Technische lijst DE NL - Stadsschouwburg Utrecht
TECHNICAL RIDER
STADSSCHOUWBURG UTRECHT
Big and small auditorium
Version 15.02
Version: 15.02
1
STADSSCHOUWBURG UTRECHT ..................................................... 5
STARTTIME .......................................................................................................... 5
ADDRESS AND DRIVING DIRECTIONS ........................................................... 5
Parking at schouwburg not posible ............................................................................ 5
By car from Amsterdam to Utrecht by A2 ................................................................ 5
By car from other directions ........................................................................................ 5
Public transport ............................................................................................................... 5
Computer network .......................................................................................................... 5
WIFI...................................................................................................................................... 5
Safety .................................................................................................................................. 6
Staff and working hours ................................................................................................ 6
MAIN AUDITORIUM ........................................................................... 7
Seating capacity ............................................................................................................... 7
Appendix 1. Seating plot .......................................................................... 7
Sound pit ............................................................................................................................ 7
Conductors room ............................................................................................................. 7
Canteen............................................................................................................................... 7
Crew catering .................................................................................................................... 7
Telephone .......................................................................................................................... 7
Dressing rooms ................................................................................................................. 7
STAGE ................................................................................................................... 8
loading/Unloading .......................................................................................................... 8
Appendix 2. stageplot ..............................................................................9
MARLEY DANCE FLOOR .................................................................................. 10
MASKING ........................................................................................................... 10
STAGE RAISERS ................................................................................................. 10
Stage piano and piano .................................................................................................. 10
RIGGING .............................................................................................................. 11
FOH bar .............................................................................................................................. 11
Sound bars ........................................................................................................................ 11
Proscenium bar ................................................................................................................ 11
Onstage bars..................................................................................................................... 11
Side bars ............................................................................................................................ 11
Point hoists ....................................................................................................................... 11
Appendix 3. Maximum weights ............................................................ 12
Appendix 4. cable distribution............................................................. 12
Appendix 5. Rigging material ................................................................ 12
Appendix 6. Flyplot ................................................................................. 13
LIGHTS AND POWER ........................................................................................ 14
Power................................................................................................................................. 14
DMX network .................................................................................................................. 14
Appendix 7. Fixed light ........................................................................... 15
Appendix 8. Light plot............................................................................ 16
Appendix 9. Light material .................................................................... 17
Appendix 10. Mobile dimmers .............................................................. 17
Dimensions and material ............................................................................................... 8
Appendix 11. Moving heads....... Fout! Bladwijzer niet gedefinieerd.
ORCHESTRA PIT .................................................................................................. 8
Appendix 12. Licht computers .............................................................. 17
Version 15.02
2
Appendix 13. Colour filters .................................................................... 18
Sound pit ......................................................................................................................... 26
SOUND ............................................................................................................... 19
Dressing rooms .............................................................................................................. 26
FOH System ..................................................................................................................... 19
Loading/Unloading ....................................................................................................... 26
Stage sound ..................................................................................................................... 19
Stage dimensions and material ................................................................................. 26
Stage announcements .................................................................................................. 19
Stage dimensions .......................................................................................................... 26
Intercom ........................................................................................................................... 19
Marley dance floor ....................................................................................................... 26
Appendix 14. Microphones ................................................................... 20
Masking ............................................................................................................................ 26
Appendix 15. Wireless ............................................................................. 21
Grand Piano .................................................................................................................... 26
Appendix 16. Mixers ................................................................................ 21
Appendix 27. Elevator plot ................................................................... 26
Appendix 17. DJ material......................................................................... 21
Appendix 28. floorplot ..........................................................................27
Appendix 18. Speakers and monitors.................................................. 21
RIGGING .............................................................................................................28
Appendix 19. Sound periferals ..............................................................22
Bars.................................................................................................................................... 28
Appendix 20. Stands ...............................................................................22
Appendix 29. Maximum load ............................................................... 28
VIDEO.................................................................................................................. 23
Grid ................................................................................................................................... 28
Video network ................................................................................................................ 23
LIGHT AND POWER ..........................................................................................28
Front view ........................................................................................................................ 23
power................................................................................................................................ 28
Conductor camera ......................................................................................................... 23
Distribution..................................................................................................................... 28
Appendix 22. Projectors ........................................................................ 24
Dimmers: .......................................................................................................................... 28
Appendix 23. Switcher/scaler/videomixer ....................................... 24
DMX .................................................................................................................................. 28
Appendix 24. Projection screens ......................................................... 24
Appendix 30. Light.................................................................................. 29
Appendix 25. Players/Recorders ......................................................... 24
Appendix 26. Monitors ...........................................................................25
SMALL AUDITORIUM ....................................................................... 26
SOUND................................................................................................................30
F.O.H. system .................................................................................................................. 30
Multi cable ...................................................................................................................... 30
FACILITIES .......................................................................................................... 26
Stage sound .................................................................................................................... 30
Seating capacity .............................................................................................................26
Intercom .......................................................................................................................... 30
Version 15.02
3
VIDEO.................................................................................................................. 30
AV- facilities ....................................................................................................................32
Video network ................................................................................................................ 30
DUDOK FOYER .................................................................................................. 32
RESTAURANT ZINDERING................................................................ 31
Floor size and height .....................................................................................................32
FACILITIES ........................................................................................................... 31
Smallest pass trough .....................................................................................................32
Sound pit ........................................................................................................................... 31
Dressing rooms ................................................................................................................ 31
Capacities .........................................................................................................................32
Dressing rooms ...............................................................................................................32
Loading/unloading ......................................................................................................... 31
ZOCHER FOYER ................................................................................................. 32
Stage size material ......................................................................................................... 31
Floor size and height .....................................................................................................32
Piano ................................................................................................................................... 31
Accessibility .....................................................................................................................32
LIGHTS AND POWER ........................................................................................ 31
Capacities .........................................................................................................................32
power ................................................................................................................................. 31
Dimmers ............................................................................................................................ 31
Dressing rooms ...............................................................................................................32
Power.................................................................................................................................32
DMX.................................................................................................................................... 31
ROUND SCHOUWBURG UTRECHT................................................33
FOH system ...................................................................................................................... 31
ZOCHER PARK ................................................................................................... 33
Multi cable ........................................................................................................................ 31
Power.................................................................................................................................33
VIDEO................................................................................................................... 31
Cable length.....................................................................................................................33
Video network ................................................................................................................. 31
ZOCHER TERRACE ............................................................................................. 33
FOYERS ............................................................................................... 32
Floor size and height .....................................................................................................33
HEKMAN FOYER ............................................................................................... 32
Power.................................................................................................................................33
Floor size and height ..................................................................................................... 32
DUDOK BALCONY ............................................................................................ 33
accessibility ..................................................................................................................... 32
Power.................................................................................................................................33
Capacity............................................................................................................................ 32
Dressing rooms ............................................................................................................... 32
Power ................................................................................................................................ 32
Version 15.02
4
STADSSCHOUWBURG UTRECHT
STARTTIME
Stadsschouwburg Utrecht strives to open auditoriums at least 15 minutes
prior to the performance. Under conditions of deliberation we can agree
to deviate.
Douwe Egbertszaal
20:00
Blauwe zaal
20:30
ADDRESS AND DRIVING DIRECTIONS
Technical Office:
phone:
+31-30-2324109
fax:
+31-30-2314499
e-mail:
techniek@utrecht.nl
Take left at the second traffic lights (T-junction behind the prison).
Follow Wittevrouwensingel.
Take right at the next traffic lights, across the bridge and take left
immediately after the bridge, on to Lucas Bolwerk.
After 200 metres the theatre is on your left hand side.
Public transport
From Utrecht Central Station, Stadsschouwburg Utrecht can be reached
on foot in about 15 minutes, or in about 5 minutes by taking bus # 3, 4,
8 or 11.
Computer network
In all spaces is an 100Mbit connection (RJ45) available on request
WIFI
WIFI is available, domain and password will be provided on the scene.
Parking at schouwburg not posible
There is no parking space at the theatre. For the main auditorium there’s
space for 2 trailers on a dock
For the small auditorium there’s 1 parking card available at the reception
on presentation of driving licence or passport, These will be kept as
security.
Cars without reservation can be parked at garage kruisstraat, or
grifthoek, these are on walking distance of the schouwburg
By car from Amsterdam to Utrecht by A2
Exit Ringweg Noord/Maarssen, towards Utrecht (N 230).
Follow direction Hilversum (N 230). Exit Tuindorp/Voordorp.
Follow this road, across the railway, on to a big roundabout
(Eykmanplein). Go straight at the roundabout and follow
Blauwkapelseweg. Take left at the second traffic lights (T-junction behind
the prison). Follow Wittevrouwensingel. Take right at the next traffic
lights, across the bridge and take left immediately after the bridge, on to
Lucas Bolwerk. After 200 metres the theatre is on your left hand side.
By car from other directions
Follow signs Utrecht/Houten or Almere on to A27.
On A27 take exit Veemarkt (30) towards Utrecht. This is Biltse Rading,
changing names into Kardinaal de Jongweg.
Take left at the second roundabout. This is Blauwkapelseweg.
Version 15.02
5
Safety
Staff and working hours
Equipment brought into the Stadsschouwburg is subject to safety checks
by Stadsschouwburg Utrecht staff.
All mains-connected electrical equipment must comply with European
safety standards.
Lighting equipment rigged overhead must be secured with a safety chain
or similar.
Overhead equipment (including scenery) must be rigged by a qualified
rigger, using appropriately certified equipment.
Scenery and large props must be of a fire retardant fabric or treated with
a fire retardant. A certificate of such treatment must be produced on
request. Polystyrene and other such materials that cannot be treated
with fire retardant are not permitted.
The area directly under the fire curtain must, by law, be kept clear of
fixed scenery. In the event of a fire the curtain can be lowered.
For the use of open fire a permit is needed from the local fire department,
to be applied for at least 2 weeks in advance. The Technical Office can
help obtaining the permit.
Pyrotechnics can only be done by a registered pyrotechnician. The
procedure to obtain a state permit can take 8 weeks or more.
In accordance with the Dutch legislation a written risk assessment is
required for all events, to be presented at least a week in advance.
The Stadsschouwburg Utrecht takes all care, but no responsibility for the
loss or damage of any visitor’s property, including personal belongings.
Artists and technicians are encouraged to refrain from bringing personal
belongings not required for the event.
The use of alcohol and drugs during working hours is forbidden by law.
Smoking is not permitted in the entire building
The theatre provides 4 all round technicians to assist the visiting
company. The company technicians operate lights and sound during the
performance.
Morning
11:00-12:30
Afternoon
13:00-17:00
Night setup day
19:00-23:00
Night show day
19:00- end of strike
Version 15.02
Different crew sizes or working hours to be discussed 6 weeks in advance.
6
MAIN AUDITORIUM
The Douwe Egbertszaal is a proscenium arch theatre, suited to medium
to large scale dramatic, dance and musical productions.
The auditorium has two settings: the normal setting, and the so-called
amphitheatre setting, where row 6 through 13 rise one by one, so that
row 13 meets the balcony. The seats under the balcony are not in use in
this setting.
Seating capacity
When the optional stage extension / orchestra pit is in use, the seating
capacity is reduced with 99 seats.
Normal/with orchestra pit
976/876
Amphitheatre/with orchestra pit
638/539
Appendix 1.
Seating plot
Sound pit
2 x 9 seats are reserved for lighting and/or sound desk, in the centre of
row 12 and 13. Total available space (w x d): 500x180cm
Conductors room/room for disabled
with telephone and cable television connections, private shower and
lavatory (suitable for disabled people).
Canteen
Space for 50 persons, 40 seats hot and cold drinks all day, soup and
sandwiches at lunchtime – to be ordered in the morning.
Crew catering
request information at our Horeca planning +31(0)302324156
Telephone
Telephone on SL and conductor room. All dressing rooms have telephone
conections on request
Dressing rooms
Clothes racks, iron and ironing board are available
Stage level
Dressing room 2
7 persons
Dressing room 3
8 persons
2x 32A CEE +1x 16A CEE (red) available. Drain for washing machine
Dressing room 4
4 persons
Dressing room 5
4 persons
Dressing room 6
4 persons
Dressing room 7
4 persons
Dressing room 8
4 persons
Dressing room 9
4 persons
Shared toilets and showers Washing machine and tumble dryer
Dressing room 14
6 persons
Dressing room 15
6 persons
Dressing room 16
9 persons
Dressing room 17
18 persons
Dressing room 18
21 persons
The theatre has no rehearsal studio, and no wardrobe staff.
Version 15.02
7
STAGE
loading/Unloading
Two loading docks, inside garage. max truck length 16m
Dimensions and material
Hardwood (Keruing)
Thickness
Maximum load
Stage size
width
depth
Height from stage level to:
auditorium floor
fly loft
max fly bar height
minimal fly bar height
1st side gallery
Distance from setting line to:
Downstage edge
Downstage audience fly bar
Upstage audience fly bar
Sound Fly bar Left/right
main curtain
proscenium fly bar
rear of fire curtain
front of proscenium
first onstage fly bar
Version 15.02
25mm
700kg/m2
27.5m
15.3m
-85cm
22.40m
20.5m
35cm
8.8m
-3.90m
-3,46m
-3,06m
-2,63m
-1.54m
-1.26m
-1.8m
-1.1m
0.45m
last onstage fly bar
back of the auditorium
Proscenium opening
Fixed opening
Variable opening
Variable width
Variable height
Main curtain
Colour
Control
Side stage (SR)
width
depth
height
13.85m
-26.5m
16x8m
10 -16m
0.3-8m
Red
Greek, manual, SL
11m
10m
7m
ORCHESTRA PIT
The orchestra pit can be adjusted to any height between pit level and
stage level. The pit consists of a part underneath the stage, and a part
(divided in three segments) in the auditorium.
Access to the pit is via the stage or via an elevator at the loading dock.
Smallest pass through opening: 1,6 x 2,2m through elevator.
music stands
60
chairs
84
conductors stand
1
Music stand lights can be dimmed by 4 channel DMX controlled. (one
channel for conductor).
8
Appendix 2.
Version 15.02
stageplot
9
Number
height
width
Black scrim gauze
Number
height
width
MARLEY DANCE FLOOR
1 rolls
width: 1,6m
length:
15m
color: black
MASKING
Material: black, wool
Legs
Number
width
height
Borders
Number
width
height
Side black
Number
width
height
Cyclorama
Version 15.02
1
10.0m
1.0m
1
12.0m
21.0m
STAGE RAISERS
21
6m
10.0m
6
21.0m
4.7m
4
6.0m
9.0m
1x2m
1x1m
0,5x1m
27
4
6
All raisers have legs of following length: 20,40,60,80,100cm
Railing for raisers
80x200cm (hxl)
80x100cm (hxl)
Stage piano and piano
10
6
Stage piano: Yamaha C7, 2.27m, build 1990
Piano: Yamaha P121 build 2006
10
RIGGING
The venue has a Computer controlled flying system, supplied by Waagner
Biro with multiple control points on the fly gallery and the stage.
Operation of the fly system is restricted to Stadsschouwburg Utrecht
staff only.
According Dutch legislation all overhead rigging must confirm to
NPR8020-10, which means that safety factors of rigging equipment
should be doubled. In practice all SWL values on industry standard
equipment are downscaled by a factor 2.
The SWL of the flying system of the venue already complies to this
standard.
FOH bar
length
16.0m
speed
max total load/point load
0,45m/s
minimal height
0,35m
8,2m
maximal height
300/150kg
Sound bars
length
2.0m
speed
max total load/point load
0,45m/s
minimal height
0,35m
8,2m
maximal height
300/150kg
max speed
max total load
max point load
1.8m/s
500kg
150kg
number of bars
length
max speed
max total load
max point load under steel
max point load between steels
distance between bars
distance between 40, 41 and 42
67
21.0m
1.8m/s
500kg
150kg
70kg
0.2m
0.3m
Onstage bars
Side bars
number of bars 6 (3 per side)
length
max speed
max total load
max point load under steel
max point load between steels
12.5m
1.8m/s
500kg
150kg
100kg
12 mobile chain hoists
4 fields of max 4 hoists per field
max load per hoist
operated from
500kg
DSL
Point hoists
Proscenium bar
length
Version 15.02
19.0m
11
Appendix 3.
Maximum weights
Appendix 5.
Rigging material
Discription
prolite truss (x30D) driehoek 2mtr
prolite truss (x30D) driehoek 3mtr
prolite truss (x30D) koppelstuk
haaks X-Y-Z
Appendix 4.
Version 15.02
cable distribution
prolite truss (x30D) circle 4 parts
Variety of scaffold material
variety of shackles
steelcable 1mtr
steelcable 2mtr
steelcable 3mtr
steelcable 4mtr
steelcable 5mtr
steelcable 6mtr
steelcable 7mtr
steelcable 8mtr
steelcable 9mtr
steelcable 10mtr
steelsling 2mtr
steelsling 3mtr
safety jackets
Variety of rope
Round sling 0,5mtr
Round sling 0,5mtr
Round sling 1,5mtr
Round sling 1mtr
spanset
Variety of tension ratchet
nr.
8
8
remark
4
1
21
27
20
36
24
44
10
42
34
25
12
10
4
WLL 150kg
WLL 150kg
WLL 150kg
WLL 150kg
WLL 150kg
WLL 280kg
WLL 280kg
WLL 400kg
WLL 280kg
WLL 200kg
WLL 1000kg
WLL 2000kg
2x small 2x large
2
10
12
5
6
WLL 1000kg
WLL 500kg
WLL 1000kg
WLL 3000kg
WLL 3000kg
12
Appendix 6.
Flyplot
Voorstelling
Datum
100
99
Afstand
tot kk
450
650
850
1050
1250
1450
1650
1850
2050
2250
2450
2650
2850
3050
3250
3450
3650
3850
4050
4250
4450
4650
4850
5050
5250
5450
5650
5850
6050
6250
6450
6650
6850
7050
7250
7450
7650
Version 15.02
Trek
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
204
Zaaltrek voor
-3060
203
202
201
Zaaltrek achter
Geluidstrek rechts
Geluidstrek links
-2630
-2630
Sluier
Portaalbrug
Omschrijving
-3460
laag
tussen
hoog
groep
Afstand
tot kk
7850
8050
8250
8550
8850
9050
9250
9450
9650
9850
10050
10250
10450
10650
10850
11050
11250
11450
11650
11850
12050
12250
12450
12650
12850
13050
13250
13450
13650
13850
links 1
links 2
links 3
rechts 1
rechts 2
rechts 3
Trek
Omschrijving
laag
tussen
hoog
groep
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
71
72
73
81
82
83
binnen
midden
buiten
binnen
midden
buiten
13
LIGHTS AND POWER
Power
All 3-phase supplies are CEE red: 230/400V 50Hz - 3 phases, neutral
and earth.
Fixed conections:
USR
2 x 125A 3phase
1 x 63A 3phase
SL
2 x 125A 3phase
USL
1 x 125A 3phase
1 x 63A 3phase
SR
2 x 125A 3phase
Dimmers
All fixed dimmers are equipped with a 30mA residual current circuit
breaker on each channel.
FOH
136 x 2.5kW ETC Sensor
6 x 5kW ETC Sensor
Proscenium gallery
42 x 2.5kW ETC Sensor
Proscenium towers
30 x 2.5kW ETC Sensor
Side galleries
30 x 2.5kW ETC Sensor
Upstage gallery
6 x 2.5kW ETC Sensor
Stage (DSL & DSR)
168 x 5kW ETC Sensor
garage
1 x 63A + 1 x 125A
Version 15.02
DMX network
All dimmers are DMX512/1990 controlled through an XLR-5 data
network. The hard patch is at DSR and contains 4 optical isolated
splitters.
Splitters
4x 1in > 3 out
DMX512 signal can be sent from:
the control room (4 lines)
FOH mixing position (2 lines)
back of the house and DSL.
DMX512 signal can be sent to
the house dimmers
the control room (2 lines)
the FOH bridge
USR (2 lines)
USL
SL (2 lines)
side stage
follow spot room.
Intermission signs and house lights are DMX512 controlled.
Exit signs can’t be dimmed or switched off.
14
Appendix 7.
brand
Robert Juliat
Robert Juliat
Robert Juliat
Robert Juliat
Robert Juliat
Robert Juliat
Robert Juliat
Altman
Robert Juliat
ADB
Robert Juliat
ETC
ADB
ETC
ETC
ETC
Version 15.02
Fixed light
type
SSBU
Aramis
714SX
714SX
710SX2
711SX2
614SX
713SX
APZ112
701SX2
Warp
306 HPC
Source 4 profile
C103
Source 4 profile
Vivid R
Source 4 profile
Discription
house lights (DMX)
followspot 2,5kw HMI
zoom profile 2kw 15-40º
zoom profile 2kw 15-40º
zoom profile 2kW 8-16º
zoom profile 2kW 10-25º
zoom profile 1,2 kW 16-35º
zoom profile 2kW 29-50º
zoom profile 1,2kW 12-40º
zoom profile 2kw 15-40º
zoom profile 800W 20-50º
pc 1kw with barndoors
directorspot 14º
curtain lights (DMX)
gsm uit bordjes
34x Vivid R verdeeld over 17 yokes
Gobo met pauze bordjes op zijwand
nr.
1
2
6
18
18
4
8
16
30
20
10
6
2
4
2
17
2
remark
1st auditorium bridge top
1st auditorium bridge bottom
2st auditorium bridge
3st auditorium bridge
portal bridge TOP
portal bridge bottom
auditorium side booms
stage bridge SL/SR
stage booms
stage booms
freely movable
15
Appendix 8.
Version 15.02
Light plot
16
Appendix 9.
brand
Robert Juliat
ETC
ETC
ETC
ADB
Robert Juliat
ADB
Appendix 10.
Light material
type
614SX
Source 4 profile
Source 4 par
Source 4 par
C203
306 HPC
SH20
type
MA-Lighting
0
MA-Lighting
0
brand
Martin
Martin
Martin
Vari*lite
showtech
Appendix 12.
brand
ETC
ETC
Jands
Version 15.02
nr.
16
12
36
8
16
18
8
remark
Discription
12* 5kW in rack 32A blue/per 3 op 32A red with
ground safety per 6 chanels 30mA
24* 2,3kW with hardpatch with ground safety per
12 chanels 30mA
nr.
remark
Discription
yoke (dmx extended mode)
yoke
yoke
yoke
active sunstrip
nr.
8
2
10
10
8
Discription
small 48 Chanel desk with 24 sub's
tracking mixer console
tracking mixer console +wing E2
nr.
2
1
1
Mobile dimmers
brand
Appendix 11.
Discription
zoom profile 1,2 kw 16-35º
zoomprofile 750w 25-50º
Source 4 PAR 750W with all lenzes
Source 4 4-bar PAR 750W with all lenses
PC 2kW
pc 1 kW
Fresnel 2kW
1
3
Intelligent light
type
Mac 700 Profile
Mac Viper Performance
Mac Viper Profile
VL2500 Wash
active sunstrip
alleen
alleen
alleen
alleen
alleen
te
te
te
te
te
remark
gebruiken
gebruiken
gebruiken
gebruiken
gebruiken
in
in
in
in
in
overleg
overleg
overleg
overleg
overleg
Licht computers
type
Smartfade 12/48
ION
Vista T2 Byron
remark
17
Appendix 13.
Colour filters
brand
Lee
Lee
Lee
Lee
Lee
Lee
Lee
Lee
Lee
Lee
Lee
Lee
Lee
type
0
0
0
0
0
0
0
0
0
0
0
0
0
Lee
Lee
0
0
Rosco(frost)
frost
Version 15.02
Discription
002,071,075,079
100,101,102,103,104,105,106,107,108,109,110
111,113,115,116,117,118,119,120
121,122,124,126,127,128
132,134,135,136,137,138,139,140
141,142,143,144,147,148
151,152,153,154,156,157,158
161,162,164,165,166,170
172,174,176,179,180
181,182,183
192,194,195,196,197,198,200
201,202,203,204,205,206
212,213,218,219
nr.
remark
241,242,243,248
363,702
114,119,132
18
SOUND
FOH System
Configuration (for each side):
6 x top:
axys U-16
2 x laag:
axys B-215
Frontfill:
6 x dual concentric in front edge of stage
FOH mixing position
1xLitton Veam (ch 1 thru 50)
1xSocapex (ch 1thru 12)
8x XLR M+F (ch 49 thru 56)
2x Madi BNC to Stage Right
2x Madi BNC to Stage Left
2x CAT-6 RJ45-ethercon to Stage Right
2x CAT-6 RJ45-ethercon to Stage Left
back of house mixing pos
2xSocapex (ch 1thru 12)
8x XLR M+F (ch 49 thru 56)
downstage right
1x Litton Veam (ch 1 thru 50)
4x Socapex + XLR F+M (ch 1 thru 48 in sections of 12)
Version 15.02
2x Socapex + XLR F+M (24 ch to upstage mid)
1x Socapex + XLR F+M (12 ch to control room)
8x XLR M+F (ch 49 thru 56)
4x XLR F+M (spare connections to downstage left)
Connections to FOH and balcony fills
2x Madi BNC to FOH mixing position.
2x CAT-6 RJ45-ethercon to FOH mixing position.
Down stage left
1x Litton Veam (ch 1thru 50)
4x Socapex + XLR F+M (ch 1 thru 48 in sections of 12)
8x XLR M+F (ch 49 thr 56)
4x XLR F+M (spare connections to downstage right)
2x Madi BNC to FOH mixing position.
2x CAT-6 RJ45-ethercon to FOH mixing position.
upstage wall
2x Socapex + XLR F+M (12 ch to downstage right)
Stage sound
All dressing rooms and canteen
Stage announcements
From SL announcements can be made to all dressing rooms and canteen
Intercom
Wired: Digital ASL system with 8 beltpacks en 2 tafelstations
Wireless: 2 channel Telex system with 8 beltpacks
19
Appendix 14.
Microphones
brand
AKG
AKG
AKG
AKG
AKG
AKG
audix
beyer
Crown
DPA
DPA
Neumann
sennheiser
sennheiser
sennheiser
sennheiser
sennheiser
sennheiser
sennheiser
Shure
Shure
Shure
Shure
Shure
type
C414
C535EB
CK31
CK91
D112
SE300B
D6
201
pcc160
4061
4066F
KM184
E604
e845s
E906
MD421
ME35 on gooseneck 60 cm
ME36 on gooseneck 40 cm
MKH416
Beta52A
Beta57A
Beta58A
Beta87A
Beta92
Shure
Beta98
Shure
Beta98H
Shure
Shure
AKG
SM57
SM58
C1000
Version 15.02
Discription
condenser,Omni/Cardioid/hypercardioid/eight,
condenser, Cardioid
head for SE300B, Omni
head for SE300B, Cardioid
dynamic cardioid (kickdrum)
Body for, CK91/CK31
dynamic cardioid (kickdrum, toms, bass amp)
dynamic hypercardioid (Hi-hat, drums)
condenser, cardioid, boundry
condenser,Omni
condenser,Omni,Headband
condenser,cardoid
dynamic cardioid,(drum with clip)
dynamic cardioid,mute switch
dynamic cardioid,(guitaramps)
dynamic cardioid,5 position basscontrol
condenser, Cardioid tabel mic with stand
condenser, Cardioid
condenser,shotgun
dynamic modified supercardioid (kickdrum)
dynamic supercardioid (instrument)
dynamic supercardioid (vocal)
condenser, supercardioid (vocal)
condenser, omni boundry
condenser,supercardioid (instrument) with A98D gooseneck mount for drumkit
condenser, cardioid (instrument) with gooseneck angle
brace
condenser, supercardioid (instrument)
condenser, supercardioid (vocal)
condenser, Cardioid/hypercardioid
remark
2
2
2
6
1
6
1
1
3
6
4
8
4
2
2
2
8
2
6
1
4
3
4
1
Base with ptt switch
4
4
4
7
2
20
Appendix 15.
brand
Shure
Shure
Shure
Shure
DPA
type
ULXD4Q
ULXD2
ULXD1
sm58
d:facto 2
Appendix 16.
brand
DiGiCo
DiGiCo
Allen & Heath
Allen & Heath
Midas
brand
SoundProjects
SoundProjects
SoundProjects
Axys
Axys
Behringer
Behringer
Behringer
Version 15.02
nr.
2
6
6
4
2
remark
working frequency 606-670mHz
working frequency 606-670mHz
working frequency 606-670mHz
for ULX D2 handheld
for ULX D2 handheld
Discription
48 flexi in 2x Drack 32in 16uit
32 in,8 flexi, 1x Drack 32in16uit
16/2
10+2/4/2
40+4/8/2/1
nr.
1
1
1
2
1
remark
digitaal
digitaal
annaloog
analoog
digitaal
Discription
mixer
mixer
CD player
turntable (with shure ellement M44-7)
nr.
1
1
2
2
remark
Discription
monitor (active)
top (active 90H*40V/1"+ 12")
Sub (active 15")
monitor (active 110Hx100V/2"+12)
speaker (active 2x 6,5 "+ 1.1"(dome))
Personal monitoring system+stand
Personal monitoring Power supply
Personal monitoring Input device
nr.
16
6
6
4
6
9
1
1
remark
DJ material
type
Xone:32
DJM600
CDJ1000MK3
SL1200MK5
Appendix 18.
Discription
4 channel reciver
wireless handheld with ksm9
wireless belt pack
cardioid capsule
cardioid capsule
Mixers
type
SD9
SD11
mixwizard
mixwizard
legend 3000
Appendix 17.
brand
Allen & Heath
pioneer
pioneer
technics
Wireless
voor platen
Speakers and monitors
type
X-act
SP2
SP15
UFM-212
U14
P16-M
P16-D
P16-I
with headphones
21
Appendix 19.
brand
radial
radial
radial
ASL
Klark Teknik
type
J48
pro AV2
JDI dual
TR2
LBB100
Appendix 20.
brand
Lexicon
tc-electronics
tc-electronics
nr.
6
2
3
4
6
remark
nr.
1
1
1
remark
Discription
DSP (2 in 4 out)
graphic EQ (dual)
Compressor/lim/gate
Compressor (4*)
CD & MD player
CD player
CD player (dubbele )
minidisk
nr.
2
2
12
1
1
2
2
2
remark
remark
Discription
multy effect processor
multy effect processor (2 engines)
multy effect processor
Stands
brand
type
Discription
nr.
k&m
0
High mic stand
10
k&m
0
table stand
Version 15.02
extended stereo
Sound periferals remaining
type
DP200 V4.00
dbx 2231
1066
dbx 1046
MD-CD 1
PMD 331
DN2000F
MDS-E11
Appendix 22.
Discription
DI Active
DI passive
DI passive
DI passive
DI
Sound periferals Effect processors
type
PCM70
M2000
M2000
Appendix 21.
brand
XTA
dbx
dbx
dbx
tascam
marantz
Denon
Sony
Sound periferals DI’s
8
22
VIDEO
Video network
A video coax network is provided with a hardpatch at DSR. In this patch
5 splitters are provided.
4x 1in > 3 output
1x 1in > 5 output
All connections are 75Ω
Location
Sound pit
Audience loge
DSL
Orchestra pit L
Orchestra pit M
Version 15.02
Number
5
2
5
1
1
Orchestra pit R
Balcony L
Balcony LM
Balcony RM
Balcony R
stage boom L
stage boom R
Fly bar bridge
Front view
1
1
1
1
1
1
1
2
A colour image of the stage is distributed to canteen, control room,
corridors round stage DSL,DSR and orchestra pit.
Conductor camera
The conductors camera is a black and white / infra red camera. Image is
available on stage left and stage right.
23
Appendix 23.
Projectors
brand
type
Christie
WX10K-M
9500 Ansi, 3 chip LCD, res: 1366 x 786 (WXGA), ILS
Lens 0.73:1 SX and ILS Lens 4.5-7.3:1 SX+ns 4.57.3:1 SX+
1
Christie
LW400
4000 Ansi, 3 chip LCD, res: 1280x800 lens: 1.2-1.9:1
1
NEC
3M
VT770
9700
LCD projector 3000 ansi
overhead projector
1
1
Appendix 24.
brand
logitech
Analogway
Analogway
Edirol
Appendix 25.
type
R400
Pulse2 PLS 350
Pulse PLS 300
V4
remark
Discription
powerpoint presenter
Seamless switcher/scaler
Seamless switcher/scaler
videomixer
nr.
2
1
1
1
remark
Discription
front or rear projection size 600x335 (projection size
L/R 580x315), with rig points
front or rear projection size 400x225 (projection size
L/R 380x205), with rig points
front or rear projection size 240x180
nr.
remark
Discription
Blue ray speler/recorder, full HD 1080p, Divx
nr.
2
Projection screens
type
Stumpfl
16/9
Stumpfl
16/9
projecta
4/3
1
1
1
Players/Recorders
brand
samsung
type
BD-P1580
Pioneer
Sony
DVD7300D
HXR-NX-70E
Philips
?
Version 15.02
nr.
Switcher/scaler/videomixer
brand
Appendix 26.
Discription
DVD player
HD camera/player/recorder
director camera (infrared (black/white) patchbaar)
2
1
remark
records on SD card
1
24
Appendix 27.
Monitors
brand
type
DataVideo
TLM-702
marshal
Discription
nr.
2x7" Wide Screen TFT LCD Monitor Bank 19"
1
V-LCD4-pro-L
tft 4"
1
marshal
V-LCD8-pro
tft 8"
2
Neovo
L-W27
led LCD screen 1920*1080
1
Neovo
L-W24
led LCD screen 1920*1080
2
Philips
?
tft 20"
2
Sony
LMD1410
tft 16"
2
sony
LMD2010
tft 20"
1
Version 15.02
remark
25
SMALL AUDITORIUM
FACILITIES
Elivator door wxh
lift size
lifting capacity:
Stage dimensions and material
Seating capacity
The Blauwe Zaal is a small ‘black-box’ theatre with a front tribune and
seats on two sides
Front tribune:
185
with sides:
240
maximum amount of seats depends on the desired sightlines.
Sound pit
In the middle of the audience there is room for a table to control sound
and lights. This takes approx. 8 audience seats
The back wall consists of large windows that can be covered with a black
backdrop.
Dressing rooms
All dressing rooms provide hot and cold drinking water, toilets showers.
total amount of rooms:
3
total amount of people:
15
Loading/Unloading
1,5x4,5m
1,75x1,85x4,50m
1000kg
Hardwood (Keruing)
It is allowed to turn screws into the floor.
Thickness
25mm
Maximum load
400kg/m2
Stage dimensions
width:
Stage height grid:
Stage height fly bars
Stage Depth:
Marley dance floor
9.5m
4.9m`
4,6
8.1m
Entire floor 10x8m
Masking
backdrop
cyclorama
Black scrim
Grand Piano
black 2 parts of 7,5m in rail
10x4.5m
10x4.5m
Yamaha C3, 1.86m, built in 1992
By Elevator, to be accessed from the street next to the main entrance of
the theatre.
Appendix 28.
Version 15.02
Elevator plot
26
Appendix 29.
Version 15.02
floorplot
27
LIGHT AND POWER
RIGGING
The Blauwe Zaal has 3 upstage fly bars on chain hoists.
A grid of 48mm pipe covers the rest of the stage. 6 rigging points can be
made on overhead steel bars.
A genie-lift is available to hang lights and other objects.
power
SL 2 USL USI,
Distribution
125A in
Bars
max load fly bars:
max load of the grid:
Appendix 30.
250kg
50kg/m
Maximum load
Dimmers:
1x125A
1x 63A CEE rood
1x 32 CEE rood
6x shuco
144 x 3kW ADB-eurodim
16 over the seating area
92 in the grind
36 on the floor
All dimmer outlets are 2 way 10A shuko.
All spotlights equipped with shuko plugs.
Control
All dimmers are DMX512 controlled through a XLR-5 data network. The
hardpatch of this network is in the control room and contains 2 opto
isolated splitters.
DMX
Grid
Above complete stage, pipes, spaced 50cm. Lights will be placed an
focused with a rolling bridge free space under the bridge is max 2,8m
DMX signals can be sent from:
the control room (2 lines)
FOH-mixing position
stage-left.
DMX signals can be sent to:
house dimmers
the control room
FOH mixing position
stage left
stage right
grid
upstage left
All DMX cables have 5 lines and no earth connection.
Version 15.02
28
Appendix 31.
Light
brand
type
ETC
ION +WING
tracking mixer console
1
ETC
Express 250
Express 250 250 chanels 24 sub's 2 playback's
1
Martin
Mac Aura
yoke
8
alleen te gebruiken in overleg
ADB
Warp
True Blue Theatre
St1/2
zoom profile 800W 12-30º
6
fixed in first row
Arri
nr.
Fresnel 2kW with barndoors
12
Source 4 PAR 575W with all lenzen
30
zoom profile 575W 25-50º
14
fresnel 1kW with barndoors
12
306HPC pebble
pc 1kw with barndoors
22
306HPC pebble
pc 1kw with barndoors
8
asymetrisch (4 voudig 4*1kw)
6
ETC
Source 4 par
ETC
Robert Juliat
Robert Juliat
Robert Juliat
Strand
Source 4 profile
Version 15.02
Discription
306HF
Coda
remark
fixed in first row
29
SOUND
Stage sound
F.O.H. system
Intercom
Sound Projects SP2/15
Per side:
1x top (90°x55°)
1x sub15 inch
Fill
Axys U14+
Processing
2x XTA DP200 2x in 4x out
Multi cable
Control room
2x Socapex (1-24)
24x XLR double
4 x USM (k1-k4)
4x grid (grid1 - grid4)
4x sound pit (25-28)
Sound pit
2x Socapex (1-24)
4x XLR double (21-24)
4x XLR double (25-28 to control room)
USL and USR
2x Socapex (1-24)
24x XLR double (1-24)
Version 15.02
Dressing rooms
1 channel intercom system ASL with connections in control room sound
pit USL USR
VIDEO
Video network
A video coax network is provided with a hardpatch at the control booth.
In this patch 2 splitters are provided. 2x 1 in > 4 out
All connections on the video network are 75Ohm coax cable terminated
with BNC-connectors. All lines are free of earth connections.
Outlets available at:
Stage right (2x)
Stage left (2x)
grid (2x)
FOH position (3x)
center (down)stage (1x)
30
RESTAURANT ZINDERING
LIGHTS AND POWER
FACILITIES
power
Sound pit
Dimmers
1x 63A red
In the back of the auditorium
3x 4 dimmers fixed position
Dressing rooms
DMX
Dressing rooms are shared with the main auditorium
Loading/unloading
FOH system
Loading and unloading trough personal lift: 93x 200cm
Stage size material
hardwood (Keruing)
thickness:
depth:
width:
Heights from stage
Ceiling:
Audience floor
Piano
Yamaha Silent Piano build 2012
Fixed Lines between sound pit and stageSound
20 mm
3m
3.5m
2.7m
-20cm
Sound Projects SP2/15
Per side:
Multi cable
1x top (90°x 55°)
1x sub 15inch
22 kanaals multi cable with following connections:
stage
1x Socapex (1-12)
10x XLR (13-22) first 4 double
Sound pit
1x Socapex (1-12)
10x XLR (13-22) first 4
VIDEO
Video network
3 fixed lines between stage and sound pit in BNC
Version 15.02
31
FOYERS
Floor size and height
HEKMAN FOYER
Smallest pass trough
Floor size and height
LxWxH 17x8,75x3,85m
There are some chandelier on the ceiling that cannot be moved
accessibility
The Hekman foyer is situated on the first floor, and is access is limited for
rolling material. Big and heavy materials like piano’s access the Heckman
Foyer
Smallest pass trough
Rolling material without staircases 75x 200cm
4 step staircase trough personal elevator: 93x 200cm
Numerous stairs trough Zocher foyer terrace 160x 210cm
Capacity
Maximum number of people in the Heckman foyer is 150.
If Seats are placed the capacity will be down scaled to 80.
Obstacles or furniture can downscale the capacity.
If in doubt Stadsschouwburg Utrecht will ask for advice at the Utrecht
fire department furniture. All Furniture is movable except for the bar.
Dressing rooms
Dressing rooms are shared with the main auditorium
Power
LxWxH 19x7,3x3,1m
140x 220cm (main entrance)
Capacities
No fixed number of audience is set. If in doubt Stadsschouwburg Utrecht
will ask for advice at the Utrecht fire department
Dressing rooms
Dressing rooms are shared with the main auditorium
ZOCHER FOYER
Floor size and height
LxWxH 13x7x7m
Accessibility
De Zocher foyer is situated 85cm above the main Floor.
Accessible trough a wide staircase from the entrance or trough the
loading dock Of the main auditorium (no stairs).
Smallest pass trough
88x 200cm. (Trough loading dock of main stage)
Capacities
No fixed number of audience is set. If in doubt Stadsschouwburg Utrecht
will ask for advice at the Utrecht fire department
Dressing rooms
Dressing rooms are shared with the main auditorium
1x 63A CEE red
AV- facilities
The Hekman foyer is equipped with a Full range Sound system, A
beamer/screen combination (16:10), lectern with laptop, 2 wireless
handheld microphones, Cd player and DVD player.
All equipment has been carefully selected for the foyer
Power
1x 32A CEE rood
1x 25A op 32A CE rood
DUDOK FOYER
De Dudok foyer positioned on the main floor. Reachable with rolling
material
Version 15.02
32
ROUND SCHOUWBURG UTRECHT
ZOCHER TERRACE
ZOCHER PARK
Can be used for performances as long as emergency exit’s stay
accessible. If in doubt Stadsschouwburg Utrecht will ask for advice at
the Utrecht fire department
Power
garage 2x
front of main entrance
Cable length
Garage 125A to main entrance
Garage 125A to main barrier
1 x 63A + 1 x 125A
1x 32A op 3 Phase with:
1x 32A rood
2x shuko 16A
25A blauw
75m
75m
Floor size and height
LxW 17x5m height of the doors 2m
Power
Balcony
2x
1x 32A CE red
DUDOK BALCONY
Power
Balcony
1x 32A CE red
Maximal 25A per Phase
Level -1 under balcony
1x 32A CE red
Maximal 25A per Phase
Version 15.02
33
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
