1

NEW DESIGN

MI/O Extension单板电脑

具有MIOe扩展接口的嵌入式单板单板电脑

研华创新型MI/O Extension(多I/O)单板电脑定位于单板电脑(SBC)和电脑核心模块(COM)之间的细分市场。MI/O

Extension 嵌入式单板电脑配有灵活的多I/O接口,可提高开发效率、节约开发资源,并可为系统集成商提供经济高效的优化解决方

案,同时还可保障其关键垂直产业领域的专业技术。

客户可通过高速插槽连接MI/O Extension模块后,扩展出更多灵活的I/O,满足不同垂直行业的使用需求。MI/O Extension接口

(MIOe)适应接口扩展需求和未来技术发展趋势,支持以下接口:DisplayPort、PCIe x1、LPC、SMBus、USB 2.0/USB 3.0、音频线

路输出和电源接口。

MI/O Extension的设计考虑了软件、硬件和固件扩展和升级。除了提供MIOe模块设计文档供客户参考,研华还提供了开发板以帮

助客户进行MIOe接口验证和测试。研华一直竭力帮助系统集成商开发经济高效、以市场为导向的灵活解决方案,帮助其迅速抢占商

机。

*

不同平台的规格不同,最多可达4对。

MI/O-Ultra

100 mm (3.9”)

Rear I/O connector coastline

Thermal Zone

CF/CFast

MIOe

MIOe Pin Assignment

▪ DisplayPort

▪ 4 PCIe x1

▪ USB 3.0

▪ USB 2.0

▪ LPC

▪ HD Audio line out

▪ SMBus

▪ +12V/ +5V Power

▪ Core TDP :低于8 W

▪ 超低功耗

Memory

Front Side

I/O Zone

Back Side

▪ 超小尺寸(与2.5"硬盘或PICO-ITX尺寸相同)

▪ 带有简易I/O,有价格优势

MI/O-Compact

146 mm (5.7”)

Rear I/O connector coastline

CF/CFast

2.5” Hard Disk

Thermal Zone

PCIe Mini Card

Expansion

MIOe

SMT Type I/O Zone

Dip Type I/O Zone

▪ Core TDP: 9 W - 40 W

▪ 丰富的I/O

▪ 尺寸紧凑,与3.5" HDD相同

Front Side

▪ 支持扩展温度设计

▪ 支持iManager

▪ 中高端性能平台

Back Side

灵活的服务模式 - 合作开发和自主开发

系统集成商可通过统一的MIOe接口插接MIOe模块,从而扩展I/O 功能。研华还提供了一系列应用模块,系统集成商可参考研华网站

上的MI/O extention模块的设计指南自己设计、开发应用。我们也为客户提高了合作开发工作模式。客户可以选择“由研华进行设计

“或者”由客户自行设计“。

MI/O SBC

MIOe Module

标准模块

▪ 可随时订购

MI/O开发过程

研华客制化设计

▪ 客户规格

▪ 研华资深技术支持

合作开发模式,即“MIOe合作开发支持”须遵守研华的项目开发

流程。如果客户选择自主开发模式,研华可在过程中针对多个检

查点协助进行进程评审。两种工作模式都要求做到以下检查点:

由客户自行设计

▪ 客户规格

▪ 丰富的专业知识

项目初始

研华协助客户审核功能块图并评估合作开发和自主开发模

式的优缺点。MI/O Extension规格、MIOe设计指南、

评估板机械图等信息,都可供用户下载。具体请访问: http://mio.advantech.com

研华客制化设计

Check Points

步骤1:项目咨询

▪ 研华提交项目概念、功能块图、规格、排程以及报价。

▪ 客户认可

步骤2:方案设计

▪ 研华提交设计方案

步骤3:元器件位置设计

▪ 研华2D/3D设计图

▪ 客户认可

步骤4:布线设计

▪ 研华提交布局布线

步骤5:生产

▪ 研华负责生产样品及组装

步骤6:验证

▪ 客户和研华FAE检验产品

由客户自行设计

Check Points

步骤1:方案审核

▪ 研华协助客户审核方案,确保其符合 MIOe设计指南的

要求

步骤2:元器件位置审核

▪ 研华提供MIOe高度限制信息和3D文件供用户参考

步骤3:布线审核

▪ 研华提供PCB层叠结构和阻抗控制建议

步骤4:生产

▪ 客户负责生产样品及组装

步骤5:验证

▪ 客户在研华的帮助下检验产品

注:研华有权根据服务规模收取设计NRE费用。

2

INNOVATIVE FLEXIBILITY

主要特性

研华引进了MI/O Extension以帮助系统集成商快速为客户提供优化解决

方案,并保证其在垂直产业技术领域的竞争力。

3

Disp layP

LPC

Pow er HD Au

USB

PCIe

SMB dio us

MIOe统一接口

MI/O Extension有一个统一的MIOe接口,可支持附加扩展接口,进而为研华或客

户设计的I/O模块提供更灵活的支持。MIOe连接器支持5mm ~ 25mm等多种高度

选择,因此能够满足不同模块的需求。

接口功能包括:

▪ DisplayPort:HDMI、LVDS、DVI、CRT或eDP显示接口

▪ PCIe x1:GbE、USB 3.0、SATA/RAID、FPGA或PCI扩展

▪ USB 2.0/ 3.0:超高速存储、采集卡、HD Webcam &显示接口

▪ LPC:传统总线& Multi-UART、PS2、GPIO、FDD、IR、超级I/O的并行端口

▪ 高清音频:线路输出,可灵活选择扩音器

▪ SMBus:GPIO控制、智能电池/充电器、W/R EEPROM

▪ 电源:MI/O Extension SBC配有电源

MIOe接口具有的特性

高速接地排针

▪ 支持多种高速协议,延长产品生命周期

多种高度选择

▪ 5, 8, 11, 16, 19, 25mm高度组合,适合

各种应用

丰富的库参考

▪ 电气/3D模型、PCB库/Footprint

▪ 终版英寸布局参考

统一的安装孔位

MI/O Extension提供了统一的螺丝安装孔,便于安装散热解决方案和

系统集成。

▪ 散热解决方案安装更容易

▪ 系统维护更便捷

▪ 平台升级更简单

为什么选择MI/O Extension SBC

进行嵌入式开发?

▪ 高度集成,节省多达20%的系统空间

▪ 灵活性高,便于以后进行I/O扩展和升级

▪ 提供专业的设计文档和开发板

▪ 是一款省时、经济、高效的解决方案

特殊机械设计

▪ 高级散热设计

▪ 全集成I/O

▪ 无线设计

单面集中散热设计

一般而言,热流都集中在嵌入式板卡的顶部和底部。研华MI/O Extension 嵌入式单板带有

集中散热设计,所有的热量都集中在顶部,通过散热片或导热片疏导热量的效果更好。

▪ 覆盖了CPU、南桥、内存、电源和主动IC

▪ 最大散热空间

▪ 集成导热片/散热片

▪ 简化系统设计

▪ 底部的热敏感部件可有效预防热引起的问题。

扩展模块选项

研华开发了一系列模块,都可用于未来的接口设计,并满足垂直应用的需求。

▪ 显示模块:48-bit LVDS/显示接口/ USB2.0

▪ 通信模块:3个GbE

▪ 多I/O模块:多个COM端口

▪ 评估板:可用于接口验证

▪ MIOe模块可保护客户核心知识产权

简化线材设计

MI/O Extension单板电脑采用了统一的I/O接口,CF卡和mini PCIe插槽的位置也都是

统一的,便于扩展。板卡下方的区域是为2.5”硬盘而设计的。这种统一的结构克服了

很多在升级中会遇到的问题。

▪ 底部接线更少,接口可锁

▪ 降低了安装和维修成本,减少了复杂度

紧凑的机构设计

紧凑型机械设计以及简化的机械设计通常是备受嵌入式系统集成商关注的两大问题。

▪ 系统组织部件减少

▪ 节省多达20%的系统空间

▪ 可选导热片,降低总体高度

4

5

PRODUCT SELECTION

MI/O卓越的散热解决方案

研华MI/O 嵌入式单板电脑采用了集中散热设计。所有发热元器件都位于顶部,可通过散热片或导热片散热。这种集中散热设计

对系统整合带来很多优势,也增强了系统可靠性。

最大化利用散热片

散热片/导热片可有效为CPU、南桥芯

片、内存和很多发热元器件提供散热保

护。

系统维护更便捷

系统集成商只需单方面考虑MI/O 嵌入

式单板的散热解决方案。

可靠性更高

MI/O 嵌入式单板电脑的底部置有热敏元

件,可有效预防热引起的问题,同时也提

高了元件的可靠性。

搭载了Intel Atom N455的MI/O CPU卡

Bottom View

热流都集中在板卡顶部,

散热更高效

Top View

搭载了Intel Atom N455的其它CPU卡

热流集中在两侧,散热效

果不理想

Top View Bottom View

PRODUCT SELECTION

MI/O Extension模块 -

易于扩展、立即可用

MI/O Extension模块支持多种嵌入式单板电脑,为客户提供灵活I/O接口,满足各种垂直应用的需求。由于采

用了统一的接口和螺丝孔位,所以MIOe模块全部兼容MI/O SBC。

** 研华为自行设计 MI/O Extension模块的客户提高了设计指南。

MI/O-Compact

MIOe-210

▪ Multiple COM Ports

(4x RS232/422/485, 2x RS422/485)

MIO-5250 MIO-5270

MIO-5290 MIO-5271

▪ Up to 6x RS232/422/485, 4x RS422/485

MI/O-Ultra

MIOe-220

▪ Triple Intel ® Gigabit Ethernet

MIO-5250 MIO-5270

MIO-5290 MIO-5271

▪ Up to 5 x Intel Gigabit Ethernet

MIOe-230

▪ 48-bit LVDS or DisplayPort, 2 x USB 2.0

MIO-5250 MIO-5270

MIO-5290 MIO-5271

▪ Up to 2 x LVDS, 8 x USB 2.0

MIOe-110

▪ 2 x RS232, 2 x RS232/422/485, 2 x USB 2.0

MIO-2260 MIO-2261

▪ Up to 4xRS232,

2xS232/422/485, 2 x USB 2.0

MI/O 开发板

MIOe-120

▪ Dual Intel

®

Gigabit Ethernet/ Mini-PCIe with

SIM holder/ HDMI/ Audio with Amp./ 2 x

▪ Up to 3 x Intel® Gigabit Ethernet/ 2

Mini-PCIe with SIM holder/ HDMI/

Audio with Amp./ 4 x USB2.0

MIOe-DB5000

▪ Evaluation board for all MI/O SBCs

▪Form factor: Micro ATX (244 x 170 mm)

▪ Digital Display Interfaces

▪ 3 PCIe x1

▪ USB 2.0/ USB 3.0

▪ HD audio line out

▪ LPC

▪ SMBus

▪ GPIO

▪ PCIe Mini Card, SIM holder

▪ SATA, SATA Power

MIOe-DB2000

▪Evaluation board for MIO-2262

▪115 x 165 mm

▪1 PCIe x1, 1 mini PCIe

▪6 USB 2.0

▪ 1 Display Port/ HDMI (HDMI supported by request)

▪ 1 SIM Card Holder

6

PRODUCT SELECTION

MI/O Extension 单板电脑

7

处理器系统

内存

显示

以太网

音频

看门狗定时器

存储

后部 I/O

内部 I/O

扩展

电源

环境

物理特性

型号名

外形尺寸

高度

带散热解决方案

CFast

SATA

以太网

VGA

HDMI

USB

LED

DC 电源插孔

USB

串行

SMBus

GPIO

I2C

Mini PCIe

CPU

频率

二级缓存

系统芯片组

BIOS

技术

最大容量

插槽

芯片组

图形引擎

LVDS

VGA

HDMI/DP eDP

双显

速度

控制器

接口

芯片组

放大器

Compact Flash mSATA

MIOe

电源类型

电源电压

外围电源总输出

MIO-5250

3.5" MI/O-Compact SBC

Intel Atom Dual Core N2600 1.6 GHz/D2550 1.86 G Hz

Dual Core 1.6 GHz/1.86 GHz

1 MB

Intel Atom N2600/D2550 + Intel NM10

AMI EFI 16Mbit

DDR3 1066 MHz (D2550), DDR3 800 MHz (N2600)

4 GB

1 x 204-pin SODIMM

Intel Atom N2600/D2550

DirectX 9 and OpenGL3.0 support

Hardware decode H/W acceleration: MPEG2

H/W Decode/Acceleration: H.264/ VC1/ WMV9

18/24-bit LVDS1: up to 1366 x 768 (N2600), 1440 x 900 (D2550)

48-bit LVDS2: up to 2560 x 1600 (only for MIO-5250D-S8A1E)

Up to 1920 x 1200

Supports 1920 x 1200, Max data rate: up to 1.65 Gb/s,

Supports HDMI v1.3 Up to 1080p support

Option (supported by request)

VGA + LVDS1/2 or VGA + HDMI or HDMI + LVDS1/2

10/100/1000Mbps

GbE1 Intel 82583V

GbE2 Intel 82583V

2 x RJ45 on Rear I/O

Realtek ALC892, High Definition Audio(HD), Line-in,

Line out, Mic-in

Can be supported via MIOe

255 levels timer interval, programmable by software

MIO-5270 MIO-5271

3.5" MI/O-Compact SBC

AMD G- Series, T40R 1.0 GHz single core,

T40E 1.0 GHz dual core,

T56N 1.65 GHz dual core

1.0 GHz single/dual core, 1.65 GHz dual core

512 KB on T40R/ T40E, 1 MB on T56N

AMD G-Series + A50M FCH

AMI EFI 32Mbit

DDR3 1066 MHz, 1333 MHz for T56N only

4 GB

1 x 204-pin SODIMM

AMD G- Series

DirectX® 11 graphics with UVD 3.0

2D Acceleration, 3D Acceleration, Motion Video Acceleration,

Supports DVD, Blu-ray*

Hardware decode (UVD 3):H.264, VC-1 & MPEG2

LVDS: Supports single channel 24-bit or dual channel 48-bit LVDS

T56N up to 2560 x 1600 at 60 Hz, T40R, T40E, up 1920 x 1200 at 60 Hz (pixel clock rate = 80 MHz)

T56N up to 2560 x 1600, T40R / T40E, up to 1920 x 1200

Supports 1920 x 1080p at 60 Hz, 36 bpp,

Supports HDMI v1.3, using TMDS data encoding

Option (supported by request)

VGA + LVDS or VGA + HDMI or HDMI + LVDS

10/100/1000Mbps

GbE1 Realtek RTL8111E-VB-GR

GbE2 Realtek RTL8111E-VB-GR

2 x RJ45 on Rear I/O

Realtek ALC892, High Definition Audio (HD), Line-in,

Line out, Mic-in

Can be supported via MIOe

255 levels timer interval, setup by software

3.5" MI/O-Compact SBC

Intel® Core™ ULT SoC Dual Core i5-4300U 1.8GHz Celeron 2025U 1.6GHz

Dual Core 1.8GHz/ 1.6GHz

3M on 4300U, 2M on 2025U

Intel Lynx Point LP

AMI UEFI BIOS at 128 Mb

DDR3L 1333/1600 MHz

8 GB

1 x 204-pin SODIMM

Intel® HD Graphics 5000

DirectX11.1, OpenGL 4.0, and OpenCL 1.3

Full AVC/VC1/MPEG2 HW Decode

LVDS with 3.3V, 5V on LCD VDD power, 5V and 12V support on LVDS inverter

Dual channel 24-bit LVDS, max resolution up to 1920 x 1200 with 60Hz

Up to 1920 x 1200 with 60 Hz, 154 MHz pixel clock rate

Up to 3200 x 2000 at 60 Hz on DisplayPort, 4096 x

2304 at 24 Hz on HDMI

Option (supported by request)

3 independent displays (VGA + DisplayPort/HDMI

+ LVDS)

10/100/1000Mbps

GbE1 - Intel i218,

GbE2 - Intel i210

2 x RJ45 on Rear I/O

Realtek ACL888, High Definition Audio (HD), Line-in,

Line out, Mic-in

Can be supported via MIOe

255 levels timer interval, programmable by software

-

Supports either mSATA or full size miniPCIe, selected by BIOS, default support full size miniPCIe

1

1, up to 3.0 Gb/s (300MB/s)

2 (10/100/1000Mbps)

1

1

4 x USB 2.0

Power, HDD

1 (Supported only on MIO-5250N-S6A1E)

2 x USB 2.0

2 RS-232, 2 RS-232/422/485

(RS485 support auto flow control)

(ESD protection for RS-232: Air gap ±15kV, Contact ±8kV)

1 (shares with I2C)

8-bit general purpose input/output

1 (shares with SMBus)

1 (full size) with SIM Holder

SMBus, 3 x USB2.0, LPC, 1 x PCIe, line out, 5

Vsb/12 Vsb power, power on, reset,Displayport

(optional)

Single 12V DC power input

Supports single 12V input, ± 10%

-

Supports either mSATA or full size miniPCIe, selected by BIOS, default support full size miniPCIe

1

2, up to 6.0 Gb/s (300MB/s)

2 (10/100/1000Mbps)

1

1

4 x USB 2.0

Power, HDD

1 (Supported only on MIO-5270S-S0A1E & MIO-

5270D-S0A1E)

2 x USB 2.0

3 RS-232, 1 RS-232/422/485

(RS485 support auto flow control)

(ESD protection for RS-232: Air gap ±15kV, Contact ±8kV)

1 (shares with I2C)

8-bit general purpose input/output

1 (shares with SMBus)

1 (full size)

SMBus, 3 x USB2.0, LPC, 4 x PCIe, line out, 5

Vsb/12 Vsb power, power on, reset,Displayport

(optional)

Single 12V DC power input

Supports single 12V input, ± 10%

-

Supports either mSATA or full size miniPCIe, selected by

BIOS, default support full size miniPCIe

-

2, up to 6.0 Gb/s (600 MB/s)

2 (10/100/1000Mbps)

1

1

2 x USB 2.0, 2 x USB 3.0

Power, HDD

Option (supported by request)

1 x USB 2.0

2 RS-232, 2 RS232/422/485

(RS485 support auto flow control)

(ESD protection for RS-232: Air gap ±15kV, Contact ± 8kV)

1 (Shares with I2C pin)

8-bit general purpose input/output

1 (Shares with SMBus pin)

1 x Full-size Mini PCIe

1 x Half-size Mini PCIe

Displayport, SMBus, 3 x USB2.0, LPC, 1 x PCIe x1, line out, 5 Vsb/12 Vsb power, Power On, Reset

Single 12V DC power input

Supports single 12V input, ± 10%

-

功耗

(典型)

功耗

(最大,HCT下测试)

电源管理

电池

工作

非工作

尺寸 (L x W)

重量

散热片

导热片

冷却器

N2600: 0.606 A @ 12 V (7.27 W), D2550: 0.829 A @

12 V (9.95 W)

N2600: 0.729 A @ 12 V (8.75 W), D2550: 1.029 A @

12 V (12.35 W)

ACPI

Lithium 3 V / 210 mAH

0 ~ 60° C (32 ~ 140° F)

(Operational humidity: 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C and 60° C @ 95% RH Non-

Condensing

146 x 102 mm (5.7" x 4")

0.78 kg (1.72 lb), weight of total package

306 mm

273 mm

-

T40R: 0.59 A @ 12 V (7.08W), T40E: 0.53 A @ 12 V

(6.36W), T56N: 0.65 A @ 12 V (7.8W)

T40R: 0.8 A @ 12 V (9.6W), T40E: 0.82 A @ 12 V

(9.84W),

T56N: 1.35 A @ 12 V (16.2W)

ACPI

Lithium 3 V/210 mAH

0 ~ 60° C (32 ~ 140° F)

(Operating humidity: 40° C @ 95% RH non-condensing)

-40° C ~ 85° C and 60° C @ 95% RH noncondensing

146 x 102 mm (5.7" x 4")

0.78 kg (1.72 lb), weight of total package

336 mm

253 mm

336 mm

TBD

TBD

ACPI

Lithium 3 V / 210 mAH

0 ~ 60° C (32 ~ 140° F)

(Operational humidity: 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C and 60° C @ 95% RH Non-

Condensing

146 x 102 mm (5.7” x 4”), same as 3.5”

0.78kg (1.72lb), weight of total package

324 mm

253 mm

-

MIO-5290 MIO-2260

3.5" MI/O-Compact SBC 2.5" MI/O-Ultra SBC (Pico-ITX)

Intel ULV Core i3 3217UE/ ULV Core i7 3517UE/

LV Core i7 3555LE

1.6 GHz (Dual Core)/ 1.7 GHz (Dual Core)/

2.5 GHz (Dual Core)

3 MB/ 4 MB/ 4 MB

Intel Core i3/ i7 + Intel QM77 PCH

AMI EFI 16 M-bit

DDR3 (1066/1333/1600)

DDR3L (1066/1333) on 2 Core BGA only

8 GB

1 x 204-pin SODIMM

Intel® HD Graphics 4000

DirectX 11, OpenGL *3.1, OpenCL* 1.1

JPEG/MJPEG decode, Full encode MPEG2

AVC/H.264 : Main and High Profiles, Up to Level 4.1

(including CABAC)VC-1 : Simple, Main and Advanced

Profiles; Up to Level 3MPEG-2 : Main Profile @ ML and HL

Intel Atom processor N455 Single Core 1.66 GHz

1.66 GHz

512 KB

Intel N455 + ICH8M

AMI 16 M-bit Flash BIOS

DDR3 800 MHz

2 GB

1 x 204-pin SODIMM

Intel Atom processor N455

Intel Gen 3.5 DX9, MPEG2 Decode in HW

Embedded Gen3.5+ GFX Core

48-bit LVDS, up to 2560x1600 at 60 Hz 18-bit LVDS up to WXGA 1366 x 768

MIO-2261

2.5" MI/O-Ultra SBC (Pico-ITX)

Intel Atom Dual Core N2600 1.6 GHz/ N2800

1.86 GHz

Dual Core 1.6 GHz/ 1.86 GHz

1 MB

Intel Atom N2600/ N2800 + Intel NM10

AMI EFI 16 M-bit

DDR3 800 MHz (N2600), DDR3 1066 MHz

(N2800)

4 GB

1 x 204-pin SODIMM

Intel Atom N2600/ N2800

DirectX 9 and OpenGL3.0 support

H/W Decode/Acceleration: H.264, VC1, MPEG2

18/24-bit LVDS1: up to 1366 x 768

MIO-2262

2.5” MI/O-Ultra SBC (Pico-ITX)

Intel Atom Dual Core N2600 1.6 GHz/ N2800

1.86 GHz

Dual Core 1.6 GHz/ 1.86 GHz

1 MB

Intel Atom N2600/ N2800 + Intel NM10

AMI EFI 16 Mbit

DDR3 800 MHz (N2600), DDR3 1066 MHz

(N2800)

4 GB

1 x 204-pin SODIMM

Intel Atom N2600/ N2800

DirectX 9 and OpenGL3.0 support

H/W Decode/Acceleration: H.264, VC1, MPEG2

18/24-bit LVDS1: up to 1366 x 768

Up to 2048x1536 at 75 Hz

Up to 1920x1200 at 60 Hz using HDMI

Up to 2560x1600 at 60 Hz through DisplayPort

-

3 independent display (VGA + LVDS + HDMI or

VGA + LVDS + DP)

10/100/1000Mbps

GbE 1 : Intel 82579LM

GbE 2 : Inte 82583V

2 x RJ45 on Rear I/O

Realtek ALC892, High Definition Audio (HD), Linein, Line out, Mic-in

Can be supported via MIOe

255 levels timer interval, setup by software

-

Supports either mSATA or full size miniPCIe, selected by

BIOS, default support full size miniPCIe

-

2, up to 6.0 Gb/s (600MB/s)

2 (10/100/1000Mbps)

1

1

2 x USB 3.0, 2 x USB 2.0

Power, Hard disk

1 (Supported only on selected SKU)

2 x USB 2.0

1 RS-232, 1 RS-232/422/485

(RS485 support auto flow control)

(ESD protection for RS-232: Air gap ±15kV, Contact ± 8kV)

1 (shares with I2C)

8-bit general purpose input/output

1 (shares with SMBus)

1 (full size) + 1 (half size)

SMBus, USB2.0, USB3.0, LPC, 4 PCIe x 1, line out, 5 Vsb/12 Vsb power, power on, reset,

Displayport (by request)

Single 12V DC power input

Supports single 12V input, ± 10%

-

3217UE: w/DDR3L: 1.507 A @ 12 V (18.08 W)

3517UE: w/DDR3L: 1.965 A @ 12 V (23.5 W)

3555LE: w/DDR3L: 2.309 A @ 12 V (27.7 W)

3217UE: w/DDR3L: 1.84 A @ 12 V (22.08 W)

3517UE: w/DDR3L: 2.3 A @ 12 V (27.6 W)

3555LE: w/DDR3L: 2.708 A @ 12 V (32.5 W)

ACPI

Lithium 3 V/210 mAH

0 ~ 60° C (32 ~ 140° F)

(Operating humidity: 40° C @ 95% RH non-condensing)

-40° C ~ 85° C and 60° C @ 95% RH noncondensing

146 x 102 mm (5.7" x 4")

0.85 kg (1.87 lb), weight of total package

-

273 mm

*583mm (MIO-5290L)

476mm (MIO-5290U)

Up to 1400 x 1050

-

-

VGA+LVDS

10/100/1000 Mbps

GbE1 Intel 82567V

RJ45

Realtek ALC892 High Definition Audio (HD),

Line-in, Line out

Can be supported via MIOe

Output System reset, Programmable counter from

1 ~ 255 minutes/ seconds

Supports CompactFlash Card TYPE II (Primary

Master IDE Channel)

-

Up to 1920 x 1200

-

-

VGA+LVDS

10/100/1000Mbps

GbE1 Intel 82583V 10/100/1000Mbps

RJ45

Realtek ALC892, High Definition Audio(HD),

Line-in, Line out

Can be supported via MIOe

Output System reset, Programmable counter from

1 ~ 255 minutes/ seconds

-

Up to 1920 x 1200

-

-

VGA+LVDS

10/100/1000Mbps

GbE1 Intel 82583V 10/100/1000Mbps

64pin connecter A

Realtek ALC892, High Definition Audio (HD),

Line-in, Line out

Can be supported via MIOe

Output System reset, Programmable counter from

1 ~ 255 minutes/seconds

-

1 (Integrate USB signal, supports either mSATA or USB interface module)

1 (Supports mSATA or USB interface module or full size miniPCIe, selected by BIOS, defaulf is mSATA)

-

1, up to 3.0 Gb/s (300MB/s)

1 (10/100/1000 Mbps)

1

-

2 x USB 2.0

-

1 (supported by request)

-

2 x RS-232(ESD protection for RS-232: Air gap

±15kV, Contact ±8kV)

1 (shares with I2C)

8-bit general purpose input/output

1 (shares with SMBus)

-

1, up to 3.0 Gb/s (300MB/s)

1 (10/100/1000 Mbps)

1

-

2 x USB 2.0

-

1 (supported by request)

2 x USB 2.0

2 x RS-232(ESD protection for RS-232: Air gap

±15kV, Contact ±8kV)

1 (shares with I2C)

8-bit general purpose input/output

1 (shares with SMBus)

-

-

-

-

-

-

-

-

64pin connecter A (12V DC input, Inverter, VGA, 2 x

USB2.0, 1GbE w/ LED)

64pin connector B (SMBus, I2C, Power/Reset button,

HDD/Power LED, 2 x USB2.0, 8-bit GPIO, HD Audio

Line in/out, 2 x RS-232)

1 (half-size Mini PCIe)

0.64 A, 12 V (7.68 W)

1 (half-size Mini PCIe) 1 (Full-size Mini PCIe)

SMBus, 3 x USB 2.0, 4 x PCIex1, LPC, line-out,

5 Vsb/12 Vsb power

2 x USB 2.0, 2 x PCIex1, LPC, line-out, SMBus,

DP or HDMI supported by request, 5 Vsb/12

Vsb power

3 x USB 2.0, 2 x PCIe x1, LPC, HD Audio lineout, SMBus, DP or HDMI supported by request, 5

Single 12V DC power input (Support DC power hot plug) Single 12V DC power input (Support DC power hot plug) Single 12V DC power input (Supports DC power hot plug)

Supports single 12V input, ± 10%

Vsb/12 Vsb Power output

Supports single 12V input, ± 10% Support single 12V input (12V+/- 10%)

5V @2.8A for CPU board and MI/O Extension module totally, 12V @2A for MI/O extension module

5V @3A for CPU board and MIOe module totally,

12V @2A for MIOe module

5V @ 3A for CPU board and MIOe module totally,

12V @ 2A for MIOe module

N2600: 0.35A @12V (4.2W)

N2800: 0.46 [email protected] 12 V (5.52 W)

N2600: 0.43 A @ 12 V (5.24 W)

N2800: 0.51 [email protected] 12 V (6.12 W)

0.86 A, 12 V (10.32 W)

APM, ACPI,wake on LAN

Lithium 3 V/210 mAH

0 ~ 60° C (32 ~ 140° F)

(Operating humidity: 40° C @ 95% RH non-condensing)

-40° C ~ 85° C and 60° C @ 95% RH noncondensing

100 x 72 mm (3.94" x 2.83")

0.42 kg (0.93 lb), weight of total package

337 mm

192 mm

-

N2600: 0.76A @12V (9.12W)

N2800: 0.80 A @ 12 V (9.6 W)

APM, ACPI,wake on LAN

Lithium 3 V / 210 mAH

0 ~ 60° C (32 ~ 140° F)

(Operational humidity: 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C and 60° C @ 95% RH noncondensing

100 x 72 mm (3.94" x 2.83")

0.42 kg (0.93 lb), weight of total package

337 mm

192 mm

N2600: 0.67 A @ 12 V (8.05 W)

N2800: 0.82 A @ 12 V (9.8 W)

APM, ACPI, wake on LAN

Lithium 3 V / 210 mAH

0 ~ 60° C (32 ~ 140° F)

(Operational humidity: 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C and 60° C @ 95% RH noncondensing

100 x 72 mm (3.9” x 2.8”)

0.37 kg (0. 82 lb),weight of total package

337 mm

192 mm

-

8

SOFTWARE INTEGRATION

嵌入式软件服务

研华提供了一系列服务,包括BIOS、嵌入式OS、以及适合于MI/O系列的软件API实用程序。采用研华提供的软件服务后,系统

集成商即可节约设计成本,降低项目复杂度。

BIOS模块化服务

研华提供了模块化嵌入式BIOS服务,具有系统集成商所需的优越的性能、兼容性和功能。研华产品支持众多选项和扩展,满足

了各种应用的需求,因此从竞争中脱颖而出。

CPU

USB

PCI-E Storage DRAM AGP Fast Boot Blank Boot OEM Logo LAN PXE LCD Timing

SATA APM/ACPI Super IO/GPIO Security COMS

Backup

Console

Redirection

Setup Screen Smart Battery

9

▪ 增强型CPU电源管理

▪ 动画Logo和声效

▪ 模块化内核架构

▪ 支持多种外围设备

▪ 安全的软件协议&接口

▪ 嵌入式控制器

▪ 远程管理

▪ 智能电池

▪ 安全特性

嵌入式OS

研华的嵌入式平台提供了自动以嵌入式OS镜像和被指配置实用程序,可帮助客户进行系统同整合。

Windows 嵌入式 OS

在嵌入式市场中,Windows Embedded OS凭借着易于编程和维护的特性而备受推崇。我们的微软最有价值(MVP)专家可为

您提供以下服务:

▪ Windows XP Embedded镜像(WES 2009、WES 7)

▪ Windows CE镜像(CE 4.2、5.0、6.0 R3)

▪ Windows XPe客制化服务

▪ 板卡支持包(BSP)服务

▪ 内置实用程序,便于配置启动logo、EWF保护、

FBWF保护等

Linux

Linux也在嵌入式市场越来越受欢迎。很多功能简单或复杂的设备都使用Linux作为操作系统。研华提供了3种Linux:

▪ General Linux发布:Ubuntu, Redhat, Fedora & SUSE

▪ Mini-Linux服务:迷你版,但是具有所有特性和图形UI

▪ Linux驱动更改和配置

▪ eSOS是存储于BIOS ROM内的紧急OS,可以电子邮

件形式发送错误通知

实时OS

QNX是一款超级可靠的OS,非常适合于生命关键系统,如气流控制系统、手术设备和核电站。Vxworks是另一款实时OS,用

于航空与国防设备、汽车信息远程处理设备、以及小尺寸消费者设备和工业设备。

▪ QNX & VxWorks评估镜像

▪ QNX & VxWorks板卡支持包(BSP)服务

嵌入式OS支持将因硬件平台不同而不同。

▪ 专业服务:我们提高了GPIO、WDT、SMBus、

I2C、HWM 和亮度驱动、以及 软件API

SOFTWARE INTEGRATION

强大的SUSIAccess & iManager软件支持

SUSIAccess用于远程设备管理

SUSIAccess软件应用已经预先加载于MI/O 嵌入式单板,可对嵌入式设备进行集中监控和管理。通过所提供的即用型远程访问解决方

案,系统集成商可以更多的聚焦于自己的应用并使用SUSIAccess配置系统、监控设备状态以及故障时恢复系统。

SUSIAccess的优势

▪ 远程监控多个设备

▪ 定期电源管理

▪ 防止系统受到潜在威胁

▪ 可在远程桌面访问系统

▪ 降低嵌入式系统部署的复杂度

▪ 节省开发时间和资源

▪ 提高系统可靠性

▪ 降低售后服务成本

Revenue Simplication Productivity

智能自我管理 - iManager

MI/O Compact系列所有产品都支持iManager。iManager是一种智能自管理跨平台工具,能够监测系统状态问题,并

在发生异常时采取措施;还能够保证在苛刻低温环境下正常启动,出现压降时系统可自动恢复。iManager使整个系统变

得更为可靠和智能。

可靠性得到提高

多级看门狗定时器保护、动态散热&

风扇控制

整合更简单

性能更卓越,API可支持跨平台整合

系统更安全

实时监控&响应、加密用户EEPROM数

据存储

*Available in all MI/O-Compact SBC series.

10

New Product Concept

MI/O Extension机箱

研华为MI/O SBC和MIOe模块提高了系统解决方案。设计理念和乐高(LEGO)积木很相似。系统集成商只需选择合适的散热解决方

案、MI/O SBC、MIOe模块,然后按照从上到下的顺序依次将其组装至MI/O Extension机箱。机箱内的灵活I/O支架可插接各种

模块,因此系统集成更快速、更便捷、更节约成本。

优化散热设计

散热效果最大化

支持Intel Atom ~ Core 平台

丰富的I/O扩展

模块化设计易于配置

可快速选择单板电脑和I/O模块

设计自己的MI/O Extension机箱

根据特定应用需求选择适合的MI/O Extension SBC和MIOe模块。

节约空间、无风扇设计

尺寸(290 x 143 x 73 mm)

外观优美

11

特点:

快速客制化

Logo

I/O支架

模块

高度集成系统

HDD/SSD/mSATA抗振设计

支持商业级内存

支持Windows/Linux/RTOS

无线连接

更加灵活

MI/O机箱兼容所有的MI/O-Compact (3.5")系列嵌入式单板和不同MIOe模块。系统集成商可根据不同的应用和性能需求更换SBC和

模块。由于MI/O SBC采用了统一的接口,因此上层的I/O支架都非常相似。而底部的I/O支架则因模块不同而不同,随意机箱可重复

使用。

更多功能

可通过更换MI/Oe模块使系统满足各种需求。客户不仅可以选择研华既成的MI/Oe模块,还可以设计自己的MIOe模块,时间和成本

实现最低化。

开发成本更低

MI/O机箱灵活度高,系统集成商只需通过更换MI/Oe模块,即可满足各种功能要求。即使需要开发新模块,也因为MI/Oe接口的灵

活性而变得很简单。

开发时间更短

MI/O机箱和MI/Oe接口的灵活性造就了业内最短的开发时间。下面以开发一款新模块为例:使用MI/O后,系统集成商完成自己的模

块设计所需的平均时间仅为3个月。

易于组装

MI/O机箱和MI/O SBC及MIOe模块的组装非常简单。我们已经简化了机械设计,因此降低了复杂度,可以极大地节约系统集成

商的时间。

配套的外围设备

为了构建总体解决方案,研华还提供了完整的外围产品系列,如flash、内存、无线模块和显示器。所有外围设备都采用了工业级标准,

都能够在恶劣环境中工作。

SQFlash

▪ 3年使用寿命和质保

▪ 工业品质和服务

▪ 全方位产品供应

SQRAM

▪ 宽温:-40~85℃

▪ DDR/DDR2/DDR3

SO-DIMM & U-DIMM

▪ 30u涂层

Wireless

▪ 7年生命周期支持

▪ WiFi/蓝牙, 3G和GPS模块

▪ 标准温度0~60℃和

宽温-40~85℃

Display

▪ 5.7" ~ 55" 尺寸选择

▪ LVDS、VGA、DVI、HDMI接口

▪ 标准温度0~50℃和

宽温-20~70℃

*

客制化支架和丝印油墨根据客户订单量进行提供。

12

CASE STUDY

适合于CNC设备的经济型I/O SBC

简介

在中国的嵌入式垂直市场中,CNC(电脑数控)应用在激光切割和铣床中

使用很普遍。CNC设备的核心通常由单板电脑进行控制。由于恶劣工作环

境(如灰尘和振动)的关系,CNC设备以往都采用的是带有PC/104接口的

SBC,可在母板上支持ISA或PCI接口,然后根据应用需要连接其它板卡。

13

应用要求

CNC设备一般采用层叠设计,可有效防止灰尘以及工作中收到震动的冲击。另外,CNC设备也要求经济高效的模块化解决方案。因

此,客户在寻求一种经济型的坚固式SBC,且要求多I/O易于扩展。传统的PC/104和COM办卡不能满足客户要求是因为前者的I/O

支持太有限,后者的价格太高。

系统解决方案

研华Pico-ITX MIO-2261办卡因为多I/O和坚固式设计而入选。研华MIO系列主要定位于PC/104和COM之间的市场,并且在价格和

灵活性指尖找到了最佳平衡点。MIO-2261不仅具有多I/O,而且还配有创新型MIOe接口,包括2 PCIe x1、USB 2.0、LPC、HD音

频线路输出、SMBus和电源接口。客户使用MIO-2261板卡上的MIOe接口设计了带有LVDS、3 x USB接口和SATA接口的扩展卡。

优势

▪ 节约了模块开发成本和时间

▪ 坚固式设计适合于高振动环境

▪ 通过MIOe接口实现最大化扩展

mSATA

SATA

Gigabit

Ethernet

Motion Control Card

MIO-2261

MIOe-120

HDMI

USB

NEW DESIGN

适用于地铁系统的规格创新型产品

简介

随着城市人口的增长,城市规模也在不断扩大,大众快速交通系统在公共

交通中起着至关重要的作用。大众快速交通系统每天可承载数百万乘客,

不仅安全、快速,而且可以有效缓解道路交通压力、减少污染。为了保证

系统能够可靠运行,必须将无法预见的事件的发生概率降至最低。因此,

维持系统安全可靠的运行是整个项目最重大的挑战。

应用要求

为了提供可靠的不间断的服务,地铁系统需要克服温度波动、电压峰值以及环境恶劣等问题。列车内的的车载设备尤其需要配备智能

控制功能,以处理意外事件或关键情形事件。如果发生故障,系统能够在最短的时间内自动恢复或者通过远程恢复。

系统解决方案

Advantech新规格SBC:MIO-5270属于MI/O-Compact系列,基于AMD Embedded G系列平台,配有研华开发的智能管理工具 iManager。iManager设计有智能风扇实用程序,系统的稳定性得到很大提高,并能够节约更多能源、减少噪声。iManager还配有

硬件监控工具,能够将信息作为事件触发或数据日志,也易于整合至应用中或通过远程控制程序访问。iManager还支持高级看门狗

定时器,可以修正或复位系统。最后,研华MIOe-220与MIO-5270进行整合后,可提供更多扩展 I/O,从而满足应用需求。

优势

▪ Compact SBC (146 x 102mm),通过MIOe扩展接口提供最大的灵活性

▪ 智能管理工具 – iManager可增强系统可靠性

▪ 根据温度自动调节风扇速度

▪ 通过本地应用或远程访问实时监控系统状态

▪ 坚固设计能够满足宽温和振动要求

14

58

MIO-9290

Intel

®

3

rd

Core™ i7/i5/i3 rPGA988, 5.25" MI/O SBC,

DDR3/DDR3L, DP, HDMI, DVI-I, 48-bit LVDS, 2GbE,

4 USB3.0, 2 Mini PCIe, mSATA, iManager, MIOe

NEW

DC Power

DDR3 SODIMM

CPU FAN

Reset

Power switch

System FAN

COM1/2

COM5/6 COM3/4

Audio

特点

ƒ

支持Intel第三代Core i7/i5/i3移动处理器(rPGA),带Intel QM77

PCH、2 x 高达16 GB DDR3/DDR3L SODIMM支持

ƒ

DirectX11,OpenGL3.1,OpenCL1.1,3种独立显示:MIOe满足垂直

应用并保留专业技术优势

ƒ

2 GbE支持,高清音频,丰富I/O接口:4 x COM、2 x

SATA、SMBUS/I2C、16-bit GPIO、2 x 全长Mini PCIe/mSATA、2 x

USB 2.0、4 x USB 3.0

ƒ

支持iManager、SUSIAccess、嵌入式软件 API & Intel iAMT 8.0

48-bit LVDS

SMBus

GbE 1 & 2

Software APIs:

Power Button

Reset Button DisplayPort

Throttling Alarm/

HDD LED

DVI-I

HDMI

USB2.0/3.0

Inverter

Utilities:

GPIO H/W

Monitor

Brightness Watchdog Backlight

On/Off

SMBus/

I

2

C

CPU Speed System

Throttling

Monitoring

规格

处理器系统

内存

显示

以太网

Audio

看门狗定时器

Storage

外部I/O

内部I/O

扩展

电源

环境

物理特性

CPU

Frequency

L3 Cache

System Chipset

BIOS

技术

最大容量

插槽

控制器

图形引擎

DisplayPort

LVDS

HDMI

DVI-I

3 Independent Display

速度

控制器

连接器

Chipset

SATAIII mSATA

以太网

显示接口

DVI-I

HDMI

USB 3.0

LED

Power Button

Reset Button

USB

LVDS/Inverter

Serial

I

2

C

SMBus

GPIO

Mini PCIe

MIOe

电源类型

电源电压

功耗 (Typical)

功耗 (Max, test in HCT)

电源管理

电池

工作

非工作

尺寸 (L x W)

Weight

Intel Core i7-3610QE

2.3 GHz (Quad Core)

Intel Core i5 3610ME

2.7 GHz (Dual Core)

Intel Core i3 3120ME

2.4 GHz (Dual Core)

6 MB

Intel QM77

3 MB

AMI EFI 64Mbit

Dual Channel DDR3 1600 MHz, DDR3L 1333 MHz

3 MB

8GB x 2

2 x 204-pin SODIMM

Intel Ivy Bridge Processor + Intel QM77 Integrated GFX Gen 7

DirectX11, OpenGL 3.1, and OpenCL 11

Hardware decode acceleration: AVC/H.264, MPEG-2, VC-1

Max resolution up to 1920 x 1200 @ 60Hz

LVDS with 3.3V, 5V on LCD VDD power, 5V and 12V support on LVDS inverter

Dual channel 24-bit LVDS, max resolution up to 1920 x 1080 @ 60Hz

Supports HDMI 1.4 for HD Video playback

Max resolution up to 2560 x 1600 @ 60Hz

Max resolution up to 2560 x 1600 @ 60Hz

DP + HDMI + DVI-I

10/100/1000Mbps

GbE1 - Intel 82579LM, GbE2 - Intel I-210IT

2 RJ45 on 外部I/O

Realtek ALC892, High Definition Audio (HD), Line-in, Line out, Mic-in

255 levels timer 间隔, programmable by software

2 x Serial-ATA port, up to 6.0 Gb/s (600 MB/s)

2 (Supports mSATA or USB 接口 module or full size miniPCIe)

2 (10/100/1000Mbps)

1

1

1

4 (USB 3.0 compliant)

Red: Throttling alarm, Yellow: HDD

1

1

2 (USB 2.0 compliant)

1

2 RS-232 from COM1/2, 2 RS-232/422/485 from COM3/4 (ESD protection for RS-232: Air gap ±15kV,

Contact ±8kV)

RS-232 with Tx/Rx only from COM5/6 is optional by request

1 (Shares with SMBus pin)

1

16-bit general purpose input/output

2 x Full-size Mini PCIe (Supports mSATA)

SMBus, 2 USB2.0, LPC, 4 PCIe x 1, line out, 5 Vsb/12 Vsb power, Displayport

Single 12V DC power input

Supports single 12V input, ± 10% w/DDR3: TBD, w/DDR3L: TBD w/DDR3: TBD, w/DDR3L: TBD

ACPI

Lithium 3 V / 210 mAH

0 ~ 60° C (32 ~ 140° F) (工作湿度: 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C and 60° C @ 95% RH Non-Condensing

203 x 146 mm (8" x 5.75")

TBD, weight of total package

MIO-9290

结构图

DP eDP

Intel Ivy Bridge

Mobile rPGA

DDR3/DDR3L

SODIMM x2

DVI-I

48-bit LVDS

HDMI

MiniPCIe or mSATA

(Full size)

MiniPCIe or mSATA

(Full size)

With SIM holder

16-bit GPIO

64Mbit SPI BIOS

4 USB 3.0

2 USB 2.0

2 x SATA III

Display port

VGA

Display port

PCIe x1, SATAII x1

USB 2.0 x1

PCIe x1, SATAII x1

USB 2.0 x1

PCA9555

SMBus

SPI

XHCI

EHCI

SATA III

Intel QM77

Panther Point

Mobile PCH

Display port

HD Audio, Line Out

USB 2.0 x 2

SMBus

LPC

4 PCIe x 1

MIOe

HD Audio

PCIe x 1

PCIe x 1

LPC

Realtek ALC 892

PHY: Intel

82579LM

GbE: Intel

I-210

Super I/O

SCH3106

Advantech iManager

Line -in

Line out

Mic-in

RJ45

RJ45

COM1/2: RS232

COM3/4: RS232/422/485

Auto Flow Control

SMBus/I

2

C

订货信息

料号 CPU Memory DP

MIO-9290F-

00A1E

插槽 rPGA988*

SO-DIMM Yes

* Full-size Mini PCIe supports mSATA

* Active = with fan

* Reserve Sandy Bridge CPU design

LVDS DVI-I HDMI

48-bit Yes Yes

GbE

2

HD

Audio

Yes

RS-422/485

2

RS-232

4

USB

3.0

4

USB

2.0

2

SATAIII

2

Full-size

Mini PCIe*

1

MIOe

Yes

Power 连

接器

2x2 pin

Thermal

Solution*

Active

Operation

Temp.

0 ~ 60° C

装箱单

料号

1700006291

1700018785

描述

MIO-9290 SBC

Startup Manual

M Cable SATA 7P/SATA 7P 30cm C=R 180/90

SATA 35cm power cable

COM RS-232 Cable 2*10P-2.0/D-SUB 9P (M)*2

1701200220

22CM

1700019584

9666929000E

Audio Cable 2*5P-2.0/JACK*3 20cm mini Jumper pack

1960054541N011 MIO-9290 cooler

后部I/O视图

2

1

1

1

1

1

1

数量

1

可选配件

料号

1700006291

1700018785

1703100260

1910002088

96MPI3M-2.4-

3M9T

96MPI5-2.7-

3M9T

96MPI7M-2.3-

6M9T

描述

SATA cable 7P/ 7P 30cm C=R 180/90

SATA 35cm power cable

Internal USB cable

The Post Standoff, F= M3*6L, M=M3*5L,

B=5, H=16 Ni

CPU i3-3120ME 2.4G 3M Dual Core

CPU i5-3610ME 2.7G 3M Dual Core

CPU i7-3610QE 2.3G 6M Quad Core

Embedded OS/API

Embedded OS/API

描述

Win XPE

WES7

WES2009

WES7E MIO-9290 ENG

WE8S

Linux

Software API

WE8S MIO-9290 ENG

CentOS iManager 2.0

在线下载 www.advantech.com.cn/products

59

60

规格

处理器系统

内存

显示

以太网

Audio

看门狗定时器

存储

外部 I/O

内部 I/O

扩展

电源

环境

物理特性

MIO-2260

NEW

Intel® Atom™ N455 MI/O-Ultra SBC,

DDR3, 18-bitLVDS, VGA ,1 GbE, Mini PCIe,

2 USB, 2 COM, MIOe

特点

ƒ

采用Intel Atom N455+ICH8M处理平台,支持DDR3内存

ƒ

Intel Gen3.5 DX9,支持MPEG2硬件解码,

双独立显示:18位LVDS+VGA

ƒ

支持12V +/_10% DC 电源输入,支持电源热拔插

ƒ

1*Giga LAN/2*COM/1*SATA/2*USB/GPIO/SMBus/CF/

MIOe 扩展接口

ƒ

支持嵌入式软件API & 开发工具

Software APIs:

GPIO H/W

Monitor

Brightness Watchdog Backlight

On/Off

SMBus CPU Speed System

Throttling

Utilities:

Monitoring eSOS Embedded

Security ID

CPU

Frequency

二级缓存

芯片组

BIOS

技术

最大容量

插槽

芯片组

VRAM

图形引擎

LVDS

VGA

双显

速度

控制器

连接器

芯片组

Compact Flash

SATA

Seriel

以太网

VGA

USB

DC Power

Seriel

I 2 C

SMBUS

GPIO

Mini PCI Express

MIOe

电源类型

电源电压

外围设备电压总输出

功耗 (Typical)

功耗

(Max, test in HCT)

电源管理

电池

Operational

非工作

尺寸 (L x W)

总高

重量

Intel Atom N455 Single Core 1.66 GHz Processor

1.66 GHz

512 KB

Intel N455 + ICH8M

AMI 16 Mbit Flash BIOS

DDR3 667 MHz

2 GB

1 x 204-pin SODIMM

Intel Atom Processor N455 1.66GHz

Optimized Shared Memory Architecture up to 224 MB system memory

Intel Gen 3.5 DX9, MPEG2 Decode in HW

Embedded Gen3.5+ GFX Core

LVDS: Single channel 18-bit LVDS up to WXGA 1366 x 768

Intel Atom N455 Single Core up to 1400 x 1050 (SXGA)

VGA+LVDS

10/100/1000 Mbps (Supports Wake on LAN)

GbE1 Intel 82567V

RJ45

Realtek ALC892

High Definition Audio (HD), Line-in, Line out

输出 System reset, Programmable counter from 1 ~ 255 minutes/ seconds

Supports CompactFlach Card TYPE II (Primary Master IDE Channel)

1 SATA II (最大数据传输数率 Rate 300 MB/s)

-

1 (10/100/1000Mbps)

1

2

1 (support by request)

2 x RS-232 (ESD protection for RS-232: Air gap ±15kV, Contact ±8kV)

1 (Share SMBus pin , support by request)

1

8-bit GPIO

1 (half size)

1 (SMbus,3 x USB2.0, 4 x PCIe,line out, LPC, 5V/12V power,ACPI S3/S5)

AT (Supports DC power hot plug design)

Support single 12V input (12V+/- 10%)

[email protected] for all devices , [email protected] for MIOe

0.64A, 12V

0.86A, 12V

APM, ACPI

Lithium 3 V/210 mAH

0 ~ 60° C (32 ~ 140° F) (工作湿度: 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C and 60° C @ 95% RH Non-Condensing

100 x 72 mm (3.9” x 2.8”)

33.48 mm

0.42kg(0.93lb), weight of total package

MIO-2260

订货信息

料号 CPU

MIO-2260NF-S6A1E Intel Atom N455 1.66 GHz

L2

Cache

LVDS VGA GbE Audio RS-232 USB

512 KB 18-bit Yes 1 Yes 2 2

GPIO SATAII CF

8-bit 1 1

MIOe mini

1 1 (half size) -

DC power jack

Thermal

Solution

Operational

Temp.

Passive 0 ~ 60° C

装箱单

料号

1700006291

1701200220

1700019156

1700019656

9666226000E

描述

MIO-2260 SBC

Startup Manual

Utility CD

SATA Cable

RS-232 x 2 ports 2.0 mm pitch 22 cm

Audio cable 2.0 mm pitch 20 cm

(line in & line out)

SATA power cable 5P-1.25/

5P-2.0+SATA 5P 15cm

Audio cable 2.0mm pitch 20cm

(line in & line out)

1960053175T001 Passive heatsink 99.5 x 70.5 x 15.7 mm

数量

1

1

1

1

1

可选配件

料号

1960053176T001

描述

Heat spreader

Embedded OS/API

Embedded OS/API

料号

Win XPE

描述

2070010314 XPE WES2009 V4.0 24MUI

WinCE

WES 7

QNX

2070010313 XPE WES2009 V4.0 ENG

2070010331 CE6.0 R3 Pro V6.0.0 ENG (3COM)

2070009835 Image WES7E Intel Lunar V5.0 ENG

V6.5/ 6.4/ 6.3

Vxwork

Linux

Software API

V6.8

Ubuntu V10.04

SUSI V3.0

在线下载 www.advantech.com.cn/products

61

62

规格

处理器系统

内存

显示

以太网

Audio

看门狗定时器

存储

外部I/O

内部I/O

扩展

MIO-2261

NEW

VGA

Power button/

HDD LED/

Power LED

HD Audio

(Line-in, Line-out)

2x RS-232

Intel

®

Atom™ N2600/ N2800 Pico-ITX SBC, DDR3,

18/24-bit LVDS, VGA, 1 GbE, Half-size Mini PCIe,

4 USB, 2 COM, SMBus, I

2

C, mSATA & MIOe

18/24-bit LVDS

特点

ƒ

嵌入式Intel Atom 双核N2600/N2800处理器 + Intel NM10,

1x 高达4 GB的DDR3内存

ƒ

DirectX 9,双独立显示:18/24-bit LVDS + VGA

ƒ

采用集成多I/O的灵活设计:MIOe满足垂直应用并保留专业技

术优势

ƒ

Intel GbE支持,丰富I/O接口:2 x COM、1 x SATA、4 x USB

2.0、GPIO、SMBus、mSATA和MIOe扩展接口

ƒ

支持SUSIAccess和嵌入式软件 API

Software APIs:

GPIO H/W

Monitor

Brightness Watchdog

Backlight

On/Off

SMBus

& I 2 C

CPU Speed System

Throttling

Utilities:

BIOS Flash Monitoring

电源

环境

物理特性

CPU

频率

二级缓存

系统芯片组

BIOS

技术

最大容量

插槽

芯片组

图形引擎

LVDS

VGA

双显

速度

控制器

连接器

速度 mSATA

SATA

以太网

VGA

USB

DC 电源接口

USB

Serial

I

2

C

SMBus

GPIO

Mini PCI Express

MIOe

电源类型

电源电压

外围设备电压总输出

功耗 (Typical)

功耗 (Max, test in HCT)

电源管理

电池

工作

非工作

尺寸 (L x W)

重量

总重

Intel Atom Dual Core N2600 1.6 GHz/ N2800 1.86 GHz

Dual Core 1.6 GHz/ 1.86 GHz

1 MB

Intel Atom N2600/ N2800 + Intel NM10

AMI EFI 16 Mbit

DDR3 800 MHz (N2600), DDR3 1066 MHz (N2800)

4 GB

1 x 204-pin SODIMM

Intel Atom N2600/ N2800

DirectX 9 and OpenGL3.0 support

H/W Decode/Acceleration: H.264, VC1, MPEG2

18/24-bit LVDS1: up to 1366 x 768

Up to 1920 x 1200

VGA+LVDS

10/100/1000Mbps

GbE1 Intel 82583V 10/100/1000Mbps

RJ45

Realtek ALC892, High De fi nition Audio (HD), Line-in, Line out output System reset, Programmable counter from 1 ~ 255 minutes/ seconds

1 (Integrates USB signal, supports either mSATA or USB 接口 module)

1 x SATA II (Max. Data Transfer Rate 300 MB/s)

1 (10/100/1000 Mbps)

1

2 x USB 2.0

1 (supported by request)

2 x USB 2.0

2 x RS-232(ESD protection for RS-232: Air gap ±15kV, Contact ±8kV)

1 (Shares with SMBus pin, supported by request)

1 (Shares with I

2

C, default support SMBus)

8-bit general purpose input/output

1 (half size)

MIOe (2 x USB 2.0, 2 x PCIe x1, LPC, HD Audio line-out,SMBus, DP or HDMI supported by request,

5 Vsb/12 Vsb power)

Single 12V DC power input (Supports DC power hot plug)

Supports single 12V input, ± 10%

5V @ 3A for CPU board and MIOe module totally, 12V @ 2A for MIOe module

N2600: 0.35 A @ 12 V (4.2 W)

N2800: 0.46 [email protected] 12 V (5.52 W)

N2600: 0.76 A @ 12 V (9.12 W)

N2800: 0.80 A @ 12 V (9.6 W)

APM, ACPI, wake on LAN

3 V / 210 mAH

0 ~ 60° C (32 ~ 140° F) (工作湿度: 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C and 60° C @ 95% RH non-condensing

100 x 72 mm (3.9" x 2.8")

0.42 kg (0.93 lb), weight of total package

33.65 mm

结构图

DDR3 800/1066

SO-DIMM up to 4GB

VGA DB15

18/24-bit LVDS

Single Channel

VGA

18/24-bit

Intel Atom

N2600 (1.6 GHz)

N2800 (1.86 GHz)

DP or HDMI

HDMI supported by request

Half-size Mini PCIe

Full-size mSATA

1 x SATAII

4 x USB2.0

16Mbit BIOS

ALC-892

PCIe x 1

USB

SATAII 300MB/s

USB

SATA 300MB/s

USB 2.0

SPI

HD Audio

Intel NM10

17x17 mm

SMBus

USB 2.0 x 2

HD Audio Line-out

2 PCIe x 1

LPC

PCIe x 1

MIOe

Intel 82583V GbE

SMBus/I 2

MIO-2261

Line-in

Line-out

8-bit GPIO

Watchdog Timer

SMSC

SCH3114

2 RS-232

订货信息

料号

MIO-2261N-S6A1E

MIO-2261N-S8A1E

MIO-2261Z-

2GS6A1E

MIO-2261Z2-

2GS6A1E

MIO-2261Z2-

2GS8A1E

CPU

Intel Atom

N2600 1.6G

Intel Atom

N2800 1.86G

Intel Atom

N2600 1.6G

Intel Atom

N2600 1.6G

Intel Atom

N2800 1.86G

L2

Cache

Memory LVDS

1MB L2 SO-SIMM 18/24-

1MB L2 SO-SIMM 18/24-

1MB L2

1MB L2

1MB L2

2GB bundle

2GB bundle

2GB bundle

18/24bit

18/24bit

18/24bit

Note: Passive = fanless; Active = with fan

装箱单

料号

1700006291

1700019656

1701200220

1700019156

1700002172

1700019705

9666226000E

1960055792T001

描述

MIO-2261 SBC

Startup Manual

Utility CD

SATA Cable 30cm

SATA power cable 5P-1.25/5P-2.0+SATA 5P

15 cm

RS-232 x 2 ports 2.0 mm pitch 22 cm

Audio cable 2.0 mm pitch 20 cm

(line in & line out)

USB cable 2.0mm pitch USB-A(F) 17cm

AT Power cable 12cm

Screw and stud pack (1 screw for Mini PCIe,

4 M3 studs and screws for heatsink)

CPU N2600/N2800 heatsink

(99.5 x 70.5 x 15.7mm) for MIO-2261N

1

1

1

1

1

1

1

1

Yes

Yes

Yes

HD

Audio VGA

Yes Yes

Yes Yes

Quantity

Yes

Yes

Yes

4

4

4

4

4

2

2

2

2

2

可选配件

料号

1960055791T001

Yes

Yes

Yes

Yes

Yes

1

1

1

1

1

Yes

Yes

Yes

Yes

Yes

Halfsize

Halfsize

Halfsize

Halfsize

Halfsize

Thermal

Solution

Passive

Passive

Operational

Temp

0 ~ 60° C

0 ~ 60° C

Passive

Passive

Passive

-20 ~ 80° C

-40 ~ 85° C

-40 ~ 85° C

描述

MIO-2261 Heat spreader (99.5 x 70.5 x 15.7mm)

Embedded OS/API

Embedded OS/API

WinCE 7.0

Win XPE

2070011283

Linux

Software API

描述

CE 7.0

WES 2009

WES7E SP1 x32 MIO-2261 V5.1 ENG

Ubuntu 12.04

SUSI V3.0

后部I/O视图

MIO-2261N-S6A1E

MIO-2261N-S8A1E

MIO-2261 w/ DC jack (by request)

在线下载 www.advantech.com.cn/products

63

64

MIO-2262

NEW

DDR3 SO-DIMM 插槽

Intel

®

Atom™ N2600/ N2800 Pico-ITX SBC, DDR3,

18/24-bit LVDS, VGA, 1 GbE, Full-size Mini PCIe,

4 USB, 2 COM, SMBus, I

2

C, mSATA & MIOe

18/24-bit LVDS

特点

ƒ

嵌入式Intel Atom 双核N2600/N2800处理器 +

ƒ

Intel NM10, 1x 高达4 GB的DDR3内存

ƒ

DirectX 9,双独立显示:18/24-bit LVDS + VGA

ƒ

采用集成多I/O的灵活设计:MIOe满足垂直应用并保留专业

技术优势

ƒ

Intel GbE支持,丰富I/O接口:2 x COM、1 x SATA、4 x

USB 2.0、GPIO、SMBus、mSATA和MIOe扩展接口

ƒ

支持SUSIAccess和嵌入式软件 API

Software APIs:

GPIO H/W

Monitor

Brightness Watchdog Backlight

On/Off

SMBus

& I

2

C

Utilities:

BIOS Flash Monitoring

规格

处理器系统

内存

显示

以太网

Audio

看门狗定时器

存储

扩展

电源

环境

物理特性

CPU

Frequency

L2 Cache

System Chipset

BIOS

技术

最大容量

插槽

Chipset

图形引擎

LVDS

VGA

双显

Speed

控制器

Chipset mSATA

SATA

Mini PCI Express

MIOe

64pin connecter A

64pin connecter B

电源类型

电源电压

外围设备电压总输出

功耗 (Typical)

功耗 (Max, test in HCT)

电源管理

电池

工作

非工作

尺寸 (L x W)

重量

总重

Intel Atom Dual Core N2600 1.6 GHz/ N2800 1.86 GHz

Dual Core 1.6 GHz/ 1.86 GHz

1 MB

Intel Atom N2600/ N2800 + Intel NM10

AMI EFI 16 Mbit

DDR3 800 MHz (N2600), DDR3 1066 MHz (N2800)

4 GB

1 x 204-pin SODIMM

Intel Atom N2600/ N2800

DirectX 9 and OpenGL3.0 support

H/W Decode/Acceleration: H.264, VC1, MPEG2

18/24-bit LVDS1: up to 1366 x 768

Up to 1920 x 1200

VGA+LVDS

10/100/1000Mbps

GbE1 Intel 82583V

Realtek ALC892, High De fi nition Audio (HD), Line-in, Line out

输出 System reset, Programmable counter from 1 ~ 255 minutes/ seconds

1 (Supports mSATA or USB 接口 module or full size miniPCIe, selected by BIOS, defaulf is mSATA)

1 x SATA II (Max. Data Transfer Rate 300 MB/s)

1 x Full-size Mini PCIe (Supports mSATA, selected by BIOS)

MIOe (3 x USB 2.0, 2 x PCIe x1, LPC, HD Audio line-out, SMBus, DP or HDMI supported by request,

5 Vsb/12 Vsb Power 输出)

12V DC input, Inverter, VGA, 2 x USB2.0, 1GbE w/ LED

SMBus, I

2

C, Power/Reset button, HDD/Power LED, 2 x USB2.0, 8-bit GPIO, HD Audio

Line in/out,

2 x RS-232

Single 12V DC power input

Supports single 12V input, ± 10%

5V @ 3A for CPU board and MIOe module totally, 12V @ 2A for MIOe module

N2600: 0.43 A @ 12 V (5.24 W)

N2800: 0.51 [email protected] 12 V (6.12 W)

N2600: 0.67 A @ 12 V (8.05 W)

N2800: 0.82 A @ 12 V (9.8 W)

APM, ACPI, wake on LAN

3 V / 210 mAH

0 ~ 60° C (32 ~ 140° F) (工作湿度: 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C and 60° C @ 95% RH non-condensing

100 x 72 mm (3.9" x 2.8")

0.37 kg (0. 82 lb), weight of total package

Top Side: 12.75 mm; Bottom Side: 9.0 mm

MIO-2262

结构图

DDR3 1067

SO-DIMM up to 4GB

18/24-bit LVDS

VGA

Single Channel

18/24-bit LVDS

Intel Atom

CedarviewM

N2600 (1.6 GHz)

N2800(1.86 GHz)

22 x 22 mm

DP or HDMI

HDMI supported by request

2 x USB 2.0

GbE w/ LED

Intel

82583V GbE

PCIe x 1

Line in/out

ALC-892

SMbus

2 x USB 2.0

I 2 C

HD Audio

Intel NM10

17 x 17 mm

SMBUS

USB 2.0x3

HD Audio Line-out

2 PCIex1

LPC

SPI

PCIe x 1

SATAII 300MB/s

USB

SATA 300MB/s

(3 x USB 2.0, 2 x PCIe x1, LPC, HD Audio line-out, SMBus, DP or HDMI supported by request, 5 Vsb/12 Vsb output)

16Mbit BIOS

Full-size

Mini PCIe

SATAII

8-bit GPIO

2 x RS-232

SMSC SCH3114

Watchdog Timer

订货信息

料号 CPU L2 Cache Memory LVDS

MIO-2262N-S6A1E

MIO-2262N-S8A1E

Intel Atom

N2600

1.6G

Intel Atom

N2800

1.86G

1MB L2

1MB L2

* Full-size Mini PCIe supports mSATA

Note: Passive = fanless; Active = with fan

装箱单

SO-

SIMM

SO-

SIMM

料号

1700006291

9666226200E

1960055792T001

18/24bit

18/24bit

描述

MIO-2262 SBC

Startup Manual

M Cable SATA 7P/SATA 7P 30cm C=R 180/90

Screw and stud pack (2 screw for Mini PCIe,

4 M3 studs and screws for heatsink)

Heatsink (99.5 x 70.5 x 15.7 mm)

VGA

Yes

Yes

数量

1

1

1

DP/

HDMI

Yes

Yes

GbE

1

1

底面视图

MIOe

64P 连接器 A mSATA or Mini PCIe

HD

Audio

USB2.0

RS-232 SATAII PCIe x1 Mini PCIe*

Yes

Yes

7

7

2

2

1

1

2

2

Full-size

Full-size

Thermal

Solution

Passive

Passive

Operational

Temp.

0 ~ 60° C

0 ~ 60° C

可选配件

料号 描述

1960055791T001 MIO-2261 Heat spreader (99.5 x 70.5 x 15.7mm)

MIOE-DB2000-00A1E MIO-2262 Evaluation Board

Embedded OS/API

Embedded OS/API

描述

2070011765

2070011766

WES7E 32bits EN/DE/JP/TC

WES7P 32bits EN/TC/SC/RU/FR/DE/ES/IT/JP/KR

WinCE 7.0

Win XPE

Linux

Software API

CE 7.0

WES 2009

Ubuntu 12.04

SUSI V3.0

SATA

64P 连接器 B

在线下载 www.advantech.com.cn/products

65

MIO-5250

NEW

DDR3 SODIMM

18/24 bit LVDS1

USB 1/2

Intel

®

Atom™ N2600/ D2550, 3.5" MI/O-

Compact SBC, DDR3, HDMI, Dual LVDS, VGA,

2 GbE, CFast, iManager, MIOe

RS-422/485

SATAII

SATA Power

FAN

LVDS1

Inverter

Reset

USB 3/4 HDMI

48 bit LVDS2

VGA

SMBUS

GbE1 GbE2

HD & PWR LED

Power Switch

LVDS2 Inverter

USB 5/6

8-bit GPIO

LVDS2 Power Select

(3.3V/5V/12V)

特点

Embedded Intel® Atom™ N2600/ D2550 双核处理器 + Intel

NM10, 1 x DDR3 内存,内存最高支持4 GB

DirectX® 9, 多显示: 18/24-bit LVDS1, 48-bit LVDS2, HDMI, VGA

灵活的集成多I/O设计

2个GbE网口,高清音频,丰富的I/O接口,包括4个COM端口,1个

SATA接口,I2C或SMBus, 8-bit GPIO, PCIe Mini Card & CFast

支持iManager,嵌入式软件API和实用工具

Software APIs:

DC Power

GPIO H/W

Monitor

Brightness Watchdog Backlight

On/Off

SMBus CPU Speed

Utilities:

Monitoring

规格

处理器系统

内存

显示

以太网

Audio

看门狗定时器

Storage

外部 I/O

内部 I/O

扩展

电源

环境

物理特性

CPU

Frequency

L2 Cache

System Chipset

BIOS

技术

最大容量

插槽

Chipset

图形引擎

LVDS

VGA

HDMI

双显

Speed

控制器

连接器

Chipset

Amplifier

CFast mSATA

SATA

Ethernet

VGA

HDMI

USB

LED

DC Jack

USB

Serial

I

2

C

SMBus

GPIO

Full-size MiniPCIe/ mSATA

MIOe

电源类型

电源电压

功耗

(Typical)

功耗

(Max, test in HCT)

电源管理

电池

Operational

非工作

尺寸 (L x W)

Weight

总重

Intel Atom Dual Core processor N2600 1.6GHz/ D2550 1.86GHz

Dual Core 1.6GHz/ 1.86GHz

1MB

Intel Atom N2600/ D2550 + Intel NM10

AMI EFI 16Mbit

DDR3 1066MHz (D2550), DDR3-800 (N2600)

4 GB

1 x 204-pin SODIMM

Intel Atom N2600/ D2550

DirectX 9 and OpenGL3.0 support

Hardware decode H/W acceleration: MPEG2

H/W Decode/Acceleration: H.264/ VC1/ WMV9

18/24-bit LVDS1: up to 1366 x 768 (N2600), 1440 x 900 (D2550)

48-bit LVDS2: 2560 x 1600 (only for MIO-5250D-S8A1E)

Up to 1920 x 1200

Supports 1920 x 1200, Max data rate: up to 1.65 Gb/s, Supports HDMI v1.3 Up to 1080p support

Yes (VGA + LVDS1 or VGA + HDMI or HDMI + LVDS1 or LVDS1 + LVDS2)

10/100/1000Mbps

GbE1: Intel 82583V 10/100/1000Mbps, GbE2: Intel 82583V 10/100/1000Mbps

2 RJ45 on 外部 I/O

Realtek ALC892, High Definition Audio (HD),Line-in, Line out, Mic-in

Optional via MIOe

255 levels timer 间隔 , programmable by software

1

(Supports either mSATA or full size miniPCIe, selected by BIOS, default support miniPCIe)

1 x SATA II (Max. Data Transfer Rate 300 MB/s)

2 (10/100/1000Mbps)

1

1

4 x USB 2.0

Power, HDD

1 (MIO-5250N-S6A1E)

2 x USB 2.0

2 RS-232 from COM1/4, 2 RS-232/422/485 support auto flow control from COM2/3

(ESD protection for RS-232: Air gap ±15kV, Contact ±8kV)

1 (Shares with SMBus pin)

1 (Shares with I

2

C pin)

8-bit general purpose input/output

1 with SIM Holder, supports mSATA via BIOS select

SMBus, 3 x USB2.0, LPC, 1 x PCIe, line out, 5 Vsb/12 Vsb power, ACPI S3/S5, Displayport (optional)

Single 12V DC power input

Supports single 12V input, ± 10%

MIO-5250N-S6A1E: 0.606 A @ 12 V (7.27 W)

MIO-5250D-S8A1E: 0.829 A @ 12 V (9.95 W)

MIO-5250N-S6A1E: 0.729 A @ 12 V (8.75 W)

MIO-5250D-S8A1E: 1.029 A @ 12 V (12.35 W)

ACPI

Lithium 3 V / 210 mAH

0 ~ 60° C (32 ~ 140° F) ( 工作湿度 : 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C and 60° C @ 95% RH Non-Condensing

146 x 102 mm (5.7" x 4"), same as 3.5"

0.78 kg (1.72 lb), weight of total package

30.6 mm

MIO-5250

结构图

DDR3

SODIMM x 1

Intel Atom

N2600 / D2550

DisplayPort 1

VGA I/F

DisplayPort 0

DMI

(note1)

Intel 82583V

Intel 82583V

COM1~COM4

(COM2/3: RS-232/422/485)

(COM1/4: RS-232)

Auto Flow Control

Full-size MiniPCIe w/ SIM Holder

16MBit

SPI BIOS

PCIe x 1

PCIe x 1

Super I/O

LPC

PCIe x 1

SPI

6 USB 2.0

SATAII

Intel NM10

1 x SATAII

HD audio line out

USB 2.0 x 1

SMBUS

LPC

1 PCIe x 1

Advantech iManager

HD

Realtek

ALC 892

Transmitter

18/24-bit LVDS1

VGA

HDMI

MIOe

48-bit LVDS2

CFast 8-bit GPIO SMBus/I

2

C note 1: Supported by request

订货信息

料号

MIO-5250N-S6A1E

MIO-5250D-S8A1E

MIO-5250NZ-

2GS6A1E

MIO-

5250NZ22GS6A1E

CPU

Intel Atom

N2600 1.6G

Intel Atom

D2550 1.86G

Intel Atom

N2600 1.6G

Intel Atom

N2600 1.6G

L2

Cache

1MB

1MB

1MB

1MB

Memory LVDS1 LVDS2

SO-DIMM 24-bit

SO-DIMM 24-bit

2GB bundle

2GB bundle

24-bit

24-bit

-

-

-

VGA &

HDMI

Yes

48-bit Yes

Yes

Yes

GbE Audio

2

2

2

2

Yes

Yes

Yes

Yes

RS-232/

422/485

2

2

2

2

RS-232 USB 2.0

2

2

2

2

6

6

6

6

SATAII CFast

1

1

1

1

1

1

1

1

Mini

PCIe

1

1

1

1

MIOe

Yes

Yes

Yes

Yes

Power 连

接器

DC Jack

2x2 type

DC Jack

DC Jack

Thermal

Solution

Passive

Passive

Passive

Passive

Operational

Temp.

0 ~ 60° C

0 ~ 60° C

-20 ~ 80° C

-40 ~ 85° C

Note: Passive = fanless; Active = with fan

Note: Wide 温度 range version has been bundled with verified industrial-grade memory module

装箱单

可选配件

料号

料号

1700008941

1700018785

1700019435

1701200220

1700019584

9689000002

1960054274T001

描述 数量

MIO-5250 SBC

Startup Manual

Utility CD

SATA cable 7P 32CM C=R 180/180D W/

Lock

SATA 35cm power cable

COM RS-485 D-SUB 9P (M)/1*5P 1.25 25cm

1

1 cable

COM RS232 Cable 2*10P-2.0/D-SUB 9P

2

(M)*2 22CM

Audio Cable 2*5P-2.0/JACK*3 20cm

2 mini Jumper pack

Heatsink 135 x 84.2 x 20 mm for MIO-5250 1

1

1

1960054269T001

1700006291

1703100260

1910002088

1757003082

描述

Heat spreader for MIO-5250 (137 x 84.2 x

16.7mm)

SATA2 cable 7P/ 7P 30cm C=R 180/90

USB5/6 cable

The Post Standoff, F= M3*6L, M=M3*5L, B=5,

H=16 Ni

Adaptor 100-240V 60W 12V 5A W/O PFC

Embedded OS/API

后部I/O视图

Embedded OS/API

描述

WinCE 7.0

Win XPE

2070011152

CE 7.0

WES 2009

WES7E SP1 x32 MIO-5250 V5.1 ENG

Linux

Software API

Ubuntu iManager 2.0

MIO-5250N-S6A1E MIO-5250D-S8A1E

在线下载 www.advantech.com.cn/products

67

68

MIO-5270

NEW

DDR3 SODIMM

AMD G-Series

USB 5/6

USB 1/2

SATA1

RS-422/485 SATA2

SATA Power Reset

Inverter

USB 3/4 HDMI

48 bit LVDS

VGA

SMBUS

GbE1 GbE2

HD & PWR LED

AMD ASOM

LVDS Power

Select

FAN

DC Power

Power Button

AMD

®

G- Series 3.5" MI/O-Compact SBC,

DDR3, HDMI, 48-bit LVDS, VGA, 2 GbE, CFast, iManager, MIOe

特点

ƒ

嵌入式AMD G系列单核/双核处理器 + AMD A50M FCH,

1x 高达4 GB的DDR3内存

ƒ

DirectX 11,2D/3D加速,多显示:48-bit

LVDS、HDMI、VGA

ƒ

采用集成多I/O的灵活设计:MIOe满足垂直应用并保留专业

技术优势

ƒ

2 GbE支持,高清音频,丰富I/O接口:4 x COM、2 x

SATA、6 x USB和GPIO

ƒ

支持iManager、SUSIAccess和嵌入式软件 API

Software APIs:

GPIO H/W

Monitor

Brightness Watchdog Backlight

On/Off

SMBus CPU Speed System

Throttling

Utilities:

Monitoring

规格

处理器系统

内存

显示

以太网

Audio

看门狗定时器

存储

外部 I/O

内部 I/O

扩展

电源

环境

物理特性

CPU

前端总线

二级缓存

芯片组

BIOS

技术

最大容量

插槽

Chipset

图形引擎

LVDS

VGA

HDMI eDP

双显

速度

控制器

连接器

芯片组

Amplifier

CFast mSATA

SATA

以太网

VGA

HDMI

USB

LED

DC Jack

USB

Serial

I 2 C

SMBus

GPIO

Full-size MiniPCIe

MIOe

电源类型

电源电压

功耗 (Typical)

功耗 (Max, test in HCT)

电源管理

电池

工作

非工作

尺寸 (L x W)

重量

总重

AMD G- Series, T40R 1.0GHz single core, T40E 1.0GHz dual core, T56N 1.65GHz dual core

1.0GHz single/dual core, 1.65GHz dual core

512 KB on T40R/ T40E, 1 MB on T56N

AMD G-Series + A50M FCH

AMI EFI 32Mbit

DDR3 1066 MHz, 1333MHz only for T56N

4 GB

1 x 204-pin SODIMM

AMD G- Series

DirectX

®

11 graphics with UVD 3.0

2D Acceleration, 3D Acceleration, Motion Video Acceleration, Supports DVD, Blu-ray*

Hardware decode (UVD 3):H.264, VC-1 & MPEG2

LVDS: Supports single channel 24-bit or dual channel 48-bit LVDS

T56N up to 2560 x 1600 @ 60 Hz, T40R & T40E up to 1920 x 1200 @ 60 Hz (pixel clock rate = 80 MHz)

T56N up to 2560 x 1600, T40R & T40E up to 1920 x 1200

Supports 1920 x 1080p at 60 Hz, 36 bpp, Supports HDMI v1.3, using TMDS data encoding

Option (supported by request)

T56N up to 2560 x 1600, T40R & T40E up to 1920 x 1200

Yes (VGA+LVDS or VGA + HDMI or HDMI + LVDS)

10/100/1000Mbps

GbE1: Realtek RTL8111E-VB-GR 10/100/1000Mbps, GbE2: Realtek RTL8111E-VB-GR 10/100/1000Mbps

2 RJ45 on 外部I/O

Realtek ALC892, High Definition Audio (HD),Line-in, Line out, Mic-in

Can be supported via MIOe

255 levels timer 间隔, programmable by software

1

(Supports either mSATA or full size miniPCIe, selected by BIOS, default support miniPCIe)

2 x SATA II (Max. Data Transfer Rate 300 MB/s)

2 (10/100/1000Mbps)

1

1

4 x USB 2.0

Power, HDD

1 (Supported only on MIO-5270S-S0A1E & MIO-5270D-S0A1E)

2 x USB 2.0

3 RS-232 from COM1/3/4, 1 RS-232/422/485 support auto flow control from COM2 (ESD protection for

RS-232: Air gap ±15kV, Contact ±8kV)

1 (Shares with SMBus pin)

1 (Shares with SMBus pin)

8-bit general purpose input/output

1

SMBus, 3 x USB2.0, LPC, 4 x PCIe, line out, 5 Vsb/12 Vsb power, ACPI S3/S5, Displayport (optional)

Single 12V DC power input

Supports single 12V input, ± 10%

MIO-5270S-S0A1E: 0.59 A @ 12 V (7.08 W)

MIO-5270D-S0A1E: 0.53 A @ 12 V (6.36 W)

MIO-5270D-S6A1E: 0.65 A @ 12 V (7.8 W)

MIO-5270S-S0A1E: 0.8 A @ 12 V (9.6 W)

MIO-5270D-S0A1E: 0.82 A @ 12 V (9.84 W)

MIO-5270D-S6A1E: 1.35 A @ 12 V (16.2 W)

ACPI

Lithium 3 V / 210 mAH

0 ~ 60° C (32 ~ 140° F) (工作湿度: 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C and 60° C @ 95% RH Non-Condensing

146 x 102 mm (5.7" x 4"), same as 3.5"

0.78 kg (1.72 lb), weight of total package

34.5 mm

MIO-5270

结构图

Display port

Realtek GbE1

RTL8111E-GR

Realtek GbE2

RTL8111E-GR

Full-size MiniPCIe

PCIe x 1

PCIe x 1

AMD G-Series

VGA I/F

COM1~COM4

(COM2: RS-232/422/485)

(COM1/3/4: RS-232)

Auto Flow Control

32MBit

SPI BIOS

6 USB 2.0

PCIe x 1

Super I/O

SPI

SATAII

CFast

LPC

2 x SATAII

UMI

AMD A50M FCH

Advantech iManager

SMBus/I 2 C 8-bit GPIO

Display port

(note 1)

HD audio line out

USB 2.0 x 3

SMBUS

LPC

4 PCIe x 1

HD

Realtek

ALC 892

Transmitter eDP

* with HDMI (DP) support

VGA

HDMI

MIOe

48-bit LVDS note 1: Supported by request

订货信息

料号

MIO-5270S-S0A1E

MIO-5270D-S0A1E

MIO-5270D-S6A1E

MIO-5270DZ-2GS0A1E

CPU

AMD T40R 1.0G SC

AMD T40E 1.0G DC

L2 Cache

512 KB

512 KB

AMD T56N 1.65G DC 1 MB

AMD T40E 1.0G DC

MIO-5270DZ22GS0A1E AMD T40E 1.0G DC

512 KB

512 KB

Memory

SO-DIMM

SO-DIMM

LVDS

VGA &

HDMI

48-bit Yes

48-bit Yes

SO-DIMM 48-bit Yes

2GB bundle 48-bit Yes

2GB bundle 48-bit Yes

GbE

2

2

2

2

2

Audio

Yes

Yes

Yes

Yes

Yes

1

1

1

RS-232/

422/485

1

1

RS-232

3

3

3

3

3

6

6

6

USB

2.0

6

6

SATAII

2

2

2

2

2

Note: Passive = fanless; Active = with fan

Note: Wide temperature range version has been bundled with industrial-grade memory module.

装箱单

可选配件

料号 描述

1700006291

1700018785

1700019435

MIO-5270 SBC

Startup Manual

Utility CD

SATA1 cable 7P/ 7P 30cm C=R 180/90

SATA Power Cable 35cm

COM1 RS-485 D-SUB 9P (M)/1*5P 1.25 25cm cable

COM RS232 Cable 2*10P-2.0/D-SUB 9P (M)*2

1701200220

1700019584

9689000002

22CM

Audio Cable 2*5P-2.0/ JACK*3 20cm mini Jumper pack

Heatsink (137 x 84 x 25 mm) for T40R/ T40E

1960053507N001 series

1960053508N001 Cooler (137 x 84 x 25 mm) for T56N series

数量

1

1

1

2

1

1

料号

1960054266T001

1700006291

1703100260

1910002088

1757003082

Embedded OS/API

2070010844

2070010845

Linux

Software API

CFast

1

1

1

1

1

Mini PCIe

1

1

1

1

1

Embedded OS/API

MIOe

Yes

Yes

Yes

Yes

Yes

Power 连

接器

DC Jack

DC Jack

Thermal

Solution

Passive

Passive

2x2 type Active

DC Jack Passive

DC Jack Passive

Operational

Temp.

0 ~ 60° C

0 ~ 60° C

0 ~ 60° C

-20 ~ 80° C

-40 ~ 85° C

描述

Heat spreader for MIO-5270 (137 x 84.2 x 16.7mm)

SATA2 cable 7P/ 7P 30cm C=R 180/90

USB5/6 cable

The Post Standoff, F= M3*6L, M=M3*5L, B=5, H=16 Ni

Adaptor 100-240V 60W 12V 5A W/O PFC

后部I/O视图

描述

XPE WES2009 MIO-5270 V4.0 24MUI

WES7E SP1 MIO-5270 V5.1 ENG

Ubuntu 12.04

iManager 2.0

MIO-5270S-S0A1E

MIO-5270D-S0A1E

MIO-5270D-S6A1E

在线下载 www.advantech.com.cn/products

69

70

MIO-5290

NEW

DDR3 SODIMM

Intel Core i Processor

RS422/485

SATAII

SATA Power

Audio

SMBus

Inverter

Reset

Intel

®

Core™ i7 / i3, 3.5" MI/O-Compact SBC,

DDR3/DDR3L, VGA, DP/HDMI, 48-bit LVDS, 2GbE,

2 x Mini PCIe, mSATA, iManager, MIOe

Power Switch

Intel QM77

2 *USB 2.0

System FAN

DC Power

USB 2.0 /USB 3.0

HDMI/

DisplayPort

VGA CPU FAN

48-bit LVDS GbE1 & 2

HDD & PWR LED

特点

ƒ

Intel Core i3和i7处理器 + Intel QM77 PCH, 1x 高达8 GB

DDR3/DDR3L SODIMM支持

ƒ

DirectX 9,双独立显示:18/24-bit LVDS + VGA

ƒ

采用集成多I/O的灵活设计:MIOe满足垂直应用并保留专业

技术优势

ƒ

2 GbE支持,高清音频,丰富I/O接口:2 x COM、2 x

SATA、SMBus、8-bit GPIO、半长Mini PCIe、全长Mini

PCIe和2 x USB 3.0

ƒ

支持iManager、SUSIAccess和嵌入式软件 API

Software APIs:

Utilities:

GPIO H/W

Monitor

Brightness Watchdog Backlight

On/Off

SMBus/

I 2 C

CPU Speed System

Throttling

Monitoring

规格

处理器系统

内存

显示

以太网

Audio

看门狗定时器

存储

外部 I/O

内部 I/O

扩展

电源

环境

物理特性

CPU

Frequency

L3 Cache

System Chipset

BIOS

技术

最大容量

插槽

控制器

图形引擎

VGA

LVDS

HDMI / DisplayPort

3 Independent Display

速度

控制器

连接器

Chipset

Amplifier

SATA

Ethernet

VGA

HDMI / DisplayPort

USB 2.0

USB 3.0

LED

DC Jack

USB

Serial

I 2 C

SMBus

GPIO

Mini PCIe

MIOe

电源类型

电源电压

功耗(Typical)

功耗(Max, test in HCT)

电源管理

电池

工作

非工作

尺寸 (L x W)

重量

高度

ULV Core i3 3217UE

1.6GHz (Dual Core)

3MB

Intel QM77

ULV Core i7 3517UE

1.7GHz (Dual Core)

4MB

AMI EFI 64Mbit

DDR3 1600MHz, DDR3L 1333 MHz

8 GB

1 x 204-pin SODIMM

Intel QM77 Integrated GFX Gen 7

DirectX11, OpenGL 3.1, and OpenCL 11

Hardware decpde acceleration: AVC/H.264, MPEG-2, VC-1

Integrated 340.4MHz RAMDAC, Max resolution up to 2048 x 1536 @ 75Hz

LV Core i7 3555LE

2.5GHz (Dual Core)

4MB

LVDS with 3.3V, 5V on LCD VDD power, 5V and 12V support on LVDS inverter

Dual channel 24-bit LVDS, max resolution up to 2560 x 1600 @ 60Hz

Supports HDMI 1.4 for HD Video playback

Max resolution up to 2560 x 1600 @ 60Hz on DisplayPort, Max resolution up to 1920 x 1200 @ 60Hz on HDMI

VGA + Displayport (coastline) + Displayport (MIOe) or LVDS + Displayport (coastline) + DisplayPort (MIOe)

10/100/1000Mbps

GbE1 - Intel 82579LM, GbE2 - Intel 82583V

2 RJ45 on 外部I/O

Realtek ALC892, High Definition Audio (HD), Line-in, Line out, Mic-in

Optional via MIOe

255 levels timer 间隔, programmable by software

1

1

2 x Serial-ATA port, up to 6.0 Gb/s (600 MB/s)

2 (10/100/1000Mbps)

2 x USB 2.0

2 x USB 3,0

Power, HDD

1 DC Jack 连接器 on MIO-5290U-S6A1E/MIO-5290U-S7A1E

2 x USB 2.0

RS-232 from COM1, RS-232/422/485 from COM2 with RS-485 auto flow control (ESD protection for RS-232: Air gap

±15kV, Contact ±8kV)

1 (Shares with SMBus pin)

1 (Shares with I

2

C pin)

8-bit general purpose input/output

1 x Full-size Mini PCIe (Supports mSATA)

1 x Half-size Mini PCIe

Displayport, SMBus, 1 x USB2.0, 1 x USB3.0, LPC, 4 x PCIe x1, line out, 5 Vsb/12 Vsb power, ACPI S3/S5

Single 12V DC power input

Supports single 12V input, ± 10%

MIO-5290U-S6A1E: w/DDR3: 1.615 A @ 12 V (19.38 W), w/DDR3L: 1.507 A @ 12 V (18.08 W)

MIO-5290U-S7A1E: w/DDR3: 2.023 A @ 12 V (24.28 W), w/DDR3L: 1.965 A @ 12 V (23.5 W)

MIO-5290L-U5A1E: w/DDR3: 2.356 A @ 12 V (28.27 W), w/DDR3L: 2.309 A @ 12 V (27.7 W)

MIO-5290U-S6A1E: w/DDR3: 2.024 A @ 12 V (24.29 W), w/DDR3L: 1.84 A @ 12 V (22.08 W)

MIO-5290U-S7A1E: w/DDR3: 2.412 A @ 12 V (28.94 W), w/DDR3L: 2.3 A @ 12 V (27.6 W)

MIO-5290L-U5A1E: w/DDR3: 2.896 A @ 12 V (34.75 W), w/DDR3L: 2.708 A @ 12 V (32.5 W)

ACPI

Lithium 3 V / 210 mAH

0 ~ 60° C (32 ~ 140° F) (工作湿度: 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C and 60° C @ 95% RH Non-Condensing

146 x 102 mm (5.7" x 4"), same as 3.5"

0.84 kg (1.72lb), weight of total package

Top Side: 37 mm (MIO-5290U series), 47.7 mm (MIO-5290L series); Bottom Side: 9 mm; PCB: 1.6mm

Intel

®

Core™ i7 / i3, 3.5" MI/O-Compact SBC,

DDR3/DDR3L, VGA, DP/HDMI, 48-bit LVDS, 2GbE,

2 x Mini PCIe, mSATA, iManager, MIOe

结构图

COM1: RS-232

COM2: RS-232/422/485

Auto Flow Control

DDR3/DDR3L

SODIMM x1

1600/1333MHz

Intel 82579LM

Intel 82583V

Super I/O

64Mbit

SPI BIOS

Half-size Mini PCIe

Full-size Mini PCIe

(Supports mSATA)

PCIe x1

PCIe x1

LPC

SPI

PCIex1, USB2.0

PCIex1, USB2.0, SATA

Intel Core i3 / i7

FDI DMI

Intel QM77

PCH

RGB

DisplayPort

LVDS

HD Audio LINE OUT

USB 2.0 x1

USB 3.0 x1

LPC

4 PCIe x 1

Display Port

VGA

HDMI / DisplayPort

48-bit LVDS

MIOe

MIO-5290

2 x SATA III 4 x USB 2.0

2 x USB 3.0

Advantech iManager

Realtek

ALC892

8-bit GPIO SMBus/I

2

C

订货信息

料号 CPU

L3

Cache

MIO-5290U-S6A1E

MIO-5290U-S7A1E

MIO-5290L-U5A1E

Intel Core i3 ULV

1.6GHz 3217UE

DC, 17W

Intel Core i7 ULV

1.7GHz 3517UE

DC, 17W

Intel Core i7 LV

2.5GHz 3555LE

DC, 25W

3MB

4MB

4MB

1

Full-size Mini PCIe supports mSATA

2

Active = with fan

LVDS VGA HDMI/DP GbE

48-bit Yes

48-bit Yes

48-bit Yes

Yes

Yes

Yes

2

2

2

HD

Audio

Yes

Yes

Yes

1

1

1

RS-

232/422/485

RS-232

USB

3.0

USB

2.0

SATAIII

1

1

1

2

2

2

4

4

4

2

2

2

Half-size

Mini PCIe

1

1

1

装箱单

料号

2006529000

1700006291

1700018785

1700019435

1701200220

1700019584

9689000002

1960057431N001

1960057432N001

描述

MIO-5290 SBC

Startup Manual

M Cable SATA 7P/SATA 7P 30cm C=R 180/90

SATA 35cm power cable

COM RS-485 D-SUB 9P (M)/1*5P 1.25 25cm cable

COM RS-232 Cable 2*10P-2.0/D-SUB 9P (M)*2 22CM

Audio Cable 2*5P-2.0/JACK*3 20cm mini Jumper pack

Cooler for MIO-5290L series only (Height: 47.7mm)

Cooler for MIO-5290U series only (Height: 37mm)

后部I/O视图

MIO-5290U-S6A1E

MIO-5290U-S7A1E

1

1

1

1

1

1

数量

1

1

1

1

MIO-5290L-U5A1E

可选配件

料号

1960058000N001

1700006291

1703100260

1757003934

Embedded OS/

API

Windows

Embedded

Standard

Windows

Embedded

Standard 7

Linux

Software API

Full-size

Mini PCIe

1

1

Embedded OS/API

MIOe

Power 连

接器

Yes DC Jack

Thermal

Solution

2

Operation

Temp.

Active 0 ~ 60° C

描述

Heat spreader for MIO-5290

SATA cable 7P/ 7P 30cm C=R 180/90

USB5/6 cable

Adaptor 100-240V 60W 12V 5A W/O PFC

料号

2070011449

1

1

2070011453/

2070011452

描述

Yes

Yes

DC Jack

2x2 pin

Active

Active

WES2009 MIO-5290 ENG

0 ~ 60° C

0 ~ 60° C

WES7E 32/64bit MIO-5290 ENG/GER/

JPN/CH

Ubuntu 12.04

iManager 2.0

在线下载 www.advantech.com.cn/products

71

72

MI/O

扩展模块

MIOe-110

2 x RS-232,

2 x RS-232/422/485

(with power and isolation),

2 x USB 2.0

规格

General

Bus 接口

Super I/O

外部I/O

MIOe LPC/USB

SCH3106

COM port

COM1/2: Both at coastline and internal box wafer, simultaneously

COM1: RS-232/422/485 (With isolation. RS-485 with auto flow control).

COM2: RS-232/422/485 (Supports wake on ring. Supply 5V/12V power selected by jumper. RS-485 with auto flow control).

内部I/O

COM port

USB 2.0

Communications

Data Bits

COM3/4: RS-232 (Support wake on ring)

2

Data Signals

IRQ

Parity

速度

Stop Bits

Protection

ESD

Isolation

Compatibility

外部I/O

机械

Function

环境

尺寸(WxD)

重量

工作温度

工作湿度

存储环境

5, 6, 7, 8

RS-422: TxD+, TxD-, RxD+, RxD-

RS-485: DATA+, DATA-

RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, RI, GND

Depends on MI/O CPU Board even, odd, sticky or no

50 to 460k, 921k* and 1.5M* Baud

1, 1.5, 2

Air gap ±15kV and contact ±8kV for all COM ports

2.5kV for COM1

MI/O-Ultra

MI/O-Ultra

MI/O-Compact*, MI/O-Ultra*

100 x 72 mm (3.9" x 2.8")

0.04 kg (0.09lb), only for board

0 ~ 60° C (32 ~ 140° F)

40° C @ 95% RH Non-Condensing

-40° C ~ 85° C and 60° C @ 95% RH Non-

Condensing

Power

电源电压 Supported by MI/O Extension SBC

* Except for MIO-2261 and MIO-5270, other MI/O CPU boards need customized

BIOS.

订货信息

P/N 描述

MIOe-110F-00A1E 2 x RS-232/422/485, 2 x RS-232, w/ isolation, 2 x USB

MIOe-110L-00A1E 1 x RS-232/422/485, 2 x RS-232, w/o isolation, 2 x USB

附件

P/N

1700018999

描述

COM3/4 cable 22cm

数量

1

可选配件

P/N

1700019414

1700019071

描述

COM1/2 internal cable 30cm

2 ports USB cable w/o bracket, 12cm

MIOe-120

2 x GbE, HDMI, Mini PCIe,

SIM holder, speaker out,

LPC, 2 x USB 2.0

规格

General

Bus 接口

Ethernet 控制器

PCIe Switch

USB Hub 控制器

外部I/O

GbE

MIOe PCI Express/ USB/ LPC/ Audio line-out

GbE Intel

®

82583V

PLX PEX8605

Terminus FE1.1 USB 2.0 4-port hub

USB 2.0

HDMI

内部I/O

GbE

Speaker out

LPC

扩展

Mini PCIe

Compatibility

外部I/O

机械

Function

机械和环境

尺寸 (L x W)

Weight

工作温度

工作湿度

存储温度

Power

电源电压

1 (10/100/1000 Mbps), both at coastline and internal box wafer, simultaneously

2 (Both at coastline and internal box wafer, simultaneously)

1 (by request, only for MIO-2261)

1 (10/100/1000 Mbps)

1 with amplifier (Max 2.2W/ch stereo into a 3Ω load )

1 (support extra four COM ports by PCA-COM232-

00A1E or PCA-COM485-00A1E, TPM module by PCA-

TPM-00A1E)

1 (full size, with SIM holder, including of USB 接口)

MI/O-Ultra

MI/O-Compact, MI/O-Ultra

MI/O-Compact*, MI/O-Ultra*

100 x 72 mm (3.9" x 2.8")

0.04 kg (0.09lb), only for board

Standard operating: 0 ~ 60° C (32 ~ 140° F)

40° C @ 95% RH Non-Condensing

-40° C ~ 85° C and 60° C @ 95% RH Non-Condensing

Supported by MI/O Extension SBC

* 1. HDMI: Only for MIO-2261, supported by request

2. LPC: Supported by OEM BIOS for PCA-COM232-00A1E, PCA-COM485-00A1E,

and PCA-TPM-00A1E

3. MIO-5250 doesn’t support MIOe-120L

订货信息

P/N

MIOe-120F-00A1E

MIOe-120L-00A1E

描述

2 x GbE w/ PCIe switch, 2 x USB, Mini PCIe, SIM holder, speaker-out with amplifier, LPC

1 x GbE w/o PCIe switch, 2 x USB, Mini PCIe, SIM holder, speaker-out with amplifier, LPC

可选配件

P/N

1700019001

1700019071

PCA-COM232-00A1E

PCA-COM485-00A1E

PCA-TPM-00A1E

描述

1 x LAN cable, 15cm

2 ports USB cable w/o bracket, 12cm

4 x RS-232 extension module, 31.5x48mm

4 x RS-422/485 extension module, 31.5x48mm

TPM module, 31.5x48mm

MI/O

扩展模块

MI/O

扩展模块

MIOe-210

4 x RS232/422/485,

2 x RS422/485, 8-bit GPIO

MIOe-220

3 x Intel

®

Gigabit Ethernet

规格

General

Bus 接口

Ports

GPIO

Communications

Data Bits

MIOe LPC

4 x RS232/422/485, 2 x RS422/485

8-bit with 3.3V level

Data Signals

IRQ

Parity

Speed

Stop Bits

Protection

EFT Protection

Compatibility

外部I/O

机械

Function

环境

尺寸(WxD)

Weight

工作湿度

工作温度

存储温度

电源

电源电压

5, 6, 7, 8

RS-422: TxD+, TxD-, RxD+, RxD-

RS-485: DATA+, DATA-

RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, RI, GND

Depends on MI/O CPU Board even, odd, sticky or no

50 to 460k, 921k* and 1.5M* Baud

1, 1.5, 2

Air gap ±15kV, contact ±8kV

MI/O-Compact

MI/O-Compact

MI/O-Compact*, MI/O-Ultra*

146 x 102 mm (5.7" x 4")

0.186 kg (0.41 lb)

0 ~ 90 % relative humidity, non-condensing

0 ~ 60° C (32 ~ 140° F)

-40° C ~ 85° C and 60° C @ 95% RH Non-Condensing

Supported by MI/O Extension SBC

* Requires customized BIOS for MI/O CPU board support.

订货信息

P/N

MIOe-210-D6A1E

描述

4 x RS232/422/485, 2 x RS422/485, 8-bit GPIO

附件

料号

1703040157

描述

RS-422/485 W/D-SUB COM 4P 15 cm

数量

2

规格

General

Bus 接口

Chipset

PCIe Switch

Port

Speed

Compatibility

外部I/O

机械

Function

机械和环境

尺寸 (L x W)

Weight

工作温度

工作湿度

存储温度

电源

电源电压

订货信息

P/N

MIOe-220-L3A1E

MIOe-220-B3A1E

MIOe PCI Express

Intel

®

82583V Gigabit Ethernet 控制器

PLX PEX8605

3 x RJ45

10/100/1000 Mbps

MI/O-Compact

MI/O-Compact

MI/O-Compact, MI/O-Ultra

102 x 83 mm (4" x 3.2")

0.182 kg (0.401 lb)

Standard operating: 0 ~ 60° C (32 ~ 140° F)

0% ~ 90% relative humidity, non-condensing

-40° C ~ 85° C and 60° C @ 95% RH Non-Condensing

Supported by MI/O Extension SBC

描述

3 x Intel

®

Gigabit Ethernet without PCIe Switch

3 x Intel

®

Gigabit Ethernet with PCIe Switch (for MIO-5250 or MIO-2261)

MIOe-230

48-bit LVDS or DisplayPort

1

,

2 x USB 2.0

规格

General

Bus 接口

控制器

Brightness Control

USB

Compatibility

外部I/O

机械

Function

机械 环境

尺寸 (L x W)

Weight

工作温度

工作湿度

电源

电源电压

MIOe Displayport & USB 2.0

Chrontel CH7511

Supported

2 x USB 2.0

MI/O-Ultra

MI/O-Compact, MI/O-Ultra

MI/O-Compact

2

, MI/O-Ultra

2

100 x 72 mm (3.9" x 2.8")

0.084 kg (0.185 lb)

0 ~ 60° C (32 ~ 140° F)

0% ~ 90% relative humidity, non-condensing

Supported by MI/O Extension SBC

1

Supports by request

2

Requires customized BIOS for or HW adjustment MI/O CPU board support.

订货信息

P/N

MIOe-230-L0A1E

描述

48-bit LVDS or DisplayPort, 2 x USB 2.0

在线下载 www.advantech.com.cn/products

73

74

扩展

电源

环境

机械

MIOe-DB2000

NEW

Line in

Line out

USB

I

2

C

SMBus

GPIO

Inverter

RS-232

MIOe

LPC

PCIe x1

SATA

Evaluation Board for MIO-2262

特点

ƒ

完整和灵活的接口,可满足垂直应用需求

ƒ

加快客户载板开发

ƒ

所有电路设计参照MI/O扩展设计指南

ƒ

使用标准EPIC尺寸

ƒ

接口:1 x DP、1 x PCIe、1 x miniPCIe、1 x SIM卡槽、6 x

USB 2.0、1 x LPC、1 x SMBus、1 x I2C、1 x 线路输出、1 x 带电SATA、8-bit GPIO、电源/HDD LED,电源/复位按

钮、逆变器、+12 V电源输入

Power button

DC Power

VGA

USB

LAN

DP/HDMI Reset button

HDD/Power LED

规格

外形

兼容模式

显示

存储

外部 I/O

内部 I/O

VGA

DP/HDMI

SATA with Power

以太网

VGA

DP/HDMI

USB

LED

Power Button

Reset Button

HD Audio

Serial

DC Power Jack

I

2

C

SMBus

Inverter

GPIO

LPC

PCIe x1 slot

Mini PCI Express

SIM card Holder

MIOe connector

64pin connector

Independent Power voltage

工作

非工作

尺寸 (L x W)

重量

EPIC

MIO-2262

1

1 DP or HDMI (HDMI supported by request)

1 (connect to 2.5" HDD)

1 x RJ45

1

1 (HDMI supported by request)

6 x USB2.0

Power, HDD

1

1

Line in, Line out

2 x RS-232 (ESD protection for RS-232: Air gap ±15kV, Contact ±8kV)

1 (default 2x2pin power connector, DC jack supported by request)

1

1

1

8-bit general purpose input/output

1

1

1

2

1 (Full-size)

1

Single +12V DC in

0 ~ 60° C (32 ~ 140° F) (工作湿度: 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C and 60° C @ 95% RH Non-Condensing

115 x 165 mm (4.5" x 6.5")

0.25 kg (0.55 lb), weight of total package

Evaluation Board for MIO-2262

MIOe-DB2000

结构图

GPIO Header

Line in

Line out

2 RS-232

2 USB

I 2 C Wafer

SMBus Wafer

8-bit GPIO

HD Audio

USB 2.0

MIO-2262

SBC

RGB

PCIe

USB 2.0

VGA

LAN

2 USB

PCIe

USB 2.0

PCIe x 1 Slot

MiniPCIe slot

(With SIM holder)

(Note 1)

DP or HDMI

2 USB

LPC Header

SATA with power

SATA II 300MB/s

Note 1 : Supported by request

订货信息

料号

DP/

HDMI

MIOe-DB2000-00A1E 1*

VGA GbE PCIe x1 RS-232 Full-size

1 1 1 2 1

* HDMI and DC jack supported by request

SIM holder SATA II LPC

1 1 1

SMBus I

2

C

1 1

USB

2.0

6

Audio MIOe

Yes Yes

Power

Conn.

2x2 pin*

装箱单

料号

MIOe-DB2000-

00A1E

描述

Evaluation Board for MIO-2262

后部I/O视图

数量

1

可选配件

料号

MIO-2262N-S6A1E

MIO-2262N-S8A1E

描述

MIO-2262 N2600 SBC

MIO-2262 N2800 SBC

在线下载 www.advantech.com.cn/products

75

76

MIOe-DB5000

Power Conn

FAN

LineOut

SATA II

USB 3.0

USB 2.0

CPLD

SMBus PWR

RST

SIM Holder

Half-size

Mini PCIe

MIOe Evaluation Board for

MI/O-Compact and MI/O-Ultra SBC

特点

ƒ

同时支持MI/O-Compact SBC和MI/O-Ultra SBC

ƒ

兼容MIOe,用于灵活接口验证的评估板

ƒ

接口:1 x DP、3 x PCIe、1 x miniPCIe、1 x SIM卡槽、1 x

USB 3.0、1 x USB 2.0、1 x LPC、1 x SMBus、1 x 带扩大器

的线路输出、1 x 带电SATA、2 x 系统风扇、+12 V电源输入

GPIO

LPC MIOe DisplayPort PCIe x1

规格

外形

兼容模式

扩展

I/O

电源

环境

机械

DisplayPort

PCIe x1 slot

MIOe connector

SIM card Holder

Full-size Mini PCIe

SATA with Power

LPC

USB 2.0

USB 3.0

LineOut

System FAN

SMBus

Independent Power voltage

工作温度

工作湿度

尺寸(WxD)

1

1

ATX

Advantech MI/O-Compact (146 x 102 mm), MI/O-Ultra (100 x 72 mm)

1 (only can evaluate with the 1st port of DisplayPort Riser Card)

3 (MIOe-DB5000-01A1E has only two ports)

1

1 (connect to 2.5 HDD)

1 (evaluate by using 4 ports RS-232/422/485 Module)

1

1*

1 (with amplifier AMP LM4863)

2

1

Single +12V DC in (2x2 power connector is only for external power input)

0 ~ 60° C (32 ~ 140° F)

0% ~ 90% relative humidity, non-condensing

304.8 x 170 mm (12" x 6.69")

* For USB 3.0 to work depends on if MI/O SBC supports USB 3.0 or not

PS: Pinout functions depend on SBC platform chipset

MIOe Evaluation Board for

MI/O-Compact and MI/O-Ultra SBC

MIOe-DB5000

结构图

DisplayPort

USB 2.0 x 3 or USB 3.0 x 1

4 PCIe x 1

MI/O-Compact or

MI/O-Ultra

SBC

LPC

Audio Line Out

SMBUS

+12VSB VCC (Power)

+5VSB VCC (Power)

MIOe

Connector

DP

USB

PCIE

USB

AUDIO

LPC

SMBus

Display Port

(PCIE x16 Slot)

USB 2.0 x2 or

USB 3.0 x1 + USB 2.0 x1

3 PCIe x 1

1 miniPCIe slot

(With SIM holder)

LINE OUT

(With amplifier)

Port 80

LPC Header

SMBus Wafer BOX

Option module:

DisplayPort Riser Card

Option Module:

4 Ports COM-232/422/485 module

(Note 1)

Note 1: The signal varies depending on

MI/O-Compact or MI/O-Ultra SBC

SATA

订货信息

料号

MIOe-DB5000-00A1E 1*

MIOe-DB5000-01A1E 1*

3

2**

1

1

1

1**

1

1

SIM holder SATA II LPC SMBus

1

1

1

1

1

1

1

1

USB

2.0

USB

3.0

1***

1***

1

1

1

1

* The DisplayPort Riser Card has both HDMI and DisplayPort. Each can be supported individually by signal setting on the MI/O main board.

** MIOe-DB5000-01A1E has 2 PCIe x1 and 1 Mini PCIe.

*** For USB 3.0 to work depends on if the MI/O mainboard supports USB 3.0 or not. If the bundled MI/O main board doesn't support USB 3.0 explicitly, the USB connector supports USB 2.0 only.

Power

Conn

2x2

2x2

装箱单

料号

-

描述

MIOe-DB5000 development board

1700020235-01 Reset/Power button cable

数量

1

2

可选配件

料号

9696EA2000E

PCA-COM232-00A1E

PCA-COM485-00A1E

* Supported by request

描述

DisplayPort Riser Card

4 ports RS-232 Module*

4 ports RS-422/485 Module*

在线下载 www.advantech.com.cn/products

77

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Languages
