PRODUCT CATALOGUE 2012/13
musiclights.it
Product Index
ProLights è un brand di Music & Lights Company
Moving heads
Music & Lights is a leader in the show business industry, its growth has been guided by the achievements
of its brands on the global market and by the continuous efforts of a young and dynamic team.
Our target is to offer creative and competitive solutions, supporting work of our customers.
Quality and commercial seriousness are the values that in the meantime we pursue with consistency,
availing ourselves of an open, fair and constructive communication.
Prolights product line for professional lighting is the result of a rigorous R&D process in technology
supported by a strong impulse for innovation, having the aim of developing solutions excelling in all
fields of entertainment and architectural lighting.
Careful selection of optics, mechanics and building materials is the basis of Prolights philosophy of
development, allowing the achievement of a superior standard in performance, luminous efficiency,
precision and reliability.
Close relationship with professionals - LD, architects and photography directors - provides a valuable
feedback inspiring development with their needs and their wishes, to deliver luminaires of surpassing
quality and performance in the wide and creative environment of professional lighting.
Zenith Series
6
Cromo Series
24
Vision Series
42
LED projectors
ArcLed Series
48
LedMatrix
82
LED wall
Ambient
Vortex Series
100
Follow spot
109
Theater
Accessories
Accessories
110
Moving heads
Prolights line of moving heads is composed of 19 models featuring different Spot, Beam and Wash projectors, resulting as one of the widest in the field of professional
lighting. Zenith, Vision and Cromo series infact have luminaires covering all different requirements of lighting projects, implementing latest innovations in optics,
mechanics and electronics and making them available to professional users.
Prolights moving heads are designed and engineered for highest versatility in live events, theaters, TV studios, corporate events and all rental applications in professional
show lighting.
Advanced optical efficiency and selection of components
Superiore luminous efficiency of Prolights projectors is guaranteed by a continuous
research and selection of optical components, offering high-profile performance
in terms of precision and reliability.
Lenses developed and fine-tuned by our R&D department are optimized to
constantly obtain the maximum output from light sources (>85% for LEDs).
Our whole range of intelligent projectors employs Philips lamps and latestgeneration CREE LED diodes, surpassing other projectors of same nominal power
in terms of luminance.
Fast-Zoom even on LED projectors
Prolights has always carried out a thorough study of optical components, with
the aim of reaching optimal results in terms of precision and homogeneity,
angle amplitude and velocity of zooming technology. LED projectors of Prolights
range are infact among the first ones ever implementing “fast-zoom” technology.
Innovative elliptical optics and motorized optical panels allow to switch from a
spot beam to a wide flood to have performance of both beamers and washers.
Homogeneous electronic and mechanic dimmer
The control of a combination of electronic and mechanic dimming allows Prolights
moving heads to ensure a complete homogeneity of projection and a linear control
over the whole 0-100% range.
Electronic dimming also allows reduction of heat generation, minimizing typical
causes of malfunctioning and extending lamps life.
This same feature is even further essential for projectors employing LED technology,
whereas an efficient power management maximizes luminance and extends diodes
life (>50.000h).
Vivid and natural colors over the whole chromatic range
Prolights projectors are equipped with most advanced chromatic calibration
systems to deliver rich uniform colors, with no distorsions or halos on the edges.
Color wheels employ dichroic filters to enhance source light, having thermal
properties ensuring highest efficiency combined with durability.
CMY color mixing satisfies most demanding chromatic requirements, allowing a
smooth and uniform transition between shades, with CTO and CTB filters offering
control over color temperature adjustment.
LED-based projectors offer RGB color synthesis to reproduce the whole chromatic
range with White and Amber diodes enabling fine-tuning of color temperature.
A virtual color wheel is available on all LED projectors for selection of several premixed colors.
An exceptionally rich set of effects
Prolights series spotlights offer an amazing and wide set of effects, employing
latest technologies for generation of eye-catching effects. Gobos are designed
to reproduce striking moving rays in the air and impressive static and moving
projections. All spotlight models are equipped with 2 gobo wheels placed ont
different focusing layers to create impressive Morphing effects in combination with
the linear motorized focusing system.
Graphic effects are even further exhalted by fixed and rotating prisms, iris and frost
lenses with variable intensity.
Gobos mounted into Prolights projectors are interchangeable, custom gobos can
be easily installed using the magnetic locking mechanism.
Latest generation modular electronics
Electronics in Prolights moving heads features advanced components, software
and constructive modularity, optimizing mechanical performance and allowing
comfortable and interactive usage.
A LCD graphic display enables the user to access a control menu rich of informations
and settings. Electronics constantly executes a check-up of all working parameters
and of internal temperature, displaying diagnostics status.
The innovative energy-saving system reduces consumption to 50% during nonoperating status, enabling a temporary stand-by mode for electronics which is
instantly restored when any DMX signal is sent.
Assembly of Prolights projectors is completely modular, every component can
infact be accessed with no need of removing parts not involved in the intervention.
Quiet operations and lack of any luminous dispersion
Prolights moving heads are remarkable for being quiet in working operations.
In the high-profile constructive features, projectors use an innovative internal
cooling system plus electronics allowing dynamic adjustment of fan rotation speed,
reducing undesirable noises.
This is a distinguishing feature in design of lighting projects in theaters and TV
studios, where no noise as well as lack of any luminous dispersion are primary
requirements.
Highest attention to requirements of lighting specialists
All projects of Prolights moving heads are inspired by requirements and wishes of
lighting specialists. Dimensions and weighing of projectors are an evidence of this
logic: a professional luminaire like Zenith 700 Spot features a compact 40cm mobile
head in a total weight of 20kgs only. All processes of positioning, mounting and
transportation are then highly optimized to reduce time and energies required,
hardware parts and carriage accessories of each projector are carefully designed.
For these reasons rigging operations are facilitated, overall dimensions are reduced
and setup operations do not require lots of personnel anymore.
Contents - Moving heads
Zenith Series
Z1200 Spot
Z1200 Wash
Z700 Spot
Z300 Beam
Z4000 Digital
Z2500 Digital
Slash
Titan
8
10
12
14
16
18
20
22
Cromo Series
Cromo Wash 600
Cromo Wash 300
ElfinFc
ElfinVW
Cromo Wash 100
Cromo Spot 500
Cromo Spot 250
Cromo Beam 250
Cromo Spot 150
24
26
28
30
32
34
36
38
40
Vision Series
V575 Spot 42
V575 Wash 44
Z1200SPOT
DISCHARGE
1200W
zoom
12°/30°
CMY+CTO
C°
-10 +40
IP20
Zenith 1200SPOT is the Prolights moving-head projector developed with cutting-edge technological
contents and mechanical solutions. The brightness, the construction quality and the effects section
make Z1200SPOT the perfect item for concerts, shows, TV studios, theatres and large venues. Z1200
Spot, equipped with Philips MSR Gold 1200 FastFit lamp with electronic ballast features linear CMY
colour mixing system, linear CTO, an additional colour wheel (7 colours + open), linear motorized zoom
(12°-30°), motorized iris and focus, 2 gobos wheels, 3 different modes of rotating prism.
Lamp
• Philips MSRGold 1200W Fastfit (cod. 800186 included)
• Socket : PGJX50
• Colour temperature: 6300 K
• Luminous flux: 95.000 lm
• Average life span: 750 h
Optics
• High definition anti-reflection lenses with achromatic coating
• Parabolic glass reflector with dichroic coating
• 12°-30° electronic linear zoom
• Focus: motorized focusing, from 2 m to infinity
Dimmer / shutter / strobe
• 0-100% linear dimmer
• Independent shutter and fading effects with adjustable speed
• Strobe: mechanical, 8 flash per second
Compatible with WR24A
Antenna receiver
Scan with your PHONE
to view product page.
8
Accessories
FCZ1200S (optional): Carrying Roadcase designed to contain 1pc of Zenith 1200Spot Dim. 700x900x620 mm
WR24A (optional): DMX Antenna receiver, 2,4GHz by Wireless solution
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Rotating gobos
Zenith Series - moving heads
Ø 37,3 mm - image: Ø 32 mm
Fixed gobos
Ø 37,3 mm - image: Ø 32 mm
Color wheel
Ø 170 mm
Colour system
• CMY colour mixing
• Linear CTO colour temperature correction
• Additional colour wheel with 7 dichroic filters
+ open (linear-stepless selection)
• Bidirectional rainbow effect
• E asy calibration and maintenance by
magnetic repositioning
Effects
• 2 rotating bidirectional indexable gobo
wheels
6 dichroic rot. gobos each + open • 49 possible overlapping gobos combinations
• “Gobo-shake” and morphing effects
• Gobo change with synchronized blackout
• Easy access to gobo wheels for replacement
• Effects wheel with 3 prisms (3 facet, 5 facet
and diagonal prism) and “water” effect
• 5%-100% motorized linear iris
Illuminance at a Distance
12°- 30°
0m
5.0m
10.0m
15.0m
20.0m
33000lx/6599lx
1.05m/2.61m
8250lx/1649lx
2.09m/5.22m
3666lx/733lx
3.14m/7.83m
2062lx/413lx
4.19m/10.44m
Lux Center
Beam Angle: 12°-30°
Beam Width
Electronics
• 3 ,5” LCD display for a simplified access
to control menu, configuration and DMX
addressing
• 3 DMX available configurations: 24/24/32
channels for full flexibility and control
• Input and output signal through XLR 3p and
5p connectors
• “ ENERGY SAVE” mode: 50% reduction of
power consumption during blackout status
• Remote ON/OFF lamp control by DMX
• Remote unit reset by DMX
760
37 kg
555
• E lectronic self-test and check-up for
diagnostics
• Lamp life timer
• Thermal sensor monitoring optimum lamp
temperature
• C ooling: filtered forced ventilation with
variable speed low-noise fans
Structure and moving body
• A luminum structure with polycarbonate
cover, black colour
• Ergonomic side handles for transportation
• Motion Angle: Pan = 540° Tilt = 270°
• Pan/Tilt resolution: 8-bit or 16-bit Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt Fine = 0,004°
• Feedback automatic repositioning
• Suspension and fixing: any possible working
position through omega kit (included) with
“quick lock” system
• Pan and Tilt locking for transportation and
maintenance
Power supply
• Electronic ballast: 200-240V 50/60Hz universal
power supply
• Power consumption: 1470VA at 230V/50Hz
Weight and dimensions
• Weight: 37 kgs
• Dimensions (WxHxD): 555x760x435 mm
435
9
Z1200WASH
DISCHARGE
1200W
zoom
12°/45°
CMY+CTO
C°
-10 +40
IP20
Zenith 1200 WASH is the most powerful washlight projector of Prolights range. Light output is ensured
by double-lens optical system, powered by a 1200W discharge lamp Philips MSRGold FastFit (included)
combined with a dichroic parabolic reflector.
Z1200 WASH features CMY color mixing, linear CTO correction, 2 additional colour wheels (7 colours
each), double colour temperature correction filter, motorized 12°-45° linear zoom and electronic
ballast. The refined engineering of the mechanics and the multiple functionalities make Z1200 Wash
particularly suitable for “on the road” usage in concerts, events, tours, as well as for hi-end performance
in clubs, theatres and sets, anywhere lighting of objects and surfaces with unlimited variety of colours
is required.
Lamp
• Philips MSRGold, 1200W Fastfit (cod. 800186 included)
• Socket : PGJX50
• Colour temperature: 6300 K
• Luminous flux: 95.000 lm
• Average life span: 750 h
Optics
• High efficiency light optical system
• Fresnel lens: 200 mm diameter
• Parabolic glass reflector with dichroic coating • 12°-45° electronic linear zoom
Compatible with WR24A
Antenna receiver
Scan with your PHONE
to view product page.
10
Accessories
FCZ1200W (optional): Carrying Roadcase designed to contain 1 pc of Zenith 1200Wash, Dim. 705x880x620 mm
WR24A (optional): DMX Antenna receiver, 2,4GHz by Wireless solution
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Zenith Series - moving heads
Dimmer / shutter / strobe
• 0-100% linear dimmer
• Independent shutter and fading effects with
adjustable speed
• Strobe: mechanical, 8 flash per second
Colour system and effects
• CMY colour mixing
• Linear CTO colour temperature correction
• 2 additional overlapping colour wheels with
7 dichroic filters + open each (linear-stepless
selection)
• Overlapping colour wheels
• UV and 5600 K colour temperature filters
• Bidirectional rainbow effect
• “Spot” beam mode disabling zoom optics
• E asy calibration and maintenance by
magnetic repositioning
Illuminance at a Distance
12°- 45°
0m
5.0m
10.0m
15.0m
20.0m
1.05m/3.9m
75000lx/6000lx
2.09m/7.8m
18750lx/1500lx
3.14m/11.71m
8333lx/666lx
4.19m/15.61m
4687lx/375lx
Lux Center
Beam Angle: 12°-45°
Electronics
• 3 ,5” LCD display for a simplified access
to control menu, configuration and DMX
addressing
• 3 DMX available configurations: 16/21/21
channels for full flexibility and control
• Input and output signal through XLR 3p and
5p connectors
• “ ENERGY SAVE” mode: 50% reduction of
power consumption during blackout status
• Remote ON/OFF lamp control by DMX
• Remote unit reset by DMX
• Electronic self-test and check-up for diagnostics
• Lamp life timer
Beam Width
810
36 kg
555
• Thermal sensor monitoring optimum lamp
temperature
• C ooling: filtered forced ventilation with
variable speed low-noise fans
Structure and moving body
• A luminium structure with polycarbonate
cover, black colour
• Ergonomic side handles for transportation
• Motion angle: Pan = 540° Tilt = 270°
• Pan/Tilt resolution : 8-bit or 16-bit Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt Fine = 0,004°
• Feedback Automatic repositioning
• Suspension and fixing: any possible working
position through omega kit (included) with
“quick lock” system
• Pan and Tilt locking for transportation and
maintenance
Power supply
• Electronic ballast: 200-240V 50/60Hz universal
power supply
• Power consumption: 1446VA at 230V/50Hz
Weight and dimensions • Weight: 36 kgs
• Dimensions (WxHxD): 555x810x435 mm
435
11
Z700SPOT
DISCHARGE
700W
zoom
15°/35°
CMY
C°
-10 +40
IP20
ZENITH 700 SPOT is a moving-head projector equipped with a powerful 700W discharge lamp, lighter
and more compact of other projectors in the same range.
Electronics and optics have been developed according to cutting-edge technological contents,
reaching performance and brightness given by larger spotlights with higher wattages.
Z700SPOT includes a complete array of effects, featuring a staggering speed with instant acceleration
and silent operations.
Its technical profile makes Z700SPOT a professional device for Live events, TV studios and theatres.
Z700SPOT is equipped with Philips MSR Gold 700 FastFit lamp and electronic ballast, featuring linear
CMY mixing colour system, a colour wheel (7 colours + open), linear motorized zoom (15°-35°),
motorized iris and focus, 2 gobo wheels and a 3-facet rotating prism. Easy to handle and install, and
weighing only 23 Kgs, Z700SPOT is a reliable and powerful tool for professional lighting.
Lamp
• Philips MSRGold 700W/2 miniFastfit (cod. 800188 included)
• Socket: PGJX28
• Colour temperature: 7500 K
• Luminous flux: 50.000 lm
• Average life span: 750 h
Optics
• High definition anti-reflection lenses with achromatic coating
• Parabolic glass reflector with dichroic coating
• 15°-35° electronic linear zoom
• Focus: motorized focusing, from 2 m to infinity
Compatible with WR24A
Antenna receiver
Scan with your PHONE
to view product page.
12
Dimmer / shutter / strobe
• 0-100% linear dimmer
• Independent shutter and fading effects with adjustable speed
• Strobe: mechanical, 8 flash per second
Accessories
FCZ700S2 (optional): Carrying Roadcase designed to contain 2pcs of Zenith700Spot,Dim. 1125x850x510 mm
WR24A (optional): DMX Antenna receiver, 2,4GHz by Wireless solution
C462S (optional): Aluminium hook style single Truss Clamp, Slim version
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Zenith Series - moving heads
Rotating gobos
Fixed gobos
Color wheel
Ø 27 mm - image: Ø 25 mm
Colour system
• CMY colour mixing
• A dditional colour wheel with 7 dichroic
filters + open (linear-stepless selection with
3200K/5600K color temperature filters)
• Bidirectional rainbow effect
• E asy calibration and maintenance by
magnetic repositioning
Ø 32 mm - image: Ø 29 mm
Effects
• 1st Gobo wheel: 7 dichroic rotating Gobos
• 2nd Gobo wheel: 8 metallic fixed Gobos
• 72 possible overlapping gobos combinations
• “Gobo-shake” and morphing effects
• Linear frost filter
• Gobo change with synchronized blackout
• Easy access to gobo wheels for replacement
• 3 facet prism effect, rotating, indexable,
replaceable
• 5%-100% motorized linear iris
Ø 136 mm
Illuminance at a Distance
15°- 35°
0m
5.0m
10.0m
15.0m
20.0m
26800lx/6500lx
1.2m/3.0m
6700lx/1600lx
2.6m/6.0m
3000lx/700lx
3.8m/9m
1770lx/440lx
5.2m/12m
Lux Center
Beam Angle: 15°-35°
Electronics
• LCD display for a simplified access to control
menu, configuration and DMX addressing
• 3 DMX available configurations: 22/22/29
channels for full flexibility and control
• Input and output signal through XLR 3p and
5p connectors
• “ ENERGY SAVE” mode: 50% reduction of
power consumption during blackout status
• Remote ON/OFF lamp control by DMX
• Remote unit reset by DMX
• Electronic self-test and check-up for diagnostics
Beam Width
600
23,2 kg
430
• Lamp life timer
• Battery powered display
• Thermal sensor monitoring optimum lamp
temperature
• C ooling: filtered forced ventilation with
variable speed low-noise fans
Structure and moving body
• A luminium structure with polycarbonate
cover, black colour
• Ergonomic side handles for transportation
• Motion Angle: Pan = 540° Tilt = 270°
• Pan/Tilt resolution: 8-bit or 16-bit Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt Fine = 0,004°
• Feedback automatic repositioning
• Suspension and fixing: any possible working
position through omega kit (included) with
“quick lock” system
• Pan and Tilt locking for transportation and
maintenance
Power supply
• Electronic ballast: 100-240V 50/60Hz universal
power supply
• Power consumption: 881VA at 230V/50Hz
Weight and dimensions
• Weight: 23,2 kg
• Dimensions (WxHxD): 430x595x370 mm
370
13
Z300BEAM
DISCHARGE
300W
FROST
CMY+CTO
C°
-10 +40
IP20
ZENITH 300 BEAM is the innovative moving-head projector featuring “Beam” output technology,
generating an extremely powerful and focused parallel light beam.
Designed to fulfil several application needs in professional lighting, Z300BEAM freedoms creativity and
versatility, concentrating on a single fixture the functions and benefits of moving-heads, of “long-throw”
projectors and of ACL Par sets. Optical unit is composed by a smooth-surface Fresnel lens combined
with a special elliptical reflector. Based on a powerful 300W discharge lamp (MSD/MSR Gold MiniFastFit
Philips), Z300 Beam is designed to generate a parallel 8° light beam; the innovative frost system allows
to adjust the beam perfectly uniform into a more gradual diffusion of light.
Z300BEAM features linear CMY colour mixing, colour wheel (7 colours + open), interchangeable rotating
gobos, rotating 3-facet prism, combining creativity and versatility to peculiar “beam” output in studio
or “open-air” live event.
Lamp
• Philips MSDGold 300W MiniFast Fit (cod. 800182 included) or Philips MSRGold 300W MiniFast Fit (cod.
800184 optional)
• Socket : PGJX28
• Colour temperature: 8000 K
• Luminous flux: 23.000 lm
• Average life: 750 h (MSR Gold) or 2000 h (MSD Gold)
Optics
• Optical system: combined with a smooth surface elliptical reflector, the new Fresnel lens design grants
a high luminous efficiency delivering an astonishing parallel output beam
• Innovative progressive frost system consisting of 2 paddles, to gradually pass from “beam” to “wash
mode”, spreading colours into a perfect uniform even coverage
Compatible with WR24A
Antenna receiver
Scan with your PHONE
to view product page.
14
Accessories
FCZ300B2 (optional): Carrying Roadcase designed to contain 2pcs of Zenith300BEAM,
Dim.1125x850x510 mm
WR24A (optional): DMX Antenna receiver, 2,4GHz by Wireless solution
C462S (optional): Aluminium hook style single Truss Clamp, Slim version
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Zenith Series - moving heads
Rotating gobos
Color wheel
Ø 27 mm - image: Ø 25 mm
Dimmer / shutter / strobe
• 0-100% linear dimmer
• Independent shutter and fading effects with
adjustable speed
• Strobe: electronic, 8 flash per second
Ø 136 mm
Colour system • CMY Color Mixing • Additional colour wheel with 7 dichroic filters
+ open (linear-stepless selection)
• Colour wheel with double CTO filter (3200K +
5600K)
• Bidirectional rainbow effect
• E asy calibration and maintenance by
magnetic repositioning
Illuminance at a Distance
8°
0m
5.0m
10.0m
15.0m
20.0m
132000lx
0.7m
33000lx
1.4m
14666lx
2.9m
8250lx
Effects • 1 rotating gobo wheel with 7 metal gobos +
open
• Rotating, indexable and easily replaceable
gobos • Gobo change with synchronized blackout
• Easy access to gobo wheel for replacement
• 3-facet prism with bidirectional rotation and
adjustable speed
2.79m
Lux Center
Beam Angle: 8°
Beam Width
19,9 kg
605
Electronics
• 3 ,5” LCD display for a simplified access
to control menu, configuration and DMX
addressing
• 3 DMX available configurations: 18/18/25
channels for full flexibility and control
• Input and output signal through XLR 3p and
5p connectors
435
370
• “ ENERGY SAVE” mode: 50% reduction of
power consumption during blackout status
• Remote ON/OFF lamp control by DMX
• Remote unit reset by DMX
• Electronic self-test and check-up for diagnostics
• Lamp life timer
• Battery powered display
• Thermal sensor monitoring optimum lamp
temperature
• Cooling: forced ventilation with variable
speed low-noise fans
Structure and moving body:
• A luminium structure with polycarbonate
cover, black colour
• Ergonomic side handles for transportation
• Motion angle: Pan = 540° Tilt = 270°
• Pan/Tilt resolution: 8-bit or 16-bit Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt Fine = 0,004°
• Feedback automatic repositioning
• Suspension and fixing: any possible working
position through omega kit (included) with
“quick lock” system
• Pan and Tilt locking for transportation and
maintenance
Power supply
• Electronic ballast: 100-240V 50/60Hz universal
power supply
• Power consumption: 416VA at 230V/50Hz
Weight and dimensions
• Weight: 19,9 kgs
• Dimensions (WxHxD): 435x605x370 mm
15
Z4000DIGITAL
ansi
DISCHARGE
3600
avi/jpg
8 Gb
C°
-10 +40
IP20
Prolights Z4000DIGITAL is a moving head digital luminaire, conceived to combine in one fixture the
effects of digital projectors with features of traditional moving-heads.
The light source is based on a 280W, discharge lamp emitting 3600 ANSILumen output with DLP
screening technology. Z4000DIGITAL offers a limitless graphic effect range and control possibilities,
projecting pictures and videos stored inside the editable internal memory.
The video capture system through VGA, S-Video, Composite inputs allow Z4000DIGITAL to be
compatible with every multimedia device or external media servers. Its high-end technical profile
makes it a revolutionary tool for design of lighting projects in small Live events, theaters, clubs and corporate events.
Lamps and projector specifications
• Model: OSRAM HRI280 (cod. 800192 included)
• Efficiency: 3600 ANSILumen
• Power: 280W
• Rated lamp life: 1000 h
• Aspect ratio: 4:3, 16:9
• Resolution: SVGA 800*600
• Throw ratio: 2.38:1
• Optics: 24°
• Contrast ratio: 1800:1
• Display technology: DLP by Texas Instruments
• Display colours: full 16,7 million colours
Compatible with WR24A
Antenna receiver
Scan with your PHONE
to view product page.
16
Video Graphic Engine:
• 1 Video layer
• Video folders for maximum 1024 files
• Supported video extension: AVI, MJPEG
• Video speed control
Accessories
FCZ4000D (optional): Carrying Roadcase designed to contain 1pc of Zenith4000DIGITAL,Dim.585x835x405mm
WR24A (optional): DMX Antenna receiver, 2,4GHz by Wireless solution
C462S (optional): Aluminium hook style single Truss Clamp, Slim version
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Zenith Series - moving heads
Pictures Graphic Engine:
• 3 Pictures and DigiGobos layers
• Picture folders for maximum 1024 files
• Digital RGB Color calibration with built-in
Macros
• Supported pictures extensions: JPG
• Layer centre offset adjustment
• Independent CW and CCW layer rotation
• Independent X and Y layer ZOOM
• Zoom macros channel
• Channel with several layer position presets
Display settings:
• Electronic focus
• Motorized shutter
• Linear Dimmer
• Colour display settings
• Video format selection: 1:1, 16:9, 4:3, Auto
• X & Y Mirror
• Keystone function +/-40°
• Freeze function
• Source selection: SD card, CVBS, S-Video, VGA
540
17,5 kg
520
250
Electronics:
• Internal Memory: 8Gb (through SD card) for
picture/video storage
• 2 DMX available configurations: 29/54
channels
• User Interface: graphic LCD user interface for
auto programs execution, static colour mode,
creation of custom shows, colour calibration
presets
• Video input: VGA, S-Video, Composite
• DMX In/Out through XLR 3p/5p
• Remote ON/OFF lamp control by DMX
• Remote function reset by DMX
• E lectronic self-test and check-up for
diagnostics
• Lamp life timer
• Thermal sensor monitoring optimum lamp
temperature
• Working conditions: 0-40°
• C ooling: filtered forced ventilation with
variable speed low-noise fans
Structure and moving body:
• A luminium structure with polycarbonate
cover, black colour
• Ergonomic side handles for transportation
• Motion Angle (3 phase motors): Pan = 540° Tilt = 270°
• Pan/Tilt resolution: 8-bit or 16-bit Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt Fine = 0,004°
• Feedback automatic repositioning
• Suspension and fixing: any possible working
position through omega kit (included) with
“quick lock” system
• Pan and Tilt locking for transportation and
maintenance
Power Supply
• Electronic ballast: 100-240V 50/60Hz universal
power supply
• Power consumption: 380W at 230V/50Hz
Weight and dimensions
• Weight: 17,5 kgs
• Dimensions (WxHxD): 520x540x250 mm
17
Z2500DIGITAL
ansi
DISCHARGE
2500
avi/jpg
8 Gb
C°
-10 +40
IP20
Prolights Z2500DIGITAL is a moving head digital luminaire conceived to combine in one fixture the
effects of digital projectors with features of traditional moving-heads.
The light source is based on a 180W, discharge lamp emitting 2500 ANSILumen output with DLP
screening technology. Z2500DIGITAL offers a limitless graphic effect range and control possibilities,
projecting pictures and videos stored inside the editable internal memory. The video capture system
through VGA, S-Video, Composite inputs allow Z2500DIGITAL to be compatible with every multimedia
device or external media servers. Its high-end technical profile makes it a revolutionary tool for design
of lighting projects in small Live events, theatres, clubs and corporate events.
Lamps and projector specifications
• Model: OSRAM E20.8 (cod. 800190 included)
• Efficiency: 2500 ANSILumen
• Power: 180W
• Rated lamp life: 1000 h
• Aspect ratio: 4:3, 16:9
• Resolution: SVGA 800*600
• Throw ratio: 2.38:1
• Optics: 24°
• Contrast ratio: 1800:1
• Display technology: DLP by Texas Instruments
• Display colours: full 16,7 million colours
Compatible with WR24A
Antenna receiver
Scan with your PHONE
to view product page.
18
Video Graphic Engine:
• 1 Video layer
• Video folders for maximum 1024 files
• Supported video extension: AVI, MJPEG
• Video speed control
Accessories
FCZ2500D (optional): Carrying Roadcase designed to contain 1pc of Zenith2500DIGITAL,Dim.585x8
35x405mm
WR24A (optional): DMX Antenna receiver, 2,4GHz by Wireless solution
C462S (optional): Aluminium hook style single Truss Clamp, Slim version
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Zenith Series - moving heads
Pictures Graphic Engine:
• 3 Pictures and DigiGobos layers
• Picture folders for maximum 1024 files
• Digital RGB Color calibration with built-in
Macros
• Supported pictures extensions: JPG
• Layer centre offset adjustment
• Independent CW and CCW layer rotation
• Independent X and Y layer ZOOM
• Zoom macros channel
• Channel with several layer position presets
Static logo/picture (max 1024 images)
Display settings:
• Electronic focus
• Motorized shutter
• Linear Dimmer
• Colour display settings
• Video format selection: 1:1, 16:9, 4:3, Auto
• X & Y Mirror
• Keystone function +/-40°
• Freeze function
• Source selection: SD card, CVBS, S-Video, VGA
Video (max 992 video clips)
540
17,5 kg
520
250
Electronics:
• Internal Memory: 8Gb (through SD card) for
picture/video storage
• 2 DMX available configurations: 29/54 channels
• User Interface: graphic LCD user interface for
auto programs execution, static colour mode,
creation of custom shows, colour calibration
presets
• Video input: VGA, S-Video, Composite
• DMX In/Out through XLR 3p/5p
• Remote ON/OFF lamp control by DMX
• Remote function reset by DMX
• Electronic self-test and check-up for diagnostics
• Lamp life timer
• Thermal sensor monitoring optimum lamp
temperature
• Working conditions: 0-40°
• C ooling: filtered forced ventilation with
variable speed low-noise fans
Structure and moving body:
• A luminium structure with polycarbonate
cover, black colour
• Ergonomic side handles for transportation
• Motion Angle (3 phase motors): Pan = 540° Tilt = 270°
• Pan/Tilt resolution: 8-bit or 16-bit Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt Fine = 0,004°
• Feedback automatic repositioning
• Suspension and fixing: any possible working
position through omega kit (included) with
“quick lock” system
• Pan and Tilt locking for transportation and
maintenance
Power Supply
• Electronic ballast: 100-240V 50/60Hz universal
power supply
• Power consumption: 260W at 230V/50Hz
Weight and dimensions
• Weight: 17,5 kgs
• Dimensions (WxHxD): 520x540x250 mm
19
SLASH
DISCHARGE
189W
zoom
0°/4°
FROST
PRISM
WIRELESS
SLASH is a 189W moving Beam light which allows an extreme brightness, achievable only with 8
times higher wattage fixtures. The new generation optic design combined with the high-efficiency 5R
Platinum lamp source produce a laser-like 0° parallel beam, performing an incredible output of 130’000
lux at 10mt. The effect range offers a great creativity with 14 colours, 12 rotating gobos, 4° zoom lens, 8
facet rotating prism, focus, frost and shutter to reproduce spectacular mid-air effects. The compact sizes
(H. 50cm) and its light-weight profile (12,5Kg) make SLASH a suitable fixture to be installed everywhere
for Live, TV studio, theatre, showroom and conference event.
Lamp
• Philips MSD Platinum 5R 189W (cod. 800198 included)
• Colour temperature: 8000 K
• Luminous flux: 7.950 lm
• Average life span: 2000 h
Optics
• High efficiency Fresnel special optics featuring 0° parallel beam • Laser-like parallel Beam
• Frost filter to obtain soft-board
• Zoom lens for passage between 0° and 4°
• Focus: motorized focusing, from 2 m to infinity
WDMX receiver on board
Scan with your PHONE
to view product page.
20
Accessories
FCLSLASH (optional): Carrying Roadcase designed to contain 2 pcs of SLASH, Dim. 760x500x800mm
C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Rotating gobos
Zenith Series - moving heads
Ø 12 mm - image: Ø 8 mm
Dimmer / shutter / strobe
• 0-100% linear dimmer
• Independent shutter and fading effects with
adjustable speed
• Strobe: mechanical, 8 flash per second
Color wheel
Colour system
• Colour wheel with 14 dichroic filters + open
(linear-step-less selection)
• 3200K + 5600K colour temperature filters
• Bidirectional rainbow effect
Illuminance at a Distance
3.4°
0m
20.0m
40.0m
60.0m
80.0m
35200lx
1.2m
8800lx
2.4m
3911lx
3.6m
2200lx
Lux Center
4.8m
Beam Angle: 3.4°
Beam Width
553
12.5 kg
310
310
Effects
• G o b o s g r o u p c o m p o s e d b y 1 2
interchangeable gobos
• Gobos rotation in both CW and CCW direction
• Gobo change with synchronized blackout
• Easy access to gobo wheels for replacement
• 8 facet prism effect, rotating, indexable,
replaceable
Electronics
• LCD display for a simplified access to control
menu, configuration and DMX addressing
• 2 DMX available configurations: 12/14
channels for full flexibility and control
• Integrated 2,4GHz WDMX receiver (Wireless
solution) • Input and output signal through XLR 3p and
5p connectors
• “ ENERGY SAVE” mode: 50% reduction of
power consumption during blackout status
• Remote ON/OFF lamp control by DMX
• Remote unit reset by DMX
• E lectronic self-test and check-up for
diagnostics
• Lamp life timer
• Thermal sensor monitoring optimum lamp
temperature
• C ooling: filtered forced ventilation with
variable speed low-noise fans
Structure and moving body
• A luminium structure with polycarbonate
cover, black colour
• Ergonomic side handles for transportation
• Motion Angle: Pan = 540° Tilt = 270°
Pan/Tilt resolution: 8-bit or 16-bit Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt Fine = 0,004°
• Feedback automatic repositioning
• Suspension and fixing: any possible working
position through omega kit (included) with
“quick lock” system
Power supply
• Electronic ballast: 100-240V 50/60Hz universal
power supply
• Power consumption: 315W at 230V/50Hz
Weight and dimensions
• Weight: 12,5 kg
• Dimensions (WxHxD): 320x525x310 mm
21
TITAN
DISCHARGE
189W
zoom
15°/35°
FROST
PRISM
IP20
TITAN is a new generation moving Spot, conceived to combine power, performance, green design
and light-weight in the same fixture. The new generation optics combined with the high-efficiency 5R
Platinum lamp allow an extreme brightness, higher than traditional fixture with MSI575W, reducing
consumptions of 1:2 factor. TITAN offers an unprecedent effect range for such small fixtures as linear
9°-31° zoom, frost, Iris, focus, 14 colours, 18 gobos, 3 facet rotating prism.The special optic and the
flexible control possibilities make TITAN a multipurpose fixture for Spot, Wash, Beam applications. The
compact sizes (H. 50cm) and its light-weight profile (12,5Kg) make it a suitable fixture to be installed
everywhere for Live, TV studio, theatre, showroom and conference event.
Lamp
• Philips MSD Platinum 5R 189W (cod. 800198 included)
• Colour temperature: 8000 K
• Luminous flux: 7.950 lm
• Average life span: 2000 h
Optics
• High definition anti-reflection lenses with achromatic coating
• Parabolic glass reflector with dichroic coating
• 9°-31° electronic linear zoom
• Focus: motorized focusing, from 2 m to infinity
Dimmer / shutter / strobe
• 0-100% linear dimmer
• Independent shutter and fading effects with adjustable speed
• Strobe: mechanical, 8 flash per second
WDMX receiver on board
Scan with your PHONE
to view product page.
22
Accessories
FCLTITAN (optional): Carrying Roadcase designed to contain 2 pcs of TITAN, Dim. 107x480x800 mm
C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Rotating gobos
Fixed gobos
Colour system
• Colour wheel with 14 dichroic filters + open
(linear-step-less selection)
• 3200K + 5600K colour temperature filters
• Bidirectional rainbow effect
Ø 32 mm - image: Ø 29 mm
Effects
• 1st Gobo wheel: 9 dichroic rotating Gobos
• 2nd Gobo wheel: 9 metallic fixed Gobos
• 81 possible overlapping gobos combinations
• “Gobo-shake” effect and continuous rotation
• Easy access to gobo wheel for replacement
• Linear Frost filter for washer performance
• 3 facet prism effect, rotating, indexable,
replaceable
• 5-100% motorized iris
Color wheel
12°- 30°
Illuminance at a Distance
Zenith Series - moving heads
Ø 12 mm - image: Ø 8 mm
0m
2.5m
5.0m
7.5m
25060lx/4985lx
0.54m/1.33m
7136lx/1366lx
1.08m/2.66m
3178lx/635lx
1.62m/3.99m
Lux Center
Beam Angle: 12°-30°
Beam Width
557
12.5 kg
375
Electronics
• LCD display for a simplified access to control
menu, configuration and DMX addressing
• 2 DMX configurations available: 15/17
channels for full flexibility and control
• Integrated 2,4GHz WDMX receiver (Wireless
solution) • Input and output signal through XLR 3p and
5p connectors
• Remote ON/OFF lamp control by DMX
• Remote unit reset by DMX
• E lectronic self-test and check-up for
diagnostics
• Lamp life timer
• Thermal sensor monitoring optimum lamp
temperature
• C ooling: filtered forced ventilation with
variable speed low-noise fans
Structure and moving body
• A luminium structure with polycarbonate
cover, black colour
• Ergonomic side handles for transportation
• Motion Angle: Pan = 540° Tilt = 270°
Pan/Tilt resolution: 8-bit or 16-bit Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt Fine = 0,004°
• Feedback automatic repositioning
• Suspension and fixing: any possible working
position through omega kit (included) with
“quick lock” system
Power supply
• Electronic ballast: 100-240V 50/60Hz universal
power supply
• Power consumption: 400W at 230V/50Hz
Weight and dimensions
• Weight: 12,5 kg
• Dimensions (WxHxD): 320x480x370 mm
365
23
CROMOWASH600
LED
37X10W
zoom
RGBW/FC
15°/45°
C°
-10 +40
IP33
CROMOWASH600 is a moving ledwasher featuring 37x10W RGBW FullColor LEDs with a slim housing
and a multi-purpose technical profile. Wash, Beam or eye-candy, the CROMOWASH600 has been
designed to renew every-lighting show with an advanced creativity, introducing a new generation of
cues, patterns and aerial effects. The new LED technology uses several LED chips on a single module
that creates just perfect point source of extremely smooth new dimensional colour mixing of RGBW.
The virtual colour wheel grants a quick access to the built-in library of calibrated colours, for an excellent
reproduction of saturated and pastel tones including the white variants. The fast-zoom optic design
combined with a dual top-heat system feature a perfect fusion between the 4 primary colours and allows a 15-45° linear zoom for both “long through” beam performance and “flood” projection.
Its noise-free operation makes CROMOWASH600 an ideal tool where the silence is a top-priority like
theaters and TV studios, keeping very quick movements and fast rushing over music beats.
Accessories
FCL600W (optional): Carrying Roadcase designed to contain 2 pcs of Cromo Wash600, 660x680x480 mm
C462S (optional): Aluminium hook style single Truss Clamp, Slim version
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
WR24A (optional): DMX Antenna receiver, 2,4GHz by Wireless solution
Compatible with WR24A
Antenna receiver
Scan with your PHONE
to view product page.
24
Cromo Series - moving heads
Light source and optics
• 3 7 x 10W high-efficiency CREE RGBW
FullColor LEDs
• Lumens: > 6860 lm
• Lux @5m: 2’285
• Colour synthesis: RGBW FullColor mixing (>16
million colours) for a limitless colour range
and variable CTC control
• White temperature presets: 3200K~10000K
• Beam angle: 15°-45° Zoom
• Electronic linear zoom with motorized and
scrolling lens panel
• LEDs average life span: >50’000 h
15°
Illuminance at a Distance
0m
2.0m
4.0m
6.0m
8.0m
10.0m
14280lx
0.53m
3570lx
1.05m
1587lx
1.58m
893lx
2.11m
571lx
2.63m
Lux Center
Beam Angle: 15°
Beam Width
394
11,6 kg
400
Dimmer/Shutter/Strobe
• 0-100% linear dimmer
• 4 different dimming curves available
• Independent shutter and fading effects with
adjustable speed
• Strobe: Electronic, 1-20 flash per second
Electronics
• 3 ,5’’ LCD display for a simplified access
to control menu, configuration and DMX
addressing
• M a s te r / S l ave m o d e fo r s t a n d - a l o n e
operations
• Edit mode: creation and memorization of
custom shows (up to 255 steps) directly from
LCD user interface
• Linear and “stepless” transition between DMX
values
• Flicker-free operations (400Hz)
• 4 DMX available configurations: 8, 10, 16,
21 channels for a basic or advanced control
mode
• 2,4GHz Wireless DMX antenna receiver by
Wireless solution Sweden (optional)
• Unit reset: through control panel or via DMX
• C ooling: forced air, protection against
overheating
Structure and moving body
• High resistance and flame retardant polymer
case in black colour
• Internal protection: IP33
• Power cable (shuko 1,5mt) included
• Motion Angle: Pan = 540° Tilt = 300°
• Pan/Tilt resolution: 8-bit or 16-bit:
• Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt
Fine = 0,004°
• Suspension and fixing: any possible working
position through omega kit (included)
Power supply
• Power unit: 100-240V 50/60Hz
• Max power consumption: 465W
Weight and dimensions
• Weight: 11,6 kg
• Dimensions (WxHxD): 400x394x270 mm
270
25
CROMOWASH300
LED
91X3W
zoom
RGBWA
8°/40°
C°
-10 +40
IP20
Prolights CROMOWASH300 is a moving LedWasher equipped with the brand-new “fast-zoom”
technology, providing an impressive zoom range. The LED section is equipped with 91 high efficiency
3W LEDs with RGBWA colour synthesis, giving it unequalled performance for a fixture in its class.
The full spectrum RGBWA colour mixing allows perfect chromatic performance combining with a
variable CTC for a linear transition from cold to warm shades.
The new “fast-zoom” optics provides a fast and linear passage from 8° tight beam to 40° flood projection,
maintaining an outstanding colour mixing throughout the entire zooming range.
Its compact dimensions and lightweight profile (only 11Kg) allows CROMOWASH300 to have very
silent, precise and rapid movements.
The high-end technical profile of this multi-purpose fixture makes it a reliable tool for production of
professional lighting design in various environments as Live, Touring and Tv studios.
Light source and optics
• 91 x 3W high-efficiency CREE RGBWA LEDs (22 red, 23 green, 22 blue, 12 white, 12 amber)
• Lumens: > 4500 lm
• Lux @2m: 33’000
• Colour synthesis: RGBWA colour mixing (>16 million colours) for a limitless colour range and variable
CTC control
• White temperature presets: 3200K~10000K
• Beam angle: 8°-40° Zoom
• Electronic linear zoom with motorized and scrolling lens panel
• LEDs average life span: >50’000 h
Scan with your PHONE
to view product page.
26
Accessories
FCL300W (optional): Carrying Roadcase designed to contain 2 pcs of Cromo Wash300, Dim.785x650x400 mm
CW300FILTER5 (optional): 5° FLOOD filter for Cromo Wash300
C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Cromo Series - moving heads
8°
Illuminance at a Distance
0m
2.0m
4.0m
6.0m
8.0m
10.0m
54213lx
0.35m
13554lx
0.70m
6024lx
1.05m
3389lx
1.41m
2168lx
1.76m
Lux Center
Beam Angle: 8°
Dimmer/Shutter/Strobe
• 0-100% linear dimmer
• 4 different dimming available curves.
• Independent shutter and fading effects with
adjustable speed
• Strobe: Electronic, 1-20 flash per second
• Motion Angle: Pan = 540° Tilt = 270°
Pan/Tilt resolution: 8-bit or 16-bit:
Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt
Fine = 0,004°
• Suspension and fixing: any possible working
position through omega kit (included)
Electronics
• User Interface: graphic LCD user interface for
auto programs execution, static colour mode,
creation of custom shows, colour calibration
presets
• Master/Slave mode for stand-alone operations
• Edit mode: creation and memorization of
custom shows (up to 255 steps) directly from
LCD user interface
• Linear and “stepless” transition between DMX
values
• Flicker-free operations (400Hz)
• 2 DMX available configurations: 12 channels
(8 bit) and 16 channels (16 bit) for basic or
advanced control modes
• Unit reset: through control panel or via DMX
• C ooling: forced air, protection against
overheating
Power supply
• Power unit: 100-240V 50/60Hz
• Max power consumption: 310W
Weight and dimensions
• Weight: 11 kg
• Dimensions (WxHxD): 340x361x232 mm
Beam Width
Structure and moving body
• High resistance and flame retardant polymer
case in black colour
• Internal protection: IP33
• Power cable (shuko 1,5mt) included
361
11 kg
340
232
27
ELFINFC
LED
12X10W
beam
RGBW/FC
12°
FAST SPEED
QUADRANT
IP33
ELFINFC is an innovative moving LED-washer conceived to deliver a new level of visual effect to any
show like Wash, Pixel map and beam. The light source features 12x10W CREE RGBW FullColour LED
granting a powerful and brilliant chromatic synthesis. The advanced control mode allows to control
each quadrant as an indipendent fixture to generate multi-coloured beams or assembling the pixels
in a video-LED. The brand new optical design with tubular tracks is conceived to feature a very bright
and narrow beam (12°) for striking performance even in long-throw projections. The slim body (only
30cm high) and its weight of 4,5Kg make the ELFIN a striking solution for all concept of light-project
as Live,showrooms, clubs, theater.
Light source and optics
• 12 x 10W high-efficiency CREE RGBW FullColor LEDs
• Lux @5m: 1’500
• Colour synthesis: RGBW FullColor mixing (>16 million colours) for a limitless colour range and variable
CTC control
• White temperature presets: 3200K~10000K
• Beam angle: 12°
• Field angle: 23°
• LEDs average life span: >50’000 h
Scan with your PHONE
to view product page.
28
Accessories
FCLELFIN (included): Carrying Roadcase designed to contain 6 pcs of ELFIN
C360 (included): Aluminium single Truss Clamp with a 15mm hole
C60 (included): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Cromo Series - moving heads
Dimmer/Shutter/Strobe
• 0-100% linear dimmer
• 4 different dimming available curves • I ndependent shutter and fading effects with
adjustable speed
• Strobe: Electronic, 1-30 flash per second
Illuminance at a Distance
12°
0m
1.0m
2.0m
3.0m
4.0m
5.0m
23600lx
0.21m
6880lx
0.42m
3050lx
0.63m
1700lx
0.84m
1070lx
Lux Center
1.05m
Beam Angle: 12°
285
4.58 kg
258
149
Beam Width
Electronics
• LCD display for a simplified access to control menu,
configuration and DMX addressing
• Master/Slave mode for stand-alone operations
• Edit mode: creation and memorization of custom
shows (up to 255 steps) directly from LCD user
interface
• Sound mode: sound activation through built-in
microphone with sensitivity adjustment
• L inear and “stepless” transition between DMX
values
• Flicker-free operations (400Hz)
• 2 DMX available configurations: 12 channels (8
bit) and 28 channels (16 bit) for basic or advanced
control modes
• Independent quadrant control for for pixel map
effect or multi-coloured beams • Unit reset: through control panel or via DMX
• Cooling: forced air, protection against overheating
• Pan/Tilt resolution: 8-bit or 16-bit:
• Pan = 2,47° Pan Fine = 0,01° Tilt = 0,78° Tilt Fine =
0,004°
• S uspension and fixing: any possible working
position through omega kit (included)
Power supply
• Power unit: 100-240V 50/60Hz
• Max power consumption: 139W
Weight and dimensions
• Weight: 4,58 kg
• Dimensions (WxHxD): 148x256x304 mm
Structure and moving body
• High resistance and flame retardant polymer case
in black colour
• Internal protection: IP20
• Power cable (shuko 1,5mt) included
• Motion Angle: Pan = 630° Tilt = 200°
29
ELFINVW
LED
12X10W
beam
WW+CW
12°
FAST SPEED
QUADRANT
IP33
ELFINVW is an innovative moving LED-washer conceived to deliver a new level of visual effect to any
show like Wash, Pixel map and beam. The light source features 12x10W CREE CW and WW White LED
granting a powerful and brilliant reproduction of all white variants. The advanced control mode allows
to control each quadrant as an indipendent fixture to generate multi-coloured beams or assembling
the pixels in a video-LED. The brand new optical design with tubular tracks is conceived to feature a
very bright and narrow beam (12°) for striking performance even in long-throw projections. The slim
body (only 30cm high) and its weight of 4,5Kg make the ELFIN a striking solution for all concept of
light-project as Live,showrooms, clubs, theatres.
Light source and optics
• 12 x 10W high-efficiency CREE WW/CW White LEDs
• Lux @5m: 1’500
• Colour synthesis: RGBW FullColor mixing (>16 million colours) for a limitless colour range and variable
CTC control
• White temperature presets: 2700K~6000K
• Beam angle: 12°
• Field angle: 23°
• LEDs average life span: >50’000 h
Scan with your PHONE
to view product page.
30
Accessories
FCLELFIN (included): Carrying Roadcase designed to contain 6 pcs of ELFIN
C360 (included): Aluminium single Truss Clamp with a 15mm hole
C60 (included): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Cromo Series - moving heads
Dimmer/Shutter/Strobe
• 0-100% linear dimmer
• 4 different dimming available curves • I ndependent shutter and fading effects with
adjustable speed
• Strobe: Electronic, 1-30 flash per second
Illuminance at a Distance
12°
0m
1.0m
2.0m
3.0m
4.0m
5.0m
23600lx
0.21m
6880lx
0.42m
3050lx
0.63m
1700lx
0.84m
1070lx
Lux Center
1.05m
Beam Angle: 12°
285
4.58 kg
258
149
Beam Width
Electronics
• LCD display for a simplified access to control menu,
configuration and DMX addressing
• Master/Slave mode for stand-alone operations
• Edit mode: creation and memorization of custom
shows (up to 255 steps) directly from LCD user
interface
• Sound mode: sound activation through built-in
microphone with sensitivity adjustment
• L inear and “stepless” transition between DMX
values
• Flicker-free operations (400Hz)
• 2 DMX available configurations: 10 channels (8
bit) and 20 channels (16 bit) for basic or advanced
control modes
• Indipendent quadrant control for for pixel map
effect or multi-coloured beams
• Unit reset: through control panel or via DMX
• Cooling: forced air, protection against overheating
• Pan/Tilt resolution: 8-bit or 16-bit:
Pan = 2,47° Pan Fine = 0,01° Tilt = 0,78° Tilt Fine
= 0,004°
• S uspension and fixing: any possible working
position through omega kit (included)
Power supply
• Power unit: 100-240V 50/60Hz
• Max power consumption: 139W
Weight and dimensions
• Weight: 4,58 kg
• Dimensions (WxHxD): 148x256x304mm
Structure and moving body
• High resistance and flame retardant polymer case
in black colour
• Internal protection: IP20
• Power cable (shuko 1,5mt) included
• Motion Angle: Pan = 630° Tilt = 200°
31
CROMOWASH100
LED
37X3W
beam
RGB
6°
FAST SPEED
IP20
Prolights CROMOWASH100 is a compact moving Led-Washer with high luminous capacity (>2800
lumen) and simple operating system. LED section is equipped with 37 high-efficiency 3W LEDs with
RGB colour synthesis (13 red, 12 green, 12 blue). The brand new optical design with tubular tracks is
conceived to feature a very bright and narrow beam (6°) for striking performance even in long-throw
projections.
Supported by its small dimensions and exceptionally low weight (only 6.5 Kg), CROMOWASH100 is the
fastest Prolights moving-head allowing immediate repositioning and fast rushing over music beats.
Its affordable price, low power consumption and compactness makes CROMOWASH100 ideal for
projects requiring several fixtures like large matrices and as dynamic replacement for static Par cans in
Live, disco, TV studios, exhibitions and decorative applications.
Light source and optics
• 37 x 3W high-efficiency CREE RGB LEDs (13 red, 12 green, 12 blue)
• Lumen: > 2800 lm
• Lux @2m: 28’000
• Projection angle: 6°
• Energy-saving LEDs employed, with more vivid colours and lower power consumption than traditional
lamps
• Colour synthesis: RGB colour mixing (>16 million colours) for a limitless colour range
• High efficiency optical design with tubular tracks to generate a tight BEAM effect
• LED average life span: >50’000 h
Scan with your PHONE
to view product page.
32
Accessories
FCL100W (optional): Carrying Roadcase designed to contain 8pcs of Cromo Wash100, Dim.1200x585x705 mm
CW100TH (optional): Round barndoor for Cromo Wash100
C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Cromo Series - moving heads
6°
Illuminance at a Distance
0m
2.0m
4.0m
6.0m
8.0m
10.0m
33984lx
0.26m
8496lx
0.53m
3776lx
0.79m
2124lx
1.06m
975lx
Lux Center
1.32m
Beam Angle: 6°
Beam Width
Dimmer/Shutter/Strobe
• 0-100% linear dimmer
• 4 different dimming available curves • Independent shutter and fading effects with
adjustable speed
• Strobe: Electronic, 1-20 flash per second
• Motion Angle: Pan = 540° Tilt = 270°
Pan/Tilt resolution: 8-bit or 16-bit:
Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt
Fine = 0,004°
• Suspension and fixing: any possible working
position through omega kit (included)
Electronics
• User Interface: graphic LCD user interface for
auto programs execution, static colour mode,
creation of custom shows, colour calibration
presets
• M a s te r / S l ave m o d e fo r s t a n d - a l o n e
operations
• Edit mode: creation and memorization of
custom shows (up to 255 steps) directly from
LCD user interface
• Linear and “step-less” transition between DMX
values
• Flicker-free operations (400Hz)
• 2 DMX available configurations: 9 channels
(8 bit) and 13 channels (16 bit) for basic or
advanced control modes
• Unit reset: through control panel or via DMX
• C ooling: forced air, protection against
overheating
Power supply
• Power unit: 100-240V 50/60Hz
• Max power consumption: 130W
Weight and dimensions
• Weight: 6,5 kg
• Dimensions (WxHxD): 295x344x190 mm
Structure and moving body
• High resistance and flame retardant polymer
case in black colour
• Internal protection: IP33
• Power cable (shuko 1,5 m) included
344
6,5 kg
295
190
33
CROMOSPOT500
LED
3X60W
IRIS
PRISM
C°
-10 +40
IP20
CROMOSPOT500 is a moving head SPOT conceived to employ the brand-new optical design with
3x60W White Luminous LED source. The high luminous capacity makes CROMOSPOT500 one of the
most powerful luminaires in its range, becoming a valuable replace of traditional projectors equipped
with discharge MSR/HMI 575W lamp. CROMOSPOT500 features a wide range of functions and effects,
composed by 7 dichroic colour filters, 2 gobo wheels, one rotating (6 gobos) and one static (7 gobos),
3-facet prism, electronic iris and focus for limitless effect combinations.
CROMOSPOT500 represents the last goal of LED technology applied to intelligent lighting device,
allowing true advantages as minimized electric consumptions, light-weight, no-need of technical
maintenance, fast moves, suitable operations.
Light source and optics
• 3 x 60W high-power white Luminus LED
• Projection angle: 18°
• High efficiency optical system
• High definition anti-reflection lenses with achromatic coating
• Focus: electronic focusing, from 2 m to infinity
• LED average life span: >50’000h
Accessories
FCL500S (optional): Carrying Roadcase designed to contain 2 pcs of Cromo Spot500, Dim. 925x750x485mm
C462S (optional): Aluminium hook style single Truss Clamp, Slim version
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Scan with your PHONE
to view product page.
34
Rotating gobos
Fixed gobos
Ø 35,85 mm - image: Ø 27 mm
Color wheel
Illuminance at a Distance
0m
3.3m
5.0m
6.7m
8.3m
10.0m
14700lx
0.6m
3610lx
1.1m
1610lx
1.7m
900lx
2.2m
570lx
2.7m
400lx
3.2m
Lux Center
Beam Angle: 18°
Beam Width
605
19,5 kg
405
Dimmer/Shutter/Strobo
• 0-100% linear dimmer
• Independent shutter and fading effects with
adjustable speed
• Strobe: mechanical, 1-20 flash per second
Colour system
• Colour wheel with 7 dichroic filters + open
(linear-step-less selection)
• Rainbow effect with speed adjustment
• E asy calibration and maintenance by
magnetic repositioning
18°
1.7m
Cromo Series - moving heads
Ø 32,75 mm - image: Ø 27/26,2 mm dichroic
Effects
• Gobos group composed by 13 gobos over 2
overlapping wheels
• R otating gobo wheel: 6 interchangeable
gobos
• Static gobo wheel: 7 gobos
• Gobos rotation in both CW and CCW direction
• “Gobo-shake” effect and continuous rotation
• Easy access to gobo wheel for replacement
• Effect wheel with 3 facet prism rotating in
both directions at different speed
• Iris: 4-100% high-speed
• Easy show: built-in programs with automatic/
sound activated mode enabled by LCD
control panel
• Edit mode: creation and memorization of
custom shows (up to 255 steps) directly from
LCD user interface
Electronics
• User Interface: graphic LCD display to control
unit DMX addressing, general settings
• 2 DMX available configurations: 11 channels
(8 bit) and 14 channels (16 bit) for advance or
basic control mode
• I nput and output signal through XLR 3p
connector
• Unit reset: through control panel or via DMX
• Electronic self-test and check-up for diagnostics
• C ooling: forced air, protection against
overheating
Structure and moving body:
• High resistance and flame retardant polymer
case in black colour
• Ergonomic side handles for transportation
• Motion Angle: Pan = 540° Tilt = 270°
• Pan/Tilt resolution: 8-bit or 16-bit
• Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt
Fine = 0,004°
• Automatic repositioning of effects in case of
accidental movements
• Suspension and fixing: any possible working
position through omega kit (included)
Power supply
• Power unit: 100-240V 50/60Hz
• Max power consumption: 300W
Weight and dimensions
• Weight: 19,5 kg
• Dimensions (WxHxD): 405x605x295 mm
295
35
CROMOSPOT250
LED
1X60W
focus
ELECTR.
PRISM
C°
-10 +40
IP20
CROMOSPOT250 is a moving-head spot equipped with a 60W LED source, designed for professional
applications. Its performance makes this projector an evolution of the conventional fixtures based on
250W discharge lamp, reducing power consumption to a 1:3 factor.
CROMOSPOT250 features a wide range of effects, composed by 8 dichroic colour filters, 2 gobo
wheels, one rotating (7 gobos) and one static (9 gobos), 3-facet prism for limitless effect combinations.
CROMOSPOT250 offers a wide range of built-in automatic and sound-activated shows plus the
possibility to create custom programs directly from the user interface, with no need of external
controllers. Its compact-size structure, its rapid movements and silent operations grant this projector
to be a valuable solution for lighting projects in medium-sized environments like live stages and clubs.
Light source and optics
• 1 x 60W high-power white Luminus LED
• Projection angle: 15°
• High efficiency optical system
• High definition anti-reflection lenses with achromatic coating
• Focus: electronic focusing, from 2 m to infinity
• LED average life span: >50’000 h
Accessories
FCL250S (optional): Carrying Roadcase designed to contain 2 pcs of CromoSpot250,Dim. 710x750x410 mm
C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Scan with your PHONE
to view product page.
36
Rotating gobos
Fixed gobos
Color wheel
Ø 28,95 mm - image: Ø 22 mm
Ø 30 mm
Illuminance at a Distance
0m
4.0m
6.0m
8.0m
10.0m
4230lx
0.5m
1058lx
1.1m
470lx
1.7m
264.4lx
2.2m
169.2lx
2.8m
Lux Center
Beam Angle: 15°
Beam Width
485
13,6 kg
295
Dimmer/Shutter/Strobo
• 0-100% linear dimmer
• Independent shutter and fading effects with
adjustable speed
• Strobe: mechanical, 1-20 flash per second
Colour system
• Colour wheel with 8 dichroic filters + open
(linear-stepless selection)
• Rainbow effect with speed adjustment
• E asy calibration and maintenance by
magnetic repositioning
15°
2.0m
Cromo Series - moving heads
Ø 25,95 mm - image: Ø 19 mm
290
Effects
• Gobos group composed by 16 gobos over 2
overlapping wheels
• R otating gobo wheel: 7 interchangeable
gobos (2 of which dichroic)
• Static gobo wheel: 9 gobos
• Gobos rotation in both CW and CCW direction
• “Gobo-shake” effect and continuous rotation
• Easy access to gobo wheel for replacement
through slot-n-lock panel
• Effect wheel with 3 facet prism rotating in
both directions at different speed
• Easy show: built-in programs with automatic/
sound activated mode enabled by LCD
control panel
• Edit mode: creation and memorization of
custom shows (up to 255 steps) directly from
LCD user interface
Electronics
• User Interface: graphic LCD display to control
unit DMX addressing, general settings
• 2 DMX available configurations: 11 channels
(8 bit) and 14 channels (16 bit) for advance or
basic control mode
• I nput and output signal through XLR 3p
connector
• Unit reset: through control panel or via DMX
• Electronic self-test and check-up for diagnostics
• C ooling: forced air, protection against
overheating
Structure and moving body
• High resistance and flame retardant polymer
case in black colour
• Motion Angle: Pan = 540° Tilt = 270°
• Pan/Tilt resolution: 8-bit or 16-bit
• Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt
Fine = 0,004°
• Automatic repositioning of effects in case of
accidental movements
• Suspension and fixing: any possible working
position through omega kit (included)
Power supply
• Power unit: 100-240V 50/60Hz
• Max power consumption: 140 W
Weight and dimensions
• Weight: 13,6 kg
• Dimensions (WxHxD): 295x485x290 mm
37
CROMOBEAM250
LED
1X60W
beam
6°
FAST SPEED
C°
-10 +40
IP20
CROMOBEAM250 is the first BEAM moving head based on LED light source, housing a high-power 60W
diode. The optical unit is composed by a special smooth-surface lens, featuring a 6° highly concentrated
parallel beam. Its light output can be compared to a MSR575 luminaire with Iris effect enabled. The
amazing rapid movements and the absence of noise make CROMOBEAM250 the perfect device to
generate effect in the air, replacing the traditional long-throw projectors and the ACL par sets in
medium sized light-shows.
Light source and optics
• 1 x 60W high-power white Luminus LED
• Projection angle: 6°
• High efficiency optical system with a smooth-surface lens to generate a parallel BEAM effect
• LED average life span: >50’000 h
Accessories
FCL250B (optional): Carrying Roadcase designed to contain 2 pcs of CromoBeam250, Dim. 780x760x380 mm
C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Scan with your PHONE
to view product page.
38
Cromo Series - moving heads
Rotating gobos
Ø 25,95 mm - image: Ø 19 mm
Dimmer/Shutter/Strobo
• 0-100% linear dimmer
• Independent shutter and fading effects with
adjustable speed
• Strobe: mechanical, 1-20 flash per second
Color wheel
Colour system
• Colour wheel with 8 dichroic filters + open
(linear-stepless selection)
• Rainbow effect with speed adjustment
• E asy calibration and maintenance by
magnetic repositioning
6°
Illuminance at a Distance
0m
2.0m
4.0m
6.0m
8.0m
10.0m
32000lx
0.2m
8030lx
038m
3020lx
0.58m
2110lx
0.76m
1020lx
Lux Center
0.96m
Beam Angle: 6°
Beam Width
12,6 kg
Effects
• Rotating gobo wheel: 7 interchangeble gobos
(1 of which dichroic)
• Gobos rotation in both CW and CCW direction
• “Gobo-shake” effect and continuous rotation
• Easy access to gobo wheel for replacement
• Easy show: built-in programs with automatic/
sound activated mode enabled by LCD
control panel
• Edit mode: creation and memorization of
custom shows (up to 255 steps) directly from
LCD user interface
• Unit reset: through control panel or via DMX
• Electronic self-test and check-up for diagnostics
• C ooling: forced air, protection against
overheating
Structure and moving body
• High resistance and flame retardant polymer
case in black colour
• Motion Angle: Pan = 540° Tilt = 270°
• Pan/Tilt resolution: 8-bit or 16-bit:
• Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt
Fine = 0,004°
• Suspension and fixing: any possible working
positionthrough omega kit (included)
Power supply
• Power unit: 100-240V 50/60Hz
• Max power consumption: 150W
Weight and dimensions
• Weight: 12,6 kg
• Dimensions (WxHxD): 330x550x290 mm
550
Electronics
• User Interface: graphic LCD display to control
unit DMX addressing, general settings
• 2 DMX available configurations: 8 channels (8
bit) and 11 channels (16 bit) for advanced or
basic control mode
• I nput and output signal through XLR 3p
connector
330
290
39
CROMOSPOT150
LED
1X20W
focus
MANUAL
PRISM
C°
-10 +40
IP20
CROMOSPOT150 is a moving-head spot equipped with high-power 20W LED source. Its luminous
output can be compared to conventional moving-heads based on 150W discharge lamp, with a
reduced 1:3 power consumption factor.
CROMOSPOT150 features a wide effect range, composed by 9 dichroic colour filters, 7 rotating and
interchangeable gobos (2 dichroic) and 3-facet prism effect for limitless effect combinations. Moreover
CROMOSPOT150 has a selection of automatic and sound-activated built-in shows, whose execution
can be controlled through the multi-function LCD display. Performance and structural design, make
this fixture an excellent tool to realize lighting projects in clubs, discos and small-sized stages.
Light source and optics
• 1 x 20W high-power white Luminus LED
• Projection angle: 16°
• High efficiency optical system
• High definition anti-reflection lenses with achromatic coating
• Focus: Manual adjustment on the head
• LED average life span: >50’000 h
Accessories
C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Scan with your PHONE
to view product page.
40
Cromo Series - moving heads
Rotating gobos
Ø 25,95 mm - image: Ø 19 mm
Color wheel
Dimmer/Shutter/Strobo
• 0-100% linear dimmer
• Independent shutter and fading effects with
adjustable speed
• Strobe: mechanical, 1-20 flash per second
Colour system
• Colour wheel with 9 dichroic filters + open
(linear-step-less selection)
• Rainbow effect with speed adjustment
• E asy calibration and maintenance by
magnetic repositioning
15°
Illuminance at a Distance
0m
2.0m
4.0m
6.0m
8.0m
10.0m
4230lx
0.5m
1058lx
1.1m
470lx
1.7m
264.4lx
2.2m
169.2lx
2.8m
Lux Center
Beam Angle: 15°
Beam Width
7 kg
Effects
• R otating gobo wheel: 7 interchangeable
gobos (2 of which dichroic)
• Gobos rotation in both CW and CCW direction
• “Gobo-shake” effect and continuous rotation
• Easy access to gobo wheel for replacement
• Effect wheel with 3 facet prism
• Easy show: built-in programs with automatic/
sound activated mode enabled by LCD
control panel
• Edit mode: creation and memorization of
custom shows (up to 255 steps) directly from
LCD user interface • I nput and output signal through XLR 3p
connector
• Unit reset: through control panel or via DMX
• E lectronic self-test and check-up for
diagnostics
• C ooling: forced air, protection against
overheating
Structure and moving body
• High resistance and flame retardant polymer
case in black colour
• Motion Angle: Pan = 540° Tilt = 270°
• Pan/Tilt resolution: 8-bit or 16-bit
• Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt
Fine = 0,004°
• Automatic repositioning of effects in case of
accidental movements
• Suspension and fixing: any possible working
position through omega kit (included)
Power supply
• Power unit: 100-240V 50/60Hz
• Max power consumption: 45W
Weight and dimensions
• Weight: 7 kg
• Dimensions (WxHxD): 240x370x245 mm
370
Electronics
• User Interface: graphic LCD display to control
unit DMX addressing, general settings
• 2 DMX available configurations: 9 channels
(8 bit) and 12 channels (16 bit) for advance
or basic control mode
240
245
41
V575SPOT
DISCHARGE
575W
IRIS
PRISM
C°
-10 +40
IP20
V575SPOT is the best seller spotlight moving-head. Equipped with 575W discharge lamp and a special
dichroic parabolic refelector, V575SPOT has been designed to be a versatile and suitable tool for all
professional applications, both mobile (events, concerts, show) and fixed ones (clubs, venues), where
a compact device with a high efficiency luminous output is needed. V575SPOT includes a wide range
of effects: two gobo wheels (one rotating plus one static, all gobos are replaceable), a colour wheel,
motorized iris, focus and a 3 facet rotating prism effect.
Lamp
• Philips MSI575HR/2 or HMI/2 (cod. 8001134 included)
• Socket: Sfc10-4
• Colour temperature: 7000 K
• Luminous flux: 49.000 lm
• Average life span: 750 h
Optics
• High definition anti-reflection lenses with achromatic coating
• Parabolic glass reflector with dichroic coating
• Projection angle: 14°
• Focus: motorized focusing, from 2 m to infinity
Dimmer / shutter / strobe
• 0-100% linear dimmer
• Independent shutter and fading effects with adjustable speed
• Strobe: mechanical, 10 flash per second
Scan with your PHONE
to view product page.
42
Accessories
FCV575S (optional): Carrying Roadcase designed to contain 2pcs of Vision575Spot, Dim. 865x830x520 mm
C462S (optional): Aluminium hook style single Truss Clamp, Slim version
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Rotating gobos
Fixed gobos
Ø 26,5 mm - image: Ø 22 mm
Color wheel
Ø 144 mm
Illuminance at a Distance
14°
0m
5.0m
10.0m
15.0m
20.0m
7686lx
1.22m
1921lx
2.44m
854lx
3.66m
480lx
4.88m
Lux Center
Beam Angle: 14°
Beam Width
545
27 kg
425
Vision Series - moving heads
Ø 26,5 mm - image: Ø 21 mm
380
Colour system
• Colour wheel with 9 dichroic filters + open
(linear-stepless selection)
• Bidirectional rainbow effect
• E asy calibration and maintenance by
magnetic repositioning
• Colour change with synchronized blackout
• Lamp On/Off: through control panel or via
DMX
• Unit reset: through control panel or via DMX
• Electronic self-test and check-up for diagnostics
• C ooling: forced air, protection against
overheating. Fan speed control for quieter
operation
Effects
• 1 static gobo wheel: 9 fixed interchangeable
gobos + open
• 1 bidirectional rotating gobo wheel: 5 metal
gobo + 2 dichroics + open
• 80 possible overlapping gobos combinations
• “Gobo-shake” effect and continuous rotation
• Easy access to gobo wheels for replacement
• Effect wheel with 3 facet prism rotating in
both directions at different speed
• Iris: motorised 0-100% iris diaphragm
• Easy show: built-in programs with automatic/
sound activated mode enabled by LED
control panel or by EC800 remote control
(not included)
Structure and moving body
• Aluminium structure with die-cast polymer
cover, black colour
• Ergonomic side handles for transportation
• Motion Angle: Pan = 540° Tilt = 270°
• Pan/Tilt resolution: 8-bit or 16-bit
Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt
Fine = 0,004°
• Feedback automatic repositioning
• Suspension and fixing: any possible working
position through omega kit (included) with
“quick lock” system
Electronics
• User Interface: 4-digit multi-function LED
display to control unit addressing, general
settings and fixture life timer
• 2 DMX available configurations: 8 channels (8
bit) and 16 channels (16 bit) for full flexibility
and control
• I nput and output signal through XLR 3p
connector
Power supply
• Electromagnetic ballast: 200-240V 50/60Hz
universal power supply
• Power consumption: 800W
Weight and dimensions
• Weight: 27 kgs
• Dimensions (WxHxD): 425x545x380 mm
43
V575WASH
DISCHARGE
575W
zoom
CMY
11°/28°
C°
-10 +40
IP20
V575WASH is the most powerful washlight in the Vision range. Fitted with a high-efficiency 575W
discharge lamp combined with a new-designed Fresnel lens.
V575WASH also features a limitless colour generation, allowed by CMY mixing and dichroic colour wheel
to find application in any lighting project. The linear zoom is 11°- 28°. The frost filter and the surprising
brightness allow its short, medium and long range use, in professional and architectural lighting.
Lamp
• Philips 575W 95V MSD/MSR575 (cod. 800144 included)
• Socket: GX9,5
• Colour temperature: 7000 K
• Luminous flux: 49.000 lm
• Average life: 1000 h
Optics
• High efficiency optical system
• Fresnel lens: 150 mm diameter
• Parabolic aluminium with elliptical profile
• Zoom: electromechanical linear zoom 11-28° Accessories (optional)
FCV575W (optional): Carrying Roadcase designed to contain 2pcs of Vision 575Wash,Dim. 865x830x520 mm
C462S (optional): Aluminium hook style single Truss Clamp, Slim version
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Scan with your PHONE
to view product page.
44
Vision Series - moving heads
Dimmer / shutter / strobe
• 0-100% linear dimmer
• Independent shutter and fading effects with
adjustable speed
• Strobe: mechanical, 10 flash per second
Color wheel
Illuminance at a Distance
11°- 28°
0m
5.0m
10.0m
15.0m
20.0m
8296lx/3499lx
0.96m/2.44m
2074lx/874lx
1.92m/4.87m
921lx/388lx
2.88m/7.31m
518lx/218lx
3.84m/9.75m
Lux Center Beam Angle: 11°-28° Beam Width
570
30 kg
425
380
Colour system
• Advanced CMY colour mixing obtained by 3
dichroic filters cyan, magenta, yellow
• Additional colour wheel with 6 dichroic filters
+ open (linear-stepless selection)
• Bidirectional rainbow effect and Macro preset
• Frost filter to increase light-beam aperture;
adjustable positioning “banana” effect
• E asy calibration and maintenance by
magnetic repositioning
• Colour change with synchronized blackout
• Easy show: built-in programs with automatic/
sound activated mode enabled by LED
control panel or by EC800 remote control
(not included)
Electronics
• User Interface: 4-digit multi-function LED
display to control unit addressing, general
settings and fixture life timer
• 2 DMX available configurations: 8 channels (8
bit) and 16 channels (16 bit) for full flexibility
of control
• I nput and output signal through XLR 3p
connector
• Lamp On/Off: through control panel or via DMX
• Unit reset: through control panel or via DMX
• Electronic self-test and check-up for diagnostics
• C ooling: forced air, protection against
overheating. Fan speed control for quieter
operation
Structure and moving body
• Aluminium structure with die-cast polymer
cover, black colour
• Ergonomic side handles for transportation
• Motion Angle: Pan = 540° Tilt = 270°
• Pan/Tilt resolution: 8-bit or 16-bit
Pan = 2,10° Pan Fine = 0,008° Tilt = 1,05° Tilt
Fine = 0,004°
• Feedback automatic repositioning
• Suspension and fixing: any possible working
position through omega kit (included) with
“quick lock” system
Power supply
• Electromagnetic ballast: 200-240V 50/60Hz
universal power supply
• Power consumption: 800W
Weight and dimensions
• Weight: 30 kgs
• Dimensions (WxHxD): 425x570x380 mm
45
technical data
Light source
Z1200 Spot
Z1200 Wash
Z700 Spot
1200W fastfit
1200W fastfit
700W fastfit
Z300 Beam
300W mini fastfit
750/2000
8°
•
1 (7+open)
•
7 (interchang.)
7
7
•
Z4000 Digital
Z2500 Digital
280W
180W
Slash
Titan
Platinum 5R
189W
2000h
Platinum 5R
189W
2000h
Cromo Wash
600
37x10W CREE
RGBW/FC LEDs
>50'000
15°-45° Zoom
•
Average life (h)
750
750
750
1000
1000
Beam angle
12°-30° Zoom
12°-45° Zoom
15°-35° Zoom
24°
24°
0°-4°
9°-31° Zoom
0-100% linear dimmer
•
•
•
•
•
•
•
Color wheel/s
1 (7+open)
1 (7+open)
1 (7+open)
“Virtual”
“Virtual”
1 (14+open)
1 (14+open)
Rainbow effect
•
•
•
•
•
•
Gobo Wheel/s 6 + 6 (interchang.)
7 + 8 (interchang.)
“Virtual”
“Virtual”
12 (interchang.) 9+9 (interchang.)
Dichroic gobos
1
7
7
3
Rotating gobos
6
7
12
9
Strobe effect
•
•
•
•
•
•
•
•
Focus
Electronic
Electronic
Electronic
Electronic
Electronic
Electronic
Gobo shake
•
•
•
•
•
•
Prism effect
3/5/diagonal
3 facet
3 facet
8 facet
3 facet
Menu interface
LCD 3,5’’
LCD 3,5’’
LCD 3,5’’
LCD 3,5’’
LCD
LCD
LCD
LCD
LCD
Dmx channels
24/24/32
16/21/21
22/22/29
18/18/25
29/54
29/54
12/14
15/17
8/10/16/21
Edit Mode
up to 255 steps
DMX reset
•
•
•
•
•
•
•
•
•
Functions self-test
•
•
•
•
•
•
•
•
•
Fixtures hours
•
•
•
•
•
•
•
•
•
Fans speed control
•
•
•
•
•
•
•
•
•
Pan/tilt angle
540/270
540/270
540/270
540/270
540/270
540/270
540/270
540/270
540/300
Electronic
repositioning of the
•
•
•
•
•
•
•
•
•
effects
Power supply 200-240 50/60Hz 200-240 50/60Hz 100-240 50/60Hz 100-240 50/60Hz 100-240 50/60Hz 100-240 50/60Hz 100-240 50/60Hz 100-240 50/60Hz 100-240 50/60Hz
Power consumption
1470W
1446W
881W
416W
380W
260W
315W
400W
450W
Weight (Kgs)
37
36
23.2
19.9
17.5
17.5
12.5
12.5
11.6
Dimensions (mm)
555x760x435
555x810x435
430x595x370
435x605x370
520x540x250
520x540x250
310x525x310
375x557x365
400x394x270
technical data
Cromo Wash
300
ElfinFC
ElfinVW
Cromo Wash
100
Cromo Spot
500
Cromo Spot
250
Cromo Beam Cromo Spot
250
150
V575 Spot
V575 Wash
91x3W CREE 12x10W CREE 12x10W CREE 37x3W CREE 3x60W Luminus 1x60W Luminus
1x60W
1x20W
575W
575W
RGBWA LEDs RGBW/FC LEDs WW+CW LEDs
RGB LEDs
LED
LED
Luminus LED Luminus LED
discharge
discharge
Average life (h)
>50'000
>50'000
>50'000
>50'000
>50'000
>50'000
>50'000
>50'000
750
1000
Beam angle 8°-40° Zoom
12°
12°
6°
18°
15°
6°
16°
14°
11-28° Zoom
0-100% linear dimmer
•
•
•
•
•
•
•
•
•
•
Color wheel/s
1(7+open)
1(8+open)
1(8+open)
1(9+open)
1(9+open)
1 (6+open)
Rainbow effect
•
•
•
•
•
•
•
•
•
•
Gobo Wheel/s
7+6 (interchang.) 9+7 (interchang.) 7 (interchang.) 7 (interchang.) 9 (interchang.)
Dichroic gobos
1
2
1
2
2
6
Rotating gobos
7
7
7
7
9
Strobe effect
•
•
•
•
•
•
•
•
•
•
Focus
Electronic
Electronic
Manual
Electronic
Gobo shake
•
•
•
•
•
•
Prism effect
3 facet
3 facet
3 facet
3 facet
Menu interface
LCD
LCD
LCD
LCD
LCD
LCD
LCD
LCD
LED
LED
Dmx channels
12/16
12/28
10/20
9/13
13/18
11/14
8/11
9/12
8/16
8/16
Edit Mode
up to 255 steps
DMX reset
•
•
•
•
•
•
•
•
•
•
Functions self-test
•
•
•
•
•
•
•
•
•
•
Fixtures hours
•
•
•
•
•
•
•
•
•
•
Fans speed control
•
•
•
•
•
•
•
•
•
•
Pan/tilt angle
540/270
630/200
630/200
540/270
540/270
540/270
540/270
540/270
540/270
540/270
Electronic repositioning
•
•
•
•
•
•
•
•
•
•
of the effects
100-240
100-240
100-240
100-240
200-240
200-240
200-240
200-240
100-240 50/60Hz 200-240 50/60Hz
Power supply
50/60Hz
50/60Hz
50/60Hz
50/60Hz
50/60Hz
50/60Hz
50/60Hz
50/60Hz
Power consumption
140W
139W
170W
45W
300W
140W
150W
45W
800W
700W
Weight (Kgs)
11
4.6
4.6
6.5
19.5
13,6
12.6
7
27
30
Dimensions (mm) 340x361x232 148x256x304 148x256x304 295x344x190 405x605x295
295x485x290
330x550x290 240x370x245 425x545x380 425x570x380
Light source
ArcLed series
Prolights Arcled series is composed of 16 color washers employing LED technology and covering a wide range of applications in professional lighting: linear projectors,
spotlights, architectural projectors and luminaires for accent lighting. Design and selection of components is inspired by a rigorous logic of quality, employing latest
innovations in opticas, mechanics and electronics addressed to professional users. Arcled colorchangers then represent versatile and efficient tools for any lighting project
in live and corporate events, theaters, architectural lighting and club installations.
Superior class luminosity
Extraordinary luminous efficiency of Arcled projectors is guaranteed by a continuous research and selection of optical components, offering top-class performance in terms of precision and reliability.
All Arcled projectors are equipped with CREE LED diodes, optics and power supply
units optimized on specifications of each model by our R&D department, with the
aim to maximize efficiency of each component (optical efficiency >85%).
Luminous performance of Prolights projectors delivers a higher luminance of other
projectors in the same range of power, often offering a higher luminous capability
than other models declaring a higher watt consumption.
Un’ elettronica di ultima generazione
Electronics in Arcled projectors features advanced components, software and constructive modularity, optimizing mechanical performance and allowing comfortable and interactive usage.
A graphic display enables the user to access a control menu rich of informations
and settings, also allowing selection of working modes. Arcled projectors infact
allow DMX control, execution of built-in automatic shows, selection of static colors,
creation and editing of custom scene to be stored in the internal memory.
Color synthesis for unlimited chromatic possibilities
Projectors of Arcled series are based on RGB color sysnthesis allowing an unlimited
color mixing to reproduce vivid and uniform colors and amazing generation of pastel shades. White and Amber LEDs offer advanced control over color temperature,
for a perfect chromatic reproduction of white color scale from 3200°K to 10000°K.
Arcled projectors are among the first ones introducing Tri-Color and 4-in-1 technologies, employing a special system of custom lenses engineered and fine-tuned by
our R&D department and last-generation multi-chip CREE diodes.
This innovative optical system allows primary colors to be mixed into single optics
removing unwanted shadows or distorsions due to overlapping. For this reason
color mixing is perfect even for short-throw projections and all lenses show a uniform coverage having a continuous and coherent color tone.
Winner in its category for linear zoom
Arcled projectors have been the first ones introducing Fast-zoom technology, a
result obtained following a constant activity of research & development focused
on optics and mechanics.
Fast-zoom technology has been implemented after developing special elliptical
lenses combined with motor-driven excursion of lens panel.
This combination allowed to reach a great result in terms of precision and saturation of projection, angle amplitude, linearity and moving speed of zoom feature.
Application of this new technology opens new horizons to possible applications for
static projectors, enabling the possibility of modeling the projection from beam-like
narrow spot to flood for background painting.
Outdoor chassis and IP construction for on-the-road applications
Arcled line of projectors also includes models having water-proof construction
(IP>65) for outdoor touring applications or architectural permanent installations.
Design of outer structure is completely made in toughened glass and die-cast
aluminium, allowing heat to be dissipated by natural convection with no need of
fans. For this reason proper operations are ensured in demanding environments
(-40°/+45°) and in places where total absence of typical cooling noises is a primary
requirement.
IP65 projectors of Arcled series employ an innovative system for balancing internal
temperature and pressure with changing environmental conditions: GORE microporous membranes allow rapid bidirectional exchange of air into the structure, in
order to avoid overheating or condensation of water vapor on front glass.
Respect for environment (eco-friendly)
Prolights has always been committed to respect for the future and for the environment when designing new products. All projectors are designed and assembled
with eco-friendly materials, containing no lead or mercury, guaranteeing a low
environmental impact.
Prolights follows a logic of design and development of products maximizing luminous efficiency and minimizing power absorption through employment of most
advanced techniques applied to LED sources and optics.
Contents - ArcLed Series
ArcLed Series
Atmosfera 1803
Atmosfera 903
ArcLed 7361 Zoom
Arcled 7337 Zoom
ArcLed 7337 VW
ArcLed 8107Q
ArcLed 7314 TRI
ArcLed 1307 TRI
ArcLed 4312 WX
ArcLed 338 PIX
ArcLed 3172 RGBWA
ArcLed 3144 RGBWA
ArcLed 1101Q
ArcLed 1107 RGBW
ArcLed 1107 AW
ArcLed 1107 UV
52
54
56
58
60
62
64
66
68
70
72
74
76
77
78
79
ATMOSFERA1803
LED
180X3W
C°
-40 +50
matrix
RGBWA
CONTROL
IP66
ATMOSFERA1803 is an outdoor projector excelling in the class of architectural LED luminaires for the
outstanding power of its 180 3W RGBWA LEDs. Its amazing light output is comparable to 2500W lampbased architectural projectors, having power consumption reduced to only 680W. ATMOSFERA1803 is
absolutely silent, due to cooling by natural convection and absence of fans, allowing IP66 protection
rate for large outdoor lighting projects as large events, building facades or architectural integration.
Light source and optics
• 180 x 3W Seoul RGBWA LEDs (1’000mA green, blue, white, 700mA red, amber)
• Lumen: 18000
• [email protected]: [email protected]
• LED section: 44 red, 44 green, 44 blue, 24 white, 24 amber
• Energy-saving LEDs employed, with more vivid colours and lower power consumption than traditional
lamps
• Colour synthesis: RGBWA colour mixing (>16 million colours) for a limitless colour range with full
control over saturation and temperature allowed by amber and white LEDs
• White temperature presets: 3200K~10000K
• Installed optics: 30°
• Beam angle: 25°
• Field angle: 50°
• LEDs average life span: >50’000 h
Accessories
52
Compatible with WR24A
Antenna receiver
WR24A
DMX Antenna receiver.
WT24DMXIP
DMX Wireless transmitter,
2.4 GHz protocol, IP65
Scan with your PHONE
to view product page.
FCL1803 (included): Carrying Roadcase designed to contain 1 pc of ATMOSFERA1803, Dim. 865x610x460 mm
ARCATL15 (optional): Spare optics for ATMOSFERA1803 projectors, 15°
ARCATL256 (optional): Spare optics for ATMOSFERA1803 projectors, 25°x6°
ARCATL55 (optional): Spare optics for ATMOSFERA1803 projectors, 55°
C462S (optional): Aluminium hook style single Truss Clamp, Slim version
Arcled Series - led projectors
-10°/+90°
Electronics and features
• Frontal tempered glass panel
• Several DMX selectable configurations (3, 4,
5, 6, 7, 10, 17 channels) for advanced or basic
controlling
• Internal Protection: IP66
3 channels: RGB
-96°/+96°
3 channels: HSV
• Mechanical system for individual positioning
of LED panels
4 channels: RGB, dimmer
• Individual panel excursion: -10°-/+90°
5 channels: RGBWA
• Simultaneous panel excursion: -96°/+96°
6 channels: dimmer, RGBWA
• Power (shuko) and data (xlr-3p) adapter
cables included
7 channels: dimmer, RGBWA, strobe
30°
Illuminance at a Distance
Center Beam LUX
Field Width
16500lx
0.98m 0.98m
4.0m
4140lx
1.95m 1.96m
6.0m
1840lx
2.92m 2.93m
8.0m
1035lx
3.90m 3.90m
10.0m
662lx
4.87m 4.87m
2.0m
Vert. Spread: 28°
10 channels: BLOCK1 (RGBWA), BLOCK2
(RGBWA) for independent control of each
panel
• E rgonomic handles for carr ying and
positioning
17 channels: dimmer, BLOCK1 (RGBWA),
BLOCK2 (RGBWA), macro, strobe, auto,
dimmer speed, ID address
• Suspension and fixing: any possible working
position through omega kit (included) with
“quick lock” system
• LED display user interface for auto programs
execution, static colour mode, creation of
custom shows, colour calibration presets
• 5 different dimming available curves.
• M a s te r / S l ave m o d e fo r s t a n d - a l o n e
operations
Horiz. Spread: 28°
• Pressure and temperature balance through
GORE membrane vents
• Storage and carrying flight case included
• Power unit: 100-240V 50/60Hz
• Working condition: -40/+50°
• Max power consumption: 680 W
• Weight: 40,3 kg
• Dimensions (WxHxD): 808x516x252 mm
• Linear and “step-less” transition between DMX
values
40,3 kg
• Flicker-free operations (400Hz)
516
• Silent operations, due to natural cooling of
the peculiar chassis and to absence of fans
Structure and Power supply
• Sturdy die-cast aluminium body conceived
for long-time durability and demanding
applications
808
252
53
ATMOSFERA903
LED
90X3W
C°
-40 +50
matrix
RGBWA
CONTROL
IP66
ATMOSFERA903 is an outdoor projector excelling in the class of architectural LED luminaires for the
outstanding power of its 90 3W RGBWA LEDs. Its amazing light output is comparable to 1200W lampbased architectural projectors, having power consumption reduced to only 300W. ATMOSFERA903 is
absolutely silent, due to cooling by natural convection and absence of fans, allowing IP66 protection
rate for large outdoor lighting projects as large events, building facades or architectural integration.
Light source and optics
• 90 x 3W Seoul RGBWA LEDs (1’000mA green, blue, white, 700mA red, amber)
• Lumen: 9000
• Lux: [email protected]
• LED section: 22 red, 22 green, 22 blue, 12 white, 12 amber
• Energy-saving LEDs employed, with more vivid colours and lower power consumption than traditional
lamps
• Colour synthesis: RGBWA colour mixing (>16 million colours) for a limitless colour range with full
control over saturation and temperature allowed by amber and white LEDs
• White temperature presets: 3200K~10000K
• Installed optics: 30°
• Beam angle: 25°
• Field angle: 50°
• LEDs average life span: >50’000 h
Accessories
54
Compatible with WR24A
Antenna receiver
WR24A
DMX Antenna receiver.
Scan with your PHONE
to view product page.
FCL903 (included): Carrying Roadcase designed to contain 1 pc of ATMOSFERA903, Dim. 865x610x460 mm
ARCATL15 (optional): Spare optics for ATMOSFERA1803 projectors, 15°
ARCATL256 (optional): Spare optics for ATMOSFERA1803 projectors, 25°x6°
ARCATL55 (optional): Spare optics for ATMOSFERA1803 projectors, 55°
C462S (optional): Aluminium hook style single Truss Clamp, Slim version
WT24DMXIP
DMX Wireless transmitter,
2.4 GHz protocol, IP65
Arcled Series - led projectors
Electronics and features
• S everal DMX selectable configurations (3,
4, 5, 6, 7, 11 channels) for advanced or basic
controlling
3 channels: RGB
-96°/+96°
3 channels: HSV
4 channels: RGB, dimmer
Illuminance at a Distance
Center Beam LUX
Field Width
• Individual panel excursion: -10°-/+90°
• Simultaneous panel excursion: -96°/+96°
• Power (shuko) and data (xlr-3p) adapter
cables included
5 channels: RGBWA
• E rgonomic handles for carr ying and
positioning
6 channels: dimmer, RGBWA
• Storage and carrying flight case included
7 channels: dimmer, RGBWA, strobe
• Suspension and fixing: any possible working
position through omega kit (included) with
“quick lock” system
11 channels: dimmer, RGBWA, macro, strobo,
auto, auto speed, dimmer speed
30°
• Mechanical system for individual positioning
of LED panels
• LED display user interface for auto programs
execution, static colour mode, creation of
custom shows, colour calibration presets
• Power unit: 100-240V 50/60Hz
• Working condition: -40/+50°
• Max power consumption: 300 W
16500lx
0.98m 0.98m
• 5 different dimming available curves
• Weight: 24 kg
4.0m
4140lx
1.95m 1.96m
• Dimensions (WxHxD): 784x252x310 mm
6.0m
1840lx
2.92m 2.93m
• M a s te r / S l ave m o d e fo r s t a n d - a l o n e
operations
8.0m
1035lx
3.90m 3.90m
10.0m
662lx
4.87m 4.87m
2.0m
Vert. Spread: 28°
• Linear and “step-less” transition between DMX
values
• Flicker-free operations (400Hz)
Horiz. Spread: 28°
• Silent operations, due to natural cooling of
the peculiar chassis and to absence of fans
Structure and Power supply
24 kg
310
• Sturdy die-cast aluminium body conceived
for long-time durability and demanding
applications
• Frontal tempered glass panel
• Internal Protection: IP66
784
252
• Pressure and temperature balance through
GORE membrane vents
55
ARCLED7361ZOOM
LED
61X3W
zoom
RGBW
8°/40°
C°
-40 +50
IP67
ARCLED7361ZOOM is a unique LED luminaire in LED lighting range for its performance and technological contents.
It has been conceived to innovate the concept of LED source applied to lighting sector, featuring the innovative
zoom technology for a linear passage from 8° spot to 40° wide beam.
Optical section is composed by a brand new elliptical lens placed on a motorized scrolling panel.
The great flexibility of control, combined to its powerful output (37x3W RGBW LEDs), make ARCLED7361ZOOM an
outstanding tool for professional Light-Designers to fulfill lighting projects in large outdoor events (IP67 rated),
roadshows, theatres, architectural installations.
Accessories (optional)
98
Ø1
203
Scan with your PHONE
to view product page.
90
132
ARC7361TPG
Filter frame holder
suitable
227
203
8
19
ARCLED7361TZ - “Tour” version
connections with Neutrik Powercon IN / OUT, ​​IP54
Ø
ARCLED7361IP - “Waterproof”
version with connections to IP67
56
6
19
116
Versions
227
Ø
234
28
Ø2
280
ARC7361BD
Adjustable
barndoor suitable
ARC7361RBD
Round barn-door
ARC7361FILTER5
FLOOD filter 5°
FCL7361 (optional): Carrying Roadcase designed to contain 8 pcs of ARCLED7361ZOOM, Dim. 820x570x490mm
ARCLEDEXAC3L02 (optional): Extension IP68 power cable, L.1mt comp. ARCLED7314/7337/7361/8107
ARCLEDEXDC3L02 (optional): Extension IP67 data cable, L.1mt comp. ARCLED7314/7337/7361/8107
C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Arcled Series - led projectors
Light source and optics
• 5 different dimming available curves
• 61 x 3W high-efficiency CREE RGBW LEDs (17
red, 17 green, 17 blue, 10 white)
• M a s te r / S l ave m o d e fo r s t a n d - a l o n e
operations
• Lumen: 3500
• Linear and “step less” transition between DMX
values
• Lux: [email protected]
• Energy-saving LEDs employed, with more
vivid colours and lower power consumption
than traditional lamps
• Colour synthesis: RGBW colour mixing (>16
million colours) for a limitless colour range
8°
• Silent operations, due to natural convection
cooling of the peculiar chassis and to absence
of fans
• White temperature presets: 3200K~10000K
Structure and Power supply
• Beam angle: 8°-40° Zoom
• Electronic linear zoom with motorized and
scrolling lens panel
• Sturdy die-cast aluminium body conceived
for long-time durability and demanding
applications
• LEDs average life span: >50’000h
• Frontal tempered glass panel
• Internal Protection: IP67
0m
Illuminance at a Distance
• Flicker-free operations (400Hz)
2.0m
4.0m
6.0m
8.0m
10.0m
Electronics and features
31041lx
0.30m
7761lx
0.6m
3449lx
0.94m
1939lx
1.25m
1241lx
1.56m
Lux Center
Beam Angle: 8°
Beam Width
• S everal DMX configurations selectable (3,
4, 5, 6, 12 channels) for advanced or basic
controlling
3 channels: RGB
3 channels: HSV
4 channels: RGB, dimmer
4 channels: RGBW
5 channels: RGBW, dimmer
9 kg
6 channels: RGBW, dimmer, strobe
Ø 237
12 channels: RGBW, dimmer, macro, strobe,
auto programs, programs speed, dimmer
curve, zoom, Zoom reset
302
311
• Pressure and temperature balance through
GORE membrane vents
• Power (shuko) and data (xlr-3p) adapter
cables included
• D ouble hanging bracket suitable for safe
hanging and for floor positioning
• Power unit: 100-240V 50/60Hz
• Working temperatures: -40/45°
• Power output to link more units in a chain: up
to 12 fixtures at 230V
• Max power consumption: 180W
• Weight: 9 kg
• Dimensions (WxHxD): 302x237x311 mm
• LED display user interface for auto programs
execution, static colour mode, creation of
custom shows, colour calibration presets
57
ARCLED7337ZOOM
LED
37X3W
zoom
RGBW
8°/40°
C°
-40 +50
IP67
ARCLED7337ZOOM is a unique LED luminaire in LED lighting range for its performance and technological contents.
It has been conceived to innovate the concept of LED source applied to lighting sector, featuring the innovative
zoom technology for a linear passage from 8° spot to 40° wide beam. Optical section is composed by a brand
new elliptical lens placed on a motorized scrolling panel. The great flexibility of control, combined to its powerful
output (37x3W RGBW LEDs), make ARCLED7337ZOOM an outstanding tool for professional Light-Designers to
fulfill lighting projects in large outdoor events (IP67 rated), roadshows, theatres, architectural installations.
Accessories (optional)
70
Ø1
168
58
77
112,5
ARC7337TPG
Filter-frame for
ARCLED7337ZOOM
189
168
2
Scan with your PHONE
to view product page.
16
ARCLED7337ZOOMIP - “Waterproof” version
with IP67 connections
ARCLED7337ZOOMTZ - “Tour” version
with Neutrik Powercon IN/OUT, IP54 connections
Ø
2
16
97,5
Versions
189
Ø
196
90
Ø1
242
ARC7337BD
Adjustable suitable
barn door projector
ARC7337RBD
Round barn door for
ARCLED7337ZOOM.
ARC7337FILTER5
FLOOD filter for ARCLED7337.
FCL7337 (optional): Carrying Roadcase designed to contain 8pcs of ARCLED7337ZOOM, Dim. 960x525x515mm
ARCEXAC3L02 (optional): Extension IP68 power cable, L.1mt comp. ARCLED7314/7337/7361/8107
ARCEXDC3L02 (optional): Extension IP67 DMX cable, comp. with outdoor (IP) ARCLED projectors
ARCEXAC4L005 (optional): Power ext cable, comp with indoor (TZ) ARCLED proj, NAC3FCA->NAC3FCB, L.0,5mt C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Arcled Series - led projectors
Light source and optics
• 5 different dimming available curves • 37 x 3W high-efficiency CREE RGBW LEDs (10
red, 10 green, 10 blue, 7 white)
• M a s te r / S l ave m o d e fo r s t a n d - a l o n e
operations
• Lumens: 2280
• Linear and “stepless” transition between DMX
values
• [email protected]: [email protected]
• Energy-saving LEDs employed, with more
vivid colours and lower power consumption
than traditional lamps
• Colour synthesis: RGBW colour mixing (>16
million colours) for a limitless colour range
• Silent operations, due to natural convection
cooling of the peculiar chassis and to absence
of fans
• White temperature presets: 3200K~10000K
Structure and Power supply
• Beam angle: 8°-40° Zoom
• Electronic linear zoom with motorized and
scrolling lens panel
• Sturdy die-cast aluminium body conceived
for long-time durability and demanding
applications
• LEDs average life span: >50’000h
• Frontal tempered glass panel
8°
• Internal Protection: IP67
0m
Illuminance at a Distance
• Flicker-free operations (400Hz)
2.0m
4.0m
6.0m
8.0m
10.0m
Electronics and features
• S everal DMX configurations selectable (3,
4, 5, 6, 12 channels) for advanced or basic
controlling
13777lx
0.35m
3444lx
0.7m
1531lx
1.05m
861lx
1.41m
3 channels: HSV
551lx
1.76m
4 channels: RGB, dimmer
Lux Center
Beam Angle: 8°
Beam Width
3 channels: RGB
4 channels: RGBW
5 channels: RGBW, dimmer
6 channels: RGBW, dimmer, strobe
6,5 kg
Ø 203
12 channels: RGBW, dimmer, macro, strobe,
auto programs, programs speed, dimmer
curve, zoom, Zoom reset
248
311
• Pressure and temperature balance through
GORE membrane vents
• Power (shuko) and data (xlr-3p) adapter
cables included
• D ouble hanging bracket suitable for safe
hanging and for floor positioning
• Power unit: 100-240V 50/60Hz
• Working temperatures: -40/45°
• Power output to link more units in a chain: up
to 24 fixtures at 230V
• Max power consumption: 100W
• Weight: 6,5 kg
• Dimensions (WxHxD): 203x248x311 mm
• LED display user interface for auto programs
execution, static colour mode, creation of
custom shows, colour calibration presets
59
ARCLED7337VW
LED
37X3W
zoom
WW+CW
8°/40°
C°
-40 +50
IP67
ARCLED7337VW is a LED projector in Variable White version conceived for a linear reproduction of the entire
range of white variants.
The light source is composed by 37x3W WarmWhite and ColdWhite LEDs granting a precise white temperature
adjustment, for a gradual passage between warm and cold tones by keeping a high luminous efficiency all over
the white range.
ARCLED7337VW features the new 8°-40° fast zoom technology allowing to change the projection angle between
a narrow tight spot and a soft flood diffusion, making this fixture an outstanding versatile tool for all white-light
projects. ARCLED7337VW is built in a compact and stylish aluminium waterproof case (IP67) allowing a natural
convection cooling system for totally silent performance and even outdoor lighting projects.
This compact-size luminaire is the ideal choice to replace traditional halogen luminaires in theatres, live,
architectural, TV studios and showrooms, reducing energy consumption and allowing a full temperature control.
Accessories (optional)
70
Ø1
168
77
112,5
ARC7337TPG
Filter-frame for
ARCLED7337ZOOM
189
168
2
16
Scan with your PHONE
to view product page.
Ø
2
97,5
ARCLED7337VWIP - “Waterproof” version
with IP67 connections
ARCLED7337VWTZ - “Tour” version
with Neutrik Powercon IN/OUT, IP54 connections
60
16
Versions
189
Ø
196
90
Ø1
242
ARC7337BD
Adjustable suitable
barn door projector
ARC7337RBD
Round barn door for
ARCLED7337ZOOM.
ARC7337FILTER5
FLOOD filter for ARCLED7337.
FCL7337 (optional): Carrying Roadcase designed to contain 8pcs of ARCLED7337ZOOM, Dim. 960x525x515mm
ARCLEDEXDC3L02 (optional): Extension IP67 data cable, L.1mt comp. ARCLED7314/7337/7361/8107
ARCLEDEXAC3L02 (optional): Extension IP68 power cable, L.1mt comp. ARCLED7314/7337/7361/8107
C260 (optional): Single aluminum ‘’quick-lock’’ truss clamp suitable for 48-52 mm tube
C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Arcled Series - led projectors
Light source and optics
• Flicker-free operations (400Hz)
• 37 x 3W high-efficiency CREE Variable White
LEDs (30 WarmWhite, 7 ColdWhite)
• Silent operations, due to natural convection
cooling of the peculiar chassis and to absence
of fans
• Lumens: 2280
• Lux: [email protected]
• Energy-saving LEDs employed, with more
vivid colours and lower power consumption
than traditional lamps
• Frontal tempered glass panel
• White temperature presets: 3200K~10000K
• Internal Protection: IP67
• Beam angle: 8°-40° Zoom
• Pressure and temperature balance through
GORE membrane vents
• LEDs average life span: >50’000 h
Illuminance at a Distance
0m
2.0m
4.0m
6.0m
8.0m
10.0m
Electronics and features
13777lx
0.35m
3444lx
0.7m
1531lx
1.05m
• 1 channel: Master dimmer
861lx
1.41m
• 3 channels: dimmer, Warm+Cold White, Zoom
551lx
1.76m
• 4 channels: dimmer, WarmWhite, ColdWhite,
Zoom
Lux Center
Beam Angle: 8°
Beam Width
6,5 kg
• Sturdy die-cast aluminium body conceived
for long-time durability and demanding
applications
• Colour synthesis: Variable White for a full
white temperature control
• Electronic linear zoom with motorized and
scrolling lens panel
8°
Structure and Power supply
• Several DMX selectable configurations (1,3, 4
channels) for advanced or basic controlling
• LED display user interface for auto programs
execution, static colour mode, creation of
custom shows, colour calibration presets
• Power (shuko) and data (xlr-3p) adapter
cables included
• D ouble hanging bracket suitable for safe
hanging and for floor positioning
• Power unit: 100-240V 50/60Hz
• Working temperatures: -40/45°
• Power output to link more units in a chain: up
to 12 fixtures at 220V
• Max power consumption: 100 W
• Weight: 6,5 kg
• Dimensions (WxHxD): 203x248x311 mm
• 5 different dimming available curves Ø 203
• M a s te r / S l ave m o d e fo r s t a n d - a l o n e
operations
248
311
• Linear and “stepless” transition between DMX
values
61
ARCLED8107Q
LED
7X10W
RGBW/FC
beam
C°
10°
-40 +50
IP67
ARCLED8107Q is an innovative LED luminaire engineered to employ the brand-new CREE RGBW FullColor 10W
multi-chip LED, granting an impressive luminous output in a compact-size housing. The cutting-edge optic design
(over 85% optic efficiency) offers an advanced chromatic generation and a full control over colour saturation and
temperature. ARCLED8107Q is built in a compact and stylish aluminium waterproof case (IP66) allowing a natural convection
cooling system for totally silent performance and even outdoor architectural lighting project.
ARCLED8107Q represents an outstanding versatile tool for realization of lighting project in live events, theatre, TV
studios and architectural. Accessories (optional)
70
Ø1
168
Scan with your PHONE
to view product page.
62
2
ARCLED8107QIP - “Waterproof” version
with IP67 connections
ARCLED8107QTZ - “Tour” version
with Neutrik Powercon IN/OUT, IP54 connections
16
Versions
Ø
2
16
97,5
168
Ø
196
90
Ø1
242
77
112,5
ARC8107TPG
Filter frame
holder suitable for
ARCLED8107Q
ARC8107BD
Adjustable
barndoor suitable
for ARCLED8107Q
projector
ARC8107RBD
Round barn-door to
perform spot beam,
comp. ARCLED8107
FCL8107 (optional): Carrying Roadcase designed to contain 8 pcs of ARCLED8107Q, Dim. 780x540x480mm
ARCLEDEXAC3L02 (optional): Extension IP68 power cable, L.1mt comp. ARCLED7314/7337/7361/8107
ARCLEDEXDC3L02 (optional): Extension IP67 data cable, L.1mt comp. ARCLED7314/7337/7361/8107
C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Arcled Series - led projectors
Light source and optics
• 7 x 10W high-efficiency CREE RGBW/FC
• Linear and “step less” transition between DMX
values
• Lumen: 3000
• Flicker-free operations (400Hz)
• Lux: [email protected]
• Silent operations, due to natural cooling of
the peculiar chassis and to absence of fans
• Energy-saving LEDs employed, with more
vivid colours and lower power consumption
than traditional lamps
• Colour synthesis: 4in1 RGBW mixing for tones,
temperature and saturation control 8°
Illuminance at a Distance
0m
2.0m
4.0m
6.0m
8.0m
10.0m
13777lx
0.35m
3444lx
0.7m
1531lx
1.05m
861lx
1.41m
551lx
1.76m
Lux Center
Beam Angle: 8°
Beam Width
Structure and Power supply:
• White temperature presets: 3200K~10000K
• Sturdy die-cast aluminium body conceived
for long-time durability and demanding
applications
• Beam angle: 11°
• Frontal tempered glass panel
• Higher optic efficiency (>85%)
• Internal Protection: IP66
• LEDs average life span: >50’000 h
• Pressure and temperature balance through
GORE membrane vents
Electronics and features:
• Power (shuko) and data (xlr-3p) adapter
cables included
• S everal DMX selectable configurations (3,
4, 5, 6, 10 channels) for advanced or basic
controlling
3 channels: RGB
3 channels: HSV
4 channels: RGB, dimmer
4 channels: RGBW
5 channels: RGBW, dimmer
6 channels: RGBW, dimmer, strobe
• D ouble hanging bracket suitable for safe
hanging and for floor positioning
• Power unit: 100-240V 50/60Hz
• Power output to link more units in a chain: up
to 15 fixtures at 230V
• Max power consumption: 85W
• Weight: 5,7 kg
• Dimensions (WxHxD): 240x191x290 mm
10 channels: RGBW, dimmer, macro, strobe,
auto programs, programs speed
5,4 kg
Ø 191
• LED display user interface for auto programs
execution, static colour mode, creation of
custom shows, colour calibration presets
• 5 different dimming available curves
• Master/Slave mode for stand-alone operations
240
290
63
ARCLED7314TRI
LED
14X3W
beam
RGB/FC
17°
C°
-40 +50
IP67
ARCLED7314TRI is a professional luminaires featuring 14 RGB/Full Color 3W LEDs fitted into a single matrix.
ARCLED7314TRI is the first choice in terms of quality and performance for professionals light-design projects in
medium and large size environments.
The advantages of Tricolor technology:
• Perfect colour mixing and saturation, even in short-range projections
• Unwanted RGB shadows are completely eliminated; this makes ARCLED7314 suitable for theatrical, studios and
architectural applications
• Perfect for frontal video recordings: colours are mixed into the optical system, avoiding single Red, Green, Blue
colour spreads
Accessories (optional)
70
Ø1
168
64
2
Scan with your PHONE
to view product page.
16
ARCLED7314TRI IP - “Waterproof” version
with IP67 connections
ARCLED7314TRI TZ - “Tour” version
with Neutrik Powercon IN/OUT, IP54 connections
Ø
2
16
97,5
Versions
168
Ø
196
90
Ø1
242
77
112,5
ARC7314TPG
Filter frame for
ARCLED7314
ARC7314BD
Adjustable suitable
barn door for
ARCLED7314TRI
ARC7314RBD
Round barn door for
ARCLED7314TRI
FCL7314 (optional): Carrying Roadcase designed to contain 8pcs of ARCLED7314TRI,Dim. 1000x460x525 mm
ARCEXAC3L02 (optional): Extension IP68 power cable, L.1mt comp. ARCLED7314/7337/7361/8107
ARCEXDC3L02 (optional): Extension IP67 DMX cable, comp. with outdoor (IP) ARCLED projectors
ARCEXAC4L005 (optional): Power ext cable, comp with indoor (TZ) ARCLED proj, NAC3FCA->NAC3FCB, L.0,5mt
C360 (optional): Aluminium single Truss Clamp with a 15mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Arcled Series - led projectors
Light source and optics
• 14 x 3W high-efficiency CREE RGB/FC LEDs
• Linear and “step less” transition between DMX
values
• Lumen: 950
• Flicker-free operations (400Hz)
• [email protected]: [email protected]
• Silent operations, due to natural cooling of
the peculiar chassis and to absence of fans
• Energy-saving LEDs employed, with more
vivid colours and lower power consumption
than traditional lamps
• Colour synthesis: Tricolor colour mixing (>16
million colours) for a limitless colour range
• White temperature presets: 3200K~10000K
• Sturdy die-cast aluminium body conceived
for long-time durability and demanding
applications
• Installed optics: 16°
• Frontal tempered glass panel
• Beam angle: 17°
• Internal Protection: IP67
• Field angle: 32°
• Pressure and temperature balance through
GORE membrane vents
• LEDs average life span: >50’000h
Electronics and features
Illuminance at a Distance
15°
1.0m
2.0m
3.0m
4.0m
5.0m
0.20m
807/1347lx
202/337lx
0.39m
90/150lx
0.59m
50/84lx
0.78m
32/54lx
0.98m
Eavg/Emax
Beam Angle:11.18°
Beam Width
Structure and Power supply
• Several DMX configurations selectable (3, 4, 5,
10 channels) for advanced or basic controlling
3 channels: RGB
• Power (shuko) and data (xlr-3p) adapter
cables included
• D ouble hanging bracket suitable for safe
hanging and for floor positioning
• Power unit: 100-240V 50/60Hz
3 channels: HSV
• Power output to link more units in a chain: up
to 24 fixtures at 230V
4 channels: RGB, dimmer
• Max power consumption: 52W
5 channels: RGB, dimmer, strobe
• Weight: 4,8 kg
10 channels: RGB, dimmer, macro, strobe,
• Dimensions (WxHxD): 245x205x245 mm
auto programs, programs speed, dimmer
curve, ID address
• LED display user interface for auto programs
execution, static colour mode, creation of
custom shows, colour calibration presets
4,8 kg
Ø 205
• 5 different dimming available curves • Master/Slave mode for stand-alone operations
245
245
65
ARCLED1307TRI
LED
7X3W
beam
RGB/FC
17°
C°
-40 +50
IP33
ARCLED1307TRI is a professional luminaire featuring 7 RGB/Full Color 3W LEDs fitted into a single matrix.
ARCLED1307TRI is the first choice in terms of quality and performance for professionals light-design
projects in medium and large size environments.
The advantages of Tricolor technology:
• Perfect colour mixing and saturation, even in short-range projections
• Unwanted RGB shadows are completely eliminated; this makes ARCLED1307 suitable for theatrical,
studios and architectural applications
• Perfect for frontal video recordings: colours are mixed into the optical system, avoiding single Red,
Green, Blue colour spreads
Accessories (optional)
Ø
0
11
118
118
ARC1307BD
Adjustable and
suitable barn door for
ARCLED1307TRI projector
Scan with your PHONE
to view product page.
66
C260 (optional): Single aluminum ‘’quick-lock’’ truss clamp suitable for 48-52 mm tube
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
ARCEXAC5L005 (optional): Power extension cable, VDE M->VDE F,
Arcled Series - led projectors
Light source and optics
Structure and Power supply
• 7 x 3W high-efficiency CREE RGB/FC LED
technology
• High resistance and flame retardant polymer
case in black colour
• Lumen: 540
• Internal Protection: IP33
• [email protected]: [email protected]
• Power (shuko) and cable (1,5mt) included
• Energy-saving LEDs employed, with more
vivid colours and lower power consumption
than traditional lamps
• D ouble hanging bracket suitable for safe
hanging and for floor positioning
• Colour synthesis: Tricolor colour mixing (>16
million colours) for a limitless colour range
• Power output to link more units in a chain: up
to 40 fixtures at 230V
• White temperature presets: 3200K~8500K
• Max power consumption: 35W
• Beam angle: 16°
• Weight: 2,5 kg
• LEDs average life span: >50’000 h
• Dimensions (WxHxD): 193x157x243 mm
• Power unit: 100-240V 50/60Hz
Electronics and features
• Several DMX selectable configurations (3, 4,
9 channels) for advanced or basic controlling
17°
Illuminance at a Distance
0m
2.0m
4.0m
6.0m
8.0m
10.0m
3 channels: RGB
1174lx
1.20m
4 channels: RGB, dimmer
293lx
2.40m
130lx
3.40m
9 channels: RGB, dimmer, macro, strobe, auto
programs, programs speed, ID address
73lx
4.80m
47lx
Lux Center
5.9m
Beam Angle: 17°
Beam Width
• LCD display user interface for auto programs
execution, static colour mode, creation of
custom shows
• Master/Slave mode for stand-alone operations
• Linear and “stepless” transition between DMX
values
• Flicker free operations (400Hz)
2,5 kg
Ø 157
• Cooling: forced ventilation with adjustment
of fan speed from LCD user interface
193
243
67
ARCLED4312WX
LED
12X3W
+
RGB/FC
-
12h BATTERY
IP44
WIRELESS
ARCLED4312WX is the first LED luminaire in the Prolights range conceived to guarantee a totally wireless operation.
The internal battery pack allows a 12 hours autonomy (continuous operation) and the DMX input is provided by
a 2.4 GHz antenna receiver.
ARCLED4312WX employs 12 CREE 3W LEDs with Full-Color calibration system for outstanding performance even
in outdoor application or architectural lighting projects.
The 6-units optional carrying Roadcase is also suitable as battery-charger though the external Powercon socket.
ARCLED4312WX is a versatile, innovative and portable lighting fixture, designed to match all kinds of applications
as wall/background luminaire where the venue does not allow fixed laying of cables or energy consumption
limitation.
Accessories
FCL4312E (optional): Roadcase for 6pcs ARCLED4312WX, with internal battery charger, Dim.770x565x485mm
WT24DMX (optional): DMX Wireless transmitter, 2.4 GHz protocol
ARC4312DC (optional): External battery charger for ARCLED4312WX
Scan with your PHONE
to view product page.
Scan with your PHONE
to view product page.
68
FCL4312E (optional): Roadcase for 6pcs ARCLED4312WX,
with internal battery charger, Dim.770x565x485mm
Arcled Series - led projectors
Light source and optics
• 5 different dimming available curves • 12 x 3W high-efficiency CREE RGB/FC LED
• Master/Slave mode for stand-alone operations
• Lumen: >800. [email protected]: [email protected]
• Linear and “stepless” transition between DMX
values
• Energy-saving LEDs employed, with more
vivid colours and lower power consumption
than traditional lamps
• Colour synthesis: Tricolor colour mixing (>16
million colours) for a limitless colour range
Structure and Power supply
• Installed optics: 16°
• Protection: IP44 (indoor/outdoor use)
• Beam angle: 17°. Field angle: 32°
• Frontal tempered glass panel
• LED blocks inclination: Independent screw
stepless adjustment of LED blocks
• Internal Protection: IP44 (indoor/outdoor)
16°
Illuminance at a Distance
Electronics and features
2.0m
4.0m
6.0m
8.0m
10.0m
2084lx
0.58m
521lx
1.15m
232lx
1.73m
130lx
83lx
Lux Center
Beam Angle: 16°
• S everal DMX selectable configurations (3,
4, 5, 6, 12 channels) for advanced or basic
controlling
• Battery: 12V, 24Ah lead-acid battery
• Battery autonomy: 20 hours (color change
mode), 12 hours (permanent white light)
• R echarge operations: 6-units Road case
with integrated battery charger or through
external power supply
• Recharge time: max 12 hours.
3 channels: RGB
2.30m
• LED battery status indicator
3 channels: HSV
2.88m
• Load/Storage battery switch
4 channels: dimmer, RGB
• Dmx connections: XLR 3p Input/Output
5 channels: dimmer, RGB, strobe
• Ergonomic carrying handle
6 channels: Block1 (RGB), Block2 (RGB)
• Adjustable foot support for tilt regulation
(max 10°) Beam Width
12 channels: dimmer, BLOCK1 (RGB), BLOCK2
(RGB), macro, strobe, auto, auto speed,
dimmer curve regulation
13,5 kg
199
85°
• WDMX: Antenna receiver (2.4 Ghz) by Wireless
Solution Sweden
• LCD display user interface for auto programs
execution, static colour mode, creation of
custom shows
199
• Silent operations, due to natural cooling of
the peculiar chassis and to absence of fans
• White temperature presets: 3200K~10000K
• LEDs average life span: >50’000 h
0m
• Flicker free operations (400Hz)
• Power unit: 100-240V 50/60Hz
• Working temperature: -40/+45°
• Weight: 13,5 kg
• Dimensions (WxHxD): 199x342x199 mm
342
69
ARCLED338PIX
LED
8X3W
pixel
RGB/FC
CONTROL
C°
-10 +40
IP33
ArcLed338Pix is a linear projector, featuring 8 LEDs (3W each) with RGB/Full Color synthesis. Its modular
design and the cutting-edge digital “Pixel control” technology allow to setup more projector in a ledmatrix with synchronized operations for endless graphic and stage solutions. The “Pixel” control mode
allows to drive each Fullcolor LED separately to create low resolution screens, large dynamic ledwalls
and chromatic patterns.
TriColor optical group makes ArcLed338Pix suitable even for professional architectural applications where
a perfect chromatic expression is needed.
Scan with your PHONE
to view product page.
70
Accessories
FCL338 (optional): Carrying Roadcase designed to contain 20 pcs of ARCLED338PIX
C60 (included): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
C260 (optional): Single aluminum ‘’quick-lock’’ truss clamp suitable for 48-52 mm tube
Arcled Series - led projectors
Light source and optics
• 8 x 3W high-efficiency CREE RGB/FC LED
technology
• Master/Slave mode for stand-alone operations
• Lumen: 650
• Flicker free operations (400Hz)
• [email protected]: [email protected]
• Cooling: forced ventilation with adjustment
of fan speed from LCD user interface
• Energy-saving LEDs employed, with more
vivid colours and lower power consumption
than traditional lamps
• Colour synthesis: Tricolor colour mixing (>16
million colours) for a limitless colour range
• White temperature presets: 3200K~10000K
• Installed optics: 16°
• Beam angle: 17°
16°
Illuminance at a Distance
4.0m
6.0m
8.0m
10.0m
• Internal Protection: IP33
• Power cable (shuko 1,5 mt) included
• LEDs average life span: >50’000h
• Power unit: 100-240V 50/60Hz
Electronics and features
• Power output to link more units in a chain: up
to 24 fixtures at 230V
0.58m
376lx
1.16m
167lx
1.74m
94lx
2.32m
3 channels: RGB
60lx
2.9m
3 channels: HSV
Beam Angle: 16°
• High resistance and flame retardant polymer
case in black colour
• D ouble hanging bracket suitable for safe
hanging and for floor positioning
1506lx
Lux Center
Structure and Power supply
• Field angle: 32°
0m
2.0m
• Linear and “stepless” transition between DMX
values
• S everal DMX selectable configurations (3,
4, 10, 24 channels) for advanced or basic
controlling
• Max power consumption: 40W
• Weight: 3,1 kg
• Dimensions (WxHxD): 575x89x160 mm
4 channels: RGB, dimmer
Beam Width
10 channels: Dimmer, RGB, Colour Macros,
strobe, auto programs, programs speed,
Dimming curve, block selection
24 channels: RGB (each pixel)
• LCD display user interface for auto programs
execution, static colour mode, creation of
custom shows
89
3,1 kg
575
165
• 5 different dimming available curves 71
ARCLED3172RGBWA
LED
72X1W
matrix
RGBWA
CONTROL
C°
-10 +40
IP33
ARCLED3172RGBWA is a professional linear colour-changer housing 72 high-power LEDs with RGBWA
colour mixing. This projector performs a limitless colour range, combining the wide chromatic scale
obtained with RGB mixing with saturation and temperature adjustment granted by control of amber
and white LEDs.
The advanced control system of this fixture offers independent control of each of the 3 sectors
composing the light bar, for a professional and flexible control.
ARCLED3172RGBWA is optimized to produce theatrical-quality whites (3200K-10000K range) and tints
that render pigments and skin tones in their natural appearance. Scan with your PHONE
to view product page.
72
Accessories
FCL3172 (optional): Carrying Roadcase designed to contain 8pcs of ARCLED3172RGBWA,Dim.580x1
195x370mm
ARCLED3L256 (optional): Asymmetric 25°x6° optics for ARCLED3172RGBWA projector
C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Arcled Series - led projectors
Light source and optics
• 72 x 1W CREE high-efficiency RGBWA LEDs (18
red, 18 green, 18 blue, 9 white, 9 amber)
• Lumen: 2180
• [email protected]: [email protected]
• Energy-saving LEDs employed, with more
vivid colours and lower power consumption
than traditional lamps
• C olour synthesis: RGBWA colour mixing
(>16 million colours) for a limitless colour
range with full control over saturation and
temperature allowed by amber and white
LEDs
• White temperature presets: 3200K~10000K
• Installed optics: 30°
13 channels: RGBWA, dimmer, dimmer curve,
strobe, macro, auto programs, programs
speed, ID address, segment selection
15 channels: RGBWA (independent segment
control)
• LED display user interface for auto programs
execution, static colour mode, creation of
custom shows, colour calibration presets
• M a s te r / S l ave m o d e fo r s t a n d - a l o n e
operations
• Linear and “stepless” transition between DMX
values
• Flicker-free operations (400Hz)
• Cooling: forced ventilation with adjustment
of fan speed from LCD user interface
• Beam angle: 40°
• Field angle: 54°
Structure and Power supply
• LEDs average life span: >50’000h
• Extruded aluminium case in black colour
• Internal Protection: IP33
30°
Electronics and features
Illuminance at a Distance
0m
2.0m
4.0m
6.0m
8.0m
10.0m
1030lx
1.10m
258lx
2.2m
• Several DMX selectable configurations (3, 4, 5,
6, 7, 9, 13, 15 channels) for advanced or basic
controlling
• I nput/Output power connections: Neutrik
NAC3MPA, NAC3MPB
• Double bracket suitable as a floor stand for
accurate positioning, 0é-180° adjustment
155lx
3.7m
3 channels: RGB
• Power unit: 100-240V 50/60Hz
64lx
4.10m
3 channels: HSV
• Power output to link more units in a chain: up
to 12 fixtures at 230V
41lx
Lux Center
4 channels: RGB, dimmer
5.8m
Beam Angle: 30°
5 channels: RGBWA
Beam Width
6 channels: RGBWA, dimmer
7 channels: RGBWA, dimmer, strobe
4,4 kg
• Max power consumption: 87W
• Weight: 4,4 kg
• Dimensions (WxHxD): 989x74x156 mm
74
9 channels: RGB (segment control)
989
156
73
ARCLED3144RGBWA
LED
144X1W
RGBWA
matrix
dual-optic
CONTROL
15°/30°
IP33
ARCLED3144RGBWA is a professional linear colour-changer housing 144 high-power LEDs
with RGBWA colour mixing. This projector performs a limitless colour range, combining the
wide chromatic scale obtained with RGB mixing with saturation and temperature adjustment
granted by control of amber and white LEDs.
The new concept dual-optic design with 15° and 30° lenses makes this linear projector a
multipurpose fixture, granting an high luminous capacity for long-throw projection by keeping
a smooth and uniform chromatic reproduction in close proximity to the fixture. The advanced control system of this fixture offers independent control of each of the 3 sectors
composing the light bar, for a professional and flexible control.
ARCLED3144RGBWA is optimized to produce theatrical-quality whites (3200K-10000K range)
and tints that render pigments and skin tones in their natural appearance.
Accessories (optional)
5
Ø 2,5
10
Scan with your PHONE
to view product page.
74
FCL3144 (optional): Carrying Roadcase designed to contain 8 pcs of ARCLED3144RGBWA
C460 (optional): Aluminium single Truss Clamp with a 13mm hole
C60 (optional): Steel security cable for hanging bodies - inox steel shackle - 60cm L.
Arcled Series - led projectors
Light source and optics
• 144 x 1W CREE high-efficiency RGBWA LEDs
(36 red, 36 green, 36 blue, 18 white, 18 amber)
• Lumen: 5160
• Lux: [email protected]
• Energy-saving LEDs employed, with more
vivid colours and lower power consumption
than traditional lamps
• C olour synthesis: RGBWA colour mixing
(>16 million colours) for a limitless colour
range with full control over saturation and
temperature allowed by amber and white
LEDs
• White temperature presets: 3200K~10000K
13 channels: RGBWA, dimmer, strobe, macro,
auto programs, programs speed, ID address,
segment selection
15 channels: RGBWA (independent segment
control)
• LED display user interface for auto programs
execution, static colour mode, creation of
custom shows, colour calibration presets
• Master/Slave mode for stand-alone operations
• Linear and “stepless” transition between DMX
values
• Flicker-free operations (400Hz)
• Cooling: forced ventilation with adjustment
of fan speed from LCD user interface
• Installed optics: 15° and 30° dual-optic design
15°
Illuminance at a Distance
0m
2.0m
4.0m
6.0m
8.0m
10.0m
9390lx
0.52m
2347lx
1.04m
1043lx
1.56m
587lx
2.08m
376lx
2.60m
Lux Center
Beam Angle: 15°
• Upper section optics: 15°
Structure and Power supply
• Lower section optics: 30°
• Extruded aluminium case in black colour
• LEDs average life span: >50’000 h
• Internal Protection: IP33
Electronics and features
• I nput/Output power connections: Neutrik
NAC3MPA, NAC3MPB
• Several DMX selectable configurations (3, 4, 5,
6, 7, 9, 12, 15 channels) for advanced or basic
controlling
3 channels: RGB
Beam Width
8,2 kg
• Double bracket suitable as a floor stand for
accurate positioning, 0-180° adjustment
• Power unit: 100-240V 50/60Hz
3 channels: HSV
• Power output to link more units in a chain: up
to 6 fixtures at 230V
4 channels: RGB, dimmer
• Max power consumption: 170W
5 channels: RGBWA
• Weight: 8,2 kg
6 channels: RGBWA, dimmer
• Dimensions (WxHxD): 997x133x212 mm
7 channels: RGBWA, dimmer, strobe
133
9 channels: RGB (segment control)
997
212
75
ARCLED1101Q
LED
1X10W
beam
RGBW/FC
10°
C°
-10 +40
IP20
ARCLED1101Q is a new-concept light device, designed to house 1x10W high-power RGBW FullColour LED in a
super-slim body. The multi-chip RGBW/FC colour calibration system offers an advanced chromatic generation
and a full control over colour saturation and temperature. The brand-new optic design features an homogeneous
mixing of the 4 primary colours (RGBW) inside a single lens avoiding the view of the pixels or RGB shadows. The
compact sizes makes ARCLED1101Q suitable for all kind of environments or lighting project in limited spaces as
truss lighter (10° light beam). accent luminaire or blinder. 11°
Illuminance at a Distance
0m
2.0m
4.0m
6.0m
8.0m
10.0m
302lx
0.78m
76lx
1.56m
34lx
2.33m
19lx
3.11m
12lx
3.89m
Lux Center
Beam Angle: 22°
Beam Width
Scan with your PHONE
to view product page.
76
Electronics and features
• Several DMX selectable configurations (3, 4, 5, 6 and
9 channels) for advanced or basic controlling
3 channels: RGB
3 channels: HSV
4 channels: RGB, dimmer
4 channels: RGBW
5 channels: RGBW, dimmer
6 channels: RGBW, dimmer, strobe
Accessories
C260 (optional): Single aluminum ‘’quick-lock’’ truss
clamp suitable for 48-52 mm tube
C60 (optional): Steel security cable for hanging bodies
- inox steel shackle - 60cm L.
9 channels: RGBW, dimmer, macro, strobe, auto
programs, programs speed
• L ED display user interface for auto programs
execution, static colour mode, creation of custom
shows, colour calibration presets
• Master/Slave mode for stand-alone operations
• Linear and “step-less” transition between DMX values
• Flicker free operations (400Hz)
• S ilent operations, due to natural cooling of the
peculiar chassis and to absence of fans
Structure and power supply
• Sturdy die-cast aluminium body conceived for longtime durability and demanding applications
• Internal protection: IP20
• Power (shuko) and data (xlr-3p) cables included
• Double hanging bracket suitable for safe hanging
and for floor positioning
• Power unit: 100-240V 50/60Hz
• Max power consumption: 16W
• Weight: 1 kg
• Dimensions (WxHxD): 212x124x80 mm
1 kg
124
Light source and optics
• 1 x 10W high-efficiency CREE RGBW FullColour
• Lumen: 269
• Lux: [email protected]
• E nergy-saving LEDs employed, with more vivid
colours and lower power consumption than
traditional lamps
• Colour synthesis: 4 in1 RGBW mixing for tones,
temperature and saturation control • White temperature presets: 3200K~10000K
• Beam Angle: 11°
• Higher optic efficiency (>85%)
• LEDs average life span: > 50.000 hours
80
213
ARCLED1107RGBW
LED
7X1W
beam
RGBW
20°
Arcled Series - led projectors
IP33
ARCLED1107 is a new-concept light device, designed to renew lighting projects in confined spaces. Despite its
diminutive dimensions (only 17x6,5 cm), ARCLED1107 has an amazing light output due to its 7 high-efficiency
1W LEDs and a large chromatic flexibility allowed by RGBW colour mixing. The sleek design, the robust aluminium
housing, the DMX and manual control make this device suitable for all kind of application like truss warmer, casting
accent colour in segments on a stage set, blinder, furniture lighting.
0m
2.0m
4.0m
6.0m
8.0m
10.0m
262lx
0.64m
65lx
1.28m
29lx
1.92m
16lx
2.56m
10lx
Lux Center
3.20m
Beam Angle: 18°
Beam Width
Scan with your PHONE
to view product page.
Electronics and features
• Several DMX selectable configurations (3, 4 and 9
channels) for advanced or basic controlling
3 channels: RGB
4 channels: RGBW
9 channels: RGBW, dimmer, macro, strobe, auto
programs, programs speed
Accessories
ARC1107L35 (optional): 35° optics for ARCLED1107/
ARCSPIKE7
C260 (optional): Single aluminum ‘’quick-lock’’ truss
clamp suitable for 48-52 mm tube
C60 (optional): Steel security cable for hanging bodies
- inox steel shackle - 60cm L.
• U ser interface through dip-switches for DMX
addressing, manual control, auto-mode and selection
of DMX mode
• Master/Slave mode for stand-alone operations
• Linear and “step-less” transition between DMX values
• Flicker free operations (400Hz)
• S ilent operations, due to natural cooling of the
peculiar chassis and to absence of fans
Structure and power supply
• Sturdy die-cast aluminium body conceived for longtime durability and demanding applications
• Internal protection: IP20
• Power (shuko) and data (xlr-3p) cables included
• Double hanging bracket suitable for safe hanging
and for floor positioning
• Power unit: 100-240V 50/60Hz
• Max power consumption: 10W
• Weight: 0,8 kg
• Dimensions (WxHxD): 110x65x175 mm
0,8 kg
65
Illuminance at a Distance
18°
Light source and optics
• 7 x 1W high-efficiency CREE LEDs: (2 red, 2 green, 2
blue, 1 white)
• Lumen: 160
• [email protected]: [email protected]
• E nergy-saving LEDs employed, with more vivid
colours and lower power consumption than
traditional lamps
• Colour synthesis: RGBW colour mixing (>16 million
colours) for a limitless colour range
• White temperature presets: 3200K~8500K
• Installed optics: 18°
• Beam angle: 20°
• Field angle: 37,5°
• LEDs average life span: > 50.000 hours
110
175
77
ARCLED1107AW
LED
7X1W
beam
WW+CW
20°
C°
-10 +40
IP33
ARCLED1107AW is an innovative LED luminaire, designed to express a new concept of lighting in indoor location
where a compact (only 17x6,5cm), lightweight, powerful and low-consumption (less than 10W) projector is needed.
ARCLED1107AW features 7 LEDs, 1W each, 3 cool white, 4 warm white, for a perfect reproduction of every hues
of white scale. Its performance makes this projector, the best lighting tool for projects in showroom, museums,
architectural application, churches, indoor locations, stage blinder.
Light source and optics
• 7 x 1W high-efficiency CREE LEDs: (3 cool white, 4
warm white)
5 channels: dimmer, WW, CWo, white macros, strobe
• U ser interface through dip-switches for DMX
addressing, manual control, auto-mode and program
speed adjustment
• E nergy-saving LEDs employed, with more vivid
colours and lower power consumption than
traditional lamps
• Master/Slave mode for stand-alone operations
• C olour synthesis: AW mixing for a per fect
reproduction of white scale
• Flicker free operations (400Hz)
• White temperature presets: 3200K~5600K
• Linear and “step-less” transition between DMX values
• S ilent operations, due to natural cooling of the
peculiar chassis and to absence of fans
• Installed optics: 18°
4.0m
6.0m
8.0m
10.0m
• Internal protection: IP20
201lx
0.86m
50lx
1.72m
22lx
2.58m
13lx
3.44m
2 channels: WW, CW
• Power unit: 100-240V 50/60Hz
8lx
4.30m
2 channels: dimmer, white macros
• Max output consumption: 10W
3 channels: dimmer, WW, CW
• Weight: 0,8 kg
Lux Center
Beam Angle: 24°
Beam Width
Scan with your PHONE
to view product page.
78
• Sturdy die-cast aluminium body conceived for longtime durability and demanding applications
• LEDs average life span: > 50.000 hours
0m
2.0m
Structure and power supply
• Field angle: 37,5°
Electronics and features
• Power (shuko) and data (xlr-3p) cables included
• Several DMX selectable configurations (2, 3 and 5
channels) for advanced or basic controlling
• Double hanging bracket suitable for safe hanging
and for floor positioning
Accessories
ARC1107L35 (optional): 35° optics for ARCLED1107/
ARCSPIKE7
C260 (optional): Single aluminum ‘’quick-lock’’ truss
clamp suitable for 48-52 mm tube
C60 (optional): Steel security cable for hanging bodies
- inox steel shackle - 60cm L.
• Dimensions (WxHxD): 110x65x175mm
0,8 kg
65
Illuminance at a Distance
24°
• Beam angle: 20°
110
175
ARCLED1107UV
LED
7X1W
beam
UV
20°
Arcled Series - led projectors
IP33
ARCLED1107UV is an innovative LED luminaire, designed to express a new concept of lighting in indoor location
where a compact (only 17x6,5cm), lightweight, powerful and low-consumption (less than 10W) projector is
needed. ARCLED1107UV features 7 LEDs, 1W each, with innovative UV technology for reproduction of wood
lamp effect through LED source, exalting white colour in penumbra environments . Its performance makes this
projector, the best lighting tool for entertainment in discos, clubs, dance-floors.
Light source and optics
• Linear and “step-less” transition between DMX values
• E nergy-saving LEDs employed, with more vivid
colours and lower power consumption than
traditional lamps
• Flicker free operations (400Hz)
• C olour synthesis: UV to exalt white colours in
penumbra environments
• Installed optics: 18°
0m
2.0m
4.0m
6.0m
8.0m
10.0m
2.86lx
0.69m
0.71lx
1.38m
0.32lx
2.08m
0.18lx
2.77m
0.11lx
Lux Center
3.46m
Beam Angle: 20°
Beam Width
Scan with your PHONE
to view product page.
• S ilent operations, due to natural cooling of the
peculiar chassis and to absence of fans
Structure and power supply
• Beam angle: 20°
• Sturdy die-cast aluminium body conceived for longtime durability and demanding applications
• Field angle: 37,5°
• Internal protection: IP20
• LEDs average life span: > 50.000 hours
• Power (shuko) and data (xlr-3p) cables included
Electronics and features
• Double hanging bracket suitable for safe hanging
and for floor positioning
• Several DMX selectable configurations (1, 2 channels)
for advanced or basic controlling
• Power unit: 100-240V 50/60Hz
• Max output consumption: 10W
1 channel: master dimmer
• Weight: 0,8 kg
2 channels: dimmer, strobe
• Dimensions (WxHxD): 110x65x175 mm
• U ser interface through dip-switches for DMX
addressing, manual control, auto-mode and program
speed adjustment
Accessories
ARC1107L35 (optional): 35° optics for ARCLED1107/
ARCSPIKE7
C260 (optional): Single aluminum ‘’quick-lock’’ truss
clamp suitable for 48-52 mm tube
C60 (optional): Steel security cable for hanging bodies
- inox steel shackle - 60cm L.
0,8 kg
65
Illuminance at a Distance
20°
• Master/Slave mode for stand-alone operations
• 7 x 1W high-efficiency CREE LEDs: UV technology
110
175
technical data
Color calibration
LED Source
Beam angle
Zoom
White presets
Avg LEDs life (h)
Atmosfera 1803
Atmosfera 903
RGBWA
44x3W Red
44x3W Green
44x3W Blue
24x3W White
24x3W Amber
30°
RGBWA
22x3W Red
22x3W Green
22x3W Blue
12x3W White
12x3W Amber
30°
3200 - 10000K
>50.000
3200 - 10000K
>50.000
ArcLed 7361 Zoom ArcLed 7337 Zoom ArcLed 7337VW
RGBW
VARIABLE WHITE
RGBW Full Color
RGB Full Color
RGB Full Color
17x3W Red
17x3W Green
17x3W Blue
10x3W White
10x3W Red
10x3W Green
10x3W Blue
7x3W White
30x3W Warm
White
7x3W Cold White
7x10W Led
RGBW/FC
14x3W
RGB/FC
7x3W
RGB/FC
8°- 40° Zoom
Electronic
3200 - 10000K
>50.000
8°- 40° Zoom
Electronic
3200 - 10000K
>50.000
8°- 40° Zoom
Electronic
3200 - 5600
>50.000
11°
17°
16°
3200 - 10000K
>50.000
3200 - 10000K
>50.000
3200 - 8500K
>50.000
3ch: RGB
3ch: HSV
3ch: RGB
3ch: RGB
4ch: RGB, dimmer
3ch: HSV
3ch: HSV
5ch: RGBWA
4ch:
RGB,
dimmer
4ch:
RGB, dimmer
6ch: dimmer, RGBWA
5ch: RGBWA
4ch: RGBW
DMX modes
7ch: dimmer,
6ch: dimmer, RGBWA 5ch: RGBW, dimmer
RGBWA, strobe
7 ch: dimmer,
6ch: RGBW, dimmer,
10ch: Block1
RGBWA, strobe
strobe
(RGBWA),
11ch: Full channels
12ch: Full channels
block2(RGBWA)
17ch: Full channels
Macro
Master/Slave
User Interface
Ingress
protection
Power supply
Consumption
Barndoor (opt.)
Chassis color
Weight (kgs)
Dimensions (mm)
•
•
LED display
•
•
LED display
ArcLed 8107Q ArcLed 7314 TRI ArcLed 1307 TRI
RGBW
•
•
LED display
3ch: RGB
3ch: HSV
4ch: RGB, dimmer
4ch: RGBW
5ch: RGBW, dimmer
6ch: RGBW, dimmer,
strobe
12ch: Full channels
•
•
LED display
IP66
IP66
IP67/IP54
IP67/IP54
100-240V 50/60Hz
680W
100-240V 50/60Hz
300W
Black
40,3
808x516x252
Black
24
784x252x310
100-240V 50/60Hz
180W
•
Black
9
302x237x311
100-240V 50/60Hz
100W
•
Black
6,5
203x248x311
3ch: RGB
1ch: Master
3ch: HSV
3ch: RGB
dimmer
4ch:
RGB, dimmer
3ch: HSV
3ch: Dimmer,
4ch:
RGBW
4ch:
RGB, dimmer
3ch: RGB
Warm+Cold White,
5ch: RGBW,
5ch: RGB, dimmer, 4ch: RGB, dimmer
Zoom
dimmer
strobe
9ch: Full channels
4ch: Dimmer,
6ch: RGBW,
10ch: Full
WarmWhite,
dimmer,
strobe
channels
ColdWhite, Zoom 9ch: Full channels
•
•
LED display
•
•
LED display
•
•
LED display
•
•
LCD display
IP67/IP54
IP67/IP54
IP67/IP54
IP33
100-240V 50/60Hz 100-240V 50/60Hz 100-240V 50/60Hz 100-240V 50/60Hz
100W
68W
52W
35W
•
•
•
•
Black
Black
Black
Black
6,5
5,4
4,8
2,5
203x248x311
203x248x311
245x205x245
193x157x243
technical data
ArcLed 4312WX ArcLed 338 PIX
Color calibration
LED Source
Beam angle
Zoom
White presets
Avg LEDs life (h)
RGB Full Colour
RGB Full Colour
12x3W
RGB/FC Leds
8x3W
RGB/FC Leds
17°
17°
3200 - 10000K
>50.000
3200 -10000K
>50.000
3ch: RGB
3ch: HSV
4ch: RGB, dimmer
5ch:
dimmer,
RGB,
DMX modes
strobe
6ch: Block1 (RGB),
Block2 (RGB)
12ch: Full channels
ArcLed 3172 RGBWA ArcLed 3144 RGBWA ArcLed 1101Q ArcLed 1107 RGBW ArcLed 1107 AW ArcLed 1107 UV
RGBWA
RGBWA
18x1W Red
18x1W Green
18x1W Blue
9x1W White
9x1W Amber
30°
36x1W Red
36x1W Green
36x1W Blue
18x1W White
18x1W Amber
Dual optics 15° - 30°
RGBW/Full Colour
RGBW
Warm White + Cool
White
UV
1x10W
RGBW/FC
2x1W Red
2x1W Green
2x1W Blue
1x1W White
3 x1W cool white
4 x1W warm white
7x1W UV LEDs
11°
20°
20°
20°
3200 - 8500K
>50.000
3200 - 5600K
>50.000
>50.000
3ch: RGB
4ch: RGBW
9ch: Full channels
2ch: WW, CW
2ch: dimmer, white
macros
3ch: dimmer, WW,
CW
5ch: dimmer, WW,
CW, macro, strobe
1ch: master
dimmer
2ch: dimmer,
strobe
•
•
dip-switches
•
•
dip-switches
•
•
dip-switches
IP20
IP20
3200 - 10000K
3200 - 10000K
3200 - 10000K
>50.000
>50.000
>50.000
3ch: RGB
3ch: RGB
3ch: HSV
3ch: HSV
3ch: RGB
3ch: RGB
4ch: RGB, dimmer
4ch: RGB, dimmer
3ch: HSV
3ch: HSV
5ch:
RGBWA
5ch:
RGBWA
4ch:
RGB,dimmer
4ch: RGB, dimmer
6ch:
RGBWA
dimmer
6ch:
RGBWA,
dimmer
4ch:
RGBW
10ch: Full
7ch: RGBWA dimmer,
7ch: RGBWA, dimmer, 5ch: RGBW,dimmer
channels
strobe
strobe
6ch: RGBW,dimmer
24ch: RGB
9ch: RGB Blocks (1-3)
9ch: RGB
strobo
(each pixel)
13ch: Full channels
12ch: Full channels
9ch: Full channels
15ch: RGBWA Blocks (1-3)
15ch: RGBWA
•
•
•
•
•
•
•
•
LCD display
LCD display
LCD display
LED display
Macro
•
Master/Slave
•
User Interface
LED display
Ingress
IP44
IP33
protection
Power supply 100-240V 50/60Hz 100-240V 50/60Hz
Consumption 12/18h autonomy
40W
Barndoor (opt.)
Chassis color
Mirror/Black
Black
Weight (kgs)
13,5
3
Dimensions (mm)
199x199x342
575x89x160
IP33
IP33
IP20
IP20
100-240V 50/60Hz
87W
100-240V 50/60Hz
170W
•
Black
8,2
997x133x212
100-240V 50/60Hz
12W
100-240V 50/60Hz
10W
Black
1
212x124x80
Black
0,8
110x65x175
Black
4,4
989x74x156
100-240V 50/60Hz 100-240V 50/60Hz
10W
10W
•
•
Black
Black
0,8
0,8
110x65x175
110x65x175
LedMatrix series
LedMatrix is the new project developed by Prolights for multimedia entertainment, applying latest developments of LED technology in professional video.
LedMatrix series of ledwalls is composed of 5 models with pitch ranging from 6mm to 37.5mm and designed with innovative SMD FullColor LED technology, suitable for
projection of videos, images and backgrounds in large events and TV studios in both indoor or outdoor environments.
Modular design even for outdoor applications
LedMatrix screens are composed of square or rectangular modules, designed to
have compact size for comfortable transportation and maximum efficiency during
mounting operations. Each panel has its own electronics for power and control,
connection between modules is established through a daisy chain.
Modules can be combined in screens having any shape or dimension, controllable
thorugh a computer interface for initial configuration and control over the whole
matrix. Ledmatrix screens have been designed for both indoor and outdoor
applications: some models have IP65 protection on front panel and IP54 on the rear.
Modules are assembled to have a natural heat dissipation, avoiding fans or other
system of dissipation through forced air.
A project born for rental
Prolights ledwalls have been conceived and designed for professional emplyoment
in large touring events or TV studios. Structure of single modules is assembled in
aluminium and steel to offer operators the best compromise between weight and
sturdiness. Weight is not a limit any more; latest SMD and SMPS technologies allow
modules to be exceptionally lightweight and leave highest flexibility to designers
when hanging peculiar shapes or complex configurations, while requiring minimal
efforts of mounting labour.
Hardware parts for connection of panels have been improved to allow instant and
safe mounting, with no need of third-party tools or other hardware.
Modularity logic inspiring Ledmatrix systems also allows fast and convenient
maintenance operations on single panels, not requiring the disassembly of the matrix.
Benefits of transparency
Demand for transparent ledwalls in large events is getting higher since it allows showdesigners to combine video projection and lighting sequences in creating sceneries
of great visual impact.
The range of Ledmatrix products includes modules structured with vertical LED bars
allowing the light to flow through the screen surface, opening unlimited creative
possibilities to designers, while not compromising the overall image quality.
In this way lighting designers are able to create striking scenical effects with
backlights generated with washlights and beam effects or 3D projections overlapping
screens with different resolutions over different layers.
Vivid and natural colors through SMD technology
LED sources employed in LedMatrix modules are of SMD (Surface Mounted Diodes)
Full Color type, most advanced technology in terms of luminous efficiency, color
mixing and LED lifetime.
SMD technology allows Ledmatrix screens to offer an excellent visibility in any
lighting environment and even under daylight.
Any single pixel is generated by a Full-Color diode, ensuring an unlimited
generation of colors and a perfect display of the images over long distances and
wide angles (140° horizontal and 140° vertical).
LED screens, a multipurpose investment with high ROI
Prolights LedMatrix screens are an excellent solution for a wide number of
applications like in live events and TV studios, for entertainment setups of any
size to corporate and advertising events. This is mainly due to their technical
specifications, ease of installation and use, variety of the assortment with models
having different pitch and resolution rates.
Affordable price of screen controllers suggests having more than one processing
unit to employ LedMatrix modules in different projections at the same time.
LED light source combined to careful selection of construction materials and to
minimal running costs make our LedMatrix a technologically advanced set of
systems, a long-lasting investment with fast ROI (Return On Investment).
Contents - Led wall
LedMatrix Series
LedMatrix 10
LedMatrix 6
LedMatrix 12
LedMatrix 18
LedMatrix 25
LedMatrix 37
86
88
90
92
94
96
LEDMATRIX10
10mm
pitch
IP65
10000 LED/m2
5000 NIT
wide view
density
LEDMATRIX10 is a LED module to create high-definition led screens with 6mm pixel pitch, ideal for video
screening, pictures and backgrounds for short viewing distances from led wall surface.
The architecture of LEDMATRIX10 is conceived with 400x400mm module size, featuring 1600 SMD
FullColor LEDs for an impressive light output (up to 5000NIT) even for daylight application.
The instantaneous colour calibration system, through the control unit, features rich and vibrant video
images with superb colour depth and uniformity, providing vivid and natural true colours.
IP65 protection rate on front side makes LEDMATRIX10 suitable for both indoor and outdoor projects.
The architecture of LEDMATRIX0 modules has been designed to optimize the assembling times, the
carrying volume and the total weight by observing the needs of professional rental users. The main structure is designed in aluminium, making LEDMATRIX10 extremely lightweight (only 6,40
kg/module), allowing a wide flexibility in configuration, also in hanging applications, with no limits
of weight.
Applications
• In environments where the video-projection is not allowed by the high luminosity or short depth of
the room
• In TV Studios for multiple viewing angle
• Touring and Live event for Camera streaming
• Large trade show booths with creative video imaging
• In theme parks or public events
Scan with your PHONE
to view product page.
86
Led Matrix - Ledwall
Mechanical architecture
• Module dimensions (WxHxD): 400x400x60
mm
• Module weight: 6.400 g
• Weight per square meter: 40,00 kg
• Main structure in steel
• Mechanical finishing: black
• Cooling: natural airflow
• Working position: every orientation
• Vertical hanging system: Iron Fly-bar with
aliscaf clamps
Electrical features
• Power supply: AC 110/230V 50/60Hz
• Power IN connections: Neutrik Powercon
• Max power consumption (module): 100W
• Average power consumption (module): 80W
• Max power consumption (per square meter):
625W
• Power output: Max 12 moduli
• MTBF: > 1.000 h
• Working temperature: -10° / 50°
• Max ambiance humidity: 10% - 90%
1 mq: 40.00 kg
400
6.4 kg
400
64
• Colours: >68,7 billions through RGB mixing
• Gray scale: 12bit
• Refresh rate: >300 Hz
• Colour calibration through PC software
• M aximum video IN signal resolution:
1024x768 pixel
• Viewing angle: 140° horizontal, 140° vertical
• Dead pixel ratio: <0,002
Control system
• Dedicated interface (Sender box) for video
signal distribution and screen configuration
• Data IN sender box: USB connector
• Data IN module: RJ45 connectors
• Connection between screen and sender box:
USB cable
• Connection between sender box and video
wall: CAT5 data cable + Ethercon Neutrik
connectors
Video features
• LED source: high-power SMD FullColor
• Module resolution: 40x40 pixel, 1600 total
pixel
• Pixel pitch: 10 mm
• LED density: 10’000 LED/sqm
• Luminous flux: 5.000 Cd/sqm (NIT)
• LED life span: >50.000 h
87
LEDMATRIX6
6mm
indoor
pixel pitch
use
27778 LED/m2
2500 NIT
wide view
density
LEDMATRIX6 is a LED module to create high-definition led-screens with 6mm pixel pitch, ideal for video
screening, pictures and backgrounds for short viewing distances from led-wall surface.
The architecture of LEDMATRIX6 is conceived with 400x400mm module size, featuring 4096 SMD Full
Color LEDs for an impressive light output (up to 2800NIT).
The instantaneous colour calibration system, through the control unit, features rich and vibrant video
images with superb colour depth and uniformity, providing vivid and natural true colours.
The high LED density grants to create high definition screens by assembling small size matrix, making
LEDMATRIX6 the most suitable choice for installation in TV studios, theatre and conference halls
replacing the traditional video projectors.
The architecture of LEDMATRIX6 modules has been designed to optimize the assembling times, the
carrying volume and the total weight by observing the needs of professional rental users. The main structure is designed in ABS and aluminium mechanics, making LEDMATRIX6 extremely
lightweight (only 6,4 kg), allowing a wide flexibility in configuration, also in hanging applications,
with no limits of weight.
Applications
• In environments where the video-projection is not allowed by the high luminosity or short depth of
the room
• In TV Studios for multiple viewing angle
• Touring and Live event for Camera streaming
• Large trade-show booths with creative video imaging
• In theme parks or public events
Scan with your PHONE
to view product page.
88
Led Matrix - Ledwall
Mechanical architecture
• Module dimensions (WxHxD): 400x400x64
mm
• Module weight: 6.400 g
• Weight per square meter: 40,00 kg
• Main structure in steel
• Mechanical finishing: black
• Cooling: natural airflow
• Working position: every orientation
• Vertical hanging system: Iron Fly-bar with
aliscaf clamps
Electrical features
• Power supply: AC 110/230V 50/60Hz
• Power IN connections: Neutrik Powercon
• Max power consumption (module): 100W
• Average power consumption (module): 80W
• Max power consumption (per square meter):
625W
• Power output: Max 12 moduli
• MTBF: > 1.000 h
• Working temperature: -10° / 50°
• Max ambiance humidity: 10% - 90%
1 mq: 40.00 kg
400
6.4 kg
400
64
• Colours: >68,7 billions through RGB mixing
• Gray scale: 12bit
• Refresh rate: >300Hz
• Colour calibration through PC software
• M aximum video IN signal resolution:
1024x768 pixel
• Viewing angle: 140° horizontal, 140° vertical
• Dead pixel ratio: <0,002
Control system
• Dedicated interface (Sender box) for video
signal distribution and screen configuration
• Data IN sender box: USB connector
• Data IN module: RJ45 connectors
• Connection between screen and sender box:
USB cable
• Connection between sender box and videowall: CAT5 data cable + Ethercon Neutrik
connectors
• Video INPUT: DVI
• S oftware for screen setup and video
processing (included)
Video features
• LED source: high-power SMD FullColor
• Module resolution: 64x64 pixel, 4096 total
pixel
• Pixel pitch: 6mm
• LED density: 25.600 LED/sqm
• Luminous flux: 2.800 Cd/sqm (NIT)
• LED life span: >50.000h
89
LEDMATRIX12
12mm
14%
pixel pitch
transparency
IP65
3500 NIT
wide view
LEDMATRIX12 is a LED module to create ledscreens with 12,00 mm pixel pitch, ideal for video screening,
pictures and backgrounds for medium viewing distances from ledwall surface.
The architecture of LEDMATRIX12 is conceived with 600x600 mm module size, featuring 2304 SMD
FullColor LEDs for an impressive light output (up to 3500NIT).
The instantaneous colour calibration system, through the control unit, features rich and vibrant video
images with superb colour depth and uniformity, providing vivid and natural true colours.
IP65 protection rate on front side makes LEDMATRIX12 suitable also for temporary outdoor application
With a transparency factor of 14%, LEDMATRIX12 allows the light to go through the screen surface,
opening up a wide range of creative design possibilities, combining video screening with backlights
through washlight and beam projectors, even for 3D projections.
The main structure is designed in aluminium, making LEDMATRIX12 extremely lightweight (only 25,00
kg/m2), allowing a wide flexibility in configuration, also in hanging applications, with no limits of
weight.
Applications
• In arenas or sport stadiums with large audiences
• In concerts and live events, where heavy large-size screen would overload the supporting structure
• Wide-canvas dynamic backdrops for theatres and TV studios combined with lighting effects
• Large trade-show booths with creative video imaging
• In theme parks or public events
Scan with your PHONE
to view product page.
90
Mechanical architecture
• Module dimensions (WxHxD): 600x600x60
mm
• Module weight: 9.000 g
• Weight per square meter: 25,00 kg
• LED housing bar in aluminium
• Transparency rate: 14%
• Main structure in steel
• Mechanical finishing: black
• Cooling: natural airflow
• Working position: every orientation
• Vertical hanging system: built-in aliscaf clamp
support
9 kg
Electrical features
• Power supply: AC 110/230V 50/60Hz
• Power IN connections: Neutrik Powercon
• Max power consumption (module): 200W
• Average power consumption (module): 160W
• Max power consumption (per square meter):
555W
• Power output: Max 10 moduli
• MTBF: > 1.000 h
• Working temperature: -10° / 50°
• Max ambience humidity: 10% - 90%
1 mq: 25.00 kg
• Luminous flux: 3.500 cd/sqm (NIT)
• LED life span: >50.000h
• Colours: >68,7 billions through RGB mixing
• Grayscale: 12bit
• Refresh rate: >300Hz
• Colour calibration through PC software
• M aximum video IN signal resolution:
1024x768 pixel
• Viewing angle: 140° horizontal, 140° vertical
• Dead pixel ratio: <0,002
Control system
• Dedicated interface (Sender box) for video
signal distribution and screen configuration
• Data IN sender box: USB connector
• Data IN module: RJ45 connectors
• Connection between screen and sender box:
USB cable
• C onnection between sender box and
videowall: CAT5 data cable + Ethercon Neutrik
connectors
600
Test
600
60
Video features
• LED source: high-power SMD FullColor
• Module resolution: 48x48 pixel, 2304 total
pixel
• Pixel pitch: 12,00mm
• LED density: 6.400 LED/sqm
91
LEDMATRIX18
18mm
40%
pixel pitch
transparency
IP65
3000 NIT
wide view
LEDMATRIX18 is a LED module to create ledscreens with 18,75 mm pixel pitch, ideal for video screening,
pictures and backgrounds for medium viewing distances from ledwall surface.
The architecture of LEDMATRIX18 is conceived with 600x600 mm module size, featuring 1024 SMD
FullColor LEDs for an impressive light output (up to 3000NIT).
The instantaneous colour calibration system, through the control unit, features rich and vibrant video
images with superb colour depth and uniformity, providing vivid and natural true colours.
IP65 protection rate on front side, makes LEDMATRIX18 suitable for both indoor and outdoor projects.
With a transparency factor of 40%, LEDMATRIX18 allows the light to go through the screen surface,
opening up a wide range of creative design possibilities, combining video screening with backlights
through washlight and beam projectors, even for 3D projections.
The main structure is designed in aluminium, making LEDMATRIX18 extremely lightweight (only 18,05
kg/m2), allowing a wide flexibility in configuration, also in hanging applications, with no limits of
weight.
Applications
• In arenas or sport stadiums with large audiences
• In concerts and live events, where heavy large-size screen would overload the supporting structure
• Wide-canvas dynamic backdrops for theatres and TV studios combined with lighting effects
• Large trade-show booths with creative video imaging
• In theme parks or public events
Scan with your PHONE
to view product page.
92
Led Matrix - Ledwall
Mechanical architecture
• Module dimensions (WxHxD): 600x600x60
mm
• Module weight: 6.500 g
• Weight per square meter: 18,05 kg
• LED housing bar in aluminium
• Transparency rate: 40%
• Main structure in steel
• Mechanical finishing: black
• Cooling: natural airflow
• Working position: every orientation
• Vertical hanging system: built-in aliscaf clamp
support
1 mq: 18.05 kg
600
6.5 kg
Electrical features
• Power supply: AC 110/230V 50/60Hz
• Power IN connections: Neutrik Powercon
• Max power consumption (module): 200W
• Average power consumption (module): 100W
• Max power consumption (per square meter):
555W
• Power output: Max 10 moduli
• MTBF: > 1.000 h
• Working temperature: -10° / 50°
• Max ambience humidity: 10% - 90%
600
60
• Luminous flux: 3.000 cd/sqm (NIT)
• LED life span: >50.000h
• Colours: >68,7 billions through RGB mixing
• Grayscale: 12bit
• Refresh rate: >400Hz
• Colour calibration through PC software
• M aximum video IN signal resolution:
1024x768 pixel
• Viewing angle: 140° horizontal, 140° vertical
• Dead pixel ratio: <0,002
Control system
• Dedicated interface (Sender box) for video
signal distribution and screen configuration
• Data IN sender box: USB connector
• Data IN module: RJ45 connectors
• Connection between screen and sender box:
USB cable
• Connection between sender box and video
wall: CAT5 data cable + Ethercon Neutrik
connectors
Video features
• LED source: high-power SMD FullColor
• Module resolution: 32x32 pixel, 1024 total
pixel
• Pixel pitch: 18,75mm
• LED density: 2.844 LED/sqm
93
LEDMATRIX25
25mm
50%
pixel pitch
transparency
IP65
3040 NIT
wide view
LEDMATRIX25 is a LED module to create led screens with 25 mm pixel pitch, ideal for video screening,
pictures and backgrounds for medium/long viewing distances from ledwall surface.
The architecture of LEDMATRIX25 is conceived with 1600x80 0mm module size, featuring 2048 SMD
FullColor LEDs for an impressive light output (up to 2000NIT).
The instantaneous colour calibration system, through the control unit, features rich and vibrant video
images with superb colour depth and uniformity, providing vivid and natural true colours.
IP65 protection rate on front side, makes LEDMATRIX25 suitable for both indoor and outdoor projects.
With a transparency factor of 50%, LEDMATRIX25 allows the light to go through the screen surface,
opening up a wide range of creative design possibilities, combining video screening with backlights
through washlight and beam projectors, even for 3D projections.
The main structure is designed in aluminium, making LEDMATRIX25 extremely lightweight (only 16,6
kg/m2), allowing a wide flexibility in configuration, also in hanging applications, with no limits of
weight.
Applications
• In arenas or sport stadium with large audiences
• In concerts and live events, where heavy large-size screen would overload the supporting structure
• Large and long-viewing advertising banners
• Wide-canvas dynamic backdrops for theatres and TV studios combined with lighting effects
• Large tradeshow booths with creative video imaging
Scan with your PHONE
to view product page.
94
Led Matrix - Ledwall
Mechanical architecture
• Module dimensions (WxHxD): 1600x800x140
mm
• Module weight: 21.500 g
• Weight per square meter: 16,6 kg
• LED housing bar in aluminium
• Transparency rate: 50%
• Main structure in steel
• Mechanical finishing: black
• Cooling: natural airflow
• Working position: every orientation
• Vertical hanging system: built-in aliscaf clamp
support
1 mq: 16.06 kg
800
21.5 kg
Electrical features
• Power supply: AC 110/230V 50/60Hz
• Power IN connections: Neutrik Powercon
• Max power consumption (module): 700W
• Average power consumption (module): 500W
• Max power consumption (per square meter):
546W
• Power output: Max 4 moduli
• MTBF: > 1.000 h
• Working temperature: -10° / 50°
• Max ambience humidity: 10% - 90%
1600
140
• Luminous flux: 3.040 cd/sqm (NIT)
• LED life span: >50.000 h
• Colours: >68,7 billions through RGB mixing
• Grayscale: 12bit
• Refresh rate: >400Hz
• Colour calibration through PC software
• M aximum video IN signal resolution:
1024x768 pixel
• Viewing angle: 140° horizontal, 140° vertical
• Dead pixel ratio: <0,002
Control system
• Dedicated interface (Sender box) for video
signal distribution and screen configuration
• Data IN sender box: USB connector
• Data IN module: RJ45 connectors
• Connection between screen and sender box:
USB cable
• C onnection between sender box and
videowall: CAT5 data cable + Ethercon Neutrik
connectors
Video features
• LED source: high-power SMD FullColor
• Module resolution: 64x32 pixel, 2048 total
pixel
• Pixel pitch: 25 mm
• LED density: 1.600 LED/sqm
95
LEDMATRIX37
37mm
60%
pixel pitch
transparency
IP65
1350 NIT
wide view
LEDMATRIX37 is a LED module to create ledscreens with 37,5 mm pixel pitch, ideal for video screening,
pictures and backgrounds for long viewing distances from ledwall surface.
The architecture of LEDMATRIX37 is conceived with 600x600mm module size, performing 256 SMD
FullColor LEDs for an impressive light output (up to 1350NIT).
The instantaneous colour calibration system, through the control unit, features rich and vibrant video
images with superb colour depth and uniformity, providing vivid and natural true colours.
IP65 protection rate on front side, makes LEDMATRIX37 suitable for both indoor and outdoor projects.
With a transparency factor of 60%, LEDMATRIX37 allows the light to go through the screen surface,
opening up a wide range of creative design possibilities, combining video screening with backlights
through washlight and beam projectors, even for 3D projections.
The main structure is designed in aluminium, making LEDMATRIX37 extremely lightweight (only 15,2
kg/m2), allowing a wide flexibility in configuration, also in hanging applications, with no limits of
weight.
Applications
• In arenas or sport stadium with large audiences
• In concerts and live events, where heavy large-size screen would overload the supporting structure
• Large and long-viewing advertising banners
• Wide-canvas dynamic backdrops for theatres and TV studios combined with lighting effects
Scan with your PHONE
to view product page.
96
Led Matrix - Ledwall
Mechanical architecture
• Module size (WxHxD): 600x600x60 mm
• Module weight: 5.500 g
• Weight per square meter: 15,2 kg
• LED housing bar in aluminium
• Transparency rate: 60%
• Main structure in steel
• Mechanical finishing: black
• Cooling: natural airflow
• Working position: every orientation
• Vertical hanging system: built-in aliscaf clamp
support
1 mq: 15.02 kg
600
5.5 kg
Electrical features
• Power supply: AC 110/230V 50/60Hz
• Power IN connections: Neutrik Powercon
• Max power consumption (module): 95W
• Average power consumption (module): 70W
• Max power consumption (per square meter):
263W
• Power output: 15 modules max
• MTBF: > 1.000 h
• Working temperature: -10° / 50°
• Max ambience humidity: 10% - 90%
600
60
• Colours: >68,7 billions through RGB mixing
• Grayscale: 12bit
• Refresh rate: >400Hz
• Colour calibration through PC software
• M aximum video IN signal resolution:
1024x768 pixel
• Viewing angle: 140° horizontal, 140° vertical
• Dead pixel ratio: <0,002
Control system
• Dedicated interface (Sender box) for video
signal distribution and screen configuration
• Data IN sender box: USB connector
• Data IN module: RJ45 connectors
• Connection between screen and sender box:
USB cable
• C onnection between sender box and
videowall: CAT5 data cable + Ethercon Neutrik
connectors
Video features:
• LED source: high-power SMD FullColor
• Module resolution: 16x16 pixel, total 256 pixel
• Pixel pitch: 37,5 mm
• LED density: 711 LED/sqm
• Luminous flux: 1.350 cd/sqm (NIT)
• LED life span: >50.000 h
97
technical data
CODE
Pixel pitch (mm)
Brightness (Nit or cd/m2)
LED type
LED/pixel
Module size (mm)
Module Area
Pixel/module
Pixel density/m2
Trasparency
Viewing horizontal
Viewing vertical
Weight/m2
IP Front
IP Rear
Humidity prof
Colours
Processing
Input frequency
Refresh rate
Data interconnect
Processor
Max power m2
Working temperature
Working humidity
LEDMATRIX 10
LEDMATRIX 6
LEDMATRIX 12
LEDMATRIX 18
LEDMATRIX 25
10
6
12
18.75
25
LEDMATRIX 37
37.5
5000
2500
3500
3000
3040
1350
SMD FullColor
1
400x400x64
0.16m2
40x40
10000
SMD FullColor
1
400x400x64
0.16m2
64x64
27778
>140°
>140°
40 kg
IP65
IP54
Yes
68,7 billion
1280x1024/1024x768
60 Hz
>400 Hz
CAT5 + Ethercon RJ45
LMDVIPROC
>140°
>140°
40 kg
Indoor
Indoor
Yes
68,7 billion
1280x1024/1024x768
60 Hz
>400 Hz
CAT5 + Ethercon RJ45
LMDVIPROC
SMD FullColor
1
600x600x60
0.36m2
48x48
6400
14.00%
>140°
>140°
25,00 kg
IP65
IP54
Yes
68,7 billion
1280x1024/1024x768
60 Hz
>400 Hz
CAT5 + Ethercon RJ45
LMDVIPROC
SMD FullColor
1
600x600x60
0.36m2
32x32
2844
40.00%
>140°
>140°
18,05 kg
IP65
IP54
Yes
68,7 billion
1280x1024/1024x768
60 Hz
>400 Hz
CAT5 + Ethercon RJ45
LMDVIPROC
SMD FullColor
1
1600x800x140
1.28m2
64x32
1600
50.00%
>140°
>140°
16,6 kg
IP65
IP54
Yes
68,7 billion
1280x1024/1024x768
60 Hz
>400 Hz
CAT5 + Ethercon RJ45
LMDVIPROC
SMD FullColor
1
600x600x60
0.36m2
16x16
711
60.00%
>140°
>140°
15,2 kg
IP65
IP54
Yes
68,7 billion
1280x1024/1024x768
60 Hz
>400 Hz
CAT5 + Ethercon RJ45
LMDVIPROC
625W
625W
555W
555W
546W
263W
-10°/50°
10%-90%
-10°/50°
10%-90%
-10°/50°
10%-90%
-10°/50°
10%-90%
-10°/50°
10%-90%
-10°/50°
10%-90%
Contents - Ambient effects
Vortex Series
HZ 660D
FZ 2000D
FZ 600D
HZ 1700D
FX 3000D
VX 1500D
VXCLOUD
102
103
104
105
106
107
108
HZ660D
hazer
liquid
OIL BASED
tank
FAN CONTROL
DMX 2 CH
3,2 lt
DISPLAY
HZ660D is the latest technological innovation in the Haze machines range. Its performance makes this
professional tool suitable for all kind of application and lighting project, bringing the best atmospheric
effect to all events.
• HZ660D is contained inside a sturdy flight-case to simplify carriage, handling and protect it from
shocks or damages
• Functioning with oil-based Haze fluids allowing very low consumption of liquid (5.88 ml/min)
• Haze output: 3’500 cu.ft/min
• Silent operation allows also indoor or theatre applications
• Plug and play technology for an instant functioning without pre-heating waiting time
• Dry haze: HZ660D produces very dry haze which generates no redundant moisture
• HZ660D makes incredibly tiny particulates. Thus, the haze can be distributed through air further and
faster. In addition, it means a greater hanging time
• Full control of direction and fog jet through the controllable fans
• Metal net and filter in the liquid duct against clogging failures
• On-board user interface with LCD display for settings and selection of operating modes
• Manual and Auto mode functioning with direction, volume and interval regulation
• 2 Channels DMX mode with volume and fan speed control
• Anti-closure security system, the fixtures stops working if the output door gets obstructed
• Oil tank capacity: 3,2lt
• Power supply: AC 220-240V 50/60 Hz
• DMX connection: XLR-3p IN, XLR-3p OUT
• Power consumption: 500W
• Dimensions (WxHxD): 380x340x500mm
• Weight: 33,2kg
Scan with your PHONE
to view product page.
102
Accessories
SMOKEOILHZ (optional): High density Oil-fluid for Haze machines, 1L tank
FZ2000D
fazer
liquid
WATER BASED
tank
DMX 2 CH
3 lt
DISPLAY
Ambient effects
FZ2000D is an high-performance Fazer machine featuring a continuous production of haze effect. The
air-pump system mixes fog and air to produce a fine, dry for with minimal fluid consumption (1L/5h).
• FZ2000D is contained inside a sturdy flight-case to simplify carriage, handling and protect it from
shocks or damages
• Stackable cases for overlapped effects
• Functioning with water-based Haze fluids allowing very low consumption of liquid (1 L/5h)
• Haze output: 3’500 cu.ft/min
• Silent operation allows also indoor or theatre applications
• Pre-heating time: 1,6 mins
• Dry haze: FZ2000D produces very dry haze which generates no redundant moisture
• FZ2000D makes incredibly tiny particulates. Thus, the haze can be distributed through air further and
faster without any loss of visibility
• Full control of direction and fog jet through the controllable fans
• Metal net and filter in the liquid duct against clogging failures
• On-board user interface with LCD display for settings and selection of operating modes
• Manual and Auto mode functioning with direction, volume and interval regulation
• 2 Channels DMX mode with volume and fan speed control
• Electronic thermic sensor against over-heating failure
• Oil tank capacity: 3 lt
• Power supply: AC 220-240V 50/60 Hz
• DMX connection: XLR-3p IN, XLR-3p OUT
• Power consumption: 1660W
• Dimensions (WxHxD): 524x176x403mm
• Weight: 20,5kg
Scan with your PHONE
to view product page.
Accessories
SMOKEFLUIDHZ (optional): Medium density fluid for haze machines, 5kg tank
103
FZ600D
fazer
liquid
WATER BASED
tank
DMX 2 CH
2.5 lt
DISPLAY
remote
FZ600D is a compact-size Fazer machine featuring high-emitting performances. The air and fog mixing
allows a continuous production of haze effect, with minimal fluid consumption.
• Functioning through traditional water-based Fazer fluids, performance comparable to hazer effects,
allowing thin, transparent, continuous fogging
• Haze output: 1200 cu.ft/min
• Silent operation allows also indoor or theatre applications
• First heat-up time: 6 min
• Dry haze: fz600D produces very dry haze which generates no redundant moisture
• FZ600D makes incredibly tiny particulates. Thus, the haze can be distributed through air further and
faster without any loss of visibility
• Full control of direction and fog jet through the controllable fans
• Wire controller for settings and selection of operating modes
• Manual and Auto mode functioning with direction, volume and interval regulation
• 2 Channels DMX mode with volume and fan speed control
• Electronic thermic sensor against over-heating failures
• Liquid tank capacity: 2,5lt
• Power supply: AC 220-240V 50/60 Hz
• DMX connection: XLR-3p IN, XLR-3p OUT
• Power consumption: 600W
• Dimensions (WxHxD): 258x267x287mm
• Weight: 8kg
Accessories
SMOKEFLUIDHZ (optional): Medium density fluid for haze machines, 5kg tank
Scan with your PHONE
to view product page.
104
HZ1700D
fazer
liquid
WATER BASED
tank
DMX 2 CH
2,5 lt
DISPLAY
Ambient effects
HZ1700D is an high-performance Fazer machine featuring a continuous production of haze effect. The
air-pump system mixes fog and air to produce a fine, dry for with minimal fluid consumption.
• Functioning through traditional water-based Fazer fluids, performance comparable to hazer effects,
allowing thin, transparent, continuous fogging
• Stackable cases for overlapped effects
• Functioning with water-based Haze fluids allowing very low consumption of liquid (15,1 mL/min)
• Haze output: 3’500 cu.ft/min
• Silent operation allows also indoor or theatre applications
• Pre-heating time: 2,5 mins
• Dry haze: HZ1700D produces very dry haze which generates no redundant moisture
• HZ1700D makes incredibly tiny particulates. Thus, the haze can be distributed through air further
and faster without any loss of visibility
• Full control of direction and fog jet through the controllable fans
• On-board user interface with LCD display for settings and selection of operating modes
• Manual and Auto mode functioning with direction, volume and interval regulation
• 2 Channels DMX mode with volume and fan speed control
• Electronic thermic sensor against over-heating failure
• Oil tank capacity: 2,5 lt
• Power supply: AC 220-240V 50/60 Hz
• DMX connection: XLR-3p IN, XLR-3p OUT
• Power consumption: 1600W
• Dimensions (WxHxD): 280x280x560mm
• Weight: 12,5kg
Accessories
SMOKEFLUIDHZ (optional): Medium density fluid for haze machines, 5kg tank
Scan with your PHONE
to view product page.
105
FX3000D
fogger
liquid
WATER BASED
tank
DMX 1CH
5 lt
DISPLAY
remote
FX3000D is a professional Fog machine, suitable for large size environments as live, arenas, outdoor
events where a powerful ambient effect with great fogging volume is required.
• Functioning based on internal heater for high pressure and voluminous fog emission
• Compatible with traditional water based fog liquid for dry and homogeneous fog
• Fog output: 30’000 cu.ft/min
• First heat-up time: 11 min
• Plug and play technology: FX3000D is ready to work when connected with no need of additional
settings or connection
• Control panel can be taken out to be used as wire-remote controller
• Wireless controller is included
• Control panel with LCD display for settings and functioning selection
• Manual and Auto mode functioning with volume and interval regulation
• 1 Channel DMX mode
• Electronic thermic sensor against over-heating failures
• Security system against clogging or pump failures
• Security system with electronic thermic sensor against over-heating failures
• Liquid tank capacity: 5 lt
• Ergonomic hanging bracket for an easy transportation
• Power supply: AC 220-240V 50/60 Hz
• DMX connection: XLR-3p IN, XLR-3p OUT
• Power consumption: 3000W
• Dimensions (WxHxD): 290x240x643mm
• Weight: 19,5kg
Scan with your PHONE
to view product page.
106
Accessories
SMOKEFLUIDHD (optional): High density Fluid for fog machines, 5Kg tank
SMOKEFLUIDSD (optional): High density Fluid for fog machines, 5Kg tank - green fluid
SMOKEFLUIDMD (optional): Medium density Fluid for fog machines, 5Kg tank
VX1500D
fogger
liquid
WATER BASED
tank
DMX 2 CH
2,5 lt
DISPLAY
Ambient effects
VX1500D is a professional Fog machine, suitable for middle size environments as discos, theatre, indoor
events where a powerful ambient effect with great fogging volume is required.
• Functioning based on internal heater for high pressure and voluminous fog emission
• Compatible with traditional water based fog liquid for dry and homogeneous fog
• Fog output: 20’000 cu.ft/min
• First heat-up time: 8 min
• Plug and play technology: VX1500D is ready to work when connected with no need of additional
settings or connection
• Control panel can be taken out to be used as wire-remote controller
• Wireless controller is included
• Dipswitches for DMX addressing and settings
• Manual and Auto mode functioning with volume and interval regulation
• 2 Channels DMX mode
• Security system against clogging or pump failures
• Electronic thermal sensor against over-heating failures
• Ergonomic hanging bracket for an easy transportation
• Liquid tank capacity: 2,5 lt
• Power supply: AC 220-240V 50/60 Hz
• DMX connection: XLR-3p IN, XLR-3p OUT
• Power consumption: 1500W
• Dimensions (WxHxD): 255x180x425mm
• Weight: 9,4kg
Scan with your PHONE
to view product page.
Accessories
SMOKEFLUIDSD (optional): High density Fluid for fog machines, 5Kg tank - green fluid
SMOKEFLUIDMD (optional): Medium density Fluid for fog machines, 5Kg tank
SMOKEFLUIDHD (optional): High density Fluid for fog machines, 5Kg tank
107
VXCLOUD
fogger
liquid
capacity
DRY-ICE
4.5 kg
VXCLOUD is a professional low-fog machine conceived on dry-ice functioning. VXCLOUD produces
thick, white fog that cover the floor without rising in the air. The Dual-heating system allows a faster
heat-up and recycle time, reducing the dry-ice consumption and improving the run time. A low water
sensor increase safety and the easy control system allows to manage volume and flow.
• Dry-ice operation, plates or pellets, to produce low fog, thin and white.
• Cover range: 200 sqm
• Heat-up time: 50 min (single heater), 30min (double heater)
• Reheat time: 30 min (single heater), 15min (double heater) • Average run time: 6min
• Dry-ice capacity: 4,5 Kgs
• Max water temperature: 79°
• Low-water and temperature sensors automatically shut off heaters for added safety
• Adjustable, multi-level control handle manipulates the output and flow
• Power supply: AC 100-240V 50/60 Hz
• Power consumption: 1500W (single heater), 3000W (double heater)
• Dimensions: (WxHxD): 600x550x555 mm
• Weight: 13,5 Kg
Scan with your PHONE
to view product page.
108
OPERA1200INSE
focus
DISCHARGE
IRIS
ELECTRONIC
strobe/shutter
colour wheels
Follow spot
OPERA1200INSE: MSI 1200 W discharge lamp (not included): compatible with 800114. Weight: 44 Kg.
OPERA575INSE: MSI 575 W discharge lamp (not included): compatible with 800102. Weight: 32,5 Kg.
Technical Specifications
• Lamp On/Off: through control panel or via DMX.
• Unit reset: restart from the control panel or by the DMX.
• Optical System: high definition anti-reflection lenses with achromatic coating, parabolic glass reflector
with spherical profile, 18° max beam angle.
• Focus: 2 m to infinity motorised focusing lens.
• Control: DMX 512 protocol through 3 poles XLR connection, 6 channels at 16 bit. Integrated controller
equipped with 9 buttons and 4 cursors for an easy access to the main functions.
• Mechanical dimmer: 0 – 100% linear dimming.
• Strobe/Shutter: strobe effect (1-10 flashes per second) and fading effects with adjustable speed.
Instant open and blackout.
• Iris: motorised iris diaphragm with a 13° max angle.
• 2 colour wheels: independent and overlapping wheels to create more colours. The former with 8
dichroic colours + open, the latter with 3 temperature colour filters (3200 K - 5600 K - 6000 K) + open.
Rainbow effect plus colour change with synchronized blackout option.
• User Interface: 4-digit multi-function LED display to control unit addressing, diagnostics, lamp life.
• Cooling: filtered forced air, protection against overheating. Fans control for quieter operation.
• Body: in die-cast aluminium and steel, black colon, 4 ergonomic handles for an easy transportation.
• Suspension and fixing: positioning through the adjustable bracket.
• Power Supply: electromagnetic ballast, 230V~ 50Hz, connection cable without plug.
• Dimensions (WxHxD): 330x225x1170 mm.
• Controller dimensions (WxHxD): 405x360x35 mm.
Scan with your PHONE
to view product page.
Accessori
LS162 (included): 2 stage Steel Stand, 50kg max load limit, max height 1.5mt
FCL313 (included): Flight-case for OPERA575/1200INSE and stand, with skate, (WxHxD) 1225x495x525mm
109
Contents - Accessories
Accessories
Lamps
Optics
Filters
Filter-frames
Barndoors
Flightcase
Rigging
Extensions
Cables
Adapters
WDMX
Accessories LedMatrix
Liquid
112
113
113
113
113
114
118
119
119
119
120
121
122
Lamps
112
MSR Gold 1200 FastFit
• Watt: 1200
• Socket: PGJX50
• Lumen (lm): 95000
• Color temperature (K): 6300
• Life (h): 750
• Comp.: Z1200SPOT, Z1200WASH
• Order code: 800186
MSR Gold 700 FastFit
• Watt: 700
• Socket: PGJX50
• Lumen (lm): 50000
• Color temperature (K): 6000
• Life (h): 750
• Comp.: Z700SPOT
• Order code: 800188
MSD Gold 300/2 MiniFastFit
• Watt: 300
• Socket: PGJX28
• Lumen (lm): 22000
• Color temperature (K): 8800
• Life (h): 2000
• Comp.: Z300BEAM
• Order code: 800182
MSR Gold 300/2 MiniFastFit
• Watt: 300
• Socket: PGJX28
• Lumen (lm): 23000
• Color temperature (K): 8000
• Life (h): 750
• Comp.: Z300BEAM
• Order code: 800184
OSRAM E20.8
• Watt: 180
• Type: overhead projector
• Socket: E20.8
• Lumen (lm): 2400
• Life (h): 6000
• Comp.: Z2500DIGITAL
• Order code: 800190
OSRAM HRI280W
• Watt: 280
• Type: overhead projector
• Socket: E20.8
• Lumen (lm): 15000
• Life (h): 2000
• Comp.: Z4000DIGITAL
• Order code: 800192
MSI HR 575/2
• Watt: 575
• Socket: SFc10-4
• Lumen (lm): 47000
• Color temperature (K): 7000
• Life (h): 1000
• Comp.: V575SPOT
• Order code: 8001134
MSR 575W/2
• Watt: 575
• Socket: GX9.5
• Lumen (lm): 49.000
• Color temperature (K): 7200
• Life (h): 1000
• Comp.: V575WASH
• Order code: 800144
MSR Platinum 5R
• Watt: 189
• Socket: Pins 2.8x0.8mm
• Lumen (lm): 15000
• Color temperature (K): 8000
• Life (h): 2000
• Comp.:
• Order code: 800198
Optics, filters, filter-frames, barndoors
15°
25°x6°
30°
55°
17° Tri-Colour
ARCATL55
-
5° filter
1° filter
ARCATL15
ARCATL256
Cromowash300
CW300FILTER5
CW300FILTER1
Arcled7314tri
-
-
-
-
Arcled7361zoom
ARC7361FILTER5
ARC7361FILTER1
Arcled1307tri
-
-
-
-
Arcled7337zoom
ARC7337FILTER5
ARC7337FILTER1
Arcled4312wx
-
-
-
-
Arcled8107q
ARC8107FILTER5
ARC8107FILTER1
Arcled338Pix
-
-
-
-
Arcled3172RGBWA
-
ARCLED3L256
Atmosfera1803
Arcled3144RGBWA
ARCLED3L256
Arcled1107
-
ARC1107L35
-
-
-
-
-
-
TPG
BARNDOOR
ROUND-BARNDOOR
TOP-HEAD
ARCLED1307TRI
-
ARC1307BD
-
-
ARCLED7314TRI
ARC7314TPG
ARC7314BD
ARC7314RBD
-
ARCLED7337ZOOM
ARC7337TPG
ARC7337BD
ARC7337RBD
-
ARCLED7361ZOOM
ARC7361TPG
ARC7361BD
ARC7361RBD
-
ARCLED8107Q
ARC8107TPG
ARC8107BD
ARC8107RBD
-
ARCLED3172RGBWA
-
ARC3172BD
-
-
ARCLED3144RGBWA
-
ARC3144BD
-
-
CROMOWASH100
-
-
-
CW100TH
ARC338RIG
113
Flightcase
FCZ1200S
Carrying Roadcase designed to contain 1pc of
Zenith 1200Spot Dim. 700x900x620 mm
FCZ300B2
Carrying Roadcase designed to contain 2pcs
of Zenith300BEAM, Dim.1125x850x510 mm
114
FCZ1200W
Carrying Roadcase designed to contain 1 pc of
Zenith 1200Wash, Dim. 705x880x620 mm
FCZ2500D
Carrying Roadcase designed to contain 1pc of Ze
nith2500DIGITAL,Dim.585x835x405mm
FCZ700S2
Carrying Roadcase designed to contain 2pcs
of Zenith700Spot,Dim. 1125x850x510 mm
FCLSLASH
Carrying Roadcase designed to contain 2
pcs of SLASH, Dim. 760x500x800mm
Flightcase
FCLTITAN
Carrying Roadcase designed to contain 2
pcs of TITAN, Dim. 107x480x800 mm
FCL100W
Carrying Roadcase designed to contain 8pcs
of Cromo Wash100, Dim.1200x585x705 mm
FCL600W
Carrying Roadcase designed to contain 2 pcs
of Cromo Wash600, 660x680x480 mm
FCL500S
Carrying Roadcase designed to contain 2 pcs
of Cromo Spot500, Dim. 925x750x485mm
FCL300W
Carrying Roadcase designed to contain 2 pcs
of Cromo Wash300, Dim.785x650x400 mm
FCL250S
Carrying Roadcase designed to contain 2 pcs
of CromoSpot250,Dim. 710x750x410 mm
115
Flightcase
116
FCL250B
Carrying Roadcase designed to contain 2 pcs
of CromoBeam250, Dim. 780x760x380 mm
FCV575S
Carrying Roadcase designed to contain 2pcs
of Vision575Spot, Dim. 865x830x520 mm
FCV575W
Carrying Roadcase designed to contain 2pcs
of Vision 575Wash,Dim. 865x830x520 mm
FCL1803
Carrying Roadcase designed to contain 1 pc of
ATMOSFERA1803, Dim. 865x610x460 mm
FCL7361
Carrying Roadcase designed to contain 8 pcs of
ARCLED7361ZOOM, Dim. 820x570x490mm
FCL7337
Carrying Roadcase designed to contain 8pcs
of ARCLED7337ZOOM, Dim. 960x525x515mm
Flightcase
FCL8107
Carrying Roadcase designed to contain 8 pcs
of ARCLED8107Q, Dim. 780x540x480mm
FCL7314
Carrying Roadcase designed to contain 8pcs
of ARCLED7314TRI,Dim. 1000x460x525 mm
FCL4312E
Roadcase for 6pcs ARCLED4312WX,
with internal battery charger,
Dim.770x565x485mm
FCL338
Carrying Roadcase designed to contain
20 pcs of ARCLED338PIX
FCL3172
Carrying Roadcase designed to contain 8pcs of
ARCLED3172RGBWA,Dim.580x1195x370mm
FCL3144
Carrying Roadcase designed to contain
8 pcs of ARCLED3144RGBWA
117
Rigging
118
OS10
Hanging support for aliscaf linking,
compat. with Cromo Spot500/Wash100.
OS12
Hanging support for aliscaf linking, compat.
with Cromo Spot150/Spot250/Beam250.
OS14
Hanging support for aliscaf linking,
compat with Cromo Wash300
OS16
Hanging support for aliscaf linking,
compat. with Vision575Spot/575Wash.
OS18
Hanging support for aliscaf linking, compat.
with Zenith 300Beam/700Spot/1200Spot
C260
Single aluminum ‘’quick-lock’’ truss
clamp suitable for 48-52 mm tube
C460
Aluminium single Truss Clamp
with a 13mm hole
C460S
Aluminium single Truss Clamp
with a 13mm hole, Slim version
C462S
Aluminium hook style single
Truss Clamp, Slim version
C60
Steel security cable for hanging bodies - inox
steel shackle - 60cm L.
C120
Steel security cable for hanging bodies
- inox steel shackle - 120cm L.
Extensions, cables, adapters.
ARCEXAC3
Extension IP67 power cable,
IPpowercon-F -> IPpowercon-M.
Compatible with: ARCLED7314,
ARCLED7337.
ARCEXDC3
Extension IP68 data cable,
IPdatacon-F -> IPdatacon-M.
Compatible with:
ARCLED7314, ARCLE7337.
ARCADAC4
Power adapt cable, compat.
with indoor (TZ) ARCLED
proj, NAC3FCA->Shuko.
ARCEXAC5
Power ext cable, comp
with indoor (TZ) ARCLED
proj, NAC3FCA->NAC3FCB.
ARCEXAC4
Power ext cable, comp with
indoor ( TZ) ARCLED proj,
NAC3FCA->NAC3FCB.
TOUR53413
Dmx cable HC5340. CANC3MXX
XLR 3p->CANC3FXX XLR (f) 3p.
(mt)
0,5
1
3
5
10
15
20
Code
ARCEXAC5L005
ARCEXAC5L01
ARCEXAC5L03
ARCEXAC5L05
ARCEXAC5L10
ARCEXAC5L15
ARCEXAC5L20
€ 12
€ 12.5
€ 14.5
€ 16.5
€ 21.5
€ 26.5
€ 32
TOUR53415
Dmx cable HC5340. CANC5MXX
XLR 5p->CANC5FXX XLR (f) 5p.
Code
TOUR53415L01
TOUR53415L03
TOUR53415L05
TOUR53415L10
TOUR53415L15
TOUR53415L20
TOUR53415L25
€ 28
€ 30.5
€ 33.5
€ 41
€ 48
€ 55.5
€ 62.5
(mt)
1
3
5
10
15
20
25
(mt)
0,5
1
3
5
10
15
20
Code
ARCEXAC4L005
ARCEXAC4L01
ARCEXAC4L03
ARCEXAC4L05
ARCEXAC4L10
ARCEXAC4L15
ARCEXAC4L20
€ 33
€ 34.5
€ 42
€ 49
€ 67
€ 85
€ 103
DYN53413
Dmx cable HC5340. CAX300MV
XLR 3p->CAX300FV XLR (f) 3p.
Code
DYN53413L01
DYN53413L03
DYN53413L05
DYN53413L10
DYN53413L15
DYN53413L20
DYN53413L25
€ 5.85
€ 8.75
€ 11.75
€ 19
€ 26
€ 33.5
€ 41
(mt)
1
3
5
10
15
20
25
Code
TOUR53413L01
TOUR53413L03
TOUR53413L05
TOUR53413L10
TOUR53413L15
TOUR53413L20
TOUR53413L25
€ 14.5
€ 17.25
€ 20
€ 27.5
€ 34.5
€ 42
€ 49.5
(m)
1
3
5
10
15
20
25
DYN53415
Dmx cable HC5340. CAX500MV
XLR 5p->CAX500FV XLR (f) 5p.
Code
DYN53415L01
DYN53415L03
DYN53415L05
DYN53415L10
DYN53415L15
DYN53415L20
DYN53415L25
€ 6.65
€ 9.55
€ 12.5
€ 20
€ 27.5
€ 34.5
€ 42
(mt)
1
3
5
10
15
20
25
119
WDMX
WT24DMX
DMX-signal “transmitter” unit
• “Wireless Solution Sweden” technology
• Working frequencies: 2.45 GHz
• Operating distance: up to 750mt
• 6 DMX universes output (3072
channels)
• Safe data transmission through FHSS
system
• B oth point-to-point and point-tomultipoint operation
• Add receiver button with LED indicator
• R otary antenna for wide range of
transmitting
• Input connection: XLR3p/5p
• Power supply: Internal 230V-50Hz
• Dimensions: 165x112x61 mm
• Weight: 1.0Kg
WR24DMX
DMX-signal “receiver” unit
• “Wireless Solution Sweden” technology
• Working frequencies: 2.45 GHz
• Operating distance: up to 750mt
• 512 DMX channels receiver
• Safe data transmission through FHSS
system
• B oth point-to-point and point-tomultipoint operation
• Add receiver button with LED indicator
• R otary antenna for wide range of
transmitting
• Input connection: XLR3p/5p
• Power supply: Internal 230V-50Hz
• Dimensions (WxHxD): 120x58x88 mm
• Weight: 1.0Kg
WR24A
WDMX Antenna Receiver
• “Wireless Solution Sweden” technology
• Working frequencies: 2.45 GHz
• Operating distance: up to 750mt
120
WT24DMXIP
IP65 DMX-signal “transmitter” unit
• “Wireless Solution Sweden” technology
• Working frequencies: 2.45 GHz
• Operating distance: up to 750mt
• 6 DMX universes output (3072
channels)
• Safe data transmission through FHSS
system
• B oth point-to-point and point-tomultipoint operation
• Add receiver button with LED indicator
• R otary antenna for wide range of
transmitting
• Input connection: XLR3p/5p
• Power supply: Internal 230V-50Hz
• Dimensions: 165x112x61 mm
• Weight: 1.0Kg
WR24DMXIP
IP65 DMX-signal “receiver” unit
• “Wireless Solution Sweden” technology
• Working frequencies: 2.45 GHz
• Operating distance: up to 750mt
• 512 DMX channels receiver
• Safe data transmission through FHSS
system
• B oth point-to-point and point-tomultipoint operation
• Add receiver button with LED indicator
• R otary antenna for wide range of
transmitting
• Input connection: XLR3p/5p
• Power supply: Internal 230V-50Hz
• Dimensions (WxHxD): 185x49,7x167
mm
• Weight: 1.0Kg
Flightcase for LedMatrix
LM376CASE
Flight-case with internal
compartments to house 6
mudules of LEDMATRIX37.
Dimensions: 135x660x875
LM254CASE
Flight-case with internal
compartments to house 4
mudules of LEDMATRIX25.
Dimensions: 1670x78x1030
LM186CASE
Flight-case with internal
compartment to house 6
mudules of LEDMATRIX18.
Dimensions: 135x660x875
LM126CASE
Flight-case with internal
compartment to house 6
mudules of LEDMATRIX12.
Dimensions: 135x660x875
LM68CASE
Flight-case with internal
compartment to house 8
mudules of LEDMATRIX6.
LM108CASE
Flight-case with internal
compartment to house 8
mudules of LEDMATRIX10.
121
Rigging, cables and extensions for LedMatrix
LM37CLAMP
Aluminium rigging
system for LEDMATRIX37
modules.
LM12CLAMP
Aluminium rigging
system for LEDMATRIX12
modules.
LMEXDCIP65
Extension data cable for
LEDMATRIX videowalls.
Assembled with CAT5
cable and IP65 Data
IPCON connectors.
Code
122
€ 16
€ 21
€ 49
Code
LMEXDCL005
LMEXDCL01
LMEXDCL05
LMEXDCL10
LMEXAC
Power distribution cable for
LEDMATRIX videowalls.
Assembled with Neutrik
Powercon connectors:
MENAC3FCA, MENAC3FCB.
(mt)
0,5
1
5
Code
LMEXACL005
LMEXACL01
LMEXACL05
LM18CLAMP
Aluminium rigging
system for LEDMATRIX18
modules.
LMEXDC
Extension data cable, conceived for
LEDMATRIX screens.
Assembled with CAT5 cable and
RJ45 Ethercon Neutrik connectors.
LMBAR3W
FlyBar for hanging of 3 columns of
LEDMATRIX10 and LEDMATRIX6
LMBAR2W
FlyBar for hanging of 2 columns of
LEDMATRIX10 and LEDMATRIX6
LMEXDCIP65L005
LMEXDCIP65L01
LMEXDCIP65L05
LM25CLAMP
Aluminium rigging
system for LEDMATRIX25
modules.
€ 42
€ 52
€ 79
mt
0.5
1
5
€ 16
€ 21
€ 49
€ 60
mt
0,5
1
5
10
LMADAC
Power adaptor for
LEDMATRIX system, Neutrik
MENAC3FCA/ 16A CEE plug.
Code
LMADACL10
€ 100
mt
10
Video processor for LedMatrix
LMDVIPROC1
Video processor for signal transmission between LEDMATRIX ledwalls and PC.
• Linsn sender card included
• Input connections: DVI socket
• Output connections: Ethernet RJ45 socket
• Software for screen configuration and mediaplayer included
• Power supply: AC 100-240V 50/60Hz
LMSCALER
HD Video scaler with 2 integrated sender cards
• Input connections: VGA, DVI, YpbPr, BNC, Composite, D/P, SDI
• Output connections: VGA, 2xDVI
• Sender Card: 2x Linsn
• User interface through LCD graphic display and buttons for an easy access to settings,
selection of input channels, brightness, setup
• Output resolution: 1920x1080 or 1600x1200
• Dimensions: 485x155x350 mm
• Power supply: VDE 100-240V 50/60 Hz
123
Liquid
SMOKEFLUIDSD
High density Fluid for
fog machines, 5Kg
tank - green fluid
SMOKEFLUIDHD
High density Fluid for
fog machines, 5Kg tank
SMOKEFLUIDMD
Medium density
Fluid for fog
machines, 5Kg tank
SMOKEFLUIDHZ
Medium density fluid for
haze machines, 5kg tank
SMOKEOILHZ
High density Oil-fluid for
Haze machines, 1L tank
BUBBLEFLUID
Fluid for bubble
machines, 5Kg tank
SNOWFLUID
Fluid for snow
machines, 5Kg tank
124
NOTE
NOTE
Rivenditore autorizzato
MUSIC & LIGHTS s.r.l.
Entertainment Technologies
Ufficio Vendite Italia
tel. +39 0771 72190
fax +39 0771 721955
tel. +39 0771 72190
[email protected]
fax +39 0771 721955
Foreign Sales Office
tel. +39 0771 721966
www.musiclights.it
fax +39 0771 721977
[email protected]
[email protected]
Azienda Certificata ISO 9001:2008
Via Appia Km 136.200
04020 ITRI (LT) Italy
ProLights è un marchio registrato. Progetto grafico: Music & Lights Srl © 2011
Le immagini contenute sono solo a scopo illustrativo. Le specifiche possono essere variate senza alcuna notifica.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
