SLP 81
2621 Ridgepoint Drive, Suite 235 Austin, TX 78754
800.866.6506
www.ikey.com
SLP-81
Compact Backlit Industrial Keyboard
The SLP-81 provides a solution for low-light areas where size constraints exist.
Its compact design and durable construction ensure mobility and durability no
matter the application. Integrated backlighting ensures functionality in low-light
environments. The SLP-81 is completely sealed and designed to meet NEMA 4X
specifications.
Technical Specifications
Certifications
NEMA 4X, CE UL60950, FCC Part 15 Class B
Shock
3x11 ms pulses of 50g on each of 3 axes
Cable
LENGTH: 10 feet (3 meters) DESIGN: PS/2, USB or AT Cable
Key Switch
MATERIAL: Industrial Silicone Rubber . LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION
FORCE: 6.35 oz. +/- 1.06 oz. (180g +/- 30g) FEEDBACK: Tactile with Mechanical Snap
Vibration
POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3
hours
Power
PS/2: [email protected] (from Keyboard port) USB: [email protected] (from CPU port)
Flammability
PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94 HB INTERFACE CABLE: 94 VO
Compatability
PS/2: All Windows Operating Systems USB: All Windows and Macintosh OS
Temperature Range
STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F)
Weight
3.50 lbs (1.59 kg)
Warranty
1 year limited warranty
Humidity
100%
Dimensions
14.05" x 7.81" x 1.58" (w-h-d) 356.9mm x 198.4mm x 40.1mm
Model Numbers
Features and Benefits
12 Function Keys
81-Key Functionality
Industrial Silicone Rubber Keypad
Numlock Key for Secondary Keyboard
USB, PS/2 and AT Configurations Available
©2011 iKey, Ltd. All rights reserved. 2621 Ridgepoint Drive Suite 235 Austin, TX 78754 1-800- 866-6506
