Online UPS

Professional Series (1P/1P) - Tower

Online Professional Series

1kVA – 6kVA

Small Computer

Network

Local Area

Network (LAN)

Work-Stations Servers

Professional Series (1P/1P) is an advanced yet affordable single-phase UPS system that uses online double conversion technology. It is designed to protect against power outages, disturbances and spikes, making them most suitable for voltage fluctuating environments. This device is able to provide high-efficiency charging with its high input power factor correction.

Professional Series is available in capacities ranging from 1000VA to

6000VA. High voltage battery chargers and battery extension assembly are made available for longer runtime applications. Users can also have the option to top-up an additional isolation transformer to obtain pure and clean power for their sensitive devices.

• True Double-Conversion Online UPS

• Wide input voltage range (110~300VAC)

• Input Power Factor correction of 0.98

• Output Power Factor of 0.8

• Generator compatible

• LCD User Interface

• Choice between RS-232 communication port or USB / RS-232 / AS400 / SNMP interface

• Smart battery charger designed to optimize battery performance

• Isolation transformer (optional)

Rear Panel

For 1kVA to 6kVA model

1. Output receptacles

2. AC input

3. Input circuit breaker

4. Network/Fax Modem Surge Protection

5. Intelligent slot for communication port/

SNMP. (standard come with USB port)

6. External battery connection (only available for L model)

7. Output terminal

8. Output circuit breaker

9. Fan

5

6

9

3

4

2

1

PRO901S/L

PRO902S/L

9

4

1

8

6

5

3

7

2

PRO903S/L

2

9

5

4

1

8

6

7

PRO906S/L

04

Online UPS

Options

• RS-232 Port (communication interface)

• AS-400 Card (External alarm indicator)

• SNMP Card for data communication via network connection

• Output Isolation Transformer

• External PDU & Maintenance Bypass Switch (suitable for UPS up to 3kVA only)

Full Specifications

MODELS

Capacity

INPUT

Voltage Range

Frequency Range

Power Factor

OUTPUT

Output Voltage

Voltage Regulation (Batt. Mode)

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer Time

AC Mode to Batt. Mode

Inverter to Bypass

Waveform (Batt. Mode)

EFFICIENCY

AC Mode

BATTERY

Standard Model

Long-Run Model

Type

Capacity

Recharge Time (Typical)

Charging Current

Type

Capacity

Charging Current

OVERLOAD

100% < Load < 110%

110% < Load <130%

>130%

INDICATORS

LCD Display

PHYSICAL

Standard Model

Long-Run Model

ENVIRONMENT

Operation Humidity

Ambient Temperature

Noise Level

Regulations

MANAGEMENT

USB

Dimension (mm) D x W × H

Net Weight (kgs)

Dimension (mm) D × W × H

Net Weight (kgs)

PRO901S/ L

1 000 VA

PRO902S/ L

2000 VA

PRO903S/ L

3 000 VA

110-300 VAC ± 5 %

40 ~ 70H z (Auto sensing)

≧ 0.98 @ Nominal Voltage (100% load)

200/208/220/230/240 VAC or 100/110/115/120/127 VAC

± 1 %

47 ~ 53 Hz or 57 ~ 63 Hz

50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz

3:1

≦ 3 % THD (Linear Load), ≦ 7 % THD (Non-linear Load)

Zero

4 ms (Typical)

Pure Sinewave

Up to 88%

PRO906S/ L

6 000 VA

Valve regulated Lead Acid battery (Maintenance free batteries)

9AH

Back to 90% capacity in 9 hours

1 .0A (max)

Depending on the application

Depending on the application

1A / 2A / 4A / 8A (Default)

10AH

1A / 2A / 4A / 6A (Default)

Overload warning only (No shutdown)

30 seconds

1.5 seconds

10.8

5.7

Input / Output Voltage, Load Level, Batt Level, UPS Status, Fault Conditions

397 x 145 x 220

397×145×220

17.2

8.9

421 × 190 × 318

28.7

421×190×318

13.1

426 × 190 × 318

36.2

426×190×318

15.2

<90% (Non-condensing)

0°C - +40°C

≤ 45dB @ 1 Meter

Safety: EN62040-1-1; EMI62040-2; EN62040-3

< 55dB @ 1 Meter

Supports Windows ® 2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

05

Online UPS

Professional Series (1P/1P) - Dual

Online Professional Series

1kVA – 3kVA

Small Computer

Network

Local Area

Network (LAN)

Work-Stations Servers

Professional Series (1P/1P) - Dual is an advanced yet affordable single-phase UPS system that uses on-line double conversion technology with 2 different input voltage ranges. It is designed to protect against power outages, disturbances and spikes, making them most suitable for voltage fluctuating environments.

Professional Series (1P/1P) – Dual is most suitable to be used in areas that are plagued by voltages that are as low as 100V. With the advanced double-conversion technology, the dual series is able to regulate and maintain consistent output even when it is fully loaded.

Also, this device is able to provide full isolation and complete common mode noise rejection from complementary equipment. The

Dual Series is available in various capacities, ranging from 1000VA to 3000VA.

• True double-conversion

• Accepts dual input voltage for special power environment with High

Voltage and Low Voltage

• Complete galvanic isolation design offers full isolation and complete common mode noise rejection

• Wide input voltage range (88-144VAC and 176-288VAC) at full load

• Selectable output voltage at 110VAC or 220VAC

• ECO mode for energy saving

• Input power factor correction 0.99

• Output voltage regulation < ± 1%

• Mini slot for USB / RS-232 / AS400 / SNMP communication

• Smart battery charger design for optimized battery performance

Rear Panel

For 1kVA to 3kVA model

1. Output receptacles

2. AC input

3. Input circuit breaker

4. Network/Fax/Modem surge protection

5. Intelligent slot for communication port/SNMP

(standard come with USB port)

6. External battery terminal

(only available for Long-run model)

7. Output terminal

8. Output circuit breaker

9. Fan

5

9

4

3

2

9

6

1

PRO901DS/DL

9

5

4

6

1

9

2

9

PRO902DS/DL

2

9

9

5

8

4

6

1

7

9

PRO903DS/DL

06

Online UPS

Options

• RS-232 Port (communication interface)

• AS-400 Card (External alarm indicator)

• SNMP Card for data communication via network connection

• External PDU & Maintenance Bypass Switch (suitable for UPS up to 3kVA only)

Full Specifications

MODELS

Capacity

INPUT

Nominal Voltage

Voltage Range

Frequency Range

Power Factor

OUTPUT

Output Voltage

AC Voltage Regulation (Static)

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer Time

AC Mode to Battery Mode

AC Mode to Bypass

Bypass to AC Mode

Waveform (Batt. Mode)

EFFICIENCY (Peak)

AC Mode (@100% RCD load)

Battery Mode(@100% RCD load)

ECO Mode

BATTERY

Standard Model

Long-Run Model

Battery Type

Battery Numbers

Recharge Time (Typical)

Charging Current

Charging Voltage

Battery Type and Numbers

Charging Current

Charging Voltage

INDICATORS

LCD Panel

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Standard Model

Long-Run Model

Dimension (mm) D x W × H

Net Weight (kgs)

Dimension (mm) D × W × H

Net Weight (kgs)

ENVIRONMENT

Operation Humidity

Noise Level

MANAGEMENT

Communication

Optional SNMP

PRO901DS/DL

1000 VA

PRO902DS/DL

2000 VA

110/115/120/127 VAC or 208/220/230/240 VAC (Auto sensing)

88-144 VAC and 176 - 288 VAC (Auto sensing)

45Hz ~ 55 Hz or 56Hz ~ 65 Hz

≧ 0.99 @ Nominal Voltage (100% Load)

PRO903DS/DL

3000 VA

76% (Typical); 78% (Peak)

84% (Typical); 86% (Peak)

85%

110/115/120/127 VAC or 208/220/230/240 VAC

± 1%

47 Hz ~ 53 Hz or 57 Hz ~ 63 Hz

50 Hz ± 0.2 Hz or 60Hz ± 0.2 Hz

3:1

≦ 2 % THD (Linear Load) ; ≦ 6 % THD (Non-linear Load)

Zero

4 ms (Typical)

4 ms (Typical)

Pure Sinewave

77% (Typical); 79% (Peak)

86% (Typical); 88% (Peak)

88%

78% (Typical); 80% (Peak)

87% (Typical); 89% (Peak)

90%

2

27.4 VDC ± 1%

12V / 9Ah

4

Back to 90% capacity in 5 hours

1 .0A (max)

54.8 VDC ±1%

Depending on application

4A or 8A

54.8 VDC ±1%

6

82.2 VDC ±1%

27.4 VDC ± 1% 82.2 VDC ±1%

UPS status, Load level, Battery level, Input / Output / battery info, Discharge timer, and Fault conditions

Sounding every 4 seconds

Sounding every second

Sounding twice every second

Continously sounding

423 x 145 x 332

26.5

423 x 145 x 332

21.5

426 x 190 x 448

34

426 x 190 x 448

23

426 x 190 x 448

56

426 x 190 x 448

41

20-95 % RH @ 0- 40°C (Non-condensing)

Less than 50dBA @ 1 Meter

RS232 Card / Optional USB Card, SNMP Card, or AS400 Card

Supports Windows ® 2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

Power management from SNMP manager and web browser

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

07

Online UPS

Master Series (1P/1P) - Tower

Online Master Series

1kVA – 10kVA

Small Computer

Network

Local Area

Network (LAN)

Work-Stations Servers

Master Series (1P/1P) is a single-phase UPS system that employs a true online double-conversion technology. It is designed to deliver clean and high quality electrical power for devices such as small computer centres, servers, telecom applications, lab testing equipments and industrial applications. The Master series (1P/1P) comes with a wide input voltage range that protects devices against outages, disturbances and spikes. In addition, this device comes with a smart battery charger that optimizes the battery performance, ensuring longer lasting battery life. High voltage battery chargers and battery extension assembly are made available for longer runtime applications. The Master series (1P/1P) also comes in various capacities ranging from 1kVA to 10kVA to suit your needs.

The 6kVA and 10kVA UPS system comes with 2 additional features; an internal bypass system and a parallel redundant system. An internal bypass system allowing continuous power is integrated for convenience when maintenance is necessary and a parallel redundant system that allows two UPS models to operate in parallel as backup for each other.

• True Double-Conversion Online UPS

• Output Power Factor 0.8

• Wide input voltage range (110~300V)

• Programmable power management outlets

• 50/60 Hz Frequency Converter Mode

• ECO mode operation for energy saving

• Emergency Power Off (EPO) Function

• SNMP/USB+RS-232 multiple communications

(SNMP is optional)

• DSP technology applied for 6K and up models

• Smart battery charger design to optimize battery

performance

• Maintenance bypass available for 6K and up models

• Optional hot standby mode and N+X parallel redundancy

available for 6K and up models

• Adjustable battery numbers for 6K and up models

• Built-in isolation transformer (Option)

Rear Panel

For 1kVA to 3kVA model

1. Programmable outlets: connect to non-critical loads

2. Output receptacles: connect to mission critical loads

3. AC input

4. Input circuit breaker

5. Network/ Fax/ Modem surge protection

6. Emergency power off function connector (EPO)

7. USB communication port

8. RS-232 communication port

9. SNMP intelligent slot

10. External battery connection (only available for L model)

11. Output terminal

12. Output circuit breaker

13. Fan

7

6

8

13

4

3

5

9

1

2

PRO801S/L

PRO8015S/L

10

7 8

6

4

3

13

13

9

10

2 1

PRO802S/L

5

7 8

6

4

3

13

13

9

10

12

2 1

11

PRO803S/L

5

08

For 6kVA to 10kVA model

1. RS-232 communication port

2. USB communication port

3. Emergency power off function connector (EPO connector)

4. Share current port (only available for parallel model)

5. Parallel port (only available for parallel model)

6. Intelligent slot

7. Charger fan

8. Power stage fan

9. Maintenance bypass switch

10. Input circuit breaker

11. Input/Output terminal

12. Output terminal 1

13. Output terminal 2

14. External battery terminal (only available for Long-run model)

15. Utility input terminal

16. Output IEC Socket

1 2 3 4

8

7

5 5

6

8

14

16

9

10

12 13 15

11

Online UPS

PRO806S/L

PRO810S/L

Battery Pack

For 1kVA to 3kVA model

G6

Model

Battery Type

Battery Number (max)

12V7AH

6 pcs

12V9AH

6 pcs

Dimension (DxWxH) mm

Weight (kg)

397 × 145 × 220

18 20

12V7AH

12 pcs

G12

12V9AH

12 pcs

421 × 190 × 318

36 40

12V7AH

18 pcs

G18

12V9AH

18 pcs

535 × 190 × 318

55 61

For 6kVA to 10kVA model

G40

Model

Battery Type

Battery Number (max)

12V7AH

40 pcs

Dimension (DxWxH) mm

Weight (kg)

12V9AH

40 pcs

109

592 × 250 × 576

125

G60

12V7AH / 12V9AH

60 pcs 60 pcs

166

830 × 250 × 576

190

09

Online UPS

Options

• AS-400 Card (External alarm indicator)

• SNMP Card for data communication via network connection

• Output Isolation Transformer

• External PDU & Maintenance Bypass Switch (Only suitable for UPS that are up to 3kVA)

Full Specifications

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Voltage Range

Frequency Range

Power Factor

OUTPUT

Output Voltage

Voltage Regulation (Batt. Mode)

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer Time

Waveform (Batt. Mode)

EFFICIENCY

AC Mode

Battery Mode

BATTERY

AC Mode to Batt. Mode

Inverter to Bypass

Type

Number

Standard Model Recharge Time (Typical)

Long-Run Model

Charging Current

Charging Voltage

Battery Type

Numbers

Charging Current

Charging Voltage

INDICATORS

LCD Display

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Standard Model

Long-Run Model

ENVIRONMENT

Operation Humidity

Noise Level

Dimension (mm) D x W × H

Net Weight (kgs)

Dimension (mm) D × W × H

Net Weight (kgs)

MANAGEMENT

Smart RS-232

USB

Optional SNMP

PRO801S/ L

1 000

13

7

VA

12 V / 7 Ah

3

PRO8015S/ L

1500

41.0 VDC ± 1%

397 x 145 x 220

397×145×220

14

7

VA

12 V / 9 Ah

8.0A

Supports Windows ®

PRO802S/ L

2000

13

VA

12 V / 7 Ah

Less than [email protected]

6

PRO803S/ L

Single phase with ground

3

82.1 VDC ±1%

421×190×318

000

200/208/220/230/240 VAC or 100/110/115/120/127 VAC

55-150 VAC ± 5 % or 110-300 VAC ± 5 % at 50% load

80-150 VAC ± 5 % or 160-300 VAC ± 5 % at 100% load

40 ~ 70H z

0.99 @ Nominal Voltage (100% Load)

200/208/220/230/240 VAC or 100/110/115/120/127 VAC

87%

83%

47~53 Hz or 57~63 Hz

50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz

≦ 2 % THD (Linear Load)

≦ 4 % THD (Non-linear Load)

Zero

4 ms (Typical)

± 1 %

3:1

Pure Sinewave

90%

87%

26

421 × 190 × 318

28

13

VA

12 V / 9 Ah

3

Back to 90% capacity in 4 hours

41.0 VDC ± 1%

1 .0A (max)

82.1 VDC ±1%

Depending on the application

6

Sounding every 4 seconds

Sounding every second

Sounding twice every second

Continuously sounding

20-90 % RH @ 0- 40°C (Non-condensing)

PRO806S/ L

6

000

25

VA

12 V / 7 Ah

273.0 VDC ±1%

81

592 x 250 x 576

592 x 250 x 576

Less than

[email protected]

2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

Power management from SNMP manager and web browser

A derate will occur during the Frequency converter mode (Capacity is reduced to 60%) and when the output voltage is adjusted to 208VAC (Capacity is reduced to 80%).

If the UPS is installed in a location where the altitude is above 1000m, the output power must be lowered by one percent for every 100m covered.

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

Zero

89%

88%

Back to 90% capacity in 7 hours

20

18-20

4.0A

PRO810S/ L

10000

208/220/230/240 VAC

208/220/230/240 VAC

273.0 VDC ±1%

UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions

83

27

VA

110-300 VAC at 50% load

176-300 VAC at 100% load

46 ~ 54 Hz or 56 ~ 64 Hz

≧ 0.99 @ 100% Load

46 ~ 54 Hz or 56 ~ 64 Hz

50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz

3 % THD (Linear Load)

6 % THD (Non-linear Load)

12 V / 9 Ah

Back to 90% capacity in 9 hours

Less than

[email protected]

10

Online UPS

True double-conversion Online UPS

A true double conversion UPS will provide clean, high level quality power to fully protect mission-critical devices such as sensitive networks, small computer centers, servers, telecom applications, as well as for industrial applications.

SNMP + USB + RS-232 Multiple

Communication port for Models ranging from 1 to 3kVA.

This feature allows either the USB or RS-232 communication port to simultaneously operate with the

SNMP interface.

Output Power factor of 0.8

As compared to the online UPS models in the current market, the Master Series (1P/1P) provides better output power factor of up to 0.8. This unit is able to offer higher performance and efficiency for your critical applications.

Higher Accuracy for Output Voltage

The advanced control firmware allows the Master Series

(1P/1P) to achieve higher accuracy with the output voltage tolerance of +/- 1%. The device is applicable for the use with critical test and IT equipments.

Wide Input Voltage Range (110 V -300 V)

Master Series (1P/1P) can still provide stable power to connected devices under unstable power environments.

Programmable Power Management Outlets

The programmable power management outlets allow users to easily and independently control the load segment. In the event of a power failure, this feature enables users to manage and extend the battery time for mission critical devices by shutting down the non-critical devices.

Programmable Outlets (P1)

- connect to non-critical devices

Smart Battery Charger Design to Optimise

Battery Performance

Master Series (1P/1P) 1-3kVA models are equipped with a 2-stage charger design to guarantee precise battery discharge time. The charging voltage is also automatically adjusted according to the ambient temperature, to lengthen the service life of the battery.

The 6kVA and 10kVA models come with an additional extendable charger that allows for large-capacity battery charging.

DSP Technology (Applies for the above models)

A DSP controller improves the performance and efficiency of the UPS.

50/60 Hz Frequency Converter Mode

Lock output frequency at 50Hz or 60Hz to suit power sensitive equipments.

Maintenance Bypass Available For 6kVA And

Above Models

Internal bypass assures continuous power to critical devices during UPS maintenance.

ECO Mode Operation For Energy Saving

Offers efficiency as high as 97% to cut energy usage & cost. UPS power application via static bypass, timely returning to online double conversion when the need arises.

Emergency Power Off (EPO) Function

This feature can protect the personnel and the equipment in the case of fire outbreak or other types of emergency.

Optional Hot Standby and N+X Parallel

Redundant System (Available for Models ranging from 6kVA and above)

An internal bypass system allowing continuous power is integrated for convenience when maintenance is necessary and a parallel redundant system that allows two UPS models to operate in parallel as backup for each other.

11

Online UPS

Master Series (1P/1P) - Tower

Online Master E Series

6kVA – 10kVA

0.9

Output Power

Factor

Small Computer

Network

Local Area

Network (LAN)

Work-Stations Servers

Master E Series (1P/1P) is a single-phase UPS system that employs a true online double-conversion technology. It is designed to deliver clean and high quality electrical power for devices such as small computer centres, servers, telecom applications, lab testing equipments and industrial applications. The Master E

Series (1P/1P) comes with a wide input voltage range that protects devices against outages, disturbances and spikes. In addition, this device comes with a smart battery charger that optimizes the battery performance, ensuring longer lasting battery life. High voltage battery chargers and battery extension assembly are made available for longer runtime applications. The E-Series provides better output power factor of up to 0.9, offering high performance and efficiency for your critical applications.

The Master E Series (1P/1P) comes with 2 additional features; an internal bypass system and a parallel redundant system. An internal bypass system that allows continuous power is integrated for convenience when maintenance is necessary and a parallel redundant system that allows two UPS models to operate in parallel as backup for each other.

• True double-conversion

• DSP technology guarantees high performance

• Output power factor 0.9

• Wide input voltage range (110-300 VAC)

• Active input power factor correction 0.99

• 50Hz/60Hz frequency converter mode

• Eco mode operation for energy saving (ECO)

• Programmable power management outlets

Rear Panel

For 6kVA to 10kVA model

1. RS-232 communication port

2. USB communication port

3. Emergency power off function connector (EPO connector)

4. Share current port (only available for parallel model)

5. Parallel port (only available for parallel model)

6. Intelligent slot

7. Charger fan

8. Power stage fan

9. Maintenance bypass switch

10. Input circuit breaker

11. Input/Output terminal

12. Output terminal 1

13. Output terminal 2

14. External battery terminal (only available for Long-run model)

15. Utility input terminal

16. Output IEC Socket

• Emergency power off function (EPO)

• Generator compatible

• Charger capacity expansion to 8A for long-run models

• SNMP/USB/RS-232 communications

• 3-stage extendable charging design for optimized battery

performance

• Adjustable battery numbers

• Maintenance bypass available

1

16

2

8

8

9

3 4

7

12 13 15

PRO806ES/EL

PRO810ES/EL

5 5

6

14

10

11

12

Online UPS

Options

• AS-400 Card (External alarm indicator)

• SNMP Card for data communication via network connection

• Output Isolation Transformer

Full Specifications

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Voltage Range

Frequency Range

Power Factor

OUTPUT

Output Voltage

AC Voltage Regulation (Batt. Mode)

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer Time

AC Mode to Batt. Mode

Inverter to Bypass

Waveform (Batt. Mode)

EFFICIENCY

AC Mode

Battery Mode

BATTERY

Standard Model

Long-Run Model

Type

Numbers

Recharge Time (Typical)

Charging Current

Charging Voltage

Type

Numbers

Charging Current

Charging Voltage

INDICATORS

LCD Display

INDICATORS

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Standard Model

Long-Run Model

Dimension (mm) D x W × H

Net Weight (kgs)

Dimension (mm) D × W × H

Net Weight (kgs)

ENVIRONMENT

Operation Humidity

Noise Level

MANAGEMENT

Smart RS-232 / USB

Optional SNMP

PRO806ES/EL

6000 VA

Single phase with ground

PRO810ES/EL

10000 VA

208/220/230/240 VAC

110-300 VAC at 50% load

176-300 VAC at 100% load

46~54 Hz or 56~64 Hz

≧ 0.99 @ full load

200/ 208/ 220/ 230/ 240VAC

± 1 %

46~54 Hz or 56~64 Hz

50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz

3:1 (max)

≦ 3 % THD (Linear Load), ≦ 6 % THD (Non-linear Load)

Zero

Zero

Pure Sinewave

89%

88%

12 V / 7 Ah 12 V / 9 Ah

20

7 hours recover to 90% capacity 9 hours recover to 90% capacity

1 .0 A (max)

273 VDC ± 1%

Depending on the application

18-20

4.0 A (max)

273 VDC ± 1%

UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions

Sounding every 4 seconds

Sounding every second

Sounding twice every second

Continously sounding

592 x 250 x 576

592 x 250 x 576

81

25

83

27

20-90 % RH @ 0- 40°C (Non-condensing)

Less than 55dBA @ 1 Meter Less than 58dB @ 1 Meter

Supports Windows2 2000/2003/XP/Vista/2008, Windows2 7/8, Linux, Unix, and MAC

Power management from SNMP manager and web browser

A derate will occur during the Frequency converter mode (Capacity is reduced to 60%) and when the output voltage is adjusted to 208VAC (Capacity is reduced to 80%).

If the UPS is installed in a location where the altitude is above 1000m, the output power must be lowered by one percent for every 100m covered.

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

13

Master Series (1P/1P) - 2-in-1 Rack/ Tower

Online Master Series 1kVA – 10kVA

Small Computer

Network

Local Area

Network (LAN)

Work-Stations Servers 19” Rack

Mount

0.9

Output Power

Factor

Online UPS

Master Series (1P/1P) – 2-in-1 Rack/Tower is a single-phase UPS system that employs a true online double-conversion technology. This device comes with a practical 2U universal-mount case that provides an option for the user to either install it as a floor-standing tower or in a mounted position using a 19-inch rack mount bracket. With its high density output power factor of 0.9, this device is able to provide outstanding performance and efficiency to meet the requirements of a mission critical environment.

This 2-in-1 Rank/Tower UPS is brilliantly designed with a hot-swapping battery feature to facilitate the replacement of the existing batteries without the hassle of having to shut the devices down. On top of that, models with a 6kVA and 10kVA capacity comes with a parallel redundant system that allows two UPS models to operate in parallel and as backup for each other. High voltage battery chargers and battery extension assembly are made available for longer runtime applications. The PROLiNK 2-in-1 Rank/Tower UPS comes with a wide range of capacities from as low as 1kVA to as high as 10kVA to accommodate to your every need.

• True Double-Conversion Online UPS

• Output Power factor of 0.9

• User-friendly and easy-shift LCD display

• Rack/ Tower design

• Programmable power management outlets for 1-3K

• 50/60 Hz frequency converter mode

• ECO and advanced ECO mode for energy saving

• Emergency Power Off Function (EPO)

• Hot-swappable battery design for all model

• DSP technology applied for 6K and up models

• Active input power factor correction 0.99 for 6K and up models

• N+X parallel redundancy available for 6K and up models

14

Online UPS

Rear Panel

For 1kVA to 3kVA model

1. Programmable outlets: Connect to non-critical loads

2. Output receptacles: Connect to mission-critical loads

3. AC input

4. Input circuit breaker

5. Network/Fax/Modem surge protection

6. Emergency power off function connector (EPO)

7. USB communication port

8. RS-232 communication port

9. SNMP intelligent slot

10. External battery terminal (only available for Long-run model)

11. Output IEC320-C20 connector

12. Fan

For 6kVA to 10kVA model

1. Programmable outlets: Connect to non-critical loads

2. Output receptacles: Connect to mission-critical loads

3. AC input

4. Input circuit breaker

5. Network/Fax/Modem surge protection

6. Emergency power off function connector (EPO)

7. USB communication port

8. RS-232 communication port

9. SNMP intelligent slot

10. Battery connection

11. Input terminal

12. Fan

13. Parallel port (only available for parallel model)

14. External maintenance by-pass switch connection

15. Output Terminal

16. Ground

Battery Pack

For 1kVA to 3kVA model

Capacity

Battery Type

Battery Number (max)

Dimension (DxWxH) mm

Net Weight (kg)

1K

12 V / 9 Ah

4 pcs

380 x 438 x 88

17.3

1.5K

12 V / 9 Ah

6 pcs

480 x 438 x 88

2K

12 V / 9 Ah

8 pcs

24.8

29.8

For 6kVA to 10kVA model

Capacity

Battery Type

Battery Number (max)

Dimension (DxWxH) mm

6K

12 V / 7 Ah

20 pcs

580 x 438 x 133

10K

12 V / 9 Ah

20 pcs

Net Weight (kg)

57 63

14

9

13

3K

12 V / 9 Ah

12 pcs

600 x 438 x 88

42.5

5

5 12

6

10

7

8

9

1

2 4

3

PRO801RS/RL PRO8015RS/RL PRO802RS/RL

12 12

7

10

8

9

6

PRO803RS/RL

1

2

11

3

4

6

7

7

12

10

PRO806RS/RL

PRO810RS/RL

4

11 16 15

15

Online UPS

Options

• AS-400 Card (External alarm indicator)

• SNMP Card for data communication via network connection

• MODBUS Card (communication interface)

• Universal Rackmount Slider for installation in rack cabinets

• External PDU & Maintenance Bypass Switch (Only suitable for UPS that are up to 3kVA)

• Maintenance Bypass Switch [MBS] (Only available in UPS ranging from 6 to 10kVA)

• External Automatic Transfer Switch (ATS)

Full Specifications

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Voltage Range

Frequency Range

Power Factor

OUTPUT

Output Voltage

Voltage Regulation (Batt. Mode)

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion (Line Mode)

Transfer Time

Line Mode to Battery Mode

Inverter to Bypass

Waveform (Batt. Mode)

EFFICIENCY

AC Mode

Battery Mode

ECO Mode

BATTERY

Standard Model

Long-Run Model

Battery Type

Number

Recharge Time (Typical)

Charging Current (Max.)

Charging Voltage

Battery Type

Number

Recharge Time (Typical)

Charging Current (Max.)

Charging Voltage

INDICATORS

LCD Display

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Standard Model

Long-Run Model

Dimension (mm) D x W × H

Net Weight (kgs)

Dimension (mm) D × W × H

Net Weight (kgs)

ENVIRONMENT

Operation Humidity

Noise Level

MANAGEMENT

Smart RS-232 / USB

Optional SNMP

PRO801RS/ RL

1 000 VA

PRO8015RS/ RL PRO802RS/ RL

Single phase with ground

1500 VA 2000 VA

100*/110*/115*/120 /127 VAC or 200/208/220/230/240 VAC

55-150 VAC ± 5% or 110-300 VAC ± 5%

40Hz ~ 70Hz

≧ 0.99 @ Nominal Voltage (100% Load)

PRO803RS/ RL

3 000 VA

100*/110*/115*/120/127 VAC or 200/208/220/230/240 VAC

± 1 %

47 ~ 53 Hz or 57 ~ 63 Hz

50 Hz ± 0.5% or 60Hz ± 0.5%

5:1 (max.)

≦ 2 % THD (Linear Load) ; ≦ 4 % THD (Non-linear load)

Zero

4 ms

Pure Sinewave

88%

86%

95%

87%

85%

94%

89%

87%

97%

2

27.4 VDC ± 1%

12 V / 9 Ah

3 4

Back to 90% capacity in 4 hours

1.0A

41.1 VDC ± 1% 54.7 VDC ±1%

Depending on the capacity of external batteries

41.1 VDC ± 1%

1A / 2A / 4A / 8A

54.7 VDC ±1%

6

82.1 VDC ±1%

27.4 VDC ± 1% 82.1 VDC ±1%

Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicator

Sounding every 4 seconds

Sounding every second

Sounding twice every second

Continously sounding

380x438x88 (2U)

12.9

380x438x88 (2U)

8.6

17.6

10.7

480x438x88 (2U)

480x438x88 (2U)

20.6

11.3

20-90 % RH @ 0- 40°C (Non-condensing)

Less than 50dBA @ 1 Meter

Supports Windows

®

2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

Power management from SNMP manager and web browser

600x438x88 (2U)

28

600x43x88(2U)

13.8

L stands for Long-run model

S stands for Standard model

*All specifications, designs and contents are subject to change without prior notice.

16

Online UPS

Full Specifications

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Voltage Range

Frequency Range

Power Factor

OUTPUT

Nominal Voltage

AC Voltage Regulation

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer Time

Bypass to Inverter

Waveform (Batt. Mode)

EFFICIENCY

Line Mode

Battery Mode

ECO Mode

BATTERY

Line Mode to Battery Mode

Battery Mode to Line mode

Inverter to Bypass

Standard Model

Long-Run Model

Nominal Voltage

Battery Type

Numbers

Recharge Time (Typical)

Charging Current (max.)

Float Charging Voltage

Battery Type and Numbers

Charging Current (max.)

Float Charging Voltage

INDICATORS

LCD Display

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Dimension (mm) D x W × H

Standard Model

Net Weight (kgs)

Long-Run Model

ENVIRONMENT

Operation Humidity

Noise Level

MANAGEMENT

Smart RS-232 / USB

Optional SNMP

Dimension (mm) D x W × H

Net Weight (kgs)

PRO806RS/ RL

6 000 VA

Single phase with ground

PRO810RS/ RL

10000

200/208/220/230/240 VAC

110-300 VAC ± 3% at 50% load; 176-300 VAC ± 3% at 100% load

46~54 Hz or 56~64 Hz

≧ 0.99 @ 100% load

VA

200/208/220/230/240 VAC

± 1 %

≦ 2 % THD (Linear Load),

≦ 4 % THD (Non-linear Load)

46~54 Hz or 56~64 Hz

50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz

3:1 (Max.)

200/208/220/230/240 VAC

±1%

≦ 2 % THD (Linear Load),

≦ 4 % THD (Non-linear Load)

0 ms

4 ms

Pure Sinewave

90%

88%

96%

240 VDC

12 V / 7 Ah

20 (18-20 pcs adjustable)*

Back to 90% capacity in 7 hours

12 V / 9 Ah

20 (18-20 pcs adjustable)*

Back to 90% capacity in 9 hours

1.0 A

273 VDC (based on battery numbers at 20 pcs)

Depending on the application

4.0 A

273 VDC (based on battery numbers at 20 pcs)

Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicator

Sounding every 4 seconds

Sounding every second

Sounding twice every second

Continously sounding

90%

88%

96%

UPS Unit: 580 x 438 x 133 (3U)

Battery Pack: 580 x 438 x133 (3U)

UPS Unit: 20

Battery Pack: 57

580 x 438 x 133

20

UPS Unit: 668 x 438 x 133 (3U)

Battery Pack: 580 x 438 x133 (3U)

UPS Unit: 23.5

Battery Pack: 63

668 x 438 x 133

23.5

0-95 % RH @ 0- 40°C (Non-condensing)

Less than 58dBA @ 1 Meter Less than 60dBA @ 1 Meter

Supports Windows ® 2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

Power management from SNMP manager and web browser

L stands for Long-run model

S stands for Standard model

*All specifications, designs and contents are subject to change without prior notice.

17

Online UPS

True Double-conversion Online UPS

A true double conversion UPS system will provide clean and high quality electrical power to fully protect mission critical systems such as sensitive networks, small computer centers, servers, telecom applications and industrial applications.

Output Power Factor 0.9

Master (1P/1P) 2-in-1 rack/Tower Series is a high-density UPS system with an output power factor of

0.9. With this high power factor, the Master series is able to provide higher performance to critical applications.

User-friendly LCD Display

The front panel digital display comes with an auto-rotation feature that caters to your installation preference; either vertically or wall mounted.

Programmable Power Management Outlets

The programmable power management outlets allow users to easily and independently control the load segment. In the event of a power failure, this feature enables users to manage and extend the battery time for mission critical devices by shutting down the non-critical devices.

Programmable Outlets (P1)

- connect to non-critical

devices

Rack Display

Tower Display

Rack / Tower Design

This device comes with a practical 2U universal-mount case that provides an option for the user to either install it as a floor-standing tower or in a mounting position using a 19-inch rack mount bracket.

ECO and Advanced ECO Mode for Energy Saving

It allows the UPS to operate in high efficiency of up to

97% during energy saving ECO mode and 98% in operation mode. In the event of an electrical AC failure, the inverter will automatically step-in and provide electrical supply to the connected systems.

Emergency Power Off Function (EPO)

This feature provides adequate protection for the user and the equipment against hazards such as fire break-out or other emergencies.

19” Rack-mounting Floor-standing Tower

High Output Crest Ratio

The Master (1P/1P) 2-in-1 Rack/Tower Series is designed with a high output crest ratio of 5:1 that allows the device to be extremely compatible with equipment such as compressors, generators and motors.

Hot-swapping Battery Design

The hot-swapping battery feature helps to facilitate the replacement of the existing batteries without the hassle of having to shut the devices down.

Output Voltage Regulation (tolerance +/- 1%)

The Master (1P/1P) 2-in-1 rack / Tower Series is able to produce extremely stable and clean electrical power with its high efficiency output voltage regulator. This regulator is able to achieve a tolerance of +/- 1%, making it extremely compatible even with sensitive power supplies.

Long Battery Runtime Models Available

Our Long Battery Runtime Models offers the flexibility to add-on additional external batteries to provide a longer back-up time.

18

Online UPS

Master Series (3P/1P) - Tower

Online Master Series

10kVA – 30kVA

Local Area

Network

(LAN)

Telecommunication

Devices

Data

Centre

Electro-Medical

Device

Storage

PLCS

Emergency

Alarm

Devices

E-Business

(Server Farms,

ISP/ASP/POP)

Master Series (3P/1P) three-phase input / single-phase output, true online double conversion

UPS system guarantees consistent and quality electrical power to protect your mission critical applications such as mid-sized business servers, telecommunication systems and industrial equipment. The (3P/1P) UPS is designed with a wide input voltage range to handle voltage fluctuating situations and a high accuracy output voltage to fail-safe your equipment.

This Voltage Frequency Independent (VFI) system is available in capacities from 10kVA to

30kVA. By adopting the latest IGBT technology, this device is able offer excellent voltage switching characteristics during generator operation. An internal bypass system allowing continuous power is also integrated for convenience when maintenance is necessary. In addition, this device comes with a parallel redundant system that allows two UPS models to operate in parallel and as backup for each other. The Master series (3P/1P) UPS also offers the option of adding on an isolation transformer to suit your requirements.

• True double-conversion

• DSP technology guarantees high performance

• Output power factor 0.8

• Wide Input Voltage Range (305-478VAC for 3-Phase/

100-300VAC for 1-Phase)

• Supports Auto Phase Adaptation

• Active power factor correction in all phases

• Built-in phase auto adapt function simplifies wire installation

• 50Hz/60Hz frequency converter mode

• ECO mode operation for energy saving

Rear Panel

For 10kVA model

1. RS-232 communication port

2. USB communication port

3. Emergency power off function connector (EPO connector)

4. Share current port (only available for parallel model)

5. Parallel port (only available for parallel model)

6. Intelligent slot

7. Charger fan

8. Power stage fan

9. Maintenance by-pass switch

10. Input circuit breaker

11. Output circuit breaker for receptacles

12. Output receptacles: connect to mission-critical loads

13. Input/Output terminal

14. External battery connector (Only available for Long-run Model)

• Programmable power management outlets

• Emergency power off function (EPO)

• Generator compatible

• SNMP/USB+RS-232 multiple communications

(SNMP is optional)

• 3-stage extendable charging design for optimized

battery performance

• Adjustable battery numbers

• Maintenance bypass available

• Optional N+X parallel redundancy

• Optional isolation transformer available

1 2 3 4

11

12

8

8

9

13

7

5 5

6

14

PRO83110S/L

10

19

Online UPS

For 15kVA to 30kVA model

1. RS-232 communication port

2. USB communication port

3. Emergency power off function connector (EPO connector)

4. Share current port (only available for parallel model)

5. Parallel port (only available for parallel model)

6. Intelligent slot

7. Charger fan

8. Power stage fan

9. Maintenance by-pass switch

10. Input circuit breaker

11. Output circuit breaker for receptacles

12. Output receptacles: connect to mission-critical loads

13. Input/Output terminal

14. Output Terminal: Connect to mission-critical loads

15. Programmable Output terminal: Connect to non-critical loads

16. External battery terminal (only available for Long-run model)

17. Utility input terminal

18. Grounding terminal (only available for parallel system)

For 10K model For 15K & 30K model

1 2 3 4 5 5

6

8

7

1 2 3 4 5 5

6

8

7

8

9

7

10

11

8

9

7

10

11

18

PRO83115L

PRO83120L

PRO83115S

PRO83120S

PRO83130S/L

PRO83130L

18

14 15 17

14 15 16 17

Options

• AS-400 Card (External alarm indicator)

• SNMP Card for data communication via network connection

• MODBUS Card (Communication interface)

• Output Isolation Transformer (Available only for Long-run Model)

20

Online UPS

Full Specifications

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Voltage Range

Frequency Range

Power Factor

THDi

OUTPUT

Output Voltage

Voltage Regulation (Batt. Mode)

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer Time

AC Mode to Batt. Mode

Inverter to Bypass

Waveform (Batt. Mode)

EFFICIENCY

AC Mode

Battery Mode

BATTERY

Battery Type

Numbers

Standard Model

Long-Run Model

Recharge Time (Typical)

Charging Current (Max.)

Charging Voltage

Battery Type

Numbers

Charging Current (Max.)

Charging Voltage

INDICATORS

LCD Display

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Standard Model

Long-Run Model

ENVIRONMENT

Humidity

Noise Level

MANAGEMENT

Smart RS-232 / USB

Optional SNMP

Dimension (mm) D x W × H

Net Weight (kgs)

Dimension (mm) D × W × H

Net Weight (kgs)

PRO83110S/ L

10 kVA

86%

20 pcs

1 A

4 A

3 x 400VAC (3Ph+N)

305-478 VAC (3-phase) at 100% load ; 190-520 VAC (3-phase) at 50% load

(18 - 20 pcs adjustable)*

46~54Hz or 56~64Hz

≧ 0.99 @ 100% Load

< 6% @ 100% load

208/220/230/240VAC

±1%

46~54Hz or 56~64Hz

50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz

3:1

≦ 2 % THD (Linear Load)

≦ 5 % THD (Non-linear Load)

Zero

Zero

Pure Sinewave

12 V / 9 Ah

20 pcs (18 - 20 pcs adjustable)* x 2 strings

Back to 90% capacity in 9 hours

2 A

273 VDC ± 1% (Based on 20pcs batteries)

Depending on the application

Depending on the application

8 A

273 VDC ± 1% (Based on 20pcs batteries)

UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions

592 x 250 x 576

83

592 ×250 × 576

28

Less than 58dB @ 1 Meter

PRO83115S/ L

Supports Windows

15 kVA

89%

88%

®

PRO83120S/ L

3-phase in / 1-phase out

Sounding every 4 seconds

Sounding every second

87%

Sounding twice every second

Continously sounding

815 × 250 × 826

164

592 x 250 x 576

40

20 kVA

0-95 % RH @ 0- 40°C (Non-condensing)

Less than 60dB @1 Meter

Power management from SNMP manager and web browser

PRO83130S/ L

30kVA

90%

89%

20pcs(18-20pcs adjustable)*x3 strings

2 A

12 A

815 × 300 × 1000

2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

234

815 × 250 × 826

64

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

21

Online UPS

Master Series (3P/1P) - Tower

Online Master E Series

10kVA – 30kVA

0.9

Output Power

Factor

Local Area

Network

(LAN)

Telecommunication

Devices

Data

Centre

Electro-Medical

Device

Storage

PLCS

Emergency

Alarm

Devices

E-Business

(Server Farms,

ISP/ASP/POP)

Master E Series (3P/1P) three-phase input / single-phase output, true online double conversion

UPS system guarantees consistent and quality electrical power to protect your mission critical applications such as mid-sized business servers, telecommunication systems and industrial equipment. The (3P/1P) UPS is designed with a wide input voltage range to handle voltage fluctuating situations and a high accuracy output voltage to fail-safe your equipment. The

E-Series provides better output power factor of up to 0.9; offering high performance and efficiency for your critical applications.

By adopting the latest IGBT technology, this device is able offer excellent voltage switching characteristics during generator operation. In addition, this device comes with a parallel redundant system that allows two UPS models to operate in parallel and as backup for each other.

The Master series (3P/1P) UPS also offers the option of adding on an isolation transformer to suit your requirements.

• True double-conversion

• DSP technology guarantees high performance

• Output power factor 0.9

• Wide input voltage range (110-300 VAC)

• Active power factor correction in all phases

• Built-in phase auto adapt function simplifies wire installation

• 50Hz/60Hz frequency converter mode

• ECO mode operation for energy saving

• Programmable power management outlets

Rear Panel

For 10kVA model

1. RS-232 communication port

2. USB communication port

3. Emergency power off function connector (EPO connector)

4. Share current port (only available for parallel model)

5. Parallel port (only available for parallel model)

6. Intelligent slot

7. Charger fan

8. Power stage fan

9. Maintenance by-pass switch

10. Input circuit breaker

11. Output circuit breaker for receptacles

12. Output receptacles: connect to mission-critical loads

13. Input/Output terminal

14. External battery connector (Only available for Long-run Model)

• Emergency power off function (EPO)

• Generator compatible

• SNMP+USB+RS-232 multiple communications

• 3-stage extendable charging design for optimized

battery performance

• Adjustable battery numbers

• Maintenance bypass available

• Optional N+X parallel redundancy

• Optional isolation transformer available

1 2 3 4

11

12

8

8

9

13

7

5 5

6

14

10

PRO83110ES/EL

PRO83110ELI

22

Online UPS

For 15kVA to 30kVA model

1. RS-232 communication port

2. USB communication port

3. Emergency power off function connector (EPO connector)

4. Share current port (only available for parallel model)

5. Parallel port (only available for parallel model)

6. Intelligent slot

7. Charger fan

8. Power stage fan

9. Maintenance by-pass switch

10. Input circuit breaker

11. Output circuit breaker for receptacles

12. Output receptacles: connect to mission-critical loads

13. Input/Output terminal

14. Output Terminal: Connect to mission-critical loads

15. Programmable Output terminal: Connect to non-critical loads

16. External battery terminal (only available for Long-run model)

17. Utility input terminal

18. Grounding terminal (only available for parallel system)

For 10K model For 15K & 30K model

1 2 3 4 5 5

6

8

7

1 2 3 4 5 5

6

8

7

8

9

7

10

11

8

9

7

10

11

18

PRO83115ES/ EL PRO83120ES/ EL

PRO83120ELI

PRO83130ES/ EL

18

14 15 17

14 15 16 17

Options

• AS-400 Card (External alarm indicator)

• SNMP Card for data communication via network connection

• MODBUS Card (Communication interface)

• Output Isolation Transformer (Available only for PRO83110ELI & PRO83120ELI)

23

Online UPS

Full Specifications

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Voltage Range

Frequency Range

Power Factor

THDi

OUTPUT

PRO83110ES/ EL PRO83110ELI PRO83115ES/ EL

10kVA 10kVA

PRO83120ES/ EL PRO83120ELI PRO83130ES/ EL

3-phase in / 1-phase out

15kVA 20kVA 20kVA 30kVA

3 x 400VAC (3Ph+N)

190-520 VAC (3-phase) at 50% load ; 305-478 VAC (3-phase) at 100% load

46 ~ 54Hz or 56 ~ 64Hz

≧ 0.99 @ 100% load

< 6% @ 100% load

Output Voltage

208/220/230/

240VAC

104/110/115/

120VAC or 208/

220/230/240VAC

208/220/230/240VAC

104/110/115/

120VAC or 208/

220/230/240VAC

208/220/230/

240VAC

Voltage Regulation (Batt. Mode)

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

±1%

46~54Hz or 56~64Hz

50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz

3.1

Harmonic Distortion

≦ 2 % THD

(Linear Load)

≦ 5 % THD

(Non-linear Load)

≦ 2 % THD

(Linear Load)

≦ 6% THD

(Non-linear Load)

≦ 2 % THD (Linear Load)

5 % THD (Non-linear Load)

≦ 2 % THD

(Linear Load)

≦ 7% THD

(Non-linear Load)

≦ 2 % THD

(Linear Load)

≦ 5% THD

(Non-linear Load)

Transfer Time

AC Mode to Batt. Mode

Inverter to Bypass

Waveform (Batt. Mode)

EFFICIENCY

AC Mode

Battery Mode

BATTERY

Battery Type

91%

86%

85%

83% 88%

Zero

Zero

Pure Sinewave

91%

87%

87%

83%

91%

88%

Numbers

Standard Model

Recharge Time (Typical)

Long-Run Model

Charging Current (Max.)

Charging Voltage

Battery Type

Numbers

Charging Current (Max.)

Charging Voltage

INDICATORS

LCD Display

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Standard Model

Long-Run Model

ENVIRONMENT

Humidity

Noise Level

MANAGEMENT

Smart RS-232 / USB

Optional SNMP

Dimension (mm) D x W × H

Net Weight (kgs)

Dimension (mm) D × W × H

Net Weight (kgs)

20 pcs (18 - 20 pcs adjustable)*

1A

4A

12 V / 9 Ah

20 pcs (18 - 20 pcs adjustable)* x 2 strings

Back to 90% capacity in 9 hours

2A

273 VDC ± 1% (Based on 20pcs batteries)

Depending on the application

Depending on the application

8A

273 VDC ± 1% (Based on 20pcs batteries)

Not Applicable

20pcs(18-20pcs adjustable) x3 strings

Back to 90% capacity in 9 hours

2A

12A

UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions

592 x 250 x 576 592 x 250 x 826

83 144

592 ×250 × 576

28

592 x 250 x 826

91

Less than 58dB @ 1 Meter

Sounding every 4 seconds

Sounding twice every second

Sounding twice every second

Continously sounding

815 × 250 × 826

164

592 x 250 x 576

40

0 - 95% RH @ 0 - 40°C (Non-condensing)

Supports Windows

®

Not Applicable

Less than 60dB @ 1 Meter

815 × 300 × 1000

234

141

815 × 250 × 826

64

2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

Power management from SNMP manager and web browser

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

24

Master Series (3P/1P) - Rack Mount

Online Master Series 10kVA – 20kVA

Local Area

Network

(LAN)

Telecommunication

Devices

Data

Centre

19” Rack

Mount

Storage

PLCS

Emergency

Alarm

Devices

Online UPS

Master Series (3P/1P) – Rack three-phase input / single-phase output, true online double conversion UPS system guarantees consistent and quality electrical power to protect your mission critical applications such as mid-sized business servers, telecommunication systems and industrial equipments. This (3P/1P) UPS is designed with a wide input voltage range to handle voltage fluctuating situations and a high accuracy output voltage to fail-safe your equipment.

This Voltage Frequency Independent (VFI) system is available in capacities from 10kVA to 20kVA. By adopting the latest

IGBT technology, this device is able offer excellent voltage switching characteristics during generator operation. An internal bypass system allowing continuous power is also integrated for convenience when maintenance is necessary.

In addition, this device comes with a parallel redundant system that allows two UPS models to operate in parallel and as backup for each other. The Master series (3P/1P) – Rack UPS also offers the option of adding on an isolation transformer to suit your requirements.

• True double-conversion

• DSP technology guarantees high performance

• Output power factor 0.8

• Wide input voltage range (110-300 VAC)

• Active power factor correction in all phases

• Built-in phase auto adapt function simplifies wire

installation

• 50Hz/60Hz frequency converter mode

Rear Panel

For 10kVA to 20kVA model

1. RS-232 communication port

2. USB communication port

3. Emergency power off function connector (EPO connector)

4. Parallel port (only available for parallel model)

5. Intelligent slot

6. Fan

7. External maintenance by-pass switch connection

8. Input circuit breaker

9. Input/Output terminal

10. Output terminal

11. Battery terminal

12. Input terminal

• ECO mode operation for energy saving

• Emergency power off function (EPO)

• Generator compatible

• SNMP/USB+RS-232 multiple communications (SNMP is

optional)

• 3-stage extendable charging design for optimized battery

performance

• Adjustable battery numbers

• Optional N+X parallel redundancy

4 4 4

11

5 7

1

2

3

9 12 10

8

6 6

11

9

12

10

5

7

8

PRO83110RS/RL

6

6

6

6

PRO83115RS/ RL PRO83120RS/RL

1

2

3

4

4

4

25

Online UPS

Options

• AS-400 Card (External Alarm Indicator)

• SNMP Card for data communication via network connection

• MODBUS Card (Communication interface)

• Universal Rackmount Slider for installation in rack cabinets

• External Maintenance Bypass Switch (Only available with 10kVA model)

Full Specifications

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Voltage Range

Frequency Range

Power Factor

THDi

OUTPUT

Output Voltage

AC Voltage Regulation (Batt. Mode)

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer Time

AC Mode to Batt. Mode

Inverter to Bypass

Waveform (Batt. Mode)

EFFICIENCY

AC Mode

Battery Mode

BATTERY

Standard Model

Long-Run Model

Battery Type

Numbers

Recharge Time (Typical)

Charging Current (Max.)

Charging Voltage

Battery Type

Numbers

Charging Current (Max.)

Charging Voltage

INDICATORS

LCD Display

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Standard Model

Dimension (mm) D x W × H

Net Weight (kgs)

Long-Run Model

ENVIRONMENT

Operation Humidity

Noise Level

MANAGEMENT

Smart RS-232 / USB

Optional SNMP

Dimension (mm) D × W × H

Net Weight (kgs)

PRO83110RS/ RL

10kVA

190-520 VAC (3-phase) at 50% load ; 305-478 VAC (3-phase) at 100% load

86%

20 (18 - 20 adjustable)

1A

PRO83115RS/ RL

3-phase in / 1-phase out

15kVA

3 x 400 VAC (3Ph+N)

46~54 Hz or 56~64Hz

≧ 0.99 @ 100% Load

< 6% @ 100% Load

208/220/230/240VAC

±1%

46~54Hz or 56~64Hz

50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz

3:1

≦ 2 % THD (Linear Load) ; ≦ 5 % THD (Non-linear Load)

12 V / 9 Ah

20 pcs x 2 strings (18 - 20 adjustable)

Back to 90% capacity in 9 hours

2A

273 VDC ± 1% (based on battery numbers at 20 pcs)

Depending on the capacity of external batteries

4A

273 VDC ± 1% (based on battery numbers at 20 pcs)

Less than 60dB @ 1 Meter

Zero

Zero

Pure Sinewave

89%

88%

Sounding every 4 seconds

Sounding every second

Sounding twice every second

Continously sounding

UPS Unit: 668 x 438 x 266 (6U)

BatteryPack: 580 x 438 x 133 (3U) x 2PCS

UPS unit: 45

Battery pack: 63 x 2PCS

668 x 438 x 266 (6U)

45

0-95 % RH @ 0- 40°C (Non-condensing)

Supports Windows ®

Less than 65dB @ 1 Meter

2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

Power management from SNMP manager and web browser

PRO83120RS/ RL

20kVA

87%

UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions

UPS Unit: 668 x 438 x 133 (3U)

Battery Pack: 580 x 438 x 133 (3U)

UPS unit: 22

Battery pack: 63

668 x 438 x 133 (3U)

22

L stands for Long-run model

S stands for Standard model

*All specifications, designs and contents are subject to change without prior notice.

26

Online UPS

Master Series (3P/3P) - Tower

Online Master Series

10kVA – 30kVA

Local Area

Network

(LAN)

Telecommunication

Devices

Data

Centre

Electro-Medical

Device

Storage

PLCS

Emergency

Alarm

Devices

E-Business

(Server Farms,

ISP/ASP/POP)

Master Series (3P/3P) – Tower three-phase input / three-phase output, true online double conversion UPS system guarantees consistent and quality electrical power to protect your mission critical applications such as small server room, medical devices, telecommunication facilities and industrial processes. This (3P/3P) UPS is designed with a wide input voltage range to handle voltage fluctuating situations and a high accuracy output voltage to fail-safe your equipment.

The Master Series (3P/3P) UPS system is available in capacities from 10kVA to 30kVA.

By adopting the latest IGBT technology, this device is able offer excellent voltage-switching characteristics during generator operation. An internal bypass system allowing continuous power is also integrated for convenience when maintenance is necessary. In addition, this device comes with a parallel redundant system that allows two UPS models to operate in parallel and as backup for each other. The Tower series UPS also offers the option of adding on an isolation transformer to suit your requirements.

• True double-conversion

• DSP technology guarantees high performance

• Output power factor 0.8

• Active power factor correction in all phases

• 50Hz/60Hz frequency converter mode

• ECO mode operation for energy saving

• Accepts dual-mains inputs (only available for dual input

unit)

• Emergency power off function (EPO)

• Generator compatible

• SNMP/USB+RS-232 multiple communications (SNMP

is optional)

• 3-stage extendable charging design for optimized

battery performance

• Adjustable battery numbers

• Maintenance bypass available

• Optional N+X parallel redundancy

• Optional isolation transformer offers full isolation and

complete common mode noise rejection

1 2 3 4

8

7

5

6

Rear Panel

For 10kVA to 30kVA model

1. RS-232 communication port

2. USB communication port

3. Emergency power off function connector (EPO connector)

4. Share current port (only available for parallel model)

5. Parallel port (only available for parallel model)

6. Intelligent slot

7. Charger fan

8. Power stage fan

9. Maintenance bypass switch

10. Bypass Input Circuit Breaker (Only available for dual input unit)

11. Input circuit breaker

12. Input/Output terminal

13. External battery terminal (only available for Long-run model)

9

8

11 10 13

12

7

PRO83310S/L

PRO83320S/L

PRO83330S/L

27

Online UPS

Options

• AS-400 Card (External Alarm Indicator)

• SNMP Card for data communication via network connection

• MODBUS Card (Communication interface)

• Output Isolation Transformer

Full Specifications

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Input Voltage Range

Frequency Range

Power Factor

OUTPUT

Output Voltage

AC Voltage Regulation (Batt. Mode)

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer Time

AC Mode to Batt. Mode

Inverter to Bypass

Waveform (Batt. Mode)

EFFICIENCY

AC Mode

Battery Mode

BATTERY

Battery Type

Numbers

Standard Model

Long-Run Model

Recharge Time (Typical)

Charging Current (Max.)

Charging Voltage

Battery Type

Numbers

Charging Current (Max.)

Charging Voltage

INDICATORS

LCD Display

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Standard Model

Long-Run Model

ENVIRONMENT

Humidity

Noise Level

MANAGEMENT

Smart RS-232 / USB

Optional SNMP

Dimension (mm) D x W × H

Net Weight (kgs)

Dimension (mm) D × W × H

Net Weight (kgs)

PRO83310S/ L

10kVA

86%

20 pcs

190-520 VAC (3-phase) at 50% load ; 305-478 VAC (3-phase) at 100% load

(18 - 20 adjustable)*

1A

109

38

Less than 60dB @ 1 Meter

PRO83315S/ L

≦ 2 % THD (Linear Load) ; ≦ 5 % THD (Non-linear Load)

Supports Windows

15kVA

®

50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz

89%

88%

3-phase in / 3-phase out

3 x 400 VAC (3Ph+N)

46~54 Hz or 56~64Hz

≧ 0.99 @ 100% Load

3 x 400 VAC (3Ph+N)

± 1%

46~54Hz or 56~64Hz

3:1 (Max.)

Zero

Zero

Pure Sinewave

12 V / 9 Ah

20 pcs x 2 strings (18 - 20 adjustable)*

Back to 90% capacity in 9 hours

2A

273 VDC ± 1%

Depending on the capacity of external batteries

4A

273 VDC ± 1%

UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault

Sounding every 4 seconds

Sounding every second

Sounding twice every second

Continously sounding

815 x 250 x 826

592 x 250 x 826

164

40

PRO83320S/ L

20kVA

87%

0-95 % RH @ 0- 40°C (Non-condensing)

Less than 65dB @ 1 Meter

Power management from SNMP manager and web browser

PRO83330S/ L

30kVA

90%

89%

20pcs x 3 strings

(18-20 adjustable)*

4A

12A

815 x 300 x 1000

2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

233.5

815 x 250 x 826

64

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

28

Online UPS

Master Series (3P/3P) - Tower

Online Master E Series

10kVA – 30kVA

0.9

Output Power

Factor

Local Area

Network

(LAN)

Telecommunication

Devices

Data

Centre

Electro-Medical

Device

Storage

PLCS

Emergency

Alarm

Devices

E-Business

(Server Farms,

ISP/ASP/POP)

Master E Series (3P/3P) – Tower three-phase input / three-phase output, true online double conversion UPS system guarantees consistent and quality electrical power to protect your mission critical applications such as small server room, medical devices, telecommunication facilities and industrial processes. This (3P/3P) UPS is designed with a wide input voltage range to handle voltage fluctuating situations and a high accuracy output voltage to fail-safe your equipment.

The Master E Series (3P/3P) UPS system is available in capacities from 10kVA to 30kVA.

By adopting the latest IGBT technology, this device is able offer excellent voltage-switching characteristics during generator operation. An internal bypass system allowing continuous power is also integrated for convenience when maintenance is necessary. In addition, this device comes with a parallel redundant system that allows two UPS models to operate in parallel and as backup for each other. The Tower series

UPS also offers the option of adding on an isolation transformer to suit your requirements.

• True double-conversion

• DSP technology guarantees high performance

• Output power factor 0.9

• Active power factor correction in all phases

• 50Hz/60Hz frequency converter mode

• ECO mode operation for energy saving (ECO)

• Accepts dual-mains inputs

• Emergency power off function (EPO)

• Generator compatible

• SNMP+USB+RS-232 multiple communications

• 3-stage extendable charging design for optimized

battery performance

• Adjustable battery numbers

• Maintenance bypass available

• Optional N+X parallel redundancy

Rear Panel

For 10kVA to 30kVA model

1. RS-232 communication port

2. USB communication port

3. Emergency power off function connector (EPO connector)

4. Share current port (only available for parallel model)

5. Parallel port (only available for parallel model)

6. Intelligent slot

7. Charger fan

8. Power stage fan

9. Maintenance bypass switch

10. Bypass Input Circuit Breaker (Only available for dual input unit)

11. Input circuit breaker

12. Input/Output terminal

13. External battery terminal (only available for Long-run model)

1 2 3 4

8

7

5

6

9

8

7

11 10 13

12

PRO83310ES/EL

PRO83320ES/EL

PRO83330ES/EL

29

Online UPS

Options

• AS-400 Card (External Alarm Indicator)

• SNMP Card for data communication via network connection

• MODBUS Card (Communication interface)

• Output Isolation Transformer

Full Specifications

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Input Voltage Range

Frequency Range

Power Factor

OUTPUT

Output Voltage

AC Voltage Regulation (Batt. Mode)

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer Time

AC Mode to Batt. Mode

Inverter to Bypass

Waveform (Batt. Mode)

EFFICIENCY

AC Mode

Battery Mode

BATTERY

Battery Type

Numbers

Standard Model

Long-Run Model

Recharge Time (Typical)

Charging Current (Max.)

Charging Voltage

Battery Type

Numbers

Charging Current (Max.)

Charging Voltage

INDICATORS

LCD Display

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Standard Model

Long-Run Model

ENVIRONMENT

Humidity

Noise Level

MANAGEMENT

Smart RS-232 / USB

Optional SNMP

Dimension (mm) D x W × H

Net Weight (kgs)

Dimension (mm) D × W × H

Net Weight (kgs)

PRO83310ES/ EL

10kVA

86%

20 pcs

190-520 VAC (3-phase) at 50% load ; 305-478 VAC (3-phase) at 100% load

(18 - 20 adjustable)*

1A

109

38

Less than 60dB @ 1 Meter

PRO83315ES/ EL

≦ 2 % THD (Linear Load) ; ≦ 5 % THD (Non-linear Load)

Supports Windows

15kVA

®

50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz

89%

88%

3-phase in / 3-phase out

3 x 400 VAC (3Ph+N)

46~54 Hz or 56~64Hz

≧ 0.99 @ 100% Load

3 x 400 VAC (3Ph+N)

± 1%

46~54Hz or 56~64Hz

3:1 (Max.)

Zero

Zero

Pure Sinewave

12 V / 9 Ah

20 pcs x 2 strings (18 - 20 adjustable)*

Back to 90% capacity in 9 hours

2A

273 VDC ± 1%

Depending on the capacity of external batteries

4A

273 VDC ± 1%

UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault

Sounding every 4 seconds

Sounding every second

Sounding twice every second

Continously sounding

815 x 250 x 826

592 x 250 x 826

164

40

PRO83320ES/ EL

20kVA

87%

0-95 % RH @ 0- 40°C (Non-condensing)

Less than 65dB @ 1 Meter

Power management from SNMP manager and web browser

PRO83330ES/ EL

30kVA

90%

89%

20pcs x 3 strings

(18-20 adjustable)*

4A

12A

815 x 300 x 1000

2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

233.5

815 x 250 x 826

64

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

30

Online UPS

Power Series

Online Power Series

15kVA – 120kVA

Local Area

Network

(LAN)

Telecommunication

Devices

Data

Centre

Electro-Medical

Device

Storage

PLCS

Emergency

Alarm

Devices

E-Business

(Server Farms,

ISP/ASP/POP)

Power Series (3P/3P) three-phase input / three-phase output, true online double conversion UPS system guarantees to supply consistent and quality electrical power to protect your mission critical applications such as data centres, medical equipments and call centres. Harmful effects of harmonic injection are eliminated with the employment of Adaptive Feed Forward Cancellation (AFC) technology. With a UPS system that reflects low harmonic distortion and high input power factor, it is able to lower installation costs by utilizing smaller cables and miniature circuit breakers (MCB).

Our team of specialists has gathered together to revolutionize the UPS usability by adding in a 5.7” LCD monitor display with all information and alarm notifications viewable within a single display. To ensure our products are user centered, our group of specialist has also adopted a front access concept to create a UPS system that is easy for users to carry out preventative maintenance and replacement activities. In addition, this device comes with a parallel redundant system that allows four UPS models to operate in parallel. An option of an additional isolation transformer is also available to suit your requirements. The Power series is available in models ranging from 15kVA to

120kVA.

• Online double conversion technology with DSP control

• Advanced control with Adaptive Feed Forward Cancellation

(AFC) technology for very low harmonic distortion

• Very low input current distortion (THDi < 1%)

• Input power factor 0.99 at 10% load

• Output efficiency up to 95%

• Space-saving compact design

• Front access makes maintenance and replacement easily

• Highly flexibility in single phase/three-phase set-ups

• Control designed to withstand all kinds of loads

• Parallel redundant operation with up to 4 units

• Variety of communication options available

• Over 60% mateirals recyclable

• Remaining backup time calculation

• 5.7" graphic LCD panel design with multiple

languates for easy-configuration

• Optional touch panel design for 5.7" LCD

Rear Panel (Internal)

For 15kVA to 80kVA model

1. Relay interface

2. Emergency Power Off (EPO)

3. RS-232 COM ports

4. Intelligent Slow

5. Input circuit breaker

6. Maintenance bypass switch

7. Output switch

8. Battery switch

9. System Terminal

10. Parallel port (only available for parallel model)

1

3

10

2

4

5 6 7 8

9

PRO73315S/SI

PRO73320S/SI

1

3

10

2

4

5 6

9

7

PRO73330S/SI

PRO73340S/SI

8

1

3

10

2

4

5 6 7

9

8

PRO73360S/SI

PRO73380S/SI

31

Online UPS

For 100kVA to 120kVA model

1. Relay interface

2. Emergency Power Off (EPO)

3. RS-232 COM ports

4. Intelligent Slow

5. Input circuit breaker

6. Maintenance bypass switch

7. Output switch

8. Battery switch

9. System Terminal

10. Parallel port (only available for parallel model)

1

3

10

2

4

5 6 7 8

9

PRO733100S

PRO733120S

Full Specifications

MODELS

Capacity

INPUT

Nominal Voltage

Acceptable Voltage Range

Frequency

Total Harmonic Distortion (THDi)

PRO73315S/ SI

15kVA

PRO73320S/ SI

20kVA

< 1.5% @ 100% load

< 2.5% @ 50% load

< 6.0% @ 10% load

PRO73330S/ SI

30kVA

PRO73340S/ SI

40kVA

PRO73360S/ SI

60kVA

3 x 400V (3Ph + N)

+15% or –20%

50/60 Hz ± 5 %

< 1.0% @ 100% load

< 2.0% @ 50% load

< 5.0% @ 10% load

High overload: PFC Limit (discharging batteries)

1.0

PRO73380S/ SI

80kVA

Current Limitation

Power Factor

INVERTER

Nominal Voltage

Precision

Frequency

Max. Synchronisation Speed

Waveform

Total Harmonic Distortion (THDv)

Phase Displacement

Dynamic Recovery Time

Admissible Overload

Admissible Crest Factor

Admissible Power Factor

Imbalance Output Voltage @ 100% Unbalanced Load

Current Limit

STATIC BYPASS

Type

Voltage

Frequency

Activation Criterion

Transfer Time

Admissible Overload

Transfer to Bypass

Retransfer

MAINTENANCE BYPASS

Type

Voltage

Frequency

Overall Efficiency (Line mode)

BATTERY

Built-in Battery Type (2x31)

Back-up Time (minutes)

Max. Charging Current

PHYSICAL

Dimensions, D x W x H(mm)

Net Weight (W/O batteries) (Kg)

Net Weight (w/built-in batteries) (Kg)

3.4 : 1

3 x 400V (3Ph + N)

Stationary: ±1% ; Transitory: ±2% (load variations 100-0-100%)

50/60 Hz synchronised ±4 % With mains absent ±0.05%

±10 Hz/s

Pure Sinewave

<0.5% (Linear Load) ; <1.5% (Non-linear Load)

120º ±1% (balanced load) ; 120º ±2% (imbalances 50% of the load)

10 ms. at 98 % of the static value

125% for 10 min., 150% for 60 s

3.2 :1

0.7 inductive to 0.7 capacitive

Solid state

3x400V (3Ph + N)

50/60 Hz

Microprocessor control

Zero

400% for 10 sec.

Immediate, for overloads above 150%

Automatic after alarm clear

Without interruption

3 x 400V (3Ph + N)

92%

50/60 Hz

92.5%

2.8 : 1

<1%

High overload, short-circuit: RMS Voltage Limit ; High Crest-Factor current: Peak Voltage Limit

90.5%

12V 4.5Ah

10

91%

12V 9Ah

9

23.5 A

700 x 450 x 1100

110

280 300

12V 12Ah

8

180

12V 18Ah

7

47 A

93%

Not Applicable

94%

70.5 A

565

805 x 590 x 1320

210

Not Applicable

230

430

If the UPS is installed in a location where the altitude is above 1000m, the output power must be lowered by one percent for every 100m covered.

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

32

Online UPS

MODELS

Capacity

INPUT

Nominal Voltage

Acceptable Voltage Range

Frequency

Total Harmonic Distortion (THDi)

Current Limitation

Power Factor

INVERTER

Nominal Voltage

Precision

Frequency

Max. Synchronisation Speed

Waveform

Total Harmonic Distortion (THDv)

Phase Displacement

Dynamic Recovery Time

Admissible Overload

Admissible Crest Factor

Admissible Power Factor

Imbalance Output Voltage @ 100% Unbalanced Load

Current Limit

STATIC BYPASS

Type

Voltage

Frequency

Activation Criterion

Transfer Time

Admissible Overload

Transfer to Bypass

Retransfer

MAINTENANCE BYPASS

Type

Voltage

Frequency

Overall Efficiency (Line mode)

BATTERY

Max. Charging Current

PHYSICAL

Dimensions, D x W x H(mm)

Net Weight (W/O batteries) (Kg)

Net Weight (w/built-in batteries) (Kg)

PRO733100S

100kVA

3 x 400V (3Ph + N)

+15% or –20%

50/60 Hz ± 5 %

< 1.0% @ 100% load

< 2.0% @ 50% load

< 5.0% @ 10% load

High overload: PFC Limit (discharging batteries)

1.0

PRO733120S

120kVA

3 x 400V (3Ph + N)

Stationary: ±1% ; Transitory: ±2% (load variations 100-0-100%)

50/60 Hz synchronised ±4 % With mains absent ±0.05%

±10 Hz/s

Pure Sinewave

<0.5% (Linear Load) ; <1.5% (Non-linear Load)

120º ±1% (balanced load) ; 120º ±2% (imbalances 50% of the load)

10 ms. at 98 % of the static value

125% for 10 min., 150% for 60 s

3.2 :1

0.7 inductive to 0.7 capacitive

<1%

High overload, short-circuit: RMS Voltage Limit ; High Crest-Factor current: Peak Voltage Limit

Solid state

3x400V (3Ph + N)

50/60 Hz

Microprocessor control

Zero

400% for 10 sec.

Immediate, for overloads above 150%

Automatic after alarm clear

Without interruption

3 x 400V (3Ph + N)

50/60 Hz

93% 93.3%

188 A

805 x 590 x 1320

255

Not Applicable

Options

• SNMP Card for data communication via network connection

• MODBUS Card (Communication interface)

• Output Isolation Transformer

If the UPS is installed in a location where the altitude is above 1000m, the output power must be lowered by one percent for every 100m covered.

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

33

Online UPS

The Most Versatile Solution For Power

Protection

The Power Series is designed with the new state of art transformerless PWM technology that can be easily adapted to any kinds of complicated loads such as the non-linear systems (IT systems), highly inductive/ capacitive loads, high-density discharge lamps and induction motors. The Power series is designed with 2 important criterions in mind; maximum efficiency and energy conservation. The unit also comes with a small form factor to allow for minimum installation effort.

Furthermore, a parallel redundant system is integrated to allow two UPS models to operate in parallel as backup for each other. The Power Series is available in capacities ranging from 15 to 120kVA.

Input Power Factor 0.99 At 10% Load

Lower power losses would result in reduced consumption, lower operation and maintenance costs.

INPUT POWER FACTOR

1,20

1,00

0,80

0,60

0,40

0,20

0,00

0% 25% 50%

LOAD

Online Double Conversion Technology with

DSP Control

The Power Series is able provide a higher load up-time and effective insulation against network disturbance with its online double conversion technology. A Digital

Signal Processor (DSP) controller improves the performance and efficiency of the UPS.

Advanced Control with Adaptive Feed Forward

Cancellation (AFC) Technology

By cancelling both the input current and the output voltage harmonics, the harmful effects of harmonic injection can be eliminated and this enhances the load integrity.

Output Efficiency of up to 95%

Designed with a DSP controller and fourth generation

IGBT transistors, the UPS is able to achieve extremely high efficiency of up to 95%. With such high ratings, components in the UPS are not only protected but also prolonged due to the decrease in heat losses.

SERIES TIPICAL EFFICIENCY

100%

75%

50%

25%

0%

0%

25% 50%

LOAD

Low Input Current Distortion (THDi < 1%)

AFC cells are used to achieve extremely low distortion values. The Power series is able to obtain a low input current distortion at THDi < 1% under full load and a THDi

< 5% under smaller load (i.e. 10% of load). This will prevent distortion of electrical network upstream and thus, result in the reduction of cable usage and protective devices in the electrical network.

Small Form Factor

Utilizes a transformerless technology allows the design of the UPS to be lighter and smaller.

34

Online UPS

An important consideration has been given during the UPS design phase to create a system that allows users to access the unit’s electronic cards and power components with minimum effort. All electronic boards and components can be accessed from the front panel for easy maintenance and replacement activities.

Variety Of Communications And Option

Available

The UPS has provided the following standard communication selections:

• Relay interface

• RS-232/485 port

• 1 × SNMP slot

• Modbus RTU / SEC protocol

• 2 × connectors for parallel connection

Made of 60% Recyclable

Materials

When it comes to conserving the environment, PROLiNK is committed to play a part by designing their UPS products using recyclable materials.

Versatile Single-Phase / Three-Phase set-ups

This highly versatile UPS is designed with different types of setting-up options;

• Three-phase input / Three-phase output (III/III)

• Three-phase input / Single phase output (III/I)

Control Components are designed to with stand all kinds of loads

In the Power Series, the control components are designed to withstand all types of loads. These include loads such as; resistive, capacitive, non-linear, high-density discharge lamps, induction motors, speed drives etc. This makes the UPS extremely compatible with many types of electronics. Better yet, the UPS comes with a wide array of parameters that can be programmed locally or remotely to fit different types of environment.

Back-up Time indicator

With the use of simple algorithms, an estimated remaining back-up time can be calculated and indications will be reflected on a LCD panel.

5.7” Multiple Languages Graphical LCD

Display

Our team of specialists has gathered together to revolutionize the UPS usability by adding in a 5.7” LCD monitor display with all information and alarm notifications viewable within a single display.

N+1 Redundancy

A parallel redundant system allows 4 UPS models to operate in parallel and as backup for each other.

35

Online UPS

Power Series

Online Power E Series

10kVA – 120kVA

Local Area

Network

(LAN)

Telecommunication

Devices

Data

Centre

Electro-Medical

Device

Storage

PLCS

Emergency

Alarm

Devices

E-Business

(Server Farms,

ISP/ASP/POP)

PROLiNK UPS Power E Series (3P/3P) three-phase input / three-phase output, true online double conversion UPS system guarantees to supply consistent and quality electrical power to protect your mission critical applications such as data centres, medical equipments and call centres. Power E Series give excellent output leading power factor up to 0.9 leading for 100% load. Harmful effects of harmonic injection are eliminated with the employment of Adaptive

Feed Forward Cancellation (AFC) technology. With a UPS system that reflects low harmonic distortion and high input power factor, it is able to lower installation costs by utilizing smaller cables and miniature circuit breakers (MCB).

Our team of specialists has gathered together to revolutionize the UPS usability by adding in a

5.7” LCD monitor display with all information and alarm notifications viewable within a single display. To ensure our products are user centered, our group of specialist has also adopted a front access concept to create a UPS system that is easy for users to carry out preventative maintenance and replacement activities. In addition, this device comes with a parallel redundant system that allows four UPS models to operate in parallel. An option of an additional isolation transformer is also available to suit your requirements. The Power series is available in models ranging from 10kVA to 120kVA.

• Online double conversion technology with DSP control

• Output power factor 0.9

• Advanced control with Adaptive Feed Forward

Cancellation (AFC) technology for very low

• Very low input current distortion (THDi < 1%)

• Input power factor 0.99 at 10% load

• Output efficiency up to 95%

• Space-saving compact design

• Over 60% materials recyclable

• Remaining backup time calculation

• Remaining backup time calculation

• Front access makes maintenance and replacement

easily

• Highly flexibility in single phase/ three-phase set-ups

• Parallel redundant operation with up to 4 units

• Variety of communications and options available

• Flexible battery type configuration by request

(only available for Taurus Pro 400V models)

• Long-run models available for 400V 10KVA-40KVA

and 208V 7.5KVA-20KVA

Rear Panel (Internal)

For 10kVA to 80kVA model

1. Relay interface

2. Emergency Power Off (EPO)

3. RS-232 COM ports

4. Intelligent Slow

5. Input circuit breaker

6. Maintenance bypass switch

7. Output switch

8. Battery switch

9. System Terminal

10. Parallel port (only available for parallel model)

1

3

10

2

4

5 6 7 8

9

PRO73310ES

PRO73315ES

PRO73320ES

1

3

10

2

4

5 6

9

7

PRO73330ES

PRO73340ES

8

1

3

10

2

4

5 6 7

9

PRO73360ES

PRO73380ES

8

36

Online UPS

For 100kVA to 120kVA model

1. Relay interface

2. Emergency Power Off (EPO)

3. RS-232 COM ports

4. Intelligent Slow

5. Input circuit breaker

6. Maintenance bypass switch

7. Output switch

8. Battery switch

9. System Terminal

10. Parallel port (only available for parallel model)

1

3

10

2

4

5 6

9

7 8

PRO733100ES

PRO733120ES

Full Specifications

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Acceptable Voltage Range

Frequency

Current Limitation

Power Factor

Total Harmonic Distortion (THDi)

PRO73310ES

10kVA

PRO73315ES

15kVA

PRO73320ES PRO73330ES PRO73340ES

3-phase in / 3-phase out

20kVA 30kVA 40kVA

PRO73360ES

60kVA

< 1.5% @ 100% load;

< 2.5% @ 50% load;

< 6.0% @ 10% load

3 x 400V (3Ph + N)

+15% or –20%

50 / 60 Hz ±5 %

High overload: PFC Limit (discharging batteries)

1.0

< 1.0% @ 100% load;

< 2.0% @ 50% load;

< 5.0% @ 10% load

PRO73380ES

80kVA

INVERTER

Nominal Voltage

Precision

Frequency

Max. Synchronisation Speed

Waveform

Total Harmonic Distortion (THDv)

Phase Displacement

Dynamic Recovery Time

Admissible Overload

Admissible Crest Factor

Admissible Power Factor

Imbalance Output Voltage

@ 100%Unbalanced Load

Current Limit

STATIC BYPASS

Type

Voltage

Frequency

Activation Criterion

Transfer Time

Admissible Overload

Transfer to Bypass

Retransfer

MAINTENANCE BYPASS

Type

Voltage

Frequency

Overall Efficiency (Line mode)

BATTERY

Built-in Battery Type (2x31)

Back-up Time (minutes)

Max. Charging Current

PHYSICAL

Dimension (mm) D x W x H

Net Weight (without batteries) (kgs)

Net Weight (w/built-in batteries) (kgs)

90%

±10 Hz/s

Pure Sinewave

< 0.5% (Linear Load) ; < 1.5% (Non-linear Load)

120º ±1% (balanced load) ; 120º ±2% (imbalances 50% of the load)

10 ms. at 98 % of the static value

Phase Overload: 125% for 10 min., 150% for 60s ; Total Overload: 112.5% for 10 min., 135% for 60s

3.4 : 1 3.2 :1

0.7 inductive to 0.7 capacitive

12V 4.5Ah

5

78

178

High overload, short-circuit: RMS Voltage Limit ; High Crest-Factor current: Peak Voltage Limit

90.5%

12V 4.5Ah

3

86

186

3 x 400V (3Ph + N)

Stationary: ±1% ; Transitory: ±2% (load variations 100-0-100%)

50/60 Hz synchronised ±4 % With mains absent ±0.05%

23.5 A

Immediate, for overloads above 150%

91%

12V 7Ah

5

94

249

<1%

Solid state

3x400V (3Ph + N)

50/60 Hz

Microprocessor control

Zero

400% for 10 sec.

Automatic after alarm clear

Without interruption

770 x 450 x 1100

3 x 400V (3Ph + N)

50/60 Hz

92%

12V 9Ah

3

110

290

92.5%

12V 12Ah

3

122

357

If the UPS is installed in a location where the altitude is above 1000m, the output power must be lowered by one percent for every 100m covered.

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

47 A

93%

162

2.8 : 1

Not Applicable

Not Applicable

94%

70.5 A

805 x 590 x 1320

231

37

Online UPS

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Acceptable Voltage Range

Frequency

Current Limitation

Power Factor

Total Harmonic Distortion (THDi)

INVERTER

Nominal Voltage

Precision

Frequency

Max. Synchronisation Speed

Waveform

Total Harmonic Distortion (THDv)

Phase Displacement

Dynamic Recovery Time

Admissible Overload

Admissible Crest Factor

Admissible Power Factor

Imbalance Output Voltage

@ 100%Unbalanced Load

Current Limit

STATIC BYPASS

Type

Voltage

Frequency

Activation Criterion

Transfer Time

Admissible Overload

Transfer to Bypass

Retransfer

MAINTENANCE BYPASS

Type

Voltage

Frequency

Overall Efficiency (Line mode)

BATTERY

Max. Charging Current

PHYSICAL

Dimension (mm) D x W x H

Net Weight (without batteries) (kgs)

Net Weight (w/built-in batteries) (kgs)

Options

• SNMP Card for data communication via network connection

• MODBUS Card (Communication interface)

• Output Isolation Transformer

PRO733100ES

100kVA

3-phase in / 3-phase out

3 x 400V (3Ph + N)

+15% or –20%

50 / 60 Hz ±5 %

High overload: PFC Limit (discharging batteries)

1.0

< 1.5% @ 100% load;

< 2.0% @ 50% load;

< 6.0% @ 10% load

PRO733120ES

120kVA

3 x 400V (3Ph + N)

Stationary: ±1% ; Transitory: ±2% (load variations 100-0-100%)

50/60 Hz synchronised ±4 % With mains absent ±0.05%

±10 Hz/s

Pure Sinewave

< 0.5% (Linear Load) ; < 1.5% (Non-linear Load)

120º ±1% (balanced load) ; 120º ±2% (imbalances 50% of the load)

10 ms. at 98 % of the static value

Phase Overload: 125% for 10 min., 150% for 60s ; Total Overload: 112.5% for 10 min., 135% for 60s

3.2 :1

0.7 inductive to 0.7 capacitive

<1%

High overload, short-circuit: RMS Voltage Limit ; High Crest-Factor current: Peak Voltage Limit

Solid state

3x400V (3Ph + N)

50/60 Hz

Microprocessor control

Zero

400% for 10 sec.

Immediate, for overloads above 150%

Automatic after alarm clear

Without interruption

3 x 400V (3Ph + N)

50/60 Hz

93%

70.5 A

93.3%

188 A

805 x 590 x 1320

255

Not Applicable

If the UPS is installed in a location where the altitude is above 1000m, the output power must be lowered by one percent for every 100m covered.

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

38

Online UPS

The Most Versatile Solution For Power

Protection

The Power Series is designed with the new state of art transformerless PWM technology that can be easily adapted to any kinds of complicated loads such as the non-linear systems (IT systems), highly inductive/ capacitive loads, high-density discharge lamps and induction motors. The Power series is designed with 2 important criterions in mind; maximum efficiency and energy conservation. The unit also comes with a small form factor to allow for minimum installation effort.

Furthermore, a parallel redundant system is integrated to allow two UPS models to operate in parallel as backup for each other. The Power Series is available in capacities ranging from 15 to 120kVA.

Input Power Factor 0.99 At 10% Load

Lower power losses would result in reduced consumption, lower operation and maintenance costs.

INPUT POWER FACTOR

1,20

1,00

0,80

0,60

0,40

0,20

0,00

0% 25% 50%

LOAD

Online Double Conversion Technology with

DSP Control

The Power Series is able provide a higher load up-time and effective insulation against network disturbance with its online double conversion technology. A Digital

Signal Processor (DSP) controller improves the performance and efficiency of the UPS.

Advanced Control with Adaptive Feed Forward

Cancellation (AFC) Technology

By cancelling both the input current and the output voltage harmonics, the harmful effects of harmonic injection can be eliminated and this enhances the load integrity.

Output Efficiency of up to 95%

Designed with a DSP controller and fourth generation

IGBT transistors, the UPS is able to achieve extremely high efficiency of up to 95%. With such high ratings, components in the UPS are not only protected but also prolonged due to the decrease in heat losses.

SERIES TIPICAL EFFICIENCY

100%

75%

50%

25%

0%

0%

25% 50%

LOAD

Low Input Current Distortion (THDi < 1%)

AFC cells are used to achieve extremely low distortion values. The Power series is able to obtain a low input current distortion at THDi < 1% under full load and a THDi

< 5% under smaller load (i.e. 10% of load). This will prevent distortion of electrical network upstream and thus, result in the reduction of cable usage and protective devices in the electrical network.

Small Form Factor

Utilizes a transformerless technology allows the design of the UPS to be lighter and smaller.

Output Power Factor

Nowadays IT installation requirements are driving to power sources able to supply loads with leading power without affecting the power capability. Power E Series

UPS are able to supply full power without any derating for all loads from 0.9 lagging to 0.9 leading. This unique characteristic avoids any UPS over sizing in case of unity or leading power factor as for the loads.

39

Online UPS

Front Access concept

An important consideration has been given during the UPS design phase to create a system that allows users to access the unit’s electronic cards and power components with minimum effort. All electronic boards and components can be accessed from the front panel for easy maintenance and replacement activities.

Variety Of Communications And Option

Available

The UPS has provided the following standard communication selections:

• Relay interface

• RS-232/485 port

• 1 × SNMP slot

• Modbus RTU / SEC protocol

• 2 × connectors for parallel connection

Made of 60% Recyclable

Materials

When it comes to conserving the environment, PROLiNK is committed to play a part by designing their UPS products using recyclable materials.

Versatile Single-Phase / Three-Phase set-ups

This highly versatile UPS is designed with different types of setting-up options;

• Three-phase input / Three-phase output (III/III)

• Three-phase input / Single phase output (III/I)

Control Components are designed to with stand all kinds of loads

In the Power Series, the control components are designed to withstand all types of loads. These include loads such as; resistive, capacitive, non-linear, high-density discharge lamps, induction motors, speed drives etc. This makes the UPS extremely compatible with many types of electronics. Better yet, the UPS comes with a wide array of parameters that can be programmed locally or remotely to fit different types of environment.

Back-up Time indicator

With the use of simple algorithms, an estimated remaining back-up time can be calculated and indications will be reflected on a LCD panel.

5.7” Multiple Languages Graphical LCD

Display

Our team of specialists has gathered together to revolutionize the UPS usability by adding in a 5.7” LCD monitor display with all information and alarm notifications viewable within a single display.

N+1 Redundancy

A parallel redundant system allows 4 UPS models to operate in parallel and as backup for each other.

40

Online UPS

PPM Series

PROLiNK Power

Modular (PPM)

UPS System

Local Area

Network

(LAN)

Telecommunication

Devices

Data

Centre

Electro-Medical

Device

Storage

PLCS

Emergency

Alarm

Devices

E-Business

(Server Farms,

ISP/ASP/POP)

PROLiNK PPM Series modular three-phase input / three-phase output online double conversion UPS takes scalability to a whole new level. Based on a scalable design, the PPM comes with a wide range of capacity, ranging from as low as

30kVA to as high as 210kVA. The PPM series is designed with a N+X parallel redundancy system that allows two or more UPS modules to operate in parallel and as back-up for each other. This unit provides an ideal protection for data centers, telecommunication facilities and other critical applications. Up to seven

30kVA modules can be fitted into a standard cabinet to simplify maintenance and replacement activities. The PPM Series guarantees a low mean-time-to-repair

(MTTR), giving users a shorter elapsed time between the point of repair and the point of equipment recovery.

• High efficiency online double conversion technology

• High scalability

• Unity output power factor

• Modular design lowers MTTR

• N+1 or N+X parallel redundancy for power guarantee

• Ease of installation and maintenance

• Flexible battery configuration adapts different applications

• Adjustable charging current

• High overload capability

• Graphic 5.7” LCD design for easy management

High Efficiency Online Double Conversion

Technology

PROLiNK PPM is designed with the latest online double conversion technology that provides a high efficiency rating of 96%. With such a high efficiency rating, the PPM can save you hundreds of dollars each year.

High Scalability

Based on a scalable design, the PPM Series simplifies future expansion by making UPS units easily upgradable.

This architecture allows you to meet power demands by adding additional modules vertically in a single rack enclosure.

Unity Output Power Factor

With a unity output factor (kVA = kW), the PROLiNK

PPM UPS system is 100% compatible with today's high power factor loads. It is able to meet the latest server requirements, giving the best value for your IT investments.

Modular Design Lowers MTTR

The modular design ensures uninterrupted power supply during UPS maintaining and replacing activities. Also, the

PPM Series guarantees a low mean-time-to-repair

(MTTR), giving users a shorter elapsed time between the point of repair and the point of equipment recovery.

41

Online UPS

N+X Parallel Redundancy

The PPM series is designed with a N+X parallel redundancy system that allows two or more UPS modules to operate in parallel and as back-up for each other.

Adjustable Charging Current

PROLiNK PPM comes with a maximum charging current of up to 8A for each individual module. The charging current can be adjusted based on the necessary requirement.

5.7” LCD Graphic Mimic Panel

A multilingual 5.7" graphic

LCD screen is integrated as part of the design to provide users with visual information and advanced control abilities.

Ease Of Installation and Maintenance

With a built-in maintenance bypass feature, the UPS is able to deliver continuous power to the critical load during maintenance. Better yet, the PPS comes with a front access concept to facilitate installation.

High Overload Capability

PROLiNK PPM supports 110% overload for 60 minutes,

120% for 10 minutes and 150% for 1 minute.

PPM90

The PROLiNK PPM90 is a compact stand alone UPS system that provides the best backup solution for small and medium loads. This unit comes with a standard EIA height of 30U and is able to fit capacities ranging from 30kVA to

90kVA in the same cabinet. With features such as N+1 redundancy and the capability for future expansion, the PROLiNK PPM90 is definitely able to make your backup experience an absolute cinch.

No. Of Module

1

2

3

Capacity

30kVA

60kVA

90kVA

Dimension

600 x 1100 x 1485 (30U) mm

Exterior

PPM210

The PROLiNK PPM210 is a standalone UPS system that comes with a standard

EIA height of 42U. This unit is able to fit 7 x 30kVA modular redundancy in the same cabinet. Even better, the PPM210 has the capability to manage future capacity expansion of up to 210kVA, making the PPM210 the best backup solution for greater loads.

No. Of Module

1

2

3

4

5

6

7

Capacity

30kVA

60kVA

90kVA

120kVA

150kVA

180kVA

210kVA

Dimension

600 x 1100 x 2030 (42U) mm

Exterior

Interior

Interior

42

Online UPS

Full Specifications

MODELS

Phase

Total Capacity*

UPS Power Modules

Topology

INPUT

Nominal Voltage

Voltage Range

Nominal Frequency

Frequency Range

Power Factor

Harmonic Distortion (THDi)

OUTPUT

Nominal Voltage

Voltage Regulation (Steady state)

Voltage Regulation (Transient)

Nominal Frequency

Frequency Range (Synchronized)

Overload Capability

Harmonic Distortion

Efficiency

BATTERY / CHARGER

Nominal Voltage

Maximum Voltage

Minimum Voltage

Float Charging Voltage

Boost Charging Voltage

Temperature Compensation

Maximum Charging Current

PHYSICAL

Medium Size (mm) D x W x H

Full Size (mm) D x W x H

ENVIRONMENT

Operation Temperature

Relative Humidity

Altitude

IP Class

MANAGEMENT

Smart RS-232 / USB

Optional SNMP

STANDARDS

Safety

EMC

PPM30

30KW

1

PPM60

60KW

2

PPM90 PPM120

3-phase in/3-phase out

PPM150

90KW

3

120KW

4

150KW

True Double-Conversion Online

5

3 x 400 VAC (3Ph+N)

305 ~ 477 Vac @Full load, 208 ~ 477 Vac @ <70% load

50/60Hz (auto-selectable)

40Hz ~70Hz

> 0.99 @ 100% Load , >0.98 @ 50% Load

< 3% @ 100% load

PPM180

180KW

6

3 x 400 VAC (3Ph+N)

≦ ± 1% Typical (balanced load) ; ≦ ± 2% Typical (unbalanced load)

≦ ± 5% Typical

50/60Hz

46Hz ~ 54Hz or 56Hz ~ 64Hz

1 hour for 110%, 10 mins for 120%, ; 1 min for 150%, 200ms for >150%

≦ 1.5% THD (Linear Load) ; ≦ 4% THD (Non-linear Load)

>94.5%

+/- 216V (12V x 36 pcs)

+/- 240V (12V x 40 pcs)

+/- 192V (12V x 32 pcs)

2.25V / Cell

2.35V / Cell

Yes

8A (User-adjustable)

1100 x 600 x 1485 (30U) Not Applicable

1100 x 600 x 2030 (42U)

0 ~ 40°C

0 ~ 95% non-condensing

<1000m for Nominal power

IP 20

Supports Windows ® 2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

Power management from SNMP manager and web browser

IEC/EN 60950-1; IEC/EN 62040-1

IEC/EN 62040-2 Category C3

PPM210

210KW

7

When temperature above 30°C, the system output power factory will become 0.8

One power module provides 30kW power capacity. One battery module contains 10 pcs of 12V7Ah, 12V9Ah or 12V10Ah (subject to requirement) Valve Regulated Lead Acid batteries.

All specifications, designs and contents are subjected to changes without prior notice.

43

Online UPS

PRO-R Series

1U Online UPS 1000VA

Local Area

Network

(LAN)

Telecommunication

Devices

Data

Centre

Electro-Medical

Device

Storage

PLCS

Emergency

Alarm

Devices

E-Business

(Server Farms,

ISP/ASP/POP)

PROLiNK PRO-R is a transformerless Online UPS that is designed with a small footprint. Despite being thinner and lighter, the PRO-R is able to provide similar performance as any other online UPS. Built with a true online double-conversion technology, it guarantees consistent and clean electrical power to fully protect your mission-critical devices.

In addition, the UPS comes with a built-in master and slave feature to conserve energy when the master device is no longer drawing current. PROLiNK PRO-R works with a variety of applications such as servers, networking and IP telephone systems.

• True double conversion online topology

• Microprocessor control optimizes reliability

• Output power factor 0.8

• Input power factor correction

• ECO mode for energy saving

• Built-in serial communication port/Dry contact

Rear Panel

For PRO1000RS

1. Ac Input

2. Output Receptacles: Connect to Mission-critical Loads

3. USB/ RS-232 Serial Communication Port

4. ROO/ PRO Function Connector

5. SNMP Intelligent Slot

1

For PRO1000RL

1. Ac Input

2. Output Receptacles: Connect to Mission-critical Loads

3. USB/ RS-232 Serial Communication Port

4. ROO/ PRO Function Connector

5. SNMP Intelligent Slot

6. Dry Contact

7. External Battery Connector

2

IPS1000RS

5

6

4

7

IPS1000RL

4 3 5

2 1

44

Online UPS

Full Specifications

MODELS

Capacity

INPUT

Voltage

Acceptable Voltage Range

Frequency Range

OUTPUT

Output Voltage

Voltage Regulation

Frequency Range

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer Time

AC Mode to Batt. Mode

Inverter to Bypass

Waveform (Batt. Mode)

EFFICIENCY

AC Mode

Battery Mode

BATTERY

Battery Type

Battery Spec & Numbers

Typical Recharge Time

INDICATORS

LED

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Dimension (mm) D x W × H

Net Weight (kgs)

ENVIRONMENT

Humidity

Noise Level

MANAGEMENT

USB or RS-232

Dry Contact (Option)

PRO1000RS

1000 VA

110/120 VAC or 220/230/240 VAC

55-150 VAC or 110-300 VAC @ 50% load

80-150 VAC or 160-300 VAC @ 100% load

60/50 Hz (Auto sensing)

PRO1000RL

1000 VA

220/230/240 VAC

110-300 VAC

110/120 VAC or 220/230/240 VAC

±1%

40-70 Hz (50/60Hz Auto sensing)

50/60 ± 0.5% Hz

5:1 (110/120 VAC)

3:1 (220/230/240 VAC)

≦ 3 % THD (Linear Load)

≦ 5 % THD (Non-linear Load)

0ms

4 ms (Typical)

Pure Sinewave

220/230/240 VAC

3:1

86%

83%

Sealed Lead-acid battery

6 V / 7 Ah x 4

Back to 90% capacity in 4 hours

Lithium-ion battery or Sealed Lead-acid battery

Battery Spec & Numbers (Battery voltage: 48VDC)

Depending on external battery capacity

477 x 438 x 44

13

AC mode, Battery mode, and fault indicators

Sounding every 4 seconds

Sounding every second

Sounding twice every second

Continuously sounding

300 x 440 x 44

6

20-90 % RH @ 0- 40°C (Non-condensing)

Less than 50dBA @ 1 Meter

Supports Windows

®

2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

Signal for AC Power Normal, Battery OK and Fault Alarm

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

45

Online UPS

PRO-M Series

Online UPS

1kVA - 6kVA

Local Area

Network

(LAN)

Telecommunication

Devices

Data

Centre

Electro-Medical

Device

Storage

PLCS

Emergency

Alarm

Devices

E-Business

(Server Farms,

ISP/ASP/POP)

PRO-M Series is a true online double-conversion UPS system that provides clean and consistent electrical power to those who experience underserved power supply. It is designed with a wide input voltage range to handle voltage fluctuating situations to fail-safe your equipment.

The PRO-M Series is noticeably compact in size and is ideal for ATMs, banking and other business critical applications. Users can also adjust the charging current from 1A to 6A to suit their requirements.

• True double-conversion

• Microprocessor control optimizes reliability

• Output power factor 0.8

• Wide input voltage (110 V – 300 V)

• Converter mode available

• ECO mode for energy saving (Only available for 1-3KVA)

• Generator compatible

• Smart SNMP works well with either USB or RS-232

• Comprehensive display allows easy monitoring and access of UPS status

3

4

5

Rear Panel

For 1kVA to 2kVA model

1. AC input

2. Input circuit breaker

3. USB communication port

4. RS-232 communication port

5. SNMP intelligent slot (optional)

6. External battery connection (only available for EML model)

7. Output receptacles

8. Output circuit breaker

9. Output terminal

7

1

2

5

PRO801M

3

4

7

1

2

PRO802M

3

4

5

6

1

2

7

3

PRO801ML

4 5

1

2

7

PRO802ML

46

Online UPS

For 3kVA model

1. AC input

2. Input circuit breaker

3. USB communication port

4. RS-232 communication port

5. SNMP intelligent slot (optional)

6. External battery connection (only available for EML model)

7. Output receptacles

8. Output circuit breaker

9. Output terminal

3

4

5

1

2

PRO803M

9

7

For 5kVA to 10kVA model

1. External battery connector

2. RS-232 communication port

3. Intelligent slot

4. USB communication

5. Emergency power off function connector

(EPO connector)

6. Cooling fan

7. Input circuit breaker

8. Input/ Output terminal

(Refer to diagram 3 for the details)

9. Maintenance bypass switch (option)

10. Output terminal

11. Grounding terminal

12. Utility input terminal

2

6

4

1

5

3

9

6

7

8

3

4

5

1

2

9

7

PRO803ML

2

6

4

1

5

3

9

6

7

8

PRO805M / PRO806M /

PRO810M

11

10 12

PRO805ML /

PRO806ML /

PRO810ML

47

Online UPS

Full Specifications

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Input Voltage Range

Frequency Range

Power Factor

OUTPUT

Output Voltage

Voltage Regulation

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer Time

AC to DC

Inverter to Bypass

Waveform (Batt. Mode)

EFFICIENCY

AC Mode

Battery Mode

BATTERY

Standard Model

Battery Type

Numbers

Recharge Time (Typical)

Charging Current

Charging Voltage

Battery Type

Numbers

Charging Current

Long-Run Model

Charging Voltage

INDICATORS

LCD Display

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Standard Model

Long-Run Model

ENVIRONMENT

Humidity

Noise Level

MANAGEMENT

Smart RS-232 / USB

Optional SNMP

PRO801M/ ML PRO802M/ ML

1000 VA 2000 VA

PRO803M/ ML PRO805M/ ML

Single phase with ground

3000 VA 5000 VA

PRO806M/ ML

6000 VA

100/110/115/120/127VAC or 200/208/220/230/240VAC

55-150 VAC or 110-300 VAC (Based on load at 50%)

85-140VAC or 160-280VAC (Based on load at 100%)

208/220/230/240VAC

110-300 VAC (Based on load at 50%)

176-300 VAC (Based on load at 100%)

40 Hz ~ 70 Hz

≧ 0.99 @ Nominal Voltage (100% load)

46~54 Hz or 56~64 Hz

208/220/230/240VAC 100/110/115/120/127VAC or 200/208/220/230/240VAC

±1%

47~ 53 Hz or 57 ~ 63 Hz

50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz

3:1

≦ 3 % THD (Linear Load)

≦ 6 % THD (Non-linear Load)

Zero

4 ms (Typical)

Pure Sinewave

46~54 Hz or 56~64 Hz

50 Hz or 60Hz ± 0.1 Hz

3 % THD (Linear Load)

5 % THD (Non-linear Load)

Zero

83%

88%

85%

90%

88%

89% 92%

90%

93%

91%

27.4VDC ± 1%

2

2

3

Back to 90% capacity in 4 hours

4

4

1A

54.7 VDC ±1%

6 8

6

82.1 VDC ±1%

Depending on the capacity of external batteries

6 8

1A/2A/4A/6A (Adjustable)

12 V / 9 Ah

8

115.2 VDC ±1%

16

Back to 90% capacity in 9 hours

1 A / 2 A

20

218.4 VDC ±1%

273VDC

±1%

16

1A/2A/4A/6A (Adjustable)

20

1A/2A/4

(Adjustable)

27.4

VDC

± 1%

41.0

VDC

± 1%

54.7

VDC

±1%

82.1

VDC

±1%

109.4

VDC

±1%

82.1

VDC

±1%

109.4

VDC

±1%

115.2 VDC ±1% 218.4 VDC ±1%

273 VDC

±1%

Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators

Sounding every 4 seconds

Sounding every second

Sounding twice every second

Continuously sounding

Dimension (mm) D x W × H

Net Weight (kgs)

Dimension (mm) D × W × H

Net Weight (kgs)

282 x 145 x 220

9.8

282 x 145 x 220

4.1

397 x 145 x 220

17

421 x 190 x 318

27.6

397 x 145 x 220

6.8

7.4

442 x 190 x 688

43

442 x 190 x 318

15

369 x 190 x 688

61

369 x 190 x 318

12

20-90 % RH @ 0- 40°C (Non-condensing)

Less than 50dBA @ 1 Meter

0-95% [email protected]°C

(Non-condensing)

0-95% [email protected]°C

(Non-condensing)

Less than 58dBA

@ 1 Meter

Less than 55dBA

@ 1 Meter

Supports Windows ® 2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

Power management from SNMP manager and web browser

PRO810M/ ML

10000 VA

442 x 190 x 688

66 75

442 x 190 x 318

16 18

0-95% RH @ 0-40°C

(Non-condensing)

Less than 58dBA

@ 1 Meter

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

48

Online UPS

PRO-EM Series

Online UPS

1kVA - 10kVA

Local Area

Network

(LAN)

Telecommunication

Devices

Data

Centre

Electro-Medical

Device

Storage

PLCS

Emergency

Alarm

Devices

E-Business

(Server Farms,

ISP/ASP/POP)

PRO-EM Series is a true online double-conversion UPS system that provides clean and consistent electrical power to those who experience underserved power supply. It is designed with a wide input voltage range to handle voltage fluctuating situations to fail-safe your equipment.

Also, the UPS provides better output factor of up to 0.9 and is ideal for

ATMs, banking and other business critical applications. PRO-EM Series comes with standard USB and RS-232 communication ports and a built-in intelligent slot for additional options such as adapters, protocol converters and relay contact cards.

• True double-conversion

• Microprocessor control optimizes reliability

• Input power factor correction

• Output power factor 0.9

• Wide input voltage

• Converter mode available

• ECO mode for energy saving only available for 1-3KVA models

• Generator compatible

• Smart SNMP works well with either USB or RS-232

• Comprehensive display allows easy monitoring and access of UPS status

Rear Panel

For 1kVA model

1. AC input

2. Input circuit breaker

3. USB communication port

4. RS-232 communication port

5. SNMP intelligent slot (optional)

6. External battery connection (only available for EML model)

7. Output receptacles

3

4

5

2

1

PRO801EM

7

3

4

5

6

2

1

7

PRO801EML

49

For 2kVA to 3kVA model

1. AC input

2. Input circuit breaker

3. USB communication port

4. RS-232 communication port

5. SNMP intelligent slot (optional)

6. External battery connection (only available for EML model)

7. Output receptacles

8. Output circuit breaker

9. Output terminal

5

2

1

3

PRO802EM

4

7

3 4

5

2

1

9

PRO803EM

7

For 6kVA to 10kVA model

1. External battery connector

2. RS-232 communication port

3. Intelligent slot

4. USB communication

5. Emergency power off function connector

(EPO connector)

6. Cooling fan

7. Input circuit breaker

8. Input/ Output terminal

9. Maintenance bypass switch (optional)

10. Output terminal

11. Grounding terminal

12. Utility input terminal

2

6

4

1 5

3

9

6

7

8

PRO810EM

2

6

4

1 5

3

9

6

8

7

10

11

12

PRO810EML

50

3 4

Online UPS

5

6

1

2

7

PRO802EML

3 4

5

6

1

2

9

7

PRO803EML

Online UPS

Full Specifications

MODELS

Phase

Capacity

INPUT

Nominal Voltage

Input Voltage Range

Frequency Range

Power Factor

OUTPUT

Output Voltage

Voltage Regulation

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer Time

AC to DC

Inverter to Bypass

Waveform (Batt. Mode)

EFFICIENCY

AC Mode

Battery Mode

BATTERY

Standard Model

Long-Run Model

Battery Type

Numbers

Recharge Time (Typical)

Charging Current

Charging Voltage

Battery Type

Numbers

Charging Current

Battery Type

INDICATORS

LCD Display

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Standard Model

Long-Run Model

Dimension (mm) D x W × H

Net Weight (kgs)

Dimension (mm) D × W × H

Net Weight (kgs)

ENVIRONMENT

Humidity

Noise Level

MANAGEMENT

Smart RS-232 / USB

Optional SNMP

PRO801EM/ EML

1000 VA

PRO802EM/ EML

2000 VA

PRO803EM/ EML

Single phase with ground

3000 VA

PRO806EM/ EML

6000 VA

100/110/115/120/127VAC or 200/208/220/230/240VAC

60-150 VAC or 120-300 VAC at 50% load

90-140 VAC or 180-280 VAC at 100% load

40 Hz ~ 70 Hz

≧ 0.99 @ Nominal Voltage (100% load)

208/220/230/240VAC

110-300 VAC (Based on load at 50%)

176-300 VAC (Based on load at 100%)

46~54 Hz or 56~64 Hz

208/220/230/240VAC 100/110/115/120/127VAC or 200/208/220/230/240VAC

±1%

47~ 53 Hz or 57 ~ 63 Hz

50 Hz or 60Hz ± 0.5%

3:1

≦ 3 % THD (Linear Load)

≦ 6 % THD (Non-linear Load)

Zero

4 ms (Typical)

Pure Sinewave

46~54 Hz or 56~64 Hz

50 Hz or 60Hz ± 0.1 Hz

3 % THD (Linear Load)

5 % THD (Non-linear Load)

Zero

88%

83%

89%

85%

90%

88% 90%

94%

91%

2

27.4VDC ± 1%

2

27.4VDC ± 1%

4

Back to 90% capacity in 4 hours

12 V / 9 Ah

6 16 20

Back to 90% capacity in 9 hours

1.0A

54.7 VDC ±1% 82.1 VDC ±1% 218.4 VDC ±1%

Depending on the capacity of external batteries

1A, 2A (Adjustable)

273 VDC ±1%

4

1A/2A/4A/6A

54.7 VDC ±1%

6

82.1 VDC ±1%

16 20

1A, 2A, 4A (Adjustable)

218.4 VDC ±1% 273 VDC ±1%

Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators

282 x 145 x 220

9.8

282 x 145 x 220

4.1

Sounding every 4 seconds

Sounding every second

Sounding twice every second

Continuously sounding

397 x 145 x 220

17

397 x 145 x 220

6.8

421 x 190 x 318

27.6

397 x 145 x 220

7.4

20-90 % RH @ 0- 40°C (Non-condensing)

Less than 50dBA @ 1 Meter

369 x 190 x 688

61

369 x 190 x 318

12

Supports Windows

®

2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

Power management from SNMP manager and web browser

PRO810EM/ EML

10000 VA

442 x 190 x 688

76

442 x 190 x 318

16

0-95% [email protected]°C

(Non-condensing)

Less than 55dBA

@ 1 Meter

0-95% RH @ 0-40°C

(Non-condensing)

Less than 58dBA

@ 1 Meter

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

51

Online UPS

Giant Series

Online UPS

30kVA - 80kVA

Local Area

Network

(LAN)

Telecommunication

Devices

Data

Centre

Electro-Medical

Device

Storage

PLCS

Emergency

Alarm

Devices

E-Business

(Server Farms,

ISP/ASP/POP)

PROLiNK Giant Series (3P/3P) three-phase input/ three-phase output, true online double conversion UPS system guarantees to supply consistent and quality electrical power to protect your mission critical applications. The front access design makes it easy for users to perform maintenance and replacement activities.

A parallel redundant system is implemented in the Giant Series to provide adequate power supply in the event where a single module fails or needed to be taken offline for service. The Giant Series (3P/3P) also comes with a built-in transformer to provide 100% protection against unexpected AC power problems.

• True double-conversion

• Microprocessor control optimizes reliability

• Input power factor correction

• Output power factor 0.9

• Wide input voltage

• Converter mode available

• Generator compatible

• Smart SNMP works well with either USB or RS-232

• Comprehensive display allows easy monitoring and access of UPS status

Rear Panel

For 30kVA to 80kVA model

1. Intelligent slot

2. Output circuit breaker

3. Input circuit breaker

4. Emergency power off function connector

(EPO connector)

5. USB communication

6. RS-232 communication port

7. RS-485 communication port

8. Parallel connection

9. AC input

10. Bypass

11. Maintenance bypass

12. AC output

13. Battery

9 10 11 12 13

5

6

1

2

3

4

7

8

1

5

6

2

3

4

7

8

9 10 11 12 13

PRO633030S / PRO633040S PRO633060S / PRO633080S

52

Online UPS

Full Specifications

MODELS

Capacity

INPUT

Nominal Voltage

Acceptable Voltage Range

Frequency

INVERTER

Nominal Voltage

Precision

Frequency

Max. Synchronisation Speed

Waveform

Total Harmonic Distortion (THDv)

Phase Displacement

Dynamic Recovery Time

Admissible Overload

Admissible Crest Factor

Admissible Power Factor

Imbalance Output Voltage @ 100% Unbalanced Load

Current Limit

STATIC BYPASS

Type

Voltage

Frequency

Activation Criterion

Transfer Time

Admissible Overload

Transfer to Bypass

Retransfer

MAINTENANCE BYPASS

Type

Voltage

Frequency

Overall Efficiency

Overall Efficiency

Low Battery

BATTERY & CHARGER

Battery Type and Numbers

Nominal Battery Voltage

Charging Method

Precision

Charging Current

Charging Voltage

PHYSICAL

Dimensions, D x W x H(mm)

Net Weight (Kgs)

PRO633030S

30 kVA

PRO633040S

40 kVA

PRO633060S

60 kVA

3 x 380VAC/400VAC (3Ph + N)

304VAC ~ 440VAC

50/60 Hz ± 10 %

3 x 380VAC/400VAC (3Ph + N)

Stationary: ±1%

Transitory: ±5% (load variations 100-0-100%)

50/60 Hz synchronised ±1 %

With mains absent ±0.1 Hz

±1 Hz/s

Pure Sinewave

<2% (Linear Load) ; <5% (Non-linear Load)

120º ±1% (balanced load) ; 120º ±2% (imbalances 50% of the load)

1 cycle at 98 % of the static value

110% for 60min,125% for 10 min, 150% for 60s

3:1

0.6~1 (inductive or capacitive)

<1%

High overload, short-circuit: RMS Voltage Limit

High Crest-Factor current: Peak Voltage Limit

PRO633080S

80 kVA

Solid state

3 x 380VAC/400VAC (3Ph + N)

50/60 Hz

Microprocessor control

Zero

200% for 10 sec

Immediate, for overloads above 150%

Automatic after alarm clear

Without interruption

3 x 400V (3Ph + N)

50/60 Hz

90%

95%

12V x 30 pcs, sealed lead acid battery

360 VDC

CC/CV

±1%

40 A

405 VDC

271.5

847.5 x 432.4 x 1134.5

298 462

1054 x 508 x 1287

532

L stands for Long-run model

S stands for Standard model

I stands for Isolation Transformer (Optional)

*All specifications, designs and contents are subject to change without prior notice.

53

Jupiter Series (3P/3P)

Online Jupiter Series

10kVA - 320kVA

Online UPS

Key Features

• True Galvanic Isolation technology designed to provide full protection against high voltage surges, noise and leakage

current etc

• Plug and Play modular design allows users to carry out maintenance and repair works effortlessly

• Cold start function

• Multi-CPU design

• Hot-swappable battery design

• Temperature compensation for battery charging

• Wide input voltage range

• Output power factor of 0.80

• Software and Hardware redundant design

• EMI suppression provides approximately 200dB noise reduction

• Static Bypass Switch provides automatic transfer to a back-up power source in the event of a failure within the UPS

• Maintenance Bypass Switch

• Smart battery charger designed to optimize battery performance

• LCD User Interface

Options

• Remote control panel

• PC monitoring software

• Auto dialling module

• SNMP/ HTTP network card

• Emergency Power Off switch (EPO)

54

Online UPS

Full Specifications

10KVA ~ 60KVA UPS 3-Phase Input / 3-Phase Output

MODELS

Capacity

INPUT

Input Voltage

Input Range

Input Frequency

Input Power Factor

Normal Input Current(A)

Maximum Input Current(A)

Power Walk In

Efficiency

Voltage Regulation

Current Limit(A)

Ripple Voltage

BATTERY

Type

No. Of Cells

Voltage Range

Maximum Charge Current (Adc)

Battery Low Voltage

Battery Low Stop

Boost Charge

Float Charge

INVERTER

Dc Input Range

Wave Form

Output Voltage

Output Power Factor

Voltage Regulation 100% Unbalance Load

Frequency Lock Range

Output Frequency (Free Running)

Phase Shift Under 100% Unbalance Load

THD (Linear Load)

<110%

110 - 125%

Overload

125 - 150%

>150%

Efficiency (100% Load)

Maximum Output Peak Current(A)

STATIC SWITCH

Voltage Range

Frequency Range

Efficiency

Transfer Time

Overload

Isolation With Output

OVERALL CHARACTERISTICS

Overall Efficiency

Mains > Inverter

Inverter > Mains

100%

300%

OPERATING ENVIRONMENT

Temperature

Humidity

Altitude

Maximum Heat Dissipation(Kw)

Weight(Kg) (No Battery)

Dimension (mm) D x W x H

Audible Noise

Standards

En50091-1,-2

Fcc Class A

Short Circuit

Protections

Lightning

Emc Filter

Galvanic Isolation

Data Display By Lcd

Indications & Alarms

LED,LCD,BUZZER

Dry Contact

Battery Start

PRO533010S

10kVA

18

24

27

5

43

0.65

270

PRO533020S

20kVA

36

45

54

10

93%

87

91%

1.3

300

PRO533030S

30kVA

PRO533040S

40kVA

380 / 400 / 415VAC 3 Phase 4 Wire

307 – 520V

50 / 60Hz +/- 7%

0.8

54 72

68 90

0% - 100% : 20 sec

99%

1%

81 108

0.5%

Seal Lead Acid / NiCd

174 / 271

295 – 410VDC / 285-415VDC

15 20

320VDC / 305VDC

295VDC / 285VDC

402VDC / 415VDC

390VDC / 410VDC

285 – 420VDC

Sinusoid

380 / 400 / 415 VAC 3 Phase 4 Wire

0.8

+ / - 1 %

45 – 55Hz / 55 – 65Hz

50 / 60Hz + / - 0.1Hz

120 % + / - 0.5

°

< 2 %

Continuous

15 min

10 min

60 sec

93.5%

130 174

173 – 277 VAC (Line To Neutral)

45 – 55Hz / 55 – 65Hz

99.5%

0 ms

0 ms

30 sec

1 sec

Yes

91.5%

0 – 40°F ( 32 – 104°F )

0% - 90% ( Non–condensing )

<1500m Above Sea Level

1.9

400

800 x 550 x 1600

< 65 dBA (@ 1 m)

2.6

480

Yes

Yes

Rectifier, Reserve, Bypass Nfb

Mov

Input & Output

Between Input & Output

Yes

Yes

Yes

Yes

PRO533050S

50kVA

90

113

135

25

218

3

550

92%

PRO533060S

60kVA

108

136

162

30

94%

260

3.5

680

55

Online UPS

80KVA ~ 160KVA UPS 3-Phase Input / 3-Phase Output

MODELS

Capacity

INPUT

Input Voltage

Input Range

Input Frequency

Input Power Factor

Normal Input Current(A)

Maximum Input Current(A)

Power Walk In

Efficiency

Voltage Regulation

Current Limit(A)

Ripple Voltage

BATTERY

Type

No. Of Cells

Voltage Range

Maximum Charge Current (Adc)

Battery Low Voltage

Battery Low Stop

Boost Charge

Float Charge

INVERTER

Dc Input Range

Wave Form

Output Voltage

Output Power Factor

Voltage Regulation 100% Unbalance Load

Frequency Lock Range

Output Frequency (Free Running)

Phase Shift Under 100% Unbalance Load

THD (Linear Load)

Overload

<110%

110 - 125%

125 - 150%

>150%

Efficiency (100% Load)

Maximum Output Peak Current(A)

STATIC SWITCH

Voltage Range

Frequency Range

Efficiency

Transfer Time

Overload

Isolation With Output

OVERALL CHARACTERISTICS

Overall Efficiency

OPERATING ENVIRONMENT

Mains > Inverter

Inverter > Mains

100%

300%

Temperature

Humidity

Altitude

Maximum Heat Dissipation(Kw)

Weight(Kg) (No Battery)

Dimension (mm) D x W x H

Audible Noise

Standards

En50091-1,-2

Fcc Class A

Protections

Short Circuit

Lightning

Emc Filter

Galvanic Isolation

Data Display By Lcd

Indications & Alarms

LED,LCD,BUZZER

Dry Contact

Battery Start

PRO533080S

80kVA

144

180

216

40

348

4.6

820

94.5%

92.5%

PRO533100S

100kVA

285 – 420VDC

Sinusoid

380 / 400 / 415 VAC 3 Phase 4 Wire

0.8

+ / - 1 %

45 – 55Hz / 55 – 65Hz

50 / 60Hz + / - 0.1Hz

120 % + / - 0.5

°

< 2 %

Continuous

15 min

10 min

60 sec

432

PRO533120S

120kVA

380 / 400 / 415VAC 3 Phase 4 Wire

307 – 520V

50 / 60Hz +/- 7%

0.8

180

225

216

270

0% - 100% : 20 sec

99%

1%

270 324

0.5%

Seal Lead Acid / NiCd

174 / 271

295 – 410VDC / 285-415VDC

50 60

320VDC / 305VDC

295VDC / 285VDC

402VDC / 415VDC

390VDC / 410VDC

520

173 – 277 VAC (Line To Neutral)

45 – 55Hz / 55 – 65Hz

99.5%

0 ms

0 ms

30 sec

1 sec

Yes

0 – 40°F ( 32 – 104°F )

0% - 90% ( Non–condensing )

<1500m Above Sea Level

5.4

950

6.5

1180

800 x 1100 x 1600

< 65 dBA (@ 1 m)

Yes

Yes

Rectifier, Reserve, Bypass Nfb

Mov

Input & Output

Between Input & Output

Yes

Yes

Yes

Yes

95%

93%

PRO533160S

160kVA

288

360

432

80

693

8.7

1450

56

200KVA ~ 320KVA UPS 3-Phase Input / 3-Phase Output

MODELS

Capacity

INPUT

Input Voltage

Input Range

Input Frequency

Input Power Factor

Normal Input Current(A)

Maximum Input Current(A)

Power Walk In

Efficiency

Voltage Regulation

Current Limit(A)

Ripple Voltage

BATTERY

Type

No. Of Cells

Voltage Range

Maximum Charge Current (Adc)

Battery Low Voltage

Battery Low Stop

Boost Charge

Float Charge

INVERTER

Dc Input Range

Wave Form

Output Voltage

Output Power Factor

Voltage Regulation 100% Unbalance Load

Frequency Lock Range

Output Frequency (Free Running)

Phase Shift Under 100% Unbalance Load

THD (Linear Load)

Overload

<110%

110 - 125%

125 - 150%

>150%

Efficiency (100% Load)

Maximum Output Peak Current(A)

STATIC SWITCH

Voltage Range

Frequency Range

Efficiency

Transfer Time

Overload

Isolation With Output

OVERALL CHARACTERISTICS

Overall Efficiency

OPERATING ENVIRONMENT

Mains > Inverter

Inverter > Mains

100%

300%

Temperature

Humidity

Altitude

Maximum Heat Dissipation(Kw)

Weight(Kg) (No Battery)

Dimension (mm) D x W x H

Audible Noise

Standards

En50091-1,-2

Fcc Class A

Protections

Short Circuit

Lightning

Emc Filter

Galvanic Isolation

Data Display By Lcd

Indications & Alarms

LED,LCD,BUZZER

Dry Contact

Battery Start

PRO533200S

200kVA

350

437

525

100

800

11.5

2500

PRO533240S

240kVA

PRO533300S

300kVA

380 / 400 / 415VAC 3 Phase 4 Wire

307 – 520V

50 / 60Hz +/- 7%

0.8

420

525

525

656

0% - 100% : 20 sec

99%

1%

630 788

0.5%

Seal Lead Acid / NiCd

174 / 271

295 – 410VDC / 285-415VDC

120 150

320VDC / 305VDC

295VDC / 285VDC

402VDC / 415VDC

390VDC / 410VDC

285 – 420VDC

Sinusoid

380 / 400 / 415 VAC 3 Phase 4 Wire

0.8

+ / - 1 %

45 – 55Hz / 55 – 65Hz

50 / 60Hz + / - 0.1Hz

120 % + / - 0.5

°

< 5 %

Continuous

15 min

10 min

60 sec

95%

1000 1250

173 – 277 VAC (Line To Neutral)

45 – 55Hz / 55 – 65Hz

99.5%

0 ms

0 ms

30 sec

1 sec

Yes

93%

0 – 40°F ( 32 – 104°F )

0% - 90% ( Non–condensing )

13

2700

<1500m Above Sea Level

16.3

3000

800 x 2200 x 1600

< 65 dBA (@ 1 m)

Yes

Yes

Rectifier, Reserve, Bypass Nfb

Mov

Input & Output

Between Input & Output

Yes

Yes

Yes

Yes

*All specifications, designs and contents are subject to change without prior notice.

Online UPS

PRO533320S

320kVA

560

700

840

160

1300

17.4

3100

57

Line Interactive UPS

PRO SFC Series

Super Fast Charging

Line Interactive Series

650VA - 1200VA

PC Printer Work-Stations

PROLiNK SFC series is a single-phase input/ single-phase output

Line-Interactive UPS system with PROLiNK’s latest Super-Fast

Charging technology. This cutting-edge technology is able to recharge the battery back to 90% of its capacity within 2-4 hours, and is ideal for providing stable backup power to home/ small office applications. A wide input voltage range is supported due to the integrated 3-Step AVR which features 2 boosts and 1 buck to regulate output voltage. This prevents under voltage brownouts and over voltage surges. The unit also comes with universal sockets to provide better compatibility with a wider range of devices.

• Built-in super fast charger, battery can be recharged to 90% of

its capacity within 2-4 hours

• Excellent microprocessor control guarantees high reliability

• Boost and buck AVR for voltage stabilization

• Auto restart while AC is recovering

• Simulated sine wave

• Off-mode charging

• Cold start function

• Optional USB/RS-232 communication port and RJ-11/RJ-45 protection

Rear Panel

For 650VA to 1200VA model

1. AC Input

2. Backup Output

3. Bypass Output (without battery back up)

4. USB Port (Only available in SFCU series)

5. RJ11

1

4 5

1

4

2

2

2

PRO700SFC/ SFCU

2

PRO850SFCU

4

2

2 3

PRO1200SFC/ SFCU

1

5

58

Line Interactive UPS

Full Specifications

MODELS

Capacity VA

INPUT

Nominal Voltage

V o lta g e Ran g e

Nominal Frequency

OUTPUT

Output Voltage Regulation (Battery Mode)

Fre q uenc y

Transfer Time (Typical)

Waveform

BATTERY

Number of Battery

Recharge Time (Typical)

PROTECTION

Full Protection

INDICATION

LED Display

ALARM

Sounding

PHYSICAL

Di m en s i o n (mm) D x W × H

Net W ei g ht (kgs)

ENVIRONMENT

Humidity

Noise Level

MANAGEMENT

USB/ RS-232

PRO700SFC/ SFCU

650

PRO850SFCU

850

PRO1200SFC/ SFCU

1200

Typical 2-6 ms

220/ 230/ 240VAC

140-300VAC

50 or 60Hz (Auto Sensing)

±10%

50 Hz or 60Hz ±1Hz

2 - 6ms, 10ms (max)

Simulated Sinewave

1 x 12V8.2AH

1 x 12V10AH

Back to 90% capacity in 2-4 hours

Short Circuit, Overload, Discharge and Overcharge Protection

2 x 12V8.2AH

AC Mode – Green Lighting

Battery Mode – Yellow Lighting

Charging Mode – Green Flashing every 2 seconds

Overload – Red Flashing every 0.5 seconds

Fault – Red Lighting

Battery Mode – Sounding every 10 seconds

Low Battery – Sounding every second

Overload – Sounding every 0.5 seconds

Battery Replacement Alarm – Sounding every 2 seconds

Fault – Continuously Sounding

4.25

287 x 100 x 142

4.9

0-90% relative Humidity, 0°C - +40°C

Less than 40dB

350 x 146 x 160

Supports Windows ® 2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

8

*All specifications, designs and contents are subject to change without prior notice.

59

Line Interactive UPS

PRO SFT Series

Super Fast Charging

Line Interactive With

Touch Screen Panel

650VA - 1200VA

PC Printer Work-Stations

The PRO SFT series is a single-phase input/ single-phase output

Line-Interactive UPS system with PROLiNK's latest Super-Fast

Charging technology. It allows for the battery to be recharged back to 90% of its capacity within 2-4 hours, and is ideal for providing stable backup power to home/ small office applications.

A wide input voltage range is supported due to the integrated

3-Step AVR which features 2 boosts and 1 buck to regulate output voltage. This helps prevent under voltage brownouts and over voltage surges. The unit also comes with a LCD user interface that provides valuable information such as output voltage, input voltage, load level, battery voltage and overload warning signals.

• Built-in super fast charger, battery can be recharged to 90% of

its capacity within 2-4 hours

• Excellent microprocessor control guarantees high reliability

• Boost and buck AVR for voltage stabilization

• Auto restart while AC is recovering

• Simulated sine wave

• Off-mode charging

• Cold start function

• LCD User Interface

Rear Panel

For 650VA to 1200VA model

1. AC Input

2. Backup Output

3. Bypass Output (without battery back up)

4. USB Port (Only available in SFTU series)

5. RJ11

1

4 5

1

4

2

2

2

PRO700SFT/ SFTU

2

PRO850SFTU

4

2 1

5

2 3

PRO1200SFT/ SFTU

60

Line Interactive UPS

Full Specifications

MODELS

Capacity VA

INPUT

Nominal Voltage

V o lta g e Ran g e

Nominal Frequency

OUTPUT

Output Voltage Regulation (Battery Mode)

Fre q uenc y

Transfer Time (Typical)

Waveform

BATTERY

Number of Battery

Recharge Time (Typical)

PROTECTION

Full Protection

Display

LCD Display

ALARM

Sounding

PHYSICAL

Di m en s i o n (mm) D x W × H

Net W ei g ht (kgs)

ENVIRONMENT

Humidity

Noise Level

MANAGEMENT

USB/ RS-232

PRO700SFT/ SFTU

650

PRO850SFTU

850

PRO1200SFT/ SFTU

1200

Typical 2-6 ms

230VAC

140-300VAC

50 or 60Hz (Auto Sensing)

+/ -10%

50 Hz or 60Hz +/ -1 Hz

2 - 6ms, 10ms (max)

Simulated Sinewave

1 x 12V8.2AH

1 x 12V10AH

Back to 90% capacity in 2-4 hours

Short Circuit, Overload, Discharge and Overcharge Protection

2 x 12V8.2AH

Input voltage, output voltage, battery level, load level and UPS status

Battery Mode – Sounding every 10 seconds

Low Battery – Sounding every second

Overload – Sounding every 0.5 seconds

Battery Replacement Alarm – Sounding every 2 seconds

Fault – Continuously Sounding

4.4

300 x 101 x 142 350 x 146 x 160

5

0-90% relative Humidity, 0°C - 40°C (Non -condensing)

Less than 40dB

Supports Windows

®

2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

8

*All specifications, designs and contents are subject to change without prior notice.

61

Line Interactive UPS

PRO Series

Line Interactive Series

650VA – 1200VA

PC Printer Work-Stations

PRO Series is a single-phase input / single-phase output line-interactive UPS system. It is able to provide clean electrical power and is ideal for home / small office applications. A wide input voltage range is supported due to the integrated 3-Step AVR which features 2 boosts and 1 buck to regulate output voltage. This prevents under voltage brownouts and over voltage surges. The unit also comes with universal sockets to provide better compatibility with a wider range of devices.

• Built-in super smart charger, shorten 50% of charging time

• Excellent microprocessor control guarantees high reliability

• Boost and buck AVR for voltage stabilization

• Auto restart while AC is recovering

• Simulated sine wave

• Off-mode charging

• Cold start function

• Optional USB/RS-232 communication port and RJ-11/RJ-45 protection

• Offering LED and LCD panels for selections

Rear Panel

For 650VA to 1200VA model

1. AC Input

2. Backup Output

3. Bypass Output (without battery back up)

4. USB Port (Only available in VU and SVU series)

5. RJ11

4

4

1

2

1

2

PRO700V/ VU

2

2

PRO850VU

5

1

3

2

2

PRO850SU

4

2 1

5

2 3

PRO1200SV/ SVU

62

Line Interactive UPS

Full Specifications

MODELS

Capacity VA

INPUT

Nominal Voltage

V o lta g e Ran g e

Nominal Frequency

OUTPUT

Output Voltage Regulation (Battery Mode)

Fre q uenc y

Transfer Time (Typical)

Waveform

BATTERY

Number of Battery

Recharge Time (Typical)

PROTECTION

Full Protection

INDICATION

LED Display

ALARM

Sounding

PHYSICAL

Di m en s i o n (mm) D x W × H

Net W ei g ht (kgs)

ENVIRONMENT

Humidity

Noise Level

MANAGEMENT

USB/ RS-232

PRO700V/ VU

650

Typical 2-6 ms

1 x 12V8.2AH

PRO850VU/ SU

850

PRO1200SV/ SVU

1200

220/ 230/ 240VAC

140-300VAC

50 or 60Hz (Auto Sensing)

±10%

50 Hz or 60Hz ±1Hz

2 - 6ms, 10ms (max)

Simulated Sinewave

1 x 12V10AH

Back to 90% capacity in 4-6 hours

Overload, discharge, and overcharge protection

2 x 12V8.2AH

AC Mode – Green Lighting

Battery Mode – Yellow Lighting

Charging Mode – Green Flashing every 2 seconds

Overload – Red Flashing every 0.5 seconds

Fault – Red Lighting

Battery Mode – Sounding every 10 seconds

Low Battery – Sounding every second

Overload – Sounding every 0.5 seconds

Battery Replacement Alarm – Sounding every 2 seconds

Fault – Continuously Sounding

4.25

287 x 100 x 142

4.9

0-90% relative Humidity, 0°C - +40°C

Less than 40dB

350 x 146 x 160

Supports Windows ® 2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

8

*All specifications, designs and contents are subject to change without prior notice.

63

Line Interactive UPS

PRO-L Series

Line Interactive Series

600VA – 2000VA

PC Printer Work-Stations

PRO-L Series is a single-phase input / single-phase output line-interactive UPS system that provides clean and reliable back-up power for longer periods of time. It is able to provide clean electrical power and is ideal for home / small office applications. A wide input voltage range is supported due to the integrated 3-Step AVR which features 2 boosts and 1 buck to regulate output voltage. High voltage battery chargers and battery extension assembly are made available for longer runtime applications. The PRO-L Series with capacities of up to 850VA also comes with universal sockets to provide better compatibility with a wider range of devices.

• Excellent microprocessor control guarantees high reliability

• Boost and buck AVR for voltage stabilization

• Adjustable battery charging current

• Auto restart while AC is recovering

• Off-mode charging

• Cold start function

• Simulated sine wave

Rear Panel

For 600VA to 2000VA model

1. AC input

2. Input protection

3. Output outlet

4. Battery Connection

5. Fan

1

2

5

4

3

PRO700L

2

4

5

1

3 3

PRO1000L/

PRO2000L

64

Line Interactive UPS

Battery Pack

For 600VA to 2000VA model

G6

Model

Battery Type

Battery Number

Dimension (DxWxH) mm

6 pcs

397 × 145 × 220

G12 G18

12V7AH/ 12V9AH/ 12V10AH

12 pcs 18 pcs

421 × 190 × 318 535 × 190 × 318

G60

60 pcs

830 x 250 x 576

Full Specifications

MODELS

Capacity

INPUT

Nominal Voltage

V o lta g e Ran g e

Nominal Frequency

VA

OUTPUT

Output Voltage Regulation (Battery Mode)

Fre q uenc y

Transfer Time (Typical)

Waveform

BATTERY

Battery Voltage

Battery Capacity

Charging Current (max.)

PROTECTION

Full Protection

INDICATION

LED Display

ALARM

Sounding

PHYSICAL

Di m en s i o n (mm) D x W × H

Net W ei g ht (kgs)

ENVIRONMENT

Humidity

Noise Level

PRO700L

600

PRO1000L

1000

220/ 230/ 240VAC

140 - 300VAC

50Hz

PRO2000L

2000

±10%

50 Hz ±1 Hz

Typical 4-8 ms

Simulated Sinewave

2.5A/ 6A/ 10A (adjustable)

12VDC

Depending on the application

5A/ 10A/ 15A/ 20A (adjustable)

24VDC

Overload, discharge, and overcharge protection

AC Mode – Green Lighting

Battery Mode – Yellow Lighting

Fault – Red Lighting

358.5 x 96.8 x 146.5

5.8

Low Battery – Sounding every second

Overload – Sounding every 0.5 seconds

Battery Replacement Alarm – Sounding every 2 seconds

Fault – Continuously Sounding

395 x 145 x 220

9.0

0-90% relative Humidity, 0°C - +40°C

Less than 40dB

13.55

*All specifications, designs and contents are subject to change without prior notice.

65

Line Interactive UPS

PRO Rack/ Tower Series

Line Interactive Series 800VA – 3000VA

PC Printer Work-Stations 19” Rack

Mount

PRO Rack / Tower series is a single-phase input / single-phase output UPS that employs a line-interactive technology.

This device comes with a practical 2U universal-mount case that provides an option for the user to either install it as a floor-standing tower or in a mounting position using a 19-inch rack mount bracket. With its high density output power factor of 0.8, this device is able to provide outstanding performance and efficiency for any home / small office applications. A wide input voltage range is supported due to the integrated 3-Step AVR which features 2 boosts and 1 buck to regulate output voltage.

• Microprocessor-based line interactive design

• Pure sine wave output online mode and battery mode

• User-friendly and easy-shift LCD display

• Rack/Tower design

• Built-in boost and buck AVR

• Output Power Factor 0.8

• Hot swappable battery design

• Programmable power management outlets

• Emergency Power Off Function (EPO)

• Long-run models available

• Multiple communication available

• Option for SNMP communication.

Rear Panel

For 800VA to 3000VA model

1. Programmable outlets: Connect to non-critical loads

2. Output receptacles: Connect to mission-critical loads

3. AC input

4. Input circuit breaker

5. Network/Fax/Modem surge protection

6. Emergency power off function connector (EPO)

7. USB communication port

8. RS-232 communication port

9. SNMP intelligent slot

10. Battery Compartment (only available for Standard model)

11. Output terminal (IEC320-14)

12. Fan

13. External battery pack numbers detection port

5

9

8 6

7

13

12

12

5

PRT800S

1

2

12

10

7

8

9

6

13

PRT3000S/ PRT3000L

1

2

4 3

9

8 6

13

12

5

1

4 3

7

10

2

PRT1100S/ PRT1100L/ PRT2000S/ PRT2000L

11

3

4

66

Line Interactive UPS

Battery Pack

For 1.1kVA to 3kVA model

G8R

Model

Battery Type

Battery Number

Dimension (DxWxH) mm

8 pcs

480 x 438 x 88

G12R

12V7AH/ 12V9AH/ 12V10AH

12 pcs

600 x 438 x 88

G20R

20 pcs

580 x 438 x 133

Full Specifications

MODELS

Capacity

INPUT

Nominal Voltage

V o lta g e Ran g e

Nominal Frequency

OUTPUT

Voltage Regulation (Batt. Mode)

Fre q uenc y

Power Factor

Current Crest Ratio

Voltage Distortion

Liner Load

Non-Liner Load

Waveform

EFFICIENCY

AC Mode

BATTERY

Standard Model

Type

Capacity

Recharge Time (Typical)

Charging Current

Type

Long-Run Model Capacity

Charging Current

INDICATORS

LCD Display

PHYSICAL

Standard Model

Dimension (mm) D × W × H

Net W ei g ht (kgs)

Di m en s i o n (mm) D x W × H

Long-Run Model

ENVIRONMENT

Operation Humidity

Ambient Temperature

Net W ei g ht (kgs)

Noise Level

MANAGEMENT

USB/ RS-232

PRT800S

800 VA

7AH

N/A

12.9

N/A

Value regulated Lead Acid battery (Maintenance free batteries)

1.0 A (max.)

9AH

Back to 90% capacity in 4 hours

Depending on the application

Depending on the application

4A / 8A

AC Mode, Battery Mode, Load Level, Battery Level, Input Voltage, Output Voltage, Overload, Fault, and Low Battery

380 x 438 x 88

PRT1100S/ L

Supports Windows

1100 VA

®

14.23

10.8

50

380 x 438 x 88

162 ~ 290VAC

50 or 60Hz

±3%

Hz or 60Hz ±1Hz

0.8

3:1

≦ 8% THD

≦ 15% THD

Pure Sinewave

Up to 97%

480 x 438 x 88

0-90% (Non-condensing)

0°C - +40°C

PRT2000S/ L

≤ 45dB @ 1 Meter

2000 VA

208/ 220/ 230/ 240VAC

480 x 438 x 88

23.1

14

2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

PRT3000S/ L

3000 VA

600 x 438 x 88

32.24

600 x 438 x 88

18

*All specifications, designs and contents are subject to change without prior notice.

67

Outdoor Line Interactive UPS

Outdoor Line Interactive Series

PC Work-Stations CCTV Traffic Light

Control System

Line Interactive UPS

The PROLiNK® PRO2000LD is a single-phase input/ single-phase output Outdoor UPS system. A wide operating temperature range of -40°C to 80°C makes it ideal for outdoor usage. Designed to put up the best performance under the harshest environment, the PRO2000LD is able to supply continuous power to critical loads during a blackout or power outage.

Equipped with dry contacts, the PRO2000LD is able to program safety-oriented signals to meet the requirements of different applications. As such, users are able to monitor UPS events that are most concerned to them. The PRO2000LD comes in a capacity of 2000VA.

• Selectable transfer time for normal or generator mode

• User-adjustable charging current

• Adjustable input threshold voltage

• Provides programmable signals for dry contacts

• Battery compensation design

• RS-232, USB and SNMP intelligent port interface

Front Panel

For 2000VA model

1. AC input terminal block

2. AC input breaker

3. AC output terminal block

4. AC output breaker

5. Input contact

6. Dry contact

7. Internal fan

8. GND

9. Battery connector

10. Battery temperature sensor

11. External FAN connector

12. PTS control connector

13. Battery breaker

14. Battery voltage test points

15. Function keys

16. Liquid Crystal Display (LCD)

17. Indicator LEDs

18. USB connector

19. RS232 connector

20. Intelligent slot (optional)

19 18

20

2

1 3

4

17

5

16

6

15

PRO2000LD

7

14

12

11

10

8

13

9

68

Full Specifications

MODELS

Rated Power

INPUT

Nominal Voltage

Acceptable Voltage Range

Frequency Range

OUTPUT

Nominal Voltage

Voltage Regulation (Batt. Mode)

Output Frequency

THD (Batt. Mode)

Efficiency

Transfer Time

Waveform

BATTERY

Nominal DC Voltage

Low DC Warning Voltage

Liner Mode

AVR Mode

Battery Mode

Normal Mode (max.)

Generator Mode (max.)

Battery Type

Charging Current

INDICATORS

Bypass Mode

Battery Mode

No Output

Warning with Output

Fault without Output

MANAGEMENT

Communication

Dry Contact Rating

PHYSICAL

Dimension (mm) D × W × H

Net W ei g ht (kgs)

Type of Mechanical Protection

ENVIRONMENT

Operation Humidity

Operating Temperature

Noise Level

COMPLIANCE

EMI Compliance

Surge Protection

PRO2000LD

2000 VA

230VAC

170-300VAC

50 Hz/60 Hz (Auto sensing)

230VAC

230VAC ± 5%

50Hz/60Hz ± 0.1%

<3% @ Full resistive load

95%

90%

90%

12ms

25ms

Pure Sinewave

48VDC

46VDC ± 0.4VDC @ no load

AGM/Gel

2A/4A/6A/8A/10A (Adjustable)

Depending on the application

Green LED On

Green LED Flashing

Green LED Off

Yellow LED On

Red LED On

RS-232/USB and SNMP

3A @ 250Vac

400 x 240 x 133

12.5

IP 20

5% to 95% Relative Humidity (Non-condensing)

-40°C to 80°C

< 48dB

Class A FCC/CISPR [EN50091-2: 1995]

IEEE/ANSI C.62.41 & 2KV, L-N

Line Interactive UPS

*All specifications, designs and contents are subject to change without prior notice.

69

Inverter UPS

IPS Series

Inverter Series

PROLiNK IPS Series is a compact home inverter system that delivers high efficiency conversion from DC to AC power.

This economically ideal system provides clean and stable power for home appliances and generator related devices. In cases where the electrical utility is down, the home inverter system is able to draw DC current from the battery and supply power to all the AC loads connected to it. Covering a wide selection of sizes, the IPS Series is available in capacities as low as 600VA to as high as 5000VA.

• Selectable Voltage Range (Except for IPS600)

• Advanced Protection

• Auto restart while AC is recovering

• Comes with a built-in transformer (Only applies to IPS600, IPS850 & IPS1500)

• LCD and/or LED panel (Refer to the specifications)

4 4

Rear Panel

For IPS600

1. AC input

2. Output receptacles

3. Circuit breaker

4. External battery connector

1

3

2

IPS600

For IPS700 and IPS1201

1. Input voltage range selector

2. AC input

3. Input breaker

4. External battery connector

5. Charge current selector

6. Output receptacles

3

2

1 5

6

4

IPS700/ IPS1201

4

70

For IPS850 and IPS1500

1. Input voltage range selector

2. AC input

3. Input breaker

4. External battery connector

5. Charge current selector

6. Output receptacles

For IPS1200 and IPS2400

1. Operation mode selector

2. AC input

3. Input breaker

4. External battery connectors

5. Charge current selector

6. Output receptacles

For IPS3000 and IPS5000

1. Battery connector

2. Input protector

3. AC input

4. Inverter output

1

5

4

Inverter UPS

3

2

1 5

6

4

IPS850/ IPS1500

4

6

2

3

IPS1200/ IP2400

2

3 4

IPS3000

1

2

3 4

IPS3001

1

2

3 4

IPS5000

1

71

Inverter UPS

Full Specifications

Simulated Sinewave Inverter

MODELS

Capacity

INPUT

Nominal Voltage

VA

V o lta g e Ran g e

Frequency Range

OUTPUT

AC Voltage Regulation (Batt. Mode)

Transfer Time

Waveform (Batt. Mode)

Peak Efficiency

BATTERY

Battery Voltage

Floating Charge Voltage

Low Battery Alarm Voltage

Shutdown Voltage

Overcharge Protection

Maximum Charge Current

PROTECTION

Full Protection

INDICATORS

LCD Display

LED Display

ALARM

Low Battery

Overload

Fault

Battery Replacement

PHYSICAL

Di m en s i o n (mm) D x W × H

Net W ei g ht (kgs)

ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

Line Mode

Fault

Battery Mode

Low Battery

Shutdown Mode

Charging Mode

Overload

IPS600

600VA/ 360W

230 VAC

100 – 290 VAC

200 ~ 230VAC ± 5%

13 ms (Typical)

>95% @ Rated R load and battery full charged

IPS850

850VA/ 600W

IPS1200

1200VA

IPS1500

1500VA/ 1050W

IPS2400

2400VA

120 VAC or 230 VAC 220/ 230/ 240 VAC 120 VAC or 230 VAC 220/ 230/ 240 VAC

90-145 VAC/

180-260 VAC

(For Personal Computers)

50-160 VAC/

100-300 VAC

(For Home Appliances)

170-280 VAC

(For Personal Computers)

90-280 VAC

(For Home Appliances)

90-145 VAC/

180-260 VAC

(For Personal Computers)

50-160 VAC/

100-300 VAC

(For Home Appliances)

170-280 VAC

(For Personal Computers)

90-280 VAC

(For Home Appliances)

50/60 Hz (Auto Sensing)

120VAC ± 10% or

230VAC ± 10%

20 ms (max)

Not Applicable

230VAC ± 10%

10 ms (Typical)

20 ms (max)

Simulated Sinewave

>95%

120VAC ± 10% or

230VAC ± 10%

20 ms (max)

Not Applicable

230VAC ± 10%

10 ms (Typical)

20 ms (max)

>95%

12 VDC

3.7 VDC ± 2%

10.8 VDC ± 2% 10.2 VDC ± 2%

10.0 VDC ± 2%

14.5 VDC ± 2%

13A

9.9 VDC ± 2%

15 VDC ± 2%

10A or 20A

13.7 VDC ± 0.25 VDC

Not Applicable

Not Applicable

15 VDC

10A or 20A (Selectable)

27.4 VDC ± 2%

20.4 VDC ± 2%

24 VDC

27.4 VDC ± 0.5 VDC

Not Applicable

19.8 VDC ± 2%

30 VDC ± 2%

10A or 20A

Not Applicable

30 VDC

10A or 20A (Selectable)

Overload, deep discharge, overcharge and short circuit protection

Overload and short circuit protection

AC Mode, Battery Mode,

Load Level, Battery Level,

Input Voltage,

Output Voltage,

Overload, Fault and

Low Battery

Not Applicable

Green Lighting

Red Lighting

Yellow Flashing

Not Applicable

Not Applicable

Input Voltage,

Output Voltage,

Load level, Battery level and Fault alarm

Not Applicable

Red Lighting

Yellow Flashing

Yellow Flashing

Yellow Flashing

Green Flashing

Red Flashing

Not Applicable

Green Lighting

Red Lighting

Yellow Flashing

Not Applicable

Not Applicable

Input Voltage,

Output Voltage,

Load level, Battery level and Fault alarm

Not Applicable

Red Lighting

Yellow Flashing

Yellow Flashing

Yellow Flashing

Green Flashing

Red Flashing

Sounding every

2 seconds

Sounding every second

Not Applicable

Sounding every

2 seconds

Sounding every

2 seconds

Sounding every 0.5 second

Continuously sounding

Sounding every second

Not Applicable

Sounding every

2 seconds

358.5 x 96.8 x 146.5

4.6

-15°C to 50°C

289 x 290 x 127

6.99

293 x 231.5 xx 82.5

2.35

289 x 290 x 127

10

0 to 90% Relative Humidity (Non-condensing)

0°C to 40°C

-15°C to 70°C Not Applicable -15°C to 70°C

Not Applicable

293 x 231.5 xx 82.5

2.55

Not Applicable

*All specifications, designs and contents are subject to change without prior notice.

72

Inverter UPS

Full Specifications

Pure Sinewave Inverter

MODELS

Capacity

INPUT

Nominal Voltage

VA

V o lta g e Ran g e

Frequency Range

OUTPUT

AC Voltage Regulation (Batt. Mode)

Transfer Time

Waveform (Batt. Mode)

Peak Efficiency

BATTERY

Battery Voltage

Floating Charge Voltage

Low Battery Alarm Voltage

Shutdown Voltage

Overcharge Protection

Maximum Charge Current

PROTECTION

Full Protection

INDICATORS

LCD Display

ALARM

Low Battery

Overload

Fault

PHYSICAL

Di m en s i o n (mm) D x W × H

Net W ei g ht (kgs)

ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

IPS700

700VA/ 500W

IPS1201

1200VA/ 840W

IPS3000

3000VA/ 2400W

230 VAC

IPS3001

3000VA/ 2400W

170-280 VAC (Normal Range)

90-280 VAC (Wide Range)

170-280 VAC (For Personal Computers)

90-280 VAC (For Home Appliances)

230VAC ± 5%

90%

12 VDC

13.5 VDC

11.5 VDC

10.5 VDC

15 VDC

10A or 15A (Selectable)

50/60 Hz (Auto Sensing)

10 ms (For Personal Computers)

20 ms (For Home Appliances)

Pure Sinewave

95%

230VAC ± 10%

24 VDC

27 VDC 27.4 VDC

21 VDC

20 VDC

30 VDC

10A or 20A (Selectable)

IPS5000

5000VA/ 4200W

180-270 VAC

(Normal Range)

100-270 VAC

(Wide Range)

90%

48 VDC

53.6 VDC

42 VDC

40 VDC

58 VDC

20A or 35A (Selectable)

Overload and short circuit protection Not Applicable

Protection against misconnection and improper usage

Not Applicable

Line Mode, Line mode with charging battery, battery mode, off-mode charging, fault mode,

Low Battery, Overload, Power limitation,

Fan lock and Overcharge

AC Mode, Inverter Mode, Charger Mode

Load Level, Fault

Sounding every second

4.5

289 x 290 x 127

4.8

0 to 90% Relative Humidity (Non-condensing)

0°C to 50°C

-15°C to 70°C

Sounding every 2 seconds

Sounding every 0.5 second

Continuously sounding

268 x 330 x 76

4.9

330 x 268 x 76

5

5 to 95% (Non-condensing)

0°C to 45°C

-15°C to 60°C

350 x 110 x 407

9

*All specifications, designs and contents are subject to change without prior notice.

73

Auto Voltage Regulator

PROLiNK PVR

PVR Series

PROLiNK PVR Series is designed to automatically maintain a constant voltage level to protect sensitive electronics from brownouts, under voltages and over voltages. The PROLiNK PVR takes efficiency to a new level with its microprocessor controller tailored to allow extremely fast response for detecting and regulating voltage. Equipped with a time-delay function, the PVR is able to protect connected devices from power-back surges.

This high performance AVR comes with the versatility to fit all kinds of equipment with its wide input voltage range selection.

The PROLiNK PVR provides you with the optimum solution for your everyday needs.

• Microprocessor control

• Accepts wide input voltage range

• Time delay function eliminates transient that can affect

connected equipment

• Provides stable output voltage

• Provides under-voltage, over-voltage, over-heat and over

current protection

• High voltage cut off

Full Specifications

MODELS

Capacity

INPUT

Norminal Voltage

Voltage Range

Nominal Frequency

VA

OUTPUT

Voltage

Output Voltage Regulation

EFFICIENCY

Normal Mode

AVR Mode

PROTECTION

Delay Time

Full Protection

INDICATION

LED Display

LCD/Meter Display

PHYSICAL

Dimension, D X W X H (mm)

Net Weight (kgs)

ENVIRONMENT

Operating Temperature

Humidity

PVR500 D/M

500

PVR1000 D/M

1000

PVR2000 D/M

2000

220VAC

110VAC ~ 270VAC or 140VAC ~ 260VAC (selectable)

50 or 60Hz (Auto Sensing)

220VAC

± 10%

95%

92%

10 seconds

Over-voltage, under-Voltage, over-heat and over current Protection

Normal indicator, AVR indicator, delay time setting and Fault indicator

Input and Output voltage

PVR3000 D/M

3000

2.4

196.8 x 110 x 123.5

3.91

233.6 x 134 x 181

6.55

0

°

C - +40

°

C

0-90% relative Humidity (Non-condensing)

297.1 x 150 x 199

8.56

D = LCD display, M = Analogue display

*All specifications, designs and contents are subject to change without prior notice.

74

PROLiNK DC UPS

PDC Series - DC UPS

PROLiNK PDC series is a compact DC UPS system that converts AC to DC power. This device comes with a built-in dynamic voltage regulator that ensures the voltage from the power source is kept within acceptable limits. The PDC

Series is ideal for devices such as switches, hubs, routers and modems. With the built-in DC start function, the PDC

UPS can be started up with the absence of AC power. The

PROLiNK PDC series is definitely your number one choice for back-up power solution.

• Dual DC Outputs

• Microprocessor control guarantees high reliability

• Compact size for standing and mounting flexibility

• Supports solar powered devices and communication applications

• Auto restart while AC is recovering

• Off-mode charging

• Overload protection and short circuit protection

Full Specifications

MODELS

INPUT

Nominal Voltage

V o lta g e Ran g e

Frenquency

OUTPUT

Nominal Voltage

Output Voltage Regulation

Transfer Time

EFFICIENCY

AC Mode

Battery Mode

BATTERY

Battery Type

Charging Voltage

Charging Current

Typical Recharge Time

INDICATION

AC Mode

Battery Mode

Low Battery

Fault

PROTECTION

Full Protection

PHYSICAL

Di m en s i o n (mm) D x W × H @ Vertically Stand

Net W ei g ht (kgs)

ENVIRONMENT

Humidity

Temperature

PDC50

220VAC

160 - 280VAC

50 or 60Hz

12VDC

10V ~ 13.7V

0ms

>75% at Nominal Voltage (Battery Fully Charged)

>95% at Full Load

12V9AH x 1

13.7V ±0.25V

2.8A or 2.3A at Nominal Voltage without Load

Back to 90% capacity in 4-6 hours

Green Lighting

Yellow Lighting

Yellow Flashing

Red Lighting

Short Circuit and Overload Protection

228 x 82.5 x 207

3

0 ~ 90%

0°C ~ 40°C

DC UPS

75

DC UPS

PROLiNK DC BACK-UP UNIT

PBU Series

PROLiNK Back-Up (PBU) unit is a user-friendly lighting power supply unit that is suitable for home/ outdoor settings. This portable-sized unit is compact in size but it comes with a powerful 230VDC output that can be used for powering up energy saving light bulbs of up to 11W. The unit is designed with the flexibility to be powered by regular AC supply or via the supplied battery. The PROLiNK PBU unit’s potential is best realized for users that commonly experience power blackouts.

The unit is also brilliantly designed to allow a range of flexible display methods: vertically or horizontally standing, wall-mounted or as a portable display; as well as a choice to select between a B22 or E27 light bulb terminal. The PROLiNK Back-Up unit is the perfect cost-effective solution for your lighting requirements.

• DC-powered outlets for 11watts energy saving bulb

• 3 sets DC-powered outlets for energy saving light bulbs

• Off mode charging

• Overload protection in battery mode and short circuit protection

• LED indication

• 3-step charging design for extended battery life

Backup Time Table:

11W Safe Energy Light Bulb x 1 no

11W Safe energy light bulb x 2 nos

11W Safe energy light bulb x 3 nos

11W Safe energy light bulb x 4 nos

Full Specifications

MODELS

Rated Power

INPUT

Voltage

Voltage Range

OUTPUT

Output Voltage (AC Mode)

2-pin Sockets

BATTERY & CHARGER

Battery Type and Number

Battery Voltage

Output Voltage (Batt. Mode)

Waveform

Typical Recharge Time

INDICATORS

LED Display

PROTECTION

Full Protection

PHYSICAL

Dimension, D X W X H (mm)

Net Weight (kgs)

OPERATING ENVIRONMENT

Operating Temperature

Humidity

PBU5022 / PBU5027

50VA

220VAC

100VAC – 300VAC

230VDC

160-230VDC ± 10%

DC Output

230 VAC

12V 7Ah x 1

12VDC

Back to 90% capacity in 6 hours

AC Mode – Green Lighting

Battery Mode – Yellow Lighting

Output Short-circuited – Red Lighting

Charging Mode – Green flashing every 2 seconds

Low Battery – Yellow flashing every second

Overload – Red Flashing every 0.5 seconds

Red LED staying on for one second and off for 4 seconds

Overload Protection and short circuit protection

209 x 87 x 200

2.7

0

°

C to 40

°

C

0-90% relative Humidity (Non-condensing)

Up to 6 hours

Up to 3 hours

Up to 2 hours

Up to 1.5 hours

B22 Connector E27 Connector

PBU5022 = for B22 light bulb terminal.

PBU5027 = for E27 light bulb terminal.

*All specifications, designs and contents are subject to change without prior notice.

76

Solar

PROLiNK Solar Inverter

Zonne Series

PROLiNK Zonne 450 unit is a compact and user-friendly solar power unit that is suitable for use in home like settings. The Zonne series is designed with a built-in charger controller that facilitates proper charging of the battery; enhancing the overall lifespan of the battery.

Also, the PROLiNK Portable Solar unit comes with the flexibility to be powered by regular AC supply, solar

PV modules or via the supplied battery. The Zonne unit is capable of supporting up to one block of

100AH battery, giving users ample amount of power supply to operate multiple home appliances.

• 450W Inverter

• PWM technology solar charger

• Off mode charging

• Overload protection and short circuit protection in battery mode

• Universal socket

Home Appliance

External Battery

Utility Supply

Solar Panel

Backup Time Table:

Battery Type Effective Suns h ine Duration

1 b l o c k x 12V40 AH 5 h o ur s

Application / Load

2 x ener gy s avin g li g ht bulb

1 x ener gy s avin g li g ht bulb

1 x Fan

2 x ener gy s avin g li g ht bulb

1x Fan

Battery back-up

8 h o ur s per day

6 h o ur s per day

4 h o ur s per day

1 b l

Battery Type

o c k x 12V 65AH

Effective Suns

5 h o

h ine Duration

ur s

Application / Load

2 x ener gy s avin g li g ht bulb

1 x ener gy s avin g li g ht bulb

1 x Fan

2 x ener gy s avin g li g ht bulb

1x Fan

All specifications, designs and contents are subjected to changes without prior notice.

The above Battery back-up calculation is based on estimated values and will be subject to change (Variables include; load consumption, sunshine duration and PV panel peak power supply).

Battery back-up

10 h o ur s per day

8 h o ur s per day

6 h o ur s per day

77

Full Specifications

MODELS

Rated Power

AC INPUT

Voltage

V o lta g e Ran g e

OUTPUT

Output Voltage

Voltage Regulation (Batt.Mode)

Waveform

BATTERY & CHARGER

Battery Voltage

Floating Voltage

Maximum Charge Current

PROTECTION

Full Protection

INDICATORS

Line Mode

Battery Mode

Low Battery

Shutdown Mode

Charging Mode at Power On

Charging Mode at Power Off

Overload

Overcharging

Fault

SOLAR CHARGER

Charging Current

System Voltage

PHYSICAL

Di m en s i o n (mm) D x W × H

Net W ei g ht (kgs)

Zonne 450

450W

220/ 230/ 240VAC

162 - 290VAC (UPS Mode)

90 or 280VAC (INV. Mode)

230VAC

±10%

Simulated Sinewave

12VDC

13.4VDC ± 1.5%

10Amp

Overload and Short Circuit Protection

Green Lighting

Yellow Lighting

Yellow Flashing every 2 seconds

Yellow Flashing every 5 seconds

Green Flashing every 2 seconds

Green Flashing every 5 seconds

Red Flashing for 0.5sec. every seconds

Red Flashing every 5 seconds

Red lighting

10Amp

12VDC

293 x 231.5 x 82.5

2.35

Solar

*All specifications, designs and contents are subjected to changes without prior notice.

*Above mentioned Back-up timetable is for reference purpose only.

78

Solar

PROLiNK PORTABLE SOLAR

PPS Series

PROLiNK Portable Solar (PPS) unit is a compact and user-friendly lighting solar power supply unit that is suitable for use in home / outdoor settings. This portable-sized unit is compact in size but it can be used for powering up energy saving light bulbs of up to 11W. In addition, there is also a 5VDC USB port for charging your mobile devices and a 12VDC round pin connector for equipment such as DC fans.

PROLiNK Portable Solar unit provides you the option of doubling up your backup duration by adding another block of 7AH battery on top of the existing supplied battery. The PPS is the perfect device for users living in rural locations where the power supply is often inconsistent and unstable.

PPS70M

PPS70

• DC-powered outlets for 11watts energy

saving bulb

• 3 x 5V USB charging ports for mobile phones

• PWM technology solar charger

• Off mode charging

• Overload and short circuit protection in

battery mode

• 12VDC round pin connector output for 12VDC

equipment

• Option for lamp holder with 2m cable

• Option for 24W Solar PV panel

3 Outlet For Energy Saving Bulb

Mobile Phone

Solar

PPS70M

• 11W DC UPS

• Built-in 3 watts LED.

• 12VDC-powered outlets for 11watts energy saving bulb

• 1 x 5V USB charging ports for mobile phones

• PWM technology solar charger

• Off mode charging

• Overload and short circuit protection

in battery mode

• Lamp holder with 5m cable

• 16W Solar PV panel

1 Outlet For 3watt LED Light Bulb

Mobile Phone

PPS70

12VDC Supply

External Battery

Utility Supply

Solar

79

Full Specifications

MODELS

PV INPUT

Maximum PV Array Open Circuit Voltage

Maximum Solar Charging Current

AC INPUT

Voltage

Frequency Range

OUTPUT

2-pin Sockets

Output Voltage (AC Mode)

Output Voltage (Batt. Mode)

Waveform

DC Connector

USB Charger

LED LIGHT (Built-in)

Power

BATTERY & CHARGER

Battery Type and Number

Battery Voltage

Typical Recharge Time

PROTECTION

Full Protection

PHYSICAL

Dimension, D X W X H (mm)

Net Weight (kgs)

OPERATING ENVIRONMENT

Operating Temperature

Humidity

PPS70 PPS70M

30VDC

2A 1A

230VAC

50 Hz or 60 Hz (auto sensing)

230VDC

160-230VDC ± 10%

12VDC 2A x 1 pc

5VDC 1A x 3 pcs

DC Output

Not Applicable

Not Applicable

12V 7Ah x 1 (Optional external battery)

Back to 90% capacity in 8 hours

12VDC

Overload Protection and short circuit protection

Not Applicable

12VDC

Not Applicable

5VDC 1A x 1 pc

3W

Not Applicable

Back to 90% capacity in 4-6 hours

229 x 110 x 123.5

3.8

0

°

C to 40

°

C

0-90% relative Humidity (Non-condensing)

Solar

*All specifications, designs and contents are subject to change without prior notice.

80

Solar

PROLiNK Solar System

PCC Series

PCC Series is a Solar Installation System that combines the benefits of both the Maximum Power Point Tracking (MPPT) technology and DSP controller system. The MPPT enhances the

PCC Series by transferring the most power from its PV solar modules and the DSP controller system provides a high level of computational performance for real-time signal processing in the solar power inverters. This allows your solar panels to operate at their optimum power output voltage, thereby increasing the level of efficiency to 97.7% and at the same time lowering power loss.

Users can start generating green energy for their home applications by integrating the PCC Series with solar panels, inverter and external battery packs. Batteries are compatible with up to 4 types; sealed lead acid, vented, gel and NiCad.

• Intelligent Maximum Power Point Tracking technology

• Built-in DSP controller with high performance

• Automatic battery voltage detection

• Multi-functional LCD

• Reverse polarity protection for solar panel and battery

• Overcharge and overload protection

• Suitable for battery types such as sealed lead acid, vented Gel and NiCd

• Standard RJ45 port or optional RS-485 communication port for remote monitoring

PCC300 Solar Panel

External Battery Packs

Home Appliances

*All specifications, designs and contents are subject to change without prior notice.

Inverter

81

Solar

Full Specifications

MODELS

INPUT

MPPT Range @ Operating Voltage

Maximum PV Array Open Circuit Voltage

Maximum Array

Maximum Current

OUTPUT

Nominal Battery Voltage

Connected Battery Type

Maximum Charging Current

Ripple Voltage

Maximum Efficiency

Stanby Power Consumption

Charging Method

PROTECTIONS

Overload Protection

Overcharge Protection

Polarity Reversal Protection @ Solar Cell & Battery

INDICATION

LCD Panel

LED Display

PHYSICAL

Dimension (mm) D x W × H

Net Weight (kgs)

Connector

Type of Mechanical Protection

ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

Altitude

PCC300 PCC600

15 ~ 33V @ 12V

50V

Maximum PV Array Power

18A

30 ~ 66V @ 24V

75V

12V

1W

24V

Sealed Lead Acid, Vented, Gel, MiCd Battery

25A

<±1V

98%

2W

Three Stages: Bulk, Absorption & Floating

12V

PCC3000

800W

60 VDC ~ 115 VDC

145VDC

1600W

50A

3200W

24V

60A

98%

48V

>110%: Audiable Alarm Yes

Yes

Yes

LCD Panel indicating Solar Power, Output Power, Battery Voltage, Charging Current, and Fault Conditions

Three indicators: Solar, Charging & Load Status

Three indiators: Solar, Battery &

Wiring Fault

135 x 170 x 57.5

0.92

IP43

220 x 170 x 57.5

1.85

Input or Output Terminal Block

315 x 165 x 128

4.5

IP31

5~95% Relative Humidity

(Non-condensing)

0~90% Relative Humidity (Non-condensing)

-20°C to 55°C

-40°C to 75°C

0 ~ 3000m

*All specifications, designs and contents are subject to change without prior notice.

82

PROLiNK Solar System

PSI Hybrid

HYBRID Series

PSI Hybrid Series is a hybrid inverter that combines the solar power system, AC utility and battery power source to supply continuous power to your home / office applications. This device is most suitable for rural areas where electrical supply is unstable and inconsistent. The PSI Hybrid series comes with a grid-tie operation mode where surplus electricity can be fed back to the main grid, making it an economic and cost-effective power option. If gaining access on the grid is not possible, the PSI Hybrid Series also comes with an off-grid operation mode where power can be stored directly to the back-up battery; making the Hybrid series one of most versatile solar inverters in the market.

• Works as an On-grid inverter during the day

• Works as an Off-grid inverter during the night or rainy conditions

• Pure sine wave output

• Multiple operations: Grid tie, Off grid, and grid-tie with backup

• Built-in MPPT solar charger

• LCD display panel for comprehensive information

Full Specifications

MODELS

Phase

PV INPUT

Maximum DC Voltage

MPP Voltage Range

DC Nominal Voltage

Start-up Voltage / Initial Feeding Voltage

Maximum Input Current

GRID/ UTILITY INPUT (AC)

Phase

Nominal AC Voltage/ Range

Acceptable Voltage Range

Maximum Input Current

GRID OUTPUT (AC)

Nominal AC Voltage/ Range

AC Grid Frequency Range

Nominal Output Current

Power Factor

BATTERY MODE OUTPUT (AC)

Output Voltage

Output Frequency

Output Waveform

Efficiency (DC to AC)

BATTERY & CHARGE

Nominal DC Voltage

Maximum Charging Current

PHYSICAL

Dimension (mm) D x W × H

Net Weight (kgs)

INTERFACE

Communication Port

Intelligent Slot

ENVIRONMENT

Operation Humidity

Operating Temperature

Altitude

HYBRID 3K

13A

Single Phase

500VDC

250 VDC ~ 450VDC

360VDC

116VDC / 150VDC

HYBRID PRO 3K

18A

Single Phase

208/ 220/ 230/ 240VAC

170 ~ 280VAC

30A

220VAC / 184~265VAC

47.5 ~ 50.2Hz

13A

>0.99

202/ 208/ 220/ 230/ 240VAC

50Hz / 60Hz (auto sensing)

Pure Sinewave

93%

48VDC

25A

107 x 438 x 480

15.5

RS-232 / USB

Optional SNMP, Modbus and AS-400 cards available

0°C~40°C

0~90% (Non-condensing)

0 ~ 1000m

HYBRID 10K

Three Phase

900VDC

400 ~ 800VDC

720VDC

320VDC / 350VDC

18.6A x 2

Three Phase

400VAC

170 - 280VAC

25A

400VAC / 320~460VAC

14.5A

-

400VAC

96%

200A

622 x 500 x 167.5

45

-10°C to 55°C

Solar

** Upcoming product. This category is for products to be released in the future. Please contact PROLiNK for more details.

*All specifications, designs and contents are subject to change without prior notice.

83

Solar

PROLiNK Solar System

PSI On-Grid

AMNETZ Series

PSI On-Grid Series is a grid-connected photovoltaic power system that is designed to operate at its optimum power output voltage even under unfavourable weather conditions. This device uses high quality Amnetz

PV inverters to convert DC to AC power at a maximum conversion efficiency of up to 96%. On top of that, this user-friendly device is bundled with a monitoring software kit that allows users to observe from a graphical overview of the module voltage/current and temperature.

• 1.5KW/2KW/3KW/5KW & 3-phase 10KW on-grid PV inverter

• Advanced DSP control technology delivers accurate data

• Smart MPPT technology enhances overall efficiency

• Modular design for easy maintenance

• Industrial-grade components used for robust operation

• Up to 15 years of data logging

• Ingress Protection rated 65 (good for any type of environmental conditions)

• Comprehensive LCD monitor for easy-reading

• Free monitoring software

Full Specifications

MODELS

Phase

INPUT (DC)

Maximum DC Voltage

MPP Voltage Range

Nominal DC Voltage

Start-up Voltage/ Initial Feeding Voltage

Maximum Input Current/ Per String

OUTPUT (AC)

Nominal AC Voltage

AC Voltage Range

AC Grid Frequency

Nominal Output Current

Power Factor

EFFICIENCY

Maximum Efficiency

PROTECTION

DC Reverse-Polarity Protection

Ground Fault Monitoring

Grid Monitoring

AC Short Circuit Protection

PHYSICAL

Dimension (mm) D x W × H

Net Weight (kgs)

INTERFACE

Intelligent Slot

ENVIRONMENT

Humidity

Operating Temperature

Altitude

COMPLIANCE

Standard

AMNETZ 1500

450VDC

150 ~ 400VDC

500VDC

200 ~ 450VDC

360VDC

120/ 150VDC

11A

230VAC 230VAC

6.6A

96.0%

136.5 x 268.5 x 410

11.5

AMNETZ 2000 AMNETZ 3000

1 Phase-In 1 Phase-Out

8.7A

500VDC

13A

230VAC

184 - 264VAC*

50Hz / 60Hz

13A

>0.99

AMNETZ 5000

150 ~ 500VDC

370VDC

125/ 150VDC

Yes

Yes

Yes

Yes

160 x 270 x 450

15

97%

500VDC

2 x 15A

230VAC

20A

182 x 308 x 515

20

AMNETZ 10K**

3 Phase-In 3 Phase-Out

900VDC

320 ~ 800VDC

600VDC

250/ 250VDC

2 x 17A / 17A

3/ N/ PE, 230/ 400VAC

-20% ~ +15%*

14.5A

98.0%

171.2 x 503.5 x 653.3

40

USB Card/ Optional: SNMP, RS-232, AS-400 and GPRS Cards

0 ~ 100% Relative Humidity (nNon-condensing)

-25 ~ 60°C -25 ~ 60°C

0 ~ 1000m (Power derating 1% every 100m when altitude is over 1000m)

CE, VDE-AR-N 4105, VDE-0126-1-1, IEC62109

*All specifications, designs and contents are subject to change without prior notice.

**Upcoming product. This category is for products to be released in the future. Please contact PROLiNK for more details.

84

Solar

PROLiNK Solar System

PSI Off-Grid

HAUS Series

The PSI HAUS Series is a wall-mounted off grid PV inverter that employs a PWM technology. It is best used in remote locations without utility services. The device is able to supply generous amount of electrical power to the load via PV modules, battery sources and AC powered sources. The HAUS Series is able to fully utilize the energy from the sun to convert stable electrical power to any home / commercial applications. In the event where it is inapplicable to draw power from PV modules and battery sources, an AC power source can still be supplied by a generator to get you through a rainy day.

• Pure sine wave inverter

• Selectable input voltage range

• Selectable charging current

• Utility or Solar input priority configuration via LCD setting

• Generator compatible

• Auto restart while AC is recovering

• Overload and short circuit protection

• Cold start function

• Optional N+1 parallel redundancy

Full Specifications

MODELS

Rated Power

INPUT

Voltage

Selectable Voltage Range

Frequency Range

OUTPUT

AC Voltage Regulation (Batt. Mode)

Surge Power

Efficiency (Peak)

Transfer Time

Waveform

BATTERY

Battery Voltage

Floating Charge Voltage

Overcharge Protection

Maximum Charge Current

SOLAR CHARGER (OPTION)

Charging Current

Maximum PV Array Open Circuit Voltage

PHYSICAL

Dimension, D X W X H (mm)

Net Weight (kgs)

OPERATING ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

HAUS 1000

1kVA / 800W

2000VA

12VDC

13.5VDC

15VDC

10A or 20A

30VDC

95 x 240 x 316

5.0

HAUS 2000

2kVA / 1.6kW

HAUS 3000

3kVA / 2.4kW

HAUS 4000

4kVA / 3.2kW

230VAC

170 - 280VAC (For Personal Computers)

90 - 280VAC (For Home Applicances)

50 Hz / 60 Hz (Auto Sensing)

HAUS 5000

5kVA / 4kW

4000VA

230VAC ± 5 %

6000VA

93%

10 ms (For Personal Computers)

Pure sine wave

8000VA

24VDC

27VDC

30VDC

20A or 30A

48VDC

54VDC

60VDC

20A or 30A

10000VA

50A

60VDC 90VDC

6.4

100 x 272 x 355

6.9

5% to 95% Relative Humidity (Non-condensing)

0°C to 55°C

-15°C to 60°C

120 x 295 x 468

9.8

*All specifications, designs and contents are subject to change without prior notice.

85

PROLiNK Solar System

PSI Off-Grid

HAUS MPPT Series

Solar

HAUS

1KM/ 1KMHDC/ 2KM/ 3KM/ 3KMHDC

HAUS

4KMHDC/ 5KMHDC

HAUS PLUS

2KM/ 2KMHDC/

3KM/ 3KMHDC

The PSI HAUS MPPT Series is a wall-mounted off grid PV inverter that employs a MPPT technology. It is best used in remote locations without utility services. The device is able to supply generous amount of electrical power to the load via

PV modules, battery sources and AC powered sources. The HAUS MPPT Series is able to fully utilize the energy from the sun to convert stable electrical power to any home / commercial applications. In the event where it is in applicable to draw power from PV modules and battery sources, an AC power source can still be supplied by a generator to get you through a rainy day.

• Pure sine wave inverter

• Built-in MPPT solar charge controller

• Selectable input voltage range for home appliances and personal computers

• Selectable charging current based on applications

• Configurable AC/Solar input priority via LCD setting

• Compatible to mains voltage or generator power

• Auto restart while AC is recovering

• Overload and short circuit protection

• Smart battery charger design for optimized battery performance

• Cold start function

• Parallel operation with up to 6 units only available for 4KVA/5KVA

• Optional Remote Control Panel available

86

Solar

Full Specifications

MODELS

Capacity

INPUT

Voltage

Selectable Voltage Range

Frequency Range

OUTPUT

AC Voltage Regulation (Batt. Mode)

Surge Power

Efficiency (Peak)

Transfer Time

Waveform

BATTERY & AC CHARGER

Battery Voltage

Floating Charge Voltage

Overcharge Protection

SOLAR CHARGER & AC CHARGER

Maximum PV Array Power

MPPT Range @ Operating Voltage

Maximum PV Array Open Circuit Voltage

Maximum Solar Charge Current

Maximum AC Charge Current

Maximum Charge Current

Maximum Efficiency

Standby Power Consumption

PHYSICAL

Dimension, D x W x H (mm)

Net Weight (kgs)

ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

HAUS

1KM

HAUS

1KMHDC

HAUS

2KM

HAUS

3KM

HAUS

3KMHDC

HAUS

4KMHDC

1000VA/ 800W 1000VA/ 800W 2000VA/ 1600W 3000VA/ 2400W 3000VA/ 2400W 4000VA/ 3200W

HAUS

5KMHDC

5000VA/ 4000W

230 VAC

170-280 VAC (For Personal Computers)

90-280 VAC (For Home Appliances)

50/60 Hz (Auto sensing)

24 VDC

27 VDC

31 VDC

2000 VA

90% - 93%

48 VDC

54 VDC

62 VDC

4000 VA

230VAC ± 5%

6000 VA 8000 VA

93%

10 ms (For Personal Computers); 20 ms (For Home Appliances)

Pure sine wave

24 VDC

27 VDC

31 VDC 62 VDC

48 VDC

54 VDC

60 VDC

10000 VA

600 W

30VDC ~ 66VDC

75 VDC

25A

20A

25A

900 W

60VDC ~ 88VDC

6.8

102 VDC

18A

15A

18A

600 W

30VDC ~ 66VDC

75 VDC

25A

30A

30A

900 W

60VDC ~ 88VDC

102 VDC

18A

15A

18A

AC charger and solar charger can’t work at the same time.

100 x 272 x 355

7.0

98%

2 W

7.4

5% to 95% Relative Humidity(Non-condensing)

0°C - 55°C

-15°C - 60°C

3000 W

60VDC ~115VDC

145 VDC

60A

60A

120A

120A

120 x 295 x 468

11

MODELS

Inverter Power

Pmax. Generated From Solar Charger

Best Panel Configuration

HAUS

1KM

800W

25Amp, 600W

500Wp

(250Wp x 2pcs)

HAUS

1KMHDC

HAUS

2KM

HAUS

3KM

HAUS

3KMHDC

HAUS

4KMHDC

HAUS

5KMHDC

1000W 1600W 2400W 2400W 3200W 4000W

20Amp, 900W 25Amp, 600W 25Amp, 600W 20Amp, 900W 60Amp, 3000W 60Amp, 3000W

1000Wp

(250Wp x 4pcs)

500Wp

(250Wp x 2pcs)

500Wp

(250Wp x 2pcs)

1500Wp

(250Wp x 6pcs)

3000Wp

(250Wp x 12pcs)

3000Wp

(250Wp x 12pcs)

87

Solar

MODELS

Capacity

INPUT

Voltage

Selectable Voltage Range

Frequency Range

OUTPUT

AC Voltage Regulation (Batt. Mode)

Surge Power

Efficiency (Peak)

Transfer Time

Waveform

BATTERY & AC CHARGER

Battery Voltage

Floating Charge Voltage

Overcharge Protection

SOLAR CHARGER & AC CHARGER

Maximum PV Array Power

MPPT Range @ Operating Voltage

Maximum PV Array Open Circuit Voltage

Maximum Solar Charge Current

Maximum AC Charge Current

Maximum Efficiency

Standby Power Consumption

PHYSICAL

Dimension, D x W x H (mm)

Net Weight (kgs)

ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

HAUS PLUS

2KM

2000VA/ 800W

HAUS PLUS

2KMHDC

2000VA/ 1000W

HAUS PLUS

3KM

2000VA/ 1600W

HAUS PLUS

3KMHDC

3000VA/ 2400W

120 VAC or 230 VAC

95-140 or 170-280 VAC (For Personal Computers)

65-140 or 90-280 VAC (For Home Appliances)

230 VAC

170-280 VAC (For Personal Computers)

90-280 VAC (For Home Appliances)

50/60 Hz (Auto sensing)

110/120 VAC ± 5% (User Selectable) or 230VAC ± 5%

4000 VA

90% - 93%

10 ms (For Personal Computers); 20 ms (For Home Appliances)

Pure sine wave

230VAC ± 5%

6000 VA

24 VDC

27 VDC

31 VDC

1500 W

30~115 VDC or 60~115 VDC

48 VDC

54 VDC

62 VDC

24 VDC

27 VDC

31 VDC

20A or 20A / 30A

3000 W

60~115 VDC

10A or 10A / 15A

1500 W

30~115 VDC or 60~115 VDC

145 VDC

60A

20A 30A

98%

2 W

140 x 295 x 479

11.5

48 VDC

54 VDC

62 VDC

3000 W

60~115VDC

10A / 15A

5% to 95% Relative Humidity(Non-condensing)

0°C - 55°C

-15°C - 60°C

MODELS

Inverter Power

Pmax. Generated From Solar Charger

Best Panel Configuration

HAUS PLUS

2KM

60Amp, 1500W

HAUS PLUS

2KMHDC

1600W

60Amp, 3000W

1500Wp (250Wp x 6pcs)

HAUS PLUS

3KM

60Amp, 1500W

HAUS PLUS

3KMHDC

1600W

60Amp, 3000W

3000Wp (250Wp x 12pcs)

There are charging current selection only available for 230VAC system.

*All specifications, designs and contents are subject to change without prior notice.

88

Software & Accessories

PROLiNK Online UPS Accessories

External Battery Charger (PEC)

PROLiNK External Charger (PEC) is an additional external smart charger for PROLiNK Online UPS system. It designed with isolation structure and operated in parallel with several units for charging capability expandable.

• Input PFC control

• Back feed protection

• Three-stage smart charging

• Short circuit and over voltage protection

• Maximum current restriction

• Redundancy operation

With PROLiNK External Battery Cabinet

With External Battery Bank

UPS Expandable

Charger units

Full Specifications

MODELS

INPUT

Nominal Voltage

Voltage Range

Nominal Frequency

Input Current (max) @ full load

OUTPUT

Nominal Voltage

Output Current (max)

Floating Charging Voltage

EFFICIENCY

AC Mode

PROTECTION

Full Protection

INDICATION

LED Display

PHYSICAL

Dimension (mm) D x W × H

Net Weight (kgs)

ENVIRONMENT

Relative Humidity

Operation Temperature

Noise Level

IP Class

Expandable PROLiNK battery cabinets

UPS Expandable

Charger units

Expandable battery units

PEC20-24

24VDC

20A

27.3VADC

PEC15-36 PEC15-48

230VAC

170~280VAC

50/60Hz

8A

PEC12-72

36VDC

41.1VDC

48VDC

15A

54.8VDC

72VDC

12A

82.2VDC

Up to 85%

PEC10-96

96VDC

10A

109.6VDC

PEC24-240

110~300VAC

60A

240VDC

24A

273.6VDC

Over-voltage, Thermal control, Over current, Short circuit, Reversal polarity

Charger ON – Green LED

Boost Charging Status – Yellow LED

Floating Charging Status – Green LED

Low Charging Voltage – Red LED

300 x 177 x 90

3.1

<95% (Non-condensing)

0 ~ 40°C

<50dB

IP20

N/A

570 x 250 x 215

14

All specifications, designs and contents are subjected to changes without prior notice.

89

PROLiNK Online UPS Accessories

Automatic Transfer Switch

Software & Accessories

PROLiNK Automatic Transfer Switch (ATS) is designed to allow two independent power inputs to supply power to the connected load. In the event where the primary power source fails, the ATS automatically transfers the backup connection to the secondary power source without any interruption, providing seamless electrical power and the highest protection for your equipment. The PROLiNK ATS is also designed to automatically transfer the connection back to the primary power source once it has detected restored power.

• 16A maximum input current

• Powered by two separate independent power sources

• Dual power supply for redundancy

• Provides seamless power switch for IT equipment

• Preferred source selection on front panel

• 19” rack-mount design (1U)

• Built-in USB and RS-232 interface

Full Specifications

MODELS

Current Rating

INPUT

Input Voltage

Acceptable Input Voltage

Input Frequency

OUTPUT

Output Voltage

Maximum Output Current

CONNECTION

Input

Output

Communication

Transfer Time

PHYSICAL

Dimension (mm) D x W x H

Net Weight (kgs)

ENVIRONMENT

Operating Temperature

ATS16-R

16A

230VAC

207 ~ 253VAC

50Hz/ 60Hz

230VAC

10A for IEC-C13 Outlets; 16A for IEC-C19 Outlets

2xIEC-C20 Inlets

8xIEC-C13; 1xIEC-C19

USB/ RS-232

9 ~ 12ms (Typical)

310 x 430 x 44

3.65

20 ~ 95% Relative Humidity @ -5°C ~ 45°C (Non-condensing)

*All specifications, designs and contents are subject to change without prior notice.

90

Software & Accessories

PROLiNK Online UPS Accessories

PDU & Maintenance

Bypass Switch

The PDU & Maintenance Bypass Switch is an external power distribution unit used in conjunction with UPS systems or large-scale voltage regulators. This device enables the UPS to be isolated for scheduled maintenance or replacement without interrupting the power to the load. Designed with a master-controller concept, the PROLiNK PDU is able to handle both the maintenance bypass function and power saving function effectively.

• 16A for 208/220/230/240 VAC

• Provides continuous power to connecting equipment during UPS maintenance

• Easy operation with simple rotary switch and indicators

• Master-slave function for energy saving

• Multiple sockets to support more devices

• Choose between a rack or tower design to fit into any working environment

• Simple installation with plug-and-play socket type

• Suitable for all UPSs up to 3kVA

IEC UK Schuko NEMA

Full Specifications

MODELS

Current Rating

Voltage Rating

Master/ Slave Function

CONNECTION

Input

AC Power

UPS Input

UPS Output

IEC

Output

Schuko

UK

NEMA

PHYSICAL

Dimension (mm)

D x W x H

Net Weight (kgs)

ENVIRONMENT

Operating Temperature

IEC

Schuko

UK

NEMA

MBS16-R (I/U/S/N) (*)

16A

208/ 220/ 230/ 240/VAC

Yes. When power consumption in Master Outlet is lower than 20W (±5W), it will shut off the power for slave outlets.

MBS16-T (I/U/S/N) (*)

NA

1 x IEC (16A) Connector & 1 x Customized Plug Cable

1 x IEC (16A) Connector & 1 x Cable (16A ~ 10A IEC Cable for 1k/ 2k, 16A ~ 16A IEC cable for 3k)

5 x IEC 10A Socket + 1 x IEC 16A Socket (with 2 circuit breakers) 8 x IEC 10A Socket + 1 x IEC 16A Socket (with 2 circuit breakers)

4 x Schuko 16A Sockets

4 x UK 13A Sockets

5 x NEMA 20A Sockets 6 x NEMA 20A Sockets

80 x 438 x 50

80 x 438 x 60

80 x 438 x 50

1.50

180 x 160 x 50

180 x 200 x 50

180 x 160 x 50

1.30

20 ~ 95% Relative Humidity @ -0°C ~ 40°C (Non-condensing)

I = IEC, U = UK, S = EU, N = Nema

*All specifications, designs and contents are subject to change without prior notice.

91

PROLiNK Online UPS Accessories

SNMP Card

Integrated with our latest ViewPower software, the SNMP manager operates as an enhanced communication solution for your UPS system. It allows you to remotely manage and monitor your UPS system via internet connectivity. Once connected to the internet, the ViewPower software provides you access to remotely program or even shut down your UPS system.

• Allows control and monitoring of multiple UPSs through RJ-45 network connection

• Real-time dynamic graphs reflecting UPS data (Voltage, frequency, load level and

battery level)

• Warning notifications via audible alarm, broadcast, mobile messenger,

e-mail and SNMP traps

• Historical data logging

• One click easy firmware upgrade

• Password security protection and remote access management

• Supports optional environmental monitoring detector for temperature, humidity and smoke

Modbus Card

The ModBus Card provides UPS and PV inverter systems with the functionality to communicate with PCs through the ModBus Protocol.

• Adopts ModBus RTU Protocol

• Comes with functions that includes read Holding Registers and write Registers

• RS232 and RS485 interface

AS-400 Card

The AS-400 communication card is designed with a high quality contact closure board that accurately converts UPS signals into dry contacts for users to monitor UPS events that are most concerned to them. By setting the jumper, the AS-400 communication card allows you to select various status indicators such as; UPS alarm, UPS failure, Bypass, Low Battery etc.

• Capable of selecting the status of the dry-contact signal by setting the jumper to meet

different application requirements

• Suitable applications include; IBM Server, Personal PC & Workstations equipments,

Auto-controlled industrial equipment & communication applications

Rack Mount Slider

The PROLiNK Rack-mount slider kit offers you the best solution to install a PROLiNK UPS system into a 19” server rack enclosure. This kit comes with a pair of heavy duty sliders that are attached with quality assured ball bearings to ensure that your server can slide effortlessly into and out of the rack. Furthermore, the PROLiNK Rack-mount slider kit includes a superior quality front and rear mounting brackets to withstand the weight of your UPS.

• Simple and easy installation

• Suitable for PROLiNK Rack Mount Online UPS system

• Slider length available in 700mm and 1100mm to suit different types of cabinet

Software & Accessories

92

Software & Accessories

PROLiNK Online UPS Software

Viewpower – UPS Management Software

ViewPower is an advanced UPS management software that is designed for users to remotely monitor and manage multiple UPS units in a networked environment, either by LAN or INTERNET. The ViewPower software is able to protect your important data by executing a safety OS shutdown during power failure. Better yet, this software gives users the ability to store programming data and also scheduled a UPS shutdown when necessary.

• Allows control and monitoring of multiple UPSs via

LAN and INTERNET

• User-friendly power analysis graphs

• Real-time dynamic graphs of UPS data

• Safety OS shutdown to prevent data losses during

power failure

• Warning notifications via audible alarm, broadcast,

mobile messenger, and e-mail

• Scheduled UPS on/off, battery test, programmable

outlet control, and audible alarm control

• Password security protection and remote access

management

• Supports multiple OS and local languages

Solar Power Management Software

SolarPower Pro is a solar inverter monitoring software that is capable of monitoring up to 247 devices via a modbus interface. When connected to a networking environment, users are able to monitor the Solar inverter via a web browser. The

SolarPower Pro comes with a variety of features including; data logging, ability to generate statistical data, alarm notifications, prompting fault messages and parameter control for devices.

• Allows control and monitoring of multiple devices

via LAN and INTERNET

• Automatic and real-time data acquisition

• Secure data logging

• Graphic display of device data for quick and easy

reading

• Warning notifications or fault alarms via audible

alarm, pop-up screen, broadcast, mobile messenger,

tray message and e-mail

• Easy diagnosis from event statistics and amount

calculation for energy saving

• Maximum data log up to 10 billion records

• Supports online upgrade and manually upgrade

• Supports multiple languages: English, Chinese,

French, German, Spanish, Russian, Portuguese,

Ukrainian, Italian, Polish

93

Appendix

PROLiNK UPS Battery Backup Configuration List

1. Professional Series (1P/1P) - Tower

POWER

RATING

BACK UP

TIME

BATTERY

GROUP

DC BUS

(VDC)

PRO901L 2/24VDC

PRO902L

PRO903L

PRO906L

4/48VDC

6/72VDC

8/96VDC

15 MINUTES

QUANTITY

C1*1

12V26AH*2

C2*1

12V26AH*4

C3*1

12V26AH*6

C4*1

12V17AH*16

30 MINUTES

QUANTITY

C1*1

12V17AH*4

C2*1

12V17AH*8

C3*1

12V17AH*12

C8*1

12V26AH*16

1 HOUR

QUANTITY

C2*1

12V65AH*2

C4*1

12V65AH*4

C6*1

12V65AH*6

C8*1

12V100AH*8

2 HOURS

QUANTITY

C3*1

12V100AH*2

C4*1

12V100AH*4

C6*1

12V100AH*6

C24*1

12V65AH*24

PC96*1

3 HOURS

QUANTITY

C6*1

12V65AH*6

PEC20-24*1

C12*1

12V65AH*12

PEC15-48*1

C20*1

12V65AH*18

PEC12-72*1

C32*1

12V65AH*32

PEC10-96*2

4 HOURS

QUANTITY

C8*1

12V65AH*8

PEC20-24*1

C16*1

12V65AH*16

PEC15-48*1

C24*1

12V65AH*24

PEC12-72*1

C20*2

12V65AH*40

PEC10-96*3

REMARK

1. Without cable from

UPS system to

battery bank.

2. All batteries supply

are without battery

cables.

2. Master Series (1P/1P) - Tower

POWER

RATING

BACK UP

TIME

BATTERY

GROUP

DC BUS

(VDC)

PRO801L 3/36VDC

PRO8015L

PRO802L

PRO803L

PRO806L

PRO810L

3/36VDC

6/72VDC

6/72VDC

20/240VDC

20/240VDC

15 MINUTES

QUANTITY

C1*1

12V17AH*3

C1*1

12V26AH*3

C2*1

12V17AH*6

C3*1

12V26AH*6

C6*1

12V17AH*20

C12*1

12V26AH*20

30 MINUTES

QUANTITY

C1*1

12V26AH*3

C2*1

12V17AH*6

C3*1

12V26AH*6

C3*1

12V17AH*12

C12*1

12V26AH*20

C6*2

12V17AH*40

1 HOURS

QUANTITY

C3*1

12V26AH*6

C3*1

12V65AH*3

C6*1

12V26AH*12

C6*1

12V65AH*6

C4*2

12V18AH*40

C20*1

12V65AH*20

2 HOURS

QUANTITY

C3*1

12V65AH*3

C3*1

12V100AH*3

C6*1

12V65AH*6

C6*1

12V100AH*6

PEC12-72*1

C20*1

12V26AH*40

PEC24-240*1

C20*1

12V100AH*20

PEC24-240*2

3 HOURS

QUANTITY

C6*1

12V65AH*6

PEC15-36*1

C6*1

12V100AH*6

PEC15-36*1

C20*1

12V26AH*36

PEC12-72*1

C12*1

12V100AH*12

PEC12-72*1

C20*1

12V100AH*20

PEC24-240*1

C20*3

12V65AH*60

PEC24-240*1

4 HOURS

QUANTITY

C6*1

12V100AH*6

PEC15-36*1

C12*1

12V65AH*12

PEC15-36*2

C12*1

12V100AH*12

PEC12-72*1

C20*1

12V65AH*18

PEC12-72*1

C20*2

12V65AH*40

PEC24-240*1

C20*2

12V100AH*40

PEC24-240*1

REMARK

1. Without cable from

UPS system to

battery bank.

2. All batteries supply

are without battery

cables.

3. Master Series (1P/1P) - 2-in-1 Rack/ Tower

POWER

RATING

BACK UP

TIME

PRO801RL

PRO8015RL

PRO802RL

PRO803RL

PRO806RL

PRO810RL

BATTERY

GROUP

DC BUS

(VDC)

2/24VDC

3/36VDC

4/48VDC

6/72VDC

20/240VDC

20/240VDC

15 MINUTES

QUANTITY

G8R*1

12V7AH*8

G12R*1

12V7AH*12

G20R*1

12V7AH*16

G12R*2

12V7AH*24

G20R*2

12V9AH*40

G20R*4

12V7AH*80

30 MINUTES

QUANTITY

C1*1

12V17AH*4

C2*1

12V17AH*6

C2*1

12V17AH*8

C3*1

12V17AH*12

C12*1

12V26AH*20

C20*1

12V26AH*40

The above battery backup configuration list is only applicable to the isolation transformer UPS version.

All specifications, designs and contents are subjected to changes without prior notice.

1 HOURS

QUANTITY

C2*1

12V65AH*2

C3*1

12V65AH*3

C4*1

12V65AH*4

C6*1

12V65AH*6

C20*1

12V26AH*40

PEC24-240*1

C20*1

12V100AH*20

PEC24-240*1

2 HOURS

QUANTITY

C3*1

12V100AH*2

PEC20-24*1

C3*1

12V100AH*3

PEC15-36*1

C4*1

12V100AH*4

PEC15-48*1

C6*1

12V100AH*6

PEC12-72*1

C20*1

12V65AH*20

PEC24-240*1

C20*2

12V65AH*40

PEC24-240*1

3 HOURS

QUANTITY

C6*1

12V65AH*6

PEC20-24*1

C6*1

12V100AH*6

PEC15-36*1

C12*1

12V65AH*12

PEC15-48*1

C20*1

12V65AH*18

PEC12-72*1

C20*2

12V65AH*40

PEC24-240*1

C20*2

12V100AH*40

PEC24-240*1

4 HOURS

QUANTITY

C8*1

12V65AH*8

PEC20-24*1

C12*1

12V65AH*12

PEC15-36*2

C16*1

12V65AH*16

PEC15-48*2

C24*1

12V65AH*24

PEC12-72*2

C20*3

12V65AH*60

PEC24-240*1

C20*4

12V65AH*80

PEC24-240*1

REMARK

1. Without cable from

UPS system to

battery bank.

2. All batteries supply

are without battery

cables.

94

Appendix

4. Master Series (3P/1P) - Tower

POWER

RATING

BACK UP

TIME

BATTERY

GROUP

DC BUS

(VDC)

PRO83110L 20

PRO83115L

PRO83120L

PRO83130L

20

20

20

15 MINUTES

QUANTITY

C12*1

12V26AH*20

C6*2

12V17AH*40

C12*2

12V26AH*40

C20*1

12V65AH*20

30 MINUTES

QUANTITY

C6*2

12V17AH*40

C20*1

12V26AH*40

C12*3

12V26AH*60

C20*1

12V100AH*20

PEC24-240*1

1 HOURS

QUANTITY

C20*1

12V65AH*20

C20*1

12V100AH*20

C20*2

12V65AH*40

PEC24-240*1

C20*2

12V100AH*40

PEC24-240*1

2 HOURS

QUANTITY

C20*1

12V100AH*20

PEC24-240*1

C20*2

12V100AH*40

PEC24-240*1

C20*2

12V100AH*40

PEC24-240*1

C20*3

12V100AH*60

PEC24-240*1

3 HOURS

QUANTITY

C20*3

12V65AH*60

PEC24-240*1

C20*4

12V65AH*80

PEC24-240*1

C20*6

12V65AH*120

PEC24-240*2

C20*5

12V100AH*100

PEC24-240*2

4 HOURS

QUANTITY

C20*2

12V100AH*40

PEC24-240*1

C20*3

12V100AH*60

PEC24-240*1

C20*4

12V100AH*80

PEC24-240*2

C20*7

12V100AH*140

PEC24-240*3

REMARK

1. Without cable from

UPS system to

battery bank.

2. All batteries supply

are without battery

cables.

5. Master Series (3P/1P) - Rack Mount

POWER

RATING

BACK UP

TIME

BATTERY

GROUP

DC BUS

(VDC)

PRO83110RL 20

PRO83120RL 20

15 MINUTES

QUANTITY

G20R*3

12V9AH*60

C12*2

12V26AH*40

30 MINUTES

QUANTITY

C4*2

12V17AH*40

C12*3

12V26AH*60

1 HOURS

QUANTITY

C20*1

12V65AH*20

C20*2

12V65AH*40

PEC24-240*1

2 HOURS

QUANTITY

C20*1

12V100AH*20

PEC24-240*1

C20*2

12V100AH*40

PEC24-240*1

3 HOURS

QUANTITY

C20*3

12V65AH*60

PEC24-240*1

C20*6

12V65AH*120

PEC24-240*2

4 HOURS

QUANTITY

C20*2

12V100AH*40

PEC24-240*1

C20*4

12V100AH*80

PEC24-240*2

REMARK

1. Without cable from UPS

system to battery bank.

2. All batteries supply are

without battery cables.

6. Master Series (3P/3P) - Tower

POWER

RATING

BACK UP

TIME

BATTERY

GROUP

DC BUS

(VDC)

PRO83310L 20

PRO83315L

PRO83320L

PRO83330L

20

20

20

15 MINUTES

QUANTITY

C12*1

12V26AH*20

C6*2

12V17AH*40

C12*2

12V26AH*40

C20*1

12V65AH*20

30 MINUTES

QUANTITY

C4*2

12V17AH*40

C20*1

12V26AH*40

C12*3

12V26AH*60

C20*1

12V100AH*20

PEC24-240*1

1 HOURS

QUANTITY

C20*1

12V65AH*20

C20*1

12V100AH*20

C20*2

12V65AH*40

PEC24-240*1

C20*2

12V100AH*40

PEC24-240*1

2 HOURS

QUANTITY

C20*1

12V100AH*20

PEC24-240*1

C20*2

12V100AH*40

PEC24-240*1

C20*2

12V100AH*40

PEC24-240*1

C20*3

12V100AH*60

PEC24-240*1

3 HOURS

QUANTITY

C20*3

12V65AH*60

PEC24-240*1

C20*4

12V65AH*80

PEC24-240*1

C20*6

12V65AH*120

PEC24-240*2

C20*5

12V100AH*100

PEC24-240*2

4 HOURS

QUANTITY

C20*2

12V100AH*40

PEC24-240*1

C20*3

12V100AH*60

PEC24-240*1

C20*4

12V100AH*80

PEC24-240*2

C20*7

12V100AH*140

PEC24-240*3

REMARK

1. Without cable from

UPS system to

battery bank.

2. All batteries supply

are without battery

cables.

The above battery backup configuration list is only applicable to the isolation transformer UPS version.

*All specifications, designs and contents are subject to change without prior notice.

95

1. Without cable from UPS

system to battery bank.

2. All batteries supply are

without battery cables.

Appendix

7. Power Series (3P/3P)

POWER

RATING

BACK UP

TIME

BATTERY

GROUP

DC BUS

(VDC)

PRO73315S 62

PRO73320S

PRO73330S

PRO73340S

PRO73360S

PRO73380S

62

62

62

62

62

15 MINUTES

QUANTITY

30 MINUTES

QUANTITY

C16*1

12V17AH*62

C16*1

12V17AH*62

C32*1

12V26AH*62

C16*2

12V17AH*124

C32*2

12V26AH*124

C32*2

12V65AH*62

C32*1

12V26AH*62

C16*2

12V17AH*124

C32*2

12V26AH*124

C32*2

12V65AH*62

C32*2

12V100AH*62

PRO733100S

PRO733120S

62

62

C32*2

12V100AH*62

C32*2

12V100AH*62

1 HOURS

QUANTITY

C16*2

12V17AH*124

C16*2

12V17AH*124

C32*2

12V65AH*62

C32*2

12V100AH*62

C32*4

12V65AH*124

C32*6

12V65AH*186

2 HOURS

QUANTITY

C32*2

12V26AH*124

C32*2

12V65AH*62

3 HOURS

QUANTITY

C32*2

12V100AH*62

C32*2

12V100AH*62

4 HOURS

QUANTITY

C32*4

12V65AH*124

C32*4

12V65AH*124

REMARK

C32*2

12V100AH*62

C32*4

12V65AH*124

C32*4

12V100AH*124

C32*8

12V65AH*248

C32*6

12V65AH*186

C32*4

12V100AH*124

C32*6

12V100AH*186

C32*8

12V100AH*248

C32*4

12V100AH*124

C32*8

12V65AH*248

C32*8

12V100AH*248

1. Without cable from

UPS system to

battery bank.

2. All batteries supply

are without battery

cables.

C32*10

12V100AH*310

C32*4

12V65AH*124

C32*4

12V100AH*124

C32*4

12V100AH*124

C32*6

12V100AH*186

C32*10

12V100AH*310

C32*14

12V100AH*434

C32*8

12V65AH*248

C32*8

12V100AH*248

C32*12

12V100AH*372

C32*16

12V100AH*496

Battery Configurations

CI

C2

C3

C4

C6

C8

C12

C16

C20

C24

C32

G6

G12

G18

G60

G8R

G12R

G20R

MODEL NO

CABINET

DIMENSION

(D * W * H)

435*210*270

450*470*320

585*470*320

450*470*615

585*470*615

780*470*615

780*470*900

780*470*1190

950*470*1190

1150*470*1190

780*880*1190

100AH

4

6

8

1

1

3

12

16

20

24

32

65AH

4

6

8

1

2

3

12

16

20

24

32

Available Battery Quantity

38AH

8

12

16

2

4

6

24

32

40

/

62

24AH

8

12

16

3

4

6

24

32

40

/

62

17AH

20

28

36

5

10

14

/

62

/

/

/

12V7AH or

12V9AH or 10Ah

/

/

/

/

/

/

/

/

/

8

12

20

6

12

/

/

18

60

CABINET WEIGHT

3.5kg

6kg

8kg

18kg

22kg

25kg

32kg

45kg

45kg

75kg

95kg

REMARK

1. Option for DC

switch/protection

2. Option for battery

cable inter

connection.

For Power Series

Included cables, without switch

Completed assembled

Completed assembled

Completed assembled completed assembled

Completed assembled

Completed assembled

Completed assembled

The above battery backup configuration list is only applicable to the isolation transformer UPS version.

*All specifications, designs and contents are subject to change without prior notice.

96

SINGAPORE

FIDA INTERNATIONAL (S) PTE LTD

Block 16 Kallang Place

#06-02, Singapore 339156

Tel: (65) 6357 0668

MALAYSIA

FIDA SYSTEMS (M) SDN BHD

Tel: (60) 3 8024 9151

INDONESIA

PROLiNK INDONESIA

Tel: (62) 21 3483 1777

Technical Support Hotline:

Singapore

(65) 6357 0666

Malaysia

(60) 3 8023 9151

Indonesia

(62) 21 3483 1717

Operating Hours

Monday - Friday: 9.00am - 6.00pm

Closed on Saturdays, Sundays & Public Holidays

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
