PRODUCT HIGHLIGHTS
Cobalt AV brings you the newest, most innovative communication
products available, always with value and versatility in mind. Established
in 2003, as the house brand of ComtronICS Inc., Cobalt AV offers the most
complete selection of 2-way radio audio accessories and peripherals from
a single source. Advantageously located in Lexington, KY, Cobalt AV
products generally ship with quick 2-day UPS Ground delivery to much
of the eastern and central United States. We ship to Canada every day.
KLSN2 and other Surveillance Kits,
pg. 28
TTC Bone Conduction
Headset, pg. 24
Learn more about us on page 51...
product index
PAGES
2
4-9
Wireless headset intercoms from HME
10
Introduction to Cobalt Muff Headsets
11
theCobra Mic noise canceling microphone technology for extreme noise
12-13
Cobalt Signature Blue Muff Headsets
14
VH Value Headests, the new standard for value-priced muff headsets
15
BLUE-TOP will turn Cobalt headsets in wireless BT headsets
16
SPML-BLUE, our new Bluetooth wireless speaker microphone
17
BLUE-MIC, our BT surveillance kit with lapel mic and ear kit
18-19
BLUE-MOBILE, BT adapters for your vehicle or base station radios
19
BLUE-PTT, our wireless BT-PTT switch
20-21
BLUE-BT adapters for portable radios
22-23
The largest lightweight headsets selection anywhere, including for hard hat/helmet wear
24-25
TTC bone conduction headset and HSM skull mic headset for hard hat/helmets
26
TM throat mic kit
27
Add large inline TACTICAL SWITCH to many Cobalt headset models
28-31
Surveillance audio kits for portable radios
31
QD Quick Disconnect adapter system
32-35
Speaker microphones for portable radios
36-37
Listen-only ear kits
37
Ear tips for acoustic tube kits
37
Sudio connector adapters for portable radios
38-41
Cobalt fire truck headset intercoms
41
Helmet audio kits
42-43
MM, our replacement mobile radio hand microphones series
44-49
Portable radio connector guide
50-51
The ComtronICS Story, check out our capabilities
WH-300, wireless headsets
page 4
BLUE-TOP, convert headset
into BT wireless,
pg. 15
T-10 and T-20, best selection
of lightweight headsets,
pg. 22
BLUE -MOBILE,
BT adapters for vehicle
& base station radios
pg. 18
SPML-BLUE Bluetooth
Speaker Microphone
page 16
WIRELESS COMMUNICATION SPECIALISTS
A Division of ComtronICS Inc.
3
WIRELESS INTERCOM:
Crystal Clear Headset
Intercom System
Critical job communication has become lot more portable and
affordable with HME’s DX-series spread spectrum digital
wireless headset intercoms!
Now get crystal-clear digital voice “conversation”--all built into a super compact
design for easy setup and operation. Since this duplex “hot mic” technology
allows simultaneous talking and listening among users, the term “conversation”
is used instead of transmission to distinguish this from two-way radios.
DX300
The DX300 package was developed for
football coaching. It is flexible, expandable
and economical. In two-channel mode,
the user selects which channel he or she
talks on. There are two headset ports on
the compact table top base station which
has an “AA” battery backup compartment.
The DX300 system allows 3 simultaneous
wireless talkers per base in dual channel
mode (or 4 talkers in single channel mode)
with up to 15 users (listeners). By simply
adding a EB300 base expander module or
daisy-chaining two or three MB300 base
stations with a simple modular connector
cable, you can double or triple the number
of talkers or users or increase areas of
coverage. Interface with external 4-wire
systems are possible.
BP300 belt packs with choice of headset or
WH300 wireless “all-in-one” headsets may
be used. Each BP300 and WH300 come with
1 BAT41 battery pack.
cobaltav.com
1.800.264.6021
4
DX300ES
The DX300ES is our tactical wireless
headset intercom since it adds contact
closure relays allowing connection of a
portable or mobile two-way radio. This
is the only difference from the standard
DX300. The function allows a team locally
to converse privately and monitor two-way
radio dispatch traffic plus the ability to use
the “all” button on the belt pac or all-in-one
headset to “push-to-transmit” message over
the 2-way radio network. If multiple base
stations are connected, users on one base or
multiple bases can use the PTT function.
EB300
The EB300 base station expansion module
easily expands a DX300 or DX300ES
system by allowing an additional three
BP300 or WH300 talkers at the same time in
dual channel mode (or 4 additional talkers
in single channel mode). This set-up allows
up to eight workers to plug in and talk
at once, with a substantial discount over
purchasing a second MB300 or MB300ES
base station.
Fast, easy set-up
Superior sound quality
Hands-free operation
Link base stations to add talkers and users
No frequency coordination
2.4 GHz license free ISM band
EB300 base station
extender doubles the
Secure encrypted conversation
number of headsets and
Triple diversity--space, time and frequency
headset talkers which
Rugged ergonomic design
may be used.
Small, lightweight energy efficient portable units
Up to 20 hour Li-Ion battery use life per charge
Wide variety of headset choices including “all-in-one” headset
Expandable and interface-capable base models
Four talkers per base in single channel mode, three talkers per base
in dual channel mode
Perfect for many critical applications:
SWAT/SRT/bomb/hostage negotiation
Nuclear outage coordination
Film and video crews
Industrial production/maintenance
Wireless for command vehicles
Flight line
Theatrical production
Test facilities
Emergency preparedness centers
Pump/straying operations
Corrugated machinery line
Protective clothing communication
Training & Plant tours
Crane rigging
Houses of worship
Fire ground training
Police training
PICTURED:
DX300 system including
MB300 base station, WH300
base station, WH300 “all-in one”
headset, BP300 belt packs, and
several headset options.
The MB300ES base station
interfaces with
two-way radios.
5
DX 300 WIRELESS HEADSET SYSTEM
The DX300 Wireless Headset System links you and your team in secure, twoway, hands-free conversation. Coupled with headsets from Cobalt and HME,
you can improve communications, ensuring that all your hard work pays off!
Superior Sound Quality
DX300’s digital technology offers superior sound clarity, so you can be sure
your instructions are clearly heard above noise and general confusion.
Rugged ergonomic design means your team will handle the
rigors of even the toughest job.
Fast, Easy Setup
The DX 300 takes only minutes to set up. There are no special startup
procedures or complex antennas to worry about. And because
there is no frequency coordination required, you can use this system
virtually anywhere without losing communication due to local interference.
BP-300
Belt Pak
Triple Diversity
Triple diversity--space, time, and frequency--operation for extreme multipath
situation provides redundant communication that offers the most dependable
system available. The strongest signal is selected from two different
antennas, transmitted and received at two different times, on two
different frequencies.
Easy to Use Headset System
With no buttons to fumble with, the DX300 wireless headset system is easy to
use and hassle-free. Compact, convenient headsets give you the freedom to
do what you do best and not worry about whether equipment is functioning
properly.
DX300 is easily expanded from a basic 4-man wireless headset system to
a system to accommodate a staff of more than 20 — all in one cost-saving,
performance-enhancing package. Choose between lightweight belt pack with
choice of attached headset or the “all-in-one” wireless headset, or mix-andmatch both.
The basic typical DX300 package includes 4 wireless headsets and a base
station supporting 2 wired headsets. The system can be set for either single
channel, or 2 channel operation switchable on belt pack, or “all-in-one”
headset.
HS-15
All-in-One
Headset
CH-16 Cobalt blue
Signature Series Headset
SYSTEM HIGHLIGHTS:
Hands-free operation, conversational like a phone call
Secure, encrypted communication (scanner proof)
Flexible power options (AC and battery)
Rugged ergonomic belt pack
All-in-One wireless single ear headset
FCC license free 2.4 GHZ ISM band
cobaltav.com
1.800.264.6021
6
No frequency coordination required
Rechargeable lithium-ion batteries (cell phone battery size)
Up to 20 hours battery life per charge
7
Tactical Wireless Systems, cont.
KLSA
The compact DX100 wireless headset system
supports up to 4 simultaneous headset talkers and up to 15 listening users, like all our base
station systems.
With simplicity and economy in mind the DX base has no
connections for expansion or interface. System is perfect for
applications where there is no expansion in the number of “talkers” or interfacing with
other systems is anticipated. The DX100 wireless headset intercom system features a
compact economical base station which is sealed for dust and moisture. Powered by 120
V AC or 12 VDC but also has 6 “AA” batteries for backup power. Supports up to 15 users
and 4 “talkers” using any combination of BP200 belt packs with headset choice, and/or
WH200 wireless “all-in-one” headsets. Two BAT41 li-ion battery packs are included with
each headset unit.
The DX200 19inch rack mount
base system
offers the most
expansion and
interface options.
Capable of interface with 4-wire matrix
intercoms, 2-wire intercoms, telephone interfaces
or connection of multiple base stations, the DX200
is a flexible system for many applications. Each
DX200 base station supports up to 15 users, using
any combination of BP200 belt packs and choice
of headset, as well as WH200 wireless “all-in-one”
headsets. Wired intercom ports support Bosch
Telex RTS, ClearCom and other brands two-wire
and 4-wire matrix intercoms. Interface system to
telephone with additional components. Increase
number of talkers or expand coverage area by
linking multiple base stations together.
DX210
DX210’s base station has the same footprint and
features as DX200 base but adding dual (two)
channel operation when used with BP210 belt
packs with headset or WH210 wireless “all-inone” headsets. BP200 belt packs with headset
and WH200 wireless “all-in-one” headsets may be
mixed and matched with BP210 and WH210 units.
The DX210 supports two separate two-wire and
four-wire matrix channel interfaces. Like DX300,
DX210 supports 4 talkers in single channel and 3
talkers in dual channel modes.
8
CH-21
T-20
CH-11
CH-13
Most Cobalt headsets can be
provided for use with DX-series
belt packs. Note: Headset PTT
switch is non-functional when
used with a Belt Pack.
CH-16
TM
System Specifications
RF frequency range: All band 2400-2383.5 MHz,
low band 2401.9-2439.9 MHz,
high band 2443.4-2481.4 MHz
Frequency response: 200 Hz-3.5 kHz
Distortion:
<2%
RF sensitivity: -90 dBm with 10-3 BER
Temperature range: -4 to 131°F (-20 to 55° C) Typ.
Transmit/Receive type: Frequency-hopping spread spectrum
<2%. -90dBm with 10-3 BER
-4 to 131˚F (-20 to 55˚C) Typ spectrum (FHSS)
Modulation type: Gaussian filtered FSK, TDMA
Encryption:
64-bit RoHS compliant
BP300 Wireless belt pack
(pouch not shown)
BP200/BP210 (not shown)
looks same except for controls
MD-XLR
Subscriber Specifications
Transmit power:
100 mW burst
Antenna:
Internal
Mic input:
Electret (except WH200/
210/300)
Headset connector: Mini-DIN (except WH200/ 210/300)
Headset output:
160 mW into 32 ohms
Power requirements: BAT41 battery, 50-60 Mz or 12-14 VDC, or 6 AA batteries
Battery life:
Hands-free Up to 14 hrs, PTT
up to 20 hrs. with BAT41
FCC acceptance:
Part 15 (no license required)
HS16
SP10
Base Station Monitor
Speaker DX200
Base Station Specifications
Transmit power:
100 mW burst
TX & RX antenna:
dipole
Mic input: Electret (not applicable on DX100)
Headset connector Mini-DIN (DX200, DX300/ES)
Power requirements: 100 mW burst 1/2-wave, dual diversity
100- 240 VAC, 50-60 Mhz or12-
14 VDC on all models, plus 6AA (DX100 and DX300/ES
FCC acceptance: Part 15 (no license required
WH300 Wireless All-in-One Headset
WS200/WS210 (not shown)
Looks same except for controls
BAT41
Rechargeable Lithium-ion
battery pack
Pigtail adapter for Dynamic
mic intercom headsets with
XLR4 male or female
connector (specify).
HS4-3 Earpiece &
Lapel Microphone
Belt Pack Pouch
Included with each BP200
and BP300 Belt Pack
HS15
Headset
Extension Cable
(7 foot)
Antenna
Splitter
Travel Case
For DX300/ES
HS15D
ANT-874
Optional Trident
multi-polarized
antenna for non-line
of sight
AC40A
4-slot battery
rapid charger
Cell phone 2.5 mm
headset interface
adapter
9
theCOBRA
Noise Canceling Microphone
Rated among the best noise canceling microphones, theCobra cartridge can be
added to any Cobalt “blue” headset. For the ultimate headset, add theCobra to
our ANR active noise cancellation optioned headsets.
Dramatic Noise Reduction
TheCobra has an average 10 dB improvement over standard headset mics
with a maximum of 30 db improvement in average speech bandwidth.
The Best Speech Intelligibility
theCobra microphone enables crystal clear speech in 100+ dB noise.
Improves intelligibility scores to 82% in noise levels of 105 dB
compared to 72% intelligibility for standard microphone.
Ideal for high noise environments, theCobra’s
noise rejection performance surpasses all
other microphone technologies, and is
particularly stark in high noise levels.
SIGNATURE HEADSETS
Cobalt muff headsets offer premium quality and features that rate
them world class, with value in mind.
Our signature Cobalt blue “ecto-skin” coating provides a no glare finish with UV
protection, acoustic baffling with a rubber-coat surface that rejects scratches and
scuffs. Premium features include full flex boom, dome PTT (or mic mute) switch,
dome volume control and high efficiency speakers. Each headset comes standard
with comfort-fit foam ear seals, washable cloth ear covers and a mic windscreen.
Various types of noise canceling mic are available as options, including theCobra
technology mic.
Headsets are available in behind-head and over-head support versions as well
as single ear and hard hat slot mount versions. Headset cords for portable radios
or Cobalt fire truck intercoms attach and detach at ear cup for easy change-out.
Headset and cord versions can be used with two-way portable and mobile radios,
intercoms (wired & wireless), as well as cell and wireless phones.
We also offer the BLUE-BT-TOP Bluetooth headset adapter which can convert any
Cobalt headset into wireless with any radio with attached Cobalt BLUE BT adapter
connected to radio audio accessory connector. It also works with most radios and
cell phones with built-in Bluetooth.
As an alternative to our signature premium Cobalt blue muff headsets, we have just
introduced our high quality Value Series headsets, which features over-head,
hard hat slot mount, and listen-only versions.
10
Noise Rejection takes a new shape
Patented noise cancellation technology rejects
extraneous background noise. An acoustically
based approach; theCobra accentuates the
speaker’s voice by concentrating it on the front port
of a two-port microphone, while deflecting background noise
from the back port.
Passive Noise Canceling Technology
No processor is required, so power requirements are low.
Active noise canceling technology relies on creating an anti-noise signal to cancel out
the noise in a signal. Since there is inherent overlap in frequencies between speech and
noise, this results in speech signals often being identified as noise and vice versa. An
observable consequence of this is distorted or garbled speech, and unsatisfactory noise
cancellation. It also requires a power supply (typically, additional battery). Other
electronic noise-canceling techniques use algorithms to identify a noise from a digital
signal and to filter it out using digital filters. These techniques are also frequency
dependent, which results in the same problems mentioned above.
Available in preamped or non-preamped electret, or dynamic versions.
Microphone Specifications:
Sensitivity -35 dBVrms
Impedance 2,200 Ohms
Frequency 50-20,000 Hz
S/N ratio >70 dB
Mono sound
cobaltav.com
1.800.264.6021
Using our acoustically based approach,
theCobra accentuates the user’s voice
by concentrating it in the front of the
microphone while deflecting the
voice from the back port. The
background noise is directed
towards both ports to reduce
noise vibration.
theBoom-O
Boom-O pictured. Other lightweight
headset models feature theCobra
noise canceling microphone technology
include theBoom-W Bluetooth wireless headset,
-E behind head support with acoustic tube ear
speakers and -BC also behind head support with bone
conduction listen audio. Both the -E and -BC enhance
listening in noisy areas.
theCobra and theBoom are tradenames of Umevoice.
11
HEADSETS:
Our Signature Blue Muff Series
HD
HD
2 YEAR
2 YEAR
WARRANTY
WARRANTY
BEHIND the HEAD
OVER the HEAD
Wear with helmet, hardhat, logo cap.
24 dB NRR rated. Connect cord on right or
left side.
CH-20 Mic mute switch (yellow button)
CH-21 PTT switch (red button)
CH-31 Listen only (3.5 mm mono fixed audio cable)
Very comfortable headband. Rotate mic
boom for left or right side. 24 dB NRR rated.
CH-10 Mic mute switch (yellow button)
CH-11 PTT switch (red button)
CH-30 Listen only (3.5 mm mono fixed
audio cable)
VENTED
LISTEN ONLY
1 ear cup is vented with no speaker to
allow listening to ambient noise.
Connect cord on right or left side.
CH-40 Mic mute switch (yellow button)
CH-41 PTT switch (red button)
Has coiled 3.5 mm mono audio cable.
Dual muff with 24 dB NRR rated
CH-30 Dual overhead
CH-31 Dual behind head
CH-32 Dual hardhat slot
THROAT MICROPHONE
Dual muff, 24dB NRR rated, available in
behind-head, hard hat slot mount or overhead styles. Throat mic features injection
molded dual mic elements covering 2/3rds of the
neck area with an adjustable cloth retainer strap.
NOTE ABOUT MICS:
HARD HAT
12
Attaches to side slots. Ear cups can
be rotated to side when not in use.
Dual muff with 24 dB NRR.
CH-12 Mic mute switch (yellow button)
CH-13 PTT switch (red button)
CH-32 Listen only (3.5 mm mono fixed audio cable)
SINGLE EAR
Secure fit with comfort.
CH-15 Mic mute switch (yellow button)
CH-16 PTT switch (red button)
cobaltav.com
1.800.264.6021
Headsets normally come standard with
non-amplified electret microphones when
used with portable radio, wireless intercom
or telephony devices. Pre-amped electret
mics are provisioned when used with mobile
radios and vehicle intercoms. Dynamic mics
are also available.
13
BLUE-TOP HEADSET ADAPTER
VALUE SERIES HEADSETS
Our new Bluetooth BLUE-TOP Headset Adapter
pairs with any device that uses standard Bluetooth
headsets, INCLUDING CELL PHONES, and Cobalt
BLUE-BT Radio Adapters!
1 YEAR
WARRANTY
BLUE-TOP also works with all Cobalt “blue”
Muff Headsets, our Value Series Muff Headsets,
and is additionally available as a custom wireless
kit with our lightweight and tactical headsets.
VH-21 Behind-Head Dual Muff
VH-11 Over-Head Dual Muff
Pit crew racing style dual muff headset.
23 dB NRR hearing protection with noisecanceling dynamic wire-style support boom
microphone. Transmit PTT button on ear cup.
3.5 mm audio jack allows for 2nd audio device
(scanner or MP3 player). Wear w/ helmet, hard
hat, logo cap.
Euro-look aviation style headset. 24 dB NRR
hearing protection. Flexible electret boom
microphone. Volume and transmit PTT button
on ear cup. Adjustable padded over-head support for maximum comfort.
VH-21 Black, VH-21-GR Grey, VH-21-BL* Blue
Detachable radio interface cable sold separately.
Electret, pre-amped electret and pre-amped
dynamic mic cartridges available.
*Dynamic wire boom only.
VH-11 Black
VH-11-Y Yellow
VH-32
Hard Hat Mount
Listen Only
VH-32 Black VH-32-Y Yellow
VH-32TM
Clips to most standard hard hat models
with side slots. 24 dB NRR hearing protection
with flexible electret boom microphone.
VH-13 Black
VH-3-Y Yellow
Detachable radio interface cable sold separately.
Electret, pre-amped electret and pre-amped dynamic
mic cartridges available.
14
1 YEAR
WARRANTY
Detachable radio interface cable sold separately.
General aviation cables also available.
Hard hat slot mount dual
earmuff listen-only
headphone (no microphone).
24 dB NRR hearing protection.
Includes 3.5 mm to 3.5mm cable
(suitable for connection to Cobalt
Speaker Microphones).
VH-13 Hard Hat Slot Mount
The BLUE-TOP may also work with other
brands of muff headsets.
Hard Hat Mount
Listen Only + Throat Mic +
Tactical Switch
Hard hat slot mount dual earmuff
listen-only headphone (no microphone)
with throat mic and inline tactical
PTT switch. 24 dB NRR hearing
protection.
TVH-32-TM Black
TVH-32Y-TM Yellow
SPECIFICATIONS:
Operating Temp Range: -20˚ to +50˚ C
Weight:140 grams
Bluetooth Version:
v 2.1 + EDR
Transmitted Power:
GFSK 5.37 dBm
Rx Sensitivity:8DPSK 4.55 dBm
PTT Mode:SPP
Power Class:2
Average Range:10 meters
LED Display Indicator:
Dual color indicator
Rechargeable Battery:
5 VDC, 330mAh
Average Duty Cycle:
12 hours
cobaltav.com
1.800.264.6021
15
SPML-BLUE:
Wireless Bluetooth Speaker Microphone
The NEW Cobalt SPML-BLUE is the Bluetooth-enabled version of
our popular SPML Remote Speaker Microphone, which connects
wirelessly to any of our Cobalt Radio Adapters, and is compatible with
the optional Cobalt BT-PTT wireless Bluetooth PTT (sold separately).
FEATURES:
W!
NE
Great sounding transmit and receive audio,
just like the wired version!
Compact size: measures only 3” H x 2” W x
.6” D (excluding clip).
Lightweight: weighs less than 2.5 ounces.
Simple controls make operation easy!
1 YEAR
Integrated PTT button. To transmit, use either
the PTT button on the side of the SPML-BLUE
or on the Cobalt radio adapter.
WARRANTY
Also compatible with the optional Cobalt BTPTT wireless Bluetooth PTT (sold separately).
Front firing speaker
Microphone
Long battery life: up to 11 hours active under
typical operating conditions. USB wall charger
included.
Spring loaded metal reinforced clothing clip
can be rotated 360˚.
PTT
Button
Durable polycarbonate housing.
Accessory/Charging Jack
Clothing Clip
Status LED
Multifunction Button
Built-in earphone jack for additional privacy
and security. Compatible with standard 3.5
mm earphone plug such as our KLSH, KLEL,
or KLSC.
BLUE-MIC:
Bluetooth Surveillance Kit
Bluetooth Lapel Microphone technology has arrived!
The new BLUE-MIC delivers a full 12 hour shift talk time (typical),
easy pairing, no connectivity loss, and a fully functional PTT.
12-Hour Talk Time!
Other features include:
Volume control
USB charging port
Directional mic
(sensitive to a whisper)
Clothing Clip
3.5 mm ear kit pack
(listen only ear kits sold
separately)
Rechargeable/replaceable
battery
16
Ear Bud Speaker Kit
Included.
Directional
Microphone
Wireless Push-to-Talk
Button
Volume Up/Down buttons
And most importantly:
A strategically placed pairing
light on the back side of the
module!
Heavy Duty Clip
The BLUE-MIC can be paired with
our BLUE 2-way radio adapters and
other BT devices, including
mobile phones.
Multi-function Button
Power On/Off Switch • BT Pairing
1 YEAR
WARRANTY
Because receive audio volume is controlled
using the radio’s volume control, this product
is not recommended for use with our BLUEMOBILE series adapters that have fixed level
receive audio.
Cobalt KLSH-S3.5 ear kit shown with SPML-BLUE.
Earphone sold separately.
3.5 mm Ear Kit Jack
Earphone Jack
USB Charging Port
(Charger Included)
Pairing LED Light
(Hidden on back for
covert use)
cobaltav.com
1.800.264.6021
BLUE-MIC BT surveillance kit includes
acoustic tube ear speaker for
listening. Other ear kits available.
17
BLUE-MOBILE:
BT Adapters for Vehicle or Base Station Radios
Cobalt BLUE-MOBILE BT newly upgraded kits allow you to use a compatible
wireless Bluetooth headset or other audio accessory with a MOBILE two-way
radio. The new kits eliminate the cigarette plug adapter and now provide
Receive and Transmit audio. As before, all adapters feature an integrated PTT
on the adapter, but are also available with optional wired foot switch or BLUEPTT wireless switch.
Foot Switch
BLUE-PTT
BLUE-MOB-V1
Bluetooth Adapter Kit for Vertex Mobile radios.
Plugs into Rear Accessory connector (DB15).
Compatible with EVX-5300/5400, VX2100/2200/4100/4200/4500/4600.
BLUE-MOB-MXTL
Bluetooth Adapter Kit for Motorola Mobile radios.
Plugs into Rear Accessory connector (uses
Motorola OEM connector kit). Compatible with
XTL1500, XTL2500, XTL5000 and APX7000.
BLUE-MOB-IC1
BLUE-MOB-V2
Bluetooth Adapter Kit for Vertex Mobile radios.
Plugs into Rear Accessory connector (uses DB25).
Compatible with VX-4000, VX- 5500, VX-6000.
Bluetooth Adapter Kit for ICOM Mobile radios.
USES BOTH FRONT (Mic) AND REAR (Speaker)
jacks. Compatible with IC-F110, IC-F110S, ICF111, IC-F111S, IC-F121, IC-F121S, IC-F1610, ICF1710, IC-F1721, IC- F1721D, IC-F1810, IC-F1821,
IC-F1821D, IC-F210, IC-F210S, IC-F211, IC-F211S,
IC-F221, IC-F221S, IC-F2610, IC-F2710, IC-F2721,
IC-F2721D, IC-F2810, IC-F2821, IC-F2821D, ICF320, IC-F320S, IC-F410S, IC-F420, IC-F420S,
IC-F5011, IC-F5021,IC-F5022, IC-F5061, IC-F5062,
IC-F510, IC-F5121D, IC-F521, IC-F6011, IC-F6021,
IC-F6022, IC-F6061, IC- F6062, IC-F610, ICF6121D, IC-F621, IC-F621TR, IC-F9511, IC-F9521.
BLUE-MOB-AM
Bluetooth Adapter Kit for Alinco, ICOM, Kenwood,
Yaesu and most other Amateur radios that use
a standard 6-pin DIN Packet Radio connector.
BLUE-MOB-HY1
BLUE-MOB-K60
Bluetooth Adapter Kit for Hytera (HYT) Mobile
radios. Plugs into Rear Accessory connector
(DB26). Compatible with MD78X/MD78G. Base
price without wired or wireless PTT.
Bluetooth Adapter Kit for Kenwood Mobile radios.
USES BOTH FRONT (Mic) AND REAR (Speaker)
jacks. Compatible with TM-271, TK- 762, TK-862,
TK-7160, TK-8160, TK-7162, TK-8162, TK-7180,
TK-8180, TK-7189, TK-8189, TKR-750, TKR-850, TK768G, TK-868G, TK-760, TK- 860, TK-780, TK-880,
TK-7102, TK-8102.
Bluetooth Adapter Kit for Kenwood Mobile radios.
Plugs into Rear Accessory connector (DB25) so
Mic can still be used. Compatible with TK-7180,
TK-8180, TK-7189, TK-8189, NX-700, NX-800,
NX-900, NX-901.
BLUE-MOB-M16
Bluetooth Adapter Kit for Motorola Mobile radios.
Plugs into Rear Accessory connector (uses
Motorola OEM connector kit). Compatible with
CDM Series, CM Series, GM Series, GR series, M
Series, MAXTRAC Series, PM Series, SM Series.
Base price without wired or wireless PTT.
18
Bluetooth Adapter Kit for Motorola and MotoTRBO
Mobile radios. Plugs into Rear Accessory connector
(uses Motorola OEM connector kit). Compatible
with XPR4300, XPR4350, XPR4380, XPR4500,
XPR4550, XPR4580, XPR5350, XPR5550, XPR8300.
BLUE-PTT:
BLUE-MOB-KNX
cobaltav.com
1.800.264.6021
BLUE-MOB-MXPR
Wireless Bluetooth PTT
Compatible with a wide variety of mobile radio models.
LED indicator.
Push-to-Talk function.
USB-type charging connector.
Allows you to activate 2-way radio’s Push-to-Talk function wirelessly.
Pairs quickly and easily with any BLUE adapter.
Remembers paired connection even if PTT, wireless headset, or twoway radio is powered off.
Automatically re-stores wireless connection next time PTT
and BLUE Adapter are turned on.
Multi-function LED keeps user updated on BLUE-PTT’s status.
Internal Li-Ion battery pack powers up to 12 hours per charge
(charger included).
19
WIRELESS ADAPTERS:
for Portable 2-way Radios
Cobalt Blue™ Wireless Bluetooth Adapters allow compatible BT headsets and other audio
devices to connect with portable 2-way radios. BLUE pairs easily with Cobalt BT-TOP
adapters for muff headsets, SPML-BLUE speaker mics, BLUE-MIC surveillance kits,
the BLUE-HS headset, and the BLUE-PTT wireless tx switch. It will also pair with many
other BT headsets.
The adapter will remember paired components even when turned off. Patented “smart
switch” feature automatically routes radio audio and mic to BT or wired accessory. When no
audio accessory is connected, audio and mic are routed to radio’s internal speaker and mic.
This feature does not work on all radios.
HD
1 YEAR
WARRANTY
BLUE-MHT
BLUE-IMC
BLUE-KMC*
BLUE-MBO
*Kenwood radios may require reprogramming in order to provide power to the BLUE-KMC.
Some older Kenwood radios may be incompatible. Contact COBALT for compatibility.
BLUE-PTT
Multi-pin radio adapters shown on page 20 are powered by the connected radio (no adapter
battery).
Some adapters feature Herose quick-disconnect jacks allowing use of Cobalt QD wired
audio accessories when not using BT accessories--without removing adapter from radio.
Adapters shown on page 21 contain a rechargeable Li-ion battery and come with wall
charger. Typical battery life about 12 hours before requiring recharging. The battery
powered adapters are available in a longer cord version (at no extra charge), positioning
PTT where it is easier to reach and improving wireless rang. Specify LC after part number
such as BLUE-MSC-LC.
** Portable radio connectors not shown are supported by
purchasing the quick disconnect audio adapter for that
radio with the BLUE-HER quick disconnect BT adapter.
Radio
shown with
BLUE-MXT
Adapter
BLUE-MXT
BLUE-HYT
BLUE-VNM
BLUE-MSC
BLUE-HAR
BLUE-KSC
BLUE-VSS2S
BLUE-HER**
BLUE-APX
BLUE-HYP
BLUE-MBX
BLUE-VTC
BLUE-ISC2S
BLUE-IFR
20
BLUE-VSC
BLUE-MEX
21
LIGHTWEIGHT HEADSETS
T-10 Single and T-20 Dual Ear Headsets Feature:
Newly retooled design
Replaceable oversized leatherette ear pads. (Foam filled fabric covered also available.)
Flexible metal boom microphone with replaceable windscreen.
Noise reducing electret condensor microphone. (Dynamic and pre-amp electret
also available.)
Pre-amp electret and dynamic mics available.
1 YEAR
WARRANTY
Comfortable adjustable metal overhead support with replaceable padding.
Inline PTT for radio uses, mute switch for phones and no switch for intercoms.
Headsets may be configured for radios, phones, intercoms, aviation or computers.
Perfect for dispatch, retail, restaurant, movie/TV set, hospitality, entertainment
and industrial.
Available for OEM users.
T-20 is hard hat, helmet, logo cap compatible.
Standard Microphone
Type
Noise Canceling Electret Condenser Mic
Sensitivity
-47±-3dB
Impedance
680Ω Typ
Frequency
500Hz ̃8000Hz
Standard operation voltage
10V
Current Consumption Max. 0.4mA
Sensitivity reduction -3dB at 1V
S/N ratio
> 60dB
TT
Temple transducer headset with
bone conduction speakers and
boom mic. Inline PTT. Hard hat/
helmet compatible.
SPECIFICATIONS
T-20 Dual Ear Headset with
Nylon Strap
T-10 Single Ear Headset
With our innovative convertible design, the T-20 headset comes ready to be used with hard hat, helmet
or caps. To convert, simply install provided nylon strap in the ear speaker slots at 90 degrees from headband, put on headset with strap over head, shifting headband to become a neck band, adjust buckle to
correctly position speakers over ears and reposition boom mic.
Speaker
Size
Outer Diameter 40mm
Impedance
300Ω @ 1kHz
Power Rating
Nominal 10mW RMS, 20mW Max.
Output Sound Pressure Level
96 ± 3dB / 100mW /1cm
Frequency Range
100Hz ̃10Hz
Distortion
5% Maximum at 1KHz / 100mW
KLSB
Similar to KLSA but has
dual acoustic tube ear
kits for use in noisy
applications.
1 YEAR
WARRANTY
MIL
STD
810
KLSA
22
T-20 Dual Ear Headset with
Padded Headband
Lightweight behind head support headset with
N/C micro-flex boom mic and ear speaker. In
line PTT. Hard hat/helmet compatible.
DT-818
BLUE-HS
The DT818 headset has
Anti-Radiation circuitry,
inline volume control with
mic gain and mute switches.
2.5mm plug for cordless
telephones.
Ear support Bluetooth headset with built-in
PTT switch to key two-way radios.
NOTE: Includes changing cable and can
be charged from any USB device (wall, car,
computer) but DOES NOT include wall
charger. Wall charger sold separately.
COV-QD
KLSA pictured
on model
Covert audio adapter for portable radios
converts cell phone headphones with mic
into a push-to-talk for handheld radios.
Use either QD adapter or BLUE adapter
via Herose connector (sold separately).
Depending on radio model, transmit from
radio PTT, QD adapter PTT or BLUE BT
adapter with BLUE-PTT. Available for MXT,
MHT, MBO, KSC, KMC and HAR.
23
TTC:
High Noise Bone Conduction Headset
The Cobalt TTC bone conduction headset with a dual bone
conduction temple speakers, features a behind head support
headset and directional noise reduction boom mic.
Shown: TTC High Noise Bone
Conduction Headset
The TTC headset uses speakers that transmit audio directly into the user’s skull, using
advanced bone conduction technology. Since the dual speakers do not block the user’s ears
allowing the user to hear what is going on around (situational awareness). Also, the noise
canceling mic is mounted on an adjustable flex boom to place the mic where you need it.
Dual-Bone Conduction temple speakers transmit audio directly from vibrations into the
user’s skull. Adjustable wrap-around style headset secures behind the user’s head.
Over-the-head, adjustable strap holds headset firmly in-place. Comes with round tactical
PTT (alternative switch: belt mounted junction PTT with detachable finger switch)
Unique Bone Conduction speakers leave the user’s ears uncovered so that the user can hear
both incoming radio transmissions and the sounds going on around them. Or hear standard
issue hearing protection ear plugs required for your work and hear the communication
without need of a large muff headset.
HD
Use with hearing protection ear plugs as a lighter
and less heat stress alternative to using muff headsets.
2 YEAR
WARRANTY
ADD $30. FOR
QUICK DISCONNECT
VERSION
HSM:
Wear under hard hat or helmet.
High Noise In-Helmet Skull Microphone
The Cobalt HSM lightweight in-helmet communications system mounts without
tools to the helmet (or hard hat) liner using a unique strap fastener system. The
ear speaker provides ambient sound and allows you to hear incoming radio
communications without blocking ability to hear what is going on around you.
Voice transmissions are picked up by noise-resistant microphone which sense
sound vibrations through the skull.
Tactical teams can wear with kevlar helmets.
Wear under tight fitting plastic or other encapsulating hoods.
USES:
ADD $30. FOR
QUICK DISCONNECT
VERSION
Interior firefighters will like the quick
don and doff of fire gear with SCBA
Any industrial or public safety
application where hard hat or
helmet used and where SCBA
or other face gear is also used.
Easily and quickly installs into most hardhats or helmets with plastic liners.
Heavy-duty, featuring polyurethane cable, rubber, and high-impact polycarbonate.
Use with welder, PAPR and other face
protective shields.
Picks up the voice audio directly from vibrations in the user’s skull, very resistant to
picking up background noise.
HD
Large, ambient receive ear speaker leaves ears uncovered to hear what is going on
around you
2 YEAR
WARRANTY
24
Comes with standard round tactical switch for easy activation and radio connector
cord. Other switch options are available (sold separately) and can be interchanged
with standard switch.
Shown: HSM High Noise
In-helmet Skull Microphone
cobaltav.com
1.800.264.6021
25
THROAT MICROPHONE
TACTICAL SWITCH HEADSET KITS
Tactical Neck Mic
Our Tactical Switch combines with a variety of headset styles:
HD
2 YEAR
WARRANTY
MIL
STD
810
IP
68
TKSLA
TM
Our tactical throat microphone series has created a new standard in price, performance and comfort
for demanding law enforcement, fire, industrial and other
task critical or high noise communication applications.
TCH21
Add these accessories to customize your kit.
PHP-29 dB NRR Plugs, sold
in 100 per box.
(shown on acoustic tube).
*Throat mic top rated IP68 (fully
submersible.) Standard round
tactical switch rated IP56.
26
Tactical PTT
Acoustic Tube
with Ear Bud
HD
2 YEAR
WARRANTY
Belt and Finger
PTT Combo
We also include a rubber mushroom tip ear plug and a medium-sized semicustom ear mold connecting to an acoustic ear tube. An adjustable cloth retainer
strap is now integrated into the neck mic assembly and does not generally need
to be secured unless wearing inside protective clothing to insure a secure fit.
Options include PHP disposable 29 dB NRR hearing protection plugs with an
internal tube to attached to acoustic tube.
Semi-custom
Ear Mold
TCH11
With the popularity of our throat mic and bone conduction headset
kits, we now provide inline round tactical switch versions of our
Cobalt “blue” headsets and several other audio accessories.
Throat mics, bone conduction headsets and all of our tactical switch
accessories come with inline round tactical switch. We also offer a
switch alternative: instead of a standard switch, we can substitute a
belt clip PTT with detachable finger switch.
The TM is one of the most versatile economical audio accessories yet devised. It
has been effectively used in activities requiring breathing protection including
SCBA’s, gas masks, hazmat, plastic suit and confined space. It is also effective to
talk and listen in noisy areas. Perfect for police tactical units and firefighters.
Included with our rugged use throat mic kit is a molded plastic neck mic with
adjustable water sealed rubber cover, dual mic elements, clear acoustic ear tube,
large round detachable tactical PTT switch and a radio connector cord. The throat
mic is designed to fit necks 12 to 17 inches in size.
TCH16
cobaltav.com
Tactical
Switch
1.800.264.6021
27
SURVEILLANCE KITS:
For 2-Way Radios
Cobalt features the widest range of surveillance kits found anywhere.
Sometimes referred to as lapel mics, 2-wire or 3-wire kits, we feature models
with ear buds, acoustic tubes, plastic D-rings, and optional quick disconnect
radio cords.
1 YEAR
WARRANTY
SPYM
Medium duty rugged lapel mic with inline
acoustic tube earphone featuring a microspeaker-transducer. Heavy duty cable with
strong polyurethane jacket and superior
strain relief. Light and comfortable to
wear, Compatible with all ear tips and
semi-custom ear molds.
BLUE-MIC
Bluetooth lapel microphone delivers
a full 12 hr. shift talk time with easy
pairing, no connectivity loss, and a
fully functional PTT. Requires
provided ear kit for listening.
More details on pg. 16.
1 YEAR
WARRANTY
Shown acoustic tube
ear kit (KLSH)
1 YEAR
1 YEAR
WARRANTY
WARRANTY
CLBG
DLBG
Inline noise reduction lapel
mic/push-to-talk/clip and
comfortable cleanable
hygienic plastic D-ring ear
shell speaker. D-ring loops
over the flap of the ear and
swivels for left or right
ear use.
Inline noise reduction
lapel mic/push-to-talk/
clip and comfortable
cleanable hygienic
plastic C-loop ear
shell speaker. The
adjustable“C” securely
loops over the flap of the
ear and swivels for right
or left ear use.
KLBG
Inline noise reduction lapel
mic/push-to-talk/clip and
in-the-ear ear bud speaker.
Soft ear hook holds the
ear bud in place.
HLBG
Inline noise reduction lapel
mic/push-to-talk/clip and
in-the-ear bud speaker with
integrated ear hook
containing receiver wire.
Replacement speaker foam
available.
Limited radio connectors
available, including: KSC,
MSC, VSS2S & MOP.
1 YEAR
WARRANTY
PYM
Inline noise reduction lapel
mic/push-to-transmit/clip
and clear acoustic tube
reinforced transducer speaker.
This is our most popular surveillance kit.
On acoustic ear tube models, a KLP rubber earplug
and a right medium size SCE semi-custom ear mold
is included. Optionally, SCE’s are available in small,
medium, and large for left or right ears. Also available:
PHP 29 dB NRR disposable hearing protection
communication ear plugs (100 per box).
See Listen Only ear kits on pages 36-37 for more detail.
28
cobaltav.com
1.800.264.6021
29
SURVEILLANCE KITS:
For 2-Way Radios
KLSN2
BLBG
Traditional two-wire surveillance kit with
clear acoustic tube reinforced transducer
speaker and noise reduction lapel mic/
push-to-transmit/clip assembly.
6 MONTH
WARRANTY
Budget priced inline lapel mic/
push-to-transmit/clip and in-theear ear bud speaker. Soft earhook
holds the ear bud in place.
6 MONTH
WARRANTY
BYM
1 YEAR
WARRANTY
Budget priced inline lapel mic/pushto-transmit/clip and clear acoustic
tube transducer speaker. Limited
radio connectors available, including
KSC, MSC, VSS2S and MOP.
QUICK DISCONNECT
QUICK DISCONNECT FEATURE
KLSN3
For covert operations, you can conceal
our 3-wire kit under clothing. Kit has clear
acoustic tube transducer speaker, micro
lapel mic/clip and 3rd wire for form fit
barrel push-to-talk switch.
Our Quick Disconnect
System allows easy connect
and disconnect of your audio
accessory, yet is secure
enough to be used in most
situations. Interchangeable
with all QD Adapters,
making communications
convenient for multiple
radio model users.
QD’s prevent wear and tear,
prolonging your radio’s life.
HD
1 YEAR
WARRANTY
MIL
STD
810
These and other accessories are available.
KLSA Headset
KLSN
30
Two-wire kit with push-to-talk/clip module at midsplit junction module with wire to lapel mic/push-totalk/clip and wire to clear acoustic tube reinforced
transducer speaker.
1 YEAR
WARRANTY
SPMW Speaker Mic
PYM Surveillance KIt
cobaltav.com
1.800.264.6021
31
AMPS1:
Advance Microphone for Public Safety
Hi/Low Volume
Switch
(6dB switch)
Noise Cancelling
Mic reduces
background noise
Large
Tactile
Side PTT
The AMPS1 is a heavy duty
remote speaker microphone,
built for public safety use.
Engineered for performance
and durability, AMPS1 features
a noise-canceling mic, high
output speaker and high/low
switch to toggle speaker volume.
Waterproof
Connector
(selected
models)
3.5 mm External Jack for
Listen-only Ear Kit
Waterproof
Cables
Large speaker microphone
Front-firing, hi volume speaker
Hi/Low volume toggle switch
with 6 dB range
Rugged heavy duty design
built for public safety use
Fully submersible--meets
IP67 standards!
Large tactile switch PTT is easy
to use even wearing gloves
Earphone jack for optional
listen-only earphone
Panic switch available (radio
must support external panic)
HD
3 YEAR
Large PTT
Design
Waterproof
Connector
(selected
models)
High Impact Water
Resistant Polycarbonate
Housing
IP
67
LISTEN-ONLY OPTIONS for
all COBALT Speaker Mics
KLSC-S3.5
Metal Reinforced
Swivel Clip on rear
3.5 mm External Jack
for Listen-Only Ear Kit
The AMPS2 is the weatherized
version of our popular SPMW
speaker microphone.
KLEL-S3.5
KLSH-S3.5
Waterproof
Cable Connections
PLATFORM FEATURES:
IP56 rating- sealed against
dust and liquid
3.5 mm ear kit jack faces down
to prevent rain from rain from
entering. Jack cover cap must
be used when not in use.
Large PTT button easy to
operate even with gloves
Noise cancelling microphone
WARRANTY
32
Noise Canceling
Microphone
PLATFORM FEATURES:
Panic Switch
(selected models)
MIL
STD
810
Water-Rated Noise Canceling Speaker Mic
Rubberized Grip
prevents slippage
Fully rotating Metalreinforced Clothing Clip
Rubber
Non-slip
Grips
AMPS2:
cobaltav.com
HD
2 YEAR
WARRANTY
MIL
STD
810
IP
56
1.800.264.6021
33
SPEAKER MICROPHONES:
Remote Speaker Microphones for 2-Way Radios
3.5 mm External Jack
for Ear Kit
Waterproof
Connector
(selected
models)
Noise-reducing
Microphone
Rubberized Grips
prevents slippage
High Output
Speaker
High Impact Water
Resistant Polycarbonate
Housing
HD
NEW SPML-BLUE!
IP
56
Our best seller is now available in
Bluetooth, with the same great
features as the original wired style.
Details, page 16.
IP
56
IP
55
6 MONTH
WARRANTY
IP
54
SPMW
SPML
SPMM
Our best selling speaker mic is water resistant!
Heavy duty impact-resistant polystyrene top
Rubber sealed for wet environments
Quality components insure clear transmit and receive
Large PTT and metal reinforced 360˚ swivel clip
3.5 mm accessory jack for remote ear kit
Small lightweight remote
speaker microphone
Mic produces excellent transmit audio
Powerful speaker despite small size
Remote 3.5 mm audio jack
Spring loaded, metal reinforced
rotating clothing clip.
Durable polycarbonate housing for
long product lifespan
Flexible polyurethane jacketed
microphone cable with ample
strain relief
3.5mm accessory jack
Designed with retail, hospitality, and
healthcare users in mind, our SPMM
MINI MIC is our smallest, lightest
speaker microphone yet!
Small, lightweight and easy to use.
Mic top measures only 2.8” x 1.9” x 0.85”
(1.4” clip)
Adjustable, rotating clip secures mic to
user’s clothing
Loud matches the audio output of much
larger speaker mics
Tactile Push-To-Transmit button
3.5mm accessory jack for listen only
ear kits
SPMM is available for limited radio
connector models.
Our speaker microphones offer the quality product
you need at a value price. First class features include
a rugged 360˚ swivel clip, excellent audio quality,
rugged radio connector coiled cords and
positive action PTT switches.
We offer both public safety-quality and
retail compact sized models for most
portable radios. Tactical antenna mics
are also available.
34
WARRANTY
WARRANTY
WARRANTY
MIL
STD
810
HD
2 YEAR
1 YEAR
2 YEAR
Waterproof Cables
OEM style speaker microphone
Solidly built, modeled from radio
manufacturers’ styles-but at a
fraction of the cost.
Uses many of the same cables and
parts as other speaker microphones.
Includes standard 3.5 mm jack for
all earphone options.
Custom printing of your name and/or
logo available on orders of over 100.
Large PTT
Design
HD
Metal Reinforced
Swivel Clip on rear
SPMR
cobaltav.com
1.800.264.6021
35
LISTEN ONLY EAR KITS
KLEL
KLSC
D-ring over ear loop
speaker kit. Swivels
for left or right ear.
Hygienically cleanable.
Economy ear bud
speaker kit. Soft ear-hook
holds the ear bud in place.
S2.5 15 inch coil cord
S2.5 15 inch coil cord
with 2.5 mm right
angle connector
S3.5 15 inch coil cord
S3.5 15 inch coil cord
with 3.5 mm right
angle connector
L2.5 25 inch coil cord
L2.5 25 inch coil cord
with 2.5 mm right
angle connector
with 2.5 mm right angle
connector
with 3.5 mm right angle
connector
with 2.5 mm right angle
connector
KLSH
Clear acoustic tube
reinforced transducer kit.
S2.5 15 inch coil cord
with 2.5 mm right angle
connector
S3.5 15 inch coil cord
with 3.5 mm right angle
connector
L2.5 30 inch straight
cord with 2.5 mm right
angle connector
L3.5 30 inch straight
cord with 3.5 mm right
angle connector
Portable Radio Connector
L3.5 25 inch coil cord
with 3.5 mm right angle
connector
MTC 30 inch straight
cord with 3.5 mm threaded
straight connector (MTC,
see radio chart)
QD 30 inch straight cord
with QD connector (mates
with QD radio adapter, sold
separately)
KLP
Ear Bud rubber mushroom
shaped ear insert for large
elbow fitting.
KLAC
KLAC Replacement clear acoustic tube
KLAB Replacement black acoustic tube
KLAZ Replacement clear acoustic tube with metal threading
KLAP Replacement clear acoustic tube with 36
cobaltav.com
1.800.264.6021
plastic twist connect
L3.5 25 inch coil cord
with 3.5 mm right
angle connector
PORTABLE
RADIO ADAPTERS
See radio connector chart on pgs. 52-55
for more details.
M9716
MSC to MHT
M6766
MTC to MXT
M9717
MTC to MHT
K0111
KSC to KMC
PHP
Disposable foam
hearing protectors,
29 dB NRR, for small
elbow fitting. Box of 100.
SCE
Semi-custom comfort fit ear mold for
small elbow fitting.
RS Right small
RM Right medium
RL Right large
LS Left small
LM
Left medium
LL Left large
M4455
MSC to MEX
M9783
MSC to MBO
AN-100 & N-100
Comply™ Foam Tips A-100 are for hearing your
surroundings. N-100 is for noise reduction (but
not qualified hearing protection). The patented
“Dual Layer” technology increases retention to
provide a secure in-ear fit and is comfortable
during extended use. Compatible with acoustic
tube ear kits. Three to a pack or 100 per box.
37
VEHICLE INTERCOMS:
With 2-way Radio Interface
Variety of headset styles available.
CH21
CH11
CH41
550 Single
Radio Intercom
Cobalt apparatus intercoms offer effective vehicle communications
and mandated hearing protection for fire and emergency
responders. Jack boxes and intercoms are made of anodized
magnesium alloy finish extruded aluminum with gasket seals. Cables
can withstand extremes of temperature, moisture and sun.
All cables are terminated with round metal locking connectors..
800 Single Radio Intercom
Supports driver and officer positions and up to 2 remote
pump panel/outside transmit capable positions. Up to 6
crew intercom/non-transmit positions. Includes 1 mobile
radio interface, plus cell phone jack, audio IN with auto
muting and record OUT jacks.
800 Dual
Radio Intercom
CH16
Headset
Pumper: 550, driver/
officer, pump panel
and radio interface.
6 position: 550, driver/
officer, 4 crew, pump
panel and radio interface.
EMS: dual radio 800 with
2 radio interfaces, driver/
officer 0611 A-B switch
jacks, 0640 EMS medic
jack with foot switch and
hospital radio interface.
550 Dual Radio Intercom
Same as 550, adds two mobile radio interfaces.
38
cobaltav.com
1.800.264.6021
39
Vehicle Intercom Accessories continued:
611
600
601
PP
FS
HH
Driver/officer A-B switch
jack box with PTT switch
(for 800 intercom).
Driver/officer
transmit jack box.
Driver/officer
transmit jack box
with PTT switch.
Outdoor pump panel
transmit jack box with
string action jack cover.
FS Transmit function
foot switch for connection
to jack box or to intercom.
Headset hanger
Intercom
Cables
High quality cable used
for connecting intercom
to jack boxes.
441
5 foot
442
10 foot and up in
5 foot intervals
434
Y-splitter cable
635
Dual crew nontransmit jack box
Cobalt A/V
David Clark
David Clark
S2120-05 - 5 ft.
S2120-15 - 15 ft.
S2110-05 - 5 ft.
S2110-15 - 15 ft.
S2130-05 - 5 ft.
S2130-15 - 15 ft.
5-conductor Nexus
plug fits Cobalt A/V
intercom jacks
Firecom
5-conductor Nexus
plug fits Firecom
intercom jacks
PTT positions:
S2121-05 - 5 ft.
S2121-15 - 15 ft.
Crew positions:
S2122-05 - 5 ft.
S2122-15 - 15 ft.
40
3/16” plug fits old
style David Clark
intercom jacks
1/4” military style
plug fits David Clark
intercom jacks
Sigtronics & Setcom
1/4” plug fits both Sigtronics
and Setcom intercom jacks
S2100-05 - 5 ft.
S2100-15 - 15 ft.
David Clark/Sigtronics
4-conductor Nexus style plug fits David
Clark and Sigtronics intercom jacks
S2140-05 - 5 ft.
S2140-15 - 15 ft.
Headset Cord
Coiled cords with Nexus 5-contact connector (used on Cobalt intercoms).
Cords are polyurethane outer jacket with 100% foil shield for optimal RFI imm
S2120-05
5 foot coil cord
S2120-15
15 foot coil cord
MKB/MKF
Motorcycle In-helmet Headset Kit
Powerful in-helmet speakers allow the user to hear
radio transmissions over road noise. High quality
electret condenser element produces excellent
transmit audio. Handle-bar mountable Push-To-Talk
switch for convenient communications. Installs into
helmet using only two-sided fastening tape. No
drilling of holes is required. Modular features allow
the mic system to be easily disconnected from the
motorcycle. Available for both open faced (MKB)
and full faced (MKF) helmets.
Limited radio connector cord availability:
-ISC, -ITC, -KSC, -MSC, -MOP, -MTC, -VSC,
-VTC. For -KMC radios, use K0111 with
-KSC. For MEX, use M4455 with -MSC. For
-MHT use M9716 with -MSC or M9716 with
-MTC. For MXT, use M9717 with -MTC.
See connector page on page 52 for radio chart.
MKF
MKB
41
MOBILE RADIO MICROPHONES
Cobalt Mobile Mics are direct replacements for popular models.
(Additional mic models are being developed, so check with us for
updates for your particular model if you don’t see it below.)
MM-KK
Replacement Microphone for OEM model KMC-32 with 16 button
DTMF keyboard. Has RJ-45 type connector and fits most Kenwood
models including:TM-271A, TM-281A, TK-7100, TK-7102, TK-7108, TK7160, TK-7162, TK-7180, TK-7189, TK-7302, TK-7360, TK-8100, TK- 8102,
TK-8108, TK-8160, TK-8162, TK-8180, TK-8189, TK-8302, TK- 8360, TK-90,
TM-V71A, and TM-D710A
MAIN FEATURES:
1 YEAR
WARRANTY
Rugged Microphone for Mobile radios
Direct replacement for OEM (original manufacturer) units
Noise Canceling Mic Element
Rugged 5.5 mm diameter cable
Stainless steel plates and hardware
Rugged PC and ABS cases
Includes mounting clip and hardware
MM-M
Replacement Microphone for OEM model RMN4025.
Has RJ-45 type connector and fits many models including: CDM1250,
CDM1550, CDM1550LS, CDM1550LS+, CDM750, GM1280, GM140,
GM160, GM300, GM338, GM340, GM360, GM380, GM398, GM640,
GM660, MCX760, MCX780, PRO3100, PRO5100, PRO7100
MM-1
Replacement Microphone for OEM model HMI360.
Has RJ-45 type connector and fits: CY F121S, CY F221S, IAS 100D, IAS
100W, IAS X- Band 50, IC-A110, IC-F110, IC-F110S, IC-F111, IC-F111S,
IC-F121, IC- F121S, IC-F1610, IC-F1710, IC-F1721, IC-F1721D, IC-F1810,
IC-F1821, IC-F1821D, IC-F210, IC-F210S, IC-F211, IC-F211S, IC-F221,
IC-F221S, IC- F2610, IC-F2710, IC-F2721, IC-F2721D, IC-F2810, IC-F2821,
IC- F2821D, IC-F320, IC-F320S, IC-F410S, IC-F420, IC-F420S, IC-F5011,
IC- F5021, IC-F5022, IC-F5061, IC-F5062, IC-F510, IC-F5121D, IC-F521, ICF6011, IC-F6021, IC-F6022, IC-F6061, IC-F6062, IC-F610, IC-F6121D, ICF621, IC-F621TR, IC-F9511, IC-F9521, IC-FR3000, IC-FR4000, IC- FR6000,
IC-FR6100, IF-BF510, IF-BF610, IC-FR5000, IC-FR5100
MM-MB
Replacement Microphone for OEM model RMN5052.
Has Motorola GCAI (special round) type connector and fits many
models including: DGM4100, DGM4100+, DGM6100, DGM6100+,
DM3400, DM3401, DM3600, DM3601, DM4400, DM4401, DM4600,
DM4601, XiR M8220, XiR M8228, XiR M8260, XiR M8268, XiR M8620, XiR
M8628, XiR M8660, XiR M8668, XPR4300, XPR4350, XPR4500, XPR4550,
XPR5350, XPR5550GM640, GM660, MCX760, MCX780, PRO3100,
PRO5100, PRO7100
MM-K
MM-V
Replacement Microphone for OEM model KMC-30.
Has RJ-45 type connector and fits most Kenwood models including:
TM-271, TK-762, TK-862, TK-7160, TK-8160, TK-7162, TK-8162, TK-7180,
TK-8180, TK- 7189, TK-8189, TKR-750, TKR-850, TK-768G, TK-868G, TK760, TK-860, TK-780, TK-880, TK-7102, TK-8102
Replacement Microphone for OEM model SM31.
Has RJ-45 type connector and fits many models including: VX-1400,
VX-2100, VX- 2200, VX-4104, VX-4107, VX-4204, VX-4207, VXR-7000,
VXR-9000
cobaltav.com
42
1.800.264.6021
43
44
45
cobaltav.com
46
1.800.264.6021
47
cobaltav.com
48
1.800.264.6021
49
PRODUCTS &
SERVICES
THE COMTRONICS STORY
ACCESS CONTROL
MICROWAVE
We offer access control systems for a wide variety of facilities, both single site and multiple sites, with
single badge access or Keyfob products.
We offer point-to-point, point-to-multipoint,
Bridge, AP, Subscribers, and Network Design.
VIDEO SURVEILLANCE
SOFTWARE PTT
We offer IP and conventional composite video surveillance solutions.
TELEPHONY
We provide applications for Windows, Mac, IOS,
and Android, as well as private servers for secure
communications.
We offer IP and SIP phone systems and WiFI (including WiMax) solutions, integrated voice mail and smart
phone integration. We also provide Avaya IP office systems.
MOBILE DATA
RF SOLUTIONS
We offer RF Solutions with turnkey implementation including FCC Licensing, tower location, system
design, construction, and system installation. Microwave point-to-point or multi-point solutions.
As a total mobile solutions integrator (hardware,
software, connectivity), we provide a wide
variety of products and services for the mobile
workforce. Our focus is to design solutions to
suit your specific application and situation.
TWO-WAY RADIO
While we offer two-way sales, programming, installation and service, we also provide FCC licensing
consultation, complete system integration, dispatch and 911 consoles. We offer IP radio solutions as well
as P25 and digital radio systems. We specialize in providing protective clothing wireless communication.
We offer rugged devices and laptops with
software solutions, including custom applications
developed for your needs.
DAS/BDA DISTRIBUTED ANTENNA SYSTEMS
In addition, we provide private networks, VPN,
and installation services for a complete turnkey
project experience.
(DAS) and Bi-direction antenna systems (BDA) are used to provide cellular coverage in large public facilities
such as arenas and stadiums, hospitals, office buildings and college campuses. We specialize as system
integrators for in-building wireless installation and partner with end users, carriers and manufacturers,
and contractors. We provide a turn key project approach from concept through closing. Through project
management methodology, we create a detailed design with drawings followed by a quality installation
with strict adherence to industry standards.
TOWER SERVICES
We provide tower maintenance that includes antennas, radio heads, TTA, RET cables, lights, and cable
replacement. We provide PIM , sweep, and other testing.
CUSTOM HEADSETS & CABLES
For years we have custom assembled headsets
for connection to just about any communication
device and system, including intercoms, radios,
and telephones. We can often provide quick
turn around value solutions that most headset
vendors do not offer.
ComtronICS Inc (aka Comtronics Industrial
Communication Systems) is a 35 year veteran of
the wireless business, based in Lexington KY. We
have developed a solid reputation for innovative
system design and as a reliable supplier of
headsets, radios and wireless technologies.
Our expertise spans several vertical markets,
including nuclear, public safety, energy, and
paper products manufacturing. Our customers
include many Fortune 500 companies.
ComtronICS is an authorized Motorola
2-Way Radio dealer since 1993, offering the
most experienced source for Motorola radio
communication products and services in the
central Kentucky and Cincinnati metropolitan
area. Two times we achieved the select Motostar
excellence rating and are also recognized as a
Platinum Channel Partner.
In 2003, we created our popular radio audio
accessories division, Cobalt AV, which brings you
cutting edge products. Our signature Cobalt blue
muff headsets have become an industry favorite.
Our warehouse location puts us within one or
two ground shipping days of much of central and
eastern United States.
In 2012, we opened our second office in Florence,
KY to better serve the Cincinnati market.
OPENBTS
We offer consultation, integration, and deployment of OpentBTS. This technology has uses as an
alternative to cellular. Public safety emergency management will be keen to use OpenBTS for mobile
data, especially during cellular outages. OpenBTS is a Unix application that uses a software radio
to present a GSM Um interface to handsets and uses an SIP soft switch or PBX to connect calls. The
combination of global-standard GSM air interface with low-cost VoIP backhaul provides a new type of
cellular network that can be deployed and operated at much lower cost than existing technologies in
rural cellular deployments and private cellular networks.
PRODUCT WARRANTIES
Each product line represented by ComtronICS |
Cobalt AV offers different warranties. We stand by
the manufacturer’s warranty plus we may offer
various other types of service warranties.
We always stand 100% behind our products and
services through normal and expected usage.
WIRELESS COMMUNICATIONS EXPERTS
www.comtronicsnow.com
50
51
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
