PRODUCT GUIDE
“We are integrators building
products for integrators.”
– Sean McDermott, CEO
Great people, superior design and excellence in manufacturing all play critical roles in creating all Current Audio products.
Current Audio is backed by an award winning and inspiring team of seasoned designers, engineers, and installation experts,
holding title as CE Pro Top 100 Integrators with years of patented, custom audio product development, manufacturing and
experience.
You don’t have to go far to see how the electronics industry has changed over the last few
decades but what can we say about the actual speakers?
With decades of sales and installation know-how in the speaker business, as integrators we
understand the installers’ wants, needs, and struggles because we are installers ourselves.
Current Audio presents proven and innovative products that excel in quality and performance
which will save you time and money. We carefully listen to and respond to our customers’
suggestions and needs. The result of our listening has modeled a superior company and
product line.
Current Audio is holder of fifteen international pending patents. This is a true testament of our
determination to bring a fresh set of innovative ideas to what has become known as stagnant part of the industry.
Take part in this exciting, revolutionary time in the audio industry. Start impressing your clients with the crisp and clear sound
that is Current Audio. Call us today and Believe Your Ears!™
MULTI-ROOM
AUDIO
AX-800DAV
Enjoy your media where you want it with ether the 4 zone or
8 zone multi source audio sustems. They are controlled with
your choice of in wall keypads.
o 50 Watts per channel 8 ohm - 4 ohm capable
o Backward compatible
o Output short cct, thermal and hard clipping protection
o Extensive zone linking
o Analog input level gain adjustment
o Keypad/IR connection for every zone
o Up to 120ms of adjustable audio delay per zone
o USB, RS232 and Ethernet interface
o 96 zones
o 14 amplifier presets, two page presets
o Bass, Treble, Balance Loudness adjustments per zone
o AMP-ON status: 12VDC Outputs
o 11 Sources
o Setup lockout
o Storage for up to 10 seconds of 44.1 KHz 16 Bit stereo
o Static/DHCP network connections
o 10 Buffered IR outputs. 1 – 8 have routing, 9-10 summed
o Power Supply 90 – 240VAC 50/60 HZ
o Zone 1-4 have a 4 source composite video switcher
o Power Consumption 320 WRMS
o Internal real time clock
o Standby Power 6W
o Internal Web Page
2
3
MULTI-ROOM
AUDIO
AX-KPC2.8
AX-400DA
4
o 2.8” LCD touch panel
o Range of Skins available for graphical user interface (GUI)
o Operating voltage: 12VDC ± 3V
o Support for Transparent and multilayer images
o Current draw typically 60mA – 100mA
o Background images using PNG, BMP, JPG or GIF formats
o Memory: 8Mbytes Flash for GUI and IR commands
o Anti-aliased Text with user defined Font, Color and Unicode
support
o IR learning of both Modulated and Pulse IR codes
o Polygon button outlines provide very close button spacing
o Large IR database supplied
o User defined button sounds: wav file
o Portrait or Landscape display orientations
o Wiring: Up to 300m CAT5E ‘Home Run’ RJ45 terminated
cable with option to daisy chain to another keypad.
o Full featured conditional flow macro functions
o 50 Watts per channel 8 ohm - 4 ohm capable
o Backward compatible
o Output short cct, thermal and hard clipping protection
o Extensive zone linking
o Analog input level gain adjustment
o Keypad/IR connection for every zone
o Up to 120ms of adjustable audio delay per zone
o USB, RS232 and Ethernet interface
o 96 zones
o 14 amplifier presets, two page presets
o Bass, Treble, Balance Loudness adjustments per zone
o AMP-ON status: 12VDC Outputs
o 1.5” color TFT LCD
o Large IR database supplied
o 11 Sources
o Setup lockout
o Operating voltage: 12VDC ± 3V
o Wiring: Up to 300m of CAT5E ‘Home run’ cable.
o Storage for up to 10 seconds of 44.1 KHz 16 Bit stereo
o Static/DHCP network connections
o Current draw typically 100mA, Maximum = 140mA
o Connection: RJ45 plug.
o 10 Buffered IR outputs. 1 – 8 have routing, 9-10 summed
o Power Supply 90 – 240VAC 50/60 HZ
o Memory: 8Mbytes Flash for GUI and IR commands
o Zone 1-4 have a 4 source composite video switcher
o Power Consumption 320 WRMS
o Anti-aliased Text with user defined Font, Colour and Unicode
support.
o Internal real time clock
o Standby Power 6W
o IR learning of both Modulated and Pulse IR codes
o Full featured conditional flow macro functions.
o Internal Web Page
AX-KPD
5
Platinum Series Speakers
PLATINUM
Series
We know there are those who truly want the best sound quality
for their home and office. We understand that good enough is not how you roll.
Here we introduce the tightest bass and clearest highs for you, “Believe Your Ears!”
Driver Material: Woven Carbon Fiber
•Without a doubt this is our favorite material. Woven carbon fiber is used in aerospace and Formula 1 race
cars. Five years of research through trial and error has resulted in a superior state of the art material.
•Woven carbon fiber has a very low moving mass. The lowest moving mass of any cone material. It also has
the highest stiffness of any of the materials available. The ideal driver cone has no moving mass and is stiff to
allow a perfectly linear, pistonic movement of the driver cone / voice coil assembly.
WSLCR654FL
FIT804FL
FIT654FL
WSLCR654FL
CS654DBFL
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
w/ FastLoc™ grille
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
w/ FastLoc™ grille
low profile, in-wall, coaxial,
infinite baffle loudspeaker,
w/ FastLoc™ grille
6.5” 2-way, low profile dipole/bipole,
in-ceiling,coaxial, infinite baffle
loudspeaker, w/ FastLoc™ grille
DRIVER
8” Woven Carbon Fiber Cone w/ Butyl Rubber Surround
6.5” Woven Carbon Fiber Cone w/ Butyl Rubber Surround
Two 6.5” Woven Carbon Fiber w/ Butyl Rubber Surround
6.5” Woven Carbon Fiber w/ Butyl Rubber Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm) Ceramic
Coated Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Ceramic
Coated Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm)
Ceramic Coated Aluminum Ferrofluid Cooled
Two 1” (25mm), Diffractionless Ceramic Coated Aluminum
Ferrofluid Cooled Dome
FREQ RESP
33Hz - 21kHz
35Hz - 21kHz
35Hz - 21kHz
35Hz - 21kHz
IMPEDANCE
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
8 Ohms. Three Position Crossovers
8 Ohms. Adjustable Tweeters, Selectable Dipole or Bipole
POWER
5-150 Watts
5 - 150 Watts
5 - 150 Watts
5 - 150 Watts
SPL
91.5 db 1W/1m
91.5 db 1W/1m
91.5 dB 1W/1m
91.5 db 1W/1m
PRODUCT Dimension
12 1/4” (311 mm) x 7 1/8” (182mm)
10 1/4” (260mm) x 5 5/8” (144mm)
15 3/4” (401mm) x 8 15/16” (227mm) x 3 7/8” (98.6mm)
10 1/4” (260mm) x 3 3/4” (95mm)
RETROFIT CUTOUT
10 1/2” (265mm)
8 3/8” (213mm)
14 1/5”(360.7mm) x 7 3/5”(193mm)
8 1/4” (210mm)
FASTLOCTM GRILLE Dimension
13” (330mm)
10 7/8 (276mm)
17” (432mm) x 9 5/8” (248mm)
10 7/8 (276mm)
BRACKET TYPE
NC8FITCBi
NC6CB
NC6LCRWBi
NC6CB
•The midrange articulation is amazing with this material. Neutral, uncolored midrange. One of toughest
challenges in midrange performance is reproduction of a female vocal. You listen to this driver versus other
materials and manufacturers you can really hear the difference. The woven carbon fiber allows for extremely
detailed vocals. There are no “muddy” overtones.
•The other outstanding characteristic is transient response. The speed at which a driver cone can move
forward and backwards in a linear fashion. Low moving mass allows for the driver cone to react quickly
while the stiffness of the cone allows for a linear motion that won’t allow for distortion in the low frequency
range. This gets rid of the boomy bass or muddy bass associated with inferior designs. Many manufacturers
try to get more bass by using loose and floppy mechanical suspension instead of using high stiffness low mass
assemblies.
Tweeter Material: Ceramic Coated Aluminum Dome Tweeter
•We take our 2 series aluminum dome tweeter material and add a sputtered ceramic coating to the dome.
The sputtering process is a coating of ceramic at a molecular level. It is not “painted on” or dipped in
ceramic. If it were, the coating would be too thick, too heavy and inconsistent.
•Our ceramic coating imparts a stiffness on the center of the dome to prevent high frequency distortion
caused by dome deformation at high power levels in high frequencies.
•We make adjustments in the voice coil materials to offset the small additional mass that the ceramic coating
adds. This allows for the efficiency of the tweeter to be maintained and the high frequencies to be extended.
6
CS804FL
CS804FL
CS654FL
WS804FL
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
w/ FastLoc™ grille
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
w/ FastLoc™ grille
8” 2-way, in-wall,
full range loudspeaker
w/ FastLoc™ grille
DRIVER
8” Woven Carbon Fiber Cone w/ Butyl Rubber Surround
6.5” Woven Carbon Fiber Cone w/ Butyl Rubber Surround
8” Woven Carbon Fiber Cone w/ Butyl Rubber Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm) Ceramic Coated Aluminum
Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Ceramic Coated Aluminum
Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Ceramic Coated Aluminum
Ferrofluid Cooled Dome
FREQ RESP
33Hz - 21kHz
35Hz - 21kHz
33Hz - 21kHz
IMPEDANCE
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
8 or 6 Ohms dependant on driver EQ Setting
POWER
5 - 150 Watts
5 - 150 Watts
5 - 150 Watts
SPL
91.5 db 1W/1m
91.5 db 1W/1m
91.5 db 1W/1m
PRODUCT Dimension
12 1/4” (311mm) x 4 3/8” (111mm)
10 1/4” (260mm) x 3 7/8” (98mm)
14 7/8” (378mm) x 10 1/8” (257mm) x 4 1/4” (107mm)
RETROFIT CUTOUT
9 3/4” (247mm)
8 1/4” (210mm)
13 9/16” (345mm) x 8 3/4” (233mm)
FASTLOCTM GRILLE Dimension
13” (330mm)
10 7/8 (276mm)
16 5/16” (415mm) x 10 13/16” (274mm)
BRACKET TYPE
NC8CB
NC6CB
NC8WB
7
ELITE
Series
CS802FL
Elite Series Speakers
FIT652FL
CS802FL
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
w/ FastLoc™ grille
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
w/ FastLoc™ grille
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
w/ FastLoc™ grille
DRIVER
8” Aluminum Cone w/ Butyl Rubber Surround
6.5” Aluminum Cone w/ Butyl Rubber Surround
8” Aluminum Cone w/ Butyl Rubber Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm)
Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm)
Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm)
Aluminum Ferrofluid Cooled Dome
FREQ RESP
35Hz - 20kHz
38Hz - 20kHz
35Hz - 20kHz
IMPEDANCE
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
POWER
5-150 Watts
5 - 125 Watts
5 - 150 Watts
SPL
91 db 1W/1m
91 db 1W/1m
91 db 1W/1m
PRODUCT Dimension
12 1/4” (311 mm) x 7 1/8” (182mm)
10 1/4” (260mm) x 5 5/8” (144mm)
12 1/4” (311mm) x 4 3/8” (111mm)
RETROFIT CUTOUT
10 1/2” (265mm)
8 3/8” (213mm)
9 3/4” (247mm)
FASTLOCTM GRILLE Dimension
13” (330mm)
10 7/8 (276mm)
13” (330mm)
BRACKET TYPE
NC8FITCBi
NC6CB
NC8CB
We are known for making great sounding products. We chose to
step it up for those who not only desire but demand high performance out of their system. High output, richer bass and clear clean
highs.
Driver Material: Aluminum Cone
•This was our favorite driver material for years before we perfected the woven
carbon fiber material.
•This is a special aluminum alloy with a hard coat anodized coating.
•Very low moving mass with high stiffness. The result is a driver that has great
detail in the midrange. The bass is very tight and detailed. This driver is “warm”
sounding, neutral and detailed.
Tweeter Material: Aluminum Dome Tweeter
•This tweeter dome material is not your normal aluminum dome. It is a specially
produced aluminum alloy with a hard coat anodized coating.
•This dome allows for minimum distortion of the upper dome in the higher
frequency ranges.
•The majority of the energy of the tweeter dome comes from the largest diameter
of the dome’s sphere. The majority of the acoustical energy does not come from the
center of the dome as most people think. In fact, the center of the dome’s sphere
usually breaks up and causes distortion.
8
FIT802FL
FIT802FL
FIT652FL
9
PREMIER
Series
Premier Series Speakers
CS801FL
WS801FL
We took our Signature line and tweaked it some to bring you
better clarity and smoother bass. The Premier Series brings you
that step up.
Driver Material: Injection Molded Carbon Fiber
•This material is injection molded in a plastic injection molding machining. The
material itself contains cross-linked fibers of carbon fiber.
•This material is very stiff with low mass. It is a neutral sounding material that
has great midrange response and bass response.
•This is a difficult material to work with during the manufacturing process.
The cross-linked carbon fiber, if not processed correctly, can produce a driver
cone that is not of even density. This results in distorted midrange. Very few
manufacturers use this material because of the processing challenges during
the molding process. We have several years experience in perfecting the
processing and it results in a superior cone material at a cost just above an
entry level product with enhanced performance.
Tweeter Material: Aluminum Dome Tweeter
•This tweeter dome material is not your normal aluminum dome. It is a specially produced aluminum alloy with a hard coat anodized coating.
•This dome allows for minimum distortion of the upper dome in the higher
frequency ranges.
FIT651FL
•The majority of the energy of the tweeter dome comes from the largest
diameter of the dome’s sphere. The majority of the acoustical energy does not
come from the center of the dome as most people think. In fact, the center of
the dome’s sphere usually breaks up and causes distortion.
10
CS501
FIT801FL
FIT651FL
CS801FL
CS801
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
w/ FastLoc™ grille
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
w/ FastLoc™ grille
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
w/ FastLoc™ grille
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
DRIVER
8” Injection Molded Carbon Fiber Cone w/ Butyl Rubber
Surround
6.5” Injection Molded Carbon Fiber Cone w/ Butyl Rubber
Surround
8” Injection Molded Carbon Fiber Cone w/ Butyl Rubber
Surround
8” Injection Molded Carbon Fiber Cone w/ Butyl Rubber
Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm)
Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm)
Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Aluminum
Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm)
Aluminum Ferrofluid Cooled Dome
38Hz - 20kHz
FREQ RESP
38Hz - 20kHz
40Hz - 20kHz
38Hz - 20kHz
IMPEDANCE
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
POWER
5 - 150 Watts
5 - 125 Watts
5 - 150 Watts
5 - 150 Watts
90 db 1W/1m
SPL
90 db 1W/1m
90 db 1W/1m
90 db 1W/1m
PRODUCT Dimension
12 1/4” (311 mm) x 7 1/8” (182mm)
10 1/4” (260mm) x 5 5/8” (144mm)
12 1/4” (311mm) x 4 3/8” (111mm)
12 1/4” (311mm) x 4 3/8” (111mm)
RETROFIT CUTOUT
10 1/2” (265mm)
8 3/8” (213mm)
9 3/4” (247mm)
9 3/4” (247mm)
FASTLOCTM GRILLE Dimension
13” (330mm)
10 7/8 (276mm)
13” (330mm)
NA
BRACKET TYPE
NC8FITCBi
NC6CB
NC8CB
NC8CB
CS651FL
CS501
WS801FL
WS651FL
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
w/ FastLoc™ grille
5.25” 2-way, in-ceiling,
coaxial, infinite baffle loudspeaker
8” 2-way, in-wall,
full range loudspeaker
w/ FastLoc™ grille
6.5” 2-way, in-wall,
full range loudspeaker
w/ FastLoc™ grille
DRIVER
6.5” Injection Molded Carbon Fiber Cone w/ Butyl Rubber
Surround
5.25” Injection Molded Graphite Cone w/ Butyl Rubber
Surround
8” Injection Molded Carbon Fiber Cone w/ Butyl Rubber
Surround
6.5” Injection Molded Carbon Fiber Cone w/ Butyl Rubber
Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm)
Aluminum Ferrofluid Cooled Dome
3/4” (19mm) Titanium Coated Polycarbonate Ferrofluid
Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm)
Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Aluminum
Ferrofluid Cooled Dome
FREQ RESP
40Hz - 20kHz
55Hz - 19kHz
38Hz - 20kHz
40Hz - 20kHz
IMPEDANCE
8, 6 or 4 Ohms dependant on driver EQ Setting
8 Ohms. Fixed Crossovers
8 or 6 Ohms dependant on driver EQ Setting
8 or 6 Ohms dependant on driver EQ Setting
POWER
5 - 125 Watts
5 - 45 Watts
5 - 150 Watts
5 - 125 Watts
SPL
90 dB 1W/1m
89 db 1W/1m
90 db 1W/1m
90 db 1W/1m
PRODUCT Dimension
10 1/4” (260mm) x 3 7/8” (98mm)
8” (203mm) x 3 1/4” (83mm)
14 7/8” (378mm) x 10 1/8” (257mm) x 4 1/4” (107mm)
12 1/16” (310mm) x 8 3/16” (208mm) x 3 1/4” (83mm)
RETROFIT CUTOUT
8 1/4” (210mm)
6 1/2” (165mm)
13 9/16” (345mm) x 8 3/4” (233mm)
10 13/16” (270mm) x 6 3/4” (172mm)
FASTLOCTM GRILLE Dimension
10 7/8 (276mm)
NA
16 5/16” (415mm) x 10 13/16” (274mm)
13 5/8” (346mm) x 8 7/8” (225mm)
BRACKET
NC6CB
NC5CB
NC8WB
NC6WB
11
SIGNATURE
Series
Signature Series
WSLCR650FL
We started from a clean slate and made a statement
in our Signature line. Believe your ears when you hear our products.
They truly are made with passion and care.
Driver Material: MetaPlex™
•This is an electronically bonded substrate on a copolymer cone. Basically it is a
trilaminate cone, the first layer is a copolymer base material. The second layer is a
material that allows the third layer (green colored surface) to bond to the copolymer.
WS650FL
•Copolymer cones alone are found in other speakers. The key to our material is that
the green coating allows for a well damped material (the first layer) to combine with
a low mass high stiffness coating (the green layer). This improves the performance by
stiffening the cone material that is normally used alone in entry level speakers. Better
midrange performance and less bass distortion is the result from less cone breakup.
Tweeter Material: Silk Dome Tweeter
•Our silk dome tweeters use a treated soft silk dome. This material is neutral sounding
and is used in many higher end bookshelf and cabinet speakers.
12
FIT800FL
FIT650/FIT650FL
WSLCR650FL
CS650DBFL
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
w/ FastLoc™ grille
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
low profile, in-wall, coaxial,
infinite baffle loudspeaker,
w/ FastLoc™ grille
6.5” 2-way, low profile dipole/bipole,
in-ceiling, coaxial, infinite baffle
loudspeaker, w/ FastLoc™ grille
DRIVER
8” MetaPlex™ Composite Cone w/ Butyl Rubber Surround
6.5” MetaPlex™ Composite Cone w/ Butyl Rubber Surround
Two 6.5” MetaPlex™ Composite w/ Butyl Rubber Surround
6.5” MetaPlex™ Composite Cone w/Butyl Rubber Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm) Silk
Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Silk
Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Silk
Ferrofluid Cooled Dome
Two 1” (25mm), Diffractionless Dome Silk Ferrofluid
Cooled Dome
FREQ RESP
40Hz - 20kHz
42Hz - 20kHz
42Hz - 20kHz
42Hz - 20kHz
IMPEDANCE
8 Ohms. Fixed Crossovers
8 Ohms. Fixed Crossovers
8 Ohms. Fixed Crossover
8 Ohms. Adjustable Tweeters, Selectable Dipole or Bipole
POWER
5 - 125 Watts
5 - 100 Watts
5 - 100 Watts
5 - 100 Watts
SPL
89.5 db 1W/1m
90 db 1W/1m
90 dB 1W/1m
90dB 1W/1m
PRODUCT Dimension
12 1/4” (311 mm) x 7 1/8” (182mm)
10 1/4” (260mm) x 5 5/8” (144mm)
15 3/4” (401mm) x 8 15/16” (227mm) x 3 7/8” (98.6mm)
10 1/4” (260mm) x 3 3/4” (95mm)
RETROFIT CUTOUT
10 1/2” (265mm)
8 3/8” (213mm)
14 1/5”(360.7mm) x 7 3/5”(193mm)
8 1/4” (210mm)
FASTLOCTM GRILLE Dimension
13” (330mm)
10 7/8 (276mm)
17” (432mm) x 9 5/8” (248mm)
10 7/8 (276mm)
BRACKET TYPE
NC8FITCBi
NC6CB
NC6LCRWBi
NC6CB
CS650FL
CS650
WS650FL
WS650
6.5” 2-way, in-ceiling,
coaxial, infinite baffle loudspeaker
w/ FastLoc™ grille
6.5” 2-way, in-ceiling,
coaxial, infinite baffle loudspeaker
6.5” 2-way, in-wall,
full range loudspeaker
w/ FastLoc™ grille
6.5” 2-way, in-wall,
full range loudspeaker
DRIVER
6.5” MetaPlex™ Composite Cone w/Butyl Rubber Surround
6.5” MetaPlex™ Composite Cone w/Butyl Rubber Surround
6.5” MetaPlex™ Composite Cone w/Butyl Rubber Surround
6.5” MetaPlex™ Composite Cone w/Butyl Rubber Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm) Silk
Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Silk
Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Silk
Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Silk
Ferrofluid Cooled Dome
FREQ RESP
42Hz - 20kHz
42Hz - 20kHz
42Hz - 20kHz
42Hz - 20kHz
IMPEDANCE
8 Ohms. Fixed Crossovers
8 Ohms. Fixed Crossovers
8 Ohms. Fixed Crossover
8 Ohms. Fixed Crossover
POWER
5 - 100 Watts
5 - 100 Watts
5 - 100 Watts
5 - 100 Watts
SPL
90 db 1W/1m
90 db 1W/1m
90 db 1W/1m
90 db 1W/1m
PRODUCT Dimension
10 1/4” (260mm) x 3 7/8” (98mm)
10 1/4” (260mm) x 3 7/8” (98mm)
12 1/16” (310mm) x 8 3/16” (208mm) x 3 1/4” (83mm)
12 1/16” (310mm) x 8 3/16” (208mm) x 3 1/4” (83mm)
RETROFIT CUTOUT
8 1/4” (210mm)
8 1/4” (210mm)
10 13/16” (270mm) x 6 3/4” (172mm)
10 13/16” (270mm) x 6 3/4” (172mm)
FIT650FL
CS650FL
FASTLOCTM GRILLE Dimension
10 7/8 (276mm)
NA
13 5/8” (346mm) x 8 7/8” (225mm)
13 5/8” (346mm) x 8 7/8” (225mm)
BRACKET TYPE
NC6CB
NC6CB
NC6WB
NC6WB
13
SOUNDBARS
SB80
14
Soundbar
The SB80 & SB65 Soundbar delivers
the latest digital technology in amplified
speaker sound bars with a powerful
wireless amplified MegaBass subwoofer
by Current Audio. The powerful subwoofer can be located anywhere in the
room. This is the perfect Home Theater
System with a wide sound stage.The
system comes with a handheld remote to
control power, switch inputs and adjust
sound fields. The slim depth and sleek
design blends with all flat LED/LCD TV
models.
SB80
SB65
60 Watt Six Drivers with
Two Tweeter Soundbar
and 80 Watt 8” Wireless
Woofer w/
streaming
40 Watt Four Drivers with
Two Tweeter Soundbar
and 60 Watt 6.5” Wireless
Woofer
Soundbar Power
Subwoofer Power
60 Watts RMS Ported
80 Watts RMS Powered
40 Watts RMS Ported
60 Watts RMS Powered
Sound Mode
Selectable 2.0/2.1 with Enhanced DSP Surround Modes
Selectable 2.0/2.1 with Enhanced DSP Surround Modes
Speakers
8 Speakers. 6 2.5” Midrange Drivers and 2 1.25” Tweeters
6 Speakers. 4 2.5” Midrange Drivers and 2 1.25” Tweeters
Subwoofer
2.4GHz 8” Long Throw Ported Woofer
2.4GHz 6.5” Long Throw Ported Woofer
Audio Inputs
Digital Optical, Digital Coaxial, RCA,3.5mm
Digital Optical, Digital Coaxial, RCA,3.5mm
Connectivity for iPhone,Android,MP3 and PC
N/A
USB and SD Memory Slot
MP3,USB HD, PC, Mobile Phone
MP3,USB HD, PC, Mobile Phone
Frequency Response
20 Hz to 20 kHz
20 Hz to 20 kHz
FM Tuner
Built-in FM Tuner
Built-in FM Tuner
Soundbar Dimensions
39 3/4” (1010mm) x 3 1/2”” (89mm) x 3 5/16” (84mm)
39 3/4” (1010mm) x 3 1/2”” (89mm) x 3 5/16” (84mm)
Subwoofer Dimensions
17 1/8”(435mm) x 8 11/16”(221mm) x 14 1/4”(362mm)
16 3/8” (416mm) x 7 7/8” (200mm) x 13” (330mm)
15
AMPLIFIERS
Amplifier
Improve the quality of your whole house audio system with
powerful 2, 8 and 12 channel amplifiers that contain key
features like global and individual inputs that can be selected
per zone, Phoenix connectors which ensure reliable speaker
connection and independent gain control for each channel.
Continuous Power
Output BOTH channels
driven
16
AMP870
AMP2150
6 Zone,
12 Channel Amplifier
w/auto-sensing
4 Zone,
8 Channel Amplifier
1 Zone,
2 Channel Amplifier
w/auto-sensing
70 Watts RMS at 4 ohms
50 Watts at 8 ohms
70 Watts RMS at 4 ohms
50 Watts at 8 ohms
150 Watts RMS at 4 ohms
100 Watts RMS at 8 ohms
140 Watts per channel RMS at 8 ohms
140 Watts per channel RMS at 8 ohms
300 Watts per channel RMS at 8 ohms
Caution: Maintain an 8 ohm load in the
bridged mode
Caution: Maintain an 8 ohm load in the
bridged mode
Caution: Maintain an 8 ohm load in the
bridged mode
Input Sensitivity
500 millivolts
500 millivolts
500 millivolts
Input Impedance
20,000 ohms
20,000 ohms
20,000 ohms
Signal to Noise Ratio
95 dB
95 dB
95 dB
Frequency Response
20 Hz to 20 kHz
20 Hz to 20 kHz
20 Hz to 20 kHz
Total Harmonic
Distortion
(Unbridged or Bridged)
0.1% THD 20 Hz to 20 kHz
0.1% THD 20 Hz to 20 kHz
0.2% THD 20 Hz to 20 kHz
LENGTH x WIDTH x DEPTH
17” (431.8mm) x 4” (101.6mm) x 13”
(330.2mm)
17” (431.8mm) x 4” (101.6mm) x 13”
(330.2mm)
17” (431.8mm) x 4” (101.6mm) x 13”
(330.2mm)
Weight
32 lbs (14.6kgs)
25 lbs (11.4kgs)
18 lbs (8.2kgs)
Bridged Power Output
BoTH channels driven
AMP1270
AMP1270
17
FASTLOC
TM
Unique patent pending
mechanism allows for
quick installation
and removal
of the FastLocTM grille
Smallest exposed bezel
in the industry!
Disappears into the
mounting surface
FastLocTM grilles take only seconds to twist into place.
This allows for easy access to the installed speaker for
quick, custom positioning. Offering the smallest exposed
plastic bezel in the industry - virtually invisible!
STANDARD SPEAKER
FASTLOC SPEAKER
Available in:
18
FIT Series
CS Series
In-Wall Series
LCR Theater Series
SPA525
19
FIT
Series
Patent Pending Three-dimensional woofer positioning
Patent Pending Diffractionless, pivoting tweeter
The only speaker with the Patent Pending Positive Positioning Lock
Clear, undistorted sound where you want it, with deeper
room penetration
FIT series (Focused Image TechnologyTM) ceiling speakers incorporate a patent pending
design that allows for precise focusing of the acoustic image to the desired listening area.
No other manufacturer allows for the range of adjustability that this product offers. The
FIT series should be your first choice when purchasing home theater and distributed audio
speakers. The FIT speaker puts the sound where you want it, not where you place it.
FIT series speakers features include 3 position EQ switches, gold press terminals and
weatherized, perforated aluminum grilles. All Focused Image TechnologyTM speakers are
available in either FastLoc™ Grilles (Patent Pending) or standard press fit grilles.
Woofer. The Focused Image TechnologyTM series incorporates the patent pending (positive positioning lock) or PPL. Once positioned, PPL allows for
the woofer to be securely locked into place. The patent pending locking feature consistently focuses all of the energy to your sweet spot. In addition, the
lock prevents the woofer assembly from moving and changing the sweet spot due to temperature and humidity variations. No other manufacturer in the
marketplace can offer this exclusive locking feature.
Tweeter. Not only is our patent pending tweeter diffractionless, it’s also easily positioned to the sweet spot of the room allowing for a cleaner and
more natural sound.
20
FastLoc grille. The Focused Image TechnologyTM series are available with our patent pending FastLocTM grilles. The look of these grilles have
revolutionized the industry. They are extremely easy to install with consistent fit and finish. FastLocTM offers the industry’s smallest exposed bezel. The
mechanism that locks the grille in place is secure and vibration free.
21
LCR THEATER
Series
The easy to install LCR Theater Series are
best in class in-wall loudspeakers that
incorporate high tech woofer materials
with a butyl rubber surround and state-ofthe-art, 1” Patent pending diffractionless,
pivoting, ferrofluid-cooled dome tweeters,
ensuring true left/center/right sound with
flawless imaging.
WSLCR654FL
22
See specs on page 7
23
DIPOLE/BIPOLE
Series
CS650DBFL
See specs on page 13
24
The Dipole/Bipole Series delivers a sound much like you’d
experience in a movie theater that has multiple surround speakers.
This dual-purpose speaker rolls both side surround and surround
back applications in one package, with a switch on the tweeter
bridge deciding functionality. The dipole function sets tweeters out
of phase to create a null around the listening area that detunes the
localization for ambience, while the bipole functionality sets tweeters in phase to enhance localization for Dolby Digital EX, DTS-ES,
THX-EX and Dolby True HD. Patent Pending FastLoc™ grilles slip
into place without magnets and offer the smallest exposed bezel
on the market, seamlessly blending the speaker into the ceiling.
CS654DBFL
See specs on page 7
25
DUAL TWEETER
Series
Dual Tweeter Series Ceiling Speakers
The easy to install Dual Tweeter Series is a full
range stereo ceiling loudspeaker in a single
speaker package, perfect for bathroom and
hallway applications where a pair of speakers
isn’t practical. The dual voice coil woofer offers
revolutionary natural sound for foreground and
background applications.
CS800DTFL
26
See specs on page 13
CS800DTFL
CS650DTFL
CECS65DT
8” 2-way low profile, in-ceiling,
coaxial, infinite baffle loudspeaker,
w/ FastLoc™ grille
6.5” 2-way, in-ceiling, coaxial,
infinite baffle, dual input stereo,
single loudspeaker, w/ FastLoc™ grille
6.5” 2-way, in-ceiling, coaxial,
infinite baffle, dual input stereo,
single loudspeaker
DRIVER
8” Dual Voice Coil MetaPlex™ Composite w/Butyl
Rubber Surround
6.5” Dual Voice Coil MetaPlex™ Composite Cone w/Butyl
Rubber Surround
6.5” Dual Voice Coil, Talc Filled Polypropylene Cone w/
Butyl Rubber Surround
TWEETER
Dual 1” (25mm), Silk Ferrofluid Cooled Dome
Dual 1” (25mm) Silk Ferrofluid Cooled Dome
Dual 3/4” (19mm) Silk Ferrofluid Cooled Dome
FREQ RESP
40Hz - 20kHz
42Hz - 20kHz
55Hz - 19.5kHz
IMPEDANCE
8 Ohms. Fixed Crossovers
8 Ohms. Fixed Crossovers
8 Ohms. Fixed Crossovers
POWER
5 - 125 Watts
5 - 100 Watts
5 - 55 Watts
SPL
89.5 db 1W/1m
90 db 1W/1m
88 db 1W/1m
DIAMETER x DEPTH
12 1/4”(311mm) x 4 4/16”(112mm)
10 1/4” (259mm) X 3 3/4” (95mm)
8 15/16” (227mm) x 2 7/8” (75mm)
RETROFIT CUTOUT
DIAMETER
9 3/4” (247mm)
8 1/4” (210mm)
7 3/4” (197mm)
FASTLOCTM GRILLE
DIAMETER
13” (330mm)
10 7/8 (276mm)
NA
BRACKET
NC8CB
NC6CB
NC6CB
27
CONTRACTOR
Series
CECS65
Built to install easily in both residential and
commercial applications, the CECS Series
provides the best possible sound at a value
price level. Their talc filled polypropylene cone
drivers, butyl rubber surrounds and pivoting
5/8” polycarbonate, ferrofluid-cooled dome
tweeters are sure to outperform similar products
at much higher price points.
CECS80
28
CECS65DT
CECS Series Ceiling Speakers
CECS80
CECS65
CECS65DT
8” 2-way, in-ceiling,
coaxial, infinite baffle
loudspeaker
6.5” 2-way, in-ceiling,
coaxial, infinite baffle
loudspeaker
6.5” 2-way, in-ceiling, coaxial,
infinite baffle, dual input stereo,
single loudspeaker
DRIVER
8” Talc Filled Polypropylene Cone w/Butyl Rubber
Surround
6.5” Talc Filled Polypropylene Cone w/Butyl
Rubber Surround
6.5” Dual Voice Coil, Talc Filled Polypropylene Cone w/
Butyl Rubber Surround
TWEETER
Pivoting 5/8” (16mm) Polycarbonate Ferrofluid
Cooled Dome
5/8” (16mm) Polycarbonate Ferrofluid Cooled
Dome
Dual 3/4” (19mm) Silk Ferrofluid Cooled Dome
FREQ RESP
50Hz - 19.5kHz
55Hz-19.5kHz
55Hz - 19.5kHz
IMPEDANCE
8 Ohms. Fixed Crossovers
8 Ohms. Fixed Crossovers
8 Ohms. Fixed Crossovers
POWER
5 - 60 Watts
5-55 Watts
5 - 55 Watts
SPL
88.5 db 1W/1m
88 db 1W/1m
88 db 1W/1m
DIAMETER x DEPTH
10 11/16” (272mm) x 3 3/8” (85.7mm)
8 15/16” (227mm) x 2 13/16” (72mm)
8 15/16” (227mm) x 2 7/8” (75mm)
RETROFIT CUTOUT
DIAMETER
9 7/16” (240mm)
7 3/4” (197mm)
7 3/4” (197mm)
BRACKET
NC8CB
NC6CECB
NC6CB
29
PRO
Series
SPA525FR
30
Pro Series
Whether you need speakers for a resort in Las Vegas, boardroom in New
York or a yoga studio in Northern California our Pro Series speaker lineup
provides a best in class solution. These dynamic sounding speakers will
deliver improved low frequency response, higher highs and great mid range
in all applications. Our Pro Series speakers will enhance any project.
CECS80-70V
SPA525FR
CECS80-70V
CECS65-70V
5.25” low profile, UL listed,
in-ceiling, full range loudspeaker,
w/ fastloc™ grille w/back can
8” 2-way, in-ceiling,
coaxial, infinite baffle
loudspeaker w/back can
6.5” 2-way, in-ceiling,
coaxial, infinite baffle
loudspeaker w/back can
DRIVER
5.25” Paper Cone, Cloth Surround
8” Talc Filled Polypropylene Cone w/Butyl Rubber Surround
6.5” Talc Filled Polypropylene Cone w/Butyl Rubber Surround
TWEETER
NA
Pivoting 5/8” (16mm) Polycarbonate Ferrofluid Cooled Dome
Pivoting 5/8” (16mm) Polycarbonate Ferrofluid Cooled Dome
FREQ RESP
75Hz-18kHz
50Hz-19.5kHz
55Hz - 19.5kHz
IMPEDANCE
8 ohms
8 ohms. Fixed Crossovers
8 ohms. Fixed Crossovers
POWER
16 Watts Continuous & 32 Watts Program
5-85 Watts @ 8Ω
30-15-7.5 Watts @ 70Volts
5-55 Watts @ 8Ω
30-15-7.5 Watts @ 70Volts
SPL
83 dB 1W/1m
88.5 db 1W/1m
88 db 1W/1m
DIAMETER X DEPTH
9 3/4“ (248mm) x 4” (102mm)
10 11/16” (273mm) x 7 1/2” (190.5mm)
8 15/16”(227mm) x 7 1/2” (190.5mm)
RETROFIT CUTOUT DIAMETER
8 15/16” (227mm)
9 7/16” (240mm)
7 7/8” (200mm)
BRACKET
NA
NC8CB
NC6CECB
SUB801-70V
OC8B-70V
OC65B-70V
8” 8 ohm/70Volt, indoor/outdoor
in-ceiling subwoofer w/back can
8” 2-way indoor/outdoor,
full range loudspeaker
6.5” 2-way indoor/outdoor,
full range loudspeaker
DRIVER
8” Injection Molded Carbon Fiber w/Butyl Rubber Surround
8” Mica Filled Polypropylene Cone w/Butyl Rubber Surround
6.5” Mica Filled Polypropylene Cone w/Butyl Rubber Surround
TWEETER
NA
1” (25mm) Titanium Ferrofluid Cooled Dome
1” (25mm) Titanium Ferrofluid Cooled Dome
FREQ RESP
35Hz-300kHz
42Hz - 20kHz
47Hz - 20kHz
IMPEDANCE
8 ohms. Fixed Crossovers
8 ohms. Fixed Crossovers
8 ohms. Fixed Crossovers
POWER
5-150 Watts @ 8Ω
60-30-15 Watts @ 70Volts
5-150 Watts @ 8Ω
60-30-15 Watts @ 70Volts
5-125 Watts @ 8Ω
30-15 -7.5 Watts @ 70Volts
SPL
90db 1W/1m
90 db 1W/1m
90 db 1W/1m
DIAMETER X DEPTH
10 11/16” (273mm) x 7 1/2” (190.5mm)
16 1/2”(419mm) x 11”(279.4mm) x 10”(254mm)
12 1/8” (308mm) x 8 1/2” (216mm) x 8 1/8” (206mm)
RETROFIT CUTOUT DIAMETER
9 7/16” (240 mm)
NA
NA
31
SUBWOOFER
Series
Subwoofer
The FL Series is a complete line of powered, front firing,
floor-standing subwoofers with both line level and speaker
level inputs. The slotted port helps the sub reproduce tight,
crisp bass, which is ideal for both movies and music.
WSSUB6x2FL
The WS Series in wall subwoofer with it’s FastLocTM grille is
a perfect solution for those applications where a cabinet
sub just won’t work. It is paired with a 300 watt remote
amplifier.
32
FLSUB-10
*Pictured without cloth grille.
FLSUB-10
FLSUB-8
10” floor subwoofer
*Pictured without grille.
Includes cloth grille.
8” floor subwoofer
*Pictured without grille.
Includes cloth grille.
DRIVER
10” Mica Treated Paper Pulp Cone w/ Butyl Rubber Surround
Front Firing Active 8” w/ Down Firing 8” Passive Radiator
POWER HANDLING
175 Watts
250 Watts
SPL
112 db 1W/1m @ 30Hz
NA
FREQ RESPONSE
25Hz-250Hz
25-200Hz
IMPEDANCE
8 ohms. Variable Crossover 40-150Hz
NA
INPUTS
RCA (LFE) and High Level Speaker Inputs with High Pass Output @75Hz to Satellite Speakers
RCA
OUTPUTS
High Pass Filtered Line Level and Speaker Level
NA
ADJUSTMENTS
Level, Crossover and Phase
Level, Crossover and Phase
LENGTH x WIDTH x DEPTH
17 1/4” (437mm) x 13 2/8” (328mm) x 19” (483mm)
WEIGHT
44 lbs
WSSUB6x2FL
AMPSUB300
6.5” in-wall subwoofer
Iin-wall subwoofer amplifier
DRIVER
Dual 6.5” Woofers with Mica Filled, Carbon Reinforced Paper Cone w/ Butyl Rubber Surround
POWER HANDLING
300 watts RMS @ 8 ohms
POWER HANDLING
300 Watts
VOLTAGE
5V - 20V
IMPEDANCE
8 Ohms.
CROSSOVER
18 - 180Hz
SPL
91dB
EQ MODES
Music (flat), Movie (+8dB @ 40Hz)
FREQ RESPONSE
30 – 250Hz
BOUNDARY EQ
On (flat), Off (+3dB)
PRODUCT Dimension
15 3/4” (401mm) x 8 15/16” (227mm) x 3 7/8” (98.6mm)
PRODUCT Dimension
15 3/4” (401mm) x 8 15/16” (227mm) x 3 7/8” (98.6mm)
RETROFIT CUTOUT
14 1/5”(360.7mm) x 7 3/5”(193mm)
33
OUTDOOR
Series
Outdoor Speakers
This dual-purpose loudspeaker series is the perfect choice for main listening
or sound reinforcement applications, with a ported bass reflex that supplies
serious sound. Graphite mica filled polypropylene woofer cones and butyl
rubber surround are impervious to the weather and insects, and perforated
powder-coated aluminum alloy grilles are corrosion-resistant and rustproof.
OR6G
OC65W
34
OC65B
Outdoor simulated rock speakers are ‘heard but not seen’ in outdoor landscapes,
resembling real rock right down to the grille. The single stereo, standalone speaker
is built with dual voice coils and tweeters to deliver both left and right sound in
one package — providing high fidelity sound required in outdoor environments.
Encased in a totally weatherized material and offered in two colors, they can
withstand sun, rain, heat, cold, fog and coastal dew, even deterring theft via a
threaded insert for an eyebolt for added security.
OR6S
OC8B
can be used as standalone subwoofer
OC65B
OC65W
8” 2-way indoor/outdoor,
full range loudspeaker
6.5” 2-way indoor/outdoor,
full range loudspeaker
6.5” 2-way indoor/outdoor,
full range loudspeaker
DRIVER
8” Mica Filled Polypropylene Cone w/Butyl Rubber Surround
6.5” Mica Filled Polypropylene Cone w/Butyl Rubber Surround
6.5” Mica Filled Polypropylene Cone w/Butyl Rubber Surround
TWEETER
1” (25mm) Titanium Ferrofluid Cooled Dome
1” (25mm) Titanium Ferrofluid Cooled Dome
1” (25mm) Titanium Ferrofluid Cooled Dome
FREQ RESP
42Hz - 20kHz
47Hz - 20kHz
47Hz - 20kHz
IMPEDANCE
8 Ohms. Fixed Crossover
8 Ohms. Fixed Crossover
8 Ohms. Fixed Crossover
POWER
5 - 150 Watts
5 - 125 Watts
5 - 125 Watts
SPL
90 db 1W/1m
90 db 1W/1m
90 db 1W/1m
HEIGHT x WIDTH x DEPTH
16 1/2”(419mm) X 11”(279.4mm) X 10”(254mm)
12 1/8” (308mm) x 8 1/2” (216mm) x 8 1/8” (206mm)
12 1/8” (308mm) x 8 1/2” (216mm) x 8 1/8” (206mm)
OC525B
OC525W
OR6G
OR6S
5.25” 2-way indoor/outdoor,
full range loudspeaker
5.25” 2-way indoor/outdoor,
full range loudspeaker
6.5” 2-way, outdoor rock speaker,
dual input stereo. Can be used as a single
stand alone or separates for true stereo
6.5” 2-way, outdoor rock speaker,
dual input stereo. Can be used as a single
stand alone or separates for true stereo
DRIVER
5.25” Mica Filled Polypropylene Cone w/Butyl Rubber
Surround
5.25” Mica Filled Polypropylene Cone w/Butyl
Rubber Surround
6.5” Mica Filled Polypropylene Cone w/Dual Voice Coil
and Butyl Rubber Surround
6.5” Mica Filled Polypropylene Cone w/Dual Voice Coil
and Butyl Rubber Surround
TWEETER
1” (25mm) Titanium Ferrofluid Cooled Dome
1” (25mm) Titanium Ferrofluid Cooled Dome
Dual 3/4” (19mm) Titanium Dome Tweeters
Dual 3/4” (19mm) Titanium Dome Tweeters
FREQ RESP
52Hz - 20kHz
52Hz - 20kHz
47Hz - 20kHz
47Hz - 20kHz
IMPEDANCE
8 Ohms. Fixed Crossovers
8 Ohms. Fixed Crossovers
8 Ohms. Fixed Crossover
8 Ohms. Fixed Crossover
POWER
5 - 100 Watts
5 - 100 Watts
5 - 125 Watts
5 - 125 Watts
SPL
89 db 1W/1m
89 db 1W/1m
88.5 db 1W/1m
88.5 db 1W/1m
HEIGHT x WIDTH x DEPTH
9 7/8” (251mm) x 6 3/4” (171mm) x 6 1/4” (159mm)
9 7/8” (251mm) x 6 3/4” (171mm) x 6 1/4” (159mm)
12” (304m) x 14” (356mm) x 11” (279mm)
12” (304m) x 14” (356mm) x 11” (279mm)
35
ACCESSORIES
New Construction Brackets
NC6CB
NC8CB
NC8FITCBi
NC6WB
NC8WB
NC6LCRWBi
NC6CECB
In-Line Surge Suppression
Pre-wire prior to drywall,
new construction speaker
mounting brackets
SPEAKER CROSSREFERENCE
ILS-120
CS650, CS651, CS654,
CS654FL CS651FL, CS650FL,
CS654DBFL, CS650DBFL,
CS650DTFL, FIT654, FIT652,
FIT651, FIT650, FIT654FL,
FIT652FL, FIT651FL, FIT650FL,
CECS65DT
CS804FL, CS802FL, CS801FL,
CS800DTFL, CS804, CS802,
CS801, CECS80
FIT804FL, FIT802FL,
FIT801FL, FIT800FL
WS651FL, WS650FL, WS651,
WS650
WS804FL, WS801FL, WS804,
WS801
SPEAKER CROSSREFERENCE
36
CS650, CS651, CS654, CS650FL,
CS651FL, CS654FL, CECS65,
CECS65DT, CS650DTFL,
CS650DBFL, CS654DBFL, FIT654,
FIT652, FIT651, FIT650,FIT654FL,
FIT652FL, FIT651FL, FIT650FL
CECS65
CS Back Cans
Tile Bridge Brackets
TB6
WSLCR654FL,
WSLCR650FL
TB8
CS804FL, CS802FL, CS801FL,
CS800DTFL, CS804, CS802,
CS801, CECS80
TBFIT8
FIT804FL, FIT802FL, FIT801FL,
FIT800FL
LINE VOLTAGE
120 VAC,50/60Hz
MAX LOAD CAPACITY
10 amps
PROTECTION MODE
3-way line to ground, line to neutral, neutral to ground
POWER Dissipation
1575 joules
PEAK IMPULSE CURRENT
60,000 amps
UL RATING
UL 1449 Revision 3
TOTAL LENGTH
76.98” (6.5 feet)
CS65BC
acoustical rear enclosure, ready to attach, comes complete with gold constant
tension binding posts, wiring and dacron damping material
DIAMETER x DEPTH
8 1/10” (205mm) x 5 4/9” (138mm)
SPEAKER CROSSREFERENCE
CS650, CS650FL, CS651FL, CS654FL, CS650DTFL, CS650DBFL, CS654DBFL
CS80BC
ILS-PAC Power Adapter Cord
The Current Audio ILS-PAC is a special power adapter cord for the
ILS-120 Surge Protector. The purpose of the ILS-PAC is to allow
the ILS-120 Surge Protector to be used on slim line TVs and other
female 3-prong plugs that do not have a removable power cord.
You can also use it to take advantage of the unused IEC outlets
on the back of some PCs to power printers, monitors and other
120VAC devices.
*Fits speakers produced from November 2011 and later.
acoustical rear enclosure, ready to attach, comes complete with gold constant
tension binding posts, wiring and dacron damping material
DIAMETER x DEPTH
9 3/5” (244mm) x 7 1/10” (180mm)
SPEAKER CROSSREFERENCE
CS801, CS804FL, CS802FL, CS801FL, CS800DTFL
*Fits speakers produced from November 2011 and later.
37
Speaker Insulation
Wire Whisker Plate
ZLoc Volume Control
WWP
ZL45R
The Current Audio WWP universal Wire Whisker Pass Through Plate allows
installers to offer a clean on wall wire management device. There is no need to
stock multiple plates and connectors for various wire feeds. The WWP does it all!
You have a choice of brush color - white or black. The WWP may be double or
triple ganged for larger wire feeds. Avalable in Black or White.
High quality stereo autoformer, multiple speaker
impedance matching, 12 step rotary knob, make before
break switching volume control
SpeKap
- Breathable membrane insulation and debris speaker cap
PLATE STYLE
Decora
CONTROL SWITCH SILENT STEP
12-step rotary knob
FREQUENCY RESPONSE
20Hz-20kHz
POWER HANDLING
45 watt RMS
PAIRS OF SPEAKERS BY JUMPER POSITION
1-2-4-8
DEPTH BEHIND PLATE X HEIGHT
OF CIRCUIT BOARD
2.688” (6.8cm) X 2.87” (7.3cm)
- Keeps insulation, debris, and rodent dropping out of the speaker.
- Fits most 5” to 8” in-ceiling and in-wall speakers
Volume Control Faceplates
Included Per Pack:
5x - Trim Plate
5x - Decora Inserts
5x - Knobs
10x- Screws
COLOR
VCDII
Ivory
VCDIA
Almond
VCDIB
Black
TAPS
38
Transformer
Speaker Selector
R70VT
4PS
Multi-tap 70V to 8 ohm Transformer,
70 volt line common, mounts directly
onto WS, CS, CSFL, CE Series speakers
Four Pair Manual Stereo
Speaker Selector
70 Volt to 8 ohm, Color Coded Wattage Wire Taps
30 Watt, 16 Watt, 8 Watt, 4 Watt
POWER
40 Watts RMS @ 8 ohms
MAX WIRE GAUGE
#14
LENGTH x WIDTH x DEPTH (WEIGHT)
2“ (50mm) x 8 5/8“ (216mm) x 4 2/5“ (112mm) 1.8 lbs.
39
40
1890 Cordell Court, Suite 105, El Cajon, CA 92020 • Sales 866-927-7181
©2013 Current Audio LLC, All product specifications are subject to change without notice.
www.currentaudio.com
Rev. PGv6_2013_0913
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
