ADVANTECH

SOLID STATE DRIVE (SSD)

Q1/2016 Roadmap

PAPS Product Management

Q1/2016

PAPS SSD Product Portfolio

Intel® SSD Solution

High Input Output per second. Best for server applications.

Form Factor

NVME 2.5”

NVME HHHL

SATAIII 2.5

Plextor® SSD Solution

Excellent Sequential R/W for enterprise application requiring high R/W performance.

Form Factor

SATAIII 2.5” mSATA

Transcend 370 Solution

Extended temperature(-10° – 80°& -40°-80°) best for tough environment applications

.

Form Factor

SATAIII 2.5” mSATA

M.2

PAPS

PAPS SSDs Add-ons Value

PAPS

Fixed F/W and

Fixed Memory

Reliability

Quality

System

Compatibility

Premium

NAND

Intel Data Center SSDs Features

Breakthrough Performance

Up to six times faster data transfer speed than 6 Gbps

SAS/SATA SSDs. The performance of a single drive from the

Intel SSD Data Center Family for PCIe, specifically the Intel®

Solid-State Drive Data Center P3700 Series (460K IOPS).

Modernizes Data Center Storage

Intel led the industry in creation of a new Non-Volatile

Memory Express* (NVMe) storage interface standard.

NVMe overcomes SAS/SATA SSD performance limitations by optimizing hardware and software to take full advantage of NVM SSD technology.

Comprehensive Solution

Intel is driving transition to NVMe SSDs by providing a comprehensive product line, enabling extensive system compatibility, delivering Intel® drivers as well as supporting industry driver development, and completing numerous industry-standard compliance certifications.

Proven Quality and Reliability

Intel SSD Data Center Family for PCIe devices are based on

Intel®-developed controller, firmware, and leading manufacturing process NAND flash memory. Rigorous qualification and compatibility testing ensures a highly reliable SSD.

Plextor SSDs Features

High Tg

(Glass Transition Temperature)

Value PCB for better heat and bending resistance

Over Voltage Protection

Product Longevity (3 years)

AES

(Advanced Encryption Standard)

Encryption

Fixed Firmware

Better Lead Time

Type C NAND

Plextor SSD Focus on

Server-Class

Controller

Best Japanese

Components

Exclusive

Firmware

Excellent Quality

Q1/2016

True Speed Advantages- Plextor

Clean State

The extensive read and write of large amount of temporary files, or frequent add and delete of files, or producing numerous fragmented files may cause memory block to become dirty state.

The test result shows how SSD performance are affected before and after the block became dirty in the

IOmeter benchmark test. After a heavy usage for processing everyday office application, the average write speed dropped significantly

Q1/2016

Dirty State

True Speed Advantages- Plextor

True Speed

performs an unique algorithm to ensure data block write optimization by utilizing internal cache to perform the block erase process and garbage collection to speeds up the data writing speed.

So even after long usage, Plextor SSD can still maintain the same level of performance as a new drive. This perfectly overcomes the slowdown problems associated with dirty state

SSDs.

Q1/2016

Transcend 370 SSDs Features

Wide Temperature

More space. More to store

Q1/2016

Ultra-Slim, Ultra-portable

Power saving. Fast response

SSD Naming Convention

96 Part Number

9 6 F D

Flash Memory

FD=Solid State Drive

1 8

Form

Factor

18=1.8”

25=2.5”

35=3.5”

42= M.2

22mmx42mm

60=M.2

22mmx60mm

80=M.e

22mmx80mm mSATA & half slim = Blank

S

Interface

S=SATA

P=PCIE

M=Mini SATA

N=NGFF

H=HALF SLIM

8 0

Capacity

8G=8GB

16=16GB

32=32GB

64=64GB

128=128GB

256= 256GB

512=512GB

1TB=1TB

Color / Symbol Key

I

Application

I= Industrial Temp

I N A

Product Series

INA=Intel 335

INB=Intel S3500

PLG=Plextor G

TR7=Transcend370B

IN=Innodiskk

Q1/2016

SATA

1.8”

FLASH DRIVE (0~70°C) MLC

96FD18-S80-INB

IntelSSD DC S3500 80GB, 1.8" SATAIII, MLC 5mm EOL: Q1/2016

96FD18-S240-INB

IntelSSD DC S3500 240GB, 1.8" SATAIII, MLC 5mm EOL:Q1/2016

Q1/2016

Q1/2016 Q2/2016 Q3/2016 Q4/2016

SATA

2.5” 7MM

FLASH DRIVE (0~70°C) MLC

96FD25-S80-INB

IntelSSD DC S3500 80GB, 2.5" SATAIII, MLC 7mm EOL:Q4/2015

96FD25-S80-INB1

IntelSSD DC S3510, 80GB, 2.5" SATAIII, MLC

96FD25-S120-INB

IntelSSD DC S3500 120GB, 2.5" SATAIII MLC 7mm EOL:Q4/2015

96FD25-S120-INB1

IntelSSD DC S3510 , 120GB, 2.5" SATAIII, MLC

96FD25-S160-INB

IntelSSD DC S3500 160GB, 2.5" SATAIII MLC 7mm EOL:Q2/2016

96FD25-S240-INB

IntelSSD DC S3500 240GB, 2.5" SATAIII MLC 7mm EOL:Q4/2015

96FD25-S240-INB1

IntelSSD DC S3510, 240GB, 2.5" SATAIII, MLC

96FD25-S300-INB

IntelSSD DC S3500 300GB, 2.5" SATAIII, MLC 7mm EOL:Q4/2015

96FD25-S480-INB

IntelSSD DC S3500 480GB, 2.5" SATAIII, MLC 7mm EOL:Q4/2015

96FD25-S480-INB1

IntelSSD DC S3510 , 480GB, 2.5" SATAIII, MLC

96FD25-S600-INB

IntelSSD DC S3500 600GB, 2.5" SATAIII MLC 7mm EOL:Q2/2016

Q1/2016

Q1/2016 Q2/2016 Q3/2016 Q4/2016

SATA 2.5” 7MM

FLASH DRIVE (0~70°C)

MLC

96FD25-S032-PLG

Plextor SSD 32GB, 2.5" SATAIII, MLC 7mm

96FD25-S064-PLG

Plextor SSD 64GB, 2.5" SATAIII, MLC 7mm

96FD25-S128-PLG

Plextor SSD 128GB, 2.5" SATAIII, MLC 7mm

96FD25-S256-PLG

Plextor SSD 256GB, 2.5" SATAIII, MLC 7mm

96FD25-S512-PLG

Plextor SSD 512GB, 2.5" SATAIII, MLC 7mm

96FD25-S1TB-PLG

Plextor SSD 1TB, 2.5” SATAIII, MLC 7mm

Q1/2016

Q1/2016 Q2/2016 Q3/2016 Q4/2016

mSATA FLASH DRIVE (0~70

C)

MLC

96FD-M032-PLG

Plextor SSD 32GB, mSATA SATAIII, MLC EOL:Q4/2015

96FD-M032-PLG1

Plextor mSATA, PX-32G7Me, A19nm, 32GB, SATA 6GB/s

96FD-M064-PLG

Plextor SSD 64GB,mSATA SATAIII, MLC EOL:Q4/2015

96FD-M064-PLG1

Plextor mSATA, PX-64G7Me, A19nm, 64GB, SATA 6GB/s

96FD-M128-PLG

Plextor SSD 128GB, mSATA SATAIII, MLC EOL:Q4/2015

96FD-M128-PLG1

Plextor mSATA, PX-128G7Me, A19nm, 128GB, SATA 6GB/s

96FD-M256-PLG

Plextor SSD 256GB, mSATA SATAIII, MLC EOL:Q4/2015

96FD-M256-PLG1

Plextor mSATA, PX-256G7Me, A19nm, 256GB, SATA 6GB/s

96FD-M512-PLG

Plextor mSATA, PX-512G7Me, A19nm, 512GB, SATA 6GB/s

Q2/2016

Q1/2016

Q1/2016 Q3/2016 Q4/2016

HALF SLIM SATA FLASH DRIVE (0~70

C)

MLC

96FD-H032-PLG

Plextor SSD 32GB HALFSLIM SATAIII MLC

96FD-H064-PLG

Plextor SSD 128GB, HALF SLIM SATAIII MLC

96FD-H128-PLG

Plextor SSD 128GB, HALF SLIM SATAIII MLC

Q1/2016

Q1/2016 Q2/2016 Q3/2016 Q4/2016

M.2 2242 FLASH DRIVE (0~70

C)

MLC

96FD42-N064-PLG

Plextor PX-64G7Ge, SSD 64GB M.2 2242 MLC

96FD42-N128-PLG

Plextor PX-128G7Ge, SSD 128GB M.2 2242 MLC

M.2 2280 FLASH DRIVE (0~70

C)

MLC

96FD80-N064-PLG

Plextor PX-64G7Ne, SSD 64GB M.2 2280 MLC

96FD80-N128-PLG

Plextor PX-128G7Ne, SSD 128GB M.2 2280 MLC

96FD80-N256-PLG

Plextor PX-256G7Ne, SSD 128GB M.2 2280 MLC

Q1/2016

Q1/2016 Q2/2016 Q3/2016 Q4/2016

SATA 2.5” 7MM

FLASH DRIVE (-10~80°C)

MLC

96FD25-S032-TR7

Transcend370 SSD 32GB, 2.5" SATAIII, MLC 7mm

96FD25-S064-TR7

Transcend370 SSD 64GB, 2.5" SATAIII, MLC 7mm

96FD25-S128-TR7

Transcend370 SSD 128GB, 2.5" SATAIII, MLC 7mm

96FD25-S256-TR7

Transcend370 SSD 256GB, 2.5" SATAIII, MLC 7mm

96FD25-S512-TR7

Transcend370 SSD 512GB, 2.5" SATAIII, MLC 7mm

96FD25-S1TB-TR7

Transcend370 SSD 1TB, 2.5" SATAIII, MLC 7mm

Q1/2016

Q1/2016 Q2/2016 Q3/2016 Q4/2016

SATA 2.5” 7MM

FLASH DRIVE (-40~90°C)

MLC

96FD25-S032-ITR4

Transcend370 W-temp SSD 32GB, 2.5" SATAIII, MLC 7mm

96FD25-S064-ITR4

Transcend370 W-temp SSD 64GB, 2.5" SATAIII, MLC 7mm

96FD25-S128-ITR4

Transcend370 W-temp SSD 128GB, 2.5" SATAIII, MLC 7mm

96FD25-S256-ITR4

Transcend370 W-temp SSD 256GB, 2.5" SATAIII, MLC 7mm

96FD25-S512-ITR4

Transcend370 W-temp SSD 512GB, 2.5" SATAIII, MLC 7mm

96FD25-S1TB-ITR4

Transcend370 W-temp SSD 1TB, 2.5" SATAIII, MLC 7mm

Q1/2016

Q1/2016

Q2/2016 Q3/2016 Q4/2016

mSATA

FLASH DRIVE (-10~80°C)

MLC

96FD-M032-TR7

Transcend370 SSD 32GB, mSATA SATAIII, MLC

96FD-M064-TR7

Transcend370 SSD 64GB, mSATA SATAIII, MLC

96FD-M128-TR7

Transcend370 SSD 128GB, mSATA SATAIII, MLC

96FD-M256-TR7

Transcend370 SSD 256GB, mSATA SATAIII, MLC

96FD-M512-TR7

Transcend370 SSD 512GB, mSATA SATAIII, MLC

Q1/2016

Q1/2016 Q2/2016 Q3/2016 Q4/2016

M.2 2242

FLASH DRIVE (-10~80°C)

MLC

96FD42-N032-TR7

Transcend370 SSD 32GB, M.2 2242 SATAIII, MLC

96FD42-N064-TR7

Transcend370 SSD 64GB, M.2 2242 SATAIII, MLC

96FD42-N128-TR7

Transcend370 SSD 128GB, M.2 2242 SATAIII, MLC

96FD42-N256-TR7

Transcend370 SSD 256GB, M.2 2242 SATAIII, MLC

Q1/2016

Q4/2015 Q1/2015 Q2/2016 Q3/2016

M.2 2280

FLASH DRIVE (-10~80°C)

MLC

96FD80-N032-TR7

Transcend370 SSD 32GB, M.2 2280 SATAIII, MLC

96FD80-N064-TR7

Transcend370 SSD 64GB, M.2 2280 SATAIII, MLC

96FD80-N128-TR7

Transcend370 SSD 128GB, M.2 2280 SATAIII, MLC

96FD80-N256-TR7

Transcend370 SSD 256GB, M.2 2280 SATAIII, MLC

Q1/2016

Q4/2015 Q1/2015 Q2/2016 Q3/2016

SSD Performance Chart

Intel DC S3500

Form Factor

SATAIII 2.5” X

9.5mm

Plextor G Series

Micro SATA III

1.8”

SATA III 2.5” 7mm mSATA

Large Data Center Industrial Application

Target Market

Capacity (GB)

80/120/240/480/

600

80/240 32/64/128/256

80GB:340MB 80GB:340MB 32/64GB:360MB

32/64/128/256

32GB:390MB

Seq. Read Peak

(MB/s)

Seq. Write Peak

(MB/s)

Max Write IOPS

Max Read IOPS

120GB:445MB 240GB:500MB 128/256GB:530MB

240GB+:500MB

80GB:100MB 80GB:100MB

120GB:175MB 240GB:260MB

240GB:260MB

600GB:410MB

80GB:70K

80GB:70K

120GB+:75K

80GB:7K

120GB:7.5K

240GB:7.5K

600GB:11K

240GB+:7.5K

80GB:7K

240GB:7.5K

32GB:80MB

64GB:160MB

128GB:310MB

256GB:440MB

32/64GB:40K

128GB:89K

256GB:95K

32GB:20K

64GB:40K

128GB:75K

256GB:80K

Q1/2016

64GB:530MB

128GB:530MB

256GB:520MB

32GB:70MB

64GB:150MB

128GB:300MB

256GB:410MB

32GB:41K

64GB:70K

128GB:75K

256GB:74K

32GB:19K

64GB:39K

128GB+:70K

SATA III 2.5” 7mm

Wide Temperature

Environment

32/64/128/256/512/1T

32GB:260MB

64GB:520MB

128GB:570MB

256GB:570MB

512GB:570MB

1TB:570MB

32GB:40MB

64GB:90MB

128GB:170MB

256GB:310MB

512GB:470MB

1TB:470MB

32GB:20K

64GB:40K

128GB:70K

256GB:75K

512GB:75K

1TB:75K

32GB:10K

64GB:20K

128GB:40K

256GB:75K

512GB:75K

1TB:75K

Transcend 370 mSATA

Wide Temperature

Environment

32/64/128/256/512

32GB:230MB

64GB:450MB

128GB:550MB

256GB:550MB

512GB:570MB

32GB:40MB

64GB:80MB

128GB:170MB

256GB:320MB

512GB:470MB

32GB:20K

64GB:40K

128GB:70K

256GB:75K

512GB:70K

32GB:5K

64GB:10K

128GB:40K

256GB:70K

512GB:75K

Thank you

Q1/2016

SSD Market Trend

Q1/2016

Differences between M.2 and mSATA

M.2 or NGFF ( Next Generation Form Factor) is a new specification for computer with limited internal space.

It is used to replace mSATA and has more flexible physical form factor allowing different module widths and lengths. With more advanced features, M.2 is more suitable for varieties of industrial PC applications

PAPS

mSATA M.2

Form factor

Full Size 50.8mm

Half Size 26.8mm

Type 22110 110mm

Type 2280 80mm

Type 2260 60mm

Standard width

Standard

Thickness

29.85mm

4.85mm

22mm

Single side 2.15mm

Double side 3.58mm

Q1/2016

SSD Product Comparison

– Enterprise

E50

Product

Spare Block Indicator

SP610

X210 SSD 3510

NAND Flash Type MLC (Sync.)

Capacity 16GB ~ 1TB

Seq. Read

/Write

512GB

256 GB

128GB

4K

Radom

Read

/Write

512GB

256 GB

128GB

Operating

Temp

Standard

Features

520MB/450MB

530MB/440MB

520MB/310MB

94K/73K

94K/85K

92K/73K

0°C ~ 70°C

Advanced Write

Optimization

Q1/2016

MLC (Sync.)

16GB ~ 256GB

535MB/500MB

5350MB/500MB

535MB/500MB

52K/31K

59K/76K

85K/79K

0°C ~ 70°C

DuraClass

MLC (Sync.)

128GB ~ 1TB

560MB/450MB

560MB/290MB

560MB/150MB

73K/72K

75K/67K

66K/35K

0°C ~ 70°C

Short Circuit

Protection

MLC (Sync.)

128GB ~ 512GB

505MB/470MB

505MB/470MB

505MB/330MB

89K/58K

88K/60K

86K/55K

0°C ~ 70°C

Unexpected Power

Loss Protection

MLC (Sync.)

80~480 GB

500MB/440MB

500MB/260MB

500MB/135MB

75K/11K

68K/10K

68K/5K

0°C ~ 70°C

SSD Product Comparison

– Industrial System

Product

SFD 25A-M

3MG-P

3MR-P PS3108

PS3109

NAND Flash Type

Capacity

MLC (Sync.)

32 GB ~ 1TB

MLC

(Async.)

MLC (Sync.)

MLC (Async.)

16GB ~ 256GB

MLC (Sync.)

8GB ~ 512GB 32GB ~ 512GB

512GB

Seq.

Read

256 GB

128GB

570MB/s

570MB/s

570MB/s

N/A

385MB/s 450MB/s

385MB/s 450MB/s

460MB/s

500MB/s

460MB/s

460MB/s

260MB/s 512GB

Seq.

Write

256 GB

128GB

470MB/s

310MB/s

170MB/s

Operatin g Temp

Standard

Features

-10°C ~ 80°C

-40°C ~ 90°C

Advanced Power

Shield (HW)

Q1/2016

N/A

170MB/s 430MB/s

170MB/s 300MB/s

0°C ~ 70°C

Power Failure

Management

240MB/s

0°C ~ 70°C

iCell (optional)

240MB/s

240MB/s

0°C ~ 70°C

iCell

MLC (Sync.)

Up to 1TB

500MB/s

460MB/s

0°C ~ 70°C

MLC (Sync.)

4G ~ 256GB

N/A

500MB/s

N/A

200MB/s

0°C ~ 70°C

SSD EOL Procedure

In order to optimize support and product management, PAPS will follow the SSD phase-out procedure as below.

3 Month

Official EOL

Announcement

Last Time

Buy Order

Replacement and Evaluation Approval

2 Month

EOL

Q1/2016

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
