Save energy with unparalleled total home control

HomeWorks

®

QS

HomeWorks has been the leader in light control for exclusive homes for over a decade. And now, we’ve taken that light control to a new level— total home control. This level of control includes lights, shades, HVAC, sensors, and appliances and incorporates a variety of new products, such as sensors, a temperature control, and a dynamic keypad.

HomeWorks QS offers

increased energy savings

, is a

more powerful system

, is

easier to install

, and provides

greater integration capabilities

than before. With HomeWorks QS, you can offer your customers a system that works harder and smarter to bring energy savings to their homes without having to sacrifice comfort and convenience.

The New York Times Building uses Quantum and saves over

70% light energy.

The power of Quantum

®

Quantum was developed to meet the challenges of creating systems that can scale to accommodate thousands of lighting zones and thousands of shades in buildings that are often in use 24 hours a day.

Using the Quantum architecture in HomeWorks

®

QS provides for powerful control over daylight and electric light, from small systems through large applications.

The new architecture provides large-scale processing power and easier communications wiring, along with powerful design, programming, and documentation software to make your project workflow easier and faster.

Lutron

|

01

HomeWorks

®

Energy-saving features

QS

Every time you dim your lights you save energy. Dim them by 25%, for example, and you’ll save 20% energy. The more you dim, the more you save. While a HomeWorks QS system provides the energy-saving benefits of dimming, it also provides other energy-saving benefits, too.

Occupied: On Vacant: Off

Occupancy sensing

Sensors turn off the lights when the room is empty and can

save up to 20%

lighting energy.

Full On Dim

Energy-efficient light control

Lutron leads the industry in control of high-efficacy light sources, including LED and fluorescent.

Our Hi-lume

®

A-Series LED driver provides the ultimate dimming performance for LED fixtures from popular OEM fixture brands.

Raise Temp Lower Temp

Temperature control

The perfect complement to light and shade control, temperature control gives you the ability to adjust heating and cooling systems any time of day. This can

save up to 16%

or more on heating and cooling costs.

Appliance On Appliance Off

Appliance control

Save energy by turning off standby power to A/V equipment and computers—via keypads, sensors, or the system timeclock. Standby power can amount to

10% of a typical

home’s electricity use.

02

|

Lutron

Shade Open Shade Closed kWh kWh

More Energy Less Energy

Shades

In summer, close shades to block the sun, which will reduce cooling costs. In winter, open shades to let daylight warm your home—then close them in the evening to retain the heat. Doing so can

save 10%

on heating and cooling costs.

“Green” button

Use the “green” button to save energy by controlling lights, shades and temperature with a single touch.

7am: Off 7pm: Dim

Scheduling

The timeclock can be programmed to automatically dim or turn off lights in spaces where lights are often inadvertently left on.

Scene 1

All Off

Lights On

Scene 1

All Off

All Lights Off

“All Off’ button

Place a keypad with an “All Off” button near an entry to conveniently turn off all of the lights throughout the home with a single touch.

Lutron

|

03

HomeWorks

®

System architecture

QS

Supports 100 devices/100 zones per link

Maestro

® dimmer keypad seeTemp

™ thermostat seeTouch

® keypads keypad

GRAFIK Eye

® and receiver (right)

04

|

Lutron

Plug-in dimming module

Plug-in appliance module

Pico

® wireless control

Sivoia

®

QS Wireless shades (right)

Radio Powr Savr

™ occupancy/vacancy sensor (left), daylight sensor (middle), and temperature sensor (right)

Pico

® wireless control

Home network

First Floor

Current Temperature

FFF

FFF iPhone

®

/iPod touch

®

/iPad

®

app

FFF

FFF

QS link devices

Supports 100 devices/

512 zones per link

Flexible wiring topology

24 V DC power seeTouch

®

keypad

GRAFIK Eye

®

System capacities:

100

devices per link

2

links per processor

16

processors per system

1,500

wireless devices

10,000

zones total

Panels

Supports HomeWorks

®

RPM and spec grade panels

Uses existing module interface

Supports 16 panels/

256 zones per link

Remote power panel (right) interface interface Sivoia

®

QS shades (right)

Lutron

|

05

HomeWorks

®

Sensors

QS

Radio Powr Savr

occupancy/vacancy sensor

Occupancy/vacancy sensors are ideal for laundry rooms, bathrooms, walk-in closets, and other rooms where lights are often inadvertently left on. By turning lights off automatically you can save up to 20% of the energy used.

Reliable Clear Connect

RF technology ensures consistent performance, while XCT

technology enhances the sensor’s ability to detect fine motions—such as reading— so occupants aren’t left in the dark.

Radio Powr Savr daylight sensor

You can use these wireless sensors to provide the perfect balance of daylight and electric light, based on available light in a space.

Radio Powr Savr sensors are battery powered and wireless, so they are easy to place in the space, and can be repositioned if needed.

06

|

Lutron

Temperature control

seeTemp thermostat and matching wallplate shown in Satin Colors

®

mocha stone

Remote temperature sensors allow the temperature to be measured in the optimum location.

seeTemp

, remote temperature sensor, and HVAC controller

seeTemp puts temperature control where it makes sense for you in an easy to use, aesthetically pleasing design.

Simple user interface

seeTemp, sensor, and HVAC controller communicate via Clear Connect

RF Technology

The HVAC controller connects to the mechanical equipment using standard thermostat wiring

Simply push the “eco” button to set back the temperature and save energy

seeTemp control can be mounted in locations which would not normally be appropriate for a thermostat, such as exterior walls and sunny locations

Designer opening allows you to easily gang seeTemp with other designer opening products

Lutron

|

07

HomeWorks

®

Dynamic keypad

QS

room or an entire home.

08

|

Lutron

Use individual pages for simple control of lighting, shades, and temperature in rooms throughout your home

Create or modify on-screen button labels easily

Three hard buttons provide instant access to frequently used lighting functions

QS wired communication or Clear Connect

RF technology ensures reliable system control

Keypad is 5

1

8

" high × 2

3

8

" wide; the profile is ¹∕

2

" off the wall

Hybrid seeTouch

®

keypad

Hybrid seeTouch is a keypad in one unit.

Hybrid seeTouch keypad

The new hybrid seeTouch keypad offers the popular seeTouch user interface with built-in dimming capability to power the existing lighting load. This control is perfect for retrofit applications where a single-gang switch controls lighting in a space.

A keypad button controls the attached load, and raise/lower allows control of the light level.

Hybrid seeTouch is available to control:

Incandescent/MLV

The hybrid seeTouch keypad is available in

20 Satin Colors

®

and 7 designer gloss finishes.

Lutron

|

09

HomeWorks

®

seeTouch

®

keypads

QS

Designer seeTouch keypad in midnight with a stainless steel wallplate

Available button configurations

All configurations are available in Architectural keypads with insert, Architectural keypads without an insert (shown below), and Designer keypads.

seeTouch keypads

seeTouch keypads offer intuitive control of lights and shades at the touch of a button.

Backlit, custom engraving ensures your client can easily see the function of each button.

Status LEDs are now inside the buttons, combining status and control.

Button kits are offered in multiple configurations to meet your client’s needs.

without insert (left) and with insert (right) with insert

10

|

Lutron

Maestro

®

controls

Dimmer and matching wallplate shown in Satin Colors

®

merlot

Left to right:

Non-dimmable switch and table lamp dimmer

Maestro dimmers, switches, and fan controls

The popular Maestro aesthetic remains a staple of the HomeWorks

®

QS offering. Its sleek, modern design makes it a perfect addition to any home.

Available as a dimmer, switch, and tabletop lamp dimmer, the Maestro aesthetic can be used throughout the home, in any space.

Maestro is available to control:

Incandescent/MLV

LED

Fluorescent

The Maestro designer opening allows it to coordinate with a wide selection of Satin Colors and designer gloss controls and accessories.

Maestro controls are available in 20 Satin Colors and 7 designer gloss finishes.

ELV

Switched loads

Lutron

|

11

HomeWorks

®

Pico

®

wireless controls

QS

Pico controls on pedestal

(single and dual pedestals available)

Pico wireless control

The versatile Pico wireless control can function as a lightweight handheld remote, a stylish tabletop control, or a wall-mounted keypad within a Lutron

®

Claro

®

designer faceplate.

Pico can be installed to provide 3-way functionality wherever control of lights or shades is desired, without wiring.

This control is offered in 6 designer gloss colors to coordinate with any décor. A tabletop pedestal allows Pico to be conveniently located by your bedside or on a countertop.

12

|

Lutron

Plug-in devices

Plug-in dimming module

Lamp dimmers

Tabletop lamp dimmers and plug-in dimming modules allow you to easily control table and floor lamps. The tabletop lamp dimmer was designed for local on/off and raise/lower control. The plug-in dimming module can be used if no local control is required.

Plug-in appliance module

The plug-in appliance module allows for switching control of appliances and other non-lighting loads. Used with appliances such as printers, monitors, and A/V equipment, it receives commands from sensors or keypads to conveniently save energy by turning off standby power.

Lutron

|

13

HomeWorks

®

GRAFIK Eye

®

QS

QS

Dedicated shade buttons on the front of the unit offer an easy way to adjust up to three groups of shades.

GRAFIK Eye QS

HomeWorks QS brings the power of GRAFIK Eye QS—the world standard for light control in a room—to residential systems applications.

With GRAFIK Eye QS, the user can control multiple lights and shades, creating just the right mood for any activity.

GRAFIK Eye has long been the benchmark for home theater control, but it’s also perfect for rooms with multiple lights where the user wants to create different scenes, such as in the kitchen, dining room, or master suite.

Main units use wireless communication for easy installation.

Wired communication can be used for new construction or major renovation.

14

|

Lutron

Remote system monitoring and control

Poconos Home

Change

Next Event Away, 8:00

AM

First Floor

Current Temperature

68

FFF

FFF

70

FFF

FFF

Remote system monitoring and control

Lutron

®

applications for mobile devices give you the ability to control and monitor your HomeWorks

®

QS system right from your mobile device—at home or while away. Use the iPhone

®

/iPod touch

®

Lutron

Home Control app to control and monitor lights, shades and keypads.

Full two-way functionality allows the app to update in real time as you

67

68

F

F change the lights in the space.

Schedules

Setpoint

Settings

Current Temperature

Second Floor

The Lutron Home Control app for the iPad

®

provides more information and control than the iPhone or iPod touch. Using the iPad, your client can adjust scenes, time clock and thermostat programming himself, as well as save energy using new features like the “Green” button.

iPhone, iPod touch, and iPad are registered trademarks of Apple

®

, Inc., registered in the U.S. and other countries.

68

70

F

F

Lutron

|

15

HomeWorks

®

Sivoia

®

QS shades

QS

16

|

Lutron

Sivoia

®

QS shades

The new generation of Lutron

®

precision-controlled window treatments is called Sivoia QS. All Sivoia

QS shades can be wired or wireless.

Sivoia QS shade drives use only four conductors instead of seven and have a smaller cable diameter, making it easier to route in new construction or renovation projects.

All options include:

drapery system

Lutron

|

17

HomeWorks

®

Sivoia

®

QS shades

QS

NEW Venetian blinds with Intelligent

Tilt Alignment

technology

Venetian blinds are an attractive and effective way to ensure privacy, while still allowing sunlight to filter a space. Only Lutron

®

Venetians with Intelligent Tilt

Alignment can offer precision alignment of both tilt and lift position between multiple shades for the finest aesthetic. Create the right light in a space with the ability to smoothly control tilt independent of lift or by simply recalling a favorite preset.

Available in over 60 colors; custom matching also available.

Kirbe

vertical drapery system

An industry first, the Kirbé vertical drapery system smoothly pulls fabric up and completely out of the way. The unique design of the Kirbé provides greater access to windows and views by eliminating stack back—the mass of fabric that gathers as traditional draperies are opened.

18

|

Lutron

Roman shades with CERUS

safety technology

Lutron has revolutionized the design of Roman shades by introducing CERUS (Cord Eliminating

Roman Uptake System) safety technology. This patent-pending innovation creates a safer shade by removing the exposed inner cords that are typical of

Roman shade construction—and which may pose a strangulation hazard to small children.

Tensioned shades

Tensioned shades combine electronic drive technology with a new tension system that eliminates the stress on the surrounding structure when installed. Fabric is kept taut regardless of slope, making it a perfect solution for skylights, bottom-up, or angled window applications.

Lutron

|

19

HomeWorks

®

Processor

QS

System capacities:

100

devices per link

2

links per processor

16

processors per system

1,500

wireless devices

10,000

zones total

HomeWorks QS processor

Flexible QS link

Lutron’s next generation wired communication link

Single link accommodates most

HomeWorks QS wired products

Supports up to 100 devices/512 zones using any wiring topology

Continuous, non-invasive diagnostics

24 V DC supply capable of powering more devices

New Clear Connect

RF link

Based on 15 years of RF development

Fast uploads and system performance

Simpler system commissioning

Supports up to 100 devices/

100 zones per link

20

|

Lutron

Dimming panel link

Control HomeWorks dimming and spec grade panels

Fast system uploads

Simultaneous Ethernet transfer of files to all processors

Faster transfer of databases to RF devices

Uploading minimal data for certain database changes

Integral QS shades and drapes

QS shades and drapes are part of the system with no interfaces

Enhanced QS shade power panel with wiring diagnostics and control

4-conductor wiring and terminal blocks

Hybrid repeater and low voltage enclosure

Hybrid repeater

Creates Clear Connect RF network

Connects to RF link on HomeWorks

®

QS processor

Easily add wireless devices to your system

Low voltage enclosure

HomeWorks QS keypads, shades, and other low voltage devices are powered by 24 V DC

Provides power and low voltage wiring terminations

Houses processor, contact closure I/O interface, and RS-232 interface

Lutron

|

21

HomeWorks

®

Open integration

QS

HomeWorks QS extends the open integration capability that has always been a foundation of HomeWorks.

Serial (RS-232) and Ethernet drivers, as well as the capability to interface with contact closure input or output devices, provide complete control of and from other devices and systems in the home.

HomeWorks QS car visor transmitter

The car visor transmitter, which has a range of 100 feet, allows you to conveniently open and close your garage door or a gate. You can also use it to light a pathway into your home. Press an “Away” button to turn off lights or set an away scene as you leave. control

Security system

Subsystem automation

(i.e. door locks, pool equipment, irrigation)

HomeWorks QS visor control receiver

The car visor control receiver provides contact closure outputs for four garage doors or gates. It also receives a contact closure input for a security system. The receiver, used in conjunction with the car visor transmitter, communicates via RF technology.

22

|

Lutron

Contact closure I/O interface

This interface provides integration to contact closure devices and has five inputs and five outputs. Inputs are designed for security system or low-voltage wired sensors; outputs are perfect for gates and fireplaces. This interface uses QS link communication.

RS-232 interface

This interface provides integration to RS-232 integration devices. It has one RS-232 port, uses QS link communication, and can be installed near RS-232 equipment to minimize serial cable length.

Lutron

®

works with many third-party manufacturers to ensure that our systems integrate reliably. Lutron provides documentation along with product and technical support to many manufacturers to ensure that our system works with a wide variety of remotes and automation systems.

AMX

www.amx.com

Control4

www.control4.com

ELAN

www.elanhomesystems.com

HAI

www.homeauto.com

HomeLogic

www.homelogic.com

Life|ware

www.life-ware.com

NetStreams

www.netstreams.com

Philips www.pronto.philips.com

RTI

www.rticorp.com

Savant

www.savantav.com

Universal Electronics Inc.

www.uei.com

Universal Remote Control

www.universalremote.com

Lutron

|

23

HomeWorks

®

Remote power panels

QS

Left to right:

Feed-through dimming panel, dimming panel with breakers, and spec grade dimming panel

Dimming panels

HomeWorks QS is compatible with existing panel-based solutions.

Panels are available in standard feed-through, breaker, and spec grade models. New models are available with arc-fault breaker protection. Spec grade panels provide the highest performance for dimmed zones up to 1920 W per output.

24

|

Lutron

Wallbox power module

Wallbox power modules provide a compact power solution for 6 lighting zones. Installed in a 4-gang wallbox, these modules provide power to lighting zones where keypad control is used in place of dimmers in the space.

QS plug-in power supply

The QS plug-in power supply powers a QS shade or other QS link device, such as a keypad or interface. Its mounting tabs and small size allow for discrete installation.

QS power panel

This panel provides 10 outputs to power up to 30 shades. It can also be used to power other QS devices, such as keypads and interfaces.

QS J-box power supply

The QS J-box power supply is plenum rated and can power a QS shade or other QS devices, such as a keypad or interface. Pass-through communication makes wiring easy.

Lutron

|

25

HomeWorks

®

QS

Design and programming tool

NEW design and programming tool

The HomeWorks QS design and programming utility is built on a new platform for faster uploads and improved workflow.

The new utility features five easy steps in design and programming a HomeWorks QS system as well as a section for creating a customized report.

Design

Define control station locations and enter load information in the Design tab.

Add controllable shades to your project.

Define the backroom equipment and assign the processor links that devices will use to communicate.

Customize your toolbox of products to suit the type of job you are working on or your personal design preferences.

26

|

Lutron

Program

Program lighting zone and scene control, shade presets, and system time clock events. Conditional logic, state variables, sequences, occupancy events and shared (global) scenes can also be defined in the Program tab.

Activate

Activate system devices using device serial numbers or by pressing device buttons throughout the home. The Activate tab is where the physical device in the home and the virtual device in Lutron

®

Designer become one.

Transfer

Transfer firmware updates and system database to the processor to start up or make programming changes to your system. Transfer to multiple processors over Ethernet makes transfer faster in HomeWorks

®

QS.

Diagnostics

Give your system a checkup in the diagnostics tab. Communication of wired and RF devices to the processor is checked and verified.

Report Center

Print or export to pdf the bill of materials, load schedule, engraving, and integration information for your project. Customize a report package with or without system pricing.

Lutron

|

27

HomeWorks

®

QS

Residential system comparison

System features

System size

System design

Dimmers and switches

Keypads

GRAFIK Eye

®

Touchscreen control

Shades

Thermostat

Sensors

Centralized dimming

Software

28

|

Lutron

RadioRA

®

2

200 devices

Local wireless

Maestro

®

RF

seeTouch

®

keypads

RF designer

RF hybrid designer

RF tabletop

GRAFIK Eye

®

QS Wireless

Third-party integration

Sivoia

®

QS wireless shades

seeTemp

RF occupancy/vacancy

RF daylight

None

Basic

HomeWorks

®

4,096 zones

Local wireless

Local wired

Centralized

Hybrid

Maestro

RF

Wired

Vareo

®

Wired

seeTouch keypads

RF designer

RF tabletop

Wired architectural

Wired designer

GRAFIK Eye

Third-party integration

Sivoia QED

®

wireless shades

(Roller 64 only)

Sivoia QED wired shades

Integration—third party

Wired occupancy/vacancy

Specification grade panels

Dimming panels

Advanced

HomeWorks

®

QS

10,000 zones

Local wireless

Centralized

Hybrid

Maestro

RF

seeTouch keypads

RF designer

RF hybrid designer

RF tabletop

Wired architectural

Wired designer

GRAFIK Eye QS Wireless

GRAFIK Eye QS Wired

Dynamic keypad

Third-party integration

Sivoia QS wireless shades

Sivoia QS wired shades

seeTemp

Integration—third party

RF occupancy/vacancy

RF daylight

Specification grade panels

Dimming panels

Advanced

System features

System size

System design

Dimmers and switches

Keypads

GRAFIK Eye

®

Touchscreen control

Shades

Thermostat

Sensors

Centralized dimming

Software

RadioRA

®

2

200 devices

Local wireless

Maestro

®

RF

seeTouch

®

keypads

RF designer

RF hybrid designer

RF tabletop

GRAFIK Eye

®

QS Wireless

Third-party integration

Sivoia

®

QS wireless shades

seeTemp

RF occupancy/vacancy

RF daylight

None

Basic

HomeWorks

®

4,096 zones

Local wireless

Local wired

Centralized

Hybrid

Maestro

RF

Wired

Vareo

®

Wired

seeTouch keypads

RF designer

RF tabletop

Wired architectural

Wired designer

GRAFIK Eye

Third-party integration

Sivoia QED

®

wireless shades

(Roller 64 only)

Sivoia QED wired shades

Integration—third party

Wired occupancy/vacancy

Specification grade panels

Dimming panels

Advanced

HomeWorks

®

QS

10,000 zones

Local wireless

Centralized

Hybrid

Maestro

RF

seeTouch keypads

RF designer

RF hybrid designer

RF tabletop

Wired architectural

Wired designer

GRAFIK Eye QS Wireless

GRAFIK Eye QS Wired

Dynamic keypad

Third-party integration

Sivoia QS wireless shades

Sivoia QS wired shades

seeTemp

Integration—third party

RF occupancy/vacancy

RF daylight

Specification grade panels

Dimming panels

Advanced

Lutron

|

29

Connect is Lutron’s latest advancement in reliable RF communication.

Quiet frequency band, essentially free of interference

Dedicated network ensures communication between system devices is reliably delivered

Group commands ensure smooth, simultaneous system response usage during peak demand periods, which saves you money.

For technical information and specification sheets visit www.lutron.com/service-support/technical/pages/overview

www.lutron.com/homeworksqs

Lutron Electronics Co., Inc.

7200 Suter Road

Coopersburg, PA 18036-1299

World Headquarters 1.610.282.3800

Technical Support Center 1.800.523.9466

Customer Service 1.888.LUTRON1

© 09/2010 Lutron Electronics Co., Inc.

Printed in the U.S.A.

P/N 367-2021 REV A

www.lutron.com/energy

Abu Dhabi

Ashland

Bangalore

Barcelona

Beijing

Berlin

Bogotá

Chicago

Chihuahua

Fort Lauderdale

Hong Kong

Las Vegas

London

Los Angeles

Madrid

Milan

Mexico City

Montreal

Moscow

Mumbai

Munich

New Delhi

New York

Panama City

Paris

Puerto Rico

Rio De Janeiro

São Paulo

Seattle

Shanghai

Singapore

St. Kitts

Stockholm

Toronto

Washington D.C.

Vancouver

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
