Auto pan with 16steps
20x Mega pixel zoom
1080p 30fps
Light distance 200m
HD-SDI(SMPTE 292M)
EWSJ-M202
Full HD Mega-pixel Speed Dome Camera
SPECIFICATIONS
MECHANICAL / ENVIRONMENTAL
Pan
360° Continuous Pan
0.1º to 90º/sec (64 steps proportional to zoom)
FEATURES
Block diagram
Slip ring
LVDS buffer with transmit
Pre-Emphasis and
receive equaliztion
1920 x1080
1920 x1080
/ 60i
/ 60i
LVDS
Gennum
Transmitter
LVDS
L
VDS
Rx
Camera
Part
HD-SDI
0.1º to 90º/sec. (64 steps proportional to zoom)
Tilt Preset Speed
150°/sec, ± 0.01° Accuracy
Weight
Approx. 4.4Kg (10.8 lbs) / Packing : 4.9Kg
Dimensions
236(Ø) x 325.9(H) mm – 166(Ø) dome
Construction
Aluminum
Ingress Protection
IP66 (Outdoor Housing)
Color
Cool gray
Operating Temp
-20°C to 50°C (Fan&Heater power ON)
Storage Temp
-10°C to 50°C (14° F to 122° F)
Humidity
0% to 90% (non-condensing)
Digital Out
Controller
(BT1120)
CVBS Out
RS-232
Web
Server
Tilt motor :RS-232
Tilt
Motor
24pin slip ring
MCU Board
PAN
Motor
DIMENSIONS
Unit : mm
Ø197
Ø177.3
Ø125.2
83.2
83.2
Ø166.0
Ø236.0
EWSJ-M202
CVBS -1 channel , IP Webserver (Option)
FUNCTIONS
Preset
255 points
less than 0.1° accuracy
Tour
8 programmable
Pattern
4 patterns for 240 second.
Flip
Digital ON/OFF
Scan
8 (programmable speed and diagonal scan)
Privacy Zone
Programmable up to 16
ID Address
Up to 255 selectable ID (Rotary switch)
Data Communication
RS-485 / RS-422
Protocol
Multiple protocol (PELCO-D/P, WONWOO)
Baud rate
2400, 4800, 9600, 19200, 38400, 57600 bps selectable
Alarm In
8 alarm
Alarm Out
2 relay out
Display
16 Area title
ELECTRICAL / USER CONNECTIONS
Power
21~28VAC 60Hz / 50Hz(Power adaptor not included)
Camera
18.0W
Heater
33W or 62.7W, Fan Power Consumption: 3.4W
RS-422, 485
Dip Switch setting
RS-485, 422
RS-422, 485 + / - Optional Control Data
Alarm Inputs
8 Programmable
Relay Out
2 Dry Contact Output Rating: 2A @30VAC
EWSJ-M202F
Picture elements
Lens
Digital zoom
1/3” 2M Pixel CMOS Sensor
1920 x 1080 pixels
20× zoom F= 4.7 mm (WIDE) to 94.0 mm (TELE), F1.6 to F3.5
32x (640x with optical zoom)
Angle of view (H)
Approx. 55.4 degrees (WIDE end), approx. 2.9 degrees (TELE end) (1080i mode)
Approx. 37.6 degrees (WIDE end), approx. 2.0 degrees (TELE end) (720p mode)
Min. working distance
Sync system
Min. illumination
10 mm (WIDE end), 800 mm(TELE end)
Internal
0.5 lux/1/30 sec., 50% (Interlace mode) (High Sensitivity mode ON)
1.7 lux/1/30 sec., 50% (Typical value) 0.26 lux/1/4 sec (NTSC),
1/3 sec (PAL) (Typical value) /
Recommended illumination
183.6
266.8
185.5
57.2
207
HD-SDI - 1 channel (1080i60,1080p30,720p60,1080i50, 1080p25, 720p50 )
CAMERA
(NTSC/PAL)
I/F Board
Video Out
(1080/60i)
OSD
10pin
10pin
325.9
380°/sec, ± 0.1° Accuracy
Tilt
VIDEO
• 1/3" 2M Pixel CMOS image sensor that supports FULL HD (High Definition)
• Using progressive scan and Auto WDR
• 20x optical zoom and F1.6 aperture (optical zoom + digital zoom = 240x).
• Good at low-light environments using the Noise Reduction function.
• Video signals can be output as digital and analog Y/Pb/Pr outputs.
• A variety of digital output methods
• Auto ICR
• Motion Detection
• IP66 Outdoor Application
• Digital Auto Flip
• 8 Alarm Inputs(Normal Open or Normal Close), 2 relay out puts
• 8 Auto Scan(Programmable speed and diagonal scan)
• Pan Motion Allows 0.1-90°/sec Pan Speed
• Programmable Privacy Masking(8 Zones)
• RS-422, RS-485 communication support and remote program update
• Programmable Zoom Speeds
RS-232
Pan Preset Speed
ICR-ON Mode 0.0005 lux/1/4 sec (NTSC), 1/3 sec (PAL)
100 to 100,000 lux
S/N ratio
Back light compensation
Electronic shutter speed
50 dB (Weight ON)
ON/OFF
60/30 mode: 1/1 to 1/10000 sec.(22 steps) /
50/25 mode: 1/1 to 1/10000 sec. (22 steps)
White balance
Gain
AUTO, ATW, Indoor, Outdoor, One Push WB,
Manual WB, Outdoor Auto, Sodium Vapor
Auto/Manual (–3 dB to +28 dB, 16 steps)
Wide dynamic range
Noise reduction
Color Enhancement
Aperture control
ON/OFF/AUTO
ON/OFF (level 5 to 1 / OFF, 6 steps)
ON/OFF
16 steps
Preset
Serial interface
6 positions
VISCA protocol (TTL/CMOS) 9.6 Kbps, 19.2 Kbps, 38.4 Kbps
WTK-M202
Full HD Mega-pixel Rugged PTZ Camera
Auto pan with 16steps
20x Mega pixel zoom
1080p 30fps
Light distance 200m
HD-SDI(SMPTE 292M)
SPECIFICATIONS
MECHANICAL
Pan
Tilt
Angle
360° Continuous pan
Manual Speed
0.1° to 90°/sec (64 step proportional to zoom)
Preset Speed
150°/sec, ±0.1° Accuracy
Angle
180°(±90°)
Manual Speed
0.1° to 90°/sec (64 step proportional to zoom
Preset Speed
150°/sec, ±0.1° Accuracy
Dimensions
392(W) x 211 (H) x 389.5 (D)
Weight
Motor
less then 12.5Kg
Holding Torque
13.5Kgf/㎝, 1.35N.m
Step Angle
1.8° Deg.
Winding Type
Bipola
ENVIRONMENTAL
FEATURES
Ingress Protection
• 1/3" 2M Pixel CMOS image sensor that supports FULL HD (High Definition)
• Using progressive scan and Auto WDR
• 20x optical zoom and F1.6 aperture (optical zoom + digital zoom = 240x).
• Good at low-light environments using the Noise Reduction function.
• Video signals can be output as digital and analog Y/Pb/Pr outputs.
• A variety of digital output methods
• Auto ICR
• Up to 63 preset positions.
• Variable speed control for all motorized functions.
• 360° unobstructed rotation using the heavy duty long life slip ring.
• All weather, lightweight, high impact aluminum die-cast enclosure(IP66).
• Built-in wiper system for constant load and reduced noise.
• Built-in Super IR LED 30pcs. (Light distance 200m / manual focusing)
• Smart IR response by Auto Light Control (100 steps)
• Auto position calibration by encoding data
Temperature
Temperature
Operating Control
PTZ Control
LVDS buffer with transmit
Pre-Emphasis and
receive equaliztion
1920 x1080
/ 60i
/ 60i
Gennum
Transmitter
LVDS
L
VDS
Rx
Camera
Part
(1080/60i)
OSD
Digital Out
(BT1120)
CVBS Out
10pin
10pin
HD-SDI
Controller
-20°C to 60°C
Fan
-10°C to 40°C (4 step control)
Heater
-10°C to 0°C (4 step sontrol)
Humidity
50% to 90% (4 step control)
Method
RS-422(4 wire), RS-485(2 wire)
Power
Voltage
DC11.5V ~ DC30V, AC15 ~ AC30V(60HZ), Dual Power
Current
DC15V,8A / AC24V,5A
Heater / Fan
10W, 3.4W
VIDEO
Video Out
HD-SDI - 1 channel (1080i60,1080p30,720p60,1080i50, 1080p25, 720p50 )
CVBS -1 channel , IP Webserver (Option)
IR ILLUMINATION
Length
200m (Manual Focusing)
Power
OSRAM 870n, 1W, 30EA
CAMERA
Slip ring
1920 x1080
-20°C to 50°C
Storage Temp
ELECTRICAL
Block diagram
RS-232
Aluminum
Operating
COMMUNICATION
IR LED
LVDS
IP66
Construction
Picture elements
1/3” 2M Pixel CMOS Sensor
1920 x 1080 pixels
Lens
Digital zoom
20× zoom F= 4.7 mm (WIDE) to 94.0 mm (TELE), F1.6 to F3.5
32x (640x with optical zoom)
Angle of view (H)
Approx. 55.4 degrees (WIDE end), approx. 2.9 degrees
(TELE end) (1080i mode)
Approx. 37.6 degrees (WIDE end), approx. 2.0 degrees
(NTSC/PAL)
I/F Board
RS-232
Web
Server
Tilt motor :RS-232
Tilt
Motor
PAN
Motor
MCU Board
24pin slip ring
DIMENSIONS
392
114
211
70
389.5
Unit : mm
28
172
(TELE end) (720p mode)
Min. working distance
Sync system
Min. illumination
10 mm (WIDE end), 800 mm(TELE end)
Internal
0.5 lux/1/30 sec., 50% (Interlace mode) (High Sensitivity mode ON)
1.7 lux/1/30 sec., 50% (Typical value) 0.26 lux/1/4 sec (NTSC),
1/3 sec (PAL) (Typical value) /
Recommended illumination
S/N ratio
ICR-ON Mode 0.0005 lux/1/4 sec (NTSC), 1/3 sec (PAL)
100 to 100,000 lux
50 dB (Weight ON)
Back light compensation
Electronic shutter speed
ON/OFF
60/30 mode: 1/1 to 1/10000 sec.(22 steps) /
White balance
50/25 mode: 1/1 to 1/10000 sec. (22 steps)
AUTO, ATW, Indoor, Outdoor, One Push WB,
Manual WB, Outdoor Auto, Sodium Vapor
Gain
Wide dynamic range
Auto/Manual (–3 dB to +28 dB, 16 steps)
ON/OFF/AUTO
Noise reduction
Color Enhancement
Aperture control
ON/OFF (level 5 to 1 / OFF, 6 steps)
ON/OFF
16 steps
Preset
Serial interface
6 positions
VISCA protocol (TTL/CMOS) 9.6 Kbps, 19.2 Kbps, 38.4 Kbps
WCA-M202
Full HD Mega-pixel Rugged IR PTZ Camera
20x Mega pixel zoom
1080p 30fps
HD-SDI(SMPTE 292M)
WDR (Wide dynamic range)
The Camera delivers clear, high quality pictures even in backlight,
by increasing exposure in dark areas while decreasing it in bright areas
a corrected image with clear details results.
HOUSING &
ACCESSORY
SPECIAL
RAPPORT
IR BULLET
CAMERA
VANDAL &
PLASTIC
BOX
CAMERA
ZOOM
CAMERA
CONTROLLER
RUGGED
PTZ CAMERA
SPEED
DOME CAMERA
HD SDI
At Normal Speed Shutter
FEATURES
• 1/3" 2M Pixel CMOS image sensor that supports FULL HD (High Definition)
• Using progressive scan and Auto WDR
• 20x optical zoom and F1.6 aperture (optical zoom + digital zoom = 240x).
• Good at low-light environments using the Noise Reduction function.
• Video signals can be output as digital and analog Y/Pb/Pr outputs.
• A variety of digital output methods
• Auto ICR
• 12pcs of 18ø IR LED(120m manual focusing)
• DC12V version for vehicle application :
The power ground and video ground in DC12V version is unified in
common so that the power can be input from vehicle.
• AC24V version for CCTV : AC24V is available for CCTV application.
• IP66 Outdoor Application
• Endless Pan rotation(TOP 15°~270°, BOTTOM 345°~90° tilt angle)
• Up to 63 programmable presets
• less than 0.3° Preset Accuracy
• 8 programmable Tour, 2 Pattern
• Alarm - Move the camera to programmed Preset position
with Alarm trigger.(Max. 2)
• 4 Scan(Programmable speed and diagonal scan)
• Programmable Privacy Masking(2 Zones)
• RS-422, RS-485 communication
• Multiple protocol (WTX, PELCO-D V1, PELCO-P, PELCO-D V5)
• Built-in Menu System for Setup of Programmable Functions
• Mechanical Auto Flip
• Programmable Zoom Speed(Optional Update tool)
At High Speed Shutter
Simulated Image
Light Function
It’s builtin 12pcs of 18ø IR Lens , So it provides visible distance up
to 120m in the dark.(manual focusing)
Auto ICR
These cameras offers optimal sensitivity in both day and night shooting
applications. At a set level of darkness, the IR-cut filter is automatically
disabled (ICR ON) and the near-infrared sensitivity is increased. At a set
level of brightness, the filter is automatically enabled (ICR OFF). The IR-cut
filter automatically engages depending on the ambient light, allowing
the camera 24/7 operation in a variety of lighting conditions.
WCA-M202
Full HD Mega-pixel Rugged IR PTZ Camera
SPECIFICATIONS
CAMERA SELECTION
MECHANICAL
Pan
MODEL
WCA-M202
360° Endless Pan
Imager
1/3” 2M Pixel CMOS Sensor
0.1° to 100°/sec.
Picture elements
1920 x 1080 pixels
110°/sec, 0.3° Accuracy
Lens
20× zoom F= 4.7 mm (WIDE) to 94.0 mm (TELE), F1.6 to F3.5
Tilt
TOP 15°~270° , BOTTOM 345°~90° tilt angle, Proportional to zoom
Digital zoom
12x (240x with optical zoom)
Tilt Preset Speed
60°/sec, 0.3° Accuracy
Angle of view (H)
Approx. 55.4 degrees (WIDE end), approx. 2.9 degrees
Weight
2.7kg
Dimensions
138(Ø) x 212(H) mm
Pan Preset Speed
(TELE end) (1080i mode)
Approx. 37.6 degrees (WIDE end), approx. 2.0 degrees
(TELE end) (720p mode)
ENVIRONMENTAL
Min. working distance
10 mm (WIDE end), 800 mm(TELE end)
Sync system
Internal
Min. illumination
0.5 lux/1/30 sec., 50% (Interlace mode) (High Sensitivity mode ON)
Construction
Aluminum
1.7 lux/1/30 sec., 50% (Typical value) 0.26 lux/1/4 sec (NTSC),
Ingress Protection
IP66
1/3 sec (PAL) (Typical value) /
Color
Black
Operating Temp
-20°C to 50°C (Fan&Heater power ON)
Humidity
0% to 90%
ICR-ON Mode 0.0005 lux/1/4 sec (NTSC), 1/3 sec (PAL)
Recommended illumination
100 to 100,000 lux
S/N ratio
50 dB (Weight ON)
Back light compensation
ON/OFF
Electronic shutter speed
60/30 mode: 1/1 to 1/10000 sec.(22 steps) /
50/25 mode: 1/1 to 1/10000 sec. (22 steps)
FUNCTIONS
AUTO, ATW, Indoor, Outdoor, One Push WB,
White balance
Preset
63 points
Tour
8 programmable
Gain
Auto/Manual (–3 dB to +28 dB, 16 steps)
Pattern
2 patterns
Wide dynamic range
ON/OFF/AUTO
Flip
Mechanical / Auto / Off (Rotate 90° at bottom of tilt)
Noise reduction
ON/OFF (level 5 to 1 / OFF, 6 steps)
Auto Scan
4 (programmable speed and diagonal scan)
Color Enhancement
ON/OFF
Privacy Zone
2 blocks with title (Masking / Video off)
Aperture control
16 steps
Address
Up to 255 selectable ID (Rotary switch)
Preset
6 positions
Serial interface
VISCA protocol (TTL/CMOS) 9.6 Kbps, 19.2 Kbps, 38.4 Kbps
Data Communication
RS-485 / RS-422
Protocol
Multiple protocol(WTX, PELCO-D V1, PELCO-P, PELCO-D V5)
Baud rate
2400, 4800, 9600, 19200, 38400 ,57600, 115200 bps
Alarm In
2 alarm (NO/NC, Priority)
Alarm Out
2 relay out (Hold, Latch)
Display
Zone title on/off (start / end zone)
Manual WB, Outdoor Auto, Sodium Vapor
DIMENSIONS
Unit : mm
ELECTRICAL
Power
177
DC 12V, 40W, 3.3A
(Power adaptor not included)
IR : 1.9A (23W) (Fan &Heater ON)
12pcs of 18ø IR LED
Light distance
120m (manual focusing)
212
Light
Video Out
55
VIDEO
HD-SDI - 1 channel (1080i60,1080p30,720p60,1080i50,
1080p25, 720p50 )
CVBS -1 channel , IP Webserver (Option)
138
80
CERTIFICATION
60
8
13
145
90
CE, FCC CLASS A, RoHS
2.2 Mega Pixel
1080p & 720p
WDR & ACE
DSS & 3D-DNR
MB-12
2.2Mega pixel HD-SDI Box camera
SPECIFICATIONS
MODEL
MB-12
Image Sensor
1/3" Panasonic CMOS
Total Pixels
2010(H) x 1108(V) = 2,227,080 (pixel)
Active pixels
1944(H) x 1092(V) = 2,122,848 (pixel)
Scanning system
Progressive
Resolution
Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps)
Analog : 700TVL
FEATURES
• 1/3” 2.2Mega pixel CMOS image sensor that supports both Full HD of 1080p
and HD 720p (Max 1,100TV Lines, OSD selectable)
• Using progressive scan and Auto WDR
• Supports DSS(Digital Slow Shutter) and 3D DNR(Dynamic Noise Reduction)
to enhance the performance in low-light environment
• Minimum illumination of Color 1.0 lux (DSS off)
• Supports not only SDI output, but also analog spot-out
• Supports various white balance mode of Auto, One pushing and Manual
• Supports ACE (Advanced Contrast Enhancement)
• Supports various digital features of Mirror, Flip, Digital Zoom, Privacy Masking,
Motion Detection, Sharpness control and shading
• Supports Multi-protocol of Pelco D/P
• Supports TDN IR Cut-filter change
DIMENSIONS
Unit : mm
Min. illumination
Color : 1.0 lux , BW : 0.5lux, Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video Output
HD-SDI, Analog : NTSC, PAL(without WDR)
S/N Ratio
more than 50dB (AGC off)
BRIGHTNESS
0 ~ 20 steps
LENS
C/CS mount lens
SHUTTER SPEED
Auto / Manual ( 1/30(1/25) ~ 1/60000 )
DSS
Off / x2 / x3 / x4
AGC
Off / On
WDR/BLC
Off / WDR / BLC
DAY&NIGHT
Auto / Day / Night / Ext
SMART IR
Off / On
WHITE BALANCE
Auto / Preset / Manual / Indoor / Outdoor
SHARPNESS
0 ~ 10 steps
MIRROR
Off / H / V / H&V
FREEZE
Off / On
E.ZOOM
x1 ~ x32
HLC
Off / On
ACE
Off / On
DNR
Off / Low / Middle / High / Auto
D.COMPRESS
OFF / ON
PRIVACY
Off / On (32 points)
MOTION
Off / On (4 points)
SHADING DET
Off / On
SHADING
Off / On
DEFECT DET
Off / On
DEFOG
Off / On
SYSTEM
NTSC / PAL
HD FORMAT
1080P / 720P
PG(Pattern Generator)
Off / On
CVBS
Off / On
COMMUNICATION
ID (1 ~ 255)
BAUDRATE ( 2400 / 4800 / 9600 / 19200 / 38400 / 57600/115200 )
2- 1/4"-20 UNC
PROTOCOL (PELCO-P / PELCO-D / UPDATE)
RS-485 N C ALARM D&N
GND OUT GND
EXT
HD-SDI
POWER
VIDEO OUT
DEFAULT
ON / DONE
Language
English
OSD Text
0~9,A~Z,a~z
Power Source
DC12V±10%
Power Consumption
250mA
Power Input
TERMINAL BLOCK
Video Output(HD-SDI)
BNC Connector
DC12V
14
54.5
47.3
70.6
10.5
134.8
Operating Temperature
-10℃ ~ +50℃ (Humidity : 0%RH ~ 80%RH)
Storage Temperature
-20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH)
MS-100/101
SPECIFICATIONS
2.2M Full HD Mega pixel HD-SDI Mini Box Camera
MS-100/101
MODEL
Image Sensor
1/3" Panasonic CMOS
Total Pixels
2010(H) x 1108(V) = 2,227,080 (pixel)
Active pixels
1944(H) x 1092(V) = 2,122,848 (pixel)
Scanning system
Progressive
Resolution
Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps)
Analog : 700TVL
Min. illumination
Color : 1.0 lux , BW : 0.5lux, Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video Output
HD-SDI, Analog : NTSC, PAL(without WDR)
S/N Ratio
more than 50dB (AGC off)
BRIGHTNESS
0 ~ 20 steps
LENS
MS-100 : 3.0mm fixed lens / MS-101 : C/CS mount lens
SHUTTER SPEED
Auto / Manual ( 1/30(1/25) ~ 1/60000 )
DSS
Off / x2 / x3 / x4
AGC
Off / On
WDR/BLC
Off / WDR / BLC
DAY&NIGHT
Auto / Day / Night / Ext
SMART IR
Off / On
WHITE BALANCE
Auto / Preset / Manual / Indoor / Outdoor
FEATURES
SHARPNESS
0 ~ 10 steps
MIRROR
Off / H / V / H&V
• 2.2M 1080p Full HD with Panasonic CMOS
• HDMI OUT
• HD SDI (SMPTE292M)
• Composite Video output (750TV Lines)
• Digital Zoom Max 32x
• Day & Night
• Wide Dynamic Range
• Privacy Mask Function
• On Screen Display
• Intelligent motion detection
• Defog function
• 3.0mm fixed lens(MS-100)
• C/CS Mount(MS-101)
FREEZE
Off / On
E.ZOOM
x1 ~ x32
HLC
Off / On
ACE
Off / On
DNR
Off / Low / Middle / High / Auto
D.COMPRESS
OFF / ON
PRIVACY
Off / On (32 points)
MOTION
Off / On (4 points)
SHADING DET
Off / On
SHADING
Off / On
DEFECT DET
Off / On
DEFOG
Off / On
SYSTEM
NTSC / PAL
HD FORMAT
1080P / 720P
PG(Pattern Generator)
Off / On
CVBS
Off / On
COMMUNICATION
ID (1 ~ 255)
MS-101
MS-100
BAUDRATE ( 2400 / 4800 / 9600 / 19200 / 38400 / 57600/115200 )
DIMENSIONS
PROTOCOL (PELCO-P / PELCO-D / UPDATE)
Unit : mm
66.0
MS-100
50.0
55.0
59.0
DEFAULT
ON / DONE
Language
English
OSD Text
0~9,A~Z,a~z
Power Source
DC12V±10%
Power Consumption
250mA
Power Input
Connector
Video Output(HD-SDI)
BNC Connector
Operating Temperature
-10℃ ~ +50℃ (Humidity : 0%RH ~ 80%RH)
Storage Temperature
-20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH)
Connections
MS-101
50,0
55,0
og)
CVBS(Anal
g)
alo
(An
BS
CV
R
WE
PO
59,0
POWER
(+)
485
RS
low
Yel
(-)
485
RS en
Gre
RS485(+)
Yellow
RS485(-)
Green
MS-300
Mega Pixel Mini AF Zoom Box camera
SPECIFICATIONS
MODEL
MS-300
Image Sensor
1/2.9" Sony "Exmor" CMOS
Effective pixels
Approx. 2 Mega Pixels
Aspect Ratio
16 : 9
Lens
3x Optical Zoom
f=3.0mm(wide) ~ 9.0mm(tele)
F1.2 to F2.1
Digital Zoom
Max 32x
Resolution
1080P/30, 720P/60
Min. illumination
Color : 0.5 lux , BW : 0.1lux
Color DSS : 0.002 lux , BW DSS : 0.001 lux
more than 50dB (AGC off)
Camera Control Comm
Baud Rate:2400 / 4800 / 9600 / 19200 / 38400 /
57600 / 115200
Protocol : VISCA / Pelco-D / Pelco- P / Update
Focusing Mode
Auto / One Push / Manual
Shutter Speed
1/30(25) ~ 1/60,000 sec
WDR/BLC
OFF / WDR / BLC
White Balance
AUTO / One Push / Manual / Indoor / Outdoor
Power Source
9V to 15V DC
Power Consumption
500mA
Storage Temperature
-20℃ ~ +60℃ (Humidity : 20%RH ~ 95%RH)
Operating Temperature
-5℃ ~ +60℃ (Humidity : 20%RH ~ 80%RH)
External Dimension
85 X 59 X 60 mm (tentative)
DIMENSIONS
Unit : mm
FULL HD
1080P
A
6
59.00
6
5
80
95
A
59.00
63.00
• 1/2.9" Sony “Exmor” CMOS sensor
All-Pixel Scan: 1920(H) X 1200(V) app. 2.3 Mega Pixel
• x3 Optical Zoom (3mm ~9mm)
• Full HD Resolution
1920x1080p / 30fps
1280x720p / 60fps
• Day & Night (ICR)
The ICR will automatically engage depending on the
ambient light, allowing the camera to be effective in day &
night environment.
• WDR (Wide Dynamic Range)
WDR, more effectively than previous models, by applying
an optimum fusion ratio when combining the high speed
shutter used in bright areas and the low speed shutter
used in dark areas.
• DNR (Digital Noise Reduction, 2D+3D)
The DNR technology eliminates noise thus generating a
distinct and clear image. This camera DNR function
utilizes both an adaptive 2D filter reducing noise in the
brightness of the image and an adaptive 3D filter reducing
noise caused by movement.
• Privacy mask Function
The privacy zone function makes it possible to make
specific areas of the scene from view.
• Intelligent motion detection
You can transmits an alert signal when it detects motion
of an object on the screen. This feature is useful when
you have to monitor several screens simultaneously.
• Defog
Defogging foggy video image.
• HLC(High Light Compensation Function)
HDMI, HD-SDI, CVBS
S/N Ratio
HDMI
FEATURES
Video Output
MB-202
Mega Pixel Box Camera
SPECIFICATIONS
MB-202
Image sensor
Sensor type
1/3" Panasonic CMOS
Total pixels
2010(H) x 1108(V) = 2,227,080
Active pixels
1944(H) x 1092(V) = 2,122,648
Resolution
1920 x 1080 (1080p/30fps)
1280 x 720 (720p/60fps)
(Analog : 700TVL)
Scanning system
Progressive
Min.Illumination
Color : 1.0 lux , BW : 0.5 lux
Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video output
HDMI, HD-SDI, CVBS
S/N Ratio
Lens
FEATURES
• 1/3" Panasonic CMOS sensor
2,227,080pixels(Total) / 2,122,848pixels(Active)
• x20 Optical Zoom
• Full HD Resolution
1920x1080p / 30fps
1280x720p / 60fps
• Day & Night (ICR)
• WDR (Wide Dynamic Range)
• DNR (Digital Noise Reduction, 2D+3D)
• Privacy mask Function
• Intelligent motion detection
• Defog
• HLC(High Light Compensation Function)
Function
• Protocol (VISCA, Pelco-D, Pelco-P)
DIMENSIONS
Unit : mm
128
107
5
Communication
Electrical
HD Supremacy
General
More than 50dB(AGC off)
Lens type
x20, 1/3" Day & Night Zoom Lens
Zoom Ratio
Optical x20 , Digital x32
Focal length
f = 4.7 mm ~ 94 mm
Aperture Ratio
F1.6 (wide) ~ F3.5 (tele)
Focus distance
0.1 / 1.0 / 2.0 / 3.7 / 11.0 m
E.zoom
Off / x2 ~ x4
Exposure
Auto / Manual
Gain control
Off / On (Auto max.30dB)
Shutter speed
1/30(1/25) ~ 1/30,000
Digital Shutter Speed
Off / x2 ~ x512
Brightness
1 ~ 15 steps
Output format
1080p / 720p
Frequency
60Hz / 50Hz
WDR
Off / On
BLC
Off / On
HLC
Off / On
Day & Night
Auto / Day / Night / Ext.
White Balance
ATW / Preset / Indoor / Outdoor / Manual
DNR
Off / Auto / Low / Middle / High
Privacy Mask
Off / 32 positions
Motion Detection
Off / 4 positions
Defog
Off On
Mirror
Off / H / V / H+V
Sharpness
Off / On
Shading
Off / On
Smart IR
Off / On
Defect compensation
Off / On
Pattern Generation
Off / On
CVBS output
Off / On
Protocol
Pelco -D / Pelco-P / VISCA
Baud Rate
2400 / 4800 / 9600 / 19200 / 38400 / 57600
Power source
DC 12V ± 10%
Power consumption
500mA
Operating Temperature
-10℃ ~ 50℃
Storage Temperature
-20℃ ~ 60℃
REMOTE CONTROLLER
67
IRC-300
Key setting : TELE(UP) , WIDE(DOWN)
70
NEAR(LEFT), FAR(RIGHT)
MENU, F1, F2
FlatV-M12
2.2Mega pixel HD-SDI Vandal Flat dome camera
2.2 Mega Pixel
1080p & 720p
WDR & ACE
DSS & 3D-DNR
SPECIFICATIONS
MODEL
Flat V-M12
Image Sensor
1/3" Panasonic CMOS
Total Pixels
2010(H) x 1108(V) = 2,227,080 (pixel)
Active pixels
1944(H) x 1092(V) = 2,122,848 (pixel)
Scanning system
Progressive
Resolution
Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps)
Analog : 700TVL
FEATURES
• 1/3” 2.2Mega pixel CMOS image sensor that supports both Full HD of 1080p
and HD 720p (Max 1,100TV Lines, OSD selectable)
• Using progressive scan and Auto WDR
• Supports DSS(Digital Slow Shutter) and 3D DNR(Dynamic Noise Reduction)
to enhance the performance in low-light environment
• Minimum illumination of Color 1.0 lux (DSS off)
• Supports not only SDI output, but also analog spot-out
• Supports various white balance mode of Auto, One pushing and Manual
• Supports ACE (Advanced Contrast Enhancement)
• Supports various digital features of Mirror, Flip, Digital Zoom, Privacy Masking,
Motion Detection, Sharpness control and shading
• 3.0mm Mega-pixel Fixed Lens
• Supports Multi-protocol of Pelco D/P
• IP66 Aluminum Die-casting Housing
• Superior design concept of Flat dome
Min. illumination
Color : 1.0 lux , BW : 0.5lux, Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video Output
HD-SDI, Analog : NTSC, PAL(without WDR)
S/N Ratio
more than 50dB (AGC off)
BRIGHTNESS
0 ~ 20 steps
LENS
3.0mm fixed lens
SHUTTER SPEED
Auto / Manual ( 1/30(1/25) ~ 1/60000 )
DSS
Off / x2 / x3 / x4
AGC
Off / On
WDR/BLC
Off / WDR / BLC
DAY&NIGHT
Auto / Day / Night / Ext
WHITE BALANCE
Auto / Preset / Manual / Indoor / Outdoor
SHARPNESS
0 ~ 10 steps
MIRROR
Off / H / V / H&V
FREEZE
Off / On
E.ZOOM
E.ZOOM
HLC
Off / On
ACE
Off / On
DNR
Off / Low / Middle / High / Auto
D.COMPRESS
OFF / ON
PRIVACY
Off / On (32 points)
MOTION
Off / On (4 points)
SHADING DET
Off / On
SHADING
Off / On
DEFECT DET
Off / On
DEFOG
Off / On
SYSTEM
NTSC / PAL
HD FORMAT
1080P / 720P
PG(Pattern Generator)
Off / On
CVBS
Off / On
COMMUNICATION
ID (1 ~ 255)
BAUDRATE ( 2400 / 4800 / 9600 / 19200 / 38400 / 57600/115200 )
PROTOCOL (PELCO-P / PELCO-D / UPDATE)
DIMENSIONS
Unit : mm
140
139
49
DEFAULT
ON / DONE
Language
English
OSD Text
0~9,A~Z,a~z
Power Source
DC12V±10%
Power Consumption
150mA
Power Input
DC JACK
Video Output(HD-SDI)
BNC CONNECTOR
Operating Temperature
-10℃ ~ +50℃ (Humidity : 0%RH ~ 80%RH)
Storage Temperature
-20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH)
FlatP-M12
2.2Mega pixel HD-SDI Plastic Flat dome camera
2.2 Mega Pixel
1080p & 720p
WDR & ACE
DSS & 3D-DNR
SPECIFICATIONS
MODEL
Flat P-M12
Image Sensor
1/3" Panasonic CMOS
Total Pixels
2010(H) x 1108(V) = 2,227,080 (pixel)
Active pixels
1944(H) x 1092(V) = 2,122,848 (pixel)
Scanning system
Progressive
Resolution
Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps)
Analog : 700TVL
FEATURES
• 1/3” 2.2Mega pixel CMOS image sensor that supports both Full HD
of 1080p and HD 720p (Max 1,100TV Lines, OSD selectable)
• Using progressive scan and Auto WDR
• Supports DSS(Digital Slow Shutter) and 3D DNR(Dynamic Noise Reduction)
to enhance the performance in low-light environment
• Minimum illumination of Color 1.0 lux (DSS off)
• Supports not only SDI output, but also analog spot-out
• Supports various white balance mode of Auto, One pushing and Manual
• Supports ACE (Advanced Contrast Enhancement)
• Supports various digital features of Mirror, Flip, Digital Zoom, Privacy
Masking, Motion Detection, Sharpness control and shading
• 3.0mm Mega-pixel Fixed Lens
• Supports Multi-protocol of Pelco D/P
• Superior design concept of Flat dome
Min. illumination
Color : 1.0 lux , BW : 0.5lux, Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video Output
HD-SDI, Analog : NTSC, PAL(without WDR)
S/N Ratio
more than 50dB (AGC off)
BRIGHTNESS
0 ~ 20 steps
LENS
3.0mm fixed lens
SHUTTER SPEED
Auto / Manual ( 1/30(1/25) ~ 1/60000 )
DSS
Off / x2 / x3 / x4
AGC
Off / On
WDR/BLC
Off / WDR / BLC
DAY&NIGHT
Auto / Day / Night / Ext
WHITE BALANCE
Auto / Preset / Manual / Indoor / Outdoor
SHARPNESS
0 ~ 10 steps
MIRROR
Off / H / V / H&V
FREEZE
Off / On
E.ZOOM
E.ZOOM
HLC
Off / On
ACE
Off / On
DNR
Off / Low / Middle / High / Auto
D.COMPRESS
OFF / ON
PRIVACY
Off / On (32 points)
MOTION
Off / On (4 points)
SHADING DET
Off / On
SHADING
Off / On
DEFECT DET
Off / On
DEFOG
Off / On
SYSTEM
NTSC / PAL
HD FORMAT
1080P / 720P
PG(Pattern Generator)
Off / On
CVBS
Off / On
COMMUNICATION
ID (1 ~ 255)
BAUDRATE ( 2400 / 4800 / 9600 / 19200 / 38400 / 57600/115200 )
PROTOCOL (PELCO-P / PELCO-D / UPDATE)
DIMENSIONS
Unit : mm
119
119
44
DEFAULT
ON / DONE
Language
English
OSD Text
0~9,A~Z,a~z
Power Source
DC12V±10%
Power Consumption
150mA
Power Input
DC JACK
Video Output(HD-SDI)
BNC CONNECTOR
Operating Temperature
-10℃ ~ +50℃ (Humidity : 0%RH ~ 80%RH)
Storage Temperature
-20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH)
MP-12R
2.2Mega pixel HD-SDI Plastic dome Smart IR camera
2.2 Mega Pixel
1080p & 720p
WDR & ACE
Smart IR
SPECIFICATIONS
MODEL
MP-12R
Image Sensor
1/3" Panasonic CMOS
Total Pixels
2010(H) x 1108(V) = 2,227,080 (pixel)
Active pixels
1944(H) x 1092(V) = 2,122,848 (pixel)
Scanning system
Progressive
Resolution
Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps)
Analog : 700TVL
FEATURES
• 1/3” 2.2Mega pixel CMOS image sensor that supports both Full HD of 1080p
and HD 720p (Max 1,100TV Lines, OSD selectable)
• Using progressive scan and Auto WDR
• Supports DSS(Digital Slow Shutter) and 3D DNR(Dynamic Noise Reduction)
to enhance the performance in low-light environment
• IR LED 27pcs, IR LED Range 10~12m(32~40ft)
• Supports not only SDI output, but also analog spot-out
• Supports various white balance mode of Auto, One pushing and Manual
• Supports ACE (Advanced Contrast Enhancement)
• Supports various digital features of Mirror, Flip, Digital Zoom, Privacy Masking,
Motion Detection, Sharpness control and shading
• 2.8~10mm Mega-pixel Varifocal Lens
• Supports Multi-protocol of Pelco-D/P
• Supports Smart IR Function
• Plastic indoor dome housing
Min. illumination
Color : 1.0 lux , BW : 0.5lux, Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video Output
HD-SDI, Analog : NTSC, PAL(without WDR)
S/N Ratio
more than 50dB (AGC off)
BRIGHTNESS
0 ~ 20 steps
LENS
2.8~10mm
SHUTTER SPEED
Auto / Manual ( 1/30(1/25) ~ 1/60000 )
DSS
Off / x2 / x3 / x4
AGC
Off / On
WDR/BLC
Off / WDR / BLC
DAY&NIGHT
Auto / Day / Night / Ext
SMART IR
Off / On
WHITE BALANCE
Auto / Preset / Manual / Indoor / Outdoor
SHARPNESS
0 ~ 10 steps
MIRROR
Off / H / V / H&V
FREEZE
Off / On
E.ZOOM
x1 ~ x32
HLC
Off / On
ACE
Off / On
DNR
Off / Low / Middle / High / Auto
D.COMPRESS
OFF / ON
PRIVACY
Off / On (32 points)
MOTION
Off / On (4 points)
SHADING DET
Off / On
SHADING
Off / On
DEFECT DET
Off / On
DEFOG
Off / On
SYSTEM
NTSC / PAL
HD FORMAT
1080P / 720P
PG(Pattern Generator)
Off / On
CVBS
Off / On
COMMUNICATION
ID (1 ~ 255)
BAUDRATE ( 2400 / 4800 / 9600 / 19200 / 38400 / 57600/115200 )
PROTOCOL (PELCO-P / PELCO-D / UPDATE)
DIMENSIONS
44.5
46
97.5
53
Unit : mm
83.5
DEFAULT
ON / DONE
Language
English
OSD Text
0~9,A~Z,a~z
Power Source
DC12V±10%
Power Consumption
250mA
Power Input
DC JACK
Video Output(HD-SDI)
BNC Connector
Operating Temperature
-10℃ ~ +50℃ (Humidity : 0%RH ~ 80%RH)
Storage Temperature
-20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH)
2.2 Mega Pixel
1080p & 720p
WDR & ACE
DSS & 3D-DNR
MP-12
2.2Mega pixel HD-SDI Plastic dome camera
SPECIFICATIONS
MODEL
MP-12
Image Sensor
1/3" Panasonic CMOS
Total Pixels
2010(H) x 1108(V) = 2,227,080 (pixel)
Active pixels
1944(H) x 1092(V) = 2,122,848 (pixel)
Scanning system
Progressive
Resolution
Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps)
Analog : 700TVL
FEATURES
• 1/3” 2.2Mega pixel CMOS image sensor that supports both Full HD of 1080p
and HD 720p (Max 1,100TV Lines, OSD selectable)
• Using progressive scan and Auto WDR
• Supports DSS(Digital Slow Shutter) and 3D DNR(Dynamic Noise Reduction)
to enhance the performance in low-light environment
• Minimum illumination of Color 1.0 lux (DSS off)
• Supports not only SDI output, but also analog spot-out
• Supports various white balance mode of Auto, One pushing and Manual
• Supports ACE (Advanced Contrast Enhancement)
• Supports various digital features of Mirror, Flip, Digital Zoom, Privacy Masking,
Motion Detection, Sharpness control and shading
• 2.8~10mm Mega-pixel Varifocal Lens
• Supports Multi-protocol of Pelco-D/P
• Plastic indoor dome housing
Min. illumination
Color : 1.0 lux , BW : 0.5lux, Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video Output
HD-SDI, Analog : NTSC, PAL(without WDR)
S/N Ratio
more than 50dB (AGC off)
BRIGHTNESS
0 ~ 20 steps
LENS
2.8~10mm
SHUTTER SPEED
Auto / Manual ( 1/30(1/25) ~ 1/60000 )
DSS
Off / x2 / x3 / x4
AGC
Off / On
WDR/BLC
Off / WDR / BLC
DAY&NIGHT
Auto / Day / Night / Ext
SMART IR
Off / On
WHITE BALANCE
Auto / Preset / Manual / Indoor / Outdoor
SHARPNESS
0 ~ 10 steps
MIRROR
Off / H / V / H&V
FREEZE
Off / On
E.ZOOM
x1 ~ x32
HLC
Off / On
ACE
Off / On
DNR
Off / Low / Middle / High / Auto
D.COMPRESS
OFF / ON
PRIVACY
Off / On (32 points)
MOTION
Off / On (4 points)
SHADING DET
Off / On
SHADING
Off / On
DEFECT DET
Off / On
DEFOG
Off / On
SYSTEM
NTSC / PAL
HD FORMAT
1080P / 720P
PG(Pattern Generator)
Off / On
CVBS
Off / On
COMMUNICATION
ID (1 ~ 255)
BAUDRATE ( 2400 / 4800 / 9600 / 19200 / 38400 / 57600/115200 )
PROTOCOL (PELCO-P / PELCO-D / UPDATE)
DIMENSIONS
44.5
46
97.5
53
Unit : mm
83.5
DEFAULT
ON / DONE
Language
English
OSD Text
0~9,A~Z,a~z
Power Source
DC12V±10%
Power Consumption
250mA
Power Input
DC JACK
Video Output(HD-SDI)
BNC Connector
Operating Temperature
-10℃ ~ +50℃ (Humidity : 0%RH ~ 80%RH)
Storage Temperature
-20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH)
2.2 Mega Pixel
1080p & 720p
WDR & ACE
MP-032
2.2Mega pixel HD-SDI Zoom camera
SPECIFICATIONS
MODEL
MP-032
Image Sensor
1/2.9” Sony "Exmor" CMOS
Effective Number of pixels
Approx. 2 Mega Pixels
Aspect Ratio
16 : 9
Lens
3x Optical Zoom
f=3.0mm(wide) ~ 9.0mm(tele)
F1.2 to F2.1
Digital Zoom
Max 32x
Resolution
1080P/30, 720P/60
Min. illumination
Color : 0.5 lux , BW : 0.1 lux
Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video Output
more than 50dB (AGC off)
Camera Control Comm
Baud Rate : 2400 / 4800 / 9600 / 19200 / 38400 / 57600 / 115200
Protocol : VISCA / Pelco-D / Pelco- P / Update
Focusing Mode
Auto / One Push / Manual
Shutter Speed
1/30(25) ~ 1/60,000 sec
WDR/BLC
OFF / WDR / BLC
White Balance
AUTO / One Push / Manual / Indoor / Outdoor
Power Source
9V to 15V DC
Power Consumption
500mA
Storage Temperature
-20℃ ~ +60℃ (Humidity : 20%RH ~ 95%RH)
Operating Temperature
-5℃ ~ +60℃ (Humidity : 20%RH ~ 80%RH)
OPTIONAL MOUNT BRACKET(PLASTIC)
WM-120 + MP-032
CB-120 + MP-032
WB-120 + MP-032
DIMENSIONS
46
53
Unit : mm
38.7
• 1/2.9" Sony “Exmor” CMOS sensor
All-Pixel Scan: 1920(H) X 1200(V) app. 2.3 Mega Pixel
• x3 Optical Zoom Auto Focus(3mm ~9mm)
• Full HD Resolution
1920x1080p / 30fps
1280x720p / 60fps
• Day & Night (ICR)
The ICR will automatically engage depending on the ambient light,
allowing the camera to be effective in day & night environment.
• WDR (Wide Dynamic Range)
WDR, more effectively than previous models,
by applying an optimum fusion ratio when combining the high speed
shutter used in bright areas and the low speed shutter used in dark areas.
• DNR (Digital Noise Reduction, 2D+3D)
The DNR technology eliminates noise thus generating a distinct and clear
image. This camera DNR function utilizes both an adaptive 2D filter
reducing noise in the brightness of the image and an adaptive 3D filter
reducing noise caused by movement.
• Privacy mask Function
The privacy zone function makes it possible to make specific areas of the
scene from view.
• Intelligent motion detection
You can transmits an alert signal when it detects motion of an object on
the screen. This feature is useful when you have to monitor several screens
simultaneously.
• Defog
Defogging foggy video image.
• HLC(High Light Compensation Function)
Analog: CVBS (up to 700TVL)
S/N Ratio
44.5
FEATURES
Digital: HD-SDI (1080p)
83.5
MV-12R
2.2Mega pixel HD-SDI Vandal-dome Smart IR camera
2.2 Mega Pixel
1080p & 720p
WDR & ACE
Smart IR
SPECIFICATIONS
MODEL
MV-12R
Image Sensor
1/3" Panasonic CMOS
Total Pixels
2010(H) x 1108(V) = 2,227,080 (pixel)
Active pixels
1944(H) x 1092(V) = 2,122,848 (pixel)
Scanning system
Progressive
Resolution
Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps)
Analog : 700TVL
FEATURES
• 1/3” 2.2Mega pixel CMOS image sensor that supports both Full HD of 1080p
and HD 720p (Max 1,100TV Lines, OSD selectable)
• Using progressive scan and Auto WDR
• Supports DSS(Digital Slow Shutter) and 3D DNR(Dynamic Noise Reduction)
to enhance the performance in low-light environment
• IR LED 27pcs, IR LED Range 10~12m(32~40ft)
• Supports not only SDI output, but also analog spot-out
• Supports various white balance mode of Auto, One pushing and Manual
• Supports ACE (Advanced Contrast Enhancement)
• Supports various digital features of Mirror, Flip, Digital Zoom, Privacy Masking,
Motion Detection, Sharpness control and shading
• 2.8~10mm Mega-pixel Varifocal Lens
• Supports Multi-protocol of Pelco-D/P
• Supports Smart IR Function
• IP67 Aluminum Die-casting Housing
Min. illumination
Color : 1.0 lux , BW : 0.5lux, Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video Output
HD-SDI, Analog : NTSC, PAL(without WDR)
S/N Ratio
more than 50dB (AGC off)
BRIGHTNESS
0 ~ 20 steps
LENS
2.8~10mm
SHUTTER SPEED
Auto / Manual ( 1/30(1/25) ~ 1/60000 )
DSS
Off / x2 / x3 / x4
AGC
Off / On
WDR/BLC
Off / WDR / BLC
DAY&NIGHT
Auto / Day / Night / Ext
SMART IR
Off / On
WHITE BALANCE
Auto / Preset / Manual / Indoor / Outdoor
SHARPNESS
0 ~ 10 steps
MIRROR
Off / H / V / H&V
FREEZE
Off / On
E.ZOOM
x1 ~ x32
HLC
Off / On
ACE
Off / On
DNR
Off / Low / Middle / High / Auto
D.COMPRESS
OFF / ON
PRIVACY
Off / On (32 points)
MOTION
Off / On (4 points)
SHADING DET
Off / On
SHADING
Off / On
DEFECT DET
Off / On
DEFOG
Off / On
SYSTEM
NTSC / PAL
HD FORMAT
1080P / 720P
PG(Pattern Generator)
Off / On
CVBS
Off / On
COMMUNICATION
ID (1 ~ 255)
BAUDRATE ( 2400 / 4800 / 9600 / 19200 / 38400 / 57600/115200 )
PROTOCOL (PELCO-P / PELCO-D / UPDATE)
DIMENSIONS
Unit : mm
DEFAULT
ON / DONE
Language
English
OSD Text
0~9,A~Z,a~z
Power Source
DC12V±10%
Power Consumption
250mA
Power Input
DC JACK
Video Output(HD-SDI)
BNC Connector
Operating Temperature -10℃ ~ +50℃ (Humidity : 0%RH ~ 80%RH)
126.0
75.0
35.0
41.0
Storage Temperature
75.0
-20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH)
MV-12
2.2Mega pixel HD-SDI Vandal-dome camera
2.2 Mega Pixel
1080p & 720p
WDR & ACE
DSS & 3D-DNR
SPECIFICATIONS
MODEL
MV-12
Image Sensor
1/3" Panasonic CMOS
Total Pixels
2010(H) x 1108(V) = 2,227,080 (pixel)
Active pixels
1944(H) x 1092(V) = 2,122,848 (pixel)
Scanning system
Progressive
Resolution
Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps)
Analog : 700TVL
FEATURES
• 1/3” 2.2Mega pixel CMOS image sensor that supports both Full HD of 1080p
and HD 720p (Max 1,100TV Lines, OSD selectable)
• Using progressive scan and Auto WDR
• Supports DSS(Digital Slow Shutter) and 3D DNR(Dynamic Noise Reduction)
to enhance the performance in low-light environment
• Minimum illumination of Color 1.0 lux (DSS off)
• Supports not only SDI output, but also analog spot-out
• Supports various white balance mode of Auto, One pushing and Manual
• Supports ACE (Advanced Contrast Enhancement)
• Supports various digital features of Mirror, Flip, Digital Zoom, Privacy Masking,
Motion Detection, Sharpness control and shading
• 2.8~10mm Mega-pixel Varifocal Lens
• Supports Multi-protocol of Pelco-D/P
• IP67 Aluminum Die-casting Housing
Min. illumination
Color : 1.0 lux , BW : 0.5lux, Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video Output
HD-SDI, Analog : NTSC, PAL(without WDR)
S/N Ratio
more than 50dB (AGC off)
BRIGHTNESS
0 ~ 20 steps
LENS
2.8~10mm
SHUTTER SPEED
Auto / Manual ( 1/30(1/25) ~ 1/60000 )
DSS
Off / x2 / x3 / x4
AGC
Off / On
WDR/BLC
Off / WDR / BLC
DAY&NIGHT
Auto / Day / Night / Ext
SMART IR
Off / On
WHITE BALANCE
Auto / Preset / Manual / Indoor / Outdoor
SHARPNESS
0 ~ 10 steps
MIRROR
Off / H / V / H&V
FREEZE
Off / On
E.ZOOM
x1 ~ x32
HLC
Off / On
ACE
Off / On
DNR
Off / Low / Middle / High / Auto
D.COMPRESS
OFF / ON
PRIVACY
Off / On (32 points)
MOTION
Off / On (4 points)
SHADING DET
Off / On
SHADING
Off / On
DEFECT DET
Off / On
DEFOG
Off / On
SYSTEM
NTSC / PAL
HD FORMAT
1080P / 720P
PG(Pattern Generator)
Off / On
CVBS
Off / On
COMMUNICATION
ID (1 ~ 255)
BAUDRATE ( 2400 / 4800 / 9600 / 19200 / 38400 / 57600/115200 )
PROTOCOL (PELCO-P / PELCO-D / UPDATE)
DIMENSIONS
Unit : mm
DEFAULT
ON / DONE
Language
English
OSD Text
0~9,A~Z,a~z
Power Source
DC12V±10%
Power Consumption
250mA
Power Input
DC JACK
Video Output(HD-SDI)
BNC Connector
Operating Temperature -10℃ ~ +50℃ (Humidity : 0%RH ~ 80%RH)
126.0
75.0
35.0
41.0
Storage Temperature
75.0
-20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH)
MV-032
2.2Mega pixel HD-SDI Zoom camera
2.2 Mega Pixel
1080p & 720p
WDR & ACE
SPECIFICATIONS
MODEL
Image Sensor
MV-032
1/2.9” Sony "Exmor" CMOS
Effective Number of pixels Approx. 2 Mega Pixels
Aspect Ratio
16 : 9
Lens
3x Optical Zoom
f=3.0mm(wide) ~ 9.0mm(tele)
F1.2 to F2.1
Digital Zoom
Max 32x
Resolution
1080P/30, 720P/60
Min. illumination
Color : 0.5 lux , BW : 0.1 lux
Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video Output
more than 50dB (AGC off)
Camera Control Comm Baud Rate : 2400 / 4800 / 9600 / 19200 / 38400 / 57600 / 115200
Protocol : VISCA / Pelco-D / Pelco- P / Update
Focusing Mode
Auto / One Push / Manual
Shutter Speed
1/30(25) ~ 1/60,000 sec
WDR/BLC
OFF / WDR / BLC
White Balance
AUTO / One Push / Manual / Indoor / Outdoor
Power Source
9V to 15V DC
Power Consumption
500mA
Storage Temperature
-20℃ ~ +60℃ (Humidity : 20%RH ~ 95%RH)
Operating Temperature
-5℃ ~ +60℃ (Humidity : 20%RH ~ 80%RH)
DIMENSIONS
Unit : mm
4-
83.5
80.0
50.0
.4
Ø4
4-
Ø140.0
.2
R2
Ø100.0
117.9
• 1/2.9" Sony “Exmor” CMOS sensor
All-Pixel Scan: 1920(H) X 1200(V) app. 2.3 Mega Pixel
• x3 Optical Zoom Auto Focus(3mm ~9mm)
• Full HD Resolution
1920x1080p / 30fps
1280x720p / 60fps
• Day & Night (ICR)
The ICR will automatically engage depending on the ambient light,
allowing the camera to be effective in day & night environment.
• WDR (Wide Dynamic Range)
WDR, more effectively than previous models,
by applying an optimum fusion ratio when combining the high speed
shutter used in bright areas and the low speed shutter used in dark areas.
• DNR (Digital Noise Reduction, 2D+3D)
The DNR technology eliminates noise thus generating a distinct and clear
image. This camera DNR function utilizes both an adaptive 2D filter
reducing noise in the brightness of the image and an adaptive 3D filter
reducing noise caused by movement.
• Privacy mask Function
The privacy zone function makes it possible to make specific areas of the
scene from view.
• Intelligent motion detection
You can transmits an alert signal when it detects motion of an object on
the screen. This feature is useful when you have to monitor several screens
simultaneously.
• Defog
Defogging foggy video image.
• HLC(High Light Compensation Function)
Analog: CVBS (up to 700TVL)
S/N Ratio
67.9
FEATURES
Digital: HD-SDI (1080p)
46.0
80.0
OPTIONAL MOUNT BRACKET
DSB-304
CPA-304(300mm)
- Aluminum body
- Unit : 1.0kg
- Color : Cool gray / Black
- Aluminum & Steel body
- Unit : 1.6kg
- Color :Cool gray
IRV-M12-36
2.2Mega pixel HD-SDI Varifocal IR Bullet camera
2.2 Mega Pixel
1080p & 720p
WDR & ACE
External Adjustment
SPECIFICATIONS
MODEL
IRV-M12-36
Image Sensor
1/3" Panasonic CMOS
Total Pixels
2010(H) x 1108(V) = 2,227,080 (pixel)
Active pixels
1944(H) x 1092(V) = 2,122,848 (pixel)
Scanning system
Progressive
Resolution
Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps)
Analog : 700TVL
FEATURES
• 2.2M 1080p Full HD with Panasonic CMOS
• HD-SDI (SMPTE 292M)
• Composite Video output (700TV Lines)
• Supports WDR & ACE (Advanced Contrast Enhancement)
• Viewable length at night 30m (36pcs IR LED)
• Support DNR & DSS
• Support Privacy Mask & HLMask
• Intelligent Motion Detection
• Multi-protocol support through RS-485
• 3~10mm Varifocal Lens
• CDS Auto switching IR LED control
• OSD control with Wireless Remocon
• Externally Adjustable focal length and focus
• Cable managed bracket
• Pipeline adaptor optional
• IP66 Waterproof
• DC12V
Min. illumination
Color : 1.0 lux , BW : 0.5lux, Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video Output
HD-SDI, Analog : NTSC, PAL(without WDR)
S/N Ratio
more than 50dB (AGC off)
BRIGHTNESS
0 ~ 20 steps
LENS
3~10mm Varifocal Lens
SHUTTER SPEED
Auto / Manual ( 1/30(1/25) ~ 1/60000 )
DSS
Off / x2 / x3 / x4
AGC
Off / On
WDR/BLC
Off / WDR / BLC
DAY&NIGHT
Auto / Day / Night / Ext
SMART IR
Off / On
WHITE BALANCE
Auto / Preset / Manual / Indoor / Outdoor
SHARPNESS
0 ~ 10 steps
MIRROR
Off / H / V / H&V
FREEZE
Off / On
E.ZOOM
1~32x
HLC
Off / On
ACE
Off / On
DNR
Off / Low / Middle / High / Auto
D.COMPRESS
OFF / ON
PRIVACY
Off / On (32 points)
MOTION
Off / On (4 points)
SHADING DET
Off / On
SHADING
Off / On
DEFECT DET
Off / On
DEFOG
Off / On
SYSTEM
NTSC / PAL
HD FORMAT
1080P / 720P
PG(Pattern Generator)
Off / On
CVBS
Off / On
COMMUNICATION
ID (1 ~ 255)
BAUDRATE ( 2400 / 4800 / 9600 / 19200 / 38400 / 57600/115200 )
PROTOCOL (PELCO-P / PELCO-D / UPDATE)
DIMENSIONS
Unit : mm
350
191.5
DEFAULT
ON / DONE
Language
English
OSD Text
0~9,A~Z,a~z
Power Source
12V DC±10%
Video Output(HD-SDI)
BNC Connector
Operating Temperature
-10℃ ~ +50℃ (Humidity : 0%RH ~ 80%RH)
Storage Temperature
-20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH)
154
90.8
External adjustment
External adjustment
controller for focal-length
173.0
335.8
ME-12V
Full HD Mega-pixel Eye-ball camera
SPECIFICATIONS
MODEL
ME-12V
Image Sensor
1/3" Panasonic CMOS
Total Pixels
2010(H) x 1108(V) = 2,227,080 (pixel)
Active pixels
1944(H) x 1092(V) = 2,122,848 (pixel)
Scanning system
Progressive
Resolution
Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps)
Analog : 700TVL
FEATURES
• 2.2M 1080p Full HD with Panasonic CMOS
• HD-SDI
• Composite Video output (750TV Lines)
• BT1120 format digital output
• Supports WDR & ACE(Advanced Contrast Enhancement)
• Support DNR
• Support Privacy Mask & Intelligent Motion Detection
• Multi-protocol support through RS-485
• Wider range of SMART IR function
• Built-in 2.8~10mm Mega Pixel Lens
• CDS Auto switching IR LED control
• OSD control with Wireless Remocon
• Externally Adjustable focal length and focus
• IP66 Waterproof
• AC24V/DC12V Dual voltage
DIMENSIONS
Unit : mm
Min. illumination
Color : 1.0 lux , BW : 0.5lux, Color DSS : 0.002 lux , BW DSS : 0.001 lux
Video Output
HD-SDI, Analog : NTSC, PAL(without WDR)
S/N Ratio
more than 50dB (AGC off)
BRIGHTNESS
0 ~ 20 steps
LENS
DC / Manual
SHUTTER SPEED
Auto / Manual ( 1/30(1/25) ~ 1/60000 )
DSS
Off / x2 / x3 / x4
AGC
Off / On
WDR/BLC
Off / WDR / BLC
DAY&NIGHT
Auto / Day / Night / Ext
SMART IR
Off / On
WHITE BALANCE
Auto / Preset / Manual / Indoor / Outdoor
SHARPNESS
0 ~ 10 steps
MIRROR
Off / H / V / H&V
FREEZE
Off / On
E.ZOOM
E.ZOOM
HLC
Off / On
ACE
Off / On
DNR
Off / Low / Middle / High / Auto
D.COMPRESS
OFF / ON
PRIVACY
Off / On (32 points)
MOTION
Off / On (4 points)
SHADING DET
Off / On
SHADING
Off / On
DEFECT DET
Off / On
DEFOG
Off / On
SYSTEM
NTSC / PAL
HD FORMAT
1080P / 720P
PG(Pattern Generator)
Off / On
CVBS
Off / On
COMMUNICATION
ID (1 ~ 255)
BAUDRATE ( 2400 / 4800 / 9600 / 19200 / 38400 / 57600/115200 )
PROTOCOL (PELCO-P / PELCO-D / UPDATE)
DEFAULT
ON / DONE
Language
English
OSD Text
0~9,A~Z,a~z
Power Source
12V DC±10%
Video Output(HD-SDI)
BNC Connector
Operating Temperature -10℃ ~ +50℃ (Humidity : 0%RH ~ 80%RH)
Storage Temperature
①
②
③
-20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH)
③ Functions
① Focal Length Adjustment Lever
· Adjusting by lever, focal length can I be changeable.
② Zoom Adjustment Lever
· Tele : To zoom in, turn the Zoom Adjustment lever clockwise.
· Wide : To zoom out, turn the Zoom Adjustment lever counter
clockwise.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
