Energy Management
The Smart Choice for Lighting Control and Energy Solutions
For most companies, the last time they reaped significant financial
benefit from a change in their lighting systems was with an upgrade
to more efficient lamps and electronic ballasts. But a lot has changed
since then. Now, in virtually every business, there is an opportunity to significantly reduce
existing lighting costs further by adopting newly developed energy management control systems.
Why Adopt Energy Management Controls Now? It’s The Code.
Energy codes are now the law of the land. From the ASHRAE/IESNA 90.1 Energy Standard and
IECC, to LEED, CEC Title 24 2005 and more, federal and state codes are underscoring the need for
better energy-saving controls for lighting by either mandating compliance or encouraging it with
tax incentives and utility rebates.
Competitive Advantage
Energy costs are rising faster than
ever before, making the reduction
of energy consumption by businesses an increasingly more powerful
competitive advantage. With over
38% of a typical business’ energy
bill related to lighting, energy saving
controls for lighting are squarely at
the center of any effort to reduce
energy expenditures.
2
Occupancy Sensing Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Energy Harvesting Wireless Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Wall Switch Occupancy Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Line Voltage Occupancy Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Low Voltage Occupancy Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Power Packs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Power Base Adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Outdoor Motion Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
53
Table of contents
Energy Management Lighting Control Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Room Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
LevNet RF™ Energy Harvesting Wireless Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
miniZ™ Intelligent Daylight Management System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Centralized Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
GreenMAX® Relay Control Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
EZ-MAX® Plus Relay Control Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Distributed Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Sector® Intelligent Digital Lighting Control System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Metering Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Lighting Control Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
OEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Zipline™ Fluorescent Retrofit Solution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Fluorescent Lampholders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Renoir™ II Commercial Dimmers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Residential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
www.leviton.com/les
3
4
Every industry, facility and application has different lighting control needs. Some needs can be met with a simple solution,
such as an occupancy sensor, while others require the advanced customization and control of GreenMAX® and Sector®.
Leviton offers a spectrum of lighting control and energy management strategies to meet any application:
• Occupancy Sensing Control
A complete line of PIR, ultrasonic and multi-technology occupancy sensors
• Room Control
LevNet RF™ Energy Harvesting Solutions, Classroom Lighting Control Solutions and miniZ™ Intelligent Daylight Harvesting
System
• Centralized Control
EZ-MAX® Plus and GreenMAX Relay Control Systems
• Distributed Control
Sector and SectorFlex Intelligent Digital Lighting Control Systems
• Hybrid Controls
Combined Leviton technologies to meet any application
• Metering Solutions
Leviton Metering Solutions system components including submetering equipment and Energy Management software
Self-Powered
Energy Harvesting
Systems – zero power
consumption - no external
power or batteries required
Wall Box Dimmers stand alone dimming
controls save energy
Wall Switch Sensors –
provides occupancy
sensing and manual
ON/OFF switching
Ceiling Occupancy
Sensors – keeps lights
off when vacant
Digital Lighting Control –
topology-free energy
management control
Architectural Lighting
Control Systems** –
multi-zone dimming control
High-Bay Occupancy
Sensor – mounts to
fixtures for a simple,
energy-saving retrofit
Outdoor
Occupancy Sensors –
ensure lights remain off
in the daytime
Entertainment Fixtures
and Consoles* - lighting
effects for presentations
and performances
Relay Control Systems –
integrate centralized lighting control
for an energy smart solution
lighting control solutions | Commercial
LEVITON COMMERCIAL LIGHTING CONTROL SOLUTIONS
Submeters – LEED validation,
measure and reduce energy use
for electricity, gas, water
and steam
Energy Manager –
Real time
data analysis
Wall-Mount
Occupancy Sensors –
reduce energy waste
in unoccupied
hallways and corridors
*Please see the Leviton Commercial Entertainment Product Catalog for more information, or visit Leviton.com/Entertainment.
**Please see the Leviton Commercial Architectural Controls Catalog for more information, or visit Leviton.com/Architectural.
www.leviton.com/les
5
lighting control solutions | Commercial
Leviton Lighting Control Solutions can be selected and tailored to commercial, institutional and industrial
applications including:
• Single, small, midsize and large office complexes
• Retail spaces
• K-12 schools and college campuses
• Municipalities
• Museums, convention centers and lecture halls
• Prison and correctional facilities
• Health care and hospital facilities
• Houses of worship
• Warehouses
• Restaurants
• Shopping malls and complexes
• Government facilities
• Airports
• National parks and monuments
Leviton Lighting Control Solutions help facilities meet energy saving and lighting control goals. Using simple and advanced
methods, Leviton Solutions leverage energy saving technologies for:
Code Compliance Implementing a Leviton solution as a new construction or retrofit project can accomplish goals set by
state, federal and local municipal codes for sustainability and energy efficiency. Tax incentives and utility company rebates
are also available for eligible projects. Leviton devices can help meet ASHRAE, CEC Title 24, IECC and LEED certification
requirements. Learn more about specific product code compliance at www.leviton.com/energycodes.
Dimming and Switched Lighting Whether switching lights ON or OFF based on occupancy or subtly dimming multiple zones, reducing lighting is one of the easiest ways to
reduce overall electricity consumption. Dimmed or OFF lights produce less heat, which
reduces facility cooling costs. By being on less, light bulbs last longer, translating to
additional cost savings. Leviton dimming and switching products include: box-mounted
dimmers; scene dimming stations and controllers; and sophisticated multizone dimming
systems that incorporate dimming and relay cabinets, architectural lighting, and more.
These products can help buildings meet mandatory ASHRAE 90.1-2010 and CEC Title 24
requirements.
Reduces
Dimming
incandescent energy
consumption by:
lights by:
10%
10%
25%
20%
50%
40%
75%
60%
Occupancy Detection In the majority of cases, if a facility is empty, lights should be OFF. Occupancy sensing takes the
burden of lighting control from occupants and into a self-contained, automated system. Numerous styles of occupancy
sensors accommodate a broad range of coverage areas and patterns of usage. Leviton’s occupancy sensor line includes
commercial and residential, energy harvesting, wide-view and high-bay, dual-relay and outdoor models for a broad range of
coverage areas and patterns. These products can help buildings meet mandatory ASHRAE 90.1-2010, IECC-2012 and CEC
Title 24 requirements, and earn LEED certification.
Timed Controls Using timers to automate switching of lights and other loads is a simple way to ensure that devices are
only on for a set period of time. Sophisticated relay systems (such as EZ-MAX Plus and GreenMAX) provide advanced load
scheduling based on scheduled or astronomical time. Leviton offers preset and programmable timer switches as well as
relay systems that integrate with lighting and other building controls in commercial and industrial applications. These
products can help buildings meet mandatory ASHRAE 90.1-2010, IECC-2012 and CEC Title 24 requirements, and earn LEED
certification.
Integration with Building Controls
When lighting, security, HVAC and
other building management systems
are integrated into a single control
system, optimal energy efficiency is
one of a host of benefits. Integrated
systems provide superior interoperability as well as essential function
for companies participating in load
shedding programs. Leviton energy
management components are building
blocks that can interact with other
Leviton products and, in some cases,
with non-Leviton building controls.
POTENTIAL SAVINGS WITH LIGHTING CONTROL STRATEGIES
100%
85%
80%
60%
60%
46%
40%
20%
20%
0%
6
95%
All Strategies
Occupancy +
Daylighting +
Task Tuning
Occupancy +
Daylighting
Occupancy +
Hold Off
Photocell
Load
Shedding
23%
Dimming:
Task Tuning
27%
26%
23%
Dimming:
Daylighting
Occupancy
Sensors
Bi-Level
Switching
From Task
Lighting (20%)
-8¢
From Daylight
Harvesting (35%)
-13¢
40¢
-6¢
32¢
19¢
From Occupancy
Sensors (18%)
13¢
Source: Midwest Energy Efficiency Alliance
Benefits from Daylight Harvesting
• Energy savings
• Reduce peak electric load
• Allow continued operation during power outages
• Connecting people to their external environment
• Improved productivity and health
Lighting, heating and air conditioning account for up to 70% of all energy being consumed in today’s modern buildings.
Daylight harvesting controls are the best way to optimize the low cost, natural resource of daylight.
Key energy saving points for Daylight Harvesting
• Architectural Daylighting design utilizing top, side and surface lighting can reduce glare and heat concerns
• Assuring lights are only utilized when light is required and space is occupied
• Automatically balancing natural and artificial light for optimized lighting usage
• Switched or dimmed light loads have less heat emissions which reduces cooling costs
• Shading systems assist in maintaining environmental controls, reducing glare and maintaining scenic views.
• Solar screening controls lights without eliminating it
• Lighting and Energy Solutions provide total energy efficient control and savings
Source: Commercial Buildings Energy Consumption Survey (CBECS) 1995, released July 1998 by the Energy Information Administration
lighting control solutions | Commercial
Savings
Standard
Cost of Lighting Energy $/sf/yr
Daylight Harvesting By utilizing present natural light
within a space, facilities reap the dual benefits of reduced
energy usage and a more pleasant, ambient building
environment. Photocells and timed systems (such as
GreenMAX, EZ-MAX Plus, Sector and SectorFlex) measure
light provided by windows, skylights and open spaces and
dim or switch OFF overhead lighting accordingly. Leviton
offers photocells, occupancy sensors, relay cabinets,
dimmers and dimming systems for daylight harvesting
systems. These products can help buildings meet mandatory IECC-2012 and CEC Title 24 requirements, and earn
LEED certification.
Greater Health, Well Being and Productivity
Studies done by the United States Green Building Council (USGBC) have shown that daylighting can improve health,
well-being and productivity of individuals, co-workers, students and employees. The determining factors for this are not
only from the amount of natural scenery and light, but from the quality and color of the artificial lamp light. Daylight
harvesting technology strives to achieve this optimal color temperature and rendition to provide visual stimulation for
health, well-being and productivity.
INTERIOR LIGHT LEVEL
Daylighting Harvesting
ENERGY
SAVINGS
12AM
6 AM
12 PM
6 PM
12 AM
TIME OF DAY
TARGET
LIGHT LEVEL
FLUORESCENT
LIGHTING
DAYLIGHT
ENERGY
SAVINGS
Source: Lighting Design Lab
www.leviton.com/les
7
lighting control solutions | Commercial
OCCUPANCY SENSING CONTROL
Occupancy sensors deliver one of the simplest and most effective methods of reducing energy usage. Basic rooms such
as restrooms, private offices, medical exam rooms and meeting rooms will see a significant drop in lighting costs when an
occupancy sensor is installed.
GOOD SOLUTION
OCCUPANCY SENSOR WITH AUTO ON/OFF CONTROL
PROBLEM: Facility contains rooms that are sporadically
occupied and do not require manual override capabilities.
PIR Ceiling
Sensor
SOLUTION: A single auto ON/OFF occupancy sensor takes the
burden of lighting control off the occupants, ensuring lights
are ON when they are needed and OFF when they
are not.
• Works best in enclosed spaces without obstructions
• Economical solution with immediate results
• Saves a significant amount of energy over traditional
switch-operated spaces
• Ideal Applications: Restrooms, conference rooms,
closets and storage areas
Zone 1
SOLUTION REQUIREMENTS
PRODUCT
QUANTITY
Occupancy Sensor
ODC0S Self-Contained PIR Ceiling Mount Occupancy Sensor
OR OPB15 & OSC15-I/M Passive Infrared Ceiling Occupancy Sensor
and Power Base Adaptor
1
Good – OS Only, 1 Zone
BETTER SOLUTION
OCCUPANCY SENSOR WITH MANUAL-ON/OFF CONTROL
PROBLEM: Occupancy sensor control is desired, but manual
overrides by occupants may occasionally be necessary to
accommodate temporary needs.
Wall Switch
PIR Sensor
SOLUTION: Occupancy sensors with manual-ON/OFF control
add a level of flexibility to the occupancy sensing solution.
Users can manually override the sensors by switching ON or
OFF to accommodate temporary needs.
• Combines the energy savings of occupancy sensing with
the convenience of manual-ON/OFF switching
• Cost-effective method of regulating lighting usage
• Ideal Applications: Smaller enclosed areas such as private
offices, conference rooms, classrooms and storage spaces
Zone 1
SOLUTION REQUIREMENTS
PRODUCT
QUANTITY
Occupancy Sensor
ODS10 PIR Wall Switch Occupancy Sensor
Good –OS Wall-box Only, 1 Zone
1
OR OSSMT Multi-Technology Wall Switch Occupancy Sensor
For Bi-Level Switching: ODS0D PIR Dual-Relay Wall Switch Occupancy Sensor
OR OSSMD Multi-Technology Dual-Relay Wall Switch Occupancy Sensor
8
Power Pack
OCCUPANCY SENSOR MULTI-ZONE/BI-LEVEL
SWITCHING SOLUTION
PROBLEM: Room is used in multiple applications, and the
same levels of light are not always desired.
SOLUTION: By dividing a space into zones, lighting
becomes more versatile. Multi-zone/bi-level switching,
controlled by an occupancy sensor, allows occupants to
accommodate A/V presentations, computer usage and
other tasks where full overhead lighting is not desired.
The integration of a Power Pack with HVAC relay lends the
option of incorporating heating and cooling systems into
the occupancy sensor control for additional energy savings.
Decora®
Wall
Switches
Zone 1
Zone 2
Multi-Tech
Ceiling
Sensor
• Multi-zone/bi-level lighting maximizes energy savings
through use of both manual and automatic controls
• Offers various lighting settings for different tasks and preferences
• Occupancy sensing adds a valuable, low-cost energy saving technique
• Flexibility with two zone settings, manual switching controls and HVAC integration
Good - PowerPack 2 Zone, OS, Sw
• Ideal Applications: Meeting and conference rooms, classrooms, training areas and small commercial spaces
Solution Requirements
PRODUCT
Occupancy Sensor
OSC15-I PIR Ceiling Occupancy Sensor
OR OSC20-M Multi-Technology Ceiling Occupancy Sensor
QUANTITY
1
Add-a-Relay Power Pack
OSP20-RDH
1
Decora Plus Rocker Commercial Grade Switch
56081-2
2
lighting control solutions | Commercial
BEST SOLUTION
OCCUPANCY SENSING CASE STUDIES
Bronner’s Christmas Wonderland
Commercial Warehouse Space, Frankenmuth, Michigan
Bronner’s Christmas Wonderland contained a large storage, shipping and receiving area that was normally
illuminated when unoccupied. Leviton divided the warehouse into separate aisleways, with each aisle containing
an OSFHU high-bay fixture-mount occupancy sensor. Once installed, switching the lights OFF when aisles were
unoccupied equated to a 90% reduction in energy usage.
Lava Beds National Park
Parks and Recreation, Tulelake, CA
Lava Beds National Monument contains 47,000 acres of park lands including lava tube caves, rugged desert
terrain and historical sites. Leviton’s LevNet RF products were selected to help control lighting in common areas,
offices and restrooms. The results were annual savings of approximately 65,000 kWh and $6,400 in energy costs.
www.leviton.com/les
9
lighting control solutions | Commercial
10
ROOM CONTROL
Leviton Room Control solutions build on the foundation of occupancy sensing to add value and convenience for facilities.
Room controls introduce daylight harvesting capabilities, which takes advantage of natural light entering a space from
windows, skylights and other open spaces. Utilizing daylight to evenly light a room while improving productivity and user
experience diminishes the amount of overhead lighting necessary to light the space.
GOOD SOLUTION
LEVNET RF DAYLIGHT HARVESTING SWITCHING
SOLUTION
Wall
Switch
PROBLEM: Facility wants to implement an occupancy
sensing and daylight harvesting solution, but cannot
interrupt building functionality with a costly wiring
project.
SOLUTION: Versatile, easy-to-retrofit and maintenancefree, LevNet RF offers an ideal energy management
solution. Switches and sensors communicate wirelessly
and respond to ambient light and occupancy within the
space to turn lights ON and OFF.
Receiver
Energy
Harvesting
Photocell
Energy
Harvesting
Sensor
Zone 1
• Energy harvesting solution is easy to install with no
need to pull or run wires, speeding up installation and
significantly reducing costs
• No batteries means associated labor, material and
maintenance costs are eliminated
• Basic daylight harvesting solution with photocell to
measure ambient light, reducing overall energy use
• Ideal Applications: Private offices, meeting and
conference rooms, hotel rooms and classrooms with
windows and/or skylights
Solution Requirements
PRODUCT
QUANTITY
LevNet RF Energy Harvesting Occupancy Sensor
WSC04-IRW
1
LevNet RF Energy Harvesting Photocell
WSCPC-00W
1
LevNet RF Wall Switch
WSS0S-00D
1
LevNet RF Line Voltage Receiver
WST05-10
1
miniZ INTELLIGENT DAYLIGHT HARVESTING DUAL-ROOM SOLUTIONS
PROBLEM: Similar office spaces share fixtures on separate zones, but will be used by occupants at different times.
SOLUTION: The miniZ Dual Room system allows separate spaces to be controlled on separate zones. Connected occupancy
sensors and photocells account for different levels of light and/or occupancy in each unique space. miniZ switching
solutions keep lights OFF when the room is unoccupied. The miniZ switching module controls two zones, which allows for
switching the lights in areas where levels of occupancy are not the same. The miniZ dimming solution creates a more ambient
space by allowing natural light to be utilized in place of overhead lighting, which reduces energy use while increasing user
satisfaction.
• Cost-effective solution allows separate spaces to be centrally controlled with separate switching or dimming needs for
different levels of light and occupancy for each zone
• Adjusts overhead lighting based on daylight present in each space
• User-friendly system incorporates multiple occupancy sensors and photocells for streamlined programming and ease-of-use
• Ideal Applications: Windowed and skylit spaces such as classrooms, private offices, conference rooms and small shops
DUAL-ROOM SWITCHING
Photocell
Zone 1
Low
Voltage
ON/OFF
Switch
Photocell
Zone 2
Dual Room
miniZ,
Switching
Multi-Tech
Ceiling
Sensor
Low
Voltage
ON/OFF
Switch
Multi-Tech
Ceiling
Sensor
lighting control solutions | Commercial
GOOD SOLUTION
Solution Requirements
PRODUCT
QUANTITY
miniZ 2-Zone, Switching
MZB02-102
1
Multi-Technology Ceiling Mount Occupancy Sensor
OSC10-M0W
2
Low Voltage Switch, ON/OFF
LV240-00W
2
Photocell
ODC0P-00W
2
www.leviton.com/les
11
lighting control solutions | Commercial
12
DUAL-ROOM DIMMING
Photocell
Photocell
Zone 1
MultiTech
Wall
Sensor
Zone 2
Dual Room
miniZ,
Dimming
MultiTech
Wall
Sensor
Low
Voltage
5-Button
Switch
Low
Voltage
5-Button
Switch
Solution Requirements
PRODUCT
QUANTITY
Dual Room miniZ, Dimming
MZD22-102
1
Multi-Technology Ceiling Mount Occupancy Sensor
OSW12-M0W
2
Photocell
ODC0P-00W
2
Low Voltage Switch, 5-Button
LV200-00W
2
LEVNET RF MULTI-ZONE DAYLIGHT HARVESTING
SOLUTION
5-Wire
Relay
Receiver
PROBLEM: Space contains several zones of overhead
lights, and those closest to natural light sources are
needed less than those further away.
SOLUTION: LevNet RF adds an extra dimension of energy
conservation with daylight harvesting and dual-zone
switching. Energy Harvesting photocells measure the
natural light entering from windows, skylights and open
areas and switch lights ON or OFF to compensate. By
adding zonal control, lights very close to windows stay
OFF longer than lights placed further in for a more
evenly-lit, user-friendly space.
5-Wire
Relay
Receiver
Energy
Harvesting
Dual Rocker
Switch
Energy
Harvesting
Photocell
Zone 1
Zone 2
Energy
Harvesting
Sensor
• Control two zones of lighting to evenly light the space
and accommodate A/V presentations, quiet times, etc.
• Switches can override occupancy sensor and photocell
when temporary manual control is needed
Better - Levnet RF 2 Zone, PC, OS, Sw
• Self-powered with no hard wiring makes the solution
easy to install in tough-to-wire retrofits
• Ideal Applications: Classrooms, presentation and
meeting rooms, offices and hospitality
SOLUTION REQUIREMENTS
PRODUCT
QUANTITY
LevNet RF Energy Harvesting Sensor
WSC04-IRW
1
LevNet RF Energy Harvesting Photocell
WSCPC-00W
1
LevNet RF Dual Rocker Decora Switch
WSS0S-D2W
1
LevNet RF 5-Wire Relay Receiver
WST12-020
2
www.leviton.com/les
lighting control solutions | Commercial
BETTER SOLUTION
13
lighting control solutions | Commercial
14
BETTER SOLUTION
miniZ MULTI-ZONE BI-LEVEL SWITCHING SOLUTION
PROBLEM: Facility contains lighting fixtures that are zoned
to switch by lamp. Lighting that switches incrementally is
desired. Incorporation of photocells, occupancy sensors
and manual switches is necessary for users to make
optimal use of the space.
Zone 1
Zone 2
212
SOLUTION: miniZ enables rooms to be bi-level switched,
so that zoned lamps are dimmed when adequate natural
light is present and are turned OFF when the room is
vacant. Centralize all levels of the room, including sensors
and switches, with miniZ’s easy-to-use auto-calibration
technology.
• By dividing fixtures into zones, lighting in occupied zones
can be automatically or manually switched ON/OFF while
the unused areas remain OFF (A/V presentations, offices
used by individuals at odd hours).
Low
Voltage
5-Button
Switch
miniZ
2-Zone,
Switching
212
Multi-Tech
Ceiling
Sensor
212
212
Photocell
212
212
• Switching brings a simple solution to each unique space
• Ideal Applications: Schools, office complexes, restaurants and mixed-use commercial and residential spaces
212
Zone 2
212
Solution Requirements
PRODUCT
QUANTITY
miniZ 2-Zone, Switching
MZB00-102
1
Multi-Technology Ceiling Mount Occupancy Sensor
OSC20-M0W
1
Photocell
ODC0P-00W
1
Low Voltage Switch, 5-Button
00LVS-05W
1
Better – miniZ 3 rooms, 3 ways
- power pack
miniZ INTELLIGENT DAYLIGHT HARVESTING 3-ZONE
DIMMING SOLUTION
PROBLEM: Room requires manual control of staggered
zones of lights, ranging from closest into the building
to furthest toward the window. Additionally, occupants
desire the flexibility to manually switch the zones ON and
OFF to accommodate temporary needs for presentations,
media viewing, etc.
SOLUTION: Stagger the dimming of light loads with the
miniZ 3-zone dimming system. miniZ self-calibrates to a
maintained light level to optimize lighting within a space
while taking advantage of ambient light. Zones can be
manually switched ON or OFF to compensate for specific
occupant needs, such as switching lights near a
projection screen OFF during a presentation.
3-Zone
miniZ,
Dimming
Renoir II
Switch
Zone 1
Zone 2
Zone 3
Low
Voltage
5-Button
Switch
Multi-Tech
Ceiling
Sensor
Photocell
• Occupancy sensors keep lights OFF when the space is
empty, while photocell and miniZ measure and manage
lighting when occupied for better ambience and energy
conservation
• Daylight harvesting of 3 zones offers a more
comfortable, ambient environment which increases
end user satisfaction
• Ideal Applications: Education applications, hospital
waiting areas and lobbies
Good – Large Room MiniZ 3 zone, OS, PC, Sw
Solution Requirements
PRODUCT
QUANTITY
miniZ 3-Zone, Dimming
MZD30-101
1
Multi-Technology Ceiling Mount Occupancy Sensor
OSC20-M0W
1
Photocell
PCIND-000
1
Low Voltage Switch, 5-Button
LV220-00W
1
Renoir II Wall Switch, Thin Heat Sink
AWWMT-00W
1
www.leviton.com/les
lighting control solutions | Commercial
BEst SOLUTION
15
lighting control solutions | Commercial
BEST SOLUTION
LEVNET RF ZONAL AND INDIVIDUAL FIXTURE CONTROL
Relay
Receiver
Energy
Harvesting
Sensor
Energy
Harvesting
Photocell
Relay
Receiver
Energy
Harvesting
Wall Switch
Receiver
Relay
Receiver
Energy Harvesting
Sensor
Relay
Receiver
Energy Harvesting
Sensor
Energy
Harvesting
Dual Rocker
Switch
Energy
Harvesting
Wall
Switch
Receiver
Relay
Receiver
Energy Harvesting
Photocell
Energy
Harvesting
Single and
Dual Rocker
Switches
Relay
Receiver
Energy
Harvesting
Sensor
Relay
Receiver
Energy
Harvesting
Sensor
Energy
Harvesting
Sensor
Relay
Receiver
Relay
Receiver
Relay
Receiver
Relay
Receiver
Relay
Receiver
Relay
Receiver
Relay
Receiver
Relay
Receiver
Zone 2
Energy
Harvesting
Sensor
Relay
Receiver
Relay
Receiver
Energy
Harvesting
Sensor
Zone 1
Relay
Receiver
Energy
Harvesting
Sensor
Relay
Receiver
Energy
Harvesting
Sensor
Relay
Receiver
Energy
Harvesting
Sensor
Relay
Receiver
Zone 3
PROBLEM: Facility with multiple rooms and uses wants to implement one energy management system as a retrofit. Some
overhead lights should be controlled as zones and respond to occupancy sensing and daylight harvesting controls as one,
while other fixtures require individual manual and sensing controls.
SOLUTION: LevNet RF system components can be combined to create dynamic lighting options for a variety of spaces.
Zones can be designated in rooms by connecting LevNet RF dimmer modules to ganged fixtures, which respond to the
occupancy sensor, photocell and switch signals to dim lighting by groups of lights incrementally further from daylight
sources. In large open spaces where windows are not present, individual fixtures or small groups of fixtures can be
switched ON or OFF by occupancy sensors and manual switching.
• Easy-to-retrofit, energy harvesting technology can be installed and modified to accommodate evolving needs of the
space, significantly reducing labor and material costs
• Create zonal control by assigning one dimmer module to a ganged set of fixtures and an associated switch, or individual
fixture control by placing one line voltage per fixture to respond to occupancy sensor signals. The entire area can be
manually controlled ON or OFF by switch. The result is flexibility at a low cost
• Ideal Applications: Schools, college campuses, libraries, municipal buildings, mixed-use commercial and residential
spaces and hospitality
16
PRODUCT
lighting control solutions | Commercial
SOLUTION REQUIREMENTS
QUANTITY
LevNet RF Relay Receiver
WST05-010
21
LevNet RF Energy Harvesting Sensor
WSC04-IRW
11
LevNet RF Energy Harvesting Photocell
WSCPC-00W
2
LevNet RF Wall Switch Receiver
WSS10-GDW
3
LevNet RF Dual Rocker Switch Receiver
WSS0S-D2W
2
ROOM CONTROL CASE STUDY
UC Santa Cruz Science and Engineering Library
Post-Secondary Education, Santa Cruz, California
The Science and Engineering Library is one of two libraries
that serve over 16,000 students on the UC Santa Cruz
campus. Faced with time constraints and the high cost of
conventional wired technologies, the energy group chose to
use Leviton’s energy harvesting technologies to achieve their
energy goals. LevNet RF receivers paired to energy harvesting
occupancy sensors and light sensors contributed to the
energy retrofit of the existing fluorescent fixtures from T12 to
T8 and saved an actual 50% of energy consumption in the
facility—an anticipated $48,000 energy cost savings annually.
www.leviton.com/les
17
lighting control solutions | Commercial
CENTRALIZED CONTROL
Total facility control from one access point is the goal of Leviton’s Centralized Control Solutions. Relay panels, including the
EZ-MAX Plus and GreenMAX models, integrate multiple room controls into a single system that reduces troubleshooting,
narrows the scope of maintenance and expedites installation, which translates into significant labor cost savings. With
advanced features such as GreenMAX’s programmable Behaviors, Centralized Control opens up new possibilities for
managing energy use while making the facility safer, smarter and more user-friendly.
GOOD SOLUTION
EZ-MAX PLUS RELAY ZONAL CONTROL
PROBLEM: More precise energy control is required in the
building, such as programming in a school’s daily class
schedule.
SOLUTION: EZ-MAX Plus offers programmed energy
management in an affordable, compact stand-alone relay
panel system. The system can be easily programmed to
automatically turn lights ON or OFF based on planned
times (open/close) or astronomical clock (sunrise/
sunset). Occupancy sensor and photocell integration
enhance programmed settings with daylight harvesting
and ON/OFF occupancy switching.
Photocell
• Single point of facility control saves on labor and
maintenance costs
• Programmable ON/OFF features consistently keep
lights ON when lighting is likely needed and OFF when
unused
Multi-Tech
Ceiling
Sensor
• Time clock feature useful for controlling common areas
and site lighting for added safety in courtyards, parking
lots, etc.
• Ideal Applications: Restaurants, offices, houses of
worship and retail spaces
SOLUTION REQUIREMENTS
PRODUCT
18
Low
Voltage
2-Button
Switch
QUANTITY
EZ-MAX Plus 8-Relay Panel
R08BD-L30
1
Multi-Technology Ceiling Mount Occupancy Sensor
OSC20-M0W
1
Photocell
ODC0P-00W
1
Low Voltage 2-Button Switch
00LVS-02W
1
ezMax 2 zone
EZ-MAX
Plus
8-Relay
Panel
EZ-MAX PLUS RELAY– A/V CLASSROOM
PROBLEM: Facility seeks to incorporate timing and astronomical clock control into a facility where overhead lights
are designed to be manually controlled to accommodate
presentations, media viewing, etc.
SOLUTION: The EZ-MAX Plus solution allows for modern
schools to accommodate evolving classroom needs.
Many classes now include dynamic visuals requiring the
use of projection screens, TV and computer monitors
as presentation tools. EZ-MAX Plus can be programmed
to control the lighting zone at the head of the class
separately from the lights over desks.
Zone 1
Zone 2
Low
Voltage
4-Button
Switch
Zone 3
EZ-MAX
Plus
8-Relay
Panel
Photocell
• Reduce eye strain from trying to watch A/V presentations
in full overhead light
• Allows instructors to adjust lighting in presentation
area while the student zone remains lit by ambient and
overhead lighting for note-taking
Multi-Tech
Ceiling
Sensor
• Ideal Applications: K-12 classrooms, college campuses
and office training facilities
SOLUTION REQUIREMENTS
PRODUCT
QUANTITY
EZ-MAX Plus 8-Relay Panel
R08BD-L30
1
Multi-Technology Ceiling Mount Occupancy Sensor
OSC20-M0W
1
Photocell
ODC0P-00W
1
Low Voltage 4-Button Switch
00LVS-04W
1
lighting control solutions | Commercial
BETTER SOLUTION
ezMax 3 zone
www.leviton.com/les
19
lighting control solutions | Commercial
BEST SOLUTION
GREENMAX
Photocell
Multi-Tech
Ceiling
Sensor
4-Button 4-Button
Digital
Digital
Switch
Switch
Multi-Tech
Ceiling
Sensor
1-Button Digital Switch
1-Button Digital Switch
4-Button
Digital
Switch
GreenMAX
Relay
System
4-Button
Digital
Switch
Multi-Tech
Ceiling
Sensor
Multi-Tech
Ceiling
Sensor
Multi-Tech
Ceiling
Sensor
Multi-Tech
Ceiling
Sensor
Photocell
Keyswitch Digital Switch
PROBLEM: Commercial facility has several rooms that utilize occupancy sensors and daylight harvesting technologies,
but does not require specific zonal controls.
SOLUTION: Installing several GreenMAX systems allows for similar rooms to be controlled from a central location.
Pre-programmed Behaviors can be set to anticipate daily routine patterns of usage, along with circumstances such as
closures and breaks.
• Practical solution for large buildings with many smaller rooms, but not requiring numerous zonal configurations
• Centralized control for time-settings; ready to integrate with building automation systems
• Ideal Applications: Office buildings, schools, college campuses, municipal buildings, airports
20
PRODUCT
lighting control solutions | Commercial
SOLUTION REQUIREMENTS
QUANTITY
GREENMAX RELAY SYSTEM COMPONENTS
GreenMAX Relay Cabinet, 8-Relay Size
R08TC-100
1
GreenMAX Relay Cabinet, 32-Relay Size
R32TC-100
1
GreenMAX Main Command Module
RPM16-110
2
GreenMAX Relay Insert Panel - 8-Relay Size
R0800-000
1
GreenMAX Relay Insert Panel - 16-Relay Size with
16 GreenMAX Dimming Relays
R1616-1DS
2
GreenMAX Dimming Relays
RELAY-1DS
8
GREENMAX EXTERNAL SYSTEM COMPONENTS
GreenMAX Handheld Display Unit (HDU)
RHDUI-000
1
GreenMAX Digital Switch, 4-Button
RDGSW-4DW
4
GreenMAX Digital Switch, 1-Button
RDGSW-1DW
4
GreenMAX Digital Switch, Keyswitch
RGDSW-1KS
1
Multi-Technology Ceiling Mount Occupancy Sensor
OSC20-M0W
6
Photocell
ODC0P-0DW
2
www.leviton.com/les
21
lighting control solutions | Commercial
BEST SOLUTION
GREENMAX ZONAL CONTROL
GreenMAX
Relay
System
GreenMAX
Relay
System
Photocell
Multi-Tech
Ceiling
Sensor
Multi-Tech
Ceiling
Sensor
4-Button 4-Button
Digital
Digital
Switch
Switch
1-Button Digital Switch
1-Button Digital Switch
1-Button Digital Switch
1-Button Digital Switch
4-Button 4-Button
Digital
Digital
Switch
Switch
MT Ceiling
Mount OS
GreenMAX
Relay
System
GreenMAX
Relay
System
MT Ceiling
Mount OS
Photocell
MT Ceiling
Mount OS
MT Ceiling
Mount OS
Keyswitch Digital Switch
PROBLEM: Large commercial space has areas that must be controlled independently, and each room has areas that may
need to be segregated by zone for customizable control. The length and amount of wire needed to bring all room controls
to one centralized location would be labor and cost-prohibitive.
SOLUTION: GreenMAX allows large areas, or rooms divided into zones, to be centrally controlled. Pre-programmed Behaviors
can be set in advance to control rooms on common-use settings or for separate circumstances such as closures and breaks.
• Rooms are equipped with photocells and occupancy sensors to achieve optimal daylight harvesting
• Using the sensors and switches allows shorter and less expensive wiring options
• Incorporating smaller panels allows for less wiring and lower installation and maintenance costs
• Centralized control for time-settings; ready to integrate with building automation systems
• Ideal Applications: Office buildings, schools, college campuses, municipal buildings, airports
22
PRODUCT
lighting control solutions | Commercial
SOLUTION REQUIREMENTS
QUANTITY
GREENMAX RELAY SYSTEM COMPONENTS
GreenMAX Relay Cabinet, 8-Relay Size
R08TC-100
4
GreenMAX Main Command Module
RPM16-116
4
GreenMAX Relay Insert Panels, 8-Relay Size
R0800-000
4
GreenMAX Dimming Relays
RELAY-1DS
32
GREENMAX EXTERNAL SYSTEM COMPONENTS
GreenMAX Handheld Display Unit (HDU)
RHDUI-000
1
GreenMAX Digital Switch, 4-Button
RDGSW-4DW
4
GreenMAX Digital Switch, 1-Button
RDGSW-1DW
4
GreenMAX Digital Switch, Keyswitch
RGDSW-1KS
1
Multi-Technology Ceiling Mount Occupancy Sensor
OSC20-M0W
6
Photocell
ODC0P-0DW
2
www.leviton.com/les
23
lighting control solutions | Commercial
DISTRIBUTED CONTROL
Flexibility, cost-effectiveness and energy efficiency are the goals of Leviton’s Distributed Control Solutions. Sector Intelligent
Digital Lighting Control Systems and SectorFlex integrates scheduling, daylight harvesting, occupancy sensing, dimming
and manual control into an intelligent digital lighting control system. Sector and SectorFlex systems are easy to design,
install and program and provide energy savings and increase occupant comfort and productivity.
BEST SOLUTION
SECTOR BALLAST INDIVIDUAL CONTROL
Sector Ballast
Sector
Photocell
Sector
Multi-Tech
Ceiling
Sensor
Sector
Multi-Tech
Ceiling
Sensor
Sector Bus
Controller
Sector
Multi-Tech
Ceiling
Sensor
Sector
Sector
5-Button 5-Button
Switch
Switch
Sector
Multi-Tech
Ceiling
Sensor
Sector
Photocell
Sector
Multi-Tech
Ceiling
Sensor
24
Sector
Sector
5-Button 5-Button
Switch
Switch
Sector Ballast Individual Control
Sector
Multi-Tech
Ceiling
Sensor
SOLUTION: The Sector solution includes 0-10V ballasts, controllers, occupancy sensors, photocells and switches and a
GUI software for a scalable solution for a variety of facilities. Leviton’s Sector ballasts can be controlled at any level, from
an entire room or facility to individual lighting loads. Individual control allows occupants to control their light from their
personal computer, and also frees up a space to be used in various, evolving ways. For example, a large open space can be
built with Sector implemented for a retail application, but in the future easily reconfigured for smaller offices and shops.
The fixtures can be programmed to work together within the newly defined space with a few clicks using the GUI software.
• Leviton’s Sector ballasts measure energy usage in each fixture, allowing facility managers to view actual use and plan
energy management strategies and conservation efforts accordingly
• Vary zones of light to any scale, large or small, and change at any time without needing to switch out hardware. One
investment saves on numerous material and labor costs, presenting a superior value to facilities
• Sector combines daylight harvesting technologies with occupancy sensing and manual control, offering a solution which
encompasses all major energy-saving technologies: occupancy sensing, dimming and switching, daylight harvesting and
manual overrides
• Ideal Applications: Newly constructed schools, college campuses, office buildings, commercial spaces, shopping malls,
airports and other commercial facilities
SOLUTION REQUIREMENTS
PRODUCT
Sector Ballasts
SD2J8-32M
QUANTITY
43
Sector Bus Controller
SBP00-00M
1
Sector Digital Switch, 5-Button
SDS00-15W
4
Sector Multi-Technology Ceiling Mount Occupancy Sensor
OSC20-MSW
6
Sector Photocell
ODC0P-0SW
2
www.leviton.com/les
lighting control solutions | Commercial
PROBLEM: New construction is beginning on a facility that will have multiple uses, and may be configured in different ways
in the future based on changing tenants. Each room will be used in unique ways: there will be some cubicle areas where
users would prefer to control lights directly above and around them, and other areas where overhead lights should be
controlled as one seamless unit.
25
lighting control solutions | Commercial
BEST SOLUTION
SECTORFLEX ZONAL LIGHTING CONTROL
Sector Ballast Controller
Sector
Multi-Tech
Ceiling
Sensor
Sector
Photocell
Sector
Sector
2-Button 2-Button
Switch
Switch
Sector
2-Button
Switch
Sector Bus
Controller
Sector
2-Button
Switch
Sector
Sector
5-Button 5-Button
Switch
Switch
Sector
Photocell
Sector
Multi-Tech
Ceiling
Sensor
Sector
Multi-Tech
Ceiling
Sensor
Sector
Multi-Tech
Ceiling
Sensor
Sector
Multi-Tech
Ceiling
Sensor
PROBLEM: Existing facility desires the flexible features of the Sector system to control overhead lighting by zones, but the
building has existing non-Sector ballasts. Replacing all ballasts would be cost-prohibitive.
SOLUTION: The SectorFlex solution contains all of the flexibility and features of Sector into a system that can be implemented
with any 0-10V ballast or load. This makes SectorFlex ideal for retrofit projects where ballasts already exist. Ballasts can later
be upgraded to Leviton Sector ballasts to allow for energy usage tracking. SectorFlex allows the integration of the Sector
system without completing an entire overhaul of a structure’s existing ballast systems currently in place.
• Controls lighting areas by zones with the ability to add and merge zones as lighting needs evolve
• Contains all of the flexible options of Sector without requiring immediate replacement of existing ballasts
• Ideal Applications: Retrofit applications such as hotels, schools, universities, hospitals, airports, and other pre-existing
structures
26
PRODUCT
Sector Ballast Controller
SBCS0-L00
lighting control solutions | Commercial
SOLUTION REQUIREMENTS
QUANTITY
15
Sector Bus Controller
SBP00-00M
1
Sector Digital Switch, 5-Button
SDS00-15W
2
Sector Digital Switch, 2-Button
SDS00-12W
4
Sector Multi-Technology Ceiling Mount Occupancy Sensor
OSC20-MSW
5
Sector Photocell
ODC0P-0SW
2
www.leviton.com/les
27
lighting control solutions | Commercial
HYBRID CONTROL
1-Button
Digital
Switch
Some facilities require an even deeper level of customization to meet unique needs and specific goals. Leviton’s
systems can be designed to work together to meet any
application need as hybrids of Occupancy Sensing, Room
Control, Centralized and Distributed Control Solutions.
4-Button
Digital
Switch
GreenMAX
Relay
System
BEST SOLUTION
GREENMAX DIMMING/SWITCHING WITH REMOTE LOW
VOLTAGE CABINET AND LEVNET RF
PROBLEM: Facility requires a deeper level of customization to retrofit existing areas with a minimally-invasive
system. They also desire a high level of programming
precision to centralize control and set lighting on Behavior
schedules.
SOLUTION: By adding a Remote Low Voltage Panel to a
GreenMAX configuration, facilities can incorporate low
voltage components such as LevNet RF energy harvesting
solutions to monitor room occupancy and daylight harvesting. Combining the two systems blends the wireless
convenience and easy installation of LevNet RF with the
advanced Behavior programming and zonal control of
GreenMAX.
• Multiple zones controlled by occupancy, ambient light
or pre-programmed Behaviors
Wireless
Sensor
Zone 1
Daylight Harvesting
Dimmed
Zone 2
Zone 3
Switched
Switched
• Centralized control of multiple systems reduces
maintenance costs
• Ideal Applications: Restaurants, classrooms and commercial spaces
SOLUTION REQUIREMENTS
PRODUCT
QUANTITY
GREENMAX RELAY SYSTEM COMPONENTS
GreenMAX Relay Cabinet, 16-Relay Size
R16TC-116
1
GreenMAX Main Command Module
RPM16-110
1
GreenMAX Relay Insert Panels, 8-Relay Size
R0800-000
1
GreenMAX Dimming Relays
RELAY-1DS
8
GREENMAX EXTERNAL SYSTEM COMPONENTS
28
LevNet RF
5-Wire
Relay
Receiver
Wireless
Photocell
GreenMAX Handheld Display Unit (HDU)
RHDUI-000
1
GreenMAX Digital Switch, 4-Button
RDGSW-4DW
1
GreenMAX Digital Switch, 1-Button
RDGSW-1DW
1
LevNet RF Energy Harvesting Sensor
WSC04-IRW
1
LevNet RF Energy Harvesting Photocell
WSCPC-00W
1
LevNet RF 5-Wire Relay Receiver
WST02-R10
1
GreenMAX Closed Loop Dimming
Leviton Metering Solutions enhance any Application
Solution by allowing facilities to accurately track actual
energy usage. By measuring energy usage over days,
weeks and months, trends can be identified and the
effectiveness of conservation efforts can be proven.
Implementing a submetering strategy in your facility
is simple, and with Leviton’s options, scalable to your
project’s needs. Start your solution with Leviton
Metering Kits, which include the meter (indoor or
outdoor) and required current transformers. Make
translation of data easy with our Energy Management Hub (EMH) and Energy Management Software,
which translates data collected from meters into
user-friendly, real-time reports. Leviton helps facilities
implement a metering solution that fits any project’s
needs, regardless of size or requirements.
Consultative Approach Leviton believes that no customer is identical, and each project has unique considerations to
provide equipment that will yield the most effective results. Finding the right match for each client, versus a blanket
solution, ensures that each project gets exactly the equipment it needs—no more, no less.
Open Protocol By designing open protocol products and operating systems, Leviton ensures ease of communication
between multiple parties and platforms. The result is scalable, streamlined solutions that are easy to integrate with new
and existing systems.
Scalable System Leviton Metering Solutions can be implemented as an entire solution or in stages, based on the project
and the customer’s needs for ease and flexibility. Options for future upgrades and additions are available with Leviton’s
flexible solution—no need to purchase an entire new system, adding long-term value and cost savings.
Leviton Metering Solutions deliver accurate information for:
• Load profiling and benchmarking
• Tenant cost allocation
• Measurement and verification (M & V)
• Energy conservation and cost reduction
• Green building initiatives and Government mandates
lighting control solutions | Commercial
METERING SOLUTIONS
• AMR/BAS/BMS/EMS integration
• Power Quality Analysis
• Usage aggregation
See the Metering Solutions section for more information on product offerings.
www.leviton.com/les
29
30
www.leviton.com/les
31
OCCUPANCY SENSING CONTROL
Lighting energy consumption has climbed to over 38% of all energy used in today’s commercial facilities. With rising energy
costs and its mounting environmental impact, turning lights OFF in unoccupied spaces is a necessity. One of the best ways
to ensure that energy is not wasted is by installing occupancy sensors..
An E Source survey, focusing only on
the addition of occupancy sensors,
highlights the significant energy
savings their adoption can provide
Typical Savings with
Occupancy Sensors
Type of Room
Energy
Savings %
Private Office
13 to 15%
Open-Plan Office 20 to 28%
Classroom
40 to 46%
Conference Room 22 to 65%
Bathrooms
30 to 90%
Corridors
30 to 80%
Storage Area
45 to 80%
E Source Purchasing Advisor, 2009
According to a Midwest Energy Efficiency Alliance study,
their cost-saving potential is considerable:
ANNUAL LIGHTING ENERGY COST ($/SQ.FT.)
OCCUPANCY SENSING CONTROL | VACANCY AND OCCUPANCY SENSORS
32
Saves on energy costs
Saves on material and labor costs
A study by the Electrical Power Research Institute found that while the increased ON/OFF switching by occupancy sensors
reduced fluorescent lamp life from 34,000 to 30,000 hours, it also dramatically increased lamp longevity for always-on
lamps from 3.9 years to 6.8 years by not wasting lamp life during unoccupied hours. Though the energy savings from
occupancy sensors remains their most compelling feature, the reduced frequency of lamp replacement over time and the
associated decline in maintenance costs can also provide significant savings. Their ease of installation makes their use a
cost effective and viable energy saving alternative in both new construction and retrofit applications.
The need to optimize building energy performance has resulted in a variety of mandatory energy codes. Occupancy sensors
provide a very cost-effective means of compliance with these codes. They also offer an easy way to achieve higher levels of
voluntary certification for implementation of energy saving measures, resulting in potential income tax credits for building
owners or tenants who meet these “green” standards.
ASHRAE 90.1-2010 ENERGY STANDARD
• Requires occupancy sensors that turn lights OFF within 30 minutes after a space is vacated as one solution for required
automated shut OFF of lights in commercial buildings greater than 5000 square feet.
• Occupancy sensors required:
- In certain non K-12 classrooms
- Conference/meeting rooms
- Employee lunch and break rooms (if no multi-scene control is in place)
- Copy and print rooms
- Office spaces up to 250 square feet
- Restrooms, locker and fitting rooms
IECC 2012 Lighting Control Provisions
• Used by government agencies to formulate requirements for minimum energy efficiency in commercial building design.
• Section 805.2.2.1 allows occupancy sensors to be used in open areas as an alternative to a provision requiring manual
control that uniformly reduces lighting by at least 50%.
California Energy Commission (CEC) Title 24 Program
The California Energy Commission (CEC) original Title 24 program applies to nonresidential and residential high-rise buildings
as well as hotel/motel occupancies. Key provisions now in effect include:
A. A
rea Controls: An occupancy sensor that turns lights off within 30 minutes after the space is vacated for all areas
enclosed by ceiling height partitions
B. Multi-Level Lighting Controls: General lighting for any enclosed space 100 sq. ft. or larger where connected lighting
load exceeds 0.8 watts per sq. ft. for the space and has more than one light source shall have at least one control step
that is between 50% and 70% and allow the power of all lights to be manually turned OFF (Occupancy sensors that
switch alternate rows of lighting fixtures based on occupancy are a possible solution)
C. Shut-off Controls: For every floor, all interior lighting must have a separate automatic control – an occupancy sensor
or some other device – capable of automatically shutting off the lighting. Occupancy sensor is required for Offices
≤ 250 sq. ft.; Multipurpose room < 1000 sq. ft.; Classrooms of any size; Conference rooms of any size. Shall allow lights to
be manually shut off regardless of sensor status
D. New Single and Low-Rise Residential Structures: Bathroom, garage, laundry room, utility room and outdoor lighting
in single residences as well as lighting in common areas of low-rise residential buildings with four or more dwelling units
must be from high-efficacy luminaires. If luminaires are used in these locations that are not high efficacy, occupancy
sensors must control them. Lighting in other areas of residential buildings that is not from high-efficacy luminaires is
only permitted if controlled by either a dimmer switch or an occupancy sensor
E. Demand Responsive Lighting Controls: Retail buildings with sales floor areas > 50,000 sq. ft. require automatic
demand responsive lighting controls; uniformly reduce lighting power consumption ≥ 15%; Exception: Buildings where
> 50% lighting power is controlled by daylighting controls
LEED Voluntary Certification Program
• Voluntary program developed and administered by the U.S. Green Buildings Council (USGBC)
• Four-tiered rating and certification system
• Focus on daylight harvesting to reduce a building’s operating costs and occupancy sensors for better control of lights
and HVAC systems
• LEED requires compliance with ASHRAE and as such occupancy sensors are required
EPACT (Energy Policy Act of 2006)
OCCUPANCY SENSING CONTROL | VACANCY AND OCCUPANCY SENSORS
SAVE ON ENERGY CODE COMPLIANCE COSTS
• Tax incentives for buildings that reduce lighting energy below ASHRAE 90.1-2004 by at least 25% with sliding scale up to
50% savings
• Must comply with ASHRAE 90.1-2001 plus additional bi-level lighting control, which can be met with dual-relay occupancy
sensor and dimming
For more information, visit leviton.com/cenergycodes
www.leviton.com/les
33
OCCUPANCY SENSING CONTROL | VACANCY AND OCCUPANCY SENSORS
ABOUT SENSING TECHNOLOGIES
Passive Infrared (PIR)
Infrared occupancy sensors are passive devices designed to detect the movement of heat-emitting bodies. They are
installed to monitor areas where there are no physical obstructions to block the sensor’s field of view.
Ultrasonic (US)
Ultrasonic sensing technology provides highly accurate small-motion detection. Leviton sensors employing ultrasonic
technology are well suited to monitoring areas, especially smaller or narrow ones, with inanimate objects (such as furniture)
that block the line of site and hence are likely to block the field of view of PIR sensors. They are also ideal where more
sensitive detection is required.
Multi-technology
Multi-technology occupancy sensors combine ultrasonic sensing for maximum sensitivity with PIR technology to prevent
false triggers from air conditioning and corridor activity. These sensors are ideal for large, open areas including office areas
with cubicles, general workspaces, warehouse and storage facilities, cafeterias, and public areas in commercial facilities.
Adaptive Definition
A dedicated internal microprocessor continually analyzes the room environment and adjusts itself automatically. The internal
timer, detection sensitivity and thresholds are automatically adjusted. Once installed, a sensor incorporating adaptive
technology should not require manual adjustment or calibration.
OCCUPANCY SENSOR INSTALLATION TYPES AND TIPS
Passive Infrared (PIR) Occupancy Sensors
• Use a semiconductor to sense movement of infrared heat from the
human body
• Require an unobstructed line-of-sight for accurate detection—any
furniture or decorations that block the sensor’s view will prevent
occupant’s movement from being “seen”
• Respond to larger movements than ultrasonic sensors
• Work best in small, enclosed areas with high levels of occupant
motion
• Locate PIR sensors with a clear line-of-view of the area to be
covered, perpendicular to the likely movement
Ultransonic (U/S) Occupancy Sensors
• Continually transmit ultrasonic sound waves and respond to shifts in
position of a person relative to the sensor (doppler shift), and do not
require an unobstructed line-of-sight
• More effective at sensing motion around corners and in cubicles,
and locations where only small amounts of motion are taking place
• Since U/S sensors are omni-directional, locate sensors away from
doorways, room openings or adjacent areas, or closer than 6 feet of
HVAC ducts to avoid unwanted sensing of motion
• Carpeting, partitions and ceiling tiles will absorb U/S raves and
reduce range, while hard surfaces such as tile or metal will increase
sensitivity
• Most effective when mounted 8 feet or lower
Multi-Technology Occupancy Sensors
• Combine PIR and U/S technology to provide the most reliable
detection means possible, with PIR’s long-range detection and U/S
high sensitivity
• Must be located with an unobstructed line-of-sight view of a room’s
entrance
• Must be located at least 6 feet from HVAC ducts
• Locate where small-motion work occurs, such as desks and
workstations
34
Sensor Type
When to Use
Wall Switch
This sensor replaces an existing wall switch. Get both occupancy sensing and manual on/off
switching in a single device.
Ceiling-Mount
For 180° or 360° coverage of an area (360° sensor shown).
Wall-Mount
For coverage of irregularly shaped areas and those with varying ceiling heights, as well as
narrow hallway and high-bay corridor applications. For detection in spaces outside the field of
view of other occupancy Adjustable swivel neck rotates 80° vertically and 60° horizontally to
allow wall or ceiling mount installation.
Fixture-Mount
For mounting on or in fixtures.
SELECTION & PLACEMENT
Sensors can be mounted in the middle of walls, in corners, or on ceilings. Occupancy sensors must be intelligently placed in
order to ensure that motion is detected throughout an entire space. With a variety of models from which to choose, care
should be taken to select the proper combination of sensors to cover an entire area with motion detection.
Factors to consider before selecting and placing an occupancy sensor include:
• Size and shape of area needing coverage compared to ranges of occupancy sensors
• Obstacles that may block the sensor’s line of sight
• How much activity there is in a space
• Ceiling height
• Airflow that can falsely register as motion
• Location of HVAC ducts
Leviton’s Lighting Management Systems Division provides a complimentary occupancy sensor layout service. This
service provides suggested sensor selection and placement on a customer’s drawings in either paper or electronic form,
along with a bill of material detailing the components necessary for that layout. Register for this complimentary service
at http://portal.leviton.com.
UNDERSTANDING SENSOR CATALOG NUMBERS
First 2 Letters 3rd Character: Last 2 Characters –
type of product
1st Character of Suffix: 2nd Character of 3rd Character of
sensor technologySuffix: voltage Suffix: color
OS = Occupancy C = Ceiling Mount
02 = 200sf or 2A F = 10 min delayed-OFF for 2nd relay
1 = 120V
W = White
Sensor
W = Wall Mount
04 = 400sf or 4A G = Neutral not required
2 = 230V
I = Ivory
OD = Occupancy
P = Power Pack 05 = 500sf or 5A I = Infrared
3 = 347V
T = Light Almond
Detector
A = Add-A-Relay 10 = 1000sf or 10A M = Multi-technology
4 = 480V
G = Gray
WS = Wireless
S = Switch Mount
12 = 1200sf or 12A R = Relay (HVAC)
7 = 277V
E = Ebony/Black
Sensor
F = Fixture Mount
15 = 1500sf or 15A P = Self-powered
8 = 240V
R = Red
D = Dimmer
20 = 2000sf or 20A T = CEC Title 24 Compliant, 2nd Relay D = 120-277V
0 = N/A
G = Plug
0D=Dual relay U=Ultrasonic
U=Universal
R = Room Controller 0S = Self-contained 0 = N/A
N = Nafta/
0=N/A
CG=CageBuy America*
HU=High Bay
0=
N/A
LR
=
Long Range
MD
=
Multi-Tech
Dual Relay
MT
=
Multi-Tech
Single Relay
RA
=
Raceway
Adapter
*Contact Leviton for NAFTA/Buy America compliant occupancy sensors.
WV
=
Wide View
www.leviton.com/les
OCCUPANCY SENSING CONTROL | VACANCY AND OCCUPANCY SENSORS
ABOUT DIFFERENT SENSOR DESIGNS
35
OCCUPANCY SENSING CONTROL I ENERGY HARVESTING
ENERGY HARVESTING SENSORS
LevNet RF Energy Harvesting Sensors are part of LevNet RF’s complete line of wireless solutions. The wireless occupancy sensors have built-in solar cells that draw on
available ambient light within a space to power themselves and can operate for up to
48 hours in total darkness. The self-powered wireless sensor design also overcomes
the placement and coverage challenges of traditional sensors. Self-powered wireless
sensors enable flexible placement allowing sensors to be mounted wherever needed
without the complexity of moving or installing new wiring.
SPECIFICATIONS & FEATURES
• Zero Power Consumption: Solar power provides the energy to keep the device on and sensor technology turns the lights
off, eliminating additional expenses to the end user’s energy bill
• Zero External Power Required: With no power wire limitations, this enables the installer to place the sensor in the optimal
location of any application to capture minor motion and reduce false OFFs
• No Additional Wiring: Self-powered wireless technology eliminates the need to pull additional wire making installation
quick and easy and increasing labor savings with little to no impact to business during conversion
• Advanced Field-of-View: Superior detection for parallel and perpendicular motion; innovative technology detects motion
moving directly towards the sensor; 360° rotation to fine tune location of solar cells and field-of-view for the most accurate
sensing possible
Ideal Uses
• Retrofits, new construction, restrooms, conference rooms, classrooms, private and executive offices and retail spaces
TESTING & CODE COMPLIANCE
• CEC Title 24 Compliant
• FCC Certified for wireless communication
• Backed by a limited five-year warranty
COMMERCIAL GRADE
DESCRIPTION
CAT. NO.
COVERAGE
COLOR
LevNet RF Low Profile Self-Powered PIR Occupancy Sensor
WSC04-IRW
360°, 450SF
White
LevNet RF Low Profile Self-Powered PIR Occupancy Sensor
WSC15-IRW
360°, 1500SF
White
LevNet RF Self-Powered PIR Occupancy Sensor
WSC04-I0W
360°, 450SF
White
NOTE: For more information on LevNet RF, see the LevNet RF Energy Harvesting Wireless Solutions section (pages 59-68)
WSC15
WSC04
Field of View (in feet)
Field of View (in feet)
TOP VIEW
12
TOP VIEW
20
5
10
0
0
5
10
12
20
Minor Motion
Major Motion
SIDE VIEW
8
SIDE VIEW
8
0
20
36
15 11 9 5.6 3 0 3 5.6 9 11 15
20
12
9
7
5
3
0
3
5
7
9
12
S
Manual override turns lights on at any time regardless of override setting
X
X
X
X
X
X
X
X
X
X
Dual pushbuttons provide manual ON/OFF switching for 2 separate banks
from a single unit
Exclusive automatic “walk-through” sensing increases energy savings by
shutting lights within 2-1/2 minutes after momentary occupancy
Unit beeps to indicate load is going to be switched off automatically
X
X
Choice of “Conference Room” or “Classroom” modes for maximum
performance and energy savings in a variety of installations
Manual delayed-off-time settings: 10, 20, and 30 minutes, with 30-second
test mode
X
OSSMD-FT
S
OSSMD-GD
ODS0D-TD
S
OSSMD-MD
ODS0D-ID
X
OSSMT-GD
ODS15
Internal photocell prevents lights from turning on when there is ample
natural light (S = self adjusting)
commercial
OSSMT-MD
ODS10
SPECIFICATIONS & FEATURES
OSSNL
Convenient switch and occupancy sensor combo utilizes Decora® wallplates for sleek aesthetics. Advanced passive infrared
technology provides highly accurate monitoring in a variety of commercial and residential applications. The OSSMD and
OSSMT Multi-Tech unit combines passive infrared and ultrasonic technologies to provide maximum sensitivity with immunity
to false triggering.
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Manual delayed-off-time settings: 30 seconds, 30 minutes, 1 hour, 2 hours
X
10 minute delayed-OFF on 2nd relay
X
Three-position service switch with off, auto, on
X
X
X
Single-pole and 3-way wiring
X
X
X
X
X
Elegant Decora wallplates complement any interior for sleek aesthetics
X
X
X
X
X
X
X
X
X
X
Fits in standard wallbox; units may be ganged
X
X
X
X
X
X
X
X
X
X
Neutral Wire not required for retrofit installations
X
X
X
X
X
Night Light mode or “Guide Light” feature
X
Night Light dim feature
X
X
Patented adjustable integral blinders with 180° to 32° field-of-view
X
X
X
X
X
X
X
X
X
Vandal resistant
X
X
X
X
X
X
X
X
X
X
X
Manual ON/Auto OFF operation for CEC Title 24 compliance
X
X
X
X
X
X
X
X
X
OCCUPANCY SENSING CONTROL | WALL SWITCH
DECORA® WALL SWITCH OCCUPANCY SENSORS
Ideal UseS
ODS10-ID — Enclosed areas: small offices, conference rooms, storage rooms, copy rooms, closets
ODS15-ID — Commercial areas: small offices, conference rooms, classrooms, stockrooms, lounges, restrooms, warehouses
ODS0D-ID/ODS0D-TD — Classrooms, multimedia and conference rooms, day care centers, office, lounges
OSSNL — Hotel restrooms, hospital restrooms, conference rooms, class rooms, small offices, lounges, storage areas, and
bathrooms
OSSMD — Bi-level offices, partitioned areas, bathrooms
OSSMT — Private and executive offices, conference rooms, storage areas, restrooms, classrooms, lounges, and training areas
TESTING & CODE COMPLIANCE
• UL and cUL Listed (ODS10, ODS15, ODS0D-ID, ODS0D-TD, OSSNL and OSSMT-MD)
• ETL and cETL Listed to UL 508 and CSA C22.2 No. 14 (OSSMT-GD, OSSMD-MD, OSSMD-GD, and OSSMD-FT)
• CEC Title 24 compliant (ODSXX-, and OSSMX models) and meets ASHRAE Standard 90.1 requirements
• Backed by a Limited Five-Year Warranty
www.leviton.com/les
37
Vandal resistant
Fresnel lens for
optimal field
of view
Time, range
and light adjustments
Photocell detects light
to enable energy-saving
ambient light override
ODS10-ID shown
Ground clip to ensure
solid connection
Push button
for manual on/off
RESIDENTIAL
PR180
SPECIFICATIONS & FEATURES
PR150
LED indicator
flashes when sensor
detects motion
X
X
X
X
X
X
Ambient light override prevents lights from turning on when there is ample natural light (S = self adjusting)
True 3-way occupancy sensing when used with IPP0R X
Manual override turns lights on at any time regardless of override setting
Manual delayed-off-time settings: 10, 20, and 30 minutes, with 30-second test mode
Manual delayed-off-time settings: 15 seconds to 15 minutes
X
X
Single-pole and 3-way wiring*
X
Elegant Decora wallplates complement any interior
for sleek aesthetics
X
X
X
Fits in standard wallbox; units may be ganged
X
X
X
Patented adjustable integral blinders with
180° to 32° field-of-view
X
Vandal resistant
X
Manual ON/Auto OFF operation for CEC Title 24 compliance X
*When used with IPP0R or Vizia +® Remote.
38
Patented adjustable
blinders block
peripheral signals
IPP15
OCCUPANCY SENSING CONTROL | WALL SWITCH
Exclusive dual PIR sensors
detect IR signal
IDEAL USES
IPP15 — Kitchen, bathrooms, laundry rooms and
garages or any odd shaped or large room when
used with IPP0R
PR150-1L — Wide variety of residential applications
PR180-1L — Large rooms, home offices, and a variety
of light commercial and residential applications
TESTING & CODE COMPLIANCE
• UL Listed
• CSA Certified
• CEC Title 24 compliant (IPP15 models) and meets
ASHRAE Standard 90.1 requirements
• Backed by a Limited Five-Year Warranty
Commercial Grade+
DESCRIPTION CAT. NO. RATING COVERAGE COLOR*
Decora Wall Switch PIR Occupancy Sensor
ods10-id
Incandescent: 800W @ 120V. Fluorescent: 1200VA @ 120V,
180°, 2100SF
2700VA @ 277V. For 60Hz AC only. Motor: 1/4HP @ 120V
W, I, T,
G, E, R
Decora Wall Switch PIR Occupancy Sensor
ods15-id
with Self-Adaptive Technology
Incandescent: 1800W @ 120V. Fluorescent: 1800VA @ 120V, 180°, 2100SF
4000VA @ 277V. 50/60Hz. Motor: 1/4HP @ 120V
W, I, T,
G, E
Decora Dual-Relay Wall Switch PIR Occupancy ods0d-id
Sensor with Self-Adaptive Technology.
Default setting = Conference Room mode,
alternate setting = Classroom mode**
Primary Relay–Fluorescent: 1200VA @ 120V,
180°, 2100SF
2700VA @ 277V; Incandescent: 800W @ 120V.
Secondary Relay–Fluorescent: 800VA @ 120V,
1200VA @ 277V; Incandescent: 800W @ 120V. 50/60Hz.
W, I, T,
G, E, R
Decora Dual-Relay Wall Switch PIR Occupancy ods0d-td
Sensor with Self-Adaptive Technology.
Secondary relay provides manual ON only
for CEC Title 24 compliance
Primary Relay–Fluorescent: 1200VA @ 120V,
180°, 2100SF
2700VA @ 277V; Incandescent: 800W @ 120V.
Secondary Relay–Fluorescent: 800VA @ 120V,
1200VA @ 277V; Incandescent: 800W @ 120V. 50/60Hz.
W, I, T,
G, E
Decora Wall Switch PIR Occupancy Sensor
ossnl-id
with LED Night Light
Incandescent: 800W @ 120V. Fluorescent: 1200VA @ 120V,
180°, 2100 SF
2700VA @ 277V. Motor: 1/4 HP @ 120V
W, I, T,
G, E
Protective Cage for Wall Switch Sensors
oswwg-pow—
—
W
COVERAGE COLOR*
Residential Grade
DESCRIPTION CAT. NO. RATING Decora Manual-ON Vacancy Sensor, CEC
ipp15-1l
Title 24 Compliant. Single-Pole, 3-Way or more
when used with IPP0R Remote and/or Vizia +®
Remote Dimmers and Remote Switches
Incandescent: 1800W. @ 120V.
180°, 900SF
Fluorescent: 1800VA @ 120V.
Motor: 1/4HP @ 120V
W, I, T, E
Decora Manual-ON Vacancy Sensor Remote. For use with IPP15 Sensor or Vizia +® Dimmers.
120VAC–No load rating. For use with IPP15 or Vizia +® Dimmers
180°, 900SF
W, I, T
Decora Wall Switch PIR Occupancy Sensor,
pr150-1l
Single-Pole
Incandescent: 500W. Fluorescent: 400VA rapid start
magnetic only @ 120VAC. Motor: 1⁄8HP @ 120VAC
150°, 350SF
W
Decora Wall Switch PIR Occupancy Sensor,
pr180-1l
Single-Pole, 3-Way
Incandescent: 500W. Fluorescent: 400VA rapid start
magnetic only @ 120VAC. Motor: 1⁄8HP @ 120VAC
180°, 400SF
W, I
ipp0r-1l
Decora Wall Switch Multi-TechNOLOGY Occupancy Sensors
Commercial Grade+
DESCRIPTION CAT. NO. RATING COVERAGE COLOR*
Decora Wall Switch Multi-Technology Occupancy ossmt-md
Sensor with Self-adaptive Technology
Incandescent/Tungsten: 800W @ 120V. Fluorescent:
180°, 2400 SF 1200VA @ 120V, 2700VA @ 277V. Motor: 1/4HP @ 120V
W, I, T,
G, E, R
Decora Wall Switch Multi-Technology Occupancy ossmt-gd
Sensor. No neutral wire required for installation. Incandescent/Tungsten: 800W @ 120V. Fluorescent:
180°, 2400SF
1200VA @ 120V, 2700VA @ 277V. Motor: 1/4HP @ 120V
W, I, T, G, E, R
Decora Dual-Relay Wall Switch Multi-Technology ossmd-md
Occupancy Sensor
Primary Relay: Fluorescent: 1200VA @ 120V, 2700VA @ 277V.
180°, 2400SF
Incandescent: 800W @ 120V. Secondary Relay–Fluorescent:
800VA @ 120V, 1200VA @ 277V; Incandescent: 800W @ 120V.
Motor: 1/4HP @ 120V
W, I, T,
G, E
Decora Dual-Relay Wall Switch Multi-Technology ossmd-gd
Occupancy Sensor. No neutral wire required
for installation.
Primary Relay: Fluorescent: 1200VA @ 120V, 2700VA @ 277V.
180°, 2400SF
Incandescent: 800W @ 120V. Secondary Relay–Fluorescent:
800VA @ 120V, 1200VA @ 277V; Incandescent: 800W @ 120V
Motor: 1/4HP @ 120V
W, I, T,
G, E
Decora Dual-Relay Wall Switch Multi-Technology ossmd-ft
Occupancy Sensor. 10 minute delayed-OFF on
2nd relay.
Primary Relay: Fluorescent: 1200VA @ 120V, 2700VA @ 277V.
180°, 2400SF
Incandescent: 800W @ 120V. Secondary Relay–Fluorescent: 800VA @ 120V, 1200VA @ 277V; Incandescent: 800W @ 120V
Motor: 1/4HP @ 120Vc
W, I, T,
G, E
Protective Cage for Wall Switch Sensors
oswwg-pow—
—
OCCUPANCY SENSING CONTROL | WALL SWITCH
DECORA Wall Switch INFRARED Vacancy and OCCUPANCY SENSORS
W
* Add to end of catalog number suffix for color of switch: White (W), Ivory (I), Light Almond (T), Gray (G), Ebony (E) and Red (R) available on select models.
Wallplates sold separately.
** In Conference Room Mode, both primary and secondary relays respond to ambient light override. In Classroom Mode, primary relay responds only to ambient
light override.
Note: See Pages 54-55 for wiring diagrams, Page 40 for dimensioned photos and Page 41 for Field of View
+ Consult with factory for 208, 220, 230, and 240V models.
www.leviton.com/les
39
OCCUPANCY SENSING CONTROL | WALL SWITCH
DECORA Wall Switch Vacancy & OCCUPANCY SENSORS DIMENSIONS
2.60
(66.1)
4.06
(103.2)
2.66
(67.5)
4.11
(104.4)
ODS10-ID/ODS15-ID
OSSNL-ID
Shown with Night Light ON
ODS0D-ID/ODS0D-TD
1.35
(33.6)
1.35
(33.6)
2.66
(67.5)
1.75
(44.5)
1.75
(44.5)
OSSMT-MD/OSSMT-GD/OSSMD-FT
Multi-Tech Sensor
2.66
(67.5)
4.11
(104.4)
OSSMD-MD/OSSMD-GD
Multi-Tech Dual Relay Sensor
1.35
(34.3)
2.60
(66.1)
4.06
(103.2)
1.75
(44.4)
IPP15
40
PR150/PR180
2.66
(67.5)
4.11
(104.4)
1.75
(44.5)
1.75
(44.5)
1.75
(44.4)
4.11
(104.4)
1.35
(33.6)
1.35
(33.6)
1.35
(34.3)
TOP VIEW
30
40
TOP VIEW
20
TOP VIEW
30
30
15
0
15
0
0
20
15
30
15
5
4
0
30
SIDE VIEW
30
0
Major Motion, IR
20
40
Minor Motion, IR
40
SIDE VIEW
5
4
0
Major Motion, PIR
Major Motion, U/S
5
4
Major Motion, PIR
Major Motion, U/S
0
SIDE VIEW
15
0
0
15
40
OSSXX-ID/ODSXX-ID/ODS0D-TD
ODSXX-ID
Field of View (in feet)
30
IPP15 Field of View (in feet)
Minor Motion= Dual Technology coverage. This also represents the
maximum ultrasonic range coverage.
OSSMD/OSSMT Field of View (in feet)
TOP VIEW
TOP VIEW
10
10
10'
8'
6'
4'
2'
0'
2'
4'
6'
TOP VIEW
8'
10'
8'
6'
4'
2'
0
0
0'
2'
4'
6'
10
10
8'
SIDE VIEW
10'
0'
2'
SIDE VIEW
SIDE VIEW
4'
5
4
5
4
6'
OCCUPANCY SENSING CONTROL | WALL SWITCH
DECORA Wall Switch Vacancy & OCCUPANCY SENSOR FIELDS OF VIEW
8'
0
0
0
0
20
PR150-1L Field of View (in feet)
OSF10 Field of View
(in feet)
20
PR180-1L Field of View (in feet)
PR180-1L
PR150-1L
TOP VIEW
TOP VIEW
TOP VIEW
30
30
30
20
20
20
10
10
10
0
0
0
10
10
10
20
20
20
30
30
30
SIDE VIEW
0
20
S
H
E
L
V
E
S
20
15
30
40
SIDE VIEW
0
SIDE VIEW
0
30
20
30
30
20
10
0
10
360° High-Bay
(White lens)
20
20
10
0
10
20
30
360° Low-Bay
(blue lens)
OSFHU Field of View (in feet)
30
40
30
20
S
H
E
L
V
E
S
10
0
10
20
30
Aisle
(black lens)
www.leviton.com/les
41
OCCUPANCY SENSING CONTROL | LINE VOLTAGE
SELF-CONTAINED OCCUPANCY SENSORS
SPECIFICATIONS & FEATURES
• Sensor and switching relay combined in a single, self-contained unit—no control unit (power
pack) required
• Ambient light override option prevents lights from turning on when there is ample natural light
• ODC and ODW Power Base Combo Sensors combine sensors with the OPB15 Power Base
Adaptor to convert low voltage sensors into self-contained line voltage sensors for immediate
energy savings
2.15
(54.6)
• Adjustable delayed-OFF-time settings from 20 seconds (for test mode) to 15 minutes
• Small, unobtrusive self-contained unit
4.30
(109.2)
Ideal Uses
• Storage areas, small bathrooms, copy rooms, and a variety of small spaces without wall
switches
TESTING & CODE COMPLIANCE
ODC0S-I1W
• UL/cUL Listed
• CEC Title 24 compliant and meets ASHRAE Standard 90.1 requirements
• Backed by a Limited Five-Year Warranty
SELF-CONTAINED INFRARED CEILING MOUNT OCCUPANCY SENSORS
Field of View (in feet)
Commercial Grade
DESCRIPTION
CAT NO.
RATING
COVERAGE
COLOR
Self-Contained Ceiling Mount
PIR Occupancy Sensor and
Switching Relay, 120V
odc0s-i1w
Incandescent: 1000W
@120V. Fluorescent:
1000VA @ 120V.
Motor: 1HP @ 120V.
For 60Hz AC only
360°, 530SF*
White
Self-Contained Ceiling Mount
PIR Occupancy Sensor and
Switching Relay, 220V
odc0s-i2w
Incandescent: 1000W
@220V. Fluorescent:
500VA @ 220V.
For 50Hz AC only
360°, 530SF*
White
Self-Contained Ceiling Mount
PIR Occupancy Sensor and
Switching Relay, 277V
odc0s-i7w
Fluorescent: 2700VA
@277V. For 60Hz AC
only
360°, 530SF*
Protective Cage for
Ceiling Mount Sensors
odccg-000
-
-
Protective Cage for Wall
Mount Sensors
OSWCG-P0W
TOP VIEW
13
0
13
*When surface mounted on standard, 8-foot ceiling. Note: See Page 56 for wiring diagrams.
White
SIDE VIEW
8
0
13
7
3
0
3
7
ODC0S-I Field of View (in feet)
ODC0S
42
13
OCCUPANCY SENSING CONTROL | LINE VOLTAGE
LINE VOLTAGE SENSORS
Low Voltage Sensors with OPB15 Power Base Adaptor Combos
TESTING & CODE COMPLIANCE
• UL/cUL Listed
• CEC Title 24 compliant and meets ASHRAE Standard 90.1 requirements
• Backed by a Limited Five-Year Warranty
COMMERCIAL GRADE
DESCRIPTION
CAT NO.
RATING
Ceiling Mount MultiTechnology Occupancy
Sensor with Power Base
Combo
ODC05-MDW
ODC10-MDW
ODC20-MDW
15A, 120V Incandescent; 15A,
500SF
277V Fluorescent ballast; Motor: 1000SF
120V @ 3/4HP, 277V @ 2HP
2000SF
—
ODW12-MDW
Wall Mount MultiTechnology Sensor with
Power Base Combo
1200SF
15A, 120V Incandescent; 15A,
277V Fluorescent ballast; Motor:
120V @ 3/4HP, 277V @ 2HP
—
Wall Mount Wide-View
PIR Sensor with Power
Base Combo
115°, 2500SF
15A, 120V Incandescent; 15A,
277V Fluorescent ballast; Motor:
120V @ 3/4HP, 277V @ 2HP
—
Wall Mount High Bay PIR ODWHB-IDW
Sensor with Power Base
Combo
15A, 120V Incandescent; 15A,
55ft., 7 ft side
277V Fluorescent ballast; Motor: @ 30 ft high
120V @ 3/4HP, 277V @ 2HP
—
Wall Mount Long Range
PIR Sensor with Power
Base Combo
ODWLR-IDW
100ft., 110° @
15A, 120V Incandescent; 15A,
277V Fluorescent ballast; Motor: 10ft. high
120V @ 3/4HP, 277V @ 2HP
—
Ceiling Mount PIR
Occupancy Sensor with
Power Base Combo
ODC04-IDW
15A, 120V Incandescent; 15A,
277V Fluorescent ballast; Motor:
120V @ 3/4HP, 277V @ 2HP
450SF
White
Ceiling Mount PIR
Occupancy Sensor with
Power Base Combo
ODC15-IDW
15A, 120V Incandescent; 15A,
277V Fluorescent ballast; Motor:
120V @ 3/4HP, 277V @ 2HP
1500SF
White
ODWWV-IDW
COVERAGE
COLOR
Ceiling Mount Ultrasonic ODC05-UDW
Occupancy Sensor with
Power Base Combo
15A, 120V Incandescent; 15A,
500SF
277V Fluorescent ballast; Motor:
120V @ 3/4HP, 277V @ 2HP
White
Ceiling Mount Ultrasonic ODC10-UDW
Occupancy Sensor with
Power Base Combo
15A, 120V Incandescent; 15A,
1000SF
277V Fluorescent ballast; Motor:
120V @ 3/4HP, 277V @ 2HP
White
Ceiling Mount Ultrasonic ODC20-UDW
Occupancy Sensor with
Power Base Combo
15A, 120V Incandescent; 15A,
2000SF
277V Fluorescent ballast; Motor:
120V @ 3/4HP, 277V @ 2HP
White
www.leviton.com/les
43
OCCUPANCY SENSING CONTROL | LINE VOLTAGE
Self-Contained infrared Fixture-Mount High Bay and integral luminaire
occupancy Sensors
SPECIFICATIONS & FEATURES
Infrared Fixture-Mount High Bay Occupancy Sensor
• Universal unit includes three interchangeable lenses for 360° high bay, 360° low bay, and aisle way patterns at no
additional cost
• Cold storage models for applications as low as -40° F and 480V models available in non-neutral versions
• Mounts directly to industrial-style fluorescent luminaires or electrical junction box
• Self-contained PIR sensor and relay turn individual fixtures ON/OFF based on occupancy
• Up to 40 ft mounting height and quick and easy installation with long 42” leads
• Relay uses zero-crossing circuitry for enhanced reliability and long-life operation
• Bright green LED status indicator blinks to signify that the sensor is functioning properly
OSFHU
• Delayed-OFF time adjustment from 30 sec to 20 min
• Offset Adaptor Accessory snaps into 1/2" knockout to position sensor below fixture body for improved
field of view with deep-body fixtures
Infrared Fixture Mount Integral Luminaire Occupancy Sensor
• Easy installation with longer 38” leads allows for easy connection to any ballast eliminating the need to
splice additional wiring
• Integrated photocell prevents lights from turning ON when room is illuminated by natural light for
maximum energy savings
• 8’ to 10’ mounting heights
• Adjustable Time Delay and Light Level dials located on sensor housing for easy access
OSFHS
Ideal Uses:
• OSFHU: Commercial facilities with high ceilings, including warehouses, manufacturing, cold storage, and others.
• OSF10: Task lighting, cabinet lighting, cubicles, small bathroom lighting.
TESTING & CODE COMPLIANCE
• UL/cUL Listed • CEC Title 24 compliant
• Backed by a Limited Five-Year Warranty
OSF10
Commercial Grade†
DESCRIPTION
CAT. NO.
RATING
COVERAGE
Fixture Mount High-Bay
PIR Sensor with Three
Interchangeable Lenses
for 360° High-Bay,
360°Low Bay and Aisle
Way Coverage
OSFHU-ITW (120-230-277-347V)
OSFHU-CTW (cold storage)
OSFHU-I4W (480V)
OSFHU-C4W (cold storage)
Fluorescent: 800VA @ 120V, 1200VA
@ 277V, 1500VA @ 347V, 2400VA
@ 480V (OSFHU-x4W models only).
50/60Hz. Motor: 1/4 HP @ 120V
360° high-bay lens - 2:1 spacing to mounting
height under 20 ft. and 1.5:1 spacing to mounting
height @ 40 ft 360° low-bay lens - 2:1 spacing to
mounting height @ 8 ft. to 20 ft. aisle lens - 40
ft. long by 20 ft. wide @ 40 ft.
Fixture Mount High-Bay
PIR Sensor with Three
Interchangeable Lenses
and Light Sensor, Low
Voltage
OSFHP-ILW (24V)
Input: 20mA, Output: 120mA, HVAC:
1A, 30VDC
360° high-bay lens - 2:1 spacing to mounting
height under 20 ft. and 1.5:1 spacing to mounting
height @ 40 ft. 360° low-bay lens - 2:1 spacing
to mounting height @ 8 ft. to 20 ft. aisle lens 40 ft. long by 20 ft. wide @ 40 ft.
Fixture Mount High-Bay
PIR Sensor with Three
Interchangeable Lenses
and Light Sensor
OSFHP-ITW (120-230-277-347V)
OSFHP-I4W (240-480V)
Dual Relay:
OSFHD-ITW (120-230-277-347V)
OSFHD-CTW (cold storage)
Fluorescent: 800VA @ 120V, 1000VA
@ 230VAC, 1200VA @ 277VAC,
1500VA @ 347VAC, 2000VA @
480VAC, 50/60Hz. Motor: 1/4 HP
@ 120V
360° high-bay lens - 2:1 spacing to mounting
height under 20 ft. and 1.5:1 spacing to mounting
height @ 40 ft. 360° low-bay lens - 2:1 spacing
to mounting height @ 8 ft. to 20 ft. aisle lens 40 ft. long by 20 ft. wide @ 40 ft.
Fixture Mount High-Bay
PIR Sensor with Three
Interchangeable Lenses
and Alternating Relay
OSFHD-IAW (120-230-277-347V)
OSFHD-CAW (cold storage)
Fluorescent: 800VA @ 120V, 1000VA
@ 230VAC, 1200VA @ 277VAC,
1500VA @ 347VAC, 2000VA @
480VAC, 50/60Hz. Motor: 1/4 HP
@ 120V
360° high-bay lens - 2:1 spacing to mounting
height under 20 ft. and 1.5:1 spacing to mounting
height @ 40 ft. 360° low-bay lens - 2:1 spacing
to mounting height @ 8 ft. to 20 ft. aisle lens 40 ft. long by 20 ft. wide @ 40 ft.
Fixture Mount
Integral Luminaire
PIR Occupancy Sensor
OSF10-I0W (120-230-277V)
OSF10-IUW 240VDC
OSF10-PPW (power pack)
(120-230-277V)
Incandescent: 598W @ 120V.
Fluorescent: 800VA @ 120 VAC,
1000VA @ 230VAC, 1200VA @
277VAC 50/60Hz.
360°, 1:1 spacing to mounting height up to 8’
OSFHS-ITW
800VA @ 120VAC Ballast1200VA @ 55ft., 7 ft side @ 30 ft high
277VAC Ballast1500VA @ 347VAC
Ballast; Motor: 120V @ 1/4 HP
Surface Mount PIR
High Bay Occupancy
Sensor
Lenses for High-Bay
Sensors
OSFLN-00W (High-Bay Lens)
OSFLN-00B (Low-Bay Lens)
OSFLN-00E (Aisle Lens)
Offset Adapter
Accessory for FixtureMount High-Bay
Occupancy Sensor
OSFOA-00W
OSFLO-ooW
Protective Cage for
High-Bay Sensors
OSFCG-00W
—
—
—
—
—
—
Agency Listings & Code Compliance: UL/cUL Listed and CEC Title 24 Compliant * Available in White only. Consult with factory for 208, 220, 230 and 240V models.
NOTE: See Page 56 for wiring diagrams.
44
These advanced motion sensors combine infrared and ultrasonic technology for highly accurate monitoring without false
triggers. All-digital self-adjusting technology provides "install and forget" solution for automatic lighting control. Available in
a variety of coverage patterns to suit many applications. Use with Leviton Power Pack.
1.55
(39.4)
SPECIFICATIONS & FEATURES
Functional
• Ultrasonic sensing for maximum sensitivity combined with passive infrared (PIR)
sensing to prevent false triggers from air conditioning and corridor activity
• Self-adjusting settings continuously analyze and adjust sensitivity, timer operation,
and air current compensation for reliable, long-term performance
4.20
(106.7)
• Isolated relay supports HVAC or other Class 2 low voltage signals
• Supports both 24VAC/VDC power supplies
• Ambient light override to prevent lights from turning on when there is ample natural light
• Manual delayed-off-time settings of 30 seconds to 30 minutes
• Self-adjusting delayed-off-time interval settings for 30 seconds to 30 minutes
OSC05-M0W
• Compensates for real-time occupancy patterns—preventing unnecessary on/off switching
• Non-volatile memory preserves all automatic and manual settings during power outages
1.55
(39.4)
Physical
• Small, unobtrusive unit blends in with any décor
• Fast, simple installation using 4 color-coded low-voltage wires and a single mounting post
• Compatible with Wiremold® surface raceways for mounting to hard ceilings
Ideal Uses
• Classrooms, office areas with cubicles, cafeterias, and public areas in commercial facilities
4.20
(106.7)
TESTING & CODE COMPLIANCE
• CUL/US, FCC and NOM Certified
• CEC Title 24 compliant and meets ASHRAE Standard 90.1 requirements
• Backed by a Limited Five-Year Warranty
OSC20-M0W
Commercial Grade
DESCRIPTION
CAT. NO.
OPERATING
FREQUENCY
COVERAGE
COLOR
Ceiling Mount Multi-Technology Occupancy Sensor
osc05-m0w
40kHz
180°, 500SF
Off-White
Ceiling Mount Multi-Technology Occupancy Sensor
osc10-m0w
40kHz
360°,1000SF
Off-White
Ceiling Mount Multi-Technology Occupancy Sensor
osc20-m0w
32kHz
360°, 2000SF
Off-White
Ceiling Mount Multi-Technology Occupancy Sensor with Isolated Relay
OSC05-RMW
40kHz
180°, 500SF
White
Ceiling Mount Multi-Technology Occupancy Sensor with Isolated Relay
OSC10-RMW
40kHz
360°, 1000SF
White
Ceiling Mount Multi-Technology Occupancy Sensor with Isolated Relay
OSC20-RMW
32kHz
360°, 2000SF
White
Power Base Adaptor
OPB15-0DW
-
-
Off-White
Cosmetic Adaptor
OPBCA-00W
-
-
Off-White
Protective Cage for Ceiling-Mount Sensors
odccg-000
—
—
Off-White
OCCUPANCY SENSING CONTROL | LOW VOLTAGE
MULTI-TECHNOLOGY CEILING-MOUNT OCCUPANCY SENSORS
NOTE: Use low-voltage wiring to connect sensors to OSPXX Power Pack.
See Page 50 for information on OSP Power Packs and Page 56 for wiring diagrams.
TOP VIEW
TOP VIEW
20
TOP VIEW
20
20
16
11.5
11.5
8.5
11.5
8.5
0
0
0
8.5
8.5
11.5
11.5
11.5
16
20
20
20
SIDE VIEW
8
SIDE VIEW
8
0
0
0
3 5.6
9 11
15
17
20
23
Minor Motion, IR
OSC05-M0W Field of View (in feet)
Minor Motion, IR
OCS05-M0W
Major Motion, IR
23
20
17
15
11 9
5.6 3
Minor Motion, IR
0
3 5.6
9 11
15
20
17
23
Major Motion, IR
32
OSC10-M0W Field of View (in feet)
OSC10-M0W
Major Motion, IR
Minor Motion, Ultrasonic
Minor Motion, Ultrasonic
Major Motion, Ultrasonic
Major Motion, Ultrasonic
SIDE VIEW
8
22.5
20
15
11 9 5.5 3
0
3 5.5 9 11
15
20
22.5
32
OSC20-M0W Field of View (in feet)
Minor Motion, Ultrasonic
Major Motion, Ultrasonic
OSC20-M0W
www.leviton.com/les
45
OCCUPANCY SENSING CONTROL | LOW VOLTAGE
ULTRASONIC CEILING-MOUNT OCCUPANCY SENSORS
1.34 (34.0)
Advanced ultrasonic sensing technology for highly accurate monitoring, including smallmotion detection. All-digital self-adjusting technology provides an "install and forget"
solution for automatic lighting control. Use with Leviton Power Pack.
SPECIFICATIONS & FEATURES
4.20
(106.7)
Functional
• Ultrasonic sensing for maximum range and sensitivity combined with accurate smallmotion detection
• Self-adjusting settings continuously analyze and adjust sensitivity, timer operation, and
air current compensation for reliable, long-term performance
OSC05-U0W
• Ambient light override to prevent lights from turning on when there is ample natural light
• Manual delayed-off-time settings of 30 seconds to 30 minutes
1.34 (34.0)
• Self-adjusting delayed-off time interval settings for 30 seconds to 30 minutes. Compensates for real-time occupancy patterns—preventing unnecessary on/off switching
• Non-volatile memory preserves all automatic and manual settings during power outages
Physical
• Small, unobtrusive unit blends in with any décor
4.20
(106.7)
• Fast, simple installation using 4 color-coded low-voltage wires and a single mounting post
• Compatible with Wiremold® surface raceways for mounting to hard ceilings
Ideal Uses
• Restrooms, office areas with cubicles, warehouse and storage facilities, cafeterias, and
public areas in commercial facilities
OSC20-U0W
TESTING & CODE COMPLIANCE
• CUL/US Certified
• Meets AHRAE Standard 90.1 requirements
• Backed by a Limited Five-Year Warranty
Commercial Grade
DESCRIPTION
Ultrasonic Ceiling Mount Occupancy Sensor
Ultrasonic Ceiling Mount Occupancy Sensor
Ultrasonic Ceiling Mount Occupancy Sensor
Power Base Adaptor
Ultrasonic Ceiling Mount Occupancy Sensor with Isolated Relay
Ultrasonic Ceiling Mount Occupancy Sensor with Isolated Relay
Ultrasonic Ceiling Mount Occupancy Sensor with Isolated Relay
Cosmetic Adaptor
Protective Cage for Ceiling-Mount Sensors
OPERATING
FREQUENCY
40kHz
40kHz
32kHz
40kHz
40kHz
32kHz
-
CAT. NO.
osc05-u0w
osc10-u0w
osc20-u0w
OPB15-0DW
OSC05-RUW
OSC10-RUW
OSC20-RUW
OPBCA-00W
odccg-000
COVERAGE
180°, 500SF
360º, 1000SF
360°, 2000SF
180º, 500SF
360º, 1000SF
360º, 2000SF
-
COLOR
Off-White
Off-White
Off-White
Off-White
White
White
White
Off-White
Off-White
NOTE: Use low-voltage wiring to connect sensors to OSPXX Power Pack.
See Page 50 for information on OSP Power Packs and Page 56 for wiring diagrams.
11.5
16
8.5
11.5
11.5
8.5
0
0
0
8.5
8.5
11.5
11.5
5
0
10
17
20
23
OSC05-U0W Field of View (in feet)
11.5
16
23
0
17
IR
Minor Motion, Ultrasonic
46
23
32
Minor Motion,
IR
OSC10-U0W
Field of View (in Major
feet) Motion, IR
OSC10-U0W
Major Motion,
OSC05-U0W
17
Minor Motion, IR
Major Motion, Ultrasonic
Minor Motion, Ultrasonic OSC20-U0W
Major Motion, Ultrasonic
22.5
0
22.5
OSC20-U0W Field of View (in feet)
32
1,55
(39.4)
SPECIFICATIONS & FEATURES
Functional
• Self-adjusting settings continuously analyze and adjust sensitivity, timer operation, and
long-term performance
• Isolated relay supports HVAC or other Class 2 low voltage signals
• Supports both 24VAC/VDC power supplies
• Ambient light override prevents lights from turning on when there is ample natural light
4.20
(106.7)
• Manual delayed-off-time settings of 30 seconds to 30 minutes
• Self-adjusting delayed-off-time interval settings for of 30 seconds to 30 minutes.
Compensates for real-time occupancy patterns—preventing unnecessary on/off switching
• Non-volatile memory preserves all automatic and manual settings during power outages
Physical
• Small, unobtrusive unit blends in with any décor
OSC04-I0W
• Fast, simple installation using 4 color-coded low-voltage wires and a single mounting post
• Compatible with Wiremold® surface raceways for mounting to hard ceilings
Ideal Uses
• Small offices, closets, open offices, and other areas in commercial facilities with unobstructed
view of the sensor
TESTING & CODE
• CUL/US Certified
• Meets ASHRAE Standard 90.1 requirements
• Backed by a Limited Five-Year Warranty
Commercial Grade
DESCRIPTION
CAT. NO.
COVERAGE
COLOR
Ceiling Mount PIR Occupancy Sensor
osc04-i0w
360°, 450SF
Off-White
Ceiling Mount PIR Occupancy Sensor
osc15-i0w
360°, 1500SF
Off-White
Ceiling Mount PIR Occupancy Sensor with Isolated Relay
OSC04-RIW
360°, 450SF
White
Ceiling Mount PIR Occupancy Sensor with Isolated Relay
OSC15-RIW
360°, 1500SF
White
Power Base Adaptor
OPB15-0DW
-
-
Cosmetic Adaptor
OPBCA-00W
-
-
Protective Cage for Ceiling-Mount Sensors
odccg-000
-
Off-White
OCCUPANCY SENSING CONTROL | LOW VOLTAGE
INFRARED CEILING-MOUNT OCCUPANCY SENSORS
NOTE: Use low-voltage wiring to connect sensors to OSPXX Power Pack.
See Page 50 for information on OSP Power Packs and Page 56 for wiring diagrams.
TOP VIEW
12
TOP VIEW
20
10
5
0
Minor Motion, IR
0
Major Motion, IR
Minor Motion, Ultrasonic
5
10
12
Major Motion, Ultrasonic
20
SIDE VIEW
8
SIDE VIEW
8
0
12
9
7
5
3
0
3
5
7
9
12
20
OSC04-I0W Field of View (in feet)
OSC04-I0W
15 11 9 5.6 3
0
3 5.6 9 11 15
20
OSC15-I0W Field of View (in feet)
OSC15-I0W
www.leviton.com/les
47
OCCUPANCY SENSING CONTROL | LOW VOLTAGE
MULTI-TECHNOLOGY WALL-MOUNT OCCUPANCY SENSORS
SPECIFICATIONS & FEATURES
• Ultrasonic sensing for maximum sensitivity combined with passive infrared (PIR) sensing
to prevent false triggers from air conditioning and corridor activity
• Isolated relay supports HVAC or other Class 2 low voltage signals
• Supports both 24VAC/VDC power supplies
OSW12-M0W
• Adjustable swivel neck rotates 80° vertically and 60° horizontally. Can be used for ceiling
or wall mounting
• Self-adjusting settings continuously analyze and adjust sensitivity, timer operation, and
air current compensation for reliable, long-term performance
• Ambient light override to prevent lights from turning on when there is ample natural light
• Manual delayed-off-time settings of 30 seconds to 30 minutes
• Self-adjusting delayed-off-time interval settings of 30 seconds to 30 minutes. Compensates for real-time occupancy patterns, preventing unnecessary on/off switching
• Non-volatile memory preserves all automatic and manual settings during power outages
• Fast, simple installation using 3 color-coded low-voltage wires and a single mounting post
OSW12-RMW
Ideal Uses
• Conference rooms, stairwells, high-ceiling rooms, open areas, storage rooms, and
classrooms—including corner mounting in a variety of applications
TESTING & CODE COMPLIANCE
Field of View (in feet)
• CUL/US Certified
• Meets ASHRAE Standard 90.1 requirements
TOP VIEW
58
• Backed by a Limited Five-Year Warranty
Commercial GradE
DESCRIPTION
CAT. NO.
OPERATING
FREQUENCY
COVERAGE
COLOR
Wall Mount
Multi-Technology
Occupancy Sensor
osw12-m0w
32kHz
115°, 1200SF
Off-White
Wall Mount
Multi-Technology
Occupancy Sensor
with Isolated Relay
OSW12-RMW
Power Base Adaptor
OPB15-0DW
-
-
-
Cosmetic Adaptor
OPBCA-00W
-
-
-
Protective Cage for
Wall-Mount Sensors
oswcg-p0w
-
-
Off-White
31
16
11.5
0
32kHz
115°, 1200SF
White
11.5
16
31
NOTE: Use low-voltage wiring to connect sensors to OSPXX Power Pack
See Page 50 for information on OSP Power Packs and Page 57 for wiring diagrams.
58
SIDE VIEW
8
0
0 3 8 15
23
31
32
68
OSW12-M0W Field of View (in feet)
OSW12-M0W
Minor Motion, IR
Major Motion, IR
Minor Motion, Ultrasonic
Major Motion, Ultrasonic
48
Advanced PIR technology for highly accurate monitoring. All-digital self-adjusting technology provides an "install and forget"
solution for automatic lighting control. Use with Leviton Power Pack.
SPECIFICATIONS & FEATURES
• Self-adjusting settings continuously analyze and adjust for optimum performance
• Isolated relay supports HVAC or other Class 2 low voltage signals
• Supports both 24VAC/VDC power supplies
• Adjustable swivel neck rotates 80° vertically and 60° horizontally. Can be used for ceiling
or wall mounting
OSWxx-I0W
• Ambient light override prevents lights from turning on when there is ample natural light
• Manual delayed-off-time settings of 30 seconds to 30 minutes
• Self-Adjusting delayed-off-time interval settings for 30 seconds to 30 minutes.
Compensates for real-time occupancy patterns—preventing unnecessary on/off switching
• Non-volatile memory preserves all automatic and manual settings during power outages
•Fast, simple installation using 3 color-coded low-voltage wires and a single mounting post
OSWHB-I0W
Ideal Uses
• OSWWV-I: conference rooms, stairwells, high-ceiling rooms, large open areas, parking garages,
storage rooms, and rooms with pendant fixtures. Also ideal for corner mounting
• OSWHB-I & OSWLR-I: monitoring long, narrow spaces such as warehouse aisles,
hallways, closets, and storage areas. Also ideal for corner mounting
TESTING & CODE COMPLIANCE
• CUL/US Certified • Meets ASHRAE Standard 90.1 requirements • Backed by a Limited Five-Year Warranty
commercial grade
DESCRIPTION
Wide-View Wall Mount PIR
Occupancy Sensor
High-Bay Wall Mount PIR
Occupancy Sensor
Long-Range Wall Mount PIR
Occupancy Sensor
Wide-View Wall Mount PIR
Occupancy Sensor with Isolated Relay
High Bay Wall Mount PIR Occupancy
Sensor with Isolated Relay
Long-Range Wall Mount PIR
Occupancy Sensor with Isolated Relay
Power Base Adaptor
Cosmetic Adaptor
Protective Cage for
Wall-Mount Sensors
Field of View (in feet)
CAT. NO.
oswwv-i0w
COVERAGE
115°, 2500SF
COLOR
Off-White
oswhb-i0w
55 ft., 7 ft. wide
@ 30 ft. high
100ft., 110º
@ 10ft. high
115°, 2500SF
Off-White
oswlr-i0w
OSWWV-RIW
OSWHB-RIW
55ft., 7ft wide
@ 30ft. high
100ft., 110°
@ 10ft. high
-
OSWLR-RIW
OPB15-0DW
OPBCA-00W
oswcg-P0W
TOP VIEW
58
29
Off-White
0
White
White
29
OCCUPANCY SENSING CONTROL | LOW VOLTAGE
INFRARED indoor WALL-MOUNT OCCUPANCY SENSORS
White
58
Off-White
Off-White
Off-White
SIDE VIEW
8
0
NOTE: Use low-voltage wiring to connect sensors to OSPXX Power Pack.
See Page 50 for information
on OSP
Power Packs and Page 57 for wiring diagrams.
Field of View
(in feet)
0 3 8 15
31
68
OSWWV Field of View (in feet)
TOP VIEW
Field of View (in feet)
16.6
TOP VIEW
OSWWV-I0W
3.5
0
0
3.5
16.6
Minor Motion, IR
Major Motion, IR
SIDE VIEW
10
SIDE VIEW
30
Minor Motion, Ultrasonic
Major Motion, Ultrasonic
0
0
14
42
71
100
0 3
OSWLR Field of View (in feet)
OSWHB-I0W
OSWLR-I0W
13
25
52
OSWHB Field of View (in feet)
www.leviton.com/les
49
OCCUPANCY SENSING CONTROL | Power Packs
OCCUPANCY SENSOR power packs
Power packs provide power for occupancy sensors as well as load switching circuitry. A Leviton Power Pack is required with
any low voltage occupancy sensor. Add-A-Relay units can be used to expand control capability.
SPECIFICATIONS & FEATURES
3.66
(93.0)
Power Pack
• For use with all OS Series occupancy sensors
2.35
• Power supply for OS Series occupancy sensors
(59.7)
• Auto-ON and manual-ON inputs for occupancy sensors (OSP20-RDH)
• Hold-ON and Hold-OFF capabilities (OSP20-RDH)
• Switches incandescent, magnetic and electronic fluorescent, magnetic
and electronic low voltage, and motor loads
• Compact size and light weight allows easy mounting through knockout
in junction box (from either inside or outside the box) with a simple
1.38
twist-on nut
(35.1)
OSP20-RD0
Add-A-Relay
1.655"
• Expands power pack load capacity by functioning as a supplementary relay
• Provides ability to switch loads in different voltage systems
• Compatible with electronic ballasts
• Same compact size and mounting features as Power Pack
• Zero-crossing switching circuitry for outstanding durability
Nipple Adapter
• Simplifies the connection of occupancy sensor to the low-voltage side of a power pack mounted inside a fluorescent
ballast cavity
• 1/2" conduit lock nut included
TESTING & CODE COMPLIANCE
• CUL/US, FCC and NOM Certified • Meets ASHRAE Standard 90.1 requirements • Backed by a Limited 5-Year Warranty
Commercial Grade
DESCRIPTION
CAT. NO.
POWER INPUT*
CONTROL INPUT
POWER SUPPLY OUTPUT
Power Pack
osp20-0d0
120-230-277VAC, 20A fluorescent/incandescent @ 120V, 20A
50/60Hz
fluor. @ 230-277V; 1HP @ 120V, 2HP @ 240V
5mA, 24VDC
150mA, 24VDC
Power Pack with
HVAC relay
osp20-rd0
120-230-277VAC, 20A fluorescent/incandescent @ 120V, 20A
50/60Hz
fluor. @ 277V; 1HP @ 120V, 2HP @ 240V;
HVAC: 0.5A @ 120VAC, 1A @ 30VDC
5mA, 24VDC
150mA, 24VDC
Power Pack with
HVAC relay
osp15-r30
347VAC, 60Hz
15A fluorescent @ 347V; 1HP @ 120V, 2HP @ 5mA, 24VDC
240V; HVAC: 0.5A @ 120VAC, 1A @ 30VDC
120mA, 24VDC
Add-A-Relay Unit with
HVAC relay
osa20-r00
—
15A incandescent @ 120V, HVAC: 0.5A @
125VAC, 1A @ 30VDC
5mA, 24VDC
—
5mA, 24VDC
225mA, 24VDC
Power Pack with HVAC osp20-rdh
Relay with Auto-ON and
Manual-ON Inputs for
Occupancy Sensors
RELAY RATING
120-230-277VAC, 20A incandescent @ 120V, 20A fluor. @
50/60Hz
120-230-277/347VAC; 1/2HP @ 120V, 2HP
@ 240-277V; HVAC: 0.5A @ 120VAC, 1A @
30VDC
* Consult with factory for 208, 220, and 240V models.
NOTE: See page 71 for Ordering Information on Low Voltage Switches for use with Power Packs
Power Pack Capacity Formula
Leviton power packs can be used to provide power to one or more occupancy sensors. Since current consumptions of
occupancy sensors may vary, the best way to ensure you order the correct number of power packs and add-a-relays is by
using this formula: # of sensor Model As
# of sensor Model Bs
X
X
consumption rating
consumption rating
+
Sensor A current
Sensor B current
Sensor
OSC04-I, OSC15-I, OSWHB-I, OSWLR-I, OSWWV-I
50
# of Add a Relays
X
+
<
- Power Supply Output
50mA
Current Consumption
10-15mA
OSC05-M, OSC05-U, OSW12-M
25mA
OSC10-M, OSC10-U
30mA
OSC20-M, OSC20-U
40mA
OSA20-R00 Add a Relay
50mA
• Patent-pending design converts Leviton low voltage ceiling sensors to line voltage
• Ideal for both existing buildings with limited access to low-voltage wiring and new
constructions with line-voltage circuiting only.
• Mounts easily in standard 2.125" deep x 4" octagon or 2.125" deep x 4" square electrical
box with a 2-gang mud ring; flying leads provide fast line voltage connections
• Two-piece terminal block provides fast, easy low-voltage connections to the sensor
Ø4.50
(114.3)
• Relay uses zero-crossing circuitry for enhanced reliability and long-life operation
Ideal Uses
• Lavatories, remodels in hard ceiling spaces, energy conservation retrofits and any
installation with limited access for low-voltage wiring.
1.75
(44.5)
OPB15-0DW
TESTING & CODE COMPLIANCE
• NOM Certified
Power Base Adaptor*
DESCRIPTION
CAT. NO.
power input/output
rating
COLOR
Converts select Leviton low-voltage ceiling Opb15-0DW
or wall mount occupancy sensor models to
a self-contained line voltage unit
Power Input: 120-230-277VAC, 50/60Hz Control Input: 24VDC, 5mA
15A
Power Output: 120VAC @ 15A incandescent; 277VAC @ 15A fluorescent;
Motor: 120VAC 3/4HP, 277VAC 2HP Control Output: 24VDC, 40mA
Off-White
Cosmetic Adaptor
—
Off-White
OPBCA-00W
—
Agency Listings & Code Compliance: NOM Certified.
* Available in Off-White only. Consult with factory for 208, 220, 230 and 240V models.
Note: See Page 57 for wiring diagrams.
NOTE: Coverts OSCxx-I, OSCxx-M and OSCxx-U. Does not convert OSCxx-R.
NEUTRAL (WHITE)
HOT (BLACK)
120-277V
LOAD
LOAD (BLUE)
OPB15 Power Base
Any Leviton Low-Voltage
Ceiling or Wall Mount Sensor
OPB15-0DW (Occupancy sensor not included)
OPB15-0DW Wiring Diagram
www.leviton.com/les
OCCUPANCY SENSING CONTROL | Power Base Adaptor
Self-Contained Power Base Adaptor
51
OCCUPANCY SENSING CONTROL | Outdoor
OUTDOOR MOTION SENSORS
9.16
(232.7)
Passive Infrared (PIR) outdoor motion sensors provide outstanding value in
security lighting, as well as convenience, safety and energy savings for a wide
range of commercial and residential applications.
5.36
(136.1)
SPECIFICATIONS & FEATURES
Professional Series
4.50
(114.3)
• Adjustable sensitivity and immunity to RFI signals reduces false triggers
2.43
(63.0)
• Ambient light override prevents lights from turning on when there is ample
natural light
• Surge suppression minimizes likelihood of damage due to electrical surges
• Temperature compensation feature ensures uniform performance in extreme
hot or cold weather and during temperature fluctuations
PS200
Residential Series
• Ideal for a wide range of residential settings including backyards, garages,
entranceways, porches, swimming pool areas, doorways, and private docks
Field of View (in feet)
Field of View (in feet)
TOP VIEW
• Adjustable sensitivity reduces false triggers
TOP VIEW
50
Both Series
50
1.838
(00.0)
• Sensor neck adjustment allows accurate monitoring: 110° vertical, 180°
horizontal, 110° rotational
• With or without with dual floodlight lampholder
• Adjustable delayed-off-time settings from 20 seconds (for test mode) to
15 minutes
• Provides automatic, test and continuous modes. Test mode simulates
automatic operation with short delayed-off-time for easy adjustments.
Continuous mode enables manual override for constant
­­
"lights on" operation
(when used with standard on/off switch)
0
0
50
50
Ideal Uses
SIDE VIEW
• A wide range of commercial/industrial settings including parking areas,
storage facilities, warehouses, loading docks, marina, garages, walkways,
campus grounds, and outbuildings
10
0
0
50
0
PS110
TESTING & CODE COMPLIANCE
SIDE VIEW
10
PS110/RS110
Field of View
(in feet)
50
0
PS200
PS200
Field of View
(in feet)
• UL and cUL Listed
• Meets ASHRAE Standard 90.1 requirements
• Backed by a Limited Five-Year Warranty
Commercial Grade
DESCRIPTION
CAT. NO.
RATING
COVERAGE
COLOR
Outdoor PIR Motion Sensor
ps200-10
Incandescent: 1000W @ 120V. For 60Hz AC only
200°
White
Outdoor PIR Motion Sensor with Dual Floodlight Lampholder
ps200-1f
Same as Above
200°
White
Outdoor PIR Motion Sensor
ps110-10
Same as Above
110°
White
Outdoor PIR Motion Sensor with Dual Floodlight Lampholder
ps110-1f
Same as Above
110°
White
Outdoor PIR Motion Sensor
ps200-70w
277VAC, 60Hz. 7.22 incandescent, 5A ballasts.
200°
White
Outdoor PIR Motion Sensor with Dual Floodlight Lampholder
ps200-7fw
277VAC, 60Hz. 7.22 incandescent, 5A ballasts.
200°
White
Outdoor PIR Motion Sensor
ps200-40w
220-240VAC, 50/60Hz. 10A incandescent, 5A ballasts.
200°
White
Outdoor PIR Motion Sensor withDual Floodlight Lampholder
ps200-4fw
220-240VAC, 50/60Hz. 10A incandescent, 5A ballasts.
200°
White
Outdoor PIR Motion Sensor
ps110-70w
277VAC, 60Hz. 7.22 incandescent, 5A ballasts.
110°
White
Outdoor PIR Motion Sensor with Dual Floodlight Lampholder
ps110-7fw
277VAC, 60Hz. 7.22 incandescent, 5A ballasts.
110°
White
Outdoor PIR Motion Sensor
ps110-40w
220-240VAC, 50/60Hz. 10A incandescent, 5A ballasts.
110°
White
Outdoor PIR Motion Sensor with Dual Floodlight Lampholder
ps110-4fw
220-240VAC, 50/60Hz. 10A incandescent, 5A ballasts.
110°
White
DESCRIPTION
CAT. NO.
RATING
COVERAGE
COLOR
Outdoor PIR Motion Sensor
rs110-10w
Incandescent: 500W @ 120V. For 60Hz AC only
110°
White
Outdoor PIR Motion Sensor with Dual Floodlight Lampholder
rs110-1fw
Incandescent: 500W @ 120V. For 60Hz AC only
110°
White
Residential Grade
52
Two Occupancy Sensors Controlling One Load
(manual override off)
IPP15 Wall Switch Occupancy Sensor Wiring Diagram
IPP15
Neutral
Rocker Switch
LOAD
WH
Hot (Black)
BK
Green
Ground
Line
Black
Blue
Blue
Black
Line
RD
Black
YL/RD
White
Green Ground
Line
60Hz
Use Terminal for 3-Way or 120VAC,
More Applications Only.
For Single-Pole Applications,
Do Not Remove This Label.
Load
Neutral (White)
Green Ground
Note: Ground must be connected
Occupancy Sensor and Dimmer Controlling One Load
(manual override off)
Neutral
White (if necessary) White
0 Line
Ballast
Blue Black
3-way IPP15 with IPP0R or VZ0SR Wiring Diagram
IPP0R/VZ0SR-1L Remote
Hot (Black)
WH
WH
BK
Black
Blue
IPP15
BK
Green
Ground
Any Dimmer
Line
120VAC, 60Hz
Green
Ground
RD
YL/RD
YL/RD
Black
Load
White
Green Ground
Green Ground
Note: Ground must be connected
Neutral (White)
PR150 Wall Switch Occupancy Sensor Wiring Diagram
PR180 Wall Switch Occupancy Sensor 3-Way
Wiring Diagram
PR150
Switch #1
PR180
Common
Terminal
(Black Screw)
Hot (Black) Black
Black
Load
White
Line
120VAC,
60Hz
Traveler B
Neutral (White)
Traveler
A
Yellow
Red
Load
Green
Ground
Green
Ground
White
Green
Ground
Hot (Black)
Black
Line
120VAC,
60Hz
Jumper
Black
Black
OCCUPANCY SENSING CONTROL | Wiring Diagrams
APPLICATIONS
Neutral (White)
www.leviton.com/les
53
ODS10/15 Wall Switch Occupancy Sensor Wiring
Diagram, Single Location Control†
ODS10/15
ODS10/15
Blue
Blue
Hot (Black)
Black
Black
Black
Blue
Hot (Black)
Black
Black
Line
120-230-277VAC,
60Hz
Load
Line
120-230-277VAC,
60Hz
Load
Green
Ground
Green
Ground
White
Neutral (White)
Neutral (White)
Note: Ground must be connected
Note: Ground must be connected
ODS0D Wall Switch Occupancy Sensor Wiring Diagram
(For Single Pole, Single Phase Application)†
ODS0D Wall Switch Occupancy Sensor Wiring Diagram
(For Single Pole, Two Phase Applications†)
ODS0D
Hot (Black)
Phase 1
ODS0D
Red (To Phase 2)
Red
Black
Red
Hot (Black)
Phase 1
Red
Black
Blue
Line
120-230-277VAC,
60Hz
Blue
Primary
Load
Green
Ground
Secondary
Load
Line 1
120-230-277VAC,
60Hz
Green
Ground
Neutral 1 (White)
Neutral (White)
Neutral 2
Note: Ground must be connected
Note: Ground must be connected
OSSNL/10 Wall Switch Occupancy Sensor Wiring
Diagram, Single Location Control†
Blue
Black (Hot)
Line
120-230-277VAC, 60Hz
White
Green
Ground
OSSNL/OSS10
Black
Black
White
Load
Green
Ground
Neutral (White)
† Consult with factory for 208, 220, 230, and 240V models.
54
ODS10/15 Wall Switch Occupancy Sensor Wiring
Diagram, Two-Location Control†
Line 2
OCCUPANCY SENSING CONTROL | WIRING DIAGRAMS
Wall Switch Occupancy Sensors
White
Primary
Load
Secondary
Load
OSSMD-GD Wall Switch Occupancy Sensor Wiring
Diagram, Single Location Control†
OSSMD-FT Wall Switch Occupancy Sensor Wiring
Diagram, Single Location Control†
OSSMT-MD Wall Switch Occupancy Sensor Wiring
Diagram, Single Location Control†
OSSMT-GD Wall Switch Occupancy Sensor Wiring
Diagram, Single Location Control†
OCCUPANCY SENSING CONTROL | Wiring Diagrams
OSSMD-MD Wall Switch Occupancy Sensor Wiring
Diagram, Single Location Control†
† Consult with factory for 208, 220, 230, and 240V models.
www.leviton.com/les
55
OSFHU-ITW Occupancy Sensor Wiring Diagram†
OSF10 Occupacy Sensor Wiring Diagram†
Red
Hot (Black)
OSF10
Black
Hot (Black)
Red
Line
120-230-347VAC,
50/60Hz
Black
Sensor
Load
White
Neutral (White)
White
Integral to Fixture
Neutral (White)
OSFHU-I4W Occupancy Sensor Wiring Diagram†
ODC0S-I1 Ceiling Mount Occupancy Sensor
Wiring Diagram
Wiring Diagram
Hot (Black)
Red
Hot (Black)
Black
Red
Load
Blue
Blue
Black
Line
480VAC,
50/60Hz
Red
Sensor
Sensor
White
Line 120VAC, 60Hz
Load
White
Hot (Black)
Neutral (White)
ODC0S-I2 Ceiling Mount Occupancy Sensor,
Single-Location Wiring Diagram
ODC0S-I2 Ceiling Mount Occupancy Sensor,
Two-Location Wiring Diagram
Blue
Black
Blue
Black
Line
220/230/240VAC
50/60Hz
Load
Black
Load
Sensor
Neutral (White)
Neutral (White)
OS-Series Ceiling Mount Occupancy Sensor
(with Power Pack) Wiring Diagram
Hot (Black)
OSPxx Series
Power Pack
Sensor
Black
NC-Brown
Common-Green
NO-Brown/White
To HVAC System
Blue
Red (24VDC)
Blue
(control)
Gray*
Load
(photocell
+ occupancy)
White
Neutral (White)
Hot
Black
Blue
Blue
Black
Neutral (White)
Blue* (occupancy)
Gray*
(photocell
+ occupancy)
Load
White
120-230-277/347VAC
60Hz
Red
Black
White
† Consult with factory for 208, 220, 230, and 240V models.
Red
Black
Blue* (occupancy)
Black
Sensor
Black
Blue
Black
White
Line 277VAC, 60Hz
Blue
White
White
Sensor
Blue
Blue
Line
220/230/240VAC
50Hz
Blue
Black
Hot (Black)
Black
Hot (Black)
ODC0S-I7 Ceiling Mount Occupancy Sensor
Wiring Diagram
56
Load
White
Line
120-230-347VAC
50/60Hz
White
OCCUPANCY SENSING CONTROL | WIRING DIAGRAMS
fixture-mount high bay and ceiling mount occupancy sensors
OSWxx Occupancy Sensor Wiring Diagram with Single
Power Pack†
OSPxx Series
Power Pack
OSWxx Occupancy Sensor Wiring Diagram with Multiple
Power Packs†
OSPxx Series
Power Pack
Sensor
Sensor
NC-Brown
Common-Green To HVAC
System
NO-Brown/White
NC-Brown
Common-Green
NO-Brown/White
Red (24VDC)
Red (24VDC)
Black
Black
Blue
(Control)
Black
To HVAC
System
Blue
(Control)
Red
Black
Red
Black
Black
Blue*
Blue*
(occupancy)
Hot (Black)
(occupancy)
Gray*
Blue
Load
(photocell +
occupancy)
Blue
Hot (Black)
Red
Black
Gray*
Blue
Blue
Black
Red
Black
Line
120-230-277VAC
60Hz
White
Blue*
White
(occupancy)
Gray*
Line
120-230-277VAC
60Hz
Load
(photocell +
occupancy)
Black
White
White
Blue*
(occupancy)
Gray*
(photocell +
occupancy)
(photocell +
occupancy)
Neutral (White)
Neutral (White)
NC-Brown
Common-Green
NO-Brown/White
To HVAC
System
OSPxx Series
Power Pack
Hot (Black)
OSWxx Occupancy Sensor Wiring Diagram with Power
Pack and Add-A-Relay†
OSPxx Series
Power Pack
Line
120-230-277VAC
60Hz
Blue
Blue
Black
Black
White
Load
Neutral (White)
White
Sensor
NC-Brown
Common-Green
NO-Brown/White
Red (24VDC)
To HVAC
System
Black
Blue
(Control)
Black
Red
Black
Blue*
(occupancy)
Gray*
Blue
Hot (Black)
Blue
OPB15-0DW Power Base Adaptor
Red
Black
Line
120-230-277VAC
60Hz
Load
(photocell +
occupancy)
Black
White
White
Blue*
OCCUPANCY SENSING CONTROL | WIRING DIAGRAMS
Wall-Mount Occupancy Sensors
(occupancy)
Gray*
(photocell +
occupancy)
NC-Brown
Common-Green
NO-Brown/White
Hot (Black)
120-230-277VAC
To HVAC
System
Blue
Load (Blue)
OPB15 Power Base
OSA20
Add-A-Relay
Hot (Black)
Load
Neutral (White)
Neutral (White)
Any Leviton Low-Voltage
Ceiling Sensor
Blue
Line
120-230-277VAC
60Hz
Neutral (White)
Black
Load
White
† Consult with factory for 208, 220, 230, and 240V models.
*When the photocell function is not being used, connect the Blue Occupancy
Sensor lead to the Blue Power Pack lead. When using the Photocell function,
connect the Gray Occupancy Sensor lead to the Blue Power pack lead–Do not
use the Blue Occupancy Sensor lead for the photocell function.
www.leviton.com/les
57
58
www.leviton.com/les
59
ROOM CONTROL | LEVNET RF™
ROOM CONTROL | LEVNET RF™
LevNet RF is Leviton’s family of energy harvesting radio frequency products based on EnOcean’s technology.
EnOcean-based products, including the LevNet RF products, have three common features. They are:
• Energy harvesting technology
• Wireless (radio frequency)
• Interoperable within an RF-based network.
Energy harvesting technology allows LevNet RF Transmitters (i.e., occupancy sensors, switches, light sensors and hotel
key card switches) to operate indefinitely without external power or batteries. Self-powered Transmitters receive power
from the motion of a switch actuation, light on a solar cell or temperature differentials in the environment for a true zeromaintenance wireless device. Operating in the 315 mHz band provides minimal competing traffic and greater transmission
range than other wireless technologies. With no additional or new wiring required, LevNet RF delivers easy to install wireless
lighting controls with little to no interruption to a customer’s operations and without damage to the customer’s property.
PRODUCT OVERVIEW
There are three main types of LevNet RF Products: Transmitters, Receivers, and Transceivers (Transmitter – Receiver in
one). A fourth type of category might best be referred to as accessories.
A Transmitter, such as a switch, generates a wireless RF control signal (e.g., “ACTUATE RELAY”). All Transmitters are
self-powered completely wireless products which can be located anywhere and send transmission signals. Transmitters
are available in Occupancy Sensor, Light Sensor, Switch Leg, Vizia Style Remote Switch, Decora Rocker Switch Remote,
Handheld Remote, Hotel Key Card and 3x3 Remote Switch (International) varieties.
A Receiver receives a control signal from a Transmitter and performs the appropriate action (e.g., activate or deactivate
the relay). All Receivers are connected to a power source and a load which the Receiver then operates when the RF signal
is received. Receivers are available in Basic and Advanced Wall Switch, 3- and 5 Wire Relay, Plug-In and Thermostat styles.
A Transceiver acts as both a Transmitter (when it is generating an RF signal) and as a Receiver (when it receives and
processes an RF signal generated by a Transmitter). The Transceiver can also be used as a repeater where it utilizes the
Receiver and then re-transmits the RF signal. Leviton offers room, shade, dimmer and 4- and 8- Channel Relay Controllers.
Accessories available for LevNet RF products include RS-232 Serial Box, Signal Strength Meter, Power Packs and Industrial
Wireless Relay.
FEATURES
• Easy to install for new construction and retrofitting applications, requiring minimal labor or disruption to operations
• Requires no new wiring and installs in ¼ the time of hardwired sensors, translating into faster turnaround and reduced costs
• With no batteries to replace and no maintenance to perform, plus annual energy savings and rebates that can total up to
80% in reduced costs, LevNet RF revolutionizes efficiency and savings
• Lowest power consumption of any RF device with less than one Watt per device used annually, saving approximately 70%
over other RF devices
• LevNet RF is the only energy harvesting wireless solution that fulfill LEED requirements to earn LEED points for both wireless
control and no battery.
Wired vs. Wireless Costs
60
* Installation time per device: 45-50 minutes for hardwire vs. 10-15 minutes for wireless devices
TIP: A good way to visualize your wireless system is to imagine that the “wires” connecting each device are invisible wires or “unique addresses.”
LEVNET RF
RECEIVERS
LOADS
LEVNET RF
TRANSMITTERS
Thermostat
HVAC Unit
Wireless
Occupancy Sensor
24V 5-Wire
Relay Receiver
Fan
Wireless Switches
Wireless
3 x 3 Switches
5-Wire
Relay Receiver
Lighting
4-Button
Handheld Remote
Plug-In ON/OFF
Relay Receiver
Plug-In ON/OFF
Relay Receiver
Television
ROOM CONTROL | LEVNET RF™
HOW TO PUT IT ALL TOGETHER
Wireless
Control
Signal
Up To
150 ft.
Hotel Key
Card Switch
STEP Determine what LOADS you want to control — lighting, HVAC, lamp, TV, etc.
1
STEP Pick the appropriate RF RECEIVER and/or TRANSCEIVER
2
LevNet RF Energy Harvesting Wired-In Receivers
Receives One Way Communication
LevNet RF Energy Harvesting Wired-In Transceivers
Receiver
Transmitter
Repeater
STEP Pick the appropriate Energy Harvesting RF Transmitter (sensor or switch)
3
LevNet RF Energy Harvesting Transmitters
One Way Communication
www.leviton.com/les
61
ROOM CONTROL | LEVNET RF™
LevNet RF Energy Harvesting Solutions
Frequency
315MHz
Range
50-150 feet
Listings
FCC Certified for Wireless Communication (U.S.), I.C. Certified (Canada)*
Warranty
Limited 5-year
*Excludes WSD02-020.
NAFTA and Made in USA models available - visit www.leviton.com/NAFTA or www.leviton.com/USA.
RECEIVERS and transceivers
WALL SWITCH RECEIVERS
BASIC WALL SWITCH
RECEIVERS
with Color Change Kit
WSS10-0DZ | WSS10-GDZ
Use for single loads and 3-way
switching. Condensed pairing
for WSC and WSS0S-P only.
Input Voltage
Power Consumption
120-230-277VAC
120V < 1/2 Watt; 277V < 3/4 Watt
Memory
Button Pairing Modes
ADVANCED WALL SWITCH
RECEIVERS
with Color Change Kit
WSS10-0UZ | WSS10-GUZ
Use for larger rooms with multiple loads.
Advanced pairing for rocker,
momentary and toggle.
Stores up to 10 Transmitter IDs
WSS0S-P, WSCxx
Rocker, Momentary and Toggle
Vacancy Confirmation
30 seconds
Mode
Presentation
Time Delay
2 min (test), 10, 20, 30 min
Load Rating
Incandescent: 800W @ 120V
Fluorescent Ballasts: 1200VA @ 120V, 2700VA @ 277V
Motor: 1/4 HP Load @ 120V
For non-neutral models: 25W minimum load required (reduce range by 15’)
Additional Listings
ETL/C-ETL: UL508, Title 24 Compliant
All WSS10 models ship with a Color Change Kit which includes a White, Ivory and Light Almond faceplate.
Gray and Ebony faceplates available in quantities of 25.
RELAY RECEIVER MODULES
5-Wire Relay Receivers
WST12-010
WST12-020
WST12-080
WST02-R10
Utilizes isolated relay
3-Wire Relay Receivers
WST05-010
WST05-020
WST05-080
Memory
Power Supply Input
Max Loads/Contact
Ratings
Output Channels
Time Delay
Additional Listings
Stores up to 30 Transmitter IDs
WST05-010: 120VAC, 50/60Hz
WST05-020: 277VAC, 50/60Hz
WST05-080: 240VAC, 50/60Hz
WST12-010: 120VAC, 50/60Hz
WST12-020: 277VAC, 50/60Hz
WST12-080: 240VAC, 50/60Hz
WST02-R10: 24VAC, 50/60Hz
Tungsten/Incandescent:
WST05-010: 500W
WST05-020: 1150W
WST05-080: 1000W
Fluorescent Ballast: 3A
General Duty: 6A
A300 Pilot Duty:
WST05-010: 120VA
WST05-020: 277VA
WST05-080: 240VA
Tungsten/Incandescent:
1500W @ 120VAC / 500W @ 120VAC;
3000W @ 240VAC / 1000W @ 240VAC;
3400W @ 277VAC / 1100W @ 277VAC
Fluorescent Ballast:
8A (N.O. Contacts); 2A (N.C. Contacts)
General Duty:
16A (N.O. Contacts); 5A (N.C Contacts)
A300 Pilot Duty:
72VA @ 24VAC, 360VA @ 120VAC,
720VA @ 240VAC, 830VA @ 277VAC
Motor Load:
60 LRA, 10 FLA, 1/2HP @ 120VAC,
1HP @ 240VAC, 1HP @ 277VAC
Other Devices: 16A
1 FORM A Relay
1 FORM C Relay COM, N.O., N.C.
15 min
ETL: UL244A and UL2043, C-ETL: CSAc22.2#14-05
For WSx02-R10: ETL: UL244A (pending), C-ETL: CSAc22.2#156 (pending)
WSTxx models: include ½” threaded nipple, external antenna, and repeater function
62
Plug-In Dimmer Receiver
WSG0S-D1T
Dimming control
of devices
Memory
Plug-In ON/OFF
Relay Receiver
WSG0S-S1T
Relay (on/off) control of devices
Stores up to 30 unique Transmitter IDs
Power Supply Input
120VAC, 60Hz
Dimmer Output
120VAC, 300W max (resistive)
incandescent or other dimmable
loads only – no motor loads
-
1 dimming or ON/OFF output
-
-
General: 6A
Ballast: 3A
Tungsten: 500W
Motor: no motor loads
Output Channels
Output Rating
Time Delay
15 min
Additional Listings
ETL: UL244A (pending), C-ETL: CSAc22.2#156 (pending)
ROOM CONTROLLERS AND RELAY RECEIVERS
Channels
2, 3, and 4-Channel
Room Controller
WS0RC-200
WS0RC-300
WS0RC-400
Unified control of lights
with power packs and low
voltage sensors
2-Channel
Shade Controller
WS0RC-S00
Enables manual and
automated control of
window shades
and blinds
4- and 8-Channel
Relay Receiver
WSPAS-LV4
WSPAS-LV8
Connects wireless
switches and sensors
to new or existing
industrial systems
WS0RC-200: 2-in/2-out
WS0RC-300: 1-in/3-out
WS0RC-400: 0-in/4-out
-
-
-
1 = up/down
2 = up/down
WSPAS-LV4:
4, Form C – N.O. and
N.C. Dry Contacts
WSPAS-LV8: 8, Form A –
N.O. Dry Contacts
8-30VDC, 40mA
8-30VDC, 40mA
8-28VAC or 8-30VDC,
250mA max
0-30VDC, 130mA max
0-30VDC, 130mA max
2A @ 30VAC/VDC
30VDC max, 100mA max
30VDC max, 100mA max
-
Field configurable
-
-
Output Channels
Power Supply Input
Output Rating
Relay Driver
Repeater
Time Delay
ROOM CONTROL | LEVNET RF™
PLUG-IN RECEIVERS
15 min
Power supply not included.
DIMMER MODULES
Memory
Power Supply Input
Rating
RF Constant
Voltage LED Dimmer
WSD02-010
Constant Voltage
LED Dimmer
WSD02-020
0-10V RF
Dimmer with ON/OFF
Control and
Sensor Input
WSD01-001
Stores up to 30
Transmitter IDs
-
Stores up to 30
Transmitter IDs
8-28VDC, 40mA (not incl. load current)
Sensor Input Rating
Output Rating
Output Rating, Switched
Output
Input Channels
Output Channels
Time Delay
12-28V, 40mA
0-28VDC, <1V is low, >3V is high
Constant Voltage 0-28VDC, 5A max
-
-
1 Motion Detector/Sensor Input;
1 Wired Control Switch
1 Output PWM Dimming
4mA, 0-10V Output
5A DC, Isolated, 30VDC
max
1 Motion Detector/
Sensor Input
1 Output 0-10V, 1 Switch Output
15 minutes
Power supply not included.
www.leviton.com/les
63
ROOM CONTROL | LEVNET RF™
TRANSMITTERS
SENSORS
OCCUPANCY SENSORS
WSC04-IRW | WSC15-IRW | WSC04-I0W
Power Consumption
LIGHT SENSORS
WSCPC-00W
Zero
Photocell
Transmission Interval
-
0-94.8FC (0-1020 LUX)
60 seconds (+/- 10 sec)
Upon >20FC (200 LUX) changes
Minimum Light Required
4FC (40 LUX)
Minimum Charge Time to Begin Operation
1 minute @ 20FC (200 LUX)
Maintain Charge Time
3 hours per 24 hours @ 20FC (200 LUX)
Operating Life at Full Charge
48 hours
Additional Listings
Title 24 Compliant
REMOTE SWITCHES Controls virtually any on/off device
Remote
Single Push
ON/OFF
Decora™
Switch*
WSS0S-P0x
Single/Dual
Rocker
Decora™ Switch*
WSS0S-D0x
WSS0S-D2x
Handheld 4-Button
Remote
WSS0S-R0W
Hotel
Key Card
Switch
WSS0S-H0W
3 x 3 Single/Dual
Rocker Switch
WSS0S-E0W
WSS0S-E0B
WSS0S-E2W
WSS0S-E2B
1 Button
WSS0S-D: 2 Buttons
(1 Rocker) WSS0S-D2:
4 Buttons (2 Rockers)
4 Buttons
(2 Rockers)
-
WSS0S-E: 2 Buttons
(1 Rocker) WSS0S-E2:
4 Buttons (2 Rockers)
-
-
-
1 (card IN, card OUT)
-
Buttons
Card Slot
Output Channels
Addressing
Only limited by number of Receivers in range
Factory set unique ID (1 of 4 billion)
* Available in White (-W), Ivory (-I), Light Almond (-T), Gray (-G) and Ebony (-E).
Thermostat WS0TH -S00
Adjusts temperature based on “occupied” and “unoccupied” signals
Input Voltage
24VAC
Load Rating
1.5A/circuit
Temperature Monitor Range
32°F to 99.9°F (0°C to 37.7°C)
Temperature Set Point Range
60°F to 85°F (15.5°C to 29.5°C)
Sampling Rule
Fan Control
Every 5 seconds
Selectable: Auto Cycle, Low, Medium, High, Economy, Off
Time Delay
5 sec to 15 min
Memory
Stores up to 30 Switch IDs
Heat/Cool Control
1 Heat and 1 Cool circuit
SLT TRANSMITTERS
Power Supply Input
SWITCH LEG Transmitter
WSSLT-010 | WSTLT-010 | WSSLT-R10
Replaces wires between an electrical load and a
switch with an RF control signal to control loads
4-Channel SLT Transmitter
WSSLT-GP0
Connects 4 GPIO signals from the HVAC
controller to control lighting
WSxLT-010: 120VAC, 50/60Hz
WSSLT-R10: 24VAC, 50/60Hz
8-28VDC, 40mA
Addressing
Additional Listings
Factory set unique ID (1 of 4 billion)
ETL: UL244A, C-ETL: CSAc22.2#14-05
–
RS-232 Serial Box Data Interface
WS0RF-300
Connects to any system that
uses an RS-232 serial port
Signal Strength Meter WSMET-010
Verifies whether the installation
of LevNet RF products are
possible at the positions planned
8-28VAC or 8-30VDC
-
ACCESSORIES
Power Supply Input
Current
Power Supply
Receiver Sensitivity
64
25mA @ 12VDC, 15mA @ 24VDC
-
Not included
9VDC battery
-
-95dBm
Channel Bandwidth
-
280kHz
RF Data Rate
-
120kbps
ROOM CONTROL | LEVNET RF™
BASIC LEVNET RF SOLUTIONS
Basic Lighting
OR
Wireless
Switches
Wireless
Control
Signal
Up To
150 ft.
Plug-In ON/OFF
Relay Receiver
3-Way or Multi-Location Switching
Wireless
Remote
Switch
Wireless
Control
Signal
Up To
150 ft.
Wall Switch
Receiver
Lighting
Daylight Harvesting with Bi-Level Control
3-Wire
Relay Receiver
Wireless
Dual Rocker
Switch
Lighting
Wireless
Light Sensor
Wireless
Control
Signal
Up To
150 ft.
3-Wire
Relay Receiver
Occupancy Sensor with Bi-Level Control
Wall Switch
Receiver
Wireless
Occupancy
Sensor
Lighting
Wireless
Control
Signal
Up To
150 ft.
Wall Switch
Receiver
Hospitality Application
Wall Switch
Receiver
Lighting
Hotel Key
Card Switch
Wireless
Control
Signal
Up To
150 ft.
HVAC Unit
Thermostat
www.leviton.com/les
65
ROOM CONTROL | LEVNET RF™
LevNet RF Energy Harvesting SOLUTIONS
ENERGY HARVESTING SENSORS (USE WITH WSS10-0DX, WSS10-GDX, OR WSS0S-P0X)
DESCRIPTION
CAT. NO.*
COVERAGE
COLOR
Low Profile Self-Powered PIR
Occupancy Sensor, 450SF
WSC04-IRW
360°, 450SF
W
Low Profile Self-Powered PIR
Occupancy Sensor, 1500SF
WSC15-IRW
360°, 1500SF
W
Self-Powered PIR
Occupancy Sensor, 450SF
WSC04-IOW
360°, 450SF
W
Self-Powered Light Sensor,
0-95 FC
WSCPC-00W
360°, 50-150SF
W
DESCRIPTION
CAT. NO.*
RATING
COLOR
Basic RF Wall Switch Receiver with
Color Change Kit (use with WSC
and WSS0S-P only)
WSS10-0DZ
Incandescent: 800 @ 120V, 2000W @ 277V
Fluorescent Ballasts: 1200VA @ 120V, 2700VA @ 277V.
Motor: 1/4 HP Load @ 120V
W, I, T, G, E
Basic RF Wall Switch Receiver, NonNeutral with Color Change Kit (use
with WSC and WSS0S-P only)
WSS10-GDZ
Incandescent: 800 @ 120V, 2000W @ 277V
Fluorescent Ballasts: 1200VA @ 120V, 2700VA @ 277V.
Motor: 1/4 HP Load @ 120V
Non-Neutral: 25W minimum load required (reduce range by 15’)
W, I, T, G, E
Advanced RF Wall Switch Receiver
with Color Change Kit (use with
WSC and WSS0S-P only)
WSS10-0UZ
Incandescent: 800 @ 120V, 2000W @ 277V
Fluorescent Ballasts: 1200VA @ 120V, 2700VA @ 277V.
Motor: 1/4 HP Load @ 120V
W, I, T, G, E
Advanced RF Wall Switch Receiver,
Non-Neutral with Color Change Kit
(use with WSC and WSS0S-P only)
WSS10-GUZ
Incandescent: 800 @ 120V, 2000W @ 277V
Fluorescent Ballasts: 1200VA @ 120V, 2700VA @ 277V.
Motor: 1/4 HP Load @ 120V
Non-Neutral: 25W minimum load required (reduce range by 15’)
W, I, T, G, E
WALL SWITCH RECEIVERS
Note: All WSS10 models ship with a Color Change Kit which includes a White, Ivory and Light Almond wall plate. Gray and Ebony wallplates
available in quantities of 25.
REMOTE SWITCHES
DESCRIPTION
CAT. NO. *
COLOR
Single Push ON/OFF Decora™ Remote Switch
wss0s-p0x
W, I, T, G, E
1-Gang Single Rocker Decora™ Switch
wss0s-d0x
W, I, T, G, E
1-Gang Dual Rocker Decora™ Switch
wss0s-d2x
W, I, T, G, E
Handheld 4-Button Remote
wss0s-r0w
W
Hotel Key Card Switch
wss0s-h0w
W
Thermostat, 4VAC
ws0th-s00
W
3 x 3 Single Switch
wss0s-e0x
W, E
3 x 3 Dual Switch
wss0s-e2x
W, E
RELAY RECEIVER MODULES
DESCRIPTION
CAT. NO. *
COLOR
3-Wire Relay Receiver, Threaded Mount, 120VAC, 500W
WST05-010
W
3-Wire Relay Receiver, Threaded Mount, 277VAC, 1200W
WST05-020
W
3-Wire Relay Receiver, Threaded Mount, 240VAC, 1000W
WST05-080
W
5-Wire Relay Receiver, Threaded Mount, 120VAC, 1500W
WST12-010
W
5-Wire Relay Receiver, Threaded Mount, 2770VAC, 3200W
WST12-020
W
5-Wire Relay Receiver, Threaded Mount, 240VAC, 3000W
WST12-080
W
5-Wire Relay Receiver, Threaded Mount, 24VAC, 300W
WST02-R10
W
PLUG-IN RECEIVERS
66
DESCRIPTION
CAT. NO. *
COLOR
Plug-In Dimmer Receiver
wsg0s-d1t
T
Plug-In ON/OFF Relay Receiver
wsg0s-s1t
T
ROOM CONTROL | LEVNET RF™
ROOM CONTROLLERS AND RELAY RECEIVERS
DESCRIPTION
CAT. NO. *
COLOR
2-Channel Room Controller, 2 Inputs/2 Outputs, 8-30VDC
ws0rc-200
W
3-Channel Room Controller, 1 Input/3 Outputs, 8-30VDC
ws0rc-300
W
4-Channel Room Controller, 0 Input/4 Outputs, 8-30VDC
ws0rc-400
W
2-Channel Shade Controller, 8-30VDC
ws0rc-s00
W
4-Channel Relay Receiver, 8-30VAC or 8-30VDC
wspas-lv4
W
8-Channel Relay Receiver, 8-30VAC or 8-30VDC
wspas-lv8
W
DIMMER MODULES
DESCRIPTION
CAT. NO.*
COLOR
RF Constant Voltage LED Dimmer
WSD02-010
W
Constant Voltage LED Dimmer
WSD02-020
W
010V RF Dimmer with ON/OFF Control and Sensor Input
WSD01-001
W
SLT TRANSMITTERS
DESCRIPTION
CAT. NO.*
COLOR
SLT Circuit Interlock Transmitter, 120VAC
wsslt-010
W
SLT Circuit Interlock Transmitter, 240VAC
wsslt-r10
W
4-Channel SLT Transmitter, 8-28VDC
wsslt-gp0
W
SLT Threaded Mount, 120 VAC
wstlt-010
W
ACCESSORIES
DESCRIPTION
CAT. NO. *
COLOR
RS-232 Serial Box Data Interface
ws0rf-300
W
Signal Strength Meter
wsmet-010
W
* Colors available as listed, add suffix to catalog number as follows: Ivory (-I), White (-W), Light Almond (-T),
Gray (-G), Ebony (-E).
www.leviton.com/les
67
WIRELESS ACCESSORIES
WSMET-010 - Signal Strength Meter
WS0RF-300 - RS-232 Data Interface
WSSLT-GP0 - 4-Channel SLT Transmitter
WSSLT-R10 - 240VAC Circuit Interlock Trans
WSTLT-010 - 120VAC Circuit Interlock Trans (Threaded)
WIRELESS TRANSMITTERS
WSSLT-010 - 120VAC Circuit Interlock Trans
WS0TH-S00 - Thermostat, 24VAC
WSPAS-LV8 - 8-Channel LV Relay Receiver
WSPAS-LV4 - 4-Channel LV Relay Receiver
WSD02-010 - Constant Voltage LED Dimmer w/o Wireless
WSD02-010 - Constant Voltage LED Dimmer w/ Wireless
WSD01-001 - 0-10V Dimmer Module
WS0RC-S00 - 2-Channel Shade Controller
WS0RC-400 - Room Controller, 0 Input/4 Outputs
WIRELESS LOW VOLTAGE RECEIVERS
WS0RC-300 - Room Controller, 1 Input/3 Outputs
WS0RC-200 - Room Controller, 2 Inputs/2 Outputs
WSG0S-S1T - Plug-In Relay
WIRELESS PLUG-IN RECEIVERS
WSG0S-D1T - Plug-In Dimmer
WST02-R10 - 24VAC 5-Wire Receiver (Threaded)
WST12-080 - 240VAC 5-Wire Receiver (Threaded)
WST12-020 - 277VAC 5-Wire Receiver (Threaded)
WST12-010 - 120VAC 5-Wire Receiver (Threaded)
WST05-080 - 240VAC 3-Wire Receiver (Threaded)
WST05-020 - 277VAC 3-Wire Receiver (Threaded)
WIRELESS LINE VOLTAGE RECEIVERS
WST05-010 - 120VAC 3-Wire Receiver (Threaded)
WSS0S-H0w - Hotel Key Card Switch
WSS0S-E2x - 3 x 3 Dual Switch
WSS0S-E0x - 3 x 3 Single Switch
WSS0S-R0w - Handheld 4-Button Remote
WSS0S-D2x - Dual Rocker Switch
WSS0S-D0x - Single Rocker Switch
WIRELESS REMOTE SWITCHES
WSS0S-P0x - Single Button Remote Switch
WSS10-GUX - Wall Switch Receiver NN (Advanced)
WSS10-GDX - Wall Switch Receiver NN (Basic)
WSS10-0UX - Wall Switch Receiver (Advanced)
WIRELESS RECEIVER SWITCHES
WSS10-0DX - Wall Switch Receiver (Basic)
WSCPC-00W - Self Powered Light Sensor
WSC15-IRW - 1500SF New Occ. Sensor
WSC04-IRW - 450SF New Occ. Sensor
PART NUMBER
- DESCRIPTION
WSC15-I0W - 1500SF Occ. Sensor
PRODUCT
COMPATIBILITY
MATRIX
WIRELESS OCC SNSRS AND LIGHT SENSOR
LEVNET RF
RF PRODUCT
COMPATIBILITY
LevNet
Self-Powered
Wireless MATRIX
Solutions
WSC04-I0W - 450SF Occ. Sensor
ROOM CONTROL | LEVNET RF™
PRODUCT COMPATIBILITY MATRIX
WIRELESS OCC SNSRS AND LIGHT SENSOR
WSC04-I0W
PIR Occupancy Sensor, 450SF
WSC15-I0W
PIR Occupancy Sensor, 1500SF
WSC04-IRW
New PIR Occupancy Sensor, 450SF
WSC15-IRW
New PIR Occupancy Sensor, 1500SF
WSCPC-00W
New Self Powered Light Sensor
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
WIRELESS RECEIVER SWITCHES
WSS10-0DX
Decora™ Wall Switch Receiver (Basic)
WSS10-0UX
Decora™ Wall Switch Receiver (Advanced)
WSS10-GDX
Decora™ Wall Switch Receiver, Non-Neutral (Basic)
WSS10-GUX
Decora™ Wall Switch Receiver, Non-Neutral (Advanced)
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
p
p
p
p
x
x
x
x
x
x
x
x
x
p
p
p
p
x
x
WIRELESS REMOTE SWITCHES
WSS0S-P0x
Single Push ON/OFF Remote Switch
WSS0S-D0x
1-Gang Single Rocker Decora™ Switch
WSS0S-D2x
1-Gang Dual Rocker Decora™ Switch
WSS0S-R0w
Handheld 4-Button Remote
WSS0S-E0x
3 x 3 Single Switch
WSS0S-E2x
3 x 3 Dual Switch
WSS0S-H0w
Hotel Key Card Switch
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
WIRELESS LINE VOLTAGE RECEIVERS
WST05-010
3-Wire 500 Relay Receiver, 120VAC (Threaded)
WST05-020
3-Wire 1200 Relay Receiver, 277VAC (Threaded)
WST05-080
3-Wire 1000 Relay Receiver, 240VAC (Threaded)
WST12-010
5-Wire 1500 Relay Receiver, 120VAC (Threaded)
WST12-020
5-Wire 3200 Relay Receiver, 277VAC (Threaded)
WST12-080
5-Wire 3000 Relay Receiver, 240VAC (Threaded)
WST02-R10
5-Wire 300 Relay Receiver, 24VAC (Threaded)
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
WIRELESS PLUG-IN RECEIVERS
WSG0S-D1T
Plug-In Dimmer Receiver
WSG0S-S1T
Plug-In ON/OFF Relay Receiver
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
WIRELESS LOW VOLTAGE RECEIVERS
WS0RC-200
2-Ch. Room Controller, 2 Inputs/2 Outputs, 8-30VDC
WS0RC-300
3-Ch. Room Controller, 1 Input/3 Outputs, 8-30VDC
WS0RC-400
4-Ch. Room Controller, 0 Input/4 Outputs, 8-30VDC
WS0RC-s00
2-Channel Shade Controller, 8-30VDC
WSD01-001
0-10V Dimmer Module
WSD02-010
Constant Voltage LED Dimmer w/ Wireless
WSD02-010
Constant Voltage LED Dimmer w/o Wireless
WSPAS-LV4
4-Channel Relay Receiver, 8-30VAC or 8-30VDC
WSPAS-LV8
8-Channel Relay Receiver, 8-30VAC or 8-30VDC
WS0TH-S00
Thermostat, 24VAC
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
p
p
p
p
x
x
x
x
x
x
p
p
p
p
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
WIRELESS TRANSMITTERS
WSSLT-010
SLT Circuit Interlock Transmitter, 120VAC
WSTLT-010
SLT Circuit Interlock Transmitter, 120VAC (Threaded)
WSSLT-R10
SLT Circuit Interlock Transmitter, 240VAC
WSSLT-GP0
4-Channel SLT Transmitter, 8-28VDC
p
p
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
p
p
x
x
x
p
p
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
p
p
x
x
x
p
p
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
p
p
x
x
x
p
p
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
p
p
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
WIRELESS ACCESSORIES
WS0RF-300
RS-232 Serial Box Data Interface
WSMET-010
Signal Strength Meter
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x Indicated Compatibility
p Indicates Partial Support (PTM Mode ONLY)
With Leviton v1.19 or newer firmware
Leviton Mfg. Co., Inc. Lighting Management Systems
20497 SW Teton Avenue, Tualatin, OR 97062 1-800-736-6682 Tech Line: 1-800-959-6004 Fax: 503-404-5594 www.leviton.com/lms
© 2010 Leviton Manufacturing Co., Inc. All rights reserved. Subject to change without notice.
68
x
x
x
x
x
x
x
x
x
x
x
x
ROOM CONTROL | miniZ™
www.leviton.com/les
69
ROOM CONTROL | miniZ™
miniZ™ Intelligent Daylight Management System
Combines Occupancy Sensing, Daylight Harvesting and Flexible Lighting Control
The miniZ combines occupancy sensing, daylight harvesting and flexible lighting control functions in a single extremely
easy-to-install package. miniZ is the first system to offer self-configuring daylight harvesting system with ladderless
commissioning for install-and-forget convenience. The performance, features and capabilities of the miniZ provide a
powerful package at an affordable price.
Features
• Autocal™ (patent-pending) automatic photocell calibration
• Ladderless commissioning™ provides install–and-forget convenience
• Automatic correction for Light Loss Factor
• Recognizes and corrects for lumen maintenance issues
• Cost-effective energy code compliance
• Automatic closed- or open-loop, multi-zone daylight harvesting control
• Convenient occupancy sensor and photocell integration
• Simplified daylight harvesting with full range dimming
• Input for external time clock integration, load shedding and emergency override
• Simplified integration with emergency systems
• Controls maximum lighting output for additional energy savings potential
• Daylight switching, full range 0-10V sinking fluorescent dimming and network models available
• Accepts input from local momentary or maintained switches as well as low-voltage input from photocells and occupancy
sensors for a comprehensive yet easily installed energy management solution
• Accepts multi-voltage (120, 277, 347V) input; 10W Max, 50/60Hz
miniZ
• Factory pre-tested
• 5-Year Warranty
Applications
• Offices
Typical miniZ
installation
• Classrooms
Photocell
(ODC0P)
Multi-technology
Occupancy Sensor
(OSW12-M0W)
Low-voltage
Switch
(LV220)
• Skylit spaces
miniZ Intelligent Daylight Management System
(20A output relays (120/277V); 15A output relays (347V); Fluorescent,
non-dimmed and 1-10V dimmed (0,2 or 3 zones); 120mA/24V output
for operation of occupancy sensors, etc.)
20A Power 0-10V Cat. No.
Control
CircuitsDimming
Input
CircuitsVoltage
70
Zone 2
Zone 1
mzb00-1022
0 120/277VAC
mzd20-1022
2 120/277VAC
mzd30-1011
3 120/277VAC
mzb00-c022
0 220/347VAC
mzd20-c022
2 220/347VAC
mzd30-c011
3 220/347VAC
mzb02-1022
0 120/277VAC
mzd22-1022
2 120/277VAC
mzb02-c022
0 220/347VAC
mzd22-c022
2 220/347VAC
Commercial Closed Office - Diagrams 7
© Copyright 2006 Christopher A. Carbone, Inc. All Rights Reserved.
miniZ Daylight
Harvesting
Controller
(MZD20)
Leviton offers a comprehensive line of commercial- and industrial-grade switches, including zone-control lighting switches
and switches for low voltage AC or DC energy control systems such as thermostats, fan controls and those related to
solar and wind energy. They are perfect in locations where it is important to maintain the look and feel of conventional
AC switches.
ORDERING INFORMATION
CAT. NO.
DESCRIPTION
COLOR
LV200-00W
Low voltage 5-button dimming ON/OFF controller
White
LV240-00W
Low voltage 2-button switching ON/OFF controller
White
01081-00I
Low voltage momentary contact toggle switch
Ivory
01081-00W
Low voltage momentary contact toggle switch
White
01081-0GY
Low voltage momentary contact toggle switch
Gray
56081-02I
Low voltage momentary contact Decora® rocker switch
Ivory
56081-02W
Low voltage momentary contact Decora rocker switch
White
12021-02I
Low voltage standard toggle switch
Ivory
®
12021-02W
Low voltage standard toggle switch
White
56021-02I
Low voltage Decora® rocker switch
Ivory
56021-02W
Low voltage Decora rocker switch
White
®
www.leviton.com/les
ROOM CONTROL | miniZ™
LOW VOLTAGE SWITCHES
71
72
CENTRALIZED CONTROL
www.leviton.com/les
73
Smart Lighting Control
Designed for the contractor, specifier and end user, GreenMAX Relay Control Panels offer the best performance, reliability,
flexibility and energy savings of any relay control available. Featuring a 25,000A Short Circuit Current Rating (SCCR),
GreenMAX easily integrates various lighting control strategies like switching, dimming, behavior controls, scheduling,
occupancy sensing and daylight harvesting. Programming and monitoring GreenMAX is quick and simple with a portable
Handheld Display Unit (HDU) that allows for onsite or remote access. The modular design allows total installation flexibility
and labor savings as well as easy expansion opportunities.
FEATURES
• Scalable solution offers future expansion opportunities
• Easy energy code compliance and LEED point eligibility
• Highest Short Circuit Current Rating (SCCR) of 25,000A
at 277VAC for maximum equipment performance
Photocell
• Robust latching Relay Modules are rated 30A general
fluorescent ballast and 20A incandescent in 1-pole and
2-pole configurations with the same footprint, available
with or without the Return to Closed (RTC) functionality
• Dimming control with Dimming and Switching Relay
Modules
• Daylight harvesting capabilities
• Programming and monitoring of the system is conveniently done with a portable Handheld Display Unit
(HDU) and simplified Behavior settings in the space
being controlled rather than from the electrical room
• Modular system was designed to ship the empty cabinet
enclosure, complete with doors and covers, to the job
site to make installation of the cabinet and conduits
easier
• Supports native network communication protocols –
BACnet/IP, Ethernet, and LumaCAN – to simplify
configuration and ensure start simplicity
• Accommodates low voltage inputs such as occupancy
sensors, photocells, contact closures, and switches –
connect using the onboard Low Voltage Input Card or
remotely in the Remote Input Cabinet
Loads
GreenMAX 16 - Relay Cabinet
Digital Switch - 1 button
Digital Switch - 2 buttons
Digital Switch - 4 buttons
Photocell
APPLICATIONS
• Heavy retrofit applications
Low Voltage Switch
0-10V BALLAST
GreenMAX 8 - Relay Cabinet
Keyswitch
• New construction projects
• Government facilities
• Office buildings
• Hospitals/medical offices
• Universities
• Restaurants
• Large campuses
• Any other location where centralized lighting control,
programming, and monitoring are required
74
Occupancy
Sensor
Remote Low Voltage Cabinet
• Wiring area covers and isolation barriers conceal the
circuit wiring and provide maximum arc flash protection
when installed allowing work to be done with power on
without chance of exposure to high voltage – no Arc
Flash Suit needed
• Custom engraving available on digital switches and wall
plates
Occupancy
Sensor
0-10V BALLAST
LumaCan
CENTRALIZED CONTROL | GREENMAX®
GREENMAX® RELAY CONTROL PANELS
Digital Switch - 4 Button Dimmer Control
Loads
LumaCAN
Port
Ethernet
Port
Power
Supply
Main
Processor
Low Voltage
16-Input Card
Communication Link
(Between Command
Module and Relay
Insert Panel)
Wiring
Diagram
Relay
Insert
Panel
Lock
Right
Panel
Cover
Door
with
Split
Hinges
Left Panel
Cover
2-Pole
Relay
Grounding
Points
Lower Ventilation
Cover
Power and
Lighting
Wire Way
CENTRALIZED CONTROL | GREENMAX®
Command Module
USB Port
Manual
Actuator
GREENMAX INNOVATION
GREENMAX SYSTEM
• Industry leading 25,000A Short Circuit Rating (SCCR) at 277 VAC withstands circuit faults for increased safety
• Native communication network protocols—BACnet IP, Ethernet and LumaCAN—are built into each Command Module to
offer unparalleled connectivity; no additional parts or adapters are needed to communicate with other products utilizing
these protocols
• Modular system includes separate empty Cabinet enclosures, Command Modules and Relay Insert Panels to minimize
handling and subsequent damage during the installation process
• Easy updates—loading firmware is automated and only requires plugging in a flash memory card and pressing a button
• System can be connected via Ethernet or LumaCAN networks
• All network connections are made with RJ45 connectors and cabling is standard CAT6
• Low Voltage Remote Input Card can be combined with LevNet RF Self-Powered Wireless Solutions to create a wireless
hybrid system of inputs
• All programming and configurations are stored in a MicroSD memory card, which eliminates the need for non-volatile
memory
www.leviton.com/les
75
CENTRALIZED CONTROL | GREENMAX®
GREENMAX RELAY CABINETS
• GreenMAX cabinet has a 25,000A at 277 VAC Short Circuit Current
Rating (SCCR) for increased reliability and durability
• Empty cabinet enclosures ship separately from electronic components – Command Module and Relay Insert Panel – making the cabinets lighter and easier to handle and requiring less effort to install
• Empty cabinet also provides unobstructed access to conduit entry
points and reduces the risk of damaging electronics
• Relay cabinets can hold 8, 16, 32 and 48 relays, each with unlimited
and flexible configuration capabilities; the 0-10 VDC dimming and
switching relay models can be installed in any available relay slot
• Increased arc flash protection—the cabinet door opens to expose
only the low voltage area of the cabinet
• Remote Low Voltage Panels allow the connection points of the
low voltage wiring enclosure to be installed closer to the devices it
serves, reducing wiring and labor costs and making commissioning
or troubleshooting easier
• Takes only eight screws to assemble the internal Relay Insert Panels
and Command Module of a 48-Relay GreenMAX cabinet
• A single relay or group of relays can be separated by sliding an isolation barrier between relays to eliminate the need for an additional
cabinet to handle emergency loads and allows voltages from mixed
sources in the same cabinet
• Native communication network protocols—BACnet/IP and Ethernet
—are built into each Command Module to offer unparalleled connectivity; no additional devices are needed to communicate with other
products utilizing these protocols
GREENMAX RELAY MODULES
• All GreenMAX relay modules have a 25,000A at 277 VAC Short Circuit
Current Rating (SCCR) for increased reliability and durability
• Rated at 30A general fluorescent ballast and 20A incandescent, HID,
electronic ballast
• All GreenMAX Relay Modules are 1-pole or 2-pole latching relay types
that reduce parasitic energy use. All relay modules are the same
physical size, allowing the optimal mix of relays to be customized for
each application
• Self-contained Dimming and Switching Relay Module in 1-pole
configurations features daylight harvesting capabilities
• All four wires required for 0-10V dimming ballast wiring connect
directly to the module—no additional control board required
• All relays are latching with a manual actuator that allows users to
manually bypass the system to turn lights ON or OFF without CPU
power
76
CENTRALIZED CONTROL | GREENMAX®
HANDHELD DISPLAY UNIT (HDU)
• Allows programming, system configuration, and scheduling to be
done in the space being controlled rather than the electrical room
to make commissioning and set-up functions easier
• Configure and control the entire GreenMAX system (or multiple
systems) from any convenient network access point—relay cabinets, switches, or remote low voltage cabinets with just one HDU
• Provides interface with all devices and relays in the system
• Can be stored in the cabinet or designated docking station
• Communicate via LumaCAN
• 7 hour run time on a single full charge
• Astronomical clock – sunrise/sunset
• HDU does not need to be connected to system during operation.
The full computing power of a PC remains in the palm of your hand
• Comes complete with a set of rechargeable batteries
GREENMAX SWITCHES
• GreenMAX digital key switch provides secure button presses on
the network
• Available in 1, 2, and 4 button configurations, and key switch
version with custom engraved labeling available on switch buttons
and screwless wall plates
• Switch colors available: white, light almond, ivory, gray, black, and
red; all come with a matching wallplate. Keyswitch comes with
a stainless steel wallplate and tamper-resistant screws (tool
included)
• Each digital switch button has a green LED pilot light to report the
corresponding relay state
• Switches can be ganged together in wallboxes (multi-gang
wallplate sold separately)
• RJ45 connectors to provide inline connection to the LumaCAN
network
• Any 4-button switch model can be configured to control 0-10 VDC
dimming circuits
• Easy to access port on top of switch provides connectivity for the
GreenMAX HDU
www.leviton.com/les
77
CENTRALIZED CONTROL | GREENMAX®
PROGRAMMING GREENMAX WITH LIGHTING BEHAVIORS
LIGHTING CUSTOMIZATION
GreenMAX controls allow different Behavior settings to be programmed throughout the day. Using the HDU, any room can
be set with just a few button selections:
• Select the Behavior desired and time Behavior will take place
• Choose any additional Behavior transitions and the time transition will take place
• Optional override to sunrise/sunset astronomical clock prevents lights from activating prematurely in summer or too late
in winter
• Set Behaviors to scale on a daily, weekly, monthly or holiday schedule
• Up to 24 Behaviors per 24 hour period can be programmed and can be as close together as one minute
Simple and Easy Programming
• Using the HDU, select the number on the screen corresponding with the desired Behavior
• Enter time and dates to be in effect and any corresponding Behavior Modifiers. Behaviors can be set for entire system or
individual rooms/relays
BEHAVIORS
Number
Description
Occupancy
Sensor
Photocell
Switch
Time
B1
Lights turned ON with the switch.
Can be turned OFF with switch.
Occupancy Sensor will turn OFF upon vacancy.
OFF
-
ON/OFF
-
B2
Lights turned ON with the Occupancy Sensor.
Can be turned OFF/ON with switch.
Occupancy Sensor will turn OFF upon vacancy.
ON/OFF
-
ON/OFF
-
B3
Occupancy sensor turns lights ON/OFF.
ON/OFF
-
-
-
B4
Switch ON/OFF.
-
-
ON/OFF
-
B5
Time triggers a Blink Warn sequence, an OFF blink followed by a
variable ON delay.
Switch interrupts sequence and starts override timer.
Will automatically turn OFF relay if override timer reaches zero.
-
-
ON/OFF
Blink/OFF
B6
Turn ON at specific time.
-
-
-
ON
B7
Turn OFF at specific time.
-
-
-
OFF
ON/OFF
OFF
-
-
OFF
OFF
ON/OFF
-
ON/OFF
OFF
ON/OFF
-
-
OFF
ON/OFF
-
-
OFF
-
ON
Occupancy sensor turns ON lights with occupancy.
B8
Measured light levels above Photocell trigger point turns OFF or keep
lights OFF, below set-point allows control by Occupancy Sensor.
Occupancy Sensor turns OFF lights with vacancy.
Switch turns ON/OFF lights.
B9
Measured light levels above Photocell trigger point turns OFF or keep
lights OFF, below set-point allows control by Occupancy Sensor.
Occupancy Sensor turns OFF lights with vacancy.
Occupancy Sensor turns ON lights with occupancy.
B10
Measured light levels above Photocell trigger point turns OFF or keep
lights OFF, below set-point allows Occupancy Sensor control.
Switch can turn ON/OFF lights by over-riding Occupancy Sensor control.
Occupancy Sensor will turn OFF lights upon vacancy.
Switch ON/OFF.
B11
Measured light levels above Photocell trigger point turns OFF or keep
lights OFF, below set-point allows Switch control.
Turn ON at specific time.
B12
78
Measured light levels above Photocell trigger point turns OFF or keep
lights OFF, below set-point reliquishes control to the constant ON state.
Auto-Prompt Customizations
Name
Description
Value Range
Switch OFF
Delay
When relay is turned ON with the switch, length of time before relay will automatically turn OFF.
Occupancy
Sensor OFF
Delay
When vacancy is determined, length of time before relay will automatically turn OFF.
Photocell
Delay
2.5, 5, 10, 15, 30, 60, 90, 120
minutes, and Constant ON
0, 0.5, 2.5, 5, 10, 20, 30
minutes
Delay before action is taken after a Photocell trigger point has been crossed.
0, 0.5, 2.5, 5, 10, 20 minutes
Blink Warn The length of the OFF Blink used to notify occupants than an OFF sequence has been initiated.
Blink
Duration
0.5-25.4 seconds
This period follows the Blink and lasts the length of the specified time. If button is pressed dur-
Blink Warn - ing this period, the Delay timer stops and the Override Time starts. If no buttons are pressed,
Delay
the lights will turn OFF.
1-254 minutes
Blink Warn - The relay will remain ON for the duration of this timer. A new Blink Warn sequence will be initialized at the end of this period. If the relay had been OFF previously and a button is pressed to
Override
turn the relay ON, this timer will be started again.
Time
4-254 minutes
ORDERING INFORMATION
CAT. NO
DESCRIPTION
CAT. NO
DESCRIPTION
Tubs and Covers (all cabinets are surface mount with
a locking door)
Remote Inputs with Power Supply (all remote inputs are
rated 100-277VAC)
R08TC-100
GreenMAX Relay Cabinet, 8-Relay Size,
NEMA 1
RLV08-108
Remote Low Voltage Input Cabinet,
8 Inputs, NEMA 1 Enclosure
R16TC-100
GreenMAX Relay Cabinet, 16-Relay Size,
NEMA 1
RLV16-116
Remote Low Voltage Input Cabinet,
16 Inputs, NEMA 1 Enclosure
R32TC-100
GreenMAX Relay Cabinet, 32-Relay Size,
NEMA 1
Relays (all relays are rated 30A, 120-230-277/347VAC,
50/60Hz)
R48TC-100
GreenMAX Relay Cabinet, 48-Relay Size,
NEMA 1
RELAY-1CB
GreenMAX Latching Relay, 1-Pole RTC
Basic
Command Modules (includes power supply and main
processor unit)
RELAY-1DS
GreenMAX Latching Relay, 1-Pole
Dimming and Switching
RPM00-100
Main Command Module, 100-277VAC,
no inputs
RELAY-1TB
GreenMAX Latching Relay, 1-Pole Basic
RPM08-108
Main Command Module with 8-Port
Low Voltage Input Card, 100-277VAC,
50/60Hz
RELAY-2CB
GreenMAX Latching Relay, 2-Pole RTC
RELAY-2TB
GreenMAX Latching Relay, 2-Pole Basic
RELAY-BFM
Blank Filler Module
RPM16-116
Main Command Module with 16-Port
Low Voltage Input Card, 100-277VAC,
50/60Hz
RGBAR-008
GreenMAX Voltage Barriers for 8 Relay
Cabinets
RGBAR-016
GreenMAX Voltage Barriers for 16, 32
and 48 Relay Cabinets
Panel Interiors (all panels are 16-position, rated 30A,
120-230-277/347VAC, 50/60Hz)
R0800-000
Relay Insert Panel, Empty with (8) Spaces
R1600-000
Relay Insert Panel, Empty with (16) Spaces
R1616-1CB
Relay Insert Panel with (16) 1-Pole
Basic Relays
R1616-1DS
Digital Switches
RDGSW-1DX
GreenMAX Digital Switch, 1-Button
RDGSW-2DX
GreenMAX Digital Switch, 2-Button
RDGSW-4DX
GreenMAX Digital Switch, 4-Button
Relay Insert Panel with (16) 1-Pole
RDGSW-1KS
GreenMAX Keyswitch
R1616-1TB
Relay Insert Panel with (16) 1-Pole
Basic Relays
RDGSW-1KX
GreenMAX 1 Button Color Change Kit
RDGSW-2KX
GreenMAX 2 Button Color Change Kit
R1616-2CB
Relay Insert Panel with (16) 2-Pole
RTC Relays
RDGSW-4KX
GreenMAX 4 Button Color Change Kit
R1616-2TB
Relay Insert Panel with (16) 2-Pole
Basic Relays
Handheld Display Unit (HDU)
RHDU1-000
Handheld Display Unit, Cabinet Mounting
RHDU1-001
Handheld Display Unit, Mounting Bracket
Requires 2 Gang Back Box
CENTRALIZED CONTROL | GREENMAX®
BEHAVIORS, CONT.
Replace x to indicate color: (W) = White, (I) = Ivory, (T) = Light Almond,
(G) = Gray
Note: See page 71 for Ordering Information on Low Voltage Switches
www.leviton.com/les
79
CENTRALIZED CONTROL | EZ-MAX™ PLUS
80
EZ-MAX™ PLUS Relay Control Panels
EZ-MAX Plus relay lighting control panels pack power and performance in compact and cost-effective 4/8-circuit and
16/24-circuit models. EZ-MAX Plus is the ideal solution for smaller, stand-alone applications that do not require the field
configuration or advanced networking features.
Programming is easy with the EZ-MAX Plus with a large LCD screen on the panel or an off-line editor. EZ-MAX Plus includes
standard programming configurations for occupancy sensors and photocells as well as a built-in astronomical time clock
(ATC) with 101 major city and states programmed into the system.
• Combines clock, cabinet, terminal blocks and contactors in a single integrated solution to reduce labor and material costs
• Easy programming using an offline editor or wizard-driven LCD display and oversized buttons
• Easy standard programming configuration:
- Occupancy sensors: manual-ON or auto-ON applications
- Photocells: interior or exterior application modes
- Photocell light level trip points: ON or OFF
• Built-in astronomical time clock and scheduler
-101 major cities and states programmed for easy astronomical setup
- Sunrise/sunset time clock events
• Auto detection/auto assign of installed network switches
• Enable/disable of low voltage and digital input devices minimizes power consumption
• Optional modem configuration for remote touch-tone control
• Clearly labeled access points allow installer to locate optimum knock-out locations
• UL and cUL Listed Industrial Control Equipment and Emergency Lighting Equipment for 120V, 277V and 347V Panels
• ASHRAE 90.1 compliant for 120V, 277V and 347V Panels
• CEC Title 24 compliant for 120V, 277V and 347 Panels
• Rated for 100% load capacity
• 10 year warranty on Relays, 2 year warranty on Panels
APPLICATIONS
• Low voltage control
• Site lighting
• Daylight harvesting
• Occupancy sensor integration
• Parking garage/parking lot lighting
• Smart replacement of time clock/contactor installations
CENTRALIZED CONTROL | EZ-MAX™ PLUS
FEATURES
• Any application requiring reliable and cost-effective automatic lighting control
ORDERING INFORMATION
CAT. NO.DESCRIPTION
R08BD-000
EZ-MAX Plus 8 Panel, 120V, 277V, and 347V, No Relays
R08BD-L04
EZ-MAX Plus 8 Panel, 120V, 277V, and 347V, (4) 30A (NO/NC) Relays
R08BD-L08
EZ-MAX Plus 8 Panel, 120V, 277V, and 347V, (8) 2-Pole (NO) Relays
R24BD-000
EZ-MAX Plus 24 Panel, 120V, 277V, and 347V, No Relays
R24BD-L16
EZ-MAX Plus 24 Panel, 120V, 277V, and 347V, (16) 30A (NO/NC) Relays
R24BD-L24
EZ-MAX Plus 24 Panel, 120V, 277V, and 347V, (24) 30A (NO/NC) Relays
R24BD-216
EZ-MAX Plus 16 Panel, 120V, 277V, and 347V, (16) 2-Pole (NO) Relays
R24BD-224
EZ-MAX Plus 24 Panel, 120V, 277V, and 347V, (24) 2-Pole (NO) Relays
R08BF-000
EZ-MAX Plus 8 Panel, 230V, No Relays
R08BF-L08
EZ-MAX Plus 8 Panel, 230V, (8) 30A (NO/NC) Relays
R08BF-208
EZ-MAX Plus 8 Panel, 230V, (8) 2-Pole (NO) Relays
R24BF-000
EZ-MAX Plus 24 Panel, 230V, No Relays
Note: See page 71 for Ordering Information on Low Voltage Switches
www.leviton.com/les
81
CENTRALIZED CONTROL | EZ-MAX™ PLUS
EZ-MAX Plus Relay Cards
EZ-MAX Plus Panels use individual Relay Cards for each circuit allowing for the most flexibility in matching the relay type to
your specific load requirements. The benefit of a single relay card for a single circuit allows an infinite arrangement of relay
types to position in your system and supports individual replacement should the need ever occur.
• For maximum equipment protection, standard 30A relay card has a Short Circuit Current Rating (SCCR) of 20,000A
• Relay cards individually replaceable
• Mechanical attachment to panel of each relay card is with a single screw
• Listed for use with ballasted loads
• From the panel, each relay card can be controlled as follows:
- Override ON
- Override OFF
- Locked Override ON
- Locked Override OFF
- Timed ON
- Timed Override OFF
• 10 year warranty
EZ-MAX PLUS RELAY CARDS
CAT. NO.DESCRIPTION
RELAY-L30
1-Pole N/O or N/C Relay Card with Manual Override, 30A, 120-277V, 347V, 20A Ballast
RELAY-2PL
2-Pole, N/O Relay Card, 20A, 208-480V
RELAY-347
347V N/O Relay Card, 20A, 347V
ACCESSORIES*
CAT. NO.DESCRIPTION
RAC00-2SB
Low-Voltage Switch Adapter, reduces required wire count of GE style switch by 1.
(installed at the switch itself, cabinet has terminations for ON/OFF/LED/+1/com)
00LVS-xxW**
xx Button, Low Voltage Switch, White
ZMDSW-xxW**
xx Button, Digital Switch, White
PCOUT-000Outdoor Photocell, 0-10V
PCIND-000
Indoor Photocell, 0-10V
PCATR-000
Atrium Photocell, 0-10V
PCSKY-000
Skylight Photocell, 0-10V
* For a complete range of occupancy sensors for use with EZ-MAX Plus, refer to www.leviton.com/cenergyproducts
** x = 01, 02, 04, 05, 06, 08 or 10 button switch
82
www.leviton.com/les
83
DISTRIBUTED CONTROL | SECTOR®
DISTRIBUTED CONTROL | SECTOR®
SECTOR INTELLIGENT DIGITAL LIGHTING CONTROL SYSTEM
The Sector Intelligent Digital Lighting Control System combines occupancy sensing, daylight harvesting and flexible dimming
lighting control in one conveniently integrated system to easily save time, money and energy. This topology-free, polarity-free
system allows the entire network to be installed using the same wiring for all components and accessories making it one of
the easiest lighting control systems to install. All components are on a single bus, with accessories connected to the network,
not the ballast. The Sector family of products provides a scalable solution that offers maximum flexibility and coverage in any
application – from a single room to a campus of buildings in retrofit or new construction projects.
FEATURES
Sector Intelligent Digital Lighting Control System
• Topology free
• Polarity free – Class 1 or Class 2 Wiring/standard building supported wiring in same conduit as power wiring
• No special terminations or installation requirements
• Personal workspace lighting control from user’s personal computer for user comfort
• Easy to commission – ultimate flexibility in design, installation and configuration using a drag and drop GUI interface with
Illustrator layout tool
• Easy to design, easy to install and easy to maintain
Ideal Uses:
Hospitals, offices buildings, medical offices, universities, labs, restaurants, government facilities and any other location that
could benefit from the cost savings and energy efficiency of a controlled lighting environment.
ADVANTAGES
• Easy to Design – scalable system for small and large applications; devices that connect directly to the network can be
installed anywhere in the system
• Easy to Install – topology free, polarity independent, and operates on standard Class 1 or Class 2 wiring throughout the
entire systems to reduce installation costs by as much as 35% or more; standard wire is found in every contractor’s
inventory
• Easy to Commission – configuration and commissioning is completed from the PC application without physically having to
go to each device
• Ultimate time-saving design flexibility – easily integrate various lighting control strategies—switching, distributed dimming,
scheduling, occupancy sensing, and daylight harvesting – in one system offering future expansion opportunities
• Easy energy code compliance and eligibility for LEED points
• Control and customization from occupant’s desktop as well as remote control and administrator software interface
• SectorFlex system controls Sector and non-Sector 0-10V ballasts or LED dimmers by any manufacturer, allowing for
flexibility in implementation
SECTORFLEX INTELLIGENT DIGITAL LIGHTING CONTROL SYSTEM
SectorFlex works for either zonal switching or dimming lighting control and gives you the full power of the Sector design
with the flexibility and value of the SectorFlex system. SectorFlex offers the most cost effective and energy efficient lighting
control solution that works with virtually any 0-10V load and is frequently used to control 0-10V ballasts, like Sector 7, or
0-10V controllable LED fixtures.
84
DISTRIBUTED CONTROL | SECTOR®
SECTOR INTELLIGENT DIMMING FLOURESCENT BALLASTS
• Intelligent dimming offers higher energy savings and flexibility than
traditional switching
• Dimming fluorescent ballasts allow 100% to 1% dimming capabilities
• Ballasts have an addressable labeling system for easy programming
and personal lighting control
SECTOR RELAY
• Provides switching control for non-dim devices and 0-10V control for
synching and sourcing controllable loads
• Used for both switching only loads and dimming loads controllable with
a 0-10 control signal
• Provides additional system design options, allowing control of Ballast
incandescent, LED, cold cathode or other sources that may attempt a
0-10VDC control input
SECTOR BUS CONTROLLER
• Contains the brain and the power supply for the Sector system in one
component
• Controls a maximum of 64 devices on a system with the ability to
expand and include a maximum of 250 systems
SECTOR OCCUPANCY SENSORS
• Turns lights ON/OFF based on vacancy or occupancy
• Multi-technology and infrared (PIR) models available
• Self-adjusting settings continually analyze and adjust sensitivity, timer
operation and long-term performance, reducing user complaints
SECTOR PHOTOCELL
• Daylight harvesting capabilities offer consistent lighting at desired level
for greater visual comfort
www.leviton.com/les
85
DISTRIBUTED CONTROL | SECTOR®
86
SECTOR DIGITAL SWITCH
• User controls desired light level at the push of a button
• 5 button (ON, MAX, BRIGHT, DIM, OFF) and 2 button (ON, OFF) available
SECTOR HANDHELD REMOTE
• User controls desired light level at the push of a button (ON, MAX, BRIGHT, DIM, OFF)
• Controls lighting levels up to 25 feet from anywhere in the room
SECTOR LOW VOLTAGE INTERFACE
• Allows integration of Sector System with non-Sector occupancy sensors and photocells
• Provides for cost and install time savings by utilizing existing site components
SECTORNET SOFTWARE
• Personal Dimming Option (PDO): Individual control for the lights above a user’s workspace
right from their desktop PC
• Central control: Facility personnel and lighting administrators can re-configure control
as needed with Illustrator layout tool
• A computer is only needed to initially configure the system. Afterward, Sector can be
ran as an independent system
• Commissioning quickly associates fixtures to Sector devices for easy configuration that
can be remotely controlled
• Data acquisition for energy usage monitoring
• Ladderless commissioning – remotely configure and control system components
• 3 levels of load shed allow user to automatically adjust power consumption across the
entire system by simply clicking a button
2 Button
Switch
Remote
Occupancy
Sensor
2 Button
Switch
Photocell
Non-Dim Device
Signage
Photocell
~ Sector Ballast
Line
Voltage
~
Area 2
Voltage
Area 3
Area 1
LumaCAN Network
Wiring may follow any
topology; daisy chain,
star, home run etc. or
“T” at any point in the
network. SectorNet
Network is also
polarity free!
~ Sector Ballast
Line
Voltage
~ Sector Ballast
Line
*Power
Supply
Bus
Controller
Up to 8 areas
per Bus
Controller
Area 5
* Max 256mA per Power Supply
Max distance between
Bus Controller & last
device on line is
1,000'/304 Meters
*Power
Supply
Bus
Controller
LumaCAN Network
CLASS 2 WIRING
64 SectorNet
devices per
Bus Controller
Photocell
~
~ Sector Ballast
Line
Voltage
~ Sector Ballast
Line
Voltage
Occupancy
Sensor
Max 32 input
devices (Switch,
Photocell, or
Occupancy
Sensor
To other Bus Controllers
SectorNet Network
Occupancy
Sensor
Occupancy
Sensor
Area 1
~
Line
Voltage
5 Button
Switch
2 Button
Switch
SectorNet Network
Sector
Relay
Areas 2 - 7
Occupancy
Sensor
~
Line
Voltage
SectorNet Network
0-10V
Control
& Power
Sector
Relay
CLASS 1 or 2 WIRING
Load - 0-10V
Dimming
Ballasts
5 Button
Switch
Terminate each end
of the LumaCAN
network by pushing
blue button
Area 8
Area 6
Area 4
~ Sector Ballast
Line
Voltage
Dimmer
SectorNet Network
Max Longest Run - 1000’
Sector
Relay
Line
Voltage
SectorNet Wiring
Min 18 AWG
~ Sector Ballast
Line
Voltage
Occupancy
Sensor
Power
DISTRIBUTED CONTROL | SECTOR®
5 Button
Switch
Up to 250 devices are
supported on each
LumaCAN subnet. A
Bus Controller counts
as (1) device
www.leviton.com/les
87
DISTRIBUTED CONTROL | SECTOR®
Sector 7
Sector 7 Traditional 0-10V Dimming Ballasts bring advantages to any system and dimming application.
Advantages
• Light level dimming range from 1% to 100% - <1% dimming for no more cost than 10% dimming
• Universal input – Works with both 120/277V and 50/60Hz
• Flexible – Integrates into existing installations with a variety of off-the-shelf fixtures
• Energy and cost savings – Enables energy conservation when combined with dimming, daylight harvesting and demand
response controls
Installation and Operation Benefits
• Minimal installation time – color coded easy-insert connectors simplify wiring and minimize installation time
• Mis-wire protection – Protects lamp failure if wired incorrectly
• Smooth fade – Through dimming rande of 1% to 100% for flicker-free dimming
• Lamps turn on at any dimmed level without flashing to full brightness,
this extends lamp life and provides better user experience
• Non-volatile memory – restores all ballast settings after power failure
ORDERING INFORMATION
88
CAT. NO.
DESCRIPTION
SBP00-00M
Sector Bus Controller/Power Supply,
120-277V, 50/60Hz
SBCS0-L00
Sector Relay, 120-347V 20A Output,
120-277V, 50-60Hz Input
SEN04-000
Sector 4-Module Enclosure (to hold a
maximum of 4 Bus Controllers)
OSC04-ISW
Sector PIR Occupancy Sensor, White,
450SF
OSC20-MSW
Sector Multi-Technology Occupancy
Sensor, White, 2000SF
ODC0P-0SW
Sector Photocell
SDS00-15W
5-Button Digital Switch, White
SDS00-12W
2-Button Digital Switch, White
SHH00-000
Sector Handheld Infrared Remote
Controller
SLM00-000
USB-to-LumaCAN Adapter
SIF00-000
SectorNET Administrative Software
SIFPD-000
SectorNET Client Software
SLIQD-000
SectorNET Low Voltage Interface
Module for Occupancy Sensors and
Photocells
SLIQS-000
SectorNET Low Voltage Interface
Module for Switches, 5-Channel
Sector Ballasts
S D
8 # OF LAMPS:
1 or 2
CAN SIZE
F = 9.5” can
J = 16.5” can
M
WATTAGE
17 = 17 watts
25 = 25 watts
32 = 32 watts
Sector Ballasts
S D
J 5 # OF LAMPS:
1 or 2
M
WATTAGE
14 = 14 watts
21 = 21 watts
28 = 28 watts
35 = 35 watts
Sector Ballasts
S D
1
J 5 -
M
WATTAGE
24 = 24 watts
39 = 39 watts
54 = 54 watts
Sector 7 Ballasts
S A
8 # OF LAMPS:
1 or 2
CAN SIZE
F = 9.5” can
J = 16.5” can
M
WATTAGE
17 = 17 watts
25 = 25 watts
32 = 32 watts
METERING SOLUTIONS
www.leviton.com/les
89
METERING SOLUTIONS
SMARTer Metering. SMARTer Control. REAL Savings. Our revenue-grade
submetering products meet all measurement and verification-based
opportunities, including smart metering, load management and LEED rating
achievement.
A Solution to Rising Energy Costs
Knowing exactly when and where energy is being used is a valuable tool that will help you better manage and conserve
energy, thus saving money. The process is simple and effective – if power is flowing through a circuit, Leviton can measure
it. The submeter is installed on the facility side of the master meter and captures accurate measurements of power
consumption. Leviton submeters are easy to specify and install for new construction or retrofit projects.
The Benefits of Submetering
Leviton submeters determine exactly when and where energy is being used; information that can be both a powerful
motivator and a significant money-saver. Studies have proven that once tenants became accountable for their energy
consumption, it was significantly reduced. This accountability can result in long-term cost savings from 15 to 20 percent.
Leviton submeters deliver accurate information for:
• Load profiling and benchmarking
• Tenant cost allocation
LINE
L2 L3
L1
H1
N
CT1
• Measurement and verification (M & V)
• Energy conservation and cost reduction
H2
CT2
H3
CT3
• Green building initiatives and Government mandates
• AMR/BAS/BMS/EMS integration
• Power Quality Analysis
• Usage aggregation
Simple Installation
Leviton submeters require no setup or programming. Simply
pass the conductors to be measured through the current
transformers (CTs) and connect the meter to the power.
* Short Circuit Protection
LOAD
The Most Options, The Most Performance
Leviton submeters quantify electrical energy consumption for virtually any commercial, industrial or residential application.
Engineered to provide the best performance in the submetering industry – accuracy, communication, installation and
support – Leviton sets the standard. Sold as individual meters and kits with both solid core and split core Current
Transformers (CTs), Leviton Metering Solutions include superior product features standard.
• ANSI accurate current transformers (CTs) deliver superior revenue-grade accuracy for high quality, long-term reliability
• Built in communication features allow for future automation without an additional investment
- All meters are equipped standard with an isolated pulse output channel for easy AMR/BAS/BMS/EMS
system interface
- All Series 1000, 2000 and 3000 meters feature native Modbus RTU standard
- Series 3000 Smart Meters conveniently display the date and time for maximum demand
• Installer friendly, reverse phase LED and power and load indicators provide installation diagnostics by visually confirming
that the product is properly installed and functioning
• UL 916 Listed for Energy Monitoring Equipment, Leviton Series 1000 and 2000 meters are available in an indoor steel or
outdoor NEMA 4X enclosure at the same low price
• Offering includes automated data collection solutions and energy reporting and analysis software to easily and intelligently
manage energy consumption
• Open architecture design provides easy integration with third party AMR/BAS/BMS/EMS platforms
• Confidently backed by the best warranty in the industry at 10 years
90
• Measures kWh with optional Demand functionality
(includes Reset Key)
• Conforms to all applicable standards of ANSI C12.1
• Equipped with both Isolated Pulse Output and RS-485
Serial Port (Modbus Native) standard for easy interface
with most AMR/BAS/BMS/EMS systems
• Utilizes split and solid core current transformers (CTs)
that are certified to all revenue grade accuracy
standards
Indoor Series 1000
Single Phase Meters
Outdoor Series 1000
Single Phase Meters
• Up to three sets of CTs per phase can be paralleled per
meter
• Ten year warranty
• 1- or 2-Phase applications, 120V, 120/240V, 277V or
277/480V
METERING SOLUTIONS
Series 1000 Single Phase Meters
* 100A-800A Services
SERIES 1000 SINGLE PHASE METER KITS
Note: Kits include meter, specified enclosure and required current transformers
INDOOR ENCLOSURE
VOLTAGE
120V 1PH 2W
120/208V 1PH 3W or
120/240V 1PH 3W (Split Phase)
277V 1PH 2W
OUTDOOR ENCLOSURE
VOLTAGE
120V 1PH 2W
120/208V 1PH 3W or
120/240V 1PH 3W (Split Phase)
277V 1PH 2W
AMPS
CTS INCLUDED
CAT. NO.
100
1 Split CT
1K120-01W
200
1 Split CT
1K120-02W
400
1 Split CT
1K120-04W
800
1 Split CT
1K120-08W
100
1 SOLID CT
1K120-1SW
200
1 SOLID CT
1K120-2SW
100
2 Split CTs
1K240-01W
200
2 Split CTs
1K240-02W
400
2 Split CTs
1K240-04W
800
2 Split CTs
1K240-08W
100
2 SOLID CTs
1K240-1SW
200
2 SOLID CTs
1K240-2SW
100
1 Split CT
1K277-01W
200
1 Split CT
1K277-02W
400
1 Split CT
1K277-04W
800
1 Split CT
1K277-08W
100
1 SOLID CT
1K277-1SW
200
1 SOLID CT
1K277-2SW
AMPS
CTS INCLUDED
CAT. NO.
100
1 Split CT
1O120-01W
200
1 Split CT
1O120-02W
400
1 Split CT
1O120-04W
800
1 Split CT
1O120-08W
100
2 Split CTs
1O240-01W
200
2 Split CTs
1O240-02W
400
2 Split CTs
1O240-04W
800
2 Split CTs
1O240-08W
100
1 Split CT
1O277-01W
200
1 Split CT
1O277-02W
400
1 Split CT
1O277-04W
800
1 Split CT
1O277-08W
www.leviton.com/les
91
METERING SOLUTIONS
Series 2000 Three Phase Meters
• Measures kWh with optional Demand functionality
(includes Reset Key)
• Conforms to all applicable standards of ANSI C12.1
• Equipped with both Isolated Pulse Output and RS-485
Serial Port (Modbus Native) standard for easy interface
with most AMR/BAS/BMS/EMS systems
• Utilizes split and solid core current transformers (CTs)
that are certified to all revenue grade accuracy
standards
Indoor Series 2000
Three Phase Meters
• Up to three sets of CTs per phase can be paralleled per
meter
• 3-Phase, 4-Wire applications, 120/208V or 277/480V
• 100A-1200A Services
SERIES 2000 THREE PHASE METER KITS
Note: Kits include meter, specified enclosure and required current transformers
INDOOR ENCLOSURE
VOLTAGE
120/208V 3PH 4W WYE kWh Meter
277/480V 3PH 4W WYE kWh Meter
120/208V 3PH 4W WYE Demand Meter
277/480V 3PH 4W WYE Demand Meter
AMPS
CTS INCLUDED
CAT. NO.
100
3 Split CTs
2K208-01W
200
3 Split CTs
2K208-02W
400
3 Split CTs
2K208-04W
800
3 Split CTs
2K208-08W
1200
3 Split CTs
2K208-12W
100
3 SOLID CTs
2K208-1SW
200
3 SOLID CTs
2K208-2SW
100
3 Split CTs
2K480-01W
200
3 Split CTs
2K480-02W
400
3 Split CTs
2K480-04W
800
3 Split CTs
2K480-08W
1200
3 Split CTs
2K480-12W
100
3 SOLID CTs
2K480-1SW
200
3 SOLID CTs
2K480-2SW
100
3 Split CTs
2K208-01D
200
3 Split CTs
2K208-02D
400
3 Split CTs
2K208-04D
800
3 Split CTs
2K208-08D
1200
3 Split CTs
2K208-12D
100
3 Split CTs
2K480-01D
200
3 Split CTs
2K480-02D
400
3 Split CTs
2K480-04D
800
3 Split CTs
2K480-08D
1200
3 Split CTs
2K480-12D
AMPS
CTS INCLUDED
CAT. NO.
100
3 Split CTs
2O208-01W
OUTDOOR ENCLOSURE
VOLTAGE
120/208V 3PH 4W WYE kWh Meter
277/480V 3PH 4W WYE kWh Meter
92
200
3 Split CTs
2O208-02W
400
3 Split CTs
2O208-04W
800
3 Split CTs
2O208-08W
1200
3 Split CTs
2O208-12W
100
3 Split CTs
2O480-01W
200
3 Split CTs
2O480-02W
400
3 Split CTs
2O480-04W
800
3 Split CTs
2O480-08W
1200
3 Split CTs
2O480-12W
Outdoor Series 2000
Three Phase Meters
• kWh meter with standard Demand functionality (includes Reset Key)
• 120/208V, 277/480V, 347/600V 3PH 4W WYE;
208V, 240V 480V 3PH 3W DELTA
• 100-5000 Amps
• Advanced data meter
• Volt, amps, watts, PF and VA per phase
• Modbus RTU (RS485) and Pulse output - standard features
• Certified to all applicable standards of ANSI C12.1
• Utilizes split and solid core current transformers (CTs) that are
certified to all revenue grade accuracy standards
• Up to three sets of CTs per phase can be paralleled per meter
Indoor Series 3000
Advanced kWh Meters
Outdoor Series 3000
Advanced kWh Meters
SERIES 3000 ADVANCED KWH/DEMAND METER KITS
Note: Kits include meter, specified enclosure and required current transformers
INDOOR ENCLOSURE
OUTDOOR ENCLOSURE
VOLTAGE
AMPS
CTS INCLUDED
CAT. NO.
VOLTAGE
AMPS
CTS INCLUDED
CAT. NO.
120/208V
3PH 4W WYE
Demand Meter
100
3 Split CTs
3K208-01D
100
3 Split CTs
3O208-01D
200
3 Split CTs
3K208-02D
200
3 Split CTs
3O208-02D
400
3 Split CTs
3K208-04D
120/208V
3PH 4W WYE
Demand Meter
400
3 Split CTs
3O208-04D
800
3 Split CTs
3K208-08D
800
3 Split CTs
3O208-08D
1600
3 Split CTs
3K208-16D
1600
3 Split CTs
3O208-16D
3000
3 Split CTs 3
K208-30D
3000
3 Split CTs
3O208-30D
5000
3 Split CTs
3K208-50D
5000
3 Split CTs
3O208-50D
100
3 SOLID CTs
3K208-1SD
100
3 Split CTs
3O480-01D
200
3 SOLID CTs 3
K208-2SD
200
3 Split CTs
3O480-02D
100
3 Split CTs
3K480-01D
400
3 Split CTs
3O480-04D
200
3 Split CTs
3K480-02D
800
3 Split CTs
3O480-08D
400
3 Split CTs
3K480-04D
1600
3 Split CTs
3O480-16W
800
3 Split CTs
3K480-08D
3000
3 Split CTs
3O480-30D
1600
3 Split CTs
3K480-16D
5000
3 Split CTs
3O480-50D
3000
3 Split CTs
3K480-30D
100
3 Split CTs
3O600-01D
5000
3 Split CTs
3K480-50D
200
3 Split CTs
3O600-02D
100
3 SOLID CTs
3K480-1SD
400
3 Split CTs
3O600-04D
200
3 SOLID CTs
3K480-2SD
800
3 Split CTs
3O600-08D
100
3 Split CTs
3K600-01D
1600
3 Split CTs
3O600-16D
200
3 Split CTs
3K600-02D
3000
3 Split CTs
3O600-30D
400
3 Split CTs
3K600-04D
5000
3 Split CTs
3O600-50D
800
3 Split CTs
3K600-08D
100
3 Split CTs
3O24D-01D
1600
3 Split CTs
3K600-16D
200
3 Split CTs
3O24D-02D
3000
3 Split CTs
3K600-30D
400
3 Split CTs
3O24D-04D
5000
3 Split CTs
3K600-50D
800
3 Split CTs
3O24D-08D
100
3 SOLID CTs
3K600-1SD
1600
3 Split CTs
3O24D-16D
200
3 SOLID CTs
3K600-2SD
3000
3 Split CTs
3O24D-30D
100
3 Split CTs
3K24D-01D
5000
3 Split CTs
3O24D-50D
200
3 Split CTs
3K24D-02D
100
3 Split CTs
3O48D-01D
400
3 Split CTs
3K24D-04D
200
3 Split CTs
3O48D-02D
800
3 Split CTs
3K24D-08D
400
3 Split CTs
3O48D-04D
1600
3 Split CTs
3K24D-16D
800
3 Split CTs
3O48D-08D
3000
3 Split CTs
3K24D-30D
1600
3 Split CTs
3O48D-16D
5000
3 Split CTs
3K24D-50D
3000
3 Split CTs
3O48D-30D
100
3 Split CTs
3K48D-01D
5000
3 Split CTs
3O48D-50D
200
3 Split CTs
3K48D-02D
400
3 Split CTs
3K48D-04D
800
3 Split CTs
3K48D-08D
1600
3 Split CTs
3K48D-16D
3000
3 Split CTs
3K48D-30D
5000
3 Split CTs
3K48D-50D
277/480V
3PH 4W WYE
Demand Meter
347/600V
3PH 4W WYE
Demand Meter
208 or 240V
3PH 3W DELTA
Demand Meter
480V 3PH 3W
DELTA
Demand Meter
METERING SOLUTIONS
Series 3000 Advanced kWh Meters
277/480V
3PH 4W WYE
Demand Meter
347/600V
3PH 4W WYE
Demand Meter
208 or 240V
3PH 4W DELTA
Demand Meter
480V 3PH 3W
DELTA
Demand Meter
www.leviton.com/les
93
METERING SOLUTIONS
Mini Meter™
Equitable Tenant Billing
To be truly equitable, tenants should pay only for what they actually use. Leviton Mini Meter submeters enable building
managers to allocate energy usage costs fairly to multiple tenants, as well as recoup energy expenses from common-use
areas (parking lots, hall lighting, etc.). Tenants benefit by paying only for the energy they use; and when they focus on
conserving energy, they can see direct financial benefits from their efforts.
• Measures kWh
• Certified to all applicable standards of ANSI C12.1
• Equipped with an isolated pulse output for automated meter reading
• Available in indoor flush mount enclosure
• Available in NEMA 4X indoor/outdoor individual meter enclosures and Multiple Meter Units (MMUs) from 2 to 19 meters
• Utilizes split and solid core current transformers (CTs) that are certified to all revenue grade accuracy standards
• CTs feature a 0.1A secondary current, allowing up to three sets of CTs per phase to be installed in parallel per meter
• Components of Mini Meter Kits are UL Listed: “6” models UL/cUL Listed Energy Usage Monitor per CCN FTRZ; “7” models
UL/cUL Recognized Energy Usage Monitoring Equipment
• 1-Phase, 2-Wire applications, 120V and 1-Phase, 3-Wire applications, 120/208/240V
• 100A-200A Services
MINI METER KITS
Indoor Enclosure
NOTE: All kits include meter, specified enclosure and Current Transformers (CTs)
Voltage
Amps
CTs Included
CAT. NO.
120/208V 3W or
120/240V 1PH 3W (Split Phase)
100A
2 SOLID CTs
MK240-1SW
200A
2 SOLID CTs
MK240-2SW
Voltage
Amps
CTs Included
CAT. NO.
120/208V 3W or
120/240V 1PH 3W (Split Phase)
100A
2 SOLID CTs
MO240-1SW
200A
2 SOLID CTs
MO240-2SW
100A
2 Split CTs
MO240-01W
200A
2 Split CTs
MO240-02W
Outdoor Enclosure
120/208V 2PH 3W or
120/240V 1PH 3W (Split Phase)
Indoor Flush Mount
Mini Meter
Outdoor Mini Meter
94
Leviton meters utilize highly accurate current transformers for revenue-grade
performance certified to ANSI standards. Competing products use current sensors
that do not provide the same level of performance. Leviton offers CTs in solid and
split core styles to accommodate all phases of installation and construction. Both
solid and split core CTs have built-in voltage suppressors that prevent hazardous
voltages from developing should the CT wires become disconnected from the meter
while under load. All CTs offer high quality, long term accuracy and reliability.
Split Core
Current Transformers
ORDERING INFORMATION
NOTE: Meters sold separately.
AMP
CAT. NO.
DESCRIPTION
SINGLES
Solid Core
Current Transformers
SOLID CORE
100:0.1A
CDE01-K11
Solid Core, 0.67”, Black
100:0.1A
CDE01-L11
Solid Core, 0.67”, Blue
100:0.1A
CDE01-R11
Solid Core, 0.67”, Red
200:0.1A
CDA02-L12
Solid Core, 0.72”, Blue
200:0.1A
CDE02-R11
Solid Core, 0.67”, Red
200:0.1A
CDA02-R12
Solid Core, 0.72”, Red
200:0.1A
CDE02-K11
Solid Core, 0.67”, Black
200:0.1A
CDE02-K12
Solid Core, 0.72”, Black
200:0.1A
CDE02-L11
Solid Core, 0.67”, Blue
100:0.1A
CTD01-K16
Split Core, .75” x .75”
200:0.1A
CTD02-K16
Split Core, 1” x 1”
400:0.1A
CDF04-K24
Split Core, 1.5”
400:0.1A
CTD04-K23
Split Core, 1.4” x 1.4”
800:0.1A
CTC08-K46
Split Core, 3” x 3.5”
1200:0.1A
CTC12-K46
Split Core, 4” x 6”
1600:0.1A
CTC16-K96
Split Core, 4” x 6”
3000:0.1A
CTC30-57B*
Split Core, 5” x 7”
5000:0.1A
CTC50-57B*
Split Core, 5” x 7”
AMP
CAT. NO.
DESCRIPTION
100:0.1A
CDE01-211
CT Kit, 0.67”, Red, Black
100:0.1A
CDE01-311
CT Kit, 0.67”, Blue, Red, Black
200:0.1A
CDE02-211
CT Kit, 0.67”, Red, Black
200:0.1A
CDE02-311
CT Kit, 0.67”, Blue, Red, Black
200:0.1A
CDA02-212
CT Kit, 0.72”, Red, Black
200:0.1A
CDA02-312
CT Kit, 0.72”, Blue, Red, Black
METERING SOLUTIONS
Current Transformers
SPLIT CORE
KITS
*Consult factory for availability
Leviton recommends solid core transformers (CTs) for revenue-grade accuracy. Our 100A and 200A
color coded CTs assist with correct installation by indicating phase monitored. Split core CTs are
also available upon request for applications where power cannot be interrupted during installation.
www.leviton.com/les
95
METERING SOLUTIONS
Multiple Meter Units (MMUs)
Leviton’s Multiple Meter Units (MMUs) are ideal for multi-family residential applications—allowing building managers to monitor and bill each
tenant based on actual energy use. Tenants are accountable only for
the energy they use, and have more motivation to conserve energy to
save money. Building managers are able to easily track the energy use
in common areas (parking lots, hall lighting, etc.) to recover these previously hard-to-allocate costs, and divide them fairly among tenants.
For both retrofit and new construction, Leviton MMUs are fast and
easy to install. They come pre-wired per project panel schedules with
clearly labeled connections, minimizing the electrical installation
time, another great money saving feature.
Extra Large Mini Meter
Multiple Meter Unit
(MMU)
Large Mini Meter
Multiple Meter Unit
(MMU)
All Leviton MMUs are UL Listed assemblies, giving your customers extra assurance for no extra cost. Choose from an indoor
steel model in 4/8/16 unit single- or three-phase configurations or a weatherproof outdoor enclosure in 4/8/19 single-phase
meter configurations for about the same price (Outdoor enclosure option for Mini Meter MMUs only). If your application
requires a different configuration, Leviton is ready to help.
ORDERING INFORMATION
SERIES 2000 MMUs
Mini Meter MMUs
Voltage
Description
CAT. NO.
120/240V 1PH 3W
120/208V 3PH 4W
120/208V 3PH 4W
120/208V 3PH 4W
96
CAT. NO.
2M202-CFG
3 Three Element Meters
2M203-CFG
6M204-CFG
4 Three Element Meters
2M204-CFG
2 Dual Element Meters
6M302-CFG
2 Three Element Meters
2M402-CFG
3 Dual Element Meters
6M303-CFG
3 Three Element Meters
2M403-CFG
4 Dual Element Meters
6M304-CFG
4 Three Element Meters
2M404-CFG
6M202-CFG
3 Dual Element Meters
6M203-CFG
4 Dual Element Meters
120/208V 3PH 4W
277/480V 3PH 4W
LARGE SERIES 2000 MMU, 5-8 METERS
5 Dual Element Meters
6L205-CFG
5 Three Element Meters
2L205-CFG
6 Dual Element Meters
6L206-CFG
6 Three Element Meters
2L206-CFG
7 Dual Element Meters
6L207-CFG
7 Three Element Meters
2L207-CFG
8 Dual Element Meters
6L208-CFG
8 Three Element Meters
2L208-CFG
5 Dual Element Meters
6L305-CFG
5 Three Element Meters
2L405-CFG
6 Dual Element Meters
6L306-CFG
6 Three Element Meters
2L406-CFG
7 Dual Element Meters
6L307-CFG
7 Three Element Meters
2L407-CFG
8 Dual Element Meters
6L308-CFG
8 Three Element Meters
2L408-CFG
EXTRA-LARGE MINI METER MMU, 9-19 METERS, NEMA
4X ENCLOSURE
120/240V 1PH 3W
Description
2 Three Element Meters
2 Dual Element Meters
LARGE MINI METER MMU, 5-8 METERS
120/240V 1PH 3W
Voltage
MEDIUM SERIES 2000 MMU, 2-4 METERS
MEDIUM MINI METER MMU, 2-4 METERS
120/208V 3PH 4W
277/480V 3PH 4W
EXTRA-LARGE SERIES 2000 MMU, 9-16 METERS
9 Three Element Meters
2X209-CFG
9 Dual Element Meters
6X209-CFG
10 Three Element Meters
2X210-CFG
10 Dual Element Meters
6X210-CFG
11 Three Element Meters
2X211-CFG
11 Dual Element Meters
6X211-CFG
12 Three Element Meters
2X212-CFG
12 Dual Element Meters
6X212-CFG
13 Three Element Meters
2X213-CFG
13 Dual Element Meters
6X213-CFG
14 Three Element Meters
2X214-CFG
14 Dual Element Meters
6X214-CFG
15 Three Element Meters
2X215-CFG
15 Dual Element Meters
6X215-CFG
16 Three Element Meters
2X216-CFG
16 Dual Element Meters
6X216-CFG
9 Three Element Meters
2X409-CFG
17 Dual Element Meters
6X217-CFG
10 Three Element Meters
2X410-CFG
18 Dual Element Meters
6X218-CFG
11 Three Element Meters
2X411-CFG
19 Dual Element Meters
6X219-CFG
12 Three Element Meters
2X412-CFG
9 Dual Element Meters
6X309-CFG
13 Three Element Meters
2X413-CFG
10 Dual Element Meters
6X310-CFG
14 Three Element Meters
2X414-CFG
11 Dual Element Meters
6X311-CFG
15 Three Element Meters
2X415-CFG
12 Dual Element Meters
6X312-CFG
16 Three Element Meters
2X416-CFG
13 Dual Element Meters
6X313-CFG
14 Dual Element Meters
6X314-CFG
15 Dual Element Meters
6X315-CFG
16 Dual Element Meters
6X316-CFG
17 Dual Element Meters
6X317-CFG
18 Dual Element Meters
6X318-CFG
19 Dual Element Meters
6X319-CFG
120/208V 3PH 4W
277/480V 3PH 4W
Leviton/
3rd Party Meters
Meter Network
Data Collection
External
Communication
Stakeholders
ONSITE
Electric
LAN
Water
On-Site
PC/
Server
Building
Management
System
METERING SOLUTIONS
LEVITON METERING SOLUTIONS SYSTEM ARCHITECTURE
CLOUD
OFFSITE
Gas
Wide Area
Network
Leviton Energy
Manager
ModBus RS485
Serial Network
ModBus TCP
Steam
Pulse, Analog
Data Pushed
HTTP & FTP
.CSV/XML
Third Party
Billing
Energy Services
Provider
LAN equipment available from others.
www.leviton.com/les
97
METERING SOLUTIONS
METERING COMMUNICATIONS SYSTEMS
To create a data network between Leviton submeters and stakeholders (BAS, third party billing, Leviton Energy Manager
software, etc.), Leviton offers Metering Communication Systems. These solutions transmit data from meters to end
systems, creating a seamless transition between data collection and data display. Leviton Metering Communications
Systems also enable facilities to create metering systems that can easily share data through open protocols such as
Modbus, and IP-based data transfer through HTTP/FTP of .csv or XML files. The results are robust and reliable networks
scalable to accommodate future expansion, with data made accessible from any internal or external location.
METERING COMMUNICATION HUBS
Metering Communication Hubs, including the Energy Monitoring Hub (EMH), EMB and EMBLite, are intelligent, flexible data
acquisition servers allowing users to collect energy data from meters and environmental sensors. Designed to connect to
IP-based applications such as enterprise energy management, demand response and smart grid programs, Hub servers let
you connect thousands of energy points, benchmark energy usage and reduce energy costs.
• Collects and logs data from connected wired or wireless devices based on user-set intervals
• Pushes or pulls data via HTTP, XML, FTP or any custom protocol using an Ethernet (LAN) connection
• No software required: Information can be accessed through any web browser in any location
• Plug and play connectivity
• Compatible with nearly any front-end software platform allowing customers to use a variety of reporting tools
• Push or pull meter data to energy dashboards, kiosks and software applications
• Monitor performance of critical systems (lighting, HVAC, PDUs, inverters, etc.)
ORDERING INFORMATION
CAT. NO.
DESCRIPTION
A8812-001
Energy Monitoring Hub – Configured for
Leviton Energy Manager
A8812-000
Energy Monitoring Hub – Non-Configured
A8810-000
EMB Hub
A7810-000
EMB HubLite
YBM05-010
Power Supply for EMB Hub and EMB HubLite
EMB HubLite
Energy Monitoring Hub
MODHOPPER
The ModHopper is a breakthrough mesh technology design that makes connecting Modbus RTU (RS485) and pulse devices simple and cost effective. Our “smart” ModHopper transceivers eliminate the need for costly wiring runs allowing users
to capture meter data in the most challenging retrofit and campus environments. Collect meter points in existing buildings
with minimum down-time or disruption of day-to-day operations.
• Designed specifically for wireless metering and Leviton Metering Solutions for guaranteed compatibility
• No software or programming required and devices automatically configure when powered, reducing labor costs and
installation time
• Wireless “mesh” network—self-healing, self-optimizing for ease of installation and maintenance
• Connect up to 32 Modbus and 2 pulse devices per ModHopper for the ultimate expandable solution
• Long distance communication (3000ft indoor/14 miles LOS) for flexibility of placement and easier future expansion
• Multiple independent network capability
• Reliable, constant two-way communication and packet verification
• Point to multi-point communication
• Field upgradable firmware for user-friendly future upgrades and expansion
ModHopper
98
The High Density Pulse Module provides a convenient way to expand a Leviton Metering
System by connecting the HD Pulse Module to an Energy Monitoring Hub (EMH) and/or
ModHopper for system expansion. The HD Pulse Module accepts up to 23 standard pulse
sensors and can function as a slave device with any Modbus master. This data can easily
be integrated to a network of other critical energy sensors to provide a comprehensive
energy monitoring solution. The HD Pulse Module is ideal for applications with a high
density of pulse output devices, giving users access to meters that would previously
require multiple modules.
• External communications handled via shielded twisted pair 18-22 gauge wire allowing
communication up to 4000 feet and pulse input communications up to 200 feet
(consult factory for longer runs) using 18-24 gauge control wire
High Density Pulse Module
• DIN or wall mounting make installations quick and easy
• Device verification - LED indicators for each pulse input allow for fast indication and verification of pulses to reduce
installation and troubleshooting time
• Non-volatile memory retains configuration and pulse count totals during power failures for reliable data collection and
retention
METERING SOLUTIONS
HIGH DENSITY PULSE MODULE
• Easily add pulse meters to Modbus network for a scalable, open protocol solution
• Field upgradable firmware for user-friendly future upgrades and expansion
FLEX I/O MODULE
The Flex I/O Module is a cost-effective way to collect data from meters or sensors and bring the information into a Modbus
network or energy monitoring system. As a stand-alone or bundled package, the Leviton Flex I/O can be incorporated with
data acquisition and metering devices to provide a cost-effective energy monitoring solution. The Flex I/O is compatible
with virtually any Modbus master, allowing customers the flexibility to use it in existing Modbus networks. Use with the
Leviton Energy Monitoring Hub (EMH).
• Easily add meters and sensor to Modbus network
• 8x user selectable inputs
• 2x output relays
• 2x pulse replicator
• Non-volatile memory
• Industrial temperature range (-30°C to 70°C)
• LEDs for visual verification/status reduce installation and
troubleshooting time
Flex I/O Module
• Din or wall mount for easy installation
• Field upgradable firmware for user-friendly future upgrades
and expansion
ORDERING INFORMATION
CAT. NO.
DESCRIPTION
A8911-000
High Density Pulse Module, 23 Inputs
A8332-000
Flex I/O Module, 8 User Selectable Inputs, 2 Relay Outputs
R9120-500
ModHopper and Power Supply
www.leviton.com/les
99
METERING SOLUTIONS
Energy Manager Monitoring Software
Measure. Monitor. Manage. If You Don’t Measure It, You Can’t Manage It!
Energy monitoring and reporting is the key to measuring and managing energy efficiency and cost.
Save Energy, Reduce Costs, Be Sustainable
With a competitive global economy, soaring energy prices, increasing environmental issues and technology-based decision
making, your profitability depends on the ability to analyze and control operating costs. Better energy management saves
money and translates to an improved bottom line.
Decision makers everywhere are turning to Leviton Energy Manager to get the information they need to make smart energy
choices. An advanced web based platform that provides real time data for your entire enterprise, Leviton Energy Manager
gives you the most sophisticated tools to drive energy efficiencies, reduce operating costs and create more sustainable,
environmentally sound facilities.
How Leviton Energy Manager Works
Simple, Effective, Turn Key Solution to Monitor Energy in Real Time
Internet
Leviton
Submeters
Energy
Monitoring
Hub (EMH)
Leviton
Energy Manager
Data Center
User Interface
Energy Manager
Web Reports
• Meters record real time consumption data
• Energy Monitoring Hub (EMH) receives meter data and pushes it to Energy Manager data center
• Data Center stores, manages and reports data in real time
• Energy Manager software analyzes, formats and reports the data
• User logs into Energy Manager website and accesses data and reports
Leviton Energy Manager is Packed with Features
Leviton Energy Manager Package
• Illustrates information in real time
• Load profiling and benchmarking
• Works with existing meters
• Easy to install and use
• Measure & validate
• Scalable to an unlimited number of meters
• Configurable on-site system
• Instant alarm notification system
Energy Monitoring Hub (EMH)
• Easy to install
• Fully expandable for any sized application
• Accepts all meter types
• Compatible with ModBus RTU metering
• Plug & Play - no programming needed
• Collects real time energy data in 15 minute
intervals
• Automatically pushes data to Energy
Manager data center
100
Energy Manager Monitoring Software
• Simplified, easy to use with intuitive drilldown
functionality
• Instant productivity for all users
• All reports are no more than three clicks away!
• Real-time Report
• Daily Report
• Weekly Report
• Weekly Profile Report
• Monthly Report
• Monthly Profile Report
• Annual Report
• Comparison Report
• Carbon Emissions Report
• Energy Center Report
METERING SOLUTIONS
Energy Manager Monitoring Software
Detailed Reporting in Just Three Clicks!
Daily Report
Energy Center Report
Annual Report
Carbon Emissions Report
Comparison Report
Multiple Meter Analysis Report
Energy Manager Monitoring Software
CAT. NO.
DESCRIPTION
Year One
LEMSB-000
Energy Manager Software - Base License Program - includes (8) control points and (1) user account
LEMSP-000
Energy Manager Software - Additional Points License - includes (8) control points
Annual Renewal
LEMSB-R00
Energy Manager Software - Base License Program Renewal
LEMSP-R00
Energy Manager Software - Additional Points License Renewal
www.leviton.com/les
101
102
www.leviton.com/les
103
LIGHTING CONTROL SOLUTIONS
lighting control solutions | OEM
104
For OEM Applications
Leviton offers a range of devices for fixture manufacturers
designed to help you capitalize on the growing demand for
energy efficient lighting. Through intelligent design of innovative products that keep
pace with the latest trends in lighting, Leviton OEM products can help you control costs and
streamline the assembly process—all while adding value to your products.
Zipline is an industry-first linear fluorescent lighting fixture retrofit
solution that dramatically reduces installation time and eliminates
wiring errors. This patent-pending Leviton innovation integrates the
entire lighting system into two simple to install components, cutting
retrofit installation time by up to half. This translates to less downtime for facility managers, and more productivity for contractors.
Additionally, Zipline eliminates socket wiring errors by eliminating
socket wiring, making it a virtually error-proof system.
Zipline uses a ballast design with over a decade of field proven
performance, and is constructed of ultra-duty polycarbonate for
industry-leading service life.
THE OLD WAY:
THE ZIPLINE WAY:
A labor-intensive and time-consuming process:
An integrated modular solution:
• Removal, replacement and re-wiring of ballast and
ampholders
• Ballast and lampholders are integrated into one unit
• Multiple connections, fasteners and wiring
• Installs quickly and easily using only two screws per side
• Potential for installation errors
FEATURES
lighting control solutions | OEM
ZIPLINE™ FLUORESCENT RETROFIT SOLUTION
ORDERING INFORMATION
• Easy to install
Cat. No.
• Fits most 2x2 and 2x4 ceiling troffers
ZIPLINE COMPONENTS
• Available in 2- and 3-lamp configurations
360RC-002
2-lamp, normal ballast factor system
• Snap-in reflectors available
360RC-012
2-lamp, low ballast factor system
• Available in high, normal and low ballast factors
360RC-022
2-lamp, high ballast factor system
• 5 year limited warranty
360RC-003
3-lamp, normal ballast factor system
• Integrated ballast with 10 years of proven reliability
in service
360RC-013
3-lamp, low ballast factor system
Description
ZIPLINE REFLECTORS
REFLT-402
2-Lamp, white, 4ft reflector,
91% reflectivity
REFLT-412
2-lamp, enhanced aluminum,
4ft reflector, 95% reflectivity
REFLT-403
3-lamp, white, 4ft reflector,
91% reflectivity
REFLT-413
3-lamp, enhanced aluminum,
4ft reflector, 95% reflectivity
REFLT-202
2-lamp, white, 2ft reflector,
91% reflectivity
REFLT-212
2-lamp, enhanced aluminum,
2ft reflector, 95% reflectivity
REFLT-203
3-lamp, white, 2ft reflector,
91% reflectivity
REFLT-213
3-lamp, enhanced aluminum,
2ft reflector, 25% reflectivity
www.leviton.com/les
105
lighting control solutions | OEM
Fluorescent Lampholders
Lamp and ballast technologies have evolved significantly during the last ten years and their improved efficiency ratings
have made it attractive for businesses and institutions to replace their old, fluorescent lamps with new, more energyefficient lamps. With strong demand for T-8 and T-5 linear fluorescent bulbs and fixtures in this highly competitive market,
any device that lowers your cost and increases profitability can be important to your business. Leviton’s extensive line of
fluorescent lampholders includes:
• Miniature bi-pin fluorescent T-5 lampholders
• T-8-to-T-5 lampholder adapter
• 2G11-based fluorescent lampholders
• Dedicated T-8 bi-pin fluorescent lampholders
• A full line of compact fluorescent lampholders
26800
26725-202
26730, 36735, 26740
23652, 23653, 23654
RENOIR™ II COMMERCIAL DIMMERS
Packaging Renoir™ II dimmers with your fixtures and selling them as one lets you offer an attractive option to those seeking
a complete lighting energy management solution. The Renoir II line includes options for switch, slide and rotary dimmers,
and these stylish controls are available in thin and standard heat sink with multiple gangs. With a variety of colors and
finishes from which to choose, there’s a dimmer to complement just about any fixture.
Renoir II Slide
Preset Master
Standard
Heat Sink
106
26725-201
Renoir II Rotary
Preset Master
Renoir II Slide
Master Thin
Heat Sink
Renoir II Rotary
Preset Master
Renoir II Remote
Switch Thin
Heat Sink
In addition to the inherent benefits of increased efficiency, such
as conserving precious resources and minimizing air pollution,
green lighting controls deliver big savings. According to the American
Lighting Association, lighting accounts for 25 percent of the average homeowner’s
electric bill. Between the rising cost of energy and an increased concern for the
environment, it’s no wonder that home-owners have become eager to incorporate
energy-efficient lighting controls and devices in their homes.
Occupancy sensors, motion sensors and timers are not only convenient and safety-enhancing, but
they also reduce electricity consumption. And there’s one more reason to use lighting controls in
new construction: even in the residential arena, energy efficiency codes are increasingly becoming
the law of the land. Lighting control devices can make a significant contribution to a home’s ability to
meet energy efficiency standards including California’s Title 24. Although they are not as “green” as
their fluorescent counterparts, many homeowners find incandescent lighting much more appealing
because of the warm quality of the light itself and because of the wide selection of designer fixtures.
Leviton’s incandescent lighting controls allow homeowners to save on electricity while enjoying
the lighting they really want. As new technologies evolve and become more commonplace, Leviton
continues to keep up with the pace. We offer dimmers that control dimmable LED and CFL light sources.
Whatever the homeowner’s preference, we offer a quality solution.
www.leviton.com/les
lighting control solutions | Residential
For Residential Applications
107
lighting control solutions | Residential
Single- or multi-family homes of style
Every day, in homes all across the country, people rely
on Leviton’s lighting controls to illuminate their way and
reduce their electricity bills. Our extensive line of reliable
Decora® controls includes residential occupancy sensors,
timers and dimmers—and our Vizia +® designer lines
provide the ultimate in aesthetics and state-of-the art
technology.
Universal dimmers set
the mood and work with
an incandescent, dimmable
LED or dimmable CFL bulbs.
Timers ensure outdoor
lights are on during
specific nighttime periods
and turn off automatically
at others.
Motion sensor to light
driveway and garage
as person approaches
and to time out after
person has left.
T24: Complies with
California Title 24.
108
Fluorescent Ceiling
Lampholder for bright,
efficient garage
lighting and built-in
occupancy sensor to
activate or turn off
lights automatically
Occupancy sensorsT24 and
timers ensure that lights
and fans don’t stay on any
longer than they need to. Scene lighting for
one touch dimming
of all lights.T24
Dimmers set the mood
with lighting while
reducing electricity bills.T24
Cooking, cleaning, eating and doing homework: there’s a lot going on in the typical kitchen. In a large kitchen, there may be
several banks of lights for illuminating different areas. To meet standards such as California’s Title 24 up to one half of all
lights in this room must be fluorescent; the other half may be incandescent or low-voltage fixtures, which may be dimmed
to suit the task at hand while minimizing electricity usage. Dimmers give the homeowner the ability to control each bank of
lights separately. Matching on/off switches can be installed to control required, high-efficacy lighting.
Matching
Switch
Remote
(VP0SR-1L)
Electronic
Switch
(VPS15)
Incandescent
Dimmer
ELV
(VPI06)
Dimmer
(VPE06)
Matching
Dimmer
Remote
(VP00R-1L)
In the bathroom
Dimmers, timers and occupancy sensors can all be combined to reduce energy consumption in the bathroom. With a Vizia +
dimmer attached to a manual-on occupancy sensor remote, lights can be kept down low except when needed for tasks
that require extra light, like shaving and applying makeup. They can turn off by themselves after the room is vacated.
To combat excess humidity, the exhaust fan can be wired to a Decora preset timer so it can run for a set period of time
before automatically shutting off.
Residential Kitchen - Diagram 1
lighting control solutions | Residential
In the kitchen
© Copyright 2006 Christopher A. Carbone, Inc. All Rights Reserved.
Preset Timer
(LTB30)
Dimmer
(VPI06)
Manual-On
Occupancy
Sensor Remote
(IPP0R-1L)
www.leviton.com/les
109
lighting control solutions | Residential
In the laundry room
People often leave the laundry room with their hands full so it’s easy to see why the lights there are prone to being left on.
The easy solution is to install a vacancy sensor: a manual-on sensor to ensure maximum energy savings. If meeting codes
such as California Title 24 is not an issue, consider installing a standard Leviton Wall Switch occupancy sensor (PR150 or
PR180). Either of these sensors will turn on the lights when motion is detected, which is convenient when carrying a heavy
basketful of laundry.
Manual-On
Vacancy
Sensor
(IPP15-1L)
Outside the house
Exterior lighting is one of the most basic home security measures but there’s a downside: if left on, these lights can waste
a lot of electricity. Adding sensors and timers to the scenario allows exterior lights to turn and remain on only when they
have value from a security or safety perspective. With outdoor motion sensors, lights turn on only when needed and for a
limited period of time. Timers, on the other hand, can illuminate entrances to deter would-be trespassers. A Compact
Fluorescent Ceiling Lampholder with an Occupancy Sensor inside the garage can automatically turn the lights on when a
car or person enters the garage and off automatically when the car or person exits.
Residential Laundry Room - Diagram 4
© Copyright 2006 Christopher A. Carbone, Inc. All Rights Reserved.
Motion Sensor
with Integral Light
(RS110-1F)
Compact
Fluorescent Ceiling
Lampholder with
Occupancy
Sensor
(9863)
110
Programmable
Timer (VPT24)
There is much more to making lighting more energy efficient than just installing a simple device or two. System design,
product selection, installation and service: it has all got to come together. That’s where Leviton service and support
options come in. We’ll help you design your system and make the right product selections so you can create a lighting
control system that does exactly what you want it to do while saving electricity, meeting codes and standards, and even
garnering rebates.
It all starts with the Leviton sales representative. Our lighting control specialists are here to support you every step of the
way. They can perform on-site facility audits and suggest specific products and strategies for improving lighting energy
efficiency.
Exclusive Wealth of Resources
• Occupancy sensor layout services – have a team of experts create
occupancy sensor layouts directly on your CAD drawings, complete
with a List of Equipment at no cost – go to portal.leviton.com
LEVITON SUPPORT
Service and Support During Every Step of the Process
• LightLogger® Program – get an accurate estimate of your
energy-savings potential with this exclusive payback analysis tool –
go to www.leviton.com/logger
• ez-Learn – get sensor smart in just 90 minutes from the comfort of
your home or office with this exclusive 24/7 online training – go to
www.leviton.com/ezlearn
• ASAP Lighting Design software – point-and-click software allows
you to quickly and simply design, specify and enter orders – go to
www.leviton.com/asap
• Find more exclusive no cost design tools at www.leviton.com/lesdesign
• Lighting control specialists at your disposal
• Field service engineers for top-level support
• Factory commissioning service
• Dedicated technical support via phone at 800 959-6004
Contact your local Leviton Lighting Control Specialist
to get your free energy audit, or call 800-323-8920.
Leviton Lighting Energy Management Products:
• LevNet RF™ Energy Harvesting Self-Powered Solutions
• Wall Switch, ceiling-mount, wall-mount, fixture-mount and energy harvesting vacancy and occupancy
sensors
• Outdoor motion sensors
• Box-mounted dimmers including Vizia +®, Monet™, Renoir™, Van Gogh™, Mural®, True Touch™, ToggleTouch™,
IllumaTech™, SureSlide™ and Trimatron™
• Renu® switches, dimmers and outlets
• Universal dimmers for dimmable LED, dimmable CFL and incandescent
• Zipline™ fluorescent retrofit solution
• Dimensions® dimming systems
• Preset and programmable electronic timer switches
• Relay Systems including GreenMAX®, EZ-MAX® Plus, and miniZ™
• Sector® Intelligent Ballast and Lighting Control System
• Compact Fluorescent Ceiling Lampholders
www.leviton.com/les
111
Leviton Manufacturing Co., Inc. Lighting & Energy Solutions
20497 SW Teton Avenue
Tualatin, OR 97062
Tel: 503-404-5555
Fax: 503-404-5594
Tech Line (6:00AM-4:00PM P.S.T. Mon-Fri): 1-800-959-6004
Leviton Manufacturing Co., Inc. Global Headquarters
201 N. Service Rd.
Melville, NY 11747-3138
Tech Line: 1-800-824-3005
Fax: 1-800-832-9538
Leviton International
Middle East & Africa
Canada
South Korea
T +971-4-886-4722
T +1-514-954-1840
T +82-2-3273-9963
F +971-4-866-4723
F +1-514-954-1853
F +82-2-3273-9962
E [email protected]
E pcservi[email protected]
E [email protected]
China
ASEAN Countries
Australia & New Zealand
T +852-2774-9876
T +65-9824-4468
T +64-4-562-8327
F +852-2774-1741
F +65-9464-9592
F +64-4-562-8327
E [email protected]
E [email protected]
E [email protected]
Latin America
Europe
India
T +52-55-5082-1040
T +47-40-60-30-30
T +91-80-6579-1273
F +52-55-5386-1797
F +47-40-60-30-31
E [email protected]
E [email protected]
E [email protected]
facebook.com/leviton
twitter.com/leviton
youtube.com/levitonmfg
Visit our Website at: www.leviton.com/les
G-8047B/H12-ak
2012 Leviton Manufacturing Co., Inc. All rights reserved. Subject to change without notice.
‘USGBC’ and related logo is a trademark owned by the U.S. Green Building Council and is used by permission
The American Recovery And Reinvestment Act of 2009 (“ARRA”) provides federal grants and loans for projects throughout the country. Section 1605 of the Act, named the “Buy American” provision, requires
that certain materials and manufactured products used in projects funded by the Act be manufactured in the United States. The appearance of the Recovery Act Logo in relation to a Leviton product is only
intended to reflect that such product may be used in an ARRA funded project. It does not mean that such product or Leviton is sponsored or endorsed by, or that Leviton receives funds from, the federal
government or the Recovery Accountability and Transparency Board. Nothing in Leviton’s use of the logo is intended to suggest anything regarding the requirements for funding under ARRA.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
