Yamaha PDM-5520 User manual

IMPORTANT SAFETY INSTRUCTIONS
SAFETY POINTS YOU SHOULD KNOW ABOUT
YOUR Yamaha High Definition Plasma Monitor
Please read this section carefully to obtain a proper understanding of how to operate your Yamaha High Definition Plasma Monitor.
And make sure you follow all of the warnings and instructions marked on this monitor.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
a sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle, is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
the appliance.
WARNING:
• TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS MONITOR TO RAIN OR MOISTURE.
• THE MONITOR SHOULD NOT BE EXPOSED TO DRIPPING OR SPLASHING AND OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED ON THE MONITOR.
NOTE:
• There are no user serviceable parts inside the monitor.
• Model and serial numbers are indicated on back side of the monitor.
CAUTION:
Adjust only those controls that are covered in the instructions, as improper changes or modifications not
expressly approved by YAMAHA could void the user's authority to operate the monitor.
POWER SOURCE
THIS MONITOR IS DESIGNED TO OPERATE ON 120 VOLTS 60Hz, ALTERNATING CURRENT. INSERT THE POWER
CORD INTO A 120 VOLT 60Hz OUTLET.
TO PREVENT ELECTRIC SHOCK, DO NOT USE THE MONITOR'S (POLARIZED) PLUG WITH AN EXTENSION CORD,
RECEPTACLE, OR OTHER OUTLET UNLESS THE BLADES AND GROUND TERMINAL CAN BE FULLY INSERTED TO
PREVENT BLADE EXPOSURE.
NEVER CONNECT THE MONITOR TO DIRECT CURRENT OR ANYTHING OTHER THAN THE SPECIFIED VOLTAGE.
CAUTION:
Never remove the back cover of the monitor as this can expose you to very high voltages and other
hazards. If the monitor does not operate properly, unplug the monitor and call your authorized dealer
or service center.
For Canadian customers:
To prevent electric shock, match wide blade of plug to wide slot and fully insert.
This Class B digital apparatus complies with Canadian ICES-003.
READ ALL INSTRUCTIONS CAREFULLY.
KEEP THIS USER’S MANUAL FOR FUTURE REFERENCE.
For future reference, record the serial number of your monitor.
SERIAL NO.
The serial number is located on the rear of the monitor.
1
010_PDM-5520_U_E
2
12/13/04, 9:23 AM
IMPORTANT SAFETY INSTRUCTIONS
Follow all warnings and instructions marked on this monitor.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding- type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use the attachments/accessories specified by the
manufacturer.
12.
Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is
used, use caution when moving the
cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
Do not place any objects on the top of the monitor which
may fall or cause a child to climb to retrieve the objects.
15. Monitors are designed to comply with the recommended
safety standards for tilt and stability.
Do not apply excessive pulling force to the front, or top, of
the cabinet which could cause the product to overturn
resulting in product damage and/or personal injury.
16. Follow instructions for wall, shelf or ceiling mounting as
recommended by the manufacturer.
17. An outdoor antenna should not be located in the vicinity of
overhead power lines or other electrical circuits.
18. If an outside antenna is connected to the receiver be sure
the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges.
Section 810 of the National Electric Code, ANSI/NFPA No.
70-1984, provides information with respect to proper
grounding for the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size of
grounding connectors, location of antenna-discharge unit,
connection to grounding electrodes and requirements for the
grounding electrode.
ENGLISH
Read before operating equipment
ANTENNA
LEAD IN
WIRE
GROUND
CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ELECTRIC
SERVICE
EQUIPMENT
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUNDING CONDUCTORS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250 PART H)
NEC NATIONAL ELECTRICAL CODE
Note to the CATV system installer: This reminder is provided to
call the CATV system installer's attention to Article 820-40 of the
NEC that provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be connected to
the grounding system of the building, as close to the point of
cable entry as practical.
Disposal of this product may require specific instructions
pertaining to your resident state. For disposal or
recycling information, please contact your local
authorities or the Electronic Industries Alliance:
www.eiae.org.
PREVENTION OF IMAGE RETENTION
Continuous on-screen displays such as video games, stock market quotations, computer generated graphics, and other fixed
(non-moving) patterns can cause permanent damage to the monitor.
PUBLIC VIEWING OF COPYRIGHTED MATERIAL
Public viewing of programs broadcast by TV stations and cable companies, as well as programs from other sources, may
require prior authorization from the broadcaster or owner of the video program material.
1
2
011_PDM-5520_U_E
1
12/13/04, 9:23 AM
• FCC (Federal Communications Commission) STATEMENT WARNING
COMPLIANCE INFORMATION STATEMENT
(DECLARATION OF CONFORMITY PROCEDURE)
Responsible Party:
Yamaha Electronics Corporation
Address:
6660 Orangethorpe Avenue
Buena Park, CA90620
Telephone:
714-522-9105
Fax:
714-670-0108
Type of Equipment:
High Definition Plasma Monitor
Model Name:
PDM-5520
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received including interference that may cause undesired operation.
See the user manual instructions if interference to radio reception is suspected.
FCC INFORMATION (for US customers)
1.
IMPORTANT NOTICE: DO NOT MODIFY THIS
UNIT!
This product, when installed as indicated in the instructions
contained in this manual, meets FCC requirements.
Modifications not expressly approved by Yamaha may void
your authority, granted by the FCC, to use the product.
2.
IMPORTANT: When connecting this product to accessories
and/or another product use only high quality shielded cables.
Cable/s supplied with this product MUST be used. Follow all
installation instructions. Failure to follow instructions could
void your FCC authorization to use this product in the USA.
3.
NOTE: This product has been tested and found to comply
with the requirements listed in FCC Regulations, Part 15 for
Class “B” digital devices. Compliance with these
requirements provides a reasonable level of assurance that
your use of this product in a residential environment will not
result in harmful interference with other electronic devices.
This equipment generates/uses radio frequencies and, if not installed
and used according to the instructions found in the users manual, may
cause interference harmful to the operation of other electronic devices.
Compliance with FCC regulations does not guarantee that
interference will not occur in all installations. If this product is found
to be the source of interference, which can be determined by turning
the unit “OFF” and “ON”, please try to eliminate the problem by
using one of the following measures:
Relocate either this product or the device that is being affected by the
interference.
Utilize power outlets that are on different branch (circuit breaker or
fuse) circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient the antenna.
If the antenna lead-in is 300 ohm ribbon lead, change the lead-in to
coaxial type cable.
If these corrective measures do not produce satisfactory results,
please contact the local retailer authorized to distribute this type of
product. If you can not locate the appropriate retailer, please contact
Yamaha Electronics Corp., U.S.A. 6660 Orangethorpe Ave, Buena
Park, CA 90620.
The above statements apply ONLY to those products distributed by
Yamaha Corporation of America or its subsidiaries.
22-1
011_PDM-5520_U_E
2
12/13/04, 9:23 AM
ENGLISH
USER’S MANUAL
Thank you very much for purchasing the Yamaha High Definition
Plasma Monitor.
Before using your monitor, please carefully read this manual so you
will know how to operate the monitor properly. Keep this manual in a
safe place. You will find it useful in the future.
Notes on lnstallation Work:
This product is marketed assuming that it is installed by qualifed
personnel with enough skill and competence. Always have an
installation specialist or your dealer install and set up the product.
YAMAHA cannot assume liabilities for damage caused by mistake
in installation or mounting, misuse, modification or a natural
disaster.
Note for Dealers:
After installation, be sure to deliver this manual to the customer
and explain to the customer how to handle the product.
Notes about This Manual
• The information in this manual is subject to change without
notice.
• While meticulous care has been taken in the preparation of this
manual, you are requested to notify your dealer or us should
you have any comments, views or questions about our product.
• Fully understand the prerequisites to using the product, such
as hardware and software specifications and constraints, in
using the product. We are not held liable for damages caused
by improper handling of the product.
• Reproduction of this manual in whole or in part without our prior
written permission is prohibited.
• The product names mentioned in this manual may be
trademarks or registered trademarks of their respective
owners.
3
011_PDM-5520_U_E
3
12/13/04, 9:23 AM
FEATURES
Large-screen, high-definition plasma
display panel
The 55-inch color plasma display panel, with a resolution of
1366 (H) x 768 (V) pixels, creates a high-definition, large-screen
(aspect ratio : 16:9) and low-profile flat display. Free from
electromagnetic interferences from geomagnetic sources and
ambient power lines, the panel produces high-quality display
images free from color misconvergence and display distortion.
High Performance Digital Processor
A wide range of personal computer signals can be handled, from
640 x 400, 640 x 480 VGA to 1600 x 1200 UXGA. (RGB Analog
input)
Easy-to-use remote control and on screen
display system
The remote control included eases the work of setting display
controls. Further, the on-screen display system, displays the status
of signal reception and display control settings in an easy-to-view
fashion.
TruBass
TruBass, SRS and (O) symbol are trademarks of SRS Labs, Inc.
TruBass technology is incorporated under license from SRS Labs,
Inc.
Built in Video Unit
(1) A Composite/S video terminal and two component terminals
have been added. A composite video output terminal is also
provided as a monitoring output.
(2) A wide range of devices other than personal computers can
also be connected.
(3) It is possible to swich the component terminal to RGB input
from the Menu screen.
(4) A SCART terminal is also provided for the signal of the
European standard. It operates as composite/S/RGB input
terminal, or video output terminal.
Options
Ask your local retail dealer for further details on the following
optional attachments.
• Pedestal
PDS-355
• This User’s Manual was printed before final product
development. After printing, some product specifications may
change due to operational upgrades and other reasons. In this
case, the specifications of the product itself will take precedence
over the specifications in this manual.
• TRADEMARK ACKNOWLEDGEMENT
VGA and XGA are registered trademarks of International
Business Machines Corporation.
APPLE and Macintosh are registered trademarks of Apple
Computer, Inc.
All brand or product names are trademarks or registered
trademarks of their respective holders.
4
011_PDM-5520_U_E
4
12/13/04, 9:23 AM
CONTENTS
INSTALLATION INSTRUCTIONS FOR PC ... 27
Main Unit ........................................................................... 10
Input Switching ................................................................. 30
Remote control .................................................................. 11
Volume Adjustment ........................................................... 30
Loading Batteries ........................................................... 11
Audio Mute ........................................................................ 30
Handling the Remote Control ......................................... 11
Size Switching ................................................................... 31
INSTALLATION INSTRUCTIONS ................ 12
Input Signal Screen Display ............................................. 31
Installation ......................................................................... 12
Anti-tumble measures ....................................................... 12
Automatic Adjustment of
Screen Position and the Clock ....................................... 32
Connecting to Video Imaging Device ............................... 13
Independant Operation of Multiple Monitors .................... 32
Power Cord Connection .................................................... 14
Using the Menu Screen .................................................... 32
OPERATING INSTRUCTIONS ..................... 15
PICTURE MENU ................................................................ 33
Turning Power On and Off ................................................ 15
AUDIO MENU ................................................................... 34
Input Switching ................................................................. 16
TIMER MENU .................................................................... 34
Volume Adjustment ........................................................... 16
FUNCTION MENU ............................................................ 35
Audio Mute ........................................................................ 16
SETUP MENU ................................................................... 36
Connecting to a PC ........................................................... 27
Power Cord Connection .................................................... 28
OPERATING INSTRUCTIONS FOR PC ........ 29
Turning Power On and Off ................................................ 29
Size Switching ................................................................... 17
LANGUAGE MENU ........................................................... 37
Input Signal Screen Display ............................................. 18
OTHER FEATURES FOR PC ........................ 37
Displaying MULTI PICTURE .............................................. 18
Automatic Store ................................................................ 37
PICTURE MENU ................................................................ 19
Signal Check ..................................................................... 38
FUNCTION MENU ............................................................ 21
Power Save Mode ............................................................. 38
SETUP MENU ................................................................... 22
Automatic Store ................................................................ 23
IMAGE RETENTION OF PLASMA DISPLAY
PANEL ..................................................... 39
TROUBLESHOOTING FOR PC .................... 40
TROUBLESHOOTING ................................. 24
Symptoms That Appear to be Failures ............................. 40
OTHER FEATURES ..................................... 23
ENGLISH
FEATURES ................................................... 4
CAUTION: READ THIS BEFORE
OPERATING YOUR UNIT. .......................... 6
PRECAUTIONS ............................................. 9
COMPONENT NAMES ................................ 10
Symptoms That Appear to be Failures ............................. 24
Actions to Correct Abnormal Displays .............................. 42
PRODUCT SPECIFICATIONS ...................... 24
PRODUCT SPECIFICATIONS FOR PC ........ 43
Signal Input ....................................................................... 25
Signal Input ....................................................................... 43
Recommended Signal List ................................................ 26
Recommended Signal List ................................................ 44
5
011_PDM-5520_U_E
5
12/13/04, 9:23 AM
CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.
This Plasma monitor has been designed and manufactured to meet international safety standards, but like any electrical equipment, care must
be taken if you are to obtain the best results and safety is to be assured.
Before using this product, please read and understand the Safety Instructions thoroughly to ensure correct usage, and follow all the
instructions.
Never use the monitor if a problem occurs.
Abnormal operations such as smoke, strange odor, no image, no sound, excessive sound, damaged casing, elements, cables, penetration of
liquids or foreign matter, etc. can cause a fire or electrical shock.
In such case, immediately turn off the power switch and then disconnect the power plug from the power outlet. After making sure that the
smoke or odor has stopped, contact your dealer. Never attempt to make repairs yourself because this could be dangerous.
Do not insert liquids or foreign objects.
Penetration of liquids or foreign objects could result in fire or electrical shock. Use special caution in households where children are present.
If liquids or foreign objects should enter the projector, immediately turn off the power switch, disconnect the power plug from the power outlet
and contact your dealer.
• Do not place the monitor in a bathroom.
• Do not expose the monitor to rain or moisture.
• Do not place flower vases, pots, cups, cosmetics, liquids such as water, etc on or around the monitor.
• Do not place metals, combustibles, etc. on or around the monitor.
Never disassemble or modify the monitor.
The monitor contains high voltage components. Modification could result in fire or electrical shock.
• Never remove any fixed cover.
Do not give the monitor any shock or impact.
If the monitor should be shocked and/or broken, it could result in an injury, and continued use could result in fire or electrical shock.
If the glass panel is broken or damaged, immediately turn off the power switch, disconnect the power plug from the power outlet and contact
your dealer.
Do not place the monitor on an unstable surface.
If the monitor should be dropped and/or broken, it could result in an injury, and continued use could result in fire or electrical shock.
• Do not place the monitor on an unstable, slanted or vibranting surface such as a wobbly or inclined stand.
Do not obstruct the ventilation of the monitor.
If the ventilation is obstructed during the operation of the monitor or just after switching off the power, it could result in damage and shorten the
lifespan of your monitor due to overheating. Make sure there is ample ventilation.
• Keep a space of 100mm (10cm) or more between the sides, rear and top of the monitor and other objects such as walls.
• Do not place anything around ventilation openings of the monitor.
• Never block ventilation openings.
• Do not put the plasma display panel side up.
• Do not cover the monitor with a tablecloth, etc.
• Do not place the monitor on a carpet or bedding, or near a curtain.
Use only the correct power outlet.
Incorrect power supply could result in fire or electrical shock. Use only the correct power outlet depending on the indication on the monitor and
the safety standard.
• The enclosed power cord must be used depending on the power outlet to be used.
Be cautious of the power cord connection.
Incorrect connection of the power cord could result in fire or electrical shock.
• Do not touch the power cord with a wet hand.
• Check that the connecting portion of the power cord is clean (with no dust), before using. Use a soft and dry cloth to clean the power plug.
• Insert the power plug into a power outlet firmly. Avoid using a loose, unsound outlet or contact failure.
• Do not cut off the fitted power plug, the removal of which could lead to impaired performance. If you wish to extend the lead, obtain an
appropriate extension lead or consult your dealer.
• Should you require replacing the fuse in the molded plug with a new fuse, then please replace with new one of the same value, type and
approval as the original. Ensure the fuse cover is returned to its original position.
Be sure to keep safety ground connection.
Connect the ground terminal of AC inlet of this monitor with the ground terminal provided at the power outlet using the enclosed power cord. If
the provided plug does not fit your outlet, consult an electrician for replacement of the obsolete outlet.
6
011_PDM-5520_U_E
6
12/13/04, 9:23 AM
CAUTION: READ THIS BEFORE OPERATING YOUR UNIT. (continued)
ENGLISH
Be careful in handling the power cord and external connection cables.
If you keep using a damaged power cord or cables, it can cause a fire or electrical shock. Do not apply too much heat, pressure or tension to
the power cord and cables.
If the power cord or cables are damaged (exposed or broken core wires, etc.), contact your dealer.
• Do not place the monitor or heavy objects on the power cord and cables. Also, do not place a spread, cover, etc, over them because this
could result in the inadvertent placing of heavy objects on the concealed power cord or cables.
• Do not pull the power cord and cables. When connecting and disconnecting the power cord or cables, do it with your hand holding the plug
or connector.
• Do not place the cord near the heater.
• Do not touch the power plug just after disconnecting it from the power outlet to prevent electric shock.
• Do not touch the power plug when lightening is close to you.
• Avoid coiling the power cord and bending it sharply.
• Protect the power cord from being walked on, pinched particularly at plugs, conveniences receptacles, and the point where they exit from
the apparatus.
• Do not modify the power cord.
Be careful in handling the battery of the remote control.
Incorrect handling of the battery could result in fire or personal injury. The battery may explode if not handled properly.
• Keep the battery away from children and pets. If swallowed consult a physician immediately for emergency treatment.
• Do not allow the battery to be exposed to fire or water.
• Avoid fire or high-temperature environment.
• Do not hold the battery with metallic tweezers.
• Keep the battery in a dark, cool and dry place.
• Do not short circuit the battery.
• Do not recharge, disassemble or solder the battery.
• Do not physically impact the battery.
• Use only the battery specified in the manual of this monitor.
• Make sure the plus and minus terminals are correctly aligned when loading the battery.
• If you observe a leakage of the battery, wipe out the liquid and then replace the battery. If the liquid adheres your body or clothes, rinse well
with water.
• Obey the local laws on disposing the battery.
Be careful in moving the monitor.
Neglect could result in an injury or damage.
• Do not move the monitor during use. Before moving, disconnect the power plug and all external connections.
• You are advised to move the monitor with two persons.
• Avoid any impact or shock to the monitor; particularly take care of glass screen.
Do not put anything on top of the monitor.
Placing anything on the monitor could result in loss of balance or falling, and cause an injury or damage. Use special caution in households
where children are present.
Avoid a humid or dusty place.
Placing the monitor in a smoke, a highly humid, dusty place, oily soot or corrosive gas could result in fire or electrical shock.
• Do not place near the kitchen, a humidifier or other place where there is oil, smoke or humidity.
Avoid a high temperature environment.
The heat could have adverse influence on the monitor and other parts, and could result in transformation, melting or fire.
• Do not place the monitor, the remote control and other parts in direct sunlight or near a hot object such as heater, etc.
• Do not put the monitor in a place where the temperature is widely changing.
Remove the power cord for complete separation.
• For safety purposes, disconnect the power cord if the monitor is not to be used for prolonged periods of time.
• Before cleaning, turn off and unplug the monitor. Neglect could result in fire or electrical shock.
How to view the monitor
If you use the monitor in too dark a room, your eyes may become tired.
Please use it in a reasonably bright room.
Avoid direct rays of the sun to the screen in order to prevent eye fatigue.
Your eyes will get fatigued after viewing the monitor for long period of time.
Relax your eyes by viewing away from the monitor from time to time.
Please watch the monitor in downward direction.
7
011_PDM-5520_U_E
7
12/13/04, 9:23 AM
CAUTION: READ THIS BEFORE OPERATING YOUR UNIT. (continued)
Note on image retention
The plasma monitor illuminates phosphor to display images. The phosphor has a finite illumination life. After extended periods of illumination,
the brightness of the phosphor will be degraded to such extent that stationary images would burn-in that part of the screen as grayed-out
images.
Tips to prevent such image retention are:
- Do not display images having sharp brightness differences or high-contrast images, such as monochrome characters and graphic patterns,
for long.
- Do not leave stationary images appearing for long, but try to refresh them at appropriate intervals of time, or try to move them using screen
saver function.
- Turn down the contrast and brightness controls.
How to clean the plasma display panel of the monitor
Before cleaning the monitor, turn off the monitor and disconnect the power plug from the power outlet.
To prevent scratching or damaging the plasma display panel face, do not knock or rub the surface with sharp or hard objects. Clean the
screen with a soft cloth moistened with warm water and dry with a soft cloth. If it is not enough, then use a cloth with mild detergent. Do not
use harsh or abrasive cleaners.
How to clean the cabinet of the monitor
Use a soft cloth to clean the cabinet and control panel of the monitor. When the plasma monitor is excessively soiled dilute a neutral
detergent in water, wet and wring out the soft cloth and afterward wipe with a dry soft cloth.
Never use acid/alkaline detergent, alcoholic detergent, abrasive cleaner, powder soap, OA cleaner, car wax, glass cleaner, etc. especially
because they would cause discoloration, scratches or cracks.
Prevention of an obstacle to Radio receivers
This monitor has been designed pursuant to the international EMI standards. This is to prevent a problem to Radio receivers.
- Keep the monitor away from Radio.
- Adjust Radio antennas in order for the monitor not to receive interference.
- The antenna cable of Radio should be kept away from the monitor.
- Use a coaxial cable for antenna.
You can check if this monitor influences Radio receivers by turning off all other equipment other than the monitor.
If you find a problem receiving Radio when using the monitor, check the instructions mentioned above.
Precautions for the cable connection
- Do ensure that all connections, (including the power plug, extension leads and interconnections between the pieces of equipment), are
properly made and in accordance with the manufacturers instructions. Switch off and withdraw the power plug before making or changing
connections.
- Confirm the connector is fixed tightly when the signal cable is connected.
Also confirm the screws on the connector are tightened.
- Plug the power cord of the monitor into a different socket from that for other equipment, such as Radio etc.
- Use a plug with ground terminal and make sure that it connects to the ground.
Precaution during transportation
Please pay attention when you transport this monitor because it is heavy.
Furthermore, use the original carton box and its packaging materials when the monitor is transported.
Failure to transport the monitor in any carton except the original carton may result in damage to the monitor.
Save the original carton box and all packing material.
Do not physically impact the remote control.
A physical impact could cause damage or malfunction of the remote control.
• Take care not to drop the remote control.
• Do not place heavy objects on the remote control.
Avoid strong rays.
Any strong rays (such as direct sun rays or room lighting) onto the remote control sensors could invalidate the remote control.
Avoid radio interference.
Any interfering radiation could cause distorted images or noises.
• Avoid radio generator such as a mobile telephone, transceiver, etc. around the monitor.
Set the sound volume at a suitable level.
It is better to keep the volume level low and close the windows at night to protect the neighborhood environment.
8
011_PDM-5520_U_E
8
12/13/04, 9:23 AM
CAUTION: READ THIS BEFORE OPERATING YOUR UNIT. (continued)
ENGLISH
Precautions for the installation
- Do not use makeshift pedestals and NEVER fix legs with wood screws - to ensure complete safety, always fit the manufacturers approved
pedestal or legs with the fixings provided according to the instructions.
- Use only with the cart, pedestal, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid injury from tip-over.
- This product is designed to comply with the recommended safety standards for tilt and stability. Do not apply excessive pulling force to the
front, or top, of the cabinet that could cause the product to overturn resulting in product damage and/or personal injury.
- Follow instructions for wall, shelf or ceiling mounting as recommended by the manufacturer.
- Only use the attachments/accessories specified by the manufacturer.
- Consult your dealer if you are in any doubt about installation, operation or safety of your equipment.
Other precautions
- Do not leave equipment switched on when it is unattended unless it is specifically stated that it is designed for unattended operation or has
a stand-by mode. Switch off using the switch on the equipment and show your family how to do this. Make special arrangements for infirm
or handicapped people.
- Disposal of this product may require specific instructions pertaining to your resident region.
- Never guess or take any chances with electrical equipment of any kind - it is better to be safe than sorry!
PRECAUTIONS
• Please read this User's Manual thoroughly, especially the "IMPORTANT SAFETY INSTRUCTIONS" and the "CAUTION: READ THIS BEFORE
OPERATING YOUR UNIT." and the "PRECAUTIONS" sections. Mis-use may cause damage to your plasma monitor, which could shorten its
lifespan, or cause injury to yourself. Should you encounter any difficulty in the set-up or operation of your monitor, firstly refer to the
Troubleshooting guide at the rear of this manual.
In the unlikely event of a problem occurring with your plasma monitor, switch off at the mains sockets, pull out the plugs, and contact your
dealer immediately.
• Under no circumstances remove the rear cover of your plasma monitor.
Never guess or take any chances with electrical equipment of any kind - it is better to be safe than sorry!
• It is prohibited for the end user of this product to copy, reverse engineer or reverse compile the software included therein, save to the extent
permitted by law.
• After the plasma monitor has been turned on for any length of time, you will notice that the screen becomes warm. Please note that this is
normal.
Sometimes the screen might have some tiny bright or dark spots. Please note that this is normal.
• To prevent scratches or damages to the plasma display panel, do not knock or rub the surface with sharp or hard objects.
9
011_PDM-5520_U_E
9
12/13/04, 9:23 AM
COMPONENT NAMES
Front
Main Unit
Cabinet
(front frame)
Panel
Pedestal (option)
Control panel
• Adjustment buttons are located
on the bottom.
• The back cover is provided with
indications to distinguish the
adjustment buttons.
Indicating lamp 15
Remote-control
receiver
11
•The main power switch is located at the
back, on the lower surface.
Menu button 32
Main power switch 15
–
+
INPUT SELECT button
16
VOLUME
(OK button)
UP/DOWN
RECALL button 18
buttons 16
( SELECT button)
(
ADJUST
SIZE
button 17
buttons)
( SELECT button)
SUB-POWER button 15
スピーカー端子
(6 12W)
• ( ) indicates the function while the MENU is displayed on the screen.
Caution when moving the main unit
Rear
• As this product is heavy, whenever it is moved, two or
more people are required to transport it safely.
• Whenever carrying this product, hold it by the top and
bottom on both ends. Attached parts could come loose,
causing the product to fall and possibly causing injury.
External
speaker
terminals
External
speaker
terminals
13
13
スピーカー端子
(6 12W)
スピーカー端子
(6 12W)
External device connection terminals
13
10
012_PDM-5520_U_E
10
12/13/04, 9:23 AM
27
COMPONENT NAMES (continued)
POWER OFF button 15
ENGLISH
Remote control
15 POWER ON/OFF button
POWER ON button 15
MUTE button 16
16 VOLUME UP/DOWN buttons
RGB/VIDEO buttons 16
PINP button 18
RGB 1
RGB 2
MUTE
VOL
AV1
AV2
AV3
AV4
AUTO
PIN P
SIZE
RECALL
AUTO button 32
17 SIZE button
18 RECALL button
MENU
18 RETURN button
OK
MENU button 32
ID
32 SELECT/ADJUST button
ID SET
ID button 32
32 ID SET button
OK button 32
Loading Batteries
1. Open the battery cover.
• Slide back and remove the battery
cover in the direction of the arrow.
Handling the Remote Control
Use the remote control within 5m from the front of the unit, within a
30 degree arc either side of the remote control sensor.
2. Load the batteries.
• Load the two Size AA batteries included, matching polarity
markings on the batteries to those on
the case.
With in 30
degrees
With in 30
degrees
About 3m
About 3m
About 5m
RGB 1
RGB 2
MUTE
VOL
AV1
AV2
AV3
AV4
AUTO
PINP
SIZE
RECALL
MENU
OK
3. Close the battery cover.
ID
ID SET
• Replace the battery cover in the
direction of the arrow and snap it back
into place.
CAUTION
ATTENTION
• Do not use new and old batteries together. The batteries could
explode or leak, resulting in fires, physical injury, or stains.
• When loading batteries, observe their correct polarities as
marked on the product. If loaded in the wrong direction, the
batteries could explode or leak, resulting in fires, physical injury,
or stains.
• Do not drop or exert undue force on the remote control.
• To avoid possible failures. Do not splash the remote control with
water or put it on a wet object.
• If you do not intend to use the remote control for an extended
period of time, remove the batteries from it.
• If the remote control begins to lack responsiveness, replace the
batteries.
• Strong light such as direct sunlight impinging on the
photoreceptor of the remote control can cause operational
failure. Position this unit to avoid direct contact with such light.
012_PDM-5520_U_E
11
12/13/04, 9:23 AM
11
INSTALLATION INSTRUCTIONS
Installation
• If you have purchased the model without the pedestal attached:
When installing the monitor, use the optional pedestal.
The pedestal has been used for the illustrations in this manual.
CAUTION
• Use one of commercially available mount units to install this product. A mount of insufficient
strength or inadequate design can cause overturning or dropping and result in fire, electrical
shock or injury. Please note that our company assumes absolutely no responsibility for
personal injuries or property damage caused by improper installation.
• Installation of the wall mount unit and ceiling mount unit can be dangerous, so do not attempt
this work yourself. Ask your dealer to provide the name of a qualified installer.
• In order to prevent an internal temperature increase, maintain a space of 10cm (4 inches :
For a desktop set-up) or more between the sides and other objects such as walls, etc.,
so that the ventilation holes are not blocked. (✻)
10cm (4 inches) or more*
cord or chain
clamp
Wall or Pillar
Anti-tumble measures
CAUTION
Have this unit mounted in a stable place. Take measures to prevent it from tumbling down to avoid possible physical injury.
Securing to a wall or pillar
Use a commercially available cord or chain, and a clamp to secure the set to a firm wall or
pillar.
Hook
cord or chain
Cord or Chain
clamp
Wall or Pillar
Securing to a desktop
1)Using wood screws (two), fasten the set to the clamping screw holes on the rear of the pedestal as shown.
2)Using commercially available wood screws, secure the set firmly in position.
Wood screw
Two places
12
012_PDM-5520_U_E
12
12/13/04, 9:23 AM
INSTALLATION INSTRUCTIONS (continued)
to 9 )
ENGLISH
Read CAUTION: READ THIS BEFORE OPERATING YOUR UNIT. and PRECAUTIONS ( 6
carefully to ensure maximum safety before proceeding to these steps:
• Choose a safe, level location to install the product.
• Install the monitor in a location with easy access to a power socket.
• Make sure that the power switch of this device is turned off.
Connecting to Video Imaging Device
(1) Make sure that the power switch of the monitor is turned off.
(2) Make sure that the power switch of the imaging device is turned off.
(3) Use a commercially available cable and connector to connect the signal input terminal on the rear panel of this
device and the signal output terminal of the imaging device.
Monitor rear panel
Speaker (R)
スピーカー端子
(6Ω12W)
Speaker (L)
スピーカー端子
(6Ω12W)
To audio input
terminals
To composite
input terminal
Power
cord
20
18
16
14
12
10
21 19
17
15
13
11
9
8
7
6
5
4
3
DVD player
2
Set-Top Box
1
VCR
To audio output
terminals
To component
output terminals
To component
input terminals
To composite
output terminal
To audio output
terminals
To S video output
terminal
Do not connect both
plugs at the same time.
Use either of them.
To audio output
terminals
S-video/Composite video
To component
output terminals
To component
input terminals
Adaptor
Use if the
video
equipment
has an
S-video
input terminal.
[An example of connecting video imaging device]
Video disc player
VCR
• If video equipment with an S video output terminal is used,
connection with S video cable is recommended to provide finer
video quality. (If the S-video input terminal and the video input
terminal of AV3 connect to the monitor at the same time, S-video
input would govern.)
• If the OUTPUT (MONITOR) terminal is connected to an external
monitor with a 75 Ohm terminal, it is possible to view the same
image as on the monitor. But it is possible to monitor only the
composite video signal from AV1, AV2, AV3 or AV4 input that is
To Subwoofer
displayed on the screen at the time.
• If the adaptor (included) is applied to AV4 input as shown in the
To component video equipment
drawing, it is impossible to receive RGB signal.
Please use connection cable suitable
DVI-STB and RGB component setup
SUB WOOFER
for the terminal form of video
equipment.
Applicable video signals for each input terminal (See PRODUCT SPECIFICATIONS for details. 24 )
Terminal
RCA/SCART
Signal
CVBS
S-video
Component
AV1
‡
‡
AV2
‡
‡
AV3
‡
‡
AV4
‡
‡
DVI
RGB
PC
STB
RGB
Component
Refer to Setup Menu. 22
‡
Refer to Setup Menu. 22
‡
Refer to Setup Menu. 23
‡
RGB2
Remarks
‡
‡
RGB1
D-sub
‡
Refer to Setup Menu. 23
(‡ : available)
012_PDM-5520_U_E
13
12/13/04, 9:23 AM
13
INSTALLATION INSTRUCTIONS (continued)
Power Cord Connection
Connect the power cord after completing all other connections.
①
②
1 Connect the power cord to this monitor.
2 Connect the power cord plug to the power outlet.
(The type of plug is different from this drawing for some countries.)
CAUTION
• Use only the power cord provided.
• Do not use a power supply voltage other than that indicated (AC100-240V, 50/60Hz) as this may cause fire or electric shock.
14
012_PDM-5520_U_E
14
12/13/04, 9:23 AM
OPERATING INSTRUCTIONS
ENGLISH
Turning Power On and Off
Indicating lamp
• To turn the monitor power on, press the main power
switch on the monitor to ON, and then press the SUB
POWER button or the ON/OFF or ON button on the
remote control.
• To turn the monitor power off, press the SUB POWER
button or the ON/OFF or OFF button on the remote
control, and then set the main power switch on the
monitor to OFF.
• During normal use, the main power switch is set in the ON
position, and the monitor can then be turned ON/OFF using the
SUB POWER button or the ON/OFF button on the remote control.
スピーカー端子
(6 12W)
Indicating lamp
Main power switch
Indicating
lamp
Power status
Operating
Off
Off
When the main power switch is set
to OFF.
Lights red
Off
(standby)
When the main power switch is
ON, and the OFF button on the
remote control or the SUB POWER
button on the underside of the front
of the frame is OFF.
On
When the main power switch is
ON, and the ON button on the
remote control or the SUB POWER
button on the underside of the front
of the frame is ON.
Lights green
When the main power switch is
ON, and the ON button on the
remote control or the SUB POWER
Off
button on the underside of the front
Lights orange
(Power Save) of the frame is ON.
However, the indicator also light
orange when the unit is in POWER
SAVE mode.
SUB-POWER button
POWER OFF
button
POWER ON/OFF
button
POWER ON
button
When the indicating lamp lights orange or the message “No Sync.
Signal”, “Power Save” or “Invalid Scan Freq.” appears on the
screen, see “Power Save Mode” or “Symptoms That Appear to be
Failures.” 38 40
ATTENTION
RGB 1
RGB 2
MUTE
VOL
AV1
AV2
AV3
AV4
AUTO
PIN P
SIZE
RECALL
MENU
• Avoid repeatedly turning the monitor on and off at short
intervals. Failures might result from such operation.
• Turn off the main power switch if you do not plan to use the
monitor for an extended period of time.
• If a power failure occurs while the monitor is running, it will be
powered on upon recovery from the failure. Turn off the unit
main power switch before you leave the area in which the
monitor is located.
OK
ID
ID SET
15
013_PDM-5520_U_E
15
12/13/04, 9:23 AM
OPERATING INSTRUCTIONS (continued)
Volume Adjustment
The volume can be adjusted by pressing the VOL+ and
VOL- buttons of the remote control (or the + and –
volume buttons of the monitor unit).
–
Volume setting value
+
➛
INPUT SELECT button
VOLUME
UP/DOWN SIZE button
buttons
Volume 15
Adjustment status guide display
• When a button is pressed, the volume adjustment
status guide will be displayed.
MUTE button
RGB/VIDEO
buttons
RGB 1
RGB 2
MUTE
VOL
AV1
AV2
AV3
AV4
AUTO
PIN P
SIZE
RECALL
VOLUME
UP/DOWN buttons
• The volume will increase when the VOL+ (or
pressed while the guide is being displayed.
•The volume will decrease when the VOL- (or
pressed while the guide is being displayed.
+
) button is
–
) button is
SIZE button
MENU
Audio Mute
OK
The audio volume can be temporarily muted by pressing
the MUTE button of the remote control.
Input Switching
AV1
AV2
RGB2
RGB1
Volume setting value
➛
• Input can be switched by pressing the AV1, AV2, AV3,
AV4, RGB1 or RGB2 buttons of the remote control.
• Input can be switched in the sequence of AV1 ➝ AV2 ➝
AV3 ➝ AV4 ➝ RGB1 ➝ RGB2 by pressing the INPUT
SELECT button of the monitor.
Volume 15
AV3
AV4
Adjustment status guide display
(The display color will change to magenta.)
• When a button is pressed, the volume adjustment
status guide (magenta) will be displayed.
•The volume setting can be lowered by pressing the VOL- button
while the audio is mute.
•The muting can be cancelled by pressing the VOL+ button or
MUTE button while the audio is mute.
When the MUTE button of the remote control is pressed
again, the audio will be restored and the volume display
(green) will appear.
16
013_PDM-5520_U_E
16
12/13/04, 9:23 AM
Size Switching
ENGLISH
Each time the SIZE button of the remote control or the
monitor is pressed, the screen display size will change
in sequence and the status will be displayed at the
bottom of the screen.
• During VIDEO signal input (AV1, AV2, AV3, AV4, RGB1
(set to [DVI-STB]) and RGB2 (set to [Component])
4:3
Panoramic
Full
Zoom
Cinema
• The size will be fixed Full mode and not change when receiving
the component signal of 1080i/50, 1080i/60 or 720p/60.
Full
Display size selection diagram
When you want to
Play a 4:3 image in a 16:9 screen.
Play a 4:3 image in a 16:9 screen with the
height and width of the middle of the
screen enlarged on equal scales and with
both sides appearing somewhat enlarged.
Play a 16:9 VISTA size image from a 4:3
image faithfully reproduced on the 16:9
screen.
Set the display size
Input signal
Display screen
Blanking occurs on both sides.
4:3
Panoramic
(4.:3 signal)
• The 4:3 image is called a letterbox
image.
• In some cases, some slight blanking
may remain at the top and bottom.
Zoom
(Vista)
Play a 21:9 Cinema size image from a 4:3
image expanded vertically on the 16:9
screen.
Cinema
Play a 4:3 image faithfully in a 16:9 screen
in the standard vertical size and
horizontally squeezed.*
Full
Remarks
In some cases, some slight blanking may
remain at the top and bottom.
(Cinema)
* An image with an aspect ratio of 16:9
shrunk horizontally to 4:3 to display in a
4:3 screen
(Squeeze)
Vertical picture position can be adjusted for [Panoramic], [Zoom] and [Cinema] mode as follows.
1. Press the SIZE button and
SELECT buttons during picture size display.
2. The position display will appear.
3. The adjustment range of each picture size is as shown below.
[Panoramic]
- 12 to + 12
[Zoom] and [Cinema]
- 31 to + 31
4. When 1080i/60 component signal is received, vertical position can be adjusted only one step up. (The range: 0 to +1)
Position + 31
Press
Position - 31
Press
ATTENTION
Using a wide-screen monitor
• This monitor has a screen mode selection feature. If an incompatible screen mode is selected to play certain software, such as a TV
program, the image will appear different from the original. Take this into consideration when making screen mode choices.
• Use of this monitor in its enlarged display mode with the wide feature enabled in coffee shops, hotels and other establishments for
commercial or public viewing purposes could infringe on the copyright holder’s rights protected by Copyright Law.
• When a normal 4:3 image is displayed over the entire screen in the Panoramic mode, parts of the periphery of the image may disappear
and/or appear distorted in some cases. Use the 4:3 mode to view images which were created in 4:3 mode.
This mode allows 4:3 content to be viewed without picture distortion.
17
013_PDM-5520_U_E
17
12/13/04, 9:23 AM
OPERATING INSTRUCTIONS (continued)
Displaying MULTI PICTURE
If the PINP button on the remote control is pressed
MULTI PICTURE will display.
Activating the P-in-P mode from the RGB input screen
Pressing the PINP button once will display 2 pictures.
• This mode can be available from RGB1 (DVI-PC) and
RGB2 (RGB) input.
• The speaker icon can be shifted left and right by pressing the
and SELECT buttons; the audio of the video will be output from
the side on which the speaker icon is located.
• The sub-screen position can be
RGB2
selected up and down by pressing
AV1
SELECT buttons.
• When the speaker icon appears on
the left of the subscreen, as in the
illustration at right, you can use the
AV1, AV2, AV3, or AV4 buttons to
(Subscreen)
select the subscreen input mode.
• Pressing the PINP button or the
RETURN button will cancel the 2 pictures display.
• “Frequency Mode” in the Setup Menu should be set to Movie
when sub-screen is the component signal of 1080i/50 or 1080i/60.
RECALL button
PINP button
RGB 1
RGB 2
MUTE
VOL
AV1
AV2
AV3
AV4
AUTO
PIN P
SIZE
RECALL
RECALL button
AV1: Displays the VIDEO input signal of the sub-screen.
Activating the Split mode from the video input screen
Pressing the PINP button one time will display 2 pictures.
MENU
• The speaker icon can be shifted left
AV1
AV2
and right by pressing the and
SELECT buttons; the audio of the
video will be output from the side on
which the speaker icon is located.
• The same video input mode cannot
be selected for both screens at the
same time.
• Pressing the PINP button or the
RETURN button will cancel the 2 pictures display.
• When the Video input is set to RGB Video, this Split mode is not
possible.
• Refer to the table for 2 pictures (Split) mode.
RETURN button
OK
ID
ID SET
2 pictures (Split)
Input terminal
AV1~AV4
Main
AV1
~AV4
AV1
AV2
RGB1
RGB2
Sub
PAL-N
NTSC-M , PAL-M
576i, 576p
480i, 480p
1080i/50
1080i/60
720p/60
STB
Component
PAL-N
‡
‡
NTSC-M
PAL-M
‡
‡
‡
‡
‡
‡
‡
‡
‡
‡
‡
‡
‡
‡
AV1, AV2
576i 480i
576p 480p
‡
‡
1080i/50
1080i/60 720p/60
‡
‡
‡
‡
‡
‡
‡
‡
‡
‡
‡
‡
‡
RGB1
RGB2
STB
Component
Main
Sub
(‡ : available)
NOTE
• Even if the input of the horizontal / vertical synchronizing signal (or video signal) stops in the MULTI PICTURE display, the mode will not
change to power save mode.
• Please be careful since image retention will occur if the plasma monitor is left in MULTI PICTURE display state for a long period of time.
AV1
Composite
The input signal status can be displayed on the screen
by pressing the RECALL button of the remote control or
the monitor.
• The display will go out in approximately 6 seconds.
18
013_PDM-5520_U_E
18
Off-timer
On-timer
➛
➛
OFF
-- -- Min.
-- -- : -- --
12/13/04, 9:23 AM
➛
➛
Input Signal Screen Display
Input mode
Signal mode
OPERATING INSTRUCTIONS (continued)
➛
Picture Mode
Contrast
Brightness
Color
Sharpness
Tint
Color Temperature
Contrast Mode
Reset
Select OK Set
Day
+31
-31
0
+15
0
Normal
Normal
Reset
Return
OK
➛
Picture Mode
Next/Prev
Day
Return
➛
➛
Day
+31
-31
0
+15
0
Normal
Normal
Reset
Return
OK
➛
Contrast Mode
Next/Prev
Select
Normal
Return
YNR
Next/Prev
Off
➛
Picture Mode
Contrast
Brightness
Color
Sharpness
Tint
Color Temperature
Contrast Mode
Reset
Select OK Set
Select
➛
OK
➛
MENU
Audio
Timer
Function
Setup
Language
Select
OK Set
ENGLISH
PICTURE MENU
➛
OK
➛
Return
➛
➛
Day
Off
Off
On
On
Off
Off
Off
Off
Reset
Return
OK
➛
Auto Color
Next/Prev
Off
On/Off
Return
➛
YNR
CNR
Film Mode
PAL Comb Filter
LTI
CTI
Black Enhancement
Auto Color
Reset
Select OK Set
Select
➛
Day
Off
Off
On
On
Off
Off
Off
Off
Reset
Return
➛
YNR
CNR
Film Mode
PAL Comb Filter
LTI
CTI
Black Enhancement
Auto Color
Reset
Select OK Set
➛
Day
OK
Return
➛
➛
Color Temp. Adjust
Color Management
Color Decoding
Select OK Set
Color Temp. Adjust
Amplitude
Red
– 63
Green
0
Blue
– 31
Cut Off
Red
+ 31
Green
0
Blue
+ 31
Reset
Select
On/Off
On
Reset
Return
➛
Color Management
Day
OK
Return
Magenta
Red
Yellow
Green
Cyan
Blue
➛
Reset
Select
➛
Color Temp. Adjust
Color Management
Color Decoding
Select OK Set
On
+ 60
+ 30
0
+ 60
+ 30
0
Reset
Return
On/Off
➛
Color Temp. Adjust
Color Management
Color Decoding
Select OK Set
Color Decoding
Day
OK
Return
➛
RGB
Red
Green
Color
Tint
R
G
Reset
Select
B
0
+ 60
0
+ 31
Reset
Return
Exit
19
013_PDM-5520_U_E
19
12/13/04, 9:23 AM
OPERATING INSTRUCTIONS (continued)
Selected characters
▲
▲
PICTURE MENU (continued)
Day
Picture Mode
Setup hint
Day: This setting is best for very bright ambient lighting.
Night: This setting is for normal lighting conditions.
Night
Contrast
Narrows the gap between
brightness and darkness.
Broadedns the gap between
brightness and darkness.
Adjust for maximum visibility to suit the ambient brightness.
This can be adjusted further till [+40] by pressing and holding
cursor button at [+31]. The color for [+32] to [+40] numbers
will change from white to magenta. This special mode is better
for dark scenes.
For normal viewing we recommend that the Contrast is set to
[+31] or less.
“Panel Life” in the Function Menu should be set to Normal when
this Contrast setting is adjusted.
Brightness
Black is subdued for
increased overall darkness.
Black is set off for increased
overall brightness.
Depending on the source component, the picture may appear
too dark or too bright. In this case, adjust the “Brightness”
setting to suit your taste.
Color
Darkness colors.
Lightens colors.
Adjust to taste
Sharpness
Soft
Sharp
Normally set to Center position. Shift to the minus (-) side for a
softer effect and plus (+) for a sharper picture.
Tint
Enhances red and weakens
green.
Enhances green and weakens This is adjustable when receiving PAL/SECAM signal.
Then the character will be grayed out.
red.
Adjust for most realistic skin color.
Cool
Color Temperature
Normal
Warm
Normal
Auto
Black / White
Dynamic
Contrast Mode
Reset
(Selects the Reset mode)
YNR
Off
Low
Adjust to taste.
Dynamic: Emphasizes the differences between video shadings
to improve the feeling of contrast.
Normal: The gradation of an image is reproduced as faithfully
as possible.
Auto:
Detects image brightness and automatically adjusts
for natural brightness.
The original factory settings for the items of this Menu page can
be restored by pressing the OK button.
Performs picture signal noise reduction. Turn up to reduce
noise.
High
Performs color signal noise reduction. Turn up to reduce noise.
It will be fixed as Off only when selecting DVI-STB mode.
CNR
Film Mode
Off
On
On: Automatically detects the movie film material and faithfully
reproduces the original film image.
Off: Set to OFF when switching between images does not
appear natural.
PAL Comb Filter
Off
On
This is available only when receiving a PAL composite signal.
Turn On to reduce the discolorations in fine picture detail and
provide purer color.
LTI
CTI
Black Enhancement
Adjusts the sharpness of the picture signal.
Off
Low
Middle
High
Adjusts the sharpness of the color signal.
Adjusts the black level compensation.
Auto Color
Off
On
This is available only when receiving an NTSC composite/
S-Video signal. This monitors and adjusts the color to maintain
constant color levels. It also maintains natural flesh tones while
preserving fidelity of background colors.
Color Temp. Adjustment
Off
On
Turn On when you wish to change color temperature depending
on the user's preference.
Amplitude
Cut Off
Red
Brightness scenes are
decreased in reddish color.
Brighter scenes are increased
in reddish color.
Green
Brightness scenes are
decreased in greenish color.
Brighter scenes are increased
in greenish color.
Blue
Brightness scenes are
decreased in bluish color.
Brighter scenes are increased
in bluish color.
Red
Dark scenes are decreased in Dark scenes are increased in
reddish color.
reddish color.
Green
Dark scenes are decreased in Dark scenes are increased in
greenish color.
greenish color.
Blue
Dark scenes are decreased in Dark scenes are increased in
bluish color.
bluish color.
Adjust color temperature depending on the user’s preference.
These settings are independently stored in each of the 4 Color
Temperature modes.
20
013_PDM-5520_U_E
20
12/13/04, 9:23 AM
OPERATING INSTRUCTIONS (continued)
▲
▲
Selected characters
Off
Color Management
Magenta
Magenta is strengthened.
Red is weakened.
Red is strengthened.
Yellow
Yellow is weakened.
Yellow is strengthened.
Green
Green is weakened.
Green is strengthened.
Cyan
Cyan is weakened.
Cyan is strengthened.
Blue
Blue is weakedned.
Blue is strengthened.
RGB
Color Decoding
R
G
B
Red
Darkenes red only.
Lightens red only.
Green
Darkens green only.
Lightens green only.
Color
Darkens colors.
Lightens colors.
Enhances red and weakens
green.
Enhances green and weakens
red.
Tint
Setup hint
Turn On when the original balance of each color is required to
adjust to suit user preferences.
On
Magenta is weakened.
Red
ENGLISH
PICTURE MENU (continued)
This adjusts listed colors individually to make them either
deeper or more pure. These settings are independently stored
in each of the 4 Color Temperature modes.
Select the single color screen you need to adjust R/G/B level
individually depending on the user’s preference. Set it back to
RGB mode that indicates each color (R/G/B) mode after
adjusting.
Press the OK button every time the setting is changed.
This adjusts R/G/B levels or tints to make the color appear
natural. These settings are independently stored in each of
the 4 Color Temperature modes.
FUNCTION MENU
1 item is added to the Menu shown in the page 35 .
➛
➛
OK
➛
Function
Screen Saver
Screen Wipe
Black Side Panel
Video Power Save
Freeze Mode
Default Zoom
Reset
Select
Set
Off
On 60Min.
Off
Off
Split
Panoramic
Reset
Return
➛
MENU
Audio
Timer
Function
Setup
Language
Select
OK Set
➛
Selected characters
▲
▲
Function
Panel Life
Mode Display
ID Number
Inverse
Standby White
Gamma
Reset
Select
Set
Off
Video Power Save
On
Normal
Off
1
On 60Min.
Off
2.2
Reset
Return
Setup hint
This is used to reduce power consumption for video input when
there is no video signal. Setting it to On will place the monitor to
the standby mode when the AV input with no signal is selected.
21
013_PDM-5520_U_E
21
12/13/04, 9:23 AM
OPERATING INSTRUCTIONS (continued)
SETUP MENU
MENU
➛
Audio
Timer
Function
Setup
Language
Select
OK Set
➛
OK
➛
Setup
System
Color System
Video Input
Audio Input
Scart Output
RGB1
RGB2
OK Set
Setup
Color System
OK
➛
Monitor
DVI-STB
Component
HDTV
Return
AV1
AV2
AV3
AV4
Select
Auto
NTSC-M
PAL-M
PAL-N
Return
Exit
➛
Select
System 2
➛
Setup
System
Color System
Video Input
Audio Input
Scart Output
RGB1
RGB2
OK Set
OK
➛
Monitor
DVI-STB
Component
HDTV
Return
AV1
AV2
AV3
AV4
Select
Auto
Composite/Component
Auto
S-Video
Return
Exit
➛
Select
Setup
Video Input
System 2
➛
Setup
System
Color System
Video Input
Audio Input
Scart Output
RGB1
RGB2
Selected characters
OK Set
OK
Monitor
DVI-STB
Component
HDTV
Return
▲
▲
Select
System 2
System1
System
System2
➛
Setup
Audio Input
AV1
AV2
AV3
AV4
Select
Stereo
L/Mono
Stereo
L/Mono
Return
Exit
Setup hint
Do not change the original setting.
(System1 : Europe/Asia, System2 : North America)
Color System
Auto
PAL-N
AV1
NTSC-M
PAL-M
This should correspond to the color system of the signal from
the equipment that is connected to the AV1 video input terminal.
• Normally, set this to Auto. The system of the input signal will
be automatically recognized.
• If the input signal contains a lot of noise or has a low level at
Auto and the operation is erratic, set this to match the input
signal.
• When the component signal is received, this setting is not
available (grayed out).
AV2
AV3
(Same to AV1)
AV4
Video Input
AV1
AV2 (1st step)
AV2 (2nd step)
AV4
Auto
RGB
HDTV
SDTV/DVD
Composite/Component
Auto
HDTV
S-Video
SDTV/DVD
Composite
This should correspond to the signal mode of the signal from
the equipment that is connected to AV1 video input terminal.
• Normally, set this to Auto. The signal mode of the input signal
will be automatically recognized.
• If the input signal contains a lot of noise or has a low level at
Auto and operation is erratic, set this to match the input
signal.
This should correspond to the signal mode of the signal from
the equipment that is connected to AV2 video input terminal.
This step should be set only when [Composite/Component] is
selected on the 1st step. The procedure is same as for AV1.
• If the signal from the equipment that is connected to the AV4
Scart input terminal is S-Video or Composite, set this to
correspond to that signal.
• If the signal is RGB, it will be automatically recognized and
this setting will have no effect.
22
013_PDM-5520_U_E
22
12/13/04, 9:23 AM
OPERATING INSTRUCTIONS (continued)
▲
▲
Selected characters
ENGLISH
SETUP MENU (continued)
Setup hint
Audio Input
Stereo
AV1
This should correspond to the audio signal from the
equipment that is connected to the AV1 audio input
terminal. If the signal is monaural audio, set this to L/Mono.
L/Mono
AV2
(Same to AV1)
AV3
AV4
Scart Output
Not Available (grayed out)
RGB1
DVI-PC
RGB2 (1st step)
RGB
Auto
RGB2 (2nd step)
DVI-STB
This should correspond to the signal mode of the signal
from the equipment that is connected to the RGB1 DVI
terminal.
Component
This should correspond to the signal mode of the signal
from the equipment that is connected to the RGB2
D-sub terminal.
HDTV
This step should be set only when [Component] is
selected on the 1st step.
This should correspond to the signal mode of the signal
from the equipment that is connected to the RGB2
D-sub terminal.
• Normally, set this to Auto. The signal mode of the input
signal will be automatically recognized.
• If the input signal contains a lot of noise or has a low
level at Auto and the operation is found erratic, set this
to match the input signal.
SDTV/DVD
OTHER FEATURES
Automatic Store
Approximately 1 sec. after adjustment is completed, the adjustments will be recorded as shown in the table below.
Menu
Display
Registration condition
Picture Mode
Contrast
Brightness
Color
Sharpness
Tint
Color Temperature
Contrast Mode
YNR
CNR
Film Mode
PAL Comb Filter
LTI
CTI
Black Enhancement
Auto Color
Color Temp. Adjust
R Amplitude
G Amplitude
B Amplitude
R Cut Off
G Cut Off
B Cut Off
1 setting is registered.
For every input function and every
Picture Mode, 1 setting is
registered.
Function
Setup
For every Color Temperature, 1
setting is registered.
For every input function and every
Picture Mode, 1 setting is registered.
Magenta 1 setting is registered.
Red
Color Management
Menu
Display
Yellow
Green
Cyan
Blue
Color Decoding
Red
Green
Color
Tint
Video Power Save
System
Color System
AV1
AV2
AV3
AV4
Video Input
AV1
AV2
AV4
Audio Input
AV1
AV2
AV3
AV4
RGB1
RGB2
Registration condition
1 setting is registered.
For every Color Temperature, 1
setting is registered.
For every input function and every
Picture Mode, 1 setting is registered.
1 setting is registered.
1 setting is registered.
1 setting is registered.
1 setting is registered.
1 setting is registered.
• The previously recorded items will be lost.
013_PDM-5520_U_E
23
12/13/04, 9:23 AM
23
TROUBLESHOOTING
Symptoms That Seemingly Appear to be Failures
Make the checks suggested below depending on the symptoms observed. If the symptoms remain uncorrected contact your dealer.
CAUTION
Customer servicing can be hazardous.
Point to check
See page
• This sometimes occurs when a component output VCR such
as the 480i is connected.
This is not a malfunction; therefore, please take note that this
may occur. When it does occur, change to composite output,
or S-Video output.
–
Symptom
• The screen becomes dark and the images cannot be seen
during VCR special playback (fast forward, rewind).
PRODUCT SPECIFICATIONS
Panel
Display dimensions
Approx. 55 inches (1229 (H) x 691 (V) mm, diagonal 1410 mm)
Resolution
1366 (H) x 768 (V) pixels
Net dimensions (excluding pedestal)
1394 (W) x 857 (H) x 105 (D) mm
Net weight (excluding pedestal)
63.5kg
Ambient
conditions
Temperature
Operating : 5˚C to 35˚C, Storage : 0˚C to 40˚C
Relative humidity
Operating : 20% to 80%, Storage : 20% to 90% (non-condensing)
Power supply
AC100 - 240V, 50/60Hz
Power consumption/at standby
530W / <3W
Audio output
speaker 12W + 12W (6 ), sub woofer (RCA)
(RGB input)
Input terminals
RGB1 DVI input terminal (DVI-D)
RGB1 audio input terminal (3.5mm Stereo Mini Jack)
RGB2 analog RGB input terminal (D-sub 15-pin)
RGB2 audio input terminal (3.5mm Stereo Mini Jack)
Video signals
0.7 V/1.0 Vp-p, analog RGB (Recommended Signal)
480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
Sync signals
H/V separate, TTL level [2K ]
H/V composite, TTL level [2K ]
Sync on green, 0.3 Vp-p [75 ]
Input signals
Recommended signal
47 modes
26
45
(Video input)
Input terminals
AV1: composite video input terminal (RCA)
AV1: Y PB PR video input terminal (RCA)
AV1: L/R audio input terminal (RCA)
AV2: composite video input terminal (RCA)
AV2: Y/G PB/B PR/R video input terminal (RCA)
AV2: L/R audio input terminal (RCA)
AV3: composite video input terminal (RCA)
AV3: S video input terminal (RCA)
AV3: L/R audio input terminal (RCA)
AV4: composite video / S video / RGB / L/R audio input terminal (Scart)
Video signals
AV1: NTSC-M, PAL-M, PAL-N
AV1: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
AV2: NTSC-M, PAL-M, PAL-N
AV2: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60, RGB
AV3: NTSC-M, PAL-M, PAL-N
AV4: NTSC-M, PAL-M, PAL-N
AV4: RGB
Input signals
Video output Signal
OUTPUT (MONITOR): composite video monitor-output terminal (RCA)
OUTPUT (MONITOR): L/R audio monitor-output terminal (RCA)
AV4: composite video / L/R audio monitor-output terminal (SCART)
Recommended signal
13 modes
26
• The monitor takes at least 30 minutes to attain optimal picture quality.
24
013_PDM-5520_U_E
24
12/13/04, 9:23 AM
PRODUCT SPECIFICATIONS (continued)
ENGLISH
Signal Input
RGB terminal (D-sub 15-pin connector)
Pin
5 4 3 2 1
0 9 8 7 6
@ ! ~ = -
Input signal
1
R (PR/CR)
2
G or sync on green (Y)
3
B (PB/CB)
4
No connection
5
No connection
6
R.GND (PR/CR, GND)
• When different kinds of input signals are simultaneously input to
the monitor via a graphics board or the like, the monitor will
automatically select the signals in the following priority order:
7
G.GND (Y, GND)
Sync signal type
Priority
8
B.GND (PB/CB, GND)
H/V seperate sync.
1
9
No connection
H/V composite sync.
2
10
GND
sync. on Green *
3
11
No connection
12
[SDA]
13
H. sync or H/V composite sync
14
V. sync. [V.CLK]
15
[SCL]
*There may be instances when correct display is not possible
even when displaying the signals listed on the following page. In
this case, use H/V seperate sync or H/V composite sync.
( ) : With component input
S-input connector pin specifications
Pin
3
Input signal
1
Y
2
Y-GND
3
C
4
C-GND
Frame
GND
1
2
4
Scart connector pin specifications
Pin
Signal
Pin
Signal
1
AUDIO OUT (RIGHT)
12
Not Used
2
AUDIO IN (RIGHT)
13
RGB-R GND
3
AUDIO OUT (LEFT/MONO)
14
GND
4
AUDIO GND
15
RGB-R / S.VHS CHROMINANCE IN
5
RGB-B GND
16
BLANKING SIGNAL
6
AUDIO IN (LEFT/MONO)
17
COMPOSITE VIDEO GND
7
RGB-B IN
18
BLANKING SIGNAL GND
8
AUDIO/RGB SWITCH / 16:9
19
COMPOSITE VIDEO OUT
9
RGB-G GND
20
COMPOSITE VIDEO / S.VHS LUMINANCE IN
10
Not Used
21
GND / SHIELD (CHASSIS)
11
RGB-G IN
20
18
16
14
12
10
21 19
17
15
13
11
9
8
7
6
5
4
3
2
1
25
014_PDM-5520_U_E
25
12/13/04, 9:24 AM
PRODUCT SPECIFICATIONS (continued)
Recommended Signal List
With Digital RGB signal input (RGB1 input)
No.
Signal Name
1
VGA
2
Signal Mode
Vertical frequency
Resolution
(Hz)
Horizontal Dot clock Setup Menu Condition
frequency frequency
DVI-STB
DVI-PC
(kHz)
(MHz)
640 X 400
70.08
31.47
25.18
‡
640 X 480
59.94
31.47
25.18
‡
864 X 480
59.94
31.47
34.24
‡
4
640 X 480
72.81
37.86
31.50
‡
5
640 X 480
75.00
37.50
31.50
‡
6
640 X 480
85.01
43.27
36.00
‡
36.00
‡
W-VGA
3
7
800 X 600
56.25
35.16
8
800 X 600
60.32
37.88
40.00
‡
800 X 600
72.19
48.08
50.00
‡
10
800 X 600
75.00
46.88
49.50
‡
11
800 X 600
85.06
53.67
56.25
‡
12
1024 X 768
60.00
48.36
65.00
‡
75.00
‡
‡
VESA
9
13
1024 X 768
70.07
56.48
14
1024 X 768
75.03
60.02
78.75
Remarks
‡
WVGA type : On
15
480p
720 X 480
59.94
31.47
27.00
‡
EIA-861
16
720p/60
1280 X 720
60.00
45.00
74.25
‡
EIA-861
17
1080i/60
1920 X 1080
60.00
33.75
74.25
‡
EIA-861
(‡ : acceptable)
With Composite Input (AV1~AV4 input) and S-video Input (AV3 input).
No.
Signal Name
Signal Mode
Vertical frequency
Resolution
(Hz)
Horizontal frequency
(kHz)
Dot clock frequency
(MHz)
1
NTSC-M
PAL-M
525
59.94
15.73
–
2
PAL-N
625
50.00
15.63
–
Horizontal frequency
(kHz)
Dot clock frequency
(MHz)
15.73
15.63
–
Remarks
With R, G, B Video input (AV2 and AV4 input).
No.
1
Signal Name
Signal Mode
Vertical frequency
Resolution
(Hz)
(NTSC-M, PAL-M)
(PAL-N)
525
625
59.94
50.00
Remarks
With component input (AV1, AV2 and RGB2-component input).
No.
Signal Name
Signal Mode
Vertical frequency
Resolution
(Hz)
Horizontal frequency
(kHz)
Dot clock frequency
(MHz)
1
576i
576
50.00
15.63
–
2
480i
480
59.94
15.73
–
3
576p
576
50.00
31.26
–
4
480p
480
59.94
31.47
–
5
1080i/50
1080
50.00
28.13
–
6
1080i/60
1080
60.00
33.75
–
7
720p/60
720
60.00
45.00
–
Remarks
• The monitor differentiates the signal modes according to the horizontal and vertical sync signal polarities. Note that different signals having
all these elements alike may be handled as the same signal.
• Displaying images with more than 768 lines of vertical resolution at Full display (compressed display) can result in the interpolation of stripes.
26
014_PDM-5520_U_E
26
12/13/04, 9:24 AM
INSTALLATION INSTRUCTIONS FOR PC
ENGLISH
Read CAUTION: READ THIS BEFORE OPERATING YOUR UNIT. and PRECAUTIONS ( 6 to 9 )
carefully to ensure maximum safety before proceeding to these steps:
• Choose a safe, level location to install the product.
• Install the monitor in a location with easy access to a power socket.
• Make sure that the power switch of this device is turned off.
Connecting to a PC
(1) Make sure that the display signal of the personal computer to be used is compatible with the specifications of this
device.
• See “Product Specifications for PC” concerning the specifications of this device. 43 ~ 45
(2) Make sure that the power switch of the personal computer is turned off.
(3) Connect the signal input terminal (RGB 1 or RGB 2) on the rear panel of this monitor to the display signal output
terminal of the personal computer.
• Use a cable that fits the input terminal of this device and the output terminal of the personal computer.
• Depending on the type of personal computer being connected, the use of an optional conversion adapter or the adapter provided with
the personal computer may be necessary in some cases. For details, refer to the instruction manual of the personal computer, or ask the
personal computer manufacturer or your local retail dealer.
Monitor rear panel
Speaker (R)
Speaker (L)
スピーカー端子
(6Ω12W)
スピーカー端子
(6Ω12W)
Power cable
connector
SUB WOOFER
Power
cord
(DVI)
To signal
output
terminal
(D-sub)
3.5mm
Stereo
mini jack
To signal
output
terminal
To audio
output
terminal
(RCA pin plug)
To audio
sub woofer
PC
27
014_PDM-5520_U_E
27
12/13/04, 9:24 AM
INSTALLATION INSTRUCTIONS FOR PC (continued)
Power Cord Connection
Connect the power cord after completing all other connections.
①
②
1 Connect the power cord to this monitor.
2 Connect the power cord plug to the power outlet.
(The type of plug is different from this drawing for some countries.)
CAUTION
• Use only the power cord provided.
• Do not use a power supply voltage other than that indicated (AC100-240V, 50/60Hz) as this may cause fire or electric shock.
28
014_PDM-5520_U_E
28
12/13/04, 9:24 AM
OPERATING INSTRUCTIONS FOR PC
ENGLISH
Turning Power On and Off
Indicating lamp
• To turn the monitor power on, press the main power
switch on the monitor to ON, and then press the SUB
POWER button or the ON/OFF or ON button on the
remote control.
• To turn the monitor power off, press the SUB POWER
button or the ON/OFF or OFF button on the remote
control, and then set the main power switch on the
monitor to OFF.
• During normal use, the main power switch is set in the ON
position, and the monitor can then be turned ON/OFF using the
SUB POWER button or the ON/OFF button on the remote control.
スピーカー端子
(6 12W)
Indicating lamp
Main power switch
Indicating
lamp
Power status
Operating
Off
Off
When the main power switch is set
to OFF.
Lights red
Off
(standby)
When the main power switch is
ON, and the OFF button on the
remote control or the SUB POWER
button on the underside of the front
of the frame is OFF.
On
When the main power switch is
ON, and the ON button on the
remote control or the SUB POWER
button on the underside of the front
of the frame is ON.
Lights green
When the main power switch is
ON, and the ON button on the
remote control or the SUB POWER
Off
Lights orange
(Power Save) button on the underside of the front
of the frame is ON.
However, the indicator also light
orange when the unit is in POWER
SAVE mode.
SUB-POWER button
POWER OFF
button
POWER ON/OFF
button
POWER ON
button
When the indicating lamp lights orange or the message “No Sync.
Signal”, “Power Save” or “Invalid Scan Freq.” appears on the
screen, see “Power Save Mode” or “Symptoms That Appear to be
Failures.” 38 40
ATTENTION
RGB 1
RGB 2
MUTE
VOL
AV1
AV2
AV3
AV4
AUTO
PIN P
SIZE
RECALL
MENU
• Avoid repeatedly turning the monitor on and off at short
intervals. Failures might result from such operation.
• Turn off the main power switch if you do not plan to use the
monitor for an extended period of time.
• If a power failure occurs while the monitor is running, it will be
powered on upon recovery from the failure. Turn off the unit
main power switch before you leave the area in which the
monitor is located.
OK
ID
ID SET
29
014_PDM-5520_U_E
29
12/13/04, 9:24 AM
OPERATING INSTRUCTIONS FOR PC (continued)
Volume Adjustment
The volume can be adjusted by pressing the VOL+ and
VOL- buttons of the remote control (or the + and –
volume buttons of the monitor unit).
Volume setting value
➛
+
–
VOLUME UP/DOWN
buttons
Volume 15
INPUT SELECT button
Adjustment status guide display
• When a button is pressed, the volume adjustment
status guide will be displayed.
• The volume will increase when the VOL+ (or + ) button is
pressed while the guide is being displayed.
•The volume will decrease when the VOL- (or – ) button is
pressed while the guide is being displayed.
RGB button
MUTE button
RGB 1
RGB 2
MUTE
VOL
AV1
AV2
AV3
AV4
AUTO
PIN P
SIZE
RECALL
VOLUME
UP/DOWN buttons
MENU
Audio Mute
The audio volume can be temporarily muted by pressing
the MUTE button of the remote control.
OK
ID
ID SET
Volume setting value
➛
Volume 15
Input Switching
• Input can be switched by pressing the RGB1 or RGB2
buttons of the remote control.
Adjustment status guide display
(The display color will change to magenta.)
• When a button is pressed, the volume adjustment
status guide (magenta) will be displayed.
•The volume setting can be lowered by pressing the VOL- button
while the audio is mute.
•The muting can be cancelled by pressing the VOL+ button or
MUTE button while the audio is mute.
When the MUTE button of the remote control is pressed
again, the audio will be restored and the volume display
(green) will appear.
30
014_PDM-5520_U_E
30
12/13/04, 9:24 AM
OPERATING INSTRUCTIONS FOR PC (continued)
RGB 2
MUTE
VOL
AV1
AV2
AV3
AV4
AUTO
PIN P
SIZE
RECALL
ENGLISH
RGB 1
RECALL button
MENU
OK
SIZE button
ID
ID SET
RECALL button
SIZE button
Size Switching
Each time the SIZE button of the remote control or the monitor is pressed, the screen display area will change in
sequence and the status will be displayed at the bottom of the screen.
Normal
Real
Full
Zoom3
Zoom1
Zoom2
* This mode is only available for VGA (640 X 480), SVGA (800 X 600), XGA (1024 X 768), WVGA (1280 X 768).
Display area selection diagram (RGB input)
Resolution
Full display
Display
Full
Circular display
Normal
Real
Zoom1
Zoom2
Zoom3
640 X 480
(VGA)
800 X 600
(SVGA)
1024 X 768
(XGA)
1280 X 768
(WXGA)
1280 X 1024
(SXGA)
can’t select
1600 X 1200
(UXGA)
1366 X 768
(WXGA)
can’t select
Processes such as compression (thinning) and expansion are performed for the above signal display. Because of this, there is a possibility
that flicker may become noticeable on Zoom (1 ~ 3) depending on the display contents. If this occurs, turning the Vertical Filter On 36 can
reduce the flicker.
Input Signal Screen Display
The input signal status can be displayed on the screen by pressing the RECALL button of the remote control or the
monitor.
• The display will go out approximately 6 seconds.
Off-timer
On-timer
➛
➛
OFF
-- -- Min.
-- -- : -- --
➛
➛
➛
➛
RGB2
RGB
H : 48.4kHz
V : 60.1 Hz
Input mode
Signal mode
Input horizontal frequency
Input vertical frequency
31
014_PDM-5520_U_E
31
12/13/04, 9:24 AM
OPERATING INSTRUCTIONS FOR PC (continued)
Using the Menu Screen
(on-screen display system)
AUTO button
RGB 1
RGB 2
MUTE
VOL
AV1
AV2
AV3
AV4
AUTO
PIN P
SIZE
RECALL
RETURN buttons
MENU
MENU button
OK button
When the MENU button is pressed, the adjustment menu
screen will be displayed; from there, PC signal
adjustment and setting is possible by using the SELECT
button, ADJUST button and OK button.
• Refer to 33 ~ 37 concerning the adjustment items and the
settings.
OK
ID
ID SET
ID button
SELECT/ADJUST
buttons
ID SET button
Example: Selecting the Picture screen
1. Press the MENU button to display the Main Menu
screen.
MENU
Automatic adjustment of
Screen Position and the Clock
Adjustment of the screen to a position suitable for the
PC signal and the clock adjustment can be performed
automatically by pressing the AUTO button of the remote
control.
CAUTION
2. Press the OK button to display the Picture Menu
screen. (Use the ▲ and ▼ SELECT buttons to select
other items.)
OK
Perform this adjustment for each input (RGB1 or RGB2) and for
each signal.
* Depending on the signal, satisfactory adjustment may not be
possible in some cases. In such cases, adjust by referring to the
Setup Menu item.
Independant Operation of
Multiple Monitors (ID No)
Setting the ID No. of the remote control allows separate
control of up to a maximum of seven monitors.
Remote control ID No. 2 (initially ID No. 1) can be set by
pressing the ID SET button for 2 sec. or more while
holding down the ID button. The number will be
incremented (2···6➝7➝1➝2) when this button pressed
continuously.
➛
➛
ID Number
Monitor
[1]
R/C
[1]
The remote control ID No. can be
checked by pressing the ID SET button
while holding down the ID button.
Contrast
Next / Prev
:
:
:
:
:
:
+ 31
– 31
0
+ 31
Off
Normal
Reset
Exit
+ 31
Adjust
• Press the RETURN button to return to the previous screen.
• If there is no operation for a period of one minute, the
Adjustment Menu screen will be closed automatically.
Monitor ID No.
The ID remote control is operated by pressing the
various buttons while holding down the ID button;
Operation is possible only when the remote control and
monitor ID Nos. are the same.
• The remote control can be operated normally by pressing the
various remote control buttons without holding down the ID button.
• Set the monitor using the ID No. of Function MENU. 35
32
32
Contrast
Brightness
Color
Tint
Picture Enhancement
Color Temperature
Color Temp. Adjust
Reset
Select
Return
3. Use the ▲ and ▼ SELECT buttons to select the item to
be adjusted and then use the and ADJUST
buttons to adjust (example: Contrast).
Remote control ID No.
015_PDM-5520_U_E
Audio
Timer
Function
Setup
Language
Select
OK Set
12/13/04, 9:24 AM
Return
OPERATING INSTRUCTIONS FOR PC (continued)
Audio
Timer
Function
Setup
Language
Select
OK Set
OK
➛
Contrast
Brightness
Color
Tint
Picture Enhancement
Color Temperature
Color Temp.Adjust
Reset
Select
OK Set
:
:
:
:
:
:
+ 31
– 31
0
+ 31
Off
Normal
OK
➛
Reset
Return
Contrast
Next / Prev
Return
➛
➛
:
:
:
:
:
:
+ 31
– 31
0
+ 31
Off
Normal
OK
➛
Reset
Return
Color Temperature
Next/Prev
Select
Normal
Return
➛
Contrast
Brightness
Color
Tint
Picture Enhancement
Color Temperature
Color Temp. Adjust
Reset
Select
OK Set
+ 31
Adjust
➛
➛
MENU
ENGLISH
PICTURE MENU
➛
Selected characters
:
:
:
:
:
:
+ 31
– 31
0
+ 31
Off
Normal
OK
➛
Reset
Return
▲
▲
Contrast
Brightness
Color
Tint
Picture Enhancement
Color Temperature
Color Temp.Adjust
Reset
OK Set
Select
Color Temp. Adjust
Amplitude
Red
– 63
Green
0
Blue
– 31
Cut Off
Red
+ 31
Green
0
Blue
+ 31
Reset
Select
On/Off
On
Reset
Return
Setup hint
Adjust for maximum visibility to suit the ambient brightness.
Adjust further till [+40] by pressing and holding
cursor button
at [+31]. The color for [+32] to [+40] numbers will change from
white to magenta. This special mode is better for dark scenes.
For brighter scene some parts of the picture might not be clear.
We recommend to set at [+31]. "Panel Life" in the Function Menu
should be set to Normal when Contrast setting is adjusted.
Contrast
Narrows the gap between
brightness and darkness.
Broadens the gap between
brightness and darkness.
Brightness
Black is subdued for
increased overall darkness.
Black is set off for increased
overall brightness.
Adjust to taste.
Color
Darkens colors.
Lightens colors.
Adjust to taste.
Tint
Enhances red and weakens
green.
Enhances green and weakens This is not available for adjustment when receiving PAL/SECAM signal.
In this case the character will be grayed out. Adjust for the most realistic skin color.
red.
Off
Picture Enhancement
Cool
Color Temperature
Color Temp. Adjustment
Amplitude
Normal
Middle
Warm
Off
High
Black / White
On
Red
Brighter scenes are
decreased in reddish color.
Brighter scenes are increased
in reddish color.
Green
Brighter scenes are
decreased in greenish color.
Brighter scenes are increased
in greenish color.
Sets the clarity of small details to the desired level.
Normally set to Normal.
Turn On when you wish to change color temperature to suit user
preferences.
Brighter scenes are increased
Adjust color temperature to suit user preference. These settings
in bluish color.
are independently stored in each of the 4 Color Temperature
Dark scenes are decreased in Dark scenes are increased in modes.
reddish color.
reddish color.
Brighter scenes are
decreased in bluish color.
Blue
Cut Off
Low
Red
Green
Dark scenes are decreased in Dark scenes are increased in
greenish color.
greenish color.
Blue
Dark scenes are decreased in Dark scenes are increased in
bluish color.
bluish color.
Reset
(Selects the Reset mode)
The original factory settings for the items of this Menu page can
be restored by pressing the OK button.
33
015_PDM-5520_U_E
33
12/13/04, 9:24 AM
OPERATING INSTRUCTIONS FOR PC (continued)
AUDIO MENU
➛
➛
OK
➛
Selected characters
Movie
Audio Mode
Audio
Audio Mode
Treble
Bass
Balance
SRS TruBass
Matrix Surround
Perfect Volume
Reset
Select
Set
▲
▲
MENU
Audio
Timer
Function
Setup
Language
Select
OK Set
Music
Speech
Favorite
:
:
:
:
:
:
:
Movie
+ 10
– 10
0L
Middle
Off
Off
Reset
Return
R
Setup hint
Movie: This selects the audio mode suitable for Movies.
Music: This selects the audio mode suitable for Music.
Speech: This selects the audio mode suitable for News, Talk
show etc.
Favorite: This mode should be adjusted to suit your preference.
Treble
Suppresses treble.
Enhances treble.
Adjust to taste.
Bass
Suppresses bass.
Enhances bass.
Adjust to taste.
Balance
Suppresses right-side sound.
Suppresses left-side sound.
Adjust to taste.
Middle
SRS TruBass takes advance of the ability of the human ear to
distinguish between two different tones. By using this ability,
TruBass gives enhanced bass sound that otherwise would not
be heard. Adjust it depending on the user’s preference.
Off
SRS TruBass
Low
High
Matrix Surround
Off
On
This features the spacious sound effects of a stadium.
Perfect Volume
Off
On
This will automatically adjust volume so each channel and input
has the same average volume level.
Reset
(Selects the Reset mode)
The original factory settings for the items of this Menu page can
be restored by pressing the OK button.
TIMER MENU
➛
➛
Selected characters
OK
➛
--Min.
30Min.
60Min.
120Min.
90Min.
Off Timer
(- - : )- minutes
On Timer
Timer
Off Timer
On Timer
Select
▲
▲
MENU
Audio
Timer
Function
Setup
Language
Select
OK Set
(- - : )- minutes
34
:
30Min.
: --:-Return
Setup hint
This function automatically sets the power to standby status
when the indicated time period has elapsed.
This automatically sets the power from standby to ON when the
indicated time period has elapsed. The settable time is
00:00~11:59. Input the required time by SELECT buttons on
the remote control.
34
015_PDM-5520_U_E
Adjust
12/13/04, 9:24 AM
OPERATING INSTRUCTIONS FOR PC (continued)
➛
➛
OK
➛
Function
Screen Saver
Screen Wipe
Black Side Panel
Video Power Save
Freeze Mode
Default Zoom
Reset
Select
Set
Off
On 60Min.
Off
Off
Split
Panoramic
Reset
Return
➛
MENU
Audio
Timer
Function
Setup
Language
Select
OK Set
ENGLISH
FUNCTION MENU
➛
Selected characters
▲
▲
Function
Panel Life
Mode Display
ID Number
Inverse
Standby White
Gamma
Reset
Select
Set
Off
60Min.
Screen Saver
5Min.
40Min.
10Min.
20Min.
On
Screen Wipe
60 Min.
Off
Black Side Panel
Normal
Off
1
On 60Min.
Off
2.2
Reset
Return
Setup hint
This moves the picture around the screen in small amounts, at
set intervals, to reduce the panel image retention. Image
retention occurs when stationary objects, such as screen logos,
leave a slight image visible after they should have disappeared.
This is used to reduce the panel image retention that can occur
with stationary pictures by displaying a completely white screen.
Select On (continuous operation) or 60 Min. (time limit operation)
and press the OK button. Press the MENU or RETURN button on
the remote control to return to normal viewing.
This turns the gray sidebars On/Off when watching normal
mode screen size area. It is always set to Off when the monitor
is powered On. It is recommended to set Black Side Panel to off
to reduce the panel image retention.
On
Video Power Save
21
Reset
(Selects the Reset mode)
Normal
Panel Life
Mode Display
Extend 1
Extend 2
On
60 Min.
Off
ID Number
1
Inverse
7
Off
Standby White
4
5
15Min.
30Min.
120Min.
60Min.
2.2
Gamma
3
6
This function suppresses the contrast of the screen regardless of
the Contrast setting in the Picture Menu. By this control, power
consumption can be reduced or degradation of a panel can be
mitigated. The order of power consumption is Extend 2 < Extend
1 < Normal. If the Contrast setting is changed when this item is
set to Extend 1 or 2, it will be changed to Normal automatically.
This function displays the Input Signal Screen Display every time
the input mode and signal mode are changed. Set to OFF if the
Input Signal Screen Display is not needed when switching signals.
Assigns ID Nos. to the monitors so that they can be controlled
individually (up to 7 monitors can be controlled).
On
2
The original factory settings for the items of this Menu page can
be restored by pressing the OK button.
2.8
This function changes each level of RGB signal invert to reduce
the panel image retention. When this function is required, select
On (continuous operation) or 60Min. (time limit operation) and
press the OK button. And press the Menu or Return button to exit.
This function is also provided to prevent image retention. If time
is set for this item, the screen changes into a white pattern when
the monitor enters power save mode, and continues for the
period of setting time.
Normally set to 2.2.
35
015_PDM-5520_U_E
35
12/13/04, 9:24 AM
OPERATING INSTRUCTIONS FOR PC (continued)
SETUP MENU
MENU
➛
➛
Audio
Timer
Function
Setup
Language
Select
OK Set
OK
➛
Setup
Auto Adjust
Horizontal Position
Vertical Position
Horizontal Clock
Clock Phase
Reset
Select
Return
Adjust
0
+ 31
– 20
10
Reset
Exit
OK
➛
0
Return
➛
➛
Horizontal Position
Next / Prev
Adjust
➛
➛
Setup
Auto Adjust
Horizontal Position
Vertical Position
Horizontal Clock
Clock Phase
Reset
Select
Return
Adjust
0
+ 31
– 20
10
Reset
Exit
OK
➛
10
Adjust
Return
➛
Clock Phase
Next / Prev
➛
Selected characters
0.7V
Off
Off
Off
On
Movie
DVI-PC
RGB
Return
▲
▲
Setup
Input Level
Frequency Display
WVGA Type
WXGA Mode
Vertical Filter
Frequency Mode
RGB1
RGB2
Select
Set
(Adjust)
Press the OK button to start
automatic regulation.
(Menu)
Auto Adjust*
Setup hint
Horizontal Position, Vertical Position, Horizontal Clock and Clock
Phase are adjusted automatically.
Horizontal Position
Moves the horizontal position to left. Moves the horizontal position to right. Adjust the horizontal display position.
(This function is only for RGB2. It is not available (grayed out)
for RGB1.)
Vertical Position
Moves down the vertical position. Moves up the vertical position. Adjust the vertical display position.
(This function is only for RGB2. It is not available (grayed out)
for RGB1.)
Horizontal Clock
Reduces the dot clock frequency Increases the dot clock frequency
Adjust for maximum character clarity.
(expands the right side).
(shrinks the right side).
(This function is only for RGB2. It is not available (grayed out)
for RGB1.)
Slows the dot clock phase
(shifts slightly to left).
Clock Phase
Reset
Advances the dot clock phase
Adjust for clear character visibility.
(shifts slightly to right).
(This function is only for RGB2. It is not available (grayed out)
for RGB1.)
(Selects the Reste mode)
0.7V
Input Level
Frequency Display
WVGA Type
Off
WXGA Mode
On
Set this to Off if the frequency information of the Input Signal
Screen Display is not required.
Off
On
This is only available for W-VGA signal.
When it is set to On, the display area mode can be selected Full or Real.
1280x768
Movie
Frequency Mode
RGB1
RGB2
Normally set to 0.7 V. If white is found to spread across the
screen, set to 1.0 V. (This is effective only for RGB2.)
Off
Off
Vertical Filter
1.0V
The original factory settings for the items of this Menu page can be
restored by pressing the OK button. (This is effective only for RGB2.)
1366x768
On
PC
This is only available for W-XGA signal.
When it is set to On, the display area mode can be selected Full
or Real. (RGB2 (ANALOG) INPUT only)
Turn On when concerned about screen flicker.
Set to Movie when viewing moving images on a personal
computer.
23
* Depending on the type of signal displayed, displays may not be optimized through automatic adjustment. Adjust manually to optimize them.
36
015_PDM-5520_U_E
36
12/13/04, 9:24 AM
OPERATING INSTRUCTIONS FOR PC (continued)
MENU
➛
Audio
Timer
Function
Setup
Language
Select
OK Set
➛
ENGLISH
LANGUAGE MENU
Language
English
Français
Español
OK
➛
Select
Return
Exit
Select a language using the ▼ ▲ SELECT buttons and press the OK button.
OTHER FEATURES FOR PC
Automatic Store
Approximately 1 sec. after adjustment is completed, the adjustments will be recorded as shown in the table below.
Menu
Display
Registration condition
Contrast
For every input function, 1 setting
is registered.
Brightness
Menu
Display
Function
Screen Saver
1 setting is registered.
Screen Wipe
(not registered)
Color
Black Side panel
(not registered)
Tint
Panel Life
1 setting is registered.
Picture Enhancement
Mode Display
Color temperature
ID Number
Color Temp. Adjust
Inverse
R Amplitude For every Color Temperature, 1
G Amplitude setting is registered.
B Amplitude
Standby White
Gamma
Setup
R Cut Off
Auto Adjust
B Cut Off
Horizontal Clock
Audio Mode
1 setting is registered.
Clock Phase
Treble
Input Level
Bass
For every Audio Mode, 1 setting is
registered.
Balance
1 setting is registered.
WVGA Type
SRS TruBass
Matrix Surround
Perfect Volume
(not registered)
Horizontal Position For every signal Mode, 1 setting is
registered. (Only for RGB2)
Vertical Position
G Cut Off
Audio
Registration condition
1 setting is registered.
Frequensy Display
Vertical Filter
For every Audio mode, 1 setting is
registered.
Frequency Mode
Language
1 setting is registered.
• The previously recorded items will be lost.
• The signal mode can be identified by the horizontal/vertical sync
frequency and the sync signal polarity. Different signals for which
all the elements are the same or similar will be handled as the
same signal.
37
015_PDM-5520_U_E
37
12/13/04, 9:24 AM
OTHER FEATURES FOR PC (continued)
Signal Check
Changes in the signal status are displayed on the screen as they arise.
Status
Display
When Mode Display is set to ON,
the input signal is switched or
when the RECALL button is
pressed.
RGB
Action
A guide is displayed for the input
terminal and the horizontal and
vertical sync frequency.
RGB2
RGB
H : 48.4kHz
V : 60.1 Hz
––––––––––
OFF
When the sync signal is no longer
detected.
• A guide displays No Sync.
Signal, and Power Save (for
approx. 5 sec.)
• When the condition continues
When the input signal does not
match the monitor specifications or and the sync signal cannot be
detected, the indicator lamp of
is in an unstable state.
the power source changes in
orange and the mode switches
to power save mode.
Recheck the personal computer
power switch status and the
connection status.
-- -- Min.
-- -- : -- --
! No Sync. Signal
“Invalid Scan Freq” appears on the Recheck the input signal
display panel.
specifications.
! Invalid Scan Freq.
43 ~ 45
Power Save Mode
When the RGB1, RGB2 input is selected
• When this unit is connected to a VESA DPMS computer, the Power Save (Off) mode can be set to be activated automatically when the
computer is not being used to reduce power consumption by this unit.
Horizontal
Yes
No
Yes
No
Vertical
Yes
Yes
No
No
RGB sync signal
PC signal
Active (normal display)
Blank (no display)
Operation mode
On
Off
Indicating lamp
Lights green
Lights Orange
530W
3W or less (RGB1)
1W or less (RGB2 ; 100V AC 120V)
3W or less (RGB2 ; 120V < AC 240V)
Power consumption
Returning to operating status
• Operate the personal computer, or press either the INPUT SELECT button of the monitor or the RGB1/RGB2 buttons of the remote control to
return the unit to power on mode.
38
015_PDM-5520_U_E
38
12/13/04, 9:24 AM
IMAGE RETENTION OF PLASMA DISPLAY PANEL
ENGLISH
There are different characteristics that result in panel image retention depending on how the plasma monitor is used.
Situations and effective usage methods related to ghosting are provided below.
Image retention characteristics of a plasma display panel
The image retention phenomenon of a plasma display panel occurs due to partial phosphor degradation arising from partial character and
figure display.
For example, when the character image as shown in Fig. A at the right is
continuously displayed for a long period of time, the only part of the phosphor
(Red, Green, Blue) that will degrade will be the color of the applicable character
display portion. Consequently, when a white image is displayed on the entire
screen as shown in Fig. A, the character marks displayed up to that time will
become a color difference visible to the eye, but the phosphor will never burn.
■The degree of image retention is proportional to the brightness of the characters and figures displayed as well as the display time.
• The tendency of the phosphor is to degrade more the brighter the characters
and figures are displayed. When images of figures with different levels of
brightness, as shown in Fig. B, are continuously displayed for a long period of
time, it becomes easier for image marks at locations when the brighter figures
are displayed to be noticeable.
* The image retention images in this document are exaggerated for the purpose of explanation. The actual manner in which the image
retention is seen differs depending on the operation time and brightness.
Methods to Reduce the Occurrence of Image Retention
• Lower the Contrast and Brightness settings of the plasma display panel as much as possible.
A function is provided in the display that allows you to control the brightness of the screen to reduce degradation of the panel. Using this
function makes it possible to reduce image retention.
(Refer to Panel Life (Extend 1 or Extend 2 shown on 35 )
• Set the plasma monitor to an “Screen Wipe” or “Inverse” display.
The occurrence of image retention when displaying images of identical patterns, such as static images, for long periods of time can be
reduced by displaying a reversed color or completely white screen for about 1 ~ 2 hours after terminating the display.
(Settings can be made using Screen Wipe and Inverse of Function MENU shown on 35 )
• Using in combination with moving images
Since the degradation of the fluorescent material progresses comparatively uniformly for moving images, the occurrence of partial image
retention can be controlled. We recommend using the plasma monitor in combination with moving images such as those of DVD playback.
* Please be careful since image retention will occur if display is left in a two screen display state for a long period of time.
* Television broadcasts include images displayed for long periods of time in which the left and right or top and bottom of the image are cut
and broadcast station name or time are displayed for a long period of time at the same portion of the screen. Image retention in these
portions can be expected to occur, so please be aware.
Notes
About screen defects
• High precision technology is used in the making of plasma display panel but there may be dark spots (points that do not illuminate) and
bright spots (points that are too bright) in some cases. These do not indicate a malfunction.
About residual images
• In some cases, residual images may remain after the short-term display of still images and another image is displayed, but these will
disappear and return to normalcy. This is not a malfunction.
About the panel screen
• Plasma display panels display images by means of electrical discharges inside the panel. Because of this, the temperature of the panel
surface may rise in some cases. Also, plasma display panels are made of finely processed glass. A reinforced glass filter is installed over the
panel surface but avoid strong impact because there is still danger of glass breakage.
39
015_PDM-5520_U_E
39
12/13/04, 9:24 AM
TROUBLESHOOTING FOR PC
Symptoms That Appear to be Failures
Make the checkes suggested below dpending on the symptoms observed. If the symptoms remain uncorrected, contact your dealer.
CAUTION
Customer servicing can be hazardous.
Symptom
Point to check
• No picture with the power-indicating lamp
off.
• Check the way the power cable is connected.
• Press the power switch.
• The message “No Sync. Signal” or
“Power Save” is displayed.
No sync signal is detected.
• Check the way the signal cable is connected.
• Make sure that the switch of the computer, imaging
equipment, etc., is turned on.
• Make sure the computer is not in the power-save mode.
• Check to see if the input selection matches the connection
terminal.
! No Sync. Signal
• No picture, with the power indicating
lamp lit orange.
• The message “Invalid Scan Freq.” is
displayed.
See page
28
29
27
An input signal is not received normally.
• Check to see if the input signal matches the monitor
specifications.
• Check the way the signal cable is connected.
27
• The power indicating lamp is lit normally
but no picture displays.
• Check the contrast and brightness settings (adjust them for
higher contrast and brightness).
• Check the way the signal cable is connected.
27
• The display image appears flowing
slantwise.
• Text displayed across the screen appears
vertically streaked, with the characters in
vertical columns blurred.
• Adjust the dot clock frequency and phase. (Adjust the dot
clock frequency first, the dot clock phase next.)
(RGB input)
36
• Text displayed across the screen appears
blurred.
• A fine pattern flickers when displayed on
the screen.
• Adjust the dot clock phase for the clearest viewing.
(RGB input)
36
• The remote control does not work.
• Check to see if the batteries are loaded in the remote control
in opposite direction.
• Check to see if the batteries in the remote control are OK.
• Check if the setting of remote control ID no. is correct.
! Invalid Scan Freq.
40
45
33
42
42
40
015_PDM-5520_U_E
44
12/13/04, 9:24 AM
11
32
TROUBLESHOOTING FOR PC (continued)
Symptom
• The temperature of the display panel surface is high.
Point to check
See page
• Plasma display panel is lighting the phosphors in the display
panel by the discharge of internal radiation. In some cases,
this may cause the temperature of the panel surface to
increase. Please note that this is not a malfunction.
-
• There are points (*) on the screen that differ in color from the • High-precision technology is used to manufacture the
periphery of the screen.
plasma display panel, However in some cases, there are
* Points that do not light, points with brightness different
minor defects in some parts of the screen. Please note that
from that of the periphery, points with color different from
this is not a malfunction.
that of the periphery, etc.
• Vertical stripes appear, depending on the screen contents.
ENGLISH
Symptoms That Appear to be Failures (continued)
-
• The plasma display panel is lighting the phosphors by the
discharge of internal radiation. Depending on the screen
contents, in rare cases this may cause vertical stripes to
appear because of failure to light. Please note that this is not
a malfunction.
-
• Coarse horizontal stripes appear in FULL display.
• Adjusting the Clock Phase will reduce the horizontal stripes.
(RGB input)
36
• Flickering in the form of horizontal lines oscillating up and
down.
(PC INPUT MODE only)
• If the direct frequency from the computer is below 85Hz, try
a higher frequency (upper limit 85Hz). There may be a slight
attenuation of the current image.
• Try turning the Vertical Filter On. For this case however, the
vertical resolution will drop.
36
• The top of the monitor heats up.
• When used for long periods of time, the top of the monitor
may heat up. This is not a malfunction.
• Text characters are displayed with varying thicknesses.
• The thicknesses of characters and lines may vary if images
with a vertical resolution greater than 768 lines are
displayed; however, this is not a malfunction.
-
-
41
015_PDM-5520_U_E
41
12/13/04, 9:24 AM
TROUBLESHOOTING FOR PC (continued)
Actions to Correct Abnormal Displays
Depending on the kind of system equipment used, images may not be displayed normally. In this case, make the
adjustments suggested below. (only for RGB2)
Symptom 1
Text displayed across the screen appears vertically streaked, with some characters blurred (figure 1).
The display image appears flowing (figure 2) (RGB input).
Vertical
streaks
Figure 1
Before adjustment
Some characters
are blurred.
ABCDEFGHIJ
abcdefgABCDEFGabcd
ABCDEFGHIJ
abcdefgABCDEFGabcd
Example
ABC
B
ABC
After adjustment
All characters appear
crisp now.
ABC
ABC
After adjustment
All characters are
blurred.
1) Press the AUTO button on the remote control.
Adjustment
procedure
When adjustment is not possible with Auto Adjust
2) Press the MENU button. The Main Menu will be displayed.
3) Press the SELECT button and select Setup.
4) Press the OK button. The Setup Menu will be displayed.
5) Press the SELECT button and select Horizontal Clock.
(Display fine patterns as characters or a vertical striped pattern over the entire screen during Horizontal Clock adjustment.)
6) Press the or ADJUST buttons and search for clear characters over the entire screen.
7) Perform adjustment for symptom 2 below, when the characters are blurred on the entire screen.
• The display image may be momentarily disturbed during clock adjustment but this is not a failure.
Symptom 2
Text displayed across the screen appears blurred in its entirety (figure 2).
A fine pattern flickers when displayed on the screen (figure 3).
Before adjustment
Figure 2
ABCDEFGHIJ
abcdefgABCDEFGabcd
ABCDEFGHIJ
abcdefgABCDEFGabcd
Figure 3
Before adjustment
ABC
ABC
Example
After adjustment
After adjustment
ABC
1) Press the AUTO button on the remote control.
Adjustment
procedure
When adjustment is not possible with Auto Adjust
2) Press the MENU button. The Main Menu will be displayed.
3) Press the SELECT button and select Setup.
4) Press the OK button. The Setup Menu will be displayed.
5) Press the SELECT button and select Clock Phase.
(Display fine patterns as characters or a vertical striped pattern over the entire screen during Clock Phase adjustment.)
6) Press or ADJUST buttons to make the text appear
clean across the screen.
6) Press or ADJUST buttons to make the text appear
without flickering.
42
015_PDM-5520_U_E
42
12/13/04, 9:24 AM
PRODUCT SPECIFICATIONS FOR PC
Product specifications and designs are subject to change without notice.
Display
dimensions
Approx. 55 inches (1229 (H) x 691 (V) mm, diagonal 1410mm)
Resolution
1366 (H) x 768 (V) pixels
Net dimensions
(excluding pedestal)
1394 (W) x 857 (H) x 105 (D) mm
Net weight
(excluding pedestal)
63.5kg
Ambient
conditions
ENGLISH
Panel
Temperature
Operating : 5˚C to 35˚C, Storage : 0˚C to 40˚C
Relative humidity
Operating : 20% to 80%, Storage : 20% to 90% (non-condensing)
Power supply
AC100 - 240V, 50/60Hz
Power consumption/at standby
530W / <3W
Audio output
12W + 12W (6 ), sub woofer (RCA)
(RGB input)
Input terminals
RGB1 DVI input terminal (DVI-D)
RGB1 audio input terminal (3.5mm Stereo Mini Jack)
RGB2 analog RGB input terminal (D-sub 15-pin)
RGB2 audio input terminal (3.5mm Stereo Mini Jack)
Video signals
0.7 V/1.0 Vp-p, analog RGB (Recommended Signal)
Sync signals
H/V separate, TTL level [2K ]
H/V composite, TTL level [2K ]
Sync on green, 0.3 Vp-p [75 ]
Input signals
Recommended signal
44 modes
44
45
• The monitor takes at least 30 minutes to attain optimal picture quality.
Signal Input
RGB terminal (D-sub 15-pin connector)
Pin
Input signal
1
R
2
G or sync on green
3
B
4
No connection
5
No connection
6
R.GND
7
G.GND
8
B.GND
9
No connection
10
GND
11
No connection
12
[SDA]
13
H. sync or H/V composite sync
14
V. sync. [V.CLK]
15
[SCL]
5 4 3 2 1
0 9 8 7 6
@ ! ~ = • When different kinds of input signals are simultaneously input to
the monitor via a graphics board or the like, the monitor will
automatically select the signals in the following priority order:
Sync signal type
Priority
H/V seperate sync.
1
H/V composite sync.
2
sync. on Green *
3
*Even in the case of the recommended signals shown on the
following page, there may be instances when correct display is
not possible. In this case, use H/V separate sync, H/V composite
sync.
43
015_PDM-5520_U_E
43
12/13/04, 9:24 AM
PRODUCT SPECIFICATIONS FOR PC (continued)
Signal Input (continued)
DVI terminal (DVI-D)
Pin
Input signal
Pin
Input signal
1
T.M.D.S. Data2-
14
+5 Power
2
T.M.D.S. Data2+
15
Ground (for+5V)
3
T.M.D.S. Data2/4 Shield
16
Hot Plug Detect
4
T.M.D.S. Data4-
17
T.M.D.S. Data0-
5
T.M.D.S. Data4+
18
T.M.D.S. Data0+
6
DDC Clock
19
T.M.D.S. Data0/5 Shield
7
DDC Data
20
T.M.D.S. Data5-
8
No Connect
21
T.M.D.S. Data5+
9
T.M.D.S. Data1-
22
T.M.D.S. Clock Shield
10
T.M.D.S. Data1+
23
T.M.D.S. Clock+
11
T.M.D.S. Data1/3 Shied
24
T.M.D.S. Clock-
12
T.M.D.S. Data3-
13
T.M.D.S. Data3+
Frame
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
GND
Recommended Signal List
With Digital RGB signal input (RGB1 input)
No.
Signal Name
Signal Mode
Vertical frequency
Resolution
(Hz)
Horizontal frequency
(kHz)
Dot clock frequency
(MHz)
640 X 400
70.08
31.47
25.18
640 X 480
59.94
31.47
25.18
864 X 480
59.94
31.47
34.24
4
640 X 480
72.81
37.86
31.50
5
640 X 480
75.00
37.50
31.50
6
640 X 480
85.01
43.27
36.00
7
800 X 600
56.25
35.16
36.00
8
800 X 600
60.32
37.88
40.00
800 X 600
72.19
48.08
50.00
800 X 600
75.00
46.88
49.50
56.25
1
2
3
9
10
VGA
W-VGA
VESA
11
800 X 600
85.06
53.67
12
1024 X 768
60.00
48.36
65.00
13
1024 X 768
70.07
56.48
75.00
14
1024 X 768
75.03
60.02
78.75
• Make sure that the signal of the equipment to be connected is compatible with the specifications on this list.
44
015_PDM-5520_U_E
44
12/13/04, 9:24 AM
Remarks
WVGA type : On
PRODUCT SPECIFICATIONS FOR PC (continued)
ENGLISH
Recommended Signal List (continued)
With Analog RGB signal input (RGB2 input)
No.
Signal Name
1
Signal Mode
Vertical frequency
Resolution
(Hz)
Horizontal
frequency (kHz)
Dot clock
frequency (MHz)
Remarks
640 X 400
70.08
31.47
25.18
640 X 480
59.94
31.47
25.18
864 X 480
59.94
31.47
34.24
4
640 X 480
72.81
37.86
31.50
5
640 X 480
75.00
37.50
31.50
6
640 X 480
85.01
43.27
36.00
7
800 X 600
56.25
35.16
36.00
8
800 X 600
60.32
37.88
40.00
9
800 X 600
72.19
48.08
50.00
10
800 X 600
75.00
46.88
49.50
11
800 X 600
85.06
53.67
56.25
12
1024 X 768
60.00
48.36
65.00
1024 X 768
70.07
56.48
75.00
14
1024 X 768
75.03
60.02
78.75
15
1024 X 768
85.00
68.68
94.50
16
1152 x 864
75.00
67.50
108.00
17
1280 x 1024
60.02
63.98
108.00
18
1280 x 1024
75.03
79.98
135.00
19
1280 x 1024
85.02
91.15
157.50
20
1600 x 1200
60.00
75.00
162.00
21
1600 x 1200
75.00
93.75
202.50
22
1600 x 1200
85.00
106.25
229.50
23
640 x 480
66.67
35.00
30.24
24
832 x 624
74.55
49.72
57.28
1024 x 768
74.93
60.24
80.00
1152 x 870
75.06
68.68
100.00
1280 x 768
59.833
47.986
81.00
1280 x 768
69.997
56.137
94.760
1280 x 768
59.876
47.776
79.50
WXGA Mode: (1280 x 768)
1366 x 768
60.015
47.712
85.50
WXGA Mode: (1366 X 768)
2
3
13
25
VGA
W-VGA
VESA
Macintosh
26
27
28
29
30
W-XGA
W-XGA
WVGA type : On
• The type of video board or connecting cable used may not allow for correct display adjustment of Horizontal Position, Vertical Position,
Horizontal Clock and Clock Phase.
• The monitor may fail to display an animation image correctly when a signal having a vertical frequency of 85Hz or higher is input to it.
• The monitor differentiates signal modes according to the horizontal and vertical frequencies and the horizontal and vertical sync signal
polarities. Note that different signals having all these elements alike may be handled as the same signal.
• Displaying images with more than 768 lines of vertical resolution at Full diplay (compressed display) can result in the interpolation of stripes.
45
015_PDM-5520_U_E
45
12/13/04, 9:24 AM
Basic connection to an AV Receiver
PDM-5520
Monitor rear panel
High Definition Plasma monitor
PDM-5520
U.S.
Connection Guide
スピーカー端子
(6Ω12W)
スピーカー端子
(6Ω12W)
To AC outlet
DVD player
Audio pin cable
Video pin cable
Audio pin
cable
S video cable
Video
pin
cable
S video
cable
Component
video cable
20
21
19
17
15
18
16
14
12
10
8
6
13
11
9
7
5
3
1
4
2
Component video cable
20 18 16
21 19
17
15
14
12 10
13
11
9
8
7
6
5
4
3
2
1
AV receiver
VCR
PURE DIRECT
REC OUT/ZONE 2
SOURCE/REMOTE
S video cable
2CH/MULTI CH
DTV/LD
CABLE
SPEAKERS
A
B
INPUT MODE
MULTI CH
INPUT
TUNING MODE
MEMORY
STRAIGHT
DSP
PROGRAM
MONITOR OUT
VOLUME
MULTI JOG
BALANCE
DVD
MD/TAPE
SAT
INPUT SELECTOR
CD-R
EFFECT
CD
VCR 1
VCR 2
TUNER
PRESET
/TUNING
FM/AM
TONE
CONTROL
PHONO
DVR
VIDEO AUX
STANDBY
/ON
SILENT
PHONES
VIDEO AUX
OPTIMIZER
MIC
S VIDEO
VIDEO
L
AUDIO
R
COMPONENT
VIDEO
OPTICAL
Audio pin cable
Y/G
PR / R
S VIDEO VIDEO
PB / B
Video pin cable
Video
pin
cable
Audio pin
cable
S video
cable
Component
video cable
S video cable
Component video cable
Video camera
NOTE:
When this plasma monitor receives signals through both
S VIDEO and VIDEO terminals, signals input through
the S VIDEO terminal have priority.
Sat/Cable box
All cables listed are sold separately.
IN
Surround Presence Surround
back left
left
left
speaker speaker speaker
OUT
Front
left
speaker
Center Subwoofer
speaker
Front
right
speaker
Surround Presence Surround
right
right
back right
speaker speaker speaker
©2004
All rights reserved.
Printed in Japan
Connection_U_PDM-5520
1
11/25/04, 11:03 AM
QT45541 A
Examples of Image Retention
Exemples de Rétention d’Image
English
Image Retention
Image Retention can be an issue for all plasma monitors, however if you follow the simple guidelines listed below, you can
enjoy many years of viewing.
YAMAHA has included a number of features in our range of plasma monitors which help to reduce image retention.
Please refer to the user manual for this model for instruction on how to use these features.
*
*
*
*
*
Ensure screen save mode is activated.
Always display the image in a mode that fills the screen.
Avoid using split screen modes for long periods of time.
Do not allow the “On Screen Display” to stay on for long periods of time.
Do not display still images, such as menus from game consoles, Teletext, PCs or logos on the monitor for long periods
of time.
* We recommend that you reduce “Contrast” and “Brightness” levels as much as possible.
Français
Rétention d’image
La rétention peut être un problème pour les écrans Plasma, néanmoins si vous suivez les simples instructions suivantes,
vous pourrez profiter de votre écrans pendant de longues années.
YAMAHA a pourvu ses écrans moniteurs plasma de fonctions permettant de réduire la rétention d’image.
Veuillez s’il vous plaît vérifier dans le mode d’emploi de ce modèle comment utiliser ces fonctions.
*
*
*
*
*
Assurez vous que l’économiseur d’écran est bien activé.
Vérifiez toujours que le format d’image que vous utilisez est constamment adapté à l’écran.
Evitez d’utiliser le mode de séparation d’écran sur une longue période.
Ne pas laisser le menu à l’écran affiché pendant de longue périodes.
Ne pas afficher des images fixes, comme les menus des jeux vidéo, télétexte, ordinateurs ou Logos sur l’écran pendant
de longues périodes.
* Nous vous recommandons également de régler le contraste et la luminosité à un niveau le plus faible possible.
PDM-5520
ImageRetention_PDM-5520
1
10/12/04, 8:17 PM
QT45911

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
