PowerLite 1825
Multimedia Projector
®
User’s Guide
Important Safety Information
WARNING: Never look into the projector lens when the lamp is turned on; the bright light can damage your eyes.
Never let children look into the lens when it is on. Never open any cover on the projector, except the lamp and
filter covers. Dangerous electrical voltages inside the projector can severely injure you. Except as specifically
explained in this User’s Guide, do not attempt to service this product yourself. Refer all servicing to qualified service
personnel.
WARNING: The projector and its accessories come packaged in plastic bags. Keep plastic bags away from small
children to avoid any risk of suffocation.
Caution: When you replace the lamp, never touch the new lamp with your bare hands; the invisible residue left by
the oil on your hands may shorten the lamp life. Use a cloth or glove to handle the new lamp.
Copyright Notice
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of Seiko Epson Corporation. The information contained herein is designed only for use with
this Epson product. Epson is not responsible for any use of this information as applied to other products.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for
damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of
this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to
strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.
Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any options or
any consumable products other than those designated as Original Epson Products or Epson Approved Products by
Seiko Epson Corporation.
Trademarks
Epson, Quick Corner, EasyMP, and Instant Off are registered trademarks, and Epson Exceed Your Vision is a
trademark of Seiko Epson Corporation.
PowerLite and PrivateLine are registered trademarks; SizeWise is a trademark; and Epson Store and Epson Extra
Care are service marks of Epson America, Inc.
Pixelworks, DNX, and the DNX logo are trademarks of Pixelworks, Inc.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of
their respective owners. Epson disclaims any and all rights in those marks.
The contents of this manual are subject to change without notice.
© 2007 Epson America, Inc.
2
12/07
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using Your Documentation . . . . . . . . . . . . . . . . . . . . . . . . . 10
Getting More Information . . . . . . . . . . . . . . . . . . . . . . . 10
Registration and Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Unpacking the Projector. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Additional Components. . . . . . . . . . . . . . . . . . . . . . . . . 12
Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1
Displaying and Adjusting the Image . . . . . . . . 15
Positioning the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Turning the Projector On and Off . . . . . . . . . . . . . . . . . . . . 17
Using the Direct Power On Function . . . . . . . . . . . . . . 19
Shutting Down the Projector . . . . . . . . . . . . . . . . . . . . . 20
Displaying an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Troubleshooting Display Problems. . . . . . . . . . . . . . . . . . . . 21
You Can’t Project an Image . . . . . . . . . . . . . . . . . . . . . . 21
The Projector and Notebook Don’t Display the
Same Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Adjusting the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Adjusting the Height of the Image . . . . . . . . . . . . . . . . . 23
Focusing and Zooming the Image . . . . . . . . . . . . . . . . . 24
Adjusting the Image Shape. . . . . . . . . . . . . . . . . . . . . . . 24
Selecting the Color Mode . . . . . . . . . . . . . . . . . . . . . . . 28
Resizing Video Images . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3
2
Presenting With the Remote Control . . . . . . . . 29
Using the Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Controlling the Picture and Sound. . . . . . . . . . . . . . . . . . . . 30
Switching Between Picture Sources . . . . . . . . . . . . . . . . 30
Turning Off the Picture and Sound . . . . . . . . . . . . . . . . 31
Stopping Action. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Zooming Part of Your Image . . . . . . . . . . . . . . . . . . . . . 32
Controlling the Volume. . . . . . . . . . . . . . . . . . . . . . . . . 33
Highlighting Your Presentation . . . . . . . . . . . . . . . . . . . . . . 33
Using the Pointer Tool . . . . . . . . . . . . . . . . . . . . . . . . . 33
Customizing the Pointer Tool . . . . . . . . . . . . . . . . . . . . 34
Operating Your Computer With the Remote Control . . . . . 35
Operating Two or More Projectors With the
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Setting the Projector ID. . . . . . . . . . . . . . . . . . . . . . . . . 36
Setting the Remote Control ID . . . . . . . . . . . . . . . . . . . 37
3
Connecting to Computers, Cameras, and
Other Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Connecting to a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . 40
Connecting to the Computer Port . . . . . . . . . . . . . . . . . 40
Connecting to the USB Port . . . . . . . . . . . . . . . . . . . . . 41
Connecting the Cable for Remote Mouse Control . . . . 42
Connecting to Video Equipment . . . . . . . . . . . . . . . . . . . . . 44
Connecting a Composite Video Source . . . . . . . . . . . . . 45
Connecting an S-Video Source . . . . . . . . . . . . . . . . . . . 46
Connecting a Component Video Source . . . . . . . . . . . . 47
Connecting an RGB Video Source. . . . . . . . . . . . . . . . . 48
Connecting an External Monitor . . . . . . . . . . . . . . . . . . . . . 49
Playing Sound Through the Projector . . . . . . . . . . . . . . . . . 50
Connecting External Speakers . . . . . . . . . . . . . . . . . . . . 51
Connecting to a Digital Camera or Other Device. . . . . . . . . 52
Removing the USB Cable . . . . . . . . . . . . . . . . . . . . . . . 52
Inserting a CompactFlash Card . . . . . . . . . . . . . . . . . . . . . . 53
Inserting the Wireless 802.11g/b/a Module . . . . . . . . . . . . . 54
Connecting a Network Cable . . . . . . . . . . . . . . . . . . . . . . . . 55
4
4
Presenting Through a Wireless Network . . . . 57
Starting EasyMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Configuring Basic Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Configuring the Connection. . . . . . . . . . . . . . . . . . . . . . . . . 61
Using Ad Hoc Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Using Access Point Mode. . . . . . . . . . . . . . . . . . . . . . . . 68
Making a WPS (Wi-Fi Protected Setup) Connection . . . 78
Using Wireless Security Options. . . . . . . . . . . . . . . . . . . . . . 84
Enabling WEP Encryption. . . . . . . . . . . . . . . . . . . . . . . 84
Enabling WPA Security . . . . . . . . . . . . . . . . . . . . . . . . . 86
Enabling EAP, LEAP, or PEAP Authentication . . . . . . . 87
Enabling EAP-TLS Certificate Validation . . . . . . . . . . . 88
Projecting Over a Network . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Solving Connection Problems . . . . . . . . . . . . . . . . . . . . 92
Using the Control Bar . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Connecting in Advanced Connection Mode . . . . . . . . . 94
Enabling Network Security . . . . . . . . . . . . . . . . . . . . . . 95
Multi-screen Projection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Projecting Video Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Using Special Presentation Modes . . . . . . . . . . . . . . . . . . . 103
Using Presentation Mode . . . . . . . . . . . . . . . . . . . . . . . 103
Using Presenter View . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Connecting With Windows Vista . . . . . . . . . . . . . . . . . . . . 107
Vista Network Projector Limitations . . . . . . . . . . . . . . 109
5
Presenting From a USB Drive, Camera, or
CompactFlash Card . . . . . . . . . . . . . . . . . . . . . . . . 111
Presenting Files From a USB Drive or
CompactFlash Card. . . . . . . . . . . . . . . . . . . . . . . . . . 112
Presenting Image Files From a Digital Camera . . . . . . . . . . 113
Creating a Slideshow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Displaying the Slideshow . . . . . . . . . . . . . . . . . . . . . . . 114
Controlling Your Slideshow . . . . . . . . . . . . . . . . . . . . . 115
Changing Timing and Other Settings . . . . . . . . . . . . . 116
5
Creating a Scenario. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Converting a PowerPoint File to a Scenario . . . . . . . . . 118
Creating a Scenario from Scratch . . . . . . . . . . . . . . . . . 119
Editing a Scenario . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Transferring Your Scenario to a USB Drive or
CompactFlash Card . . . . . . . . . . . . . . . . . . . . . . . . . 128
Presenting Scenarios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Controlling Your Scenario . . . . . . . . . . . . . . . . . . . . . . 130
Copying and Deleting CompactFlash Card Files . . . . . . . . 131
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Supported File Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
6
7
6
Fine-Tuning the Projector. . . . . . . . . . . . . . . . . . 135
Using the Menu System . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Restoring the Default Settings . . . . . . . . . . . . . . . . . . . 137
Adjusting the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Six-Axis Color Adjustment. . . . . . . . . . . . . . . . . . . . . . 140
Adjusting Signal Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Customizing Projector Features . . . . . . . . . . . . . . . . . . . . . 143
Using the Projector Security Features . . . . . . . . . . . . . . . . . 144
Enabling Password Protection . . . . . . . . . . . . . . . . . . . 145
Creating Your Own Startup Screen . . . . . . . . . . . . . . . 146
Disabling the Projector’s Buttons. . . . . . . . . . . . . . . . . 148
Customizing Power and Operation . . . . . . . . . . . . . . . . . . 149
Multi-screen Color Adjustment . . . . . . . . . . . . . . . . . . . . . 151
Managing Projectors. . . . . . . . . . . . . . . . . . . . . . . . 153
Connecting to a Wired Network . . . . . . . . . . . . . . . . . . . . 154
Using Projector E-mail Alerts . . . . . . . . . . . . . . . . . . . . . . . 155
Using EMP Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Opening and Closing EMP Monitor . . . . . . . . . . . . . . 157
Registering a Projector . . . . . . . . . . . . . . . . . . . . . . . . . 158
Monitoring Your Projectors . . . . . . . . . . . . . . . . . . . . . 160
Controlling Your Projectors . . . . . . . . . . . . . . . . . . . . . 164
Configuring the Monitoring Interval . . . . . . . . . . . . . . 165
Using E-mail Alerts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
Understanding the Notification Messages . . . . . . . . . . 167
Using a Browser to Monitor the Projector . . . . . . . . . . . . . 167
Transferring Files by SMB . . . . . . . . . . . . . . . . . . . . . . . . . 169
8
Maintaining the Projector . . . . . . . . . . . . . . . . . . 171
9
Solving Problems
A
Cleaning the Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Cleaning the Projector Case . . . . . . . . . . . . . . . . . . . . . . . . 172
Cleaning the Air Filter and Vent. . . . . . . . . . . . . . . . . . . . . 173
Replacing the Lamp and Air Filter . . . . . . . . . . . . . . . . . . . 174
Resetting the Lamp Timer . . . . . . . . . . . . . . . . . . . . . . 177
Checking Lamp Usage . . . . . . . . . . . . . . . . . . . . . . . . . 178
Replacing the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Transporting the Projector . . . . . . . . . . . . . . . . . . . . . . . . . 180
. . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Using On-Screen Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Checking Projector Status. . . . . . . . . . . . . . . . . . . . . . . . . . 183
What To Do When the Lights Flash . . . . . . . . . . . . . . 183
Solving Projector Operation Problems . . . . . . . . . . . . . . . . 185
Solving Problems With the Image or Sound . . . . . . . . . . . . 185
Solving Network Problems . . . . . . . . . . . . . . . . . . . . . . . . . 191
Solving EasyMP Problems . . . . . . . . . . . . . . . . . . . . . . . . . 193
Solving Problems With the Remote Control. . . . . . . . . . . . 196
Where To Get Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Speak to a Support Representative . . . . . . . . . . . . . . . . 197
Software Installation
. . . . . . . . . . . . . . . . . . . . . . . 199
Windows System Requirements . . . . . . . . . . . . . . . . . . . . . 199
Limitations in Windows Vista . . . . . . . . . . . . . . . . . . . 200
Mac System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . 200
Installing the Software in Windows . . . . . . . . . . . . . . . . . . 201
Installing the Software on a Mac. . . . . . . . . . . . . . . . . . . . . 202
7
B
Projector Installation . . . . . . . . . . . . . . . . . . . . . . . 203
C
Technical Specifications . . . . . . . . . . . . . . . . . . . . 205
D
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . 211
FCC Compliance Statement. . . . . . . . . . . . . . . . . . . . . . . . 213
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215
8
-
Welcome
The PowerLite
®
1825 is an easy-to-use projector that weighs less than
7 pounds (3.2 kg). The projector offers up to 3500 lumens of
brightness. You can connect it to a wide range of computers and video
sources, or you can project from a USB or CompactFlash® storage
device, or over an 802.11g, 802.11b, or 802.11a wireless or wired
network.
Easy setup, control, and security:
■
5-second startup time and Instant Off ® feature for fast setup and
shut down
■
Automatic digital keystone correction
■
1.6x optical zoom lens for flexible placement and positioning
■
Security features include password, user’s logo, and the ability to
lock the projector buttons
■
A/V mute slide (lens cover) to block the lens and save lamp life
when you want to temporarily stop projecting
Additional enhancements:
■
Connect three computers, one via USB 2.0 cable and another two
via VGA cable for multi-source presentations
■
With Windows Vista,® you can use the wireless Network Projector
feature to quickly connect to the projector without installing any
software
■
Wirelessly send MPEG2, MPEG4, and WMV full-screen video
from a PC
■
Project up to four different images from one computer
■
Color match images from up to four projectors for a uniform,
wide-screen view
9
■
Project only the PowerPoint® slide images while viewing handout
notes and controls on the computer screen
■
Perform six-axis color adjustment for fine art and photography
Using Your Documentation
This book contains all the information you need to set up and use
your projector. Please follow these guidelines as you read through it:
■
Warnings must be followed carefully to avoid bodily injury.
■
Cautions must be observed to avoid damage to your equipment.
■
Notes contain important information about your projector.
■
Tips contain additional projection hints.
Getting More Information
Need tips on giving presentations? Quick steps for setting up your
projector? Here’s where you can look for help:
■
Quick Setup sheet
Gives you the instructions you need to get your projector up and
running if you are connecting to a notebook, MacBook,®
PowerBook,® or iBook® computer, or projecting over a wireless
network.
■
Projector kit
Includes this User’s Guide, your Quick Setup sheet, warranty
brochures, and Epson PrivateLine® Support card. Keep the kit
with your projector at all times.
■
Built-in help system
Provides assistance for common problems. Available from the
Help button on the projector or the remote control. See page 182
for details.
■
epson.com/support
Download FAQs and e-mail your questions to Epson® support.
10
Welcome
■
If you still need help after checking this User’s Guide and the
sources listed above, you can use the Epson PrivateLine Support
service to get help fast. Call (800) 637-7661 and enter the PIN on
the PrivateLine card. Or take advantage of Epson’s automated
support services 24 hours a day. See page 197 for more
information.
■
presentersonline.com
Includes a library of articles covering presentation tips, tricks, and
technology. The site provides templates, clip art, and sound clips,
as well as Presenters Services to use on the road. Even more
resources and services are available if you register to join the
Presenters Club—and it’s free.
Registration and Warranty
Your projector comes with a basic carry-in 2-year and 90-day lamp
warranty that lets you project with confidence. For details, see the
warranty brochure included with your projector.
In addition, for customers who register their projector, Epson offers
free Extra Care Road Service. In the unlikely event of an equipment
failure, you won’t have to wait for your unit to be repaired. Instead,
Epson will ship you a replacement unit anywhere in the United States
or Canada, usually via overnight delivery. See the brochure included
with your projector for details.
SM
To register, simply fill out the registration card and mail it to Epson.
Or you can register online at epson.com/webreg. Registering also lets
you receive special updates on new accessories, products, and service.
Welcome 11
Unpacking the Projector
After unpacking the projector, make sure you have all these parts:
PDF manual and
registration CD-ROM
Projector software
CD-ROM
Projector
Wireless LAN module
and security screw
Power cable
Remote control and
2 AAA batteries
USB cable
VGA computer cable
Carrying case
Save all packaging in case you need to ship the projector. Always use
the original packaging (or the equivalent) when you need to send the
projector to another location. If you are moving the projector by
hand, use the carrying case. See page 13 for ordering information, and
page 180 for transportation instructions.
Additional Components
Depending on how you plan to use the projector, you may need
additional components:
■
To receive an S-video signal, you’ll need an S-video cable.
■
To receive a component video signal from a VCR or other video
device, you’ll need an HD15 to component video cable.
You can purchase these items from Epson. See “Optional Accessories”
on page 13.
12
Welcome
Optional Accessories
To enhance your use of the projector, Epson provides the following
optional accessories:
Product
Part number
Replacement lamp
V13H010L40
Air filter replacement set (2 filters)
V13H134A08
Universal ceiling mount
False ceiling plate
Security bracket/cabling for gyro lock mounts
Adjustable ceiling channel
Suspension adapter
ELPMBUNI
ELPMBFCP
ELPMBSEC
ELPMBACC
ELPMBAPL
Kensington® security lock
ELPSL01
50-inch portable screen (4:3 aspect ratio)
60-inch portable pop-up screen (4:3 aspect ratio)
80-inch portable pop-up screen (4:3 aspect ratio)
83.6-inch hanging pull-down screen (4:3 aspect ratio)
DUET Portable Projector Screen (4:3/16:9 combination)
ELPSC06
ELPSC07
ELPSC08
ELPSC09
ELPSC80
HD-15 to component video cable
S-video cable
ELPKC19
ELPSV01
Distribution amplifier
ELPDA01
Image presentation camera (ELPDC05)
V12H162020
You can purchase screens or other accessories from an Epson
authorized reseller. To find the nearest reseller, call 800-GO-EPSON
(800-463-7766). Or you can purchase online at www.epsonstore.com
(U.S. sales) or www.epson.ca (Canadian sales).
Welcome 13
14
Welcome
1
Displaying and Adjusting
the Image
W
hether you’re presenting from a computer or video equipment,
you need to follow some basic steps to display your image on the
screen.
Follow the guidelines in this chapter for:
■
Positioning the projector
■
Turning on and off the projector
■
Displaying an image
■
Troubleshooting display problems
■
Adjusting the image
15
Positioning the Projector
note
You can mount the projector
on the ceiling, or place it
behind a translucent screen
for rear projection. See
page 203 for details.
If the projector isn’t already installed in the room you’re using, you’ll
probably want to place it on a table in front of the screen, as shown.
This lets you stand in the front of the room, face the audience, and
remain close enough to the equipment to be able to control it. Try to
leave as much space as possible between the projector and the screen to
get a good-size image.
Use the figure below to help you determine placement. Image size
increases with distance, but can vary depending on how you position
the zoom ring and whether you’ve adjusted the image with other
settings.
TBD
29.7 to 48.2 ft
(9 to 14.7 m)
5.7 to 9.4 ft
(1.7 to 2.9 m)
2.7 to 4.6 ft
(0.8 to 1.4 m)
Distance from screen
Also keep these considerations in mind:
16
■
Place the projector on a sturdy, level surface.
■
Make sure there is plenty of space for ventilation around and
under the projector. Do not set the projector on top of anything
that could block the vents under the projector.
■
Make sure the projector is within 10 feet (3 meters) of a grounded
electrical outlet or extension cord.
Displaying and Adjusting the Image
Ideally, you should place the projector directly in front of the center of
the screen, facing it toward the screen squarely. The base of the lens
should be at about the level of the bottom of the screen.
note
After positioning the
projector, you may want to
connect a Kensington
MicroSaver® anti-theft
device to the lock port on the
projector. You can purchase
this from Epson; see
page 13.
Projector
Screen
If you place the projector below screen level, you’ll have to tilt it up by
extending the front adjustable foot. This causes the image to become
“keystone” shaped, but you can correct the distortion (see page 24).
For instructions on installing the projector in a permanent location,
such as a theater or conference room, see page 203.
Turning the Projector On and Off
Turn on any connected computer or video equipment before starting
the projector so it can automatically detect and display the image
source. If you turn on the projector first, or have multiple pieces of
connected equipment, you may have to select the image source
manually (see page 20).
Displaying and Adjusting the Image 17
Follow these steps to turn on the projector:
1. Open the A/V mute slide (lens cover).
note
You can set the projector to
automatically turn off the
lamp and enter “sleep mode”
when it has not received any
signals for 30 minutes. This
conserves electricity, cools the
projector, and extends the
life of the lamp. If you want
to start projecting again,
press the P Power button.
If you are done using the
projector, unplug the power
cord. To enable sleep mode,
see page 149.
2. Plug one end of the power cable into the projector, and the other
end into an electrical outlet.
The Power light turns orange.
Power light
18
Displaying and Adjusting the Image
3. Press the P Power button on the remote control or on top of the
projector.
The projector beeps once and the Power light flashes green as the
projector warms up, then an image begins to appear. When the
Power light stops flashing and remains green, the projector is
ready for use.
4. If you are prompted to enter a password, see page 146.
warning
Never look into the lens
when the lamp is on. This
can damage your eyes, and is
especially dangerous for
children.
Using the Direct Power On Function
The Direct Power On function enables faster setup. The projector
starts up automatically when you plug it in or turn it on with a wall
switch. You don’t have to press the P Power button.
Follow these steps to enable Direct Power On:
1. Press the Menu button on the remote control or projector and
select the Extended menu.
2. Choose Operation and press Enter.
3. Choose Direct Power On and press Enter.
note
If a power outage occurs
when Direct Power On is
enabled and the projector is
plugged in, the projector will
restart when the power is
restored.
4. Highlight ON and press Enter.
5. Press Menu to exit. The setting will take effect the next time you
plug in the projector.
Displaying and Adjusting the Image 19
Shutting Down the Projector
note
Lamp life results will vary
depending on mode selected,
environmental conditions,
and usage.
Turn off this product when
not in use to prolong the life
of the projector.
This projector incorporates Instant Off technology. To turn it off, you
can press its P Power button as described below, unplug it, or turn
off a power switch that supplies power to the projector. You don’t
have to wait for the projector to cool off first.
1. To turn off the projector, press the P Power button on the
remote control or projector.
You see a confirmation message.
(If you don’t want to turn it off,
press any other button.)
2. Press the P Power button again. The projection lamp turns off
and you can unplug the power cord.
If you want to turn the projector on again, make sure the orange
Power light is not flashing, then press the P Power button.
Displaying an Image
You may need to select the image source if you have multiple video
sources connected to the projector (such as a computer or DVD
player). Selecting the image source lets you switch between images
input from different pieces of connected equipment.
If you don’t see the image you want, press the Search button on the
remote control or the Source Search button on the projector until
you see the image you want to project.
You can also use the Source buttons on the remote control to switch
between devices connected to the ports identified on each button, or
select EasyMP® to project wirelessly or from a USB drive.
20
Displaying and Adjusting the Image
Troubleshooting Display Problems
Follow these guidelines if you’re having trouble displaying an image.
You Can’t Project an Image
If you don’t see the image you are trying to project, try the following:
■
Make sure the cables are connected correctly, as described
beginning on page 39.
■
Make sure the Power light is green and not flashing and the A/V
mute slide (lens cover) is open.
■
If you’ve connected more than one computer and/or video source,
you may need to press the Source Search button on the
projector’s control panel or Search button on the remote control
to select the correct source. (Allow a few seconds for the projector
to sync up after pressing the button.)
■
If you’re using a PC notebook, press the function key on your
keyboard that lets you display on an external monitor. It may be
labeled CRT/LCD or have an icon such as
. You may have to
hold down the Fn key while pressing it. Allow a few seconds for
the projector to sync up after changing the setting.
The Projector and Notebook Don’t Display the
Same Image
If you’re projecting from a notebook, and you can’t see your image on
the projection screen and on your computer at the same time, follow
these guidelines.
If you’re using a PC notebook:
■
On most systems, there’s a function key that lets you toggle
between the LCD screen and the projector, or display on both at
the same time. It may be labeled CRT/LCD or have an icon such as
. You may have to hold down the Fn key while pressing it.
Allow a few seconds for the projector to sync up after changing
the setting.
Displaying and Adjusting the Image 21
■
If the function key doesn’t permit you to display simultaneously
on both screens, you should check your monitor settings to make
sure both the LCD screen and the external monitor port are
enabled.
From the Control Panel, open the Display utility. In the Display
Properties dialog box, click the Settings tab, then click
Advanced. The method for adjusting the settings varies by
brand; you may need to click a Monitor tab, then make sure the
external Monitor port is set as your primary display and/or
enabled. See your computer’s documentation or online help for
details.
If you’re using Mac OS X:
You may need to set up your system to display on the projector screen
as well as the LCD screen. Follow these steps:
1. From the Apple® menu, select System Preferences, then select
Displays.
2. Make sure the VGA Display or Color LCD dialog box is selected.
3. Click the Arrangement (or Arrange) tab.
Make sure
Mirror Displays
is checked
4. Make sure the Mirror Displays checkbox is selected.
22
Displaying and Adjusting the Image
Adjusting the Image
Once you see your image, you need to make certain adjustments:
■
If the image is too high or too low, reposition it as described
below.
■
To focus or zoom your image, see page 24.
■
If the image isn’t square, see page 24.
■
To quickly adjust the color, brightness, or contrast, see page 28.
■
To change the image aspect ratio, see page 28.
■
If you need to fine-tune the image and/or sound, see Chapter 6.
Adjusting the Height of the Image
If the image is too low on the screen, you can use the front adjustable
foot to raise it.
1. Stand behind the projector. Press the foot release lever up and lift
the front of the projector.
2. Once the image is positioned where you want it, release the lever
to lock the foot in position.
3. If necessary, you can fine-tune the height or level the image by
turning any of the projector’s adjustable feet.
Raising the projector causes the image to distort or “keystone,” but
you can correct the shape as described on page 24.
Displaying and Adjusting the Image 23
Focusing and Zooming the Image
Turn the focus ring on the projector to sharpen the image.
Turn the zoom ring to reduce or enlarge the image.
Focus
Zoom
If the image still isn’t large enough, you may need to move the
projector farther away from the screen. You can also use the E-Zoom
buttons on the remote control to zoom in on a portion of the image.
See page 32 for instructions.
Adjusting the Image Shape
You can maintain a square or rectangular image by placing the
projector directly in front of the screen and keeping it level. This also
produces the best picture quality. If the projector is tilted up or placed
at an angle, you’ll need to correct the image shape by using one of the
functions described below.
Automatic Image Adjustment
Use the projector’s Quick Setup feature to set up quickly for a
presentation. This function automatically corrects the shape and
position of the image to fit on a screen with a 4:3 aspect ratio. It can
correct image distortion when the projector is placed up to a 45° angle
to the screen (vertically) and 20° (horizontally).
1. Press the Quick Setup button on the projector’s control panel.
24
Displaying and Adjusting the Image
You see a projected message:
2. Aim the projector so the message appears near the middle of the
screen. Then use the zoom ring to enlarge the image so the white
frame (not shown above) extends beyond the edges of the screen
on all sides.
3. Press the Quick Setup button again. Two white boxes flash
momentarily onto the screen, and the adjustment is complete.
Your projected image now fits on the screen (some slight overlap
is normal).
The Quick Setup adjustment is retained when the projector is turned
off. If the projector is installed in a fixed location, you won’t need to
repeat the adjustment each time you turn it on. To fine-tune the
Quick Setup adjustment, use Quick Corner® (below).
Using Quick Corner
Use Quick Corner to adjust the shape and size of the image when it’s
uneven on all sides, or to finely adjust the image after performing
Quick Setup. If you just used Quick Setup, you can use the projector’s
arrow buttons to make the Quick Corner adjustment. If not, you’ll
have to select Quick Corner as follows:
1. Press the Menu button on the remote control or on the
projector’s control panel.
2. Select the Settings menu and press Enter.
note
If Quick Setup did not
detect the edges of your
screen (for example, if you’re
projecting on a wall), then
the arrow buttons will be in
Keystone correction mode
after performing Quick
Setup (see page 26).
3. From the Settings menu, select Keystone and press Enter.
4. Select Quick Corner and press Enter.
Displaying and Adjusting the Image 25
You see this screen:
5. Use the
pointer button on the remote control (or the arrow
buttons on the projector) to select the corner you want to adjust,
and press Enter.
6. Use the
pointer button on the remote control (or the arrow
buttons on the projector) to adjust the shape.
7. Repeat steps 5 and 6 as needed to adjust any remaining corners.
8. When done, press Menu to exit the menu system.
Using Keystone Correction
The projector automatically corrects vertical keystone distortion when
it is tilted within a range of 30° up or down.
Projector tilted up
Corrected image
Projector tilted down
It takes about one second after projection starts for the image to be
corrected. During this time, a vertical keystone correction gauge
appears on the screen. If keystone correction isn’t automatically
performed, you may need to turn on the Auto V-Keystone setting in
the projector’s menu system (see page 143).
26
Displaying and Adjusting the Image
You can manually adjust the shape of the image to compensate for
vertical and horizontal keystone distortion. First make sure the
Keystone setting in the projector’s menu system is set to H-Keystone
or V-Keystone:
1. Press the Menu button on the remote control (or on the
projector’s control panel).
note
The projector’s arrow
buttons may already be in
Keystone correction mode if
you haven’t used Quick
Setup or Quick Corner.
2. Select the Settings menu and press Enter.
3. From the Settings menu, select Keystone and press Enter.
4. Select H/V-Keystone and press Enter.
5. Select H-Keystone (for horizontal adjustment) or V-Keystone
(for vertical adjustment) and use the l and r arrow buttons to
adjust the shape of the image.
Vertical
keystone
adjustment
Horizontal
keystone
adjustment
If the image becomes smaller, use the zoom ring to enlarge the image
so it fits the screen. If the image contains faint lines or a gridlike
pattern, decrease the sharpness setting (see page 139).
Displaying and Adjusting the Image 27
Selecting the Color Mode
The Color Mode adjusts the brightness, contrast, and color for various
common viewing environments. Use this setting to quickly obtain a
good picture.
Press the Color Mode button on the remote control, and then select
from one of these options:
■
Presentation: For making color presentations in a bright room.
■
Text: For making black-and-white presentations in a bright
room.
■
Theatre: For watching movies in a darkened room; gives images a
natural tone.
■
Photo: For vivid, high-contrast still images in a bright room.
■
Sports: For vivid TV images projected in a bright room (video,
S-video, or composite video only).
■
sRGB: Matches the color palette of standard sRGB computer
displays.
■
Blackboard: Projects accurate colors on a green chalkboard
(adjusts the white point).
■
Customized: For manual color adjustment (see page 139).
■
Game: Increases brightness when playing video games or
watching TV in a bright room. Emphasizes dark gradations.
Resizing Video Images
You can use the Resize button on the remote control to adjust how
an image fits into the display area.
Press Resize to switch the aspect ratio between 4:3 and 16:9. This lets
you play certain digital video images or movies recorded on certain
DVDs in 16:9 widescreen format. You can also select 16:9 (Up) or
16:9 (Down) to reposition videos to accommodate subtitles or
supertitles.
For computer images, select Normal to automatically resize the image
and make the best use of the display area.
28
Displaying and Adjusting the Image
2
Presenting With the Remote
Control
T
he projector includes a number of tools to enhance your
presentation. All of them can be accessed using the remote control,
which lets you operate the projector from anywhere in the room—up
to 20 feet (6 meters) away.
You can use the remote control to adjust the picture and sound
(page 30) or as a pointer to highlight your presentation (page 33).
You can also use it as a wireless mouse when projecting from a
computer (page 35), or to control two or more projectors at the same
time (page 36).
This chapter covers:
■
Using the remote control
■
Controlling the picture and sound
■
Highlighting your presentation
■
Operating your computer with the remote control
■
Operating two or more projectors with the remote control
29
note
If a button is pressed longer
than 30 seconds, the remote
control stops operating to
conserve power. When you
release the button, normal
operation resumes.
Using the Remote Control
Make sure batteries are installed as described on page 179. Follow
these tips for using the remote control:
■
Point the remote control at the front of the projector or at the
screen.
■
Stand within 20 feet (6 meters) of the projector.
■
Avoid using the remote under bright fluorescent lamps or in
direct sunlight, or the projector may not respond properly.
Controlling the Picture and Sound
You can use the remote control to preview and select your picture
sources, temporarily turn off the picture and sound, freeze the action,
zoom in on the picture, and adjust the volume.
Switching Between Picture Sources
If your projector is connected to more than one computer and/or
video source, you can switch between the different sources:
30
■
The easiest way to select your source is to press the Search button
on the remote control (or the Source Search button on the
projector) repeatedly until you see the image you want on the
screen.
■
On the remote control, there are several Source buttons.
Use them to switch between equipment connected to the port
identified on each button.
Presenting With the Remote Control
After you select a source, the screen goes dark for a moment before the
image appears.
Turning Off the Picture and Sound
You can temporarily turn off the image and sound when you want to
redirect your audience’s attention. There are two ways to do this:
■
Close the A/V mute slide, as shown below:
■
Press the A/V Mute button on the remote control. This turns the
image black and stops the sound. To turn the image and sound
back on, press the button again.
You can have the screen turn blue when you press the A/V Mute
button. You can also have an image, such as a company logo,
display on the screen (see page 146).
Presenting With the Remote Control 31
Stopping Action
You can use the remote control to stop the action in your video or
computer image.
note
This function pauses the
image, not the sound.
Because the source continues
to transmit signals, when
you resume the action, it
won’t be at the point you
stopped it.
■
To stop the action and keep the current image on the screen, press
the Freeze button. The sound continues.
■
To restart it, press the Freeze button again.
Zooming Part of Your Image
You can zoom in on a portion of the image using the E-Zoom buttons
on the remote control.
1. Press the E-Zoom
button on the remote control.
You see a crosshair indicating the center of the zoom-in area.
2. Use the
pointer button to position the crosshair.
3. Continue pressing the E-Zoom
area up to 4 times.
button to enlarge the selected
4. While the image is enlarged, you can:
■
Use the
pointer button to move around the screen.
■
Press the E-Zoom
button to zoom out.
5. When done, press the ESC button to return the image to its
original size.
32
Presenting With the Remote Control
Controlling the Volume
To change the volume, press the
control.
or
button on the remote
note
To temporarily shut off the
sound and picture, press the
A/V Mute button or close
the A/V mute slide.
You can also adjust the volume using the projector’s menu system.
See page 143.
Highlighting Your Presentation
You can display a pointer to call out important information on the
screen. If you want to customize the pointer tool, you can choose from
three alternative shapes.
Using the Pointer Tool
1. To activate the pointer tool, press the Pointer button on the
remote control. A pointer appears on the screen.
Pointer
If you prefer to use a different style of pointer, see the instructions
in the next section.
Presenting With the Remote Control 33
2. Use the
pointer button on the remote control to position the
pointer on the screen.
3. When you’re done using the pointer, press Esc to clear the screen.
Customizing the Pointer Tool
You can change the appearance of the pointer by choosing from three
alternative shapes.
1. Press the Menu button on the remote control, highlight the
Settings menu, highlight Pointer Shape, and press Enter. You
can select one of the pointer shapes shown at the left.
2. Select the shape you want and press Enter.
3. Highlight Return and press Enter.
4. Press Menu to exit the menu system.
34
Presenting With the Remote Control
Operating Your Computer With the
Remote Control
If you connect a computer to the projector with a USB cable, as
described on page 42, then select Wireless Mouse for the USB
Type B setting in the Extended menu (see page 150), you can use the
remote control in place of your computer’s mouse. This gives you
more flexibility when delivering slideshow-style presentations, since
you won’t have to stand next to the computer to change slides.
■
Use the
Up and
Down buttons to move through a
®
Microsoft PowerPoint slideshow.
Page up or down
to change slides
in PowerPoint
Use to move pointer
on screen
Left-click
Right-click
■
Use the
pointer button to move the pointer on the screen.
■
Press the Enter button once to left-click, or press it twice to
double-click. Press the Esc button to right-click.
■
To drag-and-drop, hold down the Enter button. Then use the
pointer button to drag the object. When it’s where you want it,
release the Enter button.
Presenting With the Remote Control 35
Operating Two or More Projectors With
the Remote Control
If you’re using more than one projector, you can control all the
projectors—or just selected ones—by using the projector ID system.
To operate a projector, you have to set the remote control’s ID to
match that of the projector. Or you can control all the projectors at
once by setting the remote control’s ID to zero.
Setting the Projector ID
The projector’s default ID is set to Off. This lets it respond to
commands from any remote control. To change the ID, follow these
steps:
1. Press the Menu button on the remote control. You see the
projector’s menu screen.
2. Select Extended, then Projector ID.
3. Use the
pointer button to highlight the new ID, and press
Enter to select it.
4. When you’re done, press Menu to exit the menu system.
36
Presenting With the Remote Control
Setting the Remote Control ID
The remote control’s default ID is zero. This lets you operate any
projector. To set it to operate a specific projector, follow these steps:
1. Point the remote control at the projector you want to be able to
operate.
2. Press and hold the ID button on the remote control.
note
If you’re using a remote
control ID other than the
default ID of zero, you have
to set the ID each time you
turn on the projector.
3. While holding the ID button, press a numbered button on the
remote control (0 through 9) to select the desired ID. Select zero
to control all projectors, or select a number to match the ID of the
projector(s) you want to operate.
After setting the ID, you can check whether the remote control works
with a specific projector:
1. Point the remote control at the projector you want to check.
2. Press the ID button on the remote control. You see a message on
the screen like one of these:
If the message says the remote control is “On,” then you can use
the remote control to operate that projector. If it says “Off,” then
you have to change the ID of the remote control and/or projector
before operation is possible.
Presenting With the Remote Control 37
38
Presenting With the Remote Control
3
Connecting to Computers,
Cameras, and
Other Equipment
T
his chapter tells you how to connect the projector to a notebook or
desktop computer, and/or to video equipment, such as a VCR, DVD
player, or video camera. You can also connect the projector to a USB
storage device or digital camera, use it with a CompactFlash memory
card, or connect it to your local area network.
Follow the instructions in this chapter on:
■
Connecting to a computer
■
Connecting video equipment
■
Connecting an external monitor
■
Playing sound through the projector
■
Connecting to a digital camera or other USB device
■
Inserting a CompactFlash card
■
Inserting the wireless 802.11g/b/a module
■
Connecting a network cable
39
Connecting to a Computer
You can connect the projector to any computer that has a standard
video output (monitor) port, including desktop models, PC notebook
computers, MacBook, PowerBook, and iBook computers, and
hand-held devices.
You can also connect a Windows® computer to the Type B USB port
on the projector (see page 41). This allows you to connect an
additional computer to the projector. If you want to use the
projector’s remote control as a wireless mouse to operate your
computer during presentations, see page 42.
Connecting to the Computer Port
You can connect to the projector using the VGA computer cable that
came with it (the monitor port on your computer must be a mini
D-sub 15-pin port).
1. If you’re using the VGA computer cable, connect one end to the
projector’s Computer1 or Computer 2 port, and the other end
to your computer’s monitor port.
caution
Don’t try to force a
connector to fit a port with a
different shape or number of
pins. You may damage the
port or connector.
2. You may need to change the Computer1 Input or
Computer2 Input setting in the projector’s Signal menu to
RGB (see page 142).
40
Connecting to Computers, Cameras, and Other Equipment
3. You can connect an optional stereo mini-jack audio cable to play
sound through the projector (see page 50), or connect a USB
cable to use the remote control as a mouse (see page 42).
4. When you’ve finished making any connections, see page 17 for
instructions on turning on the projector and adjusting the
image.
Connecting to the USB Port
You can connect a Windows XP or Windows 2000 (SP4) computer to
the projector’s Type B (square)
USB port and project your
computer’s display. A USB 2.0 connection provides better picture
quality and response than USB 1.1.
The first time you connect a computer to the projector’s USB port,
software from the projector installs on your computer.
note
You can’t use the remote
mouse control function
when you use the USB port
to project your computer’s
display.
1. Follow the instructions beginning on page 17 to turn on the
projector and adjust the image.
2. Make sure the USB Type B setting under the projector’s
Extended menu is set to USB Display (see page 150).
3. Turn on your computer.
4. Locate the USB cable that came with your projector.
5. Connect the square end of the cable to the projector’s Type B
(square)
USB port.
USB cable
Connecting to Computers, Cameras, and Other Equipment 41
6. Connect the flat end of the cable to any available USB port on
your notebook or desktop computer.
Messages appear as the projector is recognized and the software
installation begins.
7. Follow the instructions on your computer screen to install the
Epson USB Display software. If you see a “Digital Signature
Warning,” select Continue. You will need to install the software
only the first time you connect.
After the software has been installed, you see your computer’s
desktop displayed by the projector. You can switch the projector
to other image sources using the Source buttons on the remote
control, and then switch back to your desktop display by pressing
EasyMP.
When you’re done projecting from your computer, disconnect
the USB cable.
Connecting the Cable for Remote Mouse
Control
note
For details on how to use the
remote control in place of
your computer’s mouse, see
page 35.
If you’ve connected a computer as described in this chapter (using the
Computer 1 or Computer 2 port) and set the USB Type B setting
under the projector’s Extended menu to Wireless Mouse (see
page 150), you can use the projector’s remote control as a wireless
mouse. This lets you control your computer and click through
slideshow-style presentations, such as PowerPoint, from up to 20 feet
(6 meters) away.
Move
cursor
Leftclick
Rightclick
42
Connecting to Computers, Cameras, and Other Equipment
The wireless mouse function is supported on systems with a USB port
running Windows Vista, Windows XP, 98SE, Me, or 2000, or
Mac OS® X 10.2.x to 10.4.x.
1. Connect the square end of a USB cable to the projector’s
USB port.
USB cable
2. Connect the flat end of the cable to any available USB port on
your notebook or desktop computer.
3. If necessary, configure your computer to work with an external
USB mouse. See your computer documentation for details.
Connecting to Computers, Cameras, and Other Equipment 43
Connecting to Video Equipment
RCA connector
(composite video)
S-video
connector
You can connect several video sources to the projector at the same
time. Before starting, look at your video equipment to determine its
available video output connections:
■
If your video player has a yellow RCA-style video output
connector, see “Connecting a Composite Video Source” on
page 45.
■
If your video player has an S-video connector, see “Connecting an
S-Video Source” on page 46.
■
If your video player has a component video port (three connectors
labeled either Y/Cb/Cr or Y/Pb/Pr), see “Connecting a
Component Video Source” on page 47.
■
If your video player has an RGB video port (either a single
connector for a VGA-style monitor cable or three connectors
labeled R/G/B), see “Connecting an RGB Video Source” on
page 48.
VGA connector
(RGB video)
After connecting video cables, you may also want to connect an audio
cable to play sound through the projector; see page 50.
44
Connecting to Computers, Cameras, and Other Equipment
Connecting a Composite Video Source
1. Locate an RCA-style video cable (one is usually provided with
your video equipment or you can purchase one from an
electronics dealer).
2. Connect the cable to the yellow video output connector on your
player and the yellow Video connector on the projector:
3. If you want to play sound through the projector, see page 50 for
instructions on connecting audio cables.
4. If you don’t need to make any other connections, see page 17 for
instructions on turning on the projector and adjusting the image.
Once the projector is turned on, select the image source: press the
Search button on the remote control or press the Source
Search button on the projector’s control panel repeatedly until
the image appears.
Connecting to Computers, Cameras, and Other Equipment 45
Connecting an S-Video Source
1. Locate an S-video cable (one is usually provided with your video
equipment or you can purchase one from Epson; see page 12).
2. Connect the cable to the S-video connector on your player and
the S-Video connector on the projector:
3. If you want to play sound through the projector, see page 50 for
instructions on connecting audio cables.
4. If you don’t need to make any other connections, see page 17 for
instructions on turning on the projector and adjusting the image.
Once the projector is turned on, select the image source: press the
Search button on the remote control or press the Source
Search button on the projector’s control panel repeatedly until
the image appears.
46
Connecting to Computers, Cameras, and Other Equipment
Connecting a Component Video Source
You will need a special cable to connect your component video
equipment to the HD15 (VGA-style) connector on the projector. You
can order the HD15 to component cable (ELPKC19) from Epson; see
page 13 for more information.
1. Locate an HD15 to component video cable or adapter.
2. Connect the cable to your player and the Computer 1 or
Computer 2 connector on the projector.
note
Be sure your video player is
not an RGB video source.
If you select the wrong
source, image quality may
suffer. Check your video
player’s documentation.
Also, make sure the
Computer Input setting in
the Signal menu is set to
Auto or Component Video
(see page 142).
HD15 to component
adapter
HD15 to component cable
(ELPKC19)
3. You may need to change the Computer1 Input or Computer2
Input setting in the projector’s Signal menu to Component
(see page 142).
4. If you want to play sound through the projector, see page 50 for
instructions on connecting audio cables.
5. If you don’t need to make any other connections, see page 17 for
instructions on turning on the projector and adjusting the image.
Once the projector is turned on, select the image source: press the
Search button on the remote control or press the Source
Search button on the projector’s control panel repeatedly until
the image appears.
Connecting to Computers, Cameras, and Other Equipment 47
Connecting an RGB Video Source
note
Be sure your video player is
not a component video
source. If you select the
wrong source, image quality
may suffer. Check your
video player’s
documentation.
1. Locate the VGA computer cable provided with the projector.
2. Connect the cable to the video port on your player and
the Computer1 or Computer2 port on the projector.
3. You may need to change the Computer1 Input or
Computer2 Input setting in the projector’s Signal menu
to RGB (see page 142).
4. If you want to play sound through the projector, see page 50 for
instructions on connecting audio cables.
5. If you don’t need to make any other connections, see page 17 for
instructions on turning on the projector and adjusting the image.
Once the projector is turned on, select the image source: press the
Search button on the remote control or press the Source
Search button on the projector’s control panel repeatedly until
the image appears.
48
Connecting to Computers, Cameras, and Other Equipment
Connecting an External Monitor
If you want to monitor your computer presentation close-up (on a
monitor placed beside the projector) as well as on the screen, you can
connect an external monitor. You can use it to check on your
presentation even if you’ve pressed the A/V Mute button or switched
to a different picture source.
First make sure your computer’s VGA cable is connected to the
projector’s Computer1 port (see page 40). Then connect your
monitor to the projector’s Monitor Out port, as shown:
note
The monitor cannot display
component video, nor
computer images via the
Computer2 or USB port.
Some LCD monitors may
not be able to display the
image correctly. If you have
trouble displaying the
image, connect a multiscan
monitor. If you’re projecting
computer images, make sure
the computer’s refresh rate is
set to 65 Hz or greater.
Connecting to Computers, Cameras, and Other Equipment 49
Playing Sound Through the Projector
You can play sound through the projector’s speaker system or attach
an external speaker system.
To play sound through the projector, follow these steps:
1. Locate the appropriate cable and connect it to the Audio jack on
the projector.
■
If you have equipment connected to the Computer 1 or
Computer 2 port, use a stereo mini-jack cable. Connect the
cable to the Audio1 port (for Computer1) or the Audio2
port (for Computer2).
■
If you have equipment connected to the Video or S-Video
port, connect an RCA-style audio cable to L-Audio-R.
2. Connect the other end of the cable to the audio output
connector(s) on your computer or video equipment.
50
Connecting to Computers, Cameras, and Other Equipment
Connecting External Speakers
You can output sound to external speakers with built-in amplifiers.
When you play sound through external speakers, the projector’s
built-in speaker system is disabled.
1. Locate the appropriate cable to connect your speakers.
Depending on your speakers, you may be able to use a
commercially available audio cable with a stereo mini-jack
connector on one end and pin jacks on the other end. For some
speakers, you may have to purchase a special cable or use an
adapter.
2. Connect the stereo mini-jack end of the audio cable to the
Audio Out port on the projector.
3. Connect the other end of the cable to your speakers.
The projector’s internal speaker system is disabled while sound is
output to external speakers. You can use the remote control to adjust
the volume.
Connecting to Computers, Cameras, and Other Equipment 51
Connecting to a Digital Camera or
Other Device
note
Use a cable less than 10 feet
(3 meters) long and connect
the camera directly to the
projector. Your projector
may not function correctly if
you use a longer cable or
connect your camera to a
USB hub.
You can connect your digital camera, USB flash memory drive, USB
hard drive, or multimedia storage viewer, such as the Epson P-5000 or
Apple® iPod.® Use the USB cable specified for your device. Then you
can use your device’s slideshow function or the projector’s EasyMP
PC Free feature (see page 111) to present images.
1. Connect the flat end of the USB cable to the flat
on the projector, as shown.
USB port
If you connect a USB hard
drive, make sure you use the
AC adapter to power the
hard drive.
The slideshow function on
some devices may not work
with the USB connection.
2. Connect the other end of the cable to your camera or other
device.
Removing the USB Cable
If you’re using PC Free mode to project your images, exit PC Free
mode before you remove the USB cable from the projector.
1. Position the cursor over the Exit button in the upper right corner
of the PC Free screen.
2. Press the Enter button on the remote control to close PC Free
mode.
3. Disconnect the USB cable.
52
Connecting to Computers, Cameras, and Other Equipment
Inserting a CompactFlash Card
You can use a CompactFlash card to store images, movies, and
Scenario files. This lets you project your files without connecting to a
laptop or PC. To place your files on the card, copy them from your
computer to the card using a card reader.
Insert the CompactFlash card face-up into the slot as shown:
The indicator light next to the slot comes on or flashes when the
CompactFlash card is in use. Do not remove the card when the light is
on or flashing.
Eject
button
note
The memory card slot also
accepts MicrodriveTM cards.
You can also use an SDTM
card, Memory Stick,® or
xD-Picture CardTM by
inserting it in a
CompactFlash adapter.
caution
Do not remove the card
when the indicator light is
on or flashing, or you may
damage the card or
projector.
Indicator
light
To remove the card, press the eject button next to the card slot.
The button pops out. Press the button again to eject the card.
Connecting to Computers, Cameras, and Other Equipment 53
Inserting the Wireless 802.11g/b/a
Module
caution
Use only the Epson
802.11g/b/a wireless module
in the projector.
To use the projector over a wireless network, you need to install the
projector’s wireless LAN module (included). Once the module is
installed, see page 57 to configure the projector and your network.
1. Insert the wireless LAN module that came with your projector.
caution
Never remove the module
while its indicator light is
green or when projecting
wirelessly. You may damage
the module or lose data.
54
2. Turn the projector over and insert the included screw to secure
the module and keep it from being easily removed.
Connecting to Computers, Cameras, and Other Equipment
Connecting a Network Cable
To connect the projector to your local area network (LAN), use a
commercially available 100baseTX or 10baseT network cable. To
ensure proper data transmission, use a Category 5 shielded cable or
better.
Connect the cable to the projector and your network port as shown:
LAN port
Connecting to Computers, Cameras, and Other Equipment 55
56
Connecting to Computers, Cameras, and Other Equipment
4l
Presenting Through a
Wireless Network
T
his chapter tells you how to send pictures to the projector through
a wireless network. Using EMP NS Connection, you can project
images shown on your computer screen—including text, graphics,
and video—directly to your audience. If you have Windows Vista,
you can also use the Network Projector feature to communicate with
your network-connected projector without installing any software.
You’ll find instructions in this chapter on:
■
Starting EasyMP
■
Configuring basic settings
■
Connecting to the projector in Ad Hoc (computer-to-computer)
mode or Access Point (infrastructure) mode
■
Using wireless security options
■
Projecting wirelessly
■
Multi-screen projection
■
Projecting video clips
■
Using special presentation modes
■
Using Windows Vista to connect to the projector
Before starting, make sure you’ve installed the wireless network
module as described on page 54. You must also install the EMP
NS Connection software as described on page 199 for each computer
you connect to the projector. Then follow the steps in this chapter to
start EasyMP, configure your projector and computer, and run EMP
NS Connection.
57
Starting EasyMP
note
Use only the Epson
802.11a/b/g wireless module
in the projector.
If you see a message asking
you to insert a LAN or
memory card, check to make
sure your 802.11 a/b/g
module is properly inserted
(see page 54).
Before connecting to the projector, you have to switch it to EasyMP
mode. Follow these steps:
1. Point the remote control at the projector and press the P Power
button.
2. Press the EasyMP button on the remote control to select EasyMP
as the source.
You see this screen. The network settings appear in the lower left.
3. If you’ve already set up your computer and projector for the mode
you want to use—Ad Hoc mode (also called computer-tocomputer mode) or Access Point mode (also called infrastructure
mode)—skip to “Projecting Over a Network” on page 89.
Otherwise, continue with the next section.
58
Presenting Through a Wireless Network
Configuring Basic Settings
You can give your projector a unique name, enable a projector
keyword, or create a password for controlling the projector using your
computer’s Web browser.
1. Press the Menu button, then choose Network and press Enter.
2. Choose Network Configuration and press Enter.
3. Choose Basic and press Enter.
You see the following screen:
4. Make sure the projector has a unique name, so you can identify it
when connecting to it from your computer.
If you need to rename it, highlight the Projector Name text box
then press Enter.
Presenting Through a Wireless Network 59
5. Press the
pointer button to select individual letters; then press
Enter to input a character. To add a blank space or to navigate
backward and forward through the input text, highlight the
arrows and press Enter. To toggle symbol settings or capital
letters, highlight the option and press Enter. When you’re done,
highlight Finish and press Enter.
6. If you want to create a password for remote access to the
projector, highlight Web Control Password, press Enter, and
enter a password of up to 8 alphanumeric characters. When you’re
done, highlight Finish and press Enter.
7. If you want to set up a security keyword so that only people who
are in the same room as the projector can access it, turn Projector
keyword on. When you connect to the projector, a randomized
four-digit number or “keyword” is displayed on the screen. When
prompted by NS Connection, enter the keyword on your
computer to connect to the projector (see page 91).
note
You can interrupt projection
even when a keyword is
used. Press the Esc button
on the remote control and
select the Close option.
60
8. If you want to prevent others from overwriting or deleting files on
a CompactFlash card without permission, enter a password of up
to 16 characters for the Network Drive Password.
9. When you’re done making these settings, select Return, select
Setup complete, and then select Yes to confirm that you want
to save the changes. Press Menu to exit the menu system.
Presenting Through a Wireless Network
Configuring the Connection
You can use NS Connection to connect to the projector and send
images wirelessly in two modes: Ad Hoc mode or Access Point mode.
■
■
Ad Hoc mode (computer-to-computer mode) lets you connect
just one computer to the projector at a time; it’s easy to set up,
and the only equipment you need is a computer with a wireless
(802.11g, 802.11b, or 802.11a) network card or adapter, or a
Macintosh® with an AirPort® or AirPort Extreme card. When
you connect to the projector in this mode, your connection to
other wireless networks or devices is broken; you can connect to
the projector only.
Access Point mode (infrastructure mode) lets multiple computers
access the projector at the same time and easily trade off control
over the projector. To use Access Point mode, you need a wireless
(802.11a, 802.11b, or 802.11g) access point or an AirPort
Extreme (or AirPort) base station, and one or more computers
with wireless network cards or adapters.
Follow the instructions below for the mode you want to use.
Using Ad Hoc Mode
To use Ad Hoc (computer-to-computer) mode, adjust your projector
and wireless card or adapter settings as described in this section.
Configuring the Projector
1. Press the Menu button, then choose Network and press Enter.
note
Make sure you’ve installed
the NS Connection software
as described on page 199.
To connect to the projector
over a wireless network, your
computer must be running
Windows 2000, XP, or
Vista. Your Mac® must be
running Mac OS X 10.3 or
later. See page 199 for
complete system
requirements for projecting
wirelessly.
Access Point mode
(infrastructure mode) is
required to achieve transfer
speeds up to 54MB/sec on an
802.11g network. Ad Hoc
mode (computer-tocomputer mode) limits
network connections to
11MB/sec. This is a
standard specification of
802.11g networking.
2. Choose Network Configuration and press Enter.
3. Choose Wireless LAN and press Enter.
Presenting Through a Wireless Network 61
You see this screen:
4. Make sure Quick is selected for the Connection mode. If not, use
the
pointer button on the remote control to highlight Quick,
then press Enter to select it.
note
If you are using a
WPS-compatible access
point, see page 78 for
connection information.
5. If your network is using 802.11a, use the
pointer button on
the remote control to highlight 802.11a, then press Enter to
select it.
6. If your computer’s network card supports an SSID (or ESSID)
name (see page 66), highlight the SSID text box, press Enter, and
enter a name.
Press the
pointer button to select individual letters; then press
Enter to input a character. To add a blank space or to navigate
backward and forward through the input text, highlight the
arrows and press Enter. To toggle symbol settings or capital
letters, highlight the option and press Enter. When you’re done,
highlight Finish and press Enter.
62
Presenting Through a Wireless Network
Note that the SSID is case-sensitive (if you enter the name in
uppercase on the projector, you must type it the same way on the
computer connecting to the projector).
7. If you want to prevent the SSID from being displayed on the
standby screen, set the SSID Display option to Off.
8. To prevent the IP address from appearing on the standby screen,
set the IP Address Display setting to Off.
9. When you’re done making these settings, select Return, select
Setup complete, and then select Yes to confirm that you want
to save the changes. Press Menu to exit the menu system.
Now you’re ready to set up your computer to project wirelessly. Go to
“Configuring the Network Settings for Windows” below, or “Setting
Up Your Mac for Ad Hoc Mode” on page 66.
Presenting Through a Wireless Network 63
Configuring the Network Settings for Windows
Before connecting to the projector, you need to make sure the settings
for your notebook’s or PC’s network card match the settings you
entered for the projector.
note
On some Windows systems,
you can right-click
My Network Places or
Network Neighborhood
1. Access your wireless network Properties window. For example, in
Windows XP you would click Start > Control Panel > Network
and Internet Connections. Then click the Network
Connections icon. You see a screen similar to this:
on the desktop and select
Properties.
Settings may vary,
depending on your wireless
network adapter. See the
documentation for your
adapter for more
information.
Right-click and select Properties
64
Presenting Through a Wireless Network
2. Right-click the Wireless Network Connection icon and select
Properties. You see a screen similar to this:
Click here
3. Click the Configure button.
4. Click the Advanced tab. You see a screen similar to this:
Presenting Through a Wireless Network 65
5. Check your wireless card or adapter device settings. (Depending
on the type of card or adapter you’re using, some of the settings
may be different than those listed here.)
■
Set the Network Type to 802.11 Ad Hoc.
■
Set the SSID to match the name you assigned to the
projector’s SSID.
■
Make sure Encryption is Disabled.
note
When you connect in Ad
Hoc mode, your connection
to other wireless networks or
devices is broken. If you need
to remain connected to your
wireless network, use Access
Point mode, as described on
page 68. Also, make sure
you reconnect to your
original wireless network
when you are done using the
projector.
6. Click the General tab and make sure that your wireless card or
adapter is enabled.
7. When you’re done, click OK to close the Properties dialog box.
Now you’re ready to connect to the projector. See “Projecting Over a
Network” on page 89.
Setting Up Your Mac for Ad Hoc Mode
Your AirPort software is automatically configured to allow your Mac
to detect both computer-to-computer (Ad Hoc) and Access Point
networks.
Typically, you only need to select your projector’s ESSID from the
AirPort status menu on the Mac menu bar. If you’re having problems
detecting the projector, follow these steps:
1. From the Apple pull-down menu, select System Preferences.
2. Double-click the Network icon. You see the Network settings
window.
66
Presenting Through a Wireless Network
3. Make sure Location is set to Automatic.
Select
Automatic
Select Network Port
Configurations
note
If you don’t need the other
network port configurations,
disable them by deselecting
their checkboxes.
Then select AirPort
4. Select Network Port Configurations in the Show pull-down
menu.
5. Under Port Configurations, select AirPort.
6. Click Apply Now. Then close the window.
When you connect in Ad
Hoc mode, your connection
to other wireless networks or
devices is broken. If you need
to remain connected to your
wireless network, use Access
Point mode, as described on
page 68. Also, make sure
you reconnect to your
original wireless network
when you are done using the
projector.
7. Click the AirPort icon on the menu bar at the top of the Mac
desktop. You see the AirPort status menu:
Choose the SSID you
assigned to the
projector
8. Check to make sure AirPort is turned on.
9. Select your projector’s SSID.
Presenting Through a Wireless Network 67
Using Access Point Mode
To use Access Point (infrastructure) mode, first adjust your projector
and wireless access point or AirPort base station settings as described
in this section.
Configuring the Projector
1. Press the Menu button, then choose Network and press Enter.
2. Choose Network Configuration and press Enter.
3. Choose Wireless LAN and press Enter. You see this screen:
4. Make sure Advanced is selected for the Connection mode. If
not, use the
pointer button on the remote control to highlight
Advanced, then press Enter to select it.
note
If you are using a
WPS-compatible access
point, see page 78 for
connection information.
68
5. If your network is using 802.11a, use the
pointer button on
the remote control to highlight 802.11a, then press Enter to
select it.
6. To enable your computer to find the projector on the network,
you need to enter the SSID name of your access point or AirPort
network in the SSID text box. (The name of your AirPort
network may be different from that of your AirPort base station;
select your base station in the AirPort Admin utility and click
Configure to check the name of your network.)
Presenting Through a Wireless Network
Highlight the SSID text box, press Enter, and enter a name as
follows:
Press the
pointer button to select individual letters; then press
Enter to input a character. To add a blank space or to navigate
backward and forward through the input text, highlight the
arrows and press Enter. To toggle symbol settings or capital
letters, highlight the option and press Enter. When you’re done,
highlight Finish and press Enter.
Note that the SSID is case-sensitive (if you enter the name in
uppercase on the projector, you must type it the same way on the
computer connecting to the projector).
7. If your access point assigns IP addresses automatically, turn on
DHCP. Otherwise, turn off DHCP and enter the following
information:
■
IP address: Enter the IP address you want to assign to the
projector. It must be formatted like other addresses on the
network. The last section should be unique.
■
Subnet mask: For example: 255.255.255.000, but this
depends on how your network is set up.
■
Gateway address: Enter the IP address that was assigned to
the access point or AirPort base station when it was set up.
8. If you want to prevent the SSID from being displayed on the
standby screen, set the SSID Display option to Off.
9. To prevent the IP address from appearing on the standby screen,
set the IP Address Display setting to Off.
note
For specific details about
your network, please consult
your network administrator.
If you don’t know your
gateway or access point
address, see page 75. If
you’re using AirPort, start
the AirPort Admin utility,
select your base station and
click Configure. Then click
the Network tab to see your
base station’s IP address.
10. When you’re done making these settings, select Return, select
Setup complete, and then select Yes to confirm that you want
to save the changes. Press Menu to exit the menu system.
Presenting Through a Wireless Network 69
Now you’re ready to set up your computer for wireless projecting. Go
to “Configuring the Network Settings for Windows” below, or go to
“Setting Up Your Mac for Access Point Mode” on page 76. If you
want to enable security options for your network, see page 84 to set up
the option that your network uses on the projector.
Configuring the Network Settings for Windows
Before connecting to the projector, you need to make sure the settings
for your computer’s wireless card or adapter match the settings you
entered for the projector.
note
On some Windows systems,
you can right-click
My Network Places or
Network Neighborhood
on the desktop and select
Properties.
1. Access your wireless network Properties window. For example, in
Windows XP you would click Start > Control Panel > Network
and Internet Connections. Then click the Network
Connections icon. You see a screen similar to this:
Settings may vary,
depending on your wireless
network adapter. See the
documentation for your
adapter for more
information.
Right-click and select Properties
2. Right-click the Wireless Network Connection icon and select
Properties.
70
Presenting Through a Wireless Network
You see a screen similar to this:
Click here
3. Click the Configure button.
4. Click the Advanced tab. You see a screen like this:
Presenting Through a Wireless Network 71
5. Check your wireless card’s or adapter’s device settings.
(Depending on the type of card or adapter you’re using, some of
the settings may be different than those listed here.)
■
Set the Network Type to Infrastructure.
■
Set the SSID to match the name assigned to the access point
(which should also match the projector’s SSID).
■
Make sure Encryption is Disabled if you have not set up
encryption on the projector.
6. Click the General tab and make sure that your wireless card or
adapter is enabled.
7. When you’re done, click OK to close the wireless properties dialog
box.
8. Right-click the Wireless Network Connection icon again and
select Properties. You see this screen:
72
Presenting Through a Wireless Network
9. Select Internet Protocol and click the Properties button. You
see this screen:
10. If your access point uses DHCP, select Obtain an IP address
automatically. Otherwise select Use the following IP address
and Use the following DNS server addresses, then enter the
required information:
■
IP address: Type in the IP address you want to assign to the
computer. It must be formatted like other addresses on the
network. The last section must be unique.
■
Subnet mask: For example: 255.255.255.000, but this
note
For specific details about
your network, please consult
your network administrator.
depends on how your network is set up.
■
■
Default gateway: Enter the IP address that was assigned to
note
the access point when it was set up.
If you don’t know your
gateway or access point
address, see page 75.
Preferred DNS server/Alternate DNS server: Enter the IP
address of the DNS server(s) for your network.
11. When you’re done, click OK.
Presenting Through a Wireless Network 73
12. Click the Wireless Networks tab. (If you don’t see this tab, you
may need to enable your wireless card or adapter by clicking
Configure to access the device settings; then follow any
instructions on the screen to enable the device.)
You see a screen like this:
13. Verify that you’ve enabled your computer’s connection to the
access point. It should be listed with the small icon next to it,
indicating a connection.
If it’s not listed, click Configure and type the name of your access
point.
14. When you’re done making settings, click OK to close the dialog
box.
Now you’re ready to connect to the projector. See “Projecting Over a
Network” on page 89.
74
Presenting Through a Wireless Network
Checking the Gateway IP Address on Windows
If you’re entering IP addresses manually and need to find out the
gateway IP address (the IP address of your access point), make sure the
wireless connection to the access point is currently active, as described
in the previous section. Then follow these steps:
1. Access your wireless network Properties window. For example, in
Windows XP you would click Start > Control Panel > Network
and Internet Connections. Then click the Network
Connections icon. You see a screen similar to this:
note
If you cannot identify the
gateway address using this
Windows utility, use the
administrator’s utility
software that came with
your access point.
Right-click and select Status
2. Right-click the Wireless Network Connection icon and select
Status.
Presenting Through a Wireless Network 75
3. Click the Support tab. The gateway’s IP address is listed as
shown:
Gateway address
Setting Up Your Mac for Access Point Mode
Your AirPort software is automatically configured to allow your Mac
to detect Access Point networks.
Typically, you only need to select your AirPort network name from
the AirPort status menu on the Mac menu bar. If you’re having
problems connecting to the projector, follow these steps:
1. From the Apple pull-down menu, select System Preferences.
2. Click the Network icon. You see the Network settings window.
76
Presenting Through a Wireless Network
3. Make sure Location is set to Automatic.
note
If you don’t need the other
network ports, disable them
by deselecting their
checkboxes. If more than one
network port is enabled, the
projector software warns you
to turn off AirPort when you
first connect the projector.
Disregard this message.
Select
Automatic
Select Network Port
Configurations
Then select AirPort
4. Select Network Port Configurations in the Show pull-down
menu.
5. Under Port Configurations, select AirPort.
Your AirPort network and
base station names may be
different. To check or
change your AirPort
network name, start the
AirPort Admin utility, select
your base station, and click
Configure. Click Show
All Settings, then make
any changes you want on the
AirPort tab.
6. Click Apply Now. Then close the window.
7. Start the AirPort Admin utility. Select your base station, then
click Configure.
8. On the AirPort tab, make sure your AirPort network name
matches your projector’s SSID. If not, enter the projector’s SSID
in the AirPort Network text box and click Update.
9. If you turned DHCP on in your projector’s advanced menu, click
the Network tab and make sure the Distribute IP addresses
checkbox is selected. If you need to select it, click Update.
If you’re connecting to your
projector in static IP mode,
deselect the Distribute IP
addresses checkbox. Make
sure your projector’s gateway
address is identical to the
base station’s IP address,
and the first three segments
of the projector’s IP address
are identical to the first
three segments of the base
station’s IP address.
Presenting Through a Wireless Network 77
10. Click the AirPort icon on the menu bar at the top of the
Macintosh desktop. You see the AirPort status menu:
11. Check to make sure AirPort is turned on.
12. Select the name of your AirPort network.
Making a WPS (Wi-Fi Protected Setup)
Connection
If you are using a WPS-compatible access point, you can configure the
settings for the connection between the projector and the access point
from the projector’s Configuration menu using one of these methods:
78
■
Push Button Method
Press both the Enter button on the projector and the button on
the access point to make the SSID and security settings. This
method is recommended when the projector and access point are
close together.
■
PIN Code Method
With the PIN code method, you enter an 8-digit code from the
computer to enable the SSID and security settings. The
connection between the computer and the access point must have
already been established. (For connection instructions, refer to the
manual provided with the access point.) This method lets you
make the settings without having to press any buttons on the
projector, and is recommended when the projector is mounted on
the ceiling.
Presenting Through a Wireless Network
Follow these steps to open the WPS connection screen:
1. Press the Menu button to open the projector menu.
2. Select Network, then Network Configuration, and press Enter.
The Network Configuration screen is displayed.
3. Select Wireless LAN and press Enter.
Presenting Through a Wireless Network 79
4. Select To Setup Wizard, then press Enter. You see the WPS
(Wi-Fi Protected Setup) connection screen:
5. For the Push Button Method, follow the instructions below.
For the PIN Code Method, follow the instructions on page 82.
Using the Push Button Method
1. Select Push Button Method and press Enter. You see this screen:
2. Press the Enter button on the projector.
80
Presenting Through a Wireless Network
3. When prompted by the screen, press the WPS button on the
access point.
You see a message that WPS setup is complete.
4. Press the Enter button or the Esc button to return to the wireless
LAN setting page.
5. Select Setup Complete and press Enter.
6. Make sure Yes is selected and press Enter.
7. Press the Menu button to exit.
Presenting Through a Wireless Network 81
Using the PIN Code Method
Before you can make a connection using the PIN Code Method, a
connection must have already been established between the computer
and the access point. For details on how to make this connection, refer
to the manual provided with the access point.
1. Follow steps 1 through 4 on page 79 to access the WPS
Connection Screen.
2. Select PIN Code Method and press Enter. You see this screen:
3. From the computer, enter the displayed PIN code for the access
point, select Start Setup and then press Enter.
You see a progress meter on the screen.
82
Presenting Through a Wireless Network
4. When you see a message that WPS Setup is complete, press the
Enter or Esc button.
5. When you see the wireless LAN setting page, select Setup
Complete and press Enter. You see this screen:
6. Select Yes and press Enter to save the settings.
7. Press the Menu button and then close the configuration menu to
exit.
Presenting Through a Wireless Network 83
Using Wireless Security Options
You can use the following security options when connecting to the
projector wirelessly: WEP encryption, WPA security, EAP-TLS
certificate validation, or LEAP, EAP, or PEAP authentication. To set
these security features on your wireless network, see your
documentation or get help from your network administrator. See the
following sections to enable the security option on your projector:
■
“Enabling WEP Encryption” below
■
“Enabling WPA Security” on page 86
■
“Enabling EAP, LEAP, or PEAP Authentication” on page 87
■
“Enabling EAP-TLS Certificate Validation” on page 88
Enabling WEP Encryption
1. Press Menu on the remote control, then highlight Network and
press Enter.
2. Choose Network Configuration and press Enter.
3. Highlight Security and press Enter. Then press Enter again to
display the security options:
4. Highlight WEP and press Enter.
84
Presenting Through a Wireless Network
5. For the WEP encryption setting, highlight 128Bit or 64Bit and
press Enter.
6. For Format, highlight ASCII to enable text input or HEX to
enable hexadecimal input. Then press Enter.
7. If you chose 64Bit, choose Key ID 1, 2, 3, or 4.
note
Highlight the Encryption key text box that corresponds to the
Key ID you selected, then press Enter. Press the
pointer
button to select individual letters; then press Enter to input a
character. To add a blank space or to navigate backward and
forward through the input text, highlight the arrows and press
Enter. To toggle symbol settings or capital letters, highlight the
option and press Enter. When you’re done, highlight Finish and
press Enter.
Text input for WEP
encryption varies with
different access points; check
with your network
administrator. Try ASCII
first. If that doesn’t work,
try Text2 and then Text3.
8. Check with your network administrator for directions on entering
a key for your network, and follow these general guidelines:
■
For 128 bit WEP encryption with hexadecimal input, enter
26 characters, from 0 to 9 and from A to F.
■
For 64 bit WEP encryption with hexadecimal input, enter 10
characters, from 0 to 9 and from A to F.
■
For 128 bit WEP encryption with ASCII or text input, enter
13 alphanumeric characters.
■
For 64 bit WEP encryption with ASCII or text input, enter 5
alphanumeric characters.
9. When you’re done making these settings, select Return, select
Setup complete, and then select Yes to confirm that you want
to save the changes. Press Menu to exit the menu system.
Presenting Through a Wireless Network 85
Enabling WPA Security
1. Press Menu. Highlight Network and then press Enter.
2. Choose Network Configuration and press Enter.
3. Highlight Security and press Enter. Then press Enter again to
display the security options:
4. Choose WPA-PSK(TKIP), WPA-PSK(AES), WPA2-PSK(TKIP),
or WPA2-PSK(AES) and press Enter.
Highlight the PSK (pre-shared key) text box and press Enter.
Press the
pointer button to select individual letters; then press
Enter to input a character. To add a blank space or to navigate
backward and forward through the input text, highlight the
arrows and press Enter. To toggle symbol settings or capital
letters, highlight the option and press Enter. When you’re done,
highlight Finish and press Enter.
5. When you’re done making these settings, select Return, select
Setup complete, and then select Yes to confirm that you want
to save the changes. Press Menu to exit the menu system.
86
Presenting Through a Wireless Network
Enabling EAP, LEAP, or PEAP Authentication
1. Press Menu. Highlight Network and then press Enter.
2. Choose Network Configuration and press Enter.
3. Highlight Security and press Enter. Then press Enter again to
display the security options:
4. Choose EAP-TTLS/MD5, EAP-TTLS/MS-CHAPv2,
PEAP/MS-CHAPv2, PEAP/GTC, LEAP,
EAP-Fast/MS-CHAPv2, or EAP-FAST/GTC. Then press Enter.
5. Enter the user name and password that match the settings on your
authentication server.
Highlight the User name text box and press Enter. Press the
pointer button to select individual letters; then press Enter to
input a character. To add a blank space or to navigate backward
and forward through the input text, highlight the arrows and
press Enter. To toggle symbol settings or capital letters, highlight
the option and press Enter. When you’re done, highlight Finish
and press Enter.
Presenting Through a Wireless Network 87
Highlight the Password text box and press Enter. Enter the
password as you entered the User name.
6. When you’re done making these settings, select Return, select
Setup complete, and then select Yes to confirm that you want
to save the changes. Press Menu to exit the menu system.
Enabling EAP-TLS Certificate Validation
Once you have created an EAP-TLS certificate, follow the steps below
to enable it. (Contact your Network Administrator for more
information on obtaining or creating the certificate.)
1. Press Menu. Highlight Network and then press Enter.
2. Choose Network Configuration and press Enter.
3. Highlight Security and press Enter. Then press Enter again to
display the security options:
4. Choose EAP-TLS and press Enter. The certificate information
appears on the screen.
5. When you’re done, select Return, Setup complete, and then
Yes to confirm that you want to save the changes. Press Menu to
exit the menu system.
88
Presenting Through a Wireless Network
Projecting Over a Network
Once you’ve started EasyMP and set up your projector and computer
in either Ad Hoc (Quick) mode or Access Point (Advanced) mode, or
in the optional wired LAN mode, as described on page 154, follow
these steps to start NS Connection and project wirelessly over the
network:
1. Make sure you’ve set up your projector (see page 58).
2. Windows: Select Start > Programs or All Programs >
EPSON Projector > EMP NS Connection.
Macintosh: Double-click the EMP NS Connection icon in your
Applications folder.
3. The first time you start NS Connection, you see this dialog box.
Choose a connection mode and click OK.
4. If you see a message asking you to disable the firewall, click Yes to
make an exception for the projector and allow projection.
note
If you don’t see your network
adapter’s IP address, allow a
minute for it to appear. If
your access point or AirPort
base station uses DHCP
(Distribute IP addresses
setting is enabled for
AirPort), sometimes it takes
a minute for the server to
pick up the IP address.
Once you’ve selected the IP
address for your network
adapter, you won’t see the
Switch network dialog
box when you start
NS Connection. If you want
to change to a different
network adapter, click
Extension on the EMP NS
Connection dialog box, then
click Switch LAN on the
extension dialog box.
In Windows Vista, click Continue when the User Account
Control screen appears.
Presenting Through a Wireless Network 89
You see the screen below. (If you have previously started NS
Connection, this may be the first screen you see.)
note
If a projector is in use and is
“locked,” you won’t be able to
select it.
To lock the projector from
connection by other users
while you are connected, click
the Disable interrupt
connection checkbox.
De-select it to disable the lock
and allow connection by other
users.
If Microsoft PowerPoint is
already running when you
start the projection and you
see a message that says you
need to restart PowerPoint,
close and reopen PowerPoint
after starting NS Connection.
Select projector
If the connection is working properly, you see your projector
listed. If you have additional Epson projectors on the network,
they are also listed, along with their status.
The status is indicated next to each projector’s name.
5. Once the name of your projector appears, select it and click
Connect. If more than one projector is listed, you can select
additional ones and connect to them (up to four) at the same
time.
If the selected projector is already being used by another person,
you can still connect to it (unless it is “locked”); doing so
automatically disconnects the other user. If a projector is locked,
you won’t be able to connect to it when it is in use.
If you don’t see the projector, follow the suggestions on page 92.
90
Presenting Through a Wireless Network
6. If you set up the projector to prompt you for a keyword before
connecting, you see a screen like this one:
Enter keyword
Type in the four-digit number displayed on the EasyMP Network
screen and click OK.
7. Once the connection is established, you see your computer’s
image transmitted to the screen, and a floating control bar on
your computer desktop:
8. If necessary, you can drag the control bar out of the way on your
screen.
9. When you’re done with your presentation, click Disconnect on
the control bar.
Presenting Through a Wireless Network 91
Solving Connection Problems
If you don’t see your projector, check the following:
1. Make sure your wireless signal is strong enough to establish a
connection. If you have a Mac, check the AirPort icon on the Mac
menu bar. For Windows, see the documentation for your access
point or wireless network card or adapter.
note
If none of these suggestions
work, see the troubleshooting
information beginning on
page 191.
2. Make sure you’re trying to connect to the right network. In
Windows, verify that you’ve enabled your computer’s connection
to the access point or that your wireless card or adapter is enabled,
and that its SSID matches the projector’s SSID (or ESSID). On a
Macintosh, check the AirPort status menu (click the AirPort icon
on your menu bar) to make sure AirPort is turned on and the
projector’s SSID or your AirPort network is selected.
3. Make sure you aren’t projecting one of the EasyMP configuration
screens. (You should see a message that the projector is ready to
connect.) If you have to exit a configuration screen, restart NS
Connection.
note
The AirPort network name
may be different than the
AirPort base station name.
To check the network name,
start the AirPort Admin
utility, select your base
station, and click
Configure. Then click
Show All Settings. The
network name appears on
the AirPort tab.
4. Make sure the SSID for your projector matches the SSID for your
wireless card, adapter, or access point. If you have an AirPort base
station, make sure the projector’s SSID matches the AirPort
network name. Remember that the SSID is case-sensitive.
5. Check the IP address for both your projector and your wireless
card, adapter, access point, or AirPort base station. The first three
segments of the IP address should be identical. The last segment
of the projector’s IP address should be close, but not identical, to
the last segment of the IP address for your wireless interface,
access point, or base station.
6. Restart your computer and start NS Connection again.
7. If you still don’t see your projector, follow the instructions in
“Connecting in Advanced Connection Mode” on page 94 to
connect to the projector.
92
Presenting Through a Wireless Network
Using the Control Bar
From the control bar, you can access these NS Connection features:
Displays the Select target projector dialog box.
Stops projection of computer images while connecting to the
projector.
The projector projects the computer image.
Pauses projection of computer images. Click again to restart
projection.
Starts Presentation Mode for the selected projector. In
Presentation Mode, only your slideshow images are projected.
See page 103.
Displays the Projector Control screen, which allows you to
enable A/V Mute, switch the PC source, or switch the video
source.
Allows you to set up Multi-screen display and see a preview of
how the images will appear on each screen. See page 98.
Displays the Projector Settings dialog box.
note
Starts Movie Sending Mode for projecting MPEG2 and WMV
videos from your computer. See page 102.
Movie Sending Mode does
not work with DVD movies.
Disconnects the connection to the projector.
Changes which buttons are displayed on the control bar.
Clicking one of the buttons on the control bar may cause a submenu
to appear above the control bar.
When you’re done, click the arrow in the upper right corner to close
the submenu.
Presenting Through a Wireless Network 93
Connecting in Advanced Connection Mode
1. Click Manual search on the NS Connection screen.
2. Enter the IP address or the projector name for the projector you
want to connect to, and click OK.
The Projector is added to the EMP NS Connection screen.
If the search fails to find a projector with the specified IP address,
the searching icon turns into a question mark. If this happens, run
EasyMP on your projector (see page 58) to check the projector’s
IP address, then repeat this step.
3. Click the projector you want to connect to and click the Connect
button. If more than one projector is listed, you can select
additional projectors and connect to them at the same time.
94
Presenting Through a Wireless Network
4. If you are prompted for a keyword, enter the four-digit number
displayed on the EasyMP Network screen and click OK.
The computer’s image is transmitted to the projector and appears
on the screen. See page 91 for details about using the floating
control bar on your computer desktop.
Enabling Network Security
The projector includes the following network security options which
you can enable for network projection:
■
Data encryption
Encode and transmit data. Even if data is intercepted, it cannot be
deciphered. See page 96 to enable encryption.
■
Connection limitation (Authentication)
A user’s name and a password are registered in advance, which
means that only the registered wireless port can connect to the
network and prevents unauthorized third parties from connecting to
the network.
■
Firewall
Prevents unauthorized computer access by closing ports that are
not used.The security functions that can be used with this
projector vary depending on the connection mode of the wireless
LAN. Use the firewall function provided with your OS.
The security functions that can be used with this projector vary
depending on the connection mode:
■
Quick Connection Mode
note
The authentication and
firewall features are only
effective when the access
point for the connection
destination supports the
same functions.
Encrypted communication
■
Advanced Connection Mode
Encrypted communication, WEP, WPA-PSK (TKIP), WPA-PSK
(AES), WPA2-PSK (TKIP), WPA2-PSK (AES), EAP-TLS,
EAP-TTLS/MD5, EAP-TTLS/MS-CHAPv2,
PEAP/MS-CHAPv2, PEAP/GTC, LEAP,
EAP-FAST/MS-CHAPv2, EAP-FAST/GTC
Presenting Through a Wireless Network 95
Enabling Data Encryption
1. Click Set options on the main screen.
2. Click the General Settings tab and select the Encrypt
communications checkbox.
3. Click OK.
96
Presenting Through a Wireless Network
Enabling Network Security Options
You need to enable network security including WEP, WPA, EAP,
LEAP, or PEAP, or firewall settings on your network and on the
projector (see page 84). For network setting details, follow the
directions from your network administrator.
If using EAP, you need to make settings at the projector that match
the authentication server settings. Check with your network
administrator for details on RADIUS settings.
Presenting Through a Wireless Network 97
Multi-screen Projection
note
For a Mac, you have to
connect a monitor to the
computer and use the
multi-screen display
function. For Windows,
even if a monitor is not
connected, you can set a
virtual display by installing
the virtual display driver in
EMP NS Connection. See
page 201.
When using Multi-screen display, you can set each projector to
display a section of the screen or image, to create a single image
spanning a large area. Make sure the projectors are at least 3.6 feet
(1.1 meters) apart to avoid overheating.
Multi-screen projection is not supported in Windows Vista.
Here are some examples:
For Windows, when the real
monitor is connected as a
secondary monitor, the
image for that screen cannot
be projected.
You can adjust each
projector’s color to match the
images as closely as possible.
See page 151.
98
Presenting Through a Wireless Network
To set up multi-screen display in NS Connection, follow these steps:
1. Select the Use multi-display checkbox, then click Display
properties (Windows) or Display preferences (Macintosh).
Presenting Through a Wireless Network 99
2. Windows: On the Settings tab, drag the monitor icons to arrange
the positions of the displays.
Macintosh: Click the Arrangement button, then de-select the
Mirror Displays checkbox. Drag the displayed monitor icon and
place it where desired.
100
Presenting Through a Wireless Network
3. Close the Display Preferences (Windows) or System Preferences
(Macintosh) window, when you are done arranging the display
numbers.
4. To allocate projectors to each display, choose a number from the
menu under Display.
5. Click the Connect button when you are ready to project the
image.
6. You can use the
Screen Preview button on the NS
Connection toolbar to check the image on each screen.
Presenting Through a Wireless Network 101
Projecting Video Clips
note
Only MPEG1-Layer2
audio is supported. The
maximum supported
MPEG2 video resolution
is 720 × 480 NTSC or
720 × 756 PAL (without
audio).
You can project full-screen MPEG2 and WMV video clips with audio
in real time (30 frames per second). For best performance, advanced
wireless mode, 802.11g, or 802.11a are recommended.
1. Click the
Movie Sending Mode button on the NS
Connection toolbar.
2. If you are connected to more than one projector, select the one
you want to use for the video.
3. Click the Select file button. Locate the video you want to project
and click Open.
note
The video will be projected
on the screen, but will not
appear on the host
computer.
102
4. Use the standard playback buttons on the screen to start, pause,
rewind, and control other video functions.
5. When you’re finished projecting video, click the Close button on
the screen.
Presenting Through a Wireless Network
Using Special Presentation Modes
Your projector provides several features that allow you to show
presentation slides to your audience and hide other activity on your
laptop. Both work with PowerPoint in Windows and Keynote® on
Macintosh.
■
Presentation Mode displays only slides to your audience and hides
other activity on your computer.
■
Presenter View lets you see your notes and slideshow controls
while projecting your slides.
Using Presentation Mode
In Presentation Mode, the projector shows a black screen (or an image
of your choice) while you search for files or perform other activities on
your laptop. When you start a PowerPoint (Windows) or Keynote
(Mac) slideshow, the projector shows your slides.
1. Click the
Presentation Mode button on the NS Connection
toolbar. The projector displays a black screen with the Epson
logo.
2. Open your presentation in PowerPoint or Keynote.
3. In PowerPoint, open the Slide Show pull-down menu and select
Set Up Show. Set the Multiple monitors box to Display slide
show on Monitor 2. Then click OK.
4. In Keynote, select Preferences. Set the Presentation Mode to
Present on secondary display.
note
If you want to display an
image or logo instead of a
black screen, you can replace
the image.jpg file in the
EMP NS Connection V2.30
\Image folder. In windows,
this is located in C:\Program
Files \Epson Projector
\EMP NS Connection
V2.30 \image. On a Mac, it
is located in \Applications
\EMP NS Connection
V2.30 \Image. Disconnect
and then reconnect to the
projector after you replace
the image.
5. Start your slideshow. The projector displays your slides. When
you finish your slideshow, the projector again displays a black
screen.
6. When you want to exit Presentation Mode, click the
Presentation Mode button on the NS Connection toolbar.
Presenting Through a Wireless Network 103
Using Presenter View
Presenter View allows you to see your PowerPoint notes and controls
on your laptop while projecting only the presentation slides to your
audience. Follow these steps to set up and use Presenter View:
1. Make sure you have at least one EPSON Virtual Display enabled.
If you did not enable Virtual Displays when you installed NS
Connection, select EPSON Projector from Start > Programs or
All Programs. Select Add-Remove EPSON Virtual Display,
then check EPSON Virtual Display 1. If you see a message that
the driver has not passed Windows Logo testing, click Continue
Anyway. Then restart your computer.
2. Launch NS Connection as described on page 89.
3. Click Use multi-display, then click Display properties.
4. On the Display Properties screen in Windows, make sure your
Epson Projector Virtual Display Driver is selected, then check
Extend my Windows desktop onto this monitor and click
OK.
In the Mac Displays program, select the Arrangement tab and
uncheck the Mirror Displays setting to deselect it.
104
Presenting Through a Wireless Network
5. Set your projector to Display 2 (or the Virtual Display Driver you
selected in step 4) in NS Connection, then click Connect.
6. Open your presentation in PowerPoint or Keynote.
7. In Keynote, select Preferences.
Presenting Through a Wireless Network 105
In PowerPoint, open the Slide Show pull-down menu and select
Set Up Show.
8. In Keynote, set the Presentation Mode to Present on secondary
display.
In PowerPoint, set the Multiple monitors box to Display slide
show on Monitor 2 (or the monitor associated with your Epson
Virtual Display) and check Show Presenter View. Then click
OK.
9. Start your slideshow.
The projector displays the slides, and your laptop displays your
notes and controls.
106
Presenting Through a Wireless Network
Connecting With Windows Vista
If you have Windows Vista, you can use the Network Projector
function to connect to the projector without installing the EasyMP
software. This provides a quick, easy way to connect wirelessly,
though with limited capabilities. Not all the features available with
EMP NS Connection are possible when connecting using the Vista
network projector function. All performances are enhanced when you
use EMP NS Connection.
Follow these steps:
1. Turn on the projector.
note
Use only the Epson
802.11a/b/g wireless module
in the projector. If you see a
message asking you to insert
a LAN or memory card,
check to make sure your
802.11 a/b/g module is
properly inserted (see
page 54).
2. Press the EasyMP button on the remote control. The standby
screen appears.
3. From the Start menu on your computer, select All Programs,
Accessories, then Connect to a Network Projector. You see
this screen:
Presenting Through a Wireless Network 107
4. You can select the projector automatically or manually:
■
To let your computer search automatically for the projector,
select Search for a projector. You see this screen:
After locating the connected projectors, your computer lists
them on the screen. Select the one you want and then click
Connect.
■
To locate the projector by IP address, select Enter the
projector address. You see this screen:
Enter the IP address for the projector in the format shown.
Enter a password for the projector if one has been set. Then
click Connect.
108
Presenting Through a Wireless Network
5. If you need to pause your presentation, press the Pause button.
Click Resume when you are ready to continue.
6. When you want to disconnect from the projector, click the
Disconnect button.
Vista Network Projector Limitations
When you connect wirelessly to the projector using Windows Vista,
be aware of the following limitations:
■
You can connect to only one projector at a time.
■
You cannot connect the projector to a PC with a video output
resolution in excess of 1024 × 768 (XGA).
■
You cannot project a Windows Photo Gallery slideshow in
full-screen mode.
■
When using the optional network projector feature of the
Meeting Space function, set the display color quality on your PC
to Highest (32-bit).
■
Network presentation via wireless ad-hoc is not supported.
Presenting Through a Wireless Network 109
110
Presenting Through a Wireless Network
5
Presenting From a USB
Drive, Camera, or
CompactFlash Card
T
he projector’s EasyMP PC Free feature lets you give presentations
from a USB flash drive, digital camera, USB multicard reader, or
CompactFlash card. You can play movies, display graphics, or play a
scenario, a format that lets you create your own slideshow using
PowerPoint files, image files, and MPEG videos.
When a CompactFlash card is inserted and the projector is on a
network, you can also transfer files to the card over the network. See
page 53 for instructions.
note
Also make sure you’ve
installed the EMP
SlideMaker software
(available for Windows
only), as described on
page 201.
This chapter covers the following:
■
Presenting files from a USB drive or CompactFlash card
■
Presenting image files from a digital camera
■
Creating a slideshow on the fly
■
Creating a scenario
■
Transferring your scenario to a USB drive
■
Presenting scenarios
■
Supported file formats
111
Presenting Files From a USB Drive or
CompactFlash Card
This section explains how to project individual image or movie files
from a USB hard drive, flash memory drive, or CompactFlash card
using EasyMP. See page 133 for a list of the supported file formats.
Follow these steps to display images or play movies:
1. Connect your external drive or insert your CompactFlash
memory card into the projector (see page 52 or 53).
If you are using an external hard drive, plug in its power cord.
2. Turn on the projector, if it is not already on.
3. Select EasyMP as the source by pressing the EasyMP button on
the remote control.
If you have more than one card inserted in a multicard reader, use
the
pointer button on the remote control to select the card you
want to use and press Enter.
You see your folders and files displayed on the screen:
4. To open a folder, use the
pointer button on the remote
control to select the folder and press Enter. (Or press Esc and
select Open Folder from the pop-up menu.)
112
Presenting From a USB Drive, Camera, or CompactFlash Card
5. Position the cursor on the movie or image file you want to project
and press Enter. (Or press Esc and then select View Image or
Play Movie.)
If you selected an image, it is projected on the screen. If you want,
you can press the
pointer button up or down to rotate the
image while you’re viewing it.
note
If you exit the PC Free mode
on the projector, disconnect
and re-connect your USB
device before starting again.
If you selected a movie, it begins playing. You can use the
pointer button to control playback, as indicated on the
bottom of the screen.
6. To stop viewing an image or movie, press Esc. Then select Exit at
the top of the screen and press Enter.
See page 114 for instructions on playing a slideshow.
Presenting Image Files From a Digital
Camera
This section explains how to project individual image files on your
digital camera using EasyMP PC Free mode and a USB cable
connection.
Follow these steps:
1. Connect your digital camera (see page 52).
2. Turn on your digital camera.
3. Turn on the projector, if it is not already on.
4. Select EasyMP as the source by pressing the EasyMP button on
the remote control. If your camera complies with the DCIM
standard, you’ll see a DCIM folder appear on the EasyMP PC Free
screen.
note
Most digital cameras also
have the ability to play
internal slideshows.
Depending on the kind of
cable you have, you can
connect a camera with a
video or A/V out port to the
projector’s Video or
S-Video port and transmit
your camera’s slideshow
directly to the projector. You
must press the Video or
S-Video button on the
remote control to select the
correct signal source. See
pages 45 or 46 for details.
5. Use the
pointer button on the remote control to position the
cursor on the folder and press Enter (or press Esc and select
Open Folder from the pop-up menu).
When the folder opens, you see another folder with your
manufacturer’s name.
Presenting From a USB Drive, Camera, or CompactFlash Card 113
6. Select the folder and press Enter (or press Esc and select
Open Folder). You see your image files when the folder opens.
note
Make sure your camera
shows up on your desktop as
a drive letter. If it does, it is
probably a USB-mounted
device and will work with
the projector software. The
EasyMP software does not
support TWAIN-compliant
digital cameras.
7. Position the cursor on the file you want to project and press Enter
(or press Esc and select View Image).
While the image is projected on the screen, you can:
■
Press the
pointer button right to display the next image.
■
Press the
pointer button left to display the previous image.
■
Press the
pointer button up or down to rotate the image.
■
Press Enter to start a slideshow.
■
Press Esc to return to the folder screen.
8. To stop viewing images, select Exit at the top of the screen and
press Enter.
Creating a Slideshow
If you have a folder containing an assortment of images, you can
display them as a slideshow. See page 133 for a list of the supported
file formats.
Displaying the Slideshow
First make sure the images are stored in a folder on the USB drive or
CompactFlash memory card. Then follow these steps:
1. Connect your external drive (see page 52) or insert your
CompactFlash memory card (see page 53).
If you are using an external hard drive, plug in its power cord.
2. Turn on the projector, if it is not already on.
3. Select EasyMP as the source by pressing the EasyMP button on
the remote control.
If you have more than one card inserted in a multicard reader, use
the
pointer button on the remote control to select the card you
want to use and press Enter.
114
Presenting From a USB Drive, Camera, or CompactFlash Card
You see your files displayed on the screen:
4. Use the
pointer button to highlight the folder containing your
images. Then press Esc and select Play Slideshow from the
pop-up menu, or highlight the Slideshow button at the bottom
of the screen and press Enter.
The images contained in the folder are presented as a slideshow. Use
the remote control to run the slideshow as described in the next
section.
Controlling Your Slideshow
While your slideshow is running, use the remote control as follows:
■
Press Enter or
Page down to display the next slide or image,
or to begin playing a movie. You can also press right on the
pointer button.
■
Press
Page up to display the previous slide or image, or to
replay a movie. You can also press left on the
pointer button.
■
Press the
pointer button up or down to rotate a slide or image
on the screen.
■
To exit the slideshow at any point, press the Esc button. Select
Exit and press the Enter button.
Presenting From a USB Drive, Camera, or CompactFlash Card 115
Changing Timing and Other Settings
For each folder on the USB drive or memory card, you can set the
display timing for your slides and change several other display settings.
1. Select the folder containing the images for the slideshow settings
you want to change and press Enter.
note
You can also display the
Option screen by selecting
Option at the bottom of the
PC Free screen and pressing
Enter.
2. From the drop-down menu, use the pointer to select Option and
press Enter.
You see this screen:
3. Use the
pointer button to select from the following settings.
After making a selection, press Enter to save the change.
■
Display order
Lets you choose between displaying alphabetically by file
name or by image file date.
■
Sort Order
Determines the order in which the images are shown (from
first to last (Ascending) or last to first (Descending).
■
Continuous Play
Determines whether to repeat the display of images in the
folder.
116
Presenting From a USB Drive, Camera, or CompactFlash Card
■
Screen switching time
Sets the display time for each image. Choose No if you want
to change slides manually.
■
Effect
Lets you choose from various transitions between slides, such
as Dissolve or Wipe.
4. When you’re done, highlight OK and press Enter. Your changes
are permanently saved with each folder—even if you turn off the
projector or disconnect the drive or camera.
Creating a Scenario
A scenario is a combination of images, movies, and/or audio files that
you can present from a USB drive. The easiest way to create a scenario
is to drag and drop a PowerPoint file on the
EMP SlideMaker2
icon on your desktop. This automatically converts the file to a
scenario that you can save to the drive. Use this method if you have an
existing PowerPoint presentation that you want to transfer to the
projector.
If you prefer, you can create a scenario from scratch by combining
a selection of PowerPoint slides, other graphics, and even movies
(see page 119).
note
To create a scenario, you need
a USB drive connected to
your computer. Also make
sure you’ve installed the EMP
SlideMaker software
(available for Windows only),
as described on page 199.
Presenting From a USB Drive, Camera, or CompactFlash Card 117
Converting a PowerPoint File to a Scenario
Follow these steps to convert a PowerPoint file to a scenario. Once the
scenario is created, you can set up transitions as described on
page 123.
1. Make sure the EMP SlideMaker program is closed.
2. Locate the PowerPoint file you want to use in My Computer or
Windows Explorer.
3. Drag the file icon on top of the
your desktop.
EMP SlideMaker2 icon on
4. When you see a message about file conversion, click Continue.
5. When you see the next message, click Start.
EMP SlideMaker 2 starts and your PowerPoint slides open
one-by-one as they are converted. Do not interrupt this process or
your PowerPoint file won’t be completely converted.
6. When the scenario is done, click on the screen. The slideshow
closes and you see the following message:
7. Connect a USB device and browse to the drive, then click OK to
transfer your scenario file.
When the transfer is complete, you see a question asking whether you
want to autorun the scenario. See page 128 for instructions on the
autorun setting.
118
Presenting From a USB Drive, Camera, or CompactFlash Card
Creating a Scenario from Scratch
Use this method when you want to create a scenario from a selection
of PowerPoint slides, graphics, or movie files. You’ll need to set up
your scenario file and folder, build the scenario, set up transitions, and
check the scenario.
Setting Up the Scenario File and Folder
1. Double-click the
EMP SlideMaker2 icon on your computer’s
desktop (or click Start > Programs or All Programs > Epson
Projector > EMP SlideMaker2).
You see the EMP SlideMaker 2 screen with the Properties
window open as shown:
Presenting From a USB Drive, Camera, or CompactFlash Card 119
2. Type a name for your scenario file and folder that’s easy to
remember, using up to eight capital letters and numbers. Then
select from the following options:
note
The scenario name you enter
is also the name of the folder
for your scenario on your
hard drive.
■
The default location for the scenario file and folder is in the
\Program Files\EMP SlideMaker2 folder. Click Browse to
choose a new location.
■
Click Configure BGM(W) to play an audio file during the
scenario. A selection screen appears letting you choose a
.WAV file. After you select the file you want, click the arrow
button to the right of the option to play it.
■
The Background Color appears around images that don’t fill
the entire screen area. Select a new color, if desired.
■
Select the Image Quality for imported PowerPoint slides.
Higher-quality images look better on the screen but may take
longer to appear.
3. Click OK. You see the EMP SlideMaker 2 screen.
Continue with the instructions in the next section to build your
scenario.
note
You can also use the
instructions in this section to
add files to an existing
scenario.
120
Building a Scenario from Different Files
You can build your scenario from any of the following file types, either
alone or in combination with other file types:
■
PowerPoint slides, version 2000 through 2003
(file names have PPT extension)
■
JPEG files (with JPG extension)
■
Bitmap files (with BMP or DIB extension)
■
Movie files (with MPG, MP4, WMV or ASF extensions); MPG
files must be MPEG2 or MPEG4 (MPEG1 is not supported)
Presenting From a USB Drive, Camera, or CompactFlash Card
Follow these steps:
1. Use the navigation tools on the left side of the EMP SlideMaker 2
screen to locate the files you want to include in your scenario.
PowerPoint, JPEG, bitmap, and movie files appear as icons in the
file window.
Click to see
preview
Thumbnail
preview
2. Click the icon for each file that you want to preview. The preview
appears in the thumbnail preview window. If you click a
PowerPoint icon, thumbnail images are generated for all the slides
in the PowerPoint file. If you click a movie file, an illustration of a
filmstrip appears.
note
Thumbnail previews for
PowerPoint slides will not
appear if PowerPoint is not
installed on your computer.
Presenting From a USB Drive, Camera, or CompactFlash Card 121
3. Drag and drop the files you want to include in your scenario from
either the file window or thumbnail window into the scenario
window. (You can also double-click a thumbnail to add the file to
the scenario.)
Scenario cell
Check a slide’s
animation
effects here
note
Transition effects created in
PowerPoint look smoother
than those you add with
EMP SlideMaker 2.
To include a whole PowerPoint file (instead of individual slides),
drag the PowerPoint icon itself into the scenario window.
Dragging an entire file preserves the transitions set in PowerPoint.
4. Continue dragging files into the scenario window to build your
presentation. Each slide appears in a numbered cell. The cell
background color varies according to the type of file in the cell.
5. If you want, you can make changes to the scenario:
note
Unless you change the
transition setting, your slides
will automatically advance
after 30 seconds.
122
■
To rearrange cells, drag and drop them as necessary within
the scenario window.
■
To delete a cell, right-click the cell and select Cut.
■
To check the animation for a slide, click its cell. A section
appears at the bottom of the scenario window displaying each
animation operation. (Slides using animation have an .EMA
extension.)
You can also create transitions between slides, as described in the
next section.
Presenting From a USB Drive, Camera, or CompactFlash Card
6. When you’re done, click the Save button or choose Save from
the File menu. Then see page 128 to transfer the scenario to your
USB drive or CompactFlash card.
Setting Up Transitions
EMP SlideMaker 2 lets you set your slides to advance manually or
automatically after a specified period of time. You can also choose
from a variety of transition effects between slides.
1. Click the cell or cells you want to set up in the scenario window.
To select more than one cell, hold down the Ctrl key while you
click. To select all the cells, choose Select All from the Edit
menu. Selected cells turn yellow.
2. Right-click the selected cell or cells. The cell menu appears:
Cell
menu
3. Click Cell Properties. You see this dialog box:
Click to change
slides manually
Click to change slides automatically
Select transition effects
Presenting From a USB Drive, Camera, or CompactFlash Card 123
4. Choose how you want to advance to the next cell:
note
Transition effects look
smoother when you create
them in the PowerPoint file
itself and use that file to
create a scenario.
■
If you want to change slides manually using the remote
control, select On mouse click.
■
If you want your slides to advance automatically, set the
timing in the Automatically after box. You can set any
length of time between 1 and 1800 seconds (30 minutes).
Even if you select this setting, you can still change slides
manually using the remote control.
5. To add a transition effect (such as a dissolve, fade, or wipe), select
one of the Animation Effects settings and choose a Direction
setting, if applicable.
6. When you’re finished setting up the transition for the selected cell
or cells, click OK.
7. Click the Save button or choose Save from the File menu.
Continue with the steps in the next section when you’re ready to
transfer your scenario to a USB drive.
124
Presenting From a USB Drive, Camera, or CompactFlash Card
Checking Your Scenario
You can play your scenario before you transfer it to a USB drive to
make sure it looks and sounds the way you want it to.
1. Use the navigation tools in the folders window to locate the
scenario file you want to review. Click the file, then select
File > Open to open the scenario.
2. Click Scenario Option(s) > Scenario Preview. The Scenario
Preview window appears.
If the scenario is set to advance automatically (see page 124), it
begins to play. If it is set to advance each time you click the
mouse, click the
play button to go through your slides one by
one.
Status bar
Volume
Stop
Pause
Play
Rewind
Fast forward
3. Use the controls in the Scenario Preview window to pause, stop,
rewind, or fast forward your scenario. When you’re done, close
the window.
Presenting From a USB Drive, Camera, or CompactFlash Card 125
Editing a Scenario
You can edit a scenario stored on a USB storage device or
CompactFlash card to change the order in which images are projected,
or select whether to display individual images.
1. Press the
pointer button on the remote control to move the
cursor to the icon for the scenario you want to edit, and then press
the Esc button. You see this screen:
2. Select Edit Scenario and press the Enter button.
3. Use the cursor to select the desired slide, then press Esc.
126
Presenting From a USB Drive, Camera, or CompactFlash Card
■
To select whether to display a slide, select Show/Hide and
press Enter.
■
To change the order of the slide, select Move Files, then
move the cursor to the desired position and press Enter.
Select the slide
to be moved
Cursor for
selecting the
desired position
4. When you are done editing, use the remote control to select the
Edit Complete button and press Enter.
The edited content can be accessed only while the CompactFlash card
or USB storage device is inserted into the projector.
Presenting From a USB Drive, Camera, or CompactFlash Card 127
Transferring Your Scenario to a USB
Drive or CompactFlash Card
note
Don’t use Windows to copy
the scenario to your USB
drive or memory card, or it
may not play properly.
You must connect the USB
drive (or card reader) before
you select Send Scenario
from the Scenario Option(s)
menu. If you don’t, you
won’t be able to see the drive
in the drive selection
window. If this happens,
close and restart EMP
SlideMaker 2.
Once your scenario is saved, you can transfer it to a USB drive or
CompactFlash memory card. Be sure to use the transfer process
described below to ensure that the scenario plays properly:
1. Connect the USB drive. If you are using a CompactFlash card,
insert it in your computer or insert it in a card reader and connect
the card reader to your computer.
2. Start EMP SlideMaker 2 (see page 119).
3. Use the navigation tools in the folders window to locate the
scenario file you want to review. Click the file, then select
File > Open to open the scenario.
4. From the Scenario Option(s) menu, choose Send Scenario.
You see a drive selection window:
Select your
USB drive
5. Choose the drive (and folder) and click OK.
6. Click OK again to confirm. Your scenario is transferred to the
location you specified.
Once the scenario is transferred, you see this message about your
scenario’s autorun setting:
The autorun setting means that the scenario will start playing
whenever the projector is turned on (with the drive connected to
the projector).
128
Presenting From a USB Drive, Camera, or CompactFlash Card
7. Do one of the following:
■
If you don’t want the scenario to run automatically, click
Cancel. Skip to step 11 to remove the drive and insert it in
the projector.
■
If you want it to run automatically, click OK and continue
with the following instructions.
You see the Edit Autorun window:
8. To set a scenario to run automatically, select it from the list on the
left side of the screen and use the
arrow button to move it to
the list on the right.
9. Click the Revive box if you want your scenario to repeat
continuously. Clear the checkbox if you want it to play only once.
note
If more than one scenario is
set to run automatically,
they will play in the order
listed on this screen.
10. When done, click OK.
11. Disconnect the USB device or card reader, or remove the
CompactFlash card. See your computer’s documentation if you
need instructions. If you’re using Windows XP, 2000, or Me, you
may first need to click an icon to stop or disconnect the drive.
Presenting From a USB Drive, Camera, or CompactFlash Card 129
Presenting Scenarios
Before you begin, connect the USB drive (see page 52) or insert the
CompactFlash card containing the scenario to your projector (see
page 53).
Then follow these steps to present your scenario:
1. Turn on the projector, if it’s not already on.
■
If your scenario is set to autorun, it will start as soon as the
projector warms up.
■
If your scenario is not set to autorun, you need to start it
manually. Continue with the following steps.
2. Select EasyMP as the source by pressing the EasyMP button on
the remote control.
JPEG files are displayed as thumbnails. Other files or folders are
displayed as icons. A
scenario icon identifies a scenario file.
note
Your files may take up more
than one screen. If so, use the
Page up and Page down
buttons on the remote
control to view all your files.
3. Use the
pointer button on the remote control to highlight
your
scenario file and press Enter. In a moment, your
scenario begins playing.
Controlling Your Scenario
While your scenario is running, use the remote control as follows:
■
Press Enter or
Page down to display the next animation,
slide, or image, or to begin playing a movie.
■
Press
Page up to display the previous slide or image, or to
replay a movie.
■
Press the appropriate side of the
slide or image on the screen.
■
To exit the scenario at any point, press the Esc button. Select Exit
and press the Enter button.
note
Even if your scenario is set to
change slides automatically,
you can still change slides
manually as described here.
130
Presenting From a USB Drive, Camera, or CompactFlash Card
pointer button to rotate a
Copying and Deleting CompactFlash
Card Files
You can use your computer to copy and delete files on a
CompactFlash card that is inserted in the projector even if the
projector is mounted on the ceiling or in a remote location. (You
cannot copy or delete files on a USB storage device this way.)
Follow the steps below for your operating system when the EasyMP
standby screen is displayed.
Windows
1. Right-click My Computer and select Map Network Drive.
2. For Drive, enter a drive name that is not being used. For Folder,
enter the IP address, followed by \share, as shown below. Then
click Finish.
You see the CompactFlash folder.
Presenting From a USB Drive, Camera, or CompactFlash Card 131
3. Double-click the CompactFlash folder. For the password, enter
the network drive password set for the projector. Then click OK.
4. Copy the target folder(s) or file(s) to the CompactFlash card.
Macintosh
1. Click the Finder icon.
2. From the Transfer menu, select Connect to Server.
3. In the address field, enter smb://Projector IP
address/CompactFlash.
4. Click Connect.
132
Presenting From a USB Drive, Camera, or CompactFlash Card
Supported File Formats
The following file types may be projected from a digital camera,
external hard drive, flash memory drive, or CompactFlash card:
File Type
Extension
Notes
Scenario
.sit
These are scenario files created using the
EMP SlideMaker 2 program that is included
with the projector.
Graphics
.bmp
Images with a resolution greater than
1024 × 768 cannot be projected.
.gif
Images with a resolution greater than
1024 × 768 cannot be projected.
.jpg
Projection is not possible for CMYK color
formats, progressive formats, and images
with a resolution in excess of 4608 × 3072.
.png
Projection is not possible for images with a
resolution in excess of 1024 × 768.
.mpg
MPEG2-PS
Movie
The reproducible audio format is MPEG-1
Layer 1/2. Linear PCM and AC- 3 audio
cannot be played back, but MPEG contents
with no sound can be played.
.mp4
MPEG4, ASP/MPEG-4 AVC
The reproducible audio format is MPEG4
AAC-LC.
.mov
QuickTime® format Motion JPEG files.
.wmv,
.asf
WMV8, WMV9
The reproducible audio format is wma.
DPOF
.mrk
For DPOF version 1.10, only files named
AUTPLAYx.mrk (where x is a number
between 0 and 9) can be projected.
Presenting From a USB Drive, Camera, or CompactFlash Card 133
Files with the extension JPEG and MPEG can’t be projected. Rename
or save files as JPG or MPG. Files with high compression will not look
good, and movie files may not look as good from media with a slow
access speed. Files to which DRM (digital rights management) is
applied cannot be projected.
134
Presenting From a USB Drive, Camera, or CompactFlash Card
6
Fine-Tuning the Projector
Y
ou can use the projector’s on-screen menus to adjust the image,
sound, and other features. This chapter covers the following
information:
■
Using the menu system
■
Adjusting the image
■
Adjusting signal settings
■
Customizing projector features
■
Using the projector security features
■
Customizing power and operation
■
Multi-screen color adjustment
135
Using the Menu System
You can use the remote control or the projector’s control panel to
access the menus and change settings. Follow these steps:
1. To display the menu screen, press the Menu button on the
remote control or on the projector.
You see a menu screen similar to the one below:
Options
Menu list
The menus are listed on the left and the options available for the
highlighted menu are shown on the right.
2. Use the
pointer button on the remote control (or the
navigational buttons on the projector) to scroll through the menu
list. When you’ve highlighted the desired menu, press the Enter
button to select it.
3. Once you’ve selected the menu, use the
pointer button to
scroll through the list of options. (Some of the options may be
grayed out or unavailable, depending on the selected source.)
136
Fine-Tuning the Projector
4. After highlighting the option you want to adjust, use the
pointer button to change the setting. In some cases, you may
have to press the Enter button to view a sub-screen for changing
the setting.
■
Press the left or right side of the
a slider bar.
pointer button to adjust
■
To select from two or more settings, use the
pointer
button to highlight the desired setting and press Enter.
5. After changing the settings, press the Esc button to save your
changes and return to the previous menu (or press it repeatedly to
exit the menu system).
You can also press the Menu button to exit.
Restoring the Default Settings
You can use the menu system’s Reset options to restore the factorydefault settings for all the settings listed in a specific menu, or all the
settings in all menus.
To restore the settings in a specific menu, enter the menu whose
settings you want to change, select Reset, and confirm as needed.
(The example below shows how to reset the Image menu.)
Reset settings
for current menu
Reset settings for
all menus
note
When you select Reset All
in the Reset menu, it does
not reset the Computer
Input, User’s Logo,
Multi-screen, Language,
Lamp Hours, or Network
settings.
To restore all the projector settings to their factory-default values,
select the Reset menu, highlight Reset All, and press Enter.
Fine-Tuning the Projector 137
Adjusting the Image
You can use the Image menu to adjust the brightness, sharpness, color,
tint, and contrast.
1. Press the Menu button on the projector or remote control and
select the Image menu. You see the Image menu screen.
2. Use the
pointer button to highlight the desired option, then
adjust it as needed:
note
The available settings vary
depending on the input
source selected.
■
Color Mode
Lets you quickly adjust the color and brightness for various
environments. Use either the remote control or the Color
Mode setting in the Image menu. You can save a different
setting for each source. Select from these settings:
Game: Ideal for use in bright rooms and when playing video
games, this mode produces the brightest images and most
vivid colors.
Presentation: For making presentations with color materials
in bright rooms.
Text: For making presentations with black-and-white
materials in bright rooms.
Theatre: For watching movies in a darkened room; gives
images a natural tone.
Photo: For vivid, high-contrast still images in a bright room.
Sports: For vivid TV images projected in a bright room.
138
Fine-Tuning the Projector
sRGB: For matching the color palette of standard sRGB
computer displays.
Blackboard: For projecting accurate colors on a green
chalkboard (adjusts the white point).
note
Customized: For manual color adjustment (see below).
■
The Brightness setting
changes the opacity of the
projector’s LCD panels. You
can also change the lamp’s
brightness. Select
Brightness Control in the
Settings menu, then choose
High or Low (the default
setting is High).
Brightness
Lightens or darkens the overall image.
■
Contrast
Adjusts the difference between light and dark areas.
■
Color Saturation
Adjusts the color depth of the image.
■
Tint
Adjusts the balance of green to magenta in the image.
■
Sharpness
Adjusts the sharpness of the image.
■
Abs. Color Temp.
Sets a color temperature between 5000 and 10000 °K. (Not
available if sRGB is selected as the Color Mode setting.)
■
Color Adjustment
Adjusts the color values. For Customized color mode, select
RGBCMY to adjust individual red, green, blue, cyan,
magenta, and yellow hue and saturation values. For other
color modes, RGB may be selected to adjust red, green, and
blue hue and saturation values. (Not available if sRGB is
selected as the Color Mode setting.)
Fine-Tuning the Projector 139
Six-Axis Color Adjustment
For special projection material, such as high-quality photographs or
artwork, you can adjust the hue and saturation for six different color
axes.
1. Follow the instructions on page 138 to open the Image menu and
select Color Mode.
2. Press the Enter button to select Customized, then press Esc to
return to the Image menu.
3. Select Color Adjustment and press Enter. You see hue and
saturation controls on the screen for six colors: RGBCMY (red,
green, blue, cyan, magenta, and yellow).
4. Select the color axis you want to adjust and press Enter. You see
color controls for hue and saturation.
Hue changes the balance of color, and saturation changes the
strength of the color.
5. Use the
pointer button to adjust the hue and saturation. You
see the adjustments reflected on the screen. When you are satisfied
with the color, press Esc.
6. Repeat steps 4 and 5 for each color axis you want to adjust.
You may need to readjust the color as the lamp in your projector
changes over time.
140
Fine-Tuning the Projector
Adjusting Signal Settings
Although the projector normally detects and optimizes the input
signal automatically, you can use the Signal menu to make manual
adjustments. In addition to changing the position of the projected
image, you can correct tracking and sync for computer images, or
change the aspect ratio to widescreen format for video images.
1. Press the Menu button and select the Signal menu.
You see a screen similar to one of those below. (The settings will
be different depending on the source you are projecting from.)
Computer/RGB Video
Composite Video/S-Video
2. Use the
pointer button to highlight the desired option, then
adjust it as needed:
■
Auto Setup
Leave this setting On to automatically optimize computer
images. Turn it off if you want to save adjustments you have
made to the Tracking, Sync, and Position settings.
■
Tracking
Adjust this value to eliminate vertical stripes in computer
images.
■
Sync
Adjust this value if computer images appear blurry or flicker.
■
note
You can also use the remote
control’s Auto button to
automatically reset the
projector’s Tracking, Sync,
and Position settings. See
page 189 for details.
Progressive
For composite video and S-video only. Turn this setting On
to convert interlaced signals into progressive signals (best for
still images). Leave the setting Off for moving images.
Fine-Tuning the Projector 141
■
Position
If the image is slightly cut off on one or more sides, it may not
be centered exactly. Select this setting and use the
pointer
button to center it.
■
Computer1 Input
Computer2 Input
If the colors don’t look right on the Auto setting, select the
setting for the type of equipment you’ve connected to the
Computer1 or Computer2 port:
RGB: For a computer or RGB-video connection.
Component: For a video player that outputs a component
video signal (with connectors labeled Y/Cb/Cr or Y/Pb/Pr).
■
Video Signal
Leave this setting at Auto unless you are using a 60-Hz PAL
system (then select PAL60).
■
Resize
Choose an aspect ratio of either 4:3 or 16:9. For videos, you
can also select 16:9 (Up) or 16:9 (Down) to accommodate
subtitles or supertitles. Normal is the default setting for a
computer connection.
142
Fine-Tuning the Projector
Customizing Projector Features
You can use the Settings menu to lock the buttons on the projector,
adjust audio volume, and customize several other features.
■
Keystone
Adjusts the shape of the image if the projector has been tilted
upward or placed at an angle to the screen.
Select H/V-Keystone to correct horizontal and vertical keystone
distortion, or to turn Auto V-Keystone on or off (see page 26).
Select Quick Corner to adjust the shape and position of the
projected image (see page 25).
■
Operation Lock
Lets you disable all of the buttons on the projector except the
P Power button. See page 148 for more information.
■
Pointer Shape
Lets you choose from three pointer shapes. See page 33 for more
information.
■
Brightness Control
Lets you select from two levels of brightness. The Low setting
reduces power consumption and noise, and extends the lamp’s
operating life.
■
Volume
Raises or lowers the volume of the projector’s speaker.
note
You can also adjust the
volume using the remote
control.
Fine-Tuning the Projector 143
■
Remote Receiver
Deactivates the projector’s front and/or back sensors that detect
signals from the remote control. Use this setting to prevent use of
the remote control or to stop interference from bright fluorescent
lights.
■
Test Pattern
Displays a test pattern for use when adjusting the zoom and focus,
and when performing keystone correction.
Using the Projector Security Features
note
You can also attach a
security cable to the
projector to prevent theft
(see page 204).
144
To prevent unauthorized use of the projector, you can do the
following:
■
Assign a password. You can use the password to prevent the
projector from being turned on, prevent your custom startup
screen from being changed, and lock network settings.
■
Create a custom screen that is displayed at startup and/or when
the A/V Mute button is pressed. The screen can be locked with a
password to discourage theft and provides a way to identify the
projector should it be stolen. See page 146.
■
Disable the projector’s buttons; this is useful, for example, if
you’re projecting in a classroom and you want to ensure that no
one touches the projector’s buttons while you’re using the remote
control. See page 148.
Fine-Tuning the Projector
Enabling Password Protection
caution
The default setting for the password is 0000. Follow these steps to
create a new password:
If you lose the remote
control, you will not be able
to enter the password. Keep
the remote control in a safe
place at all times. Also, it’s a
good idea to write down
your password.
1. Press the Freeze button on the remote control for about five
seconds. You see this screen:
2. Use the
pointer button to select Password and press Enter.
3. When you see a message asking if you want to change the
password, select Yes and press Enter.
Hold down
4. Hold down the Num button on the remote control and use
the numeric keypad to enter a four digit password. (The default
setting is 0000.)
5. When you see a confirmation message, reenter the password.
Then press the Menu button to exit the screen.
To set security options, access the Password Protect screen as
described above, and then turn on any of the following options:
■
Power On Protect to prevent unauthorized use of the projector.
After the projector is plugged in and turned on, you must enter a
password to use the projector. For details, see page 146.
■
User’s Logo Protect to prevent your custom screen and display
settings from being changed. None of the User’s Logo features in
the Extended menu can be changed when the User’s Logo Protect
function is enabled. For details on creating a custom screen, see
page 146.
■
Network Protect to lock the Network settings in the menu
system (see page 59).
Fine-Tuning the Projector 145
Starting the Projector with a Password
note
If you leave the projector
plugged in, the Password
Protect Release screen will
not appear. It appears only
if you unplug and reconnect
the power cable.
When the password function is enabled, you see this screen when you
plug in and turn on the projector:
5GG[QWTFQEWOGPVCVKQPHQTOQTGKPHQTOCVKQP
Hold down
Hold down the Num button on the remote control and use the
numeric keypad to enter the four digit password. The password screen
closes and projection begins.
If the password is not correct, you see a message prompting you to
re-enter the password. If you enter an incorrect password three times
in succession, you see the message The projector’s operation will be
locked and the projector switches to standby mode. Disconnect the
projector’s power cord from the electrical outlet, reconnect it, and
turn the projector back on.
When you see the Password screen again, you can try to enter the
correct password.
If you enter an incorrect password 30 times in succession, the
projector remains locked and you must contact Epson to unlock it.
If you have forgotten the password, contact Epson with the request
code number that appears in the Password screen for assistance.
See “Where To Get Help” on page 197.
Creating Your Own Startup Screen
You can transfer any image from your computer or video source to the
projector and then use it as your startup screen. You can also use it as
the screen displayed when the projector is not receiving a signal or
when you press the A/V Mute button. The image can be a company
logo, slogan, photograph, or any other image you want to use.
146
Fine-Tuning the Projector
Capturing the Image
Start by displaying the image you want to use from either a computer
or video source, such as a DVD player or digital camera. Then follow
these steps to capture the image and transfer it to the projector:
note
1. Press the Menu button on the remote control, highlight the
Extended menu, and press Enter.
When you choose an image
for the user’s logo, it erases
any previously used image.
You can save an image up to
300 × 400 pixels in size.
2. Highlight User’s Logo and press Enter.
333
3. When you see a message asking Choose this image as the
user’s logo?, select Yes and press Enter. A selection box displays
over the image.
4. Use the
pointer button to select the area of the image you
want to use. Then press Enter.
5. When you see the message Select this Image?, highlight Yes
and press Enter.
6. Use the arrow buttons to select a zoom factor (display size) and
press Enter.
7. When the message Save this image as the user’s logo?
appears, select Yes and press Enter. Saving the logo may take a
few moments. Do not use your projector, remote control, or
video source while the logo is being saved.
8. When you see the message Completed, press Menu to exit the
menu system.
Fine-Tuning the Projector 147
Choosing When to Display the Image
After your image is saved, you can set it to display as the startup
screen, the screen you see when there’s no signal, or the screen you see
when you press the A/V Mute button (see page 31).
1. Press the Menu button, highlight the Extended menu, and press
Enter.
2. Select Display and press Enter.
3. Choose from these display options:
note
You can lock these settings to
prevent them from being
changed without a password
(see page 145).
■
Set Display Background to Logo to display your image
when there is no signal.
■
Set Startup Screen to On to display your image when the
projector is warming up.
■
Set A/V Mute to Logo to display your image when you press
the A/V Mute button.
4. When you’re finished, press Menu to exit.
Disabling the Projector’s Buttons
When you enable the Operation Lock function, you can lock all the
projector’s buttons, or all buttons except the Power button. The
remote control can still be used to operate the projector.
1. Press the Menu button, highlight the Settings menu, and press
Enter.
2. Select Operation Lock and press the Enter button.
3. Select Full Lock (to lock all projector buttons) or Partial Lock (to
lock all buttons except the Power button) and press Enter.
4. Select Yes and press Enter to confirm the setting.
5. Press the Menu button to exit.
To disable the Operation Lock function, select Off in the Operation
Lock menu. Or press and hold the Enter button on the projector’s
control panel for 7 seconds. A message is displayed and the lock is
released.
148
Fine-Tuning the Projector
Customizing Power and Operation
You can use the Extended menu to customize the way the projector
displays images, enable quick startup, turn sleep mode on or off, and
customize other projector operations.
■
Display
Use this setting to turn off the display of messages, change the
background color, enable logo display, or turn off the startup
screen display.
■
User’s Logo
Create a custom startup screen, as described on page 146.
■
Projection
Select Front (to project from the front of a screen and right side
up), Front/Ceiling (when the projector is mounted upside-down
from the ceiling), Rear (to project from behind onto a
transparent screen), or Rear/Ceiling (to project from behind onto
a transparent screen when the projector is mounted upside-down
from the ceiling).
■
Operation
Enable Direct Power On if you want to have the projector start
when the power cable is connected (without pressing the Power
button). Enable Sleep Mode if you want to have the projector
note
If Direct Power On is
enabled, the power cable is
connected, and a power
outage occurs, the projector
will start when the power is
restored.
Do not use the projector at
altitudes above 7500 feet
(2,286 meters).
turn off automatically if it is idle (and no signal is received) for 30
minutes or when the A/V mute slide (lens cover) is closed. Enable
High Altitude Mode when you are using the projector above
4900 ft (1500 meters).
Fine-Tuning the Projector 149
■
Standby Mode
Select Network On to enable the projector to be monitored over
a network when it is in standby mode (the power light is orange).
■
USB Type B
Select Easy MP to project your computer’s display through the
projector’s Type B USB port (see page 41). Choose Wireless
Mouse if you want to be able to use the remote as a wireless
mouse for a USB-connected computer (see page 42).
■
Projector ID
Lets you assign a numeric ID to each projector. When you are
using multiple projectors, you can use the ID to select the one you
want to operate with the remote control. See page 36 for
instructions.
■
Multi-screen
Use this option if you want to color-match two or more projectors
that are being used to display images near each other, or you are
using the multi-screen feature to project from one source (one
image) with multiple projectors (see page 98). You can make
image adjustments at each of five adjustment levels. First choose
an Adjustment Level and then adjust the settings for each level:
Brightness Correct. to adjust the brightness, and Color
Correct. to adjust the balance between red and green, or blue and
yellow. See page 151 for more information about multi-screen
color adjustment.
■
Language
Select from 20 languages to be used for the projector menus.
150
Fine-Tuning the Projector
Multi-screen Color Adjustment
You can match the color of projected images when two or more
projectors are being used to display images near each other, or when
you use the multi-screen feature to project from one source (one
image) as described on page 98. For each screen, you can set five levels
of brightness and color correction.
1. Before starting, you may want to assign a numeric ID to each
projector. This lets you use the remote control to select the
projector you want to adjust. See page 36 for instructions.
To match the display colors as closely as possible, make sure that
all the projectors are set to the same color mode before starting.
See page 138 for instructions.
note
If you use two or more
projectors side-by-side,
exhaust from adjacent
projectors might cause
overheating. Leave at least
2 feet (60 centimeters) of
space between projectors.
2. Press the Menu button on the remote control. You see the
projector’s menu screen.
3. Select Extended > Multi-screen.
4. Start by setting the Adjustment Level to 1 for two projectors.
Then use Brightness Correct to match the darker projector to
the lighter one. Press Enter to see the effects of your adjustments.
5. Next, adjust the brightness of Level 5 for the same two projectors.
Match the brighter projector to the darker one.
6. Adjust and match the brightness of Levels 2, 3, and 4.
7. Adjust and match the G/R color correction for all levels. Then
adjust and match the B/Y correction for all levels.
8. If you are using three or more projectors, repeat steps 4 through 7
to match projector 3 to projector 2, then match projector 4 to
projector 3, and so on.
Fine-Tuning the Projector 151
152
Fine-Tuning the Projector
7
Managing Projectors
T
he software included with your projector lets you monitor and
control your projectors from a remote computer:
■
Use EMP Monitor (available for Windows only) to see your
projectors’ status, switch image sources, and control basic settings.
■
Use the mail notification function to receive e-mail alerts about
possible problems.
You can also use NS Connection to register up to 16 projectors as a
group. This allows you to provide quick and easy access to these
projectors from other computers.
To use the software to manage your projectors, first install EMP
Monitor as described on page 201. If you plan to create projector
groups, also install EMP NS Connection. Then connect and
configure each projector you want to monitor. You can connect the
projector wirelessly in Access Point mode (see page 68) or over a wired
network as described here.
This chapter covers the following information:
■
Connecting your projector to a wired network
■
Monitoring and controlling your projector with EMP Monitor
■
Using e-mail alerts to warn you of problems
■
Using a browser to monitor the projector
153
Connecting to a Wired Network
Follow these steps to connect the projector to your network and
configure it with an IP address:
1. Connect the projector to your network using a commercially
available 100BaseTX or 10BaseT network cable. Connect the
cable to the LAN port on the projector. See page 55.
2. Point the remote control at the projector and press the P Power
button.
3. Press the EasyMP button on the remote control to select EasyMP
as the source.
4. Press the Menu button on the remote control, select the
Network menu, then press Enter.
5. Choose Network Configuration and press Enter.
6. Choose Wired LAN and press Enter. You see the following
screen:
154
Managing Projectors
7. Do one of the following:
■
If your network assigns addresses automatically, turn on the
DHCP setting.
■
If your network does not assign addresses automatically, turn
off DHCP and enter the projector’s IP Address, Subnet
Mask, Gateway Address, and DNS Servers, as needed.
note
If you’re a network
administrator, you can use
the SNMP option to enter a
trap IP address. This lets you
receive trap alerts for the
projectors you’re monitoring.
To enter numbers, use the
pointer button on the remote
control to highlight the number you want to input, then press
the Enter button.
8. When you’re done making all necessary changes, select Return,
select Setup complete, and then select Yes to confirm that you
want to save the changes. Press Menu to exit the menu system.
Using Projector E-mail Alerts
When this feature is enabled, the projector sends you an e-mail alert if
it has any problems.
1. Press the Menu button on the remote control, select the
Network menu, then press Enter.
2. Choose Network Configuration and press Enter.
note
You can also set e-mail alerts
from EMP Monitor (see
page 166).
3. Choose Mail, then press Enter. You see the following screen:
Managing Projectors 155
4. Highlight On to receive email notifications, then press Enter.
5. Enter the IP address for the SMTP server for the projector.
note
If a critical problem develops
with a projector which
causes it to suddenly stop
working, it may not be
possible for the projector to
send a message.
If Standby Mode is set to
Network On in the
Extended menu, the
projector can still be
monitored even if the
projector is in standby mode
(when the power is off).
You can enter a number from 0 to 255 in each field of the address.
However, the following IP addresses cannot be used: 127.x.x.x,
224.0.0.0 to 255.255.255.255 (where x is a number from 0 to
255).
6. Enter the SMTP server’s port number. The default value is 25.
You can enter a numeric value from 1 to 65535.
7. Choose one of the Email Address fields, then enter the e-mail
address where you want to receive a message when a problem
occurs. You can register up to three addresses. You can enter up to
32 alphanumeric characters for the e-mail address.
8. Select problems or warnings to be notified about by mail.
(Numbers 1 through 3 in this section correspond to the e-mail
addresses you entered.)
9. When you’re done making all necessary changes, select Return,
select Setup complete, and then select Yes to confirm that you
want to save the changes. Press Menu to exit the menu system.
When the selected problem or warning occurs, an e-mail message is
sent to the specified notification addresses. The subject line of the
e-mail is EPSON Projector. The e-mail includes the following
information:
156
Managing Projectors
■
Line 1: The name of the projector where the problem has
occurred
■
Line 2: The IP address of the projector where the problem has
occurred
■
Line 3: Details of the problem
Using EMP Monitor
EMP Monitor lets you use a remote computer to manage your
projectors, whether connected wirelessly or over a wired network. It
lets you easily turn the projectors on or off (together or individually),
switch image sources, and check their status.
Before using EMP Monitor, make sure you’ve installed the software
(available for Windows only) as described on page 201. The
computer you’re using to monitor the projector should already
be connected to your network.
note
If you want to monitor
projectors while they are
in standby mode, select
Standby Mode in the
Extended menu, then
select Network On.
See page 150.
Opening and Closing EMP Monitor
To start EMP Monitor, click Start > Programs or All Programs >
EPSON Projector > EMP Monitor.
If you’ve added the program to the Startup programs folder, then it
may already be open. If so, click the icon in the system tray on the
lower-right corner of your screen to display the EMP Monitor
window:
Click here to start EMP Monitor
To close EMP Monitor, select Exit from the File menu or right-click
the program icon shown above, then select Exit.
Managing Projectors 157
Registering a Projector
Before you can monitor a projector, you have to register it. Follow
these steps to automatically search for your projector(s):
1. Open EMP Monitor as described above. You see this screen:
2. Select Edit > New > Projector (automatic search).
You see this screen:
note
If the projector is not
automatically found, your
projector may not be
connected or configured
correctly for the network. See
page 61.
158
Managing Projectors
3. Click Search to locate projectors currently operating on the
network.
Any projectors found on the network are listed as shown below:
4. Select the projector you want to add by clicking its name, then
click the Edit button.
You see this screen:
5. Enter a Display name, select a Parent group (if necessary), enter a
Monitor Password (if necessary), and enter a Description for the
projector. Then click the Register button.
Managing Projectors 159
To register additional projectors with EMP Monitor, repeat steps
2 through 5.
6. When you’re done adding projectors, click Cancel.
note
You see a screen with a list of all registered projectors:
To delete a projector from
the list, right-click the
projector name, and click
Delete.
Monitoring Your Projectors
note
To monitor a projector
when it’s in standby mode
(plugged in but not turned
on), you must select
Network On as the
Standby Mode setting in
the projector’s Extended
menu (see page 150).
160
Managing Projectors
The EMP Monitor screen lets you monitor your projectors using the
Status, Video Source, and Error icons shown below. This lets you see
which projectors are currently being used, from which source (or port)
they are projecting an image, and if a problem occurs.
For detailed status information, right-click the projector in question
and click Property.
The following tables describe the status icons shown on the EMP
Monitor screen.
Group status icons
No warnings or problems. All projectors in the group
are operating normally.
Warning or problem. A projector in the group has a
warning or problem.
Monitoring disabled. Right click the icon and select
Monitoring Enabled to begin monitoring the group.
Data is currently being updated.
Type status icons
No warnings or problems.
Warning or problem.
Monitor Password error. No monitor password was
entered when the projector was registered, or an
incorrect password was entered.
Monitoring disabled. Right-click the icon and select
Monitoring Enabled to begin monitoring the
projector.
Data is currently being updated.
Network error (for example, the projector is not
connected to the network, or power cable is
disconnected).
You may also see this error if Network Off is
selected in Standby Mode.
Network error (Esc/VP.net communication error).
Managing Projectors 161
Power status icons
The projector is powered on and its status is
normal.
The projector is powered off and its status is
normal.
The projector is powered on and its status is
abnormal.
The projector is powered off and its status is
abnormal.
Temperature level status icons
The projector’s internal temperature is normal (low).
The projector’s internal temperature is normal
(medium).
The projector’s internal temperature is normal
(high).
The projector’s internal temperature is high
(high-temperature warning).
The projector’s internal temperature is too high
(internal temperature error). The projector is turned
off automatically.
Error status icons
Lamp life warning. The lamp is nearing the end of
its life.
High-temperature warning. The projector is getting
too hot but continues to operate.
Replace air filter.
No air filter. The air filter is not installed or installed
incorrectly.
Low air flow. The air filter needs to be cleaned or
replaced.
162
Managing Projectors
Error status icons (continued)
Air flow sensor error. There is a problem with the
projector’s air flow sensor; contact Epson as
described on page 197.
Lamp cover door open. Close the lamp cover door.
Lamp out. The lamp has reached the end of its life.
Lamp failure at power on. The lamp has reached its
end of life or is installed incorrectly.
High internal temperature error. The projector is
turned off automatically.
Internal (system) error. Contact Epson as described
on page 197.
Fan error. Contact Epson as described on page 197.
Sensor error. Contact Epson as described on
page 197.
Other error. Contact Epson as described on
page 197.
See page 181 for recommended solutions to problems.
Managing Projectors 163
Controlling Your Projectors
note
To turn on a projector when
it’s in standby mode
(plugged in but not
projecting), you must have
selected Network On as the
Standby Mode setting in
the projector’s menu system
(see page 150).
The control buttons in the upper-right let you turn the projector on
and off and select video sources. (Hold the mouse pointer over a
button to see a description of its meaning.) Make sure you’ve selected
the projector you want to operate (with the mouse pointer) before
clicking one of the buttons.
Control buttons
164
Managing Projectors
Configuring the Monitoring Interval
If you need to have the most current status information about your
projectors, click the Refresh button in EMP Monitor.
To select how often EMP Monitor checks the status of projectors,
follow these steps:
1. From the Tool menu, select Environment Setup. You see this
screen.
note
If you want EMP Monitor
to run whenever you start
your computer, click
Register at startup.
2. Enter the desired Update interval and click OK.
Managing Projectors 165
Using E-mail Alerts
note
You can also set e-mail alerts
from the projector’s menu
system (see page 155).
You can set up e-mail alerts to warn you of problems with the
projector. Follow the steps below:
1. Open EMP Monitor.
2. From the Tool menu, select Mail notification function.
You see this screen:
3. Turn the Mail notification function setting On.
4. Enter the IP address and port number of your network’s SMTP
(outgoing) mail server.
5. Enter the Sender (projector) mail address.
6. Enter up to three e-mail addresses to send alerts to the Recipient
mail address boxes.
7. Click the Notification event buttons to select the conditions
under which an e-mail alert will be sent.
8. When you’re done, click the OK button to close the Set mail
notification function window.
166
Managing Projectors
Understanding the Notification Messages
If a projector experiences a problem, EMP Monitor sends an e-mail
message to each of the addresses you entered in the Set mail
notification function window.
The subject line of the message includes the projector’s display name,
shown in EMP Monitor, and the warning/error.
note
If a projector develops a
critical problem, it may not
be possible for it to report the
error.
The body of the message contains:
■
The projector’s display name in EMP Monitor
■
The error/warning message
The problem descriptions are similar to the errors listed on page 162.
When the problem has been fixed, EMP Monitor sends a message
indicating the problem has been resolved.
Using a Browser to Monitor the
Projector
If your projector is connected to a network, you can use a standard
web browser to monitor and control it.
1. Make sure that the projector is set up for your network, as
described on page 61. (Standby Mode in the Extended menu
should be set to Network On to monitor the projector in standby
mode.) When using a browser to access the projector, you cannot
connect through a proxy server.
2. Open your web browser and enter the IP address of the projector
you want to monitor in the browser window.
If you’re not sure what the address of the projector is, turn the
projector on and select Wired LAN or Wireless LAN from the
Network menu to display the IP address of the projector.
Managing Projectors 167
You see a login screen.
3. Do one of the following:
■
If you didn’t set a Web control password in the projector’s
Network menu, click OK.
■
If you set a Web control password in the projector’s Network
menu, enter it in the Password box, then click OK.
You see this screen:
Menus
Functions corresponding to remote control buttons
168
Managing Projectors
4. Select one of the menu options listed on the left, then change any
of the settings as needed. These settings correspond to those
found in the projector’s menu system.
You cannot change the following settings using a web browser:
■
Pointer in the Settings menu
■
User’s Logo, High Altitude Mode, and Language in the
Extended menu
■
Reset All and Reset Lamp Hours in the Reset menu
Use the controls at the bottom of the screen just as you would the
corresponding remote control buttons. Choose a source, stop the
action, turn off the picture and sound, or turn the projector’s power
on or off.
Transferring Files by SMB
If your projector is connected to a network as described on page 154,
you can send files over the network to a CompactFlash card inserted
in the projector (see page 53). Then you can use the projector’s PC
Free feature to present images and movies.
On a Windows PC, you can use SMB (Server Message Block) to send
files to the projector, as described below. On a Macintosh, you can
connect to the projector using the Finder.
note
To send files to a projector
when it’s in standby mode
(plugged in but not turned
on), you must select
Network On as the
Standby Mode setting in
the projector’s Extended
menu (see page 150).
In Windows, follow these steps:
1. Open Windows Explorer.
2. Enter the IP address of the projector in the Address field (for
example, 192.168.100.100).
Managing Projectors 169
You see the contents of the projector’s CompactFlash card
displayed on the right:
3. Copy your files to the projector.
170
Managing Projectors
8
Maintaining the Projector
Y
our projector needs little maintenance. All you have to do is keep
the lens clean. You may also need to clean the air filter and vent. A
clogged air filter or vent can block ventilation needed to cool the
projector.
warning
Before you clean any part of
the projector, turn it off and
unplug the power cord.
Never open any cover on the
projector, except the lamp
cover. Dangerous electrical
voltages in the projector can
injure you severely. Do not
try to service this product
yourself, except as specifically
explained in this User’s
Guide. Refer all other
servicing to qualified service
personnel.
The only parts you should replace are the lamp and air filter. If any
other part needs replacing, contact your dealer or a qualified servicer.
This chapter covers the following:
■
Cleaning the lens
■
Cleaning the projector case
■
Cleaning the air filter and vent
■
Replacing the lamp and air filter
■
Replacing the remote control batteries
■
Transporting the projector
171
Cleaning the Lens
Clean the lens whenever you notice dirt or dust on the surface.
Use a canister of compressed air to remove dust.
To remove dirt or smears on the lens, use a commercially available
cloth for cleaning glasses.
Cleaning the Projector Case
caution
Do not use wax, alcohol,
benzene, paint thinner, or
other chemical detergents.
These can damage the case.
172
Before you clean the case, turn off the projector and unplug the power
cord.
■
To remove dirt or dust, wipe the case with a soft, dry, lint-free
cloth.
■
To remove stubborn dirt or stains, moisten a soft cloth with water
and a neutral detergent. Then wipe the case.
Maintaining the Projector
Cleaning the Air Filter and Vent
Your projector includes an air filter to ensure the best performance. If
dust collects on the air filter (on the bottom of the projector) or vent
(on the front of the projector), clean them as described below. Dust
clogs prevent proper ventilation and can cause overheating, which can
damage the projector.
Follow these steps:
note
To order replacement air
filters, request part number
V13H134A08. See page 13
for ordering information.
1. Turn off the projector and unplug the power cord.
2. To clean the intake vent and filter, use a small vacuum cleaner
designed for computers and other office equipment. If you don’t
have one, gently clean the vent with a soft brush (such as an
artist’s paintbrush).
You can remove the air filter to clean both sides even if the
projector is mounted on the ceiling. (See page 177).
Vent
Air filter
3. If the dirt is difficult to remove or the filter is broken, replace the
filter as described on page 177. Contact your dealer or call Epson
at 800-GO-EPSON (800-463-7766) to obtain a new filter.
Maintaining the Projector 173
Replacing the Lamp and Air Filter
note
When you get a replacement
lamp for your projector, you
should replace the filter.
Turn off this product when
not in use to prolong the life
of the projector.
The life span of the projection lamp is about 2500 hours if
Brightness Control in the Settings menu is set to High (default), and
3000 hours if Brightness Control is set to Low. See page 178 to
check the lamp usage.
It is time to replace the lamp when:
■
The projected image gets darker or starts to deteriorate.
■
The message Replace the lamp appears on the screen when the
lamp comes on and the lamp warning light
flashes orange. To
maintain projector brightness and image quality, replace the lamp
as soon as possible.
■
The lamp warning light
flashes red (the lamp is burnt out).
Lamp warning light
Contact your dealer or call Epson at 800-GO-EPSON
(800-463-7766). Request part number V13H010L40.
174
Maintaining the Projector
Follow these steps to replace the lamp and air filter:
warning
1. Turn off the projector and unplug the power cord.
2. Let the projector cool for at least an hour (if it has been on). The
lamp is extremely hot immediately after use.
3. Loosen the lamp cover screw (you don’t need to remove it). Then
slide the lamp cover to the side and lift it off of the projector.
4. Loosen the two screws holding the lamp in place (you can’t
remove them).
Let the lamp cool fully
before replacing it.
In the unlikely event that
the lamp has broken, small
glass fragments may be
present and should be
removed carefully to avoid
injury.
If the lamp is used after the
replacement period has
passed, the possibility that
the lamp may break
increases. When a lamp
replacement message
appears, replace the lamp
with a new one as soon as
possible, even if it is still
working.
Loosen, but don’t
remove these screws
Maintaining the Projector 175
5. Hold the lamp as shown and pull it straight out.
note
The lamp(s) in this
product contain mercury.
Please consult your state and
local regulations regarding
disposal or recycling. Do not
put in the trash.
6. Gently insert the new lamp. (If it doesn’t fit easily, make sure it is
facing the right way.)
7. Once the lamp is fully inserted, tighten its screws.
8. Replace the lamp cover, then tighten its screw.
176
Maintaining the Projector
9. Slide out the air filter on the bottom of the projector and
remove it.
10. Slide in the new air filter until it clicks in place.
11. Reset the lamp timer as described in the next section.
Resetting the Lamp Timer
After you replace the lamp, you need to reset the lamp timer using the
projector’s menu.
1. Press the Menu button on the remote control or on the
projector’s control panel. You see the main menu.
2. Use the
pointer button on the remote control (or the arrow
buttons on the projector) to highlight Reset, then press Enter.
You see this screen:
Maintaining the Projector 177
3. Select Reset Lamp Hours and press Enter.
4. When you see the prompt, select Yes and press Enter.
5. When you’re finished, press Menu to exit the menu system.
Checking Lamp Usage
To check the number of hours the lamp has been used, press the
Menu button and highlight the Info menu. You see a screen like this:
note
The information displayed
depends on the input signal
currently selected.
The life span of the lamp is about 2500 hours if the Brightness
Control setting in the Settings menu is set to High (default), and
3000 hours if the Brightness Control setting is set to Low. Make
sure you have a spare lamp handy if the usage hours on this menu
are close to the life span of your lamp.
178
Maintaining the Projector
Replacing the Batteries
Replace the batteries in the remote control as described below:
caution
1. Turn the remote control over.
When replacing batteries,
take the following
precautions:
2. Press down on the tab on the
battery cover as you lift the cover
off.
3. Install two AAA batteries,
inserting the + and – ends as
shown.
■
Replace the batteries as
soon as they run out. If the
batteries leak, wipe away
battery fluid with a soft
cloth. If fluid gets on your
hands, wash immediately.
■
Do not expose batteries to
heat or flame.
■
Dispose of used batteries
according to local
regulations.
■
4. Position the cover as shown, then
press down until it snaps into
place.
Remove the batteries if
you won’t be using the
projector for a long period of
time.
Maintaining the Projector 179
Transporting the Projector
note
Epson shall not be liable for
any damages incurred
during transportation.
180
The projector contains many glass and precision parts. Follow these
guidelines to prevent damage:
■
When shipping the projector for repairs, use the original
packaging material if possible. If you do not have the original
packaging, use equivalent materials, placing plenty of cushioning
around the projector.
■
When transporting the projector a long distance, first place it in a
hard-shell shipping case, then pack it in a firm box with
cushioning around the case.
■
Close the A/V mute slide (lens cover) to protect the lens.
■
If a CompactFlash card is installed, remove it from the projector.
Make sure the card eject button is pushed all the way in, or it
could be damaged.
Maintaining the Projector
9
Solving Problems
This chapter helps you solve problems with your projector, and tells
you how to contact technical support for problems you can’t solve
yourself. The following information is included:
■
Using the projector’s on-screen help system
■
What to do when the projector’s status lights flash
■
Solving projector operation problems
■
Solving problems with the image or sound
■
Solving network problems
■
Solving EasyMP problems
■
Solving problems with the remote control
■
Contacting technical support
181
Using On-Screen Help
If the image doesn’t look right or your audio isn’t working, you can
get help by pressing the ? Help button on top of the projector or on
the remote control.
1. Press the ? Help button on the remote control or on the
projector.
You see the Help menu:
2. Use the pointer button on the remote control or the
navigational buttons on the projector to highlight menu items.
3. Press the Enter button on the remote control or on the projector
to select the menu item.
4. To exit the help system, press the ? Help button.
If none of the suggestions solve your problem, see additional solutions
to problems in the following sections.
182
Solving Problems
Checking Projector Status
If your projector isn’t working correctly, first turn it off, wait for it to
cool (the Power light stops flashing orange), and unplug it. Then
plug the power cord back in and turn on the projector. If this doesn’t
solve the problem, check the lights on top of the projector.
What To Do When the Lights Flash
The lights on top of the projector indicate the projector’s status.
Power light
Temperature
light
Lamp light
Refer to the following table for a complete description of the
projector’s status lights:
Status lights
Light
Status
Description
Orange
The projector is in sleep or standby mode. You can unplug it or press the
P Power button to turn it on.
Flashing green
The projector is warming up. Wait for the image to appear.
Green
The projector is operating normally.
Flashing orange
The projector is cooling down. You can’t turn it back on until the light
stops flashing and remains orange.
Red
There is a problem with the projector. Check the other two lights and the
information on page 184 to diagnose the problem.
Solving Problems 183
Status lights (continued)
Light
Status
Description
Flashing orange
Rapid cooling is in progress. Although this is not an abnormal condition,
projection will stop automatically if the temperature rises higher. Make
sure there is plenty of space around and under the projector for
ventilation, and that the air filter and vents are clear.
Red
The projector is overheating, which turns the lamp off automatically.
Wait until the cooling fan stops, then unplug the power cord. Plug the
power cord back in and press the P Power button. Make sure the room
temperature is not above 95 °F (35 °C), and there is plenty of space
around and under the projector for ventilation.
If you’re using the projector above an altitude of 5000 feet (1500 meters),
turn on High Altitude Mode in the Operation menu (see page 149).
The air filter or vents may be clogged. Clean them or replace the air filter
as described on pages 173 to 177.
If the projector continues to overheat after you clean the air filter, the
problem may be caused by damage to the cooling fan or temperature
sensor. Contact Epson for help as described on page 197.
Warning: Except as specifically explained in this User’s Guide, do not
attempt to service this product yourself.
Flashing red
There is a problem with the fan or temperature sensor. The air filter or
vents may be clogged. Clean them or replace the air filter as described on
pages 173 to 177.
If this does not resolve the problem, stop using the projector, disconnect
the power cable, and contact Epson as described on page 197.
Flashing orange
It’s time to replace the lamp. See page 174 for instructions. If you
continue to use the lamp after the replacement warning, there is an
increased possibility that the lamp may break.
Flashing red
The lamp may be burnt out. First make sure the lamp cover is securely
installed. If that’s not the problem, let the lamp cool, remove the lamp,
and replace it as described on page 174.
The air filter or vents may be clogged. Clean them or replace the air filter
as described on pages 173 to 177.
If this does not resolve the problem, contact Epson as described on
page 197.
Flashing red
184
Solving Problems
Power is cut off because of an internal problem. Unplug the power cord
and contact Epson for help, as described on page 197.
Solving Projector Operation Problems
The power doesn’t turn on.
■
If the projector doesn’t turn on when you press the P Power
button, make sure the power cable is connected to the projector
and plugged into a working electrical outlet.
■
The power cable may be defective. Disconnect the cable from the
outlet and contact Epson as described on page 197.
■
Check to see if the A/V mute slide (lens cover) is closed.
The buttons on the projector don’t work.
If the Operation Lock function has been enabled, you can’t use the
buttons on the projector. Try using the remote control instead. See
page 148 for information about the Operation Lock function.
Solving Problems With the Image
or Sound
No image appears on the screen.
■
Check that the Power light is green, not flashing.
■
The projector may be in standby or sleep mode. If the Power
light is orange, press the P Power button to turn the projector
on.
■
If the power was switched off and then on again, the projector
may be cooling down. Wait until the Power light stops flashing
and remains orange; then press the P Power button again.
■
Press the A/V Mute button on the remote control to make sure
the picture has not been turned off temporarily.
■
Open the A/V mute slide (lens cover), if it is closed.
■
The attached computer may be in sleep mode or displaying a
black screen saver. Try pressing a key on the computer.
Solving Problems 185
■
If you are projecting from a DVD player or other video source,
make sure you turn it on and press its Play button.
You’ve connected a computer and see a blue screen with the
message No Signal displayed.
■
Make sure the cables are connected correctly, as described on
page 40.
■
If you’ve connected a computer and one or more video sources,
you may need to press the Source Search button on the
projector or one of the source buttons on the remote control to
select the correct source. Allow a few seconds for the projector to
sync up after pressing the button.
If you’re using a PC notebook:
■
Hold down the Fn key on the keyboard and press the function
key that lets you display on an external monitor. It may have an
icon such as
, or it may be labelled CRT/LCD. Allow a few
seconds for the projector to sync up after pressing it. Check your
notebook’s manual or online help for details.
On most systems, the
key lets you toggle between the LCD
screen and the projector, or display on both at the same time.
■
Depending on your computer’s video card, you might need to use
the Display utility in the Control Panel to make sure that both the
LCD screen and external monitor port are enabled. See your
computer’s documentation or online help for details.
If you’re using Mac OS X:
1. Open System Preferences.
2. Click Displays.
3. Click Detect Displays.
4. Make sure the VGA Display or Color LCD dialog box is selected.
5. Click the Arrangement or Arrange tab.
6. Make sure the Mirror Displays checkbox is selected.
186
Solving Problems
The message Not Supported is displayed.
■
Make sure the correct input signal is selected in the Signal menu
(see page 141).
■
Make sure your computer’s resolution doesn’t exceed UXGA
(1600 × 1200) and the frequency or refresh rate is supported by
the projector (see page 207). If necessary, change your computer’s
resolution setting.
Only part of the computer image is displayed.
■
Press the Auto button on the remote control.
■
Make sure the image Position setting is correct in the Signal
menu. See page 142 for more information.
■
Press the Resize button on the remote control.
■
Press the Esc button on the remote control to cancel the E-Zoom
function.
■
Make sure your computer’s resolution setting is correct. Ideally, it
should be 1024 × 768 to match the projector’s native resolution.
If this option isn’t available, select one of the other compatible
video formats listed on page 207.
■
You also may need to modify existing presentation files if you
created them for a different resolution. See your software
documentation for specific information.
The image isn’t square, but keystone-shaped.
■
If the image isn’t square or rectangular, adjust its shape as
described on page 24.
■
Enable the Auto Keystone feature to automatically fix the shape
when the projector is tilted upward. See page 143.
Solving Problems 187
The image contains static or noise.
■
If you’re using a computer cable longer than 6 feet, or an
extension cable, the image quality may be reduced.
■
Keep your computer and video cables away from the power cord
as much as possible to prevent interference.
■
The video signal may be split between the computer and the
projector. If you notice a decline in the projected image quality
when the image is displayed simultaneously on your notebook
computer and the projector, turn off the notebook’s LCD display.
■
Make sure the correct input signal is selected in the Signal menu
(see page 142).
■
If you’ve used the Quick Setup, Quick Corner, or Keystone
adjustment, you may need to decrease the Sharpness setting in
the Image menu (see page 139).
The image is blurry.
188
Solving Problems
■
There may be dirt or smears on the lens. Clean the lens as
described on page 172.
■
Adjust the focus using the focus ring (see page 24).
■
If the projector is angled sharply toward the screen, it may not be
possible to focus the entire image. Move the projector to position
it more directly in front of the screen.
■
Make sure the projector is within the proper range (projection
distance) from the screen (see page 205).
■
Make sure the lens is not fogged by condensation. You may need
to wait before using the projector after moving it from a cold
environment to a warm environment.
■
If you’re projecting from a computer, you may need to adjust the
tracking and sync as described in the next section.
You see vertical bands or the image still looks blurry after
trying the solutions in the previous section.
■
■
If you’re projecting from a computer and displaying an image that
contains a lot of fine detail, you may notice vertical bands or some
of the characters may look heavy or blurred. Press the Auto
button on the remote control or the Enter button on the
projector to reset the projector’s Tracking, Sync, and Position
settings.
note
You must be projecting an
image for this button to have
any effect. The Auto button
works only with computer
images projected through the
VGA port.
If further adjustment is needed, you can fine-tune the Tracking
and Sync settings manually using the Signal menu, as described
on page 141.
1. Fill the screen with an image containing fine detail, such as a
pattern to appear as your desktop background, or try
projecting black text on a white background.
2. Adjust the Tracking to eliminate vertical bands.
3. Adjust the Sync setting to increase the image sharpness.
The image is too light or dark, or colors are incorrect.
■
Use the Color Mode option in the projector’s Image menu to
adjust the color (see page 138).
■
If you’re displaying video, adjust the Color Adjustment and
Color Mode settings on the Image menu. You can also try
adjusting the Color Saturation, ABS Color Temp, and Tint
settings on the Image menu.
note
Because of the different
technologies used, your
projected image may not
exactly match the colors on
your notebook or computer
monitor.
Solving Problems 189
■
Try adjusting the Brightness and Contrast settings on the Image
menu.
■
Check your computer display settings to correct the color balance.
■
The projector’s lamp may need to be replaced. See page 174 for
instructions.
■
Make sure the correct input signal is selected in the Signal menu
(see page 142).
There is no sound, or the sound is not loud enough.
190
Solving Problems
■
Use the Volume buttons on the remote control to adjust the
volume, or adjust the Volume setting in the Settings menu (see
page 143).
■
Make sure A/V Mute is not enabled. (The A/V Mute button may
have been pressed.)
■
Make sure the A/V mute slide (lens cover) is open.
■
If your presentation includes computer audio, make sure the
volume control on your computer is not turned all the way down
or muted. In Windows, you may be able to check this by clicking
the volume control in your Windows system tray (lower right
corner of the screen). On a Mac, you may be able to adjust the
volume from your menu bar (top right corner of the screen) or via
the volume control function keys.
■
If you’re using a DVD player or other video source, make sure the
cables are connected correctly, as described on page 50.
■
If you’re using a computer audio cable, make sure it is connected
to your computer’s
headphone jack or
audio out jack.
Connect the other end to the projector’s Audio1 port when the
computer’s video cable is connected to the Computer1 port.
Otherwise, connect the cable to Audio2 if you’re using
Computer2 for the computer’s video connection.
Solving Network Problems
You don’t see your projector in the EMP Monitor window.
■
Make sure that you’ve connected the projector to the network and
configured it correctly; see page 61. Also, make sure you’ve
registered the projector with EMP Monitor; see page 157.
■
Make sure that Standby Mode in the projector’s Extended menu
is set to Network On.
■
If the computer you are using is running Windows XP, Vista, or
2000, you must be logged in as the Administrator.
■
Try restarting your computer.
You can’t connect to the projector using NS Connection.
■
Make sure the wireless network module is installed correctly in
the projector; see page 54. If you have to reinstall the module,
restart NS Connection or the program will not be able to detect
the projector.
■
Make sure you are using Version 2.30 of EMP NS Connection. If
you are using an older version, you must uninstall it and install
version 2.30 on the EasyMP CD-ROM that came with your
projector. See page 199 for instructions.
■
Restart your computer.
■
Make sure your projector and computer are configured correctly;
see page 61 (Ad Hoc mode) or page 68 (Access Point mode).
■
Make sure that you have sufficient wireless signal strength (above
50 percent). On a Mac, check the AirPort icon on the Mac menu
bar. In Windows, see the documentation for your computer’s
wireless card or adapter for details.
■
Make sure you aren’t projecting one of the EasyMP configuration
screens. (You should see a message that the projector is ready to
connect.) If you have to exit a configuration screen, restart
NS Connection.
Solving Problems 191
192
Solving Problems
■
If the projector is configured for Access Point mode and you’re
using DHCP, allow time for your projector to appear. It takes the
server a little while to pick up the IP address.
■
If you’ve changed any settings for your projector or network, or
restarted your computer, allow a minute or two for the
connection to appear. If you’re using AirPort, try turning AirPort
off and then on again.
■
Make sure that you’re trying to connect to the right network. In
Windows, verify that you’ve enabled your computer’s connection
to the access point (see page 74) or that your wireless card or
adapter is enabled and its SSID is set to match the projector’s
SSID (or ESSID); see page 66. On a Mac, click the AirPort icon
at the top of your Mac desktop to make sure AirPort is turned on
and the projector’s SSID or your AirPort network is selected.
■
If you have an access point or AirPort base station and you’re not
using DHCP, check your projector’s IP address on the Access
Point mode advanced settings screen. The first three segments of
the IP address should be identical to the first three segments of the
IP address of your access point or base station. The last segment of
the projector’s IP address should be close, but not identical, to the
last segment of the IP address of the access point or base station.
■
If you’re not using DHCP, check your projector’s Gateway
address on the projector’s Access Point mode advanced settings
screen. It should be identical to the IP address for your access
point or AirPort base station.
■
If you’re using a projector keyword, it changes each time you turn
the projector off and then on again, or remove and reinsert the
wireless network module. Check the projector’s keyword on the
EasyMP Network screen and enter it at the prompt.
■
If you’re using AirPort, check the configuration of your network.
Start the AirPort Admin utility, select your base station, click
Configure and click Show All Settings. Click the Network tab.
If you set up your projector to connect in DHCP mode, turn on
Distribute IP Addresses and Share a Single IP Address.
■
If you’re using AirPort and DHCP is turned off on your
projector’s Access Point mode advanced settings screen, make sure
Distribute IP Addresses is off.
■
If you’re using Access Point mode and you’re connecting to the
wrong network, you may be experiencing signal interference from
another network. Try resetting your access point or base station,
then restart NS Connection.
■
If you’re using AirPort, the projector’s ESSID should match the
AirPort network name, not the name of the AirPort base station.
To check the network name, start the AirPort Admin utility,
select your base station, and click Configure. Then click Show
All Settings. The network name appears on the AirPort tab.
■
If you’re prompted for a password when you connect, enter the
WEP encryption key (if you’re using WEP encryption).
■
Try connecting using IP Connect Mode; see page 94.
Solving EasyMP Problems
An image displayed with EasyMP appears distorted.
Some high-resolution images cannot be displayed correctly. Files with
a high compression ratio may appear blurry. For BMP, GIF, and
PNG files, make sure the resolution is not greater than 1024 × 768.
For JPG files, the resolution must not be greater than 8192 × 6144,
and the image cannot be in progressive and CMYK color format.
In EMP SlideMaker, PowerPoint files don’t appear in the
file window.
EMP SlideMaker does not support PowerPoint 95 or 97. Files created
in these versions of PowerPoint must be opened and resaved in
PowerPoint 2000 or later.
Solving Problems 193
In EMP SlideMaker, your PowerPoint files don’t display
thumbnails and can’t be pasted into scenarios.
Make sure the MS Office JPEG converter has been installed. See the
MS Office documentation for instructions. Also, make sure
PowerPoint is installed on the computer you’re using to build the
scenario.
You can’t edit scenario files in EMP SlideMaker after they
have been transferred to the USB drive.
You can only edit scenarios before they are transferred. Open the
scenario files saved on your hard drive, make any changes, then
transfer the scenario to your USB drive.
You can’t transfer your slideshow to the drive because you
aren’t able to see the drive letter.
You must connect the drive to your computer before you select Send
Scenario from the Scenario Option(s) menu. If this happens, close
and restart EMP SlideMaker 2. Make sure your drive is connected
before you select Send Scenario.
You can’t play your movies on the projector.
194
Solving Problems
■
The projector supports MPEG2 and WMV files. It does not
support MPEG1 files. The audio format is MPEG1 Layer 2.
Linear PCM and AC-3 audio cannot be played back.
■
If your MPEG2 movie stops playing, check the light on the
projector’s wireless module. If the light doesn’t come on, turn off
the projector and reinstall the module.
■
Movie files included in a PowerPoint presentation can’t be played
back in a scenario.
EasyMP is unable to see the image files on your camera or
external drive.
Make sure your camera or drive shows up on your desktop as a drive
letter when you connect it to your computer. If it does, it is probably a
USB-mounted device and will work with your projector. The
projector does not support TWAIN-compliant digital cameras.
When using EasyMP, you see an ERR code at the bottom of
the screen.
Check for the code below.
ERR Code
Meaning
2, 50, 53, 245, or
-103
Failed to start EasyMP. Turn the projector off, then
turn it back on again.
51, 52, or 100
EasyMP processing error. If you’re using EMP NS
Connection, try reconnecting to the projector.
If you’re projecting through the projector’s USB
port, reconnect the USB cable.
-101
Communication was cut off. Check the access
point connection (see page 68).
-102 or -105
Unstable wireless communication. Network traffic
may be high. Wait for a while, then try
reconnecting.
Solving Problems 195
Solving Problems With the Remote
Control
The projector doesn’t respond to remote control commands.
196
Solving Problems
■
The remote control’s batteries may not be installed correctly or
may be low on power. To change the batteries, see page 179.
■
Make sure you are within about 20 feet (6 meters) of the projector
and within range of the projector’s front or back sensor
(approximately 30° to the left or right and 15° above or below).
■
Dim the room lights and turn off any fluorescent lights. Make
sure the projector is not in direct sunlight. Strong lighting,
especially fluorescent lights, may affect the projector’s infrared
receivers. Also, turn off any nearby equipment that emits infrared
energy, such as a radiant room heater. If necessary, use the
Remote Receiver setting to disable the projector’s front or back
sensor if it continues to pick up interference (see page 144).
■
Make sure the Remote Receiver setting isn’t disabling both of
the projector’s sensors (see page 144).
■
If any buttons are held for longer than 30 seconds, the remote
enters sleep mode. Release any button that is held to wake the
remote.
Where To Get Help
Epson provides these technical support services:
Internet Support
Visit Epson’s support website for solutions to common problems. You
can download utilities and documentation, get FAQs and
troubleshooting advice, or e-mail Epson with your questions.
Visit Presenters Online to access tips, templates, and training for
developing successful presentations.
Speak to a Support Representative
To use the Epson PrivateLine Support service, call (800) 637-7661
and enter the PIN on the included Epson PrivateLine Support card.
This is the fastest way of speaking to a live representative, and it’s free.
This service is available 6 AM to 6 PM, Pacific Time, Monday through
Friday, for the duration of your warranty period.
You may also speak with a projector support specialist by dialing one
of these numbers:
■
U.S.: (562) 276-4394, 6 AM to 6 PM, Pacific Time, Monday
through Friday.
■
Canada: (905) 709-3839, 6 AM to 6 PM, Pacific Time, Monday
through Friday.
Days and hours of support are subject to change without notice. Toll
or long distance charges may apply.
Solving Problems 197
Before you call for support, please have the following information
ready:
■
Product name (PowerLite 1825)
■
Product serial number (located on the projector)
■
Proof of purchase (such as a store receipt) and date of purchase
■
Computer or video configuration
■
Description of the problem
Purchase Supplies and Accessories
You can purchase screens or other accessories from an Epson
authorized reseller. To find the nearest reseller, call 800-GO-EPSON
(800-463-7766). Or you can purchase online at www.epsonstore.com
(U.S. sales) or www.epson.ca (Canadian sales).
198
Solving Problems
A
Software Installation
T
he EasyMP software CD-ROM includes the software you need to
use the projector’s EasyMP features—for presenting over a wireless
network, transferring PowerPoint presentations to a memory card,
and monitoring the projector from a remote location. The Epson
Projector Software CD-ROM includes EMP Monitor and EMP
Network Manager for presenting and monitoring the projector from a
remote location.
Windows System Requirements
note
Although EMP Slidemaker
and EMP Monitor work in
Windows 98 and Me, EMP
NS Connection requires
Windows 2000, XP, or
Vista.
note
If you install the EasyMP
software on your computer
and then upgrade to
Windows Vista, you must
uninstall the software and
then reinstall it on Windows
Vista.
Before you install the software, make sure your computer meets these
requirements:
■
Microsoft Windows 2000 (SP4), Windows XP, or Windows
Vista
■
802.11g or 802.11b, or 802.11a network card or wireless adapter
(to use EMP NS Connection wirelessly)
■
IBM® compatible PC with at least a Pentium® III 1.2 GHz
processor
■
At least 256MB of RAM (512 recommended)
■
At least 128MB of free hard disk space
■
XGA (1024 × 768) or better display adapter and monitor, 16-bit
color or higher
199
Limitations in Windows Vista
If you install the Epson projector software in a previous version of
Windows and later upgrade to Windows Vista, you must uninstall the
software before you upgrade. Then reinstall it after you are running
Windows Vista.
EMP NS Connection V2.30 is compatible with Windows Vista, but
note the following:
■
If you are upgrading to Windows Vista and a USB display driver
is installed on your computer, uninstall it before upgrading to
Windows Vista.
■
The Multi-screen projection feature is not available.
■
When you project content from Windows Photo Gallery or
Windows Media Center, you cannot use the full-screen mode
options in those programs.
■
On the EMP NS Connection General settings tab, you cannot
select Use full-screen video transfer.
■
You may find that you have to input your user account name into
the User Account Control screen each time you start EMP NS
Connection. To disable this, set the Windows Firewall setting to
On (recommended), click the Exceptions tab (in the Windows
Firewall Settings window), and register EMP NS Connection.
Mac System Requirements
note
You can present over a
wireless network from
Mac OS X using EMP NS
Connection. However,
EMP SlideMaker and
EMP Monitor are available
only for Windows.
200
Software Installation
Before you install the software, make sure your Mac meets the
following requirements:
■
Mac OS X 10.3 or later (OS X 10.3.9 to 10.4.5 recommended)
■
AirPort (802.11b) or AirPort Extreme (802.11g) wireless network
interface to use EMP NS Connection wirelessly
■
Power Macintosh series G3 900 MHz or more, iMac,®
PowerBook, or iBook
■
At least 256MB of RAM
■
At least 128MB of free hard disk space
■
XGA (1024 × 768) or better display adapter and monitor, 16-bit
color or higher
Installing the Software in Windows
Follow these steps:
1. Insert the Projector Software CD-ROM in your computer’s
CD-ROM or DVD drive. The installation program starts and
you see this screen:
2. Click Easy Install, then make sure all three programs are selected
(including EMP Monitor).
Software Installation 201
3. Click Install, then follow the on-screen instructions to install
your projector software.
note
If you select more virtual
displays, your computer may
slow down depending on its
capabilities.
4. When you see the Virtual Display screen, you can select one or
more virtual displays to use for multi-screen projection (see
page 98). Windows lets you use two by default, but you can select
up to four more if you plan to use additional projectors.
After you install the software, you can change your Virtual
Display selection by accessing EPSON Projector from the Start
menu and selecting Add-Remove EPSON Virtual Display.
If you see a message that the Epson Projector Support Driver has
not passed Windows Logo testing, click Continue Anyway. If
you have selected multiple Virtual Displays, you will see this
message several times.
5. When installation is complete, click Finish to close the
installation window.
Installing the Software on a Mac
Follow these steps to install EMP NS Connection:
1. Insert the EasyMP software CD-ROM in your drive.
2. If necessary, double-click the Epson CD-ROM icon to open its
window.
3. Double-click the Installer for Mac OS X icon.
4. Click Install, then follow the on-screen instructions to install the
software.
5. When installation is complete, click Finish to close the
installation window.
202
Software Installation
B
Projector Installation
T
his appendix provides guidelines on installing the projector in a
permanent location, such as a theater or conference room.
The projector can be installed for four different viewing setups: front
projection, ceiling projection, rear projection onto a semi-transparent
screen, or rear/ceiling projection, as shown:
Front projection
Ceiling projection
Rear projection
Rear/ceiling projection
To project from overhead, you’ll need the optional ceiling mounting
hardware (see page 13). You’ll also need to select the appropriate
Projection setting in the projector’s Extended menu to flip the image
upside-down (see page 149).
If you’re mounting the projector on the ceiling and you place it above
screen level, you’ll have to tilt the projector down to position the
image on the screen. This causes the image to lose its square shape.
You can correct the image using the projector’s Quick Setup, Quick
Corner, and/or Keystone functions, as described on page 24.
203
The projector includes security features to prevent its theft when
installed or used in public locations:
■
Security cable attachment. You can attach a commercially
available security cable as shown below to secure the projector to a
table or ceiling mount.
■
Kensington security slot. The security slot is compatible with
the MicroSaver security systems manufactured by Kensington.
You can purchase this lock from Epson (see page 13).
Kensington security
slot
Security cable
attachment
In addition, the projector includes several menu-operated security
features. See page 144.
204
Projector Installation
C
Technical Specifications
General
Type of display
Epson poly-silicon TFT active matrix
Resolution
(native format)
1024 × 768 pixels (XGA)
Color reproduction
16.8 million colors
Brightness
3500 lumens (High Brightness mode)
2700 lumens (Low Brightness mode)
Contrast ratio
500:1
Image size
30 to 300 inches (76.2 to 762 centimeters)
Projection distance
2.7 to 48.2 feet (0.8 to 14.7 meters)
Projection methods
Front, rear, upside-down (ceiling mount)
Internal sound system
5 W monaural
Optical aspect ratio
4:3 (horizontal:vertical)
Zoom ratio
1:1.6
Noise level
32 dB in Low Brightness mode, 37 dB in
High Brightness mode
Keystone correction
±30°
Mouse compatibility
Supports USB (type B)
vertical (automatic/manual)
±20° horizontal (manual)
205
Projection Lamp
note
Lamp life results will vary
depending upon mode
selected, environmental
conditions, and usage.
Turn off this product when
not in use to prolong the life
of the projector.
Type
UHE (Ultra High Efficiency)
Power consumption
210 W
Lamp life
Approx. 2500 hours (High Brightness
mode)
Approx. 3000 hours (Low Brightness mode)
Part number
V13H010L40
Remote Control
Range
20 feet (6 meters)
Batteries (2)
Alkaline AAA
Dimensions
Height
3.4 inches (86 mm), feet retracted
Width
13.6 inches (345 mm)
Depth
10.1 inches (257 mm)
Weight
6.9 lb (3.1 kg)
Electrical
Rated frequency
50/60 Hz AC
Power supply
100 to 120 VAC, 3.4 A
200 to 240 VAC, 1.5 A
Power consumption
Operating:
100 to 120 VAC, 306 W
220 to 240 VAC, 286 W
Standby:
100 to 120 VAC, 2.6 W (network off)
12 W (network on)
220 to 240 VAC, 4.6 W (network off)
12 W (network on)
206
Technical Specifications
Environmental
Temperature
Humidity
(non-condensing)
Operating: 41 to 95 °F (5 to 35 °C)
Storage: 14 to 140 °F (–10 to 60 °C)
Operating: 20 to 80% RH
Storage: 10 to 90% RH
Operating altitude
0 to 7,500 ft (0 to 2,286 m)
Safety and Approvals
United States
FCC 47CFR Part 15B Class B (DoC)
UL60950 Third Edition
Canada
ICES-003 Class B
CSA C22.2 No. 60950
CE Marking
Directive 73/23/EEC
Directive 89/336/EEC
IEC 60950 Third Edition
EN 55022, EN 55024
Pixelworks™ DNX™ ICs are used in this projector.
Compatible Video Formats
The projector supports the high definition video and computer
display formats listed below, as well as traditional NTSC, PAL, and
SECAM video standards.
To project images output from a computer, the computer’s video card
must be set at a refresh rate (vertical frequency) that’s compatible with
the projector. Some images are automatically resized using Epson’s
SizeWize™ technology to display in the projector’s native format
(XGA). The frequencies of some computers may not allow images to
display correctly; see your computer’s documentation for details.
Technical Specifications 207
Compatible video formats
208
Technical Specifications
Mode
Refresh Rate (Hz)
Resolution
VGA EGA
70
640 × 350
VGA—60
VESA—72
VESA—75
VESA—85
VGA—120
60
72
75
85
120
640 × 480
640 × 480
640 × 480
640 × 480
640 × 480
SVGA—56
SVGA—60
SVGA—72
SVGA—75
SVGA—85
SVGA—120
56
60
72
75
85
120
800 × 600
800 × 600
800 × 600
800 × 600
800 × 600
800 × 600
XGA—60
XGA—70
XGA—75
XGA—85
XGA—120
60
70
75
85
120
1024 × 768
1024 × 768
1024 × 768
1024 × 768
1024 × 768
SXGA1—70
SXGA1—75
SXGA1—85
SXGA1—120
70
75
85
120
1152 × 864
1152 × 864
1152 × 864
1152 × 864
SXGA2—60
SXGA2—75
SXGA2—85
SXGA+60
SXGA+75
SXGA+85
60
75
85
60
75
85
1280 × 960
1280 × 960
1280 × 960
1400 × 1050
1400 × 1050
1400 × 1050
SXGA3—60
SXGA3—75
SXGA3—85
60
75
85
1280 × 1024
1280 × 1024
1280 × 1024
UXGA—60
60
1600 × 1200
iMAC VGA
iMAC SVGA
iMAC XGA
MAC13
MAC16
MAC19
MAC19-60
MAC21
117
95
75
67
75
75
59
75
640 × 480
800 × 600
1024 × 768
640 × 480
832 × 624
1024 × 768
1024 × 768
1152 × 870
Compatible video formats (continued)
Mode
Refresh Rate (Hz)
Resolution
NTSC
NTSC 4:43
PAL
N-PAL
M-PAL
PAL—60
SECAM
60
60
50
50
60
60
50
—
—
—
—
—
—
—
HDTV (720p)
HDTV (720p)
HDTV (1080i)
HDTV (1080i)
60
50
60
50
—
—
—
—
TV480i
TV625i
SDTV (480p)
SDTV (576p)
60
50
60
50
—
—
—
—
Technical Specifications 209
210
Technical Specifications
D
Notices
This appendix includes safety instructions and other important information
about your projector.
Important Safety Instructions
Follow these safety instructions when setting up and using the projector:
■
Do not look into the lens when the projector is on. The bright light can
damage your eyes.
■
Do not place the projector on an unstable cart, stand, or table.
■
Do not operate the projector on its side, or while tilted to one side.
Do not tilt the projector forward or back at a greater angle than that
specified for vertical keystone correction (see page 205).
■
If the projector is mounted on a ceiling, it should be installed by
qualified technicians using mounting hardware designed for use with
this projector.
■
Do not stand on the projector or place heavy objects on it.
■
Do not use the projector where it may be exposed to rain, water, or
excessive humidity.
■
Unplug the projector from the wall outlet before cleaning. Use a damp
cloth for cleaning. Do not use liquid or aerosol cleaners.
■
Never spill liquid of any kind into the projector.
■
Do not use the projector where it may be exposed to excessive dust or
smoke.
■
Never push objects of any kind through the cabinet slots.
■
Do not use or store the projector or remote control in a hot location,
such as near a heater, in direct sunlight, or in a closed vehicle.
■
Do not block the slots and openings in the projector case. They provide
ventilation and prevent the projector from overheating. Do not operate
the projector on a sofa, rug, or other soft surface, or set it on top of loose
papers, which could block vents underneath your projector.
211
212
Notices
■
Do not operate the projector in a closed-in cabinet unless proper
ventilation is provided.
■
If you are using two or more projectors side-by-side, leave at least 2 feet
(60 cm) of space between the projectors to allow for proper ventilation.
■
You may need to clean the air filter and vent. A clogged air filter or vent
can block ventilation needed to cool the projector.
■
Do not use the projector outside of the required temperature range of
41 to 95 °F (5 to 35 °C). Doing so may cause an unstable display and
could lead to projector damage.
■
Do not store the projector outside of the required temperature range of
14 to 140 °F (–10 to 60 °C) or in direct sunlight for long periods of
time. Doing so may cause damage to the case.
■
Unplug the projector during lightning storms or when it will not be used
for extended periods.
■
Unplug the projector from the wall outlet and refer servicing to qualified
service personnel under the following conditions: If it does not operate
normally when you follow the operating instructions, or exhibits a
distinct change in performance. If smoke, strange odors, or strange
noises come from the projector. If the power cord or plug is damaged or
frayed. If liquid or foreign objects get inside the projector, or if it has
been exposed to rain or water. If it has been dropped or the housing has
been damaged.
■
Except as specifically explained in this User’s Guide, do not attempt to
service this product yourself. Refer all servicing to qualified personnel.
Opening or removing covers may expose you to dangerous voltages and
other hazards.
■
Use the type of power source indicated on the projector. If you are not
sure of the power available, consult your dealer or power company.
■
If you use the projector in a country other than where you purchased it,
use the correct power cord for that country.
■
Do not overload wall outlets, extension cords, or power strips. This can
cause fire or electric shock.
■
Take the following precautions when handling the plug: Do not hold
the plug with wet hands. Do not insert the plug into an outlet with dust
present. Insert the plug firmly into the outlet.
■
Do not place the projector where the cord can be walked on.
■
The lamp(s) in this product contain mercury. Please consult your
state and local regulations regarding disposal or recycling. Do not put in
the trash.
■
If the lamp breaks, ventilate the room to prevent gases contained in the
lamp from being inhaled or coming in contact with the eyes or mouth.
■
If the projector is mounted overhead and the lamp breaks, be careful to
prevent pieces of glass from falling into your eyes when you open the
lamp cover.
WARNING: The cords included with this product contain chemicals,
including lead, known to the State of California to cause birth defects or
other reproductive harm. Wash hands after handling. (Provided in accordance
with Proposition 65 in Cal. Health & Safety Code §25249.5 et seq.)
FCC Compliance Statement
For United States Users
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio or television reception.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause interference to radio and television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
■
Reorient or relocate the receiving antenna.
■
Increase the separation between the equipment and receiver.
■
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
■
Consult the dealer or an experienced radio/TV technician for help.
WARNING
The connection of a non-shielded equipment interface cable to this
equipment will invalidate the FCC Certification of this device and may cause
interference levels which exceed the limits established by the FCC for this
equipment. It is the responsibility of the user to obtain and use a shielded
equipment interface cable with this device. If this equipment has more than
one interface connector, do not leave cables connected to unused interfaces.
Changes or modifications not expressly approved by the manufacturer could
void the user’s authority to operate the equipment.
Notices 213
For Canadian Users
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement
sur le materiel brouilleur du Canada.
214
Notices
Index
A
C
A/V Mute
button, 31
display settings, 148
Access Point mode, 68 to 78
Access point, checking IP address of, 75 to 76
Accessories, 13
Ad Hoc mode, 61 to 67
Air filter
cleaning, 173
ordering, 13
replacing, 174 to 177
AirPort, configuring for wireless, 66 to 67,
76 to 78
Altitude, 149, 184, 207
Anti-theft device, 13, 17, 204
Aspect ratio, 205
Audio
connecting equipment, 50 to 51
controlling volume, 33
problems, troubleshooting, 190
turning off (using A/V Mute), 31
using with scenarios, 120
Authentication, 87 to 88
Auto Setup setting, 141
Autorun setting, 128 to 129
Cables
HD15-to-component, 12, 47
illustrations, 12
mouse, 42
network, 55
ordering, 13
remote control cable set, 13
security, 204
S-video, 13, 46
VGA, 40
VGA-to-component, 12, 47
Camera, see Digital camera
Capturing image, 147
Carrying case, 12
Ceiling mount, 13, 203
Certificate validation, 88
Cleaning
air filter, 173
lens, 172
projector case, 172
CMYK color format, 133
Color
correcting, 28
multi-screen adjustment, 151
problems, 189 to 190
saturation, 139
settings, 138 to 139
temperature, 139
Color Mode, 28, 138 to 139
CompactFlash card
inserting, 53
moving files to, 169 to 170
projecting from, 112 to 113
transferring scenarios to, 128 to 129
Component video cable, 13, 44
Composite (RCA) video cable, 44 to 45
Computer
connecting to, 40 to 43
selecting source, 20
B
Background Color setting, 120
Background screen settings, 148
Bands, vertical, 189
Blackboard color mode, 28, 139
Blackboard, projecting on, 28
Blank screen, 21 to 22
Blurry image, 188
bmp, 133
Brightness, 205
Brightness control, 143
Brightness setting, 139
215
Connecting projector
to audio equipment, 50 to 51
to computer, 40 to 43
to digital camera, 52
to external monitor, 49
to speakers, 51
to video equipment, 44 to 48
Continuous play setting, 116, 129
Contrast setting, 139
Custom screen, see User’s Logo
Customized color mode, 28, 139
D
Data encryption, 96 to 97
Default settings, restoring, 137
DHCP, 69, 73, 77, 192, 193
Digital camera
connecting to, 52
projecting images from, 113 to 114
Direct Power On, 19
Display order setting, 116
Distance from projector to screen, 16, 205
Documentation, 10
DPOF, 133
Drive, external, 112 to 113
DVD player, connecting, 44 to 48
E
EAP authentication, 87 to 88
EAP-TLS certificate, 88
EasyMP
problems, 193 to 195
software, 199 to 202
starting, 58, 154
Electrical specifications, 206
E-mail alerts, 155 to 156
EMP Monitor
changing monitoring interval, 165
monitoring the projector, 157 to 165
problems, 191
using, 157 to 165
216
Index
EMP NS Connection
configuring projector for, 68 to 88
creating password for, 60
disconnecting, 91
entering keyword, 91
installing software, 199 to 202
problems, 191 to 193
projecting wirelessly, 57 to 101
using, 89 to 101
EMP SlideMaker
checking scenarios, 125
converting PowerPoint files, 117 to 118
creating scenarios, 117 to 124
problems, 193 to 194
setting up transitions, 123 to 124
transferring scenarios to drive, 128 to 129
Encryption, 66, 72, 84 to 85, 96 to 97
Environmental specifications, 207
Epson
accessories, 13
presentation tips, 11
PrivateLine Support, 11
technical support, 10, 197 to 198
warranty, 11
ESSID, 63, 66, 72, 77, 92, 192
Ethernet connection, 154 to 155
Explorer, Windows, 169 to 170
External drive, projecting from, 112 to 113
External monitor, connecting, 49
E-Zoom button, 32
F
FCC compliance statement, 213
Files, sending to projector, 169 to 170
Filter, see Air filter
Finder, Macintosh, 169 to 170
Focusing image, 24
Freeze button, 32
FTP, sending files to projector, 169 to 170
G
K
Game color mode, 28, 138
Gateway address, checking, 75
Kensington anti-theft device, 13, 17, 204
Keystone correction, 24 to 27, 143, 187, 205
Keyword, 60, 91
H
HDTV images, video formats, 209
Height of image, adjusting, 23
Help, 197 to 198
Help system, using, 182
Help, Epson, 10
High altitude, 149, 184
I
adjusting, 23 to 28, 138 to 139
blurry, 188
capturing and saving in projector, 147
correcting shape, 24 to 27, 143, 187
fitting on screen, 141, 187
height, adjusting, 23
problems with, 185 to 190
projecting on chalkboard, 28
raising, 23
rotating, 113, 114, 115, 130
selecting source, 20, 30, 45 to 48
shape, correcting, 24 to 27
size and projection distance, 16, 205
turning off (using A/V Mute), 31
turning off temporarily, 31
zooming, 24, 32
Image menu, 138 to 139
Info menu, 178
Infrastructure mode, see Access Point mode
Input signal, selecting, 20, 30, 45 to 48
Installing projector, 203 to 204
Installing software, 199 to 202
Instant Off, 20
IP Connect Mode, 94 to 95
J
jpg, 133
L
Lamp
number of hours used, 178
ordering, 13
replacing, 174 to 178
specifications, 206
status light, 183 to 184
Lamp timer, resetting, 177 to 178
Language setting, 150
Laptop computer
connecting to, 40 to 41
display problems, 21 to 22, 185 to 186
selecting source, 20, 30
LEAP authentication, 87 to 88
Lens, cleaning, 172
Lights, status, 183 to 184
Locking projector, 90
Logo, saving on projector, 146 to 148
M
Mac
configuring for wireless, 66 to 67, 76 to 78
display problems, 186
EasyMP system requirements, 200
Finder, 169 to 170
Manuals, 10
Menus
changing settings, 136 to 137
default settings, restoring, 137
Image, 138 to 139
Info, 178
network, 59, 61, 68, 84, 86, 87, 88, 154,
155
Signal, 141 to 142
User’s Logo, 147
Monitor, connecting, 49
Index 217
Monitoring projector
e-mail notifications, 155 to 156
EMP Monitor, 157 to 165
Mouse
compatibility, 205
connecting cable for remote, 42 to 43
using remote control as, 35
Movie files
projecting from external drive, 112 to 113
using in scenarios, 120 to 123
Movie Sending Mode, 102
MP4, 133
MPEG, 102, 133
mpg, 133
mrk, 133
Multiple projectors, controlling, 36 to 37
Multi-screen color adjustment, 151
Multi-screen projection, 98 to 101, 202
N
Network
cable, 55
managing projector remotely, 153 to 170
problems, 191 to 193
projecting, 89 to 91
security, 95 to 97
setting, 160, 169
wired, 154 to 155
wireless, 54, 57 to 109
Network card
compatible, 199
inserting, 54
Network settings, configuring, 58 to 88
No Signal message, 21, 186
Noise level, 205
Not Supported message, 187
NS Connection, see EMP NS Connection
Numeric keypad, using, 145
218
Index
O
Operation Lock setting, 143, 148
Optical aspect ratio, 205
Options for projector, 13
P
Password
protection, 145 to 146
remote access, 60
request code, 146
PC Free, 112 to 117, 130 to 134
PEAP authentication, 87 to 88
Photo color mode, 28, 138
Picture source, selecting, 20, 30, 45 to 48
Picture, see Image
PIN code method, 78, 82 to 83
png, 133
Pointer shape, 143
Pointer tool, using, 33 to 34
Positioning
image, 23
projector, 16 to 17, 203 to 204
Power
button, 19
specifications, 206
status light, 19, 183 to 184
PowerPoint files
adding slides to a scenario, 120 to 122
converting to scenarios, 117 to 118
presenting, 130
problems, 193 to 194
Presentation color mode, 28, 138
Presentation Mode, 103
Presentations
computer, 40 to 43
digital camera, 52, 113 to 114
images and movies, 112 to 117
room conditions, 16, 30
scenarios, 130
tips and training, 11
using the pointer tool, 33 to 34
video, 44 to 48
wireless, 57 to 101
Presenter View, 104 to 106
Presenters Online, 11
PrivateLine Support, 11
Problems
color, 189 to 190
connecting wirelessly, 92, 191 to 193
image, 185 to 190
monitoring projector, 191
no signal, 21, 186
remote control, 196
scenarios, 193 to 194
sound, 190
using on-screen help, 182
Progressive format, 133, 141
Projecting without screen, 28
Projection lamp, see Lamp
Projector
cleaning, 172
disabling buttons, 148
distance from screen, 16, 205
installing, 203 to 204
lamp specifications, 206
locking, 90
monitoring remotely, 153 to 170
options, 13
password protection, 145 to 146
positioning, 16 to 17
resolution, 205
security features, 144 to 148, 204
specifications, 205 to 207
transporting, 180
troubleshooting, 181 to 184
turning off, 20
turning on, 17 to 19
unpacking, 12
viewing information about, 178
Projector ID, setting, 36
Push button method, 78, 80 to 81
Q
Quick Corner, 25, 143
R
Raising image, 23
Rear-screen projection, 149, 203
Registration, 11
Remote control
A/V Mute button, 31
as wireless mouse, 35
battery used, 206
connecting cable for mouse, 42 to 43
controlling multiple projectors, 36 to 37
correcting color, 28
E-Zoom button, 32
Freeze button, 32
ID, 37
numeric keypad, using, 145
pointer tool, using, 33 to 34
problems, 196
range, 206
running slideshow with, 130
specifications, 206
switching sources, 30
troubleshooting, 196
Remote Receiver setting, 144
Replacing lamp, 174 to 178
Request code, password, 146
Resetting lamp timer, 177 to 178
Resetting menu options, 137
Resize image, 28
Resolution, 28, 187, 205
Rotating the image, 113, 114, 115, 130
S
Safety
instructions, 211 to 213
specifications, 207
Saturation setting, 139
Index 219
Scenarios
adding movie files, 120 to 123
adding sound, 120
background color, 120
cells, 122
converting PowerPoint files, 117 to 118
creating, 117 to 124
default location, 120
editing, 126 to 127
exiting, 115, 130
presenting on the projector, 130
previewing, 125
problems, 193 to 194
rearranging, 122
running automatically, 128 to 129
transferring to drive, 128 to 129
transitions, 123 to 124
Screen
blank, 21 to 22
distance from projector, 16, 205
ordering, 13
startup screen, creating, 146 to 147
Screen image, see Image
Screen switching time setting, 117
Security
cables, 204
identifying logo, 147 to 148
Kensington lock, 13, 204
network, 95 to 97
Operation Lock, 148
password protection, 145 to 146
Sharpness setting, 139
Signal menu, 141 to 142
sit (presentation file type), 133
Six-axis color adjustment, 140
Sleep mode, 18
SlideMaker, see EMP SlideMaker
Slideshow, creating from images, 114 to 117
Software installation, 199 to 202
Sound
adding to scenarios, 120
troubleshooting, 190
Source, selecting, 20, 30
Speaker, specifications, 205
220
Index
Speakers, connecting, 51
Special effects, adding to slide transitions, 117,
124
Specifications
brightness, 205
dimensions, 206
electrical, 206
environmental, 207
general, 205
lamp, 206
remote control, 206
resolution, 205
safety, 207
Sports color mode, 28, 138
sRGB color mode, 28, 139
SSID, see ESSID
Standby Mode setting, 160, 169
Startup screen
creating, 146 to 148
settings, 148
user’s logo, see User’s Logo
Status lights, 183 to 184
Support, see Technical support
S-video cable, 13, 46
Switching picture source, 20, 30
Sync setting, 141
Synchronization, adjusting, 189
T
Technical support, 10, 197 to 198
Temperature
requirements, 207
status light, 183 to 184
Temperature, color, 139
Test pattern, displaying, 144
Text color mode, 28, 138
Theatre color mode, 28, 138
Thumbnails, scenario, 121
Tint setting, 139
Tracking, adjusting, 189
Transferring files to projector, 169 to 170
Transitions, scenario, 123 to 124
Transporting projector, 180
Troubleshooting
blank screen, 21 to 22, 185 to 186
cut-off image, 187
distorted image, 24 to 27
EasyMP problems, 193 to 195
image and sound problems, 185 to 190
network problems, 191 to 193
no signal, 21, 186
projector problems, 181 to 184
remote control problems, 196
tapered image, 24 to 27
wireless projection problems, 92,
191 to 193
Turning off picture (using A/V Mute), 31
Turning off projector, 20
U
Unpacking projector, 12
USB
cable, 12, 41, 43
display, 41 to 42
USB drive
projecting from, 112 to 113
transferring scenarios to, 128 to 129
User’s Logo
creating, 147
display settings, 148
V
VCR, connecting, 44 to 48
Video
cables, 12, 13, 44
connecting video equipment, 44 to 48
formats, supported, 207 to 209
projecting wirelessly, 102
selecting source, 20, 30, 45, 46
Video Signal setting, 142
Virtual display, 202
Volume, controlling, 33, 143
W
Warning lights, 183 to 184
Warranty, 11
WEP encryption, 84 to 85
Wi-Fi, 78 to 83
Windows
configuring for wireless, 64 to 66, 70 to 74
display problems, 186
EasyMP system requirements, 199
Explorer, 169 to 170
Vista, 107 to 109, 199 to 200
Wired network, 154 to 155
Wireless
connecting manually, 94 to 95
EAP, 87 to 88
EAP-TLS, 88
LEAP, 87 to 88
module, 12
network card, 54, 58, 199
PEAP, 87 to 88
presentation, 57 to 101
problems, 191 to 193
security, 95 to 97
WEP encryption, 84 to 85
Windows Vista, 107 to 109, 199 to 200
WPA security, 86
Wireless, mouse, 35, 42 to 43
WMA, 133
WMV, 133, 194
WPA security, 86
WPS connection, 78 to 83
Z
Zoom ratio, 205
Zooming image, 24, 32
Index 221
