PRODUCT CATALOG
R&D SERVICE. OEM WELCOME.
ELDES specializes in designing and manufacturing GSM Machine to Machine
(M2M) equipment. If you need a specific project or product that works over
GSM network do not hesitate to contact us.
We are here to meet your needs.
GSM CONTROL SYSTEMS
CUSTOMIZED BY YOU
CONTENT
GSM DIALERS-PAGERS AND GATE OPENERS
GSM GATE CONTROLLER ESIM010..................................................................................4
GSM AUTO DIALLER AND REMOTE RELAY ESIM151........................................................4
ALARM AND CONTROL PANELS
GSM ALARM AND CONTROL PANEL ESIM264 . ...............................................................5
GSM ALARM AND CONTROL PANEL ESIM262 . ...............................................................6
GSM ALARM SYSTEM EPIR ..............................................................................................7
GSM PAGER FOR CARS ZEUS...........................................................................................7
GSM GATEWAY ET07.........................................................................................................8
GSM GATEWAY ET07P.......................................................................................................8
KEYPAD EKB1 ...................................................................................................................9
KEYPAD EKB2 ...................................................................................................................9
PLASTIC ENCLOSURE ED1 FOR IBUTTON READER.........................................................9
AUDIO OUTPUT MODULE EA1.........................................................................................10
AUDIO AMPLIFIER MODULE EA2.....................................................................................10
HARDWIRED ZONE EXPANSION EPGM1.........................................................................10
HARDWIRED PROGRAMMABLE OUTPUT EXPANSION EPGM8 .....................................10
WIRELESS TRANSMITTER EWT1.....................................................................................11
WIRELESS EXPANSION MODULE EW1............................................................................11
WIRELESS EXPANSION MODULE EW2 ...........................................................................11
WIRELESS PIR SENSOR EWP1 ......................................................................................11
WIRELESS MAGNETIC DOOR/WINDOW SENSOR EWD1................................................11
MONITORING STATION SOFTWARE
IP RECEIVER SOFTWARE EGR100...................................................................................12
CENTRAL MONITORING STATION SOFTWARE E-GUARD...............................................12
ETHERNET SNMP CONTROLLERS
I/O ETHERNET CONTROLLER ELAN1..............................................................................13
GSM/GPS TRACKING BUSINESS
GSM TRACKER TOBECITY...............................................................................................14
GPS TRACKER TOBE.......................................................................................................14
PRODUCT CATALOG
3
GSM GATE
CONTROLLER ESIM010
(REMOTE RELAY)
ESIM010 automatic gate controller (remote relay over GSM) is used to
open gates, lifts road barriers or turn on electronic devices remotely
over GSM network. Calling on the number of the SIM card inserted in
ESIM010 the system checks if the number of the caller is recorded in the
memory. If the number exists in the database the system rejects the call
and turns on the relay for the pre-set period.
APPLICATIONS
• Barrier control
• Gate control
FEATURES
• Built-in GSM/GPRS communicator
• The system can be controlled by up to 500 users
and 5 administrators
• Notification SMS about a
fault in gate or other automatics device over GSM
• Computer system restart
TECHNICAL SPECIFICATIONS
Inputs
3
• Optional IP65 enclosure
Relay output
1 (1 A)
• 3 ways of configuration:
SMS, USB or Internet
Event Buffer
1000
Built in GSM/GPRS module
900/1800/1900 MHz; 850 MHz
optional
Administrators
5
Authorized users
500 (up to 2000 optional)
• Din-Rail plastic enclosure
• Event Log access by
Internet
GSM AUTO DIALLER AND
REMOTE RELAY ESIM151
The main function of the ESIM151 is to operate as a
supplement for any of the control panels. If PGM or Bell are
activated, a warning call is dialled and SMS message is sent
to the pre-set phone numbers. It can remotely control any
electric equipment switching by a free of charge short call.
APPLICATIONS
• Any electronic device failure or
restore informing via SMS/CALL
• Heating system switching
• Lighting switching
FEATURES
TECHNICAL SPECIFICATIONS
• Built-in GSM/GPRS communicator
Inputs
5
Relay output
1 (1 A)
Event Buffer
1000
Built in GSM/GPRS module
900/1800/1900 MHz; 850 MHz optional
Authorized users
5
Microphone connector
yes
• Each input could be assigned to a separate user
• SMS and/or CALLS to 5 authorized users
• Optional Din-Rail plastic enclosure
• 3 ways of configuration: SMS, USB or Internet
• Event Log access by Internet
4
• Informing about a triggered
alarm system to a mobile phone
GSM DIALERS-PAGERS AND GATE OPENERS
GSM ALARM AND
CONTROL PANEL ESIM264
ESIM264 is an Alarm and Control Panel for securing
premises and controlling electronic devices or managing
buildings/automatics through GSM network. The panel can
work as a personal alarm system just informing authorized
users via SMS/CALL or can communicate with the
monitoring station.
APPLICATIONS
FEATURES
• Security of premises
• Arm/disarm by free of charge call,
keypad or iButton
wireless alarm panel
• Temperature measurement and
control
• SMS and/or CALLS to 5 authorized users
• Temperature measurement and
alarming in case of controlled
temperature deviating from the
allowable limits
• Electric power network failure control
• Each zone can be assigned to a
separate user
• STAY feature
• Intercom extension module
• CONTACT ID for monitoring station through GSM voice or GPRS
• 4 ways of configuration: SMS,
keypad, USB or Internet
• Easily transformable to 868MHz
• Event Log access by Internet
• Control of electrical devices
by SMS
• Wireless intercom
• Built-in GSM/GPRS communicator
TECHNICAL SPECIFICATIONS
On-board zones
6 (12 ATZ mode)
Expandable hardwired zones
16
Wireless
Optional
Expandable wireless devices: (zones, PGM, key fobs, etc.)
16
Keypads
4
Keypad zone support
yes
Partitions
2
User codes
50
Dallas key iButton reader
yes
On-board programmable outputs
4x500mA
Expandable programmable outputs
8x500mA
Event Buffer
500
Built in GSM/GPRS module
900/850/1800/1900 MHz
Ways of event communication
Ademco Contact ID, SMS, Voice Calls
Authorized users
5
Digital temperature sensor
DS18S20, DS18B20
Microphone
yes
Audio OUT
yes
ALARM AND CONTROL PANELS
5
GSM ALARM AND
CONTROL PANEL ESIM262
ESIM262 is an Alarm and Control Panel for securing
premises and controlling electronic devices or
managing buildings/automatics through GSM network.
The panel informs authorized users via SMS/CALL
about triggered zones.
APPLICATIONS
FEATURES
• Security of premises
• Arm/disarm by free of charge call, keypad or iButton
• Electrical devices control by SMS
• Built-in GSM communicator
• Temperature measurement
and control
• SMS and/or CALLS to 5 authorized users
• Electric power network failure control
• Temperature measurement and alarming in case of controlled temperature
deviating from the allowable limits
• Wireless intercom
• STAY feature
• Intercom extension module
• 3 ways of configuration: SMS, keypad, USB.
TECHNICAL SPECIFICATIONS
6
On-board zones
6 (12 ATZ mode)
Keypads
1
Partitions
1
User codes
1
Dallas key iButton reader
yes
On-board programmable outputs
2x150mA
Expandable programmable outputs
8x500mA
Event Buffer
128
Built in GSM/GPRS module
900/1800/1900 MHz; 850MHz optional
Ways of event communication
SMS, Voice Calls
Authorized users
5
Digital temperature sensor
DS18S20, DS18B20
Microphone
yes
Audio OUT
yes
ALARM AND CONTROL PANELS
GSM ALARM SYSTEM EPIR
Home alarm EPIR is a self-install system for end users. The whole
system looks like a simple PIR. All you need to do is to simply insert
SIM card and enter phone numbers of authorized users. In case
of trespass EPIR sends SMS to authorized numbers and calls. It
possesses an implemented Contact ID for monitoring stations.
APPLICATIONS
• Security
of premises
• Electric power network
failure control
• Spy
listening
TECHNICAL SPECIFICATIONS
FEATURES
On-board zones
1
Wireless
Optional
• Built-in GSM/GPRS communicator
Expandable wireless devices:
(zones, PGM, key fobs, etc.)
16
• SMS and/or CALLS to 5 authorized users
Event Buffer
500
• CONTACT ID for monitoring station through
GSM voice or GPRS
Built in GSM/GPRS module
900/1800/1900 MHz; 850 MHz optional
Ways of event communication
Ademco Contact ID, SMS, Voice Calls
• Optional 868 MHz ELDES WIRELESS version
Authorized users
5
• Built in microphone and backup battery
Microphone
yes
• 3 ways of configuration: SMS, USB or Internet
Backup battery
Yes, built-in
• Event Log access by Internet
Detection angle and range
90° up to 10 m
• Self-install system
• Arm/disarm by free of charge call
GSM PAGER FOR CARS ZEUS
The system ZEUS is a device used to remotely observe and
control cars, motorbikes and other vehicles over GSM network.
APPLICATIONS
• Informing the user by an SMS
message or phone call about
the triggered security system of
the vehicle.
microphone
• A possibility to check over the
mobile phone if you have not
forgotten turning on the security
system.
• Informing the user about low
battery
• CELL ID vehicle tracking
• Listening to what is happening
inside the car through a remote
• Emergency Button connection
FEATURES
TECHNICAL SPECIFICATIONS
• Built-in GSM
communicator
Number of “high” level (positive) inputs
1
Number of “low” level (negative) inputs
2
• SMS and/or CALLS to
2 authorized users
Security mode activation at “low” level (with a negative)
1 input
• Back-up battery
included
Security mode activation at “high” level (with a positive)
1 input
Built in GSM/GPRS module
900/1800/1900 MHz; 850 MHz optional
Authorized users
2
Built in microphone
yes
ALARM AND CONTROL PANELS
7
GSM GATEWAY ET07
ET07 is used for transferring information from the Alarm
Control Panel to the monitoring station via GSM voice
connection channel where no land line is available.
APPLICATIONS
• Alarm communication
• Making and receiving normal telephone handset calls via GSM voice connection channel
• Lift intercoms
• Replacing PSTN line to GSM network
FEATURES
TECHNICAL SPECIFICATIONS
• Transmits information from the Alarm Control
Panel to the monitoring station via GSM voice
connection signal
Built in GSM module
900/1800/1900 MHz; 850 MHz optional
Authorized users
5
• Transmits information from the Alarm Control
Panel only to the registered users via SMS message
Supported protocols
Contact ID, 4+2, SIA
Inputs
3 (optional)
• Transmits information from the Alarm Control
Panel to the monitoring station via GSM voice
connection signal as well as to registered users
via SMS message.
Generated phone line voltage
48 V
Power supply voltage
11-24 V AC/DC
GSM GATEWAY ET07P
ET07P is a cost-reduced solution for enterprises when calling
from fixed line to GSM network. When connected to PBX it cuts
the costs of an enterprise for the fixed line.
APPLICATIONS
• Alarm communication
• To make and receive normal telephone handset calls via GSM voice
connection channel
• Lift intercoms
• Replacing PSTN line to GSM network
FEATURES
TECHNICAL SPECIFICATIONS
• Built-in GSM communicator
Built in GSM module
900/1800/1900 MHz; 850 MHz optional
RJ11 connector
yes
Ringing voltage of generated
phone line
± 72 V (25 Hz)
• Compatible with PBX
• Plastic enclosure
• Simply plug the telephone plug into RJ11 jack.
• No configuration needed
8
ALARM AND CONTROL PANELS
Dial tone of generated phone line 350 Hz
Generated phone line voltage
48 V
Power supply voltage
11-24 V AC/DC
USER INTERFACE
KEYPAD EKB1
• Large buttons
• ARM, STAY, BYPASS LED
• Backlit buttons
• Buttons indicate triggered zones
• Easy-to-install
• Compatible with ESIM262, ESIM264 panels
KEYPAD EKB2
• Modern design
• Touch sensitive buttons
• LCD display
• Easy-to-install
• Compatible with ESIM264 panel
PLASTIC ENCLOSURE ED1 FOR IBUTTON
READER AND TEMPERATURE SENSOR
• Enclosure for easy installation of iButton reader
• Built-in buzzer
• Temperature Sensor DS18S20 (-55°C to +125°C)
ALARM AND CONTROL PANELS
9
AUDIO MODULES
AUDIO OUTPUT MODULE EA1
• 3.5 mm headphone jack
• Possibility to connect headphones or computer speakers.
AUDIO AMPLIFIER MODULE EA2
• 1 W 8 Om
• For Intercoms, Lifts
ZONE AND PGM
EXPANSION MODULES
HARDWIRED ZONE EXPANSION EPGM1
• 16 hardwired zones
• 2 programmable outputs 500 mA
• Compatible with ESIM264
HARDWIRED PROGRAMMABLE OUTPUT EXPANSION EPGM8
• 8 programmable outputs 500 mA
• 1 A
• Compatible with ESIM264, ESIM262
10
ALARM AND CONTROL PANELS
868 MHZ WIRELESS MODULES
WIRELESS TRANSMITTER EWT1
• Supports up to 16 wireless devices: PIR, Zones, PGM, Key fobs, etc.
• Compatible with ESIM264 panel
WIRELESS EXPANSION MODULE EW1
• 2 zones
• 2 programmable outputs 500 mA
• Expansion for any not wireless device such as Bell,
Motion or Smoke detector
• Compatible with ELDES WIRELESS
WIRELESS EXPANSION MODULE EW2
• 4 zones
• 6 programmable outputs 500 mA
• 1 programmable relay output 1 A
• Mates with EW1
• Recommended for Gate control or automatic devices.
• Compatible with ELDES WIRELESS
WIRELESS PIR SENSOR EWP1
• Digital motion detector
• Indoor
• Viewing angle 90° up to 10 m
• Compatible with ELDES WIRELESS
WIRELESS MAGNETIC DOOR/WINDOW SENSOR EWD1
• Monitor doors, windows
• Compatible with ELDES WIRELESS
ALARM AND CONTROL PANELS
11
IP RECEIVER SOFTWARE EGR100
EGR100 receives information from ELDES control panels via GPRS and converts it to the
popular MLR2 format used by monitoring stations. All you have to do is simply install the
program to a PC that has access to Internet. EGR100 creates a virtual COM port and
transfers all alarm data received from alarm control panels.
FEATURES
• Freeware!
• Easy upgrade of an existing telephone-line
Central Monitoring Stations to GPRS based
communication.
• Compatible with MLR2 receivers of central monitor stations.
• You will need a PC with Windows XP, VISTA
• Up to 50 000 users
• Encrypted transmission
• Configurable PING signal timeout
• Event LOG buffer
CENTRAL MONITORING
STATION SOFTWARE E-GUARD
E-Guard is powerful database software for CMS operators. It has everything that an
organisation can need, from small to large security companies. The software interprets and
records alarm data obtained from various receivers.
FEATURES
• Developed and tested by real working monitoring
station company
• Compatible with Surgard MLR2 protocol
• Simultaneously supports as many alarm receivers as you need. Up to 256 COM ports.
• You will need a PC with Windows XP, VISTA
• 100; 300; 500; 1000 and 50 000 user packages
• Program has the following functional windows:
Main, Object Card, Object Status, Problems,
Control Panel Failure, Reminder, Records, Diagnostic etc.
• Event LOG buffer
12
MONITORING STATION SOFTWARE
I/O ETHERNET
CONTROLLER ELAN1
ELAN1 allows managing the inputs and outputs of
any network device via SNMP Protocol.
APPLICATIONS
FEATURES
• Process automation control
• Super price/performance
• Building automation monitoring
• SNMP - Simple Network Management Protocol
• Lift monitoring
• 4 analogic/digital input
• Monitoring electricity power transmission systems
• 1 output
• Easy web configuration – built-in WEB server
• Aluminium enclosure
• Ethernet connection
TECHNICAL SPECIFICATIONS
10/100BaseT Ethernet port
yes
Inputs
4 (0-10 V or 4-20 mA)
Output
1 (150 mA )
Status LEDs
3
Power supply voltage
10-24 V AC/DC
Dimensions
82x55x25mm
ETHERNET SNMP CONTROLLERS
13
GSM TRACKER TOBECITY
TobeCity is a device that works with TOBE LBS software platform or
some other CELL ID search engines and defines position using Cell
Towers instead of GPS information.
TobeCity - simple way to get into mass market!
APPLICATIONS
FEATURES
• Child tracking
• Small in size – 40x40x15 mm
• Employee tracking
• Compatible with LBS*
• Pet tracking
• 5 days battery life
• Luggage tracking
GPS TRACKER TOBE
Personal GPS/GSM/GPRS tracker built to grow sense of
safety in the society.
APPLICATIONS
TECHNICAL SPECIFICATIONS
• Child safety
GPS
-161 dBm
• Elder people care
GPS ANTENNA
Internal
GSM
900/850/1800/1900 MHz
BUILT IN MICROPHONE
Yes
CONNECTION TO PC
Mini USB
CONFIGURATION
via server
BATTERY
Li-Ion (780 mAh)
• GPS module
CHARGER
Mini USB
• GSM/GPRS data communication
DIMENSIONS
69.5x50.5x21
WEIGHT
80 g
COLOUR
White
STAND BY
Up to 5 days
• Employee safety/control
• Pets safety
FEATURES
• Voice communication
• Small size
• Adopted to Tobe software server platform**
• Customization for any server available
* TOBE Location-based service (LBS) software is the most competitive on market in terms of functionality and price. We can offer competetive price.
** Software for GPS tracking business TOBE
DO NOT HESITATE – ASK FOR MORE INFORMATION NOW
If you read this at your place now and want to get more information take the following steps:
1. Go to www.tobegps.com
14
GSM/GPS TRACKING BUSINESS
2. Find contacts 3. Send us an email or make a call
YOUR IDEA
+
ELDES R&D
= SUCCESS
REPRESENTATIVE
www.eldes.lt
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
