CONTROL REFERENCE GUIDE
IMPORTANT SAFETY
INSTRUCTIONS
C. Using the Built-in Battery
1.
2.
3.
4.
5.
6.
7.
Portable cart warning
13. Unplug this apparatus during lightning storms or when unused for long
periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
DISC FORMATS
The unit can playback
Audio CDs
[8cm/12cm disc]
DVDs
[8cm/12cm disc]
Compatible
AC power
1 To
outlet
AC power
adapter
Region Management Information: This unit is designed and manufactured to respond to the
Region Management Information that is encoded on DVDs. If the region number printed on the
DVD does not correspond to the region number of this unit, it cannot play that disc.
1)
2)
3)
4)
LCD Screen
DC IN 9V - 12V Jack
AUDIO / VIDEO OUT Jacks
CHARGE / STANDBY(power off) / ON
Switch
5) VOLUME Control
Adjusts the volume.
6) Headphone Jack
7) Cursor ( , , , ) Buttons
Highlights selections on a menu screen
and adjusts certain settings.
PLAY Button
Starts or resumes playback of a disc.
Confirms selections on a menu screen.
STOP Button
Stops playing a disc.
PAUSE Button
Pauses playback of a disc. Each time you
press the
PAUSE button the picture
advances one frame on a DVD. Press the
PLAY button to resume playback.
SEARCH Button
Press to perform fast reverse playback on
a DVD.
Press and hold to perform fast reverse
playback on an Audio CD.
SEARCH Button
Press to perform fast forward playback on
a DVD.
Press and hold to perform fast forward
playback on an Audio CD.
PREV Button
Press to go back to the previous chapters
on a DVD.
Disc Function or Operation that is Not Available
When the
symbol appears on the screen, it indicates that the function or operation
attempted is not available at that time. This occurs because the DVD manufacturer determines
the specific functions of DVDs. Certain functions may not be available on some DVDs. Be sure
to read the documentation provided with the DVD.
Language selections for audio
Language selections for subtitles
Screen aspect ratio
Multiple camera angles
Region code indicator
1
Note: When playing back a CD-G (Graphics) or CD EXTRA disc, the audio portion will be
played, but the graphic images will not be shown.
9)
10)
11)
12)
1. Slide the CHARGE / STANDBY / ON switch on the left side of the unit to the ON position.
See CUSTOMIZING THE FUNCTION SETTINGS before proceeding to step 2.
2. Slide the open knob rightwards to open the disc door.
3. Hold the disc by its sides and carefully place it onto the spindle
with the label side facing up, pushing gently until you hear a “click”.
4. Gently push the disc door closed. It takes a short while for your
unit to load the disc. After loading, for most DVDs, the unit will
automatically start playing or take you to the main menu.
5. If the unit does not automatically start playing the DVD, press the
PLAY button.
To DC IN
9V - 12V jack
Recharging
is completed
the switch
3 Slide
to CHARGE
5 when charging
light goes out
4 Charging
light ON
Pausing Playback (Still Mode)
•
•
•
•
Warnings:
The built-in battery can only be recharged when the unit is in CHARGE mode while using
the AC adapter.
The built-in battery cannot be recharged when the unit is in power ON mode.
Do NOT recharge the built-in battery in a vehicle using the car power adapter.
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
Notes:
• When the built-in battery power is low, "Battery Low" will display on the screen and the unit
will stop playing.
• Recharge the built-in battery when you are ready to use it again.
• While using the built-in battery, the environmental temperature should be 41°F (5°C) to 95°F (35°C).
• To get the longest service life of the built-in battery, charge at indoor-temperature.
• The built-in battery in this device may present a risk of fire or chemical burn if mistreated.
Do not disassemble, heat above 212oF (100oC), or incinerate.
• The unit should not be exposed to excessive heat such as sunshine, fire or the like.
• When discarding the unit, environmental problems must be considered and local rules or
laws governing the disposal of such products must be strictly followed.
Turning on the Unit
1. Slide the CHARGE / STANDBY / ON switch on the left side of the unit
to the ON position.
LEFT SIDE OF UNIT
A. Using the AC Power Adapter
• DVDs are divided into “titles” and “chapters”.
If the disc has more than one movie on it, each
movie would be a separate “title”. “Chapters” are
sections of titles.
• Audio CDs are divided into “tracks”. A “track” is
usually one song on an Audio CD.
Title1
Chapter1
Chapter2
Chapter3
Chapter1
2
AC Power Adapter
To DC IN 9V - 12V Jack
If your TV has Audio/Video inputs, you can connect the unit to your TV using a standard Audio/
Video cables (not included).
LEFT SIDE OF UNIT
Cautions:
• The AC power adapter included with this unit is for its use only. Do not use it with other
equipment.
• When the unit is not going to be used for long time, disconnect the AC power adapter
from the AC power outlet.
• When the AC power adapter is plugged in, the apparatus is not completely disconnected
from the main power supply, even when the power is turned off.
Warning:
The AC power adapter is used as disconnect device and it should remain readily operable
during intended used. In order to disconnect the apparatus from the mains completely, the
AC power adapter should be disconnected from the mains socket outlet completely.
Track1
Track2
Track3
Track4
Track5
Notes on Unauthorized Discs
You may not be able to play some DVDs on this unit, particularly if they were purchased from
outside your geographic area or made for business purposes.
ACCESSORIES
Please check and identify the supplied accessories.
• To order accessories visit website http://www.venturer.com
AC Power Adapter ........................................................................................................ x 1
Car Power Adapter........................................................................................................ x 1
Fast Forward / Fast Reverse
1. Press the SEARCH
or
SEARCH button when a DVD is playing. Each time you press
the SEARCH
or
SEARCH button, the playback speed changes in the following
sequence: (For an Audio CD, press and hold the SEARCH
or
SEARCH button to
perform fast forward/reverse.)
2x
2. Press the
4x
8x
2x
16 x
4x
8x
16 x
PLAY button when you reach the desired point to resume normal playback.
Notes:
• The DVD player mutes sound and subtitles during reverse and forward scan of DVDs.
• The fast playback speed may differ depending on the disc.
Press the
NEXT button to advance chapters on a DVD.
Press and hold the
NEXT button to skip to the next tracks on an Audio CD.
Press the
PREV button to go back to the previous chapters on a DVD.
PREV button to skip to the previous tracks on an Audio CD.
Press and hold the
Car Power Adapter
Audio 1/3:Dolby D 2ch English
White Red Yellow
To AUDIO / VIDEO
OUT Jacks
Audio / Video Cable
(not included)
Watching a DVD on your TV
TV
WARNING:
Disconnect
the car power
adapter when
not in use. Not
for use in 24V
vehicles.
Subtitle Selection
B. Using Headphones
1. While a DVD is playing, press the SUBTITLE button to display the current language setting,
as shown in the example.
Caution:
Avoid listening to sound at levels which
may be harmful to your ears.
E-3
Subtitle 02/03:Spanish
2. Press the SUBTITLE button repeatedly to select the desired subtitle language. You can turn
subtitles off by pressing the SUBTITLE button repeatedly until “ Subtitle Off ” is displayed.
Headphones
(3.5mm diameter plug)
Dolby Digital
Dolby Digital is a technology developed by Dolby Laboratories. Soundtracks encoded in Dolby
Digital can reproduce from one to 5.1 discrete channels of excellent quality audio.
The unit automatically recognizes the Dolby Digital bitstream and provides a downmix suitable
for two-channel listening. An additional Dolby Digital decoder is required for reproduction of the
discrete multi-channel soundtracks available on many DVDs.
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
E-4
DVD
LEFT SIDE OF UNIT
SOUND SYSTEM
Cautions:
• Use the provided 12V car power adapter only. Use with other car power adapters could
damage the unit.
• The 12V car power adapter included with this unit is for its use only. Do not use it with
other equipment.
• In the interest of traffic safety, do not operate this unit or view videos while driving a vehicle.
• Make sure the unit is securely fastened to prevent it from falling or flying through the air in
the event of an accident.
• When the inside of the cigarette lighter socket is dirty with ashes or dust, the plug section may
become hot due to poor contact. Be sure to clean the cigarette lighter socket before use.
• After use, disconnect the 12V car power adapter from both the unit and cigarette lighter socket.
Notes:
• If only one audio format is recorded on the DVD, the number does not change.
• Some DVDs allow you to change audio selections via the disc menu only. If this is the case,
press the MENU button and choose the appropriate language on the disc menu.
• You can select different audio channels (Stereo, Mono Left, Mono Right or Mix-Mono) on an
Audio CD by pressing the AUDIO button repeatedly.
1. Turn on the unit.
2. Turn on the TV and follow the instructions included with it to play the DVD.
• When headphones are connected, no sound
will be emitted from the unit's speaker.
2 To DC IN 9V - 12V Jack
On some DVDs, the sound is recorded in two or more formats. Follow the directions below to
select the preferred language and sound system.
1. While a disc is playing, press the AUDIO button to show the current audio format number.
2. Press the AUDIO button repeatedly to select the desired audio format.
• Turn down the volume before connecting, and
then adjust the level.
To Cigarette
Lighter Socket
Note: Numbers identify each title, chapter, and track on a disc. Most discs have these numbers
recorded on them, but some do not.
E-2
LEFT SIDE OF UNIT
1
Chapter2
Press the STOP button at the location where you want to interrupt playback. To resume
playback at the position where the disc was stopped, press the
PLAY button.
If you press the
STOP button twice, the unit’s memory will be cleared and pressing the
PLAY button will reset the DVD to the beginning.
Audio Selection
A. Connecting a TV
The 12V car power adapter allows the unit to be
used with vehicles that have a 12V, negative ground
electrical system.
Title2
Stopping Playback
CONNECTIONS
To AC
Power
Outlet
B. Using the Car Power Adapter
Title, Chapter and Tracks
Press the PAUSE button. To resume normal playback, press the
PLAY button.
Each time you press the PAUSE button, the picture advances one frame on a DVD.
Skip (Forward / Reverse)
2. The DVD logo (start-up picture) will appear on the screen.
3. After use, slide the CHARGE / STANDBY / ON switch to the STANDBY (power off) position.
White Red Yellow
Sample lcons
8)
Press and hold to skip to the previous
tracks/JPG pictures on an Audio CD/
JPG disc.
NEXT Button
Press to advance chapters on a DVD.
Press and hold to skip to the next
tracks/JPG pictures on an Audio CD/
JPG disc.
Disc Door
Close tray by pushing the disc door.
Open Knob
Power ON Indicator
CHARGING Indicator
Charge the rechargeable battery before
using it for the first time. The normal
charging time should be completed in
approximately 4-5 hours. The charging
light will go out when the batter y
becomes fully charged.
SETUP Button
Opens and closes the SETUP menu
while in stop mode.
Adjusts Brightness, Panel Display or
Contrast of the LCD screen while in
playback mode.
AUDIO Button
Selects one of the audio sound tracks
programmed on a DVD or selects the
audio output mode on an Audio CD.
SUBTITLE Button
Selects one of the subtitle languages
programmed on a DVD.
MENU Button
Opens and closes the DVD menu.
POWER SUPPLY
The supplied AC power
adapter operates on
AC 120V.
The region number of this unit is 1.
Playing a Disc
2
Region Management Information
Icons Used on DVDs
This owner’s manual explains the basic instructions for operating this unit. Some
DVDs are produced in a manner that allows specific or limited operation during
playback. Therefore, this unit may not respond to all operating commands. THIS IS
NOT A DEFECT. Please refer to the instructions accompanying the specific DVD in
question for more information about the options available on that DVD.
” may appear on the screen during operation. A “
” means that the desired
“
operation is not permitted by the unit or disc.
To Recharge the Built-in Battery
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with a dry cloth.
Do not block the ventilation openings. Install in accordance with the
manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding - type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
PLAYING A DISC
The unit has a built-in, non-replaceable, rechargeable battery. Charge the built-in battery before
using it for the first time. The normal charging time should be completed within 4-5 hours. The
charging light will go out when the built-in battery becomes fully charged.
Notes:
• Some DVDs are set to display subtitles automatically, and you cannot turn them off even if
you set the subtitle function to off.
• During some scenes, the subtitles may not appear immediately after you select your desired
scene.
• The number of subtitle languages recorded differs depending on the disc. If only one
language is recorded, the language does not change.
• This function can only be used for discs on which subtitles have been recorded in multiple
languages.
• Some DVDs allow you to change subtitles via the disc menu only. If this is the case, press
the MENU button and choose the appropriate subtitle on the disc menu.
Adjust the LCD Screen
You can adjust the Brightness, Panel Display or Contrast of the LCD screen in playback mode.
1. Press the SETUP button in playback mode.
2. Press the / button to select Brightness, Panel Display or Contrast.
3. Then press the / button to change the setting.
4. Press the SETUP button to exit the menu.
E-5
TV Display
VIEWING JPG FILES
This unit can play JPG files recorded on a CD-R or CD-ROM disc (CD-RW is not recommended).
Viewing JPG Files
1. Slide the open knob rightwards to open
the disc door.
2. Hold a JPG file disc by its edges and
gently push it onto the spindle with the
label side facing up until you hear a “click”.
3. Close the disc door. The JPG files on
the disc will be displayed one by one
automatically.
4. Press the
STOP button to display a
folder list. Press the
or
button to
highlight a JPG file to play. Press the
PLAY button to start playback.
00:00 00:00
001/035
\
DSCN0281
DSCN0282
DSCN0283
DSCN0284
DSCN0285
DSCN0286
Notes:
• You can press the
PAUSE button to freeze the picture. Press the
PLAY button to
resume picture slide show.
• You can press the STOP button to quit playback.
PREV or
NEXT button to change the picture.
• You can press and hold the
• You can press the Cursor buttons ( , , , ) to rotate direction of the picture by 90o.
• Some discs may not permit this operation.
Pan Scan
• When wide-screen video is played, this mode clips the right and left
sides of the image so that it can be viewed on a conventional screen.
• Some wide-screen DVDs that do not permit Pan Scan mode playback
are automatically played in letterbox mode (black bands that appear
at the top and bottom of the screen).
Letter Box
• When wide-screen video is played in this mode on a conventional
screen, black bands appear at the top and bottom of the screen.
Wide Screen
• This is the correct mode for playing wide-screen videos on the unit
screen or other external wide-screens.
Notes:
• The displayable picture size is preset on the DVD. Therefore the playback
picture of some DVDs may not conform to the picture size selected.
• When you play DVDs recorded in the 4:3 aspect ratio, the playback
picture will always appear in the 4:3 aspect ratio regardless of the TV
display setting.
• Select Wide Screen to conform the LCD screen on the unit. Always
be sure that your TV display conforms to the actual TV in use if you
connect the unit to a TV.
Cut off when a
wide-screen video
image is played.
LIMITED WARRANTY
VENTURER ELECTRONICS ("VENTURER") makes the following limited warranty. This limited
warranty extends to the original consumer purchaser and is limited to non-commercial use of
the product.
Pan Scan
Letter Box
Wide Screen
Default
7” PORTABLE DVD
PLAYER
Ninety (90) Day Parts & Labor Warranty
VENTURER products purchased in the United States are warranted to be free from defects in
materials or workmanship for a period of ninety (90) days from the date of their original retail
purchase. If the unit fails to conform to this warranty, we will service the product using new or
refurbished parts and products, at VENTURER's sole discretion.
During a period of ninety (90) days from the effective warranty date, Venturer will provide,
when needed, service labor to repair a manufacturing defect at its designated Service Center.
To obtain warranty service in the United States, you must first call our Customer Support
Center at 1-866-444-6478 or 1-800-252-6123, during the hours listed in the box below.
The determination of service will be made by VENTURER Customer Support. PLEASE DO
NOT RETURN YOUR UNIT TO VENTURER WITHOUT PRIOR AUTHORIZATION. New
or remanufactured replacements for defective parts or products will be used for repairs by
Venturer at its designated Service Center for ninety (90) days from the effective warranty date.
Such replacement parts or products are warranted for an additional ninety (90) days from the
date of repair or replacement. The Customer will be required to ship the unit to the Service
Center indicated at the time Customer Support is contacted to make the necessary repairs.
The customer is responsible for all transportation charges to the service facility.
PVS8370
OWNER’S MANUAL
SAFETY PRECAUTIONS
It takes 3-5 seconds to reset the DVD settings to the factory default.
Packaging and Shipping Instruction
When you send the product to the Venturer service facility you must use the original carton box
and packing material or an equivalent as designated by VENTURER.
CUSTOMIZING THE FUNCTION SETTINGS
MAINTENANCE
Language Setup
1. Press the SETUP button in stop mode.
2. Press the
button to select Language
Setup Page.
3. Press the
/
button to select the
option (OSD Language, Audio, Subtitle
or Disc Menu), then press the button.
4. Press the
/
button to select your
preferred language, then press the
PLAY button to confirm.
5. Repeat steps 3 and 4 to adjust other
options. Press the
button to return to
the previous menu.
6. Press the SETUP button to exit the menu.
Video
Language
System
- - Language Setup Page - OSD Language
Audio
Subtitle
Disc Menu
Eng
Eng
Off
Eng
Go To Language Setup Page
LIMITED WARRANTY
Cleaning the Disc
A defective or soiled disc inserted into the unit can cause sound to drop out during playback.
Handle the disc by holding its inner and outer edges.
• Do NOT touch the surface of the unlabeled side of the disc.
• Do NOT stick paper or tape on the surface.
• Do NOT expose the disc to direct sunlight or excessive heat.
• Clean the disc before playback. Wipe the disc from the center outward
with a cleaning cloth.
• NEVER use solvents such as benzine or alcohol to clean the disc.
• Do NOT use irregular shaped discs (example: heart shaped, octagonal, etc.). They may
cause malfunctions.
Cleaning the Unit
Notes:
• Some DVDs may not play in the audio language selected. A prior language may be
programmed on the disc.
• Some DVDs may be set to display subtitles in a language other than the one you selected.
A prior subtitle language may be programmed on the disc.
• Some DVDs allow you to change subtitle selections using the disc menu only. If this is
the case, press the MENU button and choose the appropriate subtitle language from the
selection on the disc menu.
• Some DVDs may not include your pre-selected language. In this case, the DVD player
automatically displays disc menus consistent with the disc's initial language setting.
• Be sure to turn the unit off and disconnect the AC power adapter before maintaining the unit.
• Wipe the unit with a dry soft cloth. If the surfaces are extremely dirty, wipe clean with a cloth
that has been dipped in a weak soap-and-water solution and wrung out thoroughly, then
wipe with a dry cloth.
• Never use alcohol, benzine, thinner, cleaning fluid or other chemicals. Do NOT use
compressed air to remove dust.
Important Note
Before transporting the unit, remove the disc from the disc compartment.
TROUBLESHOOTING GUIDE
Video Setup
1. Press the SETUP button in stop mode.
button to select Video
2. Press the
/
Setup Page.
3. Press the
/
button to select the
option (Brightness or Contrast), then
press the button.
4. Press the
/
button to adjust the
setting, then press the
PLAY button
to confirm.
5. Repeat steps 3 and 4 to adjust other
options. Press the
button to return to
the previous menu.
6. Press the SETUP button to exit the menu.
Video
Language
System
- - Video Setup Page - Brightness
Contrast
00
00
CAUSE (AND REMEDY)
No power.
• Ensure the AC power adapter is connected.
• The unit is not turned on.
No sound or only
a ver y low-level
sound is heard.
Go To Video Setup Page
No picture.
System Setup
1. Press the SETUP button in stop mode.
2. Press the
/
button to select System
Page.
3. Press the
/
button to select the
option (TV Display or Default), then press
the button.
4. Press the
/
button to adjust the
settings, then press the
PLAY button
to confirm.
5. Repeat steps 3 and 4 to adjust other
options. Press the
button to return to
the previous menu.
6. Press the SETUP button to exit the menu.
SYMPTOM
Language
Video
- - System Page - Tv Display
Default
Wide
No
• Make sure that you select ON mode.
• The system is in pause mode. Press the
PLAY button to return to
normal play mode.
• The unit is in fast-forward or fast-reverse mode. Press the
PLAY
button to return to normal play mode.
• Make sure the AUDIO/VIDEO output connections are correct.
• The DTS DVD disc cannot be decoded to have speaker output.
• The unit is too hot; shut off the unit for 30 minutes to cool it down.
• The region number of the disc doesn't match the region number of this
unit.
Your Responsibility
(1) You must retain the original sales receipt to provide proof of purchase.
(2) These warranties are effective only if the product is purchased and operated in the U.S.A.
or Canada.
(3) Warranties extend only to defects in material or workmanship, and do not extend to any
product or parts which have been lost or discarded, or damage to product or parts caused
by misuse, accident, improper operation or maintenance, or use in violation of instructions
provided with the product, or to product which has been altered or modified without
authorization of VENTURER, or to products or parts thereof which have had the serial
number removed or changed.
The picture is not
clear.
• Clean the disc.
• The disc is scratched.
• Please adjust the LCD's brightness and contrast using the SETUP
button on the panel.
S ev e r e h u m o r
noise is heard.
• The plugs and jacks are dir ty. Wipe them with a cloth slightly
moistened with alcohol.
• Clean the disc.
The disc does not
play.
•
•
•
•
•
In the event your product requires repair after the limited warranty period has expired,
please contact our Customer Support Center at 1-866-444-6478, 1-800-252-6123 or
www.venturer.com.
Hours: Monday-Thursday: 9-7, Friday: 9-5, Saturday: 9-12 EST.
Important:
You are responsible for any transportation, shipping or insurance relative to the return of
product to our Product Returns Center.
All warranties implied by state law, including the implied warranties of merchantability and
fitness for a particular purpose, are expressly limited to the duration of the limited warranties
set forth above. With the exception of any warranties implied by state law as hereby limited, the
foregoing warranty is exclusive and in lieu of all other warranties, guarantees, agreements and
similar obligations of manufacturer or seller with respect to the repair or replacement of any
parts. In no event shall VENTURER be liable for consequential or incidental damages.
No person, agent, distributor, dealer or company is authorized to change, modify or extend
the terms of these warranties in any manner whatsoever. The time within action must be
commenced to enforce any obligation of VENTURER arising under the warranty or under any
statute, or law of the United States or any state thereof, is hereby limited to ninety (90) days
from the date of purchase. This limitation does not apply to implied warranties arising under
state law.
This warranty gives you specific legal rights and you may also have other rights, which
may vary, from state to state. Some states do not allow limitation on how long an implied
warranty lasts, when an action may be brought, or the exclusion or limitation of incidental or
consequential damages, so the above provisions may not apply to you.
For more information on other products and services, please visit our web site at
Important: Also keep your "Bill of Sale" as proof of purchase.
Serial no........................................................ Invoice no. ......................................................
Date purchased ............................................ Dealer name ..................................................
Go To System Page
There is no disc inside. (“No Disc” appears on the screen).
Insert the disc correctly with the playback side facing down.
Clean the disc.
The unit and disc region number are incompatible.
Condensation may have formed inside the unit due to a sudden
change in temperature. Wait about an hour for it to clear and try again.
The exclamation point within the
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in this owner’s manual.
CAUTION
INVISIBLE LASER RADIATION
* SEE BOTTOM OF UNIT FOR GRAPHIC SYMBOLS *
This product
contains a low
power laser device.
WHEN OPEN.
AVOID EXPOSURE TO BEAM.
THIS CLASS B DIGITAL APPARATUS
COMPLIES WITH CANADIAN ICES-003.
On Placement
Out of Warranty
www.venturer.com
System
The lightning flash with an arrowhead
symbol, within the equilateral triangle,
is intended to alert the user to the
presence of uninsulated "dangerous
voltage" within the product's enclosure that may be
of sufficient magnitude to cause an electric shock.
WARNING: TO REDUCE THE RISK
OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
WA R N I N G : TO P R E V E N T F I R E O R
SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
DO NOT PLACE OBJECTS FILLED WITH
LIQUIDS ON OR NEAR THIS UNIT.
C AU T I O N : U S E O F C O N T RO L S O R
ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE
SPECIFIED MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
CAUTION: DANGER OF EXPLOSION IF
BATTERY IS INCORRECTLY REPLACED.
REPLACE ONLY WITH THE SAME OR
EQUIVALENT TYPE.
• Do not use the unit in places that are extremely hot, cold, dusty, or humid.
• Place the unit on a flat and even surface.
• Do not restrict the air flow of the unit by placing it in a place with poor air flow, by covering it
with a cloth, or by placing it on carpeting.
• To avoid magnetized, do not place the unit near speaker or magnet.
• Do not use this unit in direct sunlight or leave the unit in a closed automobile (or yacht, etc)
where it would be exposed to high temperatures above 104°F (40°C).
• No naked flame sources such as lighted candles should be placed on the AC power adapter
and main unit.
• The apparatus shall not be exposed to dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on apparatus.
On Safety
• When connecting or disconnecting the AC power adapter, grip the plug and not the cord
itself. Pulling the cord may damage it and create a hazard.
• When you are not going to use the unit for a long period of time, disconnect the AC power adapter.
On Condensation
• When left in a heated room where it is warm and damp, water droplets or condensation may
form inside the unit. When there is condensation inside the unit, the unit may not function
normally. Let the unit stand for 1 to 2 hours before turning the power on, or gradually heat
the room and allow the unit to dry before use.
Ventilation Warning
• Do not block the ventilation openings or holes. (If the ventilation openings or holes are
blocked by a newspaper or cloth, etc., the heat may not be able to get out.)
• Do not operate the unit in a confined space, such as a bookcase or built-in cabinet, allow
about 4 inch (10cm) of free space all around the unit for adequate ventilation.
Rating Plate Location
• The rating plate is located on the bottom of unit.
FCC Statements
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
FOR SERVICE AND REPAIR, PLEASE VISIT www.venturer.com
WARNING: Should any trouble occur, disconnect the AC power adapter and refer
servicing to a qualified technician.
Specifications and external appearance are subject to change without notice.
Notes on Copyright
It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, or rent
copyrighted material without permission.
Apparatus Claims of U.S. Patent Nos. 6,836,549; 6,381,747; 7,050,698; 6,516,132 and 5,583,936
licensed for limited viewing uses only.
This product incorporates copyright protection technology that is protected by U.S. patents
and other intellectual property rights. Use of this copyright protection technology must be
authorized by Macrovision, and is intended for home and other limited viewing uses only
unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
E-6
E-7
Printed in China
811-837091W040
E-1

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
