5.8GHz
FEATURING
TCO-5808
This product was designed with the harshest
environments in mind and is not susceptible to
interference from 2.4GHz 802.11 b/g networks.
Featuring 8 user selectable channels and rugged
IP-67 all-weather enclosures, this system is ideal for
applications that demand high resolution and real-time
video surveillance and monitoring.
DT-900
The 900MHz DT-900 data radios transmit license free
wireless PTZ controls and other data sources up to
7 miles where trenching cable may not be possible,
convenient or economical. Designed to have the
greatest compatibility with all major pan-tilt-zoom
camera manufacturers. The DT-900 configuration
software allows the user to easily configure the system
to minimize installation time and maximize results in
the most demanding applications.
MXR-5842
The innovative MXR-5842 Kit sends video from
locations normally not possible, convenient or
economical with the industries smallest 5.8GHz
wireless 8 channel user selectable, color camera
system. The system includes a wireless receiver,
AA battery pack holder, universal mounting bracket
and power supplies.
TC-5808
Plug & Play out of the box, the low profile desktop
design is not susceptible to interference from 802.11
b/g networks. Featuring 8 user selectable channels.
This system is perfect for applications ranging from
surveillance to remote monitoring.
TABLE OF CONTENTS
Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Frequency Performance Chart . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.8GHz
All Weather Video Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Desktop Video Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Mini Wireless Cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1 Watt Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Micro Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
High Gain Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.4GHz
All Weather Video Systems . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Indoor Transmitters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
PTZ Digital Data Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
High Gain Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
1.2GHz
All Weather Video Systems . . . . . . . . . . . . . . . . . . . . . . . . . . 38
900MHz
PTZ Digital Data Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Mini Wireless Cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Indoor Transmitters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Indoor Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
High Gain Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
UHF
Indoor Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Indoor Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
ACCESSORIES
Mounting Brackets / Cables / Power Supplies . . . . . . . . . . . . 52
Solar Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Wireless Video Applications . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Contact Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
© Copyright 2006 Printed in Canada
PROFILE
WIRELESS VIDEO
Has created a revolution in security surveillance relieving the costs associated with running
wires over long distances or difficult to reach locations. It offers new opportunities to protect
lives, property and assets, in ways that were impractical until now. Wireless video is reliable and
remarkably affordable and is ready to meet almost any CCTV application you can imagine.
VideoComm Technologies is the recognized market leader in Real-Time wireless video
transmission technologies, products and technical support. From systems serving a single
camera over a few feet, up to multi-camera systems covering large university campuses. Our
wireless video products overcome many of the installation limits applicable to most CCTV
projects.
COST
VideoComm products eliminate the need to run wires. We offer video transmission solutions
that give installers the advantage of saving thousands of dollars in wire, conduit, labor,
under-ground trenching, suspended race ways or dedicated phone lines.
FREEDOM
VideoComm manufactures products for CCTV applications that have been physically impossible
to serve before now. We specialize in wireless video applications capable of using alternate
power sources while also providing complete camera mobility during transmission – including
products for temporary monitoring, mobile surveillance and covert investigations.
SIZE
VideoComm is the industry leader in the manufacturing of micro wireless video products. We
offer the smallest UHF, 900MHz, 2.4GHz and 5.8GHz video transmitters commercially available
on the market today.
DISTANCE
VideoComm manufactures a full range of indoor and outdoor all-weather products that can
transmit video signals economically anywhere from a few hundred feet (through walls), up to
remote monitoring sites 50 miles away.
COMPLETE SOLUTIONS
More than products, VideoComm Technologies is a wireless video solutions provider. Since
1996 we have offered an extensive range of leading-edge technologies, quality manufacturing,
product engineering and application knowledge. With a diverse range of product frequencies,
transmitter sizes and capabilities, we can offer a solution to almost any wireless video scenario.
Not all wireless applications are created equal, we have solutions.
4
IT'S ABOUT REAL-TIME
FREQUENCY PERFORMANCE COMPARISON
VideoComm Technologies is the industry leading manufacturer of a broad spectrum of
Real-Time wireless video products. We offer devices in a variety of sizes, configurations
and power levels for frequencies ranging from UHF, 900MHz, 1.2GHz, 2.4GHz and
5.8GHz, to satisfy the most demanding CCTV applications.
Choice of operating frequency in any application is dependant on a number of different
performance factors. From the chart below, select which frequency category will
perform best for your specific wireless application requirement.
FEATURES
FEATURES
5.8 GHz
2.4 GHz
1.2 GHz
900 MHz
UHF
AVAILABLE CHANNELS
8–16–32
4
4
3
Multiple
INTERFERENCE RISK
Very Low
High
Medium
Medium
Medium
BAND TYPE
FM
FM
FM
AM
AM
RESOLUTION
Excellent
Excellent
Excellent
Good
Average
OPTIMUM RANGE PERFORMANCE
Long
Medium
Medium
Short
Short
OUTDOOR PERFORMANCE
Excellent
Excellent
Excellent
Good
Average
MOBILE Tx OR BODYCAM
Poor
Poor
Average
Good
Excellent
SECURITY/PRIVACY
Excellent
Good
Good
Average
Poor
LICENSE FREE OPERATION
Yes
Yes
No
Yes
No
WOOD
Average
Average
Good
Very Good
Excellent
DRYWALL
Average
Average
Good
Very Good
Excellent
CINDER BLOCK
Average
Average
Average
Good
Very Good
POURED CONCRETE
Average
Average
Average
Good
Very Good
TREES
Average
Average
Average
Good
Good
TINTED/UV COATED WINDOWS
Poor
Poor
Poor
Poor
Poor
METAL
None
None
None
None
None
WIRELESS PENETRATION THROUGH:
5
5.8GHz
TCO-5808R6
Designed with the harshest environments in mind, the robust TCO−5808R6
series delivers high resolution, Real-Time video up to 2,000 feet line of
sight. Its rugged IP−67 all weather enclosure transmits in applications where
trenching cable may not be possible, convenient or economical.
2,000 Feet Range
ADVANTAGES
6
• Easy to install and operate
• Delivers high resolution Real-Time video
• Not susceptible to interference from
2.4GHz 802.11 b/g networks
• Unique embedded transmitter and
receiver antenna system
• 8 user selectable channels
• Range up to 2,000 feet line of sight
• Rugged all weather IP-67 protective enclosure
• Perfect for commercial, industrial, scientific,
law enforcement and government video
security applications
APPLICATIONS INCLUDE
FREEWAYS
PARKING LOTS
AIRPORTS
CONSTRUCTION SITES
MARINAS
INDUSTRIAL
5.8GHz
TCO-5808R6
SPECIFICATIONS
OPERATING FREQUENCY
5.725GHz – 5.875GHz; 8 User Selectable Channels
RADIATED POWER
50mV/m @ 3m
RANGE (LINE–OF–SIGHT)
Up to 2,000 Feet
TRANSMITTER ANTENNA TYPE
3dB Internal Fixed Directional Patch
RECEIVER ANTENNA TYPE
7dB Internal Removable Directional Patch
RECEIVER SENSITIVITY
–84 dBm
VIDEO FORMAT
NTSC or PAL
VIDEO CONNECTOR
BNC Female @ 75 Ohms 1 Volt P–P
AUDIO CONNECTOR
One Left and One Right BNC Female @ 600 Ohms 1 Volt P–P
TEMPERATURE RANGE
-40ºF to +170ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
Transmitter: 230 mA @ 12 VDC Receiver: 330 mA @ 12 VDC
DIMENSIONS
7.0” x 7.0” x 4.5”
MOUNTING BRACKETS
Included – Universal Wall / Pole Mount
WEIGHT
0.9 kg or 32 oz each
FCC / IC / CE APPROVED
Yes
KIT INCLUDES
• ALL WEATHER TRANSMITTER
• ALL WEATHER RECEIVER
• OPERATING INSTRUCTIONS
• TWO 12VDC POWER SUPPLIES
• UNIVERSAL MOUNTING BRACKETS
• ONE YEAR LIMITED WARRANTY
7
5.8GHz
TCO-5808Q4
Designed with the harshest environments in mind, the robust TCO−5808Q4
series delivers high resolution, Real-Time video up to one mile line of sight.
Its rugged IP−67 all weather enclosure transmits in applications where
trenching cable may not be possible, convenient or economical.
One Mile Range
ADVANTAGES
8
• Easy to install and operate
• Delivers high resolution Real-Time video
• Not susceptible to interference from
2.4GHz 802.11 b/g networks
• Unique embedded transmitter and
receiver antenna system
• 8 user selectable channels
• Range up to One Mile line of sight
• Rugged all weather IP-67 protective enclosure
• Perfect for commercial, industrial, scientific,
law enforcement and government video
security applications
APPLICATIONS INCLUDE
FREEWAYS
PARKING LOTS
AIRPORTS
CONSTRUCTION SITES
HARBOR
INDUSTRIAL
5.8GHz
TCO-5808Q4
SPECIFICATIONS
OPERATING FREQUENCY
5.725GHz – 5.875GHz; 8 User Selectable Channels
RADIATED POWER
50mV/m @ 3m
RANGE (LINE–OF–SIGHT)
Up to 1 Mile
TRANSMITTER ANTENNA TYPE
3dB Internal Fixed Directional Patch
RECEIVER ANTENNA TYPE
14dB Internal Removable Directional Patch
RECEIVER SENSITIVITY
–84 dBm
VIDEO FORMAT
NTSC or PAL
VIDEO CONNECTOR
BNC Female @ 75 Ohms 1 Volt P–P
AUDIO CONNECTOR
One Left and One Right BNC Female @ 600 Ohms 1 Volt P–P
TEMPERATURE RANGE
-40ºF to +170ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
Transmitter: 230 mA @ 12 VDC Receiver: 330 mA @ 12 VDC
DIMENSIONS
7.0” x 7.0” x 4.5”
MOUNTING BRACKETS
Included –Universal Wall / Pole Mount
WEIGHT
0.9 kg or 32 oz each
FCC / IC / CE APPROVED
Yes
KIT INCLUDES
• ALL WEATHER TRANSMITTER
• ALL WEATHER RECEIVER
• OPERATING INSTRUCTIONS
• TWO 12VDC POWER SUPPLIES
• UNIVERSAL MOUNTING BRACKETS
• ONE YEAR LIMITED WARRANTY
9
5.8GHz
TCO-5808Q9
Designed with the harshest environments in mind, the robust TCO−5808Q9
series delivers high resolution, Real-Time video up to 4 miles line of sight.
Its rugged IP−67 all weather enclosure transmits in applications where
trenching cable may not be possible, convenient or economical.
Four Mile Range
ADVANTAGES
• Easy to install and operate
• Delivers high resolution Real-Time video
• Not susceptible to interference from
2.4GHz 802.11 b/g networks
• Unique embedded transmitter and
receiver antenna system
• 8 user selectable channels
• Range up to Four Miles line of sight
• Rugged all weather IP-67 protective enclosure
• Perfect for commercial, industrial, scientific,
law enforcement and government video
security applications
10
APPLICATIONS INCLUDE
FREEWAYS
BRIDGES
AIRPORTS
CONSTRUCTION SITES
HARBOR
INDUSTRIAL
5.8GHz
TCO-5808Q9
SPECIFICATIONS
OPERATING FREQUENCY
5.725GHz – 5.875GHz; 8 User Selectable Channels
RADIATED POWER
50mV/m @ 3m
RANGE (LINE–OF–SIGHT)
Up to 4 Miles
TRANSMITTER ANTENNA TYPE
3dB Internal Fixed Directional Patch
RECEIVER ANTENNA TYPE
29dB External Parabolic Dish
RECEIVER SENSITIVITY
–84 dBm
VIDEO FORMAT
NTSC or PAL
VIDEO CONNECTOR
BNC Female @ 75 Ohms 1 Volt P–P
AUDIO CONNECTOR
One Left and One Right BNC Female @ 600 Ohms 1 Volt P–P
TEMPERATURE RANGE
-40ºF to +170ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
Transmitter: 230 mA @ 12 VDC Receiver: 330 mA @ 12 VDC
DIMENSIONS
7.0” x 7.0” x 4.5”
MOUNTING BRACKETS
Included –Universal Wall / Pole Mount
WEIGHT
0.9 kg or 32 oz each
FCC / IC CE / APPROVED
Yes
KIT INCLUDES
• ALL WEATHER TRANSMITTER
• ALL WEATHER RECEIVER
• OPERATING INSTRUCTIONS
• TWO 12VDC POWER SUPPLIES
• UNIVERSAL MOUNTING BRACKETS
• 29dB PARABOLIC DISH ANTENNA
11
5.8GHz
TCO-5816R6
Designed with the harshest environments in mind, the robust TCO−5816R6
delivers high resolution, Real-Time video up to 2,000 feet line of sight.
Its rugged IP−67 all weather enclosure transmits in applications where
trenching cable may not be possible, convenient or economical. This unit
includes a unique embedded video scrambling feature that provides an
additional level of security and privacy.
2,000 Feet Range
ADVANTAGES
• Easy to install and operate
• Delivers high resolution Real-Time video with
a unique video scrambling feature
• Not susceptible to interference from
2.4GHz 802.11 b/g networks
• Unique embedded transmitter and
receiver antenna system
• 16 user selectable channels - 32 channels optional
• Range up to 2,000 feet line of sight
• Rugged all weather IP-67 protective enclosure
• Perfect for commercial, industrial, scientific,
law enforcement and government video
security applications
12
APPLICATIONS INCLUDE
FREEWAYS
PARKING LOTS
AIRPORTS
CONSTRUCTION SITES
MARINAS
INDUSTRIAL
5.8GHz
TCO-5816R6
SPECIFICATIONS
OPERATING FREQUENCY
5.725GHz – 5.875GHz; 16 User Selectable Channels
RADIATED POWER
50mV/m @ 3m
RANGE (LINE–OF–SIGHT)
Up to 2,000 Feet
TRANSMITTER ANTENNA TYPE
3dB Internal Fixed Directional Patch
RECEIVER ANTENNA TYPE
7dB Internal Removable Directional Patch
RECEIVER SENSITIVITY
–94 dBm
VIDEO FORMAT
NTSC or PAL
VIDEO CONNECTOR
BNC Female @ 75 Ohms 1 Volt P–P
AUDIO CONNECTOR
One Left and One Right BNC Female @ 600 Ohms 1 Volt P–P
ALARM INPUT CONNECTOR
Terminal Strip
TEMPERATURE RANGE
-40ºF to +170ºF
POWER SUPPLY INCLUDED
7 – 30 VDC Polarity Protected
CURRENT CONSUMPTION
Transmitter: 70 mA @ 12 VDC Receiver: 180 mA @ 12 VDC
DIMENSIONS
7.0” x 7.0” x 4.5”
MOUNTING BRACKETS
Included –Universal Wall / Pole Mount
WEIGHT
0.9 kg or 32 oz
FCC/IC APPROVED
Yes
KIT INCLUDES
• ALL WEATHER TRANSMITTER
• ALL WEATHER RECEIVER
• OPERATING INSTRUCTIONS
• TWO 12VDC POWER SUPPLIES
• UNIVERSAL MOUNTING BRACKETS
• ONE YEAR LIMITED WARRANTY
13
5.8GHz
TC-5808
Plug & Play out of the box, the low profile desktop design is not susceptible
to interference from 2.4GHz 802.11 b/g networks and data devices. Featuring
8 user selectable channels, this system is the ideal choice when multiple indoor
wireless video links are required for any commercial, industrial or consumer
applications up to 1,000 feet line of sight.
5.8GHz Desktop Transmitter & Receiver
ADVANTAGES
• 8 user selectable channels
• Low profile metal case desktop design with
convenient slots for permanent mounting
• Stereo audio transmission capable
• Convenient front panel frequency selection,
video gain adjustment, power indicator & switch
• Not susceptible to interference from 2.4GHz
802.11 b/g data devices
• Operating voltage from 8.0 to 32 Volts DC with 90% +
efficient, low noise switching voltage regulators
• Ideal solution for portable, temporary and covert
surveillance or monitoring applications
• One Year Limited Warranty
14
APPLICATIONS INCLUDE
MANUFACTURING
RETAIL
TRANSPORTATION
OFFICE
WAREHOUSE
PROPERTY MANAGEMENT
5.8GHz
TC-5808
SPECIFICATIONS
OPERATING FREQUENCY
5.725GHz – 5.875GHz; 8 User Selectable Channels
RADIATED POWER
50mV/m @ 3m
RANGE (LINE-OF-SIGHT)
Up to 1,000 Feet
INDOOR RANGE
Up to 300 Feet
ANTENNA TYPE
Omnidirectional Rubber Duck – SMA Male
RECEIVER SENSITIVITY
-84 dBm
VIDEO FORMAT
NTSC or PAL
VIDEO CONNECTOR
BNC Female @ 75 OHMS 1 Volt P–P
AUDIO CONNECTOR
RCA Female Stereo Left & Right @ 600 OHMS 1 Volt P–P
TEMPERATURE RANGE
-22ºF to +150ºF
OPERATING VOLTAGE
8.0 – 32 VDC – Polarity Protected
CURRENT CONSUMPTION
Transmitter: 140 mA Receiver: 170 mA – @ 12 VDC – 90% + efficient
DIMENSIONS
7.4" x 4.2" x 1.2"each
WEIGHT
441g or 15.5 oz each
FCC / IC / CE APPROVED
Yes
KIT INCLUDES
• DESKTOP TRANSMITTER
• DESKTOP RECEIVER
• TWO 12 VDC POWER SUPPLIES
• TWO RUBBER DUCK ANTENNAS
• OPERATING INSTRUCTIONS
• ONE YEAR LIMITED WARRANTY
15
5.8GHz
MXR-5847VF
The innovative MXR-5847VF Kit sends video from locations normally not
possible, convenient or economical with the industries smallest 5.8GHz
wireless 8 channel user selectable, color varifocal camera system. The
system includes a wireless 470 line high-resolution color CCD camera with
varifocal lens, wireless receiver, AA battery pack holder and power supplies.
470 Lines High Resolution COLOR CCD
ADVANTAGES
• Easy to use – "Plug & Play"
• 8 user selectable channels
• 470 line high resolution color CCD
• Not susceptible to interference from
2.4GHz 802.11 b/g networks
• Range up to 300 feet indoors, 1,000' line of sight
• Extremely low current consumption
• Perfect for office, warehouse or nursery
• Ideal for portable, temporary and covert
surveillance or monitoring applications
• One Year Limited Warranty
16
8
4.0 - 9.0mm Zoom Lens
APPLICATIONS INCLUDE
MANUFACTURING
RETAIL
TRANSPORTATION
OFFICE
WAREHOUSE
PROPERTY MANAGEMENT
5.8GHz
MXR-5847VF
SPECIFICATIONS
OPERATING FREQUENCY
5.725GHz – 5.875GHz; 8 User Selectable Channels
RADIATED POWER
50mV/m @ 3m
RANGE (LINE-OF-SIGHT)
Up to 1,000 Feet
OPERATING DISTANCE INDOORS
Up to 300 Feet
ANTENNA TYPE
Fixed Omnidirectional
CAMERA TYPE
RESOLUTION
Color 1/3" Sharp CCD
470 TV Lines
LENS TYPE
Varifocal 4.0 – 9.0mm F 1.6 - minimum 1.0 Lux
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
Less than 150mA @ 12VDC
DIMENSIONS
1.4” x 2.9” x 3.9" with lens 2.14" without
WEIGHT
80g or 2.8oz
FCC / IC / CE APPROVED
Yes
KIT INCLUDES
• WIRELESS COLOR CAMERA
• DESKTOP RECEIVER
• MOUNTING BRACKET
• RUBBER DUCK ANTENNA
• AA BATTERY PACK HOLDER
• TWO 12 VDC POWER SUPPLIES
• TWO POWER INPUT JUMPER CABLES
• ONE YEAR LIMITED WARRANTY
17
9
5.8GHz
MXR-5842C
MXR-5842BW
The industries smallest 5.8GHz wireless 8 channel user selectable
camera sends video from locations normally not possible, convenient or
economical. The system includes a 420 line high-resolution CCD camera,
receiver, AA battery pack holder, mounting bracket and power supplies.
3.7mm Pinhole Cone Lens
ADVANTAGES
• Easy to use – "Plug & Play"
• 8 user selectable channels
• 420 line high resolution CCD
• Not susceptible to interference from
2.4GHz 802.11 b/g networks
• Range up to 300 feet indoors, 1,000' line of sight
• Extremely low current consumption
• Perfect for office, warehouse or nursery
• Ideal for portable, temporary and covert
surveillance or monitoring applications
• One Year Limited Warranty
18
8
MXR-5842C
5.8GHz
MXR-5842BW
APPLICATIONS INCLUDE
MANUFACTURING
RETAIL
TRANSPORTATION
OFFICE
WAREHOUSE
PROPERTY MANAGEMENT
SPECIFICATIONS
OPERATING FREQUENCY
5.725GHz – 5.875GHz; 8 User Selectable Channels
RADIATED POWER
50mV/m @ 3m
RANGE (LINE-OF-SIGHT)
Up to 1,000 Feet
OPERATING DISTANCE INDOORS
Up to 300 Feet
ANTENNA TYPE
Fixed Omnidirectional
MODEL # MXR-5842C
RESOLUTION
Color 1/3" Sharp CCD - minimum 1.0 Lux
B&W 1/3" Sharp CCD - minimum 0.05 Lux
420 TV Lines
LENS TYPE
3.7mm Pinhole Cone
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
MODEL # MXR-5842BW
CURRENT CONSUMPTION
Less than 150mA @ 12VDC
DIMENSIONS
1.4” x 2.9” x 2.2" with lens
MOUNTING BRACKET
Included
WEIGHT
80g or 2.8 oz
FCC / IC / CE APPROVED
Yes
KIT INCLUDES
• WIRELESS CAMERA
• DESKTOP RECEIVER
• MOUNTING BRACKET
• RUBBER DUCK ANTENNA
• AA BATTERY PACK HOLDER
• TWO 12 VDC POWER SUPPLIES
• TWO POWER INPUT JUMPER CABLES
• ONE YEAR LIMITED WARRANTY
9
19
5.8GHz
MXR-5838C
This versatile 5.8GHz wireless 4 channel user selectable camera sends
video from locations normally not possible, convenient or economical.
The system includes a 420 line high-resolution CCD camera, receiver, AA
battery pack holder, mounting bracket and power supplies.
420 Line Color Camera
ADVANTAGES
• Easy to use – "Plug & Play"
• 4 user selectable channels
• 420 line high resolution CCD
• Not susceptible to interference from
2.4GHz 802.11 b/g networks
• Range up to 300 feet indoors, 1,000' line of sight
• Perfect for office, warehouse or retail
• Ideal for portable, temporary and covert
surveillance or monitoring applications
• One Year Limited Warranty
20
APPLICATIONS INCLUDE
MANUFACTURING
RETAIL
TRANSPORTATION
OFFICE
WAREHOUSE
PROPERTY MANAGEMENT
5.8GHz
MXR-5838C
SPECIFICATIONS
OPERATING FREQUENCY
5.725GHz – 5.875GHz; 4 User Selectable Channels
RADIATED POWER
50mV/m @ 3m
RANGE (LINE-OF-SIGHT)
Up to 1,000 Feet
OPERATING DISTANCE INDOORS
Up to 300 Feet
ANTENNA TYPE
Fixed Directional
CAMERA TYPE
RESOLUTION
Color 1/4" CCD - minimum 1.0 Lux
420 TV Lines
LENS TYPE
3.7mm Wide Angle
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
330mA @ 12VDC
DIMENSIONS
5.8" x 1.95" x 2.77"
MOUNTING BRACKET
Included
WEIGHT
247g or 8.7 oz
FCC / IC / CE APPROVED
Yes
KIT INCLUDES
• WIRELESS CAMERA
• AA BATTERY PACK HOLDER
• DESKTOP RECEIVER
• MOUNTING BRACKET
• RUBBER DUCK ANTENNA
• TWO 12 VDC POWER SUPPLIES
• TWO POWER INPUT JUMPER CABLES
• ONE YEAR LIMITED WARRANTY
21
5.8GHz
MX-5847VF
The innovative MX-5847VF sends
video from locations normally not
possible, convenient or economical
with the industries smallest 5.8GHz
wireless 8 channel user selectable, color
varifocal camera system.
ADVANTAGES
• 8 user selectable channels
• Incredibly sharp high resolution color picture
• Perfect for office, warehouse or nursery
• Ideal for portable, temporary and covert
surveillance or monitoring applications
• Extremely low current consumption
• One Year Limited Warranty
Wireless Color Camera
SPECIFICATIONS
OPERATING FREQUENCY
5.725GHz – 5.875GHz; 8 User Selectable Channels
RADIATED POWER
50mV/m @ 3m
RANGE (LINE–OF–SIGHT)
Up to 1,000 Feet
OPERATING DISTANCE INDOORS
Up to 300 Feet
ANTENNA TYPE
RESOLUTION
Fixed Omnidirectional
Color 1/3" Sharp CCD
470 TV Lines
LENS TYPE
Varifocal 4.0 – 9.0mm F 1.6 - minimum 1.0 Lux
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
Less than 150mA @ 12VDC
DIMENSIONS
1.4” x 2.9” x 3.9" with lens 2.14" without
WEIGHT
80g or 2.8 oz
FCC / IC / CE APPROVED
Yes
CAMERA TYPE
KIT INCLUDES
• WIRELESS CAMERA
• MOUNTING BRACKET
• TWO POWER INPUT JUMPER CABLES
22
• AA BATTERY PACK HOLDER
• 12 VDC POWER SUPPLLY
• ONE YEAR LIMITED WARRANTY
MX-5842C
5.8GHz
MX-5842BW
The innovative MX-5842 color &
black & white sends video from
locations normally not possible,
convenient or economical with the
industries smallest 5.8GHz wireless
8 channel user selectable, color & black
& white pinhole camera system.
ADVANTAGES
• 8 user selectable channels
• Incredibly sharp high resolution color or
black & white picture
• Perfect for office, warehouse or nursery
• Ideal for portable, temporary and covert
surveillance or monitoring applications
• Extremely low current consumption
• One Year Limited Warranty
Wireless Color Camera
SPECIFICATIONS
OPERATING FREQUENCY
5.725GHz – 5.875GHz; 8 User Selectable Channels
RANGE (LINE-OF-SIGHT)
Up to 1,000 Feet
OPERATING DISTANCE INDOORS
Up to 300 Feet
ANTENNA TYPE
Fixed Omnidirectional
MODEL # MX-5842C
RESOLUTION
Color 1/3" Sharp CCD - minimum 1.0 Lux
B&W 1/3" Sharp CCD - minimum 0.05 Lux
420 TV Lines
LENS TYPE
3.7mm Pinhole Cone
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
MODEL # MX-5842BW
CURRENT CONSUMPTION
Less than 150mA @ 12VDC
DIMENSIONS
1.4” x 2.9” x 2.2" with lens
WEIGHT
80g or 2.8 oz
FCC / IC / CE APPROVED
Yes
KIT INCLUDES
• WIRELESS CAMERA
• MOUNTING BRACKET
• TWO POWER INPUT JUMPER CABLES
• AA BATTERY PACK HOLDER
• 12 VDC POWER SUPPLLY
• ONE YEAR LIMITED WARRANTY
23
5.8GHz
WXR-5810w
Dramatically increase range and improve performance with this 5.8GHz
1 Watt RF amplifier. Designed with law enforcement agencies in mind, the
system boosts any 5.8GHz transmitter signal through multiple walls or
obstacles and draws less than 380mA.
1 Watt Tx Amplifier
ADVANTAGES
• Low profile metal case design
• Extremely low current consumption
• Rugged IP-65 all weather enclosure
• Easy set up and operation
SPECIFICATIONS
OPERATING FREQUENCY
5.0GHz – 6.0GHz
OUTPUT POWER
1 Watt
IMPEDANCE
50 Ohms
INPUT VSWR
2:1
INPUT-OUTPUT CONNECTORS
SMA–Female
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
12 – 28 VDC Polarity Protected
CURRENT CONSUMPTION
Less than 380mA @ 12VDC
DIMENSIONS
5.0” x 3.1” x 1.6"
WEIGHT
239g or 8.4 oz
FCC / IC / CE APPROVED
Export – Law Enforcement
KIT INCLUDES
24
• 1 WATT TRANSMITTER AMPLIFIER
• WEATHERPROOF 3-PIN DIN TYPE POWER CABLE
• SMA – MALE TO MALE JUMPER CABLE
• 12 VDC POWER SUPPLY
• ONE LIMITED WARRANTY
Operating in the unlicensed 5.8GHz ISM band, the smallest video transmitter
available on the market sends real-time, high-resolution color video signals
up to 1,000 feet line of sight. The TMX-5808 is the best choice for building
into custom mini cameras or in applications where only a battery is possible.
Perfect for medical, scientific, law enforcement and OEM solutions.
• 8 user selectable channels
• Smallest 5.8GHz video transmitter on the market
• Not susceptible to interference from 2.4GHz
802.11 b/g data devices
• Operating voltage from 8.0 – 32 VDC
• Ideal solution for portable, temporary
and covert surveillance applications
• One Year Limited Warranty
31.7mm
ADVANTAGES
OEM 5.8GHz
TMX-5808
31.7mm
Mini 5.8GHz Tx
SPECIFICATIONS
OPERATING FREQUENCY
5.725GHz – 5.875GHz; 8 User Selectable Channels
RADIATED POWER
50mV/m @3m
RANGE ( LINE-OF-SIGHT)
Up to 1,000 Feet
INDOOR RANGE
Up to 300 Feet
ANTENNA TYPE
Fixed Omnidirectional
VIDEO FORMAT
NTSC or PAL
VIDEO CONNECTOR
2 Micro-Post Male Connectors @ 75 OHMS 1 Volt P–P
TEMPERATURE RANGE
-22ºF to +150ºF
OPERATING VOLTAGE
8.0 – 32 VDC – Polarity Protected
CURRENT CONSUMPTION
40 mA @ 12VDC – 90% + efficient
DIMENSIONS
31.7mm x 31.7mm x 10.5mm
WEIGHT
9.0g or 0.3 oz
FCC / IC / CE APPROVED
Yes
KIT INCLUDES
• MINI
INI 5.8GHz TRANSMITTER
• OMNIDIRECTIONAL WHIP ANTENNA
• 12 VDC POWER SUPPLY
• 2 MINI 9 VOLT BARREL JACKS
• OPERATING INSTRUCTIONS
• ONE YEAR LIMITED WARRANTY
• REQUIRES OPTIONAL RECEIVER AND NOT INCLUDED
25
5.8GHz
ANT-5808ip
Manufactured from the highest quality materials to ensure superior electrical
performance, mechanical durability and longevity. Meet your application
demands by choosing this antenna to increase your signal strength and
improve video quality.
ADVANTAGES
• Improve video quality and signal strength
• Unique design capable up to 110 degree tilt
• Magnetic mount base for quick deployment
• Convenient screw tab slots for permanent
wall or ceiling mounting
• Two Year Limited Warranty
Side View
Desktop Antenna
Wall Mount
8dB DIRECTIONAL DESKTOP ANTENNA
• Ideal for temporary or permanent indoor
equipment applications
• Frequency range: 4.9 – 5.85GHz
• Impedance: 50 Ohms
• Beam Width: Horizontal 55 degrees
Vertical 40 degrees
• Dimensions: 2.7" x 3.0" x 4.2"
• Fixed 18" low loss microwave cable
with SMA-Male connector
26
Magnetic Mount
Designed to connect to your VideoComm Technologies 5.8GHz video/audio
receiver, this series of specialty antennas allows you to match the antenna
to your specific application needs. Manufactured from the highest quality
materials to ensure superior electrical performance, mechanical durability and
longevity from the harsh elements of weather. Meet your application demands
by choosing this antenna to increase your signal strength and improve video
quality.
5.8GHz
Antennas
ADVANTAGES
• Improve video quality and signal strength
• Increase transmission range
• All-Weather construction
• All Antennas – 50 Ohm Impedance
• Mounting brackets and hardware included
• "Plug & Play" and ready to install
• Two Year Limited Warranty
8dB HIGH GAIN OMNIDIRECTIONAL ANTENNA
• Ideal for permanent, indoor and outdoor applications
• Frequency range: 5.2 – 5.9GHz
• Beam Width: Horizontal 360 degrees
Vertical 12 degrees
• Dimensions: 0.8" x 15.6"
• Maximum 2.0" pole mount
• Includes 6 feet low loss microwave cable
and mounting bracket
ANT-5808OD
17dB HIGH GAIN DIRECTIONAL ANTENNA
• Ideal for permanent, indoor and outdoor applications
• Frequency range: 5.2 – 5.9GHz
• Beam Width: Horizontal 25 degrees
Vertical 25 degrees
• Dimensions: 9.75" x 1.75"
• Maximum 2.0" pole mount
• Includes 6 feet low loss microwave cable
• Includes unique tilting mounting bracket for adjusting
vertical or horizontal polarization
ANT-5817DP
29dB HIGH GAIN PARABOLIC ANTENNA
• Ideal for permanent, indoor and outdoor applications
• Frequency range: 5.725 – 5.85GHz
• Beam Width: Horizontal 6 degrees
Vertical 6 degrees
• Dimensions: 25.5" Diameter
• Maximum 3.0" pole mount
• Includes 6 feet low loss microwave cable
• Includes unique pan-tilt mounting bracket for adjusting
vertical or horizontal polarization
PARA-5829
27
2.4GHz
TCO-2415R
TCO-2415L
Easy to install, the TCO-2415 series is a fully weatherproof 2.4GHz
wireless video transmitter and receiver system that's ready to operate right
out the box. Simply connect a power supply, video cable, aim and shoot. With a
range up to 1,500 feet, this system is the best choice for short range wireless
applications.
1,500 Feet Range
ADVANTAGES
• Easy to install and operate
• Delivers high resolution Real-Time video
• 4 user selectable channels
• Unique embedded transmitter and
receiver antenna system
• Range up to 1,500 feet line of sight
• Perfect for commercial, industrial, scientific,
law enforcement and government video
security applications
28
TCO-2415L
APPLICATIONS INCLUDE
FREEWAYS
PARKING LOTS
AIRPORTS
CONSTRUCTION SITES
MARINAS
INDUSTRIAL
2.4GHz
TCO-2415R
SPECIFICATIONS
OPERATING FREQUENCY
2.41GHz – 2.47GHz; 4 User Selectable Channels
RADIATED POWER
50mV/m @ 3m
RANGE (LINE–OF–SIGHT)
Up to 1,500 Feet
TRANSMITTER ANTENNA TYPE
3dB Internal Circular Directional Patch
RECEIVER ANTENNA TYPE
3dB Internal Circular Directional Patch
RECEIVER SENSITIVITY
–84 dBm
VIDEO FORMAT
NTSC or PAL
VIDEO CONNECTOR
BNC-Male @ 75 Ohms 1 Volt P–P
AUDIO CONNECTOR
One Left and One Right BNC-Male @ 600 Ohms 1 Volt P–P
TEMPERATURE RANGE
-30ºF to +170ºF
POWER SUPPLY INCLUDED
12 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
Transmitter: 140 mA @ 12 VDC Receiver: 350 mA @ 12 VDC
DIMENSIONS
8.25” x 8.25” x 4.25” each
MOUNTING BRACKETS
Included – Maximum 2" Diameter Mast Mount
WEIGHT
2.0 kg or 4.4 lbs each
FCC / IC APPROVED
Yes
KIT INCLUDES
• ALL WEATHER TRANSMITTER
• ALL WEATHER RECEIVER
• OPERATING INSTRUCTIONS
• TWO 12VDC POWER SUPPLIES
• MOUNTING BRACKETS AND HARDWARE
• ONE YEAR LIMITED WARRANTY
29
2.4GHz
TC-2445
TC-2485
TC-2495
Ideal for short to long range transmission when
running cable is not possible, economical or
convenient. These transmitters are mounted in
a metal case for improved EMI / RFI shielding
and includes a rubber duck antenna to ensure
a robust RF signal. With four user selectable
frequencies, this system is perfect for
applications ranging from surveillance to remote
monitoring.
ADVANTAGES
• Eliminates the need for cabling or trenching
• Sends video from locations normally not possible,
convenient or economical with cable
• Ideal for portable, temporary and covert
surveillance or monitoring applications
• Four user selectable channels
• One Year Limited Warranty
4 Channels
SPECIFICATIONS
MODELS
# TC-2445
OPERATING FREQUENCY
2.4108GHz – 2.4728GHz; 4 User Selectable Channels
# TC-2495
RADIATED POWER
50mV/m @ 3m
100mW
900mW
RANGE (LINE–OF–SIGHT)
1,000 Feet
2,000 Feet
One Mile
ANTENNA TYPE
Omnidirectional Rubber Duck
VIDEO FORMAT
NTSC or PAL
VIDEO CONNECTOR
BNC Male @ 75 Ohms 1 Volt P–P
AUDIO CONNECTOR
BNC Female @ 600 Ohms 1 Volt P–P
TEMPERATURE RANGE
-22ºF to +150ºF
POWER SUPPLY INCLUDED
CURRENT CONSUMPTION: TX
12 VDC Polarity Protected
140mA
200 mA
CURRENT CONSUMPTION: RX
350 mA @ 12 VDC
DIMENSIONS
2.30" x 5.25" x 1.25" each
WEIGHT
FCC / IC APPROVED
KITS INCLUDE
30
# TC-2485
• VIDEO TRANSMITTER
• VIDEO RECEIVER
• TWO RUBBER DUCK ANTENNAS
• TWO 12VDC POWER SUPPLIES
• ONE YEAR LIMITED WARRANTY
390 mA
213g or 7.5 oz each
YES
PART 90 AVAILABLE
2.4GHz
T-2490
The T-2490 features an incredible 900mW of
RF power, packed into the smallest design
ever created for 2.4GHz video transmission.
Weighing just over 45g (antenna excluded), this
little powerhouse was intended for long-range
transmission or punching through multiple walls.
This unit is perfectly suited for building into
custom mini camera housings and applications
where only battery use is possible.
ADVANTAGES
• Easy to use – "Plug & Play"
• Four user selectable channels
• Eliminates the need for cabling or trenching
• Powerful 900mW of RF
• Smallest configuration, only 45g
• Ideal for law enforcement, military, RC robots
and RC plane applications
Super Power
SPECIFICATIONS
OPERATING FREQUENCY
2.4108GHz – 2.4728GHz; 4 User Selectable Channels
RADIATED POWER
900mW
RANGE (LINE–OF–SIGHT
Up to 1 Mile
VIDEO FORMAT
NTSC or PAL
ANTENNA TYPE
2.13" x 5.25" Directional Patch – SMA Male Connector
VIDEO IMPEDANCE & LEVEL
75 Ohms @ 1 Volt P–P
AUDIO IMPEDANCE & LEVEL
600 Ohms @ 1 Volt P–P
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
12 VDC Polarity Protected
CURRENT CONSUMPTION
390 mA @ 9 VDC
DIMENSIONS
1.0" x 2.5" x 0.25" ( not including antenna)
WEIGHT
45g or 1.6 oz ( not including antenna)
FCC / IC APPROVED
PART 90 AVAILABLE
KIT INCLUDES
• SUPER POWER TRANSMITTER
• DIRECTIONAL PATCH ANTENNA
• 7.5 VDC POWER SUPPLY
• OPERATING INSTRUCTIONS
• ONE YEAR LIMITED WARRANTY
• VIDEO RECEIVER NOT INCLUDED
31
2.4GHz
T-2440X
T-2480X
This Multi-Channel series is the smallest and most versatile transmitter of its
kind on the market today. With standard features including four user selectable
channels, audio line level, the multi-channel series is perfectly suited for
building into custom mini camera housings and in applications where only
battery use is possible.
4 Channel Mini Transmitter
ADVANTAGES
• Easy to use – "Plug & Play"
• Four user selectable channels
• Standard features include audio line level input
• Includes video receiver and power supplies
• Eliminates the need for cabling or trenching
• Outperforms 900MHz for use with color
or high resolution cameras
• Video Transmitter and Receiver included
• One Year Limited Warranty
32
T-2480X
APPLICATIONS INCLUDE
MANUFACTURING
RETAIL
TRANSPORTATION
OFFICE
WAREHOUSE
PROPERTY MANAGEMENT
2.4GHz
T-2440X
SPECIFICATIONS
MODEL
# T-2440x
OPERATING FREQUENCY
2.4108GHz – 2.4728GHz; 4 User Selectable Channels
#T-2480x
RADIATED POWER
50mV/m @ 3m
100mW
RANGE (LINE–OF–SIGHT)
Up to 900 Feet
Up to 1,700 Feet
ANTENNA TYPE
Fixed Directional
VIDEO FORMAT
NTSC or PAL
VIDEO CONNECTOR
RCA Male @ 75 Ohms 1 Volt P–P
AUDIO CONNECTOR
RCA Male @ 600 Ohms 1 Volt P–P
TEMPERATURE RANGE
-30ºF to +170ºF
POWER SUPPLY INCLUDED
CURRENT CONSUMPTION
DIMENSIONS
WEIGHT
FCC / IC APPROVED
8 –14 VDC Polarity Protected
45 mA @ 12 VDC
95mA @12VDC
Tx: 1" x 2.5" x 0.5" Rx: 2.3" x 5.3" x 1.3"
Tx: 37g or 1.3 oz Rx: 213g or 7.5 oz
# T-2440x – YES
#T-2480x – N/A
KIT INCLUDES
• MINI VIDEO TRANSMITTER
• WIRELESS VIDEO RECEIVER
• TWO 12VDC POWER SUPPLY
• 2.4GHz RUBBER DUCK ANTENNA
• AA BATTERY PACK HOLDER
• ONE YEAR LIMITED WARRANTY
33
2.4GHz
DT-2400
The 2.4GHz DT-2400 digital spread spectrum data radios transmit license free
wireless PTZ controls and other data sources up to 3 miles where trenching
cable may not be possible, convenient or economical. Designed to have the
greatest compatibility with all major pan-tilt-zoom camera manufacturers, the
DT-900 configuration software allows the user to easily configure the system
to minimize installation time and maximize results for the most demanding of
application needs.
010011000 10
10011100110
010011000 10
1 001110011
Range up to 3 miles
ADVANTAGES
34
• Rugged IP-67 enclosures
• License free range up to 3 miles,
up to 10 miles with optional high gain antenna
• Programming software included
• Compatible with most PTZ camera systems
and other data sources
• RS-422, RS-485, or RS-232 compatible
• Excellent penetration through walls
• Point–to–Point or Point to Multi–Point capable
• Data outputs from sensors, gauges or alarm
• Gates, parking lots, highways, warehouses, refineries,
power stations, or other commercial and industrial scenario systems
• One year limited warranty
APPLICATIONS INCLUDE
FREEWAYS
PARKING LOTS
AIRPORTS
CONSTRUCTION SITES
MARINAS
INDUSTRIAL
2.4GHz
DT-2400
SPECIFICATIONS
OPERATING FREQUENCY
2.4000GHz – 2.4835GHz Digital Spread Spectrum
RADIO TECHNIQUE
Full Duplex, Frequency Hopping
MODULATION
Frequency Shift Keying (FSK), Direct FM
ANTENNA TYPE
Omnidirectional Rubber Duck
DATA FORMATS
RS-422, RS-485, or RS-232
PROGRAMMABLE DATA RATES
1,200bps – 57.6Kbps selectable
SERIAL DATA THROUGHOUT
9,600bps – 19.2Kbps selectable
RF POWER / SENSITIVITY
50mW @ – 102dBm
TEMPERATURE RANGE
-40ºF to +170ºF
POWER SUPPLY INCLUDED
7 – 18 VDC Polarity Protected
CURRENT CONSUMPTION
Transmitter: 200 mA Receiver: 70 mA
DIMENSIONS
7.0" x 7.0" x 4.5" each
MOUNTING BRACKETS
Included – Universal Wall / Pole Mount
WEIGHT
32oz or 0.9 kg each
FCC / IC APPROVED
Yes
KIT INCLUDES
• ALL-WEATHER DATA TRANSMITTER
• ALL-WEATHER DATA RECEIVER
• TWO 12 VDC POWER SUPPLIES
• TWO 2.4GHz RUBBER DUCK ANTENNAS
• UNIVERSAL MOUNTING BRACKETS
• DB-9 PROGRAMMING CABLE AND SOFTWARE
• OPERATING INSTRUCTIONS
• ONE YEAR LIMITED WARRANTY
35
2.4GHz
DXR-2400
The 2.4GHz indoor digital spread spectrum
data radio transmits license free wireless PTZ
controls and other data sources up to 3 miles
where trenching cable may not be possible,
convenient or economical. Designed to have
the greatest compatibility with all major pantilt-zoom camera manufacturers, the system
includes configuration software to minimize
installation time and maximize results.
11000 10
10011100110
0011000 10
1 001110011
ADVANTAGES
• License free range up to 3 miles
• Program software included
• Compatible with most PTZ camera systems
and other data sources
• RS-422, RS-485, or RS-232 compatible
• Excellent penetration through walls
• Point–to–Point or Point to Multi–Point capable
• Data outputs from sensors, gauges or alarms
• One year limited warranty
Up to 3 Miles
SPECIFICATIONS
OPERATING FREQUENCY
2.4000GHz – 2.4835GHz Digital Spread Spectrum
RADIO TECHNIQUE
Full Duplex, Frequency Hopping
MODULATION
Frequency Shift Keying (FSK), Direct FM
ANTENNA TYPE
Omnidirectional Rubber Duck
DATA FORMATS
RS-422, RS-485, or RS-232
PROGRAMMABLE DATA RATES
1,200bps – 57.6Kbps Selectable
RF POWER / SENSITIVITY
50mW @ – 102dBm
TEMPERATURE RANGE
-40ºF to +170ºF
CURRENT CONSUMPTION
190mA @ 12VDC
DIMENSIONS
2.8" x 6.0" x 1.1"
WEIGHT
200g or 7.1 oz
FCC / IC APPROVED
Yes
KIT INCLUDES
36
• DATA TRANSCEIVER
• 12 VDC POWER SUPPLY
• RUBBER DUCK ANTENNA
• PROGRAMMING CABLE & SOFTWARE
• ONE YEAR LIMITED WARRANTY
Designed to connect to your VideoComm Technologies 2.4GHz video/audio receiver,
this series of specialty antennas allows you to match the antenna to your specific
application needs. Manufactured from the highest quality materials to ensure superior
electrical performance, mechanical durability and longevity from the harsh elements of
weather. Meet your application demands by choosing this antenna to increase your signal
strength and improve video quality.
ADVANTAGES
• Improve video quality and signal strength
• Increase transmission range
• All-Weather construction
• All Antennas – 50 Ohm Impedance
2.4GHz
Antennas
• Mounting brackets and hardware included
• "Plug & Play" and ready to install
• Two Year Limited Warranty
15dB HIGH GAIN DIRECTIONAL ANTENNA
• Ideal for permanent, indoor and outdoor applications
• Frequency range: 2.4 – 2.5GHz
• Beam Width: Horizontal 42 degrees
Vertical 31 degrees
• Dimensions: 9.6" x 8.5" x 2.2"
• Maximum 2.0" pole mount
• Includes 6 feet low loss microwave cable
and mounting bracket
• Includes unique vertical tilting mounting bracket
ANT-2415dp
13dB HIGH GAIN OMNIDIRECTIONAL ANTENNA
• Ideal for permanent, indoor and outdoor applications
• Frequency range: 2.4 – 2.5GHz
• Beam Width: Horizontal 360 degrees
Vertical 7 degrees
• Dimensions: 48" x 0.6"
• Maximum 2.0" pole mount
• Includes 6 feet low loss microwave cable
• Includes mounting bracket and hardware
ANT-2413od
24dB HIGH GAIN PARABOLIC ANTENNA
• Ideal for permanent, indoor and outdoor applications
• Frequency range: 2.4 – 2.5GHz
• Beam Width: Horizontal 9.5 degrees
Vertical 8 degrees
• Dimensions: 34" x 28"
• Maximum 3.0" pole mount
• Includes 6 feet low loss microwave cable
• Includes unique pan-tilt mounting bracket for adjusting
vertical or horizontal polarization
PARA-2424
Para-2424
37
1.2GHz
TCO-1245
TCO-1291SP
All-Weather 1.2GHz wireless video transmitter and receiver system that's ready
to operate right out of the box. Designed with the harshest environments in
mind, the robust TCO-1200 series delivers high resolution, Real-Time video
from rugged IP-67 all-weather enclosures.
4 Channels
ADVANTAGES
• Easy to install and operate
• Rugged all weather IP-67 protective enclosure
• Four user selectable channels
• Eliminates the need for cabling or trenching
• Perfect for law enforcement and government
video security applications
• One Year Limited Warranty
38
TCO-1245
APPLICATIONS INCLUDE
FREEWAYS
PARKING LOTS
AIRPORTS
CONSTRUCTION SITES
HARBOR
INDUSTRIAL
1.2GHz
TCO-1291SP
SPECIFICATIONS
MODEL
# TCO-1245
OPERATING FREQUENCY
1.080GHz - 1.2GHz; 4 User Selectable Channels
# TCO-1291sp
RADIATED POWER
200mW
RANGE (LINE–OF–SIGHT)
Up to 1,500 Feet
1 Watt
Up to One Mile
ANTENNA TYPE
Omnidirectional Rubber Duck
VIDEO FORMAT
NTSC
VIDEO CONNECTOR
BNC Female @ 75 Ohms 1 Volt P–P
AUDIO CONNECTOR
BNC Female @ 600 Ohms 1 Volt P–P
TEMPERATURE RANGE
-40ºF to +170ºF
POWER SUPPLY INCLUDED
CURRENT CONSUMPTION
12 – 14 VDC Polarity Protected
120mA @ 12 DVC
530mA @ 12 DVC
DIMENSIONS
7.0” x 7.0” x 4.5” each
MOUNTING BRACKETS
Included –Universal Wall / Pole Mount
WEIGHT
FCC / IC APPROVED
0.9 kg or 32 oz each
N/A – Amateur Radio, Law Enforcement, Government & Export
KIT INCLUDES
• ALL WEATHER TRANSMITTER
• ALL WEATHER RECEIVER
• TWO RUBBER DUCK ANTENNAS
• TWO 12VDC POWER SUPPLIES
• UNIVERSAL MOUNTING BRACKETS
• ONE YEAR LIMITED WARRANTY
39
900MHz
DT-900
The 900MHz DT-900 digital spread spectrum data radios transmit license
free wireless PTZ controls and other data sources up to 7 miles where
trenching cable may not be possible, convenient or economical. Designed for
the greatest compatibility with all major pan-tilt-zoom camera manufacturers,
the configuration software allows the user to easily configure the system to
minimize installation time and maximize results for the most demanding
applications.
010011000 10
10011100110
010011000 10
1 001110011
Range up to 7 miles
ADVANTAGES
40
• Rugged IP-67 enclosures
• License free range up to 7 miles
• Programming software included
• Compatible with most PTZ camera systems
and other data sources
• RS-422, RS-485, or RS-232 compatible
• Excellent penetration through walls
• Point–to–Point or Point to Multi–Point capable
• Data outputs from sensors, gauges or alarm
• Gates, parking lots, highways, warehouses, refineries,
power stations, or other commercial and industrial scenario systems
• One year limited warranty
APPLICATIONS INCLUDE
FREEWAYS
PARKING LOTS
AIRPORTS
CONSTRUCTION SITES
MARINAS
INDUSTRIAL
900MHz
DT-900
SPECIFICATIONS
OPERATING FREQUENCY
902MHz – 928MHz Digital Spread Spectrum
RADIO TECHNIQUE
Full Duplex, Frequency Hopping
MODULATION
Frequency Shift Keying (FSK). Direct FM
ANTENNA TYPE
Omnidirectional Rubber Duck
DATA FORMATS
RS-422, RS-485, or RS-232
PROGRAMMABLE DATA RATES
2400bps – 57.6Kbps
RF POWER / SENSITIVITY
140mW @ – 107dBm
TEMPERATURE RANGE
-40ºF to +170ºF
POWER SUPPLY INCLUDED
7 – 18 VDC Polarity Protected
CURRENT CONSUMPTION
Transmitter: 190 mA Receiver: 70 mA
DIMENSIONS
7.0" x 7.0" x 4.5" each
MOUNTING BRACKETS
Included – Universal Wall / Pole Mount
WEIGHT
32oz or 0.9 kg each
FCC / IC APPROVED
Yes
KIT INCLUDES
• ALL-WEATHER DATA TRANSMITTER
• ALL-WEATHER DATA RECEIVER
• TWO 12 VDC POWER SUPPLIES
• TWO RUBBER DUCK ANTENNAS
• UNIVERSAL MOUNTING BRACKETS
• DB-9 PROGRAMMING CABLE AND SOFTWARE
• OPERATING INSTRUCTIONS
• ONE YEAR LIMITED WARRANTY
41
900MHz
DXR-900
The 900MHz DXR-900 digital spread
spectrum data radio transmits license
free wireless PTZ controls and other data
sources up to 7 miles where trenching
cable may not be possible, convenient
or economical. Designed to have the
greatest compatibility with all major
pan-tilt-zoom camera manufacturers, the
system includes configuration software to
minimize installation time and maximize
results.
11000 10
10011100110
0011000 10
1 001110011
Range up to 7 miles
ADVANTAGES
• License free range up to 7 miles
• Program software included
• Compatible with most PTZ camera systems
and other data sources
• RS-422, RS-485, or RS-232 compatible
• Excellent penetration through walls
• Point–to–Point or Point–to–Multi–Point capable
• Data outputs from sensors, gauges or alarm
• Gates, parking lots, highways, warehouses,
refineries, power stations, or other commercial
and industrial scenario systems
• One year limited warranty
SPECIFICATIONS
OPERATING FREQUENCY
902MHz – 928MHz Digital Spread Spectrum
RADIO TECHNIQUE
Full Duplex, Frequency Hopping
MODULATION
Frequency Shift Keying (FSK), Direct FM
ANTENNA TYPE
Omnidirectional Rubber Duck
DATA FORMATS
RS-422, RS-485, or RS-232
PROGRAMMABLE DATA RATES
2400bps – 57.6Kbps Selectable
RF POWER / SENSITIVITY
140mW @ – 107dBm
TEMPERATURE RANGE
-40ºF to +170ºF
CURRENT CONSUMPTION
190mA @ 12VDC - Polarity Protected
DIMENSIONS
2.8" x 6.0" x 1.1"
WEIGHT
200g or 7.1 oz
FCC / IC APPROVED
Yes
KIT INCLUDES
42
• DATA TRANSCEIVER
• 12 VDC POWER SUPPLY
• 900MHz RUBBER DUCK ANTENNA
• ONE YEAR LIMITED WARRANTY
MSC-916CR
900MHz
MSC-906CR
The 900MHz Mini-SpyCam wireless
COLOR camera series sends Real-Time,
high resolution, color video signals
in applications ranging from covert
surveillance to remote monitoring.
ADVANTAGES
• Size: only 1.37" x 2.1" x 0.65"
• Eliminates the need for cabling or trenching
• Perfect for office, warehouse, nursery and more
• Outperforms 2.4GHz for penetration through walls,
mobile and bodycam applications
• One Year Limited Warranty
Wireless Color Camera
SPECIFICATIONS
MODEL
# MSC-906CR
# MSC-916CR
FIXED FREQUENCY
906MHz
916MHz
RADIATED POWER
50mW / m @ 3m
RANGE (LINE–OF–SIGHT
Up to 1,000 Feet ( 400 Feet Indoors )
ANTENNA TYPE
Fixed Omnidirectional
VIDEO FORMAT
NTSC
COLOR CMOS CAMERA
3.7mm Auto Iris 2 Lux
RESOLUTION
380 Lines ( H ) x 350 Lines ( V )
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
75 mA @ 12VDC
DIMENSIONS
1.37" x 2.1" x 0.65"
WEIGHT
23g or 0.8 oz
FCC / IC APPROVED
Yes
KIT INCLUDES
• WIRELESS COLOR CAMERA
• WIRELESS RECEIVER
• UNIVERSAL MOUNTING BRACKET
• AA BATTERY PACK HOLDER
• RUBBER DUCK ANTENNA
• TWO 12 VDC POWER SUPPLY
• OPERATING INSTRUCTIONS
43
900MHz
T-906
T-916
Ideal choice for building into custom mini
camera housings, these tiny transmitters are
perfectly suited for applications where only
a battery is possible. Choose one of two
fixed frequencies for applications ranging
from surveillance to remote monitoring.
ADVANTAGES
• Ideal for portable, temporary and covert
surveillance or monitoring applications
• Low current consumption for convenient battery
operation
• Custom configure your own wireless video camera
• Eliminates the need for cabling or trenching
• One Year Limited Warranty
Low Current Consumption
SPECIFICATIONS
MODEL
# T-906
FIXED FREQUENCY
906MHz
# T-916
916MHz
RADIATED POWER
50 mV / m @ 3m
RANGE (LINE–OF–SIGHT)
Up to 1,000 Feet
ANTENNA TYPE
Fixed Omnidirectional
VIDEO FORMAT
NTSC
VIDEO CONNECTOR
RCA Male @ 75 Ohms 1V P–P
AUDIO CONNECTOR
NONE
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
50 mA @ 12VDC
DIMENSIONS
0.75" x 0.6" x 0.2"
WEIGHT
12g or 0.4 oz
FCC/IC APPROVED
YES
KIT INCLUDES
44
• MINI TRANSMITTER
• 12 VDC POWER SUPPLY
• ONE YEAR LIMITED WARRANTY
• REQUIRES 900MHz RECEIVER – NOT INCLUDED
T-916AHPM
900MHz
T-906AHPM
These transmitters are perfectly
suited for applications where only a
battery is possible. Connecting video and
power source is easy with convenient
terminal strip input. Choose one of two
fixed frequencies for applications ranging
from surveillance to remote monitoring.
ADVANTAGES
• Ideal for portable, temporary and covert
surveillance or monitoring applications
• Low current consumption for convenient battery
operation
• Custom configure your own wireless video camera
• Easy connect terminal strip for quick setup
• One Year Limited Warranty
Low Current Consumption
SPECIFICATIONS
MODEL
# T-906AHPM
# T-916AHPM
FIXED FREQUENCY
906MHz
916MHz
RADIATED POWER
350 mW
RANGE (LINE–OF–SIGHT)
Up to 3,000 Feet
ANTENNA TYPE
Fixed Omnidirectional
VIDEO FORMAT
NTSC
VIDEO CONNECTOR
Terminal Block @ 75 Ohms 1V P–P
AUDIO CONNECTOR
Terminal Block @ 60O hms 1V P–P
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
100 mA @ 12 VDC
DIMENSIONS
2.5" x 1.1" x 0.2"
WEIGHT
45g or 1.5 oz
FCC/IC APPROVED
N/A
KIT INCLUDES
• MINI TRANSMITTER
• 12 VDC POWER SUPPLY
• ONE YEAR LIMITED WARRANTY
• REQUIRES 900MHz RECEIVER – NOT INCLUDED
45
900MHz
TC-916 / TC-906
TC-916HP / TC-906HP
The TC-900 wireless transmitter series is
ideal for punching video through walls
or other objects when running cable is
not possible or economical. Mounted in
a metal case for improved EMI / RFI
shielding and includes a Rubber Duck
antenna to ensure a robust RF signal.
Choose one of two fixed frequencies for
applications ranging from surveillance to
remote monitoring.
ADVANTAGES
• Easy to use – "Plug & Play"
• Transmitter Size: 2.5" x 1.5" x 0.6"
• Punches through concrete or cinder block walls
• Outperforms 2.4GHz for wall penetration, mobile
and bodycam applications
• One Year Limited Warranty
Punches Through Concrete
SPECIFICATIONS
POWER TYPE
Low Power
High Power
916 MHz MODELS
# TC-916
# TC-916HP
906 MHz MODELS
# TC-906
# TC-906HP
RADIATED POWER
50 mV / m @ 3m
250 mW
RANGE (LINE–OF–SIGHT)
Up to 1,000 Feet
Up to 2,000 Feet
ANTENNA TYPE
Omnidirectional Rubber Duck
VIDEO FORMAT
NTSC
VIDEO CONNECTOR
RCA Female @ 75 Ohms 1 Volt P–P
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
50 mA @ 12 VDC
80 mA @ 12 VDC
DIMENSIONS
2.5” x 1.5” x 0.6”
2.5” x 1.5” x 0.6”
WEIGHT
99g or 3.5 oz
99g or 3.5 oz
FCC / IC APPROVED
YES
N/A
KIT INCLUDES
46
• VIDEO TRANSMITTER
• 12 VDC POWER SUPPLY
• RUBBER DUCK ANTENNA
• ONE YEAR LIMITED WARRANTY
• REQUIRES 900MHz RECEIVER – NOT INCLUDED
TC-916SP
900MHz
TC-906SP
The TC-900 SUPER POWER series
was made with law enforcement in
mind. Capable of punching through an
entire building, this "little power house"
was intended for transmission through
multiple walls. Choose one of two fixed
frequencies for applications ranging from
surveillance to remote monitoring.
ADVANTAGES
• Easy to use – "Plug & Play'
• 750mW RF power Punches through
concrete or cinder block walls
• Outperforms 2.4GHz for wall penetration,
mobile and bodycam applications
• One Year Limited Warranty
Range up to 5,700 Feet
SPECIFICATIONS
MODEL
# TC-906sp
# TC-916sp
FIXED FREQUENCY
906MHz
916MHz
RADIATED POWER
750 mW
RANGE (LINE–OF–SIGHT)
Up to 5,700 Feet
ANTENNA TYPE
Omnidirectional Rubber Duck
VIDEO FORMAT
NTSC
VIDEO CONNECTOR
RCA Female @ 75 Ohms 1 Volt P–P
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
90 mA @ 12VDC
DIMENSIONS
2.5" x 1.5" x 0.6"
WEIGHT
99g or 3.5 oz
FCC / IC APPROVED
N/A
KIT INCLUDES
• VIDEO TRANSMITTER
• 12 VDC POWER SUPPLY
• RUBBER DUCK ANTENNA
• ONE YEAR LIMITED WARRANTY
• REQUIRES 900MHz RECEIVER – NOT INCLUDED
47
900MHz
CCR-900
The CCR-900 video receiver offers
rock-solid frequency stability by
utilizing a microprocessor controlled
PPL tuning system. Use this receiver for
all AM band 900MHz transmitters and
enjoy trouble free operation without
re-tuning or adjusting in any environment.
ADVANTAGES
• 902 – 928MHz user selectable
• Convenient signal strength indicator
• Power On/Off Switch with LED indicator
• Convenient Terminal Block connectors for
various power supply input options
• One Year Limited Warranty
Range 902MHz – 928MHz
SPECIFICATIONS
OPERATING FREQUENCY
902MHz – 928MHz
FREQUENCY SELECTION
User Selectable
FREQUENCY STABILITY
Micro Processor Controlled PLL
ANTENNA TYPE
Omnidirectional Rubber Duck
ANTENNA CONNECTOR
TNC Female
VIDEO FORMAT
NTSC
VIDEO CONNECTOR
BNC Female @ 75 Ohms 1 Volt P–P
AUDIO CONNECTOR
RCA Female @ 600 Ohms 1 Volt P–P
TEMPERATURE RANGE
-20ºF to +150ºF
POWER SUPPLY INCLUDED
Terminal Block Input 6.4 – 24 VDC – Polarity Protected
CURRENT CONSUMPTION
200mA @ 6.4 VDC
DIMENSIONS
5.37” x 4.25” x 1.44”
WEIGHT
416g or 14.7 oz
FCC / IC APPROVED
YES
KIT INCLUDES
48
• VIDEO RECEIVER
• 12 VDC POWER SUPPLY
• RUBBER DUCK ANTENNA
• ONE YEAR LIMITED WARRANTY
Designed to connect to your VideoComm Technologies 900MHz video/audio receiver,
this series of specialty antennas allows you to match the antenna to your specific
application needs. Manufactured from the highest quality materials to ensure superior
electrical performance, mechanical durability and longevity from the harsh elements of
weather. Meet your application demands by choosing this antenna to increase your signal
strength and improve video quality.
ADVANTAGES
• Improve video quality and signal strength
• Increase transmission range
• All-Weather construction
• All Antennas – 50 Ohm Impedance
900MHz
Antennas
• Mounting brackets and hardware included
• "Plug & Play" and ready to install
• Two Year Limited Warranty
5 dB MAGNETIC MOUNT OMNIDIRECTIONAL
PORTABLE WHIP ANTENNA
• Ideal for portable and temporary, vehicle or mobile
equipment applications
• Heavy Duty 3" Magnet – 54lbs. pull strength
• Twin enclosed coil reduces wind noise
• Minimum ground plane required – 8" diameter
• Dimensions: 3.0" x 16.5"
• Includes 6 feet low loss cable and connector
ANT-905MM
8 dB HIGH GAIN DIRECTIONAL PATCH ANTENNA
• Ideal for portable and permanent, indoor and outdoor
equipment applications
• Universal brackets for wall mount or 2" diameter pole mount
• Excellent front – back ratio VSWR 1.5:1 or less
• Low Profile Dimensions: 9.4" (L) x 6.75" (W) x 1.1" (D)
• Includes 6 feet shielded low loss cable and connectors
ANT-908DP
11 dB HIGH GAIN DIRECTIONAL YAGI ANTENNA
• Ideal for portable and permanent, indoor and outdoor
equipment applications
• Durable aluminum all-weather construction
• Wind Load rating – 100 mph
• Mounting brackets / hardware included – up to 2" diameter
• Includes 6 feet duel shielded low loss cable and connectors
MODEL NUMBER
DIMENSIONS
GAIN
YAGI-9111
8" x 35" Long
11 dB Gain
YAGI-9111
49
UHF
TX-440
The new TX-440 wireless transmitter is
ideal for punching through walls or in a
mobile video application. Featuring 8 user
selectable channels, this product is ideal
for mobile wireless applications including
beta-cam operators and hobbyists.
ADVANTAGES
• Easy to use – "Plug & Play"
• Transmitter Size: 2.6" x 1.1" x 2.0"
• Punches through concrete or cinder block walls
• Eliminates the need for cabling or trenching
• Excellent for mobile wireless applications
• 8 user selectable channels
• One Year Limited Warranty
8 Channels
SPECIFICATIONS
OPERATING FREQUENCY
8 user selectable
Cable Channels:
58 – 59 – 60 – 61
Off Air Channels:
14 – 15 – 16 – 17
RADIATED POWER
100 mW
RANGE (LINE–OF–SIGHT)
Up to 1,000 Feet
ANTENNA TYPE
Omnidirectional Rubber Duck
VIDEO FORMAT
NTSC
VIDEO CONNECTOR
RCA Female @ 75 Ohms 1 Volt P–P
AUDIO CONNECTOR
RCA Female @ 600 Ohms 1 Volt P–P
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
200 mA @ 12 VDC
DIMENSIONS
2.6” x 1.1” x 2.0”
WEIGHT
144g or 5.1 oz
FCC/IC APPROVED
N/A
KIT INCLUDES
50
• VIDEO TRANSMITTER
• 12 VDC POWER SUPPLY
• RUBBER DUCK ANTENNA
• ONE YEAR LIMITED WARRANTY
RX-440
UHF
The RX-440 video receiver offers
rock-solid frequency stability by
utilizing a microprocessor PLL controlled
tuning system. Use this receiver with its
matching transmitter, and enjoy trouble
free operation without re-tuning or
adjusting in any environment.
ADVANTAGES
• Easy to use – "Plug & Play"
• Receiver Size: 3.1" x 1.1" x 2.1"
• Punches through concrete or cinder block walls
• Eliminates the need for cabling or trenching
• 8 user selectable channels
• One Year Limited Warranty
8 Channels
SPECIFICATIONS
OPERATING FREQUENCY
8 user selectable
Cable Channels:
58 – 59 – 60 – 61
Off Air Channels:
14 – 15 – 16 – 17
SENSITIVITY
-84 dBm
ANTENNA TYPE
Omnidirectional Rubber Duck
VIDEO FORMAT
NTSC
VIDEO CONNECTOR
RCA Female @ 75 Ohms 1 Volt P–P
AUDIO CONNECTOR
RCA Female @ 600 Ohms 1 Volt P–P
TEMPERATURE RANGE
-22ºF to +140ºF
POWER SUPPLY INCLUDED
9 – 14 VDC Polarity Protected
CURRENT CONSUMPTION
200 mA @ 12 VDC
DIMENSIONS
3.1” x 1.1” x 2.1”
WEIGHT
144g or 5.1 oz
FCC/IC APPROVED
N/A
KIT INCLUDES
• VIDEO RECEIVER
• 12 VDC POWER SUPPLY
• RUBBER DUCK ANTENNA
• ONE YEAR LIMITED WARRANTY
51
ACCESSORIES
UNIVERSAL WALL MOUNTING BRACKET
• Low profile design
• Heavy duty 1.5" galvanized steel tube for greater strength
• Convenient 90º tilt adjustment
• Durable 150lb load rating
• Ideal for mounting all types of wireless video systems
and antennas
• UVM–150: 6" wide mounting flange – 16" length mounting arm
• UVM–200: 6" wide mounting flange – 25" length mounting arm
UVM-150
AUDIO / VIDEO GRABBER / CONVERTER
• Converts analog video / audio signal into Real-Time
MPEG recording
• High Speed USB vers. 2.0
• Use your Laptop or PC to record
• Brightness, Contrast, Hue, Saturation, Sharpness control
• Record MPEG video format up to 720 x 480 @ 30fps
• Includes CD-ROM with video editing software
• Minimum requirements:
USB 2.0 equipped Pentium–4 processor
1 Gig or above computer
Min RAM 128MB / Windows 2000 / XP / Sound card
RF CABLES AND JUMPER CABLES
• High quality connectors to ensure superior
electrical connections
• 50 Ohms impedance
• Various low loss microwave cables
• Various types of jumper cables and connectors
to meet your application requirements
• Contact VideoComm Technologies sales representative
or visit www.VideoTransmitters.com for more details
TV-2USB
LMR-206
POWER SUPPLIES
• Various UL listed Class 2 power supplies ranging
from 6 – 15 VDC
• Various AC to DC converter boards
• Various power jumper cables and connectors
• Contact VideoComm Technologies sales representative
or visit www.VideoTransmitters.com for more details
52
Power Supplies
The wireless Solar Power System is a stand-alone solar photovoltaic power
generator designed to supply a reliable source of electricity for any electronic
device when conventional power sources are not available. When used in
tandem with wireless transmitters, the Solar Power System creates a fully
autonomous wireless video surveillance system for remote video monitoring.
ACCESSORIES
Solar Power
Wireless Solar panel
ADVANTAGES
• Perfect for permanent, temporary, or
portable video surveillance installations
• Ideal for remote applications including:
Commercial, Industrial, and Law Enforcement
• Easy to set up and install
• All weather light weight aluminum design
• Can deliver 5 days of continuous power
without a recharge ( batteries not included )
• 12 Volt DC to 24 Volt AC option, with
SPI-40 power inverter
SPECIFICATIONS
REGULATED SYSTEM OUTPUT VOLTAGE
14.1 VDC
MAXIMUM SYSTEM OUTPUT
6 amps
OVERLOAD CAPACITY
7.5 amps for 5 minutes
TEMPERATURE RANGE
-40ºF to +140ºF
BATTERY CHARGE TEMPERATURE COMPENSATION
YES – "Smart Charge"
BATTERY CAPACITY
1260 watt / hours or 105 ampere–hours
SOLAR PANEL – DIMENSIONS
48" x 13" per panel ( Max. 5 panels )
SOLAR PANEL – WEIGHT
14 lbs per panel
MASTER CONTROL UNIT – DIMENSIONS
16" x 13.5" x 9.5"
MASTER CONTROL UNIT & BRACKET – WEIGHT
25 lbs. ( not including battery )
53
WIRELESS VIDEO APPLICATIONS
RETAIL
• LOSS PREVENTION – Inventory control and cash monitoring
• VANDALISM – Building and elevator monitoring
• GAS STATION – Self serve and car wash monitoring
• SECURITY – Restricted zone monitoring, safe rooms and locked merchandise
• SHOPPING MALLS – Theft, vandalism and parking lot monitoring
• EMPLOYEE SUPERVISION – Performance monitoring
INDUSTRIAL
• EQUIPMENT MONITORING – Back up cameras, cranes and loaders
• ASSEMBLY LINES – Process control monitoring, quality control inspection
• DANGEROUS AREA MONITORING – Chemical hazard and mine shafts
• REMOTE GAS, OIL RIG AND PIPE LINE MONITORING
• CONSTRUCTION SITES – Portable visible link monitoring and remote situations
• PIPE INSPECTION – Ventilation shafts
• REMOTE TRAFFIC CONTROL – Lights and signals
COMMERCIAL
• PROPERTY MANAGEMENT – Parking lot and building surveillance
• INSURANCE INDUSTRIES – Fraud prevention and claims investigations
• PRIVATE INVESTIGATION – Monitoring and visual identification
• FIRE – Thermal Imaging
• LAW ENFORCEMENT – Investigations and body-cam surveillance
• HOSPITALS – Alzheimer patients, extendicare homes and pharmacies
• MEDICAL – Surveillance of biohazards, equipment and patient monitoring
• SCHOOLS – Pick up and drop off zone monitoring, crime prevention
• TRANSPORT – Road and traffic control monitoring, airports and railways
• GATED COMMUNITY – Access control monitoring
• DAYCARE – Child activity and monitoring
OTHER
• HOBBYIST – Radio controlled cars, boats, planes, helicopters, rockets, and robots
• BROADCAST TV – Steadycam
• GOLF COURSE – Hole in one monitoring
• GOVERNMENT & MILITARY – Facilities, Embassies and Prisons
• NATURE ENTHUSIASTS – Bird or wildlife monitoring
• SCIENTIFIC – Remote monitoring of active volcano
• LIVESTOCK MONITORING – Calving
• HOME THEATRE – Home automation
We have solutions on-line
www.VideoTransmitters.com
• GET MORE
detailed and up-to-date specification sheets
instructions, technical notes and software
• GET A PRICE QUOTE
complete the on-line request for quotation form,
and we'll send you a detailed quotation
within 48-hours
technical support you've been looking for.
• BATTERY CONSUMPTION CALCULATOR
find out how many hours your battery will last.
Or what size battery you will need to make it last
CALL NOW
• WIRELESS APPLICATION IDEAS
including some with technical write-ups
and detailed schematic drawings
• GLOSSARY AND FREQUENTLY ASKED QUESTIONS
to improve your understanding of wireless
transmitters
Visit our website to find the wireless
To talk with our team of
knowledgeable sales
& technical support
North America TOLL FREE
1.888.379.2666
or
From elsewhere in the world
1.905.339.0366
• TECHNICAL NOTES
review postings of helpful installation tips, drawings,
charts or recent discoveries
• COMPLETE THE HELP REQUEST FORM
and we'll email you specs, photos, drawings and
installation tips
• KEEP UP TO DATE
with our most recent product releases, upcoming
events, press releases and more
• FIND
an authorized distributor or re-seller near you
CLICK NOW
www.VideoTransmitters.com
Go on-line to visit our Help
Request Form and our team of
experienced Sales and Technical
support representatives will
send the information you need
to ensure a successful wireless
installation
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
