D-Link DSM-510 - MediaLounge High-Definition Media Player User manual | Manualzz
Table of Contents
Table of Contents
Safety Information...................................................4
Product Overview....................................................8
Package Contents............................................................... 8
Minimum System Requirements........................................ 8
Recommended................................................................... 8
Introduction........................................................................ 9
Features............................................................................ 10
Wireless Installation Considerations........................... 11
Setup Your DSM-510 Using an Intel® Viiv™ Technology-Based
PC.................................................................... 12
Setup................................................................................ 13
Wireless Connection......................................................... 14
Wired Connection............................................................. 14
Connecting the DSM-510................................................. 15
Video Connections..................................................... 15
Audio Connections..................................................... 16
Network Connections................................................. 17
Using the Remote Control................................................ 18
Power on the DSM-510.................................................... 19
Finalizing Your Wireless Connection with an Intel® Viiv™
Technology Verified Router............................................... 20
Finalizing Your Wireless Connection without an Intel® Viiv™
Technology Verified Router............................................... 21
Finalizing Your Wired Connection..................................... 22
D-Link DSM-510 User Manual
Adding a Device without an Intel® Viiv™ Technology Verified
Router.............................................................................. 23
Adding a Device................................................................ 24
Setting Up the Intel® Viiv™ Media Library.......................... 25
Navigating to the Intel® Viiv™ Technology Settings Screen
and Images on Your PC.................................................... 25
Windows® Media Player 11 Setup.............................. 26
Enable Media Sharing - Windows® Vista.......................... 32
Settings............................................................. 35
Options............................................................................. 35
On-Screen Keyboard........................................................ 36
Network Settings.............................................................. 37
Wired LAN Settings.................................................... 37
Wireless LAN Settings............................................... 38
TV Settings....................................................................... 40
Audio Output Settings...................................................... 40
Language Settings............................................................ 41
Settings for Ease of Use................................................... 41
Reset Settings.................................................................. 42
Software Update............................................................... 43
Device Information........................................................... 43
Windows® Connect Now for XP.................................. 44
Windows® Connect Now for Vista.................................... 50
Table of Contents
Operating the DSM-510........................................... 56
Music............................................................................... 57
Time Search............................................................... 63
Podcasts........................................................................... 64
Importing Podcasts.................................................... 65
Adding Podcasts........................................................ 66
Photo................................................................................ 69
Video................................................................................ 72
DivX®......................................................................... 73
Time Search............................................................... 75
Search Filter............................................................... 76
Intel® Viiv™ Zone............................................................... 77
Server............................................................................... 78
USB.................................................................................. 79
Contacting Technical Support...................................101
Warranty...........................................................102
Registration.......................................................107
Troubleshooting.................................................... 80
Wireless Basics.................................................... 86
Networking Basics................................................. 91
Check your IP Address..................................................... 91
Statically Assign an IP Address........................................ 92
General Appendix.................................................. 93
How to Check your Media................................................. 93
Convert an Earlier WMV File into WMV9 ......................... 94
Remote Control Table..................................................... 100
D-Link DSM-510 User Manual
Safety Information
For optimum performance, please read the following information carefully.
Safety Precautions
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert users to the presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
CAUTION!
THE POWER SUPPLY CORD IS USED AS THE MAIN DISCONNECT DEVICE. ENSURE THAT
THE SOCKET-OUTLET IS LOCATED/INSTALLED NEAR THE EQUIPMENT AND IS EASILY
ACCESSIBLE.
CAUTION!
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PRODUCT DAMAGE, DO NOT EXPOSE
THE UNIT TO RAIN, MOISTURE, DRIPPING, OR SPLASHING. DO NOT PLACE OBJECTS FILLED
WITH LIQUIDS UPON THE UNIT.
D-Link DSM-510 User Manual
CAUTION!
• DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN CABINET OR IN
ANOTHER CONFINED SPACE. ENSURE THE UNIT IS WELL VENTILATED. TO PREVENT RISK
OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO OVERHEATING, ENSURE THAT CURTAINS
AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION VENTS.
• DO NOT OBSTRUCT THE UNIT’S VENTILATION OPENINGS WITH NEWSPAPERS,
TABLECLOTHS, CURTAINS, AND SIMILAR ITEMS.
• DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED CANDLES, ON THE
UNIT.
• DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY-FRIENDLY MANNER.
CAUTION!
TO PREVENT ELECTRIC SHOCK, MATCH THE WIDE BLADE OF THE PLUG TO THE WIDE
SLOT OF THE ELECTRICAL OUTLET AND FULLY INSERT.
This device is designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit
will protect you if you observe the following procedures for installation, use, and servicing. This device does not contain any user serviceable parts.
• Carefully read and follow the Manual and Install Guide.
• Do not place the product near heat sources such as radiators, heat registers, stoves, or other products that produce heat.
• Do not use this product near water.
• Unplug the unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
• Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them.
• Do not overload wall outlets.
• Do not use this product during a storm. Unplug the unit from the wall outlet. If the product is to be left unattended for a long period of time. This will prevent damage to the
product due to lightning and power-line surges.
• Do not attempt to service this product yourself. Opening the cover may expose you to dangerous voltage or other hazards. For service, please contact a qualified service
technician.
D-Link DSM-510 User Manual
Radio and TV Interference:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
•
•
•
•
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Any unauthorized changes or modifications to this equipment would void the user’s authority to operate this device. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Important Note:
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of
20cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. The
firmware setting is not accessible by the end user.
Industry Canada statement:
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired operation.
Important Note:
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm
between the radiator and your body.
This device has been designed to operate with an antenna having a maximum gain of 2dB. An antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The
required antenna impedance is 50 ohms.
Disclaimers: Certain content and services accessible via the DSM-510 may include materials owned by third parties. The users shall be entirely responsible for ensuring that they have the necessary rights to access and use such third party content. D-Link assumes
no liability for and shall not be responsible for a user’s access of such content, including but not limited to unlawfully ‘ripped’ or downloaded content. Further, D-Link does not guarantee the availability of any third party content or services, including that which may
D-Link DSM-510 User Manual
be referenced herein, and shall not be responsible for any changes to or the lack of availability of such third party content or services.
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing
uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
Consumers should note that not all high definition television sets are fully compatible with this product and may cause artifacts to be displayed in the picture. In case of 525 progressive scan picture problems, it is recommended that the user switch the connection
to the “Standard Definition” output. If there are questions regarding our TV set compatibility with this model please contact our customer service center.
Subscription may be required for services from Yahoo, TotalVid, Live365™, My Kid’s Tunes, or Napster™.
Certain features of this device may be unavailable when accessing stored media content on UPnP AV network attached storage devices.
USB flash drive and USB hard drive sold separately. D-Link is not responsible for damage to USB drives, or loss and/or damage to files on the USB drives, due to improper installation or usage.
This device supports the codec file formats listed herein, however D-Link cannot guarantee full compatibility or proper playback with all such codec files due to modifications and/or other variations that may occur with the end-user’s encoded codec files. Certain
file formats and/or features are not accessible from USB drives attached to the USB port.
Windows® Media Connect and Windows® Connect Now require Windows® XP SP2, and can be downloaded using Windows update on your computer.
24/7 Technical Support available only in the U.S.A.
1-Year Warranty available only in the U.S.A. and Canada.
Latest Software and Documentation are available at http://support.dlink.com.
MPEG-4 contains Advanced Simple Profile only without quarter pixel or global motion compensation.
Maximum wireless signal rate based on IEEE Standard 802.11g specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead lower
actual data throughput rate.
Copyright ©2006-2007 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link and the D-Link logo are registered trademarks of D-Link Corporation or its subsidiaries in the United States and other countries. Intel, the Intel logo and Intel Viiv are
trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Other trademarks are the property of their respective owners. The PlaysForSure logo, Windows Media, Windows and the Windows logo are
trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. Other trademarks are the
property of their respective owners. All references to speed are for comparison purposes only. Product specifications, size and shape are subject to change without notice, and actual product appearance may differ from that depicted on the packaging. See inside
packaging for warranty details. For an updated list of available online service providers, please visit http://support.dlink.com. This product is covered by certain intellectual property rights of Microsoft© Corporation. Use or distribution of such technology outside of
this product is prohibited without a license from Microsoft or an authorized Microsoft subsidiary.
D-Link DSM-510 User Manual
Section 1 - Product Overview
Product Overview
Package
Contents
• D-Link DSM-510 High-Definition Media Player
• Quick Install Guide
• Manual, QIG, software, and warranty on CD
• 2dBi Wireless Antenna
• Ethernet (CAT5-UTP/Straight-Through) Cable
• Composite RCA Audio/Video Cable
• Remote Control with 2AAA Batteries
• Power Adapter
• Vertical Stand
Note: Please remove the plastic covers attached to the unit so that proper ventilation is allowed.
If any of the above items are missing, please contact your reseller.
Minimum System Requirements
• PC with:
Windows® Vista™/XP
1GHz plus processor
Memory Size: 512MB or above
100MB of available hard drive space and a wireless or Ethernet network.
•TV with Composite Video, or HDMI Input.
•Stereo or A/V Receiver with Composite Audio, or Optical Digital.
•If you want to connect the DSM-510 to a Windows XP-based PC without Intel® Viiv™ technology, use the included
CD for steps on how to configure Windows® Media Player 11 software and refer to this manual.
Recommended
• Windows® Vista/XP MCE-based PC with Intel® Viiv™ technology.
• An Intel® Viiv™ technology verified router.
• Broadband Connection for Accessing Online Content.
• Wired or Wireless Network (Wired network is recommended for video streaming).
D-Link DSM-510 User Manual
Section 1 - Product Overview
Introduction
D-Link introduces the latest addition to its multimedia family of products: the D-Link DSM-510 High-Definition Media Player. The
DSM-510 is a device that plays back video, audio, and photos that are stored on a Media Server.
The DSM-510 integrates home computer systems and home entertainment centers. Digital media content can be accessed directly
from a computer, so that movies, music, and photos can be enjoyed from the comfort of your living room. The DSM-510 connects
easily to a wired or wireless network, and features 802.11g wireless technology for transfer speeds on a wireless network. These
options provide you with the maximum throughput for sharing and transferring digital media.
Simple to setup with a sleek design that makes it a natural addition to any home entertainment center. The AV jacks on the back
panel of the DSM-510 allow for direct connection to your television. Use the included remote control to access media content stored
on your PC. Browse music files, watch videos, and display photos, all on your television! In addition, the DSM-510 lets you access
online media content through Intel® Viiv™ Zone with an existing broadband Internet connection.
The DSM-510 adheres to the universal Plug-&-Play AV specification, allowing it to communicate with other UPnP AV media
devices.
The DSM-510 supports the majority of audio, video, and image file formats and streams them directly from your PC. You can stream
MP3, WMA, WAV, OGG Vorbis, and AIFF files from your computer and enjoy them on your home stereo system. Watch stored videos
in DVR-MS, MPEG1/2/4, AVI, DivX®, or Xvid format on your television. Enjoy slideshows of your favorite photos in JPEG, TIFF, GIF,
BMP or PNG formats. Better yet, it’s easy to access the files through the television interface using the remote control included with
the DSM-510.
Experience digital media like never before with the DSM-510 High-Definition Media Player. The DSM-510 includes everything you
need to instantly access and play music, videos, and photos using your home entertainment center.
This is an official DivX® Certified product that plays all versions of DivX® video (including DivX® 6) with standard playback of DivX®
media files.
D-Link DSM-510 User Manual
Section 1 - Product Overview
Features
•Stream media content from a PC or D-Link Network Attached Storage to your entertainment center.
•Listen to digital music on your stereo system.
•View digital photos, slideshows with music, and high-definition videos on TV.
•Easily connect to your wireless network using 802.11g at up to 54Mbps.
•Connect using an Ethernet network cable at up to 100Mbps.
•UPnP AV compliant for maximum compatibility.
•Support for most popular digital media formats, including Microsoft Windows® recorded TV files (DVR-MS).
•Remote controlled TV interface for quick access to your media content.
•Experience a world of online media content through Intel® Viiv™ Zone.
•Sleek design complements your existing audio/video equipment.
•Optical digital audio output.
•HDMI output.
•64-bit or 128-bit WEP & WPA security.
•Supports DHCP for easy connection to your home network.
•Color coded one-touch shortcut buttons on the remote, for quick access to music, photos, and videos.
•Podcasts can be used to access Internet radio streams.
D-Link DSM-510 User Manual
10
Section 2 - Installation
Wireless Installation Considerations
The D-Link High-Definition Media Player lets you access your network using a wireless connection from virtually anywhere within the
operating range of your wireless network. Keep in mind, however, that the number, thickness and location of walls, ceilings, or other
objects that the wireless signals must pass through, may limit the range. Typical ranges vary depending on the types of materials
and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these basic
guidelines:
1.Keep the number of walls and ceilings between the D-Link adapter and other network devices to a minimum - each
wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number
of walls or ceilings is minimized.
2.Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a
45-degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet (14 meters)
thick! Position devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for
better reception.
3.Building Materials make a difference. A solid metal door or aluminum studs may have a negative effect on range.
Try to position access points, wireless routers, and computers so that the signal passes through drywall or open
doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (fish tanks), mirrors, file
cabinets, brick, and concrete will degrade your wireless signal.
4.Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF
noise.
5.If you are using 2.4GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home security
systems), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4GHz phone
base is as far away from your wireless devices as possible. The base transmits a signal even if the phone in not in
use.
Note: For best video quality, a wired connection is recommended.
D-Link DSM-510 User Manual
11
Section 2 - Installation
Setup Your DSM-510 Using an Intel® Viiv™
Technology-Based PC
To get the most out of this guide, you must have an Intel® Viiv™ technology-based PC featuring the Intel® Viiv™ logo below. If you do
not have an Intel® Viiv™ technology-based PC at this time, please continue to page 13.
If you already have wireless settings configured on your PC, instead of using the Intel® Viiv™ setup, you can use Windows® Connect
Now (WCN) to configure the wireless settings on your DSM-510. Please see the user manual on the CD for further information.
Your High-Definition Media Player has been designed to work with Intel® Viiv™ technology-based PCs, which helps you add this
device to your network and enjoy content from your PC. To enjoy these features, you may need to update the Intel® Viiv™ software
on your PC.
Intel® Viiv™ technology-based PCs have this logo on
them.
Insert the CD that came with your DSM-510 into your Intel® Viiv™ technology-based PC, and follow the on-screen instructions to
guide you through the update process.
IMPORTANT:
• This software will enable the instant on/off power management features of your computer, which allows your new
device to “wake-up” your PC to access content and services marked “Enjoy with Intel® Viiv™ technology”.
• You may need to restart your PC to begin using the Intel® Viiv™ software.
D-Link DSM-510 User Manual
12
Section 2 - Installation
Turn on the computer and insert the D-Link DSM-510 CD into the CD-ROM drive.
Click Setup
If the Autorun function does not automatically start on your computer, click Windows®
Start > Run. In the Run command box type “D:\DSM510.exe”, where D: represents the
drive letter of your CD-ROM.
Setup
Clicking “Setup” on a PC that does not contain Intel® Viiv™ technology, will launch the Windows® Media Player and Setup Guide with
instructions on how to setup your Windows® Media Player 11 for sharing. This is a UPnP AV compliant media server software that
allows you to share your music, photos or video files to the DSM-510. Please continue to the section “Windows® Media Player 11
Installation” on page 26 for more information.
After configuring Windows® Media Player 11, refer to page 15 to connect your DSM-510.
If your PC is Intel® Viiv™ technology based, clicking on “Install Media Server” will confirm your PC has the latest version of the Intel®
Viiv™ software and update it if necessary. This software includes the Intel® Viiv™ Media Server.
At the Intel® Viiv™ software setup screen, select the option Yes, start Intel Viiv Settings now (recommended).
Click Next to start the installation process, and at the next screen click add a device.
Note: Click “Install DivX®” to install the DivX® player, DivX® codec, and the DivX® Converter software on the PC. The DivX® Converter
software converts other file types to DivX® files.
D-Link DSM-510 User Manual
13
Section 2 - Installation
Wireless Connection
Select the option wirelessly.
If you select connecting it to the router with an Ethernet network cable, please skip to the “Wired Connection” section below.
If the Intel® Viiv™ software does not find an Intel® Viiv™ technology verified router, then connect your DSM-510 (see page 15). Power
on your DSM-510 (see page 19) and follow the instructions that apply to finalizing your wireless connection without an Intel® Viiv™
technology verified router.
Intel® Viiv™ technology verified routers have this
logo on them.
If an Intel® Viiv™ technology verified router is detected, you should see the adding a device to your home network screen. Proceed
to page 15 to connect your DSM-510 and power it up for the first time.
Wired Connection
For a wired connection, select the option connecting it to the router with an Ethernet network cable.
At the adding a device to your home network screen, leave your PC and connect your DSM-510 (see page 15).
Connect your DSM-510, please continue to page 15.
D-Link DSM-510 User Manual
14
Section 2 - Installation
Connecting the DSM-510
All audio, video, and networking connections are located on the rear panel of the DSM-510.
Video Connections
Select one of two ways to connect video to your DSM-510:
Composite Audio/Video Connector
• Plug the supplied 3.5mm mini-jack connector into the DSM-510. Plug the opposite end (the yellow
video cable and the red and white audio cables) into your television input.
HDMI
• Plug the HDMI cable into the HDMI connector on the back panel of the DSM-510. Plug the opposite
end to the matching HDMI connector on your television or audio/video system.
Note: This cable is not supplied.
By default the DSM-510 will automatically detect and switch between Digital (HDMI) and Analog
(Composite) modes.
High-Definition Multimedia Interface (HDMI) supports standard, enhanced, or high-definition video, plus multi-channel digital
audio on a single cable.
D-Link DSM-510 User Manual
15
Section 2 - Installation
Audio Connections
Select one of two ways to connect audio to your DSM-510:
Composite Audio/Video Connector
• Plug the supplied 3.5mm mini-jack connector into the DSM-510. Plug the opposite end (the yellow
video cable and the red and white audio cables) into your television/receiver input.
Optical Digital Audio
• Connect an optical audio connector into the S/PDIF connector on the DSM-510 and the matching opposite
end of the cable to the audio input of your audio system.
Note: This cable is not supplied.
D-Link DSM-510 User Manual
16
Section 2 - Installation
Network Connections
Select one of two ways to connect your DSM-510 to your network:
RJ-45 Ethernet Connector
• Connect the supplied Ethernet cable to the network cable connector, and attach the other end to
a router or hub on your network.
Wireless Antenna
• Attach the supplied antenna by threading it onto the antenna connector. Be sure the antenna is
secure and in an upright position.
D-Link DSM-510 User Manual
17
Section 2 - Installation
Using the Remote Control
1. Power
2. Alphanumeric Keys
3. HOME
4. SHIFT
5. DELETE
6. VOLUME + & 7. PAGE UP & DOWN
8. MUTE
9. BACK
10. Enter & Navigation Buttons
11. MENU
12. SETUP
13. Color-Coded Shortcut Keys
14. USB
15. Stop, Play/Pause, REV,
FF, PREV, and NEXT
16. REPEAT
17. SHUFFLE
18. SEARCH
19. INFO
20. SLOW
21. A-B
22. L/R
3
1
2
5
4
7
6
9
8
10
11
12
13
14
15
16
19
20
18
22
21
17
Note: Please see the Remote Control Table in the Appendix on page 100 for more information on the functionality of the DSM-510
remote control..
D-Link DSM-510 User Manual
18
Section 2 - Installation
Power on the DSM-510
Plug in the DSM-510’s power cable into the back panel connector, the unit should power on
immediately.
Note: If you are using the composite or HDMI video connection, the DSM-510 will automatically detect
the correct video signal.
If you do not have an Intel® Viiv™ technology-based PC at this time, or if you are connecting the
DSM-510 wirelessly and do not have an Intel® Viiv™ technology verified router, please continue to
page 21.
If you are connecting the DSM-510 wirelessly and have an Intel® Viiv™ technology verified router,
please continue to page 20.
If you are connecting though a wired Ethernet cable, please continue to page 22.
D-Link DSM-510 User Manual
19
Section 2 - Installation
Finalizing Your Wireless Connection with an Intel® Viiv™
Technology Verified Router
Note: Skip to page 21, if you do not have an Intel® Viiv™ technology verified router.
From the “Welcome to Setup” page of Express Setup, click OK if you have an Intel® Viiv™ technology verified router.
(1) After clicking OK, the next screen will provide you with a temporary four-character passcode. Please memorize or write down
this passcode.
(2) Return to your PC and follow the on-screen instructions to complete the addition of your device to the network. Click next to
continue to the passcode screen.
(3) Enter the passcode before the timer expires. and click next.
Note: If the timer expires before you enter the temporary passcode, you can obtain a new passcode by starting the timer again from
the DSM-510.
(4) After the device has been added to the network, and when you have clicked OK, a home page will appear. Please return to your
PC to complete the addition of your device.
Please Continue to page 24!
D-Link DSM-510 User Manual
20
Section 2 - Installation
Finalizing Your Wireless Connection without an
Intel® Viiv™ Technology Verified Router
From the “Welcome to Setup” page of Express Setup, click CANCEL or MANUAL SETUP if you do not have an Intel® Viiv™ technology
verified router.
(1) At the next screen, select Scan for wireless LANs and click OK.
(2) Using your remote control, select a wireless network from the list and press ENTER.
(3) Select the Encryption Type and the Cryptography Key (Network Password) to configure your wireless settings. Once you’ve
completed all of your settings, please click OK.
(4) If you need to manually configure the IP Settings, click the IP Address Settings button. You will see a new screen appear that allows
you to manually enter in the values.
(5) To manually enter the IP address information, select NO from Get IP Address and press the ENTER button on your remote control.
The navigation arrows on your remote control will allow you to select the corresponding field that needs to be updated. Press
the ENTER button on your remote control to select the field and use the number keys to input the information. Press ENTER
when you have completed entering the information. Click OK after you’ve finished updating the IP Address Settings screen.
If you have an Intel® Viiv™ technology-based PC, please continue to page 23.
If you do not have an Intel® Viiv™ technology-based PC, please refer to page 26 for steps to configure Windows® Media Player 11.
Please Continue to page 23!
D-Link DSM-510 User Manual
21
Section 2 - Installation
Finalizing Your Wired Connection
If you connected to your network using a wired Ethernet cable, you will see a screen Congratulating you on a successful connection,
click OK.
After you have clicked OK, a home page will appear. Please return to your PC to complete the addition of your device. At the adding
a device to your home network screen click next.
Please Continue to page 24!
D-Link DSM-510 User Manual
22
Section 2 - Installation
Adding a Device without an Intel® Viiv™ Technology
Verified Router
At the main settings screen, click view network map.
Note: Your device may have a “?” on it, this means that it is not approved yet.
(1) After you’ve clicked on your media device, the next screen will provide details about this device. Click next to continue.
(2) At the device classification screen, select approved if you want the media device to allow access to the network. Click next and
you should notice that the following screen has automatically selected your media device. Click next to continue.
(3) If you are using Windows® Vista, you have the opportunity to select a device location.
(4) When you see the grant Intel® Viiv™ Media Server access screen, click yes to grant access for your media device. Click next
to continue.
(5) After you’ve granted access to the media device you should be returned to the network map menu. Notice that the “?” no longer
appears on your media device. Click back to return to the main menu.
(6) At the main menu screen click the update media library button to set up your Intel® Viiv™ Media Library.
Please Continue to page 25!
D-Link DSM-510 User Manual
23
Section 2 - Installation
Adding a Device
Your PC will begin adding the device. Please wait…this may take up to five minutes. When it has been added, you will see the new
device found screen, listing the device name and type. Click next to continue.
The following screen should have automatically selected your media device. Click next to continue.
If you are using Windows® Vista, you have the opportunity to select a device location.
The next screen you should see is the device added to the network screen. When you see this screen, you have successfully added
your device to the network.
Please Continue to page 25!
D-Link DSM-510 User Manual
24
Section 2 - Installation
Setting Up the Intel® Viiv™ Media Library
In order to access the media content on your PC, you must setup your Intel® Viiv™ Media Library. At the get ready screen, click
next.
At the choose a setup and go screen, it is recommended to select Standard Update.
When you see the update complete screen, you have successfully completed the setup of your Intel® Viiv™ Media Library.
Click finish and return to your DSM-510 unit. You should see a menu, use your remote control to navigate through the menu.
Navigating to the Intel® Viiv™ Technology Settings Screen
and Images on Your PC
You may navigate to the Intel® Viiv™ settings window either by selecting the Intel® Viiv™ logo on your desktop or system tray. The
logo can also be found in the More Programs area in Windows® XP Media Center Edition 2005.
You are now ready to use your DSM-510!
D-Link DSM-510 User Manual
25
Section 2 - Installation
Windows® Media Player 11 Setup
Note: Do not configure Windows® Media Player 11 sharing if you have an Intel® Viiv™ technology verified PC, because you can
use the Intel® Viiv™ Media Server that is included with your Intel® Viiv™ technology verified PC.
To share audio, video, and photo files from your computer, it is necessary to have Windows ® Media Player 11 or another
UPnP™ AV server software on any PC that is not Intel® Viiv™ technology verified. Windows® Media Player 11 software allows
you to share your PC’s audio, video, and photo files with your media player. Windows ® Media Player 11 software then streams the
content to your DSM-510 via your wired/wireless network connection.
If more than one PC contains files you want to share, you can select one of the following options:
1. Copy all of the files to one computer designated to run the Windows® Media Player 11 software.
2. Map network drives on the computer with the Windows ® Media Player 11 software to additional computers that
contain files you want to share. This method also allows you to share files from computers that cannot run the
Windows® Media Player 11 software such as Macintosh systems. The computer running the Windows® Media Player 11
software must always be on when streaming content from any computer.
Note: In order to share files from your MAC to your PC you must turn on Windows sharing from Preferences Menu and select
Sharing.
3. Configure the Windows ® Media Player 11 software on each computer. The DSM-510 will aggregate your media into one list
under music/photo/video.
4. Power on your DSM-510, and do the following based on your network connection:
• Wireless: Select the option Cancel. Connect to your network by selecting a network name and by providing the necessary information for authentication. Please refer to page 21 for step-by-step instructions.
• Wired: After powering on your DSM-510 your network will automatically be detected. Click Finish.
To download Media Player 11, visit microsoft.com.
D-Link DSM-510 User Manual
26
Section 2 - Installation
If you do not have an Intel® Viiv™ technology based PC, the autorun will provide you with steps to configure sharing through
Windows® Media Player 11 instead.
In order to share media to your DSM-510 using Windows® Media Player 11 you must first allow your media player access in
the software. Click the down arrow under Library and select Media Sharing.
Click the Share my media to: check box. Select your D-Link DSM-510 media player from the Media Sharing box and then click
the Allow button.
D-Link DSM-510 User Manual
27
Section 2 - Installation
Your device will now have a green check mark. Click Apply and then click OK.
Now you need to add the folders containing media you want shared with your DSM-510. Click on Library and then click on
Add to Library.
D-Link DSM-510 User Manual
28
Section 2 - Installation
Click the Advanced Options button in the bottom left-hand corner. Click Add and choose the folders with media you wish to be
shared. If you have folders in other areas of your hard drive or on other drives in your pc or network, you will need to select
the Add button and select each folder manually. Once you have added the folder(s) you want to share click OK.
Windows® Media Player 11 will now search for supported media files in the folders you selected to share.
Click Close and you are ready to use Windows® Media Player 11 as your server.
D-Link DSM-510 User Manual
29
Section 2 - Installation
You can now return to your TV and select the Server option from the Home page of the D-Link DSM-510 or you can press the
Server button on the D-Link DSM-510 remote control.
Once you have confirmed that your Windows® Media Player sharing has been enabled and is showing on your D-Link DSM-510
you can select your Music, Photos or Videos options in the Home menu or press the hotkeys on your remote control.
D-Link DSM-510 User Manual
30
Section 2 - Installation
Note: Please refer to page 15 for information on connecting your DSM-510 device.
D-Link DSM-510 User Manual
31
Section 2 - Installation
If you are using Windows Vista and Media Sharing is disabled, follow these steps to enable media sharing:
Open Windows® Media Player 11. Click the down arrow under Library and select Media Sharing.
Click the Networking button.
D-Link DSM-510 User Manual
32
Section 2 - Installation
Click the Customize button.
Select Private under Location Type. Click the Next button.
D-Link DSM-510 User Manual
33
Section 2 - Installation
Click the Close button. Media sharing should now be accessible from your Windows® Vista machine.
D-Link DSM-510 User Manual
34
Section 3 - Configuration
Settings
Press the Setup button on your remote control to configure your DSM-510.
Options
Network Settings: This option allows you to modify your wireless and wired settings. You can also
access your WCN® setup wizard from this screen.
TV Settings: This option allows you to change your video output type between Digital (HDMI)
and Analog (Composite), as well as the resolution size.
Audio Output Select the audio output type for different audio formats.
Settings:
Language Settings: This option allows you to choose the language that the interface is displayed in.
Here you can configure settings for your device’s startup, which will allow easier
Settings for Ease of access to your media.
Use:
This will restart your device to factory settings.
Reset Settings:
This option allows you to update the DSM-510.
Software Update:
This option displays information concerning the DSM-510.
Device Information:
D-Link DSM-510 User Manual
35
Section 3 - Configuration
On-Screen Keyboard
In order to input information, you must use the DSM-510 keyboard interface. When
information is needed within an input box, click the MENU key on your remote control
and select the Keyboad Input option.
Use the selection arrows and the ENTER button to select from Numbers, Lower (lower
case alphabet), Upper (upper case alphabet), or Symbol. The SHIFT key on your remote
control can also toggle between these options if pressed repeatedly. Once you’ve selected
your character type, use the selection arrows on your remote control to select the
characters you want to input. When you have finished, select OK.
D-Link DSM-510 User Manual
36
Section 3 - Configuration
Network Settings
Wired LAN Settings: If you want to connect through an Ethernet cable, then select this option.
Wireless LAN
Settings:
Select this option if you are using the antenna to connect wirelessly to a server.
Wired LAN Settings
Get IP Address: Clicking this button will retrieve the IP address automatically (Recommended).
IP Address:
Subnet Mask:
Default Gateway:
DNS Server:
Input the IP Address.
Input the Subnet Mask.
Input the Default gateway.
In case a DNS server exists in the network, input the IP Address of the DNS server.
Displays the MAC Address.
MAC Address:
D-Link DSM-510 User Manual
37
Section 3 - Configuration
Wireless LAN Settings
Scan for wireless Click this button to search for wireless LANs, and select your Access Point.
LANs:
Click this button to manually connect to the network (see the following screen).
Manual
®
Configuration: Click this option if you want to use Windows Connect Now to configure your
device’s wireless connection. If you want to configure your device’s wireless
Windows Connect connection, please continue to page 37.
Now:
Wireless LAN Profile Settings
To exchange connection priorites, click the MENU button on your remote control.
Set to Exchange: Pick the wireless access point that you want to exchange connection priorites.
Exchange:
Remove:
This option will initialize the move between wireless access points.
This will remove the wireless access point profile from the list.
Note: In order for the exchange to take effect, you must power cycle the DSM-510
(meaning you must turn off the DSM-510 and turn it back on again).
D-Link DSM-510 User Manual
38
Section 3 - Configuration
Manual Configuration
MODE: Choose between Ad-Hoc or Infrastructure.
Ad-Hoc should be selected when the DSM-510 is directly connected to other
wireless network devices without an access point.
Infrastructure should be selected when the DSM-510 is connected to the
wireless LAN where an accesss point device exists. (Recommended)
Wireless LAN Type:
Displays the Wireless LAN Type as 802.11b/g.
Using the software keyboard input the SSID, which should be used by the
SSID: existing wireless network.
Encryption Type:
Select between None, WEP, or WPA.
When WEP or WPA is selected in Encryption Type, two boxes will appear (the Index Selection box and the Cryptography Key input
Cryptography Key or box.
Network Passcode:
Index Selection box allows you to select an Index number from 1 to 4. Each index number saves a Cryptography Key.
Cryptography Key allows you to enter the WEP or WPA key used in the existing wireless network.
D-Link DSM-510 User Manual
39
Section 3 - Configuration
TV Settings
Output Type: Select between Digital (HDMI) and Analog (Composite).
Screen Size: Select between 4:3 or 16:9.
Resolution: If the output type is set to Digital (HDMI), select between Auto, 480i, 480p, 1080i,
and 720p. If the output type you selected is Analog (Composite), select between
480i, 480p, 1080i, and 720p.
Audio Output Settings
AAC: You can choose to output audio in LPCM or have it turned off to the digital
output.
Dolby Digital: You can choose to output audio in 2 channel or 5.1 for analog. You can also change
the digital output from LPCM to Dolby Digital or off.
WMA: You can choose to output audio in 2 channel or 5.1 for analog. You can also change
the digital output from LPCM to off.
Auto Volume Control There are three variable settings to select from: Small, Moderate, and Strong. These
Strength: control tha audio output depending on the strength of the media file.
D-Link DSM-510 User Manual
40
Section 3 - Configuration
Language Settings
Select the available language that best fits your interface.
Settings for Ease of Use
Connect to last On startup your DSM-510 will try to access the last media source it was connected
accesed server to.
automatically:
Connect to single If only one media source or USB is detected the media server will connect to it
server/USB automatically.
automatically:
Resume last screen After turning on the unit, the last screen accessed will be displayed.
from standby:
D-Link DSM-510 User Manual
41
Section 3 - Configuration
Reset Settings
You can reset the DSM-510’s settings from Options and select Reset Settings. On the
following screen, select RESET.
To perform a hard reset, please locate the pinhole reset button on the bottom edge
of the device. Insert a paperclip while the unit is powered on and hold it in for 10
seconds. After 10 seconds, remove the paperclip from the pinhole reset button.
D-Link DSM-510 User Manual
42
Section 3 - Configuration
Software Update
Update over Select this option to update the DSM-510 through an Internet connection. Select
Internet: OK and then select Next for the DSM-510 to check for an update. If an update is
available, you will be able to click Next and the DSM-510 will download and install
the updated software.
Update from USB: Select this option to update the DSM-510 through a USB device. Download the
USB Update Software from http://support.dlink.com. Extract and copy the update
folder from your PC onto your USB drive. Insert the USB drive into the DSM-510
and select Next. If an update is found, you will be able to select Next and continue
updating your DSM-510 software.
Device Information
This screen will display information about the DSM-510.
Device Name: Displays the name of the device.
Version: This will show the current version of the software that the device is using.
MAC Address: Shows the Wired and Wireless MAC address of the DSM-510.
D-Link DSM-510 User Manual
43
Section 3 - Configuration
Windows® Connect Now for XP
If you already have wireless settings configured on your PC, instead of using the Intel® Viiv™ setup , you can use Windows® Connect
Now (WCN) to configure the wireless settings on your DSM-510.
Note: WCN is only available on PCs running Windows® Vista and Windows® XP with Service Pack 2 installed. If you are running
Windows® Vista on your PC, continue to page 44.
Go to Start > All Programs > Accessories > Communications and click Wireless Network
Setup Wizard.
Your system will display the Setup Wizard Welcome screen. Click Next to continue.
Click Next
D-Link DSM-510 User Manual
44
Section 3 - Configuration
Select to add a new device to your existing wireless network and click Next to continue.
Click Next
The wizard provides two methods for setting up a wireless network. Select to use a USB flash
drive to save your wireless network settings and click Next to continue.
Note: Using a USB flash drive is recommended.
Click Next
D-Link DSM-510 User Manual
45
Section 3 - Configuration
Plug your flash drive into a USB port on this computer. The drive letter will appear in the pull
down menu. You can choose to use this drive or select another drive. Click Next to save your
wireless settings to the USB flash drive. This may take a few seconds.
Click Next
This screen will appear when the wireless settings have been saved to the USB flash drive.
Click Next
Next, remove the USB Flash Drive from your PC and insert into the USB port on the back panel of the DSM-510.
D-Link DSM-510 User Manual
46
Section 3 - Configuration
From the device, select the option Windows Connect Now. Click OK.
The following screen will appear, manually configure your Wireless LAN settings. After
you’ve completed your settings, click OK.
D-Link DSM-510 User Manual
47
Section 3 - Configuration
The following screen confirms that your wireless settings have been applied. Click OK.
Next, return to your PC and remove the USB Flash Drive from the DSM-510 and insert
it back into the USB port on your PC. Click Next to continue.
Click Next
D-Link DSM-510 User Manual
48
Section 3 - Configuration
Wireless configuration using WCN is now complete. The setup wizard will display the devices
that have been setup with your wireless network. Click Finish.
Click Finish
Windows® Connect Now has been configured for Windows® XP/2000!
D-Link DSM-510 User Manual
49
Section 3 - Configuration
Windows® Connect Now for Vista
On your Windows® Vista PC, open up your Control Panel and select the Network
and Internet option.
Next, select the Network and Sharing Center option.
D-Link DSM-510 User Manual
50
Section 3 - Configuration
On the following screen, select Set up a connection or network.
The choose a connection option window will appear. Select the Set up a wireless
router or access point option and click Next.
The following screen offers more information, click Next to begin the wizard.
D-Link DSM-510 User Manual
51
Section 3 - Configuration
Select the Create wireless network settings and save to USB flash drive
option.
Enter a passphrase to secure your network and click Next.
The following screen will provide you with a list of network security options.
Select the best option and click Next to continue.
D-Link DSM-510 User Manual
52
Section 3 - Configuration
The choose file and printer sharing options window will appear, select the option
to keep the custom setting you already have, and click Next.
Plug your flash drive into a USB port on your computer. The driver letter will
appear in the pull down menu. You can choose to use the drive or select another
drive. Click Next to save your wireless settings to the USB flash drive.
The following screen will begin saving the wireless settings to your USB flash
drive. This may take a few seconds.
D-Link DSM-510 User Manual
53
Section 3 - Configuration
This screen will appear when the wireless settings have been saved to the USB
flash drive.
Remove the USB flash drive from your PC and insert it into the USB port on
the front panel of the DSM-510.
From the device, select the option Windows Connect Now. Click OK.
D-Link DSM-510 User Manual
54
Section 3 - Configuration
The following screen will appear after you’ve verified your settings.
Click OK to continue.
The following screen confirms that your wireless settings have been applied.
Click OK.
Windows® Connect Now has been configured for Windows® Vista!
D-Link DSM-510 User Manual
55
Section 4 - Operation
Operating the DSM-510
VIDEO: Click ENTER on your remote control to show the Video Contents selection
screen.
MUSIC: Click ENTER on your remote control to show the Music Contents selection
screen.
PHOTO: Click ENTER on your remote control to show the Photo Contents selection
screen.
SERVER: Click ENTER on your remote control to show the Server selection screen.
Click ENTER on your remote control to show the Connected USB Device List.
USB:
Click ENTER on your remote control to show the Options screen.
OPTION:
Note: To directly access this screen, press the HOME button on the remote control.
Note: If the Intel® Viiv™ technology verified PC is powered down, selecting the Intel® Viiv™ Media Server will power it back up to provide access to music,
photo, video, and the Intel® Viiv™ Zone.
Menu Basics
The DSM-510 uses an on-screen menu interface. As you move through the menus, you will use the selection arrows on the remote
control to move up, down, right and left. The highlight bar moves from item to item as you press the selection arrows. You will need
to press ENTER on the remote control to access the item. The Page Up and Page Down buttons can be used to navigate through the
track list one page at a time. Once you are in a particular category, you can press the MENU button on your remote control to access
the pulldown menu within that category.
D-Link DSM-510 User Manual
56
Section 4 - Operation
Music
Music Quality
Your music listening experience on the media player depends upon the quality of your digital music files on your PC. Avoid quality
settings below 48kbps as they create low quality audio. For CD quality music, rip your MP3s at 128kbps or higher, with a sample
rate of 44.1kHz.
Supported Music Formats
The following music file formats are supported:
•MP3 (up to 320 kbps)
MPEG-1, Layer 3 Audio file -The standard Internet music file
format. This is the most commonly used audio format.
•WMA (Does not support WMA lossless)
Windows Media Audio file - Supported by the Microsoft Windows
Media player and some music jukebox programs. Also supports
WMDRM protected WMA files downloaded from online services
and WMA Pro.
•WAV
WAV was developed by Microsoft and IBM. WAV sound files end
in .wav and are compatible with Windows applications supporting
audio.
•AIFF (AIFF files must be encoded in PCM format only.)
AIFF (Audio Interchange File Format) was developed by Apple
Computers and is the standard audio format for Macintosh
computers. File extensions are .AIF or .IEF.
•MPEG 1 and MPEG 2
Moving Pictures Experts Group created standards for compressing audio and video. Audio uses the file extension .mp3.
•OGG Vorbis
Open source audio format. Uses the file extension .ogg.
D-Link DSM-510 User Manual
57
Section 4 - Operation
Accessing Music
Select the MUSIC category from the HOME page or click the MUSIC button on the remote control. Select a category, by using the
down arrow and up arrow on the remote control to navigate (choose from Playlist, Genre, Artist, Album, All Music, Folders, or
Favorites). Select your option by clicking ENTER. If you want to play all of the tracks within the category you selected, simply press
the Play button. If you want to play just one track, use the up arrow and down arrow buttons to navigate one track at a time. After the
appropriate track is highlighted, press ENTER on the remote control. The Page Up and Page Down buttons can be used to navigate
through the track list one page at a time.
Playing a Track
Once you enter the music menu, there are several ways that you can view tracks. You can view Playlist, Genre, Artist, Album, All
Music, Folders, or Favorites.
If you select to view All Music (see the following menu), then use the
selection arrows to navigate to the track you wish to play. Once you
have located the appropriate track, highlight it and press ENTER or Play
on the remote control. The track will begin playing on your stereo or
television speakers.
To play all of the tracks visible in this category, simply press Play.
D-Link DSM-510 User Manual
58
Section 4 - Operation
Playing a Group of Songs
Select a music folder and press the Play button on the remote control, all of the songs within the selected folder will be played. You
can highlight a genre of music and all files that are associated with that genre will be displayed. Genre categories are defined when
an audio file is created.
You can play songs within a folder from a specified track forward. For instance, if you have a folder with ten tracks and select Track
3, clicking on the Play button will play tracks 3 through 10.
Creating Music Playlists using 3rd Party Software
Use your favorite music software on your PC to create music playlists. A playlist allows you to specify exactly what tracks to play
and in what order to play them. For example, create a “favorites” playlist and just listen to your favorite tracks.
The DSM-510 will play tracks from playlists you create on your computer. The media player supports playlists in three standard
formats:
•m3u Playlist File
•pls Playlist File
•wpl Playlist File
Software for playing music on your PC can be used to create playlists. WinAmp™ and Microsoft Windows® Media Player™ are two
examples.
D-Link DSM-510 User Manual
59
Section 4 - Operation
Playing a Playlist
To play all the tracks in a playlist, select the playlist name and press the Play button. All tracks will be played in the playlist.
Adding Favorites
Click the MENU button on your remote control and you should see the Add Favorite option. Highlight the Add Favorite option and
press ENTER (see the following image).
Select the Favories folder you want to add this Playlist, Genre, Artist, Album,
or Folder to and click OK.
D-Link DSM-510 User Manual
60
Section 4 - Operation
Browsing for Music
There are many ways to browse for a music track. For example, let’s use the following music file located in the following shared
location:
c:\Documents and Settings\Administrator\My Documents\My Music\Beethoven\Ode to joy.mp3
To browse for this track in the track list:
1. Select All Music
2. Highlight Ode to joy
To browse by artist:
1. Select Artist
2. Select Ludwig van Beethoven
3. Select Beethoven
4. Highlight Ode to joy
Track: Ode to joy.mp3
Artist: Ludwig van Beethoven
Album: Beethoven
Genre: Classical
To browse by album:
1. Select Album
2. Select Beethoven
3. Highlight Ode to joy
To browse by genre:
1. Select Genre
2. Select Classical
3. Select Ludwig van Beethoven
4. Select Beethoven
5. Highlight Ode to joy
To browse by folder:
1. Select Folders
2. Select My Music
3. Select Beethoven
4. Select Ode to joy
D-Link DSM-510 User Manual
61
Section 4 - Operation
Controlling Music Playback
Your DSM-510 works just like a stereo or CD player. Controlling your music playback will be an easy and natural experience. Use the
remote to Play, Pause, or Stop music. You can also use your remote control to Fast Forward or Fast Reverse the track. Press the
Previous and Next buttons to skip to the previous or next track.
Repeat
You can turn on the repeat function to continuously play individual tracks, playlists, or groups of tracks within a folder.
To repeat a track or a group of tracks, press REPEAT on the remote control. When the the Repeat icon appears in the lower right
hand corner
, than you are in the repeat current group of tracks mode. Press REPEAT for the second time and the Repeat One
icon will appear in the lower right hand corner
, this will repeat the track that is currently playing.
Shuffle
When you are playing a group of tracks, you can randomize the play order by pressing the SHUFFLE button on the remote control.
You will see the shuffle icon in the lower right hand corner light up
.
D-Link DSM-510 User Manual
62
Section 4 - Operation
Time Search
You can search to a specific time in a music file by using the Time Search
function. While your music is playing, click the MENU button on your
remote control. Navigate to the Time Search option and press ENTER
(see the following image). Using your remote control, enter the minutes
and seconds you want the player to start from, and click OK.
Note: The Time Search function may not be supported outside the Intel®
Viiv™ Server.
D-Link DSM-510 User Manual
63
Section 4 - Operation
Podcasts
After selecting the Music option from the DSM-510 main menu, a new menu will
appear. Locate and select the Podcast option.
To add or import a podcast stream, use your remote control and select the MENU
button.
D-Link DSM-510 User Manual
64
Section 4 - Operation
Importing Podcasts
You should see a menu that appears over the podcast section.
(1) To import your Podcasts you will need a USB thumb drive. You can either export your podcasts from iTunes software or create
your own list in notepad on your pc. If you are manually creating your list please use the following format.
<?xml version=”1.0” encoding=”UTF-8”?>
<opml version=”1.0”>
<head>
</head>
<body>
<outline type=”rss” xmlUrl=” http://www.dlinktv.com/podcast” />
<outline type=”rss” xmlUrl=” http://www.yourpodcasthere/url” />
</body>
</opml>
(2)Once you have added your URL’s to the notepad document, save the file as Podcasts.opml.
Note: Make sure that the save as type is set to All Files, and then click Save.
(3) Next, copy your Podcasts.opml document to your USB thumb drive. Insert your
USB thumb drive into the front panel of the DSM-510.
(4) Next, go to Music > Podcasts. Select MENU on your remote control, locate the
Import option and press ENTER on your remote control..
(5) The DSM-510 will now search your USB drive for the Podcasts.opml file and
save the links into your device.
(6) Once the links have been loaded you may remove your USB thumb drive and
access your Podcast stations.
D-Link DSM-510 User Manual
65
Section 4 - Operation
Adding Podcasts
Using your remote control, toggle down to the option Add Podcast and select the
remote’s ENTER button.
On the following screen, enter the URL of the podcast stream by accessing the
on-screen keyboard option.
D-Link DSM-510 User Manual
66
Section 4 - Operation
Using your remote control, toggle to the appropriate letter and press ENTER. After
you’ve completed entering the URL, click OK.
The podcast stream should now appear on the podcast main menu screen. Select
your stream by clicking the remote’s ENTER button.
D-Link DSM-510 User Manual
67
Section 4 - Operation
The following screen will showcase all available streams. Use your remote control
to toggle and select your option.
After a selection has been made, the file will play.
D-Link DSM-510 User Manual
68
Section 4 - Operation
The following photo file formats are supported:
Supported Photo Formats
•BMP (non-compressed)
Windows bitmap file. Widely used in Microsoft
Windows for pictures and backgrounds.
•JPEG (grayscale, RGB, YCbCy)
(Does not support CMYK, YCCK.)
The JPEG format is the Internet and digital photo
format standard used by most digital cameras.
•GIF
(Animated GIF’s are not supported)
Older format still widely available on the internet
for photos, web pages, and clip art.
•PNG (Non-alpha channel only)
Portable Network Graphics standard created in
response to limitations in the GIF file format.
•TIFF (RGB)
(Does not support CMYK, YMC, YMCK, KCMY)
Tagged Image File Format is a raster file format.
Select the PHOTO category from the Home page or click the PHOTO button on the remote control. Select a category, by using the
down arrow and up arrow on the remote control to navigate (choose between All Pictures, Album, or Favorites). Select your category
by clicking ENTER. After the appropriate picture is highlighted, press ENTER, or Play to start a slideshow, on the remote control.
The Page Up and Page Down buttons can be used to navigate through the picture list one page at a time.
D-Link DSM-510 User Manual
69
Section 4 - Operation
Organizing Photo Albums
Unlike music files, photos contain little information about their content. Therefore, photos are organized by their filename and by the
folder they are in. Many digital cameras will organize your photos into folders when you connect and unload them to your PC. Each
time you dock or connect, a new folder is created using the current date and time, and all photos are copied into that folder.
To simplify browsing on your DSM-510, you can create folders on your PC. For instance, create a folder in the My Pictures directory
called Vacation and copy all of your vacation photos into it. Your DSM-510 will show the Vacation folder. To play a slideshow of the
folder, highlight it and press the Play button. To view a list of photos in the folder, highlight it and press the right arrow button.
You can give your photos meaningful names by renaming the files on the PC. Most digital cameras number photos sequentially.
For example, rename the photo IM001125.jpg to sunset.jpg on your PC. The photo will be displayed as sunset.jpg on your DSM510*.
Right-click on the file and select Rename.
If the file extension does not appear as part of the
name displayed when you select rename, then it
is not necessary to enter the file extension (.jpg)
at the end of the filename. To rename IM001125.
jpg to sunset.jpg, type in sunset and hit Enter on
your computer’s keyboard.
sunset
If the file extension appears as part of the name
when you select rename, then be sure to include
the extension when renaming the file. To rename
IM001125.jpg to sunset.jpg, type in sunset.jpg
and hit Enter on your computer’s keyboard.
You can create as many folders as you need. Create a folder for the year, then create folders inside for each of the months, and then
folders in each month for special occasions (birthday, vacation, holidays, etc...).
*Folder creation and renaming files must be done on the PC via standard Windows® procedures.
D-Link DSM-510 User Manual
70
Section 4 - Operation
Playing a Photo Slideshow
To start playing a photo slideshow, select a folder and press Play to start your slideshow. The first photo will be displayed, followed
by the next photo in the folder, and so on. All the photos in the folder will display.
Playing a Photo Slideshow with Music
To start playing a photo slideshow accompanied by music, start by selecting a music track in a folder and press the Play button. Next,
press the BACK button on the remote control to exit the music playing screen and return to the list of music tracks. You can also
press the PHOTO button and select the folder that has the photos to be displayed. Select the first photo to be viewed and press the
Play button to start your slideshow. All the photos in the folder will display. Before you begin the slideshow, or after it ends, press
the MUSIC button to return to the list of music tracks.
You can also play music from your favorite list by pressing the menu key during a photo slideshow and selecting the favorite group
with your music.
If you wish to retun to the music you were playing before starting the slideshow, press the BACK button on the remote control to
leave the photo slideshow. Then press the MENU key on the remote control and select View Current Slideshow Music.
Controlling Photo Playback
Controlling photo playback is very similar to controlling a CD player. Once you have started a photo slideshow, use the remote to
Play, Pause, or Stop the show. Press the Previous and Next buttons to skip to the previous or next photo.
Repeat
You can turn on the repeat function to repeat all of the photos in a slideshow.
To repeat a slideshow, press REPEAT on the remote control. When the the Repeat icon appears in the lower right hand corner
than you are in the repeat current slideshow mode.
,
Shuffle
During slideshow playback you can shuffle the order by pressing the SHUFFLE button on the remote control.
D-Link DSM-510 User Manual
71
Section 4 - Operation
Video
The following video file formats are supported:
Supported Video Formats
•MPEG-1 (Resolution up to 480p)
•MPEG-2 (Resolution up to 1080i)
•MPEG-4 (ASP - Advanced Simple Profile)
•AVI (MPEG4 layer only, does not support uncompressed AVI, Resolution up to 1080i)
•XVID (with MP3 and PCM)
•WMV9 (Resolution up to 720p)
•DVR-MS (Recorded TV files from Microsoft Windows® Media Center Edition)
Viewing a Video
Once you enter the VIDEO menu, you can view your list of videos.
Use the selection arrows to navigate to the video folder you wish to view
(choose from All Video, Genre, Actor, Folder, or Favorites). Highlight the
video folder and press ENTER.
After you have selected a video folder, scroll down and highlight the video
you wish to view and press ENTER. The Page Up and Page Down buttons
can be used to navigate through the picture list one page at a time.
D-Link DSM-510 User Manual
72
Section 4 - Operation
DivX®
DivX® is a video technology that compresses video. When streaming video to devices like the DSM-510 it is important to use smaller
bandwidth files in order to eliminate interrupted video transmission. Using DivX® to compress your videos allows you to save them
and send them much more efficiently.
The DSM-510 is a DivX® Home Theater Certified device. Being certified by DivX® guarantees that the DSM-510 can playback DivX®
video files.
Playing a DivX® file
Playing a DivX® file on the D-Link DSM-510 is just like playing any other video file. Once you have placed the video file in your shared
directory you will be able to view it by following the instructions listed on Pg. 72.
To create DivX® video files using the DivX® converter you can simply drag your pre-existing video files onto the DivX® converter
software, select the video type by click the left or right arrow on the application and then click the convert button.
Playing DivX® VOD content
In order to play back DivX® Video On Demand content with your DSM-510 you must first install the DivX® player software on your
PC and register an account. Once you have installed the DivX® player software (either through the included Autorun CD or from
http://www.divx.com) you may register an account by doing the following.
Step 1. Step 2. Step 3. Open DivX® Player.
Select Tools > Device Management
If you have not registered for an account you will be prompted to register. Please enter in the required information to
create your account.
D-Link DSM-510 User Manual
73
Section 4 - Operation
Step 4. Step 5. Step 6. Step 7. Step 8. Step 9. Step 10. Login to your DivX® account.
Click the register device button at the bottom.
Select D-Link from the brand list and then click Next.
Click the next button after entering your DivX® VOD code and a friendly device name.
Your DivX® player will now begin downloading the Activate video file. This needs to be played on your DSM-510
in order to complete the activation process.
Once the download is complete, rename the file from friendlydevicename.divx to friendlydevicename.avi.
Share this device from your media server and play it on your DSM-510 to finalize activation.
How to display my DiVX Registration Code
Step 1. Step 2. Step 3. Press the setup key on the remote control.
Select DivX® VOD Reigstration Code from the device menu.
Write down the Registration code provided, and when prompted by the DivX® Player enter the code for your devices
activation code.
Note: Pressing the SHIFT button on your DSM-510 remote control allows you to switch in between different DivX® subtitles. Pressing
the L/R button on your DSM-510 remote control allows you to switch in between different DivX® audio languages.
D-Link DSM-510 User Manual
74
Section 4 - Operation
Time Search
You can search to a specific time in a video file by using the Time Search
function. While your video is playing, click the MENU button on your
remote control. Navigate to the Time Search option and press ENTER
(see the following image). Using your remote control, enter the minutes
and seconds you want the player to start from, and click OK.
Note: The Time Search function may not be supported outside the Intel®
Viiv™ Server.
D-Link DSM-510 User Manual
75
Section 4 - Operation
Search Filter
When browsing the menus of music, photos, and videos, you can press the
MENU button on the remote control and select the filter option. You may also
press the SEARCH button on your remote control to bring up the filter menu.
Select the Filter option and press ENTER on your remote control.
The following screen should reveal the filter menu. You can search your content
for titles, albums, artists, and genres. The search filter will only work when
accessing your music, photos, and videos through the top level menu. The
search filter will not work when accessing your content through the server
select screen.
D-Link DSM-510 User Manual
76
Section 4 - Operation
Intel® Viiv™ Zone
The Intel® Viiv™ Zone is your gateway to a world of online applications and services,
and is only made available to Viiv™ PCs only.
Click on a category by using the buttons on the left (see the following image) and
browse the available applications and services.
D-Link DSM-510 User Manual
77
Section 4 - Operation
Server
Use the selection arrows and the ENTER button to select a media source for your
photos, music, and video files.
Once the media server is selected you can browse your files that are being shared
on your server.
D-Link DSM-510 User Manual
78
Section 4 - Operation
USB
If there is a USB thumbdrive plugged in to the device, the DSM-510 will display a storage
device menu. When you plug in a USB thumbdrive, the USB thumbdrive type will display.
Use the selection arrows and press ENTER to select a USB thumbdrive for viewing. Depending on your photo display options,
your files will either display in a list or as thumbnails. Press ENTER to display the image in a full screen and use the up and down
selection arrows to navigate back and forward through your files. You can also select Auto Play in the setup menu and your files will
automatically play when a card is inserted.
Note: When playing MP3s, you can press the INFO button for information on the current track playing.
D-Link DSM-510 User Manual
79
Section 5 - Troubleshooting
Troubleshooting
1 What kind of files are supported by the DSM-510?
Audio - MP3, WMA, WAV, AIFF, OGG
Video - WMV9, MPEG 1, 2, and 4, AVI, XVID, DVR-MS
Images - JPEG, PNG, BMP, GIF, TIFF
2. What do I need to set up the D-Link’s DSM-510?
You must have a Microsoft Windows®-based home network in place, with at least one Intel® Viiv™ technology-based PC or a PC
running Microsoft Windows® Vista/XP.
3. What is required to run the server software?
Intel® Viiv™ technology-based verified PC is required to run the Intel® Viiv™ media server, or a Windows® Vista/XP PC with Windows®
Media Player 11 installed.
4. How does the D-Link DSM-510 get its files from my computer?
The Intel® Viiv™ Media Server software on your PC will launch, allowing you to add media files. You may then select folders that
contain music, photos, and videos that you want to play. If you have a PC running Windows® Vista/XP, the Windows ® Media Player
11 software that supports the DSM-510 should already be installed on your Windows® PC or you can launch the Windows® Update
service to download and install it.
D-Link DSM-510 User Manual
80
Section 5 - Troubleshooting
5. Why do my WMA files fail to play?
The following low bit rate WMA files may fail to play:
WMA 9.1 Quality 10 44kHz Stereo VBR
WMA 9.1 Lossless Quality 100 @ 96kHz 2channel 24bit VBR
WMA 9.1 Voice Quality 4kbps 8kHz mono
WMA 9.1 Voice Quality 20kbps 22kHz mono
WMA 9.1 Quality 98 44kHz Stereo
WMA 9.1 Lossless Quality 100 @ 44kHz 2channel 16 bit VBRnetwork.
6. What about Copy Protection and DRM support?
The most common method of copy protection is WM DRM (Digital Rights Management). The DSM-510 can play these types of files
from your Intel® Viiv™ technology verified PC or a Windows® PC, running WMP11 or Windows Media Connect.
7. Can I use my Universal remote control?
No, the DSM-510 is not compatible with a universal remote but you can use a remote with learning ability.
8. Can I connect the DSM-510 directly to a PC without using a router or a hub?
Yes, please make note of the following:
Wireless Users: Set the Mode to Ad-Hoc in the wireless settings.
Wired Users: Connect an Ethernet cable directly from the DSM-510’s Ethernet port to the Ethernet port on your PC. The DSM-510’s Ethernet port is Auto MDI/MDI-X, so a special Ethernet cable is not required.
All Users: If DHCP software isn’t running on your computer, you will need to assign a static IP address to the DSM-510 by changing the network settings from automatic to manual.
Note: The Viiv™ Zone and firmware upgrades are not available without an Internet connection.
D-Link DSM-510 User Manual
81
Section 5 - Troubleshooting
9. How do I change the bit rate of an audio file?
There are various audio editing programs available for download on the Internet.
10. Why do my AVI files fail to play?
The DSM-510 will only support MPEG-4 encoded AVI files. You may need to re-encode your AVI files with a video encoding software
program, such as Nero Recode.
11. I cannot see anything when I turn on my DSM-510 player for the first time.
• Make sure your TV is displaying the appropriate video source. You may need to use the AV Input, Source, Select, or
TV/Video button on your TV or TV remote to change video sources. If you are having trouble changing the video source,
refer to the instructions that came with your TV.
• If you did not connect the player directly to your TV, but are instead passing the signal through your VCR, make sure
your VCR is displaying the appropriate video source. You may need to use the Input or Source button on your VCR
or VCR’s remote control. Some VCRs only pass the signal through when they are turned off. If you are having trouble
displaying the correct video source, refer to the instructions that came with your VCR.
• Make sure cables are connected to the IN jacks on your TV or VCR, not the OUT jacks.
• The cables you are using to connect your receiver to your TV or other equipment may be damaged or defective. Try
exchanging the cables connected to the receiver with other cables that you know are working properly.
• Make sure you have firmly attached the power adapter plug to the back of the player. Also, verify the power adapter is
plugged into a working power outlet and that the outlet is not controlled by a light switch.
12. My remote control isn’t working.
• Make sure the batteries are inserted correctly.
• Try removing the batteries and reinserting them without touching any buttons on the remote control.
• Replace the batteries with new ones.
13. The volume and mute buttons on the remote control don’t work when playing content that was encoded in 5.1 surround.
• The volume can only be adjusted on your digital stereo receiver. The DSM-510 can pass-through the audio signal to a
D-Link DSM-510 User Manual
82
Section 5 - Troubleshooting
compatible audio receiver for multi-channel decoding.
14. I can’t find any of my music, photos, or video.
• If using a wired network, verify the Ethernet cable is properly attached to your DSM-510 and to a network switch, hub
or router. Verify that the switch, hub or router is powered on.
• If you are using static IP addresses, verify the IP address and netmask are in the same range as other addresses on
your network. Verify that the address is not already in use by another PC or device.
• Make sure the files you are sharing use a supported file format and encoding scheme.
• Verify the folder is shared in the Viiv Media Libary on your Intel® Viiv™ technology verified PC.
15. I can’t hear any sound when I’m playing music.
• Make sure the audio cables are properly connected.
• If the audio cables are connected to your TV, the TV must be on to hear any music.
• If the audio cables are connected to your stereo, make sure the stereo is on and you have the correct stereo input
source selected. If you are having trouble selecting the correct audio source, refer to the instructions that came with
your stereo.
16. Some of my MP3 and WMA files don’t appear.
• The DSM-510 supports the most common music file formats. However, there are almost an infinite variety of bit rates
and sample rates. If a file does not appear on the receiver, it most likely uses an unsupported rate.
• The files may be copy protected. To share your files, turn copy protection off when you rip them.
• The following MP3 sample rates are supported: 4, 8, 16, 22.05, 24, 32, 44.1, 48, 88.2 and 96 kHz.
• For best results, rip your MP3 files at 128 kbps or higher, with a sample rate of 44.1 kHz.
17. I am not able to play certain media files.
• The DSM-510 supports most industry standard file formats but even supported file formats can be encoded in ways
that are not supported. Try exporting media with different encoding settings or using different software applications
to encode your files.
D-Link DSM-510 User Manual
83
Section 5 - Troubleshooting
18. Checking the bit and sample rates of a music file.
• To check the bit and sample rates of a music file:
1. Right-click on the file and select Properties.
2. Select the Summary tab and click the Advanced button. Scroll to the bottom of the list.
In most cases, the sample rate does not matter unless you come across a file that will not play or appear on your player.
Use the above procedure to check the file settings for supported rates.
19. I created a playlist on my computer, but it doesn’t appear on my media player.
• Make sure the playlist file is located in a folder shared by your media player. Copy the playlist to your shared music
folder or click on the Media Server icon to add or change your folder options.
20. How do I reset my DSM-510?
• Under normal circumstances, you should not need to reset your media player. However, to fully reset the media player,
press the SETUP button and select Reset Settings.
21. What version of firmware do I have?
• From the main home screen, press the SETUP button and select Device Information. The firmware version will be
listed.
22. The DSM-510 will not play my AVI files.
• Make sure that your AVI files are smaller than 2GB. AVI files have a limitation of 2GB. This is a limitation set in the AVI
standard.
24. The DSM-510 will not play my WMV files.
D-Link DSM-510 User Manual
84
Section 5 - Troubleshooting
• Make sure that your WMV files are not recorded at a resolution above 1080i. Playback of WMV files will only work if
the resolution is 1080i or below.
D-Link DSM-510 User Manual
85
Appendix A - Wireless Basics
Wireless Basics
D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity
within your home, business or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family
of products will allow you to securely access the data you want, when and where you want it. You will be able to enjoy the freedom
that wireless networking delivers.
A wireless local area network (WLAN) is a computer network that transmits and receives data with radio signals instead of wires.
Wireless LANs are used increasingly in both home and office environments, and public areas such as airports, coffee shops and
universities. Innovative ways to utilize WLAN technology are helping people to work and communicate more efficiently. Increased
mobility and, the absence of cabling and other fixed infrastructures have proven to be beneficial for many users.
Under many circumstances, it may be desirable for mobile network devices to link to a conventional Ethernet LAN in order to use
servers, printers or an Internet connection supplied through the wired LAN. A Wireless Router is a device used to provide this link.
D-Link DSM-510 User Manual
86
Appendix A - Wireless Basics
What is Wireless?
Wireless or WiFi technology is another way of connecting your computer to the network without using wires. WiFi uses radio frequency
to connect wirelessly, so you have the freedom to connect computers anywhere in your home or office network.
Why D-Link Wireless?
D-Link is the worldwide leader and award winning designer, developer, and manufacturer of networking products. D-Link delivers
the performance you need at a price you can afford. D-Link has all the products you need to build your network.
How does wireless work?
Wireless works similar to how cordless phones work, through radio signals that transmit data from point A to point B. But wireless
technology has restrictions as to how you can access the network. You must be within the wireless network range area to be able
to connect your computer. There are two different types of wireless networks Wireless Local Area Network (WLAN), and Wireless
Personal Area Network (WPAN).
Wireless Local Area Network (WLAN)
In a wireless local area network, a device called an Access Point (AP) connects computers to the network. The access point has a
small antenna attached to it, which allows it to transmit data back and forth over radio signals. With an indoor access point, the signal
can travel up to 300 feet. With an outdoor access point the signal can reach out up to 30 miles to serve places like manufacturing
plants, industrial locations, college and high school campuses, airports, golf courses, and many other outdoor venues.
Who uses wireless?
Wireless technology has become so popular in recent years that almost everyone is using it, whether it’s for home, office, or business,
D-Link DSM-510 User Manual
87
Appendix A - Wireless Basics
D-Link has a wireless solution for it.
Home
• Gives everyone at home broadband access
• Surf the web, check email, instant message, and etc
• Gets rid of the cables around the house
• Simple and easy to use
Small Office and Home Office
• Stay on top of everything at home as you would at office
• Remotely access your office network from home
• Share Internet connection and printer with multiple computers
• No need to dedicate office space
Where is wireless used?
Wireless technology is expanding everywhere, not just at home or the office. People like the freedom of mobility and it’s becoming
so popular that more and more public facilities now provide wireless access to attract people. A wireless connection in a public place
is usually called a “hotspot”.
D-Link DSM-510 User Manual
88
Appendix A - Wireless Basics
Using a D-Link Cardbus Adapter with your laptop, you can access the hotspot to connect to the Internet from remote locations like:
Airports, Hotels, Coffee Shops, Libraries, Restaurants, and Convention Centers.
A wireless network is easy to setup, but if you’re installing it for the first time it could be quite a task not knowing where to start.
That’s why we’ve put together a few setup steps and tips to help you through the process of setting up a wireless network.
Tips
Here are a few things to keep in mind, when you install a wireless network.
Centralize your router or Access Point
Make sure you place the router/access point in a centralized location within your network for the best performance. Try to place the
router/access point as high as possible in the room, so the signal gets dispersed throughout your home. If you have a two-story
home, you may need a repeater to boost the signal to extend the range.
Eliminate Interference
Place home appliances such as cordless telephones, microwaves, and televisions as far away as possible from the router/access
point. This would significantly reduce any interference that the appliances might cause since they operate on the same frequency.
Security
Don’t let you next-door neighbors or intruders connect to your wireless network. Secure your wireless network by turning on the
WPA or WEP security feature on the router. Refer to the product manual for detailed information on how to set security up.
D-Link DSM-510 User Manual
89
Appendix A - Wireless Basics
Wireless Modes
There are basically two modes of networking:
•Infrastructure – All wireless clients will connect to an access point or wireless router.
•Ad-Hoc – Directly connecting to another computer, for peer-to-peer communication, using wireless network adapters
on each computer, such as two or more WNA-1330 wireless network Cardbus adapters.
An Infrastructure network contains an Access Point or wireless router. All the wireless devices, or clients, will connect to the wireless
router or access point.
An Ad-Hoc network contains only clients, such as laptops with wireless cardbus adapters. All the adapters must be in Ad-Hoc mode
to communicate.
D-Link DSM-510 User Manual
90
Appendix B - Networking Basics
Networking Basics
Check your IP Address
After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server
(i.e. wireless router) automatically. To verify your IP address, please follow the steps below.
Click on Start > Run. In the run box type cmd and click OK.
At the prompt, type ipconfig and press Enter.
This will display the IP address, subnet mask, and the default
gateway of your adapter.
If the address is 0.0.0.0, check your adapter installation, security
settings, and the settings on your router. Some firewall software
programs may block a DHCP request on newly installed
adapters.
If you are connecting to a wireless network at a hotspot (e.g.
hotel, coffee shop, airport), please contact an employee or
administrator to verify their wireless network settings.
D-Link DSM-510 User Manual
91
Appendix B - Networking Basics
Statically Assign an IP Address
If you are not using a DHCP capable gateway/router, or you need to assign a static IP address, please follow the steps below:
Step 1
Windows® XP - Click on Start > Control Panel > Network Connections.
Windows® 2000 - From the desktop, right-click My Network Places > Properties.
Step 2
Right-click on the Local Area Connection which represents your D-Link network adapter and select Properties.
Step 3
Highlight Internet Protocol (TCP/IP) and click Properties.
Step 4
Click Use the following IP address and enter an IP address that is on the same subnet as your network or the LAN IP address on
your router.
Example: If the router´s LAN IP address is 192.168.0.1, make your IP address 192.168.0.X
where X is a number between 2 and 99. Make sure that the number you choose is not in
use on the network. Set Default Gateway the same as the LAN IP address of your router
(192.168.0.1).
Set Primary DNS the same as the LAN IP address of your router (192.168.0.1). The Secondary
DNS is not needed or you may enter a DNS server from your ISP.
Step 5
Click OK twice to save your settings.
D-Link DSM-510 User Manual
92
Appendix C - General Appendix
General Appendix
How to Check your Media
For WMA/WMV/MP3, you may use “Windows Media ASF Viewer 9 Series” to examine your media files. This tool can be
downloaded from: http://www.microsoft.com/windows/windowsmedia/format/ASFViewer.aspx
Here is a sample screenshot of the Windows Media ASF Viewer examining a WMV file.
For AVI/WMV/OGG/MPEG/MP3, you may use “AVICodec” to examine your media
files. This tool can be downloaded from:
http://avicodec.duby.info/
Here is a sample screenshot of AVICodec
D-Link DSM-510 User Manual
93
Appendix C - General Appendix
Convert an Earlier WMV File into WMV9
There are many variations of video files (including WMV files) which may affect playback on the DSM-510. To alleviate this issue, there
are software tools available on the web to check the properties of a video file and to convert an earlier WMV file into WMV9. If you have
Windows® XP or ME, your Windows comes with a tool from Microsoft called “Movie Maker.” With this tool, you can create and edit
video files into Windows Media Video 9 (WMV9) format. Here is an example of converting a WMV8 file into WMV9.
Step 1: Verify your WMV file codec using a validation tool. In the “Video” field, it tells you the selected video file is a WMV8 instead of
a supported WMV9 by your HD media player. Therefore, we need to convert this file into a WMV9 format in order for you to play it.
This is AVIcodec, which is used to check for an earlier version of
a WMV file.
Step 2: Open “Windows Movie Maker”. Import the video you wish to convert.
D-Link DSM-510 User Manual
94
Appendix C - General Appendix
Step 3: Select the video file.
Step 4: Movie Maker will start importing the file.
D-Link DSM-510 User Manual
95
Appendix C - General Appendix
Step 5: The video file you selected will show up in display.
Step 6: Drag and drop the video into the bottom panel for editing.
D-Link DSM-510 User Manual
96
Appendix C - General Appendix
Step 7: Select “Save to my computer” on the left panel.
Step 8: Give the new file a name and select the desired location to save it.
D-Link DSM-510 User Manual
97
Appendix C - General Appendix
Step 9: Select the quality of your new video file.
Step 10: Once selected, Movie Maker will start creating your new video file.
D-Link DSM-510 User Manual
98
Appendix C - General Appendix
Step 11: Once completed, this screen will show up.
You can verify the new video file is created in WMV9 format.
This screenshot shows you both the old file (WMV8) and the new file
(WMV9).
D-Link DSM-510 User Manual
99
Appendix C - General Appendix
Remote Control Table
Power
Turn the DSM-510 ON or OFF.
HOME
Returns to the Home menu page
Number Keys
Allows you to enter alphanumeric information
SHIFT
Allows you to use upper and lower case letters and/or numbers for entering characters. Pressing the SHIFT button on your DSM-510 remote control allows you
to switch in between different DivX® subtitles.
DELETE
Delete numbers and text.
BACK
Return to the previous page.
SETUP
Access the Setup Menu.
MUTE
Turn OFF the audio.
Page Up/Down
Arrow keys ENTER
Vol + Vol - Press Up to scroll up a page, and press Down to scroll down a page.
Move the onscreen cursor to navigate through the user interface.
Selects a single file for playback, and allows the selection of menu options.
Increase the volume.
Decrease the volume.
MENU
Access the current mode’s menu.
MUSIC
Access the Music mode.
Access the Photo mode.
VIDEO Access the Video mode.
SERVER Access the Server mode.
USB Access the USB thumbdrive mode.
Play Functions
While viewing and listening to your media, you can use these keys to Stop, Play/Pause, Rewind, Fast Forward, go back (Prev), or go to the next item (Next).
REPEAT
Repeat the current Music, Video, Photo Slideshow selection.
SHUFFLE
Randomize the current Music, Video, Photo Slideshow selection.
SEARCH
Search for a specific file or folder.
INFO
Access the information on a music, photo, or video file that is currently playing.
SLOW
Slows down the music or video file that is currently playing.
A-B
Select a start point (A) and an end point (B) of video to replay while viewig a video.
L/R
Changes a mode of a sound that is currently playing from a music or video file. Pressing the L/R button on your DSM-510 remote control allows you to switch in
between different DivX® audio languages.
D-Link DSM-510 User Manual
Ver.1.1(E)_20070919
100
