Dakal Lighting Product Catalogue 2014

Dakal Lighting Product Catalogue 2014

www.dakal.co.uk

PRODUCT

CATALOGUE

SUPPLIERS OF INDUSTRIAL

& COMMERCIAL LIGHTING

PRODUCTS

www.dakal.co.uk | 01604 750098

ABOUT US

Dakal Ltd specialise in all areas of commercial

& industrial lighting and have over 25 years of experience in the industry. We can supply all types of light fi ttings from Induction Lighting, LED fl oodlights, low energy, bulkheads, high bay’s, low bay’s, modulars, lamps, lighting components and lighting spares. This extensive range enables us to provide a lighting solution for many different requirements.

OUR HISTORY

Dakal

was formed in the late 80’s. It started off as a small Sole Trading company, then became a limited company in 1994. It started out specialising in supplying cable accessories, cable glands and associated cable management products.

The customer base was and continues to be, the electrical wholesale trade. Developing quickly,

Dakal found the need to diversify into supplying lighting accessories – e.g. chokes, starters and ballasts. This led onto supplying complete lighting units and Dakal is now a recognised and popular supplier within the industry.

Following a change of ownership in 2001, we have continued to develop our product range which now includes a diverse choice of industrial and commercial lighting products. The demand for LG7 compliant luminaires has become an important requirement throughout the lighting industry and these continue to feature prominently in our range. We are sensitive to the changing requirements within the industry and are pleased to introduce both LED and Induction technology options which are already proving to be very popular.

Our lighting design service continues to be a valuable asset which many end users, contractors and wholesalers utilise. With the introduction of the CIBSE Lighting Guide LG7, the lighting of offi ce spaces in particular has become more complex.

We are able to produce computer aided plots to reassure the client the specifi cation is being met effectively and provide detailed data sheets to illustrate the equipment being used.

OUR SERVICES

EMERGENCY CONVERSIONS

Dakal Ltd offers a light fi tting conversion service and can convert most standard fl uorescent fi ttings to emergency i n o u r e m e r g e n c y c o n v e r is o n c e n t r e .

W e c a n c o n v e r t integrally or remotely depending on the space that is available.

We can convert :

• T8 Fluorescent

• T5 Fluorescent

• PL ( Compact Fluorescent )

• Switch Start

• High Frequency

• Analogue Dimmable (High Frequency)

• DSI Dimmable (High Frequency)

• DALI Dimmable (High Frequency)

• And many other lamp types

• LED Conversions also available

LIGHTING DESIGN SERVICE

We can offer a complete design service for industrial and commercial installations.

We have a range of luminaires which enable us to meet the specifi cations required. We have recessed surface and suspended luminaires with direct, indirect and combination light outputs and are able to produce computer aided plots to reassure the client the specifi cation is being met. We can also provide detailed data sheets to illustrate the equipment being used which are all available on the website. Whilst we prefer ‘hard copy’ drawings, we can accept PDF and

AutoCAD drawings via e-mail as well.

We aim to turn a scheme around in 3-5 working days depending on the complexity.

REFURBISHMENTS

Give existing fi ttings that are showing signs of ageing a new lease of life by refurbishing the old components for a fraction of the price of buying new!

We can upgrade your existing switch start fi ttings to High

Frequency to help with energy savings and effi ciency.

We can also offer to install integral emergency conversion packs so that the fi ttings come on in the event of mains failure (subject to assessment).

We can Refurb/Convert:

F l o o d il g h t s , N o n C o r r o is v e s , B a t t e n s , L o w E n

Highbays, Lowbays, Modulars and many more...

e r g y F ti it n g s ,

Copyright Dakal Ltd 2014. Subject to change without prior notic. E & OE. Techincal details shown if offered as a guide only.

Visit: www.dakal.co.uk

Call Us:

01604 750098

CONTENTS

ITEM

INDUCTION LIGHTING

LED FLOODLIGHTS

LOW ENERGY

LED

110V LIGHTING

AMENITY LIGHTING

BULKHEADS

DOWNLIGHTS

EMERGENCY LIGHTING

FLOODLIGHTS

PAGE NO

1

5

7

9

11

13

17

21

23

25

ITEM

HIGHBAYS

LAMPS & TUBES

LED EMERGENCY LIGHTING

LOWBAYS

NON CORROSIVES & BATTENS

RECESSED LUMINAIRES

PAGE NO

29

33

35

39

41

47

RETAIL DISPLAY LIGHTING

SURFACE & SUSPENDED LUMINAIRES

TECHNICAL INFORMATION

49

53

55

HAVE YOU HEARD?

We now have a

‘Cost and Energy Saving Calculator’

on our website. Use it now:

www.dakal.co.uk

Use our easy to use calculator to help work out how much you could save by replacing your existing units with our energy saving range.

Visit: www.dakal.co.uk Call Us: 01604 750098

INDUCTION LIGHTING

ITEM DETAILS:

PART NUMBER LAMP TYPE

DIH120W/G3

DIH150W/G3

DIH200W/G3

DIH250W/G3

120w Induction

150w Induction

200w Induction

250w Induction

INDUCTION HIGHBAY G3

PHOTOPIC

LUMENS

9,600

12,000

16,000

20,000

KEY FEATURES:

• Heavy gauge sheet steel gear housing fi nished in white

• Supplied with highly polished anodised spun aluminium

refl ector

• Optimal thermal shock resistant tempered glass in silicon

rubber sealing gasket complete with securing clips

• Eyebolt fi tted for suspension purposes

• Supplied complete with induction lamp and ballast

• 5 year guarantee ( Please request details )

• Dished polycarbonate diffuser is available upon request

add PD to the part number

• Meshed wire guard is available upon request

add WG to the part number

SCOTOPIC

LUMENS

18,000

22,000

30,000

37,000

LENGTH

(mm)

620

620

620

620

DIAMETER

(mm)

490

490

490

490

IP65 INDUCTION

HIGHBAY G4

KEY FEATURES:

• Die cast aluminium ballast housing fi nished in black

• Supplied complete with induction lamp and ballast

• IP65 ( weather proof & dust proof )

• Eyebolt provided for suspension purposes

• 5 year guarantee ( Please request details )

• Dished polycarbonate diffuser is available upon request

add PD to the part number

11

ITEM DETAILS:

PART NUMBER LAMP TYPE

DIHIP135W/G4

DIHIP165W/G4

DIHIP200W/G4

135w Induction

165w Induction

200w Induction

PHOTOPIC

LUMENS

9,600

12,000

16,000

SCOTOPIC

LUMENS

18,000

22,000

30,000

LENGTH

(mm)

614

614

614

DIAMETER

(mm)

490

490

490

Visit: www.dakal.co.uk Call Us: 01604 750098

INDUCTION LIGHTING

DECORATIVE INDUCTION

HIGHBAY G3

KEY FEATURES:

• White steel highbay gear housing

• UV stabilized polycarbonate refractor and conical lens

• Supplied complete with Induction lamp and ballast

• IP44 rating when supplied with refractor and conical lens

• U-Bolt provided for suspension

• 5 year guarantee ( Please request details )

ITEM DETAILS:

PART NUMBER LAMP TYPE

DIDH120W/G3

DIDH150W/G3

DIDH200W/G3

DIDH250W/G3

120w Induction

150w Induction

200w Induction

250w Induction

PHOTOPIC

LUMENS

9,600

12,000

16,000

20,000

INDUCTION LAMP

AMENITY G3

KEY FEATURES:

• Polycarbonate black body

• Stainless steel fasteners

• Textured diffuser for greater eye comfort

• IP65 ( weather proof & dust proof )

• 5 year guarantee ( Please request details )

• Easy Access to control gear compartment

• Supplied complete with Induction lamp and ballast

• Can be fi tted with photocell on request add PC to part

number

ITEM DETAILS:

PART NUMBER LAMP TYPE

DIA40W/G3 40w Induction

PHOTOPIC

LUMENS

2,800

SCOTOPIC

LUMENS

4,600

SCOTOPIC

LUMENS

18,000

22,000

30,000

37,000

HEIGHT

(mm)

273

LENGTH

(mm)

710

710

710

710

WIDTH

(mm)

273

DIAMETER

(mm)

567

567

567

567

DEPTH

(mm)

180

Visit: www.dakal.co.uk Call Us: 01604 750098

2

INDUCTION LIGHTING

INDUCTION LOWBAY G3

ITEM DETAILS:

PART NUMBER LAMP TYPE

DIL80W/G3 80w Induction

DIL120W/G3 120w Induction

DIL150W/G3 150w Induction

DIL200W/G3 200w Induction

DIL250W/G3 250w Induction

PHOTOPIC

LUMENS

6,400

9,600

12,000

16,000

20,000

KEY FEATURES:

• White steel housing

• Refl ector is produced from high grade aluminium

• Typical mounting height from 4-7m

• IP20 Rating

• 20mm conduit entry holes pre drilled

• Supplied complete with induction lamp and ballast

• Can be fi tted with a range of PIR and Microwave sensors

• 5 year guarantee ( Please request details )

• Flat polycarbonate diffuser is available upon request

add PD to the part number

SCOTOPIC

LUMENS

11,648

18,000

22,000

30,000

37,000

LENGTH

(mm)

800

800

800

800

800

WIDTH

(mm)

350

350

350

350

350

DEPTH

(mm)

60

60

60

60

60

INDUCTION

LOWBAY IP65 G3

KEY FEATURES:

• Die cast aluminium housing fi nished in white

• Refl ector is produced from high grade aluminium

• Typical mounting height from 4-7m

• 20mm conduit entry holes are provided

• IP65 ( weather proof & dust proof )

• Supplied complete with induction lamp and ballast

• 5 year guarantee ( Please request details )

3

ITEM DETAILS:

PART NUMBER LAMP TYPE

DILIP120W/G3 120w Induction

DILIP150W/G3 150w Induction

PHOTOPIC

LUMENS

9,600

12,000

SCOTOPIC

LUMENS

18,000

22,000

LENGTH

(mm)

705

705

WIDTH

(mm)

325

325

DEPTH

(mm)

160

160

Visit: www.dakal.co.uk Call Us: 01604 750098

INDUCTION LIGHTING

INDUCTION

FLOODLIGHT G3

KEY FEATURES:

• Die cast aluminium body housing fi nished in black

• 5mm thick tempered glass cover

• Pure high quality symmetrical aluminium refl ector

• Supplied complete with induction lamp and ballast

• IP65 ( weather proof & dust proof )

• 5 year guarantee ( Please request details )

• Photocell is available upon request add PC to the part

number

ITEM DETAILS:

PART NUMBER LAMP TYPE

DIF40W/G3

DIF80W/G3

DIF120W/G3

DIF150W/G3

DIF200W/G3

40w Induction

80w Induction

120w Induction

150w Induction

200w Induction

PHOTOPIC

LUMENS

2,800

6,400

9,600

12,000

16,000

SCOTOPIC

LUMENS

4,600

11,648

18,000

22,000

30,000

HEIGHT

(mm)

220

323

323

323

440

WIDTH

(mm)

290

416

416

416

566

INDUCTION

FLOODLIGHT G4

KEY FEATURES:

• Die cast aluminium body housing fi nished in black

• 5mm thick tempered glass cover

• Stainless steel glass retaining clips

• Pure high quality symmetrical aluminium refl ector

• Supplied complete with induction lamp and ballast

• IP65 ( weather proof & dust proof )

• 5 year guarantee ( Please request details )

• Photocell is available upon request add PC to the part

number

• Dished polycarbonate diffuser is available upon request

add PD to the part number

ITEM DETAILS:

PART NUMBER

DIF135W/G4

DIF165W/G4

DIF200W/G4

LAMP TYPE

135w Induction

165w Induction

200w Induction

PHOTOPIC

LUMENS

9,600

12,000

16,000

SCOTOPIC

LUMENS

18,000

22,000

30,000

HEIGHT

(mm)

455

455

455

WIDTH

(mm)

405

405

405

DEPTH

(mm)

190

270

270

270

410

DEPTH

(mm)

295

295

295

Visit: www.dakal.co.uk Call Us: 01604 750098

4

5

LED FLOODLIGHTS

LED IP65 FLOODLIGHT

ITEM DETAILS:

PART NUMBER WATTAGE LAMP

TYPE

DLED10W/F 10 LED

DLED30W/F

DLED50W/F

30

50

LED

LED

PHOTOPIC

LUMENS

700

2200

4000

KEY FEATURES:

• Aluminium die cast body

• Black fi nish

• 75 ° viewing angle

• IP65 protected

• 50,000 hour lamp life

• 6000k colour temperature

• High colour rendering index

• 2 year guarantee

• Flat polycarbonate diffuser is available upon request

add FPD to the part number

CRI

80

80

80

LENGTH

(mm)

86

185

236

WIDTH

(mm)

114

225

290

DEPTH

(mm)

90

112

183

WEIGHT

(Kg)

0.6

3.0

4.2

80W LED IP65

FLOODLIGHT

KEY FEATURES:

• Aluminium die cast body

• Black fi nish

• 75 ° viewing angle

• IP65 protected

• 50,000 hour lamp life

• 6000k colour temperature

• High colour rendering index

• 2 year guarantee

• Flat polycarbonate diffuser is available upon request

add FPD to the part number

ITEM DETAILS:

PART NUMBER

DLED80W/F

WATTAGE LAMP

TYPE

80 LED

PHOTOPIC

LUMENS

6,200

CRI LENGTH

(mm)

80 360

WIDTH

(mm)

285

DEPTH

(mm)

110

WEIGHT

(Kg)

6

Visit: www.dakal.co.uk Call Us: 01604 750098

LED FLOODLIGHTS

150W LED IP65

FLOODLIGHT

KEY FEATURES:

• Aluminium die cast body

• Black fi nish

• 75 ° viewing angle

• IP65 protected

• 50,000 hour lamp life

• 6000k colour temperature

• High colour rendering index

• 2 year guarantee

• Polycarbonate diffuser is available upon request

add FPD to the part number

ITEM DETAILS:

PART NUMBER

DLED150W/F

WATTAGE LAMP

TYPE

150 LED

PHOTOPIC

LUMENS

11,000

CRI LENGTH

(mm)

80 288

WIDTH

(mm)

562

DEPTH

(mm)

217

WEIGHT

(Kg)

12

LED IP65 FLOODLIGHT

C/W PIR MOTION SENSOR

KEY FEATURES:

• Aluminium die cast body

• Black fi nish

• 75 ° viewing angle

• IP65 protected

• 50,000 hour lamp life

• 6000k colour temperature

• High colour rendering index

• Supplied c/w PIR motion sensor

• 2 year guarantee

• Polycarbonate diffuser is available upon request

add FPD to the part number

ITEM DETAILS:

PART NUMBER WATTAGE

DLED10W/F/PIR

DLED30W/F/PIR

DLED50W/F/PIR

10

30

50

LAMP

TYPE

LED

LED

LED

PHOTOPIC

LUMENS

700

2200

4000

CRI LENGTH

(mm)

80 145

80

80

225

265

WIDTH

(mm)

115

225

288

DEPTH

(mm)

105

129

145

WEIGHT

(Kg)

2.5

3.0

4.0

Visit: www.dakal.co.uk Call Us: 01604 750098

6

LOW ENERGY

EXCEL FLOBAY

PHOTOPIC

LUMENS

14,000

19,400

24,000

KEY FEATURES:

• Housing manufactured from steel and fi nished in white

• Luminaire typically mounted between 3 and 7m

• Fitting can be surface mounted or suspended

• Individual refl ector per lamp increases effi ciency

• 20mm cable entry provided

• Dimmable versions available upon request

• Can be fi tted with a range of PIR and Microwave sensors

• Supplied complete with col 840 lamps

• Emergency version is available upon request add EM

• Flat polycarbonate diffuser is available upon request

add FPD to the part number

• Wire guard is available upon request

add WG to the part number

LENGTH

(mm)

750

750

750

WIDTH

(mm)

330

330

330

DEPTH

(mm)

92

92

92

ITEM DETAILS:

PART NUMBER WATTAGE

XLF440

XLF455

XLF480

4 x 40w PLL

4 x 55w PLL

4 x 80w PLL

7

T5 POWERLUX 5FT

(1500mm)

KEY FEATURES:

• Housing manufactured from steel and fi nished in white

• Luminaire typically mounted between 6 and 16m

• Fitting can be surface mounted or suspended

• High quality Miro 4 (95% refl ectance ) supplied as standard

• Dimmable versions available upon request

• 20mm cable entry provided

• Can be fi tted with a range of PIR and Microwave sensors

• Supplied complete with col 840 lamps

• Emergency version is available upon request add EM

• Flat polycarbonate diffuser is available upon request

add FPD to the part number

• Wire guard is available upon request

add WG to the part number

ITEM DETAILS:

PART NUMBER

PLX449

PLX480

PLX680

WATTAGE

4 x 49w T5

4 x 80w T5

6 x 80w T5

PHOTOPIC

LUMENS

19,600

24,640

36,960

LENGTH

(mm)

1524

1524

1524

WIDTH

(mm)

509

509

509

Visit: www.dakal.co.uk Call Us: 01604 750098

DEPTH

(mm)

98

98

98

LOW ENERGY

ITEM DETAILS:

PART NUMBER WATTAGE

PLX454

PLX654

4 x 54w T5

6 x 54w T5

PHOTOPIC

LUMENS

19,400

29,100

T5 POWERLUX 4FT

(1200mm)

KEY FEATURES:

• Housing manufactured from steel and fi nished in white

• Luminaire typically mounted between 6 and 16m

• Fitting can be surface mounted or suspended

• High quality Miro 4 (95% refl ectance ) supplied as standard

• 20mm cable entry provided

• Dimmable versions available upon request

• Can be fi tted with a range of PIR and Microwave sensors

• Supplied complete with col 840 lamps

• Emergency version is available upon request add EM

• Flat polycarbonate diffuser is available upon request

add FPD to the part number

• Wire guard is available upon request

add WG to the part number

LENGTH

(mm)

1224

1224

WIDTH

(mm)

509

509

DEPTH

(mm)

98

98

T5 IP65 WEATHERPROOF

POWERLUX (1200mm)

KEY FEATURES:

• Polycarbonate body & diffuser

• IP65 ( weather proof & dust proof )

• Can be surface mounted or suspended by chain

• Cable entry and conduit entry points provided

• High frequency control gear supplied as standard

• Stainless steel clips as standard

• Supplied complete with col 840 lamps

• Dimmable versions available upon request

• Can be fi tted with a range of PIR and Microwave sensors

• Emergency versions available add EM to the part number

ITEM DETAILS:

PART NUMBER

PLX454/IP

PLX654/IP

WATTAGE

4 x 54w T5

6 x 54w T5

PHOTOPIC

LUMENS

19,400

29,100

LENGTH

(mm)

1200

1200

WIDTH

(mm)

600

600

Visit: www.dakal.co.uk Call Us: 01604 750098

DEPTH

(mm)

115

115

8

LED

LED RECESSED

PANEL LIGHT

KEY FEATURES:

• Fits into standard size ceiling grids both 15mm and 24mm

• IP44 Rating

• Complies with Part L1 & L2 of building regulations

• 50,000 hour average lamp life

• -40 ° C - 55 ° C

• No humming

• Dimmable versions available upon request

• 3 year guarantee

• Surface mounting frame can be supplied at an additional cost

• Emergency versions available add EM to part number

ITEM DETAILS:

PART NUMBER

DLED/P/42/600

DLED/P/45/1232

DLED/P/72/1260

LAMP TYPE

LED

LED

LED

PHOTOPIC

LUMENS

3300

3150

5500

WATTAGE

42w

45w

72w

LENGTH

(mm)

595

1200

1200

WIDTH

(mm)

595

300

600

DEPTH

(mm)

12

15

15

T8 LED TUBES

9

KEY FEATURES:

• Instant on/off switching

• Mercury and lead free

• No UV

• Resistant to shock and vibration

• Specially designed heat sink

• T8 Rotating end caps

• IP20

• CRI Ra >=80

• 6000k colour temperature

• -30 °C to + 50 °C operating temperature

• 3 year guarantee

ITEM DETAILS:

PART NUMBER LAMP TYPE

DF/T8/2/LED/12W

DF/T8/4/LED/22W

DF/T8/5/LED/24W

DF/T8/6/LED/32W

LED

LED

LED

LED

PHOTOPIC

LUMENS

1100

1980

2200

2800

WATTAGE

12w

22w

24w

32w

LENGTH

(mm)

603

1214

1514

1814

Visit: www.dakal.co.uk Call Us: 01604 750098

Diameter

(mm)

26

26

26

26

LED

LED FLOBAY

KEY FEATURES:

• Housing manufactured from steel and fi nished in white

• Luminaire typically mounted between 3 and 7m

• Fitting can be surface mounted or suspended

• Fitted with branded driver and LED chips

• High quality Miro 4 (95% refl ectance ) supplied as standard

• Dali dimmable versions available upon request

• Can be fi tted with a range of PIR and Microwave sensors

• 5 year guarantee

• Emergency version is available upon request add EM

to part number

• Flat polycarbonate diffuser is available upon request

add FPD to the part number

ITEM DETAILS:

PART NUMBER WATTAGE LAMP TYPE

XLF433/LED

XLF633/LED

4 x 33w

6 x 33w

LED

LED

PHOTOPIC

LUMENS

16,680

25,020

CRI

70

70

LENGTH

(mm)

750

750

WIDTH

(mm)

330

330

DEPTH

(mm)

92

92

LED DOWNLIGHT

KEY FEATURES:

• White Bezel

• Opal Diffuser

• 120 ° beam angle

• 35,000 hour lamp life

• 6000k colour temperature

• Epistar chip

• High colour rendering index

• IP44 rating

• Seperate driver provided

• 3 year guarantee

• Emergency version is available upon request add EM

to part number

ITEM DETAILS:

PART NUMBER WATTAGE LAMP TYPE

DLED10W

DLED15W

DLED20W

10w

15w

20w

LED

LED

LED

PHOTOPIC

LUMENS

820

1245

1640

DIAMETER

(mm)

112

150

194

CUTOUT

(mm)

100

130

173

DEPTH

(mm)

55

62

66

Visit: www.dakal.co.uk Call Us: 01604 750098

10

110

V

LIGHTING

ITEM DETAILS:

PART NUMBER

NCC22/HF/110/Y

NCC5/HF/110/Y

NCC25/HF/110/Y

WATTAGE

2 x 18w T8

1 x 58w T8

2 x 58w T8

110

V

IP65 EMERGENCY

BULKHEAD

KEY FEATURES:

• Durable yellow body

• Clear polycarbonate diffuser

• IP65 protected ( weatheproof & dust proof )

• 110v supply

• 3 hour maintained emergency

• Cable entries on both ends and rear of fi tting

• Supplied complete with lamp

LENGTH

(mm)

660

1560

1560

110

V

IP65

NON CORROSIVE

KEY FEATURES:

• Durable yellow body

• Clear polycarbonate diffuser

• Fixing kit supplied to enable ceiling or suspension mounting

• IP65 protected ( weather proof & dust Proof )

• 110v supply

• High frequency control gear

• Supplied less lamp

• Emergency versions available upon request add EM to part

number

• Flex & Plugs can be added at extra cost P.O.A

WIDTH

(mm)

135

90

135

DEPTH

(mm)

100

100

100

11

ITEM DETAILS:

PART NUMBER

DB8/110V/Y

WATTAGE

8w T5

EMERGENCY

TYPE

Maintained

LENGTH

(mm)

355

WIDTH

(MM)

95

DEPTH

(MM)

77

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

110

V

LIGHTING

110

V

IP65 FLOODLIGHTS

KEY FEATURES:

• Die cast aluminium yellow body

• Clear glass lense

• IP65 ( weather proof & dust proof )

• 110v supply

• Supplied complete with lamp

ITEM DETAILS:

PART NUMBER

DF/110/70/Y

DF/110/150/Y

DF/110/400/Y

WATTAGE

70w HQI R7

S

150w HQI R7

S

400w HQI T

LENGTH

(mm)

267

267

410

WIDTH

(mm)

370

370

450

DEPTH

(mm)

130

130

141

110

V

IP65

LED FLOODLIGHTS

KEY FEATURES:

• Aluminium die cast body

• Black fi nish

• 75 ° viewing angle

• IP65 protected

• 50,000 hour lamp life

• 6000k colour temperature

• High colour rendering index

• 2 year guarantee

• Suplied with 300mm of yellow 1mm 3 core artic cable

• Polycarbonate diffuser is available upon request

add FPD to the part number

ITEM DETAILS:

PART NUMBER

DLED10W/F/110v

DLED30W/F/110v

DLED50W/F/110v

WATT-

AGE

10w

30w

50w

LAMP

TYPE

LED

LED

LED

LUMENS

700

2200

4000

CRI LENGTH

(mm)

80 86

80

80

185

236

WIDTH

(mm)

114

225

290

DEPTH

(mm)

90

126

183

WEIGHT

(Kg)

0.6

2.3

4.2

Visit: www.dakal.co.uk Call Us: 01604 750098

12

AMENITY LIGHTING

LED IP65 DECORATIVE

OUTDOOR BULKHEAD

KEY FEATURES:

• Base formed from die cast aluminium

• Bezel formed from die cast aluminium

• 5000k LED Gear Tray

• 50,000 hour lamp life

• IP65 ( weather proof & dust proof )

• Black powder coated fi nish

• Polycarbonate opal diffuser

• 3 year guarantee

• Emergency versions available add EM to part number

• Photocell versions available add PC to part number

ITEM DETAILS:

PART NUMBER LAMP TYPE

DBDC16/O 16w LED

WATTAGE

16w

PHOTOPIC

LUMENS

1050

DIAMETER

(mm)

351

DEPTH

(mm)

128

LED IP65 DECORATIVE

OUTDOOR BULKHEAD

EYELID

KEY FEATURES:

• Base formed from die cast aluminium

• Bezel formed from die cast aluminium

• 5000k LED Gear Tray

• 50,000 hour lamp life

• IP65 ( weather proof & dust proof )

• Black powder coated fi nish

• Polycarbonate opal diffuser

• 3 year guarantee

• Emergency versions available add EM to part number

• Photocell versions available add PC to part number

ITEM DETAILS:

PART NUMBER LAMP TYPE WATTAGE

DEBDC16/O LED 16w

PHOTOPIC

LUMENS

1050

DIAMETER

(mm)

351

DEPTH

(mm)

142

13

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

AMENITY LIGHTING

LED IP65 AMENITY LIGHT

KEY FEATURES:

• LED 30W

• Integral driver

• IP65 ( weather proof & dust proof )

• Polycarbonate base & Eyelid

• 35,000 hour LED life

• 92 lumens per watt

• 6000k colour temperature

• 3 year guarantee

• Photocell versions available add PC to part number

ITEM DETAILS:

PART NUMBER LAMP TYPE

DA30W/LED LED

WATTAGE

30w

PHOTOPIC

LUMENS

3227

HEIGHT

(mm)

308

WIDTH

(mm)

264

DEPTH

(mm)

182

AMENITY

LIGHT

KEY FEATURES:

• Compact HID & PL wall pack for external area applications

• Polycarbonate base & Eyelid

• IP65 ( weather proof & dust proof )

• Hinged front cover for easy installation & lamp replacement

• Supplied complete with lamp

• Photocell versions available add PC to part number

ITEM DETAILS:

PART NUMBER

DA70S/C

DA70M/C

DA226/PL/C

DA142/PL/T

LAMP TYPE

70w SON-I

70w HQI-E

2 x 26w PLC

1 x 42w PLT

PHOTOPIC

LUMENS

5900

4500

3600

3200

HEIGHT

(mm)

308

308

308

308

WIDTH

(mm)

264

264

264

264

Visit: www.dakal.co.uk Call Us: 01604 750098

DEPTH

(mm)

182

182

182

182

14

AMENITY LIGHTING

IP65 DECORATIVE

OUTDOOR BULKHEAD

KEY FEATURES:

• Base formed from die cast aluminium

• Bezel formed from die cast aluminium

• High frequency gear as standard

• IP65 Protected ( Weatherproof & Dustproof )

• Black powder coated fi nish

• Polycarbonate opal diffuser

• Supplied complete with col 840 lamp

• Emergency versions available add EM to part number

• Photocell versions available add PC to part number

ITEM DETAILS:

PART NUMBER WATTAGE

DBDC28/O

DBDC38/O

DBDC218/O

DBDC226/O

28w

38w

2 x 18w

2 x 26w

LAMP TYPE

2D

2D

PL-C

PL-C

PHOTOPIC

LUMENS

2050

2850

2400

3600

DIAMETER

(mm)

351

351

351

351

DEPTH

(mm)

128

128

128

128

15

IP65 DECORATIVE

OUTDOOR BULKHEAD

EYELID

KEY FEATURES:

• Base formed from die cast aluminium

• Eyelid formed from die cast aluminium

• High frequency gear as standard

• IP65 Protected ( Weatherproof & Dustproof )

• Black powder coated fi nish

• Polycarbonate opal diffuser

• Supplied complete with col 840 lamp

• Emergency versions available add EM to part number

• Photocell versions available add PC to part number

ITEM DETAILS:

PART NUMBER WATTAGE LAMP TYPE

DEBDC28/O

DEBDC38/O

DEBDC218/O

DEBDC226/O

28w

38w

2 x 18w

2 x 26w

2D

2D

PL-C

PL-C

PHOTOPIC

LUMENS

2050

2850

2400

3600

DIAMETER

(mm)

351

351

351

351

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

DEPTH

(mm)

128

128

128

128

AMENITY LIGHTING

ITEM DETAILS:

PART NUMBER WATTAGE

DBPC28/O

DBPC218/O

DBPC226/O

28w

2 x 18w

2 x 26w

POLYCARBONATE

BULKHEAD

KEY FEATURES:

• Round Polycarbonate Base

• Round Polycarbonate eyelid cover

• Steel gear tray

• IP54 rating

• Supplied with High Frequency Control Gear as standard

• Available with opal or prismatic diffuser

• Supplied complete with col 840 lamp

• Emergency versions available add EM to part number

• Photocell versions available add PC to part number

• Microwave sensor available add MWS to part number

LAMP TYPE

2D

PL-C

PL-C

PHOTOPIC

LUMENS

2050

2400

3600

DIAMETER

(mm)

332

332

332

DEPTH

(mm)

111

111

111

INDUSTRIAL BOLLARD

KEY FEATURES:

• Powder coated black alumnium body

• Polycarbonate diffuser

• IP65 ( weather proof & dust proof )

• Louvred

• Supplied complete with lamp

• Photocell versions available add PC to part number

• Root mount kit available add RM to part number

ITEM DETAILS:

PART NUMBER

CBD1100/70M

CBD1100/70S

CBD1100/26W

CBD1100/32W

WATTAGE

70w

70w

1 x 26w

1 x 32w

LAMP TYPE

HQI

SON

PL-C

PL-T

PHOTOPIC

LUMENS

4500

5900

1800

2200

HEIGHT

(mm)

1000

1000

1000

1000

Visit: www.dakal.co.uk Call Us: 01604 750098

DIAMETER

(mm)

150

150

150

150

16

BULKHEADS

LED OPALITE

BULKHEAD

KEY FEATURES:

• IP20 steel base with polycarbonate opal diffuser

• Steel LED geartray

• Ceiling or wall mounted

• Available in white or chrome body

• 3 year guarantee

• Emergency versions available add EM to part number

• Microwave sensor available add MWS to part number

ITEM DETAILS:

PART NUMBER BODY

PLE443/W/O/LED

PLE443/C/O/LED

White

Chrome

DIFFUSER WATTAGE

Opal

Opal

16w

16w

LAMP TYPE

LED

LED

PHOTOPIC

LUMENS

1050

1050

DIAMETER

(mm)

425

425

DEPTH

(mm)

114

114

LED POLO

BULKHEAD

KEY FEATURES:

• IP65 ( weather proof & dust proof )

• Polycarbonate body & diffuser

• Steel LED geartray

• Available with white or chrome bezel

• 3 year guarantee

• Emergency versions available add EM to part number

• Microwave sensor available add MWS to part number

ITEM DETAILS:

PART NUMBER

PLE116/W/O/LED

PLE116/C/O/LED

BODY

White

Chrome

DIFFUSER WATTAGE LAMP TYPE

Opal

Opal

16w

16w

LED

LED

PHOTOPIC

LUMENS

1050

1050

DIAMETER

(mm)

325

325

DEPTH

(mm)

100

100

17

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

BULKHEADS

LED ROUND IP65

BULKHEAD

KEY FEATURES:

• Round Polycarbonate base black or white

• Round Polycarbonate Cover opal or prismatic

• Steel LED gear tray

• IP65 ( weather proof & dust proof )

• Available with opal or prismatic diffuser

• Emergency versions available add EM to part number

• Photocell versions available add PC to part number

• Microwave sensor available add MWS to part number

ITEM DETAILS:

PART NUMBER BODY

PLE24/W/O/LED

PLE24/W/P /LED

PLE24/B/O/LED

PLE24/B/P/LED

White

White

Black

Black

LED GEARTRAYS

DIFFUSER

Opal

Prismatic

Opal

Prismatic

WATTAGE LAMP TYPE PHOTOPIC

LUMENS

16w LED 1050

16w

16w

16w

LED

LED

LED

1050

1050

1050

DIAMETER

(mm)

282

282

282

282

DEPTH

(mm)

85

85

85

85

KEY FEATURES:

• Steel LED gear tray

• Available in both cool white and warm white

• 3 year guarantee

• Emergency versions available add EM to part number

• Microwave sensor available add MWS to part number

ITEM DETAILS:

PART NUMBER

GT116/CW/LED

GT116/WW/LED

WATTAGE

16w

16w

LAMP TYPE

LED

LED

PHOTOPIC

LUMENS

1050

1050

COLOUR

Cool white

Warm white

DIAMETER

(mm)

325

325

DEPTH

(mm)

100

100

Visit: www.dakal.co.uk Call Us: 01604 750098

18

19

BULKHEADS

OPALITE

KEY FEATURES:

• IP20 steel base with polycarbonate opal diffuser

• High frequency gear as standard

• Ceiling or wall mounted

• Available in white/chrome body

• Supplied complete with col 840 lamp

• Emergency versions available add EM to part number

• Microwave sensor available add MWS to part number

ITEM DETAILS:

PART NUMBER BODY

PLE443/W/O

PLE443/C/O

PLE445/W/O

PLE445/C/O

PLE448/W/O

PLE448/C/O

White

Chrome

White

Chrome

White

Chrome

DIFFUSER WATTAGE LAMP TYPE PHOTOPIC

LUMENS

Opal

28w

2D

2050

Opal

Opal

Opal

Opal

Opal

28w

38w

38w

2 x 26w

2 x 26w

2D

2D

2D

PL-C

PL-C

2050

2850

2850

3600

3600

DIAMETER

(MM)

425

425

425

425

425

425

DEPTH

(MM)

114

114

114

114

114

114

POLO

KEY FEATURES:

• Polycarbonate body & diffuser

• High frequency gear as standard

• Available with white or chrome bezel

• IP65 ( weather proof & dust proof )

• Supplied complete with col 840 lamp

• Emergency versions available add EM to part number

• Microwave sensor available add MWS to part number

ITEM DETAILS:

PART NUMBER BODY

PLE16/W/O

PLE16/C/O

PLE28/W/O

PLE28/C/O

White

Chrome

White

Chrome

DIFFUSER WATTAGE LAMP TYPE PHOTOPIC

LUMENS

Opal

16w

2D 1050

Opal

Opal

Opal

16w

28w

28w

2D

2D

2D

1050

2050

2050

DIAMETER

(MM)

325

325

325

325

DEPTH

(MM)

100

100

100

100

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

BULKHEADS

ROUND IP65

BULKHEAD

KEY FEATURES:

• Round Polycarbonate Base

• Round Polycarbonate Cover

• Steel gear tray

• IP65 ( weather proof & dust proof )

• Supplied with High Frequency Control Gear as standard

• Available with opal or prismatic diffuser

• Supplied complete with col 840 lamp

• Emergency versions available add EM to part number

• Photocell versions available add PC to part number

• Microwave sensor available add MWS to part number

ITEM DETAILS:

PART NUMBER BODY

PLE24/W/O

PLE24/W/P

PLE24/B/O

PLE24/B/P

White

White

Black

Black

DIFFUSER

Opal

Prismatic

Opal

Prismatic

WATTAGE LAMP TYPE DIAMETER (MM) DEPTH

(MM)

28w 2D 282 85

28w

28w

28w

2D

2D

2D

282

282

282

85

85

85

SQUARE IP65

BULKHEAD

KEY FEATURES:

• Square Polycarbonate Base

• Square Polycarbonate Cover

• Steel gear tray

• IP65 ( weather proof & dust proof )

• Supplied with High Frequency Control Gear

• Supplied complete with col 840 lamp

• Emergency versions available add EM to part number

• Photocell versions available add PC to part number

• Microwave sensor available add MWS to part number

ITEM DETAILS:

PART NUMBER

PLE22/W/O

PLE22/W/P

PLE22/B/O

PLE22/B/P

BODY

White

White

Black

Black

DIFFUSER WATTAGE LAMP TYPE LENGTH

(MM)

Opal 28w 2D 260

Prismatic

Opal

Prismatic

28w

28w

28w

2D

2D

2D

260

260

260

WIDTH

(MM)

260

260

260

260

DEPTH

(mm)

90

90

90

90

Visit: www.dakal.co.uk Call Us: 01604 750098

20

DOWNLIGHTS

COMPACT FLUORESCENT

DOWNLIGHT 1

KEY FEATURES:

• Supplied with high frequency gear as standard

• Gearbox formed from steel

• White bezel as standard

• Gearbox can be detached for remote fi tting in ceilings with

restricted clearance

• Dimmable versions available upon request

• Can be fi tted with IP44 cover and various drop glass options

• Supplied complete with col 840 Lamp

• Emergency versions available add EM to part number

ITEM DETAILS:

PART NUMBER WATTAGE

NMA118/HF

NMA126/HF

NMA218/HF

NMA226/HF

1 x 18w

1 x 26w

2 x 18w

2 x26w

LAMP TYPE

PL-C

PL-C

PL-C

PL-C

PHOTOPIC

LUMENS

1200

1800

2400

3600

DIAMETER

(mm)

224

224

224

224

CUT OUT

(mm)

200

200

200

200

DEPTH

(mm)

183

183

183

183

21

COMPACT FLUORESCENT

DOWNLIGHT 2

KEY FEATURES:

• Supplied with high frequency gear as standard

• Gearbox formed from steel

• White bezel as standard

• Dimmable versions available upon request

• Can be fi tted with drop glass options

• Supplied complete with col 840Lamp

• Emergency versions available add EM to part number

ITEM DETAILS:

PART NUMBER WATTAGE LAMP TYPE

GMA118/HF

GMA126/HF

GMA132/HF

GMA142/HF

GMA218/HF

GMA226/HF

GMA232/HF

GMA242/HF

1 x 18w

1 x 26w

1 x 32w

1 x 42w

2 x 18w

2 x26w

2 x 32w

2 x 42w

PL-C

PL-C

PL-T

PL-T

PL-C

PL-C

PL-T

PL-T

PHOTOPIC

LUMENS

1200

1800

2200

3200

2400

3600

4400

6400

DIAMETER

(mm)

190

190

190

190

190

190

190

190

CUT OUT

(mm)

165

165

165

165

165

165

165

165

DEPTH

(mm)

130

130

130

130

130

130

130

130

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

DOWNLIGHTS

ITEM DETAILS:

PART NUMBER WATTAGE

GMA218/HF/IP65

GMA226/HF/IP65

2 x 18w

2 x 26w

LAMP TYPE

PL-C

PL-C

IP65 COMPACT

FLUORESCENT

DOWNLIGHT

KEY FEATURES:

• Matt white bezel

• Glass cover

• IP65 ( weather proof & dust proof )

• Supplied with spring clips

• Supplied complete with col 840 lamp

• Supplied with high frequency gear as standard

• Dimmable versions available upon request

• Emergency versions available add EM to part number

PHOTOPIC

LUMENS

2400

3600

DIAMETER

(mm)

220

220

CUT OUT

(mm)

210

210

DEPTH

(mm)

115

115

LED DOWNLIGHT

KEY FEATURES:

• White Bezel

• Opal Diffuser

• 120 ° beam angle

• 35,000 hour lamp life

• 6,000k colour temperature

• Epistar chip

• High colour rendering index

• IP44 rating

• Seperate driver provided

• 3 year guarantee

• Emergency version is available upon request add EM

to part number

ITEM DETAILS:

PART NUMBER WATTAGE LAMP TYPE

DLED10W

DLED15W

DLED20W

10w

15w

20w

LED

LED

LED

PHOTOPIC

LUMENS

820

1245

1640

DIAMETER

(mm)

112

150

194

Visit: www.dakal.co.uk Call Us: 01604 750098

CUTOUT

(mm)

100

130

173

DEPTH

(mm)

55

62

66

22

EMERGENCY LIGHTING

EMERGENCY IP65

BULKHEAD

KEY FEATURES:

• Polycarbonate base

• Polycarbonate diffuser

• Cable entries both ends

• IP65 ( weather proof & dust proof )

• Supplied complete with Lamp

• 3 hour emergency

ITEM DETAILS:

PART NUMBER LAMP TYPE

ZE208/NM

ZE218/M

8w T5

8w T5

EMERGENCY TYPE

Non Maintained

Maintained

LENGTH

(mm)

345

345

WIDTH

(mm)

107

107

DEPTH

(mm)

77

77

EMERGENCY EXIT

BOX

KEY FEATURES:

• Sheet Steel Construction

• PVC Screened legend supplied - arrow down

• Supplied Complete with Lamp

• 3 hour emergency

• Various legend options available upon request

ITEM DETAILS:

PART NUMBER

ZE308/NM

ZE318/M

LAMP TYPE

8w T5

8w T5

EMERGENCY TYPE

Non Maintained

Maintained

LENGTH

(mm)

390

390

WIDTH

(mm)

190

190

DEPTH

(mm)

60

60

23

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

EMERGENCY LIGHTING

TWINSPOT

KEY FEATURES:

• White steel body

• Twin Lamp

• Compact size

• 1 and 3 hour variants available

• Non maintained emergency

ITEM DETAILS:

PART NUMBER LAMP TYPE

ZT220

ZT255

2 x 20w

2 x 55w

EMERGENCY TYPE

3 Hour Non Maintained

1 Hour Non Maintained

LENGTH

(mm)

270

270

WIDTH

(mm)

350

350

DEPTH

(mm)

108

108

EMERGENCY

CONVERSION PACKS

KEY FEATURES:

• All types of emergency conversion pack available

• Slimline conversion packs available

• Self Test Conversion packs available

• All convesrion packs include Inverter, Batteries,

Battery End Caps, Battery wires & LED Charge

indicator

• Please ask for more details

ITEM DETAILS:

PART NUMBER

ZE18/T8/CP

ZE36/T8/CP

ZE58/T8/CP

ZE70/T8/CP

LAMP TYPE

4 to18w T8

18 to 36w T8

36w to 58w T8

58w to 70w T8

EMERGENCY TYPE

3 Hour Maintained/Non Maintained

3 Hour Maintained/Non Maintained

3 Hour Maintained/Non Maintained

3 Hour Maintained/Non Maintained

Visit: www.dakal.co.uk Call Us: 01604 750098

24

FLOODLIGHTS

SLIMLINE

FLOODLIGHT

KEY FEATURES:

• Die-cast aluminium body

• Polyester powder coated body available in black or white

• 5mm thick tempered glass

• High quality aluminium refl ector

• Asymmetrical distribution

• Supplied complete with Lamp

• IP65 ( weather proof & dust proof )

• Photocell can be fi tted add PC to part number

• Wire guard can be supplied upon request add WG to part

number

ITEM DETAILS:

PART NUMBER WATTAGE

DFAM70G

DFAM150G

70w

150w

LAMP TYPE

HQI R7

S

HQI R7

S

PHOTOPIC

LUMENS

4500

5900

HEIGHT

(mm)

440

440

WIDTH

(mm)

250

250

DEPTH

(mm)

86

86

WEIGHT

( Kg)

5.2

6.0

25

SUPERIOR

FLOODLIGHT

KEY FEATURES:

• Die-cast aluminium body

• Polyester powder coated body available in black or white

• 5mm thick tempered glass

• High quality aluminium refl ector

• Symmetrical distribution

• Supplied complete with Lamp

• IP65 ( weather proof & dust proof )

• Photocell can be fi tted add PC to part number

• Wire guard can be supplied upon request add WG to part

number

ITEM DETAILS:

PART NUMBER WATTAGE LAMP TYPE

DFCPS150

DFCPS250

DFCPS400

DFCPM150

DFCPM250

DFCPM400

150w

250w

400w

150w

250w

400w

SON E40

SON E40

SON E40

HQI E40

HQI E40

HQI E40

PHOTOPIC

LUMENS

14,500

27,500

46,000

11,400

18,900

34,000

HEIGHT

(mm)

538

538

538

538

538

538

WIDTH

(mm)

427

427

427

427

427

427

DEPTH

(mm)

144

144

144

144

144

144

WEIGHT

(Kg)

9.5

10.5

11.5

9.5

10.5

11.5

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

FLOODLIGHTS

POLYCARBONATE

FLOODLIGHT

KEY FEATURES:

• Polycarbonate body and diffuser

• High quality aluminium refl ector

• Black body

• Symmetrical distribution

• Supplied complete with lamp

• IP65 ( weather proof & dust proof )

• Photocell can be fi tted add PC to part number

ITEM DETAILS:

PART NUMBER WATTAGE LAMP TYPE

DFS70i/PD

DFS70T/PD

DFM70/PD

70w

70w

70w

SON-I E27

SON-T E27

HQI R7

S

PHOTOPIC

LUMENS

5900

5900

4500

HEIGHT

(mm)

298

298

298

WIDTH

(mm)

243

243

243

DEPTH

(mm)

207

207

207

WEIGHT

(Kg)

4.0

4.0

4.0

SLIMLINE

FLOODLIGHT 2

KEY FEATURES:

• Die-cast aluminium body

• Polyester powder coated body available in black or white

• 5mm thick tempered glass

• High quality aluminium refl ector

• Asymmetrical distribution

• Supplied complete with Lamp

• IP65 ( weather proof & dust proof )

• Photocell can be fi tted add PC to part number

• Wire guard can be supplied upon request add WG to part

number

ITEM DETAILS:

PART NUMBER WATT-

AGE

DFAM70B 70w

DFAM150B 150w

LAMP TYPE

HQI R7s

HQI R7s

PHOTOPIC

LUMENS

4500

5900

HEIGHT

(mm)

440

440

WIDTH

(mm)

250

250

DEPTH

(mm)

86

86

WEIGHT

( Kg)

5.2

6.0

Visit: www.dakal.co.uk Call Us: 01604 750098

26

FLOODLIGHTS

AREA

FLOODLIGHT

KEY FEATURES:

• Die-cast aluminium body

• Polyester powder coated in black

• 5mm tempered glass front

• Stainless steel glass retaining clips

• Pure high quality aluminium symmetrical refl ector

• IP65 ( weather proof & dust proof )

• Supplied complete with Lamp

• Photocell can be fi tted add PC to part number

ITEM DETAILS:

PART NUMBER LAMP TYPE

DFS150

DFS250

DFS400

DFM150

DFM250

DFM400

150w

250w

400w

150w

250w

400w

LAMP TYPE

SON E40

SON E40

SON E40

HQI E40

HQI E40

HQI E40

PHOTOPIC

LUMENS

14,500

27,500

46,000

11,400

18,900

34,000

HEIGHT

(mm)

305

305

305

305

305

305

WIDTH

(mm)

405

405

405

405

405

405

DEPTH

(mm)

300

300

300

300

300

300

WEIGHT

(Kg)

9.5

10.5

11.5

9.5

10.5

11.5

AREA FLOODLIGHT C/W

POLYCARBONATE DIFF

KEY FEATURES:

• Die-cast aluminium body

• Polyester powder coated in black

• 5mm tempered glass front covered by dished

polycarbonate diffuser

• Stainless steel glass retaining clips

• Pure high quality aluminium symmetrical refl ector

• IP65 ( weather proof & dust proof )

• Supplied complete with Lamp

• Photocell can be fi tted add PC to part number

27

ITEM DETAILS:

PART NUMBER

DFS150/PD

DFS250/PD

DFS400/PD

DFM150/PD

DFM250/PD

DFM400/PD

WATTAGE

150w

250w

400w

150w

250w

400w

LAMP TYPE

SON E40

SON E40

SON E40

HQI E40

HQI E40

HQI E40

PHOTOPIC

LUMENS

14,500

27,500

46,000

11,400

18,900

34,000

HEIGHT

(mm)

305

305

305

305

305

305

WIDTH

(mm)

405

405

405

405

405

405

DEPTH

(mm)

380

380

380

380

380

380

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

WEIGHT

(Kg)

9.5

10.5

11.5

9.5

10.5

11.5

FLOODLIGHTS

1000W FLOODLIGHT

KEY FEATURES:

• Die-cast aluminium body

• Polyester powder coated in black

• 5mm tempered glass front

• Stainless steel glass retaining clips

• Pure high quality aluminium symmetrical refl ector

• IP65 ( weather proof & dust proof )

• Supplied complete with Lamp

• Contol gear supplied in IP65 remote gear box

ITEM DETAILS:

PART NUMBER

DFCS1000/REM

DFCM1000/REM

WATTAGE LAMP TYPE VOLTAGE

(V)

1000w SON 230

1000w HQI 230

PHOTOPIC

LUMENS

135,000

85,000

HEIGHT

(mm)

714

714

WIDTH

(mm)

552

552

DEPTH

(mm)

207

207

WEIGHT

(Kg)

25

25

2000W FLOODLIGHT 415

V

KEY FEATURES:

• Die-cast aluminium body

• Polyester powder coated in black

• 5mm tempered glass front

• Stainless steel glass retaining clips

• Pure high quality aluminium symmetrical refl ector

• IP65 ( weather proof & dust proof )

• Supplied complete with Lamp

• Contol gear supplied in IP65 remote gear box

ITEM DETAILS:

PART NUMBER

DFCM2000/REM/415v

WATTAGE LAMP TYPE VOLT-

AGE

(V)

2000w HQI 415

PHOTOPIC

LUMENS

HEIGHT

(mm)

230,000 520

WIDTH

(mm)

590

DEPTH

(mm)

WEIGHT

(Kg)

295 35

Visit: www.dakal.co.uk Call Us: 01604 750098

28

HIGHBAYS

ITEM DETAILS:

PART NUMBER

DLED150/HB

DLED200/HB

WATTAGE

150w

200w

LED HIGHBAY

KEY FEATURES:

• Aluminium refl ector

• Large heat sink

• 35,000 hour LED life

• Bridgelux LED chip

• -20 °c to + 50 °C operating temperature

• 6000k colour temperature

• IP44 rating

• 35,000 hour lamp life

• 3 year guarantee

LAMP TYPE

LED

LED

PHOTOPIC

LUMENS

13,500

18,000

HEIGHT

(mm

495

580

DIAMETER

(mm

488

488

H.I.D HIGHBAY

29

KEY FEATURES:

• Sheet steel housing fi nished in white powder coating

• Highly polished aluminium spun refl ector

• Tempered glass in a silicon rubber sealing gasket

• IP44 protection when supplied with glass kit

• U bolt supplied for suspension purposes

• Supplied complete with lamp

• Dished polycarbonate diffuser can be supplied upon

request add PD to the part number

• Wire guard can be supplied upon request add WG to part

number

ITEM DETAILS:

PART NUMBER WATTAGE LAMP TYPE

CHB150S

CHB250S

CHB400S

CHB150M

CHB250M

CHB400M

150w

250w

400w

150w

250w

400w

SON E40

SON E40

SON E40

HQI E40

HQI E40

HQI E40

PHOTOPIC

LUMENS

14,500

27,500

46,000

11,400

18,900

34,000

HEIGHT

(mm)

620

620

620

620

620

620

DIAMTER

(mm)

490

490

490

490

490

490

WEIGHT

(Kg)

5

9

10.5

5

9

9

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

HIGHBAYS

IP65 H.I.D HIGHBAY

ITEM DETAILS:

PART NUMBER

HBW150S

HBW250S

HBW400S

HBW150M

HBW250M

HBW400M

WATTAGE

150w

250w

400w

150w

250w

400w

LAMP TYPE

SON E40

SON E40

SON E40

HQI E40

HQI E40

HQI E40

KEY FEATURES:

• Die-cast aluminium gear housing fi nished in black

• Highly polished aluminium spun refl ector

• Tempered glass in a silicon rubber sealing gasket

• IP65 ( weather proof & dust proof )

• U bolt supplied for suspension purposes

• Supplied complete with lamp

• Dished polycarbonate diffuser can be supplied upon

request add PD to the part number

• Wire guard can be supplied upon request add WG to part

number

PHOTOPIC

LUMENS

14,500

27,500

46,000

11,400

18,900

34,000

HEIGHT

(mm)

614

614

614

614

614

614

DIAMTER

(mm)

490

490

490

490

490

490

WEIGHT

(Kg)

5

9

10.5

5

9

9

DECORATIVE

H.I.D HIGHBAY

KEY FEATURES:

• Sheet steel housing fi nished in white powder coating

• UV stabilzed polycarbonate refractor and conical lens

• IP20 Rating

• U bolt provided for suspension

• Supplied complete with lamp

ITEM DETAILS:

PART NUMBER WATTAGE

HBR150S

HBR250S

HBR400S

HBR150M

HBR250M

HBR400M

150w

250w

400w

150w

250w

400w

LAMP TYPE

SON E40

SON E40

SON E40

HQI E40

HQI E40

HQI E40

PHOTOPIC

LUMENS

14,500

27,500

46,000

11,400

18,900

34,000

HEIGHT

(mm)

614

614

614

614

614

614

DIAMTER

(mm)

490

490

490

490

490

490

WEIGHT

(Kg)

5

9

9

5

9

10.5

Visit: www.dakal.co.uk Call Us: 01604 750098

30

WHAT CAN WE REPLACE WITH ?

REPLACE YOUR OLD FITTINGS

WITH A LOW ENERGY OPTION

CURRENT

Floodlights

100w Halogen Floodlight

300w Halogen Floodlight

500w Halogen Floodlight

70w HQI/SON Floodlight

150w HQI/SON Floodlight

250w HQI/SON Floodlight

400w HQI/SON Floodlight

Lowbays

150w HQI/SON Lowbay

250w HQI/SON Lowbay

400w HQI/SON Lowbay

Highbays

150w HQI/SON Highbay

250w HQI/SON Highbay

400w HQI/SON Highbay

Amenity Light

70w SON/HQI Amenity

Bulkheads

28w 2D

Emergency Lighting

8w IP65 Bulkhead

8w Exit Box

2 x 20w Twinspot

2 x 20w Twinspot IP65

OPTION 1

DLED10W/F

DLED30W/F

DLED50W/F

DIF40W

DIF80W

DIF150W

DIF200W

DIL80W/G3

DIL150W/G3

DIL200W/G3

DIH80W/G3

DIH150W/G3

DIH200W/G3

DIA40W

PLE116/W/O/LED

ZE218M/LED

ZE318M/LED

ZT120/LED

ZT120/LED/IP

1

19

35

35

36

36

1

1

1

3

3

3

PAGE NO

5

5

5

4

4

4

4

OPTION 2

DLED50W/F

DLED80W/F

DLED150W/F

DLED150W/F

XLF433/LED

XLF433/LED

DLED150/HB

DLED200/HB

DA30W/LED

PAGE NO

5

5

6

6

10

10

29

29

14

31

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

WHAT CAN WE REPLACE WITH ?

REPLACE YOUR OLD FITTINGS

WITH A LOW ENERGY OPTION

CURRENT

Non Corrosives

1 x 18w T8

1 x 36w T8

1 x 58w T8

1 x 70w T8

2 x 18w T8

2 x 36w T8

2 x 58w T8

2 x 70w T8

Recessed Modulars

4 x 18w T8

2 x 36w T8

4 x 36w T8

Downlights

1 x 18w PL-C

2 x 18w PL-C

1 x 26w PL-C

2 x 26w PL-C

OPTION 1

NCCF2/LED

NCCF4/LED

NCCF5/LED

NCCF6/LED

NCCF22/LED

NCCF24/LED

NCCF25/LED

NCCF26/LED

DLED/P/42/600

DLED/P/45/1232

DLED/P/72/1260

DLED10W

DLED15W

DLED20W

DLED20W

22

22

22

22

9

9

9

PAGE NO

41

41

41

41

41

41

41

41

OPTION 2

NCSL40/LED

NCSL60/LED

CMFOC414

CMFOC428

PAGE NO

41

41

45

Visit: www.dakal.co.uk Call Us: 01604 750098

32

LAMPS & TUBES

ITEM DETAILS:

PART NUMBER LAMP TYPE

DF/T8/2/LED/12W

DF/T8/4/LED/22W

DF/T8/5/LED/24W

DF/T8/6/LED/32W

LED

LED

LED

LED

T8 LED TUBES

PHOTOPIC

LUMENS

1100

1980

2200

2800

KEY FEATURES:

• Instant on/off switching

• Mercury and lead free

• No UV

• Resistant to shock and vibration

• Specially designed heat sink

• T8 Rotating end caps

• IP20

• CRI Ra >=80

• 6000k colour temperature

• -30 °C to + 50 °C operating temperature

• 3 year guarantee

WATTAGE

12w

22w

24w

32w

LENGTH

(mm)

603

1214

1514

1814

DIAMETER

(mm)

26

26

26

26

33

T8 & T5 FLUORESCENT

LAMPS

KEY FEATURES:

• T8 tubes work with switch start and high frequency

control gear

• T5 tubes work with high frequency control gear only

• All tubes supplied as colour 840

• Other colour tubes also available upon request

ITEM DETAILS:

PART NUMBER LAMP TYPE WATTAGE

DFL18/T8

DFL36/T8

DFL58/T8

DFL70/T8

DFL14/T5

DFL28/T5

DFL35/T5

DFL49/T5

DFL54/T5

DFL80/T5

T8

T8

T5

T5

T5

T5

T8

T8

T5

T5

18w

36w

35w

49w

54w

80w

58w

70w

14w

28w

PHOTOPIC

LUMENS

1350

3350

5200

6550

1220

2610

3290

4900

4850

6160

LENGTH

(mm)

600

1200

1500

1800

600

1200

1500

1500

1200

1500

DIAMETER

(mm)

26

26

16

16

16

16

26

26

16

16

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

LAMPS & TUBES

HQI DISCHARGE LAMPS

KEY FEATURES:

• Traditional discharge lamps

• Metal halide or HQI lamp

• Runs off mercury based control gear

• Available in tubular and eliptical shape

for eliptical swap the “ T “ in part number for “ E “

ITEM DETAILS:

PART NUMBER

DLM70/R7s

DLM150/R7s

DLM70T

DLM150T

DLM250T

DLM400T

WATTAGE

70w

150w

70w

150w

250w

400w

LAMP TYPE

HQI

HQI

HQI

HQI

HQI

HQI

SON DISCHARGE LAMPS

KEY FEATURES:

• Traditional discharge lamps

• Sodium lamp ( SON )

• Runs off sodium based control gear

• Available in tubular and eliptical shape

for eliptical swap the “ T “ in part number for “ E “

PHOTOPIC

LUMENS

4500

11,400

4500

11,400

18,900

34,000

LAMP CAP

R7s

R7s

E27

E40

E40

E40

ITEM DETAILS:

PART NUMBER

DLS70/R7s

DLS150/R7s

DLS70T

DLS150T

DLS250T

DLS400T

WATTAGE

70w

150w

70w

150w

250w

400w

LAMP TYPE

SON

SON

SON

SON

SON

SON

PHOTOPIC

LUMENS

5900

14,500

5900

14,500

27,500

50,000

Visit: www.dakal.co.uk Call Us: 01604 750098

LAMP CAP

R7s

R7s

E27

E40

E40

E40

34

LED EMERGENCY LIGHTING

LED IP65

BULKHEAD

KEY FEATURES:

• Body and diffuser formed from polycarbonate

• IP65 ( weather proof & dust proof )

• Hinged gear tray for easy installation

• Cable entry on both ends, side and rear

• LED life greater than 50,000 hours

• 3 hour emergency

ITEM DETAILS:

PART NUMBER LAMP TYPE

ZE208/NM/LED

ZE218/M/LED

LED

LED

EMERGENCY

TYPE

Non Maintained

Maintained

LENGTH

(mm)

345

345

LED EMERGENCY

EXIT BOX

KEY FEATURES:

• Sheet Steel Construction

• LED

• 32m viewing distance

• PVC Screened legend supplied - arrow down

• 3 hour maintained emergency

• Various legend options available upon request

WIDTH

(mm)

107

107

DEPTH

(mm)

77

77

35

ITEM DETAILS:

PART NUMBER

ZE/EXIT/AL/LED

ZE/EXIT/AR/LED

ZE/EXIT/AD/LED

LAMP TYPE

LED

LED

LED

ARROW DIREC-

TION

Arrow Left

Arrow Right

Arrow Down

LENGTH

(mm)

390

390

390

WIDTH

(mm)

190

190

190

DEPTH

(mm)

60

60

60

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

LED EMERGENCY LIGHTING

LED TWINSPOT

KEY FEATURES:

• Metal body

• Polycarbonate lenses

• IP20 Protection

• 120 leds with running wattage of 20w

• Can be mounted in any orientation

• Cable entry on both ends,side and rear

• LED life greater than 50,000 hours

• 3 hour non maintained emergency light

• Very light weight fi tting only weighs 3kg

ITEM DETAILS:

PART NUMBER LAMP TYPE

ZT120/LED LED

E M E R G E N C Y

TYPE

Non maintained

LENGTH

(mm)

290

WIDTH

(mm)

270

DEPTH

(mm)

70

IP65 LED TWINSPOT

KEY FEATURES:

• Polycarbonate body

• Polycarbonate lenses

• IP65 ( weather proof & dust proof )

• Can be mounted in any orientation

• Cable entry on both ends,side and rear

• LED life greater than 50,000 hours

• 3 hour non maintained emergency light

• Very light weight fi tting only weighs 3kg

ITEM DETAILS:

PART NUMBER

ZT120/LED/IP

LAMP TYPE

LED

E M E R G E N C Y

TYPE

Non maintained

LENGTH

(mm)

290

WIDTH

(mm)

270

DEPTH

(mm)

70

Visit: www.dakal.co.uk Call Us: 01604 750098

36

LED EMERGENCY LIGHTING

LED SEMI RECESSED

EXIT SIGN

KEY FEATURES:

• Body and diffuser formed from polycarbonate

• IP65 ( weather proof & dust proof )

• Hinged gear tray for easy installation

• Cable entry on both ends, side and rear

• LED life greater than 50,000 hours

• 3 hour emergency

ITEM DETAILS:

PART NUMBER

ZE908/NM/LED

ZE918/M/LED

LAMP TYPE

LED

LED

EMERGENCY

TYPE

Non Maintained

Maintained

LENGTH

(mm)

240

240

LED HANGING EXIT SIGN

KEY FEATURES:

• Sheet Steel Construction

• LED

• 32m viewing distance

• PVC Screened legend supplied - arrow down

• Supplied Complete with Lamp

• 3 hour maintained emergency

• Various legend options available upon request

WIDTH

(mm)

355

355

DEPTH

(mm)

113

113

37

ITEM DETAILS:

PART NUMBER

ZE/ELS/AL/LED

ZE/ELS/AR/LED

ZE/ELS/AD/LED

LAMP TYPE

LED

LED

LED

ARROW DIRECTION

Arrow Left

Arrow Right

Arrow Down

LENGTH

(mm)

250

250

250

WIDTH

(mm)

360

360

360

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

DEPTH

(mm)

54

54

54

LED EMERGENCY LIGHTING

LED EMERGENCY

DOWNLIGHTS 1

KEY FEATURES:

• Metal canned body

• IP20 Protection

• 3 hour non maintained emergency light

• Supplied with remote driver and batteries

• 4.8v Ni-cd batteies

ITEM DETAILS:

PART NUMBER

DLD3W

LAMP TYPE

3w LED

EMERGENCY

TYPE

Non maintained

DIAMETER

(mm)

25

CUT OUT

(mm)

20

DEPTH

(mm)

20

LED EMERGENCY

DOWNLIGHTS 2

KEY FEATURES:

• Metal canned body

• IP20 Protection

• Effi cient refl ector design

• Recessed mounting brackets included

• 3 hour non maintained emergency light

• Supplied with remote driver and batteries

ITEM DETAILS:

PART NUMBER

DLDN1W

DLDN3W

DLDN5W

LAMP TYPE

1w LED

3w LED

5w LED

EMERGENCY

TYPE

Non maintained

Non maintained

Non maintained

DIAMETER

(mm)

45

78

78

CUT OUT

(mm)

32

62

62

Visit: www.dakal.co.uk Call Us: 01604 750098

DEPTH

(mm)

27

32

55

38

LOWBAYS

LED FLOBAY

ITEM DETAILS:

PART NUMBER WATTAGE LAMP TYPE

XLF433/LED

XLF633/LED

4 x 33w

6 x 33w

LED

LED

KEY FEATURES:

• Housing manufactured from steel and fi nished in white

• Luminaire typically mounted between 3 and 7m

• Fitting can be surface mounted or suspended

• Fitted with branded driver and LED chips

• High quality Miro 4 (95% refl ectance ) supplied as standard

• Dali dimmable versions available upon request

• Can be fi tted with a range of PIR and Microwave sensors

• 5 year guarantee

• Emergency version is available upon request add EM

to part number

• Flat polycarbonate diffuser is available upon request

add FPD to the part number

PHOTOPIC

LUMENS

16,680

25,020

CRI

70

70

LENGTH

(mm)

750

750

WIDTH

(mm)

330

330

DEPTH

(mm)

92

92

H.I.D LOWBAY

39

KEY FEATURES:

• Body formed from pre-treated pressed steel

• Powder coated white

• Refl ector is produced from high grade aluminium

• Removable gear tray for easy maintenance

• 20mm conduit entry provided

• Supplied complete with Lamp

• Polycarbonate diffuser can be supplied upon request add

PD to part number

• Wire guard can be supplied upon request add WG to part

number

ITEM DETAILS:

PART NUMBER WATTAGE LAMP TYPE

LB150S

LB250S

LB400S

LB150M

LB250M

LB400M

150w

250w

400w

150w

250w

400w

SON E40

SON E40

SON E40

HQI E40

HQI E40

HQI E40

PHOTOPIC

LUMENS

14,500

27,500

46,000

11,400

18,900

34,000

LENGTH

(mm)

600

600

600

600

600

600

WIDTH

(mm)

284

284

284

284

284

284

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

DEPTH

(mm)

154

154

154

154

154

154

LOWBAYS

IP65 H.I.D LOWBAY

KEY FEATURES:

• Body is 2mm die cast aluminium

• Pure high quality symmetrical aluminium refl ector

• Removable geartray for easy maintenance

• IP65 ( weather proof & dust proof )

• Brackets supplied for surface or suspension mounting

• Supplied complete with Lamp

ITEM DETAILS:

PART NUMBER WATTAGE

LB150S/IP

LB250S/IP

LB400S/IP

LB150M/IP

LB250M/IP

LB400M/IP

150w

250w

400w

150w

250w

400w

LAMP TYPE

SON E40

SON E40

SON E40

HQI E40

HQI E40

HQI E40

PHOTOPIC

LUMENS

14,500

27,500

46,000

11,400

18,900

34,000

LENGTH

(mm)

570

570

570

570

570

570

H.I.D WEATHERBAY

KEY FEATURES:

• Die cast aluminium body

• Polyester black powder coat fi nish

• 5mm tempered glass front

• Refl ector is produced from high grade aluminium

• IP65 ( weather proof & dust proof )

• Supplied complete with dished polycarbonate diffuser

• Supplied complete with lamp

• Photocell can be fi tted add PC to part number

ITEM DETAILS:

PART NUMBER WATTAGE

LBW150S/PD

LBW250S/PD

LBW400S/PD

LBW150M/PD

LBW250M/PD

LBW400M/PD

150w

250w

400w

150w

250w

400w

LAMP TYPE

SON E40

SON E40

SON E40

HQI E40

HQI E40

HQI E40

PHOTOPIC

LUMENS

14,500

27,500

46,000

11,400

18,900

34,000

LENGTH

(mm)

450

450

450

450

450

450

WIDTH

(mm)

300

300

300

300

300

300

WIDTH

(mm)

380

380

380

380

380

380

Visit: www.dakal.co.uk Call Us: 01604 750098

DEPTH

(mm)

156

156

156

156

156

156

DEPTH

(mm)

330

330

330

330

330

330

40

NON CORROSIVES & BATTENS

LED

ITEM DETAILS:

PART NUM-

BER

WATTAGE

NCCF2/LED

NCCF4/LED

NCCF5/LED

NCCF6/LED

NCCF22/LED

NCCF24/LED

NCCF25/LED

NCCF26/LED

LED 2

1 x 12w

1 x 22w

1 x 25w

1 x 30w

2 x 12w

2 x 22w

2 x 25w

2 x 30w

KEY FEATURES:

• Polycarbonate body & diffuser

• IP65 ( weather proof & dust proof )

• Can be surface mounted or suspended by chain

• Cable entry and conduit entry points provided

• Stainless steel clips as standard

• Supplied with T8 stand alone LED Tubes

• Emergency versions available add EM to the part number

• Microwave sensor available add PIR to part number

LAMP

TYPE

LED

LED

LED

LED

LED

LED

LED

LED

PHOTOPIC

LUMENS

LENGTH

(mm)

1100

1980

2200

2800

2200

3960

4400

5600

650

1278

1578

1874

650

1278

1578

1874

WIDTH

(mm)

70

100

100

100

116

158

158

158

HEIGHT

(mm)

87

100

100

100

87

100

100

100

FIXING CEN-

TRE

(mm)

500

1035

960

1110

500

1030

1033

1110

CLIPS

8

10

14

10

14

4

4

8

KEY FEATURES:

• Polycarbonate body & diffuser

• IP65 ( weather proof & dust proof )

• Can be surface mounted or suspended by chain

• Cable entry and conduit entry points provided

• Stainless steel clips as standard

ITEM DETAILS:

PART NUMBER WATTAGE

NCSL40/LED

NCSL60/LED

40w

60w

LAMP TYPE

LED

LED

PHOTOPIC

LUMENS

3900

5100

LENGTH

(mm)

1280

1575

WIDTH

(mm)

135

135

HEIGHT

(mm)

95

95

41

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

NON CORROSIVES & BATTENS

LED 3

KEY FEATURES:

• ABS Base

• Polycarbonate diffuser

• 40,000 hour LED life

• IP65 ( weather proof & dust proof )

• Can be surface mounted or suspended by chain

• Stainless steel clips as standard

• Emergency versions available add EM to the part number

ITEM DETAILS:

PART NUMBER WATTAGE

NCC124/LED

NCC224/LED

NCC140/LED

NCC240/LED

1 x 24w

2 x 24w

1 x 40w

2 x 40w

LAMP TYPE PHOTOPIC

LUMENS

LED

LED

LED

LED

2660

4800

3860

7530

BATTENS

C/W T8 LED TUBES

KEY FEATURES:

• Steel Body

• IP20

• Microwave sensor available add MWS to part number

• Prismatic diffuser available add PD to part number

• Aluminium refl ector available add AREF to part number

• 3 year guarantee on LED Tubes

LENGTH

(mm)

1270

1270

1565

1565

WIDTH

(mm)

93

140

93

140

HEIGHT

(mm)

100

100

100

100

CLIPS

10

10

12

12

ITEM DETAILS:

PART NUMBER WATTAGE

DBF2/LED

DBF4/LED

DBF5/LED

DBF22/LED

DBF24/LED

DBF25/LED

1 x 12w

1 x 22w

1 x 25w

2 x 12w

2 x 22w

2 x 25w

LAMP TYPE

LED

LED

LED

LED

LED

LED

PHOTOPIC

LUMENS

1100

1980

2200

2200

3960

4400

LENGTH

(mm)

615

1230

1530

615

1230

1530

WIDTH

(mm)

48

48

48

48

48

48

HEIGHT

(mm)

40

40

40

40

40

40

Visit: www.dakal.co.uk Call Us: 01604 750098

42

NON CORROSIVES & BATTENS

T5

43

ITEM DETAILS:

KEY FEATURES:

• Polycarbonate body & diffuser

• IP65 ( weather proof & dust proof )

• Can be surface mounted or suspended by chain

• Cable entry and conduit entry points provided

• High frequency control gear supplied as standard

• Dimmable versions available upon request

• Stainless steel clips as standard

• Emergency versions available add EM to the part number

• Microwave sensor available add PIR to part number

PART NUMBER WATTAGE LAMP TYPE LUMENS LENGTH

(mm)

WIDTH

(mm)

HEIGHT

(mm)

CLIPS

NCOF128

NCOF135

NCOF149

NCOF154

NCOF228

NCOF235

NCOF249

1 x 28w

1 x 35w

1 x 49w

1 x 54w

2 x 28w

2 x 35w

2 x 49w

T5

T5

T5

T5

T5

T5

T5

2610

3290

4900

4850

5220

6580

9800

1210

1510

1510

1210

1210

1510

1510

65

65

65

65

104

104

104

80

80

80

80

80

80

80

FIXING CEN-

TRE

(mm)

670

780

780

670

670

780

780

10

12

12

10

10

12

12

T8

KEY FEATURES:

• Polycarbonate body & diffuser

• IP65 ( weather proof & dust proof )

• Can be surface mounted or suspended by chain

• Cable entry and conduit entry points provided

• High frequency control gear supplied as standard

• Stainless steel clips as standard

• Emergency versions available add EM to the part number

• Microwave sensor available add PIR to part number

ITEM DETAILS:

PART NUMBER WATTAGE LAMP

TYPE

LUMENS LENGTH

(mm)

NCCF2/HF

NCCF4/HF

NCCF5/HF

NCCF6/HF

NCCF22/HF

NCCF24/HF

NCCF25/HF

1 x 18w

1 x 36w

1 x 58w

1 x 70w

2 x 18w

2 x 36w

2 x 58w

T8

T8

T8

T8

T8

T8

T8

1350

3350

5200

5600

2700

6700

10,400

650

1278

1578

1874

650

1278

1578

WIDTH

(mm)

70

100

100

100

116

158

158

HEIGHT

(mm)

87

100

100

100

87

100

100

FIXING CEN-

TRE

(mm)

500

1035

960

1110

500

1030

1033

CLIPS

4

8

10

14

4

8

10

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

NON CORROSIVES & BATTENS

STAINLESS STEEL IP65 T5

KEY FEATURES:

• Stainless steel body & Polycarbonate diffuser

• IP65 ( weather proof & dust proof )

• Can be surface mounted or suspended by chain

• Cable entry and conduit entry points provided

• High frequency control gear supplied as standard

• Dimmable versions available

• Stainless steel clips as standard

• Emergency versions available add EM to the part number

• Microwave sensor available add PIR to part number

ITEM DETAILS:

PART NUMBER WATTAGE

DSTS135/IP

DSTS149/IP

DSTS235/IP

DSTS249/IP

1 x 35w

1 x 49w

2 x 35w

2 x 49w

LAMP TYPE

T5

T5

T5

T5

LUMENS

3290

4900

6580

9800

LENGTH

(mm)

1605

1605

1605

1605

WIDTH

(mm)

140

140

200

200

HEIGHT

(mm)

90

90

90

90

T5 BATTENS

KEY FEATURES:

• Steel Body

• IP20

• Dimmable versions available upon request

• Emergency versions available add EM to the part number

• Microwave sensor available add MWS to part number

• Prismatic diffuser available add PD to part number

• Aluminium refl ector available add AREF to part number

• Microwave sensor available add PIR to part number

ITEM DETAILS:

PART NUMBER WATTAGE LAMP TYPE LUMENS

DBF128

DBF135

DBF149

DBF154

DBF228

DBF235

DBF249

DBF254

1 x 28w

1 x 35w

1 x 49w

1 x 54w

2 x 28w

2 x 35w

2 x 49w

2 x 54w

T5

T5

T5

T5

T5

T5

T5

T5

2610

3290

4900

4850

5220

6580

9800

9700

LENGTH

(mm)

1175

1473

1473

1175

1175

1473

1473

1175

WIDTH

(mm)

38

38

38

38

38

38

38

38

Visit: www.dakal.co.uk Call Us: 01604 750098

HEIGHT

(mm)

33

33

33

33

33

33

33

33

44

45

RECESSED LUMINAIRES

LED

KEY FEATURES:

• Fits into standard size ceiling grids both 15mm and 24mm

• IP44 Rating

• Complies with Part L1 & L2 of building regulations

• 50,000 hour average lamp life

• -40 ° C - 55 ° C

• No humming

• Dimmable versions available upon request

• 3 year guarantee

• Surface mounting frame can be supplied at an

additional cost

• Emergency versions available add EM to part number

ITEM DETAILS:

PART NUMBER LAMP TYPE

DLED/P/42/600

DLED/P/45/1232

DLED/P/72/1260

LED

LED

LED

T5

PHOTOPIC

LUMENS

3300

3150

5500

WATTAGE

42w

45w

72w

LENGTH

(mm)

595

1200

1200

WIDTH

(mm)

595

300

600

DEPTH

(mm)

12

15

15

KEY FEATURES:

• Body is formed from 0.6mm trimmed sheet steel

• Perforated sheet steel between louvres

• White powder coated fi nish

• High Frequency gear as standard

• Dimmable versions available upon request

• Suitable for 15mm and 24mm T Bar

• Double parabolic louvre

• Supplied less lamps

• Emergency versions available add EM to the part number

ITEM DETAILS:

PART NUMBER WATTAGE

CMFOC314

CMFOC414

CMFOC428

3 x 14w

4 x 14w

4 x 28w

LAMP TYPE

T5

T5

T5

PHOTOPIC

LUMENS

3660

4880

10,440

LENGTH

(mm)

595

595

1195

WIDTH

(mm)

595

595

595

DEPTH

(mm)

61

61

61

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

RECESSED LUMINAIRES

INDIRECT

KEY FEATURES:

• Body and side baffl es formed from 0.6mm trimmed sheet

steel

• Perforated baffl e

• White powder coated fi nish

• High Frequency gear as standard

• Dimmable versions available upon request

• Suitable for 15mm and 24mm T Bar

• Supplied complete with col 840 lamps

• Emergency versions available add EM to the part number

ITEM DETAILS:

PART NUMBER WATTAGE

CMFID240/P

CMFID255/P

CMFID214/P

CMFID224/P

2 x 40w

2 x 55w

2 x 14w

2 x 24w

LAMP TYPE

PLL

PLL

T5

T5

PHOTOPIC

LUMENS

7000

9700

2440

3520

LENGTH

(mm)

595

595

595

595

WIDTH

(mm)

595

595

595

595

DEPTH

(mm)

95

95

95

95

INDIRECT/DIRECT

KEY FEATURES:

• Body and side baffl es formed from 0.6mm trimmed sheet

steel

• Double parabolic louvre between perforated sheet steel

sections

• White powder coated fi nish

• High Frequency gear as standard

• Dimmable versions available upon request

• Suitable for 15mm and 24mm T Bar

• Double parabolic louvre

• Supplied complete with col 840 lamps

• Emergency versions available add EM to the part number

ITEM DETAILS:

PART NUMBER WATTAGE

CMFIC240/P

CMFIC255/P

CMFIC214/P

CMFIC224/P

2 x 40w

2 x 55w

2 x 14w

2 x 24w

LAMP TYPE

PLL

PLL

T5

T5

PHOTOPIC

LUMENS

7000

9700

2440

3520

LENGTH

(mm)

595

595

595

595

WIDTH

(mm)

595

595

595

595

Visit: www.dakal.co.uk Call Us: 01604 750098

DEPTH

(mm)

95

95

95

95

46

RECESSED LUMINAIRES

T8

KEY FEATURES:

• Body is formed from 0.6mm trimmed sheet steel

• White powder coated fi nish

• High Frequency gear as standard

• Dimmable versions available upon request

• Suitable for 15mm and 24mm T Bar

• Double parabolic louvre

• Supplied less lamps

• Emergency versions available add EM to the part number

ITEM DETAILS:

PART NUMBER

CMFC664/HF

CMFC1264/HF

WATTAGE

4 x 18w

4 x 36w

LAMP TYPE

T8

T8

PHOTOPIC

LUMENS

2700

5600

LENGTH

(mm)

595

1195

WIDTH

(mm)

595

595

DEPTH

(mm)

86

86

47

PRISMATIC

KEY FEATURES:

• Body is formed from 0.6mm trimmed sheet steel

• White powder coated fi nish

• High Frequency gear as standard

• Dimmable versions available upon request

• Prismatic diffuser supplied

• Suitable for 15mm and 24mm T Bar

• Emergency versions available add EM to the part number

ITEM DETAILS:

PART NUMBER

CMFP664/HF

CMFP414/HF

CMFP1264/HF

CMFP428/HF

WATTAGE

4 x 18w

4 x 14w

4 x 36w

4 x 28w

LAMP TYPE

T8

T5

T8

T5

PHOTOPIC

LUMENS

5400

4880

13,400

10,440

LENGTH

(mm)

595

1195

1195

1195

WIDTH

(mm)

595

595

595

595

DEPTH

(mm)

86

61

86

61

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

RECESSED LUMINAIRES

IP54

KEY FEATURES:

• Body is formed from 0.6mm trimmed sheet steel

• White powder coated fi nish

• High Frequency gear as standard

• Dimmable versions available upon request

• Prismatic diffuser supplied

• Suitable for 15mm and 24mm T Bar

• Fitting has IP54 polyurethane gasket

• Luminaire sealed to IP54

• Emergency versions available add EM to the part number

ITEM DETAILS:

PART NUMBER

CMRI414/HF/P

WATTAGE

4 x 14w

LAMP TYPE

T5

PHOTOPIC

LUMENS

4880

LENGTH

(mm)

595

WIDTH

(mm)

595

DEPTH

(mm)

92

IP65

KEY FEATURES:

• Body is formed from 0.6mm trimmed sheet steel

• White powder coated fi nish

• High Frequency gear as standard

• Dimmable versions available upon request

• Prismatic diffuser supplied

• Suitable for 15mm and 24mm T Bar

• Fitting has IP65 polyurethane gasket

• IP65 ( weather proof & dust proof )

• Emergency versions available add EM to the part number

ITEM DETAILS:

PART NUMBER

CMRI414/HF/P/IP65

WATTAGE

4 x 14w

LAMP TYPE

T5

PHOTOPIC

LUMENS

4880

LENGTH

(mm)

595

WIDTH

(mm)

595

DEPTH

(mm)

92

Visit: www.dakal.co.uk Call Us: 01604 750098

48

49

RETAIL DISPLAY LIGHTING

SURFACE

PROJECTOR

KEY FEATURES:

• Die cast aluminium white body

• Toughened front glass lens

• R7s double ended lamp holder

• IP20 rating

• 5A replaceable fuse fi tted

• Supplied complete with Lamp

• Barn doors available add BD to part number

ITEM DETAILS:

PART NUMBER

CDF70

CDF150

WATTAGE

70w

150w

LAMP TYPE

HQI R7s

HQI R7s

PHOTOPIC

LUMENS

4500

11,400

LENGTH

(mm)

245

245

WIDTH

(mm)

204

204

DEPTH

(mm)

98

98

CIRCULAR FIXED

KEY FEATURES:

• Die cast aluminium white body & bezel

• Gloss white powder coated fi nish

• Toughened front glass lens

• High quality aluminium refl ector

• IP20 rating

• Supplied with remote encapsulated gearbox

• Supplied complete with lamp

ITEM DETAILS:

PART NUMBER

DFC70

DFC150

WATTAGE

70w

150w

LAMP TYPE

HQI R7s

HQI R7s

PHOTOPIC

LUMENS

4500

11,400

DIAMETER

(mm)

229

229

DEPTH

(mm)

130

130

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

RETAIL DISPLAY LIGHTING

ROUND ADJUSTABLE

KEY FEATURES:

• Die cast aluminium white body

• Gloss white powder coated fi nish

• Toughened front glass lens

• High quality aluminium refl ector

• IP20 rating

• Adjustable to 45 °

• Supplied with remote encapsulated gearbox

• Supplied complete with G12 lamp

ITEM DETAILS:

PART NUMBER

DRCDM70

DRCDM150

WATTAGE

70w

150w

LAMP TYPE

HQI G12

HQI G12

PHOTOPIC

LUMENS

4500

11,400

DIAMETER

(mm)

170

170

DEPTH

(mm)

160

160

RECTANGULAR

ADJUSTABLE

KEY FEATURES:

• Die cast aluminium white body

• Gloss white powder coated fi nish

• Toughened front glass lens

• High quality aluminium refl ector

• IP20 rating

• Adjustable to 45 °

• Supplied with remote encapsulated gearbox

• Supplied complete with R7s lamp

ITEM DETAILS:

PART NUMBER

DFR70

DFR150

WATTAGE LAMP TYPE

70w

150w

HQI R7s

HQI R7s

PHOTOPIC

LUMENS

4500

11,400

LENGTH

(mm)

230

230

WIDTH

(mm)

143

143

DEPTH

(mm)

123

123

Visit: www.dakal.co.uk Call Us: 01604 750098

50

RETAIL DISPLAY LIGHTING

ASYMETRIC

WALL WASHER

KEY FEATURES:

• Sheet steel white body

• Gloss white powder coated fi nish

• Polished specular aluminium refl ector

• High Frequency gear as standard

• Supplied complete with col 840 lamp

• Emergency versions available add EM to the part number

ITEM DETAILS:

PART NUMBER

CMWW155

CMWW255

WATTAGE

1 x 55w

2 x 55w

LAMP TYPE

PLL

PLL

LENGTH

(mm)

595

1195

WIDTH

(mm)

295

295

LED WALL WASHER

KEY FEATURES:

• Sheet steel white body

• Gloss white powder coated fi nish

• Polished specular aluminium refl ector

• Fitted with branded driver and LED chips

DEPTH

(mm)

95

95

51

ITEM DETAILS:

PART NUMBER WATTAGE LAMP TYPE

CMWW133/LED

CMWW233/LED

1 x 33w

2 x 33w

LED

LED

PHOTOPIC

LUMENS

4170

8340

CRI

70

70

LENGTH

(mm)

595

1195

WIDTH

(mm)

295

295

DEPTH

(mm)

95

95

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

RETAIL DISPLAY LIGHTING

LED ROUND ADJUSTABLE

KEY FEATURES:

• Die cast aluminium white body

• Gloss white powder coated fi nish

• 4200k colour temperature

• Supplied complete with remote driver

• IP20 rating

• Adjustable to 45 °

• Supplied with remote LED driver

ITEM DETAILS:

PART NUMBER WATTAGE

DRCDM30/LED 30w

LAMP TYPE

LED

PHOTOPIC

LUMENS

1650

DIAMETER

(mm)

215

CUT OUT

(mm)

200

DEPTH

(mm)

175

LED RECTANGULAR

ADJUSTABLE

KEY FEATURES:

• Die cast aluminium white body

• Gloss white powder coated fi nish

• Front glass lens

• Supplied complete with remote driver

• 4200k colour temperature

• High quality aluminium refl ector

• IP20 rating

• Adjustable to 45 °

• Supplied with remote LED driver

ITEM DETAILS:

PART NUMBER

DFR30/LED

DFR45/LED

WATTAGE

30w

45w

LAMP TYPE

LED

LED

PHOTOPIC

LUMENS

1720

3825

DIAMETER

(mm)

215

215

DEPTH

(mm)

175

175

Visit: www.dakal.co.uk Call Us: 01604 750098

52

SURFACE & SUSPENDED LUMINAIRES

SURFACE

MODULAR T5 & T8

KEY FEATURES:

• Body is formed from 0.6mm sheet steel

• White powder coated fi nish

• Highly polished cat 2 louvre

• High Frequency gear as standard

• Dimmable versions available upon request

• Emergency versions available add EM to the part number

• Supplied less lamps

ITEM DETAILS:

PART NUMBER LAMP TYPE

CMSC664/HF

CMSC1232/HF

CMSC1532/HF

CMSC1832/HF

CMSC228

CMSC235

CMSC249

CMSC254

4 x18w T8

2 x 36w T8

2 x 58w T8

2 x 70w T8

2 x 28w T5

2 x 35w T5

2 x 49w T5

2 x 54w T5

PHOTOPIC

LUMENS

5400

6700

10,400

13,100

5220

6580

9800

9700

LENGTH

(mm)

604

1223

1522

1822

1223

1522

1522

1223

WIDTH

(MM)

611

304

304

304

304

304

304

304

DEPTH

(mm)

80

80

80

80

80

80

80

80

SURFACE LUMINAIRE T5

53

KEY FEATURES:

• Body formed from sheet steel

• IP44 rated

• Powder coated white fi nish

• Can be surface mounted or suspended

• Supplied less lamp

• Dimmable versions available upon request

• Emergency versions available add EM to the part number

• Microwave sensor available add PIR to part number

ITEM DETAILS:

PART NUMBER LAMP TYPE

GPH128

GPH135

GPH149

GPH154

GPH228

GPH235

GPH249

GPH254

1 x 28w T5

1 x 35w T5

1 x 49w T5

1 x 54w T5

2 x 28w T5

2 x 35w T5

2 x 49w T5

2 x 54w T5

PHOTOPIC

LUMENS

2610

3290

4900

4850

5220

6580

9800

9700

LENGTH

(mm)

1210

1510

1510

1210

1210

1510

1510

1210

WIDTH

(mm)

208

208

208

208

208

208

208

208

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

DEPTH

(mm)

70

70

70

70

70

70

70

70

SURFACE & SUSPENDED LUMINAIRES

INDIRECT SURFACE T5

KEY FEATURES:

• Body is formed from white stove enamelled steel

• Finished in white gloss powder coat

• Plastic end caps support a centrally mounted curved metal

diffuser

• Perforated diffuser supplied as standard

• Can be surface mounted or suspended

• Ideal for schools, hospitals and Universities

• Supplied less lamps

• Dimmable versions available upon request

• Emergency versions available add EM to the part number

ITEM DETAILS:

PART NUMBER LAMP TYPE

CY228

CY235

CY249

CY254

2 x 28w T5

2 x 35w T5

2 x 49w T5

2 x 54w T5

PHOTOPIC

LUMENS

5220

6580

9800

9700

LENGTH

(mm)

1212

1512

1512

1212

WIDTH

(mm)

100

100

100

100

DEPTH

(mm)

80

80

80

80

INDIRECT/DIRECT

SUSPENDED T5

KEY FEATURES:

• Body formed from aluminium

• Light grey powder coated fi nish

• Polished specular aluminium louvre

• Opal acrylic diffuser on rear of fi tting

• Supplied less lamp

• Supplied with 2 wire suspension kit

• Dimmable versions available upon request

• Emergency versions available add EM to the

part number

ITEM DETAILS:

PART NUMBER

DCL228

DCL235

DCL249

DCL254

LAMP TYPE

2 x 28w T5

2 x 35w T5

2 x 49w T5

2 x 54w T5

PHOTOPIC

LUMENS

5220

6580

9800

9700

LENGTH

(mm)

1192

1492

1492

1192

WIDTH

(MM)

278

278

278

278

DEPTH

(MM)

82

82

82

82

Visit: www.dakal.co.uk Call Us: 01604 750098

54

5934 ADVANCED LIGHTING DOUBLE PAGE SPREAD:Layout 1 17/04/2013 17:50 Page 1

Vacuum Formed Cover

l

Aesthetic Design l

Light Weight l

High Grade / High Heat ABS material l

Panel mount sensor option

Advanced Lighting

Components

from

VENTURE

L I G H T I N G

Reflector

l

Light Weight l

High Grade MIRO. 8510 l

Minimum Assembly Time l

Two Designs,

- Open Space = Symmetrical

- High Racking = Di Symmetrical

Jewel Reflector

l

95% LOR l

Highly Efficient Glass Reflector l

Optimised Optical Prisms l

Maximum Light Control l

Minimum Losses

Ventronic Integral Ballast

l

Exceptional long life l

Exceptional lumen maintenance l

Available in 70/100/150/200/250/320/350/400w l

Suitable for Highbays/Lowbays/Floodlights and Streetlights l

Protected Lamps available for open Fixtures l

All Lamps are compatible with both Standard and

Electronic Control Gear

Ventronic

Highbay POD

V

Integral Ballasts & Highbay POD

70%

energy saving, dimming and control

– Simple switch-dimming

– 1-10V variable dimming

Integral DALI

Compatible with all widely available sensors and controls

Highest performance Venture Pulse Start & Pulse Start

Sustainability MH Lamps

Highly efficient

Engineered, lightweight and compact unit

Stable operation

Smart and intelligent

– Thermal protection with dynamic circuit maintenance

– Fast and reliable protective lamp ignition; enhanced strike/ re-strike time

– Microprocessor control achieving highest levels of safety, performance and reliability

Longlife with extended life and warranty option available

venturelightingeurope.com

5934 ADVANCED LIGHTING DOUBLE PAGE SPREAD:Layout 1 17/04/2013 17:50 Page 1

Vacuum Formed Cover

l

Aesthetic Design l

Light Weight l

High Grade / High Heat ABS material l

Panel mount sensor option

Advanced Lighting

Components

from

VENTURE

L I G H T I N G

Reflector

l

Light Weight l

High Grade MIRO. 8510 l

Minimum Assembly Time l

Two Designs,

- Open Space = Symmetrical

- High Racking = Di Symmetrical

Jewel Reflector

l

95% LOR l

Highly Efficient Glass Reflector l

Optimised Optical Prisms l

Maximum Light Control l

Minimum Losses

Ventronic Integral Ballast

l

Exceptional long life l

Exceptional lumen maintenance l

Available in 70/100/150/200/250/320/350/400w l

Suitable for Highbays/Lowbays/Floodlights and Streetlights l

Protected Lamps available for open Fixtures l

All Lamps are compatible with both Standard and

Electronic Control Gear

Ventronic

Highbay POD

V

Integral Ballasts & Highbay POD

70%

energy saving, dimming and control

– Simple switch-dimming

– 1-10V variable dimming

Integral DALI

Compatible with all widely available sensors and controls

Highest performance Venture Pulse Start & Pulse Start

Sustainability MH Lamps

Highly efficient

Engineered, lightweight and compact unit

Stable operation

Smart and intelligent

– Thermal protection with dynamic circuit maintenance

– Fast and reliable protective lamp ignition; enhanced strike/ re-strike time

– Microprocessor control achieving highest levels of safety, performance and reliability

Longlife with extended life and warranty option available

venturelightingeurope.com

55

DIMMING GUIDE

Dimming a fluorescent lamp is different from a standard dimming circuit for GLS or Halogen Lamps.

All of the dimming is managed by the ballast, not by the amount of voltage fed into the fitting as is the case with a traditional dimmer switch.

Types of Dimming- Quick Guide

Split into two main categories

ANALOGUE - also known as 0-10v or 1-10v

Switch type: A potentiometer, rotary, slider, with a separate control for turning on/off

Advantages

• An older system which some contractors feel more comfortable with

• No interference with the switching of the luminaire.

Disadvantages

• A separate ‘dimming pair’ must be wired to each fitting in the circuit.

• Limited control options, i.e. working with further applications, such as

• Daylight linked dimming, or movement detectors.

DIGITAL - also known as touch dim, switch dim, DSI or DALI

Switch type: Bell push, push to make, retractive.

Advantages

• Simple installation, only a 4 core cable needed, as in an emergency lighting fitting, so sometimes no need to re-wire.

• Greater control over dimming, down to as low as 1%.

• Can be used in simple applications in conjunction with PIR’s and daylight sensors.

Disadvantages

• Interference can occur with switching, as control wire and switch wire run together.

Analogue Dimming

Analogue dimming is known as 1-10v dimming. This is because the dimmable ballast produces a 1-10v DC supply that can be increased or decreased by using a potentiometer (Also known as a high frequency push/rotary or slide dimmer switch).

The DC supply can be increased or decreased by the switch to affect the resistance, hence the dimness of the lamp. This form of dimming requires a ‘dimming pair ’of cables to be run around to each fitting in the circuit in order for it to operate.

Digital Dimming

Digital dimming can be split into 3 sub sections - Switch dim/Touch dim, DSI and DALI

Switch Dim/ Touch Dim

This is the most popular and simplest option for digital dimming. It is operated by a push to make or retractive switch, which is then wired to each luminaire in the circuit via a 4 core cable consisting of a switched live, (via a push to make) neutral, earth, and an un-switched live. The switch controls the switching on and off of the luminaire, and also the dimming.

Each push on the button sends a pulse to the ballast which then reads it and controls the lamp accordingly,

Long push / Hold down-Dim down/up - Short push- Turns lamp on off

DSI

DSI stands for Digital Series Interface, and is a more controllable version of digital dimming. It enables the user to group luminaires, operate daylight linked dimming and other controlling options. This is wired using a dimming pair, run to each luminaire in the circuit (similar to the analogue system). DSI is am Tridonic based technology, and can be set up with a variety of control options and controllers, some of which are offered by other manufacturers, designed purely to work with the DSI ballast. DSI ensures there are no issues with interface from the switching of the luminaire and the dimming of the luminaire which can affect switch on.

DALI

DALI stands for Digitally Addressable Lighting Interface. This is a uniform standard employed by all ballast manufacturers that offer DALI ballasts. This system assigns an individual address to each luminaire, i.e. 001, 002, 003 and so on, for the complete installation. These ballasts can then be controlled via their address. This means that scenes can be set, groups controlled, all this is achieved through a desktop PC. It can be manually over ridden at a wall switch, or can be used in conjunction with a daylight sensor, or a PIR. DALI can offer 2 way communications between the fitting and the controller, and includes invaluable information such as ballast run time and operating status.

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

NOTES

Visit: www.dakal.co.uk Call Us: 01604 750098

56

Key features

• mounting height

• for easy control and set up

• and in damp areas

Suitable with fluorescent,

CFL and LED lamps

Direct Dim (DD) and analogue dimming (AD)

Manufactured in the UK

EBMPIR-MB

Batten Mount PIR Detector

What it is

New from CP Electronics is a series of miniature PIR (passive infrared) presence detectors that have been specifically engineered for mounting directly onto a batten style luminaire.

The EBMPIR-MB series of batten mounting miniature PIR presence detectors provide automatic control of lighting loads, with optional manual control for easy management. Ideal for retrofit and for improving energy saving efficiency of existing installations, it is suitable for a wide range of applications such as storage rooms and exterior parking areas.

What it does

The EBMPIR-MB detects movement using a PIR detector and turns the load on. When an area is no longer occupied the load will switch off after an adjustable time-out period.

For easy control, it is fully programmable using an infrared programming handset (available separately). The EBMPIR-MB’s enhanced capabilities include the ability to program its settings without it needing removal or direct access to it.

These detectors are IP65 rated, making them suitable for both outdoor use and in damp areas.

A selection of fixing components are supplied to allow easy incorporation into a variety of luminaire styles.

The manufacturing default for the DD detectors is DALI.

Key features

• mounting height

• for easy control and set up

• and in damp areas

Suitable with fluorescent,

CFL and LED lamps

Direct Dim (DD) and analogue dimming (AD)

Manufactured in the UK

EBMPIR-MB

Batten Mount PIR Detector

What it is

New from CP Electronics is a series of miniature PIR (passive infrared) presence detectors that have been specifically engineered for mounting directly onto a batten style luminaire.

The EBMPIR-MB series of batten mounting miniature PIR presence detectors provide automatic control of lighting loads, with optional manual control for easy management. Ideal for retrofit and for improving energy saving efficiency of existing installations, it is suitable for a wide range of applications such as storage rooms and exterior parking areas.

What it does

The EBMPIR-MB detects movement using a PIR detector and turns the load on. When an area is no longer occupied the load will switch off after an adjustable time-out period.

For easy control, it is fully programmable using an infrared programming handset (available separately). The EBMPIR-MB’s enhanced capabilities include the ability to program its settings without it needing removal or direct access to it.

These detectors are IP65 rated, making them suitable for both outdoor use and in damp areas.

A selection of fixing components are supplied to allow easy incorporation into a variety of luminaire styles.

The manufacturing default for the DD detectors is DALI.

57

GLOSSARY

TERM

Lumens

DESCRIPTION

The amount of light emitted from a light source ( lamp ).

Luminaire Lumens

Lux

DLOR

The total amount of light coming from a luminaire. This figure can be significantly lower than the total light emitted by the lamps.

For building control purposes, the total circuit watts are divided into the luminaire lumens to give luminaire lumens per watt.

The amount of light falling onto a surface.

Downward Light ratio. The percentage of light coming from a luminaire below the horizontal plane.

ULOR Upward Light ratio. The percentage of light coming from a luminaire above the horizontal plane.

Luminaire Efficiency

LG7

Halo phosphate

Triphosphor

T5, T8 & T12

The amount of light coming from a luminaire divided by the total lamp lumens. The is shown as a percentage.

The standard to which most rooms are designed. In the case of an LG7 compliant luminaire, the standard relates to the louvre design.

The fluorescent tube coating which converts invisible UV into useable light.

These phosphors were banned by the EU in 2010.

Normally a triple coating of rare earth phosphors. These are up to 15% more efficient than halophosphates.

This relates to the tube diameter in 8ths of an inch. Continental sizes are T16, T25 and T38 respectively. T12 lamps have been banned by the EU with the exception of 8ft which is unique to the UK.

SS

HF

QS

Switch Start Gear. This is the cheapest form of circuitry comprising of a conventional wire wound ballast and starter switch. Not recommended in the building regulations due to high circuit losses.

High Frequency. Although it has been around since the early 1960’s it is the most energy efficient form of powering a lamp. There is no flicker from the lamps and no wire wound components to generate heat.

Quick Start. A now obsolete form of circuitry still found in some older installations.

SRS Semi Resonant Start. A now obsolete from of circuitry still found in some older installations.

LED

H.I.D

Kelvin's

CRI

Light Emitting Diode.

High Intensity Discharge.

Colour Temperature.

Colour Rendering Index.

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

2

3

4

0

1

5

6

7

8

5

6

3

4

0

1

2

IP RATINGS

The International Protection code, commonly known as the Ingress Protection code (IP) indicates the protection afforded by an enclosure against the ingress of foreign (solid) bodies and ingress of moisture and liquids. The IP rating also classifies the protection given by an enclosure against touching live or moving parts.

The IP rating is given by the use of two numbers:

First Digit

Protection Against Ingress of Solid Objects

No protection

Protection against large sized bodies such as hands

Protection against medium sized bodies such as fingers

Protection against small sized bodies 2.5mm dia. or larger such as tools & wires

Protection against very small sized bodies 1mm dia. or greater

Protection against harmful deposits of dust. (Dust proof)

Complete protection against deposits of dust. (Dust tight)

Second Digit

Protection Against Ingress of Liquids

No protection

Protection against vertically falling drops of water

Protection against drops of water up to 15º from the vertical

Protection against rain falling up to 60º from the vertical

Protection against splashed water from any angle

Protection against jets of water from any angle

Protection against water from heavy seas

Protection against immersionW for a defined period

Protection against immersion for an indefinite period

Visit: www.dakal.co.uk Call Us: 01604 750098

58

EXTERIOR FLOODLIGHTING CALCULATION together with the anticipated Lux level. For larger areas or higher Lux levels, increase the number of floodlights accordingly.

Watts Mounting

Height

Area Covered

(Sq. M)

Ave. Lux Max Distance

Between Poles

Max Throw

70w HQI

70w SON

5m

5m

225

225

8

10

15m

15m

15m

15m

150w HQI

150w SON

250w HQI

250w SON

5-6m

5-6m

6-8m

6-8m

225-324

225-324

324-576

324-576

20-14

25-18

23-13

33-18

15-18m

15-18m

18-24m

18-24m

15-18m

15-18m

18-24m

18-24m

400w HQI

400w SON

8-10m

8-10m

576-900

576-900

24-15

34-21

24-30m

24-30m

24-30m

24-30m

59

“The information relating to lighting applications etc. is for guidance purposes and is only intended to give a general idea.

Dakal cannot be held responsible for any incorrect lighting levels or non compliance with current regulations resulting from use of the examples.

You are strongly recommended to enlist the help of the Dakal Lighting Design Service to ensure complete compliance with lighting levels, regulations etc.”

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

LED LAMP COMPARISON

LED

Wattage

35

70

140

210

224

7

9

13

Lumen

Output

800

1100

1600

2500

5000

10000

15000

20000

Lumens

Per Watt

71

71

71

71

89

114

122

123

Nearest

Conventional

Lamp

TC-D

T5

TC-D

T5

TC-L

SON

SON

HQI

Wattage

28

55

100

150

250

13

14

26

Lumen

Output

900

1230

1710

2640

4850

10000

15000

19000

Lumens

Per Watt

94

88

100

100

76

69

88

66

TYPICAL ELECTRICAL DATA FOR DISCHARGE LUMINAIRES

Total Circuit

Watts

Starting

Current

Running

Current

Fusie Rating

(amps)

HBC/MBC

MBF

250 watt

400 watt

275

430

2.2

4.0

1.3

2.2

10

16

HQI

70 watt

150 watt

250 watt

400 watt

1000 watt 415v

1000 watt 240v

86

172

288

430

1050

1080

0.4

0.8

1.5

3.7

5.2

9.5

0.3

0.8

1.3

2.0

3.1

5.5

10

16

4

4

16

20

SON

50 watt

70 watt

150 watt

250 watt

400 watt

62

86

172

280

432

0.4

0.6

0.7

1.5

3.0

0.3

0.4

0.8

1.3

2.2

4

4

4

10

16

“The information relating to lighting applications etc. is for guidance purposes and is only intended to give a general idea.

Dakal cannot be held responsible for any incorrect lighting levels or non compliance with current regulations resulting from use of the examples.

You are strongly recommended to enlist the help of the Dakal Lighting Design Service to ensure complete compliance with lighting levels, regulations etc.”

Visit: www.dakal.co.uk Call Us: 01604 750098

60

61

Lamp Type

SON RX 7S



T/H





TC-TEL





TC-L







PL-T







SON











HQI



MBF/U



HQI G12



W

T8 HALO







T8 TRIPHOSPHOR













2D





T5









USEFUL LAMP INFORMATION

Watts

Lumens

Per Watt

81

88

88

75

N/A

75

74

19

69

67

69

97

100

17

17

56

60

79

73

64

76

76

85



84

97

110

125

94

100

77

66

87

73

93

90

73

75

71

75

93

90

94

61

78

78

80

Initial

Lumens

2900

3500

4850

6000

N/A

4300

5200

6800

15000

2600

5000

9500

900

1200

1800



5900

14500

27500

50000

4500

11400

18900

34000

14000

24000

5500

11000

1220

1760

2610

4850

3290

4900

6160

1050

1350

3350

5200

6550

1100

2800

4500

5600

2050

2850

3900

CRI

Group

1B

1B

1B

1B

N/A

1B

1B

1A

1B

1B

1B

1A

1A

4

4

1B

1B

3

3

2

2

1B

1B



4

4

4

4

1B

1B

1B

1B

1B

1B

1B

1B

1B

1B

1B

1B

1B

1B

1B

3

3

3

3

80

42

57

70

36

40

55

500

13

18

26

70

150

150

300

250

400

70

150

70

150

250

400



70

150

250

400

35

49

80

16

14

24

28

54

28

38

55

18

36

58

70

18

36

58

70

Colour

Temp

Deg Kelvin



3000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

N/A

3000-4000

3000-4000

2700-4000

2700-4000

2700-4000

2700-4000

4000

4000

4000

4000

2000

2000

2850

2900

2000

2000

2000

2000

4000

4000

4000

4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

3000-4000

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

Length

(Nominal)

500

600

600





600













































549

549

1149

1149

1449

1449

1449









600

1200

1500

1800

600

1200

1500

1800

Average

Life

10000

10000

10000

10000

N/A

N/A

N/A

6000

6000

2000

2000

2000

10000

10000

10000



24000

24000

24000

24000

6000

6000

10000

20000

24000

24000

6000

6000

16000

18000

16000

18000

16000

18000

18000

10000

9000

9000

9000

9000

15000

15000

15000

15000

10000

10000

10000

LAMP COLOURATIONS

Lamp Type

HQI / MBI

SON

MBFU

Description

Metal Halide

Sodium

Mercury

COLOUR TEMPERATURES

Colour Reference

830

840

865

Colour Temperature

3000 k

4000 k

6500 k

LAMP CAPS

Lamp Cap

E14

E27

E40

B15D

B22D

B22D-3

R7S

GX5.3

GX4

Colour

White Light

Orange Light

White Light

Colour

Warm White

Cool White

Daylight

Description

SES ( Small Edison Screw )

SES ( Small Edison Screw )

GES ( Giant Edison Screw )

Small Bayonet Cap

Bayonet Cap

Bayonet Cap 3 Pin

Linear Tungsten Halogen

2 Pin Halogen 5.3mm between pins

2 Pin Halogen 4.0mm between pins

Visit: www.dakal.co.uk Call Us: 01604 750098

62

63

TERMS & CONDITIONS

1. Interpretation

1.1 In these Terms:

“BUYER” means the person who accepts the Seller’s Written quotation for the sale of the Goods or whose Written order for the Goods is accepted by the Seller;

“GOODS” means the goods (including any instalment of the goods or any parts for them) which the Seller is to supply in accordance with these Terms;

“SELLER” means Dakal Limited (registered in under number 03080267);

“CONTRACT” means the contract for the sale and purchase of the Goods;

“INCOTERMS” means the international rules for the interpretation of trade terms of the International Chamber of Commerce as in force at the date when the Contract is made;

“TERMS” means the standard terms of sale set out in this document and (unless the context otherwise requires) includes any special terms agreed in Writing between the Buyer and the Seller;

“WRITING”, and any similar expression, includes facsimile transmission but not electronic mail or other forms of electronic

communication.

1.2

1.3

A reference in these Terms to a provision of a statute shall be construed as a reference to that provision as amended, re-enacted or extended at the relevant time.

The headings in these Terms are for convenience only and shall not affect their interpretation.

2. Basis of the sale

2.1 The Seller shall sell and the Buyer shall purchase the Goods in accordance with the Seller’s Written quotation (if accepted by the Buyer), or the Buyer’s Written order

(if accepted by the Seller), subject in either case to these Terms, which shall govern the Contract to the exclusion of any other terms subject to which any such quotation is accepted or purported to be accepted, or any such order is made or

2.2 purported to be made, by the Buyer.

No variation to these Terms shall be binding unless agreed in Writing between the authorised representatives of the Buyer and the Seller.

2.3 The Seller’s employees or agents are not authorised to make any representations concerning the Goods unless confirmed by the Seller in Writing. In entering into the

Contract the Buyer acknowledges that it does not rely on any such representations which are not so confirmed, but nothing in these Terms affects the liability of either party for fraudulent misrepresentation.

2.4 Any advice or recommendation given by the Seller or its employees or agents to the Buyer or its employees or agents as to the storage, application or use of the

Goods which is not confirmed in Writing by the Seller is followed or acted upon entirely at the Buyer’s own risk, and accordingly the Seller shall not be liable for any such advice or recommendation which is not so confirmed.

2.5 Any typographical, clerical or other error or omission in any sales literature, quotation, price list, acceptance of offer, invoice or other document or information issued by the Seller shall be subject to correction without any liability on the part of the Seller.

3. Orders and specifications

3.1

3.2 giving the Seller any necessary

3.3

No order submitted by the Buyer shall be deemed to be accepted by the Seller unless and until confirmed in Writing by the Seller’s authorised representative.

The Buyer shall be responsible to the Seller for ensuring the accuracy of the terms of any order (including any applicable specification) submitted by the Buyer, and for

The quantity, quality and description of the Goods and any specification for them shall be as set out in the Seller’s quotation (if accepted by the Buyer) or the Buyer’s order (if accepted by the Seller).

information relating to the Goods within a sufficient time to enable the Seller to perform the Contract in accordance with its terms.

3.4 If the Goods are to be manufactured or any process is to be applied to the Goods by the Seller in accordance with a specification

submitted by the Buyer, the Buyer shall indemnify the Seller against all loss, damages, costs and expenses awarded against or incurred by the Seller in connection with, or paid or agreed to be paid by the Seller in settlement of, any claim for infringement of any patent, copyright, design, trade mark or other industrial or intellectual property rights of any other person which results from the Seller’s use of the Buyer’s specification.

3.5 The Seller reserves the right to make any changes in the specification of the Goods which are required to conform with any applicable statutory or E.U. requirements or, where the Goods are to be supplied to

3.6 indemnify the Seller in full against all loss the Seller’s specification, which do not materially affect their quality or performance.

No order which has been accepted by the Seller may be cancelled by the Buyer except with the agreement in Writing of the Seller and on terms that the Buyer shall

(including loss of profit), costs (including the cost of all labour and materials used), damages, charges and expenses incurred by the Seller as a result of cancellation.

3.7 The buyer’s written order must always state list numbers.

4. Price of the goods

4.1 The price of the Goods shall be the Seller’s quoted price or, where no price has been quoted (or a quoted price is no longer valid), the price listed in the Seller’s published price list current at the date of

Buyer.

4.2 acceptance of the order. Where the Goods are supplied for export from the United Kingdom, the Seller’s published export price list shall apply. All prices quoted are valid for 30 days only or until earlier acceptance by the Buyer, after which time they may be altered by the Seller without giving notice to the

The Seller reserves the right, by giving Written notice to the Buyer at any time before delivery, to increase the price of the Goods to reflect any increase in the cost to the Seller which is due to any factor beyond the control of the Seller (such as, without limitation, any foreign exchange fluctuation, currency regulation, alteration of duties, significant increase in the costs of labour, materials or other costs of manufacture), any change in delivery dates, quantities or specifications for the Goods which is requested by the Buyer, or any delay caused by any instructions of the Buyer or failure of the Buyer to give the Seller adequate information or

instructions.

4.3 Except as otherwise stated in the Seller’s Written quotation or in any price list of the Seller, and unless otherwise agreed in Writing between the Buyer and the Seller, all prices are given by the Seller on an ex works basis, and where the Seller agrees to deliver the Goods otherwise than at the Seller’s premises, the Buyer shall be liable to pay the Seller’s charges for transport, packaging and insurance. Please note that any order with a nett value of less than ££200 will incur a minimum carriage charge of ££12 (this charge may be subject to alteration at the time of order).

4.4

4.5

The price is exclusive of any applicable value added tax, which the Buyer shall be additionally liable to pay to the Seller.

The cost of pallets and returnable containers will be charged to the Buyer in addition to the price of the Goods, but full credit will be given to the Buyer

provided they are returned undamaged to the Seller before the due payment date.

5. Terms of payment

5.1 Subject to any special terms agreed in Writing between the Buyer and the Seller, the Seller may invoice the Buyer for the price of the Goods on or at any time after delivery of the Goods, unless the Goods are tendered delivery of the Goods.

5.2 to be collected by the Buyer or the Buyer wrongfully fails to take delivery of the Goods, in which event the Seller shall be entitled to invoice the Buyer for the price at any time after the Seller has notified the Buyer that the Goods are ready for collection or (as the case may be) the Seller has

The Buyer shall pay the price of the Goods within 30 days of the end of the month in which the Goods are invoiced, and the Seller shall be entitled to recover the price, notwithstanding that delivery may not have taken place and the property in the Goods has not passed to the Buyer. The time of payment of the price shall be of the essence of the Contract. Receipts for payment will be issued only upon request.

5.3

5.3.1

If the Buyer fails to make any payment on the due date then, without limiting any other right or remedy available to the Seller, the Seller may: cancel the contract or suspend any further deliveries to the Buyer;

5.3.2 appropriate any payment made by the Buyer to such of the Goods (or the goods supplied under any other contract between the Buyer and the Seller) as the Seller may think fit (notwithstanding any purported

5.3.3 to time, until payment in full is made (a appropriation by the Buyer); and charge the Buyer interest (both before and after any judgment) on the amount unpaid, at the rate of 6 per cent per annum above Bank of England base rate from time part of a month being treated as a full month for the purpose of calculating interest).

6. Delivery

6.1 Delivery of the Goods shall be made by the Buyer collecting the Goods at the Seller’s premises at any time after the Seller has notified the Buyer that the Goods are ready for collection or, if some other place

6.2 delivery shall not be of the essence of the for delivery is agreed by the Seller, by the Seller delivering the Goods to that place.

Any dates quoted for delivery of the Goods are approximate only and the Seller shall not be liable for any delay in delivery of the Goods however caused. Time for

Contract unless previously agreed by the Seller in Writing. The Goods may be delivered by the Seller in advance of the quoted delivery date on giving reasonable notice to the Buyer.

6.3 Where the Goods are to be delivered in instalments, each delivery shall constitute a separate contract and failure by the Seller to deliver any one or more of the instalments in accordance with these Terms or any claim by the Buyer in respect of any one or more instalments shall not entitle the Buyer to treat the Contract as a whole as repudiated.

6.4 If the Seller fails to deliver the Goods (or any instalment) for any reason other than any cause beyond the Seller’s reasonable control or the Buyer’s fault, and the Seller is accordingly liable to the Buyer, the Seller’s liability shall be limited to the excess (if any) of the cost to the Buyer (in the cheapest available market) of similar goods to replace those not delivered over the price of the Goods.

6.5 If the Buyer fails to take delivery of the Goods or fails to give the Seller adequate delivery instructions at the time stated for delivery (otherwise than by reason of any cause beyond the Buyer’s reasonable control or by reason of the Seller’s fault) then, without limiting any other right or remedy available to the Seller, the Seller may:

6.5.1

6.5.2 store the Goods until actual delivery and charge the Buyer for the reasonable costs (including insurance) of storage; or sell the Goods at the best price readily obtainable and (after deducting all reasonable storage and selling expenses) account to the Buyer for the excess over the price under the Contract or charge the Buyer for any shortfall below the price under the Contract.

7. Risk and property

7.1

7.1.1

7.1.2 time when the Seller has tendered delivery

7.2

7.2.1

Risk of damage to or loss of the Goods shall pass to the Buyer: in the case of Goods to be delivered at the Seller’s premises, at the time when the Seller notifies the Buyer that the Goods are available for collection; or in the case of Goods to be delivered otherwise than at the Seller’s premises, at the time of delivery or, if the Buyer wrongfully fails to take delivery of the Goods, the which payment is then due.

of the Goods.

Notwithstanding delivery and the passing of risk in the Goods, or any other provision of these Terms, the property in the Goods

Buyer until the Seller has received in cash or cleared funds payment in full of the price of the Goods and all other goods agreed to be sold by the Seller to the Buyer for

Until such time as the property in the Goods passes to the Buyer, the Buyer shall hold the Goods as the Seller’s fiduciary agent shall not pass to the and bailee, and shall keep the Goods separate from those of the Buyer and third parties and properly stored, protected and

insured and identified as the Seller’s property, but the Buyer may resell or use the Goods in the ordinary course of its business.

7.2.2 Until such time as the property in the Goods passes to the Buyer (and provided the Goods are still in existence and have not been any time require the Buyer to deliver up the Goods to the Seller and, if the Buyer fails to do so forthwith, resold), the Seller may at enter on any premises of the Buyer or any third party where the

Goods are stored and repossess the Goods.

7.3 The Buyer shall not be entitled to pledge or in any way charge by way of security for any indebtedness any of the Goods which remain the property of the

Seller, but if the Buyer does so all moneys owing by the Buyer to the Seller shall (without limiting any other right or remedy of the Seller) forthwith become due and payable.

Buy Now Online: www.dakal.co.uk Call Us: 01604 750098

TERMS & CONDITIONS

8. Warranties and liability

8.1

8.2

8.2.1

8.2.2

Subject to the following provisions the Seller warrants that the Goods will correspond with their specification at the time of delivery and will be free from defects in material and workmanship for a period of 12 months from the date of their initial use or 12 months from delivery, whichever is the first to expire.

The above warranty is given by the Seller subject to the following conditions: the Seller shall be under no liability in respect of any defect in the Goods arising from any drawing, design or specification supplied by the Buyer; the Seller shall be under no liability in respect of any defect arising from fair wear and tear, wilful damage, negligence, abnormal working conditions, failure to follow the

Seller’s instructions (whether oral or in

8.2.3 due date for payment;

Writing), misuse or alteration or repair of the Goods without the Seller’s approval; the Seller shall be under no liability under the above warranty (or any other warranty, condition or guarantee) if the total price for the Goods has not been paid by the

8.2.4

8.3 the above warranty does not extend to parts, materials or equipment not manufactured by the Seller, in respect of which the Buyer shall only be entitled to the benefit of any such warranty or guarantee as is given by the manufacturer to the Seller.

Subject as expressly provided in these Terms, and except where the Goods are sold to a person dealing as a consumer (within the meaning of the Unfair Contract

Terms Act 1977), all warranties, conditions or other terms implied by statute or common law are excluded to the fullest extent permitted by law.

Where the Goods are sold under a consumer transaction (as defined by the Consumer Transactions (Restrictions on Statements) Order 1976) the statutory rights of 8.4 the Buyer are not affected by these Terms.

8.5 A claim by the Buyer which is based on any defect in the quality or condition of the Goods or their failure to correspond with specification shall (whether or not delivery is refused by the Buyer) be notified to the Seller within seven days from the date of delivery or (where the defect or failure was not apparent on reasonable inspection) within a reasonable time after discovery of the defect or failure. If delivery is not refused, and the Buyer does not notify the Seller accordingly, the Buyer shall not be entitled to reject the Goods and the Seller shall have no liability for such defect or failure, and the Buyer shall be bound to pay the price as if the Goods had been delivered in accordance with the Contract.

8.6 Where a valid claim in respect of any of the Goods which is based on a defect in the quality or condition of the Goods or their failure to meet specification is notified to the Seller in accordance with these Terms, the Seller may replace the Goods (or the part in question) free of charge or, at the Seller’s sole discretion, refund to the

Buyer the price of the Goods (or a proportionate part of the price), in which case the Seller shall have no further liability to the Buyer.

Except in respect of death or personal injury caused by the Seller’s negligence, or liability for defective products under the Consumer Protection Act 1987, the Seller 8.7 shall not be liable to the Buyer by reason of any representation (unless fraudulent), or any implied warranty, condition or other term, or any duty at common law, or under the express terms of the Contract, for loss of profit or for any indirect, special or consequential loss or damage, costs, expenses or other claims for compensation whatsoever (whether caused by the negligence of the Seller, its employees or agents or otherwise) which arise out of or in connection with the supply of the Goods (including of the Seller any delay in supplying or any failure to supply the Goods in accordance with the Contract or at all) or their use or resale by the Buyer, and the entire liability under or in connection with the Contract shall not exceed the price of the Goods, except as expressly provided in these Terms.

8.8 The Seller shall not be liable to the Buyer or be deemed to be in breach of the Contract by reason of any delay in performing, or any failure to perform, any of the

Seller’s obligations in relation to the Goods, if the delay or failure was due to any cause beyond the Seller’s reasonable control. Without limiting the foregoing, the following shall be regarded as causes beyond the Seller’s reasonable control:

8.8.1

8.8.2

8.8.3

8.8.4

8.8.5

8.8.6

8.8.7

Act of God, explosion, flood, tempest, fire or accident; war or threat of war, sabotage, insurrection, civil disturbance or requisition; acts, restrictions, regulations, bye-laws, prohibitions or measures of any kind on the part of any governmental, parliamentary or local authority; import or export regulations or embargoes; strikes, lock-outs or other industrial actions or trade disputes (whether involving employees of the Seller or of a third party); difficulties in obtaining raw materials, labour, fuel, parts or machinery; power failure or breakdown in machinery.

9. Indemnity

9.1 intellectual property rights of any other person, then unless the claim arises from the use of a drawing, design or specification supplied by the Buyer, the Seller shall indemnify the

Buyer against all loss, damages, costs and expenses awarded against or settlement of the claim, provided that:

9.1.1

9.1.2

9.1.3 except pursuant to a final award, the Buyer shall not pay or accept the claim, or compromise any such proceedings without the consent of the Seller (which shall not be unreasonably withheld);

9.1.4 indemnity shall not apply to the extent

9.1.5

If a claim is made against the Buyer that the Goods infringe or that their use or resale infringes the patent, copyright, design, trade mark or other industrial or the Seller is given full control of any proceedings or negotiations in connection with the claim; the Buyer shall give the Seller all reasonable assistance for the purposes of any such proceedings or negotiations; the Buyer shall do nothing which would or might vitiate any policy of insurance or insurance cover which the Buyer may have in relation to such infringement, and this the Seller shall be entitled to the benefit of, and the Buyer shall accordingly account to the Seller for, all damages and costs (if any) awarded in favour of the Buyer which are payable by, or agreed with the claim; and

9.1.6 incurred by the Buyer in connection with the claim, or paid or agreed to be paid by the Buyer in that the Buyer recovers any sums under any such policy or cover (which the Buyer shall use its best endeavours to do); consent of the Buyer (which consent shall not be unreasonably withheld) to be paid by, any other party in respect of any such without limiting any duty of the Buyer at common law, the Seller may require the Buyer to take such steps as the Seller may reasonably require to mitigate or reduce any such loss, damages, costs or ex penses for which the Seller is liable to indemnify the Buyer under this clause.

10. Insolvency of buyer

10.1

10.1.1

(within the meaning of the Insolvency Act 1986); or

10.1.2

10.1.3

10.1.4

10.2

This clause 10 applies if: the Buyer makes a composition or voluntary arrangement with its creditors or (being an individual or firm) becomes bankrupt or (being a company) enters administration or goes into liquidation (otherwise than an encumbrancer takes possession, or a receiver is appointed, of any of the property or assets of the Buyer; or the Buyer ceases, or threatens to cease, to carry on business; or the Seller reasonably apprehends that any of the events mentioned above is about to occur in relation to the Buyer and notifies the Buyer accordingly.

If this clause applies then, without limiting any other right or remedy available to the Seller, the Seller may cancel the Contract or suspend any further deliveries under the Contract without any liability to the Buyer, and if the Goods have been delivered but not paid for the price shall become immediately due and payable notwithstanding any previous agreement or arrangement to the contrary.

for the purposes of amalgamation or reconstruction), or a moratorium comes into force in respect of the Buyer

11. Export terms

12. Unless the context otherwise requires, any term or expression which is defined in or given a particular meaning by the provisions of Incoterms shall have the same meaning in these Terms, but if there is any

12.1

Buyer and the Seller) apply not conflict between the provisions of Incoterms and these Terms, the latter shall prevail.

Where the Goods are supplied for export from the United Kingdom, the provisions of this clause 11 shall (subject to any special terms agreed in Writing between the

12.2 payment of any duties on them.

withstanding any other provision of these Terms.

The Buyer shall be responsible for complying with any legislation or regulations governing the importation of the Goods into the country of destination and for the

12.3 obligation to give notice under section

12.4

Unless otherwise agreed in Writing between the Buyer and the Seller, the Goods shall be delivered fob the air or sea port of shipment and the Seller shall be under no

32(3) of the Sale of Goods Act 1979.

The Buyer shall be responsible for arranging for testing and inspection of the Goods at the Seller’s premises before shipment. The Seller shall have no liability for any claim in respect of any defect in the Goods which would be apparent on inspection and which is made after shipment, or in respect of any damage during transit.

12.5 Unless otherwise required by the Seller, payment of all amounts due to the Seller shall be made by irrevocable letter of credit, in a form acceptable to the Seller, to be opened by the Buyer in favour of the Seller and confirmed by a bank in the United Kingdom acceptable to the Seller within 14 days after the Contract is concluded.

13. General

13.1 A notice required or permitted to be given by either party to the other under these Terms shall be in Writing addressed to that other party at its registered office or principal place of business or such other

13.2

13.3 of the Contract and the remainder of the

13.4 address as may at the relevant time have been notified pursuant to this provision to the party giving the notice.

No waiver by the Seller of any breach of the Contract by the Buyer shall be considered as a waiver of any subsequent breach of the same or any other provision.

If any provision of the Contract is held by a court or other competent authority to be invalid or unenforceable in whole or in part the validity of the other provisions provision in question shall not be affected.

The Contract shall be governed by the laws of England, and the Buyer agrees to submit to the non-exclusive jurisdiction of the English courts.

14. WEEE Regulations

‘WEEE’ means waste electrical and electronic equipment as defined in the WEEE Regulations. ‘WEEE Regulation’ means The Waste Electrical and Electronic Regulations 2006 (SI

2006/3289).

14.1

14.1.1

The Customer shall: be responsible for financing the collection, treatment, recovery and environmentally sound disposal of:

14.1.1.1 all WEEE arising or deriving from the products; and

14.1.1.2 all WEEE arising or deriving from products placed on the market prior to 13 August 2005 where such products are to be replaced by the products and the products are of an equivalent type or are fulfilling the

14.1.2 and same function as that of such products.

comply with all additional obligations placed upon the customer by the WEEE Regulations by virtue of the customer accepting responsibility set out in clause 14.1.1

14.1.3 provide the customer’s WEEE compliance scheme operator with such data, documents, information and other assistance as such scheme operator may from time to time reasonably require to enable such

14.2

14.3 operator to satisfy the obligations assumed by it as result of the Sellers membership of the operators compliance scheme.

The customer shall be responsible for all costs and expenses arising from and relating to its obligations in clause 14.1.

Further information in respect of the arrangements set out in clause 14.1 can be found at www.electrolink.eu.com by clicking on the button and quoting WEEE registration number [WEEE/JH0060TU] where prompted.

‘WEEE FINAL USERS’

Visit: www.dakal.co.uk Call Us: 01604 750098

64

Dakal Ltd

Web: www.dakal.co.uk

Call: 01604 750098 Email: [email protected]

Unit 4 | Stour Road | Off Ross Road | Northampton | NN5 5AA

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
