Intel Quality System Handbook April 2014

Intel Quality System Handbook April 2014

Intel Quality System Handbook

April 2014

Intel Quality System Handbook

December 2013

2

Revision History

Date Revision Notes

April 2014 7.0

December 2013 6.0

June 2011 5.0

December 2009 4.0

September 2008 3.0

August 2006 2.0

November 2005 1.0

Reformatted for Intel Clear Font, new cover layout

Chapter 1 - Removed reference to previous CEO, Paul S Otellini

Minor edits within all chapters. Reformatted.

Chapter 3- Consolidated and reorganized content

Chapter 4 –Rewrite of PRQ Report Milestone paragraph, Section

4.3.4

Chapter 5 – Global replacement of the term Platform with Modules;

Revised Figure 5.4

Chapter 7 – Rewrite of section 7.2.1; Revised section 7.2.5; Modified figure 7-1

Added 48/14 content, completed other minor edits

Updated corporate mission, modified section 7.2.3, revised typography and graphics, completed other minor edits.

Released

Intel Quality System Handbook 2014

3

Disclaimers

The information contained in this document is provided for informational purposes only and represents the current view of Intel Corporation (“Intel”) and its contributors (“Contributors”) on quality, as of the date of publication. Intel and the Contributors make no commitment to update the information contained in this document, and Intel reserves the right to make changes at any time, without notice.

THIS DOCUMENT IS PROVIDED “AS IS.” NEITHER INTEL, NOR THE CONTRIBUTORS MAKE ANY REPRESENTATIONS OF

ANY KIND WITH RESPECT TO PRODUCTS REFERENCED HEREIN, WHETHER SUCH PRODUCTS ARE THOSE OF INTEL,

THE CONTRIBUTORS, OR THIRD PARTIES. INTEL, AND ITS CONTRIBUTORS EXPRESSLY DISCLAIM ANY AND ALL

WARRANTIES, IMPLIED OR EXPRESS, INCLUDING WITHOUT LIMITATION, ANY WARRANTIES OF MERCHANTABILITY,

FITNESS FOR ANY PARTICULAR PURPOSE, NON-INFRINGEMENT, AND ANY WARRANTY ARISING OUT OF THE

INFORMATION CONTAINED HEREIN, INCLUDING WITHOUT LIMITATION, ANY PRODUCTS, SPECIFICATIONS, OR OTHER

MATERIALS REFERENCED HEREIN. INTEL, AND ITS CONTRIBUTORS DO NOT WARRANT THAT THIS DOCUMENT IS

FREE FROM ERRORS, OR THAT ANY PRODUCTS OR OTHER TECHNOLOGY DEVELOPED IN CONFORMANCE WITH THIS

DOCUMENT WILL PERFORM IN THE INTENDED MANNER, OR WILL BE FREE FROM INFRINGEMENT OF THIRD PARTY

PROPRIETARY RIGHTS, AND INTEL, AND ITS CONTRIBUTORS DISCLAIM ALL LIABILITY THEREFOR.

INTEL, AND ITS CONTRIBUTORS DO NOT WARRANT THAT ANY PRODUCT REFERENCED HEREIN OR ANY PRODUCT OR

TECHNOLOGY DEVELOPED IN RELIANCE UPON THIS DOCUMENT, IN WHOLE OR IN PART, WILL BE SUFFICIENT,

ACCURATE, RELIABLE, COMPLETE, FREE FROM DEFECTS OR SAFE FOR ITS INTENDED PURPOSE, AND HEREBY

DISCLAIM ALL LIABILITIES THEREFOR. ANY PERSON MAKING, USING OR SELLING SUCH PRODUCT OR TECHNOLOGY

DOES SO AT HIS OR HER OWN RISK.

Licenses may be required. Intel, its contributors and others may have patents or pending patent applications, trademarks, copyrights or other intellectual proprietary rights covering subject matter contained or described in this document. No license, express, implied, by estoppel or otherwise, to any intellectual property rights of Intel or any other party is granted herein. It is your responsibility to seek licenses for such intellectual property rights from Intel and others where appropriate.

Limited License Grant. Intel hereby grants you a limited copyright license to copy this document for your use and internal distribution only. You may not distribute this document externally, in whole or in part, to any other person or entity.

LIMITED LIABILITY. IN NO EVENT SHALL INTEL, OR ITS CONTRIBUTORS HAVE ANY LIABILITY TO YOU OR TO ANY

OTHER THIRD PARTY, FOR ANY LOST PROFITS, LOST DATA, LOSS OF USE OR COSTS OF PROCUREMENT OF

SUBSTITUTE GOODS OR SERVICES, OR FOR ANY DIRECT, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING

OUT OF YOUR USE OF THIS DOCUMENT OR RELIANCE UPON THE INFORMATION CONTAINED HEREIN, UNDER ANY

CAUSE OF ACTION OR THEORY OF LIABILITY, AND IRRESPECTIVE OF WHETHER INTEL, OR ANY CONTRIBUTOR HAS

ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES. THESE LIMITATIONS SHALL APPLY NOTWITHSTANDING

THE FAILURE OF THE ESSENTIAL PURPOSE OF ANY LIMITED REMEDY.

Copyright © 2000-2014, Intel Corporation. All rights reserved.* Other names and brands may be claimed as the property of others.

Intel Quality System Handbook 2014

4

Table of Contents

1

THE INTEL QUALITY POLICY ......................................................................................................................................................................................... 7

2

INTEL’S QUALITY MANAGEMENT SYSTEM .......................................................................................................................................................... 8

2.1

Q

UALITY

M

ANAGEMENT

S

YSTEM

(QMS) F

RAMEWORK

............................................................................................................................................................ 8

2.1.1

Intel’s Mission and Values .............................................................................................................................................................................. 8

2.1.2

Intel’s Quality Policy ........................................................................................................................................................................................... 9

2.1.3

Elements of Intel’s QMS................................................................................................................................................................................. 10

2.2

Q

UALITY

D

OCUMENTATION

S

YSTEM

............................................................................................................................................................................................. 13

2.2.1

Document Structure ......................................................................................................................................................................................... 13

2.2.2

Document Control ............................................................................................................................................................................................. 14

3

TECHNOLOGY DEVELOPMENT ................................................................................................................................................................................. 16

3.1

M

OORE

S

L

AW AND THE

I

MPACT OF

S

CALING

............................................................................................................................................................................. 16

3.2

T

ECHNOLOGY

D

EVELOPMENT TO

P

RODUCTION

........................................................................................................................................................................ 17

3.2.1

Stress-Based and Knowledge-Based Testing ................................................................................................................................ 19

3.2.2

Key Challenges to Certification of Logic Technology Processes ....................................................................................... 20

3.2.3

Key Challenges to Certification of Flash Memory ........................................................................................................................ 22

3.2.4

Key Challenges to Package Certification .......................................................................................................................................... 23

3.2.5

Key Challenges to Test Certification .................................................................................................................................................... 23

3.2.6

Key Challenges to Board-Stack Ingredient Certification ........................................................................................................ 24

4

PRODUCT DEVELOPMENT ........................................................................................................................................................................................... 25

4.1

P

RODUCT

Q

UALIFICATION

S

YSTEM

................................................................................................................................................................................................ 25

4.2

I

NTEL

P

RODUCT

L

IFE

C

YCLE

.............................................................................................................................................................................................................. 26

4.3

P

RODUCT

Q

UALIFICATION AND THE

I

NTEL

P

RODUCT

L

IFE

C

YCLE

...................................................................................................................................... 26

4.3.1

Exploration Phase ............................................................................................................................................................................................. 27

4.3.2

Planning Phase ................................................................................................................................................................................................... 28

4.3.3

Development Phase ......................................................................................................................................................................................... 28

4.3.4

Production Phase .............................................................................................................................................................................................. 29

4.4

V

ALIDATION

............................................................................................................................................................................................................................................. 30

4.4.1

Pre-Silicon Validation ..................................................................................................................................................................................... 30

4.4.2

Post-Silicon Validation .................................................................................................................................................................................. 31

4.4.3

Software Validation ......................................................................................................................................................................................... 32

4.5

P

RODUCT

T

RANSFER TO

M

ANUFACTURING

................................................................................................................................................................................. 32

5

MATERIALS QUALITY ...................................................................................................................................................................................................... 33

5.1

M

ATERIALS

Q

UALITY

S

YSTEM

M

ODULES

..................................................................................................................................................................................... 33

5.1.1

Materials QOS Module One - Supplier Selection ......................................................................................................................... 34

5.1.2

Materials QOS Module Two - Materials and Supplier Qualification ............................................................................... 35

5.1.3

Materials QOS Module Three - Supplier PCS and Excursion Management ............................................................... 36

5.1.4

Materials QOS Module Four - Supplier Continuous Improvement ................................................................................... 37

5.1.5

Supplier Continuous Quality Improvement Program ................................................................................................................ 38

5.2

M

ETROLOGY

L

ABS

................................................................................................................................................................................................................................. 39

5.3

S

UBCONTRACTOR

/O

UTSOURCING

Q

UALITY

............................................................................................................................................................................... 39

6

MANUFACTURING QUALITY SYSTEMS ............................................................................................................................................................... 40

6.1

F

ACTORY

O

VERVIEW

............................................................................................................................................................................................................................ 40

6.2

E

NVIRONMENTAL

C

ITIZENSHIP

......................................................................................................................................................................................................... 40

6.3

C

OPY

E

XACTLY

! ...................................................................................................................................................................................................................................... 41

6.3.1

Process Change Management .................................................................................................................................................................. 42

Intel Quality System Handbook 2014

6.4

M

ANUFACTURING

S

YSTEMS

............................................................................................................................................................................................................... 43

6.4.1

Factory Process Control ................................................................................................................................................................................ 43

6.4.2

Continuous Improvement of Products and Services .................................................................................................................. 43

6.4.3

Monitors and Manufacturing Quality Audits ................................................................................................................................... 44

6.4.4

Factory Environmental Control ................................................................................................................................................................ 45

6.5

C

ONTROL OF

I

NSPECTION

, M

EASURING AND

T

EST

E

QUIPMENT

.......................................................................................................................................... 45

6.5.1

Calibration Traceability ................................................................................................................................................................................ 46

6.5.2

Calibration Capability .................................................................................................................................................................................... 46

6.5.3

Calibration Intervals and Records .......................................................................................................................................................... 47

6.6

C

ONTROL OF

N

ONCONFORMING

P

RODUCT

................................................................................................................................................................................. 47

6.7

P

RODUCT

I

DENTIFICATION AND

T

RACEABILITY

........................................................................................................................................................................... 48

6.7.1

Latest Generation CPU and Chipset Product Identification .................................................................................................. 48

6.7.2

Boards and Systems Product Identification .................................................................................................................................... 48

6.7.3

Records Retention/Retrieval ....................................................................................................................................................................... 49

7

CUSTOMER SUPPORT .................................................................................................................................................................................................... 50

7.1

S

UPPORT

N

ETWORK

O

PERATIONS

................................................................................................................................................................................................. 50

7.2

C

USTOMER

Q

UALITY

S

UPPORT AND

S

ERVICES

.......................................................................................................................................................................... 51

7.2.1

Compliance to Product Regulations - Responsible Product Design ............................................................................... 51

7.2.2

Manufacturing Enabling ............................................................................................................................................................................... 51

7.2.3

Product Change Management ................................................................................................................................................................. 52

7.2.4

Order Fulfillment Quality.............................................................................................................................................................................. 56

7.2.5

Technical Quality ............................................................................................................................................................................................... 58

7.2.6

Returns Management ..................................................................................................................................................................................... 59

7.2.7

Measuring Customer Satisfaction .......................................................................................................................................................... 60

8

SYNOPSIS ............................................................................................................................................................................................................................... 62

5 Intel Quality System Handbook 2014

6

Figures

F

IGURE

2-1: I

NTEL

S

V

ALUES AND

S

UPPORTING

B

EHAVIORS

............................................................................................................................................................. 9

F

IGURE

2-2: I

NTEL

S

Q

UALITY

M

ANAGEMENT

S

YSTEM

E

LEMENTS

............................................................................................................................................... 10

F

IGURE

2-3: C

ORPORATE

P

LANNING

P

ROCESS

: S

TRATEGIC

P

LANNING

C

YCLE

........................................................................................................................ 11

F

IGURE

2-4: A F

UNCTIONAL

V

IEW OF

I

NTEL

S

M

AJOR

O

PERATIONS

........................................................................................................................................... 12

F

IGURE

2-5: Q

UALITY

R

ELATED

F

UNCTIONS

.......................................................................................................................................................................................... 12

F

IGURE

2-6: QMS E

LEMENTS

, O

PERATIONS

,

AND

F

UNCTIONS

...................................................................................................................................................... 13

F

IGURE

2-7: Q

UALITY

D

OCUMENT

H

IERARCHY

..................................................................................................................................................................................... 14

F

IGURE

3-1: I

NCREASING

C

HIP TO

P

ACKAGE

C

ONNECTIONS

........................................................................................................................................................... 16

F

IGURE

3-2: P

HASES OF

T

ECHNOLOGY

D

EVELOPMENT

..................................................................................................................................................................... 17

F

IGURE

3-3: R

ELIABILITY

S

TRESS

C

ONDITIONS AND

D

URATIONS

.................................................................................................................................................. 20

F

IGURE

4-1: P

RODUCT

Q

UALIFICATION

S

YSTEM

A

RCHITECTURE

E

LEMENTS

............................................................................................................................ 25

F

IGURE

4-2: I

NTEL

S

P

RODUCT

L

IFE

C

YCLE

............................................................................................................................................................................................ 26

F

IGURE

4-3: P

RODUCT

Q

UALIFICATION

PLC M

ILESTONES

.............................................................................................................................................................. 27

F

IGURE

5-1: M

ATERIALS

Q

UALITY

N

ETWORK

I

NTERRELATIONSHIPS

............................................................................................................................................ 33

F

IGURE

5-2: S

UPPLIER

S

ELECTION

P

ROCESS

S

TEPS

........................................................................................................................................................................... 35

F

IGURE

5-3: E

LEMENTS OF

P

ROCESS

C

ONTROL AND

E

XCURSION

M

ANAGEMENT

................................................................................................................... 36

F

IGURE

5-4: S

UPPLIER

C

ONTINUOUS

Q

UALITY

I

MPROVEMENT

C

YCLE

........................................................................................................................................ 37

F

IGURE

5-5: S

UPPLIER

A

WARDS

P

ROGRESSION

................................................................................................................................................................................... 39

F

IGURE

6-1: C

OPY

E

XACTLY

!

M

ETHODOLOGY

...................................................................................................................................................................................... 41

F

IGURE

6-2: R

ESULTS OF

C

OPY

E

XACTLY

!

M

ETHODOLOGY

............................................................................................................................................................. 42

F

IGURE

6-3: C

ALIBRATION

T

RACEABILITY

C

HAIN

................................................................................................................................................................................. 46

F

IGURE

6-4: I

NVENTORY

M

ANAGEMENT

S

YSTEM

................................................................................................................................................................................. 49

F

IGURE

7-1: C

OMMUNICATION AND

N

OTIFICATION

F

LOW

............................................................................................................................................................... 53

Tables

T

ABLE

5-1: K

EY

M

ATERIALS

QOS M

ODULES AND

O

UTCOMES

..................................................................................................................................................... 34

T

ABLE

7-1: M

INIMUM

C

ORPORATE

G

UIDELINES FOR

PCN N

OTIFICATION

................................................................................................................................. 55

T

ABLE

7-2: IA CPU P

RODUCTS

.................................................................................................................................................................................................................. 55

T

ABLE

7-3: F

LASH

P

RODUCT

G

ROUP

....................................................................................................................................................................................................... 56

T

ABLE

7-4: O

RDER

F

ULFILLMENT

Q

UALITY

I

SSUES

D

EFINITIONS

.................................................................................................................................................. 57

Intel Quality System Handbook 2014

1 The Intel Quality Policy

Intel’s mission is to “delight our customers, employees, and shareholders by relentlessly delivering the platform and technology advancements that become essential to the way we work and live“. Our commitment to quality is an essential ingredient of our corporate culture and values, is a fundamental part of our corporate systems and processes, and is articulated in our Corporate Business Principle:

Intent – lntel’s products symbolize world-class leadership in technology and performance, outstanding quality, and lasting reliability. All employees share the responsibility to sustain and improve product quality for our customers.

Policy Statement – We strive to maintain the highest standards and ship product that meets our stated goals. If and when a problem arises, we will quickly communicate with our customer on the issue and take action to resolve the problem.

World-class quality leadership is a top priority as semiconductor geometries relentlessly continue to shrink in accordance with Moore’s Law. As we design chips with billions of transistors, the real key is world-class manufacturing control and robust design practices working together to produce reliable and technologically superior products. Intel achieves world-class quality through operational excellence, continual improvement, and satisfying customer needs in everything we do. We are committed to delivering the quality and reliability that is worthy of our customers’ trust and enables our products to connect people with information and touch lives around the world.

7 Intel Quality System Handbook 2014

8

2 Intel’s Quality Management System

Over 40 years ago, Intel co-founder Gordon Moore forecast the rapid pace of technology innovation. His prediction, popularly known as “Moore’s Law,” states that transistor density of integrated circuits doubles about every two years.

(For more information on Moore’s Law, see http://www.intel.com/pressroom/kits/events/moores_law_40th/index.htm

.)

The semiconductor industry is a tough proving ground for a company’s commitment to quality. Intel’s status as a global leader in semiconductor manufacturing relies upon a relentless pursuit of defect reduction, and a tremendous investment in innovation to deliver ever-increasing value to our customers.

Intel’s brand name stands for technology and safety worldwide. Intel pursues innovation and improvement in all of our business processes, systems, and methods. Rather than simply detect and correct defects in the later stages of production, Intel strives to build quality and reliability into every step of our design, development, and manufacturing processes. The Intel Quality Management System provides the framework to meet the challenges of this competitive and innovative environment.

2.1 Quality Management System (QMS) Framework

Intel established the Quality Management System (QMS) as the foundation for customer satisfaction and continuous improvements in all aspects of our business. The quality management system is based on the customer-supplier relationship and provides a framework for managing the activities used to develop and deliver quality products that consistently satisfy customer and other external requirements. QMS is deeply rooted in Intel’s culture, our corporate mission and values, business principles, actions, and results.

Improving QMS is an ongoing process throughout Intel organizations.

2.1.1 Intel’s Mission and Values

Intel’s QMS begins with the responsibility of management to define how the organization will conduct business. Intel’s corporate mission and values statements guide these business plans.

Intel’s Mission — Delight our customers, employees, and shareholders by relentlessly delivering the platform and technology advancements that become essential to the way we work and live.

Intel’s Corporate Values — Intel’s corporate values and supporting behaviors provide employees with effective ways to create a work culture that strongly supports Operational Excellence. Our values of Customer Orientation, Discipline, Quality, Risk Taking, Great Place to Work, and Results

Orientation define Intel’s commitment to excellence in both the marketplace and the work place

( Figure 2-1 ).

Intel Quality System Handbook 2014

9

Figure 2-1: Intel’s Values and Supporting Behaviors

Through these values and the behaviors, Intel seeks to:

• Continuously improve the customer-perceived value of our products, processes and people

• Continuously improve our efficiency and performance of all activities

• Continuously reduce our total cost of doing business

2.1.2 Intel’s Quality Policy

Intel’s management is committed to the integration of quality principles into our management systems. They have established a clear quality policy and embedded it in our corporate business

principles. Refer to Intel’s Quality Policy in Section 1.0 for details.

Intel Quality System Handbook 2014

2.1.3 Elements of Intel’s QMS

Intel’s Quality Management System consists of four key elements: 1) Plan, 2) Organize, 3) Execute,

and 4) Monitor ( Figure 2-2 ). Intel uses these elements to achieve customer satisfaction by driving our

management processes and providing a framework for ensuring predictable and consistent planning, development, quality, and service support. Intel’s QMS promotes customer focus, clear management responsibility, a process approach to doing work, and continuous improvement of the system.

10

Figure 2-2: Intel’s Quality Management System Elements

Plan — Quality is the result of proper planning and regularly reviewing and adjusting plans. Intel

management uses the Corporate Planning Process ( Figure 2-3 ) to review organizational performance

for customer and market needs, and to direct changes in the way we perform work. The Corporate

Planning Process begins with a current situation analysis that identifies areas needing strategic focus. This involves a variety of tools and activities, such as customer satisfaction surveys and competitive benchmarks. The Corporate Planning Process also uses assessments of our future direction, our industry, the economy, environmental trends, and other factors. With this information,

Intel prepares to develop or revise our strategic long-range plan. Typically encompassing a three- to five-year outlook, the strategic long-range plan serves as the basis for Intel’s annual plan.

Intel Quality System Handbook 2014

11

Figure 2-3: Corporate Planning Process: Strategic Planning Cycle

The annual product-line business plan identifies corporate objectives for each business group.

Business groups then define strategies and tactics to meet corporate objectives. The approved tactics evolve into projects and programs that form the plan of record. Intel evaluates these plans on a quarterly basis to track progress.

This planning sequence—situation analysis, strategic long-range planning, annual planning and quarterly reviews—ensures that individual employee, department and group plans positively affect our corporate business objectives. Plans nest vertically in the organization and resources align crossfunctionally to optimize the interfaces between organizations.

Organize — Resource management is required to carry out the organization’s work for satisfying customer quality needs and maintaining the system. The scope of resource management includes chartering of groups to do work, and providing funding, people, training, tools, and methods.

Intel sets the project priorities and allocates resources (money and people) based on business priorities. This funding method, combined with specific planning processes, aligns the quality resources necessary to achieve business objectives down to the project level.

Intel University develops and delivers training, utilizing both internal and external resources, to upgrade the skills and knowledge of all employees. Employee training courses include quality and reliability concepts, methods, and tools. The Corporate Quality Network’s (CQN) College of Quality

(COQ) provides these training courses through the Intel University systems to employees worldwide.

Execute — This QMS element encompassed the activity needed to create Intel’s products and services and deliver them to its customers. Structured business processes define how to execute

work across all major operations in the company. Intel’s five major operations are ( Figure 2-4 ):

Intel Quality System Handbook 2014

Figure 2-4: A Functional View of Intel’s Major Operations

Technology Development — Enables Intel’s products to provide better value through improved performance, increased functionality, or smaller size

Product Development — Processes used to take a product from market research through production and eventually to product discontinuance

Materials Management — Provides materials and services for production to meet agreed upon requirements, lead times and pricing

Manufacturing — Enables quality production by understanding customer quality requirements and implementing processes that help ensure operations meet these requirements

Customer Support — Provides customer assistance by understanding, documenting, analyzing, and resolving customer issues

These five major operations integrate to form the “Execute” element of Intel’s QMS. Each operation

has a quality management system that performs the quality related functions as shown in Figure 2-5 .

12

Figure 2-5: Quality Related Functions

Monitor — Intel’s Quality System provides the framework for ensuring predictable, consistent product planning, product development, product quality, and quality service support. Intel regularly reviews how well we deliver value to our customers and we believe that strong business results are our ultimate measure of success.

We regularly monitor and evaluate results from all of our key operations, processes, products, services, customers and suppliers. Based on these evaluations, quality management teams understand opportunities for improvement, prioritize actions, and provide resources. Execution teams may address one or more specific issues as part of their charter.

Intel Quality System Handbook 2014

Figure 2-6 shows the overall relationships between Intel QMS elements, and the operations and

functions they support. Chapters 3 through 7 provide further details on the quality systems supporting each operation.

13

Figure 2-6: QMS Elements, Operations, and Functions

2.2 Quality Documentation System

Intel’s quality documentation system is comprised of a document structure hierarchy and a network of document control centers.

2.2.1 Document Structure

Figure 2-7 shows Intel’s document structure. Moving from the top of this structure downward,

documents become more specific in their purpose and scope, and document content becomes increasingly detailed.

Intel Quality System Handbook 2014

14

Figure 2-7: Quality Document Hierarchy

Corporate Business Principles represent Intel’s leadership principle and occupy the peak of Intel’s document structure. They are guidance for making key decisions and apply to all Intel employees through group guidelines.

Group Guidelines are high-level requirements for achieving synergy across operations, and consist of major policies/guidelines, high level requirements and organizational roles and responsibilities.

Governing Specifications are requirements to achieve synergy across operations and groups, and include detailed methodologies, best-known methods, specific criteria, requirements, and roles and responsibilities. These roles and responsibilities govern operational policies and procedures and apply to several operations in a business group or across business groups.

Operational Policy/Guidelines are requirements to define roles and responsibilities, and requirements for a specific operation or function within a business group.

Operational Procedures are systematic instructions, details of execution and supporting information for a specific operation or function within a business group.

2.2.2 Document Control

Intel has an extensive system for ensuring quality documentation using document control and engineering change control. The Document Control Management System incorporates requirements for quality assurance, assessment, and improvement. It encompasses specifications that represent the cumulative technical expertise of design, development, and manufacturing activities.

Corporate Document Control acts as a centralized focal point for developing, implementing, standardizing, and controlling Intel specifications worldwide. It also provides guidelines to over 50 satellite Document Control Centers (DCCs). DCCs are located at Intel facilities to support geographically dispersed organizations, and DCC guidelines indicate minimum requirements for controlling and handling Intel documents. Each DCC supplements the guidelines with requirements specific to local organizational and customer needs.

Intel Quality System Handbook 2014

Control of Quality Records — Intel maintains quality records that demonstrate the effectiveness of our quality system and achievement of required quality system standards. Quality records are critical tools for analyzing results and trends. They not only enable us to determine the need for corrective action, but also help us track ongoing improvements.

Intel has established procedures for identifying, collecting, indexing, filing, storing, maintaining, and disposing of quality records. Quality records for a given product, whether centrally located or retained by individual organizations, are identifiable, retrievable, and legible. Intel’s Corporate

Records Management has procedures for submitting records to off-site storage and for retrieving them. These procedures also state minimum record retention periods. Quality records in electronic format are available on-line and are subject to regular backup according to documented procedures.

15 Intel Quality System Handbook 2014

3 Technology Development

Technology Development produces a set of core technologies shared by many Intel products. Intel utilizes combinations of silicon technologies, package technologies, test technologies, and board technologies to bring products to market.

Silicon Technology — The fabrication process used to create integrated circuits (IC) on silicon wafers by adding and patterning the layers that form transistors and interconnects.

Package Technology — The assembly process used to enclose silicon ICs in an electronic package with connections accessible to the user.

Test Technology — The test process, from wafer sort through package-level test and burn-in, designed to ensure that shipped devices meet quality and data sheet requirements.

Board Technology — The design and fabrication of printed circuit boards using multiple components.

3.1 Moore’s Law and the Impact of Scaling

Over 40 years ago, Intel co-founder Gordon Moore forecasted the rapid pace of technology innovation. His prediction, popularly known as “Moore’s Law,” states that transistor density on integrated circuits doubles about every two years. Today, Intel continues to lead the industry, driving Moore’s Law to increase functionality and performance and decrease costs, bringing growth to industries worldwide. For additional information on Moore’s Law, refer to http://www.intel.com/pressroom/kits/events/moores_law_40th/index.htm

.

In addition to the progress made in silicon technologies, generational advancement has occurred in package, test, and board technologies. For example, as processor performance increases with improvements in process technologies, the demand on packaging solutions also increases. Device input/output (I/O)

requirements increase the number of connections of chip-to-package or within a package ( Figure 3-1 ), and

also increase demand on package interconnects to deliver more complex thermal, power delivery, and signal integrity solutions.

16

Figure 3-1: Increasing Chip to Package Connections

Intel Quality System Handbook 2014

Smaller transistors consume less power, but as transistor density and speed rise, the chip consumes more overall power and generates more heat. In addition, leakage — the continued flow of current even when the transistor is “off” — becomes more problematic, wasting a higher portion of total device power. Power densities are increasing exponentially and the thermal impact to quality and reliability is growing in complexity. To meet this challenge, Intel has developed a variety of novel power-saving techniques, such as new transistor structures and materials, innovative approaches to circuit and micro-architecture design, and advanced packaging materials and system components.

3.2 Technology Development to Production

Developing and certifying new processes for wafer fabrication, package, test, and board manufacturing is the responsibility of Intel’s Technology Development organization. Technology certification demonstrates the quality and reliability of the technology and ensures that interactions between technologies (for example, between a silicon technology and a packaging technology) are understood.

Technology certification at Intel follows a cycle defined in four distinct phases: Pathfinding, Definition,

Development, and Deployment. Figure 3-2 illustrates the phases of Technology Development.

17

Figure 3-2: Phases of Technology Development

Pathfinding

The Pathfinding phase involves exploration of product needs and understanding the options for design, material, process, and equipment.

• For Silicon and Package technologies, Intel compiles quality and reliability requirements based on customer expectations, product use conditions, technology features and risks.

• Test technology teams interact with architecture groups and division to ensure that product functionality needs are understood. The effort has to ensure that equipment capability will be commensurate with product needs, and that issues that have the potential of being quality limiters are identified early in the technology maturity phase. The Pathfinding phase also provides an opportunity to pursue breakthrough technologies to redefine test to meet product needs.

• Board Technology teams identify multiple technology options and evaluate them from manufacturing, quality, and reliability perspectives.

Definition

During the Definition phase, Intel performs additional development on those technologies that represent the best candidates for meeting performance, manufacturing, quality, and reliability requirements. The

Technology Development organization develops technology and business plans to satisfy Technology

Intel Quality System Handbook 2014

18

Target Specifications. In parallel, the quality and reliability organization develops certification strategies based on anticipated failure mechanisms to achieve the reliability requirements. Design for Quality,

Reliability, and Test design rules are established based on design Failure Mode and Effects Analysis (FMEA).

During the Definition phase, Technology Development also determines if the needed materials and infrastructures exist or can be developed in time to support the targeted product.

• For Silicon and Package Technologies, critical parameters for design, test and manufacturing are defined and key specifications are developed. Reliability target specifications for process modules are defined based on the quality and reliability goals and the technology characteristics. Quality and reliability test vehicles for silicon and package technologies are selected and developed.

• For Test technology, target specifications and critical success indicators are defined given the planned devices and structures for silicon and package technologies. Selections for test equipment, tooling and material are finalized based on the test FMEA to ensure products can be tested without compromising quality and at an affordable cost. The Definition phase also formalizes the engagement between test technology development, quality and reliability teams, and other partners to initiate the test certification process.

• For the Board Technology Definition phase, selected options are narrowed based on finite element analysis modeling and empirical data collection. Critical inputs and options affecting materials, process, and design selection are evaluated. Failure Mode and Effects Analysis is used to document anticipated failure mechanisms that require special attention during reliability testing. Technical risk assessment is performed and only technologies representing high confidence solution paths are carried into Development. The Definition phase concludes with which technologies will be developed and their associated certification strategies.

Development

In the Development phase, the development site establishes an initial process or test flow. The flow is characterized and the findings are used to refine and optimize the process to meet the technology target specifications. A detailed reliability certification plan is defined based on known or anticipated failure mechanisms. Reliability characterization is an integral part of this iterative process; key learnings are fed back to the Technology Development team for process optimization. When a technology meets the yield, manufacturability, quality and reliability, and performance goals on a test vehicle and lead product, the technology is certified and moves into Deployment.

Upon completion of a technology certification, a report is generated with the results and a summary of the methodology used to validate the quality and reliability requirements for each core technology. Stress descriptions, test requirements, and goals which support the targeted technology envelope are included.

Performance results are subject to peer review and approved by management designated forums. Reports are placed in a secure database and serve as official documents; as such they are retained in accordance with corporate guidelines for quality documents. Intel also performs enabling validation on most reference designs and publishes results in the form of thermal and mechanical design guidelines.

• For Silicon, Package, and Test Technologies, the Development phase is highly integrated and all three must successfully meet objectives to establish certification readiness. Silicon and Package technology characterizations include detailed analyses of failure mechanisms and failure rates, and interactions between technologies (such as silicon-to-package interactions) are also characterized.

Quantitative failure models are developed ( Section 3.2.1

) and overall process reliability is verified by

characterizing failure populations and kinetic behaviors on representative devices. The Development phase for test includes strong interaction between both product and package teams to ensure test flow is capable of testing product functionality as intended. Module capability is initially developed

Intel Quality System Handbook 2014

19 on test vehicles and the test flow/technology is validated when product (silicon and package) becomes mature enough to be tested.

• In the final phases of development, critical process steps are evaluated by additional process window characterizations to measure the effects of process and design rule variations on reliability performance. Lead product tests are concluded, and process control parameters and systems are finalized.

When adequate baseline performance is demonstrated, the test vehicle is certified. Technology milestones such as test vehicle certification are used in conjunction with product qualification data to assess the quality of samples available to customers for design evaluations and manufacturing line qualifications.

• For the Board Technology Development phase, Intel refines and documents critical attributes on materials, assembly processes, and design as requirements to meet technology certification targets.

Board level reliability certification is finalized based on technical risk assessments and existing results. Execution of the certification plan involves completion of all required data collection by the use of test vehicles or reference design boards. Intel optimizes process materials specifications, board assembly processes, and design rules through this testing. A risk assessment methodology monitors progress against the certification requirements and goals.

Deployment

In the Deployment phase, the certified technology is transferred to manufacturing sites and ramped into

production. Intel’s Copy Exactly! methodology ( Section 6.3

) ensures that a technology is transferred

identically to all Intel manufacturing sites for Silicon, Package, and Test processes. Matching includes process parameters, yields, and reliability results. This approach allows Intel to ramp new technologies quickly across multiple locations, enables each site to share what they learn for continuous improvement, decreases production ramp time, and improves product availability.

• Silicon, package, and test processes are transferred from development to manufacturing sites using the Copy Exactly! method. Transfer certification is achieved when parameters are matched between

• Board Process Deployment: After certification of board technology ingredients, the board process technology is validated as part of high volume mother board ramp. development and manufacturing sites on a statistically valid sample size of processed material.

3.2.1 Stress-Based and Knowledge-Based Testing

Reliability certification and product qualification use a complimentary approach of both stress-based testing and failure-mechanism-based (also known as knowledge-based) testing. A mix of standardsbased and knowledge-based approaches has been used for many years in product qualifications. For example, qualification life-tests often use a standard requirement of 1000 hours at 125°C, but results have been extrapolated to 55°C operation based on knowledge of the activation energies for the failure mechanisms.

Stress-based testing refers to the use of standardized stress conditions and durations (e.g. JEDEC

Standard JESD47) which has strong historical precedence and is used to establish the framework for certification strategies during the Definition phase. However, its one-size-fits-all approach may fail to detect some mechanisms and over-accelerate others, and may inadequately comprehend the difference between the usage conditions across various types of products. It is therefore used in conjunction with failure-mechanism testing which refers to the use of customized stresses that

Intel Quality System Handbook 2014

accelerate known failure mechanisms. Sole reliance on failure-mechanism testing can miss new failure mechanisms, because advance knowledge of the failure mechanism, acceleration model, and detect methods is required. Industry standard JESD94 describes the certification methods emulating product usage and JESD91 can be used as a reference to describe generalized model forms and examples.

Figure 3-3 describes the sequence of actions and evaluations that lead to the final reliability stress

conditions and durations.

20

Figure 3-3: Reliability Stress Conditions and Durations

3.2.2 Key Challenges to Certification of Logic Technology Processes

Bringing advanced silicon technology processes to market is subject to a variety of electrical, thermo-mechanical and environmental reliability considerations and risks. For example, electrical effects leading to contact degradation, electromigration, gate oxide leakage and changes in transistor circuit characteristics must be considered. Thermo-mechanical mechanisms caused by temperature cycling or moisture changes are also important. Environmental risks such as electrostatic discharge events or the effects of ionizing radiation are also key considerations.

Understanding these types of reliability risks and developing the tools and techniques to assess them define the key challenges for silicon technology certification.

Intel Quality System Handbook 2014

21

Intel’s technology certifications consist of a combination of standards-based testing and failure

mechanism-based testing ( Section 3.2.1

). The following are examples of stress tests and failure

mechanisms:

Infant Mortality Evaluations and Extended Life tests measure the impact of latent defects on earlylife and late-life reliability and the onset of intrinsic failures in late-life. These tests functionally exercise the device at elevated junction temperatures and multiple voltages to accelerate failure mechanisms. The data is used to derive acceleration factors and construct proprietary quantitative technology models for the early-life and late-life portions of the product life curve. Statistical comparisons of products to the model are then made to validate that the product behaves according to the model.

High temperature bake with no applied voltage tests evaluate the early-life and late-life reliability impact of high temperature storage without electrical bias, in conformance with the procedures defined in JEDEC Standard JESD22-A103. This stress accelerates failure mechanisms such as C4 joint degradation, ionic contamination, contact integrity, and metal void propagation.

Highly accelerated stress tests (HAST) use high temperature and high humidity stress to evaluate early-life and late-life moisture reliability of non-hermetic devices, according to procedures defined in JEDEC Standards JESD22-A110 and JESD22-A118. This stress accelerates moisture-related failure mechanisms such as metal corrosion and contamination-induced threshold shifts. These tests complement highly accelerated stress tests on test chips biased at multiple voltages. Based on the resulting data, Intel develops proprietary quantitative failure models and compares them to product data.

Temperature cycling evaluates the early-life and late-life mechanical integrity of the device when exposed to temperature extremes, in conformance with procedures defined in JEDEC Standard

JESD22-A104 or JESD22-106. This stress accelerates mechanical failure mechanisms such as solder joint fatigue, package cracking, and interlayer dielectric cracking in the die and package.

Soft error testing is performed on test vehicles at specialized facilities, in conformance with JEDEC standard JESD89. Soft errors are caused by ionizing radiation passing through the circuit. The resultant charge upsets the balance of logic nodes. This radiation originates from two sources: alpha particles from the radioactive decay of materials employed in component fabrication and highenergy neutrons from intergalactic sources.

Latch up testing determines product sensitivity to parasitic bipolar action in CMOS technologies.

Intel tests parts functionally and parametrically after stress using an automated tester, in conformance with JEDEC Standard JESD78. Tests include voltage latch-up to determine the product sensitivity to Vcc over-voltage and input/output (I/O) latch-up to determine product sensitivity to pin overshoot and undershoot.

Electrostatic Discharge (ESD) tests measure a product’s sensitivity to electrostatic damage. The human body model (HBM) test simulates human handling. This type of event occurs when a person transfers a charge from their body into a device. Intel uses the JEDEC standard JESD22-A114 to determine the HBM test conditions. The charged device model (CDM) simulates mechanical handling. This type of event occurs when a device accumulates charge during automated handling and is discharged to a low resistance, low inductance ground plane. Intel uses the JEDEC standard

JESD22-C101 to determine the CDM test conditions.

Electromigration causes the interconnect resistance to increase during use and can result in circuit failure. Current in metal lines and vias causes motion of metal ions in the direction of electron flow.

This motion can result in void formation at points of flux divergence and can cause resistance

Intel Quality System Handbook 2014

22 increases. If the forces produced by the ion motion exceeds the limits of the surrounding dielectric, extrusion formation may result leading to shorts to adjacent structures. Intel evaluates electromigration mechanisms using specialized test structures that represent the physical structures allowed by design rules. Failure population statistics and kinetics are characterized using elevated temperatures and current densities.

Time dependent dielectric breakdown is a gate dielectric failure resulting from gate leakage current. Failure kinetics depends on applied voltage bias and temperature. Intel develops proprietary quantitative failure models based on data from accelerated stress testing.

Hot carrier injection occurs when hot carriers, produced by impact ionization, are accelerated toward the gate by the applied electric fields. This causes CMOS transistors to suffer an increase in trapped oxide charge and interface state density at the drain end of the channel. The resulting changes can cause circuit failures such as timing faults or latch stability faults. Intel performs stresses on simple circuits in AC and DC, various transistor dimensions in DC, and integrated circuits

(e.g. SRAM and microprocessors) in AC. Failures are defined as a change in transistor or test circuit characteristics or a failure to meet data sheet specifications. Proprietary quantitative models are developed based on test data collected before and after each accelerated stress.

Bias temperature instability is an important reliability issue for PMOS transistors in the negative bias condition. These transistors suffer an increase in interface trap density and positive fixed oxide charge. The resulting changes can cause circuit failures such as timing faults or latch stability faults.

Intel defines a failure as a change in transistor or test circuit characteristics consistent with design rules, or a failure to meet data sheet specifications.

3.2.3 Key Challenges to Certification of Flash Memory

Overall, the technology certification methods for flash memory certification are similar to those used for other silicon technologies in the previous section. Intel’s NAND Flash Memory certifications follow the guidelines set forth in the JEDEC Standard JESD47. The main differences in certification focus areas are in reliability stresses related to flash endurance and retention. Endurance is the ability of a flash memory to survive repeated program/erase cycles. Retention is the ability of a flash memory to retain data over time, with or without power. The following are examples of stress tests and failure mechanisms specific to NAND Flash Memory:

Non-Volatile Memory Cycling Endurance testing performs program/erase/read cycles to the maximum specified cycle count on a sampling of the blocks at both high and low temperatures. This stress accelerates defect related and dielectric charge trap mechanisms. Typical failure examples are wordline to wordline shorts, column to column shorts, cell defects causing the cell to be slow to program, program disturb of adjacent cells, and over programming cells.

Post cycling data retention testing is performed at high and room temperature. High temperature data retention is performed on the devices that were cycled at elevated temperature. The devices are programmed with a data pattern and baked at high temperature with pattern verify reads at defined intervals. The dominant fail mechanism is from dielectric charge de-trapping. Low temperature data retention is performed on the devices that were cycled at room temperature to look for fail mechanisms that may be masked by dielectric charge de-trapping at higher temperature.

Read Disturb and Erase Disturb stresses are also performed to ensure that there is no data loss during normal operation within a block or adjacent blocks of data. Typical failure modes during erase disturb are defect related and prevent a wordline or wordlines from floating causing data loss on those pages or block. Endurance failures have also been found that cause the erase operation to fail.

Intel Quality System Handbook 2014

23

3.2.4 Key Challenges to Package Certification

Increasing product and market performance needs drive process and design development for package, assembly, and enabling processes. New products typically require feature size reduction and added design complexity to accommodate improved functionality and increased electrical and thermal requirements. Physical design complexity translates into mechanical and thermomechanical challenges. Stringent electrical requirements result in higher current and power density and higher electrical fields. The development and validation of reference designs for the heat sink, socket, and board also have increasing design complexity and performance-driven requirements.

Package, assembly, and enabling processes must be synchronized with silicon process and product development, as well as board and system development. New product requirements drive additional complexity into all aspects of the packaging technologies used in finished products. Intel uses a combined technology risk assessment approach during development—where all technologies are simultaneously exercised—to identify and explore interactions and enable a successful integrated product qualification.

To allow product design flexibility, packages and assembly processes are exercised using design and process window characterizations to establish the technology envelope, form factor ranges, and design rule envelopes.

Validation is performed on mechanical reference designs, sockets, and heat sinks to provide the customer with proof of concept. Accelerated environmental reliability stresses such as bake, temperature cycle, and moisture test are used for enabling characterization and validation. The output of the enabling validation is contained in product specific electrical-thermal-mechanical design guides available at http://developer.intel.com

. Validated socket reports are available from the respective Intel-qualified socket suppliers.

3.2.5 Key Challenges to Test Certification

Electrical testing ensures that the product meets Intel’s quality goals and demonstrates product functionality at the required speed and thermal envelope. Test processes also provide valuable feedback to the upstream silicon and assembly processes, often detecting subtle variations in product performance parameters, such as defect density, frequency, power, etc. Test feedback is used to reduce variations, optimize performance and improve upstream processes to ensure the released product meets customer expectations of quality and performance. Test functions not only as a monitor of process health (silicon and package), it also serves to screen material to Intel’s quality standards.

Each generation of process technology and product design can double or triple the number of transistors in a product while at the same time shrinking the form factors. This growing complexity demands constant improvement in test capability and capacity and efficient use of test resources in such ways as utilizing design for test features, for instance, enabling very high speed array tests.

Other efficiency efforts include designing in redundancy to increase fault tolerance, improving tester hardware architecture to support optimizations, such as parallel device testing, and optimizing test content that may include eliminating redundant or ineffective content and replacing with quality monitors.

In addition, extensive optimization of product test flows, equipment layout, and software automation are used to minimize the complexity of manufacturing while ensuring high quality products.

Intel Quality System Handbook 2014

24

Market needs for increased product performance, higher functionality, environmental compliance, and lower cost are significant factors in developing new silicon, package, and board technologies.

Anticipating and planning for the impact of these factors on testing requires creative solutions and improvements for issues related to increased product power densities (particularly at burn-in), mechanical fragility due to low-k dielectrics, lead free metallurgy, and thin packages, ESD sensitivity

(reduced capacitance for higher performance), and off current (I-off) of new technologies impact on burn-in power.

3.2.6 Key Challenges to Board-Stack Ingredient Certification

Increasing product performance demand and market needs drive integrated board and stack ingredient technology development and certification to enable the customer with proof of reliable design concepts and design guidance. A board-stack is composed of a loaded heat sink, component

(CPU and/or socket) and board. Certification includes the validation of new enabling components and thermal solutions, as well as board reference designs.

The board technology ingredient quality and reliability development efforts involve close collaboration with internal development groups in other functional areas (e.g., package technology, enabling components, PCB board technology) to deliver a robust integrated solution that meets the market needs. Many options are available to achieve increased board performance. These include feature size reduction (both at the component and board level) and increased complexity in enabling components and board design. Generally, the changes that produce increased functionality and overall system performance also affect the requirements for thermal and mechanical performance.

During board technology development and certification, Intel focuses primarily on ensuring that the stringent requirements for board level interconnect are met.

To identify potential manufacturing issues during launch of new board products or technologies, a

Customer Manufacturing Enabling (CME) team engages directly with board manufacturers and system integrators to mitigate high risks for technology ramp. This engagement may involve the direct transfer of process technology information, working with the manufacturer to set-up and characterize their assembly line, or troubleshooting fabrication problems. Industry readiness assessment is a required element for technology certification.

Intel places emphasis on continuous improvement of the methodology via post-launch data collection, customer feedback, and internal development activities. Capability development and enhancements, such as refining reliability models, creating new predictive simulators, and improving knowledge of product use conditions, also contribute to the Board Technology Development Flow from a quality and reliability perspective.

Intel Quality System Handbook 2014

4 Product Development

Intel delivers on the Intel brand promise in the markets we serve through a commitment to achieving undeniable quality and reliability leadership. The Product Development organization responds to this commitment through the Product

Qualification System and the Validation Process. The results are qualified products that achieve the stated quality goals prior to revenue shipment.

4.1 Product Qualification System

Intel maintains world-class product quality and reliability even as product complexity and performance steadily increase. Intel anticipates and addresses these challenges using the Product Qualification System

(PQS) to deliver products that consistently meet the quality and reliability goals.

The PQS system provides the framework to:

• Apply the product quality and reliability requirements

• Develop and apply engineering solutions through the Design In Quality and Reliability (DIQR) process

• Validate product performance through reliability stress testing, quality testing, and safety and regulation checks for the finished product

• Deliver meaningful collaterals to our customers

• Release healthy products into Intel’s world-class manufacturing system

Figure 4-1 illustrates the Qualification System Architecture, its closed loop nature, and the relationships

between elements.

25

Figure 4-1: Product Qualification System Architecture Elements

The elements of the Product Qualification System Architecture are:

Strategic Intent — the Corporate Quality Business Principle documents the objective for quality and reliability leadership

Policy — high-level requirements to achieve qualification synergy across organizations in response to the Strategic Intent

Qualification System Oversight — how the Qualification System is managed

Intel Quality System Handbook 2014

Goals/Use Condition Requirements — establishes and maintains product quality and reliability requirements

Methodology — high-level process to manage product quality and reliability risk from inception to end-of-life

Execution — the identification, development, and performance of the evaluations required for product health

Output — qualified products, their associated qualification results, and the mechanisms for sharing this information with our customers

Feedback Mechanisms — processes for input from product quality and reliability evaluations, internal stakeholders, and external customers in order to drive continual improvement

4.2 Intel Product Life Cycle

The Intel Product Life Cycle (PLC) is an integrated approach to the major phases of a product’s life including

exploration, planning, development, production, and eventual discontinuance ( Figure 4-2 ). It involves all

operations and levels of the organization. Management approvals are required to move from one phase to the next.

Figure 4-2: Intel’s Product Life Cycle

Exploration — a product or product family opportunity is evaluated

Planning — a program Plan of Record (POR) is established to enable the organization to commit funding and resources to the project

26

Development — a Product Development Team develops the product to meet its requirements and validates product quality

Production — Manufacturing, Sales, Customer Support, and Service Support production availability, and eventual product discontinuance

4.3 Product Qualification and the Intel Product Life Cycle

Successful product qualification relies on a series of evaluations designed to validate performance to the quality and reliability goals. Intel tracks the advancement of qualification activities and milestones through

the PLC phases ( Figure 4-3 ). These milestones shape and drive the requirements, establish the development

expectations, and result in qualified products. Validation, the process of proving product and platform designs, is performed in parallel with the product qualification process.

Intel Quality System Handbook 2014

27

Figure 4-3: Product Qualification PLC Milestones

4.3.1 Exploration Phase

Usage Segment Milestone — Intel classifies product applications into usage segments. Groups of products that have similar usage conditions and characteristics, such as product lifetime, ambient temperature, or thermal cycling, define usage segments. Determining the usage segment early in the product lifecycle helps frame the overall product quality and reliability expectations. Examples of usage segments are:

• Mobile Personal Computer

• Desktop Business Client and Home Personal Computer

• Workstation Personal Computer

• Consumer Electronics

• Enterprise and Carrier Grade Server

• Telecom Controlled Environment

• Telecom Uncontrolled Environment

• Industrial

• Communications Infrastructure

• In-Vehicle Infotainment

• Mobile Internet Device

• Ultra Mobile Personal Computer

Q&R Requirements Milestone — In the Exploration phase, a product is designated for use in one or more of the segments. As the Exploration phase continues, a comprehensive set of quality and reliability goals and use conditions are developed. Information from customer surveys, usage measurement studies, and hypothetical usage scenarios are considered. National and international regulatory compliance is also taken into account. The result is a quality and reliability qualification plan and risk assessment strategy that is integrated into the product requirements document.

Intel Quality System Handbook 2014

28

4.3.2 Planning Phase

Risk Management Strategy Milestone — In the Planning phase of the Product Life Cycle, technical challenges (risks) are identified and evaluated. Therefore, product qualification can be viewed as a risk management and risk mitigation or reduction process. For example, a reliability stress such as temperature cycling evaluates the risk of thermal cycling triggering a failure mechanism. If the mechanism occurs, the risk during normal operating conditions needs to be quantified. An initial strategy would be based on factors including information from similar qualified products and from the silicon and package technology certifications. The strategy would include identifying possible failure mechanisms, developing failure acceleration methods, and ensuring the needed test and analytical tools are available. During the Development phase, data would be collected to quantify the risk, and measure the effects of mitigation and corrective actions. The risk level must be reduced to a low level of risk to achieve qualification of the product.

Project Planning Milestone — The key output from the planning phase is a product implementation plan that includes all the elements for successful qualification:

• Critical product success indicators

• Required resources including headcount, expenses, capital costs

• Tasks and tools needed, such as reliability calculators, Computer Aided Design (CAD) tools and flows, and reliability stress equipment

4.3.3 Development Phase

Qualification Plan and QAB Review Milestone — Early in the Development phase, the Qualification

Approval Board (QAB) reviews the qualification plan to ensure it is complete and accurate. The plan includes the quality and reliability requirements, the risk management strategy, and qualification execution details. It documents how the product will be evaluated to meet the product data sheet characteristics, usage segment goals, customer needs, and industry standards. Key plan elements include the pre-silicon qualification plan and the quality and reliability validation plan.

Pre-Silicon Qualification Plan — The Pre-Silicon Qualification Plan (PSQP) defines how Design for

Quality and Reliability methods is applied to the product development process. Key methods include

Correct-by-Construction, Design for Reliability, Reliability Verification, Design for Test and Design for

Manufacturing. These methods employ a CAD tool or a best known method (BKM) or both. (A BKM is a process of making and checking designs using a proven workflow and checklist.) CAD tools - including DIQR tools - go through a certification process to ensure they are effective, accurate, and have adequate coverage and performance.

Correct-by-Construction — In order to ensure that reliability design rules and goals are met during design, Correct-By-Construction tasks such as power-grid planning for electro-migration, signal routing for joule heating, and verification of cell libraries are performed.

Design For Reliability — BKMs are applied to assure the product design has robust reliability performance for ESD protection, latch-up performance, gate dielectric reliability, hot carrier reliability, and threshold voltage stability.

Reliability Verification — Design databases are verified for compliance to the reliability design rules through automated reliability verification checks. Regardless of styles of designs (custom design,

Intel Quality System Handbook 2014

29 analog, ASIC or SOC), each undergoes verification steps at multiple hierarchy-levels (block and full chip). For example, design rules are developed and checked for electromigration/joule heating, ESD,

Latch-up, IR drop and signal integrity, hot carrier effects, negative bias temperature instability, antenna charging, and thin film cracking.

Design for Test — BKMs ensure the product is testable to Intel’s test coverage standards and incorporate features to accelerate the qualification process. These methods include structural testing of memory and logic, quiescent current measurements, and guard banding rules and techniques. DFT also incorporates features into the silicon design to accelerate product development such as silicon debug, fault isolation, and fault tolerance schemes.

Design for Manufacturing — BKMs ensure the product is manufactureable through wafer fabrication and assembly processes, whether in house or outsourced. These methods comprehend Fab, Design for Burn-in, Design for Assembly, Design for Packaging, and Design for Debug.

Quality and Reliability Validation Plan — The QRV contains the details of how the quality and reliability will be validated. It includes the list of stress assessments, sampling plans and success criteria. The assessment strategy is to compare the reliability behavior of the product to the expected baseline behavior. The assessment plan also includes how other available, relevant data may be applied. Other data may come from relevant product qualifications or technology certifications.

Pre-Production Samples (PPS) Milestone — Pre-Production Samples become available when the product has completed a substantial portion of the qualification plan activities. This milestone allows our customers to obtain representative samples of production material to enable their application and manufacturing qualification processes. Pre-production samples have very limited availability, carry a special mark and are not covered by Intel’s product warranty.

Production Release Qualification (PRQ) Milestone — At Production Release Qualification, the qualification plan is complete, the supporting technologies have been successfully transferred to manufacturing, and factory control systems are in place. At PRQ, Intel ships commercial products that meet Intel’s quality and reliability requirements and are supported by Intel’s product warranty.

4.3.4 Production Phase

Production Release Qualification Report Milestone — Product Qualification Reports document the product’s quality and reliability performance along with the methodology used; included are stress descriptions, test requirements, and goals, which support the data sheet, customer needs, and Intel’s qualification requirements. Performance results are subject to peer review and approved by management designated forums. Reports are placed in a secure database and serve as official documents; as such, they are retained in accordance with corporate guidelines for quality documents.

Qualification Approval Board (QAB) Postmortem Milestone — All Product Development Teams conduct a formal qualification postmortem. The Qualification Approval Board, or equivalent body, collects and consolidates product qualification postmortem results. This final milestone completes a feedback loop that provides two important benefits. First, it captures learning from product generation to generation, which can be applied to future product qualifications. Second, it provides feedback about the qualification system to drive system improvements.

Intel Quality System Handbook 2014

30

Figure 4-4: Software Quality Milestones

4.4 Validation

Validation, the process of proving product and platform designs, is performed in parallel with the product qualification process. We believe we maintain the industry’s most advanced and comprehensive testing environment. Thousands of employees in more than 20 facilities around the world are dedicated to validation testing, and to delivering the world’s most reliable and compatible computing and communication platforms. For more information about validation, refer to the Intel Platform Validation Lab Tour at: http://www.intel.com/design/chipsets/labtour.htm

.

Validation teams focus on both pre-silicon and post-silicon methods. Pre-silicon validation aligns with the

Planning and early Development phases of the product life cycle while post-silicon validation aligns to

Development and early Production phases ( Figure 4-2 ).

4.4.1 Pre-Silicon Validation

Functional Unit/Cluster Level Simulation — Intel validation engineers test the internal workings of each major subsystem within the chip design with the goal of assuring each Functional Unit and

Cluster functionally meets its specification. This validation is typically a software simulation in the design environment, where subsystem interfaces can be controlled and monitored. Software simulation enables a more targeted testing than is possible in hardware. With this approach, validation detects problems early and resolves them quickly to accelerate product development.

Chip Level Simulation — Chip level simulation tests the performance of all chip design subsystems operating simultaneously. All units are combined in an environment where stimulus is provided at the component pins. The primary focus is on unit and pin interfaces and global functionality.

Interfaces are tightly controlled, and functionality is validated under an enormous variety of conditions.

System Level Simulation (SLS) — For system level simulation, the simulated component is tested in a full operating environment to ensure that it works with other platform components. Operation is also tested against industry bus standards to validate compatibility.

Intel Quality System Handbook 2014

31

Emulation — Once a behavioral model for a chip is developed, it can be transformed to produce a hardware emulator. Emulation enables Intel engineers to validate the logic functionality of the design, to debug BIOS and software drivers, and to verify the quality of the tools and processes that will be used in post-silicon testing.

Intel is an industry leader in emulator technology application and has heavily invested in advanced hardware emulators to enable realistic pre-silicon validation. The advantage of hardware emulation is its speed, typically several orders of magnitude faster than software simulation. Each emulator can model tens of millions of gates at emulation frequencies exceeding 10 MHz. Another advantage is that it permits the behavioral model to run with actual external system hardware. Intel has also developed fast, proprietary interfaces to accelerate the testing process and enable a more comprehensive pre-silicon validation. All of these advantages are instrumental in improving overall quality and accelerating product development.

4.4.2 Post-Silicon Validation

System Validation — System Validation (SV) tests all the features and functions of a chip, as defined by its specifications, on a specialized, highly instrumented SV platform. Specialized SV hardware and software is designed to exercise all functions of the component, detect flaws, and facilitate root cause analysis. Testing paradigms include focused testing and directed random testing. Given its specialized nature, System Validation is tailored to the specific type of chip – either microprocessor or chipset.

Microprocessor — System Validation stresses both the architectural and micro-architectural features of the microprocessor, with a focus on cache coherency and multiprocessor environments.

Systematic and random tests are used to cover very deep data space and intensive floating-point demands. System Validation tests for the Intel Pentium 4 processor offer an example of the scope and intensity of the process:

• 2,450 microprocessor feature tests; 2,000 legacy architectural tests

• 1 trillion random instructions tested per week

• Millions of chipset feature permutations and focused I/O stress testing.

Chipset — All chipset features are tested with custom-built system validation boards and test cards.

Performance parameters are pushed to their limits on cards and busses concurrently to validate performance limits and to verify bus compatibility.

For Intel chipsets that have integrated graphics, specialized tools and test suites are used for validation testing. Special test images are created to ensure a rigorous baseline for automated testing. Root cause is determined for every wrong bit so that the problem can be fully resolved, ensuring outstanding visual quality.

Analog Verification — Analog Validation focuses on processor and chipset signals to ensure functionality and specification compliance under varied environmental and voltage conditions.

Component-level validation includes AC timings, buffer characteristics, and rise/fall times. Platformlevel validation includes testing for signal integrity, power integrity, cross talk, and voltage droop.

Circuit Marginality Validation (CMV) — During Circuit Marginality Validation, test suites are applied to microprocessors that focus on reliability and performance under extreme operating conditions.

Both commercial and custom tests are used to test at voltage, frequency, and temperature extremes, and to ensure reliable operations within the processor’s specification.

Intel Quality System Handbook 2014

32

Analog Integrity Engineering (AIE) — Analog Integrity Engineering tests the electrical integrity of the chipset to make sure the entire platform is electrically robust. Performance is validated under a wide variety of worst-case scenarios. Intel works closely with customers, providing simulation models, correlating models to silicon and validating electrical robustness to demanding test conditions.

Compatibility Validation (CV) — Compatibility Validation (CV) is performed on a complete, typical system that includes subsystems such as components, boards, chassis, BIOS, operating systems, and application software. Typical areas of CV coverage include:

• Functionality (application related requirements)

• Performance and benchmarking stress (concurrency, overloading)

• Conformance (standards, protocols)

• Interoperability/compatibility

• Usage models

4.4.3 Software Validation

Software validation tightly integrates with hardware validation to ensure that hardware and software components operate together smoothly. Successful software validation shows that the total platform delivers top performance and reliability in the widest possible range of real-world environments. Driver software validation begins during system-level emulation, well before manufacture of the first silicon prototypes of the new component. This accelerates hardware and software development by ensuring high quality drivers during early design stages.

All Intel software specified for use in a Microsoft® Windows operating environment undergoes

Microsoft® Windows Hardware Quality Labs (WHQL) Certification testing. Intel executes proprietary tests in addition to the WHQL test suite to ensure exceptionally strong validation with Microsoft® applications and operating systems.

4.5 Product Transfer to Manufacturing

Together, qualification and validation enable robust physical, logical and electrical designs. To bring their benefits to market, the product must successfully transfer and ramp into manufacturing. Intel’s Copy Exactly!

procedure is key to successful product transfers ( Section 6.3

). It provides comprehensive set of evaluations,

establishes critical process parameters, process capability and process control limits to enable transfer into manufacturing.

Intel Materials Quality organization acts as a conduit between Intel suppliers and Intel factories, Technology

Development (TD) and product divisions. Intel Materials Quality uses a proven Quality Operating System

(QOS) process to select, develop, and manage suppliers so that they are capable of delivering materials and services for high volume manufacturing. All incoming materials must meet the manufacturing requirements and must function as expected at the lowest total cost.

Intel Quality System Handbook 2014

5 Materials Quality

The Materials Quality Network (MQNW) consists of Materials Quality teams working with technology development, factories, and subcontractors in the factory supply chain. These teams play critical roles in all phases of the product life cycle, from product conception to product delivery. They work closely with suppliers to address issues that may occur, and drive supplier material and process improvements to meet manufacturing requirements. The net result is that

production runs smoothly and the final product satisfies our customers. Figure 5-1 illustrates the interrelationships of

the Materials Quality Network and its relationship to the Materials Life Cycle.

Figure 5-1: Materials Quality Network Interrelationships

33

5.1 Materials Quality System Modules

The Materials Quality Operating System (QOS) is used to manage material and supplier quality. There are four modules in the Materials QOS. Each module has methods with associated tools, indicators, and training.

Table 5-1 illustrates each of the four Materials QOS modules and outcomes.

Intel Quality System Handbook 2014

34

Table 5-1: Key Materials QOS Modules and Outcomes

Key Materials Module Module Outcome

Module 1 – Supplier

Selection/Development

Module 2- Materials/

Supplier Qualification

Module 3- Process Control

System and Excursion Management

Suppliers selected and developed with materials of the highest quality and lowest cost.

High Volume Manufacturing (HVM) go/no-go decisions.

Change is controlled, with stable material quality and effective management of excursions.

Module 4 - Supplier Continuous

Quality Improvement

Improved supplier quality, overall capability, and costs.

5.1.1 Materials QOS Module One - Supplier Selection

Each Materials group defines their requirements and assesses potential supplier candidates based on their capabilities. As part of their development, the selected supplier will receive appropriate training from Intel to close gaps in their systems in order for them to be successful in meeting

business expectations. Figure 5-2 illustrates the steps involved in the supplier selection process.

Intel Quality System Handbook 2014

35

Figure 5-2: Supplier Selection Process Steps

5.1.2 Materials QOS Module Two - Materials and Supplier Qualification

In this module, the Materials group validates the capabilities of the supplier to support high volume manufacturing. Each Materials group establishes their business requirements and module target specifications (MTS).

Specific materials attributes must be satisfied to qualify a new material at Intel. They include quality and reliability requirements, specification requirements validation, and proven equivalence, if materials come from different suppliers or sites. New materials must also meet Intel manufacturing yield goals.

To qualify a new supplier at Intel, an effective supplier system must be in place. System expectations include change control, supplier quality reviews, valid sampling plans to enable incoming quality control elimination, reliability monitors, traceability, statistical process control with metrology, inspection correlation, and an excursion management system.

Intel uses Design of Experiments (DOE) and audits to generate the data required for risk assessment and decision-making. Risk mitigation actions, such as ensuring materials quality, making process improvements, and requiring further training, may be necessary to prepare a supplier before final approval for production.

Intel Quality System Handbook 2014

5.1.3 Materials QOS Module Three - Supplier PCS and Excursion Management

In high volume manufacturing, the supplier must demonstrate the capability to maintain stable and predictable material quality and deal with any excursions in an effective manner. The purpose of

Process Control System (PCS) and excursion management is to prevent excursions, and detect and

react to them when they do occur to minimize any impact to the customer. Figure 5-3 categorizes

the tools and processes Intel uses to control supplier processes and manage excursions.

36

Figure 5-3: Elements of Process Control and Excursion Management

Prevention — Issue prevention tools reduce the occurrence of materials-related quality issues.

Product and process change control prevent issues from arising due to unintended consequences of such changes. Tools such as Failure Mode and Effects Analysis can identify potential causes of issues and identify areas for preventive checks and balances. Quality system assessments identify areas for improvement, and supplier process yield improvements reduce the risk of non-conforming product or materials from being shipped. Intel’s robust change control forum reviews and approves material and process changes and tracks the change results. Changes are limited and scheduled accordingly.

This action controls the introduction of materials variation into the manufacturing system.

Detection — Process control methods are used to detect when materials-related quality issues occur. These methods include inspection tests, monitors and indicators that are designed to highlight when and where a quality issue arises. Early detection helps to prevent worsening or spread of the problem. Intel sets expectations for suppliers to have effective monitors to detect issues, and may include this expectation in the quality assessment agenda. Suppliers should provide updated control charts and timely closure for any out of control situation. Suppliers are rated on their process control maturity. If necessary, training may be provided to the supplier to reinforce their capability.

Reaction — Issue reaction includes the procedures used to contain and correct materials-related quality issues. These procedures notify the suppliers about quality issues and request corrective actions. They also address containment and disposition of questionable materials. Structured problem-solving methods determine the root cause and identify permanent corrective and preventive actions.

Intel Quality System Handbook 2014

In the event of an excursion, Intel expects suppliers to trace discrepant materials and isolate them.

Risk assessment must be performed, and the materials must be disposed appropriately, based on the technical and business implications. The root cause of the problem must be determined and fixed within a specified time frame to avoid manufacturing and customer impacts.

5.1.4 Materials QOS Module Four - Supplier Continuous Improvement

The purpose of this module is to improve the performance of Intel suppliers. The supplier’s performance is assessed in several areas, including quality and opportunities for improvement. The

Materials group and the supplier jointly coordinate supplier improvement activities. The tools used in this module include:

Supplier Scorecard — to rate the supplier in critical categories, such as cost, quality, availability, technology and customer satisfaction

Supplier Standardized Quality Assessment (SSQA) or Supplier QOS Health Assessment

(QOS HA) — conducted jointly by Intel and a supplier to identify areas of strength and system improvement opportunities

Annual Improvement Plan (AIP) — to identify specific areas that Intel and supplier work together on selected activities and key results

Supplier Business Review (SBR) — meetings to communicate performance, progress, and outcome of selected activities in the Annual Improvement Plan

Supplier Corrective Action Request (SCAR) — to alert the supplier of a serious issue requiring immediate action. The supplier is expected to report their findings and commit to closing the issue in a timely manner

The Supplier Continuous Quality Improvement Cycle illustrates how Intel and the supplier work

together on quality improvement ( Figure 5-4 ).

37

Figure 5-4: Supplier Continuous Quality Improvement Cycle

Intel Quality System Handbook 2014

38

Intel and the supplier discuss their expectations and then align activities and indicators.

Expectations, activities, and indicators are tracked and assessed periodically so that improvements can be made in identified areas.

When suppliers excel in specific areas and their overall scorecard performance, Intel may recognize their accomplishments in an appropriate forum.

5.1.5 Supplier Continuous Quality Improvement Program

The Supplier Continuous Quality Improvement Program (SCQI) directs, monitors, and rewards supplier-driven quality improvement. Suppliers that excel in this area receive public recognition from

Intel.

The SCQI vision establishes relationships with a select group of key suppliers who provide the highest quality materials, equipment, and services with a commitment to continuous improvement.

To enable this vision:

• Intel and the supplier mutually drive continuous improvements

• Key or strategic suppliers are placed on the SCQI roadmap and certified

• The SCQI program is viewed as a journey toward operational excellence rather than a destination

Intel and the supplier mutually establish goals and expectations and commit to allocate time and resources to participate in this program. Supplier performance is tracked in report cards that contain evaluations of a supplier’s performance against expectations with input from Intel managers, Intel

Quality and Reliability, and the Intel factories. Routine quality assessments are conducted to identify areas for improvement in the supplier’s quality systems. Supplier improvement plans are generated jointly between Intel and the supplier’s management to address the gaps identified in the supplier assessments and the supplier report cards.

Supplier Awards — Suppliers Awards are part of the SCQI program. It recognizes suppliers who exhibit excellence in their assessment scores, report cards, and performance in their improvement

plans receive recognition from Intel. Figure 5-5 illustrates the progressive recognition of supplier

awards. Performance is recognized by one of three performance awards:

Certified Supplier Award Certification — awarded to suppliers consistently meeting Intel expectations. Suppliers have achieved 80% scores in their report cards for 2 quarters with no major issues in SSQA.

Preferred Quality Supplier — awarded to suppliers consistently exceeding Intel expectations. Suppliers have achieved better than 80% scores on their report cards for a year, with no major issues in SSQ. Their superior quality systems provide consistent and predictable performance.

Supplier Quality Improvement Award (SCQI) — awarded to suppliers who have achieved better than 95% scores on their report cards for a year. They are the best in their class and have shown consistent, predictable performance that outpaces other suppliers. They are industry role models for their products, services, and business practices.

Intel Quality System Handbook 2014

Figure 5-5: Supplier Awards Progression

39

5.2 Metrology Labs

The Metrology Lab characterizes new materials and develops metrology equipment and methods to monitor critical parameters. To ensure that metrology is never a gating factor at product launch, Materials Quality requires in-process metrics and end-of-line metrics at major assembly materials suppliers and assembly subcontractors.

The critical steps in the metrology development and deployment require the Metrology Labs to work closely with the suppliers. Their objectives are to a) define quality metrics, b) develop the metrology capability, c) characterize materials, d) proliferate this new capability to the suppliers, and e) and assure suppliers incorporate the metrics into their process control systems. Once Intel and supplier metrologies correlate, the supplier’s process control data is accepted and the materials are placed in a “No Inspection Necessary” or

“Dock to Stock” status.

5.3 Subcontractor/Outsourcing Quality

Intel uses subcontractors to perform some or all of the manufacturing process steps, including wafer production, assembly, test, board, and system manufacturing. Potential subcontractors are evaluated on their ability to meet technical, business, and quality requirements. Only suppliers that measure up to Intel form, fit, and function specifications are certified to manufacture products bearing the Intel logo. Intel is able to offer customers a wider choice of products and increase the availability of some products because certification of subcontractors results in overall customer support improvement while meeting Intel’s high standards of product performance and quality.

Once a subcontractor site is certified and products are qualified, subcontractor quality management is similar to other supplier management. Intel’s Material Quality System resembles a standard supplier management system:

• Quality monitors are required to produce a reliable indication of shipped quality

• Process changes are subject to approval via Intel’s change management process

• Excursion response is closely managed

• Improvement areas are identified through regular quality process audits and quality system

Supplier Business Reviews and a scorecard process assure good communication and alignment on trends and requirements

Intel Quality System Handbook 2014

40

6 Manufacturing Quality Systems

The Manufacturing Quality System encompasses Intel products from silicon and components to boards and modules.

To deliver products efficiently that meet Intel’s customer expectations, Manufacturing transfers proven quality system fundamentals into each new business area. Issue prevention is the focus, utilizing systems that enable the prevention, detection, and containment of issues. Validation through assessments and audits focuses on business processes and quality culture. The best-known methods captured through these assessments are shared across factories.

6.1 Factory Overview

Intel’s manufacturing organization encompasses wafer fabrication, assembly, high-volume testing, boards manufacturing, and outsourcing. This geographically dispersed manufacturing organization consists of:

• Wafer fabrication facilities in the United States, Ireland, and Israel

• Assembly test manufacturing facilities in the United States, Malaysia, Costa Rica, and China

• Subcontracting and outsourcing facilities in multiple worldwide locations

At each manufacturing site, the Quality and Reliability staff monitors quality, provides feedback to the

Product Design and Technology Development organizations, and participates in problem solving. The local quality and reliability organizations report jointly to local site management and the Corporate Quality

Network management, thus meeting local needs and maintaining policy consistency across Intel.

Internal training organizations develop and provide training for manufacturing job functions, including supervisors, engineers, and factory support personnel. All manufacturing technicians and production operators receive training for their job and certification to a set of competencies. Each factory has a training group that is responsible for developing manufacturing skills specific to its needs. Intel emphasizes training in statistics, Statistical Process Control, structured problem solving, and team building.

The local organizations have the responsibility and authority to improve product quality and reliability through the following actions:

• Identify and record problems and corrective actions

• Initiate and provide solutions and improvements

• Verify implementation of solutions

• Control nonconforming products until deficiencies are corrected

• Initiate actions to prevent nonconformities

• Share information and best-known methods across the geographically dispersed organizations

6.2 Environmental Citizenship

Over the past several years, environmental focus has expanded from the manufacturing of electronic products to the environmental attributes of the electronic products themselves. This expanded focus

Intel Quality System Handbook 2014

presents an interesting challenge for the highly specialized and distributed world of electronics manufacturing.

Intel has long focused on design for the environment and improving its environmental performance.

However, this focus has historically been at the manufacturing level. That is, reducing and minimizing the environmental impact of its manufacturing processes as each new generation of microprocessor is introduced. As environmental attention has turned to the performance of electronic products, Intel has expanded its own environmental focus to include the environmental attributes of the components it produces.

Although our components make up a small piece of the final electronic device sold to the consumer, we believe that our role can be significant in helping to minimize the environmental impact of the final product.

As a company, we are committed to conserving natural resources, reducing environmental impact and developing environmentally compatible products and processes.

Intel’s Corporate Responsibility Report ( http://www.intel.com/intel/cr/gcr/overview.htm

) and the Intel

Environmental Health and Safety Policy ( http://www.intel.com/intel/other/ehs/policy.htm

) describe Intel’s policy, goals, and progress to reduce and minimize the environmental impact of Intel products.

6.3 Copy Exactly!

Fab, Sort and Assembly Test Manufacturing follow a Copy Exactly (CE!) philosophy. Copy Exactly! enables delivery of product from multiple production sites, which operate as a virtual factory that performs consistently and independent of the manufacturing source site. Additional benefits include faster production ramps that improve product availability and improved consistency to quality performance. Intel found that copying the embedded learning from the development Fab was the key to minimizing output loss with

process transfer. This led to the development of the Intel Copy Exactly! Method ( Figure 6-1 ).

41

Figure 6-1: Copy Exactly! Methodology

The Copy Exactly! Methodology focuses on matching the manufacturing site to the development site.

Matching occurs at all levels for physical inputs and statistically matched responses (outputs). This process enables continuous matching over time by using coordinated changes, audits, process control systems, and joint Fab management structures.

Intel Quality System Handbook 2014

Physical inputs such as equipment configuration, chemical purity, facilities, and equipment hookups derive from the same specifications. In-line process or equipment monitors that predict product performance, yield, or reliability must match at all levels.

Early in the transfer, Process Technology Development (Process TD) selects process and product parameters for statistical control and documents detailed control plans. Process TD continues working with the factory location to achieve process control and yield targets in high volume manufacturing. Throughout the transfer, factory personnel are responsible for quality and statistical control of all key parameters.

Once matched, changes are coordinated through joint engineering teams. Intel performs cross-site audits of equipment configuration and in-line process and equipment monitor results using a common process control system. Fabs execute high-level tactical and strategic changes under the auspices of the joint engineering and strategic management structure. As each factory begins to build a new technology, it starts at the same yield and improves at the same rate as the other factories.

42

Figure 6-2: Results of Copy Exactly! Methodology

6.3.1 Process Change Management

The Process Change Control Board (PCCB) is the primary tool for control and managing process changes in Intel factories. The PCCB process requires that appropriate technical forums review changes, stakeholder notification, and that qualification plans and success criteria are documented in a PCCB white paper. Additionally, the process addresses technical and practical concerns raised by key stakeholders, and verifies that:

• Changes are documented

• Changes are value-add

• Proposed implementation plans are comprehensive, timely, and realistic

• Anticipated risks are addressed

• The factory is committed to the implementation of the change as documented in a white paper

• Benefits are verified following implementation

• Assigned tasks are tracked through completion

Intel Quality System Handbook 2014

43

6.4 Manufacturing Systems

6.4.1 Factory Process Control

Statistical Process Control (SPC) tools allow Intel Manufacturing to identify problems early and prevent excursions. Station-manufacturing SPC is a key tool to reduce variability of key parameters for all of the manufacturing and job processes/products.

In-line process control monitoring is ongoing, and significant parameters are tracked using tools such as control charts. The goal is to monitor any parameter that may affect the final product’s performance or factory flow. Every process step has a number of monitored variables. For example, in a bonding operation the monitored parameters may include machine controls (e.g., power, pressure, time, frequency) and finished product parameters (e.g., bond pulls and thermal cycling performance). For a photo resist development step, these variables might be equipment-related

(e.g., develop volume, water pressure, spin speed) and inspections-related (e.g., amount of residual resist, levels of contamination).

As processes, equipment, and products change, the monitoring program and parameters evolve.

Ongoing learnings change the way Intel monitors its Fab, assembly, and board processes. A monitor may be eliminated or replaced with a more effective one if it is no longer generating useful information. At other times, monitors may be added to address problems until implementation of corrective actions.

Station-manufacturing statistical process control is performed with a real-time, computer-based capability. Real-time operator inspections and key parameters monitoring allow immediate corrective action when process drifts occur. Manufacturing technicians and engineers use response flow checklists and decision trees to address process interruptions and significant out-of-statisticalcontrol indications.

Intel monitors the health and effectiveness of the process control systems by examining various metrics such as control chart run rates, centering metrics, control limit health, and tool matching metrics.

6.4.2 Continuous Improvement of Products and Services

Manufacturing engineers continually focus on defect reduction and process margin improvement.

Technical structured problem solving methods are taught and used extensively. These common methods allow cross-functional teams to form quickly to address improvement opportunities with a common approach and language, and to focus on root cause and systemic corrective actions.

Problem solving methods and tools such as Pareto analysis, process flow charts, and cause-effect diagrams are widely used. Advanced statistical methods such as response surface analysis and statistical experimental design are used to pinpoint the root cause of process variations or other manufacturing issues. Site statisticians assist teams and individuals in using statistical methods.

Intel manufacturing systems integrate advanced statistical methods with other types of data systems to produce powerful and effective improvement tools. One example is the integration of test information across individual wafers with data from the process control system. This allows for statistical correlation of wafer Fab process parameters with device yield and performance data at the individual die level. The resulting wafer map studies have proven to be a valuable tool for finding and reducing sources of variation and yield loss. For additional information, refer to “Reliability

Improvement and Burn In Optimization Through the Use of Die Level Predictive Modeling” and “Unit

Intel Quality System Handbook 2014

44

Level Predicted Yield: A Method of Die Level Defect Reliability Segregation” proceedings. See references listed at the end of this chapter.

New wafer Fab equipment qualification begins in the strategic capabilities and technology development organizations. There, the manufacturer’s specifications are validated and a manufacturability evaluation is performed. Upon meeting requirements, it is transferred for beta site testing in a production area. Beta test criteria are tailored to the process step involved. Procedures are similar for qualifying new equipment or adding equipment to installed base. Copy Exactly! methodologies are also applied for establishing machine control limits, in-line control criteria and finished product performance criteria such as yields and reliability. The process includes an exhaustive fingerprinting to enable the added equipment to behave like the existing equipment. This includes matching physical inputs such as gas flows, plumbing, and matching product and performance parameters. Process module (several sequential manufacturing steps) testing is also performed to check for interactions with the installed equipment base.

Change Control Boards review all equipment qualification plan changes. These boards require the use of rigorous statistical methods, including sequential matching for equipment qualifications. Once in the production environment, equipment undergoes preventive maintenance monitoring with a predetermined frequency. Preventive maintenance specifications provide the details including PM frequency and equipment maintenance logging requirements.

6.4.3 Monitors and Manufacturing Quality Audits

Reliability Screens, Monitors and Sampling — Product and process reliability monitors are defined and used in various stages of product development and qualification. They are executed in-line or off-line as needed in wafer fabrication, assembly, boards and systems processes. Some monitors are defined during development and are continued into the manufacturing life of a product.

In addition to monitors, certain reliability screens are included in wafer-sort testing or finished product testing. Examples include margin screens, such as guard-banding charge-loss performance on memory cells, and defect screens such as high-voltage cell stress for gate dielectrics.

Intel performs periodic sample monitoring for each wafer Fab, assembly, board, and package assembly process. The sample size criteria varies based on process attributes. For example, package reliability monitors consider such factors as high sensitivity to reliability stress, cavity type, frame type, lead count, and die attach method. Sampling plans also consider production volumes and failure analysis complexity.

Each sampling plan has defined control limits and reaction plans. The reaction plans include quickly validating failures, identifying their potential impact on product reliability, and determining corrective actions. Quality and reliability engineering teams routinely review these indicators and drive appropriate actions and responses to make sure that they are healthy.

Internal Quality System Audits — Internal auditing determines if requirements are met, evaluates processes and systems for effectiveness and efficiency, and identifies opportunities for continual improvement. The ISO 9001 Standard serves as the baseline for quality system requirements throughout Intel’s worldwide factory and outsource network.

Each manufacturing site has a Lead Auditor responsible for the Internal Quality System Audit. The

Lead Auditor coordinates all internal audit activities including managing the audit team; team members are from different aspects of manufacturing and support groups and are highly trained in audit skills.

Intel Quality System Handbook 2014

45

The Lead Auditor develops audit plans for their manufacturing site. Manufacturing reviews and update these plans quarterly based on business needs and risks. Upon audit completion, the Lead

Auditor provides the factory staff with an assessment of the adequacy and effectiveness of the systems and processes in use. If necessary, the factory staff or the area owner recommends improvements or corrective actions to the existing systems and operations. A system-wide corrective action tracking system monitors actions for closure. Corrective actions are verified to make certain that they become permanent.

Self-Audits — Self-audits are another method Intel uses to monitor systems. Self-audits are indepth assessments led by a process owner or expert. Self-audit teams, composed of functional content experts, train on basic auditing methods and techniques and ISO 9001 requirements. Selfaudits include planning and performing the audit, reporting the audit findings, tracking corrective action closure and effectiveness, and continuous improvement planning. At a minimum, sites and operations perform annual self-audits of their quality system and processes. Regularly scheduled management reviews monitor corrective action closure and the overall effectiveness of the program.

6.4.4 Factory Environmental Control

Intel factories control environmental factors such as air purity, humidity, temperature, and electrostatic charge where needed for comfort, contamination control, and process optimization.

Cleanroom air is filtered to achieve Class 1 conditions in the process areas. The velocity and direction of airflow is also controlled in the process area, and cleanrooms are maintained in positive pressure relative to the outside environment. Intel factories control relative humidity to accommodate operator comfort, reduce electrostatic charge, and chemical processes optimization.

Factories control ambient temperature for operator comfort and as required by sensitive equipment.

Since the motion of air, people, and equipment contribute to the generation of electrostatic charge, ceiling ionizers are used for static mitigation. The ionizers neutralize any generated charge before discharge can occur, and thus help prevent damage to circuits during the production process.

6.5 Control of Inspection, Measuring and Test Equipment

lntel’s calibration program ensures the measurement capability of any instrument that provides quantitative or qualitative data on Intel products. The program includes mechanical, electrical, electronic, and physical measurements. Its purpose is to meet ISO 9001 and customer requirements and maintain traceability to national standards. Intel’s Measuring Equipment and Calibration Policy require all inspection and test equipment used in the manufacturing environment or for product acceptance to be under calibration control at all times.

The calibration service ensures that all measuring and test equipment meets the specified tolerances. The calibration process corrects and compensates for drift, inaccuracies, and out-of-tolerance conditions found in equipment. Notification is required if an out-of-tolerance condition is found. Reports of calibration results are available at the certifying facility.

A network of laboratories located at major Intel sites worldwide provides the calibration service to maintain cost-effective, accurate measurements. This network maintains or has access to primary and secondary standards for voltage, current, resistance, frequency, mass, light intensity, dimensional parameters and others. Each site tracks equipment to verify and schedule calibration and maintain calibration traceability.

Equipment owners are responsible for ensuring equipment calibration and each department is responsible for conformance to the calibration policy.

Intel Quality System Handbook 2014

A system of standards and procedures helps enable product uniformity across manufacturing sites while internal audits achieve monitoring and compliance. Uniform application of the calibration system and development of calibration policies and practices are the responsibility of the Standards Labs.

6.5.1 Calibration Traceability

A traceability process links inspection and test instruments through Intel standards laboratories to the National Institute of Standards and Technology (NIST), acceptable international standards, or

natural physical constants ( Figure 6-3 ). Where no recognized national standard is available,

consensus standards are used. These can include an artifact or process used as a de facto standard by agreement of the contractor.

46

Figure 6-3: Calibration Traceability Chain

6.5.2 Calibration Capability

Intel tailors measurement requirements for calibration facilities to meet the specifications of each site. There are many different testing requirements and each calibration facility has a range of standards designed to the equipment owner’s needs. At a location where a calibration capability does not exist, another Intel location or a vendor calibration laboratory may perform calibrations.

Intel Quality System Handbook 2014

47

6.5.3 Calibration Intervals and Records

Intel establishes initial calibration intervals for measuring equipment and measurement standards based on manufacturer recommendations or local site Standards Lab operating procedures. After obtaining a sufficient history of the stability, calibration intervals can be extended based on risk analysis or shortened to enable equipment reliability.

Calibration labels identify unique tracking systems, the present calibration status, and the individual support group. They serve as a visible indicator of unit serviceability. Some labels are valid only when sealed with the appropriate site calibration stamp by a qualified Standards Lab team member.

The calibration system requires the following data and equipment maintenance information in a calibration record:

• Unique identification of unit tested

• Environmental condition under which the unit is tested

• Deviations, correction factors or limits of calibration, if applicable

• Equipment owner/user department

• Calibration interval

• Last calibration date and next due date

• Calibration procedures

• Repair information, if applicable

• Identity of person performing the calibration

• Standards used to perform the calibration

6.6 Control of Nonconforming Product

A corporate specification governs the review and disposition of questionable or discrepant nonconforming product across Intel, including wafer fabs, assembly and test sites, distribution centers, and business divisions. The specification details the requirements for review and disposition of nonconforming product or raw materials.

Operational procedures are also used to define detailed disposition procedures, including scrap, rework, or release criteria. All nonconforming products are subject to a formal risk assessment of potential performance degradation by a Disposition Review Board (DRB), Material Review Board (MRB), or Quality

Action Notice (QAN).

Review board membership varies by site, product, or problem situation. Membership may include representatives from manufacturing, engineering, quality and reliability, and planning and other business and technical resources as needed.

The process begins when discrepant material is identified. The review board process will then:

Intel Quality System Handbook 2014

48

• Identify and quarantine affected material

• Conduct a risk assessment and develop a material evaluation plan

• Identify the root cause

• Develop a corrective/preventive action plan

• Implement the corrective/preventive action plan

• Disposition affected material

Actions are tracked to successful conclusion and the review board creates a final report to document all actions taken to disposition the affected material. The board ensures that all preventive actions are completed or transferred to an organization/owner and monitored to assure the permanent solution is effective. The reports are used as reference for future excursion management and problem resolution.

Additionally, factory self-audits, corporate audits, and quality system audits help define needed improvements.

6.7 Product Identification and Traceability

Intel employs systems to manage Product Identification with Unit Level Traceability for CPUs and Chipsets and Lot Level Traceability for Boards and Systems. A Record Retention System is used to manage and store this information.

6.7.1 Latest Generation CPU and Chipset Product Identification

Intel’s component traceability system enables product identification and tracking through all stages of manufacturing, storage, and shipment to the first point of sale. Identification methods include lottracking numbers that allow forward and reverse traceability of products. Periodic audits are performed at each site to ensure compliance. Record retention guidelines ensure lot history maintenance.

Intel moves component production material through the factories in lots. For component products,

Intel assigns a unique Fab lot number. When Assembly receives the released lots, an Assembly Lot

Traveler is assigned to track the lot through the Assembly operations. At selected locations throughout the Assembly/Test and Finish processes, each unit is identified through the 2-D mark establishing unit level traceability, with critical data associated with these individual units.

6.7.2 Boards and Systems Product Identification

Production materials move through the factories in work order lots, which assign a unique serial number to individual boards. This serial number is the key identifier linking the board or system to a particular lot and its manufacturing history, including components mounted on the board or system, and shipment destination records.

Intel Quality System Handbook 2014

6.7.3 Records Retention/Retrieval

Intel’s Records Management Policy requires keeping records pertaining to product traceability for up to seven years unless mandated otherwise.

In components manufacturing the tracking system provides lot and unit genealogy, last known location, and status of products. This system facilitates tracing component products from the

customer back to the Fab lot and from the Fab lot to the customer/location. Figure 6-4 shows how

data feeds into databases and moves to the tracking system.

49

Figure 6-4: Inventory Management System

Manufacturing Quality System References:

R. Miller, W. Riordan, “Unit Level Predicted Yield: A Method of Die Level Defect Reliability

Segregation”, Proceedings of the International Test Conference, 2001

W. Riordan, R. Miller, E. St. Pierre, “Reliability Improvement and Burn In Optimization Through the

Use of Die Level Predictive Modeling”, International Reliability Physics Symposium, 2005, pp 435-

445

Intel Quality System Handbook 2014

7 Customer Support

Intel has an extensive Customer Quality Support Network that supports technical and order fulfillment quality issue resolution, return materials authorizations, launch coordination and collaboration. Change Management and the

Customer Excellence Program are also important parts of the Customer Support Network.

Intel’s Customer Quality Support Network mission is to provide best-in-class quality support services to our customers, offer value-added services for technical problem solving, enable timely launch of new Intel technologies and products in our customers’ production, enable robust manufacturing, and create an environment where leadership, innovation, and impact are rewarded.

The Customer Quality Support Network responsibilities include:

Understanding Intel customer quality and reliability requirements and product expectations

Resolving customer usability and quality issues

Recommending standard and uniform internal quality goals based on customer expectations

Enabling customer manufacturing launch of new Intel technologies through specialized services

Measuring customer satisfaction as part of the Intel Customer Excellence Program

50

Figure 7-1: Intel’s Customer Quality Services

7.1 Support Network Operations

There are a number of ways for customers to engage Intel for support. The worldwide internet access includes multiple language support and can be found at http://www.intel.com/p/en_US/support?iid=hdr+support .

Many types of support information and Intel’s customer Support Hotline phone numbers can be found there.

Some direct purchase customers (those who buy product directly from Intel) have a dedicated account team.

These teams include Field Sales Engineers (FSE) and Field Applications Engineers (FAE) who are focal points for the customer during the early design and pre-launch stages. The teams also include Customer Quality

Intel Quality System Handbook 2014

51

Engineers (CQE) and Corporate Business Analysts (CBA) who serve as the primary contacts for technical quality and order fulfillment concerns after product launch.

7.2 Customer Quality Support and Services

Intel’s Customer Quality Support Network offers a broad portfolio of technical, enabling, and support services and programs:

• Materials declaration data sheet

• Manufacturing enabling

• Product change management

• Order fulfillment quality

• Technical quality

• Returns management

• Customer Excellence Program

For Intel customers, effective use of these systems can lower the cost of doing business, speed time-tomarket, and increase competitiveness. These systems are designed to help Intel understand customer needs and to furnish customers with valuable information about Intel products and services.

7.2.1 Compliance to Product Regulations - Responsible Product Design

Intel is committed to integrating design for the environment and safety principles into our operations and products at all phases in the product life cycle: development, production, use, and disposal. We are committed to designing and manufacturing products that are safe, energy efficient and minimize impact to the environment. Additional information is available regarding responsible product design in Intel Corporation’s Corporate Responsibility Report . The Corporate Responsibility

Report contains information on material content compliance to product regulations and industrywide initiatives (e.g. RoHS regulations and removing halogenated flame retardants). Additional information regarding some of these programs and industry initiatives at Intel is available by key word searches at http://www.intel.com

.

Material Declaration Data Sheets (MDDS) are available for most Intel Corporation products at http://intelmdds.pcnalert.com

. These MDDSs provide material composition information on restricted and reportable materials as defined in industry-wide standards, e.g. J oint Industry Guide - Material

Composition Declaration for Electrotechnical Products .

7.2.2 Manufacturing Enabling

Manufacturing Advantage Services (MAS) is a medium by which methods and considerations are shared with Intel’s customers to grow industry knowledge of manufacturing with technologies.

Intel Quality System Handbook 2014

52

Use of these methods and considerations may assist with customer’s manufacturing knowledge and skill set to achieve improved yields and more reliable product. These methods and considerations relating to Intel technologies can create a more robust manufacturing environment.

Services offer a library of enabling documents on new technologies, updates to existing technologies, videos, and language translations to support our emerging markets.

Channel Webinars focus on development of fundamentals using on-line, interactive training, sharing

Intel Best Known Methods (BKMs) that span Manufacturing, New Product Introduction & Post Sales

Support. Trainings are delivered one to many (one training, multiple countries), with language translation. This service improves Time-to-Market and Product Quality while assisting in increase

Production Output and Reduce Returns.

For more information, see http://www.intel.com/design/quality/cme.htm

.

7.2.3 Product Change Management

Product changes result from a variety of reasons including adding manufacturing capacity, yield improvements, quality improvements, supplier changes, and customer requests. Product Change

Management is the process used to control the modification to a product’s performance, appearance, quality, reliability, interchangeability, functionality, usability, supportability, manufacturability, customer handling, ability to integrate, and software interface. Intel’s minimum guidelines follow the industry standards set forth in the JESD48-B and JESD46-C for Product

Change Notifications and Product Discontinuances respectively. Although Intel uses these standards as guidelines, we handle exceptions on an as-needed basis.

Customer Change Notification — Communicating changes to customers and ensuring their readiness to receive enhanced product are key elements of Intel’s change management system. The objectives of the change notification system are to:

• Communicate critical information, including expected customer impact

• Provide sufficient evaluation time

• Enable fast and controlled factory changes, product enhancements, and process improvements

The Communication and Notification Flow ( Figure 7-2 ) shows the progress of conversions from

change inception through customer notification and factory implementation. Customer Notification

Change Forums (CNCF) track conversions from initiation through implementation.

Intel Quality System Handbook 2014

53

Figure 7-2: Communication and Notification Flow

Notification Criteria — The Product Change Notification (PCN) is the primary mechanism used to communicate product changes to Intel customers. Intel’s notification criteria apply to any products

that have reached Product Release Qualification ( Chapter 4 ) and are sold for revenue. Upon receiving

a PCN, customers should to evaluate the impact of the change on their products and factory operations. The information included in a PCN typically includes:

• conversion number

• conversion title

• type of change

• type of notification

• customer acceptance deadline

• recommended action for customer

• description/reason for change

• milestone dates

• products affected

• products discontinued

• order codes affected

• reference documents

Key Characteristic of Change — Intel categorizes all changes according to a list of key characteristics. Product Design and Manufacturing site key characteristics of change affect the form, fit, function or reliability of the product. A change in form, fit, function or reliability may have significant impact on a customer’s application (e.g. electrical or performance characteristics) or on a customer’s manufacturing process. These changes may or may not exceed product data sheet parameters. Qualification samples are typically available to direct customers 60 days before the customer must be ready to receive the new material. Qualification data is made available before the conversion date.

A list of all the key characteristics of change along with their definition is listed below.

Intel Quality System Handbook 2014

54

Product Discontinuance — Intel provides product discontinuance notifications to direct customers and authorized distributors, allowing customers to place final purchase orders. Customers are notified if they are in the design phase or have purchased product from Intel within the last two rolling years before the product discontinuance notification. Intel-authorized distributors are required to provide product discontinuance notifications to their end customer(s) who have purchased Intel product from the distribution channel, and to customers known to be in the design phase for up to two years before the product discontinuance notification. Final shipments are delivered commensurate with Intel’s production capacity.

Product Design (Affects the Fit, Function, or Reliability of the Product) — This characteristic of change may include but is not limited to board layout, boards and systems BIOS changes, stepping changes, die shrink changes, product packaging changes, or any other change which directly affects the performance of the product.

The minimum notification window for a product design change is 90 days for components and varies for boards. The notification window commences from the date the PCN is published to the customer until the last ship date as indicated on the PCN milestones.

Manufacturing Site — This characteristic of change may include but is not limited to proliferation of product to additional FAB and/or Assembly sites, or transfer of product to other FAB and/or

Assembly sites.

Product Material — This characteristic of change may include but is not limited to materials which do not affect the fit, function or reliability of the product sold to customers. Example: molding compounds, lead frame, heat sync, new parts, alternative parts, etc.; any physical portion, entity that goes into a board or system, e.g., brackets, IC’s, LED’s, assembly material changes, etc. If the material change affects the fit, function, or reliability of the product, the change should be considered a

Product Design change.

Product Marking — This characteristic of change describes a change to the marking of the product and not the ingredients or components of that product. Examples may include but are not limited to the methodology used to mark the product (Ink vs. Laser) or a change in content or location of the mark on the product.

Transport Media — This characteristic of change may include but is not limited to intermediate and shipping boxes, tubes, JEDEC trays, anti-static bags, carrier tape and reels, etc.

Label — This characteristic of change affects any dimensional or visual change made to any visible labels associated with the product. This includes box labels, transport media labels, etc.

Order Code — This characteristic of change may include but is not limited to a change in the Intel order code that may be due to a need to segregate pre-conversion to post-conversion material.

Documentation — This characteristic of change is to be used by Corp. Change Management or their designee to communicate business process changes to methods in how Intel communicates product changes to customers. This will not to be used for communicating spec. updates, changes to data sheets, or any other documentation not related to the PCN communication process.

Product Support - This PCN informs customers that the product (s) will transfer from one business unit to another and the support and availability of that product (s) will change. It consists of the impacted product (s) and the reason for the change in support.

The minimum notification window for PCNs varies by business group. The corporate guidelines are listed in the tables below.

Intel Quality System Handbook 2014

55

Table 7-1: Minimum Corporate Guidelines for PCN Notification

Key Characteristic of

Change

Days of Notification

Boards and Systems*

Days of Notification

Components*

Product Discontinuance

Product Design

120

15

365

90

Manufacturing Site

Product Material

Product Marking

Transport Media

Label

Order Code

Documentation

15

15

15

15

15

15

15

Table 7-2: IA CPU Products

30

30

30

90

30

30

30

Key Characteristic of

Change

Days of Notification

Non-Full Qualification

Days of Notification

Full Qualification

Product Discontinuance

Product Design

Manufacturing Site

Product Material

Product Marking

Transport Media

Label

Order Code

Documentation

N/A

60

N/A

N/A

N/A

N/A

N/A

N/A

N/A

30

30

30

365

90

90

30

30

30

Intel Quality System Handbook 2014

56

Table 7-3: Flash Product Group

Days of Notification -Components

Key Characteristic of

Change

Embedded

546

Cellular

273 Product Discontinuance

Product Design

Manufacturing Site

Product Material

Product Marking

Transport Media

Label

Order Code

90

90

30

30

30

30

30

90

90

30

30

30

30

30

Documentation 30 30

More PCN information is available through the Intel Product Change Notification System (PCNS) located at http://intel.pcnalert.com

.

7.2.4 Order Fulfillment Quality

Order fulfillment quality refers to the quality of ordering and logistics processes from initiation through customer receipt and any issues that involve the order placement and delivery. Order fulfillment quality issues can occur when procedures or processes are incomplete, incorrect, absent, or not followed. The Order Fulfillment Quality (OFQ) program assures the delivery of Intel products and services are complete, on time, and in perfect condition. OFQ issues are assigned to the categories indicated in Table 7-4 : Order Fulfillment Quality Definitions.

Intel Quality System Handbook 2014

57

Table 7-4: Order Fulfillment Quality Issues Definitions

OFQ Issue Type Definition

Damage

Electronic Data

Incomplete

Systems/Kits

Shipment received with punctured, crushed, damaged product tubes, trays, reels, bags, and /or boxes.

Incorrect or missing data transfer from one system to another.

Shipment received with system parts, kits, or accessories missing.

Labels - Box/Ship

Shipment received with missing, wrong, or damaged labels on packaging or shipping containers. This includes all labels on tubes, reels, trays, bags, boxes, intermediate boxes, and shipping boxes; excludes labels on the actual product.

Miss - Delivery

Packing

Paperwork

Wrong Product

Entire shipment was not received or a portion of the shipment is missing cartons.

Tubes, reels, trays, bags, or boxes are not packed per customer specification

Packing lists, shipping documentation, Certificate of Compliance, and customer specific documentation is illegible, incorrect, or missing.

The product received was different from what the customer ordered or expected. This includes mixed product, wrong accessories, wrong hardware, and wrong software.

Wrong Quantity

The quantity of units or systems received was more or less than the quantity that the customer ordered or expected.

Order Fulfillment Quality Support — Order fulfillment quality is measured by an Order Defect Per

Million (DPM) calculation and is monitored through a worldwide database for technical and administrative quality issue management. Performance to goals is monitored and improvements are made through corrective actions and problem solving teams.

Order fulfillment quality issues should be directed to the account Customer Business Analyst or

Customer Quality Engineer. The problem resolution process begins when the information is entered into the worldwide database. Then, the organization responsible for the issue resolution will:

• determine the root cause

• implement containment actions

• develop and validate corrective actions

• address systemic corrective actions

The CBA or CQE communicates with the customer regarding the status, root cause and corrective actions.

Customers who buy Intel products from a distributor dealer should contact that distributor for technical support and information services.

Intel Quality System Handbook 2014

58

7.2.5 Technical Quality

Technical quality refers to the product performance, usability, quality and reliability. Intel product failure during a customer’s manufacturing or test operation is an example of a technical quality issue.

Intel provides customers with problem response and resolution for technical quality issues.

Support and response for technical quality issues are based on customer impact and priority given to a specific issue. Priority and urgent levels are assigned to Technical Quality issues. Urgent issues have high impact to the customer. Examples include manufacturing lines down, special rework or product screening, customer not shipping products, serious field failure, or delay of a new product.

Priority issues are typically routine issues with the possibility of becoming urgent if not responded to in a timely manner.

Functional Analysis Correlation Request (FACR) — Intel customers who experience Technical

Quality issues are supported by Intel’s Quality Support Centers (QSCs) and the FACR process. Quality

Support Centers are a worldwide network of technical quality support specialists. QSCs are located in all major geographies to deliver responsive quality support and take advantage Intel’s worldwide capabilities and knowledge. Some are located at major factory sites, taking advantage of Intel’s manufacturing and advanced testing capabilities. Others are located at sites where they can leverage

Intel’s product, design, and process and package technology expertise.

When customers experience a technical quality issue, they can access the FACR process through their assigned Customer Quality Engineer (CQE). The CQE helps the customer determine if returning the failing product for credit or providing product support information will resolve the issue to their satisfaction. If more detailed analysis is needed, the FACR process helps Intel understand the issue experienced by the customer, manage the return of the units to Intel, conduct an investigation to understand the issue and provide a written analysis report. Customers typically request using the

FACR process to understand failures in their manufacturing process or after shipping to their customers.

The FACR process starts by the Intel CQE gathering detailed information about the suspected failure.

This includes the failure conditions and symptoms, the test environment, and product traceability information. The quality and timeliness of the initial issue discovery information is a critically important first step, and the information is immediately transmitted to the QSC. In urgent cases, customers are urged to ship the failing units quickly to the provided QSC address.

Upon receipt at the QSC, the product enters the FACR process. Throughput time goals for the FACR process are to provide the customer with a Preliminary Analysis Update within 48 hours and close the issue with an Engineering Evaluation Report within 14 days.

The FACR process is executed by Intel’s Product Quality Engineers (PQEs). PQEs, experts in product failure and data analysis, evaluate each issue and determine the appropriate analysis methods and sequence on a case-by-case basis. A wide variety of methods are available. The FACR process may include visual, scanning acoustic, infrared emission, and electron microscopy techniques. Data analysis techniques may include product manufacturing health analysis, manufacturing commonality analysis and returns commonality analysis. Electrical test methods may include automated test equipment, platform validation testing, and curve tracing. Signature failure analysis, sophisticated fault isolation, and physical analysis techniques are also among the many methods available.

If the FACR process determines the returned product has failed, Intel determines and takes appropriate containment, corrective and preventive actions. These actions are based on the outcome of the FACR process and the particular customer issue. In over half of the FACR cases, the QSCs offer

Intel Quality System Handbook 2014

59 service and support information to help customers who have returned components into the FACR process due to improper testing or handing procedures in their facilities.

When the FACR has been closed, customers are invited to participate in a satisfaction survey. This survey allows Intel to improve the effectiveness of the FACR process and customer quality support services.

For more information, customers may contact their Intel Field Sales Engineer or Customer Quality

Engineer.

7.2.6 Returns Management

The materials return process is different for direct customer and channel customers. For direct customers, we utilize a Return Management Authorization (RMA) process. For Intel’s channel customers, we offer a product exchange process.

Direct Customer Return Materials Authorization Policy — The Worldwide Direct Customer RMA

Policy identifies three categories of returns:

Administrative — Non-technical returns authorized by Intel caused by an administrative error made by Intel, such as, but not limited to, wrong product shipments, order entry errors, duplicate orders, over-shipments, wrong destinations, and wrong shipping dates.

Technical in-warranty — Returns of defective product made within the product’s warranty terms and conditions.

Technical out-of-warranty — Returns of defective product or product to which the customer desires to have work done (e.g., upgrade to latest revision), but not covered within the product warranty terms and conditions.

Channel Warranty — The worldwide Channel Warranty Program policy offers two levels of programs:

Standard warranty program — Customer contacts Intel for authorization. Upon Intel receipt of the defective product, Intel dispatches replacement product.

Advanced warranty program — Customer contacts Intel for authorization. Intel dispatches a replacement part to the customer, and the customer returns the defective part to Intel.

Business rules defined by Intel Channel Management determine access to the standard warranty and advanced warranty program, including quantity limits. All product warranty returns are subject to Intel’s business terms and conditions.

Warranty Returns Process — Customers may request support on warranty returns for defective product. Warranty periods may vary by product. Intel’s Returns Management Center maintains records characterizing warranty period and terms by product.

For direct customers, requests for warranty returns should be directed to the regional returns management offices or using Intel Business Link (IBL) web-based tool. Support on returns can also be provided via the account team and the Customer Quality Engineer (CQE).

For channel customers, returns are coordinated through the Channel Warranty Program. For specific details visit www.intel.com/reseller and select technical support. Warranty requests can

Intel Quality System Handbook 2014

60 be submitted by email, web tools, or telephone. For a listing of telephone numbers, visit www.intel.com/reseller and select contact support.

Technical In-Warranty Returns are approved at Intel’s discretion. Intel offers the repair, replacement, or credit services that are subject to eligibility criteria and vary by geographic region.

To validate eligibility, customers must provide proof of purchase information (such as the invoice) or serial number information for products being returned. Customers must also identify the technical reasons for the product return. Returned products may be screened and tested by Intel.

If the product is determined by Intel to be Customer Induced Damage, No Defect Found, or Out-of-

Warranty, Intel reserves the right to take one or more of the following actions:

• Deny request for credit or replacement

• Reverse any credits which might have been issued already for the product

• Return the material at the customer’s expense

7.2.7 Measuring Customer Satisfaction

Intel’s ‘Customer Excellence Program’ (CEP) measures overall customer satisfaction and drives corporate or business unit improvement actions. This program uses a third-party market research firm to obtain statistically relevant feedback on Intel’s products, processes, and programs through a web-based survey. The survey covers a range of customer job functions and supports multiple languages, asking questions that are most relevant to the job role of each participant.

Through the Intel CEP, we elicit and listen to our customer’s feedback to:

• Take a holistic approach to understanding and improving customer satisfaction

• Obtain statistically relevant and actionable data from a variety of business touch-points within customer accounts world-wide

• Prioritize and drive identified high-impact issues to resolution while ensuring communication of our actions and results back to our valued customers

• Continuously measure and improve Intel customer satisfaction and preference across every geography and channel

• Reinforce a company-wide customer orientation focus

Intel Quality System Handbook 2014

Survey Analysis — Once customer feedback has been collected, in-depth data reviews and regression analyses are performed. This provides multiple views across customer accounts:

• A broad level view indicates overall customer satisfaction and future commitment

• A business level view measures satisfaction in areas such as Intel’s technological innovation, value-add services, and attributes such as responsiveness and product features and performance.

• A detailed view to help identify specific customer concerns or issues.

Responding to Issues — Intel Executive Management reviews survey analysis findings and sets the corporate focus for company-wide action and resolution of high-impact customer issues. A wellestablished issue management and response processes is used to drive resolution to CEP issues and the owning organizations make certain that priority is given to high-impact issues. Existing efforts may be reinforced or redirected based on the survey results. The results of these actions are then communicated back to customers through sales, marketing, quality or other communication channels.

61 Intel Quality System Handbook 2014

62

8 Synopsis

Intel implemented a flexible Quality Management System architecture based on Intel’s Mission, Corporate Values, and

Quality Policy. The QMS utilizes four key elements: 1) Plan, 2) Organize, 3) Execute, and 4) Monitor. These elements adapt quickly and effectively to new business trends in order to satisfy customers’ changing needs for quality and reliability in products and services. This architecture encompasses a wide range of mature and robust systems and processes, and enables Intel to provide responsive support to customers and optimize the customer usage of Intel products.

Intel’s quality documentation system consists of corporate business principles, group guidelines, governing specifications, and operational policies, guidelines, and procedures. These provide output that creates value for customers and stakeholders, and enables profitability and growth for Intel.

Intel manages quality throughout Technology Development, Product Development, Materials Quality, Manufacturing, and Customer Support. Each of these operations depends on the quality management and quality delivery of the other.

Technology Development enables Intel products to provide better value, through improved performance, increased functionality, or smaller size. Product Development uses processes to take a product from market research through production, and eventually to product discontinuance. Materials Quality provides materials and services for production to meet agreed-upon requirements, lead times, and pricing. Manufacturing enables quality production by understanding customer quality requirements and implementing processes that help ensure operations meet these requirements. Customer Support provides customer assistance by understanding, documenting, analyzing, and resolving customer issues.

Intel uses each generation of technology to manufacture a large number of products. Therefore, it is crucial to ensure that each core technology exhibits high quality and reliability. At Intel, the term ‘qualification’ refers to the quality and reliability assessment of a particular product, and the term ‘technology certification’ refers to the quality and reliability assessment of a core technology.

From Pathfinding through Deployment, Intel uses standard and custom tests to address the challenges inherent in the rapid advancement of electronics core technologies. This systematic approach enables Intel to ensure that high quality technologies are developed along the path to production. Intel bases the development of technology on planning and certification for silicon, package, sort/test, and boards.

Silicon Technology is the fabrication process used to create the IC on silicon wafers by adding and patterning the layers that form transistors and interconnects. Intel certifies a process technology when it meets quality and reliability goals, and a lead product has been manufactured on the technology and shown to meet requirements.

Package Technology is the assembly process used to enclose the silicon IC in an electronic package with connections accessible to the user. Increasing product and market performance needs drive process and design development for package, assembly, and enabling processes. New products typically require feature size reduction and added design complexity to accommodate improved functionality and increased electrical requirements.

Sort/Test Technology is the test process, from wafer sort through package-level test and burn-in, designed to ensure that shipped devices meet datasheet requirements. The primary reasons Intel performs tests are to ensure proper functionality of the product at the required speed and to assure the products customers receive meet Intel’s quality goals. Test processes also provide valuable feedback to the upstream silicon and assembly processes, often detecting subtle variations that change product performance parameters such as, defect density, frequency, power, etc.

Board Technology consists of the design and fabrication of printed circuit boards or motherboards that enable integration of individual components. Ever increasing demands for higher product performance drive Board technology development and certification. Certification activities include the validation of new enabling components and thermal

Intel Quality System Handbook 2014

63 solutions, as well as board reference designs. Advancements in silicon technology act as the primary driver of board technology developments.

Once a technology has been developed, the next step is to create a product based on that technology. The Product

Development organization utilizes the Intel Product Qualification System and Product Life Cycle to take a product from market research through production and eventually to product discontinuance. The Product Qualification System provides the framework to apply the product quality and reliability requirements, develop and apply engineering solutions, validate product performance, deliver meaningful collateral to our customers, and release healthy products.

The Intel Product Life is an integrated approach to product planning, development, manufacturing, support, and discontinuance, involving all operations and levels of the organization. It has four phases major phase, Exploration,

Planning, Development, and Production, with management approvals required to move from one phase to the next.

Intel tracks the advancement of qualification activities through the PLC phases and associated milestones. Nine qualification milestones shape requirements, establish development expectations, and drive conformance to those requirements, resulting in qualified products. The inherent quality, compatibility, and robustness of our product and platform designs are major aspects of delivering to the Intel brand promise.

At Intel, Validation refers to the process devoted to proving out our product and platform designs. It is important to ensure that the product successfully transfers and ramps into manufacturing. Intel’s qualification methodology relies on assessments using process and product matching, and product-specific process control systems.

By integrating the Product Life Cycle and the Product Qualification System, Product Development quality and reliability personnel meet customer needs through early customer and market engagement, innovative engineering, thorough validation, and world-class manufacturing.

Materials quality is a key consideration in all stages of the product life cycle starting with new material discovery, characterization and eventually, certified material that is used in the manufacturing sites. Stable and predictable quality, availability, and cost effectiveness of incoming material are critical and necessary conditions for Intel factories to run smoothly and deliver products that meet customer satisfaction. The Materials Group works closely with the supplier and collaborates in Intel’s Supply Chain to accomplish this mission. The Materials Quality Operating System (QOS) is the approach employed to achieve the quality objectives in each of the four QOS modules.

The Supplier Selection module defines the needs and assessment criteria for selecting and developing the best supplier. Next, the Supplier and Materials Qualification Module certifies the supplier and qualifies the materials. This module provides the necessary supporting data and validation to show that Intel system requirements and product specifications are met and determined risks are understood and reduced. The Process Control System and Excursion

Management Module allows the supplier to prove its ability to prevent, detect, and respond to issues, such that Intel and Intel’s customers are minimally impacted by discrepant material found by the supplier. In the Supplier Continuous

Quality Improvement Module, Intel works closely with supplier to track and communicate supplier performance, address current and potential issues, and identify opportunities for further improvement. This module enables the supplier to consistently meet Intel expectations and have a competitive advantage in the industry.

Intel uses the same Materials QOS approach with subcontractors, such that their products meet Intel form, fit and function specifications and are equivalent to those from Intel factories. Essentially, suppliers and subcontractors managed by proven Materials QOS methods and tools deliver products and services that meet, and sometimes exceed, the expectations of Intel and Intel’s customer.

Manufacturing uses issue prevention as its main approach in providing quality products. This is evident in the use of the

Intel Copy Exactly! methodology and manufacturing systems. Intel’s Copy Exactly!, a methodology followed by Fab, Sort and Assembly Test Manufacturing, focuses on matching the manufacturing site to the development site. Copy Exactly! benefits include faster production ramps for enhanced product availability and improved consistency to quality performance. Manufacturing systems such as environmental citizenship, process transfer, the use of statistical techniques, the manner of new equipment qualifications, manufacturing monitors, and control systems, and the control of inspection, measurement, and test equipment also aid in issue prevention. If issues are unpreventable, Manufacturing

Intel Quality System Handbook 2014

64 focuses on detection and containment of these issues. The systems in place to enable detection and containment of issues include traceability, manufacturing equipment matching and qualification, process control systems, and bestknown methods. Traceability is an identification method that includes lot-tracking numbers that allow forward and reverse traceability of products. Record retention guidelines ensure lot history maintenance. Intel’s traceability system enables product identification and tracking through all stages of manufacturing, storage, and shipment to the first point of sale. Manufacturing equipment matching and qualification consists of matching the new tool to a reference tool using sequential statistical methods that allow the equipment to be qualified as soon as matching is demonstrated.

Manufacturing rarely encounters any equipment issues because of the meticulous matching process. Reduction of variation and various process control systems and best-known practice sharing across factories also enable the detection and containment of unpreventable issues.

Manufacturing also validates through various forms of audits and assessments focusing on quality culture and business processes. Internal quality system audits provide an evaluation of whether the existing requirements are met. Internal auditing evaluates processes and systems for effectiveness and efficiency and identifies opportunities for continual improvement. Sites and operations perform at minimum annual self-audits of their quality system and processes. Selfaudit teams, comprising functional content experts, train on auditing methods and techniques as well as ISO 9001

Standard requirements.

Primarily, Intel’s Customer Quality Support Network provides post launch support. The Intel Customer Quality Support

Network’s portfolio of value-add service and support ensures ongoing support to our customers. These services include

Materials Declaration, Manufacturing Enabling, Product Change Management, Order Fulfillment Quality, Technical

Quality, and Returns Management.

Materials Declaration data sheets provide the necessary material composition information on restricted and banned substances. Intel’s Manufacturing Enabling program results in the successful product launch of new technologies at customer sites. The outcome of successful launches is higher yields and improved quality and reliability.

Communicating changes to customers and ensuring their readiness to receive enhanced product are key elements of

Intel’s Product Change Management system. Intel’s change notification objectives are to ensure that critical information is communicated, including expected customer impact, provide sufficient evaluation time, enable fast and controlled factory launches, product enhancements, and process improvements for customers.

Order Fulfillment Quality refers to the logistics management of customer orders from initiation through customer receipt, including issues that involve the order placement and delivery. The objective of the OFQ program is to ensure world-class order fulfillment quality that results in Intel products and services delivered complete, on time, and in perfect condition.

Intel’s Technical Quality objective is to assure world-class product quality that meets the committed market warranty and lifetimes. Intel provides customers with rapid problem response and resolution. Intel manages two fundamental

Returns Management processes for its customer base. For direct customers, Intel offers a Return Management

Authorization (RMA) program, and for channel customers Intel offers a product exchange program.

Additionally, Intel listens to customers through daily interactions and through the Customer Excellence Program (CEP).

Intel internalizes customer feedback and uses it for continuous improvement of services and customer satisfaction.

Intel strengthens customer devotion by using customer feedback to enable strategic investments in our products, brand, and services.

Intel’s Quality Policy is that business results are the ultimate measure of success, and the results prove that Intel’s

Quality Management System works. Intel’s Quality Management System provides the architecture through which

Technology Development, Product Development, Materials Quality, Manufacturing, and Customer Support fulfill the commitment to providing customers with quality products and services alluded to in Intel’s Mission, Corporate Values, and Quality Policy.

Intel Quality System Handbook 2014

Our ability to maintain world-class leadership in technology and performance depends on our commitment to our corporate values of Operational Excellence, Continuous Improvement, and Customer Satisfaction. These values mesh with Intel’s policy of striving to maintain the highest standards, ship products that meet our stated goals, quickly communicate with customers, and act to resolve problems. Intel places achieving and maintaining world-class quality leadership as top priorities, creating systems and architectures to achieve this goal, resulting in a quality culture that keeps us at the forefront of semiconductor technology today and tomorrow.

65 Intel Quality System Handbook 2014
