SLA6845MZ

High Voltage 3-Phase Motor Driver

Features and Benefits

Built-in pre-drive IC

IGBT power element

CMOS compatible input (3.3 to 5 V)

High-side gate driver using bootstrap circuit or floating power supply

Integrated Fast Recovery Diode (FRD) as freewheeling diode for each IGBT

Built-in protection circuit for controlling power supply voltage drop

Built-in overtemperature detection circuit (TD)

Output of fault signal during operation of protection circuit

Output current 3 A

Small SIP (SLA 24-pin)

Package: Power SIP

Description

The SLA6845MZ inverter power module (IPM) device provides a robust, highly-integrated solution for optimally controlling

3-phase motor power inverter systems and variable speed control systems used in energy-conserving designs to drive motors of residential and commercial appliances. These ICs take 230 VAC input voltage, and 3 A (continuous) output current. They can withstand voltages of up to 600 V (IGBT breakdown voltage).

The SLA6840M power package includes an IC with all of the necessary power elements (six IGBTs), pre-driver ICs

(two), and freewheeling diodes (six), needed to configure the main circuit of an inverter. This enables the main circuit of the inverter to be configured with fewer external components than traditional designs.

Applications include residential white goods (home applications) and commercial appliance motor control:

• Air conditioner fan

• Refrigerator compressor

• Dishwasher pump

Leadform

2171

Leadform

2175

Not to scale

Leadform

2178

Functional Block Diagram

VB 1 VB 2 VB3

VBB 1

VBB 2 VCC1

HIN1

HIN2

HIN3

COM1

UVLO

Input

Logic

VCC2

VREG

LIN1

LIN2

LIN3

COM2

FO

7.5 V

Reg.

UVLO

Input

Logic

Figure 1. Driver block diagram.

UVLO UVLO UVLO

High Side

Level Shift Driver

Overtemperature

Detection

Low Side

Driver

U

V

W1

W2

LS3

LS2

LS1

SLA6845MZ-DS

SLA6845MZ

High Voltage 3-Phase Motor Driver

Selection Guide

Part Number

SLA6845MZ

Packing

18 pieces per tube

IGBT Breakdown

Voltage, V

CES

(min)

(V)

600

IGBT Saturation

Voltage, V

CE(sat)

(typ)

(V)

1.75

Output Current

Continuous, I

O

(max)

(A)

Pulsed, I

OP

(A)

(max)

3 6

Absolute Maximum Ratings

, valid at T

A

= 25°C

Characteristic

Main Supply Voltage

Main Supply Voltage (Peak)

Symbol

V

BB

V

BB(surge)

Remarks

Maximum voltage that can be applied between VBB and LSx continuously

Maximum voltage allowed between VBB and LSx, including transient switching noise. If surge voltages reach this rating, the snubber circuit should be improved so the voltage does not exceed this level.

IGBT Breakdown Voltage

Logic Supply Voltage

Bootstrap Voltage

Output Current, Continuous

Output Current, Pulsed

Output Current for Regulator

Input Voltage

Allowable Power Dissipation

Thermal Resistance (Junction to Case)

Thermal Resistance (Junction to Ambient)

Case Operating Temperature

Junction Temperature (IGBT)

Storage Temperature

V

IN

P

D

R

JC(I)

R

JC(F)

R

JA

T

COP

T

J

T stg

V

CES

V

CC

V

BS

I

O

I

OP

I

REG

Between VCC and COM

Between VB and HS (U,V, and W phases)

T

C

= 25°C

PW

≤ 100 μs

T

C

= 25°C, all elements operating

All elements operating (IGBT)

All elements operating (FRD)

All elements operating (IGBT and FRD)

Rating

450

500

600

20

20

3

6

35

–0.5 to 7

32

3.8

4.2

25

–20 to 100

150

–40 to 150

Unit

V

V

°C/W

°C/W

°C/W

°C

°C

°C

A mA

V

W

V

V

V

A

Recommended Operating Conditions

Characteristic

Main Supply Voltage

Logic Supply Voltage

Shunt Resistor

Dead Time

Symbol

V

BB

V

CC

R

S t dead

Remarks

Between VBB and LS, I

BB

≤ 2 A

Between VCC and COM

LS1, LS2, LS3 to COM2

Between LS1, LS2, LS3 and COM

Overcurrent Protection (OCP)

Response Time t

OCP

No built-in OCP. If OCP required, implement using an external circuit. Measure t

OCP

from overcurrent occurrence to shutdown command received on corresponding HINx or LINx terminal.

Snubber Capacitor C

S

Between VCC and COM. Use properly-rated film capacitor for voltage surge suppression.

Junction Temperature T

J

All performance characteristics given are typical values for circuit or system baseline design only and are at the nominal operating voltage and an ambient temperature, T

A

, of 25°C, unless oth er wise stated.

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

Min.

13.5

0.3

1.5

0.01

Typ.

300

Max.

450

16.5

2.0

Units

V

V

μs

μs

0.1

125

μF

°C

2

SLA6845MZ

High Voltage 3-Phase Motor Driver

Typical Application Diagram

D

BOOT

R

BOOT

5

2 3 4

VB1 VB2 VB3

VCC1

HVIC

HO1

HS1

9

8

7

6

HIN1

HIN2

HIN3

COM1

HO2

HS2

HO3

HS3

SLA6845MZ

11

10

1

13

M

Cs

12

14

23

VCC2

LVIC

LO1

24

CC

20

LIN1

19

LIN2

18

LIN3

16

VREG

22

FO

21

COM2

LO2

LO3

17

15

RS

15V

NOTE:

All of the input pins are connected to GND with internal pull-down resistors rated at 100 k

Ω, however, an external pull-down resistor may be required to secure stable condition of the inputs if high impedance conditions are applied to them.

The external electrolytic capacitors should be placed as close to the IC as possible, in order to avoid malfunctions from external noise interference. Put a ceramic capacitor in parallel with the electrolytic capacitor if further reduction of noise susceptibility is necessary.

3

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

SLA6845MZ

High Voltage 3-Phase Motor Driver

ELECTRICAL CHARACTERISTICS, valid at T

A

=25°C, unless otherwise noted

Characteristics

Logic Supply Voltage

Logic Supply Current

Symbol

V

CC

I

CC

Between VCC and COM

V

CC

= 15 V, V

IN

= 5 V

Conditions

Input Voltage

Input Voltage Hysteresis

V

IH

V

IL

V

Ihys

I

IH

Input Current

V

CC

= 15 V, output on

V

CC

= 15 V, output off

V

CC

= 15 V

High side, V

CC

= 15 V, V

IN

= 5 V

Low side, V

CC

= 15 V, V

IN

= 0 V

Undervoltage Lockout

I

IL

V

UVHL

V

UVHH

V

UVHhys

V

UVLL

V

UVLH

V

UVLhys

High side, between VB and U, V, or W

High side, hysteresis

Low side, between VCC and COM

Low side, hysteresis

–V

O

for Output Voltage

1

LS Negative Surge Voltage 2

Between U, V, or W and COM

Between LS1, LS2, or LS3 and COM

FO Terminal Output Voltage

Overtemperature Detection Activating and Releasing Temperature

Output Voltage for Regulator

–V

O

V

LS

V

FOL

V

FOH

T

TDH

T

TDL

T

TDhys

V

REG

V

V

CC

V

CC

CC

= 15 V, I

= 15 V, I

FO

FO

= –1 mA

= –1.6 mA

= 15 V, no heatsink, I

REG

= 0 mA

IGBT Breakdown Voltage

IGBT Leakage Current

IGBT Saturation Voltage

Diode Forward Voltage

Diode Recovery Time

Switching Time, High Side

V

V

I

CES

CES

CE(sat)

V

F t rr t dH(on) t rH t dH(off)

I

REG

= 0 to 35 mA

V

CC

= 15 V, I

C

= 1 mA, V

IN

= 0 V

V

CC

= 15 V, V

CE

= 600 V, V

IN

= 0 V

V

CC

= 15 V, I

C

= 3 A, V

IN

= 5 V

V

CC

= 15 V, I

F

= 3 A, V

IN

= 0 V

I

F

= 3 A, di / dt = 100 A/

μs t fH t dL(on) t rL

V

BB

= 300 V, V

CC inductive load

Switching Time, Low Side t dL(off) t fL

1 Indicates normal operating range for the high-side driver IC.

2

Indicates the allowable range assuming any transient surge <1

μs.

= 15 V, I

C

= 3 A, 0 V

≤ V

IN

≤ 5 V, –

6.75

600

–5

–5

0

4.0

135

105

1.0

9.0

Min

13.5

9.5

10.0

11.0

10.5

11.5

– 0.5

Typ

15

4

2.0

1.5

0.5

50

2.5

100

– 2

10.0

11.0

10.5

0.5

Max Units

16.5

V

6 mA

11.5

V

V

V

μA

μA

V

V

V

12.0

12.5

V

V

V

150

120

30

7.5

5

1.0

5.5

165

135

8.25

1

°C

V

V mA

V

V

V

V

°C

°C

1.75

1.65

50

315

50

375

165

325

60

400

165

2.1

2.0

– ns ns ns ns ns ns ns

V

V ns ns

4

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

SLA6845MZ

High Voltage 3-Phase Motor Driver

High-Side Driver Input/Output Timing Diagrams

V

V

• High-side turn-on at next rising edge on HIN signal after UVLO release.

• FO output state does not change at high-side UVLO.

Low-Side Driver Input/Output Timing Diagrams

V

V

• Low-side turn-on in accordance with LIN signal level after UVLO release.

• FO output state goes high at low-side UVLO.

T

T

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

5

SLA6845MZ

High Voltage 3-Phase Motor Driver

Pin-out Diagram

Pad Side

1 3 5 7 9 11 13 15 17 19 21 23

2 4 6 8 10 12 14 16 18 20 22 24

(Top View)

Terminal List Table

Number Name

1 U Output of U phase

10

11

12

13

14

15

7

8

9

2

3

4

5

6

20

21

22

23

24

16

17

18

19

Function

VB1

VB2

VB3

High side bootstrap terminal (U phase)

High side bootstrap terminal (V phase)

High side bootstrap terminal (W phase)

VCC1 High side logic supply voltage

COM1 High side logic GND terminal

HIN3

HIN2

HIN1

VBB1

VBB2

W1

V

W2

LS3

High side input terminal (W phase)

High side input terminal (V phase)

High side input terminal (U phase)

Main supply voltage 1 (connect to VBB2 externally)

Main supply voltage 2 (connect to VBB1 externally)

Output of W phase (connect to W2 externally)

Output of V phase

Output of W phase (connect to W1 externally)

Low side emitter terminal (W phase)

VREG

LS2

LIN3

LIN2

Internal regulator output terminal

Low side emitter terminal (V phase)

Low side input terminal (W phase)

Low side input terminal (V phase)

LIN1 Low side input terminal (U phase)

COM2 Low side GND terminal

FO

VCC2

LS1

Overtemperature detection fault-signal output terminal

Low side logic supply voltage

Low side source terminal (U phase)

6

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

SLA6845MZ

High Voltage 3-Phase Motor Driver

Package Outline Drawing

Leadform 2171

Dual rows, 24 alternating pins; vertical case mounting; pin #1 on pad side

Exposed heatsink pad

31.3 ±0.2

31 ±0.2

24.4 ±0.2

16.4 ±0.2

Gate protrusion

0.6

1.7 ±0.1

4.8 ±0.2

Ø3.2 ±0.15

2X Gate protrusion

Branding Area

View A

Ø3.2 ±0.15

9.9 ±0.2

12.9 ±0.2

16 ±0.2

B

2.45 ±0.2

BSC

2X Exposed tie bar

0.6

+0.15

– 0.05

2 4 6 8 10 12 14 16 18 20 22 24

1.27 ±0.7

A

9.5

+0.7

– 0.5

5 ±0.5

R1

REF

0.5

+0.15

– 0.05

4.5

REF

4.5 ±0.7

Heatsink exposed this side

1 3 5 7 9 11 13 15 17 19 21 23

0.7 MAX

0.7 MAX

Deflection at pin bend

View A

A

B

Measured at pin tips

To case top

Leadform: 2171

Terminal core material: Cu

Terminal plating: Ni

Recommended attachment: Solder dip (Sn-Ag-Cu)

Dimensions in millimeters

Branding codes (exact appearance at manufacturer discretion):

1st line, type: SLA6845M

2nd line, lot:

YMDD

Z

Where: Y is the last digit of the year of manufacture

M is the month (

1

to

9, O, N, D

)

DD is the date

Z represents the version, SLA6845MZ

Leadframe plating Pb-free. Device composition complies with the RoHS directive.

Appearance: The body shall be clean and shall not bear any stain, rust or flaw.

Marking: The type number and lot number shall be clearly marked.

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

7

SLA6845MZ

High Voltage 3-Phase Motor Driver

Package Outline Drawing

Leadform 2175

Dual rows, 24 alternating pins; pins bent 90° for horizontal case mounting; pin #1 in outer row

Ø3.2 ±0.15

2X Gate protrusion

Branding Area

View A

Exposed heatsink pad

31.3 ±0.1

31 ±0.2

24.4 ±0.2

16.4 ±0.2

Gate protrusion

0.6

1.7 ±0.1

4.8 ±0.2

Ø3.2 ±0.15

9.9 ±0.1

12.9 ±0.2

16 ±0.2

B

3 ±0.3

BSC

2.45 ±0.1

BSC

2.2 ±0.6

BSC

R1

REF

4.4

REF

1.27 ±0.2

A

2.2 ±0.6

BSC

0.5 ±0.1

2X Exposed tie bar

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

0.7 MAX

0.7 MAX

Deflection at pin bend

View A

A Measured at pin exit from case

B

To case top

Leadform: 2175

Terminal core material: Cu

Terminal plating: Ni

Recommended attachment: Solder dip (Sn-Ag-Cu)

Dimensions in millimeters

Branding codes (exact appearance at manufacturer discretion):

1st line, type: SLA6845M

2nd line, lot:

YMDD

Z

Where: Y is the last digit of the year of manufacture

M is the month (

1

to

9, O, N, D

)

DD is the date

Z represents the version, SLA6845MZ

Leadframe plating Pb-free. Device composition complies with the RoHS directive.

Appearance: The body shall be clean and shall not bear any stain, rust or flaw.

Marking: The type number and lot number shall be clearly marked.

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

8

SLA6845MZ

High Voltage 3-Phase Motor Driver

Package Outline Drawing

Leadform 2178

Dual rows, 24 alternating pins; vertical case mounting; pin #1 on pad side

Exposed heatsink pad

31.3 ±0.2

31 ±0.2

24.4 ±0.2

16.4 ±0.2

Gate protrusion

0.6

1.7 ±0.1

4.8 ±0.2

Ø3.2 ±0.15

2X Gate protrusion

Branding Area

View A

Ø3.2 ±0.15 x3.8

9.9 ±0.2

12.9 ±0.2

16 ±0.2

B

2.45 ±0.2

2X Exposed tie bar

0.6

+0.15

– 0.05

2 4 6 8 10 12 14 16 18 20 22 24

1.27 ±0.7

A

8 ±0.5

5 ±0.5

R1

REF

0.5

+0.15

– 0.05

3 REF

4.5 ±0.7

Heatsink exposed this side

1 3 5 7 9 11 13 15 17 19 21 23

A

B

Measured at pin tips

To case top

Leadform: 2178

Terminal core material: Cu

Terminal plating: Ni

Recommended attachment: Solder dip (Sn-Ag-Cu)

Dimensions in millimeters

Branding codes (exact appearance at manufacturer discretion):

1st line, type: SLA6845M

2nd line, lot:

YMDD

Z

Where: Y is the last digit of the year of manufacture

M is the month (

1

to

9, O, N, D

)

DD is the date

Z represents the version, SLA6845MZ

Leadframe plating Pb-free. Device composition complies with the RoHS directive.

Appearance: The body shall be clean and shall not bear any stain, rust or flaw.

Marking: The type number and lot number shall be clearly marked.

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

9

SLA6845MZ

High Voltage 3-Phase Motor Driver

Packing Specification

Leadform 2171

Dimensions in millimeters

31.2

13.8

X

580

Tube material: PVC

Maximum 18 pieces per tube

(pins aligned along X direction)

Rubber plug each end

137

621

186

Y

Z

Maximum 12 tubes in Y direction

Maximum 3 tubes in Z direction

Maximum pieces per carton:

18 pieces per tube

12 tubes per layer x 3 layers of tubes

648 pieces per carton

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

10

SLA6845MZ

High Voltage 3-Phase Motor Driver

Packing Specification

Leadform 2175

Dimensions in millimeters

31.0

15.8

X

580

Tube material: PVC

Maximum 18 pieces per tube

(pins aligned along X direction)

Rubber plug each end

130

610

185

Y

Z

Maximum 10 tubes in Y direction

Maximum 3 layers in Z direction

Maximum pieces per carton:

18 pieces per tube

10 tubes per layer x 3 layers of tubes

540 pieces per carton

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

11

SLA6845MZ

High Voltage 3-Phase Motor Driver

Packing Specification

Leadform 2178

Dimensions in millimeters

31.2

13.8

X

580

Tube material: PVC

Maximum 18 pieces per tube

(pins aligned along X direction)

Rubber plug each end

137

621

186

Y

Z

Maximum 12 tubes in Y direction

Maximum 3 tubes in Z direction

Maximum pieces per carton:

18 pieces per tube

12 tubes per layer x 3 layers of tubes

648 pieces per carton

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

12

SLA6845MZ

High Voltage 3-Phase Motor Driver

WARNING

— These devices are designed to be operated at lethal voltages and energy levels. Circuit designs that embody these components must conform with applicable safety requirements. Pre cau tions must be taken to prevent accidental contact with power-line potentials. Do not connect ground ed test equipment.

The use of an isolation transformer is recommended during circuit development and breadboarding.

Because reliability can be affected adversely by improper storage environments and handling methods, please observe the following cautions.

Cautions for Storage

• Ensure that storage conditions comply with the standard temperature (5°C to 35°C) and the standard relative humidity

(around 40 to 75%); avoid storage locations that experience extreme changes in temperature or humidity.

• Avoid locations where dust or harmful gases are present and avoid direct sunlight.

• Reinspect for rust on leads and solderability of products that have been stored for a long time.

Cautions for Testing and Handling

When tests are carried out during inspection testing and other standard test periods, protect the products from power surges from the testing device, shorts between adjacent products, and shorts to the heatsink.

Remarks About Using Silicone Grease with a Heatsink

When silicone grease is used in mounting this product on a heatsink, it shall be applied evenly and thinly. If more silicone grease than required is applied, it may produce stress.

Volatile-type silicone greases may permeate the product and produce cracks after long periods of time, resulting in reduced heat radiation effect, and possibly shortening the lifetime of the product.

Our recommended silicone greases for heat radiation purposes, which will not cause any adverse effect on the product life, are indicated below:

Type

G746

YG6260

SC102

Suppliers

Shin-Etsu Chemical Co., Ltd.

Momentive Performance Materials, Inc.

Dow Corning Toray Silicone Co., Ltd.

Heatsink Mounting Method

Torque When Tightening Mounting Screws. The recommended tightening torque for this product package type is: 58.8 to 78.4 N•cm (6.0 to

8.0 kgf•cm).

Soldering

• When soldering the products, please be sure to minimize the working time, within the following limits:

260±5°C 10 s

380±5°C 5 s

Soldering iron should be at a distance of at least 1.5 mm from the body of the products

Electrostatic Discharge

• When handling the products, operator must be grounded.

Grounded wrist straps worn should have at least 1 M

Ω of resistance to ground to prevent shock hazard.

• Workbenches where the products are handled should be grounded and be provided with conductive table and floor mats.

• When using measuring equipment such as a curve tracer, the equipment should be grounded.

• When soldering the products, the head of soldering irons or the solder bath must be grounded in other to prevent leak voltages generated by them from being applied to the products.

• The products should always be stored and transported in our shipping containers or conductive containers, or be wrapped in aluminum foil.

13

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

SLA6845MZ

High Voltage 3-Phase Motor Driver

The products described herein are manufactured in Ja pan by Sanken Electric Co., Ltd. for sale by Allegro MicroSystems, Inc.

Sanken and Allegro reserve the right to make, from time to time, such de par tures from the detail spec i fi ca tions as may be re quired to per mit im-

prove ments in the per for mance, reliability, or manufacturability of its prod ucts. Therefore, the user is cau tioned to verify that the in for ma tion in this publication is current before placing any order.

When using the products described herein, the ap pli ca bil i ty and suit abil i ty of such products for the intended purpose shall be reviewed at the users responsibility.

Although Sanken undertakes to enhance the quality and reliability of its prod ucts, the occurrence of failure and defect of semi con duc tor products at a certain rate is in ev i ta ble.

Users of Sanken products are requested to take, at their own risk, preventative measures including safety design of the equipment or systems against any possible injury, death, fires or damages to society due to device failure or malfunction.

Sanken products listed in this publication are designed and intended for use as components in general-purpose electronic equip ment or apparatus

(home ap pli anc es, office equipment, tele com mu ni ca tion equipment, measuring equipment, etc.). Their use in any application requiring radiation hardness assurance (e.g., aero space equipment) is not supported.

When considering the use of Sanken products in ap pli ca tions where higher reliability is re quired (transportation equipment and its control systems or equip ment, fire- or burglar-alarm systems, various safety devices, etc.), contact a company sales representative to discuss and obtain written confirmation of your spec i fi ca tions.

The use of Sanken products without the written consent of Sanken in applications where ex treme ly high reliability is required (aerospace equipment, nuclear power-control stations, life-support systems, etc.) is strictly prohibited.

The information in clud ed herein is believed to be accurate and reliable. Ap pli ca tion and operation examples described in this pub li ca tion are given for reference only and Sanken and Allegro assume no re spon si bil i ty for any in fringe ment of in dus tri al property rights, intellectual property rights, or any other rights of Sanken or Allegro or any third party that may result from its use.

The contents in this document must not be transcribed or copied without Sanken’s written consent.

Copyright © 2011 Allegro MicroSystems, Inc.

14

Allegro MicroSystems, Inc.

115 Northeast Cutoff, Box 15036

Worcester, Massachusetts 01615-0036 (508) 853-5000 www.allegromicro.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
