2009 Catalogue

DPS Cat Cover V2 16/1/09 13:01 Page 1

DPS 2009 Cat Contents Pg 19/1/09 09:14 Page 1

Contents

Pg 2 Introduction

Pg 3 - 14 Heatbanks

Pg 15 - 20 Electric Central Heating

Pg 21 - 22 Multifuel Case Study

Pg 23 Foamed Copper Cylinders

Pg 24 Budget Mains Fed

Thermal Storage Systems

Pg 25 DPS Hi Flow Mains

Conversion Kit

Pg 26 Boiler Master PHE Heat

Exchange Systems

Pg 27 - 28 Communal Heating

Systems

Pg 29 - 30 Solar Electric Heat

Bank Pack

Pg 31 - 36 Unvented Cylinders

Pg 37 - 40 Pumps & Pump Sets

Pg 41 Accumulators

Pg 42 Pump Accessories

HOT WATER SYSTEMS...

Is there anything we haven’t thought of?

Free Advice.

DPS have always provided free advice and system design, both domestic and commercial. Furthermore, our internet site has hosted free software and technical articles on all types of hot water system for over 10 years.

Fit and forget mains hot water systems with outstanding performance.

Take our Heat Banks for example. No annual maintenance requirements or discharge pipes. A Heat Bank can do everything an unvented can, plus a whole lot more, including higher pressures, a far greater range of sizes including four cylinder diameters as well as custom rectangular tanks, no need to use a registered installer and no need to notify building control. Technical advice is given on choosing the best system.

A comprehensive set of domestic system design software, available free of charge, with free technical consultancy backup.

It is no longer difficult to design a system that combines multiple heat sources

(electric, gas, oil, solar, solid fuel, bio-mass or heat pumps) into a property.

Answer a few basic questions and the software will do a preliminary design for you, providing system layout, wiring and installation instructions. It only takes a couple of minutes to use and requires only basic technical knowledge. Further discussion with our technical sales will help advance and finalise the most suitable design.

Customised and pre-fabricated systems to your exact requirements, fitted with your choice of controls, tested and ready for quick installation.

Effectively a plug-and-play hot water system that is designed to do whatever you desire and fit into whatever space you have. Circular or rectangular, vertical or horizontal, short and fat or tall and thin and with the combination of heat sources you wish to make use of or provide for future connection. To top it off, all the controls, pumps, programmers and valves are factory fitted, wired and tested, reducing the installers job to little more than connecting pipes. Just tell us your cupboard space and what you are trying to achieve... we’ll do the rest.

Ancillary equipment to cover every requirement.

From silent low power pumps to high output pump sets, gas boilers to solar panels, programmers to underfloor heating kits. DPS aim to provide a single source for all domestic system hardware, with the technical backup to help you choose the best equipment for the job.

Service second to none.

As a family business we take great pride in our ability to satisfy every customer, from initial design through to on-site service backup. When you deal with DPS you can be confident that we care as much about satisfying your needs as we do about making a sale. As standard we provide one year on-site cover, two years guarantee on all components and typically twenty-five years guarantee on cylinders.

An Encyclopedia of Hot Water.

The freely available DPS CD-ROM contains information on all types of hot water and central heating systems. It is also packed with free software, including our latest system design software and HVAC calculators - everything required to design a complete system. Our PDF library has information and datasheets from across the industry, including a comprehensive section on solar hot water panels and systems and to top it off, the CD contains a complete copy of the

DPS heatweb internet site.

Phone today for your

FREE COPY

0845 241 1441 www.heatweb.com

DPS take the ‘um’ out of Plumbing

How Epsom based designers and suppliers of plumbing systems, DPS, can help you solve all your hot water problems.

Richard Hanson-Graville explains.

DPS design and manufacture the latest in hot water and central heating products for domestic homes, major house builders, local authorities and plumbers.

Armed with all the general technical information, we then put together a design that will do everthing that is asked for, and can be supplied pre-fabricated ready for easy connection to pipework. We supply full specifiactions, prices, and installation instructions, and talk the customer through the design, offering any options that have not been considered, and making any fine adjustments that are needed.

The approach is similar for architects, consultants, house

DPS started life as a family run consultancy, with a long history in manufacturing hot water systems. One of the first products designed and brought to the market was the

Heat Bank range of thermal stores, the first domestic hot water cylinders to make use of a plate heat exchanger for extensively for ten years by major house builders and local authorities, the range has become a trusted solution with better performance and lower installation and maintenance requirements than alternative more conventional approcahes.

Although DPS have a standard basic range of cylinders, the options by no means stops there. All systems require controls of some sort, be they immersion heater controllers, boiler pumps, motorised valves or underfloor heating controls. These are usually assembled on site by the installer, to achieve the customers requirements.

The more complicated a system gets, the more controls are required, and the design burden on the installer increases. Where a customer wished to combine a number of technologies the complexity can reach a point where more specialist installers are required.

DPS have the ability to pre-fabricate all the controls into a single ready-to-connect system, overcoming the more difficult design and installation requirements. Our prefabricated systems come with all controls piped up, wired and tested, and can be installed by any reasonable plumber. Many can even be legally DIY installed.

System are hand assembles to cutomers requirements (above). All systems are tested and setup to suit (below).

For private home-owners or pumbers who are installing a new hot water and heating system, we will first go over all the heat sources they wish to use. These can be electric heaters, a gas or oil boiler, wood burning stove, solid fuel cooker, solar panels, geo-thermal energy, or heat pumps.

We then find out what they are trying to accomplish in terms of central heating, be it radiators, underfloor heating or a combination of both, and how they want to control it.

Next we find out the hot water requirements; how many baths, or showers are typcally required, and what is the maximum use they wish to allow for. Finally we look at the cupboard space provided, as this can affect a design. All this can usually be done in a single phone conversation.

Experienced designers with computerised design service.

builders or local authorities, except that there may be some more specific requirments such as to use a particular manufacturers controls, or fit additional metering equipment.

DPS have worked closely with consultants over the years, and started life itself as a design consultancy. We know a great deal about designing both individual and multiple dwelling systems, the controls that are available, the best ways of connecting heat sources to loads, using storage to maximise energy efficiency, and we can provide free consultancy in all these fields.

We do the design work and provide finished designs for free becuase we believe customers who are informed will choose our products because they make sense. This is why you will find our website holds more generic techncial information than any other in the industry, and why we hand out free CD’s packed with technical reading from a number of manufacturers, as well as free design software. We want you to understand the various options and systems so you can make an informed choice, rather than be guided by sales talk.

DPS’s philosophy is simple: to manufacture or source the best solution to our customers requirements, and present customers with all the options and technical information to allow them to make an informed choice.

We try not to focus on a set range of products, but rather to offer the best solution, whatever it may be, and to enable us to do this better we have expanded our range by acting as distributors for what we feel are the best of the rest, including unvented cylinders, pumps, solar panels, underfloor controls and booster sets... sometimes a £125 pump will solve the problem, and we would prefer to offer this as a solution as well as maybe a brand new mains pressure system upwards of £500.

DPS provide one year on-site cover, two years guarantee on all components, and typically twenty-five years on any hot water cylinders from leaks.

Anyone wishing to learn more about what DPS can offer is always welcome to visit the Epsom showroom and factory where systems are on display and technical help can be provided.

Further reading and help:

DPS Heatweb Web Site:

www.heatweb.com

Online Domestic Design Software:

www.dpsheatweb.com

Solar Facts and Products:

www.heatweb.com/solar

Dedicated Pressure Systems Lt d.

T el 01372 803 675 / 643

The simplest system ever ?

The Electric Pandora Heat Bank provides mains pressure hot water and can be installed in 1 hour.

Probably our biggest ever seller, the

Electric Pandora Heat Bank provides full mains pressure hot water up to nine bar pressure and at flows that can fill a bath in four minutes.

It only has two pipe connections, cold in and hot out, and is supplied fully prefabricated, with economy immersion heater controls and power supply cables ready for very quick installation.

To make life even better, the system has no annual maintenance requirements, and does not require a registered installer or notification to building control.

Tall and thin or short and fat ?

Not all cupboards are the same size, but DPS can provide systems to fit almost anywhere.

In an ideal worlds, one has a large cupboard or even a plant room for all the hot water equipment. In real life however, space in a property is often limited, and usually sacrifices have to be made to fit in a suitable sized hot water cylinder.

To help overcome this, DPs can offer the same capacity stores in a number of sizes, including four circular stores and a variety of rectangular models. For example, all the cylinders below hold the same amount of water.

Everything Covered

Heat Bank Thermal Stores

Unvented Cylinders

British Standard Cylinders

High Output Tank Fed

Underfloor Heating

District Heating Systems

500 to 3000 ltr Cylinders

Commercial Equipment

Silent Booster Pump

Pumps and Pump Sets

Accumulators

Plate Heat Exchangers

Mains Conversion Kit

Solar Panels & Equipment

Integrated Solar Stores

Solar Pandora Heat Bank

Solar Unvented

Free Design & Consultancy

Free Design Software

1 Year On-Site Cover

2 Years Warranty on Parts

10 Years on Copper Stores

25 Years on Stainless Stores

Our showroom and factory are located in Epsom, Surrey, are are fitted with working demonstrations systems for a number of technologies including thermal storage and solar. Please phone DPS on

01372 803 643 / 675 for product information or to arrange a visit.

An Encyclopedia of Hot Water and Central

Heating

The latest DPS CD ROM contains technical information on all types of hot water system, as well as articles, products and links to helpful web sites. The CD also contains free software including the lates domestic system designer covering gas, electric, solar, solid fuel, geothermal, and underfloor heating.

Phone for your FREE COPY

01372 803 643 / 675

Approved Manufacturer

www .heatw

eb.com

2

PANDORA

VS

UNVENTED

A comparison of Pandora Heat Bank Thermal Stores to Unvented Hot Water Cylinders

HIGHER PRESSURES AND FLOW RATES

UNVENTED:

limited in the pressure they can supply to taps by a pressure reducing valve, typically in the region of

3 bar.

PANDORA:

pressures up to 9 bar to hot taps, mains providing.

NO DISCHARGE PIPES

UNVENTED:

require a discharge pipe and tundish to protect against overpressurisation of the store.

Common for discharge to spill over tundish onto floor.

PANDORA:

requires none.

NO SPECIAL TRAINING

UNVENTED:

require a person to possess an industry recognised qualification to install or service.

PANDORA:

requires none.

NO NEED TO NOTIFY BUILDING INSPECTOR

UNVENTED:

installations should be reported to, and inspected by, the building inspector, as according to the G3 building regulations for unvented, pressurised cylinders.

PANDORA:

requires none.

NO ANNUAL MAINTENANCE

UNVENTED:

should be regularly serviced to check operation of safety controls. Cylinders using an internal bubble for expansion may also need this re-charged to prevent dripping discharge pipe.

PANDORA:

requires no regular maintenance, other than renewal of corrosion inhibitor every

3 to 5 years.

NO LIME-SCALE IN STORE

UNVENTED:

as water is heated, limescale is deposited onto the inside walls of the cylinder, and on heating surfaces. Fresh limescale is introduced with each draw-off, and this cannot be flushed out.

PANDORA:

it is the same water in the store in 10 years as the day it was installed, so no limescale build-up. Plate heat exchanger is relatively immune, but can be easily flushed if needed.

All the advantages, None of the disadvantages.

3

PRODUCT DATA SHEET

Pandora Heat Bank

Thermal Stores

Pandora Heat Banks

Mains Pressure Hot Water Systems using unpressurised storage for the high performance mains hot water via a plate heat exchanger (PHE). The unique feature of the patented design is the lack of a discharge pipe from the store, making it ideal for apartments or other places where pipework is hard to run. In addition, there is no annual servicing required, making the

Pandora the simplest ways of obtaining high pressure hot water.

Mains Pressure Hot Water up to 9 bar.

Unpressurised system suitable for DIY installation.

No discharge from store.

Indirect and Electric models.

Ability to run central heating from stored water.

Rapid recovery option using PHE instead of coil.

Cased with 40mm Insulation

Choice of Diameters and Heights.

Solar options.

Options for additional immersion heaters.

Cased units available.

Additional bosses on request.

Options for fitted control assemblies.

No Annual Maintenance Requirements.

Plate Heat Exchanger

Technology:

Mains pressure hot

STANDARD OPTIONS

DHW Heat Exchanger

Thermostatic DHW Mixer

Secondary Return Pump (Grundfos) water is heated through a plate heat exchanger that pulls heat from the stored hot water. The store itself is unpressurised, overcoming all safety and servicing demands that arise from a pressurised store.

Indirect Primary Coil

Rapid Recovery via PHE

Primary Control Assemblies

Primary Motorised Valves

Boiler Pump (Grundfos)

Sealed System Kit on Primary

Heating Circuit, Full Store

Heating Circuit, Lower Store

Heating Pump Grundfos (Grundfos)

Modulating Heating Pump

Underfloor Heating Valve

Programmer

Programmable Room Thermostat

RF Radio Communication with Room

Thermostat(s)

Immersion Heater

Immersion Heater Controller

Solar Coil

Sealed System Solar Controls

Direct Solar or Heat Pump Connections

Direct Solar Controls

Overheat Thermostatic Switch (wired to heating)

Overheat Discharge (mains hot water to drain)

100, 160, 300 kW

22, 28mm

15-14, 15-50

9 to 16 turn

Y-Plan, S-Plan

22, 28mm

15-60, 25-55

22, 28mm

22, 28mm

15-60, 25-55, 25-80

22, 28mm

One, Two Channel

TP5000, TP7000

1, 2, 3 Zone

3, 6 kW

3, 15kW

Dedicated Pressure Systems Ltd.

www.heatweb.com

4

PRODUCT DATA SHEET

Standard Electric:

The most basic form of

Pandora is the standard electric model. The unit only has two pipework connections, cold in & hot out, and can be installed in a fraction of the time of comparable hot water systems. The unit can be supplied with a pre-wired immersion heater controller, reducing the electrical installation further.

Pandora Heat Banks

Standard Indirect:

The indirect model is fitted with a high recovery coil that allows connection to any gas or oil boiler system. The unit is perfect for customers wishing to swap from a standard tank fed system with minimal effort, as the store has the same four connections - cold in, hot out, flow from boiler, and return to boiler. The only difference is the cold in comes from the mains rather than from the cold tank.

Electric Hot Water and

Central Heating:

The Pandora can be used to provide a stand alone electric hot water and wet central heating systems, without the need for any other boilers, tanks, controls, or even a discharge. The unit has the unique ability to run the central heating using stored heat from cheap rate electricity, making it a serious alternative to gas.

Prefabricated Indirect:

The indirect Pandora can be supplied with the full array of central heating controls fully assembled and wired onto the side of the unit. This ensures a rapid installation, both mechanically and electrically, with little to be done other than connect to pipework and wire to the boiler. The choice of controls is endless, with customers able to specify the make and layout of the supplied controls.

Rapid Indirect Recovery Options:

Instead of using a coil to allow connection to a boiler, the

Pandora can be supplied with a plate heat exchanger

(PHE) to reheat the store using everything the boiler can provide. This reduces heat up times dramatically, and reduces the size of store required.

System Design made Easy:

Pandora Heat Banks can be easily designed online on the DPS web site using our PANEX System Designer.

Systems are fully assembled and wired to match the chosen design, tested and supplied ready for a rapid installation.

On-site backup is provided as well as two years guarantee on all components, and ten years on all copper cylinders (twenty on stainless).

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 0845 2411441 Fax. 01372 803678

5

STANDARD SIZES (COPPER)

CAPACITY

130 ltr

150 ltr

180 ltr

180 ltr

210 ltr

210 ltr

210 ltr

250 ltr

250 ltr

250 ltr

300 ltr

300 ltr

350 ltr

400 ltr

415 ltr

DIAMETER

530mm

530mm

530mm

580mm

530mm

580mm

680mm

530mm

580mm

680mm

580mm

680mm

680mm

680mm

680mm

HEIGHT

1150mm

1300mm

1550mm

1300mm

1750mm

1500mm

1150mm

2000mm

1700mm

1300mm

2000mm

1550mm

1800mm

1950mm

2000mm

Rectangular Tanks can be supplied upon request to specified width, depth and height.

www.heatweb.com

email: [email protected]

CPC-150-ABBAA

Manually Filled store - NO discharge pipe or overflow.

100kW Plate Heat Exchanger can heat 30 ltr/min of mains hot water, up to 6 bar pressure.

6

8

9

10

7

1 Plate Heat Exchanger, L18-14 (80kW)

2 Flow switch

3 Heat Exchanger Pump

4 Thermostatic mixing valve, RWC Heatguard 22mm

5 Drain off cock

6 Removable lid

7 White plastic coated steel casing

8 Anti-vacuum valve

9 Vent, with evaporation protection

10 Filling Point, with hose

11 Wiring Centre

13 Boost Immersion Heater

17 Cylinder Thermostat, Immersed [70°C]

53 Y-Pattern Strainer

11

53

13

HX14

1

4

17

3

2

5

16A, 3kW

Wiring Diagram:

CPC-150-ABBAA

Flow

Switch

CPC-150-ABIAJ

Manually Filled store - NO discharge pipe or overflow.

100kW Plate Heat Exchanger can heat 30 ltr/min of mains hot water, up to 6 bar pressure.

6

8

9

10

7

28

1 Plate Heat Exchanger, L18-14 (80kW)

2 Flow switch

3 Heat Exchanger Pump

4 Thermostatic mixing valve, RWC Heatguard 22mm

5 Drain off cock

6 Removable lid

7 White plastic coated steel casing

8 Anti-vacuum valve

9 Vent, with evaporation protection

10 Filling Point, with hose

11 Wiring Centre

13 Boost Immersion Heater

17 Cylinder Thermostat, Immersed [70°C]

18 Lockshield Balancing Valve, 22mm

19 Automatic Air Vent with Manual Vent

20 Three Port Motorised Valve, 22mm

23 Primary pump, Grundfos UPS15-50

28 Danfoss FP715 Two Channel Programmer

30 Danfoss RMT230 Room Thermostat

53 Y-Pattern Strainer

60 Plate Heat Exchanger CB18-30

61 Htg Exchanger Pump

62 Sensor Point

63 Flow Setter

11

13

HX14

1

4

17

20 19

63

18

16A, 3kW

62

60

23

61

3

2

30

53

5

Wiring Diagram:

CPC-150-ABIAJ

Flow

Switch

CPC-250-DBVCGL-UFH

Manually Filled store - NO discharge pipe or overflow.

160kW Plate Heat Exchanger can heat 45 ltr/min of mains hot water, up to 6 bar pressure.

25

6

8

9

10

7

29

28

26

1 Plate Heat Exchanger, L18-28 (160kW)

2 Flow switch

3 Heat Exchanger Pump

4 Thermostatic mixing valve, RWC Heatguard 28mm

5 Drain off cock

6 Removable lid

7 White plastic coated steel casing

8 Anti-vacuum valve

9 Vent, with evaporation protection

10 Filling Point, with hose

11 Wiring Centre

13 Boost Immersion Heater

17 Cylinder Thermostat, Immersed [70°C]

18 Lockshield Balancing Valve, 22mm

19 Automatic Air Vent with Manual Vent

20 Hot Water Zone Valve, 22mm

21 Heating Motorised Valve, 28mm

22 Heating Motorised Valve, 22mm

23 Primary pump, Grundfos UPS25-55

24 Automatic By-Pass Valve, 22mm

25 Primary expansion vessel, 18 litre

26 Primary Pressure relief valve with gauge, 3 bar

27 Primary filling loop

28 Danfoss TS715 Programmer (Hot Water)

29 Danfoss RX1 Radio Reciever

30 Danfoss TP7000 Programmable Thermostat

32 Flow to Solar Coil

33 Return from Solar Coil

34 Solar Sensor Pocket

37 Underfloor Heating Mixing Valve, 28mm

38 Underfloor Heating Pump, Grundfos 15-60

53 Y-Pattern Strainer

53

34 11

19

20

13

HX28

4

1

3

2

38

17

37

21

23

27

34

32

5

33

18

16A, 3kW

22

24

30

Wiring Diagram:

CPC-250-DBVCGL-UFH

Flow

Switch

CPC-180-APA

Manually Filled store - NO discharge pipe or overflow.

100kW Plate Heat Exchanger can heat 30 ltr/min of mains hot water, up to 6 bar pressure.

6

8

9

10

7

16

11

1 Plate Heat Exchanger, L18-14 (80kW)

2 Flow switch

3 Heat Exchanger Pump

4 Thermostatic mixing valve, RWC Heatguard 22mm

5 Drain off cock

6 Removable lid

7 White plastic coated steel casing

8 Anti-vacuum valve

9 Vent, with evaporation protection

10 Filling Point, with hose

11 Wiring Centre

13 Boost Immersion Heater

14 Economy Immersion Heater

16 Economy/Boost Immersion Heater Controller

53 Y-Pattern Strainer

HX14

1

4

13

53

3

2

14

5

16A, 3kW

Wiring Diagram:

CPC-180-APA

Flow

Switch

CPC-250-APAAB-EAAB

Manually Filled store - NO discharge pipe or overflow.

100kW Plate Heat Exchanger can heat 30 ltr/min of mains hot water, up to 6 bar pressure.

25

6

8

9

43

10

7

16

28

26

16A, 3kW

30

34 11

1 Plate Heat Exchanger, L18-14 (80kW)

2 Flow switch

3 Heat Exchanger Pump

4 Thermostatic mixing valve, RWC Heatguard 22mm

5 Drain off cock

6 Removable lid

7 White plastic coated steel casing

8 Anti-vacuum valve

9 Vent, with evaporation protection

10 Filling Point, with hose

11 Wiring Centre

13 Boost Immersion Heater

14 Economy Immersion Heater

16 Economy/Boost Immersion Heater Controller

19 Automatic Air Vent

25 Expansion Vessel, 18 litre

26 Pressure Relief Valve (3 bar) with Gauge

28 Danfoss FP715 Two Channel Programmer

30 Danfoss RMT230 Room Thermostat

32 Flow to Solar Coil

33 Return from Solar Coil

34 Solar Sensor Pocket

42 Filling Point / Drain

43 Solar Controller (Resol BS4)

44 Solar Pump (6m)

45 Non-Return Valve

53 Y-Pattern Strainer

53

HX14

1

4

13

3

2

14

34

19

32

5

33

45

42

44

Wiring Diagram:

CPC-250-APAAB-EAAB

Flow

Switch

PRODUCT DATA SHEET

GX Heat Bank Thermal

Storage Systems

GX Heat Bank Systems

Mains Pressure Hot Water Systems using Vented Storage for the highest performance from any hot water systems in our range. Particularly well suited to multiple heat sources or variable hot water loads, there are few applications where the

GX is not the best option.

Mains Pressure Hot Water up to 9 bar.

Fully Vented system suitable for DIY installation.

Integrated into Vented Boiler and Heating system.

Rapid Recovery using full boiler output.

Control over volume heated by boiler.

Ability to shower continuously from a small store.

Rapid heat up of radiators.

Cased with 40mm Insulation

Choice of Diameters and Heights.

Solar and Solid Fuel options.

Ability to use solar or solid fuel

towards central heating.

Options for fitted immersion heaters.

Cased units available.

Additional bosses on request.

250 litre GX Heat Bank with controls for Boiler, Radiators,

Underfloor Heating, and

Mains Hot Water with Solar

Coil.

Options for fitted control assemblies.

No Annual Maintenance Requirements.

Plate Heat Exchanger

Technology:

Mains pressure hot water

STANDARD OPTIONS

DHW Heat Exchanger

Thermostatic DHW Mixer

Secondary Return Pump (Grundfos)

GX Boiler Return Control is heated through a plate heat exchanger that pulls heat from the stored hot water. The GX itself is unpressurised, overcoming all safety and servicing demands that arise from a pressurised store.

Boiler Pump (Grundfos)

Twin Cylinder Thermostats

Heating Circuit, Full Store

Heating Circuit, Lower Store

Heating Pump Grundfos (Grundfos)

Modulating Heating Pump

Underfloor Heating Valve

Programmer

Programmable Room Thermostat

RF Radio Communication with Room

Thermostat(s)

Immersion Heater

Immersion Heater Controller

Solid Fuel Connections 28mm

Solar Coil

Sealed System Solar Controls

Direct Solar or Heat Pump Connections

Direct Solar Controls

Overheat Thermostatic Switch (wired to heating)

Overheat Discharge (mains hot water to drain)

100, 160, 300 kW

22, 28mm

15-14, 15-50

22, 28mm

15-60, 25-55, 25-80

22, 28mm

22, 28mm

15-60, 25-55, 25-80

22, 28mm

One, Two Channel

TP5000, TP7000

1, 2, 3 Zone

3, 6 kW

3, 15kW

Dedicated Pressure Systems Ltd.

www.heatweb.com

11

PRODUCT DATA SHEET

Primary Integration:

The GX System is part of the boiler and radiator (primary) system, and connects to a feed and expansion tank located higher than all radiators and associated pipework. Water is pumped directly from the store to the boiler and returns hot into the top of the store, without any coils to limit transfer. Likewise, central heating is pumped straight from the store to radiators or to underfloor heating manifolds, which in turn heat up very rapidly.

Buffered Operation of Boiler:

With the GX Heat Bank the boiler is effectively disconnected from the central heating, and is only used to reheat the store when required. This allows central heating to run from stored heat for a period without the boiler firing. Once there is sufficient water ready to reheat in one long efficient burn, the boiler is started. It also means that boilers can be oversized without any cycling problems.

Rapid Recovery and Smaller Stores:

The original concept of the GX was as a rapid recovery store, with the entire boiler output directed into the top of the store where it can be immediately used for hot water. This means that if a shower is run the boiler will keep up and no stored heat is used up until a second outlet is opened... so it is possible for a 90 litre store to run a bath and a 30 minute shower.

System Design made Easy:

GX Heat Banks can be easily designed online on the DPS web site using our PANEX System

Designer. Systems are fully assembled and wired to match the chosen design, tested and supplied ready for a rapid installation.

On-site backup is provided as well as two years guarantee on all components, and ten years on all copper cylinders (twenty on stainless).

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 0845 2411441 Fax. 01372 803678

GX Heat Bank Systems

STANDARD SIZES (COPPER)

CAPACITY

90 ltr

130 ltr

150 ltr

180 ltr

180 ltr

210 ltr

210 ltr

210 ltr

250 ltr

250 ltr

250 ltr

300 ltr

300 ltr

330 ltr

350 ltr

400 ltr

450 ltr

DIAMETER

480mm

530mm

530mm

530mm

580mm

530mm

580mm

680mm

530mm

580mm

680mm

580mm

680mm

580mm

680mm

680mm

680mm

HEIGHT

850mm

1100mm

1250mm

1400mm

1250mm

1600mm

1400mm

1200mm

1850mm

1600mm

1350mm

1850mm

1500mm

2000mm

1700mm

1850mm

2000mm

Rectangular Tanks can be supplied upon request to specified width, depth and height.

www.heatweb.com

email: [email protected]

12

CXC-150-ABADB-AIBD

Connects to a Feed and Expansion Tank (max. 10m head).

100kW Plate Heat Exchanger can heat 30 ltr/min of mains hot water, up to 6 bar pressure.

1 Plate Heat Exchanger, L18-14 (80kW)

2 Flow switch

3 Heat Exchanger Pump

4 Thermostatic mixing valve, RWC Heatguard 22mm

5 Drain off cock

7 White plastic coated steel casing

8 Vent

9 Cold Feed

11 Wiring Centre

13 Boost Immersion Heater

17 Cylinder Thermostat, Immersed [70°C]

28 Danfoss FP715 Two Channel Programmer

30 Danfoss RMT230 Room Thermostat

40 Primary Return Valve, 28mm

44 Heating Pump 5m

53 Y-Pattern Strainer

7

8

28

40

11

13

HX14

1

4

17

17

44

53

9

3

2

5

16A, 3kW

30

Wiring Diagram:

CXC-150-ABADB-AIBD

Flow

Switch

CXC-150-ABADD-BIDZD

Connects to a Feed and Expansion Tank (max. 10m head).

100kW Plate Heat Exchanger can heat 30 ltr/min of mains hot water, up to 6 bar pressure.

1 Plate Heat Exchanger, L18-14 (80kW)

2 Flow switch

3 Heat Exchanger Pump

4 Thermostatic mixing valve, RWC Heatguard 22mm

5 Drain off cock

7 White plastic coated steel casing

8 Vent

9 Cold Feed

11 Wiring Centre

13 Boost Immersion Heater

17 Cylinder Thermostat, Immersed [70°C]

28 Danfoss TS715 Programmer (Hot Water)

30 Danfoss TP7000 Programmable Thermostat

32 Flow to Solar Coil

33 Return from Solar Coil

34 Solar Sensor Pocket

40 Primary Return Valve, 28mm

42 Heating Pump 5m

44 Heating Pump 5m

53 Y-Pattern Strainer

55 Solid Fuel / Gravity 1'' Connection

7

8

30

28

55

42

34 11

13

HX14

1

4

17

17

45

44

3

2

40

16A, 3kW

53

55

9

34

32

5

33

Wiring Diagram:

CXC-150-ABADD-BIDZD

Flow

Switch

PRODUCT DATA SHEET

Electric Central Heating: HB2000

Electric Central Heating:

Heat Bank 2000 Range

Mains Pressure Hot Water Systems using unpressurised storage for the high performance mains hot water via a plate heat exchanger (PHE). Systems are heated Electrically, and also provide central heating to either radiators or underfloor heating. In addition, there is no annual servicing required, making the range an ideal way to obtaining high pressure hot water, and central heating, without a boiler.

Mains Pressure Hot Water up to 9 bar.

Unpressurised system suitable for DIY installation.

No discharge from store.

Electrically Heated up to 24kW.

Solar / Solid Fuel options.

Ability to run Central Heating from stored water.

Cased with 40mm Insulation

Choice of Diameters and Heights.

Options for additional immersion heaters.

Cased units available.

Additional bosses on request.

Options for fitted control assemblies.

No Annual Maintenance Requirements.

Plate Heat Exchanger

Technology:

Mains pressure hot water is heated through a plate heat exchanger that pulls heat from the stored hot water. The GX itself is unpressurised, overcoming all safety and servicing demands that arise from a pressurised store.

STANDARD OPTIONS

Xcel Model: Feed and Expansion Tank

Pandora Model: Manual Fill, No Discharge

DHW Heat Exchanger

Thermostatic DHW Mixer

Secondary Return Pump (Grundfos)

Sealed System Kit on Heating

Heating Circuit, Full Store

Heating Circuit, Lower Store

100, 160, 300 kW

22, 28mm

15-14, 15-50

22, 28mm

22, 28mm

Heating Pump Grundfos (Grundfos)

Modulating Heating Pump

Underfloor Heating Valve

Programmer

Programmable Room Thermostat

RF Radio Communication with Room

Thermostat(s)

Immersion Heater

Immersion Heater Controller

Solid Fuel Connections

Solar Coil

Sealed System Solar Controls

Direct Solar or Heat Pump Connections

Direct Solar Controls

Overheat Thermostatic Switch (wired to heating)

Overheat Discharge (mains hot water to drain)

15-60, 25-55, 25-80

22, 28mm

One, Two Channel

TP5000, TP7000

1, 2, 3 Zone

3, 6 kW

3, 15kW

28mm

Dedicated Pressure Systems Ltd.

www.heatweb.com

15

PRODUCT DATA SHEET

Standard Electric:

The most basic form of

HB2000 is the Xcel model, and the best for most applications. The unit connects to a feed and expansion tank (separate) to fill the cylinder and the central heating system. The central heating is pumped directly from the store, with the option for separately fed circuits. Underfloor heating manifold can pull directly from stored hot water.

Electric Central Heating: HB2000

Underfloor Heating Controls:

Electric central heating works best with underfloor heating, and the range includes options for fitted underfloor temperature control and pump. This simplifies the manifold assemblies considerably, and makes it easier to use more than one manifold.

The choice of controls varies from basic thermostatic control, up to weather compensation and even

C-Bus linked systems.

Solar or Solid Fuel Models:

The Heat Bank range can connect to solar panels either directly, or indirectly via a coil. Units can be fitted with a complete solar kit for quick connection to panels. They can also connect to a wood burner or other biomass boiler as an auxiliary heat source. Wood burners are particularly useful to match peak heating demand where electrical power supplies are limited and gas or oil is ruled out.

System Design made Easy:

Heat Banks can be easily designed online on the DPS web site using our

PANEX System Designer. Systems are fully assembled and wired to match the chosen design, tested and supplied ready for a rapid installation. www.dpsheatweb.com

On-site backup is provided as well as two years guarantee on all components, and ten years on all copper cylinders (twenty on stainless).

15kW Immersion Heater Controller:

The MCT50 Immersion Heater Controller provides flexible control of up to 15kW of heaters. These are split into two separate power supplies, 6kW and 9kW, to allow connection to dual meters.

Timers for Economy and Boost are provided, as well as the ability to sense supplies coming on. Remote 2-wire boost facility is provided, as well as the ability to use any clock as boost.

Overheat and Low Water

Protection facilities, and it is possible to sequence immersion heaters from top to bottom.

System Sizing:

Picking the correct size of unit and number of heating elements is affected by the economy tariffs available, the type of meter, and the peak central heating demands. With this information, DPS can help select the best combination and advise how the options will affect electrical load and running costs.

STANDARD SIZES - XCEL

CAPACITY

DIAMETER

210 ltr

250 ltr

530mm

530mm

250 ltr

300 ltr

300 ltr

300 ltr

530mm

530mm

580mm

680mm

330 ltr

350 ltr

400 ltr

450 ltr

580mm

680mm

680mm

680mm

STANDARD SIZES - PANDORA

HEIGHT

1600mm

1850mm

1600mm

2000mm

1850mm

1500mm

2000mm

1700mm

1850mm

2000mm

CAPACITY

210 ltr

250 ltr

250 ltr

300 ltr

300 ltr

DIAMETER

530mm

530mm

580mm

580mm

680mm

HEIGHT

1750mm

2000mm

1700mm

2000mm

1550mm

350 ltr

415 ltr

680mm

680mm

1800mm

2000mm

Rectangular Tanks can be supplied upon request to specified width, depth and height.

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 01372 803 643 / 675 Fax. 01372 803678

www.heatweb.com email: [email protected]

16

CXC-250-BN63AAA-AAAB

Connects to a Feed and Expansion Tank (max. 10m head).

160kW Plate Heat Exchanger can heat 45 ltr/min of mains hot water, up to 6 bar pressure.

1 Plate Heat Exchanger, L18-28 (160kW)

2 Flow switch

3 Heat Exchanger Pump

4 Thermostatic mixing valve, RWC Heatguard 22mm

5 Drain off cock

7 White plastic coated steel casing

8 Vent

9 Cold Feed

11 Wiring Centre

13 Immersion Heater 3kW

14 Economy Immersion Heater

53 Y-Pattern Strainer

7

8

11

HX28

4

13

13

1

53

9

3

2

14

5

2x 16A, 6kW

16A, 3kW

Wiring Diagram:

CXC-250-BN63AAA-AAAB

Flow

Switch

CXC-250-BQ66AAD-AAAD

Connects to a Feed and Expansion Tank (max. 10m head).

160kW Plate Heat Exchanger can heat 45 ltr/min of mains hot water, up to 6 bar pressure.

1 Plate Heat Exchanger, L18-28 (160kW)

2 Flow switch

3 Heat Exchanger Pump

4 Thermostatic mixing valve, RWC Heatguard 22mm

5 Drain off cock

7 White plastic coated steel casing

8 Vent

9 Cold Feed

11 Wiring Centre

12 Water Level Sensor

13 Immersion Heater 3kW

30 Danfoss TP7000 Programmable Thermostat

44 Heating Pump 5m

49 Heater Control Stat + Overheat Stat

50 Lower Heater Control Stat

51 Immersion Heater Controller Plus

53 Y-Pattern Strainer

7

8

12

11

49

51

53

HX28

4

13

13

1

44

9

3

2

50

13

13

5

30

32A, 6kW

32A, 6kW

Wiring Diagram:

CXC-250-BQ66AAD-AAAD

32A, 6kW

32A, 6kW

Flow

Switch

CXC-250-BQ96AAD-LABQ

Connects to a Feed and Expansion Tank (max. 10m head).

160kW Plate Heat Exchanger can heat 45 ltr/min of mains hot water, up to 6 bar pressure.

1 Plate Heat Exchanger, L18-28 (160kW)

2 Flow switch

3 Heat Exchanger Pump

4 Thermostatic mixing valve, RWC Heatguard 22mm

5 Drain off cock

7 White plastic coated steel casing

8 Vent

9 Cold Feed

11 Wiring Centre

12 Water Level Sensor

13 Immersion Heater 3kW

14 Immersion Heater 6kW

30 Danfoss TP7000 Programmable Thermostat

32 Flow to Solar Coil

33 Return from Solar Coil

34 Solar Sensor Pocket

44 Heating Pump 6m

49 Heater Control Stat + Overheat Stat

50 Lower Heater Control Stat

51 Immersion Heater Controller Plus

53 Y-Pattern Strainer

7

8

53

12

34 11

49

51

HX28

14

13

4

13

1

3

2

50

13

13

9

34

32

5

33

45

44

30

45A, 9kW

32A, 6kW

Wiring Diagram:

CXC-250-BQ96AAD-LABQ

32A, 6kW

45A, 9kW

Flow

Switch

PRODUCT DATA SHEET

15kW Immersion Controller

15kW Immersion Heater

Controller: MCT50

For systems requiring more than the usual 3 to 6kW of elements, typically for driving hot water and central heating, the MCT50 covers every possible immersion heater wiring configuration we have encountered in 20 years.

Controls up to five 3kW immersion heaters.

Suitable for single or dual supplies.

Staggered firing of heating elements.

Fuses for each heater built in.

Ability to split storage into 1,2 or 3 zones.

Ability to sequence between zones.

Ability to sense an externally switched power supply.

Option economy timers (3 on/offs).

Boost timer.

Menu driven setup, with hidden engineers' menu.

Hard wired power relays.

Large rising clamp cable terminals.

Ability to chain units together for up to 45kW.

The versatility of the MCT50 allows electrical tariffs or meter arrangements to be changed on site without rewiring the heating controls to suit. It has been designed for reliability and ease to service, and overcomes a great deal of site labour when fitted to a

Heat Bank and pre-wired.

Remote Boost:

The MCT50 comes with a 2-wire boost button to bring on elements for 1 hour when pressed. The button flashes on overheat or low water level trip. Alternatively one can use any switch of timer for boost control.

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 0

845 2411441 Fax. 01372 803678

SPECIFICATION

Purpose of control

Classification

Heaters

Contact rating

Level Sensor Output

Control power supply

Load power supply

Boost duration

Remote Boost duration

Operating temperature range

Control pollution situation

Shock protection

Rated impulse voltage

Ball pressure test

Enclosure protection

Contacts

Case material

Weight

Overall Dimensions

Mounting

Sensing control

Type 1.B Action, microdisconnection on operation

230VAC Suitable for heating elements up to 3kW

230VAC 3A resistive / 3A inductive

230V AC 50Hz 4W

230V AC 50Hz

3 x 3kW, 9kW max and 2 x 3kW, 6kW max

30, 60 and 120 min, timed

60 min

0°C to 40°C

Pollution degree 2

Class II

4000V

75°C

IP30

Micro-disconnection

Flame retardant high impact

Polystyrene (HIPS)

Master 1.2 kg; Slave 1.0kg

Width 220mm (including cable glands) Height 254mm

Depth 63mm

Surface mounting

www.heatweb.com email: [email protected]

20

DPS DPS 9/1/09 16:27 Page 1

Want a renovating fairytale?

Call in the specialists …

When you have a characterful older property, the challenge is to bring it up to the twenty-first century without losing any of its traditional charm. And when Michael Axler renovated his Edwardian home, he decided not only to modernise but to prepare for the future.

“Our home is rather unusual,” Michael explains, “in that it’s part of a

very large Edwardian manor which has been divided into separate apartments. But at the same time, it’s a very normal scenario – before we renovated, we had a conventional boiler, antiquated pipes and poor water pressure which we had to boost with two rather noisy pumps. Our ideal heating system would be multi-fuel, so that it could be connected to our solar panels and wood burner as well as to our gas supply, and one which was flexible enough to be adaptable to our future requirements. We also hoped to find a system that would dispense with the lengthy and antiquated pipework in the property, as well as improving our water pressure.”

This may seem like a lot to ask, but the Axlers weren’t disappointed. “Well,” Michael says, “we found everything we were

looking for in the DPS Heatbank. We’ve connected it to our solar panels and our wood burning stove and removed those unsightly pipes – although we were able to leave some of the original radiators as period features. Now it’s much neater, with everything in one place. And we have control over the heat we use: if we want to use more energy from the wood burner or our solar panels, we just adjust it accordingly. In fact, now we tend to only use the gas supply for

‘backup’, so we’ve definitely saved a lot of money on energy bills.”

In fact, the DPS Heatbank brought even more advantages than they’d hoped for. “For one thing,” Michael says, “our water pressure

is now so good we’ve dispensed with the pumps entirely, which is a huge benefit as they were just so noisy and quite unreliable. Unlike the DPS Heatbank, which comes with a twenty five year warranty on the store itself, so I have complete peace of mind. And now, when I take a shower, I know the water isn’t from a tank where it’s been stored for ages, but is arriving freshly heated from the mains supply.

The other benefit is that hard water isn’t a problem any more. When we removed the old pipes, they were almost completely furred up on the inside with limescale: in a one and a half inch pipe, only a quarter of an inch remained unblocked. It’s good to know that hard water won’t be a problem any more: the DPS Heatbank itself is a closed system so isn’t affected by limescale build up, and we had it fitted with a water softener so that all our pipes and appliances are protected too.”

It may seem like a renovating fairytale, but the project had its teething problems. Michael explains, “when we first decided to

overhaul our heating and hot water, we asked the company responsible for installing our wood burning stove to install a new system. Unfortunately, they installed completely the wrong type of tank in the wrong location with the wrong connections. Luckily, when we called in our plumber to try to undo some of the damage, he suggested we speak to industry experts DPS, who were excellent. It just showed us how important it is to have people who know what they are doing: it takes a lot of planning and experience to understand what’s needed for each particular situation. DPS have decades of experience and are relatively rare in that they understand all aspects of the systems, from the different energy sources to the electrics. They came out to oversee the installation of the DPS

Heatbank twice and were simply excellent.”

So, the question is, would he recommend DPS and the DPS

Heatbank? “Definitely,” he says, “I would recommend both DPS and

the DPS Heatbank without hesitation.” So, if you’re looking for a

multi-fuel, reliable heating and hot water system designed and manufactured by industry experts, it seems the DPS

Heatbank is one way to get your renovating happy ending!

DPS Commentary:

We were called in to have a look at Mr.Axlers property by

Nick Manual of Griffon House. Nick has described the job as

‘very interesting’ and he was not wrong. On our first site visit we were shown around the property, including two existing wood burners and a large solar array. One of the wood burners had been plumbed up dangerously using plastic fittings and no vent pipe, the solar system did not work, and in the basement boiler room we saw three types of storage unit from previous attempts to get the system working. In addition to this one of the existing gas boilers had blown apart due to a lack of expansion vessel and safety relief, and the pipework was a mess.

Mr. Axlers also wanted another multifuel stove and a 40kW gas boiler to be added into the system, along with simple controls that allowed summer/winter modes to be used, where the gas boiler can be brought into backup the wood burners and solar if demand so required.

We agreed on a suitable location for the new Heat Bank and went over the possible pipework layout with Nick, as well as how best to integrate the solar, wood and gas and ensure the entire system is protected against overheat (even during power cuts or with pump failures).

The system was quoted, ordered by the customer, and supplied to site within a week. The following week we attended a site meeting to finalise a few minor installation points, and go over the system with the customer.

PRODUCT DATA SHEET

British Standard

Foamed Copper

Cylinders

The full range of insulated copper hot water cylinders including all standard sizes, as well as custom models made to requirements.

Copper Grades 1, 2 or 3 (25m, 15m, 10m head)

Many models available in Stainless Steel.

Foam Insulation up to 80mm

Choice of Diameters and Heights

Choice of Coils for indirect heating.

Solar and Solid Fuel options.

Options for fitted immersion heaters.

Cased units available.

Additional bosses on request.

Options for fitted control assemblies.

The table below provides information on the standard sizes, as well as the standard specifications for coils and material thicknesses.

Special sizes and additional bosses on request.

Foamed Copper Cylinders

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 0

845 2411441 Fax. 01372 803678

23

www.heatweb.com email: [email protected]

PRODUCT DATA SHEET

Budget Mains Systems

Budget Mains Fed Thermal

Storage Systems

The low cost approach to providing mains pressure hot water, using standard insulated copper hot water cylinders in conjunction with the patented DPS Hi-Flow conversion unit.

Very Low Capital Costs

Full Mains Pressure Hot Water

Huge Range of Cylinder Sizes

Foam Insulation up to 80mm

Choice of Diameters and Heights

Choice of Coils for indirect heating.

Solar and Solid Fuel options.

Additional bosses on request.

Patented

DPS Hi-Flow Mains

Conversion Unit

+

British Standard Grade

3 Copper Cylinder

Within the Hi-Flow are all the components required to generate mains pressure hot water up to 9 bar. The Hi-Flow uses a Plate Heat Exchanger to transfer thermal energy from the stored water to heat mains water, and a pump to circulate water from the cylinder through the heat exchanger and back. A thermostatic mixing valve controls the temperature of hot water delivered to taps. The unit is 375mm x 375mm x 175mm and can be easily wall mounted.

The Hi-Flow can connect to any hot water cylinder, including low-cost British Standard cylinders, making it far easier to source the correct size store to fit into a given location.

The table to the right shows just some of the standard cylinder sizes available.

Installation also requires connection to a feed tank for initial filling of the cylinder, and to replace any evaporation losses. A standard 16 litre tank usually suffices.

Budget Foam Lagged Heat Banks

Alternatively, the budget range of

Heat Bank Systems provides our lowest cost, fully assembled mainsfed stores. Available in basic electric or indirect, as well as solar, solid-fuel options, with insulation to specified thickness.

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 0

845 2411441 Fax. 01372 803678

www.heatweb.com email: [email protected]

24

PRODUCT DATA SHEET

PHE Assemblies: Hi-Flow

DPS Hi-Flow Mains

Conversion Kit

Mains Pressure Hot Water Systems using vented storage for the high performance mains hot water via a plate heat exchanger (PHE). The simplest way to provide mains hot water from a standard vented cylinder. Easy to retro-fit, there is no annual servicing required, and the cost is a fraction of other mains systems.

Mains Pressure Hot Water up to 9 bar.

Suitable for DIY installation.

Connects to any type of hot water cylinder.

Easy to Install.

Instantaneous Hot Water.

No Annual Maintenance Requirements.

The Hi-Flow converts a cylinder into a thermal store, adding the benefits of mains pressure hot water while keeping the existing vented hot water storage. The existing cold water storage tank can be left in place to act as the feed and expansion for the cylinder, or can be replaced with a much smaller tank.

Plate Heat Exchanger

Technology:

Mains pressure hot water is heated through a plate heat exchanger that pulls heat from the stored hot water. The cylinder remains unpressurised, overcoming all safety and servicing demands that arise from a pressurised store.

Greater Flexibility on Sizing:

The ability to convert any cylinder to provide mains hot water opens up possibilities where space is a problem. Unvented cylinders and other mains water systems usually come in standard sizes, which may not be the best suited to a particular application. Instead one can use a British Standard Copper

Cylinder, easily made in one-offs to specified diameter and height, and connect a Hi-Flow remotely.

When there is a real squeeze on space, the Hi-Flow can connect to a rectangular tank made to fit exactly into a specified void.

Existing System Conversion:

The diagram opposite shows how the

Hi-Flow can be added to an existing system with minimal pipework alterations. The cylinder itself does not need to be touched. The cold feed and hot draw off are cut into and taken to the Hi-Flow. The cold feed connection from the cold tank is fed back into the vent to create a combined feed and vent. The cold mains is connected to the Hi-Flow, and the hot mains out to the existing hot feed to taps.

STANDARD SPECIFICATIONS

DHW Plate Heat Exchanger

Thermostatic DHW Mixer

Width

Height

Depth

Dedicated Pressure Systems Ltd.

100 kW

22mm

350mm

375mm

175mm

25

www.heatweb.com

PRODUCT DATA SHEET

PHE Assemblies: BoilerMaster

BoilerMaster PHE Heat

Exchanger Systems

Designed to run in conjunction with central boiler applications, the BoilerMaster range uses plate heat exchanger technology to provide instantaneous mains pressure hot water with central heating options.

Mains Pressure Hot Water up to 9 bar.

Instantaneous Hot Water.

No Hot Water Storage.

Suitable for DIY installation.

No Discharge Requirements for Hot Water.

Takes up less room than other systems.

Standard and Custom Built Models

Fit and Forget Design.

No Annual Maintenance Requirements.

Options for Sealed Central Heating.

All mechanical models available (no power).

Options for Energy Metering.

Options for C-Bus Communication.

Unlimited Options:

In its basic form, the BoilerMaster is fitted with a motorised valve that opens when a hot taps is started. This allows hot primary water to flow through the heat exchanger, in turn heating up the mains water which is mixed to a preset temperature. The additional options can provide for any combination of control valves a system designer specifies, along with any controls and metering that is needed.

Complete Systems:

Both hot water and central heating can be provided from a single pre-fabricated unit, ready for rapid installation.

Consultancy:

DPS has a great deal of experience with a wide variety of systems and we provide free consultancy to all our customers.

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 01372 803 643 / 675 Fax. 01372 803678

STANDARD OPTIONS

DHW Plate Heat Exchanger

Central Heating Heat Exchanger

Thermostatic DHW Mixer

Primary Motorised Valves (HW/HTG)

Thermo-mechanical Primary Valves

Modulating 0-10v Primary Valves

Primary Differential Pressure Control

Primary Shunt Pump

Heating Pump

Modulating Heating Pump

Sealed System Kit on Central Heating

Underfloor Heating Valve

Modulating 0-10v UFH Valve for weather compensation

Programmer

Programmable Room Thermostat

RF Radio Communication with Room

Thermostat(s)

Heat Metering

C-BUS Communication and Control

100, 160 kW

10, 18 kW

22, 28mm

22, 28mm

22, 28mm

22, 28mm

15-60

15-60

Alpha, UPE

22, 28mm

22, 28mm

One, Two Channel

TP5000, TP7000

1, 2, 3 Zone

www.heatweb.com email: [email protected]

26

PRODUCT DATA SHEET

Communal 17931

Communal Heating System (17931) for 6-10 Flats

A turn-key solution to the provision of domestic hot water and central heating in communal properties. Modular design using domestic boilers and storage, combined with commercial controls and monitoring facilities, makes this a very robust and cost effective solution.

Benefits to User:

Central heating

Instantaneous mains pressure hot water up to 6 bar, 30 lpm

No gas appliances or pressurised cylinders to maintain

Benefits to Landlord:

Off-site reading of individual energy usage for billing

Off-site monitoring and control of all plant

Automatic forwarding of alarms (e.g. to a mobile)

Software required for monitoring provided FREE

NO license fees or ongoing charges

Features of Plant:

Redundancy on Boiler, Pumps, and Storage

Twin 37kW Condensing Boilers (74kW peak)

Boiler sequence controller

Twin 300 litre Buffer Stores (600 litres total)

Duplex (Duty/Standby) Modulating Primary Pump

Up to 230 lpm (14m3/h) primary circulation

Automatic pump changeover

Low system pressure alarm

All controls C-BUS linked to central modem.

Modular and easy to upgrade.

DPS BoilerMaster

Plate Heat Exchange Technology:

Mains pressure hot water is heated locally within each flat through a plate heat exchanger at up to 30 litres per minute, and 6 bar pressure, without

Legionella risks. Also provides central heating control and metering of energy used for billing purposes.

Dedicated Pressure Systems Ltd.

PRODUCT DATA SHEET

27

www.heatweb.com

Communal 17931

PRODUCT DATA SHEET

Communal 17931

2 x Vaillant 37kW

EcoTEC Plus Condensing

System Boilers:

Together providing up to 74kW of energy input, the boilers have been selected for efficiency, quality, and after sales backup.

2 x Stainless Steel

Buffer Stores:

As standard providing 600 litres of primary storage.

Selection of sizes available to match space available. Options for electric backup and input from renewable sources.

Grundfos Duplex

Magna 32-100

Variable Speed Pump:

Provides duty / standby operation that adjusts output to match demand. The pumps.

Each head can supply up to

200 lpm at a head of 0.7 bar.

6 x BoilerMaster

District Interface Units:

Provides 100kW mains pressure hot water within flats, as well as central heating control, and primary metering.

Connects on C-BUS to plant room.

< Pump Graph and

BoilerMaster

Schematic >

Boiler Sequence

Controller:

Manages the firing of the two boilers to match demand. Also includes timing function, as well as boiler lockout alarm, and control over set point temperatures.

Temperature Module:

Provides access to information from four temperature sensors, for boiler flow temperatures, as well as distributed primary flow and return temperatures.

Pump Changeover

Module:

Provides duty / standby control over pump, with pump overload alarm.

Automatically alternates the operation of pumps.

Energy Meter Module:

Fitted within each

BoilerMaster the unit stores the energy used by each flat for billing purposes. Also records two auxiliary inputs for gas, electricity or water.

Modem Module:

Connects all the C-BUS modules to a telephone line to allow off-site monitoring and control, as well as access to billing information. GSM modem optional.

The software required to access the Coster modules remotely is provided free of charge, as is technical backup. Combined with the huge range of other modules available, you can be confident in connecting all possible plant equipment to the same remotely managed system, without hidden operating costs.

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 0

845 2411441 Fax. 01372 803678

www.heatweb.com email: [email protected]

28

PRODUCT DATA SHEET

Solar Electric Xcel

Heat Bank Pack

Solar Electric Heat Bank Pack

An Advanced Heat Bank thermal store, capable of providing electric central heating and mains pressure hot water, complete with solar panels, header tank, and all controls factory fitted and wired to store. Just add pipework for a totally renewable, maintenance free solution.

Mains Pressure Hot Water up to 9 bar.

Fully Vented System.

Solar and Electric Ready.

Options for Solid Fuel and Heat Pumps.

Fully Pre-Fabricated for quick reliable installation.

No Annual Maintenance Requirements.

Glycol Free, Maintenance Free, Solar Operation.

The Full Kit:

The Solar Panels included in the pack have been carefully selected for the best balance of performance, reliability, appearance and price.

The Feed and Expansion Tank is fully assembled and insulated, further saving installation time.

Open Vented for connection to Feed and

Expansion Tank for automatic maintenance-free filling of both store, heating system and solar panels.

Solar Controller provides the necessary control of the solar pump to transfer heat from panels to the store. Various models available.

Spare connections (flow and return) for feeding a radiator circuit, towel rail circuit, or a heat dump for solar excess input.

Central heating controls can be supplied, with options from standard mechanical room thermostats up to full RF radio multi-zone control of UFH.

The system is designed to run hot water and heating using only electricity. To make simple connection to virtually any supply arrangement or tariff, the unit may be fitted with a 15kW Immersion

Controller, pre-wired to elements and providing both economy and boost control.

All central heating and hot water controls run from a separately fused 3A mains supply, and are pre-wired to a fitted wiring centre.

The unit is fitted with a combination of

3kW and 6kW heating elements to meet the required power input.

Immersion Heaters are controlled using cylinder thermostats that allow users to adjust the storage temperature in the top and bottom half of the store separately.

Plate heat exchanger provides mains pressure hot water up to 9bar and 40 litres per minute, without any service requirements.

Hot water temperature is controlled using a standard Heatguard Thermostatic Mixing

Valve, for reliable operation, and easy to service.

The solar pump is fitted and wired to the solar controller. A standard 5m pump is fitted as standard, with options for a low voltage DC pump that can be driven directly from a PV solar panel.

Solar and Electric systems run particularly well with underfloor heating, and it is an option for the store to come with a standard underfloor control set providing a low temperature pumped flow that can be fed to one or more basic manifolds.

Heating elements in the lower half of the store can be timed or switched separately to those in the upper half.

Where electricity is used to drive heating it is often desired to connect a heat pump to reduce running costs, and connections are provided for this.

Dedicated Pressure Systems Ltd.

PRODUCT DATA SHEET

29

www.heatweb.com

Solar Electric Heat Bank Pack

PRODUCT DATA SHEET

Plate Heat Exchanger

Technology:

Mains pressure hot water is heated through a plate heat exchanger that pulls heat from the stored hot water.

The Solar-PHE itself is unpressurised, overcoming all safety and servicing demands that arise from a pressurised store.

Solar Electric Heat Bank Pack

System Integration:

Although it sounds complicated, combining multiple heat sources with multiple heat loads, the use of a thermal store simplifies everything considerably. The single feed and expansion tank is used to feed all the circuits, removing the need for any separate filling loops, pressure relief, or expansion vessels. Everything automatically fills, and there is only one discharge (from the feed tank), making the system more user friendly and removing the possibility of panels running dry.

This approach is also more efficient, without the need for a solar coil or heat exchanger, allowing a large number of panels to be connected without causing problems. Overheat protection can be provided by either stopping the solar pump, or dumping heat to radiators or the underfloor heating. Frost protection can be provided by either the solar controller (starting the pump) or by allowing gravity circulation back to the panel during freezing conditions.

Solar Options:

The alternative options for solar include the use of a PV pump for direct connections to an PV electric solar panel, that allows solar to operate power-free. Units can also be supplied with a coil and pressurised solar circuit for glycol systems.

Wood Burner

STANDARD OPTIONS

DHW Heat Exchanger 160 kW

Connection:

Solar Assembly Direct Fed

Connection to wood burners, or similar, is made directly to the

Thermostatic DHW Mixer

Solid Fuel Connections 28mm

Twin Heating Circuits

Immersion Heater

22mm

22mm

(4x3kW) 12 kW store in larger diameter 28mm fittings. The store is typically positioned higher than the wood burner so that the heat rises into the store under thermo-syphon (gravity) action, without the need for further controls.

ADDITIONAL OPTIONS

Immersion Heaters

Immersion Heater Controller

12kW to 24kW

15kW, 30kW

Thermostatic DHW Mixer

Temperature Gauge

28mm

STANDARD SIZES (COPPER)

Solar Coil, and Sealed System Controls

PV Solar Pump

CAPACITY

210 ltr

DIAMETER

530mm

HEIGHT

1600mm

Secondary Return Pump 15-14, 15-50

250 ltr 530mm 1850mm

Heating Pump Grundfos

Modulating Heating Pump

15-60, 25-55, 25-80

250 ltr

250 ltr

530mm

530mm

1600mm

1350mm

Underfloor Heating Valve

Programmer

22, 28mm

One, Two Channel

300 ltr

300 ltr

580mm

680mm

1850mm

1500mm

Programmable Room Thermostat

RF Radio Communication with

Room Thermostat(s)

Overheat Thermostatic Switch (wired to heating)

TP5000, TP7000

1, 2, 3 Zone

330 ltr

350 ltr

400 ltr

450 ltr

580mm

680mm

680mm

680mm

2000mm

1700mm

1850mm

2000mm

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 01372 803 643 / 675 Fax. 01372 803678

www.heatweb.com

email: [email protected]

30

PRODUCT DATA SHEET

Amazon Tempest

Unvented Cylinders

Amazon Unvented

High Pressure Hot Water Systems using pressurised unvented storage for high performance mains hot water. Stainless steel, with a lifetime guarantee, the Amazon range sticks to standard unvented principals, using an expansion vessel

(supplied) instead of internal bubbles. Units come with the full unvented control packs required for installation.

Mains Fed Hot Water up to 3 bar.

Duplex 2304 Stainless Construction.

Indirect and Electric models.

15 bar Test Pressure.

Up to 55 litres/minute of flow.

Cased with Highly Efficient Insulation

Choice of Diameters and Heights.

All Unvented Controls Supplied.

Solar options.

Options for fitted control assemblies.

High Quality Construction:

All of our Amazon unvented cylinders are now manufactured using 2304 Duplex Stainless Steel.

Tempest units are finished using a wipe-clean, white-coated steel case. Continuing our philosophy of using only the finest materials, the heat loss from the cylinder is minimal, making it extremely economical to run. We are so confident of the construction that we have given all of our stainless cylinders a life-time guarantee to give each customer total peace of mind.

Reheat Times:

Heat-up and re-heat times assume a cold water temperature of 15°C If using a twin coil variant, where the second coil is linked to a solar energy recovery application, the recovery times listed will improve significantly. Depending on the energy input, the recovery times could be halved.

INDIRECT REHEAT TIMES (minutes)

90 125 150 170 200 250

300

Capacity

Reheat after

70% Drawn

Reheat from

Cold to 65°C

18

26

25

36

26

37

25

36

24

33

25

35

29

40

DIRECT REHEAT TIMES (minutes)

Capacity

Reheat after

70% Drawn

Reheat from

Cold to 65°C

90

27

52

125

37

72

150 170 200 250

45

86

51

98

63

108

75

144

300

136

202

Dedicated Pressure Systems Ltd.

31

STANDARD SPECIFICATIONS

Cylinder Body Material

Outer Casing

Insulation

Immersion Heaters

Cold Inlet / Hot Outlet

Primary Coil Flow and Return

Temperature and Pressure Relief

Inlet Group

Tundish Outlet

Test Pressure

Working Pressure

Temperature Pressure Relief

Maximum Flow

Expansion Provision

Duplex 2304

Stainless Steel

Plastic Coated Mild

Steel, Wipe Clean

Polyurethene

CHC+HCFC Free

Low Noise Incaloy

22mm

22mm

1/2"

22mm

22mm

15 bar

3 bar

7 bar, 95°C

55 ltr/min

External Vessel

www.heatweb.com

PRODUCT DATA SHEET

Amazon Unvented

Material :

Until recently, Duplex 2304 was reserved only for use in chemical plants and refineries due to its corrosion resistant technology. The corrosion resistant properties of Duplex are greater than those offered by other grades of stainless steel used in today's water tanks. These properties are carried forward to our stainless cylinders to ensure total peace of mind for the end customer. Tempest cylinders also undertake the extra process of "pickling" every stainless cylinder before casing. This removes any impurities, which can appear during the welding process. As a result, the cylinder becomes resistant to all forms of corrosion, including pitting and crevice corrosion. Another feature of stainless steel cylinders is that no anode is required, unlike mild steel variants. The benefit is the removal of worry and expense of having the anode replaced on a regular basis. Mild steel cylinders which do not have the anode replaced, are susceptible to early corrosion failure! Duplex steel is totally recyclable. As much as 90% of the post-service life steel is converted into prime stainless products.

Whichever way you look at it, Duplex 2304 is superior.

Twin Coil Solar Option:

Environmental issues are currently at the forefront of peoples thoughts.

Developers are now looking at solar energy as a compliment to gas or oil powered boilers. Solar not only benefits the environment by reducing the amount of natural resources we consume, but also makes the heating of a building far more efficient and helps to lower utility bills. Our twin coil stainless cylinder is available in all sizes throughout the Tempest range and includes all necessary safety controls.

Rapid Indirect Recovery Options:

Instead of using a coil to allow connection to a boiler, the Pandora can be supplied with a plate heat exchanger (PHE) to reheat the store using everything the boiler can provide. This reduces heat up times dramatically, and reduces the size of store required.

STANDARD SIZES (INDIRECT)

Capacity

Height ø A

90 750

B C D

510 170 200 400 495

E

-

F

550

125

150

170

200

250

300

950

1075

1225

1175

1375

1650

510 170 200 400 495

510 170 200 400 495

-

-

750

880

510 170 200 450 600 1030

554 195 225 475 625 815 930

554 195 225 555 845 975 1140

554 195 225 555 845 1255 1435

400 1590 660 240 270 640 870 1240 1340

500 1835 660 240 270 640 890 1390 1590

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 01372 803 643 / 675 Fax. 01372 803678

32

STANDARD SIZES (DIRECT)

Capacity

Height

90 750

ø A B C

510 170 200 400

125

150

950

1075

510

510

170

170

200

200

400

400

170

200

250

300

400

500

1225

1175

1375

1650

1590

1835

510 170 200 400

D

-

-

-

-

E

550

750

880

1030

554 195 225 400 815 930

554 195 225 400 975 1140

554 195 225 500 1255 1435

660 240 270 500 1240 1340

660 240 270 500 1390 1590

www.heatweb.com email: [email protected]

PRODUCT DATA SHEET

A.O.Smith Commercial

Unvented Cylinders

Commercial Unvented

High Pressure Hot Water Systems using pressurised unvented storage for very high performance mains or pump fed hot water. The A.O.Smith range of commercial storage vessels ranges from 300 to 3000 litres, and it suitable for virtually any application from unvented mains storage to buffering large boiler / heating systems.

Mains Fed Hot Water up to 10 bar.

Coated Steel Construction.

PermaGlas® Ultra Coat™ second-generation glass coating.

Direct, Indirect and Twin Coil models.

Electric Elements from 3 to 36kW.

10 bar Working Pressure.

Up to 3" Inlet / Outlet Connections.

Highly Efficient Removable Insulation Casing

Single-wall spiral heat exchanger

Insulated access cover for comprehensive maintenance

Replaceable magnesium anode (option for powered)

3 Year Warrantee.

Range of Application:

The A.O.Smith storage comes in three types, Direct, Indirect and Twin Coil, with options for External Heat

Exchangers allowing for a combination of up to four heat sources (including electrical). They can be used with domestic mains water, or with boiler primary water up to very high pressures, and with sizes up to 3000 litres make this range the first choice for most commercial applications.

Dedicated Pressure Systems Ltd.

PHE Recovery:

To generate higher quantities of hot water, units can be supplied with plate heat exchanger recovery sets up to 320kW, equivalent to another 6000 litres per hour of hot water. Resulting store sizes are much smaller than otherwise possible. This option also provides the ability to heat up specific quantities, which can be very useful when an economy mode is required, or there are is a variable source such as solar also employed.

Intelligent Controls:

Further options include the fitting of Coster C-BUS linked controls enabling remote control over storage temperatures and timing, and even automatic communication of alarms via modem. Any number of systems can be linked using the 2-wire system, and unlike most systems the computer software and backup is provided completely free of charge for any number of sites.

33

www.heatweb.com

PRODUCT DATA SHEET

Commercial Unvented

TECHNICAL SPECIFICATIONS

Capacity

Output coil

Surface area coil l kW m2

Water capacity coil

Flow rate coil (80-60°C)

Pressure drop coil

Max pressure tank

Max pressure coil

Maximum temp tank

Maximum temp coil

Standby loss

Anodes

Maximum weight l l/h mbar bar bar

°C

°C kWh/24h

kg

Draw-off capacity

Storage capacity

30 min. dT=44°C

60 min. dT=44°C

90 min. dT=44°C

120 min. dT=44°C l l l l l

Continuous dT=44°C l/h

Heating-up time dT=55°C min.

Weight empty kg

Weight incl. packaging

Width packaging

Height packaging

Depth packaging kg mm mm mm

300

46

1.47

8.9

1978

110

1.32

1

413

58

10

16

95

400

78

2.45

14.8

3345

244

10

16

95

110

1.6

1

524

500

100

3.11

18.8

4300

489

10

16

95

110

1.88

1

653

600

104

3.45

29.3

4472

104

10

16

95

110

1.85

1

884

750

112

3.72

31.6

4816

128

10

16

95

110

2.03

1

979

1000

145

4.82

40.9

6235

259

10

16

95

110

2.19

1

1343

1500

136

5.2

43.8

5848

688

7

7

95

99

9.2

3

1938

2000

136

5.2

43.8

5848

688

7

7

95

99

10.9

3

2568

2500

145

5.5

46.4

6235

583

7

7

95

99

12.3

3

3202

3000

145

5.5

46.4

6235

583

7

7

95

99

14

3

3797

296

728

1177

1627

2076

899

20

117

128

780

1510

780

385

1106

1868

2631

3393

1525

15

139

150

780

1850

780

473

1396

2373

3350

4327

1955

15

180

191

780

2150

780

643

1616

2633

3649

4665

2033

19

241

252

870

1930

870

725

1776

2871

3965

5060

2189

20

254

265

870

2150

870

1007

2374

3791

5208

6625

2834

21

336

348

1010

2100

1010

1500

2834

4165

5496

6827

2661

34

438

458

1200

2100

1655

2000

3999

5330

6661

7992

2661

45

568

588

1200

2300

1655

2500

4004

5424

6843

8262

2837

53

702

735

1500

2160

1980

STANDARD SIZES (INDIRECT 300 to 1000 litre)

R

S

O

P

G

H

M

N

A

D

Capacity

A

300 400

1370 1705

1370 1705

720 720

500

2040

2040

720

325

765

255

1010

255

1205

75 70 70

1310 1650 1990

115

325

595

375

115

330

115

330

500 500

1095 1290

600

1835

1835

910

750

2030

2030

910

305

1145

305

1205

85 85

1795 1990

180

415

180

415

180

445

650 650 700

1235 1295 1395

1000

2000

2000

1060

345

1305

95

1960

1

2

T

U

3

4

Cold water

Cold water

-

1115

1"

1"

Inlet coil

Outlet coil

1"

1"

1360 1700

-

2"

2"

2"

2"

1"

1"

1"

1"

1475 1670 1600

-

3"

3"

3"

3"

3"

3"

1.1/4" 1.1/4" 1.1/4"

1.1/4" 1.1/4" 1.1/4"

7

8

Connection 3/4"

Anode -

3/4" 3/4" 3/4" 3/4" 3/4"

1.1/4" 1.1/4" 1.1/4" 1.1/4" 1.1/4"

10 Anode 1" -

Sizes for 1500 to 3000 litres on request.

3000

4550

5969

7388

8807

2837

63

797

840

1500

2300

1980

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 01372 803 643 / 675 Fax. 01372 803678

www.heatweb.com email: [email protected]

34

PRODUCT DATA SHEET

Unvented Cylinders with

Plate Heat Exchanger

Recovery

Unvented PHE

It is possible to considerably increase the output of an unvented hot water cylinder by using a plate heat exchanger in place of a coil for recovery by a boiler. It becomes possible to run a shower continuously without using up stored hot water, resulting in smaller cylinder sizes.

Cuts reheat times to less than half otherwise possible.

Use the full boiler output to reheat water.

Hot water within one minute from cold start.

Vary volume of store heated by boiler.

Combination mode with constant output.

Smaller cylinder sizes.

Models from 60 to 320kW.

Plate Heat Exchange:

The heat exchanger consists of thirty or more stainless steel plates, with a huge surface area for heat transfer.

The reheat time of a typical unvented cylinder is 25 minutes, and once the cylinder has been emptied of hot water you have to wait another 20 minutes to get further hot water. The main problem is the way the stores are heated, using a coil through which the boiler water is pumped. Coils usually only transfer a third of the boilers maximum output, and oversizing a boiler will not speed up reheat times. Coils also put the energy into the bottom half of the stored water, and this is no good when we want hot water instantly.

Using a plate heat exchanger allows the full boiler output to be used, cutting reheat times down to only 9 minutes to recover from a bath. The water heated through the plate heat exchanger is fed into the top of the store, where it can be used immediately. This allows showers to be run when the cylinder is cold, and also to choose how much of the store should be heated - it is very easy to select between heating up a sink of hot water, a shower, a bath, or the entire cylinder, just by selecting the time the boiler heats the cylinder.

LITRE PER HOUR

Commercial

Range:

For sizes up to 3000 litres, with control option including remote monitoring and control.

See separate Data

Sheet.

Type of store

Standard Indirect

Unvented

PHE Unvented

Capacity

125 ltr

200 ltr

300 ltr

125 ltr

200 ltr

300 ltr

500 ltr

Heat Exchange

Capacity

12kW

20kW

26kW

40kW

40kW

40kW

140kW

Litres in First

Hour

15-65°C

335

560

750

805

880

980

2900

Litres per

Hour

15-65°C

210

360

450

680

680

680

2400

5485

500 ltr 320kW 5985

It can be seen than a 125 litre unvented using plate recovery from a 40kW boiler will outperform a 300 litre standard unvented connected to the same boiler.

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 0

845 2411441 Fax. 01372 803678

www.heatweb.com email: [email protected]

35

PRODUCT DATA SHEET

DHW Hot Out

P&T Relief

Unvented PHE

Single Cylinder Setup:

This photograph shows a typical basic single store setup, with fitted plate heat exchanger and circulating pump. The unit shown is not fitted with temperature control and is for use with low temperature heat sources such as Heat Pumps .

Stat Position

Boiler Flow

Plate Heat Exchanger

Boiler Return

Bronze

Pump

Cold Mains In

Twin Cylinder Setup:

This photograph shows a typical twin store setup, with fitted plate heat exchanger, circulating pump, temperature control valve, and flow regulators for balancing flow to each store. 28mm cold feed connections ensure that some very high output flow rates can be achieved, and the system is suitable for feeding up to 6 bathroom simultaneously.

P&T Relief

Flow to Coil

Cold Mains In

DHW Hot Out

Return from

Coil

DHW Hot Out

Flow

Meter

Flow

Meter

Secondary Return

Flow to Coil

Boiler Flow

Plate Heat Exchanger

Stat Position

Bronze

Pump

Return from

Coil

RAVK Valve

Immersion Heater

36

PRODUCT DATA SHEET

Home Booster Pump

UPA 15-90

The UPA Home Booster is the quietest potable water booster pump we know of. It is silent running, and capable of turning a poor low flow shower into a power shower, or increasing flow to taps.

Increases pressure and flow to outlets.

Silent running.

Suitable for DIY installation.

Possible for use on direct mains with permission.

No Annual Maintenance Requirements.

Home Booster Pump

The UPA is capable of adding 0.6 bar (6m head) of pressure under flow, with flow up to 24 l/min. It has a built in flow switch that detects the start of flow and turns the pump on. The pump will then shut off once the outlet shuts and flow stops. It can be used for boosting the flow from a tank fed hot water cylinder, or with permission from local water authority can be used to boost the mains flow through a combination boiler. The pump is approved for use on potable water supplies.

Simple Installation:

The UPA can easily be cut into existing supply pipework, and comes with two pipework adapters and a 1.5m power cable.

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 01372 803 643 / 675 Fax. 01372 803678

SPECIFICATIONS

Pump Casing

Motor Protection

Connection Size

Port to Port Length

Voltage

Current

Weight

Enclosure Class

Length of Lead

Minimum liquid temperature

Maximum liquid temperature

Maximum operating pressure

Minimum inlet pressure

Method of Control

Cast Iron, Coated

Impedance Protected

3/4"

160mm

230V @ 50Hz

0.48 A

2.7 Kg

IP42

1.5m

2°C

70°C

6 bar

0.2 bar

Internal Flow Switch

www.heatweb.com email: [email protected]

37

PRODUCT DATA SHEET

MXSU Pump

MXSU Stainless Steel

Low Noise Pumps

The Calpeda MXSU Pump provides high pressure and flow, with significantly lower noise levels than comparable pumps. The pump chrome-nickel stainless steel, with motor shields in brass, and the motor is encased within the water flow, which assists cooling and absorbs sound.

The pump has a small footprint, and comes with a prewired wall switch for easier installation.

Pressures up to 6 bar.

Flow rates up to 180 lpm from a single pump.

Low Noise.

Small Footprint or 190mm x 150mm.

Submergible.

The pumps are typically used in conjunction with a pressure switch, non-return valve, and expansion vessel, to control the pump and buffer its operation. All these are available as accessories, or the pump can be supplied in a fully pre-fabricated pump-set (see separate data sheet).

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel.

0845 2411441 Fax. 01372 803678

SPECIFICATIONS

Pump Casing and Shaft

Motor Shield

Connection Size

Voltage

Current

Weight

Enclosure Class

Length of Lead

Minimum liquid temperature

Maximum liquid temperature

Maximum operating pressure

Minimum inlet pressure

Method of Control

38

Chrome-nickel Steel

Brass

1.1/4"

230VAC Single Phase

400VAC Three Phase

3.5 to 7 A (on model)

11 to 14.8 Kg

IP68

2m

2°C

35°C

10 bar

0.2 bar

External Switching

www.heatweb.com email: [email protected]

PRODUCT DATA SHEET

Pump Sets

Pump Sets for

Cold Water Boosting

The Calpeda range of Pumps and Pump Sets provides a truly comprehensive range of options for cold water pressure and flow boosting. From low cost single pump sets up to multiple pump set assemblies for heavy commercial loading, we can supply the right equipment for the job, tailored to meet the customers precise needs.

Pressures to suit.

Flow rates to suit.

Single, Twin and Multiple pump set options.

Fully assembled and wired.

Fixed speed and variable speed pump options.

BMS options.

As with all DPS products, the range is backed up by our free design and consultancy service.

Simply let us know what you are trying to achieve and we will provide designs and pricing for suitable equipment, and talk you through any options that may apply.

The choice of pump controls ranges from basic fixed speed on/off control using pressure switches, through to full changeover control of multiple pumps using either duty/assist or duty/standby control. To add to this we can tie the sets into our range of commercial plant controls that will allow off-site monitoring of equipment using a modem link with all software provided free of charge. We can even get sets to phone up a service engineer when a problem occurs, without the need for additional on or off-site equipment.

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 01372 803 643 / 675 Fax. 01372 803678

www.heatweb.com email: [email protected]

39

PRODUCT DATA SHEET

Pump Accessories

A selection of fittings and controls that are typically required with a pump booster set.

CHECK VALVES

VNR 1

VNR 1 1/4

VNR 1 1/2

VNR 2

FOOT VALVES

VDF 1

VDF 1 1/4

VDF 1 1/2

VDF 2

CONNECTOR

RA5 H 92

RA5 H 105

1"

1"

SPHERICAL VESSEL

Type

SS 24

Conn'

1"

Capacity

24 ltr

BUTYL Rubber Diaphragm

INOX VESSEL

Type Conn' Capacity

SCX 24 1" 20 ltr

BUTYL Rubber Diaphragm

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 01372 803 643 / 675 Fax. 01372 803678

Pump Accessories

See Also:

MXSU Pumps

MXH Pumps

Accumulators

Cold Storage Tanks

PRESSURE GAUGES

Axial Connection Types:

MA 0-6

MA 0-6 ABS

Radial Connection Type:

MR 0-10

MR 0-12

MR 0-16

PRESSURE SWITCHES

Type

FSG 2

Standard

Setting

1.4 bar

2.8 bar

Max

Pressure

4.5 bar

FSG 22

FSG 32

5.4 bar

7 bar

8 bar

10.5 bar

7 bar

10.5 bar

CYLINDRICAL VESSEL

Type Conn' Capacity

SC 20 BP 1" 20 ltr

BUTYL Rubber Diaphragm

INOX VESSEL

Type Conn' Capacity

SCX 20 BP 1" 20 ltr

BUTYL Rubber Diaphragm

www.heatweb.com email: [email protected]

40

PRODUCT DATA SHEET

Accumulator

Pressure Vessels

Accumulator Vessels

Accumulators are used to store water under pressure and to take up expansion or contraction within hot water systems. They are charged with water from either the mains or from a pump system, and are capable of delivering extremely high flow rates until empty.

Overcomes loss of pressure when second outlet opens.

Overcomes poor flow resulting from small mains supply.

Suitable for DIY installation.

Connects anywhere into cold mains pipework.

No Annual Maintenance Requirements.

Membrane can be replaced on site.

Ideal for unvented systems.

Smoothes operation of pumped systems

Suitable for hard water.

Where a property is supplied via a small bore or long mains supply pipe the loss of pressure within these pipes reduces the amount of water that can be supplied to taps, even if the mains pressure is high to start with. The vessel will charge up to the local static mains pressure, compressing the air pre-charge until it reaches the same pressure. When taps are opened the vessel can make up the extra flow required that the mains can't supply. This is particularly useful where showers are affected by second outlets.

Vessels should be sized to meet the maximum short term demand to taps. The actual volume of water stored is lower than the vessel size as the air is never totally squashed. The air pre-charge pressure should be set to 0.8 times the supply pressure with one outlet running.

When used with pump systems, the large the accumulator used with a pump, the less often the pump will need to be on to match demand, and allows large pumps to be used with variable demand and flow rates lower than the pump should run at.

For accurate sizing please contact DPS technical department.

STANDARD SIZES

CAPACITY

40 ltr Vertical

60 ltr Vertical

60 ltr

80 ltr Vertical

80 ltr

100 ltr Vertical

100 ltr

200 ltr Vertical

300 ltr Vertical

500 ltr Vertical

700 ltr Vertical

1000 ltr Vertical

DIAMETER

320mm

380mm

380mm

450mm

450mm

450mm

450mm

550mm

630mm

780mm

780mm

930mm

HEIGHT / LENGTH

610mm

850mm

850mm

870mm

870mm

965mm

965mm

1235mm

1400mm

1550mm

1950mm

1950mm

TECHNICAL SPECIFICATIONS

Maximum Pressure

Body Material

Flange Material

Bladder Material

8 bar (40 to 80 ltr)

10 bar

(100 to 1000 ltr)

Epoxy coated carbon steel

Stainless steel

Butyle rubber

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 01372 803 643 / 675 Fax. 01372 803678

www.heatweb.com email: [email protected]

41

PRODUCT DATA SHEET

Pump Accessories

Polyethylene Cold Water Tanks

Polyethylene cold tanks are supplied with:

Snap-on Lid.

Bylaw 30 Kit and fitting instructions.

1/2" BS1212 Part 2 Ball Valve and 4.5" Float

Ball Valve Back Plate

22mm Compression Tank Connector

15mm x 1/2" Angled Service Valve

Insulation and Ties

STANDARD RECTANGULAR TANKS

Capacity

55 Litre / 12 Gallon

55 Litre / 12 Gallon

Inch Size

20-12-20

24-16-15

55 Litre / 12 Gallon

68 Litre / 15 Gallon

68 Litre / 15 Gallon

68 Litre / 15 Gallon

68 Litre / 15 Gallon

82 Litre / 18 Gallon

82 Litre / 18 Gallon

20-15-18

18-18-18

24-12-20

24-15-18

24-17-17

24-12-24

24-18-19

91 Litre / 20 Gallon

91 Litre / 20 Gallon

114 Litre / 25 Gallon

114 Litre / 25 Gallon

136 Litre / 30 Gallon

136 Litre / 30 Gallon

159 Litre / 35 Gallon

159 Litre / 35 Gallon

20-20-20

24-15-24

27-20-20

55-20-12

24-24-24

39-20-17

29-22-22

30-24-23

190 Litre / 42 Gallon

190 Litre / 42 Gallon

227 Litre / 50 Gallon

227 Litre / 50 Gallon

227 Litre / 50 Gallon

318 Litre / 70 Gallon

454 Litre / 100 Gallon

39-20-21

46-19-19

46-24-19

36-24-23

64-18-19

64-24-19

64-26-23

Length

510mm

610mm

510mm

470mm

615mm

610mm

610mm

615mm

615mm

515mm

615mm

690mm

1390mm

610mm

1000mm

750mm

750mm

1020mm

1185mm

1190mm

925mm

1650mm

1615mm

1670mm

FRAMED TANKS

Capacity

182 Litre / 40 Gallon

227 Litre / 50 Gallon

204 Litre / 45 Gallon with 18 ltr F&E Tank

Inch Size

23-23-28

23-23-35

23-23-34

Width

590mm

590mm

590mm

STANDARD FEED AND EXPANSION TANKS

Capacity

18 Litre / 4 Gallon

Inch Size

20-12-20

Width

480mm

PRE-INSULATED FEED AND EXPANSION TANK

18 Litre / 4 Gallon 24-16-15

540mm

Width

300mm

410mm

390mm

470mm

305mm

385mm

435mm

310mm

460mm

515mm

380mm

515mm

500mm

590mm

500mm

570mm

570mm

500mm

503mm

610mm

600mm

460mm

610mm

690mm

Depth

590mm

590mm

590mm

Depth

320mm

320mm

Dedicated Pressure Systems Ltd.

17 Manor Green Road, Epsom, Surrey KT19 8RA

Tel. 01372 803 643 / 675 Fax. 01372 803678

42

Height

525mm

460mm

460mm

475mm

550mm

460mm

440mm

615mm

480mm

530mm

590mm

520mm

310mm

590mm

440mm

570mm

570mm

550mm

503mm

500mm

570mm

475mm

500mm

580mm

Height

711mm

893mm

870mm

Height

250mm

350mm

www.heatweb.com

email: [email protected]

An Encyclopedia of Hot Water and Central Heating

Heat Loss

Calculators

Cylinder Size

Calculator

Unit Converter

Communal Designer

System Builder

Schematic Building

For many years DPS has been supplying systems for local authorities, house builders, plumbers and the public. Our exhaustive product range, our ability to easily provide on-site consultancy and specials, and our track record with regard to reliability and service backup have ensured increasing use of our systems. To continue in our tradition of providing comprehensive technical design support, we are launching our third CD-ROM, packed with everything a designer or specifier could hope for.

Not only does the CD contain full product range information, it is also packed with software design tools for everything from heat loss calculations to generating schematics and wiring diagrams, all fully functional and completely free.

All on our Free CD

Also, technical articles on subjects ranging from solar hot water and heating, to limescale, to underfloor heating, with case studies and links to useful web sites for further reading. Complimented by a huge library of over three hundred PDF documents from both ourselves and other well known suppliers of hot water equipment and controls. With this CD you have all technical data and tools to take on the most challenging designs with confidence.

Tel:

Fax:

Email:

• 10+ separate design software tools

• Technical editorials and animated help

• System Wiring Diagram Generator

• The entire Heatweb website

• ‘Build Your Own System’ software

• PDF document library

If you would like a free copy of the DPS CD, or would like to find out more information on the DPS range of products please contact us on:

0845 2411441

01372 803 678 [email protected]

Dedicated Pressure Systems Ltd

www.heatweb.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
