Televisions
Panasonic ..........................................386-393
Pioneer ................................................394-405
Samsung ............................................406-409
Sanyo ..............................................................421
Sharp .....................................................410-413
Sony .......................................................414-421
The
SourceBook
A/VPresentation
PHOTO - VIDEO - PRO AUDIO
Section5
Obtaining information and ordering from B&H is quick and
easy. When you call us, just punch in the corresponding
Quick Dial number anytime during our welcome message.
The Quick Dial code then directs you to the specific
professional sales associates in our order department.
For Section 5, Televisions,
use Quick Dial #: 821
386
F L AT PA N E L D I S P L AYS
PA N A S O N I C
FLAT PANEL DISPLAYS
Professional 37” - 65” SD and
HD Plasma and LCD Monitors
Because flat panel displays are used in a variety of applications, they must
meet a range of requirements. They must offer clear, faithful images. And
they must provide advanced functions, screen sizes large enough for the
installation location, and a level of resolution suited to the content that
will be displayed. Available in five sizes and two different definition panels,
Panasonic’s plasma and LCD line-up provide all that and more.
Boasting phenomenal image quality, the industry’s highest gradation and outstanding contrast, Panasonic’s 8th generation
SD-Standard Definition (852 x 480 resolution) and HD-High Definition (1024 x 768 and 1366 x 768 pixel resolution) plasma
and LCD monitors provide pictures with the kind of breathtaking beauty that stirs emotion.
The TH-32LHD7UY 32” HD LCD display is perfect when space is at a premium. Function slots let you customize the unit
for a specific application. This panel is suitable for displaying both text and still images. The 37” TH-37PWD8UK SD and
TH-37PHD8UK HD plasma displays fit well in stores. They can display images from two video sources at the same time,
making it ideal for information displays in stores, show windows and other uses.
When set up for portrait display, the 42” TH-42PWD8UK SD and TH-42PHD8UK HD plasma displays are similar in size
and aspect ratio to a movie-size poster. Use them as a moving image poster. Or upgrade the system with a scheduling
function that displays content according to the correct time zone, and use them as a digital signboard.
For business meetings, presentations and other situations calling for powerful visual impact, the 50” TH-50PHD8UK HD
plasma is ideal. An optional touch panel adds sophistication and ease. It can also be upgraded to display handwritten
notes for even greater persuasive power. The massive 65” TH-65PHD8UK HD monitor is ideal for any application calling
for an eye-catching, super-sized vertical or horizontal display. Use it in a directory in a building lobby, an information
board for an airport, train station or other large public facility, or a monitor at event sites. With its large screen and high
resolution, it displays images that look clear and crisp even from a distance.
They are packed with innovative picture-improving technologies including a Real Black Drive System, Super Real Gamma
System, Motion Picture Disturbance (MPD) Noise Reduction, 3D Color Management, and Active I/P (Interlace/Progressive)
Conversion. They offer long service life, multi-screen capabilities and customization options.
To meet a variety of applications they offer advanced functions such as Dual Picture and Digital Zoom and a built-in
video wall processor that enables up to 4x 4 multi-screen
configuration. They also have multi-function slots where a
variety of optional networking or AV input boards can be added
or exchanged allowing the monitors to be customized. For added
convenience, they offer a host of energy-saving functions, and
their Contrast Automatic Tracking System (C.A.T.S.) senses
ambient lighting conditions and adjusts brightness and gradation
accordingly. The displays can be vertically or horizontally mounted
and are ideal as updateable digital signage or for an endless
array of multimedia applications.
PHOTO - VIDEO - PRO AUDIO
www.bhphotovideo.com
F L AT PA N E L D I S P L AYS
PA N A S O N I C
387
FLAT PANEL DISPLAYS
Highest Picture Quality
◆ The front protective glass of the plasma display panels incorporate a
Deep Black Filter that suppresses light transmittance and slashes the
amount of external light reflected. This allows the displays to achieve
high contrast ratio when viewed in bright surroundings.
◆ New Real Black Drive System reduces the pre-discharge emission
when reproducing black, providing deeper, richer blacks and a
stunning 4000:1 contrast in SD models, and 3000:1 in HD models.
The result is dramatically enhanced image
◆ They use ultra-precise, 14-bit signal processing to produce vividly rich
details. The Advanced Real Gamma System then takes it another step
further with full-time, full-pixel 1,536-step gradation and 2,048-step
dark-area gradation. This level of gradation brings intricate details and
more faithful color reproduction to all scenes, dark and bright.
◆ The area in which the phosphor can be applied has been increased,
dramatically improving both light-emitting efficiency and intensity.
Furthermore, by optimizing the gas composition ratio, lighting
efficiency has been increased by about 15%. The result is the industry’s
highest level of brightness.
◆ Standard AGC (Automatic Gain Control) detects the brightness level of
the entire image, then boosts it as necessary. However, this increases
noise. Panasonic’s Adaptive AGC raises contrast while suppressing
noise by detecting and boosting only the image edges.
◆ Improvements to the drive circuit and plasma gas inside the panel
have enabled Panasonic to boost peak brightness while lowering
power consumption. They boast a long service life of 60,000 hours.
A newly developed phosphor also raises the displays resistance to
static-image screen burning to the same level as CRT displays.
◆ High-precision MPD (Motion Picture Disturbance) Noise Reduction
detects motion patterns that tend to generate noise and makes the
necessary adjustments to maximize image quality. The result is crisp,
clean moving images. Plus, it doesn’t diminish the quality of stationary
objects, such as those in the backyard.
◆ For vibrant colors and natural skin tones, Panasonic’s 3D Color
Management system works in a three-dimensional color matrix
(hue, saturation, brightness). By correcting hue and brightness
independently and providing finer control, this process delivers
vibrant colors and natural skin tones.
◆ Active I/P (Interlace/Progressive) Conversion system detects slow
movements more precisely by increasing the range for detecting
moving-picture and still-picture pixels. This reduces I/P conversion
noise that often occurs when reproducing tiny movements, thereby
producing crisper images while raising the vertical resolution in
interlaced images.
Advanced Dual Picture Mode
Panasonic plasma displays feature a new Advanced Dual Picture Mode in addition to the conventional Dual Picture Mode. This new
mode lets you overlay a video image onto a full-screen PC image. For example, you can superimpose text information from a PC over
a video clip, giving you a more effective way to present information. When displaying two separate images, you can select the audio
output from either source (previous models reproduced audio from the main source only). Playing back the audio from the sub-source
can be useful in teleconferencing, for example.
Note: TH-42PWD8UK and 37PWD8UK cannot display two images when both are from component video or RGB (PC) signal sources. The Advanced
Dual Picture Mode may not work properly with some video signals and is not available on the TH-32LHD7UY.
Advanced
Dual
Mode
Dual
Mode
Picture-And-Picture
Picture-Out-Picture
Picture-In-Picture
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
388
F L AT PA N E L D I S P L AYS
PA N A S O N I C
FLAT PANEL DISPLAYS
New Cabinet Design
Enhanced
Screen Saver Functions
Panasonic plasma displays (except the 65”)
have a simple, slim front bezel design. Control
buttons and the Power button are set on the
bottom surface. This gives the panels a
smooth, clean look while also helping prevent
accidental operation and tampering.
◆ A variety of screen saver functions help
minimize the risk of uneven phosphor aging.
You can also use the timer to set the screen
saver operating cycles, operating time, and
start and stop times. This lets you make
settings that match your application.
◆ The 65”, 50” and 42” models can be
positioned vertically to display portrait
images, allowing them to serve as effective
storefront signboards. There’s no need to
install an optional fan kit.
— White Bar Scroll: White bars move across
the screen from left to right at regular intervals. Good for ordinary still-image displays.
— Screen Reversal: Displays images with black
and white reversed. Good for text displays.
— Side Panel Adjustment: Brightens the black
bands on the sides of the screen when
displaying images in the 4:3 format.
— Wobbling: Shifts the image’s position by
several pixels at fixed time intervals.
— Peak Limit Mode: Lowers the peak
brightness level (image contrast) by 30%.
Energy-Saving Functions
◆ A broad range of environment-friendly
functions help minimize energy consumption.
— DPMS (Display Power Management
Signaling): Power is automatically turned
on or off in response to a sync signal from
a PC connected to the built-in PC input
terminal.
Remote System Monitoring
In addition to the conventional display control command and power supply/input selection
check command, Panasonic flat panel displays feature a new monitor command that lets you
check the signal from a distant location. In conventional systems, you had to install a monitoring
camera to check the images displayed on an advertising display panel or digital signage system.
This new monitor command, on the other hand, lets you monitor images by simply connecting
a PC via a serial cable.
Multi-Screen Applications
The built-in image-enlarging function makes it easier to set up a multi-screen display system
with four (2 x 2), nine (3 x 3), or 16 (4 x 4) units. For example, with sixteen 65” displays you can
configure a huge display equivalent to 260” by simply connecting ordinary cables. That’s the
kind of display that catches eyes at shopping malls and event sites. This function works with
component video signals, so you can use enlarged images from DVD and other high-quality
sources in your display.
— Auto Power Off: When you’re using a device
connected to the multi-function slots, the
display panel goes into standby mode after
10 minutes if no sync signal is received.
— Power Save Mode: Reduces the display’s
brightness.
— Standby Power Save Mode: Reduces power
consumption when on standby.
Additional Features
◆ The Sound Menu gives you a choice of three
sound settings (Standard/Dynamic/Clear) to
best match the kind of input source.
◆ Panasonic’s “silence engineering” eliminates
the need for a fan — and fan noise — giving
you the kind of quiet operation that makes
for a more pleasant viewing experience.
◆ 4x Digital Zoom lets you enlarge a portion
of an image by up to 4x normal size and
display it on the full screen. Use this function
to give your presentations greater impact.
PHOTO - VIDEO - PRO AUDIO
Thanks to the ID control function, you can use the standard remote control
unit to control multiple panels individually. There is also a mode that displays
a full-screen image, including the edges (the width of the frame) of the display
panel — something not possible with previous systems. This is especially
suitable for displaying text information, since no words are hidden by the frame.
www.bhphotovideo.com
F L AT PA N E L D I S P L AYS
PA N A S O N I C
389
FLAT PANEL DISPLAYS
Unmatched Expandability
In addition to their fixed inputs, the Panasonic line offer
dual and triple function slots and a host of optional
function boards, to offer outstanding flexibility and
adaptability, allowing them to display solutions to an even wider range of
customer needs. This gives you the flexibility to add digital or analog capabilities as necessary and to
create a customized system that meets your exact needs. Combined with the superb image quality, this level of flexibility
makes Panasonic flat panel displays THE high-performance solution to almost any application.
ion
Multi-Funct
and
Slots on 32”
:
37” Models
These models come with the standard
terminal boards mounted in slots 1
and 2. You can remove the standard
boards and mount one or two of the
optional boards.
ion
Multi-Funct
50”
Slots on 42”,
dels:
and 65” Mo
These models come equipped with the standard
terminal boards mounted in slots 2 & 3. You can
mount optional terminal board in slot 1. Or, you
can remove the standard terminal boards and
mount up to three optional boards.
TY-42TM6B BNC Composite Video Terminal Board
TY-42TM6G RGB Active-Through Terminal Board
For connection with analog equipment, the TY-42TM6B BNC
Composite Video Terminal Board lets you connect a VCR, DVD player
or video camera. This board has a video output terminal too, so you
can also connect a sub-monitor device for image monitoring.
For multi-screen system configuration, the TY-42TM6G allows the daisy
chaining of multiple plasma displays, making it easy to configure a
multi-screen plasma display system.
TY-42TM6V RCA Composite Video Terminal Board
TY-42TM6D RGB (Digital) Terminal Board (DVI-D with HDCP)
Same as above except with RCA terminals instead of BNCs.
The TY-42TM6D lets you connect a PC or other compatible digital
equipment that outputs digital RGB signals (DVI-D compliant).
TY-42TM6A BNC Component Video Terminal Board
TY-4FB8HM HDMI Terminal Board
For connection with analog equipment, the TY-42TM6A lets you
connect a VCR, DVD player or video camera. This board has a video
output terminal too, so you can also connect a sub-monitor device for
image monitoring.
The next-generation standard digital interface, HDMI terminal board
digitally transfers video and audio signals over a single cable. Connect a
compatible DVD player via an HDMI terminal, and the plasma display can
reproduce images with the equivalent of 4,096 gradation levels.
TY-42TM6Z RCA Composite Video Terminal Board
TY-FB7SD SDI and TY-FB7HD HD-SDI Terminal Boards
Same as above except with RCA terminals instead of BNCs.
For connection with broadcast equipment, these boards are compatible
with the SDI or HD-SDI (for HDTV) systems used by broadcasting stations.
These boards let the plasma displays to reproduce crisp, clear images in a
studio or control room.
TY-42TM6Y Composite/Component Video Terminal Board
For connection with analog equipment, the TY-42TM6Y lets you
connect a VCR, DVD player or video camera. Component connections
use BNCs, the composite connections use RCA terminals.
TY-42TM6P PC Input Terminal Board
Allows you to connect multiple PCs. Use it in conference rooms, class
rooms, lecture halls—any site where PCs are often used.
TY-42TM6B
TY-42TM6G
TY-42TM6V
TY-42TM6A
TY-42TM6D
TY-FB7WPU Wireless Presentation Board
For wireless connection, the TY-FB7WPU allows the plasmas to
simultaneously display signals from up to four notebook PCs. With a
wireless connection, you can get a presentation or meeting under way
quickly without taking the time and trouble to connect cables.
TY-42TM6Y
TY-4FB8HM
TY-42TM6P
TY-FB7SD
TY-FB7WPU
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
390
F L AT PA N E L D I S P L AYS
PA N A S O N I C
PLASMA SYSTEM SOLUTIONS
Digital Signage/Narrowcasting System
Complete with Touch Panel
Easily construct a simple, interactive content distribution system
for retail chains and public spaces such as shopping malls, office
buildings and hotels.
Constructing a Multi-Language Environment:
In contrast with conventional methods, in which several information panels are
prepared in different languages, this digital system allows visitors to simply touch
the panel itself to switch to the language they want. It is a highly effective and
efficient way to offer people the content that they want to see.
Flexible Content Control:
Each PDP controller fits inside the plasma and has a unique IP address, allowing
content to be streamed to the plasma on any LAN, modem, Internet or satellite
network. It speeds up the process of updating information, and any combination
of plasmas can be controlled locally or from a central location.
Space-Saving and Easy to Install:
The display system is slimmed down by incorporating the optional PDP Controller
right inside the plasma display. It requires only two connections, power and network.
The mouse/keyboard connections can be wireless, through the PCMCIA slots.
Universal System Design:
Since the entire system is configured in a Windows environment, the Controller is
compatible with a wide variety of off-the-shelf software applications.
Information System
Using the Twisted-Pair-Cable Receiver Board
Displays up-to-date information
such as transportation
schedule changes, stock market
conditions, and countless other
possible subjects.
Real-Time Information Bulletins:
The use of the CAT5e twisted-pair cable allows content to be sent from the server in
real-time, for instant response to events such as sudden changes in transportation
schedules or accident information as it becomes available.
Long-Distance Transmission of High-Quality Video Signals:
High-resolution XGA images, sound and RS232C control signal are transmitted
approximately 492’ over a single cable. PDP control signals can also be sent over the
same cable to allow remote operation of power ON/OFF and other functions.
Higher Signal Quality, Lower Costs, and Easier Installation:
Thin, lightweight CAT5e twisted-pair cables do a better job of preventing signal
degradation than coaxial cables. They also reduce costs and shorten the time needed
for installation.
PHOTO - VIDEO - PRO AUDIO
www.bhphotovideo.com
F L AT PA N E L D I S P L AYS
PA N A S O N I C
391
PLASMA SYSTEM SOLUTIONS
Multi-Presentation System
Using a Variety of Peripheral Equipment
Panasonic plasma TVs support diverse video sources. Mount
peripherals to the plasma display to take advantage of its detailed
images and wide viewing angle.
No Complicated Connections: You can connect multiple notebook PCs
to a single plasma display by simply making the appropriate network settings.
Naturally, this means that the conference room is neater, because there are no
connection cables to clutter it up. The display can also be controlled by the PCs.
Display Four PC Screens at the Same Time: It is easy to hold group
presentations, because the screen images of up to four PCs can be displayed
simultaneously.
A Wealth of Functions in a Compact System: The large screen and
wide viewing angle of the plasma display make it ideal for use in discussions.
You can optimize it even further by adding an array of peripheral equipment:
◆ Mounting a component video
terminal board lets it receive the
input of high-resolution DVD signals.
◆ Mounting a composite video
terminal board enables connection
of various analog equipment.
You can select the input for whichever video source you want easily with the
remote control. And you can mount the entire system to a wheeled stand, for
easy movement.
BP-S700PD Networked MPEG2 Player
◆ The local remote control allows playback control without the need for a
mouse and keyboard.
◆ Video signals are transmitted digitally to ensure crisp, clear images.
◆ The hardware decoder produces DVD-level image quality by supporting
MPEG2 [email protected] (Main [email protected] Level) transport. High-bit-rate data
also streams smoothly because all playback data is first stored in the
built-in hard disk.
◆ Combined with the BB-SMG700 Management Software, it is possible to
schedule the distribution of motion video, still images and other content,
and deliver over a LAN or Internet.
BB-SMG700
Management Software
Lets you control up to 100
plasma display panels, and
contains all of the functions
necessary for video distribution.
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
392
F L AT PA N E L D I S P L AYS
PA N A S O N I C
OPTIONAL PLASMA ACCESSORIES
Pedestals
Flush Wall-Hanging
Brackets
TY-ST07-K (PATYST07K) ...................CALL
TY-ST08-K (PATYST08K) ...............159.95
TY-ST65-K (PATYST65K) ...............849.95
TY-ST32L7-K (PATYST32L7K) ..........CALL
TY-WK37PV3 (PATYWK37PV3) ....314.95
TY-WK42PV7 (PATYWK42PV7) ....349.95
TY-WK65PV7 (PATYWK65PV7) ....374.95
TY-WK42PV7
Drawer Type
Wall Hanging Bracket
TY-WK65PV7
Stands
Angled Wall-Hanging
Brackets
Flush Wall
Hanging Brackets
Wall Stand (PATYST42PW1) .............CALL
Mobile Stand (PATYST42PF3) .....899.95
TY-WK32LR1S (PATYWK32LR1S) ....CALL
TY-WK42PR7 (PATYWK42PR7) ....429.95
Drawer Type
Wall Hanging Bracket
Ceiling-Hanging Bracket
TY-WK42DR1 (PATYWK42DR1) ......CALL
TY-CE42PS7 (PATYCE42PS1) ........719.95
TY-WK42PR7 Angled
Wall Hanging Bracket
TY-ST42PW1
Wall Stand
TY-ST08-K
Pedestal
TY-ST42PF3
Mobile Stand
TY-ST07-K Pedestal
CO M PAT I B L E M O U N T I N G M O D E L S AT A G L A N C E
TY-ST65-K
TY-ST08-K
TY-ST07-K
TY-ST42PF3
TY-CE42PS7
65PHD8UK
✓
—
—
TY-ST32L7-K TY-WK42DR1 TY-WK65PV7 TY-WK42PV7 TY-WK37PV3 TY-WK42PR7 TY-WK32LR1S TY-ST42PW1
—
—
✓
—
—
—
—
—
—
—
TH-50PHD8UK
—
✓
✓
—
✓
—
✓
—
✓
—
✓
✓
✓
TH-42PHD/PWD8UK
—
✓
✓
—
✓
—
✓
—
✓
—
✓
✓
✓
TH-37PHD/PWD8UK
—
✓
✓
—
—
—
✓
✓
✓
—
✓
—
✓
TH-32LHD7UY
—
—
—
✓
—
—
—
—
—
✓
—
—
—
Detachable Stereo Speakers
Designed for Panasonic plasma monitors, these 2-way, 3-speakers mount on the sides of the
monitor and will be powered by the monitor’s built-in audio amplifier.
Speakers for 65” Plasma Display (PATYSP65P7WK)
Measures 3.9 x 36.4 x 3.5” (WHD). Each speaker weighs 4.9 lbs ....749.95
Touch
Panel
An add-on touch-panel lets you write directly
onto the screen with a light touch. It is ideal
for adding written comments during a
presentation or meeting.
◆ Highly reliable optical sensor system
◆ Outstanding resolution, easy operation
◆ Thin design — a precise fit with the screen
Speakers for 50” Plasma Display (PATYSP50P8WK)
Measures 4.2 x 28.5 x 3.5” (WHD). Each speaker weighs 4.4 lbs ....299.95
Speakers for 42” Plasma Display (PATYSP42P8WK)
Measures 4.2 x 24 x 3.5” (WHD). Each speaker weighs 4.4 lbs........259.95
Speakers for TH-37PHD8UK/37PWD8UK Displays (PATYSP37P8WK)
Measures 4.2 x 21.7 x 3.5” (WHD). Each speaker weighs 4.4 lbs ....249.95
Speakers for TH-32LHD7UY Display (PATYSP32L7WS)
Measures 4 x 19.7 x 4.0” (WHD). Each speaker weighs 4.2 lbs........259.95
◆ Lets you use display as a “whiteboard”
For 65” display (PATYTP65P8S) .....................3999.95
For 50” display (PATYTP50P8S) .....................2879.95
For 42” displays (PATYTP42P8S) ...................2639.00
Touch Pen (PATYTPEN6)
For Touch Panel...............................................224.95
PHOTO - VIDEO - PRO AUDIO
PDP Controller for 42-, 50- and 65” Models
◆ Function board design reduces wiring and
saves space.
◆ Realistic display images are achieved by a
1:1 pixel correspondence with Panasonic
plasma displays.
www.bhphotovideo.com
◆ The controller can also be used in vertical
display applications.
◆ Only requires a network and power
connection. Mouse/keyboard connections
can be wireless, through the PCMCIA slots.
F L AT PA N E L D I S P L AYS
PA N A S O N I C
393
PLASMA SPECIFICATIONS
TH-32LHD7UY
TH-37PWD8UK
TH-42PWD8UK
TH-37PHD8UK
TH-42PHD8UK
TH-50PHD8UK
TH-65PHD8UK
PATH32LHD7UY
PATH37PWD8UK
PATH42PWD8UK
PATH37PHD8UK
PATH42PHD8UK
PATH50PHD8UK
PATH65PHD8UK
120V AC, 50/60 Hz
120V AC, 50/60 Hz
120V AC, 50/60 Hz
120V AC, 50/60 Hz
120V AC, 50/60 Hz
120V AC, 50/60 Hz
120V AC, 50/60 Hz
Power Consumption
234 W
250 W
275 W
282 W
337 W
440 W
675 W
Power Off Condition
0.2 W
0.05 W
0.05 W
0.05 W
0.1 W
0.1 W
0.2 W
Stand-By Condition
Save On: 0.6 W
Save Off: 0.8 W
Save On: 0.7 W
Save Off: 1.0 W
Save On: 0.7 W
Save Off: 1.0 W
Save On: 0.7 W
Save Off: 1.0 W
Save On: 0.4 W
Save Off: 0.6 W
Save On: 0.4 W
Save Off: 0.6 W
Save On: 0.5 W
Save Off: 0.7 W
a-Si TFT active
matrix 32”,
16:9 aspect ratio
Drive method:
AC type 37”,
16:9 aspect ratio
Drive method:
AC type 42”,
16:9 aspect ratio
Drive method:
AC type 37”,
16:9 aspect ratio
Drive method:
AC type 42”,
16:9 aspect ratio
Drive method:
AC type 50”,
16:9 aspect ratio
Drive method:
AC type 65”,
16:9 aspect ratio
800:1
4000:1
4000:1
3000:1
3000:1
3000:1
3000:1
27.4” x 15.4”
31.5”
32.2” x 18.1”
37”
36.2” x 20.4”
42”
32.2” x 18.1”
37”
36.2” x 20.4”
42”
43.5” x 24.5”
50”
56.5” x 31.7”
65”
Number of Pixels
1,049,088
1,366 x 768 (WH)
408,960
852 x 480 (WH)
408,960
852 x 480 (WH)
737,280
1,024 x 720 (WH)
786,432
1,024 x 720 (WH)
1,049,088
1,366 x 768 (WH)
1,049,088
1,366 [W] x 768 [H]
Audio Output (10% THD)
16 W (8 W + 8W)
16 W (8 W + 8W)
16 W (8 W + 8W)
16 W (8 W + 8W)
16 W (8 W + 8W)
16 W (8 W + 8W)
16 W (8 W + 8W)
Applicable PC Signals
XGA
VGA
VGA
XGA
XGA
XGA
XGA
Dimensions (W x H x D)
31.7” x 19.7” x 4.0”
36.2” x 21.7” x 3.5”
40.2” x 24.0” x 3.5”
36.2” x 21.7” x 3.5”
40.2” x 24.0” x 3.5”
47.6” x 28.5” x 3.7”
61.2” x 36.4” x 3.9”
37.5 lbs.
55.1 lbs.
65 lbs.
57.3 lbs.
69.4 lbs.
94.8 lbs.
172 lbs.
B&H Product No.
Power Source
LCD Display Panel
Contrast Ratio
Screen Size (W x H)
Diagonal
Weight
Color System
Safety Standards
Terminals (AV)
(COMPONENT/RGB)
(PC)
(SERIAL)
NTSC, PAL, PAL 60, SECAM, Modified NTSC
UL6500/C-UL
VIDEO IN/OUT (BNC): 1.0 Vp-p (75-ohms), S-VIDEO (Mini DIN 4-pin): Y: 1.0 Vp-p (75-ohms), C: 0.286 Vp-p (75 ohms), AUDIO IN L/R (RCA x 2): 0.5 Vrms
Y/G (BNC): 1.0 Vp-p/composite (75-ohms); 0.7 Vp-p/non-composite (75 ohms), PB, PR/CB, CR (BNC): 0.7 Vp-p (75 ohms); R/B (BNC): 0.7 Vp-p (75 ohms)
AUDIO IN L/R (RCA pin jack x 2): 0.5 Vrms (high impedance)
(Mini D-sub 15-pin), fH: 15 — 110 kHz; fV: 48 — 120 Hz, R,G,B: 0.7 Vp-p (75-ohms), Y: 1.0 Vp-p (75-ohms: including sync)
PB, PR/CB, CR: ± 0.7 Vp-p (75-ohms); HD, VD/1.0 — 5.0 Vp-p (high impedance), Audio In (M3 jack): 0.5 Vrms (high impedance)
External control terminal (D-sub 9-pin), RS-232C compatible
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
394
F L AT PA N E L D I S P L AYS
PIONEER
PLASMA DISPLAYS
Pioneer’s plasma displays have become the preferred standard for
applications including information visualization, lobbies, conference
and boardrooms, large area viewing command control centers, point
of information or public display, information kiosks and digital
signage. Utilizing Pioneer’s extensive understanding of industrial
displays, leading edge product design and manufacturing ability,
these displays take performance and flexibility to an entirely new
level by increasing brightness, sharpness and color reproduction
quality while also increasing reliability, operating ease and versatility.
Pioneeer initiated the development of plasma displays in 1991, and
have worked ceaselessly to achieve higher levels of detail, picture
quality and functionality. In 1999, they developed the industry’s first Encased Cell Structure panel and Advanced
Continuous Emission (ACE) technology. Then in 2001, they achieved a further breakthrough with the Deep Encased Cell
Structure. In terms of functionality, they were the first to provide expansion slots for professional applications and to be
certified by Microsoft’s WHQL (Windows Hardware Qualification Labs).
Pioneer Plasma Displays fit seamlessly and elegantly into corporate offices. They can be
used in lobbies, conference rooms, common office areas or even open meeting areas and
are highly effective tools in business.
Electronic advertising, promotions or up to date product information
can be easily displayed and read by customers on a Pioneer Plasma
Display in retail environments.
PHOTO - VIDEO - PRO AUDIO
Pioneer Plasma Displays can be used in control room type applications where space is a
premium. Important information can be easily read and monitored with wide viewing
angles and bright, sharp images.
Public information displays are gaining popularity using Pioneer Plasmas. High visibility combined with leadingedge Pioneer Plasma technology, make this venue a perfect fit. Get their attention, convey your message and
make an impression, all with the help of Pioneer Plasma Displays.
www.bhphotovideo.com
F L AT PA N E L D I S P L AYS
PIONEER
395
PDP-424MV
42” WVGA Professional
Plasma Display
Pioneer’s PDP-424MV professional plasma display offers high
image quality at an affordable price, in a compact 42” size.
Offering commercial users another option for their digital
signage, boardroom and other business applications, the
PDP-424MV features superior brightness and contrast. A
wide range of user-friendly functions such as programmable
timer, up to 9x point zoom, energy and image burn-in
management and video wall capability, enable outstanding control and convenience. For added value, it offers significant
longevity for a commercial user. 60,000 hours is the time for the display panel to reach half of its original luminescence.
F E AT U R E S
High Image Quality
Superior Image Processing Technology Quality
◆ The PDP-424MV uses a precisely engineered
CCF (Capsulated Color Filter) that decreases
light reflection for better view ability and filters out unnecessary elements in the red,
green, and blue light for true color reproduction. Skin tones, for example appear
more natural because the filter is designed
to reduce the orange tint present in the red
color range. All images, even fast-moving
ones, will be accurate, crisp and natural.
◆ From input to output, through all processing steps, the video signal remains in the digital
domain. This ensures noise-free, no-loss processing of a variety of inputs from video to PC,
allowing the highest possible signal quality.
◆ For precision, four gamma modes allows a
more accurate display of the tone gradations,
even for images with low lighting.
◆ Scan converts input signals with high sampling
accuracy so even minor details such as small
letters are sharp and clear.
◆ I/P conversion and scaling Larger Scale
Integrated (LSI) circuits smooth jagged
edges, correct color bleeds and select the
ideal input resolution by simultaneously
sensing both Y and C signals, resulting in
images that are smooth and clean.
◆ Black Stripe inhibits the reflection of outer
light and enhanced contrast to ensure that
dark colors remain crisp and clear, even in
bright settings.
Video Wall Capability
Easy-to-configure multi-monitor
video walls. Possible configurations
are 2 x 2, 3 x 3, 4 x 4 and 5 x 5. Two
display modes are available, one that
enlarges all picture elements so the
entire picture is visible and one that
enlarges the whole image so lines
between units are not visible. Other
functions include Power On Delay to
reduce initial power load, ABL Link for
aligning monitor brightness in multimonitor displays and Auto ID Setting.
◆ Encased Cell Structure is a key factor in the
PDP-424MV’s superior performance. The
cells feature a larger phosphor surface area
that prevents light leakage enabling better
performance. Luminous efficiency is higher,
the screen is brighter, and subtle details are
enhanced.
◆ Pioneer knows that colors are crucial to your
business. “Red” can mean a lot of different
things to different companies. Get red rightor whichever colors you need to fine-tunewithout skewing the other colors in the picture-using Pioneer's essential Color Detail
Adjustment feature.
◆ Point Zoom
function lets you expand any
portion of a PC or video image from 1x to 9x
in 64 steps.
Conveniences
◆ ABL (Auto Brightness Limiter) Lock provides three selectable modes to reduce power
consumption when desired. Modes to manage image burn-in include Orbiter (moves image
one pixel at a time), Inverse (displays image as negative), Full Mask (white) and others.
◆ Timer function features a convenient Weekly Timer and the following programmable functions:
power on/off, input selection, activation of image burn-in management modes.
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
396
F L AT PA N E L D I S P L AYS
PIONEER
PDP-425CMX
42” XGA Professional
Plasma Display
A professional plasma display, the PDP-425CMX offers the
flexibility of Expansion Solutions in a 42” size and displays
images with a new level and brilliance as well as exceptional depth. PureVision and the Pure Drive system ensure the
image you project is compelling and true-to-source. This
next generation panel has pure digital processing and is
ideally suited for a wide range of professional and public
display applications.
F E AT U R E S
Pure Black Panel
◆ In addition to Deep Encased Cell Structure
the PDP-425CMX uses another breakthrough technology called Crystal Emissive
Layer to achieve high luminous efficiency.
The result is unprecedented high brightness
of 1,400 cd/m2 (peak/panel) and greatly
improved dark-area contrast. Blacks are
blacker, while light areas maintain their true
brightness values. Bright-area contrast is
also much higher, meaning that the PDP425CMX will provide conspicuous, effective
displays in bright places such as shopping
malls, event venues and showrooms.
Dual Screen Function
The new Pure Drive Pro image processing engine greatly improves processing of not only the
main image, but also the sub-image in dual image modes. As a result, a variety of dual-image
displays not previously possible can now be shown, allowing presentations and product promotions that are impressive and persuasive.
Standard Dual Screen Mode
Remote control operation permits the use of Picture-in-Picture (P-in-P) and Side-by-Side modes.
With P-in-P you can shift the position of the sub-image among four locations. Side-by-Side
switches between the left and right images, and in addition to the swap function, you can also
switch the audio via remote control.
Intelligent Dual Screen Mode
The P-in-P mode permits a number of display variations. You can select four sizes of P-in-P
sub-images and you can set the transparency of the sub-image from 0 to 80%.
New Pure Drive Pro
Upgraded Side-By-Side Mode
◆ High efficiency and the best possible picture
Easily switch between Side-by-Side and
P-out-P modes with the Integrator Menu.
It is also possible to select three horizontal
aspect ratios for dual image, full screen
display.
quality have been achieved by mounting
the color management, scaling, GUI mix and
other image processing technologies on a
single chip that Pioneer developed
exclusively for their professional monitors.
◆ Superb scaling performance ensures that
even high-resolution signals are reproduced
with minimal data loss. Even when the
image is expanded by video wall or point
zoom functions, the monitor displays
detailed information with extreme clarity.
◆ In addition, ACE IV technology enables the
panel to accurately reproduce high level
gray scale for each color. The panel instantly
identifies the type of image being shown
(fast- vs. slow-motion scenes, dark vs. light
scenes) and dynamically optimizes the
distribution of color gradation.
PHOTO - VIDEO - PRO AUDIO
Side-by-Side
Banner PIP Mode Displays
On-Screen Titles
You can easily display titles prepared in
PowerPoint presentation software or
other programs on the screen. You can
Picture-out-Picture
choose four positions for the titles:
top, medium top, medium bottom, and
bottom. The transparency of the on-screen titles can also be varied.
Sub-Image Detection
If the sub-image input signal is lost during P-in-P display, this mode shuts off, and is automatically
selected again when the signal is restored (operates only with P-in-P mode).
www.bhphotovideo.com
F L AT PA N E L D I S P L AYS
PIONEER
397
PDP-425CMX
Video Wall – Display up to 25 Images
Pioneer makes it easy to configure multi-monitor video walls.
Possible configurations are 2x2, 3x3, 4x4 and 5x5. Two display
modes provided: Normal, for showing data and text, enlarges
the image so that no elements are hidden by bezels, while
Adjusted, for pictures and video, enlarges the image as a single
whole unit, as though looking through a window. Video Wall
functions include Power On Delay, ABL Link, Auto ID Setting
and Repeat Timer. Video Wall is an internal function, no
external processing equipment required.
Power On Delay: The Power On Delay function automatically
varies the powering up of each display to reduce the load on the
power source.
ABL Link: The Auto Brightness Limiter Link function sets the brightness
display at a uniform level (operates only with 2x2 and 3x3 configurations).
Auto ID Setting: Automatically sets an ID for each display
Repeat Timer: This function allows the repetition of two settings.
For example, you the timer to display a video image on the full screen for
three minutes, a PC image divided into four screens for six minutes. This is
continuously repeated (operates only with 2x2 and 3x3 configurations).
connected via a combination control cable to permit simpler errorfree setting (operates only and 3x3 configurations).
Seamless Orbiter
Conventional orbiter modes reduce ghosting by moving the displayed image by one pixel at regular intervals.
Because viewers can notice the movement, it interferes with their viewing. The PDP-425CMX has an improved
Seamless Orbiter function, which moves the entire image in extremely small steps of less than a pixel. The most
effective orbiting pattern was adopted based on a variety of simulations, achieving the maximum possible
mitigation of ghosting without viewers noticing the process.
Conventional
Orbiter Mode
The entire image moves one or more
pixels at a time, easily noticeable in
meetings.
Conventional PDP
Seamless Orbiter Mode
The entire image moves in extremely small steps undetectable to the human eye. Three types of processing can
be selected to tailor the display s performance to the type of application and input — for example whether the
content is primarily still or video images.
PDP-425CMX
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
398
F L AT PA N E L D I S P L AYS
PIONEER
PDP-425CMX
High Performance
CONVENIENCES
◆ When a command is transmitted from a
control device to the PDP via the RS-232C
interface, the PDP returns its status. This not
only permits remote confirmation of current
PDP status, it can also specify the cause of
errors, should they occur, speeding up
service response. The PDP-425CMX provides
high control capacity - combination
connections, variable baud rate setting,
acknowledge function and more:
— Serial number information, Product model
name, Hour meter, Interior temperature
information, Power on/off information,
Input signal information, Cause of error
◆ Programmable timer can control designated
functions according to a schedule. Take
advantage of a convenient weekly timer and
seven programmable functions including
power on/off, input selection, and activation
of image burn-in reduction modes.
◆ The PDP-425CMX has a high performance
dual image processing function that switches
from one input image to another at the high
speed of approximately 0.4 seconds. This
ensures smooth, comfortable viewing of
displays at exhibition halls or event
venues and presentations in offices.
Five Pro modes allow image adjustment
for professional applications:
– Under-Scan: Displays input video signals without modification.
– Color-Off: Removes color information for optimum display of black and white signals.
– Still Image Processing: Suppresses movement to display still images accurately by
varying movement detection processing.
– Pure Image: Displays images as close as possible to the original signal with no image
processing except I/P conversion.
– High Contrast mode: Uses special dynamic range expansion to make images more vivid.
Numerous image burn-in alleviation modes:
– Side mask brightness adjustment: Adjusts side mask brightness during 4:3 image
display.
– White signal display: Displays white over the entire screen. This restores ghosted
locations to their former condition.
– Screen reversal display: Restores ghosting by reversing the colors of the area where
ghosting occurs.
– Soft focus: Blurs the edges of the image, making ghosting difficult to see.
Low power consumption and four energy saver modes:
This PDP-425CMX achieves the industry’s lowest
power consumption of 285-watts thanks to the
high light emission efficiency of the new Pure
Black Panel. Four energy saver modes contribute
to further low power consumption:
◆ Dual Image Freeze displays stills of new
images as small images Image Freeze
temporarily freezes a displayed image. The
still image can be the sub-image in P-in-P
mode or the left-side image in Side-by-Side
mode. You will find this function to be
convenient during presentations or
meetings.
Power Save, Intermediate, Linear Brightness, which
decreases the peak intensity of high-brightness images, and Auto Brightness Control,
which automatically adjusts panel brightness depending upon room lighting.
Additional Features
◆ Large GUI Display
◆ Frame Rate Conversion mode
◆ Display Call ◆ Point Zoom
◆ Intelligent Auto Setup
◆ Color Detail Adjustment
◆ Smart Cooling System
◆ Vertical and Left to Right Reversal Modes
◆ Priority Input Mode
◆ Layered Key Lock
◆ Retake Specialized Color Temperature
Switching Function
◆ OSD Off
PHOTO - VIDEO - PRO AUDIO
◆ LED Off
◆ Memory Lock
www.bhphotovideo.com
F L AT PA N E L D I S P L AYS
PIONEER
399
PDP-425CMX
Expansion Solutions
For the next-generation line of professional plasma displays, Pioneer offers a powerful
concept—Expansion Solutions. Imagine a display with Pioneer’s unprecedented image
quality, custom tailored to fit each unique installation minus all the extra boxes and
wires. These cutting-edge, open-architecture data and communications card-slot
solutions enable you to change functionality as your business needs evolve and grow.
Other manufacturers utilize proprietary technology that forces you to build your
concept around their constraints. Pioneer’s open-architecture card slots are integrated
right into all of the CMX models ranging from 42” to 50”, making it easy for third-party
card developers to develop customized cards to your exact specifications. And they
offer a wealth of extra features such as added security and monitoring capabilities.
The PDP-425CMX is designed to be ready for any type of application with the integration of two ES Card Slot interfaces, one for communication and
one for enhanced data. It comes supplied with a removable communication card that includes RS-232C and combination I/O interfaces. The second
slot may optionally be used to enable video capabilities through the input of a wide range of analog or digital signals, with additional control. This
means that one PDP-425CMX can be used for multiple tasks, including various applications that other PDPs can’t handle. You have extensive flexibility right out of the box, and it is also ready for additional needs that may arise in the future. Pioneer’s “Expansion Solutions” is just one more reason
why the PDP-425CMX is the first choice in professional plasma display.
PDA-5003
PDA-5004
BNC Connector Interface Card
RCA Connector Interface Card
Designed for exclusive use with Pioneer plasma
displays, the PDA-5003 enables the ability to
display high definition video through RGB/
component, S-Video and composite input
terminals. The plasma display has been originally
designed as a computer monitor, but by
installing the optional PDA-5003 video card,
the supplementary features are produced:
Enables the ability to display high definition video
through component, S-Video and composite input
terminals. The PDA-5004 is a video card designed
for exclusive use with the Pioneer plasma display.
The plasma display has been originally designed as
a computer monitor, but by installing the optional
PDA-5004 video card, the supplementary features
are produced:
◆ Allows use of additional input jacks (INPUT 3,4,5)
◆ Allows use of additional input jacks (INPUT 3,4,5)
supporting S-Video, composite video,
component video and analog RGB signals.
Communication Slot
supporting S-Video, composite video and
component video.
◆
Allows connection to a wide variety of optional
video and computer equipment.
◆ Allows connection to a wide variety of optional
◆
Has 3 video input connectors, video output
connector, and 2 audio input connectors.
◆ Has 3 video input connectors,
video equipment.
video output
connector, and 3 audio input connectors.
Video Slot
Pioneer Certified Third Party Expansion Solution Cards
Extron Electronics
Magenta Research
IP Link Interface Module (IPL M PDP-ES)
This compact
ethernet control
card enables
IP-based
remote control,
proactive monitoring, and troubleshooting.
MultiView AK1000PDP
Integrated Analog CAT-5 Receiver
Enables high
resolution
video
distribution
over CAT-5/UTP. Signals can be transmitted
over longer distances.
Alcorn McBride
HDSDI Digital Video Interface (PDP HDSDI)
Allows the
PDP to
connect
directly to
professional quality broadcast equipment or
any other device with SMPTE-292M and
SMPTE-259M output capability.
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
400
F L AT PA N E L D I S P L AYS
PIONEER
PDP-505CMX
50” WXGA Professional Plasma Display
The consummate professional plasma display, the
PDP-505CMX PureVision plasma offers Pioneer’s
First Surface Pure Color Filter, creating incredibly
lifelike images for digital signage that truly stand
out from ordinary displays. A fourth-generation
panel has true 30-bit processing and is ideally
suited for a wide range of professional and public
display applications.
Super sleek, this 50” display capitalizes on
Pioneer’s Expansion Solutions technology, giving
you the ability to insert a variety of expansion
cards in a slot at the bottom of the plasma to
change or enhance the capabilities of the display. Expansion cards are available from Pioneer as well as a variety of
third-party manufacturers to create custom display solutions.
F E AT U R E S
◆ Pioneer’s Pure Drive technology encompasses the
entire range of image generation and processing that
gives the PDP-505CMX its astoundingly clear, smooth
and natural color. Unlike other PDP systems, Pure
Drive maintains all signals in the digital domain,
which eliminates image transmission loss, reduces distortion, and provides a far greater degree of
control. An important step in this process is Pioneer’s
ACE III (Advanced Continuous Emission III) technology,
which uses 10-bit processing to create a palette of
over a billion hues for much greater color gradation
accuracy and detail, ensuring that data images are
perfectly clear.
◆ The cells of a plasma display panel, where light is generated, are the most
important factor determining image quality.
Pioneer has continually refined their cell
technology, which is called Deep Encased Cell
Structure. The latest version incorporates and
additional green fluorescent body material,
contributing to ultra-high contrast and
1,000dc/m2 brightness.
◆
First surface pure color filter improves display performance in well-lit environments,
which means most professional applications. The thin precision filter is bonded
directly to the glass panel covering the plasma cells. Not only does it reduce
reflections and improve contrast, but each color is precisely balanced as it passed
through, resulting in more accurate reproduction of all images.
First Surface Pure Color Filter
Pioneer’s plasma displays have become
the preferred standard for applications
including information visualization,
boardrooms, large area viewing command
control centers, information kiosks and
digital signage. Pioneer’s extensive
understanding of industrial displays,
leading edge product design and
manufacturing ability has gone into
producing the PDP-505CMX. This plasma
takes performance and flexibility to an
entirely new level by increasing brightness and color reproduction quality while also increasing reliability, operating ease and versatility.
PHOTO - VIDEO - PRO AUDIO
www.bhphotovideo.com
F L AT PA N E L D I S P L AYS
PIONEER
401
PDP-505CMX
Three Dual Picture Modes
High Performance
◆ With a native resolution of 1,280 x 768, this
high precision panel can accurately display
person computer signals ranging from 640 x
400 and 640 x 480 (VGA) to 1,024 x 768
(XGA) and 1,280 x 768 (WXGA). It is also
compatible with display resolutions of 1,280
x 1,024 (SXGA) and 1,600 x 1,200 (UXGA).
◆ Intelligent Auto Setup feature improves
both performance and convenience,
allowing image adjustment via the remote
control. This display incorporates a new
function, Auto Adjust, which detects the PC
signal and automatically adjusts the position
of the image, making it unnecessary to have
to push the Auto Setup button.
◆ Pioneer knows that colors are crucial to your
business. “Red” means a lot of different
things to different companies. Get red right
– or whichever colors you need to fine-tune
without affecting the other colors in the
picture using Pioneer's essential Color Detail
Adjustment feature.
◆
A number of functions can be locked,
making the display system more secure.
Lock modes are on/off, main unit buttons,
remote control, main unit buttons plus
remote control, and memory lock, which
selects input and volume default settings
when the unit is turned on.
◆ Having a GUI display is a definite advantage,
making operation considerably easier, but
if it is too small to see when the unit is
mounted, its usefulness is limited. However,
the PDP-505CMX models provides an
extra-large display, which is visible even
when the unit is mounted in a high location.
◆ Peak Pattern Detection System also helps to
prevent burn-in monitoring the prolonged
display of still images and the concentration
of brightness in any segment of the panel.
◆ The PDP-505CMXcan transmit various
information to a PC via the RS-232C port
using the Get Command, including power
on/off, input number, signal detection and
complete error data. This ensures that
remote monitoring is worry-free.
The PDP-505CMX offers a
choice of three Dual
Picture modes for
simultaneous display
of images for two
connected sources.
Split screen shows
two images side
by side, Picture-in
Picture superimposes a small picture over a full-screen picture in any of the four corners, and
Picture-Out-Picture displays the second image on the right side of the screen.
Enhanced Point Zoom and 2x2 Image Expansion
◆ The Enhanced Point Zoom
function lets you instantly
expand any portion of a PC
image in three steps (1.5x, 2x,
3x), great for emphasizing key
points in presentations. The
Zoom Area sub-display area
makes it easy to confirm the expanded portion.
◆ 2 x 2 Image Expansion mode
allows a 2 x 2 data wall using
four units without the need for
an expansion device. Two
display modes are available,
one that will enlarge all picture
elements so the entire picture
is visible, and one that enlarges the whole image so lines between units are not visible.
Conveniences
◆ The PDP-505CMX consumes only 360-watts of power while producing bright images. This is
extremely low for a 50” XGA-class plasma displays. Standby power is a mere 0.8W.
◆ In addition to the normal operating mode, the PDP-505CMX provides a choice of four
energy save modes that further reduce power consumption. These modes are: Power Save,
Intermediate, Linear Brightness which decreases the peak intensity of high brightness images,
and Auto Brightness Control which automatically adjusts panel brightness depending upon
room lighting.
◆ The PDP-505CMX employs powerful tools to manage burn-in. These include RGB separate full
mask, side mask brightness adjustment, Orbiter mode for one-pixel-at-a-time movement of
displayed images at fixed intervals, and Inverse mode that displays images as negative. Full
mask and Inverse can be controlled by the on/off timer via the Screen Management functions.
◆ In order to minimize downtime, the PDP-505CMX displays comprehensive error information.
Errors, their causes and part serial numbers are displayed and identified by symbols. In
addition, various numbers are indicated by the two front LEDs, so even if the display
malfunctions, the cause can be quickly identified and corrected.
◆ Smart cooling system with internal fans
◆ Pioneer’s plasma displays are the industry's first to receive the Windows Hardware Qualification
which are only activated when needed,
keeping fan noise to a minimum and
conserving power.
Labs (WHQL) certification of compliance. The PDP-505CMX continues this tradition by providing
Plug & Play drivers to support Microsoft Windows and other operating systems. This is a
display you can use with confidence.
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
402
F L AT PA N E L D I S P L AYS
PIONEER
PDP-505CMX
Expandable to Meet a Wide Variety of Present and Future Needs
The PDP-505CMX is designed to be ready for any type of application with the integration of two
ES Card Slot interfaces, one for communication and one for enhanced data. It comes supplied
with a removable communication card that includes
RS-232C and combination I/O interfaces. The second slot
may optionally be used to enable video capabilities
through the input of a wide range of analog or digital
signals, with additional control. This means that one
PDP-505CMX can be used for multiple tasks, including
various applications that other PDPs can’t handle. You
have extensive flexibility right out of the box, and it is also
ready for additional needs that may arise in the future.
PDA-5003
BNC Connector Interface Card
The PDA-5003 gives the PDP-505CMX the ability
to display compelling high-definition video
through RGB/component, S-Video and composite
input terminals. This card can use additional
input jacks (INPUT 3, 4, 5) supporting S-Video,
composite video and component video. It can also be connected to a wide variety of optional
video equipment.
PDP-S05-LR
Optional Side-Mount Speakers
2-way speaker with a dome tweeter and a
newly designed perpendicularly installed oval
unit. These speakers are compact, yet deliver
wide-range performance. Maximum output is
12-watts/8 Ohm. They weigh 4 lbs. each.
DK-TS01Tabletop Stand
This tabletop stand is for desk or boardroom
installations (for PDP-425CMX or PDP-505CMX)
PDA-5003
BNC Connector
Interface Card
Double-sided
Ceiling Adapter
(PCA-2)
PDA-5004
RCA Connector
Interface Card
PDA-5004
RCA Connector Interface Card
The PDA-5004 gives the PDP-505CMX the ability
to display compelling high-definition video
through component, S-Video and composite
input terminals. This interface card can use
additional input jacks (INPUT 3, 4, 5) supporting
S-Video, composite video and component video.
It can also be connected to a wide variety of optional video equipment.
Pioneer Certified 3rd Party Expansion Solution Cards
Extron Electronics IP Link Interface Module (IPL M PDP-ES)
This compact ethernet control card enables IP-base remote control, proactive monitoring,
and troubleshooting.
Magental Research Integrated Analog CAT-5 Receiver (MultiView AK1000PDP)
Enables high resolution video distribution over CAT-5/UTP. Signals can be transmitted over
longer distances.
Alcorn McBride HDSDI Digital Video Interface (PDP HDSDI)
Connects the PDP directly to professional quality broadcast equipment or any other device
with SMPTE-292M and SMPTE-259M input capability.
Adjustable Height
Suspension
Adapter (PSA-1)
Double-sided
Ceiling Adapter
(PCA-1)
Adjustable Height
Suspension Adapter (PSA-2)
Suspension and Ceiling Adapters
Adjustable Height Suspension Adapter (PSA-1)
Adjustable Height Suspension Adapter (PSA-2)
112⁄ ” NTP Single-sided Ceiling Adapter (PCA-1)
2” NTP Double-sided Ceiling Adapter (PCA-2)
Wall Mount Brackets
Tilt Wall Mount Bracket (PIPWM503) ............449.95
Flat Wall Mount Bracket (PDWB-503) ...............CALL
PHOTO - VIDEO - PRO AUDIO
www.bhphotovideo.com
F L AT PA N E L D I S P L AYS
PIONEER
403
PDK-50HW3
Plasma Touch Screen Device
The ideal tool for effective presentations, kiosks,
meetings and many other applications. Plasma
display panels are a great way to present digital
information, and now there’s another powerful tool
that makes them even more effective. Use the
PDK-50HW3 device plus touch screen software to
turn the Pioneer 50” PDP-505CMX professional
plasma into a touch-screen monitor—just touch it to
call up a wide variety of information, using a finger
or the dedicated pen (included) to write or draw
right over content shown on the screen. You can
add comments, highlight information, cross out
parts, make changes, and so on. The PDK-50HW3
features a quicker response, newly designed pen, USB 1.1 connection for communication and operating, easy single cable
setup, and redesigned appearance.
No Calibration Required
Presentations/Meetings
The PDK-50HW3 is highly reliable and holds its
own without calibration or drifting. The pen
coordinates do not slip, even when moved or
used for extended periods of time, making
this device ideal for use as a permanent installation in shops, public facilities and other high
traffic locations.
Make presentations and meetings more interactive and effective by controlling your software
applications with just a touch. When used with commercially available annotation and handwriting software, comments, arrows and circles can be used to emphasize important points as you
speak. Jot down opinions and comments expressed during a meeting or teleconference just like
using a whiteboard.
Easy Installation, Flexible Layout
Although a very sophisticated device, it is surprisingly easy to install. Installation area is
equivalent to that of the PDP-505CMX. Plus
it's lightweight—the total weight of the
device with pen stand is only 15 lbs. Simply
connect to the data source devices via the USB
1.1 cable. Mobile cart, wall-mount and ceilingmount installations are also available
High-Speed
Infrared Scanning System
Worried that using a touch screen device will
interfere with clarity? Stop worrying and start
presenting because the PDK-50HW3 doesn’t
cover the PDP surface. It features a high-speed
infrared scanning system that doesn’t interfere
with bright, clear PDP images. PDP surface
isn’t covered, thus no luminance degradation,
focus blurring parallaxing occurs. High-speed
response function supports the needs of most
handwriting input systems. Offers resolution
above WXGA (1280 x 768).
Promotions/Information Board
The touch panel device allows a Pioneer 50” professional plasma display to be utilized as an
interactive information board. Set it up as an information kiosk, allowing users to access a wealth
of content simply by touching the screen.
Microsoft Windows OS Driver Software
Microsoft Windows OS driver software enables optimal,
high-speed management of scanned coordinate data
and easy operation of various applications via pen or
finger-based input using only a USB 1.1 connection.
In addition to the recommended resolution of 1280 x
768, projection of resolutions from VGA to UXGA is
also possible.
MOUNTING
OPTIONS
Dedicated Pen Included
Choose the marking option that is most
comfortable for you. Finger-touch operation
is an easy way to go; a dedicated pen is also
provided to capture sudden flashes of
inspiration naturally. It's intuitive so you
can keep up with your thoughts. The pen
incorporates a mouse button feature
(left, right, middle), allowing it to be used
for the operation of various PC applications.
PDK-5011
Hang-on
Wall Unit
PDK-5012
Ceiling Mount Kit
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
404
F L AT PA N E L D I S P L AYS
PIONEER
PDP-614MX
61-inch WXGA Professional Plasma Display
There are many plasma display choices for professional and public display applications, but the
PDP-614MX is the best choice for three reasons:
what you see, what you don’t see and what’s
inside. What you see is an enormous 61˝ display
with with image clarity that is exceptional and colors that are rich and natural. What you don’t see
are artifacts and distorted images. What’s inside
are advanced technologies that maintain this high
image quality for extended monitor life and a wide
range of of useful functions for outstanding control and convenience.
The PDP-614MX measures a full 61˝ for big ideas
that need room to glow. PureVision™ technologies ensure the image you project comes to life with rich color and intense
clarity. A wide range of useful functions enable outstanding control and convenience.
F E AT U R E S
Superior Image Processing Technology Quality
High Image Quality
◆ The PDP-614MX uses a precisely engineered
CCF (Capsulated Color Filter) that decreases
light reflection for better view ability and filters out unnecessary elements in the red,
green, and blue light for true color reproduction. Skin tones, for example appear more
natural because the filter is designed to
reduce the orange tint present in the red
color range. All images, even fast-moving
ones, will be accurate, crisp and natural.
◆ Black Stripe inhibits the reflection of outer
light and enhanced contrast to ensure that
dark colors remain crisp and clear, even in
bright settings.
◆ The PDP-614MX’s Encased Cell Structure fea-
ture a larger phosphor surface area that prevents light leakage from neighboring cells.
Luminous efficiency is higher, so the screen
is brighter, and subtle details are enhanced.
◆ Colors are crucial to your business. “Red” can
mean a lot of different things to different
companies. Get red right—or whichever colors you need to fine-tune-without skewing
the other colors in the picture—using the
Color Detail Adjustment feature.
◆ Point Zoom
function lets you expand any
portion of a PC or video image from 1x to 9x
in 64 steps.
PHOTO - VIDEO - PRO AUDIO
◆ From input to output, through all processing steps, the video signal remains in the digital
domain. This ensures noise-free, no-loss processing of a variety of inputs from video to PC,
allowing the highest possible signal quality.
◆ For precision, four gamma modes allows for
a more accurate display of the tone gradations, even for images with low lighting.
◆ Scan converts input signals with high sam-
pling accuracy so even minor details such as
small letters are sharp and clear.
Video Wall Capability
Easy to configure multi-monitor video
walls. Possible configurations are 2x2,
3x3, 4x4 and 5x5. Two display modes
are available, one that enlarges all
picture elements so the entire picture
is visible and one that enlarges the
whole image so lines between units
are not visible. Other functions
include Power On Delay to reduce initial power load, ABL Link for aligning
monitor brightness in multi-monitor
displays and Auto ID Setting.
Conveniences
◆ ABL (Auto Brightness Limiter) Lock provides three selectable modes to reduce power consump-
tion when desired. Modes to manage image burn-in include Orbiter (moves image one pixel at
a time), Inverse (displays image as negative), Full Mask (white) and others.
◆ Timer function features a convenient Weekly Timer and the following programmable functions:
power on/off, input selection, activation of image burn-in management modes.
www.bhphotovideo.com
F L AT PA N E L D I S P L AYS
PIONEER
405
DVD-7400
Professional DVD/CD Player
A professional DVD/CD player, the DVD-V7400 is ideal for a variety
of professional and industrial applications, including in-store sales
promotions, education, corporate training, museums and exhibitions,
video walls, trade shows and public presentations. Take a closer
look and you’ll be amazed at what this DVD-Video player can do
for your business.
To ensure easy operation, all major functions can be accessed via
wireless or optional wired remote. In addition, most user interface functions,
such as on screen menu buttons, can be accessed via a standard PS/2 mouse which connects directly to the front panel of
the player. For added convenience, it is compatible with with DVD Barcode and Laser Barcode control systems, as well as
NTSC and PAL video standards
F E AT U R E S
◆
Compatibility with both NTSC and PAL video
standards. The following disc formats and
disc media formats are supported:
◆ RS-232C port
enables connection to an
external computer or custom controller. The
player’s mnemonic command protocol is
backward compatible with Pioneer's other
industrial LaserDisc and DVD-Video players.
This compatibility makes it possible to use
LaserDisc control programs with little
revision and to control features unique to
DVD, such as multi-angle and sub-picture.
— Multiple Disc Formats: Video CD, CD-DA,
DVD-Video, DVD Hybrid (DVD-Video
segments)
— Multiple Disc Media: CD-R, CD-RW, DVD-R
— The player also adds component video and
DTS audio stream outputs to the host of
other hardware connections.
◆
video output (BNC), two composite video
outputs (BNC/RCA) and S-Video connector.
Connect a standard PS/2 mouse directly to
the front panel of the player, and users can
perform a variety of operations including
menu selections (during DVD video playback), player control and set up, similar to
operating a computer with a mouse.
◆
◆ The DB-15 computer connection provides
additional signal lines that allow simple
external switches to select DVD menu items
or execute Barcode Stack/Command Stack
functions. For example, with a simple contact closure switch, 70 separate commands
including Play, Pause, etc., can be performed.
Get sophisticated custom control from a
simple and inexpensive user input device.
◆
Weekly Timer function lets you simultaneously set the player's On/Off times and set
particular video segments for playback on
each day of the week. For added flexibility,
the timer memory can accommodate up to
24 events per week. Users can distribute the
commands throughout the week as required
by their specific application.
◆
The player can immediately display the DVD
disc’s first-play menu upon powering up –
ideal for exhibits, point-of-purchase &
information, and retail display applications.
◆
It can track user selections and store the
data in the player’s non-volatile flash RAM.
The data can then be retrieved to evaluate
user selections and preferences. This feature
is perfect for kiosk and point of purchase
and information installations.
◆
For extra flexibility, users can operate the
DVD-V7400 using the wireless remote
control accessory or the optional wired
remote control unit.
◆
The DVD-V7400 has a small foot-print and
takes up little space on a desk, shelf or store
counter. For multiple player installations,
two players will fit side-by-side in a standard
rack system. It weighs 10 lbs. and measures
8 14⁄ x 4111⁄ 6 x 16 11⁄ 6” (WHD).
control can be achieved by scanning printed
barcodes with the optional barcode reader.
◆ Hardware connections include component
◆
An external black burst sync signal can be
applied and looped through the EXT SYNC
IN/OUT terminals to enable clean switching
with other video sources and frame
synchronization when using multiple players.
◆ With DVD Barcode, video and audio playback
◆ Designed for the high level of durability that
industrial applications demand. Equipped
with a high-performance brushless spindle
motor combined with a heat and dust resistant enclosure for use in tough environments.
◆
◆
The DVD-V7400 supports X-Y coordinate
RS-232 commands that allow it to be directly
connected to special touch screens (available
through 3rd party developers). This feature
makes the DVD-Video player with touch
screen integration a reliable and cost-effective interactive display for use in museums,
art galleries, shopping malls or hotels.
Advanced frame search function offers the
precision of random access, frame accurate
search required in many industrial applications. Moreover, all frame search operations
are completely seamless with the player's
expanded video buffer.
Barcode Stack/Command Stack function lets
you save play lists into RAM (up to 300
command lines, organized in up to 150
groups) for automatic recall and display.
Playback of single commands or stacks of
several linked commands is possible. Users
can input command sequences via remote
control, barcode reader or RS-232c control.
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
406
F L AT PA N E L D I S P L AYS
SAMSUNG
LN-S SERIES
26-, 32-, 40- and 46” LCD Flat Panel TVs
Slim, light and beautiful, Samsung’s LCD Flat Panel TVs combine
sleek looks and high performance. Consisting of the LN-S2651D
(26”), LN-S3251D (32”), LN-S4051D (40”) and LN-S4692D (46”),
these widescreen LCD HDTV sets let you display HDTV images from
any high-definition source.
They feature 4000:1 dynamic contrast ratios and a fast response
time (12ms) for superb picture
playback and color vibrancy
on a 16:9 screen. Even highspeed sports remain clear-cut,
thanks to Samsung’s ultra-fast
switching technology.
Samsung’s Patterned Vertical Alignment (PVA) screens provide high contrast and
brightness for lifelike images with realistic colors and outstanding detail.
The LN-S Series of flat panel TVs offer a 170° viewing angle. They have hidden
bottom speakers that produce deep, rich SRS TruSurround XT sound to deliver a
superb audio-visual experience. They are versatile, as well, with two HDMI inputs
that allow connectivity to a wide range of digital devices, including digital
satellite/cable boxes, camcorders, HD-DVD up converters and more.
F E AT U R E S
DNle —Digital Natural Image Engine
Advanced Picture Quality
Samsung's revolutionary DNle technology offers digital perfection in
naturally presented, crystal-clear images that uncover even the most
minute detail.
◆
Dynamic Contrast 4000:1— Samsung’s PVA screen enables brighter
whites, deeper blacks and every shade in between. Its higher contrast
ratio provides an abundant palette of perfect colors.
◆ Motion Optimizer—
◆
Samsung’s 10-bit processing method produces billions of lifelike colors
to ensure a more natural and vivid picture and aids in video signal
processing of analog sources.
◆
To the left, to the right, even upside-down, Samsung’s 178° vertical and
horizontal wide-viewing screen solution ensures easy viewing from any
angle.
◆
Progressive scan virtually eliminates the flicker that you see on traditional,
interlaced scanning TVs. The LN-R series display progressive scan signals
with ease from DVD players and HDTV decoders.
Fast-moving images are optimized to produce
more natural-looking motion, thus reducing video noise or blurring.
◆
Contrast Enhancer— Brightness and contrast levels are enhanced
for deeper, richer blacks with greater detail and more natural
whites.
◆ Color Optimizer— Colors are reproduced with a more lifelike
realism, whites are more accurate, and skin tones are given a more
natural hue.
◆
Detail Enhancer— DNIe analyzes video signal elements to produce
sharper detail, clearer image separation, and more natural edge
transition.
◆ My Color Control—
Samsung’s patented “My Color Control”
technology lets you control specific colors without affecting the
whole screen. Samsung provides six-color control selections: white,
red, pink, yellow, green and blue. It’s your picture - you decide.
PHOTO - VIDEO - PRO AUDIO
www.bhphotovideo.com
◆ High resolution 1366 x 768 pixel density with built-in image scaler to
handle inputs from a variety of digital and analog audio/video sources.
◆
3D Y/C digital comb filter constantly analyzes the 3 dimensions of picture
height, picture width, and picture changes over-time, to dramatically
reduce edge image artifacts while improving transition detail.
F L AT PA N E L D I S P L AYS
407
SAMSUNG
LN-S SERIES
Easy Connections
◆
HDMI connection allows for the transmission
of both video and audio digital signals
through a single connection for higher
quality and fewer wires.
◆ Connect
DVD/DTV sources with two smart
component video inputs that accept
480p/720p/1080i signals. They can also
function as PC monitors.
Panel:
Pixel Resolution (HV)
Dynamic Contrast Ratio
Viewing Angle
Channel coverage
Surround Sound
◆
◆
◆
High-quality surround sound can be
experienced with just the speakers built into
the TV. SRS TruSurround XT technology
delivers an amazing, simulated 3-D effect
with clear dialog and powerful bass.
The interior hidden speaker system with
DACS (Dual Acoustic Chamber System)
simulates dual separate chambers for each
speaker to maximize low-range-sound
performance and enhance sound clarity.
Auto volume leveler keeps audio volume
consistent during channel changing.
◆
Samsung’s LCD panels have up to 60,000
hours of lamp life.
◆
Built-in brightness sensor automatically
detects the ambient light and adjusts the
TV’s luminance accordingly.
◆
Picture-in-picture (PIP) enables convenient
simultaneous viewing of TV programs and
video or PC sources.
◆
Swivel stand (on 40-and 46” models) provides a ±15° swivel. This convenient feature
makes it easy to move the screen without
lifting or moving the television.
◆
◆
◆
All except the LN-S2651 offer side A/V ports
to provide easy connections so you can
connect a camcorder, digital camera, or any
other digital device with no hassles.
Removable stand and VESA compatible hole
mounts let you install them on a wall. Easily
remove the stand and use a VESA compatible wall mount to safely and stylishly attach
them to the wall.
LN-S3251D
LN-S4051D
LN-S4692D
Wide (16:9) LCD
Wide (16:9) LCD
Wide (16:9) LCD
Wide (16:9) LCD
1366 x 768
1366 x 768
1366 x 768
1366 x 768
4000:1
4000:1
4000:1
5000:1
170°(H) / 170°(V)
178°(H) / 178°(V)
178°(H) / 178°(V)
178°(H) / 178°(V)
VHF 2-13, UHF 14-69,
UHF 14-69,
CATV 1-125
(up to 18 preselected channels)
VHF 2-13, UHF 14-69,
UHF 14- 69,
CATV 1-125
(up to 18 preselected channels)
VHF 2-13, UHF 14-69, VHF 2-13, UHF 14-69,
UHF 14-69,
UHF 14-69,
CATV 1-125
CATV 1-125
(up to 18 pre(up to 18 preselected channels)
selected channels)
75-ohm Antenna
CATV/VHF/UHF
CATV/VHF/UHF
CATV/VHF/UHF
CATV/VHF/UHF
VESA compatible
100 x 200
200 x 200
200 x 200
600 x 400
8ms
8ms
8ms
8ms
Response time
AU D I O
Speaker System
Watts per channel
SRS TruSurround XT
Conveniences
LN-S2651D
“Hidden” bottom
“Hidden” bottom
“Hidden” bottom
“Hidden” bottom
speakers with D.A.C.S. speakers with D.A.C.S. speakers with D.A.C.S. speakers with D.A.C.S.
(Dual Acoustic
(Dual Acoustic
(Dual Acoustic
(Dual Acoustic
Chamber System)
Chamber System)
Chamber System)
Chamber System)
5w x2
✓
10w x2
10w x2
10w x2
✓
✓
✓
CO N N E C T I O N S
HDMI
2
2
2
2
2 (air/cable)
2 (air/cable)
2 (air/cable)
2 (air/cable)
Component Video
Input (Y,Pb,Pr)
(480i/480p/720p/1080i)
1
1
1
2
S-Video input
1
1
2
2
R/F input
Composite video input
1
1
2
2
PC (RGB) input
1
1
1
1
Sound monitor out
1
1
1
1
Optical sound out
1
1
1
1
Stereo headphone jack
1
1
1
1
RS232C
1
1
1
1
N E T D I M E N S I O N S A N D W E I G H T (WxHxD)
Monitor without stand
Monitor with stand
Stylish design creates a look for any room.
Piano black finish and rounded corners give
these TV unmatched style.
Weight
◆
Multi-lingual on-screen displays in English,
Spanish or French.
Dimensions:
◆
Clock on/off timer as well as variable sleep
timer to turn the TV off in varying time
intervals.
26.6 x 18.7 x 3”
31.5 x 21.6 x 3.1”
39 x 25.9 x 3.4”
44.3 x 29.6 x 5.5”
26.6 x 20.9 x 8.5”
31.5 x 23.7 x 9.9”
39 x 28.1 x 12.8”
44.3 x 32.2 x 14.2”
22.3 lbs.
32.6 lbs.
50.3 lbs.
81.6 lbs.
SHIPPING DIMENSIONS
Weight
Warranty
30.5 x 25.6 x 8”
36.0 x 29.3 x 8.3”
43.7 x 32.5 x 16.1”
49.2 x 38.2 x 17.7”
30 lbs.
44.1 lbs.
66.6 lbs.
103.6 lbs.
1 year
parts and labor
1 year
parts and labor
1 year
parts and labor
1 year
parts and labor
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
408
F L AT PA N E L D I S P L AYS
SAMSUNG
HPS-4253 • HPS-5053
42- and 50” Widescreen HD Plasma TVs
Samsung’s 5th generation plasma panels combine with
a proprietary electronic chassis design, and incorporate
the latest DNIe picture enhancement circuitry to deliver
outstanding brightness, contrast and overall picture
clarity. Samsung’s high-quality smoothing technology
delivers a more pleasurable viewing experience —even
at a 175° angle.
Everything you’ll need in an HD (High Definition)
plasma flat panel TV is here - 10,000:1 contrast ratio,
13-bit processing, and 60,000-hour panel life. Two HDMI
connections and additional video inputs allow full digital
A/V playback; hidden speakers incorporate SRS Tru
Surround XT technology to maximize the audio effect.
All this performance and convenience in a package that is less than 4” deep.
F E AT U R E S
Video
◆ To reproduce natural images, they
incorporate 13-bit processing to produce
over 549 billion colors and over 64,000
shades of gray. From the faint sunlight of
dawn to the extreme spotlights of a fashion
show, they provide vivid, life-like images
that literally rival reality.
◆
High Performance
Two of the most important factors in overall
picture quality, the contrast ratio (10,000:1)
and brightness levels (1300 cd/m2) achieve
new heights in these latest plasma panels.
◆ Built-in HDTV tuner (ATSC/NTSC) with split
screen & PIP (small, large, double). Built-in
analog tuner allows you to connect an analog RF signal cable directly to the set and
watch “regular” TV right out of the box.
◆ 1024 x 768 (HP-S4253) and 1366 x 768
(HP-S5053 pixel resolution presents video &
text with outstanding clarity and resolution.
DNle —Digital Natural Image Engine
◆
Color Tone modes include: Normal, Cool1,
Cool2, Warm1, Warm2
◆
Picture modes include: Standard, Dynamic,
Custom and Movie
◆ 16:9 widescreen lets you fill you screen
Samsung’s exclusive DNIe technology dramatically improves the picture by enhancing
contrast, detail, white balance and reducing noise. It offers digital perfection in naturally
presented, crystal-clear images that uncover even the most minute detail.
Motion Optimizer: Fast-moving images are optimized to produce more natural-looking
motion, thus reducing video noise or blurring.
with DVD and HDTV images. On-board
aspect ratio controls also handles analog 4:3
sources in standard, wide screen, panorama
and zoom modes.
◆ 3D Y/C Digital Comb Filter constantly ana-
lyzes the three dimensions of picture height,
picture width, and picture changes overtime, to dramatically reduce edge image
artifacts while improving transition detail.
Contrast Enhancer: Brightness and contrast levels are enhanced for deeper, richer blacks
with greater detail and more natural whites.
Color Optimizer: Colors are reproduced with a more lifelike realism, whites are more
accurate, and skin tones are given a more natural hue.
Detail Enhancer: DNIe analyzes video signal elements to produce sharper detail, clearer
image separation, and more natural edge transition.
My Color Control: Allows you to adjust the individual colors of your set without distorting other colors. The range of color adjustment includes Red, Green, Blue, Yellow, Red and
White. This ensures true to life colors such as green grass, blue sky and realistic skin tones.
White Tone Enhancement also ensures the purest, brightest whites possible. DNIe with
“My Color Control” gives A/V presenters a powerful tool for customizing their picture.
PHOTO - VIDEO - PRO AUDIO
www.bhphotovideo.com
◆ With 60,000 hour panel life, Samsung’s 5th
generation panels are made to last longer,
so you can be confident that the high
picture quality will endure.
◆
Burn-in resistant panel with:
— Auto pixel shift (user programmable)
— Signal pattern processing function
— White screen processing function
F L AT PA N E L D I S P L AYS
SAMSUNG
409
HPS-4253 • HPS-5053
Audio
HPS-4253
◆ SRS TruSurround XT is a patented SRS tech-
nology that solves the problem of playing
5.1 multichannel content over two speakers.
TruSurround delivers a compelling, virtual
surround sound experience through the two
speaker internal playback system.
◆ They incorporate integrated speakers for
ease of use and beautiful design. Home
theater enthusiasts can use an An external
audio system can also be used if desired, for
full multi-channel audio effect.
◆
Powerful built-in amplifier to drive the
integrated stereo speakers.
◆
Sound modes include: Standard, Custom,
Music, Movie and Speech
◆
Closed Caption displays dialog that can be
read along with encoded broadcast TV
programs and pre-recorded videos.
Connections
Rear A/V Connections:
— 2 HDMI – High Definition Multimedia
Interface
— 2 component video inputs (Y,Pb,Pr)
— S-Video and composite video input
Monitor with speakers: 41.5” x 28.1” x 3.8”
With speakers and stand: 41.5” x 30.1” x 13.4”
Monitor weighs 88.2 lbs.
HPS-5053
Monitor with speakers: 48.3” x 31.6” x 3.8”
With speakers and stand: 48.3” x 33.3” x 13.4”
Monitor weighs 108 lbs.
PPM42M5H • PPM42M5H • PPM50M5H
42- and 50” Plasma Displays for PRO A/V and
Commercial Applications
Samsung’s professional plasma monitors
are ideal or digital signage, financial,
multimedia presentation and professional
audio and video applications. They offer
high brightness of 1,100 cd/m2, and a
super-high 10,000:1 contrast ratio for
whiter whites, blacker blacks and greater
shadow detail. In order to achieve the
super-high contrast ratio, Samsung has
developed an exclusive octal plasma pixel structure that increases the electrical
separation between the pixels. This reduces the tendency for one pixel to influence the
adjacent pixel, which increases the contrast. Samsung has also chosen a high-Xenon
gas, which is up to 50% more efficient in generating brightness.
◆ The 42” PPM42M5H features 1024 x 768 resolution and is true high-definition by matching
— PC (RGB) input
the 720p HDTV format without the need for processing. The more economical 42” standarddefinition PPM42M5S incorporates a 852 x 480 resolution. The 50” PPM50M5H is ideal for
use in presentation and digital signage applications and sports a 1366 x 768 resolution.
Side A/V Connections:
— S-Video and composite video input
◆ They offer a host of advanced features to ensure outstanding image quality and
— Headphone jack
performance. All models include:
Conveniences
◆ Fanless cooling
– Picture-in-Picture and Picture-by-Picture functionality that is ideal for videoconferencing
and a built-in processor for “tiling” displays in a 2 x 2, 3 x 3, 4 x 4, 1x 5 and 5 x1 configuration,
making them perfect for video wall applications.
for low noise operation
◆
FilterBright anti-glare filter
◆
Power save feature
– They can be mounted either horizontally or vertically.
◆ Trilingual on-screen displays
– For an array of display options, they feature variable aspect ratios with six separate modes
including 16:9 and 4:3, and a 10x digital zoom and pan control.
◆ HDMI interface allows for the transmission of
◆ Advanced anti-burn technologies include Auto Pixel Shift that keeps the images moving
both video and audio digital signals through
a single connection for higher quality and
fewer wires.
◆ Control all your Samsung A/V components
through a single TV remote with Samsung’s
Anynet. A network control solution for operating Samsung devices, Anynet allows you
to control key functions of the A/V devices
connected to your TV via on screen menu.
Many Samsung components now feature
Anynet.
imperceptibly and Samsung’s Always White technology combines with its Signal Pattern
Process to eliminate electrically charged residual images.
◆ They feature an array of signal inputs for direct hook up to nearly any video source. Each
includes inputs for composite and S-Video, component video that offers 480i/p, 720p and
1080i viewing, DVI for digital video sources and an RGB input for use with a PC.
◆ Additional features include multi-standard (PAL, SECAM, NTSC 3.58, NTSC 4.43), 3D comb
filter, selectable color temperature, selectable picture mode, Multiple Display Control
(RS232C), display power management signaling, digital NR, progressive scan, variable
aspect ratio, clock and clock phase adjustment, on/off timer, digital zoom and picture freeze.
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
410
F L AT PA N E L D I S P L AYS
SHARP
AQUOS LCD TVs
AQUOS LCD TVs capture attention with incredible image quality, uniquely sculpted style and contemporary design.
AQUOS not only changes the way you’ll look at television, but also the way television looks. These award-winning
TVs offer an elegant alternative to traditional CRTs, and make dramatic statements about your lifestyle. Whichever
model you choose, AQUOS TVs redefine what’s possible in home entertainment.
A WHOLE NEW PERSPECTIVE ON TELEVISION
From the sleek contemporary design, to the startling clarity of the LCD
panel, AQUOS will enhance every aspect of your television experience.
13”, 15” and 20” sizes allow you to bring amazing television into every
corner of your home. Plus all AQUOS offer component video, S-Video,
composite video and RF inputs. And that’s just the beginning.
LONG-LIFE BACKLIGHT SYSTEM
A redesigned backlight system minimizes light loss, providing a long
lamp life of about 60,000 hours (when used continuously in a room
at 25°C and in standard lighting conditions and brightness). AQUOS
Liquid Crystal Televisions also feature an Auto-Save function that
automatically adjusts the brightness of the backlight to match ambient
light conditions, contributing to further energy savings.
EARTH-FRIENDLY DESIGN
Thanks to their compact size, AQUOS TVs require fewer parts and
less packaging than conventional CRT televisions. The main unit
employs non-halogen materials and lead-free solder, while the
base stand is made of 30% recycled materials. The entire unit
disassembles easily and uses unified grades of non-combustible
materials for easier recycling. Sharp has eliminated the use of
polystyrene packaging and molded parts that contain vinyl
chloride, further reducing the burden on the environment.
LOW POWER CONSUMPTION
AQUOS TVs consume 30 to 50% less than comparably sized CRT
televisions, which not only makes them more economical, but also
contributes to the reduction of global CO2 emissions.
DV20U Series
20-and 26”16:9 LCD TV/DVD Combo’s
Slim and versatile space-saving solutions, the DV20U series are widescreen LCD
TV/DVD combination units that combine Sharp’s superior LCD TV performance
with the rich, true-to-life color output of a progressive-scan DVD player. They
feature built-in NTSC/ATSC/QAM tuners, HDMI and an HD component input for
simple, versatile set-up and high-definition compatibility when connected to a
separate set-top box. With true 16:9 (1366 x 768) resolution, the DV20U series is
capable of displaying 1080i and 720p high-definition signals.
Both models feature a high contrast ratio (800:1) for rich black tones and crisp
images. These units feature 170° viewing angles so they can be viewed clearly
from almost anywhere in a room, and high brightness levels for clear, vibrant
pictures and true-to-life color clarity in any lighting conditions. Because of Sharp’s
proprietary Advanced Super View (ASV) panel with “Black TFT” low-reflection coating, the units
can be placed near doors, windows or other light sources and still display a clear, vivid picture.
◆
True 16:9 aspect ratio (1366 x 768) LCD panel
displays widescreen programs without the
need for scaling or other video processing.
◆
170º/170º viewing angles let you view the
TVs from almost anywhere in the room!
◆
Built-in side-loading progressive scan DVD
player is the ultimate in convenience!
PHOTO - VIDEO - PRO AUDIO
◆ With high brightness
of 450 cd/m2 you can
put them anywhere – even near windows,
doors or other light sources – and their picture is still vivid.
◆
Built-in NTSC tuner (LC-20DV20U) and,
ATSC/QAM/NTSC tuners for DTV and analog
TV viewing (LC-26DV20U).
www.bhphotovideo.com
◆
HDMI input for convenient connection to
digital devices.
◆
800:1 contrast ratio provides incredible
images whether you’re watching dark or
bright scenes
◆
8ms response time ensures you enjoy all fast
motion video without blurring or delay.
F L AT PA N E L D I S P L AYS
411
SHARP
LC-15S5U • LC-20S5U
15- and 20” AQUOS 4:3 Enhanced Definition LCD TVs
Available in 15- and 20” screen sizes, the S5U Series offers exceptional
picture clarity and brightness in a sleek body, bringing superior LCD
performance to any room in the house.
The LC-15S5U (15”) and LC-20S5U (20”) have fixed bottom speakers
and a silver finish with black side trim, making them ideal for a
variety of rooms. They feature a Black TFT/Advanced Super View VGA
(640 x 480) panel that brings movies and television broadcasts to
life, and 480p compatibility for viewing progressive DVDs in
true-to-life color and clarity. The S5U series includes Optical
Picture Control (OPC) for automatic brightness adjustment to
accommodate a room’s lighting conditions. Both feature NTSC,
PAL and SECAM video playback capability, HD compatible input
and a high brightness level of 430 cd/m2 (15”) and 450 cd/m2 (20”),
so the picture can be seen clearly in any lighting environment.
F E AT U R E S
◆
◆
They provide a unique, versatile solution for
home installation. Their stylish yet simple
design, with speakers placed below the LCD
screen, makes them much narrower than
side-speaker models. This enables them to
fit into many places throughout the home,
all without sacrificing any features.
They incorporate Sharp’s proprietary ASV
(Advanced Super View) LCD Panel with Black
TFT low reflection coating to effectively
reduce screen glare caused by indoor lights
and sunlight.
◆
Built-in 181-channel tuner allows you to
plug your cable TV line right into the TV and
start watching.
◆
They are very bright, so you can put them
anywhere — even near windows, doors or
other light sources — and their picture will
still be vivid.
◆
◆
◆
480p (EDTV Monitor) compatibility enables
compatibility with progressive DVD players.
500:1 contrast ratio provides incredible
images whether you’re watching dark or
bright scenes!
170º/170º viewing angles are so wide that
you can view the TVs from almost anywhere
in the room!
◆
They include an easel-style table stand that allows the TVs to occupy an amazingly small
footprint. In addition, the stand is easily removed for wall mounting applications (VESA 100mm
standard mounting pattern and are compatible with a wide range of brackets.
◆
Sharp’s LCD backlight life is long enough (60,000-hour lamp life) to give you viewing pleasure
for many years.
LC-20DV20U
LC-26DV20U
LC-15S5U
LC-20S5U
B&H Number
SHLC20DV20U
SHLC26DV20U
SHLC15S5U
SHLC20S5U
Screen
20” ASV Black
TFT LCD panel
26” ASV Black
TFT LCD panel
15” ASV Black
TFT LCD panel
20” ASV Black
TFT LCD panel
1366 x 768
1366 x 768
640 x 480
640 x 480
Audio System
5W + 5W
5W + 5W
2.1W + 2.1W
2.1W + 2.1W
Contrast Ratio
800:1
550:1
500:1
500:1
Number of Pixels
HDMI In
HD Component Input
S-Video Input
Composite Video Input
Audio In
RF In
Composite Out
Audio Out
Cabinet Color
Dimensions* (WHD)
Weight*
HDMI x 1
HDMI x 1
—
—
Y/Pr/Pb x 1
Y/PB/PR x 1
Y/PB/PR x 1
Y/PB/PR x 1
4-pin DIN x 1
4-pin DIN x 1
4-pin DIN x 1
4-pin DIN x 1
RCA x 2
RCA x 2
RCA x 2
RCA x 2
RCA L/R x 4
RCA L/R x 4
RCA L/R x 3
RCA L/R x 3
Yes x 1
Yes x 1
Yes x 1
Yes x 1
RCA Video Out x 1
RCA Video Out x 1
RCA Video Out x 1
RCA Video Out x 1
RCA L/R x 1
RCA L/R x 1
RCA L/R x 1, Digital Audio Output x 1
Silver
Silver
Silver with black sides Silver with black sides
21.8 x 17.6 x 8.7”
26.9 x 22.3 x 10.3”
14.6 x 15.2 x 7.4”
19 x 18.7 x 9.5”
19.8 lbs.
35.2 lbs.
10.6 lbs.
15.9 lbs.
* with stand and speakers
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
412
F L AT PA N E L D I S P L AYS
SHARP
SH20U SERIES
20-, 26- 32 -37- and 42”16:9 LCD HDTVs
Available in 20-, 26-, 32- and 37” screen sizes, the SH20U series
provides a slim, versatile high-definition television solution with
a distinctive design. They all feature a high-performance LCD
panel for high brightness, a high contrast ratio, low-reflection
glare protection and wide viewing angles, as well as Sharp’s
Emmy Award-winning LCD technology.
They feature true 16:9 resolution of 1366 x 768, built-in
ATSC/QAM/NTSC tuners (except the 20” model) and HDMI and
HD component terminals for the remarkable experience of HDTV
programming combined with simple and versatile connectivity
options. They feature a high contrast ratio of 800:1 for rich black
tones and crisp on-screen images, and a pixel response time of
less than 12ms for excellent picture quality even on fast-moving
action scenes. They offer a wide viewing angle (170°) so they can be
viewed clearly from almost anywhere in a room, and high brightness
levels for clear, vibrant pictures and true-to-life color clarity in any lighting conditions. The 20” LC-20SH20U has all of
the features of the SH20U Series except it is also PC compatible and is only an HDTV monitor (no built-in tuner.) It is compatible with all HDTV signals (480p, 720p an 1080i) but requires a separate decoder.
F E AT U R E S
◆ True 16:9 Aspect Ratio (1366 x 768) LCD
Panel displays 16:9 widescreen programs in
their native aspect ratio without the need
for scaling or other video processing.
◆ Built-in ATSC / QAM / NTSC Tuners for DTV
and analog TV viewing (LC-20SH20U
includes only NTSC tuner).
◆ High Brightness (450 cd/m2) Sharp Liquid
Crystal Televisions are very bright, so you
can put them anywhere – even near windows, doors or other light sources – and
their picture is still vivid.
◆ HDMI Input for convenient connection to
digital devices.
◆ 170°H x 170°V Viewing Angles are so wide
you can view Sharp Liquid Crystal
Televisions from anywhere in the room!
◆ Sharp’s 60,000-hour LCD backlight lamp life will give you viewing pleasure for many years.
B&H Number
Screen
Pixel Resolution
◆ 12ms response time ensures you enjoy all
fast motion video without blurring or delay.
PHOTO - VIDEO - PRO AUDIO
LC-26SH20U
LC-32SH20U
LC-37SH20U
LC-42SH20U
SHLC26SH20U
SHLC32SH20U
SHLC37SH20U
SHLC42SH20U
13” Active Matrix 15” Active Matrix 20” Active Matrix 15” Active Matrix 20” Active Matrix
VGA (640 x
RGB x 480)
VGA (640 x
RGB x 480)
XGA (H1024 x
RGB x V 768)
VGA (H640 x
RGB x V480)
640 x 480 x
R/G/B=VGA
Video Systems
NTSC, PAL,
PAL-M, PAL-N
SECAM, PAL-60
NTSC, PAL
PAL-M, PAL-N
SECAM, PAL-60
NTSC, PAL
PAL-M, PAL-N
SECAM, PAL-60
NTSC, PAL
PAL-M, PAL-N
SECAM, PAL-60
NTSC, PAL
SECAM
Audio System
2.1W + 2.1W
2.1W + 2.1W
2.1W + 2.1W
2.1W + 2.1W
2.1W + 2.1W
Contrast Ratio
500:1
500:1
500:1
500:1
500:1
HD Component Input
Y/PB/PR x 1
Y/PB/PR x 1
Y/PB/PR x 2
Y/PB/PR x 1
Y/Pr/Pb x 1
S-Video Input
4-pin DIN x 1
4-pin DIN x 1
4-pin DIN x 1
4-pin DIN x 1
4-pin DIN x 1
RCA x 2
RCA x 2
RCA x 2
RCA x 2
RCA x 2
Silver top and
bottom. Black
side speakers.
Silver top and
bottom. Black
side speakers.
Silver top and
bottom. Black
side speakers.
Silver
Silver
Composite Video Input
Cabinet Color
◆ 800:1 Contrast Ratio provides incredible
images whether you're watching dark or
bright scenes!
LC-20SH20U
SHLC20SH20U
Power Consumption AC
47W
54W
81W
36W
73W
Dimensions with Stand
71516⁄ 4 x 13
x 8131⁄ 6” (WHD)
19 596⁄ 4 x 14 31⁄ 6
x 8131⁄ 6” (WHD)
2518⁄ x 17 296⁄ 4
x 9 173⁄ 2” (WHD)
14196⁄ 4 x 14 7⁄8
x 71⁄8” (WHD)
19 13⁄ 2 x 18 253⁄ 2
x 8 536⁄ 4” (WHD)
9.5 lbs.
10.6 lbs.
19.4 lbs.
9.5 lbs.
15.2 lbs.
Weight with stand
www.bhphotovideo.com
F L AT PA N E L D I S P L AYS
SHARP
413
D40U SERIES
AQUOS 26- 32 -and 37” 16:9 Widescreen HDTVs
Sharp’s unrivaled selection of screen sizes, unique designs and
sophisticated cabinet finishes now includes the AQUOS D40U
series. Available in 26-, 32-,37-, and 45”, this competitively-priced
line of widescreen HDTVs delivers crisp on-screen images and the
most vibrant colors possible, as well as increased viewing angles,
for a stellar picture from almost anywhere in a room.
The D40U series includes an enhanced version of the ASV
(Advanced Super View) LCD panel, which provides an incredibly
sharp contrast ratio of 1200:1, and an enhanced pixel response time
of less than 6ms to further improve the picture quality on fast-moving action scenes. With multi-pixel technology enabling wider viewing angles than previous models (176°), the television can be viewed
from almost anywhere in the room. And with 1366 x 768 resolution
for a true 16:9 aspect ratio, built-in ATSC/QAM/NTSC tuners and dual
HDMI and HD component terminals, the D40U series delivers a stunning
experience of HDTV programming combined with incredible connectivity options for simple, versatile set-up. All feature
high brightness (450 cd/m2) and Black TFT low-reflection coating, so they can be placed near bright light sources or
windows without compromising picture quality. Available in an elegant piano black finish with fixed bottom-mounted
speakers and an included table stand, for flexibility in room placement.
F E AT U R E S
◆ 1366 x 768p panel displays HDTV program
images in 720p and is compatible with
off-air, cable and satellite HDTV broadcasts.
◆
Black TFT LCD panels deliver contrast ratios
up to 1200:1 and produce whiter whites and
blacker blacks than ever before achieved in
LCD television.
◆
Quick Shoot Sharp’s proprietary fast response time video circuit, for response time of 6ms,
resulting in smoother, more lifelike moving images, even in fast-motion scenes.
◆
Built-in speakers and Table Stand are the ultimate in convenience.
LC-26D40U
LC-32D40U
LC-37D40U
SHLC26D40U
SHLC32D40U
SHLC37D40U
26˝ Active Matrix
Advanced Super View LCD
32˝ Active Matrix
Advanced Super View LCD
37˝ Active Matrix
Advanced Super View LCD
HDTV 1366 x 768
HDTV 1366 x 768
HDTV 1366 x 768
Video Systems
8VSB (ATSC), QAM, NTSC
8VSB (ATSC), QAM, NTSC
8VSB (ATSC), QAM, NTSC
Audio System
10W + 10W
10W + 10W
10W + 10W
Contrast Ratio
1200:1
1200:1
1200:1
Y/PB/PR x 2, HDMI x2
Y/PB/PR x 2, HDMI x2
Y/PB/PR x 2, HDMI x2
4-pin DIN x 2
4-pin DIN x 2
4-pin DIN x 2
RCA x 2
RCA x 2
RCA x 2
Piano Black
with bottom speakers
Piano Black
with bottom speakers
Piano Black
with bottom speakers
B&H Number
Screen
◆ With high brightness
of 450 cd/m2 you can
put them anywhere – even near windows,
doors or other light sources – and their
picture is still vivid.
◆
Proprietary Low-Reflection Coating allows
Sharp LCD TVs to effectively reduce
reflection of sunlight and interior lighting to
provide vivid large-screen pictures wherever
you install your LCD television.
Pixel Resolution
HD Component Input
S-Video Input
Composite Video Input
◆
170º/170º viewing angles let yo view the TVs
from almost anywhere in the room!
Cabinet Color
◆
Fast 6ms response results in smoother,
more lifelike moving images, even in
fast-motion scenes.
Power Consumption AC
145W
170W
186W
Dimensions with Stand
26 78⁄ x 21111⁄ 6
x 10 496⁄ 4” (WHD)
32 51⁄ 6 x 25173⁄ 2
x 10 496⁄ 4” (WHD)
3714⁄ x 26356⁄ 4
x 12 16⁄ 4” (WHD)
Built-in speakers for added convenience.
Weight with stand
35.3 lbs.
43 lbs.
53.8 lbs.
◆
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
414
F L AT PA N E L D I S P L AYS
S O NY
BRAVIA S SERIES
16:9 HDTV LCD Televisions
Sleek and stylish LCD TVs, Sony’s high-performance Bravia S Series
include the KDL-26S2000 (26”), KDL-32S2000 (32”), KDL-40S2000 (40”),
and the KDL-46S2000 (46”). Each has an integrated ATSC digital tuner
and each features 1366 x 768 screen resolution, 1000:1 contrast ratio, a
3D Y/C comb filter and ample inputs including HDMI, component, two
composite and a PC input. They also incorporate Sony’s new 1-chip
digital video processor that reduces “block noise” around letters, such
as on-screen graphics and subtitles and enhances contrast, producing
crisp and vivid images. The chip also automatically adjusts greens
and blues for truer and brighter colors.
They feature the latest in Sony’s unique S-PVA technology, which delivers
vivid and accurate colors along with wide 178° viewing angles and a blazing
8ms response time. Other features such as PC input allow users to connect a PC for viewing
content in a 16:9 high resolution environment. And with integrated HDTV capabilities, you can enjoy digital programming
with enhanced audio and video reproduction. Space-saving bottom speaker design (two 10-watt speakers with SRS Tru
Surround XT), a simple remote with direct input keys, and VESA compliant mounting holes round out the S-series package.
Providing exceptional value and performance, the KLV-32U100M (32”) and KLV-40U100M (40”) HD monitors are identical
to the S Series except they don’t have a tuner. They are designed to receive HD and standard TV signals via set top boxes
(cable or satellite).
F E AT U R E S
At the forefront of technological advancement in every
generation of television for the past 40 years, Sony’s
newest brand, BRAVIA, introduces the next generation
of LCD TVs. An acronym for “Best Resolution Audio
Video Integrated Architecture”, BRAVIA brings three
key advances to LCD televisions: larger color gamut,
higher refresh rates, and televisions that automatically
adjust to ambient light conditions.
Their Super-Patterned Vertical Alignment (S-PVA) panels divide pixels into more
segments than was possible with PVA (Pattered Vertically Aligned) technology. These
segments have an incredibly fast 8-millisecond response time that increases the
television’s refresh rate. Dividing the pixel display into more segments also allows a
cleaner break between dark and light pixels, improving viewing angles, color, and
contrast. The accompanying diagram demonstrates how, by increasing in the number
of segments per sub-pixel from one to two, and increasing speed of refresh rate
accordingly, picture quality can be achieved that can entirely eliminate flicker and bring
the viewing experience to a whole new level.
Sony brings decades of television expertise and experience to LCD with a revolutionary
backlight — WCG-CCFL (Wide Color Gamut-Cold Cathode Fluorescent Light) Displaying
a color gamut almost 30% larger than a conventional CCFL display, the larger color
gamut allows BRAVIA televisions to reproduce more faithfully the colors of real life
using new spectrum phosphors to achieve deeper reds, more vivid greens, and cleaner
blues. BRAVIA TVs using WCG-CCFL in concert with HDTV standards display an image
that is far closer to what your eye would normally expect to see. Images are reproduced
with enhanced vibrancy and intensity resulting in an even greater sense of realism.
BRAVIA televisions even feature LCD panels that automatically adjust to ambient light
to ensure the optimal image the entire time you’re watching. Within every BRAVIA S
Series LCD television is an intelligent light sensor that adjusts the screen brightness to
match the ambient light in a room. The benefit to you is that the sensor makes your
viewing experience more comfortable. In a dim room, for example, the screen
automatically reduces brightness. This “intelligent” adjustment results in a more
satisfying television viewing experience.
PHOTO - VIDEO - PRO AUDIO
www.bhphotovideo.com
F L AT PA N E L D I S P L AYS
S O NY
415
BRAVIA S SERIES
◆ Integrated HDTV lets you watch digital
television programs and enjoy the audio/
video quality offered by these programs.
◆
◆
◆
◆
Component video input offers the best
video quality for DVD (480p and 480i), and
digital set-top box (1080i, 720p, 480p and
480i) connections.
HDMI Interface (High-Definition Multimedia
Interface) provides an uncompressed, alldigital A/V interface between the TV and any
HDMI-equipped A/V component, like set-top
box, DVD player and A/V receiver. HDMI
supports enhanced, or high-definition video,
plus multi-channel digital audio.
Display Resolution
Screen Size (Diagonal)
Display Panel Technology
HDMI Connection:
KDL-26S2000
KDL-32S2000
KDL-40S2000
KDL-46S2000
1366 x 768
1366 x 768
1366 x 768
1366 x 768
16”
32”
40”
46”
S-PVA LCD
S-PVA LCD
S-PVA LCD
S-PVA LCD
1 Rear (with L/R
RCA audio
1 Rear (with L/R
RCA audio
1 Rear (with L/R
RCA audio
1 Rear (with L/R
RCA audio
PC Input
Component Video Inputs
1 Rear with D-sub 15 and L/R stereo mini plug connections
2 Rear
S-Video Inputs
2 Rear
2 Rear
3 (1 side/2 rear)
3 (1 side/2 rear)
3 (1 side/2 rear)
1 Rear
1 Rear
1 Rear
1 Rear
5 (1 side/4 rear)
5 (1 side/4 rear)
5 (1 side/4 rear)
5 (1 side/4 rear)
Audio Out (Variable/Fixed)
1 Rear
1 Rear
1 Rear
1 Rear
WEGA GATE Easy Operation Guide allows you
to easily navigate to the most convenient TV
functions: favorite channels, TV channel list,
external input list or settings.
Digital Audio Output(s)
1 Rear
1 Rear
1 Rear
1 Rear
CineMotion technology using the reverse
3-2 pull down technology, the Cinemotion
feature provides smoother picture
movement when playing back movies or
other video sources on film.
Contrast Ratio
◆
VESA compliant mounting holes
◆
Freeze function allows you to freeze one
screen while the other screen continues
showing the program.
Composite Video Inputs
2 Rear
2 (1 side/1 rear) Rear with Auto S Video Input Detection
RF Connection Input
Audio In
Headphone Output(s)
Viewing Angle (L/R x U/D)
Aspect Ratio
3 (1 side/2 rear)
1 Side
1 Side
1 Side
1 Side
178° x 178°
178° x 178°
178° x 178°
178° x 178°
16:9
16:9
16:9
16:9
1300:1
1300:1
1300:1
1300:1
Panel Response Time
8 ms (gray to gray)
8 ms (gray to gray)
8 ms (gray to gray)
8 ms (gray to gray)
Tuner
ATSC Digital Tuner
ATSC Digital Tuner
ATSC Digital Tuner
ATSC Digital Tuner
3D digital
3D digital
3D digital
3D digital
Comb Filter
Picture Modes
Vivid/Standard/Custom
Wide Mode (16:9)
Wide Zoom/Normal/Full/Zoom
Light Sensor
Yes
Yes
Yes
Yes
Noise Reduction
Yes
Yes
Yes
Yes
Advanced Video
Processor
Motion and edge adaptive I/P converter; Contrast enhancer circuit; MPEG noise
reduction; Green and blue enhancer; CineMotion/Film Mode/Cinema Drive
◆
PC Input allows you to connect your PC and
display the PC screen on your TV.
VESA Compliant
Yes
Yes
Yes
◆
ATSC Integrated Tuner allows the reception
of local, off-air digital broadcasts providing
the viewing of free, true high-definition
network programming without the addition
of a set top box or a monthly fee.
Energy Star Compliant
Yes
Yes
Yes
Yes
VESA FDMI Complian
Yes
Yes
Yes
Yes
Wide Screen Mode allows you to watch 4:3
normal broadcasts in wide screen mode
(16:9 aspect ratio).
Light Sensor allows the picture brightness
level to be optimized to ambient light. The
effect from the Light Sensor depends on the
setting of Picture Mode and Power Saving.
The factory setting is Off.
◆
◆
◆
◆
◆
SRS TruSurround XT audio enhancement
delivers a full and immersive Virtual
Surround Sound experience from any
two-speaker system playback system using
any multi-channel audio source.
Bottom speaker design saves space and
delivers dynamic sound.
Caption Vision/Info Banner allows Closed
Caption and/or Channel Programming
Information to be displayed.
Sound Mode
SRS TruSurround XT
Yes
Dynamic/Standard/Custom
Yes
Yes
Yes
Yes
Yes (AC3 for ATSC)
Yes (AC3 for ATSC)
Yes (AC3 for ATSC)
Yes (AC3 for ATSC)
MTS Stereo Decoder
Yes
Yes
Yes
Yes
A/V Sync
Yes
Yes
Yes
Yes
Picture Freeze
Yes
Yes
Yes
Yes
Favorite Channel
Yes
Yes
Yes
Yes
Channel Label / Skip, Add
Yes
Yes
Yes
Yes / Yes
Dolby Digital Decoding
Parental Control (V-Chip)
Yes
Yes
Yes
Yes
Input Skip
Yes
Yes
Yes
Yes
Power Save Mode
Yes
Yes
Yes
Yes
Clock
Yes
Yes
Yes
Yes
Sleep Timer / Timer Clock
Yes
Yes
Yes
Yes
Auto SAP / Video Label
Yes
Yes
Yes
Yes
Closed Caption (CC)
Yes
Yes
Yes
Yes
ID1 Detection
Yes
Yes
Yes
Yes
Weight with Pedestal
28.7 lbs.
37.5 lbs.
59.5 lbs.
75 lbs.
Weight w/o Pedestal
25.3 lbs
33.1 lbs.
46.3 lbs
61.7 lbs.
Dimensions with Pedestal
25 293⁄ 2 x 20 51⁄ 6 x 858⁄ ”
3131⁄ 6 x 23113⁄ 2 x 8 58⁄ ”
38 78⁄ x 28 31⁄ 6 x 13 53⁄ 2”
44 18⁄ x 3134⁄ x 1314⁄ ”
Dimensions w/o Pedastal
25 293⁄ 2 x 18 12⁄ x 3233⁄ 2”
3131⁄ 6 x 2112⁄ x 378⁄ ”
38 78⁄ x 26 53⁄ 2 x 4 11⁄ 6”
44 18⁄ x 29 34⁄ x 4 58⁄ ”
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
416
F L AT PA N E L D I S P L AYS
S O NY
FWD-32LX1 • FWD-40LX1
32” and 40” High Definition Flat Panel LCD Monitors
Offering businesses advanced networking and display capabilities, the
FWD-32LX1 (32”) and FWD-40LX1 (40”) LCD monitors are designed to
fit a variety of businesses ranging from small retail shops to large
hotels. Restaurant, lounge and shopping mall operators will especially
appreciate the long lived high brightness display. They incorporate
the Sony WEGA Engine system, a digital processing system that
reduces video artifacts that can result from those analog/digital
conversions. They deliver 1000:1 contrast ratio, and both incorporate
S-LCD panels which produce exceptional black level reproduction and
drastically improves gradation.
For even more versatility, they are equipped with an option slot(s) for
a tuner, IP addressable network media card with flash memory, or
expanded video I/O. Each display can be controlled remotely with
Sony's BKM-FW32 Network Management Card or BKM-FW50 Network Media
Card via ethernet. The BKM-FW50 networking card also has the ability to remotely control multiple displays, as well as
transmit movies or still images.
At 40-inches, the FWD-40LX1LCD panel fits easily into most hospitality-standard dressers. As a result, guests are given a
better viewing experience without the added expense of a major room renovation. This model also has a 178/178° viewing angle, a key feature for conference room space. They feature Sony’s elegant bezel or flat design and are available in
three colors: pearl white, crystal silver and frosted black.
F E AT U R E S
Phenomenal Picture Quality
◆ High brightness, superior contrast (1000:1)
and super-fast 16ms response time combine
to deliver crisp, clear text and smooth
motion images for video applications.
◆ They use the latest S-LCD panel technology,
providing a 178° wide viewing angle, along
with WEGA Engine technology to deliver
remarkable resolution and image clarity.
◆ Unique WEGA Engine technology optimizes
the display’s potential by minimizing signal
deterioration caused by digital-to-analog
conversion. The result is better resolution
and sharpness, higher contrast, less digital
noise, and greater picture dimension.
◆ Their 1366 x 768 native resolution is capable
of delivering HD performance in an elegant
flat display design. They are capable of handling various input timings and sources,
including video and PC timings for use with
up to 1080i video or 1600 x 1200 PC timing.
PHOTO - VIDEO - PRO AUDIO
Flexible Inputs
◆ They come ready to work with a wide array
of video devices or PC applications. Inputs
include analog and digital HD video (using
component to HD15 cable, or DVI-D Cable
with HDMI to DVI-HDCP), as well as PC
input, using HD15 (RGB/YUV) or DVI-HDCP
inputs.
Multi Display
◆ Building a video wall? Don’t pay thousands
of dollars for external display processors!
They feature an Automatic Video Wall Set
Up Mode for up to 16 panels.
◆ The displays can be set used as a video wall
segment right out of the box. Simply select
the desired matrix size from the choices of
2 x 2, 3 x 3 or 4 x 4.
◆ Next, use the remote control to indicate on
the matrix graphic what position in the
video wall puzzle this TV will occupy.
www.bhphotovideo.com
High Performance
◆ They support P-i-P (Picture-In-Picture) as well
as P-i-P features for flexible multi-tasking.
P-i-P lets you watch two program sources
side by side with the ability to smoothly
zoom in on one picture and listen to the
program in the selected window.
◆ Discrete IR Codes are available for use with
installations where control systems are used
with the Control-S (In/Out) or front IR sensor.
In addition, users may select from the
Onscreen display (OSD) a setting to fix the
input to maintain its current setting.
◆ RS-232C port and serial control available for
advanced installations.
◆ They accept Sony expansion cards for more
inputs or networking control such as the
BKMFW50 digital signage card. The FWD32LX1 has one open card slot (the FWD40LX1 has two slots), with one populated
with a composite (BNC) / S-Video input card
with shared L/R audio input.
F L AT PA N E L D I S P L AYS
S O NY
417
FWD-32LX1 • FWD-40LX1
Optional Input Boards
Conveniences
◆ Confused by the endless picture sizing
options presented to you by 16:9 aspect
ratio wide screen TVs? The monitors can
interpret the new Identification Control
Signal embedded in some digital broadcasts. When selected, the Auto Wide function selects the most appropriate screen display size and aspect ratio based on the
Identification Control Signal.
◆
Compatible with NTSC, PAL, SECAM, NTSC
4.43, PAL60, PAL-M and PAL-N systems
◆ On/Off Timer lets you use them like an
alarm clock to wake you up, or be on time
for a teleconference. By programming the
On/Off Timer you can make your home or
office seem occupied while you’re not there.
◆ To make installation easier, Sony includes a
10’ component (Y/Pb/Pr) to HD15 cable for
connecting Digital Cable or satellite
receivers. Also included is a DVI-D cable for
versatile digital connections.
◆
Cable management system conceals wires
and cables, keeping the back looking
streamlined and uncluttered.
◆ Cinema Drive uses reverse 3-2 pull down
technology, also known as Inverse Telecine,
to detect the unique cadence of film-originated video and reconstruct the original
film frames resulting in smoother action
when watching movies.
◆
◆
Burn-in resistant LCD technology ensures
long life when using static images. Low
power consumption and long-life panel
delivers hours of use to keep total cost of
ownership low. Also features anti-glare and
anti-reflective screen protectors.
Component/RGB Interface Board (SOBKMFW11): This board enables the FWD-42PV1 to receive
component (5x BNC) signals. The audio input is realized via phone Jack (L/R)...........................149.00
RGB/Component Active Through Board (SOBKMFW12): With the BKM-FW12 interface a loop
function can be created to connect multiple plasma monitors in an active loop function. The
audio input is realized via a single audio-in ..............................................................................................149.00
Networking Options
Optional network cards and boxes let you centrally control, deliver and troubleshoot digital
content across a standard IP network to one or hundreds (up to 255) of networked displays.
Network Management Card (SOBKMFW32): Fits into the
FWD-series displays and provide status and control via IP.
The card provides network status and control functions, for
use with Sony’s PJNet! software program (sold separately),
for a centralized “command” center, which connects up to
255 networked devices including Sony’s flat-panel displays and LCD projectors ......................439.95
Network Media Card (SOBKMFW50): Provides status and control
via IP, as well as streaming video and media. Create content on
your PC for use on the card with industry standard development
languages/applications such as HTML, Photoshop, Microsoft
Movie Maker and other Windows applications. A CompactFlash
memory slot inside the monitor enables JPEG images and MPEG movies to be displayed in
slideshow mode, for local playback for users who do not wish to stream content ...................584.95
Network Streaming Box (SOEBSN200): Another key benefit of the
displays is their ability to remotely monitor and control them
and send content across a standard IP network. Sony’s
integrated network box enables network status and
control to monitor and troubleshoot multiple devices
from a central location. Additionally, it provides the ability
to stream MPEG video, access the Web and present remote
desktop applications across a standard IP network. Usercan continuously
loop feeds from internal sources, such as proprietary, in-house programming..........................739.95
Hospitality Clone Device (SOEBSSP15): A stand-alone TV tuner with hotel
networking, that works with the displays, the Hospitality Clone Device is
suitable for home use, recreation vehicles, corporate, campus, conference
rooms, and hotels. It provides connection to cable and over the air broadcasts
(181 channel CATV Tuner), and has internal Picture-in-Picture capability. It also
allows connectivity to all major hotel VOD systems (OnCommand, LodgeNet,
Hospitality Network, and others) ................................................................................654.95
On-screen display (OSD), available in 10 languages
◆
Built-in closed caption decoder
◆
Three custom picture modes as well as Vivid
and Standard
◆
Scratch-resistant crystal-look bezel in a
choice of three elegant colors adds upscale
refinement to any interior.
FWD-32LX1RB Frosted Black (SOFWD32LX1RB)
FWD-32LX1RS Frosted Silver (SOFWD32LX1RS)
FWD-32LX1
Composite Video
S-Video
RGB Component Vide
Stereo Audio for RGB Video
DVI
DVI Stereo Audio
FWD-32LX1RW Frosted White (SOFWD32LX1RW)
High Impedance Audio (500mVrms)
FWD-40LX1B Frosted Black (SOFWD40LX1B)
Composite Video (Loop- Through)
FWD-40LX1S Frosted Silver (SOFWD40LX1S)
S-Video (Loop-Through
FWD-40LX1W Frosted White (SOFWD40LX1W)
Dimensions (WxHxD) / Weight
FWD-40LX1
BNC x1
BNC x1
Mini Din 4 Pin x1
Mini Din 4 Pin x1
D-sub 15-Pin (female) x1
D-sub 15-Pin (female) x1
3.5 mm Stereo Minijack x1
3.5 mm Stereo Minijack x1
1
1
3.5 mm Stereo Minijack x1
3.5 mm Stereo Minijack x1
Pinjack x2
Pinjack x2
BNC x1
BNC x1
Mini Din 4 Pin x1
Mini Din 4 Pin x1
31.6 x 19.4 x 4.2”; 38.5 lbs.
39.3 x 23.7 x 5”; 60.6 lbs.
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
418
F L AT PA N E L D I S P L AYS
S O NY
FWD-42PV1
42” Extended Definition
Plasma Monitor
The FWD-42PV1 PlasmaPro is a flat panel display with several
features that make it well-suited for the demands of today’s
business environment, including a category-leading 10,000:1
contrast ratio for vivid picture quality for digital signage,
hospitality and conference room applications. It also offers
WVGA resolution (852 x 480), and the ability to display images
and video from a wide assortment of inputs and formats.
The monitor has two slots to accommodate a television tuner
and the BKM-FW32 network card, enabling users to monitor
the display's status and troubleshoot multiple networked
displays from one central location. For added convenience when
integrating into a system, an AC outlet is provided to supply power to equipment such as twisted pair transceivers up to
0.5 A. Last, lower total cost of ownership, due in part to low power consumption, adds to overall value. A special edition
model FWD-42PV1A/S which works effectively at high altitudes, which can affect standard plasma displays is also available.
F E AT U R E S
◆ Incorporates a WVGA plasma display panel
that achieves a high brightness and high
contrast ratio. Resolutions of 852 x 480
pixels and a 1.08mm pixel pitch produce
excellent image quality and sharp colors
◆ Digital Video Input (DVI-D HDCP) offers a
high picture quality when used with a DVIequipped PC (DVI video cable is supplied).
◆ Ultra-high panel brightness and contrast
(10,000:1) ratio. Anti-reflection (AR) coating
on the glass protection panel reduces light
reflection for clear, high-contrast pictures.
Ideal for HD content or PC signals.
◆ Long panel life (60,000 hours to half
◆ Added flexibility comes from the format-free
brightness)
layout. The unit can be mounted horizontally,
fixed on an optional stand or to a wall, or
hung from the ceiling. The connector panel
is located on the lower back of the display
providing easy, inconspicuous hookup.
◆ Lower power consumption at only 260W
◆ Full screen saver functions including Auto
Dimmer function and on/off timer.
◆ 7-watt digital stereo audio amplifier with
optional speakers (SS-SP42FW/S)
◆ In addition to standard 4:3 mode, the
FWD-42PV1 can optimize the display of
other aspect ratios to eliminate or greatly
reduce the amount of dead space visible
around the image. Available modes include
Expanded 4:3 (16:9 wide zoomed), Letterbox
(16:9 zoomed), Full 16:9 and Subtitle 16:9.
◆ Supports standard and HDTV formats
including 1080i, 720p, 1080/24Psf, and 480p
as well as DVI and RGB computer signals
◆ Energy-saving mode decreases the power
consumption
◆ A core part of the FWD-42PV1’s appeal is its
versatility. In addition to fixed HD15
RGB/Component and DVI-HDCP inputs, it
has composite and S-Video inputs on a
removable module. This can be swapped out
for other options, including 5-way BNC or a
pass-through for connecting multiple
monitors in an active loop.
Get your Message Across
Combining attention-grabbing image quality with versatility, stylish design and long
product life, the FWD-42PV1 was designed to be noticed. The outstandingly bright and clear
picture is ideal for digital signage applications, public entertainment or any situation where
the aim is to get the message across.
Featuring 852 x 480 ED (Extended Definition) resolution and anti-reflective panel protection,
the FWD-42V1 PlasmaPro monitor is designed for sales and marketing promotions for digital
signage applications, including point-of-purchase and brand advertising, as well as
information display in transportation hubs. It is perfect for setting the right mood in
restaurants, casinos, clubs and lounges playing background video to entertain. The monitor’s
rugged yet durable design also makes it ideal for rental and trade show applications.
PHOTO - VIDEO - PRO AUDIO
www.bhphotovideo.com
◆
Control-S and RS-232 ports for remote
management. Control-S allows for simple,
unidirectional control of single units or
daisy-chained arrays, while the RS-232 port
is bi-directional and provides feedback such
as status checks and even failure codes.
F L AT PA N E L D I S P L AYS
419
S O NY
FWD-42V1
Screen Saver
Multi Display
The lifetime of the plasma screen can be
greatly prolonged by a screen saver. That’s
because, if an image doesn’t change in
brightness, or a still image, such as the kind of
image displayed on a computer, is displayed
for a long time, an after-image (ghosting) may
be burned into the display panel. To correct or
lessen the severity of this problem, the monitor
is equipped with a screen saver function.
There are three screen saver modes: Picture
Orbiting; Picture Inversion and Background.
• Orbiting and Inversion are timer-programmable modes that move the image around and
reverse its color tones, both methods of
reducing the danger of burn-in.
• The Background function is used when there
is dead space around the image creating a
sharp contrast in brightness. The background
tone can be set from black to dark grey or
light grey to compensate.
For fast and easy video wall creation, the on-screen control features a Multi Display Setup
function. This lets users set the zoom factor or the amount of screens in the array, then the
location in the wall of each individual monitor. When audio is needed, users can rely on the
inboard amplifier to deliver 2x 7w of clean, punchy sound. Better still, the optional SS-SP42FW
speaker set mounts at the sides of the cabinet and delivers great sound from a compact but
stylish format which matches the overall design of the display. “
The zoom function can be used when multiple monitors are assembled into a video wall. By
setting the zoom level to 2x, 3x or 4x, arrays of 4, 9 or even 16 screens can be co-ordinated to
display a single image – all without any need for an additional picture processor.
Optional Interface Boards
To ensure that the FWD-42PV1 is compatible with the widest possible range of signal
types, three optional modules are available for adding more connectors. You can fit a
module using a slot next to the standard connectors on the rear panel:
Video Interface Board (SOBKMFW10)
The Video Interface Board enables the FWD-42PV1
to connect composite video, S-video and audio
sources ...........................................................................CALL
• An internal timer can be used to switch the
display on or off at specific times,
independently of the external control system.
This both reduces overall power consumption
and extends the life of the display.
Audio
◆
When audio is needed, users can rely on the
inboard amplifier to deliver 2x 7-watts of
clean, punchy sound. Better yet, the optional
SS-SP42FW speaker set mounts at the sides
of the cabinet and delivers great sound from
a compact but stylish format which matches
the overall design of the display.
Component/RGB Interface Board (SOBKMFW11)
This board enables the FWD-42PV1 to receive
component (5x BNC) signals. The audio input is
realized via the phone jack (L/R)...........................149.00
RGB/Component
Active Through Board (SOBKMFW12)
This card provides 15-pin input and loop output
connectors so that multiple monitors can be fed
the same computer/video signal .....................149.00
FWD-42V1
Signal System
RM-980 Remote Commander
◆
◆
To make setup as speedy as possible, the
FWD-42PV1 is supplied with the RM-980
Remote Commander. This allows direct
access to important functions such as input
selection, volume control, picture control,
aspect ratio and picture size and position.
The remote can also be used to select and
control an individual display in an array
using it’s ID-mode and numerical keypad.
◆
The monitor can also be configured using a
6-language graphical on-screen menu.
◆
When required the remote can be used to
disable the physical control panel on the
monitor itself, including the on/off function.
NTSC, PAL and Secam systems
Screen Size
Aspect Ratio
Number of Pixels
Contrast Ratio
Input and
Output Connectors
42”
16:9 wide screen panel
852 horizontal x 480 vertical pixels
10,000:1 contrast; over 1 billion colors differentiated
DVI-D- special 24-pin (x 1); Analog Component/RGB - 15-pin (x 1 input);
S-Video- 4-Pin (x 1 input); Composite Video- BNC (x 1 input, 1 loop output);
Audio- RCA (x 4 input, 2 stereo pairs); Headphone- stereo-mini (x 2 output);
RS-232C Control- 9-pin (x 1 input)
Speakers
Dimensions and Weight
Included Accessories
Optional
44.75” x 25” x 4” (WHD); it weighs 66 lbs.
Wireless remote control, 2x AA batteries, DVI-D cable, AC plug holder,
4x cable holders, 2 years parts and labor warranty except for the
plasma panel, which has a 1 year warranty
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
420
F L AT PA N E L D I S P L AYS
S O NY
FWD-42PX2 • FWD-50PX2
42- and 50” High Definition
Plasma Monitors
Well suited for corporate and consumer applications, the FWD42PX2 and FWD-50PX2 are stylish 42- and 50” plasma displays
with a 10,000:1 contrast ratio and more than 60,000 hours of
life. The displays have both DVI-HDCP and dual option slots.
Additionally, they feature picture-in-picture, advanced video
wall and optional network connectivity, making them ideal for a
digital signage applications in office lobbies or reception areas.
Integrated stereo amplifier and optional speakers will support
all of your audio requirements. The FWD-42PX2 comes in black,
the FWD-50PX2 has a flat finish available in silver or black.
F E AT U R E S
High Performance
◆ Ultra-high panel brightness and contrast
Flexible Inputs
◆
The displays come ready to work with a
wide array of video devices or PC applications. Inputs include support for analog and
digital HD video (using component to HD15
cable, or DVI-D cable with HDMI to DVIHDCP), as well as PC input, using HD15
(RGB/YUV) or DVI-HDCP inputs.
◆
They are also capable of using compatible
Sony expansion cards for additional inputs
or networking control. The display has two
available card slots, with one populated
with a Composite (BNC) / S-Video input card
with shared L/R audio input.
◆
RS232 port and serial control available for
advanced installations.
(10,000:1) ratio. Anti-reflection (AR) coating
on the glass protection panel reduces light
reflection for clear, high-contrast pictures.
Ideal for HD content or PC signals.
◆
The 1366 x 768 native resolution is capable
of delivering HD performance in an elegant
flat display design. The display is capable of
handling various input timings and sources,
including video and PC timings for use with
up to 1080i video or 1600 x 1200 PC timing.
◆ The displays have a long-life panel of 60,000
hours—that’s seven years. The panels are
capable of 1.07 billion colors, the result is a
life-like image with rich color reproduction
for home theater applications.
well as P-i-P features for flexible multitasking. P-i-P lets you watch two program
sources side by side with the ability to
smoothly zoom in on one picture and listen
to the program in the selected window.
◆ Building a video wall? Don’t pay thousands
Discrete IR Codes are available for use with
installations where control systems are used
with the Control-S (In/Out) or front IR
sensor. In addition, users may select from
the Onscreen Display (OSD) a setting to fix
the input to maintain its current setting.
segment right out of the box. Simply select
the desired matrix size from the choices of
2 x 2, 3 x 3 or 4 x 4.
PHOTO - VIDEO - PRO AUDIO
User-selected screen saver adds a signal
monitor that identifies a static image on the
screen that can cause permanent image
retention. If the display senses this static
video image for several minutes, it will
automatically dim the display brightness to
reduce the potential effect of permanent
image retention.
◆
Other screen saver modes include
Background, Multi-Mode Picture Orbit,
Picture Inversion, Power Save, Smart Fan
Technology, Timers and White screen.
◆
Included accessories make a difference for
easy installations, which is why Sony
includes a 10’ component (Y/Pb/Pr) to HD15
cable for connecting digital cable or
satellite receivers. Also included is a DVI-D
cable for versatile digital connections.
◆
Cable management system conceals wires
and cables, keeping the back looking
streamlined and uncluttered.
◆
Low power consumption and long-life panel
delivers hours of use to keep total cost of
ownership low. Also features anti-glare and
anti-reflective screen protectors.
◆
Selectable color temperature modes include
Cool, Neutral, and Warm. Selectable picture
modes include Custom (3), Vivid and
Standard.
Multi Display
◆ They support P-i-P (Picture-In-Picture) as
◆
Conveniences
◆
of dollars for external display processors!
They feature an Automatic Video Wall Set
Up Mode for up to 16 panels.
◆ The displays can be set used as a video wall
◆ Next, use the remote control to indicate on
the matrix graphic what position in the
video wall puzzle this TV will occupy.
www.bhphotovideo.com
F L AT PA N E L D I S P L AYS
S O NY
Optional Input Boards
Component/RGB Interface Board
(SOBKMFW11): Enables the FWD-series displays to
receive component (5x BNC) signals.......149.00
Signal System
RGB/Component Active Through Board
(SOBKMFW12): Allows a loop function to be
created to connect multiple plasma monitors
in an active loop function ...........................149.00
Network Media Card (SOBKMFW50): Provides
status and control via IP, as well as streaming
video and media. Create content on your PC
for use on the card with industry standard
development languages/applications such as
HTML, Photoshop, Microsoft Movie Maker and
other Windows applications. A CompactFlash
memory slot inside the monitor enables JPEG
images and MPEG movies to be displayed in
slideshow mode, for local playback for users
who do not wish to stream content........584.95
Network Streaming Box (SOEBSN200): Enables
network status and control to monitor and
troubleshoot multiple devices from a central
location. Additionally, it provides the ability to
stream MPEG video, access the Web and
present remote desktop applications across
a standard IP network. Usercan continuously
loop feeds from internal sources, such as
proprietary, in-house programming .......739.95
Hospitality Clone Device (SOEBSSP15): A
stand-alone TV tuner with hotel networking.
For home use, recreation vehicles, corporate,
campus, conference rooms, and hotels. It
provides connection to cable and over the air
broadcasts (181 channel CATV Tuner), and has
internal Picture-in-Picture capability. It also
allows connectivity to all major hotel VOD
systems (OnCommand, LodgeNet, Hospitality
Network, and others) ....................................654.95
NTSC, PAL and Secam Systems
NTSC, PAL and Secam Systems
42”
50”
Aspect Ratio
16:9 Wide Screen Panel
16:9 Wide Screen Panel
Brightness
450cd/M2
450cd/M2
Number of Pixels (HV)
1024 x 768
1366 x 768
10,000:1
10,000:1
Contrast Ratio
Networking Options
Network Management Card (SOBKMFW32):
For use with Sony’s PJNet! software program
(sold separately). Provides network status and
control functions via IP, for a centralized
“command” center, which connects up to 255
networked devices including Sony’s flat-panel
displays and LCD projectors.......................439.95
FWD-50PX2
Screen Size
Input and Output Connectors
Optional network cards and boxes let you centrally control, deliver and troubleshoot digital
content across a standard IP network to one or
hundreds (up to 255) of networked displays.
FWD-42PX2
Dimensions (WxHxD) / Weight
421
YUV/RGB Component- 3 BNC (x 2 input); S-Video- 4-Pin (x 1 input);
Composite Video- RCA (x 1 input, 1 output);
Audio- RCA (x 4 input, 2 stereo pairs); RS-232C Control- 9-Pin (x 1 input)
40.7 x 24.8 x 4.8”; 66.1lbs.
49.4 x 29.6 x 4.4”; 96.8 lbs.
S A NYO PDP-42H2AMC
42˝ HD Multimedia Plasma Display
This HDTV-compatible
42” plasma monitor
offers a typical contrast
ratio of 1000:1 as well as
overall brightness rated
at 1100 cd/m2. It displays
a full 1024 x 1024 image
(up to 1080 lines
interlaced or 720 lines
progressive. 3D chrominancel and luminance
separation and digital progressive scanning further enhance its extraordinary
picture performance. Ideal for any type of multimedia presentation—in
addition to component and composite video options, it has been engineered
to function as a computer display monitor meeting XGA display specifications.
◆
The PDP-42H2AMC performs well in a
wide range of room settings. Its
unusually broad viewing angle–more
than 175° vertical & horizontal–ensures
that audience members at the extreme
right and left will see a clear,
undistorted image without straining.
◆
An innovative Dynamic AI circuit
constantly monitors different picture
performance parameters (ambient
lighting, white balance, etc.) and
automatically makes any adjustments
necessary to maintain optimum image
quality. A built-in screen saver to
reduce the possibility of burn-in.
◆
Select from three composite or S-Video
inputs (3 RCA and 2 BNC), one
component video/RGB input (D-Sub 15),
two computer inputs (D-Sub 15 and a
DVI-D input with HDCP for an HD set
top box) and an RS-232 control port.
There are also jacks for an external
monitor (BNC and RCA), component/
RGB output (D-Sub 15), optional PD-Net
Organizer and optional speakers.
◆
Optional network card lets you use the
PDP-42H2AMC as a network monitor,
using the web to monitor and control
the display. Additional software is not
required.
(212) 444-6605 • 1-800-947-9905 • Quick Dial 821
PHOTO - VIDEO - PRO AUDIO
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
