Accessories — General
AC Adapters . . . . . . . . . . . . . . . . 3
Binocular Neck Strap . . . . . . . . . 3
Binocular Tripod Adapter . . . . . . 3
Photo Accessories
Reducer/Corrector f/6.3 . . . . . . .22
..................... 3
Radial Guider . . . . . . . . . . . . . . .22
Car Battery Adapters . . . . . . . . . . 4
Hand Controller . . . . . . . . . . . . .23
Collimation Tool . . . . . . . . . . . . 4
Focus Motors . . . . . . . . . . . . . . .23
Dew Eliminator . . . . . . . . . . . . . 4
Flashlights . . . . . . . . . . . . . . . . . . 4
Counterweights . . . . . . . . . . . . .24
Focuser Assembly . . . . . . . . . . . . 5
Lens Shades . . . . . . . . . . . . . . . .24
LensPen . . . . . . . . . . . . . . . . . . . 5
T-Adapters and T-Rings
Accessory Package Kits . . . . . . . . 5
Tele-Extender . . . . . . . . . . . . . . .26
Car Window Mount . . . . . . . . . . 5
Piggyback Mounts . . . . . . . . . . .26
. . . . . . . . . . . . . . . .23
T-C 16mm Adapter
Economy, Terrestrial, SMA . . . . . 6
. . . . . . .25
. . . . . . . . . .26
Plössl, Ultima . . . . . . . . . . . . . . . 7
Computerized Circles/
Sky Maps/Books
LV, Cross Hair, Deluxe Zoom . . . 8
Advanced Astro Master
Ultima Spotting Scope . . . . . . . . 9
Beginning Books
Eyeguard Set . . . . . . . . . . . . . . . . 9
Planispheres . . . . . . . . . . . . . . . .28
Barlow Lenses . . . . . . . . . . . .10
Diagonals . . . . . . . . . . . . . . . .11
Finderscopes . . . . . . . . . . . . . .12
Eyepiece . . . . . . . . . . . . . . . . . . .14
Polarizing, Skylight, Moon . . . . .17
Solar . . . . . . . . . . . . . . . . . . . . . .18
LPR . . . . . . . . . . . . . . . . . . . . . . .19
Motor Drives
Economy and Deluxe . . . . . . . . .20
Declination Motors
Guiding Eyepieces &
Illuminators . . . . . . . . . . . . .21
. . . . . . . . . .20
. . . . . . .27
. . . . . . . . . . . .27
CD-ROM . . . . . . . . . . . . . . . . . . .28
Sky Maps . . . . . . . . . . . . . . . . . .28
Stereo Binocular Viewer
Tripods and Accessories
Equatorial Wedges . . . .
Equatorial Mounts . . . .
Warranty . . . . . . . . . . . . . . . . .34
Please note:
Items requiring 220V-50HZ are
available through Celestron’s
international dealers only.
AC Adapters
Allow DC (battery powered) telescopes to be converted for use with 120 volt AC power.
AC Adapter – C5 , Celestar 8, Ultima 91/4 & 11
AC Adapter – Celestar 8 Deluxe, G-9, G-11 and G14 Mounts, Ultima® 2000 [18770]
Binocular Neck Strap – #71520
This wide, black cloth strap, enhanced with the
Celestron logo, is designed to add greater
comfort and ease of use to your binocular
viewing. Fits most manufacturers’ binocular
Binocular Tripod Adapter – #93512-A
This useful adapter attaches to the center hinge of most high
quality binoculars, allowing you to mount them to any tripod
equipped with a standard 1/4" x 20 mounting bolt. A must for
vibration-free viewing, this adapter conveniently sets your
hands free for other tasks while observing.
If you own a C5 or C8 telescope,
it’s imperative that you
protect your investment.
Celestron offers a large
case suitable for the
task, which accommodates almost any C5 or
C8 fork mounted
telescope. It’s constructed of space age resin,
making it waterproof, unbreakable, airtight and
extremely durable. The case is lined with die cut
foam for custom fitting. It features large handles and is equipped with wheels,
for easy transportation. Weight is 17 lbs. Made in the USA.
A case is available for all C90 Spotting Scopes. It’s made of sturdy ABS plastic
and is die cut to fit the C90, a camera body and several accessories.
C5/C8 Case — I.D.— 29" x 173/4" x 91/4" [302070]
C90 Case — I.D. — 141/2" x 101/2" x 51/4" [302042]
Car Battery Adapters
Allow you to link your telescope drive directly to
the cigarette lighter receptacle of your car, for a
quick and easy DC power source in one step.
Car Batter Adapter – C5+, Celestar 8, Ultima®
91/4 & 11 [18767]
Car Battery Adapter – Ultima® 2000 [18769]
Collimation Tool – #94183
The optical performance of most Newtonian telescopes can be optimized by collimating, or realigning, the telescope’s optics, as needed. This procedure
is easily accomplished with Celestron’s Collimation
Tool, a handy accessory that comes with detailed
Dew Eliminator – #94122
Celestron’s 12 volt Dew Eliminator means viewing sessions
can last longer. It blows warm air to keep your corrector
plate and any optional accessories dew-free. Just plug it into
your car’s cigarette lighter receptacle for trouble-free observing. 156 watts. Weight: 9 ounces.
Red Astro Lite – #93590
An economical, disposable squeeze-type flashlight fitted
with a red cap to help preserve your night vision. Remove
the red cap for normal flashlight operation. Very compact size and
handy keychain.
LED Flashlight – #93592
A cost effective red LED flashlight for astronomy. It’s compact – only 6"
long and weighs just 2.5 ounces. Operates on two AA batteries (included).
Night Vision Flashlight – #93588
Celestron’s premium model for astronomy, using two red LEDs to preserve
night vision better than red filters or
other devices. Brightness is adjustable.
Operates on a single 9 volt battery
(included). Made in the USA.
From Top:
#93588, #93592,
Focuser Assembly – #93670
Celestron offers this very smooth and economical
11/4" rack and pinion focuser for Newtonian
telescopes. The focuser glides easily and provides 2"
of focus travel. An adapter is included to allow use
with .96" eyepieces as well as 11/4" eyepieces.
LensPen™ – #93575
A superb new tool in optical lens cleaning technology. Perfect for cleaning binocular lenses, small
aperture spotting scopes
and telescopes, eyepieces,
and other optical items.
The LensPen™ comes
with a handy retractable
dust removal brush and a
special non-liquid
cleaning element, designed to never dry out. Safe and very easy to use.
Accessory Package Kits
Accessory packages are offered especially for Dobsonian telescopes at savings over
individually priced items.
#92505 — contains a 5x24 finderscope, 10mm SMA eyepiece — 11/4", moon filter
— 11/4" and a CD-ROM “The Sky for Celestron”.
#92506 — contains a 6x30 finderscope, 10mm SMA eyepiece — 11/4", moon filter
— 11/4", LED flashlight and Celestron Sky Maps.
#92507 — contains a 9x50 finderscope, 7.5mm Plössl eyepiece — 11/4", 17mm
Plössl eyepiece — 11/4", moon filter — 11/4", Night Vision flashlight and a CD-ROM
“The Sky for Celestron”.
Car Window Mount – #93513
This durable, heavy-duty mount is carefully
designed to attach easily to your car window
and provide stable, vibration-free support for
binoculars, telephoto lenses and spotting scopes.
Economy Eyepieces: .96" and 11/4"
Celestron offers these very economical
eyepieces to expand your viewing options.
They are all simple eyepiece designs —
Ramsden (SR & F) and Huygens (H & HM)
but perform quite well on f/8 or slower
telescopes. The optics are all glass and
they’re priced to make a complete range of
powers easily available.
4mm – SR
6mm – F
8mm – H
12.5mm – H
20mm – H
25mm – HM
Item #
Item #
.96" models
11/4" models
Terrestrial .96" Erecting Eyepiece – #93216
This 1.5x eyepiece can be used on any telescope with
a .96" focuser to achieve an image correctly oriented
from top to bottom (rather than upside-down, as
most eyepieces display an image). Especially useful for
daytime terrestrial observing.
Super Modified Achromatic (SMA)
Eyepieces: .96" and 11/4"
The SMA design is an improved version of the
Kellner eyepiece. SMAs are very good, economical, general purpose eyepieces that deliver a wide
apparent field, good color correction and an
excellent image at the center of the field of view.
The eyepieces are fully coated for maximum
contrast. Celestron offers a range of SMA
eyepieces in both .96" and 11/4" sizes.
Focal Length
Item # .96"
Item # 11/4"
Eye Relief
Apparent Field
Plössl Eyepieces: .96" and 11/4"
In a recent Sky and Telescope review, Celestron’s .96"
and 11/4" Plössl eyepieces were rated as top ranking,
and found to outperform many similar, but more
expensive eyepieces. An exceptional value!
Celestron offers these premium eyepieces at
affordable prices, yet they’re among the best
designed and corrected eyepieces available. They’re
multicoated for enhanced contrast and all of the
11/4" models are threaded to accept Celestron
colored eyepiece filters.
Focal Length
Item # .96"
Item # 11/4"
Eye Relief
Apparent Field
Ultima® Eyepieces: 11/4"
These are Celestron’s top of the line eyepieces, utilizing
a hybrid design of five elements. They feature long eye
relief and a wide field, and each air-to-glass surface is
fully multicoated to enhance contrast levels. These
special eyepieces are computer designed to keep visual
aberrations to an absolute minimum. They virtually
eliminate the following aberrations: spherical, color,
field curvature, coma, astigmatism, distortion and spherical distortion of the
exit pupil. The inside surfaces and edges of all lenses are blackened, to keep out
reflected light. Outside surfaces are flat black, with rubber grips for secure
handling. Rubber eyecups are included both for comfortable use and to keep
out extraneous light. Threaded barrels accept Celestron thread-in filters. Lens
and barrel caps are included for safe storage.
Focal Length
Item #
Eye Relief
Apparent Field
Recently, Sky &
Telescope reviewed
Celestron’s Ultima®
eyepieces and rated
them best in their
class, with greater
contrast and image
sharpness than the
competitive models
of other
LV Eyepieces: 11/4"
These Vixen brand eyepieces (6 to 8 elements) are a
new breed, using the rare earth glass lanthanum in
one of their field lenses, for almost total freedom
from any visual aberrations. All focal lengths have a
comfortable 20mm of eye relief. Even when using
the 2.5mm LV eyepiece on a telescope, you’ll have
eye relief of 20mm! These eyepieces also feature soft rubber eyecups, rubber
coated bodies, and fully multicoated lenses for optical excellence.
Focal Length
Item #
Apparent Field
LV Zoom Eyepiece: 11/4"– #3777
This super premium zoom eyepiece has a focal length of
8mm to 24mm. It is the finest zoom eyepiece for low to
medium power observing. It’s an excellent zoom eyepiece that performs superbly, with fully multicoated
surfaces. It offers an apparent field of 40° at 24mm and
60° at 8mm. Eye relief ranges from 15mm to 19mm.
Cross Hair Eyepiece: 11/4" – #93304
This eyepiece is of the Kellner design, with a focal length of
20mm. It’s ideal for centering alignment stars when using digital
setting circles or computerized telescopes. A useful all-around
eyepiece for many applications, including terrestrial observing. It
is fully coated and has an apparent field of 43°.
Deluxe Zoom Eyepiece: 11/4" – #93306
The Deluxe Zoom 6.5mm to 18mm 11/4" eyepiece is a
recent design that has rapidly become the finest
zoom eyepiece ever offered for medium to highpowered observing. This phenomenal eyepiece is
multicoated and extremely lightweight, weighing
just 5 ounces. It offers an apparent field of 38.5° at
18mm and 60.5° at 6.5mm. Eye relief is 11mm, even
at the highest power.
Ultima Spotting Scope Eyepieces
Extremely high quality eyepieces designed exclusively for the Ultima line of
spotting scopes.
65mm Spotter
80mm Spotter
Mount Type
16-48x Zoom
20-60x Zoom
Clockwise: #1838, #1828, #1830
Eyeguard Set — #93330
A set of 10 rubber eyeguards that fit Celestron 11/4" Economy, SMA and Plössl
(except 32 and 40mm) eyepieces as well as many eyepieces of other manufacturers. Allows more comfortable viewing by blocking out auxiliary light and
provides increased contrast for both astronomical and terrestrial viewing.
Barlow lenses offer an easy, economical way to
increase the magnification range of your eyepieces,
and Celestron carries an assortment of these highly
useful lenses. A Barlow lens doubles the magnifying
power of your eyepiece by doubling its effective focal
length. For example, an 18mm eyepiece used with a
2x Barlow lens would have the magnifying power of
a 9mm eyepiece. It’s like having two eyepieces in
If you’re looking for an affordable way to achieve
high-power viewing of the moon and planets, double
stars and even close-up views of terrestrial subjects, a
Barlow lens is the answer.
Top: #93506, 93502, #93507
Bottom: #93213, #93211
Barlow lenses mount into either your telescope’s focuser or visual back.
The Economy models of .96" and 11/4" are good choices when you want to
expand your power ranges at a very economical price.
Celestron’s premium quality .96" and 11/4" achromatic Barlow lenses (#93502
and #93507) are compact and lightweight. Both are under three inches long,
with the 11/4" lens weighing in at 4 ounces and the .96" lens a mere 2 ounces!
The clear aperture is 27mm on the 11/4" model, and 21mm on the .96" unit.
The .96" Barlow is fully multicoated and the 11/4" lens is multicoated.
The Ultima® Series Barlow (2x – 11/4") is an air-spaced, three element apochromatic design with a 27mm clear aperture. This lens features a very high
quality, fully multicoated design. Amazingly compact and lightweight, it’s
just 5 ounces and 2.75" in length.
2x Barlow Lens – Economy – .96" [93211]
2x Barlow Lens – Economy – 11/4" [93213]
2x Barlow Lens – Deluxe – .96" [93502]
2x Barlow Lens – Deluxe – 11/4" [93507]
2x Barlow Lens – Ultima® Series - 11/4"
Focuser or
Visual Back
Barlow Lens
Diagonals: .96" and 11/4"
Celestron’s Erect Image Diagonals are an Amici
prism design. This design allows you to look into
the telescope at a 45° angle, at images that are
oriented properly, meaning the image is upright
and correct from left to right. Use of Celestron’s .96"
to 11/4" 45° Erect Image Diagonal on a telescope
equipped with .96" eyepieces means greater versatility. This diagonal will allow you to use 11/4" eyepieces, to obtain a larger field of view and better eye
relief. A 90° 11/4" Erect Image Diagonal is available
for those who prefer that angle.
A Star Diagonal lets you view objects that are at a
90° angle from the direction the telescope is
pointing, thereby allowing comfortable viewing
when the telescope is pointed at, or near, the zenith
(i.e. directly overhead). The resulting image is right
side up, but will be reversed from left to right.
Clockwise: #94115-A,
#93630, #94106
The economy Hybrid Mirror Diagonal (90°) provides
a cost effective way to upgrade telescopes supplied
with .96" eyepieces, to higher quality 11/4" eyepieces.
Erect Image Diagonal 45° – .96" [94111-A]
Erect Image Diagonal 45° – 11/4" [94112-A]
Clockwise: #94112-A,
#94113-A, #94111-A, #94108
Erect Image Diagonal 45° – .96" to 11/4" [94113-A ]
Erect Image Diagonal 90° – 11/4" [94108]
Star Diagonal – .96" [93630]
Star Diagonal – 11/4" [94115-A ]
Hybrid Mirror Diagonal – .96" to 11/4"
2" Diagonal – #93519
Celestron offers a standard 2" 90°
Mirror Diagonal to thread on SchmidtCassegrain telescopes. This improved
version of our 2" Diagonal includes an
adapter to accept 11/4" eyepieces. It has
a multicoated mirror and smooth
mechanics that are precision manufactured for reliability.
Finderscopes are secondary scopes, used to help
locate objects in the main telescope. The larger
the finderscope, the more you’ll see, to an upper
limit of 50mm. Units larger than 50mm have
too narrow a field of view to be useful.
Finderscopes mount onto the main telescope
tube and are an invaluable tool in locating
objects for viewing.
Clockwise: #93777, #93775,
#93779, #93783-8
5x24 Finderscope – #93775
An economical finderscope for Celestron’s Star Hopper™ Dobsonian telescopes.
Includes mounting bracket.
6x30 Finderscope – #93779
This achromatic finderscope has an extra wide 7° field of view. Its aluminum
body is painted a glossy black color, and the mounting bracket is the same as
that used on many C8 telescopes.
6x30 LER (Long Eye Relief) Finderscope – #93777
This model has all the features of the 6x30 Finderscope (model #93779) and
comes with a mounting bracket. It’s a particularly good choice for Celestron’s
Star Hopper™ Dobsonian telescopes. Can also be used to upgrade Firstscope 60,
70 and 114 telescopes, which come with a standard 5x24 finderscope.
Finderscope also sold separately (model #51602-B).
9x50 Finderscope – #93783-8
A high quality, economical 9x50 finderscope with fully coated lenses and a
5.8° field of view. It comes with a mounting bracket for C8 type telescopes.
Finderscope also sold separately (model #51611).
7x50 Polaris Finderscope – #93785-8P
The 7x50 Polaris Finderscope comes
with a mounting bracket (for C8
telescopes) and hardware, setting plate,
and the Polaris etched reticle and
Pulstar Illuminator for quick, accurate
polar alignment. It has a 5° field of
view and eye relief of 17.5mm.
Finderscope also sold separately
(model #51614).
Quick Release Finder Bracket –
A unique bracket for 50mm finderscopes, it’s
designed for C8, C91/4 and C11 telescopes. No
tools are required, and once it’s aligned, you
can take it off and put it on without losing
alignment. Bracket includes necessary mounting hardware. The additional weight of this
accessory may require that you use additional
optional counterweights for your telescope.
Star Pointer – #51630
A 1x, or unit power finderscope designed so you can point the telescope while
scanning the sky with both eyes. Finding
objects couldn’t be easier! A mirror lens
projects the image of a LED illuminated
pinpoint into the line of sight, providing you
with a red dot of light to center on the object
you want to view. Something like having a
laser pointer that reaches into the sky, it
greatly simplifies finding objects. The brightness level is adjustable, and the Star Pointer
can be used during daytime observing as well.
It’s also a handy guide when using binoculars.
Attaches to any telescope easily.
Extra bases are available (#51631) to make it easy to move the Star Pointer for
use on different telescopes.
Polar Axis Finderscope – #94221
This useful accessory speeds accurate polar
alignment by providing a means of visually
aligning your German equatorial mount with
Polaris and true north. As a result, you can
spend more time observing and less time
setting up. The finderscope has an easy to use
cross hair reticle. For CG-4 and CG-5 mounts.
Eyepiece filters are an invaluable aid in lunar and planetary observing. They
reduce glare and light scattering, increase contrast through selective filtration,
increase definition and resolution, reduce irradiation and lessen eye fatigue.
Celestron’s filters are made of high quality, solid plane parallel glass with excellent homogeneity. They’re anti-reflection coated to prevent glaring and ghosting.
All eyepiece filters are threaded to fit Celestron’s, and most other manufacturer’s,
11/4" eyepieces, and offer a full 26mm clear aperture.
Celestron filters are mounted in black anodized aluminum cells with the Kodak
Wratten Series Number individually engraved, and come with a plastic case for
safe storage. The cells
of each filter are
double-threaded, so
they can be stacked
(piggybacked) in
various combinations.
This allows you to
create different color
combinations and
transmission characteristics, or to have
the same color
characteristic, but
with a lower transmission. When stacking color filters, the effective transmission of the combination
you create is equal to the product of the spectral transmission of each of the
filters used.
The effectiveness of the filters depends on several factors, including: the aperture
and focal length of the telescope, the magnification being used, and seeing
Following, you’ll find descriptions of all of Celestron’s eyepiece filters and what
you can expect from them in different viewing situations. Some of these filters
are available individually, and others are available in convenient four filter sets
Celestron has put together to affordably expand your range of observing options.
You’ll find the information on these filters arranged in the following color categories: Yellow, Orange, Red, Blue, Green and Violet. In each category, the information that applies to all of the filters within that color group is listed, then specific
information for each filter is broken out into a separate category, where applicable.
This way, you’ll know what to expect from each of Celestron’s color filters. At the
same time, you’ll become familiar with the astounding variety of enhancements
available through these simple accessories.
#12 Deep Yellow 74% T [#94118-03 & Series 2]
#15 Deep Yellow 67% T [Series 4]
Moon – Enhance lunar features. Jupiter – Penetrate and darken atmospheric currents containing
low-hue blue tones. Enhance orange and red features of the belts and zones. Useful for studies of
the polar regions. Mars – Reduce light from the blue and green areas which darken the maria, oases
and canal markings, while lightening the orange-hued desert regions. Also sharpen the boundaries
of yellow dust clouds. Neptune – Improve detail in larger telescopes (11" and larger apertures).
Saturn – Penetrate and darken atmospheric currents containing low-hue blue tones. Enhance
orange and red features of the belts and zones. Uranus – Improve detail in larger telescopes (11" and
larger apertures). Venus – Reveal low-contrast surface features. Comets – Enhance definition in
comet tails.
#8 Yellow 83% T [Series 4]
All observing information for this filter is the same as that given for the #12 and #15 Deep Yellow
filters, with the exception of the following:
Mars – Improves the Martian maria by reducing scattered light from blue areas, while allowing
passage of more green light for studying yellow dust clouds. Comets – Brings out highlights in
yellowish dust tails and enhances appearance of comet heads.
#21 Orange 46% T [#94118-05 & Series 1]
Moon – Greatly enhances lunar features. Jupiter – Improves appearance and detail revealed in
structure of Jovian belts. Enhances viewing of festoons and polar regions. Mars – Reduces light
from the blue and green areas which darken the maria, oases and canal markings, while lightening
the orange-hued desert regions. Also sharpens the boundaries of yellow dust clouds. Mercury –
Reduces the brightness of blue sky during daylight observing, to reveal surface features. Saturn –
Improves structure of the Saturnian bands and highlights blue polar regions. Venus – Use during
daylight observing to reduce brightness of blue sky. Comets – Enhances definition of comet dust
tails and heads in larger telescopes (11" and greater aperture). Solar – When using a Celestron Mylar
Solar Filter, adding this orange filter will give true color rendition.
#25 Red 14% T [#94118-07 & Series 2]
Moon – Improves lunar features. Jupiter – Useful for studying bluer
clouds. Mars – Ideal for observation of the polar ice caps and features
on the Martian surface. Sharpens the boundaries of yellow dust
clouds. Mercury – Improves observation at twilight, when the planet
is near the horizon. During daylight, it reduces the brightness of the
blue sky to enhance surface features. Saturn – Useful for studying
bluer clouds. Venus – Use during daylight observing to reduce
brightness of blue sky. Occasionally deformations of the terminator are visible.
#23A Light Red 25% T [Series 3]
All observing information for this filter is the same as that given for the #25 filter, with the exception
of the following:
Mars – Reduces light from blue and green areas which darkens the maria, oases and canal markings,
while lightening the orange-hued desert regions. Sharpens the boundaries of yellow dust clouds.
Comets – Improves definition of comet dust tails.
#80A Light Blue 30% T [#94118-12 & Series 1]
#82A Pale Blue 73% T [Series 4]
#38A Blue 17% T [Series 3]
Moon – Enhance lunar detail. Jupiter – Enhance the boundaries between the reddish belts and
adjacent bright zones. Useful for viewing the Great Red Spot. Mars – Very useful during the violet
clearing. Helpful in studying surface features and polar caps. Mercury – Improve observation of dusky
surface markings at twilight, when the planet is near the horizon. Saturn – Enhance low-contrast
features between the belts and zones. Venus – Useful for increased contrast of dark shadings in upper
Venusian clouds. Comets – Bring out the best definition in comet gas tails.
#56 Light Green 53% T [Series 2]
Moon– Enhances lunar features. Jupiter – Increases visibility of the Great Red Spot. Useful for
observing the low-contrast hues of blue and red that exist in the Jovian atmosphere. Mars – Excellent
for increased contrast of Martian polar caps, low clouds and yellowish dust storms. Venus – Useful for
Venusian cloud pattern studies. Reduces brightness of blue sky during daylight observing.
#58 Green 24% T [#94118-11 & Series 3]
All observing information for this filter is the same as that given for the #56 Green filter, with the
exception of the following:
Saturn – Enhances white features in the Saturnian atmosphere.
Comets – Useful for observing brighter comets.
#47 Violet 3% T [Series 4]
Mars – Useful for detecting high clouds and haze over the
Martian polar caps. Very useful during the violet clearing.
Mercury – Helpful in detecting faint features. Saturn – Good for
ring structure studies. Venus – Increases contrast of dark shading
in upper Venusian clouds. Comets – Useful for observing
brighter comets.
#96ND 50% T – Density 0.3 [Series 3]
#96ND 25% T – Density 0.6 [#94118-15 & Series 2]
#96ND 13% T – Density 0.9 [#94118-16 & Series 1]
Moon – Excellent for reducing irradiation, glare and subject brightness. Colors are unaltered, as light
is transmitted uniformly over the entire spectrum. Each model performs somewhat differently,
depending on the brightness of the moon. Planets – Stacking in combination with color filters lowers
transmission, but retains true color balance for specific applications. Reduces glare on brighter planets
and minimizes irradiation. Binary Stars – Helpful in splitting binary stars, because it reduces glare and
diffraction effects around the brighter star of the binary pair.
[#94118-17 & Series 1]
Reduces reflected polarized light in the earth’s atmosphere.
Moon & Planets – Invaluable in reducing irradiation and glare. Binary Stars – Helpful in splitting
binary stars, because it reduces glare and diffraction effects around the brighter star of the binary pair.
Celestron offers four convenient filter sets, which contain four different filters per set. Not only are
these highly useful filter combinations, but they also offer an economical way to add versatility to
your filter collection. Descriptions of all filters within these sets are given above.
[Series 1 – #94118-S1]
Orange, Light Blue, ND13%T, Polarizing (#s 21, 80A, 96ND-13, Polarizing)
[Series 2 – #94118-S2]
Deep Yellow, Red, Light Green, ND25% T (#s 12, 25, 56, 96ND-25)
[Series 3 – #94118-S3]
Light Red, Blue, Green, ND50% T (#s 23A, 38A, 58, 96ND-50)
[Series 4 – #94118-S4]
Yellow, Deep Yellow, Violet, Pale Blue (#s 8, 15, 47, 82A)
11/4" Polarizing Filter Set: – #93608
Ambient daylight is normally comprised of multiple
wavelengths of light, vibrating in multiple planes. The
Eyepiece Polarizing Filter Set transmits only light moving
along a specific plane, thereby increasing the contrast
between surfaces with different planar transmissions.
Generally, the polarization effect makes blue skies a
deeper blue, eliminates surface reflections and helps
reduce atmospheric haze.
The Polarizing Filter Set is intended for visual use. It’s particularly useful for reducing
glare while observing the moon, double stars, the planets and terrestrial subjects – all
without affecting the color of the object being observed.
The Filter Set is comprised of two filters that thread into either the eyepiece or the
filter adapter, which comes with the set. When one filter is used alone, you get 30%
light transmission. When both filters are used together, you can vary the degree of
transmission. By causing the amount of transmitted light to vary, the filters become,
in effect, a continuously variable neutral density filter. At
maximum density, the Polarizing Filter Set transmits only 5%
of entering light.
Skylight Filter/Dust Seal – #93621
If you were to use only one filter, Celestron’s Skylight
Filter/Dust Seal would be your most versatile choice. This
general purpose, Wratten #1A filter improves color saturation
and balance, increases visual and photographic contrast, helps
to decrease glare in lunar and planetary observing, and penetrates atmospheric haze.
It’s also an inexpensive way to protect your investment in quality optics. This filter
threads onto the rear cell of your Celestron C5, C8, C91/4, C11 or C14 telescope to
serve as an effective dust seal. By leaving the Skylight Filter/Dust Seal on when
removing or attaching other visual accessories, you prevent dust and other atmospheric contaminants from entering the rear of your telescope. Needless to say, it’s much
easier to clean a dusty filter than a dusty primary mirror, secondary mirror and
corrector plate.
The Skylight Filter/Dust Seal must be threaded onto the rear cell of the instrument
before any other accessory is installed. The female end attaches to the rear cell of the
C5, C8 and C91/4 telescopes and the reducer plate of the C11 and C14 telescopes. All
additional accessories mount onto the exterior/male threads.
Moon Filters
Celestron’s Moon Filters are economical eyepiece filters for
reducing the brightness of the moon and improving
contrast, so greater detail can be observed on the lunar
surface. The clear aperture is 21mm for the 11/4" filter and
10mm for the .96" filter. Transmission is about 18%.
11/4" Moon Filter [94119-A]
.96" Moon Filter (for Economy and SMA Series
eyepieces) [94119-B]
Solar Filters
Celestron’s Solar Skreen® solar filters
transmit .001% of visible light, allowing
direct observation of the sun. You can see
sunspots and the mottled areas known as
granules with these filters. In addition to
reducing the intensity of the sun’s visible
light, they also block 99.999% of invisible
infrared light, so you can observe the sun
in complete safety and comfort.
The material used to make these filters is a
strong, precision engineered, aluminized
Clockwise: #94162,
polyester film known as Mylar. Each filter
#94134, #94131, #94135
consists of two sheets of Mylar. A layer of
aluminum is vacuum-deposited on each of these pieces of Mylar. The two
coated surfaces are then placed against each other to protect them from
scratching and other abuses. The material is very thin, about .0003", which is
about one-tenth the thickness of a human hair. Mylar offers superior performance to thicker filters and is less expensive than conventional glass filters. In
addition, glass filters are subject to breakage whereas the mylar filters are more
Mylar is a very flexible substance by nature. In fact, when the Solar Skreen is
mounted in the filter cell, it will be quite wrinkled. Don’t be fooled by appearance, because the best resolution is obtained when the material is slightly
relaxed or wrinkled.
The color of the solar image will look different than it does with other filters.
The aluminum coating creates a solar image that’s a cool, pale blue color. A
more true color image can be obtained with the appropriate correction filter:
either #21 Orange or #23A Light Red.
F60s & F60EQs [94131]
F70s, F80s and C80s [94135]
F114s and C114s [94134]
C8s [94162]
LPR Filters
Light Pollution Reduction (LPR) Filters are
designed to selectively reduce the transmission
of certain wavelengths of light, specifically
those produced by artificial light. This
includes mercury, and both high and low
pressure sodium vapor lights. In addition, they
block unwanted natural light caused by
neutral oxygen emission in our atmosphere
(i.e. sky glow). As a result, Celestron LPR
Filters darken the background sky, making
deep-sky observation and photography of
nebulae, star clusters and galaxies possible
from urban areas. LPR Filters are not used for
lunar, planetary or terrestrial photography.
While blocking unwanted light, Celestron LPR Filters permit the transmission of more desirable wavelengths. The wavelengths
included are hydrogen alpha,
hydrogen beta, doubly ionized
oxygen and singly ionized
nitrogen. This will improve your
viewing of emission nebulae,
both from urban and rural
settings. Some examples of
objects that will show improved
contrast are: the Orion Nebula,
the Rosette Nebula, the North
American Nebula, the Veil
Nebula and the Helix Nebula.
The latest generation of
Celestron LPR Filters is made of
high quality, flat, polished
optical glass. These units are not
laminated! With over 40 layers
of coating, these filters are stateof-the-art. They’re also protected with a broadband anti-reflection coating to
prevent ghosting and to improve contrast. They provide superior performance and contrast over competitive models.
LPR Filter – for 11/4" eyepieces [#94126A]
LPR Filter – for rear cell of Celestron’s C5, C8 or C91/4 [#94127A]
(Fits on the reducer plate of C11 and C14 telescopes.)
To allow automatic tracking of celestial objects,
Celestron offers several motor drives. All models
include a hand controller, which makes observing more fun as it makes centering objects
much easier. In addition, the hand controller
can be used as a drive corrector for long exposure celestial photography.
Economy Models
These models are single axis (R.A.), DC motor
drives. They are powered by four D-cell batteries
(not included). 2x and 4x sidereal speeds are
available through the included hand controller.
Model #93515 — MDCG-3 (for Firstscope 80s and 114s)
Model #93517 — MDCG-4 (for CG-4 mounts)
Model #93518 — MDCG-5 (for CG-5 mounts)
Deluxe Model — Polaris Motor Drive System – #93820-C
This dual axis motor drive, with drive corrector capabilities, is designed for
Celestron’s CG-5 and GP mounts. It precisely controls the telescope’s
tracking speed during long, timed exposures of celestial objects, producing
the best possible image sharpness. Precision drive correctors are a must for
those with a serious interest in astrophotography or
CCD imaging. Three speeds are available — (1x)
sidereal, 1.3x for guiding and 6x for centering.
This precision, state-of-the-art DC motor drive
operates on a 9 volt battery (not included). The hand
controller module is very compact and fits easily in
the palm of your hand. Motors for both axes are
included, along with brackets, clutches and hardware. Made in the USA.
Declination Motors
Celestron’s Declination Motor attaches to your
telescope’s manual declination control to offer
smooth, vibration-free control in declination.
Run by the telescope’s power supply, it plugs
directly into the drive base and is controlled by
two buttons, for north and south declination
movement. Highly useful for observing, and a
must for astrophotography.
DEC Motor for C5+ [93547]
DEC Motor for Celestar 8, Ultima 91/4 & 11
Guiding (or reticle) eyepieces are mandatory for guided
astrophotography. They keep a guide star stationary
during long exposures to avoid star trailing. #94169 and
#94170 require an illuminator — choose from models
#60001 and #60011.
12mm Kellner Reticle Eyepiece: 11/4" –
The reticle pattern is a .0075" spaced double line system.
The optics are fully coated and offer good eye relief. This
type of reticle pattern allows you to position the guide star
in the middle square or at the intersection of two lines,
whichever is easier for you. It has a 42° apparent field of view.
Clockwise: #94171,
#94169, #94170
10mm Plössl Reticle Eyepiece: 11/4" – #94169
This five element guiding eyepiece has the same pattern as the Kellner
design above. The optics are multi-coated for increased contrast and
have long eye relief. The high power is ideal for guiding and it has a
50° apparent field of view.
Micro Guide Eyepiece: 11/4" – #94171
This multi-function guiding eyepiece features a laseretched reticle with a built-in, battery illuminator. The
eyepiece is a multicoated 12.5mm Abbe (four element)
Orthoscopic. Usage possibilities include: direct guiding on
stars outside the center of the field of view; greatly
improved off-axis guiding to capture much fainter, sharply
focused guide stars without reducing limiting magnitude;
and measuring position angles and separation of double
The Micro Guide Eyepiece is totally free of internal
reflections and offers sufficient eye relief for the reticle to be viewed easily, even with
eyeglasses. Its finely etched micrometer scale has gradations 50 microns apart and 15
microns wide. Included are: the eyepiece, built-in cordless illuminator with adjustable
brightness control, batteries and instructions. The apparent field of view is 42°.
Standard Illuminator — #60011
An adjustable brightness red LED which can be used in
Celestron (and most other manufacturers) guiding eyepieces
and the Polaris finderscope.
Pulstar Illuminator – #60001
Celestron’s Pulstar Illuminator is an innovative new design that takes pulsing illuminators to a new level of performance. Not only does it allow for easy adjustment of
pulsing rates and timing intervals, it also has an adjustable brightness level and
important automatic shutdown feature to save you the frustration of a dead battery.
The Pulstar Illuminator improves contrast while locating and
using guide stars for CCD imaging and astrophotography, and
helps in locating objects during viewing sessions. Fits most
reticle eyepieces and Polaris finderscopes. Battery is included.
Made in the USA.
Reducer/Corrector f/6.3 – #94175
This combination focal reducer and field corrector lens
accessory works with all Celestron C5, C8, C91/4 , C11
and C14 telescopes. This clever accessory makes it
possible to have a dual focal ratio instrument, without
sacrificing image quality. The Reducer/Corrector is f/6.3
for C5, C8, C91/4 and C11 telescopes and f/7 for the C14
If offers wide fields of view with any SchmidtCassegrain telescope. Used for astrophotography, it reduces exposure time by a
factor of 3.
Celestron doesn’t offer a f/6.3 Schmidt-Cassegrain telescope, because the
design is impractical, with a large central obstruction, and resulting loss in
contrast. This, added to the inability to utilize longer focal ratios for certain
objects, led Celestron to design the four-element, fully multicoated f/6.3
Reducer/Corrector. Results are amazing both visually and photographically.
Radial Guider – #94176
Specifically for use in prime focus, deep-sky imaging or astrophotography with
Schmidt-Cassegrain telescopes, the Radial Guider is compact and sleek in
design. This accessory makes it possible to simultaneously photograph and guide through the optical
tube assembly of your telescope. The Radial Guider
also eliminates the problem of differential flexure,
because you’re both guiding and photographing
through the telescope.
The Radial Guider is compatible with Celestron’s
C5, C8, C91/4, C11 and C14 telescopes and comes
with a unique prism angle adjustment screw. It
must be used with a guiding eyepiece, camera TRing and drive corrector (dual axis preferred).
Primarily for use with catadioptric telescopes, but also works on refractor
telescopes having adequate back focus.
This guider is a tremendous improvement over conventional off-axis guiders.
Not only is the angle of the prism tunable, but it also maintains a fixed rigid
camera orientation while still offering users the freedom to move the guiding
eyepiece radially about 135°.
Hand Controller – #28983
For use with the C5+ and Celestar 8, both for astrophotography
and CCD imaging. It’s also great for observing, where it serves
to make centering objects easier. Provides easy centering and
guiding on both axes. (Requires declination motor for use of the
declination axis).
Focus Motors
These motors allow you to focus the telescope electronically,
instead of manually. The motorized
focuser eliminates the possibility of
bumping or shaking the telescope when
focusing. The motor speed is variable, to
make fine focusing a snap.
Focus Motor for Ultima 91/4 , 11 and
2000 [94143]
Focus Motor for all C8s and C11s with
separate hand control [94142]
60mm Guidescope – #22212
A 60mm Guidescope of 700mm focal
length. Comes standard with a 11/4" mirror
diagonal and 5x24 finderscope. Includes
hardware and tube rings to mount it onto a
C8 telescope. A necessary accessory for
guiding longer exposures.
Using accessories such as cameras, Lens Shades, Tele-Extenders and the 2"
Diagonal will affect the balance of your Celestron Schmidt-Cassegrain telescope.
Counterweights restore proper balance, increasing ease in handling and improved
tracking accuracy.
You don’t need perfect balance to operate your telescope. In fact, it’s not always
possible to achieve perfect balance with fixed-position weights. All you need to
do is reduce, or eliminate, swing when R.A. and DEC locks are released. Celestron
counterweights help you achieve the desired balance and stability with ease.
Counterweight Bar Assemblies
The Counterweight Bar Assembly is a metal rod that runs the length of the
telescope tube. It attaches to both the front and
rear cells. Once the Bar Assembly is in place,
counterweights can be attached to it and moved
along its length, as well as perpendicular to it, for
better dynamic balancing. Each Counterweight
Bar Assembly comes with mounting hardware and
one 2.5 lb. weight.
Counterweight Bar Assembly – 8" [94191]
Counterweight Bar Assembly – 91/4" [94196]
Counterweight Bar Assembly – 11" [94192]
Extra Weight – 2.5 lbs. [94193]
Extra Weight – 5 lbs. [94194]
Counterweight Set: Ultima® 2000 – #94190
The standard set of weights works well when using
standard accessories, but when adding heavier
optional accessories, you’ll require this optional set of
weights to achieve proper balance. The set contains
one large and four small weights.
Lens Shades/Dew Caps
A Lens Shade/Dew Cap is a tube, of approximately the same diameter as your
telescope tube, designed to fit on the front end of the telescope to reduce the
amount of dew that builds up on the corrector plate. It
also serves as a Len Shade by preventing stray light
from falling on the corrector plate, which greatly
improves contrast.
The C8 Lens Shades are made of rugged plastic, and
have a tapered design (other designs made with
different materials cause vignetting). They snap easily
onto the front cell of all of Celestron’s C8 telescopes.
Dewstar Lens Shade – C8 [94017]
Lens Shade – Ultima® 2000 and C8 [94019]
A T-Adapter allows you to attach your
35mm SLR camera to the prime focus of
your telescope or spotting scope. This
arrangement is used for terrestrial photography and short exposure lunar and planetary
photography. It can also be used for long
exposure deep-sky photography when using
a separate guidescope.
Both a T-Adapter and T-Ring are required to
mount a camera to your instrument.
T-Adapters are available for the following
Celestron instruments — some instruments have built-in T-Adapters (see your
instruction manual):
#93625—Universal 11/4" T-Adapter. Fits (drop in style) any type of telescope that uses a 11/4" focuser or
visual back.
#93640—Universal 11/4" T-Adapter. Similar to #93625 but in addition includes an integral 2x Barlow
lens which can be used visually or photographically.
#93632—Universal .96" T-Adapter. Fits (drop in style) any type of telescope that uses a .96" focuser.
#93634-A—for Firstscope 80AZ and EQ models. Also fits various older style Celestron refractors and
#93633-A—for all Schmidt-Cassegrains. It threads onto the rear cell.
#93635-A—for all C90 Spotting Scopes.
#94177—required when using the Radial Guider for CCD imaging.
#93638—for Nature Zoom Spotters.
#93628—for Pro Zoom Spotters.
#93627—for Wildlife Zoom Spotters.
#1836—for Ultima Spotters.
FPO (pick up)
T-Rings – 35mm
A T-Ring couples your 35mm camera body to a T-Adapter, Radial Guider or
Tele-Extender. This accessory is required if you want to do any type of photography through a telescope or spotting scope. Each camera manufacturer has a
different mount, which requires a specific T-Ring, so Celestron offers a full line
of T-Rings.
To use a T-Ring, remove the diagonal and/or eyepiece from your telescope
(some models require use of an eyepiece — see your instruction manual). Then
you need only remove your normal camera lens, attach the proper T-Ring for
your camera, and mount the combination to the rear cell of your telescope or
spotting scope with a Celestron T-Adapter. Models available:
Canon [93413]
Canon EOS [93419]
Minolta [93400]
Minolta Maxxum [93418]
Nikon [93402]
Olympus [93414]
Pentax – Universal M42 Thread Mount [93401]
Pentax K – Universal Bayonet Mount [93403]
If you own an older camera with a thread mount, it will probably accept the
Pentax Universal Thread Mount T-Ring. If you have a new camera with a
bayonet mount not listed above (Ricoh, Cosina, etc.), it most likely accepts the
Pentax K-Universal Bayonet Mount T-Ring. Check your camera’s instruction
manual for more detailed information.
Deluxe Tele-Extender – #93643
The Deluxe Tele-Extender for Schmidt-Cassegrain telescopes is
a hollow tube that allows you to attach a camera to your
telescope, with an eyepiece installed. By using the Deluxe TeleExtender in combination with an eyepiece, you can increase
your instrument’s effective focal length to well over
10,000mm! And this corresponds with a matching increase in
image size. This technique is known as eyepiece projection
photography. The following formula can be used to determine
approximate effective focal length:
EFL = Telescope focal length/Eyepiece focal length x DF (the distance from the center of the eyepiece
to the film).
The Deluxe Tele-Extender is used for high-power lunar, solar and planetary photography as well as for
extreme terrestrial photography. It fits over the telescope’s eyepiece (even large eyepieces such as
those in Celestron’s Ultima line), and connects to the visual back of the telescope. Optional
counterweights will be necessary to properly balance the telescope when using the TeleExtender.
To use the Deluxe Tele-Extender, remove the diagonal from your telescope and insert an
eyepiece directly into the visual back. Place the Tele-Extender over both the eyepiece
and the visual back, then attach your 35mm SLR camera to the back of the Tele35mm
Extender, using a T-Ring. The Tele-Extender’s built-in safety device will help
prevent your eyepiece from becoming accidentally dislodged.
There are a few things to keep in mind when using this accessory. First, the
image you’ll see through your camera’s viewfinder will be upside-down.
Visual Back
Secondly, due to the extremely high magnifying effect afforded by
this accessory, extra care to prevent camera and telescope vibration,
accurate polar alignment and use under good seeing conditions
will all assist you in capturing high quality images.
Piggyback Mounts
Celestron’s Piggyback Mounts are a great accessory for all observers
interested in deep-sky astrophotography, particularly beginners. These
mounts allow you to attach your camera, with its lens, to either the
top or side of the telescope, making it possible to shoot with a normal
or wide angle lens while guiding through the telescope.
One model fits the C8, C9 1/4", C11 and C14 telescopes and mounts to
the rear cell of the telescope. The C5 model includes a weight set and
mounting hardware to attach the camera to the telescope’s piggyback
Piggyback Counterpoise – 5" [93603]
Piggyback Mount – 8", 91/4", 11", 14" [93598]
T-C 16mm Adapter – #93636
This valuable adapter converts video cameras, (or 16mm film cameras)
with removable lenses from the standard “C-mount” thread, to the
larger T-thread used in still cameras. Thus, any of these cameras can be
converted for use with a telescope.
To adapt a C-mount camera for use with a Celestron instrument, first
thread the T-C Adapter onto the camera, next thread a T-Adapter onto
the T-C Adapter, and last, thread this assembly onto the rear cell of
your Celestron instrument.
Please note that some film and video cameras use standard still camera lenses, and therefore
use a normal T-Adapter and T-Ring. Check your camera’s instruction manual for more detailed
Digital Setting Circles: Advanced Astro
Computerize your telescope! This pointing
system contains a database of over 10,000
objects. Once aligned, it will guide you to any
one of these objects. Included are the entire
RNGC catalog, the Messier catalog, IC catalog
(selected objects), major planets, over 241
interesting double and multiple stars, and a user
definable catalog of 25 objects!
Can be used with or without an equatorial
mount, eliminating the need to polar align, enter longitude or time. Gives a
scrolling description of each object, directs you from object to object, and
immediately aligns on the object currently viewed. The 16 character LED
readout provides object coordinates, magnitude, type, common name, constellation and additional description. Operates on a 9 volt battery (included),
weighs 6 ounces and is easy to install.
It contains a RS-232 serial interface to PC programs. The module is sold
separately and installation kits are available for various telescopes. The kit
contains two optical encoders, cables and all necessary brackets and hardware.
Made in USA.
Advanced Astro Master Module [93900]
Installation Kits:
For Celestar 8, Celestar 8 Deluxe, Ultima 91/4 & 11 [93911]
For CI 700 Mount [93908]
For G-9 and G-11 Mounts [93915]
Cable for AAM RS-232 Port [93921]
Peterson First Guides® — Astronomy — #93728
A simplified field guide to the stars, planets and the universe. A great road map
for those starting out in
Peterson First Guides® —
Birds — #93731
A simplified field guide to the
common birds of North
America. Very easy to understand, especially for beginners.
A simple and inexpensive tool for all levels of observers,
from naked eye viewers to users of highly sophisticated
telescopes. The Celestron Planisphere makes it easy to
locate stars for observing and is a great planet finder as
well. A map of the night sky, oriented by month and
day, rotates within a depiction of the 24 hours of the
day, to display exactly which stars and planets will be
visible at any given time. Ingeniously simple to use, yet
quite effective. Made of durable materials and coated for
added protection.
The Celestron Planisphere comes in three different
models, to match the latitude from which you’re
For 20° to 40° latitude [93720-30]
For 30° to 50° latitude [93720-40]
For 40° to 60° latitude [93720-50]
CD-ROM – #93700
Celestron and Software Bisque have teamed up to present
a comprehensive CD-ROM called The Sky™ Level 1 – for
Celestron. A computerized sky map that features a 10,000
object database, 75 color images, horizontal projection,
custom sky chart printing, and zoom capability. A fun,
useful and educational product. PC format.
Sky Maps – #93722
Celestron Sky Maps are the ideal teaching guide for learning the night sky. You
wouldn’t set off on a road trip without a road map, and you don’t need to try to
navigate the night sky without a map either. Even if you already know your way
around the major constellations, these maps can help you locate all kinds of fascinating objects.
The front cover has a specially designed
luminous planisphere that rotates to
simulate the seasonal progression of
celestial objects through the sky. When the
planisphere is pre-exposed to light, star
positions glow brightly against a dark
background, mimicking actual constellations. More than a thousand stars and deepsky objects are listed and charted. The
illustrated reference section provides basic
information and the visual characteristics of
various types of stars, nebulae and galaxies.
The maps measure 133/4" x 111/2" and are
printed on a heavyweight, moisture
resistant card stock. The pages have a special comb binding so they can lay flat or be
folded over.
Enjoy your telescope in a completely new and fascinating way — use your brain to
its full capacity rather than speculating on the next, larger size telescope.
The Stereo Binocular Viewer (#93690) allows you to adapt two eyepieces to the
telescope for simultaneous viewing (i.e., like binoculars). The result: a fantastic three
dimensional effect when observing many celestial objects. The Stereo Binocular
Viewer greatly improves contrast and definition on lunar, planetary and solar subject
matter as well as on deep sky objects.
Using both eyes to view through a telescope is a new, relaxed and thrilling way to at
last enjoy your observing time. When both eyes are open, your eye muscles are
relaxed and you do not suffer from eyestrain.
To demonstrate just one of the effects you will see, compare an eye chart when
examining your eyes. Cover one eye and read the chart to the smallest line you can
see clearly. Now remove the cover over the eye, relax for a few seconds and then
examine the chart with both eyes open — you can see more detail than with one
eye. In addition, the brain corrects for small defects (aberrations) of the eyes when
given the information from both eyes.
Beyond a 50 foot distance, pupils are nearly parallel and prevent real stereoscopic
viewing. However, since our brain “knows” (due to near distance experience), we
identify distant objects as three dimensional. The more experienced the observer, the
more this effect will be apparent.
The optics are precision aligned and MgF2 coated. Interpupillary adjustment reaches
from 53mm to 76mm. The optical head has a 60° viewing angle for a comfortable
viewing position. Full 360° head rotation is provided, together with 2" sleeve and
11/4" drawtube to fit 2" Focuser and 11/4" Visual Backs of all Schmidt-Cassegrains —
and also Focusers of Refractors.
The removable 11/4" drawtube features a camera T-2 thread on the Binocular side and
11/4" Filter Thread on the entrance side, to accept Celestron 11/4" Eyepiece Filters.
Utilizes 11/4" eyepieces (not included). Must use two eyepieces of equal focal length
and design type. Made in Germany.
Photographic/Video Tripod – #93596
For use with photographic and visual instruments fitted with a
standard 1/4" x 20 threaded hole. The Photo Tripod provides
stable support for video cameras, telephoto lenses, spotting
scopes and binoculars. This tripod boasts a number of deluxe
features, including: oil fluid pan head, peg for video camera
attachment, quick release pan head, adjustable aluminum legs,
adjustable central column, extendible length vertical pan
handle, and retractable metal feet for added traction on a
variety of surfaces. New clamp-style leg locks. Both lightweight
and reliable.
Alt-Az Photo Tripod Mount – #91533-A
This heavy-duty mount is perfect for cameras with large
telephoto lenses, and for spotting scopes and binoculars. If you
already own a small telescope mount and are interested in one
offering greater stability, the Alt-Az is an ideal upgrade. The
adjustable wood tripod comes with two slow motion cables and
is equipped with a 1/4" x 20 photo head. It’s the same mount
that’s supplied with Celestron’s Firstscope 80AZ telescope.
Slow Motion Controls for Photographic
Have you ever tried to use a powerful telephoto lens or
spotting scope with a standard photographic tripod? If so, you know that it isn’t
easy. Try to adjust the position of the lens to follow a target and you’ll discover that
just touching the lens can cause so much vibration, it can be difficult to even find the
target, let alone center it. By using Celestron’s Slow Motion Controls between your
lens/spotting scope and your photographic tripod, you gain accurate slow motion
adjustment in both elevation and azimuth (i.e. up/down
and left/right).
The Tripod Slow Motion Controls fit on top of any
standard photo tripod and have a large stable base with a
standard 1/4" x 20 mounting screw to attach a camera,
telephoto lens, spotting scope or binocular. Makes bird
watching and telephotography easy!
The deluxe model has ultra smooth controls and virtually
no backlash.
Tripod Slow Motion Controls [93804-A]
Deluxe Tripod Slow Motion Controls [93804-DX]
Mini Table Tripod – #93599
A very sturdy tripod designed for tabletop or platform use,
where portability is important. It has rugged, metal construction
and features slow motion controls for fine tuning when
acquiring a target object. Works well with most spotting scopes
and binoculars with a 1/4" x 20 adapter. It weighs under two
pounds and has a height adjustment range of 12" to 17".
Lightweight Field Tripod – #93591-A
Designed for Celestron’s C5 telescope, this rigid,
metal tripod weighs less than 10 lbs. and is very
compact when folded up. It’s great for traveling.
It can be used with the Celestar 8 telescope
when high portability is required.
An optional accessory tray (#93594) is available
for this tripod. Not only is the tray handy for
small accessories, but it also enhances the
overall rigidity of the tripod.
Adjustable 8" Tripod – #93499
This deluxe metal tripod has fully adjustable
legs with all metal clamps for positive
height adjustment. It’s designed for
Celestron’s C8, C91/4 and C11 telescopes,
and also makes a very stable and sturdy
platform for the C5+ telescope. A new leg
support has been added for additional
stability and the 2" diameter legs provide
excellent damping.
Vibration Suppression Pads –
Telescope and spotting scope vibration is
caused by windy conditions, an unsteady mount or tripod or even an
accidental bump to the instrument, and results in reduced image quality.
Celestron’s set of three Vibration Suppression Pads will reduce vibration time
by almost 100% and decrease vibration amplitude. The pads fit between the
bottom of the tripod legs
and the ground, a simple
and functional solution to
the problem of image
disturbance. They work on
any surface: grass, dirt,
concrete, asphalt, wood,
etc., for both telescopes
and spotting scopes.
For optimal performance in astronomical observing
that involves setting circles or motorized tracking,
Celestron’s telescopes with a fork mount and motor
drive must be mounted on an Equatorial Wedge. The
wedge allows you to tilt the telescope so that its polar
axis (R.A. axis) is parallel to the earth’s axis.
The angle of tilt will depend on your latitude when
the telescope is level. The angle between the horizon
level and the polar axis will equal your latitude when
the telescope’s axis is parallel with that of the earth’s.
Once properly mounted and adjusted on the wedge,
the telescope is said to be equatorially mounted and
its setting circles can be used to locate deep-sky
Left: #93656
Right: #93654
C5 Wedge — #93654
Is standard with the C5+ telescope. An optional upgrade for the C8 telescope is to use
the C5 Wedge, which allows the C8 to be used more easily as a tabletop telescope. The
C5 Wedge comes with height adjustment screws and
a bubble level, and has a latitude range of 0° to 90°.
Standard C8 Wedge — #93656
Is Standard with the Celestar 8 Deluxe telescope. It
can be used as an upgrade for the basic Celestar 8
telescope when used with an adjustable tripod or as a
tabletop telescope.
Deluxe Latitude Adjuster – #93528
Raise and lower the tilt plate of the C8 wedge
(#93656) with fine precision, using Celestron’s Deluxe
Latitude Adjuster. Used during the polar alignment
process, this adjuster is a real time saver. Especially convenient if you observe from a
variety of different sites, which necessitates readjusting your polar alignment for each
The Deluxe Latitude Adjuster consists primarily of a heavy-duty latitude adjustment bar
with a large central adjustment knob. Also included are bolts with oversized knobs for
attaching the telescope to the wedge, and for locking
the tilt plate to the side of the wedge.
with #93662
Heavy-Duty Wedge — #93655
For Celestron‘s C8 and C11 telescopes. It is available
for the more serious observer. It is standard with the
Ultima 91/4 and Ultima 11 telescopes. It is sold as an
option for Ultima 2000 — 8" telescopes. It can also be
used as an upgrade for the standard C8 telescopes. It
increases the rigidity of the telescope while giving a 0°
to 90° range of operation. An upgrade kit with a
deluxe latitude adjuster and azimuth controls for easy
polar alignment is available (#93662).
Telescope Equatorial Mount –
CG-3 – #91503
A durable, rigid, German equatorial mount with a
wooden tripod, offering both affordability and
high quality. Designed as an excellent and inexpensive upgrade option when you’re ready to
move to a sturdier mount for your beginning
telescope. R.A. and DEC setting circles, a latitude
scale, slow motion controls and a handy accessory
tray are included. This is the same mount
Celestron uses with the Firstscope 80EQ and 114
Telescope Equatorial Mount – CG-4 – #91510
The CG-4 mount is a very rigid German equatorial mount. A counterweight,
latitude scale, setting circles and slow motion controls on both axes are
standard. The adjustable height aluminum, very
rigid tripod has excellent damping characteristics
and a handy accessory tray. It is the same mount as
used on Celestron HD telescopes.
Optional motor drives and a polar alignment
finderscope are available.
Telescope Equatorial Mount –
CG-5 – #91515
The CG-5 EQ mount is the newest generation of
Celestron’s German mounts (replaces the GP
mount). Both axes of the equatorial mount have
precision worm gears for extremely smooth motion.
It is a step up from the CG-4.
This heavy duty mount delivers jitter-free images
easily and the adjustable height aluminum, very
rigid tripod has excellent damping characteristics
and a convenient accessory tray.
Included are setting circles on both axes, slowmotion controls and latitude scale. An adjustable
counterweight makes it easy to point, balance and
An optional polar alignment scope for fast polar
alignment as well as motor drives are available for
easy tracking.
A. Celestron International (CI) warrants its accessories to be free from defects in materials
and workmanship for one year. CI will repair or replace such product or part thereof
which, upon inspection by CI, is found to be defective in materials or workmanship.
As a condition to the obligation of CI to repair or replace such product, the product
must be returned to CI together with proof-of-purchase satisfactory to CI.
B. The proper Return Authorization Number must be obtained from CI in advance of
return. Call Celestron at (310) 328-9560 to receive the number to be displayed on the
outside of your shipping container.
All returns must be accompanied by a written statement setting forth the name, address
and daytime telephone number of the owner, together with a brief description of any
claimed defects. Parts or product for which replacement is made shall become the
property of CI.
The customer shall be responsible for all costs of transportation and insurance, both to and from the factory of CI, and shall be required to prepay
such costs.
CI shall use reasonable effort to repair or replace any accessory covered by this warranty
within thirty days of receipt. In the event repair or replacement shall require more than
thirty days, CI shall notify the customer accordingly. CI reserves the right to replace any
product which has been discontinued from its product line with a new product of
comparable value and function.
This warranty shall be void and of no force of effect in the event a covered
product has been modified in design or function, or subjected to abuse,
misuse, mishandling or unauthorized repair. Further, product malfunction
or deterioration due to normal wear is not covered by this warranty.
CI disclaims any warranties, express or implied whether of merchantability or fitness for a
particular use, except as expressly set forth herein.
The sole obligation of CI under this limited warranty shall be to repair or replace the
covered product, in accordance with the terms set forth herein. CI expressly disclaims any
lost profits, general, special, indirect or consequential damages which may result from
breach of any warranty, or arising out of the use or inability to use any CI product. Any
warranties which are implied and which cannot be disclaimed shall be limited in
duration to a term of one year from the date of original retail purchase.
Some states do not allow the exclusion or limitation of incidental or consequential
damages or limitation on how long an implied warranty lasts, so the above limitations
and exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
CI reserves the right to modify or discontinue, without prior notice to you, any model or
style of accessory. If warranty problems arise, or if you need assistance in using your
accessory contact:
Celestron International
Customer Service Department
2835 Columbia Street, Torrance, CA 90503 U.S.A.
(310) 328-9560, Fax (310) 212-5835
Monday - Friday 8 a.m. - 4 p.m. PST
This warranty supersedes all other product warranties.
NOTE: This warranty is valid to U.S.A. and Canadian customers who have purchased
this product from an authorized CI dealer in the U.S.A. or Canada. Warranty outside
the U.S.A. and Canada is valid only to customers who purchased from a CI
International Distributor or Authorized CI Dealer in the specific country. Please
contact them for any warranty service.
Celestron International
2835 Columbia Street
Torrance, CA 90503
TEL (310) 328-9560 • FAX (310) 212-5835
Web site at http//www.celestron.com
#93685-98 $2.00
© 1998 Celestron International
Was this manual useful for you? Yes No
Thank you for your participation!

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project

Download PDF
