hp officejet 4200 series
all-in-one
user guide
hp officejet 4200 series
all-in-one
© 2004 Copyright Hewlett-Packard
Development Company, LP
The information herein is subject to
change without notice.
Reproduction, adaptation or
translation without prior written
permission is prohibited, except as
allowed under the copyright laws.
This product incorporates Adobe’s
PDF technology, which contains an
implementation of LZW licensed under
U.S. Patent 4,558,302.
Adobe and the
Acrobat logo
are trademarks
of Adobe
Systems
Incorporated.
Portions Copyright © 1989-2004
Palomar Software Inc. The
HP Officejet 4200 Series includes
printer driver technology licensed from
Palomar Software, Inc.
www.palomar.com
Copyright © 1999-2004 Apple
Computer, Inc.
Apple, the Apple logo, Mac, Mac
logo, Macintosh, and Mac OS are
trademarks of Apple Computer, Inc.,
registered in the U.S. and other
countries.
notice
The only warranties for HP products
and services are set forth in the
express warranty statements
accompanying such products and
services. Nothing herein should be
construed as constituting an additional
warranty. HP shall not be liable for
technical or editorial errors or
omissions contained herein.
The Hewlett-Packard Company shall
not be liable for incidental or
consequential damages in connection
with, or arising out of the furnishing,
performance, or use of this document
and the program material which it
describes.
Note: Regulatory information can be
found in the Technical Information
chapter of this guide.
It is not lawful in many places to make
copies of the following items. When in
doubt, check with a legal
representative first.
•
Publication number: Q5600-90113
First edition: January 2004
Windows®, Windows NT®, Windows
ME®, Windows XP®, and Windows
2000® are U.S.-registered trademarks
of Microsoft Corporation.
Intel® and Pentium® are U.S.
registered trademarks of Intel
Corporation.
•
Governmental paper or
documents:
- Passports
- Immigration papers
- Selective service papers
- Identification badges, cards, or
insignias
Governmental stamps:
•
•
•
•
Postage stamps
Food stamps
Checks or drafts drawn on
Governmental agencies
Paper currency, traveler’s checks,
or money orders
Certificates of deposit
Copyrighted works
safety information
Warning! To prevent fire
or shock hazard, do not
expose this product to
rain or any type of
moisture.
Always follow basic safety precautions
when using this product to reduce risk
of injury from fire or electric shock.
Warning! Potential
shock hazard
1
Read and understand all
instructions in the setup poster.
2
Use only a grounded electrical
outlet when connecting the device
to a power source. If you do not
know whether the outlet is
grounded, check with a qualified
electrician.
3
Observe all warnings and
instructions marked on the
product.
4
Unplug this product from wall
outlets before cleaning.
5
Do not install or use this product
near water or when you are wet.
6
Install the product securely on a
stable surface.
7
Install the product in a protected
location where no one can step
on or trip over the line cord, and
where the line cord will not be
damaged.
8
If the product does not operate
normally, see the online
Troubleshooting help.
9
No operator-serviceable parts
inside. Refer servicing to qualified
service personnel.
10
Use in a well-ventilated area.
Warning! The handset
ear cap used with this
product may attract
dangerous objects like
pins, staples, or needles.
Take care to avoid harm
that might occur from the
retention of dangerous
objects on the ear piece
of the handset.
Warning! This
equipment will be
inoperable when mains
power fails.
contents
1
hp officejet overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
the hp officejet at a glance . . . . . . . . . . . .
front panel overview . . . . . . . . . . . . . . . .
menu overview . . . . . . . . . . . . . . . . . . . .
use the hp director software to do more with
open the hp director for Windows users .
open the hp director for Macintosh users
2
............
............
............
your hp officejet
............
............
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 4
. 5
. 8
. 8
. 9
10
load paper and load originals . . . . . . . . . . . . . . . . . . . . . . . . . . 15
open and close the hp officejet . . . . . . . . . . . . . . . . . . . . . . . . . .
open and close the paper tray . . . . . . . . . . . . . . . . . . . . . . . .
open and close the document feeder tray and document catcher .
papers for printing and copying. . . . . . . . . . . . . . . . . . . . . . . . . .
recommended papers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
papers to avoid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
load paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
load full-size papers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
load envelopes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
load 4 by 6 inch (10 by 15 cm) photo paper with tear off tabs . .
load postcards, index, or Hagaki cards . . . . . . . . . . . . . . . . . .
load other types of paper in the paper tray . . . . . . . . . . . . . . .
set the paper type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
paper type settings for copying . . . . . . . . . . . . . . . . . . . . . . .
set the paper type for copying . . . . . . . . . . . . . . . . . . . . . . . .
set the paper size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
paper size setting for copying . . . . . . . . . . . . . . . . . . . . . . . . .
paper size setting for receiving a fax . . . . . . . . . . . . . . . . . . . .
avoid jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
load originals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
15
15
16
17
17
18
19
19
20
20
22
22
23
23
24
24
24
24
25
25
use the copy features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
use the copy features from the front panel. . . . .
increase copy speed or quality . . . . . . . . . . . .
change default copy settings. . . . . . . . . . . . . .
copy a two-page black-and-white document . . . . .
make multiple copies of the same original . . . . . .
copy a photo onto a full-size page . . . . . . . . . . .
copy a legal-size document onto letter paper . . . .
copy a washed-out original . . . . . . . . . . . . . . . .
copy a document that has been faxed several times
enhance light areas of your copy . . . . . . . . . . . .
stop copying . . . . . . . . . . . . . . . . . . . . . . . . . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
27
27
28
28
29
30
30
32
32
33
34
34
i
contents
4
use the scan features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
scan an original . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
stop scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
5
use the fax features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
send a fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
enable fax confirmation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
send a basic fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
send a color original or photo fax . . . . . . . . . . . . . . . . . . . . . . . .39
send a fax using speed dials . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
send a fax using redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
schedule a fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
cancel a scheduled fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
send a fax from memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
send a fax using monitor dialing . . . . . . . . . . . . . . . . . . . . . . . . .43
send a fax manually from a telephone . . . . . . . . . . . . . . . . . . . . .43
set the answer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
receive a fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
set the number of rings before answering . . . . . . . . . . . . . . . . . . . 47
receive a fax manually from a phone . . . . . . . . . . . . . . . . . . . . . .48
receive a fax manually from the front panel . . . . . . . . . . . . . . . . . .48
receive a fax manually using the attached handset (hp officejet 4250 series only)
49
poll to receive a fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
use the attached handset (hp officejet 4250 series only) . . . . . . . . . . . .50
answer incoming calls using the handset . . . . . . . . . . . . . . . . . . . .50
make phone calls using the handset . . . . . . . . . . . . . . . . . . . . . . .50
receive faxes using the handset. . . . . . . . . . . . . . . . . . . . . . . . . . .51
send faxes using the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
adjust the handset volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
set the fax header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
enter text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
enter a phone number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
print reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
generate reports automatically . . . . . . . . . . . . . . . . . . . . . . . . . . .53
generate reports manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
set up speed dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
create individual speed-dial entries . . . . . . . . . . . . . . . . . . . . . . . .56
add group speed-dial entries . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
update speed-dial entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
delete speed-dial entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
change fax resolution and lighter/darker settings. . . . . . . . . . . . . . . . .58
change the fax resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
change lighter/darker setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
set new defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
set fax options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
set the date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
set the paper size for received faxes . . . . . . . . . . . . . . . . . . . . . . .61
ii
hp officejet 4200 series
contents
set tone or pulse dialing . . . . . . . . . . . . . . . . . .
adjust the ring volume . . . . . . . . . . . . . . . . . . . .
adjust the phone line monitor volume . . . . . . . . .
forward faxes to another number . . . . . . . . . . . .
edit or cancel fax forwarding . . . . . . . . . . . . . . .
change the answer ring pattern (distinctive ringing)
redial a busy or unanswered number automatically
set automatic reduction for incoming faxes . . . . . .
use error correction mode . . . . . . . . . . . . . . . . .
set the fax speed . . . . . . . . . . . . . . . . . . . . . . .
use caller ID . . . . . . . . . . . . . . . . . . . . . . . . . .
block junk fax numbers . . . . . . . . . . . . . . . . . . .
set backup fax reception . . . . . . . . . . . . . . . . . .
set the country and language . . . . . . . . . . . . . . .
reprint the faxes in memory . . . . . . . . . . . . . . . . . .
stop faxing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
61
61
62
62
62
63
63
64
65
65
66
66
67
68
68
68
print from your computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
print from a software application
Windows users . . . . . . . . . .
Macintosh users . . . . . . . . .
set printing options . . . . . . . . .
Windows users . . . . . . . . . .
Macintosh users . . . . . . . . .
stop a print job . . . . . . . . . . . .
7
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
71
71
72
72
72
73
.74
order supplies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
order media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
order print cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
order other supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
8
maintain your hp officejet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
clean the glass . . . . . . . . . . . . . . . .
clean the white strip . . . . . . . . . . . .
clean the exterior . . . . . . . . . . . . . .
work with print cartridges . . . . . . . . .
check the ink levels . . . . . . . . . . .
print a self-test report . . . . . . . . .
handle the print cartridges . . . . . .
replace the print cartridges . . . . .
use a photo print cartridge . . . . . .
use the print cartridge protector. . .
align the print cartridges . . . . . . .
clean the print cartridges . . . . . . .
clean the print cartridge contacts .
replace the telephone cord . . . . . . . .
restore factory defaults . . . . . . . . . . .
set the scroll speed . . . . . . . . . . . . .
set the prompt delay time . . . . . . . . .
user guide
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
77
78
79
79
79
80
82
82
85
85
86
88
88
89
90
90
91
iii
contents
set the language and country/region . . . . . . . . . . . . . . . . . . . . . . . . .91
self-maintenance sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
9
hp officejet 4200 series support . . . . . . . . . . . . . . . . . . . . . . . . . 93
get support and other information from the Internet
hp customer support . . . . . . . . . . . . . . . . . . . . .
call in North America during warranty . . . . . .
call elsewhere in the world . . . . . . . . . . . . . .
call in Australia post-warranty . . . . . . . . . . . .
prepare your hp officejet for shipment . . . . . . . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.93
.93
. 94
. 94
.96
.96
10 warranty information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
duration of limited warranty . . . . . . . . . . . . . . . .
warranty service . . . . . . . . . . . . . . . . . . . . . . . .
warranty upgrades . . . . . . . . . . . . . . . . . . . . . .
returning your hp officejet for service . . . . . . . . . .
hewlett-packard limited global warranty statement
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. .99
. .99
. .99
.100
.100
11 technical information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
paper specifications. . . . . . . . . . . . . . . . . . .
paper-tray capacities. . . . . . . . . . . . . . . .
automatic document feeder paper capacity
paper sizes . . . . . . . . . . . . . . . . . . . . . .
print margin specifications . . . . . . . . . . . .
fax specifications. . . . . . . . . . . . . . . . . . . . .
scan specifications. . . . . . . . . . . . . . . . . . . .
physical specifications . . . . . . . . . . . . . . . . .
power specifications . . . . . . . . . . . . . . . . . .
environmental specifications . . . . . . . . . . . . .
environmental product stewardship program . .
regulatory notices . . . . . . . . . . . . . . . . . . . .
declaration of conformity . . . . . . . . . . . . . . .
declaration of conformity . . . . . . . . . . . . . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.103
.103
.104
.104
.105
.105
.105
.106
.106
.106
.106
.109
.114
.115
12 fax setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
faxing from a DSL line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
faxing with a PBX phone system or an ISDN line . . . . . . . . . . . .
how to tell if the following instructions apply to you . . . . . . . . . .
how to choose the right fax setup for your office . . . . . . . . . . . .
select your fax setup case from this table . . . . . . . . . . . . . . . . .
case A: separate fax line (no voice calls received) . . . . . . . . . . .
how your hp officejet will answer fax calls . . . . . . . . . . . . . .
case B: faxing with a distinctive ring service on the same line . . .
how your hp officejet will answer fax calls . . . . . . . . . . . . . .
case C: shared voice/fax line . . . . . . . . . . . . . . . . . . . . . . . . .
hp officejet 4210 series (with no handset) . . . . . . . . . . . . . .
hp officejet 4250 series (with handset) . . . . . . . . . . . . . . . . .
case D: fax line shared with PC modem (no voice calls received) .
how your hp officejet will answer fax calls . . . . . . . . . . . . . .
case E: shared voice/fax line with PC modem. . . . . . . . . . . . . .
iv
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.118
.119
.119
.120
.121
. 123
. 123
. 124
. 124
.125
.125
. 126
. 126
. 127
.128
hp officejet 4200 series
contents
hp officejet 4210 series (with no handset). . . . . . . . . . . . . . . . . . 129
hp officejet 4250 series (with handset) . . . . . . . . . . . . . . . . . . . . 129
case F: shared voice/fax line with answering machine . . . . . . . . . . . 130
how your hp officejet will answer fax calls . . . . . . . . . . . . . . . . . 130
case G: shared voice/fax line with PC modem and answering machine131
how your hp officejet will answer fax calls . . . . . . . . . . . . . . . . . 132
case H: shared voice/fax line with voice mail . . . . . . . . . . . . . . . . . 133
how to answer fax calls manually . . . . . . . . . . . . . . . . . . . . . . . 133
case I: shared voice/fax line with PC modem and voice mail. . . . . . . 134
how to answer fax calls manually . . . . . . . . . . . . . . . . . . . . . . . 135
13 troubleshooting information . . . . . . . . . . . . . . . . . . . . . . . . . . 137
installation troubleshooting . . . . . . . . . . . . . . . . . . .
software and hardware installation troubleshooting
fax setup troubleshooting . . . . . . . . . . . . . . . . . .
operational troubleshooting. . . . . . . . . . . . . . . . . . .
user guide
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
137
137
146
150
v
contents
vi
hp officejet 4200 series
get help
This User Guide contains information on using your HP Officejet and provides
additional troubleshooting assistance for the installation process. The User Guide
also contains information on how to order supplies and accessories, technical
specifications, support, and warranty information.
The table below lists additional sources of information for your HP Officejet.
help
description
Setup Poster
The Setup Poster provides instructions for setting up and configuring your
HP Officejet. Make sure you use the correct instructions for your operating
system (Windows or Macintosh).
HP Image Zone Help The HP Image Zone Help provides detailed information on using the
software for your HP Officejet.
For Windows users: Go to the HP Director, and click Help.
For Macintosh users: Go to the HP Director, click Help, and then click
hp image zone help.
Note: The HP Image Zone Help is not available if you performed a
Minimum Install when you installed your software.
Troubleshooting help
To access troubleshooting information:
For Windows users: In the HP Director, click Help. Open the
Troubleshooting book in the HP Image Zone Help, then follow the links to
general troubleshooting as well as links to Troubleshooting help that is
specific to your HP Officejet. Troubleshooting is also available from the
Help button that appears on some error messages and in the
Troubleshooting chapter of this User Guide on page 137.
For Macintosh users: Open the Apple Help Viewer, click hp image zone
troubleshooting, then click hp officejet 4200 series.
Note: The HP Image Zone Troubleshooting is not available if you
performed a Minimum Install when you installed your software.
Internet help and
technical support
If you have Internet access, you can get help from the HP website at:
www.hp.com/support
The website also provides answers to frequently-asked questions.
Readme file
After you install your software, you can access the Readme file (if any) from
either the HP Officejet 4200 Series CD-ROM or the HP Officejet
4200 Series program folder. A Readme file contains late-breaking
information that does not appear in this User Guide or the online help.
1
help
description
Dialog-box help
(Windows only)
For Windows: Use one of the following ways to find information on a
specific feature:
• Right-click on the feature.
2
•
Select the feature and press F1.
•
Select the ? in the upper-right corner, then click on the feature.
hp officejet 4200 series
1
Your HP Officejet is ready to use whenever you are, as many features and
functions of your HP Officejet can be used without turning on your computer.
Tasks such as sending a fax or making a copy of a document or photo can be
accomplished quickly and easily from the front panel of your HP Officejet.
Tip: You can do more with your HP Officejet by using the
HP Director that was installed on your computer during the initial
setup. The HP Director provides enhanced fax, copy, and scan
functionality, as well as troubleshooting tips and online help. For
more information on the use of the HP Director, see use the
hp director software to do more with your hp officejet on page 8.
This section contains the following topics:
•
the hp officejet at a glance on page 4
•
front panel overview on page 5
•
menu overview on page 8
•
use the hp director software to do more with your hp officejet on page 8
3
hp officejet overview
hp officejet overview
hp officejet overview
chapter 1
the hp officejet at a glance
1
3
2
hp officejet 4210 series
4
5
10
9
8
7
6
1
3
2
hp officejet 4250 series
11
4
5
10
9
8
4
7
feature
purpose
1
Automatic document feeder tray
2
Automatic document feeder
3
Document guides
4
Front panel
5
Print-carriage access door
6
Paper tray
7
Paper tray extender
8
Paper guides
9
Document catcher
10
Document catcher extender
11
Handset (handset model only)
6
hp officejet 4200 series
hp officejet overview
hp officejet overview
12
13
14 15
16
18
17
feature
purpose
12
Power connector
13
1-LINE port
14
2-EXT port
15
USB port
16
Handset port (HP Officejet 4250 Series only)
17
Rear cleanout door
18
Rear cleanout door access tab
front panel overview
1
2
3
4
5
6
8
7
9
10
11
12
13
21
user guide
20
19
17
18
15
16
14
5
hp officejet overview
chapter 1
feature
purpose
1
Answer Mode: Switch between four answer settings, Fax (Fax)
mode, Telephone (Tel) mode, Fax and Telephone (FaxTel) mode
(only available on the HP Officejet 4250 Series), and Answering
Machine (AnswerMachine) mode. See set the answer mode on
page 44 for an explanation of these settings.
2
Fax Resolution: Choose the resolution in which a fax will be sent.
3
Redial/Pause: Redial the most recently dialed fax number. Also, use
to insert a pause while entering a telephone number.
4
Speed Dial: Select a number from programmed speed dial entries.
Use the Speed Dial button, the arrows, or the keypad numbers on
the front panel to navigate to a speed dial fax number.
5
Status Light: Indicates whether the HP Officejet is on, off, or busy.
6
Attention Light: Indicates an error condition.
7
Front Panel Display: View menus, prompts, status messages, and
error messages.
8
Flash: Cancel a fax and bring up a dial tone. Also, use to answer
a call waiting (handset model only).
9
Photo Fit to Page: Resize a copy of a photo, maintaining its
proportions, to fit within the printable area of a full-size page.
10
Setup: Access the menu system for reports, speed dial setup, fax
settings, tools, and preferences.
11
Fax: Select the fax function. Press the Fax button repeatedly to scroll
through the Fax menu settings.
12
Scan: Select the scan function. Press the Scan button repeatedly to
scroll through the Scan menu settings.
13
Copy: Select the copy function. Press the Copy button repeatedly to
scroll through the Copy menu settings.
14
Start Black, Start Color: Start a black or color fax, copy, or scan job.
15
Cancel: Stop a job, exit a menu, exit settings, or exit the speed dial
menu.
16
Right Arrow: Increase values, or go forward when viewing settings
on the front panel display.
17
OK: Select the current menu setting on the front panel display. Also,
use to respond to prompts on the front panel display.
18
Left Arrow: Decrease values, or go back when viewing settings on
the front panel display.
19
On: Turn the HP Officejet on or off.
Warning! When the HP Officejet is off, a minimal amount of
power is still supplied to the device. Unplug the power cord to
completely disconnect the power supply to the HP Officejet.
6
hp officejet 4200 series
hp officejet overview
purpose
20
Keypad: Enter fax numbers, values, or text.
21
One-Touch Speed Dial: Dial a fax number quickly by pressing a
one-touch speed dial button. The 5 one-touch speed dial buttons
each hold 2 numbers and correspond to the first 10 fax numbers
entered during speed dial setup.
user guide
hp officejet overview
feature
7
hp officejet overview
chapter 1
menu overview
The following provides a quick reference to top-level menus that appear on the
HP Officejet front panel display.
Copy
Number of Copies
Copy Quality
Lighter/Darker
Reduce/Enlarge
Paper Type
Copy Paper Size
Enhancements
Color Intensity
Set New Defaults
Fax
Phone Number
Backup Fax Reception
Lighter/Darker
How to Fax
Set New Defaults
Scan
HP Image Zone
Setup
1: Print Report
2: Speed Dial Setup
3: Basic Fax Setup
4: Advanced Fax Setup
5: Tools
6: Preferences
Note: Contents of this menu
vary depending on the
number of potential scan
destinations on your computer.
use the hp director software to do more with your hp officejet
When you first installed the HP Officejet software on your computer during setup,
the HP Director was automatically installed on your computer.
Note: If you performed a Minimum Install when you set up your
HP Officejet, you will not have access to the HP Director and HP Image
Zone software.
You can quickly and easily expand the functionality of your HP Officejet. Look
for boxes, like this one, throughout this guide that provide topic-specific tips, and
helpful information for your projects.
This section contains the following topics:
8
•
open the hp director for Windows users on page 9
•
open the hp director for Macintosh users on page 10
hp officejet 4200 series
hp officejet overview
1
Do one of the following:
– Double-click the HP Director icon on the desktop.
– In the Windows taskbar, click Start, point to Programs or All Programs
(XP), point to HP, then select HP Director.
2
In the Select Device box, click to see a list of installed HP devices.
3
Select the Officejet 4200 Series.
4
The HP Director displays only the icons that are appropriate for the
selected device.
Note: The HP Director graphic below might appear differently on your
computer. The HP Director is customized based upon the HP device that is
selected. If your device is not equipped with a particular feature, then the
icon for that feature will not display in the HP Director on your computer.
Tip: If the HP Director on your computer does not contain any
icons, an error might have occurred during the software
installation. To correct this, use the Control Panel in Windows to
completely uninstall the HP Director software, and then reinstall the
HP Director.
1
2
3
6
5
4
7
8
9
10
14
13
12
feature
user guide
11
purpose
1
Scan Picture: use this feature to scan an image and display
it in the HP Image Zone.
2
Scan Document: use this feature to scan text and display it
in the selected text editing software program.
3
Send a Fax: use this feature to open the fax dialog box so
you can enter the appropriate information and then send
your fax.
9
hp officejet overview
open the hp director for Windows users
hp officejet overview
chapter 1
feature
purpose
4
Make Copies: Use this feature to display the Copy dialog
box where you can select the copy quality, number of
copies, color, size, and then start a copy.
5
Status: Use this feature to display the current status of your
HP Officejet.
6
Select Device: Use this feature to select the device you want
to use from the list of installed HP devices.
7
Settings: Use this feature to view or change various settings
for your HP Officejet, such as print, scan, copy, or fax.
8
Help: Use this feature to access the HP Image Zone Help,
which provides software help, a product tour,
troubleshooting information for your HP Officejet, and
HP Officejet product-specific help.
9
HP Image Zone: Use this feature to display the HP Image
Zone, where you can view and edit images, print photos in
multiple sizes, make and print a photo album, share
images through e-mail or a website, or make a multimedia
CD.
10
Click this arrow to display tool tips that explain each of the
HP Director options.
11
Software Update: Use this feature to check for software
updates for your HP Officejet.
12
HP Shopping: Use this feature to shop for HP products.
13
Creative Ideas: Use this feature to learn about creative
ways to use your HP Officejet.
14
Support: Use the feature to go to the product support
website.
open the hp director for Macintosh users
Use one of the following methods to launch or access the HP Director, depending
on which Macintosh OS you are using.
open the hp director using Macintosh OS X
If you are using Macintosh OS X, the HP Director is launched automatically
during the HP Image Zone software installation, and causes the HP Director icon
to be created in the Dock for your device. You access the device capabilities via
the HP Director menu that is associated with the HP Director icon.
Tip: If you do not want the HP Director to launch automatically
each time to start your Macintosh, you can change this setting in
the HP Director Preferences menu.
To display the HP Director menu:
!
10
In the Dock, click the HP Director icon for your device.
The HP Director menu displays.
hp officejet 4200 series
hp officejet overview
1
2
3
4
5
6
7
8
9
feature purpose
user guide
1
Scan Picture: use this feature to scan an image and display it in
the HP Gallery.
2
Scan document: use this feature to scan text and display it in the
selected destination text editing software program.
3
Make Copies: use this feature to make a copy in black and white
or color.
4
Send Fax: use this feature to open the fax dialog box so you can
enter the appropriate information and then send your fax.
5
HP Gallery: use this feature to display the HP Gallery to view
and edit images.
6
More Applications: use this feature to select other applications on
your computer.
7
HP on the Web: use this feature to select an HP website.
8
HP Help: use this feature to select a source for help with your
HP Officejet.
9
Settings: use this feature to change device settings.
11
hp officejet overview
Note: If you install more than one HP device, an HP Director icon for each
device appears in the Dock. For example, if you have an HP scanner and
an HP Officejet installed, two HP Director icons are present in the Dock, one
for each device. However, if you installed two of the same kind of device
(for example, two HP Officejet devices) only one HP Director icon appears
in the Dock to represent all devices of that kind.
chapter 1
hp officejet overview
open the hp photo and imaging director using Macintosh OS 9
In Macintosh OS 9, the HP Director is launched automatically during the
HP Image Zone software installation, and the HP Director appears as an alias
on the desktop. Use one of the following methods to launch the HP Director.
!
Double-click the HP Director alias on the desktop.
!
Double-click HP Director in the Applications:Hewlett-Packard:HP Photo and
Imaging Software:HP Director folder.
The HP Director displays only the buttons that pertain to the selected device. For
more information, see the onscreen hp image zone help that came with your
software.
The following graphic shows some of the features available through the
HP Director for Macintosh OS 9. Consult the legend for a brief explanation of
specific features.
Note: The HP Director graphic below might appear differently on your
computer. The HP Director is customized based upon the HP device that is
selected. If your device is not equipped with a particular feature, then the
icon for that feature will not display in the HP Director on your computer.
Some HP devices might show additional buttons than shown below.
1
12
2
3
4
5
6
7
feature
purpose
1
Scan Picture: use this feature to scan an image and display it in
the HP Gallery.
2
Scan document: use this feature to scan text and display it in the
selected destination text editing software program.
3
Select Device: use this pull-down list to select the HP device you
want to use.
4
Make Copies: use this feature to make a copy in black and
white or color.
5
Send Fax: use this feature to open the fax dialog box so you can
enter the appropriate information and then send your fax.
6
HP Gallery: use this feature to display the HP Gallery to view
and edit images.
hp officejet 4200 series
hp officejet overview
purpose
7
Settings: use this pull-down list to provide access to device
settings.
hp officejet overview
user guide
feature
13
hp officejet overview
chapter 1
14
hp officejet 4200 series
load paper and load originals
2
The HP Officejet 4200 Series allows you to load different types and sizes of
paper in your HP Officejet, including letter, photo paper, and envelopes. You
can also change settings for paper types and paper sizes to get the highest
quality copies from your HP Officejet.
•
open and close the hp officejet on page 15
•
papers for printing and copying on page 17
•
load paper on page 19
•
set the paper type on page 23
•
set the paper size on page 24
•
avoid jams on page 25
•
load originals on page 25
load originals & paper
This section contains the following topics:
open and close the hp officejet
The HP Officejet’s trays are designed to close in order to save space in your
office. These procedures show you how to open and close the paper tray,
document catcher, and the document feeder tray.
Tip: You can print and automatically receive faxes with the
document feeder tray and document catcher in the closed position,
as shown below.
This section contains the following topics:
•
open and close the paper tray on page 15
•
open and close the document feeder tray and document catcher on
page 16
open and close the paper tray
The paper tray must be open with paper loaded for the HP Officejet to print,
copy, and receive faxes.
15
chapter 2
Open the paper tray door.
2
Unfold the paper tray.
3
Only unfold the paper tray extender if you are using Draft or Fast mode
and paper is overshooting the paper tray. The paper tray extender may
cause jams in other cases.
load originals & paper
1
open and close the document feeder tray and document catcher
The document feeder tray and document catcher must be open to copy, send
faxes and scan. However, you can print and receive faxes with them closed.
1
16
Lift the document feeder tray.
hp officejet 4200 series
load paper and load originals
2
Lower the document catcher and unfold the document catcher extender.
papers for printing and copying
You can use many types and sizes of paper in your HP Officejet. Review the
following recommendations to get the best printing and copying quality.
Whenever you change paper types or sizes, remember to change those settings.
This section contains the following topics:
•
recommended papers on page 17
•
papers to avoid on page 18
recommended papers
These are the types and sizes of papers recommended for printing and copying.
paper types
If you want the best print quality, we recommend HP Papers. Using paper that is
too thin, paper that has a slick texture, or paper that stretches easily can cause
paper jams. Using paper that has a heavy texture or does not accept ink can
cause printed images to smear, bleed, or not be filled in completely. For more
information about HP Papers, go to our website at:
www.hp.com/support
user guide
•
HP Premium Paper is the ultimate coated paper for high-resolution usage. A
smooth, matte finish makes it ideal for your special documents.
•
HP Bright White Paper delivers high-contrast colors and sharp text. It is
opaque enough for two-sided color usage, with no show-through, which
makes it ideal for newsletters, reports, and flyers.
•
HP Premium Photo Paper, Glossy and Matte, and HP Premium Plus Photo
Paper, Glossy and Matte are high-quality, glossy-finish or matte-finish,
photo-based papers. They look and feel like photographs and can be
mounted under glass or in an album. Photo papers dry rapidly and resist
fingerprints and smudges. HP Premium Plus Photo Paper, Glossy and
17
load originals & paper
Note: The document catcher and document catcher extender must be
closed before the document feeder tray can be closed.
chapter 2
load originals & paper
HP Premium Plus Photo Paper, Glossy and Matte are available in 4 by 6
inch (10 by 15 cm) photo paper size (with tabs) for printing photos from
your HP Officejet.
•
HP Premium Inkjet Transparency Film makes your color presentations vivid
and even more impressive. This film is easy to use and handle and dries
quickly without smudging.
•
HP Matte Greeting Cards, HP Glossy Greeting Card Paper, HP Textured
Greeting Cards, Ivory, Half-Fold and HP Textured Greeting Cards, White,
Half-Fold allow you to make your own greeting cards.
•
HP Brochure & Flyer Paper, Glossy or HP Brochure & Flyer Paper, Matte is
matte-coated or glossy-coated on both sides for two-sided use. It is the
perfect choice for near-photographic reproductions and business graphics
for report covers, special presentations, brochures, mailers, and calendars.
paper sizes for printing
Following are the paper sizes available for printing.
size group
specific size
full size pages
letter, A4, legal
smaller pages
executive, B5, A5, A6
photo paper
letter, A4, 4 by 6 inch with tear off tabs
cards
3 by 5 inch, 4 by 6 inch, Hagaki, 5 by 8 inch, A6
envelopes
#10 and DL
paper sizes for copying
You may copy only onto full size pages (letter, legal and A4) of plain and photo
paper and transparency film.
papers to avoid
We do not recommend the following papers for printing:
•
Paper with cutouts or perforations.
•
Highly textured stock, such as linen. It might not print evenly, and the ink
can bleed into these papers.
•
Extremely smooth, shiny, or coated papers not specifically designed for
your HP Officejet. They can jam the HP Officejet or actually repel ink.
•
Multi-part forms (such as duplicate and triplicate forms). They can wrinkle
or get stuck. The ink is also more likely to smear.
•
Envelopes with clasps or windows.
We do not recommend the following papers for copying:
18
•
Paper with cutouts or perforations.
•
Photo paper other than HP Premium Plus Photo Paper.
•
Envelopes.
•
Transparency film other than HP Premium or Premium Plus.
•
Multiple-part forms or label stock.
hp officejet 4200 series
load paper and load originals
load paper
These procedures describe how to load different sizes and types of papers into
the paper tray for printing and copying.
This section contains the following topics:
•
load full-size papers on page 19
load envelopes on page 20
•
load 4 by 6 inch (10 by 15 cm) photo paper with tear off tabs on page 20
•
load postcards, index, or Hagaki cards on page 22
•
load other types of paper in the paper tray on page 22
load full-size papers
The following procedure describes how to load letter, legal, and A4 size paper
into the paper tray. There are specific considerations for loading certain types of
paper and envelopes. After you review this procedure, see load envelopes on
page 20, load 4 by 6 inch (10 by 15 cm) photo paper with tear off tabs on
page 20, and load other types of paper in the paper tray on page 22.
For best results, adjust the paper settings each time you change paper types or
paper sizes. For more information, see set the paper type for copying on
page 24.
Tip: Help prevent rips, wrinkles, and curled or bent edges by
storing all media flat in a resealable bag. Extreme changes in
temperature and humidity might result in curled media that does
not work well in the HP Officejet if the media is not stored properly.
user guide
1
Open the paper tray door and unfold the paper tray. See open and close
the paper tray on page 15.
2
If it is open, fold up the document catcher.
3
Slide the paper guide to its outermost position.
4
Tap the stack of paper on a flat surface to align the edges of the paper,
and then check to make sure all of the paper in the stack is the same size
and type.
5
Insert the short edge of the paper into the paper tray (print side down) until
it stops. To avoid bending the paper, make sure you do not push the paper
in too far, or push too hard. If you are using letterhead, insert the top of the
page first.
19
load originals & paper
•
chapter 2
load originals & paper
6
Slide the paper guide in until it stops at the edge of the paper. Make sure
that the stack of paper lies flat in the paper tray and fits under the tab of
the paper guide.
load envelopes
The following procedure describes how to load envelopes into the HP Officejet.
You can load the paper tray with one or more envelopes. For best results,
consider using a label for the return address on envelopes. Do not use shiny or
embossed envelopes, or envelopes that have clasps or windows.
Tip: Consult your word processing software help files for specific
details on how to format text for printing on envelopes.
1
Remove all paper from the paper tray.
2
Insert one or more envelopes into the right side of the paper tray with the
envelope flap up and to the left. Slide the envelope forward until it stops.
3
Slide the paper guide against the envelopes (do not bend the envelopes
with the paper guide). Make sure the envelopes fit under the tab of the
paper guide.
load 4 by 6 inch (10 by 15 cm) photo paper with tear off tabs
The following procedure describes how to load 4 by 6 inch (10 by 15 cm) photo
paper with tear off tabs into your HP Officejet. Do not use 4 by 6 inch (10 by
15 cm) photo paper without the tear off tabs.
Note: You cannot copy or fax to small size paper.
20
hp officejet 4200 series
load paper and load originals
Note: For the best results, use a recommended type of 4 by 6 inch (10 by
15 cm) photo paper with tear off tabs. For more information, see
recommended papers on page 17. In addition, for best results, set the
paper type and paper size before printing. For more information, see set the
paper type for copying on page 24 and set the paper size on page 24. You
may also want to use a photo cartridge to produce the best picture quality.
For more information, see use a photo print cartridge on page 85.
user guide
1
Remove all paper from the paper tray.
2
Insert the short edge of a stack of photo paper with the glossy (print) side
down and the tear off tabs toward you, completely forward and to the far
right side of the paper tray until it stops.
3
Slide the paper guide against the stack of photo paper (do not bend the
photo paper with the paper guide). Make sure the stack of photo paper fits
under the tab of the paper guide.
21
load originals & paper
Tip: Help prevent rips, wrinkles, curled or bent edges by storing
all media flat in a resealable bag. Extreme changes in temperature
and humidity might result in curled media that does not work well
in the HP Officejet if the media is not stored properly.
chapter 2
load postcards, index, or Hagaki cards
The following describes the procedure for loading postcards, index cards, or
Hagaki cards into your HP Officejet for printing.
Note: You cannot copy or fax to small size paper.
Remove all paper from the paper tray.
2
Slide a stack of cards with the print side down completely forward and to
the far right side of the paper tray until it stops. Position the long edge of
the cards against the long edge of the paper tray.
3
Slide the paper guide against the stack of cards. Make sure the stack of
cards fits under the tab of the paper guide.
load originals & paper
1
load other types of paper in the paper tray
The following table provides guidelines for loading certain types of paper and
transparency film. For best results, adjust the paper type each time you change
paper types and paper sizes. For more information, see set the paper type for
copying on page 24.
paper
tips
HP Papers
• HP Premium Paper: Locate the gray arrow on the
nonprinting side of the paper, and then insert the
paper with the arrow side facing up.
• HP Premium Inkjet Transparency Film: Insert the film
so that the white transparency strip (with arrows and
the HP logo) is on top and goes into the paper tray
first.
• HP Greeting Card Paper, HP Glossy Greeting Card
Paper, or HP Textured Greeting Cards: slide a small
stack of greeting cards with the print side down,
completely forward into the paper tray until it can
go no further.
22
hp officejet 4200 series
load paper and load originals
paper
tips
Labels
(work only with
printing)
• Always use letter or A4 label sheets designed for
use with HP inkjet products (like Avery Inkjet Labels),
and make sure that the labels are not over two years
old.
• Fan the stack of labels to make sure none of the
pages are stuck together.
load originals & paper
• Place a stack of label sheets on top of standard
paper in the paper tray, print side down. Do not
insert labels one sheet at a time.
set the paper type
Whenever you change paper types, be sure to set the paper type for your
HP Officejet.
paper type settings for copying
Select the Paper Type setting that matches the paper or transparency film you are
using. Use the paper types listed for best copy quality.
paper
front panel setting
Copier paper or letterhead
Plain
Other plain paper
Plain
HP Premium Paper
Plain
HP Bright White Paper
Plain
Other Inkjet papers
Plain
HP Premium Photo Paper
HP Premium Plus Photo Paper
Other photo paper1
HP Premium Inkjet Transparency Film
Transparency
Other transparency paper
Transparency
Special Papers
Plain
HP Matte Greeting Cards, Quarter-fold
Plain
HP Glossy Greeting Cards, Half-fold
Plain
HP Felt-Textured Greeting Cards
Plain
HP Professional Brochure & Flyer Paper, Glossy
HP Professional Brochure & Flyer Paper, Matte
Plain
1 Not all photo papers are compatible.
user guide
23
chapter 2
set the paper type for copying
The following procedure describes how to set the paper type for the Copy option
on your HP Officejet. Select the Paper Type setting that matches the paper or
transparency film you are using.
load originals & paper
Note: These steps are for copying, when printing from your computer, set
the paper-type properties in the Print or Page Setup dialog box of the
software program from which you are printing.
1
Press the Copy button until Paper Type appears.
2
Press ! until the appropriate paper type appears.
3
Press OK to choose the displayed paper type.
Note: This setting returns to its default setting two minutes after the job has
been completed. For information on changing the default setting, see
change default copy settings on page 28.
set the paper size
The following procedure describes how to set the paper size on your
HP Officejet. Select the Paper Size in software for printing and the Paper Size
setting for copying or faxing that matches the paper or transparency film you are
using.
This section contains the following topics:
•
paper size setting for copying on page 24
•
paper size setting for receiving a fax on page 24
paper size setting for copying
Copies can be made onto letter, A4, or legal paper only.
Note: This setting returns to its default setting two minutes after the job has
been completed. For information on changing the default copy setting, see
change default copy settings on page 28.
1
Press the Copy button until Copy Paper Size appears.
2
Press ! until the appropriate paper size appears.
3
Press OK to choose the displayed paper size.
paper size setting for receiving a fax
You can select the paper size for received faxes. The paper size selected should
match what is loaded in your paper tray. Faxes can be printed on letter, A4, or
legal paper only.
Note: If an incorrect paper size is loaded in the paper tray when a fax is
received, the fax will not print. Load letter, A4, or legal paper, and then
press OK to print the fax.
24
1
Press Setup.
2
Press 3, then press 4.
This selects Basic Fax Setup and then Fax Paper Size.
3
Press ! to highlight an option, and then press OK.
hp officejet 4200 series
load paper and load originals
avoid jams
To help avoid paper jams, follow these guidelines:
Prevent curled or wrinkled paper by storing all unused media flat in a
resealable bag.
•
Remove printed papers from the output tray frequently.
•
Ensure that media loaded in the automatic document feeder and the paper
tray lay flat and the edges are not bent or torn.
•
Do not combine different paper types and paper sizes in either the
automatic document feeder or in the paper tray. Always load the same
paper type and paper size in the automatic document feeder or in the
paper tray.
•
Adjust paper guides in the automatic document feeder and the paper tray
to fit snugly against all media. Make sure the paper guides do not bend
the media.
•
Do not force media too far forward in the paper tray.
•
Use paper types that are recommended for your HP Officejet.
load originals
You can copy, fax, or scan an original by placing it in the document feeder tray.
The following procedure describes how to load originals into the HP Officejet
automatic document feeder.
Note: The document feeder tray holds a maximum of 20 sheets of paper.
Tip: When working with fragile, torn, or odd-sized originals, we
recommend that you use a document sleeve or sheet protector
(available from most office-product stores) for the original. Place a
single sleeve into the ADF with the sealed edge first and the
transparent side down.
1
Load your original in the center of the document feeder tray face down and
top first.
Tip: Always load small originals in a portrait orientation, with the
shorter edge going into the HP Officejet first.
2
Slide the document guides inward until they stop at the edges of the
original.
Tip: Make sure the document catcher extender is unfolded.
user guide
25
load originals & paper
•
chapter 2
3
Press Copy, Scan, or Fax on the front panel.
Note: If you want to change a Copy or Fax setting, or change a Scan
destination, press the Copy, Fax, or Scan button repeatedly until the
appropriate setting or destination appears on the front panel display. Once
the setting you want to change appears, press ! to move to a specific value
(such as a specific paper size) and then press OK to select the setting or
destination.
4
Press Start Black or Start Color on the front panel to start the job.
load originals & paper
For more information on making copies of original photos, see copy a photo onto
a full-size page on page 30.
26
hp officejet 4200 series
use the copy features
3
The HP Officejet enables you to produce high-quality color and black-and-white
copies on plain paper, photo paper, and transparencies. You can enlarge or
reduce the size of an original to fit a specific paper size, adjust the copy’s
darkness, and use special features to make high-quality copies of photos,
enlarged to fit a full page.
This section contains the following topics:
•
overview on page 27
•
copy a two-page black-and-white document on page 29
•
make multiple copies of the same original on page 30
•
copy a photo onto a full-size page on page 30
•
copy a legal-size document onto letter paper on page 32
•
copy a washed-out original on page 32
•
copy a document that has been faxed several times on page 33
•
enhance light areas of your copy on page 34
•
stop copying on page 34
copy
overview
You can make copies by using the front panel of your HP Officejet or by using
the HP Director software on your computer. Many copy features are available
using either method. However, you might find that the software offers easier
access to special copy features.
This section explains how to perform common copy tasks from the HP Officejet
front panel only. For more information on performing copy tasks from the
HP Director, see the onscreen HP Image Zone Help that came with your
software.
This section contains the following topics:
•
use the copy features from the front panel on page 27
•
increase copy speed or quality on page 28
•
change default copy settings on page 28
use the copy features from the front panel
1
Load your original, and then press the Copy button on the front panel.
The first option in the Copy menu appears in the front panel display.
2
Press Copy repeatedly to scroll through the menu options.
3
When the option you want to change appears in the front panel display,
press the " and ! buttons to scroll through the option settings.
Note: To change multiple options, press OK after each setting.
4
Press Start Black or Start Color.
27
chapter 3
increase copy speed or quality
The HP Officejet provides three options that affect copy speed and quality.
•
Normal delivers high-quality output and is the recommended setting for
most of your copying. Normal copies faster than Best.
•
Fast copies faster than the Normal setting. The text is of comparable quality
to the Normal setting, but the graphics might be of lower quality. Using
Fast reduces the frequency of replacing your print cartridges, because it
uses less ink.
•
Best produces the highest quality for all paper and eliminates the banding
(striping) effect that sometimes occurs in solid areas. Best copies more
slowly than the other quality settings.
1
Load your original face down and top first in the document feeder tray. For
more information, see load originals.
2
Press Copy until Copy Quality appears in the top line of the display.
The following options are available in the Copy Quality menu.
copy
Copy Menu
Number of Copies
Copy Quality
Lighter/Darker
Reduce/Enlarge
Paper Type
Copy Paper Size
Enhancements
Color Intensity
Set New Defaults
Copy Quality
Normal
Fast
Best
3
Press ! until the quality setting you want appears.
4
Press Start Black or Start Color.
change default copy settings
When you change copy settings from the front panel or the HP Director, they
apply only to the current copy job. To apply copy settings to all future copy jobs,
you can save the settings as defaults.
28
1
Load an original face down and top first in the document feeder tray. For
more information, see load originals on page 25.
2
Make any changes to the options in the Copy menu.
hp officejet 4200 series
use the copy features
3
Press Copy until Set New Defaults appears in the top line of the display.
Copy Menu
Number of Copies
Copy Quality
Lighter/Darker
Reduce/Enlarge
Paper Type
Copy Paper Size
Enhancements
Color Intensity
Set New Defaults
4
Press ! until Yes appears.
5
Press Start Black or Start Color to make a copy with the new default
settings or press OK to save the settings without making a copy.
The settings you specify here are only saved on the HP Officejet itself. They do
not adjust the settings in the software. If you use the HP Director software to
control the settings on copies you make, you should set your most frequently
used settings as the defaults in the HP Copy dialog box. For more information,
see the onscreen hp image zone help that came with your software.
copy
copy a two-page black-and-white document
You can use the HP Officejet to copy a single- or multiple-page document in color
or black and white. In this example, the HP Officejet is used to copy a two-page
black-and-white original.
user guide
1
Arrange your originals so they are in order with the first page on top.
2
Load your originals face down and top first in the document feeder tray.
For more information, see load originals on page 25.
3
Press Copy.
4
Press Start Black.
29
chapter 3
make multiple copies of the same original
1
Load your original face down and top first in the document feeder tray. For
more information, see load originals on page 25.
2
Press Copy until Number of Copies appears in the top line of the display.
3
Press ! or use the keypad to enter the number of copies, up to the
maximum.
(The maximum number of copies varies by model.)
Tip: If you hold down either of the arrow buttons, the number of
copies changes by increments of 5 to make it easier to set a large
number of copies.
4
Press Start Black or Start Color.
If you are copying a stack of originals in the document feeder tray, the
HP Officejet makes multiple copies of a single page before copying the
next page. You will need to sort and staple the copies yourself.
copy a photo onto a full-size page
copy
Use Photo Fit to Page when you want to automatically enlarge your original
photo to fill the printable area of the paper size loaded in the paper tray.
Photo Fit to Page only enlarges original photos that are standard photo sizes. The
standard photo sizes are as follows:
•
3.5 by 5 inches (9 by 13 cm)
•
4 by 6 inches (10 by 15 cm)
•
5 by 7 inches (13 by 18 cm)
•
6 by 8 inches (15 by 20 cm)
•
8 by 10 inches (25 by 25 cm)
For originals containing text or photos that are not a standard size, use Reduce/
Enlarge.
Tip: You can optimize the quality of the photos you print and copy
with your HP Officejet by purchasing a photo print cartridge.
Remove the black print cartridge and insert the photo print
cartridge in its place. (See use the print cartridge protector on
page 85 for proper storage information.) With the tri-color print
cartridge and the photo print cartridge installed, you have a sixink system, which provides enhanced quality photos. When you
want to print regular text documents, swap the black cartridge
back in.
For more information, see order print cartridges on page 75.
30
hp officejet 4200 series
use the copy features
Load your original photo face down and top first in the document feeder
tray. For more information, see load originals on page 25.
Position the photo in the center of the document feeder tray and move the
paper guides next to it.
2
Load letter or A4 paper in the paper tray.
3
Press Photo Fit to Page.
The HP Officejet only supports copying to letter, A4, and legal-size paper.
Paper Type appears in the top line of the display.
Paper Type
Plain Paper
Photo Paper
4
Press ! until Plain Paper or Photo Paper appears, as appropriate.
5
Press Start Color.
Note: In order to fit your original within the printable area of the full-size
page without changing the proportions of the original, the HP Officejet
might leave an uneven amount of white space around the edges of the
paper.
user guide
31
copy
1
chapter 3
copy a legal-size document onto letter paper
1
Load the legal document face down and top first in the document feeder
tray. For more information, see load originals on page 25.
2
Press Copy until Reduce/Enlarge appears in the top line of the display.
The following options are available in the Reduce/Enlarge menu.
Copy Menu
Number of Copies
Copy Quality
Lighter/Darker
Reduce/Enlarge
Paper Type
Copy Paper Size
Enhancements
Color Intensity
Set New Defaults
Reduce/Enlarge
Actual Size
Custom 100%
Full Page 91%
Legal > Ltr 72%
Press ! until Legal > Ltr 72% appears.
4
Press Start Black or Start Color.
The HP Officejet reduces the size of your original to fit within the printable
area of the letter paper, as shown below.
copy
3
copy a washed-out original
Use Lighter/Darker to adjust the lightness and darkness of the copies you make.
1
Load your original face down and top first in the document feeder tray. For
more information, see load originals on page 25.
2
Press Copy until Lighter/Darker appears in the top line of the display.
The range of Lighter/Darker values appears as circles on a scale on the
front panel display.
3
Press ! to darken the copy.
Note: You can also press " to lighten the copy.
4
32
Press Copy until Color Intensity appears in the top line of the display.
The range of Color Intensity values appears as circles on a scale on the
front panel display.
hp officejet 4200 series
use the copy features
5
Press ! to make the image more vivid.
Note: You can also press " to make the image more pale.
6
Press Start Color or Start Black.
copy a document that has been faxed several times
The Enhancements feature automatically adjusts the quality of text documents by
sharpening edges of black text or photographs by enhancing light colors that
might otherwise appear white.
Text enhancement is the default option. Use Text enhancement to sharpen edges
of black text. Use Photo to enhance light colors in your photographs, Mixed if
your original contains both photographs and text, or None to turn off all
enhancements.
1
Load your original face down and top first in the document feeder tray. For
more information, see load originals on page 25.
2
Press Copy until Enhancements appears in the top line of the display.
The following options are available in the Enhancements menu.
3
4
copy
Copy Menu
Number of Copies
Copy Quality
Lighter/Darker
Reduce/Enlarge
Paper Type
Copy Paper Size
Enhancements
Color Intensity
Set New Defaults
Enhancements
Text
Mixed
None
Press ! until Text appears.
Press Start Black or Start Color.
Tip: If any of the following occur, turn off Text enhancement by
selecting Photo or None:
–
–
–
–
user guide
Stray dots of color surround some text on your copies
Large, black typefaces look splotchy (not smooth)
Thin, colored objects or lines contain black sections
Horizontal grainy or white bands appear in light- to medium-gray areas
33
chapter 3
enhance light areas of your copy
Use Photo enhancements to enhance light colors that might otherwise appear
white. You can also copy with Photo enhancements to eliminate or reduce any
of the following that might occur when copying with Text enhancements:
•
Stray dots of color surround some text on your copies
•
Large, black typefaces look splotchy (not smooth)
•
Thin, colored objects or lines contain black sections
•
Horizontal grainy or white bands appear in light- to medium-gray areas
1
Load your original photo face down and top first in the document feeder
tray. For more information, see load originals on page 25.
2
Press Copy until Enhancements appears in the top line of the display.
The following options are available in the Enhancements menu.
copy
Copy Menu
Number of Copies
Copy Quality
Lighter/Darker
Reduce/Enlarge
Paper Type
Copy Paper Size
Enhancements
Color Intensity
Set New Defaults
Enhancements
Text
Mixed
None
3
Press ! until Photo appears.
4
Press Copy until Color Intensity appears in the top line of the display.
The range of Color Intensity values appears as circles on a scale on the
front panel display.
5
Press ! to make the image more vivid.
Note: You can also press " to make the image more pale.
6
Press Start Color or Start Black.
stop copying
!
To stop copying, press Cancel on the front panel.
The HP Officejet immediately stops printing and releases the paper.
34
hp officejet 4200 series
use the scan features
4
Scanning is the process of converting pictures and text into an electronic format
for your computer. You can scan photos and text documents.
Because the scanned image or text is in an electronic format, you can bring it
into your word processor or graphics software program and modify it to suit your
needs. You can do the following:
•
Scan photos of your kids and e-mail them to relatives, create a
photographic inventory of your house or office, or create an electronic
scrapbook.
•
Scan text from an article into your word processor and quote it in a report,
saving you a lot of retyping.
To use the scan features, your HP Officejet and computer must be connected and
turned on. The HP Officejet software must also be installed and running on your
computer prior to scanning. To verify that the HP Officejet software is running on
a Windows PC, look for the hp officejet 4200 series icon in the system tray at
the lower right side of your screen, next to the time. On a Macintosh, the
HP Officejet software is always running.
You can start a scan from your computer or from your HP Officejet. This section
explains how to scan from the front panel of the HP Officejet only.
For more information about how to scan from the computer and how to adjust,
resize, rotate, crop, and sharpen your scans, see the onscreen
hp image zone help that came with your software.
Note: High resolution scanning (600 dpi or higher) requires a large amount
of hard disk space. If there is not enough hard disk space available, your
system might stall.
This section contains the following topics:
scan an original on page 36
•
stop scanning on page 36
scan
•
35
chapter 4
scan an original
1
Load your original face down and top first in the document feeder tray. See
load originals.
2
Press Scan.
A Scan menu appears, listing your existing scanning destinations. The
default destination is whichever one you selected the last time you used this
menu.
3
Select the destination by pressing " or !, or by pressing the Scan button
repeatedly.
4
Press Start Black or Start Color.
stop scanning
To stop scanning, press Cancel on the front panel.
scan
!
36
hp officejet 4200 series
use the fax features
5
Using your HP Officejet, you can send and receive faxes, including color faxes.
You can set up speed dials to send faxes quickly and easily to frequently used
numbers. From the front panel, you can set a number of fax options, such as
resolution.
This section contains the following topics:
•
send a fax on page 38
•
set the answer mode on page 44
•
receive a fax on page 47
•
use the attached handset (hp officejet 4250 series only) on page 50
•
set the fax header on page 51
•
enter text on page 52
•
enter a phone number on page 52
•
print reports on page 53
•
set up speed dialing on page 55
•
change fax resolution and lighter/darker settings on page 58
•
set fax options on page 60
•
reprint the faxes in memory on page 68
•
stop faxing on page 68
You should explore the HP Director that comes with your HP Officejet to take
full advantage of all of its features. Using the HP Director, you can do these
tasks and more that are not available through the front panel of your
HP Officejet. For more information, see the onscreen hp image zone help that
came with your software.
fax
37
chapter 5
send a fax
Using the front panel, you can send a black-and-white or color fax from your
HP Officejet.
This section contains the following topics:
•
enable fax confirmation on page 38
•
send a basic fax on page 39
•
send a color original or photo fax on page 39
•
send a fax using speed dials on page 40
•
send a fax using redial on page 41
•
schedule a fax on page 41
•
cancel a scheduled fax on page 42
•
send a fax from memory on page 42
•
send a fax using monitor dialing on page 43
•
send a fax manually from a telephone on page 43
enable fax confirmation
If you need printed confirmation that your faxes are successfully sent, follow these
instructions before sending any faxes.
The default fax confirmation setting is Every Error. This means that your
HP Officejet prints a report only if there is a problem with sending or receiving
a fax. A confirmation message indicating whether an item was successfully sent
appears briefly on the front panel display after each transaction. To have a
confirmation printed for every fax, follow these instructions. For more information,
see generate reports automatically on page 53.
1
Press Setup.
2
Press 1, then press 1.
This selects Print Report and then selects Automatic Reports Setup.
Print Report
1: Automatic Reports Setup
2: Last Transaction
3: Fax Log
4: Speed Dial List
5: Self-Test Report
6: Caller ID Report *
7: Junk Fax Report *
Automatic Reports Setup
Every Error
Send Error
Receive Error
Every Fax
Send Only
Off
* Not available in all countries/regions. This menu item does not appear in the Print
Report menu if any of the following apply:
fax
•
•
3
38
Caller ID service is not supported in your country/region.
Your country/region Caller ID service is not supported by the HP Officejet.
Press ! until Every Fax appears in the second line of the display, and then
press OK.
hp officejet 4200 series
use the fax features
The HP Officejet will print a confirmation report every time you send a fax
informing you whether the fax was sent successfully or not.
For more information on printing reports, see print reports on page 53.
send a basic fax
This section describes how to send a basic black-and-white fax from the front
panel.
If you are interested in sending a color or photo fax, see send a color original or
photo fax on page 39.
1
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
2
Press Fax.
Phone Number appears in the top line of the display.
3
Enter the fax number by using the keypad.
4
Press Start Black.
Tip: You must press Start to send a fax. Pressing OK is for menu
choices.
Did you know that you can send a fax from your computer by using the
HP Director that comes with your HP Officejet? You can also create and attach
a computer-generated cover page to send with your fax. It’s easy. For more
information, see the onscreen hp image zone help that came with your
software.
send a color original or photo fax
You can fax a color original or photo from your HP Officejet. If your HP Officejet
determines that the recipient’s fax machine only supports black-and-white faxes,
the HP Officejet sends the fax in black and white.
We recommend that you use only color originals for color faxing.
1
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
2
Press Fax.
Phone Number appears in the top line of the display.
3
Enter the fax number by using the keypad.
Tip: To enter a pause in the fax number, press Redial/Pause.
4
If you are faxing a photo, change the resolution to Photo.
For information on changing the resolution, see change the fax resolution
on page 58.
5
Press Start Color.
fax
user guide
39
chapter 5
Note: If the recipient’s fax machine only supports black-and-white faxes, the
HP Officejet automatically sends the fax in black and white. A message
appears once the fax has been sent indicating that the fax was sent in black
and white. Press OK to clear the message.
Did you know that you can send a fax from your computer by using the
HP Director that comes with your HP Officejet? You can also create and attach
a computer-generated cover page to send with your fax. It’s easy. For more
information, see the onscreen hp image zone help that came with your
software.
send a fax using speed dials
You can quickly send a fax from the front panel by pressing Speed Dial or a onetouch speed dial button on the front panel.
Speed Dials will not appear until you have set them up. For more information,
see set up speed dialing on page 55.
1
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
2
Press Fax.
Phone Number appears in the top line of the display.
3
Do one of the following:
– Press Speed Dial until the appropriate speed-dial entry appears in the
top line of the display. You can also scroll through the speed-dial
entries by pressing " or !.
– Press Speed Dial and then enter the speed-dial entry code from the front
panel.
– Press a one-touch speed dial button. Press it once to access the first
speed-dial entry and twice to access the second speed-dial entry
assigned to that button.
Tip: You can print out a list of the speed-dial entries for your
reference. For information, see generate reports manually on
page 54.
4
Press Start Black or Start Color.
Note: If you send a fax to a group speed dial, you can only send the fax in
black and white. The fax is scanned into memory and the first number in the
group speed dial list is dialed. When a connection is made, the fax is sent
and the next number is dialed, and so on. If a number is busy or not
answering, the HP Officejet follows the settings for Busy Redial and No
Answer Redial. If a connection cannot be made, the next number in the
group speed dial list is dialed and an error report is generated for your
information.
fax
You can quickly and easily set up speed-dial entries from your computer by
using the HP Director. For more information, see the onscreen
hp image zone help that came with your software.
40
hp officejet 4200 series
use the fax features
send a fax using redial
You can send a fax to the last fax number dialed by using the Redial/Pause
button.
1
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
2
Press Redial/Pause.
The last number dialed appears in the display.
3
Press Start Black or Start Color.
schedule a fax
You can schedule a black-and-white fax to be sent later the same day (for
example, when telephone lines are not as busy or phone rates are lower). When
scheduling a fax, the originals must be loaded in the automatic document feeder.
Tip: The date and time must already be set to use this feature. For
more information, see set the date and time on page 60.
When the specified time is reached, your fax is automatically sent as soon as a
connection can be made.
Note: Use the front panel to schedule a fax for later. If you use the handset
(HP Officejet 4250 Series only), the fax is sent immediately.
You can only schedule one fax to be sent at a time. You can continue to send
faxes normally, however, while a fax is scheduled.
1
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
2
Press Fax.
Phone Number appears in the top line of the display.
3
Enter the fax number by using the keypad, press a one-touch speed dial
button, or press Speed Dial until the appropriate speed-dial entry appears.
For more information on speed dials, see set up speed dialing on page 55.
Tip: To enter a pause in the fax number, press Redial/Pause.
4
Press Fax until How to Fax appears in the top line of the display.
5
Press ! until Send Fax Later appears in the top line of the display, and
then press OK.
6
Enter the Send Time by using the numeric keypad.
7
If prompted, press 1 for AM or 2 for PM.
8
Press Start Black.
Note: If you press Start Color, the fax will be sent in black and white and a
message will appear on the display.
The HP Officejet scans the originals into memory and sends them at the
scheduled time. The scheduled time appears on the front panel display.
fax
user guide
41
chapter 5
cancel a scheduled fax
You can cancel a scheduled fax or one that is currently in progress. Once you
schedule a fax, the scheduled time appears on the front panel display.
!
When the scheduled time appears on the display, press Cancel, and then
press 1.
send a fax from memory
Your HP Officejet can scan a black-and-white fax from the automatic document
feeder into memory before sending it. This feature is useful if the fax number you
are trying to reach is busy or temporarily unavailable. The HP Officejet scans the
originals into memory, and sends them once it is able to connect. You can
immediately remove the originals from the HP Officejet once the pages are
scanned.
Note: Use the front panel to send a fax from memory. If you use the handset
(HP Officejet 4250 Series only), the fax is sent immediately.
1
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
2
Press Fax.
Phone Number appears in the top line of the display.
3
Enter the fax number by using the keypad, press a one-touch speed dial
button, or press Speed Dial until the appropriate speed-dial entry appears.
For more information on speed dials, see set up speed dialing on page 55.
Tip: To enter a pause in the fax number, press Redial/Pause.
4
Press Fax until How to Fax appears in the top line of the display.
5
Press ! until Fax from Memory appears in the top line of the display.
6
Press Start Black.
Note: If you press Start Color, the fax is sent in black and white and a
message appears on the display.
fax
The HP Officejet scans the originals into memory and sends them when the
receiving fax machine is available.
42
hp officejet 4200 series
use the fax features
send a fax using monitor dialing
Monitor dialing allows you to dial a number from the front panel as you would
dial a regular telephone. This feature is useful when you want to use a calling
card to charge the call. You can also use it when you need to respond to tone
prompts while dialing and must pace your dialing speed.
Depending on which model you have, you can send a fax using monitor dialing
from the front panel or by using the attached handset (HP Officejet 4250 Series
only).
to send a fax using monitor dialing from the front panel
1
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
2
Press Start Black or Start Color.
3
Once you hear the dial tone, enter the number by using the keypad on the
front panel. You can also use speed dials. For information on using speed
dials, see send a fax using speed dials on page 40.
4
Follow any prompts that might occur.
Your fax is sent when the receiving fax machine answers.
to send a fax using monitor dialing from the handset (hp officejet
4250 series only)
Note: This procedure only applies to the HP Officejet 4250 Series product.
If you have an HP Officejet 4210 Series, refer to the previous section for
instructions.
1
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
2
Pick up the attached handset.
3
Once you hear the dial tone, enter the number by using the keypad on the
front panel. You can also use speed dials. For information on using speed
dials, see send a fax using speed dials on page 40.
4
Follow any prompts that might occur.
5
Press Start Black or Start Color.
Your fax is sent when the receiving fax machine answers.
send a fax manually from a telephone
Sending a fax manually allows you to make a phone call and talk with the
recipient before you send the fax. This is useful if you want to inform the recipient
that you are going to send them a fax before sending it.
You can send a fax manually by using a phone that is directly connected to your
HP Officejet or by using the attached handset (HP Officejet 4250 Series only).
The phone must be connected to the “2-EXT” port on the back of the HP Officejet.
1
user guide
fax
to send a fax manually from a connected phone
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
43
chapter 5
2
Dial the number by using the keypad on the phone that is connected to
your HP Officejet.
Note: You must use the keypad on the phone to dial the number. Do not use
the keypad on the front panel of the HP Officejet.
3
Do one of the following:
– If after dialing the number you hear fax tones, press Start Black or Start
Color within three seconds.
– If the recipient answers the telephone, instruct them to press Start on
their fax machine once they hear fax tones. Make sure you press Start
Black or Start Color on the HP Officejet before the recipient presses
Start on the receiving fax machine.
4
Wait for the fax tones, and then hang up the telephone.
to send a fax manually using the attached handset (handset model only)
Note: This procedure applies only to the HP Officejet 4250 Series product
with the attached handset. If you have an HP Officejet 4210 Series, refer to
the previous section for instructions.
1
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
2
Pick up the handset that is attached to the HP Officejet and dial the number
by using the keypad on the front panel.
3
Do one of the following:
– If after dialing the number you hear fax tones, press Start Black or Start
Color within three seconds.
– If the recipient answers the telephone, instruct them to press Start on
their fax machine once they hear fax tones. Make sure you press Start
Black or Start Color on the HP Officejet before the recipient presses
Start on the receiving fax machine.
4
Wait for the fax tones, and then hang up the telephone.
set the answer mode
By default, your HP Officejet automatically answers incoming calls and receives
faxes. You can change the Answer Mode to receive faxes manually or
automatically, based on the types of equipment and services (if any) share the
same phone line with your HP Officejet. This section explains the various ways
of answering fax calls.
It is strongly recommended that you set the Answer Mode from the front panel
and not the HP Director.
to change the answer mode from the front panel
fax
!
44
Press Answer Mode until the appropriate answer mode setting appears on
the display.
The selected Answer Mode setting appears on the display and becomes
the default setting.
hp officejet 4200 series
use the fax features
Refer to the following table to determine which Answer Mode setting you should
use. From the first column in the table, choose the type of equipment and services
applicable to your office setup. Then, look up the appropriate setting in the
second column. The third column describes how the HP Officejet will answer
incoming calls.
equipment/services sharing
your fax line
recommended
answer mode
setting
description
None.
Fax
The HP Officejet automatically answers all
incoming calls using the Rings to Answer
setting. See set the number of rings before
answering on page 47.
FaxTel
The HP Officejet automatically answers all
incoming calls using the Rings to Answer
setting. See set the number of rings before
answering on page 47.
If the call is a fax call, the HP Officejet will
receive the fax. If the call is a voice call, the
HP Officejet will create a special ring to
indicate it is a voice call. You will need to
answer the incoming voice call using the
attached handset.
(You have a separate fax line
on which you do not receive
voice calls.)
A shared voice and fax line
with the HP Officejet
4250 Series (handset model)
and no answering machine.
(This mode only
applies to the
HP Officejet
4250 Series.)
Note: If the HP Officejet determines
the call is a voice call, only the
HP Officejet will ring with the special
ring tone. The other phones on the
same phone line will not ring at all.
You will need to answer the incoming
voice call using the attached handset.
You should not answer voice calls
from other telephones on the line. The
device cannot tell that you picked up
the extension phone and will keep
ringing. You will have to press Cancel
on the HP Officejet to stop the ringing.
A shared voice and fax line,
with either the HP Officejet
4210 Series or the
HP Officejet 4250 Series.
Tel
The HP Officejet will not automatically
answer calls. You will need to receive faxes
manually by pressing Start Black or Start
Color. For information on receiving faxes
manually, see receive a fax on page 47.
You might use this setting if the majority of
calls on this phone line are voice calls and
you rarely receive faxes.
fax
user guide
45
chapter 5
equipment/services sharing
your fax line
recommended
answer mode
setting
description
Voice mail service provided by Tel
your telephone company.
The HP Officejet will not automatically
answer calls. You will need to receive faxes
manually by pressing Start Black or Start
Color. For information on receiving faxes
manually, see receive a fax on page 47.
An answering machine and a
shared voice and fax line.
The HP Officejet will not automatically
answer calls. Instead, the answering
machine will answer the call and the
HP Officejet will monitor the line. If fax
tones are detected, the HP Officejet will
receive the fax. Otherwise, the answering
machine will record the incoming message.
AnswerMachine
Note: This is the recommended
default setting if you have an
answering machine.
Fax
The HP Officejet automatically answers all
incoming calls.
Make sure the ring pattern the phone
company set for your fax line matches the
Answer Ring Pattern set for the HP Officejet.
For more information, see change the
answer ring pattern (distinctive ringing) on
page 63.
fax
Distinctive ringing service.
46
hp officejet 4200 series
use the fax features
receive a fax
By default, your HP Officejet automatically receives and prints incoming faxes.
Depending on your Answer Mode setting, the HP Officejet can receive faxes
automatically or manually. For more information on Answer Mode, see set the
answer mode on page 44.
Note: If you set the Answer Mode to Tel, you need to receive faxes manually
and respond in person to the incoming fax call. If Fax, FaxTel, or
AnswerMachine is set, you can receive faxes automatically or manually.
You can receive faxes manually from the following:
•
A phone directly connected to the HP Officejet (on the “2-EXT” port)
•
A phone that is on the same telephone line, but not directly connected to
the HP Officejet
•
The front panel
•
The attached handset (handset model only)
Refer to the following topics for information on receiving faxes.
This section contains the following topics:
•
set the number of rings before answering on page 47
•
receive a fax manually from a phone on page 48
•
receive a fax manually from the front panel on page 48
•
receive a fax manually using the attached handset (hp officejet 4250 series
only) on page 49
•
poll to receive a fax on page 49
set the number of rings before answering
You can specify how many rings should occur before your HP Officejet
automatically answers the phone. The default is 2 rings (varies by country/
region).
Note: This setting applies only if you set the Answer Mode to Fax or FaxTel.
1
Press Setup.
2
Press 3, then press 3.
This selects Basic Fax Setup and then Rings to Answer.
user guide
fax
Basic Fax Setup
1: Date and Time
2: Fax Header
3: Rings to Answer
4: Fax Paper Size
5: Tone or Pulse Dialing
6: Ring Volume
7: Phone Line Monitor Volume
8: Fax Forwarding Black Only
47
chapter 5
3
Enter the appropriate number of rings to answer by using the keypad.
4
Press OK to accept the setting.
receive a fax manually from a phone
You can receive faxes manually from a phone that is:
•
Directly connected to the HP Officejet (by using “2-EXT” port)
•
On the same phone line, but is not connected to the HP Officejet
Note: If you would like to receive a fax manually using the attached handset
(handset model only), see receive a fax manually using the attached
handset (hp officejet 4250 series only) on page 49.
1
Remove any originals from the automatic document feeder.
2
Set the Answer Mode to Tel so that the HP Officejet does not automatically
answer incoming calls. Or, set the Rings to Answer setting to a high
number to allow you to answer the incoming call before the HP Officejet.
For information on setting the Answer Mode, see set the answer mode on
page 44. For information on setting the number of Rings to Answer, see set
the number of rings before answering on page 47.
3
To receive a fax manually from a phone, do one of the following:
– If your phone is plugged into the back of the HP Officejet and you hear
fax tones from a sending fax machine, press Start Black or Start Color.
– If your phone is not plugged into the back of the HP Officejet (but is on
the same phone line) and you hear fax tones from a sending fax
machine, press 1 2 3 on your phone.
– If you are currently on the phone with the sender using a phone
connected to the HP Officejet, instruct them to press Start on their fax
machine. Once you hear fax tones from a sending fax machine, press
Start Black or Start Color.
4
Wait until you hear the HP Officejet send answering fax tones, then hang
up the telephone.
The HP Officejet receives the fax.
receive a fax manually from the front panel
You can receive faxes manually from the front panel.
Remove any originals from the automatic document feeder.
2
Set the Answer Mode to Tel so that the HP Officejet does not automatically
answer incoming calls. Or, set the Rings to Answer setting to a high
number to allow you to answer the incoming call before the HP Officejet.
For information on setting the Answer Mode, see set the answer mode on
page 44. For information on setting the number of Rings to Answer, see set
the number of rings before answering on page 47.
3
When your HP Officejet rings, press Start Black or Start Color.
The HP Officejet receives the fax.
fax
1
48
hp officejet 4200 series
use the fax features
receive a fax manually using the attached handset (hp officejet 4250 series only)
You can receive faxes manually by using the attached handset.
Note: This section applies only to the HP Officejet 4250 Series models with
attached handset. If you do not have an attached handset, see receive a fax
manually from a phone on page 48 or receive a fax manually from the
front panel on page 48.
1
Remove any originals from the automatic document feeder.
2
Set the Answer Mode to Tel so that the HP Officejet does not automatically
answer incoming calls. Or, set the Rings to Answer setting to a high
number to allow you to answer the incoming call before the HP Officejet.
For information on setting the Answer Mode, see set the answer mode on
page 44. For information on setting the number of Rings to Answer, see set
the number of rings before answering on page 47.
3
To receive a fax manually from a phone, do one of the following:
– If the HP Officejet rings, pick up the attached handset. If you hear fax
tones from a sending fax machine, press Start Black or Start Color, and
then press 2.
– If you are currently on the phone with the sender using the attached
handset, instruct them to press Start on their fax machine first. Once
you hear fax tones from a sending fax machine, press Start Black or
Start Color.
4
Wait until you hear the HP Officejet send answering fax tones, and then
hang up the telephone.
The HP Officejet receives the fax.
poll to receive a fax
Polling allows your HP Officejet to ask another fax machine to send a fax that it
has in its queue. When you use the Poll to Receive feature, the HP Officejet calls
the designated fax machine and requests the fax from it. The designated fax
machine must be set for polling and have a fax ready to send.
1
Press Fax.
Phone Number appears in the top line of the display.
2
Enter the fax number of the other fax machine.
3
Press Fax until How to Fax appears in the top line of the display.
4
Press ! until Poll to Receive appears in the top line of the display.
5
Press Start Black or Start Color.
fax
user guide
49
chapter 5
use the attached handset (hp officejet 4250 series only)
You can use the attached handset to answer incoming calls, make phone calls,
receive faxes, and send faxes. While the HP Officejet is processing another job,
such as copying, scanning, or printing, you can still use the handset for phone
calls.
Note: If the HP Officejet is sending or receiving fax data, you will not be
able to use the handset for phone calls. If you pick up the handset during
faxing, you will not hear a dial tone. Wait for the HP Officejet to finish
sending or receiving the fax before using the handset.
Use this section only if you have the HP Officejet 4250 Series (with the attached
handset).
This section contains the following topics:
•
answer incoming calls using the handset on page 50
•
make phone calls using the handset on page 50
•
receive faxes using the handset on page 51
•
send faxes using the handset on page 51
•
adjust the handset volume on page 51
answer incoming calls using the handset
!
Pick up the attached handset.
Note: If you are currently on the phone and receive another call, press Flash
to answer the call waiting. Call waiting is a subscription service and is not
available in all areas. Contact your phone company for information.
make phone calls using the handset
You can make phone calls using the attached handset. You can use Redial,
Speed Dial, or a one-touch speed dial button to quickly dial numbers.
1
Pick up the attached handset.
2
Do
–
–
–
fax
–
one of the following:
Dial the number by using the numeric keypad.
Press Redial to dial the last number dialed.
Press Speed Dial until the appropriate individual speed-dial entry
appears in the top line of the display (do not select a group speed-dial
entry) and press OK.
You can also scroll through the speed-dial entries by pressing " or !
or enter the speed-dial entry code from the front panel.
Press a one-touch speed dial button and press OK.
Press it once to access the first speed-dial entry and twice to access the
second speed-dial entry assigned to that button.
50
hp officejet 4200 series
use the fax features
receive faxes using the handset
!
For information on receiving faxes by using the attached handset, see
receive a fax manually using the attached handset (hp officejet 4250 series
only) on page 49.
send faxes using the handset
!
For information on sending faxes by using the attached handset, see to
send a fax manually using the attached handset (handset model only) on
page 44.
adjust the handset volume
Note: This feature has been disabled in those countries/regions where
telephone regulations prohibit handset volume adjustment.
You can adjust the handset volume from Normal to Loud.
1
Pick up the attached handset.
2
Press " to decrease the volume or ! to increase the volume.
Note: You can also adjust volume of the ring tones and dial tone. For more
information, see adjust the ring volume and adjust the phone line monitor
volume.
set the fax header
The fax header prints your name and fax number on the top of every fax you
send. We recommend that you use the Fax Setup Wizard during the HP Image
Zone software installation to set up the fax header; however, you can also set it
up from the front panel.
The fax header information is required by law in many countries/regions.
Note: In Hungary, the subscriber identification code (fax header) can be set
or changed only by authorized personnel. For more information, contact
your authorized HP dealer.
1
Press Setup.
2
Press 3, then press 2.
This selects Basic Fax Setup and then selects Fax Header.
3
Enter your personal or company name at the prompt. For information on
entering text from the front panel, see enter text on page 52.
4
Press OK.
5
Enter your fax number by using the numeric keypad.
6
Press OK.
user guide
51
fax
You might find it easier to enter fax header information by using the HP Director
that you installed with your HP Officejet. In addition to entering fax header
information, you can enter cover page information. This information will be
used when you send a fax from your computer and attach a cover page.
For more information, see the onscreen hp image zone help that came with
your software.
chapter 5
enter text
The following list provides tips for entering text by using the front panel keypad.
Use these instructions to enter speed dial names and the fax header name.
•
Press the keypad numbers that correspond to the letters of a name.
2
ABC
•
The letters A, B, and C correspond to the number 2,
and so on.
Press a button multiple times to see the available characters.
5
JKL
For example, to get this j
character:
k
l
J
K
L
5
Press 5 this many times: 1
2
3
4
5
6
7
Note: Depending on your language and country/region setting, additional
characters might be available.
•
After the correct letter appears, wait for the cursor to automatically
advance to the right, or press !. Press the number that corresponds to the
next letter in the name. Press the button multiple times until the correct letter
appears. The first letter of a word is automatically set to uppercase.
Tip: The cursor will automatically advance to the right after two
seconds.
•
To insert a space, press Space (#) or !.
•
To enter a symbol, such as *, press Symbols (*) repeatedly to scroll through
the list of symbols. The symbols are available to visually separate text for
easier reading. The list of available symbols for a name is:
@._-&/:;,?*()‘=+#!%“
•
If you make a mistake, press " to clear it, and then make the correct entry.
•
After you are done entering text, press OK to store your entries.
enter a phone number
The following list provides tips for entering phone numbers. Use these instructions
to enter speed dial phone numbers and the fax header number.
•
Press the keypad number and wait for the cursor to automatically advance
to the right, or press !.
Tip: The cursor will automatically advance to the right after two
seconds.
To enter a three-second pause, press Redial/Pause.
fax
•
52
hp officejet 4200 series
use the fax features
•
To enter a symbol, such as *, press Symbols (*) repeatedly to scroll through
the list of symbols. The following table represents the available symbols.
available description:
symbols:
*
Provides the Dual Tone Multiple-Frequency (DTMF) tones
assigned to the asterisk character.
–
When auto-dialing, the HP Officejet enters a three-second
pause in the number sequence.
()
Displays a left or right parenthesis to visually separate
numbers, such as area codes, for easier reading. These
symbols do not affect dialing.
W
When auto-dialing, W causes the HP Officejet to wait for a
dial tone before continuing to dial.
R
During auto-dialing, the R functions the same as the Flash
button.
+
Displays a plus symbol in the fax header. This symbol does
not affect dialing
•
If you make a mistake, press " to clear it, and then make the correct entry.
•
After you are done entering text, press OK to store your entries.
print reports
You can set up your HP Officejet to automatically print error reports and
confirmation reports for each fax you send and receive. You can also manually
print system reports as you need them; these reports provide useful system
information about your HP Officejet.
By default, your HP Officejet is set to print a report only if there is a problem with
sending or receiving a fax. A confirmation message that indicates whether a fax
was successfully sent appears briefly on the front panel display after each
transaction.
This section contains the following topics:
•
generate reports automatically on page 53
•
generate reports manually on page 54
generate reports automatically
This setting lets you configure your HP Officejet so that it automatically prints
error and confirmation reports.
Note: If you need printed confirmation each time your faxes are successfully
sent, follow these instructions before sending any faxes.
Press Setup.
2
Press 1, then press 1.
This selects Print Report and then selects Automatic Reports Setup.
fax
user guide
1
53
chapter 5
Print Report
1: Automatic Reports Setup
2: Last Transaction
3: Fax Log
4: Speed Dial List
5: Self-Test Report
6: Caller ID Report *
7: Junk Fax Report *
Automatic Reports Setup
Every Error
Send Error
Receive Error
Every Fax
Send Only
Off
* Not available in all countries/regions. This menu item does not appear in the
Print Report menu if any of the following apply:
•
•
3
Caller ID service is not supported in your country/region.
Your country/region Caller ID service is not supported by the HP Officejet.
Press ! to scroll through the following report types:
– Every Error: prints whenever there is any kind of fax error (default).
– Send Error: prints whenever there is a transmission error.
– Receive Error: prints whenever there is a receiving error.
– Every Fax: confirms every time a fax is sent or received.
– Send Only: prints every time a fax is sent.
– Off: does not print fax reports.
Note: If you select Send Only, you will also receive error reports if there is
any kind of error generated.
4
Press OK to select a report.
generate reports manually
You can manually generate reports about your HP Officejet, such as the status of
the last fax you sent, a list of programmed speed-dial entries, or a Self-Test Report
for diagnostic purposes.
1
Press Setup, then press 1.
This selects Print Report.
Print Report
1: Automatic Reports Setup
2: Last Transaction
3: Fax Log
4: Speed Dial List
5: Self-Test Report
6: Caller ID Report *
7: Junk Fax Report *
* Not available in all countries/regions. This menu item does not appear in the Print
Report menu if any of the following apply:
fax
•
•
54
Caller ID service is not supported in your country/region.
Your country/region Caller ID service is not supported by the HP Officejet.
hp officejet 4200 series
use the fax features
2
Press ! to scroll through the following report types:
– Automatic Reports Setup: prints automatic reports as described in
generate reports automatically on page 53.
– Last Transaction: prints details of the last fax transaction.
– Fax Log: prints a log of the last 30 fax transactions.
– Speed Dial List: prints a list of programmed speed-dial entries.
– Self-Test Report: prints a report to assist you in diagnosing print and
alignment problems. For more information, see print a self-test report
on page 80.
– Caller ID Report: prints a log of the last 30 Caller ID calls. The report
prints the phone number, the date and time, and the name of the caller
(if available).
Note: Caller ID service is not available in all countries/regions. If Caller ID
service is not supported in your country/region, this menu item will not
appear in the Print Report menu. Further, a Caller ID service is dependent
on country/region telephone system programming and may not be
compatible with the HP Officejet internal programming. For information, see
use caller ID on page 66.
–
3
Junk Fax Report: prints a report of the fax numbers you designated to
block. For more information, see block junk fax numbers on page 66.
Press OK to select a report.
set up speed dialing
You can assign speed-dial entries to frequently used fax numbers. Use the onetouch speed dial buttons on the front panel to quickly send faxes. You can also
press Speed Dial to scroll through and select from the list of speed-dial entries.
The first 10 speed-dial entries are automatically saved to the 5 one-touch speed
dial buttons on the front panel. When you create more than 5 speed-dial entries,
2 speed-dial entries will be assigned to a button. Press the one-touch speed dial
button repeatedly to toggle between the numbers. For example, press the first
one-touch button to toggle between speed-dial entries 1 and 6, press the second
one-touch button to toggle between speed dial entries 2 and 7, and so on,
through the fifth one-touch button. For information on using one-touch speed dial
buttons, see send a fax using speed dials on page 40.
We recommend that you use the HP Director to set up speed-dial settings;
however, you can also use the front panel.
You can quickly and easily set up speed-dial entries from your computer by
using the HP Director. For more information, see the onscreen
hp image zone help that came with your software.
This section contains the following topics:
create individual speed-dial entries on page 56
•
add group speed-dial entries on page 56
•
update speed-dial entries on page 57
•
delete speed-dial entries on page 57
fax
user guide
•
55
chapter 5
create individual speed-dial entries
You can create speed-dial entries for fax numbers that you use frequently.
1
Press Setup.
2
Press 2, then press 1.
This selects Speed Dial Setup and then selects Individual Speed Dial.
Speed Dial Setup
1: Individual Speed Dial
2: Group Speed Dial
3: Delete Speed Dial
The first unassigned speed-dial entry appears on the display.
3
Press OK to select the displayed speed-dial entry.
Tip: To select another empty entry, press " or !, and then press
OK.
4
Enter the fax number to assign to that entry, and then press OK.
The fax number can be up to 50 digits in length.
Tip: To enter a pause in the fax number, press Redial/Pause.
5
Enter the name, and then press OK.
The name is limited to 13 characters in length.
For more information on entering text, see enter text on page 52.
6
After Enter Another? appears, press 1 (Yes), if you want to set up another
number, or press 2 (No) to exit.
add group speed-dial entries
This feature allows you create groups of up to 62 individual speed-dial entries so
that you can send black-and-white faxes to specific groups of people with one
speed-dial button.
Note: You can only send black-and-white faxes to groups; color faxes and
Very Fine resolution are not supported for group faxing.
You can only assign previously entered speed-dial numbers to a group.
Additionally, only individual speed-dial entries can be added; you can’t assign
a group to another group.
1
Press Setup.
2
Press 2, then press 2.
This selects Speed Dial Setup and then selects Group Speed Dial.
fax
Speed Dial Setup
1: Individual Speed Dial
2: Group Speed Dial
3: Delete Speed Dial
56
hp officejet 4200 series
use the fax features
The first unassigned speed-dial entry appears on the display.
3
Press OK to select the displayed speed-dial entry.
Tip: To select another empty entry, press " or !, and then press
OK.
4
Press " or ! to select an individual speed-dial entry to add the to the
group. You can also enter the speed-dial code by using the front panel.
5
Press OK.
6
After Enter Another? appears, press 1 (Yes), to add another individual
speed-dial entry.
7
When you have added all your entries, press 2 (No).
8
Enter the group speed-dial name, and then press OK.
The name is limited to 42 characters in length.
For more information on entering text, see enter text on page 52.
9
After Another Group? appears, press 1 (Yes), if you want to set up another
group speed dial, or press 2 (No) to exit.
update speed-dial entries
You can change the phone number or name of an individual speed-dial entry.
Note: If the individual speed-dial entry is also a part of a speed-dial group,
the speed-dial group will reflect the any updates made to the individual
speed-dial entry.
1
Press Setup.
2
Press 2, then press 1.
This selects Speed Dial Setup and then selects Individual Speed Dial.
3
Press " or ! to scroll through the speed-dial entries, and then press OK to
select the appropriate entry.
4
When the current fax number appears, press " to erase it.
5
Reenter the fax number.
Tip: To enter a pause in the fax number, press Redial/Pause.
6
Press OK to save the new number.
7
If you need to change the name, press " to erase it, and then reenter the
name using the keypad.
8
Press OK.
9
Press 1 (Yes) to update another entry or 2 (No) to exit.
delete speed-dial entries
Follow these steps to delete an individual or group speed-dial entry.
Press Setup.
2
Press 2, then press 3.
This selects Speed Dial Setup and then selects Delete Speed Dial.
3
Press ! until the speed-dial entry that you want to delete appears, and
then press OK. You can also enter the speed-dial code by using the front
panel.
57
fax
user guide
1
chapter 5
Tip: You can also cancel fax forwarding by pressing Cancel and
then 2, when “Fax Forwarding” appears on the front panel
display.
change fax resolution and lighter/darker settings
You can change the fax resolution and lighter/darker settings of documents that
you are sending.
Note: These settings do not affect copy settings. Copy resolution and copy
contrast are set independently from fax resolution and fax contrast. Also, the
settings that you change from the front panel do not affect faxes sent from
your computer.
This section contains the following topics:
•
change the fax resolution on page 58
•
change lighter/darker setting on page 59
•
set new defaults on page 59
change the fax resolution
The Fax Resolution setting affects the transmission speed and quality of faxed
black-and-white documents. The HP Officejet only sends faxes at the highest
resolution supported by the receiving fax machine. You can only change the fax
resolution for faxes that you are sending in black and white. All color faxes will
be sent using Fine resolution. The following Fax Resolution settings are available:
•
Fine: this is the default setting. It provides high-quality text suitable for
faxing most documents.
•
Very Fine: use this setting when you are faxing documents with very fine
detail. If you choose this option, be aware that the faxing process takes
longer to complete and you can only send black-and-white faxes.
•
Photo: this setting provides the best quality fax when sending photographs.
If you choose Photo, be aware that the faxing process takes longer to
complete. When faxing photographs, we recommend that you choose
Photo.
•
Standard: this setting provides the fastest possible transmission with the
lowest quality of fax.
1
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
2
Press Fax Resolution until the desired resolution setting appears.
Note: The Fax Resolution setting you select is retained until you change it
again.
fax
Tip: You can also change the Fax Resolution by pressing Fax, then
using " or ! to scroll to Fax Resolution and then press OK. Use
" or ! to scroll to the setting you want and press OK again.
3
Enter the fax number by using the keypad, press a one-touch speed dial
button, or press Speed Dial until the appropriate speed-dial entry appears.
4
Press Start Black.
Note: If you press Start Color, the fax will be sent using the Fine setting.
58
hp officejet 4200 series
use the fax features
change lighter/darker setting
Use this setting to change the contrast of a fax to be darker or lighter than the
original. This feature is useful if you are faxing a document that is faded, washed
out, or hand written. You can darken the original by adjusting the contrast.
Your changes revert to the default values after two minutes of inactivity, unless
you set them as the default. For information, see set new defaults on page 59.
1
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
2
Press Fax.
Phone Number appears in the top line of the display.
3
Enter the fax number by using the keypad, press a one-touch speed dial
button, or press Speed Dial until the appropriate speed-dial entry appears.
4
Press Fax until Lighter/Darker appears in the top line of the display.
The range of values appears as a circle on a scale on the display.
5
Press " to lighten the fax or ! to darken it.
The circle moves left or right as you press a button.
6
Press Start Black or Start Color.
set new defaults
You can change the default values for the Lighter/Darker setting through the front
panel.
1
Load your original face down and top first in the document feeder tray.
For more information, see load originals on page 25.
2
Press Fax.
Phone Number appears in the top line of the display.
3
Enter the fax number by using the keypad, press a one-touch speed dial
button, or press Speed Dial until the appropriate speed-dial entry appears.
For more information on speed dials, see set up speed dialing on page 55.
4
Press Fax until Lighter/Darker appears in the top line of the display.
5
Make your changes, as needed.
6
Press Fax again until Set New Defaults appears in the top line of the
display.
7
Press ! to select Yes.
8
Press Start Black or Start Color.
The HP Officejet uses the new default setting to send your fax.
fax
user guide
59
chapter 5
set fax options
There are numerous fax options that you can set, such as controlling whether the
HP Officejet redials a busy number automatically. When you make changes to
the following options, the new setting becomes the default. Review this section
for information on changing fax options.
This section contains the following topics:
•
set the date and time on page 60
•
set the paper size for received faxes on page 61
•
set tone or pulse dialing on page 61
•
adjust the ring volume on page 61
•
adjust the phone line monitor volume on page 62
•
forward faxes to another number on page 62
•
edit or cancel fax forwarding on page 62
•
change the answer ring pattern (distinctive ringing) on page 63
•
redial a busy or unanswered number automatically on page 63
•
set automatic reduction for incoming faxes on page 64
•
use error correction mode on page 65
•
set the fax speed on page 65
•
use caller ID on page 66
•
block junk fax numbers on page 66
•
set backup fax reception on page 67
set the date and time
fax
You can set the date and time from the front panel. When a fax is transmitted,
the current date and time are printed along with the fax header. The date and
time format is based upon the language and country/region setting.
60
1
Press Setup.
2
Press 3, then press 1.
This selects Basic Fax Setup and then selects Date and Time.
3
Enter the month, day, and year (last two digits only) by pressing the
appropriate number on the keypad. Depending on your country/region
setting, you might enter the date in a different order.
The underline cursor presented initially beneath the first digit advances
automatically to each digit each time you press a button. The time prompt
automatically appears after you enter the last digit of the date.
4
Enter the hours and minutes.
The AM/PM prompt automatically appears after the last digit of the time is
entered if your time is displayed in the 12-hour format.
5
If prompted, press 1 for AM or 2 for PM.
The new date and time settings appear on the front panel display.
hp officejet 4200 series
use the fax features
set the paper size for received faxes
You can select the paper size for received faxes. The paper size selected should
match what is loaded in your paper tray. Faxes can be printed on letter, A4, or
legal paper only (varies by country/region).
Note: If an incorrect paper size is loaded in the paper tray when a fax is
received, the fax will not print and an error message appears on the display.
Load letter, A4, or legal paper, and then press OK to print the fax.
1
Press Setup.
2
Press 3, then press 4.
This selects Basic Fax Setup and then Fax Paper Size.
3
Press ! to select an option, and then press OK.
set tone or pulse dialing
You can set the dial mode for tone or pulse dialing. Most phone systems work
with either type of dialing. If you have a public phone system or a private branch
exchange (PBX) system that requires pulse dialing, you may need to select Pulse
Dialing. The default setting is Tone Dialing. Some phone system features might
not be accessible if pulse dialing is used. In addition, it can take longer to dial
a fax number with pulse dialing. Contact your local phone company if you are
unsure which setting to use.
Note: Pulse dialing is not available in all countries. If your phone system
does not require pulse dialing, we recommend using the default setting of
Tone Dialing.
1
Press Setup.
2
Press 3, then press 5.
This selects Basic Fax Setup and then Tone or Pulse Dialing.
3
Press ! to select between Tone or Pulse.
4
Press OK.
adjust the ring volume
The HP Officejet provides four levels for adjusting how loud it will ring when there
is an incoming fax or phone call. You can select Off, Low, Medium, or High. The
default setting is Medium.
1
Press Setup.
2
Press 3, then press 6.
This selects Basic Fax Setup and then selects the Ring Volume.
3
Press ! to select an option, and then press OK.
fax
user guide
61
chapter 5
adjust the phone line monitor volume
The Phone Line Monitor Volume setting allows you to control the volume of the
dial tones and fax tones. You can select Low, Medium, or High. The default
setting is Medium.
1
Press Setup.
2
Press 3, then press 7.
This selects Basic Fax Setup and then selects the Phone Line Monitor
Volume.
3
Press ! to select an option, and then press OK.
forward faxes to another number
Use the Fax Forwarding feature to forward your received faxes to another fax
number. During the period you have Fax Forwarding enabled, your HP Officejet
will not print received faxes. If a color fax is received, it will be forwarded in
black-and-white.
1
Press Setup.
2
Press 3, then press 8.
This selects Basic Fax Setup and then selects the Fax Forwarding Black
Only.
3
Press ! to select On, and then press OK.
4
At the prompt, enter the number of the fax machine that will receive the
forwarded faxes.
5
Press OK.
Fax Forwarding appears on the display.
edit or cancel fax forwarding
Once fax forwarding is enabled, you might need to change the number you are
forwarding to or you might want to cancel your fax forwarding setup altogether.
Follow the steps below to edit or turn off fax forwarding.
1
Press Setup.
2
Press 3, then press 8.
This selects Basic Fax Setup and then selects Fax Forwarding Black Only.
3
Press ! to select Off, and then press OK.
fax
Tip: You can also cancel fax forwarding by pressing Cancel and
then 2, when “Fax Forwarding” appears on the front panel
display.
62
hp officejet 4200 series
use the fax features
change the answer ring pattern (distinctive ringing)
Many phone companies offer a distinctive ringing feature that allows you to have
several phone numbers on one phone line. When you subscribe to this service,
each number will have a different ring pattern, for example, single, double, and
triple rings.
If you connect your HP Officejet to a line with distinctive ringing, have your
telephone company assign one ring pattern to voice calls and another to fax
calls. We recommend that you request double or triple rings for a fax number.
When the HP Officejet detects the specified ring pattern, it will answer the calls
and receive the fax.
If you do not have this service, use the default ring pattern, which is All Rings.
1
Verify that the correct Answer Mode setting is selected. For information, see
set the answer mode on page 44.
2
Press Setup.
3
Press 4, then press 1.
This selects Advanced Fax Setup and then selects Answer Ring Pattern.
4
Press ! to scroll through these options: All Rings, Single Rings, Double
Rings, Triple Rings, and Double & Triple.
5
When the ring pattern that the phone company established for your fax
number appears on the display, press OK.
Note: If you do not have distinctive ringing service, use the default ring
pattern, which is All Rings.
redial a busy or unanswered number automatically
You can set your HP Officejet to redial a busy or an unanswered number
automatically. The default setting for Busy Redial is Redial. The default setting for
No Answer Redial is No Redial.
1
Press Setup.
2
Do one of the following:
– To change the Busy Redial setting, press 4, and then press 2.
This selects Advanced Fax Setup, and then selects Busy Redial.
– To change the No Answer Redial setting, press 4, and then press 3.
This selects Advanced Fax Setup and then selects No Answer Redial.
fax
user guide
63
chapter 5
Advanced Fax Setup
1: Answer Ring Pattern
2: Busy Redial
3: No Answer Redial
4: Automatic Reduction
5: Error Correction Mode
6: Fax Speed
7: Caller ID Mode*
8: Junk Fax Numbers*
9: Backup Fax Reception**
Busy Redial
Redial
No Redial
No Answer Redial
No Redial
Redial
* Not available in all countries/regions. This menu item does not appear in the
Advanced Fax Setup menu if any of the following apply:
•
•
Caller ID service is not supported in your country/region.
Your country/region Caller ID service is not supported by the HP Officejet.
**If Caller ID service does not appear in the menu, Backup Fax Reception will be
number 7.
3
Press ! to select Redial or No Redial.
4
Press OK.
set automatic reduction for incoming faxes
This setting determines what your HP Officejet does if it receives a fax that is too
large for the default paper size. With this setting on (the default), the image is
reduced so that it fits on one page, if possible. With this feature off, information
that doesn’t fit on the first page is printed on a second page. Automatic
Reduction is useful when you receive a legal-size fax and letter-size paper is
loaded in the paper tray.
Press Setup.
2
Press 4, then press 4.
This selects Advanced Fax Setup and then selects Automatic Reduction.
3
Press ! to select On or Off.
4
Press OK.
fax
1
64
hp officejet 4200 series
use the fax features
use error correction mode
Error Correction Mode (ECM) eliminates data lost due to poor phone lines by
detecting errors that occur during transmission and automatically requesting
retransmission of the erroneous portion. Phone charges are unaffected, or might
even be reduced, on good phone lines. On poor phone lines, ECM increases
sending time and phone charges, but sends the data much more reliably. Turn
ECM off (the default setting is on) only if it increases phone charges substantially,
and you can accept poorer quality in exchange for reduced charges.
Note: If your Fax Speed setting is set to Fast or you are sending a color fax,
then ECM is always On.
1
Press Setup.
2
Press 4, then press 5.
This selects Advanced Fax Setup and then selects Error Correction Mode.
3
Press ! to select On or Off.
4
Press OK.
set the fax speed
You can set the fax speed used to communicate between your HP Officejet and
other fax machines when sending and receiving faxes. The default fax speed is
Fast.
In certain environments, setting the fax speed to a slower speed might be
required. For example, if you use one of the following:
•
an Internet phone service
•
a PBX system
•
Fax over Internet Protocol (FoIP)
•
an integrated services digital network (ISDN) service
Also, if you experience problems sending and receiving faxes, you might want
to try setting the Fax Speed to Medium or Slow. If you want to send with ECM
turned off, you must use Medium or Slow. The following fax speeds are available.
fax speed setting
fax speed
Fast
v.34 or 33600 bps
Medium
v.17 or 14400 bps
Slow
v.29 or 9600 bps
1
Press Setup.
2
Press 4, then press 6.
This selects Advanced Fax Setup and then Fax Speed.
3
Press ! to select an option, and then press OK.
fax
user guide
65
chapter 5
use caller ID
Caller ID Mode allows you to view the phone number or names of callers on the
front panel display, if you subscribe to Caller ID service through your phone
company.
If you subscribe to supported Caller ID service through the phone company, you
can block future faxes from designated numbers using the Junk Fax Numbers
feature.
Note: Caller ID service is available through your phone company. It is not
supported in all countries/regions and not all country/region Caller ID
services are compatible with the HP Officejet. If it is not supported in your
country/region or it is not compatible, you will not see Caller ID Mode in
the Advanced Fax Menu. For more information on Caller ID service, contact
your phone company.
In addition to viewing the numbers or names of callers, you can also block
numbers so that the HP Officejet will not receive faxes from those numbers. For
more information on blocking numbers, see block junk fax numbers on page 66.
1
Press Setup.
2
Press 4, then press 7.
This selects Advanced Fax Setup and then Caller ID Mode.
3
Press ! to select one of the following options:
– On: select this option to activate Caller ID Mode.
– On (Block Junk): select this option to activate Caller ID Mode and block
junk fax numbers.
– Off: select this option to turn off Caller ID Mode.
4
Press OK.
block junk fax numbers
If you subscribe to Caller ID service through the phone company, you can block
future faxes from designated numbers using the Junk Fax Numbers feature. You
can block faxes from up to 20 numbers.
Before using this feature, you must set the Caller ID Mode to On (Block Junk). For
information, see use caller ID on page 66.
Note: Caller ID service is available through your phone company. It is not
supported in all countries/regions and the feature may not be compatible
with the HP Officejet. If it is not supported in your country/region, you will
not see Junk Fax Numbers in the Advanced Fax Menu. For more information
on Caller ID service, contact your phone company.
fax
Note: You can also block faxes using the HP Director, however, you may
find that the front panel method is better. For more information, see the see
the onscreen hp image zone help Help that came with your software.
66
hp officejet 4200 series
use the fax features
to add junk fax numbers
1
Press Setup.
2
Press 4, then press 8.
This selects Advanced Fax Setup and then Junk Fax Numbers.
3
Press ! to select Add, and then press OK.
The most recently received Caller ID number appears on the display.
4
Press " or ! to scroll through the list of Caller ID numbers, and then press
OK to select a number to add to the list.
5
If you want to add another number to the list, press 1 (Yes). Otherwise,
press 2 (No).
6
If you pressed 1, repeat steps 4 and 5 until you have finished adding
Caller ID numbers to the list.
to delete junk fax numbers
1
Press Setup.
2
Press 4, then press 8.
This selects Advanced Fax Setup and then Junk Fax Numbers.
3
Press ! to select Delete, and then press OK.
The first Junk Number appears on the display.
4
Press " or ! to scroll through the list of numbers, and then press OK to
delete the selected number from the list.
5
If you want to delete another number from the list, press 1 (Yes). Otherwise,
press 2 (No).
6
If you pressed 1, repeat steps 4 and 5 until you have finished deleting
numbers from the list.
set backup fax reception
Use the Backup Fax Reception feature to store received faxes in memory. For
example, if your print cartridge runs out of ink while receiving a fax, the fax will
be stored in memory. Then, once you have replaced the print cartridge, you can
print out the fax. The front panel display notifies you when there are faxes in
stored in memory that need to be printed. The front panel display notifies you
when there are faxes stored in memory that need to be printed.
By default, Backup Fax Reception is enabled. For information on printing faxes
stored in memory, see reprint the faxes in memory on page 68.
Note: If the memory becomes full, the HP Officejet overwrites the oldest,
printed faxes. All unprinted faxes will remain in memory until they are
printed or deleted. When the memory becomes full of unprinted faxes, the
HP Officejet will not receive any more fax calls until the unprinted faxes are
printed. To delete all faxes in memory, including the unprinted faxes, unplug
your HP Officejet.
Press Setup.
Press 4, then press 7 or 9 (depends on your country/region).
This selects Advanced Fax Setup and then Backup Fax Reception.
fax
user guide
1
2
67
chapter 5
3
Press ! to select one of the following options:
– On: select this option to activate Backup Fax Reception.
– Off: select this option to turn off Backup Fax Reception.
4
Press OK.
set the country and language
Usually, you set the language and country/region when you first set up the
HP Officejet. However, you can change these settings at any time.
1
Press Setup.
2
Press 6, then press 3.
This selects Preferences and then selects Set Language & Country/Region.
Press 11 for English appears on the display. You can press ! to scroll
through the available language or wait for them to display automatically.
3
When you see the language you want, enter its two-digit number using the
keypad.
4
When prompted to confirm the language, press 1 for Yes or 2 for No.
You are prompted with all the countries/regions for the selected language.
You can also scroll through the countries/regions using " or !.
5
Using the keypad, enter the two-digit number for the desired country/
region.
6
When prompted, press 1 for Yes or 2 for No.
reprint the faxes in memory
Reprint Faxes in Memory enables you to reprint a fax stored in memory. The faxes
are printed in reverse order with the most recently received fax printed first. Any
time the HP Officejet begins printing a fax you do not need, press Cancel to stop
it from printing. The HP Officejet begins printing the next fax in memory.
Note: You will need to press Cancel for each stored fax in order to stop it
from printing.
1
Press Setup.
2
Press 5, then press 4.
This selects Tools and then selects Reprint Faxes in Memory.
The faxes are printed from memory.
stop faxing
•
To stop a fax you are sending or receiving, press Cancel.
•
To cancel a number your are currently dialing and bring up a dial tone,
press Flash.
fax
Note: If the HP Officejet is already connected to the other fax machine and
sending or receiving fax data, you must press Cancel to cancel the fax. Flash
will not cancel a fax that is already in progress.
68
hp officejet 4200 series
use the fax features
fax
user guide
69
fax
chapter 5
70
hp officejet 4200 series
print from your computer
print
6
Most print settings are automatically handled by the software application you are
printing from or by HP ColorSmart technology. You only need to change the
settings manually when you change print quality, print on specific types of paper
or film, or use special features.
This section contains the following topics:
•
print from a software application on page 71
•
set printing options on page 72
•
stop a print job on page 74
The HP Officejet can perform special print jobs such as printing borderless
images, posters, and printing on transparency film. For more information on
performing special print jobs, see the onscreen hp image zone help that came
with your software.
print from a software application
Follow these steps to print from the software application that you used to create
your document.
Windows users
1
Load the paper tray with the appropriate paper.
Form more information, see load paper and load originals on page 15.
2
From your software application’s File menu, select Print.
3
Make sure that you select the HP Officejet.
If you need to change settings, click the button that opens the Properties
dialog box (depending on your software application, this button might be
called Properties, Options, Printer Setup, or Printer), and then select the
appropriate options for your print job by using the features available in the
Paper/Quality, Finishing, Effects, Basics, and Color tabs.
Note: When printing a photo, you must select options for the correct paper
type and photo enhancement. See the hp image zone help that came with
your computer for more information.
4
Click OK to close the Properties dialog box.
The settings you select apply only to the current print job. To set print
settings for all jobs, see set printing options on page 72.
5
Click OK to begin your print job.
71
chapter 6
Macintosh users
print
To specify a document's paper size, scaling, and orientation, use the Page Setup
dialog box. To specify other print settings for a document, and to send the
document to the printer, use the Print dialog box.
Note: The following steps are specific to OS X. For OS 9, the steps might be
slightly different. Be sure to select the HP Officejet in the Print Center (OS X)
or in the Chooser (OS 9) before you begin printing.
1
From your software application’s File menu, select Page Setup.
The Page Setup dialog box appears.
2
In the Format for pull-down menu, select the HP Officejet.
3
Change other settings as needed:
– Select the paper size. (To set a custom paper size, select Custom Paper
Size from the Settings pull-down menu.)
– Select the orientation.
– Enter the scaling percentage.
For OS 9, the Page Setup dialog box includes options to rotate or mirror
the image, and to edit custom paper sizes.
4
Click OK.
5
From your software application’s File menu, select Print.
The Print dialog box appears.
If you are using OS X, the Copies & Pages panel opens. If you are using
OS 9, the General panel opens.
6
Select the print settings appropriate for your project.
Use the pull-down menus to access the other panels.
7
Click Print to begin printing.
set printing options
You can customize the print settings of the HP Officejet to handle nearly any print
task including customized, high-quality photos and documents.
Windows users
If you want to change print settings, you need to decide if you want to change
them for the current job, or for all jobs. How you display print settings depends
on whether or not you want to make the setting permanent.
to change the print settings for all future jobs
72
1
In the HP Director, click Settings, and then select Printer Settings.
2
Make changes to the print settings, and click OK.
hp officejet 4200 series
print from your computer
to change the print settings for the current print job
From your software application’s File menu, select Print, Print Setup, or
Page Setup. Make sure that the selected printer is the HP Officejet.
2
Click Properties, Options, Printer Setup, or Printer (the option names are
different depending on your software application).
3
Make changes to the settings, and click OK.
4
Click OK to print the job.
Macintosh users
!
To display the Page Setup dialog box, open the document you want to
print, then select Page Setup from the File menu.
Note: To find out more about the settings in a particular panel, click the ?
in the lower left corner of the Page Setup dialog box.
page attributes panel
Use the Page Attributes panel in the Page Setup dialog box to select the Page
Size, document Scaling, or Orientation. In OS 9, you can also choose to print a
Mirror Image or select Borderless printing. In OS X, you can select the
HP Officejet from this panel; in OS 9 use the Chooser to select the HP Officejet.
application attributes panel
Use the Application Attributes panel to set print options specific to the software
application being used.
summary panel
In OS X, use the Summary panel to view the print settings for the document. In
OS 9, this information appears on the General panel in the Print dialog box.
!
To display the Print dialog box, open the document you want to print, then
select Print from the File menu.
Note: To find out more about the settings in a particular panel, click the ?
in the lower left corner of the Print dialog box.
copies & pages panel
Use the Copies & Pages panel on OS X and General panel on OS 9 in the Print
dialog box to select the number of copies and the pages you want to print. You
can also choose to collate your prints from this panel.
!
Click the Preview button to see a preview of the printed document.
layout panel
Use the Layout panel in the Print dialog box to print multiple pages on a sheet
and to determine the order in which they will print. You can also choose border
options from this panel.
user guide
73
print
1
chapter 6
output options panel (OS X)
print
Use the Output Options panel in the Print dialog box to save your file as an
Adobe Acrobat PDF® (portable document format) file. The HP Officejet does not
support PostScript printing.
!
Select the Save as File check box to save your document as a PDF file.
Note: The Output Options panel is not available in OS 9.
paper type/quality panel
Use the Paper Type/Quality panel on OS X and General panel on OS 9 in the
Print dialog box to select the paper type, print quality, and on OS X, color
settings. You can also use this panel to change the contrast and sharpness of your
digital photos and to adjust the amount of ink you want to use in your prints.
The Color Options and Digital Photo tabs in OS X appear as separate pull-down
panels in OS 9. If you are using OS 9, use the Color and Digital Photography
pull-down panels to select your settings.
stop a print job
You can stop a print job from the HP Officejet or from your computer, although
we recommend the following method for best results.
!
74
To stop a print job from the HP Officejet, press Cancel on the front panel.
Look for the Print Cancelled message on the front panel display. If it doesn’t
appear, press Cancel again.
The HP Officejet prints any pages it has already started printing and then
cancels the remainder of the job. This can take a few moments.
hp officejet 4200 series
order supplies
7
You can order print cartridges, recommended types of HP paper, and
HP Officejet accessories online from the HP website.
This section contains the following topics:
order media on page 75
•
order print cartridges on page 75
•
order other supplies on page 75
order media
To order media such as HP Premium Paper, HP Premium Inkjet Transparency Film,
HP Iron-On Paper, or HP Greeting Cards, go to:
www.hp.com
Choose your country/region, and then select Buy or Shopping.
order print cartridges
The following table lists the print cartridges that are compatible with your
HP Officejet. Use this information to determine which print cartridge to order.
print cartridges
hp reorder number
HP black inkjet print cartridge
#56, 19 ml black print cartridge
HP tri-color inkjet print cartridge
#57, 17 ml color print cartridge
HP photo inkjet print cartridge
#58, 17 ml color print cartridge
HP black inkjet print cartridge
#27, 10 ml black print cartridge
HP tri-color inkjet print cartridge
#28, 8 ml color print cartridge
Get more information about print cartridges from the HP website:
www.hp.com
Choose your country/region, and then select Buy or Shopping.
order other supplies
To order other supplies such as HP Officejet software, a copy of the printed User
Guide, a Setup Poster, or other customer-replaceable parts, call the appropriate
number.
•
In the U.S. or Canada, dial 1-800-HP-INVENT (1-800-474-6836).
•
In Europe, dial +49 180 5 290220 (Germany) or +44 870 606 9081
(U.K.).
75
order supplies
•
chapter 7
To order HP Officejet software in other countries/regions, call the phone number
for your countries/regions. The numbers listed below are current as of the
publication date of this guide. For a list of current ordering numbers, go to the
following website and choose your own country/region or language:
order supplies
www.hp.com/support
76
country/region
number for ordering
Asia Pacific
65 272 5300
Australia
61 3 8877 8000
New Zealand
0800 441 147
South Africa
+27 (0)11 8061030
U.S. and Canada
1-800-HP-INVENT (1-800-474-6836)
hp officejet 4200 series
maintain your hp officejet
8
The HP Officejet requires little maintenance. Sometimes you might want to clean
the glass and white strip on back of the lid to remove surface dust and ensure
that your copies and scans remain clear. You might also want to replace, align,
or clean your print cartridges from time to time. This section provides instructions
for keeping your HP Officejet in top working condition. Perform these simple
maintenance procedures as necessary.
This section contains the following topics:
clean the glass on page 77
•
clean the white strip on page 78
•
clean the exterior on page 79
•
work with print cartridges on page 79
•
replace the telephone cord on page 89
•
restore factory defaults on page 90
•
set the scroll speed on page 90
•
set the prompt delay time on page 91
•
self-maintenance sounds on page 92
clean the glass
Dirty glass from dust, smudges, hair, and so on slows down performance and
affects the accuracy of features such as Photo Fit to Page, Copy, and Scan.
1
Turn off the HP Officejet, unplug the power cord, and raise the scanner lid.
Note: Print all faxes that are in memory before unplugging the power cord.
Faxes in memory will be lost when the power cord is unplugged. See reprint
the faxes in memory on page 68.
77
maintain your hp officejet
•
chapter 8
2
Clean the glass with a soft cloth or sponge slightly moistened with a
nonabrasive glass cleaner.
Caution! Do not use abrasives, acetone, benzene, or carbon
tetrachloride on the glass; these can damage it. Do not place or
spray liquids directly on the glass. They might seep under it and
damage the HP Officejet.
maintain your hp officejet
3
Dry the glass with a chamois or cellulose sponge to prevent spotting.
clean the white strip
Minor debris can accumulate on the white strip located underneath the scanner’s
lid.
1
Turn off the device, unplug the power cord, and raise the scanner lid.
Note: Print all faxes that are in memory before unplugging the power cord.
Faxes in memory will be lost when the power cord is unplugged. See reprint
the faxes in memory on page 68.
78
hp officejet 4200 series
maintain your hp officejet
2
Clean the white strip with a soft cloth or sponge slightly moistened with a
mild soap and warm water.
3
Wash the strip gently to loosen debris; do not scrub the strip.
4
Dry the strip with a chamois or soft cloth.
Caution! Do not use paper-based wipes as these might scratch the
strip.
5
If this does not clean the strip well enough, repeat the previous steps using
isopropyl (rubbing) alcohol, and wipe the strip thoroughly with a damp
cloth to remove any residual alcohol.
clean the exterior
Use a soft cloth or slightly moistened sponge to wipe dust, smudges, and stains
off the case. The interior of the device does not require cleaning. Keep fluids
away from the interior of the device as well as the front panel.
Note: To avoid damage to painted parts of the HP Officejet, do not use
alcohol or alcohol-based cleaning products on the front panel or the lid of
the device.
To ensure the best print quality from your HP Officejet, you will need to perform
some simple maintenance procedures and, when prompted by a front panel
message, replace the print cartridges.
This section contains the following topics:
•
check the ink levels on page 79
•
print a self-test report on page 80
•
handle the print cartridges on page 82
•
replace the print cartridges on page 82
•
use a photo print cartridge on page 85
•
use the print cartridge protector on page 85
•
align the print cartridges on page 86
•
clean the print cartridges on page 88
•
clean the print cartridge contacts on page 88
check the ink levels
You can easily check the ink supply level to determine how soon you might need
to replace a print cartridge. The ink level supply shows an approximation of the
amount of ink remaining in the print cartridges. Checking the ink levels can only
be done from the HP Director with the HP Officejet turned on and connected.
Windows users
user guide
1
From the HP Director, choose Settings, choose Print Settings, and then
choose Printer Toolbox.
2
Click the Estimated Ink Levels tab.
The estimated ink levels appear for the print cartridges.
79
maintain your hp officejet
work with print cartridges
chapter 8
Macintosh users
1
From the HP Director, choose Settings, and then choose Maintain Printer.
2
If the Select Printer dialog box opens, select your HP Officejet, and then
click Utilities.
3
From the list, select Ink Level.
The estimated ink levels appear for the print cartridges.
print a self-test report
If you are experiencing problems with printing, print a Self-Test Report before you
replace the print cartridges. This report provides useful information about your
print cartridges, including status information.
1
Load letter, A4, or legal-size paper.
2
Press Setup.
3
Press 1, then press 5.
This selects Print Report, and then selects Self-Test Report.
maintain your hp officejet
Print Report
1:Automatic Reports Setup
2:Last Transaction
3:Fax Log
4:Speed Dial List
5:Self-Test Report
6:Caller ID Report
7:Junk Fax Report
Black bar
Color bars
Black and tri-color cartridges installed
80
hp officejet 4200 series
maintain your hp officejet
Tri-color and photo cartridge installed
4
81
maintain your hp officejet
user guide
Check the Self-Test Report for streaking or white lines in the color bars.
Make sure that the color bars have even consistency and the lines of color
extend across the page.
– If the black and tri-color cartridges are installed, you will find four color
bars on the self-test report: black, cyan, magenta, and yellow.
– If the tri-color and photo cartridges are installed, you will find six color
bars on the self-test report: cyan, magenta, yellow for the tri-color
cartridge and light cyan, light magenta, and black for the photo
cartridge.
– If any color bars are missing, this might indicate that particular print
cartridge is out of ink. You might need to replace the print cartridge.
For more information on replacing print cartridges, see replace the
print cartridges on page 82.
– Streaks might indicate clogged nozzles or dirty contacts. You might
need to clean the print cartridges or the print cartridge contacts. For
more information on cleaning the print cartridges, see clean the print
cartridges on page 88 and clean the print cartridge contacts on
page 88. Do not clean with alcohol.
chapter 8
handle the print cartridges
Before you replace or clean a print cartridge, you should know the part names
and how to handle the print cartridge.
Gold-colored
contacts
Ink nozzles
under tape
Plastic tape with
pink pull tab
(must be removed)
maintain your hp officejet
Do not touch the gold-colored contacts or the ink nozzles
replace the print cartridges
A message appears on the front panel display to let you know when the ink level
for the print cartridge is low. In addition, you can check the ink levels through the
HP Director on your computer. For information, see check the ink levels on
page 79. When you receive this message, it is recommended that you have a
replacement print cartridge available. You should also replace the print
cartridges when you see faded text or if you experience print quality issues
related to the print cartridges.
You may also need these instructions to remove the black print cartridge when
you want to use the photo print cartridge for printing high-quality photos.
For information on ordering replacement print cartridges, see order print
cartridges on page 75.
1
Turn on the HP Officejet, and then lift open the print-carriage access door.
Print-carriage
access door
The print carriage moves into view.
82
hp officejet 4200 series
maintain your hp officejet
2
After the carriage stops moving, push down on the top of the print
cartridge to release it, and then pull it toward you out of its slot.
If you are removing the black print cartridge in order to install the photo
print cartridge, store it in the print cartridge protector. For more information
on the print cartridge protector, see use the print cartridge protector on
page 85.
4
Remove the new print cartridge from its packaging and, being careful to
touch only the black plastic, gently remove the tape by using the pink pull
tab.
Caution! Do not touch the gold-colored contacts or ink nozzles.
Once you have removed the plastic tape, install the print cartridge
immediately to prevent the ink from drying in the nozzles.
user guide
83
maintain your hp officejet
Note: It is normal to see ink buildup in the print cartridge slots.
3
chapter 8
5
Hold the black or photo print cartridge with the HP label on top. Slide the
print cartridge at a slight angle up into the right side of the print carriage.
Press firmly until the print cartridge snaps into place.
Caution! Do not attempt to push the cartridge straight into the slot.
It must slide in at a upward slight angle.
6
Hold the tri-color print cartridge with the HP label on top. Slide the print
cartridge at a slight angle into the left side of the print carriage.
Press firmly until the print cartridge snaps into place.
maintain your hp officejet
Caution! Do not attempt to push the cartridge straight into the slot.
It must slide in at a slight upward angle.
Note: You must install both print cartridges in order for your HP Officejet to
work.
84
7
Close the print-carriage access door.
“Press OK to print Align page” appears on the display.
8
Press OK.
For information on aligning the print cartridges, see align the print
cartridges on page 86.
hp officejet 4200 series
maintain your hp officejet
use a photo print cartridge
You can optimize the quality of the photos you print with your HP Officejet by
purchasing a photo print cartridge. Remove the black print cartridge and insert
the photo print cartridge in its place. With the tri-color print cartridge and the
photo print cartridge installed, you have a six-ink system, which provides
enhanced quality photos.
When you want to print regular text documents, swap the black print cartridge
back in. Use a print cartridge protector to keep your print cartridge secure and
prevent it from drying out when it is not being used. For more information on
using the print cartridge protector, see use the print cartridge protector on
page 85 and for more information replacing print cartridges, see replace the
print cartridges on page 82.
For more information on purchasing a photo print cartridge, see order print
cartridges on page 75.
use the print cartridge protector
When you purchase a photo print cartridge, you will receive a print cartridge
protector.
user guide
!
To insert a print cartridge into the print cartridge protector, slide the print
cartridge into the print cartridge protector at a slight angle and snap it
securely into place.
!
To remove the print cartridge form the print cartridge protector, press down
and back on the top of the print cartridge protector to release the print
cartridge, then slide the print cartridge out of the print cartridge protector.
85
maintain your hp officejet
The print cartridge protector is designed to keep your print cartridge secure when
it is not being used. It also prevents the ink from drying out. Whenever you
remove a print cartridge from the HP Officejet, store it in the print cartridge
protector.
chapter 8
align the print cartridges
The HP Officejet prompts you to align print cartridges every time you install or
replace a print cartridge. You can also align the print cartridges at any time from
the front panel or the HP Director. Aligning the print cartridges ensures highquality output.
Note: If you remove and reinstall the same print cartridge, the HP Officejet
will not prompt you to align the print cartridges.
to align the print cartridges from the front panel
1
To align the print cartridges when prompted, press OK.
The HP Officejet prints an alignment page.
2
Otherwise, you can align the print cartridges manually from the front
panel. Press Setup.
3
Press 5, then press 2.
This selects Tools and then selects Align Print Cartridge.
maintain your hp officejet
Tools Menu
1:Clean Print Cartridge
2:Align Print Cartridge
3:Restore Factory Defaults
4:Reprint Faxes in Memory
The HP Officejet prints an alignment page.
4
Load the alignment page face down in the document feeder tray and press
OK.
When “Alignment Complete” appears on the front panel display,
alignment is complete. Recycle or discard the alignment page.
86
hp officejet 4200 series
maintain your hp officejet
to align the print cartridges from the hp director
1
Access the HP Director.
For information on accessing the HP Director, see use the hp director
software to do more with your hp officejet on page 8.
2
For Windows users, do the following:
a. Choose Settings, choose Print Settings, and then choose Printer
Toolbox.
b. Click the Device Services tab.
c. Click Align the Print Cartridges.
The HP Officejet prints an alignment page.
3
For the Macintosh users, do the following.
a. Choose Settings, and then choose Maintain Printer.
b. If the Select Printer dialog box opens, select your HP Officejet, and
then click Utilities.
c. From the list, select Calibrate.
d. Click Align.
The HP Officejet prints an alignment page.
4
Load the alignment page face down and top first in the document feeder
tray and press OK.
maintain your hp officejet
When “Alignment Complete” appears on the front panel display,
alignment is complete. Recycle or discard the alignment page.
user guide
87
chapter 8
clean the print cartridges
Use this feature when the Self-Test Report shows streaking or white lines through
any of the colored bars. Do not clean print cartridges unnecessarily. This wastes
ink and shortens the life of the ink nozzles.
1
Press Setup.
2
Press 5, then press 1.
This selects Tools and then selects Clean Print Cartridge.
Tools Menu
1:Clean Print Cartridge
2:Align Print Cartridge
3:Restore Factory Defaults
4:Reprint Faxes in Memory
maintain your hp officejet
A test page is printed as the print cartridges are cleaned. Recycle or
discard the page.
If copy or print quality still seem poor after you clean the print cartridges,
try cleaning the print cartridge contacts before replacing the print cartridge
that is affected. For information on replacing print cartridges, see replace
the print cartridges on page 82.
clean the print cartridge contacts
Clean the print cartridge contacts only if you get repeated front panel messages
prompting you to check a print cartridge after you already have cleaned or
aligned the print cartridges.
Before cleaning remove the cartridge and verify that nothing is covering the print
cartridge contacts then reinstall the cartridge. If you continue to get messages to
check the cartridges, clean the contacts.
Caution! Do not remove both print cartridges at the same time.
Remove and clean each print cartridge one at a time.
Make sure you have the following materials available:
•
Dry foam rubber swabs, lint-free cloth, or any soft material that will not
come apart or leave fibers.
•
Distilled, filtered, or bottled water (tap water might contain contaminants
that can damage the print cartridges).
Caution! Do not use platen cleaners or alcohol to clean the print
cartridge contacts. These can damage the print cartridge or the
HP Officejet.
88
1
Turn the HP Officejet on and open the print-carriage access door.
2
After the carriage stops moving, unplug the power cord from the back of
the HP Officejet.
3
Push down on the top of the print cartridge to release it, and then pull it
toward you out of its slot.
4
Inspect the print cartridge contacts for ink and debris buildup.
hp officejet 4200 series
maintain your hp officejet
5
Dip a clean foam rubber swab or lint-free cloth into distilled water, and
squeeze any excess water from it.
6
Hold the print cartridge by its sides.
7
Clean only the contacts. Do not clean the nozzles.
Contacts
Nozzles - do not clean
8
Place the print cartridge back into the carriage.
9
Repeat if necessary for the other print cartridge.
10 Close the print-carriage access door and plug in the HP Officejet.
In some countries/regions you must use a special telephone cord to connect your
device to the telephone system.
Please check the Fax Setup chapter on page 131 to see if this applies to you.
user guide
89
maintain your hp officejet
replace the telephone cord
chapter 8
restore factory defaults
You can restore the original factory settings to what they were when you
purchased your HP Officejet.
Note: Restoring the factory defaults will not change the date information
you set, nor will it affect any changes you made to scan settings and the
language and country/region settings.
You can perform this process from the front panel only.
1
Press Setup.
2
Press 5, then press 3.
This selects Tools and then selects Restore Factory Defaults.
maintain your hp officejet
Tools Menu
1:Clean Print Cartridge
2:Align Print Cartridge
3:Restore Factory Defaults
4:Reprint Faxes in Memory
The factory default settings are restored.
set the scroll speed
The Scroll Speed option lets you control the rate that text messages scroll from
right to left in the front panel display. For example, if the message is long and
does not completely fit in the front panel display, it will need to scroll. This is so
that you can read the entire message. You can choose the rate at which it will
scroll: Normal, Fast, or Slow. The default is Normal.
1
Press Setup.
2
Press 6, then press 1.
This selects Preferences and then selects Set Scroll Speed.
Preferences Menu
1:Set Scroll Speed
2:Set Prompt Delay Time
3:Set Language & Country/Region
3
90
Press ! to select a scroll speed, then press OK.
hp officejet 4200 series
maintain your hp officejet
set the prompt delay time
The Prompt Delay Time option allows you to control the amount of time that
passes before a message is displayed prompting you to take further action. For
example, if you press Copy and the prompt delay time passes without pressing
another button, “Load Original, then press Start” appears in the front panel
display. You can choose Normal, Fast, or Slow. The default is Normal.
1
Press Setup.
2
Press 6, then press 2.
This selects Preferences and then selects Set Prompt Delay Time.
Preferences Menu
1:Set Scroll Speed
2:Set Prompt Delay Time
3:Set Language & Country/Region
3
Press ! until the delay time appears, then press OK.
Normally the language and country/region for your HP Officejet is set when you
first set up your device. However, you can change it at any time.
1
Press Setup.
2
Press 6, then press 3.
This selects Preferences and then selects Set Language & Country/Region.
Preferences Menu
1:Set Scroll Speed
2:Set Prompt Delay Time
3:Set Language & Country/Region
Press 11 for English appears on the display. You can press ! to scroll
through the available languages or wait for them to display automatically.
user guide
3
When you see the language you want, enter its two-digit number using the
keypad.
4
When prompted to confirm the language, press 1 for Yes or 2 for No.
You are prompted with all the countries/regions for the selected language.
You can also scroll through the countries/regions using " or !.
5
Using the keypad, enter the two-digit number for the desired country/
region.
6
When prompted, press 1 for Yes or 2 for No.
91
maintain your hp officejet
set the language and country/region
chapter 8
self-maintenance sounds
maintain your hp officejet
During the life of your product you might hear various mechanical sounds. This
is a normal part of your device’s self-maintenance.
92
hp officejet 4200 series
hp officejet 4200 series support
9
Hewlett-Packard provides Internet and phone support for your HP Officejet.
This section contains the following topics:
•
get support and other information from the Internet on page 93
•
hp customer support on page 93
•
prepare your hp officejet for shipment on page 96
If you are unable to find the answer you need in the printed or onscreen documentation
supplied with your product, you can contact one of the HP support services listed in the
following pages. Some support services are available only in the U.S. and Canada, while
others are available in many countries/regions worldwide. If a support service number is
not listed for your country/region, contact your nearest authorized HP dealer for help.
get support and other information from the Internet
If you have Internet access, you can get help from the following HP website:
www.hp.com/support
This website offers technical support, drivers, supplies, and ordering information.
hp customer support
Software programs from other companies might be included with your HP Officejet. If you
experience problems with any of those programs, you will receive the best technical
assistance by calling the experts at that company.
If you need to contact HP Customer Support, do the following before you call.
Make sure that:
a. Your HP Officejet is plugged in and turned on.
b. The specified print cartridges are installed correctly.
c. The recommended paper is properly loaded in the paper tray.
2
Reset your HP Officejet:
a. Turn off the HP Officejet by using the On button located on the front panel.
b. Unplug the power cord from the back of the HP Officejet.
c. Plug the power cord back into the HP Officejet.
d. Turn on the HP Officejet by using the On button.
3
For more information, go to the HP website at:
www.hp.com/support
hp officejet support
1
93
chapter 9
4
If you are still experiencing problems and need to speak with an HP Customer
Support Representative, do the following:
a. Have the specific name of your HP Officejet, as it appears on the front panel,
available.
b. Have your service ID and serial number ready.
To display your service ID and serial number on the front panel, press OK and
Start Color at the same time. Press ! until Model Number appears, and then
press OK. The service ID appears on the bottom line of the front panel display.
Make note of the service ID, and then press Cancel. You are returned to the Info
Menu. Press ! until Serial Number appears, and then press OK. The serial
number appears on the bottom line of the front panel display. Make note of the
serial number, and then press Cancel repeatedly to exit the Info Menu.
c. Print a Self-Test Report. For information on printing a Self-Test Report, see print a
self-test report on page 80.
d. Make a color copy to have available as a sample printout.
e. Be prepared to describe your problem in detail.
5
Call HP Customer Support. Be near your HP Officejet when you call.
call in North America during warranty
Call 1-800-HP-INVENT. US phone support is available in both English and Spanish
languages 24 hours a day, 7 days a week (days and hours of support may change without
notice). This service is free during the warranty period. A fee may apply outside the
warranty period.
call elsewhere in the world
The numbers listed below are current as of the publication date of this guide. For a list of
current international HP Support Service numbers, go to this website and choose your own
country/region or language:
www.hp.com/support
You can call the HP support center in the following countries/regions. If your country/
region is not listed, contact your local dealer or nearest HP Sales and Support Office to
find out how to obtain services.
Support service is free during the warranty period; however, your standard long-distance
phone charges will apply. In some cases, a flat fee per single incident will also apply.
hp officejet support
For phone support in Europe, please check for the details and conditions of phone support
in your country/region by going to the following website:
www.hp.com/support
Alternatively, you can ask your dealer or call HP at the phone number provided in this
guide.
As part of our constant efforts to improve our phone support service, we advise you to
check our website on a regular basis for new information regarding service features and
delivery.
country/region
hp technical support
country/region
hp technical support
Algeria1
+213(0)61 56 45 43
Luxembourg (French)
900 40 006
Argentina
(54)11-4778-8380
0-810-555-5520
Luxembourg (German)
900 40 007
Australia
+61 3 8877 8000
1902 910 910
Malaysia
1-800-805405
Austria
+43 (0) 820 87 4417
Mexico
01-800-472-6684
94
hp officejet 4200 series
hp officejet 4200 series support
country/region
hp technical support
country/region
hp technical support
Bahrain (Dubai)
+973 800 728
Mexico (Mexico City)
5258-9922
1
+212 224 047 47
+32 (0) 70 300 005
Morocco
Belgium (French)
+32 (0) 70 300 004
Netherlands (0.10 Euro/
min.)
0900 2020 165
Bolivia
800-100247
New Zealand
0800 441 147
Brazil (Demais
Localidades)
0800 157751
Norway
+47 815 62 070
Brazil (Grande São
Paulo)
(11) 3747 7799
Oman
+971 4 883 8454
Canada during
warranty
(905) 206 4663
Palestine
+971 4 883 8454
Canada post-warranty
(per-call charge)
1-877-621-4722
Panama
001-800-7112884
Caribbean & Central
America
1-800-711-2884
Peru
0-800-10111
Chile
800-360-999
Philippines
632-867-3551
China
86-21-38814518
8008206616
Poland
+48 22 865 98 00
Colombia
9-800-114-726
Portugal
+351 808 201 492
Costa Rica
0-800-011-0524
Puerto Rico
1-877-232-0589
Czech Republic
+42 (0) 2 6130 7310
Qatar
+971 4 883 8454
Denmark
+45 70202845
Romania
+40 1 315 44 42
Ecuador (Andinatel)
999119+1-8007112884
Russia, Moscow
+7 095 797 3520
Ecuador (Pacifitel)
1-800-225528+1-8007112884
Russia, St. Petersburg
+7 812 346 7997
Europe (English)
+44 (0) 207 512 5202
Saudi Arabia
+966 800 897 14440
Egypt
+20 02 532 5222
Singapore
(65) 272-5300
Finland
+358 (0) 203 66 767
Slovakia
+ 421 2 6820 8080
France (0.34 Euro/min.) +33 (0) 892 6960 22
South Africa (Outside
Republic)
+27-11 258 9301
Germany (0.12 Euro/
min.)
+49 (0) 180 5652 180
South Africa (RSA)
086 000 1030
Greece
+30 10 6073 603
Spain
+34 902 010 059
Guatemala
1 800-995-5105
Sweden
+46 (0)77 120 4765
2
Hong Kong
+85 (2) 3002 8555
Switzerland (0.08 CHF/ +41 (0) 848 672 672
min. during peak hours,
0.04 CHF/min. during offpeak hours)
Hungary
+36 (0) 1 382 1111
Taiwan
+886-2-2717-0055
0800 010 055
India
1-600-112267
91 11 682 6035
Thailand
+66 (2) 661 4000
user guide
95
hp officejet support
Belgium (Dutch)
chapter 9
country/region
hp technical support
country/region
1
hp technical support
+216 1 891 222
Indonesia
62-21-350-3408
Tunisia
Ireland
+353 1890 923902
Turkey
+90 216 579 7171
Israel
+972 (0) 9 830 4848
Ukraine
+7 (380-44) 490-3520
Italy
+39 848 800 871
United Arab Emirates
800 4910
Japan
0570 000 511
+81 3 3335 9800
United Kingdom
+44 (0) 870 010 4320
Jordan
+971 4 883 8454
Venezuela
01-800-4746-8368
Korea
+82 1588 3003
Venezuela (Caracas)
(502) 207-8488
Kuwait
+971 4 883 8454
Vietnam
84-8-823-4530
Lebanon
+971 4 883 8454
Yemen
+971 4 883 8454
1 This Call Center supports French-speaking customers from the following countries/regions:
Morocco, Tunisia, and Algeria.
2 This Call Center supports German-, French- and Italian-speaking customers in Switzerland.
call in Australia post-warranty
If your product is not under warranty, you can call 03 8877 8000. A per-incident, out-ofwarranty support fee of $27.50 (inc GST) will be charged to your credit card. You can also
call 1902 910 910 ($27.50 charged to your phone account) from 9:00 A.M. to
5:00 P.M. Monday through Friday. (Charges and support hours are subject to change
without notice.)
prepare your hp officejet for shipment
If after contacting HP Customer Support or returning to the point of purchase, you are
requested to send your HP Officejet in for service, please follow the steps below to avoid
further damage to the HP product.
hp officejet support
Note: When transporting your HP Officejet, make sure that the print cartridges have
been removed. Make sure that you have properly shut down the HP Officejet by
pressing the On button.
1
Turn on the HP Officejet.
Disregard steps 1 through 6 if your device will not turn on and the print carriage is
not visible under the print carriage access door. You will not be able to remove the
print cartridges. Proceed to step 7.
2
Open the print carriage access door.
3
Remove the print cartridges.
For information on removing the print cartridges, see replace the print cartridges.
Caution! Remove both print cartridges. Failure to do so might damage
your HP Officejet.
96
4
Place the print cartridges in an airtight bag so they will not dry out, and put them
aside. Do not send them with the HP Officejet, unless instructed to by the
HP customer support call agent.
5
Close the print-carriage access door. Turn off the HP Officejet.
6
Remove the front panel cover as follows:
a. Grasp the front of the front panel cover with two hands, as shown.
b. Firmly lift the front panel cover to unsnap it from the HP Officejet.
hp officejet 4200 series
hp officejet 4200 series support
Retain the front panel cover. Do not return the front panel cover with the HP Officejet.
Fold the document catcher up, over the front panel area, and then fold the automatic
document feeder tray down, over the document catcher.
9
Make sure the paper tray extender is in its closed position, and then fold the paper
tray door up until it snaps into place.
This places the HP Officejet in its fully closed position, as shown below.
10
If available, pack the HP Officejet for shipment by using the original packing
materials or the packaging materials that came with your exchange device.
hp officejet support
7
8
user guide
97
chapter 9
If you do not have the original packaging materials, please use other adequate
packaging materials. Shipping damage caused by improper packaging and/or
improper transportation is not covered under the warranty.
Place the return shipping label on the outside of the box.
12
Include the following items in the box:
– A complete description of symptoms for service personnel (samples of print
quality problems are helpful).
– A copy of the sales slip or other proof of purchase to establish the warranty
coverage period.
– Your name, address, and a phone number where you can be reached during
the day.
hp officejet support
11
98
hp officejet 4200 series
warranty information
10
Your HP Officejet comes with a limited warranty that is described in this section.
Information about how to obtain warranty service and how you can upgrade your standard
factory warranty is also provided.
This section contains the following topics:
•
duration of limited warranty on page 99
•
warranty service on page 99
•
warranty upgrades on page 99
•
returning your hp officejet for service on page 100
•
hewlett-packard limited global warranty statement on page 100
duration of limited warranty
Duration of Limited Warranty (hardware and labor): 1 Year
Duration of Limited Warranty (CD media): 90 Days
Duration of Limited Warranty (print cartridges): Until the HP ink is depleted or the “end of
warranty” date printed on the cartridge has been reached, whichever occurs first.
warranty service
express service
To obtain HP express repair service, the customer must contact an HP service office or an
HP Customer Support Center for basic troubleshooting first. See hp customer support on
page 93 for steps to take before calling Customer Support.
Note: HP express repair service might not be available in certain countries/regions.
If a customer device needs a minor part replacement and these parts can normally be
replaced by the customer, the customer-replaceable components may be serviced through
expedited part shipment. In this event, HP will prepay shipping charges, duty and taxes;
provide telephone assistance on replacement of the component; and pay shipping
charges, duty, and taxes for any part that HP asks to be returned.
The HP Customer Support Center may direct customers to designated authorized service
providers who are certified by HP to service the HP product.
warranty upgrades
For more information, please call 1-888-999-4747 or go to the HP website:
www.hp.com/go/hpsupportpack
99
warranty information
Upgrade your standard factory warranty to a total of three years with the
HP SUPPORTPACK. Service coverage begins on product purchase date and the pack must
be purchased within the first 180 days of product purchase. This program offers phone
support from 6:00 A.M. to 10:00 P.M. Mountain Standard Time (MST) Monday through
Friday and 9:00 A.M. to 4:00 P.M. (MST) on Saturdays. If during your technical support
call it is determined that you need a replacement product, then HP will ship you this product
next business day free of charge. Available in U.S. only.
chapter 10
Outside the U.S., please call your local HP Customer Support office. See call elsewhere in
the world on page 94 for a list of international Customer Support numbers.
returning your hp officejet for service
Before returning your HP Officejet for service, you must call HP Customer Support. See
hp customer support on page 93 for steps to take before calling Customer Support.
hewlett-packard limited global warranty statement
The following information specifies the HP limited global warranty.
This section contains the following topics:
•
extent of limited warranty on page 100
•
limitations of warranty on page 101
•
limitations of liability on page 101
•
local law on page 101
extent of limited warranty
Hewlett-Packard (“HP”) warrants to the end-user customer (“Customer”) that each
HP Officejet 4200 Series product (“Product”), including related software, accessories,
media, and supplies, shall be free from defects in material and workmanship for the
duration (specified below), which begins on the date of purchase by the Customer.
For each software Product, HP’s limited warranty applies only to a failure to execute
programming instructions. HP does not warrant that the operation of any Product shall be
uninterrupted or error free.
HP’s limited warranty covers only those defects which arise as a result of normal use of a
Product, and does not cover any other problems, including those which arise as a result of
(a) improper maintenance or modification, (b) software, accessories, media, or supplies
not provided or supported by HP, or (c) operation outside the Product’s specifications, or
unauthorized modifications or misuse.
For any hardware Product, the use of a non-HP print cartridge or a refilled print cartridge
does not affect either the warranty to the Customer or any HP support contract with the
Customer. However, if Product failure or damage is attributable to the use of a non-HP or
refilled print cartridge, HP shall charge its standard labor and materials charges to service
the Product for the failure or damage.
If HP receives, during the applicable warranty period, notice of a defect in any Product,
HP shall either repair or replace the defective Product, that is covered by HP’s warranty, at
HP’s option. Where labor charges are not covered by HP’s limited warranty, repairs shall
be at HP’s standard charges for labor.
If HP is unable to repair or replace, as applicable, a defective Product which is covered by
HP’s warranty, HP shall, within a reasonable time after being notified of the defect, refund
the purchase price for the Product.
HP shall have no obligation to repair, replace, or refund until the Customer returns the
defective Product to HP.
warranty information
Any replacement product may be either new or like-new, provided that it has functionality
at least equal to that of the Product being replaced.
HP products, including each Product, may contain remanufactured parts, components, or
materials equivalent to new in performance.
HP’s limited warranty for each Product is valid in any country/region or locality where the
covered HP product is distributed by HP. Contracts for additional warranty service, such as
on-site service, are available from any authorized HP service facility in countries/regions
where the product is distributed by HP or by an authorized representative.
100
hp officejet 4200 series
warranty information
limitations of warranty
TO THE EXTENT ALLOWED BY LOCAL LAW, NEITHER HP NOR ITS THIRD PARTY
SUPPLIERS MAKE ANY OTHER WARRANTY OR CONDITION OF ANY KIND, WHETHER
EXPRESS OR IMPLIED, WARRANTIES OR CONDITIONS OF MERCHANTABILITY,
SATISFACTORY QUALITY, AND FITNESS FOR A PARTICULAR PURPOSE.
limitations of liability
To the extent allowed by local law, the remedies provided in this Limited Warranty
Statement are the Customer’s sole and exclusive remedies.
TO THE EXTENT ALLOWED BY LOCAL LAW, EXCEPT FOR THE OBLIGATIONS
SPECIFICALLY SET FORTH IN THIS LIMITED WARRANTY STATEMENT, IN NO EVENT
SHALL HP OR ITS THIRD PARTY SUPPLIERS BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER BASED ON CONTRACT,
TORT, OR ANY OTHER LEGAL THEORY AND WHETHER ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES.
local law
This Limited Warranty Statement gives the Customer specific legal rights. The Customer may
also have other rights which vary from state to state in the United States, from province to
province in Canada, and from country/region to country/region elsewhere in the world.
To the extent this Limited Warranty Statement is inconsistent with local law, this Statement
shall be deemed modified to be consistent with such local law. Under such local law,
certain disclaimers and limitations of this Statement may not apply to the Customer. For
example, some states in the United States, as well as some governments outside the United
States (including provinces in Canada), may:
Preclude the disclaimers and limitations in this Statement from limiting the statutory rights
of a consumer (for example, the United Kingdom);
Otherwise restrict the ability of a manufacturer to enforce such disclaimers or limitations; or
Grant the Customer additional warranty rights, specify the duration of implied warranties
which the manufacturer cannot disclaim, or not allow limitations on the duration of implied
warranties.
FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW ZEALAND, THE TERMS
IN THIS LIMITED WARRANTY STATEMENT, EXCEPT TO THE EXTENT LAWFULLY
PERMITTED, DO NOT EXCLUDE, RESTRICT, OR MODIFY, AND ARE IN ADDITION TO,
THE MANDATORY STATUTORY RIGHTS APPLICABLE TO THE SALE OF THE COVERED
HP PRODUCTS TO SUCH CUSTOMERS.
warranty information
user guide
101
warranty information
chapter 10
102
hp officejet 4200 series
11
The technical specifications and international regulatory information for your HP Officejet
are provided in this section.
This section contains the following topics:
•
paper specifications on page 103
•
fax specifications on page 105
•
scan specifications on page 105
•
physical specifications on page 106
•
power specifications on page 106
•
environmental specifications on page 106
•
environmental product stewardship program on page 106
•
regulatory notices on page 109
paper specifications
This section contains the following topics:
•
paper-tray capacities on page 103
•
automatic document feeder paper capacity on page 104
•
paper sizes on page 104
•
print margin specifications on page 105
paper-tray capacities
type
paper weight
input tray1
output tray2
Plain paper
20 to 24 lb.
(70 to 90 gsm)
100
20
Cards
110 lb.
(200 gsm)
20
10
Envelopes
20 to 24 lb.
(75 to 90 gsm)
10
5
Transparency film
N/A
30
10
Labels
N/A
20
10
4 by 6 inch (10 by 15
cm) Photo Paper
145 lb.
(236 gsm)
20
10
1 Maximum capacity.
2 Output tray capacity is affected by the type of paper and the amount of ink
you are using. HP recommends emptying the output tray frequently.
103
technical information
technical information
chapter 11
technical information
automatic document feeder paper capacity
type1
paper weight
quantity
Letter
20 lb.
(70 gsm)
20
Legal
20 lb.
(70 gsm)
20
A4
20 lb.
(70 gsm)
20
1 Automatic document feeder accepts plain paper only. It does not
accept transparency film, envelopes, or labels.
paper sizes
104
type
size
Paper
Letter: 8.5 by 11 inches (216 by 279 mm)
Legal: 8.5 by 14 inches (216 by 356 mm)
A4: 210 by 297 mm
Envelopes
U.S. #10: 4.125 by 9.5 inches (105 by 241 mm)
A2: 111 by 146 mm (4.4 by 5.8 inches)
DL: 110 by 220 mm (4.3 by 8.7 inches)
C6: 114 by 162 mm (4.5 by 6.4 inches)
Transparency film
Letter: 8.5 by 11 inches (216 by 279 mm)
A4: 210 by 297 mm
Photo paper
4 by 6 inches (10 by 15 cm)
Labels
Letter: 8.5 by 11 inches (216 by 279 mm)
A4: 210 by 297 mm
hp officejet 4200 series
technical information
top
(leading edge)
bottom
(trailing edge)1
left
right
technical information
print margin specifications
paper or transparency film
U.S. (Letter, Legal,
Executive)
0.07 inches
(1.8 mm)
0.46 inches
(11.7 mm)
0.25 inches (6.4
mm)
0.25 inches
(6.4 mm)
ISO (A4, A5) and
JIS (B5)
0.07 inches
(1.8 mm)
0.46 inches
(11.7 mm)
0.13 inches
(3.2 mm)
0.13 inches
(3.2 mm)
0.13 inches
(3.2 mm)
0.46 inches
(11.7 mm)
0.13 inches
(3.2 mm)
0.13 inches
(3.2 mm)
0.07 inches
(1.8 mm)
0.46 inches
(11.7 mm)
0.13 inches
(3.2 mm)
0.13 inches
(3.2 mm)
envelopes
cards
1 This margin is not Officejet compatible; however, the total writing area is compatible. The writing
area is offset from center by 0.21 inches (5.4 mm), which causes asymmetric top and bottom
margins.
fax specifications
•
Walk-up black and white and color fax capability
•
Confirmation and activity reports
•
CCITT/ITU Group 3 fax with Error Correction Mode
•
33.6 Kbps transmission
•
3 seconds per page speed at 33.6 Kbps (based on ITU-T Test Image #1 at standard
resolution.) More complicated pages or higher resolution take longer and use more
memory
•
Ring detect with automatic fax/answering machine switching
scan specifications
user guide
•
Image editor included
•
Integrated OCR software automatically converts scanned text to editable text
•
Contact image sensor (CIS)
•
Twain-compliant interface
•
Scan speeds vary according to the complexity of the document
•
Resolution: 600 by 2400 ppi maximum (19200 ppi)
•
Bit depth: 36 bits color; 12 bits grayscale
•
Maximum scan size from automatic document feeder: 8.5 by 14 inches (216 by
356 mm)
105
technical information
chapter 11
physical specifications
height
width
depth
weight (without print
cartridges)
16.4 inches (41.6 cm)
8 inches (20.4 cm)
12 lbs (5.5 kg)
16.4 inches (41.6 cm)
16.7 inches (45 cm)
12 lbs (5.5 kg)
with paper trays closed
7.1 inches (18 cm)
with paper trays opened
13 inches (33 cm)
power specifications
•
Power consumption: 50 W maximum
•
Input voltage: AC 100 to 240 V, 0.7 A (maximum), 50–60 Hz
environmental specifications
•
Recommended operating temperature range: 15º to 32º C (59º to 90º F)
•
Allowable operating temperature range: 5º to 40º C (41º to 104º F)
•
Humidity: 15% to 85% RH non-condensing
•
Non-operating (Storage) temperature range: –40º to 60º C (–40º to 140º F)
•
In the presence of high electromagnetic fields it is possible the output from the
HP Officejet may be slightly distorted
•
HP recommends using a USB cable less than or equal to 3m (10 feet) in length to
minimize injected noise due to potential high electromagnetic fields
environmental product stewardship program
This section contains the following topics:
•
protecting the environment on page 106
•
ozone production on page 106
•
energy consumption on page 107
•
paper use on page 107
•
plastics on page 107
•
material safety data sheets on page 107
•
recycling program on page 108
•
hp inkjet supplies recycling program on page 108
protecting the environment
Hewlett-Packard Company is committed to providing quality products in an environmentally
sound manner. This product has been designed with several attributes to minimize impacts
on our environment.
For more information, visit HP’s Commitment to the Environment website at:
www.hp.com/hpinfo/globalcitizenship/environment/index.html
ozone production
This product generates no appreciable ozone gas (O3).
106
hp officejet 4200 series
technical information
Energy usage drops significantly while in ENERGY STAR® mode, which saves natural
resources, and saves money without affecting the high performance of this product. This
product qualifies for ENERGY STAR, which is a voluntary program established to
encourage the development of energy-efficient office products.
ENERGY STAR is a U.S. registered service mark of the U.S. EPA. As an ENERGY STAR
partner, HP has determined that this product meets ENERGY STAR guidelines for energy
efficiency.
For more information on ENERGY STAR guidelines, go to the following website:
www.energystar.gov
paper use
This product is suited for the use of recycled paper according to DIN 19309.
plastics
Plastic parts over 25 grams are marked according to international standards that enhance
the ability to identify plastics for recycling purposes at the end of the product’s life.
material safety data sheets
Material safety data sheets (MSDS) can be obtained from the HP website at:
www.hp.com/go/msds
Customers without Internet access should contact their local HP Customer Care Center.
user guide
107
technical information
energy consumption
chapter 11
technical information
recycling program
HP offers an increasing number of product return and recycling programs in many
countries, as well as partnering with some of the largest electronic recycling centers
throughout the world. HP also conserves resources by refurbishing and reselling some of
its most popular products.
This HP product contains the following materials that may require special handling at endof-life:
•
Mercury in the fluorescent lamp in the scanner (<2 mg)
•
Lead in the solder
•
A lithium battery
This product contains a small Lithium battery that must be removed an disposed of
properly at the end of the product’s useful life. The battery is located on the Main
board.
– Battery part number: Panasonic CR2032
– Battery material: Lithium
– Battery type: button/coin cell battery
– Quantity per product: 1
– Weight: approx. 3 grams
– Lithium type: solid
– Battery manufacturers: Panasonic, Japan
hp inkjet supplies recycling program
HP is committed to protecting the environment. The HP Inkjet Supplies Recycling Program
is available in many countries/regions, and lets you recycle used print cartridges free of
charge. For more information, go to the following website:
www.hp.com/hpinfo/globalcitizenship/environment/recycle/inkjet.html
108
hp officejet 4200 series
technical information
The HP Officejet meets product requirements from regulatory agencies in your country/
region.
This section contains the following topics:
•
regulatory model identification number on page 109
•
notice to users of the U.S. telephone network: FCC requirements on page 109
•
FCC statement on page 110
•
note à l’attention des utilisateurs du réseau téléphonique Canadien/notice to users
of the Canadian telephone network on page 110
•
note à l’attention des utilisateurs Canadien/notice to users in Canada on page 111
•
notice to users in the European Economic Area on page 112
•
notice to users of the German telephone network on page 112
•
declaration of conformity (European Union) on page 112
•
geräuschemission on page 112
•
notice to users in Korea (Officejet 4255 only) on page 113
regulatory model identification number
For regulatory identification purposes, your product is assigned a Regulatory Model
Number. The Regulatory Model Number for your product is either SDG0B-0306-01 or
SDG0B-0306-02. This regulatory number should not be confused with the marketing name
(HP Officejet 4200 Series) or product number (Q5600A, Q5610A).
notice to users of the U.S. telephone network: FCC requirements
This equipment complies with FCC rules, Part 68. On this equipment is a label that
contains, among other information, the FCC Registration Number and Ringer Equivalent
Number (REN) for this equipment. If requested, provide this information to your telephone
company.
An FCC compliant telephone cord and modular plug is provided with this equipment. This
equipment is designed to be connected to the telephone network or premises wiring using
a compatible modular jack which is Part 68 compliant. This equipment connects to the
telephone network through the following standard network interface jack: USOC RJ-11C.
The REN is useful to determine the quantity of devices you may connect to your telephone
line and still have all of those devices ring when your number is called. Too many devices
on one line may result in failure to ring in response to an incoming call. In most, but not
all, areas the sum of the RENs of all devices should not exceed five (5). To be certain of
the number of devices you may connect to your line, as determined by the REN, you should
call your local telephone company to determine the maximum REN for your calling area.
If this equipment causes harm to the telephone network, your telephone company may
discontinue your service temporarily. If possible, they will notify you in advance. If advance
notice is not practical, you will be notified as soon as possible. You will also be advised of
your right to file a complaint with the FCC. Your telephone company may make changes
in its facilities, equipment, operations, or procedures that could affect the proper operation
of your equipment. If they do, you will be given advance notice so you will have the
opportunity to maintain uninterrupted service.
If you experience trouble with this equipment, please contact the manufacturer, or look
elsewhere in this manual, for warranty or repair information. Your telephone company may
ask you to disconnect this equipment from the network until the problem has been corrected
or until you are sure that the equipment is not malfunctioning.
This equipment may not be used on coin service provided by the telephone company.
Connection to party lines is subject to state tariffs. Contact your state’s public utility
commission, public service commission, or corporation commission for more information.
user guide
109
technical information
regulatory notices
chapter 11
technical information
This equipment includes automatic dialing capability. When programming and/or making
test calls to emergency numbers:
•
Remain on the line and explain to the dispatcher the reason for the call.
•
Perform such activities in the off-peak hours, such as early morning or late evening.
Note: This equipment is hearing aid compatible.
The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use
a computer or other electronic device, including fax machines, to send any message unless
such message clearly contains in a margin at the top or bottom of each transmitted page
or on the first page of transmission, the date and time it is sent and an identification of the
business, other entity, or other individual sending the message and the telephone number
of the sending machine or such business, other entity, or individual. (The telephone number
provided may not be a 900 number or any other number for which charges exceed local
or long-distance transmission charges.) In order to program this information into your fax
machine, you should complete the steps described in the software.
FCC statement
The United States Federal Communications Commission (in 47 CFR 15.105) has specified
that the following notice be brought to the attention of users of this product.
Declaration of Conformity: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may
cause undesired operation. Class B limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy, and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient the receiving antenna.
•
Increase the separation between the equipment and the receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
For more information, contact the Product Regulations Manager, Hewlett-Packard
Company, San Diego, (858) 655-4100.
The user may find the following booklet prepared by the Federal Communications
Commission helpful: How to Identify and Resolve Radio-TV Interference Problems. This
booklet is available from the U.S. Government Printing Office, Washington DC, 20402.
Stock No. 004-000-00345-4.
Caution! Pursuant to Part 15.21 of the FCC Rules, any changes or
modifications to this equipment not expressly approved by the HewlettPackard Company may cause harmful interference and void the FCC
authorization to operate this equipment.
note à l’attention des utilisateurs du réseau téléphonique Canadien/notice to
users of the Canadian telephone network
Cet appareil est conforme aux spécifications techniques des équipements terminaux
d’Industrie Canada. Le numéro d’enregistrement atteste de la conformité de l’appareil.
L’abréviation IC qui précède le numéro d’enregistrement indique que l’enregistrement a été
110
hp officejet 4200 series
technical information
Pour leur propre sécurité, les utilisateurs doivent s’assurer que les prises électriques reliées
à la terre de la source d’alimentation, des lignes téléphoniques et du circuit métallique
d’alimentation en eau sont, le cas échéant, branchées les unes aux autres. Cette précaution
est particulièrement importante dans les zones rurales.
Le numéro REN (Ringer Equivalence Number) attribué à chaque appareil terminal fournit
une indication sur le nombre maximal de terminaux qui peuvent être connectés à une
interface téléphonique. La terminaison d’une interface peut se composer de n’importe
quelle combinaison d’appareils, à condition que le total des numéros REN ne dépasse pas
5.
Basé sur les résultats de tests FCC Partie 68, le numéro REN de ce produit est 0.5B.
This equipment meets the applicable Industry Canada Terminal Equipment Technical
Specifications. This is confirmed by the registration number. The abbreviation IC before the
registration number signifies that registration was performed based on a Declaration of
Conformity indicating that Industry Canada technical specifications were met. It does not
imply that Industry Canada approved the equipment.
Users should ensure for their own protection that the electrical ground connections of the
power utility, telephone lines and internal metallic water pipe system, if present, are
connected together. This precaution may be particularly important in rural areas.
Note: The Ringer Equivalence Number (REN) assigned to each terminal device
provides an indication of the maximum number of terminals allowed to be connected
to a telephone interface. The termination on an interface may consist of any
combination of devices subject only to the requirement that the sum of the Ringer
Equivalence Numbers of all the devices does not exceed 5.
The REN for this product is 0.5B, based on FCC Part 68 test results.
note à l’attention des utilisateurs Canadien/notice to users in Canada
Le présent appareil numérique n‘émet pas de bruit radioélectrique dépassant les limites
applicables aux appareils numériques de la classe B prescrites dans le Règlement sur le
brouillage radioélectrique édicté par le ministère des Communications du Canada.
This digital apparatus does not exceed the Class B limits for radio noise emissions from the
digital apparatus set out in the Radio Interference Regulations of the Canadian Department
of Communications.
user guide
111
technical information
effectué dans le cadre d’une Déclaration de conformité stipulant que les spécifications
techniques d’Industrie Canada ont été respectées. Néanmoins, cette abréviation ne
signifie en aucun cas que l’appareil a été validé par Industrie Canada.
chapter 11
technical information
notice to users in the European Economic Area
This product is designed to interwork with the analogue telephone networks in the
following countries:
Austria
Greece
Portugal
Belgium
Ireland
Spain
Denmark
Italy
Sweden
Finland
Luxembourg
Switzerland
France
Netherlands
United Kingdom
Germany
Norway
Network compatibility depends on customer selected settings, which must be reset to use
the equipment on a telephone network in a country other than where the product was
purchased. Contact the vendor or Hewlett-Packard Company if additional product support
is necessary.
This equipment has been certified by the manufacturer in accordance with Directive 1999/
5/EC (annex II) for Pan-European single-terminal connection to the public switched
telephone network (PSTN). However, due to differences between the individual PSTNs
provided in different countries, the approval does not, of itself, give an unconditional
assurance of successful operation on every PSTN network termination point.
In the event of problems, you should contact your equipment supplier in the first instance.
This equipment is designed for DTMF tone dialing and loop disconnect dialing. In the
unlikely event of problems with loop disconnect dialing, it is recommended to use this
equipment only with the DTMF tone dial setting.
notice to users of the German telephone network
This HP fax product is designed to connect only to the analogue public-switched telephone
network (PSTN). Please connect the TAE N telephone connector plug, provided with the
HP Officejet 4200 and 4250 Series into the wall socket (TAE 6) code N. This HP fax
product can be used as a single device and/or in combination (in serial connection) with
other approved terminal equipment.
geräuschemission
LpA < 70 dB
am Arbeitsplatz
im Normalbetrieb
nach DIN 45635 T. 19
declaration of conformity (European Union)
The Declaration of Conformity in this document complies with ISO/IEC Guide 22 and
EN 45014. It identifies the product, manufacturer’s name and address, and applicable
specifications recognized in the European community.
112
hp officejet 4200 series
technical information
user guide
technical information
notice to users in Korea (Officejet 4255 only)
113
technical information
chapter 11
declaration of conformity
According to ISO/IEC Guide 22 and EN 45014
Manufacturer’s name and address:
Hewlett-Packard Company, 16399 West Bernardo Drive, San Diego, CA 92127-1899, USA
Regulatory model
number:
SDGOB-0306-01
Declares that the product:
Product name:
HP Officejet 4200 Series (Q5600A, Q5607A)
Model number(s):
4215 (Q5601A), 4215xi (Q5602A), 4215v (Q5603A)
4211 (Q5604A), 4212 (Q5605A), 4219 (Q5606A)
Power adapters:
Not Applicable
Conforms to the following product specifications:
Safety:
IEC 60950:1999 3rd Edition
EN 60950:1999
UL1950/CSA22.2 No.950, 3rd Edition: 1995
EMC:
CISPR 22:1997 / EN 55022:1998, Class B
CISPR 24:1997 / EN 55024:1998
IEC 61000-3-2:1995 / EN 61000-3-2:1995
IEC 61000-3-3:1994 / EN 61000-3-3:1995
FCC Part 15-Class B/ICES-003, Issue 2
Telecom:
TBR 21:1998
Supplementary Information:
The product herewith complies with the requirements of the Low Voltage Directive 73/23/EC, the EMC
Directive 89/336/EC, and with the R&TTE Directive 1999/5/EC (Annex II) and carries the CE marking
accordingly.
• The product was tested in a typical configuration.
European Contact for regulatory topics only: Hewlett Packard GmbH, HQ-TRE, Herrenberger Strasse
140, D-71034 Böblingen Germany. (FAX +49-7031-14-3143)
114
hp officejet 4200 series
technical information
technical information
declaration of conformity
According to ISO/IEC Guide 22 and EN 45014
Manufacturer’s name and address:
Hewlett-Packard Company, 16399 West Bernardo Drive, San Diego, CA 92127-1899, USA
Regulatory model
number:
SDGOB-0306-02
Declares that the product:
Product name:
HP Officejet 4250 Series (Q5610A)
Model number(s):
4255 (Q5611A), 4252 (Q5613A), 4259 (Q5614A)
Power adapters:
Not Applicable
Conforms to the following product specifications:
Safety:
IEC 60950:1999 3rd Edition
EN 60950:1999
UL1950/CSA22.2 No.950, 3rd Edition: 1995
NOM 019SFCI 1993, A2/N25 3260
GB4943: 2001
EMC:
CISPR 22:1997 / EN 55022:1998, Class B
CISPR 24:1997 / EN 55024:1998
IEC 61000-3-2:1995 / EN 61000-3-2:1995
IEC 61000-3-3:1994 / EN 61000-3-3:1995
AS/NZS3548:1998
CNS13438 Approved 1994, Revised 1997
FCC Part 15-Class B/ICES-003, Issue 2
GB9254:1998
Telecom:
TBR 21:1998
TBR 38: 1998
Supplementary Information:
The product herewith complies with the requirements of the Low Voltage Directive 73/23/EC, the EMC
Directive 89/336/EC, and with the R&TTE Directive 1999/5/EC (Annex II) and carries the CE marking
accordingly.
• The product was tested in a typical configuration.
European Contact for regulatory topics only: Hewlett Packard GmbH, HQ-TRE, Herrenberger Strasse
140, D-71034 Böblingen Germany. (FAX +49-7031-14-3143)
user guide
115
technical information
chapter 11
116
hp officejet 4200 series
fax setup
fax setup
12
After completing all steps in the Setup Poster, use the instructions in this section
to complete your fax setup. Please keep your Setup Poster for later use.
In this section, you will learn how to set up your HP Officejet so that faxing works
successfully with any equipment and services you might already have on the
same telephone line as your HP Officejet.
If you subscribe to Caller ID, refer to use caller ID on page 66 after you have
completed this chapter.
Read at least through page 119 to determine what additional (if any) setup you
need to do.
This section contains the following topics:
•
faxing from a DSL line on page 118
•
faxing with a PBX phone system or an ISDN line on page 119
•
how to tell if the following instructions apply to you on page 119
•
how to choose the right fax setup for your office on page 120
•
select your fax setup case from this table on page 121
•
case A: separate fax line (no voice calls received) on page 123
•
case B: faxing with a distinctive ring service on the same line on page 124
•
case C: shared voice/fax line on page 125
•
case D: fax line shared with PC modem (no voice calls received) on
page 126
•
case E: shared voice/fax line with PC modem on page 128
•
case F: shared voice/fax line with answering machine on page 130
•
case G: shared voice/fax line with PC modem and answering machine on
page 131
•
case H: shared voice/fax line with voice mail on page 133
•
case I: shared voice/fax line with PC modem and voice mail on page 134
117
chapter 12
faxing from a DSL line
fax setup
If you have a digital subscriber line (DSL) service through your phone company,
use the instructions in this section to connect a DSL filter between the telephone
wall jack and your HP Officejet. This filter removes the digital signal that would
block your HP Officejet from communicating properly with the telephone line.
Caution! If you have a DSL line and you do not connect the DSL
filter, you will not be able to send and receive faxes with your
HP Officejet.
Use the phone cord supplied in
the box with your HP Officejet
Telephone
wall jack
DSL filter
supplied by your
DSL provider
Back view of the HP Officejet
Caution! If you do not use the supplied cord to connect from the
DSL filter to your HP Officejet, you may not be able to fax
successfully. If you live in one of the countries listed in the table on
page 119, you received a special 2-wire cord. This special 2-wire
cord is different from the more common 4-wire phone cords you
might already have in your office. For more information about how
to tell the difference between the cords, see I have difficulties when
sending faxes and when receiving faxes on page 146.
118
1
Obtain a DSL filter from your DSL provider.
2
Using the phone cord supplied in the box with your HP Officejet, connect
one end to the open port on the DSL filter, then connect the other end to the
port labeled “1-LINE” on the back of your HP Officejet.
3
Connect the DSL filter cord to the telephone wall jack.
4
Proceed to how to tell if the following instructions apply to you on
page 119 to determine what else you need to do to finish setting up your
HP Officejet.
hp officejet 4200 series
fax setup
faxing with a PBX phone system or an ISDN line
Caution! Many digital PBX systems include a call-waiting tone that
is factory-set to “on.” This call-waiting tone will interfere with any
fax transmission, and you will not be able to send or receive faxes
with your HP Officejet. Refer to your digital PBX system’s
documentation for instructions on how to turn off the call-waiting
tone.
If you are using either a PBX or an ISDN converter, make sure the HP Officejet is
connected to the port that is designated for fax and phone use.
Some ISDN systems allow you to configure the ports for specific phone
equipment—for example, you might have assigned one for telephone and Group
3 fax and another for multiple purposes.
Note: If you have problems when connected to the fax/phone port of your
ISDN converter, try using the port designated for multiple purposes (might
be labeled “multi-combi” or something similar).
how to tell if the following instructions apply to you
The rest of the fax setup instructions in this chapter are intended for parallel-type
telephone systems, which are most common in the countries/regions listed in the
table below.
•
If all of your telephone equipment (modems, phones, answering machines,
and faxes) connects directly to your telephone wall jack, you probably
have a serial-type telephone system. Check the table below to make sure
that your country/region does not appear in the list. If you are unsure
which kind of telephone system you have (parallel or serial), check with
your telephone company. If you have a serial system, you do not need to
read further. If you have Caller ID on the line where you will install your
HP Officejet, please refer to use caller ID on page 66 and block junk fax
numbers on page 66.
•
If your country/region is listed, use the following instructions to complete
your fax setup.
use this chapter if located in one of these countries/regions
user guide
Argentina
Australia
Brazil
Canada
Chile
China
Colombia
Greece
India
Indonesia
Ireland
Japan
Korea
Latin America
Malaysia
Mexico
Philippines
Poland
Portugal
Russia
Saudi Arabia
119
fax setup
If your telephone line has a PBX system, make sure you dial the number for an
outside line before dialing the fax number.
chapter 12
fax setup
use this chapter if located in one of these countries/regions
Singapore
Spain
Taiwan
Thailand
USA
Venezuela
Vietnam
how to choose the right fax setup for your office
Caution! Please refer to how to tell if the following instructions
apply to you on page 119 before following any of these
instructions.
To fax successfully, you need to know what types of equipment and services (if
any) share the same telephone line with your HP Officejet. This is important
because you might need to connect some of your existing office equipment
directly to your HP Officejet, and you might also need to change some fax
settings before you can fax successfully.
To determine the best way to set up the HP Officejet in your office, first read
through the questions in this section and record your answers. Next, refer to the
table in the following section and choose the recommended setup case based on
your answers.
Be sure to read and answer the following questions in the order they are
presented.
120
1
Do you subscribe to a distinctive ring service through your phone company
that provides multiple phone numbers with different ring patterns?
!
Yes, I have distinctive ring.
!
No.
If you answered “Yes,” proceed directly to case B: faxing with a distinctive
ring service on the same line on page 124. You do not need to continue
answering questions.
If you answered “No,” please continue answering questions.
Not sure if you have distinctive ring? Many phone companies offer a
distinctive ring feature that allows you to have several phone numbers on
one phone line.
When you subscribe to this service, each number will have a different ring
pattern—for example, single, double, and triple rings. You might assign
one phone number with a single ring to your voice calls, and another
phone number with double rings to your fax calls. This allows you—and
your HP Officejet—to tell the difference between voice and fax calls when
the phone rings.
2
Do you receive voice calls at the same phone number you will use for fax
calls on your HP Officejet?
!
Yes, I receive voice calls.
!
No.
Please continue answering questions.
3
Do you have a PC modem on the same telephone line as your
HP Officejet?
hp officejet 4200 series
fax setup
Yes, I have a PC modem.
!
No.
Here is how to determine if you have a PC modem. If you answer “Yes” to
any of the following questions, you are using a PC modem:
– Do you send and receive faxes directly to and from your computer
programs through a dial-up connection?
– Do you use e-mail on your computer through a dial-up connection?
– Do you access the Internet from your computer through a dial-up
connection?
Please continue answering questions.
4
Do you have an answering machine that answers voice calls at the same
phone number you will use for fax calls on your HP Officejet?
!
Yes, I have an answering machine.
!
No.
Please continue answering questions.
5
Do you subscribe to a voice mail service through your phone company at
the same phone number you will use for fax calls on your HP Officejet?
!
Yes, I have a voice mail service.
!
No.
select your fax setup case from this table
Now that you have answered all of the questions about the equipment and
services that share the phone line with your HP Officejet, you are ready to
choose the best setup case for your office.
From the first column in the following table, choose the combination of equipment
and services applicable to your office setting. Then look up the appropriate setup
case in the second column. Step-by-step instructions are included for each case
later in this chapter.
If you have answered all of the questions in the previous section and have none
of the described equipment or services, choose “None” from the first column in
the table.
other equipment/services sharing your fax line
recommended fax setup
None
(You answered “No” to all questions.)
Case A: Separate fax line
(no voice calls received)
Distinctive ring service
(You answered “Yes” to question 1 only.)
Case B: Faxing with a distinctive ring
service on the same line
Voice calls
(You answered “Yes” to question 2 only.)
Case C: Shared voice/fax line
PC modem
(You answered “Yes” to question 3 only.)
Case D: Fax line shared with PC
modem (no voice calls received)
user guide
121
fax setup
!
fax setup
chapter 12
other equipment/services sharing your fax line
recommended fax setup
Voice calls and PC modem
(You answered “Yes” to questions 2 and 3 only.)
Case E: Shared voice/fax line with PC
modem
Voice calls and answering machine
(You answered “Yes” to questions 2 and 4 only.)
Case F: Shared voice/fax line with
answering machine
Voice calls, PC modem, and answering machine
(You answered “Yes” to questions 2, 3, and 4
only.)
Case G: Shared voice/fax line with PC
modem and answering machine
Voice calls and voice mail service
(You answered “Yes” to questions 2 and 5 only.)
Case H: Shared voice/fax line with
voice mail
Voice calls, PC modem, and voice mail service
(You answered “Yes” to questions 2, 3, and 5
only.)
Case I: Shared voice/fax line with PC
modem and voice mail
122
hp officejet 4200 series
fax setup
case A: separate fax line (no voice calls received)
Telephone
wall jack
Use the phone cord
supplied in the box with
your HP Officejet
Back view of the HP Officejet
1
Using the phone cord supplied in the box with your HP Officejet, connect
one end to your telephone wall jack, then connect the other end to the port
labeled “1-LINE” on the back of your HP Officejet.
Caution! If you do not use the supplied cord to connect from the
telephone wall jack to your HP Officejet, you probably will not be
able to fax successfully. This special 2-wire cord is different from
the more common 4-wire phone cords you might already have in
your office. For more information about how to tell the difference
between the cords, see I have difficulties when sending faxes and
when receiving faxes on page 146.
2
Press the Answer Mode button on the front panel until Fax appears on the
display.
how your hp officejet will answer fax calls
When the phone rings, your HP Officejet will answer automatically after the
number of rings you set in the Rings to Answer setting. Then it will begin emitting
fax reception tones to the sending fax machine and receive the fax.
user guide
123
fax setup
If you have a separate fax line on which you receive no voice calls, and you have
no other equipment connected on this phone line, connect your HP Officejet as
described in this section.
chapter 12
case B: faxing with a distinctive ring service on the same line
fax setup
If you subscribe to a distinctive ring service through your phone company that
allows you to have multiple phone numbers on one phone line, each with a
different ring pattern, connect your HP Officejet as described in this section.
Telephone
wall jack
Use the phone cord
supplied in the box with
your HP Officejet
Back view of the HP Officejet
1
Using the phone cord supplied in the box with your HP Officejet, connect
one end to your telephone wall jack, then connect the other end to the port
labeled “1-LINE” on the back of your HP Officejet.
Caution! If you do not use the supplied cord to connect from the
telephone wall jack to your HP Officejet, you probably will not be
able to fax successfully. This special 2-wire cord is different from
the more common 4-wire phone cords you might already have in
your office. For more information about how to tell the difference
between the cords, see I have difficulties when sending faxes and
when receiving faxes on page 146.
2
Press the Answer Mode button on the front panel until Fax appears on the
display.
3
Change the Answer Ring Pattern setting to the pattern that has been
assigned by the phone company to your fax number—for example, double
rings or triple rings.
a. Press Setup.
b. Press 4, then press 1.
c. Press ! to scroll through the options.
d. When the ring pattern that the phone company established for your fax
number appears on the display, press OK.
Note: Your HP Officejet is factory-set to answer all ring patterns. If you do
not set the correct ring pattern assigned by the phone company to your fax
number, your HP Officejet might answer both voice calls and fax calls or it
might not answer at all.
how your hp officejet will answer fax calls
Your HP Officejet will automatically answer incoming calls that have the ring
pattern you selected (Answer Ring Pattern setting) after the number of rings you
selected (Rings to Answer setting). Then it will begin emitting fax reception tones
to the sending fax machine and receive the fax.
124
hp officejet 4200 series
fax setup
case C: shared voice/fax line
Telephone
wall jack
Use the phone cord
supplied in the box with
your HP Officejet
Back view of the HP Officejet
1
Optional phone for
HP Officejet 4210
Series with no
handset.
Using the phone cord supplied in the box with your HP Officejet, connect
one end to your telephone wall jack, then connect the other end to the port
labeled “1-LINE” on the back of your HP Officejet.
Caution! If you do not use the supplied cord to connect from the
telephone wall jack to your HP Officejet, you probably will not be
able to fax successfully. This special 2-wire cord is different from
the more common 4-wire phone cords you might already have in
your office. For more information about how to tell the difference
between the cords, see I have difficulties when sending faxes and
when receiving faxes on page 146.
2
Remove the white plug from the port labeled “2-EXT” on the back of your
HP Officejet, and then connect a phone to this port.
3
Follow the instructions below that apply to your HP Officejet.
hp officejet 4210 series (with no handset)
Now you need to decide how you want to answer fax calls: automatically or
manually.
how to answer fax calls automatically
4
Press the Answer Mode button on the front panel until Fax appears on the
display.
5
Set Rings to Answer to 6.
a. Press Setup.
b. Press 3, then 3.
c. Enter 6 using the keypad.
d. Press OK.
Your HP Officejet will not be able to distinguish between fax and voice calls in
this case. If you suspect a voice call is incoming, you will need to answer it before
the 6th ring or the HP Officejet will answer with fax tones.
user guide
125
fax setup
If you receive both voice calls and fax calls at the same phone number, and you
have no other office equipment (or voice mail) on this phone line, connect your
HP Officejet as described in this section.
chapter 12
fax setup
Note: If you pick up the phone before the 6th ring and hear fax tones from
a sending fax machine, you will need to manually answer the fax call. For
information about how to receive fax calls manually from your attached
phone and from an extension phone, see receive a fax manually from a
phone on page 48.
how to answer fax calls manually
To receive faxes manually, you must be available to respond in person to
incoming fax calls or your HP Officejet cannot receive faxes.
6
Press the Answer Mode button on the front panel until Tel appears on the
display.
The HP Officejet will never answer the call. You must answer the call, and if it is
a fax call, manually accept the fax. For information about how to receive fax
calls manually from your attached phone and from an extension phone, see
receive a fax manually from a phone on page 48.
hp officejet 4250 series (with handset)
!
Press the Answer Mode button on the front panel until Fax/Tel appears on
the display.
how your hp officejet will answer fax calls
The HP Officejet automatically answers all incoming calls based on the
Rings to Answer setting. If the call is a fax call, the HP Officejet will receive
the fax.
If the call is a voice call, the HP Officejet will create a special ring to
indicate it is a voice call. You will need to answer the incoming voice call
using the attached handset. You should not answer voice calls from other
telephones on the line. The device cannot tell that you picked up the
extension phone and will keep ringing. You will have to press Cancel on
the HP Officejet to stop the ringing.
case D: fax line shared with PC modem (no voice calls
received)
If you have a fax line on which you receive no voice calls, and you also have a
PC modem connected on this line, connect your HP Officejet as described in this
section.
Note: Since your PC modem shares the telephone line with your
HP Officejet, you will not be able to use both your PC modem and your
HP Officejet simultaneously. For example, while you are sending and
receiving faxes, you will not be able to e-mail or access the Internet.
126
hp officejet 4200 series
fax setup
fax setup
Use the phone cord
supplied in the box with
your HP Officejet
PC with modem
Telephone
wall jack
Back view of the HP Officejet
1
Remove the white plug from the port labeled “2-EXT” on the back of your
HP Officejet.
2
Find the phone cord that connects from the back of your computer (your PC
modem) to a telephone wall jack. Disconnect the cord from the telephone
wall jack and plug it into the port labeled “2-EXT” on the back of your
HP Officejet.
3
Using the phone cord supplied in the box with your HP Officejet, connect
one end to your telephone wall jack, then connect the other end to the port
labeled “1-LINE” on the back of your HP Officejet.
Caution! If you do not use the supplied cord to connect from the
telephone wall jack to your HP Officejet, you probably will not be
able to fax successfully. This special 2-wire cord is different from
the more common 4-wire phone cords you might already have in
your office. For more information about how to tell the difference
between the cords, see I have difficulties when sending faxes and
when receiving faxes on page 146.
4
Press the Answer Mode button on the front panel until Fax appears on the
display.
5
If your PC modem’s software is set to automatically receive faxes to your
computer, turn off that setting.
Caution! If you do not turn off the auto fax receive setting in your
PC modem software, your HP Officejet will not be able to receive
faxes.
how your hp officejet will answer fax calls
When the phone rings, your HP Officejet will answer automatically after the
number of rings you set in the Rings to Answer setting. Then it will begin emitting
fax reception tones to the sending fax machine and receive the fax.
user guide
127
chapter 12
case E: shared voice/fax line with PC modem
fax setup
If you receive both voice calls and fax calls at the same phone number, and you
also have a PC modem connected on this phone line, connect your HP Officejet
as described in this section.
Note: Since your PC modem shares the telephone line with your
HP Officejet, you will not be able to use both your PC modem and your
HP Officejet simultaneously. For example, while you are sending and
receiving faxes, you will not be able to e-mail or access the Internet.
Use the phone cord
supplied in the box with
your HP Officejet
PC with modem
Telephone
wall jack
Telephone
Back view of the HP Officejet
IN
OUT
1
Remove the white plug from the port labeled “2-EXT” on the back of your
HP Officejet.
2
Find the phone cord that connects from the back of your computer (your PC
modem) to a telephone wall jack. Disconnect the cord from the telephone
wall jack and plug it into the port labeled “2-EXT” on the back of your
HP Officejet.
3
Connect a phone to the “out” port on the back of your PC modem.
4
Using the phone cord supplied in the box with your HP Officejet, connect
one end to your telephone wall jack, then connect the other end to the port
labeled “1-LINE” on the back of your HP Officejet.
Caution! If you do not use the supplied cord to connect from the
telephone wall jack to your HP Officejet, you probably will not be
able to fax successfully. This special 2-wire cord is different from
the more common 4-wire phone cords you might already have in
your office. For more information about how to tell the difference
between the cords, see I have difficulties when sending faxes and
when receiving faxes on page 146.
5
If your PC modem’s software is set to automatically receive faxes to your
computer, turn off that setting.
Caution! If you do not turn off the auto fax receive setting in your
PC modem software, your HP Officejet will not be able to receive
faxes.
6
128
Follow the instructions below that apply to your HP Officejet.
hp officejet 4200 series
fax setup
hp officejet 4210 series (with no handset)
how to answer fax calls automatically
1
Press the Answer Mode button on the front panel until Fax appears on the
display.
2
Set Rings to Answer to 6.
a. Press Setup.
b. Press 3, then 3.
c. Enter 6 using the keypad.
d. Press OK.
Your HP Officejet will not be able to distinguish between fax and voice calls in
this case. If you suspect a voice call is incoming, you will need to answer it before
the 6th ring or the HP Officejet will answer with fax tones.
Note: If you pick up the phone before the 6th ring and hear fax tones from
a sending fax machine, you will need to manually answer the fax call. For
information about how to receive fax calls manually from your attached
phone and from an extension phone, see receive a fax manually from a
phone on page 48.
how to answer fax calls manually
To receive faxes manually, you must be available to respond in person to
incoming fax calls or your HP Officejet cannot receive faxes.
!
Press the Answer Mode button on the front panel until Tel appears on the
display.
The HP Officejet will never answer the call. You must answer the call, and if it is
a fax call, manually accept the fax. For information about how to receive fax
calls manually from your attached phone and from an extension phone, see
receive a fax manually from a phone on page 48.
hp officejet 4250 series (with handset)
!
Press the Answer Mode button on the front panel until Fax/Tel appears on
the display.
how your hp officejet will answer fax calls
The HP Officejet automatically answers all incoming calls based on the
RIngs to Answer setting. If the call is a fax call, the HP Officejet will receive
the fax.
If the call is a voice call, the HP Officejet will create a special ring to
indicate it is a voice call. You will need to answer the incoming voice call
using the attached handset. You should not answer voice calls from other
telephones on the line. The device cannot tell that you picked up the
extension phone and will keep ringing. You will have to press Cancel on
the HP Officejet to stop the ringing.
user guide
129
fax setup
Now you need to decide how you want to answer fax calls: automatically or
manually.
chapter 12
case F: shared voice/fax line with answering machine
fax setup
If you receive both voice calls and fax calls at the same phone number, and you
also have an answering machine that answers voice calls at this phone number,
connect your HP Officejet as described in this section.
Use the phone cord
supplied in the box with
your HP Officejet
Telephone
wall jack
Answering
machine
Back view of the HP Officejet
IN
Telephone
(optional)
OUT
1
Remove the white plug from the port labeled “2-EXT” on the back of your
HP Officejet.
2
Unplug your answering machine from the telephone wall jack, and connect
it to the port labeled “2-EXT” on the back of your HP Officejet.
Caution! If you do not connect your answering machine directly to
your HP Officejet, fax tones from a sending fax machine could be
recorded on your answering machine, and you probably will not
be able to receive faxes with your HP Officejet.
3
Using the phone cord supplied in the box with your HP Officejet, connect
one end to your telephone wall jack, then connect the other end to the port
labeled “1-LINE” on the back of your HP Officejet.
Caution! If you do not use the supplied cord to connect from the
telephone wall jack to your HP Officejet, you probably will not be
able to fax successfully. This special 2-wire cord is different from
the more common 4-wire phone cords you might already have in
your office. For more information about how to tell the difference
between the cords, see I have difficulties when sending faxes and
when receiving faxes on page 146.
4
Press the Answer Mode button on the front panel until AnswerMachine
appears on the display.
5
(Optional) If your answering machine does not have a handset, for
convenience you might want to connect a phone to the back of your
answering machine at the “out” port.
how your hp officejet will answer fax calls
When the phone rings, your answering machine will answer and then play
your recorded greeting. The HP Officejet monitors the call during this time,
“listening” for fax tones. If incoming fax tones are detected, the
130
hp officejet 4200 series
fax setup
case G: shared voice/fax line with PC modem and answering
machine
If you receive both voice calls and fax calls at the same phone number, and you
also have a PC modem and answering machine connected on this phone line,
connect your HP Officejet as described in this section.
Note: Since your PC modem shares the telephone line with your
HP Officejet, you will not be able to use both your PC modem and your
HP Officejet simultaneously. For example, while you are sending and
receiving faxes, you will not be able to send e-mail or access the Internet.
Use the phone cord
supplied in the box with
your HP Officejet
PC with modem
Answering
machine
Telephone
wall jack
Back view of the HP Officejet
IN
Telephone
(optional)
OUT
1
Remove the white plug from the port labeled “2-EXT” on the back of your
HP Officejet.
2
Find the phone cord that connects from the back of your computer (your PC
modem) to a telephone wall jack. Disconnect the cord from the telephone
wall jack and plug it into the port labeled “2-EXT” on the back of your
HP Officejet.
3
Unplug your answering machine from the telephone wall jack, and connect
it to the “out” port on the back of your PC modem.
This allows a direct connection between the HP Officejet and your
answering machine, even though the PC modem is connected first in line.
Caution! If you do not connect your answering machine in this
way, fax tones from a sending fax machine could be recorded on
your answering machine, and you will probably not be able to
receive faxes with your HP Officejet.
4
user guide
Using the phone cord supplied in the box with your HP Officejet, connect
one end to your telephone wall jack, then connect the other end to the port
labeled “1-LINE” on the back of your HP Officejet.
131
fax setup
HP Officejet will emit fax reception tones and receive the fax; if there are
no fax tones, the HP Officejet stops monitoring the line and your answering
machine can record a voice message.
chapter 12
fax setup
Caution! If you do not use the supplied cord to connect from the
telephone wall jack to your HP Officejet, you probably will not be
able to fax successfully. This special 2-wire phone cord is different
from the more common 4-wire cords you might already have in
your office. For more information about how to tell the difference
between the cords, see I have difficulties when sending faxes and
when receiving faxes on page 146.
5
Press the Answer Mode button on the front panel until AnswerMachine
appears on the display.
6
If your PC modem’s software is set to automatically receive faxes to your
computer, turn off that setting.
Caution! If you do not turn off the auto fax receive setting in your
PC modem software, your HP Officejet will not be able to receive
faxes.
7
(Optional) If your answering machine does not have a built-in phone, for
convenience you might want to connect a phone to the back of your
answering machine at the “out” port.
how your hp officejet will answer fax calls
When the phone rings, your answering machine will answer and then play
your recorded greeting. The HP Officejet monitors the call during this time,
“listening” for fax tones. If incoming fax tones are detected, the
HP Officejet will emit fax reception tones and receive the fax; if there are
no fax tones, the HP Officejet stops monitoring the line and your answering
machine can record a voice message.
132
hp officejet 4200 series
fax setup
case H: shared voice/fax line with voice mail
If you receive both voice calls and fax calls at the same phone number, and you
also subscribe to a voice mail service through your phone company, connect
your HP Officejet as described in this section.
Telephone
wall jack
Use the phone cord
supplied in the box with
your HP Officejet
1
Telephone
(optional)
Back view of the HP Officejet
Using the phone cord supplied in the box with your HP Officejet, connect
one end to your telephone wall jack, then connect the other end to the port
labeled “1-LINE” on the back of your HP Officejet.
Caution! If you do not use the supplied cord to connect from the
telephone wall jack to your HP Officejet, you probably will not be
able to fax successfully. This special 2-wire cord is different from
the more common 4-wire phone cords you might already have in
your office. For more information about how to tell the difference
between the cords, see I have difficulties when sending faxes and
when receiving faxes on page 146.
2
Remove the white plug from the port labeled “2-EXT” on the back of your
HP Officejet, and then connect a phone to this port.
3
Press the Answer Mode button on the front panel until TEL appears on the
display.
how to answer fax calls manually
You must be available to respond in person to incoming fax calls, or your
HP Officejet cannot receive faxes. For information about how to receive fax calls
manually from your attached phone and from an extension phone, see receive a
fax manually from a phone on page 48.
user guide
133
fax setup
Note: The HP Officejet cannot receive faxes automatically if you have a
voice mail service, so you must be available to respond in person (manually)
to incoming fax calls. If you want to receive faxes automatically instead,
contact your phone company to subscribe to a distinctive ring service, or to
obtain a separate phone line for faxing.
chapter 12
case I: shared voice/fax line with PC modem and voice mail
fax setup
Note: The HP Officejet cannot receive faxes automatically if you have a
voice mail service, so you must be available to respond in person (manually)
to incoming fax calls. If you want to receive faxes automatically instead,
contact your phone company to subscribe to a distinctive ring service, or to
obtain a separate phone line for faxing.
If you receive both voice calls and fax calls at the same phone number, use a PC
modem on the same phone line, and also subscribe to a voice mail service
through your phone company, connect your HP Officejet as described in this
section.
Note: Since your PC modem shares the telephone line with your
HP Officejet, you will not be able to use both your PC modem and your
HP Officejet simultaneously. For example, while you are sending and
receiving faxes, you will not be able to e-mail or access the Internet.
Use the phone cord
supplied in the box with
your HP Officejet
PC with modem
Telephone
wall jack
Telephone
Back view of the HP Officejet
IN
OUT
1
Remove the white plug from the port labeled “2-EXT” on the back of your
HP Officejet.
2
Find the phone cord that connects from the back of your computer (your PC
modem) to a telephone wall jack. Disconnect the cord from the telephone
wall jack and plug it into the port labeled “2-EXT” on the back of your
HP Officejet.
3
Connect a phone to the “out” port on the back of your PC modem.
4
Using the phone cord supplied in the box with your HP Officejet, connect
one end to your telephone wall jack, then connect the other end to the port
labeled “1-LINE” on the back of your HP Officejet.
Caution! If you do not use the supplied cord to connect from the
telephone wall jack to your HP Officejet, you probably will not be
able to fax successfully. This special 2-wire cord is different from
the more common 4-wire phone cords you might already have in
your office. For more information about how to tell the difference
between the cords, see I have difficulties when sending faxes and
when receiving faxes on page 146.
134
hp officejet 4200 series
fax setup
Press the Answer Mode button on the front panel until TEL appears on the
display.
6
If your PC modem’s software is set to automatically receive faxes to your
computer, turn off that setting.
Caution! If you do not turn off the auto fax receive setting in your
modem software, your HP Officejet will not be able to receive
faxes.
how to answer fax calls manually
You must be available to respond in person to incoming fax calls, or your
HP Officejet cannot receive faxes. For information about how to receive fax calls
manually from your attached phone and from an extension phone, see send a
fax manually from a telephone on page 43.
user guide
135
fax setup
5
fax setup
chapter 12
136
hp officejet 4200 series
troubleshooting information
troubleshooting
13
This section contains troubleshooting information for the HP Officejet
4200 Series (HP Officejet). Specific information is provided for installation and
configuration topics. References to our online troubleshooting help are provided
for operational topics.
This section contains the following:
•
installation troubleshooting on page 137
•
operational troubleshooting on page 150
installation troubleshooting
Installation and configuration troubleshooting tips are included in this section for
some of the most common issues associated with HP Officejet fax setup, and
software and hardware installation.
This section includes the following topics:
•
software and hardware installation troubleshooting on page 137
•
fax setup troubleshooting on page 146
software and hardware installation troubleshooting
If you encounter a software or hardware problem during installation, see the
topics below for a possible solution.
During a normal installation of the HP Officejet software, the following things
occur:
•
The HP Officejet CD-ROM runs automatically
•
The software installs
•
Files are copied to your hard drive
•
You are requested to plug in the HP Officejet
•
A green OK and check mark appear on an installation wizard screen
•
You are requested to restart your computer
•
the Fax Setup wizard runs
•
The registration process runs
If any of these things did not occur, there might be a problem with the installation.
137
chapter 13
troubleshooting
To check the installation on a Macintosh, verify the following:
• Double-click the HP Officejet and make sure the essential icons (scan
picture, scan document, send fax, and hp gallery appear in the
HP Director. If the essential icons do not appear immediately, you might
need to wait a few minutes for the HP Officejet to connect to your
computer. Otherwise see below.
•
Open the Chooser and check to see that the HP Officejet is listed.
To check the installation on a PC, verify the following:
• Double-click the HP Officejet and make sure the essential icons (scan
picture, scan document, send fax, and hp image zone appear in the
HP Director. If the essential icons do not appear immediately, you might
need to wait a few minutes for the HP Officejet to connect to your
computer. Otherwise see below.
•
Open the Printers dialog box and check to see that the HP Officejet is
listed.
Look at the system tray for an HP Officejet icon. This indicates that the
HP Officejet is ready. The HP Officejet icon normally appears in the lower-right
corner of the desktop in the Task Tray.
Task Tray
software installation troubleshooting
Use this section to solve any problems you might encounter while installing the
HP Officejet software.
138
problem
possible cause and solution
When I insert the
CD-ROM into my
computer's CD-ROM
drive, nothing
happens
If nothing appears on your computer screen after you insert the
HP Officejet 4200 Series CD-ROM into your computer’s CD-ROM
drive:
1
From the Windows Start menu, choose Run.
2
In the Run dialog box, enter d:\setup.exe (if your CD-ROM
drive is not assigned to drive letter d, use the appropriate drive
letter), then click OK.
hp officejet 4200 series
troubleshooting information
possible cause and solution
The minimum system
checks screen
appears during
installation
If the minimum system checks screen appears, your system does not
meet the recommended requirements to install the software. Click
Details to see what the specific problem is. Then correct the problem
before attempting to install the software.
A red X appears on
the USB connect
prompt
If a red X appears on the USB connect prompt, follow these steps:
1
Verify that the front panel cover is firmly attached, then unplug
the HP Officejet and plug it in again.
2
Verify that the USB and power cables are plugged in.
3
Verify that the USB cable is set up properly as follows:
– Unplug the USB cable and plug it in again.
– Do not attach the USB cable to a keyboard or non-powered
hub.
– Verify that the USB cable is 3 meters or less in length.
– If you have several USB devices attached to your computer,
you might want to unplug the others during the installation.
4
Continue with the installation and reboot the computer when
prompted. Then open HP Director and check for the essential
icons (scan picture, scan document, send fax, and
hp image zone).
5
If the essential icons still do not appear in HP Director, remove
the software and then reinstall it as described in Some of the
icons are missing in the HP Director on page 140.
I received a message If you receive an unknown error message, try to continue with the
installation. If that doesn’t work, discontinue the installation and try
that an unknown
to begin the installation again.
error has occurred
user guide
139
troubleshooting
problem
troubleshooting
chapter 13
problem
possible cause and solution
Some of the icons
are missing in the
HP Director
If the essential icons (scan picture, scan document, send fax, and
hp image zone) do not appear, your installation might not be
complete.
If your installation is incomplete, you might need to uninstall and then
reinstall the software. Do not simply delete the HP Officejet program
files from your hard drive. Be sure to remove them properly using the
uninstall utility provided in the HP Officejet program group.
to uninstall from a Windows computer
1
Disconnect your HP Officejet from your computer.
2
On the Windows task bar, click Start, Programs or All
Programs (XP), Hewlett-Packard, hp officejet 4200 series,
uninstall software.
3
Follow the directions on the screen.
4
If you are asked whether you would like to remove shared files,
click No.
Other programs that use these files might not work properly if
the files are deleted.
5
After the program finishes removing the software, disconnect
your HP Officejet, and restart your computer.
Note: It is important that you disconnect your HP Officejet
before restarting your computer.
140
6
To reinstall the software, insert the HP Officejet 4200 Series
CD-ROM into your computer’s CD-ROM drive, and follow the
instructions that appear on the screen
7
After the software is installed, connect the HP Officejet to your
computer. Turn on the HP Officejet using the On button. To
continue with the installation, follow the onscreen instructions
and the instructions provided in the Setup Poster that came with
your HP Officejet.
After connecting and turning on your HP Officejet, you might
have to wait several minutes for all of the Plug and Play events
to complete.
When the software installation is complete, you will see a
Status Monitor icon in the System Tray.
8
To verify that the software is properly installed, double-click the
HP Director icon on the desktop. If the HP Director shows the
key icons (scan picture, scan document, send fax, and
hp image zone), the software has been properly installed.
hp officejet 4200 series
troubleshooting information
possible cause and solution
Some of the icons
are missing in the
hp director
(continued)
to uninstall from a Macintosh computer
1
Disconnect the HP Officejet from your Macintosh.
2
Double-click the Applications:HP All-in-One Software folder.
3
Double-click HP Uninstaller.
4
Follow the onscreen instructions.
5
After the software is uninstalled, disconnect your HP Officejet,
and restart your computer.
6
To reinstall the software, insert the HP Officejet 4200 Series
CD-ROM into your computer’s CD-ROM drive.
Note: When reinstalling the software, follow the instructions in
the Setup Poster. Do not connect the HP Officejet to your
computer until after you have completed the software
installation.
7
On the desktop, open the CD-ROM, double-click hp all-in-one
installer, and follow the instructions that appear.
The fax wizard does If the fax wizard does not start automatically, launch the fax wizard
as follows:
not start
1 Start HP Director in the Hewlett-Packard folder on the Windows
Start menu.
2
Click the Settings menu, and select Fax Settings and Setup and
then Fax Setup Wizard.
The registration
screen does not
appear
If you wish to register your HP Officejet but the registration wizard
does not automatically appear, launch the Product Registration
program in the HP folder on the Windows Start menu.
The Digital Imaging
Monitor does not
appear in the Task
Tray
If the Digital Imaging Monitor does not appear in the Task Tray, wait
several minutes. If it still doesn’t appear, click HP Director to check
whether or not essential icons are there. For more information, see
Some of the icons are missing in the HP Director on page 140.
The Task Tray normally appears in the lower-right corner of the
Windows desktop.
Task Tray
HP Digital
Imaging Monitor
icon
user guide
141
troubleshooting
problem
chapter 13
troubleshooting
hardware installation troubleshooting
Use this section to solve any problems you might encounter while installing the
HP Officejet hardware.
142
problem
possible cause and solution
I received a message
on the front panel
display to attach the
front panel cover
This might mean the front panel cover is not attached, or it is
attached incorrectly. Make sure that you attach the cover as
described below and that it is firmly in place.
1
Insert the front-panel cover tabs into the slots on the top of the
device.
2
Snap the front-panel cover down firmly on both front corners.
Make sure it is even with the device.
3
Make sure all the buttons can move freely.
hp officejet 4200 series
troubleshooting information
possible cause and solution
The front panel
displays the wrong
language
The HP Officejet has been set up with the incorrect language or
country/region. Usually, you set the language and country/region
when you first set up the HP Officejet. However, you can change
these settings at any time by using the following procedure:
I received a message
on the front panel
display to align the
print cartridges
user guide
1
Press Setup.
2
Press 6, then press 3.
This selects Preferences and then selects Set Language &
Country/Region.
After starting the routine, the following prompt is presented on
the front panel display:
Press 11 for English?
If you want to change the language to English, enter 11 using
the keypad, or you can also scroll through the languages
using " or !. Otherwise, wait for five seconds and the
display changes automatically to the next available
language. When you see the language you want, enter its
two-digit number using the keypad.
3
When prompted to confirm the language, press 1 for Yes or 2
for No.
You are prompted with all the countries/regions for the
selected language. You can also scroll through the countries/
regions using " or !.
4
Using the keypad, enter the two-digit number for the desired
country/region.
5
When prompted, press 1 for Yes or 2 for No.
6
You can confirm the language and country/region by
printing a Self-Test Report, as follows:
a. Press Setup.
b. Press 1, then press 5.
This selects Print Report, and then selects Self-Test Report.
The HP Officejet prompts you to align cartridges every time you
install a new print cartridge. For more information, see align the
print cartridges on page 86.
143
troubleshooting
problem
chapter 13
troubleshooting
problem
possible cause and solution
My HP Officejet does •
not power on
The HP Officejet may not be properly connected to a power
supply.
–
•
•
Make sure the connection from the power outlet to the
HP Officejet is firmly connected. Plug the power cord into
a grounded power outlet, surge protector, or power
strip.and wait a few seconds for the HP Officejet to power
on
– If the HP Officejet is plugged in to a power strip, make
sure the strip is turned on.
– Test the power outlet to make sure it is working.
– If you plugged the HP Officejet into a switched outlet,
make sure the switch is on.
The HP Officejet might not respond if you press the On button
too quickly. Press the On button once slowly.
If the HP Officejet still does not turn on, it might have a
mechanical failure. Unplug the HP Officejet from the power
outlet and contact HP.
The HP Officejet does First check to see whether the print cartridge is out of ink. To do this,
not print satisfactorily see print a self-test report on page 80.
However, before you do this, check the print cartridge to make sure
you have properly removed its packaging. Being careful not to touch
the gold-colored contacts or ink nozzles, make sure you have gently
pulled the pink tab to remove the plastic tape.
If you determine that you need to replace a print cartridge see
replace the print cartridges on page 82.
I received a message
on the front panel
display about a paper
jam or a blocked
carriage
144
If either a paper jam or blocked carriage error message appears
in the front panel display there might be some packing material
inside the HP Officejet. Lift open the print-carriage access door to
expose the print cartridges and remove any packing material or
other items that do not belong there.
hp officejet 4200 series
troubleshooting information
possible cause and solution
My USB cable is not
connected
Connecting your computer to your HP Officejet with a USB cable is
straightforward. Simply plug one end of the USB cable into the
back of your computer and the other in the back of the
HP Officejet. You can connect to any USB port on the back of your
computer.
additional installation troubleshooting help
You might want to refer to the Read Me file for more information on possible
installation problems. In Windows, you can access the Read Me file from the
Start button on the taskbar; select Programs, Hewlett-Packard, HP Officejet
4200 Series, View the Readme File. In Macintosh OS 9 or OS X, you can access
the readme file by double-clicking the icon located in the top-level folder of the
HP Officejet software CD-ROM.
The readme file provides more information, including:
•
Using the Re-install utility after a failed installation to return your computer
to a state that will allow the HP Officejet to be re-installed.
•
Using the Re-install utility in Windows 98 to recover from a Composite USB
System Driver missing.
This error might occur if the hardware is installed prior to installing the
software. After running the Re-install utility, reboot your PC, and install the
HP Officejet software before connecting the HP Officejet to your computer.
You can also find more information on the HP website at:
www.hp.com/support
user guide
145
troubleshooting
problem
chapter 13
troubleshooting
fax setup troubleshooting
Use this section to solve any problems you might encounter while setting up your
HP Officejet for faxing.
For information about how to set up your HP Officejet for faxing, see fax setup
on page 131.
For more information on solving problems you could have while faxing with your
HP Officejet, see the hp officejet 4200 series troubleshooting section in the
onscreen hp image zone help that came with your software.
problem
possible cause and solution
I have difficulties
when sending faxes
and when receiving
faxes
•
Make sure you connected the HP Officejet from the port labeled
“1-LINE” to your telephone wall jack using the phone cord supplied
in the box with your HP Officejet.* This special 2-wire cord is
different from the more common 4-wire cords you might already
have in your office. Check the end of the cord and compare it to the
two types of cords shown below:
2-wire cord
End view of the 2-wire phone cord
supplied in the box with your
HP Officejet
4-wire cord
End view of a 4-wire phone cord that
will probably cause faxing problems if
connected directly to your HP Officejet
* This possible cause/solution applies only in the countries/regions that
receive a 2-wire phone cord in the box with the HP Officejet, including:
Argentina, Australia, Brazil, Canada, Chile, China, Colombia, Greece,
India, Indonesia, Ireland, Japan, Korea, Latin America, Malaysia, Mexico,
Philippines, Poland, Portugal, Russia, Saudi Arabia, Singapore, Spain,
Taiwan, Thailand, USA, Venezuela, and Vietnam.
If you used a 4-wire cord, disconnect it, find the supplied 2-wire
cord, and then connect the 2-wire cord to the HP Officejet (at the
port labeled “1-LINE”).
Note: If the 2-wire cord is not long enough and you need to extend
it, you might want to purchase an in-line coupler and use a 4-wire
cord to increase the length. The type of coupler you would need
allows you to connect a 2-wire cord at one end, and a 4-wire cord
at the other. Attach the 2-wire cord from the “1-LINE” port of the
HP Officejet to one side of the coupler; then attach a 4-wire cord
from the opposite side of the coupler to the telephone wall jack.
146
hp officejet 4200 series
troubleshooting information
possible cause and solution
I have difficulties
when sending faxes
and when receiving
faxes
(continued)
•
Make sure you have correctly connected the HP Officejet to the
telephone wall jack, and correctly connected any additional
equipment and services that share the phone line with your
HP Officejet.
•
Using a telephone line splitter can cause faxing problems. (A
splitter is two-cord connector that plugs into a wall jack.) Try
removing the splitter and connecting the HP Officejet directly to the
telephone wall jack.
•
Check that the telephone wall jack has a working telephone line by
plugging in a phone and checking for a dial tone.
•
Telephone lines with poor sound quality (noise) can cause faxing
problems. Check the sound quality of the telephone line by
plugging a phone into the wall jack and listening for static or other
noise. If you hear noise, turn off the Error Correction Mode (ECM)
feature on your HP Officejet and try faxing again. For information,
see use error correction mode on page 65. Also contact your
phone company to report the noise problem on your line.
•
Other equipment using the same telephone line as the HP Officejet
might be in use. For example, you cannot use your HP Officejet for
faxing if an extension phone is off-hook, or if you are using your PC
modem to e-mail or access the Internet.
•
If you are using a digital subscriber line (DSL), make sure that you
have a DSL filter connected or you will not be able to fax
successfully. Obtain a DSL filter from your DSL provider. The DSL
filter removes the digital signal that blocks your HP Officejet from
communicating properly with the telephone line.
•
•
For information on how to connect the DSL filter, see faxing from a
DSL line on page 131.
Check for error messages on the front panel display of your
HP Officejet. Until a product error condition is resolved, you will not
be able to send or receive faxes. For information on resolving error
conditions, see the hp officejet 4200 series troubleshooting section
in the onscreen hp image zone help that came with your software.
If you are using either a PBX or an ISDN converter, make sure the
HP Officejet is connected to the port that is designated for fax and
phone use.
Note that some ISDN systems allow you to configure the ports for
specific phone equipment—for example, you might have assigned
one for telephone and Group 3 fax and another for multiple
purposes. If you continue to have problems when connected to the
fax/phone port, try using the port designated for multiple purposes
(might be labeled “multi-combi” or something similar).
user guide
147
troubleshooting
problem
troubleshooting
chapter 13
problem
possible cause and solution
I cannot receive faxes, •
but I can send faxes
•
The Rings to Answer feature might not be set to answer after the
appropriate number of rings for your office setup.
If you have a voice mail service at the same phone number you use
for fax calls, you must receive faxes manually, not automatically. For
information on how to receive faxes manually, see receive a fax
manually from a phone on page 48.
•
If you have a PC modem on the same phone line with your
HP Officejet, check to make sure that the modem’s software is not
set to receive faxes automatically. Modems with this auto fax
receive feature turned on will take over the phone line to receive all
incoming faxes, which will prevent the HP Officejet from receiving
fax calls.
•
If you have an answering machine on the same phone line with
your HP Officejet, you might have one of the following problems:
–
•
Your outgoing message might be too long or too loud to allow
the HP Officejet to detect fax tones, and the calling fax machine
might disconnect.
– Your answering machine might not have enough quiet time after
your outgoing message to allow the HP Officejet to detect fax
tones. This problem is more common with digital answering
machines.
The following actions might help solve these problems:
a. Disconnect the answering machine and then try receiving a fax.
If faxing is successful without it, the answering machine might
be causing the problem.
b. Reconnect the answering machine and re-record your outgoing
message. Make sure the message is as short as possible (no
more than 10 seconds long), and that you speak softly and
slowly when recording it. Try again to receive a fax.
If you have a special ring pattern for your fax phone number (using
a distinctive ring service through your telephone company), make
sure that the Answer Ring Pattern feature on your HP Officejet is set
to match. For example, if the phone company has assigned your
fax number a double ring pattern, make sure Double Rings is
selected as the Answer Ring Pattern setting. For information on
changing this setting, see change the answer ring pattern
(distinctive ringing) on page 63.
Note that some ring patterns cannot be recognized by the
HP Officejet, such as those with alternating short and long ringing
patterns. If you are having problems with a ring pattern of this type,
ask your phone company to assign a non-alternating ring pattern.
148
hp officejet 4200 series
troubleshooting information
possible cause and solution
I cannot receive faxes, •
but I can send faxes
(continued)
•
If you are not using a distinctive ring service, check to make sure
that the Answer Ring Pattern feature on your HP Officejet is set to
All Rings. For information, see change the answer ring pattern
(distinctive ringing) on page 63.
If your HP Officejet shares the same phone line with other types of
phone equipment—such as an answering machine or a PC
modem—the fax signal level could be reduced, causing fax
reception problems.
To find out if other equipment is causing a problem, disconnect
everything except the HP Officejet from the phone line, and then try
to receive a fax. If fax reception is successful without the equipment,
then one or more pieces of the equipment is causing problems; try
adding them back one at a time and faxing, until you identify
which equipment is causing the problem.
I cannot send faxes, •
but I can receive faxes
If you are using speed dial to dial the fax number, the HP Officejet
might be dialing too fast or too soon. To solve this problem, try one
of the following:
–
•
Try manually dialing the fax number from the HP Officejet front
panel, or from an attached phone. For information, see send a
fax using monitor dialing on page 43 or send a fax manually
from a telephone on page 43.
– Re-create the speed dial setting and insert some pauses. For
information, see create individual speed-dial entries on
page 56.
If your telephone line has a PBX system, make sure you are dialing
the number for an outside line before dialing the fax number.
•
The receiving fax machine might be having problems. To check this,
try calling the fax number from a telephone and listen for fax tones.
If you cannot hear fax tones, the receiving fax might not be turned
on or connected, or a voice mail service could be interfering with
the recipient’s phone line.
•
I hear static on my
telephone line ever
since I connected the
HP Officejet
If you did not connect the HP Officejet from the port labeled “1LINE” to your telephone wall jack using the phone cord supplied in
the box with your HP Officejet, you could hear static on your phone
line and you probably will not be able to fax successfully.* This
special 2-wire cord is different from the more common 4-wire cords
you might already have in your office. For more information, see I
have difficulties when sending faxes and when receiving faxes on
page 146.
I hear static on my
telephone line ever
since I connected the
HP Officejet
(continued)
* This possible cause/solution applies only in the countries/regions that
receive a 2-wire phone cord in the box with the HP Officejet, including:
Argentina, Australia, Brazil, Canada, Chile, China, Colombia, Greece,
India, Indonesia, Ireland, Japan, Korea, Latin America, Malaysia, Mexico,
Philippines, Poland, Portugal, Russia, Saudi Arabia, Singapore, Spain,
Taiwan, Thailand, USA, Venezuela, and Vietnam.
•
user guide
Using a telephone line splitter could affect the sound quality of your
phone line, causing static. Try removing the splitter and connecting
the HP Officejet directly to the telephone wall jack.
149
troubleshooting
problem
troubleshooting
chapter 13
operational troubleshooting
The hp officejet 4200 series troubleshooting section in the hp image zone help
contains troubleshooting tips for some of the most common issues associated with
your HP Officejet.
To access the troubleshooting information from a Windows computer, go to the
HP Director, click Help, and then choose Troubleshooting and Support.
Troubleshooting is also available through the Help button that appears on some
error messages.
To access troubleshooting information from the Macintosh (OS X), click the
HP Director icon in the Dock, select HP Help from the HP Director menu, select
hp image zone help, and then click hp officejet 4200 series troubleshooting in
the Help Viewer.
To access troubleshooting information from Macintosh OS 9, click the
HP Director icon on the desktop, go to the Help menu and choose hp image zone
help. Click hp officejet 4200 troubleshoot.
If you have Internet access, you can get help from the HP website at:
www.hp.com/support
The website also provides answers to frequently asked questions.
150
hp officejet 4200 series
index
exterior, 79
glass, 77
print cartridge contacts, 88
print cartridges, 88
white strip on scanner lid,
Numerics
4 by 6 inch (10 by 15 cm)
borderless photos
fit to page, 30
load paper, 20
78
A
align ink cartridge, 143
align print cartridge, 86, 143
answer call waiting calls, 50
answer mode, 44
answering machine
set up with voice/fax line,
130
set up with voice/fax/PC
modem line, 131
attaching the front panel, 142
attaching the USB cable, 145
automatic document feeder, 4
paper capacity, 104
automatic fax reports, 53
B
baud rate, 65
best
copy setting, 28
block numbers, 66
blocked carriage, 144
C
call waiting, 50
caller ID, 66
cancel
copy, 34
fax, 68
print, 74
scan, 36
scheduled fax, 42
cartridges
align, 86
check ink level, 79
clean, 88
clean contacts, 88
handle, 82
order, 75
replace, 82
self-test report, 80
CD-ROM, 138
clean
color
enhance photos, 34
faxes, 39
intensity, 32
contrast, fax, 58
copy, 27
black and white, 29
cancel, 34
default settings, 28
enlarge, 30
fit to page, 30
legal to letter, 32
number of copies, 30
paper size, 24
paper type, 23, 24
photos, enhance, 34
quality, 28
reduce, 32
speed, 28
text, enhance, 33
washed out original, 32
country setup, 143
customer support, 93
Australia, 96
contact, 93
North America, 94
outside U.S., 94
warranty, 99
website, 93
D
darken
copies, 32
faxes, 59
photos, 34
date, set, 60
declaration of conformity
(European Union), 112
(U.S.), 114, 115
default settings
copy, 28
fax, 59
print, 72
restore factory defaults, 90
digital imaging monitor, 141
distinctive ringing, 63
E
empty print cartridge, 144
envelopes
load, 20
environment
energy consumption, 107
environmental product
stewardship program,
106
inkjet supplies recycling,
108
material safety data sheets,
107
ozone production, 106
paper use, 107
plastics, 107
protecting, 106
recycling program, 108
environmental specifications,
106
error correction mode (ECM),
65
essential icons, 139
essential icons missing, 140
F
factory defaults, restore, 90
fast copy setting, 28
fax, 37, 89
answer calls with handset,
50
answer ring pattern, 63
automatically receive, 44
block junk fax numbers, 66
busy, 63
caller ID, 66
cancel, 68
cancel forward, 62
cancel scheduled, 42
confirm, 38
contrast, 58
date and time, 60
defaults, 59
151
index
distinctive ringing, 63
enter text, 52
error correction mode
(ECM), 65
fax specifications, 105
fax speed, 65
forward, 62
header, 51
lighten or darken, 59
manually receive, 44
monitor dialing, 43
paper size, 24, 61
pause, 52
photos, 39
poll to receive, 49
problems sending and/or
receiving faxes, 146, 147,
148, 149
problems with static on the
phone line, 149
pulse dial, 61
receive, 47
receive manually, 48, 49
receive manually from a
front panel, 48
receive manually from a
phone, 48
receive manually from
handset, 49, 50
redial busy or unanswered
numbers, 63
reduce automatically, 64
reports, 53
reprint, 68
resolution, 58
rings to answer, 47
schedule, 41
send, 38
send a color fax, 39
send basic fax, 39
send fax using redial, 41
send from memory, 42
send manually, 43
send manually from a
phone, 43
send manually from handset,
43, 50
set answer mode, 44
set up distinctive ring line,
124
set up DSL line, 118
set up office equipment, 119
set up separate fax line, 123
set up shared voice/fax line,
125
152
set up with fax/PC modem
line, 126
set up with voice/fax/
answering machine line,
130
set up with voice/fax/PC
modem line, 128
set up with voice/fax/PC
modem/answering
machine line, 131
set up with voice/fax/PC
modem/voice mail line,
134
set up with voice/fax/voice
mail line, 133
setup, 117
setup ISDN line, 119
setup PBX system, 119
speed dial, 40
speed-dial entries, add, 56
speed-dial entries, delete,
57
speed-dial entries, update,
57
symbols, 52
tone dial, 61
unanswered, 63
volume, 61, 62
fax setup
troubleshooting, 146
fax wizard does not start, 141
FCC requirements, 109
FCC statement, 110
fit to page, 30
forward faxes
cancel, 62
set up, 62
front panel, 4
enter text, 52
menus, 8
overview, 5
prompt delay, 91
scroll speed, 90
front panel display, 142
set language, 143
G
glass, clean, 77
greeting cards, 22
group speed dial entries, 56
H
handset
call waiting, 50
receive a fax, 49
send a fax, 43
use, 50
help, 1
HP customer support, 93
HP Director, 3
HP Officejet
front panel, 5
maintain, 77
menus, 8
office setup, 119
overview, 3
parts, 4
prepare to ship, 96
return, 100
I
icons missing, 140
individual speed dial entries,
56
ink
check level, 79
ink cartridge, 143
ink cartridge empty, 144
ink cartridges. see print
cartridges
installation fails, 139
installation incomplete, 140
installing software, 138
J
junk fax number, 66
K
keypad, enter text, 52
L
labels
load, 22
language setup, 143
lighten
faxes, 59
load
envelopes, 20
paper, 19
photo paper, 20
M
maintenance, 77
align print cartridges, 86
check ink level, 79
clean exterior, 79
clean glass, 77
clean print cartridge
contacts, 88
clean print cartridges, 88
hp officejet 4200 series
index
clean scanner lid white strip,
78
replace print cartridges, 82
restore factory defaults, 90
self-maintenance sounds, 92
self-test report, 80
set scroll speed, 90
manual fax reports, 54
memory
reprint faxes, 68
menu overview, 8
minimum system requirements,
139
modem. See PC modem
monitor dialing, 43
N
normal copy setting, 28
number of copies
copy, 30
O
order
media, 75
other supplies, 75
print cartridges, 75
P
page setup dialog box, 72
paper
avoid jams, 25
legal to letter copy, 32
load, 15
load in input tray, 19
load originals, 25
load other types, 22
load photo, 20
order, 75
paper sizes, 104
papers to avoid, 18
recommended, 17
recommended copy types,
23
size, set for copy, 24
size, set for fax, 61
type, set, 24
paper jam, 144
paper specifications, 103
paper-tray capacities, 103
PC modem
set up with fax line, 126
set up with voice/fax line,
128
set up with voice/fax/
answering machine line,
131
user guide
phone numbers, customer
support, 93
photo paper
load, 20
photos
enhance copies, 34
fax, 39
fit to page, 30
physical specifications, 106
poll to receive fax, 49
power specifications, 106
powering on, 144
print, 71
cancel, 74
change current settings, 73
change default settings, 72
fax reports, 53
faxes in memory, 68
from software, 71, 72
self-test report, 80
print cartridge, 143
print cartridge empty, 144
print cartridges
align, 86
check ink level, 79
clean, 88
clean contacts, 88
handle, 82
order, 75
replace, 82
self-test report, 80
print dialog box
copies & pages panel, 73
layout panel, 73
output options panel, 74
paper type/quality panel,
74
print margin specifications,
105
print settings, 72
printing error, 144
printing, unsatisfactory, 144
prompt delay, set, 91
pulse dial, 61
Q
quality
copy, 28
R
receive faxes, 47, 48
red X on USB screen, 139
redial fax, 41, 63
reduce faxes to fit, 64
reduce/enlarge copies
fit to page, 30
resize to fit letter, 32
registration screen does not
appear, 141
regulatory notices, 109
Canadian statement, 110
declaration of conformity
(European Union), 112
declaration of conformity
(U.S.), 114, 115
European Economic Area,
112
FCC requirements, 109
FCC statement, 110
German statement, 112
Korea statement, 113
notice to users in Canada,
111
regulatory model
identification number, 109
reinstalling on a Macintosh,
141
reinstalling software, 140
replace print cartridges, 82
replace telephone cord, 89
replacing, 89
reports
fax, automatic, 53
fax, manual, 54
self-test, 80
reprint faxes in memory, 68
resolution, 58
fax, 58
restore factory defaults, 90
return your HP Officejet, 100
ring, answer pattern, 63
rings to answer fax, 47
S
scan, 35
cancel, 36
from front panel, 36
high resolution, 35
scan specifications, 105
scanner lid white strip, clean,
78
scroll speed, 90
self-test report, 80
send fax later, 41
send faxes, 38
set
language and country, 143
settings
answer mode, 44
country and language, 143
153
index
fax speed, 65
setup
fax, 117
setup, fax, 117
ship your HP Officejet, 96
software, 138
print from, 71
sounds, adjust fax, 61, 62
sounds, self-maintenance, 92
speed
copy, 28
front panel prompt delay, 91
front panel scroll, 90
speed dial entries
add, 56
delete, 57
overview, 55
send fax with speed dials,
40
update, 57
stop
copy, 34
fax, 68
print, 74
scan, 36
scheduled fax, 42
subscriber identification code,
51
support services, 93
154
symbols, 52
hardware and software
installation, 137
hardware installation, 142
installation, 137
operations, 150
software installation, 138
T
technical information
automatic document feeder
paper capacity, 104
environmental
specifications, 106
fax specifications, 105
paper sizes, 104
paper specifications, 103
paper-tray capacities, 103
physical specifications, 106
power specifications, 106
print margin specifications,
105
scan specifications, 105
telephone cord, 89
telephone line with multiple
numbers, 63
telephone numbers, customer
support, 93
text
enhance on copies, 33
enter on keypad, 52
time, set, 60
tone dial, 61
troubleshooting
fax setup, 146
U
uninstalling from a Macintosh,
141
unknown error message, 139
USB cable, 139, 145
USB cable installation, 145
V
voice mail
set up with voice/fax line,
133
set up with voice/fax/PC
modem line, 134
volume, adjust fax, 61, 62
W
warranty, 99
duration, 99
express, 99
service, 99
statement, 100
upgrades, 99
hp officejet 4200 series
Visit the hp officejet information center
It has everything you need to get the most value from your HP Officejet.
•
Technical Support
•
Supplies and Ordering Information
•
Project Tips
•
Ways to Enhance Your Product
www.hp.com/support
© 2004 Hewlett-Packard Development Company, L.P.
Printed on recycled paper.
Printed in [country].
*Q5600-90113*
*Q5600-90113*
Q5600-90113
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
