Oracle Database 12c on
Windows
Santanu Datta
VP of Development
Alex Keh
Sr. Principal PM
THE FOLLOWING IS INTENDED TO OUTLINE OUR
GENERAL PRODUCT DIRECTION. IT IS INTENDED FOR
INFORMATION PURPOSES ONLY, AND MAY NOT BE
INCORPORATED INTO ANY CONTRACT. IT IS NOT A
COMMITMENT TO DELIVER ANY MATERIAL, CODE, OR
FUNCTIONALITY, AND SHOULD NOT BE RELIED UPON IN
MAKING PURCHASING DECISIONS. THE DEVELOPMENT,
RELEASE, AND TIMING OF ANY FEATURES OR
FUNCTIONALITY DESCRIBED FOR ORACLE'S PRODUCTS
REMAINS AT THE SOLE DISCRETION OF ORACLE.
4
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Program Agenda
• Windows Platform support
• Oracle Home User support
• Performance
• Security
• Oracle RAC
• Microsoft Cluster Services Support
• .NET Application Development
• Q&A
5
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Windows 8 and Windows 2012
Supported Editions
 Windows 8 Editions
– Windows 8 Pro
– Windows 8 Enterprise
 Windows Server 2012 Editions
– Essentials
– Foundation
– Standard
– Datacenter
6
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Windows 32-bit Platform Support
7
OS
10gR2
11gR1
11gR2 #2
12cR1 #3
Windows XP Professional
#1
Yes
Yes
Yes
No
Windows Server 2003 and
Windows Server 2003 R2
Yes
Yes
Yes
No
Windows Vista #1
10.2.0.4
Yes
Yes
No
Windows 7 #1
10.2.0.5
No
Yes
Yes
Windows Server 2008
10.2.0.4
11.1.0.7
Yes
Yes
Windows Server 2008 R2
10.2.0.5
11.1.0.7
Yes
Yes
Windows 8 #1
No
No
Planned in Patchset
Yes
Windows Server 2012
No
No
Planned in Patchset
Yes
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
#1
RAC and some
other features not
supported on
Windows client
systems
#2
RAC not
supported for 32bit Windows in
11gR2 and later
#3
Only Database
Client is
supported for 32bit Windows in
12c and later
Windows 64-bit (x64) Platform Support
OS
10gR2
11gR1
11gR2
12cR1
Windows XP (#1), Windows Server
2003, and Windows Server 2003 R2
Yes
Yes
Yes
No
10.2.0.4
Yes
Yes
No
Windows 7 #1
10.2.0.5
No
Yes
Yes
Windows Server 2008
10.2.0.4
11.1.0.7
Yes
Yes
Windows Server 2008 R2
10.2.0.5
No
Yes
Yes
Windows 8 #1
No
No
Planned in
Patchset
Yes
Windows Server 2012
No
No
Planned in
Patchset
Yes # 2
Windows Vista #1
8
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Windows 32-bit
Client is also
supported on x64
systems
#1
RAC and some
other features not
supported on
Windows client
systems
#2
Single Instance
and Client support
only; RAC support
planned in a
future patchset
Hyper-V and Windows Azure Certification
 Windows 2012 Hyper-V
– DB 12cR1 (Single Instance) certified on Windows 2012 guest OS
– DB 12cR1 (Single Instance ) planned to be certified on Windows 2008R2 guest OS in a
future patchset
– DB 11gR2 (Single Instance) planned to be certified on Windows 2008R2 and Windows 2012
guest operating systems in a future patchset
 Windows Azure
– DB 12cR1(Single Instance) on Windows 2012 and Oracle Linux 6.4 (Preview)
– DB 11gR2 (Single Instance) on Windows 2012 and Windows 2008R2 planned in future
9
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Program Agenda
• Windows Platform support
• Oracle Home User support
• Security
• Performance
• Oracle RAC
• Microsoft Cluster Services support
• .NET Application Development
• Q&A
10
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Oracle Home User Support
• Run Windows Services for Oracle using a
standard Windows account
• Specify a standard (not an administrator) Windows
User Account as Oracle Home User during install
and upgrade
11
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Oracle Database Services on Windows
•
Windows Services
Oracle Listener
Service
Oracle Database
Service
•
•
•
•
File System ACLs
ORACLE HOME
ORACLE BASE
`
Databases
12
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Other Files
•
Services run as a Windows User (e.g.
domain1\frank)
Each service also has a unique Service SID
(e.g. Database sid orcl has service SID:
NTAUTHORITY\OracleServiceORCL)
Access controlled by File System ACLs
Oracle sets appropriate ACLs for Oracle
Home and Oracle Base
For customer specific files/directories in nonstandard locations, ACLs may need to be
changed to make them accessible to Oracle
Services
Either user name or Service SID can be used
to grant privileges or set ACLs
Please check Oracle Database Platform
Guide 12.1 for Microsoft Windows for
more information.
Database Server Install
13
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Oracle Home User
• Services for the Oracle Home run with this user name
• Can be Windows Built-in Account or a standard Windows User
Account
• Can not be changed post install
• Different from Oracle Installation User who must have OS
administration privileges
• Have similarities with ‘oracle’ user on Linux, though you can not log
in as the Oracle Home User on Windows and perform administration
tasks (e.g. Create DB, Install, Upgrade)
14
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Install
• Only OS Administrators can install Oracle
Windows Account option for
Oracle Home User
DB Server
(Single
Instance)
DB Client
DB Server
(RAC)
Grid
Infrastructure
Built-in Account
Y
Y
Y
Y*
Local User Account
(Enter user id and password)
Y
Y
N
N
Managed Services Account
(Enter user id only)
Y
Y
N
N
Domain Account
(Enter user id and password)
Y
Y
Y
Y
* If Grid Infrastructure Management Repository option is used, Built-in account option is not
allowed
15
Copyright
© 2013,Corporation
Oracle and/or its affiliates.
rights reserved.
© 2010
Oracle
– AllProprietary
and Confidential
Database Client Install
• For Built-in Account
option, Windows
Services run under
LocalService (not
LocalSystem) for
Database Client
16
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Oracle Grid Infrastructure Install
17
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Database Creation
• Database Configuration Assistant (DBCA) is used to create or modify
Oracle Database as a part of install or as post install action
• Administrators, invoking the tools, need to be an OS Administrator and
should have appropriate database privileges
• Use the icon Database Configuration Assistant created during Oracle
Database install (the icon is set up to “run as administrator”)
• As Windows Service creation requires both user id and password, DBCA
will ask for the password of Oracle Home User (if needed) in order to
create the Windows Service
• For Single Instance DB, password needed for Windows Local User and Domain
User
• For RAC, the customer has the option to store password in wallet; if not stored,
the password needs to be input for Windows Domain User
18
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Oracle Database Upgrade
ORACLE_BASE
ORACLE_HOME
(11.2)
ORACLE_BASE
ORACLE_HOME
(11.2)
ORADATA
Database 1
(11.2)
Database 2
(11.2)
19
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
ORACLE_HOME
(12c)
ORADATA
Database 1
(12c)
Database 2
(11.2)
Oracle Home and Database Upgrade
• Database Upgrade Assistant (DBUA) is used for database upgrade
across Oracle Homes as a part of install or as post install action
• Administrator, invoking the tools, needs to be an OS Administrator and
should have appropriate database privileges
• Use the icon Database Upgrade Assistant created during Oracle
Database install (the icon is set up to “run as administrator”)
• Requirement to enter Oracle Home User and Password is similar to
Database creation
• When a database is upgraded, it will ask for password of Oracle
Home User (if needed)
20
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Administration Tools
 All GUI tools (e.g. DBCA, NETCA) enhanced to support Oracle Home
User and ask for password if needed
 All command line tools (e.g. ORADIM, LSNRCTL, CMCTL) enhanced
to accept Oracle Home User name and password through stdin for
service creation
 Silent Install and Cloning enhanced to support Oracle Home User
 CRSCTL can be used to create wallet for storing password of Oracle
Home User (RAC environment)
 Enterprise Manager support of Oracle Home User for provisioning,
patching, and service creation
21
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Management of Oracle Home User
 As it is a standard Windows user, Windows tools can be used to
manage the Windows account (e.g. add privileges, change password)
 For changing password of the Oracle Home User account
– Use Windows tools to change the password
– Windows also requires all Windows Services to be updated in order to use the new
password
– For all Windows Services used by Oracle, you can use the icon Update Password
for Oracle Home User to:
 update password for all Windows services used by Oracle on a computer (Single
Instance Database or Client)
 change password in Oracle wallet and update password for all Windows
services used by Oracle in a cluster (for RAC)
You can also use the tool Oracle Home User Control (orahomeuserctl) in command
line (run as administrator)
22
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Program Agenda
• Windows Platform support
• Oracle Home User support
• Performance
• Security
• Oracle RAC
• Microsoft Cluster Services support
• .NET Application Development
• Q&A
23
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Large Pages Support
• Improve performance with large pages support
• 2 MB Page size (instead of 4 KB)
• If Oracle Home User is a standard Windows account, the
administrator must grant the "Lock pages in memory"
privilege to Oracle Home User or Service SID of Oracle
Database Service (NTAUTHORITY\OracleService<sid>)
24
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Large Pages Support
 Under HKEY_LOCAL_MACHINE\SOFTWARE\ORACLE\KEY_HOMENAME
– Create ORA_LPENABLE or ORA_SID_LPENABLE
– Set the value to 1 for regular mode and 2 for mixed mode
– Mixed mode is the new option to allow use of large pages but fall back to small
pages if OS is not able to allocate large pages
– ORA_SID_LPMAXTIME is the optional time parameter for mixed mode
(if a server has been running for some time and memory is fragmented, OS may
fail to allocate large pages; mixed mode can be used to ensure that DB comes
up in such cases)
25
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Direct NFS Client on Windows
• Network Attached Storage (NAS) uses Network File System (NFS)
• Oracle Database 11g allows direct Windows NFS v3 access
• Part of DB kernel in Oracle Disk Manager library
• Bypasses a lot of software layers in OS
• Tailored for the specific I/O patterns that Oracle uses
• Linear scalability of direct NFS can be achieved with inexpensive NICS
• Database 12c
• dnfs_batch_size can be used on windows systems that don't have
enough bandwidth to throttle the number of IOs queued to the system,
which may improve overall performance. (Bug 13647945)
26
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Support of Multiple Processor Groups
• Support a max of 4 processor groups with up to 64 CPUs in each
group for a total of 256 logical CPUs (Support of 10 processor groups
planned in a patchset)
• ORACLE_AFFINITY enhanced to enable affinity of Oracle threads to
cpus in multiple processor groups
• processorgroup is an optional parameter designating Windows CPU
group. On systems with 64+ logical CPUs, Windows divides all available
CPUs into 4 groups (0,1,2,3) with each group containing no more than
64 logical CPUs
Details in Oracle® Database Platform Guide 12c Release 1 (12.1) for
Microsoft Windows
27
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Program Agenda
• Windows Platform support
• Oracle Home User support
• Performance
• Security
• Oracle RAC
• Microsoft Cluster Services support
• .NET Application Development
• Q&A
28
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Windows Native Authentication (NTS)



Enabled by default and can work across Windows systems
Windows user logon credentials used for database authentication
Windows Explorer or Oracle Administration Assistant can be
used to manage user authentication and role authorization
Examples: CONNECT / AS SYSDBA
CONNECT / AS SYSASM
29
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Windows Native Authentication
SYSDBA and SYSOPER Privileges
• ORA_DBA
• SYSDBA privileges for all Oracle Databases on the system
• ORA_OPER
• SYSOPER privileges for all Oracle Databases on the system
• ORA_<HomeName>_DBA (12cR1)
• SYSDBA privileges for Oracle Databases on a specific Oracle Home
• ORA_<HomeName>_OPER (12cR1)
• SYSOPER privileges for Oracle Databases on a specific Oracle Home
All the groups are on the server system
30
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Windows Native Authentication
Administrative Privileges for ASM Instance
• ORA_ASMADMIN (12cR1)
• SYSASM administration privileges on the computer
• ORA_ASMDBA (12cR1)
• SYSDBA privileges for ASM Instance on the computer
• ORA_ASMOPER (12cR1)
• SYSOPER privileges for ASM Instance on the computer
ORA_DBA and ORA_OPER group members no longer get privileges for
ASM instance
All the groups are on the server system
31
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Windows Native Authentication
Separation of Privileges
• ORA_<HomeName>_ SYSBACKUP (12cR1)
• Backup privileges (SYSBACKUP) for databases of a specific Oracle Home
• ORA_<HomeName>_SYSDG (12cR1)
• Data Guard Privileges (SYSDG) for databases of a specific Oracle Home
• ORA_<HomeName>_ SYSKM (12cR1)
• Encryption Key Management privileges (SYSKM) for databases of a
specific Oracle Home
All the groups are on the server system
32
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Kerberos and ASM Enhancements
• Kerberos
• Security enhancements that were introduced in the MIT
Kerberos Release 1.8 distribution
• ASM file access control
• Restrict access of database files to the owner of the database
home
33
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Program Agenda
• Windows Platform support
• Oracle Home User support
• Performance
• Security
• Oracle RAC
• Microsoft Cluster Services support
• .NET Application Development
• Q&A
34
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Oracle RAC 12c
Oracle RAC 12c provides:
Oracle EM 12
Cloud Control
Utility Computer
35
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
1.
Better Business Continuity
and High Availability (HA)
2.
Agility and Scalability
3.
Cost-effective
Workload Management
Program Agenda
• Windows Platform support
• Oracle Home User support
• Performance
• Security
• Oracle RAC
• Microsoft Cluster Services support
• .NET Application Development
• Q&A
36
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Oracle Database 12c
Oracle Fail Safe Release 4.1
 Facilitates using an Oracle Database in a Microsoft Failover Clustering
environment
 Included with all Oracle Database Server editions
 Microsoft Failover Clustering is included with Windows Server
37
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
An Oracle Database in a Failover Cluster
Clients
Basic Cluster Configuration
 Oracle homes are duplicated
across all nodes in the cluster
 A hardware or software failure
can trigger a failover to another
physical node
Backup Node
Primary Node
Local Storage
Shared Storage
Application Data
38
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Executables:
• Oracle Homes
• Application
Oracle Database 12c
Oracle Fail Safe Release 4.1
 New in this release
– Database 1 2c support, including Oracle Home User
– Integrated with Microsoft Management Console (MMC)
– Compliant with Microsoft PowerShell scripting environment
 Software is available in Database CD pack or may be downloaded
from Oracle Technology Network (OTN)
 See OTN for more information:
http://www.oracle.com/technetwork/database/windows/index082893.html
39
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Program Agenda
• Windows Platform Support
• Oracle Home User support
• Performance
• Security
• Oracle RAC
• Microsoft Cluster Services support
• .NET Application Development
• Q&A
40
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
.NET Development –
Oracle Database 12c
41
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Major New Oracle .NET Features
 High availability and scalability in .NET
 Oracle Multitenant development in Visual Studio
 Oracle Schema Compare for Visual Studio
 ODP.NET, Managed Driver
42
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
High Availability and
Scalability in .NET
43
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
High Availability and Scalability
 Global Data Services
– Extend FCF, load balancing, and affinity capabilities to Data
Guard and GoldenGate
 Oracle Notification Service (ONS) replaces AQ for Fast
Application Notification (FAN)
– Faster, more scalable, eliminates firewall issues, supports Active
Data Guard, and consolidates publish/subscribe service
44
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
High Availability
 Faster and more graceful planned outages
– DB brought offline as quickly as possible without end user
disruptions
 Transaction Guard
– Ensures transaction commits at most once
 Recoverable error detection and recovery
– Determine with certainty whether can rollback or resubmit
45
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Oracle Multitenant
Development in Visual
Studio
46
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Multitenant Architecture
Components of a Multitenant Container Database (CDB)
PDBs
Root
Pluggable Databases (PDBs)
CDB
47
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Multitenant for Test and Development
Clone production, plug into development. Clone/destroy test instances
48
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Deployment
 Unplug from development/test
environment
 Plug into production environment
49
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Oracle Multitenant with ODAC 12c
 ODP.NET works implicitly with PDBs
– Connect to the PDB service name
– Hostname and port are same as container
 Requires Oracle Database 12c and ODAC 12c
53
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
D E M O N S T R A T I O N
Multitenant
54
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Oracle Schema Compare
for Visual Studio
55
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Schema Compare Tool in Visual Studio
 New in Oracle Developer Tools for Visual Studio
– ODAC 12c
– Oracle Database 10.2 or higher
 Compare two schemas in the same or different DBs
– Visually inspect differences using UI
– Generate a diff script for deployment purposes
– Reverse schema compare to “rollback” changes
– Can compare down to granularity of schema type
 e.g. compare all tables, or all packages, etc.
56
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
D E M O N S T R A T I O N
Schema Compare
59
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
ODP.NET, Managed Driver
60
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Current ODP.NET Architecture
Managed and Unmanaged
Managed
ODP.NET
Oracle.Data
Access.dll
61
Database
Unmanaged
ODP.NET
Unmanaged
DLLs
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
OCI
NET
Oracle
Forthcoming ODP.NET Architecture
Fully Managed
62
Managed
Database
ODP.NET
Oracle.Managed
DataAccess.dll
Oracle
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Managed ODP.NET vs. Unmanaged ODP.NET
Benefits
 One assembly for both 32-bit and x64
 Easier side by side deployment
 Deploy smaller and fewer binaries
– Before: 150 MB
– After: Less than 10 MB
 Easier patching process
 Fully integrated with Code Access Security
63
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Managed ODP.NET Deployment Concepts
 Option 1: single configuration file deployment
– .NET config file contains TNS, SQL*Net, and LDAP settings
 i.e. Machine.config, web.config, app.config
 Option 2: multi-file configuration
– .NET config file
– Tnsnames.ora, sqlnet.ora, and ldap.ora
 Option 3: no configuration files
– Store connect info in Data Source attribute
67
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Unmanaged to Managed Migration
 Application migration process
– 1. Use Oracle.ManagedDataAccess.dll reference in project
– 2. Modify namespace(s) to Managed ODP.NET
– 3. Change .NET config settings for Managed ODP.NET
 Include *.ora file settings
 Managed ODP.NET APIs same as ODP.NET APIs
– Initially, Managed ODP.NET does not support all ODP.NET
features
– Plan is eventual feature parity
68
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
For More Information
•
•
•
•
•
69
Booth: Moscone South, Left - S-067 – Oracle Database on
Windows
Windows Server System Center
Oracle .NET Developer Center
Twitter - @OracleDOTNET
YouTube - http://www.youtube.com/user/OracleDOTNETTeam
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Questions
&
Answers
70
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
71
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
