2-Wire-Interfaced, 16-Bit, I/O Port Expander
with Interrupt and Hot-Insertion Protection
Features
The MAX7318 2-wire-interfaced expander provides 16bit parallel input/output (I/O) port expansion for SMBus™
and I2C applications. The MAX7318 consists of input
port registers, output port registers, polarity inversion
registers, configuration registers, and an I2C-compatible
serial interface logic compatible with SMBus. The system master can invert the MAX7318 input data by writing
to the active-high polarity inversion register.
Any of the 16 I/O ports can be configured as an input or
output. A power-on reset (POR) initializes the 16 I/Os
as inputs. Three address select pins configure one of
64 slave ID addresses.
♦ 400kbps I2C-Compatible Serial Interface
The MAX7318 supports hot insertion. All port pins, the
INT output, SDA, SCL, and the slave address inputs
AD0–2 remain high impedance in power-down (V+ =
0V) with up to 6V asserted upon them.
The MAX7318 is available in 24-pin SO, SSOP, TSSOP,
and thin QFN packages and is specified over the -40°C
to +125°C automotive temperature range.
For applications requiring an SMBus timeout function,
refer to the MAX7311 data sheet.
♦ Low Standby Current (5.4µA typ)
Applications
Servers
RAID Systems
Industrial Control
Medical Equipment
PLCs
Instrumentation and Test Measurement
♦ 2V to 5.5V Operation
♦ 5.5V Overvoltage-Tolerant I/Os
♦ Supports Hot Insertion
♦ 16 I/O Pins that Default to Inputs on Power-Up
♦ 100kΩ Pullup on Each I/O
♦ Open-Drain Interrupt Output (INT)
♦ Noise Filter on SCL/SDA Inputs
♦ 64 Slave ID Addresses Available
♦ Polarity Inversion
♦ 4mm ✕ 4mm, 0.8mm Thin QFN Package
♦ -40°C to +125°C Operation
Ordering Information
PART
TEMP RANGE
PIN-PACKAGE
PKG
CODE
MAX7318AWG -40°C to +125°C 24 Wide SO
—
MAX7318AAG
-40°C to +125°C 24 SSOP
—
MAX7318ATG
-40°C to +125°C
MAX7318AUG
-40°C to +125°C 24 TSSOP
24 Thin QFN
(4mm ✕ 4mm)
T2444-4
—
SMBus is a trademark of Intel Corp.
INT 1
I/O11
16
I/O13
17
I/O12
I/O15
18
I/O14
TOP VIEW
AD0
Pin Configurations
15
14
13
24 V+
AD1 2
SCL 19
12 I/O10
SDA 20
11 I/O9
23 SDA
AD2 3
22 SCL
V+ 21
I/O0 4
GND
8
I/O7
AD2 24
7
I/O6
19 I/O14
16 I/O11
I/O6 10
15 I/O10
I/O7 11
14 I/O9
GND 12
13 I/O8
3
4
5
6
I/O5
17 I/O12
I/O5 9
2
I/O4
I/O4 8
1
I/O3
18 I/O13
I/O2
I/O3 7
9
AD1 23
20 I/O15
I/O1
I/O2 6
MAX7318
MAX7318ATG
INT 22
I/O0
I/O1 5
10 I/O8
21 AD0
THIN QFN
TSSOP/SSOP/SO
________________________________________________________________ Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
MAX7318
General Description
MAX7318
2-Wire-Interfaced, 16-Bit, I/O Port Expander
with Interrupt and Hot-Insertion Protection
ABSOLUTE MAXIMUM RATINGS
V+ to GND ................................................................-0.3V to +6V
I/O0–I/O15 as Inputs ....................................(GND - 0.3V) to +6V
SCL, SDA, AD0, AD1, AD2, INT...................(GND - 0.3V) to +6V
Maximum V+ Current......................................................+250mA
Maximum GND Current ...................................................-250mA
DC Input Current on I/O0–I/O15 .......................................±20mA
DC Output Current on I/O0–I/O15 ....................................±80mA
Continuous Power Dissipation (TA = +70°C)
24-Pin Wide SO (derate 11.8mW/°C above +70°C) ....941mW
24-Pin SSOP (derate 8.0mW/°C above +70°C) ...........640mW
24-Pin TSSOP (derate 12.2mW/°C above +70°C) .......976mW
24-Pin Thin QFN (derate 20.8mW/°C above +70°C) .1667mW
Operating Temperature Range .........................-40°C to +125°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
DC ELECTRICAL CHARACTERISTICS
(V+ = 2V to 5.5V, TA = -40°C to +125°C, unless otherwise noted. Typical values are at V+ = 3.3V, TA = +25°C.) (Note 1)
PARAMETER
SYMBOL
Supply Voltage
V+
Supply Current
I+
Standby Current
Power-On Reset Voltage
ISTBY
CONDITIONS
MIN
TYP
2.0
All I/Os unloaded,
fSCL = 400kHz
All I/Os unloaded,
fSCL = 0
MAX
UNITS
5.5
V
V+ = 2V
24
V+ = 3.3V
45
62
V+ = 5.5V
83
124
V+ = 2V
4.8
12.1
V+ = 3.3V
5.4
14.4
V+ = 5.5V
6.4
19.4
1.4
1.7
V
0.3 x V+
V
0.4
V
+1
µA
VPOR
36
µA
µA
SCL, SDA
Input-Voltage Low
VIL
Input-Voltage High
VIH
Low-Level Output Voltage
VOL
Leakage Current
0.7 x V+
V
ISINK = 6mA
IL
-1
Input Capacitance
10
pF
I/O_
Input-Voltage Low
VIL
Input-Voltage High
VIH
0.8
1.8
Input Leakage Current
TA = -40°C to +85°C; includes internal
pullup current, VIO = V+
Internal Pullup Current
TA = -40°C to +85°C, VIO = 0
Low-Level Output Current
ISINK
34
V+ = 2V, VOL = 0.5V
8.5
17
V+ = 3.3V, VOL = 0.5V
17
32
V+ = 5V, VOL = 0.5V
High Output Current
ISOURCE
V+ = 3.3V, VOH = 2.4V
V
V
1
µA
100
µA
mA
43
29
V+ = 5V, VOH = 4.5V
41
mA
31
AD0, AD1, AD2
Input-Voltage Low
VIL
Input-Voltage High
VIH
2
0.3 x V+
0.7 x V+
_______________________________________________________________________________________
V
V
2-Wire-Interfaced, 16-Bit, I/O Port Expander
with Interrupt and Hot-Insertion Protection
(V+ = 2V to 5.5V, TA = -40°C to +125°C, unless otherwise noted. Typical values are at V+ = 3.3V, TA = +25°C.) (Note 1)
PARAMETER
SYMBOL
CONDITIONS
Leakage Current
MIN
TYP
-1
Input Capacitance
MAX
UNITS
+1
µA
4
pF
INT
Low-Level Output Current
IOL
VOL = 0.4V
6
mA
AC ELECTRICAL CHARACTERISTICS
(V+ = 2V to 5.5V, TA = -40°C to +125°C, unless otherwise noted.) (Note 1)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
400
kHz
SCL Clock Frequency
fSCL
Bus Free Time Between STOP
and START Conditions
tBUF
Figure 2
1.3
µs
Hold Time (Repeated) START
Condition
tHD,STA
Figure 2
0.6
µs
Repeated START Condition
Setup Time
tSU,STA
Figure 2
0.6
µs
STOP Condition Setup Time
tSU,STO
Figure 2
0.6
Data Hold Time
tHD,DAT
Figure 2 (Note 2)
Data Setup Time
tSU,DAT
Figure 2
100
ns
SCL Low Period
tLOW
Figure 2
1.3
µs
SCL High Period
tHIGH
Figure 2
0.7
SDA Fall Time
tF
Figure 2 (Notes 3, 4)
Pulse Width of Spike Suppressed
tSP
(Note 5)
tPV
Figure 7
µs
0.9
µs
µs
V+ < 3.3V
500
V+ ≥ 3.3V
250
50
ns
ns
PORT TIMING
Output Data Valid
3
µs
Input Data Setup Time
27
µs
Input Data Hold Time
0
µs
INTERRUPT TIMING
Interrupt Valid
tIV
Figure 9
30.5
µs
Interrupt Reset
tIR
Figure 9
2
µs
Note 1: All parameters are 100% production tested at TA = +25°C. Specifications over temperature are guaranteed by design.
Note 2: A master device must internally provide a hold time of at least 300ns for the SDA signal (referred to the VIL of the SCL
signal) to bridge the undefined region SCL’s falling edge.
Note 3: CB = total capacitance of one bus line in pF.
Note 4: The maximum tF for the SDA and SCL bus lines is specified at 300ns. The maximum fall time for the SDA output stage tF is
specified at 250ns. This allows series protection resistors to be connected between the SDA and SCL pins and the SDA/SCL
bus lines without exceeding the maximum specified tF.
Note 5: Input filters on the SDA and SCL inputs suppress noise spikes less than 50ns.
_______________________________________________________________________________________
