Precauciones de Seguridad
Safety Precautions
Cajas acústicas activas / Self-powered loudspeaker enclosures
El signo de exclamación dentro de un triángulo indica la
existencia de importantes instrucciones de operación y
mantenimiento en la documentación que acompaña al producto.
Conserve y lea todas estas instrucciones. Siga las advertencias.
ATENCIÓN: Es un producto clase A, por lo que en entornos
domésticos puede causar radio-interferencias, en cuyo caso el
usuario tendrá que tomar las medidas oportunas.
De acuerdo con EN55103-2, usar el equipo sólo en entornos E1,
E2, E3 ó E4.
No desconecte la tierra en el conector de alimentación pues el
peligroso e ilegal. Equipo de Clase I.
The exclamation point inside an equilateral triangle is intend to
alert the users to the presence of important operating and
maintenance
(servicing)
instructions
in
the
literature
accompanying the product.
Heed all warnings. Follow all instructions. Keep these
instructions.
WARNING: This is a class A product. In a domestic environment
this product my cause radio interferences in which case the user
may be required to take adequate measures.
Use this product only in E1, E2, E3 or E4 environments
according to EN55103-2.
Do not remove mains connector ground, it is dangereous and
illegal. Class I device.
El signo del rayo con la punta de flecha, alerta contra la
presencia de voltajes peligrosos no aislados. Para reducir el
riesgo de choque eléctrico, no retire la cubierta.
The lightning and arrowhead symbol warns about the presence
of uninsulated dangerous voltage. To reduce the risk of electric
shock, do not remove the cover.
No instale el aparato cerca de ninguna fuente de calor como
radiadores, estufas u otros aparatos que produzcan calor. Debe
instalarse siempre sin bloquear la libre circulación de aire por las
aletas del radiador.
Do not install near any heat sources such as radiators, heat
registers, stoves or other apparatus that produce heat.
The circulation of air through the heatsink must not be blocked.
No exponga este equipo a la lluvia o humedad. No use este
aparato cerca del agua (piscinas y fuentes, por ejemplo). No
exponga el equipo a salpicaduras ni coloque sobre él objetos
que contengan líquidos, tales como vasos y botellas. Equipo IP20.
Do not expose this device to rain or moisture. Do not use this
apparatus near water (for example, swimming pools and
fountains). Do not place any objects containing liquids, such as
bottles or glasses, on the top of the unit. Do not splash liquids
on the unit. IP-20 equipment.
Este símbolo indica que el presente producto no puede ser
tratado como residuo doméstico normal, sino que debe
entregarse en el correspondiente punto de recogida de equipos
eléctricos y electrónicos.
This symbol on the product indicates that this product should
not be treated as household waste. Instead it shall be handed
over to the appicable collection point for the recycling of
electrical and electronic equipment.
Equipo diseñado para funcionar entre 15ºC y 42ºC con una
humedad relativa máxima del 95%, con un rango de ±10% de la
tensión nominal de alimentación indicada en la etiqueta trasera
(según IEC 60065:2001).
Working temperature ranges from 15ºC to 42ºC with a relative
humidity of 95%, with ±10% of the rated main voltage value
indicated on the rear label (according to IEC 60065:2001).
El cableado exterior conectado al equipo requiere de su
instalación por una persona instruida o el uso de cables flexibles
ya preparados.
The outer wiring connected to the device requires installation by
an instructed person or the use of a flexible cable already
prepared.
Si el aparato es conectado permanentemente, la instalación
eléctrica del edificio debe incorporar un interruptor multipolar con
separación de contacto de al menos 3mm en cada polo.
If the apparatus is connected permanently, the electrical system
of the building must incorporate a multipolar switch with a
separation of contact of at least 3mm in each pole.
Desconecte este aparato durante tormentas eléctricas,
terremotos o cuando no se vaya a emplear durante largos
periodos.
Unplug this apparatus during ligtning storms, earthquakes or
when unused for long periods of time.
No emplace altavoces en proximidad a equipos sensibles a
campos magnéticos, tales como monitores de televisión o
material magnético de almacenamiento de datos.
Do not place loudspeakers in proximity to devices sensitive to
magnetic fields such as television monitors or data storage
magnetic material.
No emplace el producto sobre un carro, base, tripode, soporte o
mesa inestables. El dispositivo puede caer, causando serias
heridas y dañándose gravemente.
Do not place the product on an unstable cart, stand, tripod,
bracket or table. The device may fall, causing serious injury, and
serious damage to the device itself.
El colgado del equipo sólo debe realizarse utilizando los herrajes
de colgado recomendados y por personal cualificado. No
cuelgue la caja de las asas.
The appliance should be flown only from the rigging points and
by qualified personnel. Do not suspend the box from the
handles.
No existen partes ajustables por el usuario en el interior de este
equipo. Cualquier operación de mantenimiento o reparación
debe ser realizada por personal cualificado. Es necesario el
servicio técnico cuando el equipo se haya dañado de alguna
forma, como que haya caído líquido o algún objeto en el interior
del aparato, haya sido expuesto a lluvia o humedad, no funcione
correctamente, haya recibido un golpe o su cable de red esté
dañado.
No user serviceable parts inside. Refer all servicing to qualified
service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally or has been dropped.
Limpie con un paño seco. No use limpiadores con disolventes.
Clean only with a dry cloth. Do not use any solvent based
cleaners.
La reventa del producto sólo es posible incluyendo el manual de
usuario. Cualquier cambio producido en el producto tiene que
ser documentado por escrito y aprobado por el comprador en el
momento de la reventa.
Reselling of the product is only possible if the user manual is
aviable. Any changes made to the product have to be
documented in writing and passed on to the buyer in the event
of resale.
Manual del Usuario / LX-218A / User’s Manual
GARANTÍA
Todos nuestros productos están garantizados por un periodo de 24
meses desde la fecha de compra.
Las garantías sólo serán válidas si son por un defecto de
fabricación y en ningún caso por un uso incorrecto del producto.
Las reparaciones en garantía pueden ser realizadas,
exclusivamente, por el fabricante o el servicio de asistencia técnica
autorizado.
Otros cargos como portes y seguros, son a cargo del comprador
en todos los casos.
Para solicitar reparación en garantía es imprescindible que el
producto no haya sido previamente manipulado e incluir una
fotocopia de la factura de compra.
WARRANTY
All D.A.S. products are warrantied against any manufacturing defect
for a period of 2 years from date of purchase.
The warranty excludes damage from incorrect use of the product.
All warranty repairs must be exclusively undertaken by the factory
or any of its authorised service centers.
To claim a warranty repair, do not open or intend to repair the
product.
Return the damaged unit, at shippers risk and freight prepaid, to
the nearest service center with a copy of the purchase invoice.
Manual del Usuario / LX-218A / User’s Manual
DECLARACIÓN DE CONFORMIDAD
DECLARATION OF CONFORMITY
D.A.S. Audio, S.A.
C/ Islas Baleares, 24 - 46988 - Pol. Fuente del Jarro - Valencia. España
(Spain).
Declara que LX-218A:
Declares that LX-218A:
Cumple con los objetivos esenciales de las Directivas:
Abide by essential objectives relating Directives:
l
Directiva de Baja Tensión (Low Voltage Directive)
2006/95/CE
l
Directiva de Compatibilidad Electromagnética (EMC)
2004/108/CE
l
Directiva RoHS
2002/95/CE
l
Directiva RAEE (WEEE)
2002/96/CE
Y es conforme a las siguientes Normas Armonizadas Europeas:
In accordance with Harmonized European Norms:
l
EN 60065:2002
l
EN 55103-1:1996 Electromagnetic compatibility.
Product family standard for audio, video, audiovisual and entertainment lighting control apparatus
for professional use. Part 1:Emission.
l
EN 55103-2:1996 Electromagnetic compatibility.
Product family standard for audio, video, audiovisual and entertainment lighting control apparatus
for professional use. Part 2:Immunity.
Audio, video and similar electronic
apparatus. Safety requirements.
Manual del Usuario / LX-218A / User’s Manual
Manual del Usuario / LX-218A / User’s Manual
CONTENTS
INTRODUCTION
3
General information
Features
AMPLIFIER DESCRIPTION
3
USE
4
Preliminary
ON / OFF
Overload indicators
Overheating
Equalisation
Low mains voltage
CONNECTIONS
5
Self-powered systems connection
Pasive systems connection
TROUBLESHOOTING
7
BLOCK DIAGRAM
8
LINE DRAWINGS
8
SPECIFICATIONS
9
APPENDIX
10
Line connections: unbalanced and balanced
EN
Manual del Usuario / LX-218A / User’s Manual
EN
Manual del Usuario / LX-218A / User’s Manual
INTRODUCTION
AMPLIFIER DESCRIPTION
General information
Thank you for purchasing D.A.S. Audio S.A.
products. This unit represents 30 year of expertise
in transducer and enclosure design, achieving a
system that utilises the most advanced sound
reinforcement technology to deliver outstanding
audio performance and maximum reliability.
This manual contains the required information to
make the best use of the system you have
purchased. Please take the time to read it.
Our WEB (www.dasaudio.com) contains further
support information such as enclosure and system
drawings, data for modelling software, architectural
specifications and specification sheets.
Features
This powered subwoofer system is designed to
reproduce the low frequencies of the audio
spectrum, providing a high level of power.
It comprises two 18” model 18LX long-excursion
loudspeakers
with
enhanced
performance
(increased power handling capabily and reduced
distortion) and optimized design.
The amplifier features an intelligent power supply
which detects the mains voltage level and adjusts
internal voltages to ensure maximum system
efficiency.
Furthermore, the 2400W class D amplifier offers
exceptional performance and minimum heat
generation.
The digital signal processing (DSP) provides
improved control over the input signal treatment.
The "R" version features rigging hardware
enabling the systems to be flown simply, safely
and efficiently.
A) INPUT CLIP:
Red LED indicates and excessive input signal,
saturation of the DSP and excessive increases in
distortion.
B) LOOP THRU :
XLR-type output signal connector for
connecting several units together and sending
them all the same signal.
C) INPUT :
XLR-type input signal connector, which just like
the LOOP THRU connector, is a balanced
connector with the following pins:
1=GND (Ground).
2=(+) Non invertided input.
3=(-) Invertided input.
D) CLIP :
Red LED indicates amplifier saturation, in other
words, when it reaches Clip.
E) PROTECTION :
Yellow LED indicates that the protection
system has been activated. If the problem that
activated the protection is resolved, the amplifier
will restart. The problems that can activate the
protection system are:
-Mains power out of operating range
-Overheating.
-Overload or short-circuit.
-DC voltage present at the loudspeaker output.
F) SIGNAL :
Green LED indicates signal.
G) POWER :
Green LED indicates ON.
H) Heatsink.
Although the heatsink does not reach high
temperatures (during normal use), the heatsink
should not be covered or obstructed in any way
and it should not be touched.
I) AC INPUT :
Neutrik model PowerCon 'NCA3' connector for
connection to the mains supply. This only
connects when it is turned and locked and is
equipped with a securing tab.
EN
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION
DANGER D’ELECTROCUTION
NE PAS OUVRIR
LX-218A
Line Array Series
DSP INPUT BOARD
MADE IN SPAIN
S.N.
D.A.S. AUDIO S.A. (Valencia) SPAIN
B
LOOP THRU
CLIP
PROTECTION
INPUT
2
3
1
SIGNAL
HOT
COLD
AC INPUT
C
N1918
INPUT CLIP
GND
POWER
D
E
F
G
H
Manual del Usuario / LX-218A / User’s Manual
100V-230V
1200W MAX.
50Hz/60Hz
A
I
3
USE
Preliminary
This product should only be used in E1, E2, E3
or E4(*) environments, in accordance with standard
EN55103-2 (Electromagnetic compatibility. Product
family standard for audio, video, audio-visual and
entertainment lighting control apparatus for
professional use. Part 2: Immunity.)
Do not cover the amplifier's radiator nor
obstruct its ventilation (except for the rain protector
supplied by DAS).
For consumption reasons, it is important not to
connect the equipment to the same line as the
lighting systems, thus avoiding interruptions or
sudden drops in lighting intensity.
ON / OFF
A sound system should be switched on
sequentially. Switch on the self-powered units last
in your sound system (switch on the subwoofer
before the mid-high system). Switch on the sund
sources such as CD players or turntables, then the
mixer, then the processors, and finally the selfpowered unit. If you have several units, it is
recommended that you switch them on
sequentially one at a time.
Follow the inverse order when switching off,
turning self-powered units off before any other
element in the sound system.
Disconnect the device by removing the mains
connector from the mains socket. The mains
connector and mains socket must always be freely
accessible and never covered or blocked in any
way. The mains cable can be detached from the
device by disconnecting the Neutrik PowerCon
connector. Pull the metal lock back, turn the
Neutrik PowerCon counter clockwise to stop and
pull the Neutrik PowerCon connector out. Always
disconnect the device by removing the mains
connector from the mains socket before detaching
the mains cable at the Neutrik PowerCon
connector.
IMPORTANT: Do not disconnect the Neutrik
PowerCon connector during music.
Ensure that the device is disconnected from
mains by observing that the lamp marked POWER
is turned off. Please note that the POWER lamp
can stay on for several seconds after the mains
power has been disconnected.
EN
Overload indicators
This device has two indicators (red leds), one
for overload input signal and other for the
amplifier’s clip.
The indicators should not be lit continuously.
This distorts the signal (quickly fatiguing your ears)
and may damage the speakers. Therefore, it is
recommended that you never work with this leds
on; at most they should blink only occasionally.
4
Overheating
This equipment does not normally overheat
during normal conditions of use. When overheating
occurs, the unit protects itself and the yellow LED
'Protection' lights up. You should then find out why
and if necessary contact an authorised dealer for
Technical Assistance.
Normally it is enough just to let the unit cool
down after you have corrected the problem so that
the system functions properly again.
Equalisation
The units does not need extreme settings of
equalisation to produce quality sound. Avoid high
levels of gain on the equalisers. Gain values above
+3 dB on a console’s EQ are not recommended.
Low mains voltage
If mains voltage falls below the shutdown
voltage for the unit, it will stop playing (the yellow
led is on: Protection activated). When acceptable
levels are regained, the unit will switch back on
automatically (the yellow led is off: Protection
deactivated).
The mains supply input can assess the
network's voltage level and thus makes the system
work in two possible voltage ranges: From 85
Vrms to 130 Vrms; and from 170 Vrms to 260
Vrms.
Therefore, in a country with a nominal mains
supply voltage of 120 Vrms, the unit will
disconnect when the voltage in the socket goes
below 85V or above 130V (both Vrms). Likewise, in
a country with a nominal mains supply voltage of
230 Vrms, the unit will disconnect itself when the
voltage at the plug goes below 170V or above
260V (both Vrms).
The current draw for 230 V can be seen on the
accompanying table. Double the ratings to get the
115V current consumption.
AC input =230 Vrms
Pink Noise
Sinusoidal
Max. Power
8A
10.8A
1/3 Power
5.2A
---
1/8 Power
2.4A
---
0.6A
---
Idle
(*)Note
E1.- Residential.
E2.- Commercial and light industrial.
E3.- Urban outdoors.
E4.- Controlled EMC environment and the rural
outdoors environment.
Manual del Usuario / LX-218A / User’s Manual
CONNECTIONS
LINK
LINK
LINK
LINK
LINK
LINK
Self-powered systems connection
The illustration below show a typical diagram for connecting this system to other powered units. In this
four-way configuration and the sub-bass frequencies are handled by LX-218A units while the low, medium and
high frequencies are handled by aero 38A units. An external processor is required to time-align the sub-bass
and low frequencies by adding delays. Additional equalization or filtering are not required.
As can bee seen, the aero 38A units are connected using the loop thru’s on both the mains supply as well
as the signal. In the case of the LX-218A, only the signal can be looped thru, power must be supplied to each
unit independently.
POWER
SUPPLY
INPUT
DAS AUDIO
I
0
SIGNAL INPUT
LINK
POWER
SUPPLY
EN
POWER
SUPPLY
INPUT
Manual del Usuario / LX-218A / User’s Manual
5
Pasive systems connection
In this other four-way configuration, besides introducing delays, the external processor has to process the
signal and distribute it amongst the other external amplifiers, with the correct equalization. (Check the factory
recommendations for aero 38 or aero 48 units.)
SIGNAL INPUT
DAS AUDIO
I
0
±4HF
±3MF
±2LF2
±1LF1
POWER
SUPPLY
2 x 1200 W@4 ohms
2 x 1200 W@4 ohms
2 x 1200 W@4 ohms
LINK
POWER
SUPPLY
2 x 1200 W@4 ohms
INPUT
EN
6
Manual del Usuario / LX-218A / User’s Manual
±4HF
±3MF
±2LF2
±1LF1
TROUBLESHOOTING
PROBLEM
CAUSE
No sound from the unit. The
SIGNAL presence LED indicator(s)
do(es) not light up.
SOLUTION
1 – The signal source is sending no
signal.
1 – Check that the mixer or sound
source is sending signal to the UNIT.
2 – Defective cable.
2 – Check that the cable from the
sound source to the UNIT is
connected correctly. Replace the
cable if defective.
Full power cannot be obtained. The
overload LED indicator(s) never
light(s) up.
The signal source does not have a
hot enough output.
If using a mixer, use the balanced
output
if
available.
Use
a
professional mixer with a hotter
output.
Sound is distorted. The overload
LED indicator(s) is/are not on, or
only light up occasionally.
The mixer
distorting.
Turn mixer channel gains down.
Check that none of your signal
sources are distorting.
Sound is distorted and very loud.
One or more overload LED
indicators light up.
The system is overloaded and has
reached maximum power.
Turn down the mixer's output.
Hum or buzz when a mixer is
connected to the unit.
1.– The console probably has unbalanced outputs. You may be using
an
incorrect
un-balanced
to
balanced cable.
2.– The mixer and the powered
speaker are not plugged into the
same mains outlet.
3.– The audio signal cable is too
long or too close to an AC cable
1.– Read the appendix of this
manual to make a correct unbalanced to balanced cable.
Hum or buzz when using lighting
controls in the same building.
The power on LED indicator(s)
do(es) not light up when the power
connector is rotated and locked at
the ON (LOCK) position.
or
signal
source
is
1.– The audio signal cable is too
long or too close to the lighting
cable.
2.– On a sound system with threephase AC, the lighting equipment
and the UNIT are connected to the
same phase.
1.– Bad or loose AC connection to
the UNIT or the mains outlet.
2 – Faulty AC cable.
3 – Blown Fuse.
No sound from the unit.
Protection LED indicator is on.
The
2.– Connect the mixer and the unit
to the same mains outlet.
3.– Use a cable that is as short as
possible and/or move the audio
signal cable away from mains
cables.
1.– Move the audio signal cable
away from lighting cables. Try to find
out at what point the noise is leaking
into the system.
2.– Connect the sound system to a
different phase than the lights. You
may need the help of an electrician.
1.– Check you connections.
2.– Check the cables, connectors
and AC power with a suitable mains
tester.
3.- Take the unit to a service centre
for replace the blown fuse.
1.- Mains voltage very low or very
high.
2.- Overheating.
1.- Check mains voltage with a
suitable mains tester.
2.- Check input signal because the
level or the EQ are very high.
3.- Overload or short-circuit.
3.- Take the unit to a service centre.
4.- DC at amplifier’s output.
4.- Take the unit to a service centre.
Manual del Usuario / LX-218A / User’s Manual
EN
7
BLOCK DIAGRAM
LF1
Amplifier
Input Clip
LF2
Input
Interface / Leds
DSP
45 Hz
+4dB
33 Hz 82.4 Hz 0.5 oct
HPF
LPF
EQ
Clip
Protection
Signal
Power
Loop thru
AC INPUT
L
Power Supply
N
LINE DRAWINGS
550
1280
650
EN
ALL DIMENSIONS IN MILIMETERS
8
Manual del Usuario / LX-218A / User’s Manual
SPECIFICATIONS
LX-218A
Nominal LF Power Amplifier:
Input Type:
Input Impedance:
Sensitivity:
Frequency Range (-10 dB):
Horizontal Coverage (-6 dB):
Vertical Coverage:
Rated Maximum Peak SPL at 1 m:
Transducers/Replacement Parts:
Enclosure Geometry:
Enclosure Material:
Color/Finish:
Rigging System:
Connectors (DSP input board):
AC Power Requirements:
Dimensions (H x W x D):
Weight:
Accessories:
2400 W (Class D)
Balanced Differential Line
Line: 20 kohms
Line: 1.95 V (+8 dBu)
28 Hz-100 Hz
----141 dB
LF: 2 x 18LX/GM 18LX
Rectangular
Birch Plywood
Black Paint
Ground Stackable (integrated in box design on model LX-218R)
INPUT: Female XLR
LOOP THRU: Male XLR
AC INPUT: PowerCon NAC 3 FCA
Universal Mains 85 -230V, 50Hz/60Hz
55 x 128 x 65 cm
22 x 51 x 26 in
73.5 kg (161.7 lbs)
AX-AERO38 Bumper
AX-AERO48 Bumper
KITR-LX218 Rigging hardware kit
KITW-100 Caster kit
PL-LX218 dolly panel
PL-218S Dolly platform for vertical stacking
D.A.S. Audio S.A. continuously strives to enhance its products through investigation and development. All
specifications are subject to change without prior warning.
Product specifications, detailed technical sheets, as well as information for the use of EASE and other
modelling programs are available at www.dasaudio.com .
EN
Manual del Usuario / LX-218A / User’s Manual
9
APPENDIX: Line connections: unbalanced and balanced
There are two basic ways to transport an audio signal with microphone or line level:
Unbalanced line: Utilising a two conductor cable, it transports the signal as the voltage between them.
Electromagnetic interference can get added to the signal as undesired noise. Connectors that carry
unbalanced signals have two pins, such as RCA (Phono) and ¼” (6.35mm, often referred to as jack) mono. 3
pin connector such as XLR (Cannon) may also carry unbalanced signals if one of the pins is unused.
Balanced line: Utilising a three conductor cable, one of them acts as a shield against electromagnetic
noise and is the ground conductor. The other two have the same voltage with respect to the ground
conductor but with opposite signs. The noise that cannot be rejected by the shield affects both signal
conductors in the same way. At the device’s input the two signals get summed with opposite sign, so that
noise is cancelled out while the programme signal doubles in level. Most professional audio devices use
balanced inputs and outputs. Connectors that can carry balanced signal have three pins, such as XLR
(Cannon) and ¼” (6.35mm) stereo.
The graphs that follow show the recommended connection with different types of connectors to balanced
processor or amplifier inputs. The connectors on the left-hand side come from a signal source, and the ones
on the right hand side go to the inputs of the processor or amplifier. Note that on the unbalanced connectors
on the left-hand side, two terminals are joined in side the connector. If hum occurs with balanced to balanced
connections, try disconnecting the sleeve (ground) on the input connector. Note that the illustrations show
what should be connected to what, but that pin locations on an actual XLR connector are different. Also, pin
2 hot is assumed on XLR connectors.
EN
10
Manual del Usuario / LX-218A / User’s Manual
D.A.S. AUDIO, S.A.
C/. Islas Baleares, 24
46988 Fuente del Jarro
Valencia, SPAIN
Tel. 96 134 0525
Tel. Intl. +34 96 134 0860
Fax 96 134 0607
Fax Intl. +34 96 134 0607
D.A.S. AUDIO OF AMERICA, INC.
Sunset Palmetto Park
6816 NW 77th Court.
Miami, FL. 33166 - U.S.A.
TOLL FREE: 1-888DAS4USA
Tel. +1 305 436 0521
Fax +1 305 436 0528
UM_LX218A_01_EN
www.dasaudio.com
D.A.S. AUDIO ASIA PTE. LTD.
25 Kaki Bukit Crescent #01-00/02-00
Kaki Bukit Techpark 1
Singapore 416256
Tel. +65 6742 0151
Fax +65 6742 0157
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
