Watchdog Timer Assumes Varied Roles
May 01, 2001
Abstract: The following application note demonstrates alternative uses for the MAX6369-MAX6374 family
of pin-selectable watchdog timers. Alternative uses include a power saving power-on LED indicator
circuit, load connect/disconnect circuit and push-button reset circuit.
The MAX6369-MAX6374 series of pin-selectable watchdog timers are designed to supervise µP activity
and indicate when a system is working improperly. During normal operation, a µP should repeatedly
toggle the WDI (watchdog input) before the selected watchdog-timeout period elapses to indicate that the
system is properly executing code. If it fails to do so, the supervisor IC asserts a active-low WDO
(watchdog output) to signal that a problem exists. The cited family of watchdog supervisors is available in
SOT23-8 packages and has selectable watchdog-timeout periods and delays of 1.7msec to 104sec in
seven steps. The ICs also have selectable output-pulse widths of 1.7msec or 170msec, depending on
part selection and the state of the Set 0, Set 1, and Set 2 pins. You can use these devices for generalpurpose timing functions, especially when low current consumption is important. The ICs consume only
8mA typical and 20mA maximum over temperatures from a 2.5V to 5.5V supply. With WDI connected to
ground or VCC, the internal timer cycles, pulsing active-low WDO low upon timeout. In addition to the
lower current (20mA versus 120mA), the watchdog-timer IC takes less board space and uses no timing
resistors or capacitors. The following circuits represent a few examples.
The circuit in Figure 1 uses a MAX6373 to pulse active-low WDO low for 170msec every 5.2sec. The
load is a front-panel power-on LED with a 1kΩ current-limiting resistor. By pulsing the LED rather than
powering it continuously, the average current decreases by a factor of 30 (88µA versus 2.4mA). The LED
thus indicates that the equipment is on while minimizing battery drain. By changing the Set pins to Set 0
= 0V, Set 1 = Set 2 = VCC, you can extend the off time to 17sec, thus reducing the average current to
Page 1 of 3
Figure 1. A blinking LED allows a 30-to-1 average-current reduction in a power-on indicator.
The circuit in Figure 2 is similar to the one in Figure 1 but uses a MAX6371 to turn on a load for
170msec every 104sec. The load can be a battery-powered monitoring circuit that remains idle, saving
power, and then wakes up to make a measurement.
Figure 2. This circuit wakes up every 104sec to turn on a load for 170msec.
The circuit in Figure 3 uses a MAX6373 with its Set inputs configured for timer disabled. If you hold Set
1 low for longer than the watchdog period (5.2sec), then active-low WDO pulses low. You can use this
circuit in applications in which a reset button is on a front panel, for example. You must deliberately
depress the button for at least 5.2sec to trigger a reset. This feature can prevent an accidental reset
when someone presses the button inadvertently.
Page 2 of 3
Figure 3. You must press the reset button for at least 5.2sec for the reset to take effect.
A similar version of this article appeared in the February 1, 2001 issue of EDN magazine.
