Canon | DV-PC | Instruction manual | Canon DV-PC Instruction manual

PUB. DIM-462
DIGITAL VIDEO CAMCORDER
ENGLISH
Instruction Manual
E
CAMESCOPE ET LECTEUR VIDEO NUMERIQUES
FRANÇAIS
Mode d’emploi
F
VIDEOCAMARA Y GRABADORA DIGITAL
ESPAÑOL
Es
Manual de Instrucciones
Mini
PUB. DIM-462
NTSC
Digital
Video
Cassette
Important Usage Instructions
WARNING:
E
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK AND TO REDUCE ANNOYING
INTERFERENCE, USE THE RECOMMENDED ACCESSORIES ONLY.
COPYRIGHT WARNING:
Unauthorized recording of copyrighted materials may infringe on the rights of copyright
owners and be contrary to copyright laws.
Digital Video Camcorder, GL2 systems
Introduction
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and use in accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise specified in the manual.
If such changes or modifications should be made, you could be required to stop operation of the equipment.
Canon U.S.A. Inc.
One Canon Plaza, Lake Success, NY 11042, U.S.A.
Tel No. (516)328-5600
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Important Warning
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
2
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to
the presence of uninsulated “dangerous voltage”
within the product’s enclosure, that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point, within an equilateral triangle,
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
product.
IMPORTANT SAFETY INSTRUCTIONS
In these safety instructions the word “product”
refers to the Canon Digital Video Camcorder GL2
and all its accessories.
1. Read Instructions — All the safety and
operating instructions should be read before the
product is operated.
2. Retain Instructions — The safety and operating
instructions should be retained for future
reference.
3. Heed Warnings — All warnings on the product
and in the operating instructions should be
adhered to.
5. Cleaning — Unplug this product from the wall
outlet before cleaning. Do not use liquid or
aerosol cleaners. The product should be
cleaned only as recommended in this manual.
6. Accessories — Do not use accessories not
recommended in this manual as they may be
hazardous.
7. Avoid magnetic or electric fields — Do not use
the camera close to TV transmitters, portable
communication devices or other sources of
electric or magnetic radiation. They may cause
picture interference, or permanently damage the
camera.
12. Power Cord Protection — Power cords should
be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them. Pay particular attention to plugs
and the point from which the cords exit the
product.
13. Outdoor Antenna Grounding — If an outside
antenna is connected to the product, be sure
the antenna is grounded so as to provide some
protection against voltage surges and built-up
static charges. Section 810 of the National
Electrical Code, ANSI / NFPA No. 70—1984,
provides information with respect to proper
grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors,
location of antenna discharge unit, connection
to grounding electrodes, and requirements for
the grounding electrode. See figure 1.
E
Introduction
4. Follow Instructions — All operating and
maintenance instructions should be followed.
11. Polarization — The CA-920 Compact Power
Adapter is equipped with a polarized 2-prong
plug (a plug having one blade wider than the
other).
The 2-prong polarized plug will fit into the power
outlet only one way. This is a safety feature. If
you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug still fails
to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
EXAMPLE OF ANTENNA GROUNDING AS
PER NATIONAL ELECTRICAL CODE
Fig. 1
8. Water and Moisture — Hazard of electric shock
— Do not use this product near water or in
rainy/moist situations.
ANTENNA
LEAD IN
WIRE
GROUND
CLAMP
9. Placing or Moving — Do not place
on an unstable cart, stand, tripod,
bracket or table. The product may
fall, causing serious injury to a
child or adult, and serious damage
to the product.
A product and cart combination should be
moved with care. Quick stops, excessive force,
and uneven surfaces may cause the product
and cart combination to overturn.
10. Power Sources — The CA-920 Compact Power
Adapter should be operated only from the type
of power source indicated on the marking label.
If you are not sure of the type of power supply
to your home, consult your product dealer or
local power company. Regarding other power
sources such as battery power, refer to
instructions in this manual.
ANTENNA
DISCHARGE
UNIT
(NEC SECTION
810-20)
ELECTRIC
SERVICE
EQUIPMENT
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
NEC - NATIONAL ELECTRICAL CODE
POWER SERVICE
GROUNDING ELECTRODE
SYSTEM
(NEC ART 250. PART H)
14. Lightning — For added protection of this
product during a lightning storm, or when it is
left unattended and unused for long periods of
time, disconnect it from the wall outlet and
disconnect the antenna. This will prevent
damage to the product due to lightning and
power-line surges.
3
15. Overloading — Do not overload wall outlets and
extension cords as this can result in a risk of
fire or electric shock.
E
16. Objects and Liquid Entry — Never push objects
of any kind into this product through openings
as they may touch dangerous voltage points or
short out parts that could result in a fire or
electric shock. Be careful not to spill liquid of
any kind onto the product.
Introduction
17. Servicing — Do not attempt to service this
product yourself as opening or removing covers
may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service
personnel.
18. Damage Requiring Service — Disconnect this
product from the wall outlet and all power
sources including battery, and refer servicing to
qualified service personnel under the following
conditions:
a. When the power-supply cord or plug is
damaged.
b. If any liquid has been spilled onto, or objects
have fallen into, the product.
c. If the product has been exposed to rain or
water.
d. If the product does not operate normally even
if you follow the operating instructions. Adjust
only those controls that are covered by the
operation instructions. Improper adjustment of
other controls may result in damage and will
often require extensive work by a qualified
technician to restore the product to its normal
operation.
e. If the product has been dropped or the
cabinet has been damaged.
f. When the product exhibits a distinct change
in performance. This indicates a need for
service.
19. Replacement Parts — When replacement parts
are required, be sure the service technician has
used replacement parts that are specified by
Canon or that have the same characteristics as
the original part. Unauthorized substitutions
may result in fire, electric shock or other
hazards.
20. Safety Check — Upon completion of any
service or repairs to this product, ask the
service technician to perform safety checks to
determine that the product is in safe operating
order.
4
Operating Steps and Reference Guide
Your camcorder is supplied with two manuals: the “Digital Video Camcorder GL2 Instruction
Manual” and the “Digital Video Solution Disk Instruction Manual”.
E
Digital Video Camcorder GL2 Instruction Manual
Preparations
Recording
Playback
Using the Memory Card
Introduction
Editing
Digital Video Solution Disk Instruction Manual
Installing the Software
Connecting the Camcorder to a Computer
Downloading the Still Image to a Computer
5
Contents
Introduction
E
Important Usage Instructions ........................
Important Safety Instructions ........................
Operating Steps and Reference Guide ..........
Thank You For Choosing a Canon ................
Introducing the GL2 ......................................
2
3
5
8
9
Introduction
Preparations
Finding Your Way Around the GL2..............
Preparing the Camcorder ............................
Powering the Camcorder ............................
Loading a Cassette......................................
Using the Menus ........................................
Using the Wireless Controller/Tally Lamp ....
Setting the Date and Time ..........................
Recording
Basic Recording ..........................................
Tips for Making Better Videos ....................
Zooming ....................................................
Using the LCD Screen ................................
Turning the Optical Image Stabilizer Off ......
Using the ND Filter......................................
Recording Still Images onto a Tape..............
Selecting the Movie Mode (Normal/Frame)..
Searching and Reviewing While Recording ..
Using the Various Recording Programs ........
Audio Recording ........................................
Using the Custom Key ................................
Using Digital Effects ....................................
Using the Color Bars ..................................
Using a Canon Speedlite for Flash
Photography (Optional) ..............................
Recording with the Interval Timer ..............
Recording with the Self-Timer ....................
Using the DV Control..................................
Using the VL-3 Video Light (Optional) ........
Using the DM-50 Microphone (Optional) ....
Using the MA-300 Microphone Adapter
(Optional) ..................................................
6
10
14
16
18
20
29
32
35
40
42
43
46
47
48
50
51
52
56
58
62
67
68
69
71
72
73
74
75
Manual Adjustments
Adjusting the Exposure Manually ................ 76
Adjusting the Focus Manually .................... 79
Setting the White Balance .......................... 80
Using the AE Shift ...................................... 82
Using the Custom Preset ............................ 83
Using the Zebra Pattern .............................. 85
Recording PC Screens and Other Screens
Using CLEAR SCAN.................................... 86
Recording the Viewfinder Information..........86
Playback
Playing Back a Tape .................................... 87
Displaying Date, Time and Camcorder
Data (Data Code) ...................................... 90
Searching the Tape (Photo Search/Date
Search/Index Search) .................................. 93
Returning to a Pre-Marked Position
(Zero Set Memory) .................................... 94
Connections for Playback on a TV Screen.... 95
Editing
Editing to a VCR ........................................ 97
Dubbing to/from a Tape with Digital
Video Equipment ...................................... 99
Recording from a VCR, TV or Analog
Camcorder (Analog Line-in) .................... 101
Digitally Outputting Analog Video and
Audio Signals (Analog-Digital Converter).. 103
Recording Over Existing Scenes
(AV Insert Editing) .................................... 105
Audio Dubbing ........................................ 108
Setting the Audio Mix .............................. 111
Connecting to a PC Using a DV Cable ...... 113
Using a Memory Card
Memory Card Introduction........................ 114
Recording Still Images
onto a Memory Card .............................. 118
Playing Back a Memory Card .................... 120
Settings of the Still Images Recorded
on a Memory Card ..................................
Preventing Accidental Erasure (Protect)......
Marking a Still Image for Printing
(Print Mark)..............................................
Erasing Still Images ..................................
Combining Images and Recording Them
onto a Tape (Title Mix) ............................
Copying Still Images from Memory Card
to Tape ....................................................
Formatting a Memory Card ......................
Connecting to a PC Using a USB Cable ....
Other Information and Precautions ..........
E
122
124
125
127
129
132
133
134
135
Introduction
Additional Information
Notes on Using the Batteries ....................
Maintenance ............................................
Troubleshooting ........................................
The GL2 System Diagram ..........................
Optional Accessories ................................
Screen Displays ........................................
Caution Phrases ........................................
Specifications ............................................
Index ........................................................
Menu at a Glance ....................................
136
139
143
147
148
150
153
155
157
159
The serial number of this product may be found on the
bottom of the camera. No others have the same serial
number as yours. You should record the number and
other vital information here and retain this book as a
permanent record of your purchase to aid identification
in case of theft.
Date of Purchase
Dealer Purchased From
Dealer Address
Dealer Phone No.
Model Name GL2A
Serial No.
7
Thank You For Choosing a Canon
First, we’d like to thank you for purchasing this
Canon camcorder. Its advanced technology
makes it very easy to use — you will soon be
making high-quality videos which will give you
pleasure for years to come.
E
To get the most out of your new camcorder, we
recommend that you read this manual
thoroughly — there are many sophisticated
features which will add to your recording
enjoyment.
Your camcorder is supplied with the following
accessories:
Lens
Hood
WL-D74
Wireless
Large
Eye
Cup
Two AA
batteries
Controller
Lithium Button Battery WL-D77 Wireless
CR2025
SS-600 Shoulder Strap Controller
Lens cap and lens cap
cord
Introduction
Symbols Used in This Manual
: Reference page numbers
: Functions that can be operated from the
body of the camcorder
: Functions that can be operated from the
wireless controller
: Supplementary notes for camcorder
operation
` : Operation confirmation beeps ( 39)
Capital letters are used to refer to settings
displayed in the menus and buttons labeled on
the camcorder itself (e.g. Press the MENU
button).
Two AAA Batteries
BP-511 Battery Pack
S-150 S-video Cable
Lithium button battery
SS-650 Shoulder
Strap
STV-250N Stereo Video
Cable
CA-560 Compact Power
Adapter (including AC
power cable)
IFC-300PCU USB
Cable*
S-150 S-video Cable
CA-920 Compact
Power Adapter
(incl. AC Power Cord)
STV-250 Stereo Video
Cable
DC-920 DC Coupler
BP-915 Battery Pack
SDC-8M SD Memory
Card
Soft Case for SD Memory
Card
Software CD-ROM
Digital Video Solution
Disk*
* Required for transferring still images from a
memory card to your computer. Please refer
to the Software Instruction Manual for further
details.
8
Introducing the GL2
3CCD System with Pixel Shift
Technology
The Canon GL2 has three CCDs, delivering
outstanding picture quality, highly accurate
color reproduction and a wide dynamic range
with virtually no color noise. On top of that,
Canon uses a broadcast technology called Pixel
Shift to produce greater picture quality than
that of camcorders using CCDs with almost
twice the number of pixels.
L-Series Fluorite 20× Optical
Zoom Lens
Memory Card
You can record still images onto a SD Memory
Card or MultiMediaCard. The memory card
enables easy transfer of still images to a PC.
Use the supplied software to edit or attach still
images to your e-mail.
Image Stabilizer
Canon’s optical technology stabilizes your
recordings even in long telephoto shots.
E
The DV terminal allows highquality transfer with virtually no
deterioration in quality of images.
You can edit and process images
by connecting the camcorder to a
PC with the IEEE 1394 terminal.
Analog Line-in Recording
Connect a VCR or analog camcorder and record
onto a DV cassette in the GL2.
Audio Dubbing/AV insert
Digital Effects
Show your creativity by using the special effects
and digital faders. These digital effects and
faders can add visual appeal and greater
imaging variety.
Introduction
The GL2 incorporates a 20× Professional
L-Series Fluorite optical zoom lens. Fluorite
provides outstanding resolution, contrast and
color reproduction and delivers the ultimate in
clarity and image quality.
IEEE 1394 DV Terminal
Recording Programs
The GL2 has 7 recording programs: Easy
Recording, Auto, Tv, Av, Manual, Sand & Snow
and Spotlight.
Custom Keys
You can assign various functions to the custom
key, independent for each operating mode.
Custom Preset
You can adjust color gain, color phase,
sharpness and setup level and save the
combination to the custom preset button.
USB Terminal
Allows high-speed transfer of memory card
data to a PC with a built-in USB port. You can
organize and edit still images on your PC using
the supplied software.
Interval Recording
Interval recording allows for the capture of time
elapsed motion videography. The GL2 can be
programmed to record at various intervals for
varying amounts of time.
9
Finding Your Way Around the GL2
E
(play/pause) button (p. 87)/
Title Mix button (p. 130)/
SLIDE SHOW button (p. 121)
(rewind) button (p. 87)/
CARD – button (p. 120)
(stop) button (p. 87)/
INDEX SCREEN button
(p. 121)
PHOTO button (p. 48, 118)
(fast forward) button (p. 87)/
CARD + button (p. 120)
REC PAUSE button (p. 100,102)
AUDIO DUB. button (p. 108)
AV INSERT button (p. 105)
Preparations
START/STOP button (p. 35)
Zoom controller
(p. 42)
Speaker (p. 89)
Backup battery cover (p. 138)
BATT. (battery)
RELEASE button (p. 16)
Viewfinder (p. 14)
LCD screen
(p. 43)
AUDIO LEVEL dials (p. 57)
LCD panel OPEN button
(p. 43)
MENU button (p. 21)
CUSTOM KEY (p. 58)
CUSTOM PRESET button
(p. 83)
Memory Card
Compartment Cover
10
AUDIO REC LEVEL switch
(p. 57)
SELECT dial (p. 21)
Program selector (p. 52)
DISPLAY button (p. 38)/
DATA CODE button (p. 90)
E
Carrying handle
Zoom controller (p. 42)
PHOTO button (p. 48, 118)
Strap mount (p. 15)
Lock lever (p. 35)
Eyepiece adapter
(p. 14)
Stereo microphone
(p. 56)
TAPE/CARD switch
(p. 20, 35)
Start/stop button (p. 35)
Lens hood locking screw
(p. 14)
Preparations
Lens hood (p. 14)
Viewfinder focusing
lever (p. 14)
DC terminal
MIC terminal
(p. 57, 108)
u (LANC) terminal
(p. 98)
USB terminal
(p. 134)
(phones) terminal
(p. 89)
DV IN/OUT terminal
(p. 99, 103, 105, 113)
AV (audio/video)
IN/OUT terminal
(p. 95, 97, 101, 103)
S-video IN/OUT
terminal
(p. 95, 101, 103)
Standby lever (p. 36)
Cassette compartment
(p. 18)
Cassette compartment
cover (p. 18)
OPEN/EJECT switch
(p. 18)
Grip belt (p. 15)
11
E
ND FILTER ON/OFF button (p. 47)
FOCUS A/M button (p. 79)
Focus ring (p. 79)
Preparations
Advanced accessory shoe
(p. 68, 73-75)
POWER switch (p. 35)
REC (record) SEARCH
button(p. 51)/
Record review
button (p. 51)
Tally lamp (p. 31)
Remote sensor (p. 29)
Strap mount (p. 15)
Audio level indicator
(p. 57)
WHITE BALANCE
W (set) button (p. 80)
WHITE BALANCE
SELECT button (p. 80)
D.EFFECTS ON/OFF
button (p. 63)
D.EFFECTS SELECT
button (p. 63)
EXP (exposure) dial (p. 76)
12
Tripod socket (p. 40)
E
D.EFFECTS SELECT button (p. 63)
Transmitter
PHOTO button (p. 48, 118)
MENU button (p. 21)
Zoom buttons (p. 30, 42)
START/STOP button (p. 35)
START
/STOP PHOTO
SELF TIMER button (p. 71)
ZOOM
W
SET button (p. 21)
SELF
TIMER MENU
TV SCREEN button (p. 150)
DATA
CODE
SET
D.EFFECTS
ON/OFF
MIX
BALANCE
AUDIO
MONITOR ST-1
AUDIO MONITOR button (p. 111)
REC
PAUSE
– CARD +
ST-2
SLIDESHOW
REC PAUSE button (p. 100, 102)
ZERO SET SEARCH
MEMORY SELECT
CARD
buttons (p. 120)
ZERO SET MEMORY button (p. 94)
MIX BALANCE buttons (p. 111)
SLIDE SHOW button (p. 121)
Search buttons (p. 93)
AUDIO
DUB.
REW
PLAY
FF
AV
INSERT
–/
STOP
+/
FF
REMOTE SET PAUSE
AUDIO DUB. button (p. 108)
D.EFFECTS ON/OFF button
(p. 63)
Preparations
TV
SCREEN
DATA CODE button (p. 90)
Controller buttons (p. 21)
T
SLOW
×2
PLAY
button (p. 87)
button (p. 87)
button (p. 88)
SET
WIRELESS CONTROLLER WL-D77
AV INSERT button (p. 105)
× 2 button (p. 88)
REMOTE SET button (p. 30)
STOP
SEARCH SELECT button (p. 93)
SLOW
REW
PAUSE
button (p. 87)
button (p. 87)
button (p. 88)
button (p. 88)
button (p. 88)
13
Preparing the Camcorder
Attaching the Lens Hood
E
1. Remove the lens cap.
Preparations
• When you purchase the GL2, the lens cap cord is attached to the middle of the Velcro grip
belt. Open the Velcro and slide the lens cap cord to the position as shown in the illustration.
2. Align the hood to the lens with the Canon logo facing to the left.
3. Twist it into position (clockwise), so that the Canon logo is to the top.
• You do not need to assert any pressure — screw the hood lightly into place.
4. Finally, tighten the locking screw.
• To remove, reverse the above procedure.
Since the lens hood cuts stray light that may cause flare and ghost images and protects the lens, be
sure to attach the hood when you are recording.
Adjusting the Viewfinder
• In record pause mode, adjust the viewfinder
focusing lever to suit your eyesight.
• The viewfinder extends straight out and rotates
upwards for comfortable viewing. Store the
camcorder with the viewfinder flush with the
body of the camcorder.
• To view with the viewfinder, make sure the
LCD panel is either turned so that the subject
can monitor the screen, or totally closed with
the screen facing inwards.
• Be careful not to leave the viewfinder exposed
to bright sunlight as it may melt. (The light is
concentrated by the viewfinder lens.)
14
Adjusting the Grip Belt
E
• Adjust the length of the grip belt strap so that
you can operate the start/stop button and
zoom control effectively.
Attaching the Shoulder Strap
Preparations
• For extra security and portability, attach the
shoulder strap before using the camcorder.
• Pass the ends through the strap mount and
adjust the length as shown.
• Be careful not to leave the viewfinder
exposed to bright sunlight as it may melt.
(The light is concentrated by the viewfinder
lens.)
Attaching the Large Eye Cup
Use the supplied Large Eye Cup when
recording in very bright surroundings or when
wearing glasses.
1. Detach the eye cup from the
camcorder.
2. Replace the eye cup with the Large
Eye Cup.
• You can attach it to the right or the left.
15
Powering the Camcorder
Before operating your camcorder, you will need to use the power adapter to:
E
provide power from a household power socket
or
charge a battery pack
Notes:
• The power adapter converts current from a household power socket (100–240 V AC, 50/60 Hz)
to the DC current used by your camcorder.
• If the adapter is used next to a TV, it may cause the TV to emit noise — move the adapter away
from the TV or the antenna cable.
Preparations
Using a Household Power Source
4
5
3
2
1
Use the power adapter and the DC coupler to provide your camcorder with instant power from an
household power socket.
1. Connect the power cord to the power adapter.
2. Plug the adapter into a household power socket.
3. Connect the DC coupler to the power adapter.
4. Attach the DC coupler to the camcorder.
• Extend the viewfinder and rotate it upwards.
• Align the edge of the DC coupler with the line on the camcorder.
• Slide the coupler down in the direction of the arrow until it clicks into place.
5 After use, turn the camcorder off, detach the DC coupler and disconnect the DC
coupler from the power adapter. Unplug the power cord and disconnect it from
the power adapter.
• Press and hold the BATT. RELEASE button, while you slide the coupler up.
• Always turn the camcorder off and raise the viewfinder before removing the power source.
16
Charging and Attaching the Battery Pack
E
1
2
3
4
5
Your battery pack was partially charged before it left the factory. It should have enough power for
you to check that your camcorder is working properly. However, you must charge the battery pack
fully if you want it to power the camcorder for more than a few minutes.
• Make sure the DC coupler is not connected.
• Align the triangle on the battery pack with the line on the power adapter.
• Slide the battery across until it clicks into place.
2. Connect the power cord to the power adapter.
Preparations
1. Attach the battery pack to the power adapter.
3. Plug the power adapter into a household power socket.
• The charge indicator flashes red to show that charging is in progress. Single flashes mean that
the battery pack is less than 50% charged. Double flashes mean that it is between 50% and
75% charged. Triple flashes mean that it is more than 75% charged.
• The indicator glows steadily when the battery pack is fully charged.
4. Take the battery pack off the adapter and attach it to the camcorder.
• Extend the viewfinder and rotate it upwards.
• Align the triangle on the battery pack with the line on the camcorder, then slide the battery in
the direction of the arrow until it clicks into place.
5. Remove the battery pack after use.
• Press and hold the BATT. RELEASE button, while you slide the battery up.
• Always turn the camcorder off and raise the viewfinder before removing the power source.
Notes:
• You can find detailed notes for using the batteries in “Notes on Using the Batteries” ( 136).
These notes include charging and recording times and how to charge the backup battery.
• Using the optional CH-910 Dual Battery Charger/Holder you can power the camcorder from two
battery packs for longer continuous recording. You can exchange the battery packs independently
without cutting the power to the camcorder. In addition, the CH-910 can charge two batteries
consecutively when it is connected to a household power socket.
17
Loading a Cassette
Use only videocassettes marked with the DV logo.*
E
.
RST
IS FI
SE TH
CLO
* D logo is a trademark.
Loading and Unloading
1. Attach a power source.
Preparations
2. Slide the OPEN/EJECT button and release the cassette compartment cover.
• Wait for the cassette compartment to open automatically.
• The confirmation beep sounds when it is fully opened.
3. Load or unload the cassette.
• Insert the cassette gently with the window facing outward.
• Remove the cassette by pulling it straight out.
4. Press the P mark on the compartment until it clicks.
5. Click the cover back into place.
Notes:
• Do not interfere with the cassette compartment while it is opening or closing, or attempt to close
the cover.
• Be careful not to get your fingers caught in the cassette compartment cover.
• Do not leave the cassette in the camcorder after use — return it to its case and store it in a cool,
clean, dry place.
• When no cassette is loaded, v flashes in the display.
• With some types of tapes, the remaining tape display may not give an accurate reading.
18
Protecting Tapes from Accidental Erasure
E
REC
SAVE
REC
SAVE
Cassette Handling Precautions
Preparations
To protect your recording from accidental erasure, slide the tab on the cassette so that it exposes
the hole. (This switch position is usually labeled SAVE or ERASE OFF.)
If you load this cassette and put the camcorder in record pause mode ( 35), “THE TAPE IS SET
FOR ERASURE PREVENTION” is displayed for approx. 4 seconds and then the v mark flashes in the
display. The camcorder also shows the above phrase if you accidentally press the 2 (record) button
with the camcorder switched to TAPE PLAY (VCR) mode.
If you wish to record on the cassette again, slide the tab back so that the hole is closed.
• To protect the tape heads, transfer cassettes directly from the tape case to the camcorder — do
not open the tape protect cover or touch the tape itself.
• Do not use cassettes where the tape has been damaged or spliced — they may damage the
camcorder.
• Do not insert anything into the small holes on the cassette or cover them with cellophane tape.
• Handle cassettes with care — dropping them or exposing them to external shocks may cause
internal damage.
• Store cassettes in the provided case, rewinding them to the start of the tape first, and then
storing them upright.
• A cassette with metal plated terminals may become dirty with use, affecting information transfer.
Therefore, after using a tape around ten times, be sure to clean the terminals with a cotton
swab.
Cassette Memory Function
The cassette memory function cannot be used with this camcorder.
19
Using the Menus
Many of the camcorder’s advanced functions are selected from menus which appear in the display.
E
There are 4 main menus:
CAM. MENU
Camera menu
VCR MENU
VCR menu
C.CAM. MENU Card camera menu
C.PLAY MENU Card play menu
2
CAM. MENU
TAPE
CAM. MENU
+
Preparations
VCR MENU
SEL. SETSET
MENUCLOSE
TAPE
VCR MENU
+
C. CAM. MENU
SEL. SETSET
MENUCLOSE
CARD
+
SEL. SETSET
MENUCLOSE
C. PLAY MENU
CARD OPER.
VCR SET UP
DISP. SET UP
SYSTEM
CUSTOM KEY
RETURN
20
CARD
+
CARD TAPE
CAMERA
CAM. SET UP
CSTM PRESET
CARD SET UP
DISP. SET UP
SYSTEM
CUSTOM KEY
RETURN
2 C. PLAY MENU
CARD TAPE
PLAY
(VCR)
VCR SET UP
DISP. SET UP
SYSTEM
CUSTOM KEY
RETURN
2 C. CAM. MENU
22)
24)
25)
27)
CAMERA
CAM. SET UP
CSTM PRESET
VCR SET UP
DISP. SET UP
SYSTEM
CUSTOM KEY
TITLE MIX
RETURN
2
(
(
(
(
CARD TAPE
PLAY
(VCR)
SEL. SETSET
MENUCLOSE
CARD TAPE
Selecting From the Menus
E
2, 11
MENU
TV
SCREEN
SET
3-10
1. Slide the POWER switch and the TAPE/CARD switch to the desired settings.
2. Press the MENU button to open the menu.
• One of the main menus appears depending on the settings of the POWER switch and
TAPE/CARD switch.
3. Pull the SELECT dial up and down to move the arrow to the desired submenu.
• The submenu appears.
5. Pull the SELECT dial up and down to move the arrow to the desired function.
6. Press the SELECT dial in.
Preparations
4. Press the SELECT dial in .
• The function and its settings appear.
7. Pull the SELECT dial up and down to move the arrow to the desired setting.
8. Press the SELECT dial in.
9. Pull the SELECT dial up or down and move the arrow to bRETURN.
10.Press the SELECT dial in.
• You return to the main menu.
11.Press the MENU button.
• The main menu disappears.
Notes:
• Pressing the MENU button at any time closes the menu.
• Selecting b RETURN takes you back one menu, or closes the main menu.
• Items that are unavailable, due to the tape or card situation or the settings of other menu items,
appear in purple.
• You may often find it convenient to use the wireless controller to move around the menus. Press
its MENU button to open/close the menu and use the arrow keys in place of pulling the SELECT
dial. Push the SET button to select.
• Pressing the start/stop button or the PHOTO button will close the menu and start recording.
• You can display the menus on a connected TV screen by turning TV SCREEN ( 150) on through
the menu or using the wireless controller’s TV SCREEN button. See p. 95 for TV connecting
instructions.
21
List of Menus
E
Turn to the appropriate page for a detailed explanation of each function.
2 CAM. MENU
Set the POWER switch to CAMERA and the TAPE/CARD switch to
There are 7 submenus within the CAM. MENU.
Preparations
1
2
3
4
5
6
7
8
Camera Set Up Submenu
Custom Preset Submenu
VCR Set Up Submenu
Display Set Up Submenu
System Submenu
Custom Key Submenu
Title Mix Submenu
Close Main Menu
TAPE
.
CAM. MENU
1
3
5
7
SEL. SETSET
MENUCLOSE
CAM. SET UP
CSTM PRESET
VCR SET UP
DISP. SET UP
SYSTEM
CUSTOM KEY
TITLE MIX
RETURN
2
4
6
8
1 Camera set up Submenu
q
w
e
r
t
y
u
i
o
!0
!1
!2
!3
Digital Zoom ..........................................
Movie Mode ..........................................
Image Stabilizer .....................................
AE Shift .................................................
16:9 Effect.............................................
Zebra Pattern.........................................
Zebra Pattern Level ................................
Grip Zoom Speed...................................
Handle Zoom Speed ..............................
Clear Scan .............................................
Self-Timer ..............................................
Interval Timer.........................................
Return
42
50
46
82
37
85
85
42
42
86
71
69
SEL. SETSET
MENUCLOSE
••••••
OFF
D. ZOOM
MOVIE MODE••NORMAL
IMAGE S. i••ON
AE SHIFT••••±0
16:9••••••••OFF
ZEBRA•••••••OFF
ZEBRA LEVEL•90
ZOOM GRIP•••VARIABLE
CAM. SET UP
q
e
t
u
SEL. SETSET
MENUCLOSE
ZEBRA•••••••OFF
ZEBRA LEVEL•90
ZOOM GRIP•••VARIABLE
ZOOM HANDLE•MEDIUM
CLEAR SCAN••–––
SELF-TIMER••OFF
INTERVAL
RETURN
w
r
y
i
CAM. SET UP
o
!1
!3
!0
!2
2 Custom Preset Submenu
!4
!5
!6
!7
!8
22
Color Gain .............................................
Color Phase ...........................................
Sharpness ..............................................
Setup Level ............................................
Return
83
83
83
84
CSTM PRESET
!4
!6
!8
SEL. SETSET
MENUCLOSE
+
R
+
+
COLOR GAIN••–
COLOR PHASE•G
SHARPNESS•••–
SETUP LEVEL•–
RETURN
!5
!7
3 VCR Set Up Submenu
E
!9
@0
@1
@2
@3
@4
Recording Mode ....................................
Microphone ...........................................
Microphone Attenuator ................. 57,
Audio Mode ..........................................
Power Save ............................................
Return
37
56
108
56
36
SEL. SETSET
MENUCLOSE
••••
SP
REC MODE
MIC•••••••••NORMAL
MIC ATT•••••OFF
AUDIO MODE••16bit
PWR SAVE••••SHUT OFF
RETURN
VCR SET UP
!9
@1
@3
@0
@2
@4
4 Display Set Up Submenu
LCD Brightness ...................................... 44
Viewfinder Brightness ............................ 44
LCD Mirror Mode .................................. 44
16:9 Guides ........................................... 38
TV Screen ............................................ 150
Audio Level Indicator ............................. 57
Guide Information ................................. 34
Card Access Display ............................. 116
Demonstration Mode............................. 39
Return
SEL. SETSET
MENUCLOSE
+
–
••
LCD BRIGHT
+
EVF BRIGHT••–
LCD MIRROR••ON
16:9 GUIDES•OFF
TV SCREEN•••OFF
AUDIO LEVEL•ON
GUIDE INFO••OFF
CARD ACCESS•ON
DISP. SET UP
@5
@7
@9
#1
SEL. SETSET
MENUCLOSE
LCD MIRROR••ON
16:9 GUIDES•OFF
TV SCREEN•••OFF
AUDIO LEVEL•ON
GUIDE INFO••OFF
CARD ACCESS•ON
DEMO MODE•••ON
RETURN
@6
@8
#0
#2
Preparations
@5
@6
@7
@8
@9
#0
#1
#2
#3
#4
DISP. SET UP
#3
#4
5 System Submenu
#5
#6
#7
#8
#9
$0
$1
$2
Wireless Controller.................................
Tally Lamp..............................................
Beep ......................................................
Character Recording ..............................
DV Control ............................................
Time Zone/Daylight Saving Time ............
Setting Date/Time .................................
Return
30
31
39
86
72
32
34
SEL. SETSET
MENUCLOSE
WL. REMOTE•••
1
TALLY LAMP••ON
BEEP••••••••ON
CHAR. REC••••OFF
DV CONTROL••OFF
T. ZONE/DST••–––
D/TIME SET••–––. ––, ––––
––:––:–– ––
SYSTEM
#5
#7
#9
$1
$2
#6
#8
$0
6 Custom Key Submenu
$3 Custom Key ...........................................
$4 Return
58
SEL. SETSET
MENUCLOSE
CUSTOM KEY••INDEX WRITE
RETURN
CUSTOM KEY
$3
$4
23
7 Title Mix Submenu
E
$5 Selecting a Title ...................................
$6 Creating a Title ....................................
$7 Return
130
129
TITLE MIX
$5
$7
SEL. SETSET
MENUCLOSE
TITLE SELECT
CREATE TITLE
RETURN
$6
2 VCR MENU
Preparations
PLAY
Set the POWER switch to (VCR)
and the TAPE/CARD switch to
There are 4 submenus within the VCR MENU.
1
2
3
4
5
VCR Set Up Submenu
Display Set Up Submenu
System Submenu
Custom Key Submenu
Close Main Menu
TAPE
.
VCR MENU
1
3
5
SEL. SETSET
MENUCLOSE
VCR SET UP
DISP. SET UP
SYSTEM
CUSTOM KEY
RETURN
2
4
1 VCR Set Up Submenu
q
w
e
r
t
y
u
i
o
Recording Mode ....................................
Output Channel...................................
Audio Dubbing ....................................
Microphone ...........................................
Microphone Attenuator ................. 57,
Audio Attenuator.................................
Audio Mode ..........................................
Analog-Digital Converter .....................
Return
37
112
108
56
108
108
56
104
SEL. SETSET
MENUCLOSE
REC MODE••••SP
OUTPUT CH•••L/R
AUDIO DUB. ••AUDIO IN
MIC•••••••••NORMAL
MIC ATT•••••OFF
AUDIO ATT•••OFF
AUDIO MODE••16bit
AVaDV OUT•••OFF
VCR SET UP
q
e
t
u
o
w
r
y
i
2 Display Set Up Submenu
!0
!1
!2
!3
!4
!5
!6
!7
24
LCD Brightness ...................................... 44
Viewfinder Brightness ............................ 44
Displays ............................................... 150
6-Second Auto Date .............................. 92
Data Code ............................................. 91
Selecting Date/Time ............................... 90
Custom Key Display ............................... 58
Audio Level Indicator ............................. 57
SEL. SETSET
MENUCLOSE
+
LCD BRIGHT••–
+
EVF BRIGHT••–
DISPLAYS••••ON
6SEC. DATE•••OFF
DATA CODE•••DATE/TIME
D/TIME SEL. •DATE & TIME
CUSTOM KEY••ON
AUDIO LEVEL•OFF
DISP. SET UP
!0
!2
!4
!6
!1
!3
!5
!7
3 System Submenu
E
!8
!9
@0
@1
@2
@3
Wireless Controller.................................
Tally Lamp..............................................
Beep ......................................................
Time Zone/Daylight Saving Time ............
Setting Date and Time ..........................
Return
30
31
39
32
34
SEL. SETSET
MENUCLOSE
WL. REMOTE•••
1
TALLY LAMP••ON
BEEP••••••••ON
T. ZONE/DST••–––
D/TIME SET••–––. ––, ––––
––:––:–– ––
RETURN
SYSTEM
!8
@0
@2
!9
@1
@3
4 Custom Key Submenu
@4 Custom Key ...........................................
@5 Return
58
SEL. SETSET
MENUCLOSE
CUSTOM KEY••TV SCREEN
RETURN
CUSTOM KEY
@4
@5
Preparations
2 C. CAM. MENU
Set the POWER switch to CAMERA and the TAPE/CARD switch to
There are 6 submenus within the C. CAM. MENU.
1
2
3
4
5
6
7
Camera Set Up Submenu
Custom Preset Submenu
Card Set Up Submenu
Display Set Up Submenu
System Submenu
Custom Key Submenu
Close Main Menu
CARD
.
C. CAM. MENU
1
3
5
7
SEL. SETSET
MENUCLOSE
CAM. SET UP
CSTM PRESET
CARD SET UP
DISP. SET UP
SYSTEM
CUSTOM KEY
RETURN
2
4
6
1 Camera set up Submenu
q
w
e
r
t
y
u
i
Image Stabilizer .....................................
AE Shift .................................................
Zebra Pattern.........................................
Zebra Pattern Level ................................
Grip Zoom Speed...................................
Handle Zoom Speed ..............................
Self-Timer ..............................................
Return
46
82
85
85
42
42
71
SEL. SETSET
MENUCLOSE
IMAGE S. i••ON
AE SHIFT••••±0
ZEBRA•••••••OFF
ZEBRA LEVEL•90
ZOOM GRIP•••VARIABLE
ZOOM HANDLE•MEDIUM
SELF-TIMER••OFF
RETURN
CAM. SET UP
q
e
t
u
w
r
y
i
25
2 Custom Preset Submenu
E
o
!0
!1
!2
!3
Color Gain .............................................
Color Phase ...........................................
Sharpness ..............................................
Setup Level ............................................
Return
83
83
83
84
CSTM PRESET
o
!1
!3
SEL. SETSET
MENUCLOSE
+
R
+
+
COLOR GAIN••–
COLOR PHASE•G
SHARPNESS•••–
SETUP LEVEL•–
RETURN
!0
!2
3 Card Set Up Submenu
Preparations
!4
!5
!6
!7
!8
Image Quality ......................................
Image Resolution .................................
File Numbers........................................
Shutter Sound......................................
Return
115
116
117
117
SEL. SETSET
MENUCLOSE
QUALITY•••••FINE
IMAGES RES. •1488×1128
FILE NOS. •••CONTINUOUS
SHTR SOUND••ON
RETURN
CARD SET UP
!4
!6
!8
!5
!7
4 Display Set Up Submenu
!9
@0
@1
@2
@3
@4
@5
@6
LCD Brightness ...................................... 44
Viewfinder Brightness ............................ 44
LCD Mirror Mode .................................. 44
TV Screen ............................................ 150
Guide Information ................................. 34
Card Access Display ............................. 116
Demonstration Mode............................. 39
Return
SEL. SETSET
MENUCLOSE
+
LCD BRIGHT••–
+
EVF BRIGHT••–
••
LCD MIRROR ON
TV SCREEN•••OFF
GUIDE INFO••ON
CARD ACCESS•ON
DEMO MODE•••ON
RETURN
DISP. SET UP
!9
@1
@3
@5
@0
@2
@4
@6
5 System Submenu
@7
@8
@9
#0
#1
26
Wireless Controller.................................
Beep ......................................................
Time Zone/Daylight Saving Time ............
Setting Date/Time ..................................
Return
30
39
32
34
SEL. SETSET
MENUCLOSE
WL. REMOTE•••
1
BEEP••••••••ON
T. ZONE/DST••–––
D/TIMR SET••–––. ––, ––––
––:––:–– ––
RETURN
SYSTEM
@7
@9
#1
@8
#0
6 Custom Key Submenu
E
#2 Custom Key ...........................................
#3 Return
58
SEL. SETSET
MENUCLOSE
CUSTOM KEY•ZEBRA
RETURN
CUSTOM KEY
#2
#3
2 C. PLAY MENU
PLAY
Set the POWER switch to (VCR)
and the TAPE/CARD switch to
There are 5 submenus within the C. PLAY MENU.
Card Operation Submenu
VCR Set Up Submenu
Display Set Up Submenu
System Submenu
Custom Key Submenu
Close Main Menu
.
C. PLAY MENU
1
3
5
SEL. SETSET
MENUCLOSE
CARD OPER.
VCR SET UP
DISP. SET UP
SYSTEM
CUSTOM KEY
RETURN
2
4
6
Preparations
1
2
3
4
5
6
CARD
1-1 Card Operation Submenu (Single Image Display)
q
w
e
r
t
y
u
Copying from Card to Tape..................
Erasing All Print Marks .........................
Erasing Images.....................................
Protecting a Title..................................
Erasing a Title ......................................
Formatting...........................................
Return
132
126
127
130
131
133
SEL. SETSET
MENUCLOSE
]
COPY [
PRINT MARKS ALL ERASE
IMAGE ERASE
TITLE PROTECT
TITLE ERASE
FORMAT
RETURN
CARD OPER.
q
e
t
u
w
r
y
1-2 Card Operation Submenu (Index Screen Display)
i Protecting an Image.............................
o Print Marking.......................................
124
125
CARD OPER.
i
PROTECT
PRINT MARK
RETURN
SEL. SETSET
MENUCLOSE
o
27
2 VCR Set Up Submenu
E
!0 Recording Mode ....................................
!1 Return
37
VCR SET UP
!0
SEL. SETSET
MENUCLOSE
REC MODE••••SP
RETURN
!1
3 Display Set Up Submenu
Preparations
!2
!3
!4
!5
!6
!7
!8
LCD Brightness ...................................... 44
Viewfinder Brightness ............................ 44
Displays ............................................... 150
Selecting Date/Time ............................... 90
Custom Key Display ............................... 58
Card Access Display ............................. 116
Return
SEL. SETSET
MENUCLOSE
+
LCD BRIGHT••–
+
EVF BRIGHT••–
DISPLAYS••••ON
D/TIME SEL. •DATE & TIME
CUSTOM KEY••ON
CARD ACCESS•ON
RETURN
DISP. SET UP
!2
!4
!6
!8
!3
!5
!7
4 System Submenu
!9
@0
@1
@2
@3
@4
Wireless Controller.................................
Tally Lamp..............................................
Beep ......................................................
Time Zone/Daylight Saving Time ............
Setting Date and Time ..........................
Return
30
31
39
32
34
SEL. SETSET
MENUCLOSE
WL. REMOTE•••
1
••
TALLY LAMP ON
BEEP••••••••ON
T. ZONE/DST••–––
D/TIME SET••–––. ––, ––––
––:––:–– ––
RETURN
SYSTEM
!9
@1
@3
@0
@2
@4
5 Custom Key Submenu
@5 Custom Key ...........................................
@6 Return
28
58
SEL. SETSET
MENUCLOSE
CUSTOM KEY••TV SCREEN
RETURN
CUSTOM KEY
@5
@6
Using the Wireless Controller/Tally Lamp
The supplied wireless controller can operate the
camcorder from a distance of up to 16 feet (5
m). Point it at the camcorder’s remote sensor
while you press the buttons.
The tally lamp lights up to let you know that the
camcorder is in range and responding to your
commands.
E
m)
t (5
16f
There are four functions which can only be
operated using the wireless controller:
• Special playback ( 88)
• Photo/date/index search ( 93)
• Zero set memory ( 94)
• Audio mix ( 111)
Inserting Batteries
Preparations
Insert two AA batteries, following the + and –
markings. Be careful not to reverse the polarity of the
batteries.
Notes:
• When using the wireless controller in brightly lit places or outdoors, the effective range will be
less.
• The camcorder may have difficulty picking up the remote control signals at extremely close range.
• Do not leave the controller exposed to direct sunlight, or in hot or humid places.
• When the batteries run out, replace them both together.
• Make sure the shoulder strap does not obstruct the remote sensor.
29
When Operating 2 Canon DV Camcorders (Remote Sensor Mode)
E
To prevent interference from other Canon wireless controllers
being used nearby, there are 2 remote sensor modes and an
off setting. The wireless controller and the camcorder have
to be set to the same mode in order to be compatible.
ZOOM
W
T
REMOTE SET
The wireless controller and the camcorder have been preset to mode 1. If you change the mode on
the camcorder, be sure to change the mode on the wireless controller to the same mode.
TAPE
+
CAMERA
,
TAPE
SYSTEM
Preparations
(
+
PLAY
(VCR)
,
CARD
+
WL.REMOTE••• A1
20)
CAMERA
,
CARD
+
PLAY
(VCR)
A 1 : Mode 1
A 2 : Mode 2
OFFB : Sensor off
To turn the remote sensor off:
Open the menu and select SYSTEM. Then select WL.REMOTE, set it to OFF B and
close the menu.
•B appears in the display.
To change the mode...
...on the camcorder:
Open the menu and select SYSTEM. Then select WL.REMOTE, set it to A 1 or A
2 and close the menu.
•The selected mode will appear on the display for 4 seconds.
...on the wireless controller:
Press and hold the REMOTE SET button on the wireless controller.
Simultaneously press the ZOOM W button for mode 1 or the ZOOM T button for
mode 2. Continue to press simultaneously for over 2 seconds.
•Be sure to set the wireless controller to the same mode as the camcorder.
If your wireless controller is not working:
Make sure the camcorder and the wireless controller are both set to the same mode. Check the
mode the camcorder is set to by pushing any button other than the REMOTE SET button on the
wireless controller. The camcorder’s mode appears in purple for about 4 seconds. Set the wireless
controller’s mode accordingly by pressing the aforementioned button combinations. If the wireless
controller still does not work, change the batteries.
Notes:
• The mode of the camcorder also appears for 4 seconds when you turn the power on.
• When you replace the batteries, the wireless controller returns to mode 1. Change the mode
again if necessary.
30
Turning Off the Tally Lamp
E
The tally lamp lets you know that the camcorder is recording.
However, its flashing may be reflected into the lens during
close-up recording, or when recording through glass.
You may therefore decide to turn it off.
TAPE
+
CAMERA
SYSTEM
(
,
TAPE
+
PLAY
(VCR)
,
CARD
+
PLAY
(VCR)
TALLY LAMP•• ON
20)
1. Open the menu and select TALLY LAMP.
• The tally lamp no longer flashes during recording, but it will still light up when the camcorder
receives a signal from the wireless controller.
Preparations
2. Select the OFF setting and close the menu.
31
Setting the Date and Time
E
The date and/ time display forms part of the data code. You can choose to display or hide it during
playback ( 90).
Set the date and time display when you first start using your camcorder. Install the backup battery
before you begin ( 138).
• Before you start setting the date and time, select your home time zone from the menu.
Preparations
Setting the Time Zone/Daylight Saving Time
TAPE
+
CAMERA
,
TAPE
+
SYSTEM
(
PLAY
(VCR)
,
CARD
+
CAMERA
,
CARD
+
PLAY
(VCR)
T.ZONE/DST•• N.Y.
20)
1. Press the MENU button.
• The main menu appears.
2. Pull the SELECT dial up or down, select SYSTEM and press the SELECT dial in.
• The SYSTEM submenu appears.
3. Pull the SELECT dial up or down, select T.ZONE/DST and press the SELECT dial
in.
• The time zone settings appear.
• Your camcorder’s time zone is factory-preset to New York. If you are at another time zone,
select your time zone first and daylight saving time (DST) setting if necessary.
4. Move up or down the list of time zones by pulling the SELECT dial up or down.
Press the SELECT dial in to set the time zone that represents your time zone.
• If you are in daylight saving time, select the time zone with the daylight saving time mark U
next to the area.
5. Press the MENU button.
32
E
16
1
19
18
24
20
4
2
3
17
6
7
10
9
15
8
5
21
23
14
12
22
11
13
14 15 16 17 18 19 20 21 22 23 24
No. Time zone
2
3
4
5
6
7
8
9
10 11 12 13
No. Time zone
WELLGTN (Wellington)
SAMOA
HONOLU. (Honolulu)
ANCHOR. (Anchorage)
L.A. (Los Angeles)
DENVER
CHICAGO
N.Y. (New York)
CARACAS
RIO (Rio de Janeiro)
FERNAN. (Fernando de Noronha)
AZORES
Preparations
LONDON
PARIS
CAIRO
MOSCOW
DUBAI
KARACHI
DACCA
BANGKOK
H. KONG (Hong Kong)
TOKYO
SYDNEY
SOLOMON
1
Notes:
• After you have selected your time zone and set the date and time, when you travel to another
time zone, there is no need to reset the date and time. Just set the time zone to your destination
and the camcorder’s clock will automatically change to display the correct time for your
destination.
• The camcorder automatically accounts for the number of days in a month and leap year.
33
Setting the Clock
E
After you set the date and time, the date/time and home time zone will be displayed for about 4
seconds each time you turn the power on (in TAPE CAMERA and CARD CAMERA mode).
TAPE
+
CAMERA
,
TAPE
+
SYSTEM
(
PLAY
(VCR)
,
CARD
+
CAMERA
,
CARD
+
PLAY
(VCR)
D/TIME SET•• JAN.1,2002
12:00 AM
20)
1. Press the MENU button.
• The main menu appears.
2. Pull the SELECT dial up or down, select SYSTEM and press the SELECT dial in.
• The SYSTEM submenu menu appears.
3. Pull the SELECT dial up or down, select D/TIME SET and press the SELECT dial
in.
Preparations
• The year display starts to flash.
4. Pull the SELECT dial up or down to change the year. Press the SELECT dial in to
move to another part of the display.
• Once you move from the year, the next part of the display starts flashing.
5. Set the month, day, hours, and minutes in the same way.
6. Press the MENU button when finished to start the clock.
• The date can be set to any year between 2002 and 2030.
• When you press the MENU button during the setting, the seconds become set to zero, the
menu closes and the clock starts.
• If you press the SELECT dial in after having set the minutes, you can set date and time again
from the start.
Date and Time Display
You can choose to display or hide the date and time display during recording. When the date and
time display is set to ON, the date and time appear in the lower left-hand corner of the display but
the time zone disappears in about 4 seconds. Date and time will not be superimposed on your
recordings.
TAPE
+
CAMERA
,
DISP.SET UP
(
CARD
+
CAMERA
GUIDE INFO•• OFF
20)
To turn it on, open the menu and select DISP.SET UP. Then select GUIDE INFO, set
it to D/T DISPLAY and close the menu.
34
Basic Recording
1CARD
1
4
STANDBY LOCK
TAPE
E
START
STOP
3
STANDBY LOCK
2
Before You Start Recording
•
•
•
•
•
•
Attach a power source ( 16).
Load a cassette ( 18).
Fasten the grip belt ( 15).
Attach the lens hood ( 14).
Choose the display: viewfinder ( 14) or LCD screen (
Adjust the viewfinder or the LCD screen.
43).
You may also want to install the backup battery ( 138) in order to set the date and time display
( 32). For setting the movie mode, see “Selecting the Movie Mode” ( 50).
1. Slide the POWER switch to CAMERA and the TAPE/CARD switch to TAPE.
2. Turn the standby lever to STANDBY.
Recording
Recording
• The camcorder power indicator lights up red and PAUSE appears in the display — the
camcorder is now in “record pause mode”.
• For recording still images, see “Recording Still Images onto a Tape” ( 48) and “Recording
Still Images onto a Memory Card” ( 118).
3. Turn the program selector to [ Easy Recording mode.
• This selects the camcorder’s Easy Recording program. It allows you to simply point and shoot
without making any manual adjustments ( 53).
4. Press the start/stop button to begin recording.
• There are two start/stop buttons, to give you control from both gripping positions.
• The tally lamp flashes rapidly and REC appears in the display.
• When you start recording, the camcorder counts from 0 SEC. to 10 SEC. Recordings shorter
than 10 seconds may be difficult to edit later.
5. Press the start/stop button again to pause recording.
• The camcorder returns to record pause mode and PAUSE reappears in the display.
• You can stop and restart recording as often as you like by pressing the start/stop button.
Low-Angle Recording
The camcorder is also designed for low-angle recording. The handle is equipped with start/stop
button, PHOTO button and zoom controls. The speed of the zoom controls on the handle can be
set to low, medium or fast in the menu ( 42).
Slide the LOCK lever into the direction of the arrow to lock the handle controls to prevent
accidental operation.
35
Using the STANDBY lever
E
As long as the POWER switch is set to CAMERA, you can use the STANDBY lever to turn the
camcorder on and off. This saves battery power and prevents accidental operation of the start/stop
button.
Turn the STANDBY lever to LOCK or STANDBY to enter/leave the standby mode.
The Power Save Function
The camcorder automatically turns off if you leave it in record pause mode for more than 5 minutes
to protect tape and video heads.
You can select whether to turn off the camcorder (SHUT OFF) or only the recorder section (VCR
STOP).
At VCR STOP, the camcorder remains turned on, so that the camcorder settings such as aperture
and shutter speed are retained. Press the start/stop button to start recording from the VCR STOP
state. Press the VCR STOP Custom Key to go into record pause mode ( 58).
If you have selected SHUT OFF and the camcorder turns off, turn the standby lever to LOCK and
back to STANDBY to turn the camcorder on.
VCR STOP
Recording
Select VCR STOP as the function for the Custom Key button in the menu. Pressing the Custom Key
will then only turn off the recorder section while the camcorder remains on. This will enable you to
change the camcorder settings without being interfered by the automatic shut off.
To start recording, press the VCR STOP button and the camcorder will go into record pause mode.
When You Have Finished Recording
•
•
•
•
•
•
Close the LCD panel.
Unload the cassette.
Turn the standby lever to LOCK.
Slide the POWER switch to OFF.
Disconnect the power source.
If you have used the viewfinder, return it to its lowered and retracted position.
Notes:
• To check that the camcorder is recording correctly, make a test recording first.
• Before making important recordings, clean the video heads using a Canon DVM-CL Digital Video
Head Cleaning Cassette or a commercially available digital video head cleaning cassette.
• To close the LCD panel, rotate it vertically until the screen faces you, then push it in flat against
the side of the camcorder.
• You cannot monitor the sound from the speaker when recording.
• For tips on how to make better videos, see page 40.
• For extra recording time, see “Changing the Recording Time” ( 37)
• The flashing of the tally lamp may be reflected into the lens during close-up recording, or when
recording through glass. You may therefore decide to turn it off ( 31).
36
Changing the Recording Mode (SP/LP)
E
You can record and play back a tape in SP (standard play) and LP (long play) modes. LP extends the
tape usage by 1.5 times.
You cannot add sound (audio dubbing) or images (AV insert) to a tape that has been recorded in
LP mode. If you plan to use either of these functions later, record in SP mode.
TAPE
+
CAMERA
,
TAPE
+
VCR SET UP
(
PLAY
(VCR)
,
CARD
+
CAMERA
REC MODE•••• SP
20)
To change to LP mode, open the menu and select VCR SET UP. Then select REC
MODE, set it to LP and close the menu.
Notes:
Recording
• When recording and playing back tapes in LP mode, the nature of the tape and usage conditions
may affect recording, mosaic-like noise may appear in the image and the sound may be distorted
during playback of tapes recorded in LP mode. For important recordings, therefore, set the
camcorder to SP mode.
• If you record in both modes on the same tape, the picture may become distorted during playback
and the time code may not be written correctly.
• When the camcorder is set to LP mode, pausing between recordings may produce mosaic-like
noise.
• A tape recorded in LP mode on another camcorder may produce mosaic-like noise when played
back on this camcorder, and vice versa.
16:9 (Wide-Screen TV Recording)
Produces images in the 16:9 format for playback on wide-screen TVs.
TAPE
+
CAMERA
,
CAM.SET UP
(
TAPE
+
PLAY
(VCR)
16:9•••••••• OFF
20)
1. Open the menu and select DISP. SET UP.
2. Select 16:9, set it to ON and close the menu.
37
The 16:9 guides allows you to view the 16:9 wide screen composition while in the standard 4:3
aspect ratio. The 16:9 guides will not be superimposed on your recordings.
E
TAPE
+
CAMERA
,
DISP.SET UP
(
TAPE
+
PLAY
(VCR)
16:9GUIDES•• OFF
20)
1. Open the menu and select DISP. SET UP.
2. Select 16:9 GUIDES, set it to ON and close the menu.
Notes:
• “16:9” is shown in the display when you turn the 16:9 effect on.
• If you play back a recording made for 16:9 on a normal TV screen, the image will appear to be
vertically “squashed” (compressed).
• If you connect the camcorder to a TV with an S1 terminal or the Video ID-1 system, recordings
made in the 16:9 mode for wide screen TVs will automatically play back in wide screen mode on
the TV screen.
Recording
Turning the Camcorder Recording Displays ON/OFF
You can change the display by pressing the
DISPLAY/DATA CODE button.
Each time you press the DISPLAY/DATA CODE button,
the display will change as follows:
DISPLAY/
DATA CODE
Normal display
Recording mode, operating mode, time code,
warnings, date and time*
Date and time*
No display
* Appears when GUIDE INFO is set to D/T DISPLAY in the DISP. SET UP submenu (CAMERA menu).
Notes:
• The display becomes reset when you turn the power off by the POWER switch or standby lever.
• The same information will be displayed on a connected TV screen (TV SCREEN function).
• The audio level indicator can be displayed or hidden through the menu independently from the
DISPLAY/DATA CODE button.
38
Confirmation/Warning beeps
E
The camcorder’s short operation confirmation beeps are indicated by ` in the illustrations. Beeps
sound upon certain camcorder operations such as when you turn the camcorder on, during the
self-timer countdown, right before the camcorder’s automatic shut-off, and also upon any unusual
condition of the camcorder. Beeps are not recorded on the tape.
TAPE
+
CAMERA
,
TAPE
+
SYSTEM
(
PLAY
(VCR)
,
CARD
+
CAMERA
,
CARD
+
PLAY
(VCR)
BEEP••• ON
20)
To turn the beep off, open the menu and select SYSTEM. Then select BEEP, set it
to OFF and close the menu.
Demonstration Mode
You can see a demonstration of the camcorder’s main features. To see the demonstration, do either
of the following:
• With no cassette or memory card inserted, turn the DEMO MODE on in the CAM.MENU or
C.CAM.MENU and close the menu.
• Leave the camcorder with no cassette or memory card inserted for five minutes after turning it
on.
+
CAMERA
,
DISP. SET UP
(
CARD
+
CAMERA
Recording
TAPE
DEMO MODE••• ON
20)
To turn the demonstration mode off, open the menu and select DISP. SET UP. Then
select DEMO MODE, set it to OFF and close the menu.
Notes:
• The opening animation will not appear when the demonstration mode is turned off.
• To cancel the demo mode once it has begun: push any button, turn off the power, load a
cassette or insert a memory card.
39
Tips for Making Better Videos
Holding the Camcorder
E
For maximum stability, grip the camcorder in your right hand and keep your
right elbow pressed against your body.
If necessary support the camcorder with your left hand. With practice, you
will be able to operate the controls by touch, without taking your eye off
the action.
Using a Tripod
Recording
To prevent any unwanted movement, you can mount the camcorder on a
tripod, (or any flat surface at a suitable height) and operate it with the
wireless controller.
• When you are using a tripod, be careful not to leave the viewfinder
exposed to bright sunlight as it may melt. (The light is concentrated by the
viewfinder lens.) Change the angle of the viewfinder so that the sun does
not shine into it.
• Make sure that the fastening screw of the tripod is no longer than 1/4
inch (5.5 mm), as it will damage the camcorder.
40
Sound Recording
For greater creative control over audio recording, you
can connect an external microphone to the camcorder
via the MIC terminal. When using the MIC terminal,
use a microphone with a built-in power supply
(condenser microphone). It is possible to connect
almost any stereo microphone with a plug diameter of
1/8 inch (3.5 mm), however, their audio levels will be
different from that of the built-in microphone.
Composition
E
The most important element in the scene does not necessarily have to be
centered. For a more interesting picture, try to position your subject slightly
to one side. Leave some space on the side of the frame that the subject is
facing or moving towards.
Do not cut off the top of the subject’s head, and do not cut people off at
the neck, hips or knees (move a little bit above or below).
Watch out for distracting objects in the background.
Picture Angle
Instead of zooming while recording, try to choose your picture angle
before you begin. A good way to tell a story with video is to begin
with a long shot that establishes the situation, and then move in with
medium shots and close-ups to show the details. Remember to
change your viewpoint for each shot.
Medium shot
Close-up
Recording
Remember that any camcorder movement or change in picture angle
should have a definite purpose. Avoid unnecessary or half-hearted
movements.
Long shot
Camcorder Moves
Use pans to record a landscape or follow a moving subject.
Decide the area you wish to cover and stand facing the end
of your panning angle. Without moving your feet, turn your
waist to the starting position. Start recording, and after a
few seconds begin to turn slowly from the waist. Hold the
final image for a few seconds before you stop recording.
Pan
Tilt the camcorder up to exaggerate the height of the
subject. Tilt down from the top of a building, for example,
as an introduction to subjects at the bottom.
Tilt
41
Zooming
T
Zoom in
E
ZOOM
W
Zoom out
W
W
T
T
This camcorder is equipped with 20× optical zoom and 100× digital zoom. Optical zoom and digital
zoom can be operated from either the side grip, the camcorder handle or the wireless controller.
• Digital zoom cannot be used in CARD CAMERA mode.
20× Optical Zoom
Press the zoom control towards W to zoom out to wide-angle.
Press it towards T to zoom in to telephoto.
Recording
• The speed of the zoom controls on the camcorder can be changed in the CAMERA SET UP
submenu (grip zoom: variable, low, medium and fast; handle zoom: low, medium and fast).
• The speed of the zoom control of the wireless controller cannot be adjusted.
40×/100× Digital Zoom
The digital zoom magnifies the camcorder’s zoom range by up to 5 times.
TAPE
+
CAMERA
CAM. SET UP
(
D.ZOOM••• OFF
20)
To change the digital zoom, open the menu and select CAM.SET UP. Then select
DIGITAL ZOOM, set it to 40 × or 100 × and close the menu.
The zoom control continues to work as usual. You can freely zoom in and out between 1× and 40×
or 1× and 100x magnification — the camcorder automatically switches between optical zooming
(up to 20×) and digital zooming (20× to 100×).
Notes:
• When zooming, as a rule, keep at least 3 ft 3 3/8 in (1m) between you and your subject. However
when the zoom is at the wide-angle position, you can focus on a subject as close as 3/8 in (1 cm).
• Image resolution decreases the further you zoom towards 100× in digital zoom range.
• When the digital zoom is set to 40×, the zoom indicator extends (light blue). When the digital
zoom is set to 100× zoom, the zoom indicator extends again (a darker blue).
42
Using the LCD Screen
Opening the LCD Screen
E
Push the LCD panel OPEN button and open the panel by
pulling it away from the camcorder. This automatically
switches the LCD screen on and the viewfinder off.
When you close the LCD panel, the LCD screen
automatically switches off and the viewfinder switches
back on.
Changing the Angle of the LCD Screen
First open out the LCD panel at a right angle (90°) to the
camcorder.
You can now choose the angle of the panel that suits
you best by rotating it backwards (up to 180°) and
forwards (up to 90°) about its axis.
Recording
If you rotate the panel backwards around to 180°, you
can allow the subject to monitor the shot on the LCD
screen or you can include yourself in the picture. The
viewfinder is also activated when the panel is in this
position.
From this position you may also push the panel flat
against the camcorder, with the screen facing outwards.
Notes:
•
•
•
•
Avoid touching the LCD screen when moving the LCD panel.
Do not hold the camcorder by the LCD panel or the viewfinder.
Make sure you open the LCD panel at 90°, before attempting to rotate it backwards or forwards.
Always rotate the LCD panel vertically into place, before closing it or pushing it flat against the
side of the camcorder.
• Always fully close the LCD panel when it is not in use.
• Be careful not to leave the LCD, viewfinder or lens exposed to direct sunlight outdoors or
through a window. Doing so could cause damage.
• Bright light falling on the LCD screen may cause glare that makes it difficult for you to view the
image. In this case, switch to using the viewfinder. You can also adjust the brightness of the
screen.
43
Adjusting the Brightness of the Display
E
You can adjust the brightness of the LCD screen and the viewfinder independently.
TAPE
+
CAMERA
,
TAPE
+
DISP. SET UP
(
PLAY
(VCR)
,
+
CARD
LCD BRIGHT••–
+
EVF BRIGHT••–
+
CAMERA
,
CARD
+
PLAY
(VCR)
20)
1. Open the menu and select DISP. SET UP.
2. Select LCD BRIGHT or EVF BRIGHT and adjust the brightness.
• Pull the SELECT dial up to make the display brighter, and down to make it darker.
3. Close the menu.
Notes:
• The camcorder retains your brightness setting even if you slide the POWER switch to OFF.
• The brightness of the LCD screen/viewfinder does not effect that of the recorded images.
Recording
About the LCD Screen
The LCD screen built into this camcorder is a high precision product.
However, small black dots or bright points of light (red, blue or green) may appear constantly on
the LCD screen. This is not a malfunction of the LCD screen and they are not recorded on the tape.
(Effective dots: more than 99.99%)
Allowing the Subject to Monitor Recording
When you turn the LCD panel so that it faces into the
opposite direction, you can allow your subject to monitor
the screen, or you can monitor yourself while recording.
• You can choose the display style between reversed (LCD
MIRROR ON) or not (LCD MIRROR OFF) in the menu.
TAPE
+
CAMERA
,
DISP. SET UP
(
44
20)
CARD
+
CAMERA
LCD MIRROR••• ON
To turn the mirror mode off, open the menu and select DISP.SET UP.
E
Then select MIRROR, set it to OFF and close the menu.
• LCD MIRROR ON: The picture appears reversed like in a mirror.
• LCD MIRROR OFF: The picture appears the same as the recording.
• If you turn the LCD MIRROR ON, the recording itself is unaffected.
Indicators that appear on the LCD screen when MIRROR is turned on:
TAPE CAMERA mode :
REC
REC PAUSE
EJECT
CARD CAMERA mode :
No Card
Recording to a
memory card
CARD CAMERA mode :
Recording
Recording to a memory card
The audio level indicator will be displayed as follows:
On the LCD Screen:
Automatic
Manual
On the Viewfinder:
Automatic
Manual
45
Turning the Optical Image Stabilizer Off
E
With most camcorders, even the slightest hand movements will be noticeable during telephoto
recording. However, the GL2’s Optical Image Stabilizer allows you to obtain steady recordings even
at high magnification. Unlike electronic image stabilizers, it causes no loss of picture quality. The
Optical Image Stabilizer can compensate for a wide range of camcorder movement — you can
record stable images even if you are shooting from a moving car.
TAPE
+
CAMERA
,
CAM.SET UP
Recording
(
CARD
+
CAMERA
IMAGE S.i••• ON
20)
To turn the image stabilizer off, open the menu and select CAM.SET UP. Then
select IMAGE S. i, set it to OFF and close the menu.
• The i mark appears in the display when the stabilizer is on.
• The image stabilizer cannot be turned off when the program selector is set to the [ (Easy
Recording) program.
Notes:
• The camcorder retains your selection even if you turn the camcorder off.
• The image stabilizer is designed to deal with a normal degree of camcorder shake.
• Keep the image stabilizer turned off when the camcorder is mounted on a tripod.
46
Using the ND Filter
E
ND FILTER
ON/OFF
On bright days or when recording very bright scenes, despite the iris being at its smallest aperture,
blurring of the image may occur. If this happens, using the ND filter should remove this problem.
Turn the ND filter on by pressing the ND FILTER ON/OFF button.
• ND is shown continuously in the display while the ND filter is turned on.
– ND ON flashes in the display to advise you to switch the ND filter on. (However it does not
appear in the Manual mode or during exposure lock.)
– ND ON with the “ON” flashing advises you to fit an external ND filter* or that the light
conditions are still too bright, despite having switched the ND filter on.
* When you don’t have an external ND filter, make the shutter speed faster in Tv mode or open the
aperture in Av mode.
Recording
– ND OFF with the “OFF” flashing warns you that the ND filter is no longer suitable for the current
conditions. If this warning appears, turn the ND filter off by pressing the ND FILTER ON/OFF
button again.
Notes:
• You cannot turn the ND filter on/off during exposure lock or while the PHOTO button is pressed
halfway down.
• The camcorder retains your selection if you turn the standby lever to LOCK. However, it resets to
the OFF setting if you slide the POWER switch to OFF.
47
Recording Still Images onto a Tape
For recording still images on a memory card, see p. 118.
E
You can record still images like photographs. The camcorder records the picture and sound to tape
for several seconds. The exposure is automatically adjusted.
Starting your shooting with a still image makes it easy to find the beginning again later with the
Photo Search function ( 93).
You can take a still image at any time during regular video recording, or you can put the camcorder
into record pause mode first, then take a still image.
Recording
TAPE
+
CAMERA
During recording
Press the PHOTO button fully down and the still image will be taken immediately.
• The camcorder takes the image immediately, and then records the “photo” to the tape for
approximately 6 seconds. During this time the camcorder also records the sound, and the display
shows the still image.
• A counter display appears, and counts up as the camcorder records the image.
• The camcorder returns to record pause mode.
During record pause mode
1. Press the PHOTO button halfway down and hold it:
• “PHOTO” flashes at the bottom right of display.
• Exposure is locked.
• During autofocus F flashes white in the display as the camcorder adjusts the focus and it is
displayed continuously as a green mark when the camcorder is ready to take the still image.
• If the subject is unsuitable for autofocus ( 144), the camcorder may not be able to focus,
and F may continue to flash white in the display. Continue to hold the PHOTO button halfway
down, then adjust the focus manually with the focus ring.
• If you are using manual focus ( 79), the F mark starts as a continuous green mark. Focus
with the focus ring.
48
2. Press the PHOTO button fully down to take the still image
E
• The camcorder takes the image immediately, and then records the “photo” to the tape for
approximately 6 seconds. During this time the camcorder also records the sound, and the
display shows the still image.
• A counter display appears, and counts up as the camcorder records the still image. F
disappears from the display.
• The camcorder returns to record pause mode.
Notes:
• The camcorder automatically returns to record pause mode after recording a still image for
approximately 6 seconds. If you turn the POWER switch to OFF during that time, the camcorder
will respond only after recording is complete.
• The wireless controller’s PHOTO button has no half-way setting. Press the button fully and the
camcorder immediately takes the “photo”.
Recording
49
Selecting the Movie Mode (Normal/Frame)
The frame mode can be used when you wish to look at a video, scene by scene, free from field
slippage (the “flicker” that normally occurs when you pause a video). The vertical resolution of the
image is improved by 1.5×. During playback, pause the video at any time if you would like to view a
crystal clear still image in the display or on a connected TV screen. It is also possible to transfer your
favorite still pictures to a PC for image enhancement and print out.
Since the frame rate is close to that of a movie, this mode can be used to create “cinematic-like
appearance.”
E
TAPE
+
CAMERA
CAM.SET UP
(
MOVIE MODE•• NORMAL
20)
1. Slide the program selector to Q (program AE) mode.
2. Open the menu and select CAM. SET UP.
3. Select MOVIE MODE, set it to FRAME and close the menu.
• FRAME appears in the display.
Recording
Notes:
50
• To return to normal video shooting, you need to re-select NORMAL from MOVIE MODE in the
CAMERA menu.
• Frame mode cannot be used with the Easy Recording program.
• Frame video may not appear completely smooth during normal playback.
• The digital effects WIPE, OVERLAP, STROBE and TRAIL cannot be used when the MOVIE MODE is
set to FRAME.
Searching and Reviewing While Recording
Record Search
When the camcorder is in record pause mode,
you can use record search to play the tape
forwards or backwards to find the point where
you wish to start or restart recording. This is
useful when you wish to add a new scene to a
previously used cassette. By using record search,
you can ensure a smooth, noise-free join between
the new scene and the old one.
TAPE
+
E
REC SEARCH
CAMERA
1. Press and hold the REC SEARCH + or – button while you check the picture in
the display.
• The + button plays the recording forwards and the – button plays it backwards.
2. Release the button when you find the point where you want to start
recording.
• The camcorder returns to record pause mode.
Record Review
TAPE
+
Recording
When the camcorder is in record pause mode, you can use record review to play back the last few
seconds of your recording and then return automatically to record pause mode. You can quickly
make sure that a scene has recorded properly and then go on to shoot the next scene, without
producing any noise in the picture.
CAMERA
1. Press and release the c (record review) button while you check the picture in
the display.
• The camcorder rewinds the tape, plays back the last few seconds, and returns to record pause
mode.
Note:
• Noise may appear on the screen during record search and record review.
51
Using the Various Recording Programs
E
The camcorder provides you with a choice of seven recording programs. They use different
combinations of camcorder settings in order to adjust the exposure and other functions to match
the recording situation.
Availability of Functions in Each Recording Program
Easy
Recording
EXP dial:Exposure lock
i
EXP dial:Aperture adjustment
i
EXP dial:Shutter speed
i
EXP dial:Gain adjustment
i
Recording
Recording Program
Auto
Tv
i
i
h
i1)
h
i
Av
Manual
h
i1)
i
h
h
h
i
W. BALANCE SELECT button (Automatic)
h
W. BALANCE SET button
Custom preset setting
CSTM PRESET button
FOCUS A/M button
Focus ring
CSTM KEY button
i
i
i
i
i
h
h
h
h
h
h
h
i
(Normal)
h
i
(OFF)
h
Movie mode
16:9
Clear scan frequency
Clear scan activation
i
i
Digital effects
(excl. color bars)
i
i
i
h2)
h3)
h2)
h
i
i
Sand & Snow Spotlight
h
i1)
i1)
i1)
h
i1)
i
i
i
i
h
Color Bars
h
Digital zoom (TAPE
CAMERA mode only)
h
h = Available, i = Not available
1): Can be used when exposure is locked.
2): Frequency can be selected when clear scan is activated.
3): Shutter speed cannot be changed when the exposure is locked while clear scan is activated.
52
Setting the Program AE Mode
TAPE
+
CAMERA
,
CARD
+
E
CAMERA
1. Slide the program selector to Q (program AE) mode.
2. Press the SELECT dial in and display the program menu.
3. Pull the SELECT dial up or down and move the arrow up or down the menu.
4. Press the SELECT dial in to select the desired program.
• The program will appear in the display.
Notes:
• The name of your selected recording program appears constantly on the left of the display, with
the exception of AUTO which disappears after 4 seconds.
• Avoid changing programs during recording as the brightness of the image may change suddenly.
• The specialized AE programs are not suitable for all kinds of lighting. The image may flicker, or a
bright line may appear on the screen if you use them in unsuitable lighting conditions.
Easy Recording
[
[
Recording
The simplest way to use the camcorder is with the program
selector set to the [ position. The camcorder will take care of
focus, exposure and other adjustments, leaving you free to point
and shoot.
Auto
In normal recording conditions, set the program selector to AUTO.
This is the same as the Easy Recording program, except that you
now have the option of using any of the camcorder’s manual
functions.
AUTO
AUTO
53
Giving Priority to Shutter Speed (Shutter-Priority: Tv)
E
Use this program to select the shutter speed. Aperture and gain
are adjusted automatically.
Tv
Tv
Select Tv mode and set the shutter speed by pulling
the EXP dial up or down.
• Pull toward + for a slower shutter (the image becomes brighter) and to –
for a faster shutter (the image becomes darker).
Shutter Speeds
Recording
• You can choose from 12 shutter speeds between 1/8 and 1/15000. The available shutter speeds
in CARD CAMERA mode are from 1/60 to 1/500. If you switch from TAPE CAMERA mode to
CARD CAMERA mode, the shutter speeds will change automatically:
- Shutter speeds of 1/1000 and above in TAPE CAMERA mode → 1/500.
- Shutter speeds of 1/30 and below in TAPE CAMERA mode → 1/60
• When shooting outside on clear, bright days, the camcorder will often set a large F number to
adjust the amount of light entering the camcorder, throwing the focus off. Setting a fast shutter
speed or decreasing the amount of light with the ND filter can help correct this.
• If you try to set a shutter speed that is either too high or too low for the shooting conditions, the
indicator flashes in the display. In this case, increase or decrease the setting until the flashing
stops.
• The image may not appear smooth when a high shutter speed is set.
Notes:
• When recording in extreme low-light conditions, we recommend the use of a Canon Speedlite
( 68) or Video Light ( 73), both available as optional accessory.
• The selected shutter speed will reset if you turn the power off, change the recording program or
adjust the exposure.
Giving Priority to the Aperture (Aperture-Priority: Av)
Use this program to select the aperture (iris diameter) to give you
maximum control over the depth of field. Select between 10
aperture values (f/1.6, f/2.0, f/2.4, f/2.8, f/3.4, f/4.0, f/4.8, f/5.6,
f/6.7, f/8.0) in TAPE CAMERA mode and 9 aperture values in
CARD CAMERA mode (f/2.0 to f/8.0).
Shutter speed and gain are adjusted automatically.
Av
Av
Select Av mode and set the aperture by pulling the EXP dial up or down.
• Pull toward + to open the aperture (decrease the F number) and toward – to close the aperture
(increase the F number).
• If you try to set an F number that is too high/low for the shooting conditions, the indicator
flashes in the display. In this case, increase or decrease the setting until the flashing stops.
Notes:
• The selected aperture value will reset if you turn the power off, change the recording program or
adjust the exposure.
• If the ND filter is set to ON, increasing the F number may darken the image. Set the ND filter to
OFF and select your setting again.
54
Manual (
76)
E
Select this program for total creative freedom when operating the camcorder. You
can set aperture, shutter speed and gain independently to give you exactly the
exposure you require.
You can select between 30 shutter speed settings (1/8 to 1/15000), 19 aperture
values (f/1.6 to f/8.0) and 4 gain values (0dB to +18dB) in TAPE CAMERA mode.
MANUAL
Select MANUAL mode and set the shutter speed, aperture and gain.
• For further details, see “Adjusting the Exposure Manually” (
76).
Sand & Snow
Use this program in places where the background is so
SAND&SNOW
bright that the subject appears underexposed in the
display — a sunny beach or ski resort, for example. You
may notice some shudder when recording moving subjects.
SAND&SNOW
Spotlight
SPOTLIGHT
SPOTLIGHT
Recording
This program is designed for recording spotlit scenes,
such as on a stage. The exposure is automatically
adjusted for glare-free recordings of subjects lit by a
concentrated light source.
55
Audio Recording
Selecting the Audio Mode
E
The GL2 can record sound in two audio modes:
• 16-bit (48 kHz, 2 channel) for the highest sound quality
• 12-bit (32 kHz, 2 from 4 channels) for recording on two channels (stereo 1), leaving two channels
(stereo 2) free for you to add new sound at a later date.
TAPE
+
CAMERA
,
TAPE
+
PLAY
(VCR)
*
* Only available when AUDIO DUB. has been set to MIC. IN.
VCR SET UP
(
AUDIO MODE•• 16bit
20)
1. To switch the mode, open the VCR SET UP submenu and select AUDIO MODE.
2. Select a mode and close the menu.
• The name of the selected mode is displayed for 4 seconds.
Note:
• For audio output details and how to play back a tape with added sound on stereo 2, see p. 111.
Recording
Selecting the Built-in Microphone Sound
You can select the microphone sound to match the recording situation.
TAPE
+
CAMERA
,
TAPE
+
PLAY
(VCR)
*
* Only available when audio AUDIO DUB. has been set to MIC. IN.
VCR SET UP
(
MIC••••••••••NORMAL
20)
1. Open the VCR SET UP submenu and select MIC.
2. Select the setting and close the menu.
NORMAL:
VOICE:
W. SCREEN:
56
General recording.
When recording a person’s voice.
In windy places such as the beach or near buildings. Note that low sound may be
reduced together with the wind noise.
Adjusting the Audio Recording Level
E
The camcorder sets the audio recording level automatically when the REC LEVEL switch is set to A.
However, you can manually adjust the recoding level of the built-in microphone or an external
microphone connected via the MIC terminal or advanced accessory shoe (including microphones
connected via the optional MA-300 Microphone Adapter).
The camcorder is equipped with a audio level indicator at the side. You can also display the audio
level indicator on the LCD or viewfinder screen (open the menu, select DISPLAY SET UP and set
AUDIO LEVEL to ON).
Audio level indicator at the side of the camcorder:
Set to automatic:
Set to manual:
MANU
L
-dB 50 40
R
30
20
12 6 2 0
L
-dB 50 40
R
30
20
12 6 2 0
Audio level indicator on the LCD or viewfinder screen:
Set to automatic:
Set to manual:
2. Turn the L/R LEVEL dial to adjust the recording level.
• Adjust the level so that it slightly exceeds the 12-point (the larger 2 on the LCD or viewfinder
screen).
• Adjust the balance by turning the L/R LEVEL dial if necessary.
• Even if you turn down the LEVEL dial, the sound may be distorted if the input level is still too
high. Turn on the microphone attenuator in such case.
Recording
1. Slide the REC LEVEL switch to M.
Microphone Attenuator
Use the microphone attenuator if you need to lower the volume level or correct audio distortion of
the input audio during recording or audio dubbing. Monitor the level of the input sound with
headphones. If necessary, set the attenuator to ON in the VCR SET UP submenu of the CAMERA or
VCR menu.
57
Using the Custom Key
You can assign frequently used functions to the custom key (independently for TAPE CAMERA
mode, TAPE PLAY (VCR) mode, CARD CAMERA mode and CARD PLAY (VCR) mode). This allows
you to customize the camcoder to your recording situations.
E
Default settings:
TAPE CAMERA mode:
TAPE PLAY (VCR) mode:
CARD CAMERA mode:
CARD PLAY (VCR) mode:
INDEX WRITE
TV SCREEN
ZEBRA PATTERN
TV SCREEN
To check the current CSTM KEY setting in TAPE CAMERA or CARD CAMERA mode, open the menu,
select DISPLAY SET UP, GUIDE INFO and CUSTOM KEY. In TAPE PLAY (VCR) or CARD PLAY (VCR)
mode, open the menu, select DISPLAY SET UP and set CUSTOM KEY to ON. The current setting will
be displayed on the screen.
Recording
Functions listed below can be assigned to custom key.
* Functions with an asterisk can be operated only by the custom key.
TAPE + CAMERA
TAPE + PLAY (VCR)
Index Write*
Zebra Pattern
VCR Stop*
TV Screen
Microphone
Microphone Attenuator
Grip Zoom Speed
Handle Zoom Speed
Audio Level Indicator
AE Shift
Image Stabilizer
TV Screen
Microphone
Microphone Attenuator
Audio Attenuator
Audio Level Indicator
CARD + CAMERA
CARD + PLAY (VCR)
Zebra Pattern
TV Screen
Grip Zoom Speed
Handle Zoom Speed
AE Shift
Image Stabilizer
TV Screen
Changing the Custom Keys Setting
TAPE
+
CAMERA
,
TAPE
+
PLAY
(VCR)
,
CUSTOM KEY
(
20)
1. Open the menu and select CUSTOM KEY.
2. Select the function.
3. Close the menu.
58
CARD
+
CAMERA
,
CARD
+
PLAY
(VCR)
Operating the CSTM KEY Button
E
• A function assigned to a custom key is referred to as a button of that effect (e.g. “INDEX WRITE”
button).
Index Write
TAPE
+
CAMERA
You can add an index signal to your recording for easy search in VCR mode.
• You cannot add or erase the index signal later.
• You cannot use the “INDEX WRITE” button during photo nor interval timer recording.
• Index Write can be operated only by the CSTM KEY.
• While in record mode
Press the “INDEX WRITE” button and the index signal will be recorded for approximately 6 seconds.
During this time, “INDEX” appears in the viewfinder.
• While in record pause mode
1. Press the “INDEX WRITE” button and “INDEX” appears in the display.
2. Press the start/stop button to begin recording.
• The index signal will be recorded for approximately 6 seconds. INDEX dissappears after that time.
Zebra Pattern
TAPE
+
CAMERA
,
CARD
+
CAMERA
Recording
The zebra pattern is a series of diagonal stripes that appear in the display to highlight areas of
overexposure. Use it as a guide to set the aperture (iris) and shutter speed.
This function can also be selected from CAM. SET UP in the CAMERA or CARD CAMERA menu
(ZEBRA). The zebra pattern level can be adjusted in the same submenu (ZEBRA LEVEL) ( 85).
Press the “ZEBRA” button to display the zebra pattern. Press the button again to eliminate the
pattern.
• The camcorder does not record the zebra pattern. It only appears in the display.
VCR Stop
TAPE
+
CAMERA
You can turn the recorder section off and leave the camcorder section turned on. This allows you to
adjust the camcorder regardless of the 5-minute timer.
• VCR STOP can be operated only by the custom key.
Press the “VCR STOP” button to turn the recorder section off. Press the button again to return to
record pause mode.
59
TV Screen
E
TAPE
+
CAMERA
TAPE
,
PLAY
(VCR)
+
+
CARD
,
CAMERA
CARD
,
+
PLAY
(VCR)
You can display the information on the LCD screen/viewfinder on a connected TV.
Press the “TV SCREEN” button to display the information on the TV screen. Press the button again
to cancel.
Microphone
+
TAPE
CAMERA
+
TAPE
,
PLAY
(VCR)
*
* Only available when AUDIO DUB. has been set to MIC. IN.
Press the “MIC” button. Select the sound quality (NORMAL, VOICE, W. SCREEN) by pulling the
SELECT dial up or down and press the SELECT dial in.
Microphone Attenuator
TAPE
+
CAMERA
TAPE
,
+
PLAY
(VCR)
*
* Only available when AUDIO DUB. has been set to MIC. IN.
Recording
Use the microphone attenuator if, during recording or audio dubbing, you need to lower the
volume level or correct audio distortion via the microphone.
Press the “MIC ATT” button. Select ON or OFF by pulling the SELECT dial up or down and press the
SELECT dial in.
Grip Zoom Speed
TAPE
+
CAMERA
,
CARD
+
CAMERA
Press the “ZOOM GRIP” button. Select the grip zoom speed (VARIABLE, LOW, MEDIUM, FAST) by
pulling the SELECT dial up or down and press the SELECT dial in.
Handle Zoom Speed
TAPE
+
CAMERA
,
CARD
+
CAMERA
Press the “ZOOM HANDLE” button. Select the handle zoom speed (LOW, MEDIUM, FAST) by
pulling the SELECT dial up or down and press the SELECT dial in.
60
TAPE
Audio Level Indicator
+
CAMERA
,
TAPE
+
PLAY
(VCR)
E
Press the “AUDIO LEVEL” button to display the audio level indicator on the LCD screen/viewfinder.
Press the button again to cancel.
AE Shift
TAPE
+
CAMERA
CARD
,
+
CAMERA
• Only available when the recording program is set to AUTO, Tv or Av.
Press the “AE SHIFT” button to display the AE SHIFT menu. Pull the SELECT dial up or down and
select between –2.0 and +2.0. Press the SELECT dial in to close the menu.
Image Stabilizer
TAPE
+
CAMERA
,
CARD
+
CAMERA
Press the “Image Stabilizer” button to turn the image stabilizer on/off.
Audio Attenuator
TAPE
+
CAMERA
Use the audio attenuator if, during recording or audio dubbing you need to lower the volume level
or correct distortion of the input audio.
Press the “AUDIO ATT” button. Select ON or OFF by pulling the SELECT dial up or down and press
the SELECT dial in.
Recording
61
Using Digital Effects
Show your creativity by using the special effects and digital faders. These digital effects and faders
can add visual appeal and greater imaging variety.
E
Faders:
Start or end scenes on a tape with a fade to or from black ( 62).
Fade Trigger, Wipe*, Overlap*
Effects:
Add flavor to your recordings ( 65).
Black and White, Sepia, Art, Mirror, Mosaic, Strobe*, Trail*
Color Bars: You can display and record industry standard SMPTE color bars ( 67).
* Cannot be selected when the movie mode is set to FRAME or when a slow shutter is set (1/8,
1/15, 1/30).
Fader
Effects
Color Bar
TAPE CAMERA
Movie
Still Image
h
i
h
h
h
h
CARD CAMERA
Still Image
i
i
i
h= Available, i= Not available
Notes:
Recording
• When you do not wish to use digital effects, press the D.EFFECTS/BARS SELECT button and select
D.EFFECTS |. Press the D.EFFECTS/BARS ON/OFF button to close the menu.
• The camcorder retains the selected digital effect setting even if you turn the camcorder off.
• Digital effects can also be operated from the wireless controller.
Faders
Fade Trigger
The image gradually fades in. It gradually fades out
when you stop recording
Wipe
The camcorder retains the last recorded scene as a still
image before entering the record pause mode. When
you start recording, the movie appears from the right of
the screen until it fills the whole screen.
62
Overlap
E
The camcorder retains the last recorded scene as a still
image before entering the record pause mode. When
you start recording, the still image gradually changes to
the scene you are recording.
Operating the Fade Trigger
Sound and image fade together.
When operating faders in TAPE CAMERA mode, make sure the program selector is set to Q.
TAPE
+
CAMERA
FADER
(
FADER••••••• FADE-T
20)
1. Press the D.EFFECTS/BARS SELECT button.
• The digital effects menu appears.
2. Select FADER and press the SELECT dial in.
3. Select the FADE-T and press the D.EFFECTS/BARS SELECT button.
• The menu closes and FADE-T flashes in the display.
4. Press the D.EFFECTS/BARS ON/OFF button.
Recording
• FADE-T, WIPE and OVERLAP settings appear.
• The name of your selection stops flashing.
• Each time you press the D.EFFECTS/BARS ON/OFF button, the fader is activated (display lights
continuously) or deactivated (display flashes).
5. Press the start/stop button.
63
Operating Wipe and Overlap
E
When operating faders in TAPE CAMERA mode, make sure the program selector is set to Q.
TAPE
+
CAMERA
FADER
(
FADER••••••• OVERLAP
20)
1. Press the D.EFFECTS/BARS SELECT button.
• The digital effects menu appears.
2. Select FADER and press the SELECT dial in.
• FADE-T, WIPE and OVERLAP settings appear.
3. Select WIPE or OVERLAP and press the D.EFFECTS/BARS SELECT button.
• The menu closes and the name of the selected fader flashes in the display.
4. Press the D.EFFECTS/BARS ON/OFF button during recording.
• The name of your selection stops flashing.
• Each time you press the D.EFFECTS ON/OFF button, the chosen fader becomes activated
(display lights continuously) or deactivated (display flashes).
During recording
Recording
5. Press the start/stop button.
64
• The last scene is memorized as a still image and the camcorder goes into record pause mode.
6. Press the start /stop button.
• Recording starts, and the still image gradually changes to the scene you are recording.
Effects
E
Black and White (BLK & WHT)
The image becomes black and white.
Sepia
The image becomes monochrome with a brownish tint.
Art
The image becomes like a paint (solarization).
Creates a symmetrical image as if there would be a
mirror in the middle of the screen.
Recording
Mirror
Mosaic
The image is blurred through enlarging the size of some
pixels.
Strobe
The image is shown in a series of
still images, giving an effect
similar to slow-motion.
Trail
Moving the camcorder or moving subjects leave an
afterimage like a trail.
65
Operating the Effects
E
TAPE
+
CAMERA
EFFECT
(
EFFECT•••••••BLK&WHT
20)
1. Press the D.EFFECTS/BARS SELECT button.
• The digital effects menu appears.
2. Select EFFECT and press the SELECT dial in.
• The settings appear.
3. Select the effect setting and press the D.EFFECTS/BARS SELECT button.
• The menu closes and the name of the selected effect flashes in the display.
4. Press the D.EFFECTS/BARS ON/OFF button.
Recording
• The name of your selection stops flashing and the effect is activated.
• Each time you press the D.EFFECTS/BARS ON/OFF button, the effect becomes activated
(display lights continuously) or deactivated (display flashes).
66
Using the Color Bars
You can display and record industry standard SMPTE color bars.
E
Activating the Color Bars
TAPE
+
CAMERA
COLOR BARS
(
20)
1. Press the D. EFFECTS/BARS SELECT button.
• The digital effects menu appears.
2. Select COLOR BARS and press the SELECT dial in.
• The menu closes and COLOR BARS flashes in the display.
3. Press the D. EFFECTS/BARS ON/OFF button.
• The color bars appear in the display.
• Each time you press the D.EFFECTS/BARS ON/OFF button, the color bars are activated or
deactivated.
Recording
67
Using a Canon Speedlite for Flash Photography (Optional)
For SLR-style flash photography, attach a Canon Speedlite 220EX, 420EX or 550EX to the
camcorder’s accessory shoe.
Refer also to the Speedlite instruction manual.
E
Attaching the Speedlite
Turn the camcorder’s power off before
attaching/detaching the Speedlite.
Slide the Speedlite onto the accessory shoe and tighten
the shoe lock.
Operating the Speedlite
Recording
1. Turn the power of the Speedlite on.
•
•
•
•
Wait for the Speedlite to charge.
While the Speedlite is charging, a white S flashes in the display.
When the Speedlite is fully charged a green S lights up constantly in the display.
Replace the battery of the Speedlite if the white S continues to flash.
2. Press the PHOTO button to record the still image.
• Make sure that the Speedlite is charged before recording the still image. Although it is
possible to record while the Speedlite is still charging, the flash will not operate. The Speedlite
cannot charge while you are holding the PHOTO button halfway down.
• S disappears from the display while the camcorder records the still picture.
• If the S mark does not appear in the display when you turn the Speedlite on, make sure that
the Speedlite unit is slid fully onto the accessory shoe.
Notes:
• Turn the Speedlite unit off when you do not require a flash.
• You cannot use the Speedlite in following cases:
- In the MANUAL recording program.
- When exposure is locked (S turns off if you press the EXPOSURE dial in. It reappears when you
turn the lock off by pressing the EXPOSURE dial in again.)
• In the shutter-priority (Tv) mode, you can choose any shutter speed between 1/60 and 1/1000
and clear scan (card: between 1/60 and 1/500).
• Off-Camera Shoe and Connecting Cord for EOS models cannot be used with the GL2.
• The bounce flash on the 420EX and 550EX Speedlites cannot be used with the GL2.
• The 420EX/550EX’s multiple Speedlite control and the Speedlite Transmitter ST-E2 cannot be used
with the GL2.
• In dark recording situations, during autofocus, a assist light may be sent out by the Speedlite to
illuminate the subject while you hold the camcorder’s PHOTO button halfway down.
68
Recording with the Interval Timer
With the interval timer, you can record images over a selected time with a selected interval. This
function is useful when shooting flowers, animals, and other natural events.
You can select an interval of 30 seconds, 1 minute, 5 minutes or 10 minutes, and a recording time
of 0.5 seconds, 1 second, 1.5 seconds, or 2 seconds.
E
Example: 2 seconds recording time at a 5 minutes interval
(= standby time of 5 minutes including the recording time of 2 seconds)
2 sec.
4 min. 58 sec.
Record
Interval time
5 min.
2 sec.
4 min. 58 sec.
Record
Interval time
5 min.
Default setting:
Recording time: 0.5 seconds
Interval time: 30 seconds
TAPE
+
CAMERA
CAM.SET UP
(
INTERVAL
INTERVAL T.• ON
20)
REC TIME•••• 0.5sec
Recording
INTERVAL•••• 30sec
1. Slide the POWER switch to CAMERA and the TAPE/CARD switch to TAPE.
• Load a cassette.
2. Open the CAM. SET UP submenu and select a INTERVAL.
• The interval timer menu appears.
3. Select INTERVAL T. and set it to ON.
• You return to the interval timer menu.
4. Select INTERVAL and set the interval.
• You return to the interval timer menu.
5. Select REC TIME and set the recording time.
6. Close the menu.
7. Press the start/stop button to start recording.
• The interval recording starts and INT T. appears in the display.
• When the interval time is set to 30 seconds or 1 minute, the camcorder enters into record
pause mode between recordings. When it is set to 5 or 10 minutes, the camcorder stops
between recordings.
69
Pausing the Interval Recording
E
Press the Start/Stop button.
• The camcorder returns to record pause mode and INT T. flashes in the display.
• Press the Start/Stop button again to restart recording.
Ending the Interval Recording
Set the camcorder to record pause mode and set INTERVAL T to OFF in the
interval menu.
Note:
Recording
• The remaining tape display may not appear.
70
Recording with the Self-Timer
For stills
E
START
/STOP PHOTO
SELF
TIMER MENU
For movies
STANDBY LOCK
MENU
This is useful when you wish to include yourself in the picture when recording movies or still
images to tape or memory card.
TAPE
+
CAMERA
,
CARD
+
CAMERA
1. Open the menu, select VCR SET UP and set the SELF-TIMER to ON
or
press the SELF TIMER button on the wireless controller.
• SELF T. appears in the display.
• To have the subject monitor recording, rotate the LCD panel 180° (
44).
2. Press the start/stop button.
• The camcorder starts to record after a 10-second countdown period (or after 2 seconds when
you use the wireless controller). The time remaining counts down in the display (e.g. “5
SEC”).
• SELF T. disappears from the display when recording begins.
• The tally lamp starts flashing.
Recording
For movies
3. Press the start/stop button to end recording.
For still images
2. Press the PHOTO button on the camcorder body or the wireless controller.
• The camcorder automatically adjusts the focus 2 seconds before the countdown is complete.
The F mark flashes white then turns green after the focus and exposure are set. If you are
using the wireless controller, the F mark starts flashing immediately after you press the
PHOTO button.
• The camcorder takes the still image for approximately 6 seconds.
• In TAPE CAMERA mode, the camcorder returns to record pause mode after recording to a
tape. In CARD CAMERA mode, the currently recorded image appears after recording onto a
memory card.
Notes:
• To cancel the self-timer setting, set the SELF-TIMER to OFF through the menu, or press the SELFTIMER button on the wireless controller.
• To cancel the countdown of the self-timer, press the start/stop button (when recording a movie)
or PHOTO button (when recording a still image).
71
Using the DV Control
When another device such as a camcorder or a video recording device is connected to the GL2 via a
DV cable, you can operate the other device (record and pause recording) by pressing the start/stop
button on the GL2.
E
TAPE
+
CAMERA
SYSTEM
(
DV CONTROL•• OFF
20)
1. Open the menu and select SYSTEM.
2. Select DV CONTROL, set it to ON and close the menu.
Pressing the start/stop button:
A. When the GL2 is in record pause mode:
GL2: Recording
Connected device: Recording
B. When the GL2 is Recording:
GL2: Record Pause Mode
Connected device: Record Pause Mode
C. When the GL2 is not ready for recording (no cassette loaded etc.)
Recording
Connected device: Recording/Record pause mode
D. After loading a cassette while the connected device is recording:
GL2: Recording
Pressing the start/stop button again:
GL2: Record pause mode
Connected device: Continues recording
Connected device: Record pause mode
When the connected device is recording, [REC] appears in the display of the camcorder. When it is
stopped, [STOP] appears. When the other device is in any other mode than the recording, record
pause or stop mode, [- - -] appears. [DV IF] flashes if DV CONTROL is set to ON and no device is
connected via the DV cable.
Notes:
• When the GL2 stops recording without operating the start/stop button (e.g. tape has reached the
end) while both the GL2 and the connected device are recording, the connected device continues
recording.
• When connecting two GL2s via a DV cable, make sure to set DV CONTROL of the “connected
device” to OFF.
• Only one device can be connected to the GL2 for DV control.
• DV control may not work properly depending on the connected device.
• The DV control setting is retained by the camcorder even if you turn the power off. Make sure to
check the setting after use of the DV control function, as the tape in the connected device may
be overwritten.
• Do not use a DV cable longer than 14 ft 91/8 in (4.5 m).
72
Using the VL-3 Video Light (Optional)
1
E
LOCK
1
K
LOC
LOCK
TO ON
AU
OF
LO
F
CK
3
Using the optional Video Light enables you to record even in dark rooms. This VL-3 Video Light
attaches to the camcorder’s
advanced accessory shoe for cable-free operation and is powered
by the camcorder’s power supply.
Refer to the VL-3 Video Light instructions for further details.
Turn the camcorder’s power off before attaching/removing the Video Light.
1. Slide the Video Light onto the accessory shoe and tighten the shoe lock.
• Insert the Video Light oriented in the direction indicated by the arrow on the bottom until it
clicks.
• Be careful not to pull off the Video Light when fastening the screw.
2. Set the camcorder to TAPE CAMERA mode or CARD CAMERA mode.
• C (Connection) appears in the display.
• ON: The Video Light stays on.
• AUTO: The Video Light turns on/off automatically according to the level of brightness of the
shooting conditions. In MANUAL recording program: If the Video Light was on at the time
you switched to MANUAL, it stays on. If it was off at the time you switched to MANUAL, it
stays off.
Recording
3. Turn the Video Light’s power switch to AUTO or ON.
Cautions:
• Be careful not to touch the bulb or the surrounding area during or immediately after use; it
becomes very hot. Keep the Video Light away from flammable or plastic materials.
• Do not look directly at the bulb while the Video Light is on.
• Never carry the camcorder holding the Video Light.
73
Using the DM-50 Microphone (Optional)
E
The high sensitive Directional Stereo Microphone DM-50 attaches to the
advanced accessory
shoe for cable-free operation and is powered by the camcorder’s power supply. Use it when
recording or dubbing audio.
Refer to the DM-50 Microphone instructions for further details.
Turn the camcorder’s power off before attaching/removing the microphone.
1. Slide the microphone onto the accessory shoe and tighten with the shoe lock.
• Insert the microphone oriented in the direction indicated by the arrow on the bottom until it
clicks.
• Be careful not to pull off the microphone when fastening the screw.
Recording
2. Set the camcorder to TAPE CAMERA mode.
• C (Connection) appears in the display.
3. Set the microphone’s directivity switch.
SHOTGUN: For recording clear sound from the front (monaural).
STEREO 1: For recording sound from the front and surrounding area.
STEREO 2: For recording surrounding sound in a wider range than in STEREO 1.
Notes:
• Never carry the camcorder holding the microphone.
• The DM-50 will not pick up any sound if another microphone is attached to the camcorder’s MIC
terminal.
74
Using the MA-300 Microphone Adapter (Optional)
E
The MA-300 Microphone Adapter enables you to input audio to the camcorder with XLR connector
equipped microphones, and to convert video signals for the BNC connector.
Refer to the MA-300 Microphone Adapter instructions for further details.
Attaching the Microphone Adapter to the Camcorder
Turn the camcorder off before attaching/detaching the microphone adapter.
1. Slide the microphone adapter straight onto the camcorder’s accessory shoe.
2. Tighten the shoe lock in the direction of the arrow.
Attaching the Microphone
Recording
• Orient the microphone adapter in the direction indicated with an arrow on the bottom side
and slide it in until it clicks.
Microphone with a diameter of 25 mm can be attached directly to the microphone adapter.
Depending on how you attach the microphone, it may pick up some vibration noise.
1. Loosen the microphone clamp screw and open the microphone clamp.
2. Place the microphone into the microphone clamp and tighten the clamp screw.
• Position the microphone so that it does not appear on the camcorder’s LCD or viewfinder
screen.
3. Connect the microphone to the audio input jack.
4. Turn the camcorder’s power on.
• C (connection) appears on the camcorder’s LCD or viewfinder screen when the camcorder is
in record or record pause mode.
• The camcorder’s built-in microphone automatically turns off.
Notes:
• The accessory shoe of the microphone adapter is for exclusive use with microphones attached to
a camera-mount.
• To output video signals via the BNC connector, connect the supplied video cable to the VIDEO IN
terminal and the camcorder’s AV terminal.
75
Adjusting the Exposure Manually
E
EXP
1. Set the recording program to MANUAL.
2. Press the EXP dial in.
• An arrow appears next to the shutter speed
value.
shutter
speed
iris
no
display
gain
3. Pull the EXP dial up or down to increase
or decrease the shutter speed.
Recording
• You can select between 30 shutter speeds (1/8
to 1/15000) in TAPE CAMERA mode and 15
shutter speeds (1/60 to 1/720) in CARD
CAMERA mode.
• See “About the Shutter Speeds” ( 77).
4. Press the EXP dial in.
• The arrow moves next to the F number.
5. Pull the EXP dial up or down to open or close the iris.
• You can select between 19 aperture values (f/1.6 to f/8) in TAPE CAMERA mode and 17
aperture values (f/2.0 to 1/8) in CARD CAMERA mode, or close the iris completely.
• See “About the Iris” ( 77).
6. Press the EXP dial in.
• The arrow moves to the gain value.
7. Pull the EXP dial up or down to increase or decrease the gain.
• Set the gain to 0 dB, +6 dB, +12 dB or +18 dB in TAPE CAMERA mode or 0 dB, +6 dB or
+12 dB in CARD CAMERA mode.
• See “About the Gain” ( 77).
Notes:
• The shutter speed, F number and gain values will be reset if you slide the POWER switch to OFF.
If you use the standby lever, the camcorder retains your chosen values.
• A bar showing the standard exposure appears in the display.
• You can also adjust the exposure manually in the Auto, Tv and Av modes, but you have to first
lock the exposure to adjust shutter speed and iris.
76
● About the Shutter Speeds
E
Pull the EXP dial toward + for a slower shutter speed, or toward – for a faster shutter speed.
Available shutter speeds in TAPE CAMERA mode:
1/8 sec
1/15 sec
1/30 sec
1/60 sec
1/75 sec
1/90 sec
1/100 sec
1/300 sec
1/250 sec
1/210 sec
1/180 sec
1/150 sec
1/120 sec
1/360 sec
1/420 sec
1/500 sec
1/600 sec
1/720 sec
1/840 sec
1/2300 sec
1/2000 sec
1/1700 sec
1/1400 sec
1/1200 sec
1/1000 sec
1/2600 sec
1/3000 sec
1/4000 sec
1/8000 sec
1/15000 sec
CS
Available shutter speeds in CARD CAMERA mode:
1/60 sec
1/75 sec
1/90 sec
1/100 sec
1/120 sec
1/150 sec
1/420 sec
1/360 sec
1/300 sec
1/250 sec
1/210 sec
1/180 sec
1/500 sec
1/600 sec
1/720 sec
● About the Iris
Available F numbers in TAPE CAMERA mode:
F1.6*
F1.8*
F2*
F2.2*
F2.4*
F2.6*
F2.8
F3.2
F6.2
F5.6
F5.2
F4.8
F4.4
F4
F3.7
F3.4
F6.7
F7.3
F8
CLOSE
Recording
Pull the EXPOSURE dial toward + for a shorter depth of field, or toward – for a greater depth of
field.
Available F numbers in CARD CAMERA mode:
F2*
F2.2*
F2.4*
F2.6*
F2.8
F3.2
F3.4
F3.7
F7.3
F6.7
F6.2
F5.6
F5.2
F4.8
F4.4
F4
F8
CLOSE
* May not be available depending on the zoom position.
● About the Gain
Pull the EXPOSURE dial toward + to increase the gain, or toward – to decrease the gain.
Available gain values in TAPE CAMERA mode: 0 dB, +6 dB, +12 dB, +18 dB
Available gain values in CARD CAMERA mode: 0 dB, +6 dB, +12 dB
77
Exposure Lock/Adjustment
E
●Exposure lock
Lock the exposure at the current level in order
to control the brightness of the image.
To lock the exposure, press the EXP dial in.
Press it again to return to the automatically set
exposure level.
EXP
Notes:
• You cannot lock the exposure in the [ (Easy Recording) or MANUAL recording program.
• The standard exposure level depends on which recording program you have selected, but the
shutter normally operates at 1/60 of a second.
• The brightness of the subject may change if you zoom during exposure lock.
• If you slide the POWER switch to OFF or the standby lever to LOCK, the camcorder resets to auto
exposure.
Recording
●Exposure adjustment
When the exposure is locked, you can adjust it
manually, making the picture brighter or
darker in order to deal with difficult lighting
conditions, or to manipulate the mood of the
scene. The camcorder’s iris can be manually set
to any position from fully closed to fully open.
To make the recorded image brighter, pull the
EXP dial up (to a maximum of +11).
This may be necessary if the background is
very bright, or if the subject is lit from behind.
To make the recorded image darker, pull the
EXP dial down (to a minimum of –11). This
may be necessary if the background is very
dark, or if the subject is spotlit.
78
EXP
E.LOCK ±0
E.LOCK +11
E.LOCK ±0
E.LOCK –11
Adjusting the Focus Manually
The camcorder focuses automatically. All you have to do is point, and whatever is in the center of
the display will usually be in sharp focus. If it does not seem to be focusing well, it may be because
the subject is not suitable for autofocus ( 144). Also, if you attach a filter other than UV or ND,
the autofocus may not work effectively.
E
1. Slide the program selector to Q.
2. Push the FOCUS A/M button so that
MF appears in the display.
3. Using the zoom lever, zoom all the
way in to the telephoto end.
4. Rotate the focusing ring to adjust
the focus.
FOCUS
A/M
5. Use the zoom lever to reframe the
subject.
• To resume autofocus, press the FOCUS
A/M button again.
Notes:
Recording
• The picture in the LCD screen may appear out of focus when shooting in dark conditions.
• When zooming during manual focus, zoom out wide after setting the focus at the telephoto end.
• The focus may be thrown off if you zoom into telephoto after setting the focus at the wide angle
end.
• Autofocus is recommended for zooming in to telephoto from the wide end.
• If you slide the POWER switch to OFF or the standby lever to LOCK, the camcorder resets to auto
focus.
79
Setting the White Balance
The camcorder’s auto white balance system
compensates for a wide range of lighting
conditions. Although slight variations are
unavoidable, colors will appear natural in
virtually every situation.
E
In some cases, you will get better results by
setting the white balance yourself, or using
one of the two preset modes:
W.BALANCE
SELECT
x Indoor Mode
• Under halogen or studio/video lighting
• Subject is of one dominant color
• Close-ups
UOutdoor mode
• In daylight, especially for close-ups and
when the subject is of one dominant color
TAPE
+
CAMERA
,
CARD
+
CAMERA
Recording
1. Set the program selector to Q.
80
2. a) For auto, indoor or outdoor white balance, press the W. BALANCE SELECT
button.
• x/U appears in the display when you set the white balance to the indoor/outdoor mode.
b) For setting the white balance manually:
q Point the camcorder at a white object (such as a sheet of paper) and zoom in until it fills the
display.
w Press the W. BALANCE SELECT button.
• W appears in the display.
e Press the WHITE BALANCE W set button.
• W flashes quickly in the display and then remains lit, to show that the camcorder has set
the white balance.
• Depending on the light source, the flashing may at times change to a slower speed, rather
than remaining lit. The result will remain better than with the auto setting, and you can
continue recording.
Setting the white balance manually will probably work better than auto white balance when
shooting:
E
Subjects with one dominant color, such as sky, sea or forest
Close-ups
In rapidly changing lighting conditions
In places lit by certain types of fluorescent or mercury vapor lights
Recording
Notes:
• Turn the digital zoom off (if necessary) to set a more accurate white balance.
• If the lighting conditions change, reset the white balance by first returning to the auto setting,
and then reselecting the manual balance.
• Try to record with light from a single source. Correct white balance cannot be obtained for two
types of lighting at once.
• You cannot set the white balance manually or use the indoor/outdoor modes when the program
selector is set to the [ (Easy Recording) program.
• The camcorder returns to auto white balance when the program selector is set to [ (Easy
Recording).
• When you turn the camcorder on, the white balance returns to auto white balance. If you then
press the WHITE BALANCE W button, the camcorder will remember your last setting.
• If you shoot with studio/video lighting, use the x (indoor) mode.
• During normal outdoor shooting, setting the camcorder to auto white balance may provide
better results.
81
Using AE Shift
By controlling the level of the automatic exposure (AE) function, you can lighten or darken the
image slightly. This allows you to compensate for backlit, overexposed scenes.
E
TAPE
+
CAMERA
,
CAM. SET UP
(
CARD
+
CAMERA
AE SHIFT•••• ±0
20)
1. Set the recording program to Auto, Tv or Av.
Recording
2. Open the menu and select AE SHIFT.
3. Pull the SELECT dial up or down and select the desired level.
• Levels are from –2 to +2, in 0.25 intervals (excluding –1.75 and +1.75).
• The higher the setting, the brighter the image.
4. Close the menu.
Note:
• AE shift cannot be operated in the Easy, Manual, Sand & Snow or Spotlight recording programs.
82
Using the Custom Preset
You can adjust the color gain, color phase, sharpness and setup level for more creative recordings.
E
Setting the Custom Preset Functions
When you adjust the custom preset functions, be sure to check the picture before you start
recording. You can save these settings under the CSTM PRESET button.
TAPE
+
CAMERA
,
CARD
+
CAMERA
CSTM PRESET
(
20)
1. Open the menu and select CSTM PRESET.
• The custom preset menu appears.
2. Select the function you wish to adjust.
3. Adjust the selected function.
• See below details on each function.
• Repeat steps 2 and 3 to adjust other functions as needed.
4. Close the menu.
• The settings are saved until new changes are made.
CSTM PRESET
(
COLOR GAIN•• -
+
Recording
Adjusting the Color Gain
20)
Adjust toward + for a deeper color, and toward – for a lighter color.
Adjusting the Color Phase
CSTM PRESET
(
COLOR PHASE• G
R
20)
Adjust toward R for a redder picture, and toward G for a greener picture.
Adjusting the Sharpness
CSTM PRESET
(
SHARPNESS••• -
+
20)
Adjust toward + for a sharper picture, and toward – to soften the contour.
83
Adjusting the Setup Level
E
CSTM PRESET
(
SETUP LEVEL• -
+
20)
Adjust toward + for a brighter picture, and toward – for a darker picture.
Activating the Custom Preset Functions
1. Turn the program selector to Q.
2. Press the CSTM PRESET button.
Recording
• The picture reflects your preferences.
84
Using the Zebra Pattern
E
The zebra pattern is a series of diagonal stripes that appear in the viewfinder to highlight areas of
overexposure. Use it as a guide to set the aperture (iris) and shutter speed.
You can also select the pattern appearance level from 80, 85, 90, 95, and 100%.
Selecting the Zebra Pattern Level
TAPE
+
CAMERA
,
CARD
+
CAM. SET UP
(
CAMERA
ZEBRA LEVEL• 90
20)
2. Select ZEBRA LEVEL and select the level.
3. Close the menu.
Recording
1. Open the menu and select CAM. SET UP.
Activating the Zebra Pattern
TAPE
+
CAMERA
,
CAM. SET UP
(
CARD
+
CAMERA
ZEBRA••••••• OFF
20)
1. Open the menu and select CAM. SET UP.
2. Select ZEBRA LEVEL and set it to ON.
3. Close the menu.
Note:
• The camcorder does not record the zebra pattern, it is only shown in the display.
85
Recording PC Screens and Other Screens Using CLEAR SCAN
You can use the Clear Scan function to record PC screens or other screens without black bands
caused by differences in the field frequencies of screens.
E
TAPE
+
CAMERA
CAM. SET UP
(
CLEAR SCAN•• 60.5Hz
20)
1. Set the recording program to Tv or MANUAL.
2. Pull the EXP dial down until CS appears in the display.
3. Open the menu and select CAM. SET UP.
4. Select CLEAR SCAN and adjust the frequency so that no black bands appear in
the display.
• You can select between 120 frequencies between 60.5Hz and 201.5Hz.
5. Close the menu.
Recording the Display Information
Recording
You can record the information (such as date and time) displayed on the LCD screen/viewfinder
superimposed on the picture.
Unlike the data code, you cannot hide the display information at a later time.
SYSTEM
(
CHAR. REC••• OFF
20)
TAPE
+
PLAY
(VCR)
1. Open the menu and select SYSTEM.
2. Select CHAR. REC, set it to ON and close the menu.
Note:
• Once you set it to ON, the information will remain recorded with the picture until you select OFF.
Note that you cannot hide the information at a later time.
86
Playing Back a Tape
E
/
CARD TAPE
You can use the LCD screen for instant, on-the-spot playback. The camcorder also plays back the
sound track via the built-in speaker ( 89).
• When you play back a tape, you can also close the LCD panel with its screen side facing outward.
• When you’re using the viewfinder to view playback, close the LCD panel.
For playing back your recordings on a TV, see p. 95.
For using the wireless controller, see p. 29.
Note:
• To avoid accidental recording, make sure that you slide the tab on the cassette so that it exposes
the hole (the switch position is usually labeled SAVE or ERASE OFF).
TAPE
+
PLAY
(VCR)
1. Slide the POWER switch to PLAY (VCR) and TAPE/CARD switch to TAPE.
2. Load the cassette.
3. Press the e (play) button to start playback.
•
•
•
•
•
Playback
• The power indicator lights up green.
• The confirmation beep sounds.
Open the cover to use the buttons on the handle.
To end playback, press the 3 (stop) button.
To wind the tape forwards, stop playback and press the 1 (fast forward) button.
To wind the tape backwards, stop playback and press the ` (rewind) button.
If the playback picture is rough (mosaic-like noise), clean the video heads using a Canon DVMCL Digital Video Head Cleaning Cassette or a commercially available digital video head
cleaning cassette.
87
Other Playback Modes
E
Playback pause
Press the a (pause) button. To resume normal playback, press it again, or press the e (play) button.
The camcorder automatically goes into stop mode after about 5 minutes’ playback pause.
Fast forward playback
To play back the recording at about 9.5 times normal speed, press and hold the 1 (fast forward)
button during normal playback or press and hold the 1 (fast forward) button during normal fast
forward.
Rewind playback
For reverse playback at about 9.5 times normal speed, press and hold the ` (rewind) button
during normal playback or press and hold the ` (rewind) button during normal rewind.
Special Playback
Frame Advance
To play back frame by frame, press the +/ ae button
repeatedly during playback pause.
Press and hold to play back continuous frame advance.
Frame Reverse
REW
PLAY
FF
–/
STOP
+/
PAUSE
SLOW
×2
Playback
To play back in reverse frame by frame, press the –/4a
button repeatedly during playback pause.
Press and hold to play back continuous frame reverse.
Slow Forward Playback
To play back at about 1/3 normal speed, press the SLOW M button during normal playback.
Press the PLAY e button to return to normal playback.
Slow Reverse Playback
To play back in reverse at about 1/3 normal speed, press the –/4a button and then the SLOW M
button during normal playback.
Press the PLAY e button to return to normal playback.
88
Built-in Speaker and Headphone Terminal
E
The camcorder has a built-in speaker and a headphone terminal. You can listen to the sound
during playback. Use the speaker or headphones when using the LCD screen for playback, and use
headphones when using the viewfinder. The built-in speaker is monaural; use headphones for
stereo sound.
Built-in Speaker
Adjust the speaker and headphone volume by pulling the SELECT dial up or
down.
•
•
•
•
•
Pull the SELECT dial up to increase the volume, and down to decrease the volume.
A volume bar appears in the display to indicate the current volume. It disappears in 4 seconds.
You can turn off the volume completely by pulling the SELECT dial down until OFF appears.
You can also adjust the headphone volume separately from the built-in speaker.
The levels you adjust for the built-in speaker and headphones are memorized separately. The
camcorder retains the levels even if you slide the POWER switch to OFF.
Notes:
Playback
• The speaker turns off when you use headphones.
• Sometimes audio may sound distorted when the volume is turned up high. If this happens, turn
down the volume.
89
Displaying Date, Time and Camcorder Data (Data Code)
A data code containing the date and time the recording was made and other camcorder data
(shutter speed and exposure settings) is automatically recorded on a special data section of the
tape.
• Only the date and time appear in the data code when using a memory card.
E
DATA
CODE
During TAPE PLAY (VCR) mode, the data code can be displayed or hidden while the camcorder is in
play, slow or still mode.
Camcorder data may be displayed as “– – –” during fast forward, rewind, reverse playback,
forward and reverse ×2 playback.
Press the DISPLAY/DATA CODE button. When using a cassette, press it while the
camcorder is in play, slow or still mode.
• Press it once to display, once more to hide it.
Playback
Selecting Date/Time
Select whether you want the date, the time, or both to show up on your data code display.
TAPE
+
PLAY
(VCR)
,
DISP.SET UP
(
CARD
+
PLAY
(VCR)
D/TIME SEL.• DATE & TIME
20)
To change the date and time combination, open the menu and select DISP.SET UP.
Then select D/TIME SEL., set it to DATE, TIME or DATE & TIME and close the menu.
90
Setting the Data Code
E
You can also choose to display the camcorder data (shutter speed and exposure settings) in the
data code.
TAPE
+
PLAY
(VCR)
DISP.SET UP
(
DATA CODE••• DATE/TIME
20)
Open the menu and select DISP.SET UP. Then select DATA CODE, set it to
DATE/TIME, CAMERA DATA or CAM. & D/T and close the menu.
Available data code combinations in TAPE PLAY (VCR) mode :
D/TIME SEL.
DATA CODE
(cassette
only)
Date/Time
Date/Time &
Camera data
JAN. 1,2002
12dB
F11
1/250
12dB
F11
1/250
JAN. 1,2002
12:00:00 AM
12dB
F11
1/250
12dB
F11
1/250
12:00:00 AM
12:00 AM
JAN. 1,2002
12dB
F11
1/250
12dB
F11
1/250
12:00 AM
JAN. 1,2002
Date
Time
Date & Time
Camera data
Only Date & Time display is available in CARD PLAY (VCR) mode.
Notes:
Playback
• The data code will read “– – –” in the following situations:
– During playback of a blank section of tape.
– If the tape was recorded before entering the date and time in the camcorder’s memory.
– If the tape was recorded on a camcorder without a data code function.
– If noise or tape damage prevents the data code from being read.
• If a recording made on the GL2 is played back on a different DV camcorder, the data code may
not be displayed correctly.
• The data code will appear in the display even if DISPLAYS ( 150) has been set to OFF through
the menu.
91
Six-second Auto Date
E
The date can be displayed for 6 seconds when you start playback, or to indicate that the date or
time zone of the recording has changed. The 6-second auto date automatically adjusts to the time
zone you have selected.
TAPE
+
PLAY
(VCR)
DISP.SET UP
(
6SEC.DATE••• OFF
20)
To turn the 6-second auto date on, open the menu and select DISP.SET UP. Select
6SEC. DATE, set it to ON and close the menu.
Note:
Playback
• The 6-second auto date appears even if DISPLAYS is set to OFF in the menu and the data code is
turned off.
92
Searching the Tape (Photo Search/Date Search/Index Search)
E
ZERO SET SEARCH
MEMORY SELECT
AUDIO
DUB.
REW
PLAY
FF
AV
INSERT
–/
STOP
+/
REMOTE SET PAUSE
SLOW
×2
This allows you to move quickly through still images (photo search), between different days or areas
of recording (date search), or index signals ( 59) recorded anywhere on a tape (index search).
TAPE
+
PLAY
(VCR)
1. Press the SEARCH SELECT button to select between photo/date/index search.
• PHOTO SEARCH, DATE SEARCH or INDEX SEARCH appears for 4 seconds.
2. Press the - and + buttons to move backwards or forwards through the still
images, between different days of recording or recorded index signals.
Notes:
Playback
• Press once to move to the start of the previous/next still image, day or index on the tape.
• You can press more than once to move to the corresponding still image, day or index (up to a
maximum of 10 times), e.g. press the + button 5 times to move forward 5 still images, days
or index signals.
• PHOTO SEARCH/DATE SEARCH/INDEX SEARCH appears in the middle of the display alongside
the - or + mark and number to search through. You can change the direction easily by
pressing the button for the opposite direction.
• Press 3 (stop) to stop searching.
• If you begin a search very close to the start of a recorded still image during photo search, the
camcorder may skip straight past it.
• When you have set the time zone, date search also looks for the change in date based on the
adjusted time.
• A date/time zone cannot be identified if the total recording time on that day/time zone was less
than 1 minute.
• Date/index search playback may start slightly before or after the beginning of the located section.
• If the data code is not displayed correctly you will not be able to operate the date search correctly.
93
Returning to a Pre-Marked Position (Zero Set Memory)
E
ZERO SET SEARCH
MEMORY SELECT
AUDIO
DUB.
REW
PLAY
FF
AV
INSERT
–/
STOP
+/
REMOTE SET PAUSE
SLOW
×2
Use the wireless controller to mark a point on a tape to which you wish to return following the
playback.
TAPE
+
CAMERA
,
TAPE
+
PLAY
(VCR)
1. Press the ZERO SET MEMORY button on the wireless controller during playback
at a point you wish to return to later.
• The time code is replaced by a tape counter that is set to zero with the  indication.
• Press the ZERO SET MEMORY button once more to cancel the zero set memory.
2. When you have finished playback, rewind or fast forward the tape. The tape
stops automatically when it reaches the zero set position.
Playback
• `RTN or RTN1 appears in the display.
• The tape counter with  indication disappears from the display and the time code reappears.
94
Notes:
• The zero set memory may not function correctly when there is a break between recordings on the
tape.
• You can also use zero set memory to mark a position on a tape in TAPE CAMERA mode. When
you then play back the tape, pressing rewind will take you back to the pre-marked position.
• If you remove the tape while the zero set memory is set, the memory is canceled and the tape
counter reverts to time code.
Connections for Playback on a TV Screen
For higher picture quality, we recommend playing back recordings on a TV with an S (S1) terminal.
If you connect the camcorder to a TV with an S1 terminal or the Video ID-1 system, recordings
made in the 16:9 mode for wide screen TVs will be automatically played back in wide screen mode
on the TV screen.
E
See your TV or VCR instruction manual for further details.
If Your TV (or VCR) Has an S-video Input Terminal
STV-250N Stereo Video Cable
L
AUDIO
R
VIDEO
S-VIDEO
S-150 S-video Cable
• Use the S-150 S-video Cable to connect the S-video terminals. Use the STV-250N Stereo Video
Cable to connect the AUDIO terminals. Connect the white plug to the white AUDIO terminal L
(left). Connect the red plug to the red AUDIO terminal R (right). Do not connect the yellow plug.
• Set the TV/VIDEO selector on the television to VIDEO.
• If you are connecting the camcorder to a VCR, set the input selector on the VCR to LINE.
Playback
95
If Your TV (or VCR) Has Audio/Video Input Terminals
E
STV-250N Stereo Video Cable
L
AUDIO
R
VIDEO
• Connect the camcorder using the STV-250N Stereo Video Cable. Connect the white plug to the
white audio terminal L (left). Connect the red plug to the red audio terminal R (right). Connect
the yellow plug to the yellow video terminal VIDEO.
• Set the TV/VIDEO selector on the television to VIDEO.
• If you are connecting the camcorder to a VCR, set the input selector on the VCR to LINE.
Note:
Playback
• If you are going to use the TV as a monitor while you are shooting, remember to keep the TV
volume turned down as long as the camcorder’s audio terminals are connected to prevent
feedback.
• If your TV is already connected to a VCR, you can connect the camcorder to the VCR instead of
the TV. Follow the instructions above.
96
Editing to a VCR
E
Playback the tape on
the camcorder.
STV-250N Stereo Video Cable
L
AUDIO
R
VIDEO
S-150 S-video Cable
S-VIDEO
Record the scenes on
the VCR.
By connecting the camcorder to a VCR, you can edit your recordings in order to remove unwanted
scenes, or to combine different shots to create your own video productions.
Preparations
1. Connect the camcorder to the VCR.
• See “Connections for Playback on a TV screen” (
95).
2. Prepare the TV and VCR.
• Turn on the TV and set the TV/VIDEO selector to VIDEO.
• Turn on the VCR, and set its input selector to LINE. Load a blank cassette, and put the VCR in
record pause mode.
• See your TV and VCR instruction manuals for details.
3. Slide the POWER switch to PLAY (VCR) and the TAPE/CARD switch to TAPE.
Editing
1. Find a point on your recorded cassette slightly before the section you wish to
copy.
2. Start to play it back while you monitor the picture on the TV.
4. Pause the VCR at the end of the section you wish to copy, then stop playback
on the camcorder.
Editing
3. Start recording on the VCR as soon as the section you wish to copy appears on
the screen.
5. Repeat steps 1 to 4 until your edited recording is complete.
Note:
• The quality of the edited tape will be slightly lower than that of the original.
97
m (LANC) terminal
E
The m terminal allows you to connect compatible
devices such as remote controllers that are m LANC
compatible. Some buttons on editing equipment may
operate differently from those on the camcorder.
Notes:
Editing
• m (LANC) is a trademark. It stands for Local Application Control Bus System.
• We cannot guarantee the results when connecting to equipment not bearing the LANC m
symbol.
98
Dubbing to/from a Tape with Digital Video Equipment
Digital video equipment fitted with the DV terminal allows you to edit, copy and transfer data
digitally, with virtually no generation loss in image and sound quality. The DV terminal is for both
line-in and line-out, since a single DV cable can handle data in both directions.
• If a digital VCR is connected and an anomalous signal is sent from the VCR, the images recorded
on the tape may also be anomalous (although it may not appear so on the TV image), or not
recorded at all.
• You cannot dub tapes recorded with the copyright protective signal.
E
REC SEARCH
PAUSE SELECT
/
ZERO SET
MEMORY REW
PLAY
FF
AUDIO
DUB.
STOP
+/
–/
AV
INSERT PAUSE
SLOW
×2
: Signal flow
Preparations
Example dubbing to the camcorder
1. Connect the camcorder and the other digital device.
• Connect the Canon CV-150F DV cable (optional).
2. Prepare the other device.
• Turn on the power and load a recorded cassette.
3. Slide the camcorder’s POWER switch to PLAY (VCR) and the TAPE/CARD switch
to TAPE.
• DV IN appears in the display.
Editing
4. Load a blank cassette.
99
Dubbing
E
1. Find a point on your recorded cassette slightly before the section you wish to
copy and set it to playback pause mode.
2. Press the camcorder’s REC PAUSE button.
• The camcorder enters record pause mode.
3. Start playback on the other digital device while you monitor the picture.
4. Press the e/a (play/pause) button on the camcoder or the PAUSE a button on
the wireless controller.
• Recording starts.
5. When you get to the point where you wish to stop recording, press the stop
button or the pause button.
• Recording stops.
6. Stop playback on the other device.
Notes:
• If the cable is not connected properly, or if the cable is not connected when you press REC
PAUSE, the camcorder displays the caution ‘‘CHECK THE DV INPUT.’’ An anomalous image may
also flash onto the screen.
• Blanks between recordings on the playback tape are recorded as anomalous images on the tape
that is being recorded to.
Copyright signal
Editing
Certain pre-recorded software tapes are copyright protected. If you try to play back such a cassette,
“COPYRIGHT PROTECTED PLAYBACK IS RESTRICTED” appears in the viewfinder for a few seconds
and then the camcorder displays a blank blue screen; you cannot view the contents of the cassette.
If you try to record from such a tape via the digital cable “COPYRIGHT PROTECTED DUBBING
RESTRICTED” appears in the display; you cannot record the contents of the tape.
100
Recording from a VCR, TV or Analog Camcorder (Analog Line-in)
You can record a video played on your VCR or analog camcorder (for digital camcorder, see p. 99)
or a TV program onto a tape in the GL2, if the TV or other device has audio/video outputs.
• If an anomalous signal is sent from the TV or VCR, the images recorded on the tape may also be
anomalous (although it may not appear so on the TV image), not recorded at all, or COPYRIGHT
PROTECTED DUBBING RESTRICTED may appear in the viewfinder.
• You cannot dub tapes recorded with the copyright protective signal.
E
/
STV-250N Stereo Video Cable
L
AUDIO
R
: Signal flow
VIDEO
S-VIDEO
S-150 S-video Cable
Preparations
1. Connect the camcorder to the VCR, TV or another camcorder.
2. Prepare the device. (Example connecting to a VCR)
• Set the TV/Video selector on the television to Video. For further details, see “Connections for
Playback on a TV Screen” ( 95).
• Turn on the VCR. Load your recorded cassette, and put the VCR in playback pause mode.
• See your TV and VCR instruction manuals for details.
3. Slide the camcorder’s POWER switch to PLAY (VCR) and TAPE/CARD switch to
TAPE.
Editing
4. Load a blank cassette.
101
Dubbing
E
1. Find a point on your recorded cassette slightly before the section you wish to
copy and set it to playback pause mode.
2. Press the REC PAUSE button.
• S-video and audio IN/OUT terminals work as input terminals.
• The camera enters record pause mode.
3. Start playback on the other device or turn on the TV to see the desired
program while you monitor the picture.
4. Press the e/a (play/pause) button on the camcorder or the PAUSE a button on
the wireless controller.
• Recording starts.
5. When you get to the point where you wish to stop recording, press the stop
button or the pause button.
• Recording stops.
6. Stop playback on the other device.
Note:
Editing
• You can monitor the picture on the LCD screen/viewfinder.
102
Digitally Outputting Analog Video and Audio Signals
(Analog-Digital Converter)
E
Connecting the camcorder to your VCR or 8 mm video camera allows conversion of recorded
analog video and audio signals to digital signals in an instant. The digital signals can be output to
the other equipment with a DV terminal. The camcorder’s DV terminal works exclusively as an
output terminal.
• There may be cases where analog-digital conversion cannot be done properly, depending on the
signals output from the connected equipment.
For example: Signals that include the copyright protective signal, or anomalous signals such as
ones that include ghost signals, etc.
• You are recommended to use power from a household power source with a power adapter.
• Do not operate with a cassette inserted to the camcorder.
• Turn off the power of all equipment before performing connections.
• Refer also to the instruction manuals of the other equipment connected.
STV-250N Stereo Video Cable
OUTPUT
L
AUDIO
: Signal flow
R
VIDEO
: Signal flow
S-VIDEO
S-150 S-video Cable
DV
IN/OUT
Signal flow :
Editing
Side with
arrow
Above illustration shows the connection using a S-video cable. You can also connect the yellow
plug to the VIDEO terminal instead.
103
Turning the Analog-Digital Converter On
E
TAPE
+
PLAY
(VCR)
VCR SET UP
(
AV DV OUT••• OFF
20)
To turn the analog-digital converter on, open the menu and select VCR SET UP.
Then select AV \ DV OUT, set it to ON and close the menu.
Caution:
Editing
• For normal use, set AV \ DV OUT to OFF through the menu. If it is set to ON, you cannot input
digital signals through the camcorder’s DV terminal.
• If you attempt to perform analog-digital conversion with a cassette inserted to the camcorder, the
converted signals may not be output to the connected digital video equipment.
• When connecting to a PC equipped with a DV terminal, you may not be able to transfer
converted signals to your PC, depending on the software you are using, and the specifications of
your PC and its settings.
104
Recording Over Existing Scenes (AV Insert Editing)
You can insert and replace images/audio recorded on the camcorder’s tape with images/audio
recorded with other video equipment using analog line-in or DV terminals.
Original video and audio will be replaced with the new video and audio.
E
Scene to be inserted
The playback tape
Insert start point
Insert end point
Before inserting
The tape in the
camcorder
After inserting
The tape in the
camcorder
The video and audio of the new scene replace that of the old.
STV-250N Stereo Video Cable
L
AUDIO
R
: Signal flow
VIDEO
Editing
S-VIDEO
S-150 S-video Cable
: Signal flow
105
Preparations
E
The tape in the camcorder:
When using the GL2’s AV insert function, only use to tapes recorded in SP mode with continuously
recorded time codes.
If there are non-recorded portions or portions recorded in LP mode on the tape, recording will stop.
The playback tape:
Use only tapes without non-recorded portions.
If there are non-recorded portions or changes in the recording mode, you may not be able to insert
AV correctly.
You cannot insert AV in the following cases:
• The playback tape has been poorly recorded.
• During special playback: fast forward playback, rewind playback or slow playback etc. (analog
only).
TV:
You cannot insert AV from a TV program with anomalous synchronized signals, such as when the
program itself received poor signals.
Example recording from a VCR
1. Connect the camcorder to the VCR.
Editing
2. Prepare the VCR and TV.
• Set the TV/Video selector on the television to Video. For further details, see “Connections for
Playback on a TV Screen” ( 95).
• Turn on the VCR and load a recorded cassette.
• See your TV and VCR instruction manuals for details.
3. Slide the camcorder’s POWER switch to PLAY (VCR) and load a recorded
cassette.
• Make sure the REC/SAVE tab on the cassette has been slid to REC (closed position).
4. Slide the TAPE/CARD switch to TAPE.
106
Editing
E
1. On the VCR, locate a point 3 seconds before the scene to be inserted. Set the
VCR to playback pause mode.
2. On the camcorder, press PLAY and locate the recording start point. Set the
camcorder to playback pause mode.
• You can use the playback buttons on the body of the camcorder or the special playback
functions on the wireless controller in the same way as in playback mode.
3. Press the AV INSERT button.
• AV INSERT and 2a appear in the display.
4. Play back the tape in the VCR.
5. To start inserting, press the e/a (play/pause) button on the camcorder.
• 2a changes to 2.
6. To stop inserting, press the STOP button on the camcorder.
• Inserting stops and AV INSERT disappears from the display. The camcorder returns to stop
mode.
• If instead of pressing STOP you press e/a (play/pause), the camcorder returns to the AV insert
pause mode.
• If you set the zero set memory at the position on the tape where you wish to stop inserting,
every time you return to that point, the camcorder will cancel its AV inserting and enter stop
mode.
7. Stop playback on the VCR.
Editing
107
Audio Dubbing
You can add sound to the original sound on a pre-recorded tape from audio devices (AUDIO IN) or
with the internal or external microphone (MIC. IN). The original sound will not be erased.
If there are non-recorded portions on the tape, or portions recorded in a mode other than SP
mode, or with 16-bit or 12-bit 4-channel sound, dubbing will stop. If your tape has not been
recorded in SP mode with 12-bit sound, we recommend dubbing your original tape onto a blank
tape using the GL2’s analog line-in function, then dubbing audio onto the new tape. Make
absolutely sure to set the audio mode of the new tape to 12-bit and the recording mode to SP.
E
Add sound to tapes that have been recorded with this camcorder in SP mode with 12-bit sound.
To connect other audio devices:
: Signal flow
STV-250N
Stereo Video
Cable
OUTPUT
AUDIO
L
An audio device
(i. e. CD player)
R
Note:
• No video picture will be output via the AV terminal. Check the picture on the LCD screen,
viewfinder or a TV connected to the S-video terminal. Check the sound using the speaker or
headphones.
Editing
To connect an external microphone:
Notes:
• When using the built-in microphone for dubbing, make sure that no cables are connected to the
MIC terminal.
• If you connect a TV to the S-video terminal, you can monitor the picture on the TV screen. Use
headphones to check the sound.
108
Preparations
E
Turn the camcorder’s POWER switch to PLAY (VCR) and move the camcorder’s TAPE/CARD switch to
TAPE. Load a recorded cassette.
• Make sure the REC/SAVE tab on the cassette has been slid to REC (closed position).
Dubbing
/
ZERO SET SEARCH
MEMORY SELECT
AUDIO
DUB.
REW
PLAY
FF
AV
INSERT
–/
STOP
+/
REMOTE SET PAUSE
SLOW
×2
AUDIO
REC LEVEL
A
M
Do not connect/disconnect any cables to/from the camcorder when dubbing audio or preparing to
dub audio.
TAPE
+
PLAY
(VCR)
VCR SET UP
(
AUDIO DUB.••• AUDIO IN
20)
1. Open the menu and select VCR SET UP.
2. Select AUDIO DUB.
3. Select AUDIO IN or MIC. IN and close the menu.
4. Locate the point where you wish to start audio dubbing, then press the e/a
button or the PAUSE button.
Editing
• You can use the playback buttons on the camcorder or the special playback functions on the
wireless controller in the same way as in playback mode.
• The camcorder becomes set to playback pause mode.
5. Press AUDIO DUB.
• AUDIO DUB. and 2a appear on the display.
109
6. Adjust the input signal level.
E
AUDIO IN
Automatic adjustment:
1.Slide the REC LEVEL switch to A.
Manual Adjustment:
1.Slide the REC LEVEL switch to M.
2.Turn the L/R LEVEL dials to adjust the recording level.
• Adjust it that the level slightly exceeds the 12 point.
• Adjust the balance by turning the L/R LEVEL dial if necessary.
• Even if you turn down the LEVEL dial, the sound may be distorted if the input level is still too
high. Set the audio attenuator (AUDIO ATT) to ON in the VCR SET UP submenu of the VCR
MENU.
MIC IN
You can select the microphone sound and adjust the level when using the built-in microphone
( 108). You can only adjust the recording level when using an external microphone.
7. Press the PAUSE button (and start play on the other audio device if AUDIO IN).
• Audio dubbing starts.
• If MIC. IN, direct your voice into the microphone.
• 2a changes to 2.
8. When you get to the point where you wish to stop dubbing, press the STOP
button (and then stop play on the other audio device if AUDIO IN).
• Audio dubbing stops and AUDIO DUB. disappears from the display.
• The camcorder returns to stop mode.
• You can also set zero set memory ( 94) at the place you wish to stop audio dubbing, then
every time you return to that position, audio dubbing will stop.
• If instead of pressing STOP you press PAUSE, the camcorder will return to the playback pause
mode.
Editing
Notes:
110
• You cannot use the DV terminal while adding sound.
• You might want to adjust the audio mix ( 111) when playing back a tape with added sound.
• There may be a loss of sound quality if you add sound to a tape recorded on a camcorder other
than the GL2.
• After adding sound 3 or more times to the same place on a tape, there may be some loss in
sound quality.
Setting the Audio Mix
E
MIX
AUDIO
BALANCE
MONITOR ST-1
ST-2
When you play back a tape that was recorded in 12-bit mode, you can set the audio output to
stereo 1 (the original sound), stereo 2 (any new sound, dubbed to the tape after recording), or mix
the balance between the two.
• Audio from the 16-bit mode only contains stereo 1 sound and so you cannot/do not need to
select the audio mix. The same applies to the 12-bit stereo 1 mode, unless new sound has been
added post-recording.
TAPE
+
PLAY
(VCR)
Select the output channel.
• Press AUDIO MONITOR on the wireless controller.
• Starting with the last selected setting, 4 settings appear as you push the button:
– STEREO1 for just stereo 1.
– STEREO2 for just stereo 2.
– MIX/FIXED for an equal mix of stereo 1 and 2.
– MIX/VARI. (mix variable) for when you want to mix the balance between stereo 1 and 2.
• If you choose MIX/VARI., you can go on to mix the balance.
• Use the ST-1/ST-2 buttons to mix the balance. A bar showing the balance appears on the
screen for 4 seconds.
Note:
Editing
• When you have chosen the output, STEREO1, STEREO2, MIX/FIXED or MIX/VARI. is shown in the
top left of the display for a few seconds. If you turn the power off, the output becomes set to
STEREO1.
111
Selecting Audio Output Channels
E
When you play back a tape whose audio has been recorded on multiple channels, you can change
the output channels of that sound.
TAPE
+
PLAY
(VCR)
VCR SET UP
(
OUTPUT CH••• L/R
20)
1. Load a tape recorded with multiple-channel audio.
2. Open the menu and select VCR SET UP. Then select OUTPUT CH, set it to the
desired setting and close the menu.
• Refer to the following list.
OUTPUT CH Setting
Editing
L/R
L/L
R/R
112
Playback Sound
Tape Recorded With
Tape Recorded On
Stereo Sound
Multiple Channels
L+R channels
main + sub
L channel only
main only
R channel only
sub only
Connecting to a PC Using a DV Cable
By using a DV cable and connecting the camcorder to a PC equipped with a DV terminal
conforming to IEEE 1394/DV compatible capture board, you can transfer images taken with the
camcorder to your PC.
• While connected, it is recommended that you power your camcorder from a household power
socket using the power adapter.
• Turn off the power of both the camcorder and the PC before connecting.
• Optional software necessary.
• For transferring still images from a memory card to your PC using a USB cable, see p. 134.
DV
IN/OUT
E
DV Cable (commercially available)
Notes:
• Operation may not work correctly, depending on the software you are using, and the
specifications of your PC and its settings.
• Refer to the respective software instruction manual for further details.
Caution:
• Do not disconnect the DV cable while data is being transferred to the PC.
Editing
113
Memory Card Introduction
The camcorder can record, store and manage still images on 2 types of memory cards: the SD
Memory Card (supplied with the camcorder) or the MultiMediaCard (commercially available). The
SD Memory Card has the protect switch to protect your recordings from accidental erasure. The SD
Memory Card and the MultiMediaCard fit into the same slot.
E
You can do the following with a memory card:
• Record still images ( 118)
• View still images: Single ( 120), Slide show ( 121),
Index screen ( 121)
• Select the quality of images ( 115)
• Protect important still images against accidental erasure,
print mark and erase still images ( 122-128)
• Combine titles recorded onto the memory card with
camcorder recordings (title mix) ( 129)
• Copy multiple still images from card to tape ( 132)
• Transfer memory card still images to a PC ( 134)
SD Memory Card
Front
Back
Terminals
Protect
switch
You can use most of the camcorder’s functions when recording to a memory card, such as the
various recording programs ( 52), self-timer ( 71), shutter speed ( 77), white balance (
80) and other manual adjustments. Available functions are marked with the CARD + CAMERA or
PLAY
icons.
CARD + (VCR)
2 If you use memory cards other than the supplied one, make sure to format them with the
camcorder ( 133).
Important
• Inserting or removing the memory card without first setting the POWER switch to OFF can result
in data damage.
• This camcorder uses only SD Memory Cards (
*) or MultiMediaCards. You cannot use any
other types of memory cards.
Using a Memory Card
*
114
logo is a trademark.
Inserting and Removing the Memory Card
E
1. Turn the POWER switch to OFF.
• When removing the memory card, make sure the card access indicator is off.
2. Open the memory card compartment cover in the direction of the arrow.
3. Insert or remove the memory card.
• Push the memory card all the way in.
• Remove the memory card by pushing the card in and letting it spring out.
Do not attempt to pull the memory card out without first pushing it in.
4. Close the memory card compartment cover.
• When inserting the memory card, do not attempt to close the cover forcefully without the
memory card properly inserted.
Notes:
• When you set the camcorder to CARD PLAY (VCR) mode, the last image recorded appears. If
there are no images recorded on the memory card, NO IMAGES appears in the display.
• Do not touch the memory card terminals.
Selecting the Image Quality
Still image Quality: Fine, Standard
TAPE
+
PLAY
(VCR)
,
CARD SET UP
(
CARD
+
CAMERA
QUALITY••••• FINE
20)
• The image quality may not differ between the settings depending on the still image.
Using a Memory Card
To change the image quality, open the menu and select CARD SET UP. Then select
QUALITY, set it to STANDARD and close the menu.
115
Selecting the Image Size
E
Image Size: 1488 × 1128 pixels/640 × 480 pixels
CARD
+
CAMERA
Still Images
CARD SET UP
(
IMAGES RES.• 1488×1128
20)
To change the image size of a still image, open the menu and select CARD SET UP.
Then select IMAGES RES., set it to “640 × 480” and close the menu.
• “640” appears in the display.
Maximum Number of Still Images on an 8 MB Memory Card and Their File Sizes
Image Size
Image Quality
Fine
Standard
1488 × 1128
No of Images
File Size per Image
Approx. 6 images
860 KB
Approx. 10 images
580 KB
640 × 480
No of Images
File Size per Image
Approx. 47 images
125 KB
Approx. 93 images
65 KB
* The actual number varies on the shooting conditions and subjects.
Notes:
• Still images are compressed and recorded in the JPEG (Joint Photographic Experts Group) format.
• Refer to p. 119 for memory card display.
• The remaining number of images that can be recorded on the memory card may sometimes
decrease by 2 images at once.
Card Access Display
The operating states of the memory card are shown in the center of the display.
Using a Memory Card
TAPE
116
+
CAMERA
,
DISP.SET UP
(
CARD
+
CAMERA
,
CARD
+
PLAY
(VCR)
CARD ACCESS• ON
20)
To turn the card access display off, open the menu and select DISP.SET UP. Then
select CARD ACCESS, set it to OFF and close the menu.
File Numbers
E
The still images are automatically assigned file numbers from 0001 to 9999 and stored in folders of
9999 images each. Each folder is numbered from 100 to 999 and recorded on the memory card.
Set the image file numbers so that they reset each time a new memory card is inserted, or so that
they count up continuously.
1 CONTINUOUS
When the file numbers are set to CONTINUOUS, each image is
assigned a different number, avoiding duplication of numbers. If a
memory card already contains files, the lowest available number file
will be assigned to the added file. This is convenient when you wish
to manage your images on a PC. We recommend keeping the file
1
numbers set to CONTINUOUS.
100
Three images are
recorded on the card.
100
100-0001
100-0002
100-0003
When you insert a new empty
card and take a picture.
100-0004
100
2
100-0001
2 RESET
Each time you insert a new memory card, the file number resets to its default value (100-0001). If
the memory card already contains files, the lowest available file number in the folder with the
highest number will be assigned to the added file.
CARD
+
CAMERA
CARD SET UP
(
FILE NOS.••• CONTINUOUS
20)
To change the file numbering, open the menu and select CARD SET UP. Then
select FILE NOS., set it to RESET and close the menu.
Turning Off the Shutter Sound
CARD
+
CAMERA
Makes the sound of a shutter being released when a still image is recorded to a memory card.
SHTR SOUND•• ON
20)
To turn the shutter sound off, open the menu and select CARD SET UP. Then select
SHTR SOUND, set it to OFF and close the menu.
Using a Memory Card
CARD SET UP
(
117
Recording Still Images onto a Memory Card
E
CARD TAPE
Card Access Indicator
You can record still images onto the memory card.
• Moving pictures cannot be recorded onto a memory card.
• Memory cards cannot record audio.
• When you are using an SD Memory Card, make sure the protect switch is set to allow recording.
Make sure a memory card with enough memory available is inserted into the camcorder.
While the card access indicator flashes, do not disconnect the power source or remove the memory
card. Doing so could result in data damage.
1. Slide the POWER switch to CAMERA and the TAPE/CARD switch to CARD.
• The remaining number of images that can be recorded on the memory card, and other
information appear in the display.
• The camcorder will turn itself off if you are using a battery and do not operate the camcorder
for more than about 5 minutes. Set the Standby lever to STANDBY.
2. Press the PHOTO button halfway and hold it.
• Exposure is locked.
• During autofocus F flashes white in the display as the camcorder adjust the focus and it is
displayed continuously as a green mark when the camcorder is ready to take the still image.
3. Press the PHOTO button fully down to record the still picture.
• F disappears from the display. The shutter sound sounds and simultaneously the display
appears to close for an instant as if it were a shutter releasing.
• The card access indicator flashes and the card access display appears in the display.
Using a Memory Card
Notes:
118
• To use the self-timer ( 71), set the self-timer in the menu or on the wireless controller before
step 3, and then press the PHOTO button fully down.
• The wireless controller’s PHOTO button has no half-way setting. Press the button fully and the
camcorder immediately takes the image.
The indicators that appear in the display when recording to a memory card:
E
Image quality (
>>>>
FINE
50
1488
Number of images that can
still be recorded on the
memory card
Image size (
Backup battery
(
138)
115)
116)
Remaining battery power
(
137)
See also “The indicator that appear on the LCD screen when LCD mirror is turned on” (
44).
Memory Card Indication:
6
5
0
6
–
flashing in red: No card
in green:
6 or more images
in yellow:
1 to 5 images
in red:
No more images
flashing in red: SD memory card is protected
flashing in red: Memory card cover is open
• All indicators light in green when a memory card is played back.
• The remaining capacity indication varies depending on the recording condition. The remaining
number may sometimes not decrease or decrease by 2 images at a time.
Using a Memory Card
119
Playing Back a Memory Card
E
/
CARD
SLIDE
SHOW
CARD TAPE
Play back and view still images recorded on a memory card. (For details on connecting to a TV, see
“Connections for Playback on a TV Screen” ( 95)
• The camcorder may not be able to copy or play, etc., images recorded with a non-Canon
camcorder.
Do not change the data recorded on a memory card.
• You may not be able to play back the following still images correctly on this camcorder:
− Still images that have not been recorded with this camcorder but downloaded from a PC.
− Still images that have been recorded with this camcorder but have subsequently been enhanced
on a PC.
− Still images whose image file names have been changed on a PC.
There are 3 ways to view still images:
• Single image
• Slide show: One after the other automatically in order of recording
• Index screen: Six images at once
When the camcorder is in playback pause mode, you can use the card jump function to move
quickly through still images recorded anywhere on a memory card to find a still image you wish to
view (Card Jump function).
Make sure a memory card that has images recorded on it is inserted into the camcorder.
While the card access indicator flashes, do not disconnect the power source or remove the memory
card. Doing so could result in data damage.
2 Single Image
1. Slide the POWER switch to PLAY (VCR).
2. Slide the TAPE/CARD switch to CARD.
• The last image recorded appears in the display.
3. Search for the desired still image by pressing the CARD +/– buttons.
Using a Memory Card
• Press + to view the next image and – to view the previous image.
• Pressing + at the last image will take you to the first image. Pressing – at the first image will
take you to the last image.
120
2 Card Jump Function
E
You can jump from the current image to the desired image of unadjacent image number without
displaying the images one by one.
The numbers shown in the upper right corner in CARD PLAY (VCR) mode indicate the image
number of the current still image and the total number of still images on the memory card.
CARD
+
PLAY
(VCR)
With a still image in the display, press and hold the CARD +/– button.
• Press the + button to jump forwards through the images and press the – button to jump
backwards.
• The image number moves forwards or backwards.
• When you release the button, the still image to which the currently shown number is assigned,
appears in the display.
2 Slide Show
CARD
+
PLAY
(VCR)
With a still image in the display, press the MIX/SLIDE SHOW button.
• The still images are played back one after another.
To stop the slide show, press the MIX/SLIDE SHOW button.
• The slide show starts or stops each time you press the SLIDE SHOW button.
2 Index Screen
Up to 6 images appear at once so you can search quickly for an image.
CARD
+
PLAY
(VCR)
1. With a still image in the display, press
the INDEX SCREEN button.
INDEX
1488
1488
100–0143
1488
1488
1488
1488
SEL. INDEXEND
• Up to 6 images appear in the display.
2. Select a still image by pressing the SELECT dial or the CARD +/– buttons.
3. Press the INDEX SCREEN button with the frame on the selected image.
• The selected image appears in full size of the display.
Using a Memory Card
• A red frame appears around the selected image.
• Pull the SELECT dial up to move to the next image and down to move to the previous image.
• Pulling the SELECT dial up at the last image displays the next index screen. Pulling the SELECT
dial down at the first image displays the previous index screen.
• You can also use the CARD +/– button to switch index screen. Press the CARD – button to
display the previous index screen and the CARD + button to display the next index screen.
121
Settings of the Still Images Recorded on a Memory Card
E
/
You can easily erase unwanted still images while viewing them, protect them from accidental
erasure, or mark them for printing. (File Operation)
● Preventing Accidental Erasure (Protect
)
Select important images and protect them from accidental erasure.
• If a memory card is formatted, however, all images, including protected images, will be
permanently erased.
1.
2.
CARD
CARD
+
+
PLAY
(VCR)
PLAY
(VCR)
➡ File Operation menu SINGLE ( 123)
➡ Card Operations submenu INDEX ( 124)
● Marking a Still Image for Printing (Print Mark
)
An image on a memory card must be marked before it can be printed. The camcorder supports the
DPOF (Digital Print Order Format) print format. Images can be automatically printed on a DPOFsupporting Canon printer.
There are 3 ways to mark a still image for printing.
To mark an image for printing or erase print marks one at a time
1.
2.
CARD
CARD
+
+
PLAY
(VCR)
PLAY
(VCR)
➡ File Operation menu SINGLE ( 123)
➡ Card Operations submenu INDEX ( 125)
To erase all print marks
3.
CARD
+
PLAY
(VCR)
➡ Card Operations submenu
SINGLE
(
126)
● Erasing Still Images
Erase images singly or all at once.
• You cannot erase protected images. Cancel image protection first in order to erase an image.
• Erase images with caution. Once an image has been erased it cannot be restored.
To erase images one at a time
Using a Memory Card
1.
122
CARD
+
PLAY
(VCR)
➡ File Operation menu
SINGLE
(
123)
To erase images one at a time or erase all images on the memory card at once
PLAY
2. CARD + (VCR)
➡ Card Operations submenu SINGLE ( 127)
SINGLE
INDEX
: When playing back an image in CARD PLAY (VCR) mode
: When displaying an index screen in CARD PLAY (VCR) mode
File Operation (FILE OPER.)
CARD
+
E
PLAY
(VCR)
1. With an image in the display, press the SELECT dial in to open the FILE OPER.
menu.
• PROTECT
, PRINT MARK
, and IMAGE ERASE settings appear.
• If you select |RETURN, the menu disappears from the display.
To protect an image
2. Select PROTECT
•
•
•
•
and press the SELECT dial in.
The
protect mark appears on the image, and the image cannot be erased.
Press the SELECT dial again to cancel it.
If you select |RETURN, the menu disappears from the display.
To cancel image protection, select PROTECT
and press the SELECT dial in.
and now you can erase this image.
disappears
To mark a image for Printing (Print Mark)
2. Select PRINT MARK
•
•
•
•
and press the SELECT dial in.
The
print mark appears on the image.
Press the SELECT dial again to cancel it.
If you select |RETURN, the menu disappears from the display.
To cancel a print mark, select PRINT MARK
and press the SELECT dial in.
disappears.
To erase the image
2. Select IMAGE ERASE and press the SELECT dial in.
• ERASE THIS IMAGE? NO YES appears in the display.
• If you select |RETURN, the menu disappears from the display.
3. Select YES and press the SELECT dial in.
• The image is erased.
• One image after the erased image appears.
Using a Memory Card
123
Preventing Accidental Erasure (Protect)
E
REC SEARCH
CARD
SLIDE
SHOW
This section describes how to protect the still image from the Card Operation submenu when
displaying an index screen in CARD PLAY (VCR) mode (including the way to cancel the setting).
You can also protect a still image through the File Operation menu ( 123).
Protecting an Image While Viewing an Index Screen
CARD
+
PLAY
(VCR)
CARD OPER.
(
PROTECT
20)
Make sure a memory card that has images recorded on it is inserted into the camcorder.
1. With an image in the display, press the INDEX SCREEN button.
• Up to 6 images appear in the display.
• Select the image that you wish to protect (Index Screen
121).
2. Open the menu and select CARD OPER.
3. Select \ PROTECT
.
4. Press the SELECT dial in.
• The
protect mark appears on the image, and the image cannot be erased.
• Press the SELECT dial again to cancel it.
5. Close the menu.
Note:
Using a Memory Card
• To cancel image protection, select the protected image and press the SELECT dial in. The
protect mark disappears.
124
Marking a Still Image for Printing (Print Mark)
E
This section describes how to mark a still image for printing from Card Operation submenu in
CARD PLAY (VCR) mode (including the way to cancel the setting).
– When displaying an index screen, you can mark the still image for printing.
– When playing back a single image, you can erase all print marks.
You can also mark a still image for printing through File Operation menu ( 123).
Marking a Still Image for Printing While Viewing an Index Screen
CARD
+
PLAY
(VCR)
CARD OPER.
(
PRINT MARKS
20)
Make sure a memory card that has images recorded on it has been inserted into the camcorder.
1. With a still image in the display, press the INDEX SCREEN button.
• Up to 6 images appear in the display.
• Select the image that you wish to mark for printing (Index Screen
121).
2. Open the menu and select CARD OPER.
3. Select \ PRINT MARK .
4. Press the SELECT dial in.
• The
print mark appears next to the image.
• Press the SELECT dial again to cancel it.
5. Close the menu.
Notes:
Using a Memory Card
• To cancel a print mark, select the print-marked image and press the SELECT dial in. The
print
mark disappears.
• If there are a large number of images recorded on the memory card, it may take time for a print
mark to appear on an image.
125
Erasing all Print Marks
E
CARD
+
PLAY
(VCR)
CARD OPER.
(
PRINT MARKS
ALL ERASE
20)
Make sure a memory card that has images recorded on it has been inserted into the camcorder.
1. With a still image in the display, open the menu and select CARD OPER.
2. Select PRINT MARKS
• ERASE ALL PRINT MARKS
ALL ERASE.
? YES NO appears in the display.
3. Select YES.
• The
print mark disappears from the image.
Using a Memory Card
4. Close the menu.
126
Erasing Still Images
E
REC SEARCH
CARD
SLIDE
SHOW
This section describes how to erase still images from the Card Operation submenu when playing
back a single image in CARD PLAY (VCR) mode.
You can also erase a still image through the File Operation menu ( 123).
CARD
+
PLAY
(VCR)
CARD OPER.
(
IMAGE ERASE
20)
Make sure a memory card that has images recorded on it is inserted into the camcorder.
To erase still images one at a time
1. Select the still image you wish to erase.
• Use the index screen ( 121) or card jump function ( 121) if necessary and make sure the
image you wish to erase fills the display.
• If you are displaying the index screen, press the INDEX SCREEN button after selecting the
image. The image you selected fills the whole display.
2. Open the menu and select CARD OPER.
3. Select IMAGE ERASE.
• CANCEL, SINGLE and ALL settings appear.
• To cancel erasing, select CANCEL and close the menu.
4. Select SINGLE.
• ERASE THIS IMAGE? NO YES appears in the display.
5. Select YES.
6. Close the menu.
Using a Memory Card
• The image erases and the previous image appears for erasing.
• To erase another single image, move to that image with the CARD +/– buttons, and select
YES.
• If the image you are trying to erase is a protected image, YES appears in purple and is
unselectable.
• If you select NO, you return to step 4.
127
To erase all still images in a folder
E
1. Open the menu and select CARD OPER.
2. Select IMAGE ERASE.
• CANCEL, SINGLE and ALL settings appear.
• To cancel erasing, select CANCEL and close the menu.
3. Select ALL.
• ERASE ALL IMAGES? [EXCEPT FOR
IMAGES] NO YES appears in the display.
4. Select YES.
• All images in the folder of the displayed image except the protected ones are erased.
• If you select NO, you return to step 2.
Using a Memory Card
5. Close the menu.
128
Combining Images and Recording Them onto a Tape (Title Mix)
Combine a title image recorded on a memory card with camcorder recordings. You can change the
color of a title and adjust the mix level.
E
Creating a Title Image
• Speedlite and video light cannot be used when creating a title.
TAPE
+
CAMERA
TITLE MIX
(
20)
1. Insert a memory card into the camcorder.
2. Slide the POWER switch to CAMERA and the TAPE/CARD switch to TAPE.
3. Open the menu and select \ TITLE MIX.
• The title mix menu appears.
4. Select \ CREATE TITLE.
• The CREATE TITLE menu appears.
5. Press the PHOTO button halfway.
• F flashes white and turns green and glows steady.
6. Press the PHOTO button fully.
• F disappears and the camcorder records the title.
Selecting the Color
1. Select COLOR SELECT from the CREATE TITLE menu.
2. Select the color by pulling the SELECT dial up or down.
3. Press the SELECT dial in.
Adjusting the Mix Level
1. Select MIX LEVEL from the CREATE TITLE menu.
2. Adjust the mix level by pulling the SELECT dial up or down.
3. Press the SELECT dial in.
Recording the Title Image onto the Memory Card
• You have to record the title onto the memory card in order to use the title mix function.
2. Press the SELECT dial in.
• The camcorder records the title onto the memory card.
Note:
Title images may be assigned the same file number depending on the color selection.
Using a Memory Card
1. Select RECORD from the CREATE TITLE menu.
129
Selecting a Title Image
E
TAPE
+
CAMERA
1. Slide the POWER switch to CAMERA and the TAPE/CARD switch to TAPE.
2. Open the menu and select \ TITLE MIX.
• The title mix menu appears.
3. Select \ TITLE SELECT.
• Up to 6 titles images are displayed.
4. Select the title you wish to combine.
5. Press the SELECT dial in.
• You return to the title mix menu.
Activating the Title Mix
1. Slide the program selector to
Q and select a recording program.
• Title mix cannot be used in the [ (Easy Recording) program.
2. Press the MIX/SLIDE SHOW button.
• The selected title appears combined with your recording.
Recording the Combined Image onto the Tape as Movie
1. Press the start/stop button.
Recording the Combined Image onto the Tape as Still Image
1. Press the PHOTO button halfway.
• F flashes white and turns green and glows steady.
2. Press the PHOTO button fully.
• F disappears and the camcorder records the still image.
Protecting a Title Image
You can protect a title image to prevent accidental erasure.
• If you format a memory card, all images including the protected ones will be erased.
Using a Memory Card
1. Open the menu and select CARD OPER.
130
2. Select \ TITLE PROTECT
and press the SELECT dial in.
• The title protect index screen appears.
3. Select the title image you wish to protect and press the SELECT dial in.
• The
protect mark appears, and the title image cannot be erase.
• Press the SELECT dial again to cancel it.
Erasing a Title Image
E
1. Open the menu and select CARD OPER.
2. Select \ TITLE ERASE and press the SELECT dial in.
• The title erase index screen appears.
3. Select the title image you wish to erase and press the SELECT dial in.
• Check the title image on the index screen when selecting.
• Erase this title? NO YES appears and the title image flashes.
4. Select YES and press the SELECT dial in.
• The title image is erased.
• If you wish to erase another title image, select the next title image, select YES and press the
SELECT dial in.
• If you select NO, you return to the title erase index screen.
Using a Memory Card
131
Copying Still Images from Memory Card to Tape
E
/
You can copy multiple still images from the memory card to a tape.
• The still images’ data codes will reflect the date and time the copies are made.
CARD OPER.
(
COPY[
]
20)
Make sure a memory card that has images recorded on it and a cassette that has enough
recordable space have been inserted into the camcorder.
TAPE
+
PLAY
(VCR)
1. Locate the point on the cassette where you wish to start copying and set it to
stop.
CARD
+
PLAY
(VCR)
2. Select the first image you wish to copy by using the CARD +/– buttons.
• Still images on the memory card including and after that image will be copied onto the tape.
• If you wish to copy all the still images on the memory card, select the first image.
3. Open the menu and select CARD OPER.
].
4. Select COPY [
• CANCEL and EXECUTE settings appear.
Using a Memory Card
5. Select EXECUTE.
132
•
•
•
•
•
Select CANCEL to stop copying.
Cassette and card information appear in the display and copying starts.
] appears in the display.
NOW COPYING [
Each image is copied for about 6 seconds on the cassette.
Copying stops when all the images have been copied or the tape is full.
6. Press the 7 button when your desired images have been copied.
Formatting a Memory Card
E
Format new memory cards if you get the message CARD ERROR, or to permanently and quickly
erase all still images on a memory card, including protected images.
The SD Memory Card supplied with this camcorder has already been formatted for you.
• Be cautious when formatting recorded memory cards. All images will be permanently erased.
• If you use memory cards other than the supplied one, make sure to format them with the
camcorder, not a PC or other device.
CARD
+
PLAY
(VCR)
CARD OPER.
(
FORMAT
20)
Make sure a memory card is inserted into the camcorder.
1. Open the menu and select CARD OPER.
2. Select FORMAT.
• CANCEL and EXECUTE settings appear.
3. Select EXECUTE.
• Select CANCEL to cancel formatting.
• FORMAT THIS CARD? NO YES appears to confirm.
4. Select YES.
• Formatting starts and NOW FORMATTING appears in the display.
• If you select NO, you return to step 3.
5. Close the menu.
Using a Memory Card
133
Connecting to a PC Using a USB Cable
You can download still images from a memory card to a PC connected to the camcorder via the
USB interface. By using the supplied software, you can organize, store and print out still images.
When printing still images, you can add titles and frames to them.
Use the USB cable and the Canon Digital Video Solution Disk software supplied with the
camcorder.
E
: Signal flow
IFC-300PCU USB cable
For details on how to connect the camcorder to a PC and install and operate the
software, refer to the Canon Digital Video Solution Disk instruction manual.
• Refer also to your PC manual.
“PC CONNECT [USB]” appears to indicate that the camcorder is
connected to the PC with an USB cable.
PC CONNECT[USB]
Cautions:
• Do not disconnect the USB cable while data is being transferred (while the camcorder’s card
access indicator is flashing). Doing so may damage the data on the memory.
• The connection may not work properly depending on the specifications and settings of the
software and PC.
• The image files on your memory card and the image files you have stored (downloaded) to the
hard disk drive of your computer are your valuable, original image files. If you wish to use image
files on your computer, be sure to make copies of them first, and use the copied file, retaining
the original.
Using a Memory Card
Notes:
134
While performing USB connection:
• The buttons, excluding the POWER switch and TAPE/CARD switch on the camcorder cannot be
used.
Other Information and Precautions
The camcorder formats memory cards in DCF (Design rule for Camera File system).
Images recorded on a memory card with this camcorder can also be transferred to a PC with the
use of the following products made for SD Memory Cards or MultiMediaCards:
E
PC Card Adapter: Holds a memory card and fits into a PC card slot found on most types of laptop
PCs.
FD Adapter: Holds a memory card and fits into a PC’s floppy disk drive.
Memory Cards confirmed to operate with this camcorder (as of January 2002)
SD Memory Card—
Panasonic: 8 MB, 16 MB, 32 MB, 64 MB
SanDisk: 8 MB, 16 MB, 32 MB, 64 MB
MultiMediaCard—
SanDisk: 8 MB, 16 MB, 32 MB, 64 MB
• However, we cannot guarantee that all of these memory cards work properly.
Memory Card Operating Precautions
SDC-8M SD Memory Card Specifications
Capacity
Interface
Operating Temperatures
Dimensions
Wight
8 MB
SD Memory Card standard
32°F – 140°F (0°C – 40°C)
1 1/4 × 1 × 1/8 in (32 × 24 × 2.1 mm)
1/8 oz (2 g)
Using a Memory Card
• If you purchase additional memory cards, format them with the camcorder, not a PC or other
device. Memory cards formatted with a PC or other device may not function properly.
• We recommend saving backups of memory card images on your PC’s hard drive or other external
memory device. Image data may be damaged or lost due to a defect in a memory card, or if a
memory card is exposed to static electricity. Contents of a memory card cannot be compensated
for should data become damaged or lost.
• Do not remove the power source or the memory card while the card access indicator flashes.
• Do not use memory cards in places subject to strong magnetic fields.
• Do not disassemble memory cards.
• Do not bend or drop memory cards, or expose them to strong vibrations or external shocks.
• Do not get memory cards wet.
• Do not remove the memory card’s label or affix other labels. Affix labels to the memory card’s
case.
• Do not leave memory cards in places subject to high temperature or high humidity.
• Moving a memory card rapidly between hot and cold temperatures may cause condensation to
form on it, leading to malfunctions. Avoid this problem by placing the memory card in a plastic
bag and letting it slowly adjust to temperature changes before removing it from the bag. If
condensation should occur, maintain the memory card at a constant temperature and let the
moisture evaporate naturally.
• Do not touch the memory card’s terminals or let dust or dirt come in contact with the terminals.
Store and carry memory cards in their case to protect the terminal area.
• There is only one correct way to insert memory cards into the camcorder. Do not forcefully insert
the memory cards backwards or upside down. This could damage the memory card or the
camcorder.
135
Notes on Using the Batteries
E
Charging and Recording Times
• These times vary — the safest policy is always to have 2 or 3 times as many battery packs as you
think you will need.
• You will get more recording time if you turn the camcorder off between shots, instead of leaving
it in record pause mode.
• The charging time varies depending on the charging conditions.
Battery Pack
BP-915
BP-930
BP-945
Battery
Pack
BP-915
BP-930
BP-945
Charging Time
1 hr. 25 min.
2 hr. 25 min.
3 hr. 40 min.
Max. Recording Time
Typical Recording Time*
Using the Viewfinder Using the LCD Screen Using the Viewfinder Using the LCD Screen
2 hr.
4 hr. 40 min.
7 hr.
1 hr. 35 min.
3 hr. 55 min.
5 hr. 55 min.
1 hr. 5 min.
2 hr. 35 min.
3 hr. 55 min.
55 min.
2 hr. 15 min.
3 hr. 25 min.
* Typical Recording Time: Approximate times for recording with repeated operations such as
start/stop, zooming and power on/off. The actual time may be shorter.
• You can use the battery pack between 32° and 104°F (0° to 40°C), but it works best between
50° and 86°F (10° to 30°C). Operating time will be shorter than usual at low temperatures like a
ski ground. For better operating results, the battery pack can be warmed in your pocket or
someplace and then used.
• If the battery pack starts to give you much less operating time than usual (at normal
temperatures), it has reached the end of its life and must be replaced.
Note:
• These figures show how long you can view playback with the LCD, after attaching a fullycharged battery pack. Playback time will be shortened at low temperatures.
Additional
Information
Battery Pack
BP-915
BP-930
BP-945
136
Playback Time (Using the LCD Screen)
1 hr. 45 min.
4 hr. 15 min.
6 hr. 25 min.
How Much Power Is Left?
E
The indicator in the display shows you approximately how
much charge the battery pack has left:
Notes:
↓
• When the power is completely exhausted, “CHANGE THE
BATTERY PACK” appears in the display for 4 seconds and
the empty battery mark starts to flash. The power
indicator light also flashes.
• The indicator is not constant — it varies with the condition
under which battery pack and camcorder are used.
↓
↓
↓
100%
75%
50%
25%
CHANGE THE BATTERY PACK
0%
When to Recharge
You can recharge a lithium ion battery pack whenever it is convenient. Unlike a conventional battery
pack, it does not have to be fully discharged first. However, as the battery pack will naturally
discharge itself over time, it is best to charge it the same day you plan to use it, or the day before.
Taking Care of the Battery Pack
Always attach the terminal cover.
• Do not allow any metal objects to touch the terminals, as
this can cause a short circuit and damage the battery pack.
Attach the terminal cover whenever the battery pack is not
being used.
Keep the terminals clean.
• The camcorder adapter or battery pack will not work properly if the terminals are dirty. Attach
the terminal cover whenever the battery pack is not being used.
Storing the battery pack
• Storing a charged battery pack for long periods of time (about 1 year) can shorten its lifecycle or
affect performance. We recommend to discharge the battery pack in the camcorder fully and to
store it in a dry place. If you do not use the battery pack for long periods of time, charge it fully
and discharge it fully in the camcorder at least once a year before returning it to storage.
Additional
Information
137
E
Installing the Backup Battery
Open the backup battery cover and insert the
CR2025 lithium battery with the + side facing
outwards. Click the cover back into place.
This backup battery allows the camcorder to retain
the date and time and other settings when the
main power source is removed. It has a life span of
about a year.
When it needs replacing (or if it has not been
installed), the y mark flashes in the display.
Remove the old battery by pushing it up, releasing
and lifting it out. Make sure to attach a power
source to the camcorder first, so it will retain your
chosen settings when you change the battery.
DANGER!
Treat the battery pack with care.
• Keep it away from fire (or it might explode).
• Do not expose the battery pack to temperatures greater than 140°F (60°C).
Do not leave it near a heater, or inside a car in hot weather, for example.
• Do not try to disassemble or modify it.
• Do not drop or knock it.
• Do not get it wet.
WARNING!
• The battery used in this device may present a fire or chemical burn hazard if mistreated. Do not
recharge, disassemble, heat above 212°F (100°C) or incinerate.
• Replace the battery with a CR2025 made by Panasonic, Hitachi Maxell, Sony, Sanyo, or with
Duracell DL2025. Use of other batteries may present a risk of fire or explosion.
Additional
Information
Cautions:
138
• Do not pick up the battery using tweezers or other metal tools — this will cause a short circuit.
• Wipe the battery with a clean, dry cloth to ensure proper contact.
• Keep the battery pack out of reach of children — if it is swallowed, contact a physician
immediately, as the battery case may break down and the battery fluids damage the stomach and
intestines.
• Do not disassemble, heat or immerse the battery in water, to avoid the risk of explosion.
Maintenance
Cautions
Avoid high temperatures and high humidity.
• Do not leave the camcorder inside a car in hot weather, for example.
• Be careful of heat radiating from video lighting equipment.
• Do not take the camcorder into a humid room.
E
Avoid sudden changes in temperature.
• If you take the camcorder from a cold place to a warm place, condensation may form on the lens
and internal parts (
142).
Do not point the lens or viewfinder at strong light sources.
• Never point it at the sun, and do not leave it aimed at a bright subject.
• Be especially careful when leaving the camcorder on a tripod.
Avoid magnetic or electric fields.
• Do not use the camcorder close to TV transmitters, portable communication devices or other
sources of electric or magnetic radiation. They may cause picture interference, or permanently
damage the camcorder.
Do not expose the camcorder to water.
• Cover the camcorder when you are recording in rain or mist.
• There is a risk of electric shock if water gets inside the camcorder — contact qualified service
personnel as soon as possible.
Protect the lens.
• Sand and dust can damage the lens — be especially careful on windy days.
Handle the camcorder gently.
• Vibration or shock can cause damage.
• Do not use the viewfinder or LCD panel as a carrying handle.
Do not disassemble the camcorder.
• This is very dangerous as there is a risk of electric shock — if the camcorder does not function
properly, take it to qualified service personnel.
Additional
Information
139
E
Storage
If you do not intend to use the camcorder for a longer time, store it in a dry area free of dust, and
at temperatures no higher than 86°F (30°C). After storage, check each part and function of your
camcorder to make sure everything is still working properly.
Note:
• These cautions also apply to accessories such as battery packs and cassettes.
Maintenance
Viewfinder
• Clean the viewfinder screen. Rotate the viewfinder upwards.
Remove the viewfinder protect cover and clean it with a
cotton swab etc. When finished, return it flush with the
camcorder.
• The viewfinder screen scratches easily. Be careful when
cleaning.
LCD
• Clean the LCD screen using a commercially available cleaning
cloth for glasses.
• Moving the camcorder between hot and cold temperatures
may cause condensation (water droplets) to form on the
surface of the screen. Wipe the screen with a soft, dry cloth.
• At low temperatures the display may appear to be much
darker than usual. This is not a malfunction. As the screen
warms up the display will return to normal.
Additional
Information
Camcorder body and lens
• Use a soft, dry cloth to clean the camcorder body or lens.
Never use chemically treated cloth or volatile solvents such as
paint thinner.
140
w
q
q
w
Video heads
• When mosaic-like noise appears on the playback picture, the video heads may
be dirty. When the video heads are badly contaminated, the camcorder may
show a blank blue screen or a warning.
• For the best picture possible, after using the camcorder for approximately 20
hours, clean the video heads using Canon’s DVM-CL Digital Video Head
Cleaning Cassette. If the “noise” remains, repeat the cleaning (up to maximum of 5 times).
• Do not use a wet-type cleaning cassette, as this can cause damage.
E
Using the Camcorder Abroad
Power sources
• You can use the compact power adapter to operate your camcorder and charge battery packs in
any country where the electricity supply is between 100 and 240 V AC, 50/60 Hz. Contact your
Canon dealer for information about plug adapters for overseas use.
TV playback
• Although you can always play back your recordings on the LCD screen, your camcorder can only
be connected to TVs which use its NTSC system. This TV system is used in the following countries:
American Samoa, Bahamas, Barbados, Bermuda, Bolivia, Canada, Chile, Columbia, Costa Rica,
Cuba, Ecuador, El Salvador, Guam, Guatemala, Greenland, Haiti, Honduras, Jamaica, Japan,
Korea, Mexico, Micronesia, Myanmar, Nicaragua, Panama, Peru, Philippines, Puerto Rico, Saint
Lucia, Surinam, Taiwan, Trinidad and Tobago, USA, Venezuela.
Additional
Information
141
E
Condensation
Condensation may form on the camcorder when it is moved from a cold place to a warm place.
Using the camcorder while condensation is present can damage both the tape and the camcorder.
Condensation may form:
When you take the camcorder from a cold place to
a warm room
When a cold room is heated rapidly
When the camcorder is left in a humid room
When the camcorder is taken from an air-conditioned room to a warm, humid place
Protecting the camcorder from condensation
• Before you take the camcorder to a warm or humid place where condensation is likely to become
a problem, unload the cassette and put the camcorder in a plastic bag. Wait until the camcorder
reaches room temperature before you take it out of the bag.
What happens when condensation is detected
• “CONDENSATION HAS BEEN DETECTED” is displayed for approximately four seconds. The power
indicator flashes and the h mark flashes in the display. If there is a cassette in the camcorder, it
stops automatically and
“REMOVE THE CASSETTE” is displayed for approximately 4 seconds and v flashes in the display.
If you have the beep turned on, it will sound. Remove the tape, otherwise it may be damaged.
• The camcorder may not detect the condensation immediately — the condensation warning may
not start flashing for 10 to 15 minutes.
• You cannot load a cassette when condensation is detected.
Additional
Information
What you should do
• Remove the cassette, leave the cassette compartment open, and turn the camcorder off.
• Leave it in a dry place until the condensation evaporates. After the condensation warning stops
flashing, wait at least another hour before trying to use the camcorder.
142
Troubleshooting
Refer to this checklist first if you have any problems with your camcorder. Possible explanations are
given for each problem on the list — turn to the page numbers in parentheses for more
information.
E
Make sure that the camcorder is properly connected if you are using it with a TV or VCR. Consult
your dealer or service outlet if problems persist.
Recording/Playback
Problem
Cause and/or what to do about it
? Nothing happens when I press the
buttons.
• The camcorder is not set to the appropriate mode
(
35, 87).
• The cassette is not loaded or is set for erasure
prevention (
18-19).
• The cassette has reached the end.
• The power source is not properly connected, or
the battery pack is exhausted or not properly
attached (
16-17, 137).
• The function cannot be used in that recording
program (
52).
? The camcorder turned itself off.
• The camcorder was in record pause mode for more
than about 5 minutes (
36, 118).
• The battery pack is exhausted (
17, 137).
? The cassette compartment stopped midoperation while loading/unloading a
cassette.
• The battery pack’s power is exhausted. Recharge
or change to a new battery pack (
17).
? The start/stop button does not work.
• The cassette is not loaded or is set for erasure
prevention (
18-19).
• The cassette has reached the end.
? There is no picture in the display.
• The camcorder is not set to the appropriate mode
(
35, 87).
? There is a blank blue screen in the display.
• You are attempting to play back or record
copyright protected material (
100).
• The video heads are badly contaminated (
? The camcorder does not focus.
141).
• The camcorder is on manual focus (
79).
• The viewfinder lens needs adjusting (
14).
• The lens is dirty (
140).
Additional
Information
143
Note:
E
• Some subjects are not suitable for autofocus. In these situations, you will often get better results
using manual focus ( 79). Focus on something which is about the same distance away, lock the
focus, and then point the camcorder at your original, hard-to-focus subject.
Horizontal stripes
Many subjects at
different distances
Behind glass
Without much contrast
(e.g. a white wall)
Reflective surfaces (e.g.
shiny car surfaces)
Fast moving objects
Dark subjects
Night scenes
Additional
Information
Recording/Playback (Cont.)
144
Problem
Cause and/or what to do about it
? Some/all of the digital effects do not
work.
• There are a number of restrictions on using the
digital effects. ( 62).
? The e (play) button does not work.
• The camcorder is not set to TAPE PLAY (VCR)
mode ( 87).
• The cassette is not loaded ( 18).
• The cassette has reached the end.
? There is a bright stripe on the screen.
• When recording in dark places a bright light in
the scene may cause a vertical light bar
(“smear”) to appear. This is a normal feature of
camcorders.
? The playback picture is rough (with
mosaic-like noise).
• The video heads need cleaning (
? There is no picture on the TV screen.
• AV \ DV OUT (Analog-digital converter) is not
set to OFF in the menu ( 103).
? There is no picture on the TV screen,
even though the tape is moving.
• The video heads need cleaning ( 141).
• The TV/VIDEO selector on the TV is not set to
VIDEO ( 95-96).
? There is no sound coming from the
speaker during playback.
• The speaker has been turned off with the
selector dial ( 89).
• Headphones are being used.
141).
Memory Card Operations
Problem
Cause and/or what to do about it
? The memory card will not insert.
• It is not turned the right way ( 115).
Turn it the right way and try inserting again.
? The
mark flashes red in the display
even though a memory card has been
inserted.
• Turn the camcorder’s power off and back on
again and remove and reinsert the card. If the
mark continues to flash, format the memory
card.
? Nothing happens when I press the
buttons.
• The camcorder is not set to CARD CAMERA or
CARD PLAY (VCR) mode ( 118, 120).
• The memory card is not inserted ( 115).
• You are using an SD Memory Card and it is set
for erasure prevention. Change the position of
the protect switch.
• The memory card is full. Erase images ( 122)
or insert a new memory card.
• The power source is not properly connected, or
the battery pack is exhausted or not properly
attached ( 16-17, 137).
• The function cannot be used in that recording
program ( 52).
? The PHOTO button does not work.
• The memory card is not loaded ( 115).
• You are using an SD Memory Card and it is set for
erasure prevention. Change the position of the
protect switch.
• The memory card is full. Erase images ( 122)
or insert a new memory card.
• You have reached the maximum file number. Set
the file numbering to RESET through the menu
( 117) and insert a new memory card.
• You are using an unformatted memory card.
Format the card ( 133).
? The image cannot be erased.
• The image is protected ( 122).
• You are using an SD Memory Card and it is set
for erasure prevention. Change the position of
the protect switch.
E
Additional
Information
145
Additional
Information
E
146
Miscellaneous
Problem
Cause and/or what to do about it
? The wireless controller does not work.
• The remote sensor mode is set to OFFB in
the menu ( 30).
• The remote sensor modes of the wireless
controller and the camcorder itself are different
( 30).
• The batteries are dead or not inserted.
? The power indicator is flashing.
• Check the screen displays (
? There are air bubbles inside the lens.
• This is unlikely, but may happen if you use the
camcorder in places where the air pressure is
low, in an airplane for example. The bubbles will
disappear a week or so after you return the
camcorder to normal atmospheric pressure.
? The camcorder malfunctions.
• External interference may cause the camcorder’s
microprocessor to malfunction temporarily. If
random letters appear in the display or if normal
operation is interrupted, remove and then
replace the power source.
? The DV cable is connected correctly, but
there’s nothing in the display.
• Remove the cable and then reconnect it or turn
the power off and back on again.
? The camcorder becomes warm during
use.
• This is not a malfunction.
137).
The GL2 System Diagram
(Availability differs from area to area)
E
VL-3 Video Light
SS-650 Shoulder Strap
DM-50 Directional
Stereo Microphone
WL-D77
Wireless
Controller
MiniDV
Video
Cassette
CB-920 Car Battery
Adapter
(Available soon)
DC-920
DC Coupler
BP-900 Series
Battery Pack
MA-300 Microphone
Adapter
WD-58H
CA-920 Compact
Power Adapter
BP-900 Series
Battery Pack
CH-910 Dual Battery
Charger/Folder
S-150 S-video Cable
ZR-1000 Zoom
Remote Controller
TV
STV-250N Stereo Video Cable
VCR
220EX/420EX/550EX
Speedlight
CV-150F DV Cable
Digital Device
PC Card Adapter
BP-900 Series
Battery Pack
VL-10Li
Battery
Video Light
SD Memory Card
or
MultiMediaCard
FD Adapter
IFC-300PCU USB Cable
Personal Computer
Stereo Microphone
(commercially
available)
Additional
Information
HC-4100
Sysytem Case
147
Optional Accessories
E
Call or visit your local retailer/dealer for genuine Canon video accessories. You can also obtain
genuine accessories for your Canon camcorder by calling: 1-800-828-4040, Canon U.S.A.
Information Center.
BP-915, BP-930, BP-945 Battery Packs
Extra batteries for use with the GL2.
CB-920 Car Battery Adapter
Power your camcorder, or recharge battery packs on the
move. The car battery adapter plugs into your car’s
cigarette lighter socket and runs off a 12–24 V DC
negative ground battery.
CH-910 Dual Battery Charger/Holder
This holds two battery packs and can charge them both
consecutively. It can then be connected directly to the
GL2 to give twice the recording/playback time. It can
also make use of the high performance battery pack
BP-945, to give up to 14 hrs. recording time.
WD-58H Wide-converter
This lens decreases focal length by a factor of 0.7,
giving you a wide perspective for indoor shots or
panoramic views.
DM-50 Directional Stereo Microphone
This highly sensitive, super-directional microphone
attaches to a camcorder’s advanced accessory shoe. It is
a highly sensitive microphone that can be switched
between functioning as a directional microphone
(monaural) or a stereo microphone that also clearly
picks up sounds arriving from the front of the
microphone, for full recorded sound.
Additional
Information
VL-3 Video Light
148
Attach the Video Light to a camcorder when recording
in dark rooms. When on its automatic setting, the Video
Light turns on/off automatically according to the
brightness level of shooting conditions.
VL-10Li Battery Video Light
E
This compact yet powerful video light can be used for
both indoor and outdoor shooting.
• Use the BP-900 Series battery packs to power the
light. Approximate usage times are as follows:
BP-915: 60 min., BP-930: 120 min., BP-945: 170 min.
220EX/420EX/550EX Speedlite
Attach them to the GL2 to give SLR-style flash
photography.
220EX
420EX
550EX
MA-300 Microphone Adapter
The MA-300 Microphone Adapter enables you to input
audio to the GL2 with XLR connector-equipped
microphones, and to convert video signals for the BNC
connector.
HC-4100 System Case
A solid, lockable case that provides safe and stylish
protection for the camcorder during transportation and
storage.
O
RY CA
SO
VI
INE DE
N GENU
NO
This mark identifies genuine Canon video accessories. When you use Canon video
equipment, we recommend Canon-brand accessories or products bearing the same
mark.
ACCES
Provided accessories:
WL-D77 Wireless Controller
CA-920 Compact Power Adapter
DC-920 DC Coupler
BP-915 Battery Pack
SS-650 Shoulder Strap
S-150 S-video Cable
D83-0582-000
8029A002AA
D85-1400-000
3057A002AA
D81-1350-001
3062A002AA
STV-250N Stereo Video Cable
IFC-300PCU USB Cable
Lens Hood
Large Eye Cup
D82-0590-201
D85-0710-000
D52-0210-000
D54-0110-000
Optional accessories:
3058A002AA
JR 7.2V 10WF Halogen Bulb
4244A002AA
220EX Speedlite (Flash Unit)
8034A002AA
420EX Speedlite (Flash Unit)
3036A002AA
550EX Speedlite (Flash Unit)
8030A001AA
MA-300 Microphone Adapter
3176A002AA (D84-0120-201) MB-100 Microphone Boom
3175A002AA (D86-0121-201) HC-4100 System Case
3140A002AA (D86-0081-201) DVM-CL DV Cleaning Cassette
3141A002AA (D86-0090-201)
C50-0741-201
4590A009AA
2261A003AA (C50-0731-011)
8032A002AA
D89-0200-202
8031A001AA
3134A002AA (D36-0032-201)
Additional
Information
BP-930 Battery Pack
BP-945 Battery Pack
CB-920 Car Battery Adapter
CH-910 Dual Battery Charger/Holder
WD-58H Wide-converter
DM-50 Directional Stereo Microphone
VL-3 Video Light
VL-10Li Battery Video Light
149
Screen Displays
E
You can select to display or hide the operating state of
the camcorder on the LCD screen/viewfinder. The display
also appears on a TV connected to the camcorder.
TV
SCREEN
DATA
CODE
TV Screen Displays
Press the wireless controller’s TV SCREEN button or set TV SCREEN to OFF in the menu to hide the
displays on the TV screen. You can also use the custom key if it is set to TV SCREEN ( 58). (The
displays appear white on the screen.)
Displays will not be superimposed to any recordings you make with the camcorder.
DISP. SET UP
(
TV SCREEN••• ON
20)
To turn TV SCREEN off, open the menu and select DISP.SET UP. Then select TV
SCREEN, set it to OFF and close the menu.
For instructions on connecting to a TV, see p. 95.
Turning Off the LCD Screen Displays
You can turn off the displays to give you a clear screen for playback.
DISP. SET UP
(
DISPLAYS•••• ON
20)
To turn the displays off, open the menu and select DISP. SET UP. Then select
DISPLAYS, set it to OFF <PLAYBK> and close the menu.
Additional
Information
• If you turn the displays off, the LCD screen will be completely blank (also the connected TV
screen), but the camcorder will continue to show warning/caution displays.
• When operating the camcorder, the operating state display appears for 2 seconds. However, the
displays do not disappear when using an index screen.
150
Screen Displays in TAPE CAMERA Mode
E
qwert y
#0
@9
@8
@7
@6
@5
@4
@3
@2
@1
T
SP
REC
MANUAL
0:12:34
S1/500
10sec
60min
F1.8
SELF–T
0dB
j h A1
ON
CP NDMF
VOICE
MF
CHAR.REC
16bit
[DV IF]16:9
FADE–T
U N.Y.
12:00 AM
JAN.15,2002F C
W
u
i
o
!0
!1
!2
!3
!4
!5
!6
#2 @0 !9 !8!7 #1
q White Balance (
80)
w Recording Reminder (
35)/
Self-Timer Countdown (
71)/
Photo Recording Timer
e Image Stabilizer (
46)
r Backup Battery (
138)
t Recording Mode (
37)
y Condensation Warning
(
142)
u Operating Mode (
35)
[REC, PAUSE, EJECT, STOP, K
(Rec Search)]
i Tape Counter
o Remaining Tape
!0 Remaining Battery Charge (
137)
!1 Remote Sensor Mode (
30)
!2 Microphone (
56)/
Microphone Attenuator (
57)
!3 Audio Mode (
56)
!4 Wide Screen Mode (
37)
!5 Photo (
48), Index (
93),
Movie Mode (
50)
!6 Audio Level Indicator (
57)
!7 Self-Timer (
71)/
Interval Timer (
69)
!8 Optional video light,
microphone or microphone
adapter connected
!9 AF/AE Locked in Photo Mode
(
48, 118)
@0
@1
@2
@3
@4
@5
@6
@7
@8
Character Recording (
86)
Data Code (
90)
Time Zone/DST (
32)
Digital Effects (
62)
Manual Focus (
79)
Custom Preset (
83)
Gain (
76)
F Number (
76)
Shutter Speed (
77)/
Exposure Lock (
78)/
AE Shift (
82)
@9 Recording Program (
52)
#0 Zoom (
42)
#1 DV Control (
72)
#2 ND Filter (
47)
Screen Displays in TAPE PLAY (VCR) Mode
q w
!8
!7
!6
!5
!4
SP STOP
0:00:00:00
ST–1
ST–2
60min
INDEX SEARCH
j h A1
TV SCREEN
NORMAL
0dB
16bit
F1.8
16:9
1/500
DV IN
12:00 AM
SPEAKER
JAN. 1,2002
MIX/VARI.
e
r
t
y
u
i
o
!0
!1
!2
!3
y Remaining Battery Charge
(
137)
u Remote Sensor Mode (
30)
i Microphone (
56)
o Audio Mode (
56)
!0 Wide Screen Mode (
37)
!1 DV IN (
99)
!2 Speaker/Headphones Volume
(
89)/Audiio Level Indicator
(
57)
!3
!4
!5
!6
Backup Battery (
138)
Data Code (
90)
Custom Key (
58)
Photo Search/Date Search/
Index Search (
93)/
Audio Dubbing (
108)/
AV Insert (
105)
!7 Mix Balance (
111)
!8 Audio Mix (
111)
Additional
Information
q Recording Mode (
37)
w Condensation Warning
(
142)
e Operating Mode (
87)
[REC, PAUSE, EJECT, STOP,
Special Playback, Audio
Dubbing, AV Insert, etc]
r Tape Counter
t Remaining Tape
151
E
Screen Displays in CARD CAMERA Mode
qw
@2
@1
@0
!9
!8
!7
!6
!5
W
White Balance (
80)
Self-Timer Countdown (
Image Stabilizer (
46)
Image Quality (
115)
Remaining Card Capacity
(
119)
y Image Size (
116)
u Remaining Battery Charge
(
137)
71)
FINE
9999
1488
T
MANUAL
S1/720
F2.0
0dB
ON
CP NDMF
MF
10SEC
SELF–T
j h A1
r
t
y
u
i
12:00 AM
JAN.15,2002F
!4
q
w
e
r
t
e
!3 !2!1
!0 o
i Remote Sensor Mode (
30)
o Condensation Warning
(
142)
!0 Backup Battery (
138)
!1 Self-Timer (
71)
!2 Recording to card (
118)
!3 AF/AE Locked (
48, 118)
!4 ND Filter (
47)
!5 Date and Time (
34)
!6
!7
!8
!9
@0
Manual Focus (
79)
Custom Preset (
83)
Gain (
76)
F Number (
76)
Shutter Speed (
77)/
Exposure Lock (
78)/
AE Shift (
82)
@1 Recording Program (
52)
@2 Zoom (
42)
Screen Displays in CARD PLAY (VCR) Mode
q w
101–0001
9999/9999
1488
!2
!1
TV SCREEN
!0
12:00 AM
JAN.15,2002
j h A1
e
r
t
y
u
oi
q
w
e
r
Additional
Information
Print Mark (
125)
Protect Mark (
124)
File Number (
117)
Current Image/Total Images
(
121)
t Image Size (
116)
152
y Remaining Battery Charge
(
137)
u Remote Sensor Mode (
30)
i Condensation Warning
(
142)
o Backup Battery (
138)
!0 Date and Time (
90)
!1 Custom Key (
58)
!2 Reading from card
Caution Phrases
The camcorder displays various caution phrases for approx. 4 seconds.
E
SET THE TIME ZONE,
DATE AND TIME
Time zone, date and time are not set. This message appears
each time you turn the power on until you set the time zone,
date and time (
32).
Battery pack is exhausted. Replace or charge the battery pack.
CHANGE THE BATTERY PACK
Replace the tape or change the position of the protect switch
THE TAPE IS SET FOR ERASURE
on the cassette (
18, 19).
PREVENTION
REMOVE THE CASSETTE
CHECK THE DV INPUT
CONDENSATION
HAS BEEN DETECTED
The camcorder stopped operating to protect the cassette.
Remove the cassette and retry the operation from the
beginning (
142).
DV cable is not connected, or the connected digital device is
turned off (
99).
Condensation has been detected in the camcorder (
142).
Tape reached the end. Rewind or remove the tape (
88).
TAPE END
CHECK THE CASSETTE
[REC MODE]
CHECK THE CASSETTE
[AUDIO MODE]
CHECK THE CASSETTE
[BLANK]
HEADS DIRTY,
USE CLEANING CASSETTE
Recording is made in 16-bit or 12-bit 4-channel mode. Audio
dubbing not possible (
108).
Camcorder detected a blank section on the tape. Audio
dubbing or AV insert not possible (
105, 108).
Displayed immediately after you start recording when the video
heads are dirty. Clean the video heads (
141).
You attempted to playback a copyright protected tape
(
100).
Additional
Information
COPYRIGHT PROTECTED
PLAYBACK IS RESTRICTED
Recording is made in a mode other than the SP mode. Audio
dubbing or AV insert not possible (
105, 108).
153
E
COPYRIGHT PROTECTED
DUBBING RESTRICTED
You attempted to copy a copyright protected tape. May also
be displayed when an anomalous signal is sent during Analog
Line-in recording (
100, 101).
Memory Card Caution Phrases
Memory card not inserted into the camcorder (
115).
NO CARD
THE CARD IS SET FOR
ERASURE PREVENTION
The SD Memory Card is set for erasure prevention. Replace the
card or change the position of the protect switch (
114).
No title image is recorded on the memory card.
NO TITLES
No images are recorded on the memory card (
118).
NO IMAGES
CARD ERROR
A memory card error occurred. The camcorder cannot
record/play back. The error may be temporary. If CARD ERROR
disappears after 4 seconds and
flashes red, turn the
camcorder’s power off, remove the card and reinsert the card.
If
changes to green, you can continue recording/playback
(
118, 120).
CARD FULL
No free space remaining on the memory card. Replace with
another memory card or erase images (
127).
NAMING ERROR
File or folder numbers have already reached the maximum
value (
117).
UNIDENTIFIABLE IMAGE
The image is recorded in a JPEG format or any format that is
not compatible with the camcorder, or the image contains
corrupted data.
The marked file cannot be edited (
125).
Additional
Information
PRINT MARK ERROR
154
IN CARD POSITION
MEMORY CARD COVER
IS OPEN
Appears when you press the start/stop button in CARD
CAMERA mode to inform you that no image has been
recorded.
The cover of the memory card compartment is open.
Specifications
GL2
Power supply (rated):
Power consumption
(AF turned on):
Television system:
Video recording system:
Audio recording system:
Image sensor:
Tape format:
Tape speed:
Maximum recording time
(80 min. cassette):
Fast forward/rewind time:
Lens:
Focusing system:
Minimum focusing distance:
Maximum shutter speed:
Minimum illumination:
Recommended illumination:
Filter diameter:
Viewfinder:
LCD screen:
Microphone:
Recording media:
Number of recording pixels:
Image format:
File format:
Estimated SD Memory Card
SDC-8M capacities*:
USB terminal:
DV terminal input/output:
E
7.2 V DC
4.8 W (Using viewfinder), 5.7 W (Using LCD screen)
EIA standard (525 lines, 60 fields) NTSC color signal
2 rotary heads, helical scanning DV system (Consumer digital
VCR SD system); Digital component recording
PCM digital sound: 16 bit (48 kHz/2 ch); 12 bit (32 kHz/4 ch);
1/4” 3CCD (charge coupled device), approx. 3 × 410,000
pixels (3 × 380,000 effective pixels)
Videocassettes bearing the “MiniDV” mark.
SP: 3/4 ips (18.81 mm/s), LP: 1/2 ips (12.56 mm/s)
SP: 80 min., LP: 120 min.
Approx. 2 min. 20 sec. (with a 60 min. cassette)
F/1.6-2.9, 20x power zoom, f=4.2-84 mm
TTL autofocus, manual focusing possible
3 ft 3 3/8 in (1 m), 3/8 in (1 cm) on maximum wide angle
1/15,000 sec. (1/720 sec. when using a memory card)
0.37 lx (at 1/8 sec. slow shutter)
More than 100 lx
58 mm
0.44 in, TFT color LCD, approx. 180,000 pixels
2.5 in, TFT color, approx. 200,000 pixels
Stereo electret condenser microphone
SD Memory Card, MultiMediaCard
1488 × 1128 pixels, 640 × 480 pixels
Design rule for Camera File system (DCF), Exif 2.2 compliant*,
Digital Print Order Format (DPOF) compliant (only still images
marked for printing)
* This camcorder supports Exif 2.2 (also called “Exif Print”).
Exif Print is a standard for enhancing the communication
between camcorders and printers. By connecting to an Exif
Print-compliant printer, the camcorder’s image data at the
time of shooting is used and optimized, yielding extremely
high quality prints.
JPEG (compression mode: Fine/ Standard)
1488 × 1128: Fine 6 images/Standard 10 images;
640 × 480: Fine 47 images/ Standard 93 images
* The actual number varies depending on the images.
mini-B
Special 4-pin connector (IEEE 1394 compliant)
Additional
Information
155
A/V terminal input/output:
E
S-video terminal input/output:
MIC terminal input:
Headphone terminal:
LANC terminal:
Operating temperatures:
Dimensions:
Weight:
ø3.5 mm minijack
Audio input:
0 dBV (47 kohm load)/
47 kohms (AUDIO ATT ON)
-10 dBV (47 kohm load)/
47 kohms (AUDIO ATT OFF)
Audio output: 4 dBm (47 kohm load)/3 kohms or less
Video:
1 Vp-p/75 ohms unbalanced
1 Vp-p (Y signal), 0.286 Vp-p (C signal)
ø3.5 mm stereo mini-jack
-35 dBV (with 600 ohm mic)/5.6 kohms (MIC ATT ON)
-55 dBV (with 600 ohm mic)/5.6 kohms (MIC ATT OFF)
ø3.5 mm stereo minijack
ø2.5 mm mini minijack
32 - 104°F (0 - 40°C)
4 5/8 × 5 3/8 × 12 in (118 × 136 × 306 mm)
2 lb 7 1/2 oz (1.12 kg)
CA-920 Compact Power Adapter
Power supply:
Power consumption:
Rated output:
Operating temperature:
Dimensions:
Weight:
100 - 240 V AC, 50/60 Hz
24W
Adapter mode: 7.2 V DC, 2.0 A
Charger mode: 8.4 V DC, 1.5 A
32 - 104°F (0 - 40°C)
3 × 3 7/8 × 2 in (75 × 99 × 51 mm)
7 5/8 oz (215 g) (without power cord)
When replacing the adapter, please return it to the nearest Canon Service Center and replace it
with the same type number CA-920.
The adapter can be used with a power supply between 100 and 240 V AC. For areas where 120
V AC power is not used, you will need a special plug adapter. Contact your nearest Canon
Service Center for further information.
BP-915 Battery Pack
Additional
Information
Battery type:
Rated voltage:
Operating temperature:
Battery capacity:
Dimensions:
Weight:
156
Weight and dimensions are approximate.
Errors and omissions excepted.
Subject to change without notice.
Canon is a trademark of Canon Inc.
Rechargeable Lithium Ion Battery
7.2 V DC
32 - 104°F (0 - 40°C)
1500 mAh
1 1/2 × 3/4 × 2 3/4 in (38.2 × 20.5 × 70.5 mm)
3 3/8 oz (96 g)
Index
16:9 Guides ···············································38
16:9 Wide Screen ······································37
6-Second Auto Date.··································92
‰
Easy Recording ···········································53
Editing to a VCR ········································97
Effects························································62
Erasing a Title ··········································131
Erasing All Print Marks ·····························126
Erasing Still Images···································127
Å
Abroad, Using the Camcorder··················141
Accessories ··········································8, 148
AE Shift······················································82
Analog Line-in··········································101
Analog-Digital Converter··························103
Aperture-Priority Av····································54
Audio Attenuator·····································108
Audio Dubbing ········································108
Audio Level Indicator ···························45, 57
Audio Mix ················································111
Audio Mode···············································56
Audio Monitor ·········································111
Auto ··························································53
Autofocus ··················································79
AV Insert ··················································105
Ï
Faders ························································62
Fast Forward ··············································87
File Numbers ············································117
File Operation ··········································123
Focusing ····················································79
Formatting ···············································133
Frame Mode ··············································50
Ì
Gain···························································76
Grip Belt ····················································15
Grip Zoom ·················································42
Guide Information······································34
ı
Backup Battery·········································138
Battery Charger··········································17
Battery Pack ·······································17, 136
Beep ··························································39
Brightness ··················································44
Ó
Handle Zoom ·············································42
Headphones···············································89
È
Image Quality···········································115
Image Resolution ·····································116
Image Stabilizer··········································46
Index Screen ············································121
Index Write ················································58
Interval Timer ·············································69
Ç
Card Access Display ·································116
Character Recording ··································86
Clear Scan··················································86
Color Bar ···················································67
Color Gain ·················································83
Color Phase················································83
Condensation ··········································142
Connections ······························95, 113, 134
Copying Still Images·································132
Custom Key ···············································58
Custom Preset············································83
Ò
LANC ·························································98
LCD Brightness···········································44
LCD Mirror Mode·······································44
LCD Screen ················································43
Lens Cap····················································14
Lens Hood··················································14
LP Mode ····················································37
Î
˜
Maintenance ············································139
Manual ······················································55
Manual Focus·············································79
Memory Card···········································114
Menus ·······················································20
Microphone ···············································56
Microphone Attenuator ·····························57
Mix Balance ·············································111
Movie Mode ··············································50
Additional
Information
Data Code ·················································90
Date and Time ···········································32
Date Search ···············································93
Daylight Saving Time··································32
DC Coupler················································16
Demonstration Mode ·································39
Digital Effects ·············································62
Digital Zoom ··············································42
DV Control·················································72
DV Dubbing ···············································99
E
157
Ê
ˆ
E
ND Filter·····················································47
Tally Lamp ··················································31
Tape Protection ··········································19
Telephoto ···················································42
Time Code ···········································38, 94
Time Zone··················································32
Title Mix···················································129
Tripod ························································40
Troubleshooting ·······································143
TV Screen···················································95
Ø
Output Channel ·······································111
∏
Photo Search··············································93
Playback
Tape·····················································87
Memory Card·····································120
Playback Pause···········································88
Power Adapter···········································16
Power Save ················································36
Print Mark················································125
Protecting a Title ·····································130
Protecting an Image ·································124
◊
Video Head Cleaning ·······························141
Video ID-1 System································38, 95
Videocassettes ···········································18
Viewfinder ·················································14
Viewfinder Brightness ································44
Â
Record Pause Mode ···································35
Record Review ···········································51
Record Search ············································51
Recording
Tape···············································35, 48
Memory Card·····································118
Recording Mode ········································37
Recording Programs ···································52
Remote Sensor···········································30
Rewind ······················································87
Í
Additional
Information
S1 Video Terminal ······································95
Sand & Snow ·············································55
Screen Displays ········································150
SD Memory Card ·····································114
Self-Timer ··················································71
Setup Level ················································84
Sharpness ··················································83
Shutter Sound··········································117
Shutter Speed ············································77
Shutter-Priority Tv·······································54
Slide Show ···············································121
SP Mode ····················································37
Speaker······················································89
Speedlite ····················································68
Spotlight ····················································55
Standby Lever ············································36
S-video/S1-video ································95, 103
158
„
White Balance············································80
Wide Screen···············································37
Wind Screen ··············································56
Wireless Controller·····································29
Û
Zebra Pattern ·············································85
Zebra Pattern Level ····································85
Zero Set Memory ·······································94
Zoom Speed···············································42
Zooming ····················································42
Menu at a Glance
Camcorder Setting
Submenu
Function
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
CAM. SET UP
DISP. SET UP
DISP. SET UP
CAM. SET UP
VCR SET UP
VCR SET UP
VCR SET UP
DISP. SET UP
VCR SET UP
SYSTEM
DISP. SET UP
SYSTEM
CAM. SET UP
CUSTOM PRESET
CUSTOM PRESET
CARD OPERATION
CUSTOM KEY
DISP. SET UP
DISP. SET UP
DISP. SET UP
SYSTEM
DISP. SET UP
CAM. SET UP
DISP. SET UP
SYSTEM
CARD OPERATION
CARD OPERATION
CARD OPERATION
CARD SET UP
CARD OPERATION
CAM. SET UP
DISP. SET UP
CAM. SET UP
CARD SET UP
CARD SET UP
CAM. SET UP
CAM. SET UP
DISP. SET UP
DISP. SET UP
VCR SET UP
VCR SET UP
CAM. SET UP
VCR SET UP
VCR SET UP
CARD OPERATION
VCR SET UP
CAM. SET UP
Additional
Information
16:9 Effect
16:9 Guides
6-Second Auto Date
AE Shift
Analog-Digital Converter
Audio Attenuator
Audio Dubbing
Audio Level Indicator
Audio Mode
Beep
Card Access Display
Character Recording
Clear Scan
Color Gain
Color Phase
Copying from Card to Tape
Custom Key Set
Custom Key On/Off
Data Code
Date/Time Select
Date/Time Set
Demonstration Mode
Digital Zoom
Displays
DV Control
Erasing a Title
Erasing All Print Marks
Erasing an Image
File Numbers
Formatting
Grip Zoom Speed
Guide Information
Handle Zoom Speed
Image Quality
Image Resolution
Image Stabilizer
Interval Timer
LCD Brightness
LCD Mirror Mode
Microphone
Microphone Attenuator
Movie Mode
Output Channel
Power Save
Protecting a Title
Recording Mode
Self-Timer
E
159
E
Camcorder Setting
Additional
Information
Setup Level
Sharpness
Shutter Sound
Tally Lamp
Time Zone/DST
Title Mix
TV Screen
Viewfinder Brightness
Wireless Controller
Zebra Pattern
Zebra Pattern Level
160
Submenu
Function
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
h
CUSTOM PRESET
CUSTOM PRESET
CARD SET UP
SYSTEM
SYSTEM
→TITLE MIX
DISP. SET UP
DISP. SET UP
SYSTEM
CAM. SET UP
CAM. SET UP
U.S.A.
CANON® GL2 DIGITAL VIDEO CAMCORDER LIMITED WARRANTY
E
The limited warranty set forth below is given by Canon U.S.A., Inc. (“CUSA”) with respect to each Canon GL2 Digital Video
Camcorder (“DV Camcorder”) purchased and used in the United States.
Each Canon DV Camcorder, when delivered to you in new condition in its original container, is warranted against defective material
or workmanship as follows: for a period of one (1) year from the date of original purchase (three (3) months in the case of the video
head part), defective parts or DV Camcorders returned to a CUSA factory service center (“CUSA Center”) or an authorized DV
Camcorder service facility (“Service Facility”), and proven to be defective upon inspection, will be repaired or exchanged for new or
comparable rebuilt parts or DV Camcorders. The warranty period for repaired or replacement parts or DV Camcorders shall begin
upon shipment of the same, but shall in no event exceed the original warranty period of the defective part or DV Camcorder.
Non-Canon brand peripheral equipment and software which may be distributed with Canon DV Camcorders are sold
“AS IS”, without warranty of any kind by CUSA, including any implied warranty regarding merchantability or fitness for
a particular purpose. The sole warranty with respect to such non-Canon brand items is given by the manufacturer or
producer thereof.
CUSA shall have no responsibility under this limited warranty for use of Canon DV Camcorders in conjunction with incompatible
peripheral equipment and incompatible software.
In order to obtain warranty service, contact the authorized Canon retail dealer from whom you purchased the DV Camcorder or call
the CANON INFORMATION CENTER AT 1-800-828-4040 (which is open from 9:00 a.m. to 5:00 p.m. (E.S.T.), Monday through Friday,
excluding holidays). Have your unit serial number and your date of purchase available when you make the call to expedite service. In
either case you will be directed to ship the DV Camcorder, postage prepaid, to the CUSA Center or Service Facility nearest to you.
You must include a copy of the proof of purchase (bill of sale) and a complete explanation of the problem. DV Camcorders covered
by this limited warranty will be repaired and returned to you without charge by the CUSA Center or the Service Facility. Repairs not
under warranty will be at such cost as the CUSA Center or Service Facility may from time to time generally establish.
This limited warranty covers all defects encountered in normal use of the DV Camcorder, and does not apply in the following cases:
(a) Loss of or damage to the DV Camcorder due to abuse, mishandling, improper packaging by you, alteration, accident, leaking
batteries, exterior nicks, scratches or dents, electrical current fluctuations, failure to follow operating instructions, maintenance
and environmental instructions prescribed in CUSA’s instruction manual, or service performed by other than a CUSA Center or
Service Facility.
(b) Use of parts or supplies (other than those sold by CUSA) which cause damage to the DV Camcorder or cause abnormally
frequent service calls or service problems.
(c) If any DV Camcorder has had its serial number or dating altered or removed.
This limited warranty does not apply to accessories or consumables for the DV Camcorder, which are sold “AS IS”, without warranty
of any kind by CUSA.
NO IMPLIED WARRANTY, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, APPLIES TO THE DV CAMCORDER AFTER THE APPLICABLE PERIOD OF EXPRESS WARRANTY STATED ABOVE,
AND NO OTHER EXPRESS WARRANTY OR GUARANTY, EXCEPT AS MENTIONED ABOVE, GIVEN BY ANY PERSON, FIRM OR
CORPORATION WITH RESPECT TO THE DV CAMCORDER SHALL BIND CUSA. (SOME STATES DO NOT ALLOW LIMITATIONS
ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU) CUSA SHALL NOT
BE LIABLE FOR LOSS OF REVENUES OR PROFITS, EXPENSE FOR SUBSTITUTE EQUIPMENT OR SERVICE, STORAGE CHARGES,
LOSS OF DATA, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR
INABILITY TO USE THE DV CAMCORDER, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND
EVEN IF CUSA HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND
AGAINST CUSA BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE DV CAMCORDER SOLD BY CUSA AND
CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, YOU ASSUME ALL RISK AND LIABILITY FOR
LOSS, DAMAGE OR INJURY TO YOU AND YOUR PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF USE,
MISUSE OR INABILITY TO USE THE DV CAMCORDER NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF CUSA. (SOME
STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION MAY NOT APPLY TO YOU.) THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE
ORIGINAL PURCHASER OF ANY DV CAMCORDER, OR THE PERSON FOR WHOM IT WAS PURCHASED AS A GIFT, AND
STATES YOUR EXCLUSIVE REMEDY.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Additional
Information
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, New York 11042
161
CANADA
E
CANON CONSUMER DIGITAL VIDEO EQUIPMENT LIMITED WARRANTY
The limited warranty set forth below is given by Canon Canada Inc. (“Canon Canada”) with respect to Canon digital video
equipment purchased in Canada. This limited warranty is only effective upon presentation of a bill of sale or other proof of purchase
for this Canon digital video equipment to a Canon Service Facility when repairs are required.
Canon consumer video digital equipment is warranted under normal, non-commercial, personal use, against defective materials or
workmanship as follows:
Parts: Defective parts will be exchanged for new parts or, at Canon Canada’s option, comparable rebuilt parts for a period of one
year from the date of original purchase, except Video Heads which will be exchanged for a period of 3 months from the date of
purchase.
Labour: For a period of one year from the date of original purchase, labour will be provided free of charge by our Canon Service
Facilities in Canada.
This limited warranty covers all defects except where:
(a) The loss or damage to the product results from:
i) accident, natural disaster, mishandling, abuse, neglect, unauthorized product modification or failure to follow instructions
contained in the instruction manual;
ii) the use of accessories, attachments, products, supplies, parts or devices with this Canon product that do not conform to
Canon specifications or that cause abnormally frequent service problems;
iii) repairs or services performed by any party other than a Canon Service Facility;
iv) defective batteries or any exposure to water, sand or dirt;
v) shipping (claim must be presented to the shipper);
(b) Any serial number on the video equipment is altered or removed.
(c) The digital video equipment is used for commercial, professional or industrial purposes.
This limited warranty does not cover the cabinet (exterior finish) of the digital video equipment, video cassette tapes, head cleanings,
nor does it apply to digital video equipment purchased outside Canada.
TO OBTAIN WARRANTY SERVICE
Ship your Canon digital video equipment in its original carton, box or equivalent, properly packed, fully insured with shipping
charges prepaid, together with a copy of your bill of sale or other proof of purchase and a description of the problem to any of the
Canon Service Facilities in Canada.
LIMITATIONS
Except as otherwise required by applicable legislation, this warranty is in lieu of all other warranties, conditions, guarantees or
representations, express or implied, statutory or otherwise, relative to this Canon product, including implied warranties or conditions
of merchantability or fitness for a particular purpose.
Canon Canada assumes no liability for special, consequential or incidental damages or loss that may arise, whether on account of
negligence or otherwise, from the use, misuse or inability to use this Canon product (including loss of profit, revenue, video tapes or
enjoyment) or from failure to conform to any express or implied warranties, conditions, guarantees or representations. Any recovery
under this limited warranty shall not exceed the purchase price of the product. Canon Canada does not assume or authorize any
other person to assume for Canon Canada any other liability with respect to this Canon product.
This warranty does not extend to any person other than the original purchaser of this Canon product or the person for whom it was
purchased as a gift and states your exclusive remedy.
Additional
Information
NOTICE TO CONSUMER
If you plan to take important videos or if the product has not been used for some time, please check all functions with the
instruction book before using it.
162
CANON INC.
U.S.A.
CANON U.S.A., INC. NEW JERSEY OFFICE
100 Jamesburg Road, Jamesburg, NJ 08831 USA
CANON U.S.A., INC. CHICAGO OFFICE
100 Park Blvd., Itasca, IL 60143 USA
CANON U.S.A., INC. LOS ANGELES OFFICE
15955 Alton Parkway, Irvine, CA 92618 USA
CANON U.S.A., INC. HONOLULU OFFICE
210 Ward Avenue, Suite 200, Honolulu, HI 96814 USA
● If you have any questions, call the Canon U.S.A. Information
Center toll-free at 1-800-828-4040 (U.S.A. only).
CANADA
CANON CANADA INC. NATIONAL HEADQUARTERS
6390 Dixie Road, Mississauga, Ontario L5T 1P7
CANON CANADA INC. CALGARY
2828, 16th Street, N.E. Calgary, Alberta T2E 7K7
CANON CANADA INC. MONTREAL
5990 Côte de Liesse, Quebec H4T 1V7
● If you have any questions, call the Canon Canada Information
Center toll-free at 1-800-828-4040. (Canada only)
● Si vous avez des questions, veuillez téléphoner sans frais au
Canada 1-800-828-4040. (Canada seulement)
MEXICO
CANON MEXICANA, S. DE R.L. DE C.V.
Periferico Sur No. 4124 Col. Ex-Rancho de Anzaldo C.P. 01900
México, D.F., México
CENTRO Y
SURAMÉRICA
ASIA
CANON LATIN AMERICA, INC.
703 Waterford Way Suite 400 Miami, FL 33126 USA
CANON HONGKONG COMPANY LTD.
9/F, The Hong Kong Club Building, 3A Chater Road, Central, Hong Kong
Printed on 100% reused paper.
Document réalisé avec du papier recyclé à 100%.
El papel aqui utilizado es 100% reciclado.
PUB.DIM-462
0000A/ABXX
© CANON INC. 2002
DY8-9120-347-000
PRINTED IN JAPAN
IMPRIME AU JAPON
IMPRESO EN JAPÓN
