EF300mm f/4L IS USM



Thank you for purchasing a Canon product.

The Canon EF300mm f/4L IS USM lens is a high-performance telephoto zoom lens for EOS cameras, and it is equipped with an Image


• "IS" stands for Image Stabilizer.

• "USM" stands for Ultrasonic Motor.

Conventions used in this instruction

Warning to prevent lens or camera malfunction or damage.

Supplementary notes on using the lens and taking pictures.


1. The Image Stabilizer gives the equivalent effect of a shutter speed two stops faster*.

The lens also has a second image stabilizer mode that is optimized for following shots of moving subjects.

2. UD lens elements for excellent imaging performance.

3. Ultrasonic motor (USM) for quick and quiet autofocusing.

4. Manual focusing is available after the subject comes into focus in autofocus mode (ONE


5. The lens is compatible with Extender EF1.4X ll and EF2X ll.

* Based on [1/focal length] second. Generally, it requires a shutter speed [1/focal length] second or faster to prevent camera shake.


a Safety Precautions

a Safety Precautions

Do not look at the sun or a bright light source

through the lens or camera. Doing so could result in loss of vision. Looking at the sun directly through the lens is especially hazardous.

Whether it is attached to the camera or not, do

not leave the lens under the sun without the

lens cap attached. This is to prevent the lens from concentrating the sun’s rays, which could cause a fire.

Handling Cautions

If the lens is taken from a cold environment into

a warm one, condensation may develop on the

lens surface and internal parts. To prevent condensation in this case, first put the lens into an airtight plastic bag before taking it from a cold to warm environment. Then take out the lens after it has warmed gradually. Do the same when taking the lens from a warm environment into a cold one.

• Do not leave the lens in excessive heat such as in a car in direct sunlight. High temperatures can

cause the lens to malfunction.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Do not make any changes or modifications to the equipment unless otherwise specified in the instructions. If such changes or modifications should be made, you could be required to stop operation of the equipment.

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Consult the dealer or an experienced radio/TV technician for help.

This Class B digital apparatus complies with Canadian ICES-003.



Built-in lens hood (

→ 10)

Focusing ring (

→ 4)

Distance scale (

→ 5)

Distance index (

→ 5)

Focus mode switch (

→ 4)

Lens mount index (

→ 4)

Filter mounting thread (

→ 10)

Contacts (

→ 4)

Image stabilizer mode selector switch


→ 6)

Image stabilizer switch (

→ 6)

Tripod mount (

→ 9)

Orientation locking knob (

→ 9)

Focusing distance range selection switch (

→ 5)

For detailed information, reference page numbers are provided in parentheses (

→ **).


1. Mounting and Detaching the Lens 2. Setting the Focus

See your camera’s instructions for details on mounting and detaching the lens.


• After detaching the lens, place the lens with the rear end up to prevent the lens surface and electrical contacts from getting scratched.

• If the contacts get soiled, scratched, or have fingerprints on them, corrosion or faulty connections can result. The camera and lens may not operate properly.

• If the contacts get soiled or have fingerprints on them, clean them with a soft cloth.

• If you remove the lens, cover it with the dust cap. To attach it properly, align the lens mount index and the

K index of the dust cap as shown in the diagram, and turn clockwise. To remove it, reverse the order.

To shoot in autofocus (AF) mode, set the focus mode switch to AF.

To use only manual focusing (MF), set the focus mode switch to MF, and focus by turning the focusing ring. The focusing ring always works, regardless of the focus mode.

After autofocusing in ONE SHOT AF mode, focus manually by pressing the shutter button halfway and turning the focusing ring. (Full-time manual focus)


3. Switching the Focusing

Distance Range

4. Infinity Compensation Mark

Infinity compensation mark

You can set the focusing distance range to

1.5 m/4.9 ft. to infinity or 3 m/9.8 ft. to infinity. By setting the suitable focusing distance range, the actual autofocusing time can be shorter.

If you autofocus outside the set focusing distance range, the lens may stop focusing at the start of the focusing range; however, this is not a malfunction. Press the shutter release button halfway again.

Distance index

To compensate for shifting of the infinity focus point that results from changes in temperature.

The infinity position at normal temperature is the point at which the vertical line of the L mark is aligned with the distance indicator on the distance scale.

For accurate manual focusing on subjects at infinity distance, look through the viewfinder while rotating the focusing ring.


5. Image Stabilizer Settings

You can use the image stabilizer in AF or MF mode.

Set the STABILIZER switch to .

• If you are not going to use the image stabilizer function, set the switch to .

Select the stabilizer mode.

• MODE 1: Corrects vibrations in all directions. It is mainly effective for shooting still subjects.

• MODE 2: It compensates for vertical camera shake during following shots in a horizontal direction, and compensates for horizontal camera shake during following shots in a vertical direction.

When you press the shutter button halfway, the Image

Stabilizer will start operating.

• Make sure the image in the viewfinder is stable, then press the shutter button the rest of the way down to take the picture.


6. Tips on Using the Image Stabilizer

The image stabilizer in this lens is effective for hand-held shots under the following conditions.


• In semi-darkened areas such as indoors or outdoors at night.

• In locations where flash photography is prohibited, such as art museums and theater stages.

• In situations where your footing is uncertain.

• In situations where fast shutter settings cannot be used.

• When panning subjects in motion.


Tips on Using the Image Stabilizer

• The Image Stabilizer cannot compensate for a blurred shot caused by a subject that moved.

• Set the STABILIZER switch when you are using a tripod. If the Stabilizer switch is set to , the image stabilizer function may introduce errors.

• Set the STABILIZER switch to when you are taking pictures using the Bulb setting (long exposures). If the STABILIZER switch is set to , the image stabilizer function may introduce errors.

• The Image Stabilizer might not be fully effective in the following cases:

• You shoot while riding on a bumpy road.

• You move the camera dramatically for a panning shot in Mode 1.

• You shoot using techniques other than following shots in Mode 2.

• The Image Stabilizer consumes more power than normal shooting, so fewer shots can be taken if you use the function.

• The image stabilizer operates for about two seconds even when your finger is off the shutter button. Do not remove the lens while the stabilizer is in operation. This will cause a malfunction.

• With the EOS-1V/HS, 3, ELAN 7E/ELAN 7/30/33,


IIE/50/50E, REBEL 2000/300, IX, and D30, the Image

Stabilizer will not work during self-timer operation.

• When using a tripod, set the STABILIZER switch to prevent errors.

• The stabilizer is equally effective for hand-held photography and photography with a monopod.

• The Image Stabilizer function also operates when the lens is used with the EF12 II or EF25

II Extension Tube, and the EF1.4X II Extender.

• With Extender EF2X II attached to the lens, the

Image Stabilizer will work with the following cameras:

EOS-1Ds Mark III, EOS-1Ds Mark II, EOS-1Ds,

EOS-1D Mark lll, EOS-1D Mark II N, EOS-1D

Mark II, EOS-1D, EOS 40D, 30D, 20D, 20Da, 10D,




D30, EOS DCS1, DCS3, D2000, D6000, EOS-


7/30/33, ELAN 7NE/ELAN 7N/30V/33V, ELAN


REBEL G/500N, REBEL 2000/300, REBEL

Ti/300V, REBEL T2/300X, REBEL K2/3000V, IX,

IX Lite/IX7, 3000/88, 5000/888

• Pictures may look distorted after being taken depending on the camera, but this doesn't affect shooting.

• If you set the camera’s Custom Function to change the assigned button to operate the AF, the Image Stabilizer will operate when you press the newly assigned AF button.


7. Using the Tripod Mount

Adjusting the Revolving Mount

You can loosen the orientation lock-knob on the tripod mount to allow it to rotate as needed to fit a particular camera model for switching between vertical and horizontal positions.


Use the following procedures to remove and attach the tripod mount.

Loosen the orientation locking knob.

Rotate the tripod mount and align the mounting indicator on the tripod mount with the one on the lens.

Slide off the tripod collar away from the rear of the lens.

If the foot of the tripod mount overlaps the switch, loosen the orientation locking knob on the tripod mount to move the foot.


8. Hood

The built-in lens hood can reduce unwanted reflections and also protects the front of the lens from rain, snow, dust, and other substances.

When using the hood, extend it outward from the end of the lens until it stops and then turn it in the direction of the arrow. For storage, reverse the procedure.

9. Filters

(Sold separately)

You can attach filters to the filter mounting thread on the front of the lens.

• If you need a polarizing filter, use the Canon

Circular Polarizing Filter (77mm).

• To adjust the polarizing filter, first store the lens hood.


10. Extension Tubes

(Sold separately)

You can attach Extension Tube EF12 II or EF25

II for magnified shots. The shooting distance and magnification are shown below.




Distance (mm)


















Manual focusing is recommended for accurate focusing.

11. Close-up Lenses

(Sold separately)

Attaching a 500D (77mm) Close-up Lens enables close-up photography.

Magnification will be 0.82

× – 0.59×.

• Close-up Lens 250D cannot be attached because there is no size that fits the lens.

• Manual focusing is recommended for accurate focusing.


12. Extenders

(Sold separately)

With Extender EF1.4X ll or EF2X ll attached, the lens specifications will change as follows:


Focal length (mm)


Angle of view




Maximum magnification (


With EF1.4X ll Extender

420 f/5.6 – f/45




With EF2X ll Extender

600 f/8 – f/64





• First attach the Extender to the lens, then attach the lens to the camera. Detach it from the camera in the reverse order. If you attach the lens to the camera first, misoperation may occur.

• With Extender EF2X II attached to the lens, only manual focus is possible. However, with the EOS-

1Ds Mark III, EOS-1Ds Mark ll, EOS-1Ds, EOS-1D Mark lll, EOS-1D Mark ll N, EOS-1D Mark ll,

EOS-1D, EOS-1V/HS, EOS-3 camera, autofocusing with the center focusing point is possible.

• Only one Extender can be attached to the lens and camera.

• If you use an Extender on the lens mounted on a EOS A2/A2E/5, set the exposure compensation to -1/2 stop for the EF1.4X II or -1 stop for the EF2X II.

• Autofocusing is still enabled with Extender EF1.4X II attached.

• When an Extender is attached, the AF speed will become slower by design to retain proper

AF control.



Focal Length & Max. Aperture

Lens Construction

Min. Aperture

300 mm, f/4

15 elements in 11 groups f/32

Angle of View

Diagonal: 8°15’ Vertical: 4°35’ Horizontal: 6°50’

Min. Focusing Distance

1.5 m / 4.9 ft.

Max. Magnification & Field of view


× , 101 × 150 mm / 4.0 × 5.9 inch (at 1.5 m)

Filter Diameter

Max. Diameter & Length

77 mm


× 221 mm / 3.5 × 8.7 inch


1190 g / 42.0 oz

Lens Hood

Lens Cap





• The lens length is measured from the mount surface to the front end of the lens. Add 21.5 mm when including the lens cap and dust cap.

• The size and weight listed are for the lens only, except as indicated.

• Aperture settings are specified on the camera.

• All data listed is measured according to Canon standards.

• Product specifications and appearance are subject to change without notice.


CT1-8505-003 © CANON INC. 2002
