2015 Product Selection Guide (PSG)
About Us
Vicon is an industry-leading designer, manufacturer and marketer of video systems and components used for security, surveillance, safety and
control purposes. With almost 50 years in business, the company is unrivaled in experience developing video surveillance technologies. Vicon
systems are employed worldwide in high-profile, enterprise-scale installations by a diverse range of customers in a variety of markets, including
government, corrections, education, commercial, healthcare and transportation.
Vicon oversees its worldwide operations from its main headquarters located on New York’s Long Island and has offices worldwide.
The company is publicly traded on the New York Stock Exchange under the symbol “VII.” With thousands of successful Vicon IP, analog
and hybrid installations across the globe, you can rely on our products and service.
• Integrated video solutions providing innovative technology
• Single point-of-contact for all your security needs
• Open-platform design allows for easy integration
• Proven reliability and cost-effective ROI, with applications
for every market
• Scalable security systems designed for tomorrow’s growth
2
Vicon and IQinVision Merger Solutions:
With the recent merger of Vicon and
IQinVision, we have added a wide range of
high-resolution IP cameras to the Vicon line
of products. These IQeye cameras, found on
page 10, complement and add to our full
security solution offerings with:
• Full Range of Image Resolutions
• Open Platform Integration with 3rd Party NVRs
and VMS systems
• Reputation for High Quality and Reliability
• Innovative Features and Advanced Analytics
• ONVIF and PSIA Compliant
THE VICON DIFFERENCE:
Providing Reliable Products Backed by Extensive Customer Support
Professional Services
With our Professional Services, new solutions require less time and cost to implement, communication
is streamlined, and access to service and resources is easier:
• Vicon Classroom – On-site customized, hands-on training
• Field Services and Project Engineering –Single point-of-contact engineers work onsite and
provide on-going communication
• Factory Direct System Pre-Configuration – All system components, including pre-registration
of software licenses, are pre-configured
ViconNet Training Classes
Providing invaluable education of the Vicon security solution:
• Classes held monthly across the U.S.
• Provides hands-on training of Vicon products, including our unique features
and configuration components
• Become a certified Vicon professional with option to earn BICSCI credits
• Customized training available at the location of your choice
Certified
AEC Support Services
We make it easy to design your project:
• AEC Support website portal – CAD, BIM files, A&E specs, bandwidth calculator and more
• AutoDesk and ARCAT partnership – Download Revit 3D models, CAD drawings, RTF files,
BIM library, and product specs or use Spec Wizard to quickly specify products into all of your
designs
• Dedicated AEC Support team
Technical Support
Committed to providing world-class support to our customers with extensive online resources
and phone support:
• Helpful video tutorials are on our website and Youtube
• Software updates and patches are easy to download
• Help Forum and Knowledgebase FAQs quickly answer your questions
3
ViconNet Video Management Software
Up t
o1
6
Co or 2
mp 4
et Ca
iti m
ve
Up
to
Six
No Cam
Lic er
en
si
a Packages
m er
/Ca rk Multiple NVRs
VR
wo
• N Ne t
as g •
er icin
Pr
s
ee
as g F
n
FREE
Open Platform Network Solutions for Every Size and Budget
• ViconNet Video Management Software, available as JUMP,
ZONE or PEAK, offers customization and compatibility with a
wide range of ONVIF-compliant video, camera and computer
hardware
• Feature-rich interface, reliable performance, and fully
scalable systems have made ViconNet a critical component
in thousands of facilities worldwide
• Integrates with IP and analog technologies as well as 3rd
party technologies including access control and video
analytics
• Packages are priced for every sized system and budget,
offering video management solutions optimized for all your
security needs
Un
l
le Systems
e-Sca
pris
ter ltiple NVRs • System Re
u
En
d
u
n
d, rk M
da
ite wo
nc
y
im Net
ViconNet NVRs
ViconNet JUMP NVR
• Preloaded with ViconNet JUMP software
• Convenient small form factor with high
performance features
• 1 TB storage
• Supports up to 6 cameras from a single NVR with
no licensing fee
• Can be used with Web Browser or Workstation
software to view local video
• Vertical standing rack or VESA mounting bracket
ViconNet ZONE / PEAK NVRs
• Ability to view, control and configure
every ViconNet DVR and IP device on the
network
• Pre-configured PC running ViconNet
software
• Provides full capabilities for managers
and administrators to control operations
such as exporting video data
• Tower or 1 RU rack-mount enclosures
8-Bay NVR Shadow NVRs
• Pre-configured with ViconNet software; includes internal RAID 5 storage
• Available with 8 or 24 bays
• Ability to view, control and configure every ViconNet DVR and IP device on the network
• Hot-swappable drives
• Supports system integration with access control and video analytics
ViconNet Nucleus
• Dedicated Nucleus for a ViconNet system
• Available as a pre-configured PC or software only
• Centralized management of all system components
• Recommended for ViconNet networks
with more than five NVRs or DVRs
4
ViconNet
Virtual Matrix Display Controller
• Scalable matrix control solution for small and large installations
• 1080p high-definition; 16 x 9 viewing; H.264 compression
• Intuitive GUI provides easy-to-use controls
• Connect up to 6 monitors to each unit; add more units for
multiple monitor solutions
• Control can be shared by multiple operators
• Create large multi-monitor displays
• Network keypad provides joystick control (sold separately)
Vicon Mobile
• Covers iPad, iPhone and Android phones and tablets
• Securely connect to ViconNet systems
• View live video or playback
• Full control of PTZ cameras, including presets
• View multiple concurrent video streams; 4 on phone devices, 9 on tablets
• Touch-control on-screen jog wheel provides control of PTZ cameras
• Uses existing ViconNet user account privileges
Tablet/Phone not included
ViconNet Web Server
• Provides single point-of-access to all cameras and recorders in
an enterprise class system using the browser interface
• Enhances system ability to support simultaneous users
• Available as software only or as a pre-configured PC within
a 1 RU rack-mount enclosure
• Browser-based interface for live viewing and playback
• Compatible with Internet Explorer, Firefox, Chrome and Safari
ViconNet Network Workstation
• Ability to view, control and configure every ViconNet DVR and
IP device on the network
• Pre-configured PC running ViconNet software
• Provides full capabilities for managers and administrators
to control operations such as exporting video data
• Tower or 1 RU rack-mount enclosure
Storage
VN-SAN RAID Storage Device
• Available with 18 or 48 bays
• Up to 81 TB usable RAID5 storage
• iSCSI protocol for network connection
• Rack-mountable and stackable enclosures
• Single device may provide storage to multiple NVRs
5
Kollector DVRs
Kollector Strike Hybrid DVR
• 16-channel hybrid digital video recorder with full-featured
ViconNet VMS
• Records 16 analog and up to 8 additional IP (up to 5 MP) cameras
• 4 dry contact alarm inputs and relay control outputs;
1 serial port; 4 microphone ports
• Supports museum search for all 16 analog cameras
• Supports up to 6 TB of storage (removable HD model)
• 1 RU rack-mount enclosure
Kollector Force Hybrid DVR
Kollector Force includes all features of Kollector Strike Hybrid DVR, plus:
• 16 microphone ports and 4 serial ports
• 16 dry contact alarm inputs and relay control outputs
• 16 analog video loopouts
• 4 analog monitor outputs
Edge Devices
Encoders / Decoder
H.264-16CH-ENCDR
16-Channel Encoder
• Dual streaming video
• Up to 480 fps
• Dual network ports for redundancy
• Power-over-Ethernet (PoE or high power PoE) or 24 VAC
• Supports museum search functionality for all cameras
• 8 dry contact alarm inputs and relay control outputs
• 16 audio inputs
• Racks in standard 19-inch racking system
VN-901T
Single-Channel Encoder
6
• SIngle analog camera video input; 1 looping output
• Ideal solution for creating hybrid analog/IP systems
• H.264, MPEG-4 and M-JPEG compression
• Supports dual streaming
• Privacy masking and motion detection
• PoE or 12 VDC/24 VAC
H.264 ENCDR
4-Channel Encoder
• Dual streaming video
• Up to 120 fps
• Power-over-Ethernet (PoE) or 24 VAC
• Supports museum search functionality for all cameras
• 4 dry contact alarm inputs and relay control outputs
• 4 audio inputs
• Racking options: 2 units within 1 RU, 8 units within 5 RU
VN-DECODER-2
•Ideal companion for VMDC
• Decodes digital IP data into analog for display on monitor
• Connect up to 2 monitors
• Supports 1080p high-definition; 16 x 9 viewing;
H.264 compression
• Compact size fits easily in remote display areas
Plug-and-Play Device NVRs
HDExpress is a revolutionary IP video solution that provides 1080p highdefinition video recording while removing the pain often associated with
installing and configuring network components. Just connect up to 16 IP
cameras to the unit’s PoE ports and let HDExpress do the rest. The unit’s
software automatically detects and configures the cameras as they are
plugged in. Programming is completely optional.
1080p 60 Hz
PoE Ports for
Network Cameras
VGA
External Storage
Expansion
VGA
Monitor
HDMI
Monitor
Remote Network
Connections
HDExpress Models
4 or 8 - Channel Model
16 - Channel Model
• 1080P/60 Hz (1920 x 1080) real-time recording and display
• Built in Power-over-Ethernet switch
• No programming of network cameras required
• Auto notification with self diagnosis (HDD S.M.A.R.T,
temperature, network connection status, fan error, etc.)
• Onscreen Graphical User Interface (GUI) for local control
• Web interface for remote viewing
• Mobile phone applications (iPhone and iPad or Android OS)
• Easy export of video to USB storage devices
7
IP Cameras - PTZ
Surveyor Domes
Outdoor /
Impact Resistant
Surveyor PTZ Cameras
• HD 1080p or 720p resolution
• Optical zoom: 20x (1080p)/30x (720p)
• WDR day/night camera; low light capability
• H.264 or M-JPEG video streams
• High-speed 360° continuous pan
• Impact resistant and pressurized housings available
• ONVIF compliant
Pressurized
SN680D Network PTZ Dome
• 1080p resolution
• WDR; day/night camera with a built-in varifocal 30x
optical zoom autoiris lens
• Synchronized IR illuminators with 394 ft (120 m) range
• Triple streaming video
• IP66
• Surface mounting on wall or ceiling
• ONVIF compliant
SN663V Cruiser
• 1080P (1920x1080P) day/night camera
• H.264 and M-JPEG compression formats
• 12X optical zoom and 16X digital zoom
• WDR, DIS (Digital Image Stabilization), tampering, defog, and
object detection function
• Outdoor; IP66 rated
• ONVIF compliant
IP Cameras - Fixed
Roughneck V920D Series
• 3MP, 2MP/1080p, 1.3MP/720p and SD resolution models
• True day/night camera; WDR and IR models
• Built-in varifocal lens, including remotely adjustable motorized lenses
• H.264 high profile, MPEG-4 and M-JPEG compression
• IP66 rated; includes heater; IK10 rated for impact protection
• In-ceiling or pendant mount options
• ONVIF compliant
Analog model available
8
IP Cameras - Fixed
Cost-Effective Series
CE102D
CE202D Series
CE102B
Bullet
Indoor
• 1080p resolution
• Day/night camera with fixed 3.7 mm lens
• H.264 high-profile, MPEG-4 and M-JPEG
compression
• Remote directional positioning (outdoor model)
• Triple streaming video
• IP65
• ONVIF compliant
• 1080p resolution
• Built-in IR LEDs
• True day/night camera with
fixed 3.7 mm lens
• Triple streaming video
• IP 67
• ONVIF compliant
• 1080p resolution
• True day/night camera with fixed
3.7 mm lens
• H.264 high-profile, MPEG-4 and
M-JPEG compression
• Triple streaming video
• Built-in IR LEDs
• ONVIF compliant
IP Specialty Cameras
V920B Series Bullet Cameras
• 720p/1.3MP, 1080p/2MP and 3MP resolution models
• True day/night camera
• 3-9 mm motorized varifocal autoiris lens
• IR LEDs provide illumination in low light environments
• Built-in heater
• IP 67
• ONVIF compliant
V9360 360°Network Dome
V9360
V9360W
• Fisheye lens captures hemispheric video
• 2032 x 1920 maximum resolution
• 4 megapixel progressive scan CMOS sensor
• Day/night with mechanical IR cut filter
• 180°/360° panorama at full HD resolution
• Selectable H.264, MPEG-4 SP, M-JPEG
compressions with dual streaming
• Indoor and outdoor models
• ONVIF compliant
Roughneck HD Cell Camera
• Rugged housing with flat design
• 1080p HD resolution
• Multiple H.264 or M-JPEG streams
• Day/night camera with 2.6 mm lens
• Integrated IR LEDs
• IK 10 vandal impact rating
• Ideal for prisons and custodial suites
• ONVIF compliant
Analog model available
9
Introducing the IQeye line of cameras
Renowned for their open platform compatibility, image
quality, and reliability in the harshest environments.
These cameras enhance our current Vicon line of network
cameras, which we will continue to offer and support.
IQeye Cameras
12 MP Sentinel
NEW
12 MP
BEST IN THE INDUSTRY!
Sentinel Series
SUPERIOR FEATURES:
• 12 MP/4K resolution
• 30 fps @ QFHD, 15 fps @ 4K and 12MP
• USB storage
• Powerful Dual Core processor
• On-camera analytics
• Gigabit Ethernet PoE
• 2-way audio
• Resolutions up to 5 MP
• Remote back focus for sharp focusing
• H.264 and M-JPEG compression
• 60 fps @ HD720p, 30 fps @ 1080p,
10 fps @ 5 MP
• WDR available in 1/2/3 MP
• True day/night camera
• Lightgrabber low-light feature
• Power-Over-Ethernet, 12-24 VDC, 24 VAC
• IP66/NEMA 4 outdoor enclosure
• ONVIF and PSIA compliant
IQ Domes
Alliance-mx Dome
• Resolutions up to 5 MP
• H.264 and M-JPEG compression
• WDR available in 1/2/3 MP models
• Built-in IR LEDs
• True day/night camera
• Lightgrabber II low-light feature
• Power-over-Ethernet
• IP66/NEMA 4 outdoor enclosure
• ONVIF and PSIA compliant
Alliance-pro Dome
• Resolutions up to 5 MP
• H.264 and M-JPEG compression
• 60 fps @ 720p, 30 fps @ 1080p,
10 fps @ 5 MP
• WDR available in 1/2/3 MP models
• True day/night camera
• IP66/NEMA 4 outdoor enclosure
• Power-over-Ethernet, 12-24 VDC, 24 VAC
• ONVIF and PSIA compliant
Alliance-mini Dome
• Resolutions up to 5 MP
• H.264 and M-JPEG compression
• WDR available in 1/2/3 MP models
• True day/night camera
• 3-axis gimbal
• Lightgrabber II low-light feature
• Power-over-Ethernet
• ONVIF and PSIA compliant
IQ Bullet and Box Cameras
R5 Series Bullet
• Resolutions up to 3 MP
• H.264 and M-JPEG compression
• 30 fps @ HD720p and HD1080p,
15 fps @ 3 MP
• Built-in IR LEDs
• True day/night camera
• Power-over-Ethernet, 12 VDC
• IP66 outdoor enclosure
• ONVIF and PSIA compliant
10
3 Series
• Resolutions up to 2 MP
• 60 fps @ SD480p,
30 fps @ HD720p / HD1080p
• H.264 and M-JPEG compression
• True day/night camera
• Lightgrabber II low-light feature
• Power-over-Ethernet
• ONVIF and PSIA compliant
7 Series
• Resolutions up to 5 MP
• Remote back focus for sharp focusing
• H.264 and M-JPEG compression
• 60 fps @ HD720p, 30 fps @ 1080p,
10 fps @ 5 MP
• WDR available in 1/2/3 MP models
• True day/night camera
• Lightgrabber II low-light feature
• Power-over-Ethernet, 12-24 VDC, 24 VAC
• Continuous analog video out
• ONVIF and PSIA compliant
Analog Cameras
SurveyorVFT PTZ Domes
Outdoor /
Impact Resistant
Pressurized
• Video transmission via coaxial cable
• 22X, 23X or 36X high-resolution day/night camera
• Pendant configurations
• Impact-resistant and pressurized housings available
• 360˚ continuous pan
• Variable-speed drive
• Privacy masking
• Wide Dynamic Range (WDR); Digital Noise Reduction (DNR)
Fiber optic and twisted pair video transmission available on certain models
Cost-Effective Fixed Camera Domes
• Day/night, IR illumination and Wide Dynamic Range
(WDR) models (options vary by housing)
• Up to 750 TVL resolution (model dependent)
• Varifocal autoiris lens
• Digital Noise Reduction (DNR)
• NTSC and PAL models
V661V-1 Series
V662V-1 Vandal Proof Series V661D-1 Series
Cost-Effective Box and Bullet Cameras
V661-N-1 High-Resolution
Day/Night Camera
• 750 TV lines
• Day/night (ICR) capability with
digital WDR
• Outstanding low-light performance
• 2D Digital Noise Reduction (DNR)
• On-screen menus with innovative
joystick control make setup and
operation easy
• NTSC and PAL models
V662-D-2 High-Resolution
WDR Camera
• 750 TV lines
• 0.5 lux color; 0.01 lux BW
• Super Wide Dynamic Range (WDR)
• Digital Noise Reduction (DNR)
• On-screen menus with innovative
joystick control make setup and
operation easy
• NTSC and PAL models
V660B-488IR Bullet Camera
• Day/night, IR illumination
and Wide Dynamic Range (WDR)
• External remote controller for setup of
motorized 4.1-88 mm lens
• 600 TV lines
• 22X optical zoom
• IR LED illumination
• 2D Digital Noise Reduction (DNR)
• NTSC and PAL models
Accessories
Monitors
• Variety of HD LED sizes up to 42”
• 16:9 aspect ratio
Transmission Products
• Fiber-optic media converters for range
extension of IP networks
• Fiber-optic and twisted-pair transmission
systems for video and data
Network Switches
Camera Accessories
Surge Protection
• Extensive selection of indoor and
outdoor mounting hardware
• Varifocal lenses, including
IR and megapixel
• Power supplies
• Various port options
• PoE models
• Complete line of devices for
VMS system components
• Models to protect Ethernet,
PoE, DVRs and cameras
11
Corporate Headquarters
California
European Headquarters
Vicon Industries
135 Fell Court
Hauppauge NY 11788
Tel: 631.952.2288
800.645.9116
Email: sales@vicon-security.com
Vicon Industries
27127 Calle Arroyo, Suite 1920
San Juan Capistrano, CA 92675
Tel: 631.952.2288
800.645.9116
E-mail: sales@vicon-security.com
Vicon Industries Limited
Brunel Way
Fareham
Hampshire, PO15 5TX
United Kingdom
Tel: +44 1489 566300
E-mail: sales@vicon.co.uk
Middle East
Asian Pacific
Italy
Vicon Industries
Via Settembrini, 36
20020 Lainate, Milan,
Italy
Tel: +39 02 95938250
E-mail: info@vicon-cctv.it
Spain & Portugal
Vicon Industries
Calle Pollensa Número 4
Centro de Negocios Tartessos
Edificio Atenea Local 10
Planta Segunda
Ctra de la Coruña 23,500
28290 Las Rozas (Madrid)
Spain
Tel: +34 91 640 26 76
E-mail: sales@vicon-cctv.es
Anshassi Square
3rd floor - 302,
Shmeisani,
Amman, Jordan
Tel: +962 6 5007403
E-mail: sales@viconme.co.uk
Vicon Industries Limited
Unit 19, 8/F, Topsail Plaza
11 On Sum Street, Shatin
New Territories, Hong Kong
China
Tel: 852 2145 7118
E-mail: sales.intl@vicon-security.com
Latin America
Tel: Mexico: 55.8525.4402
Peru
Tel: 51.1.708.6818
Email: ventas@vicon-security.com
France
Tel: +33 6 84 03 20 79
E-mail: info@vicon.fr
www.vicon-security.com
ViconNet, Kollector, Roughneck, Surveyor, HD Express, Cruiser and IQeye and their logos are trademarks or registered trademarks of Vicon Industries Inc.
All other trademarks used in this publication are the property of their owners. Specification are subject to change without notice.
Copyright ©2014 Vicon Industries Inc. All rights reserved
Vicon part number: 8015-5329-00-00
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
