Asus M4A89GTD PRO/USB3 Specification

Asus M4A89GTD PRO/USB3 Specification
Motherboard
M4A89GTD
PRO Series
M4A89GTD PRO/USB3
M4A89GTD PRO
E5471
First Edition (V1)
April 2010
Copyright © 2010 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless
such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identification or explanation and to the
owners’ benefit, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product may contain copyrighted software that is licensed under the General Public License (“GPL”)
and under the Lesser General Public License Version (“LGPL”). The GPL and LGPL licensed code in this
product is distributed without any warranty. Copies of these licenses are included in this product.
You may obtain the complete corresponding source code (as defined in the GPL) for the GPL Software,
and/or the complete corresponding source code of the LGPL Software (with the complete machinereadable “work that uses the Library”) for a period of three years after our last shipment of the product
including the GPL Software and/or LGPL Software, which will be no earlier than December 1, 2011, either
(1) for free by downloading it from http://support.asus.com/download;
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
15 Li Te Rd.,
Beitou, Taipei 112
Taiwan
In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source code
we would be much obliged if you give us a notification to the email address [email protected], stating the
product and describing the problem (please do NOT send large attachments such as source code archives
etc to this email address).
ii
Contents
Contents....................................................................................................................... iii
Notices....................................................................................................................... vii
Safety information..................................................................................................... viii
About this guide.......................................................................................................... ix
M4A89GTD PRO Series specifications summary.................................................... xi
Chapter 1:
Product introduction
1.1
Welcome!..................................................................................................... 1-1
1.2
Package contents....................................................................................... 1-1
1.3
Special features.......................................................................................... 1-2
1.3.1
Product highlights........................................................................ 1-2
1.3.2
ASUS Xtreme Design—Hybrid Processor................................... 1-2
1.3.3
ASUS Xtreme Design—Hybrid Switches..................................... 1-3
1.3.4
ASUS Xtreme Design—Hybrid OS.............................................. 1-3
1.3.5
ASUS unique features................................................................. 1-3
Chapter 2:
2.1
2.2
2.3
2.4
2.5
Hardware information
Before you proceed.................................................................................... 2-1
Motherboard overview................................................................................ 2-2
2.2.1
Motherboard layout...................................................................... 2-2
2.2.2
Layout contents............................................................................ 2-3
2.2.3
Placement direction..................................................................... 2-4
2.2.4
Screw holes................................................................................. 2-4
Central Processing Unit (CPU).................................................................. 2-5
2.3.1
Installing the CPU........................................................................ 2-5
2.3.2
Installing the CPU heatsink and fan............................................. 2-7
System memory........................................................................................ 2-10
2.4.1
Overview.................................................................................... 2-10
2.4.2
Memory configurations............................................................... 2-11
2.4.3
Installing a DIMM....................................................................... 2-16
2.4.4
Removing a DIMM..................................................................... 2-16
Expansion slots........................................................................................ 2-17
2.5.1
Installing an expansion card...................................................... 2-17
2.5.2
Configuring an expansion card.................................................. 2-17
2.5.3
Interrupt assignments................................................................ 2-18
2.5.4
PCI slots..................................................................................... 2-19
2.5.5
PCI Express 2.0 x4 / x1 slots..................................................... 2-19
2.5.6
PCI Express 2.0 x16 slots.......................................................... 2-19
2.6
Jumper....................................................................................................... 2-21
2.7
Onboard switches..................................................................................... 2-22
iii
Contents
2.8
Connectors................................................................................................ 2-25
2.8.1
Rear panel connectors............................................................... 2-25
2.8.2
Audio I/O connections................................................................ 2-28
2.8.3
Internal connectors.................................................................... 2-30
2.8.4.
ASUS Q-Connector (system panel)........................................... 2-38
2.9
Onboard LEDs........................................................................................... 2-39
2.10
Starting up for the first time..................................................................... 2-41
2.11
Turning off the computer.......................................................................... 2-41
Chapter 3:
3.1
3.2
3.3
3.4
3.5
iv
BIOS setup
Knowing BIOS............................................................................................. 3-1
Updating BIOS............................................................................................. 3-1
3.2.1
ASUS Update utility..................................................................... 3-2
3.2.2
ASUS EZ Flash 2 utility................................................................ 3-4
3.2.3
ASUS CrashFree BIOS 3 utility................................................... 3-5
3.2.4
ASUS BIOS Updater.................................................................... 3-6
BIOS setup program................................................................................... 3-9
3.3.1
BIOS menu screen....................................................................... 3-9
3.3.2
Menu bar...................................................................................... 3-9
3.3.3
Navigation keys.......................................................................... 3-10
3.3.4
Menu items................................................................................ 3-10
3.3.5
Submenu items.......................................................................... 3-10
3.3.6
Configuration fields.................................................................... 3-10
3.3.7
Pop-up window.......................................................................... 3-10
3.3.8
Scroll bar.................................................................................... 3-10
3.3.9
General help.............................................................................. 3-10
Main menu................................................................................................. 3-11
3.4.1
SATA 1–6................................................................................... 3-11
3.4.2
Storage Configuration................................................................ 3-13
3.4.3
System Information.................................................................... 3-14
Ai Tweaker menu....................................................................................... 3-15
3.5.1
CPU Level UP............................................................................ 3-15
3.5.2
OC Tuner Utility.......................................................................... 3-16
3.5.3
Ai Overclock Tuner..................................................................... 3-16
3.5.4
CPU Ratio.................................................................................. 3-17
3.5.5
DRAM Frequency...................................................................... 3-17
3.5.6
CPU/NB Frequency................................................................... 3-17
3.5.7
HT Link Speed........................................................................... 3-17
3.5.8
DRAM Timing Configuration...................................................... 3-17
Contents
3.6
3.7
3.8
3.9
3.10
3.5.9
DRAM Driving Configuration...................................................... 3-18
3.5.10
CPU & NB Voltage Mode........................................................... 3-19
3.5.11
CPU VDDA Voltage.................................................................... 3-19
3.5.12
DRAM Voltage........................................................................... 3-19
3.5.13
CPU Load-Line Calibration........................................................ 3-20
3.5.14
CPU/NB Load-Line Calibration.................................................. 3-20
3.5.15
CPU Spread Spectrum.............................................................. 3-20
3.5.16
PCIE Spread Spectrum.............................................................. 3-20
3.5.17
HT Voltage................................................................................. 3-20
3.5.18
NB Voltage................................................................................. 3-20
3.5.19
NB 1.8V Voltage......................................................................... 3-20
3.5.20
SB Voltage................................................................................. 3-20
3.5.21
SidePort Memory Voltage.......................................................... 3-20
3.5.22
Internal Graphics Mode.............................................................. 3-21
3.5.23
GFX Engine Clock Override....................................................... 3-21
Advanced menu........................................................................................ 3-22
3.6.1
CPU Configuration..................................................................... 3-22
3.6.2
Chipset....................................................................................... 3-23
3.6.3
Onboard Devices Configuration................................................. 3-26
3.6.4
USB Configuration..................................................................... 3-27
3.6.5
PCIPnP...................................................................................... 3-28
Power menu............................................................................................... 3-29
3.7.1
Suspend Mode........................................................................... 3-29
3.7.2
Repost Video on S3 Resume..................................................... 3-29
3.7.3
ACPI 2.0 Support....................................................................... 3-29
3.7.4
ACPI APIC Support.................................................................... 3-29
3.7.5
APM Configuration..................................................................... 3-30
3.7.6
Hardware Monitor...................................................................... 3-31
Boot menu................................................................................................. 3-33
3.8.1
Boot Device Priority................................................................... 3-33
3.8.2
Boot Settings Configuration....................................................... 3-34
3.8.3
Security...................................................................................... 3-35
Tools menu................................................................................................ 3-37
3.9.1
ASUS EZ Flash 2....................................................................... 3-37
3.9.2
Express Gate............................................................................. 3-37
3.9.3
ASUS O.C. Profile...................................................................... 3-38
3.9.4
AI NET 2..................................................................................... 3-39
3.9.5
POST State LEDs...................................................................... 3-39
Exit menu................................................................................................... 3-40
Contents
Chapter 4:
Installing an operating system.................................................................. 4-1
4.2
Support DVD information........................................................................... 4-1
4.2.1
Running the support DVD............................................................ 4-1
4.2.2
Obtaining the software manuals.................................................. 4-2
4.3
Software information.................................................................................. 4-3
4.3.1
ASUS PC Probe II........................................................................ 4-3
4.3.2
ASUS AI Suite.............................................................................. 4-4
4.3.3
ASUS Fan Xpert.......................................................................... 4-5
4.3.4
ASUS EPU................................................................................... 4-6
4.3.5
ASUS Express Gate.................................................................... 4-7
4.3.6
Audio configurations.................................................................... 4-8
4.3.7
ASUS GPU Boost........................................................................ 4-9
4.4
ASUS Unique Overclocking Utility—TurboV EVO.................................. 4-10
4.4.1
Using ASUS TurboV................................................................... 4-10
4.4.2
Using Turbo Unlocker................................................................ 4-11
4.4.3
Using ASUS TurboV Auto Tuning Mode..................................... 4-12
4.4.4
Using CPU Level UP.................................................................. 4-13
4.4.5
Using ASUS Turbo Key.............................................................. 4-13
4.5
RAID configurations................................................................................. 4-14
4.5.1
RAID definitions......................................................................... 4-14
4.5.2
Installing Serial ATA hard disks.................................................. 4-15
4.5.3
Setting the RAID item in BIOS................................................... 4-15
4.5.4
AMD® Option ROM Utility........................................................... 4-16
4.6
Creating a RAID driver disk..................................................................... 4-19
4.6.1
Creating a RAID driver disk without entering the OS................. 4-19
4.6.2
Creating a RAID driver disk in Windows®.................................. 4-19
4.6.3
Installing the RAID driver during Windows® OS installation....... 4-19
4.6.4
Using a USB floppy disk drive.................................................... 4-20
Chapter 5:
vi
Software support
4.1
ATI® CrossFireX™ technology support
5.1
ATI CrossFireX™ technology................................................................... 5-1
5.1.1
Requirements............................................................................... 5-1
5.1.2
Before you begin.......................................................................... 5-1
5.1.3
Installing two CrossFireX™ graphics cards................................. 5-2
5.1.4
Installing the device drivers.......................................................... 5-3
5.1.5
Enabling the ATI® CrossFireX™ technology................................ 5-3
5.2
ATI® Hybrid CrossFireX™ technology....................................................... 5-4
5.2.1
System requirements................................................................... 5-4
5.2.2
Before you proceed...................................................................... 5-4
5.2.3
Installing AMD Chipset Driver...................................................... 5-4
5.2.4
Using the ATI® CATALYST® Control Center................................. 5-5
®
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
•
This device may not cause harmful interference, and
•
This device must accept any interference received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with manufacturer’s instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
•
Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required
to assure compliance with FCC regulations. Changes or modifications to this unit not
expressly approved by the party responsible for compliance could void the user’s authority
to operate this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department
of Communications.
This class B digital apparatus complies with Canadian ICES-003.
REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of
Chemicals) regulatory framework, we published the chemical substances in our products at
ASUS REACH website at http://green.asus.com/english/REACH.htm.
DO NOT throw the motherboard in municipal waste. This product has been designed to
enable proper reuse of parts and recycling. This symbol of the crossed out wheeled bin
indicates that the product (electrical and electronic equipment) should not be placed in
municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol
of the crossed out wheeled bin indicates that the battery should not be placed in municipal
waste.
vii
Safety information
Electrical safety
•
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet
before relocating the system.
•
When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
•
Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
•
Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
•
Ensure that your power supply is set to the correct voltage in your area. If you are not sure
about the voltage of the electrical outlet you are using, contact your local power company.
•
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service
technician or your retailer.
Operation safety
viii
•
Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
•
Before using the product, ensure all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
•
To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
•
Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
•
Place the product on a stable surface.
•
If you encounter technical problems with the product, contact a qualified service
technician or your retailer.
About this guide
This user guide contains the information you need when installing and configuring the motherboard.
How this guide is organized
This guide contains the following parts:
•
Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new technology it
supports.
•
Chapter 2: Hardware information
This chapter lists the hardware setup procedures that you have to perform when
installing system components. It includes description of the switches, jumpers, and
connectors on the motherboard.
•
Chapter 3: BIOS setup
This chapter tells how to change system settings through the BIOS Setup menus.
Detailed descriptions of the BIOS parameters are also provided.
•
Chapter 4: Software support
This chapter describes the contents of the support DVD that comes with the
motherboard package and the software.
•
Chapter 5: ATI® CrossFireX™ technology support
This chapter describes the ATI® CrossFireX™ feature and shows the graphics card
installation procedures.
Where to find more information
Refer to the following sources for additional information and for product and software updates.
1.
ASUS websites
The ASUS website provides updated information on ASUS hardware and software
products. Refer to the ASUS contact information.
2.
Optional documentation
Your product package may include optional documentation, such as warranty flyers,
that may have been added by your dealer. These documents are not part of the
standard package.
ix
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying to
complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to help you complete a task.
Typography
Bold text
Indicates a menu or an item to select.
Italics
Used to emphasize a word or a phrase.
<Key>
Keys enclosed in the less-than and greater-than sign means ��
��������������������������������������
that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or ��
�����������
Return key.
<Key1> + <Key2> + <Key3> If you must press two or more keys simultaneously, the key names are linked with a plus sign (+).
Example: <Ctrl> + <Alt> + <Del>
M4A89GTD PRO Series specifications summary
CPU
AMD® Socket AM3; Phenom™ II / Athlon™ II / Sempron™ 100 Series Processors
AMD® 140W CPU Support
AMD® Cool ‘n’ Quiet™�����������
Technology
Supports 45nm CPU
Chipset
AMD® 890GX / SB850
System bus
Up to 5200 MT/s; HyperTransport™ 3.0
Memory
4 x DIMM, max. 16GB, DDR3 2000(O.C.) / 1333 / 1066 MHz,
ECC / non-ECC, un-buffered memory
Dual channel memory architecture
* Due to the CPU spec., AMD AM3 100 and 200 series CPUs
support up to DDR3 1066MHz. With ASUS design, this
motherboard can support up to DDR3 1333MHz.
** When you install a total memory of 4 GB capacity or more,
Windows® 32-bit operating system may only recognize less
than 3 GB. We recommend using a maximum of 3 GB system
memory if you are using a Windows® 32-bit OS.
*** R
efer to www.asus.com or this user manual for the Memory
QVL (Qualified Vendors Lists)
Expansion slots
2 x PCI Express 2.0 x16 slots�������������
, support ATI® CrossFireX™
Technology ���
(@ ��������������
dual x8 speed)
1 x PCI Express 2.0 x4 slot
1 x PCI Express 2.0 x1 slot
2 x PCI slots
VGA Output
Integrated ATI® Radeon™ HD 4290 GPU
Multi-VGA output support: HDMI, DVI-D, and RGB ports
Supports HDMI with max. resolution 1920 x 1200 (1080P)
Supports DVI with max. resolution 2560 x 1600 @60Hz
Supports RGB with max. resolution 2560 x 1440 @75Hz
Supports H.264, VC-1, MPEG-2, DirectX 10.1 and OpenGL 2.0
Supports Shader Model 4.1, Universal Video Decoder (UVD) 2.0
Maximum UMA memory size: 512 MB
128 MB DDR3 1333 sideport memory support
Hybrid CrossFireX support
Storage
AMD® SB850 chipset
- 6 x SATA 6.0 Gb/s ports with RAID 0, 1, 5, and 10 support
JMicron® JMB361 PATA and SATA controller
- 1 x Power eSATA 3.0 Gb/s port
- 1 x Ultra DMA 133/100 for up to 2 PATA devices
LAN
Realtek® 8111E Gigabit LAN controller featuring AI NET2
Audio
ALC892 8-channel High Definition Audio CODEC
- Supports 192khz/24bit BD Lossless Sound
- DTS Surround Sensation UltraPC
- Supports Jack-Detection, Multi-Streaming, and Front Panel Jack-Retasking
- Optical S/PDIF Out port at back I/O
- ASUS Noise Filter
(continued on the next page)
xi
M4A89GTD PRO Series specifications summary
USB
M4A89GTD PRO/USB3 model
- 2 x USB 3.0 ports (blue, at back panel)
-12 x USB 2.0 ports (8 ports at midboard, 4 ports at back panel)
M4A89GTD PRO model
-14 x USB 2.0 ports (8 ports at midboard, 6 ports at back panel)
IEEE 1394
VIA® VT6308P controller supports 2 x IEEE 1394a ports (one at midboard, one at back panel)
ASUS unique features
ASUS Xtreme Design
ASUS Hybrid Processor – TurboV EVO
-TurboV, Turbo Unlocker, Auto Tuning, CPU Level UP
and GPU Boost
ASUS Hybrid OS – Express Gate
ASUS Hybrid Switches
- Turbo Key II
- Core Unlocker
ASUS Power Solutions
- 8+2 Phase Power Design
- ASUS EPU
ASUS Exclusive Features
- MemOK!
ASUS Quiet Thermal Solutions
- ASUS Fanless Design: Heat pipe solution
- ASUS Fan Xpert
ASUS EZ DIY
- ASUS Q-Design
- ASUS O.C. Profile
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2™
- Multi-language BIOS
ASUS exclusive
overclocking features
Precision Tweaker 3
- vCore: Adjustable CPU voltage at 0.003125V increment
- vDDNB: Adjustable CPU NB voltage at 0.003125V increment
- vCPU PLL: Adjustable CPU PLL voltage at 0.00625V increment
- vHT Bus: Adjustable PCH voltage at 0.00625V increment
- vDRAM Bus: Adjustable DRAM voltage at 0.00625V increment
- vChipset: Adjustable Chipset voltage at 0.00625V increment
SFS (Stepless Frequency Selection)
- Internal Base Clock tuning from 100MHz up to 600MHz at
1MHz increment
- PCI Express frequency tuning from 100MHz up to 150MHz
at 1MHz increment
Overclocking protection
- ASUS C.P.R. (CPU Parameter Recall)
(continued on the next page)
xii
M4A89GTD PRO Series specifications summary
Back panel I/O ports
1 x PS/2 keyboard port (purple)
1 x HDMI Out port
1 x DVI-D Out port
1 x D-Sub Out port
1 x Optical S/PDIF Out port
1 x Power eSATA port
1 x IEEE 1394a port
1 x LAN (RJ-45) port
2 x USB 3.0/2.0 ports (blue), and 4 x USB 2.0/1.1 ports (M4A89GTD
PRO/USB3 model)
6 x USB 2.0/1.1 ports (M4A89GTD PRO model)
8-channel Audio I/O ports
Internal I/O connectors
4 x USB connectors support additional 8 USB ports
1 x IDE connector
6 x SATA 6.0 Gb/s connectors
1 x CPU Fan connector
2 x Chassis Fan connectors (1 x 4-pin, 1 x 3-pin)
1 x Power Fan connector
1 x IEEE1394a connector
1 x S/PDIF Out header
1 x Core Unlocker switch
1 x Turbo Key II switch
1 x MemOK! button
Front panel audio connector
1 x COM connector
24-pin ATX Power connector
8-pin EATX 12V Power connector
System Panel
BIOS features
16 Mb Flash ROM, SPI, AMI BIOS, PnP, DMI 2.0, WfM 2.0,
SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS,
ASUS EZ Flash 2, ASUS CrashFree BIOS 3
Manageability
WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Support DVD contents
Drivers
ASUS Utilities
ASUS Update
Anti-virus software (OEM version)
Form factor
ATX form factor: 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
*Specifications are subject to change without notice.
xiii
xiv
Chapter 1
Chapter 1:
Product introduction
1.1
Welcome!
Thank you for buying an ASUS® M4A89GTD PRO Series motherboard!
Chapter 1
The motherboard delivers a host of new features and latest technologies, making it another
standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it, check the items in
your package with the list below.
1.2
Package contents
Check your motherboard package for the following items.
nual
User Ma
ASUS M4A89GTD PRO Series
motherboard
User guide
Support DVD
2 x Serial ATA 6.0 Gb/s cables
with 6.0 Gb/s label
2 x Serial ATA 3.0 Gb/s cables
1 x Ultra DMA 133/
100/66 cable
1 x ASUS Q-Shield
1 x VGA switch card
1 x 2-in-1 ASUS Q-Connector kit
•
If any of the above items is damaged or missing, contact your retailer.
•
The illustrated items above are for reference only. Actual product specifications may
vary with different models.
ASUS M4A89GTD PRO Series
1-1
1.3
Special features
1.3.1
Product highlights
AMD® Phenom™ II / Athlon™ II / Sempron™ 100 Series Processors (socket AM3)
Chapter 1
This motherboard supports AMD® AM3 multi-core processors with unique L3 cache and
delivers better overclocking capabilities with less power consumption. It features
dual-channel DDR3 1333 memory support and accelerates data transfer rate up to 5200MT/s
via HyperTransport™ 3.0 based system bus. This motherboard also supports AMD® CPUs in
the new 45nm manufacturing process.
AMD® 890GX Chipset
AMD® 890GX Chipset is designed to support up to 5200MT/s HyperTransport™ 3.0 (HT 3.0)
interface speed and PCI Express™ 2.0 x16 graphics. It is optimized with AMD®’s latest AM3
and multi-core CPUs to provide excellent system performance and overclocking capabilities.
Dual-Channel DDR3 2000(O.C.) / 1333 / 1066 support
The motherboard supports DDR3 memory that features data transfer rates of 2000(O.C.) /
1333 / 1066 MHz to meet the higher bandwidth requirements of the latest 3D graphics,
multimedia, and Internet applications. The dual-channel DDR3 architecture enlarges the
bandwidth of your system memory to boost system performance. Refer to page 2-10 for details.
ATI® CrossFireX™ Technology
ATI’s CrossFireX™ boosts image quality along with rendering speed, eliminating the
need to scale down screen resolution to get high quality images. CrossFireX™ allows
higher antialiasing, anisotropic filtering, shading, and texture settings. Adjust your display
configurations, experiment with the advanced 3D settings, and check the effects with a
real-time 3D-rendered previews within ATI Catalyst™ Control Center.
AMD® SB850 Chipset
The AMD® SB850 Southbridge natively supports the next generation SATA 6.0 Gb/s data
transfer rate and PCI Express 2.0 interface.
True USB 3.0 Support (M4A89GTD PRO/USB3 model only)
Experience ultra-fast data transfers at 4.8 Gb/s with USB 3.0–the latest connectivity standard.
Built to connect easily with next-generation components and peripherals, USB 3.0 transfers
data 10X faster and is also backward compatible with USB 2.0 components.
1.3.2
ASUS Xtreme Design—Hybrid Processor*
TurboV EVO
The ultimate O.C. processor satisfies every level of overclockers—from die-hard enthusiasts
to beginners. Auto tuning intelligently pushes the system to the fastest clock speeds while
maintaining stability. Turbo Key boosts performance with just one touch; while TurboV offers
more options to advanced overclockers to achieve world O.C. record. Moreover, upgrade
your CPU at no additional cost with CPU Level UP! Refer to page 4-10 for details.
Turbo Unlocker
Turbo Unlocker is the next evolution of an exclusive ASUS performance boost feature. All it takes
is one click in the TurboV EVO interface and Turbo Unlocker automatically and dynamically
adjusts each CPU core frequency to speed up performance based on actual system load. Turbo
Unclocker gets you in touch with more performance exactly when you need it.
1-2
Chapter 1: Product Introduction
Auto Tuning
Chapter 1
Auto Tuning is an intelligent tool that automates overclocking to achieve a total system level
up. This tool also provides stability testing. Even O.C. beginners can achieve extreme yet
stable overclocking results with Auto Tuning!
GPU Boost
GPU Boost overclocks the integrated GPU in real time for the best graphics performance.
User-friendly UI facilitates flexible frequency and voltage adjustments. Its ability to deliver
multiple overclocking profiles also provides rapid and stable system-level upgrades. Refer to
page 4-9 for details.
1.3.3
ASUS Xtreme Design—Hybrid Switches*
Turbo Key II
Enjoy superb performance by auto-tuning your processor to an extreme yet stable state. Simply
activate a dedicated switch on the motherboard to unleash extra processing capabilities. Refer
to page 2-23 for details.
Core Unlocker
ASUS Core Unlocker simplifies the activation of a latent AMD® CPU—with just a simple
switch. Enjoy an instant performance boost by simply unlocking the extra cores, without
performing complicated BIOS changes. Refer to page 2-24 for details.
* The actual overclocking result depends on the system configuration.
1.3.4
ASUS Xtreme Design—Hybrid OS
Express Gate
Express Gate is an ASUS exclusive OS that provides you with quick access to the Internet and
key applications before entering the Windows® OS. Refer to pages 3-37 and 4-7 for details.
1.3.5
ASUS unique features
ASUS Power Solutions
ASUS Power solutions intelligently and automatically provide balanced computing power and
energy consumption.
8+2 Phase Power Design
To fully unleash the next-generation AM3 CPU’s potential, the ASUS M4A89GTD PRO
Series motherboard has adopted the brand new 8-phase VRM power design, which
delivers high power efficiency and supreme overclocking ability. These high quality
power components effectively lower system temperature to ensure longer component
lifespan. This motherboard also features an extra 2 phase power dedicated to
integrated memory/HT controller.
ASUS EPU
The ASUS EPU (Energy Processing Unit) provides total system power management by
detecting current PC loadings and intelligently moderating power usage for critical PC
components in real-time–helping save power and money! Refer to page 4-6 for details.
ASUS M4A89GTD PRO Series
1-3
MemOK!
Chapter 1
Memory compatibility is among the top concerns during computer upgrades. Worry no more.
MemOK! is the fastest memory booting solution today. This remarkable memory rescue tool
requires nothing but a push of a button to patch memory issues and get your system up and
running in no time. The technology is able to determine failsafe settings that can dramatically
improve your system booting success. Refer to page 2-22 for details.
ASUS Quiet Thermal Solutions
ASUS Quiet Thermal solution makes system more stable and enhances the overclocking
capability.
ASUS Fanless Design—Heat pipe solution
The ASUS heat pipe features 0-dB thermal solution that offers users a noiseless
PC environment. Not only the beautiful shape upgrades the visual enjoyment for
motherboard users, but also the heat pipe design lowers the temperature of the chipset
and power phase area through high efficient heat-exchange. Combined with usability
and aesthetics, the ASUS heat pipe will give users an extremely silent and cooling
experience with the elegant appearance!
Fan Xpert
ASUS Fan Xpert intelligently allows you to adjust both the CPU and chassis fan speeds
according to different ambient temperatures caused by different climate conditions
in different geographic regions and your PC’s loading. The built-in variety of useful
profiles offer flexible controls of fan speed to achieve a quiet and cool environment.
Refer to page 4-5 for details.
ASUS EZ DIY
ASUS EZ DIY feature collection provides you with easy ways to install computer components,
update the BIOS or back up your favorite settings.
ASUS Q-Design
ASUS Q-Design enhances your DIY experience. Both of Q-Slot and Q-DIMM design
speed up and simplify the DIY process!
ASUS O.C. Profile
The motherboard features the ASUS O.C. Profile that allows you to conveniently store
or load multiple BIOS settings. The BIOS settings can be stored in the CMOS or a
separate file, giving you the freedom to share and distribute your favorite settings.
ASUS CrashFree BIOS 3
ASUS CrashFree BIOS 3 allows you to restore corrupted BIOS data from a USB flash
disk containing the BIOS file. This protection eliminates the need to buy a replacement
ROM chip.
ASUS EZ-Flash 2
ASUS EZ Flash 2 is a user-friendly utility that allows you to update the BIOS without
using a bootable floppy disk or an OS-based utility. Refer to page 3-4 for details.
Precision Tweaker 3
Allows you to adjust the CPU/NB voltage in 0.003125V steps and DRAM voltage in 0.00625V
steps to fine-tune voltage to achieve the most precise setting for the ultimate overclocking
configuration.
1-4
Chapter 1: Product Introduction
Chapter 2
Chapter 2:
Hardware information
2.1
Before you proceed
Take note of the following precautions before you install motherboard components or change
any motherboard settings.
Unplug the power cord from the wall socket before touching any component.
•
Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due
to static electricity.
•
Hold components by the edges to avoid touching the ICs on them.
•
Whenever you uninstall any component, place it on a grounded antistatic pad or in the
bag that came with the component.
•
Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, or components.
Chapter 2
•
ASUS M4A89GTD PRO Series
2-1
2.2
Motherboard overview
2.2.1
Motherboard layout
Chapter 2
Refer to 2.8 Connectors for more information about rear panel connectors and internal
connectors.
2-2
Chapter 2: Hardware information
Layout contents
Connectors/Jumpers/Slots
Page
1.
ATX power connectors (24-pin EATXPWR, 8-pin EATX12V)
2-36
2.
AM3 CPU Socket
2-5
3.
CPU, chassis, and power fan connectors (4-pin CPU_FAN,
4-pin CHA_FAN1, 3-pin CHA_FAN2, 3-pin PWR_FAN)
2-34
4.
DDR3 DIMM slots
2-10
5.
Core Unlocker switch (CORE_UNLOCKER)
2-24
6.
Turbo Key II switch (TURBO_KEY_II)
2-23
7.
MemOK! switch
2-22
8.
Serial port connector (10-1 pin COM1)
2-32
9.
IDE connector (40-1 pin PRI_EIDE)
2-30
10.
Standby power LED (SB_PWR)
2-39
11.
AMD® SB850 Serial ATA 6.0 Gb/s connectors (7-pin SATA1–6)
2-31
12.
System panel connector (20-8 pin PANEL)
2-37
13.
Clear RTC RAM (3-pin CLRTC)
2-21
14.
USB connectors (10-1 pin USB78, USB910, USB1112, USB1314)
2-33
15.
Digital audio connector (4-1 pin SPDIF_OUT)
2-35
16.
IEEE 1394a port connector (10-1 pin IE1394_2)
2-32
17.
Front panel audio connector (10-1 pin AAFP)
2-35
ASUS M4A89GTD PRO Series
Chapter 2
2.2.2
2-3
2.2.3
Placement direction
When installing the motherboard, ensure that you place it into the chassis in the correct
orientation. The edge with external ports goes to the rear part of the chassis as indicated in
the image below.
2.2.4
Screw holes
Place nine screws into the holes indicated by circles to secure the motherboard to the
chassis.
DO NOT overtighten the screws! Doing so can damage the motherboard.
Chapter 2
Place this side towards
the rear of the chassis
2-4
Chapter 2: Hardware information
2.3
Central Processing Unit (CPU)
The motherboard comes with an AM3 socket designed for AMD® Phenom™ II / Athlon™ II /
Sempron™ 100 Series Processors.
Ensure that all power cables are unplugged before installing the CPU.
The AM3 socket has a different pinout from the 940-pin socket designed for the AMD
Opteron processor. Ensure that you use a CPU designed for the AM3 socket. The CPU fits
in only one correct orientation. DO NOT force the CPU into the socket to prevent bending
the connectors on the socket and damaging the CPU!
2.3.1
Installing the CPU
1.
Locate the CPU socket on the motherboard.
2.
Press the lever sideways to unlock the
socket, then lift it up to a 90º angle.
Ensure that the socket lever is lifted up
to a 90º angle. Otherwise, the CPU will
not fit in completely.
ASUS M4A89GTD PRO Series
Chapter 2
To install a CPU:
Socket lever
2-5
3.
Position the CPU above the socket such
that the CPU corner with the gold triangle
matches the socket corner with a small
triangle.
4.
Carefully insert the CPU into the socket
until it fits in place.
Gold triangle
Small triangle
Chapter 2
5.
When the CPU is in place, push down the
socket lever to secure the CPU. The lever
clicks on the side tab to indicate that it is
locked.
6.
Apply some Thermal Interface Material
to the exposed area of the CPU that the
heatsink will be in contact with, ensuring
that it is spread in an even thin layer.
Some heatsinks come with pre-applied
thermal paste. If so, skip this step.
The Thermal Interface Material is toxic
and inedible. DO NOT eat it. If it gets into
your eyes or touches your skin, wash it
off immediately, and seek professional
medical help.
To prevent contaminating the paste, DO NOT spread the paste with your finger.
2-6
Chapter 2: Hardware information
2.3.2
Installing the CPU heatsink and fan
The AMD AM3 processor requires a specially designed heatsink and fan assembly to ensure
optimum thermal condition and performance.
®
Ensure that you use only AMD-certified heatsink and fan assembly.
To install the CPU heatsink and fan:
Place the heatsink on top of the installed CPU, ensuring that the heatsink fits properly
on the retention module base.
•
The retention module base is already installed on the motherboard upon purchase.
•
You do not have to remove the retention module base when installing the CPU or
installing other motherboard components.
•
If you purchased a separate CPU heatsink and fan assembly, ensure that a Thermal
Interface Material is properly applied to the CPU heatsink or CPU before you install
the heatsink and fan assembly.
Chapter 2
1.
CPU fan
Retention bracket
lock
Retention bracket
CPU heatsink
Retention module
base
Your boxed CPU heatsink and fan assembly should come with installation instructions for
the CPU, heatsink, and the retention mechanism. If the instructions in this section do not
match the CPU documentation, follow the latter.
ASUS M4A89GTD PRO Series
2-7
Chapter 2
2.
Attach one end of the retention bracket
to the retention module base.
3.
Align the other end of the retention
bracket to the retention module base. A
clicking sound denotes that the retention
bracket is in place.
Ensure that the fan and heatsink
assembly perfectly fits the retention
mechanism module base, otherwise
you cannot snap the retention bracket
in place.
4.
2-8
Push down the retention bracket lock on
the retention mechanism to secure the
heatsink and fan to the module base.
Chapter 2: Hardware information
When the fan and heatsink assembly is in place, connect the CPU fan cable to the
connector on the motherboard labeled CPU_FAN.
•
Do not forget to connect the CPU fan connector! Hardware monitoring errors can
occur if you fail to plug this connector.
•
This connector is backward compatible with old 3-pin CPU fan.
ASUS M4A89GTD PRO Series
Chapter 2
5.
2-9
2.4
System memory
2.4.1
Overview
The motherboard comes with four Double Data Rate 3 (DDR3) Dual Inline Memory Modules
(DIMM) sockets.
A DDR3 module has the same physical dimensions as a DDR2 DIMM but is notched
differently to prevent installation on a DDR2 DIMM socket. DDR3 modules are developed for
better performance with less power consumption.
The figure illustrates the location of the DDR3 DIMM sockets:
Chapter 2
Recommended memory configurations
One DIMM:
When installing one memory module, we suggest that you install it on A1 slot.
Two DIMMs (dual-channel operation):
Four DIMMs (dual-channel operation):
2-10
Chapter 2: Hardware information
2.4.2
Memory configurations
•
You may install varying memory sizes in Channel A and Channel B. The system maps
the total size of the lower-sized channel for the dual-channel configuration. Any excess
memory from the higher-sized channel is then mapped for single-channel operation.
•
We recommend that you install the memory modules from the blue slots for better
overclocking capability.
•
Always install DIMMs with the same CAS latency. For optimum compatibility, we
recommend that you obtain memory modules from the same vendor.
•
Due to the CPU spec., AMD AM3 100 and 200 series CPUs support up to DDR3
1066MHz. With ASUS design, this motherboard can support up to DDR3 1333MHz.
•
When overclocking, some AMD CPU models may not support DDR3 1600 or higher
frequency DIMMs.
•
Due to the memory address limitation on 32-bit Windows OS, when you install 4GB
or more memory on the motherboard, the actual usable memory for the OS can be
about 3GB or less. For effective use of memory, we recommend that you do any of the
following:
- Use a maximum of 3GB system memory if you are using a 32-bit Windows OS.
- Install a 64-bit Windows OS when you want to install 4GB or more on the
motherboard.
For more details, refer to the Microsoft® support site at
http://support.microsoft.com/kb/929605/en-us.
•
This motherboard does not support DIMMs made up of 512Mb (64MB) chips or less
(Memory chip capacity counts in Megabit, 8 Megabit/Mb = 1 Megabyte/MB).
•
The default memory operation frequency is dependent on its Serial Presence Detect
(SPD), which is the standard way of accessing information from a memory module.
Under the default state, some memory modules for overclocking may operate at a
lower frequency than the vendor-marked value. To operate at the vendor-marked
or at a higher frequency, refer to section 3.5 Ai Tweaker menu for manual memory
frequency adjustment.
•
For system stability, use a more efficient memory cooling system to support a full
memory load (4 DIMMs) or overclocking condition.
ASUS M4A89GTD PRO Series
Chapter 2
You may install 512MB, 1GB, 2GB and 4GB unbuffered ECC and non‑ECC DDR3 DIMMs
into the DIMM sockets.
2-11
M4A89GTD PRO Series Motherboard Qualified Vendors Lists (QVL)
DDR3-1066 MHz capability
Vendor
Part No.
Size
SS/DS Chip Brand Chip NO.
DIMM socket support
Timing Voltage (Optional)
1 DIMM 2 DIMM 4 DIMM
Crucial
CT25672BA1067.18FF
2GB
DS
MICRON
D9KPT(ECC)
7
-
ELPIDA
EBJ10UE8EDF0-AE-F
1GB
SS
ELPIDA
J1108EDSE-DJ-F
-
-
ELPIDA
EBJ11UD8BAFA-AG-E
1GB
DS
ELPIDA
J5308BASE-AC-E
8
-
ELPIDA
EBJ21UE8BAW0-AE-E
2GB
DS
ELPIDA
J1108BABG-DJ-E
7
-
ELPIDA
EBJ21UE8EDF0-AE-F
2GB
DS
ELPIDA
J1108EDSE-DJ-F
-
-
Hynix
HMT112U6AFP8C-G7N0
1GB
SS
HYNIX
H5TQ1G83AFPG7C
7
-
Hynix
HYMT112U64ZNF8-G7
1GB
SS
HYNIX
HY5TQ1G831ZNFP-G7
7
-
Hynix
HMT125U6AFP8C-G7N0
2GB
DS
HYNIX
H5TQ1G83AFPG7C
7
-
•
•
•
•
•
•
•
•
•
M4A89GTD PRO Series Motherboard Qualified Vendors Lists (QVL)
DDR3-1333 MHz capability
Chapter 2
2-12
Vendor
Part No.
Size
SS/ Chip
DS Brand
Chip NO.
Timing
DIMM socket support
Voltage (Optional)
1 DIMM 2 DIMM 4 DIMM
A-DATA
AD3133301GOU
1GB
SS A-DATA
AD30908C8D-15IG
-
-
•
A-DATA
AD31333002GOU
2GB
DS A-DATA
AD30908C8D-15IG
-
-
•
•
A-DATA
AD3U1333B2G9-2
2GB
DS A-DATA
AD30908C8D-15IG
-
-
•
•
A-DATA
AX3U1333PB2G7-2P
4GB(2 x 2GB) DS -
-
7-7-7-20
1.65-1.85 •
A-DATA
AD3U1333C4G9-B
4GB
H5TQ2G83AFRH9C
1333-9-9-9-24 -
A-DATA
AD31333E002G0U
6GB(3 x 2GB) DS -
-
A-DATA
AX3U1333PB2G7-3P
6GB(3 x 2GB) DS -
Apacer
78.A1GC6.9L1
2GB
CORSAIR
TR3X3G1333C9 (Ver2.1)
CORSAIR
CM3X1024-1333C9DHX
•
•
•
•
•
7-7-7-20
1.65-1.85 •
•
•
-
7-7-7-20
1.65-1.85 •
•
•
AM5D5808DEWSBG
9
-
•
•
•
3GB(3 x 1GB) SS -
-
9-9-9-24
1.5
•
•
•
1GB
DS -
-
-
1.1
•
•
CORSAIR
BoxP/N:TWIN3X2048-1333C9 2GB(2 x 1GB) DS (CM3X1024-1333C9)Ver1.1
-
9-9-9-24
1.70
•
•
•
CORSAIR
CM3X2G1333C9
DS -
-
9-9-9-24
1.5
•
•
•
CORSAIR
BoxP/N:
TW3X4G1333C9DHX
4GB(2 x 2GB) DS (CM3X2048-1333C9DHX)Ver3.2
-
9-9-9-24
1.70
•
•
CORSAIR
TR3X6G1333C9 (Ver2.1)
6GB(3 x 2GB) DS -
-
9-9-9-24
1.5
•
•
•
CORSAIR
CMX8GX3M4A1333C9
8GB(4 x 2GB) DS -
-
9-9-9-24
1.5
•
•
•
Crucial
CT12864BA1339.8FF
1GB
SS MICRON
D9KPT
9
-
•
•
•
Crucial
CT12864BA1339.8SFD
1GB
SS MICRON
MT8JF12864AY1G4D1
-
-
•
•
•
Crucial
CT12872BA1339.9FF
1GB
SS MICRON
D9KPT(ECC)
9
-
•
•
•
Crucial
BL25664BN1337.16FF(XMP)
2GB
DS -
-
7-7-7-24
1.65
•
•
•
Crucial
CT25664BA1339.16FF
2GB
DS MICRON
D9KPT
9
-
•
•
•
Crucial
CT25664BA1339.16SFD
2GB
DS MICRON
D9JNM
-
-
•
•
•
Crucial
CT25672BA1339.18FF
2GB
DS MICRON
D9KPT(ECC)
9
-
•
•
Crucial
BL25664BA1336.16SFB1
4GB(2 x 2GB) DS NA
-
6-6-6-20
1.8
•
•
•
ELPIDA
EBJ10UE8BAW0-DJ-E
1GB
SS ELPIDA
J1108BABG-DJ-E
9
-
•
•
•
ELPIDA
EBJ10UE8BDF0-DJ-F
1GB
SS ELPIDA
J1108BDSE-DJ-F
-
-
•
•
•
ELPIDA
EBJ10UE8EDF0-DJ-F
1GB
SS ELPIDA
J1108EDSE-DJ-F
-
-
•
•
•
ELPIDA
EBJ21UE8BAW0-DJ-E
2GB
DS ELPIDA
J1108BABG-DJ-E
9
-
•
•
ELPIDA
EBJ21UE8BDF0-DJ-F
2GB
DS ELPIDA
J1108BDSE-DJ-F
-
-
•
•
•
ELPIDA
EBJ21UE8EDF0-DJ-F
2GB
DS ELPIDA
J1108EDSE-DJ-F
-
-
•
•
•
G.SKILL
F3-10600CL8D-2GBHK
2GB(2 x 1GB) SS -
-
-
1.65
•
•
•
G.SKILL
F3-10666CL7T-6GBPK(XMP)
2GB
DS -
-
7-7-7-18
1.5-1.6
•
•
•
G.SKILL
F3-10666CL7D-4GBPI(XMP)
4GB(2 x 2GB) DS -
-
7-7-7-21
1.5
•
•
•
G.SKILL
F3-10666CL7D-4GBRH(XMP) 4GB(2 x 2GB) DS -
-
7-7-7-21
1.5
•
•
•
G.SKILL
F3-10666CL8D-4GBECO(XMP)
4GB(2 x 2GB) DS -
-
8-8-8-24
1.35
•
•
•
G.SKILL
F3-10666CL8D-4GBHK(XMP)
4GB(2 x 2GB) DS -
-
8-8-8-21
1.5-1.6
•
•
•
G.SKILL
F3-10666CL8D-4GBRM(XMP)
4GB(2 x 2GB) DS -
-
8-8-8-21
1.5-1.6
•
•
•
G.SKILL
F3-10666CL9T-6GBNQ
6GB(3 x 2GB) DS -
-
9-9-9-24
1.5
•
•
•
2GB
DS Hynix
DS Apacer
Chapter 2: Hardware information
M4A89GTD PRO Series Motherboard Qualified Vendors Lists (QVL)
DDR3-1333 MHz capability (cont.)
Part No.
Size
GEIL
GG34GB1333C9DC
GEIL
GV34GB1333C7DC
Hynix
Hynix
SS/ Chip
DS Brand
DIMM socket support
(Optional)
1
DIMM 2 DIMM 4 DIMM
•
•
Chip NO.
Timing
Voltage
4GB(2 x 2GB) DS GEIL
GL1L128M88BA12N
9-9-9-24
1.3
4GB(2 x 2GB) DS -
-
7-7-7-24
1.5
•
•
HMT112U6BFR8C-H9
1GB
SS Hynix
H5TQ1G83BFR
9
-
•
•
•
HMT125U6BFR8C-H9
2GB
DS Hynix
H5TQ1G83BFR
9
-
•
•
•
Hynix
HMT125U6BFR8C-H9
2GB
DS Hynix
H5TQ1G83BFRH9C
9
-
•
•
•
KINGMAX
FLFD45F-B8KG9
1GB
SS KingMax
KFB8FNGBF-ANX-15A
-
•
•
•
KINGMAX
FLFE85F-B8KG9
2GB
DS KingMax
KFB8FNGBF-ANX-15A
-
•
•
•
KINGSTON KVR1333D3N9/1G
1G
SS Kingston
D1288JELDPGD9U
-
1.5
•
•
•
KINGSTON KVR1333D3N9/2G
2GB
DS Qimonda
IDSH1G-03A1F1C-13H 9
1.5
•
•
•
KINGSTON KVR1333D3E9S/4G
4GB
DS SAMSUNG K4B2G0846B-HCH9
-
1.5
•
•
•
KINGSTON KVR1333D3N9/4G
4GB
DS SAMSUNG K4B2G0846B-HCH9
9
1.5
•
MICRON
MT8JTF12864AZ-1G4F1
1GB
SS MICRON
9FF22 D9KPT
9
-
•
•
•
MICRON
MT8JTF12864AZ-1G4F1
1GB
SS MICRON
D9KPT
9
-
•
•
•
MICRON
MT9JSF12872AZ-1G4F1
1GB
SS MICRON
D9KPT(ECC)
9
-
•
•
•
MICRON
MT16JF25664AZ-1G4F1
2GB
DS MICRON
D9KPT
9
-
•
•
•
MICRON
MT16JTF25664AZ-1G4F1
2GB
DS MICRON
9FF22 D9KPT
9
-
•
•
•
MICRON
MT18JSF25672AZ-1G4F1
2GB
DS MICRON
D9KPT(ECC)
9
-
•
•
OCZ
OCZ3P1333LV3GK
3GB(3 x 1GB) SS -
-
7-7-7
1.65
OCZ
OCZ3G1333ULV4GK
4GB(2 x 2GB) DS -
-
8-8-8
1.65
•
OCZ
OCZ3P1333LV4GK
4GB(2 x 2GB) DS -
-
7-7-7
1.65
•
OCZ
OCZ3G1333LV6GK
6GB(3 x 2GB) DS -
-
9-9-9
1.65
OCZ
OCZ3P1333LV6GK
6GB(3 x 2GB) DS -
-
7-7-7
1.65
•
OCZ
OCZX1333LV6GK(XMP)
6GB(3 x 2GB) DS NA
-
8-8-8
1.6
•
•
•
PSC
AL7F8G73D-DG1
1GB
SS PSC
A3P1GF3DGF
-
-
•
•
•
PSC
AL8F8G73D-DG1
2GB
DS PSC
A3P1GF3DGF
-
-
•
•
•
SAMSUNG M378B2873DZ1-CH9
1GB
SS SAMSUNG K4B1G0846D
9
-
•
•
•
SAMSUNG M378B2873EH1-CH9
1GB
SS SAMSUNG K4B1G0846E
-
-
•
•
•
SAMSUNG M391B2873DZ1-CH9
1GB
SS SAMSUNG K4B1G0846D(ECC)
9
-
•
•
•
SAMSUNG M378B5673DZ1-CH9
2GB
DS SAMSUNG K4B1G0846D
9
-
•
•
•
SAMSUNG M378B5673EH1-CH9
2GB
DS SAMSUNG K4B1G0846E
-
-
•
•
•
SAMSUNG M391B5673DZ1-CH9
2GB
DS SAMSUNG K4B1G0846D(ECC)
9
-
•
•
•
SAMSUNG M378B5273BH1-CH9
4GB
DS SAMSUNG K4B2G0846B-HCH9
9
-
•
•
•
Super
Talent
W1333UX2G8(XMP)
2GB(2 x 1GB) SS -
-
8
1.8
•
•
•
Asint
SLY3128M8-EDJ
1GB
SS Asint
DDRIII1208-DJ
-
-
•
•
•
Asint
SLY3128M8-EDJE
1GB
SS ELPIDA
J1108BASE-DJ-E
-
-
•
•
Asint
SLZ3128M8-EDJ
2GB
DS Asint
DDRIII1208-DJ
-
-
•
•
•
Asint
SLZ3128M8-EDJE
2GB
DS ELPIDA
J1108BASE-DJ-E
-
-
•
•
•
ASUS
N/A
1GB
DS -
-
-
-
•
•
ATP
AQ28M64A8BJH9S
1GB
SS SAMSUNG K4B1G0846E
-
-
•
•
•
ATP
AQ28M72D8BJH9S
1GB
SS SAMSUNG K4B1G0846D(ECC)
-
-
•
•
•
ATP
AQ56M64B8BJH9S
2GB
DS SAMSUNG K4B1G0846D
-
-
•
•
•
ATP
AQ56M72E8BJH9S
2GB
DS SAMSUNG K4B1G0846D(ECC)
-
-
•
BUFFALO
FSH1333D3G-T3G(XMP)
3GB(3 x 1GB) SS -
-
7-7-7-20
-
•
•
EK Memory EKM324L28BP8-I13
4GB(2 x 2GB) DS -
-
9
-
•
•
Elixir
M2Y2G64CB8HA9N-CG
2GB
DS -
-
-
-
•
•
Elixir
M2Y2G64CB8HC9N-CG
2GB
DS -
-
-
-
•
•
Patriot
PVT33G1333ELK
3GB(3 x 1GB) SS -
-
9-9-9-24
1.65
•
•
Patriot
PVS34G1333LLK
4GB(2 x 2GB) DS -
-
7-7-7-20
1.7
•
•
Patriot
PVT36G1333ELK
6GB(3 x 2GB) DS -
-
9-9-9-24
1.65
•
•
Silicon
Power
SP001GBLTU1333S01
1GB
SS NANYA
NT5CB128M8AN-CG -
-
•
Silicon
Power
SP001GBLTU133S02
1GB
SS S-POWER I0YT3E0
9
-
•
Silicon
Power
SP002GBLTU133S02
2GB
DS S-POWER I0YT3E0
9
-
•
•
UMAX
E41302GP0-73BDB
2GB
DS UMAX
-
•
•
ASUS M4A89GTD PRO Series
U2S24D30TP-13
•
Chapter 2
Vendor
•
•
•
•
•
•
•
•
•
2-13
M4A89GTD PRO Series Motherboard Qualified Vendors Lists (QVL)
DDR3-1600 MHz capability
Chapter 2
2-14
DIMM socket support
(Optional)
Vendor
Part No.
Size
Chip
SS/DS Chip
Brand NO. Timing
A-DATA
AX3U1600PB1G8-2P
2GB(2 x 1GB)
SS
-
-
8-8-8-24 1.65-1.85
•
•
•
A-DATA
AD31600E001GMU
3GB(3 x 1GB)
SS
-
-
8-8-8-24 1.65-1.85
•
•
•
A-DATA
AX3U1600PB1G8-3P
3GB(3 x 1GB)
SS
-
-
8-8-8-24 1.65-1.85
•
•
•
A-DATA
AX3U1600GB2G9-AG(XMP)
4GB(2 x 2GB)
DS
-
-
9-9-9-24 1.65~1.85 •
•
•
A-DATA
AX3U1600XB2G7-EF(XMP)
4GB(2 x 2GB)
DS
-
-
7-7-7-20 1.75-1.85
•
•
•
A-DATA
AD31600F002GMU(XMP)
6GB(3 x 2GB)
DS
-
-
7-7-7-20 1.75-1.85
•
•
•
A-DATA
AX3U1600GB2G9-3G(XMP)
6GB(3 x 2GB)
DS
-
-
9-9-9-24 1.65~1.85 •
•
•
A-DATA
AX3U1600GB2G9-3G(XMP)
6GB(3 x 2GB)
DS
-
-
9-9-9-24 1.65~1.85 •
•
•
A-DATA
AX3U1600GB2G9-3G
6GB(3 x 2GB)
DS
-
-
9-9-9-24 1.65~1.85 •
•
•
A-DATA
AX3U1600XB2G7-FF(XMP)
6GB(3 x 2GB)
DS
-
-
7-7-7-20 1.75-1.85
•
•
•
CORSAIR
TR3X3G1600C8D
3GB(3 x 1GB)
SS
-
-
8-8-8-24 1.65
•
•
CORSAIR
TR3X3G1600C8DVer2.1(XMP)
3GB(3 x 1GB)
SS
-
-
8-8-8-24 1.65
•
•
CORSAIR
TR3X3G1600C9Ver1.1(XMP)
3GB(3 x 1GB)
SS
-
-
9-9-9-24 1.65
•
•
CORSAIR
CMD4GX3M2A1600C8(XMP)
4GB(2 x 2GB)
DS
-
-
8-8-8-24 1.65
•
•
CORSAIR
CMG4GX3M2A1600C7(XMP)
4GB(2 x 2GB)
DS
-
-
7-7-7-20 1.65
•
•
CORSAIR
CMX4GX3M2A1600C9(XMP)
4GB(2 x 2GB)
DS
-
-
9-9-9-24 1.65
•
•
CORSAIR
TR3X6G1600C8D
6GB(3 x 2GB)
DS
-
-
8-8-8-24 1.65
•
CORSAIR
TR3X6G1600C8DVer2.1(XMP)
6GB(3 x 2GB)
DS
-
-
8-8-8-24 1.65
•
CORSAIR
TR3X6G1600C9Ver2.1(XMP)
6GB(3 x 2GB)
DS
-
-
9-9-9-24 1.65
CORSAIR
CMD8GX3M4A1600C8(XMP)
8GB(4 x 2GB)
DS
-
-
8-8-8-24 1.65
CORSAIR
CMX8GX3M4A1600C9(XMP)
8GB(4 x 2GB)
DS
-
-
9-9-9-24 1.65
Crucial
BL12864BA1608.8SFB(XMP)
1GB
SS
-
-
-
Crucial
BL25664BN1608.16FF(XMP)
2GB
DS
-
-
G.SKILL
F3-12800CL9D-2GBNQ
2GB(2 x 1GB)
SS
-
G.SKILL
F3-12800CL9D-4GBRL
2GB(2 x 1GB)
SS
G.SKILL
F3-12800CL7D-4GBRH(XMP)
4GB(2 x 2GB)
DS
G.SKILL
F3-12800CL8D-4GBRM(XMP)
4GB(2 x 2GB)
G.SKILL
F3-12800CL9D-4GBECO(XMP)
G.SKILL
Voltage
1 DIMM 2 DIMM 4 DIMM
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
8-8-8-24 1.65
•
•
•
-
-
1.6
•
•
-
-
-
1.6
•
•
-
-
7-7-7-24 1.65
•
•
•
DS
-
-
8-8-8-24 1.6
•
•
•
4GB(2 x 2GB)
DS
-
-
9-9-9-24 1.35
•
•
•
F3-12800CL8T-6GBPI(XMP)
6GB(3 x 2GB)
DS
-
-
8-8-8-21 1.6~1.65
•
•
•
G.SKILL
F3-12800CL9T-6GBNQ
6GB(3 x 2GB)
DS
-
-
9-9-9-24 1.5-1.6
•
•
•
KINGMAX
FLGD45F-B8MF7(XMP)
1GB
SS
-
-
-
•
•
•
KINGMAX
FLGE85F-B8MF7(XMP)
2GB
DS
-
-
-
•
•
•
KINGSTON
KHX1600C9D3K3/12GX(XMP)
12GB(3 x 4GB) DS
-
-
-
1.65
•
•
•
KINGSTON
KHX1600C9D3K3/12GX(XMP)
12GB(3 x 4GB) DS
-
-
9
1.65
•
•
•
KINGSTON
KHX1600C8D3K2/4GX(XMP)
4GB(2 x 2GB)
DS
-
-
8
1.65
•
•
•
KINGSTON
KHX1600C8D3K2/4GX(XMP)
4GB(2 x 2GB)
DS
-
-
8
1.65
•
•
•
KINGSTON
KHX1600C8D3T1K2/4GX(XMP)
4GB(2 x 2GB)
DS
-
-
8
1.65
•
•
•
KINGSTON
KHX1600C9D3K2/4G
4GB(2 x 2GB)
DS
-
-
-
1.7~1.9
•
KINGSTON
KHX1600C9D3K3/6GX(XMP)
6GB(3 x 2GB)
DS
-
-
9
1.65
•
•
•
OCZ
OCZ3OB1600LV4GK
4GB(2 x 2GB)
DS
-
-
9-9-9
1.65
•
•
•
OCZ
OCZ3P1600LV4GK
4GB(2 x 2GB)
DS
-
-
7-7-7
1.65
•
OCZ
OCZ3X16004GK(XMP)
4GB(2 x 2GB)
DS
-
-
7-7-7
1.9
•
•
•
OCZ
OCZ3G1600LV6GK
6GB(3 x 2GB)
DS
-
-
8-8-8
1.65
•
•
OCZ
OCZ3X1600LV6GK(XMP)
6GB(3 x 2GB)
DS
-
-
8-8-8
1.65
•
•
•
OCZ
OCZ3X1600LV6GK(XMP)
6GB(3 x 2GB)
DS
-
-
8-8-8
1.65
•
•
•
Super Talent
WP160UX4G8(XMP)
4GB(2 x 2GB)
DS
-
-
8
-
•
•
•
Super Talent
WP160UX4G9(XMP)
4GB(2 x 2GB)
DS
-
-
9
-
•
•
•
Super Talent
WB160UX6G8(XMP)
6GB(3 x 2GB)
DS
-
-
-
-
•
•
•
Super Talent
WB160UX6G8(XMP)
6GB(3 x 2GB)
DS
-
-
8
-
•
•
•
Cell Shock
CS322271
2GB(2 x 1GB)
DS
-
-
7-7-7-14 1.7-1.9
•
EK Memory
EKM324L28BP8-I16(XMP)
4GB(2 x 2GB)
DS
-
-
9
-
•
•
•
Elixir
M2Y2G64CB8HA9N-DG(XMP)
2GB
DS
-
-
-
-
•
•
•
Mushkin
996657
4GB(2 x 2GB)
DS
-
-
7-7-7-20 -
•
•
•
Mushkin
998659(XMP)
6GB(3 x 2GB)
DS
-
-
9-9-9-24 1.5-1.6
•
Patriot
PVT33G1600ELK
3GB(3 x 1GB)
SS
-
-
9-9-9-24 1.65
•
•
•
PATRIOT
PGS34G1600LLKA
4GB(2 x 2GB)
DS
-
-
7-7-7-20 1.7
•
Patriot
PVS34G1600ELK
4GB(2 x 2GB)
DS
-
-
9-9-9-24 1.8
•
1.8
•
•
Chapter 2: Hardware information
M4A89GTD PRO Series Motherboard Qualified Vendors Lists (QVL)
DDR3-1600 MHz capability (cont.)
Vendor
Part No.
Size
Chip
SS/DS Chip
Brand NO. Timing
Patriot
PVS34G1600LLK(XMP)
4GB(2 x 2GB)
DS
-
-
7-7-7-20 1.9
DIMM socket support
(Optional)
1 DIMM 2 DIMM 4 DIMM
•
Patriot
PVS34G1600LLKN
4GB(2 x 2GB)
DS
-
-
7-7-7-20 2.0
•
Patriot
PVT36G1600ELK
6GB(3 x 2GB)
DS
-
-
9-9-9-24 1.65
•
•
•
Patriot
PVT36G1600ELK
6GB(3 x 2GB)
DS
-
-
9-9-9-24 1.65
•
•
•
Patriot
PVT36G1600LLK(XMP)
6GB(3 x 2GB)
DS
-
-
8-8-8-24 1.65
•
Team
BoxP/N:TXD34096M1600HC6DC-L
(TXD32048M1600HC6-L)(XMP)
4GB(2 x 2GB)
DS
-
-
6-7-6-18 1.65
•
Voltage
M4A89GTD PRO Series Motherboard Qualified Vendors Lists (QVL)
DDR3-1800 MHz capability
Vendor
Part No.
Size
SS/ Chip
Chip
DS Brand NO.
Timing
Voltage
KINGSTON
KHX1800C9D3T1K3/6GX(XMP)
6GB(3 x 2GB)
DS -
-
1.65
-
DIMM socket support (Optional)
1 DIMM
2 DIMM
4 DIMM
•
SS/ Chip
DS Brand
DIMM socket support (Optional)
Chip
NO.
Timing
-
-
9-9-9-24 1.65
•
6GB(3 x 2GB) DS
-
-
9-9-9
1.65
•
4GB(2 x 2GB)
6GB(3 x 2GB)
6GB(3 x 2GB)
6GB(3 x 2GB)
6GB(3 x 2GB)
6GB(3 x 2GB)
DS
DS
DS
DS
DS
DS
-
-
8-8-8-24
7-8-7-20
9-9-9-24
9
9
7-8-7
1.65
1.65
1.65
1.65
1.65
1.65
•
•
•
•
•
•
KHX2133C8D3T1K2/4GX(XMP) 4GB(2 x 2GB) DS
-
-
8
1.65
•
Vendor
Part No.
Size
CORSAIR
TR3X6G1866C9DVer4.1(XMP)
6GB(3 x 2GB) DS
OCZ
OCZ3RPR1866C9LV6GK
CORSAIR
G.SKILL
G.SKILL
KINGSTON
KINGSTON
OCZ
CMG4GX3M2A2000C8(XMP)
F3-16000CL7T-6GBPS(XMP)
F3-16000CL9T-6GBPS(XMP)
KHX2000C9D3T1FK3/6GX(XMP)
KHX2000C9D3T1K3/6GX(XMP)
OCZ3B2000LV6GK
KINGSTON
Voltage
Chapter 2
M4A89GTD PRO Series Motherboard Qualified Vendors Lists (QVL)
DDR3-1866 MHz capability
1 DIMM
2 DIMM
4 DIMM
M4A89GTD PRO Series Motherboard Qualified Vendors Lists (QVL)
DDR3-2000 MHz capability
Vendor
Part No.
Size
CORSAIR
TW3X4G2000C7GT
4GB(2 x 2GB) DS
SS/DS Chip Chip
Brand NO.
-
-
Timing
Voltage DIMM socket support (Optional)
7-8-7-20
1.65
1 DIMM
2 DIMM
4 DIMM
•
Side(s): SS - Single-sided DS - Double-sided
DIMM support:
• 1 DIMM: Supports one (1) module inserted into any slot as Single-channel memory
configuration. We suggest that you install the module into A1 slot.
• 2 DIMMs: Supports two (2) modules inserted into either the blue slots or the black slots as one pair of Dual-channel memory configuration.
• 4 DIMMs: Supports four (4) modules inserted into both the blue and the black slots as two pairs of Dual-channel memory configuration.
•
When overclocking, some AMD CPU models may not support DDR3 1600 or higher
frequency DIMMs.
•
Visit the ASUS website for the latest QVL.
ASUS M4A89GTD PRO Series
2-15
2.4.3
Installing a DIMM
Ensure to unplug the power supply before adding or removing DIMMs or other system
components. Failure to do so may cause severe damage to both the motherboard and the
components.
1.
Unlock a DIMM socket by pressing
the retaining clip outward.
2.
Align a DIMM on the socket such that
the notch on the DIMM matches the
DIMM slot key on the socket.
DIMM notch
2
1
Unlocked retaining clip
DIMM slot key
Chapter 2
A DIMM is keyed with a notch so that it fits in only one direction. DO NOT force a DIMM into
a socket in the wrong direction to avoid damaging the DIMM.
3.
Hold the DIMM by both of its ends,
then insert the DIMM vertically into
the socket. Apply force to both ends
of the DIMM simultaneously until the
retaining clip snaps back into place,
and the DIMM cannot be pushed in
any further to ensure proper sitting of
the DIMM.
3
Locked Retaining Clip
Always insert the DIMM into the socket VERTICALLY to prevent DIMM notch damage.
2.4.4
Removing a DIMM
1.
Press the retaining clip outward to
unlock the DIMM.
2.
Remove the DIMM from the socket.
2
1
2-16
Chapter 2: Hardware information
2.5
Expansion slots
In the future, you may need to install expansion cards. The following subsections describe the
slots and the expansion cards that they support.
Ensure to unplug the power cord before adding or removing expansion cards. Failure to do
so may cause you physical injury and damage motherboard components.
2.5.1
Installing an expansion card
1.
Before installing the expansion card, read the documentation that came with it and
make the necessary hardware settings for the card.
2.
Remove the system unit cover (if your motherboard is already installed in a chassis).
3.
Remove the bracket opposite the slot that you intend to use. Keep the screw for later
use.
4.
Align the card connector with the slot and press firmly until the card is completely
seated on the slot.
5.
Secure the card to the chassis with the screw you removed earlier.
6.
Replace the system cover.
2.5.2
Chapter 2
To install an expansion card:
Configuring an expansion card
After installing the expansion card, configure it by adjusting the software settings.
1.
Turn on the system and change the necessary BIOS settings, if any. See Chapter 3 for
information on BIOS setup.
2.
Assign an IRQ to the card. Refer to the tables on the next page.
3.
Install the software drivers for the expansion card.
When using PCI cards on shared slots, ensure that the drivers support “Share IRQ” or that
the cards do not need IRQ assignments. Otherwise, conflicts will arise between the two PCI
groups, making the system unstable and the card inoperable. Refer to the table on the next
page for details.
ASUS M4A89GTD PRO Series
2-17
2.5.3
Interrupt assignments
Standard interrupt assignments
Chapter 2
IRQ
Priority
0
1
Standard function
System Timer
1
2
Keyboard Controller
2
–
Redirect to IRQ#9
4
12
Communications Port (COM1)*
5
13
IRQ Holder for PCI Steering*
6
14
Reserved
7
15
Reserved
8
3
System CMOS/Real Time Clock
9
4
IRQ Holder for PCI Steering*
10
5
IRQ Holder for PCI Steering*
11
6
IRQ Holder for PCI Steering*
12
7
Reserved
13
8
Numeric Data Processor
14
9
Primary IDE Channel
* These IRQs are usually available for PCI devices.
IRQ assignments for this motherboard
PCIE x16_1
PCIE x16_2
PCIE x4_1
PCIE x1_1
PCI_1
PCI_2
LAN
Onboard 890GX Video
Controller
USB 3.0 Controller
(M4A89GTD PRO/USB3
model only)
A
–
–
shared
–
–
–
shared
B
–
–
–
shared
–
–
–
C
–
shared
–
–
–
–
–
D
shared
–
–
–
–
–
–
E
–
–
–
–
shared
–
–
F
–
–
–
–
–
shared
–
G
–
–
–
–
–
–
–
H
–
–
–
–
–
–
–
–
–
shared
–
–
–
–
–
–
shared
–
–
–
–
–
–
–
–
shared
–
–
–
–
–
shared
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
shared
–
–
–
Oncip SATA Controller
–
Onboard JMB 36x SATA
–
Controller
1394 Controller
–
HD Audio
shared
2-18
Chapter 2: Hardware information
2.5.4
PCI slots
The PCI slots support cards such as a LAN card, SCSI card, USB card, and other cards that
comply with PCI specifications. Refer to the figure below for the location of the slots.
2.5.5
PCI Express 2.0 x4 / x1 slots
This motherboard supports PCI Express x4 / x1 network cards, SCSI cards and other cards
that comply with the PCI Express specifications. Refer to the figure below for the location of
the slots.
2.5.6
PCI Express 2.0 x16 slots
Chapter 2
This motherboard has two PCI Express 2.0 x16 slots that support PCI Express 2.0 x16
graphics cards complying with the PCI Express specifications. Refer to the figure below for
the location of the slots.
PCI slot 2
PCI slot 1
PCIe 2.0 x16_2 slot (blue, single at x 16 or dual at x8 link)
PCIe 2.0 x4_1 slot
PCIe 2.0 x1_1 slot
PCIe 2.0 x16_1 slot (gray, at x 8 link)
ASUS M4A89GTD PRO Series
2-19
VGA configuration
PCI Express operating mode
PCIe x16_1
PCIe x16_2
Single VGA/PCIe card
Installed with the bundled VGA
switch card*
x16 (Recommended for single
VGA card)
Single VGA/PCIe card
N/A
x8 (Recommended for single
VGA card)
Dual VGA/PCIe card
x8
x8
* For working at x16 speed on the PCIe 2.0 x16_2 slot (blue), it is necessary to install the bundled VGA switch card
to the PCIe 2.0 x16_1 slot (gray).
Chapter 2
2-20
•
In single VGA card mode, use first the PCIe 2.0 x16_2 slot (blue) for a PCI Express
x16 graphics card to get better performance.
•
We recommend that you provide sufficient power when running CrossFireX™ mode.
See page 2-36 for details.
•
Connect a chassis fan to the motherboard connector labeled CHA_FAN1/2 when using
multiple graphics cards for better thermal environment. See page 2-34 for details.
Chapter 2: Hardware information
2.6
Jumper
Clear RTC RAM (3-pin CLRTC)
Chapter 2
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can
clear the CMOS memory of date, time, and system setup parameters by erasing
the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in
CMOS, which include system setup information such as system passwords.
To erase the RTC RAM
1.
Turn OFF the computer and unplug the power cord.
2.
Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3
for about 5–10 seconds, then move the cap back to pins 1-2.
3.
Plug the power cord and turn ON the computer.
4.
Hold down the <Del> key during the boot process and enter BIOS setup to
re-enter data.
Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default
position. Removing the cap will cause system boot failure!
•
If the steps above do not help, remove the onboard battery and move the jumper again
to clear the CMOS RTC RAM data. After the CMOS clearance, reinstall the battery.
•
You do not need to clear the RTC when the system hangs due to overclocking. For
system failure due to overclocking, use the C.P.R. (CPU Parameter Recall) feature.
Shut down and reboot the system so the BIOS can automatically reset parameter
settings to default values.
•
Due to the chipset behavior, AC power off is required to enable C.P.R. function. You
must turn off and on the power supply or unplug and plug the power cord before
rebooting the system.
ASUS M4A89GTD PRO Series
2-21
2.7
Onboard switches
Onboard switches allow you to fine-tune performance when working on a bare or open-case
system. This is ideal for overclockers and gamers who continually change settings to enhance
system performance.
1.
MemOK! switch
Installing DIMMs that are incompatible with the motherboard may cause system
boot failure, and the DRAM_LED near the MemOK! switch lights continuously. Press
and hold the MemOK! switch until the DRAM_LED starts blinking to begin automatic
memory compatibility tuning for successful boot.
Chapter 2
2-22
•
Refer to section 2.9 Onboard LEDs for the exact location of the DRAM_LED.
•
The DRAM_LED also lights when the DIMM is not properly installed. Turn off the
system and reinstall the DIMM before using the MemOK! function.
•
The MemOK! switch does not function under Windows® OS environment.
•
During the tuning process, the system loads and tests failsafe memory settings. It
takes about 30 seconds for the system to test one set of failsafe settings. If the test
fails, the system reboots and test the next set of failsafe settings. The blinking speed
of the DRAM_LED increases, indicating different test processes.
•
Due to memory tuning requirement, the system automatically reboots when each
timing set is tested. If the installed DIMMs still fail to boot after the whole tuning
process, the DRAM_LED lights continuously. Replace the DIMMs with ones
recommended in the Memory QVL (Qualified Vendors Lists) in this user manual or on
the ASUS website at www.asus.com.
•
If you turn off the computer and replace DIMMs during the tuning process, the system
continues memory tuning after turning on the computer. To stop memory tuning, turn
off the computer and unplug the power cord for about 5–10 seconds.
•
If your system fail to boot due to BIOS overclocking, press the MemOK! switch to boot
and load BIOS default settings. A messgae will appear during POST reminding you
that the BIOS has been restored to its default settings.
•
We recommend that you download and update to the latest BIOS version from the
ASUS website at www.asus.com after using the MemOK! function.
Chapter 2: Hardware information
2.
Turbo Key II switch
This switch allows you to auto-tune your CPU to enhance the system performance.
Chapter 2
For ensuring the system performance, turn the switch setting to Enable when the system is
powered off.
•
The O2LED5 LED near the Turbo Key II switch lights when the switch setting is turned
to Enable. Refer to section 2.9 Onboard LEDs for the exact location of the O2LED5
LED.
•
If you clear the CMOS or load the BIOS setup defaults, the related overclocking items
in the BIOS menu follow the current setting of the Turbo Key II switch.
•
If you change the switch setting to Enable under the OS environment, the Turbo Key II
function will be activated after the next system bootup.
•
You may use the TurboV Auto Tuning, overclock in the BIOS setup program, and
enable the Turbo Key II function at the same time. However, the system will use the
last setting you have made.
ASUS M4A89GTD PRO Series
2-23
3.
Core Unlocker switch
This switch allows you to unlock the extra cores of your CPU.
For ensuring the system performance, turn the switch setting to Enable when the system is
powered off.
Chapter 2
2-24
•
The O2LED4 LED near the Core Unlocker switch lights when the switch setting is
turned to Enable. Refer to section 2.9 Onboard LEDs for the exact location of the
O2LED4 LED.
•
You may also press <4> during the Power-On-Self-Test (POST) or enable the ASUS
Core Unlocker item in the BIOS menu to activate the Core Unlocker function.
•
The system will use the last setting you have made.
•
If you clear the CMOS or load the BIOS setup defaults, the ASUS Core Unlocker item
in the BIOS menu follows the current setting of the Core Unlocker switch.
Chapter 2: Hardware information
Connectors
2.8.1
Rear panel connectors
Chapter 2
2.8
Rear panel connectors
1.
PS/2 keyboard port (purple)
8.
DVI-D Out port
2.
Optical S/PDIF Out port
9.
IEEE 1394a port
3.
D-Sub Out port
10. Power External SATA port
4.
USB 2.0 ports 3 and 4
5.
LAN (RJ-45) port*
11.USB 3.0 ports 1 and 2 (M4A89GTD
PRO/USB3 model)
6.
USB 2.0 ports 5 and 6
USB 2.0 ports 1 and 2 (M4A89GTD PRO
model)
7.
HDMI Out port***
12. Audio I/O ports**
*and **: Refer to the tables on the next page for LAN port and audio port definitions.
***: Refer to the notes and troubleshooting on HDTV overscaning or underscaling on the next pages.
•
DO NOT insert a different connector to the external SATA port.
•
To enable external SATA device hot-plugging, you have to set the On Board ATA
Controller item in the BIOS setting to [Enabled] and install the JMicron JMB36X
Controller Driver from the support DVD.
ASUS M4A89GTD PRO Series
2-25
* LAN port LED indications
ACT/LINK SPEED
LED
LED
Activity Link LED
Speed LED
Status
Description
Status
Description
OFF
No link
OFF
10 Mbps connection
ORANGE
Linked
ORANGE
100 Mbps connection
BLINKING
Data activity
GREEN
1 Gbps connection
LAN port
** Audio 2, 4, 6, or 8-channel configuration
Port
Headset
2-channel
4-channel
6-channel
8-channel
Light Blue
Line In
Line In
Line In
Line In
Lime
Line Out
Front Speaker Out
Front Speaker Out
Front Speaker Out
Chapter 2
Pink
Mic In
Mic In
Mic In
Mic In
Orange
–
–
Center/Subwoofer
Center/Subwoofer
Black
–
Rear Speaker Out
Rear Speaker Out
Rear Speaker Out
Gray
–
–
–
Side Speaker Out
Dual display table
This table indicates whether the dual display you want to use is supported or not.
Dual display output
Support
DVI + D-Sub
•
HDMI + D-Sub
•
Not support
DVI + HDMI
•
Playback of HD DVD and Blu-Ray Discs
For better playback quality, we suggest that you follow the system requirements in the
suggested list below.
Suggested list
CPU
AMD® Phenom II X4 955
DIMM
DDR3 1333
BIOS setup
Frame Buffer Size – 256MB or higher
Playback software
CyberLink® PowerDVD 9
File format
2-26
Best resolution
Windows XP
Windows Vista
Windows 7
Non-protected clips
1920 x 1080p
1920 x 1080p
1920 x 1080p
Blu-Ray
1920 x 1080p
1920 x 1080p
1920 x 1080p
Chapter 2: Hardware information
Troubleshooting on HDTV overscaling or underscaling:
If your desktop is extending beyond the viewable display area or the desktop or image is not
filling the entire display area while using the onboard HDMI out port and the HDMI cable, you
can resize the desktop appearing on your HDTV screen.
To resize your HDTV desktop:
Install AMD Chipset Driver from the motherboard support DVD.
2.
Right-click the desktop and select ATI CATALYST(R) Control Center.
3.
From the Graphics Settings tree, expand DTV (HDMI™) 1.
4.
Click Scaling Options.
5.
Move the Underscan/Overscan slider to adjust the overall size of the display on the
HDMI™ DTV.
Using this slider increases or decreases any black borders that may be visible around
the outside of the display.
Chapter 2
1.
3
4
5
6
6.
To ensure that forcing a custom display mode through the ATI Displays Manager does
not create conflicting resolutions, select the Use the scaling values instead of the
customized settings when the desktop resolution does not match your DFP
resolution check box.
The Scaling Options function of the DTV (HDMI™) 1 item in the ATI CATALYST Control
Center is adjustable only when you are using an HDTV compliance resolution such as 480i,
720i, or 1080i.
ASUS M4A89GTD PRO Series
2-27
2.8.2
Audio I/O connections
Audio I/O ports
Connect to Headphone and Mic
Chapter 2
Connect to Stereo / 2.1-channel Speakers
2-28
Chapter 2: Hardware information
Connect to 4.1 channel Speakers
Chapter 2
Connect to 5.1 channel Speakers
Connect to 7.1 channel Speakers
ASUS M4A89GTD PRO Series
2-29
2.8.3
1.
Internal connectors
IDE connector (40-1 pin PRI_EIDE)
The onboard IDE connector is for the Ultra DMA 133/100/66 signal cable. There are
three connectors on each Ultra DMA 133/100/66 signal cable: blue, black, and gray.
Connect the blue connector to the motherboard’s IDE connector, then select one of the
following modes to configure your device.
Chapter 2
Drive jumper setting
Single device
Cable-Select or Master
Cable-Select
Two devices
Mode of device(s)
Cable connector
-
Black
Master
Black
Slave
Gray
Master
Master
Slave
Slave
Black or gray
•
Pin 20 on the IDE connector is removed to match the covered hole on the Ultra DMA
cable connector. This prevents incorrect insertion when you connect the IDE cable.
•
Use the 80-conductor IDE cable for Ultra DMA 133/100/66 IDE devices.
If any device jumper is set as “Cable-Select”, ensure that all other device jumpers have the
same setting.
2-30
Chapter 2: Hardware information
2.
AMD® SB850 Serial ATA Serial ATA 6.0 Gb/s connectors (7-pin SATA 1-6)
These connectors are for the Serial ATA 6.0 Gb/s signal cables for Serial ATA hard disk
drives and optical disc drives.
Chapter 2
If you installed Serial ATA hard disk drives, you can create a RAID 0, RAID 1, RAID 5,
or RAID 10 configuration through the onboard AMD® SB850 controller.
•
These connectors are set to Native IDE mode by default. In Native IDE mode, you
can connect Serial ATA boot/data hard disk drives to these connectors. If you intend to
create a Serial ATA RAID set using these connectors, set the OnChip SATA Type item
in the BIOS to [RAID]. See section 3.4.2 Storage Configuration for details.
•
You must install Windows® XP Service Pack 2 or later version before using Serial
ATA hard disk drives. The Serial ATA RAID feature is available only if you are using
Windows® XP SP2 or later version.
•
When using hot-plug and NCQ, set the OnChip SATA Type in the BIOS to [AHCI].
See section 3.4.2 Storage Configuration for details.
ASUS M4A89GTD PRO Series
2-31
3.
Serial port connector (10-1 pin COM1)
This connector is for a serial (COM) port. Connect the serial port module cable to this
connector, then install the module to a slot opening at the back of the system chassis.
Chapter 2
The COM module is purchased separately.
4.
IEEE 1394a port connector (10-1 pin IE1394_2)
This connector is for an IEEE 1394a port. Connect the IEEE 1394a module cable to this
connector, then install the module to a slot opening at the back of the system chassis.
Never connect a USB cable to the IEEE 1394a connector. Doing so will damage the
motherboard!
The IEEE 1394a module is purchased separately.
2-32
Chapter 2: Hardware information
5.
USB connectors (10-1 pin USB78; USB910; USB1112; USB1314)
Chapter 2
These connectors are for USB 2.0 ports. Connect the USB module cable to any of
these connectors, then install the module to a slot opening at the back of the system
chassis. These USB connectors comply with USB 2.0 specification that supports up to
480 Mbps connection speed.
Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard!
You can connect the front panel USB cable to the ASUS Q-Connector (USB, blue) first, and
then install the Q-Connector (USB) to the USB connector onboard if your chassis supports
front panel USB ports.
The USB module cable is purchased separately.
ASUS M4A89GTD PRO Series
2-33
6.
CPU, chassis, and power fan connectors
(4-pin CPU_FAN; 4-pin CHA_FAN1; 3-pin CHA_FAN2; 3-pin PWR_FAN)
Connect the fan cables to the fan connectors on the motherboard, ensuring that the
black wire of each cable matches the ground pin of the connector.
Chapter 2
Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside the
system may damage the motherboard components. These are not jumpers! Do not place
jumper caps on the fan connectors!
2-34
•
The CPU_FAN connector supports the CPU fan of maximum 2A (24 W) fan power.
•
Only the CPU_FAN, CHA_FAN1 and CHA_FAN2 connectors support the ASUS Fan
Xpert feature.
•
If you install two VGA cards, we recommend that you plug the rear chassis fan cable
to the motherboard connector labeled CHA_FAN1 or CHA_FAN2 for better thermal
environment.
Chapter 2: Hardware information
7.
Digital audio connector (4-1 pin SPDIF_OUT)
Chapter 2
This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port. Connect
the S/PDIF Out module cable to this connector, then install the module to a slot opening
at the back of the system chassis.
The S/PDIF module is purchased separately.
8.
Front panel audio connector (10-1 pin AAFP)
This connector is for a chassis-mounted front panel audio I/O module that supports
either HD Audio or legacy AC`97 audio standard. Connect one end of the front panel
audio I/O module cable to this connector.
•
We recommend that you connect a high-definition front panel audio module to this
connector to avail of the motherboard’s high-definition audio capability.
•
If you want to connect a high-definition front panel audio module to this connector, set
the Front Panel Type item in the BIOS setup to [HD]; if you want to connect an AC'97
front panel audio module to this connector, set the item to [AC 97]. By default, this
connector is set to [HD].
ASUS M4A89GTD PRO Series
2-35
9.
ATX power connectors (24-pin EATXPWR; 8-pin EATX12V)
These connectors are for ATX power supply plugs. The power supply plugs are
designed to fit these connectors in only one orientation. Find the proper orientation and
push down firmly until the connectors completely fit.
Chapter 2
2-36
•
For a fully configured system, we recommend that you use a power supply unit
(PSU) that complies with ATX 12 V Specification 2.0 (or later version) and provides a
minimum power of 450 W.
•
Do not forget to connect the 8-pin EATX12 V power plug; otherwise, the system will
not boot.
•
We recommend that you use a PSU with higher power output when configuring a
system with more power-consuming devices. The system may become unstable or
may not boot up if the power is inadequate.
•
If you are uncertain about the minimum power supply requirement for your system,
refer to the Recommended Power Supply Wattage Calculator at http://support.
asus.com/PowerSupplyCalculator/PSCalculator.aspx?SLanguage=en-us for details.
•
If you want to use two high-end PCI Express x16 cards, use a PSU with 1000W power
or above to ensure the system stability.
Chapter 2: Hardware information
10. System panel connector (20-8 pin PANEL)
•
This connector supports several chassis-mounted functions.
Chapter 2
System power LED (2-pin PLED)
This 2-pin connector is for the system power LED. Connect the chassis power LED
cable to this connector. The system power LED lights up when you turn on the system
power, and blinks when the system is in sleep mode.
•
Hard disk drive activity LED (2-pin IDE_LED)
This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable
to this connector. The IDE LED lights up or flashes when data is read from or written to
the HDD.
•
System warning speaker (4-pin SPEAKER)
This 4-pin connector is for the chassis-mounted system warning speaker. The speaker
allows you to hear system beeps and warnings.
•
ATX power button/soft-off button (2-pin PWRSW)
This connector is for the system power button. Pressing the power button turns the
system on or puts the system in sleep or soft-off mode depending on the BIOS settings.
Pressing the power switch for more than four seconds while the system is ON turns the
system OFF.
•
Reset button (2-pin RESET)
This 2-pin connector is for the chassis-mounted reset button for system reboot without
turning off the system power.
ASUS M4A89GTD PRO Series
2-37
2.8.4.
ASUS Q-Connector (system panel)
Use the ASUS Q-Connector to connect/disconnect the chassis front panel cables.
To install the ASUS Q-Connector:
1.
Connect the front panel cables to the ASUS
Q-Connector.
Refer to the labels on the Q-Connector to
know the detailed pin definitions, and then
match them to their respective front panel
cable labels.
The labels on the front panel cables
may vary depending on the chassis
model.
Chapter 2
2-38
2.
Install the ASUS Q-Connector to the system
panel connector, ensuring the orientation
matches the labels on the motherboard.
3.
The front panel functions are now enabled.
The figure shows the Q-Connector is properly
installed on the motherboard.
IDE_LED+
IDE_LED-
PWR
Ground
Reset
Ground
IDE_LED
R SW
POWE
W
S
RESET
Chapter 2: Hardware information
2.9
1.
Onboard LEDs
Standby Power LED
Chapter 2
The motherboard comes with a standby power LED. The green LED lights up to
indicate that the system is ON, in sleep mode, or in soft‑off mode. This is a reminder
that you should shut down the system and unplug the power cable before removing or
plugging in any motherboard component. The illustration below shows the location of
the onboard LED.
2.
DRAM LED
DRAM LED checks the DRAM in sequence during motherboard booting process. If an
error is found , the LED next to the error device will continue lighting until the problem is
solved. This user-friendly design provides an intuitional way to locate the root problem
within a second.
You may disable the DRAM LED in BIOS. Refer to section 3.9 Tools menu for details.
ASUS M4A89GTD PRO Series
2-39
3.
Turbo Key II LED
The Turbo Key II LED lights when the Turbo Key II switch is turned to Enable.
Chapter 2
4.
Core Unlocker LED
The Core Unlocker LED lights when the Core Unclocker switch is turned to Enable.
The Core Unlocker LED keeps on lighting even though the ASUS Core Unlocker item in
the BIOS menu is set to [Disabled].
2-40
Chapter 2: Hardware information
1.
After making all the connections, replace the system case cover.
2.
Be sure that all switches are off.
3.
Connect the power cord to the power connector at the back of the system chassis.
4.
Connect the power cord to a power outlet that is equipped with a surge protector.
5.
Turn on the devices in the following order:
a.
Monitor
b.
External SCSI devices (starting with the last device on the chain)
c.
System power
6.
After applying power, the system power LED on the system front panel case lights up.
For systems with ATX power supplies, the system LED lights up when you press the
ATX power button. If your monitor complies with the “green” standards or if it has a
“power standby” feature, the monitor LED may light up or change from orange to green
after the system LED turns on.
The system then runs the power-on self tests or POST. While the tests are running, the
BIOS beeps (see the BIOS beep codes table below) or additional messages appear on
the screen. If you do not see anything within 30 seconds from the time you turned on
the power, the system may have failed a power-on test. Check the jumper settings and
connections or call your retailer for assistance.
7.
BIOS Beep
Description
One short beep
VGA detected
Quick boot set to disabled
No keyboard detected
One continuous beep followed by two short
beeps then a pause (repeated)
No memory detected
One continuous beep followed by three short
beeps
No VGA detected
One continuous beep followed by four short
beeps
Hardware component failure
Chapter 2
2.10 Starting up for the first time
At power on, hold down the <Delete> key to enter the BIOS Setup. Follow the
instructions in Chapter 3.
2.11 Turning off the computer
While the system is ON, pressing the power switch for less than four seconds puts the system
on sleep mode or soft-off mode, depending on the BIOS setting. Pressing the power switch
for more than four seconds lets the system enter the soft-off mode regardless of the BIOS
setting. Refer to section 3.7 Power menu in Chapter 3 for details.
ASUS M4A89GTD PRO Series
2-41
Chapter 2
2-42
Chapter 2: Hardware information
Chapter 3
Chapter 3:
3.1
BIOS setup
Knowing BIOS
BIOS (Basic Input and Output System) stores system hardware settings such as storage
device configuration, overclocking settings, advanced power management, and boot device
configuration that are needed for system startup in the motherboard CMOS. In normal
circumstances, the default BIOS settings apply to most conditions to ensure optimum
performance. We recommend that you not change the default BIOS settings except in
the following circumstances:
•
An error message appears on the screen during the system bootup and requests you to
run the BIOS Setup.
•
You have installed a new system component that requires further BIOS settings or
update.
Inappropriate settings of the BIOS may result to instability or failure to boot. We strongly
recommend that you change the BIOS settings only with the help of a trained service
personnel.
3.2
Updating BIOS
The ASUS website publishes the latest BIOS versions to provide enhancements on system
stability, compatibility, or performance. However, BIOS updating is potentially risky. If there
is no problem using the current version of BIOS, DO NOT manually update the BIOS.
Inappropriate BIOS updating may result in the system’s failure to boot. Carefully follow the
instructions of this chapter to update your BIOS if necessary.
Chapter 3
Visit the ASUS website (www.asus.com) to download the latest BIOS file for this
motherboard.
The following utilities allow you to manage and update the motherboard BIOS setup program.
1.
ASUS Update: Updates the BIOS in Windows® environment.
2.
ASUS EZ Flash 2: Updates
�����������������������������������������
the BIOS using a USB flash drive.
3.
ASUS CrashFree BIOS 3 utility: Restores the BIOS using the motherboard support
DVD or a USB flash drive when the BIOS file fails or gets corrupted.
4.
ASUS BIOS Updater: Updates and backups the BIOS in DOS environment using the
motherboard support DVD and a USB flash disk drive.
Refer to the corresponding sections for details on these utilities.
Save a copy of the original motherboard BIOS file to a USB flash disk in case you need
to restore the BIOS in the future. Copy the original motherboard BIOS using the ASUS
Update utility.
ASUS M4A89GTD PRO Series
3-1
3.2.1
ASUS Update utility
The ASUS Update is a utility that allows you to manage, save, and update the motherboard
BIOS in Windows® environment. The ASUS Update utility allows you to:
•
Save the current BIOS file
•
Download the latest BIOS file from the Internet
•
Update the BIOS from an updated BIOS file
•
Update the BIOS directly from the Internet
•
View the BIOS version information
This utility is available in the support DVD that comes with the motherboard package.
ASUS Update requires an Internet connection either through a network or an Internet
Service Provider (ISP).
Installing ASUS Update
To install ASUS Update:
1.
Place the support DVD in the optical drive.
2.
From the Main menu, click the Utilities tab, then click Install ASUS Update VX.XX.XX.
3.
The ASUS Update utility is copied to your system.
Quit all Windows® applications before you update the BIOS using this utility.
Updating the BIOS through the Internet
Chapter 3
To update the BIOS through the Internet:
1.
3-2
From the Windows® desktop, click
Start > Programs > ASUS >
ASUSUpdate > ASUSUpdate. The
ASUS Update main window appears.
2.
Select Update BIOS from the
Internet from the drop‑down menu,
and then click Next.
Chapter 3: BIOS setup
3.
Select the ASUS FTP site nearest
you to avoid network traffic, or click
Auto Select. Click Next.
4.
From the FTP site, select the BIOS
version that you wish to download. Click
Next.
5.
Follow the onscreen instructions to complete the update process.
The ASUS Update utility is capable of updating itself through the Internet. Always update
the utility to avail all its features.
Updating the BIOS through a BIOS file
1.
2.
Fom the Windows® desktop, click
Start > Programs > ASUS >
ASUSUpdate > ASUSUpdate. The
ASUS Update main window appears.
Select Update BIOS from a file
from the dropdown menu, then click
Next.
3.
Locate the BIOS file from the Open
window, then click Open.
4.
Follow the onscreen instructions to
complete the update process.
Chapter 3
To update the BIOS through a BIOS file:
M4A89GU3.ROM
M4A89GU3
Ensure to load the BIOS default
settings to ensure system
compatibility and stability. Select the
Load Setup Defaults item under
the Exit menu. See section 3.10 Exit
Menu for details.
ASUS M4A89GTD PRO Series
3-3
3.2.2
ASUS EZ Flash 2 utility
The ASUS EZ Flash 2 feature allows you to update the BIOS without having to use a
bootable floppy disk or an OS‑based utility.
Before you start using this utility, download the latest BIOS from the ASUS website
at www.asus.com.
To update the BIOS using EZ Flash 2:
1.
Insert the USB flash disk that contains the latest BIOS file to the USB port, and then
launch EZ Flash 2 in any of these two ways:
•
Press <Alt> + <F2> during POST to display the following.
•
Enter the BIOS setup program. Go to the Tools menu to select EZ Flash 2 and
press <Enter> to enable it.
ASUSTek EZ Flash 2 BIOS ROM Utility V4.12
FLASH TYPE: MXIC 25L1605A
Current ROM
BOARD: M4A89GTD PRO Series
VER: 0109
DATE: 01/07/2010
Update ROM
BOARD: Unknown
VER: Unknown
DATE: Unknown
PATH: A:\
A:
Chapter 3
Note
[Enter] Select or Load
[Up/Down/Home/End] Move
[Tab] Switch
[B] Backup
[V] Drive Info
[Esc] Exit
2.������
Press <Tab>
������ to
��������������������������������������������������������������������
switch between drives until the correct BIOS file is found. �����
When
the correct BIOS file is found, EZ Flash 2 performs the BIOS update process and
automatically reboots the system when done.
•
This function can support devices such as a USB flash disk with FAT 32/16 format and
single partition only.
•
DO NOT shut down or reset the system while updating the BIOS to prevent system
boot failure!
Ensure to load the BIOS default settings to ensure system compatibility and stability. Select
the Load Setup Defaults item under the Exit menu. See section 3.10 Exit Menu for
details.
3-4
Chapter 3: BIOS setup
3.2.3
ASUS CrashFree BIOS 3 utility
The ASUS CrashFree BIOS 3 utility is an auto recovery tool that allows you to restore the
BIOS file when it fails or gets corrupted during the updating process. You can restore a
corrupted BIOS file using the motherboard support DVD or a USB flash drive that contains
the BIOS file.
The BIOS file in the motherboard support DVD may be older than the BIOS file published
on the ASUS official website. If you want to use the newer BIOS file, download the file at
support.asus.com and save it to a USB flash drive.
Recovering the BIOS
To recover the BIOS:
1.
Turn on the system.
2.
Insert the motherboard support DVD to the optical drive, or the USB flash drive
containing the BIOS file to the USB port.
3.
The utility automatically checks the devices for the BIOS file. When found, the utility
reads the BIOS file and starts flashing the corrupted BIOS file.
4.
Turn off the system after the utility completes the updating process and power on
again.
5.
The system requires you to enter BIOS Setup to recover BIOS setting. To ensure
system compatibility and stability, we recommend that you press <F2> to load default
BIOS values.
Chapter 3
DO NOT shut down or reset the system while updating the BIOS! Doing so can cause
system boot failure!
ASUS M4A89GTD PRO Series
3-5
3.2.4
ASUS BIOS Updater
The ASUS BIOS Updater allows you to update BIOS in DOS environment. This utility also
allows you to copy the current BIOS file that you can use as a backup when the BIOS fails or
gets corrupted during the updating process.
The succeeding utility screens are for reference only. The actual utility screen displays may
not be same as shown.
Before updating BIOS
1.
Prepare the motherboard support DVD and a USB flash drive in FAT32/16 format and
single partition.
2.
Download the latest BIOS file and BIOS Updater from the ASUS website at http://
support.asus.com and save them on the USB flash drive.
3.
•
NTFS is not supported under DOS environment. Do not save the BIOS file and BIOS
Updater to a hard disk drive or USB flash drive in NTFS format.
•
Do not save the BIOS file to a floppy disk due to low disk capacity.
Turn off the computer and disconnect all SATA hard disk drives (optional).
Booting the system in DOS environment
1.
Insert the USB flash drive with the latest BIOS file and BIOS Updater to the USB port.
2.
Boot your computer. When the ASUS Logo appears, press <F8> to show the BIOS
Boot Device Select Menu. Insert the support DVD into the optical drive and select the
optical drive as the boot device.
Chapter 3
Please select boot device:
SATA:XXXXXXXXXXXXXXXX
CDROM:XXXXXXXXXXXXXXX
USB:XXXXXXXXXXXXXXXXX
Network:XXXXXXXXXXXXX
↑ and ↓ to move selection
ENTER to select boot device
ESC to boot using defaults
3. When the Make Disk menu appears, select the FreeDOS command prompt item by
pressing the item number.
4.
At the FreeDOS prompt, type d: and press <Enter> to switch the disk from
Drive C (optical drive) to Drive D (USB flash drive).
Welcome to FreeDOS (http://www.freedos.org)!
C:\>d:
D:\>
3-6
Chapter 3: BIOS setup
Backing up the current BIOS
To backup the current BIOS file using the BIOS Updater
Ensure that the USB flash drive is not write-protected and has enough free space to save
the file.
1.
At the FreeDOS prompt, type bupdater /o[filename] and press <Enter>.
D:\>bupdater /oOLDBIOS1.rom
Filename Extension
The [filename] is any user-assigned filename with no more than eight alphanumeric
characters for the filename and three alphanumeric characters for the extension.
2.
The BIOS Updater backup screen appears indicating the BIOS backup process. When
BIOS backup is done, press any key to return to the DOS prompt.
ASUSTek BIOS Updater for DOS V1.00b [09/06/22]
FLASH TYPE: MXIC 25L1605A
Current ROM
BOARD: M4A89GTD PRO Series
VER: 0109
DATE: 01/07/2010
Update ROM
BOARD: Unknown
VER: Unknown
DATE: Unknown
PATH: A:\
Chapter 3
BIOS backup is done! Press any key to continue.
Note
Saving BIOS:
ASUS M4A89GTD PRO Series
3-7
Updating the BIOS file
To update the BIOS file using BIOS Updater
1.
At the FreeDOS prompt, type bupdater /pc /g and press <Enter>.
D:\>bupdater /pc /g
2.
The BIOS Updater screen appears as below.
ASUSTek BIOS Updater for DOS V1.00b [09/06/22]
FLASH TYPE: MXIC 25L1605A
Current ROM
BOARD: M4A89GTD PRO Series
VER: 0109
DATE: 01/07/2010
Update ROM
BOARD: Unknown
VER: Unknown
DATE: Unknown
PATH: A:\
M4A89GTD.ROM
A:
Note
[Enter] Select or Load
[Up/Down/Home/End] Move
3.
2097152 2010-01-11 17:30:48
[Tab] Switch
[B] Backup
[V] Drive Info
[Esc] Exit
Press <Tab> to switch between screen fields and use the <Up/Down/Home/End> keys
to select the BIOS file and press <Enter>. BIOS Updater checks the selected BIOS file
and prompts you to confirm BIOS update.
Chapter 3
Are you sure to update BIOS?
Yes
4.
No
Select Yes and press <Enter>. When BIOS update is done, press <ESC> to exit BIOS
Updater. Restart your computer.
DO NOT shut down or reset the system while updating the BIOS to prevent system boot
failure!
3-8
•
For BIOS Updater version 1.04 or later, the utility automatically exits to the DOS
prompt after updating BIOS.
•
Ensure to load the BIOS default settings to ensure system compatibility and stability.
Select the Load Setup Defaults item under the Exit BIOS menu. See Chaper 3 of
your motherboard user manual for details.
•
Ensure to connect all SATA hard disk drives after updating the BIOS file if you have
disconnected them.
Chapter 3: BIOS setup
3.3
BIOS setup program
A BIOS Setup program is provided for BIOS item modification. When you start up the
computer, the system provides you with the opportunity to run this program. Press <Del>
during the Power-On Self-Test (POST) to enter the Setup utility. Otherwise, POST continues
with its test routines.
If you wish to enter Setup after POST, restart the system by pressing <Ctrl> + <Alt> + <Delete>,
or by pressing the reset button on the system chassis. You can also restart by turning the
system off and then back on. Do this last option only if the first two failed.
The Setup program is designed to make it as easy to use as possible. Being a menu-driven
program, it lets you scroll through the various submenus and select from the available options
using the navigation keys.
The BIOS setup screens shown in this section are for reference purposes only, and
may not exactly match what you see on your screen.
•
If the system becomes unstable after changing any BIOS setting, load the default
settings to ensure system compatibility and stability. Select the Load Setup Defaults
item under the Exit menu. See section 3.10 Exit Menu for details.
•
If the system fails to boot after changing any BIOS setting, try to clear the CMOS and
reset the motherboard to the default value. ������������
See section 2.6 Jumper for details.
BIOS menu screen
Menu items
Main
Menu bar
Ai Tweaker
System Time
System Date
Language
SATA1
SATA2
SATA3
SATA4
SATA5
SATA6
Storage Configuration
Configuration fields
BIOS SETUP UTILITY
Advanced
Power
Boot
General help
Tools
Exit
[13:51:25]
[Mon 01/11/2010]
[English]
Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.
[HDT722516DLA380]
[Not Detected]
[ATAPI DVD DH1]
[Not Detected]
[Not Detected]
[Not Detected]
Use [+] or [-] to
configure system Date.
System Information
←→
↑↓
+Tab
F1
F10
ESC
Chapter 3
3.3.1
•
Select Screen
Select Item
Change Field
Select Field
General Help
Save and Exit
Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
Submenu items
3.3.2
Navigation keys
Menu bar
The menu bar on top of the screen has the following main items:
Main
For changing the basic system configuration
Ai Tweaker
For changing the overclocking settings
Advanced
For changing the advanced system settings
Power
For changing the advanced power management (APM) configuration
Boot
For changing the system boot configuration
Tools
For configuring options for special functions
Exit
For selecting the exit options and loading default settings
ASUS M4A89GTD PRO Series
3-9
3.3.3
Navigation keys
At the bottom right corner of a menu screen are the navigation keys for that particular menu.
Use the navigation keys to select items in the menu and change the settings.
The navigation keys may differ from one screen to another.
3.3.4
Menu items
The highlighted item on the menu bar displays the specific items for that menu. For example,
selecting Main shows the Main menu items.
The other items (Ai Tweaker, Advanced, Power, Boot, Tools, and Exit) on the menu bar have
their respective menu items.
3.3.5
Submenu items
A solid triangle before each item on any menu screen means that the item has a submenu. To
display the submenu, select the item and press <Enter>.
3.3.6
Configuration fields
These fields show the values for the menu items. If an item is user-configurable, you can
change the value of the field opposite the item. You cannot select an item that is not
user-configurable.
A configurable field is enclosed in brackets, and is highlighted when selected. To change the
value of a field, select it and press <Enter> to display a list of options. Refer to 3.3.7 Pop-up
window.
Chapter 3
3.3.7
Pop-up window
Select a menu item and press <Enter> to
display a pop-up window with the configuration
options for that item.
3.3.8
BIOS SETUP UTILITY
Advanced
Power
Boot
Ai Tweaker
Suspend Mode
ACPI Version Features
ACPI APIC support
Tools
Exit
Use [ENTER], [TAB] or
[SHIFT-TAB] to select
a field.
[Auto]
[Disabled]
[Enabled]
Disabled
Enabled
Use [+] or [-] to
configure system Time.
APM Configuration
Hardware Monitor
Scroll bar
A scroll bar appears on the right side of a
menu screen when there are items that do not
fit on the screen. Press the Up/Down arrow
keys or <Page Up> / <Page Down> keys to
display the other items on the screen.
3.3.9
Main
←→
↑↓
+-
Tab
F1
F10
ESC
Select Screen
Select Item
Change Field
Select Field
General Help
Save and Exit
Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
Scroll bar
Pop-up window
General help
At the top right corner of the menu screen is a brief description of the selected item.
3-10
Chapter 3: BIOS setup
3.4
Main menu
When you enter the BIOS Setup program, the Main menu screen appears, giving you an
overview of the basic system information. Select an item and press <Enter> to display the
submenu.
Refer to section 3.3.1 BIOS menu screen for information on the menu screen items and
how to navigate through them.
Main
Ai Tweaker
System Time
System Date
Language
SATA1
SATA2
SATA3
SATA4
SATA5
SATA6
Storage Configuration
BIOS SETUP UTILITY
Advanced
Power
Boot
Tools
Exit
[13:51:25]
[Mon 01/11/2010]
[English]
Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.
[HDT722516DLA380]
[Not Detected]
[ATAPI DVD DH1]
[Not Detected]
[Not Detected]
[Not Detected]
Use [+] or [-] to
configure system Date.
←→
↑↓
+Tab
F1
F10
ESC
System Information
Select Screen
Select Item
Change Field
Select Field
General Help
Save and Exit
Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
3.4.1
SATA 1–6
Chapter 3
While entering Setup, the BIOS automatically detects the presence of SATA devices. There
is a separate submenu for each SATA device. Select a device item and press <Enter> to
display the SATA device information.
BIOS SETUP UTILITY
Main
SATA 1
Device
: Hard Disk
Vendor
: HDT722516DLA380
Size
: 164.7GB
LBA Mode
: Supported
Block Mode
: 16Sectors
PIO Mode
: 4
Async DMA
: MultiWord DMA-2
Ultra DMA
: Ultra DMA-6
SMART Monitoring:Supported
LBA/Large Mode [Auto]
Block(Multi-sector Transfer)M
[Auto]
PIO Mode [Auto]
DMA Mode [Auto]
SMART Monitoring [Auto]
32Bit Data Transfer [Enabled]
Select the type
of device connected
to the system.
←→
↑↓
+F1
F10
ESC
Select Screen
Select Item
Change Field
General Help
Save and Exit
Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
The BIOS automatically detects the values opposite the dimmed items (Device, Vendor, Size,
LBA Mode, Block Mode, PIO Mode, Async DMA, Ultra DMA, and SMART Monitoring). These
values are not user-configurable. These items show N/A if no SATA device is installed in the
system.
ASUS M4A89GTD PRO Series
3-11
Type [Auto]
Allows you to select the type of device installed.
[Not Installed]
[Auto]
[CDROM]
[ARMD]
Select this option if no device is installed.
Allows automatic selection of the appropriate device type.
Select this option if you are specifically configuring a CD-ROM drive.
Select [ARMD] (ATAPI Removable Media Device) if your device is either a
ZIP, LS-120, or MO drive.
This item appears in SATA 5/SATA 6 only.
LBA/Large Mode [Auto]
[Auto]
[Disabled]
Select [Auto] to enable the LBA mode (Logical Block Addressing mode)
if the device supports this mode, and if the device was not previously
formatted with LBA mode disabled.
Disables this function.
Block (Multi-Sector Transfer) M [Auto]
[Auto]
[Disabled]
When set to [Auto], the data transfer from and to the device occurs in
multiple sectors at a time if the device supports multi-sector transfer feature.
When set to [Disabled], the data transfer from and to the device occurs one
sector at a time.
PIO Mode [Auto]
Chapter 3
[Auto]Allows automatic selection of the PIO (Programmed input/output) modes,
which correspond to different data transfer rates.
[0] [1] [2] [3] [4]Sets the PIO mode to Mode 0, 1, 2, 3, or 4.
DMA Mode [Auto]
DMA (Direct Memory Access) allows your computer to transfer data to and from the hardware
devices installed with much less CPU overhead.
The DMA mode consists of SDMA (single-word DMA), MDMA (multi-word DMA), and UDMA
(Ultra DMA). Setting to [Auto] allows automatic selection of the DMA mode.
SMART Monitoring [Auto]
[Auto]Allows automatic selection of the S.M.A.R.T (Smart Monitoring, Analysis,
and Reporting Technology).
[Enabled]Enables the S.M.A.R.T feature.
[Disabled]Disables the S.M.A.R.T feature.
32Bit Data Transfer [Enabled]
[Enabled]Sets the controller to combine two 16-bit reads from the hard disk into
a single 32-bit double word transfer to the processor. This makes more
efficient use of the PCI bus as fewer transactions are needed for the
transfer of a particular amount of data.
[Disabled]Disables this function.
3-12
Chapter 3: BIOS setup
3.4.2
Storage Configuration
The Storage Configuration menu allows you to configure your storage devices. Select an item
then press <Enter> to display the submenu.
BIOS SETUP UTILITY
Main
Storage Configuration
OnChip SATA Channel
OnChip SATA Type
SATA Port5 - Port6
[Enabled]
[Native IDE]
[Native IDE]
OnChip SATA Channel [Enabled]
[Enabled]
[Disabled]
Enables the onboard channel SATA port.
Disables the onboard channel SATA port.
The following two items appear only when you set the OnChip SATA Channel item to
[Enabled].
OnChip SATA Type [Native IDE]
Allows you to set the SATA configuration.
Set to [Native IDE] when you want to use the Serial ATA hard disk drives as
Parallel ATA physical storage devices.
Set to [RAID] when you want to create a RAID configuration from the SATA
hard disk drives.
Set to [AHCI] when you want the SATA hard disk drives to use the AHCI
(Advanced Host Controller Interface). The AHCI allows the onboard storage
driver to enable advanced Serial ATA features that increases storage
performance on random workloads by allowing the drive to internally
optimize the order of commands.
[RAID]
[AHCI]
•
When this item is set to [AHCI], the information of the SATA connectors 1–6 can be
seen only under the OS environment or during POST.
•
For Windows® XP OS, you have to install the AHCI driver, so that you could use the
SATA connectors 1–6 in AHCI mode under the OS environment.
Chapter 3
[Native IDE]
SATA Port5 - Port6 [Native IDE]
Setting this item to [Native IDE] instead of [RAID] or [AHCI] allows the system to
recognize the optical dirves connected to the SATA connectors 5 or 6 when installing
OS.
If you use a SATA optical drive to run the OS installation disk, we strongly recommend that
you install the optical dirve to the SATA connectors 5/6 and set them to [Native IDE] mode.
ASUS M4A89GTD PRO Series
3-13
3.4.3
System Information
This menu gives you an overview of the general system specifications. The BIOS automatically
detects the BIOS information, CPU specification, and system memory in this menu.
Main
BIOS SETUP UTILITY
EC BIOS Version
: MBEC-0007
BIOS Information
Version
: 0109
Build Date: 01/07/10
Processor
Type
: AMD Phenom(tm) II X4 945 Processor
Speed
: 3010MHz
System Memory
Usable Size
: 768MB
Chapter 3
3-14
Chapter 3: BIOS setup
3.5
Ai Tweaker menu
The Ai Tweaker menu items allow you to configure overclocking-related items.
Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect field
values can cause the system to malfunction.
The configuration options for this chapter vary depending on the CPU and DIMM model you
installed on the motherboard.
Main
Ai Tweaker
BIOS SETUP UTILITY
Advanced
Power
Boot
Configure System Performance Settings
CPU Level UP
[Auto]
------------------------------------------------OC Tuner Utility
Ai Overclock Tuner
[Auto]
CPU Ratio
[Auto]
DRAM Frequency
[Auto]
CPU/NB Frequency
[Auto]
HT Link Speed
[Auto]
DRAM Timing Configuration
DRAM Driving Configuration
******* Please key in numbers directly! *******
CPU & NB Voltage Mode
[Offset]
CPU Offset Voltage
1.308 [Auto]
CPU/NB Offset Voltage 1.100 ������
[Auto]
CPU VDDA Voltage
2.490 [Auto]
DRAM Voltage
1.500 [Auto]
HT Voltage
1.196 [Auto]
NB Voltage
1.093 [Auto]
Tools
Exit
Warning: this function
belongs to overclocking, and it may cause
instability.
Select a CPU level,
and the rest will be
auto-adjusted. If you
want to adjust more,
set Ai Overclock Tuner
to Manual after you
select a CPU level.
←→
↑↓
+F1
F10
ESC
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
NB 1.8V Voltage
1.950 [Auto]
SB Voltage
1.100 [Auto]
SidePort Memory Voltage 1.500 [Auto]
***********************************************
CPU Load-Line Calibration
[Auto]
CPU/NB Load-Line Calibration [Auto]
CPU Spread Spectrum
[Auto]
PCIE Spread Spectrum
[Auto]
************** GFX Overclocking ***************
Internal Graphics Mode
[UMA+SIDEPORT]
UMA Frame Buffer Size
[Auto]
SIDEPORT Clock Speed
[DDR3-1333MHz]
GFX Engine Clock Override
[Disabled]
←→
↑↓
+F1
F10
ESC
Chapter 3
Scroll down to display the following items:
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
3.5.1
CPU Level UP [Auto]
Allows you to select a CPU level, and the related parameters will be automatically adjusted
according to the selected CPU level. If you want to manually configure the settings in detail,
set Ai Overclock Tuner to [Manual] after selecting a CPU level.
Configuration options: [Auto] [Phenom II-955] [Phenom II-3.4G] [Phenom II-3.6G]
•
The configuration options vary depending on the CPU model you install on the
motherboard.
•
The CPU Level UP function support depends on CPU types.
ASUS M4A89GTD PRO Series
3-15
3.5.2
OC Tuner Utility
OC Tuner utility automatically overclocks the frequency and voltage of the CPU and DRAM.
Press <Enter> to start auto tuning. It takes around five minutes, and the system will reboot for
several times until auto tuning is completed.
3.5.3
Ai Overclock Tuner [Auto]
Allows you to select the CPU overclocking options to achieve the desired CPU internal
frequency. Select any of these preset overclocking configuration options:
Manual
Allows you to individually set overclocking parameters.
Auto
Loads the optimal settings for the system.
D.O.C.P
CPU Level UP
Allows you to select a DRAM O.C. profile, and the related parameters
will be adjusted automatically.
Allows you to select a CPU level, and the related parameters will be
adjusted automatically.
The configuration options for the following sub-items vary depending on the CPU/DIMMs
you install on the motherboard.
OC From CPU Level UP [Auto]
This item appears only when you set the Ai Overclock Tuner item to [Manual] and allows
you to select a CPU level. The related parameters will be automatically adjusted according to
the selected CPU level.
CPU Bus Frequency [XXX]
Chapter 3
This item appears only when you set the Ai Overclock Tuner item to [Manual] and ���������
displays
the frequency sent by the clock generator to the system bus and PCI bus. Use the <+> and
<-> keys to adjust the CPU Bus frequency. You can also key in the desired frequency using
the numeric keypad. The values range from 100 to 600.
PCIE Frequency [XXX]
This item appears only when you set the Ai Overclock Tuner item to [Manual] and �������
allows
you to set the PCI Express frequency. Use the <+> and <-> keys to adjust the PCIE
frequency. You can also key in the desired value using the numeric keypad. The values range
from 100 to 150.
DRAM O.C. Profile [DDR3-1600MHz]
This item appears only when you set the Ai Overclock Tuner item to [D.O.C.P.] and allows
you to select a DRAM O.C. profile, which applies different settings to DRAM frequency,
DRAM timing and DRAM voltage. Configuration options: [DDR3-1600MHz] [DDR3-1800MHz]
[DDR3-1866MHz]
Profile Info : xxxxMHz–x-x-x-xx
This item appears only when you set the Ai Overclock Tuner item to [D.O.C.P.] and displays
the current DRAM profile information. The profile information varies according to the DRAM
O.C. Profile you’ve selected.
3-16
Chapter 3: BIOS setup
3.5.4
CPU Ratio [Auto]
Allows you to set the ratio between the CPU Core Clock and the FSB Frequency. Use the
<+> and <-> keys to adjust the ratio. The valid value ranges vary according to your CPU
model.
3.5.5
DRAM Frequency [Auto]
Allows you to set the DDR3 operating frequency. The configuration options vary with the CPU
Bus Frequency item settings.
Selecting a very high DRAM frequency may cause the system to become unstable! If this
happens, revert to the default setting.
3.5.6
CPU/NB Frequency [Auto]
Allows you to select the CPU/NB frequency.
Configuration options: [Auto] [800MHz] [1000MHz] [1200MHz] [1400MHz] [1600MHz]
[1800MHz] [2000MHz]
3.5.7
HT Link Speed [Auto]
Allows you to select the HyperTransport link speed.
Configuration options: [Auto] [200MHz] [400MHz] [600MHz] [800MHz] [1000MHz] [1200MHz]
[1400MHz] [1600MHz] [1800MHz] [2000MHz]
3.5.8
DRAM Timing Configuration
Chapter 3
The configuration options for some of the following items vary depending on the DIMMs
you install on the motherboard.
DRAM CAS# Latency [Auto]
Configuration options: [Auto] [4 CLK] – [12 CLK]
DRAM RAS# to CAS# Delay [Auto]
Configuration options: [Auto] ������������������
[5 CLK] – [12 CLK]
DRAM RAS# PRE Time [Auto]
Configuration options: [Auto] ������������������
[5 CLK] – [12 CLK]
DRAM RAS# ACT Time [Auto]
Configuration options: [Auto] �������������������
[15 CLK] – [30 CLK]
DRAM READ to PRE Time [Auto]
Configuration options: [Auto] �������������������������������
[4 CLK] [5 CLK] [6 CLK] [7 CLK]
DRAM Row Cycle Time [Auto]
Configuration options: [Auto] [11 CLK] – [41 CLK]
ASUS M4A89GTD PRO Series
3-17
DRAM WRITE Recovery Time [Auto]
Configuration options: [Auto] �������������������������������������������������
[5 CLK] [6 CLK] [7 CLK] [8 CLK] [10 CLK] [12 CLK]
DRAM RAS# to RAS# Delay [Auto]
Configuration options: [Auto] �������������������������������
[4 CLK] [5 CLK] [6 CLK] [7 CLK]
DRAM READ to WRITE Delay [Auto]
Configuration options: [Auto] ������������������
[3 CLK] – [17 CLK]
DRAM WRITE to READ Delay(DD) [Auto]
Configuration options: [Auto] ������������������
[2 CLK] – [10 CLK]
DRAM WRITE to READ Delay(SD) [Auto]
Configuration options: [Auto]��������������������������������
[4 CLK] [5 CLK] [6 CLK] [7 CLK]
DRAM WRITE to WRITE Timing [Auto]
Configuration options: [Auto] [3 CLK] – [10 CLK]
DRAM READ to READ Timing [Auto]
Configuration options: [Auto] [3 CLK] – [10 CLK]
DRAM REF Cycle Time [Auto]
Configuration options: [Auto] [90ns] [������������������������������
110ns�������������������������
]������������������������
[160ns] [300ns] [350ns]
DRAM Refresh Rate [Auto]
Chapter 3
Configuration options: [Auto] [Every 7.8ms] [Every 3.9ms]
DRAM Command Rate [Auto]
Configuration options: [Auto] [1T] [2T]
3.5.9
DRAM Driving Configuration
The configuration options for some of the following items vary depending on the DIMMs
you install on the motherboard.
CKE drive strength [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
CS/ODT drive strength [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
ADDR/CMD drive strength [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
MEMCLK drive strength [Auto]
Configuration options: [Auto] [0.75x] [1x] [1.25x] [1.5x]
3-18
Chapter 3: BIOS setup
Data drive strength [Auto]
Configuration options: [Auto] [0.75x] [1x] [1.25x] [1.5x]
DQS drive strength [Auto]
Configuration options: [Auto] [0.75x] [1x] [1.25x] [1.5x]
Processor ODT [Auto]
Configuration options: [Auto] [240 ohms +/- 20%] [120 ohms +/- 20%] [60 ohms +/- 20%]
Some of the following items are adjusted by typing the desired values using the numeric
keypad and press the <Enter> key. You can also use the <+> and <-> keys to adjust the
value. To restore the default setting, type [auto] using the keyboard and press the <Enter>
key.
3.5.10
CPU & NB Voltage Mode [Offset]
Allows you to set the CPU & CPU/NB Voltage Mode. Different sub-items appear according to
the CPU & NB Voltage Mode item setting. Configuration options: [Offset] [Manual]
CPU Offset Voltage [Auto]
This item appears only when you set the CPU & NB Voltage Mode item to [Offset] and
allows you to set the CPU Offset voltage. The values range from 0.003125V to 0.700000V
with a 0.003125V interval.
CPU/NB Offset Voltage [Auto]
Chapter 3
This item appears only when you set the CPU & NB Voltage Mode item to [Offset]
and allows you to set the CPU/NB Offset voltage. The values range from 0.003125V to
0.700000V with a 0.003125V interval.
CPU Voltage [Auto]
This item appears only when you set the CPU & NB Voltage Mode item to [Manual] and
allows you to set a fixed CPU voltage.
CPU/NB Voltage [Auto]
This item appears only when you set the CPU & NB Voltage Mode item to [Manual] and
allows you to set a fixed CPU/NB voltage.
3.5.11
CPU VDDA Voltage [Auto]
Allows you to set the CPU VDDA voltage. The values range from 2.20000V to 2.90000V with
a 0.00625V interval.
3.5.12
DRAM Voltage [Auto]
Allows you to set the DRAM voltage. The values range from 1.20000V to 2.50000V with a
0.00625V interval.
ASUS M4A89GTD PRO Series
3-19
3.5.13
HT Voltage [Auto]
Allows you to set the HyperTransport voltage. The values range from 0.80000V to 1.40000V
with a 0.00625V interval.
3.5.14
NB Voltage [Auto]
Allows you to set the Northbridge voltage. The values range from 0.80000V to 2.00000V with
a 0.00625V interval.
3.5.15
NB 1.8V Voltage [Auto]
Allows you to set the Northbridge 1.8V voltage. The values range from 1.80V to 2.10V with a
0.05V interval.
3.5.16
SB Voltage [Auto]
Allows you to set the Southbridge voltage. The values range from 1.10V to 1.40V with a
0.05V interval.
3.5.17
SidePort Memory Voltage [Auto]
Allows you to set the SidePort memory voltage. The values range from 1.50V to 1.80V with a
0.10V interval.
Chapter 3
3.5.18
•
Setting the above voltages to a high level may damage the CPU, memory module,
and chipset permanently. Proceed with caution.
•
The system may require a better cooling system to work stably under high voltage
settings.
CPU Load-Line Calibration [Auto]
Allows you to select the CPU Load-Line mode.
Configuration options: [Auto] [Disabled] [Enabled]
3.5.19
CPU/NB Load-Line Calibration [Auto]
Allows you to select the CPU/NB Load-Line mode.
Configuration options: [Auto] [Disabled] [Enabled]
3.5.20
[Auto]
[Disabled]
[Enabled]
3.5.21
[Auto]
[Disabled]
[Enabled]
3-20
CPU Spread Spectrum [Auto]
Automatic configuration.
Enhances the CPU overclocking ability.
Sets to [Enabled] for EMI control.
PCIE Spread Spectrum [Auto]
Automatic configuration.
Enhances the PCIE overclocking ability.
Sets to [Enabled] for EMI control.
Chapter 3: BIOS setup
3.5.22
Internal Graphics Mode [UMA+SIDEPORT]
Allows you to select the Internal Graphics Mode.
Configuration options: [Disabled] [UMA] [SIDEPORT] [UMA+SIDEPORT]
UMA Frame Buffer Size [Auto]
This item appears only when you set the Internal Graphics Mode item to [UMA] or
[UMA+SIDEPORT]. Configuration options: [Auto] [32MB] [64MB] [128MB] [256MB] [512MB]
SIDEPORT Clock Speed [DDR3-1333MHz]
This item appears only when you set the Internal Graphics Mode item to [SIDEPORT]
or [UMA+SIDEPORT]. Be cautious when setting the SIDEPORT clock speed. Improper
overclock setting may cause the system unstable or hardware damage.
3.5.23
GFX Engine Clock Override [Disabled]
Allows you to enable or disable the GFX Engine Clock Override function.
Configuration options: [Disabled] [Enabled]
GFX Engine Clock [500]
Chapter 3
This item appears only when you set the GFX Engine Clock Override item to [Enabled] and
allows you to set the GFX Engine Clock. Use the <+> and <-> keys to adjust the value, or key
in the desired value using the numeric keypad and press the <Enter> key.
ASUS M4A89GTD PRO Series
3-21
3.6
Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other system
devices.
Be cautious when changing the settings of the Advanced menu items. Incorrect field values
can cause the system to malfunction.
Main
Ai Tweaker
BIOS SETUP UTILITY
Advanced
Power
Boot
Tools
Exit
Configure CPU.
CPU Configuration
Chipset
Onboard Devices Configuration
USB Configuration
PCIPnP
←→
↑↓
Enter
F1
F10
ESC
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
3.6.1
CPU Configuration
The items in this menu show the CPU-related information that the BIOS automatically detects.
The items shown in this screen may be different due to the CPU you installed.
Chapter 3
BIOS SETUP UTILITY
Advanced
CPU Configuration
AGESA Version:3.5.4.0
Options
AMD Phenom(tm) II X4 945 Processor
Revision: C2
Cache L1: 512KB
Cache L2: 2048KB
Cache L3: 6MB
Speed
: 3010MHz,
NB Clk: 2000MHz
uCode Patch Level
: 0x1000086
Microcode Updation
Secure Virtual Machine Mode
Cool‘n’Quiet
ASUS Core Unlocker
C1E Support
Enabled
Disabled
[Enabled]
[Enabled]
[Enabled]
[Disabled]
[Enabled]
Microcode Updation [Enabled]
[Enabled]
[Disabled]
Allows the system to update the Microcode automatically, enhancing
system performance.
Disables this function.
Secure Virtual Machine Mode [Enabled]
[Enabled]
[Disabled]
3-22
Enables the AMD Secure Virtual Machine mode.
Disables this function.
Chapter 3: BIOS setup
Cool‘n’Quiet [Enabled]
[Enabled]
[Disabled]
Enables the AMD Cool’n’Quiet function.
Disables this function.
ASUS Core Unlocker [Disabled]
[Enabled]
[Disabled]
Enables the ASUS Core Unlocker to get the full computing power of the
processor.
Disables this function.
C1E Support [Enabled]
[Enabled]
[Disabled]
3.6.2
Enables the C1E support function. This item should be enabled in order to
enable the Enhanced Halt Sate.
Disables this function.
Chipset
The Chipset menu allows you to change the advanced chipset settings. Select an item then
press <Enter> to display the submenu.
BIOS SETUP UTILITY
Advanced
Advanced Chipset Settings
Options for NB
NorthBridge Configuration
890GX Configuration
NorthBridge Chipset Configuration
Chapter 3
BIOS SETUP UTILITY
Advanced
NorthBridge Chipset Configuration
DRAM Controller Configuration
ECC Configuration
DRAM Controller Configuration
BIOS SETUP UTILITY
Advanced
DRAM Controller Configuration
Channel Interleaving
MemClk Tristate C3/ATLVID
Memory Hole Remapping
DCT Unganged Mode
Power Down Enable
[XOR of Address bit]
[Disabled]
[Enabled]
[Always]
[Disabled]
Enable Channel Memory
Interleaving
Channel Interleaving [XOR of Address bit]
Configuration options: [Disabled] [Address bits 6] [Address bits 12]
[XOR of Address bits [20:16, 6]] [XOR of Address bits [20:16, 9]]
MemClk Tristate C3/ATLVID [Disabled]
Configuration options: [Disabled] [Enabled]
ASUS M4A89GTD PRO Series
3-23
Memory Hole Remapping [Enabled]
Configuration options: [Disabled] [Enabled]
DCT Unganged Mode [Always]
Configuration options: [Auto] [Always]
Power Down Enable [Disabled]
Enables or disables the DDR power down mode.
Configuration options: [Disabled] [Enabled]
Power Down Mode [Channel]
This item appears only when you enable the previous item and allows you to set the
DDR power down mode. Configuration options: [Channel] [Chip Select]
ECC Configuration
BIOS SETUP UTILITY
Advanced
ECC Configuration
ECC Mode
DRAM ECC Enable
DRAM SCRUB REDIRECT
4-Bit ECC Mode
DRAM BG Scrub
Data Cache BG Scrub
L2 Cache BG Scrub
L3 Cache BG Scrub
[Disabled]
[Disabled]
[Disabled]
[Disabled]
[Disabled]
[Disabled]
[Disabled]
[Disabled]
Set the level of ECC
protection. Note: The
‘Super’ ECC mode
dynamically sets the
DRAM scrub rate so
all of memory is
scrubbed in 8 hours.
ECC Mode [Disabled]
Chapter 3
Disables or sets the DRAM ECC mode that allows the hardware to report and correct
memory errors.
[Disabled]
[Basic]
[Good]
[Super]
[Max]
[User]
3-24
Disables the DRAM ECC mode.
Set to [Basic] to adjust ECC mode automatically.
Set to [Good] to adjust ECC mode automatically.
Set to [Super] to adjust the DRAM BG Scrub sub-item manually.
Set to [Max] to adjust ECC mode automatically.
Set to [User] to adjust all the subitems manually.
Chapter 3: BIOS setup
890GX Chipset Configuration
BIOS SETUP UTILITY
Advanced
890GX Chipset Configuration
Internal Graphics Conf
Internal Graphics Configuration
Primary Video Controller
[PCI-GFX0-GPP-IGFX]
Internal Graphics Configuration
BIOS SETUP UTILITY
Advanced
Internal Graphics Configuration
UMA-SP Interleave Mode
SP Power Management
SP NB Termination
SP Memory Termination
SP CMD Holde
SP DATA Hold
[Auto]
[Dynamic CMD]
[Auto]
[Auto]
[Auto]
[Auto]
Surround View
FB Location
[Auto]
[Above 4G]
AMD 880 HD Audio
[Enable]
Auto - Fine interleave
Ratio/Size selected
based on system
configuration (HT Freq,
number of memory
channel).
UMA-SP Interleave Mode [Auto]
This item appears only when you set the Internal Graphics Mode item to
[UMA+SIDEPORT]. Configuration options: [Auto] [Coarse] [Fine]
The following five items appear only when you set the Internal Graphics Mode item to
[SIDEPORT] or [UMA+SIDEPORT].
SP Power Management [Dynamic CMD]
Chapter 3
Configuration options: [Auto] [Dynamic CKE] [Dynamic CMD] [Dynamic CLK] [Disable]
SP NB Termination [Auto]
Configuration options: [Auto] [Disable] [Enabled]
SP Memory Termination [Auto]
Configuration options: [Auto] [Disable] [Enabled]
SP CMD Hold [Auto]
Configuration options: [Auto] [Disable] [Enabled]
SP DATA Hold [Auto]
Configuration options: [Auto] [Disable] [Enabled]
Surround View [Auto]
If you set the PCI Express device as the primary display and enable this item, you may use
the internal graphics as the secondary display. This
����������������������������������������
item appears only when you set the
Internal Graphics Mode item to [UMA], [SIDEPORT], or [UMA+SIDEPORT].
Configuration options: [Auto] [Enabled] [Disabled]
When set to [Auto], only the primary display could be activated.
ASUS M4A89GTD PRO Series
3-25
FB Location [Above 4G]
Allows you to select the FB Location. Configuration options: [Below 4G] [Above 4G]
AMD 880 HD Audio [Enabled]
Allows you to disable or enable the AMD 880 HD Audio.
Configuration options: [Disabled] [Enabled]
Primary Video Controller [PCI-GFX0-GPP-IGFX]
Allows you to select the graphics controller to use as the primary boot device.
Configuration options: [GFX0-GPP-IGFX-PCI] [GPP-GFX0-IGFX-PCI]
[PCI-GFX0-GPP-IGFX] [IGFX-GFX0-GPP-PCI]
3.6.3
Onboard Devices Configuration
Advanced
BIOS SETUP UTILITY
Onboard Devices Configuration
Serial Port1 Address
Serial Port1 Mode
Onboard LAN
Onboard LAN Boot ROM
Onboard 1394 Controller
[3F8/IRQ4]
[Normal]
[Enabled]
[Disabled]
[Enabled]
HD Audio Azalia Device
Front Panel Type
SPDIF OUT Type
[Enabled]
[HD]
[SPDIF]
On Board ATA Controller
On Board ATA Controller ROM
Onboard USB 3.0 Controller
[Enabled]
[Enabled]
[Enabled]
Allows BIOS to select
Serial Port1 Base
Addresses.
Chapter 3
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Serial Port1 Mode [Normal]
Allows you to select the Serial Port1 mode.
Configuration options: [Normal] [IrDA] [ASK IR]
Onboard LAN [Enabled]
[Enabled]
[Disabled]
Enables the onboard LAN controller.
Disables the controller.
Onboard LAN Boot ROM [Disabled]
This item appears only when you set the previous item to [Enabled].
[Enabled] Enables the onboard Gigabit LAN Boot ROM.
[Disabled] Disables the LAN Boot ROM.
Onboard 1394 Controller [Enabled]
[Enabled]
[Disabled]
3-26
Enables the onboard IEEE 1394a controller.
Disables the controller.
Chapter 3: BIOS setup
HD Audio Azalia Device [Enabled]
Allows you to enable or disable the HD Audio controller.
Configuration options: [Auto] [Disabled] [Enabled]
The following three items appear only when you set the HD Audio Azalia Device item to
[Enabled] or [Auto].
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or highdefinition audio depending on the audio standard that the front panel audio module supports.
[AC 97]
[HD]
Sets the front panel audio connector (AAFP) mode to legacy AC’97
Sets the front panel audio connector (AAFP) mode to high definition audio.
SPDIF OUT Type [SPDIF]
If your graphics card has HDMI output and needs to use SPDIF signal from the SPDIF_Out
header, you need to set to HDMI for HDMI audio output.
[SPDIF]
[HDMI]
Sets to [SPDIF Output] for SPDIF audio output.
Sets to [HDMI Output] for HDMI audio output.
On Board ATA Controller [Enabled]
[Enabled]
[Disabled]
Enables the onboard ATA controller.
Disables the controller.
On Board ATA Controller ROM [Enabled]
This item appears only when you set the previous item to [Enabled].
Chapter 3
[Enabled] Enables the onboard ATA controller ROM.
[Disabled] Disables the onboard ATA controller ROM.
Onboard USB 3.0 Controller [Enabled] (M4A89GTD PRO/USB3 model only)
[Enabled]
[Disabled]
3.6.4
Enables the USB 3.0 controller.
Disables the controller.
USB Configuration
The items in this menu allow you to change the USB-related features. Select an item and
press <Enter> to display the configuration options.
Advanced
BIOS SETUP UTILITY
USB Configuration
Module Version - 2.24.5-13.4
USB Devices Enabled:
2 Hubs
USB Support
Legacy USB Support
USB 2.0 Controller Mode
BIOS EHCI Hand-Off
ASUS M4A89GTD PRO Series
[Enabled]
[Auto]
[HiSpeed]
[Enabled]
3-27
The USB Devices Enabled item shows the auto-detected values. If no USB device is
detected, the item shows None.
USB Support [Enabled]
[Enabled]
[Disabled]
Enables the USB Host Controllers.
Disables the controllers.
The following items appear only when you set USB Support to [Enabled].
Legacy USB Support [Auto]
[Auto]
[Enabled]
[Disabled]
Allows the system to detect the presence of USB devices at startup. If
detected, the USB controller legacy mode is enabled. If no USB device is
detected, the legacy USB support is disabled.
Enables the support for USB devices on legacy operating systems (OS).
Disables the function.
USB 2.0 Controller Mode [HiSpeed]
[FullSpeed]
Sets the USB 2.0 controller mode to FullSpeed (12 Mbps).
[HiSpeed]
Sets the USB 2.0 controller mode to HiSpeed (480 Mbps).
BIOS EHCI Hand-off [Enabled]
[Enabled]
[Disabled]
Chapter 3
3.6.5
Enables the support for operating systems without an EHCI hand‑off feature.
Disables the function.
PCIPnP
The PCI PnP menu items allow you to change the advanced settings for PCI/PnP devices.
Advanced
BIOS SETUP UTILITY
Advanced PCI/PnP Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
Plug And Play O/S
[No]
Plug And Play O/S [No]
[Yes]
[No]
3-28
When set to [Yes] and if you install a Plug and Play operating system, the
operating system configures the Plug and Play devices not required for boot.
When set to [No], BIOS configures all the devices in the system.
Chapter 3: BIOS setup
3.7
Power menu
The Power menu items allow you to change the settings for the Advanced Power
Management (APM). Select an item then press <Enter> to display the configuration options.
Main
Ai Tweaker
BIOS SETUP UTILITY
Advanced
Power
Boot
Suspend Mode
Repost Video on S3 Resume
ACPI 2.0 Support
ACPI APIC Support
[Auto]
[No]
[Disabled]
[Enabled]
Tools
Exit
Select the ACPI state
used for System
Suspend.
APM Configuration
Hardware Monitor
←→
↑↓
Enter
F1
F10
ESC
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
3.7.1
Suspend Mode [Auto]
Allows you to select the Advanced Configuration and Power Interface (ACPI) state to be used
for system suspend.
[Auto]The system automatically configures the ACPI suspend mode.
[S1 (POS) only] Sets the ACPI suspend mode to S1/POS (Power On Suspend).
[S3 only]
Sets the ACPI suspend mode to S3/STR (Suspend To RAM).
Repost Video on S3 Resume [No]
Chapter 3
3.7.2
Determines whether to invoke VGA BIOS POST on S3/STR resume.
[No]
[Yes]
3.7.3
[Disabled]
[Enabled]
3.7.4
[Disabled]
[Enabled]
The system will not invoke VGA BIOS POST on S3/STR resume.
The system invokes VGA BIOS POST on S3/STR resume.
ACPI 2.0 Support [Disabled]
The system will not add additional tables as per ACPI 2.0 specifications.
The system adds additional tables as per ACPI 2.0 specifications.
ACPI APIC Support [Enabled]
The system disables the Advanced Configuration and Power Interface
(ACPI) support in the Advanced Programmable Interrupt Controller (APIC).
The ACPI APIC table pointer is included in the RSDT pointer list.
ASUS M4A89GTD PRO Series
3-29
3.7.5
APM Configuration
BIOS SETUP UTILITY
Power
APM Configuration
EuP Ready [Disabled]
Restore on AC Power Loss [Disabled]
Power On By PCI/PCIE Device [Disabled]
Power On By�������������������������
PS/2 Devices [Disabled]
Power On By Ring [Disabled]
Power On By RTC Alarm [Disabled]
EuP Ready [Disabled]
[Disabled]
[Enabled]
Disables the Energy Using Products (EuP) Ready function.
Allows BIOS to switch off some power at S5 state to get system ready for
the EuP requirement. When set to [Enabled], power for WOL, WO_USB,
audio and onboard LEDs will be switched off at S5 state.
Restore On AC Power Loss [Disabled]
[Power On]
[Disabled]
[Last State]
The system goes into on state after an AC power loss.
The system goes into off state after an AC power loss.
The system goes into either off or on state, whatever the system state was
before the AC power loss.
Power On By PCI/PCIE Device [Disabled]
[Disabled]
[Enabled]
Disables the PME to wake up from S5 by PCI/PCIE devices.
Allows you to turn on the system through a PCI/PCIE LAN or modem card.
This feature requires an ATX power supply that provides at least 1A on the
+5VSB lead.
Chapter 3
Power On By PS/2 Devoces [Disabled]
[Disabled]
[Enabled]
Disables the Power On by a PS/2 devices.
Enables the Power On by a PS/2 devices. This feature requires an ATX
power supply that provides at least 1A on the +5VSB lead.
Power On By Ring [Disabled]
[Disabled]Disables to power up the computer when the external modem receives a
call while the computer is in Soft-off mode.
[Enabled]The computer could be powered up when the external modem receives a
call while the computer is in Soft-off mode.
The computer cannot receive or transmit data until the computer and applications are fully
running. Thus, connection cannot be made on the first try. Turning an external modem
off and then back on while the computer is off causes an initialization string that turns the
system power on.
Power On By RTC Alarm [Disabled]
[Disabled]
[Enabled]
3-30
Disables RTC to generate a wake event.
When set to [Enabled], the items RTC Alarm Date (Days) and System
Time will become user-configurable with set values.
Chapter 3: BIOS setup
3.7.6
Hardware Monitor
BIOS SETUP UTILITY
Power
Hardware Monitor
CPU Temperature
CPU Temperature
MB Temperature
[35ºC/95ºF]
[34ºC/93ºF]
CPU Fan Speed
Chassis Fan Speed
Chassis Fan 2 Speed
Power Fan Speed
[3590RPM]
[N/A]
[N/A]
[N/A]
VCORE
Voltage
3.3V Voltage
5V
Voltage
12V
Voltage
[ 1.040V]
[ 3.008V]
[ 4.776V]
[11.648V]
CPU Q-Fan Function
CPU Fan Speed Low Limit
Select Fan Type :
CPU Q-Fan Mode
Chassis Q-Fan Function
[Enabled]
[200 RPM]
[PWR Fan]
[Optimal]
[Disabled]
←→
↑↓
Enter
F1
F10
ESC
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
CPU Temperature(PECI) / MB Temperature �������������
[xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU and motherboard
temperatures. Select Ignored if you do not wish to display the detected temperatures.
CPU Fan Speed [xxxxRPM] or [Ignored] / [N/A]
Chassis Fan / Chassis Fan 2 Speed [xxxxRPM] or [Ignored] / [N/A]
Power Fan Speed [xxxxRPM] or [Ignored] / [N/A]
Chapter 3
The onboard hardware monitor automatically detects and displays the CPU, chassis,
and power�����������������������������������������������������������������������������
fan speed in rotations per minute (RPM). If the fan is not connected to the
motherboard, the field shows N/A. Select Ignored if you do not wish to display the detected
speed.
VCORE Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage
The onboard hardware monitor automatically detects the voltage output through the onboard
voltage regulators. Select Ignored if you do not want to detect this item.
CPU Q-Fan Function [Enabled]
[Disabled]
[Enabled]
Disables the CPU Q-Fan control feature.
Enables the CPU Q-Fan control feature.
The following two items appear only when you set CPU Q-Fan Function to [Enabled].
CPU Fan Speed Low Limit [200 RPM]
A warning message will appear to remind you that the CPU fan speed is lower than the
selected value.
Configuration options: [500RPM] [400RPM] [300RPM] [200RPM] [100RPM] [Ignored]
Select Fan Type: [PWR Fan]
[PWR Fan]Sets to [PWR Fan] when using a 4-pin CPU fan.
[DC Fan]Sets to [DC Fan] when using a 3-pin CPU fan.
ASUS M4A89GTD PRO Series
3-31
CPU Q-Fan Mode [Standard]
[Turbo]
Sets to [Turbo] to achieve maximum CPU fan speed.
[Standard]Sets to [Standard] to make the CPU fan automatically adjust depending on
the CPU temperature.
[Silent]Sets to [Silent] to minimize the fan speed for quiet CPU fan operation.
[Manual]Sets to [Manual] to assign detailed fan speed control parameters.
The following four items appear only when you set CPU Q-Fan Mode to [Manual].
CPU Upper Temperature [70ºC/158ºF]
Sets the upper limit of the CPU temperature.
Configuration options: ���������������������������������������������������
[30ºC/86ºF] ���������������������������������������
[40ºC/104ºF] [50ºC/122ºF] [60ºC/140ºF]
[70ºC/158ºF] [80ºC/176ºF] [90ºC/194ºF]
CPU Fan Max. Duty Cycle [100%]
Sets the maximum CPU fan duty cycle. When the CPU temperature reaches the upper
limit, the CPU fan will operate at the maximum duty cycle.
Configuration options: [20%] [30%] [40%] [50%] [60%] [70%] [80%] [90%] [100%]
CPU Lower Temperature [20ºC/68ºF]
Displays the lower limit of the CPU temperature.
CPU Fan Min. Duty Cycle [20%]
Sets the minimum CPU fan duty cycle. When the CPU temperature is under 20ºC/68ºF,
the CPU fan will operate at the minimum duty cycle.
Configuration options: [00%] [10%] [20%] [30%] [40%] [50%] [60%] [70%] [80%] [90%]
[100%]
Chapter 3
Chassis Q-Fan Mode [Disabled]
[Disabled]
[Enabled]
Disables the Chassis Q-Fan control feature.
Enables the Chassis Q-Fan control feature.
The following item appears only when you set Chassis Q-Fan Mode to [Enabled].
Chassis Fan Speed Low Limit [200 RPM]
A warning message will appear to remind you that the chassis fan speed is lower than the
selected value.
Configuration options: [500RPM] [400RPM] [300RPM] [200RPM] [100RPM] [Ignored]
Chassis Q-Fan Mode [Silent]
[Turbo]
Sets to [Turbo] to achieve maximum chassis fan speed.
[Standard]Sets to [Standard] to make the chassis fan automatically adjust depending
on the chassis temperature.
[Silent]Sets to [Silent] to minimize fan speed for quiet chassis fan operation.
[Manual]Sets to [Manual] to assign detailed fan speed control parameters.
3-32
Chapter 3: BIOS setup
The following four items appear only when you set Chassi Q-Fan Mode to [Manual].
Upper Temperature [70ºC/158ºF]
Sets the upper limit of the system temperature.
Configuration options: [30/86ºF] [40ºC/104ºF] [50ºC/122ºF] [60ºC/140ºF] [70ºC/158ºF]
[80ºC/176ºF] [90ºC/194ºF]
Chassis Fan Max. Duty Cycle [100%]
Sets the maximum chassis fan duty cycle. When the system temperature reaches the
upper limit, the chassis fan will operate at the maximum duty cycle.
Configuration options: [20%] [30%] [40%] [50%] [60%] [70%] [80%] [90%] [100%]
Lower Temperature [20ºC/68ºF]
Displays the lower limit of the system temperature.
Chassis Fan Min. Duty Cycle [20%]
Sets the minimum chassis fan duty cycle. When the system temperature is under
20ºC/68ºF, the chassis fan will operate at the minimum duty cycle.
Configuration options: [00%] [10%] [20%] [30%] [40%] [50%] [60%] [70%] [80%] [90%]
[100%]
3.8
Boot menu
The Boot menu items allow you to change the system boot options. Select an item then press
<Enter> to display the submenu.
Ai Tweaker
BIOS SETUP UTILITY
Advanced
Power
Boot
Tools
Exit
Specifies the Boot Device
Boot Priority sequence.
Boot Settings
Boot Device Priority
Chapter 3
Main
A virtual floppy disk
drive (Floppy Drive B:
) may appear when you
set the CD-ROM drive
as the first boot
device.
Boot Settings Configuration
Security
←→
↑↓
Enter
F1
F10
ESC
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
3.8.1
Boot Device Priority
BIOS SETUP UTILITY
Boot
Boot Device Priority
1st Boot Device
2nd Boot Device
3rd Boot Device
ASUS M4A89GTD PRO Series
[Removable Dev.]
[Hard Drive]
[ATAPI CD-ROM]
3-33
1st – xxth Boot Device [Removable Dev.]
These items specify the boot device priority sequence from the available devices. The number
of device items that appears on the screen depends on the number of devices installed in the
system. Configuration options: [Removable
�������������������������������������������������������
Dev.] [Hard Drive] [ATAPI CD-ROM] [Disabled]
3.8.2
•
To select the boot device during system startup, press <F8> when ASUS Logo appears.
•
To access Windows OS in Safe Mode, do any of the following:
- Press <F5> when ASUS Logo appears.
- Press <F8> after POST.
Boot Settings Configuration
BIOS SETUP UTILITY
Boot
Boot Settings Configuration
Quick Boot Full Screen Logo
AddOn ROM Display Mode
Bootup Num-Lock
Wait For ‘F1’ If Error
Hit ‘DEL’ Message Display
[Enabled]
[Enabled]
[Force BIOS]
[On]
[Enabled]
[Enabled]
Allows BIOS to skip
certain tests while
booting. This will
decrease the time
needed to boot the
system.
Quick Boot [Enabled]
[Disabled]
When set to [Disabled], BIOS performs all the POST items.
[Enabled]When set to [Enabled], BIOS skips some power on self tests (POST) while
booting to decrease the time needed to boot the system.
Full Screen Logo [Enabled]
Chapter 3
[Enabled]
[Disabled]
Enables the full screen logo display feature.
Disables the full screen logo display feature.
Set this item to [Enabled] to use the ASUS MyLogo 2™ feature.
AddOn ROM Display Mode [Force BIOS]
[Force BIOS]
The third-party ROM messages will be forced to display during the boot
sequence.
[Keep Current] The third-party ROM messages will be displayed only if the third-party
manufacturer had set the add-on device to do so.
Bootup Num-Lock [On]
[Off]
[On]
Sets the power-on state of the NumLock to [Off].
Sets the power-on state of the NumLock to [On].
Wait For ‘F1’ If Error [Enabled]
[Disabled]
[Enabled]
Disables this function.
The system waits for the <F1> key to be pressed when error occurs.
Hit ‘DEL’ Message Display [Enabled]
[Disabled]
[Enabled]
3-34
Disables this function.
The system displays the message “Press DEL to run Setup” during POST.
Chapter 3: BIOS setup
3.8.3
Security
The Security menu items allow you to change the system security settings. Select an item
and press <Enter> to display the configuration options.
BIOS SETUP UTILITY
Boot
Security Settings
Supervisor Password
User Password
: Not Installed
: Not Installed
<Enter> to change
password.
<Enter> again to
disable password.
Change Supervisor Password
Change User Passward
Change Supervisor Password
Select this item to set or change the supervisor password. The Supervisor Password item
on top of the screen shows the default Not Installed. After you set a password, this item
shows Installed.
To set a Supervisor Password:
1.
Select the Change Supervisor Password item and press <Enter>.
2.
From the password box, key in a password composed of at least six letters and/or
numbers, then press <Enter>.
3.
Confirm the password when prompted.
The message Password Installed appears after you successfully set your password.
To change the supervisor password, follow the same steps as in setting a user password.
To clear the supervisor password, select the Change Supervisor Password then press
<Enter>. The message Password Uninstalled appears.
Chapter 3
If you have forgotten your BIOS password, you can clear clear it by erasing the CMOS Real
Time Clock (RTC) RAM. See section 2.6 Jumper for information on how to erase the RTC
RAM.
After you have set a supervisor password, the other items appear to allow you to change
other security settings.
BIOS SETUP UTILITY
Boot
Security Settings
Supervisor Password
User Password
: Installed
: Installed
Change Supervisor Password
User Access Level
Change User Password
Clear User Password
Password Check
<Enter> to change
password.
<Enter> again to
disabled password.
[Full Access]
[Setup]
User Access Level [Full Access]
This item allows you to select the access restriction to the Setup items.
[No Access]
[View Only]
[Limited]
[Full Access]
Prevents user access to the Setup utility.
Allows access but does not allow change to any field.
Allows changes only to selected fields, such as Date and Time.
Allows viewing and changing all the fields in the Setup utility.
ASUS M4A89GTD PRO Series
3-35
Change User Password
Select this item to set or change the user password. The User Password item on top of the
screen shows the default Not Installed. After you set a password, this item shows Installed.
To set a User Password:
1.
Select the Change User Password item and press <Enter>.
2.
On the password box that appears, type a password composed of at least six letters
and/or numbers, then press <Enter>.
3.
Confirm the password when prompted.
The message Password Installed appears after you set your password successfully.
To change the user password, follow the same steps as in setting a user password.
Clear User Password
Select this item to clear the user password.
Password Check [Setup]
[Setup]
[Always]
BIOS checks for user password when accessing the Setup utility.
BIOS checks for user password both when accessing Setup and booting
the system.
Chapter 3
3-36
Chapter 3: BIOS setup
3.9
Tools menu
The Tools menu items allow you to configure options for special functions. Select an item
then press <Enter> to display the submenu.
Main
Ai Tweaker
BIOS SETUP UTILITY
Advanced
Power
Boot
Tools
Exit
ASUS EZ Flash 2
Express Gate Enter OS Timer
Reset User Data
[Auto]
[10 Seconds]
[No]
ASUS O.C. Profile
AI NET 2
POST State LEDs
[Enabled]
←→
↑↓
Enter
F1
F10
ESC
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
3.9.1
ASUS EZ Flash 2
Allows you to run ASUS EZ Flash 2. When you press <Enter>, a confirmation message
appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to
confirm your choice.
For more details, refer to section 3.2.2 ASUS EZ Flash 2 utility.
Express Gate [Auto]
Chapter 3
3.9.2
Allows you to enable or disable the ASUS Express Gate feature. The ASUS Express Gate
feature is a unique instant-on environment that provides quick access to the Internet browser
and Skype. Configuration options: [Enabled] [Disabled] [Auto]
Enter OS Timer [10 Seconds]
Sets countdown duration that the system waits at the Express Gate’s first screen before
starting Windows or other installed OS. Choose [Prompt User] to stay at the first screen of
Express Gate for user action.
Configuration options: [Prompt User] [1 second] [3 seconds] [5 seconds] ������������
[10 seconds]
[15 seconds] [20 seconds] [30 seconds]
Reset User Data [No]
Allows you to clear Express Gate’s user data.
[Reset]When setting this item to [Reset], ensure that you save the setting to the
BIOS so that the user data will be cleared the next time you enter the
Express Gate. User data includes the Express Gate’s settings as well as
any personal information stored by the web browser such as bookmarks,
cookies, browsing history. This is useful in the rare case where corrupt
settings prevent the Express Gate environment from launching properly.
ASUS M4A89GTD PRO Series
3-37
[No]Sets to [No] to disable the Reset User Data function when entering the
Express Gate.
The first time wizard will run again when you enter the Express Gate environment after
clearing its settings.
3.9.3
ASUS O.C. Profile
This item allows you to store or load multiple BIOS settings.
BIOS SETUP UTILITY
O.C. PROFILE Configuration
O.C.
O.C.
O.C.
O.C.
O.C.
O.C.
O.C.
O.C.
Profile
Profile
Profile
Profile
Profile
Profile
Profile
Profile
1
2
3
4
5
6
7
8
Status
Status
Status
Status
Status
Status
Status
Status
:
:
:
:
:
:
:
:
Not
Not
Not
Not
Not
Not
Not
Not
Installed
Installed
Installed
Installed
Installed
Installed
Installed
Installed
Tools
Typing your profile
name, [0-9][a-z][A-Z]
are acceptable.
Status:
Add Your CMOS Profile.
Name:
Save To:
Load CMOS Profiles.
Load From:
[Default-Profile]
[Uninstalled]
[Blank]
←→
↑↓
F1
F10
ESC
Select Screen
Select Item
General Help
Save and Exit
Exit
Start O.C. Profile
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
Chapter 3
Add Your CMOS Profile
Allows you to save the current BIOS file to the BIOS Flash. In the Name sub-item, key in
your profile name and press <Enter>, and then choose a profile number to save your CMOS
settings in the Save to sub-item.
Load CMOS Profiles.
Allows you to load the previous BIOS settings saved in the BIOS Flash. Press <Enter> to
load the file.
3-38
Chapter 3: BIOS setup
Start O.C. Profile
Allows you to run the utility to save and load CMOS. Press <Enter> to run the utility.
ASUSTek O.C. Profile Utility V2.12
Current CMOS
BOARD: M4A89GTD PRO Series
VER: 0109
DATE: 01/07/2010
Restore CMOS
BOARD: Unknown
VER: Unknown
DATE: Unknown
PATH: A:\
A:
[Enter] Select or Load
[Up/Down/Home/End] Move
3.9.4
[Tab] Switch
[B] Backup
[V] Drive Info
[Esc] Exit
•
This function can support devices such as a USB flash disk with FAT 32/16 format and
single partition only.
•
DO NOT shut down or reset the system while updating the BIOS to prevent the
system boot failure!
•
We recommend that you update the BIOS file only coming from the same memory/CPU
configuration and BIOS version.
•
Only the CMO file can be loaded.
Chapter 3
Note
AI NET 2
BIOS SETUP UTILITY
AI NET 2
Pair Status
Tools
Length
Check Realtek LAN cable
[Disabled]
Check Realtek LAN cable [Disabled]
[Disabled]
[Enabled]
3.9.5
[Enabled]
[Disabled]
BIOS will not check the Realtek LAN cable during the Power-On Self-Test
(POST).
BIOS checks the Realtek LAN cable during the Power-On Self-Test (POST).
POST State LEDs [Enabled]
Enables the onboard DRAM_LED.
Disables this function.
ASUS M4A89GTD PRO Series
3-39
3.10 Exit menu
The Exit menu items allow you to load the optimal or failsafe default values for the BIOS
items, and save or discard your changes to the BIOS items.
Main
Ai Tweaker
Exit Options
Exit & Save Changes
Exit & Discard Changes
Discard Changes
Load Setup Defaults
BIOS SETUP UTILITY
Advanced
Power
Boot
Tools
Exit
Exit system setup
after saving the
changes.
F10 key can be used
for this operation.
←→
↑↓
Enter
F1
F10
ESC
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
Pressing <Esc> does not immediately exit this menu. Select one of the options from this
menu or <F10> from the legend bar to exit.
Exit & Save Changes
Once you are finished making your selections, choose this option from the Exit menu to
ensure the values you selected are saved to the CMOS RAM. An onboard backup battery
sustains the CMOS RAM so it stays on even when the PC is turned off. When you select this
option, a confirmation window appears. Select Ok to save changes and exit.
Chapter 3
If you attempt to exit the Setup program without saving your changes, the program prompts
you with a message asking if you want to save your changes before exiting. Press <Enter>
to save the changes while exiting.
Exit & Discard Changes
Select this option only if you do not want to save the changes that you made to the Setup
program. If you made changes to fields other than System Date, System Time, and
Password, the BIOS asks for a confirmation before exiting.
Discard Changes
This option allows you to discard the selections you made and restore the previously saved
values. After selecting this option, a confirmation appears. Select Ok to discard any changes
and load the previously saved values.
Load Setup Defaults
This option allows you to load the default values for each of the parameters on the Setup
menus. When you select this option or if you press <F5>, a confirmation window appears.
Select Ok to load default values. Select Exit & Save Changes or make other changes before
saving the values to the non-volatile RAM.
3-40
Chapter 3: BIOS setup
Chapter 4
Chapter 4:
4.1
Software support
Installing an operating system
This motherboard supports Windows® XP/ 64-bit XP/ Vista / 64-bit Vista / 7 / 64-bit 7
operating systems (OS). Always install the latest OS version and corresponding updates to
maximize the features of your hardware.
4.2
•
Motherboard settings and hardware options vary. Use the setup procedures presented
in this chapter for reference only. Refer to your OS documentation for detailed
information.
•
Ensure that you install the Windows® XP Service Pack 2 or later versions before
installing the drivers for better compatibility and system stability.
Support DVD information
The support DVD that comes with the motherboard package contains the drivers, software
applications, and utilities that you can install to avail all motherboard features.
The contents of the support DVD are subject to change at any time without notice. Visit the
ASUS website at www.asus.com for updates.
4.2.1
Running the support DVD
Place the support DVD into the optical drive. The DVD automatically displays the Highlights
menu if Autorun is enabled in your computer. Click each menu tab and select the items you
want to install.
The Drivers menu shows the available
device drivers if the system detects
installed devices. Install the necessary
drivers to use the devices.
The Utilities
menu shows the
applications and
other software that
the motherboard
supports.
The Make Disk menu
contains items to
create the RAID/AHCI
driver disk.
The Manual menu contains
the list of supplementary user
manuals. Click an item to open
the folder of the user manual.
Click the Highlights
tab to display the
software information
Click the Contact
tab to display the
ASUS contact
information.
Click an item
to install
Chapter 4
Click an icon
to display DVD/
motherboard
information
Click to obtain the
corresponding
software manuals
If Autorun is NOT enabled in your computer, browse the contents of the support DVD to
locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run
the DVD.
ASUS M4A89GTD PRO Series
4-1
4.2.2
Obtaining the software manuals
The software manuals are included in the support DVD. Follow the instructions below to get
the necessary software manuals.
The software manual files are in Portable Document Format (PDF). Install the Adobe®
Acrobat® Reader from the Utilities menu before opening the files.
1.
Click the Manual tab. Click ASUS
Motherboard Utility Guide from
the manual list on the left.
2.
The Manual folder of the support
DVD appears. Double-click the
folder of your selected software.
3.
Some software manuals are
provided in different languages.
Double-click the language to
show the software manual.
Chapter 4
The screenshots in this section are for reference only. The actual software manuals
containing in the support DVD vary by models.
4-2
Chapter 4: Software support
4.3
Software information
Most of the applications in the support DVD have wizards that will conveniently guide you
through the installation. View the online help or readme file that came with the software
application for more information.
4.3.1
ASUS PC Probe II
PC Probe II is a utility that monitors the computer’s vital components, and detects and
alerts you of any problem with these components. PC Probe II senses fan rotations, CPU
temperature, and system voltages, among others. Because PC Probe II is software-based,
you can start monitoring your computer the moment you turn it on. With this utility, you are
assured that your computer is always at a healthy operating condition.
Launching PC Probe II
1.
Install PC Probe II from the motherboard support DVD.
2.
Launch PC Probe II by clicking Start > All Programs > ASUS > PC Probe II > PC
Probe II v1.xx.xx. The PC Probe II main window appears.
3.
The PC Probe II icon appears in the Windows® notification
��������������������������������������������
area���������������������������
. Click this icon to close
or restore the application.
PC Probe II main window
Button
Function
Opens the Configuration window
Opens the Report window
Opens the Desktop Management Interface window
Opens the Peripheral Component Interconnect window
Opens the Windows Management Instrumentation window
Chapter 4
Opens the hard disk drive, memory, CPU usage window
Shows/Hides the Preference section
Minimizes the application
Closes the application
Refer to the software manual in the support DVD or visit the ASUS website at
www.asus.com for detailed software configuration.
ASUS M4A89GTD PRO Series
4-3
4.3.2
ASUS AI Suite
ASUS AI Suite allows you to launch several ASUS utilities easily.
Launching AI Suite
1.
Install AI Suite from the motherboard support DVD.
2.
Launch AI Suite by clicking Start > All Programs > ASUS > AI Suite > AI Suite v1.xx.
xx. The AI Suite main window appears.
3.
The AI Suite icon
appears in the Windows® notification area. If you minimize the
application main window, click this icon to restore the window.
Using AI Suite
Click each utility button to launch the utility, or click the Normal button to restore system
default settings.
Click to open the monitor window that displays
system information such as CPU temperature,
CPU voltage, fan speed, and CPU/FSB frequency
Click to restore
default settings
Click to launch
each utility
Chapter 4
4-4
•
The screenshots in this section are for reference only. The actual utility buttons vary
by models.
•
Refer to the software manual in the support DVD or visit the ASUS website at
www.asus.com for detailed software configuration.
Chapter 4: Software support
4.3.3
ASUS Fan Xpert
Asus Fan Xpert allows you to adjust both the CPU and chassis fan speeds according to
different ambient temperatures and your PC’s system loading. The various fan profiles offer
flexible controls of fan speeds to achieve a quiet and cool system environment.
Launching Fan Xpert
After installing AI Suite from the motherboard support DVD, launch Fan Xpert by doubleclicking the AI Suite tray icon and then clicking the Fan Xpert button
on the AI Suite
main window.
Using Fan Xpert
Click to select a fan type
Click to select a fan profile
Click to cancel
the settings and
exit the Fan Xpert
utility
Displays the current CPU/MB temperature and the fan speeds
Click to apply the settings
•
Disable: Select this mode to disable the Fan Xpert function.
•
Turbo: This mode boosts the fan to achieve maximal fan speed for the best cooling
effect
•
Standard: This mode makes the fan adjust speed in moderate pattern.
•
Silent: This mode minimizes fan speed for quiet fan operation.
•
User: This mode allows you to change the fan profile under certain limitation.
ASUS M4A89GTD PRO Series
Chapter 4
Fan profiles
4-5
4.3.4
ASUS EPU
ASUS EPU is an energy-efficient tool that provides you with a total system power-saving
solution. It detects the current computer loading and intelligently adjusts the power in
real-time. With auto phase switching for components, the EPU automatically provides the
most appropriate power usage via intelligent acceleration and overclocking.
ASUS EPU provides you with these modes to choose from:
•
Auto Mode
•
High Performance Mode
•
Max. Power Saving Mode
When you select Auto Mode
, the system shifts modes automatically according to the
current system status. You can also configure advanced settings for each mode.
Launching EPU
After installing EPU from the motherboard support
DVD, double-click the EPU tray icon to launch the
program.
EPU main menu
GPU energy saving status
GPU Boost is available only when
you install the GPU Boost driver
from the support DVD.
Displays the following message
if no VGA power saving engine is
detected.
Chapter 4
4-6
•
EPU supports GPU power saving solution when you install the GPU Boost driver from
the support DVD and set EPU to Auto or Maximum Power Saving Mode.
•
Refer to the software manual in the support DVD or visit the ASUS website
at www.asus.com for detailed software configuration.
Chapter 4: Software support
4.3.5
ASUS Express Gate
ASUS Express Gate is an ASUS exclusive OS that provides you with quick access to the
Internet and key applications before entering the Windows® OS.
Notices about ASUS Express Gate
•
Install ASUS Express Gate from the motherboard support DVD before use.
•
ASUS Express Gate does not support SATA devices in RAID mode. See chapter 3 for
BIOS setup details.
•
ASUS Express Gate does not support SATA 6Gb/s devices. Please visit
http://support.asus.com for future Express Gate updates.
•
ASUS Express Gate supports onboard ASUS WiFi modules only. All add-on WiFi
devices (such as a USB WiFi dongle) are not supported.
•
ASUS Express Gate supports file uploading from ODD and USB drives and
downloading to USB drives only.
•
ASUS Express Gate supports installation on SATA HDDs, USB HDDs and Flash
drives with at least 1.2GB of available disk space. When installed on USB HDDs or
Flash drives, connect the drive to the prior USB port (for example, USB port 1)
before turning on the computer to speed the boot-up time.
•
ASUS Express Gate’s display output varies with different monitors. Adjust the screen
resolution from the Express Gate configuration Panel.
•
Install at least 1GB system memory for better performance.
The First Screen
Express Gate’s first screen appears within a few seconds after you power on the computer.
Click any of the application icons to
enter Express Gate environment and
launch the selected application
Turn off the computer
•
The Web Search bar is available only when the system language of Express Gate is
set to English (U.S.) or Russian, and the search provider is Yahoo!® for English and
Yandex® for Russian.
•
To enter the motherboard BIOS setup program, click Exit on the Express Gate splash
screen, and then press the <Del> key during POST.
•
Click
ASUS M4A89GTD PRO Series
Chapter 4
Click to immediately enter existing OS, or it will automatically continue booting to
existing OS when the timer above the Exit icon counts down to zero (0).
in the Express Gate environment for detailed software instructions.
4-7
4.3.6
Audio configurations
The Realtek audio CODEC provides 8-channel audio capability to deliver the ultimate audio
experience on your computer. The software provides Jack-Detection function, S/PDIF Out
support, and interrupt capability. The CODEC also includes the Realtek® proprietary UAJ®
(Universal Audio Jack) technology for all audio ports, eliminating cable connection errors and
giving users plug and play convenience.
®
Follow the installation wizard to install the Realtek® Audio Driver from the support CD/DVD
that came with the motherboard package.
If the Realtek audio software is correctly installed, you will find
the Realtek HD Audio Manager icon on the taskbar. Doubleclick on the icon to display the Realtek HD Audio Manager.
A.
Realtek HD Audio Manager
Realtek HD Audio Manager for Windows® Vista™
Set default device
button
Minimize
button
Exit button
Device
advanced
settings
Configuration
option tabs
Connector
settings
Analog
and digital
connector
status
Control
settings
window
Information
button
B.
Realtek HD Audio Manager for Windows XP
Configuration
options
Chapter 4
Control settings
window
Exit button
Minimize button
Information button
4-8
Chapter 4: Software support
4.3.7
ASUS GPU Boost
ASUS GPU Boost allows you to overclock the integrated GPU in WIndows® environment and
takes effect in real-time without exiting and rebooting the OS.
Refer to the CPU documentation before adjusting the integrated GPU voltage settings.
Setting a high voltage may damage the integrated GPU permanently, and setting a low
voltage may make the system unstable.
•
ASUS GPU Boost is available only when you install the GPU Boost driver from the
motherboard support DVD.
•
For system stability, all changes made in ASUS GPU Boost will not be saved to BIOS
settings and will not be kept on the next system boot. Use the Save Profile function
to save your customized overclocking settings and manually load the profile after
Windows starts.
•
When GPU Boost is enabled, ASUS EPU will be set to High Performance mode
automatically.
To launch ASUS GPU Boost
1.
Install the ASUS TurboV EVO utility from the motherboard support DVD.
2.
Install the ASUS GPU Boost driver from the motherboard support DVD.
3.
Click start > All Programs > ASUS > TurboV EVO > TurboV EVO.
4.
Click More Settings from the TurboV EVO main screen, and then click GPU Boost.
Adjustment
sliders
Target values
Start-up values
Click to restore all start-up settings
Chapter 4
Undoes all changes
without applying
Applies all changes immediately
You can adjust the GPU Engine Clock and GPU Voltage simultaneously in the TurboV
Easy Mode.
ASUS M4A89GTD PRO Series
4-9
4.4ASUS Unique Overclocking Utility—
TurboV EVO
ASUS TurboV EVO introduces TurboV, CPU Level UP and Turbo Key—three powerful
tools that allow you to overclock your system effectively. Install ASUS TurboV EVO from the
support DVD that came with the motherboard package.
If the TurboV EVO is correctly installed, you will find the TurboV EVO icon
on the Windows® notification area. Click on the icon to display the TurboV
EVO control panel.
4.4.1
•
Refer to the software manual in the support DVD or visit the ASUS website at
www.asus.com for detailed software configuration.
•
When TurboV EVO is enabled, ASUS EPU will be set to High Performance mode
automatically.
Using ASUS TurboV
ASUS TurboV allow you to overclock the CPU frequency, CPU voltage, CPU/NB voltage,
DRAM voltage, and the integrated GPU voltage/frequency in Windows® environment and
takes effect in real-time.
Refer to the CPU documentation before adjusting CPU voltage settings. Setting a high
voltage may damage the CPU permanently, and setting a low voltage may make the
system unstable.
For system stability, all changes made in ASUS TurboV (except for Auto Tuning) will not
be saved to BIOS settings and will not be kept on the next system boot. Use the Save
Profile function to save your customized overclocking settings and manually load the
profile after Windows starts.
Easy Mode
Manual Mode
Load profile
Auto Tuning Mode
Save the current
settings as a
new profile
Target values
Start-up values
Adjustment
sliders
Advanced GPU
settings
CPU ratio setting
for each CPU core
Advanced CPU and
chipset voltage settings
Chapter 4
Click to show / hide
more settings
Undoes all changes
without applying
Click to restore all start-up settings
4-10
Applies all changes immediately
•
GPU Boost is available only when you install the GPU Boost driver from the
motherboard support DVD.
•
For advanced overclock ability, adjust first the BIOS items, and then proceed more
detailed adjustments using TurboV.
Chapter 4: Software support
4.4.2
Using Turbo Unlocker
1.
Click More Settings, and then click CPU
Ratio.
2.
Turbo Unlocker is set to OFF by default,
allowing to you adjust the ratio of
individual CPU core. Click ON to enable
Turbo Unlocker.
3.
Read through the warning message and
click Yes to continue.
4.
Turbo Unlocker is now enabled and will
dynamically and automatically adjust
CPU core ratios based on system load.
5.
The Turbo Unlocker monitor on the
bottom-right corner of the Windows
desktop shows current CPU ratio
in real-time. You can click Turbo
Unlocker on the bottom of the monitor
to enable or disable Turbo Unlocker at
any time.
ASUS M4A89GTD PRO Series
Chapter 4
Specially-designed for AMD® 6-core and Black Edition processors, the ASUS exclusive Turbo
Unlocker allows dynamic and automatic CPU core adjustments based on system load. Follow
the instructions below to enable Turbo Unlocker and unleash the full power of your system.
4-11
4.4.3
Using ASUS TurboV Auto Tuning Mode
The Auto Tuning Mode allows smart auto-overclocking. Follow the instructions below to let
TurboV EVO detect and overclock your system.
Chapter 4
4-12
1.
Click the Auto Tuning tab, and then
click Start. You can also click More
Settings first to configure more
overclocking parameters before starting
auto-overclocking.
2.
Read through the warning messages
and click Yes to start auto-overclocking.
3.
TurboV automatically overclocks the
CPU, saves BIOS settings and restarts
the system. After re-entering Windows, a
message appears indicating auto tuning
success. Click OK to exit.
•
After pressing Start, the system starts performance tuning and may reboot 2 to 3
times. An error message indicating incorrect system shut down may appear after
system reboot. Please ignore the message and continue the tuning process. In
addition, please do not operate or manually restart the computer during the tuning
process.
•
The auto-tuned system performance varies with the installed devices such as the CPU
and DRAM.
•
The auto-tuning function overclocks your system settings, including the frequency
and voltage of the CPU and DRAM. Installation of advanced cooling systems is
recommended.
•
The auto-tuned settings will be stored in system BIOS and will take effect after the
system automatically reboots.
Chapter 4: Software support
4.4.4
Using CPU Level UP
CPU Level UP allows you to upgrade your CPU at no additional cost. Pick a CPU level you
want to overclock to, and CPU Level UP will do the rest for you.
Click the CPU Level UP tab, pick a
CPU level you want to overclock to
by adjusting the slider, and then click
Apply.
1.
The CPU Level UP function support
depends on CPU types.
2.
Read through the warning messages
and click Yes to start upgrading the CPU
and restart the system.
4.4.5
Using ASUS Turbo Key
ASUS Turbo Key allows the user to set a group of hotkeys into physical overclocking buttons.
After the easy setup, Turbo Key can boost performances without interrupting ongoing work or
games—with just one touch!
Configuring ASUS Turbo Key
1
2
3
4
1.
Click the Turbo Key tab.
2.
Select your desired hotkey combination.
3.
You can decide the performance boost level by selecting Turbo Key Profile. You can
also load personal profiles saved in the TurboV tab.
4.
Choose whether to show Turbo Key OSD and status.
5.
Click Apply to save Turbo Key settings.
Chapter 4
5
You have to press the assigned hotkeys to use the Turbo Key function.
ASUS M4A89GTD PRO Series
4-13
4.5
RAID configurations
The motherboard comes with the AMD® SB850 chipset that allows you to configure
Serial ATA hard disk drives as RAID sets. The motherboard supports the following RAID
configurations: RAID 0, RAID 1, RAID 5 and RAID 10.
4.5.1
•
You must install Windows® XP Service Pack 2 or later versions before using Serial
ATA hard disk drives. The Serial ATA RAID feature is available only if you are using
Windows® XP SP2 or later versions.
•
Due to Windows® XP / Vista limitation, a RAID array with the total capacity over 2TB
cannot be set as a boot disk. A RAID array over 2TB can only be set as a data disk
only.
•
If you want to install a Windows® operating system to a hard disk drive included in a
RAID set, you have to create a RAID driver disk and load the RAID driver during OS
installation. Refer to section 4.6 Creating a RAID driver disk for details.
RAID definitions
RAID 0 (Data striping) optimizes two identical hard disk drives to read and write data in
parallel, interleaved stacks. Two hard disks perform the same work as a single drive but at a
sustained data transfer rate, double that of a single disk alone, thus improving data access
and storage. Use of two new identical hard disk drives is required for this setup.
RAID 1 (Data mirroring) copies and maintains an identical image of data from one drive to
a second drive. If one drive fails, the disk array management software directs all applications
to the surviving drive as it contains a complete copy of the data in the other drive. This RAID
configuration provides data protection and increases fault tolerance to the entire system. Use
two new drives or use an existing drive and a new drive for this setup. The new drive must be
of the same size or larger than the existing drive.
RAID 5 stripes both data and parity information across three or more hard disk drives. Among
the advantages of RAID 5 configuration include better HDD performance, fault tolerance, and
higher storage capacity. The RAID 5 configuration is best suited for transaction processing,
relational database applications, enterprise resource planning, and other business systems.
Use a minimum of three identical hard disk drives for this setup.
RAID 10 is data striping and data mirroring combined without parity (redundancy data) having
to be calculated and written. With the RAID 10 configuration you get all the benefits of both
RAID 0 and RAID 1 configurations. Use four new hard disk drives or use an existing drive
and three new drives for this setup.
Chapter 4
4-14
Chapter 4: Software support
4.5.2
Installing Serial ATA hard disks
The motherboard supports Serial ATA hard disk drives. For optimal performance, install
identical drives of the same model and capacity when creating a disk array.
To install the SATA hard disks for a RAID configuration:
1.
Install the SATA hard disks into the drive bays.
2.
Connect the SATA signal cables.
3.
Connect a SATA power cable to the power connector on each drive.
4.5.3
Setting the RAID item in BIOS
You must enable the RAID function in the BIOS Setup before creating RAID volume(s) using
SATA HDDs. To do this:
1.
Enter the BIOS Setup during POST.
2.
Go to the Main menu > Storage Configuration, and then press <Enter>.
3.
Set the OnChip SATA Type item to [RAID].
4.
Save your changes, and then exit the BIOS Setup.
Refer to Chapter 3 for details on entering and navigating through the BIOS Setup.
Chapter 4
When setting the OnChip SATA Type item to [RAID], all SATA ports run at RAID mode.
However, you can set the SATA ports 5 and 6 to [Native IDE] or [AHCI] modes. See section
3.4.2 Storage Configuration for details.
ASUS M4A89GTD PRO Series
4-15
4.5.4
AMD® Option ROM Utility
To enter the ���
AMD® Option
��������������������
ROM utility:
1.
Boot up your computer.
2.
During POST, press <Ctrl> + <F> to display the utility main menu.
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
[ Main Menu ]
View Drive Assignments
.......[ 1 ]
LD View / LD Define Menu
......[ 2 ]
Delete LD Menu
...............[ 3 ]
Controller Configuration
......[ 4 ]
[ Keys Available ]
Press 1..4 to Select Option
[ESC] Exit
The Main Menu allows you to select an operation to perform. The Main Menu options include:
•
View Drive Assignments: shows the status of the hard disk drives.
•
LD View / LD Define
������������
Menu�: displays the existing RAID set information / creates a
RAID 0, RAID 1, RAID 5 or RAID 10 configuration.
•
Delete LD Menu: deletes a selected RAID set and partition.
•
Controller Configuration: shows the system resources configuration.
Press <1>, <2>, <3>, or <4> to enter the option you need; press <ESC> to exit the utility.
The RAID BIOS setup screens shown in this section are for reference only, and may not
exactly match the items on your screen.
Chapter 4
To create a RAID volume using more than four hard disk drives, ensure that the SATA
connectors 5/6 are set to [RAID] mode.
4-16
Chapter 4: Software support
Creating a RAID volume
To create a RAID volume:
1. In the Main Menu, press <2> to enter the LD View / LD Define Menu function.
2.
Press <Ctrl> + <C>, and the following screen appears.
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
[ LD Define Menu ]
LD No
LD
LD Name
1 Logical Drive 1
Strip Block
Gigabyte Boundary
Port:ID
01:00
02:00
03:00
04:00
64 KB
ON Drive Model
xxxxxxxxx
xxxxxxxxx
xxxxxxxxx
xxxxxxxxx
RAID Mode
RAID 0
Fast Init
Cache Mode
Drv
2
ON
WriteThru
[ Drives Assignments ]
Capabilities
Capacity(GB)
xxxxxxx xxxxxx
xxxxxxx xxxxxx
xxxxxxx xxxxxx
xxxxxxx xxxxxx
Assignment
Y
Y
N
N
[ Keys Available ]
[↑] Up [↓] Down [PaUp/PaDn] Switch page [Space] Change Option
[Ctrl-Y] Save [ESC] Exit
3.
Move to the RAID Mode item and press <Space> to select a RAID mode to create.
4.
Move to the Assignment item by using the down arrow key and set Y to select the
hard disk drives you want to include in the RAID set.
5.
Press <Ctrl> + <Y> to save the setting.
6.�����������������������������������������������������������������������������������
The utility prompts the following message. ����������������������������������������
Press <Ctrl> + <Y> to input the LD name.
Please press Ctrl-Y key to input the LD Name
or press any key to exit.
If you do not input any LD name, the default LD
name will be used.
7.
E�����������������������������������������������������
enter an LD name, and then press any key to continue.
Enter the LD name here:
8.������������������������������������������������������������������������������������
Press <Ctrl> + <Y> to erase the MBR, or you may press any key to abort the settings.
Fast Initialization Option has been selected
It will erase the MBR data of the disks.
<Press Ctrl-Y Key if you are sure to erase it>
<Press any other key to ignore this option>
Press <Ctrl> + <Y> to enter the screen to modify the array capacity, or press any key to
use the maximum capacity.
ASUS M4A89GTD PRO Series
Chapter 4
9.
4-17
Deleting a RAID configuration
Take caution when deleting a RAID volume. You will lose all data on the hard disk drives
when you delete a RAID volume.
To delete a RAID volume:
1. In the Main Menu, press <3> to enter the Delete LD function.
2.
Select the RAID item you want to delete and press <Del> or <Alt> + <D>.
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
[ Delete LD Menu ]
LD No
LD
1
[↑] Up
3.
RAID Mode
Drv
RAID 0
2
[↓] Down
Capacity(GB)
Status
xxxxxx
Functional
[ Keys Available ]
[PaUp/PaDn] Switch page [Del/Alt+D] Delete LD
The utility prompts the following messages:
Press Ctrl-Y to delte the data in the disk!
or press any other key to abort...
Press <Ctrl> + <Y> to delete the RAID volume.
Dispalying a RAID set information
To display a RAID set information:
1. In the Main Menu, press <2> to enter the “LD View / LD Define Menu” function.
2.
Select a RAID item and press <Enter> to display its information.
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
[ View LD Defination Menu ]
LD No
LD
LD Name
1 xxxxx
Strip Block
Chapter 4
Port:ID
01:00
02:00
Drive Model
xxxxxxxxx
xxxxxxxxx
RAID Mode
RAID 0
64 KB
Cache Mode
Drv
Capacity(GB)
2
157.99
WriteThru
[ Drives Assignments ]
Capabilities
Capacity(GB)
xxxxxxx xxxxxx
xxxxxxx xxxxxx
Any Key To Continue.......
4-18
Chapter 4: Software support
4.6
Creating a RAID driver disk
A floppy disk with the RAID driver is required when installing Windows® XP operating system
on a hard disk drive that is included in a RAID set. For Windows® Vista or later operating
systems, use either a USB flash drive with the RAID driver or the support DVD.
4.6.1
•
The motherboard does not provide a floppy drive connector. You have to use a
USB floppy disk drive when creating a SATA RAID driver disk.
•
Windows® XP may not recognize the USB floppy disk drive due to Windows® XP
limitation. To work around this OS limitation, refer to section 4.6.4 Using a USB
floppy disk drive.
Creating a RAID driver disk without entering the OS
To create a RAID driver disk without entering the OS
1.
Boot your computer.
2.
Press <Del> during POST to enter the BIOS setup utility.
3. Set the optical drive as the primary boot device.
4. Insert the support DVD into the optical drive.
5.
Save changes and exit BIOS.
6. When the Make Disk menu appears, press <1> to create a RAID driver disk.
7. Insert a formatted floppy disk into the USB floppy disk drive, then press <Enter>.
8. Follow the succeeding screen instructions to complete the process.
4.6.2
Creating a RAID driver disk in Windows®
To create a RAID driver disk in Windows®:
1.
Start Windows®.
2. Plug the USB floppy disk drive and insert a floppy disk.
3. Place the motherboard support DVD into the optical drive.
4. Go to the Make Disk menu, and then click AMD AHCI/RAID 32/64bit xxxx Driver to
create a RAID driver disk.
5. Select USB floppy disk drive as the destination disk.
6. Follow the succeeding screen instructions to complete the process.
Write-protect the floppy disk to avoid a computer virus infection.
Installing the RAID driver during Windows® OS installation
Chapter 4
4.6.3
If you use a SATA optical drive to run the OS installation disk, we strongly recommend that
you install the optical dirve to the SATA connectors 5/6 and set them to [Native IDE] mode.
To install the RAID driver for Windows® XP
1. During the OS installation, the system prompts you to press the F6 key to install
third-party SCSI or RAID driver.
2. Press <F6>, and then insert the floppy disk with RAID driver into the USB floppy disk drive.
ASUS M4A89GTD PRO Series
4-19
3.
When prompted to select the SCSI adapter to install, select the RAID driver for the
corresponding OS version.
4. Follow the succeeding screen instructions to complete the installation.
To install the RAID driver for Windows® Vista or later OS
1.
During the OS installation, click Load Driver to allow you to select the installation
media containing the RAID driver.
2. Insert the USB flash drive with RAID driver into the USB port or the support DVD into
the optical drive, and then click Browse.
3. Click the name of the device you’ve inserted, go to Drivers > RAID, and then select
the RAID driver for the corresponding OS version. Click OK.
4. Follow the succeeding screen instructions to complete the installation.
Before loading the RAID driver from a USB flash drive, ���������������������������������
you have to use another computer
to copy the RAID driver from the support DVD to the USB flash drive.
4.6.4
Using a USB floppy disk drive
Due to OS limitation, Windows® XP may not recognize the USB floppy disk drive when you
install the RAID driver from a floppy disk during the OS installation.
To solve this issue, add the USB floppy disk drive’s Vendor ID (VID) and Product ID (PID) to
the floppy disk containing the RAID driver. Refer to the steps below:
1.
Using another computer, plug the USB floppy disk drive, and insert the floppy disk
containing the RAID driver.
2.
Right-click My Computer on the
Windows® desktop or start menu,
and then select Manage from the
pop-up window.
3.
Select Device Manager. From the
Universal Serial Bus controllers,
right-click xxxxxx USB Floppy, and
then select Properties from the pop-up
window.
or
The name of the USB floppy disk
drive varies with different vendors.
Chapter 4
4.
4-20
Click Details tab. The Vendor ID (VID)
and Product ID (PID) are displayed.
Chapter 4: Software support
5.
Browse the contents of the RAID driver
disk to locate the file txtsetup.oem.
6.
Double-click the file. A window appears,
allowing you to select the program for
opening the oem file.
7.
Use Notepad to open the file.
8.
Find the [HardwareIds.SCSI.Napa_i386_ahci8086] and
[HardwareIds.SCSI.Napa_amd64_ahci] sections in the txtsetup.oem file.
9.
Type the following line to the bottom of the two sections:
id = “USB\VID_xxxx&PID_xxxx”, “usbstor”
[HardwareIds.SCSI.Napa_i386_ahci8086]
id= “PCI\VEN_1002&DEV_4392&CC_0104”,”ahcix86”
id= “PCI\VEN_1002&DEV_4391&CC_0106”,”ahcix86”
id= “PCI\VEN_1002&DEV_4393&CC_0104”,”ahcix86”
id= “USB\VID_03EE&PID_6901”, “usbstor”
Chapter 4
[HardwareIds.SCSI.Napa_amd64_ahci]
id= “PCI\VEN_1002&DEV_4392&CC_0104”,”ahcix64”
id= “PCI\VEN_1002&DEV_4391&CC_0106”,”ahcix64”
id= “PCI\VEN_1002&DEV_4393&CC_0104”,”ahcix64”
id= “USB\VID_03EE&PID_6901”, “usbstor”
Add the same line to both sections.
The VID and PID vary with different vendors.
10. Save and exit the file.
ASUS M4A89GTD PRO Series
4-21
Chapter 4
4-22
Chapter 4: Software support
Chapter 5
ATI® CrossFireX™ technology support
Chapter 5:
5.1
ATI® CrossFireX™ technology
5.1.1
Chapter 5
The motherboard supports the ATI® CrossFireX™ technology that allows you to install
multi-graphics processing units (GPU) graphics cards. Follow the installation procedures in
this section.
Requirements
•
Prepare two identical CrossFireX-ready graphics cards or one CrossFireX-ready dualGPU graphics card that are ATI® certified.
•
Ensure that your graphics card driver supports the ATI CrossFireX technology.
Download the latest driver from the AMD website at www.amd.com.
•
Ensure that your power supply unit (PSU) can provide at least the minimum power
required by your system. See Chapter 2 for details.
•
We recommend that you install additional chassis fans for better thermal environment.
•��������������������������������������������������������������������
Visit the AMD ATI website for the latest graphics card support list.
5.1.2
Before you begin
For ATI CrossFireX to work properly, you have to uninstall all existing graphics card drivers
before installing ATI CrossFireX graphics cards to your system.
To uninstall all existing graphics card drivers:
1.
Close all current applications.
2.
For Windows XP, go to Control Panel > Add/Remove Programs.
For Windows Vista, go to Control Panel > Programs and Features.
3.
Select your current graphics card drivers.
4.
For Windows XP, select Add/Remove.
For Windows Vista, select Uninstall.
5.
Turn off your computer.
ASUS M4A89GTD PRO Series
5-1
5.1.3
Installing two CrossFireX™ graphics cards
The following pictures are for reference only. The graphics cards and the motherboard
layout may vary with models, but the installation steps remain the same.
Chapter 5
1.
Prepare two CrossFireX-ready graphics
cards.
2.
Insert the two graphics card into the
PCIEX16 slots. If your motherboard
has more than two PCIEX16 slots,
refer to Chapter 2 in this user manual
for the locations of the PCIEX16 slots
recommended for multi-graphics card
installation.
3.
Ensure that the cards are properly
seated on the slots.
4.
Align and firmly insert the CrossFireX
bridge connector to the goldfingers on
each graphics card. Ensure that the
connector is firmly in place.
CrossFireX bridge
(bundled with
graphics cards)
5-2
5. Connect two independent auxiliary power
sources from the power supply to the two
graphics cards separately.
6.
Connect a VGA or a DVI cable to the
graphics card.
Goldfingers
Chapter 5: ATI® CrossFireX™ technology support
5.1.4
Installing the device drivers
Refer to the documentation that came with your graphics card package to install the device
drivers.
5.1.5
Chapter 5
Ensure that your PCI Express graphics card driver supports the ATI® CrossFireX™
technology. Download the latest driver from the AMD website (www.amd.com).
Enabling the ATI® CrossFireX™ technology
After installing your graphics cards and the device drivers, enable the CrossFireX™ feature
through the ATI Catalyst™ Control Center in Windows environment.
Launching the ATI Catalyst Control Center
To launch the ATI Catalyst Control Center
1.
Right-click on the Windows® desktop and select
Catalyst(TM) Control Center. You can also rightclick the ATI icon in the Windows notification area
and select Cayalist Control Center.
2.
The Catalyst Control Center Setup
Assistant appears when the system
detects the existance of multi-graphics
cards. Click Go to continue to the
Catalyst Control Center Advanced
View window.
Enabling CrossFireX settings
1.
In the Catalyst Control Center window,
click Graphics Settings > CrossFireX >
Configure.
2.
From the Graphics Adapter list, select
the graphics card to act as the display
GPU.
3.
Select Enable CrossFireX.
4.
Click Apply, and then click OK to exit
the window.
2
3
1
4
ASUS M4A89GTD PRO Series
5-3
5.2
ATI® Hybrid CrossFireX™ technology
The motherboard supports the ATI® Hybrid CrossFireX™ technology that allows you to install
multi-graphics processing units (GPU) CrossFireX cards.
Chapter 5
5.2.1
System requirements
Before using ATI Hybrid CrossFireX, ensure that your system meets the following basic
requirements:
•
Operating System: Windows® Vista
•
Memory capacity: Minimum 1GB
•
CPU: AM3
•
On-board graphics card RAM: 256MB
Visit the AMD ATI website for the latest graphics card support list.
5.2.2
Before you proceed
Configure the BIOS settings for the graphics card to support ATI Hybrid CrossFireX.
To set Internal Graphics:
1. Press <Del> during the Power-On-Self-Test (POST) to enter the BIOS Setup utility.
2. Go to the Ai Tweaker menu and set UMA Frame Buffer Size to [256M] or above
3. Select Advanced > Chipset > 890GX Configuration > Internal Graphics
Configuration, set Surround View to [Enabled].
4. Press <F10> to save the changes and exit BIOS settings. Select OK to confirm.
5.2.3
Installing AMD Chipset Driver
To install the driver that supports Hybrid CrossFireX technology:
1. Insert the Support DVD that comes with your motherboard into the optical drive. The
DVD automatically displays the Drivers menu if Autorun is enabled in your computer.
If Autorun is NOT enabled in your computer, browse the contents of the support DVD to
locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run
the DVD.
5-4
2. From the Drivers menu, click AMD Chipset Driver to install it. Follow the onscreen
instructions to finish the installation.
3.
Restart your computer after the installation is completed.
4.
When the system restarts, wait for a few seconds for the driver to load automatically.
Chapter 5: ATI® CrossFireX™ technology support
5.2.4
Using the ATI® CATALYST® Control Center
1. Install a graphics card onto your motherboard. Refer to the User Guide that comes with
your graphics card for details.
2. Right-click on the Windows® desktop,
then click ATI CATALYST(R) Control
Center from the shortcut menu. The
ATI CATALYST Control Center screen
appears.
3.
Click Graphics Settings >
CrossFire™, then select the Enable
CrossFire™ check box. When a
confirmation message pops up, click
Yes. The screen blacks out for about
one minute.
4.
Click OK. The add-on graphics card is
set to be the main monitor.
Chapter 5
Using an add-on graphics card
Using the onboard graphics card
1. Right-click on the Windows® desktop, and then click ATI CATALYST(R) Control
Center from the shortcut menu. The ATI CATALYST Control Center screen appears.
2.
Click Graphics Settings > CrossFire™,
then clear the Enable CrossFire™
check box. When a confirmation
message pops up, click Yes. The screen
blacks out for about one minute.
3.
Click OK.
ASUS M4A89GTD PRO Series
5-5
Chapter 5
4.
Right-click on the Windows® desktop,
then click Personalize from the shortcut
menu.
5. Click Display Settings. Select [Default
Monitor] on ATI Radeon HD 3200
Graphics, then select the check boxes
of This is my main monitor and
Extend the desktop onto this monitor.
Click OK, and then Yes from the
confirmation window.
6.
Restart the system. Right-click on
the Windows® desktop, then click ATI
CATALYST(R) Control Center from
the shortcut menu. The ATI CATALYST
Control Center screen appears.
7.
Click Graphics Settings > CrossFire™, then select the Enable CrossFire™ check
box. When a confirmation pops up, click Yes. The screen blacks out for about one
minute.
8.
Click OK. The onboard graphics card is set to be the main monitor.
If you are using both an add-on and the on-board graphics cards at same time and want to
set the onboard graphics card as your main monitor, follow the below instructions.
5-6
1. Follow steps 1 to 3 on Using the onboard graphics card.
2.
From the ATI CATALYST(R) Control
Center screen, click Display Manager >
Graphics Adapter. Select ATI Radeon
HD 3200 Graphics [Gabbs, G HW173].
Click OK, and then Yes from the
confirmation window.
3.
Follow steps 6 to step 8 on Using the
onboard graphics card to complete
the process of setting up the onboard
graphics card as your main monitor.
Chapter 5: ATI® CrossFireX™ technology support
(510)739-3777/(510)608-4555
800 Corporate Way, Fremont, CA 94539.
Asus Computer International
Date :
Signature :
Representative Person’s Name :
Jan. 20, 2010
Steve Chang / President
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Supplementary Information:
FCC Part 15, Subpart C, Intentional Radiators
FCC Part 15, Subpart E, Intentional Radiators
FCC Part 15, Subpart B, Unintentional Radiators
Model Number : M4A89GTD PRO/USB3
Conforms to the following specifications:
Product Name : Mother board
hereby declares that the product
Phone/Fax No:
Address:
Responsible Party Name:
Per FCC Part 2 Section 2. 1077(a)
DECLARATION OF CONFORMITY
Manufacturer:
HARKORT STR. 21-23, 40880 RATINGEN
M4A89GTD PRO/USB3
Model name :
Declaration Date: Jan. 20, 2010
Year to begin affixing CE marking:2010
CE marking
EN 62301:2005
Regulation (EC) No. 1275/2008
2005/32/EC-EuP Directive
EN 60950-1:2006
EN 60950-1:2001+A11:2004
2006/95/EC-LVD Directive
EN 300 328 V1.7.1(2006-05)
EN 300 440-1 V1.4.1(2008-05)
EN 300 440-2 V1.2.1(2008-03)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V3.2.1(2007-05)
EN 301 908-2 V3.2.1(2007-05)
EN 301 893 V1.4.1(2005-03)
EN 50360:2001
EN 50371:2002
1999/5/EC-R &TTE Directive
EN 55022:2006+A1:2007
EN 61000-3-2:2006
EN 55013:2001+A1:2003+A2:2006
2004/108/EC-EMC Directive
Signature : __________
Position : CEO
Name :
Jerry Shen
(EC conformity marking)
EN 62301:2005
Regulation (EC) No. 278/2009
EN60065:2002+A1:2006
EN 301 489-1 V1.8.1(2008-04)
EN 301 489-3 V1.4.1(2002-08)
EN 301 489-4 V1.3.1(2002-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V1.3.2(2008-04)
EN 301 489-24 V1.4.1(2007-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 55024:1998+A1:2001+A2:2003
EN 61000-3-3:1995+A1:2001+A2:2005
EN 55020:2007
conform with the essential requirements of the following directives:
Mother board
Product name :
declare the following apparatus:
GERMANY
ASUS COMPUTER GmbH
Authorized representative in Europe:
Country:
Country:
Address, City:
No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN R.O.C.
TAIWAN
Address, City:
ASUSTek COMPUTER INC.
EC Declaration of Conformity
We, the undersigned,
(510)739-3777/(510)608-4555
800 Corporate Way, Fremont, CA 94539.
Asus Computer International
Manufacturer:
HARKORT STR. 21-23, 40880 RATINGEN
M4A89GTD PRO
Model name :
Signature :
Date :
Representative Person’s Name :
Jan. 18, 2010
Steve Chang / President
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Declaration Date: Jan. 18, 2010
Year to begin affixing CE marking:2010
CE marking
EN 62301:2005
Regulation (EC) No. 1275/2008
2005/32/EC-EuP Directive
EN 60950-1:2006
Supplementary Information:
EN 60950-1:2001+A11:2004
FCC Part 15, Subpart E, Intentional Radiators
2006/95/EC-LVD Directive
EN 300 328 V1.7.1(2006-05)
EN 300 440-1 V1.4.1(2008-05)
EN 300 440-2 V1.2.1(2008-03)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V3.2.1(2007-05)
EN 301 908-2 V3.2.1(2007-05)
EN 301 893 V1.4.1(2005-03)
EN 50360:2001
EN 50371:2002
1999/5/EC-R &TTE Directive
EN 55022:2006+A1:2007
EN 61000-3-2:2006
EN 55013:2001+A1:2003+A2:2006
Signature : __________
Position : CEO
Name :
Jerry Shen
(EC conformity marking)
EN 62301:2005
Regulation (EC) No. 278/2009
EN60065:2002+A1:2006
EN 301 489-1 V1.8.1(2008-04)
EN 301 489-3 V1.4.1(2002-08)
EN 301 489-4 V1.3.1(2002-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V1.3.2(2008-04)
EN 301 489-24 V1.4.1(2007-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 55024:1998+A1:2001+A2:2003
EN 61000-3-3:1995+A1:2001+A2:2005
EN 55020:2007
conform with the essential requirements of the following directives:
2004/108/EC-EMC Directive
Mother board
Product name :
declare the following apparatus:
GERMANY
ASUS COMPUTER GmbH
Authorized representative in Europe:
Country:
Country:
Address, City:
No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN R.O.C.
TAIWAN
Address, City:
ASUSTek COMPUTER INC.
EC Declaration of Conformity
We, the undersigned,
FCC Part 15, Subpart C, Intentional Radiators
FCC Part 15, Subpart B, Unintentional Radiators
Model Number : M4A89GTD PRO
Conforms to the following specifications:
Product Name : Mother board
hereby declares that the product
Phone/Fax No:
Address:
Responsible Party Name:
Per FCC Part 2 Section 2. 1077(a)
DECLARATION OF CONFORMITY
ASUS contact information
ASUSTeK COMPUTER INC.
Address
Telephone Fax E-mail
Web site
Technical Support
Telephone Online support
15 Li-Te Road, Peitou, Taipei, Taiwan 11259
+886-2-2894-3447
+886-2-2890-7798
[email protected]
www.asus.com.tw
+86-21-38429911
support.asus.com
ASUS COMPUTER INTERNATIONAL (America)
Address
Telephone
Fax
Web site
Technical Support
Telephone Support fax
Online support
800 Corporate Way, Fremont, CA 94539, USA
+1-812-282-3777
+1-510-608-4555
usa.asus.com
+1-812-282-2787
+1-812-284-0883
support.asus.com
ASUS COMPUTER GmbH (Germany and Austria)
Address
Fax
Web site
Online contact
Technical Support
Telephone
Support Fax
Online support
Harkort Str. 21-23, D-40880 Ratingen, Germany
+49-2102-959911
www.asus.de
www.asus.de/sales
+49-1805-010923*
+49-2102-9599-11
support.asus.com
* EUR 0.14/minute from a German fixed landline; EUR 0.42/minute from a mobile phone.
