19-2862; Rev 2; 3/07
KIT
ATION
EVALU
E
L
B
A
IL
AVA
750mW Audio Amplifiers with Headphone Amp,
Microphone Preamp, and Input Mux
The MAX9765/MAX9766/MAX9767 family combines
speaker, headphone, and microphone amplifiers, all in
a small thin QFN package. The MAX9765 is targeted at
stereo speaker playback applications and includes a
stereo bridge-tied load (BTL) speaker amp, stereo
headphone amp, single-ended output mic amp, input
MUX, and I 2C control. The MAX9766 is targeted at
mono speaker playback applications and includes a
mono BTL speaker amp, stereo headphone amp, differential output mic amp, input MUX, and I2C control. The
MAX9767 is targeted at applications that do not require
a headphone amp and includes a stereo BTL speaker
amp, differential output mic amp, and parallel control.
These devices operate from a single 2.7V to 5.5V supply.
A high 95dB PSRR allows these devices to operate from
noisy supplies without additional power conditioning. An
ultra-low 0.003% THD+N ensures clean, low distortion
amplification of the audio signal. Patented click-and-pop
suppression eliminates audible transients on power and
shutdown cycles.
In speaker mode, the amplifiers can deliver up to
750mW of continuous average power into a 4Ω load. In
headphone mode, the amplifier can deliver up to 65mW
of continuous average power into a 16Ω load. The gain
of the amplifiers is externally set, allowing maximum
flexibility in optimizing output levels for a given load.
The MAX9765/MAX9766 also feature a 2:1 input multiplexer, allowing multiple audio sources to be selected.
The various functions are controlled by either an I 2Ccompatible (MAX9765/MAX9766) or simple parallel
control interface (MAX9767).
All devices include two low-noise microphone preamps, a differential amp for internal microphones, and
a single-ended amplifier for additional external microphones. A microphone bias output is provided, reducing external component count.
The MAX9765/MAX9766/MAX9767 are available in a
thermally efficient 32-pin thin QFN package (5mm ✕
5mm ✕ 0.8mm). All devices have short-circuit and
thermal-overload protection (OVP) and are specified
over the extended -40°C to +85°C temperature range.
Applications
PDA Audio Systems
Notebooks
Tablet PCs
Digital Cameras
Cell Phones
Features
♦
♦
♦
♦
♦
♦
♦
♦
♦
♦
♦
750mW BTL Stereo Speaker Amplifier
65mW Stereo Headphone Amplifier
2.7V to 5.5V Single-Supply Operation
Patented Click-and-Pop Suppression
Low 0.003% THD+N
Low Quiescent Current: 13mA
Low-Power Shutdown Mode: 5µA
MUTE Function
Headphone Sense Input
Stereo 2:1 Input Multiplexer
Optional 2-Wire, I2C-Compatible, or Parallel
Interface
♦ Small 32-Pin Thin QFN (5mm ✕ 5mm ✕ 0.8mm)
Package
Ordering Information
PART
TEMP RANGE
PINPACKAGE
MAX9765ETJ
-40oC to +85oC
32 TQFN-EP*
T3255-4
o
o
PKG
CODE
MAX9766ETJ
-40 C to +85 C
32 TQFN-EP*
T3255-4
MAX9767ETJ
-40oC to +85oC
32 TQFN-EP*
T3255-4
*EP = Exposed paddle.
Pin Configurations and Functional Diagrams appear at end of data
sheet.
Simplified Diagram
MUX
INL1
SPKR
LEFT
INL2
MUX
HEADPHONE
INR1
INR2
SPKR
RIGHT
DEVICE
CONTROL
CONTROL
MICINMUX
MICIN+
MICOUT
AUXIN
MICBIAS
BIAS
MAX9765
________________________________________________________________ Maxim Integrated Products
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
1
MAX9765/MAX9766/MAX9767
General Description
MAX9765/MAX9766/MAX9767
750mW Audio Amplifiers with Headphone Amp,
Microphone Preamp, and Input Mux
ABSOLUTE MAXIMUM RATINGS
VDD to GND ...........................................................................+6V
SVDD to GND .........................................................................+6V
SVDD to VDD .........................................................................-0.3V
PVDD to VDD .......................................................................±0.3V
PGND to GND.....................................................................±0.3V
All Other Pins to GND.................................-0.3V to (VDD + 0.3V)
Output Short-Circuit Duration (to VDD or GND)..........Continuous
Continuous Input Current (into any pin except power-supply
and output pins) ...............................................................±20mA
Continuous Power Dissipation (TA = +70°C)
32-Pin Thin QFN (derate 26.3mW/°C above +70°C) ...2105.3mW
Operating Temperature Range ...........................-40°C to +85°C
Storage Temperature Range .............................-65°C to +150°C
Junction Temperature ......................................................+150°C
Lead Temperature (soldering, 10s) .................................+300°C
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
ELECTRICAL CHARACTERISTICS
(VDD = PVDD = 3.0V, GND = 0, HPS = MUTE = GND, SHDN = 3V, CBIAS = 1µF, RIN = RF = 15kΩ, RL = ∞. TA = TMIN to TMAX, unless
otherwise noted. Typical values are at TA = +25°C.) (Note 1)
PARAMETER
Supply Voltage Range
Quiescent Supply Current
(IVDD + IPVDD)
Shutdown Current
Switching Time
Turn-On/Turn-Off Time
Input Bias Current
SYMBOL
VDD/PVDD
IDD
ISHDN
tSW
tON/OFF
CONDITIONS
Inferred from PSRR test
MIN
TYP
2.7
MAX
UNITS
5.5
V
MAX9765/MAX9767
12
28
MAX9766
7
17
Headphone mode, HPS = VDD
7
17
SHDN = GND
5
18
Gain or input switching
(MAX9765/MAX9766)
10
CBIAS = 1µF, settled to 90%
250
CBIAS = 0.1µF, settled to 90%
25
Speaker mode
IBIAS
mA
µA
µs
ms
50
nA
Thermal Shutdown Threshold
150
o
C
Thermal Shutdown Hysteresis
8
o
C
Output Short-Circuit Current
To VDD or GND
1.2
VBIAS = 1.25V, VDD = 0V
230
A
STANDBY SUPPLY (SVDD)
Standby Current
ISVDD
VBIAS = 1.5V, VDD = 3V
400
5
µA
OUTPUT AMPLIFIERS (SPEAKER MODE)
Output Offset Voltage
VOS
VOUT_+ - VOUT_-, AV = 1V/V
Power-Supply Rejection Ratio
PSRR
Output Power
POUT
fIN = 1kHz, THD+N = 1%,
TA = +25oC (Note 2)
THD+N
fIN = 1kHz, BW = 22Hz to
22kHz
Total Harmonic Distortion Plus
Noise
Signal-to-Noise Ratio
2
SNR
10
VDD = 2.7V to 5.5V
72
f = 1kHz, VRIPPLE = 200mVP-P
72
RL = 8Ω
RL = 4Ω
85
450
400
750
POUT = 200mW,
RL = 8Ω
0.033
POUT = 400mW,
RL = 4Ω
0.065
RL = 8Ω, VOUT_ = 1.4VRMS, BW = 22Hz to
22kHz
45
mV
dB
mW
%
89
