Water Treatment

COOL

&

HEAT

the easy way.....

with our ‘Easy-Fit’ Air Conditioning Kits

super efficient

R410a

refrigerant

ECOFRIENDLY

*Product supplied may not be as illustrated

Model

Power Rating (Ph-V-Hz)

Capacity BTU/H (cooling) kW

Capacity BTU/H (heating) kW

Power Input (W) Cooling/Heating

Current Input (A) Cooling/Heating

EER (BTU/hr.w)

COP (W/W)

Dehumidification (L/h)

Indoor Noise Level dB(A) (Hi/M/Lo)

Outdoor Noise Level dB(A)

Indoor Airflow (m3/h) (Hi/M/Lo)

Max. Current Rating (A) Fuse Rating (type D)

Net Dimension (mm) indoor (W/D/H)

Net Dimension (mm) outdoor (W/D/H)

Net/Gross Weight (kg) indoor

Net/Gross Weight (kg) outdoor

Max Room Size (m

2

)

Max Conservatory Size (m 2 )

Connecting Pipe Length (m)

Pipe Diameter Liquid/Gas (Inch)

Selectable Temp Range ºC

Minimum Operating Temp (Cooling/Heating) ºC

Automatic Restart after Power Failure

Automatic Refrigerant Leak Detection & Self Diagnosis Systems

KFR23IW/X1CM

1 / 220-240V / 50 Hz

9000 / 2.7

9000 / 2.8

910~920

4.0~4.0

SEER 5.5

SCOP 3.4

1

36/32/28

56

400/350/320

7.5

710x189x250

700x240x540

6.5 / 8.5

29.5 / 31.5

13-22

10

4

1/4 & 3/8

17-30

-7 / -15

Yes

Yes

Inverter Wall Split Systems

INVERTER WALL SPLIT SYSTEMS

KFR33IW/X1CM

1 / 220-240V / 50 Hz

11000 / 3.2

11000 / 3.4

1110~1160

4.4~5.0

SEER 5.4

SCOP 3.4

1.1

42/35/29

56

500/400/350

9

790x196x275

780x250x540

8 / 10

29.5 / 31.5

16-27

13

4

1/4 & 3/8

17-30

-7 / -15

Yes

Yes

KFR53IW/X1CM

1 / 220-240V / 50 Hz

17000 / 5.0

18000 / 5.1

1780~1500

7.7~6.5

SEER 5.6

SCOP 3.4

1.7

46/42/36

58

730/680/560

11.5

930x198x275

760x285x590

9 / 11.5

35 / 37

25-42

22

4

1/4 & 1/2

17-30

-7 / -15

Yes

Yes

ECOR PRO

Industrial/Commercial Dehumidifiers

KDHDDH2500

KFR63IW/X1CM

1 / 220-240V / 50Hz

22500 / 6.6

25000 / 7.0

2290~2360

10.0~10.3

SEER 5.5

SCOP 3.5

3

49/45/41

60

1000/950/810

14.0

1036x230x315

845x320x700

12.5 / 18

50 / 53.5

34-56

25

6

3/8 & 5/8

17-30

-7 / -15

Yes

Yes

Ceiling Cassette System

SUPER INVERTER CEILING CASSETTE SYSTEMS

KFR50QIW/X1CM

1/ 220-240V / 50 Hz

17000 / 5.0

18000 / 5.3

1550~1460

7.1~6.7

5.6

3.8

1.7

42

51

800 max

8

570x570x260

760x590x285

18

40

25-45

N/A

5

1/4 & 1/2

17-30

-7 / -15

Yes

Yes

KFR74QIW/X1CM

1 /220-240V / 50Hz

24000 / 7.3

26000 / 8.0

2180~2100

10.0~9.6

6.5

3.8

2.6

43

54

1780 max

11

840x840x245

845x895x335

24

53

34-60

N/A

6

3/8 & 5/8

17-30

-7 / -15

Yes

Yes

KFR120QIW/X1CM

1 /220-240V / 50Hz

36000 / 10.5

40000 / 11.2

3230~3250

5.6~5.6

5.6

3.8

3.5

48

55

1850 max

12

840x840x245

990x966x354

27

82

50-100

N/A

6

3/8 & 5/8

17-30

-10 / -15

Yes

Yes

250

KDHBD1500

Model

Power Input (V-Hz)

Power Consumption (W)

Operating Temperature (ºC)

Exhaust Airflow (m3/h)

Current Max (A)

Current Normal (A)

Dehumidification Max (L/day)

Dehumidification 30ºC 80% RH (L/day)

Noise Level dB(A)

Room Maximum Volume (m3)

Rotary Compressor

Process Air Duct Outlet Diameter (mm)

Dry Air Delivery Duct Diameter (mm)

Exhaust Air Duct Diameter (mm)

Ammeter

Simple On/Off Button

R410A Refrigerant

Process Air Filter

Product Dimensions (HxWxDmm)

Product Weight (kg)

BUILDING DEHUMIDIFIER

KDHBD1500

110V/230V Dual / 50 Hz

60

360

YES

-

-

-

-

YES

1300

3 to 40

200

12

6

85

64

YES

-

880x535x580

80

KDHDDH2500

230V / 50Hz

1200

-20 to 40

70

4

2

26

26

49

-

-

125

125

80

YES

-

-

YES

340x455x350

15

AIR TREATMENT

Indoor Pool

& Commercial

Dehumidifiers

Wall or floor mounted dehumidifier especially designed for small to medium swimming pools and commercial storage.

Model

Dehumidification @ 30ºC/70%RH (L/24h)

Heat recovered to air @ 30ºC/60%RH (W)

Rated input power (W)

Power supply (V/PH/Hz)

Rated current (A)

Max current (A)

Circulating air volume (Cu³/h)

Operating temperature range (ºC)

Compressor protection

Refrigerant

Net weight (Kg)

Net dimension (mm)

PDH60A

60

2785

920

220/1/50

4.2

9.4

800

0-35

3 minutes delay

R410a

30

905/243/673

PDH110A

110

4315

1423

220/1/50

6.5

14.6

1200

0-35

3 minutes delay

R410a

36

1288/243/673

visit:

www.airconditioningcentre.com

CONSOLE SYSTEMS

KFR37CIW/X1CM

1/ 220-240V / 50 Hz

12000 / 3.5

13000 / 3.6

1090~970

5~4.5

6.2

3.8

1.1

47

51

700 max

7

700x210x600

780x250x547

15

34

16-27

12

4

1/4 & 3/2

17-30

-7 / -15

Yes

Yes

KFR57CIW/X1CM

1/ 220-240V / 50 Hz

17000 / 5.0

18000 / 5.3

1460~1380

6.7~6.3

5.6

3.8

1.7

48

55

740 max

10

700x210x600

842x324x695

15

52

25-42

20

4

1/4 & 1/2

17-30

-7 / -15

Yes

Yes

SUPER INVERTER

LOW WALL SYSTEM

KFR55LIW/X1CM

1 / 220-240V / 50Hz

18000 / 5.3

18000 / 5.3

1620~1410

7.4~6.5

6.2

3.8

2.5

42

51

900 max

8

1068x675x235

760x590x285

25

40

25-45

30

5

1/4 & 1/2

17-30

-7 / -15

Yes

Yes

LOW WALL

SYSTEM

KFR75LW/X1CM

1 / 220-240V / 50Hz

24000

26000

2423~2415

12.4~12.2

EER 2.93

COP 3.15

2.6

45/43/40

55

1200/900/700

18

990x660x203

846x335x695

24

51

55

24

6

3/8 & 5/8

17-30

-7 / -15

Yes

Yes

KFR26YW/X1CM

1 / 220-240V / 50Hz

9000 / 2.8 (3.3)

9000 / 2.9 (3.4)

800~820

3.8~3.9

6.1

3.8

1

30-38

52

500 max

3.9

800x280x190

715x235x540

10

30

13-25

12

4

1/4 & 3/8

17-30

-5 / -10

Yes

Yes

GLOSS BLACK INVERTER WALL SPLIT SYSTEMS

KFR36YW/X1CM

1 / 220-240V / 50Hz

12000 / 3.5 (4.0)

12000 / 3.5 (4.2)

1040~980

4.7~4.5

6.1

3.8

1.3

30-40

53

550 max

4.7

800x280x190

812x256x540

10

34

16-30

15

4

1/4 & 3/8

17-30

-5 / -10

Yes

Yes

KFR56YW/X1CM

1 / 220-240V / 50Hz

18000 / 5.1 (5.5)

18000 / 5.2 (5.7)

1580~1440

7.2~6.6

6.1

3.8

1.9

42-46

55

850 max

7.2

900x292x215

850x295x605

14

45

25-45

205

4

1/4 & 1/2

17-30

-5 / -10

Yes

Yes

KFR66YW/X1CM

1 / 220-240V / 50Hz

24000 / 7.0 (8.4)

24000 / 7.6 (9.0)

2180~2100

10.0~9.6

6.1

3.8

2.6

42-48

58

1050 max

10

1080x302x220

900x330x835

16

65

34-60

30

6

3/8 & 5/8

17-30

-5 / -10

Yes

Yes

Wall Mounting Kits

FOR OUTDOOR UNIT

BRKTUNI23-66 KFR 23/33/50/51/53/63/66

BRKTUNI70-120 KFR 70/74/120

FORGET

BRACKETS

KFR-26YW/X1C-M

KFR-36YW/X1C-M

KFR-56YW/X1C-M

KFR-66YW/X1C-M

Model

Power Rating (Ph-V-Hz)

Capacity BTU/H (cooling) kW

Capacity BTU/H (heating) kW

Power Input (W) Cooling/Heating

Current Input (A) Cooling/Heating

EER (BTU/hr.w)

COP (W/W)

Dehumidification (L/h)

Indoor Noise Level dB(A) (Hi/M/Lo)

Outdoor Noise Level dB(A)

Indoor Airflow (m3/h) (Hi/M/Lo)

Max. Current Rating (A) Fuse Rating (type D)

Net Dimension (mm) indoor (W/D/H)

Net Dimension (mm) outdoor (W/D/H)

Net/Gross Weight (kg) indoor

Net/Gross Weight (kg) outdoor

Max Room Size (m

2

)

Max Conservatory Size (m 2 )

Connecting Pipe Length (m)

Pipe Diameter Liquid/Gas (Inch)

Selectable Temp Range ºC

Minimum Operating Temp (Cooling/Heating) ºC

Automatic Restart after Power Failure

Automatic Refrigerant Leak Detection & Self Diagnosis Systems

KFR23IW/X1CM

1 / 220-240V / 50 Hz

9000 / 2.7

9000 / 2.8

910~920

4.0~4.0

SEER 5.5

SCOP 3.4

1

36/32/28

56

400/350/320

7.5

710x189x250

700x240x540

6.5 / 8.5

29.5 / 31.5

13-22

10

4

1/4 & 3/8

17-30

-7 / -15

Yes

Yes

INVERTER WALL SPLIT SYSTEMS

KFR33IW/X1CM

1 / 220-240V / 50 Hz

11000 / 3.2

11000 / 3.4

1110~1160

4.4~5.0

SEER 5.4

SCOP 3.4

1.1

42/35/29

56

500/400/350

9

790x196x275

780x250x540

8 / 10

29.5 / 31.5

16-27

13

4

1/4 & 3/8

17-30

-7 / -15

Yes

Yes

KFR53IW/X1CM

1 / 220-240V / 50 Hz

17000 / 5.0

18000 / 5.1

1780~1500

7.7~6.5

SEER 5.6

SCOP 3.4

1.7

46/42/36

58

730/680/560

11.5

930x198x275

760x285x590

9 / 11.5

35 / 37

25-42

22

4

1/4 & 1/2

17-30

-7 / -15

Yes

Yes

ECOR PRO

Industrial/Commercial Dehumidifiers

KFR63IW/X1CM

1 / 220-240V / 50Hz

22500 / 6.6

25000 / 7.0

2290~2360

10.0~10.3

SEER 5.5

SCOP 3.5

3

49/45/41

60

1000/950/810

14.0

1036x230x315

845x320x700

12.5 / 18

50 / 53.5

34-56

25

6

3/8 & 5/8

17-30

-7 / -15

Yes

Yes

SUPER INVERTER CEILING CASSETTE SYSTEMS

KFR50QIW/X1CM

1/ 220-240V / 50 Hz

17000 / 5.0

18000 / 5.3

1550~1460

7.1~6.7

5.6

3.8

1.7

42

51

800 max

8

570x570x260

760x590x285

18

40

25-45

N/A

5

1/4 & 1/2

17-30

-7 / -15

Yes

Yes

KFR74QIW/X1CM

1 /220-240V / 50Hz

24000 / 7.3

26000 / 8.0

2180~2100

10.0~9.6

6.5

3.8

2.6

43

54

1780 max

11

840x840x245

845x895x335

24

53

34-60

N/A

6

3/8 & 5/8

17-30

-7 / -15

Yes

Yes

KFR120QIW/X1CM

1 /220-240V / 50Hz

36000 / 10.5

40000 / 11.2

3230~3250

5.6~5.6

5.6

3.8

3.5

48

55

1850 max

12

840x840x245

990x966x354

27

82

50-100

N/A

6

3/8 & 5/8

17-30

-10 / -15

Yes

Yes

Indoor Pool

& Commercial

Dehumidifiers

Console System

CONSOLE SYSTEMS

KFR37CIW/X1CM

1/ 220-240V / 50 Hz

12000 / 3.5

13000 / 3.6

1090~970

5~4.5

6.2

3.8

1.1

47

51

700 max

7

700x210x600

780x250x547

15

34

16-27

12

4

1/4 & 3/2

17-30

-7 / -15

Yes

Yes

KFR57CIW/X1CM

1/ 220-240V / 50 Hz

17000 / 5.0

18000 / 5.3

1460~1380

6.7~6.3

5.6

3.8

1.7

48

55

740 max

10

700x210x600

842x324x695

15

52

25-42

20

4

1/4 & 1/2

17-30

-7 / -15

Yes

Yes

Low Wall System

SUPER INVERTER

LOW WALL SYSTEM

KFR55LIW/X1CM

1 / 220-240V / 50Hz

18000 / 5.3

18000 / 5.3

1620~1410

7.4~6.5

6.2

3.8

2.5

42

51

900 max

8

1068x675x235

760x590x285

25

40

25-45

30

5

1/4 & 1/2

17-30

-7 / -15

Yes

Yes

LOW WALL

SYSTEM

KFR75LW/X1CM

1 / 220-240V / 50Hz

24000

26000

2423~2415

12.4~12.2

EER 2.93

COP 3.15

2.6

45/43/40

55

1200/900/700

18

990x660x203

846x335x695

24

51

55

24

6

3/8 & 5/8

17-30

-7 / -15

Yes

Yes

Outdoor Unit

KFR26YW/X1CM

1 / 220-240V / 50Hz

9000 / 2.8 (3.3)

9000 / 2.9 (3.4)

800~820

3.8~3.9

6.1

3.8

1

30-38

52

500 max

3.9

800x280x190

715x235x540

10

30

13-25

12

4

1/4 & 3/8

17-30

-5 / -10

Yes

Yes

Gloss Black InverterWall Split System

GLOSS BLACK INVERTER WALL SPLIT SYSTEMS

KFR36YW/X1CM

1 / 220-240V / 50Hz

12000 / 3.5 (4.0)

12000 / 3.5 (4.2)

1040~980

4.7~4.5

6.1

3.8

1.3

30-40

53

550 max

4.7

800x280x190

812x256x540

10

34

16-30

15

4

1/4 & 3/8

17-30

-5 / -10

Yes

Yes

KFR56YW/X1CM

1 / 220-240V / 50Hz

18000 / 5.1 (5.5)

18000 / 5.2 (5.7)

1580~1440

7.2~6.6

6.1

3.8

1.9

42-46

55

850 max

7.2

900x292x215

850x295x605

14

45

25-45

205

4

1/4 & 1/2

17-30

-5 / -10

Yes

Yes

KFR66YW/X1CM

1 / 220-240V / 50Hz

24000 / 7.0 (8.4)

24000 / 7.6 (9.0)

2180~2100

10.0~9.6

6.1

3.8

2.6

42-48

58

1050 max

10

1080x302x220

900x330x835

16

65

34-60

30

6

3/8 & 5/8

17-30

-5 / -10

Yes

Yes

Multi Split Systems - Mix & Match

Console Indoor

Ceiling

Cassette

Wall Split Indoor

Model

Power Rating (Ph-V-Hz)

Capacity BTU/H (cooling) kW

Capacity BTU/H (heating) kW

Power Input (W) Cooling/Heating

Current Input (A) Cooling/Heating

EER (BTU/hr.w)

COP (W/W)

Dehumidification (L/h)

Indoor Noise Level dB(A) (Hi/M/Lo)

Outdoor Noise Level dB(A)

Indoor Airflow (m3/h) Hi/M/Lo

Max. Current Rating (A) Fuse

Rating (type D)

Net Dimension (mm) indoor (W/D/H)

Net Dimension (mm) outdoor (W/D/H)

Net/Gross Weight (kg) indoor

Net/Gross Weight (kg) outdoor

Max Room Size (m 2 )

Max Conservatory Size (m

2

)

Connecting Pipe Length (m)

Pipe Diameter Liquid/Gas (Inch)

Selectable Temp Range ºC

Minimum Operating Temp

(Cooling/Heating) ºC

Automatic Restart after

Power Failure

Automatic Refrigerant Leak

Detection & Self Diagnosis Systems

SUPER INVERTER MULTI SYSTEM

OUTDOOR UNITS

KMS3MIO/X1CM KMS5MIO/X1CM

1 / 220-240V / 50 Hz

27000 / 8.4 (9.9)

30000 / 9.4 (11)

2470~2380 (3.6)

10.8~10.3

SEER 7

SCOP 3.9

N/A

N/A

61

N/A

1 / 220-240V / 50 Hz

36000 / 10.5 (12.0)

42000 / 12.3 (14)

3280~3400 (4.9)

14.6~15.3

SEER 5.3

SCOP 3.4

N/A

N/A

63

N/A

16.5

22

N/A

900x315x860

N/A

62

N/A

N/A

N/A

3 Sets of 1/4 & 3/8

N/A

-7 / -15

Yes

Yes

N/A

990x345x965

N/A

80

N/A

N/A

N/A

5 Sets of 1/4 & 3/8

3 Sets of

-7 / -15

Yes

Yes

KFR23IW/X1C-MIU

1/ 220-240V / 50 Hz

9000 / 2.7

9000 / 2.8

N/A

N/A

N/A

N/A

1

36/32/28

N/A

400/350/320

N/A

710x189x250

N/A

6.5

N/A

13-22

10

Order Separately

1/4 & 3/8

17-30

-7 / -15

Yes

Yes

WALL SPLIT INDOOR

KFR33IW/X1CMIU

1/ 220-240V / 50 Hz

11000 / 3.2

11000 / 3.4

N/A

N/A

N/A

N/A

1.1

42/35/29

N/A

500/400/350

N/A

790x196x275

N/A

8

N/A

16.27

13

Order Separately

1/4 & 3/8

17-30

-7 / -15

Yes

Yes

KFR53IW/X1CMIU

1/ 220-240V / 50 Hz

17000 / 5.0

18000 / 5.1

N/A

N/A

N/A

N/A

1.7

46/42/36

N/A

730/680/560

N/A

930x189x275

N/A

9

N/A

25.42

22

Order Separately

1/4 & 1/2

17-30

-7 / -15

Yes

Yes

CEILING CASSETTE

INDOOR

KFR50QIW/X1CMIU

1/ 220-240V / 50 Hz

17000 / 5.0

18000 / 5.3

N/A

N/A

N/A

N/A

1.7

42

N/A

800 max

N/A

570x570x260

N/A

18

N/A

25.45

N/A

Order Separately

1/4 & 1/2

17-30

-7 / -15

Yes

Yes

CONSOLE INDOOR

KFR37CIW/X1CMIU

1/ 220-240V / 50 Hz

12000 / 3.5

13000 / 3.6

N/A

N/A

N/A

N/A

1.1

47

N/A

700 max

KFR57CIW/X1CMIU

1/ 220-240V / 50 Hz

17000 / 5.0

18000 / 5.3

N/A

N/A

N/A

N/A

1.7

48

N/A

740 max

N/A N/A

700x210x600 700x210x600

N/A

15

N/A

16-27

12

Order Separately

1/4 & 3/8

17-30

-7 / -15

Yes

Yes

N/A

15

N/A

25-42

20

Order Separately

1/4 & 1/2

17-30

-7 / -15

Yes

Yes

for more detailed information

AIR TREATMENT

251

Evaporative Coolers

Presenting, a hip new range of air coolers from Symphony. Sleek and stylish, a cool addition to your décor. What’s more, these chic models consume bare minimum space and energy. Revved up with many power-packed features, the right choice for a cool summer, this year.

Dura-pump Technology

For long life of the pump.

Empty Water Tank Alarm

Provides consumer convenience.

Model

Cooling Area (approx.) sqm/sqft

Air Throw dist (approx.) mtr/ft

Blower/fan dia (mm/inches)

Speed Control

Motor R.P.M.

Air delivery m3/hr / CFM

Electrical - 230V / 50 Hz (W)

Water tank capacity (Ltrs/Gallon)

Water inlet - Top + Back

Mosquito net / Dust filter

Auto Shut-off Pump

Water level indicator

Operable cooling pads

Cooling media

Remote Control

Noise dB (A) 1m Low-High

Length (mm)

Width (mm)

Height (mm)

Net Weight (Kgs/Lbs)

DiET 8i

12.5/125

7.5/25

180 / 7

Three

1400

600/350

115

8/1.75

Yes

Yes

Yes

Yes

No

Honeycomb

Yes

40-55

300

330

780

7.3/16

DiET 22i

20/200

11/37

180/7

Three

1400

1100/647

160

25/5

Yes

Yes

Yes

Yes

Yes

Honeycomb

Yes

44-59

300

330

943

12/26

DiET 50i

25/250

11/37

180/7

Three

1400

1250/740

175

50/13

Yes

Yes

Yes

Yes

Yes

Honeycomb

Yes

45-60

430

360

1155

13/29

STORM 100i

100/1000

25/80

358/14

Seven

5500

1250/740

175

100

Yes

Yes

Yes

Yes

Yes

Honeycomb

Yes

45-60

635

500

1620

25/55

Intelligent Remote

Full function remote with timer.

Feather-touch Digital Control Panel

For ease of operation.

System Restore Function

Remembers and restores previous settings.

Powerful Air Throw with Auto Swing

For faster cooling.

Cool Flow Dispenser

Channelised water distribution for superior cooling.

Large Tank Capacity

Gives uninterrupted night-long cooling.

Whisper-quiet Performance

For sound sleep.

For enhanced cooling.

Dura-pump Technology

For long life of the pump.

Empty Water Tank Alarm

Provides consumer convenience.

Intelligent Remote

Full function remote with timer.

Feather-touch Digital Control Panel

For ease of operation.

System Restore Function

Remembers and restores previous settings.

Powerful Air Throw with Auto Swing

For faster cooling.

Cool Flow Dispenser

Channelised water distribution for superior cooling.

Large Tank Capacity

Gives uninterrupted night-long cooling.

Whisper-quiet Performance

For sound sleep.

For enhanced cooling.

consumes

170 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

270 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

115 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

170 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

115 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

115 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

115 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

115 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

115 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

115 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

115 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

115 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air

Model

Power Rating

Capacity BTU/h (cooling)

Capacity BTU/h (heating)

Power Input W (C/H)

Current Input A (C/H)

EER (BTU/hr.w)

COP (w/w)

Noise dB(A)

Dehumidification (L/h)

Airflow (m3/h)

Net Dimension (mm) W/D/H

Net Weight (kg)

Max Room Size

Max Conservatory Size

Exhaust Hose Length

Exhaust Hose Diameter

Window Extraction Kit

252

consumes

115 watts* only use it outside, use it inside delivers fresh, filtered cool air consumes

115 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

115 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air consumes

115 watts* only also works on inverter power use it outside, use it inside delivers fresh, filtered cool air also works on inverter power

Mobile Air Conditioner Systems

KYR25CO/X1C

220-240V / 50Hz

9000 (2.6kW)

COOL ONLY

1000

4.5

2.6

N/A

57

1.0

370

352x378x753

35

20m sq

9m sq

1.7m

150mm

Yes

KYR35/X1C*

220-240V / 50Hz

12500 (3.5kW)

12700 (3.7kW)

1250/1345

5.5/6.0

2.8

3.04

56

1.2

480

600x480x830

42

25m sq

12m sq

1.8m

150mm

Yes

KYR45GW/X1C

220-240V / 50Hz

14000 (4.1kW)

16000 (4.5kW)

1708/1550

7.5/6.7

2.4

2.90

58

1.2

480

460x430x830

42

32m sq

15m sq

2m

150mm

Yes

AIR TREATMENT

Our high performance portable air conditioners feature heat pump technology * , enabling units to both heat and cool at the push of a button. Fitted with easy-roll castors they can be conveniently moved from room to room as required. A ducted exhaust hose is included to vent the hot air to the outside of the building. An adjustable window mounting panel is also supplied to attach the exhaust hose for ease of use. The units benefit from an automatic inbuilt condensate pump, which pumps the water out with the exhaust air, so there is no water tank to empty.

2M Exhaust Hose Extension available contact your local

Stearn branch for details

Wholehouse Heat Recovery Ventilation System

• Manufactured in the UK

• Building Regulations compliant

• SAP Appendix Q Eligible

• Normal, Boost and Purge speeds

• Energy Savings Trust best practice compliant

• Up to 91% heat recovery whilst controlling condensation

• Ideal for horizontal fitting applications

• Left or right hand installation

• Light weight for easy installation

• 3 Position switch

• 2 x Volt Free inputs

• Easy access washable EU3

• Compact size

449188

Ceiling Sweep Fans

• Suitable for winter- Destratification

applications or summer cooling

• Two Down rod lengths included

• Easy to install

• Quiet running

• Can be installed for either upward

or downward airflow

• Reversible electronic controller available

Ceiling Sweep Fans

Both long and short down rods included as standard. Short down rod including motor is 360mm, long down rod including motor is 610mm.

Ref

444122

444123

Size

36”

48”

444124 56”

Ceiling Fan Controller

White cover plate can be flush or surface mounted.

Suitble for commercial environments

Ref

444087

Description

Controls up to 5 fans

AIR TREATMENT

253

254

Domestic Range

100mm 4’’ Axial - Toilet and Bathroom Fans

Cat No.

457085A

459299A

457086A

459294A

459309A

459318A

Model

Standard fan

Standard fan plus pull cord

Standard fan plus timer

Standard fan plus humidistat plus pull cord

Standard fan plus shutters and timer

Standard fan plus humidistat and shutters m3/hr

88

88

88

88

88

88

Ltr/s

24.44

24.44

24.44

24.44

24.44

24.44

Watts dB(A)@3m

16 32

16

16

32

32

16

20

20

32

32

32

Domestic Range

150mm 6’’ Axial - Kitchen Fans

Cat No.

426566

438170

438171

435103

426568

Model

Standard fan

Standard fan and pull cord

Standard fan and timer

Standard fan plus shutters and pull cord

Standard fan plus shutters and timer m3/hr

245

245

245

245

245

Ltr/s

68.06

68.06

68.06

68.06

68.06

Watts dB(A)@3m

25 45

25

25

30

30

45

45

45

45

Quiet Fan Range

100mm 4’’ Axial Fans

Cat No.

406957

406958

406959

Model

Quiet fan 100mm

Quiet fan 100mm plus timer

Quiet fan 100mm plus humidistat m3/hr

75

75

75

Ltr/s

21

21

21

Watts dB(A)@3m

4.8

27

4.8

4.8

27

27

Domestic Range

100mm 4’’ Shower Fan Kits

Cat No.

434445A

434446A

Model

In-line standard fan

In-line standard fan plus timer m3/hr

85

85

Ltr/s

23.61

23.61

Watts dB(A)@3m

14 41

14 41

Domestic Range

100mm 4’’ Shower Fan and Light Kit

Cat No.

434448A

Model

In-line standard fan plus timer complete with light kit, white and chrome bezels m3/hr

85

Ltr/s

23.61

Watts dB(A)@3m

14 41

Domestic Range Part L Compliant

100mm 4’’ & 150mm 6’’ Fans

Cat No.

448379

448380

448381

448382

448383

448384

Model

100mm Standard fan

100mm Standard fan plus timer

100mm Standard fan plus humidistat

150mm Standard fan

150mm Standard fan plus timer

150mm Standard fan plus humidistat m3/hr

92

92

92

230

230

230

Ltr/s

25.5

25.5

25.5

63.89

63.89

63.89

Watts dB(A)@3m

11 45

11

11

45

45

18

18

18

40

40

40

Domestic Range Part L Compliant

100mm 4’’ & 150mm 6’’ Inline Shower Fan Kits

Cat No.

448385

448386

Model

100mm In-line standard fan

150mm In-line standard fan m3/hr

86

227

Ltr/s

24

63

Watts dB(A)@3m

10

20

41

40

Domestic Range Part L Compliant

100mm 4’’ & 150mm 6’’ Inline Shower Fan & Light Kits

Cat No.

448387

448388

Model

100mm In-line standard fan & light kit

150mm In-line standard fan & light kit m3/hr

86

227

Ltr/s

24

63

Watts dB(A)@3m

10 41

20 40

AIR TREATMENT

Domestic Range Part L Compliant

100mm Low Watt SELV 4’’ Axial - Toilet & Bathroom Fans

Cat No.

444119

444120

444121

Model

Standard fan

Standard fan plus timer

Standard fan plus humidistat m3/hr

78

78

78

Ltr/s

21.56

21.56

21.56

Watts dB(A)@3m

6 40

6

6

40

40

Domestic Range Part L Compliant

100mm Low Watt 4’’ Axial - Toilet & Bathroom Fans

Cat No.

444116

444117

444118

Model

Standard fan

Standard fan plus timer

Standard fan plus humidistat m3/hr

78

78

78

Ltr/s

21.56

21.56

21.56

Watts dB(A)@3m

6 40

6

6

40

40

Domestic Range Part L Compliant

Inline Mixed Flow Fan

Cat No.

442825

442826

Model

In-line standard fan 45Ltr per second

In-line standard fan 45Ltr per second plus timer

Speed m3/hr

High 244

Low

High

Low

180

244

180

Ltr/s

67.78

50

67.78

50

Watts dB(A)@3m

25 24

20

25

20

20

24

20

Domestic Range Part L Compliant

4’’ High Performance Centrifugal Fan

Cat No.

AC100TN

Model

Single speed fan with electronic over run timer m3/hr

75

Ltr/s

20.83

Watts dB(A)@3m

11 36

Low Profile Range

100mm 4’’ Low Profile (15mm) Axial and Low Voltage Axial

Cat No.

431301

431302

404119

434399

Model

Standard fan

Standard fan plus timer

Standard fan plus timer, Chrome

Standard SELV 12V fan plus timer m3/hr

90

90

90

90

Ltr/s

25

25

25

25

Watts dB(A)@3m

14 38

14

14

23

38

38

38

Low Profile Range

150mm 6’’ Low Profile (15mm) Slim Axial with Butterfly Shutters. IP44

Cat No.

435403

435404

435405

Model

Standard fan

Standard fan plus timer

Standard fan plus humidistat m3/hr

228

228

228

Ltr/s

63.33

63.33

63.33

Watts dB(A)@3m

16 45

16

16

45

45

Commercial Range

230mm 9’’ and 300mm 12 ‘‘ Axial Fans

Cat No.

401893

401896

Model

230mm 9’’ Standard fan plus auto shutters 259Ltr/sec

300mm 12’’ Standard fan plus auto shutters 415Ltr/sec

Speed m3/hr

High 932

Low

High

Low

684

1494

961

Ltr/s

258.89

190

415

266.94

Watts dB(A)@3m

90 52

90

100

100

51

53

52

Commercial Range

Fan Controller

Cat No.

401961

Model

2 Speed + off. Reversible

AIR TREATMENT

255

444769

1.0kW

Automatic

Eco Fast Dryer

• 1.2mm thick steel cover

• Epoxy coated

• Approximately 13 seconds drying time

• Infra Red Automatic

• H180xW250xD138.5mm

Automatic & Manual Hand dryers

for Commercial Applications

437656

Tornado

Hand Dryer

White

• 10-12 sec drying time

• Blue LED for hand drying range

• Powerful operation

• Lower Energy Usage

• Save up to 70% on energy costs

• 1.6kw - 240V

• H277xW201xD175mm

404164

TWISTER

Automatic Double Sided Hand Dryer

• 10-15 seconds drying time

• Built-in anti bacterial protection

• Powerful Operation

• Infrared automatic, self adjusting

• Ceramic splash plate

max. continued useage: 280

• Drain tray included

• H560xW322xD185mm

Tornado

Hand Dryer

437659

Polished Stainless Steel

437661

Satin Stainless Steel

• 10-12 sec drying time

• Blue LED for hand drying range

• Powerful operation

• Lower Energy Usage

• Save up to 70% on energy costs

• 1.6kw - 240V

• H277xW201

xD175mm

429022

1.5kW

Automatic

Hand Dryer

447481

JETDRY

Automatic Double

Sided Hand Dryer

• Approximately 10

seconds drying time

• Unique “blue dry zone”

indicator

• Powerful Operation

• Low energy usage

• H685xW300xD220mm

• White Gloss

• Approximately

30 seconds drying time

• Quiet Operation

• Hygienic

• H275xW225xD160mm

429021

2.0kW

Automatic

Hand Dryer with

Aluminium

Cover

• Die Cast Aluminium Cover painted white gloss

• Approximately 30 seconds drying time

• Quiet Operation

• Hygienic

• H275xW225xD160mm

2.4kW Heavy Duty

• 2.00mm thick steel cover

• Approximately 26 seconds drying time

• Powerful Operation

• Chrome plated nozzle

• H248xW284xD202mm

441097

Automatic

Chrome

441096

Automatic

White

256

441356

2.0kW Stainless

Steel Automatic

Hand Dryer

• Satin polished stainless steel cover

• Approximately 28 seconds drying time

• Quiet Operation

• Hygienic

• H280xW270

xD148mm

AIR TREATMENT

401936

2.4kW

Automatic

Heavy Duty

Hand & Face

Dryer

• Approximately 30 seconds drying time

• LM24 pressure die cast aluminium

• Powerful operation

• H264xW275xD177mm

441098

Manual

White

404120/21/32

404126/34

404122

404127/33

404124/37

404128/29

404123/36

404125

Flat Ducting

Cat No.

Model

100mm x 54mm Flat Ducting

404120

404121

404122

404123

404124

404125

404126

404127

404128

404129

404130

404131

Flat channel lengths 1m

Flat channel lengths 2m

Short round to rectangle adaptor male

Flat channel connector

Elbow bend 90º Male

Elbow bend 90º Female

Vertical 90º bend

Horizontal 90º bend

Horizontal air brick

Air brick grille

Flat channel clips pair

T Piece

204mm x 60mm Flat Ducting

404132

404133

404134

404135

404136

404137

404138

404139

404140

Flat channel lengths 1.5m

Horizontal 90º bend

Vertical 90º bend

Duct clip pair

Connector

Elbow bend 90º Male

Round to rectangle adaptor

Air brick connector and grille

T Piece

404130/35

404131/40 404138 404139

404141/42

404155

401900/01

404148

404153

401897/98

404144

404156

401901/02

404149

404159

401903/04

401905/06

404145

404150/51/52

404146/47

404154

404162

Additional Accessories

Cat No.

404141

404142

404143

404144

404145

404146

404147

Model

PVC Flexibe Ducting 100mm x 15m

PVC Flexibe Ducting 100mm x 45m

100mm x 350mm ABS Pipe

100mm diameter Y Piece

150mm - 100mm Reducer

100mm Round Grille White

100mm Round Grille Chrome

Multi Vent & Accessories

Cat No.

404148

404149

404150

404151

404152

404153

404154

Model

Whole house multi vent unit

80mm Inlet grille

PVC Flexibe Ducting 125mm x 6m

PVC Flexibe Ducting 80mm x 15m

PVC Flexibe Ducting 80mm x 6m

60-215mm Worm drive hose clip

125mm Wall kit

Heat Recovery Accessories

Cat No.

404155

404156

404157

404158

404159

404160

404161

404162

404163

Model

Extract diffuser

Supply diffuser

125mm x 90º Insulated bend

125mm x 2m Insulated pipe

125mm x 90º Uninsulated bend

125mm Uninsulated connector

125mm x 45º Insulated bend

125mm x 45º Uninsulated bend

125mm x 1.5m Ducting

Commercial Range

Ancillaries

Cat No.

Cat No.

401897

401898

401903

401904

401907

401908

401899

401900

401901

401902

401905

401906

401909

401910

Model

PVC Ducting 3m 100mm

PVC Ducting 3m 150mm

Gravity grille 100mm - white (401903) or brown (401905)

Gravity grille 150mm - white (401904) or brown (401906)

Fixed grille 100mm - white (401907) or brown (401909)

Fixed grille 150mm - white (401908) or brown (401910)

Window fixing kit 100mm

Window fixing kit 150mm

Wall fixing kit 100mm

Wall fixing kit 150mm

AIR TREATMENT

257

Living innovation

Air Purifiers

Are you sensitive to pollen or dust? Do you have hairy pets? Tired of kitchen smells? Been decorating and room filled with paint fumes? For all these reasons, and many more, you need the latest innovation from De’Longhi – introducing a new range of Air Purifiers. Designed for different room capacities and with colour changing lights which reveal the quality of the air around you*.

Did you know that indoor air pollution is among the top five environmental health risks, and we spend more than 80% of our time in a closed environment – that’s why it’s important to keep it clean!

2

DUST & PET

ALLERgIES

POLLEN

ALLERgIES

AIR

POLLUTION

HOUSEHOLD

ODOURS

TOBACCO

SMOKE

DECORATINg

FUMES

BACTERIA MOULD

VIRUSES

AC230 AC150 AC100

Dehumidifiers

Watch the video @

www.delonghi.com/uk_en/page/air-purifiers

A dehumidifier removes the excess moisture that we create on a daily basis through activities such as running baths, showers, cooking and drying laundry. All of which could lead to condensation, damp and mould that can damage your home and health. A dehumidifier can help maintain a more constant level of humidity and alleviate these conditions. The higher the extraction rate, the more condensation will be controlled.

AC230

AC150

AC100

DNC65

DES16E

DES14

DES12

DEM10

258

DNC65

DES16E DES14/12

DEM10

Dimensions Rated Voltage/ For rooms

(w x d x h) cm Frequency up to (m

2

)

45 x 23 x 50 220-240V 50-60

Anti Frost

Function

Timer

80 8hr

39x21x45 220-240V 50-60

39x21x45 220-240V 50-60

40

40

8hr

8hr

32.4x18.7.48.3

19x37.5x48.5

220-240V 50-60

220-240V 50-60

55

75

Electronic Air Quality Gas & Odour

Climate Control System Sensor

Pre-Filter

(washable)

XL size

HEPA

Filter

XL size

Active Carbon

Filter

Nano-silver Ti02 Filter

Filter (washable) +UV (permanent)

XL size XL size

Ioniser

Moisture Tank

Removal (L/24hr) Capacity

• •

8hr 6

16

2

3

37.5x19x48.5

220-240V 50-60

37.5x19x48.5

220-240V 50-60

33x25x42 220-240V 50-60

65

65

50

14/12

14/12

3

3

No of years

2

2

2

2

2

2

2

10 2 2

*Available on AC230 and AC150

AIR TREATMENT

All De’Longhi dehumidifiers come with a 2 year parts and 1 year labour guarantee.

* room sizes are given as an approximate guide

A versatile range of Compact, High Speed, Energy Efficient and Heavy Duty hand dryers.

Compact

Hand Dryers

High quality, low maintenance hand dryers for commercial applications

• Attractive ABS housing offers high resistance against fire, cigarette burns, water, sunlight and organic detergents

• Self re-setting overheat thermostat provides over-temperature protection should the hand dryer airflow be

deliberately blocked

• Each dryer includes a wall fixing template for easy and rapid installation

• Anti-tamper cover (fixing screws included)

2 YEAR GUARANTEE

1005

• 1.9kW compact

• Push button

• For light use in shops, offices, public houses etc.

• Provides 45 seconds drying time

1006

• 1.9kW compact

• Automatic

• For use in clinics, restaurants, kitchens, etc. where high levels of hygiene are required

Compact High Speed

Energy Saving Hand

Dryers

• For use in schools, kitchens, restaurants and places where high levels of hygiene are required

• High-speed low power motor dries hands quicker reducing energy consumption compared to

conventional hand dryers

• Changeable heat settings to suit environment

• Standby / Power-On LED indicator

3 YEAR GUARANTEE

1016WH

• 1.1kW High Speed

• Automatic

• 10 to 15 seconds drying time

1016SL

• 1.1kW High Speed

• Automatic

• 10 to 15 seconds drying time

Heavy Duty High Speed

Energy Saving Hand

Dryers

• For use in public washrooms, factories, sports establishments, schools & colleges etc.

• Durable, vandal resistant casing with tamper-proof fixings included

• Self re-setting overheat thermostat provides over-temperature protection should the hand dryer

airflow be deliberately blocked

• Standby / Power-On LED indicator

3 YEAR GUARANTEE

1019WH

• 1.8kW High Speed Heavy Duty

• White Steel

• Automatic

• 10 to 15 seconds drying time

1019CH

• 1.8kW High Speed Heavy Duty

• Polished Chrome Steel

• Automatic

• 10 to 15 seconds drying time

AIR TREATMENT

259

The fastest, most hygienic hand dryers.

The new Dyson Airblade™ hand dryers are powered by the Dyson digital motor V4 – one of the world’s smallest, fully-integrated 1600W motors. Its small size and power density are what have made our latest hand dryer technology possible.

It means you’ll now find three different formats of Airblade™ technology: quieter, smaller and one that dries hands at the sink. They all have fast dry times, use HEPA-filtered air and cost less to run than warm air dryers and paper towels.

260

AIR TREATMENT

50% quieter

1

. Acoustically re-engineered to reduce noise.

10 second dry time.

HEPA filter removes 99.9% of bacteria.

Approved for use in food environments by HACCP.

Robust, vandal-proof design.

Tough and durable.

Contains antibacterial additive.

AB14 grey

AB14 White

AB14 H 661mm W 303mm D 247mm

Grey White

Concentrated

Airblade

technology.

10 second dry time.

HEPA filters remove 99.9% of bacteria.

60% smaller than the original

Dyson Airblade

hand dryer.

Slim profile – just four inches deep, no recessing required.

Contains antibacterial additive.

AB08 Sprayed nickel

AB08 White

AB08 H 394mm W 234mm D 100mm

Sprayed nickel White

Airblade

hand drying technology in a tap.

12 second dry time.

HEPA filter removes 99.9% of bacteria.

Approved for use in food environments by HACCP.

Wash and dry hands at the sink, prevents water dripping on the floor.

AB09 Short

AB10 Long

AB11 Wal

AB09 H 158.5mm W 295mm D 280.5mm

AB10 H 308mm W 295mm D 280.5mm

AB11 W 295mm D 305mm

1

When compared to the original Dyson Airblade

hand dryer.

Short Long

AIR TREATMENT

Wall

261

ELECTROLUX OUTDOOR

PRODUCTS

ELECTROLUX OUTDOOR

PRODUCTS

White out

ELECTROLUX OUTDOOR

PRODUCTS

Portable Air Conditioner Systems

High performance portable air conditioners featuring the latest heat pump and energy saving technology, to deliver hot or cold air at the touch of a button. The units are fitted with tough casters so that it can be easily moved from room to room and a ducted exhaust hose to vent the hot air to the outside of the building. The auto restart after power failure function gives the unit the ability to work in critical heating or cooling applications such as a server room.

• 4 Operation modes: Cool, Heat, Dehumidify & Fan

• Heat pump technology

• Digital remote control

• A/A+ Energy efficiency (heat/cool)

• Adjustable fan speeds

• Auto-oscillating air vanes

• 24hr Timer

• Air filters to remove dust & odours

• Sleep function

• Full auto mode

Model

Power Rating

Capacity BTU/h

Power Input W (C/H)

Current Input A (C/H)

EER (BTU/hr.w)

COP (w/w)

Noise dB(A) (High/Med/Low)

Dehumidification (L/h)

Air volume (CFM) (High/Med/Low)

Net Dimension (mm) W/D/H

Net Weight (kg)

Max Room Size

EXP09HN1WI

220-240V / 50Hz

9000 (2.6kW)

960/810

4.4/3.6

2.7

2.82

63/60/57

1.2

386/327/305

465x397x764

30.5

18m

3

EXP12HN1WI

220-240V / 50Hz

12000 (3.3kW)

1290/1070

5.7/5.0

2.6

2.73

64/61/58

1.5

386/327/305

465x397x764

34.0

24m

3

Portable Dehumidifiers

Designed for healthier living, providing optimum humidity levels in your home, helping to prevent the growth of mould and bacteria. Adjust the fan speed easily with the LCD screen and touch button controls and sit back and relax while removing excess humidity from the air. With the convenient 24-hour timer you can delay the dehumidifier so it starts as soon as you get in and the large 5-litre water tank will have you visiting the sink to refill less often and the compact design won’t be a burden on your interior design.

Key Product Features:

• 2 Fan speeds

• 24hr Timer & delay start

• Digital display

• Antibacterial filter

• 5 Litre water tank

• Tank full indicator

• Removable/visible water tank

• Continuous drain option

Model

Power

Noise dB(A)

Extraction rate (Ltr/24hr)

Max Room Size

Net Dimension (mm) W/D/H

Net Weight (kg)

EXD15DN3W

315W

53

15

75m 2

370x293x503

12.7

EXD25DN3W

745W

53

25

120m 2

370x293x503

16.8

262

AIR TREATMENT

The Honeywell range of low cost and easy to maintain

Evaporative Air Coolers have been selected to suit commercial and domestic applications.

CO60PM

• Areas up to 80m

3

• Suitable for indoor

and outdoor use

• Large fan with high

air flow 2610m

2

/hr

• Continuous Water

Supply and Low

water cut-off

• Three sided

cooling filters

80m

3

CL48PM

• Areas up to 57m

3

• Suitable for indoor

and outdoor use

• Continuous Water

Supply and Low

water cut-off

• Three sided

cooling filters

• Adjustable louvres

57m

3

CO301PC

• Areas up to 43m

3

Touch panel control

• Suitable for indoor

and outdoor use

• Three sided

cooling filters

• Continuous Water

Supply and Low

water cut-off

• Remote control

43m

3

CHS30XC

• Areas up to 30m 3

• Integral heater

• Low water alarm

• Digital controls

• Easy fill detachable

water tank

• Remote control

30m

3

CHS12AE

• Areas up to 12m

3

• Integral heater

• Low water alarm

• Digital controls

• Remote control

12m

3

Water inlet & continuous water supply connector

Digital touch control panel

Can slots and top storage compartment

MODEL

Room Size

Air Flow

Motor Power

Tank Capacity

Low Water Pump Cut-off

Continuous Water Feed

Dimensions (mm) (LxWxH)

CO60PM CL48PM CO301PC CHS30XC CHS12AE

80m

3

57m

3

43m

3

30m

3

12m

3

2610m

2

/hr 1800m

2

/hr 1410m

2

/hr 900m

2

/hr 460m

2

/hr

220watts 140watts 270watts 252watts 65watts

60Ltrs 48Ltrs 30Ltrs 30Ltrs 12Ltrs

Yes

Yes

Yes

Yes

Yes

Yes

Alarm Alarm

No No

700x466x1017 620x375x868 433x570x1131 458x352x856 380x310x724

HOW IT WORKS:

An evaporative cooler cools the air naturally in a similar way to a sea breeze. Warm air is passed over a specially designed filter which then converts to cool air being pushed into the room. An evaporative cooler will reduce the ambient temperature by up to 30%, depending on the humidity in the room. To work effectively it is advisable to have a source of fresh air coming in and a way of expelling the warm air back out of the area to be cooled

(for example open doors or windows).

PUMP

WATER

Evaporative air coolers

The Honeywell range of low cost and easy to maintain

Evaporative Air Coolers have been selected to suit commercial and domestic applications.

CO60PM

• Areas up to 80m

3

• Suitable for indoor

and outdoor use

• Large fan with high

air flow 2610m

2

/hr

• Continuous Water

Supply and Low

water cut-off

• Three sided

cooling filters

80m

3

CL48PM

• Areas up to 57m

3

• Suitable for indoor

and outdoor use

• Continuous Water

Supply and Low

water cut-off

• Three sided

cooling filters

• Adjustable louvres

57m

3

CO301PC

• Areas up to 43m

3

Touch panel control

• Suitable for indoor

and outdoor use

• Three sided

cooling filters

• Continuous Water

Supply and Low

water cut-off

• Remote control

43m

3

CHS30XC

• Areas up to 30m 3

• Integral heater

• Low water alarm

• Digital controls

• Easy fill detachable

water tank

• Remote control

30m

3

CHS12AE

• Areas up to 12m

3

• Integral heater

• Low water alarm

• Digital controls

• Remote control

12m

3

Water inlet & continuous water supply connector

Digital touch control panel

Can slots and top storage compartment

MODEL

Room Size

Air Flow

Motor Power

Tank Capacity

Low Water Pump Cut-off

Continuous Water Feed

Dimensions (mm) (LxWxH)

CO60PM CL48PM CO301PC CHS30XC CHS12AE

80m

3

57m

3

43m

3

30m

3

12m

3

2610m

2

/hr 1800m

2

/hr 1410m

2

/hr 900m

2

/hr 460m

2

/hr

220watts 140watts 270watts 252watts 65watts

60Ltrs 48Ltrs 30Ltrs 30Ltrs 12Ltrs

Yes

Yes

Yes

Yes

Yes

Yes

Alarm Alarm

No No

700x466x1017 620x375x868 433x570x1131 458x352x856 380x310x724

HOW IT WORKS:

An evaporative cooler cools the air naturally in a similar way to a sea breeze. Warm air is passed over a specially designed filter which then converts to cool air being pushed into the room. An evaporative cooler will reduce the ambient temperature by up to 30%, depending on the humidity in the room. To work effectively it is advisable to have a source of fresh air coming in and a way of expelling the warm air back out of the area to be cooled

(for example open doors or windows).

PUMP

WATER

AIR TREATMENT

263

CEILING FANS

REMOTE CONTROL FOR USE WITH

ALL NON-COMMERCIAL FANS

Santa Monica

(Polished Brass)

264

Commercial &

Industrial Fans

• Complies with all European

standards CE/EMC

• Quiet vibration free operation

• Energy efficient

• Variable speed capability

• Tough powder coated paint finish

• Pre assembled for easy installation

• Reversible for summer and

winter applications

Rimini

Kroma

San Diego

(Polished Brass)

Rio

(White)

Bali

Neptune

(Stainless Steel)

Remote control supplied

Atlanta

San Diego

(White & Brass)

Nickel

Black

Commercial &

Industrial Fan

Accessories

RV01

SIC1

Rio

(White & Brass)

Scorpion

Cream

Blue

Genoa

RV05N

Santa Monica

(Stainless Steel)

Neptune

(White)

White

Red

AIR TREATMENT

Commercial Fans

CAT NO SIZE COLOUR

111870 36”

111887

111894

48”

56”

White

Accessories

DESCRIPTION

RF Remote Control

RV01

SIC1

RV05N

DESCRIPTION

Reversible, Complete with 12” Drop Rod

Reversible, Complete with 12” & 24” Drop Rods

Available separately

Controls one fan only - with reverse function

Controls one fan only - no reverse function

Controls up to 5 fans - with reverse function

Rimini

SIZE COLOUR

36”

42”

White

Kroma

SIZE COLOUR

36”

Chrome

DESCRIPTION

Globe light, Reversible White/White & Cane Blades, Dual mount

DESCRIPTION

Complete with 6” Drop Rod, Operated by pull cords

Genoa

SIZE COLOUR

42” White

DESCRIPTION

3 Light Kit, White Blades, Dual mount, 3 x 60W G9 lamps included

Atlanta

SIZE COLOUR

30”

White

DESCRIPTION

3 Speed, Forward & Reverse Settings Pull cord Operation,

Single Gloge Light, 4” Drop Rod, Dual Mount

San Diego

SIZE COLOUR

42”

DESCRIPTION

Polished Brass 3 Light Kit, Reversible Oak & Cane/Mahogany Blades, Dual mount

White & Brass 3 Light Kit, Reversible White/ White & Cane Blades, Dual mount

Rio

SIZE COLOUR

36”

White

42”

DESCRIPTION

3 Light Kit, Reversible White/ White Blades, Dual mount

White & Brass 3 Light Kit, Reversible White/ White & Cane Blades, Dual mount

White 3 Light Kit, Reversible White/ White Blades, Dual mount

White & Brass 3 Light Kit, Reversible White/ White & Cane Blades, Dual mount

Bali

SIZE COLOUR

42”

Stainless Steel

DESCRIPTION

Directional Halogen Light Kit, Reversible Beech/Maple Blades,

Dual mount, 3 x GU10 lamps included

Scorpion

SIZE COLOUR

48”

Chrome

DESCRIPTION

Directional 3 Light Spots, Reversible Washed Oak Blades,

Dual mount

Santa Monica

SIZE COLOUR

42”

Polished Brass

Stainless Steel

DESCRIPTION

Remote Control, 3 Light Kit, Reversible Oak & Cane/Mahogany

Blades, Dual mount

Remote Control, 3 Light Kit, Reversible Washed Oak Blades,

Dual mount

Neptune

SIZE COLOUR

White

52”

Stainless Steel

DESCRIPTION

Remote Control, 100W Halogen Light, White Blades, Dual mount

Remote Control, 100W Halogen Light, Stainless Steel Blades,

Dual mount

10” Retro Desk Fan

CAT NO

119005

119012

119029

119081

119067

119074

DESCRIPTION

Fan Retro 25cm 30W White

Fan Retro 25cm 30W Black

Fan Retro 25cm 30W Nickel

Fan Retro 25cm 30W Cream

Fan Retro 25cm 30W Red

Fan Retro 25cm 30W Blue

12” Drop Rods, Available to match All Fan Finishes

Please Contact Your local Branch For Details.

SFGP16A

16” Pedestal Fan l

Oscillating control & tilt action l

Fully guarded plastic blades l

Metal mesh safety cover l

3 Speed settings

SFG9A

9” Desk Fan l

Oscillating control

& tilt action l

Fully guarded plastic blades l

Metal mesh safety cover l

2 Speed settings

WALL MOUNTED

VERSIONS AVALABLE

SFG9 & SFG12

SFG12A

l l

12” Desk Fan

Oscillating control & tilt action

Fully guarded plastic blades l l

Metal mesh safety cover

3 Speed settings

SFG16A

16” Desk Fan l l l

Oscillating control & tilt action

Fully guarded plastic blades

Metal mesh safety cover l

3 Speed settings

STF1A

Manual Tower Fan l

75 degree angle oscillation l

3 Speed settings

STF1RA

Remote Tower Fan l

Remote control l

Up to 7.5 hour timer l

75 degree angle oscillation l

3 Speed settings

SPF18A

18” Power Fan l

Tilt action l

Fully guarded blades l

Metal mesh safety cover l

3 Speed settings

SWFM16

16” Manual Wall Fan l

Oscillating control & tilt action l

Fully guarded plastic blades l

Metal mesh safety cover l

3 Speed settings

SWFR16

16” Remote Wall Fan l

Oscillating control & tilt action l

Fully guarded plastic blades l

Metal mesh safety cover l

3 Speed settings l

Remote control l

0.5-7.5 hour timer

SFG6CA

6” Clip Fan l

Fully guarded plastic blades l

Mesh safety cover l

2 Speed settings

AIR TREATMENT

265

Silent Fan 100

Axial Bathroom and Toilet Fan

shhhh!

75% quieter - Just 16dB(A)

Silent 100mm Axial

Bathroom/Toilet Fans

Stock Ref

446658

446659

Model

VASF100B

VASF100T

The quietest bathroom fan on the market. The VASF100 provides stylish and silent ventilation without compromising on performance. Complies with current building regulations Part F&L.

• Silent intermittent bathroom fan with two speeds

• Stylish discrete design

• Backdraught shutters included

• High efficiency motor

• 2 year guarantee

• IP44 rated

• Standard Thermal Overload Protection on motor

• Suitable for wall, ceiling, window and

• panel mounting

Compatible with low energy lighting m 3 /hr Watts dB(A)@3m

Low Speed High Speed Low Speed High Speed Low Speed High Speed Shutters

54

54

76

76

4.3

4.3

Performance

6.8

6.8

16

16

28

28

P

P

Timer

P

Slimline 100 / 150

Axial Bathroom, Toilet & Kitchen Fan

Features & Benefits

• Slimline 15mm Profile

• Panel or Wall Mounted

Stock Ref

436530

436532

436533

436535

Model

BAS100SLB

BAS100SLT

BAS150SLB

BAS150SLT m 3 /hr

90

90

228

228

• IP44 (100m) & IPX4 Rated (150mm)

Performance

Watts

14

14

16

16 dB(A)@3m

38

38

45

45

Shutters

P

P

P

P

Timer

P

P

266

Eclipse 100 / 150

Axial Bathroom, Toilet & Kitchen Fan

Features & Benefits

• Slimline 19mm Profile

• Panel or Wall Mounted

Stock Ref

427310

427281

427282

427283

427313

Model

Eclipse 100X

Eclipse 100XP

Eclipse 100XT

Eclipse 150X

Eclipse 150XP

• IP44 (100m) & IPX4 Rated (150mm) m

3

/hr

93

93

93

258

258

Performance

Watts dB(A)@3m Shutters

P 15

15

15

22

37

37

37

37

P

P

P

22 37 P

Timer

P

Pullcord

P

P

AIR TREATMENT

Silhouette

®

100/150

Axial Bathroom, Kitchen and Toilet Fan

Features & Benefits

• Panel or Wall Mounted

• Window Mounted (100 only)

• Slimline 17 or 19mm Profile

• IPX4 Rated

Performance

Watts dB(A)@3m Shutters PIR Timer Humidity Stock Ref Model m 3 /hr

454055 Silhouette 100B

454056 Silhouette 100T

454057 Silhouette 100H

454058 Silhouette 100TM

454059 Silhouette 150X

75

75

75

75

241

14

14

14

14

20

38

38

38

38

43

P

P

P

P P

P

P

P

P

454060 Silhouette 150T 241 20 43 P P

454061 Silhouette 150H 241 20 43 P

Silhouette 100 - Wall Kit - Brown - 254100 - Wall Kit - White - 254102 -

Silhouette 150 - Wall Kit - Brown - 140903 - Wall Kit - White - 140902 -

P

Lo-Carbon Silhouette ®

Axial Bathroom, Toilet & Kitchen Fan

Features & Benefits

Lo-Carbon Energy Saving

Slimline 17 or 19mm Profile

• 5 Year Motor Guarantee

• IPX4 Rated (IPX7 SELV)

Max Performance

Stock Ref Model

441624 Lo-Carbon Sil 100B m

3

/hr

60

Watts

3.4

dB(A)@3m Shutter

34 P

Timer Humidity

441625

441626

441628

Lo-Carbon Sil 100T

Lo-Carbon Sil 100H

Lo-Carbon Sil 150B

60

60

241

3.4

3.4

7.5

34

34

35

P

P

P

P

P

441629 Lo-Carbon Sil 150T 241 7.5

35 P P

441630 Lo-Carbon Sil 150H 241 7.5

35 P

Silhouette 100 - Wall Kit - Brown - 254100 - Wall Kit - White - 254102 -

P

Silhouette 150 - Wall Kit - Brown - 140903 - Wall Kit - White - 140902 -

Minivent

Inline Shower Fan Kit

Features & Benefits

• Inline Fan

• IP44 Rated

Stock Ref

248710

248810

Model

Minivent SK

Minivent SKT m

3

/hr

108

108

• Integral Shutter

• Complete Installation Kit

Performance

Watts dB(A)@3m

20

20

37

37

Shutter

P

P

Timer

P

Lo-Carbon Vent-A-Light

Inline Shower Fan and Light Kit

Features & Benefits

• New LED lamp uses 90% less power

than a standard Dichroic lamp

Stock Ref

441423

441424

Model

Lo-Carbon Vent-A-Light

Lo-Carbon Vent-A-Light T

• Suitable for shower enclosure and wet areas

• Lumens output 180lm – 200lm m 3 /hr

110

110

Performance

Watts (fan)

6.5

6.5

dB(A)@3m

23

23

• Meets current Building Regulations

Approved Document F & L

Timer

P

Luminair

Inline Fan and Light Fan Kit

Features & Benefits

• Fan and Light Kit

• Safety Extra Low Voltage Fan and Lamp

Stock Ref

453410

453413

453416

Model

Luminair Kit L

Luminair Kit T

Luminair Kit H m 3 /hr

110

110

110

• IPX7 Rated

• Chrome, White and Gold Bezel Available

Performance

Timer Watts

40

40

40 dB(A)@3m

35

35

35

P

P

Humidity

P

AIR TREATMENT

267

VA100

Axial Bathroom and Toilet Fan

Features & Benefits

• Panel, Window or Wall Mounted

• IPX4 Rated

• Standard Thermal Overload Protection

Meets Building Regulations Approved Document F

Stock Ref Model

251110

251210

251310

251410

251610

251710

VA100LP

VA100LT

VA100XP

VA100XT

VA100LHP

VA100XHP m 3 /hr

107

107

107

107

107

107

Performance

Watts

13

15

15

18

18

18 dB(A)@3m

36

36

36

36

36

36

Shutters Pullcord

P

P

P

251510 VA100XHT 107 18 36 P

Wall Kit - Brown: 254100 - White: 254102 -

Window Kit: 254101 -

P

P

P

Timer Humidity

P

P

P

P

P

P

VA140/150

Axial Kitchen Fan

Features & Benefits

Panel, Window or Wall Mounted

IP44 Rated

• Standard Thermal Overload Protection

• Meets Building Regulations Approved Document F

Performance

Stock Ref Model

140120

140220

140320

140420

VA140/150KP

VA140/150KT

VA140/150KHP

VA140/150KHT m 3 /hr

245

245

245

245

Watts

18

18

18

18 dB(A)@3m

36

36

36

36

Shutters Pullcord

P

P

P

P

458915 VA140/150VS* 245 18 36

P

* Variable Speed

Wall Kit - Brown: 140903 - White: 140902 -

Window Kit: 140901 -

P

P

Timer

P

P

Humidity

P

P

Solo Plus

®

Centrifugal Bathroom & Toilet Fan

Features & Benefits

• Surface or Recess Mounting

• Trickle / Medium / High Speeds

Stock Ref Model

427477 Solo Plus P

427478

427479

427480

Solo Plus T

Solo Plus HT

Solo Plus TM

17.1

17.1

40.8

40.8

• Adjustable Rear or Side Exit Spigot

• IPX4 Rated

Performance m 3 /hr Watts dB(A)@3m Humidity Timer

80

80

80

80

17.1

17.1

40.8

40.8

P

P

P

P

Pullcord

P

PIR

P

268

Centrif

®

Duo Plus

Centrifugal Kitchen Fan

Features & Benefits

• Surface or Recess Mounting

• Trickle / Boost Speed on DP and HTP

• HTP Installation Speed Setting for Kitchen or Utility

Performance

Stock Ref Model

431613 Centrif Duo Plus P

431614

431615

431616

Centrif Duo Plus T

Centrif Duo Plus DP

Centrif Duo Plus HTP

• Meets Building Regulations Approved Document F

IP44 Rated m 3 /hr Watts dB(A)@3m Humidity Timer Pullcord Dual Speed

220

220

60

60

51.8

51.8

P

P

220

220

60

60

51.8

51.8

P P

P

P

P

AIR TREATMENT

T-Series

Traditional Axial Commercial Fans

Features & Benefits

• Fully Speed Controllable

• Panel, Window, Wall or Roof versions available

• Reversible for Intake / Extract

Stock Ref

W161510

W163510

W164510

W161110

W163110

W164110

W161610

W163610

W164610

Model

TX6WL

TX9WL

TX12WL

TX6WW

TX9WW

TX12WW

TX6PL

TX9PL

TX12PL

• Low Sound Levels

• Available in 4 Sizes 6"/ 7"/ 9"/12"

• Electronic Shutter System m 3 /hr

Performance (High)

Watts dB(A)@3m

395

870

40

85

43

43

1745

360

795

105

30

85

49

41

43

1615

435

960

1885

105

30

85

105

48

41

43

44

Size

6 Inch

9 Inch

12 Inch

6 Inch

9 Inch

12 Inch

6 Inch

9 Inch

12 Inch

Fitting

Wall

Wall

Wall

Window

Window

Window

Panel

Panel

Panel

ACM

Inline Mixed Flow Fan

Features & Benefits

• Available in 6 Sizes

• IP44 (ACM100-200) IP54 Rated (ACM250-315)

Stock Ref

17104010

17104020

17105010

17106010

17106020

17108010

17110010

17112010

Model

ACM100

ACM100T

ACM125

ACM150

ACM150T

ACM200

ACM250

ACM315 m

3

/hr

0.071

0.071

0.091

0.145

0.145

0.25

0.277

0.517

Performance

Watts

18

23

25

42

48

114

145

270 dB(A)@3m

20

23

20

31

35

32

52

56

Timer

P

P

Hand Dryers

Stock Ref Model

427935 EasyDry

436297 EasyDry

427936

EasyDry +

435424 Turbodry

435427 Turbodry

435430 Turbodry

437231 Tempest

439464 Tempest

439463 Tempest

403606 JetDry3 ®

Power

1KW

1.5KW

2KW

2.4KW

2.4KW

2.4KW

450-900W

450-900W

450-900W

400-750W

Control

Auto

Auto

Auto

Manual

Auto

Auto

Auto

Auto

Auto

Auto

Case

ABS

ABS

Metal

Metal

Metal

Metal

Metal

Metal

Metal

Plastic

Features

10 -15 sec. dry

P

P

P

P

Colour

White

White

White

White

White

Chrome

White

Satin Stainless

Polished Stainless

White

Other Ranges Available

Did you know

Vent-Axia provides a heating and design service?

Please visit www.vent-axia.com/design-service for more details.

Heat Recovery Units Heating Industrial Fans

AIR TREATMENT

269

Domestic Bathroom Fans

DX100 100mm (4”) axial extract fans complete with universal fitting kit

• Single speed short duct

• Lubricated for life motors with thermal cut-out

Cat No.

DX100

DX100PC

DX100T

Reference

90839AW

90840AW

90841AW

DX100HTA

92567AW

DX100HTAP

92568AW

DX100PIR

90844AW

Timer

No

No

Yes

Yes

Yes

No

Pullcord Humidistat Speeds

No

Yes

No

No

Yes

No

No

No

No

Yes

Yes

No

1

1

1

1

1

1

m³/h

76

76

76

76

76

76

Maximum

Watts

12

12

12

12

12

12

dB(A)@3m

35

35

35

35

35

35

LV100 100mm (4”) SELV axial extract fans complete with universal fitting kit

• Can be installed in zones 1 and 2 • Transformer to be located out of zones

Cat No.

LV100

Maximum

Reference Timer Pullcord Humidistat Speeds m³/h Watts dB(A)@3m

90845AW No No No 1 85 13 37

LV100PC

LV100T

90846AW

90847AW

LV100HTA

92569AW

LV100HTAP

92570AW

LV100PIR

90867AW

No

Yes

Yes

Yes

No

Yes

No

No

Yes

No

No

No

Yes

Yes

No

1

1

1

1

1

85

85

85

85

85

13

13

13

13

13

37

37

37

37

37

Slimline SL100 & SLDC100 100mm (4”) low profile axial extract fans

• ‘Quick Clamps’ for easy installation • SLDC models feature long life, low energy DC motors

Cat No.

SL100STD

SL100T

SL100HT

Reference

92674AW

92676AW

92677AW

SL100PIR

SLDC100

92678AW

92679AW

SLDC100T

92681AW

SLDC100HT

92682AW

SLDC100PIR

92683AW

Timer

No

Yes

Yes

No

No

Yes

Yes

No

Pullcord Humidistat Speeds

No

No

No

No

No

No

No

No

No

No

Yes

No

No

No

Yes

No

1

1

1

1

1

1

1

1

m³/h

72.5

72.5

72.5

72.5

65

65

65

65

Maximum

Watts

11

11

11

11

4.2

4.2

4.2

4.2

dB(A)@3m

32

32

32

32

33

33

33

33

Contour C100 & CDC100 100mm (4”) axial extract fans with new contoured fascia

• Discreet and stylish design • Built-in backdraught shutter fitted

Cat No.

C100

C100P

C100T

C100HT

CDC100P

CDC100T

CDC100HT

Maximum

Reference Timer Pullcord Humidistat Speeds m³/h Watts dB(A)@3m

92899AW

92855AW

No

No

No

Yes

No

No

1

1

72.5

72.5

11

11

32

32

92856AW

92857AW

92877AW

92878AW

92879AW

Yes

Yes

No

Yes

Yes

No

No

Yes

No

No

No

Yes

No

No

Yes

1

1

3

3

3

72.5

72.5

65

65

65

11

11

4.2

4.2

4.2

32

32

33

33

33

270

AIR TREATMENT

Avantgarde AV100 100mm (4”) shuttered axial extract fans

• ‘Quick Clamps’ for easy installation • Integral thermo electric shutters

Cat No.

AV100

AV100P

AV100T

AV100HT

AV100PIR

Maximum

Reference Timer Pullcord Humidistat Speeds m³/h Watts dB(A)@3m

92691AW

92692AW

No

No

No

Yes

No

No

1

1

85

85

15

15

32

32

92693AW

92694AW

92695AW

Yes

Yes

No

No

No

No

No

Yes

No

1

1

1

85

85

85

15

15

15

32

32

32

Premier DX200 & CF20 Centrifugal extract and condensation control fans

• Can be surface or recess mounted • Designed to manage longer duct run applications

Cat No.

DX200

DX200T

CF20

CF20T

Maximum

Reference Timer Pullcord Humidistat Speeds m³/h Watts dB(A)@3m

91013AW

91014AW

No

Yes

No

No

No

No

2

4

108

79

34

34

50

50

91015AW

91016AW

No

Yes

Yes

Yes

Yes

Yes

5

5

108

108

34

34

50

50

Premier LVDX, LVCF, DC2 & DC3 Centrifugal extract and condensation control fans

• Intermittent operation on DC2/DC3 models • Transformer supplied with LVDX & LVCF models

Cat No.

LVDX200T

LVCF20

LVCF20T

Reference Timer

91040AW

91041AW

91042AW

LVCF20T DC2

92335AW

Yes

No

Yes

Yes

Pullcord Humidistat

No

No

No

No

No

Yes

Yes

Yes

Speeds

2

5

5

3

m³/h

108

108

108

54

Maximum

Watts

42

42

42

5.6

dB(A)@3m

50

50

50

32

CF20T DC3

92576AW Yes No Yes 3 54 5.6

32

XIL & XXS Inline axial extract fan systems for shower cubicles

• Removes stale air via a grille installed above the shower

• Thermal cut-out protection

Cat No.

XIL100

XIL100T

XIL125

XIL125T

Reference Timer Size (mm)

90329AW No 100

90330AW

91242AW

91243AW

Yes

No

Yes

100

125

125

Installation Kit

Yes

Yes

Yes

Yes

m³/h

54

54

63

63

Maximum

Watts dB(A)@3m

29

29

20

20

30

30

43

43

XIM 100 & 125 Inline mixed flow extract fans for domestic ducted applications

• Lubricated for life motors

• Supplied with convenient installation mounting cradle

Cat No.

XIM100

XIM100T

XIM100+

XIM100+T

XIM125

Reference Timer

91252AW No

91253AW

91254AW

Yes

No

91473AW

91255AW

Yes

No

Size (mm)

100

100

100

100

125

Maximum

Speeds m³/h Watts dB(A)@3m

1

1

77

77

25

25

14

14

2

2

2

251

251

265

25

25

25

22

22

25

AIR TREATMENT

271

BriteX LV & Turbo+ Inline shower fan and SELV light systems for shower cubicles

• Supplied with 12V 35W dichroic lamp • Extracts condensation laden air from above the shower

Cat No.

BX100W

BX100WT

BX100C

BX100CT

BX100+W

BX100+WT

BX100+CT

Maximum

Reference Duct Length Supplied (m) Bezel Colour m³/h Watts dB(A)@3m

92276AW

92277AW

92278AW

92279AW

3

3

3

3

White

White

Chrome

Chrome

58

58

58

58

30

30

30

30

36

36

36

36

91248AW

91250AW

91251AW

6

6

6

White

White

Chrome

74

74

74

25

25

25

55

55

55

Domestic Kitchen Fans

GX6 & GXC6 150mm (6”) axial extract fans

• Trickle ventilation facility available

Cat No.

GX6

GX6T

GX6HT

GX6HT2

GXC6T

GXC6

• Can be wall, window or panel mounted

Maximum

Reference Timer Pullcord Humidistat Speeds m³/h Watts dB(A)@3m

90800AW

90812AW

No

Yes

No

Yes

No

No

1

1

266

266

30

30

37

37

90814AW

90863AW

90861AW

90850AW

Yes

Yes

Yes

No

Yes

Yes

Yes

Yes

Yes

Yes

No

No

1

2

1

1

266

266

266

266

30

30

30

30

37

37

37

37

GX6 EC3 & GX6 EC3 RF 150mm (6”) axial extract fans

• Energy efficient EC motors

Cat No.

GX6 EC3

Reference Pullcord

92755AW No

GXC6 EC3

GX6 EC3R

GX6 EC3 RF

92756AW

92728AW

92731AW

GX6 EC3R RF

92732AW

Yes

No

No

No

Description

GX6 EC3 RF ConneX Controller

GX6 EC3R RF ConneX Controller

Extract m³/h

284

284

284

284

284

Reference

92790AW

92791AW

• RF models require a ConneX wireless radio frequency controller

Maximum

Intake m³/h

-

-

182

-

182

Watts dB(A)@3m

10.6

30.3

7.9

11.9

10.8

11.9

30.3

30.3

30.3

30.3

272

Avantgarde AV150 & AVDC150 150mm (6”) shuttered axial extract fans

• Integral thermo electric shutter • ‘Quick Clamps’ for easy installation

Cat No.

AV150

AV150P

AV150T

AV150HT

Maximum

Reference Timer Pullcord Humidistat Speeds m³/h Watts dB(A)@3m

92711AW

92712AW

No

No

No

Yes

No

No

1

1

261

261

38.6

38.6

41

41

92713AW

92714AW

Yes

Yes

No

No

No

Yes

1

1

261

261

38.6

38.6

41

41

AIR TREATMENT

Premier DX400 & CF40 Centrifugal extract and condensation control fans

• Can be surface or recess mounted • Maintenance free for life motors

Cat No.

DX400

DX400T

DX400PC

CF40

CF40TD

CF40RSTD

Maximum

Reference Timer Pullcord Humidistat Speeds m³/h Watts dB(A)@3m

91083AW

91084AW

No

Yes

No

No

No

No

2

3

245

245

78

78

55

55

91100AW

91086AW

91087AW

91088AW

No

No

Yes

No

Yes

No

No

No

No

Yes

Yes

Yes

3

5

5

5

245

250

250

250

78

77

77

77

55

55

55

55

Slimline SL150 & SLDC150 150mm (4”) low profile axial extract fans

• ‘Quick Clamps’ for easy installation • SLDC models feature low energy DC motors

Cat No.

SL150STD

SL150PC

SL150T

SL150HTT

SL150PIR

SLDC150

SLDC150T

Reference

92664AW

92665AW

92666AW

92667AW

92668AW

92669AW

92671AW

SLDC150HT

92672AW

SLDC150PIR

92673AW

Timer

No

No

Yes

Yes

No

No

Yes

Yes

No

Pullcord Humidistat Speeds

No

Yes

No

No

No

No

No

No

No

No

No

No

Yes

No

No

No

Yes

No

1

1

1

1

1

5

5

5

5

m³/h

245

245

245

245

245

224

224

224

224

Maximum

Watts

34

34

34

34

34

13.5

13.5

13.5

13.5

dB(A)@3m

42

42

42

42

42

44

44

44

44

Commercial Fans

XIM 150 & 200 Inline mixed flow extract fans for ducted applications

• Supplied with convenient installation mounting cradle

• Lubricated for life, maintenance free motors

Cat No.

XIM150

XIM150T

XIM200

Reference Timer

91256AW

91257AW

91258AW

No

Yes

No

Size (mm)

150

150

200

Maximum

Speeds m³/h Watts dB(A)@3m

2

2

2

476

476

845

80

80

80

39

39

39

CX10 & CMF Ceiling mounted extract fans

• Axial and centrifugal model options • Lubricated for life, maintenance free motors

Cat No.

CX10

CMF171

CMF241

CMF271

Reference

90209AB

89955AW

89956AW

89957AW

Ducting Size (mm)

200

102

102

150

Hole (mm)

300 diameter

185 x 185

248 x 248

273 x 273

Maximum m³/h Watts dB(A)@3m

329

63

34

30

44

38

146

286

33

48

41

41

AIR TREATMENT

273

GX9 & GX12 Commercial window fans

• Wireless controller required on RF models

Cat No.

GX9

GXC9

GX12

Reference Motor

89994AW AC

89995AW

90012AW

AC

AC

GX9 EC3

GX12 EC3

92729AW

92730AW

GX9 EC3 RF

92733AW

GX12 EC3 RF

92734AW

EC

EC

EC

EC

Description

GX9/GX12 EC3 RF ConneX Controller

Extract m³/h

728

549

1614

847

1675

847

1675

Reference

92792AW

• GX models reversible and speed controllable

Maximum

Intake m³/h

456

None

1002

456

1002

456

1002

Watts dB(A)@3m

41 50

32

85

44

55

54.8

67.3

54.8

67.3

50

55

50

55

PX Commercial ceiling fans

• Can be installed at any angle • Controller required on 9” and 12” models

Cat No.

PX6

PX9

PX12

Maximum

Reference Duct size Extract m³/h Intake m³/h Speeds Watts dB(A)@3m

91300AW

91299AW

91298AW

200mm

250mm

315mm

246

790

1712

None

458

1037

1

2

2

34

41

85

39

50

54

RX Commercial roof fans

• Suitable for ventilating through glazed and solid roofs

Cat No.

RX6

RX9

RX12

Reference

90818AW

90424AW

90425AW

Extract m³/h

206

511

1100

• UV stabilised roof cowl assembly provides constant weather protection

Maximum

Intake m³/h Speeds Watts dB(A)@3m

None 1 35 39

438

915

2

2

41

87

52

56

WX Commercial wall fans

• Electro-thermal shutter cassette

274

• Features ‘safe lock’ metal telescopic wall liner

Cat No.

WX6/MET

WX6T/MET

WX9/MET

WX12/MET

Reference

92502AW

92523AW

92503AW

92504AW

Timer

No

Yes

No

No

Maximum

Extract m³/h Intake m³/h Speeds Watts dB(A)@3m

246

246

None

None

1

1

34

34

39

39

783

1715

477

969

2

2

41

85

50

54

AIR TREATMENT

Heating & Cooling

Digitemp WA & WHP Comfort air conditioning and heating units

• Self-contained design - no external condenser unit

• Can be installed at high or low level

Cat No.

WA210N

WA245N

WHP210N

WHP245N

Reference Cooling

92721AA Yes

92722AA

92723AA

92724AA

Yes

Yes

Yes

kW

2.1

2.45

2.1

2.45

Heating

No

No

Yes

Yes

kW

None

None

1.9

2.03

m³/h

350

390

350

390

Maximum

Watts dB(A)@3m

930

1320

37

39

930

1320

37

39

WH30, WH60 & WHP30 Commercial wall mounted fan heaters

• Tough, high performance fan heaters

• WH30 & WH60 models suitable for industrial applications

• WH30 & WH60 require a suitable inline controller to complete installation

• WHP30 suitable for commercial applications

• WHP30 supplied complete with HC301 thermostatic controller

• Supplied with mounting brackets

Cat No.

WH30

WHP30

WH60

Reference kW Phase Temperature Increase (°C) Controller m³/h

98392AC

89999AW

00147AC

3

3

6

1

3

1 or 3

26

30

45

No

Yes

No

274

300

311

Watts

930

930

1320

DCH3000A Commercial wall fan heaters

• Circulates warmth into rooms

• Built-in thermostat

• Can be set to become a circulation for year round comfort

Cat No.

DCH3000A

Reference kW Phase Number Of Heat Settings

90792AW 3 1 3

Control

Integral

Watts

1320

Whispair Commercial ceiling fans

• Designed to provide a circulation of cool air during warm periods

• Supplied with two down rods - 375mm and

750mm

Cat No.

Reference Sweep Diameter (mm)

Circulates warmth into rooms

Built-in thermostat

NWAN48

90410AW

900

1200

NWAN56

NWAN60

AWC

WAC1

WAC6

WAC6R

90411AW

90412AW

Temperature Sensor

Single Fan Controller

1400

1500

Group Fan Controller

Group Fan Reversing Controller

Maximum Speed (rpm) Watts

• Can be set to become a circulation for year round comfort

50

310

280

260

65

65

65

AIR TREATMENT

WH30

WHP30

WH60

275

276

Sensors & Switches

Cat No.

LVH

Reference

21863AW

Automatic on/off operation relative to humidity levels

Pullcord override switch

Fan indicator light

Description

12V SELV LoVolt Remote Humidistat

Cat No.

Reference Description

COS

Cat No.

90108AW

High/low speed selection

Surface or recess mounting

Reference

Change Over Switch

Description

MOS

90199AW Manual Override Switch

2 switches for speed selection and on/off operation

Surface or recess mounting

Cat No.

Reference Description

TBS

90202AW Timer and Boost Switch

Cat No.

Switching between humidity control/manual operation

Manual operation at high/low speed

Surface or recess mounting

Reference Description

XRH

Cat No.

21856AW Remote Humidistat

Automatic on/off operation relative to humidity levels

Pullcord operated override switch

Fan operation indicator light

Supply voltage 220-240V 50Hz

Reference Description

DT20B

21850AW Time Delay Controller

Typically connected to a lighting circuit

Fan turns on when light is turned on

User adjustable up to 20 minutes

Supply voltage 220-240V 50Hz

Cat No.

Reference Description

XPIRA

21871AA Passive Infrared Sensor

Switches fan on when movement is detected

Built in run on timer to avoid nuisance tripping

Supply voltage 220-240V 50Hz

Cat No.

Reference Description

FR22/30

21868AW Single Fan Controller

On/off, high/low speed and extract/intake airflow operation

Sliding switch control with power on indicator

Supply voltage 220-240V 50Hz

Cat No.

Reference Description

XCC1

21859AW Single Direction Group Fan Controller

Speed control knob provides infinitely variable speed control

Sliding on/off control with power on indicator

Extract or intake airflow

Supply voltage 220-240V 50Hz

Cat No.

Reference Description

EC6H

21854AW Reversible Group Fan Electronic Controller

Speed control knob provides infinitely variable speed control

Sliding on/off control with power on indicator

Extract/intake airflow

Supply voltage 220-240V 50Hz

Cat No.

Reference Description

HC301

21877AW Thermostatic Heating Controller

On/off switch

Fan only/fan and heater options

Variable thermostatic control

Surface or recess mounting

Suitable for ambient temperature up to 40°C

160 x 86mm

Used with: LV100, LV Premier

85 x 85mm

Used with: Premier DX400, DX400T, DX400RS with XRH

85 x 85mm

Used with: GX6, GXC6HT2, DX400. DX400RS with XRH

85 x 85mm

Used with: GX6, GXC6HT2

Surface or recess mounting

160 x 86mm

Used with: Premier DX180, DX200, DX400, DX100, XIL,

CMF, CX10, GX6/9/12, WX6/9/12, PX6/9/12, RX6/9/12

Surface or recess mounting

100 x 86mm

Used with: Premier DX180, DX200, DX400, DX100, LV100,

XIL, CMF, CX10, GX6/9/12, WX6/9/12, PX6/9/12, RX6/9/12

86 x 86mm

Used with: Premier DX200, DX400, DX100, CMF, CX10,

GX6/9/12, WX6/9/12, PX6/9/12, RX6/9/12

Surface or recess mounting

210 x 86mm

Used with: GX9/12, WX9/12, PX9/12, RX9/12

Surface or recess mounting

160 x 86mm

Used with: GX9/12, WX9/12, PX9/12, RX9/12

Do not mix fan size. For use with up to 4 12” or 6 9” fan units

Surface or recess mounting

160 x 86mm

Used with: GX9/12, WX9/12, PX9/12, RX9/12

Do not mix. For use with up to 4 12” or 6 9” fan units

Surface or recess mounting

210 x 86mm

Used with: WH30 and WHP30

AIR TREATMENT

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
