www.DetectoScale.com
Stainless Steel Physician Scales
4
Mechanical Physician Scales
5
Digital Physician & Certifier Scales
6
Digital Bariatric Scales
7
758C Digital Weight Indicator
8
CORPORATE HEADQUARTER CONTACTS:
Health and Fitness Scales
10
Wheelchair Scales
12
Chair Scales
14
Patient Lift Scales
16
In-Bed Scales
17
Digital Baby Scales
18
Mechanical Baby Scales
20
Mechanical Dietary Scales
22
Digital Dietary Scales
23
General Purpose Scales
24
Specialty Scales
25
Veterinary Scales
26
EU-Only Scales
27
Waste Receptacles
28
Step-On Cans
29
Universal Glove Box Holders
30
Index
31
Address: 203 East Daugherty Street, Webb City, MO 64870 USA
Fax: (417) 673-5001
Web Site: www.DetectoScale.com
Customer Service
8 am - 5 pm CST Mon. - Fri.
(800) 641-2008 or (417) 673-4631
[email protected]
Technical Support
(417) 673-5007
[email protected]
8 am - 5 pm CST Mon. - Fri.
Parts Department
(800) 641-2045
[email protected]
8 am - 5:30 pm CST Mon. - Fri.
Quality Assurance
(417) 673-4631
[email protected]
8 am - 5 pm CST Mon. - Fri.
INTERNATIONAL CONTACTS:
European Warehouse
Unit 17/18 Mercers Road
Chapel Pond Hill
Bury St. Edmunds, Suffolk, IP32 7HX
Phone: 44-1284-703117
Fax: 44-1284-703559
E-mail: [email protected]
Canadian Warehouse
1815 Ironstone Manor
Unit 14A
Pickering, Ontario L1W 3W9
Phone: (905) 839-6239
Fax: (905) 839-6522
E-mail: [email protected]
This equipment requires some assembly and setup
that is not included in purchase price. Contact your
local DETECTO scale technician for this service.
These scales are manufactured in compliance with
recommendations set forth in Handbook 44, issued
by the National Institute of Standards and Technology and have been issued a Certificate of Conformance under the National Type Evaluation Program.
Indicates that the device has been evaluated and
found to conform with the requirements for OIML
R76 Class III (or Class IIII if specified). Model numbers for EU-Only Scales and their capacities and increments will differ from their general referenced
product’s information and may recquire the 758CSV
indicator for conformity.
DETECTO
IT’S AN EXCITING TIME TO BE WORKING WITH DETECTO PRODUCTS.
Detecto is changing the face of digital weighing with the introduction of
the enhanced 758C Digital Weight Indicator. This versatile, full-featured
display comes standard on Detecto medical scales and now features serial
connectivity which allows output to a printer for a paper copy of weight,
Body Mass Index (BMI), time, date, and height, as well as output to a PC
for efficient Electronic Medical Record keeping. The ability to print or save
weight data is crucial in clinics, doctors’ offices, long-term care facilities,
and other medical institutions, and is now possible with Detecto’s 758C
indicator. Long-time customers will also notice new black ABS plastic end
caps have been added to improve the overall appearance of the display.
Turn to pages 8 and 9 to find out more about the powerful way in which
the 758C makes Detecto’s line of medical scales much more efficient.
Now, for the first time, you can combine the classic Detecto physician scale
with the time-honored beauty and protection of stainless steel. Detecto
has introduced a line of Stainless Steel Physician Scales availabe in eyelevel mechanical beam and state-of-the-art EMR-ready waist-high digital
models (please see page 4).
Detecto has also introduced the new Model 6880 Rolling Chair Scale
featuring zero turning radius ability and 440 lb/200 kg capacity (page
14), two different lines of Universal Glove Box Holders (page 30), the
Wall-mount Hanging and Standard Stainless Steel Waste Receptacles
(page 28), the Model 6745 Digital Baby Scale (page 18), the PS-7 and
PS-11 Digital Portion Scales (page 23), and the MD250PKG Chiropractic
Scale Package for bilateral weighing.
As we mentioned, it’s an exciting time to be working with Detecto with all
of these new products available. Please
browse through this catalog
and when you find what
you need, give us a
call or e-mail!
PHYSICIAN SCALES
4
INCREASED TO
400 LB /
180 KG
CAPACITY
Detecto Offers You
More Weighing Ability
For Your Money
Stainless Steel MECHANICAL Eye-Level Health Care Scales
Enjoy the classic elegance of beautiful stainless steel in your Detecto mechanical weighbeam scale. A platform
cover that lifts off easily combined with the protective stainless steel casing makes cleanup a breeze. Water
damage from mopping and high humidity areas around swimming pools is a thing of the past with Detecto’s
rust-resistant stainless steel health care scales. The attractive stainless steel fits well in all modern decor.
MODEL
CAPACITY
400 lb x 4 oz
439S
180 kg x 100 g
HEIGHT ROD
30 - 78 in
76 - 198 cm
SHIPPING
WEIGHT
HIBCC UPN
•
38 lb/17.2 kg
+H925439S0W
•
2391S
•
437S
•
•
2371S
•
339S
•
•
337S
•
•
•
37 lb/16.7 kg
+H9252391S0V
35 lb/15.8 kg
+H925437S0U
35 lb/15.8 kg
+H9252371S0T
38 lb/17.2 kg
+H925339S0V
35 lb/15.8 kg
+H925337S0T
Platform Size: 10.5” W x 14.5” D/27 cm W x 37 cm D
Scale Height: 59”/150 cm
Stainless Steel DIGITAL Waist-High Health Care Scales
With an ultra-modern design, Detecto’s stainless steel digital health care scales offer an extra-tough finish
which stands up to water damage from mopping around the base and high-humidity areas such as locker rooms. Enjoy the power of digital weighing with the convenience of “at-a-glance” weight readouts.
400 lb x 0.2 lb / 180 kg x 0.1 kg
HEIGHT ROD
30 - 78 in
76 - 198 cm
SHIPPING
WEIGHT
HIBCC UPN
8430S
•
•
34 lb/15.4 kg
+H9258430S0V
8437S
•
31 lb/14 kg
+H9258437S0
MODEL
CAPACITY
Platform Size: 10.5” W x 14.5” D/27 cm W x 37 cm D
Scale Height: 37.5”/95 cm
758C
Please see pages 8 and 9 for additional weight display features.
www.DetectoScale.com
MECHANICAL PHYSICIAN SCALES
5
Eye-Level Physician Scales
MODEL
CAPACITY
400 lb x 4 oz
439
180 kg x 100 g
HEIGHT ROD
30 - 78 in
76 - 198 cm
•
2391
•
437
SHIPPING
WEIGHT
HIBCC UPN
•
38 lb/17.2 kg
+H92543904
•
37 lb/16.7 kg
+H925239103
WHEELS
HANDPOST
•
2371
•
438
•
2381
•
448
•
449
•
2491
35 lb/15.8 kg
+H92543702
35 lb/15.8 kg
+H925237101
•
•
39 lb/17.6 kg
+H92543803
•
•
•
•
39 lb/17.6 kg
+H925238102
•
43 lb/19.5 kg
+H92544804
•
•
43 lb/19.5 kg
+H92544905
•
•
•
43 lb/19.5 kg
+H925249104
•
35 lb/15.8 kg
+H92533903
35 lb/15.8 kg
+H92533701
39 lb/17.6 kg
+H92533802
43 lb/19.5 kg
+H92534904
339
•
•
337
•
•
338
•
•
•
349
•
•
•
•
•
Platform Size: 10.5” W x 14.5” D/27 cm W x 37 cm D
Scale Height: 59”/150 cm
WEIGH BEAM
Dual reading, die-cast
beam.
Choose From
13 MODELS
HEIGHT ROD
Reads in both inches
and centimeters.
With A
HANDPOST
An important aid for the
elderly or weak individual.
VARIETY OF
FEATURES
WHEELS
For easy transport.
Model 437
Model 448
PLATFORM COVER
Easily removed for
cleaning.
Model
3PHTROD-WM
Wall Mount
Height Rod
ACCESSORY MODEL
DESCRIPTION
HIBCC UPN
Height Rods
3PHTROD-1
Physician scales only.
+H9253PHTROD10+
4PHTROD-2
For all waist-high mechanical scales except model 080.
+H9254PHTROD200
3PHTROD-3
For all waist-high digital scales except models 8430 and
8431.
+H9253PHTROD300
4PHTROD-3
For all waist-high digital scales except models 6029 and
6029KG.
+H9252PHTROD301
3PHTROD-WM Wall-mount height rod.
+H9253PHTRODWM08
Wheels
3PWHL
+H9253PWHL00
Wheels for scale portability. For use with all eye-level
physician scales and the 8430 and 8437 waist-high scales.
Handpost
3PHNDPST
For replacement use on physician scales only.
(800) 641-2008
+H9253PHDNPSTOM
6
DIGITAL PHYSICIAN & CERTIFIER SCALES
Eye-Level Digital Physician Scales
This scale features eye-level “at-a-glance” convenience of a battery-powered
0.5”/12.7 mm high-contrast LCD display. With the push of a button, readings
appear in pounds OR kilograms and the weight display also calculates Body
Mass Index. The platform cover is easily removed for cleaning. Handpost and
height rod combinations are also available.
Model
6437
MODEL
CAPACITY
DESCRIPTION
HIBCC UPN
6437
400 lb x 0.2 lb /
180 kg x 0.1 kg
No Height Rod
+H925643708
6439
Same
With Height Rod
+H92564390A
6449
Same
With Handpost
and Height Rod
+H92564490B
AC Adapter
+H925728R1210-
728R121
Model
6439
Platform Size: 10.5” W x 14.5” D/27 cm W x 37 cm D
Scale Height: 59”/150 cm
Model 6439 Height Rod: 30” - 78” and 76 cm - 198 cm
Shipping Weight: 6437 - 35 lb/16 kg 6439 - 38 lb/17 kg
758C
Please see pages 8 and 9 for additional weight display features.
Low-Profile Digital Physician Floor Scale
Lightweight and portable, making it perfect for mobile clinics, home care
nurses, or wherever a portable scale with Body Mass Index is needed. The
DR400-758C is battery powered and features a slip-resistant, textured mat to
ensure patient safety when getting on and off the scale.
Optional black
carrying case with
handle protects
the scale for easy
transport.
MODEL
CAPACITY
HIBCC UPN
DR400-758C
400 lb x 0.2 lb /
180 kg x 0.1 kg
+H925DR400758C0L
DR400C-CASE
Carrying Case
+H925DR400CCASE0M
728R121
AC Adapter
+H925728R1210-
Platform Size: 2.25” H x12” W x 12” D/6 cm H 31 cm W x 31 cm D
Shipping Weight: 13 lb/6 kg
758C
Please see pages 8 and 9 for additional weight display features.
Certifier Scale
This special purpose eye-level beam scale with dual wheels and non-slip gray
mat is “Legal for Trade,” which makes it the perfect choice for those who require a scale that is certified by weights and measures officials. A must for
weight loss clinics and schools and universities with wrestling teams!
Cert. No.
91-162
MODEL
CAPACITY
DESCRIPTION
HIBCC UPN
442
350 lb x 4 oz /
160 kg x 100 kg
Certifier scale with
high accuracy
+H9254420+
Optional height rod and handpost models are available
Platform Size: 13.75” W x 18.5” D/35 cm W x 47 cm D
Scale Height: 59”/150 cm
Shipping Weight: 68 lb/31 kg
www.DetectoScale.com
DIGITAL BARIATRIC SCALES
Flip Seat
Chair Scale
The seat flips up to
allow weighing in a
standing or sitting
position, depending
upon the comfort of
the patient.
7
Bariatric Flip Seat
Scale

Features a flip-up seat.
The portable 6876 with concealed wheels and battery power
features flip-up armrests which double as handgrips when
used in a standing position. The modern design is streamlined
and narrow enough to fit easily through most doorways.
The 6868’s unique design features a flip-up seat for weighing
in a standing or seated position, foam hand grips, and extrawide, non-skid platform which add comfort and assurance to
the weighing of obese and unsteady patients.
MODEL
CAPACITY
HIBCC UPN
MODEL
CAPACITY
HIBCC UPN
6876
600 lb x 0.2 lb /
270 kg x 0.1 kg
+H92568760F
6868
800 lb x 0.2 lb /
360 kg x 0.1 kg
+H92568680G
728R121
AC Adapter
+H925728R1210-
728R121
AC Adapter
+H925728R1210-
Platform Size: 24” W x 24” D/61 cm x 61 cm
Shipping Weight: 146 lb/66 kg
758C
Platform Size: 32” W x 34” D/81 cm W x 86 cm D
Shipping Weight: 147 lb/67 kg
Please see pages 8 and 9 for additional weight
display features.
Waist-High
Stand-On
Scale
758C
Please see pages 8 and 9 for additional weight
display features.
Waist-High
Stand-On Scale
The 6856 is engineered
specifically for weighing
obese and unsteady
patients and features a
low-profile platform with
non-skid surface.
450 pound patient being weighed.
The 6856 features a larger platform and higher capacity than
the 6855. Its balanced design is easy to tip back and transport
on its 3” diameter, heavy-duty rubber wheels. The stainless
steel handrails feature padded grips for patient assurance.
MODEL
CAPACITY
HIBCC UPN
6856
800 lb x 0.2 lb /
360 kg x 0.1 kg
+H92568560D
728R121
AC Adapter
+H925728R1210-
Platform Size: 24” W x 24” D/61 cm x 61 cm
Shipping Weight: 85 lb/39 kg
758C
The 6855 features a balanced design that is easy to tip back
and transport on its hard, heavy-duty rubber wheels. It features a slightly smaller platform and capacity than the 6856.
MODEL
CAPACITY
HIBCC UPN
6855
600 lb x 0.2 lb /
270 kg x 0.1 kg
+H92568550C
3PHTROD-WM
Height Rod
+H9253PHTRODWM08
728R121
AC Adapter
+H925728R1210-
Platform Size: 18” W x 14” D/46 cm x 26 cm
Shipping Weight: 70 lb/32 kg
Please see pages 8 and 9 for additional weight
display features.
758C
(800) 641-2008
Please see pages 8 and 9 for additional weight
display features.
758C DIGITAL WEIGHT INDICATOR
8
CHANGING THE FACE OF
DIGITAL WEIGHING
Detecto’s enhanced model 758C
digital weight indicator offers the
best solution to your weighing
needs: a precision, full-featured
weight indicator and an accurate
Body M
Mass Index (BMI) calculator.
Pushbutton
ushbutton and keypad tare,
automatic
utomatic display lock,, and
selectable units make the 758C
the perfect choice for weight
loss clinics, long-term care
facilities or anywhere accurate
weight is required. As you will
see from browsing through
this catalog, the 758C now
comes standard on Detecto
digital health care scales.
ALL NEW LOOK....
ALL NEW CAPABILITIES...
BODY
MASS INDEX
The 758C quickly calculates BMI by
simply entering the patient’s height
while weighing.
BODY MASS INDEX
SIMPLE TO USE
Body Mass Index (BMI)
calculations have been
shown to be an accurate
estimate of health risk
when used as part of a comprehensive health assessment.
For weighing only use, the yellow “quick keys”
(pictured to the right) provide fast, easy operation,
even by first time users. The full complement of
displayed information makes it easy to read the
data at a glance and the display hold function can
be set for manual operation or automatic activation
on stable weight. With all of the incredibly diverse
functions the 758C is capable of performing, it can
also be used quite simply for basic weighing.
TWO TARE MODES
• Push-button tare subtracts the currently displayed gross
weight with a single keystroke.
• Keypad tare lets you enter a known weight (such as that
of a wheelchair) for net weight.
758C SPECIFICATIONS
PATIENT ID
Easily enter up to an 11-digit patient ID and print it along with the
weight, time and date from a label printer or send the data to a PC.
The 758C is
battery powered
for use with
portable scales, so
you can take the
scale to the patient.
Optional AC
adapter available.
Display:
0.5” / 12.7 mm high, liquid crystal - reflective
type
Enclosure:
Painted steel
Keypad:
19 key, color-coded, sealed membrane
BMI Range:
15.0 - 60.0
Height Range:
3 to 7 ft / 90 to 215 cm
Sensitivity:
1.2 µV/d
Resolution:
5,000 divisions, maximum
Power:
6 “C” size Alkaline or Nickel-Cadmium cells (not
included) or optional AC adapter.
Temp. Range:
+14 to +104 °F / -10 to +40 °C
www.DetectoScale.com
758C NEW ENHANCED FEATURES
SERIAL CONNECTIVITY PROVIDES:
OUTPUT TO PRINTER print weight, BMI, time
time, date, and height
SEND DATA TO PC
P excellent for efficient electronic medical record keeping
The enhanced 758C is a
full-featured,
precision,
digital weight indicator
that provides all you
need for clinical weighing
regardless of the application. From stand-on scales to
wheelchair scales, baby scales to in-bed scales, the 758C is
the new standard for health care scale weight indicators.
Serial connectivity provides output to a PC or printer
for efficient record keeping, useful for patient records in
physicians' offices, weight loss clinics, or athletics.
The new serial port allows output of the
758C's data directly to a printer by simply
pressing the PRINT/ENTER key. The paper
copy can be included in a patient’s files.
Model P220 Thermal
Printer (above)
The 758C is now standard on Detecto’s
complete line of digital health care scales.
Model P185 Ticket Printer
(right) For printing weight
data from the 758C indicator.
WIRED AND WIRELESS CONNECTIVITY SOLUTIONS
With the new 758C you can transmit ASCII weight data to a printer,
PC or Local Area Network via a serial cable connection, optional TCP/
IP module, or by optional wireless transmission, as illustrated here.
YOUR WEIGHT IN WINDOWS®
Easily put YOUR WEIGHT IN WINDOWS® with Detecto’s WinDDE 2.0 Server.
Communicate with up to 20 weight indicators connected to a computer via
standard serial port or optional Ethernet (using TCP/IP). WinDDE allows the
weight and status of the indicators to be transferred directly into databases
and spreadsheets, such as Microsoft Access® and Excel®.
MODEL
DESCRIPTION
HIBCC UPN
WinDDE
Weight capture to PC software
+H925WINDDE0F
WinDDE
Whether you require a paper copy of weight data for a patient’s file
or data to be transmitted directly into a PC-based Electronic Medical
Recording (EMR) software program, Detecto can assist you and
consult with your PC solutions personnel.
(800) 641-2008
9
HEALTH AND FITNESS SCALES
10
Waist-High Digital Physician Scales
Contemporary styling and light yet rugged construction make Detecto
health and fitness scales perfect for health clubs, schools, sports teams or
homes. The 8437 and 8430 feature waist-high “at-a-glance” readouts from
their 0.5”/12.7 mm high-contrast LCD display. The platform cover is easily removed for cleaning. The heavy-duty understructure of this digital waist-high
scale incorporates a fabricated lever system that is enhanced by precisionground, pressed-in knife edges which eliminate friction.
MODEL
CAPACITY
DESCRIPTION
HIBCC UPN
8437
400 lb x 0.2 lb /
180 kg x 0.1 kg
No Height Rod
+H92584370A
8430
Same
With Height Rod
+H925843003
AC Adapter
+H925728R1210-
728R121
Model 8437
Platform Size: 10.5” W x 14.5” D/27 cm W x 37 cm D
Scale Height: 37.5”/95 cm
Model 8430 Height Rod: 30” - 78” and 76 cm - 198 cm
Shipping Weight: 8437 - 31 lb/14 kg 8430 - 34 lb/15.4 kg
Metric only models available upon request, please consult factory.
758C
Please see pages 8 and 9 for additional weight display features.
Model 8430
Personal Floor Scales
The D315’s is a result of a design using an innovative precision mechanism
which has fewer moving parts and points of contact. This scale is consistently
accurate and resistant to wear and tear. Heavy duty construction and a white
back enamel finish support the scale’s many features: Pro Helix™ accuracy
and a large 7.75”/20 cm diameter dial with a 330 lb capacity and metric
equivalent. Five different colorful indicators allow users to mark their weight
progress. The slip-proof black vinyl mat ensures comfort and user safety getting on and off the scale.
SHIPPING
WEIGHT
HIBCC UPN
330 lb x 1 lb /
150 kg x 500 g
10 lb / 5 kg
+H925D3150A
150 kg x 500 g
Same
+H925D315KG03
MODEL
CAPACITY
D315
D315K
Dimensions: 13” W x 18.5” L x 4.75” H/33 cm W x 47 cm L x 12 cm H
Personal Floor Scales
A low profile design, heavy duty construction and a non-skid vinyl mat are
just a few features of the D1130 and D1130K scales - proven performers for
budget-minded customers. They feature a white, baked-enamel finish and
personal colorful indicators to mark one person’s or a whole family’s weights.
The large diameter dial allows for easy readability even for tall people. Designed for personal use, fitness centers, and health care facilities.
Model D1130
MODEL
CAPACITY
SHIPPING
WEIGHT
HIBCC UPN
D1130
300 lb x 1 lb
7 lb / 3 kg
+H925D113006
D1130K
140 kg x 500 g
Same
+H925D1130KG0%
Dimensions: 11.5” W x 17.25” L x 3” H/29 cm W x 44 cm L x 8 cm H
www.DetectoScale.com
Model D1130K
HEALTH AND FITNESS SCALES
11
Digital Fitness Scales
758C Digital Weight Indicator:
• 0.5”/12.7 mm High-contrast LCD
• Body Mass Index Calculation
• Pushbutton Tare and Keypad Tare
MODEL
CAPACITY
DESCRIPTION
HIBCC UPN
6027
400 lb x 0.5 lb /
180 kg x 0.2 kg
No Height Rod
+H925602703
602703
6029
Same
With Height Rod
+H925602905
602905
6027KG
180 kg x 0.2 kg
No Height Rod
+H9256027KG0$
6027KG0$
6029KG
Same
With Height Rod
+H9256029K0+
6029K0+
AC Adapter
+H925728R1210728R1210-
728R121
728R1
Model 6027
Platform Size: 11” W x 13” D/28 cm W x 33 cm D
Scale Height: 38”/97 cm
Model 6029 and 6029KG Height Rod: 30” - 78” and 76 cm - 198 cm
Shipping Weight: 6027(KG) - 25 lb/11 kg 6029(KG) - 28 lb/13 kg
758C
Please see pages 8 and 9 for additional weight display features.
Model 6029
Mechanical Fitness Scales
080 Dial:
• Large 7.5”/19 cm Diameter Reading Line
• Single Revolution
• Zero Adjust Knob on Back of Dial
Model
080
MODEL
CAPACITY
SHIPPING
WEIGHT
HIBCC UPN
080
300 lb x 1 lb
28 lb / 13 kg
+H9250800$
0800$
080KG
150 kg x 0.5 kg
28 lb / 13 kg
+H925080KGOW
080KGOW
Platform Size: 11” W x 13” D/28 cm W x 33 cm D
Scale Height: 36”/91 cm
Mechanical Fitness Scales
Easy-To-Operate, Smooth-Gliding Beam
Model
057
MODEL
CAPACITY
DESCRIPTION
HIBCC UPN
057
340 lb x 0.5 lb
No Height Rod
+H92505700
0571
150 kg x 200 g
No Height Rod
+H925057101
059
340 lb x 0.5 lb
With Height Rod
+H92505902
0591
150 kg x 200 g
With Height Rod
+H925059103
Platform Size: 11” W x 13” D/28 cm W x 33 cm D
Scale Height: 38”/97 cm
Model 059 and 0591 Height Rod: 30” - 78” and 76 cm - 198 cm
Shipping Weight: 057 and 0571 - 28 lb/13 kg 059 and 0591 - 32 lb/15 kg
(800) 641-2008
Model
059
12
WHEELCHAIR SCALES
Mechanical Stationary Wheelchair Scales
This heavy-duty stationary wheelchair scale features a detachable ramp
designed for a smooth approach and exit. The platform is designed to accomodate all sizes of wheelchairs. The 495 features a padded handrail for
ambulatory patients and a non-skid mat. It features Detecto’s famous diecast, dual-sided, eye-level weighbeam graduated in 4 ounce or 100 gram increments. The weigh beam is located at a height above the platform where
the patient or attendant can perform the weighing operation. Customers
specializing in the care of non-ambulatory patients provided information
which was transferred into features and benefits of these scales, evident the
first time you use the scale!
MODEL
CAPACITY
SHIPPING
WEIGHT
HIBCC UPN
495
400 lb x 4 oz /
194 lb / 88 kg
+H92549506
4951
180 kg x 100 g
Same
+H925495107
Platform Size: 30” W x 26” D/76 cm W x 66 cm D
Digital Stationary Wheelchair Scale
With the model 6495 heavy-duty digital wheelchair scale, you get speed
and increased accuracy that only electronic weighing can provide. Weigh in
pounds or kilograms at the press of a button. The weight display is mounted
on a tilt mount which permits the indicator to be angled for easy viewing. A
keypad for entry of known weights of empty wheelchairs is also provided,
thus giving the exact weight of the patient accurately and instantly in large
0.5”/13 mm digits. The platform is designed to accomodate all sizes of wheelchairs and the 6495 also features a detachable ramp.
SHIPPING
WEIGHT
HIBCC UPN
400 lb x 0.2 lb /
180 kg x 0.1 kg
177 lb / 80 kg
+H92564950C
AC adapter
1 lb / 453 g
+H925728R1210-
MODEL
CAPACITY
6495
728R121
Platform Size: 30” W x 26” D/76 cm W x 66 cm D
758C
Please see pages 8 and 9 for additional weight display features.
Mechanical Stationary Wheelchair Scales
Built for use with any standard-size wheelchair, these scales offer the utmost
in comfort for wheelchair-bound patients, convenience for nursing personnel
and accuracy for important medical records. Detecto’s sturdy design incorporates a standard eye-level physician scale with a detachable ramp, allowing
for easy movement on and off the platform. The scale’s beam is easily read
from both sides, facilitating a faster weighing operation. The ramp kit (model
3PRAMP) is detachable, allowing for the scale’s use as a stand-alone physician
scale, or a kit may be attached to existing Detecto physician scales.
MODEL
CAPACITY
SHIPPING
WEIGHT
HIBCC UPN
485
350 lb x 4 oz
66 lb / 30 kg
+H92548505
4851
160 kg x 100 kg
Same
+H925485106
3PRAMP
Wheelchair ramp
31 lb / 14 kg
+H9253PRAMP0E
Platform Size: 27” W x 30” D/69 cm W x 76 cm D
www.DetectoScale.com
WHEELCHAIR SCALES
Folds up and latches for easy
transport in four directions.
13
Folding Portable Wheelchair Scale
This sturdy, but lightweight, scale can be used with wheelchairs, straightlegged chairs or as a stand-on scale, and its sloped ramps offer versatility by
allowing loading from either side. The 6550’s vertical fold-up feature, battery
power, and heavy-duty wheels contribute to its ease of mobility and lack of
needed storage space. With the 6550, tare weight may be either preset or
keyed in directly and the patient’s weight is automatically displayed.
MODEL
CAPACITY
SHIP
WEIGHT
6550
800 lb x 0.2 lb /
360 kg x 0.1 kg
94 lb /
43 kg
HIBCC UPN
+H925655004
6550WHLSTP
Wheelstop for dialysis chair
+H9256550WHLSTP0R
728R121
AC adapter
+H925728R1210-
1 lb / 453 g
Platform Size: 30” W x 32” D/76 cm W x 81 cm D (flat portion)
758C
Please see pages 8 and 9 for additional weight display features.
“Roll-A-Weigh” Wheelchair Scale
Featuring built-in handles, wheelstop, and wheels, the “Roll-A-Weigh” can be
moved wherever you need it. Whether’s it’s multiple weighing locations at a
single facility or a stationary location, the “Roll-A-Weigh” gives you portability
and ease of use. The “Roll-A-Weigh” features a weight display which can be
mounted on the scale, or remotely on a wall or desk for convenient viewing.
Overall dimensions: 32.5” W x 42.5” D x 3.5” H/83 cm W x 108 cm D x 9 cm H.
The perfect scale for
weighing patients
in manual or power
wheelchairs, dialysis
patients, or walk-ons. The
lightweight Roll-A-Weigh
features built-in wheels
for easy portability.
MODEL
CAPACITY
SHIPPING
WEIGHT
CR-500D
500 lb x 0.2 lb /
225 kg x 0.1 kg
113 lb /
51 kg
+H925CR500D02
CR-1000D
1,000 lb x 0.5 lb /
450 kg x 0.2 kg
Same
+H925CR1000D0+
728R121
AC adapter
1 lb / 453 g
+H925728R1210-
HIBCC UPN
Platform Size: 30” W x 32.5” D/76 cm W x 83 cm D
758C
Please see pages 8 and 9 for additional weight display features.
Geriatric/Bariatric Wheelchair Scale
The battery-operated models FHD133II and FHD144II wheelchair scales have
a black, nonskid rubber platform and ramp. The large platform accomodates
walk-on patients, wheelchairs, or straight-legged chairs. This large capacity
scale can be mounted flush with the floor if desired (please consult factory
for all pit installations). The remote weight display is suitable for desk or wall
mount and comes with 15’/4.5 m of cable. A 28.5”/72 cm ramp is included.
MODEL
CAPACITY
SHIPPING
WEIGHT
FHD-133-II
1,000 lb x 0.2 lb /
450 kg x 0.1 kg
315 lb /
143 kg
+H925FHD133110X
FHD-144-II
Same
460 lb / 209 kg
+H925FHD1441102
728R121
AC adapter
1 lb / 453 g
Platform Size: 133-II - 36”/91 cm square
758C
HIBCC UPN
+H925728R1210-
144-II - 48”/122 cm square
Please see pages 8 and 9 for additional weight display features.
(800) 641-2008
CHAIR SCALES
14
Mechanical
Chair Scale
Digital
Chair Scale
Detecto simplifies the
task of weight checks for
frail, handicapped, and
elderly patients with a
selection of innovatively-designed chair scales,
such as the 6475.
Developed to ensure patient safety and comfort as well as
to reduce weighing time, Detecto mechanical chair scales
are conveniently portable and offer easy side or front access
for your frail, handicapped, or elderly patients. The arms raise
easily on both models, so the patient can be conveniently assisted into and out of the chair scale. Die-cast, easy-to-read
beams are readable from the front and back.
These digital chair scales feature waist-high LCD displays allowing weighing with accuracy to 0.2 lb or 0.1 kilogram. Battery power and oversized wheels enhance their portability.
MODEL
CAPACITY
HIBCC UPN
6475
400 lb x 0.2 lb /
180 kg x 0.1 kg
+H92564750A
MODEL
CAPACITY
HIBCC UPN
6475K
180 kg x 0.1 kg
+H9256475K0U
475
400 lb x 4 oz
+H92547504
728R121
AC Adapter
+H925728R1210-
4751
400 lb x 4 oz /
180 kg x 100 g
+H925475105
Seat Size: 17.5” H x 17.5” W/44 cm H x 44 cm W
Shipping Weight: 78 lb/35 kg
Seat Size: 17.5” H x 17.5” W/44 cm H x 44 cm W
Shipping Weight: 78 lb/35 kg
758C
Premier Digital
Chair Scale
Rolling
Chair Scale
Please see pages 8 and 9 for additional weight
display features.
Concealed wheels and
flip-up footrest and arms.
The display con be
rotated to virtually any
angle for easy viewing by
the attendant.
Zero turning
radius wheels.
Ergonomics dictated this stylish, battery-powered chair
scale’s contemporary design. The footrests fold away to promote patient security when getting into or out of the scale.
MODEL
CAPACITY
HIBCC UPN
6875
400 lb x 0.2 lb /
180 kg x 0.1 kg
+H92564850B
AC Adapter
+H925728R1210-
728R121
Dimensions: 41.75” H x 29.375” W x 24” L/
106 cm H x 75 cm W x 61 cm L
Shipping Weight: 70 lb/32 kg
758C
Please see pages 8 and 9 for additional weight
display features.
This lightweight rolling chair scale features a flip-up footrest
and lift-away armrests. Safety stops on the rear wheels allow
for parking in one place without rolling. The 6880 features
one load cell and 3” diameter oversized wheels.
MODEL
CAPACITY
HIBCC UPN
6880
440 lb x 0.2 lb /
200 kg x 0.1 kg
+H92568800A
728R121
AC Adapter
+H925728R1210-
Seat Size: 17.5” H x 17.5” W/44 cm H x 44 cm W
Shipping Weight: 61 lb/28 kg
758C
Please see pages 8 and 9 for additional weight
display features.
www.DetectoScale.com
15
DETECTO IS
THE LEADER
IN
MEDICAL
WEIGHING
SINCE 1900
THE NAME BRAND YOU CAN TRUST
PATIENT LIFT SCALES
16
Model PL435
Model PL475
Patient Lifts
Detecto Patient Lifts make lifting and weighing patients of all sizes a simple chore. The Patient Lift features a 400 lb capacity and 4.8”
(1.5m) under bed clearance. The four ball bearing, double castor wheels with parking brakes along with adjustable, tip-free base legs
allow easy access to wheelchairs, beds, tubs, and toilets. This unit is not designed for patient transport.
MODEL
DESCRIPTION
SHIP WEIGHT
HIBCC UPN
PL425
Patient lift only, 400 lb capacity, 4.8” (1.5m) high under bed clearance,
and hydraulic lift mechanism
240 lb / 109 kg
+H925PL42502
PL435
PL425 patient lift, sling seat, yoke and suspension
249 lb / 113 kg
+H925PL43503
PL475
Complete 400 lb unit includes PL400 scale, PL425 patient lift, sling
seat, yoke, and suspension. 400 lb x 0.2 lb / 180 kg x 0.1 kg capacity
252 lb / 114 kg
+H925PL47507
Digital Patient Lift Scales
This scale determines the weight of a person suspended from a portable
patient lift and runs on one nine-volt battery. It incorporates a lock weight
feature which stores the last weight reading when the unit is turned off and
can be used where standard indicators are too large and cumbersome.
Detecto also provides kit
adapters for other
manufacturers’ patient lifts.
The 11S400H
general utility
scale can work for
multiple purposes
and bulk weighings. It will weigh
large or small
quantities with
speed and
accuracy.
SHIPPING
WEIGHT
HIBCC UPN
400 lb x 0.2 lb /
180 kg x 0.1 kg
4 lb / 2 kg
+H925PL40000
600 lb x 0.2 lb /
270 kg x 0.1 kg
Same
+H925PL60000/
MODEL
CAPACITY
PL400
PL600
Display: 0.75”/19 mm high-contrast LCD with annunciator for lb/kg, zero,
low battery and display lock.
Size: 4.125” W x 2.125” D x 4” H/105 mm W x 54 mm D x 102 mm H
(center of eye to center of eye; 5”/127 mm overall)
Mechanical Patient Lift Scale
Designed to be installed between the boom and sling of a patient lift, this
ruggedly-built general utility scale features an extra large, 7”/18 cm diameter,
single revolution, aluminum dial with black lettering and durable heavy cast
iron protective housing to protect precision parts from dust.
MODEL
CAPACITY
SHIPPING
WEIGHT
HIBCC UPN
11S400H
400 lb x 1 lb
12 lb / 5 kg
+H92511S400H0$
Height: 24.75”/63 cm
www.DetectoScale.com
WEIGHMOBILE IN-BED SCALES
Digital In-Bed Scale
Designed for fast, accurate weighing, the IB400 scale features a flame-retardant, antibacterial, self-deodorizing
stretcher which is placed under the patient and hydraulically lifted inches from the bed. The tare function lets
you easily subtract the weight of bedding. One nurse can
quickly gather data from an entire floor, without wasted
motion or patient discomfort! Safety features include
locking casters and a lockable base widening stance for
stability. Battery operation increases the portability of
these in-bed scales.
Under Bed Clearance: 4.8”/12 cm high
Dimensions: 53” H x 50” L x 25.25” W/1.3 m H x 1.2 m L
x 64 cm W
Stretcher: 6’/1.8m long, Thermoplastic Sure-Chek®
fabric
Adjustable Weighing Arm: 25.75” to 72.25” / 64 cm to
1.9 m high
758C
Please see pages 8 and 9 for additional weight
display features.
MODEL
CAPACITY / DESCRIPTION
SHIPPING WEIGHT
HIBCC UPN
IB400
400 lb x 0.1 lb / 180 kg x 0.1 kg
290 lb / 132 kg
+H925IB400L
0046-C065-08
4’ / 1.2 m pediatric stretcher - Sure-Chek® 20 fabric
4 lb / 1.8 kg
+H9250046C065080T
0046-C007-08
6’ / 1.8 m adult stretcher - Sure-Chek® 20 fabric
4 lb / 1.8 kg
+H9250046C007080P
728R121
AC Adapter
1 lb / 453 g
+H925728R1210-
Heavy-Capacity In-Bed Scale
The IB600 in-bed scale lets you easily weigh patients
who are confined to their bed and is ideal for intensive
care, surgical recovery and geriatric units. Heavy-duty, yet
transportable, these self-contained scales easily maneuver under beds and have a stretcher holder, hydraulic lift
and six foot stretcher made of flame retardant, antibacterial, self-deodorizing Thermoplastic Sure-Chek® fabric.
The sturdy hoop assembly support patients securely and
weight can be taken even if the patient is not perfectly
centered on the stretcher.
Under Bed Clearance: 4.8”/12 cm high
Dimensions: 60” H x 65.9” L x 31.5” W/152 cm H x 167
cm L x 80 cm W
Stretcher: 6’/1.8m long, Thermoplastic Sure-Chek®
fabric
Adjustable Weighing Arm: 25.75” to 72.25” / 64 cm to
1.9 m high
758C
Please see pages 8 and 9 for additional weight
display features.
MODEL
CAPACITY / DESCRIPTION
SHIPPING WEIGHT
HIBCC UPN
IB600
600 lb x 0.2 lb / 272 kg x 0.1 kg
390 lb / 177 kg
+H925IB6000N
4 lb / 1.8 kg
+H9250046C247080V
1 lb / 453 g
+H925728R1210-
0046-C247-08
6’ / 1.8 m adult stretcher -
728R121
AC Adapter
Sure-Chek®
44XL fabric
(800) 641-2008
17
18
DIGITAL BABY SCALES
Digital Baby Scale
Optional label
printer (Model P220 pictured
left) provides documentation
of baby’s weight for transfer
to medical record. The 6745
features serial output for use
with a PC or printer.
Years of experience have gone into creating the latest in accurate, dependable infant scales... Detecto’s 6745. Designed to be used with
the utmost ease, this scale can weigh even the most active baby.
With step-by-step instructions right on the keypad, there’s never
any question about what to do next. The 6745 has a lock-in weight feature which compensates for typical newborn movement. When weight stabilizes, it is “locked in” and displayed. The infant can be removed and its weight
is retained. Features battery or AC operation and built-in measuring tape.
MODEL
CAPACITY
SHIPPING
WEIGHT
6745
30 lb x 0.1 oz /
15 kg x 0.005 kg
25 lb /
11 kg
+H92567450A
6800-1006
AC Adapter
1 lb / 453 g
+H9256800100609
HIBCC UPN
Tray Size: 28” L x 14” W/71 cm L x 36 cm W
Power Source: 6 “C” cell batteries or universal AC adapter
Display: 6-digit, 7-segment 1.0”/25 mm high transflective LCD
Digital Tot Weigher
Infants readily accept the inclined seating of Detecto’s digital tot weigher
scale. With a soft foam, padded seat that is removable for easy cleaning,
pound and kilogram readings, and heavy-duty base and understructure, the
battery-powered scale has a lot to offer. The LCD display features auto zero,
lock-release and auto shutoff. The digital head can rotate 90 degrees to either side. A heavy steel base and precision lever system add to durability.
SHIPPING
WEIGHT
HIBCC UPN
44 lb x 0.05 lb /
20 kg x 0.02 kg
33 lb / 15 kg
+H9258432CH0Y
AC Adapter
1 lb / 453 g
+H925728R1210-
MODEL
CAPACITY
8432-CH
728R121
Dimensions: 20.25” H x 25” W x 22” D/51 cm H x 64 cm W x 56 cm D
758C
Please see pages 8 and 9 for additional weight display features.
www.DetectoScale.com
DIGITAL BABY SCALES
19
Digital Baby Scale
All Detecto Baby Scales
are engineered with the
active baby in mind and
built with the uncompromising quality you
expect from Detecto.
An easy-to-clean polystyrene tray cradles babies securely and comfortably
on these dependable, portable scales. The 8435 features pounds or kilograms
shown at the push of a button and a high-contrast LCD display with auto
zero, auto shutoff, and pushbutton tare. A light, attractive scale, the portability is increased by the use of battery power with 6 “C” size alkaline batteries.
SHIPPING
WEIGHT
HIBCC UPN
130 lb x 0.1 lb /
59 kg x 0.05 kg
33 lb / 15 kg
+H925843508
AC Adapter
1 lb / 453 g
+H925728R1210-
MODEL
CAPACITY
8435
728R121
Tray Size: 22” L x 14.75” W x 4.5” D/56 cm L x 37 cm W x 11 cm D
758C
Please see pages 8 and 9 for additional weight display features.
Digital Baby and Toddler Scale
Detecto’s 8440 digital baby and toddler scale provides accurate, safe weighing of infants and features selectable weight units, lb-oz or kilograms, display
hold, time and date clock function, and a memory function. Compact, battery-powered and portable, the 8440 is perfect for visiting nurses, home or
wherever space is limited. Remove the tray for double use as a toddler scale.
Optional black carrying case
MODEL
CAPACITY
SHIPPING
WEIGHT
8440
44 lb x 0.5 oz /
20 kg x 10 g
8 lb /
3.6 kg
+H925844004
8440-CASE
Carrying Case
1 lb / 453 g
+H9258440CASE0P
6800-1037
AC Adapter
1 lb / 453 g
+H925680010370D
HIBCC UPN
Tray Size: 20.5” L x 10.75” W/52 cm L x 27 cm W
Platform Size: 9.5” L x 6.5” W/24 cm L x 17 cm W
Power Source: 6V DC (4 AA batteries or optional AC adapter)
Display: 4 3/4 digits LCD 1.0”/25 mm high
Digital Low-Profile Scale
The platform, base and padded carrying handles of this lightweight scale are
incorporated into one complete unit making it easy to transport from place
to place. Padded side rails and handle covers are slightly contoured ensuring that the baby will be cradled securely while being weighed. Measure the
infant’s length in inches or centimeters with the built-in measuring tape.
Optional black carrying case built to scale size and
with a handle protects the scale for easy transport.
SHIPPING
WEIGHT
MODEL
CAPACITY
8450
44 lb x 0.02 lb /
20 kg x 0.01 kg /
704 oz x 0.5 oz
8 lb /
3.6 kg
+H925845005
8450-CASE
Carrying Case
1 lb / 453 g
+H9258450CASEOQ
6800-1039
AC Adapter
1 lb / 453 g
+H925680010390F
HIBCC UPN
Dimensions With Handle: 24.5” L x 13.7” W x 2” H/62 cm L
x 35 cm W x 5 cm H
Power Source: 9V 100mA DC adapter / 9V battery
Display: 1.0”/25 mm high LCD with 4 1/2 active digits
(800) 641-2008
MECHANICAL BABY SCALES
20
Mechanical
Infant Scales
Mechanical Infant Scales
This sturdy, compact scale incorporates springless balance
beam construction. The white metal tray holds infants comfortably, while the beam is easy to read with blue graduations
and numerals on white background. Comes in your choice of
pounds or kilograms.
This low-profile beam style scale features sturdy, compact
construction with an easy-to-read balance beam and a white
epoxy metal tray. Comes in your choice of pounds or kilograms. Perfect for hospitals, pediatrician’s offices, clinics, or
the home nursery.
MODEL
CAPACITY
HIBCC UPN
MODEL
CAPACITY
HIBCC UPN
243
20 lb x 2 oz
+H9252430/
253
41 lb x 0.25 oz
+H9252530+
2431
10 kg x 50 g
+H92524310+
2531
20.5 kg x 10 g
+H92525310%
2441
16 kg x 100 g
+H92524410%
Overall Size: 10.5” H x 21” W x 19” D/27 cm H x 53 cm W x
48 cm D
Tray Size: 2.5” H x 11” W x 19” D/6 cm H x 28 cm W x 48 cm D
Shipping Weight: 21 lb/10 kg
Overall Size: 6.75” H x 24” W x 13.75” D/17 cm H x 61 cm W
x 35 cm D
Tray Size: 2.75” H x 24” W x 11.5” D/7 cm H x 61 cm W x 29
cm D
Shipping Weight: 30 lb/14 kg
Suspended Baby
Scale
Mechanical Tot
Weigher
Waterproof weighing
trousers are attached
to a heavy-duty zincplated 4”/10 cm S-hook
providing a comfortable
suspended sling seat for
weighing babies.
Features an easyto-read, die cast
beam, heavy-duty
welded steel
construction, and
polystyrene tray.
(Model MCS25KGNT
shown to the right)
Perfect for doctors and nurses
working in remote locations,
this baby scale is lightweight
and portable. It’s designed to
withstand rugged conditions
and remain accurate through
years of continuous service. The 8”/20 cm diameter shatterproof dial features a white face with black graduations and
numerals for high contrast readouts.
MODEL
CAPACITY
HIBCC UPN
MCS25KGNT
25 kg x 100 g
+H925MCS25KGNT0G
MCS25KGN
No sling seat
+H925MCS25KGN0U
Shipping Weight: 5 lb/2 kg
Infants readily accept the inclined seating of Detecto’s mechanical tot weigher scales. With a soft foam, padded seat
that is removable for easy cleaning, pound and kilogram
readings, and heavy-duty base and understructure, the mechanical beam scale has a lot to offer. The die-cast beam can
also be read from either side for added convenience.
MODEL
CAPACITY
HIBCC UPN
459-CH
40 lb x 0.5 oz /
17.5 kg x 0.01 kg
+H925459CH0Z
Overall Size: 27” H x 22” W x 21” D/69 cm H x 56 cm W x 53
cm D
Shipping Weight: 38 lb/17 kg
www.DetectoScale.com
MECHANICAL BABY SCALES
Detecto baby scales
are designed to
weigh quickly and
accurately
while
cradling
babies in
comfort and
safety.
Mechanical Pediatric Scales
Easy-to-clean, washable polystyrene trays cradle
babies securely on these dependable, portable
scales. With three models, the 450, 451, and 459
give you a choice of pounds or kilograms or
both. Light and attractive scales, these models
features a heavy-duty, rust-resistant understructure and dual-reading, die-cast beams.
MODEL
CAPACITY
HIBCC UPN
450
130 lb x 1 oz
+H9254500/
451
65 kg x 20 g
+H9254510+
459
40 lb x 0.5 oz /
17.5 kg x 10 g
+H92545906
These scales are engineered with the active baby
in mind and are built with the uncompromising
quality you expect from Detecto.
Overall Size: 27” H x 22’’ W x 21” D/69 cm H x
56 cm W x 53 cm D
Tray Size: 4.5” H x 22” W x 14.75” D/11 cm H x
56 cm W x 37 cm D
Shipping Weight: 33 lb/15 kg
(800) 641-2008
21
22
MECHANICAL DIETARY SCALES
Petite Top-Loading
Portion Scales
Model PT-5
Model PT-1
Model PT-25
Whatever your need in a top-loading dial scale, Detecto has a model to handle the job. The PT
Series comes in a variety of capacities listed below. Sturdy construction, stability, convenient
viewing angle, temperature compensation for dependable accuracy in environments with
fluctuating temperatures and easy readability make these the petite top loaders of choice.
Model PT-25SR
Improve your efficiency
with a reliable, costeffective Top Loading
Dial Scale from Detecto
- the perfect solution
to limited space on a
limited budget.
Model PT-2R
MODEL
CAPACITY
DIAL
FINISH
HIBCC UPN
PT-1
16 oz x 0.25 oz
Fixed
Enamel
+H925PT100
PT-2
32 oz x 0.25 oz
Fixed
Enamel
+H925PT201
PT-5
5 lb x 0.5 oz
Fixed
Enamel
+H925PT504
PT-25
25 lb x 0.125 lb
Fixed
Enamel
+H925PT2506
PT-2R
32 oz x 0.25 oz
Rotating
Enamel
+H925PTR0S
PT-2-SR
32 oz x 0.25 oz
Rotating
Stainless steel
+H925PT2SR0D
PT-5R
5 lb x 0.5 oz
Rotating
Enamel
+H925PT5R0V
PT-5SR
5 lb x 0.5 oz
Rotating
Stainless steel
+H925PT5SR0G
PT-10SR
10 lb x 0.25 oz
Rotating
Stainless steel
+H925PT10SR0C
PT-25R
25 lb x 0.125 lb
Rotating
Enamel
+H925PT25R0X
PT-25SR
25 lb x 0.125 lb
Rotating
Stainless steel
+H925PT25SR0I
PT-500RK
500 g x 2 g
Rotating
Enamel
+H925PT500RK08
PT-500SRK
500 g x 2 g
Rotating
Stainless steel
+H925PT500SRK0-
PT-1000RK
1000 g x 5 g
Rotating
Enamel
+H925PT1000RK04
PT-1000SRK
1000 g x 5 g
Rotating
Stainless steel
+H925PT1000SRK0W
Overall Size: 7.5” H x 5.25” W x 7.25” D/19 cm H x 13 cm W x 18 cm D
Dial Size: 6” /15 cm diameter
Platform: 7.875”W x 5.875” D/20 cm W x 15 cm D stainless steel
Shipping Weight: 5 lb/2 kg
Dual-Reading Lbs/Kgs Top Loading Portion Scales
This dual-reading top loader series comes in a variety of capacities listed below which show
simulataneous readings of pounds and kilograms. An easy-to-clean enamel finish, sturdy construction, stability, convenient viewing angle, and easy readability make these attractive top
loaders an ideal choice for your weighing needs.
Model T1KP
MODEL
CAPACITY
DIAL
FINISH
HIBCC UPN
T1KP
2.2 lb x 0.25 oz / 1 kg x 5 g
Fixed
Enamel
+H925T1KP0K
T2KP
4.3 lb x 0.5 oz / 2 kg x 10 g
Fixed
Enamel
+H925T2KP0L
Add letter “D” to model for optional air dashpot
Overall Size: 10.5” H x 8.5” W x 10.25” D/27 cm H x 22 cm W x 26 cm D
Dial: 8” /20 cm diameter fixed
Platform: 9”/23 cm square stainless steel
Shipping Weight: 10 lb/4.5 kg
www.DetectoScale.com
Additional
Capacities
Available
DIGITAL DIETARY SCALES
AC or battery
power
23
Electronic Digital Portion Scales
MODEL
CAPACITY
PS-5A
70 oz x 0.1 oz /
1,998 g x 2 g
SHIPPING
WEIGHT
HIBCC UPN
4 lb / 1.8 kg
+H925PS5A0D
Display: 0.5”/13 mm high LCD
Overall Size: 2.75” H x 7” W x 7” D/7 cm H x 18 cm W x 18 cm D
Platform Size: 6.75” W x 5.25” D/17 cm W x 13 cm D
AC or battery
power
MODEL
CAPACITY
SHIPPING
WEIGHT
HIBCC UPN
PS-6A
70 oz x 0.25 oz
4 lb / 1.8 kg
+H925PS6A0E
Display: 0.5”/13 mm high LCD
Overall Size: 2.75” H x 7” W x 7” D/7 cm H x 18 cm W x 18 cm D
Platform Size: 6.75” W x 5.25” D/17 cm W x 13 cm D
AC or battery
power
MODEL
CAPACITY
PS-7
7 lb x 0.1 oz /
112 oz x 0.1 oz /
112 oz x 1/8 oz /
3000 g x 1 g /
7 lb x 0.005 lb
SHIPPING
WEIGHT
HIBCC UPN
4 lb / 1.8 kg
+H925PS705
Features the ability to disable
different units of measure.
Display: 5-digit, 0.8” x 0.3” characters with fractions LCD
Overall Size: 2.44” H x 8.03” W x 7.87” D / 6 cm H x 20 cm W x 20 cm D
Platform Size: 8.02” W x 4.96” D / 20 cm W x 13 cm D
AC power or built-in
rechargeable
battery
MODEL
CAPACITY
PS-11
11 lb x 0.1 oz /
176 oz x 0.1 oz /
176 oz x 1/4 oz /
5000 g x 2 g /
11 lb x 0.005 lb
SHIPPING
WEIGHT
HIBCC UPN
6 lb / 2.7 kg
+H925PS1100
Features the ability to disable
different units of measure.
Display: 5-digit, 0.8” x 0.3” characters with fractions LCD
Overall Size: 2.3” H x 7.25” W x 9.5” D / 6 cm H x 18 cm W x 24 cm D
Platform Size: 6.89” W x 6.5” D / 18 cm W x 17 cm D
Cert. No.
95-087A1
AC power
Optional Commodity
Scoop - Model 285R31
MODEL
CAPACITY
SHIPPING
WEIGHT
AP-6
99.95 oz x 0.05 oz
5 lb / 2.3 kg
+H925AP60T
HIBCC UPN
AP-8
7.998 lb x 0.002 lb
5 lb / 2.3 kg
+H925AP80V
AP-10
9.995 lb x 0.005 lb
5 lb / 2.3 kg
+H925AP1000
AP-20
19.99 lb x 0.01 lb
5 lb / 2.3 kg
+H925AP200P
AP-4K
3999 g x 1 g
5 lb / 2.3 kg
+H925AP4K04
Display: 0.5”/13 mm high LED
Overall Size: 2.75” H x 7.5” W x 7” D/7 cm H x 19 cm W x 18 cm D
Platform Size: 6.75” W x 5.25” D/17 cm W x 13 cm D
(800) 641-2008
24
GENERAL PURPOSE AND LAP SPONGE SCALES
Digital General Purpose Scales
Uses for these lightweight, portable scales are almost limitless. With detachable indicators and built-in carrying handles, they go with you anywhere. Their
large, easy-to-clean platforms (2” H x 18” W x 14” D/6 cm H x 46 cm W x 36
cm D) feature slip-proof mats and non-skid plastic feet for stability. The digital
displays can be mounted on a table top or wall. Power is provided by 6 “C” size
batteries which increase the portability of these compact scales, and if you
need “legal for trade” certification choose the GP-400-204.
MODEL
CAPACITY
SHIPPING
WEIGHT
GP-400-758C
400 lb x 0.2 lb /
200 kg x 0.1 kg
31 lb /
14 kg
+H925GP400758C0M
728R121
AC Adapter
1 lb / 453 g
+H925728R1210-
The perfect scale for those who
need a lightweight, portable
floor scale.
HIBCC UPN
Display: 0.5”/12.7 mm high LCD
758C
Please see pages 8 and 9 for additional weight display features.
MODEL
CAPACITY
SHIPPING
WEIGHT
GP-400-204
400 lb x 0.2 lb /
200 kg x 0.1 kg
28 lb /
13 kg
HIBCC UPN
+H925GP4002040$
Display: 1”/25 mm high LCD - Features include automatic zero, keypad tare,
motion detection, serial printer port, auto power off and selectable units.
Featuring removable stainless steel
trays for easy cleaning and the
compact size fits in any space.
Cert. No.
204 Display: 02-016A1
GP-400 Base: 94-098
Digital Wet Diaper / Lap Sponge Scales
Detecto packs a lot of functionality into these compact wet diaper/lap sponge
scales, designed to answer your every need in measuring fluid output. Stainless steel construction makes the removable tray a snap to clean - a major consideration in the nursery where repeated use is the rule. Time is also precious
around newborns, and this scale helps you make the most of it with an instantaneous display of 0.5”/13mm high readouts. Handy pushbutton tare simplifies weight determinations for adult incontinence and infant diapers. An AC
adapter comes with both scales.
MODEL
CAPACITY
AP-4KD
4,000 g x 1 g
SHIPPING
WEIGHT
5 lb /
2.3 kg
HIBCC UPN
+H925AP4KD0H
Display: 4 digit, 0.5”/13 mm high red LED
Overall Size: 2.75” H x 7.5” W x 7” D/7 cm H x 19 cm W x 18 cm D
Tray Size: 2” H x 9” W x 6” D/5 cm H x 23 cm W x 15 cm D
Construction: Stainless steel scale with stainless steel tray
MODEL
CAPACITY
SHIPPING
WEIGHT
PS5A-2KD
70 oz x 0.1 oz /
1,998 g x 2 g
5 lb /
2.3 kg
HIBCC UPN
+H925PS52KD0
Display: 4 digit, 0.5”/13 mm high LCD
Overall Size: 2.75” H x 7.5” W x 7” D/7 cm H x 19 cm W x 18 cm D
Tray Size: 2” H x 9” W x 6” D/5 cm H x 23 cm W x 15 cm D
Construction: Scale is metal with baked enamel finish and stainless steel tray
www.DetectoScale.com
SPECIALTY SCALES
25
Digital Visiting Nurse Scale
Accurate and reliable, Detecto’s economical DR400C platform scale
is lightweight and portable, making it perfect for mobile clinics and
home care nurses. The remote indicator features a large 1”/25 mm
high display, units conversion, and tare. The unit has a slip-resistant
mat to ensure patient safety when getting on and off the scale. The
DR400C is battery powered, so you can take it anywhere you need it.
The keypad features four keys: LB/KG, TARE/HOLD, ON, and OFF.
Optional black
carrying case
with handle
protects the
scale for easy
transport.
MODEL
CAPACITY
HIBCC UPN
DR400C
400 lb x 0.5 lb /
181 kg x 0.2 kg
+H925DR400C01
DR400C-CASE
carrying case
+H925DR400CCASE0M
Display: 4-digit, 7-segment, 1”/25mm high LCD
Power: 6 “AA” alkaline batteries or 115 volt AC adapter (included)
Platform Size: 12” x 12” / 31 cm x 31 cm
Shipping Weight: 13 lb/6 kg
Chiropractor Package - Bilateral Weight Scales
Detecto’s MD250PKG Special Chiropractor Package comes with two
model MD250 250 lb capacity scales and a 40”/1 m lock/release rod,
giving you everything you need for efficient and portable bilateral
weighing. The kit is perfect for chiropractor’s offices to check if a patient’s weight is evenly distributed. It’s also useful in spinal screenings,
in-office postural examinations, and health fairs. The size of a small
briefcase and incredibly compact and light, the MD250 portable scales
are built with sturdy steel construction for durability.
Cert. No.
88-110
Autopsy Scale
The extra-large, recessed 14.5” (37cm) double dial
is easily readable from both sides and is lithographed on metal with chrome-pated sashes and
stainess steel bands. Stainless steel housing and a
stainless steel commodity pan enhance the clean,
attractive appearance. The pinion bridge is fastened on both ends to heavy posts, insuring perfectly straight center action for precise weighing.
Long term accuracy is guaranteed by Detecto’s use
of Thermolastic springs which are not affected by
extreme temperature variations.
MODEL
CAPACITY
HIBCC UPN
T3530A
32 lb - 10 lb
x 1 oz
+H925T3530A0
Revolutions: 3.2
Pan: 15” (38cm) round stainless steel
Shipping Weight: 33 lb/15 kg
MODEL
CAPACITY
HIBCC UPN
MD250PKG
250 lb x 1 lb per scale
+H925MD250PKG05
Platform Size: 13” W x 10.5” D/33 cm W x 27 cm D
Shipping Weight: 21 lb/10 kg
Placing two MD250 scales side by side allows bilateral weighing to test for
irregularities in spinal conditions. This can be a sign of chiropractic problems. The MD250PKG kit enables a person to distribute their weight evenly,
and then lock the weight in place to view after they step off the scale. Chiropractors and nurses may use the MD250PKG to educate their patients
about spinal problems and how to correct their stance and body position.
(800) 641-2008
VETERINARY SCALES
26
Scales for
Veterinarians,
Pet Stores,
Kennels
or Labs
Medium Capacity Digital Vet Scale
This portable, compact-sized scale with a remote weight display is the ideal scale for small animals. Its scale base can be positioned up to 8 feet away
from the display. The scale and display are battery powered, and have a
power-saving automatic sleep mode. The scale’s medium base size allows
it to be used on the floor or tabletop and its light weight makes it ultra
portable. The VET50 comes with the rubber mat pictured to the right.
Dimensions: 3” H x 14” W x 12” D / 8 cm H 36 cm W x 30 cm D
758C
Please see pages 8 and 9 for additional weight display features.
MODEL
CAPACITY / DESCRIPTION
SHIPPING WEIGHT
HIBCC UPN
VET50
50 lb x 0.02 lb / 20 kg x 0.01 kg
15 lb / 7 kg
+H925VET5000O
728R121
AC Adapter
1 lb / 453 g
+H925728R1210-
The animal’s weight can be
retained after it is removed from
the scale. The scale and display are
battery powered with an automatic
sleep mode to conserve battery
power when not in use.The VET400
comes with a 8’/2.5m coiled cable.
High Capacity Digital Vet Scale
The VET400 is the perfect scale for anyone handling medium to large size animals. The large, low-profile platform makes it easy for
animals to step onto the floor scale without any hesitancy, and an optional rubber mat is also available.The removable stainless
steel platform makes cleanup fast and easy. Its scale base can be positioned up to 8’/2.5m away from the display due to the coiled
cable. The indicator features an adjustable mounting bracket for either desk or wall mount convenience. Automatic zero tracking
maintains the scale at zero while the Lock/Release feature retains the displayed weight after the animal is removed.
Dimensions: 1.75” H x 42” W x 22” D/44 cm H x 107 cm W x 56 cm D
758C
Please see pages 8 and 9 for additional weight display features.
MODEL
CAPACITY / DESCRIPTION
SHIPPING WEIGHT
HIBCC UPN
VET400
400 lb x 0.2 lb / 200 kg x 0.1 kg
76 lb / 34 kg
+H925VET4000N
VET-MAT
Rubber Mat
1 lb / 453 g
+H925VETMAT0
728R121
AC Adapter
1 lb / 453 g
+H925728R1210-
www.DetectoScale.com
EU-ONLY SCALES
Model 6550KGEU
27
Health Care Scales
Around the Globe
Model 8450KGEU
Model 6856KGEU
Model 6868KGEU
Model 6875KGEU
Model CR-1000DKGEU
Model 6880KGEU
Model 6876KGEU
Model GP-400-204KGEU
Detecto is Your
WORLDWIDE
Model 6855KGEU
SCALE PROVIDER
Model VET50KGEU
Model
VET400KGEU
Model GP-400-758CKGEU
Waist-High Digital Physician Scale
European-Only Models
Detecto’s EU522 is designed for use in European countries and features a
stainless steel casing around the 758CSV digital weight indicator. This waisthigh digital physician scale is light, but rugged and comes in white with
black trim. It is also is available with a 92 cm to 198 cm height rod - model
EU522HR. The scale features “at-a-glance” display of the weight with the
758CSV digital indicator and a slip-resistant base cover for patient safety.
Model
EU522
MODEL
CAPACITY
EU522
200 kg x 0.1 kg
EU522HR
200 kg x 0.1 kg
HEIGHT ROD
76 - 198 cm
HIBCC UPN
+H925EU5220+
•
+H925EU522HR0%
Scale Height: 95 cm
Platform Size: 26 cm x 34 cm
758C
Please see pages 8 and 9 for additional weight display features.
(800) 641-2008
Model
EU522HR
WASTE RECEPTACLES
28
Easy to Clean
and Featuring
Unitized
Construction
Featuring a selfclosing lid which
also lifts off easily
to remove the
disposable bag
• FREE Bio-Hazard and Infectious Waste Adhesive Labels
(Meets OSHA Labeling Requirements)
• Bag Securing Mechanism on Wall Mount Hanging Models
CLEAN UP IS EASY
Not only do the stainless steel and epoxy
polyester finishes on Detecto’s waste receptacles allow for quick, wipe-down cleaning,
the H models can be permanently positioned just off the ground for easy sweeping and mopping underneath and keeping
debris from collecting around the base.
Mounting brackets come with all the H
models. To remove them from the wall, simply slide them up and out of their groove.
Lift bail mechanism
and drop in bag.
Fold top of bag over
edges of bail to secure.
Press bail mechanism
back into place.
Self-Closing Lids on Wall Mount
Hanging Models
Wall Mount Hanging Waste Receptacles
MODEL
CAPACITY
DIMENSIONS
H-60S
Stainless Steel
60 quart
33” H x 18.25” W x 7” D /
(15 gallon) 84 cm H x 46 cm W x 17 cm D
H-60
White Epoxy
60 quart
33” H x 18.25” W x 7” D /
(15 gallon) 84 cm H x 46 cm W x 17 cm D
+H925H600B
H-90S
90 quart
37.25” H x 18” W x 9.25” D /
Stainless Steel (22.5 gallon) 95 cm H x 46 cm W x 23 cm D
H-90
White Epoxy
Model
H-60S
Model
SWC-64
90 quart
37.25” H x 18” W x 9.25” D /
(22.5 gallon) 95 cm H x 46 cm W x 23 cm D
+H925H90S0%
+H925H900E
Shipping Weights: H-60/H-60S - 22.5 lb / 10 kg
H-90/H-90S - 29.25 lb / 13 kg
Model
H-90
Standard Stainless Steel Waste Receptacles
Hemmed, exposed edges for safety
Model
SWC-48
HIBCC UPN
+H925H60S0$
Model
SWC-32
MODEL
CAPACITY
SWC-32
Stainless Steel
32 quart
(8 gallon)
HIBCC UPN
DIMENSIONS
+H925SWC320M
20.75” H x 10” W x 10” D /
53 cm H x 25 cm W x 25 cm D
SWC-48
Stainless Steel
48 quart
23.25” H x 11.5” W x 11.5” D / +H925SWC480T
(12 gallon) 59 cm H x 29 cm W x 29 cm D
SWC-64
Stainless Steel
+H925SWC640R
64 quart
24” H x 17” W x 10” D /
(16 gallon) 61 cm H x 43 cm W x 24 cm D
Shipping Weights: SWC-32 - 11 lb / 5 kg
SWC-48 - 13 lb / 5.9 kg
SWC-64 - 16 lb / 7.3 kg
www.DetectoScale.com
STEP-ON CANS
29
Detecto Step-On Can Waste Receptacles
Named for their rugged toughness, Detecto Step-On Cans are perfect for hospitals, doctors’
offices, patients’ rooms, and laboratory settings. They come in a variety of five different sizes
and capacities and two different materials listed below. The cans are flame retardant, have a
self-closing lid for sanitation, epoxy polyester or stainless steel finish for easy cleaning, and full
width hinges and unitized construction for long-term use. Detecto also includes free bio-hazard and infectious waste adhesive labels to meet OSHA labelling requirements.
Baked Epoxy Steel Step-On Cans
MODEL CAPACITY
Model
P-32
SHIPPING
WEIGHT
HIBCC UPN
P-16
16 quart
(4 gallon)
13” H x 11.75” W x 13” D /
33 cm H x 30 cm W x 33 cm D
12 lb /
5 kg
+H925P160K
P-24
24 quart
(6 gallon)
16” H x 11.75” W x 13” D /
41 cm H x 30 cm W x 33 cm D
14 lb /
6 kg
+H925P240J
P-32
32 quart
(8 gallon)
21” H x 11.75” W x 13” D /
53 cm H x 30 cm W x 33 cm D
16 lb /
7 kg
+H925P320I
P-48
48 quart
(12 gallon)
23.5” H x 13” W x 14” D /
60 cm H x 33 cm W x 36 cm D
20 lb /
9 kg
+H925P480P
P-100
100 quart 27.5” H x 16.75” W x 17.75” D /
(25 gallon) 70 cm H x 43 cm W x 50 cm D
31 lb /
14 kg
+H925P1000E
P-16R
16 quart
(4 gallon)
13” H x 11.75” W x 13” D /
33 cm H x 30 cm W x 33 cm D
12 lb /
5 kg
+H925P16R04
P-24R
24 quart
(6 gallon)
16” H x 11.75” W x 13” D /
41 cm H x 30 cm W x 33 cm D
14 lb /
6 kg
+H925P24R03
P-32R
32 quart
(8 gallon)
21” H x 11.75” W x 13” D /
53 cm H x 30 cm W x 33 cm D
16 lb /
7 kg
+H925P32R02
P-48R
48 quart
(12 gallon)
23.5” H x 13” W x 14” D /
60 cm H x 33 cm W x 36 cm D
20 lb /
9 kg
+H925P48R09
P-100R
100 quart 27.5” H x 16.75” W x 17.75” D /
(25 gallon) 70 cm H x 43 cm W x 50 cm D
31 lb /
14 kg
+H925P100R0+
(white)
(white)
(white)
(white)
(white)
(red)
(red)
(red)
Model
P-32R
DIMENSIONS
(red)
(red)
Stainless Steel Step-On Cans
MODEL CAPACITY
Model
C-32
DIMENSIONS
SHIPPING
WEIGHT
HIBCC UPN
C-16
C
16 quart
(4 gallon)
13” H x 11.75” W x 13” D /
33 cm H x 30 cm W x 33 cm D
12 lb /
5 kg
+H925C1607
C-24
C
24 quart
(6 gallon)
16” H x 11.75” W x 13” D /
41 cm H x 30 cm W x 33 cm D
14 lb /
6 kg
+H925C2406
C-32
C
32 quart
(8 gallon)
21” H x 11.75” W x 13” D /
53 cm H x 30 cm W x 33 cm D
16 lb /
7 kg
+H925C3205
C-48
C
48 quart
(12 gallon)
23.5” H x 13” W x 14” D /
60 cm H x 33 cm W x 36 cm D
20 lb /
9 kg
+H925C480C
C-100
C
100 quart 27.5” H x 16.75” W x 17.75” D /
(25 gallon) 70 cm H x 43 cm W x 50 cm D
31 lb /
14 kg
+H925C10001
Plastic Liners
Easy to clean plastic
liners are ideal for
use where disposable
bags are not desired.
(Model PL-32 Pictured)
MODEL
CAPACITY
SHIPPING
WEIGHT
HIBCC UPN
PL-16
16 quart (4 gallon)
2.75 lb / 1.2 kg
+H925PL160+
PL-24
24 quart (6 gallon)
3.5 lb / 1.6 kg
+H925PL2401
PL-32
32 quart (8 gallon)
4.5 lb / 2 kg
+H925PL320$
(800) 641-2008
UNIVERSAL GLOVE BOX HOLDERS
30
Wire Frame Glove Box Holders
Conserve counter space with Detecto’s Universal Glove Box Holders. Available in two sizes, the standard and large glove box holders firmly hold two
boxes upright or one box lying down. The all-steel construction with white
powder coat finish carries a Detecto lifetime guarantee. The open design allows you to see what size or type of glove is being dispensed. The holders
accomodate most glove boxes and are universal enough to be used for tissue holders where counter or shelf space is conservative. The units install in
seconds with the included mounting hardware.
MODEL
DIMENSIONS
HOLDIT
Standard Size
4.75” H x 10.75” W x 3.125” D / +H925HOLDIT0O
12 cm H x 27 cm W x 8 cm D
HOLDIT-L
Large Size
4.75” H x 11.125” W x 3.5” D /
12 cm H x 28 cm W x 9 cm D
HIBCC UPN
+H925HOLDITL02
Holds one box lying down snugly and
accomodates most gloves boxes.
Universal enough to be used for tissue holders
where counter or shelf space is conservative.
The HOLDIT Universal Glove Box Holders stores two boxes upright.
The standard holders firmly hold two boxes upright or one box lying down.
Full Frame Glove Box Holders
Detecto’s model GH Glove Box Holders are available in three different sizes.
Fit one glove box in the small GH1, two boxes side by side in the GH2, and
three boxes side by side in the GH3. The all-steel construction with white
powder coat finish carries a Detecto lifetime guarantee. The units install in
seconds via screwholes and the GH1 also features a snap-on clip in back. The
open design allows you to see what size or type of glove is being dispensed.
MODEL
DIMENSIONS
HIBCC UPN
GH1
Holds 1 Box
10.5” H x 6.5” W x 4.25” D /
27 cm H x 17 cm W x 11 cm D
+H925GH10M
GH2
Holds 2 Boxes
10” H x 12” W x 4” D /
25 cm H x 30 cm W x 10 cm D
+H925GH20N
GH3
Holds 3 Boxes
10” H x 18” W x 4” D /
25 cm H x 46 cm W x 10 cm D
+H925GH30O
MODEL
GH3
MODEL
GH1
www.DetectoScale.com
MODEL
GH2
INDEX
31
MODEL
0046-C007-08
0046-C065-08
0046-C247-08
057
0571
059
0591
080
080KG
11S400H
2371
2371S
2381
2391
2391S
243
2431
2441
2491
253
2531
337
337S
338
339
339S
349
3PHNDPST
3PHTROD-1
3PHTROD-3
3PHTROD-WM
3PRAMP
3PWHL
437
437S
439
439S
442
448
449
450
451
459
459-CH
475
4751
483
485
4851
495
4951
4PHTROD-2
4PHTROD-3
6027
6027KG
6029
6029KG
6437
6439
6449
6475
6475K
6495
6550
6550WHLSTP
6745
6800-1037
6855
6856
6875
6876
6868
6800-1037
6800-1039
6880
728R121
758C
Page 17
Page 17
Page 17
Page 11
Page 11
Page 11
Page 11
Page 11
Page 11
Page 16
Page 5
Page 4
Page 5
Page 5
Page 4
Page 20
Page 20
Page 20
Page 5
Page 20
Page 20
Page 5
Page 4
Page 5
Page 5
Page 4
Page 5
Page 5
Page 5
Page 5
Page 5
Page 12
Page 5
Page 5
Page 4
Page 5
Page 4
Page 6
Page 5
Page 5
Page 21
Page 21
Page 21
Page 20
Page 14
Page 14
Page 5
Page 12
Page 12
Page 12
Page 12
Page 5
Page 5
Page 11
Page 11
Page 11
Page 11
Page 6
Page 6
Page 6
Page 14
Page 14
Page 12
Page 13
Page 13
Page 18
Page 18
Page 6
Page 6
Page 14
Page 7
Page 7
Page 19
Page 19
Page 14
Page 6
Page 8
8430
8430S
8432-CH
8435
8437
8437S
8440
8440-CASE
8450
8450-CASE
AP-6
AP-8
AP-10
AP-20
AP-4K
AP-4KD
C-16
C-24
C-16
C-32
C-48
C-100
CR-500D
CR-1000D
D1130
D1130KG
D315
D315KG
DR400C
DR400C-CASE
DR400-758C
EU522
EU522HR
FHD-133-II
FHD-144-II
GH1
GH2
GH3
GP-400-204
GP-400-758C
H-60
H-60S
H-90
H-90S
HOLDIT
HOLDIT-L
IB400
IB600
MCS25KGNT
MD250PKG
P-100
P-100R
P-16
P-16R
P185
P220
P-24
P-24R
P-32
P-32R
P-48
P-48R
PL-16
PL-24
PL-32
PL425
PL435
PL475
PL400
PL600
PS5A-2KD
PS-5A
PS-6A
PS-7
PS-11
PT-1
PT-10SR
Page 10
Page 4
Page 18
Page 19
Page 10
Page 4
Page 19
Page 19
Page 19
Page 19
Page 23
Page 23
Page 23
Page 23
Page 23
Page 24
Page 29
Page 29
Page 29
Page 29
Page 29
Page 29
Page 13
Page 13
Page 10
Page 10
Page 10
Page 10
Page 25
Page 25
Page 6
Page 27
Page 27
Page 13
Page 13
Page 30
Page 30
Page 30
Page 24
Page 24
Page 28
Page 28
Page 28
Page 28
Page 30
Page 30
Page 17
Page 17
Page 20
Page 25
Page 29
Page 29
Page 29
Page 29
Page 9
Page 18
Page 29
Page 29
Page 29
Page 29
Page 29
Page 29
Page 29
Page 29
Page 29
Page 16
Page 16
Page 16
Page 16
Page 16
Page 24
Page 23
Page 23
Page 23
Page 23
Page 22
Page 22
PRODUCT CATEGORY
PT-1000RK
PT-1000SRK
PT-2
PT-2R
PT-25
PT-25R
PT-25SR
PT-5
PT-5R
PT-5SR
PT-500RK
SWC-32
SWC-48
SWC-64
T1KP
T2KP
T3530A
VET50
VET400
VET-MAT
WinDDE
Page 22
Page 22
Page 22
Page 22
Page 22
Page 22
Page 22
Page 22
Page 22
Page 22
Page 22
Page 28
Page 28
Page 28
Page 22
Page 22
Page 25
Page 26
Page 26
Page 26
Page 9
Acute Care
6439 Eye-Level Physician Scale
6550 Portable Wheelchair Scale
6745 Baby Scale
6856 Bariatric Scale
6880 Rolling Chair Scale
8450 Baby Scale
IB400 In-Bed Scale
IB600 In-Bed Scale
P-32 Step-On Can
PL475 Patient Lift
Bariatric Care
6550 Portable Wheelchair Scale
6855 Bariatric Scale
6856 Bariatric Scale
6868 Bariatric Scale
6876 Flip Seat Euro Scale
CR-1000D Wheelchair Scale
FHD-133-II Wheelchair Scale
Home Health Care
080 Personal Fitness Scale
437 Eye-Level Physician Scale
8440 Baby Scale
D1130 Personal Floor Scale
D315 Personal Floor Scale
DR400C Floor Scale
Long-Term Care
6475 Chair Scale
6550 Portable Wheelchair Scale
6876 Flip Seat Euro Scale
CR-1000D Wheelchair Scale
IB600 In-Bed Scale
FHD-133-II Wheelchair Scale
Physician Care
439 Eye-Level Physician Scale
6439 Eye-Level Physician Scale
CR-500D Wheelchair Scale
DR400-758C Portable Floor Scale
P-24 Step-On Can
H-90S Wall-Mount Waste Receptacle
Surgical Care
6855 Bariatric Scale
6856 Bariatric Scale
6868 Bariatric Scale
AP-4KD Portion Control Scale
PS5-2KD Portion Control Scale
PT-2R Dial Type Portion Scale
Veterinary Care
GP-400-758C General Purpose Scale
PS5-2KD Digital Scale With Tray
VET400 Veterinary Scale
VET50 VeterinaryScale
EU Class III Approved
6550KGEU Portable Wheelchair Scale
6855KGEU Bariatric Scale
6856KGEU Bariatric Scale
6868KGEU Bariatric Scale
6875KGEU Premier Chair Scale
6876KGEU Flip Seat Scale
6880KGEU Chair Scale
CR-1000DKGEU Wheelchair Scale
EU522/EU522HR Waist-High Scale
GP-400-204KGEU General Purpose Scale
GP-400-758CKGEU General Purpose Scale
VET400KGEU VeterinaryScale
VET50KGEU VeterinaryScale
EU Class IIII Approved
8450KGEU Baby Scale
(800) 641-2008
Page 6
Page 13
Page 18
Page 7
Page 10
Page 19
Page 17
Page 17
Page 29
Page 16
Page 13
Page 7
Page 7
Page 7
Page 7
Page 13
Page 13
Page 11
Page 5
Page 19
Page 10
Page 10
Page 25
Page 14
Page 13
Page 7
Page 13
Page 17
Page 13
Page 5
Page 6
Page 13
Page 6
Page 29
Page 28
Page 7
Page 7
Page 7
Page 24
Page 24
Page 22
Page 24
Page 24
Page 26
Page 26
Page 13
Page 7
Page 7
Page 7
Page 14
Page 7
Page 14
Page 13
Page 27
Page 24
Page 24
Page 26
Page 26
Page 19
DETECTO ONLINE
OUR MISSION STATEMENT
Detecto’s entire product line is available for viewing online on our Web site: www.DetectoScale.com.
Detecto aims to provide our customers with the most
up-to-date and comprehensive product information
and resources available anytime on the Web.
Detecto is dedicated to the design and manufacture
of innovative quality products of exceptional value to
a world market. These efforts are monitored and communicated throughout the organization, in order to
bring forth continuous improvement and growth for
the Detecto family and our customers.
Go to www.DetectoScale.com for extensive
Detecto product information, brochures, specification sheets, a physician scale model comparison chart,
demonstration videos, ISO certification resources, company history, and “legal-for-trade” certifications; in addition to this catalog in PDF format, all just a click away.
We will...promote an open environment encouraging
creativity, team work, and total employee involvement.
We
will...maintain
a
positive
commitment
to
continual quality improvement essential for our
customer’s satisfaction.
We will...seek mutually beneficial long term relationships with our customers, distributors, suppliers, and
community.
We will...adhere to sound business and environmental
practices.
We will...strive to attract, develop, fairly reward, and
provide secure employment for capable and committed
employees.
We will...maintain a fair rate of return on investment to
ensure the accomplishment of our mission.
SOLD BY:
Detecto Scale reserves the right to improve, enhance or modify features and specifications without prior notice. © Copyright 2004 Cardinal Scale Mfg. Co. • Printed in USA • CPS/20M/1204/C-188
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
