Dodge | 2014 Durango | Owner`s manual | Dodge 2014 Durango Owner`s manual

Dodge 2014 Durango Owner`s manual
Download a FREE electronic copy of the
Owner’s Manual or Warranty Booklet
by visiting the Owners tab at:
www.dodge.com (U.S.)
www.dodge.ca (Canada)
> 2014 durango // User Guide
14WD01-926-AA
durango
First Edition
User Guide
1419955_14a_Durango_UG_062713.indd 1
6/27/13 10:23 AM
dodge.com
This guide has been prepared to help you get quickly acquainted with your new Dodge and to
provide a convenient reference source for common questions. However, it is not a substitute for
your Owner’s Manual.
For complete operational instructions, maintenance procedures and important safety messages,
please consult your Owner’s Manual, Navigation/Uconnect® Manuals and other Warning Labels in
your vehicle.
Not all features shown in this guide may apply to your vehicle. For additional information on
accessories to help personalize your vehicle, visit www.mopar.com (U.S), www.mopar.ca (Canada)
or your local Dodge dealer.
> IMPORTANT
This User Guide is intended to familiarize you with the important features of your vehicle.
The DVD enclosed contains your Owner’s Manual, Navigation/Uconnect® Manuals, Warranty
Booklets, Tire Warranty and Roadside Assistance (new vehicles purchased in the U.S.) or
Roadside Assistance (new vehicles purchased in Canada) in electronic format. We hope you
find it useful. Replacement DVD kits may be purchased by visiting www.techauthority.com.
Copyright 2013 Chrysler Group LLC.
If you are the first registered retail owner of your vehicle, you
may obtain a complimentary printed copy of the Owner’s
Manual, Navigation/Uconnect® Manuals or Warranty Booklet
by calling 1-800-423-6343 (U.S.) or 1-800-387-1143 (Canada)
or by contacting your dealer.
The driver’s primary responsibility is the safe operation of the vehicle. Driving while
distracted can result in loss of vehicle control, resulting in a collision and personal injury.
Chrysler Group LLC strongly recommends that the driver use extreme caution when using any
device or feature that may take their attention off the road. Use of any electrical devices such
as cell phones, computers, portable radios, vehicle navigation or other devices by the driver
while the vehicle is moving is dangerous and could lead to a serious collision. Texting while
driving is also dangerous and should never be done while the vehicle is moving. If you find
yourself unable to devote your full attention to vehicle operation, pull off the road to a safe
location and stop your vehicle. Some States or Provinces prohibit the use of cellular telephones
or texting while driving. It is always the driver’s responsibility to comply with all local laws.
1419955_14a_Durango_UG_062713.indd 2
Driving and alcohol
Drunken driving is one of the most frequent causes of accidents. Your driving ability can be
seriously impaired with blood alcohol levels far below the legal minimum. If you are drinking, don’t
drive. Ride with a designated non-drinking driver, call a cab, a friend, or use public transportation.
WARNING!
Driving after drinking can lead to an accident. Your perceptions are less sharp, your reflexes are
slower, and your judgment is impaired when you have been drinking. Never drink and then drive.
6/27/13 10:23 AM
TABLE OF CONTENTS
WELCOME FROM CHRYSLER GROUP LLC . . . 2
POWER INVERTER . . . . . . . . . . . . . . 113
POWER OUTLET . . . . . . . . . . . . . . . . 114
CONTROLS AT A GLANCE
OFF-ROAD CAPABILITIES
DRIVER COCKPIT . . . . . . . . . . . . . . . . 6
INSTRUMENT CLUSTER . . . . . . . . . . . . . 8
ALL-WHEEL DRIVE OPERATION
GETTING STARTED
ROOF LUGGAGE RACK . . . . . . . . . . . . 119
TRAILER TOWING WEIGHTS (MAXIMUM
TRAILER WEIGHT RATINGS) . . . . . . . . . 120
RECREATIONAL TOWING (BEHIND
MOTORHOME, ETC.) . . . . . . . . . . . . . . 121
INTRODUCTION/WELCOME
KEY FOB . . . . . . . . . . . . . . . . . . . . 10
REMOTE START . . . . . . . . . . . . . . . . . 10
KEYLESS ENTER-N-GO™ . . . . . . . . . . . . 11
THEFT ALARM . . . . . . . . . . . . . . . . . 14
SEAT BELT . . . . . . . . . . . . . . . . . . . 14
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) —
AIR BAGS . . . . . . . . . . . . . . . . . . . . 15
CHILD RESTRAINTS . . . . . . . . . . . . . . 16
FRONT SEATS . . . . . . . . . . . . . . . . . 20
REAR SEATS . . . . . . . . . . . . . . . . . . 23
POWER FOLDING THIRD ROW HEAD
RESTRAINTS . . . . . . . . . . . . . . . . . . 25
HEATED/VENTILATED SEATS . . . . . . . . . 26
HEATED STEERING WHEEL . . . . . . . . . . 28
TILT/TELESCOPING STEERING COLUMN . . . 28
OPERATING YOUR VEHICLE
ENGINE BREAK-IN RECOMMENDATIONS . . . 30
HEADLIGHT SWITCH . . . . . . . . . . . . . . 30
TURN SIGNAL/WIPER/WASHER/HIGH BEAM
LEVER . . . . . . . . . . . . . . . . . . . . . . 31
AUTOMATIC DIMMING MIRRORS . . . . . . . 32
SPEED CONTROL . . . . . . . . . . . . . . . . 33
ADAPTIVE CRUISE CONTROL (ACC) . . . . . . 34
ELECTRONIC SHIFTER . . . . . . . . . . . . . 38
AUTOSTICK® . . . . . . . . . . . . . . . . . . 38
FUEL ECONOMY (ECO) MODE . . . . . . . . . 39
AUTOMATIC CLIMATE CONTROLS WITH
TOUCHSCREEN . . . . . . . . . . . . . . . . . 40
PARKSENSE® REAR PARK ASSIST . . . . . . 42
PARKVIEW® REAR BACK-UP CAMERA . . . . 43
BLIND SPOT MONITORING . . . . . . . . . . . 43
POWER SUNROOF . . . . . . . . . . . . . . . 44
WIND BUFFETING . . . . . . . . . . . . . . . 45
ELECTRONICS
YOUR VEHICLE'S SOUND SYSTEM . . . . . . 46
IDENTIFYING YOUR RADIO . . . . . . . . . . . 48
Uconnect® Access (AVAILABLE ON Uconnect®
8.4A AND Uconnect® 8.4AN) (IF EQUIPPED) . . . 49
Uconnect® 5.0 . . . . . . . . . . . . . . . . . 65
Uconnect® 8.4A . . . . . . . . . . . . . . . . . 72
Uconnect® 8.4AN . . . . . . . . . . . . . . . 90
STEERING WHEEL AUDIO CONTROLS . . . . 108
ELECTRONIC VEHICLE INFORMATION
CENTER (EVIC) . . . . . . . . . . . . . . . . 109
PROGRAMMABLE FEATURES . . . . . . . . . 110
UNIVERSAL GARAGE DOOR OPENER
(HomeLink®) . . . . . . . . . . . . . . . . . . 111
. . . . . . . 116
UTILITY
WHAT TO DO IN EMERGENCIES
ROADSIDE ASSISTANCE . . . . . . . . . . . 125
INSTRUMENT CLUSTER WARNING LIGHTS . . . 125
IF YOUR ENGINE OVERHEATS . . . . . . . . 130
JACKING AND TIRE CHANGING . . . . . . . 131
BATTERY LOCATION . . . . . . . . . . . . . . 142
JUMP-STARTING . . . . . . . . . . . . . . . 142
MANUAL PARK RELEASE 8–SPEED . . . . . 145
TOWING A DISABLED VEHICLE . . . . . . . 146
FREEING A STUCK VEHICLE . . . . . . . . . 147
EVENT DATA RECORDER (EDR) . . . . . . . . 148
CAP-LESS FUEL FILL FUNNEL . . . . . . . . 148
MAINTAINING YOUR VEHICLE
OPENING THE HOOD . . . . . . . . . . . . . 149
ADDING FUEL . . . . . . . . . . . . . . . . . 150
ENGINE COMPARTMENT . . . . . . . . . . . 152
FLUIDS AND CAPACITIES . . . . . . . . . . . 154
MAINTENANCE SCHEDULE — GASOLINE
ENGINE . . . . . . . . . . . . . . . . . . . . 156
MAINTENANCE RECORD . . . . . . . . . . . 160
FUSES . . . . . . . . . . . . . . . . . . . . . 161
TIRE PRESSURES . . . . . . . . . . . . . . . 164
WHEEL AND WHEEL TRIM CARE . . . . . . 164
EXTERIOR BULBS . . . . . . . . . . . . . . 165
CUSTOMER ASSISTANCE
CHRYSLER GROUP LLC CUSTOMER
CENTER . . . . . . . . . . . . . . . .
CHRYSLER CANADA INC. CUSTOMER
CENTER . . . . . . . . . . . . . . . .
ASSISTANCE FOR THE HEARING
IMPAIRED . . . . . . . . . . . . . . .
PUBLICATIONS ORDERING . . . . . .
REPORTING SAFETY DEFECTS IN THE
UNITED STATES . . . . . . . . . . . .
. . . . 166
. . . . 166
. . . . 166
. . . . 166
. . . . 167
MOPAR ACCESSORIES
AUTHENTIC ACCESSORIES BY MOPAR®
. . 168
INDEX . . . . . . . . . . . . . . . . . . . . 169
FAQ (How To?)
FREQUENTLY ASKED QUESTIONS . . . . . . 172
INTRODUCTION/WELCOME
WELCOME FROM CHRYSLER GROUP LLC
Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it
represents precision workmanship, distinctive styling, and high quality - all essentials that
are traditional to our vehicles.
Your new Chrysler Group LLC vehicle has characteristics to enhance the driver's control
under some driving conditions. These are to assist the driver and are never a substitute for
attentive driving. They can never take the driver's place. Always drive carefully.
Your new vehicle has many features for the comfort and convenience of you and your
passengers. Some of these should not be used when driving because they take your eyes
from the road or your attention from driving. Never text while driving or take your eyes more
than momentarily off the road.
This guide illustrates and describes the operation of features and equipment that are either
standard or optional on this vehicle. This guide may also include a description of features
and equipment that are no longer available or were not ordered on this vehicle. Please
disregard any features and equipment described in this guide that are not available on this
vehicle. Chrysler Group LLC reserves the right to make changes in design and specifications and/or make additions to or improvements to its products without imposing any
obligation upon itself to install them on products previously manufactured.
This User Guide has been prepared to help you quickly become acquainted with the
important features of your vehicle. It contains most things you will need to operate and
maintain the vehicle, including emergency information.
The DVD includes a computer application containing detailed owner's information which
can be viewed on a personal computer or MAC computer. The multimedia DVD also includes
videos which can be played on any standard DVD player (including the Uconnect® TouchScreen Radios). Additional DVD operational information is located on the back of the DVD
sleeve.
For complete owner information, refer to your Owner's Manual on the DVD in the owner’s
kit provided at the time of new vehicle purchase. For your convenience, the information
contained on the DVD may also be printed and saved for future reference.
Chrysler Group LLC is committed to protecting our environment and natural resources. By
converting from paper to electronic delivery for the majority of the user information for your
vehicle, together we greatly reduce the demand for tree-based products and lessen the
stress on our environment.
2
INTRODUCTION/WELCOME
VEHICLES SOLD IN CANADA
With respect to any vehicles sold in Canada, the name Chrysler Group LLC shall be deemed
to be deleted and the name Chrysler Canada Inc. used in substitution.
WARNING!
•
•
•
•
•
Pedals that cannot move freely can cause loss of vehicle control and increase the
risk of serious personal injury.
Always make sure that objects cannot fall into the driver foot well while the vehicle is
moving. Objects can become trapped under the brake pedal and accelerator pedal
causing a loss of vehicle control.
Failure to properly follow floor mat installation or mounting can cause interference
with the brake pedal and accelerator pedal operation causing loss of control of the
vehicle.
Never use the ‘PARK’ position as a substitute for the parking brake. Always apply the
parking brake fully when parked to guard against vehicle movement and possible
injury or damage.
Refer to your Owner's Manual on the DVD for further details.
3
INTRODUCTION/WELCOME
Rollover Warning
WARNING!
•
•
•
•
•
4
Pedals that cannot move freely can cause loss of vehicle control and increase the
risk of serious personal injury.
Always make sure that objects cannot fall into the driver foot well while the vehicle is
moving. Objects can become trapped under the brake pedal and accelerator pedal
causing a loss of vehicle control.
Failure to properly follow floor mat installation or mounting can cause interference
with the brake pedal and accelerator pedal operation causing loss of control of the
vehicle.
Refer to your Owner's Manual on the DVD for further details.
Never use the ‘PARK’ position as a substitute for the parking brake. Always apply the
parking brake fully when parked to guard against vehicle movement and possible
injury or damage.
INTRODUCTION/WELCOME
USE OF AFTERMARKET PRODUCTS (ELECTRONICS)
The use of aftermarket devices including cell phones, MP3 players, GPS systems, or
chargers may affect the performance of on-board wireless features including Keyless
Enter-N-Go™ and Remote Start range. If you are experiencing difficulties with any of your
wireless features, try disconnecting your aftermarket devices to see if the situation improves. If your symptoms persist, please see an authorized dealer.
CHRYSLER, DODGE, JEEP, RAM TRUCK, SRT, ATF+4, MOPAR and Uconnect are registered
trademarks of Chrysler Group LLC.
COPYRIGHT ©2013 CHRYSLER GROUP LLC
5
CONTROLS AT A GLANCE
DRIVER COCKPIT
1. Power Mirror Controls
2. Headlight Switch pg. 30
3. Turn Signal/Wiper/Washer/High Beams Lever (behind steering wheel) pg. 31
4. Instrument Cluster pg. 8
5. Electronic Vehicle Information Center (EVIC) Display pg. 109
6. Engine Start/Stop Button (behind steering wheel) pg. 13
7. Audio System (Touch-Screen Radio Shown) pg. 46
8. Power Window
9. Glove Compartment
10. Audio System Control Knob pg. 47
6
CONTROLS AT A GLANCE
11. SWITCH PANEL
13. Electronic Shifter pg. 38
• ParkSense® pg. 42
14. Front Power Outlet pg. 114
• ECO On pg. 39
15. Speed Control pg. 33
• Electronic Stability Control (ESC)
OFF pg. 147
16. EVIC Controls pg. 109
• Forward Collision Warning (FCW)
pg. 35
18. Instrument Panel Dimmer pg. 31
17. Parking Brake Release
19. Power Windows
12. Media Hub
20. Power Door Locks
• Audio Jack (AUX) pg. 67
• USB Port pg. 67
• SD Port pg. 67
7
CONTROLS AT A GLANCE
INSTRUMENT CLUSTER
1. Tachometer
2. Speedometer
Warning Lights
- Low Fuel Warning Light
- Charging System Light**
- Oil Pressure Warning Light
- Engine Temperature Warning Light
- Transmission Temperature Warning Light
- Anti-Lock Brake (ABS) Light**
- Air Bag Warning Light**
- Electronic Throttle Control (ETC) Light
- Tire Pressure Monitoring System (TPMS) Light
- Seat Belt Reminder Light
BRAKE - Brake Warning Light**
- Malfunction Indicator Light (MIL)**
- Electronic Stability Control (ESC) Activation/Malfunction Indicator Light*
- SERV (Service) AWD Indicator Light
(See page 125 for more information.)
8
CONTROLS AT A GLANCE
3. Temperature Gauge
4. Fuel Gauge
Indicators
- Turn Signal Indicators
- Adaptive Cruise Control (ACC) ON
Indicator*
- High Beam Indicator
- Adaptive Cruise Control (ACC) SET
Indicator*
- Front Fog Light Indicator*
- Park/Headlight ON Indicator*
- Vehicle Security Indicator*
- Electronic Stability Control (ESC)
Off Indicator*
- TOW/HAUL Indicator*
- Windshield Washer Fluid Low Indicator
- Electronic Speed Control SET Indicator
- Door Ajar Indicator
- Loose Gas Cap Indicator
- Forward Collision Warning (FCW)
OFF Indicator*
- Electronic Speed Control ON Indicator
- Liftgate Ajar Indicator
* If equipped
** Bulb Check with Key On
9
GETTING STARTED
KEY FOB
Locking And Unlocking The
Doors/Liftgate
• Press the LOCK button once to lock all the
doors and the liftgate. Press the UNLOCK
button once to unlock the driver’s door
only and twice within five seconds to unlock all the doors and liftgate.
• All doors can be programmed to unlock
on the first press of the UNLOCK button.
Refer to Programmable Features in the
Electronics section of this guide.
POWER LIFTGATE
twice within
• Press the liftgate button
five seconds to power open/close the
Power Liftgate. If the button is pressed
while the liftgate is being power closed,
the liftgate will reverse to the full open
position.
1 — Liftgate
2 — Unlock
3 — Lock
4 — Remote Start
5 — Panic
• Also, the power liftgate may be closed by
pressing the Liftgate switch located on the left rear trim panel, near the liftgate opening.
Pressing once will close the liftgate only. This button cannot be used to open the liftgate.
Panic Alarm
• Press the PANIC button once to turn the panic alarm on.
• Wait approximately three seconds and press the button a second time to turn the panic
alarm off.
REMOTE START
• Press the REMOTE START button 2 on the Key Fob twice within five seconds. Pressing
the REMOTE START button a third time shuts the engine off.
x
• To drive the vehicle, with a valid Keyless Enter-N-Go™ Key Fob within 5 ft (1.5m) of the
driver's side of the vehicle, grab the front driver door handle to unlock the driver's door
automatically, then press the Start/Stop switch. Or press the UNLOCK button, insert the
Key Fob in the ignition and turn to the ON/RUN position.
• With remote start, the engine will only run for 15 minutes (timeout) unless the ignition is
placed in the ON/RUN position.
• The vehicle must be started with the Key Fob after two consecutive timeouts.
10
GETTING STARTED
WARNING!
•
•
Do not start or run an engine in a closed garage or confined area. Exhaust gas
contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is
poisonous and can cause you or others to be severely injured or killed when inhaled.
Keep Key Fob transmitters away from children. Operation of the Remote Start
System, windows, door locks or other controls could cause you and others to be
severely injured or killed.
KEYLESS ENTER-N-GO™
• The Keyless Enter-N-Go™ system is an enhancement to the vehicle's Key Fob. This
feature allows you to lock and unlock the vehicle's door(s) and liftgate without having to
press the Key Fob lock or unlock buttons, as well as starting and stopping the vehicle with
the press of a button.
To Unlock From The Driver or Passenger Side
• With a valid Keyless Enter-N-Go™ Key Fob
located outside the vehicle and within 5 ft
(1.5m) of the driver or passenger side door
handle, grab either front door handle to
unlock the door automatically.
To Lock the Vehicle
• Both front door handles have LOCK buttons located on the outside of the handle.
With one of the vehicle's Keyless Enter-NGo™ Key Fobs located outside the vehicle
and within 5 ft (1.5m) of the driver's or
passenger front door handle, press the door handle LOCK button to lock all four doors and
liftgate.
• DO NOT grab the door handle, when pressing the door handle lock button. This could
unlock the door(s).
11
GETTING STARTED
NOTE:
• If “Unlock All Doors 1st Press” is programmed all doors will unlock when you grab hold of
the front driver's door handle. To select between “Unlock Driver Door 1st Press” and
“Unlock All Doors 1st Press”, refer to the Electronic Vehicle Information Center (EVIC) in
your vehicle's Owner's Manual on the DVD or Programmable Features in this guide for
further information.
• If “Unlock All Doors 1st Press” is programmed all doors and liftgate will unlock when you
press the liftgate button. If “Unlock Driver Door 1st Press” is programmed only the liftgate
will unlock when you press the liftgate button. To select between “Unlock Driver Door 1st
Press” and “Unlock All Doors 1st Press”, refer to the Electronic Vehicle Information Center
(EVIC) in your vehicle's Owner's Manual on the DVD or Programmable Features in this
guide for further information.
• If a Key Fob is detected in the vehicle when locking the vehicle using the power door lock
switch, the doors and liftgate will unlock and the horn will chirp three times. On the third
attempt, your Key Fob can be locked inside the vehicle.
• After pressing the Keyless Enter-N-Go™ LOCK button, you must wait 2 seconds before
you can lock or unlock the vehicle using the door handle. This is done to allow you to
check if the vehicle is locked by pulling the door handle, without the vehicle reacting and
unlocking.
• If a Keyless Enter-N-Go™ door handle has not been used for 72 hours, the Keyless
Enter-N-Go™ feature for that handle may time out. Pulling the deactivated front door
handle will reactivate the door handle's Keyless Enter-N-Go™ feature.
Lock Or Unlock The Liftgate
• To Lock The Liftgate — With a Remote
Keyless Entry (RKE) transmitter within 3 ft
(1.0 m) of the liftgate, press the passive
entry lock button located to the right of
electronic liftgate handle.
• To Unlock/Enter The Liftgate — The liftgate passive entry unlock feature is built
into the electronic liftgate handle. With a
Remote Keyless Entry (RKE) transmitter
within 3 ft (1.0 m) of the liftgate, press the
electronic release switch to open the
liftgate.
NOTE:
Refer to your Owner's Manual on the DVD for
further information.
1 — Electronic Release Switch
12
2 — Lock Button
Location
GETTING STARTED
Engine Starting/Stopping
Starting
• Perform the following starting procedure
with a Remote Keyless Entry (RKE) transmitter inside the vehicle:
• Place the shift lever in PARK or NEUTRAL
• While pressing the brake pedal, press
the ENGINE START/STOP button once.
If the engine fails to start, the starter
will disengage automatically after 10
seconds
• To stop the cranking of the engine prior
to the engine starting, press the button
again
Stopping
• Bring the vehicle to a complete stop.
• Shift the transmission to PARK (P).
• Press the ENGINE START/STOP button once. The ignition switch will return to the OFF
position.
NOTE:
If the transmission is not in PARK and the vehicle is in motion, the ENGINE START/STOP
button must be held for two seconds with the vehicle speed above 5 mph (8 km/h) before
the engine will shut off.
Accessory Positions with Engine Off
NOTE:
The following functions are with the driver’s foot OFF the Brake Pedal (transmission in PARK
or NEUTRAL).
13
GETTING STARTED
Beginning With The Ignition Switch In The OFF Position:
• Press the ENGINE START/STOP button once to change the ignition switch to the ACC
position.
• Press the ENGINE START/STOP button a second time to change the ignition switch to the
ON/RUN position.
• Press the ENGINE START/STOP button a third time to return the ignition switch to the OFF
position.
NOTE:
If the ignition switch is left in the ACC or
ON/RUN (engine not running) position and
the transmission is in PARK, the system will
automatically time out after 30 minutes of
inactivity and the ignition will switch to the
OFF position.
THEFT ALARM
To Arm
• Press the Keyless Enter-N-Go™ Start/Stop button until the Electronic Vehicle Information Center (EVIC) indicates that the vehicle ignition is “OFF”. Press the power door lock
switch while the door is open, press the Key Fob LOCK button, or with one of the Key Fobs
located outside the vehicle and within 5 ft (1.5 m) of the driver's and passenger front door
handles, press the Keyless Enter-N-Go™ LOCK button located on the door handle.
NOTE:
After pressing the Keyless Enter-N-Go™ LOCK button, you must wait two seconds before
you can lock or unlock the vehicle via the door handle.
To Disarm
• Press the Key Fob UNLOCK button or with one of the Key Fobs located outside the vehicle
and within 5 ft (1.5 m) of the driver's and passenger front door handles, grab the Keyless
Enter-N-Go™ door handle and enter the vehicle, then press the Keyless Enter-N-Go™
Start/Stop button (requires at least one valid Key Fob in the vehicle).
SEAT BELT
• Be sure everyone in your vehicle is in a seat and using a seat belt properly.
• Position the lap belt across your thighs, below your abdomen. To remove slack in the lap
portion, pull up a bit on the shoulder belt. To loosen the lap belt if it is too tight, tilt the
latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt
in a collision.
• Position the shoulder belt on your chest so that it is comfortable and not resting on your
neck. The retractor will withdraw any slack in the belt.
14
GETTING STARTED
• A shoulder belt placed behind you will not protect you from injury during a collision. You
are more likely to hit your head in a collision if you do not wear your shoulder belt. The lap
and shoulder belt are meant to be used together.
• A belt that is too loose will not protect you properly. In a sudden stop you could move too
far forward, increasing the possibility of injury. Wear your seat belt snugly.
• A frayed or torn belt could rip apart in a collision and leave you with no protection. Inspect
the belt system periodically, checking for cuts, frays, or loose parts. Damaged parts must
be replaced immediately. Do not disassemble or modify the system. Seat belt assemblies must be replaced after a collision if they have been damaged (bent retractor, torn
webbing, etc.).
• The seat belts for both front seating positions are equipped with pretensioning devices
that are designed to remove slack from the seat belt in the event of a collision.
• A deployed pretensioner or a deployed air bag must be replaced immediately.
NOTE:
When the ignition switch is first turned to the ON/RUN position, this light will turn on for four
to eight seconds as a bulb check. During the bulb check, if the driver's seat belt is
unbuckled, a chime will sound. After the bulb check or when driving, if the driver or front
passenger seat belt remains unbuckled, the Seat Belt Indicator Light will flash or remain on
continuously.
WARNING!
In a collision, you and your passengers can suffer much greater injuries if you are not
buckled up properly. You can strike the interior of your vehicle or other passengers, or you
can be thrown out of the vehicle. Always be sure you and others in your vehicle are
buckled up properly.
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) — AIR BAGS
• This vehicle has Advanced Front Air Bags for both the driver and front passenger as a
supplement to the seat belt restraint systems. The driver's Advanced Front Air Bag is
mounted in the center of the steering wheel. The passenger's Advanced Front Air Bag is
mounted in the instrument panel, above the glove compartment. The words SRS AIR BAG
are embossed on the air bag covers.
• Advanced Front Air Bags are designed to provide additional protection by supplementing
the seat belts in certain frontal collisions depending on several factors, including the
severity and type of collision. Advanced Front Air Bags are not expected to reduce the
risk of injury in rear, side, or rollover collisions.
• This vehicle is equipped with Supplemental Side Air Bag Inflatable Curtains to protect
the driver, front and rear passengers sitting next to a window.
• This vehicle is equipped with Supplemental Seat-Mounted Side Air Bags to provide
enhanced protection to help protect an occupant during a side impact.
15
GETTING STARTED
• This vehicle is equipped with Supplemental Driver’s Side Knee Air Bag mounted in the
instrument panel below the steering column and a Knee Bolster mounted below the
glove compartment. The Supplemental Driver’s Side Knee Air Bag provides enhanced
protection and works together with the Driver Advanced Front Air Bag during a frontal
impact.
is not on during starting, stays on, or turns on while
• If the Air Bag Warning Light
driving, have the vehicle serviced by an authorized service center immediately.
• Refer to the Owner's Manual on the DVD for further details regarding the Supplemental
Restraint System (SRS).
WARNING!
•
•
•
•
•
•
Relying on the air bags alone could lead to more severe injuries in a collision. The air
bags work with your seat belt to restrain you properly. In some collisions, the air bags
won't deploy at all. Always wear your seat belts even though you have air bags.
Being too close to the steering wheel or instrument panel during Advanced Front Air
Bag deployment could cause serious injury, including death. Air bags need room to
inflate. Sit back, comfortably extending your arms to reach the steering wheel or
instrument panel.
Supplemental Side Air Bag Inflatable Curtains and Supplemental Seat-Mounted Side
Air Bags need room to inflate. Do not lean against the door or window. Sit upright in
the center of the seat.
Being too close to the Supplemental Side Air Bag Inflatable Curtain and/or SeatMounted Side Air Bag during deployment could cause you to be severely injured or
killed.
Do not drive your vehicle after the air bags have deployed. If you are involved in
another collision, the air bags will not be in place to protect you.
After any collision, the vehicle should be taken to an authorized dealer immediately.
CHILD RESTRAINTS
• Children 12 years or younger should ride properly buckled up in a rear seat, if available.
According to crash statistics, children are safer when properly restrained in the rear
seats rather than in the front.
• Every state in the United States and all Canadian provinces require that small children
ride in proper restraint systems. This is the law, and you can be prosecuted for ignoring it.
NOTE:
• For additional information, refer to www.seatcheck.org or call 1–866–SEAT-CHECK (1–
866–732–8243).
• Canadian residents, should refer to Transport Canada’s website for additional information: http://www.tc.gc.ca/eng/roadsafety/safedrivers-childsafety-index-53.htm
16
GETTING STARTED
LATCH — Lower Anchors And Tethers For CHildren
• Your vehicle is equipped with the child restraint anchorage system called LATCH, which
stands for Lower Anchors and Tethers for CHildren.
• The second row seating positions have lower anchors and top tether anchors. The
second row center (60/40 bench seat only) and third row seating positions have a top
tether anchor only.
• You may use the LATCH anchorage system until the combined weight of the
child and the child restraint is 65 lbs
(29.5 kg). Use the seat belt and tether
anchor instead of the LATCH system once
the combined weight is more than 65 lbs
(29.5 kg).
•
The lower anchorages are round bars
that are found at the rear of the seat cushion where it meets the seatback. They are
just visible when you lean into the rear
seat to install the child restraint. You will
easily feel them if you run your finger along the gap between the seatback and seat
cushion.
17
GETTING STARTED
•
In addition, there are tether strap anchorages behind each rear seating position
located on the back of the seat. To access the top tether strap anchorages behind the
rear seat, pull the carpeted floor panel away from the seat back, this will expose the top
tether strap anchorages. DO NOT USE the cargo tie down loops located on the load floor
as tether anchorages.
• Do not install a child restraint in the center position using the LATCH system. Use the
seat belt and tether anchor to install a child seat in the center seating position.
Vehicles With Center Arm Rest Tether
• For rearward facing infant seats secured in the center seat position with the vehicle seat
belts, the rear center seat position has an armrest tether that secures the arm rest in the
upward position.
1. To access the center seat arm rest tether, first lower the arm rest. The tether is located
behind the armrest and hooked onto the plastic seat backing.
2. Pull down on the tether to unhook it from the plastic seat backing.
3. Raise the armrest and attach the tether hook to the strap located on the front of the arm
rest.
Installing The Child Restraint Using The LATCH Lower Anchors
NOTE:
Never “share” a LATCH anchorage with two or more child restraints.
1. Loosen the adjusters on the lower straps and on the tether strap of the child seat so that
you can more easily attach the hooks or connectors to the vehicle anchorages.
2. Attach the lower hooks or connectors of the child restraint to the lower anchorages in the
selected seating position.
3. If the child restraint has a tether strap, connect it to the top tether anchorage. See below
for directions to attach a tether anchor.
4. Tighten all of the straps as you push the child restraint rearward and downward into the
seat. Remove slack in the straps according to the child restraint manufacturer’s instructions.
5. Test that the child restraint is installed tightly by pulling back and forth on the child seat
at the belt path. It should not move more than 1 inch (25.4 mm) in any direction.
18
GETTING STARTED
Installing The Child Restraint Using The Vehicle Seat Belts
• The seat belts in the passenger seating positions are equipped with a Switchable
Automatic Locking Retractor (ALR) that is designed to keep the lap portion of the seat
belt tight around the child restraint. Any seat belt system will loosen with time, so check
the belt occasionally, and pull it tight if necessary.
• Always use the tether anchor when using the seat belt to install a forward facing child
restraint, up to the recommended weight limit of the child restraint.
To Install A Child Seat Using An ALR:
1. Pull enough of the seat belt webbing from the retractor to pass it through the belt path of
the child restraint. Do not twist the belt webbing in the belt path.
2. Slide the latch plate into the buckle until you hear a “click.”
3. Pull on the webbing to make the lap portion tight against the child seat.
4. To lock the seat belt, pull down on the shoulder part of the belt until you have pulled all the
seat belt webbing out of the retractor. Then, allow the webbing to retract back into the
retractor. As the webbing retracts, you will hear a clicking sound. This means the seat belt is
now in the Automatic Locking mode.
5. Try to pull the webbing out of the retractor. If it is locked, you should not be able to pull out
any webbing. If the retractor is not locked, repeat the last step.
6. Finally, pull up on any extra webbing to tighten the lap portion around the child restraint
while you push the child restraint rearward and downward into the vehicle seat.
7. If the child restraint has a top tether strap and the seating position has a top tether
anchorage, connect the tether strap to the anchorage and tighten the tether strap. See
below for directions to attach a tether anchor.
8. Test that the child restraint is installed tightly by pulling back and forth on the child seat
at the belt path. It should not move more than 1 inch (25.4 mm) in any direction.
Installing The Top Tether Strap (With Either Lower Anchors Or Vehicle Seat Belt):
• When installing a forward-facing child restraint, always secure the top tether strap, up to
the tether anchor weight limit, whether the child restraint is installed with the lower
anchors or the vehicle seat belt.
1. To access the top tether strap anchorages behind the rear seat, pull the carpeted floor
panel away from the seat back, this will expose the top tether strap anchorages.
2. Route the tether strap to provide the most direct path for the strap between the anchor
and the child seat.
3. If your vehicle is equipped with adjustable rear head restraints, raise the head restraint, and
where possible, route the tether strap under the head restraint and between the two posts. If
not possible, lower the head restraint and pass the tether strap around the outboard side of
the head restraint.
19
GETTING STARTED
4. For the center seating position, route the tether strap over the seatback and headrest.
5. Attach the tether strap hook of the child restraint to the top tether anchorage and
remove slack in the tether strap according to the child restraint manufacturer’s instructions. DO NOT USE the cargo tie down loops located on the load floor as tether
anchorages.
WARNING!
•
•
•
•
•
•
In a collision, an unrestrained child, even a tiny baby, can become a projectile inside
the vehicle. The force required to hold even an infant on your lap could become so
great that you could not hold the child, no matter how strong you are. The child and
others could be severely injured or killed. Any child riding in your vehicle should be in
a proper restraint for the child's size.
Rearward-facing child seats must never be used in the front seat of a vehicle with a
front passenger air bag. An air bag deployment could cause severe injury or death to
infants in this position.
Only use a rearward-facing child restraint in a vehicle with a rear seat.
Improper installation of a child restraint to the LATCH anchorages can lead to failure
of an infant or child restraint. The child could be severely injured or killed. Follow the
manufacturer’s directions exactly when installing an infant or child restraint.
An incorrectly anchored tether strap could lead to increased head motion and
possible injury to the child. Use only the anchor positions directly behind the child
seat to secure a child restraint top tether strap.
If your vehicle is equipped with a split rear seat, make sure the tether strap does not
slip into the opening between the seatbacks as you remove slack in the strap.
FRONT SEATS
Power Seats
• The power recline switch, located on the
outboard side of the seat, controls seatback adjustment.
• The power seat switch controls forward/
back, up/down and tilt adjustment.
20
GETTING STARTED
Power Lumbar
• Push the switch forward to increase the
lumbar support. Push the switch rearward
to decrease the lumbar support.
• Pushing upward or downward on the
switch will raise and lower the position of
the support.
Memory Seat
• The memory seat feature allows you to
save two different driver seating positions
(excluding lumbar position), outside mirrors, tilt/telescoping steering column position, and radio station preset settings.
The memory seat buttons are located on
the driver's door panel.
• Adjust all memory profile settings, press
the SET button then press 1 or 2 within five
seconds.
• To program a remote keyless entry (RKE)
transmitter to a memory position, you
must select the “Personal Settings Linked To Key Fob” feature within “Doors & Locks”
through the Uconnect® system screen. Refer to Programmable Features in the Electronics section of this guide.
• Place the ignition in the OFF position, select the desired memory profile (1) or (2). Once
the profile has been recalled, press and release the SET (S) button on the memory switch,
then press and release button (1) or (2) accordingly. Press and release the LOCK button on
the RKE transmitter within 10 seconds.
• To recall the saved positions, press 1 or 2 on the memory switch or press UNLOCK on the
programmed RKE transmitter.
• Refer to the Owner's Manual on the DVD for further details.
21
GETTING STARTED
Manual Seat Adjustment
Forward/Rearward
• Lift up on the adjusting bar located at the
front of the seat near the floor and release
it when the seat is at the desired position.
Then, using body pressure, move forward
and backward on the seat to be sure that
the seat adjusters have latched.
Recliner
• Lift the rear lever located on the outboard
side of the seat, lean back and release
when seat is in desired position.
Fold-Flat Front Passenger Seat
• The front passenger seat can be folded
flat to allow for extended cargo space.
Pull up on the recliner lever and fold the
seatback forward and down to a flat
position.
22
GETTING STARTED
CAUTION!
Do not place any article under a power seat or impede its ability to move as it may cause
damage to the seat controls. Seat travel may become limited if movement is stopped by
an obstruction in the seat's path.
WARNING!
•
•
Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the
seat could cause you to lose control. The seat belt might not be properly adjusted, and
you could be severely injured or killed. Only adjust a seat while the vehicle is parked.
Do not ride with the seatback reclined so that the seat belt is no longer resting
against your chest. In a collision, you could slide under the seat belt and be severely
injured or killed. Use the recliner only when the vehicle is parked.
REAR SEATS
60/40 Split Rear Seat
Fold and Tumble
• The left or right side of the second row
seatback can folded flat to carry cargo.
The left and right side of the second row
seat can also be tumbled forward to allow
access to the third row seat.
• Pull upward on the release lever to release
the seat.
NOTE:
Also, pulling upward on this handle allows the
outboard seating positions to be reclined.
• Tumble the seat forward using the red pull strap located behind the seatback.
NOTE:
If sitting in the third row seat, pull rearward on the tumble pull strap located at the rear of the
seat and tumble the seat forward.
23
GETTING STARTED
Rear Captain Chairs
Fold and Tumble
• The left or right side of the second row seatback can be folded flat to carry cargo. When
the lower storage compartment is accessed
using the rear push button it allows the armrest to flip forward for “fold flat mode”. Fold
flat mode allows the console armrest to be
lowered below fold flat seat plane and protect the armrest vinyl from damage when
using the vehicle to haul cargo.
• The left and right side of the second row
seat can also be tumbled forward to allow
access to the third row seat. Pull upward on the release lever to release the seat. Pulling
upward on this handle allows the outboard seating positions to be reclined.
• Tumble the seat forward using the red pull strap located behind the seatback.
NOTE:
If sitting in the third row seat, pull rearward on the tumble pull strap located at the rear of the
seat and tumble the seat forward.
• If your vehicle is equipped with a mini console there is a stepping pad to allow passengers
to easily access the third row seats.
24
GETTING STARTED
50/50 Third Row Folding Seat
• Either or both third row seats can be folded forward to increase the rear cargo storage area.
• After opening the liftgate, either seat can be folded flat by pulling up the release handle
on the back of the seat.
• A seat that is folded flat can be returned to the upright position by using the pull strap
located on the back of the seat next to the release handle.
NOTE:
The second row seats must be in their full upright position, or tumbled when folding the
third row seats.
• To raise the seat, pull the seat toward you using the strap located on the back of the seat.
WARNING!
Do not drive the vehicle with the second row seats in the tumbled position. The second row
seats are only intended to be tumbled for entry and exit to the third row seat. Failure to follow
these instructions could result in personal injury.
POWER FOLDING THIRD ROW HEAD RESTRAINTS
• For improved visibility when in reverse,
the third row head restraints can be
folded using the Uconnect® System.
• Press the Headrest Fold soft key on the
touch screen to power fold the third row
head restraints.
NOTE:
The head restraints can only be folded
downward using the Headrest Fold soft key.
The head restraints must be raised manually
when occupying the third row.
1 — Headrest Fold
25
GETTING STARTED
HEATED/VENTILATED SEATS
Front Heated Seats
• The controls for front heated seats are
located in the touch screen.
• Press the soft-key once to turn the High
setting on. Press the soft-key a second
time to turn the low setting on. Press the
soft-key a third time to shut the heating
elements Off.
• If the High-level setting is selected, the
system will automatically switch to Lowlevel after approximately 55 minutes. The
Low-level setting will turn Off automatically after approximately 45 minutes.
1 — Driver Heated
Seat
2 — Passenger
Heated Seat
1 — Driver Vented
Seat
2 — Passenger
Vented Seat
Front Ventilated Seats
• Located in the seat cushion and seatback
are small fans that draw the air from the
passenger compartment and pull air
through fine perforations in the seat
cover to help keep the driver and front
passenger cooler in higher ambient temperatures.
• There are two ventilated seat soft-keys
that allow the driver and passenger to operate the seats independently. The ventilated seat soft-keys are located in the
touch screen controls. The ventilated
seat switches are used to control the
speed of the fans located in the seat.
Press the soft-key once to choose HIGH,
press it a second time to choose LOW.
Pressing the soft-key a third time will turn
the ventilated seat OFF.
26
GETTING STARTED
Rear Heated Seats
• Second row heated seat switches are located on the rear of the center console.
• Press the switch once to select High-level
heating. Press the switch a second time
to select Low-level heating. Press the
switch a third time to shut the heating
elements Off.
• If the High-level setting is selected, the
system will automatically switch to Lowlevel after approximately 55 minutes. The
Low-level setting will turn Off automatically after approximately 45 minutes.
1 — Heated Seat Switches
WARNING!
•
•
Persons who are unable to feel pain to the skin because of advanced age, chronic
illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other
physical conditions must exercise care when using the seat heater. It may cause
burns even at low temperatures, especially if used for long periods of time.
Do not place anything on the seat that insulates against heat, such as a blanket or
cushion. This may cause the seat heater to overheat. Sitting in a seat that has been
overheated could cause serious burns due to the increased surface temperature of the
seat.
27
GETTING STARTED
HEATED STEERING WHEEL
• The steering wheel contains a heating element that heats the steering wheel to
one temperature setting.
• The heated steering wheel controls are
located in the touch screen.
• Press the soft-key once to turn on the
heated steering wheel. Press the soft-key
a second time to turn the heated steering
wheel off.
• Once the heated steering wheel has been
turned on, it will operate for approximately 58 to 70 minutes before automatically shutting off. The heated steering
wheel can shut off early or may not turn
on when the steering wheel is already
warm.
1 — Heated Wheel
TILT/TELESCOPING STEERING COLUMN
Manual - Tilt/Telescoping Steering Column
• The tilt/telescoping control handle is located below the steering wheel at the end
of the steering column.
• Push the handle down to unlock the steering column.
• To tilt the steering column, move the
steering wheel upward or downward as
desired. To lengthen or shorten the steering column, pull the steering wheel outward or push it inward as desired.
• Pull up on the handle to lock the column
firmly in place.
28
GETTING STARTED
Power - Tilt/Telescoping Steering Column
• The power tilt/telescoping steering control is located below the turn signal/
wiper/washer/high beam lever on the
steering column.
• To tilt the steering column, move the
power tilt/telescoping control up or down
as desired. To lengthen or shorten the
steering column, pull the control toward
you or push the control away from you as
desired.
WARNING!
•
•
Do not adjust the steering wheel while driving. The tilt/telescoping adjustment must
be locked while driving. Adjusting the steering wheel while driving or driving without
the tilt/telescoping adjustment locked could cause the driver to lose control of the
vehicle. Failure to follow this warning may result in you and others being severely
injured or killed.
Moving the steering column while the vehicle is moving is dangerous. Without a
stable steering column, you could lose control of the vehicle and have a collision.
Adjust the column only while the vehicle is stopped.
29
OPERATING YOUR VEHICLE
ENGINE BREAK-IN RECOMMENDATIONS
• A long break-in period is not required for the engine and drivetrain (transmission and
axle) in your vehicle.
• Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km),
speeds up to 50 or 55 mph (80 or 90 km/h) are desirable.
• While cruising, brief full-throttle acceleration within the limits of local traffic laws
contributes to a good break-in. Wide-open throttle acceleration in low gear can be
detrimental and should be avoided.
• The engine oil installed in the engine at the factory is a high-quality energy conserving
type lubricant. Oil changes should be consistent with anticipated climate conditions
under which vehicle operations will occur. For the recommended viscosity and quality
grades, refer to “Maintaining Your Vehicle”.
NOTE:
A new engine may consume some oil during its first few thousand miles (kilometers) of
operation. This should be considered a normal part of the break-in and not interpreted as
an indication to an engine problem or malfunction.
CAUTION!
Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result.
HEADLIGHT SWITCH
Automatic Headlights/Parking Lights/Headlights
• Rotate the headlight switch, located on
the instrument panel to the left of the
steering wheel, to the first detent for parkand to the second detent
ing lights
.
for headlights
• With the parking lights or low beam headlights on, push the headlight switch once
for fog lights.
• Rotate the headlight switch to “AUTO” for
AUTO headlights.
• When set to AUTO, the system automatically turns the headlights on or off based
on ambient light levels.
30
OPERATING YOUR VEHICLE
Automatic High Beams
• The Automatic High Beams system provides increased forward lighting at night by
automating high beam control through the use of a digital camera mounted on the inside
rearview mirror. This camera detects vehicle specific light and automatically switches
from high beams to low beams until the approaching vehicle is out of view. Refer to
Programmable Features in Electronics for further details.
Instrument Panel Dimmer
• Rotate the dimmer control to the extreme bottom position to fully dim the instrument
panel lights and prevent the interior lights from illuminating when a door is opened.
• Rotate the dimmer control up to increase the brightness of the instrument panel when
the parking lights or headlights are on.
• Rotate the dimmer control up to the next detent position to fully brighten the odometer
and radio when the parking lights or headlights are on. Refer to your Uconnect®/Radio
User Manual on the DVD for display dimming.
• Rotate the dimmer control up to the last detent position to turn on the interior lighting.
TURN SIGNAL/WIPER/WASHER/HIGH BEAM LEVER
Turn Signal/Lane Change Assist
• Tap the lever up or down once and the turn signal (right or left) will flash three times and
automatically turn off.
Front Wipers
Intermittent, Low And High Operation
• Rotate the end of the lever to the first detent position for one of four intermittent settings,
the second detent for low wiper operation and the third detent for high wiper operation.
Washer Operation
• Push inward on the end of the lever and hold for as long as spray is desired.
31
OPERATING YOUR VEHICLE
Mist
• Rotate the end of the lever downward when a single wipe is desired.
NOTE:
The mist feature does not activate the washer pump; therefore, no washer fluid will be
sprayed on the windshield. The wash function must be activated in order to spray the
windshield with washer fluid.
Rain Sensing Wipers
• This feature senses moisture on the vehicle's windshield and automatically activates the
wipers for the driver when the switch is in the intermittent position. Rotate the end of the
lever to one of four settings to activate this feature and adjust sensitivity.
• This feature can be activated/deactivated using the Electronic Vehicle Information
Center (EVIC). Refer to the Programmable Features under the Electronics section in this
guide.
• Refer to the Owner's Manual on the DVD for further details.
Rear Wiper
Rear Wiper Operation
• Rotate the center portion of the lever forward to the first detent for intermittent operation
and to the second detent for rear wiper operation.
Rear Washer Operation
• Rotate the center portion of the lever past the second detent to activate the rear washer.
High Beam Operation
• Push the lever forward to activate the high beams. Pull the lever toward you for flash to
pass.
NOTE:
For safe driving, turn off high beams when oncoming traffic is present to prevent headlight
glare and as a courtesy to other motorists.
AUTOMATIC DIMMING MIRRORS
• The rearview and driver side exterior mirror automatically adjusts for headlight glare
from vehicles behind you.
• You can turn the feature on or off when the Automatic Dimming Mirror feature is selected
from the Customer Programmable Features of the Uconnect® System screen.
32
OPERATING YOUR VEHICLE
SPEED CONTROL
• The speed control switches are located
on the right side of the steering wheel.
Cruise ON/OFF
• Push the ON/OFF button
the Speed Control.
to activate
• CRUISE CONTROL READY will appear on
the instrument cluster to indicate the
Speed Control is on.
a second
• Push the ON/OFF button
time to turn the system off. CRUISE CONTROL OFF will appear on the instrument
cluster to indicate the Speed Control is off.
SET
• With the Speed Control on, push and release the SET+ or SET- button to set a desired
speed.
• Once a speed has been set a message CRUISE CONTROL SET TO MPH/KM will appear
indicating what speed was set. An indicator CRUISE will also appear and stay on in the
instrument cluster when the speed is set.
Accel/Decel
• Once a speed is set, pushing the SET + button once or the SET – button once will increase
or decrease the set speed approximately 1 mph (1 km/h).
• Push and hold the SET + button to accelerate in 5 mph (10 km/h) increments or push and
hold the SET – button to decelerate in 5 mph (10 km/h) increments; release the button to
save the new set speed.
Resume
• To resume a previously selected set speed in memory, push the RES button and release.
Cancel
• Push the CANCEL button, or apply the brakes to cancel the set speed and maintain the
set speed memory.
• Push the ON/OFF button to turn the system off and erase the set speed memory.
33
OPERATING YOUR VEHICLE
ADAPTIVE CRUISE CONTROL (ACC)
• If your vehicle is equipped with adaptive
cruise control the controls operate exactly the same as the normal (fixed
speed) cruise control with one difference.
You can set a specified distance you
would like to maintain between you and
the vehicle in front of you.
• If the ACC sensor detects a vehicle ahead,
ACC will apply limited braking or acceleration automatically to maintain a preset following distance, while matching
the speed of the vehicle ahead.
• If the sensor does not detect a vehicle ahead of you, ACC will maintain a fixed set speed.
ACC ON/OFF
• Push and release the Adaptive Cruise Control (ACC) ON/OFF button.
• ACC READY will appear on the instrument cluster to indicate the ACC is on.
• Push and release the Adaptive Cruise Control (ACC) ON/OFF button a second time to turn
the system off.
• Adaptive Cruise Control (ACC) Off will appear on the instrument cluster to indicate the
ACC is off.
Distance Setting (ACC Only)
• The specified following distance for ACC can be set by varying the distance setting
between four bars (longest), three bars (long), two bars (medium) and one bar (short).
Using this distance setting and the vehicle speed, ACC calculates and sets the distance
to the vehicle ahead. This distance setting displays in the EVIC.
• To increase the distance setting, press the Distance Setting—Increase button and release. Each time the button is pressed, the distance setting increases by one bar (longer).
• To decrease the distance setting, press the Distance Setting—Decrease button and
release. Each time the button is pressed, the distance setting decreases by one bar
(shorter).
ACC Operation At Stop
• If the ACC system brings your vehicle to a standstill while following a target vehicle, if the
target vehicle starts moving within 2 seconds of your vehicle coming to a standstill, your
vehicle will resume motion without the need for any driver action.
• After the ACC system holds your vehicle at a standstill for approximately 3 consecutive
minutes, the parking brake will be activated, and the ACC system will be cancelled.
• While the ACC system is holding your vehicle at a standstill, if the driver seatbelt is
unbuckled or the driver door is opened, the parking brake will be activated, and the ACC
system will be cancelled.
34
OPERATING YOUR VEHICLE
Changing Modes (ACC Only)
• If desired, the Adaptive Cruise Control mode can be turned off and the system can be
operated as a normal (fixed speed) Cruise Control mode. When in the normal (fixed
speed) Cruise Control mode the distance setting feature will be disabled and the system
will maintain the speed you set.
• To change between the different cruise control modes, press the ADAPTIVE CRUISE
CONTROL (ACC) ON/OFF button which turns the ACC and the normal (fixed speed) control
OFF. Pressing of the NORMAL (Fixed Speed) CRUISE CONTROL ON/OFF button will result
in turning ON (changing to) the Normal (Fixed Speed) Cruise Control mode.
• Refer to your Owner's Manual on the DVD for further information.
Forward Collision Warning (FCW) With Mitigation
• The Forward Collision Warning (FCW) system with mitigation provides the driver with
audible warnings, visual warnings (within the EVIC), and may apply a brake jerk to warn
the driver when it detects a potential frontal collision. The warnings and limited autonomous braking are intended to provide the driver with enough time to react, avoid or
mitigate the potential collision.
Turning FCW ON Or OFF
NOTE:
The default status of FCW is “On”, this allows the system to warn you of a possible collision
with the vehicle in front of you when you are farther away and it applies limited braking. This
gives you the most reaction time to avoid a possible collision.
• The forward collision button is located below the climate controls, on the switch panel.
• To turn the FCW system OFF, press the forward collision button once to turn the system
OFF (led turns on).
• To turn the FCW system back ON, press the forward collision button again to turn the
system ON (led turns off).
Changing FCW Status
• The FCW feature has three settings and can be changed within the Uconnect® System
Screen:
• Far
• Near
• Off
NOTE:
The FCW and active braking settings can only be changed when the vehicle is in PARK.
35
OPERATING YOUR VEHICLE
Far
• The default status of FCW is the “Far” setting.
• The far setting provides warnings for potential collisions more distant in front of the
vehicle, allowing the driver to have the most reaction time to avoid a collision.
• This setting is designed to provide early warnings per NHTSA (National Highway Traffic
Safety Administration) recommendations.
• More cautious drivers that do not mind frequent warnings may prefer this setting.
NOTE:
This setting gives you the most reaction time.
Near
• Changing the FCW status to the “Near” setting, allows the system to warn you of a
potential frontal collision when you are much closer.
• This setting provides less reaction time than the “Far” setting, which allows for a more
dynamic driving experience.
• More dynamic or aggressive drivers that want to avoid frequent warnings may prefer this
setting.
Off
• Changing the FCW status to “Off” prevents the system from warning you of a possible
collision with the vehicle in front of you.
Turning Active Braking ON Or OFF
• The Active Braking feature has two settings and can be changed within the Uconnect®
System Screen :
• On
• Off
• Changing the Active Braking status to “Off” prevents the system from providing limited
autonomous braking, or additional brake support if the driver is not braking adequately in
the event of a potential frontal collision.
NOTE:
• If FCW is set to “Off”, “FCW OFF” will be displayed in the EVIC.
• Refer to the Owner's Manual on the DVD for further details.
36
OPERATING YOUR VEHICLE
WARNING!
•
Leaving the Electronic or Adaptive Speed Control system on when not in use is
dangerous. You could accidentally set the system or cause it to go faster than you
want. You could lose control and have a collision. Always leave the Electronic or
Adaptive Speed Control system off when you are not using it.
• Electronic Speed Control can be dangerous where the system cannot maintain a
constant speed. Your vehicle could go too fast for the conditions, and you could lose
control. A collision could be the result. Do not use Electronic Speed Control in heavy
traffic or on roads that are winding, icy, snow-covered or slippery.
• Adaptive Cruise Control (ACC) is a convenience system. It is not a substitute for
active driving involvement. Pay attention to road, traffic, and weather conditions,
vehicle speed, distance to the vehicle ahead, and brake operation to ensure safe
operation of the vehicle under all road conditions. Your attention is always required
while driving to maintain safe control of your vehicle. Failure to follow these warnings
can result in a collision or serious personal injury.
The ACC system:
• Does not react to pedestrians, oncoming vehicles, and stationary objects (i.e., a
stopped vehicle in a traffic jam or a disabled vehicle).
• Cannot take street, traffic, and weather conditions into account, and may be limited
upon adverse sight distance conditions.
• Does not predict the lane curvature or the movement of preceding vehicles and will
not compensate for such changes.
• Does not always fully recognize complex driving conditions, which can result in
wrong or missing distance warnings.
• Can only apply a maximum of 25% of the vehicle’s braking capability, and will not
bring the vehicle to a complete stop.
You should switch off the ACC system:
• When driving in fog, heavy rain, heavy snow, sleet, heavy traffic, and complex driving
situations (i.e., in highway construction zones).
• When entering a turn lane or highway off ramp; when driving on roads that are
winding, icy, snow-covered, slippery, or have steep uphill or downhill slopes; and
when towing a trailer.
• When circumstances do not allow safe driving at a constant speed.
• Failure to follow these warnings can result in a collision.
• Forward Collision Warning (FCW) is not intended to avoid a collision on its own. The
driver has the responsibility to avoid a collision by controlling the vehicle via braking
and steering. Failure to follow this warning could lead to serious injury or death.
37
OPERATING YOUR VEHICLE
ELECTRONIC SHIFTER
• Your vehicle is equipped with a fuel efficient eight-speed transmission. The
electronic Transmission Shifter is located
on the center console. The transmission
gear (PRND) is displayed both above the
shifter control and in the Electronic Vehicle Information Center (EVIC).
• To select a gear range, simply rotate the
shifter control.
NOTE:
You must press the brake pedal to shift the
transmission out of PARK or from NEUTRAL
into DRIVE or REVERSE.
• To shift past multiple gear ranges at once
(such as Park to Drive), simply rotate the switch to the appropriate detent.
• Select the DRIVE range for normal driving.
AUTOSTICK®
• AutoStick® is a driver-interactive transmission feature providing manual shift
control, giving you more control of the
vehicle.
• AutoStick® allows you to maximize engine braking, eliminate undesirable upshifts and downshifts, and improve overall vehicle performance. This system can
also provide you with more control during passing, city driving, cold slippery conditions,
mountain driving, trailer towing, and many other situations.
Operation
• When the transmission is in DRIVE, it will operate automatically, shifting between the
eight available gears. To engage AutoStick®, simply tap one of the steering wheelmounted shift paddles (+/-). Tapping (-) to enter AutoStick® will downshift the transmission to the next lower gear, while using (+) to enter AutoStick® will retain the current gear.
• When AutoStick® is active, the current transmission gear is displayed in the instrument
cluster.
• In AutoStick® mode, the transmission will shift up or down when (+/-) is manually
selected by the driver, unless an engine lugging or overspeed condition would result.
38
OPERATING YOUR VEHICLE
NOTE:
To disengage AutoStick® mode, press and hold the (+) shift paddle until "D" is once again
displayed in the instrument cluster. You can shift in or out of AutoStick® mode at any time
without taking your foot off the accelerator pedal.
WARNING!
Do not downshift for additional engine braking on a slippery surface. The drive wheels
could lose their grip and the vehicle could skid, causing a collision or personal injury.
FUEL ECONOMY (ECO) MODE
• The Fuel Economy (ECO) mode can improve the vehicle’s overall fuel economy
during normal driving conditions.
• Press the “ECO” switch in the center stack
of the instrument panel and a amber light
will indicate the ECO mode is engaged.
• When the Fuel Economy (ECO) Mode is
engaged, the vehicle control systems will
be able to change the following:
• The transmission will upshift sooner
and downshift later.
• The overall driving performance will be
more conservative.
• Some ECO mode functions may be
temporarily inhibited based on temperature and other factors.
39
OPERATING YOUR VEHICLE
AUTOMATIC CLIMATE CONTROLS WITH TOUCHSCREEN
Touchscreen Automatic Climate Controls
Uconnect® 8.4
Climate Control Knobs
40
OPERATING YOUR VEHICLE
• Press the AUTO button or AUTO soft-key.
• Select the desired temperature by pushing the up or down temperature buttons for the
driver or passenger.
• The system will maintain the set temperature automatically.
Air Conditioning (A/C)
• If the air conditioning button is pressed while in AUTO mode, the system will exit AUTO
mode and stay in A/C. The mode and blower will be set at the closest mode and blower
position that the system was operating in AUTO.
MAX A/C
• MAX A/C sets the control for maximum cooling performance.
• Touch and release to toggle between MAX A/C and the prior settings. The soft-key
illuminates when MAX A/C is ON.
• In MAX A/C, the blower level and mode position can be adjusted to desired user settings.
Pressing other settings will cause the MAX A/C operation to switch to the prior settings
and the MAX A/C indicator will turn off.
SYNC Temperature Soft-Key
• Touch the SYNC soft-key on the Uconnect® radio to control the driver and passenger
temperatures simultaneously. Touch the SYNC soft-key a second time to control the
temperatures individually.
Air Recirculation
• Use Recirculation for maximum A/C operation.
• For window defogging, turn the recirculation button off.
• If the recirculation button is pushed while in the AUTO mode, the indicator light may flash
three times to indicate the cabin air is being controlled automatically.
Heated Mirrors
• The mirrors are heated to melt frost or ice. This feature is activated whenever you turn on
the rear window defroster.
41
OPERATING YOUR VEHICLE
Rear Temperature Controls
• The rear controls for the ATC System are located in the headliner, near the center of the
vehicle.
• The rear temperature controls can be turned on two ways:
• Press the REAR control soft-key on the Uconnect® front temperature control screen
and adjust to the desired rear temperature.
• Rotate the Rear Temperature Control or the Rear Blower Control knobs on the rear
temperature controls.
• Press the REAR soft-key and then the OFF button on the Uconnect® front temperature
control screen to turn the rear controls off.
PARKSENSE® REAR PARK ASSIST
• The four ParkSense® sensors, located in the rear fascia/bumper, monitor the area behind
the vehicle that is within the sensors’ field of view.
• When an object is detected within two meters behind the rear bumper while the vehicle is
in REVERSE, a warning will display in the Electronic Vehicle Information Center (EVIC) and
a chime will sound (when Sound and Display is selected from the Customer Programmable Features section of the Uconnect® System screen). As the vehicle moves closer to
the object, the chime rate will change from single 1/2 second tone, to slow, to fast, to
continuous.
42
OPERATING YOUR VEHICLE
Cleaning the ParkSense® Sensors
• If “CLEAN PARK ASSIST SENSORS” appears in the Electronic Vehicle Information Center
(EVIC), clean the ParkSense® sensors with water, car wash soap and a soft cloth. Do not
use rough or hard cloths. Do not scratch or poke the sensors. Otherwise, you could
damage the sensors.
NOTE:
When the Instrument Cluster reads either Clean Sensor or Blinded, please clean off the
bumper sensors to see if the condition is corrected.
PARKVIEW® REAR BACK-UP CAMERA
• You can see an on-screen image of the rear of your vehicle whenever the shift lever is put
into REVERSE. The ParkView® Rear Back-Up Camera image will be displayed on the radio
display screen, located on the center stack of the instrument panel.
• If the radio display screen appears foggy, clean the camera lens located on the liftgate.
WARNING!
Drivers must be careful when backing up; even when using the ParkView® Rear Back-Up
Camera. Always check carefully behind your vehicle, and be sure to check for pedestrians, animals, other vehicles, obstructions, or blind spots before backing up. You must
continue to pay attention while backing up. Failure to do so can result in serious injury or
death.
BLIND SPOT MONITORING
• The Blind Spot Monitoring (BSM) system uses two radar-based sensors, located inside
the rear bumper fascia, to detect Highway licensable vehicles (automobiles, trucks,
motorcycles etc.) that enter the blind spot zones from the rear/front/side of the vehicle.
• The Blind Spot Monitoring (BSM) system warning light, located in the outside mirrors, will
illuminate if a vehicle moves into a blind spot zone.
• The BSM system can also be configured to sound an audible (chime) alert and mute the
radio to notify you of objects that have entered the detection zones.
• Refer to your owner's manual on the DVD for further details.
43
OPERATING YOUR VEHICLE
POWER SUNROOF
Manual Open/Close
• Press and hold the switch rearward to open or forward to close the sunroof. Any release
of the switch will stop the movement, and the sunroof will remain in a partially open or
closed position until the switch is pressed again.
Pinch Protection Feature
• This feature will detect an obstruction in the opening of the sunroof during Express Close
operation. If an obstruction in the path of the sunroof is detected, the sunroof will
automatically retract. Remove the obstruction if this occurs. Next, press the switch
forward and release to Express Close.
NOTE:
If three consecutive sunroof close attempts result in Pinch Protect reversals, the fourth
close attempt will be a Manual Close movement with Pinch Protect disabled.
44
OPERATING YOUR VEHICLE
WARNING!
•
•
•
Do not let children play with the sunroof. Never leave children unattended in a vehicle,
or with access to an unlocked vehicle. Do not leave the key fob in or near the vehicle,
and do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the
ACC or ON/RUN mode. Occupants, particularly unattended children, can become
entrapped by the power sunroof while operating the power sunroof switch. Such
entrapment may result in serious injury or death.
In a collision, there is a greater risk of being thrown from a vehicle with an open
sunroof. You could also be severely injured or killed. Always fasten your seat belt
properly and make sure all passengers are properly secured.
Do not allow small children to operate the sunroof. Never allow your fingers, other
body parts, or any object to project through the sunroof opening. Injury may result.
WIND BUFFETING
• Wind buffeting can be described as a helicopter-type percussion sound. If buffeting
occurs with the rear windows open, adjust the front and rear windows together.
• If buffeting occurs with the sunroof open, adjust the sunroof opening, or adjust any
window. This will minimize buffeting.
45
ELECTRONICS
YOUR VEHICLE'S SOUND SYSTEM
1. Uconnect® Phone Button pg. 101
2. Uconnect® Voice Command Button pg. 69
3. Phone Hang Up Button pg. 101
4. Steering Wheel Audio control (Right) pg. 108
5. Steering Wheel Audio control (Left) pg. 108
6. Volume / Mute Knob
7. Assist Button pg. 56
46
ELECTRONICS
8. Emergency 911 Button pg. 56
9. Uconnect® Radio pg. 48
10. Uconnect® Radio Screen Off Button
11. Uconnect® Radio Back Button
12. Tune / Scroll Knob / Browse / Enter Button
13. Media Hub: Audio Jack, USB Port, and SD Card Slot (located inside front console) pg. 67
14. CD Player Inside Center Console pg. 67
47
ELECTRONICS
IDENTIFYING YOUR RADIO
Uconnect® 5.0
• 5” Touchscreen
• Three hard-keys on either side of the
display
Uconnect® 5.0
Uconnect® 8.4A
• 8.4” touchscreen
• Climate soft key in lower menu bar
Uconnect® 8.4A
Uconnect® 8.4AN
• 8.4” touchscreen
• Climate soft key in lower menu bar
• HD Button will be visible on right side of
screen when viewing AM or FM
• SiriusXM Travel Link feature listed within
Apps (US Market Only)
Uconnect® 8.4AN
48
ELECTRONICS
Uconnect® Access (AVAILABLE ON Uconnect® 8.4A AND
Uconnect® 8.4AN) (IF EQUIPPED)
• Uconnect® Access enhances your ownership and driving experience by connecting your
vehicle with a Built-in 3G cellular connection. Once registered for your included trial,
Uconnect® Access provides:
• The ability to remotely lock/unlock your doors and start your vehicle from virtually
anywhere, with the Uconnect® Access App, Owner Connect website and Uconnect®
Care (Vehicle must be within the United States and have network coverage).
• The functionality to turn your vehicle into a WiFi Hotspot on demand.
• Theft Alarm Notification via text or email.
Voice Texting (U.S. Residents Only)
• Want to dictate a personal message? Register with Uconnect® Access to take advantage
of a new, cloudbased Voice Texting service, an enhancement to Voice Text Reply.
• Voice Texting allows you to compose a new text or reply to an incoming text message.
Before you attempt to use the Voice Texting feature, check to ensure you have the
following:
1. A paired, Bluetooth® enabled phone with the Message Access Profile (MAP). Not all
Bluetooth® enabled phones support MAP, including all iPhones® (Apple iOS). Visit
www.UconnectPhone.com for system and device compatibility information.
2. An active Uconnect® Access trial or paid subscription. Press the ‘U’ button on the lower
right hand corner of the touchscreen to begin the registration process.
3. Accept the Allow MAP profile request on your smart phone. (Please refer to device
manufacturer instructions for details).
Before you drive, familiarize yourself with the easy-to-use Uconnect® System.
1. The ASSIST and 9-1-1 buttons are located on your rearview mirror. The ASSIST Button is
used for contacting Roadside Assistance, Vehicle Care and Uconnect® Care. The 9-1-1
Button connects you directly to emergency assistance.
NOTE:
Vehicles sold in Canada and Mexico DO NOT have 9-1-1 Call system capabilities. 9-1-1 or
other emergency line operators in Canada and Mexico may not answer or respond to 9-1-1
system calls.
2. The Uconnect® 'Apps' button located in the bottom right corner of the radio touchscreen
is where you should begin the registration process for your included trial of Uconnect®
Access. From here, you can also manage your Apps and purchase WiFi.
3. The Uconnect® Voice Command and Uconnect® Phone buttons are located on the left
side of your steering wheel. These buttons allow you to use your voice to make phone
calls, send and receive text messages, control your media center, navigation destinations and more all without taking your hands off the steering wheel.
49
ELECTRONICS
Included Trial Period for New Vehicles
• Your new vehicle may come with an included trial period for use of the Uconnect® Access
Services starting at the date of vehicle purchase (date based on vehicle sales notification from your dealer). To activate the trial, you must first register with Uconnect®
Access.
Features and Packages
• After the included trial period, you can subscribe to continue your service by visiting the
Uconnect® Store located within the Mopar Owner Connect website (www.moparownerconnect.com). If you need assistance, U.S. residents can call Uconnect® Care at 855792-4241.
• For the latest information on packages and pricing information: U.S. residents visit
www.DriveUconnect.com.
Vehicle Health Report (If Equipped)
• Uconnect® Access equipped vehicles have diagnostic capabilities that check several
systems and are able to translate diagnostics into an easy-to-read Vehicle Health
Report. The report provides a status of specific vehicle systems and gives recommended
actions if an alert is detected. It can be accessed and viewed at any time after logging in
to your Mopar Owner Connect Account at www.moparownerconnect.com.
• When the report is available each month, customers will receive an email containing a
link to access the report. It can be easily viewed from a desktop, laptop, smartphone or
tablet. These are a few of the benefits it offers:
• Helps with vehicle maintenance
• Helps understand dashboard warning lights
• Helps save time at the dealership
NOTE:
The vehicle Health report will provide a status of specific pre-defined systems and help
serve as a guide in understanding your vehicle. It is not meant to provide comprehensive
vehicle diagnostics or take the place of an inspection at your dealership. If you suspect
potential issues with the operation of your vehicle, whether or not anything is reflected in
the vehicle health report, please contact your dealership.
How it Works
• After taking delivery of your Uconnect® Access equipped vehicle, register with
Uconnect® Access and create a Mopar Owner Connect Account.
• When a Vehicle Health Report is available, an email will be sent to the customer’s email
address (provided during registration) as notification to view the report.
• When the email arrives, open the email, click on the link, and login to your Mopar Owner
Connect Account. If the email does not arrive, check the spam filter on your email.
• After you login to your Mopar Owner Connect account, click on the Maintain and Care tab.
50
ELECTRONICS
• Review the Vehicle Health Report page containing descriptions of key vehicle systems
being monitored. Click each system heading on the report to expand the information and
read more about the particular monitored system and function.
• If a potential issue is detected in any area, the section under the affected area will be
displayed in an expanded format to show description of the issue and recommended actions.
• The vehicle health report can be viewed at any time in your Mopar Owner Connect
Account on Mopar Owner Connect.
Requirements
• Vehicle must be equipped with Uconnect® Access.
• Customer must register with Uconnect® Access, and activate the service by accepting
the Terms and Conditions during the registration process.
• Vehicle must be operational, and in area with cellular coverage.
• Available with Uconnect® 8.4A and Uconnect® 8.4AN radios.
• US Market only.
WARNING!
ALWAYS drive safely with your hands on the wheel. You have full responsibility and
assume all risks related to the use of the Uconnect® features and applications in this
vehicle. Only use Uconnect® Access features when it is safe to do so. Failure to do so
may result in an accident involving serious injury or death.
Disclaimer
• The Vehicle Health Report and Mopar Owner Connect website are meant to provide a
notification if a monitored vehicle feature triggers an alert. This product should be used as a
supplement to a regular automotive maintenance program. If you experience an issue with
your vehicle, you should consult an authorized Chrysler dealership for assistance.
Uconnect® Access via Mobile Registration (Uconnect® 5.0 only, U.S. 48 contiguous
states and Alaska)
To unlock the full potential of Uconnect® Access via Mobile in your vehicle, you first need to
register with Uconnect® Access.
1. From the parked vehicle with the radio touchscreen powered on, press the “More +”
hard-key located to the right of the display.
2. Touch the “Apps” soft-key on the radio touchscreen. If you do not see the Apps button on
the display, your radio does not have Uconnect® Access via Mobile.
3. Next touch the “Setup” soft-key on the screen and follow the instructions that follow.
NOTE:
Should you require assistance anytime during the registration process visit
www.DriveUconnect.com/features/via-mobile/ or call Uconnect® Care at 855-792-4241.
51
ELECTRONICS
Uconnect® Access Registration (Uconnect® 8.4A and 8.4AN only, U.S. 48 contiguous
states and Alaska)
NOTE:
Should you require assistance anytime during the registration process, simply call
Uconnect® Care at 855-792-4241.
1. From the parked vehicle with the radio touchscreen powered on, select the “Apps”
soft-key located near the bottom right-hand corner of the radio touchscreen.
2. Press 'Register' on the reminder screen or select 'Uconnect Registration' under the
'Favorites' tab.
3. The Uconnect® Access Registration App will open and display step-by-step instructions
to start your registration.
4. Enter your email address into the radio touchscreen.
5. A message will display on the touchscreen indicating your email submission was
accepted. In a few minutes, you will receive an email which will allow you to register your
vehicle for Uconnect® Access. You should open this email and begin your Uconnect®
Access registration "online" within 24 hours.
6. A final message will display on the touchscreen allowing you to check on the status of
your email submission. To exit the registration, press the X in the upper right corner.
7. Check for an email from Uconnect® Access that contains your personalized registration
link. If you don't see it, check your spam or junk email folder. Open the email and click on
the link to continue registering.
NOTE:
For security reasons, this link is valid for 24 hours from the time you submit your email address
into the radio touchscreen. If the link has expired, simply re-enter your email address into the
Uconnect® Registration App on the radio touchscreen to receive another link.
• The secured registration link will take you through the Uconnect® Access registration
process step by step.
• To unlock the full potential of Uconnect® Access in your vehicle, you will need to create
or validate an existing Mopar Owner Connect account (previously Owner Center).
Uconnect® along with Mopar Owner Connect have joined forces to create one destination to manage all of your vehicle needs - from managing your Uconnect® Access
account to tracking service history and finding recommended accessories for your
vehicle. If you already have a Mopar Owner Connect account, log in to the website with
your existing user name and password. For assistance with this web based registration process, U.S. residents can call Uconnect® Care at 855-792-4241.
• At this point your vehicle is registered with Uconnect® Access. Apps will be downloaded the next time you start your vehicle. It may take over 30 minutes for all of the
apps to install. If the apps have not appeared after 24 hours, please contact
Uconnect® Care. The recommended next steps are to:
8. Set up your Payment Account. (Provides the option to purchase packages and apps,
such as WiFi Hotspot)
52
ELECTRONICS
Download the Uconnect® Access App
• If you own a compatible Apple or Android® powered device, the Uconnect Access App
allows you to remotely lock or unlock your doors, start your engine or activate your horn
and lights from virtually anywhere (Vehicle must be within the United States and have
network coverage). You can download the App from Mopar Owner Connect or from the
Apple App or Google Play store. For Uconnect® phone compatibility - visit
www.UconnectPhone.com or call 1–877–855–8400.
Set up your Via Mobile Profile
NOTE:
Complete your Via Mobile Profile online during registration of your Uconnect Access
system. You can come back to this page by logging into your Mopar Owner Connect account
(www.moparownerconnect.com), going to Edit Profile, then Via Mobile Profile.
1. Download the Uconnect® Access App.
• If you haven’t done so already, download the Uconnect Access App to an Apple or
Android® compatible smartphone. This is required to use Via Mobile Apps in your
vehicle. Enter your mobile phone number to receive a text message containing a link
to download the app, or visit iTunes Apps Store (iPhone) or Google Play (Android) to
download the app by searching for “Uconnect Access App.”
2. Set up your Via Mobile Apps. If you already have an account with these apps, click “Set
Up” to enter your information. If you do not have an account, you can create a new one.
• Aha (www.aharadio.com)
• Enter your email address and password for Aha, or create a new Aha account.
• You can link your Facebook or Twitter accounts on Aha’s website .
• iHeartRadio (www.iheart.com)
• Click “Sign Up” if you’re new to iHeartRadio, or “Log In” to enter your iHeartRadio
account information.
• Select “Activate” to continue,
• Select “Close” to complete activation.
• Pandora® (www.pandora.com)
• Enter your Pandora® username/email address and password, then click “Save.”
• Slacker Radio (www.slacker.com)
• Enter your Slacker Radio username/email address and password, then click “Save.”
3. Invite Family and Friends.
• Invite family and friends to use the Via Mobile Apps in your vehicle using their own
account preferences (vehicle must be setup for Via Mobile).
53
ELECTRONICS
Purchasing Apps and WiFi (Uconnect® 8.4A and 8.4AN Only, U.S. 48 contiguous states
and Alaska)
• Apps and WiFi can be purchased from the Uconnect® Store within your vehicle, and
online at Mopar Owner Connect. You must first register and set up a Uconnect® Access
Payment account.
Purchasing Apps and WiFi From your vehicle
1. With the vehicle parked and the radio powered on, select the “Apps” soft-key located near
the bottom right-hand corner of the radio touchscreen.
2. To launch the Uconnect® Store, select Tools and then select Uconnect® Store.
3. From the Uconnect® Store, select the Application (App) you wish to purchase.
4. This will launch the selected App into purchase mode along with providing additional
information. The purchase process begins when you touch the “Buy” soft-key.
5. The Uconnect® Store will display a “Purchase Overview” message confirming the financial details for the App you are about to purchase. Touch the “Purchase” key to continue.
6. The Uconnect® Store will ask you to “Confirm Payment” using your default payment
method on file in your Payment Account. Touch the Complete key to continue.
7. The Uconnect® Payment Account will then ask for your “Payment Account PIN”. After
entering this four digit PIN, touch the Complete key to make the purchase.
8. You will receive a confirmation message that your purchase has been submitted. Touch
the OK to end the process.
NOTE:
Purchased apps can take up to 30 minutes to download, depending on your vehicle’s
cellular coverage at time of purchase. If your download takes more than 30 minutes, please
contact Uconnect® Care by pressing the ASSIST button on the rear view mirror or by calling
855-792-4241.
• You can also purchase apps or renew your subscription to a package from the Mopar
Owner Connect website. Log In to the Mopar Owner Connect website (www.moparownerconnect.com) with your user name and password, and click on the “Store” tab.
Using Uconnect® Access
Getting Started with Apps
• Applications (Apps) and features in your Uconnect® Access system deliver services that are
customized for the driver and are certified by Chrysler Group, LLC. Two different types are:
• Built-In Features – use the built-in 3G Cellular Network on your Uconnect® 8.4A or
8.4AN radio.
• Uconnect® Access via Mobile – Uconnect® Access via Mobile uses your smartphone’s
existing data plan to access Uconnect® System-enabled apps, which you can control
both using your touchscreen and steering wheel controls. Customer’s data plan
charges will apply. Available on Uconnect® 5.0, 8.4A and 8.4AN Radios (if equipped).
54
ELECTRONICS
• Get started with your Uconnect® Access apps by pressing the Uconnect® “Apps” soft-key
on the menu bar at the bottom right corner of the radio touchscreen. Available apps and
features are organized by the tabs on the left of the screen.
• Favorite Apps – this is the default screen when you first press the Apps soft-key, and
is a good place to put the apps you use most frequently. To make an App a “favorite”,
press the settings soft-key to the right of the app, and select “Make a favorite”.
• All Apps – Organizes your Uconnect® Access apps (when available).
• Running Apps – press this tab to see which apps are currently running.
Maintaining Your Uconnect® Access Account
Reinstalling an App (Uconnect® 8.4A and 8.4AN only)
• You can easily correct many Application related issues you may be experiencing by
resetting the App back to the factory setting. From the vehicle’s radio touchscreen,
complete the following steps:
1. Touch the Uconnect® App and open the Uconnect® Store and go to My Apps.
2. In My Apps, select Settings and then Reinstall App and lastly, Continue.
3. Your Apps have been successfully re-installed.
Canceling Your Subscription
• Should you want to cancel your subscription, you can remove your account information
using the same procedure contained in the Selling Your Vehicle section.
55
ELECTRONICS
Selling Your Vehicle
• When you sell your vehicle, we recommend that you remove your Uconnect® Access
Account information from the vehicle. You can do this using the radio touchscreen in the
vehicle (Uconnect® 8.4A and 8.4AN only) or on the Mopar Owner Connect website
(www.moparownerconnect.com). Removing your account information cancels your subscription and makes your vehicle factory-ready for a new owner/subscriber.
1. From your vehicle’s radio touchscreen, select the Uconnect® Store from the Apps icon.
2. Select My apps, then Settings, and then Remove Uconnect® Account.
3. Enter your Uconnect® Security PIN, select “Proceed to Remove Vehicle from Uconnect
Account”.
• For additional information on Uconnect®:
U.S. residents - visit www.DriveUconnect.com or call 1-877-855-8400.
Canadian Residents - visit www.DriveUconnect.com or call, 1-800-465-2001 (English)
or 1-800-387-9983 (French).
Built-In Features (Uconnect® 8.4A and 8.4AN only)
1. Assist Call – The rear view mirror contains an ASSIST push button which (once registered) automatically connects the vehicle occupants to one of these predefined destinations for immediate support:
• Roadside Assistance Call – If you get a
flat tire, or need a tow, you’ll be connected to someone who can help anytime. Additional fees may apply. Additional information in this section.
• Uconnect® Access Care – In vehicle
support for Uconnect® Access System,
Apps and Features.
• Vehicle Care – Total support for your
Chrysler Group LLC vehicle.
2. Emergency 9-1-1 Call (If Equipped) – The rear view mirror contains a 9-1-1 button that,
when pressed, will place a call to a local 9-1-1 operator to request help from local police,
fire or ambulance personnel in the event of an emergency. If this button is accidentally
pressed, you will have 10 seconds to cancel the call. To cancel, press the 9-1-1 Call button
again or press the cancellation button shown on the touchscreen. After 10 seconds has
passed, the 9-1-1 call will be placed and only the 9-1-1 operator can cancel it. The LED
light on the Rearview Mirror will turn green once a connection to a 9-1-1 operator has been
made. The green LED light will turn off once the 9-1-1 call is terminated. Have an
authorized dealer service the vehicle if the Rearview Mirror light is continuously red. If a
connection is made between a 9-1-1 operator and your vehicle, you understand and
agree that 9-1-1 operators may, like any other 9-1-1 call, record conversations and
sounds in and near your vehicle upon connection.
56
ELECTRONICS
3. Roadside Assistance (If Equipped) - If your vehicle is equipped with this feature and
within wireless range, you may be able to connect to Roadside Assistance by pressing
the “Assist” button on the Rearview Mirror. You will be presented with Assist Care
options. Make a selection by touching the prompts displayed on the radio If Roadside
Assistance is provided to your vehicle, you agree to be responsible for any additional
roadside assistance service costs that you may incur. In order to provide Uconnect®
Services to you, we may record and monitor your conversations with Roadside Assistance, Uconnect® Care or Vehicle Care, whether such conversations are initiated
through the Uconnect® Services in your vehicle, or via a landline or mobile telephone,
and may share information obtained through such recording and monitoring in accordance with regulatory requirements. You acknowledge, agree and consent to any recording, monitoring or sharing of information obtained through any such call recordings.
4. Yelp® - Customers have the ability to search for nearby destinations or a point of interest
(POI) either by category or custom search by using keywords (for example, “Italian
restaurant”). Searching can be done by voice or using the touchscreen keypad. Using the
touchscreen, launch Yelp® by selecting the Apps icon, touch All Apps tab, and then touch
Yelp®. Using voice recognition press the VR button on the steering wheel and say
“Launch Yelp®.”
5. Theft Alarm Notification - The Theft Alarm Notification feature notifies you via E-mail
or text message (SMS) when the vehicle’s factory-installed theft alarm system has been
set-off. There are a number of reasons why your alarm may have been triggered, one of
which could be that your vehicle was stolen. If so, please see the details of the Stolen
Vehicle Assistance service below. When you register, Theft Alarm Notification is automatically set to send you an E-mail at the mail address you provide should the alarm go
off. You may also opt to have a text message sent to your mobile device.
6. Stolen Vehicle Assistance - If your vehicle is stolen, contact local law enforcement
immediately to file a stolen vehicle report. Once this report has been filed, Uconnect®
care can help locate your vehicle. The Uconnect® Care agent will ask for the stolen
vehicle report number issued by local law enforcement. Then, using GPS technology and
the built-in wireless connection within your vehicle, the Uconnect® Care agent will be
able to locate the stolen vehicle and work with law enforcement to help recover it.
(Vehicle must be within the United States, have network coverage and must be registered with Uconnect® Access with an active subscription that includes the applicable
feature).
7. WiFi Hotspot - WiFi Hotspot is on-demand WiFi 3G connectivity that's built-in and ready
to go whenever you are. Once your vehicle is registered for Uconnect® Access, you can
purchase a Wifi Hotspot subscription at the Uconnect® Store. After you've made your
purchase, turn on your signal and connect your devices. It's never been easier to bring
your home or office with you.
• Your vehicle must have a working electrical system in order for any of the in vehicle
Uconnect® features to operate.
57
ELECTRONICS
Uconnect® Access Remote Features
• If you own a compatible iPhone or Android® powered device, the Uconnect® Access App
allows you to remotely lock or unlock your doors, start your engine or activate your horn
and lights from virtually anywhere (Vehicle must be within the United States and have
network coverage). You can download the App from Mopar Owner Connect or from the
Apple App or Google Play store. Visit www.UconnectPhone.com to determine if your
device is compatible. For Uconnect® Phone customer support and to determine if your
device is compatible:
• U.S. residents - visit www.UconnectPhone.com or call 1–877–855–8400
1. Remote Start – This feature provides the ability to start the engine on your vehicle,
without the keys and from virtually any distance. You can send a request to your vehicle
in one of two ways:
• Using the Uconnect® Access App from a compatible smartphone
• From the Mopar Owner Connect website
• You can also send a command to turn-off an engine that has been remote started.
• After 15 minutes if you have not entered your vehicle with the key, the engine will shut
off automatically.
• This remote function requires your vehicle to be equipped with a factory-installed
Remote Start system. To use this feature after the Uconnect® Access App is downloaded, login with your user name and Uconnect® Security PIN.
• You can set-up notifications for your account to receive an E-mail or text (SMS)
message every time a command is sent. Log in to Mopar Owner Connect (www.moparownerconnect.com) and click on Edit Profile to manage Uconnect® Notifications.
2. Remote Door Lock/Unlock – This feature provides the ability to lock or unlock the door
on your vehicle, without the keys and from virtually any distance. You can send a request
to your vehicle in one of three ways:
• Using the Uconnect® Access App from a compatible smartphone
• From the Mopar Owner Connect website
• By contacting the Uconnect® Care on the phone
• To use this feature after the Uconnect® Access App is downloaded, login using your user
name and Uconnect Security PIN. Touch the App button on your smartphone with the
closed lock icon to lock the door, and touch the open lock icon to unlock the driver’s door.
• You can set-up notifications for your account to receive an E-mail or text (SMS)
message every time a command is sent. Log in to Mopar Owner Connect (www.moparownerconnect.com) and click on Edit Profile to manage Uconnect® Notifications.
58
ELECTRONICS
3. Remote Horn and Lights – It’s easy to locate a vehicle in a dark, crowded or noisy parking
area by activating the horn and lights. It may also help if you need to draw attention to
your vehicle for any reason. You can send a request to your vehicle in one of three ways:
• Using the Uconnect® Access App from a compatible smartphone
• From the Mopar Owner Connect website
• By contacting the Uconnect® Care on the phone
• To use this feature after the Uconnect® Access App is downloaded, login using your
user name and Uconnect® Security PIN. You can set-up notifications for your account
to receive an E-mail or text (SMS) message every time a command is sent. Log in to
Mopar Owner Connect (www.moparownerconnect.com) and click on Edit Profile to
manage Uconnect® Notifications.
4. Voice Texting (U.S. Residents Only) – Want to dictate a personal message? Register
with Uconnect® Access to take advantage of a new, cloudbased Voice Texting service, an
enhancement to Voice Text Reply.
• Voice Texting allows you to compose a new text or reply to an incoming text message.
Before you attempt to use the Voice Texting feature, check to ensure you have the
following:
a. A paired, Bluetooth® enabled phone with the Message Access Profile (MAP). Not all
Bluetooth® enabled phones support MAP, including all iPhones® (Apple iOS). Visit
www.UconnectPhone.com for system and device compatibility information.
b. An active Uconnect® Access trial or paid subscription. Press the ‘U’ button on the
lower right hand corner of the touchscreen to begin the registration process.
c. Accept the Allow MAP profile request on your smart phone. (Please refer to device
manufacturer instructions for details).
59
ELECTRONICS
To send a text message:
a. Press the Uconnect® Phone button,
b. Wait for the beep,
c. Say “Text.”
d. Uconnect® will prompt you “Say the phone number, or full name and phone type of
the contact you want to send a message to.”
e. Wait for the beep and say a contact that is in your phonebook, or a mobile phone
number that you would like to send the message to.
f. Uconnect® will prompt you “Please say the message that you would like to send” (If you
do not hear this prompt, you may not have an active subscription with Uconnect®
Access).
g. Wait for the beep, and then dictate any message up to 140 characters. If you exceed
140 characters, you will hear the following prompt: “Message was too long; your
message will be truncated.”
h. Uconnect® will then repeat the message back to you.
i. Uconnect® will prompt you: “To add to your message, say ‘Continue’; To delete the
current message and start over, say ‘Start Over’; to send the current message, say
‘Send’; to hear the message again, say ‘Repeat’.
j. If you are happy with your message and would like to send it, wait for the beep and say
‘Send’.
k. Uconnect® will then say “Sending your message.”
Sample Commands for Voice Text Reply and Voice Texting
Example Command
“Text John Smith”
“Text 123 - 456 - 7890”
“Show messages”
“Listen to/view (message number four, for
example)”
“Reply”
“Forward text/message to ‘John Smith”
“Forward text/message to ‘123 - 456 - 7890”
60
Action
Send a message to specific contact in address book
Send 123 - 456 - 7890 a message from your
phonebook
See recent text messages listed by number
on Uconnect® screen
Hear messages or read it on Uconnect®
screen
Send a voice text reply to a current message
Forward current text to specific contact in
address book
Forward current text to specific phone number
ELECTRONICS
WARNING!
•
•
•
•
•
ALWAYS drive safely with your hands on the steering wheel. You have full responsibility and assume all risks related to the use of the Uconnect® features and applications in this vehicle. Only use Uconnect® when it is safe to do so. Failure to do so may
result in an accident involving serious injury or death.
Ignoring the Rearview Mirror light could mean you may not have 9-1-1 Call service
when you need it. If the Rearview Mirror light is illuminated, have an authorized dealer
service the 9-1-1 Call system immediately.
The Occupant Restraint Controller (ORC) turns on the Air Bag Warning Light on the
instrument panel if a malfunction is detected in any part of the air bag system. If the Air
Bag Warning Light is illuminated, the air bag system may not be working properly and the
9-1-1 system may not be able to send a signal to a 9-1-1 operator. If the Air Bag Warning
Light is illuminated, have an authorized dealer service your vehicle immediately.
If anyone in the vehicle could be in danger (e.g., fire or smoke is visible, dangerous
road conditions or location), do not wait for voice contact from a 9-1-1 operator. All
occupants should exit the vehicle immediately and move to a safe location.
The 9-1-1 Call system is embedded into the vehicle’s electrical system. Do not add any
aftermarket electrical equipment to the vehicle’s electrical system. This may prevent
your vehicle from sending a signal to initiate an emergency call. To avoid interference
that can cause the 9-1-1 Call system to fail, never add aftermarket equipment (e.g.,
two-way mobile radio, CB radio, data recorder, etc.) to your vehicle’s electrical system or
modify the antennas on your vehicle. IF YOUR VEHICLE LOSES BATTERY POWER FOR ANY
REASON (INCLUDING DURING OR AFTER AN ACCIDENT), THE UCONNECT® FEATURES,
APPS AND SERVICES, AMONG OTHERS, WILL NOT OPERATE.
Sample Commands for Voice Text Reply and Voice Texting
Example Command
“Text John Smith”
“Text 123 - 456 - 7890”
“Show messages”
“Listen to/view (message number four, for
example)”
“Reply”
“Forward text/message to ‘John Smith”
“Forward text/message to ‘123 - 456 - 7890”
Action
Send a message to specific contact in address book
Send 123 - 456 - 7890 a message from your
phonebook
See recent text messages listed by number
on Uconnect® screen
Hear messages or read it on Uconnect®
screen
Send a voice text reply to a current message
Forward current text to specific contact in
address book
Forward current text to specific phone number
61
ELECTRONICS
Uconnect® Access via Mobile (If Equipped, Available on Uconnect® 8.4A and 8.4AN)
• Uconnect® Access via Mobile offers additional apps such as Aha, iHeartRadio, Pandora
and Slacker Radio. It uses your smartphone’s existing data plan to access Uconnect®
System-enabled apps, which you can control using both your touchscreen and steering
wheel controls. Customer’s data plan charges will apply.
• To get started using Via Mobile apps, first register your Uconnect® Access system where
you'll be guided through the setup of your Via Mobile (requires a compatible Android or
iPhone smartphone). Please refer to “Uconnect® Access Registration” for more information.
• If using an Android smartphone, the Apps will function using a Bluetooth connection.
Pair your smartphone to the radio.
• If using an iPhone smartphone, plug the iPhone into the radio using a USB cable.
• Launch the Uconnect® Access App on your smartphone, and log in with your username
and password that was set up during registration. Accept the Terms and Conditions.
• Ensure that Via Mobile data has been
turned on under “Settings” in the
Uconnect® Access App.
• A green indicator next to the words Via
Mobile will show when it is ready to provide data to the radio (a blue indicator
when data is being sent). A red indicator
means that it is not ready to provide
data.
• Each time you want to use a Via Mobile
app in your vehicle, the Uconnect® Access App must be running on your smartphone and the smartphone must be
paired or connected to the radio.
(Bluetooth® connection for Android, USB
cable for iPhone).
62
ELECTRONICS
• If equipped, the Via Mobile apps can be found by selecting the “Apps” soft-key in the
lower right corner of the radio touchscreen. Via Mobile apps are listed under the “All
Apps” tab. The words “Via Mobile” will appear after the app name indicating it is a Via
Mobile app.
• Via Mobile apps can also be launched through Voice Recognition by pressing the VR
button on the steering wheel and stating “launch” and then the name of the app. For
example, you can say “launch Aha via Mobile.”
63
ELECTRONICS
NOTE:
For detailed information on how to use Via Mobile apps visit the Mopar Owner Connect
website (www.moparownerconnect.com) and log in using the username and password you
set up when registering for Uconnect® Access.
• A message will be displayed to remind you that Via Mobile apps utilize the data plan on
your connected smartphone to provide content. Many smartphones have a limit to how
much data they can utilize before incurring additional charges. The amount of data being
used varies by smartphone device, cellular service provider and specific app. Check your
mobile phone service plan for more details.* Touch “OK” to continue or the “X” to exit.
(*Additional smartphone data usage charges may apply.)
Via Mobile Apps (if equipped)
• Aha
• Easily access and organize your favorite content from the web into personalized, live
and on-demand stations. Choose from stations spanning Internet radio, personalized
music, hotels, weather, audiobooks, Facebook®, Twitter® and more.
• iHeartRadio
• iHeartRadio provides instant access to more than 1,500 live radio stations from across
the country and allows listeners to create their own stations inspired by their favorite
artists or songs.
• Pandora®
• Pandora® gives people the music and comedy they love anytime, anywhere. Personalized stations launch instantly, with the input of a favorite artist, track, comedian, or
genre. Easily control Pandora® through an intuitive interface via the radio touchscreen
and steering wheel controls.
• Slacker
• Slacker is the most complete music service on Earth. Enjoy millions of songs and
hundreds of expert-programmed stations - anytime, anywhere through Uconnect®
Access via Mobile.
• For detailed information on how to use Via Mobile apps visit the Mopar Owner Connect
website (www.moparownerconnect.com) and log in using the username and password
you set up when registering for Uconnect® Access.
64
ELECTRONICS
Uconnect® 5.0
Setting the Time
1. Press the More hard-key on the right side of the display, next press the Settings soft-key
and then the Time soft-key. OR Press the Settings hard-key on the right side of the
display, then press the Clock soft-key. The Time setting screen is displayed and the clock
can be adjusted as described in the following procedure.
NOTE:
In the Clock Setting Menu you can also select Display Clock. Display Clock turns the clock
display in the status bar on or off.
2. Touch the Up or Down arrows to adjust the hours or minutes, next select the AM or PM
soft-key. You can also select 12hr or 24hr format by touching the desired soft-key.
3. Once the time is set press the “Done” soft-key to exit the time screen.
Equalizer, Balance and Fade
1. Press the SETTINGS hard-key on the right side of the unit.
2. Then scroll down and press the Audio soft-key to get to the Audio menu.
3. The Audio Menu shows the following options for you to customize your audio settings.
Equalizer
• Touch the Equalizer soft-key to adjust the Bass, Mid and Treble. Use the + or - soft-key to
adjust the equalizer to your desired settings. Press the back arrow soft-key when done.
65
ELECTRONICS
Balance/Fade
• Touch the Balance/Fade soft-key to adjust the sound from the speakers. Use the arrow
soft-key to adjust the sound level from the front and rear or right and left side speakers.
Touch the Center “C” soft-key to reset the balance and fade to the factory setting. Press
the back arrow soft-key when done.
Speed Adjusted Volume
• Touch the Speed Adjusted Volume soft-key to select between OFF, 1, 2 or 3. This will
decrease the radio volume relative to a decrease in vehicle speed. Press the back arrow
soft-key when done.
Loudness
• Touch the Loudness soft-key to select the Loudness feature. When this feature is
activated it improves sound quality at lower volumes.
Surround Sound
• Touch the Surround Sound soft-key, select On or Off followed by pressing the arrow back
soft-key. When this feature is activated, it provides simulated surround sound mode.
Radio Operation
Seek Up/Down Buttons
• Press to seek through radio stations in AM, FM or SXM bands.
• Hold either button to bypass stations without stopping.
Store Radio Presets
• When you are receiving a station that you wish to commit into memory, press and hold
the desired numbered soft-key for more than two seconds, or until you hear a confirmation beep.
• The Radio stores up to 12 presets in each of the Radio modes. Four presets are visible at
the top of the radio screen. Touching the “all” soft-key on the radio home screen will
display all of the preset stations for that mode.
SiriusXM Premier Over 160 channels
• Get every channel available on your satellite radio, and enjoy all you want, all in one place.
Hear commercial-free music plus sports, news, talk and entertainment. Get all the
premium programming, including Howard Stern, every NFL game, Oprah Radio®, every
MLB® and NHL® game, every NASCAR® race, Martha Stewart and more. And get 20+
extra channels, including SiriusXM Latino, offering 20 channels of commercial free
music, news, talk, comedy, sports and more dedicated to Spanish language programming.
• To access SiriusXM Satellite Radio, press the “RADIO” hard-key and then the SXM
soft-key.
66
ELECTRONICS
• SiriusXM services require subscriptions, sold separately after the 12-month trial included
with the new vehicle purchase. If you decide to continue your service at the end of your trial
subscription, the plan you choose will automatically renew and bill at then-current rates
until you call SiriusXM at 1-866-635-2349 for U.S. residents and 1-888-539-7474 for Canadian residents to cancel. See SiriusXM Customer Agreement for complete terms at
www.siriusxm.com for U.S. residents and www.siriusxm.ca for Canadian residents. All
fees and programming subject to change. Our satellite service is available only to those
at least 18 and older in the 48 contiguous USA and D.C. Our Sirius satellite service is also
available in PR (with coverage limitations). Our Internet radio service is available throughout our satellite service area and in AK and HI. © 2013 Sirius XM Radio Inc. Sirius, XM and
all related marks and logos are trademarks of Sirius XM Radio Inc.
Disc Operation
• Your vehicle may have a remote CD player located in the lower center console storage bin.
• CD/Disc Mode is entered by either inserting a CD/Disc or by touching the Media button
located on the side of the display. Once in Media Mode, select Disc.
• Gently insert one CD into the CD player with the CD label facing as indicated on the
illustration located on the Disc player.
Seek Up/Down Buttons
• Press to seek through Disc tracks.
• Hold either button to bypass tracks without stopping.
Browse
• Touch the Browse soft-key to scroll through and select a desired track on the Disc. Touch
the Exit soft-key if you wish to cancel the browse function.
USB/Audio Jack (AUX)/Bluetooth® Operation
USB/iPod®
• USB/iPod® Mode is entered by either inserting a USB Jump Drive or iPod® cable into the
USB port or by touching the Media hard-key located left of the display. Once in Media
Mode, touch the source soft-key and select USB/iPod®
• Pressing the Media hard-key, then touch the source soft-key and then select USB/iPod®
to change the mode to the USB device if the device is connected, allowing the music from
your portable device to play through the vehicle's speakers.
Audio Jack (AUX)
• The AUX allows a portable device, such as an MP3 player or an iPod®, to be plugged into
the radio and utilize the vehicle’s audio system, using a 3.5 mm audio cable, to amplify
the source and play through the vehicle speakers.
• Pressing the Media hard-key, then touch the source soft-key and then select AUX to
change the mode to auxiliary device if the audio jack is connected, allowing the music
from your portable device to play through the vehicle's speakers.
• The functions of the portable device are controlled using the device buttons, not the
buttons on the radio. The volume may be controlled using the radio or portable device.
67
ELECTRONICS
Bluetooth®
• If using a Bluetooth® - equipped device, you may also be able to stream music to your
vehicle's sound system.
• Press the Media hard-key, then touch the Source soft-key. Select Bluetooth® to change
the mode to Bluetooth® if the device is paired, allowing the music from your portable
device to play through the vehicle's speakers.
Uconnect® 5.0 Available Media Hubs
Uconnect® 5.0
Media Hub (SD, USB, AUX
Ports)
S
Dual Charging Ports
O
S = Standard Equipment
O = Optional Equipment
Voice Text Reply
• Once your Uconnect® system is paired with a compatible mobile device, the system can
announce a new incoming text message, and read it to your over the vehicle audio
system. You can reply to the message using Voice Recognition, by selecting, or saying
one of the 18 pre-defined messages.
• Here’s how: Press the Uconnect® Phone button
and wait for the beep, then say “reply”.
Uconnect® will give the following prompt: “ Please say the message you would like to send”.
Wait for the beep and say one of the pre-defined messages. (If you are not sure, you can say
“help”). Uconnect® will then read the pre-defined messages allowed. As soon as you hear the
message you would like to send, you can interrupt the list of prompts by pressing the
Uconnect® phone button and saying the phrase. Uconnect® will confirm the message by
reading it back to you. Then press the Phone button and say “Send.”
Example Command
“Text John Smith”
“Text 123–456–7890”
Action
Send John Smith a message from your phone
Send 123–456–7890 a message from your
phone
“Show messages”
See recent text messages listed by number on
Uconnect® screen
“Listen to/view (message number four, for ex- Hear messages or read it on Uconnect® screen
ample)”
“Reply”
Send a voice text reply to a current message
“Forward text/message to ‘John Smith”
Forward current text to specific contact in address book
“Forward text/message to ‘123–456–7890”
Forward current text to specific phone number
• Voice texting reply and voice texting features require a compatible mobile device enabled with Bluetooth® Message Access Profile (MAP). iPhone® and some other smartphones do not currently support Bluetooth® MAP. Visit www.UconnectPhone.com for
system and device compatibility.
68
ELECTRONICS
• Want to dictate a personal message? You must first register with Uconnect® Access (U.S.
residents only) to take advantage of a new, cloud-based Voice Texting service, an
enhancement to Voice Text Reply.
WARNING!
•
•
Any voice commanded system should be used only in safe driving conditions following applicable laws regarding phone use. Your attention should be focused on safely
operating the vehicle. Failure to do so may result in a collision causing you and others
to be severely injured or killed.
In an emergency, to use Uconnect® Phone, your mobile phone must be:
• turned on,
• paired to Uconnect® Phone,
• and have network coverage.
VOICE COMMAND QUICK REFERENCE
Uconnect® 5.0 Voice Command Quick Reference
• If the Uconnect® Voice Command
button exists on your steering wheel, you have
the Voice Command feature, which is optimized for the driver. The Voice Command
feature lets you keep your hands on the wheel, and your eyes on the road.
button located on the steering wheel, you
• When you press the Voice Command
will hear a beep. After the beep, give your command. If you do not know what commands
to say, you can say “help” and the system will provide options to you. If you ever wish to
button,
interrupt the system while it lists options, press the Voice Command
after the beep, say your command.
NOTE:
All phone oriented voice commands are accessible by first pressing the Phone Pick Up
button, not the Voice Command button. To end a call, simply press the Phone Hang Up
button. In some vehicle’s, the Phone Pickup
button serves the dual purpose
of ending calls as well.
69
ELECTRONICS
Voice Command (VR) User TIPs
• To hear available commands, press the Uconnect® Voice Command button and say
“Help”. You will hear available commands for the menu displayed.
• At any time, you can say the words “Cancel” or “Help”. These commands are universal
and can be used from virtually any menu. All other specific commands can be used
depending upon the active application.
• You can interrupt the system prompts at any time by pressing the Uconnect® Voice
Command button while the system is speaking. After the beep, you can say a command.
• You can ‘chain’ commands together for faster results. Say “Call Joe Doe mobile”, for
example.
• For best performance, adjust the rearview mirror to provide at least ½ in (1 cm) gap
between the overhead console (if equipped) and the mirror.
• Always wait for the beep before speaking.
• Speak normally, without pausing, just as you would speak to a person sitting a few
feet/meters away from you.
• Make sure that no one other than you is speaking during a Voice Command period.
Steering Wheel Buttons
• You can control many of your radio features using your voice. Press either the VR
or Phone Pick Up
button on
your steering wheel.
Steering Wheel
Buttons to
Press:
Types of Voice
Commands
Available
Uconnect® Voice AM/FM & SatelCommand (VR) lite Band Control
Button
Media Mode
Phone Mode
Media Devices
Control
-
GENERAL
Uconnect®
Phone Pick Up
Button
70
Radio Mode
-
-
Call Initiation,
Call Management, Predefined Voice
Text Reply
ELECTRONICS
Voice Command Examples – Uconnect® 5.0
While In:
Anytime
AM/FM
Satellite Band Control
Voice Command Example:
GENERAL
“Go to Radio” (Media, Phone) – Compass, Settings, and More
functions are not Voice Command accessible
“Cancel”
“Help” (to listen to suggested commands specific to current
need
“Repeat”
RADIO
“Tune to AM950”, “Tune to 95.5FM (preset 5)
“Tune to Satellite Channel 80's on 8”, Tune to Satellite Channel
32 (preset 4)
MEDIA
Media Devices Control
(Functionality is dependent
on compatibility between
devices and radio)
“Browse” (show) “artist” (albums, music)
“Show paired phones” (devices)
“Play song – Maple Leaf Rag” (artist - Scott Joplin, genre rock, album - Ragtime Favorites)
Call Initiation (Requires
that phone has been
Bluetooth® paired with radio
“Dial 123-456-7890” (phone number)
“Call John Smith mobile” (home, office, other)
“Redial”
“Show outgoing” (recent) “calls”
PHONE
“Search for John Smith” (any contact name in address book)
“Show (display list) contacts”
Forward one of 18 pre-defined SMS messages to incoming
calls/text messages:
Voice Text Reply (Radio
“Yes.”
audibly recognizes these 18 “No.”
pre-defined SMS messages “Okay.”
“I can’t talk right now.”
as you speak)
NOTE: Requires a compat- “Call me.”
ible mobile device enabled “I’ll call you later.”
“I’m on my way.”
with Bluetooth Message
“Thanks.”
Access Profile (MAP). iP“I’ll be late.”
hone and some other
“I will be <number> minutes late.”
smartphones do not cur“See you in <number> minutes”
rently support Bluetooth®
“Stuck in traffic.”
MAP. Visit
“Start without me.”
www.UconnectPhone.com “Where are you?”
“Are you there yet?”
for system and device
“I need directions.”
compatibility.
“I’m lost.”
“See you later.”
Call Management
71
ELECTRONICS
Uconnect® 8.4A
Uconnect® 8.4A AT A GLANCE
Displaying the Time
• If the time is not currently displayed on the radio or player main page, touch the Settings
soft key or the Apps soft-key and then the Settings soft-key. In the Settings list, touch the
Clock soft-key then touch the check box next to Show Time in Status Bar.
Setting the Time
• Model 8.4AN synchronizes time automatically via GPS, so it should not require any time
adjustment. If you do need to set the time manually, follow the instructions below for
Model 8.4A.
• For Model 8.4A, turn the unit on, then touch the time display at the top of the screen.
Touch Yes.
• If the time is not displayed at the top of the screen, touch the Controls soft-key or the
Apps soft-key and then the Settings soft-key. In the Settings screen, touch the Clock
soft-key, then check or uncheck this option.
• Touch + or – next to Set Time Hours and Set Time Minutes to adjust the time.
• If these features are not available, uncheck the Sync with GPS box.
• Touch X to save your settings and exit out of the Clock Setting screen.
72
ELECTRONICS
Audio Settings
• Touch of the Audio soft-key to activate the Audio settings screen to adjust
Balance\Fade, Equalizer, and Speed Adjusted Volume.
• You can return to the Radio screen by touching the X located at the top right.
Balance/Fade
• Touch the Balance/Fade soft-key to Balance audio between the front speakers or fade
the audio between the rear and front speakers.
• Touching the Front, Rear, Left, or Right soft-keys or touch and drag the Speaker Icon to
adjust the Balance/Fade.
Equalizer
• Touch the Equalizer soft-key to activate the Equalizer screen.
• Touch the + or - soft-keys, or by touching and dragging over the level bar for each of the
equalizer bands. The level value, which spans between plus or minus 9, is displayed at
the bottom of each of the Bands.
Speed Adjusted Volume
• Touch the Speed Adjusted Volume soft-key to activate the Speed Adjusted Volume
screen. The Speed Adjusted Volume is adjusted by touching the + and - buttons or by
touching and dragging over the level bar. This alters the automatic adjustment of the
audio volume with variation to vehicle speed.
Surround Sound
• Touch the Surround Sound soft-key, select On or Off followed by pressing the arrow back
soft-key. When this feature is activated, it provides simulated surround sound mode.
73
ELECTRONICS
RADIO
• To access the Radio mode, touch the Radio soft-key at the lower left of the screen.
Selecting Radio Stations
• Touch the desired radio band (AM, FM or SXM) soft-key.
Seek Up/Seek Down
• Touch the Seek arrow soft-keys for less than two seconds to seek through radio stations.
• Touch and hold either arrow soft-key for more than two seconds to bypass stations
without stopping. The radio will stop at the next listenable station once the arrow
soft-key is released.
Direct Tune
• Tune directly to a radio station by pressing the “Tune” button on the screen, and entering
the desired station number.
Store Radio Presets
• Your radio can store 36 total preset stations, 12 presets per band (AM, FM and SXM). They
are shown at the top of your radio screen. To see the 12 preset stations per band, press the
arrow soft-key at the top right of the screen to toggle between the two sets of six presets.
• To set a station into memory press and hold the desired numbered soft-key for more than
two seconds or until you hear a confirmation beep.
74
ELECTRONICS
SiriusXM PREMIER OVER 160 CHANNELS
• Get every channel available on your satellite radio, and enjoy all you want, all in one place.
Hear commercial-free music plus sports, news, talk and entertainment. Get all the
premium programming, including Howard Stern, every NFL game, Oprah Radio®, every
MLB® and NHL® game, every NASCAR® race, Martha Stewart and more. And get 20+
extra channels, including SiriusXM Latino, offering 20 channels of commercial free
music, news, talk, comedy, sports and more dedicated to Spanish language programming.
• To access SiriusXM Satellite Radio, touch the SXM soft-key on the main Radio screen.
• The following describes features that are available when in SiriusXM Satellite Radio
mode.
Seek Up/Seek Down
• Touch the Seek arrow soft-keys for less than two seconds to seek through channels in
SXM mode.
• Touch and hold either arrow soft-key for more than two seconds to bypass channels
without stopping. The radio will stop at the next listenable channel once the arrow
soft-key is released.
Direct Tune
• Tune directly to a SXM channel by pressing the Tune soft-key on the screen, and entering
the desired station number.
Jump
• Automatically tells you when Traffic & Weather for a favorite city is available, and gives
you the option to switch to that channel. Touch Jump to activate the feature. After
listening to Traffic and Weather, touch Jump again to return to the previous channel.
Fav
• Activates the favorites menu. You can add up to 50 favorite artists or songs. Just touch
Add Fav Artist or Add Fav Song while the song is playing. You will then be alerted any time
one of these songs, or works by these artists, is playing on other SiriusXM channels.
SiriusXM Parental Controls
• You can skip or hide certain channels from view if you do not want access to them. Touch
the More soft-key, then the Settings soft-key, next touch the Sirius Setup soft-key, then
select Channel Skip. Touch the box, check-mark, next to the channel you want skipped.
They will not show up in normal usage.
• SiriusXM also offers the option to permanently block selected channels. Call
(1-888-601-6297 for U.S. customers, 1-877-438-9677 for Canadian customers) and request the Family - Friendly Package.
75
ELECTRONICS
Browse
• Lets you browse the SiriusXM channel listing or Genre listing. Favorites, Game Zone,
Weather and Jump settings also provide a way to browse the SiriusXM channel list.
Browse
Sub-Menu
All
Genre
Presets
Favorites
Game Zone
Jump
Sub-Menu Description
Shows the channel listing.
Provides a list of all genres, and lets you jump to a channel within the selected
genre.
Lets you scroll the list of Preset satellite channels. Touch the channel, or press
Enter on the Tune knob, to go to that channel. Touch the trash can icon to delete a
preset. Your presets are also shown at the top of the main Satellite Radio screen.
Lets you manage artists and songs in the Favorites list and configure Alert
Settings to let you know when favorite songs or artists are playing on other
channels. Also, view a list of channels airing any of your Favorites.
Provides alerts when your favorite sports teams are starting a game which is being
aired on other SiriusXM channels, or when their game score is announced. You can
select and manage your Teams list here, and configure alerts.
Lets you select your favorite cities for Traffic & Weather information, which is
used by the Jump feature on the main satellite radio screen.
Replay
• Lets you replay up to 44 minutes of the content of the current SiriusXM channel.
Replay
Option
Play/Pause
Rewind/RW
Fast
Forward/FW
Replay Time
Live
Option Description
Touch to Pause content playback. Touch Pause/Play again to resume playback.
Rewinds the channel content in steps of five seconds. Touch and hold to rewind
continuously, then release to begin playing content at that point.
Forwards the content, and works similarly to Rewind/RW. However, Fast
Forward/FW can only be used when content has been previously rewound.
Displays the amount of time in the upper center of the screen by which your
content lags the Live channel.
Resumes playback of Live content at any time while replaying rewound content.
• SiriusXM services require subscriptions, sold separately after the 12-month trial included
with the new vehicle purchase. If you decide to continue your service at the end of your
trial subscription, the plan you choose will automatically renew and bill at thencurrent rates until you call SiriusXM at 1-866-635-2349 for U.S. residents and
1-888-539-7474 for Canadian residents to cancel. See SiriusXM Customer Agreement
for complete terms at www.siriusxm.com for U.S. residents and www.siriusxm.ca for
Canadian residents. All fees and programming subject to change. Our satellite service is
available only to those at least 18 and older in the 48 contiguous USA and D.C. Our Sirius
satellite service is also available in PR (with coverage limitations). Our Internet radio
service is available throughout our satellite service area and in AK and HI. © 2013 Sirius
XM Radio Inc. Sirius, XM and all related marks and logos are trademarks of Sirius XM
Radio Inc.
76
ELECTRONICS
Disc Operation
• Your vehicle may have a remote CD player located in the lower center console storage
bin.
• CD/Disc Mode is entered by either inserting a CD/Disc or by touching the Media button
located on the side of the display. Once in Media Mode, select Disc.
• Gently insert one CD into the CD player with the CD label facing as indicated on the
illustration located on the Disc player.
Seek Up/Down Buttons
• Press to seek through Disc tracks.
• Hold either button to bypass tracks without stopping.
Browse
• Touch the Browse soft-key to scroll through and select a desired track on the Disc. Touch
the Exit soft-key if you wish to cancel the browse function.
MEDIA HUB – PLAYING iPod®/USB/MP3 DEVICES
• There are many ways to play music from iPod®/MP3 players or USB devices through your
vehicle's sound system.
Audio Jack (AUX)
• The AUX allows a portable device, such as an MP3 player or an iPod®, to be plugged into
the radio and utilize the vehicle’s sound system, using a 3.5 mm audio cable, to amplify
the source and play through the vehicle speakers.
• Touching the Media soft-key then choose AUX source will change the mode to auxiliary
device if the audio jack is connected, allowing the music from your portable device to be
heard through the vehicle's speakers. In order to activate the AUX, plug in the audio jack.
• The functions of the portable device are controlled using the device buttons. The volume
may be controlled using the radio or portable device.
• To route the audio cable out of the center console, use the access cut out in the front of
the console.
USB Port
• Connect your iPod® or compatible device using a USB cable into the USB Port. USB
Memory sticks with audio files can also be used. Then, audio from the device can be
played on the vehicle’s sound system while providing metadata (artist, track title, album,
etc.) information on the radio display.
• When connected, the iPod®/compatible USB device can be controlled using the radio or
Steering Wheel Audio Controls to play, skip to the next or previous track, browse, and list
the contents.
• The iPod® battery charges when plugged into the USB port (if supported by the specific
device).
• To route the USB/iPod® cable out of the center console, use the access cut out.
77
ELECTRONICS
NOTE:
• When connecting your iPod® device for the first time, the system may take several
minutes to read your music, depending on the number of files. For example, the system
will take approximately five minutes for every 1000 songs loaded on the device. Also
during the reading process, the Shuffle and Browse functions will be disabled. This
process is needed to ensure the full use of your iPod® features and only happens the first
time it is connected. After the first time, the reading process of your iPod® will take
considerably less time unless changes are made or new songs are added to the playlist.
• The USB port supports certain Mini, Classic, Nano, Touch, and iPhone® devices. The USB
port also supports playing music from compatible external USB Mass Storage Class
memory devices. Some iPod® software versions may not fully support the USB port
features. Please visit Apple’s website for iPod® software updates.
SD Card
• Play songs stored on an SD card inserted into the SD card slot.
• Song playback can be controlled using the radio or Steering Wheel Audio Controls to play,
skip to the next or previous track, browse, and list the contents.
Bluetooth® Streaming Audio
• If equipped with Uconnect® Voice Command, your Bluetooth®-equipped iPod® devices,
cell phones or other media players, may also be able to stream music to your vehicle's
sound system. Your connected device must be Bluetooth®-compatible, and paired with
your system (see Uconnect® Phone for pairing instructions). You can access the music
from your connected Bluetooth® device by touching the Bluetooth® soft-key while in
Media mode.
Uconnect®
8.4A & 8.4AN
Media Hub
(USB, AUX
Ports)
-
S = Standard Equipment
O = Optional Equipment
78
Media Hub
(SD, USB,
AUX Ports)
S
Remote USB
Port (Fully
Functional)
S
Remote USB
Port (Charging Only)
O
Dual Charging Ports
O
ELECTRONICS
iPod®/CD/AUX CONTROLS
• The iPod®/CD/AUX controls are accessed by touching the desired soft-key displayed on
the side of the screen and choose between Disc, AUX, iPod®, Bluetooth® or SD Card.
NOTE:
Uconnect® will usually automatically switch to the appropriate mode when something is
first connected or inserted into the system.
NAVIGATION (DEALER-ACTIVATED OPTION)
• Your Uconnect® 8.4A is “Navigation-Ready”, and can be equipped with Navigation at an
extra cost. See your dealer for details.
• The information in this section is only applicable if the feature has been equipped. If so
equipped, you will see a Nav soft-key at the bottom of the touchscreen.
Changing the Navigation Voice Prompt Volume
1. Touch the Settings soft-key.
2. In the Settings menu, touch the Guidance soft-key.
3. In the Guidance menu, adjust the Nav Volume by touching the + or – Nav Volume
Adjustment soft-keys.
79
ELECTRONICS
Finding Points of Interest (POI)
• From the main Navigation menu, touch the Where To? soft-key, then touch the Points of
Interest soft-key.
• Select a Category and then a subcategory, if necessary.
• Select your destination and touch the Yes soft-key.
Finding a Place by Spelling the Name
• From the Main Navigation Menu touch the Where to? soft-key, touch the Points of
Interest soft-key and then touch the Spell Name soft-key.
• Enter the name of your destination.
• Touch the List soft-key.
• Select your destination and touch the Yes soft-key.
Entering a Destination Address
• From the main Navigation menu touch the Where To? soft-key, then touch the Address
soft-key.
• Follow the on-screen prompts (country, state/province, city, street) to enter the address
and touch the Yes soft-key.
• Destination entry is not available while your vehicle is in motion. However, you can also
use Voice Command to enter an address while moving. See Voice Command Tips for
more information.
80
ELECTRONICS
Setting Your Home Location
• Touch the NAV soft-key in the menu bar to access the Navigation system and the Main
Navigation menu.
• Touch the Where To? soft-key, then touch the Go Home soft-key.
• You may enter your address directly, use your current location as your home address, or
choose from recently found locations.
• To delete your Home location (or other saved locations) so you can save a new Home
location, touch the Where To? soft-key from the Main Navigation menu, then touch the
Go Home soft-key, and in the Yes screen touch the Options soft-key. In the Options menu
touch Clear Home. Set a new Home location by following the previous instructions.
Go Home
• A Home location must be saved in the system. From the Main Navigation menu, touch
the Where To? soft-key, then touch the Go Home soft-key.
• Your route is marked with a blue line on the map. If you depart from the original route, your
route is recalculated. A speed limit icon could appear as you travel on major roadways.
Adding a Stop
• To add a stop you must be navigating a route.
• Touch the Menu soft-key to return to the Main Navigation menu.
• Touch the Where To? soft-key, then search for the extra stop. When another location has
been selected, you can choose to cancel your previous route, add as the first destination
or add as the last destination.
• Touch the desired selection and touch the Yes soft-key.
81
ELECTRONICS
Taking a Detour
• To take a detour you must be navigating a route.
• Touch the Detour soft-key.
NOTE:
If the route you are currently taking is the only reasonable option, the device might not
calculate a detour.
• For more information, see your Uconnect® Supplement Manual.
Uconnect® Phone (Bluetooth® HANDS FREE CALLING)
• If the Uconnect® Phone Button
Uconnect® Phone features.
exists on your steering wheel, then you have the
• The Uconnect® Phone is a voice-activated, hands-free, in-vehicle communications
system with Voice Command Capability (see Voice Command section).
• The Uconnect® Phone allows you to dial a phone number with your mobile phone using
simple voice commands or using screen soft-keys.
• Refer to the Understand The Features Of Your Vehicle section of your vehicle's Owner's
Manual on the DVD for further details.
NOTE:
The Uconnect® Phone requires a mobile phone equipped with the Bluetooth® Hands-Free
Profile, Version 1.0 or higher. For Uconnect® Customer Support: U.S. residents visit
www.UconnectPhone.com or call 1–877–855–8400. Canadian Residents visit
www.UconnectPhone.com or call, 1-800-465–2001 (English) or 1-800-387-9983 (French).
Pairing a Phone
• To use the Uconnect® Phone feature, you must first pair your Bluetooth® phone with the
Uconnect® system.
Start pairing procedure on the radio
• Touch the Phone soft-key and then the Settings soft-key. Next, touch Add Device.
• Uconnect® Phone will display an “In progress” screen while the system is connecting.
Start pairing procedure on mobile phone
• Search for available devices on your Bluetooth® enabled mobile phone. This is usually
within Settings or Options under “Bluetooth”. See your mobile phone’s manual for
details.
• When your phone finds the system, select “Uconnect” as the paired device. You may be
prompted by your phone to download the phonebook. This is so you can make calls by
saying the name of your contact (PBAP-Phone Book Access Profile).
82
ELECTRONICS
Complete the pairing procedure
• When prompted on the phone, verify with radio password shown on the Uconnect®
Screen.
• If your phone asks you to accept a connection request from Uconnect®, select “Yes”. If
available, check the box telling it not to ask again – that way your phone will automatically
connect each time you start the vehicle.
Select the mobile phone's priority level
• When the pairing process has successfully completed, the system will prompt you to
choose whether or not this is your favorite phone. Selecting Yes will make this phone the
highest priority. This phone will take precedence over other paired phones within range.
Only one phone can be paired at a time.
• You are now ready to make hands-free calls. Press the Uconnect® Phone button on your
steering wheel to begin.
Making A Phone Call
• Press the Uconnect® Phone button
.
• After the BEEP, say “dial” then the number (or “call” then the name as listed in your phone;
see Phonebook).
NOTE:
You can also initiate a call by using the touchscreen on the Phone main screen.
Receiving A Call – Accept (And End)
• When an incoming call rings/is announced on Uconnect®, press the Phone button
.
• To end a call, press the Hang Up or Phone button
.
Mute (Or Unmute) Microphone During Call
• During a call, touch the mute soft-key on the Phone main screen to mute and unmute the
call.
Transfer Ongoing Call Between Handset And Vehicle
• During an on-going call, touch the Transfer soft-key on the Phone main screen to transfer
an on-going call between handset and vehicle.
Common Phone Commands (Examples)
• “Call John Smith”
• “Call John Smith mobile”
• “Dial 1 248 555 1212
• “Call Emergency”
• “Call Towing Assistance”
• “Redial”
83
ELECTRONICS
Phonebook
• Uconnect® radios automatically downloads your phonebook from your paired phone, if
this feature is supported by your phone. Entries are updated each time that the phone is
connected. If your phone book entries do not appear, check the settings on your phone.
Some phones require you to enable this feature manually.
• Your phonebook can be browsed on your radio screen, but editing can only be done on
your phone. To browse, touch the Phone soft-key, then the Phonebook soft-key.
• Favorite phonebook entries can be saved as Favorites for quicker access. Favorites are
shown at the top of your main phone screen.
Voice Command Tips
• Using complete names (i.e; Call John Doe vs. Call John) will result in greater system
accuracy.
• You can “chain” commands together for faster results. Say “Call John Doe, mobile”, for
example.
• If you are listening to available voice command options, you do not have to listen to the
button on the
entire list. When you hear the command that you need, press the
steering wheel, wait for the beep and say your command.
Changing The Volume Of The Voice Command Prompts
• Start a dialogue by pressing the Phone button
- "Help".
, then say a command, for example
• Use the radio VOLUME/MUTE rotary knob to adjust the Uconnect® audio prompt volume
to a comfortable level. Please note that the Uconnect® audio prompt volume setting for
Uconnect® is different than the audio system.
NOTE:
To access help, press the Uconnect® Phone
"help." Touch the display or push either
or
the help session.
button on the steering wheel and say
button and say "cancel" to cancel
Voice Text Reply
• Once your Uconnect® system is paired with a compatible mobile device, the system can
announce a new incoming text message, and read it to your over the vehicle audio
system. You can reply to the message using Voice Recognition, by selecting, or saying
one of the 18 pre-defined messages.
• Here’s how: Press the Uconnect® Phone button
and wait for the beep, then say
“reply”. Uconnect® will give the following prompt: “ Please say the message you would
like to send”. Wait for the beep and say one of the pre-defined messages. (If you are not
sure, you can say “help”). Uconnect® will then read the pre-defined messages allowed.
As soon as you hear the message you would like to send, you can interrupt the list of
prompts by pressing the Uconnect® phone button and saying the phrase. Uconnect® will
confirm the message by reading it back to you. Then press the Phone button and say
“Send.”
84
ELECTRONICS
Example Command
“Text John Smith”
“Text 123–456–7890”
“Show messages”
Action
Send John Smith a message from your phone
Send 123–456–7890 a message from your phone
See recent text messages listed by number on Uconnect®
screen
“Listen to/view (message num- Hear messages or read it on Uconnect® screen
ber four, for example)”
“Reply”
Send a voice text reply to a current message
“Forward text/message to ‘John Forward current text to specific contact in address book
Smith”
“Forward text/message to ‘123– Forward current text to specific phone number
456–7890”
• Voice texting reply and voice texting features require a compatible mobile device enabled with Bluetooth® Message Access Profile (MAP). iPhone® and some other smartphones do not currently support Bluetooth® MAP. Visit www.UconnectPhone.com for
system and device compatibility.
• Want to dictate a personal message? You must first register with Uconnect® Access (U.S.
residents only) to take advantage of a new, cloud-based Voice Texting service, an
enhancement to Voice Text Reply.
WARNING!
•
•
Any voice commanded system should be used only in safe driving conditions following applicable laws regarding phone use. Your attention should be focused on safely
operating the vehicle. Failure to do so may result in a collision causing you and others
to be severely injured or killed.
In an emergency, to use Uconnect® Phone, your mobile phone must be:
• turned on,
• paired to Uconnect® Phone,
• and have network coverage.
85
ELECTRONICS
VOICE COMMAND QUICK REFERENCE
Uconnect® 8.4A Voice Command Quick Reference
• If the Uconnect® Voice Command
button exists on your steering wheel, you have
the Voice Command feature, which is optimized for the driver. The Voice Command
feature lets you keep your hands on the wheel, and your eyes on the road.
button located on the steering wheel, you
• When you press the Voice Command
will hear a beep. After the beep, give your command. If you do not know what commands
to say, you can say “help” and the system will provide options to you. If you ever wish to
button,
interrupt the system while it lists options, press the Voice Command
after the beep, say your command.
NOTE:
All phone oriented voice commands are accessible by first pressing the Phone Pick Up
button, not the Voice Command button. To end a call, simply press the Phone Hang Up
button. In some vehicles, the Phone Pickup
button serves the dual purpose
of ending calls as well.
Voice Command (VR) User TIPs
• To hear available commands, press the Uconnect® Voice Command button and say
“Help”. You will hear available commands for the menu displayed.
• At any time, you can say the words “Cancel” or “Help”. These commands are universal
and can be used from virtually any menu. All other specific commands can be used
depending upon the active application.
• You can interrupt the system prompts at any time by pressing the Uconnect® Voice
Command button while the system is speaking. After the beep, you can say a command.
• You can ‘chain’ commands together for faster results. Say “Call Joe Doe mobile”, for
example.
• For best performance, adjust the rearview mirror to provide at least ½ in (1 cm) gap
between the overhead console (if equipped) and the mirror.
• Always wait for the beep before speaking.
• Speak normally, without pausing, just as you would speak to a person sitting a few
feet/meters away from you.
• Make sure that no one other than you is speaking during a Voice Command period.
86
ELECTRONICS
Steering Wheel Buttons
• You can control many of your radio features using your voice. Press either the VR
or Phone Pick Up
button on
your steering wheel.
Steering
Wheel Buttons to
Press:
Types of
Voice
Commands
Available
Uconnect®
Voice Command (VR)
Button
Radio
Mode
Media
Mode
Climate
Controls
Navigation
Phone
Mode
APPS
AM/FM &
Satellite
Band
Control
Media
Devices
Control
Temperature
Control
Destination Selection
and View
-
Yelp®
-
Call Initiation,
Call Management,
Predefined
Voice
Text Reply
-
GENERAL
Uconnect®
Phone
Pick Up Button
-
-
-
87
ELECTRONICS
Voice Command Examples – Uconnect® 8.4A
While In:
Voice Command Example:
GENERAL
“Go to Radio” (Media, Climate, Navigation,
Phone, Apps) – Settings, and Controls are not
Voice Command accessible
“Cancel”
“Help” (to listen to suggested commands
specific to current need
“Repeat”
“Launch Yelp®” – Required 1st voice comAnytime
mand to launch Yelp® app
“Yelp® Search” – Required 2nd voice command to activate app functionality using
Steering Wheel Voice Control Button
“Hotel” (restaurant, gas station, mail, hospital) – for nearest desired general POI
“Italian restaurants” – for nearest specified
POI category
RADIO
“Tune to AM950”, “Tune to 95.5FM (preset 5)
AM/FM
“Tune to Satellite Channel 80's on 8”, Tune to
Satellite Band Control
Satellite Channel 32 (preset 4)
MEDIA
“Browse” (show) “artist” (albums, music)
“Show paired phones” (devices)
Media Devices Control (Functionality is de“Play song – Maple Leaf Rag” (artist - Scott
Joplin, genre - rock, album - Ragtime Favorpendent on compatibility between devices
ites)
and radio)
“Shuffle” – available with iPod, USB and SD
Card
CLIMATE
“Set temperature to 70 degrees” – single climate zone vehicles
Temperature Control
“Set driver” (passenger) “temperature to 75
degrees” – dual climate zone vehicles
NAVIGATION
“Go Home” – destination previously defined
by driver
“Repeat guidance” – hear the last navigation
Destination Selection & View
prompt
“Cancel Route”
“View Map”
88
ELECTRONICS
PHONE
“Dial 123-456-7890” (phone number)
“Call John Smith mobile” (home, office,
Call Initiation (Requires that phone has been
other)
Bluetooth® paired with radio
“Redial”
“Show outgoing” (recent) “calls”
“Search for John Smith” (any contact name
in address book)
Call Management
“Show (display list) contacts”
Voice Texting (Requires registration with
Uconnect® Access and a current subscription.)
NOTE: Requires a compatible mobile device
enabled with Bluetooth Message Access Profile (MAP). iPhone and some other smartphones do not currently support Bluetooth®
MAP. Visit www.UconnectPhone.com for system and device compatibility.
Create a text message using Voice Command Capability
“Send a message to John Smith (123-4567890)”
“Show Messages”
“Listen to” (view) “number 4”
“Reply”
“Forward text” (message) “to John Smith”
(phone type, number)
Forward one of 18 pre-defined SMS messages to incoming calls/text messages:
“Yes.”
“No.”
“Okay.”
“I can’t talk right now.”
Voice Text Reply (Radio audibly recognizes
“Call me.”
these 18 pre-defined SMS messages as you
“I’ll call you later.”
speak)
NOTE: Requires a compatible mobile device “I’m on my way.”
“Thanks.”
enabled with Bluetooth Message Access Pro“I’ll be late.”
file (MAP). iPhone and some other smart“I will be <number> minutes late.”
phones do not currently support Bluetooth® “See you in <number> minutes”
MAP. Visit www.UconnectPhone.com for sys- “Stuck in traffic.”
tem and device compatibility.
“Start without me.”
“Where are you?”
“Are you there yet?”
“I need directions.”
“I’m lost.”
“See you later.”
APPS
“Launch Yelp®” – Required 1st voice command to launch Yelp® app
“Yelp® Search” – Required 2nd voice command to activate app functionality using
Yelp® (Yelp® adds it's own audible prompts,
Steering Wheel Voice Control Button
and response time varies depending on car“Hotel” (restaurant, gas station, mail, hospirier coverage speed)
tal) – for nearest desired general POI
“Italian restaurants” – for nearest specified
POI category
“Hotels” (restaurants, hospitals, Starbucks)
89
ELECTRONICS
Uconnect® 8.4AN
Uconnect® 8.4AN AT A GLANCE
Displaying the Time
• If the time is not currently displayed on the radio or player main page, touch the Controls
soft-key or the Apps soft-key, then the Settings soft-key. In the Settings list, touch the
Clock soft-key then touch the check box next to Show Time in Status Bar.
Setting the Time
• Model 8.4AN synchronizes time automatically via GPS, so it should not require any time
adjustment. If you do need to set the time manually, follow the instructions below for Model
8.4A.
• For Model 8.4A, turn the unit on, then touch the time display at the top of the screen.
Touch Yes.
• If the time is not displayed at the top of the screen, touch the Controls soft-key or the Apps
soft-key, then the Settings soft-key. In the Settings screen, touch the Clock soft-key, then
check or uncheck this option.
• Touch + or – next to Set Time Hours and Set Time Minutes to adjust the time.
• If these features are not available, uncheck the Sync Time box.
• Touch X to save your settings and exit out of the Clock Setting screen.
Audio Settings
• Touch the Audio soft-key to activate the Audio settings screen to adjust Balance\Fade,
Equalizer, and Speed Adjusted Volume.
• You can return to the Radio screen by touching the X located at the top right.
90
ELECTRONICS
Balance/Fade
• Touch the Balance/Fade soft-key to Balance audio between the front speakers or fade
the audio between the rear and front speakers.
• Touching the Front, Rear, Left, or Right soft-keys or touch and drag the blue Speaker Icon
to adjust the Balance/Fade.
Equalizer
• Touch the Equalizer soft-key to activate the Equalizer screen.
• Touch the + or - soft-keys, or by touching and dragging over the level bar for each of the
equalizer bands. The level value, which spans between plus or minus 9, is displayed at
the bottom of each of the Bands.
Speed Adjusted Volume
• Touch the Speed Adjusted Volume soft-key to activate the Speed Adjusted Volume
screen. The Speed Adjusted Volume is adjusted by touching the volume level indicator.
This alters the automatic adjustment of the audio volume with variation to vehicle speed.
Surround Sound
• Touch the Surround Sound soft-key, select On or Off followed by pressing the arrow back
soft-key. When this feature is activated, it provides simulated surround sound mode.
RADIO
• To access the Radio mode, touch the Radio soft-key at the lower left of the screen.
91
ELECTRONICS
Selecting Radio Stations
• Touch the desired radio band (AM, FM or SXM) soft-key.
Seek Up/Seek Down
• Touch the Seek arrow soft-keys for less than two seconds to seek through radio stations.
• Touch and hold either arrow soft-key for more than two seconds to bypass stations
without stopping. The radio will stop at the next listenable station once the arrow
soft-key is released.
Direct Tune
• Tune directly to a radio station by pressing the “Tune” button on the screen, and entering
the desired station number.
Store Radio Presets
• Your radio can store 36 total preset stations, 12 presets per band (AM, FM and SXM). They
are shown at the top of your radio screen. To see the 12 preset stations per band, press the
arrow soft-key at the top right of the screen to toggle between the two sets of six presets.
• To set a station into memory press and hold the desired numbered soft-key for more than
two seconds or until you hear a confirmation beep.
HD Radio
• HD Radio technology (available on Uconnect® 8.4AN) allows broadcasters to transmit a
high-quality digital signal.
• With an HD radio receiver, the listener is provided with a clear sound that enhances the
listening experience. HD radio can also transmit data such as song title or artist.
SiriusXM PREMIER OVER 160 CHANNELS
• Get every channel available on your satellite radio, and enjoy all you want, all in one place.
Hear commercial-free music plus sports, news, talk and entertainment. Get all the premium
programming, including Howard Stern, every NFL game, Oprah Radio®, every MLB® and NHL®
game, every NASCAR® race, Martha Stewart and more. And get 20+ extra channels, including
SiriusXM Latino, offering 20 channels of commercial free music, news, talk, comedy, sports
and more dedicated to Spanish language programming.
• To access SiriusXM Satellite Radio, touch the SXM soft-key on the main Radio screen.
• The following describes features that are available when in SiriusXM Satellite Radio
mode.
Seek Up/Seek Down
• Touch the Seek arrow soft-keys for less than two seconds to seek through channels in
SXM mode.
• Touch and hold either arrow soft-key for more than two seconds to bypass channels
without stopping. The radio will stop at the next listenable channel once the arrow
soft-key is released.
92
ELECTRONICS
Direct Tune
• Tune directly to a SXM channel by pressing the Tune soft-key on the screen, and entering
the desired station number.
Jump
• Automatically tells you when Traffic & Weather for a favorite city is available, and gives
you the option to switch to that channel. Touch Jump to activate the feature. After
listening to Traffic and Weather, touch Jump again to return to the previous channel.
Fav
• Activates the favorites menu. You can add up to 50 favorite artists or songs. Just touch
Add Fav Artist or Add Fav Song while the song is playing. You will then be alerted any time
one of these songs, or works by these artists, is playing on other SiriusXM channels.
SiriusXM Parental Controls
• You can skip or hide certain channels from view if you do not want access to them. Touch
the More soft-key, then the Settings soft-key, next touch the Sirius Setup soft-key, then
select Channel Skip. Touch the box, check-mark, next to the channel you want skipped.
They will not show up in normal usage.
• SiriusXM also offers the option to permanently block selected channels. Call
(1-888-601-6297 for U.S. customers, 1-877-438-9677 for Canadian customers) and request the Family - Friendly Package.
Browse
• Lets you browse the SiriusXM channel listing or Genre listing. Favorites, Game Zone,
Weather and Jump settings also provide a way to browse the SiriusXM channel list.
Browse Sub- Sub-Menu Description
Menu
All
Shows the channel listing.
Genre
Provides a list of all genres, and lets you jump to a channel within the selected
genre.
Presets
Lets you scroll the list of Preset satellite channels. Touch the channel, or press
Enter on the Tune knob, to go to that channel. Touch the trash can icon to delete
a preset. Your presets are also shown at the top of the main Satellite Radio
screen.
Favorites
Lets you manage artists and songs in the Favorites list and configure Alert
Settings to let you know when favorite songs or artists are playing on other
channels. Also, view a list of channels airing any of your Favorites.
Game Zone
Provides alerts when your favorite sports teams are starting a game which is
being aired on other SiriusXM channels, or when their game score is announced. You can select and manage your Teams list here, and configure
alerts.
Jump
Lets you select your favorite cities for Traffic & Weather information, which is
used by the Jump feature on the main satellite radio screen.
93
ELECTRONICS
Replay
• Lets you replay up to 44 minutes of the content of the current SiriusXM channel.
Replay Op- Option Description
tion
Play/Pause
Touch to Pause content playback. Touch Pause/Play again to resume playback.
Rewind/RW
Rewinds the channel content in steps of five seconds. Touch and hold to rewind
continuously, then release to begin playing content at that point.
Fast
Forwards the content, and works similarly to Rewind/RW. However, Fast
Forward/FW Forward/FW can only be used when content has been previously rewound.
Replay Time Displays the amount of time in the upper center of the screen by which your
content lags the Live channel.
Live
Resumes playback of Live content at any time while replaying rewound content.
• SiriusXM services require subscriptions, sold separately after the 12-month trial included with the new vehicle purchase. If you decide to continue your service at the end
of your trial subscription, the plan you choose will automatically renew and bill at
then-current rates until you call SiriusXM at 1-866-635-2349 for U.S. residents and
1-888-539-7474 for Canadian residents to cancel. See SiriusXM Customer Agreement
for complete terms at www.siriusxm.com for U.S. residents and www.siriusxm.ca for
Canadian residents. All fees and programming subject to change. Our satellite service is
available only to those at least 18 and older in the 48 contiguous USA and D.C. Our Sirius
satellite service is also available in PR (with coverage limitations). Our Internet radio
service is available throughout our satellite service area and in AK and HI. © 2013 Sirius
XM Radio Inc. Sirius, XM and all related marks and logos are trademarks of Sirius XM
Radio Inc.
Disc Operation
• Your vehicle may have a remote CD player located in the lower center console storage
bin.
• CD/Disc Mode is entered by either inserting a CD/Disc or by touching the Media button
located on the side of the display. Once in Media Mode, select Disc.
• Gently insert one CD into the CD player with the CD label facing as indicated on the
illustration located on the Disc player.
Seek Up/Down Buttons
• Press to seek through Disc tracks.
• Hold either button to bypass tracks without stopping.
Browse
• Touch the Browse soft-key to scroll through and select a desired track on the Disc. Touch
the Exit soft-key if you wish to cancel the browse function.
94
ELECTRONICS
MEDIA HUB – PLAYING iPod®/USB/MP3 DEVICES
• There are many ways to play music from iPod®/MP3 players or USB devices through your
vehicle's sound system.
Audio Jack (AUX)
• The AUX allows a portable device, such as an MP3 player or an iPod®, to be plugged into
the radio and utilize the vehicle’s sound system, using a 3.5 mm audio cable, to amplify
the source and play through the vehicle speakers.
• Touching the Media soft-key then choose AUX source will change the mode to auxiliary
device if the audio jack is connected, allowing the music from your portable device to be
heard through the vehicle's speakers. In order to activate the AUX, plug in the audio jack.
• The functions of the portable device are controlled using the device buttons. The volume
may be controlled using the radio or portable device.
• To route the audio cable out of the center console, use the access cut out in the front of
the console.
USB Port
• Connect your iPod® or compatible device using a USB cable into the USB Port. USB
Memory sticks with audio files can also be used. Then, audio from the device can be
played on the vehicle’s sound system while providing metadata (artist, track title, album,
etc.) information on the radio display.
• When connected, the iPod®/compatible USB device can be controlled using the radio or
Steering Wheel Audio Controls to play, skip to the next or previous track, browse, and list
the contents.
• The iPod® battery charges when plugged into the USB port (if supported by the specific
device).
• To route the USB/iPod® cable out of the center console, use the access cut out.
NOTE:
• When connecting your iPod® device for the first time, the system may take several
minutes to read your music, depending on the number of files. For example, the system
will take approximately five minutes for every 1000 songs loaded on the device. Also
during the reading process, the Shuffle and Browse functions will be disabled. This
process is needed to ensure the full use of your iPod® features and only happens the first
time it is connected. After the first time, the reading process of your iPod® will take
considerably less time unless changes are made or new songs are added to the playlist.
• The USB port supports certain Mini, Classic, Nano, Touch, and iPhone® devices. The USB
port also supports playing music from compatible external USB Mass Storage Class
memory devices. Some iPod® software versions may not fully support the USB port
features. Please visit Apple’s website for iPod® software updates.
95
ELECTRONICS
SD Card
• Play songs stored on an SD card inserted into the SD card slot.
• Song playback can be controlled using the radio or Steering Wheel Audio Controls to play,
skip to the next or previous track, browse, and list the contents.
Bluetooth® Streaming Audio
• If equipped with Uconnect® Voice Command, your Bluetooth®-equipped iPod® devices,
cell phones or other media players, may also be able to stream music to your vehicle's
sound system. Your connected device must be Bluetooth®-compatible, and paired with
your system (see Uconnect® Phone for pairing instructions). You can access the music
from your connected Bluetooth® device by touching the Bluetooth® soft-key while in
Media mode.
Uconnect®
8.4A & 8.4AN
Media Hub
(USB, AUX
Ports)
-
Media Hub
(SD, USB,
AUX Ports)
S
Remote USB
Port (Fully
Functional)
S
Remote USB
Port (Charging Only)
O
Dual Charging Ports
O
S = Standard Equipment
O = Optional Equipment
iPod®/CD/AUX CONTROLS
• The iPod®/CD/AUX controls are accessed by touching the desired soft-key displayed on
the side of the screen and choose between Disc, AUX, iPod®, Bluetooth® or SD Card.
96
ELECTRONICS
NOTE:
Uconnect® will usually automatically switch to the appropriate mode when something is
first connected or inserted into the system.
NAVIGATION
• Touch the Nav soft-key in the menu bar to access the Navigation system.
Changing the Navigation Voice Prompt Volume
1. Touch the Settings soft-key.
2. In the Settings menu, touch the Guidance soft-key.
3. In the Guidance menu, adjust the Nav Volume by touching the + or – Nav Volume
Adjustment soft-keys.
Finding Points of Interest (POI)
• From the main Navigation menu, touch the Where To? soft-key, then touch the Points of
Interest soft-key.
• Select a Category and then a subcategory, if necessary.
• Select your destination and touch the Yes soft-key.
97
ELECTRONICS
Finding a Place by Spelling the Name
• From the Main Navigation Menu touch the Where to? soft-key, touch the Points of
Interest soft-key, then touch the Spell Name soft-key.
• Enter the name of your destination.
• Touch the List soft-key.
• Select your destination and touch the Yes soft-key.
Entering a Destination Address
• From the main Navigation menu, touch the Where To? soft-key, then touch the Address
soft-key.
• Follow the on-screen prompts (country, state/province, city, street) to enter the address
and touch the Yes soft-key.
NOTE:
Destination entry is not available while your vehicle is in motion. However, you can also use
Voice Commands to enter an address while moving. Refer to Common Navigation Voice
Commands in the Uconnect® Voice Command section.
Setting Your Home Location
• Touch the NAV soft-key in the menu bar to access the Navigation system and the Main
Navigation menu.
• Touch the Where To? soft-key, then touch the Go Home soft-key.
• You may enter your address directly, use your current location as your home address, or
choose from recently found locations.
• To delete your Home location (or other saved locations) so you can save a new Home
location, touch the Where To? soft-key from the Main Navigation menu, then touch the
Go Home soft-key, and in the Yes screen touch the Options soft-key. In the Options menu
touch the Clear Home soft-key. Set a new Home location by following the previous
instructions.
98
ELECTRONICS
Go Home
• A Home location must be saved in the system. From the Main Navigation menu, touch
the Where To? soft-key, then touch the Go Home soft-key.
• Your route is marked with a blue line on the map. If you depart from the original route,
your route is recalculated. A speed limit icon could appear as you travel on major
roadways.
Adding a Stop
• To add a stop you must be navigating a route.
• Touch the Menu soft-key to return to the Main Navigation menu.
• Touch the Where To? soft-key, then search for the extra stop. When another location has
been selected, you can choose to cancel your previous route, add as the first destination
or add as the last destination.
• Touch the desired selection and touch the Yes soft-key.
Taking a Detour
• To take a detour you must be navigating a route.
• Touch the Detour soft-key.
NOTE:
• If the route you are currently taking is the only reasonable option, the device might not
calculate a detour.
• For more information, see your Uconnect® Supplement Manual.
99
ELECTRONICS
SiriusXM TRAFFIC (US Market Only)
Don't drive through traffic. Drive around it.
• Avoid congestion before you reach it. By enhancing your vehicle's navigation system with the
ability to see detailed traffic information, you can pinpoint traffic incidents, determine
average traffic speed and estimate travel time along your route. Since the service is integrated with a vehicle's navigation system, SiriusXM Traffic can help drivers pick the fastest
route based on traffic conditions.
1. Detailed information on traffic speed, accidents, construction, and road closings.
2. Traffic information from multiple sources, including police and emergency services,
cameras and road sensors.
3. Coast-to-coast delivery of traffic information.
4. View conditions for points along your route and beyond. Available in over 130 markets.
SiriusXM TRAVEL LINK (US Market Only)
• In addition to delivering over 130 channels of the best sports, entertainment, talk, and
commercial-free music, SiriusXM offers premium data services that work in conjunction
with compatible navigation systems. SiriusXM Travel Link brings a wealth of useful
information into your vehicle and right to your fingertips.
• Weather -- Check variety of local and national weather information from radar maps to
current and 5-day forecast.
• Fuel Prices -- Check local gas and diesel prices in your area and route to the station of
your choice.
• Sports Scores -- In-game and final scores as well as weekly schedules.
• Movie Listings -- Check local movie theatres and listings in your area and route to the
theater of your choice.
• SiriusXM Travel Link feature is completely integrated into your vehicle. A few minutes
after you start your vehicle, Travel Link information arrives and updates in the background. You can access the information whenever you like, with no waiting.
• To access SiriusXM Travel Link, touch Apps soft-key, then the SiriusXM Travel Link soft-key.
NOTE:
SiriusXM Travel Link requires a subscription, sold separately after the 1 year trial subscription included with your vehicle purchase.
• SiriusXM Travel Link is only available in the United States.
Fuel Prices
Movie
Listings
Sports
Scores
Weather
100
Check local gas and diesel prices in your area and route to the station of your
choice.
Check local movie theatres and listings in your area and route to the theater of
your choice.
In-game and final scores as well as weekly schedules.
Check variety of local and national weather information from radar maps to
current and 5-day forecast.
ELECTRONICS
Uconnect® Phone (Bluetooth® HANDS FREE CALLING)
• If the Uconnect® Phone Button
Uconnect® Phone features.
exists on your steering wheel, then you have the
• The Uconnect® Phone is a voice-activated, hands-free, in-vehicle communications
system with Voice Command Capability (see Voice Command section).
• The Uconnect® Phone allows you to dial a phone number with your mobile phone using
simple voice commands or using screen soft-keys.
• Refer to the Understand The Features Of Your Vehicle section of your vehicle's Owner's
Manual on the DVD for further details.
NOTE:
The Uconnect® Phone requires a mobile phone equipped with the Bluetooth® Hands-Free
Profile, Version 1.0 or higher. For Uconnect® Customer Support: U.S. residents visit
www.UconnectPhone.com or call 1–877–855–8400. Canadian Residents visit
www.UconnectPhone.com or call, 1-800-465–2001 (English) or 1-800-387-9983 (French).
Pairing a Phone
• To use the Uconnect® Phone feature, you must first pair your Bluetooth® phone with the
Uconnect® system.
Start pairing procedure on the radio
• Touch the Phone soft-key and then the Settings soft-key. Next, touch Add Device.
• Uconnect® Phone will display an “In progress” screen while the system is connecting.
Start pairing procedure on mobile phone
• Search for available devices on your Bluetooth® enabled mobile phone. This is usually
within Settings or Options under “Bluetooth”. See your mobile phone’s manual for
details.
• When your phone finds the system, select “Uconnect” as the paired device. You may be
prompted by your phone to download the phonebook. This is so you can make calls by
saying the name of your contact (PBAP-Phone Book Access Profile).
Complete the pairing procedure
• When prompted on the phone, verify with radio password shown on the Uconnect®
Screen.
• If your phone asks you to accept a connection request from Uconnect®, select “Yes”. If
available, check the box telling it not to ask again – that way your phone will automatically
connect each time you start the vehicle.
101
ELECTRONICS
Select the mobile phone's priority level
• When the pairing process has successfully completed, the system will prompt you to
choose whether or not this is your favorite phone. Selecting Yes will make this phone the
highest priority. This phone will take precedence over other paired phones within range.
Only one phone can be paired at a time.
• You are now ready to make hands-free calls. Press the Uconnect® Phone button on your
steering wheel to begin.
Making A Phone Call
• Press the Uconnect® Phone button
.
• After the BEEP, say “dial” then the number (or “call” then the name as listed in your phone;
see Phonebook).
NOTE:
You can also initiate a call by using the touchscreen on the Phone main screen.
Receiving A Call – Accept (And End)
• When an incoming call rings/is announced on Uconnect®, press the Phone button
• To end a call, press the Hang Up or Phone button
.
.
Mute (Or Unmute) Microphone During Call
• During a call, touch the mute soft-key on the Phone main screen to mute and unmute the call.
Transfer Ongoing Call Between Handset And Vehicle
• During an on-going call, touch the Transfer soft-key on the Phone main screen to transfer
an on-going call between handset and vehicle.
Common Phone Commands (Examples)
• “Call John Smith”
• “Call John Smith mobile”
• “Dial 1 248 555 1212
• “Call Emergency”
• “Call Towing Assistance”
• “Redial”
Phonebook
• Uconnect® radios automatically downloads your phonebook from your paired phone, if
this feature is supported by your phone. Entries are updated each time that the phone is
connected. If your phone book entries do not appear, check the settings on your phone.
Some phones require you to enable this feature manually.
• Your phonebook can be browsed on your radio screen, but editing can only be done on
your phone. To browse, touch the Phone soft-key, then the Phonebook soft-key.
• Favorite phonebook entries can be saved as Favorites for quicker access. Favorites are
shown at the top of your main phone screen.
102
ELECTRONICS
Voice Command Tips
• Using complete names (i.e; Call John Doe vs. Call John) will result in greater system
accuracy.
• You can “chain” commands together for faster results. Say “Call John Doe, mobile”, for
example.
• If you are listening to available voice command options, you do not have to listen to the
button on the
entire list. When you hear the command that you need, press the
steering wheel, wait for the beep and say your command.
Changing The Volume Of The Voice Command Prompts
• Start a dialogue by pressing the Phone button
- "Help".
, then say a command, for example
• Use the radio VOLUME/MUTE rotary knob to adjust the Uconnect® audio prompt volume
to a comfortable level. Please note that the Uconnect® audio prompt volume setting for
Uconnect® is different than the audio system.
NOTE:
To access help, press the Uconnect® Phone
"help." Touch the display or push either
or
the help session.
button on the steering wheel and say
button and say "cancel" to cancel
Voice Text Reply
• Once your Uconnect® system is paired with a compatible mobile device, the system can
announce a new incoming text message, and read it to your over the vehicle audio system.
You can reply to the message using Voice Recognition, by selecting, or saying one of the 18
pre-defined messages.
• Here’s how: Press the Uconnect® Phone button
and wait for the beep, then say “reply”.
Uconnect® will give the following prompt: “ Please say the message you would like to send”.
Wait for the beep and say one of the pre-defined messages. (If you are not sure, you can say
“help”). Uconnect® will then read the pre-defined messages allowed. As soon as you hear the
message you would like to send, you can interrupt the list of prompts by pressing the
Uconnect® phone button and saying the phrase. Uconnect® will confirm the message by
reading it back to you. Then press the Phone button and say “Send.”
Example Command
“Text John Smith”
“Text 123–456–7890”
“Show messages”
“Listen to/view (message
number four, for example)”
“Reply”
“Forward text/message to
‘John Smith”
“Forward text/message to
‘123–456–7890”
Action
Send John Smith a message from your phone
Send 123–456–7890 a message from your phone
See recent text messages listed by number on Uconnect® screen
Hear messages or read it on Uconnect® screen
Send a voice text reply to a current message
Forward current text to specific contact in address book
Forward current text to specific phone number
103
ELECTRONICS
• Voice texting reply and voice texting features require a compatible mobile device enabled with Bluetooth® Message Access Profile (MAP). iPhone® and some other smartphones do not currently support Bluetooth® MAP. Visit www.UconnectPhone.com for
system and device compatibility.
• Want to dictate a personal message? You must first register with Uconnect® Access (U.S.
residents only) to take advantage of a new, cloud-based Voice Texting service, an
enhancement to Voice Text Reply.
WARNING!
•
•
Any voice commanded system should be used only in safe driving conditions following applicable laws regarding phone use. Your attention should be focused on safely
operating the vehicle. Failure to do so may result in a collision causing you and others
to be severely injured or killed.
In an emergency, to use Uconnect® Phone, your mobile phone must be:
• turned on,
• paired to Uconnect® Phone,
• and have network coverage.
VOICE COMMAND QUICK REFERENCE
Uconnect® 8.4AN Voice Command Quick Reference
• If the Uconnect® Voice Command
button exists on your steering wheel, you have
the Voice Command feature, which is optimized for the driver. The Voice Command
feature lets you keep your hands on the wheel, and your eyes on the road.
button located on the steering wheel, you
• When you press the Voice Command
will hear a beep. After the beep, give your command. If you do not know what commands
to say, you can say “help” and the system will provide options to you. If you ever wish to
button,
interrupt the system while it lists options, press the Voice Command
after the beep, say your command.
NOTE:
All phone oriented voice commands are accessible by first pressing the Phone Pick Up
button, not the Voice Command button. To end a call, simply press the Phone Hang Up
button. In some vehicles, the Phone Pickup
button serves the dual purpose of
ending calls as well.
Voice Command (VR) User TIPs
• To hear available commands, press the Uconnect® Voice Command button and say
“Help”. You will hear available commands for the menu displayed.
• At any time, you can say the words “Cancel” or “Help”. These commands are universal
and can be used from virtually any menu. All other specific commands can be used
depending upon the active application.
• You can interrupt the system prompts at any time by pressing the Uconnect® Voice
Command button while the system is speaking. After the beep, you can say a command.
104
ELECTRONICS
• You can ‘chain’ commands together for faster results. Say “Call Joe Doe mobile”, for
example.
• For best performance, adjust the rearview mirror to provide at least ½ in (1 cm) gap
between the overhead console (if equipped) and the mirror.
• Always wait for the beep before speaking.
• Speak normally, without pausing, just as you would speak to a person sitting a few
feet/meters away from you.
• Make sure that no one other than you is speaking during a Voice Command period.
Steering Wheel Buttons
• You can control many of your radio features using your voice. Press either the VR
or Phone Pick Up
button on
your steering wheel.
Steering
Wheel Buttons to
Press:
Types of
Voice
Commands
Available
Uconnect®
Voice Command (VR)
Button
Radio
Mode
Media
Mode
Climate
Controls
Navigation
Phone
Mode
APPS
AM/FM &
Satellite
Band
Control
Media
Devices
Control
Temperature
Control
Destination Selection
and View
-
Yelp®
-
Call Initiation,
Call Management,
Predefined
Voice
Text Reply
-
GENERAL
Uconnect®
Phone Pick
Up Button
-
-
-
105
ELECTRONICS
Voice Command Examples – Uconnect® 8.4AN
While In:
Voice Command Example:
GENERAL
“Go to Radio” (Media, Climate, Navigation,
Phone, Apps) – Settings, and Controls are not
Voice Command accessible
“Cancel”
“Help” (to listen to suggested commands
specific to current need
“Repeat”
“Launch Yelp®” – Required 1st voice comAnytime
mand to launch Yelp® app
“Yelp® Search” – Required 2nd voice command to activate app functionality using
Steering Wheel Voice Control Button
“Hotel” (restaurant, gas station, mail, hospital) – for nearest desired general POI
“Italian restaurants” – for nearest specified
POI category
RADIO
“Tune to AM950”, “Tune to 95.5FM (preset 5)
AM/FM
“Tune to Satellite Channel 80's on 8”, Tune to
Satellite Band Control
Satellite Channel 32 (preset 4)
MEDIA
“Browse” (show) “artist” (albums, music)
“Show paired phones” (devices)
Media Devices Control (Functionality is de“Play song – Maple Leaf Rag” (artist - Scott
Joplin, genre - rock, album - Ragtime Favorpendent on compatibility between devices
ites)
and radio)
“Shuffle” – available with iPod®, USB and SD
Card
CLIMATE
“Set temperature to 70 degrees” – single climate zone vehicles
Temperature Control
“Set driver” (passenger) “temperature to 75
degrees” – dual climate zone vehicles
NAVIGATION
“Navigate to” (Destination) 123 Any Street,
Any town, Any State (any full address)
“Go Home” – destination previously defined
by driver
Destination Selection & View
“Repeat guidance” – hear the last navigation
prompt
“Cancel Route”
“View Map”
106
ELECTRONICS
PHONE
“Dial 123-456-7890” (phone number)
“Call John Smith mobile” (home, office,
Call Initiation (Requires that phone has been
other)
Bluetooth® paired with radio
“Redial”
“Show outgoing” (recent) “calls”
“Search for John Smith” (any contact name
in address book)
Call Management
“Show (display list) contacts”
Voice Texting (Requires registration with
Uconnect® Access and a current subscription)
NOTE: Requires a compatible mobile device
enabled with Bluetooth Message Access Profile (MAP). iPhone and some other smartphones do not currently support Bluetooth®
MAP. Visit www.UconnectPhone.com for system and device compatibility.
Create a text message using Voice Command Capability
“Send a message to John Smith (123-4567890)”
“Show Messages”
“Listen to” (view) “number 4”
“Reply”
“Forward text” (message) “to John Smith”
(phone type, number)
Forward one of 18 pre-defined SMS messages to incoming calls/text messages:
“Yes.”
“No.”
“Okay.”
“I can’t talk right now.”
Voice Text Reply (Radio audibly recognizes
“Call me.”
these 18 pre-defined SMS messages as you
“I’ll call you later.”
speak)
NOTE: Requires a compatible mobile device “I’m on my way.”
“Thanks.”
enabled with Bluetooth Message Access Pro“I’ll be late.”
file (MAP). iPhone and some other smart“I will be <number> minutes late.”
phones do not currently support Bluetooth® “See you in <number> minutes”
MAP. Visit www.UconnectPhone.com for sys- “Stuck in traffic.”
tem and device compatibility.
“Start without me.”
“Where are you?”
“Are you there yet?”
“I need directions.”
“I’m lost.”
“See you later.”
107
ELECTRONICS
APPS
“Show Fuel prices”
“Show Current Weather” – provides access to
Forecast as well
SiriusXM Travel Link (Traffic function is not
“Show Weather map” – multiple map formats
voice command accessible within SiriusXM
available
Travel Link
“Show Sports”
“Show Movie listings”
“Show My favorites”
“Launch Yelp®” – Required 1st voice command to launch Yelp® app
“Yelp® Search” – Required 2nd voice command to activate app functionality using
Yelp® (Yelp® adds it's own audible prompts,
Steering Wheel Voice Control Button
and response time varies depending on car“Hotel” (restaurant, gas station, mail, hospirier coverage speed)
tal) – for nearest desired general POI
“Italian restaurants” – for nearest specified
POI category
“Hotels” (restaurants, hospitals, Starbucks)
STEERING WHEEL AUDIO CONTROLS
• The steering wheel audio controls are located on the rear surface of the steering
wheel.
Right Switch
• Press the switch up or down to increase or
decrease the volume.
• Press the button in the center to change
modes AM/FM/CD.
Left Switch
• Press the switch up or down to search for
the next listenable station or select the
next or previous CD track.
• Press the button in the center to select
the next preset station (radio) or to change CDs if equipped with a CD Changer.
108
ELECTRONICS
ELECTRONIC VEHICLE INFORMATION CENTER (EVIC)
• The EVIC features a driver interactive display that is located in the instrument cluster.
Pressing the controls on the left side of the steering wheel allows the driver to select
vehicle information and Personal Settings. For additional information, refer to Programmable Features in this guide.
button to
• Press and release the UP
scroll upward through the main menus
(Main Gauge, MPH/km/h, Vehicle Info, Terrain, Driver Assist, Fuel Economy, Trip A, Trip
B, Audio, Stored Messages, Screen Set Up).
• Press and release the DOWN
button
to scroll downward through the main
menu and submenus (Main Gauge, MPH/
km/h, Vehicle Info, Terrain, Driver Assist,
Fuel Economy, Trip A, Trip B, Audio, Stored
Messages, Screen Set Up).
button
• Press and release the RIGHT
to access the information screens or submenu screens of a main menu item.
button to ac• Press the BACK/LEFT
cess the information screens or submenu screens of a main menu item.
1 — EVIC Controls
• Press the OK button to access/select the information screens or sub-menu screens of a
main menu item. Press and hold the OK arrow button for two seconds to reset displayed/
selected features that can be reset.
NOTE:
Refer to the Driver Cockpit image in Controls At A Glance to see EVIC Display and EVIC
Controls location.
Compass Calibration
• This compass is self-calibrating, which eliminates the need to set the compass manually. When the vehicle is new, the compass may appear erratic and the EVIC will display
“CAL” until the compass is calibrated.
• You may also calibrate the compass by completing one or more 360 degree turns (in an
area free from large metal or metallic objects) until the “CAL” message displayed in the
EVIC turns off. The compass will now function normally.
ECO
• The ECO message will appear in your EVIC display whenever you are driving in a fuel
efficient manner.
• This feature allows you to monitor when you are driving in a fuel efficient manner, and it
can be used to modify driving habits in order to increase fuel economy.
109
ELECTRONICS
PROGRAMMABLE FEATURES
Electronic Vehicle Information Center (EVIC)
• The EVIC can be used to program the following Personal Settings. Press the UP
or
button until System Setup displays, then press the SELECT
button. Scroll
DOWN
button to
through the settings using the UP or DOWN buttons. Press the SELECT
change the setting. Press the BACK button to scroll back to a previous menu or sub
menu.
• Select Language
• Nav – Turn By Turn
• Auto Unlock Doors
• Remote Unlock Sequence
• RKE Linked To Memory
• Remote Start Comfort Sys.
• Horn with Remote Lock
• Horn With Remote Start
• Flash Lamps With Lock
• Headlamp Off Delay
• Headlamps with Wipers
• Easy Entry/Exit Seat
• Tilt Mirror in Reverse
• Key-Off Power Delay
• Illuminated Approach
• Hill Start Assist (HSA)
• Display ECO Symbol
• Keyless Enter-N-Go™
• Gauge Glow Rings
• Auto High Beams
• Intermittent Wiper
• Blind Spot Alert
• Forward Collision Warning
• Park Assist System
• Display Units of Measure In
• Liftgate Chime
• Calibrate Compass
• Compass Variance
Uconnect® Customer Programmable Features
• The Uconnect® system allows you to access Customer Programmable feature settings
such as Display, Clock, Safety/Assistance, Lights, Doors & Locks, Heated Seats, Engine
Off Operation, Compass Settings, Audio, Phone/ Bluetooth and SiriusXM Setup through
soft-keys.
• Touch the More soft-key to on the bottom of the screen, then touch the Settings soft-key
to access the Settings screen. When making a selection, scroll up or down until the
preferred setting is highlighted, then press and release the preferred setting until a
check-mark appears next to the setting, showing that setting has been selected. The
following feature settings are available:
• Display
• Safety / Assistance
• Auto-On Comfort & Remote Start
• Compass
• Phone / Bluetooth
• Lights
110
• Clock
• Doors & Locks
• Engine Off Options
• Audio
• SiriusXM Setup
ELECTRONICS
UNIVERSAL GARAGE DOOR OPENER (HomeLink®)
• HomeLink® replaces up to three hand-held transmitters that operate devices such as
garage door openers, motorized gates, lighting or home security systems. The
HomeLink® unit is powered by your vehicles 12 Volt battery.
• The HomeLink® buttons that are located in the overhead console or sunvisor designate
the three different HomeLink® channels.
• The HomeLink® indicator is located above the center button.
Before You Begin Programming HomeLink®
• Be sure that your vehicle is parked outside of the garage before you begin programming.
• For more efficient programming and accurate transmission of the radiofrequency signal it is recommended that
a new battery be placed in the hand-held
transmitter of the device that is being
programmed to the HomeLink® system.
• Erase all channels before you begin programming. To erase the channels, place
the ignition switch into the ON/RUN position, then press and hold the two outside
HomeLink® buttons (I and III) for up to 20
seconds or until the red indicator flashes.
NOTE:
• Erasing all channels should only be performed when programming HomeLink® for the
first time. Do not erase channels when programming additional buttons.
• If you have any problems, or require assistance, please call toll-free 1–800–355– 3515 or,
on the Internet at www.HomeLink.com for information or assistance.
Programming A Rolling Code
• For programming Garage Door Openers that were manufactured after 1995. These
Garage Door Openers can be identified by the “LEARN” or “TRAIN” button located where
the hanging antenna is attached to the Garage Door Opener. It is NOT the button that is
normally used to open and close the door. The name and color of the button may vary by
manufacturer.
1. Place the ignition switch into the ON/RUN position.
2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) away from the HomeLink® button you
wish to program while keeping the HomeLink® indicator light in view.
3. Simultaneously press and hold both the HomeLink® button you want to program and the
hand-held transmitter button.
111
ELECTRONICS
4. Continue to hold both buttons and observe the indicator light. The HomeLink® indicator
will flash slowly and then rapidly after HomeLink® has received the frequency signal
from the hand-held transmitter. Release both buttons after the indicator light changes
from slow to rapid.
5. At the garage door opener motor (in the garage), locate the “LEARN” or “TRAINING”
button. This can usually be found where the hanging antenna wire is attached to the
garage door opener motor. Firmly press and release the “LEARN” or “TRAINING” button.
NOTE:
You have 30 seconds in which to initiate the next step after the LEARN button has been
pressed.
6. Return to the vehicle and press the programmed HomeLink® button twice (holding the
button for two seconds each time). If the device is plugged in and activates, programming is complete.
NOTE:
If the device does not activate, press the button a third time (for two seconds) to complete
the training.
7. To program the remaining two HomeLink® buttons, repeat each step for each remaining
button. DO NOT erase the channels.
Programming A Non-Rolling Code
• For programming Garage Door Openers manufactured before 1995.
1. Turn the ignition switch to the ON/RUN position.
2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) away from the HomeLink® button you
wish to program while keeping the HomeLink® indicator light in view.
3. Simultaneously press and hold both the HomeLink® button you want to program and the
hand-held transmitter button.
4. Continue to hold both buttons and observe the indicator light. The HomeLink® indicator
will flash slowly and then rapidly after HomeLink® has received the frequency signal
from the hand-held transmitter. Release both buttons after the indicator light changes
from slow to rapid.
5. Press and hold the programmed HomeLink® button and observe the indicator light.
NOTE:
• If the indicator light stays on constantly, programming is complete and the garage door
(or device) should activate when the HomeLink® button is pressed.
• To program the two remaining HomeLink® buttons, repeat each step for each remaining
button. DO NOT erase the channels.
112
ELECTRONICS
Using HomeLink®
• To operate, press and release the programmed HomeLink® button. Activation will now
occur for the programmed device (i.e., garage door opener, gate operator, security
system, entry door lock, home/office lighting, etc.,). The hand-held transmitter of the
device may also be used at any time.
WARNING!
•
•
Your motorized door or gate will open and close while you are programming the
universal transceiver. Do not program the transceiver if people or pets are in the path
of the door or gate.
Do not run your vehicle in a closed garage or confined area while programming the
transceiver. Exhaust gas from your vehicle contains Carbon Monoxide (CO) which is
odorless and colorless. Carbon Monoxide is poisonous when inhaled and can cause
you and others to be severely injured or killed.
POWER INVERTER
• There is a 115 Volt, 150 Watt power inverter
outlet located on the back of the center
console. This outlet can power cellular
phones, electronics and other low power
devices requiring power up to 150 Watts.
NOTE:
The power inverter is designed with built-in
overload protection. If the power rating of
150 Watts is exceeded, the power inverter
will automatically shut down. Once the electrical device has been removed from the
outlet, the inverter should automatically reset. If the power rating exceeds approximately
170 Watts, the power inverter may have to be reset manually. To reset the inverter manually,
unplug the device and plug it in again. To avoid overloading the circuit, check the power
ratings on electrical devices prior to using the inverter.
WARNING!
To Avoid Serious Injury or Death DO NOT:
• insert any objects into the receptacles
• touch with wet hands
Close the lid when not in use. If this outlet is mishandled, it may cause an electric shock
and failure.
113
ELECTRONICS
POWER OUTLET
• The front power outlet is located in the
front center storage bin of the instrument
panel.
• There are two power outlets located in the center console.
• The rear power outlet is located in the
right rear cargo area.
• The power outlets are labeled with either
a “key” or a “battery” symbol to indicate
how the outlet is powered. Power outlets
labeled with a “key” are powered when the
ignition switch is in the ON/RUN or ACC
position, while the outlets labeled with a
“battery” are connected directly to the
battery and powered at all times.
114
ELECTRONICS
NOTE:
• Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13
Amp) power rating is exceeded, the fuse protecting the system will need to be replaced.
See below image for fuse locations.
• Power outlets are designed for accessory plugs only. Do not insert any other object in the
power outlet as this will damage the outlet and blow the fuse. Improper use of the power
outlet can cause damage not covered by your new vehicle warranty.
• The rear cargo power outlet can be switched to “battery” powered all the time by
switching the power outlet right rear quarter panel fuse in the fuse panel.
115
OFF-ROAD CAPABILITIES
ALL-WHEEL DRIVE OPERATION
Single-Speed Operating Instructions/Precautions
• This system contains a single-speed (HI range only) transfer case, which provides
convenient full-time all-wheel drive. No driver interaction is required. The Brake Traction
Control (BTC) System, which combines standard ABS and Traction Control, provides
resistance to any wheel that is slipping to allow additional torque transfer to wheels with
traction.
NOTE:
This system is not appropriate for conditions where AWD LOW range is recommended. Refer to
“Off-Road Driving Tips” in “Starting and Operating” on the DVD for further information.
Electronically Shifted Transfer Case (Three-Position Switch)
• This is an electronic shift transfer case
and is operated by the AWD Control
Switch (Transfer Case Switch), which is
located on the center console.
• This electronically shifted transfer case
provides three mode positions:
• All-wheel drive automatic range (AWD
AUTO)
• All-wheel drive low range (LOW RANGE)
• Neutral (NEUTRAL)
• When additional traction is required, the
LOW RANGE position can be used to lock
the front and rear driveshafts together
forcing the front and rear wheels to rotate
at the same speed. The LOW RANGE position are designed for loose, slippery road surfaces only. Driving in the LOW RANGE
positions on dry hard surfaced roads may cause increased tire wear and damage to the
driveline components.
• When operating your vehicle in LOW RANGE, the engine speed is approximately three
times that of the AWD HI position at a given road speed. Take care not to overspeed the
engine and do not exceed 25 mph (40 km/h).
116
OFF-ROAD CAPABILITIES
NOTE:
The “SERV AWD Warning Light” monitors the electronic shift all-wheel drive system. If this
light remains on after engine start up or illuminates during driving, it means that the
all-wheel drive system is not functioning properly and that service is required.
Shifting Procedures
AWD AUTO To LOW RANGE
NOTE:
When shifting into or out of LOW RANGE some gear noise may be heard. This noise is
normal and is not detrimental to the vehicle or occupants.
• Shifting can be performed with the vehicle rolling 2 to 3 mph (3 to 5 km/h) or completely
stopped. Use either of the following procedures:
Preferred Procedure
• With the engine running, slow the vehicle to 2 to 3 mph (3 to 5 km/h).
• Shift the transmission into NEUTRAL.
• While still rolling, rotate the transfer case control switch to the desired position.
• After the desired position indicator light is ON (not flashing), shift the transmission back
into gear.
Alternate Procedure
• Bring the vehicle to complete stop.
• With the ignition switch in the ON position and the engine either OFF or running, shift the
transmission into NEUTRAL.
• Rotate the transfer case control switch to the desired position.
• After the desired position indicator light is ON (not flashing), shift the transmission back
into gear.
NOTE:
• If Steps 1 or 2 of either the Preferred or Alternate Procedure are not satisfied prior to
attempting the shift or if they no longer are being met while the shift attempt is in
process, the desired position indicator light will flash continuously while the original
position indicator light is ON, until all requirements have been met.
• The ignition switch must be in the ON position for a shift to take place and for the position
indicator lights to be operable. If the ignition switch is not in the ON position, then the
shift will not take place and no position indicator lights will be on or flashing.
117
OFF-ROAD CAPABILITIES
WARNING!
•
•
118
Always engage the parking brake when powering down the vehicle if the “SERV AWD
Warning Light” is illuminated. Not engaging the parking brake may allow the vehicle
to roll which may cause personal injury.
You or others could be injured if you leave the vehicle unattended with the transfer case
in the NEUTRAL position without first fully engaging the parking brake. The transfer case
NEUTRAL position disengages both the front and rear driveshafts from the powertrain
and will allow the vehicle to move regardless of the transmission position. The parking
brake should always be applied when the driver is not in the vehicle.
UTILITY
ROOF LUGGAGE RACK
• The crossbars on your vehicle are delivered stowed within the roof rack side rails. When
installed, the roof rack can hold a maximum of 150 lbs (68 kg) of evenly distributed
weight.
Installing The Crossbars
• To install the crossbars, completely loosen the thumb screws at both ends and lift the
crossbar from its stowed position.
• Bend the pivot points at each end of the crossbar and slide the thumb screw down.
• Set the crossbars into position and tighten the thumb screws.
NOTE:
Position the crossbars across the roof making sure the letters on the crossbar align with the
matching letters on the side rail.
• Refer to the Owner's Manual on the DVD for further details.
119
120
RWD
AWD
RWD
AWD
3.6L
3.6L
5.7L
5.7L
GCWR
Frontal Area
Max. GTW
(Gross Combined Wt. Rating)
(Gross Trailer Wt.)
11,600 lbs (5 262 kg)
40 sq ft (3.72 sq m)
6,200 lbs (2 812 kg)
11,600 lbs (5 262 kg)
40 sq ft (3.72 sq m)
6,200 lbs (2 812 kg)
13,100 lbs (5 942 kg)
60 sq ft (5.57 sq m)
7,400 lbs (3 357 kg)
13,100 lbs (5 942 kg)
60 sq ft (5.57 sq m)
7,200 lbs (3 266 kg)
Refer to local laws for maximum trailer towing speeds.
Max. Trailer Tongue Wt.
(See Note)
620 lbs (281 kg)
620 lbs (281 kg)
740 lbs (336 kg)
720 lbs (327 kg)
NOTE:
Vehicles not factory equipped with trailer tow package are limited to 3,500 lbs (350 lbs tongue weight).
• If the gross trailer weight is 3,500 lbs (1587 kg) or more, it is mandatory to use a weight-distributing hitch to ensure stable handling of your
vehicle.
NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the Tire and Loading Information placard. The addition of passengers and cargo may require reducing trailer tongue load and Gross Trailer
Weight (GTW). Redistributing cargo (to the trailer) may be necessary to avoid exceeding Rear Gross Axle Weight Rating (GAWR) of 3,900 lbs (1 769 kg).
Model
Engine
TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS)
UTILITY
UTILITY
RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.)
Rear-Wheel Drive Models
• DO NOT flat tow this vehicle. Damage to the drivetrain will result.
• Recreational towing (for two-wheel drive models) is allowed ONLY if the rear wheels are
OFF the ground. This may be accomplished using a tow dolly or vehicle trailer. If using
a tow dolly, follow this procedure:
1. Properly secure the dolly to the tow vehicle, following the dolly manufacturer's instructions.
2. Drive the rear wheels onto the tow dolly.
3. Firmly apply the parking brake. Shift the transmission into PARK.
4. Turn the ignition switch to the OFF position.
5. Properly secure the rear wheels to the dolly, following the dolly manufacturer’s instructions.
6. Install a suitable clamping device, designed for towing, to secure the front wheels in the
straight position.
CAUTION!
Towing with the rear wheels on the ground will cause severe transmission damage.
Damage from improper towing is not covered under the New Vehicle Limited Warranty.
All-Wheel Drive Models (Single-Speed Transfer Case)
• Recreational towing is not allowed. This model does not have a NEUTRAL position in the
transfer case.
NOTE:
• This vehicle may be towed on a flatbed or vehicle trailer provided all four wheels are OFF
the ground.
CAUTION!
Towing this vehicle in violation of the above requirements can cause severe transmission and/or transfer case damage. Damage from improper towing is not covered under
the New Vehicle Limited Warranty.
121
UTILITY
All-Wheel Drive Models (Two-Speed Transfer Case)
• The transfer case must be shifted into NEUTRAL (N) and the transmission must be in
PARK for recreational towing. The NEUTRAL (N) selection button is at the center of the
transfer case selector switches. Shifts into transfer case NEUTRAL (N) can take place
from any other transfer case mode.
CAUTION!
•
•
•
•
•
•
DO NOT dolly tow any All-Wheel Drive (AWD) vehicle. Internal damage to the transmission or transfer case will occur if a dolly is used when recreational towing.
Tow only in the forward direction. Towing this vehicle backwards can cause severe
damage to the transfer case.
The transmission must be in PARK for recreational towing.
Before recreational towing, perform the procedure outlined under “Shifting Into
NEUTRAL(N)” to be certain that the transfer case is fully in NEUTRAL (N). Otherwise,
internal damage will result.
Failure to follow these procedures can cause severe transmission and/or transfer
case damage. Damage from improper towing is not covered under the New Vehicle
Limited Warranty.
Do not use a bumper-mounted clamp-on tow bar on your vehicle. The bumper face
bar will be damaged.
Shifting Into NEUTRAL
• Use the following procedure to prepare your vehicle for recreational towing.
1. Bring the vehicle to a complete stop, with the engine running.
2. Press and hold the brake pedal.
3. Shift the transmission into NEUTRAL.
4. Using a ballpoint pen or similar object, press and hold the recessed transfer case
NEUTRAL (N) button (located by the selector switch) for four seconds. The light behind
the N symbol will blink, indicating shift in progress. The light will stop blinking (stay on
solid) when the shift to NEUTRAL (N) is complete. A “FOUR WHEEL DRIVE SYSTEM IN
NEUTRAL” message will display on the EVIC (Electronic Vehicle Information Center).
Refer to “Electronic Vehicle Information Center (EVIC)” in “Understanding Your Instrument Panel” for further information.
5. After the shift is completed and the NEUTRAL (N) light stays on, release the NEUTRAL
(N) button.
6. Shift the transmission into REVERSE.
7. Release the brake pedal for five seconds and ensure that there is no vehicle movement.
8. Press the ENGINE STOP/START button again (without pressing the brake pedal), if
needed, to turn the ignition switch to the OFF position.
9. Firmly apply the parking brake.
122
UTILITY
10. Shift the transmission into PARK and remove the key fob.
11. Attach the vehicle to the tow vehicle using a suitable tow bar.
12. Release the parking brake.
NOTE:
• Steps 1 through 3 are requirements that must be met before pressing the NEUTRAL (N)
button, and must continue to be met until the shift has been completed. If any of these
requirements are not met before pressing the NEUTRAL (N) button or are no longer met
during the shift, the NEUTRAL (N) indicator light will flash continuously until all requirements are met or until the NEUTRAL (N) button is released.
• The ignition switch must be in the ON/RUN position for a shift to take place and for the
position indicator lights to be operable. If the ignition switch is not in the ON/RUN
position, the shift will not take place and no position indicator lights will be on or flashing.
• A flashing NEUTRAL (N) position indicator light indicates that shift requirements have
not been met.
CAUTION!
•
•
•
Towing with the rear wheels on the ground will cause severe transmission damage.
Damage from improper towing is not covered under the New Vehicle Limited Warranty.
Front or rear wheel lifts should not be used. Internal damage to the transmission or
transfer case will occur if a front or rear wheel lift is used when recreational towing.
It is necessary to follow these steps to be certain that the transfer case is fully in
NEUTRAL before recreational towing to prevent damage to internal parts.
WARNING!
You or others could be injured if you leave the vehicle unattended with the transfer case
in the NEUTRAL position without first fully engaging the parking brake. The transfer case
NEUTRAL position disengages both the front and rear driveshafts from the powertrain
and will allow the vehicle to move even if the transmission is in PARK. The parking brake
should always be applied when the driver is not in the vehicle.
123
UTILITY
Shifting Out Of NEUTRAL (N)
• Use the following procedure to prepare your vehicle for normal usage.
1. Bring the vehicle to a complete stop, leaving it connected to the tow vehicle.
2. Firmly apply the parking brake.
3. Start the engine.
4. Press and hold the brake pedal.
5. Shift the transmission into NEUTRAL.
6. Using a ballpoint pen or similar object, press and hold the recessed transfer case
NEUTRAL (N) button (located by the selector switch) for one second.
7. When the NEUTRAL (N) indicator light turns off, release the NEUTRAL (N) button.
8. After the NEUTRAL (N) button has been released, the transfer case will shift to the
position indicated by the selector switch.
9. Shift the transmission into PARK and turn the engine OFF.
10. Release the brake pedal.
11. Disconnect vehicle from the tow vehicle.
12. Start the engine.
13. Press and hold the brake pedal.
14. Release the parking brake.
15. Shift the transmission into DRIVE, release the brake pedal, and check that the vehicle
operates normally.
NOTE:
• Steps 1 through 5 are requirements that must be met before pressing the NEUTRAL (N)
button, and must continue to be met until the shift has been completed. If any of these
requirements are not met before pressing the NEUTRAL (N) button or are no longer met
during the shift, the NEUTRAL (N) indicator light will flash continuously until all requirements are met or until the NEUTRAL (N) button is released.
• The ignition switch must be in the ON/RUN position for a shift to take place and for the
position indicator lights to be operable. If the ignition switch is not in the ON/RUN
position, the shift will not take place and no position indicator lights will be on or flashing.
• A flashing NEUTRAL (N) position indicator light indicates that shift requirements have
not been met.
124
WHAT TO DO IN EMERGENCIES
ROADSIDE ASSISTANCE
• Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents.
• Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling.
• Briefly describe the nature of the problem and answer a few simple questions.
• You will be given the name of the service provider and an estimated time of arrival. If you
feel you are in an “unsafe situation”, please let us know. With your consent, we will
contact local police or safety authorities.
INSTRUMENT CLUSTER WARNING LIGHTS
- Tire Pressure Monitoring System (TPMS) Light
• Each tire, including the spare (if provided), should be checked monthly, when cold and
inflated to the inflation pressure recommended by the vehicle manufacturer on the
vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size
than the size indicated on the vehicle placard or tire inflation pressure label, you should
determine the proper tire inflation pressure for those tires.)
• As an added safety feature, your vehicle has been equipped with a Tire Pressure Monitoring System (TPMS) which display in the Electronic Vehicle Information Center (EVIC)
when one or more of your tires is significantly under-inflated. Accordingly, when the low
tire pressure EVIC display illuminates, you should stop and check your tires as soon as
possible, and inflate them to the proper pressure. Driving on a significantly underinflated tire causes the tire to overheat and can lead to tire failure. Under-inflation also
reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling and
stopping ability.
• IF THE LIGHT STARTS FLASHING INDICATING A LOW TIRE PRESSURE, ADJUST THE AIR
PRESSURE IN THE LOW TIRE TO THE AIR PRESSURE SHOWN ON THE VEHICLE PLACARD OR TIRE INFLATION PRESSURE LABEL LOCATED ON THE DRIVER'S DOOR. NOTE:
AFTER INFLATION, THE VEHICLE MAY NEED TO BE DRIVEN FOR 20 MINUTES BEFORE
THE FLASHING LIGHT WILL TURN OFF.
• Please note that the TPMS is not a substitute for proper tire maintenance, and it is the
driver’s responsibility to maintain correct tire pressure, even if under-inflation has not
reached the level to trigger illumination of the TPMS low EVIC display.
• Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when
the system is not operating properly. The TPMS malfunction indicator is combined with
the low tire pressure telltale. When the system detects a malfunction, the telltale will
flash for approximately one minute and then remain continuously illuminated. This
sequence will continue each time the vehicle is restarted as long as the malfunction
exists.
125
WHAT TO DO IN EMERGENCIES
• When the malfunction indicator is illuminated, the system may not be able to detect or
signal low tire pressure as intended. TPMS malfunctions may occur for a variety of
reasons, including the installation of replacement or alternate tires or wheels on the
vehicle that prevent the TPMS from functioning properly. Always check the TPMS malfunction telltale after replacing one or more tires or wheels on your vehicle, to ensure that
the replacement or alternate tires and wheels allow the TPMS to continue to function
properly.
NOTE:
Tire pressures change by approximately 1 psi (7 kPa) per 12° F (7° C) of air temperature
change. Keep this in mind when checking tire pressure inside a garage, especially in the
Winter. Example: If garage temperature is 68°F (20°C) and the outside temperature is 32°F
(0°C), then the cold tire inflation pressure should be increased by 3 psi (21 kPa), which equals
1 psi (7 kPa) for every 12°F (7°C) for this outside temperature condition.
CAUTION!
The TPMS has been optimized for the original equipment tires and wheels. TPMS
pressures and warning have been established for the tire size equipped on your vehicle.
Undesirable system operation or sensor damage may result when using replacement
equipment that is not of the same size, type, and/or style. Aftermarket wheels can cause
sensor damage. Do not use tire sealant from a can, or balance beads if your vehicle is
equipped with a TPMS, as damage to the sensors may result.
BRAKE - Brake Warning Light
• This light monitors various brake functions, including brake fluid level and parking brake
application. If the brake light turns on it may indicate that the parking brake is applied,
that the brake fluid level is low, or that there is a problem with the anti-lock brake system
reservoir.
• If the light remains on when the parking brake has been disengaged, and the fluid level is
at the full mark on the master cylinder reservoir, it indicates a possible brake hydraulic
system malfunction or that a problem with the Brake Booster has been detected by the
Anti-Lock Brake System (ABS) / Electronic Stability Control (ESC) system. In this case,
the light will remain on until the condition has been corrected. If the problem is related to
the brake booster, the ABS pump will run when applying the brake and a brake pedal
pulsation may be felt during each stop.
• The dual brake system provides a reserve braking capacity in the event of a failure to a
portion of the hydraulic system. A leak in either half of the dual brake system is indicated
by the Brake Warning Light, which will turn on when the brake fluid level in the master
cylinder has dropped below a specified level.
• The light will remain on until the cause is corrected.
• Vehicles equipped with the Anti-Lock Brake System (ABS), are also equipped with
Electronic Brake Force Distribution (EBD). In the event of an EBD failure, the Brake
Warning Light will turn on along with the ABS Light. Immediate repair to the ABS system
is required.
126
WHAT TO DO IN EMERGENCIES
• Operation of the Brake Warning Light can be checked by turning the ignition switch from
the OFF position to the ON/RUN position. The light should illuminate for approximately
two seconds. The light should then turn off unless the parking brake is applied or a brake
fault is detected. If the light does not illuminate, have the light inspected by an authorized dealer.
• The light also will turn on when the parking brake is applied with the ignition switch in the
ON/RUN position.
NOTE:
This light shows only that the parking brake is applied. It does not show the degree of brake
application.
WARNING!
Driving a vehicle with the red brake light on is dangerous. Part of the brake system may
have failed. It will take longer to stop the vehicle. You could have a collision. Have the
vehicle checked immediately.
- Malfunction Indicator Light (MIL)
• The Malfunction Indicator Light (MIL) is part of an onboard diagnostic system called OBD
II that monitors engine and automatic transmission control systems. The light will
illuminate when the key is in the ON/RUN position before engine start. If the bulb does
not come on when turning the key from OFF to ON/RUN, have the condition checked
promptly.
• Certain conditions, poor fuel quality, etc., may illuminate the light after engine start. The
vehicle should be serviced if the light stays on through several of your typical driving
cycles. In most situations, the vehicle will drive normally and will not require towing.
CAUTION!
Prolonged driving with the Malfunction Indicator Light (MIL) on could cause damage to
the engine control system. It also could affect fuel economy and driveability. If the MIL is
flashing, severe catalytic converter damage and power loss will soon occur. Immediate
service is required.
WARNING!
A malfunctioning catalytic converter, as referenced above, can reach higher temperatures than in normal operating conditions. This can cause a fire if you drive slowly or park
over flammable substances such as dry plants, wood, cardboard, etc. This could result in
death or serious injury to the driver, occupants or others.
127
WHAT TO DO IN EMERGENCIES
- Electronic Stability Control (ESC) Activation/Malfunction Indicator Light
• The “ESC Activation/Malfunction Indicator Light” in the instrument cluster will come on
when the ignition switch is turned to the ON/RUN position. It should go out with the
engine running. If the “ESC Activation/Malfunction Indicator Light” comes on continuously with the engine running, a malfunction has been detected in the ESC system. If this
light remains on after several ignition cycles, and the vehicle has been driven several
miles (kilometers) at speeds greater than 30 mph (48 km/h), see your authorized dealer
as soon as possible to have the problem diagnosed and corrected.
NOTE:
• The “ESC Off Indicator Light” and the “ESC Activation/Malfunction Indicator Light” come
on momentarily each time the ignition switch is turned to ON/RUN.
• Each time the ignition is turned to ON/RUN, the ESC system will be ON, even if it was
turned off previously.
• The ESC system will make buzzing or clicking sounds when it is active. This is normal; the
sounds will stop when ESC becomes inactive following the maneuver that caused the
ESC activation.
• To improve the vehicle's traction when starting off in deep snow, sand or gravel, it may be
desirable to switch the ESC system to Partial Off mode by momentarily pressing the ESC
switch located below the climate controls, on the switch panel.
Off
- Charging System Light
• This light shows the status of the electrical charging system. If the charging system light
remains on, it means that the vehicle is experiencing a problem with the charging
system.
• We recommend you do not continue driving if the charging system light is on. Have the
vehicle serviced immediately.
- Oil Pressure Warning Light
• This light indicates low engine oil pressure. If the light turns on while driving, stop the
vehicle and shut off the engine as soon as possible. A chime will sound for four minutes
when this light turns on.
• We recommend you do not operate the vehicle or engine damage will occur. Have the
vehicle serviced immediately.
- Anti-Lock Brake (ABS) Light
• This light monitors the Anti-Lock Brake System (ABS). The light will turn on when the
ignition switch is turned to the ON/RUN position and may stay on for as long as four
seconds.
• If the ABS light remains on or turns on while driving, it indicates that the Anti-Lock
portion of the brake system is not functioning and that service is required. However, the
conventional brake system will continue to operate normally if the BRAKE warning light
is not on.
128
WHAT TO DO IN EMERGENCIES
• If the ABS light is on, the brake system should be serviced as soon as possible to restore
the benefits of Anti-Lock brakes. If the ABS light does not turn on when the ignition
switch is turned to the ON/RUN position, have the light inspected by an authorized dealer.
- Electronic Throttle Control (ETC) Light
• This light informs you of a problem with the Electronic Throttle Control (ETC) system.
• If a problem is detected, the light will come on while the engine is running. Cycle the
ignition key when the vehicle has completely stopped and the shift lever is placed in the
PARK position; the light should turn off.
• If the light remains lit with the engine running, your vehicle will usually be drivable;
however, see an authorized service center immediately. If the light is flashing when the
engine is running, immediate service is required and you may experience reduced
performance, an elevated/rough idle or engine stall and your vehicle may require towing.
- Air Bag Warning Light
• This light will turn on for four to eight seconds as a bulb check when the ignition switch
is first turned to the ON/RUN position. If the light is either not on during starting, stays on,
or turns on while driving, have the system inspected at an authorized dealer as soon as
possible. Refer to “Occupant Restraints” in “Things To Know Before Starting Your Vehicle” of your owners manual for further information.
Oil Change Indicator
• Your vehicle is equipped with an engine oil change indicator system. The “Oil Change
Due” message will flash in the EVIC display for approximately 10 seconds after a single
chime has sounded, to indicate the next scheduled oil change interval. The engine oil
change indicator system is duty cycle based, which means the engine oil change interval
may fluctuate, dependent upon your personal driving style
• Unless reset, this message will continue to display each time you turn the ignition switch
to the ON/RUN position or cycle the ignition to the ON/RUN position if equipped with
Keyless Enter-N-Go™. To turn off the message temporarily, press and release the MENU
button. To reset the oil change indicator system (after performing the scheduled maintenance) refer to the following procedure.
Vehicles Equipped With Keyless Enter-N-Go™
1. Without pressing the brake pedal, cycle the ignition to the ON/RUN position (Do not start
the engine).
2. Fully depress the accelerator pedal, slowly, three times within 10 seconds.
3. Cycle the ignition to the OFF/LOCK position.
Vehicles Not Equipped With Keyless Enter-N-Go™
1. Turn the ignition switch to the ON/RUN position (Do not start the engine).
2. Fully depress the accelerator pedal, slowly, three times within 10 seconds.
3. Turn the ignition switch to the OFF/LOCK position.
129
WHAT TO DO IN EMERGENCIES
NOTE:
If the indicator message illuminates when you start the vehicle, the oil change indicator
system did not reset. If necessary, repeat this procedure.
Resetting The Light After Servicing
Vehicles Equipped With Keyless Enter-N-Go™
• Without pressing the brake pedal, push the ENGINE START/STOP button and cycle the
ignition to the ON/RUN position (Do not start the engine.)
• Fully depress the accelerator pedal, slowly, three times within 10 seconds.
• Without pressing the brake pedal, push the ENGINE START/STOP button once to return
the ignition to the OFF/LOCK position.
Vehicles Not Equipped With Keyless Enter-N-Go™
• Turn the ignition switch to the ON/RUN position (Do not start the engine.)
• Fully depress the accelerator pedal, slowly, three times within 10 seconds.
• Turn the ignition switch to the OFF/LOCK position.
NOTE:
If the indicator message illuminates when you start the vehicle, the oil change indicator
system did not reset. If necessary, repeat this procedure.
IF YOUR ENGINE OVERHEATS
• In any of the following situations, you can reduce the potential for overheating by taking
the appropriate action.
• On the highways — slow down.
• In city traffic — while stopped, shift the transmission to NEUTRAL, but do not increase
engine idle speed.
NOTE:
There are steps that you can take to slow down an impending overheat condition:
• If your air conditioner (A/C) is on, turn it off. The A/C system adds heat to the engine
cooling system and turning the A/C off can help remove this heat.
• You can also turn the temperature control to maximum heat, the mode control to floor
and the blower control to high. This allows the heater core to act as a supplement to the
radiator and aids in removing heat from the engine cooling system.
CAUTION!
Driving with a hot cooling system could damage your vehicle. If the temperature gauge reads
HOT (H), pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until
the pointer drops back into the normal range. If the pointer remains on HOT (H), and you hear
continuous chimes, turn the engine off immediately, and call for service.
130
WHAT TO DO IN EMERGENCIES
WARNING!
You or others can be badly burned by hot engine coolant (antifreeze) or steam from your
radiator. If you see or hear steam coming from under the hood, do not open the hood until
the radiator has had time to cool. Never try to open a cooling system pressure cap when
the radiator or coolant bottle is hot.
JACKING AND TIRE CHANGING
Jack Location
• The scissor-type jack and tire changing tools are located in rear cargo area, below the
load floor.
1 — Jacking Tools
131
WHAT TO DO IN EMERGENCIES
• Rotate the plastic thumb screw on the end of the jack to remove the jack from the
bracket.
Spare Tire Stowage
• The spare tire is stowed under the rear of
the vehicle by means of a cable winch
mechanism. To remove or stow the spare,
use the jack handle/lug wrench connected to the square socket extension to
rotate the “spare tire drive” nut. The nut is
located under a plastic cover at the
center-rear of the cargo floor area, just
inside the liftgate opening.
Spare Tire Removal
1. Remove the jack tools from the bag.
2. Raise the protective rubber mat covering the storage compartment floor and remove the
plug to access the winch drive.
3. Fit the jack handle extension over the drive nut. Use the lug wrench handle and extension
to completely lower the spare tire. Keep turning the handle until the winch STOPS. NOTE:
Do not use power tools to operate the winch.
132
WHAT TO DO IN EMERGENCIES
4. Slide the tire out from under the vehicle and rotate it vertically behind the rear bumper.
5. Spread the retaining tabs on the plastic
plate and pull the metal stamping toward you to release it from the plastic plate.
133
WHAT TO DO IN EMERGENCIES
6. Slide the metal stamping up the steel extension tube and winch cable. Rotate the metal
stamping and push it through the hole in the plastic plate and wheel.
7. Pinch the three short and two long tubes
to remove the protective plate from the steel spare wheel.
134
WHAT TO DO IN EMERGENCIES
Preparations For Jacking
1. Park the vehicle on a firm level surface, away from traffic for your safety.
2. Turn the engine off, place the transmission in PARK, fully depress the pedal to the floor
to set the parking brake, and activate the Hazard Warning flashers.
3. Block both the front and rear of the wheel diagonally opposite of the jacking position.
NOTE:
Passengers should not remain in the vehicle
when the vehicle is being jacked.
135
WHAT TO DO IN EMERGENCIES
Jacking Instructions
1. Loosen the lug nuts on the road wheel one
turn while still on the ground, but do not
remove.
2. Determine the jacking location on the side of the vehicle. Attach the jack tool with the
hook, the extension and the lug wrench to the jack as shown.
136
WHAT TO DO IN EMERGENCIES
137
WHAT TO DO IN EMERGENCIES
3. For the front axle, place the jack on the body flange just behind the front tire as indicated
by the triangular lift point symbol on the sill molding. Do not raise the vehicle until you
are sure the jack is fully engaged.
4. For a rear tire, place the jack in the slot on
the rear tie-down bracket, just forward of
the rear tire (as indicated by the triangular
lift point symbol on the sill molding). Do
not raise the vehicle until you are sure
the jack is fully engaged.
5. Raise the vehicle by turning the jack
screw clockwise. Raise the vehicle just
enough to remove the flat tire.
6. Remove the lug nuts and wheel.
7. Install the temporary spare wheel/tire
and lightly tighten the lug nuts prior to
lowering to prevent the vehicle from moving on the jack.
8. Lower the vehicle by turning the jack
screw counterclockwise, and remove the
jack.
9. Finish tightening the lug nuts. Push down
on the wrench while at the end of the
handle for increased leverage. Tighten
the lug nuts in a star pattern until each
nut has been tightened twice. The correct
wheel nut tightness is 110 ft lbs (150 N·m).
If in doubt about the correct tightness,
have them checked with a torque wrench
by your authorized dealer or at a service
station.
138
WHAT TO DO IN EMERGENCIES
10. Remove the Dodge center cap using a jack tool from inside the aluminum road wheel
and snap on the protective plastic plate.
NOTE:
The plastic plate will prevent the road wheel
from being scratched when sliding it under
the vehicle.
11. Stand the wheel up against the bumper
with the plastic plate facing you.
12. Slide the cable end, spring and metal tube through the wheel and plastic plate. Rotate
the stamping on the cable and push it through the wheel and plastic plate. Snap the
stamping into place.
13. Slide the road wheel on the ground using
the protective plate until it is directly
under the winch and between the rear
bumper and exhaust system heat
shields. Raise the tire by turning the lug
wrench on the winch extension clockwise until it clicks/skips three times to
make sure the cable is tight.
NOTE:
Double check to ensure the tire is snug against the underbody of the vehicle. Damage to the
winch cable may result if the vehicle is driven with the tire loose.
139
WHAT TO DO IN EMERGENCIES
14. Lower the jack to the fully closed position. Return the tools to the proper positions in the
tool bag. Fold the flap on the tool bag under the tools and roll the tools in the bag
underneath the others. Use the Velcro straps to secure the tool bag to the jack with the
lug wrench on the forward side of the jack. Expand the jack on the bracket by turning the
thumb screw clockwise until it is tight to prevent rattles.
15. Reinstall the plastic plug into the floor of
the cargo area. Roll up and store the
Jack, Tool Kit and Tire Changing Instructions. Reinstall the cover for the jack in
the rear storage bin.
NOTE:
The plastic thumb screw being on the right
and the position of the lug wrench before the
velcro straps go around the fully closed jack.
16. Remove the blocks/rocks from the opposite tire.
17. Have the aluminum road wheel and tire
repaired as soon as possible and properly
secure the spare tire, jack and tool kit.
Road Tire Installation
1. Mount the road tire on the axle.
2. Install the remaining lug nuts with the cone shaped end of the nut toward the wheel.
Lightly tighten the lug nuts.
3. Lower the vehicle to the ground by turning the jack handle counterclockwise.
4. Finish tightening the lug nuts. Push down on the wrench while at the end of the handle for
increased leverage. Tighten the lug nuts in a star pattern until each nut has been
tightened twice. The correct tightness of each lug nut is 110 ft/lbs (150 N·m). If in doubt
about the correct tightness, have them checked with a torque wrench by your authorized
dealer or service station.
5. After 25 miles (40 km) check the lug nut torque with a torque wrench to ensure that all lug
nuts are properly seated against the wheel.
CAUTION!
•
•
•
140
Do not use power tools to winch the tire up or down. Impact type tools can damage
the winch mechanism.
Do not attempt to raise the vehicle by jacking on locations other than those indicated
in the Jacking Instructions for this vehicle.
Be sure to mount the spare tire with the valve stem facing outward. The vehicle could
be damaged if the spare tire is mounted incorrectly.
WHAT TO DO IN EMERGENCIES
WARNING!
•
•
•
•
•
•
•
•
•
•
•
•
•
Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull
far enough off the road to avoid the danger of being hit when operating the jack or
changing the wheel.
Being under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and
fall on you. You could be crushed. Never put any part of your body under a vehicle that
is on a jack. If you need to get under a raised vehicle, take it to a service center where
it can be raised on a lift.
The jack is designed to be used as a tool for changing tires only. The jack should not
be used to lift the vehicle for service purposes. The vehicle should be jacked on a firm
level surface only. Avoid ice or slippery areas.
Always park on a firm, level surface as far from the edge of the roadway as possible
before raising the vehicle.
Turn on the Hazard Warning flasher.
Block the wheel diagonally opposite the wheel to be raised.
Set the parking brake firmly and set the automatic transmission in PARK.
Never start or run the engine with the vehicle on a jack.
Do not let anyone sit in the vehicle when it is on a jack.
Do not get under the vehicle when it is on a jack.
Only use the jack in the positions indicated and for lifting this vehicle during a tire
change.
If working on or near a roadway, be extremely careful of motor traffic.
To assure that spare tires, flat or inflated, are securely stowed, spares must be
stowed with the valve stem facing the ground. Carefully follow these tire changing
warnings to help prevent personal injury or damage to your vehicle:
• Raising the vehicle higher than necessary can make the vehicle less stable. It
could slip off the jack and hurt someone near it. Raise the vehicle only enough
to remove the tire.
• To avoid the risk of forcing the vehicle off the jack, do not fully tighten the
wheel nuts until the vehicle has been lowered. Failure to follow this warning
may result in personal injury.
• Do not use power tools to winch the tire up or down. Impact-type tools may
damage the winch mechanism.
• A loose tire or jack, thrown forward in a collision or hard stop could endanger
the occupants of the vehicle. Always stow the jack parts and the spare tire in
the places provided.
• To avoid the risk of forcing the vehicle off the jack, do not tighten the lug nuts
fully until the vehicle is lowered to the ground.
141
WHAT TO DO IN EMERGENCIES
BATTERY LOCATION
• The battery in your vehicle is located under the passenger's front seat. Remote battery
posts are located on the right side of the engine compartment for jump-starting.
JUMP-STARTING
• If your vehicle has a discharged battery it can be jump-started using a set of jumper
cables and a battery in another vehicle or by using a portable battery booster pack.
• Jump-starting can be dangerous if done improperly so please follow the procedures in
this section carefully.
NOTE:
When using a portable battery booster pack follow the manufacturer’s operating instructions and precautions.
Preparations for Jump-Start
• The battery in your vehicle is located under the passengers front seat. There are
remote locations under the hood to assist
in jump starting.
• Set the parking brake, shift the automatic
transmission into PARK and turn the ignition to OFF.
• Turn off the heater, radio, and all unnecessary electrical accessories.
• Remove the protective cover over the remote positive (+) battery post. Pull upward
on the cover to remove it.
• If using another vehicle to jump-start the
battery, park the vehicle within the jumper
cables reach, set the parking brake and make sure the ignition is OFF.
Jump-Starting Procedure
• Connect the positive (+) end of the jumper cable to the remote positive (+) post of the
discharged vehicle.
• Connect the opposite end of the positive (+) jumper cable to the positive (+) post of the
booster battery.
• Remove the protective cap from the negative jump post. Connect the negative end (-)of
the jumper cable to the negative (-) post of the booster battery.
• Connect the opposite end of the negative (-) jumper cable to the remote negative (-) post
of the vehicle with the discharged battery.
142
WHAT TO DO IN EMERGENCIES
• Start the engine in the vehicle that has the booster battery, let the engine idle a few
minutes, and then start the engine in the vehicle with the discharged battery.
• Once the engine is started, remove the jumper cables in the reverse sequence:
• Disconnect the negative (-) jumper cable from the remote negative (-) post of the vehicle
with the discharged battery. Replace the protective cap.
• Disconnect the negative end (-) of the jumper cable from the negative (-) post of the
booster battery.
• Disconnect the opposite end of the positive (+) jumper cable from the positive (+)post of
the booster battery.
• Disconnect the positive (+) end of the jumper cable from the remote positive (+) post of
the discharged vehicle.
• Reinstall the protective cover over the remote positive (+) battery post of the discharged
vehicle.
• If frequent jump-starting is required to start your vehicle you should have the battery and
charging system inspected at your authorized dealer.
CAUTION!
•
•
•
Do not use a portable battery booster pack or any other booster source with a system
voltage greater than 12 Volts or damage to the battery, starter motor, alternator or
electrical system may occur.
Failure to follow these procedures could result in damage to the charging system of
the booster vehicle or the discharged vehicle.
Accessories that can be plugged into the vehicle power outlets draw power from the
vehicle’s battery, even when not in use (i.e., cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle’s battery discharges sufficiently to degrade
battery life and/or prevent the engine from starting.
143
WHAT TO DO IN EMERGENCIES
WARNING!
•
•
•
•
•
•
•
144
When temperatures are below the freezing point, electrolyte in a discharged battery
may freeze. Do not attempt jump-starting because the battery could rupture or
explode and cause personal injury. Battery temperature must be brought above the
freezing point before attempting a jump-start.
Take care to avoid the radiator cooling fan whenever the hood is raised. It can start
anytime the ignition switch is on. You can be injured by moving fan blades.
Remove any metal jewelry, such as watch bands or bracelets, that might make an
inadvertent electrical contact. You could be severely injured.
Batteries contain sulfuric acid that can burn your skin or eyes and generate hydrogen
gas which is flammable and explosive. Keep open flames or sparks away from the
battery.
Do not allow vehicles to touch each other as this could establish a ground connection
and personal injury could result.
Failure to follow this procedure could result in personal injury or property damage
due to battery explosion.
Do not connect the cable to the negative post (-) of the discharged battery. The
resulting electrical spark could cause the battery to explode and could result in
personal injury.
WHAT TO DO IN EMERGENCIES
MANUAL PARK RELEASE 8–SPEED
• In order to push or tow the vehicle in cases where the transmission will not shift out of
PARK (such as a dead battery), a Manual Park Release is available.
• Follow these steps to use the Manual Park Release:
• Open the center console and locate the Manual Park Release cover, remove it by
snapping the cover away from the console hinges.
• Using a screwdriver or similar tool, push
the metal latch in towards the tether
strap.
• While the metal latch is in the open position, simultaneously pull upwards on the tether
strap until it clicks and releases out of the park position.
NOTE:
To prevent the vehicle from rolling unintentionally, firmly apply the parking brake.
• To Disengage the Manual Park Release
Lever:
• To disengage the Manual Park Release
apply tension upward while pushing the
release latch towards the tether to unlock
the lever.
• Once the tension has been released and
the lever has been unlocked be sure it is
stowed properly and locks into position.
NOTE:
Be sure to replace the cover by snapping it
back in place.
145
146
Front
Wheel Lift or Dolly
Tow
ALL
Rear
NONE
Flat Tow
Flatbed
Wheels OFF the
Ground
Towing Condition
TOWING A DISABLED VEHICLE
•
•
•
BEST METHOD
OK
Transmission in NEUTRAL
30 mph (48 km/h)
15 miles (24 km) max distance
RWD Models
•
•
•
NO
BEST METHOD
Transmission in PARK
T/case in NEUTRAL
Tow in Forward direction
AWD Models
WHAT TO DO IN EMERGENCIES
WHAT TO DO IN EMERGENCIES
FREEING A STUCK VEHICLE
• If your vehicle becomes stuck in mud, sand or snow, it can often be moved by a rocking
motion. Turn your steering wheel right and left to clear the area around the front wheels.
Then, move the shift lever back and forth between REVERSE and DRIVE. Using minimal
accelerator pedal pressure to maintain the rocking motion, without spinning the wheels,
is most effective.
• Allow the engine to idle with the transmission shift lever in NEUTRAL for at least one
minute after every five rocking-motion cycles. This minimizes overheating and reduce
the risk of transmission failure during prolonged efforts to free a stuck vehicle.
NOTE:
If your vehicle is equipped with Electronic Stability Control (ESC) then press the "ESC Off"
switch, to place the Electronic Stability Control (ESC) system in "Partial Off" mode, before
rocking the vehicle.
CAUTION!
Revving the engine or spinning the wheels too fast may lead to transmission overheating
and failure. It can also damage the tires. Do not spin the wheels above 30 mph (48 km/h)
while in gear (no transmission shifting occurring).
WARNING!
Fast spinning tires can be dangerous. Forces generated by excessive wheel speeds may
cause tire damage or failure. A tire could explode and injure someone. Do not spin your
vehicle's wheels faster than 30 mph (48 km/h) when you are stuck. Do not let anyone
near a spinning wheel, no matter what the speed.
147
WHAT TO DO IN EMERGENCIES
EVENT DATA RECORDER (EDR)
• This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR
is to record, in certain crash or near crash-like situations, such as an air bag deployment
or hitting a road obstacle, data that assists in understanding how a vehicle’s systems
performed. The EDR is designed to record data related to vehicle dynamics and safety
systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is
designed to record such data as:
• How various systems in your vehicle were operating.
• Whether or not the driver and passenger safety belts were buckled/fastened.
• How far (if at all) the driver was depressing the accelerator and/or brake pedal.
• How fast the vehicle was traveling.
• These data can help provide a better understanding of the circumstances in which
crashes and injuries occur.
NOTE:
EDR data are recorded by your vehicle only if a non-trivial crash situation occurs; no data are
recorded by the EDR under normal driving conditions and no personal data (e.g. name,
gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely
acquired during a crash investigation.
• To read data recorded by an EDR, special equipment is required, and access to the
vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties such
as law enforcement, that have the special equipment, can read the information if they
have access to the vehicle or the EDR.
CAP-LESS FUEL FILL FUNNEL
• The funnel for the Cap-Less Fuel System is located on the jacking tool kit. If your vehicle
is out of fuel and an auxiliary fuel can is needed, insert the funnel into the filler neck and
proceed to fill the vehicle.
148
MAINTAINING YOUR VEHICLE
OPENING THE HOOD
• Pull the hood release lever located below
the steering wheel at the base of the instrument panel.
• Reach into the opening beneath the center of the hood and move the safety latch
lever while lifting the hood at the same
time.
WARNING!
Be sure the hood is fully latched before driving your vehicle. If the hood is not fully
latched, it could open when the vehicle is in motion and block your vision. Failure to
follow this warning could result in serious injury or death.
149
MAINTAINING YOUR VEHICLE
ADDING FUEL
1. Press the fuel filler door release switch (located under the headlamp switch).
2. Open the fuel filler door.
NOTE:
In certain cold conditions, ice may prevent the fuel door from opening. If this occurs, lightly
push on the fuel door to break the ice buildup and re-release the fuel door using the inside
release button. Do not pry on the door.
3. There is no fuel filler cap. A flapper door inside the pipe seals the system.
4. Insert the fuel nozzle fully into the filler pipe, the nozzle opens and holds the flapper door
while refueling.
NOTE:
Only the correct size nozzle opens the latches allowing the flapper door to open.
5. Fill the vehicle with fuel, when the fuel nozzle “clicks” or shuts off the fuel tank is full.
6. Remove the fuel nozzle and close the fuel door.
150
MAINTAINING YOUR VEHICLE
Fuel Door Emergency Release
• To manually open the fuel door, remove the storage bin located in the left rear cargo area.
• Pull the release cable located in the storage bin opening.
151
152
3.6L ENGINE
ENGINE COMPARTMENT
MAINTAINING YOUR VEHICLE
5.7L ENGINE
MAINTAINING YOUR VEHICLE
153
MAINTAINING YOUR VEHICLE
FLUIDS AND CAPACITIES
Component
Engine Coolant – 3.6L Engine
Engine Coolant – 5.7L Engine
(Without Trailer Tow Package)
Engine Coolant – 5.7L Engine
(With Trailer Tow Package)
Engine Oil with Filter – 3.6L
Engine
Engine Oil with Filter –5.7L
Engine
Engine Oil Filter
Spark Plug – 3.6L Engine
Spark Plug – 5.7L Engine
Automatic Transmission
154
Fluid, Lubricant, or
Genuine Part
We recommend you use
MOPAR® Engine Coolant/
Antifreeze 10-Year/150,000
Mile Formula.
We recommend you use
MOPAR® Engine Coolant/
Antifreeze 10-Year/150,000
Mile Formula.
We recommend you use
MOPAR® Engine Coolant/
Antifreeze 10-Year/150,000
Mile Formula.
We recommend you use API
certified 5W-20 engine oil,
meeting the requirements of
Chrysler Material Standard
MS-6395 such as MOPAR®,
Pennzoil®, Shell Helix® or
equivalent. Refer to your oil
filler cap for correct SAE
grade.
We recommend you use API
certified 5W-20 engine oil,
meeting the requirements of
Chrysler Material Standard
MS-6395 such as MOPAR®,
Pennzoil®, Shell Helix® or
equivalent. Refer to your oil
filler cap for correct SAE
grade.
We recommend you use
MOPAR® Engine Oil Filters.
We recommend you use
MOPAR® Spark Plugs (Gap
0.043 in [1.1 mm]).
We recommend you use
MOPAR® Spark Plugs (Gap
0.043 in [1.1 mm]).
Use only Mopar® ZF 8&9
Speed ATF™ Automatic
Transmission Fluid or equivalent. Failure to use the correct fluid may affect the
function or performance of
your transmission.
Capacities
10.4 Quarts (9.9 Liters) Includes heater and coolant
recovery bottle filled to MAX
level.
15.4 Quarts (14.6 Liters) Includes heater and coolant
recovery bottle filled to MAX
level.
16 Quarts (15.2 Liters) Includes heater and coolant
recovery bottle filled to MAX
level.
6 Quarts (5.6 Liters)
7 Quarts (6.6 Liters)
—
—
—
—
MAINTAINING YOUR VEHICLE
Component
Fluid, Lubricant, or
Genuine Part
We recommend you use Shell
Transfer Case – 3.6L Engine
Automatic Transmission
Fluid 3353.
We recommend you use
Transfer Case – 5.7L Engine
MOPAR® ATF+4® Automatic
Transmission Fluid.
We recommend you use
Axle Differential (Front/Rear) MOPAR® GL-5 Synthetic Axle
Lubricant SAE 75W-85.
We recommend you use
MOPAR® DOT 3 and SAE
J1703. If DOT 3 is not availBrake Master Cylinder
able, then DOT 4 is acceptable. Use only recommended
brake fluids.
We recommend you use
Power Steering Reservoir –
MOPAR® Hydraulic Fluid
3.6L Engine
meeting Chrysler Material
Standard MS-11655.
We recommend you use
MOPAR® Power Steering Fluid
Power Steering Reservoir – +4, or MOPAR® ATF+4® Auto5.7L Engine
matic Transmission Fluid
meeting Chrysler Material
Standard MS-9602.
87 Octane acceptable. 89
Fuel Selection – 3.6L, 5.7L
Octane recommended for
Engine
5.7L.
Capacities
—
—
—
—
—
—
25 Gallons (94 Liters) (Approximate)
155
MAINTAINING YOUR VEHICLE
CAUTION!
•
•
•
Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is
different and should not be mixed with Hybrid Organic Additive Technology (HOAT)
engine coolant (antifreeze) or any “globally compatible” coolant (antifreeze). If a
non-OAT engine coolant (antifreeze) is introduced into the cooling system in an
emergency, the cooling system will need to be drained, flushed, and refilled with
fresh OAT coolant (conforming to MS-12106), by an authorized dealer as soon as
possible.
Do not use water alone or alcohol-based engine coolant (antifreeze) products. Do not
use additional rust inhibitors or antirust products, as they may not be compatible
with the radiator engine coolant and may plug the radiator.
This vehicle has not been designed for use with propylene glycol-based engine
coolant (antifreeze). Use of propylene glycol-based engine coolant (antifreeze) is not
recommended.
E-85 Flexible Fuel – 3.6L Engine Only
CAUTION!
Only vehicles with the E-85 fuel filler door label or a yellow gas cap can operate on E-85.
• Refer to your Owner's Manual on the DVD for further details.
MAINTENANCE SCHEDULE — GASOLINE ENGINE
Your vehicle is equipped with an automatic oil change indicator system. The oil change
indicator system will remind you that it is time to take your vehicle in for scheduled
maintenance.
Based on engine operation conditions, the oil change indicator message will illuminate.
This means that service is required for your vehicle. Operating conditions such as frequent
short-trips, trailer tow, extremely hot or cold ambient temperatures, and E85 fuel usage will
influence when the “Oil Change Required” message is displayed. Severe Operating Conditions can cause the change oil message to illuminate as early as 3,500 miles (5 600 km)
since last reset. Have your vehicle serviced as soon as possible, within the next 500 miles
(805 km).
Your authorized dealer will reset the oil change indicator message after completing the
scheduled oil change. If a scheduled oil change is performed by someone other than your
authorized dealer, the message can be reset by referring to the steps described under
“Electronic Vehicle Information Center (EVIC)/Oil Change Required” in “Understanding Your
Instrument Panel” for further information
156
MAINTAINING YOUR VEHICLE
NOTE:
Under no circumstances should oil change intervals exceed 10,000 miles (16 000 km) or
twelve months, whichever comes first.
Once A Month Or Before A Long Trip:
• Check engine oil level
• Check windshield washer fluid level
• Check the tire inflation pressures and look for unusual wear or damage
• Check the fluid levels of the coolant reservoir, brake master cylinder, power steering and
transmission as needed
• Check function of all interior and exterior lights
Required Maintenance
Refer to the Maintenance Schedules on the following pages for required maintenance.
•
At Every Oil Change Interval As Indicated By Oil Change Indicator System:
Change oil and filter.
•
Rotate the tires. Rotate at the first sign of irregular wear, even if it occurs before the oil
indicator system turns on.
Inspect battery and clean and tighten terminals as required.
•
•
•
Inspect automatic transmission fluid if equipped with dipstick.
Inspect brake pads, shoes, rotors, drums, hoses and park brake.
Inspect engine cooling system protection and hoses.
•
•
Inspect exhaust system.
Inspect engine air cleaner if using in dusty or off-road conditions.
•
157
X
X
Inspect the brake linings, replace as necessary.
Adjust parking brake.
X
** The spark plug change interval is mileage based only, yearly intervals do not apply.
Inspect and replace PCV valve if necessary.
Change transfer case fluid.
X
X
X
X
X
X
X
X
X
Flush and replace the engine coolant at 10
years or 150,000 miles (240,000 km) whichever comes first.
X
X
X
X
X
X
X
X
X
X
X
Replace spark plugs (5.7L engine).**
X
X
X
X
X
X
Replace spark plugs (3.6L engine).**
Replace air conditioning filter.
Replace engine air filter.
Additional Maintenance
X
X
Inspect the front and rear axle fluid, change
if using your vehicle for police, taxi, fleet,
off-road or frequent trailer towing.
Inspect transfer case fluid.
X
Inspect front suspension, tie rod ends, and
replace if necessary.
Inspect the CV joints.
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Or Kilometers:
X
20,000
32,000
X
48,000
X
64,000
X
80,000
X
96,000
X
112,000
Additional Inspections
15
14
13
12
30,000
11
40,000
10
50,000
9
60,000
8
70,000
7
80,000
128,000
6
90,000
144,000
5
100,000
160,000
4
110,000
176,000
3
120,000
192,000
2
130,000
208,000
Or Years:
140,000
Mileage or time passed
(whichever comes first)
150,000
224,000
158
240,000
Maintenance Chart
MAINTAINING YOUR VEHICLE
•
•
You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right
equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Failure to properly inspect and maintain your vehicle could result in a component malfunction and effect vehicle handling and
performance. This could cause an accident.
WARNING!
MAINTAINING YOUR VEHICLE
159
160
20,000 Miles
(32,000 km) or
2 Years
30,000 Miles
(48,000 km) or
3 Years
40,000 Miles
(64,000 km) or
4 Years
50,000 Miles
(80,000 km) or
5 Years
60,000 Miles
(96,000 km) or
6 Years
70,000 Miles
(112,000 km) or
7 Years
80,000 Miles
(128,000 km) or
8 Years
Odometer
MAINTENANCE RECORD
Date
Signature, Authorized
Service Center
90,000 Miles
(144,000 km) or
9 Years
100,000 Miles
(160,000 km) or
10 Years
110,000 Miles
(176,000 km) or
11 Years
120,000 Miles
(192,000 km) or
12 Years
130,000 Miles
(208,000 km) or
13 Years
140,000 Miles
(224,000 km) or
14 Years
150,000 Miles
(240,000 km) or
15 Years
Odometer
Date
Signature, Authorized
Service Center
MAINTAINING YOUR VEHICLE
MAINTAINING YOUR VEHICLE
FUSES
Power Distribution Center (fuses)
The Power Distribution Center is located in the engine compartment near the battery. This
center contains cartridge fuses, micro fuses, relays, and circuit breakers. A description of
each fuse and component may be stamped on the inside cover, otherwise the cavity
number of each fuse is stamped on the inside cover that corresponds to the following chart.
Cavity
F03
F05
Cartridge Fuse
60 Amp Yellow
40 Amp Green
F06
40 Amp Green
F07
F08
40 Amp Green
40 Amp Green
F09
40 Amp Green
F10
40 Amp Green
F11
30 Amp Pink
F12
F13
F14
F17
F20
F22
F23
F24
F25
F26
40 Amp Green
40 Amp Green
40 Amp Green
30 Amp Pink
30 Amp Pink
20 Amp Yellow
30 Amp Pink
30 Amp Pink
30 Amp Pink
30 Amp Pink
F28
20 Amp Yellow
F29
20 Amp Yellow
F30
F32
F34
F35
F36
F37
30 Amp Pink
30 Amp Pink
30 Amp Pink
30 Amp Pink
30 Amp Pink
30 Amp Pink
Micro Fuse
Description
Rad Fan
Compressor for Air Suspension if
equipped
Antilock Brakes/Electronic Stability
Control Pump
Starter Solenoid
Emission sensors (Diesel engine
only)
Diesel Fuel Heater (Diesel engine
only)
Body Controller / Exterior Lighting
#2
Trailer Tow Electric Brake - If
Equipped
Body Controller #3 / Interior Lights
Blower Motor Front
Body Controller #4 / Power Locks
Headrest Release - If Equipped
Passenger Door Module
Engine Control Module
Body Controller #1
Driver Door Module
Front Wipers
Antilock Brakes/Stability Control
Module/Valves
Trailer Tow Backup Lights - If
Equipped
Trailer Tow Parking Lights - If
Equipped
Trailer Tow Receptacle - If Equipped
Drive Train Control Module
Slip Differential Control
Sunroof - If Equipped
Rear Defroster
Rear Blower - If Equipped
161
MAINTAINING YOUR VEHICLE
162
Cavity
F38
Cartridge Fuse
30 Amp Pink
F39
F40
F42
F44
F46
F49
30 Amp Pink
10 Amp Red
Micro Fuse
20 Amp Yellow
10 Amp Red
10 Amp Red
10 Amp Red
F50
20 Amp Yellow
F51
10 Amp Red
F52
F53
5 Amp Tan
20 Amp Yellow
F56
15 Amp Blue
F57
F59
F60
F62
F63
15 Amp Blue
10 Amp Red
15 Amp Blue
10 Amp Red
20 Amp Yellow
F64
F66
25 Amp Natural
10 Amp Red
F67
15 Amp Blue
F68
F70
F71
F73
F74
F76
20 Amp Yellow
20 Amp Yellow
30 Amp Green
15 Amp Blue
20 Amp Yellow
10 Amp Red
F77
10 Amp Red
F78
10 Amp Red
F80
10 Amp Red
Description
Power Inverter 115V AC - If
Equipped
Power Liftgate - If Equipped
Daytime Running Lights
Horn
Diagnostic Port
Tire Pressure Monitor
Integrated Central Stack / Climate
Control
Air Suspension Control Module - If
Equipped
Ignition Node Module / Keyless
Ignition / Steering Column Lock
Battery Sensor
Trailer Tow – Left Turn/Stop Lights If Equipped
Additional Content (Diesel engine
only)
Transmission
Purging Pump (Diesel engine only)
Transmission Control Module
Air Conditioning Clutch
Ignition Coils (Gas), Urea Heater
(Diesel)
Fuel Injectors / Powertrain
Sunroof / Passenger Window
Switches / Rain Sensor
CD / DVD / Bluetooth Hands-free
Module - If Equipped
Rear Wiper Motor
Fuel Pump Motor
Audio Amplifier
HID Headlamps Right
Brake Vacuum Pump - If Equipped
Antilock Brakes/Electronic Stability
Control
Drivetrain Control Module/Front
Axle Disconnect Module
Engine Control Module / Electric
Power Steering - If Equipped
Universal Garage Door Opener /
Compass / Anti-Intrusion Module
MAINTAINING YOUR VEHICLE
Cavity
F81
F82
Cartridge Fuse
Micro Fuse
20 Amp Yellow
10 Amp Red
F83
F84
F85
F86
F87
10 Amp Red
15 Amp Blue
10 Amp Red
10 Amp Red
10 Amp Red
F88
F90/F91
15 Amp Blue
20 Amp Yellow
F92
F93
F94
F95
F96
10 Amp Red
20 Amp Yellow
10 Amp Red
10 Amp Red
10 Amp Red
F97
25 Amp Natural
F98
F99
25 Amp Natural
10 Amp Red
F100
F101
10 Amp Red
15 Amp Blue
F103
F104
10 Amp Red
20 Amp Yellow
Description
Trailer Tow Right Turn/Stop Lights
Steering Column Control Module/
Cruise Control
Fuel Door
Switch Bank/Instrument Cluster
Airbag Module
Airbag Module
Air Suspension / Trailer Tow /
Steering Column Control Module
Instrument Panel Cluster
Power Outlet (Rear seats) Selectable
Rear Console Lamp - If Equipped
Cigar Lighter
Shifter / Transfer Case Module
Rear Camera / Park Assist
Rear Seat Heater Switch / Flashlamp Charger - If Equipped
Rear Heated Seats & Heated Steering Wheel - If Equipped
Front Heated Seats - If Equipped
Climate Control / Driver Assistance
Systems Module
Active Damping - If Equipped
Electrochromatic Mirror/Smart
High Beams - If Equipped
Cabin Heater (Diesel engine only)
Power Outlets (Instrument Panel/
Center Console)
CAUTION!
•
•
When installing the power distribution center cover, it is important to ensure the
cover is properly positioned and fully latched. Failure to do so may allow water to get
into the power distribution center and possibly result in an electrical system failure.
When replacing a blown fuse, it is important to use only a fuse having the correct
amperage rating. The use of a fuse with a rating other than indicated may result in a
dangerous electrical system overload. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be corrected.
163
MAINTAINING YOUR VEHICLE
TIRE PRESSURES
• Check the inflation pressure of each tire, including the spare tire, at least monthly and
inflate to the recommended pressure for your vehicle.
• The tire pressures recommended for your vehicle are found on the “Tire and Loading
Information” label located on the driver’s side door opening.
NOTE:
Refer to the Owner's Manual on the DVD for
more information regarding tire warnings
and instructions.
WARNING!
•
•
Overloading of your tires is dangerous. Overloading can cause tire failure, affect
vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them.
Improperly inflated tires are dangerous and can cause collisions. Under-inflation is
the leading cause of tire failure and may result in severe cracking, component
separation, or “blow out”. Over-inflation reduces a tire’s ability to cushion shock.
Objects on the road and chuck holes can cause damage that results in tire failure.
Unequal tire pressures can cause steering problems. You could lose control of your
vehicle. Over-inflated or under-inflated tires can affect vehicle handling and can fail
suddenly, resulting in loss of vehicle control.
WHEEL AND WHEEL TRIM CARE
• All wheels and wheel trim, especially aluminum and chrome plated wheels, should be
cleaned regularly with a mild soap and water to prevent corrosion.
• To remove heavy soil and/or excessive brake dust, use MOPAR® Wheel Cleaner or
equivalent or select a non-abrasive, non-acidic cleaner.
CAUTION!
Do not use scouring pads, steel wool, a bristle brush, or metal polishes. Do not use oven
cleaner. These products may damage the wheel's protective finish. Avoid automatic car
washes that use acidic solutions or harsh brushes that may damage the wheel's protective finish. Only MOPAR® Wheel Cleaner or equivalent is recommended.
164
MAINTAINING YOUR VEHICLE
EXTERIOR BULBS
LIGHT BULBS – Exterior
Low Beam/High Beam (Bi-Xenon) Headlamps
Low Beam/High Beam/Daytime Running
Lamp (DRL) Bi-Halogen Headlamps (Base)
Low Beam/High Beam (Bi-Halogen) Headlamps (Uplevel)
Front Park/Turn Signal Lamps (Base)
Front Turn Signal Lamps (Uplevel & Premium)
Front Park Lamp/Daytime Running Lamp
(Uplevel & Premium)
Front Side Marker Lamps
Front Fog Lamps
Rear Tail Lamps/Sidemarker Lamps
Rear Stop/Turn Signal Lamps
Rear Liftgate Tail Lamps
Rear Backup Lamps
Rear License Lamps
Center High-Mounted Stop Lamp (CHMSL)
Bulb Number
D3S (Service at Authorized Dealer)
HIR2
HIR2
3157NAK
3157NAK
LED (Service at Authorized Dealer)
LED (Service at Authorized Dealer)
H11
LED (Service at Authorized Dealer)
LED (Service at Authorized Dealer)
LED (Service at Authorized Dealer)
921 (W16W)
LED (Service at Authorized Dealer)
LED (Service at Authorized Dealer)
* CHMSL is not serviceable. It is a LED lamp. To replace the LED, the entire CHMSL assembly
must be replaced.
** The headlamps are a type of high-voltage discharge tube. High voltage can remain in the
circuit even with the headlamp switch off and the Key Fob removed. Because of this, you
should not attempt to service a headlamp bulb yourself. If a headlamp bulb fails, take your
vehicle to an authorized dealer for service.
165
CUSTOMER ASSISTANCE
CHRYSLER GROUP LLC CUSTOMER CENTER
P.O. Box 21–8004 Auburn Hills, MI 48321–8004 Phone: 1–800–423–6343
CHRYSLER CANADA INC. CUSTOMER CENTER
P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: 1–800–465–2001 (English) Phone: 1–800–
387–9983 (French)
ASSISTANCE FOR THE HEARING IMPAIRED
• To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommunication Devices for the Deaf) equipment at its customer center.
Any hearing or speech impaired customer, who has access to a TDD or a conventional
teletypewriter (TTY) in the United States, can communicate with the manufacturer by
dialing 1–800–380–CHRY. Canadian residents with hearing difficulties that require assistance can use the special needs relay service offered by Bell Canada. For TTY
teletypewriter users, dial 711 and for Voice callers, dial 1–800–855–0511 to connect with a
Bell Relay Service operator.
WARNING!
Engine exhaust, some of its constituents, and certain vehicle components contain, or
emit, chemicals known to the State of California to cause cancer and birth defects, or
other reproductive harm. In addition, certain fluids contained in vehicles and certain
products of component wear contain, or emit, chemicals known to the State of California
to cause cancer and birth defects, or other reproductive harm.
PUBLICATIONS ORDERING
• If you are the first registered retail owner of your vehicle, you may obtain one free
printed copy of the Owner's Manual, Warranty Booklet or Radio Manuals on your DVD by
calling 1–800–423–6343 (U.S.) or 1–800–387–1143 (Canada) or by contacting your dealer.
• Replacement User Guide kits or DVDs or, if you prefer, additional printed copies of the
Owner's Manual, Warranty Booklet or Radio Manuals may be purchased by visiting
www.techauthority.com or by calling 1–800–890–4038 (U.S.) or 1–800–387–1143
(Canada). Visa, Master Card, American Express and Discover orders are accepted. If you
prefer mailing your order, please call the above numbers for an order form.
NOTE:
• A street address is required when ordering manuals (no P.O. Boxes).
• The Owner's Manual and User Guide electronic files are also available on the Chrysler,
Jeep, Ram Truck, Dodge and SRT websites.
• Click on the “For Owners” tab, select “Owner/Service Manuals”, then select your desired
model year and vehicle from the drop down lists.
166
CUSTOMER ASSISTANCE
REPORTING SAFETY DEFECTS IN THE UNITED STATES
• If you believe that your vehicle has a defect that could cause a collision or cause injury or
death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying the manufacturer.
• If NHTSA receives similar complaints, it may open an investigation, and if it finds that a
safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
However, NHTSA cannot become involved in individual problems between you, your
authorized dealer and the manufacturer.
• To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–
4236 (TTY: 1–800–424–9153), or go to http://www.safercar.gov; or write to: Administrator,
NHTSA, 1200 New Jersey Avenue, SE., West Building, Washington, D.C. 20590. You can
also obtain other information about motor vehicle safety from http://www.safercar.gov.
In Canada
• If you believe that your vehicle has a safety defect, you should contact the Customer
Service Department immediately. Canadian customers who wish to report a safety
defect to the Canadian government should contact Transport Canada, Motor Vehicle
Defect Investigations and Recalls at 1-800-333-0510 or go to http://www.tc.gc.ca/eng/
roadsafety/safedrivers-childsafety-index-53.htm
• French Canadian customers who wish to report a safety defect to the Canadian government should contact Transport Canada, Motor Vehicle Defect Investigations and Recalls
at 1-800-333-0510 or go to http://www.tc.gc.ca/securiteroutiere/
167
MOPAR ACCESSORIES
AUTHENTIC ACCESSORIES BY MOPAR®
• The following highlights just some of the many Authentic Dodge Accessories by Mopar
featuring a fit, finish, and functionality specifically for your Dodge Durango.
• In choosing Authentic Accessories you gain far more than expressive style, premium
protection, or extreme entertainment, you also benefit from enhancing your vehicle with
accessories that have been thoroughly tested and factory-approved.
• For the full line of Authentic Dodge Accessories by Mopar, visit your local Dodge dealership or online at mopar.com.
EXTERIOR:
• Molded Running Boards
• Front End Cover
• Wheels
• Chrome Front Air Deflector
• Hitch Receiver
• Black Tubular Side Steps
• Tubular Side Steps
• Molded Splash Guards
• Chrome Accents
INTERIOR:
• Premium Carpet Floor Mats
• Slush Mats
• Heated Seats
• Door Sill Guards
• Katzkin Leather Interiors
• Ambient Lighting
• Molded Cargo Tray
• Bright Pedal Kit
ELECTRONICS:
• Mopar Web (WiFi)
• Rear View Camera
• Electronic Vehicle Tracking
System
• Remote Start
• Park Distance Sensors
CARRIERS:
• Hitch-Mount Bike Carrier
• Roof Mount Ski and Snowboard Carrier
• Roof Rack
• Roof Box Cargo Carrier
• Roof Mount Water Sports
Carrier
• Hitch Receiver
168
• Roof Mount Bike Carrier
• Cargo Basket
INDEX
Adaptive Cruise Control (ACC)
(Cruise Control) . . . . . . . . . . . .34
Adding Fuel . . . . . . . . . . . . . . .150
Airbag . . . . . . . . . . . . . . . . . . .15
Air Conditioning . . . . . . . . . . . .40, 41
Alarm (Security Alarm) . . . . . . . . . .14
All Wheel Drive (AWD) . . . . . . . . . .116
Anti-Lock Brake System (ABS) . . . . .128
Arming Theft System (Security Alarm) . .14
Automatic Dimming Mirror . . . . . . . .32
Automatic Headlights . . . . . . . . . .30
Automatic Temperature Control (ATC) . .40
SYNC Temperature Button . . . . . .42
Automatic Transmission
Fluid Type . . . . . . . . . . . . . .154
Axle Fluid . . . . . . . . . . . . . .154, 155
Back-Up Camera . . . . . . . . . . . . .43
Battery
Charging System Light . . . . . . .128
Belts, Seat. . . . . . . . . . . . . . . . .14
Blind Spot Monitoring . . . . . . . . . .43
Brake Fluid . . . . . . . . . . . . .154, 155
Brake System
Warning Light . . . . . . . . . . . .126
Break-In Recommendations, New
Vehicle. . . . . . . . . . . . . . . . .30
Bulb Replacement . . . . . . . . . . . .165
Calibration, Compass . . . . . . . . . .109
Caps, Filler
Fuel . . . . . . . . . . . . . . . . .148
Cargo Compartment
Luggage Carrier . . . . . . . . . . .119
Change Oil Indicator . . . . . . . . . . .129
Changing A Flat Tire . . . . . . . . . . .131
Charging System Light . . . . . . . . .128
Check Engine Light (Malfunction
Indicator Light) . . . . . . . . . . . .127
Child Restraint . . . . . . . . . . . . . .16
Climate Control . . . . . . . . . . . . . .40
Compass Calibration . . . . . . . . . .109
Cooling System
Coolant Capacity . . . . . . . . . .154
Cruise Control (Speed Control) . . . . . .33
Cruise Light. . . . . . . . . . . . . . . .33
Customer Assistance . . . . . . . . . .166
Customer Programmable Features . . .110
Defects, Reporting . . . . . . . . . . . .167
Dimmer Control . . . . . . . . . . . . . .31
Dimmer Switch, Headlight . . . . . . . .31
Disarming, Theft System . . . . . . . . .14
ECO . . . . . . . . . . . . . . . . . . .109
Economy (Fuel) Mode. . . . . . . . . . .39
Electronically Shifted Transfer Case . . .116
Electronic Power Distribution Center
(Fuses) . . . . . . . . . . . . . . . .161
Electronics
Your Vehicle's Sound System . . .46, 47
Electronic Speed Control
(Cruise Control) . . . . . . . . . . . .33
Electronic Stability Control (ESC) . . . .128
Electronic Throttle Control Warning
Light . . . . . . . . . . . . . . . . .129
Electronic Vehicle Information Center
(EVIC). . . . . . . . . . . . . . .109, 110
Emergency, In Case of
Jacking . . . . . . . . . . . . . . .131
Overheating . . . . . . . . . . . . .130
Engine
Break-In Recommendations . . . . .30
Compartment . . . . . . . . . . . .152
Coolant (Antifreeze) . . . . . . . . .154
Malfunction Indicator
(Check Engine) . . . . . . . . . . . .127
Oil . . . . . . . . . . . . . . . . . .154
Oil Filter . . . . . . . . . . . . . . .154
Oil Selection . . . . . . . . . . . . .154
Overheating . . . . . . . . . . . . .130
Starting . . . . . . . . . . . . . . . .13
Stopping . . . . . . . . . . . . . . .13
Event Data Recorder. . . . . . . . . . .148
Exterior Lights . . . . . . . . . . . . . .165
Fluid Capacities . . . . . . . . . . . . .154
Fluids . . . . . . . . . . . . . . . . . .154
Fog Lights . . . . . . . . . . . . . . . .30
Folding Front Passenger Seat . . . . . .22
Folding Power Third Row Head
Restraints . . . . . . . . . . . . . . .25
Folding Rear Seat. . . . . . . . . . .23, 25
Forward Collision Warning . . . . . . . .35
Four Wheel Drive . . . . . . . . . . . . .116
169
INDEX
Operation . . . . . . . . . . . . . .116
Systems . . . . . . . . . . . . . . .116
Four Wheel Drive Operation . . . . . . .116
Freeing A Stuck Vehicle . . . . . . . . .147
Fuel
Economy Mode . . . . . . . . . . . .39
Filler Door Emergency Release . . .151
Specifications . . . . . . . . .154, 155
Fuses . . . . . . . . . . . . . . . . . . .161
Headlights
Automatic . . . . . . . . . . . . . .30
Dimmer Switch . . . . . . . . . . . .31
High Beam . . . . . . . . . . . . . .32
High Beam/Low Beam Select
Switch . . . . . . . . . . . . . . . .32
Head Restraints
Power Folding Third Row . . . . . . .25
Heated Mirrors . . . . . . . . . . . . . .41
Heated Seats . . . . . . . . . . . . . . .26
High Beam/Low Beam Select (Dimmer)
Switch . . . . . . . . . . . . . . . . .32
HomeLink® (Garage Door Opener) . . . .111
Hood Release . . . . . . . . . . . . . .149
Instrument Cluster . . . . . . . . . . . . .9
Indicators . . . . . . . . . . . . . . .9
Instrument Cluster Warning Lights . . . .8
Interior and Instrument Lights . . . . . . .7
Intermittent Wipers (Delay Wipers) . . . .31
Introduction . . . . . . . . . . . . . . . .2
Inverter Outlet (115V) . . . . . . . . . . .113
Inverter, Power . . . . . . . . . . . . . .113
Jacking Instructions. . . . . . . . . . .136
Jack Location . . . . . . . . . . . . . .131
Jack Operation . . . . . . . . . . .131, 136
Jump Starting . . . . . . . . . . . . . .142
Key Fob . . . . . . . . . . . . . . . . . .10
Keyless Enter-N-Go . . . . . . . . . . . .10
Lock/Unlock . . . . . . . . . . . .11, 12
Starting/Stopping . . . . . . . . . .13
Lane Change Assist. . . . . . . . . . . .31
Lap/Shoulder Belts . . . . . . . . . . . .14
LATCH (Lower Anchors and Tether for
CHildren) . . . . . . . . . . . .16, 17, 19
170
Liftgate . . . . . . . . . . . . . . . . . .10
Liftgate, Power . . . . . . . . . . . . . .10
Light Bulbs. . . . . . . . . . . . . . . .165
Lights
Headlights . . . . . . . . . . . . . .30
Warning (Instrument Cluster
Description) . . . . . . . . . . . . . .8
Locks
Liftgate, Tailgate . . . . . . . . . . .10
Luggage Rack (Roof Rack) . . . . . . . .119
Maintenance Record. . . . . . . . . . .160
Maintenance Schedule . . . . . . . . .156
Malfunction Indicator Light (Check
Engine) . . . . . . . . . . . . . . . .127
Memory Seat . . . . . . . . . . . . . . .21
Mirrors
Automatic Dimming . . . . . . . . .32
Heated . . . . . . . . . . . . . . . .41
MOPAR® Accessories . . . . . . . . . .168
Navigation . . . . . . . . . . . . . . .79, 97
New Vehicle Break-In Period . . . . . . .30
Oil Change Indicator . . . . . . . . . . .129
Oil Change Indicator, Reset . . . . . . .129
Oil, Engine
Capacity . . . . . . . . . . . . . . .154
Outlet
Power . . . . . . . . . . . . . . . .114
Overheating, Engine . . . . . . . . . . .130
Panic Alarm . . . . . . . . . . . . . . . .10
ParkSense System, Rear . . . . . . . . .42
Placard, Tire and Loading Information . .164
Power
Folding Third Row Head Restraints . .25
Inverter . . . . . . . . . . . . . . .113
Lift Gate . . . . . . . . . . . . . . .10
Outlet (Auxiliary Electrical Outlet) . .114
Seats . . . . . . . . . . . . . . . . .20
Steering . . . . . . . . . . . .154, 155
Preparation for Jacking . . . . . . . . .135
Programmable Electronic Features . . .110
Rain Sensitive Wiper System . . . . . . .31
Rear Camera . . . . . . . . . . . . . . .43
Rear Cross Path . . . . . . . . . . . . .43
INDEX
Rear Heated Seats . . . . . . . . . . . .27
Rear ParkSense System . . . . . . .42, 43
Rear Seat, Folding . . . . . . . . . . . .23
Reclining Front Seats. . . . . . . . . . .22
Recreational Towing . . . . . . . . . . .121
Shifting into Transfer Case
Neutral (N) . . . . . . . . . . . . . .122
Shifting out of Transfer Case
Neutral (N) . . . . . . . . . . . . . .124
Remote Starting System . . . . . . . . .10
Replacement Bulbs . . . . . . . . . . .165
Reporting Safety Defects . . . . . . . .167
Roll Over Warning . . . . . . . . . . . . .4
Roof Rack (Luggage Rack) . . . . . . . .119
Schedule, Maintenance . . . . . . . . .156
Seat Belts . . . . . . . . . . . . . . . . .14
Seats . . . . . . . . . . . . . . . . .20, 22
Adjustment . . . . . . . . . . . . . .22
Folding Front Passenger . . . . . . .22
Heated . . . . . . . . . . . . . . . .26
Memory . . . . . . . . . . . . . . . .21
Power . . . . . . . . . . . . . . . . .20
Rear Folding . . . . . . . . . . .23, 25
Ventilated . . . . . . . . . . . . . .26
Security Against Theft . . . . . . . . . .14
Signals, Turn . . . . . . . . . . . . . . .31
SIRIUS Travel Link . . . . . . . . . . . .100
Spare Tire . . . . . . . . . . . . . . . .132
Spark Plugs . . . . . . . . . . . . . . .154
Speed Control
Accel/Decel . . . . . . . . . . . . .33
Cancel . . . . . . . . . . . . . . . .33
Distance Setting (ACC Only) . . . . .33
Mode Setting (ACC Only) . . . . . . .35
Speed Control (Cruise Control) . . . . . .33
Starting
Remote . . . . . . . . . . . . . . . .10
Steering
Tilt Column . . . . . . . . . . . . . .28
Supplemental Restraint System Airbag . . . . . . . . . . . . . . . . .15
Temperature Control, Automatic (ATC) . . .40
Tether Anchor, Child Restraint . . . . . .18
Theft System Arming . . . . . . . . . . .14
Theft System Disarming . . . . . . . . .14
Tilt Steering Column . . . . . . . . . . .28
Tires
Air Pressure . . . . . . . . . . . . .164
Changing . . . . . . . . . . . . . .131
Jacking . . . . . . . . . . . . . . .131
Pressure Warning Light . . . . . . .125
Spare Tire . . . . . . . . . . . . . .132
Towing . . . . . . . . . . . . . . . . . .120
Disabled Vehicle . . . . . . . . . . .146
Recreational . . . . . . . . . . . . .121
Towing Vehicle Behind a Motorhome . .121
Trailer Towing
Trailer and Tongue Weight . . . . . .120
Trailer Weight . . . . . . . . . . . . . .120
Transfer Case
Electronically Shifted . . . . . . . .116
Fluid . . . . . . . . . . . . . . . . .154
Transmission
Fluid . . . . . . . . . . . . . . . . .154
Turn Signals . . . . . . . . . . . . . . . .31
Uconnect® 5.0 . . . . . . . . . . . . . .65
Uconnect® 8.4A . . . . . . . . . . . . . .72
Uconnect® 8.4AN . . . . . . . . . . . . .90
Warning, Roll Over . . . . . . . . . . . . .4
Washer
Rear . . . . . . . . . . . . . . . . .32
Washers, Headlight . . . . . . . . . . . .31
Washers, Windshield . . . . . . . . . . .31
Wheel and Wheel Trim Care . . . . . . .164
Wind Buffeting . . . . . . . . . . . . . .45
Windshield Washers . . . . . . . . . . .31
Windshield Wipers . . . . . . . . . . . .31
Wiper, Rear . . . . . . . . . . . . . . . .32
Wipers, Intermittent. . . . . . . . . . . .31
Wipers, Rain Sensitive . . . . . . . . . .32
171
FAQ (How To?)
FREQUENTLY ASKED QUESTIONS
GETTING STARTED
• How do I install my LATCH Equipped Child Seat? pg. 17
• How do I program my Front Seat Memory? pg. 21
OPERATING YOUR VEHICLE
• How does the Electronic Shifter operate? pg. 38
ELECTRONICS
• Which radio is in my vehicle?
• Uconnect® 5.0 pg. 65
• Uconnect® 8.4A pg. 72
• Uconnect® 8.4AN pg. 90
• How do I activate the Audio Jack?
• Uconnect® 5.0 pg. 67
• Uconnect® 8.4A pg. 95
• Uconnect® 8.4AN pg. 95
• How do I set the clock on my radio?
• Uconnect® 5.0 pg. 65
• Uconnect® 8.4A pg. 72
• Uconnect® 8.4AN pg. 90
• How do I use the Navigation feature?
• Uconnect® 8.4A pg. 79
• Uconnect® 8.4AN pg. 97
• How do I pair my Bluetooth® phone with the Uconnect® system ? pg. 101
• How do I use my Universal Garage Door Opener pg. 111
• What does the ECO message mean on the EVIC display? pg. 109
UTILITY
• How do I know how much I can tow with my Dodge Durango? pg. 120
172
FAQ (How To?)
WHAT TO DO IN EMERGENCIES
• What do I do if my TPMS warning light is blinking? pg. 125
• How do I change a flat tire? pg. 131
• How do I Jump-Start my vehicle? pg. 142
MAINTAINING YOUR VEHICLE
• Where is my Fuse Block located? pg. 161
• What type of oil do I use? pg. 154
• How often should I change my engine’s oil? pg. 156
• What should my tire pressure be set at? pg. 164
173
NOTES
174
NOTES
175
NOTES
176
dodge.com
This guide has been prepared to help you get quickly acquainted with your new Dodge and to
provide a convenient reference source for common questions. However, it is not a substitute for
your Owner’s Manual.
For complete operational instructions, maintenance procedures and important safety messages,
please consult your Owner’s Manual, Navigation/Uconnect® Manuals and other Warning Labels in
your vehicle.
Not all features shown in this guide may apply to your vehicle. For additional information on
accessories to help personalize your vehicle, visit www.mopar.com (U.S), www.mopar.ca (Canada)
or your local Dodge dealer.
> IMPORTANT
This User Guide is intended to familiarize you with the important features of your vehicle.
The DVD enclosed contains your Owner’s Manual, Navigation/Uconnect® Manuals, Warranty
Booklets, Tire Warranty and Roadside Assistance (new vehicles purchased in the U.S.) or
Roadside Assistance (new vehicles purchased in Canada) in electronic format. We hope you
find it useful. Replacement DVD kits may be purchased by visiting www.techauthority.com.
Copyright 2013 Chrysler Group LLC.
If you are the first registered retail owner of your vehicle, you
may obtain a complimentary printed copy of the Owner’s
Manual, Navigation/Uconnect® Manuals or Warranty Booklet
by calling 1-800-423-6343 (U.S.) or 1-800-387-1143 (Canada)
or by contacting your dealer.
The driver’s primary responsibility is the safe operation of the vehicle. Driving while
distracted can result in loss of vehicle control, resulting in a collision and personal injury.
Chrysler Group LLC strongly recommends that the driver use extreme caution when using any
device or feature that may take their attention off the road. Use of any electrical devices such
as cell phones, computers, portable radios, vehicle navigation or other devices by the driver
while the vehicle is moving is dangerous and could lead to a serious collision. Texting while
driving is also dangerous and should never be done while the vehicle is moving. If you find
yourself unable to devote your full attention to vehicle operation, pull off the road to a safe
location and stop your vehicle. Some States or Provinces prohibit the use of cellular telephones
or texting while driving. It is always the driver’s responsibility to comply with all local laws.
1419955_14a_Durango_UG_062713.indd 2
Driving and alcohol
Drunken driving is one of the most frequent causes of accidents. Your driving ability can be
seriously impaired with blood alcohol levels far below the legal minimum. If you are drinking, don’t
drive. Ride with a designated non-drinking driver, call a cab, a friend, or use public transportation.
WARNING!
Driving after drinking can lead to an accident. Your perceptions are less sharp, your reflexes are
slower, and your judgment is impaired when you have been drinking. Never drink and then drive.
6/27/13 10:23 AM
Download a FREE electronic copy of the
Owner’s Manual or Warranty Booklet
by visiting the Owners tab at:
www.dodge.com (U.S.)
www.dodge.ca (Canada)
> 2014 durango // User Guide
14WD01-926-AA
durango
First Edition
User Guide
1419955_14a_Durango_UG_062713.indd 1
6/27/13 10:23 AM
