Liquid Crystal Projector
Model 8805
USER'S MANUAL
Important Information
RF Interference
Safety Cautions
Precautions
WARNING
The Federal Communications Commission does not allow any
modifications or changes to the unit EXCEPT those specified
by Dukane corporation in this manual. Failure to comply
with this government regulation could void your right to
operate this equipment. This equipment has been tested and
found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Please read this manual carefully before using your Dukane
Projector and keep the manual handy for future reference.
Your serial number is located on the right side of your projector.
Record it here:
CAUTION
To turn off main power, be sure to remove the plug from power
outlet.
The power outlet socket should be installed as near to the
equipment as possible, and should be easily accessible.
CAUTION
TO PREVENT SHOCK, DO NOT OPEN THE CABINET.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED NEC SERVICE PERSONNEL.
This symbol warns the user that uninsulated voltage within the
unit may be sufficient to cause electrical shock. Therefore, it is
dangerous to make any kind of contact with any part inside of
the unit.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
This symbol alerts the user that important information concerning the operation and maintenance of this unit has been
provided.
The information should be read carefully to avoid problems.
In UK, a BS approved power cable with moulded plug has a Black (five
Amps) fuse installed for use with this equipment. If a power cable is not
supplied with this equipment please contact your supplier.
WARNING
TO PREVENT FIRE OR SHOCK, DO NOT EXPOSE THIS UNIT TO
RAIN OR MOISTURE.
DO NOT USE THIS UNIT’S GROUNDED PLUG WITH AN EXTENSION CORD OR IN AN OUTLET UNLESS ALL THREE PRONGS
CAN BE FULLY INSERTED.
DO NOT OPEN THE CABINET. THERE ARE HIGH-VOLTAGE COMPONENTS INSIDE. ALL SERVICING MUST BE DONE BY QUALIFIED NEC SERVICE PERSONNEL.
Important Safeguards
These safety instructions are to ensure the long life of your projector
and to prevent fire and shock. Please read them carefully and heed all
warnings.
Installation
1. For best results, use your projector in a darkened room.
DOC Compliance Notice
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Acoustic Noise Information Ordinance-3. GSGV:
The sound pressure level is less than 70 dB (A) according
to ISO 3744 or ISO 7779.
• Consult the dealer or an experienced radio / TV technician for
help.
2. Place the projector on a flat, level surface in a dry area away from
dust and moisture.
To avoid premature lamp failure, do not tilt the front of the projector
up or down by more than 15° from level.
3. Do not place your projector in direct sunlight, near heaters or heat
radiating appliances.
4. Exposure to direct sunlight, smoke or steam can harm internal components.
5. Handle your projector carefully. Dropping or jarring can damage internal components.
6. Do not place heavy objects on top of the projector.
7. If you wish to have the projector installed on the ceiling:
a. Do not attempt to install the projector yourself.
This label is on the side of the remote control.
b. The projector must be installed by qualified technicians in order
to ensure proper operation and reduce the risk of bodily injury.
CAUTION
Do not look into the laser pointer while it is on and do not
point the laser beam at a person. Serious injury could result.
c. In addition, the ceiling must be strong enough to support the
projector and the installation must be in accordance with any
local building codes.
d. Please consult your dealer for more information.
E-2
Fire and Shock Precautions
What's in the Box?
1. Ensure that there is sufficient ventilation and that vents are unobstructed to prevent the build-up of heat inside your projector. Allow
at least 3 inches (10 cm) of space between your projector and a
wall.
Make sure your box contains everything listed. If any pieces are missing, contact your dealer.
2. Prevent foreign objects such as paper clips and bits of paper from
falling into your projector.
Lens cap
Do not attempt to retrieve any objects that might fall into your projector. Do not insert any metal objects such as a wire or screwdriver
into your projector. If something should fall into your projector, disconnect it immediately and have the object removed by a qualified
NEC service personnel.
Remote Control Cable
3. Do not place any liquids on top of your projector.
4. Do not look into the lens while the projector is on. Serious damage
to your eyes could result.
FF
O
J.
AD
N
O
ER
B
W
RG
PO
TO
AU
ER
EW
VI
R
SE
LA
S
E
LE
C
T
PJ
AS
PE
CT
HE
FR
EE
ZE
LP
VO
LU
ME
PO
INT
ER
3D
PIC
-MU
TE
MA
GN
IFY
SL
ZO
OM
RE
FO
RM
IDE
FO
CU
S
FO
LDER
SLI
DE
LIS
6. Do not cover the lens with the supplied lens cap or equivalent while
the projector is on. Doing so can lead to melting of the cap and
possibly burning your hands due to the heat emitted from the light
output.
USB mouse
O
DE
VI
5. Keep any items such as magnifying glass out of the light path of the
projector. The light being projected from the lens is extensive, therefore any kind of abnormal objects that can redirect light coming out
of the lens, can cause unpredictable outcome such as fire or injury
to the eyes.
Projector
T
Remote control
Batteries
String and rivet
7. The projector is designed to operate on a power supply of 100-120
or 200-240 V 50/60 Hz AC. Ensure that your power supply fits this
requirement before attempting to use your projector.
8. Handle the power cable carefully and avoid excessive bending.
A damaged cord can cause electric shock or fire.
9. If the projector is not to be used for an extended period of time,
disconnect the plug from the power outlet.
Power cable
USB cable
RGB signal cable
CAUTION
1. Do not try to touch the ventilation outlet on the front as it can become heated while the projector is turned on.
3. Enable High-Speed Fan mode if you continue to use the projector
for consecutive days. (From the Advanced menu, select [Projector
Options] → [Setup] → [Page 4] → [High Speed Fan Mode].)
4. Do not unplug the power cable from the wall outlet under any one of
the following circumstances.
Doing so can cause damage to the projector:
*
While the Hour Glass icon appears.
*
While the message "Please wait a moment." appears. This message will be displayed after the projector is turned off.
*
While the cooling fans are running. (The cooling fans continue to
work for 90 seconds after the projector is turned off).
5. Do not eject the PC card or LAN card while its data is being accessed.
Doing so can damage your PC card or LAN card data.
Lamp Replacement
•
To replace the lamp, follow all instructions provided on page E-53.
•
Be sure to replace the lamp when the message "The lamp has
reached the end of its usable life. Please replace the lamp."
appears. If you continue to use the lamp after the lamp has reached
the end of its usable life, the lamp bulb may shatter, and pieces of
glass may be scattered in the lamp case. Do not touch them as the
pieces of glass may cause injury.
•
Allow a minimum of 90 seconds to elapse after turning off the projector. Then turn off the main power switch, disconnect the power
cable and allow 60 minutes to cool the projector before replacing
the lamp.
If this happens, contact your Dukane dealer for lamp replacement.
E-3
's
er al
Us anu
M
2. Do no use the tilt-foot for purposes other than originally intended.
Misuses such as gripping the tilt-foot or hanging on the wall can
cause damage to the projector.
CD-ROM
Projector User Supportware
TABLE OF CONTENTS
Selecting Video Filter Level .................................................................................... E-39
Selecting Noise Reduction Level ............................................................................ E-39
Signal Type ............................................................................................................ E-39
Picture Management .................................................................................................. E-39
User Adjust (when using User 1 to 4) .................................................................... E-39
Selecting Gamma Correction Mode ................................................................ E-40
Selecting Color Correction ............................................................................. E-40
Adjusting Color Temperature and White Balance ............................................ E-40
Selecting Base Setting .................................................................................... E-40
Projector Options ...................................................................................................... E-40
Using 3D Reform ................................................................................................... E-40
Cornerstone ................................................................................................... E-40
Keystone ........................................................................................................ E-40
Using Adapting Color Correction ........................................................................... E-41
Menu [Page1] ........................................................................................................ E-43
Selecting Menu Language/Selecting Menu Mode/Customizing the Menu/Selecting Projecting Pointer Icon/Selecting Menu Display Time
Menu [Page 2] ....................................................................................................... E-43
Turning On / Off Source Display / Turning On / Off Message / Selecting Menu
Color
Setup [Page 1] ....................................................................................................... E-44
Selecting Projector Orientation/Selecting a Color or Logo for Background/Setting
RGB 1 or 2 for RGB OUT/Setting Closed Caption
Setup [Page 2] ....................................................................................................... E-44
Setting Viewer Options/Selecting Capture Options/Setting Mouse Button and Sensitivity/Selecting Operation Mode
Setup [Page 3] ....................................................................................................... E-45
Selecting Signal Format [Signal Select]
Setup [Page 4] ....................................................................................................... E-45
Enabling Auto Adjust/Enabling Auto Start/Enabling Power Management/Enabling
Power Off Confirmation/Enabling Horizontal and Vertical Keystone Correction Save
/Enabling High Speed Fan Mode/Selecting Built-in Speakers/Enabling Idle Mode
Setup [Page 5] ....................................................................................................... E-46
Remote Sensor/S-Video Mode Select
Setup [Page 6] ....................................................................................................... E-46
Selecting Communication Speed/Selecting Default Source/Disabling the Cabinet
Buttons
Selecting Lamp Mode and Lamp Type ................................................................... E-46
Selecting Aspect Ratio and Position for Screen ..................................................... E-47
Selecting Auto Functions ....................................................................................... E-47
Setting LAN Mode ..................................................................................................... E-48
IP Address ............................................................................................................. E-48
Network Type ......................................................................................................... E-48
WEP ....................................................................................................................... E-49
Mail ........................................................................................................................ E-49
Status .................................................................................................................... E-50
Setting a Password .................................................................................................... E-50
Security ..................................................................................................................... E-51
Tools .......................................................................................................................... E-52
Using Sleep Timer/Using Capture/Using PC Card Files/Using ChalkBoard
Help ........................................................................................................................... E-52
Contents ................................................................................................................ E-52
Information ............................................................................................................ E-52
Returning to Factory Default ...................................................................................... E-52
Important Information ..................................................... E-2
Safety Cautions ............................................................................................................... E-2
What's in the Box? .......................................................................................................... E-3
INTRODUCTION .............................................................. E-5
Introduction to the Projector ........................................................................................... E-5
Part Names of the Projector ............................................................................................ E-6
Attaching the lens cap ................................................................................................. E-6
Carrying the Projector ................................................................................................. E-6
Top Features ................................................................................................................ E-7
Terminal Panel Features ............................................................................................... E-8
Part Names of the Remote Control .............................................................................. E-9
Battery Installation ................................................................................................. E-11
Remote Control Precautions .................................................................................. E-11
Operating Range for Wireless Remote Control ...................................................... E-11
Using the Remote Control in Wired Operation ....................................................... E-11
INSTALLATION AND CONNECTIONS ....................................... E-12
Setting Up the Screen and the Projector .......................................................................
Selecting a Location ..................................................................................................
Throw Distance and Screen Size ...............................................................................
Making Connections ......................................................................................................
When Viewing a DVI Digital Signal ............................................................................
Connecting Your PC or Macintosh Computer ............................................................
To connect SCART output (RGB) ...............................................................................
Connecting an External Monitor ................................................................................
Connecting Your DVD Player .....................................................................................
Connecting Your VCR or Laser Disc Player ...............................................................
Connecting the Supplied Power Cable .......................................................................
E-12
E-12
E-13
E-14
E-14
E-14
E-15
E-15
E-16
E-17
E-17
PROJECTING AN IMAGE (BASIC OPERATION) ........................... E-18
Turning on the Projector ................................................................................................
Selecting a Source .........................................................................................................
Adjusting the Picture Size and Position .........................................................................
Correcting the Horizontal and Vertical Keystone Distortion (3D Reform) ......................
Optimizing RGB Picture Automatically ..........................................................................
Turning Up or Down Volume .........................................................................................
Using the Laser Pointer .................................................................................................
Setting the function switch ............................................................................................
Turning off the Projector ...............................................................................................
E-18
E-19
E-19
E-20
E-22
E-22
E-22
E-23
E-23
CONVENIENT FEATURES ................................................... E-24
Using the Remote Mouse Function ...............................................................................
Connecting to your computer for the remote mouse function ...................................
When using the USB Port ..........................................................................................
Switching operation mode between computer and projector .....................................
Turning Off the Image and Sound ..................................................................................
Freezing a Picture ..........................................................................................................
Using the Pointer ..........................................................................................................
Enlarging and Moving a Picture .....................................................................................
Getting the On-line Help ................................................................................................
Using the USB Mouse ...................................................................................................
Using the USB HUB Function ........................................................................................
Changing Background Logo ..........................................................................................
Making Freehand Drawings on a Projected Image (ChalkBoard) ...................................
E-24
E-24
E-24
E-24
E-25
E-25
E-25
E-25
E-25
E-26
E-26
E-27
E-27
USING THE VIEWER ........................................................ E-28
Making the Most out of the Viewer Function .................................................................
Operating the Viewer Function from the Projector (playback) .......................................
Projecting slides (Viewer) ..........................................................................................
Auto Play Mode .........................................................................................................
Switching to Slides Directly from Other Input Modes ................................................
Viewing Digital Images ..............................................................................................
Storing Images Displayed on the Projector on the PC card (Capture) .......................
Deleting Captured Images .........................................................................................
Using the PC Card Files Fucntion (PC Card Files) ......................................................
E-28
E-29
E-29
E-30
E-30
E-30
E-30
E-31
E-31
USING ON-SCREEN MENU ................................................. E-32
Basic Menu Operation ...................................................................................................
Using the Menus .......................................................................................................
Customizing the Menu ...............................................................................................
Menu tree ......................................................................................................................
Menu Elements .............................................................................................................
Entering Alphanumeric Characters by Using the Menu ..............................................
Menu Descriptions & Functions ....................................................................................
Source Select ............................................................................................................
RGB/Video/S-Video/DVI (DIGITAL)/Viewer/LAN/Entry List
Picture .......................................................................................................................
Sound ........................................................................................................................
Image Options ...........................................................................................................
Selecting Aspect Ratio ...........................................................................................
Masking Unwanted Area (Blanking) .......................................................................
Adjusting Position and Clock .................................................................................
Horizontal/Vertical Position ....................................................................................
Selecting Resolution ..............................................................................................
Selecting Overscan Percentage ..............................................................................
E-32
E-32
E-32
E-33
E-36
E-37
E-37
E-37
E-38
E-38
E-38
E-38
E-39
E-39
E-39
E-39
E-39
MAINTENANCE ............................................................. E-53
Replacing the Lamp ......................................................................................................
Cleaning ........................................................................................................................
Cleaning or Replacing the Filter .................................................................................
Cleaning the Cabinet and the Lens .............................................................................
E-53
E-54
E-54
E-54
TROUBLESHOOTING ........................................................ E-55
Power Indicator .............................................................................................................
Status Indicator .............................................................................................................
Lamp Indicator ..............................................................................................................
Common Problems & Solutions ....................................................................................
When using the Viewer function ....................................................................................
E-55
E-55
E-55
E-56
E-56
SPECIFICATIONS ........................................................... E-57
APPENDIX ................................................................... E-58
Cabinet Dimensions ......................................................................................................
Pin Assignments of D-Sub RGB Input Connector ..........................................................
Compatible Input Signal List .........................................................................................
PC Control Codes and Cable Connection .......................................................................
PC Control Connector (D-SUB 9P) ................................................................................
Using Software Keyboard ..............................................................................................
Operation Using an HTTP Browser ................................................................................
E-4
E-58
E-58
E-59
E-60
E-60
E-60
E-61
INTRODUCTION
• Exclusive intelligent pixel blending technology - an extremely
accurate image compression technology - offers a crisp
image with UXGA (1600⳯1200) resolution*3.
Introduction to the Projector
This section introduces you to your new Projector and describes
the features and controls.
Congratulations on Your Purchase of This Projector
The Dukane ImagePro 8805 is one of the very best projectors available today. The ImagePro 8805 enables you to project precise
images up to 500 inches across (measured diagonally) from your PC or
Macintosh computer (desktop or notebook), VCR, DVD player, document camera, a laser disc player or Viewer.
You can use the projector on a tabletop or cart, you can use the projector to project images from behind the screen, and the projector can be
permanently mounted on a ceiling*1. The remote control can be used
wirelessly.
• Supports most IBM VGA, SVGA, XGA, SXGA/UXGA(compressed)
Macintosh, component signal (YCbCr/ YPbPr) or any other
RGB signals within a horizontal frequency range of 24 to 100
kHz and a vertical frequency range of 48 to 120 Hz. This includes
NTSC, PAL, PAL-N, PAL-M, PAL60, SECAM and NTSC4.43 standard video signals.
NOTE: Composite video standards are as follows:
NTSC: U.S. TV standard for video in U.S. and Canada.
PAL: TV standard used in Western Europe.
PAL-N: TV standard used in Argentine, Paraguay and Uruguay.
PAL-M: TV standard used in Brazil.
PAL60: TV standard used for NTSC playback on PAL TVs.
SECAM: TV standard used in France and Eastern Europe.
NTSC4.43: TV standard used in Middle East countries.
*1 Do not attempt to mount the projector on a ceiling yourself.
The projector must be installed by qualified technicians in order
to ensure proper operation and reduce the risk of bodily injury.
In addition, the ceiling must be strong enough to support the projector and the installation must be in accordance with any local
building codes. Please consult your dealer for more information.
Features you'll enjoy:
• 3D Reform enhanced keystone correction that allows not only horizontal and vertical access but diagonal adjustments.
• Wireless*2 or wired networking access provides easy and effective
presentation delivery.
*2 A wireless LAN card is required. The optional wireless LAN
card is available. (SWL-2100N-N∗)
• The supplied remote control can be used without a cable, and you
can even use the remote control to operate your PC's mouse wirelessly
from across the room with the built-in remote mouse function.
• You can control the projector with a PC using the PC Control port.
• USB port allows USB mouse operation*4.
*4 The USB ports meet the USB1.1 specification.
• The contemporary cabinet design is light, compact, easy to carry,
and complements any office, boardroom or auditorium.
• Safety protect by Password and Security functions
• Eight pointers are available for your presentation.
Password and Security features prevent the projector from being used
by unauthorized individuals.
Password prevents unauthorized individuals from changing projector
settings or adjustments Security offers complete protection by using
your PC card as a protect key so that the projector will not project a
signal without insertion of the registered PC card and unauthorized
use can be discouraged.
• Picture Management enables users to adjust individual color settings
to their preferences.
About this user's manual
The fastest way to get started is to take your time and do everything right the first time. Take a few minutes now to review
the user's manual. This may save you time later on. At the beginning of each section of the manual you'll find an overview. If
the section doesn't apply, you can skip it.
• Eco-mode extends lamp life and reduces total cost of ownership.
Standard lamp and optional longer life lamp
• Power zoom and power focus standard lens provide easy adjustment.
• Automatic lens focus provides extreme ease of use
• Automatic Wall Color Correction allows for quick adaptive color correction on textured or painted walls and in applications where the
display is other than screen material. With the built-in image sensor,
the projector adjusts the colors for screen sizes between 40" and
150" diagonally.
• Variable audio out control via projector
• The built-in Viewer allows you to start your presentation even when a
PC is not available at the site.
• A high-bright 275 watt DC lamp (220W Eco mode).
• The Standby mode reduces standby power consumption significantly.
• The supplied wireless remote control that operates the projector from
any angle.
• The image can be projected between 25 and 500 inches (measured
diagonally).
• The "Capture" enables you to capture the current projected image.
• An image can be projected from in front or behind a screen, and the
projector can even be installed on the ceiling.
E-5
Part Names of the Projector
Remote Sensor (See page E-11)
Controls (See page E-7)
Image Sensor
For Auto Focus and Auto Wall Color
Correction. (See page E-47)
Remote Sensor (See page E-11)
Built-in Security Slot (
)*
Lens
Ventilation (inlet)
Adjustable Tilt Foot Lever
(See page E-19)
Adjustable Tilt Foot
(See page E-19)
Carrying Handle
Adjustable Tilt Foot Lever
(See page E-19)
Ventilation (outlet)
Heated air is exhausted from here
Lens Cap
Adjustable Tilt Foot (See page E-19)
* This security slot supports the MicroSaver® Security System. MicroSaver® is a registered trademark of Kensington Microware Inc. The logo is
trademarked and owned by Kensington Microware Inc.
Lamp Cover (See page E-53)
PC Card Slot 1
PC Card Slot 2
Remote Sensor (See page E-11)
Filter Cover (inlet)
1
2
REMO
E/HUB
PC Card Eject Button
TE
PC CONT
USB(MOUS
)
ROL
R
L/MON
O
AUDIO
V
AUDIO
H
Remote Sensor
(See page E-11)
DVI IN
B/Cb
AUDIO
OUT
G/Y
AC IN
AUDIO
RGB OUT
RGB2
RGB1
IN
AUDIO
IN
L/MON
AUDIO
L/MON
O
O
R
R
AUDIO
VIDEO
IN
AUDIO
S-VIDEO
IN
Stereo Speaker (5W)
Main Power Switch
When you plug the supplied power cable into
an active wall outlet and turn on the Main
Power switch, the POWER indicator turns
orange and the projector is in standby mode.
(See page E-18)
AC Input
Connect the supplied power cable's threepin plug here, and plug the other end into
an active wall outlet. (See page E-17)
Attaching the lens cap
Carrying the Projector
To attach the lens cap to the bottom with the supplied string and rivet:
Always carry your projector by the handle.
Ensure that the power cable and any other cables connecting to video
sources are disconnected before moving the projector.
When moving the projector or when it is not in use, cover the lens with
the lens cap.
1. Thread the string through the
hole on the lens cap and then
tie a knot in the string.
2. Use the rivet to attach the
string to the bottom of the
projector.
E-6
11. SELECT (+) (–) / Volume Buttons
: Use these buttons to select the menu of the item you wish to
adjust. When no menus appear, these buttons work as a volume control.
: Use these buttons to change the level of a selected menu item.
A press of the button executes the selection. When the menus
or the Viewer tool bar is not displayed, these buttons can be
used to select a slide, or to move the cursor in Folder List or
Slide List.
Top Features
11
10
9
8
5
6
4
3
When the pointer is displayed, these buttons move the pointer.
2
12. ENTER Button
Executes your menu selection and activates items selected from the
menu.
12 13
14
7
1
1. POWER Button (ON / STAND BY)( )
Use this button to turn the power on and off when the main power is
supplied and the projector is in standby mode.
NOTE: To turn on or off the projector, press and hold this button for a minimum of two seconds.
13. CANCEL Button
Press this button to exit "Menus". Press this button to return the adjustments to the last condition while you are in the adjustment or
setting menu.
14. PC CARD Access Indicator 1/2
Lights while accessing a PC card.
2. POWER Indicator
When this indicator is green, the projector is on; when this indicator
is orange, it is in standby or idle mode. See the Power Indicator section on page E-55 for more details.
3. STATUS Indicator
If this light blinks red rapidly, it indicates that an error has occurred,
the lamp cover is not attached properly or the projector has overheated. If this light remains orange, it indicates that you have pressed
a cabinet key while the Control Panel Key Lock is enabled. See the
Status Indicator section on page E-55 for more details.
4. LAMP Indicator
If this light blinks red rapidly, it's warning you that the lamp has reached
the end of its usable life. After this light appears, replace the lamp as
soon as possible (See page E-53). If this is lit green continually, it
indicates that the lamp mode is set to Eco. See the Lamp Indicator
section on page E-55 for more details.
5. SOURCE Button
Use this button to select a video source such as a PC, VCR, DVD
player, Viewer (PC card), or LAN.
Press and release this button quickly to display the Source List.
Each time this button is pressed for a minimum of ONE second, the
input source will change as follows:
RGB1 → RGB2 → Video → S-Video → DVI (DIGITAL)* → Viewer → RGB1 → ...
If no input signal is present, the input will be skipped.
6. AUTO ADJUST Button
Use this button to adjust Position-H/V and Pixel Clock/Phase for an
optimal picture (See page E-22). Also press and hold this button for a
minimum of 2 seconds to enable the Auto Focus* or Auto Wall Color
Correction* function (See page E-47).
7. 3D REFORM Button
Press this button to enter 3D Reform mode to correct the keystone
(trapezoidal) distortion, and make the image square.
8. ZOOM Button (+/-)
Zoom the lens in and out.
9. FOCUS Button (+/-)
Adjust the lens focus.
10. MENU Button
Displays the menu.
E-7
5. S-VIDEO IN Connector (Mini DIN 4 Pin)
Here is where you connect the S-Video input from an external source
like a VCR.
Terminal Panel Features
8
9 10 13
12
NOTE: S-Video provides more vivid color and higher resolution than the traditional composite video format.
3
S-VIDEO AUDIO Input Jacks R/L (RCA)
These are your left and right channel audio inputs for stereo sound
from an S-Video source.
2
1
4
7
6. VIDEO IN Connector (RCA)
Connect a VCR, DVD player, laser disc player, or document camera
here to project video.
11
6
5
1. RGB1 IN / Component Input Connector (Mini D-Sub 15 Pin)
Connect your computer or other analog RGB equipment such as IBM
compatible or Macintosh computers. Use the supplied RGB cable to
connect to your computer. This also serves as a component input
connector that allows you to connect a component video output of
component equipment such as a DVD player. This connector also
supports SCART output signal. See page E-15 for more details.
RGB1 AUDIO Input Mini Jack (Stereo Mini)
This is where you connect the audio output from your computer or
DVD player when connected to the RGB1 input. A commercially available audio cable is required.
2. RGB2 IN / Component Input Connectors (BNC)
Connect R,G,B,H (Horizontal sync) and V (Vertical sync) outputs of
external equipment.
If using a component with a combined sync (SYNC) output, connect
it to the H/V terminal.
When using luminance and color-difference signals of HDTV and DVD,
connect Pr/Cr to the R,Y to the G and Pb/Cb to the B input of the
projector.
NOTE: The RGB IN 2 does not support Plug & Play.
RGB2 AUDIO IN Mini Jack (Stereo Mini)
This is where you connect audio output from your computer or DVD
player connected to the RGB2 input. A commercially available audio
cable is required.
3. DVI IN Connector (24 pin)
This connector can be used to accept a digital signal output from a
computer or other sources with a DVI connector.
DVI AUDIO Input Mini Jack (Stereo Mini)
This is where you connect the audio output from your computer when
connected to the DVI input. A commercially available audio cable is
required. On MT860 this AUDIO input mini jack is used for Viewer
and LAN exclusively.
4. RGB OUT Connector (Mini D-Sub 15 Pin)
You can use this connector to loop your computer image to an external monitor from the RGB 1 or 2 input source.
The RGB analog signal set on RGBOUT Terminal is output during
idle mode. See pages E-15 and 45.
RGB AUDIO OUT Mini Jack (Stereo Mini)
Connect an additional audio equipment here to listen to audio coming from your computer connected to RGB1, RGB2 or DVI input (not
available on MT860).
Note that there is no audio output from this jack during Standby and
Idle.
VIDEO AUDIO Input Jacks R/L (RCA)
These are your left and right channel audio inputs for stereo sound
from a Video source.
7. AUDIO OUT Jacks R/L (RCA)
You can use this connector to output sound from the currently selected input source (RGB 1, RGB 2, DVI (DIGITAL) (not available on
MT860), Video or S-Video).
Output sound level can be adjusted in accordance with the sound
level of the internal speaker.
8. USB Port (MOUSE/HUB) [Type A]
Connect the supplied USB mouse. You can operate the menu or Viewer
with the USB mouse via this port.
• A USB-supported scanner or PC peripheral can be connected
to this port. (USB Hub Function)
9. USB Port (PC) [Type B]
Connect this port to the USB port (type A) of your PC using the supplied USB cable. You can operate your computer's mouse functions
from the remote control. This port also serves as a PC Control port
by using Dynamic Image Utility 2.0 included on the supplied CDROM.
10. REMOTE (Mini Jack)
Connect your remote control cable here for wired operation.
11. PC CONTROL Port (D-Sub 9 Pin)
Use this port to connect your PC to control your projector via a serial
cable. This enables you to use your PC and serial communication
protocol to control the projector. A commercially available RS232C
cross cable is required to use this port. You can also control the projector by using Dynamic Image Utility 2.0 included on the supplied
CD-ROM.
To do so you must first have Dynamic Image Utility 2.0 installed on
your PC. If you are writing your own program, typical PC control codes
are on page E-60.
12. PC CARD Slot 1/2
Insert a PC card, commercially available LAN card or NEC optional
wireless LAN card here.
There are two slots: Slot 1 and Slot 2.
NOTE: A dummy card is inserted into each slot at the time of shipment. First
remove the dummy cards before use.
13. PC CARD Eject Button 1/2
Press to eject a PC card partially. Each slot has its own eject button:
1 and 2.
E-8
Part Names of the Remote Control
9. VIEWER Button
Press this button to select the Viewer source.
11. LASER Button
Press and hold this button to activate the laser pointer. When lit, you
can use the laser to draw your audience's attention to a red dot that
you can place on any object.
SE
LE
CT
ER
LAS
VIE
WE
R
AU
RG
B
TO AD
J.
PO
WE
R
VID
EO
2. LASER Pointer
Beams a laser light when the LASER button is pressed.
ON
OF
F
12. MENU Button
Displays the menu for various settings and adjustments.
3
3. Remote Jack
Connect your remote control
cable here for wired operation.
2
13. SELECT (Mouse) Button
When you are in the Computer mode, these buttons work as a computer mouse.
When you are in the Projector mode, which is indicated by lighting
the PJ button. See page E-24.
1
4
6
MENU
5
8
9
11
SELECT
13
ON
OFF
POWER
RGB
VIDEO
7
10
VIEWER
LASER
AUTO ADJ.
: Use these buttons to select the menu of the item you wish
to adjust.
: Use these buttons to change the level of a selected menu
item. A press of the button executes the selection.
When the pointer is displayed, these buttons move the pointer.
When the pointer is not displayed, these buttons are for adjusting the image.
12
14
EN
TE
CAN
R
CE
L
21
23
24
25
ASPECT
FREEZE 3D REFORM
HELP
POINTER PIC-MUTE
VOLUME MAGNIFY
14. ENTER (Left Click) Button
When you are in the Computer mode, this button works as the mouse
left button. When this button is pressed and held for a minimum of 2
seconds, the drag mode is set. When you are in the Projector mode,
which is indicated by lighting the PJ button: Use this button to enter
your menu selection. It works the same way as the ENTER button on
the cabinet. See page E-7.
15
16
PJ
17
20
10. AUTO ADJ Button
Use this button to adjust an RGB source for an optimal picture. Also
press and hold this button for a minimum of 2 seconds to enable the
Auto Focus* or Auto Wall Color Correction* function. See page E-20
or 22.
J
P
ZE
EE
FR
3D
RM
FO
RE
1. Infrared Transmitter
Direct the remote control toward
the remote sensor on the projector cabinet.
TE
U
-M
PIC
E
NOTE: If you are using a Macintosh computer, you can click either the right-click
or left-click button to activate the mouse.
SLIDE
18
19
22
15. CANCEL (Right Click) Button
When you are in the Computer mode, this button works as the mouse
right button. When you are in the Projector mode, which is indicated
by lighting the PJ button: Press this button to exit the Menus. It works
the same way as the CANCEL button on the cabinet. See page E-7.
27
4. LED
Flashes when any button is pressed.
16. PJ Button
Press this button to switch the SELECT, CANCEL, and ENTER buttons between the Projector mode (lit red) and the Computer mode.
Press this button or any one of the POWER ON/OFF, MENU, ASPECT, 3D REFORM, HELP, POINTER, MAGNIFY, VIEWER, FOLDER
LIST or SLIDE LIST buttons to switch to the Projector mode and the
PJ button lights red. To switch back to the Computer mode, press the
PJ button again. See page E-24.
5. POWER ON Button
When the main power is on, you can use this button to turn your
projector on.
17. ASPECT Button
Press this button to display the Aspect Ratio select screen. See page
E-38.
ZOOM
FOCUS
FOLDER
SLIDE
26
LIST
28
29
NOTE: To turn on the projector, press and hold the POWER ON button for a
minimum of two seconds.
6. POWER OFF Button
You can use this button to turn your projector off.
NOTE: To turn off the projector, press and hold the POWER OFF button for a
minimum of two seconds.
18. FREEZE Button
This button will freeze a picture. Press again to resume motion.
19. 3D REFORM Button
Press this button to enter 3D Reform to correct the keystone (trapezoidal) distortion, and make the image square. See page E-20.
20. HELP Button
Provides the online help or the set information.
7. VIDEO Button
Press this button to toggle between Video and S-Video inputs.
8. RGB Button
Press this button to select RGB 1, RGB 2 or DVI (DIGITAL)* inputs.
Each time this button is pressed, the input source will change as
follows:
21. POINTER Button
Press this button to display one of the eight pointers; press again to
hide the pointer. You can move your pointer icon to the area you want
on the screen using the Select button. See page E-25.
RGB 1 → RGB 2 → DVI (DIGITAL)* → RGB 1 → ...
E-9
4
6
MENU
5
8
9
11
SELECT
13
ON
OFF
POWER
RGB
VIDEO
7
10
VIEWER
LASER
AUTO ADJ.
12
14
EN
TE
CAN
R
CE
L
16
PJ
21
17
20
23
24
25
ASPECT
FREEZE 3D REFORM
HELP
POINTER PIC-MUTE
VOLUME MAGNIFY
15
SLIDE
18
19
22
27
ZOOM
26
FOCUS
FOLDER
SLIDE
LIST
28
29
22. PICTURE MUTE Button
This button turns off the image and sound for a short period of time.
Press again to restore the image and sound.
NOTE: When the menu is displayed, a press of this button mutes an image
and sound without turning off the menu.
23. VOLUME (+)(–) Button
Press (+) to increase the volume and (–) to decrease it.
24. MAGNIFY (+)(–) Button
Use this button to adjust the image size up to 400%. When the pointer
is displayed, the image is magnified about the center of the pointer.
When the image is magnified, the pointer is changed to the magnifying icon.
When the pointer is not displayed, the image is magnified about the
center of the screen. See page E-25.
25. ZOOM (+)(–) Button
Zoom the lens in and out.
26. FOCUS (+)(–) Button
Adjust the lens focus.
27. SLIDE (+)(–) Button
Press (+) to select the next folder or slide and (–) to select the previous folder or slide. See page E-29.
28. FOLDER LIST Button
Press this button to select Viewer source to display a list of folders
included in a PC card. See page E-29.
29. SLIDE LIST Button
Press this button to select Viewer source to display a list of slides
included in a PC card. See page E-29.
NOTE: The default is the Computer mode, which allows you to use the SELECT,
CANCEL, and ENTER buttons as your computer mouse. When the POWER ON/
OFF, MENU, ASPECT, 3D REFORM, HELP, POINTER, MAGNIFY, VIEWER, FOLDER
LIST, or SLIDE LIST button is pressed, the PJ button lights red to indicate that
you are in the Projector mode. If no buttons are pressed within 60 seconds, the
light goes out and the Projector mode is canceled.
E-10
Battery Installation
Remote Control Precautions
1. Press firmly and slide the battery cover off.
• Handle the remote control carefully.
• If the remote control gets wet, wipe it dry immediately.
• Avoid excessive heat and humidity.
• If you will not be using the remote control for a long time, remove the
batteries.
• Do not place the batteries upside down.
• Do not use new and old batteries together, or use different types of
batteries together
2. Remove both old batteries and install new ones (AA). Ensure that
you have the batteries' polarity (+/-) aligned correctly.
Operating Range for Wireless Remote Control
Remote sensor on the
projector cabinet
7m/22 feet
3. Slip the cover back over the batteries until it snaps into place. Do not
mix different types of batteries or new and old batteries.
7m/22 feet
Remote control
Remote sensor on the
projector cabinet
Note on Remote Control Operation:
If you press and hold the SELECT button while installing new
batteries, the remote control may fail to work properly.
Should this happen, remove the batteries and then install them again
without touching the SELECT button.
• The infrared signal operates by line-of-sight up to a distance of about
22 feet/7 m and within a 60-degree angle of the remote sensor on the
projector cabinet.
• The projector will not respond if there are objects between the remote control and the sensor, or if strong light falls on the sensor.
Weak batteries will also prevent the remote control from properly
operating the projector.
Using the Remote Control in Wired Operation
Connect one end of the supplied remote cable to the REMOTE mini
jack and the other end to the remote jack on the remote control.
REMOTE
OFF
ON
POWER
VIDEO
RGB
AUTO ADJ.
ASPECT
HELP
LASER
FREEZE 3D REFORM
POINTER PIC-MUTE
VOLUME MAGNIFY
ZOOM
VIEWER
FOCUS
SLIDE
FOLDER
SLIDE
LIST
E-11
INSTALLATION AND CONNECTIONS
This section describes how to set up your projector and how to connect video and audio sources.
Your projector is simple to set up and use.
But before you get started, you must first:
1
z Set up a screen and the projector.
x Connect your computer or video equipment to the projector. See page
E-14 – 17.
c Connect the supplied power cable. See
page E-17.
2
NOTE: Ensure that the power cable and any
other cables are disconnected before moving
the projector. When moving the projector or
when it is not in use, cover the lens with the
lens cap.
To the wall outlet.
3
Setting Up the Screen and the Projector
Selecting a Location
The further your projector is from the screen or wall, the larger the image. The minimum size the image can be is approximately 25" (0.64 m)
measured diagonally when the projector is roughly 39.4 inches (1.0 m) from the wall or screen. The largest the image can be is 500" (12.7 m) when
the projector is about 614.2 inches (15.6 m) from the wall or screen. Use the drawing below as a guide.
Screen Size
1.
6
10
.
8.
1
7.
)
m
t:
ni
(U
is
ta
n
ce
E-12
D
WARNING: To avoid premature lamp failure, do not tilt the front of the
projector up or down by more than 15° from level.
5
4
6.
5.
3
3
4.
3.
5
2.
8
1
2.
1.
4
1.
1
0
Scr
609 een s
.6(W
iz
)X4 e (Un
57.2
i
(H) t: cm
487
/24
0(W /inch)
.7(W
)X1
)X3
80(
65.8
H)
406
(
H)/1
.4(W
92(
)X3
W
)X1
04.8
44(
(H)
365
H)
/16
.8(W
300
0(W
)X2
)X1
"
74.3
20(
H)
(H)
/14
4(W
2
4
304
0"
)X1
.8(W
08(
H)
)X2
28.6
200
(H)
"
/12
0(W
243
)X9
180
0(H
.8(W
)
"
)X1
82.9
(H)
203
/96
.2(W
(W)
X72
)X1
150
(H)
52.4
"
(H)
/
80(
162
W
.6(W
)X6
0(H
)X1
)
21.9
(H)
120
/64
121
"
(W)
.9(W
X
48(
)X9
H
1.4(
)
1
00"
H)/4
81.3
8(W
(W)
)X3
X61
6(H
.
0
)
61.0
80"
(H)
/32
(W)
(W)
X45
X24
.7(H
TEL
(
E: 5
H
)
)
/24
60"
0.8(
(W)
W)X
X18
38.1
(H)
(H)/
20(W
40"
)X1
30
Len 5(H)
sc
25" "
ent
er
Throw Distance and Screen Size
The following shows the proper relative positions of the projector and screen. Refer to the table to determine the position of installation.
Distance Chart
Screen Width
Screen Diagonal
Screen Height
Screen center
(B)
Screen Bottom
Lens Center
Throw Angle (움)
Throw Distance (C)
B = Vertical distance between lens center and screen center
C = Throw distance
α = Throw angle
NOTE: Distances may vary +/-5%.
WARNING
* Installing your projector on the ceiling must be done by a qualified technician. Contact your NEC dealer for more information.
* Do not attempt to install the projector yourself.
• To avoid premature lamp failure, do not tilt the front of the projector
up or down by more than 15° from level.
Diagonal
inch
25
30
40
60
67
72
80
84
90
100
120
150
180
200
210
240
261
270
300
350
400
450
500
Screen Size
Width
inch
20
24
32
48
54
58
64
67
72
80
96
120
144
160
168
192
209
216
240
280
320
360
400
Height
inch
15
18
24
36
40
43
48
50
54
60
72
90
108
120
126
144
157
162
180
210
240
270
300
B
Diagonal
mm
635
762
1016
1524
1702
1829
2032
2134
2286
2540
3048
3810
4572
5080
5334
6096
6629
6858
7620
8890
10160
11430
12700
Screen Size
Width
mm
508
610
813
1219
1361
1463
1626
1707
1829
2032
2438
3048
3658
4064
4267
4877
5304
5486
6096
7112
8128
9144
10160
Height
mm
381
457
610
914
1021
1097
1219
1280
1372
1524
1829
2286
2743
3048
3200
3658
3978
4115
4572
5334
6096
6858
7620
inch
8.0
9.0
12.0
18.0
20.0
22.0
24.0
25.0
27.0
30.0
36.0
45.0
54.0
60.0
63.0
72.0
78.0
81.0
90.0
105.0
120.0
135.0
150.0
B
mm
191
229
305
457
511
549
610
640
686
762
914
1143
1372
1524
1600
1829
1989
2057
2286
2667
3048
3429
3810
C
Wide – Tele
inch
––– - 39.6
35.1 - 47.8
47.4 - 64.4
72.1 - 97.6
80.7 - 109.2
86.9 - 117.5
96.8 - 130.8
101.7 - 137.4
109.1 - 147.4
121.4 - 164.0
146.1 - 197.2
183.1 - 246.9
220.1 - 296.7
244.8 - 329.9
257.1 - 346.5
294.1 - 396.3
320.0 - 431.1
331.1 - 446.0
368.1 - 495.8
429.8 - 578.7
491.5 - –––
553.2 - –––
614.8 - –––
α
Wide – Tele
degree
––– - 10.7
14.4 - 10.7
14.2 - 10.5
14.0 - 10.4
14.0 - 10.4
14.0 - 10.4
13.9 - 10.4
13.9 - 10.4
13.9 - 10.4
13.9 - 10.4
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.7 - 10.3
13.7 - 10.3
13.7 - 10.3
13.7 - 10.3
13.7 - –––
13.7 - –––
13.7 - –––
C
Wide – Tele
mm
––– - 1005
891 - 1215
1204 - 1636
1831 - 2479
2050 - 2774
2207 - 2985
2458 - 3322
2583 - 3490
2771 - 3743
3084 - 4165
3711 - 5007
4651 - 6272
5591 - 7536
6217 - 8379
6531 - 8800
7471 - 10064
8129 - 10949
8410 - 11328
9350 - 12593
10917 - 14700
12484 - –––
14050 - –––
15617 - –––
α
Wide – Tele
degree
––– - 10.7
14.4 - 10.7
14.2 - 10.5
14.0 - 10.4
14.0 - 10.4
14.0 - 10.4
13.9 - 10.4
13.9 - 10.4
13.9 - 10.4
13.9 - 10.4
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.7 - 10.3
13.7 - 10.3
13.7 - 10.3
13.7 - 10.3
13.7 - –––
13.7 - –––
13.7 - –––
Reflecting the Image
Using a mirror to reflect your projector's image enables you to enjoy a
much larger image. Contact your NEC dealer if you need a mirror. If
you're using a mirror and your image is inverted, use the MENU and
SELECT buttons on your projector cabinet or buttons on your remote control to correct the orientation. (See page E-44.)
• Only use your projector on a solid, level surface. If the projector falls
to the ground, you can be injured and the projector severely damaged.
• Do not use the projector where temperatures vary greatly. The projector must be used at temperatures between 32˚F (0˚C) and 95˚F
(35˚C).
• Do not expose the projector to moisture, dust, or smoke. This will
harm the screen image.
• Ensure that you have adequate ventilation around your projector so
heat can dissipate. Do not cover the vents on the side or the front of
the projector.
E-13
Making Connections
NOTE: When using with a notebook PC, be sure to connect between the projector and the notebook PC before turning on the power to the notebook PC. In most
cases signal cannot be output from RGB output unless the notebook PC is turned on after connecting with the projector.
* If the screen goes blank while using your remote control, it may be the result of the computer's screen-saver or power management software.
* If you accidentally hit the POWER button on the remote control, wait 90 seconds and then press the POWER button again to resume.
When Viewing a DVI Digital Signal*:
To project a DVI digital signal, be sure to connect the PC and the projector using a DVI-D signal cable (not supplied) before turning on your PC or
projector. Turn on the projector first and select DVI (DIGITAL) from the source menu before turning on your PC.
Failure to do so may not activate the digital output of the graphics card resulting in no picture being displayed. Should this happen, restart your PC.
Do not disconnect the DVI-D signal cable while the projector is running. If the signal cable has been disconnected and then re-connected, an image
may not be correctly displayed. Should this happen, restart your PC.
NOTE:
• Use the DVI-D cable compliant with DDWG (Digital Display Working Group) DVI (Digital Visual Interface) revision 1.0 standard. The DVI-D cable should be within
5 m (196") long.
• The DVI (DIGITAL) connector accepts VGA (640x480), SVGA (800x600), 1152x864, XGA (1024x768) and SXGA (1280x1024 @ up to 60Hz).
Connecting Your PC or Macintosh Computer
DVI IN
RGB 2 IN
RGB 1 IN
DVI-D cable (not supplied)
Audio cable (not supplied)
RGB signal cable (supplied)
To mini D-Sub 15-pin connector on the projector. It is recommended that you use a commercially available distribution
amplifier if connecting a signal
cable longer than the supplied
one.
IBM PC or Compatibles (Desktop type)
or Macintosh (Desktop type)
PHONE
NOTE: For older Macintosh,
use a commercially available
pin adapter (not supplied) to
connect to your Mac's video
port.
PHONE
IBM VGA or Compatibles (Notebook type)
or Macintosh (Notebook type)
Connecting your PC or Macintosh computer to your projector will enable you to project your computer's screen image for an impressive presentation.
To connect to a PC or Macintosh, simply:
Connecting to RGB 2 IN connectors
Use a BNC⳯5 cable to connect your PC and the RGB 2 IN connectors
on your projector.
Connecting Your PC with a DVI Connector*
1. Turn off the power to your projector and computer.
2. Use the supplied signal cable to connect your PC or Macintosh to the
projector.
Use a DVI-D signal cable (not supplied) to connect a DVI connector of
your PC to the projector.
3. Turn on the projector and the computer.
4. If the projector goes blank after a period of inactivity, it may be caused
by a screen saver installed on the computer you've connected to the
projector.
E-14
To connect SCART output (RGB)
Before connections: An exclusive SCART adapter (ADP-SC1) and a
commercially available SCART cable are required for this connection.
NOTE:
• Audio signal is not available for this connection.
• The RGB IN 2 connector does not support Plug & Play.
1. Turn off the power to the projector and your video equipment.
2. Use the NEC ADP-SC1 SCART adapter and a commercially available SCART cable to connect the RGB 1 input of your projector and
a SCART output (RGB) of your video equipment.
3. Turn on the power to the projector and your video equipment.
4. Use the RGB 1 button on the remote control to select the RGB 1
input.
5. Press the MENU button on the remote control to display the menu.
Projector
Video equipment
such as DVD player
6. From the Advanced menu, select [Projector Options] → [Setup] →
[Page 3] → [Signal Select RGB1] → [Scart].
SCART is a standard European audio-visual connector for TVs, VCRs
and DVD players. It is also referred to as Euro-connector.
RGB 1 IN
NOTE: The ADP-SC1 SCART adapter is obtainable from your dealer in Europe
Contact your dealer in Europe for more information.
To RGB IN 1
Commercially available
SCART cable
Female
ADP-SC1
Connecting an External Monitor
RGB OUT
LINE IN
PHONE
You can connect a separate, external monitor to your projector to simultaneously view on a monitor the RGB analog image you're projecting.
To do so:
1. Turn off the power to your projector, monitor and computer.
2. Use a 15-pin cable to connect your monitor to the RGB OUT (Mini DSub 15 pin) connector on your projector.
3. Turn on the projector, monitor and the computer.
NOTE:
• The RGB OUT connector outputs RGB signal during idle mode (See page E45). When the projector goes into idle mode, the image on an external monitor disappears for a moment. Note that the RGB OUT connector will not output RGB signal during Standby mode.
• When the projector is in the Idle mode, the image may not be correctly displayed while the cooling fans are running immediately after turning on or off
the power. Note that the RGB OUT connector will not output RGB signal during Standby mode.
• Daisy chain connection is not possible.
E-15
Connecting Your DVD Player
RGB 2 IN
Optional 15-pin-to-RCA
(female)⳯3 cable (ADP-CV1)
RGB 1 IN
RCA(female)-to-BNC(male)
adapter (not supplied)
Component video RCA⳯3 cable
(not supplied)
Audio Equipment
DVD player
AUDIO IN
AUDIO OUT
L
R
L
Component
Y
Cb
R
Cr
Audio cable
(not supplied)
For a DVD player without component video (Y,Cb,Cr) output, use common RCA cables (not provided) to connect a composite VIDEO output of the DVD player to the Video Input of the projector.
You can connect your projector to a DVD player with component output
or Video output. To do so, simply:
1. Turn off the power to your projector and DVD player.
3. Turn on the projector and DVD player.
2. If your DVD player has the component video (Y,Cb,Cr) output, use a
commercially available component video cable (RCAX3) and the optional 15-pin-to-RCA (female)⳯3 cable to connect your DVD player
to the RGB IN1 or IN2 connector on the projector.
NOTE: Refer to your DVD player's owner's manual for more information about
your DVD player's video output requirements,
E-16
Connecting Your VCR or Laser Disc Player
VIDEO IN
S-VIDEO IN
Video cable (not supplied)
S-video cable (not supplied)
Audio equipment
AUDIO IN
L
R
VCR/ Laser disc player
AUDIO OUT
L
R
VIDEO OUT
S-VIDEO OUT
Audio cable (not supplied)
Use common RCA cables (not provided) to connect your VCR, laser
disc player or document camera to your projector.
To make these connections, simply:
1. Turn off the power to the projector and VCR, laser disc player or
document camera.
NOTE: Refer to your VCR or laser disc player owner's manual for more information about your equipment's video output requirements.
NOTE: An image may not be displayed correctly when a Video or S-Video source
is played back in fast-forward or fast-rewind via a scan converter.
2. Connect one end of your RCA cable to the video output connector on
the back of your VCR or laser disc player, connect the other end to
the Video input on your projector. Use an audio cable (not supplied)
to connect the audio from your VCR or laser disc player to your audio
equipment (if your VCR or laser disc player has this capability). Be
careful to keep your right and left channel connections correct for
stereo sound.
3. Turn on the projector and the VCR or laser disc player.
Connecting the Supplied Power Cable
Connect the supplied power cable to the projector.
First connect the supplied power cable's three-pin plug to
the AC IN of the projector, and then connect the other
plug of the supplied power cable in the wall outlet.
1
2
REMO
TE
PC CONT
USB(MOUS
E/HUB
)
ROL
R
L/MONO
AUDIO
V
AUDIO
H
DVI IN
B/Cb
AUDIO
OUT
G/Y
AC IN
AUDIO
RGB OUT
RGB2
RGB1
IN
AUDIO
IN
R
L/MONO
AUDIO
R
L/MONO
AUDIO
VIDEO
AUDIO
S-VIDEO
E-17
IN
IN
PROJECTING AN IMAGE (BASIC OPERATION)
This section describes how to turn on the projector and to project a
picture onto the screen.
2. Press the ENTER button to execute the selection.
MENU
Turning on the Projector
NOTE:
• When plugging in or unplugging the supplied power cable, make sure that the
main power switch is pushed to the off[O] position. Failure to do so may cause
damage to the projector.
• The projector has two power switches: main power switch and POWER button
(POWER ON and OFF on the remote control)
• The projector has a feature to prevent itself from being used by unauthorized
individuals. To use this feature, register your PC card as a protect key. See
"Security" in "Projector Options" on page E-51 for more details.
Before you turn on your projector, ensure that the computer or video
source is turned on and that your lens cap is removed.
Only after you press the ON/STAND BY button on the projector cabinet
or POWER ON button on the remote control for a minimum of 2 seconds will the power indicator turn to green and the projector become
ready to use.
L
NT
E
To turn on the main power to the projector, press the Main Power switch
to the ON position ( I ).
SELECT
ER
CA
NC
E
3. The Basic menu will be displayed in the language you have selected.
To close the menu, press the CANCEL button.
MENU
E
NT
L
SELECT
Note on Startup screen (Menu Language Select screen)
When you first turn on the projector, you will get the Startup screen. This
screen gives you the opportunity to select one of the seven menu languages: English, German, French, Italian, Spanish, Swedish and Japanese.
To select a menu language, follow these steps:
1. Use the SELECT or button to select one of the seven languages
for the menu.
CA
NC
E
After this has been done, you can proceed to the advanced menu operation.
If you want, you can select the menu language later. See "Language"
on page E-43.
NOTE: To turn the projector on by plugging in the power cable, first turn on the
Main Power switch to ON and use the menu and enable the "Auto Start" feature.
(See page E-45.) Immediately after turning on the projector, screen flicker may
occur. This is not a fault. Wait 3 to 5 minutes until the lamp lighting is stabilized.
MENU
SELECT
L
When the Lamp mode is set to Eco, the Lamp indicator will light green.
If one of the following things happens, the projector will not turn on.
E
NT
ER
ER
CA
NC
E
* If the internal temperature of the projector is too high, the projector
detects abnormal high temperature. In this condition the projector
will not turn on to protect the internal system. If this happens, wait for
the projector's internal components to cool down.
* When the lamp reaches its end of usable life, the projector will not
turn on. If this happens, replace the lamp.
* If the lamp fails to light, and if the STATUS indicator flashes on and
off in a cycle of six times, wait a full minute and then turn on the
power.
E-18
Selecting a Source
Adjusting the Picture Size and Position
Selecting the computer or video source
Place your projector on a flat level surface and ensure that the projector
is square to the screen.
Using the Remote Control
Lift the front edge of the projector to center the image vertically.
ON
OFF
POWER
VIDEO
RGB
AUTO ADJ.
VIEWER
LASER
Press any one of the RGB, VIDEO or
VIEWER buttons.
ASPECT
HELP
FREEZE 3D REFORM
POINTER PIC-MUTE
VOLUME MAGNIFY
ZOOM
FOCUS
SLIDE
FOLDER
Move the projector left to center the image horizontally on the screen.
SLIDE
LIST
NOTE: If no input signal is available, the projector will display a blue background
(factory preset).
Selecting from Source List
Source List
* If the projected image does not appear square to the screen then
use the 3D Reform feature for proper adjustment. See page E-20.
Adjust the Tilt Foot
1. Lift the front edge of the projector.
Press and quickly release the SOURCE button on the projector cabinet
to display the Source list. Each time the SOURCE button is pressed, the
input source will change as follows: "RGB1", "RGB2" (computer or DVD
with component output), "Video" (VCR, document camera, or laser disc
player), S-Video", "DVI (Digital)*", "Viewer" (slides on a PC card), or
"LAN" (wired or wireless signal aired from a PC).
To display the selected source, press the ENTER button.
Detecting the Signal Automatically
Adjustable Tilt Foot Lever
Adjustable Tilt Foot Lever
Adjustable Tilt Foot
2. Push up the Adjustable Tilt Foot Levers on the right and left sides of
the projector to extend the adjustable tilt feet (maximum height).
3. Push down the Adjustable Tilt Foot Levers.
Press and hold the SOURCE button for a minimum of 1 second, the
projector will search for the next available input source. Each time you
press and hold the SOURCE button, the input source will change as
follows:
→ RGB1 → RGB2 → Video → S-Video → DVI (Digital)*→ Viewer 
If no input signal is present, the input will be skipped. When the input
source you wish to project is displayed, release the button.
Press the ENTER button.
4. Lower the front of the projector to the desired height (max. 44.5mm/
1.8”) and release the Adjustable Tilt Foot Lever to lock the Adjustable
tilt foot. There is approximately 10 degrees of up and down adjustment for the front of the projector.
WARNING: To avoid premature lamp failure, do not tilt the front of the
projector up or down by more than 15° from level.
E-19
CAUTION:
Do not use the tilt-foot for purposes other than originally intended.
Misuses such as gripping the tilt-foot or hanging on the wall can
cause damage to the projector.
Zoom
Use the ZOOM Button (+/-) to fine adjust the image size on the screen
Correcting the Horizontal and Vertical Keystone Distortion (3D Reform)
Use the 3D Reform feature to correct keystone (trapezoidal) distortion
to make the top or bottom and the left or right side of the screen longer
or shorter so that the projected image is rectangular.
In the following description, 3D Reform (Cornerstone) correction can be
done with the USB mouse or remote control, cabinet buttons.
When using the USB connected to the projector
Preparation: Connect the USB mouse to the projector. See page E-26.
1. Project an image so that the screen is smaller than the area of the
raster.
2. Pick up any one of the corners and align the corner of the screen
with the one of the image. (The drawing shows the upper right corner.)
Projected image
You can use ZOOM +/- button to enlarge or reduce an image size within
a range of +/-15%.
Focus
Use the FOCUS Button (+/-) to obtain the best focus.
Screen
3. Press the 3D REFORM button on the remote control.
The Cornerstone adjustment screen is displayed.
The Cornerstone adjustment screen will disappear when you move
the USB mouse cursor.
4. Point to one of the remaining 3 corners and left-click on it.
Left-click on the corner.
Using Auto Focus (not available on MT860)
Press and hold the AUTO ADJUST button on the cabinet or AUTO ADJ
button on the remote control for a minimum of 2 seconds. The focus
pattern will be displayed for a moment and then the best focus will be
automatically obtained.
Screen
NOTE: The Auto Functions have two options: Focus and Wall Color Correction.
When the AUTO ADJUST or AUTO ADJ button is pressed and held for a minimum of 2 seconds, either item can be executed. You can decide in advance
which item will be enabled at the time of execution.
From the Advanced menu, select [Projector Options] → [Auto Functions]. You
can turn on or off "Focus" and "Wall Color Correction". See page E-47.
NOTE: Just pressing quickly the AUTO ADJUST button on the cabinet or AUTO
ADJ button on the remote control will enable the Auto Adjust feature instead of
the Auto Focus feature.
5. Do the above step 4 for the other two corners so that the projected
area becomes smaller than the screen.
Geometric Correction Tool
If you use a special shaped screen such as a cylindrical or
spherical screen, a downloadable program, Geometric
Correction Tool is available. This program (Geometric
Correction Tool) enables the geometrical distortion correction
of an image when projected onto a special shaped screen with
a projector. Additionally, this program allows control of the
projector via a computer.
Screen
Left-click on each corner.
E-20
4. Use the SELECT button to select one icon which points in
the direction you wish to move the projected image frame.
6. To complete the procedure, right-click anywhere on the screen.
The confirmation screen is displayed.
7. Left-click on "OK".
This completes the Cornerstone adjustment.
* To return the Cornerstone adjustment to the default settings, leftclick on "Reset" in Step 7.
You can save your Cornerstone changes. The changes are saved when
you turn off the projector. To do so, select [Projector Options] → [Setup]
→ [Page 4]. Select the 3D Reform Save check box. This is not selected
at the time of shipment.
* There are limitations of shapes which can be corrected using the Cornerstone adjustment.
When adjusting the Cornerstone beyond these limits, you will get the
message "Out of adjustment range!" and no correction can be done.
Should this happen, do the Cornerstone adjustment again within the
allowable range.
* Due to limitations of accuracy within internal processes, there may be
some discrepancy of positions between the mouse cursor and corrected
shape or one corner and the other 3 corners.
Screen
5. Press the ENTER button.
6. Use the SELECT button to move the projected image frame
as shown on the example.
7. Press the ENTER button.
When using the remote control or cabinet buttons:
Screen
1. Project an image so that the screen is smaller than the area of the
raster.
2. Pick up any one of the corners and align the corner of the screen
with the one of the image.
Projected image
8. Use the SELECT button to select another icon which points
in the direction.
Screen
Screen
On the Cornerstone adjustment screen, select
“Exit” and then “OK”, or press the CANCEL button on the remote control.
(The drawing shows the upper right corner.)
The confirmation screen is displayed.
3. Press the 3D REFORM button on the remote control.
9. Press the SELECT or button to highlight the [OK] and press the
ENTER button.
The CORNERSTONE adjustment screen is displayed.
NOTE: Press the 3D REFORM button to toggle between "Cornerstone" and "Keystone."
This completes the keystone correction.
Selecting “Cancel” will return to the adjustment screen without saving
changes (Step 3).
Selecting "Reset" will return to the factory default.
Selecting "Undo" will exit without saving changes.
NOTE: To return the 3D Reform correction setting values to the factory default,
press and hold the 3D REFORM button for a minimum of 2 seconds.
E-21
NOTE: During 3D Reform adjustment, "Aspect Ratio" and "Screen" may not be
available. Should this happen, first reset the 3D Reform data and then do each
setting. Second repeat the 3D Reform adjustment. Changing Aspect Ratio and/
or Screen setting can limit 3D Reform in its adjustable range.
Turning Up or Down Volume
Sound level from the speaker and the AUDIO OUT jack (RCA) on the
projector can be adjusted.
The adjustable ranges for 3D Reform are as follows:
Horizontal ........... Max ±35° approx.
Vertical ............... Max +50°/-25° approx.
VOLUME
increase volume
* The following are conditions at the above maximum angle when all of
the following are met
• Image is projected in Wide (Zoom)
• Resolution is XGA (SVGA on MT860)
decrease volume
Higher resolution than XGA limits 3D Reform in its adjustable range.
• Menu items should be set as follows:
Aspect Ratio ............................... 4:3
Volume bar
Screen Type ................................ 4:3
• Horizontal and Vertical are adjusted separately.
A combination of both adjustments limits 3D Reform in its adjustable
range.
• When "4:3 Fill" is selected in Aspect Ratio, "Cornerstone" and "Horizontal Keystone" are not available.
Optimizing RGB Picture Automatically
Adjusting the Image Using Auto Adjust
Optimizing RGB image automatically
Press the Auto Adjust button to optimize an RGB image automatically.
Using the Laser Pointer
You can use the laser to draw your audience's attention to a red dot that
you can place on any object.
Press and hold the LASER button to activate the laser pointer.
[Poor picture]
AUTO ADJ.
[Normal picture]
OF
F
VID
EO
TO
AU
J.
AD
ON
RR
B
WE
WE
RG
PO
PO
VIE
WE
R
LA
SE
R
SEL
EC
T
PJ
PICSLID
ZOO
M
FOC
EZE
3D
TER
MUT
REF
ORM
R
POIN
NIFY
SE
FRE
P
MAG
LA
ASP
ECT
HEL
VOL
UME
E
E
US
FOLD
SLID
ER
E
LIST
Press the Auto Adjust button to fine-tune the computer image or to remove any vertical banding that might appear and to reduce video noise,
dot interference or cross talk (this is evident when part of your image
appears to be shimmering). This function adjusts the clock frequencies
that eliminate the horizontal banding in the image. This function also
adjusts the clock phase to reduce video noise, dot interference or cross
talk. (This is evident when part of your image appears to be shimmering.)
This adjustment may be necessary when you connect your computer
for the first time.
NOTE:
• Some signals may not be displayed correctly or take time.
• The Auto Adjust function does not work for component and video signal.
• If the Auto Adjust operation cannot optimize the RGB signal, try to adjust Clock
and Phase manually. See page E-39.
• Pressing and holding the AUTO ADJUST button on the cabinet or AUTO ADJ
button on the remote control for a minimum of 2 seconds will enable the Auto
Focus* and the Auto Wall Color Correction* feature instead of the Auto Adjust
feature.
E-22
CAUTION:
• Do not look into the laser pointer while it is on.
• Do not point the laser beam at a person.
Setting the function switch
There are two switches on the bottom of the battery case: an applicable
projector selector switch (1) and laser enable/disable switch (2). Check
the projector being used and decide whether to enable or disable laser,
then set these switches as necessary using the tip of a thin ball-point
pen. On this model, an applicable projector selector switch (1) is not
used.
OFF ON
Switch (2)
On:
Off:
Enabled (the laser lights when the LASER button is pressed)
[Factory default]
Disabled (the laser does not light even when the LASER button is pressed)
Disable the laser when using in an environment in which the unit is
accessible to children.
Turning off the Projector
ON
OFF
To turn off the projector:
First press the POWER (ON/STAND BY) button on the projector cabinet or the POWER OFF
button on the remote control for a minimum of
two seconds. The power indicator will glow orange. After the projector turns off, the cooling
fans keep operating for 90 seconds (Coolingoff time).
Second, turn off the Main Power switch. The
power indicator will go out. Last unplug the
power cable.
POWER
VIDEO
RGB
LASER
AUTO ADJ.
ASPECT
HELP
FREEZE 3D REFORM
POINTER PIC-MUTE
VOLUME MAGNIFY
ZOOM
VIEWER
FOCUS
SLIDE
FOLDER
SLIDE
LIST
CAUTION
Do not unplug the power cable from the
wall outlet or do not turn off the main power
under any one of the following circumstances. Doing so can cause damage to
the projector:
• While the Hour Glass icon appears.
• While the message "Please wait a moment." appears. This message will be
displayed after the projector is turned
off.
• While the cooling fans are running. (The
cooling fans continue to work for 90 seconds after the projector is turned off).
• While accessing a PC card. (The PC Card
Access indicator lights.)
E-23
CONVENIENT FEATURES
When using the USB Port
Using the Remote Mouse Function
The built-in remote mouse function enables you to operate your
computer's mouse functions from the remote control (Computer mode).
It is a great convenience for clicking through your computer-generated
presentations. To return to the projector operation mode (Projector mode),
press the PJ button (lit red).
For PC, the mouse receiver function can only be used with a Windows
98, Windows ME, Windows XP or Windows 2000 operating system.
USB port (PC)
Connecting to your computer for the remote mouse
function
If you wish to use the remote mouse function, use the supplied USB
cable to connect the USB port (PC) of the projector and the USB port
(type A) of your computer.
NOTE: Depending on the type of connection or OS installed on your computer,
you may have to restart your computer or change you computer settings.
USB port
(Type A)
NOTE: Wait at least 5 seconds after disconnecting the USB cable before reconnecting it and vice versa. The computer may not identify the built-in mouse receiver if it is repeatedly connected and disconnected in rapid intervals.
Switching operation mode between computer and projector
The three shaded buttons shown on the drawing work as a computer mouse in the Computer mode.
In the Computer mode the PJ button is not lit.
Works as a mouse for your computer.
Works as the SELECT button on the projector.
ON
ON
OFF
VIEWER
VIDEO
OFF
POWER
POWER
VIDEO
RGB
AUTO ADJ.
LASER
AUTO ADJ.
RGB
VIEWER
LASER
Works as a right-click button
for your computer.
Works as the CANCEL
button on the projector.
Lit red
Not lit
ASPECT
HELP
ZOOM
HELP
POINTER PIC-MUTE
VOLUME MAGNIFY
Works as a left-click
button for your computer.
ASPECT
FREEZE 3D REFORM
FOCUS
SLIDE
Works as the ENTER
button on the projector.
POINTER PIC-MUTE
VOLUME MAGNIFY
ZOOM
FOLDER
FREEZE 3D REFORM
FOCUS
SLIDE
FOLDER
SLIDE
SLIDE
LIST
LIST
• When the MENU button is pressed, the PJ button lights red to indicate that you are in the Projector mode, which allows the projector menu
operation using the three buttons.
• When the POINTER button is pressed, the PJ button lights red to indicate that you are in the Projector mode and that the SELECT button works as a moving button for the POINTER or magnified image.
• If no buttons are pressed within 60 seconds, the PJ button's light goes out to indicate that you are in the Computer mode. To enable the projector
menu operation again, press the PJ button to light red. To move the pointer or a magnified image again, turn off the pointer and then turn on the
pointer (press the POINTER button two times).
• When the PJ button is lit, if you want to use the mouse function immediately, press the PJ button to return to the Computer mode (not lit).
During Computer mode:
In Computer mode, by pressing the ENTER button for 2 seconds or more then releasing, the drag mode is set and the drag operation can be
performed simply by pressing the SELECT (mouse) button. To drop the item, press the ENTER (left click) button again or press the
CANCEL (right click) button.
E-24
Turning Off the Image and Sound
Enlarging and Moving a Picture
Press the Picture Mute button to turn off the image and sound for a
short period of time. Press again to restore the image and sound.
You can enlarge the area you want up to 400 percent.
To do so:
PIC-MUTE
1. Press the Pointer button to display the pointer.
POINTER
Freezing a Picture
Press the Freeze button to freeze a picture. Press again to resume
motion.
FREEZE
2. Move the pointer to the area you want to enlarge.
Using the Pointer
SELECT
You can use one of eight pointers to draw your audience's attention to
the portion of a projected image you want.
POINTER
3. Enlarge the selected area.
When the Magnify (+) button is pressed, the image is magnified. To
move the magnified image, use the SELECT button.
MAGNIFY
Press the Pointer button to display the pointer.
Press the Pointer button to display the pointer.
4. Return the image to the original size.
MAGNIFY
SELECT
Use the Select button to move
the pointer.
Use the Select button to move the pointer.
Getting the On-line Help
You get the contents about Help.
HELP
SELECT
Display Help
Exit Help
E-25
Using the USB Mouse
Using the USB HUB Function
Using the supplied USB mouse gives you a smooth operation. A commercially available USB mouse can be also used.
When using the projector with a PC via the supplied USB cable, both
the USB port(type A) on the projector can be connected to a USB-supported scanner or other USB-supported device. (USB Hub Function)
USB(MOUSE/HUB)
Example: When connecting a PC and a scanner to each USB port respectively
USB(MOUSE/HUB)
NOTE: There may be some brands of USB mouse that the projector does not
support. The scroll button on the supplied USB mouse does not work with the
projector.
USB(PC)
An example of how a scanned image is projected
1. Install the Dynamic Image Utility on your PC.
Operate the Menus using the USB mouse
Mouse Cursor
When connecting a USB mouse to the projector, you get a mouse
cursor on the screen.
Unless you use your USB mouse within 10 seconds, the mouse cursor disappears.
NOTE: The Dynamic Image Utility is contained on the supplied CD-ROM. See
the supplied NEC Software Utility Installation Guide for the installation procedure.
2. Use your scanner to scan an image.
NOTE: A scanner driver must be installed on your PC before use.
Menu Display
Clicking with a mouse button displays the menu.
Clicking displays the pull-down menu. To close the menu, click
anywhere in the background.
Adjusting and Setting Display
You can select a menu item and click with a mouse button to make
adjustments and setting.
Examples
Click (or press and hold) the mouse button or to adjust the brightness. Or click and drag the mouse button on the slide bar horizontally
to adjust it.
To save the adjustments, click
. The display is closed. If you click
anywhere in the background while displaying adjustment and setting
menu or dialog box, you will get the main menu at the clicking point.
3. Load the scanned image on your PC using the Dynamic Image Utility.
4. Transmit the scanned image from your PC to the projector via the
USB cable and project the image on the screen.
NOTE:
• The USB HUB function is effective only when “Auto” is selected in Operation
Mode Select.
• The PCs using the USB Host Controller may not be available.
• When connecting a USB hub to the USB port (type B) on the projector, be
sure to use a USB hub capable of supplying 500mA per port of downstream
current.
E-26
Changing Background Logo
You can change the default background logo using the PC Card Files
feature.
NOTE: File size must be 256KB or less. Other file formats than JPEG and BMP
are not available.
1. From the menu, select [Tools] → [PC Card Files] to display a list of all
the files stored in the PC card so that you can select a file you want to
use as a background logo.
Making Freehand Drawings on a Projected
Image (ChalkBoard)
The ChalkBoard feature allows you to write and draw messages on a
projected image.
NOTE: The ChalkBoard feature is available only when a USB mouse is used.
From the menu, select [Tools] → [ChalkBoard] to display the ChalkBoard
tool bar that contains the following icons.
Pen
Eraser
Drive
Exit
Drag
Color
2. The Logo button allows you to select a background logo from graphic
files on a PC card and change to it as the background logo.
3. Use the SELECT or button to select a JPEG or BMP file for your
background logo.
4. Use the SELECT and then button to select "Logo".
5. Press the ENTER on the remote control or the cabinet. You will get
the confirmation dialog box.
6. Select "OK" and press the ENTER button. This completes changing
a logo for the background.
Capture
Clear
Hide
Drag ............ Drags to move the tool bar by clicking on the blue part.
(for USB mouse operation only)
Pen .............. Left-click and drag to draw. Left-click [] or right-click the
pen icon to display the pen palette containing four lines of
different thickness from which you can select a line you
prefer by left-clicking.
Color ........... Selects a color. Left-click to display the color palette from
which you can select a color you prefer by left-clicking.
Capture ....... Left click to capture and save freehand drawings in the
PC card.
Eraser ......... Left-click and drag to erase part of a drawing. Left-click
[] or right-click the eraser icon to display the eraser palette containing four eraser of different thickness from which
you can select an eraser you prefer by left-clicking.
Clear ........... Left-click to clear the drawing completely from the
ChalkBoard screen.
Drive ............ Switches between PC Card slot 1 and 2.
Hide ............. Hides the tool bar by left-clicking. Right-clicking anywhere
on the screen displays the ChalkBoard tool bar again.
Exit .............. Clears the complete drawing and exits the ChalkBoard.
NOTE:
• The menu is not available while you display the ChalkBoard screen.
• Switching slides clears a drawing completely.
* Once you have changed the background from the logo to another,
you cannot return the logo to background even by using Factory Default. To do so, repeat the above steps.
E-27
USING THE VIEWER
NOTE:
• To use the Viewer, first you need to create presentation materials on your PC
using the Dynamic Image Utility 2.0 contained on the supplied Projector
User Supportware CD-ROM. For installation, see the printed Software
Utility Installation Guide. For creating presentation materials, see the Slide
show function on the on-line manual of the Dynamic Image Utility 2.0.
• Selecting Viewer sets the audio input for DVI input.
Inserting and Removing a PC Card
NOTE:
• Do not try to force the PC card into the slot.
• A dummy card is inserted into each slot at the time of shipment. First remove
the dummy cards before use.
Making the Most out of the Viewer Function
Features
You can view presentation data, capture, and play images on the projector. A PC card is used to view presentation data prepared on the
computer and to capture and play images projected with the projector.
The Viewer feature allows you to view slides stored on a PC memory
card (referred to as PC card in this manual) on the projector. Even if no
computer is available, presentations can be conducted simply with the
projector. This feature is convenient for holding presentations at meetings and in offices, as well as for playing images taken on digital cameras.
Inserting the PC Card
• Hold the PC card horizontally and insert it slowly into PC card
slot 1 or 2 with its top facing up.
•
The eject button pops out once the PC card is fully inserted.
Check that the PC card is fully inserted.
PC card (not supplied)
Easy to use
•
Presentations can be started immediately simply by inserting a
PC card (not supplied)
•
Easy slide switching
1
2
REMOTE
•
Remote control operation
•
Jumping to list of slides or any specific slide
PC CON
USB(MOU
)
SE/HUB
TROL
R
L/MONO
AUDIO
V
H
AUDIO
OUT
AC IN
RGB OUT
AUDIO
R
L/MONO
High quality images
AUDIO
VIDEO
•
IN
High resolution up to 1024 x 768 dots
•
24-bit full color playback
•
Viewing of digital camera images
Removing the PC Card
Press the eject button. The PC card pops out a little. Grasp the edges
of the PC card and pull it out.
Simple utility software (for computer)
•
Dynamic Image Utility 2.0 operable on Windows 98/Me/XP/2000
•
Slides can be created by capturing the currently displayed image
NOTE: Do not eject the PC card while its data is being accessed.
Eject button
•
Control screen for displaying lists of slides and editing
*
Microsoft, Windows and PowerPoint are registered trademarks
of Microsoft Corporation.
1
2
REMOTE
PC CON
USB(MOU
)
SE/HUB
AUDIO
TROL
R
AUDIO
L/MONO
V
H
DVI IN
AUDIO
B/Cb
OUT
G/Y
AC IN
AUDIO
RGB OUT
RGB2
IN
RGB1
IN
AUDIO
R
L/MONO
AUDIO
R
L/MONO
AUDIO
VIDEO
IN
AUDIO
S-VIDEO
IN
Direction for Inserting the PC Card
The PC card has a top and bottom and must be inserted into the PC
card slot in a specific direction. It cannot be inserted backwards or upside-down. Attempting to force it into the slot in the wrong direction may
break the internal pin and damage the card slot. Refer to the PC card's
operating instructions for the proper direction of insertion.
PC Card Type
The PC Card slot accepts PCMCIA Type II only.
E-28
Operating the Viewer Function from the
Projector (playback)
This section describes the operation for showing slides of presentation
documents created using the Viewer function with the projector. It is
also possible to make slides directly from the images projected with the
projector.
When the tool bar is not displayed:
Press the FOLDER LIST button or the SLIDE LIST button on the remote control to display folders or from a PC card in the projector's PC
Card slot.
FOLDER
Projecting slides (Viewer)
1. Insert a PC card into the PC card slot.
Insert the PC card so that the end with the insertion direction arrow
on the top goes in first.
Multi cursor (blue marks)
* Press the eject button to eject the card.
Folder
2. Select the "Viewer" from the Source Select menu.
Folder
Folder
Folder
3. Project slides.
Folder
Checking "Show Folder List", means that selecting Viewer input displays a list of the folders in the PC card and if "Auto Play" is checked the
projector automatically starts to play slides at the first slide of the folder
you have selected.
Current folder number
A tool bar will appear when you press the MENU button on the remote
control or the projector cabinet or clicking with the right button of a mouse.
Prev
Play
Jump
Drive
02 : 0001 / 0008
Current slide
number
Number of all slides in
folder
Delete
Use the SLIDE +/- button to advance to the next folder or return to the
previous folder.
Drag
Next
Stop
Select
Setup
View
SLIDE
Folder
The tool bar includes the following buttons:
Drag ............ Drags to move the tool bar. This is available for USB mouse
operation only.
Prev ............. Returns to the previous slide or folder. Or this lets you
play slides back in reverse.
Next ............. Advances to the next slide or folder. Or this lets you play
slides back.
Play ............. Plays back automatically or manually depending on the
setting on Viewer Options of the menu. This allows you to
move on to the next slide when "Manual Play" is selected.
Use the SLIDE +/- button to advance to the next slide or return to the
previous slide.
Stop ............. This allows you to stop Auto Play while you are playing
back and to resume playing from the selected slide or folder
when "Auto Play" is selected.
Jump ........... Displays a list of slides while you are playing back.
Select .......... Displays a list of folders while you are playing back.
Slide(Table) cursor
(green marks)
Slide
Slide
Slide
Slide
Slide
Slide
Slide
Slide
Drive ............ Switches between PC Card slot 1 and 2.
Setup ........... Displays the Viewer Options dialog box on Page 2 of the
Setup dialog box.
Delete .......... Deletes a captured slide(s) or all the captured slides in
the Capture - specific folder.
View ............ Hides the tool bar while you are playing back. Pressing
the MENU button or clicking with the right button of a
mouse shows it again.
NOTE: If no memory card is inserted in the PC CARD slot, there is no signal, and
a black, blue or logo background is displayed, depending on the setting.
Playback is stopped when SLIDE +/- button on the remote control or button
on the cabinet is pressed in Auto Play mode.
Up to 12 indexes can be displayed on the list of folders. The folder in the right
bottom is always a folder exclusively for captured images, but is only displayed
when images have been captured.
E-29
02 : 0004 / 0008
NOTE: You can also use the and button on the remote control to select
folders or slides.
If you use the and button on the remote control for Viewer operation, press
the PJ button to switch to the Projector mode and the PJ button lights red.
Works as the Select button on the
projector.
EN
1. Project the image you wish to store on the projector.
2. Select the "Capture" from the Tools menu.
L
SELECT
Preparations:
Insert the PC card into the card slot.
Insert the PC card so that the end with the insertion direction arrow
on the top goes in first.
* Press the eject button to eject the card.
TE
R
CA
NC
E
PJ
Lit red
3. A tool bar will appear.
Auto Play Mode
If the "Auto Play" option is selected in "Viewer Options" of the menu,
any given slide will start to play automatically.
You can also specify Auto Play Interval between 5 and 300 seconds.
Capture
Freeze
Drag
Switching to Slides Directly from Other Input Modes
Exit
Drive
With this function it is possible to switch directly to a slide when the
picture of a VCR or computer is being projected.
Example: When conducting presentations using a combination of slides
and moving pictures from a VCR, etc., it is possible to switch from a
Viewer slide to the video picture then back to the Viewer slide simply by
using the Viewer button.
NOTE: Even if you switch the current Viewer source to another source, the current slide is retained. When you return back to the Viewer, you will get the slide
that has been retained.
The PC card editing operation cannot be performed from the projector.
Do so using the Dynamic Image Utility 2.0 software.
Viewing Digital Images
Digital images can be played with the Viewer if the following conditions
are met:
• If the image can be stored on an MS-DOS format PC card
• If the image can be stored in a format supported by the Viewer. With
the Viewer, images on the card are searched for in directories and
images in JPEG or BMP format are recognized as slides. Searchable
directories are directories within two steps from the root directory,
and searchable images are images within the first 12 files in the directory. Only file and slide switching are possible.
NOTE: The maximum number of images recognized as slides within one directory is 128.
The tool bar includes the following buttons:
Drag ............ Drags to move the tool bar by clicking on the blue part (for
USB mouse operation only).
Capture ....... Captures an image and save it as a JPEG file on a PC
card.
Freeze ......... Freezes and unfreezes images.
Drive ............ Switches between PC Card slot 1 and 2.
Exit .............. Exits the Capture function. Another option to exit the Capture function is to press MENU or CANCEL button on the
remote control or projector cabinet.
NOTE:
You can compress a captured file (JPEG) using the Capture Options in the Setup
dialog. See page E-44.
Captured images with higher resolution than the projector's native resolution
cannot be displayed correctly.
• File size of the captured image varies depending on the resolution of an input
signal.
• An hourglass indicating that an image is being captured appears on the
projector's display. Do not eject the PC card or turn off the projector's power
while this icon is displayed. Doing so will damage the PC card data. If the PC
card data is damaged, use a computer to repair the data.
• Up to 12 indexes can be displayed on the list of folders. The folder in the right
bottom is always a folder exclusively for captured images, but is only displayed when images have been captured.
Storing Images Displayed on the Projector on the PC
card (Capture)
The Capture features allows you to capture an image from a source that
is currently being displayed. The image is saved as JPEG in the PC
card. When you select Capture from the menu, you will get a tool bar.
You can capture an image directly using the tool bar when the menu is
not displayed.
NOTE:
* Unless a PC card is inserted into the PC Card slot of the projector, the Capture
feature is not available.
* The "Card Error" display means that the free space of the PC card is insufficient
for saving images. Make more space available on the card by erasing unwanted images with your PC. The number of images that can be captured
depends on the size of the PC card.
* Be sure not to turn off the power or remove the PC card while capturing an
image. Doing so could cause a loss of the data in the PC card or damage to the
card itself.
E-30
Deleting Captured Images
Using the Delete button on the tool bar for Viewer can delete captured
images.
Prev
Play
Jump
Delete
Drive
Drag
Next
Stop
Select
Setup
View
To delete captured images:
1. Select Viewer and display a folder list of captured images.
2. Use
button to select the Capture folder [Cap] in the right bottom of
the screen.
3. Press the MENU button to display the tool bar.
4. Use the or button to select the Delete icon and press the ENTER button or click with a mouse button.
Using the PC Card Files Fucntion (PC Card Files)
The PC Card Files function allows you to display a list of all the files
stored in the PC card so that you can select a file you want to display.
You can also sort files by file name or date, or display the file. Although
a list of all the files in the PC card is displayed, you can view files in idx,
text, HTML, JPEG and BMP format only. Selecting BMP and JPEG files
automatically switches to the Viewer source. See also page E-37.
NOTE: This option is not available for selection unless a PC card is inserted
properly.
Selecting "Execute" displays the file you selected.
When you select a JPEG or BMP file and press the ENTER button on
the remote or the cabinet, or "Execute" on the above, you will get a
toolbar. This toolbar is used to return to the PC Card Files screen.
Close
Drag
Return
Drag ............ Drags to move the tool bar. (for USB mouse operation
only)
Return ......... Returns to the PC Card Files screen.
Close ........... Close the toolbar.
E-31
USING ON-SCREEN MENU
The default Custom Menu items are:
Basic Menu Operation
Using the Menus
NOTE: The on-screen menu may not be displayed correctly while interlaced motion video image is projected.
1. Press the MENU button on the remote control or projector cabinet to
display the Basic, Advanced or Custom Menu.
NOTE: When using a USB mouse, click the mouse button to display the menu.
For other operations, do the same way as you use your PC mouse.
2. Press the SELECT buttons on the remote control or the projector cabinet to highlight the menu for the item you want to adjust or
set.
3. Press the SELECT button or the ENTER button on the remote
control or the projector cabinet to select a submenu or item.
4. Adjust the level or turn the selected item on or off by using SELECT
or buttons on the remote control or the projector cabinet.
The on-screen slide bar will show you the amount of increase or
decrease.
5. Changes are stored until you adjust it again.
ENTER .......... Stores the setting or adjustments.
CANCEL ........ Return to the previous screen without storing settings
or adjustments.
NOTE: You can close the main and sub menus simultaneously by pressing
the PJ button on the remote control to cancel the Projector mode.
6. Repeat steps 2-5 to adjust an additional item, or press the CANCEL
button on the projector cabinet or the remote control to quit the menu
display.
Source Select (RGB 1/2, Video, S-Video, DVI(DIGITAL) (not available
on MT860), Viewer and LAN), Picture, Sound, Image Options (Aspect
Ratio), Picture Management, Projector Options (3D Reform, Menu,
Setup, Lamp Setting, Screen and LAN Mode), Tools (Sleep Timer, Capture, PC Card Files and ChalkBoard) and Help (Contents and Information).
NOTE: Once you have selected OK on the Custom Menu Edit screen, you cannot
cancel the changes on the Menu screen. However, you can reedit the menu items
over again as described in the steps above.
NOTE: If the "Advanced Menu" item has been selected on the Menu mode, you
get the "Confirmation Change Menu" upon completion of "Custom Menu" editing.
In this case, selecting "Yes" then "ENTER" will close all the menus and apply the
changes from the Advanced menu to the Custom Menu. If you select "No" then
"ENTER" functions, then all menu items will return to the Advanced menu, but
your changes will still be available within the "Custom Menu" selection. To display the previously tailored Custom Menu, select "Custom Menu" from the "Menu
Mode".
An item "To Advanced Menu" will be added to the bottom of the Custom
Menu.
Selecting this item and pressing the ENTER button will display the "Advanced Menu" features.
Customizing the Menu
The Custom menu can be customized to meet your requirements. Selecting a menu item from the "Custom Menu Edit" list, allows you to
custom tailor the menu items to your needs.
1. Select "Custom Menu Edit" to display the "Custom Menu Edit" screen.
2. Use the SELECT or buttons to highlight your selection and press
the ENTER button to place a check mark next to an option.
This action enables that feature. Press the ENTER button again to
clear the check box.
If you select an item with a solid triangle and press the ENTER
button on the remote control or the projector cabinet, you can enable
all the items within that submenu. Also you can turn on an item within
the submenu without placing a check mark on the main menu item.
NOTE: Up to 12 main menu items (within Custom Menu Edit, not including
submenu items) can be selected.
3. In order for the changes to take effect, use the SELECT or button on the remote control or the projector cabinet to highlight "OK",
then press the ENTER button. To cancel the changes, use the SELECT or buttons to highlight "Cancel" and press the ENTER
button.
To return to the factory default, select "Reset" then press the ENTER
button.
E-32
Menu tree
Advanced Menu
RGB1
Source Select
RGB2
Video
Sound
S-Video
Image Options
DVI (DIGITAL)
User1
Picture Management
Projector Options
Viewer
LAN
User2
User3
Tools
more
Entry List
Help
Factory Default
Brightness, Contrast, Color,
Hue, Sharpness
Volume, Bass, Treble
Aspect Ratio
Blanking
Position/Clock
Resolution
Overscan
Video Filter
Noise Reduction
4:3, Letterbox, Wide Screen, Crop / 4:3
Window, Letterbox, Wide Screen, 4:3 Fill
Top, Bottom, Left, Right
Horizontal, Vertical, Clock, Phase
Auto, Native
0%, 5%, 10%, 25%
Off, Less, More
Off, Low, Medium, High
Signal Type
RGB, Component
Picture Management
Presentation, sRGB, Graphic, Video,
Movie, User 1, User 2, User 3, User 4
E-33
Advanced Menu
Source Select
Sound
Image Options
Picture Management
Projector Options
Tools
Help
Factory Default
Cornerstone
Keystone
Off, User 1, User 2, User 3, User 4 (Auto Adjust Button)
3D Reform
Wall Color Correction
Menu
Setup
Lamp Setting
Screen
Auto Functions*
LAN Mode
Password
Security
Menu
Page 1
Language
Basic Menu,
Custom Menu,
Advanced Menu
Custom Menu Edit
Projector Pointer
Pointer 1-8
Menu Display Time Manual, Auto 5sec,
Auto 15sec,
Auto 45sec
Desktop Front, Ceiling Rear,
Desktop Rear, Ceiling Front
Background
Blue, Black, Logo
RGBOUT Terminal Last, RGB1, RGB2
Closed Caption
Off, Caption1-4, Text1-4
Page 2
Source Display
Message
Menu Color Select
Page 2
Viewer Options
Show Folder List
Auto Play, Manual Play, Interval
Capture Options
High Quality, Normal,
High Compression
Mouse Button
Right Hand, Left Hand
Sensitivity Fast, Medium, Slow
Operation Mode Select Auto, Projector
Signal Select
RGB/Component, RGB, Component, Scart
RGB/Component, RGB, Component, Scart
Auto, PAL-M/PAL-N/NTSC3.58, NTSC3.58,
NTSC4.43, PAL, PAL-M, PAL-N, PAL60, SECAM
Page 4
Auto Adjust, Auto Start, Power Management,
Power Off Confirmation, 3D Reform Save,
High Speed Fan Mode, Built-in Speaker, Idle Mode,
Clear Filter Usage Meter
Page 5
Remote Sensor
Front, Back, Left, Right
S-Video Mode Select Off, S2
Page 6
Communication Speed
Default Source Select
Control Panel
Key Lock
English, Deutsch,
Français, Italiano,
Español, Svenska
Menu Mode
Setup
Page 1
Orientation
Page 3
RGB1
RGB2
Video,
S-Video
Horizontal, Vertical
4800, 9600, 19200, 38400
Last, Auto, Select (RGB1, RGB2,Video,
S-Video, DVI(DIGITAL)*, Viewer, LAN)
Enable, Disable
E-34
On, Off
On, Off
Color, Monochrome
Lamp Mode
Normal, Eco
Lamp Type
Standard Lamp,
Extended Life Lamp
Advanced Menu
Source Select
Volume
Image Options
Picture Management
Projector Options
Tools
Help
Factory Default
Screen Type 4:3, 16:9 / Position
3D Reform
Wall Color Correction
Menu
Focus*
On, Off
Wall Color Correction*
On, Off
Setup
LAN Mode
Lamp Setting
Screen
IP Address
Automatic
Manual
Auto Functions*
LAN Mode
Password
IP Address,
Subnet Mask,Gateway
Projector Name
Security
DNS Configuration
Domain Name
Network Type
Mode
SSID
Channel
TX rate
Sleep Timer
Capture
PC Card Files
ChalkBoard
WEP
WEP
Key Select
Key1-4
Contents
Information
Infrastructure,
802.11 Ad Hoc, Ad Hoc
Easy Connection
1-14
Automatic, 11M, 5.5M, 2M,
1M, 1M-2M-Automatic
Disable, 64bit, 128bit
Key1-4
Mail
Alert Mail
Sender's Address
SMTP Server Name
Recipient's Address 1
Recipient's Address 2
Factory Default
All Data,
Current Signal
Recipient's Address 3
Test Mail
Status
IP Address
Subnet Mask
MAC Address
Menu
Logo
Security
E-35
Enable, Disable, Keyword,
Use Protect key, Drive, Read,
Register, Delete
Menu Elements
Highlight
Help Button
Title bar
Close Button
Tab
Radio button
OK Button
Cancel Button
Solid triangle
Check box
Slide bar
Drag
Tool bar
Menu windows or dialog boxes typically have the following elements:
Cancel button ..... Press to cancel your setting. You will return to the
previous menu.
Title bar .............. Indicates the menu title.
Close button ....... Click to close the window with saving changes. (USB
mouse only)
Highlight ............. Indicates the selected menu or item.
Solid triangle ...... Indicates further choices are available. A highlighted
triangle indicates the item is active.
Tab ..................... Indicates a group of features in a dialog box. Selecting on any tab brings its page to the front.
Radio button ....... Use this round button to select an option in a dialog
box.
Check box .......... Place a checkmark in the square box to turn the option On.
Help button ......... Indicates that help about that feature is available (USB
mouse only). Press the Help button on the remote
control to display help.
Toolbar ............... Contains several icons for specific tasks. It is also
referred to as “launcher”.
Drag ................... Point the mouse here, and click and drag to move a
toolbar.
Slide bar ............. Indicates settings or the direction of adjustment.
OK button ........... Press to confirm your setting. You will return to the
previous menu.
E-36
Entering Alphanumeric Characters by Using the Menu
Prev
Alphabet or numeric characters are used for your IP address or projector name. To enter IP Address or projector name, use the software keyboard.
For using the software keyboard, see page E-60.
Play
Delete
Stop
Select
Setup
View
Drag ............... Drags to move the tool bar. (for USB mouse operation only)
Prev ............... Returns to the previous slide or folder.
Next ............... Advances to the next slide or folder.
Play ................ Plays back automatically or manually depending on
the setting on Viewer Options of the menu. This allows you to move on to the next slide when "Manual
Play" is selected.
Stop ............... Stops Auto Play while you are playing back and to
resume playing from the selected slide or folder when
"Auto Play" is selected.
Jump .............. Displays a list of slides while you are playing back.
Select ............. Displays a list of folders while you are playing back.
Drive .............. Switches between PC Card slot 1 and 2.
Setup ............. Displays the Viewer Options dialog box on Page 2 of
the Setup dialog box.
Delete ............ Deletes a captured slide(s) or all the captured slides
in the selected folder.
View ............... Hides the tool bar while you are playing back. Clicking with the right button of a mouse shows it again.
Provides access to controls for your image. Use the
SELECT button on the projector cabinet or the remote control to highlight the menu for the item you
want to adjust.
Menu Descriptions & Functions
Source Select
RGB
Selects the computer connected to your RGB1, RGB2 or component
signal.
Drive
Drag
Next
Selecting a Source
Enables you to select a video source such as a VCR, DVD player, laser
disc player, computer or document camera depending on what is connected to your inputs. Press the SELECT button on the projector
cabinet or on your remote control to highlight the menu for the source
you want to project.
Jump
LAN
Selects a signal from a LAN card plugged into the projector's card
slot.
Entry List
NOTE: An optional component cable (Component V or ADP-CV1 cable) is
needed for a component signal.
Video
Selects what is connected to your Video input-VCR, laser disc player,
DVD player or document camera.
S-Video
Selects what is connected to your S-Video input-VCR, DVD player,
or laser disc player.
Displays the list of the entry signals. Use the SELECT buttons on
your remote control or the projector cabinet to select the signal and
press the ENTER button on the remote control or the projector cabinet to display the Entry Edit Command screen.
NOTE: A frame may freeze for a brief period of time when a video is played
back in fast-forward or fast-rewind with a Video or S-Video source.
DVI (DIGITAL)
Selects the computer connected to the DVI input connector.
Viewer
This feature enables you to make presentations using a PC card that
contains captured images and slides created with the exclusive Dynamic Image Utility 2.0 contained in the CD-ROM. See the supplied
Software Utility Installation Guide for installing the Dynamic Image
Utility 2.0. The starting screen for the Viewer varies depending on the
settings of the Setup's Page 2. See Setup on page E-44.
Using the Entry List
Making any ajustments to the current picture will automatically register its adjustments to the Entry List. The registered signal can be
loaded any time from the Entry List.
NOTE: Even if you switch the current Viewer source to another source, the
current slide is retained. When you return back to the Viewer, you will get the
slide that has been retained. A launcher will appear when you press the MENU
button.
A press of the MENU button displays the toolbar; a press of the MENU
button again displays the Menu and hereafter each press of the MENU
button switches displaying between the Menu and the toolbar.
The launcher is a tool bar including the following buttons:
E-37
NOTE: Up to 100 presets can be registered.
Entry Edit Command
Picture (not available for Viewer and LAN)
Adjusting Brightness, Contrast, Color, Hue, and Sharpness
Brightness ...... Adjusts the brightness level or the back raster intensity.
Contrast ......... Adjusts the intensity of the image according to the
incoming signal.
Color .............. Increases or decreases the color saturation level (not
valid for RGB).
You can edit signals on the Entry List.
Load ............... Enables you to select a signal from the list.
Cut ................. Enables you to remove a selected signal from the list
and place it on the "clipboard" in the projector.
Hue ................ Varies the color level from +/- green to +/-blue. The
red level is used as reference. This adjustment is only
valid for Video and Component inputs (not valid for
RGB).
Copy .............. Enables you to copy a selected signal from the list
and place it on the "clipboard" in the projector.
Sharpness ..... Controls the detail of the image for Video (Not valid
for RGB).
Store .............. Enables you to store the currently projected signal.
Paste .............. Enables you to paste the signal placed on the "clipboard" to any other line of the list. To do this, select
"Paste" and then select the line number you want to
paste to. Last press ENTER.
Edit ................ Enables you to change source names or add source
names to "More" in the Sorce Select.
Sound
Controlling Volume, Bass and Treble.
Adjusts the sound, bass and treble level of the projector speaker and
AUDIO OUT (RCA).
Source Name .. Enter a signal name. Up to 18 alphanumeric characters can be used.
Image Options
Input Terminal .. Change the input terminal. RGB1
and RGB2 are available for RGB signal; Video and S-Video are available
for composite signal.
Selecting Aspect Ratio (not available for Viewer and LAN)
Aspect Ratio allows you to select the best Aspect mode to display your
source image.
When screen size 4:3 is selected for the source, the following selections
will display:
Source List ...... Set signal selection method.
Lock ................ Set so that the selected signal cannot be deleted when "All Delete" is
executed.
4:3 .................. Standard 4:3 aspect
Letter Box ...... Reduced to display the true aspect with black borders on top and bottom
Skip ................. Set so that the selected signal will
be skipped during auto search.
Wide Screen .. Left & Right stretched with black borders on top and
bottom
When complete, select OK and press ENTER. To exit
without storing setting, select Cancel. Select "Source
Name" and press ENTER to display the Source Name
Edit window. You can change source name on this
window. Press [] to display the software keyboard,
which you can enter alphanumeric characters. See
page E-60 for the key function of the software keyboard.
Crop ............... Left & Right stretched.
Left & Right sides cut. Available for 4:3 only.
When screen size 16:9 is selected for the source, the following selections will display:
4:3 Window .... Reduced to display the true aspect with black borders on right and left
All Delete ....... This feature enables you to delete all the registered
signals in the Entry List.
Letter Box ...... Standard 16:9 aspect
Wide Screen .. Left and right stretched to display the true aspect
The following buttons are not available for the currently projecting
signals:
4:3 Fill ............ Stretched to display in 16:9 aspect ratio
1) The Cut and Paste buttons on the Entry Edit Command screen
2) The Input Terminal button on the Entry Edit screen
NOTE: You can adjust image positions vertically for source with black borders.
See page E-47 for setting image positions.
Copyright
Please note that using this projector for the purpose of commercial gain or the
attraction of public attention in a venue such as a coffee shop or hotel and employing compression or expansion of the screen image with a "Aspect Ratio" or
"Screen" setting may raise concern about the infringement of copyrights which
are protected by copyright law.
NOTE: During 3D Reform adjustment, "Aspect Ratio" may not be available.
Should this happen, first reset the 3D Reform data and then do setting again.
Second repeat the 3D Reform adjustment.
Changing the aspect ratio can limit 3D Reform in its adjustable range.
Input
Signal
Screen
Type
4:3 Screen
16:9 Screen
E-38
4:3 Window
4:3
Letterbox
4:3
Letterbox
4:3 Fill
Letterbox
Squeeze
Wide Screen
Crop
Wide Screen
Masking Unwanted Area (Blanking)
This feature allows you to mask any unwanted area of the screen
image.
Adjust the Top, Bottom, Left or Right blanking with the SELECT or
button.
Adjusting Position and Clock
This allows you to manually adjust the image horizontally and vertically, and adjust Clock and Phase.
Selecting Noise Reduction Level (not available for RGB, Viewer and LAN)
Select one of the three levels for reducing video noise: Low, Medium
or High.
NOTE: The lower the Noise Reduction level, the better the image quality by
way of higher video bandwidth.
Signal Type
Select either the RGB signal type or the Component signal type.
Horizontal/Vertical Position:
Adjusts the image location horizontally and vertically using the SELECT and buttons. This adjustment is made automatically when
the Auto Adjust is turned on. See "Auto Adjust" on page E-45 for
turning on or off the Auto Adjust feature.
Clock .............. Use this item to fine tune the computer image or to
remove any vertical banding that might appear. This
function adjusts the clock frequencies that eliminate
the horizontal banding in the image.
Press the SELECT and buttons until the banding disappears. This adjustment may be necessary
when you connect your computer for the first time.
This adjustment is made automatically when the Auto
Adjust is turned on.
Phase ............ Use this item to adjust the clock phase or to reduce
video noise, dot interference or cross talk. (This is
evident when part of your image appears to be shimmering.) Use the SELECT and buttons to adjust
the image.
Use "Phase" only after the "Clock" is complete. This
adjustment is made automatically when the Auto Adjust is turned on.
Selecting Resolution
This allows you to activate or deactivate the Advanced AccuBlend
feature.
RGB ............... RGB signal
Component .... Component signals such as Y/Cb/Cr, Y/Pb/Pr
NOTE: This feature is available on RGB 1 and 2 only. If you do not get a better
picture even when you set "Signal Select" to "Component" in Setup, set this to
"Component".
Picture Management
This option allows you to adjust neutral tint for yellow, cyan or magenta.
There are 5 factory presets optimized for various types of images, or
you can set 4 user adjustable settings.
Presentation .. Recommended for making a presentation using a
PowerPoint file
Auto ............... Turns on the Advanced AccuBlend feature. The projector automatically reduces or enlarges the current
image to fit the full screen.
Native ............. Turns off the Advanced AccuBlend feature. The projector displays the current image in its true resolution.
See "Auto Adjust" on page E-45 for turning on or off
the Auto Adjust feature.
sRGB ............. Standard color values
Graphic .......... Recommended for graphics
Video ............. Recommended for regular picture such as TV program
Movie ............. Recommended for movie
User 1-4 ......... User adjustable
NOTE:
* When "Resolution" is set to "Native", "3D Reform", "Aspect Ratio", "Screen"
and "Overscan" are not available.
* While you are displaying an image with higher resolution than the projector's
native resolution, “Resolution” is not available.
NOTE: When "sRGB", "Graphic", "Video" or "Movie" is selected, the brightness
decreases slightly when compared to "Presentation". This is not a malfunction.
User Adjust (when using User 1 to 4)
Selecting Overscan Percentage
Select overscan percentage (0%, 5%, 10% and 25%) for signal.
NOTE: When "Resolution" is set to "Native", this feature is not available, and
the stored settings and adjustments are invalid.
NOTE: When "4:3 Fill" or "Crop" is selected in "Aspect Ratio", this feature is not
available.
Selecting Video Filter Level (not available for Video, Viewer and LAN)
This function reduces video noise.
Off .................. The filter is removed.
Less ............... The low-pass filter is applied partially.
More .............. The low-pass filter is applied fully.
When selecting one of four user adjustable presettings (User 1 through
4), the submenu will be displayed.
You can customize each gamma or color. To do so, first select [Setting] and press the ENTER button, and then proceed the following
steps.
E-39
Selecting Gamma Correction Mode
Use the or buttons to choose one mode from three options.
Each mode is recommended for :
Projector Options
Using 3D Reform
This feature corrects trapezoidal distortion so that the projected image is rectangular.
Two options are available for correcting procedures.
You can save adjustment settings by using the 3D Reform Save option on Setup (See page E-45).
Dynamic ......... For true color reproduction of natural tones
Natural ........... Normal settings
Black Detail .... For dark portions of a picture
Cornerstone
See page E-21
Selecting Color Correction
Adjusts red, green, blue, yellow, magenta, cyan and color gain each
independently to correct the tint on whole screen.
Adjusting Color Temperature and White Balance
This feature adjusts the color temperature using the slide bar.
Checking "Color Temperature" enables the color temperature slide
bar and disables the “White Balance” button.
Clear “Color Temperature” and press the White Balance button to
access the Contrast/Brightness adjustment for each R, G, and B.
NOTE: "Color Temperature" and "White Balance" are a trade-off.
The White Balance is not available for Viewer and LAN.
Keystone
Selecting Base Setting
This feature allows you to use color correction or gamma values as
reference data to optimize for various types of images. You can select
one of the following five settings.
• Presentation
• Video
• sRGB
• Movie
• Graphic
1. Press the SELECT button to adjust the horizontal keystone.
2. Press the SELECT button to select "Vertical".
3. Press the SELECT button to adjust the vertical keystone.
4. After completing, press the ENTER button. This will return to the menu
screen.
* When "Resolution" is set to "Native", "Cornerstone" and "Keystone"
are not available.
E-40
2. Highlight "Automatic".
Using Adapting Color Correction [Wall Color Correction]
This function allows for correcting the color of the projected images on
textured walls using the image sensor on the projector. There are two
ways for color correction: Automatic and Manual. Automatic correction
affects all colors; Manual correction allows you to correct each color R,
G, B, and W respectively.
Off .................. Disables this function
User 1 to 4 ..... Executes correction. Four settings can be saved.
User 4 (“AutoAdjustButton” not available on MT860)
stores settings when the Auto Function is executed
by pressing and holding the AUTO ADJUST button
or AUTO ADJ. button for a minimum of 2 seconds.
Info box .......... Displays "Automatic" or "Manual". This is the option
you have set for User 1 – 4 setting.
NOTE: Correction may not be possible depending on ambient room lighting,
walls with a texture that is glossy or with certain patterns, or walls that are the
color black or primary deep colors.
If you try to correct beyond the limit, an error message "Out of correction range!"
will be displayed. This message means that you will not be able to correct the
color due to the above reasons.
Also, When the image sensor fails to pick up the image of a wall color during
Auto Wall Color Correction, an error message "Failed to execute Auto Wall Color
Correction" will be displayed. This message means that there may be an obstacle
between the wall and the image sensor on the projector, or the image sensor
may not work because of too much ambient light. Make corrections to what
seems to be the problem and try again.
Automatic Wall Color Correction (not available on MT860)
1. Choose a selection from User 1 – 4. Highlight "Setting" and press the
ENTER button.
3. Use the SELECT button to highlight "Execute" and then press the
ENTER button.
The Auto Wall Color Correction will be executed.
NOTE: *When Auto Wall Color Correction is enabled in the Auto Functions menu,
Wall Color Correction can be executed by pressing and holding the AUTO ADJUST or AUTO ADJ button for a minimum of 2 seconds.
* In Wall Color Correction “Automatic” is not available on MT860.
Manual Wall Color Correction
Preparation: Before correcting manually, prepare a non-glossy, nontransparent, clean white paper (300 mm x 420 mm). Hereafter referred to as "the white paper for Wall Color Correction."
1. Choose a selection from User 1 – 4. Highlight "Setting" and press the
ENTER button.
The correction mode select screen is displayed.
* To read the pre-adjustment settings. Choose a selection User 1 – 4,
highlight "OK" and press the ENTER button.
2. Highlight "Manual".
3. Use the SELECT button to highlight "Execute" and then press the
ENTER button.
The Manual Wall Color Correction (Red) screen will be displayed.
The correction mode select screen will be displayed.
* To read the pre-adjustment settings. Choose a selection from User 1
– 4, highlight "OK" and press the ENTER button.
Working area
E-41
4. Place the white paper for Wall Color Correction over the working area
in the Manual Wall Color Correction (Red) screen.
Paste the white paper for Wall Color Correction loosely or get someone to hold it.
6. Use the SELECT button to move the yellow box to select a
color density.
Moving the yellow box changes the color density of the selected portion in the palette.
Move the yellow box so that a color on the white paper for Wall Color
Correction becomes close to a color of the projected image on the
wall.
Position of the white paper for
Wall Color Correction
NOTE: The size of the above Manual Wall Color Correction screen changes depending on the screen size.
Actual color of the projected
image on the wall
5. Use the SELECT or button to move the blue frame to the working area and then press the ENTER button.
A yellow box will appear in the palette.
*
To move the Manual Wall Color Correction (Red) screen, highlight "Move" and then press the ENTER button.
*
The "Slide Bar" button adjusts Hue, Saturation and Brightness.
Color of the projected image on the white
paper for Wall Color Correction
7. When you complete the correction, press the ENTER button.
The "Next" will be highlighted.
8. Press the ENTER button.
The Manual Wall Color Correction (Green) screen will be displayed.
Yellow box
Palette
9. Repeat steps 4 to 8. Adjust Red, Green, Blue and White respectively.
When you complete correcting White, the Exit Adjustment screen is
displayed.
10. Highlight the Correction Level bar and then use the SELECT or button to finely adjust.
Blue frame
11. Highlight "OK" and press the ENTER button.
E-42
Menu
Allows you to set preferences for the on-screen menu. Press "OK" to
save your changes for all the features of Page 1 and Page 2.
[Page 2]
[Page1]
Turning On / Off Source Display [Source Display]:
This option turns on or off input name display such as RGB1/2, Video,
and No Input to be displayed in the top right corner of the screen.
Selecting Menu Language [Language]:
You can choose one of seven languages for on-screen instructions.
The options are: English, German, French, Italian, Spanish, Swedish
and Japanese.
Selecting Menu Mode [Menu Mode]:
This feature allows you to select 3 menu modes: Advanced Menu,
Custom Menu and Basic Menu.
Turning On / Off Message [Message]:
This option turns on and off messages for lamp life warning, 3-minute
before power off time, “Please clean filter” and “Please wait a moment”.
Selecting Menu Color [Menu Color Select]:
You can choose between two color modes for menu color: color and
monochrome.
Advanced Menu ............ This is the menu that contains all the available menus and commands.
Basic Menu ................... This is the basic menu that contains minimum essentials of menus and commands.
Custom Menu ............... This is the menu that you can customize using the Custom Menu Edit to fit your needs.
Customizing the Menu:
See page E-32 for instructions about how to customize the Menu.
Selecting Projecting Pointer Icon [Projector Pointer]:
This enables you to select from eight different Pointer icons for the
"Pointer" button on your remote control.
After moving your Pointer icon to the area you want on the screen,
press the Magnify button on the remote control to enlarge the selected area on the screen. See page E-25 for more details.
NOTE: There may be cases where the Pointer function is not available (ex. a
non-interlace signal at 15kHz such as video game.)
Selecting Menu Display Time:
This option allows you to select how long the projector waits after the
last touch of a button to turn off the menu.
The preset choices are "Manual", "Auto 5 sec", "Auto 15 sec", and
"Auto 45 sec". The "Auto 45 sec" is the factory preset.
Manual ........... The menu can be turned off manually.
Auto 5 sec ...... The menu will automatically be turned off in 5 seconds if no buttons are pressed within 5 seconds.
Auto 15 sec .... The menu will automatically be turned off in 15 seconds if no buttons are pressed within 15 seconds.
Auto 45 sec .... The menu will automatically be turned off in 45 seconds if no buttons are pressed within 45 seconds.
E-43
Setup
Enables you to set operating options.
Press "OK" to save your changes for all the features of Page1, Page2,
Page3, Page 4, Page 5 and Page 6.
[Page 2]
[Page 1]
Selecting Projector Orientation [Orientation]:
This reorients your image for your type of projection. The options are:
desktop front projection, ceiling rear projection, desktop rear projection, and ceiling front projection.
Selecting a Color or Logo for Background [Background]:
Use this feature to display a blue/ black screen or logo when no signal is available. The default background is “Blue”. You can change the
logo screen using the PC Card Files feature. See pages E-27 and
52.
Setting RGB 1 or 2 for RGB OUT [RGBOUT Terminal]:
This option allows you to determine which RGB source is output from
the RGBOUT connector during Idle mode.
Last ................ The signal from the last RGB input will be output to
the RGBOUT connector.
RGB 1 ............ The signal from RGB1 IN will be output to the
RGBOUT connector.
Setting Viewer Options [Viewer Options]
Show Folder List:
If this option is checked, when the Viewer source is selected on the
projector, the folder lists will be displayed and allows you to select the
presentation from a PC card.
Auto Play:
If this option is checked, when the Viewer source is selected on the
projector any given slide will start to play automatically.
Auto Play Interval:
You can specify interval time between 5 and 300 seconds.
NOTE: The Auto Play Interval time set on “Slide Show Settings” of the Dynamic Image Utility 2.0 overrides the one set here.
Manual Play:
Views a slide manually when the Viewer source is selected.
Selecting Capture Options [Capture Option]: (available for JPEG only)
These options are used for the Capture function that you can select
from Tools. You have three options for JPEG compression quality:
High quality, Normal and High Compression.
High Quality .................. Gives quality of JPEG a priority.
RGB 2 ............ The signal from RGB2 IN will be output to the
RGBOUT connector.
Normal .......................... Gives normal JPEG quality.
High Compression ........ Gives compression a priority.
NOTE: The AUDIO OUT mini jack will not output sound during the Idle mode.
Setting Closed Caption:
This option sets several closed caption modes that allows text to be
superimposed on the projected image.
Setting Mouse Button and Sensitivity [Mouse]:
This option lets you to change your USB mouse settings. The mouse
settings feature is available for USB mouse only. Choose the settings
you want:
CAPTION 1-4 Text is superimposed.
Mouse Button ............... "Right Hand" or "Left Hand"
TEXT 1-4 ....... Text is displayed in full screen.
Mouse Sensitivity .......... "Fast", "Medium" or "Slow"
OFF ............... This exits the closed caption mode.
Selecting Operation Mode [Operation Mode Select]
Set the operation mode of the USB mouse connected to the USB
port (MOUSE/HUB) on the projector
Auto ............... Depending on connection of the USB port (PC) on
the projector and a USB port (type A) on your PC,
the USB mouse is operated in the following way:
* When connecting the projector to your PC
The USB mouse connected to the projector can
be used as a PC mouse.
* When not connecting the projector to your PC
The USB mouse connected to the projector can
perform menu operation of the projector.
Projector ........ The USB mouse connected to the projector can perform menu operation of the projector.
E-44
[Page 3]
Enabling Auto Start [Auto Start]:
Turns the projector on automatically when the power cable is inserted
into an active power outlet and the main power switch is turned on.
This eliminates the need to always use the "Power" button on the
remote control or projector cabinet.
Enabling Power Management [Power Management]:
When this option is on and there is no input for five minutes or more,
the projector will automatically turn itself off.
Enabling Power Off Confirmation [Power Off Confirmation]:
This option determines whether a confirmation dialog for turning off
the projector will appear or not.
NOTE: When the confirmation message is displayed, you must be in the Projector mode to operate your projector using the remote control. If not, press
the PJ button on the remote control to change your projector to the Projector
mode. The button lights to indicate that you are in the Projector mode.
Selecting Signal Format [Signal Select]
RGB1/2:
Allows you to choose "RGB" for an RGB source such as a computer,
or "Component" for a component video source such as a DVD player.
Normally select "RGB/Component" and the projector automatically
detects an either incoming signal. However there may be some component signals that the projector is unable to detect. If this is the
case, select "Component". Select "Scart" in RGB 1 or 2 for the European Scart.
VIDEO and S-VIDEO:
This feature enables you to select composite video standards manually. Normally select "Auto". Select the video standard from the pulldown menu. This must be done for Video and S-Video separately.
[Page 4]
Enabling Horizontal and Vertical Keystone Correction Save
[3D Reform Save]:
This option enables you to save your current 3D Reform settings.
Saving your change once affects all sources. The changes are saved
when you turn off the projector.
Enabling High Speed Fan Mode [High Speed Fan Mode]:
This option allows you to select two modes for fan speed:high-speed
mode and normal speed mode.
When you wish to cool down the temperature inside the projector
quickly, check this box.
NOTE: Enable High Speed Fan mode if you continue to use the projector for
consecutive days.
Selecting Built-in Speakers[Built-in Speaker]:
This option allows you to mute the built-in speakers.
Enabling Idle Mode [Idle Mode]:
The projector has two standby modes: Standby and Idle.
Standby is the mode that allows you to put the projector in the standby
condition which consumes less power than the idle mode. The projector is preset for Standby at the factory.
When this check box is turned on, you allow the RGB OUT connector
to output RGB signal during Idle mode.
NOTE:
* The RGB OUT connector will not output signal during the Standby mode.
* Via the USB interface the projector can be turned on from your PC using
Dynamic Image Utility 2.0 during the Standby or Idle mode. On the LAN
connection the projector can be controlled or monitored from your PC using Dynamic Image Utility 2.0 only in the Idle mode.
* The HTTP server functions are not available during Standby mode.
Resetting the Filter Usage Hours [Clear Filter Usage Meter]:
Resets the filter usage back to zero. Pressing this button appears a
confirmation dialog box. To reset the filter usage hours, press "OK".
Enabling Auto Adjust [Auto Adjust]:
When "Auto Adjust" is set to "On", the projector automatically determines the best resolution for the current RGB input signal to project
an image using NEC's Advanced AccuBlend Intelligent Pixel Blending Technology.
The image can be automatically adjusted for position and stability;
"Horizontal Position", "Vertical Position", "Clock", "Phase", and "Resolution".
On .................. Automatically adjusts image "Horizontal Position",
"Vertical Position", "Clock", "Phase" and "Resolution".
Off .................. User can adjust the image display functions ("Horizontal Position", "Vertical Position", "Clock", "Phase"
and "Resolution") manually.
E-45
[Page 5]
[Page 6]
Remote Sensor:
This option determines which remote sensors on the projector are
enabled in wireless mode.
The options are: front, rear, right, or left. All checked boxes indicate
that they can accept the infrared signal from the supplied remote
control.
Selecting Communication Speed [Communication Speed]:
This feature sets the baud rate of the PC Control port (Mini DIN 9
Pin). It supports data rates from 4800 to 38400 bps.
The default is 38400 bps. Select the appropriate baud rate for your
equipment to be connected (depending on the equipment, a lower
baud rate may be recommended for long cable runs).
S-Video Mode Select:
This feature is used to select the S-Video signal detection mode.
This allows identifying of the S-Video signals with different aspect
ratio (16:9 and 4:3).
Selecting Default Source [Default Source Select]:
You can set the projector to default to any one of its inputs each time
the projector is turned on.
Last ................ Sets the projector to default to the previous or last
active input each time the projector is turned on.
Off .................. Does not identify any S-video signal.
Auto ............... Searches for an active source in order of RGB1 →
RGB2 → Video → S-Video → DVI(DIGITAL) (not available on MT860) → Viewer → RGB1 and displays the
first found source.
S2 .................. Identifies the 16:9 or 4:3 signal.
Select ............. Displays the selected source input every time the projector is started up. Select an input from the pull-down
menu.
Disabling the Cabinet Buttons [Control Panel Key Lock]:
This option turns on or off the Control Panel Key Lock function.
NOTE:
* This Control Panel Key Lock does not affect the remote control and the PC
Control functions.
* When the cabinet buttons are disabled, pressing and holding the CANCEL
button for about 10 seconds will change the setting to enabled.
Selecting Lamp Mode and Lamp Type [Lamp Setting]
Lamp Mode:
This feature enables you to select two brightness modes of the lamp:
Normal and Eco modes. The lamp life can be extended by using the
Eco mode.
Normal Mode . This is the default setting (100% Brightness).
Eco Mode ...... Select this mode to increase the lamp life (80% Brightness).
Lamp Type:
The lamp type you use is displayed here.
MT60LP ......... Standard life lamp
E-46
MT60LPS ....... Optional extended life lamp. When the optional extended life lamp is used, the Lamp Mode is available.
Selecting Aspect Ratio and Position for Screen [Screen]
Screen Type:
Select either 4:3 Screen or 16:9 Screen for the screen to be used.
See also "Aspect Ratio" on page E-38.
NOTE: When "Resolution" is set to "Native", this selection is inactive.
Position:
This feature adjusts the vertical position of the image when viewing
video with an aspect ratio selected.
When some aspect ratios are selected in Image Options, the image
is displayed with black borders on the top and bottom.
You can adjust the vertical position between top and bottom.
NOTE: This option is not available when "4:3" is selected in Screen Type and
"Letterbox" is selected in Aspect Ratio.
NOTE: During 3D Reform adjustment, "Screen Type" and "Screen Position"
may not be available. To make available, first reset the 3D Reform data and
then do settings again. Secondly repeat the 3D Reform adjustment. Changing
"Screen Type" and "Screen Position" can limit 3D Reform in its adjustable
range.
Selecting Auto Functions (not available on MT860)
Focus:
When Auto Focus is enabled in the Auto Functions menu, Auto Focus can be executed by pressing and holding the AUTO ADJUST or
AUTO ADJ button for a minimum of 2 seconds.
Wall Color Correction:
When Wall Color Correction is enabled in the Auto Functions menu,
Wall Color Correction can be executed by pressing and holding the
AUTO ADJUST or AUTO ADJ button for a minimum of 2 seconds.
Correction settings will be saved on "User 4 (AutoAdjustButton)".
NOTE:
1. If neither Focus or Wall Color Correction are enabled in the Auto Functions
menu when you press and hold the AUTO ADJUST or AUTO ADJ button
for a minimum of 2 seconds, the Auto Adjust function (Position/Clock/
Phase) will be performed instead of Auto Focus and Auto Wall Color Correction.
2. Due to specifications of the image sensor on the projector, Auto Functions
are effective to image sizes between 40" and 150"(diagonal). Also in some
cases Auto Functions may not work correctly depending on projection
conditions such as textured material of the screen or ambient light.
E-47
Setting LAN Mode
DNS Configuration
This feature allows you to set various setting items when the projector is
used on your network.
Consult with your network administrator about these settings.
....................... Type in the IP address of DNS server on the network
connected to the projector. 12 numeric characters are
used.
NOTE:
• A LAN card is required for LAN connection; NEC's optional wireless LAN card
is available. For more information on inserting or ejecting a LAN card, see
page E-28.
• Either PC Card Slots 1 or 2 can accept LAN card. If two LAN cards are inserted into both PC card slots, the first inserted one is effective.
Domain Name Type in domain name of the network connected to
the projector. Up to 60 alphanumeric characters can
be used.
Network Type (required for wireless only)
CAUTION: Make sure that the LAN card is removed during Standby
mode (NOT Idle mode) or with the main power off.
Failure to do so may cause damage to the data on your PC card.
Mode:
Select communication method when using wireless LAN.
Infrastructure ................ Select this option when communicating with
one or more equipment connected to the
wireless or wired LAN network via an access point.
IP Address
An IP address can be automatically assigned to this projector by your
DHCP server. If your network does not automatically assign IP address,
ask your network administrator for an address, and then register it manually.
802.11 Ad Hoc .............. Select this option when using the wireless
LAN to communicate with a computer in a
one-to-one correspondence. This is a
method that meets the IEEE802.11 wireless
standard.
Automatic ....... Automatically assigns an IP address to the projector
from a DHCP server.
Ad Hoc .......................... Select this option when using the wireless
LAN to communicate with a computer in a
one-to-one correspondence.
Manual ........... Provides a space for you to register the IP address or
subnet mask number obtained from your network administrator.
IP Address ..... Set your IP address. Press to display the software
keyboard and type in 12 numeric characters.
Subnet Mask .. Set your subnet mask number. Press
to display
the software keyboard and type in 12 numeric characters.
Projector Name
....................... Specify a unique projector name. Press
to display
the software keyboard and type in. Up to 16 alphanumeric characters can be used.
Gateway ......... Set the default gateway of the network connected to
to display the software keythe projector. Press
board and type in 12 numeric characters.
Checking this box will make the set default route valid.
When data is sent from the LAN card, the transfer
location will be searched according to the previously
set routing information; however, when the transfer
location has not been found as a result of the search,
the data will be sent to the device that holds the IP
address set here. The IP address that is set here must
be one that can be identified by a search of the routing information.
Easy Connection .......... This allows you to easily set up wireless LAN
connection. See the supplied Software Utility Installation Guide for more information.
SSID (Network name):
Enter an identifier (SSID) for wireless LAN. Communication can be
done only with equipment whose SSID matches SSID for your wireless LAN. Up to 16 alphanumeric characters can be used (Casesensitive).
NOTE: To disable SSID, select a space (null) or "ANY"(All caps).
Channel:
Set this option when selecting [802.11 Ad Hoc] or [Ad Hoc] in [Mode].
Select a channel number from the pull-down list. The channel must
match for all wireless devices communicating on your wireless LAN.
NOTE: Channels in the pull-down list are different depending on which country you live in.
TX rate:
Select a wireless transmission speed. Normally leave it as Automatic.
Try another transmission speed when the connection fails.
E-48
WEP (for Wireless only)
Mail
Select this option whether using the WEP (Wired Equivalent Privacy)
key for encryption or not. To use encryption, specify WEP key.
NOTE: To the Mail Alert feature on wireless LAN connection, select "Infrastructure" for "Mode" in "Network Type." "Test Mail" is available only when there is a
LAN card in the PC card slot of the projector.
Disable ........... Will not turn on the encryption feature. Your communications may be monitored by someone.
64bit ............... Uses 64-bit datalength for secure transmission.
128bit ............. Uses 128-bit datalength for secure transmission. This
option will increase privacy and security when compared to use of 64bit datalength encryption.
NOTE: The WEP settings must be the same as communication devices such as
PC or access point in your wireless network. When you use WEP, your image
transmission speed will slow down.
Alert Mail:
Checking this box enables Alert Mail feature.
This option notifies your computer of an error message via e-mail
when using wireless or wired LAN. The error message will be notified
when the projector lamp has reached the end of its usable life or an
error occurs in the projector.
Sample of a message sent from the projector:
The lamp is at the end of its usable life. Please replace the lamp.
Projector Name: X X X X
Lamp Hour Meter: xxxx [H]
Projector Usage: xxxxxx [H]
Key Select:
Selects one key from the four keys below when selecting [64bit] or
[128bit] in [WEP].
Sender's Address:
Specify the senders address. Use the Software keyboard. Up to 60
alphanumeric and symbols characters can be used. See "Using Software Keyboard" in Appendix for more details.
Key1-4:
Enter encryption key when selecting [64bit] or [128bit] in [WEP].
The key can also be set in hexadecimal digit.
*
Enter 0X(numeral and alphabet respectively) right in front of your
key code.
*
Hexadecimal uses 0 to 9 and A to F.
*
Up to 10 characters can be set in 64 bit and up to 26 characters
in 128 bit.
SMTP Server Name:
Type in the SMTP server name to be connected to the projector. Up
to 60 alphanumeric characters can be used.
Recipient's Address 1 to 3:
Type in your recipient's address. Up to 60 alphanumeric and symbols
characters can be used.
Test Mail:
Send a test mail to check if your settings are correct.
NOTE: If you entered an incorrect address in a test, you may not receive an
Alert mail. Should this happen, check if the Recipient's Address is correctly
set.
NOTE: Unless any one of the "Sender's Address", "SMTP Server's Name" or
"Recipient's Address 1-3" is selected, "Test Mail" is not available.
NOTE: Be sure to highlight “OK” and press the ENTER button before executing “Test Mail”.
E-49
Make sure that "" is highlighted and then press the ENTER button.
The Software keyboard appears. Use the Software keyboard to type
a password and then highlight "OK" on the “Enter the Password”
screen and press the ENTER button.
The [Confirm Password] screen will be displayed.
Status
2. Type the same password again. Highlight "OK" on the “Enter the Password” screen and press the ENTER button.
Your password will be assigned.
Delete
To delete your password:
1. Highlight [Delete] and press the ENTER button. The "Current Password" screen will be displayed.
Displays the status of the LAN settings.
IP Address ..... Indicates the IP address of the projector.
Subnet Mask .. Indicates the subnet mask of the projector.
2. Use the Software keyboard to type your password. Highlight "OK" on
the “Current Password” screen and then press the ENTER button.
MAC Address . Indicates the MAC address of the LAN card.
Setting a Password
Your password will be deleted.
A password can be set for your projector to avoid operation by an unauthorized person.
In case you forget your password, follow the steps below to delete it.
There are two password options: one for menu and the other for logo.
When a password is set, doing any one of the following four operations
will display the Password input screen.
For Menu:
* Changing the menu to Advanced
*
2. Use the Software keyboard to type "1111".
Highlight "OK" on the “Password” entry screen and then press the
ENTER button.
The "Password Warning!!" message will be displayed.
Editing the custom menu
For Logo:
* Changing the background
*
1. Select the Advanced menu from the Basic menu. The "Password"
entry screen will be displayed.
Changing the logo data in PC Card Files
Procedures for Password setting apply to both Menu and Logo.
Entry
To assign your password:
NOTE: Up to 15 alphanumeric characters can be assigned.
1. Type a password.
Highlight "Entry" and press the ENTER button.
3. Use the Software keyboard to type "3333".
Highlight "OK" on the “Password” entry screen and then press the
ENTER button.
The "Password Warning!!" message will be displayed.
4. Use the Software keyboard to type "5555".
Highlight "OK" on the “Password” entry screen and then press the
ENTER button.
The "Delete Password. Are you sure? Yes/No" dialog box will be displayed.
5. Use the SELECT or button to highlight "Yes" and press the ENTER button.
Your password will be deleted.
The "Enter the Password screen" will be displayed.
E-50
Security
The Security function enables you to protect your projector so that the
projector will not project a signal unless you enter a keyword. There is
also an option to lock the projector by using a registered PC card as a
protect key. Once you have registered your PC card as a protect key,
you are required to insert the registered PC card into the PC card slot of
the projector each time you turn on the projector. You can enable the
Security function by using a keyword only.
4. Use the SELECT button to select "Keyword" and use the software keyboard to enter a keyword.
NOTE: To use a PC card as a protect key, you must also set up a keyword.
Please make a note of your keyword.
This completes registration of your PC card.
To enable Security, use the SELECT button to select "Enable" and
use the SELECT button to select "OK" and "Security function will
be enabled. An “Are you sure?" message will appear. Use the SELECT
button and press the ENTER button.
The Security function takes effect.
To turn on the projector when Security is enabled (when using your
keyword only).
1. Press and hold the POWER button for a minimum of two seconds.
The projector will be turned on and display a message to the effect
that the projector is security-protected.
2. Select [Projector Options] → [Security] from the menu and press the
ENTER button.
The Release Code input screen will be displayed.
3. Enter your keyword in the Release Code input screen.
You can view the projected image.
Enable/Disable .............. This turns the Security function on or off.
NOTE: Do not forget your keyword. However, if you forget your keyword,
Dukane or your dealer will provide you with your Release Code.
See more information at the end of this section.
Keyword ........................ Enter an appropriate keyword when you use
the Security function.
(Up to 10 characters can be used.)
The Security function is available only when
your keyword is entered.
Use Protect key ............ Check this box to lock your projector when
using a PC card. To use a keyword without
a PC card, do not check this box.
Drive ............................. Switches between PC Card slot 1 and 2.
Read ............................. Reads data of a PC card.
Register ........................ Registers data of the PC card.
The Security function is not available unless
at least one PC card is registered. (if the
“Use Protect key” check box is selected)
To turn on the projector when Security is enabled (when using a
PC card as a protect key).
1. Insert your registered PC card into the PC card slot.
2. Press and hold the POWER button for a minimum of two seconds.
The projector will turn on and then recognize the PC card. Once the
image has been projected, it will stay on without the PC card.
• The security disable mode is maintained until the main power is turned
off (by setting the main power switch to "O" or unplugging the power
cord).
In the following cases you will be asked to check the protect key or
input the keyword:
Up to 5 PC cards can be registered.
(1) When "OK" is selected at an image for which security is set and
the power is turned off then back on
Delete ........................... Deletes data of a registered PC card.
(2) When the main power is turned off then back on while the security function is enabled
To set up a keyword to enable the Security function without using
a registered PC card.
1. Use the SELECT button to select “Keyword” and use the software keyboard to enter a keyword.
(3) When you attempt to display an image for which security is set
while the security function is enabled
• Blanks (spaces) cannot be used in the Keyword section.
To delete PC card data you registered.
NOTE: Please make a note of your keyword.
2. Use the SELECT button to select “Enable” and use the SELECT
button to select “OK”, then the Security function will be enabled.
An “Are you sure?” message will appear. Use the SELECT button and press the ENTER button.
The Security function takes effect.
To register a PC card as a protect key.
1. Use the SELECT button to select "Delete" and use the SELECT
button to select the list window.
2. Use the SELECT button to select the PC card data you wish to
delete.
3. Press the SELECT button to select "Delete" and press the ENTER
button.
The PC card data will be deleted.
1. Insert a PC card into the PC card slot of the projector.
2. Use the SELECT button to select "Read" and press the ENTER
button.
Data of the PC card will be read into the projector.
3. Use the SELECT button to select "Register" and press the ENTER button.
Downloaded data will be registered and be displayed in the list window.
E-51
If you've lost your registered PC card, proceed as follows:
NOTE: Dukane or your dealer will provide you with your Release Code in
exchange for your registered keyword and Request Code. See more information
at the end of this section.
Using ChalkBoard
The ChalkBoard feature allows you to write and draw messages on a
projected image. See page E-27
NOTE: This feature is available only when using with USB mouse. See page E26.
1. Press and hold the POWER button for a minimum of two seconds.
The projector will be turned on and display a message to the effect
that the projector is security-protected.
2. Select [Projector Options] → [Security] from the menu and press hte
ENTER button.
The Release Code input screen will be displayed as well as your
Request Code (24 alphanumeric characters).
3. Enter your Release Code in the Release Code Input screen.
* If the projector is turned on by entering the Release Code, your Security will be disabled.
NOTE:
* Some types of PC cards cannot be registered as your protect key.
* It is recommended that you register two or more PC cards in case you lose or
damage your registered PC card.
* Formatting your registered PC card will disable your protect key function.
Help
Contents
Provides an online help about how to use the menus. An underlined link
means that you can move to an adjustment item directly.
Selecting the underlined link and pressing ENTER moves to the corresponding adjustment item.
Information
Displays the status of the current signal, and the lamp and the projector
usage hours. This dialog box has three pages.
The information included are as follows:
[Page 1]
Source Name
Input Terminal
Entry No.
Horizontal Frequency
Vertical Frequency
Sync Polarity
[Page 2]
Signal Type
Video Type
Sync Type
Interlace
[Page 3]
Remaining Lamp Time (%)
Lamp Hour Meter (H)
Filter Usage (H)
Projector Usage (H)
NOTE: The progress indicator shows the percentage of remaining bulb life. The
value informs you of the amount of lamp and projector usage respectively.
Provides tools for setting sleep timer, capturing images, displaying files
or changing your background logo in a PC Card and drawing.
Remaining Lamp Time Display
When the remaining lamp time reaches 0, the Remaining Lamp Time
bar indicator changes from 0% to 100 Hours and starts counting down.
If the remaining lamp time reaches 0 hours, the projector will not turn on
regardless of whether the lamp mode is set to Normal or Eco.
NOTE: The "Capture" and "PC Card Files" features are required for a PC card.
Returning to Factory Default
Using Sleep Timer
The Factory Default feature allows you to change adjustments and setting to the factory preset for source except the following:
Tools
1. Select your desired time between 30 minutes and 16 hours: Off, 0:30,
1:00, 2:00, 4:00, 8:00, 12:00, 16:00.
2. Select “Set” and press the ENTER button on the remote control.
3. The remaining time starts counting down.
4. The projector will turn off after the countdown is complete.
NOTE:
• To cancel the preset time, set "Off" for the preset time or turn off the power.
• When the remaining time reaches 3 minutes before the projector is turned off,
the "Projector will turn off in 3 minutes" message will be displayed on the
bottom of the screen.
Using Capture
Allows you to capture an image from a source that is currently being
displayed. The image is saved as JPEG in the PC card. When you select Capture from the menu, you will get a tool bar. You can capture an
image directly using the tool bar when the menu is not displayed.
See page E-30.
Using PC Card Files
The PC Card Files feature allows you to display a list of all the files
stored in the PC card so that you can select a file you want to display.
You can also sort files by file name or date, or display the file. See page
E-31.
Changing Background Logo:
You can change the default background logo using the PC Card Files
feature.
NOTE: File size must be 256KB or less. Other file formats than JPEG and BMP
are not available. See page E-27.
E-52
All Data ......................... Reset all the adjustments and settings for
all the signals to the factory preset except
Remaining Lamp Time, Lamp Hour Meter,
Filter Usage, Projector Usage, Language,
Background, Communication Speed, LAN
Mode, Security and Password.
Including Entry List:
Also deletes all the signals in the Entry List
and returns to the factory preset.
Current Signal ............... Resets the adjustments for the current signal to the factory preset levels.
All the items in "Picture", "Sound", "Image
Options" and "Picture Management" can be
reset.
MAINTENANCE
This section describes the simple maintenance procedures you should
follow to replace the lamp and the filter, and to clean the filter, the cabinet and the lens.
4. Insert a new lamp housing until the lamp housing is plugged into the
socket.
Replacing the Lamp
After your lamp has been operating for 2000 hours (Normal mode on
the standard life lamp) or longer, the "Lamp" indicator in the cabinet will
blink red and the message will appear. Even though the lamp may still
be working, replace it as soon as possible to maintain optimal projector
performance.
CAUTION
• DO NOT TOUCH THE LAMP immediately after it has been used.
It will be extremely hot. Turn the projector off, wait 90 seconds,
turn off the main power switch, and then disconnect the power
cable. Allow at least one hour for the lamp to cool before handling.
• DO NOT REMOVE ANY SCREWS except the two lamp case
screws. You could receive an electric shock.
CAUTION: Do not use a lamp other than the replacement lamp
(Standard life lamp: 465-8805 or Extended life lamp: MT60LPS).
5. Secure it in place with the two screws.
Be sure to tighten the screws.
• The projector will turn off and go into stand by mode after 2100
hours (Normal mode on the standard life lamp) of service. If this
happens, be sure to replace the lamp. If you continue to use the
lamp after 2000 hours (Normal mode on the standard life lamp)
of use, the lamp bulb may shatter, and pieces of glass may be
scattered in the lamp housing. Do not touch them as the pieces
of glass may cause injury.
If this happens, contact your Dukane dealer for lamp replacement.
To replace the lamp:
6. Reattach the lamp cover.
NOTE: The optional lamp comes with a flat-head screwdriver.
1. Remove the lamp cover by pushing two grooves lightly with the flathead screwdriver.
7. Snap the lamp cover into place.
2. Loosen the two screws securing the lamp housing until the screwdriver goes into a freewheeling condition. The two screws are not
removable.
NOTE: Replacing a new lamp automatically clears the lamp usage hours.
3. Remove the lamp housing by pulling out the handle.
NOTE: There is an interlock on this case to prevent the risk of electrical shock.
Do not attempt to circumvent this interlock.
NOTE: The lamp housing has an EEPROM chip memorizing its amount of usage
hours. You can check the amount usage hours in Information of the menu. (The
standard lamp and the optional lamp have an EEPROM chip in it so that when
you remove it, your lamp usage hours are saved in its own memory. The projector reads the lamp usage hours from the EEPROM chip to display them in Information of the menu.)
Interlock
E-53
3. Reinstall the new filter cover.
Cleaning
Cleaning or Replacing the Filter
Catch
The air-filter sponge keeps the inside of the projector from dust or dirt
and should be cleaned after every 100 hours of operation (more often in
dusty conditions). If the filter is dirty or clogged, your projector may overheat.
CAUTION
• Turn off the power and unplug the projector before replacing
the filter.
• Only clean the outside of the filter cover with a vacuum cleaner.
• Do not attempt to operate the projector without the filter cover.
To clean the air-filter:
NOTE: Do not wash the filter with soap and water. Soap and water will damage
the filter membrane. Before replacing the filter, remove dust and dirt from the
projector cabinet. Keep out dust and during filter replacement.
NOTE: When you replace the lamp, it is also wise to replace the filter. The filter
comes in the same package with your replacement lamp.
Vacuum the filter-through the filter cover.
Cleaning the Cabinet and the Lens
To reset the filter usage time, from the menu, select [Projector Options]
→ [Setup] → [Page 4] → [Clear Filter Usage Meter] → [OK].
See also page E-45 for resetting the filter usage time.
To replace the filter (sponge):
1. Remove the filter cover by pushing up on the catch of the cover until
you feel it detach.
1. Turn off the projector before cleaning.
2. Clean the cabinet periodically with a damp cloth. If heavily soiled,
use a mild detergent. Never use strong detergents or solvents such
as alcohol or thinner.
3. Use a blower or lens paper to clean the lens, and be careful not to
scratch or mar the lens.
2. Gently peel off the filter (sponge) and replace it with the new one.
E-54
TROUBLESHOOTING
This section helps you resolve problems you may encounter while setting up or using the projector.
Power Indicator
Indicator Condition
Blinking light
Off
Green blinking
Green blinking
Orange blinking
Steady light
Projector Condition
0.5 sec ON,
0.5 sec OFF
2.5 sec ON,
0.5 sec OFF
0.5 sec ON,
0.5 sec OFF
Green
Orange
Note
–
The main power is off
The projector is getting ready Wait for a moment.
to turn on.
The projector is in Sleep mode. –
The projector is cooling down. Wait for a moment.
–
The projector is turned on.
The projector is in Standby or –
Idle.
Status Indicator
Indicator Condition
Blinking light
Off
Red blinking
Projector Condition
3 cycle (0.5 sec ON,
0.5 sec OFF)
4 cycle (0.5 sec ON,
0.5 sec OFF)
6 cycle (0.5 sec ON,
0.5 sec OFF)
7 cycles (0.5 sec ON,
0.5 sec OFF)
Steady light
Note
Normal
–
1 cycle (0.5 sec ON, Lamp cover error or lamp Replace the lamp cover or
2.5 sec OFF)
housing error
lamp housing correctly.
2 cycle (0.5 sec ON, Temperature error
The projector is overheated.
0.5 sec OFF)
Move the projector to a cooler
location.
Power error
Fan error
Power unit will not work correctly.
Fans will not work correctly.
Fails to read lamp data
Lamp fails to light. Wait a full
minute and then turn on again.
Contact your dealer.
Green blinking
Re-firing the lamp
The projector is re-firing.
Orange
Control key locked
You have pressed control
panel key when Control Key
Lock is enabled.
Green
Idle condition
–
Lamp error
Lamp Indicator
Indicator Condition
Off
Blinking light
Red
Steady light
Red
Green
Orange
Projector Condition
Normal
Lamp has reached its end of
life. Lamp replacement message will be displayed.
Lamp has been used beyond
its limit. The projector will not
turn on until the lamp is replaced.
Lamp mode is set to Eco mode
Extended life lamp is used
E-55
Note
–
Replace the lamp.
Replace the lamp.
–
–
Common Problems & Solutions
Problem
Check These Items
Does not turn on
• Check that the power cable is plugged in and that the power button on the projector cabinet or the remote
control is on. See pages E-17 and 18.
• Ensure that the lamp cover or lamp housing is installed correctly. See page E-53.
• Check to see if the projector has overheated or the lamp has reached the end of its usable life. If there is
insufficient ventilation around the projector or if the room where you’re presenting is particularly warm, move
the projector to a cooler location.
No picture
•
•
•
•
•
Image isn’t square to the
screen
• Reposition the projector to improve its angle to the screen. See page E-19.
• Use the 3DReform function to correct the trapezoid distortion. See page E-20.
Picture is blurred
• Adjust the focus. See page E-20.
• Reposition the projector to improve its angle to the screen. See page E-19.
• Ensure that the distance between the projector and screen is within the adjustment range of the lens. See page
E-12 and 13.
• Condensation may form on the lens if the projector is cold, brought into a warm place and is then turned on.
Should this happen, let the projector stand until there is no condensation on the lens.
Image is scrolling vertically, horizontally or
both
• Use menus or Source button on the remote control or the cabinet to select the source you want to input.
Remote control does
not work
•
•
•
•
Indicator is lit or blinking
• See the Status Indicator on pages E-55.
Cross color in RGB
mode
• If Auto Adjust is off, turn it on or adjust the image manually with the Position/Clock in the Image Options. See
pages E-39 and 45.
USB mouse does not
work
• Make sure that your USB mouse is properly connected to the projector.
The projector may not support some brands of a USB mouse.
Use the menu to select your source (RGB 1/2, Video, S-Video, DVI, Viewer or LAN). See page E-19.
Ensure your cables are connected properly.
Use menus to adjust the brightness and contrast. See page E-38.
Remove the lens cap.
Reset the settings or adjustments to factory preset levels using the Factory Default in the Adjustment Menu.
See page E-52.
Install new batteries. See page E-11.
Make sure there are no obstacles between you and the projector.
Stand within 22 feet (7 m) of the projector. See page E-11.
Make sure that you are in the Projector mode and the PJ button lights in red. If not, press the PJ button. See
page E-24.
When using the Viewer function
Problem
Check These Items
No picture
•
•
•
•
Part of a slide is not displayed
• While an image with over 1024⳯768 dots is projected, several lines of information will be lost. Use
the supplied software change the image to 1024⳯768 dots in size.
Contents of PC Card are damaged
• Use a computer, etc., to repair the data.
Is “Viewer” selected from the Source menu?
Is the PC card seated in the PC Crad slot completely?
Are slide data stored in the PC card?
Have the contents of the PC card been destroyed?
For more information contact your dealer.
E-56
SPECIFICATIONS
This section provides technical information about the Projector's performance
Model Number
8805
Optical
LCD Panel
MT1065: 1.0" p-Si TFT active-matrix with Micro Lens Array
Resolution
1024⳯768 pixels up to UXGA
Lens
Motorized zoom and focus:
F1.74 – 2.18 f=30.8mm – 41.6mm
275 W DC standard / 160 W DC (Optional Extended life lamp)
23,040 pixels (160 dots⳯144 lines)
25 inches – 500 inches (0.6 m – 12.7 m) diagonal
2.96 ft – 51.23 ft / 10.0 m (Tele) – 15.6 m (Wide)
Tele : 8.2° – 8.6° Wide : 9.8° – 10.5°
Lamp
Color Image Sensor
Image Size
Projection Distance
Projection Angle
Electrical
Inputs
Outputs
USB Port
Video Compatibility
Scan Rate
Video Bandwidth
Color Reproduction
Horizontal Resolution
External Control
Sync Compatibility
Built-in Speakers
Power Requirement
Input Current
Power Consumption
Mechanical
Installation
Dimensions
Net Weight
Environmental Considerations
Operational Temperatures :
Storage Temperatures :
Regulations
2 RGB (D-Sub 15 Pin/BNC⳯5), 1 DVI, 1 S-Video, 1 Video, 2 PC Card,
3 Stereo Mini Audio, 2 (L/R) RCA Audio, 1 PC Control, 1 (L/R) RCA Audio
1 RGB, 1 Stereo Mini Audio
1 A Type, 1 B Type
NTSC, NTSC4.43, PAL, PAL-60, PAL-N, PAL-M, SECAM, HDTV:1080p, 1080i, 720p, 576p, 576i, 480p, 480i
Horizontal: 15 kHz to 100 kHz (RGB: 24 kHz or over) / Vertical: 48 Hz to 120 Hz
RGB: 80 MHz (-3dB)
16.7 million colors simultaneously, Full color
NTSC / NTSC4.43/PAL/PAL-M/PAL-N/PAL60: 550 TV lines
SECAM: 350 TV lines
YCbCr: 800 TV lines
RGB: 1024 dots (H)⳯768 dots (V),
RS232, IR, USB, LAN (optional)
Separate Sync / Composite Sync / Sync on G
5W⳯2 (stereo)
100 - 120V AC / 200 - 240V AC, 50 / 60 Hz
4.0A (100 - 120V AC) / 2.0A (200 - 240V AC)
1.0W in Standby mode/390W in Lamp Normal mode/320W in Lamp Eco mode
(250W in use of the optional Extended Life lamp)
Orientation: Desktop/Front, Desktop/Rear, Ceiling/Front, Ceiling/Rear
13.2" (W)⳯4.5" (H)⳯12.7" (D)
(not including protrusions)
13.0 lbs / 5.9 kg
32° to 95°F (0° to 35°C), 20% to 80% humidity (non-condensing)
14° to 122°F (-10° to 50°C), 20% to 80% humidity (non-condensing)
UL Approved (UL 1950, CSA 950)
Meets DOC Canada Class B requirements
Meets FCC Class B requirements
Meets AS/NZS3548 Class B
Meets EMC Directive (EN55022:1998, EN55024-1998, EN61000-3-2, EN61000-3-3)
Meets Low Voltage Directive (EN60950, TUV GS Approved)
For additional information visit:
www.dukcorp.com/av
LCD panels are inherently susceptible to pixel defects.
The specifications are subject to change without notice.
E-57
APPENDIX
323(12.7")
Cabinet Dimensions
334(13.15")
Lens center
115(4.53")
Lens center
78.6(3.1")
139(5.47")
92.2(3.63")
Unit = mm (inch)
16(0.63")
Pin Assignments of D-Sub RGB Input Connector
Mini D-Sub 15 Pin Connector
5
4 3 2 1
10 9 8 7 6
15 14 13 12 11
Signal Level
Video signal : 0.7Vp-p (Analog)
Sync signal : TTL level
* RGB 1 Input only
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
RGB Signal (Analog)
YCbCr Signal
Red
Green or Sync on Green
Blue
Ground
Ground
Red Ground
Green Ground
Blue Ground
No Connection
Sync Signal Ground
SCART Sync
Bi-directional DATA (SDA)*
Horizontal Sync or Composite Sync
Vertical Sync
Data Clock*
Cr
Y
Cb
E-58
Cr Ground
Y Ground
Cb Ground
Sync
Compatible Input Signal List
Signal
#
#
#
#
#
#
##
##
##
##
##
##
##
##
##
##
##
##
##
##
##
##
##
##
##
##
##
##
##
NTSC
PAL
SECAM
VESA
IBM
MAC
MAC
MAC
VESA
VESA
IBM
VESA
IBM
VESA
IBM
IBM
VESA
VESA
VESA
VESA
VESA
MAC
VESA
VESA
VESA
MAC
VESA
VESA
VESA
MAC
SUN
SGI
VESA
VESA
MAC
HP
SUN
VESA
VESA
SXGA+
HDTV (1080p)
SDTV(576i)(625i)
SDTV(576p)(625p)
HDTV (1080i)(1125i)
HDTV (1080i)(1125i)
HDTV (720p)(750p)
SDTV (480p)(525p)
VESA
VESA
VESA
VESA
DVD YCbCr
DVD YCbCr
Resolution
( Dots )
–
–
–
640 ⳯ 480
640 ⳯ 480
640 ⳯ 480
640 ⳯ 480
640 ⳯ 480
640 ⳯ 480
640 ⳯ 480
640 ⳯ 480
640 ⳯ 480
720 ⳯ 350
720 ⳯ 400
720 ⳯ 350
720 ⳯ 400
800 ⳯ 600
800 ⳯ 600
800 ⳯ 600
800 ⳯ 600
800 ⳯ 600
832 ⳯ 624
1024 ⳯ 768
1024 ⳯ 768
1024 ⳯ 768
1024 ⳯ 768
1024 ⳯ 768
1024 ⳯ 768
1152 ⳯ 864
1152 ⳯ 870
1152 ⳯ 900
1152 ⳯ 900
1280 ⳯ 960
1280 ⳯ 1024
1280 ⳯ 1024
1280 ⳯ 1024
1280 ⳯ 1024
1280 ⳯ 1024
1280 ⳯ 1024
1400 ⳯ 1050
1920 ⳯ 1080
–
–
1920 ⳯ 1080
1920 ⳯ 1080
1280 ⳯ 720
–
1600 ⳯ 1200
1600 ⳯ 1200
1600 ⳯ 1200
1600 ⳯ 1200
–
–
Frequency H.
( kHz )
15.734
15.625
15.625
31.47
31.47
31.47
34.97
35
37.86
37.5
39.375
43.269
31.469
37.927
39.44
39.44
35.16
37.879
48.077
46.88
53.674
49.725
35.5
48.363
56.476
60.241
60.023
68.677
67.5
68.681
61.796
71.736
60
63.981
69.89
78.125
81.13
79.976
91.146
–
67.5
15.6
31.5
33.75
28.13
45
31.47
75.0
81.3
87.5
93.75
15.734
15.625
Refresh Rate
( Hz )
60
50
50
59.94
60
60
66.67
66.67
72.81
75
75
85.01
70.09
85.04
87.85
87.85
56.25
60.32
72.19
75
85.06
74.55
43 Interlaced
60
70.07
74.93
75.03
85
75
75.06
65.95
76.05
60
60.02
65.2
72.01
76.11
75.03
85.02
–
60
50
50
60 Interlace
50 Interlace
60 Progressive
59.94 Progressive
60
65
70
75
59.94 Interlaced
50 Interlaced
##: Images in above flagged with ## are compressed on the 8805.
NOTE: Some composite sync signals may not be displayed correctly.
Signals other than those specified in the table above may not be displayed correctly. If this should happen, change
the refresh rate or resolution on your PC. Refer to Display Properties help section of your PC for procedures.
UXGA (1600⳯1200) is supported for separate sync signal only.
E-59
PC Control Codes and Cable Connection
Using Software Keyboard
PC Control Codes
Function
Code Data
POWER ON
02H 00H 00H 00H 00H 02H
POWER OFF
02H 01H 00H 00H 00H 03H
INPUT SELECT RGB 1
02H 03H 00H 00H 02H 01H 01H 09H
INPUT SELECT RGB 2
02H 03H 00H 00H 02H 01H 02H 0AH
INPUT SELECT VIDEO
02H 03H 00H 00H 02H 01H 06H 0EH
INPUT SELECT S-VIDEO
02H 03H 00H 00H 02H 01H 0BH 13H
INPUT SELECT DVI (DIGITAL)* 02H 03H 00H 00H 02H 01H 1AH 22H
INPUT SELECT VIEWER
02H 03H 00H 00H 02H 01H 1FH 27H
PICTURE MUTE ON
02H 10H 00H 00H 00H 12H
PICTURE MUTE OFF
02H 11H 00H 00H 00H 13H
SOUND MUTE ON
02H 12H 00H 00H 00H 14H
SOUND MUTE OFF
02H 13H 00H 00H 00H 15H
ON SCREEN MUTE ON
02H 14H 00H 00H 00H 16H
ON SCREEN MUTE OFF
02H 15H 00H 00H 00H 17H
1 to 0 and Characters
........................... Use to type in IP address or projector name
NOTE: Contact your local dealer for a full list of PC Control Codes if needed.
SP ...................... Inserts a space
BS ...................... Deletes one character backward
........................ Returns to the previous
........................ Advances to the next
Cable Connection
OK ...................... Executes the selection
Communication Protocol
Baud rate ............................. 38400 bps
Cancel ................ Cancels the selection
Data length .......................... 8 bits
Drag bar ............. Use to move the software keyboard on the screen.
Parity .................................... No parity
MODE ................ Selects one of three modes for alphabet and special
characters.
Stop bit ................................ One bit
X on/off ................................ None
Communications procedure . Full duplex
NOTE: Depending on the equipment, a lower baud rate may be recommended
for long cable runs.
PC Control Connector (D-SUB 9P)
To TxD of PC
To RxD of PC
To GND of PC
1
2
6
3
7
4
8
5
9
To RTS of PC
To CTS of PC
NOTE: Pins 1, 4, 6 and 9 are no used.
NOTE: Jumper “Request to Send” and “Clear to Send” together on both ends of
the cable to simplify cable connection.
E-60
Power: This controls the power of the projector.
On .................. Power is switched on.
Operation Using an HTTP Browser
Off .................. Power is switched off.
Overview
The use of HTTP server functions will allow control of the projector from
a web browser without the installation of special software. Please be
sure to use “Microsoft Internet Explorer 4.x” or a higher version for the
web browser. (This device uses “JavaScript” and “Cookies” and the
browser should be set to accept these functions. The setting method
will vary depending on the version of browser. Please refer to the help
files and the other information provided in your software.)
NOTE:
* The use of HTTP server functions is not available during Standby mode.
* The display’s or button’s response can be slowed down or operation may not
be accepted depending the settings of your network. Should this happen, consult your network administrator.
* The projector may not respond if its buttons are repeatedly pressed in rapid
intervals. Should this happen, wait a moment and repeat. If you still can’t get
any response, pull out and then re-insert the LAN card.
* Do not use the HTTP Server functions and the Dynamic Image Utility included
on the supplied CD-ROM. Using both at the same time may result in a connection failure or slow response.
Access is gained to the HTTP server functions by specifying
http:// <the projector’s IP address> /index.html
in the entry column of the URL.
Volume: This controls the volume of the projector.
.................... Increments the volume adjustment value.
.................... Decrements the volume adjustment value.
Mute: This controls the mute function of the projector.
All On ............. Mutes each of the video, audio, and on-screen display functions.
All Off ............. Cancels the muting of each of the video, audio, and
on-screen display functions.
Picture On ...... Mutes the video.
Picture Off ...... Cancels the video muting.
Sound On ...... Mutes the audio.
Sound Off ...... Cancels the audio muting.
OSD On ......... Mutes the on-screen display.
OSD Off ......... Cancels the muting of the on-screen display.
Picture: Controls the video adjustment of the projector.
Brightness .. Increments the brightness adjustment value.
Brightness .. Decrements the brightness adjustment value.
Preparation Before Use
Contrast ..... Increments the contrast adjustment value.
Make network connections and set up the projector and confirm that it
is complete before engaging in browser operations. (See “Setting LAN
Mode” on page E-48.)
Operation with a browser that uses a proxy server may not be possible
depending on the type of proxy server and the setting method. Although
the type of proxy server will be a factor, it is possible that items that have
actually been set will not be displayed depending on the effectiveness
of the cache, and the contents set from the browser may not be reflected in operation. It is recommended that a proxy server not be used
unless it is unavoidable.
Handling of the Address for Operation via a Browser
Regarding the actual address that is entered for the address or entered
to the URL column when operation of the projector is via a browser, the
host name can be used as it is when the host name corresponding to
the IP address of the projector has been registered to the domain name
server by a network administrator, or the host name corresponding to
the IP address of the projector has been set in the “HOSTS” file of the
computer being used.
Contrast ..... Decrements the contrast adjustment value.
Color .......... Increments the color adjustment value.
Color .......... Decrements the color adjustment value.
Hue ............ Increments the hue adjustment value.
Hue ............ Decrements the hue adjustment value.
Sharpness . Increments the sharpness adjustment value.
Sharpness . Decrements the sharpness adjustment value.
* The functions that can be controlled will vary depending on the signal being input to the projector.
Source Select: This switches the input connector of the projector.
RGB1 ............. Switches to the RGB 1 connector.
RGB2 ............. Switches to the RGB 2 connector.
Video ............. Switches to the Video connector.
S-Video .......... Switches to the S-Video connector.
DVI(DIGITAL) . Switches to the DVI connector (not available on MT860)
Example 1: When the host name of the projector has been set to
“pj.nec.co.jp”, http://pj.nec.co.jp/index.html is specified for the address or the entry column of the URL.
Example 2: When the IP address of the projector is “192.168.73.1”,
access is gained to the HTTP server functions by specifying
http://192.168.73.1/index.html for the address or the entry column
of the URL.
Viewer ............ Switches to the Viewer.
LAN ................ Switches to a LAN signal.
Projector Status: This displays the condition of the projector.
Remaining Lamp Time .. Displays the remaining life of the lamp as a
percentage.
Structure of the HTTP Server
Lamp Hour Meter .......... Displays how many hours the lamp has been
used.
Projector Usage ............ Displays how many hours the projector has
been used.
Filter Usage .................. Displays how many hours the filter has been
used.
Error Status .................. Displays the status of errors occurring within
the projector.
Refresh ......................... Updates the display of the following conditions.
E-61
DUKANE CORPORATION
TWO-YEAR LIMITED WARRANTY
This Dukane projector is warranted to the original purchaser for a period of two (2) years from
the original purchase date – in normal operating conditions – against defects in material and
workmanship . DUKANE CORPORATION EXPRESSLY DISCLAIMS ALL OTHER
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
DURING THE WARRANTY PERIOD, DUKANE CORPORATION’S LIABILITY FOR ANY
DEFECTIVE PRODUCT (except for the lamp, which is subject to whatever warranties the
manufacturer may provide) IS LIMITED TO THE REPAIR OR REPLACEMENT OF
PRODUCT AT DUKANE CORPORATION’S OPTION. REPLACEMENT PRODUCTS MAY
BE NEW OR USED (used units will not exceed hours of defective unit). The following are not
covered by the limited warranty and Dukane Corporation shall not be liable for:
1. Any product which is not distributed in the U.S.A. or Canada by Dukane Corporation or an
authorized dealer.
2. Normal decrease in lamp light output over time.
3. Damage, deterioration or malfunction resulting from:
• Accident, misuse, abuse, neglect, improper ventilation, fire, dust, smoke, water, lighting
or other acts of nature, unauthorized product modification, or failure to follow
instructions supplied with the product (including proper maintenance of air filters).
• Repair or attempted repair by anyone other than a Dukane Corporation authorized service
center.
• Any shipment of product (claims must be presented to the carrier).
• Removal or installation of the product.
• Any other causes which do not relate to a product defect.
• Use of the product beyond normal operating conditions. Normal operating conditions are
defined as product use not in excess of 8 hours per day and 260 days per year.
4. Cartons, carry cases, shipping cases, batteries, or any accessories used in connection with the
product.
5. Service required as a result of third party components.
6. Product used as commercial rental units
Dukane corporation will pay labor and material expenses for covered items, but Dukane
Corporation will not pay for the following:
1. Removal or installation charges.
2. Cost of technical adjustment, set-up, maintenance, or adjustment of user controls.
3. Payment of shipping and related charges incurred in returning the product for warranty
repair.
Dukane Corporation disclaims all liability for incidental or consequential damage of any kind,
including all damages arising out of any interruptions in operation of the product and all damages
to software.
No person, firm, or representative is authorized to assume any obligation or to make any warranty
on behalf of the Dukane Corporation other than as stated above.
11595-B-04
Audio Visual Products
Dukane Corporation
Audio Visual Products Division
2900 Dukane Drive
St. Charles, IL 60174-3395
E-mail: [email protected]
Phone: (630) 762-4040
Orders: (800) 676-2485
Information: (800) 676-2486
Fax: (630) 584-5156
Parts & Service: (800) 676-2487
Fax: (630) 584-0984
401-8805-00
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
