Startup Setting
memory for convenient recall. Please refer to page 77 for more
information.
3. Exiting the SHS Mode setting
Press the
FUNCTION button (BACK) to exit the SHS Mode
setting and return to the Function Menus screen.
107
Phones Settings
2 Phones Type
The Phones Type setting optimises the sound of the CA97/CA67 digital piano when listening through different
types of headphones or earphones.
* This setting does not affect the speaker or Line Out sound.
Phones Type setting
Phones Type
Description
Normal (default)
Disables headphone optimisation.
Open
Optimises the sound for open type headphones.
Semi-open
Optimises the sound for semi-open type headphones.
Closed
Optimises the sound for closed type headphones.
Inner-ear
Optimises the sound for inner-ear type headphones.
Canal
Optimises the sound for canal-type headphones.
1. Selecting the Phones Type setting
After entering the Phones Settings menu (page 106):
Press the  or  buttons to select the Phones Type setting.
2. Changing the Phones Type setting
Press the  or  buttons to cycle through the different
earphone/headphone types.
* To reset the Phones Type setting to the default setting, press the
 and  buttons simultaneously.
* Any changes made to the Phones Type setting will remain until the
power is turned off.
Settings
* Preferred Phones Type settings can be stored to the Startup Setting
memory for convenient recall. Please refer to page 77 for more
information.
3. Exiting the Phones Type setting
Press the FUNCTION button (BACK) to exit the Phones Type
setting and return to the Function Menus screen.
108
3 Phones Volume
The Phones Volume setting allows the maximum volume level of the headphones output to be increased.
The default setting for Phones Volume is ‘Normal’ in order to protect an individual’s ears from excessive volume
levels. The ‘High’ setting may be selected when using headphones with a high impedance, or in situations where it
is desirable to increase the maximum volume level of the headphones output.
* This setting does not affect the speaker or Line Out sound.
Phones Volume setting
Phones Volume
Description
Normal (default)
The instrument’s headphone connectors will output sound at the normal volume level.
High
The instrument’s headphone connectors will output sound at an increased volume level.
1. Selecting the Phones Volume setting
After entering the Phones Settings menu (page 106):
Press the  or  buttons to select the Phones Volume setting.
2. Changing the Phones Volume type
Press the  or  buttons to alternate between ‘Normal’ and
‘High’ Phones Volume settings.
* To reset the Phones Volume setting to the default setting, press the
 and  buttons simultaneously.
* Any changes made to the Phones Volume setting will remain until the
power is turned off.
Settings
* Preferred Phones Volume settings can be stored to the Startup
Setting memory for convenient recall. Please refer to page 77 for
more information.
3. Exiting the Phones Volume setting
Press the FUNCTION button (BACK) to exit the Phones Volume
setting and return to the Function Menus screen.
109
MIDI Settings
MIDI Overview
The term MIDI is an acronym for Musical Instrument Digital Interface, an international standard for connecting
musical instruments, computers, and other devices to allow the exchange of performance data.
MIDI Terminals
MIDI terminal
Function
MIDI IN
Receiving note, program change, and other data.
MIDI OUT
Sending note, program change, and other data.
MIDI channels
MIDI uses channels to exchange data back and forth between MIDI devices. There are receive (MIDI IN) and transmit (MIDI OUT)
channels. Most musical instruments or devices with MIDI functions are equipped with both MIDI IN and OUT jacks and are capable of
transmitting and receiving data via MIDI. The receive channels are used to receive data from another MIDI device, and the transmit
channels are used to transmit data to another MIDI device.
The illustration below shows three musical instruments, connected together using MIDI.
Transmitting instrument a
Receiving instrument b
Receiving instrument c
Transmitting instrument a sends transmit channel and keyboard information to receiving instruments b/c.
The information arrives at the receiving instruments b/c.
Receiving instruments b/c will respond to MIDI data that is sent if their receive channel is the same as the transmit channel of the
transmitting instrument a. If the channels do not match, the receiving instruments b/c will not respond to any data that is sent.
Settings
For both receiving and transmitting, channels 1-16 can be used.
Recording/playing with a sequencer
When connected to a sequencer (or a computer running MIDI
sequencing software), the CA97/CA67 digital piano can be used
to record and playback multi-track songs, with separate sounds
playing simultaneously on each channel.
Sequencer
110
MIDI Functions
The CA97/CA67 digital piano supports the following MIDI functions:
Transmit/receive note information
Transmit/receive program change information
Transmit/receive note information to/from a MIDI-connected
musical instrument or device.
Transmit/receive program change data to/from a MIDIconnected musical instrument or device.
Transmit/receive channel settings
Transmit/receive pedal data
Specify transmit/receive channels within the range of 1 to 16.
Transmit/receive sustain, sostenuto, and soft pedal data to/
from a MIDI-connected musical instrument or device.
Transmit/receive exclusive data
Receive volume data
Transmit/receive front panel or menu function settings as
exclusive data.
Receive MIDI volume data sent from a MIDI-connected
musical instrument or device.
Multi-timbral mode setting
Receive multiple channel MIDI data from a MIDI-connected
musical instrument or device.
* Please refer to the ‘MIDI Implementation Chart’ on page 147 for
further information regarding the MIDI capabilities of the CA97/CA67
digital piano.
MIDI Settings
No.
Setting
Description
Default setting
1
MIDI Channel
Specify the channel that is used to transmit/receive MIDI information.
1
2
Send PGM Change # Send a MIDI program change number from 1 to 128.
1
3
Local Control
Specify whether internal sounds will be heard when the keyboard is pressed.
On
4
Trans. PGM Change
Specify whether program change data is sent when sounds are changed.
On
5
Multi-timbral Mode
Specify whether the instrument can receive Multi-timbral MIDI information.
Off
6
Channel Mute
Specify which channels (1-16) are activated to receive MIDI information.
Play All
Entering the MIDI Settings menu
Selecting and adjusting the desired setting
While the normal playing mode screen is shown in the LCD display:
After entering the MIDI Settings menu:
Press the
FUNCTION button (EDIT).
Settings
* Default settings will be shown in the first LCD display illustration (i.e. Step 1) for each setting explanation below.
Press the  or  buttons to move the selection cursor over the
desired setting.
The Function menus will be shown in the LCD display.
Press the  or  buttons to adjust the selected setting.
Press the  or  buttons to select the MIDI Settings menu.
* To reset the current setting to the default value, press the  and 
buttons simultaneously.
Press the FUNCTION button (ENTER) again to enter the MIDI
Settings menu.
111
MIDI Settings
1 MIDI Channel
The MIDI Channel setting allows the transmit/receive channel to be specified. The selected channel will function as
both the transmit and receive channel (separate transmit/receive channels cannot be specified).
1. Selecting the MIDI Channel setting
After entering the MIDI Settings menu (page 111):
Press the  or  buttons to select the MIDI Channel setting.
2. Changing the MIDI Channel value
Press the  or  buttons to increase or decrease the value of
the MIDI Channel setting.
* The MIDI Channel value can be adjusted within the range of 1~16.
* To reset the MIDI Channel setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the MIDI Channel setting will remain until the
power is turned off.
* Preferred MIDI Channel settings can be stored to a Registration
memory for convenient recall. Please refer to page 77 for more
information.
3. Exiting the MIDI Channel setting
Press the FUNCTION button (BACK) to exit the MIDI Channel
setting and return to the Function Menus screen.
Settings
Omni mode
When the CA97/CA67 digital piano is turned on, the instrument is automatically set to ‘omni mode on’, allowing MIDI information to
be received on all MIDI channels (1-16). When the MIDI Channel setting is used to specify a transmit/receive channel, the instrument
will be set to ‘omni mode off’.
Multi-timbral mode and Split/Dual modes
Using Split mode with Multi-timbral mode enabled
Using Dual mode with Multi-timbral mode enabled
Notes played in the lower section of the keyboard will be
transmitted on the channel that is 1 channel higher than the
specified channel. For example, if the MIDI channel is set to
3, notes played in the lower section of the keyboard will be
transmitted on channel 4.
Notes played will be transmitted on two channels: the
specified channel and the channel that is 1 channel higher.
For example, if the MIDI channel is set to 3, notes played on
the keyboard will be transmitted on channels 3 and 4.
* If the specified MIDI channel is 16, the lower section / layered part will be transmitted on channel 1.
112
2 Send Program Change Number
The Send Program Change Number function is used to send a Program Change Number (1-128) to the connected
MIDI device.
1. Selecting the Send Program Change Number function
After entering the MIDI Settings menu (page 111):
Press the  or  buttons to select the Send Program Change
Number function.
2. Specifying and transmitting a Program Change Number
Press the  or  buttons to decrease or increase the Program
Change Number.
* The program change number can be set within the range of 1-128.
Press the
FUNCTION button (SEND) to send the specified
Program Change Number.
3. Exiting the Send Program Change Number function
Settings
Press the FUNCTION button (BACK) to exit the Send Program
Change Number function and return to the Function Menus
screen.
113
MIDI Settings
3 Local Control
The Local Control setting determines whether the instrument will play an internal sound when the keys are
pressed. This setting may be useful when using the CA97/CA67 digital piano to control an external MIDI device that
is connected to the instrument’s amplifier/speakers.
Local Control setting
Local Control
Description
Off
The instrument will transmit information to an external MIDI device only.
On (default)
The instrument will play an internal sound and transmit information to an external MIDI device.
1. Selecting the Local Control setting
After entering the MIDI Settings menu (page 111):
Press the  or  buttons to select the Local Control setting.
2. Changing the Local Control setting
Press the  or  buttons to turn the Local Control setting on
or off.
* To reset the Local Control setting to the default setting, press the
 and  buttons simultaneously.
* Any changes made to the Local Control setting will remain until the
power is turned off.
* Preferred Local Control settings can be stored to a Registration
memory for convenient recall. Please refer to page 77 for more
information.
Settings
3. Exiting the Local Control setting
Press the FUNCTION button (BACK) to exit the Local Control
setting and return to the Function Menus screen.
114
4 Transmit Program Change Numbers
The Transmit Program Change Numbers setting determines whether the CA97/CA67 digital piano will transmit
program change information via MIDI when the instrument’s panel buttons are pressed.
Transmit Program Change Numbers setting
Transmit PGM#
Multi-timbral setting
Effect of pressing panel buttons
On (default)
Off, On1
SOUND buttons will send PGM# shown in the left column*.
On
On2
SOUND buttons will send PGM# shown in the right column*.
Off
Off
Program Change information will not be transmitted via MIDI.
* Please refer to the ‘Program Change Number List’ on page 142.
1. Selecting the Transmit Program Change Numbers setting
After entering the MIDI Settings menu (page 111):
Press the  or  buttons to select the Transmit Program Change
Numbers setting.
2. Changing the Transmit Program Change Numbers setting
Press the  or  buttons to turn the Transmit Program Change
Numbers setting on or off.
* To reset the Transmit Program Change Numbers setting to the default
setting, press the  and  buttons simultaneously.
* Any changes made to the Transmit Program Change Numbers setting
will remain until the power is turned off.
Settings
* Preferred Transmit Program Change Numbers settings can be stored
to a Registration memory for convenient recall. Please refer to page
77 for more information.
3. Exiting the Transmit Program Change Numbers setting
Press the
FUNCTION button (BACK) to exit the Transmit
Program Change Numbers setting and return to the Function
Menus screen.
Omni mode
 When using Dual or Split mode, On/Off information and sound
type settings for are transmitted as exclusive data, however
program change numbers will not be transmitted.
 Program change numbers will also be transmitted when
Multi-timbral mode is set to On1 or On2.
115
MIDI Settings
5 Multi-timbral Mode
The Multi-timbral Mode setting determines whether or not the CA97/CA67 digital piano is able to receive MIDI
information on more than one MIDI channel simultaneously. This allows the instrument to play back multi-track,
multi-timbral performance data sent from an external MIDI device.
Multi-timbral Mode setting
Multi-timbral Mode
Selected sound
Off (default)
The sound shown in the left column is selected*.
On1
The sound shown in the left column is selected*.
On2
The sound shown in the right column is selected*.
* Please refer to the ‘Program Change Number List’ on page 142.
1. Selecting the Multi-timbral Mode setting
After entering the MIDI Settings menu (page 111):
Press the  or  buttons to select the Multi-timbral Mode
setting.
2. Changing the Multi-timbral Mode setting
Press the  or  buttons to change turn the Multi-timbral
Mode setting.
* To reset the Multi-timbral Mode setting to the default setting, press
the  and  buttons simultaneously.
* Any changes made to the Multi-timbral Mode setting will remain until
the power is turned off.
Settings
* Preferred Multi-timbral Mode settings can be stored to a Registration
memory for convenient recall. Please refer to page 77 for more
information.
3. Exiting the Multi-timbral Mode setting
Press the FUNCTION button (BACK) to exit the Multi-timbral
Mode setting and return to the Function Menus screen.
116
6 Channel Mute
The Channel Mute setting determines which MIDI channels (1-16) are activated to receive MIDI information when
Multi-timbral mode is enabled.
* This setting is only available when the Multi-timbral Mode setting is set to ‘On1’ or ‘On2’.
1. Selecting the Channel Mute setting
After entering the MIDI Settings menu (page 111):
Press the  or  buttons to select the Channel Mute setting.
Press the
FUNCTION button (EDIT).
The Channel Mute selection screen will be shown in the LCD
display.
2. Selecting and playing/muting channels
Press the  or  buttons to select the desired MIDI channel.
Press the  or  buttons to alternate between ‘Play’ and ‘Mute’
states.
* To reset the Channel Mute setting to the default value, press the
 and  buttons simultaneously.
* Any changes made to the Channel Mute setting will remain until the
power is turned off.
* Preferred Channel Mute settings can be stored to a Registration
memory for convenient recall. Please refer to page 77 for more
information.
3. Exiting the Channel Mute function
Settings
Press the FUNCTION button (BACK) to exit the Channel Mute
adjustment screen and return to the MIDI Settings menu.
117
USB MIDI (USB to Host connector)
The CA97/CA67 digital piano features a ‘USB to Host’ type connector, allowing the instrument to be connected to a
computer using an inexpensive USB cable and utilised as a MIDI device. Depending on the type of computer and
operating system installed, additional driver software may be required for USB MIDI communication to function
correctly.
USB MIDI driver
Operating System
Windows ME
Windows XP (no SP, SP1, SP2, SP3)
Windows XP 64-bit
Windows Vista (SP1, SP2)
Windows Vista 64-bit (SP1, SP2)
Windows 7 (no SP, SP1)
Windows 7 64-bit
Windows 8 / 8.1
Windows 8 / 8.1 64-bit
Windows 98 se
Windows 2000
Windows Vista (no SP)
USB MIDI Driver Support
Additional USB MIDI driver software NOT required.
The standard (built-in) Windows USB MIDI driver will be installed automatically when the
instrument is connected to the computer.
* After driver installation, ensure that the ‘USB Audio Device’ (Windows ME/Windows XP) or ‘USB-MIDI’
(Windows Vista/Windows 7/Windows 8) device is correctly selected in the application software.
Additional USB MIDI driver software required.
Please download the USB MIDI driver from the Kawai Japan website:
 http://www.kawai.co.jp/english
* After driver installation, ensure that the ‘KAWAI USB MIDI’ device is correctly selected in the application software.
Windows Vista 64-bit (no SP)
USB MIDI is not supported.
Please upgrade to service pack 1 or service pack 2.
Mac OS X
Additional USB MIDI driver software NOT required.
The standard (built-in) Mac OS X USB MIDI driver will be installed automatically when the
instrument is connected to the computer.
Mac OS 9
USB MIDI is not supported.
Please use the standard MIDI IN/OUT connectors.
USB MIDI information
 If the instrument’s MIDI IN/OUT jacks and USB MIDI port are
Settings
both connected simultaneously, the USB MIDI port will be
given priority.
 Ensure that the instrument is turned OFF before attempting
to connect the USB MIDI cable.

When connecting the instrument to a computer using
the USB MIDI port, there may be a short delay before
communications begin.
 If the instrument is connected to a computer via a USB hub
and USB MIDI communication becomes unreliable/unstable,
please connect the USB MIDI cable directly to the one of the
computer’s USB ports.
 Disconnecting the USB MIDI cable suddenly, or turning the
instrument on/off while using USB MIDI may cause computer
instability in the following situations:
– while installing the USB MIDI driver
– while starting up the computer
– while MIDI applications are performing tasks
– while the computer is in energy saver mode
 If there are any further problems experienced with USB MIDI
communication while the instrument is connected, please
double-check all connections and relevant MIDI settings in
the computer’s operating system.
* ‘MIDI’ is a registered trademark of the Association of Manufacturers of Electronic Instruments (AMEI).
* ‘Windows’ is registered trademark of Microsoft Corporation.
* ‘Macintosh’ is registered trademark of Apple Computer, Inc.
* Other company names and product names mentioned referenced herein may be registered trademarks or trademarks of respective owners.
118
USB Menu
The USB Menu contains functions to load/save registration memories and recorder songs from/to a USB memory
device. This menu also allows files to be renamed and deleted, and for the USB memory device to be formatted.
USB Menu functions
No.
Function
Description
1
Load Song
Load a recorder song from a USB memory device into the instrument’s internal memory.
2
Load Registration All
Load a file containing all registration memories from a USB memory device into the instrument.
3
Load Registration Single
Load a single registration memory from a USB memory device into the instrument.
4
Load Startup Setting
Load a Startup Settings file from a USB memory device into the instrument.
5
Save Internal Song
Save a recorder song stored in internal memory to a USB memory device as a Kawai song file.
6
Save SMF Song
Save a recorder song stored in internal memory to a USB memory device as an SMF (MIDI) file.
7
Save Registration All
Save a file containing all registration memories from the instrument to a USB memory device.
8
Save Registration Single
Save a single registration memory from the instrument to a USB memory device.
9
Save Startup Setting
Save the instrument’s current Startup Settings to a USB memory device.
10
Rename File
Rename a file stored on a USB memory device.
11
Delete File
Delete a file stored on a USB memory device.
12
Format USB
Format a USB memory device, erasing all stored data.
Entering the USB Menu menu
While the normal playing mode screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
The Function menus will be shown in the LCD display.
Press the  or  buttons to select the USB Menu.
FUNCTION button (ENTER) again to enter the USB
 buttons:
Move selection cursor.
Settings
Press the
Menu.
Selecting the desired USB Menu function
After entering the USB Menu:
Press the  or  buttons to move the selection cursor over the
desired function.
Press the
FUNCTION button (ENTER) to select the function.
 buttons:
Move selection cursor.
FUNCTION button:
Select function.
119
USB Menu
1 Load Song
The Load Song function is used to load CA97/CA67 recorder songs stored on a USB memory device into the
instrument’s internal memory.
* This function will overwrite any song data stored in the selected song memory.
* For more information about the instrument’s ‘Internal Song Recorder’ feature, please refer to page 48.
1. Selecting the Load Song function
After entering the USB Menu (page 119):
Press the  or  buttons to select the Load Song function.
2. Selecting the song memory
Press the  or  buttons to select the internal song memory for
the song to be loaded into.
* If a song memory contains song data, a * symbol will be shown.
Press the
FUNCTION button (ENTER).
Song has been recorded
The file selection screen will be shown in the LCD display, listing
CA97/CA67 song files stored on the USB memory device.
3. Selecting the song to be loaded
Press the  or  buttons to move the selection cursor, then
press the FUNCTION button (LOAD) to select the song file.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the load operation.
Settings
4. Confirming the load operation
Press the
FUNCTION button (YES) to confirm the load
operation, or the FUNCTION button (NO) to cancel.
5. Exiting the Load Song function
Press the
FUNCTION button (BACK) to exit the Load Song
function and return to the Function Menus screen.
To play back the loaded song file, please refer to the ‘Playing a
Song’ instructions on page 50.
120
2 Load Registration All
The Load Registration All function is used to load a file containing all 16 CA97/CA67 registrations, stored on a USB
memory device into the instrument’s registration memories.
* This function will overwrite all existing Registration memories.
* For more information about the instrument’s Registration feature, please refer to page 32.
1. Selecting the Load Registration All function
After entering the USB Menu (page 119):
Press the  or  buttons to select the Load Registration All
function.
Press the
FUNCTION button (ENTER).
The file selection screen will be shown in the LCD display, listing
CA97/CA67 registration files stored on the USB memory device.
2. Selecting the registration file to be loaded
Press the  or  buttons to move the selection cursor, then
press the FUNCTION button (LOAD) to select the registration
file.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the load operation.
3. Confirming the load operation
Press the
FUNCTION button (YES) to confirm the load
operation, or the FUNCTION button (NO) to cancel.
Settings
4. Exiting the Load Registration All function
Press the
FUNCTION button (BACK) to exit the Load
Registration All function and return to the Function Menus
screen.
To use the loaded registrations, please refer to the Registration
instructions on page 32.
121
USB Menu
3 Load Registration Single
The Load Registration Single function is used to load a single CA97/CA67 registration file stored on a USB memory
device into one of the instrument’s registration memories.
* This function will overwrite the selected Registration memory.
* For more information about the instrument’s Registration feature, please refer to page 32.
1. Selecting the Load Registration Single function
After entering the USB Menu (page 119):
Press the  or  buttons to select the Load Registration Single
function.
2. Selecting the registration memory
Press the  or  buttons to select the registration memory for
the new registration to be loaded into.
Press the
FUNCTION button (ENTER).
The file selection screen will be shown in the LCD display, listing
CA97/CA67 song files stored on the USB memory device.
3. Selecting the registration file to be loaded
Press the  or  buttons to move the selection cursor, then
press the FUNCTION button (LOAD) to select the registration
file.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the load operation.
Settings
4. Confirming the load operation
Press the
FUNCTION button (YES) to confirm the load
operation, or the FUNCTION button (NO) to cancel.
5. Exiting the Load Registration Single function
Press the
FUNCTION button (BACK) to exit the Load
Registration Single function and return to the Function Menus
screen.
To play back the loaded song file, please refer to the ‘Playing a
Song’ instructions on page 50.
122
4 Load Startup Setting
The Load Startup Setting function is used to load a CA97/CA67 startup setting file stored on a USB memory device
into the instrument’s startup memory. The loaded settings will be used as the default settings every time the CA97/
CA67 digital piano is turned on.
* This function will overwrite the previously stored Startup Settings memory.
* For more information about the instrument’s Startup Setting feature, please refer to page 77.
1. Selecting the Load Startup Setting function
After entering the USB Menu (page 119):
Press the  or  buttons to select the Load Startup Setting
function.
Press the
FUNCTION button (ENTER).
The file selection screen will be shown in the LCD display, listing
CA97/CA67 startup settings files stored on the USB memory
device.
2. Selecting the startup settings file to be loaded
Press the  or  buttons to move the selection cursor, then
press the
FUNCTION button (LOAD) to select the startup
settings file.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the load operation.
3. Confirming the load operation
Settings
Press the
FUNCTION button (YES) to confirm the load
operation, or the FUNCTION button (NO) to cancel.
4. Exiting the Load Startup Setting function
Press the FUNCTION button (BACK) to exit the Load Startup
Setting function and return to the Function Menus screen.
123
USB Menu
5 Save Internal Song
The Save Internal Song function is used to save CA97/CA67 recorder songs stored in the instrument’s internal
memory to a USB memory device in Kawai’s native song format.
* Songs saved in the native Kawai song format can be later reloaded into the instrument’s internal recorder memory.
* For more information about the instrument’s ‘Internal Song Recorder’ feature, please refer to page 48.
1. Selecting the Save Song function
After entering the USB Menu (page 119):
Press the  or  buttons to select the Save Song function.
2. Selecting the song memory to be saved
Press the  or  buttons to select the internal song memory
to be saved.
* If a song memory contains song data, a * symbol will be shown.
Press the
FUNCTION button (ENTER).
Song has been recorded
The filename input screen will be shown in the LCD display.
3. Naming the song
Press the  or  buttons to cycle through the alphanumeric
characters, and the  or  buttons to move the cursor.
Press the FUNCTION button (SAVE) to save the song, or the
FUNCTION button (BACK) to cancel.
Settings
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the save operation.
4. Confirming the save operation
Press the
FUNCTION button (YES) to confirm the save
operation, or the FUNCTION button (NO) to cancel.
* The song file will be saved in the root folder of the USB memory
device. It is not possible to save the file in a different folder.
5. Exiting the Save Song function
Press the
FUNCTION button (BACK) to exit the Save Song
function and return to the Function Menus screen.
124
6 Save SMF Song
The Save SMF Song function is used to save CA97/CA67 recorder songs stored in the instrument’s internal memory
to a USB memory device as a Standard MIDI File (SMF).
* Songs saved in SMF format cannot be later reloaded into the instrument’s internal recorder memory.
* For more information about the instrument’s ‘Internal Song Recorder’ feature, please refer to page 48.
1. Selecting the Save SMF Song function
After entering the USB Menu (page 119):
Press the  or  buttons to select the Save SMF Song function.
2. Selecting the song memory to be saved
Press the  or  buttons to select the internal song memory
to be saved.
* If a song memory contains song data, a * symbol will be shown.
Press the
FUNCTION button (ENTER).
Song has been recorded
The filename input screen will be shown in the LCD display.
3. Naming the SMF song
Press the  or  buttons to cycle through the alphanumeric
characters, and the  or  buttons to move the cursor.
Press the FUNCTION button (SAVE) to save the song, or the
FUNCTION button (BACK) to cancel.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the save operation.
Settings
4. Confirming the save operation
Press the
FUNCTION button (YES) to confirm the save
operation, or the FUNCTION button (NO) to cancel.
* The SMF song file will be saved in the root folder of the USB memory
device. It is not possible to save the file in a different folder.
5. Exiting the Save SMF Song function
Press the FUNCTION button (BACK) to exit the Save SMF Song
function and return to the Function Menus screen.
125
USB Menu
7 Save Registration All
The Save Registration All function is used to save a file containing all CA97/CA67 registration memories stored in
the instrument to a USB memory device.
* For more information about the instrument’s ‘Registration’ feature, please refer to page 32.
1. Selecting the Save Registration All function
After entering the USB Menu (page 119):
Press the  or  buttons to select the Save Registration All
function.
Press the
FUNCTION button (ENTER).
The filename input screen will be shown in the LCD display.
2. Naming the Registrations file
Press the  or  buttons to cycle through the alphanumeric
characters, and the  or  buttons to move the cursor.
Press the
file, or the
FUNCTION button (SAVE) to save the registration
FUNCTION button (BACK) to cancel.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the save operation.
3. Confirming the save operation
Press the
FUNCTION button (YES) to confirm the save
operation, or the FUNCTION button (NO) to cancel.
Settings
* The registration file will be saved in the root folder of the USB memory
device. It is not possible to save the file in a different folder.
4. Exiting the Save Registration All function
Press the
FUNCTION button (BACK) to exit the Save
Registration All function and return to the Function Menus
screen.
126
8 Save Registration Single
The Save Registration Single function is used to save a single CA97/CA67 registration memory stored in the
instrument to a USB memory device.
* For more information about the instrument’s Registration feature, please refer to page 32.
1. Selecting the Save Registration Single function
After entering the USB Menu (page 119):
Press the  or  buttons to select the Save Registration Single
function.
2. Selecting the registration memory to be saved
Press the  or  buttons to select the registration memory to
be saved.
Press the
FUNCTION button (ENTER).
The filename input screen will be shown in the LCD display.
3. Naming the registration file
Press the  or  buttons to cycle through the alphanumeric
characters, and the  or  buttons to move the cursor.
Press the FUNCTION button (SAVE) to save the registration
memory, or the FUNCTION button (BACK) to cancel.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the save operation.
4. Confirming the save operation
Settings
Press the
FUNCTION button (YES) to confirm the save
operation, or the FUNCTION button (NO) to cancel.
* The registration file will be saved in the root folder of the USB memory
device. It is not possible to save the file in a different folder.
5. Exiting the Save Registration Single function
Press the FUNCTION button (BACK) to exit the Save Registration
Single function and return to the Function Menus screen.
127
USB Menu
9 Save Startup Setting
The Save Startup Setting function is used to save the current CA97/CA67 Startup Settings to a USB memory device.
* For more information about the instrument’s ‘Startup Setting’ feature, please refer to page 77.
1. Selecting the Save Startup Setting function
After entering the USB Menu (page 119):
Press the  or  buttons to select the Save Startup Setting
function.
Press the
FUNCTION button (ENTER).
The filename input screen will be shown in the LCD display.
2. Naming the Startup Setting file
Press the  or  buttons to cycle through the alphanumeric
characters, and the  or  buttons to move the cursor.
Press the
FUNCTION button (SAVE) to save the startup
settings file, or the FUNCTION button (BACK) to cancel.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the save operation.
3. Confirming the save operation
Press the
FUNCTION button (YES) to confirm the save
operation, or the FUNCTION button (NO) to cancel.
Settings
* The startup settings file will be saved in the root folder of the USB
memory device. It is not possible to save the file in a different folder.
4. Exiting the Save Startup Setting function
Press the FUNCTION button (BACK) to exit the Save Startup
Setting function and return to the Function Menus screen.
128
10 Rename File
The Rename File function is used to rename song, audio, and registration files stored on a USB memory device.
1. Selecting the Rename File function
After entering the USB Menu (page 119):
Press the  or  buttons to select the Rename File function.
Press the
FUNCTION button (ENTER).
The file selection screen will be shown in the LCD display, listing
files stored on the USB memory device.
2. Selecting the file to be renamed
Press the  or  buttons to move the selection cursor, then
press the FUNCTION button (RENAME) to select the file to be
renamed.
The filename input screen will be shown in the LCD display.
3. Renaming the selected file
Press the  or  buttons to cycle through the alphanumeric
characters, and the  or  buttons to move the cursor.
Press the FUNCTION button (RENAME) to rename the file, or
the FUNCTION button (BACK) to cancel.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the rename operation.
4. Confirming the rename operation
Settings
Press the
FUNCTION button (YES) to confirm the rename
operation, or the FUNCTION button (NO) to cancel.
5. Exiting the Rename File function
Press the FUNCTION button (BACK) to exit the Rename File
function and return to the Function Menus screen.
129
USB Menu
11 Delete File
The Delete File function is used to delete song, audio, and registration files stored on a USB memory device.
Once a file has been deleted from the USB device it cannot be recovered.
1. Selecting the Delete File function
After entering the USB Menu (page 119):
Press the  or  buttons to select the Delete File function.
Press the
FUNCTION button (ENTER).
The file selection screen will be shown in the LCD display, listing
files stored on the USB memory device.
2. Selecting the file to be deleted
Press the  or  buttons to move the selection cursor, then
press the FUNCTION button (OK) to delete the file.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the delete operation.
3. Confirming the delete operation
Press the
FUNCTION button (YES) to confirm the delete
operation, or the FUNCTION button (NO) to cancel.
4. Exiting the Delete File function
Settings
Press the
FUNCTION button (BACK) to exit the Delete File
function and return to the Function Menus screen.
130
12 Format USB
The Format USB function is used to format the connected USB memory device, erasing all stored data.
The USB Format function will erase all data stored on the connected USB memory device.
Exercise caution when using this function in order to prevent accidental data loss.
1. Selecting the Format USB function
After entering the USB Menu (page 119):
Press the  or  buttons to select the Format USB function.
Press the
FUNCTION button (ENTER).
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the format operation.
2. Confirming the format operation
Press the
FUNCTION button (YES) to confirm the format
operation, or the FUNCTION button (NO) to cancel.
3. Exiting the Format USB function
Settings
Press the FUNCTION button (BACK) to exit the Format USB
function and return to the Function Menus screen.
131
Assembly Instructions (CA67 only)
Please read these assembly instructions thoroughly before attempting to assemble the CA67 digital piano.
Please ensure that two or more people work on assembling the CA67 digital piano, especially when lifting the
main body of the instrument onto the stand.
Included parts
Before attempting to assemble the CA67 digital piano, ensure that all parts below are included.
A Phillips-head screwdriver (not included) will also be required in order to assemble the instrument.
A
Side panel (left)
D
E
Pedal board
(including adjustor bolt)
Back board
Screw (with washer) x 2
Flat headed screw (20mm) x 2
Tapping screw (black, 30 mm) x 4
Tapping screw (black, 20 mm) x 4
Appendix
C
Main body
Screw set
Tapping screw (silver, 16 mm) x 4
132
B
Side panel (right)
Power cable
Headphone hook set
Headphone hook
Mounting screws (14 mm) x 2
1. Attaching the side panels to the pedal board
Unfasten and extend the pedal connection cable attached
to the bottom of the pedal board (D).
Attach the pedal board (D) to the left (B) and right (C) side
panels using the temporary mounting screws located on
either end of the pedal board.
Ensure that the pedal board and side panels make close
contact, and that there are no large gaps between the
assembled parts.
Insert the four short silver tapping screws into the holes as
shown, and securely fasten the pedal board to the left and
right side panels.
B
2. Attaching the back board
Allow the assembled pedal board and side panels to stand
upright (vertically) on the floor.
* Ensure that the adjustor bolt is attached to the pedal board.
Loosely attach the back board (E) to the left and right side
panels using the four long black tapping screws .
Loosely attach the back board to the pedal board using the
four mid-length black tapping screws .
Adjust the positioning of the pedal board, side panels, and
backboard to ensure that all parts are in alignment, then
tighten the screws in steps and .
B
D
D
adjustor bolt
gap
B
D
D
C
E
pedal cable
B
C
D
B
B
D
not aligned
temporary
mounting
screw
Appendix
B
133
Assembly Instructions (CA67 only)
3. Mounting the main body onto the stand
Ensure that two or more people undertake the
following step of the assembly process.
Lift the main body and carefully place it onto the stand.
Position the main body slightly towards the back of the
stand, to ensure that the guide screw in the front of the
stand is still visible.
Gently slide the main body forward until it comes to a halt.
When positioned correctly, the attachment screw holes
should be visible from the underside of the main unit.
* If the screw holes are not visible, re-adjust (loosen) the screws
attached in step 4-2.
When lifting the main body onto the stand, be
careful not to catch/trap hands and fingers.
4. Fastening the main body to the stand
View the front of the instrument to ensure that the main
body and side panels are in alignment.
* If the parts are not in alignment, re-adjust (loosen) the screws
attached in step 4-2.
Loosely fasten the front of the main body to the stand from
below, using the two screws (with washer) on either side.
Loosely fasten the rear of the main body to the stand from
below, using the two flat headed screws on either side.
When all four screws are attached and the main body is
correctly positioned on top of the stand, securely tighten
all screws.
Tighten all screws securely to ensure that the
main body is firmly attached to the stand.
Front view
A
A
B
C
C
A
Appendix
B
134
A
5. Connecting the pedal and power cables
6. Attaching the headphone hook (optional)
Pass the pedal cable (extending from the rear of the pedal
board) through the aperture to the front of the main body,
and connect to the PEDAL terminal.
Connect the power cable to the AC IN terminal on the
underside of the main body, then pass the cable through the
back board aperture, and out to the rear of the instrument.
A headphone hook is included with the CA97/CA67 digital piano
and can be used to hang headphones when not in use.
If desired, attach the headphone hook to the underside of
the main body using the two tapping screws provided.
With the power and pedal cables connected, use the binders
to fix the cables in place and tidy their appearance.
A
7. Adjusting the pedal support bolt
C
Turn the pedal support bolt anti-clockwise, extending the
bolt until it makes contact with the floor and supports the
pedals firmly.
When moving the instrument, always adjust or
remove the pedal support bolt, then readjust
when the instrument is in its new position.
Appendix
B
135
Connecting to Other Devices
The CA97/CA67 digital piano features a variety of jacks that allow the instrument to be connected to MIDI devices,
computers, speakers, and mixers. It is also possible to connect external audio sources, such as an MP3 player,
tablet, or a secondary keyboard, to the instrument’s amplifier and speaker system. The illustration below provides
a visual overview of the connectors and their typical applications.
USB type ‘B’
USB type ‘A’
Connect the audio from
other devices to the
instrument’s speakers.
Connect the instrument
to external speakers,
amplifiers, mixers, etc.
Connect the instrument
to a computer or tablet to
send or receive MIDI data.
Connect the instrument
to MIDI modules, other
instruments/devices, etc.
Appendix
Before connecting the CA97/CA67 digital piano to other devices, ensure that the power to both the instrument
and the other device is turned off. If connections are established while the power is turned on, extraneous
noise that can damage the CA97/CA67 digital piano may activate the instrument’s amplifier protection circuit,
preventing any sound from being produced. If this occurs, turn the power off and then on again to reset the
amplifier protection circuit.
Do not connect the LINE IN and LINE OUT jacks of the CA97/CA67 digital piano together with the same cable. An
audio loop (oscillation sound) will occur, resulting in damage to the unit.
136
Jack Panel
LINE IN STEREO jack (1/8” phone jack)
LINE OUT jacks (1/4” phone jack)
This jack is used to connect the 1/8” stereo outputs from
smart phones, tablets, computers, or other electronic audio
equipment to the CA97/CA67 digital piano’s amplifier and
speakers. The input level can be adjusted using the LEVEL knob,
or by adjusting the volume of the connected device.
These jacks are used to connect the stereo output of the CA97/
CA67 digital piano’s sound to external speakers, amplifiers,
mixers, recording devices, and similar equipment.
When using the USB audio recorder function, this LINE in audio
will also be mixed with the instrument’s internal sound and
recorded to the MP3/WAV file.
To output a mono signal, connect a single cable to the L/MONO
jack.
The output level can be adjusted using the LEVEL knob. The
MASTER VOLUME slider does not affect the LINE OUT level.
* The ‘Line In Level’ setting can also be used to adjust the level of the
LINE IN signal. Please refer to page 70 for more information.
USB to Host port (‘B’ type)
MIDI IN/OUT jacks
This USB port is used to connect the CA97/CA67 digital piano to
a computer using an inexpensive USB cable. When connected,
the instrument can be used as a standard MIDI device, allowing it
to send a receive MIDI data. Connect a ‘B’ type USB connector to
the instrument, and an ‘A’ type USB connector to the computer.
These jacks are used to connect the CA97/CA67 digital piano
to external MIDI devices, or to a computer (using a USB-MIDI
interface) as an alternative to the ‘USB to Host’ port.
* Please refer to page 110 for more information about MIDI.
* Please refer to page 118 for more information about USB MIDI.
With additional conversion adaptors, this port may also be used
to connect the CA97/CA67 digital piano to tablets such as the
Apple iPad and other mobile devices.
Headphone Panel
PHONES jacks (1/4” & 1/8” phone jacks)
USB to Device port (‘A’ type)
These jacks are used to connect stereo headphones to the CA97/
CA67 digital piano. Two pairs of headphones can be connected
and used simultaneously. When a pair of headphones is
connected, sound will not be produced by the speakers.
This USB port is used to connect a USB memory device to the
CA97/CA67 digital piano. This allows MP3/WAV audio files, and
SMF song files to be played directly. It is also possible to record
performances to MP3/WAV audio files, and save recorder songs
stored in internal memory for posterity.
 The ‘USB to Device’ functionality of the CA97/CA67 digital
 It may be necessary to format the USB memory device before

 Avoid removing the USB memory device while data is being
piano conforms to USB2.0 Hi-Speed standards. Older USB
devices can still be used, however data transfer speed will be
limited to the maximum transfer speed of the device.
The ‘USB to Device’ port is intended for connecting USB
memory devices, however USB floppy drive devices can also
be used to save recorder songs stored in internal memory, or
play SMF song files.
it can be used with the CA97/CA67 digital piano. If so, please
refer to the USB Format function instructions on page 131.
Formatting the device will erase all data.
loaded or saved, files are being renamed or deleted, or the
device is being formatted.

Other USB devices, such as computer mice, keyboards, or
battery chargers etc. cannot be used with this instrument.
137
Appendix
USB device information
Troubleshooting
The tables below summarise issues that may be experienced with the CA97/CA67 digital piano, explaining the
typical cause(s), and recommended solution(s).
Power
Issue
Possible Cause and Solution
Page no.
The instrument does not turn on.
Check that the power cable is firmly attached to the instrument, and
connected to an AC outlet.
p. 14
The instrument turns itself off after a period
of inactivity.
Check that the ‘Auto Power Off’ function is not enabled.
p. 79
Sound
Issue
The instrument is turned on, however no sound
is produced when the keys are pressed.
The sound distorts when playing at very loud
volume levels.
Possible Cause and Solution
Page no.
Check that the MASTER VOLUME slider is not set to the lowest position.
p. 15
Check that a pair of headphones (or headphone adaptor plug) are not
connected to the PHONES jacks.
p. 15
Check that the ‘Local Control’ setting in the MIDI Settings menu is set to On.
p. 114
Check that the MASTER VOLUME slider is set to an appropriate level,
reducing the volume if excessive distortion is heard.
p. 15
If connecting the instrument to an amplifier/mixer using the Line Out
jacks, reduce the value of the ‘Line Out Volume’ setting in the Basic
Settings menu
Strange sounds or noises are heard when
playing with piano sounds.
The CA97/CA67 digital piano attempts to reproduce the rich variety of
tones created by an acoustic grand piano as accurately as possible. This
includes various resonances, noises, and other subtle characteristics that
contribute to the overall piano playing experience.
p. 80
While these additional tones are intended to enhance the realism of
the instrument, it is possible to reduce their prominence, or disable the
effects altogether using the settings in the Virtual Technician menu.
The top 18 notes of the keyboard sustain for
longer than neighbouring notes, even when the
damper pedal is not pressed.
This is the correct behaviour, and intended to reproduce the undamped
notes (typically the top two octaves) of an acoustic grand piano.
–
The volume of the device connected to the Line
In jacks is too low/too high (distorted).
Check the position of the Line In LEVEL knob (located on the jack panel),
and adjust as necessary.
p. 137
Pedals
Appendix
Issue
138
Possible Cause and Solution
Page no.
The pedals are unreliable or do not function
at all.
Check that the pedal cable is firmly connected to the instrument
(CA67 only).
p. 135
When depressing a pedal, the pedal board
flexes and is not firm.
Check that the pedal support bolt is fully extended.
p. 135
Headphones
Issue
Possible Cause and Solution
Page no.
The headphone volume is too low.
If the ‘Nominal Impedance’ specification of the headphones is less
than 100 Ω (ohms), set the ‘Phones Volume’ setting in the Phones
Settings menu to High.
p. 109
The headphone output sounds strange.
Check that the ‘SHS Mode’ and ‘Phones Type’ settings are set to
‘Normal’.
p. 107
p. 108
USB (memory device)
Issue
Possible Cause and Solution
Page no.
p. 137
A USB memory device is not detected, cannot be
saved to, or does not appear to function when
connected to the ‘USB to Device’ port.
Check that the USB memory device is formatted to use the FAT/FAT32
filesystem, and not set to ‘Write Protect’ mode.
Disconnect the USB memory device, turn the instrument off then on, then
reconnect the USB device. If the USB device still does not function, it may
be damaged or incompatible. Please try using a different USB device.
–
The instrument pauses briefly when connecting
a USB memory device.
This is recognised behaviour when using large capacity (e.g. 8GB+) USB
memory devices.
–
USB (MIDI)
Issue
The instrument is connected to the computer
using a USB cable, however the software does
not respond to key presses.
Possible Cause and Solution
Page no.
Check that a USB MIDI driver is installed on the computer.
p. 118
Check that ‘USB Audio Device’ or ‘KAWAI USB MIDI’ is selected in the
software’s input/output device settings.
p. 118
MP3/WAV/SMF files
Possible Cause and Solution
Page no.
No sound can be heard when playing an MP3
or WAV audio file stored on a USB memory
device.
Check that the audio player volume is not set to 0.
p. 57
Check that the format of the audio file is supported and listed in the
‘Audio Player supported format specifications’ table.
p. 56
An MP3/WAV audio file stored on a USB
memory device sounds strange, or does not
play back correctly.
Check that the format of the audio file is supported and listed in the
‘Audio Player supported format specifications’ table.
p. 56
The file transfer speed of the USB memory device may be too slow to
play the audio file. Please try using a different USB memory device,
ensuring that it conforms to USB2.0 Hi-Speed standards.
p. 137
When recording MP3/WAV audio files, the
volume is too low/too high (distorted).
Check the gain setting before recording the audio, and if necessary
adjust to increase/decrease the recording level.
p. 54
An SMF MIDI file stored on a USB memory
device sounds strange when played back.
The CA97/CA67 digital piano does not contain the full General MIDI
sound bank selection. Consequently, some SMF song files may not be
reproduced entirely accurately when played through the instrument.
p. 59
Appendix
Issue
139
sectionSong List
Demo
Sound Name
Song Title
Composer
SK Concert Grand
Grande Polonaise Brillante Op.22
Chopin
EX Concert Grand
Polonaise-Fantaisie
Chopin
SK-5 Grand
Lieder Ohne Worte No.18 “Duetto”
Mendelssohn
Jazz Clean
Original
Kawai
Warm Grand
Sonata No.30 Op.109
Beethoven
Warm Grand 2
La Fille aux Cheveux de lin
Debussy
Standard Grand
Petit chien
Chopin
Pop Grand
Original
Kawai
Pop Piano
Original
Kawai
New Age Grand *
Original
Kawai
Upright Piano
Alpenglühen Op.193
Oesten
Modern Piano
Original
Kawai
Classic E.Piano
Original
Kawai
Modern E.P.
Original
Kawai
Modern E.P. 2 *
Original
Kawai
Jazz Organ
Original
Kawai
Blues Organ
Original
Kawai
Drawbar Organ
Original
Kawai
Church Organ
Chorale Prelude “Wachet auf, ruft uns die Stimme.”
Bach
Diapason
Wohl mir, daβ ich Jesum have
Bach
Full Ensemble
Original
Kawai
Harpsichord
French Suite No.6
Bach
Harpsichord Oct.
Prelude in Ab
Bach
Vibraphone
Original
Kawai
Clavi
Original
Kawai
Slow Strings
Original
Kawai
String Pad
Original
Kawai
String Ensemble
Le quattro stagioni: La primavera
Vivaldi
Choir
Londonderry Air
Irish folk song
Choir 2
Original
Kawai
Jazz Ensemble
Original
Kawai
New Age Pad
Original
Kawai
Atmosphere
Original
Kawai
Wood Bass
Original
Kawai
Finger Bass
Original
Kawai
Fretless Bass
Original
Kawai
W. Bass & Ride
Original
Kawai
Ballad Guitar
Original
Kawai
Pick Nylon Gt.
Original
Kawai
PIANO 1
PIANO 2
E. PIANO
ORGAN
HARPSI & MALLETS
STRINGS
Appendix
VOCAL & PAD
BASS & GUITAR
140
* CA97 only.
PIANO 1
HARPSI & MALLETS
SK ConcertGrand
Harpsichord
EX ConcertGrand
Harpsichord Oct
SK-5 GrandPiano
Vibraphone
Jazz Clean
Clavi
Jazz Old School *
Marimba
Warm Grand
Celesta
Warm Grand 2
Harpsichord 2 *
Standard Grand
Bell Split *
PIANO 2
STRINGS
Pop Grand
Slow Strings
Pop Grand 2
String Pad
Pop Piano
Warm Strings
New Age Grand *
String Ensemble
Upright Piano
Soft Orchestra
Modern Piano
Chamber Strings *
Boogie Piano *
Harp
Honky Tonk *
Pizzicato Str. *
E. PIANO
VOCAL & PAD
Classic E. Piano
Choir
60’s E.P.
Pop Ooh
Modern E.P.
Pop Aah
Classic E.P. 2
Choir 2
New Age E.P.
Jazz Ensemble
Crystal E.P.
Pop Ensemble
Modern E.P. 2 *
Slow Choir *
Modern E.P. 3 *
Breathy Choir *
ORGAN
New Age Pad
Jazz Organ
Atmosphere
Blues Organ
Itopia
Ballad Organ
Brightness
Gospel Organ
New Age Pad 2 *
Drawbar Organ
Brass Pad
Drawbar Organ 2
Bowed Pad
Drawbar Organ 3 *
Bright Warm Pad *
Drawbar Organ 4 *
BASS & GUITAR
Church Organ
Wood Bass
Diapason
Finger Bass
Full Ensemble
Fretless Bass
Diapason Oct.
W. Bass & Ride
Chiffy Tibia
E. Bass & Ride *
Principal Oct.
Ballad Guitar
Principal Choir *
Pick Nylon Gt.
Baroque *
Finger Nylon Gt *
Appendix
sectionList
Sound
* CA97 only.
141
Program Change Number List
Multi-timbral mode = off/on1
Sound Name
Program Number
Multi-timbral mode = on2
Program Number
CA97
CA67
SK ConcertGrand
1
1
EX ConcertGrand
2
SK-5 GrandPiano
Bank
MSB
LSB
1
121
0
2
1
95
27
3
3
1
95
30
PIANO 1
Jazz Clean
4
4
1
121
1
Jazz Old School
5
-
1
95
32
Warm Grand
6
5
1
121
2
Warm Grand 2
7
6
1
95
29
Standard Grand
8
7
1
95
16
Pop Grand
9
8
1
95
28
PIANO 2
Pop Grand 2
10
9
1
95
31
Pop Piano
11
10
2
95
10
New Age Grand
12
-
1
95
17
Upright Piano
13
11
1
95
25
Modern Piano
14
12
2
121
0
Boogie Piano
15
-
1
95
33
Honky Tonk
16
-
4
121
0
Classic E. Piano
17
13
5
121
0
60’s E.P.
18
14
5
121
3
Modern E.P.
19
15
6
121
0
E. PIANO
Classic E.P. 2
20
16
5
121
1
New Age E.P.
21
17
6
95
2
Crystal E.P.
22
18
6
95
1
Modern E.P. 2
23
-
6
121
1
Modern E.P. 3
24
-
6
121
2
Jazz Organ
25
19
18
121
0
Appendix
ORGAN
142
Blues Organ
26
20
17
121
0
Ballad Organ
27
21
17
95
5
Gospel Organ
28
22
17
95
3
Drawbar Organ
29
23
17
95
1
Drawbar Organ 2
30
24
17
95
2
Drawbar Organ 3
31
-
18
121
2
Drawbar Organ 4
32
-
17
121
3
Church Organ
33
25
20
121
0
Diapason
34
26
20
95
7
Full Ensemble
35
27
21
95
1
Diapason Oct.
36
28
20
95
6
Chiffy Tibia
37
29
20
95
17
Principal Oct.
38
30
20
95
24
Principal Choir
39
-
20
95
23
Baroque
40
-
20
95
19
Multi-timbral mode = off/on1
Sound Name
Program Number
Multi-timbral mode = on2
Program Number
CA97
CA67
Harpsichord
41
31
Harpsichord Oct
42
Vibraphone
Bank
MSB
LSB
7
121
0
32
7
121
1
43
33
12
121
0
HARPSI & MALLETS
Clavi
44
34
8
121
0
Marimba
45
35
13
121
0
Celesta
46
36
9
95
1
Harpsichord 2
47
-
7
121
3
Bell Split
48
-
15
95
5
Slow Strings
49
37
45
95
1
STRINGS
String Pad
50
38
49
95
8
Warm Strings
51
39
49
95
1
String Ensemble
52
40
49
121
0
Soft Orchestra
53
41
50
95
1
Chamber Strings
54
-
49
95
14
Harp
55
42
47
121
0
Pizzicato Str.
56
-
46
121
0
Choir
57
43
53
121
0
Pop Ooh
58
44
54
95
39
Pop Aah
59
45
54
95
40
CHOIR & PAD
Choir 2
60
46
54
95
53
Jazz Ensemble
61
47
54
95
2
Pop Ensemble
62
48
54
95
7
Slow Choir
63
-
53
95
2
Breathy Choir
64
-
53
95
1
New Age Pad
65
49
89
121
0
Atmosphere
66
50
100
121
0
Itopia
67
51
92
121
1
Brightness
68
52
101
95
1
New Age Pad 2
69
-
89
95
2
Brass Pad
70
53
62
95
2
Bowed Pad
71
54
93
121
0
Bright Warm Pad
72
-
90
95
1
73
55
33
121
0
Wood Bass
Finger Bass
74
56
34
121
0
Fretless Bass
75
57
36
121
0
W. Bass & Ride
76
58
33
95
1
E. Bass & Ride
77
-
34
95
2
Ballad Guitar
78
59
26
95
6
Pick Nylon Gt.
79
60
25
95
3
Finger Nylon Gt
80
-
25
95
4
Appendix
BASS & GUITAR
143
Drum Rhythm List
No.
Rhythm Name
Appendix
8 Beat
1
8 Beat 1
2
8 Beat 2
3
8 Beat 3
4
Pop 1
5
Pop 2
6
Pop 3
7
Pop 4
8
Pop 5
9
Pop 6
10
Ride Beat 1
11
Ride Beat 2
12
Dance Pop 1
13
Country Pop
14
Smooth Beat
15
Rim Beat
8 Beat Rock
16
Modern Rock 1
17
Modern Rock 2
18
Modern Rock 3
19
Modern Rock 4
20
Pop Rock
21
Ride Rock
22
Jazz Rock
23
Surf Rock
16 Beat
24
16 Beat
25
Indie Pop 1
26
Acid Jazz 1
27
Ride Beat 3
28
Dance Pop 2
29
Dance Pop 3
30
Dance Pop 4
31
Dance Pop 5
32
Dance Pop 6
33
Dance Pop 7
34
Dance Pop 8
35
Indie Pop 2
36
Cajun Rock
8 Beat Ballad
37
Pop Ballad 1
38
Pop Ballad 2
39
Pop Ballad 3
40
Rock Ballad 1
41
Rock Ballad 2
42
Slow Jam
43
6/8 R&B Ballad
44
Triplet Ballad 1
45
Triplet Ballad 2
16 Beat Ballad
46
16 Ballad 1
47
Dance Ballad 1
48
Dance Ballad 2
49
Dance Ballad 3
50
Electro Pop
51
16 Ballad 2
52
Mod Pop Ballad
144
No.
Rhythm Name
16 Beat Dance
53
Dance 1
54
Dance 2
55
Dance 3
56
Disco
57
Techno 1
58
Techno 2
16 Beat Swing
59
16 Shuffle 1
60
16 Shuffle 2
61
16 Shuffle 3
62
Acid Jazz 2
63
Acid Jazz 3
64
New Jack Swing
65
Modern Dance
66
Indie Pop 3
8 Beat Swing
67
Swing Beat
68
Motown
69
Country 2 Beat
70
Boogie
Triplet
71
8 Shuffle 1
72
8 Shuffle 2
73
8 Shuffle 3
74
Dance Shuffle
75
Triplet 1
76
Triplet 2
77
Triplet Rock
78
Reggae
Jazz
79
H.H. Swing
80
Ride Swing
81
Fast 4 Beat
82
Afro Cuban
83
Jazz Bossa
84
Jazz Waltz
85
5/4 Swing
Latin / Traditional
86
H.H. Bossa Nova
87
Ride Bossa Nova
88
Beguine
89
Rhumba
90
Cha Cha
91
Mambo
92
Samba
93
Sala
94
Merenge
95
Tango
96
Habanera
97
Waltz
98
Ragtime
99
March
100
6/8 March
section
Specifications
CA97
Sound Source
88 wooden keys with Ivory and Ebony Touch key surfaces
Grand Feel II (GFII) action with Let-Off, Triple Sensor, and Counterweights
Harmonic Imaging™ XL (HI-XL), 88-key piano sampling
Internal Sounds
Polyphony
Keyboard Modes
Reverb
80 voices
max. 256 notes
Dual Mode, Split Mode, Four Hands Mode (Volume/Balance adjustable)
Type:
Room, Lounge, Small Hall, Concert Hall, Live Hall, Cathedral
Parameters:
Effects
Reverb Depth, Reverb Time
Type:
Mono Delay, Ping Delay, Triple Delay, Chorus, Classic Chorus, Ensemble, Tremolo, Classic Tremolo,
Vibrato Tremolo, Tremolo+Amp, Auto Pan, Classic Auto Pan, Auto Pan+Amp, Phaser+Auto Pan,
Phaser, Classic Phaser, Phaser+Amp, Phaser+Chorus, Rotary (1~6)
Parameters:
Virtual Technician
Dry/Wet, Time, Speed, Mono/Stereo, Accel./Rotary Speed – Parameters dependent on effect.
Touch Curve:
Light+, Light, Normal, Heavy, Heavy+, Off (Constant), User Touch Curve
Voicing:
Normal, Mellow 1, Mellow 2 , Dynamic, Bright 1, Bright 2, User Voicing
Resonance,
Noise & Effects:
Damper Resonance, Damper Noise, String Resonance, Undamped String Resonance,
Cabinet Resonance, Key-off Effect, Fall-back Noise, Topboard Simulation, Decay Time
Temperament
& Tuning:
Equal, Pure Major, Pure Minor, Pythagorean, Meantone, Werckmeister, Kirnberger,
User Temperament, Temperament Key, Stretch Tuning, User Tuning
Others:
Internal Recorder
USB Functions
Metronome
Hammer Delay, Minimum Touch, User Key Volume, Half-Pedal Adjust, Soft Pedal Depth
10 song, 2 track recorder – approximately 90,000 note memory capacity
Playback:
MP3, WAV, SMF
Record:
MP3, WAV, SMF
Others:
Load Song, Load Registration All, Load Registration Single, Load Startup Setting, Save Internal
Song, Save SMF Song, Save Registration All, Save Registration Single, Save Startup Setting,
Rename File, Delete File, Format USB, Convert Song to Audio, Overdub Audio
Beat:
1/4, 2/4, 3/4, 4/4, 5/4, 3/8, 6/8, 7/8, 9/8, 12/8 + 100 drum rhythms
Tempo:
Music Menu
10~400 bpm (20~800 bpm for eighth note rhythms)
Demo Songs:
39 songs
Piano Music:
Songs from Alfred, Burgmüller, Czerny, Beyer, Bach, and Chopin lesson books ². Finger Exercises
Concert Magic:
Other Settings
& Functions
Display
Pedals
Jacks
Speaker System
Dimensions
176 songs (88 x 2 banks)
16 memories (8 x 2)
Key Transpose, Song Transpose, Tone Control (incl. User EQ), Speaker Volume, Line In Level, Wall EQ*, Tuning, Damper
Hold, Split, Four Hands, LCD Contrast, Startup Setting, Factory Reset, SHS Mode, Phones Type, Phones Volume, Lower
Octave Shift, Lower Pedal On/Off, Split Balance, Layer Octave Shift, Layer Dynamics, Dual Balance, MIDI Channel,
Send PGM#, Local Control, Transmit PGM#, Multi-timbral Mode, Channel Mute, Auto Power Off, Audio Recorder Gain
128 x 64 pixel LCD with backlight
Sustain (with half-pedal support), Soft, Sostenuto. Grand Feel Pedal System
LINE IN (1/8” STEREO), LINE IN Level, LINE OUT (1/4” L/MONO, R), LINE OUT Level, Headphones x 2 (1/4”, 1/8”)
MIDI (IN/OUT), USB to Host, USB to Device
Speakers:
7 cm x 4 (top speakers)
1.4 cm x 2 (dome tweeters)
Soundboard Speaker System
13 cm x 2 (woofers)
(8 x 12) cm x 2 (top speakers)
5 cm x 2 (tweeters)
Output Power:
45 W x 2 + 45 W transducer
50 W x 2
Power Consumption
(Not including music rack)
37 songs
29 or 42 songs ¹
Lesson Function:
Registrations
60 voices
55 W
45 W
1455 (W) x 465 (D) x 925 (H) mm
57 1/3” (W) x 18 1/3” (D) x 36 1/2” (H)
1455 (W) x 455 (D) x 925 (H) mm
57 1/3” (W) x 18” (D) x 36 1/2” (H)
85.0 Kg / 187 1/2 lbs.
76.0 Kg / 167 1/2 lbs.
Weight
* CA97 only. / ¹ depending on market area.
² Lesson books sold separately.
Appendix
Keyboard
CA67
Specifications are subject to change without notice.
145
section
MIDI
Exclusive Data Format
1st byte
2nd byte
3rd byte
4th byte
5th byte
6th byte
7th byte
8th byte
9th byte
10th byte
1
2
3
4
5
6
7
8
9
10
Byte
ID
Description
1 F0
Start code
2 40
Kawai ID number
3 00 - 0F
MIDI channel
4 10, 30
Function code (30 when setting Multi-timbre On/Off)
5 04
Indicates that the instrument is an electric piano
6 02
Indicates that the piano is a CA/ES model
7 data 1
8 data 2
See table below
9 data 3
10 F7
data 1
data 2
data 3
00
00
-
Multi-timbre Off
01
00
-
Multi-timbre On 1
02
00
-
Multi-timbre On 2
0F
00 - 7F
-
Split Point
14
00 - 7F
-
Dual/Split balance
16
1F - 60
-
Tune, 40: 440 Hz
17
00, 7F
-
00: Program Change Off, 7F: Program Chage On
18
00 - 07
-
00: Light, 01: Normal, 02: Heavy, 03: Off, 04: Light +, 05: Heavy +,
06: User1, 07: User2
19
00 - 03
-
Lower Octave Shift
00 - 3B
00 - 3B
00 - 4F *
00 - 4F *
00 - 3B
00 - 3B
00 - 4F *
00 - 4F *
00 - 3B
00 - 3B
00 - 4F *
00 - 4F *
25
00 - 08
00 - 0B
data 2: Temperament, data 3: Key
26
00, 7F
00 - 0F
Multi-timbre channel mute, data 2: 00 (mute On), 7F (mute Off), data 3: Channel
20
21
22
Appendix
End code
Function
Dual, data 2: Main sound, 3: Layer sound
Split, data 2: Upper sound, data 3: Lower sound
Four Hands, data 2: Right sound, data 3: Left sound
* CA97 only.
146
MIDI Implementation Chart
Kawai CA97/CA67
Function
Basic
Channel
Mode
Transmitted
Default
1 - 16
1 - 16
Changed
1 - 16
1 - 16
Default
Mode 3
Mode 1
X
Mode 1, 3
Messages
Altered
Note
Number
0 - 127
*****
0 - 127
Note ON
O
O
Note OFF
O
O
Key
X
X
Channel
X
X
X
X
O
X
X
X
O (Right pedal)
O (Middle pedal)
O (Left pedal)
O
O
O
O
O
O
O
O 0 - 127
O 0 - 127 ***
*****
0 - 127
O
O
Song Position
X
X
Song Select
X
X
Tune
X
X
Clock
X
X
Commands
O
X
Local ON/OFF
X
O
All Note OFF
X
O (123-127)
Active Sense
X
O
Reset
X
X
True Voice
After Touch
Pitch Bend
0, 32
7
10
11
64
66
67
Control
Change
True #
System
Exclusive
Common
System
Real Time
Others
*****
21 - 108**
Velocity
Program
Change
Section
Date: November 2014
Version: 1.0
Remarks
* The default for the OMNI mode
is ON.
Specifying MIDI channels automatically turns it OFF.
** The value depends on the
Transpose setting.
Bank Select
Volume
Pan Pot
Expression Pedal
Sustain Pedal
Sostenuto Pedal
Soft Pedal
*** Refer to the Program Change
Number List on page 142.
On/Off Selectable
Appendix
[DIGITAL PIANO]
Notes
Mode 1 : OMNI ON , POLY
Mode 3 : OMNI OFF, POLY
Mode 2 : OMNI ON , MONO
Mode 4 : OMNI OFF, MONO
O : Yes
X : No
147
Appendix
User Notes
148
Hello to Jason Isaacs!
CA97/CA67 Owner’s Manual
KPSZ-0750
OW1087E-J1501
Printed in Indonesia
Copyright © 2015 Kawai Musical Instruments Mfg. Co.,Ltd. All Rights Reserved.
