UPS SYSTEMS
UPS SYSTEMS
The CyberPower Story
The growth of CyberPower Systems is attributable to a strategic plan that engages our own award-winning international
research and development team in the design of feature-rich products for IT professionals and tech-savvy consumers
everywhere. At our advanced technology manufacturing facilities, we build a comprehensive line of innovative products,
including uninterruptible power supply (UPS) systems, power distribution units (PDUs),
surge protectors, mobile chargers and connectivity devices, all engineered to exceed international safety and
environmental standards.
Whether you run a corporate data center, own a small business or simply use electronic devices in your home office or
at leisure, CyberPower has the power protection systems to safeguard your equipment investment and valuable data.
A History of Firsts
Our rapid growth is tied directly to ongoing innovation that satisfies the needs of our customers. This focus has helped
us achieve many firsts in the power protection industry.
Our many firsts include the following achievements:
•Integrating LED and LCD control panels on UPS systems for on-the-spot battery backup management.
CyberPower still offers the largest selection of UPS models with LCD control panels.
•Developing patented GreenPower UPS™ Technology to reduce UPS heat and energy loss. The result of this
advancement was significant energy cost reduction – up to 75% savings over conventional UPS systems.
•Offering a three-year repair or replacement warranty that includes batteries.
•Providing a Connected Equipment Guarantee, valued at up to $500,000, for repair or replacement of properly
connected equipment damaged by a surge, including surges due to lightning strikes.
•Incorporating Fast Charge Technology for Extended Battery Modules, allowing the UPS to return to 100% capacity in
about one-third the time required by typical systems.
•Introducing PFC Sinewave Technology to fulfill the growing demand for pure sine wave backup for workstations and
other mid-range systems with active power factor correction (Active PFC) power supplies. The PFC Sinewave™ UPS
series was voted Best Channel Product in 2011 by readers of Business Solutions Magazine.
Global Distribution
Our products are available only through authorized distributors and are sold by value-added resellers, system
integrators, various well-known e-tailers and at select retail stores.
The company’s global reach is accomplished through offices and distribution centers located in Australia, France, the
Netherlands, Russia, Japan, China, Taiwan, Mexico and the United States.
1.877.297.6937
UPS SYSTEMS
Table of Contents
Power Protection Overview
Choosing a UPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Line Features
Features Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
UPS Solutions
Smart App Series
Smart App Online (6–10kVA)
Rack/Tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Rack/Tower Transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Rack/Tower PDU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rack/Tower PDU Transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Rack/Tower Hard-Wired . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
Tower Transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Tower Hard-Wired . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Tower Hard-Wired Transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Smart App Online (1–3kVA)
Rack/Tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16
Tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Smart App Sinewave
Rack/Tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-21
Tower & Mini-Tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23
Smart App LCD
Rack/Tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25
PFC Sinewave Series
Rack/Tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27
Mini-Tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29
Intelligent LCD Series
Mini-Tower & Compact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-31
AVR Series
Mini-Tower & Compact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33
Standby Series
Compact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34-35
Network Power Management
Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Replacement Batteries
Compact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Essential Power Solutions
Product Overviews . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Glossary
Industry Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40-41
cpsww.com
1
UPS SYSTEMS
Power Protection Overview
Choosing a UPS
CyberPower offers IT professionals and home office users a broad selection of uninterruptible power supply (UPS)
solutions, all designed to protect sensitive electronic equipment and vital data from potential harm. The three topologies
described here address ascending levels of protection from nine power problems, shown in graphic symbols.
Throughout this catalog, these symbols are provided as an aid for selecting a UPS system that meets the specific
protection needs of different users in varying environments. In addition, you will see information for each of our UPS
series about waveform output – either sine wave or simulated sine wave – which is critical to the optimal performance of
connected equipment. We are confident there is a CyberPower UPS that fits your environment and offers the protection
you require.
Essential Protection — Standby
Standby is the most basic UPS topology. During a brownout or blackout, the UPS simply resorts to an internal battery
to provide electricity. These UPS systems are designed for consumer electronics, computers, POS systems, security
systems and other basic equipment.
Professional Protection — Line-Interactive
Line-Interactive topology systems incorporate technology that allows the UPS to correct minor power fluctuations
(brownouts, overvoltages, etc.) without switching to battery. This extends the life of the battery and is essential in areas
where power fluctuations occur regularly. Typical applications are consumer electronics, PCs and mid-range servers.
Total Protection — Double-Conversion
Double-Conversion topology provides consistent, clean and near perfect power, regardless of the condition of incoming
power. Systems with this technology operate on isolated battery-supplied power 100% of the time and have a zero
transfer time because they never need to switch to battery. Double-Conversion UPS systems are designed for high-end
system components, corporate servers, lab equipment and other sensitive electronic devices.
Waveform Output
Sine Wave
For applications requiring true sine wave power, UPS systems
are available with sine wave output. These UPS systems are
designed for electronics having Active PFC power supplies or
other devices requiring pure sine wave power to function properly. When the
UPS is using normal utility power, it passes the utility-generated true or pure
sine wave power to the connected equipment.
2
1.877.297.6937
Simulated Sine Wave
Utility companies provide true sine wave AC power. Many
UPS manufacturers acknowledge that some consumer
electronics do not require a true or pure sine wave signal to
function properly, so they have engineered UPS systems that produce a
simulated sine wave. Simulated sine wave systems offer a lower cost solution
to produce battery power and are very common in entry-level to mid-level
UPS products.
UPS SYSTEMS
Product Line Features
This listing is intended as an overview of the many innovative features found in
various CyberPower UPS systems. The features listed below are not available
with all UPS models. A comprehensive list of features and specifications for
each UPS model can be found on our website at cpsww.com.
Active PFC Compatibility
CyberPower UPS systems with pure sine wave output prevent unexpected
shutdowns or component stress which may occur when devices with Active
PFC power supplies are connected to an entry-level UPS that provides
simulated sine wave power. See page 28 for more details.
Automatic Voltage Regulation (AVR)
Stabilizes AC voltages to maintain safe voltage levels without switching to
battery mode, thereby conserving battery life and delivering cleaner AC power
to connected equipment.
Connected Equipment Guarantee
CyberPower will repair or replace properly connected equipment if it is ever
damaged by a surge, including surges due to lightning strikes. Refer to the
warranty section of the device manual for more details.
Convertible Rack/Tower Configuration
Units can be set up horizontally or vertically, except 1U, and each unit ships with
a rack mounting kit and tower stands.
Critical Load Outlets
During a power outage or overload, critical load outlets ensure continuous
power to essential equipment. Systems with PowerPanel® Management
Software allow programmable control of these outlets, including scheduled
shutdowns and restarts.
Emergency Power Off Port (EPO)
EPO is a protection feature that can be used to instantly cut power to
equipment in the event of fire, flood, overheating or any other emergency where
it may not be possible to access the main disconnect device safely.
LCD Control Panel
The LCD interface allows users to check the status of the UPS, configure
settings, review event logs, disable alarms and more. See page 10 for
more details.
Multifunction LCD Display Panel
The LCD displays vital UPS status information, such as input voltage level,
output voltage level, automatic voltage regulation, battery capacity, runtime
estimate, load level, output frequency, on battery, overload, fault condition and
silent mode—depending on model. See page 24 for more details.
Multiple Communication Ports
Communication is offered via multiple HID-compliant USB ports and serial
ports, including remote monitoring using a standard web browser or network
management system, with the addition of an optional SNMP/HTTP remote
management adapter—depending on model.
Power Management Software
PowerPanel® software is included with CyberPower UPS systems. In the event
of a power loss, PowerPanel Personal Edition ensure connected devices shut
down safely. PowerPanel Business Edition gives administrators the tools for full
local and remote control. See page 37 for more details.
RoHS & WEEE
Every CyberPower device is manufactured in accordance with the Restriction
of Hazardous Substances (RoHS) directive by the European Union, mandating
environmentally safe procedures and restricting the use of lead, cadmium,
mercury, hexavalent chromium, PBB and PBDE. CyberPower manufacturing
processes adhere to the Waste Electrical and Electronic Equipment (WEEE)
directive, issued by the European Union, encouraging the collection, treatment,
recycling and recovery of electrical waste and discarded electronic equipment.
Selectable Output Voltages
Certain high capacity CyberPower UPS models may be configured to output
200V, 208V, 220V, 230V and 240V ± 2%.
Generator Mode
Surge Protection with Automatic Shutdown
During extended power outages, UPS models with this feature handle generator
output aberrations as the generator and its loads go through initial ramp-up to
full operation, preventing data corruption or shutdown of connected equipment.
Limits the impact of both externally and internally generated high-voltage
power spikes by restricting them to an acceptable level. If an electrical surge or
spike exceeds the system’s ability to suppress the electrical signal, the surge
protector will shut the UPS down to safeguard all connected equipment.
See page 34 for more details.
GreenPower UPS™ Technology
Patented advanced circuitry reduces UPS energy consumption, heat buildup
and overall UPS energy costs. See page 22 for more details.
TAA Compliant
Hot-Swappable Batteries
CyberPower manufactures products that are certified compliant with the U.S.
Trade Agreements Act (TAA) and listed on the GSA Schedule Contract for
approved use in government installations. Look for this 3 symbol for models
that are TAA compliant.
Eliminate power-related downtime and ensure maximum power availability. All
potential UPS maintenance, including complete power module exchange, can
be performed without powering down connected equipment.
Industry-Leading Three-Year Warranty
CyberPower will repair or replace damaged units within three years of purchase
date—including dead batteries—a first for the UPS industry.
Ultra-Quiet Design
Efficient design, advanced system components and GreenPower UPS™
Technology help minimize sound emissions for a quieter work environment.
UL Standards
All CyberPower UPS systems are manufactured and certified by Underwriters
Laboratories (UL) passing strict testing requirements to ensure the highest
electrical safety standards and performance.
cpsww.com
3
SMART APP SERIES
Smart App Online
6kVA – 10kVA Rack/Tower Convertible OL Models
Waveform Output
Smart App Online rack/tower UPS models, with
Double-Conversion topology, provide pure sine wave output to
mission-critical applications and equipment requiring seamless
power correction. These units offer generator compatibility and
deliver clean AC power with zero transfer time.
Typical Applications
•Corporate Data Centers
•Corporate Servers
•Network and Storage Devices
•Complex Security Systems
•PBX and VoIP Installations
Features
Key User Benefits
Rack/Tower Versatility — Adapt to changing needs with
horizontal rack or vertical tower installation options.
Removable LCD Control Panel — Easily check 38 UPS statuses and
customize operating settings from up to ten feet away, with optional cable, when the UPS is
installed in a hard-to-reach location.
Step-Down Transformer — Support both 120V and 200-240V output requirements with a single UPS
solution. On select models.
•Double-Conversion Topology
Extended Runtime Battery Modules — Expand runtime and restore full backup power faster with EBMs
featuring Fast Charge Technology.
•0.9 Power Factor
Hot-Swappable Batteries — Eliminate downtime with hot-swappable batteries.
•Pure Sine Wave Output
3-Cycle Battery Charging — Reduce heat and improve UPS battery life up to five years with the Smart
Battery Management (SBM) charging system.
•Removable LCD Control Panel
•Fast Charge Technology
•Selectable Output Voltages
•Generator Mode
•GreenPower UPS ECO Mode
•PowerPanel Business Software
GreenPower UPS™ ECO Mode — Save on electrical and cooling costs by using the configurable ECO Mode
to improve UPS efficiency up to 95%.
Remote Management — PowerPanel Business® Edition management software provides unsurpassed
control and protection of the UPS and connected equipment and allows for remote management of the
protected devices on the network.
Total Protection
Battery Technology
Fast Charge Technology
Backup power supply is returned to 100% capacity quicker with
Fast Charge Technology, because each Extended Battery Module attached
to the UPS has its own charger. Typical systems share a single charger for all
attached battery modules, increasing the time required to fully restore
backup power.
Smart Battery Management (SBM)
SBM is an intelligent battery charging system that extends
the functional life of a UPS battery. It works by charging
the battery in several phases, avoiding the constant trickle
charge that can reduce battery life in units without
SBM technology.
In addition to the advanced battery charger, SBM also reduces battery
deterioration caused by excessive heat during working cycles.
These combined features result in extended periods between UPS
battery replacements.
All new Smart App Online Extended Battery Modules include new
Fast Charge Technology.
4
1.877.297.6937
Fast Charge Technology
DOUBLE-CONVERSION
B
A
K
I
C
J
H
3U
G
L
M
N
F
D
E
P
O
3U
R
Q
OL10000RT3U
A
Input Breaker
F
Critical Load Outlet
K
SNMP Slot
P
Battery Output 240V
B
Noncritical Load Outlets
G
Serial, USB, Remote LCD Ports
L
Extended Battery Port
Q
EBM Connection
C
Output Breaker
H
High Volume Fan
M
EPO Port
R
DC Breaker
D
Hard-Wired Input
I
RJ45 Protection
N
Back-Feed Protection
E
Hard-Wired Output
J
Relay Output
O
Battery AC Input/Output
Rack/Tower UPS Specifications
Pure Sine Wave Models
Model
Input
OL10000RT3U
Output
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
6000/
5400
15.8/5.3
200–240
40–70
L6-30P
L6-20R (2)
L6-30R (2)
OL6000RT3U
OL8000RT3U
6kVA – 10kVA
8000/
7200
10000/
9000
13/5
200–240
40–70
HW
11/4
200–240
40–70
HW
On
Battery
Voltage
(VAC)
L6-30R (3)
HW (1)
L6-30R (3)
HW (1)
200, 208,
220, 230,
240
On
Battery
Frequency
(Hz)
50/60
±0.25%
50/60
±0.25%
50/60
±0.25%
General
Comm.
Ports
HID USB,
Serial, SNMP,
EPO
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended
Battery Module
6
6U
a
BP240V30ART3U
N/A
6U
a
BP240V30ART3U
N/A
6U
a
BP240V30ART3U
Extended Battery Module
Model
BP240V30ART3U
Visit website for added runtimes.
UPS Compatibility
OL6000RT3U, OL8000RT3U, OL10000RT3U
Recharge Time
Voltage
Battery
(Qty)
4 Hours
240V
12V/7.2AH (20)
Dimensions
WxHxD (in)
Weight (lbs)
Warranty
17 x 5.2 x 26
167.2
3 Years
cpsww.com
5
SMART APP SERIES
A
B
3U
B
C
A
A
A
A
E
M
K
A
L
J
D
I
3U
N
F
P
O
H
G
R
3U
Q
T
S
OL8000RT3UTF
A
Output Breaker
E
Noncritical Load Outlets
I
Serial, USB, Remote LCD Ports
M
SNMP Slot
Q
Battery AC Input/Output
B
L6-20R/L6-30R Outlets
F
Hard-Wired Input
J
High Volume Fan
N
Extended Battery Port
R
Battery Output 240V
C
120V 5-20R Outlets
G
Hard-Wired Output
K
RJ45 Protection
O
EPO Port
S
EBM Connection
D
Input Breaker
H
Critical Load Outlet
L
Relay Output
P
Back-Feed Protection
T
DC Breaker
Rack/Tower UPS with Step-Down Transformer Specifications
Pure Sine Wave Models
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
6000/
5400
15.8/5.3
200–240
40–70
L6-30P
L6-20R (2)
L6-30R (1)
5-20R (12)
OL8000RT3UTF
8000/
7200
13/5
OL10000RT3UTF
10000/
9000
OL6000RT3UTF
1.877.297.6937
11/4
200–240
200–240
40–70
40–70
6kVA – 10kVA
Output
Capacity
(VA/
Watts)
Model
6
Input
HW
HW
L6-20R (2)
L6-30R (4)
HW (1)
5-20R (12)
On
Battery
Voltage
(VAC)
120 and
200, 208,
220, 230,
240
On
Battery
Frequency
(Hz)
50/60
±0.25%
50/60
±0.25%
50/60
±0.25%
General
Comm.
Ports
HID USB,
Serial, SNMP,
EPO
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended
Battery Module
6
8U
a
BP240V30ART3U
N/A
9U
a
BP240V30ART3U
N/A
9U
a
BP240V30ART3U
DOUBLE-CONVERSION
D
A
J
H
B
I
C
G
3U
F
E
N
K
M
L
O
R
N
P
Q
3U
T
N
S
OL10000RT3UPDU
A
Input Breaker
F
Serial, USB, Remote LCD Ports
K
Extended Battery Port
P
Critical Load Outlets
B
Safety Lock
G
High Volume Fan
L
EPO Port
Q
Battery AC Input & Output
C
Maintenance Bypass Switch
H
RJ45 Protection
M
Back-Feed Protection
R
Battery Output 240V
D
Hard-Wired Input
I
Relay Output
N
Output Breaker
S
EBM Connection
E
Hard-Wired Output
J
SNMP Slot
O
Noncritical Load Outlets
T
DC Breaker
Hot-Swappable Rack/Tower UPS Specifications
Pure Sine Wave Models
Model
OL10000RT3UPDU
Output
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
6000/
5400
15.8/5.3
200–240
40–70
HW
OL6000RT3UPDU
OL8000RT3UPDU
6kVA – 10kVA
Input
8000/
7200
10000/
9000
13/5
200–240
40–70
HW
11/4
200–240
40–70
HW
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
L6-20R (2)
L6-30R (4)
HW (1)
200, 208,
220, 230,
240
On
Battery
Frequency
(Hz)
50/60
±0.25%
50/60
±0.25%
50/60
±0.25%
General
Comm.
Ports
HID USB,
Serial, SNMP,
EPO
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended
Battery Module
N/A
6U
a
BP240V30ART3U
N/A
6U
a
BP240V30ART3U
N/A
6U
a
BP240V30ART3U
Extended Battery Module
Model
BP240V30ART3U
Visit website for added runtimes.
UPS Compatibility
OL6000RT3UTF, OL8000RT3UTF, OL10000RT3UTF
OL6000RT3UPDU, OL8000RT3UPDU, OL10000RT3UPDU
Recharge Time
Voltage
Battery
(Qty)
4 Hours
240V
12V/7.2AH (20)
Dimensions
WxHxD (in)
Weight (lbs)
Warranty
17 x 5.2 x 26
167.2
3 Years
cpsww.com
7
SMART APP SERIES
B
A
A
2U
A
A
A
C
L
F
D
J
E
K
I
3U
H
G
M
N
O
S
Q
P
3U
R
U
A
T
OL6000RT3UPDUTF
A
Output Breaker
G
Hard-Wired Output
M
Extended Battery Port
S
Battery Output 240V
B
5-20R Outlets
H
Serial, USB, Remote LCD Ports
N
EPO Port
T
EBM Connection
C
Input Breaker
I
High Volume Fan
O
Back-Feed Protection
U
DC Breaker
D
Safety Lock
J
RJ45 Protection
P
Noncritical Load Outlets
E
Maintenance Bypass Switch
K
Relay Output
Q
Critical Load Outlets
F
Hard-Wired Input
L
SNMP Slot
R
Battery AC Input & Output
Hot-Swappable Rack/Tower UPS with Step-Down Transformer Specifications
Pure Sine Wave Models
Model
OL6000RT3UPDUTF
OL8000RT3UPDUTF
OL10000RT3UPDUTF
8
1.877.297.6937
Input
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
6000/
5400
15.8/5.3
200–240
40–70
HW
L6-20R (2)
L6-30R (3)
HW (1)
5-20R (12)
8000/
7200
10000/
9000
6kVA – 10kVA
Output
13/5
200–240
40–70
HW
11/4
200–240
40–70
HW
L6-20R (4)
L6-30R (5)
HW (1)
5-20R (12)
On
Battery
Voltage
(VAC)
120 and
200, 208,
220, 230,
240
On
Battery
Frequency
(Hz)
50/60
±0.25%
50/60
±0.25%
50/60
±0.25%
General
Comm.
Ports
HID USB,
Serial, SNMP,
EPO
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended
Battery Module
N/A
8U
a
BP240V30ART3U
N/A
9U
a
BP240V30ART3U
N/A
9U
a
BP240V30ART3U
DOUBLE-CONVERSION
I
A
D
B
J
H
C
G
F
3U
E
L
K
M
O
N
3U
Q
P
OL10000RT3UHW
A
Input Breaker
F
Serial, USB, Remote LCD Ports
K
Extended Battery Port
P
EBM Connection
Q
DC Breaker
B
Safety Lock
G
High Volume Fan
L
EPO Port
C
Maintenance Bypass Switch
H
RJ45 Protection
M
Back-Feed Protection
D
Hard-Wired Input
I
Relay Output
N
Battery AC Input & Output
E
Hard-Wired Output
J
SNMP Slot
O
Battery Output 240V
Hot-Swappable Hard-Wired Rack/Tower UPS Specifications
Pure Sine Wave Models
Model
Input
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
6000/
5400
15.8/5.3
200–240
40–70
HW
OL6000RT3UHW
OL8000RT3UHW
OL10000RT3UHW
8000/
7200
10000/
9000
6kVA – 10kVA
Output
13/5
200–240
40–70
HW
11/4
200–240
40–70
HW
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
HW (1)
200, 208,
220, 230,
240
On
Battery
Frequency
(Hz)
50/60
±0.25%
50/60
±0.25%
50/60
±0.25%
General
Comm.
Ports
HID USB,
Serial, SNMP,
EPO
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended
Battery Module
N/A
6U
a
BP240V30ART3U
N/A
6U
a
BP240V30ART3U
N/A
6U
a
BP240V30ART3U
Extended Battery Module
Model
BP240V30ART3U
Visit website for added runtimes.
UPS Compatibility
OL6000RT3UPDUTF, OL8000RT3UPDUTF, OL10000RT3UPDUTF,
OL6000RT3UHW, OL8000RT3UHW, OL10000RT3UHW
Recharge Time
Voltage
Battery
(Qty)
4 Hours
240V
12V/7.2AH (20)
Dimensions
WxHxD (in)
Weight (lbs)
Warranty
17 x 5.2 x 26
167.2
3 Years
cpsww.com
9
SMART APP SERIES
Smart App Online
6kVA – 10kVA Tower OL Models
Waveform Output
Typical Applications
•Corporate Data Centers
•Corporate Servers
•Network and Storage Devices
•Complex Security Systems
Smart App Online tower UPS models, with Double-Conversion topology,
provide pure sine wave output to mission-critical applications and equipment
requiring seamless power correction. These units offer generator compatibility
and deliver clean AC power with zero transfer time.
Key User Benefits
Removable LCD Control Panel — Easily check 38 different UPS statuses and
customizable operating settings from up to ten feet away, with optional cable,
when the UPS is installed in a hard-to-reach location.
Step-Down Transformer — Support both 120V and 200-240V output
requirements with a single UPS solution. On select models.
•PBX and VoIP Installations
Extended Battery Modules (EBM) — Expand runtime and restore full backup
power faster with EBMs featuring Fast Charge Technology.
Features
Hot-Swappable Batteries — Eliminate downtime with hot-swappable batteries.
•Double-Conversion Topology
Smart Battery Management (SBM) — Reduce heat and improve UPS battery life up to
five years with the three cycle battery charging system.
•0.9 Power Factor
•Pure Sine Wave Output
•Removable LCD Control Panel
•Fast Charge Technology
GreenPower UPS™ ECO Mode — Save on electrical and cooling costs by using the configurable ECO Mode
to improve UPS efficiency up to 95%.
Remote Management — PowerPanel® Business Edition management software provides unsurpassed
control and protection of the UPS and connected equipment and allows for remote management of the
protected devices on the network.
•Selectable Output Voltages
•Generator Mode
•GreenPower UPS ECO Mode
•PowerPanel Business Software
Total Protection
LCD Control Panel
Removable LCD Control Panel
When the UPS is installed in a hard-to-reach area, such as the bottom of a
rack, in a crowded IT closet or on the floor, the LCD control panel may be
removed and relocated for easy access up to ten feet away, when connected
by a DB26 cable (sold separately) to the front or back of the UPS.
Menu Functions
UPS Status — Displays 19 vital UPS statuses including input and output
voltage, battery information, runtime estimates, load data and more.
LCD Settings Configuration — Offers customization of the UPS with 38
specific operation parameters including output voltage, sync frequency,
alarm settings and more.
Event Log — Allows recording of all UPS events with or without PowerPanel
Business Edition management software.
Multi-Language — Display text in English, Spanish or French.
Disable Audible Alarms — Turn off audible alarms as needed.
Manual Battery Test — Enables self-testing to ensure the UPS is
operating properly.
10
1.877.297.6937
This innovative LCD interface permits users to check UPS status, diagnose
problems and manage setup on-site, in addition to convenient configuration
with PowerPanel® Business Edition management software and optional
remote management of the unit.
DOUBLE-CONVERSION
A
C
E
B
B
SNMP Slot
Back-Feed Protection
D
Relay Output
E
Serial, USB, Remote LCD Ports
F
High Volume Fan
G
Input Breaker
H
Output Breaker
I
Noncritical Load Outlets
J
RJ45 Protection
K
Extended Battery Port
L
Critical Load Outlets
M
Hard-Wired AC Bypass
N
Hard-Wired AC Input
O
Hard-Wired AC Output
P
Steel Caster
Q
Leveling Feet
H
G
H
F
23.6”
H
EPO Port
C
D
F
A
I
K
J
M
N
L
23.6”
O
P
Q
The Extended Battery Module offers
increased runtimes during power outages.
OL8000 / OL10000
Tower UPS Specifications
6kVA – 10kVA
Pure Sine Wave Models
Model
OL6000
OL8000
OL10000
Input
Output
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
6000/
5400
15.8/5.3
200–240
40–70
HW
8000/
7200
10000/
9000
13/5
200–240
40–70
HW
11/4
200–240
40–70
HW
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
HW (1)
L6-20R (4)
L6-30R (2)
200, 208,
220, 230,
240
General
On
Battery
Frequency
(Hz)
50/60
±0.25%
50/60
±0.25%
50/60
±0.25%
Comm.
Ports
HID USB
Serial
SNMP
EPO
Cord
Length
(ft)
Dimensions
WxHxD (in)
Energy
Saving
Compatible
Extended
Battery Module
N/A
10.4 x 23.6 x 26
a
BP240V30A
N/A
10.4 x 23.6 x 26
a
BP240V50A
N/A
10.4 x 23.6 x 26
a
BP240V50A
Extended Battery Module
Model
Visit website for added runtimes.
UPS Compatibility
Recharge Time
Voltage
Battery
(Qty)
Dimensions
WxHxD (in)
Weight (lbs)
Warranty
BP240V30A
OL6000
4 Hours
240V
12V/7.2AH (20)
10.4 x 23.6 x 26
167.2
3 Years
BP240V50A
OL8000, OL10000
5 Hours
240V
12V/9AH (20)
10.4 x 23.6 x 26
167.2
3 Years
cpsww.com
11
SMART APP SERIES
A
C
B
E
D
F
I
H
H
J
G
F
H
23.6”
H
H
A
EPO Port
B
SNMP Slot
C
Back-Feed Protection
D
Relay Output
E
Serial, USB, Remote LCD Ports
F
High Volume Fan
G
Input Breaker
H
Output Breaker
I
Noncritical Load Outlets
J
RJ45 Protection
K
Extended Battery Port
L
Critical Load Outlets
M
Hard-Wired AC Bypass
N
Hard-Wired AC Input
O
Hard-Wired AC Output
P
Steel Caster
Q
Leveling Feet
H
I
K
J
18.2”
H
M
H
N
L
O
N
P
Q
OL8000TF / OL10000TF
Tower UPS with Step-Down Transformer Specifications
Pure Sine Wave Models
Model
OL6000TF
OL8000TF
OL10000TF
6kVA – 10kVA
Input
Output
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
6000/
5400
15.8/5.3
200–240
40–70
HW
8000/
7200
10000/
9000
13/5
200–240
40–70
HW
11/4
200–240
40–70
HW
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
5-20R (12)
L6-20R (4)
L6-30R (6)
120 and
200, 208,
220, 230,
240
General
On
Battery
Frequency
(Hz)
50/60
±0.25%
50/60
±0.25%
50/60
±0.25%
Comm.
Ports
HID USB
Serial
SNMP
EPO
Cord
Length
(ft)
UPS/Transformer
Dimensions
WxHxD (in)
Energy
Saving
Compatible
Extended
Battery Module
N/A
10.4 x 23.6 x 26/
10.4 x 18.2 x 16.9
a
BP240V30A
a
BP240V50A
a
BP240V50A
N/A
N/A
Extended Battery Module
Model
12
10.4 x 23.6 x 26/
10.4 x 18.2 x 16.9
10.4 x 23.6 x 26/
10.4 x 18.2 x 16.9
Visit website for added runtimes.
UPS Compatibility
Recharge Time
Voltage
Battery
(Qty)
Dimensions
WxHxD (in)
Weight (lbs)
Warranty
BP240V30A
OL6000TF
4 Hours
240V
12V/7.2AH (20)
10.4 x 23.6 x 26
167.2
3 Years
BP240V50A
OL8000TF, OL10000TF
5 Hours
240V
12V/9AH (20)
10.4 x 23.6 x 26
167.2
3 Years
1.877.297.6937
DOUBLE-CONVERSION
A
C
E
B
D
F
F
A
EPO Port
B
SNMP Slot
C
Back-Feed Protection
D
Relay Output
E
Serial, USB, Remote LCD Ports
F
High Volume Fan
G
Input Breaker
H
RJ45 Protection
I
Extended Battery Port
J
Hard-Wired AC Bypass
K
Hard-Wired AC Input
L
Hard-Wired AC Output
M
Steel Caster
N
Leveling Feet
G
23.6”
I
H
J
K
23.6”
L
M
M
N
The Extended Battery Module offers
increased runtimes during power outages.
OL8000HW / OL10000HW
Hard-Wired Tower UPS Specifications
Pure Sine Wave Models
Model
OL6000HW
OL80000HW
OL10000HW
6kVA – 10kVA
Input
Output
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
6000/
5400
15.8/5.3
200–240
40–70
HW
8000/
7200
10000/
9000
13/5
200–240
40–70
HW
11/4
200–240
40–70
HW
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
HW (1)
200, 208,
220, 230,
240
General
On
Battery
Frequency
(Hz)
50/60
±0.25%
50/60
±0.25%
50/60
±0.25%
Comm.
Ports
HID USB
Serial
SNMP
EPO
Cord
Length
(ft)
Dimensions
WxHxD (in)
Energy
Saving
Compatible
Extended
Battery Module
N/A
10.4 x 23.6 x 26
a
BP240V30A
N/A
10.4 x 23.6 x 26
a
BP240V50A
N/A
10.4 x 23.6 x 26
a
BP240V50A
Extended Battery Module
Model
Visit website for added runtimes.
UPS Compatibility
Recharge Time
Voltage
Battery
(Qty)
Dimensions
WxHxD (in)
Weight (lbs)
Warranty
BP240V30A
OL6000HW
4 Hours
240V
12V/7.2AH (20)
10.4 x 23.6 x 26
167.2
3 Years
BP240V50A
OL8000HW, OL10000HW
5 Hours
240V
12V/9AH (20)
10.4 x 23.6 x 26
167.2
3 Years
cpsww.com
13
SMART APP SERIES
C
A
E
B
D
F
I
H
G
J
F
23.6”
A
EPO Port
B
SNMP Slot
C
Back-Feed Protection
D
Relay Output
E
Serial, USB, Remote LCD Ports
F
High Volume Fan
G
Input Breaker
H
Output Breaker
I
Noncritical Load Outlets
J
Critical Load Outlets
K
RJ45 Protection
L
Extended Battery Port
M
Hard-Wired Bypass
N
Hard-Wired Input
O
Hard-Wired Output
P
Steel Caster
Q
Leveling Feet
H
L
K
18.2”
H
M
H
N
N
O
P
P
Q
OL6000HWTF
Hard-Wired Tower UPS with Step-Down Transformer Specifications
Pure Sine Wave Models
Model
OL6000HWTF
OL8000HWTF
OL10000HWTF
Input
Output
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
6000/
5400
15.8/5.3
200–240
40–70
HW
13/5
200–240
40–70
HW
11/4
200–240
40–70
HW
8000/
7200
10000/
9000
6kVA – 10kVA
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
5-20R (2)
L6-20R (2)
L6-30R (12)
HW(1)
120 and
200, 208,
220, 230,
240
General
On
Battery
Frequency
(Hz)
50/60
±0.25%
Comm.
Ports
Cord
Length
(ft)
UPS/Transformer
Dimensions
WxHxD (in)
Energy
Saving
Compatible
Extended
Battery Module
N/A
10.4 x 23.6 x 26/
10.4 x 18.2 x 16.9
a
BP240V30A
a
BP240V50A
a
BP240V50A
HID USB
Serial
SNMP
EPO
50/60
±0.25%
50/60
±0.25%
N/A
N/A
Extended Battery Module
Model
14
10.4 x 23.6 x 26/
10.4 x 18.2 x 16.9
10.4 x 23.6 x 26/
10.4 x 18.2 x 16.9
Visit website for added runtimes.
UPS Compatibility
Recharge Time
Voltage
Battery
(Qty)
Dimensions
WxHxD (in)
Weight (lbs)
Warranty
BP240V30A
OL6000HWTF
4 Hours
240V
12V/7.2AH (20)
10.4 x 23.6 x 26
167.2
3 Years
BP240V50A
OL8000HWTF, OL10000HWTF
5 Hours
240V
12V/9AH (20)
10.4 x 23.6 x 26
167.2
3 Years
1.877.297.6937
DOUBLE-CONVERSION
Smart App Online
1kVA – 3kVA Tower & Rack/Tower Convertible OL Models
Waveform Output
Typical Applications
•Corporate Data Centers
•Corporate Servers
•Network and Storage Devices
•Complex Security Systems
•PBX and VoIP Installations
Features
•Double-Conversion Topology
•Pure Sine Wave Output
•Removable LCD Control Panel
•Fast Charge Technology
•Selectable Output Voltages
Smart App Online rack/tower UPS models provide pure sine wave output to mission-critical
servers and equipment requiring seamless power correction. Equipped with DoubleConversion topology, these units offer generator compatibility and deliver clean AC power
with zero transfer time.
Key User Benefits
Removable LCD Control Panel — Easily check 43 different UPS statuses and customizable
operating settings from up to ten feet away, with optional cable, when the UPS is installed in a
hard-to-reach location.
Extended Battery Modules (EBM) — Expand runtime and restore full backup power faster
with EBMs featuring Fast Charge Technology.
Hot-Swappable Batteries — Eliminate downtime with hot-swappable batteries.
Smart Battery Management (SBM) — Reduce heat and improve UPS battery life up to
five years with the three cycle battery charging system.
Rack/Tower Versatility — Adapt to changing needs with horizontal rack or vertical tower
installation options.
GreenPower UPS™ ECO Mode — Save on electrical and cooling costs by using the
configurable ECO Mode to improve UPS efficiency up to 93%.
Remote Management — PowerPanel® Business Edition management software provides unsurpassed
control and protection of the UPS and connected equipment and allows for remote management of the
protected devices on the network.
•Generator Mode
•GreenPower UPS ECO Mode
•PowerPanel Business Software
Total Protection
Higher Capacity UPS for Longer Runtimes
The total power load of connected equipment to be protected by an installed
UPS and the expected runtime of the unit are two key factors in determining
what size UPS (in terms of its VA/Watt rating) is best suited to a particular
application. If it is anticipated that additional devices will be connected to the
UPS in the future, thus increasing the power load, this should be considered
as well.
Estimating expected UPS runtimes can be challenging, particularly in areas
where the consistency of the utility power is not well known. Selecting a
UPS with a load capacity 30-35% above the required power load offers the
advantage of longer runtimes, thereby adding what could prove to be an
important margin of safety to an installation’s power protection. While the
initial outlay for a UPS increases with its size, due to the higher capacity
components required, operating costs are typically lower in the long run
because component wear and tear is reduced when the UPS operates below
maximum capacity. The ability to provide longer runtimes is also added
insurance against a potentially lengthy power outages.
In addition to extended runtimes, sizing a UPS to run at loads that are
significantly lower than its capacity also effectively increases battery life,
minimizing the likelihood of battery failure, a leading cause of load loss.
cpsww.com
15
SMART APP SERIES
G
H
A
B
2U
J
C
D
E
F
I
K
OL1000RTXL2U / OL1500RTXL2U
A
H
E
B
2U
J
G
K
D
C
F
K
OL2200RTXL2U
I
A
E
I
H
B
2U
J
G
K
D
C
F
K
OL3000RTXL2U
A
USB, Serial Ports
D
Cooling Fan
G
RJ45 Protection
J
Critical Load Outlets
B
Relay Outputs
E
SNMP Slot
H
Input Breaker
K
Noncritical Load Outlets
C
EPO Port
F
Extended Battery Port
I
Output Breaker
Rack/Tower UPS Specifications
Pure Sine Wave Models
Output
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
OL1000RTXL2U
1000/
900
18/6
60-150
40–70
5-15P
5-15R (8)
OL1500RTXL2U
1500/
1350
9/3
60-150
40–70
5-15P
5-15R (8)
OL2200RTXL2U
2200/
1800
18/6
60-150
40–70
L5-30P
5-20R (6)
L5-20R (1)
OL3000RTXL2U
3000/
2700
9/3
60-150
40–70
L5-30P
5-20R (6)
L5-30R (1)
Model
16
1kVA – 3kVA
Input
1.877.297.6937
On
Battery
Voltage
(VAC)
100, 110,
115, 120,
125 ±2%
100, 110,
115, 120,
125 ±2%
100, 110,
115, 120,
125 ±2%
100, 110,
115, 120,
125 ±2%
On
Battery
Frequency
(Hz)
50/60
±0.25%
50/60
±0.25%
50/60
±0.25%
50/60
±0.25%
General
Comm.
Ports
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended
Battery Module
10
2U
a
BP36V60ART2U
10
2U
a
BP36V60ART2U
10
2U
a
BP72V60ART2U
10
2U
a
BP72V60ART2U
DOUBLE-CONVERSION
B
A
C
D
E
F
A
SNMP Slot
B
EPO Port
C
USB, Serial Ports
D
Cooling Fans
E
Extended Battery Port
F
Relay Output
G
Noncritical Load Outlets
H
Critical Load Outlets
I
Output Breaker
J
Input Breaker
K
RJ45 Protection
13.3”
G
D
I
G
I
13.3”
K
H
J
The Extended Battery Module offers
increased runtimes during power outages.
OL3000XL
Tower UPS Specifications
1kVA – 3kVA
Pure Sine Wave Models
Input
Output
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
OL1000XL
1000/
900
18/6
60-150
40–70
5-15P
5-15R (9)
OL1500XL
1500/
1350
9/3
60-150
40–70
5-15P
5-15R (9)
OL2200XL
2200/
1800
18/6
60-150
40–70
L5-30P
5-20R (6)
L5-20R (1)
OL3000XL
3000/
2700
9/3
60-150
40–70
L5-30P
5-20R (6)
L5-30R (1)
Model
On
Battery
Voltage
(VAC)
100, 110,
115, 120,
125 ±2%
100, 110,
115, 120,
125 ±2%
100, 110,
115, 120,
125 ±2%
100, 110,
115, 120,
125 ±2%
General
On
Battery
Frequency
(Hz)
50/60
±0.25%
50/60
±0.25%
50/60
±0.25%
50/60
±0.25%
Comm.
Ports
Cord
Length
(ft)
Dimensions
WxHxD (in)
Energy
Saving
Compatible
Extended
Battery Module
10
6.3 x 9.1 x 16
a
BP36V60A
10
6.3 x 9.1 x 16
a
BP36V60A
10
8.3 x 13.3 x 16.3
a
BP72V60A
10
8.3 x 13.3 x 16.3
a
BP72V60A
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
Extended Battery Module
Model
Visit website for added runtimes.
UPS Compatibility
Recharge Time
Voltage
Battery
(Qty)
Dimensions
WxHxD (in)
Weight (lbs)
Warranty
BP36V60ART2U
OL1000RTXL2U, OL1500RTXL2U
5 Hours
36V
12V/9.0AH (6)
17 x 3.5 x 16.9
50.6
3 Years
BP72V60ART2U
OL2200RTXL2U, OL3000RTXL2U
5 Hours
72V
12V/9.0AH (12)
17 x 3.5 x 23.6
96.8
3 Years
BP36V60A
OL1000XL, OL1500XL
5 Hours
36V
12V/9.0AH (6)
6.3 x 9.1 x 16
48.5
3 Years
BP72V60A
OL2200XL, OL3000XL
5 Hours
72V
12V/9.0AH (12)
8.3 x 13.3 x 16.3
97
3 Years
cpsww.com
17
SMART APP SERIES
Smart App Sinewave
750VA – 6000VA Rack/Tower Convertible PR Models
Waveform Output
Typical Applications
•Corporate Servers
•Department Servers
•Storage Appliances
•Network Devices
•Telecom Installations
Features
•Line-Interactive Topology
•Pure Sine Wave Output
•100% Active PFC Compatible
•Full Buck/Boost AVR
•Rotatable Multifunction Panel
•GreenPower UPS Bypass Design
Smart App Sinewave rack/tower UPS models, with Line-Interactive topology, fulfill
the demands of corporate and departmental applications with pure sine wave output.
Offering Active PFC power source compatibility, these units correct minor power
fluctuations without switching to battery, thereby extending battery life—essential in
areas where power fluctuations occur frequently.
Key User Benefits
Pure Sine Wave Output — Provide power protection to Energy Star 5.0 systems with
Active PFC power supplies.
Automatic Voltage Regulation (AVR) — Protect connected equipment and prevent
costly business interruptions with full buck/boost technology, delivering clean and
consistent AC power to your electrical installations.
Multifunction Display Panel — Quickly and easily monitor all critical UPS operating
parameters. Rotatable panel on 2U models permits status checking whether the
UPS is installed vertically or horizontally.
GreenPower UPS™ Bypass Design — Save UPS energy costs by reducing energy
consumption and heat buildup.
Rack/Tower Versatility — Adapt to changing needs with horizontal rack or vertical tower
installation options.
Remote Management — PowerPanel® Business Edition management software provides unsurpassed
control and protection of the UPS and connected equipment and allows for remote management of the
protected devices on the network.
•PowerPanel Business Software
Professional Protection
Efficient Remote Management
The Smart App Series includes full-featured network UPS management
capabilities using the included PowerPanel Business Edition software
suite and an optional SNMP/Network management card. These remote
management tools enable centralized UPS management, monitoring,
control and configuration, as well as safe shutdown of connected servers,
workstations and other devices via a standard web browser or network
management system (NMS). See pages 36 and 37 for more details.
Safe Shutdown
The PowerPanel Business Edition software suite, included with every
Smart App Sinewave UPS, enables an administrator to remotely manage
every aspect of the UPS and facilitate the orderly automatic shutdown of
connected equipment in the event of an extended power outage.
The software also provides comprehensive network power management for
corporate servers and critical workstations supported by the UPS, such as:
application/OS shutdown, event logging, reporting, alerts and notifications.
Programmable Outlet Control
Smart App UPS systems allow programming of critical outlets over
secondary outlets. This gives administrators the ability to prioritize outlets
and increase battery backup runtimes for the most critical equipment during
extended power outages. Programmable outlet control also gives the
administrator the option to delay-start the UPS, permitting the full recharge
of its internal batteries before power is restored. This feature is vital to
datacenter installations where seamless, uninterrupted equipment boot-up is
a necessity.
18
1.877.297.6937
LINE-INTERACTIVE
B
A
C
H
F
E
D
G
K
1U
M
N
PR750LCDRM1U / PR1000LCDRM1U
D
E
I
F
M
L
2U
H
G
N
L
J
K
K
PR2200LCDRT2U
The LCD display panel provides critical
load and battery information.
A
Multifunction LCD
H
EPO Port
B
Power Safety Cover
I
RG6 Coax Protection
C
Select Button
J
RJ11/45 Protection
D
Noncritical Load Outlets
K
Serial Port
E
Critical Load Outlets
L
Output Breaker
F
SNMP Slot
M
Input Breaker
G
USB Port
N
Cooling Fan
Rack/Tower UPS Specifications Pure Sine Wave Models
750VA – 3000VA
Input
Output
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
On
Battery
Frequency
(Hz)
PR750LCDRM1U
750/
560
23/7
80–150
50–60±3
5-15P
(6) 5-15R
120±5%
50/60
±0.1%
PR1000LCDRM1U
1000/
750
14/5
80–150
50–60±3
5-15P
(6) 5-15R
120±5%
50/60
±0.1%
PR1000LCDRT2U 3
1000/
700
32/11
80–150
50–60±3
5-15P
(8) 5-15R
120±5%
50/60
±0.1%
PR1500LCDRT2U 3
1500/
1000
18/6
80–150
50–60±3
5-15P
(8) 5-15R
120±5%
50/60
±0.1%
PR2200LCDRT2U 3
2170/
1600
16/6
80–150
50–60±3
5-20P
(8) 5-15/20R
120±5%
50/60
±0.1%
PR3000LCDRT2U 3
3000/
2250
8/3
80–150
50–60±3
L5-30P
(8) 5-20R
(1) L5-30R
120±5%
50/60
±0.1%
Model
General
Comm.
Ports
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended Battery
Module
10
1U
a
N/A
10
1U
a
N/A
10
2U
a
N/A
10
2U
a
N/A
10
2U
a
N/A
10
2U
a
BP48V75ART2U3
3TAA compliant model available.
cpsww.com
19
SMART APP SERIES
B
A
C
2U
PR1000LCDRTXL2Ua / PR1500LCDRTXL2U
2U
PR3000LCDRTXL2U
A
Multifunction LCD
E
Critical Load Outlets
I
SNMP Port
M
Input Breaker
B
Power Safety Cover
F
Output Breaker
J
USB Port
N
RG6 Coax Protection
C
Select Button
G
Extended Battery Port
K
Serial Ports
O
RJ11/45 Protection
D
Noncritical Load Outlets
H
Cooling Fan
L
EPO Port
Rack/Tower XL UPS Specifications
Pure Sine Wave Models
Input
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
PR1000LCDRTXL2U
1000/
700
32/11
80–150
PR1000LCDRTXL2Ua
1000/
750
39/18
PR1500LCDRTXL2U3
1500/
1125
PR2200LCDRTXL2U3
PR3000LCDRTXL2U3
Model
1.877.297.6937
Output
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
On
Battery
Frequency
(Hz)
50–60±3
5-15P
5-15R (6)
120±5%
50/60
±0.1%
80–150
50–60±3
5-15P
5-15R (8)
120±5%
50/60
±0.1%
24/9
80–150
50–60±3
5-15P
5-15R (8)
120±5%
50/60
±0.1%
2150/
1650
14/5
80–150
50–60±3
5-20P
5-15/20R (8)
120±5%
50/60
±0.1%
3000/
2400
8/3
80–150
50–60±3
L5-30P
5-20R (6)
L5-30R (1)
120±5%
50/60
±0.1%
3TAA compliant model available.
20
1000VA – 3000VA
General
Comm.
Ports
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended Battery
Module
10
2U
a
BP48V45ART2U
10
2U
a
BP48V75ART2U3
10
2U
a
BP48V75ART2U3
10
2U
a
BP48V75ART2U3
10
2U
a
BPL48V75ART2U3
LINE-INTERACTIVE
F
A
G
B
D
E
H
C
5U
I
J
L
K
L
PR5000LCDRTXL5U / PR6000LCDRTXL5U
A
Input Breaker
G
EPO Port
B
Output Breaker
H
RJ11/45 Protection
C
Input Power Cord
I
Noncritical Load Outlets
D
SNMP Slot
J
Critical Load Outlets
E
Serial Ports
K
Extended Battery Port
F
USB Port
L
High Volume Fan
The LCD display panel provides critical
load and battery information.
Rack/Tower XL UPS Specifications Pure Sine Wave Models
5000VA – 6000VA
Input
Output
General
Model
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
PR5000LCDRTXL5U3
5000/
4000
31/11
208–240
50–60±3
L6-30P
L6-20R (2)
L6-30R (3)
208±5%
60±0.1%
PR6000LCDRTXL5U
6000/
4500
26/10
208–240
50–60±3
L6-30P
L6-20R (2)
L6-30R (3)
208±5%
60±0.1%
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
On
Battery
Frequency
(Hz)
Comm.
Ports
HID USB,
Serial, SNMP,
EPO
HID USB,
Serial, SNMP,
EPO
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended Battery
Module
10
5U
a
BPL48V75ART2U3
10
5U
a
BPL48V75ART2U3
Extended Battery Module
Model
Visit website for added runtimes.
UPS Compatibility
Recharge Time
Voltage
Battery
(Qty)
Dimensions
WxHxD (in)
Weight (lbs)
Warranty
16 Hours
48V
12V/7AH (8)
17.25 x 3.5 x 15.75
60
3 Years
BP48V45ART2U
PR1000LCDRTXL2U
BP48V75ART2U3
PR1000LCDRTXL2Ua, PR1500LCDRTXL2U,
PR2200LCDRTXL2U, PR3000LCDRT2U
8 Hours
48V
12V/9AH (8)
17.25 x 3.5 x 19.5
67
3 Years
BPL48V75ART2U3
PR3000LCDRTXL2U, PR5000LCDRTXL5U, PR6000LCDRTXL5U
8 Hours
48V
12V/9AH (12)
17.25 x 3.5 x 23.6
96
3 Years
3TAA compliant model available.
cpsww.com
21
SMART APP SERIES
Smart App Sinewave
750VA – 3000VA Tower & Mini-Tower PR Models
Waveform Output
Typical Applications
Smart App Sinewave tower and mini-tower UPS models, with Line-Interactive
topology, fulfill the demands of corporate and departmental applications with
pure sine wave output. Offering Active PFC power source compatibility, these
units correct minor power fluctuations without switching to battery, thereby
extending battery life—essential in areas where power fluctuations
occur frequently.
•Corporate Servers
Key User Benefits
•Department Servers
Pure Sine Wave Output — Provide power protection to Energy Star 5.0 systems
with Active PFC power supplies.
•Storage Appliances
•Telecom Installations
Automatic Voltage Regulation (AVR) — Protect connected equipment and prevent costly business
interruptions with full buck/boost technology, delivering clean and consistent AC power to your electrical
installations.
Features
Extendable LCD Control Panel — Easily check 41 UPS statuses and customizable operating settings from
up to ten feet away, with included cable, when the UPS is installed in a hard-to-reach location.
•Network Devices
•Line-Interactive Topology
•Pure Sine Wave Output
GreenPower UPS™ Bypass Design — Save UPS energy costs by reducing energy consumption and
heat buildup.
•100% Active PFC Compatible
Tower/Mini-Tower Form Factor — Fit these compact units into the tightest spaces.
•Full Buck/Boost AVR
Remote Management — PowerPanel® Business Edition management software provides unsurpassed
control and protection of the UPS and connected equipment and allows for remote management of the
protected devices on the network.
•Extendable LCD Control Panel
•GreenPower UPS Bypass Design
•PowerPanel Business Software
Professional Protection
GreenPower UPS™ Technology
GreenPower UPS Technology from CyberPower consists of three different
energy-saving designs that improve operating efficiency, reduce heat
generation and consume less power than conventional UPS models.
Users can noticeably reduce their energy costs by using a GreenPower
UPS system.
ECO Mode
Our ECO Mode is a form of bypass technology that can be switched on fulltime, set for noncritical times (such as nights and weekends) or switched off.
This design flexibility makes saving power and money an option anytime.
The transformer in a conventional line-interactive UPS loses significant energy
as heat is generated during normal utility power output.
Bypass Design
Our patented Bypass Design allows current to bypass the transformer and
AVR when utility power is normal, thus reducing energy consumption and
associated costs. Since most utility power operates normally 88% of the
time, this design allows for substantial savings on energy costs.
This technology also significantly reduces heat generation, which is an
important factor in reducing operating costs.
High-Efficiency Design
Our High-Efficiency Design significantly reduces power consumption, utilizing
a compact charger and power inverter to create an ultra-efficient backup
power system for home and office use.
22
1.877.297.6937
GreenPower UPS Technology bypasses the transformer when utility power is
normal, reducing energy consumption and heat loss.
LINE-INTERACTIVE
I
J
C
B
K
A
D
L
17”
E
F
G
H
F
PR2200LCD
A
SNMP Port
D
Serial, USB Ports
G
Output Breakers
J
Status Icon LEDs
B
Cooling Fan
E
Noncritical Load Outlets
H
Input Breaker
K
LCD Status Panel
C
EPO Port
F
Critical Load Outlets
I
Extendable Control Panel
L
Setup/Control Buttons
Tower & Mini-Tower UPS Specifications Pure Sine Wave Models
750VA – 3000VA
Input
Output
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
On
Battery
Frequency
(Hz)
PR750LCD3
750/
525
15/3
75–154
47–63
(auto)
5-15P
5-15R (6)
120±5%
50/60
±1%
PR1000LCD3
1000/
700
24.5/7
75–154
47–63
(auto)
5-15P
5-15R (8)
120±5%
50/60
±1%
PR1500LCD3
1500/
1050
24/8
75–154
47–63
(auto)
5-15P
5-15R (8)
120±5%
50/60
±1%
PR2200LCD3
2200/
1980
26/8
75–154
47–63
(auto)
L5-30P
5-15R (8)
5-20R (2)
120±5%
50/60
±1%
PR3000LCD3
3000/
2700
17/6
75–154
47–63
(auto)
L5-30P
5-15R (8)
5-20R (2)
120±5%
50/60
±1%
Model
General
Comm.
Ports
HID USB,
Serial,
SNMP, EPO
HID USB,
Serial,
SNMP, EPO
HID USB,
Serial,
SNMP, EPO
HID USB,
Serial,
SNMP, EPO
HID USB,
Serial,
SNMP, EPO
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended
Battery Module
6
N/A
a
N/A
6
N/A
a
N/A
6
N/A
a
N/A
10
N/A
a
N/A
10
N/A
a
N/A
3TAA compliant model available.
cpsww.com
23
SMART APP SERIES
Smart App LCD
500VA – 2190VA Rack/Tower Convertible OR Models
Waveform Output
Typical Applications
•Department Servers
•Workgroup Servers
•Workstations
•Network Devices
•Telecom Appliances
Features
•Line-Interactive Topology
•Simulated Sine Wave Output
•Full Buck/Boost AVR
•Rotatable Multifunction LCD
•GreenPower UPS Bypass Design
•PowerPanel Business Software
Smart App LCD rack/tower UPS models, with Line-Interactive topology, address the
needs of departmental servers, networking hardware and other equipment capable
of using simulated sine wave output. These units correct minor power fluctuations
without switching to battery, thereby extending battery life—essential in areas where
power fluctuations occur frequently.
Key User Benefits
Simulated Sine Wave Output — Provide cost-effective power protection to servers,
telecom and peripheral electronics.
Automatic Voltage Regulation (AVR) — Protect connected equipment and prevent
costly business interruptions with full buck/boost technology, delivering clean and
consistent AC power to your electrical installations.
Multifunction Display Panel — Quickly and easily monitor all critical UPS
operating parameters. Rotatable LCD panel on 2U models permits status
checking whether the UPS is installed vertically or horizontally. Not available on
CPS1500AVR.
GreenPower UPS™ Bypass Design — Save UPS energy costs by reducing energy
consumption and heat buildup.
Rack/Tower Versatility — Adapt to changing needs with horizontal rack or vertical tower
installation options.
Remote Management — PowerPanel® Business Edition management software provides unsurpassed
control and protection of the UPS and connected equipment and allows for remote management of the
protected devices on the network.
Professional Protection
Real-Time UPS Status and Alerts
The multifunction LCD front panel provides immediate, detailed information
on the UPS battery and power conditions, alerting users to potential
problems before they can affect critical equipment and cause downtime.
Menu Functions
UPS Status — Displays 12 vital UPS parameters including:
•Load/Current Level
•Runtime
•Battery Level
•AVR in use (on 2U units only)
•Battery in Use
•Input Voltage
•Output Voltage
•Output Frequency
•Overload
•Wiring Fault (on 2U units only)
•Silent Mode
•Normal Operation
Rack/tower convertible UPS models (2U) are equipped with a display panel
that can be rotated 90 degrees, to make the screen easily readable whether
the UPS is installed vertically as a tower or horizontally in a rack.
24
1.877.297.6937
LINE-INTERACTIVE
B
A
C
E
D
I
F
G
J
1U
L
OR500LCDRM1U / OR700LCDRM1U / OR1000LCDRM1U / OR1500LCDRM1U
D
D
H
L
K
2U
I
K
G
M
J
OR2200LCDRM2U
A
Multifunction LCD
D
Battery & Surge Protected Outlets
G
USB Port
J
Serial Ports
B
Power Safety Cover
E
Surge Protected Outlets
H
RG6 Coax Protection
K
Output Breaker
C
Select Button
F
SNMP Slot
I
RJ11/45 Protection
L
Input Breaker
M
Rack/Tower UPS Specifications
Simulated Sine Wave Models
Model
Capacity
(VA/
Watts)
500/
300
700/
400
1000/
600
1500/
900
OR500LCDRM1U
OR700LCDRM1U
OR1000LCDRM1U
OR1500LCDRM1U
500VA – 2190VA
Input
Output
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
On
Battery
Frequency
(Hz)
12/3
90–140
57–63
5-15P
5-15R (6)
120±10%
60±1%
11/3
90–140
57–63
5-15P
5-15R (6)
120±10%
60±1%
13/3
90–140
57–63
5-15P
5-15R (6)
120±10%
60±1%
11/2
90–140
57–63
5-15P
5-15R (6)
120±10%
60±1%
OR1500LCDRM2U
1500/
900
18/6
90–140
47–63
5-15P
5-15R (8)
120±10%
60±1%
OR2200LCDRM2U
2000/
1320
13/5
90–140
47–63
5-20P
5-20R (8)
120±10%
60±1%
OR1500LCDRTXL2U
1500/
1125
18/7
90–140
47–63
5-15P
5-15R (8)
120±10%
60±1%
OR2200LCDRTXL2U
2190/
1650
15/6
90–140
47–63
5-20P
5-20R (8)
120±10%
60±1%
CPS1500AVR
1500/
920
18/6
85–150
47–63
5-15P
5-15R (6)
120±10%
60±1%
General
Comm.
Ports
(Qty)
HID USB,
Serial, SNMP
HID USB,
Serial, SNMP
HID USB,
Serial, SNMP
HID USB,
Serial, SNMP
HID USB,
Serial (x2),
SNMP
HID USB,
Serial (x2),
SNMP
HID USB,
Serial (x2),
SNMP
HID USB,
Serial (x2),
SNMP
Serial (x2),
SNMP
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended Battery
Module
10
1U
a
N/A
10
1U
a
N/A
10
1U
a
N/A
10
1U
a
N/A
10
2U
a
N/A
10
2U
a
N/A
10
2U
a
BP48V75ART2U3
10
2U
a
BP48V75ART2U3
10
2U
N/A
N/A
Extended Battery Module
Model
BP48V75ART2U3
Cooling Fan
Visit website for added runtimes.
UPS Compatibility
OR1500LCDRTXL2U, OR2200LCDRTXL2U
Recharge Time
Voltage
Battery
(Qty)
Dimensions
WxHxD (in)
Weight (lbs)
Warranty
8 Hours
48V
12V/9AH (8)
17.25 x 3.5 x 19.5
67
3 Years
3TAA compliant model available.
cpsww.com
25
PFC SINEWAVE SERIES
PFC Sinewave
1500VA – 2200VA Rack/Tower Convertible OR Models
Waveform Output
Typical Applications
•Department Servers
•Workgroup Servers
•Network Devices
•Telecom Appliances
•High-End Audio/Video
Features
•Line-Interactive Topology
PFC Sinewave rack/tower UPS models, with Line-Interactive topology, provide pure sine
wave output to department servers, networking and telecommunications hardware and highend audio/video equipment requiring Active PFC power source compatibility.
These units correct minor power fluctuations without switching to battery, thereby extending
battery life—essential in areas where power fluctuations occur frequently.
Key User Benefits
Pure Sine Wave Output — Provide power protection to Energy Star 5.0 systems with Active
PFC power supplies.
Automatic Voltage Regulation (AVR) — Protect connected equipment and prevent costly
business interruptions by delivering clean and consistent AC power to your electrical
installations.
Multifunction LCD Display Panel — Quickly and easily monitor all critical UPS operating
parameters. Rotatable LCD panel permits status checking whether the UPS is installed
vertically or horizontally.
•Pure Sine Wave Output
GreenPower UPS™ Bypass Design — Save UPS energy costs by reducing power consumption and
heat buildup.
•100% Active PFC Compatible
Rack/Tower Versatility — Adapt to changing needs with horizontal rack or vertical tower installation options.
•Automatic Voltage Regulation
Power Management — PowerPanel® Business Edition management software provides unsurpassed control
and protection of the UPS and connected equipment and allows for remote management of the protected
devices on the network.
•Rotatable Multifunction LCD
•GreenPower UPS Bypass Design
•PowerPanel Business Software
Professional Protection
Sine Wave Power
Utility companies typically serve the needs of households and offices by
distributing single phase alternating current (AC) power at a frequency of 60
Hz in the U.S. In the U.S., a graphical depiction of electrical power appears
as a sine wave whereby the electrical signal alternates from +120 volts to
-120 volts at a rate of 60 times per second (60 Hz). To enable more efficient
operation of large, heavy equipment, utilities provide industry with three
phase AC power which consists of three overlapping sine waves offset by
120 degrees, thereby maintaining voltage at close to the maximum available
at all times.
While utility companies strive to distribute 100% sine wave power, multiple
factors can introduce electrical noise into the AC power signal in the form of
voltage sags, surges or spikes and various sine wave distortions. Sine wave
power is important for the functioning of laptops, desktop computers and
related peripheral equipment, as most microprocessor-based equipment can
become inoperative or sustain damage with power signal distortions of more
than 10%.
Computers incorporating Active PFC power supplies in their design
architecture require optimal power quality to function properly.
26
1.877.297.6937
Power Quality Comparison Chart
LINE-INTERACTIVE
B
A
C
D
D
F
L
E
G
H
I
2U
M
K
J
OR1500PFCRT2U
L
F
D
D
M
G
E
H
I
2U
K
J
OR2200PFCRT2U / OR2200PFCRT2Ua
A
Multifunction LCD
H
EPO Port
B
Power Switch Safety Cover
I
USB Port
C
Select Button
J
Serial Port
D
Battery & Surge Protected Outlets
K
Wiring Fault Indicator
E
Output Breaker
L
Input Breaker
F
RG6 Coax Protection
M
Cooling Fan
G
RJ45 Protection
The LCD display panel provides critical load and battery information
regardless of the units vertical or horizontal orientation.
Rack/Tower UPS Specifications
Pure Sine Wave Models
1500VA – 2200VA
Input
Capacity
(VA/
Watts)
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
OR1500PFCRT2U
1500/
900
21/7
86–142
OR2200PFCRT2U
2000/
1320
20/8
OR2200PFCRT2Ua
2200/
1320
20/8
Model
Output
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
On
Battery
Frequency
(Hz)
47–63
5-15P
5-15R (8)
120±5%
50/60
±1%
86–142
47–63
5-20P
5-20R (8)
120±5%
50/60
±1%
86–142
47–63
L5-30P
5-20R (8)
120±5%
50/60
±1%
General
Comm.
Ports
HID USB,
Serial,
SNMP, EPO
HID USB,
Serial,
SNMP, EPO
HID USB,
Serial,
SNMP, EPO
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended
Battery Module
10
2U
a
N/A
10
2U
a
N/A
10
2U
a
N/A
cpsww.com
27
PFC SINEWAVE SERIES
PFC Sinewave
850VA – 1500VA Mini-Tower CP Models
Waveform Output
Typical Applications
PFC Sinewave mini-tower UPS models, with Line-Interactive topology, provide pure
sine wave output to individual work areas, home networking hardware and devices,
entertainment electronics and equipment requiring Active PFC power source
compatibility. These units correct minor power fluctuations without switching to battery
thereby extending battery life—essential in areas where power fluctuations
occur frequently.
•Desktop Computers
Key User Benefits
•Workstations
Pure Sine Wave Output — Provide power protection to Energy Star 5.0 systems with
Active PFC power supplies.
•Personal Electronics
•High-End Audio/Video
Automatic Voltage Regulation (AVR) — Protect connected equipment and prevent
costly business interruptions by delivering clean and consistent AC power to your
computers, workstations and peripherals.
Features
Multifunction LCD Display Panel — Quickly and easily monitor all critical UPS
operating parameters.
•Home Networking/VoIP
•Line-Interactive Topology
•Pure Sine Wave Output
GreenPower UPS™ Bypass Design — Save UPS energy costs by reducing power
consumption and heat buildup.
•100% Active PFC Compatible
Ultra-Quiet Design — Minimize UPS sound emission for a quieter work environment.
•Automatic Voltage Regulation
USB Charging Ports — Charge smartphones and other devices using ports conveniently located on the
front of higher capacity mini-towers.
•Multifunction Display Panel
•GreenPower UPS Bypass Design
•Ultra-Quiet Design
Computer Monitoring — Safeguard open files and equipment with PowerPanel® Personal Edition
management software that features a user-friendly dashboard interface for controlling and monitoring a
CyberPower UPS.
•PowerPanel Personal Software
Professional Protection
Active Power Factor Correction Power Supplies in Computers
With the growth of computer
and peripheral equipment in
businesses and homes over
the last 30 years the awareness
of the amount of energy these
devices use has also increased.
The power consumed by
desktop computers and
workstations for many years
was inefficient. One factor contributing to the inefficiency was the design
architecture of the power supplies. The power supply transforms AC power
from the wall to DC power used by computers. This voltage transformation
was relatively inefficient as reflected in low power factor ratings. In 1992,
the US EPA, in conjunction with the IT industry, developed the Energy Star
program to drive the development of energy efficient products. Today the
program is recognized as an international standard for energy efficient
consumer products.
28
1.877.297.6937
To comply with Energy Star standards, desktop computer and workstation
manufacturers incorporate Active Power Factor Correction into their
engineering designs enabling energy efficiencies of 95% or greater to be
achieved. Computers with Active PFC power supplies require pure sine
wave AC power, as supplied by utility companies, for
trouble free operation making pure sine wave UPS
systems the recommended choice for backup power.
Simulated sine wave power, provided by entry-level
UPS systems, may be incompatible with Active PFC
devices. Pure sine wave power varies continuously from
Figure 1
positive to negative (Figure 1) while simulated sine wave
power mimics a pure sine wave using a squared-off
approximation (Figure 2). Due to this approximation,
simulated sine wave power creates a zero power gap for
a momentary length of time. When power is interrupted,
a computer with an Active PFC power supply may
not recognize incoming simulated sine wave power
Figure 2
and unexpectedly shut down or sustain system
component stress.
LINE-INTERACTIVE
A
B
C
H
D
I
J
F
10.4”
E
G
K
A
RG6 Coax Protection
G
Input Breaker
B
RJ11/45 Protection
H
Tamper-Proof Power Button
C
Communication Ports
I
LCD Status Panel
D
Wiring Fault Indicator
J
Setup & Control Buttons
E
Battery & Surge Protected Outlets
K
USB Charging Ports
F
Surge Protected Outlets
CP1500PFCLCD
Mini-Tower UPS Specifications
Pure Sine Wave Models
Model
CP850PFCLCD
CP1000PFCLCD 3
850VA – 1500VA
Input
Capacity
(VA/
Watts)
850/
510
1000/
600
Output
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
On
Battery
Frequency
(Hz)
8/2
90–139
57–63
5-15P
5-15R (10)
120±5%
60±1%
9/3
90–139
57–63
5-15P
5-15R (10)
120±5%
60±1%
CP1350PFCLCD
1350/
810
9/3
90–139
57–63
5-15P
5-15R (10)
120±5%
60±1%
CP1500PFCLCD 3
1500/
900
11/2
90–139
57–63
5-15P
5-15R (10)
120±5%
60±1%
General
Comm.
Ports
(Qty)
HID USB,
Serial
HID USB,
Serial
HID USB,
Serial,
(2) Front USB
5V/1A
HID USB,
Serial,
(2) Front USB
5V/1A
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended
Battery Module
5
N/A
a
N/A
5
N/A
a
N/A
5
N/A
a
N/A
5
N/A
a
N/A
3TAA compliant model available.
cpsww.com
29
INTELLIGENT LCD SERIES
Intelligent LCD
600VA – 1500VA Mini-Tower & Compact CP Models
Waveform Output
Typical Applications
•Desktop Computers
•Workstations
•Personal Electronics
•Home Networking/VoIP
Features
•Line-Interactive or Standby Topology
Intelligent LCD mini-tower UPS models with Line-Interactive topology, and compact
UPS models with Standby topology, provide simulated sine wave output to individual
work areas and home entertainment systems without Active PFC power supplies.
These units correct minor power fluctuations without switching to battery, thereby
extending battery life—essential in areas where power fluctuations occur frequently.
Key User Benefits
Simulated Sine Wave Output — Provide cost-effective power protection for servers,
telecom and peripheral electronics.
Automatic Voltage Regulation (AVR) — Protect connected equipment and prevent
costly business interruptions by delivering clean and consistent AC power to your
computers, workstations and peripherals.
Multifunction LCD Display Panel — Quickly and easily monitor all critical UPS
operating parameters.
•Simulated Sine Wave Output
GreenPower UPS™ Bypass or High-Efficiency Design — Save UPS energy costs by reducing power
consumption and heat buildup.
•Automatic Voltage Regulation
Ultra-Quiet Design — Minimize UPS sound emission for a quieter work environment.
•Multifunction Display Panel
Computer Monitoring — Safeguard open files and equipment with PowerPanel® Personal Edition
management software that features a user-friendly dashboard interface for controlling and monitoring a
CyberPower UPS.
•GreenPower UPS Bypass or
High-Efficiency Design
•Ultra-Quiet Design
•PowerPanel Personal Software
Professional Protection
Essential Protection
Power Protection without the Noise
Ultra-Quiet Design
High-efficiency ventilation, GreenPower UPS™ Technology and innovative
system components comprise the Ultra-Quiet Design found in CyberPower
UPS models designed for home or office desktop applications, audio/video
installations and quieter work environments.
Decibel Levels with Ultra-Quiet Design
Noise Filtering
For improved picture and sound quality in audio/video systems, CyberPower
uses advanced EMF/RFI noise filtering coils to reduce electromagnetic
and radio frequency interference problems. These filters smooth out minor
current fluctuations which cause disruptive humming and static.
Line Conditioning
Prolong the life of sensitive electronic equipment with line conditioning (AVR)
technology that continually adjusts the incoming AC current, keeping it within
safe levels and reducing stress caused by power fluctuations.
30
1.877.297.6937
Decibel Levels without Ultra-Quiet Design
STANDBY / LINE-INTERACTIVE
G
B
A
C
D
H
I
B
J
A
C
K
D
11”
9.75”
E
F
G
E
F
CP1500AVRLCD
CP825AVRLCD
A
RJ11/45 Protection
D
Wiring Fault Indicator
G
Input Breaker
J
LCD Panel
B
RG6 Coax Protection
E
Battery & Surge Protected Outlets
H
Power Button
K
Mode Button
C
Communication Ports
F
Surge Protected Outlets
I
Power Indicator
Mini-Tower & Compact UPS Specifications
Simulated Sine Wave Models
Model
CP600LCD*
CP750LCD* 3
CP825LCD*
CP685AVRLCD
CP825AVRLCD
CP850AVRLCD
CP1000AVRLCD
CP1350AVRLCD
CP1500AVRLCD
Capacity
(VA/
Watts)
600/
340
750/
420
825/
450
685/
390
825/
450
850/
510
1000/
600
1350/
810
1500/
900
600VA – 1500VA
Input
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Output
Frequency
Range
(Hz)
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
On
Battery
Frequency
(Hz)
General
Comm.
Ports
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended
Battery Module
9/2
100–140
57–63
5-15P
5-15R (8)
120±5%
60±1%
HID USB
6
N/A
N/A
N/A
10/3
96–140
47–63
5-15P
5-15R (8)
120±5%
50/60
±1%
HID USB
5
N/A
a
N/A
8/2
100–140
57–63
5-15P
5-15R (8)
120±5%
60±1%
HID USB
6
N/A
N/A
N/A
10/2
90–140
60±3
5-15P
5-15R (8)
120±5%
60±1%
HID USB
6
N/A
a
N/A
8/2
90–140
60±3
5-15P
5-15R (8)
120±5%
60±1%
HID USB
6
N/A
a
N/A
6
N/A
a
N/A
6
N/A
a
N/A
6
N/A
a
N/A
6
N/A
a
N/A
7/1
90–140
60±3
5-15P
5-15R (9)
120±5%
60±1%
6/1
90–140
60±3
5-15P
5-15R (9)
120±5%
60±1%
9/2
90–140
60±3
5-15P
5-15R (8)
120±5%
60±1%
11/3
90–140
60±3
5-15P
5-15R (8)
120±5%
60±1%
*Unit is non-AVR and uses Standby topology.
HID USB,
Serial
HID USB,
Serial
HID USB,
Serial
HID USB,
Serial
3TAA compliant model available.
cpsww.com
31
AVR SERIES
AVR
685VA – 1500VA Mini-Tower & Compact CP Models
Waveform Output
Typical Applications
•Desktop Computers
•Workstations
•Personal Electronics
•Home Networking/VoIP
AVR mini-tower and compact UPS models, with Line-Interactive topology, provide
simulated sine wave output to individual home and small office computer systems.
These models correct minor power fluctuations without switching to battery, thereby
extending battery life—essential in areas where power fluctuations occur frequently.
Key User Benefits
Simulated Sine Wave Output — Provide cost-effective power protection to servers,
telecom and peripheral electronics.
Automatic Voltage Regulation (AVR) — Protect connected equipment and prevent costly
business interruptions by delivering clean and consistent AC power to your computers,
workstations and peripherals.
Features
GreenPower UPS™ Bypass or High-Efficiency Design — Save UPS energy costs by
reducing power consumption and heat buildup.
•Line-Interactive Topology
Ultra-Quiet Design — Minimize UPS sound emission for a quieter work environment.
•Simulated Sine Wave Output
Computer Monitoring — Safeguard open files and equipment with PowerPanel® Personal Edition
management software that features a user-friendly dashboard interface for controlling and monitoring a
CyberPower UPS.
•Automatic Voltage Regulation
•GreenPower UPS Bypass or
High-Efficiency Design
•Ultra-Quiet Design
•PowerPanel Personal Software
Professional Protection
Automatic Voltage Regulation
Automatic Voltage Regulation (AVR) in line-interactive UPS systems stabilizes
the incoming AC signal—controlling high and low voltages—to maintain
output power at a nominal 120 volts, without resorting to battery power.
This significantly increases battery life and reduces the likelihood of data loss,
memory freezes and system crashes.
How AVR works in a Line-Interactive UPS
A line-interactive UPS includes an AVR autotransformer, a special type of
transformer designed to add or subtract powered coils of wire in response
to variances in utility power input, thereby increasing or decreasing the
magnetic field and the resulting output voltage to connected equipment.
This type of UPS can tolerate undervoltage brownouts and overvoltage
surges, without consuming reserve battery power, by automatically selecting
different power taps on the AVR autotransformer. In normal operation,
incoming AC current passes through the autotransformer where highs and
lows are controlled, while also charging the internal storage battery.
When the incoming voltage falls below a predetermined level, the UPS
switches to battery back-up and the DC-AC inverter circuitry is engaged.
Power will continue to be supplied by the battery-inverter circuit until
incoming voltage returns to within the AVR manageable range.
32
1.877.297.6937
AVR Function Diagram
LINE-INTERACTIVE
B
C
G
A
D
H
I
B
C
A
D
11”
9.75”
G
E
F
F
E
CP1500AVRT
CP825AVRG
A
RJ11/45 Protection
D
Wiring Fault Indicator
G
Input Breaker
B
RG6 Coax Protection
E
Battery & Surge Protected Outlets
H
Power Button
C
Communication Ports
F
Surge Protected Outlets
I
Power Indicator
Mini-Tower & Compact UPS Specifications
Simulates Sine Wave Models
Model
CP685AVRG
CP825AVRG
CP900AVR
CP1200AVR
CP1500AVRT
Capacity
(VA/
Watts)
685/
390
825/
450
900/
560
1200/
720
1500/
900
685VA – 1500VA
Input
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
10/2
90–140
8/2
Output
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
On
Battery
Frequency
(Hz)
60±1%
5-15P
5-15R (8)
120±5%
60±0.1
90–140
60±1%
5-15P
5-15R (8)
120±5%
60±1%
12/3
90–140
60±3
5-15P
5-15R (8)
120±5%
60
12/3
90–140
60±3
5-15P
5-15R (8)
120±5%
60
11/3
90–140
60±3
5-15P
5-15R (9)
120±5%
60
General
Comm.
Ports
HID USB,
Serial
HID USB,
Serial
HID USB,
Serial
HID USB,
Serial
HID USB,
Serial
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended
Battery Module
6
N/A
a
N/A
6
N/A
a
N/A
6
N/A
a
N/A
6
N/A
a
N/A
6
N/A
a
N/A
cpsww.com
33
STANDBY SERIES
Standby
350VA – 625VA Compact CP Models
Waveform Output
Standby compact UPS models, with Standby topology, provide simulated sine wave output
to individual home and small office computer systems. These models offer reliable lightning
protection and battery backup during power interruptions, brownouts and blackouts.
Key User Benefits
Typical Applications
•Desktop Computers
•Workstations
Simulated Sine Wave Output — Provide cost-effective power protection to servers,
telecom and peripheral electronics.
GreenPower UPS™ High-Efficiency Design — Save UPS energy costs by reducing power
consumption and heat buildup.
•Personal Electronics
Ultra-Quiet Design — Minimize UPS sound emission for a quieter work environment.
•Home Networking/VoIP
Computer Monitoring — Safeguard open files and equipment with PowerPanel® Personal
Edition management software that features a user-friendly dashboard interface for controlling
and monitoring a CyberPower UPS.
Features
•Standby Topology
•Simulated Sine Wave Output
•GreenPower UPS
High-Efficiency Design
•Ultra-Quiet Design
•PowerPanel Personal Software
Essential Protection
Surge Protection
Utility power supplied to electrical outlets is not consistent 100% of the time
and the short duration voltage surges or spikes that occasionally happen
can cause damage to sensitive components in electronic devices such as
computers and workstations. In addition to equipment damage, the potential
for irretrievable data loss is high. In the U.S., the nominal or standard voltage
supplied to household and office wiring is 120 volts. A voltage surge or spike
(a longer lasting surge) can cause electronic components to overheat; either
destroying them immediately or causing permanent damage that can lead to
premature failure.
Protection can be easily provided in the form of a surge protector (also called
a surge suppressor), a device located in the power circuit between the utility
power outlet and the connected electronic equipment. Surge protectors work
by diverting excess voltage to ground, allowing only the nominal voltage to
pass through the wiring to connected devices. This is accomplished using
a variable resistance component in the surge protector called a metal oxide
varistor, or MOV. Under normal voltage conditions, the resistance of the MOV
is such that it remains closed. As utility voltage increases beyond nominal
however, the MOV resistance decreases accordingly, forcing the unwanted
overvoltage to ground, maintaining a constant flow of nominal voltage to
sensitive electronic equipment.
34
1.877.297.6937
Lightning, a key source of voltage spikes, strikes the ground about 100 times each
second, or 8 million times a day. –The National Severe Storms Laboratory
STANDBY
D
C
A
B
E
F
B
C
D
E
9.75”
G
H
G
7.1”
H
CP550SLG
CP350SLG
A
Communication Ports
C
Wiring Fault Indicator
E
Power Button
G
Battery & Surge Protected Outlets
B
Input Breaker
D
RJ45/RJ11 Protection
F
Power Indicator
H
Surge Protected Outlets
Compact UPS Specifications 350VA – 625VA
Simulated Sine Wave Models
Model
CP350SLG*
CP425SLG
CP550SLG 3
Capacity
(VA/
Watts)
350/
255
425/
255
550/
330
Input
Runtime
Half/Full
Load
(Min)
Voltage
Range
(VAC)
Frequency
Range
(Hz)
NEMA
Plug
Type
NEMA
Outlet
Type
(Qty)
On
Battery
Voltage
(VAC)
8/2
96–140
47–63
5-15P
5-15R (6)
120±5%
7/2
96–140
47–63
5-15P
5-15R (8)
120±5%
8/2
96–140
47–63
5-15P
5-15R (8)
120±5%
*Does not include PowerPanel Software.
®
Output
On
Battery
Frequency
(Hz)
50/60
±1%
50/60
±1%
50/60
±1%
General
Comm.
Ports
Cord
Length
(ft)
Rack
Size
Energy
Saving
Compatible
Extended
Battery Module
N/A
5
N/A
a
N/A
HID USB
5
N/A
a
N/A
HID USB
5
N/A
a
N/A
3TAA compliant model available.
cpsww.com
35
POWER MANAGEMENT
Network Power Management
Hardware
Typical Applications
Remote Management Card
An optional Remote Management Card (RMCARD) may be added to
any of the Smart App UPS systems to allow for remote management
and configuration of the UPS via standard web browser or network
management system (NMS). Especially suited to enterprise installations where
the administrator may not be on-site, remote management offers complete
control, including: scheduling of UPS shutdown, startup and reboot; multiple
alert notification by e-mail, Windows Messenger and XMPP; flexible event action
setting; event logging and automatic event notification sent through SNMP trap.
•Data Centers
•Telecom Installations
•Storage Farms
•IT Closets
•Rack Installations
Features
•Remote Scheduling
of UPS Operation
Environmental Sensor
•Automatic Event Notification
•User-Upgradable Firmware
via FTP
•TCP/IP, UDP, SNMP/HTTP, NTP
and SMTP
•Auto-Shutdown
For real-time temperature and humidity readings of a datacenter, IT closet and
other critical environments combine the Environmental Sensor (ENVIROSENSOR)
with the Remote Management Card (RMCARD203). Administrators can
define environmental situations in Fahrenheit or Celsius, for example
rising temperatures, and the RM Card will send out the assigned
notification. The ENVIROSENSOR can also monitor up to four other
connected devices such as security systems, switches and
door alarms.
•Flexible Event Action Settings
•Multiple Alert Notifications
•10Mbps or 10/100Mbps
Ethernet Compatible
•Event Logging
•Quick Installation
•User-Friendly Software Interface
Remote Management Card Specifications
Remote
Mgmt.
Auto Shutdown
Upgradable
User Firmware
Auto
Event Notification
Remote
Scheduling
Ethernet
Speeds
(Mbps)
Auto
Shutdown
Clients
Environmental
Sensor
Compatible
HTTP, NMS
Workstations
Multiple Servers
N/A
SNMP TRAP
Shutdown,
Startup, Reboot
10
50
N/A
RMCARD202 3 HTTP, NMS
Workstations
Multiple Servers
a
SMTP, SMS,
SNMP TRAP
Shutdown,
Startup, Reboot
10/100
Unlimited
N/A
RMCARD203
HTTP, NMS
Workstations
Multiple Servers
a
SMTP, SMS,
SNMP TRAP
Shutdown,
Startup, Reboot
10/100
Unlimited
a
HTTP, NMS
Workstations
Multiple Servers
a
SMTP, SMS,
SNMP TRAP
Shutdown,
Startup, Reboot
10/100
Unlimited
N/A
Model
RMCARD100
RMCARD302
Environmental Sensor For additional model specifications visit our website.
Model
ENVIROSENSOR
RMCARD Compatibility
RMCARD203
3TAA compliant model available.
36
1.877.297.6937
Temperature
Accuracy
Humidity
Accuracy
Voltage
Dimensions
WxHxD (in)
Weight (oz)
Warranty
2°F – 158°F
± 1.8°F
0 – 90 RH
± 2%
12V
2.24 x 1.46 x 1.15
1.16
3 Years
POWER MANAGEMENT
Network Power Management
Software
Typical Applications
PowerPanel® Software by CyberPower
•Data Centers
PowerPanel software, included with all compatible CyberPower UPS Systems, monitors and
controls a UPS with a simple dashboard interface.
•Telecom Installations
•Storage Farms
•IT Closets
•Rack Installations
•Business Workstations
•Desktop Computers
Features
•Remote Access via Web Browser
•Network Protocol Support
PowerPanel Business Edition
PowerPanel Business Edition software provides IT professionals
with the tools they need to easily monitor and manage their backup
power. This advanced software allows users remote access from
any network PC with a web browser to instantly access vital UPS
battery conditions, load levels and runtime information as well as
provide graceful unattended shut down of network computers and
virtual machines connected to a battery backup during a power event. Power alerts can be set up
to send notifications though e-mail, text or instant message. PowerPanel software is compatible
with Windows XP, Windows Vista, Windows 7, Windows 8, Windows Server 2008, Windows Server
2012 and all versions of Windows 2k+.
•Flexible Event Action Settings
PowerPanel Business Edition for Virtual Environments
•Auto-Shutdown
This version of the PowerPanel software is a complete UPS system
management tool that works with virtual environments.
Protect an ESX/ESXi host that is connected to a UPS though
a serial or USB port by installing PowerPanel Business Edition
software, then use it to control the host and connected virtual
machines. The software logs UPS statuses and generates actions
in response to administrator defined events. If an event occurs the software then sends notification
to other connected systems to manage unattended shutdowns. PowerPanel management software
has been tested and is compatible with many popular versions of virtual machine operating systems
such as VMware vSphere™.
•Remote Scheduling
•Event Logging
•Security Management
•Quick Installation
•User-Friendly Interface
CyberPower is a member of VMware Technology Alliance Partner Program (TAP)
providing integration between PowerPanel, VMware ESX/ESXi and all Smart App
UPS models.
PowerPanel Personal Edition
PowerPanel Personal Edition software is available free for
download with all UPS systems with a USB or serial port.
The software features a user-friendly dashboard interface for
controlling and monitoring a CyberPower UPS systems.
Its advanced functionality includes; runtime management, self
testing, event logging and more. PowerPanel Personal Edition
software is compatible with Windows 8, Windows 7, Windows
Vista, Windows XP, Windows Server 2008 and all versions of
Windows 2k+.
PowerPanel for Linux
PowerPanel for Linux is a simple command line Linux daemon
to control a UPS system attached to a Linux based computer.
Functions include automatic shutdown, monitoring, notifications
and more. PowerPanel for Linux is compatible with all versions
of Linux.
PowerPanel for Mac & Mac Energy Saver
PowerPanel for Mac is now available to provide Mac users with
information and statistics about a connected UPS. During a power
event, a CyberPower UPS system and Apple’s Energy Saver power
management software can be set up to safely and securely shut
down a Mac without using PowerPanel software. PowerPanel for
Mac is compatible with Mac OS X 10.4.1+.
cpsww.com
37
REPLACEMENT BATTERIES
Replacement Batteries
Features
Battery Life
The typical lifespan of internal UPS batteries is three to five years.
The number of discharge cycles a UPS system provides to connected
devices and the environment it operates in affect the number of years
can considered as a battery.
•OEM Certified
•Leak Proof
•Maintenance-Free
•User-Installable
•Preassembled
Maintenance
•18-Month Warranty
Regularly scheduled battery maintenance and monitoring can best
determine when batteries are nearing end-of-life, specifically, when they
can no longer supply 80% of their capacity. Inspection of a UPS and
initiation of a self-test, at least once a year, is recommended. Despite their maintenancefree description (which simply means they do not require replacement fluid), sealed batteries
need scheduled preventive maintenance to check connections and remove corrosion, as well as
determine whether a battery is about to fail.
Replacement
A simple, cost-effective way to restore life to a CyberPower UPS system is to replace its internal
batteries with a CyberPower replacement battery cartridge. These sealed lead-acid batteries
are certified to meet or exceed original manufacturer specifications. These battery replacement
cartridges are preassembled for easy installation and are shipped in reusable packaging for
subsequent delivery of expired batteries to a suitable recycling center. All CyberPower batteries
include an 18-month warranty.
UPS Replacement Battery Specifications
Model
38
Style
UPS Model
Type
Nominal
Voltage
Nominal
Amperage
Warranty
RB1270
BB/BP7.2-12
CP600LCD
Sealed lead-acid
12V
7AH
18 mo.
RB1280
BB/BP8-12
CP685AVR, CP685AVRG, CP685AVRLCD
Sealed lead-acid
12V
8AH
18 mo.
RB1280A
BB/HR1234W
CP825LCD, CP800AVR, CP825AVRLCD, CP850AVRLCD
Sealed lead-acid
12V
8AH
18 mo.
RB1290
BB/HR9-12
CP1000AVRLCD
Sealed lead-acid
12V
9AH
18 mo.
RB1270X2
BB/SH1228W
CP900AVR
Sealed lead-acid
12V
7AH
18 mo.
RB1280X2A
BB/HR1234W
CP1500AVRT, CP1500AVRLCD
Sealed lead-acid
12V
8AH
18 mo.
RB0670X2
BB/BP7-6
OR500LCDRM1U
Sealed lead-acid
6V
7AH
18 mo.
RB0690X2
BB/HR9-6
OR700LCDRM1U
Sealed lead-acid
6V
9AH
18 mo.
RB0670X4
BB/BP7-6
OR1000LCDRM1U
Sealed lead-acid
6V
7AH
18 mo.
RB0690X4
BB/HR9-6
OR1500LCDRM1U
Sealed lead-acid
6V
9AH
18 mo.
RB0690X4A
BB/HR9-6
PR750LCDRM1U, PR1000LCDRM1U
Sealed lead-acid
6V
9AH
18 mo.
RB1270X4
BB/BP7.2-12
OR1500LCDRM2U
Sealed lead-acid
12V
7AH
18 mo.
RB1270X4A
BB/BP7.2-12
PR1000LCDRT2U, PR1500LCDRT2U, PR1000LCDRTXL2U
Sealed lead-acid
12V
7AH
18 mo.
RB1270X4B
BB/SH1228WFR
OR1500LCDRTXL2U
Sealed lead-acid
12V
7AH
18 mo.
RB1290X4
BB/HR9-12
OR2200LCDRM2U
Sealed lead-acid
12V
9AH
18 mo.
RB1290X4A
BB/HR9-12
PR2200LCDRT2U
Sealed lead-acid
12V
9AH
18 mo.
RB1290X4B
BB/HR9-12FR
OR2200LCDRTXL2U
Sealed lead-acid
12V
9AH
18 mo.
RB1290X4D
BB/HR9-12FR
PR3000LCDRT2U, PR1000LCDRTXL2Ua, PR1500LCDRTXL2U,
PR2200LCDRTXL2U, PR3000LCDRTXL2U
Sealed lead-acid
12V
9AH
18 mo.
1.877.297.6937
ESSENTIAL SOLUTIONS
Essential Power Solutions
Power Distribution Units
PDUs are engineered to distribute UPS, generator or utility AC power to multiple devices,
servers and network/telecom equipment in the most demanding environments. With more than
130 models offered, in Basic, Metered, Monitored and Switched configurations, CyberPower
offers a solution to meet virtually every need.
Rackbar™ Surge Protectors
Industrial rackmount surge protectors from CyberPower are designed for the most demanding
applications and will safeguard systems and networking equipment against destructive power
interruptions that can cause equipment damage, loss of valuable data and time.
Surge Protectors
Professional grade surge protectors from CyberPower are designed for office environments.
Features include surge protected outlets and data line protection (DSL/Phone/Fax), as well as
child-safe outlets (on select models). All units are covered by a Lifetime Product Warranty and
Connected Equipment Guarantee.
Telecom Power Supplies–FTTx
CyberShield DC Power Supplies and reliable battery backup systems are specifically designed
for optical network terminal (ONT) broadband applications, cable telephony, wireless local
loop (WLL), fiber to the home (FTTH), VoDSL applications and Integrated Access Devices
(IAD) for customer premises equipment (CPE). Commitment to meticulous engineering has
brought the CyberPower CyberShield DC product line to the forefront of fiber applications in the
telecommunications industry.
Power Accessories
CyberPower offers an extensive line of computer and consumer electronics such as hubs, USB
chargers, mobile batteries, power inverters plus a variety of cables to connect peripherals or
networking devices. All of these products are designed to meet the growing power needs of IT
professionals and tech-savvy consumers everywhere.
cpsww.com
39
GLOSSARY
Industry Terms
Alternating Current (AC)
The direction of an electric charge that is flowing in a circuit is constantly being
reversed back and forth.
Amp (ampere)
The standard unit of measure for electrical current, defined as the amount of
electrical flow equal to one coulomb per second.
Apparent Power
The product of the applied voltage and current in an AC circuit.
Blackout
A power failure in which line voltage drops to zero.
Brownout
A drop in voltage in electrical power supply.
Buck/Boost
Full automatic voltage regulation in a UPS stabilizes low voltage (boost) and
high voltage (buck) to maintain nominal 120V power, without resorting to battery
power when minor power fluctuations occur.
Coaxial Cable
Cables that are made of an inner conductor surrounded by an insulator and a
shield that are generally used for TV antennas, satellite dishes, cable modems
and certain computer networking applications.
Current
The flow of electric charge, measured in amps.
DHCP
Dynamic Host Configuration Protocol (DHCP), automatically assigns an IP
address to a device on a network.
Direct Current (DC)
The unidirectional flow of a electric charge.
Hard-wired
High amperage devices that require installation by a qualified electrician to be
directly wired-in, instead of simply being plugged in to an outlet.
Hertz (Hz)
The unit for frequency, defined as the number of cycles per second.
Hot-Swappable Battery
A term used to describe the functions of replacing a UPS battery without
shutting down the unit.
Joule
A measure of electrical energy — one joule is defined as the energy needed to
pass one ampere of current through one ohm of resistance.
Line-Interactive UPS
Functions the same as a standby UPS, with the additional feature of some
voltage regulation built in. It switches to battery power when voltage drops too
low, just as a standby UPS does, however if the voltage only drops slightly, a
line-interactive UPS corrects this without using battery power. The functionality
of these mid- to high-grade units falls between standby and online UPS units.
Load
The amount of power consumed by an electrical device on a circuit. Load
capacity is a critical factor in selecting a UPS or surge protector.
MOV
Metal Oxide Varistor is an electronic component that is used to protect circuits
against excessive, short-lived, voltages.
Nominal Voltage
The standard voltage for a circuit or system. Common nominal voltages in the
U.S. includes 120VAC, 208VAC and 240VAC.
Double-Conversion UPS
This high-end UPS system converts incoming utility AC power into DC power
and then back into AC power, charging connected devices with the UPS
battery. The isolated process ensures clean and stable output voltage and
zero transfer time. This UPS system is ideal for equipment sensitive to power
fluctuations such as corporate data centers, servers, and network and
storage devices.
Overvoltage
This occurs when incoming voltage is higher than normal but not high enough
to be classified as a surge.
Efficiency (Energy Conversion Efficiency)
The ratio between the amount of apparent power and the amount of true power
used by an electrical device. The closer the true power value is to the apparent
power, the more efficient the device.
Power Factor Correction
Controls the incoming power to a power supply in order to bring the power
factor as close to unity power as possible.
Electromagnetic Interference (EMI)
Commonly referred to as line noise, these interference signals can disrupt
or degrade the performance of a circuit by inserting abnormalities into the
system. Also referred to as radio frequency interference (RFI) when in high
or radio frequency.
Frequency
The number of cycles in a given time period, which is measured in Hertz.
Ground
An electrical system connection that serves as a conduit between the circuit
and earth.
40
Half-Load
The midpoint in the maximum load capacity for a UPS.
1.877.297.6937
Power Factor (PF)
The ratio of real power (watts) to apparent power (VA), expressed as a number
between 0 and 1. Watts divided by VA = Power Factor
Radio Frequency Interference (RFI)
See Electromagnetic Interference.
Real Power
The amount of power being drawn by a system, measured in watts. Real power
is a function of VA (apparent power) and the power factor.
RJ11, RJ14, RJ45
The abbreviation of registered jack (RJ) – RJ11 is for standard phone lines, RJ14
is for multiple phone lines and RJ45 is for Ethernet.
Runtime
The maximum period of time battery power is output from a UPS to its
connected devices during a power interruption. Runtime is dependent upon the
total load of all connected equipment.
GLOSSARY
Industry Terms
Simulated Sine Wave
A modified or approximated sine wave AC power output. Simulated (or nonsinusoidal) waveforms may also be referred to as a squared sine wave, modified
sine wave, trapezoidal sine wave or quasi sine wave.
Sine Wave
A smooth, repetitive oscillation of AC power.
Single Phase Power
Refers to the distribution of alternating current electric power using a system in
which all the voltages of the supply vary in unison.
SMTP
Simple Mail Transfer Protocol is the standard for e-mail transmission on the Internet.
SNMP
Simple Network Management Protocol is a commonly used protocol for devices
to communicate over a network.
Spike
A spike is a sudden, brief power surge, usually lasting less than 1ms.
Standby UPS
A UPS that passes utility power straight through to the output when conditions
are stable, but switches to battery power when utility voltage drops below an
acceptable level.
Volt
The difference in electric potential between two points when one amp of current
dissipates one watt of power.
Volt-Ampere
The unit used to express apparent power.
Voltage Regulator
A device or component that normalizes voltage to a certain standard when it
is fluctuating.
Watt
A unit of measure for true power consumption.
Waveform
Is a representation (or form) of how alternating current (AC) varies with time.
Common waveform representations include sine wave, square wave and
trapezoidal wave. An instrument called an oscilloscope can be used to visually
represent a wave as a repeating image on a screen.
Wiring-Fault
Refers to an abnormal flow of current that is due to an improperly grounded
electrical outlet.
Surge
Periods when line voltage increases dramatically, typically lasting longer than
1ms, but less than a few seconds, though they can last longer.
Total Harmonic Distortion (THD)
A calculated measure of the reduction in sine wave clarity caused by stray
wave frequencies.
Thermal Dissipation
The process of dissipating heat from an electrical system via air or liquid
cooling; also a term for the amount of heat a device can emit.
Transfer Time
The time it takes UPS to switch from AC power to battery power.
Transformer
A device that converts AC line voltage to a higher or lower value.
U
The standard unit of measure for rack-mounted equipment. A device measuring
1U is 1.75 inches high, 2U is 3.50 inches, etc.
Undervoltage
Related to both brownout and voltage sag, undervoltage falls between these
two, occurring when voltage is lower than normal for an extended period of time
without recovering, but not to low that the electronic device will not function.
USB (HID Compliant)
Universal Serial Bus devices are used to connect various components to a
computer. An HID (Human Interface Device) compliant USB follows a specific
protocol for communication that allows it to be used with virtually any system.
cpsww.com
41
CPSWW.COM
© 2012 CyberPower Systems (USA), Inc. All rights reserved. All other trademarks are the property of their respective owners. CyberPower reserves the right to modify product information or specifications without previous notice.
The information presented is accurate at the time of publication. 10-2012
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
