SGA7489Z
SGA7489ZDC
to 3000MHz
Silicon Germanium HBT Cascadable Gain
Block
DC to 3000MHz SILICON GERMANIUM HBT
CASCADABLE GAIN BLOCK
Package: SOT-89
Product Description
Features
The SGA7489Z is a high performance SiGe HBT MMIC Amplifier. A Darlington configuration featuring one-micron emitters provides high FT and
excellent thermal performance. The heterojunction increases breakdown
voltage and minimizes leakage current between junctions. Cancellation of
emitter junction non-linearities results in higher suppression of intermodulation products. Only two DC-blocking capacitors, a bias resistor, and an
optional RF choke are required for operation.

Optimum Technology
Matching® Applied
VD=5.0V, ID=115mA (Typ), TLEAD=+25C
30
InGaP HBT
25
Gain
SiGe BiCMOS
20

Gain (dB)
Si BiCMOS
SiGe HBT
GaAs pHEMT
15
Si BJT
-5

-15
Output
Return Loss
10
Si CMOS

-10
Input Return
Loss
-20
5
-25
GaN HEMT

0
Return Loss & Isolation (dB)
GaAs MESFET

Applications
Gain, Return Loss, and Isolation vs. Frequency
GaAs HBT

DC to 3000MHz Operation
Very High IF Output IP3:
39dBm at 100MHz
High Output IP3: +35.5dBm
typ. at 850MHz
Low Noise Figure: 3.3dB typ.
at 1950MHz



Oscillator Amplifiers
PA for Low/Medium Power
Applications
IF/RF Buffer Amplifier
Drivers for CATV Amplifiers
LO Driver Amplifier
Isolation
0
InP HBT
0
500
1000
1500
2000
2500
-30
3000
Frequency (MHz)
RF MEMS
LDMOS
Parameter
Small Signal Gain
Min.
20.0
17.0
Output Power at 1dB Compression
18.5
Output Third Intercept Point
31.0
Bandwidth Determined by Return
Loss
Input Return Loss
Output Return Loss
Noise Figure
10.3
9.0
Specification
Typ.
21.5
18.5
22.4
20.0
39.0
35.5
33.0
36.0*
3000
15.0
11.0
3.3
Max.
23.0
20.0
4.3
Unit
dB
dB
dBm
dBm
dBm
dBm
dBm
dBm
MHz
dB
dB
dB
Condition
850MHz
1950MHz
850MHz
1950MHz
100MHz
850MHz
1950MHz
1950MHz, Using 2GHz App. Ckt.
>9dB
1950MHz
1950MHz
1950MHz, ZS =50Ω
Reverse Isolation
23.0
dB
1950MHz
Device Operating Voltage
4.7
5.0
5.3
V
Device Operating Current
103
115
127
mA
Thermal Resistance
82
°C/W
(Junction - Lead)
Test Conditions: VS =8V, ID =115mA Typ., OIP3 Tone Spacing=1MHz, POUT per tone=0dBm, RBIAS =26Ω, TL =25°C, ZS =ZL =50Ω
RF MICRO DEVICES®, RFMD®, Optimum Technology Matching®, Enabling Wireless Connectivity™, PowerStar®, POLARIS™ TOTAL RADIO™ and UltimateBlue™ are trademarks of RFMD, LLC. BLUETOOTH is a trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed for use by RFMD. All other trade names, trademarks and registered trademarks are the property of their respective owners. ©2006, RF Micro Devices, Inc.
DS100915
7628 Thorndike Road, Greensboro, NC 27409-9421 · For sales or technical
or
.
support, contact RFMD at
1 of 6
SGA7489Z
Absolute Maximum Ratings
Parameter
Rating
Unit
Max Device Current (ID)
170
mA
Max Device Voltage (VD)
7
V
Max RF Input Power, ZL =50Ω
+16
dBm
Max RF Input Power, Load
VSWR=10:1*
+2
dBm
Max Junction Temp (TJ)
+150
°C
-40 to +85
°C
Max Storage Temp
+150
°C
Moisture Sensitivity Level
MSL 2
Operating Temp Range (TL)
ESD sensitive device.
Exceeding any one or a combination of the Absolute Maximum Rating conditions may
cause permanent damage to the device. Extended application of Absolute Maximum
Rating conditions to the device may reduce device reliability. Specified typical performance or functional operation of the device under Absolute Maximum Rating conditions is not implied.
RoHS status based on EUDirective2002/95/EC (at time of this document revision).
The information in this publication is believed to be accurate and reliable. However, no
responsibility is assumed by RF Micro Devices, Inc. ("RFMD") for its use, nor for any
infringement of patents, or other rights of third parties, resulting from its use. No
license is granted by implication or otherwise under any patent or patent rights of
RFMD. RFMD reserves the right to change component circuitry, recommended application circuitry and specifications at any time without prior notice.
*Note: Take into account out of band load VSWR presented by devices such as SAW
filters to determine maximum RF input power. Reflected harmonic levels in saturation are significant.
Operation of this device beyond any one of these limits may cause permanent damage. For reliable continuous operation, the device voltage and current must not
exceed the maximum operating values specified in the table on page one.
Bias Conditions should also satisfy the following expression:
IDVD <(TJ -TL)/RTH, j-l
Typical Performance at Key Operating Frequencies
Parameter
Unit
100
MHz
500
MHz
850
MHz
1950
MHz
Small Signal Gain
dB
23.0
22.5
21.5
18.5
Output Third Order Intercept Point
dBm
39.0
36.5
35.5
33.0*
Output Power at 1dB Compression
dBm
22.8
22.6
22.4
20.0
Input Return Loss
dB
13.5
14.5
15.5
15.0
Output Return Loss
dB
19.5
17.0
14.5
11.0
Reverse Isolation
dB
26.0
25.5
25.0
23.0
Noise figure
dB
2.7
2.7
2.8
3.3
Test Conditions: VS =8V, ID=115mA Typ., OIP3 Tone Spacing=1MHz, POUT per tone=0dBm, Bias Resistance=26Ω, TL =25°C, ZS =ZL =50Ω
*Note: An OIP3 of +36dBm at 1950MHz is achieved using the tuned circuit
OIP3 vs. Frequency over Temperature
38.0
24.0
36.0
22.0
P1dB (dBm)
OIP3 (dBm)
VD=5.0V, ID=115 mA (Typ.) at TLEAD=+25°C
26.0
34.0
32.0
TLEAD
28.0
26.0
17.0
32.2
19.0
13.5
10.5
22.0
P1dB vs. Frequency over Temperature
VD=5.0V, ID=115 mA (Typ.) at TLEAD=+25°C
40.0
30.0
2400
MHz
20.0
18.0
16.0
-40C
+25C
+85C
+25C Tuned Circuit
-40C
TLEAD
14.0
+25C
+85C
12.0
0
500
1000
1500
2000
2500
0
500
1000
Frequency (MHz)
1500
2000
2500
Frequency (MHz)
Noise Figure vs. Frequency over Temperature
VD=5.0V, ID=115 mA (Typ.) at TLEAD=+25°C
5.0
4.5
NF (dB)
4.0
3.5
3.0
2.5
2.0
TLEAD
1.5
-40C
+25C
+85C
1.0
0
500
1000
1500
2000
Frequency (MHz)
2 of 6
7628 Thorndike Road, Greensboro, NC 27409-9421 · For sales or technical
support, contact RFMD at
or
.
DS100915
SGA7489Z
Typical RF Performance Over Temperature
(Bias: VS= 8.0 V, Bias Resistance=26 Ohms, ID= 115 mA )
|S | vs. Frequency
|S | vs. Frequency
11
21
30
0
-5
24
|S11| (dB)
|S21| (dB)
-10
18
-15
-20
12
TL
+25°C
-40°C
+85°C
-25
6
TL
+25°C
-40°C
+85°C
-30
0
500
1000
1500
2000
Frequency (MHz)
2500
3000
0
500
|S | vs. Frequency
1000
1500
2000
Frequency (MHz)
2500
3000
|S | vs. Frequency
12
22
0
-10
-5
-15
|S22| (dB)
|S12| (dB)
-10
-20
-15
-20
-25
TL
+25°C
-40°C
+85°C
-25
500
1000
1500
2000
Frequency (MHz)
2500
0
3000
500
ID vs. VD Variation over Temperature
1000
1500
2000
Frequency (MHz)
2500
3000
Plot of VD vs. Temp. @ ID=115 mA
VSUPPLY = 8 V, Bias Resistance = 26 Ohms
150
5.3
140
5.2
130
120
+25°C
110
-40°C
VD (Volts)
5.1
+85°C
ID (mA)
+25°C
-40°C
+85°C
-30
-30
0
TL
5.0
4.9
100
4.8
90
80
4.70
4.80
4.90
5.00
VD (Volts)
DS100915
5.10
5.20
5.30
4.7
-40
-15
10
35
60
85
Temperature (°C)
7628 Thorndike Road, Greensboro, NC 27409-9421 · For sales or technical
support, contact RFMD at
or
.
3 of 6
SGA7489Z
Pin
1
2, 4
Function
RF IN
GND
Description
3
RF OUT/BIAS
RF input pin. This pin requires the use of an external DC blocking capacitor chosen for the frequency of operation.
Connection to ground. Use via holes for best performance to reduce lead inductance as close to ground leads as possible.
RF output and bias pin. DC voltage is present on this pin, therefore a DC blocking capacitor is necessary for proper operation.
Application Schematic
Frequency (Mhz)
ID
R BIAS
VS
1 uF
1000
pF
CD
R LDC
Bias
Inductor
Reference
Designator
100
500
850
1950
2400
CB
1000 pF
220 pF
100 pF
68 pF
56 pF
CD
100 pF
100 pF
68 pF
22 pF
22 pF
LC
470 nH
68 nH
33 nH
22 nH
18 nH
LC
Required Bias Resistance for ID=115mA
Bias Resistance = RBIAS+ RLDC = ( VS-VD ) / ID
4
1 SGA7489Z 3
RF in
CB
2
VD
RF out
CB
Supply Voltage(VS)
Bias Resistance
7V
17
8V
26
9V
12 V
35
61
Bias resistor improves current stability over temperature.
Evaluation Board Layout
Mounting Instructions:
1. Solder the copper pad on the backside of the device package to the ground plane.
2. Use a large ground pad area with many plated through-holes as shown.
3. We recommend 1 or 2 ounce copper. Measurements for this data sheet were made on a 31mil thick FR-4 board with 1
ounce copper on both sides.
4 of 6
7628 Thorndike Road, Greensboro, NC 27409-9421 · For sales or technical
support, contact RFMD at
or
.
DS100915
SGA7489Z
Suggested Pad Layout
Preliminary
Package Drawing
Dimensions in inches (millimeters)
Refer to drawing posted at www.rfmd.com for tolerances.
DS100915
7628 Thorndike Road, Greensboro, NC 27409-9421 · For sales or technical
support, contact RFMD at
or
.
5 of 6
SGA7489Z
Part Identification
Alternate marking is SGA7489Z on line 1 with Trace Code on line 2.
Ordering Information
6 of 6
Ordering Code
Description
SGA7489Z
13” Reel with 3000 pieces
SGA7489ZSQ
Sample bag with 25 pieces
SGA7489ZSR
7” Reel with 100 pieces
SGA7489ZPCK1
850MHz, 8V Operation PCBA with 5-piece sample bag
7628 Thorndike Road, Greensboro, NC 27409-9421 · For sales or technical
support, contact RFMD at
or
.
DS100915
