TO THE OWNER
Before operating this projector, read this manual thoroughly to operate the projector properly.
This projector provides many convenient features and functions. Operating the projector properly enables you to
manage those features and maintain it in better condition for a considerable time.
Improper operation may result in not only shortening the product-life, but also malfunctions, fire hazard, or other
accidents.
If your projector seems to operate improperly, read this manual again, check operations and cable connections and try
the solutions in the “TROUBLESHOOTING” section in the end at this manual. If the problem still persists, contact the
sales dealer where you purchased the projector or the service center.
SAFETY PRECAUTIONS
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
● This projector produces an intensive light from the projection lens. Do not look directly into the lens; it may
damage your eyes. Be especially careful that children do not look directly into the beam.
● This projector should be set in the way indicated. If not, it may result in fire hazard.
● Provide appropriate space on the top, sides and rear of the
projector cabinet for allowing air circulation and cooling the
projector. Minimum clearance must be maintained. If the
projector is to be built into a compartment or similarly enclosed,
the minimum distances must be maintained. Do not cover the
ventilation slot on the projector. Heat build-up can reduce the
service life of your projector, and can also be dangerous.
SIDE and TOP
REAR
20cm
50cm
50cm
50cm
● Do not put any flammable objects or spray cans near the projector, hot air is exhausted from the ventilation
holes.
● The Remote Control Unit, supplied with this projector, emits a laser beam as the laser pointer function from the
Laser Light Window while pressing the LASER button (for 1 minute / LASER POINTER INDICATOR lights red
to indicate laser emission). To reduce the risk of injury, do not look into the Laser Light Window nor shine the
laser beam on yourself or other people.
● If the projector is not to be used for an extended period of time, unplug the projector from the AC outlet.
READ AND KEEP THIS OWNER'S MANUAL FOR LATER USE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION :
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE EXCEPT LAMP REPLACEMENT. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THIS SYMBOL INDICATES THAT DANGEROUS
VOLTAGE CONSTITUTING A RISK OF ELECTRIC
SHOCK IS PRESENT WITHIN THIS UNIT.
2
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT
OPERATING AND MAINTENANCE INSTRUCTIONS IN THE
OWNER'S MANUAL WITH THIS UNIT.
SAFETY INSTRUCTIONS
All the safety and operating instructions should be read before
the product is operated.
Read all of the instructions given here and retain them for later
use. Unplug this projector from AC power supply before
cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
This projector should be operated only from the type of power
source indicated on the marking label. If you are not sure of
the type of power supplied, consult your authorized dealer or
local power company.
Follow all warnings and instructions marked on the projector.
Do not overload wall outlets and extension cords as this can
result in fire or electric shock. Do not allow anything to rest on
the power cord. Do not locate this projector where the cord
may be damaged by persons walking on it.
For added protection to the projector during a lightning storm,
or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet. This will prevent damage
due to lightning and power line surges.
Do not attempt to service this projector yourself as opening or
removing covers may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified service
personnel.
Do not expose this unit to rain or use near water... for
example, in a wet basement, near a swimming pool, etc...
Do not use attachments not recommended by the
manufacturer as they may cause hazards.
Do not place this projector on an unstable cart, stand, or table.
The projector may fall, causing serious injury to a child or
adult, and serious damage to the projector. Use only with a
cart or stand recommended by the manufacturer, or sold with
the projector. Wall or shelf mounting should follow the
manufacturer's instructions, and should use a mounting kit
approved by the manufacturers.
An appliance and cart combination should
be moved with care. Quick stops,
excessive force, and uneven surfaces
may cause the appliance and cart
combination to overturn.
Slots and openings in the back and bottom of the cabinet are
provided for ventilation, to insure reliable operation of the
equipment and to protect it from overheating.
Unplug this projector from wall outlet and refer servicing to
qualified service personnel under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the projector.
c. If the projector has been exposed to rain or water.
d. If the projector does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions as improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the projector to normal operation.
e. If the projector has been dropped or the cabinet has been
damaged.
f. When the projector exhibits a distinct change in
performance-this indicates a need for service.
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer that have the same characteristics as the
original part. Unauthorized substitutions may result in fire,
electric shock, or injury to persons.
Upon completion of any service or repairs to this projector, ask
the service technician to perform routine safety checks to
determine that the projector is in safe operating condition.
The openings should never be covered with cloth or other
materials, and the bottom opening should not be blocked by
placing the projector on a bed, sofa, rug, or other similar
surface. This projector should never be placed near or over a
radiator or heat register.
This projector should not be placed in a built-in installation
such as a book case unless proper ventilation is provided.
Never push objects of any kind into this projector through
cabinet slots as they may touch dangerous voltage points or
short out parts that could result in fire or electric shock. Never
spill liquid of any kind on the projector.
Voor de klanten in Nederland
Bij dit product zijn batterijen
geleverd.
Wanneer deze leeg zijn,
moet u ze niet weggooien
maar inleveren als KCA.
3
COMPLIANCES
Federal Communication Commission Notice
Multimedia Projector, Model : LV-5200U, LV-5200E
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures :
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise specified in the instructions. If such
changes or modifications should be made, you could be required to stop operation of the equipment.
Canon U.S.A., Inc.
One Canon Plaza, Lake Success, NY 11042, U.S.A.
Tel No. (516)328-5600
For use in Germany
This product is intended for use in residential, commercial and light industry environment.
Canadian Radio Interference Regulations
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
AC POWER CORD REQUIREMENT
The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it.
AC Power Cord for the United States and Canada :
AC Power Cord used in the United States and Canada is listed by the Underwriters
Laboratories (UL) and certified by the Canadian Standard Association (CSA).
AC Power Cord has a grounding-type AC line plug. This is a safety feature to be sure that
the plug will fit into the power outlet. Do not try to defeat this safety feature. Should you
be unable to insert the plug into the outlet, contact your electrician.
GROUND
THE SOCKET-OUTLET SHOULD BE INSTALLED NEAR THE EQUIPMENT AND EASILY ACCESSIBLE.
4
TABLE OF CONTENTS
FEATURES AND DESIGN
PREPARATION
6
7
COMPUTER INPUT (RGB Scart 21-Pin Video Input) 22
SELECTING THE INPUT SOURCE
SELECTING THE COMPUTER SYSTEM
COMPATIBLE COMPUTER SPECIFICATIONS
PC ADJUSTMENT
NOMENCHTOR
SETTING-UP THE PROJECTOR
7
8
CONNECTING AC POWER CORD
8
INSTALLING THE PROJECTOR IN PROPER POSITION 8
POSITIONING THE PROJECTOR
9
ADJUSTABLE FEET
9
MOUNTING THE LENS COVER
10
MOVING THE PROJECTOR
10
CONNECTING THE PROJECTOR 11
TERMINALS OF THE PROJECTOR
CONNECTING TO COMPUTER
CONNECTING TO VIDEO EQUIPMENT
11
12
13
AUTO PC ADJUSTMENT
MANUAL PC ADJUSTMENT
PICTURE IMAGE ADJUSTMENT
IMAGE LEVEL SELECT
IMAGE LEVEL ADJUSTMENT
PICTURE SCREEN ADJUSTMENT
VIDEO INPUT
SELECTING THE INPUT SOURCE
SELECTING THE VIDEO SYSTEM
PICTURE IMAGE ADJUSTMENT
IMAGE LEVEL SELECT
IMAGE LEVEL ADJUSTMENT
PICTURE SCREEN ADJUSTMENT
BEFORE OPERATION
LASER POINTER FUNCTION
14
REMOTE CONTROL UNIT BATTERIES INSTALLATION 15
HOW TO OPERATE THE ON-SCREEN MENU
FLOW OF ON-SCREEN MENU OPERATION
MENU BAR
BASIC OPERATION
TURNING ON / OFF THE PROJECTOR
TURNING ON THE PROJECTOR
TURNING OFF THE PROJECTOR
ADJUSTING THE SCREEN
ZOOM ADJUSTMENT
FOCUS ADJUSTMENT
KEYSTONE ADJUSTMENT
PICTURE FREEZE FUNCTION
NO SHOW FUNCTION
P-TIMER FUNCTION
SOUND ADJUSTMENT
24
25
25
26
28
28
29
30
31
31
32
33
33
34
35
14
OPERATION OF THE REMOTE CONTROL UNIT 14
TOP CONTROLS AND INDICATORS
OPERATING THE ON-SCREEN MENU
22
23
SETTING
SETTING MENU
36
36
16
17
17
17
18
APPENDIX
LAMP REPLACEMENT
LAMP REPLACE
LAMP REPLACE COUNTER
38
38
38
39
19
OPERATING WIRELESS MOUSE
40
19
INSTALLATION
OPERATING WIRELESS MOUSE
40
40
19
19
20
20
20
20
20
21
21
MAINTENANCE
WARNING TEMP. INDICATOR
AIR FILTER CARE AND CLEANING
CLEANING PROJECTION LENS
TROUBLESHOOTING
INDICATORS AND PROJECTOR CONDITION
TECHNICAL SPECIFICATIONS
CONFIGURATIONS OF TERMINALS
OPTIONAL PARTS
41
41
41
41
42
44
45
46
47
21
TRADEMARKS
● Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple Computer,Inc.
● IBM, VGA, XGA, and PS/2 are trademarks or registered trademarks of International Business Machines, Inc.
● Windows and PowerPoint are registered trademarks of Microsoft Corporation.
● Each name of corporations or products in the owner's manual is a trademark or a registered trademark of its
respective corporation.
5
FEATURES AND DESIGN
This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. It
utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology.
◆
Wide Zoom Lens
This projector is equipped with a Wide Zoom Lens with a
1.5 times optical zoom, and provides a 100” screen size
at a range of 10.4’ (3.2m) to 15.6’ (4.8m).
◆
Compact Design
This projector is extremely compact in size and weight.
It is designed to be carried and work anywhere.
◆
Lamp Mode
The Lamp Mode function can be switched into the silent
mode and reduce the brightness and set into the lower
power consumption.
◆
Compatibility
This projector accepts a wide range of video and
computer input signals including;
● Computers
IBM-compatible or Macintosh computer up to 1024
x 768 resolution.
● 6 Color TV Systems
NTSC, PAL, SECAM, NTSC 4.43, PAL-M or PALN color system can be connected.
● Component Video
Component video signal, such as a DVD player
output high definition TV signals including 480i,
480p, 575i, 575p, 720p, 1035i or 1080i, can be
connected.
● S-Video
S-Video signal, such as a S-VHS VCR or
camcorder, can be connected.
◆
High Resolution Image
This projector provides 800 x 600 dots resolution for
computer input and 500 horizontal TV lines. Resolution
from a computer between SVGA (800 x 600) and XGA
(1024 x 768) is compressed into 800 x 600 dots. This
projector cannot display image of over 1024 x 768 dots.
When the resolution of your computer is higher than
1024 x 768, reset it to a lower resolution.
◆
Multi-Scan System
This projector has the Multi-Scan System to conform to
almost all computer output signals quickly. Making
manual adjustment of frequency and other settings is
unnecessary.
◆
One-Touch Auto PC Adjustment
Incoming computer video signals are recognized and the
best adjustment is automatically set by Auto PC
Adjustment.
6
◆
Digital Zoom (for Computer)
The Digital Zoom function expands (to approx. 16 times
of screen size in SVGA) or compresses the image size,
allowing you to focus on crucial information at a
presentation.
◆ Keystone Correction
Positioning height of the projector may result in distorted
image being displayed in a trapezoid shape. Keystone
Correction solves this problem by digitally altering
projection to produce undistorted images.
◆
Power Management
The Power Management function reduces the power
consumption while the projector is not in use.
This Power Management function operates to turn the
Projection Lamp off when a signal has not been received
or a button is not pressed over 5 minutes. The
Projection Lamp is automatically turned on again when
the projector detects a signal or a button is pressed.
This projector is shipped with this function ON.
◆
Digital Visual Interface
This projector is equipped with DVI 29-pin terminal for
connecting DVI output from a computer.
◆
Switchable Interface Terminal
This projector provides a switchable Interface terminal.
You can use the terminal as computer input or monitor
output conveniently. (Refer to page 36.)
◆
Laser Pointer Function
The Remote Control Unit supplied with this projector
includes the Laser Pointer function. This function helps
you to make a smart presentation on a projected screen.
◆
Wireless Mouse
The Remote Control Unit supplied with this projector has
the Wireless Mouse function for a connected computer.
This function enables you to operate both the projector
and the computer with the Remote Control Unit only.
◆
Multilanguage Menu Display
Operation menu is displayed in; English, German,
French, Italian, Spanish, Portuguese, Dutch, Swedish,
Russian, Chinese, Korean or Japanese.
PREPARATION
NOMENCHTOR
FRONT
EXHAUST VENTS
HOT AIR EXHAUSTED !
CARRY HANDLE
INFRARED
REMOTE RECEIVER
PROJECTION LENS
LENS COVER
Air blown from Exhaust Vents is hot.
When using or installing the projector,
the following precautions should be
taken.
● Do not put any flammable object near
these vents.
● Keep front grills at least 3’(1m) away
from any object, especially heatsensitive objects.
● Do not touch this area, especially
screws and metallic parts. This area
becomes hot while the projector is used.
This projector detects internal
temperature and automatically controls
operating power of Cooling Fans.
BACK
TOP CONTROLS
AND INDICATORS
INFRARED
REMOTE RECEIVER
SPEAKER
TERMINALS
AND CONNECTORS
POWER CORD CONNECTOR
BOTTOM
AIR FILTER
LAMP COVER
ADJUSTABLE FEET
AND
FEET LOCK LATCHES
AIR INTAKE VENTS
(Back and Bottom)
This projector is equipped with the
Cooling Fans for protection from
overheating. Pay attention to the
following to ensure proper ventilation
and avoid the risk of fire and
malfunction.
● Do not cover the vent slots.
● Keep the back and the bottom clear
of any object. Obstructions may
block cooling air.
7
PREPARATION
SETTING-UP THE PROJECTOR
CONNECTING AC POWER CORD
This projector uses nominal input voltages of 100-120 V or 200-240
V AC. This projector automatically selects the correct input
voltage. It is designed to work with single-phase power systems
having a grounded neutral conductor. To reduce the risk of electric
shock, do not plug into any other type of power system.
Consult your authorized dealer or service station if you are not sure
of the type of power supply being supplied.
Connect the projector with all peripheral equipment before turning
the projector on. (Refer to pages 11 ~ 13 for connection.)
CAUTION
For safety, unplug the AC Power Cord when the projector is not
in use.
When this projector is connected to the AC outlet with the AC
Power Cord, it is in Stand-by Mode and consumes a little electric power.
Connect the AC Power Cord (supplied) to the
projector.
The AC outlet must be near this equipment and
must be easily accessible.
NOTE ON THE POWER CORD
The AC Power Cord must meet the requirements of the country where you use the projector.
Confirm the AC plug type with the chart below. The proper AC power cord must be used.
If the supplied AC Power Cord does not match the AC outlet, contact your sales dealer.
Projector side
AC Outlet side
For the U.S.A. and Canada
For Continental Europe
Ground
To the POWER CORD
CONNECTOR on the
projector.
To the AC Outlet.
(120 V AC)
To the AC Outlet.
(200 - 240 V AC)
INSTALLING THE PROJECTOR IN PROPER POSITION
Install the projector properly. Improper installation may reduce the lamp lifetime and cause fire hazard.
20˚
Do not point the projector down to
project an image.
Do not tilt the projector more than
20 degrees above and below.
20˚
NO DOWNWARD
Do not point the projector up to
project an image.
NO UPWARD
8
Do not put the projector on either
side to project an image.
NO SIDEWAYS
PREPARATION
POSITIONING THE PROJECTOR
● This projector is designed to project on a flat projection surface.
● The projector can be focused from 3.6’(1.1m) ~ 31.8’(9.7m).
● Refer to the figure below to adjust a screen size.
ROOM LIGHT
The brightness of a room has a great impact on
picture quality. It is recommended to limit
ambient lighting to provide the best image.
H1 : H2 = 9 : 1
31.8’ (9.7m)
300”
21.1’ (6.4m)
15.6’ (4.8m)
Max. Zoom
200”
10.4’ (3.2m)
202”
150”
3.6’ (1.1m)
Min. Zoom
H1
134”
100”
100”
67”
36”
H2
24”
Screen Size
(W x H) mm
24”
36”
100”
150”
200”
300”
490 x 367
728 x 546
2032 x 1524
3048 x 2286
4064 x 3048
6096 x 4572
Zoom (min)
3.6’ (1.1m)
5.4’ (1.7m)
15.6’ (4.8m)
23.5’ (7.2m)
31.4’ (9.6m)
–––––
Zoom (max)
–––––
3.6’ (1.1m)
10.4’ (3.2m)
15.6’ (4.8m)
21.1’ (6.4m)
31.8’ (9.7m)
ADJUSTABLE FEET
Picture tilt and projection angle can be adjusted by rotating the
Adjustable Feet. Projection angle can be adjusted to approx. 16
degrees.
1
Lift the front of the projector and pull the Feet Lock Latches
on both sides of the projector.
2
Release the Feet Lock Latches to lock the Adjustable Feet
and rotate the Adjustable Feet to fine tune the position and
the tilt.
3
To retract the Adjustable Feet, lift the front of the projector
and pull the Feet Lock Latches and push to feet upward.
Keystone distortion of a projected image can be adjusted by
Menu Operation. (Refer to P20 and 36.)
CAUTION
ADJUSTABLE FEET
FEET LOCK
LATCHES
Avoid positioning the projector with the angle of more than 20
degrees. The Projection Lamp may malfunction. Refer to page 8.
9
PREPARATION
MOUNTING THE LENS COVER
When transporting the projector or when it is not in use for an
extended period of time, attach the Lens Cover.
Before attaching the Lens Cover, be sure to turn the projector off
and disconnect the AC Power cord from the AC outlet.
1
2
LENS COVER
Secure the Strap for the Lens Cover through the hole.
Turn the projector upside down and secure the Strap for the
Lens Cover to the bottom of the projector with a screw.
STRAP FOR LENS COVER
Secure to the hole with a screw.
MOVING THE PROJECTOR
Use Carry Handle when moving the projector.
When moving the projector, attach the Lens Cover and retract the
Adjustable Feet to prevent damage to the lens and cabinet.
When the projector is not in use for an extended period of time,
put it into the case (carrying bag) supplied with the projector.
CAUTION
Carrying Bag (supplied) is intended for protection from dust and
scratches on the surface of a cabinet, and it is not designed to
protect the projector from external forces. Do not transport the
projector through a courier or transport services with this bag.
The projector can be damaged. When handling the projector, do
not drop, bump, subject it to strong forces or put other things on the
cabinet.
CAUTION IN CARRYING OR TRANSPORTING THE PROJECTOR
● Do not drop or bump the projector, otherwise damage or malfunction may result.
● When carrying the projector, use a suitable carrying case.
● Do not transport the projector by using a courier or transport service in an unsuitable transport case. This may cause
damage to the projector. To transport the projector through a courier or transport service, consult your dealer.
10
CONNECTING THE PROJECTOR
TERMINALS OF THE PROJECTOR
This projector has input and output terminals on its back for connecting computer and video equipment. Refer to figures on
pages 11 to 13 for these connections.
S-VIDEO INPUT JACK
AUDIO INPUT JACKS
VIDEO INPUT JACKS
AUDIO OUTPUT JACKS
Connect the S-VIDEO
output from your
video equipment to
this jack.
(Refer to P13.)
Connect the audio
output from your video
equipment to these jacks.
(Refer to P13.)
● When the audio output
is monaural, connect it
to L (mono) jack.
Connect the composite video
output from your video
equipment to VIDEO/Y jack
or connect the component
video outputs to VIDEO/Y,
Pb/Cb and Pr/Cr jacks.
(Refer to P13.)
Connect an external
audio amplifier to these
jacks.
(Refer to P12, 13.)
RESET BUTTON
DVI - I
RGB IN-2
R
VIDEO IN
Y
Pb/Cb
AUDIO
L
IN
S – VIDEO IN
COMPUTER
AUDIO IN
RGB IN-1 / OUT
R
The projector uses a micro
processor for control, and
occasionally, need to be reset.
This can be done by pressing
the RESET button with a pen,
which will shut down and
restart the unit. Do not
use the RESET function
excessively.
Pr/Cr
AUDIO
OUT L
RESET
CONTROL PORT CONNECTOR
CONTROL PORT
When
controlling
your
computer with the Remote
Control Unit of this projector,
connect the mouse port of
your computer to this
connector. (Refer to P12.)
RGB INPUT 2 TERMINAL
(DIGITAL/ANALOG)
RGB INPUT 1 / OUT TERMINAL
(ANALOG)
COMPUTER AUDIO
INPUT JACK
Connect computer output
(Digital / Analog DVI-I
type) to this terminal.
(Refer to P12.)
This terminal is switchable and
can be used as computer
input or monitor output. Set
the terminal up as either
Computer input or Monitor
output properly before using
this terminal.
(Refer to P12, 36.)
Note:This terminal outputs
analog signal from DVI-I
RGB IN 2 terminal only.
Connect the audio output
(stereo) from your
computer to this jack.
(Refer to P12.)
USB CONNECTOR (Series B)
When
controlling
your
computer with the Remote
Control Unit of this projector,
connect the USB port of your
computer to this connector.
(Refer to P12.)
11
CONNECTING THE PROJECTOR
CONNECTING TO COMPUTER
Cables used for connection
(✽ = Cable or adapter is not supplied with this projector.)
• VGA Cable (HDB 15 pin)
• USB Cable ✽
• MAC Adapter (When connecting to Macintosh computer)
• Control Cable for PS/2 Port
• DVI/VGA Adapter
• DVI-Digital Cable (for Single Link T.M.D.S.) ✽
• Control Cable for Serial Port ✽, or ADB Port ✽
• Audio Cables (RCA x 2 and Mini Plug (stereo) x 1) ✽
✽
IBM-compatible computer or Macintosh computer (VGA / SVGA / XGA / SXGA)
Desktop type
Monitor Output
MAC Adapter ✽
Set slide switches
according to the
chart below.
Monitor Output Monitor Output
or
Monitor Input
Audio Output
Audio
Cable ✽
(stereo)
VGA
Cable ✽
DVI Cable ✽
Laptop type
Serial port
USB port
USB
Cable ✽
Control Cable
for Serial Port ✽
Terminal
PS/2 port
ADB port
Control Cable
for PS/2 Port
Control Cable
for ADB Port ✽
Terminal
Terminal
VGA Cable
DVI-I RGB IN-2
DVI/VGA
Adapter
RGB IN-1 / OUT COMPUTER AUDIO IN
DVI - I
R
RGB IN-2
VIDEO IN
Y
Pb/Cb
AUDIO
L
IN
USB
Use one of these Control
Cables corresponding with
the terminal of your
computer.
CONTROL PORT
Pr/Cr
DVI-I RGB IN-2
S – VIDEO IN
COMPUTER
AUDIO IN
R
AUDIO
OUT L
RESET
NOTE
This terminal is switchable. Set
the terminal up as either
Computer input or Monitor output before using this terminal.
(See page 36)
RGB IN-1 / OUT
CONTROL PORT
Terminals
of the Projector
AUDIO OUT
NOTE :
When connecting the cable, the power
cords of both the projector and the external
equipment should be disconnected from
the AC outlet. Turn the projector and all
peripheral equipment on before the
computer is switched on.
Audio Cable
(stereo) ✽
◆ MAC ADAPTER (Not supplied)
Set switches as shown in the table
below depending on RESOLUTION MODE that you want to use
before you turn on projector and
computer.
1
13" MODE (640 x 480)
ON
16" MODE (832 x 624) OFF
19" MODE (1024 x 768) OFF
21" MODE (1152 x 870) ON
12
2
ON
ON
ON
ON
ON
ON
DIP
Audio Input
1 2 3 4 5 6
External Audio Equipment
OFF
3
4
5
6
OFF OFF OFF OFF
OFF ON OFF OFF
ON OFF OFF OFF
ON ON OFF OFF
Audio Amplifier
Audio Speaker
(stereo)
CONNECTING THE PROJECTOR
CONNECTING TO VIDEO EQUIPMENT
Cables used for connection
(✽ = Cable is not supplied with this projector.)
• Scart-VGA Cable ✽
• Video Cable (RCA x 1 or RCA x 3) ✽
• S-VIDEO Cable ✽
• Audio Cable (RCA x 2) ✽
Video Source (example)
Component video output equipment.
Video Cassette Recorder
RGB Scart
21-pin Output
Scart-VGA
Cable ✽
RGB-IN 1 / OUT
NOTE
It is necessary to select
COMPUTER 1 in the
SETTING Menu when
this terminal is used as
RGB Scart 21-Pin Video
Input. (See page 22, 36.)
S-VIDEO Output
S-VIDEO
Cable ✽
DVI - I
RGB IN-2
Composite
Video Output
Component Video Output Audio Output
(Y, Pb/Cb, Pr/Cr)
(R, L)
Video Cable
(RCA x 1) ✽
S-VIDEO IN
COMPUTER IN 1
DVI - I
(such as DVD player or high-definition TV source.)
Video Disc Player
Video Cable
(RCA x 3) ✽
VIDEO/Y IN
R – AUDIO IN – L (MONO)
AUDIO
R IN
L
S – VIDEO
S – VIDEO IN
AUDIO IN
VIDEO
Y – Pb / Cb – Pr / Cr
VIDEO IN
Y
Pb/Cb
AUDIO IN
COMPUTER
COMPUTER
AUDIO IN
Pr/Cr
R – AUDIO OUT – L
R
OUT
COMPUTER
2 / /MONITOR
RGBININ-1
OUT
Use any of VIDEO/Y jack, S-VIDEO
jack, or VIDEO/Y-Pb/Cb-Pr/Cr jacks.
• When both VIDEO/Y jack and SVIDEO jack are connected, SVIDEO jack has priority over
VIDEO/Y jack.
• When both VIDEO/Y-Pb/Cb-Pr/Cr
jacks and S-VIDEO jack are
connected, VIDEO/Y-Pb/Cb-Pr/Cr
jacks has priority over S-VIDEO
jack.
VIDEO/Y - Pb/Cb - Pr/Cr
Audio Cable
(RCA x 2) ✽
AUDIO
OUT L
RESET
RESET
PORT PORT
USB CONTROL
CONTROL
Terminals
of the Projector
AUDIO OUT
Audio Cable
(Stereo) ✽
Audio Input
NOTE :
When connecting the cable, the power
cords of both the projector and the external
equipment should be disconnected from
the AC outlet.
External Audio Equipment
Audio Speaker
(stereo)
Audio Amplifier
13
BEFORE OPERATION
OPERATION OF THE REMOTE CONTROL UNIT
Left Side
LASER POINTER INDICATOR
POWER ON-OFF BUTTON
ON
Lights red while laser beam
is emitted from Laser Light
Window.
POWER
ZOOM
Used to turn projector on or
off. (P19)
FOCUS VOLUME
F
ALL OF
INPUT BUTTON
Used to select input source.
(P22, 31)
MUTE D.ZOOM INPUT
MENU BUTTON
POINT BUTTON
Used to open or close
ON-SCREEN MENU
operation. (P17, 18)
Used to select an item or
adjust value in ON-SCREEN
MENU. They are also used to
pan the image in DIGITAL
ZOOM +/– mode. (P30)
It is also used as a PC mouse
in Wireless Mouse Operation.
(P40)
MENU
SET BUTTON
ALL-OFF SWITCH
When using the Remote Control
Unit, turn this switch to “ON.” Turn
it to “ALL OFF” when not in use.
Used to execute the item
selected, or to expand/
compress the image in
DIGITAL ZOOM +/– mode.
(P30)
It is also used as a PC
mouse in Wireless Mouse
Operation. (P40)
LASER BUTTON
KEYSTONE
RIGHT CLICK BUTTON
NO SHOW
FREEZE
AUTO PC ADJ.
Used to operate Laser Pointer
Function. Laser beam is
emitted while pressing this
button within 1 minute.
When using this Laser Pointer
for more than 1 minute, release
LASER button and press it
again.
✽ When pressing the center of this
button, it works as SET button.
LASER
Used as a PC mouse in
Wireless Mouse Operation.
(P40)
P-TIMER
P-TIMER BUTTON
Used to operate P-TIMER
function. (P21)
LASER POINTER FUNCTION
This Remote Control Unit emits a laser beam as the laser pointer function from the Laser Light Window. When the LASER
button is pressed, the laser light goes on. And when the LASER button is being pressed for more than 1 minute or the
LASER button is released, the light goes off. The LASER POINTER INDICATOR lights red and the laser is emitted with red
light to indicate that the laser beam is being emitted.
The laser emitted is a class II laser; do not look into the Laser Light Window nor shine the laser beam on yourself or other
people. The caution labels for the laser beam are shown below.
CAUTION : Use of controls, adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
These caution labels are put on the remote control unit.
LASER POINTER INDICATOR
Laser Light Window
14
BEFORE OPERATION
Operating Range
ZOOM BUTTON
POWER
Used to adjust zoom.
(P20)
ZOOM
FOCUS VOLUME
VOLUME BUTTON
Used to adjust volume.
(P21)
FOCUS BUTTON
MUTE D.ZOOM INPUT
Used to adjust focus.
(P20)
Point the Remote Control Unit
toward the projector (Receiver
Window) whenever pressing any
button. Maximum operating range
for the Remote Control Unit is about
16.4’ (5m) and 60° in front and rear
of the projector.
D.ZOOM BUTTON
Used to select DIGITAL
ZOOM +/– mode and
resize image. (P30)
MENU
MUTE BUTTON
16.4’
(5 m)
Used to mute sound.(P21)
60°
KEYSTONE BUTTON
LASER
Used to correct keystone
distortion. (P20, 36)
KEYSTONE
FREEZE BUTTON
NO SHOW
FREEZE
NO SHOW BUTTON
Used to turn the picture
into black image. (P21)
AUTO PC ADJ.
P-TIMER
Used to freeze the picture.
(P20)
IMAGE BUTTON
Used to select image
level. (P28, 33)
60°
AUTO PC ADJ. BUTTON
16.4’
(5 m)
Use to operate AUTO PC
Adjustment function. (P25)
REMOTE CONTROL UNIT BATTERIES INSTALLATION
1
Remove the battery
compartment lid.
Press the lid downward and slide it.
2
Slide the batteries into
the compartment.
3
Replace the compartment
lid.
Two AA size batteries
For correct polarity (+
and –), be sure that the
battery terminals are in
contact with the pins in
the compartment.
To insure safe operation, please observe the following precautions :
● Use (2) AA, UM3 or R06 type alkaline batteries.
● Replace both batteries at the same time.
● Do not use a new battery with a used battery.
● Avoid contact with water or liquid.
● Do not expose the Remote Control Unit to moisture, or heat.
● Do not drop the Remote Control Unit.
● If a battery has leaked on the Remote Control Unit, carefully wipe the case clean and install new batteries.
● Danger of explosion if battery is incorrectly replaced.
● Dispose of used batteries according to battery manufacturer's instructions and local rules.
15
BEFORE OPERATION
TOP CONTROLS AND INDICATORS
POWER ON–OFF BUTTON
KEYSTONE BUTTON
Used to turn projector on or
off. (P19)
Used to correct keystone
distortion. (P20, 36)
MENU BUTTON
READY INDICATOR
Used to open or close ONSCREEN MENU operation.
(P17, 18)
Lights green when the
projector is ready to be
turned on, and flashes
green while in Power
Management mode. (P37)
POWER
READY
SET BUTTON
Used to execute the item
selected, or to expand/
compress the image in
DIGITAL ZOOM +/– mode.
(P30)
KEY
STONE
MENU
LAMP REPLACE INDICATOR
LAMP
REPLACE
SET
INPUT
INPUT BUTTON
Vol –
Vol +
LAMP
ZOOM
FOCUS
WARNING
TEMP.
Used to select input source.
(P22, 31)
16
Turns yellow when the life
of Projection Lamp draws
to an end. (P38)
LAMP INDICATOR
Becomes dim when the
projector is turned on. And
bright when the projector is
in stand-by mode.
ZOOM BUTTON
WARNING TEMP. INDICATOR
Used to adjust zoom.
(P20)
Flashes red while internal
projector temperature is too
high. (P41)
POINT (VOLUME + / – ) BUTTONS
IMAGE BUTTON
FOCUS BUTTON
Used to select an item or adjust value in ONSCREEN MENU. They are also used to pan
the image in DIGITAL ZOOM +/– mode. (P30)
POINT LEFT/RIGHT buttons are also used as
VOLUME +/– buttons.
Used to select image
level. (P28, 33)
Used to adjust focus. (P20)
BEFORE OPERATION
OPERATING THE ON-SCREEN MENU
HOW TO OPERATE THE ON-SCREEN MENU
You can control and adjust this projector through the ON-SCREEN
MENU. Refer to the following pages to operate each adjustment
on the ON-SCREEN MENU.
REMOTE CONTROL UNIT
POINT BUTTON
Used to move the
Pointer UP/ DOWN/
RIGHT/ LEFT.
DISPLAY MENU
1
Press the MENU button to display the ON-SCREEN MENU.
SET BUTTON
Used to select the item.
MOVING POINTER
2
Move the pointer (✽ see below) or adjust the value of item by
pressing the POINT button(s) on the Top Control or on the
Remote Control Unit.
✽ Pointer is the icon on the ON-SCREEN MENU to select
the item. See the section “FLOW OF ON-SCREEN
MENU OPERATION” below.
TOP CONTROL
POINT BUTTONS
Used to move the
Pointer UP/ DOWN/
RIGHT/ LEFT.
SET
SELECT ITEM
3
KEY
STONE
MENU
Select the item or set the selected function by pressing the
SET button.
Vol –
ZOOM
Vol +
FOCUS
SET BUTTON
Used to select the item.
FLOW OF ON-SCREEN MENU OPERATION
MENU BAR
Display ON-SCREEN MENU
1
Press the MENU button to display the ON-SCREEN MENU
(MENU BAR). The red frame is the POINTER.
Select Menu to be adjusted
2
MENU ICON
Move the POINTER (red frame) to the MENU ICON that you
want to select by pressing the POINT RIGHT / LEFT buttons.
POINTER (red frame)
Press the POINT DOWN button to move the POINTER.
POINTER
(red frame)
ITEM
Control or adjust item through ON-SCREEN MENU
3
Press the POINT DOWN button and move the POINTER (red
frame or red arrow) to the ITEM that you want to adjust, and
then press the SET button to show the ITEM.
4
Adjust the ITEM by pressing the POINT RIGHT / LEFT
buttons.
Refer to the following pages for details of respective
adjustments.
SET
BUTTON
ITEM
Press the POINT LEFT/RIGHT
buttons to adjust the value or
set the function.
17
BEFORE OPERATION
MENU BAR
FOR PC SOURCE
Press the MENU BUTTON while connected to the PC input source.
GUIDE WINDOW
PC SYSTEM MENU
Shows a selected
item of ONSCREEN MENU.
Used to select
computer system.
(Refer to P22-24)
SCREEN MENU
SETTING MENU
Used to select image
level among ;
Standard, High
contrast and Custom.
(Refer to P28)
Used to adjust size
of image. [Normal
/ True / Wide /
Digital zoom +/–]
(Refer to P30)
Used to change
settings of projector
or reset Lamp
Replace Counter.
(Refer to P36, 37)
INPUT MENU
PC ADJUST MENU
IMAGE ADJUST MENU
SOUND MENU
Used to select
input source either
Computer or
Video.
(Refer to P22)
Used to adjust
parameters to
match with input
signal format.
(Refer to P25-27)
Used to adjust computer
image.
[Contrast / Brightness /
Color / Tint / White
balance (R/G/B) /
Sharpness / Gamma /
Auto grayscale / Auto
fleshtone]
(Refer to P29, 30)
Used to adjust
volume or mute
sound.
(Refer to P21)
FOR VIDEO SOURCE
Press the MENU BUTTON while connected to the VIDEO input source.
INPUT MENU
IMAGE SELECT MENU
Used to select
input source
either Video or
Computer.
(Refer to P31)
Used to select image
level among
Standard, Cinema
and Custom.
(Refer to P33)
Same function as
Menu for PC source.
18
IMAGE SELECT MENU
SCREEN MENU
Used to set size of
image to Normal
or Wide.
(Refer to P35)
AV SYSTEM MENU
IMAGE ADJUST MENU
Used to select
system of a selected
video source.
(Refer to P32)
Used to adjust picture image.
[Contrast / Brightness / Color /
Tint / White balance (R/G/B) /
Sharpness / Gamma / Auto
grayscale / Auto fleshtone]
(Refer to P34, 35)
Same function as
Menu for PC source.
BASIC OPERATION
TURNING ON / OFF THE PROJECTOR
TURNING ON THE PROJECTOR
1
Complete all peripheral connections (with Computer, VCR, etc.)
before turning on the projector. (Refer to the “CONNECTING
THE PROJECTOR” on page 11~13.)
2
Connect the AC Power Cord into an AC outlet. The LAMP
Indicator lights red, and the READY Indicator lights green.
3
Press the POWER ON-OFF button on the Top Control or on the
Remote Control Unit to ON. The LAMP Indicator dims, and the
Cooling Fans start to operate. The Preparation Display appears
on the screen and the count-down starts.
4
The image level that was selected last and the Lamp mode
status appear for 4 seconds, and the signal from PC or Video
source appears.
NOTE : When the On start function is ON, this projector is turned on
automatically by connecting the AC Power Cord to an AC
outlet. (Refer to the menu item “On start” on page 37.)
26
The Preparation Display disappears after 30 seconds.
Lamp mode
*Refer to page 37 for the Lamp mode.
TURNING OFF THE PROJECTOR
1
Press the POWER ON-OFF button on the Top Control or on the
Remote Control Unit, and the message “Power off?” appears on
a screen.
2
Press the POWER ON-OFF button again to turn off the
projector. The LAMP Indicator lights bright and the READY
Indicator turns off. After the projector is turned off, the Cooling
Fans operate (for 90 seconds).
3
When the projector has cooled down, the READY Indicator lights
green again.
Power off?
Message disappears after 4 seconds.
NOTE : The projector cannot be turned on during cooling period with
the READY Indicator off. You can turn it on again after the
READY Indicator lights green.
TO MAINTAIN THE LIFE OF LAMP, ONCE YOU TURN
PROJECTOR ON, WAIT AT LEAST 5 MINUTES BEFORE
TURNING IT OFF.
DO NOT DISCONNECT AC POWER CORD BEFORE
READY INDICATOR LIGHTS GREEN.
note on operation
When the Power management function is ON, the projector detects signal interruption and turns off the Projection Lamp
automatically. Refer to the menu item “Power management” on page 37.
When the WARNING TEMP. Indicator flashes red, the projector is automatically turned off. Turn the projector on with the
POWER ON-OFF button after the READY indicator lights green.
When the WARNING TEMP. Indicator continues to flash, refer to the section “MAINTENANCE” on page 41 and proper
maintenance should be taken.
19
BASIC OPERATION
ADJUSTING THE SCREEN
ZOOM ADJUSTMENT
1
Press the ZOOM button on the Top Control or the ZOOM ▲/▼
button on the Remote Control Unit. The message “Zoom” is
displayed.
2
Press the ZOOM ▲ button or the POINT UP button to make the
image larger, and press the ZOOM ▼ button or the POINT
DOWN button to make the image smaller.
Zoom
Message disappears after 4 seconds.
FOCUS ADJUSTMENT
1
Press the FOCUS button on the Top Control or the FOCUS ▲/▼
button on the Remote Control Unit. The message “Focus” is
displayed.
2
Adjust the focus of the image by pressing the FOCUS ▲/▼
button or the POINT UP/DOWN button(s) .
Focus
Message disappears after 4 seconds.
KEYSTONE ADJUSTMENT
If the projected picture has keystone distortion, correct the image with KEYSTONE adjustment.
1
Press the KEYSTONE button on the Remote Control Unit or
select Keystone on the SETTING menu. (Refer to page 36.)
The keystone dialog box appears.
2
Correct keystone distortion by pressing the POINT UP/DOWN
button(s) on the Top Control or on the Remote Control Unit.
Press the POINT UP button to reduce the upper part of the
image, and press the POINT DOWN button to reduce the lower
part.
Reduce the upper width
with the POINT UP button.
• The arrows are blue in no correction.
• The arrow of direction being corrected turns light
blue.
• The arrow disappears at the maximum correction.
• If you press the KEYSTONE button on the Remote
Control Unit once more while the keystone dialog
box is being displayed, the keystone adjustment will
be set into no correction.
Reduce the lower width with
the POINT DOWN button.
PICTURE FREEZE FUNCTION
Press the FREEZE button on the Remote Control Unit to freeze the picture on-screen. To cancel the FREEZE function,
press the FREEZE button again or press any other button.
20
BASIC OPERATION
NO SHOW FUNCTION
Press the NO SHOW button on the Remote Control Unit to black out
the image. To restore to normal, press the NO SHOW button again or
press any other button.
No show
Message disappears after 4 seconds.
P-TIMER FUNCTION
Press the P-TIMER button on the Remote Control Unit. The timer
display “00 : 00” appears and the timer starts to count time (00 : 00 ~
59 : 59).
To stop the P-TIMER display, press the P-TIMER button. Press the PTIMER button again to cancel the P-TIMER function.
SOUND ADJUSTMENT
DIRECT OPERATION
Indicates approximate
level of volume.
Volume
Press the VOLUME (+/–) button(s) on the Top Control or on the
Remote Control Unit to adjust the volume. The volume dialog box
appears. The VOLUME (+) button to increase the volume, and the
VOLUME (–) button to decrease the volume.
Mute
Press the MUTE button on the Remote Control Unit to cut off the
sound. To restore the sound to its previous level, press the MUTE
button again or press the VOLUME (+/–) button(s).
MENU OPERATION
1
2
Press the MUTE button to set
the Mute function On or Off.
Dialog box disappears after 4 seconds.
SOUND MENU
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to move the red
frame pointer to the SOUND Menu icon.
Press the POINT DOWN button to move the red frame pointer to
the item that you want to select, and then press the SET button.
SOUND Menu icon
Indicates approximate level of the
volume.
Close the SOUND Menu.
Volume
Press the POINT RIGHT button to increase the volume, and press the
POINT LEFT button to decrease the volume.
Mute
Press the POINT LEFT/RIGHT button to cut off the sound. The dialog
box display is changed to “On” and the sound is cut off. To restore
the sound to its previous level, press the POINT LEFT/RIGHT button
again.
21
COMPUTER INPUT (RGB Scart 21-Pin Video Input)
SELECTING THE INPUT SOURCE
DIRECT OPERATION
Choose either Computer 1 or Computer 2 by pressing the INPUT
button on the Top Control or on the Remote Control Unit.
If the projector cannot reproduce a proper image, select the correct
input source through the “MENU OPERATION” (see below).
INPUT button
Computer 1
✽
Computer 2
Video
✽ Computer 1 is not displayed when RGB IN 1/ OUT
terminal is used as MONITOR OUT.
MENU OPERATION
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT button to move the red
frame pointer to the INPUT Menu icon.
2
Press the POINT DOWN button to move the red arrow pointer to
either Computer 1 or Computer 2 (Computer 1 is not displayed
when MONITOR OUT is selected in the SETTING Menu.), and
then press the SET button. The Source Select Menu will
appear.
3
Move the pointer to the correct input source and then press the
SET button.
INPUT MENU
INPUT Menu icon
Computer 1
Move the pointer either
Computer 1 or Computer
2 and press the SET
button.
Source Select Menu
RGB
When the input source is coming from a computer
through RGB IN 1 / OUT terminal, select RGB.
RGB (Scart)
When the input source is coming from a DVD player
through RGB IN 1 / OUT terminal, select RGB
(Scart).
RGB (Digital)
When the digital signal is connected to DVI
terminal, select RGB (Digital).
RGB (Analog)
When the analog signal is connected to DVI
terminal, select RGB (Analog).
Move the pointer to RGB
or RGB (Scart) and
press the SET button.
Computer 2
Source Select Menu
Move the pointer to RGB
(Digital) or RGB
(Analog) and press the
SET button.
✽ Computer 1 is not displayed when RGB IN 1/ OUT
terminal is used as MONITOR OUT.
NOTE
● Computer 1 can be selected when RGB IN 1 / OUT terminal is set
as COMPUTER 1 at the menu item “Terminal” in the SETTING
Menu. (Refer to page 36.)
22
COMPUTER INPUT
SELECTING THE COMPUTER SYSTEM
This projector automatically tunes to most different types of computers based on VGA, SVGA, XGA, or SXGA (refer to the
“COMPATIBLE COMPUTER SPECIFICATIONS” on page 24). When selecting Computer, this projector automatically tunes
to the incoming signal and projects a proper image without any special setting. (Some computers need to be set manually.)
The projector displays one of the Auto, - - -, Mode 1/2/3/4/5, or the system provided in the projector.
Auto
When the projector cannot recognize the connected
signal, the Auto PC Adjustment function adjusts the
projector, and the message “Auto” is displayed on the
SYSTEM Menu icon. (Refer to page 25.) When the
image is not provided properly, adjust the parameters
manually. (Refer to page 26, 27.)
–––
There is no signal input from the connected computer.
Make sure the connection between the computer and the
projector is set correctly.
(Refer to the “TROUBLESHOOTING” on page 42.)
Mode 1
User preset adjustment in the “MANUAL PC
ADJUSTMENT.” Adjustment data can be stored in the
Mode 1 - 5.
SVGA 1
Computer systems provided in the projector. The
projector chooses a proper system and displays it.
PC SYSTEM MENU
The SYSTEM Menu icon
displays the system being
selected.
*Mode 1 and SVGA 1 are examples.
SELECT COMPUTER SYSTEM MANUALLY
This projector automatically selects the PC system among those
provided in this projector and the PC system can also be selected
manually.
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to move the red
frame pointer to the PC SYSTEM Menu icon.
2
Press the POINT DOWN button to move the red arrow pointer to
the system that you want to set, and then press the SET button.
PC SYSTEM MENU
SYSTEM Menu icon
Displays the system being
selected.
The systems on this dialog box
can be selected.
Custom Mode (1~5) set in the
PC ADJUST Menu. (P26, 27)
NOTE
● The PC SYSTEM Menu cannot be selected when the input signal is
digital.
23
COMPUTER INPUT
COMPATIBLE COMPUTER SPECIFICATIONS
This projector can accept the signal from all computers with the V, H-Frequency below mentioned and less than 100 MHz of
Dot Clock.
ON-SCREEN
DISPLAY
VGA 1
VGA 2
VGA 3
VGA 4
VGA 5
VGA 6
VGA 7
MAC LC13
MAC 13
RGB
RGB
SVGA 1
SVGA 2
SVGA 3
SVGA 4
SVGA 5
SVGA 6
SVGA 7
SVGA 8
SVGA 9
SVGA 10
SVGA 11
MAC 16
XGA 1
XGA 2
XGA 3
RESOLUTION
640 x 480
720 x 400
640 x 400
640 x 480
640 x 480
640 x 480
640 x 480
640 x 480
640 x 480
––––––––
––––––––
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
832 x 624
1024 x 768
1024 x 768
1024 x 768
H-Freq.
(kHz)
31.47
31.47
31.47
37.86
37.86
37.50
43.269
34.97
35.00
15.625
15.734
35.156
37.88
46.875
53.674
48.08
37.90
34.50
38.00
38.60
32.70
38.00
49.72
48.36
68.677
60.023
V-Freq.
(Hz)
59.88
70.09
70.09
74.38
72.81
75.00
85.00
66.60
66.67
50.00
(Interlace)
60.00
(Interlace)
56.25
60.32
75.00
85.06
72.19
61.03
55.38
60.51
60.31
51.09
60.51
74.55
60.00
84.997
75.03
ON-SCREEN
DISPLAY
XGA 4
XGA 5
XGA 6
XGA 7
XGA 8
XGA 9
XGA 10
XGA 11
XGA 12
XGA 13
XGA 14
XGA 15
MAC 19
MAC 21
SXGA 1
SXGA 11
SXGA 13
SXGA 14
SXGA 17
SXGA 18
480p (HDTV)
575p (HDTV)
720p (HDTV)
1035i (HDTV)
1080i 60(HDTV)
1080i 50(HDTV)
RESOLUTION
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1152 x 870
1152 x 864
1152 x 900
1280 x 1024
1280 x 1024
1152 x 900
1280 x 1024
––––––––
––––––––
––––––––
––––––––
––––––––
––––––––
H-Freq.
(kHz)
56.476
60.31
48.50
44.00
63.48
36.00
62.04
61.00
35.522
46.90
47.00
58.03
60.24
68.68
64.20
61.20
50.00
50.00
61.85
46.43
31.47
31.25
45.00
33.75
33.75
28.125
V-Freq.
(Hz)
70.07
74.92
60.02
54.58
79.35
H-Freq.
(kHz)
60.276
31.65
V-Freq.
(Hz)
58.069
29.80
87.17
(Interlace)
77.07
75.70
86.96
(Interlace)
58.20
58.30
72.00
75.08
75.06
70.40
65.20
86.00
(Interlace)
94.00
(Interlace)
66.00
86.70
(Interlace)
59.88
50.00
60.00
60.00
(Interlace)
60.00
(Interlace)
50.00
(Interlace)
When an input signal is digital from DVI terminal, refer to the chart below.
ON-SCREEN
DISPLAY
RESOLUTION
D-VGA
D-SVGA
D-XGA
640 x 480
800 x 600
1024 x 768
H-Freq.
(kHz)
31.47
37.879
43.363
V-Freq.
(Hz)
59.94
60.32
60.00
ON-SCREEN
DISPLAY
RESOLUTION
D-SXGA 2
D-SXGA 3
1280 x 1024
1280 x 1024
NOTE : The projector may not project a proper image for D-SXGA 2 and D-SXGA 3 depending on some computers.
Specifications are subject to change without notice.
24
COMPUTER INPUT
PC ADJUSTMENT
AUTO PC ADJUSTMENT
The Auto PC Adjustment function automatically adjusts Fine sync, Total dots, Horizontal and Vertical picture position to
conform to your computer. The Auto PC Adjustment function can be operated as follows.
Auto PC Adj.
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT button to move the red
frame pointer to the PC ADJUST Menu icon.
2
Press the POINT DOWN button to move the red frame pointer to
the AUTO PC Adj. icon and then press the SET button twice.
This Auto PC Adjustment can also be executed by pressing the
AUTO PC ADJ. button on the Remote Control Unit.
PC ADJUST MENU
PC ADJUST Menu icon
Move the pointer to the AUTO PC Adj. icon
and press the SET button.
Store adjustment parameters.
Adjustment parameters from Auto PC Adjustment can be memorized
in this projector. Once parameters are memorized, setting can be
done just by selecting Mode in the PC SYSTEM Menu (P23). Refer to
step 3 of the “MANUAL PC ADJUSTMENT” section (P27).
NOTE
● The PC ADJUST Menu cannot be operated when the input signal is
digital or RGB is selected in the PC SYSTEM Menu (P23).
● Fine sync, Total dots, Horizontal, and Vertical of some computers
cannot be fully adjusted with this Auto PC Adjustment function.
When the image is not provided properly through this function,
manual adjustments are required. (Refer to page 26, 27.)
● The Auto PC Adjustment function cannot be operated when “720p
(HDTV),” “1035i (HDTV),” or “1080i (HDTV)” is selected in the PC
SYSTEM Menu (P23).
25
COMPUTER INPUT
MANUAL PC ADJUSTMENT
This projector can automatically tune to the display signals of most personal computers. However, some computers employ
special signal formats which are different from the standard ones and may not be tuned by the Multi-Scan system of this
projector. If this happens, the projector cannot reproduce a proper image and the image may be displayed as a flickering
picture, a non-synchronized picture, a non-centered picture, or a skewed picture.
This projector has Manual PC Adjustment to enable you to precisely adjust several parameters to match those special signal
formats. This projector has 5 independent memory areas to memorize those parameters manually adjusted. This enables
you to recall the setting for a specific computer whenever you use it.
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT button to move the red
frame pointer to the PC ADJUST Menu icon.
2
Press the POINT DOWN button to move the red frame pointer to
the item that you want to adjust and then press the SET button.
The adjustment dialog box will appear. Press the POINT
LEFT/RIGHT button to adjust the value.
Fine sync
PC ADJUST MENU
PC ADJUST Menu icon
Move the pointer to the item and press the
SET button.
Adjusts an image as necessary to eliminate flicker from the display.
Press the POINT LEFT/RIGHT button to adjust the value.(From 0 to
31.)
Total dots
Selected Mode
Shows status
(Stored / Free) of the
selected Mode.
The number of total horizontal dots in your picture. Press the POINT
LEFT/RIGHT button(s) and adjust number to match your PC image.
Horizontal
Adjusts the horizontal picture position.
LEFT/RIGHT button(s) to adjust the position.
Press the POINT
Press the POINT LEFT/RIGHT
button to adjust the value.
Vertical
Adjusts the vertical picture position. Press the POINT LEFT/RIGHT
button(s) to adjust the position.
Press the SET button at this icon to
adjust “Clamp,” “Display area (H/V)” or
set “Full screen.”
Current mode
Press the SET button to show the information of your computer.
Clamp
Current mode
Adjusts the clamp level. When the image has a dark bar(s), try this
adjustment.
Press the SET button at the
Current mode icon to show
the information of your
computer.
26
COMPUTER INPUT
Display area
Selects the area displayed with this projector. Select the resolution
at the display area dialog box.
Display area H
Press the SET button at the
Display area icon and the
display area dialog box appears.
Display area
Adjustment of the horizontal area displayed with this projector. Press
the POINT LEFT/RIGHT button(s) to decrease/increase the value.
Display area V
Adjustment of the vertical area displayed with this projector. Press
the POINT LEFT/RIGHT button(s) to decrease/increase the value.
Full screen
Press the POINT LEFT
/RIGHT button(s) to
adjust the value.
Press the POINT LEFT/RIGHT button(s) to turn the Full screen
function “On” or “Off.” Set “On” to resize the image with 4 x 3 aspect
ratio to fit the screen.
NOTE : Full screen cannot be selected after Display area, Display
area H, and Display area V are adjusted.
3
Store
To store the adjustment parameters, move the red frame pointer
to the Store icon and then press the SET button. Move the red
arrow pointer to any of Mode 1 to 5 that you want to store and
then press the SET button.
To store the adjustment data.
This Mode has parameters being stored.
Mode free
To clear the adjustment parameters previously set, move the red
frame pointer to the Mode free icon and then the SET button.
Move the red arrow pointer to the Mode that you want to clear
and then press the SET button.
Other icons operate as follows.
Reset
Reset all adjustment parameters on the adjustment dialog box to
the previous figure.
Vacant Mode
Shows the values of “Total dots,”
“Horizontal,” “Vertical,” “Display
area H,” and “Display area V.”
To clear the adjustment data.
Quit
Closes the PC ADJUST Menu.
Close this dialog box.
NOTE
● Fine sync, Total dots, Display area (H/V) and Full screen cannot be
adjusted when “1035i (HDTV)” or “1080i (HDTV)” is selected on PC
SYSTEM Menu (P23).
27
COMPUTER INPUT
PICTURE IMAGE ADJUSTMENT
IMAGE LEVEL SELECT (DIRECT)
Select the image level among Standard, High contrast, and Custom by
pressing the IMAGE button on the Remote Control Unit.
IMAGE button
Standard
Standard
Normal picture adjustment preset on this projector.
High contrast
High contrast
Picture adjustment improved in reproduction of the halftones. This
adjustment is suitable for providing a better image in a brighter place.
Custom
Custom
User preset picture adjustment in the IMAGE ADJUST Menu (P29,
30).
IMAGE LEVEL SELECT (MENU)
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT button to move the red
frame pointer to the IMAGE SELECT Menu icon.
2
Press the POINT DOWN button to move the red frame pointer to
the level that you want to set and then press the SET button.
Standard
Normal picture adjustment preset on this projector.
High contrast
Picture adjustment improved in reproduction of the halftones. This
adjustment is suitable for providing a better image in a brighter place.
Custom
User preset picture adjustment in the IMAGE ADJUST Menu (P29,
30).
28
IMAGE SELECT MENU
IMAGE SELECT
Menu icon
Move the pointer to the level and
press the SET button.
The level being selected.
COMPUTER INPUT
IMAGE LEVEL ADJUSTMENT
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to move the red
frame pointer to the IMAGE ADJUST Menu icon.
2
Press the POINT DOWN button to move the red frame pointer to
the item that you want to adjust, and then press the SET button.
The level of each item is displayed. Adjust each level by
pressing the POINT LEFT/RIGHT button(s).
IMAGE ADJUST MENU
Move the pointer to the item
to be selected and then press
the SET button.
IMAGE ADJUST
Menu icon
Contrast
Press the POINT LEFT button to decrease the contrast, and the
POINT RIGHT button to increase the contrast. (From 0 to 63.)
Brightness
Press the POINT LEFT button to adjust the image darker, and the
POINT RIGHT button to adjust the image brighter. (From 0 to 63.)
Selected Image level
Color
Press the POINT LEFT button to lighten the color, and the POINT
RIGHT button to darken the color. (From 0 to 63.)
Tint
Press the POINT LEFT/RIGHT buttons to adjust the value.
Press the POINT LEFT button or the POINT RIGHT button to obtain
a proper color. (From 0 to 63.)
White balance (Red)
Press the POINT LEFT button to lighten the red tone and the POINT
RIGHT button to darken the tone. (From 0 to 63.)
Store icon
Press the SET button at this icon to
store the adjustment.
White balance (Green)
Press the POINT LEFT button to lighten the green tone and the
POINT RIGHT button to darken the tone. (From 0 to 63.)
White balance (Blue)
Press the POINT LEFT button to lighten the blue tone and the
POINT RIGHT button to darken the tone. (From 0 to 63.)
Sharpness
Press the POINT LEFT button to soften the image, and the POINT
RIGHT button to sharpen the image. (From 0 to 15.)
Gamma
Press the POINT LEFT button or the POINT RIGHT button to obtain
a better balance of the contrast. (From 0 to 15.)
Auto grayscale
When this function is “ON,” it automatically enhances the contrast of
the bright and dark part of image.
Auto fleshtone
When this function is “ON,” it produces a more vivid image according
to the image condition.
NOTE
● Auto grayscale cannot be operated when the
input signal is digital.
29
COMPUTER INPUT
3
Store
To store the manual image level, move the red frame pointer to
the Store icon and press the SET button. The message “OK?”
will appear. Select [Yes] to store manual adjustment.
To set this manual adjustment, select Custom by pressing the
IMAGE button or through the IMAGE SELECT Menu (refer to P28).
“OK?” message
Move the pointer to
[Yes] and then press
the SET button.
Other icons operate as follows.
Reset
Reset all adjustments to the previous figure.
Quit
Closes the IMAGE Menu.
PICTURE SCREEN ADJUSTMENT
This projector has the picture screen resize function, which enables you to display the desirable image size.
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT button(s) to move the
red frame pointer to the SCREEN Menu icon.
2
Press the POINT DOWN button and move the red frame pointer
to the function that you want to select and then press the SET
button.
SCREEN MENU
SCREEN Menu icon
Move the pointer to the function
and press the SET button.
Normal
Provides the image to fit the screen size.
True
Provides the image in its original size. When the original image size
is larger than the screen size (800 x 600), this projector enters
“Digital zoom +” mode automatically.
Wide
Provides the image to fit a wide video aspect ratio (16 : 9) by
expanding the image width uniformly. This function can be used for
providing a squeezed video signal at 16 : 9.
Digital zoom +
When Digital zoom + is selected, the ON-SCREEN MENU
disappears and the message “D. Zoom +” is displayed. Press the
SET button to expand the image size. And press the POINT
UP/DOWN/LEFT/RIGHT button(s) to pan the image. The Panning
function can work only when the image is larger than the screen size.
A projected image can also be expanded by pressing the D.ZOOM ▲
button on the Remote Control Unit.
Digital zoom –
When Digital zoom – is selected, the ON-SCREEN MENU
disappears and the message “D. Zoom –” is displayed. Press the
SET button to compress the image size.
A projected image can also be compressed by pressing the D.ZOOM
▼ button on the Remote Control Unit.
To cancel Digital zoom +/– mode, press any button except D.ZOOM
▲/▼, SET, POINT and LASER buttons.
30
NOTE
● This SCREEN Menu cannot be operated when
“1035i (HDTV)” or “1080i (HDTV)” is selected on
the PC SYSTEM Menu (P23).
● Wide cannot be selected when “720p (HDTV)” is
selected on the PC SYSTEM Menu (P23).
● True and Digital zoom +/– cannot be selected
when “RGB” is selected on the PC SYSTEM Menu
(P23).
● This projector cannot display any resolution higher
than 1024 x 768. If your computer’s screen
resolution is higher than 1024 x 768, lower the
resolution before connecting the projector.
● The image data in other than SVGA (800 x 600) is
modified to fit the screen size.
● The Panning function may not operate properly if
the computer system set on the PC ADJUST Menu
is used.
VIDEO INPUT
SELECTING THE INPUT SOURCE
DIRECT OPERATION
Choose Video by pressing the INPUT button on the Top Control or on
the Remote Control Unit.
If the projector cannot reproduce a proper video source, select correct
input source through the “MENU OPERATION” (see below).
INPUT button
Computer 1
✽
Computer 2
RGB Scart Input
To select RGB Scart 21-Pin video input through RGB IN 1 / OUT
terminal, see the “COMPUTER INPUT (RGB Scart 21-Pin Video
Input)” on page 22.
Video
✽ Computer 1 is not displayed when RGB IN 1/ OUT
terminal is used as MONITOR OUT.
MENU OPERATION
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT button to move the red
frame pointer to the INPUT Menu icon.
2
Press the POINT DOWN button to move the red arrow pointer to
Video and then press the SET button. The Source Select Menu
will appear.
3
Move the pointer to the source that you want to select and then
press the SET button.
Auto
When selecting Auto, the projector automatically detects
the incoming video signal, and adjusts itself to optimize
its performance. The projector selects the connection in
the following order:
1st Y-Pb/Cb-Pr/Cr
2nd S-VIDEO
3rd VIDEO
Y-Pb/Cb-Pr/Cr has priority over S-VIDEO. S-VIDEO has
priority over VIDEO.
Video
When the video input signal is connected to VIDEO/Y
jack, select Video.
S-Video
When the video input signal is connected to S-VIDEO
jack, select S-Video.
Y,Pb/Cb,Pr/Cr
INPUT MENU
VIDEO
Move the pointer to
Video and press the
SET button.
Source Select Menu (VIDEO)
Move the pointer to the source and press the SET
button.
✽ Computer 1 is not displayed when RGB IN 1/ OUT
terminal is used as MONITOR OUT.
When the video input signal is connected to
VIDEO/Y-Pb/Cb-Pr/Cr jacks, select Y, Pb/Cb, Pr/Cr.
31
VIDEO INPUT
SELECTING THE VIDEO SYSTEM
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to move the red
frame pointer to the AV SYSTEM Menu icon.
2
Press the POINT DOWN button to move the red arrow pointer to
the system that you want to select and then press the SET
button.
VIDEO/Y JACK OR S-VIDEO JACK
AV SYSTEM MENU (VIDEO OR S-VIDEO)
Auto
The projector automatically detects the incoming video system, and
adjusts itself to optimize its performance.
When the video system is PAL-M or PAL-N, select system manually.
PAL / SECAM / NTSC / NTSC4.43 / PAL-M / PAL-N
If the projector cannot reproduce a proper video image, it is necessary
to select a specific broadcast signal format among PAL, SECAM,
NTSC, NTSC 4.43, PAL-M, and PAL-N.
AV SYSTEM Menu icon
This box indicates the system
being selected.
Move the pointer to the
system and press the
SET button.
VIDEO/Y, Pb/Cb, Pr/Cr JACKS
AV SYSTEM MENU (COMPONENT VIDEO)
Auto
The projector automatically detects the incoming video signal, and
adjusts itself to optimize its performance.
COMPONENT VIDEO SIGNAL FORMAT
If the projector cannot reproduce a proper video image, it is necessary
to select a specific component video signal format among 480i, 575i,
480p, 575p, 720p, 1035i and 1080i.
32
AV SYSTEM Menu icon
This box indicates the system
being selected.
Move the pointer to the
system and press the
SET button.
VIDEO INPUT
PICTURE IMAGE ADJUSTMENT
IMAGE LEVEL SELECT (DIRECT)
Select the image level among Standard, Cinema, and Custom by
pressing the IMAGE button on the Remote Control Unit.
IMAGE button
Standard
Standard
Normal picture level preset on this projector.
Cinema
Cinema
Picture level adjusted for the picture with fine tone.
Custom
Custom
User preset picture adjustment in the IMAGE ADJUST Menu (P34,
35).
IMAGE LEVEL SELECT (MENU)
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT button to move the red
frame pointer to the IMAGE SELECT Menu icon.
2
Press the POINT DOWN button to move the red frame pointer to
the level that you want to set and then press the SET button.
IMAGE SELECT MENU
IMAGE SELECT
Menu icon
Standard
Normal picture level preset on this projector.
Cinema
Move the pointer to the level and
press the SET button.
The level being selected.
Picture level adjusted for the picture with fine tone.
Custom
User preset picture adjustment in the IMAGE ADJUST Menu (P34,
35).
33
VIDEO INPUT
IMAGE LEVEL ADJUSTMENT
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT button(s) to move the
red frame pointer to the IMAGE ADJUST Menu icon.
2
Press the POINT DOWN button to move the red frame pointer to
the item that you want to adjust and then press the SET button.
The level of each item is displayed. Adjust each level by
pressing the POINT LEFT/RIGHT button(s).
IMAGE ADJUST MENU
Move the pointer to the item
to be selected and then press
the SET button.
IMAGE ADJUST
Menu icon
Contrast
Press the POINT LEFT button to decrease the contrast, and the
POINT RIGHT button to increase the contrast. (From 0 to 63.)
Brightness
Press the POINT LEFT button to adjust the image darker, and the
POINT RIGHT button to adjust the image brighter. (From 0 to 63.)
Color
Press the POINT LEFT button to lighten the color, and the POINT
RIGHT button to darken the color. (From 0 to 63.)
Press the POINT LEFT/RIGHT buttons to adjust the value.
Tint
Press the POINT LEFT button or the POINT RIGHT button to obtain
a proper color. (From 0 to 63.)
Press the SET button at this icon to
display other items.
White balance (Red)
Press the POINT LEFT button to lighten the red tone and the POINT
RIGHT button to darken the tone. (From 0 to 63.)
Press the SET button at this icon to
display the previous items.
White balance (Green)
Press the POINT LEFT button to lighten the green tone and the
POINT RIGHT button to darken the tone. (From 0 to 63.)
Press the POINT LEFT/RIGHT buttons to adjust the value.
White balance (Blue)
Press the POINT LEFT button to lighten the blue tone and the
POINT RIGHT button to darken the tone. (From 0 to 63.)
Sharpness
Press the SET button at this icon to
store the value.
Press the POINT LEFT button to soften the image, and the POINT
RIGHT button to sharpen the image. (From 0 to 15.)
Gamma
Press the POINT LEFT button or the POINT RIGHT button to obtain
a better balance of the contrast. (From 0 to 15.)
Auto grayscale
When this function is “ON,” it automatically enhances the contrast of
the bright and dark part of image.
Auto fleshtone
When this function is “ON,” it produces a more vivid image according
to the image condition.
34
NOTE
● Tint cannot be adjusted when the video system is
PAL, SECAM, PAL-M or PAL-N.
VIDEO INPUT
3
Store
To store the manual image level, move the red frame pointer to
the Store icon and press the SET button. The message “OK?”
will appear. Select [Yes] to store manual adjustment.
To set this manual adjustment, select Custom by pressing the
IMAGE button or through the IMAGE SELECT Menu (refer to
P33).
“OK?” message
Move the pointer to
[Yes] and then press
the SET button.
Other icons operate as follows.
Reset
Store icon
Reset all adjustments to the previous figure.
Quit
Closes the IMAGE Menu.
PICTURE SCREEN ADJUSTMENT
This projector has the picture screen resize function, which enables you to display the desirable image size.
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT button(s) to move the
red frame pointer to the SCREEN Menu icon.
2
Press the POINT DOWN button and move the red frame pointer
to the function that you want to select and then press the SET
button.
SCREEN MENU
SCREEN Menu icon
Move the pointer to the function and
press the SET button.
Normal
Provides the image at a normal video aspect ratio of 4 : 3.
Wide
Provides the image at a wide screen ratio of 16 : 9.
NOTE
● The SCREEN Menu cannot be operated when “720p,” “1035i,” or
“1080i” is selected on the AV SYSTEM Menu (P32).
35
SETTING
SETTING MENU
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT button(s) to move the
red frame pointer to the SETTING icon.
2
Press the POINT DOWN button to move the red frame pointer to
the item that you want to set and then press the SET button.
The setting dialog box appears.
SETTING MENU
Set the pointer to the
item and press the
SET button.
SETTING Menu icon
Language
The language used in the ON-SCREEN MENU is available in
English, German, French, Italian, Spanish, Portuguese, Dutch,
Swedish, Russian, Chinese, Korean, and Japanese.
Keystone
This function corrects the distorted image. Select either Store or
Reset, and then press the SET button. The keystone dialog box
appears. (Refer to page 20.)
Store ···· stores the keystone adjustment data when the AC
Power Cord is disconnected.
Reset ···· resets the keystone adjustment data when the AC
Power Cord is disconnected.
When pressing the SET
button at Language, the
Language Menu appears.
Blue back
When this function is “On,” the projector produces a blue image while
the input signal is not detected.
Display
This function decides whether to display the On-Screen Displays.
On ··· shows all the On-Screen Displays.
Off ···· sets the On-Screen Displays disappeared except;
● ON-SCREEN MENU
● “Power off?” message
● P-TIMER
● “No signal” message
● “Wait a moment!” message
Move the pointer to the item
and then press the POINT
LEFT/RIGHT button(s).
Ceiling function
Logo
When this function is “On,” the projector displays our logo when
starting up.
Ceiling
When this function is “On,” the picture is top / bottom and left / right
reversed. This function is used to project the image from a ceiling
mounted projector.
Rear function
Rear
When this function is “On,” the picture is left / right reversed. This
function is used to project the image to a rear projection screen.
Terminal
RGB IN 1 / OUT terminal on the back of the projector can be used as
computer input or monitor output by switching with the POINT
LEFT/RIGHT button. (See the right Note.)
To use the terminal as computer input, select Computer 1.
To use the terminal as monitor out, select Monitor out.
36
NOTE
● This Terminal item cannot be selected when the
input source is selected as “Computer 1” in the
“SELECTING THE INPUT SOURCE” (P22).
SETTING
Power management
This function turns the Projection Lamp off when this projector
detects a signal interruption and is not used for a certain period in
order to reduce the power consumption and maintain the Lamp-life.
(This projector is shipped with this function ON.)
The Power Management function operates to turn the Projection
Lamp off when the input signal is interrupted and any button is not
pressed over 5 minutes. This function operates as follows;
1. When any input signal is interrupted, “No signal” and the count
down display appears (for 5 minutes).
2. After counting down for 5 minutes, the Projection Lamp and the
READY Indicator are turned off. (Cooling Fans keep running.)
3. The READY Indicator starts to flash after cooling down the
Projection Lamp about for 90 seconds (Power Management
mode).
In this Power Management mode, the Projection Lamp is
automatically turned on when the input signal is connected or
the projector is operated with any button on the Top Control or
on the Remote Control Unit again.
Time left until Lamp off.
Press the SET button at
this icon to display other
items.
On start
When this function is “On,” the projector is automatically turned on
just by connecting the AC Power Cord to an AC outlet.
NOTE : Be sure to turn the projector off properly (refer to the section
“TURNING OFF THE PROJECTOR” on P19). If the
projector is turned off in the wrong steps, the On Start
function does not operate properly.
Press the SET button at
this icon to display the
previous items.
Lamp mode
When selecting the “
” (Silent), the projector reduces the
brightness and sets into the low power consumption mode.
Move the pointer to the
item and then press the
POINT LEFT/RIGHT
button(s).
Remote control
This projector has two different remote control codes; the factory-set
normal code (Code 1) and the secondary code (Code 2). This
switching function prevents remote control interference when
operating several projectors or video equipment together.
When operating the projector in “Code 2,” both the projector and the
Remote Control Unit must be switched to “Code 2.”
To change the code of the Projector;
Set the Remote control in the SETTING Menu to “Code 2.”
To change the code of the Remote Control Unit;
Press both the MENU and the IMAGE buttons on the Remote
Control Unit together for over 10 seconds.
After changing the code, make sure the Remote Control Unit
operates properly.
To return to the normal code (Code 1), repeat the steps above.
NOTE : When the batteries of the Remote Control Unit are replaced
or ALL-OFF switch is turned to “ALL-OFF,” the remote
control code automatically returns to the normal code (Code
1).
Lamp counter reset
This function is used to reset the Lamp Replace Counter. When
replacing the Projection Lamp, reset the Lamp Replace Counter by
using this function. Refer to page 39 for operation.
37
APPENDIX
LAMP REPLACEMENT
LAMP REPLACE
When the life of the Projection Lamp of this projector draws to an end,
the LAMP REPLACE indicator lights yellow. If this indicator lights
yellow, replace the Projection Lamp with a new one promptly.
TOP CONTROL
Y
NE
LAMP
REPLACE
This indicator lights yellow
when the life of the Projection
Lamp draws to an end.
Replace the Projection Lamp
with a new one promptly.
LAMP
US
WARNING
TEMP.
CAUTION
Allow the projector to cool, for at least 45 minutes before
you open the Lamp Cover. The inside of the projector
can become very hot.
For continued safety, replace with a lamp assembly of
the same type.
Do not drop the lamp assembly or touch the glass bulb!
The glass can shatter and may cause injury.
Follow these steps to replace the lamp assembly.
LAMP COVER
1
Turn off the projector and disconnect the AC plug. Allow the
projector to cool for at least 45 minutes.
2
3
To remove the Lamp Cover, remove the screw with a
screwdriver.
4
Replace the Lamp Assembly with a new one and tighten 3
screws back into position. Make sure the Lamp Assembly is set
properly. Replace The Lamp Cover and tighten the screw.
5
Connect the AC Power Cord to the projector and turn on the
projector.
6
Reset the Lamp Replace Counter.
Refer to the “LAMP REPLACE COUNTER” on the next page .
SCREW
Loosen 3 screws with a screwdriver and pull out the Lamp
Assembly by grasping the Handle.
LAMP
ASSEMBLY
SCREW
HANDLE
ORDER REPLACEMENT LAMP
The Replacement Lamp can be ordered through your dealer. When ordering a Projection Lamp, give the
following information to the dealer.
●
Model No. of your projector
● Replacement Lamp Type No.
:
:
LV-5200
LV-LP16
(610 303 5826)
38
APPENDIX
LAMP REPLACE COUNTER
Be sure to reset the Lamp Replace Counter after the Lamp Assembly is replaced. When the Lamp Replace Counter is reset,
the LAMP REPLACE Indicator stops lighting.
1
Turn the projector on, press the MENU button and the ONSCREEN MENU will appear. Press the POINT LEFT/RIGHT
button(s) to move the red frame pointer to the SETTING
Menu icon (refer to page 36, 37).
2
Press the POINT DOWN button to move the red frame
pointer to “Lamp counter reset” and then press the SET
button. The message “ Lamp replace counter reset? ” is
displayed. Move the red arrow pointer to [Yes] and then
press the SET button.
3
Another confirmation dialog box appears and select [Yes] to
reset the Lamp Replace Counter.
Move the pointer to the Lamp counter reset icon and
then press the SET button. The message “Lamp
replace counter reset?” is displayed.
NOTE : Do not reset the Lamp Replace Counter until after the Projection Lamp is replaced.
LAMP HANDLING PRECAUTIONS
This projector uses a high-pressure lamp which must be handled carefully and properly. Improper
handling may result in accidents, injury, or create fire hazard.
● Lamp lifetime may differ from lamp to lamp and according to the environment of use. There is no
guarantee of the same lifetime for each lamp. Some lamps may fail or terminate their lifetime in a
shorter period of time than other similar lamps.
● If the projector indicates that the lamp should be replaced, i.e., if the LAMP REPLACE INDICATOR
lights up, replace the lamp with a new one IMMEDIATELY after the projector has cooled down.
( Follow carefully the instructions in the LAMP REPLACEMENT section of this manual. ) Continuous
use of the lamp with the LAMP REPLACE INDICATOR lighted may increase the risk of lamp explosion.
● A Lamp may explode as a result of vibration, shock or degradation as a result of hours of use as its
lifetime draws to an end. Risk of explosion may differ according to the environment or conditions in
which the projector and lamp are being used.
IF A LAMP EXPLODES, THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE TAKEN.
If a lamp explodes, disconnect the projector’s AC plug from the AC outlet immediately. Contact an
authorized service station for a checkup of the unit and replacement of the lamp. Additionally, check
carefully to ensure that there are no broken shards or pieces of glass around the projector or coming out
from the cooling air circulation holes. Any broken shards found should be cleaned up carefully. No one
should check the inside of the projector except those who are authorized trained technicians and who are
familiar with projector service. Inappropriate attempts to service the unit by anyone, especially those who
are not appropriately trained to do so, may result in an accident or injury caused by pieces of broken
glass.
39
APPENDIX
OPERATING WIRELESS MOUSE
The Remote Control Unit is not only able to operate this projector but also usable as a wireless mouse for most Personal
Computers. The POINT buttons and two CLICK buttons are used for wireless mouse operation.
This Wireless Mouse function is available only when PC mouse pointer is displayed on a projected screen. When the ONSCREEN MENU or any message / dialog box is displayed on the screen instead of PC mouse pointer, this Wireless Mouse
function cannot be used.
INSTALLATION
To use the Remote Control Unit as Wireless Mouse for a Personal Computer, installation of the mouse driver (not supplied)
is required. Make sure that the mouse driver is properly installed in your computer and that the mouse port (or USB port) of
your computer is activated.
Note : When your computer has no mouse
Connect the mouse port (or USB port) of your computer to
port, connect the Serial Port of your
Control Port (or USB connector) of this projector with the Control
computer to the Control Port of the
Cable (or USB cable). (Refer to page 11, 12 for connection.)
projector with the Control Cable for the
Serial Port (not supplied).
Turn the projector on first, and then turn on your computer.
1
2
When the computer is switched on first, Wireless Mouse may not
work properly.
OPERATING WIRELESS MOUSE
When controlling a PC mouse pointer, operate Wireless Mouse with the POINT button, SET button, and RIGHT CLICK
button on the Remote Control Unit.
POINT button
POINT button (Move the pointer)
Used to move PC mouse pointer. The pointer is moved
corresponding with the direction you are pressing.
SET (LEFT CLICK) button
This button has the same function as the left button in a PC mouse.
RIGHT CLICK button
This button has the same function as the right button in a PC mouse.
This button is not available for controlling this projector.
40
SET button
(left button of the
mouse)
RIGHT CLICK button
(right button of the mouse)
APPENDIX
MAINTENANCE
WARNING TEMP. INDICATOR
The WARNING TEMP. Indicator flashes red when an internal temperature of the projector exceeds the normal temperature.
When the WARNING TEMP. Indicator continues to flash, check the items listed below.
1
2
3
The Ventilation Slots of the projector may be blocked. In such an event, reposition the projector so that the Ventilation
Slots are not obstructed.
The Air Filter may be clogged with dust particles. Clean the Air Filter by following the section “AIR FILTER CARE AND
CLEANING” below.
If the WARNING TEMP. Indicator remains on after performing the above checks, the Cooling Fans or the Internal
Circuits may be malfunctioning. Contact service personnel from an authorized dealer or a service station.
AIR FILTER CARE AND CLEANING
The Removable Air Filter prevents dust from accumulating on the surface of the Projection Lens and the Projection Mirror.
Should Air Filter become clogged with dust particles, it will reduce the Cooling Fans’ effectiveness and may result in internal
heat build up and adversely affect the life of the projector. Clean the Air Filter following the steps below:
1
Turn off the projector, and disconnect the AC Power Cord from
the AC outlet.
2
Turn the projector upside down and remove the Air Filter by
pulling the latches upward.
3
4
Clean the Air Filter with a brush or wash out dust and particles.
Replace the Air Filter properly. Make sure the Air Filter is fully
inserted.
CAUTION
Do not operate the projector with the Air Filter removed.
Dust may accumulate on the LCD Panel and the Projection
Mirror, and may degrade the picture quality.
Do not put small parts into the Air Intake Vents. It may
result in malfunction of the projector.
AIR FILTER
Pull up and remove.
RECOMMENDATION
We recommend avoiding dusty/smoky environment when operating the projector. Operating in these environments
may cause poor image quality.
When using under dusty or smoky conditions, dust may accumulate on the lens, liquid crystal panels, or optical elements
inside the projector. This condition may degrade the quality of a projected image.
When the above symptoms are noticed, contact your authorized dealer or service station for proper cleaning.
CLEANING PROJECTION LENS
Follow these steps to clean the Projection Lens:
1
Apply a non-abrasive camera lens cleaner to a soft, dry cleaning cloth. Avoid using an excessive amount of cleaner.
Abrasive cleaners, solvents or other harsh chemicals might scratch the lens.
2
3
Lightly wipe a cleaning cloth over the Projection Lens.
When the projector is not in use, attach the Lens Cover.
41
APPENDIX
TROUBLESHOOTING
Before calling your dealer or service center for assistance, check the following:
● Make sure you have connected the projector to peripheral equipment as described properly in the section “CONNECTING
THE PROJECTOR” on pages 11 ~ 13.
● Verify that all computer, video and power cord are properly connected and turn the equipment on.
● When you are operating the projector with a computer and it does not produce an image, restart the computer.
● Select the other input source.
Problem:
No power.
Try these Solutions
● Plug the projector into an AC outlet.
● Make sure the READY Indicator lights.
● Wait 90 seconds after the projector is turned OFF before turning the projector back on.
NOTE : After pressing the Power ON-OFF button to OFF, make sure the projector works as
follows:
1. The LAMP indicator lights bright and the READY indicator turns off.
2. After 90 seconds, the READY indicator lights green again and the projector can
be turned on by pressing the Power ON-OFF button.
● Check the WARNING TEMP. indicator. If this indicator flashes red, the projector cannot
be turned on.
(See the “TURNING ON/OFF THE PROJECTOR” section on page 19.)
● Check the Projection Lamp. (Refer to page 38.)
Image is out of
focus.
● Adjust the focus of the projector.
● Make sure a projection screen is at least 3.6’ (1.1m) from the projector.
● Check the Projection Lens to see if it needs cleaning.
NOTE : Moving the projector from a cool temperature location to a warm temperature
location may result in moisture condensation on the Projection Lens. In such an
event, leave the projector OFF and wait until condensation disappears.
Picture is Left/Right
reversed.
● Check Ceiling / Rear feature. (See the “SETTING” section on page 36.)
Picture is
Top/Bottom
reversed.
● Check Ceiling feature. (See the “SETTING” section on page 36.)
Some displays are
not seen during the
Operation.
● Check Display feature.(See the “SETTING” section on page 36.)
No image.
●
●
●
●
No sound.
●
●
●
●
●
Computer 1 cannot
be selected.
42
Check the connection between your computer or video equipment and the projector.
Check the NO SHOW function. (Refer to P21.)
When turning the projector on, it takes about 30 seconds to display an image.
Check the system that you select is corresponding with your computer or video
equipment.
● Make sure the temperature is not out of the Operating Temperature (5°C ~ 35°C).
Check the audio cable connection from the audio input source.
Adjust the audio source.
Press the VOLUME (+) button.
Press the MUTE button.
Check RGB IN 1 / OUT terminal is set as COMPUTER 1. (See the “SETTING” section
on page 36.)
APPENDIX
Problem:
Try these Solutions
Remote Control Unit
does not work.
● Check the batteries.
● Check ALL-OFF switch on the Remote Control Unit is set to “ON.”
● Make sure nothing is between the Infrared Remote Receiver and the Remote Control
Unit.
● Make sure you are not too far from the projector when using the Remote Control Unit.
Maximum operating range is 16.4’ (5m).
● Make sure the code of the Remote Control Unit is set to conform to the projector.
(See the “SETTING” section on page 37.)
Wireless Mouse
function does not
work.
● Check the cable connection between the projector and your computer.
● Check the mouse setting on your computer.
● Turn the projector on before turning on your computer.
WARNING :
High voltages are used to operate this projector. Do not attempt to open the cabinet.
If the problem still persists after following all operating instructions, contact the sales dealer where you purchased the
projector or the service center. Give the model number and explain the problem in detail. We will advise you how to obtain
service.
This symbol on the nameplate means the product is Listed by Underwriters
Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety standards
against risk of fire, casualty and electrical hazards.
The CE Mark is a Directive conformity mark of the European Community. (EC)
43
APPENDIX
INDICATORS AND PROJECTOR CONDITION
Check the Indicators for the projector condition.
Indicators
LAMP
REPLACE
yellow
WARNING
TEMP.
red
READY
LAMP
green
red
Projector Condition
The projector is OFF. (The AC Power Cord is unplugged.)
✽
The projector is READY to be turned on with the POWER
ON-OFF button.
✽
The projector is operating normally.
✽
The temperature inside the projector is abnormally high. The
projector cannot be turned on. When the projector is cooled
down enough and the temperature returns to normal, the
READY indicator lights green and the projector can be turned
on. (The WARNING TEMP. indicator keeps flashing.) Check
and clean the Air Filter.
✽
The projector is cooled down enough and the temperature
returns to normal. When turning on the projector, the WARNING TEMP. indicator stops flashing. Check and clean the Air
Filter.
✽
The projector is being cooled down. It cannot be turned on until
the READY indicator lights green.
✽
The projector detects an abnormal condition and cannot be
turned on. Unplug the AC Power Cord and plug it again to turn
on the projector. If the projector is turned off again, disconnect
the AC Power Cord and contact the dealer or the service center for service and checkup. Do not leave the projector on. It
may cause electric shock or fire hazard.
✽
The projector is in the Power management mode.
• • • on
✽ When
• • • flashing
• • • dim
• • • off
the life of the Projection Lamp draws to an end, the LAMP REPLACE indicator lights yellow. When this indicator lights yellow,
replace the Projection Lamp with a new one promptly. Reset the Lamp Replace Counter after replacement of the lamp.
44
APPENDIX
TECHNICAL SPECIFICATIONS
Projector Type
Dimensions (W x H x D)
Net Weight
LCD Panel System
Panel Resolution
Number of Pixels
Color System
High Definition TV Signal
Scanning Frequency
Projection Image size (Diagonal)
Horizontal Resolution
Projection Lens
Throw Distance
Projection Lamp
Video Input Jacks
Audio Input Jacks
RGB Input Terminal
RGB Input / Output Terminal
Computer Audio Input Jack
Control Port Connector
USB Connector
Audio Output Jacks
Internal Audio Amp
Built-in Speakers
Feet Adjustment
Voltage and
Power Consumption
Operating Temperature
Storage Temperature
Remote Control Unit
Accessories
Multi-media Projector
13.05” x 3.52” x 9.61” (331.5mm x 89.5mm x 244.1mm) (not including Adjustable Feet)
9.48 lbs (4.3 kg)
0.8” TFT Active Matrix type, 3 panels
800 x 600 dots
1,440,000 (800 x 600 x 3 panels)
PAL, SECAM, NTSC, NTSC4.43, PAL-M and PAL-N
480i, 480p, 575i, 575p, 720p, 1035i, and 1080i
H-sync. 15 ~ 80 KHz, V-sync. 50 ~ 100 Hz
Adjustable from 24” to 300”
500 TV lines (S-Video)
F 1.7 ~ 2.44 lens with f 25.7 mm ~ 37.9 mm with motor zoom and focus
3.6’ ~ 31.8’ (1.1 m ~ 9.7 m)
180 W
RCA Type x 3 (Video/Y, Pb/Cb, Pr/Cr) and Mini DIN 4 pin x 1 (S-Video)
RCA Type x 2
DVI-I Terminal (Digital/Analog)x 1
(VGA) HDB 15 Terminal(Analog) x 1 (This terminal is switchable.)
Mini Jack (stereo) x 1
Mini DIN 8 pin x 1
USB Series B receptacle x 1
RCA Type x 2
1.0 W RMS
1 speaker, 1.18” x 1.57” (30mm x 40mm)
0˚ to 15.6˚
AC 100 ~ 120 V (3.0 A Max. Ampere), 50 / 60 Hz (The U.S.A and Canada)
AC 200 ~ 240 V (1.5 A Max. Ampere), 50 / 60 Hz (Continental Europe)
41 ˚F ~ 95 ˚F (5 ˚C ~ 35 ˚C)
14 ˚F ~ 140 ˚F (-10 ˚C ~ 60 ˚C)
Power Source
Operating Range
Dimensions
Net Weight
Laser Pointer
:
:
:
:
:
AA, UM3 or R06 Type x 2
16.4’ (5m) / ±30˚
2.2” x 1.3” x 7.6” (55mm x 34mm x 192mm)
0.36 lbs (165 g) (including batteries)
Class II Laser (Max. Output : 1mW / Wave length : 650±20nm)
Owner’s Manual
AC Power Cord
Remote Control Unit and Batteries
VGA Cable
Control Cable for PS/2 port
DVI/VGA Adapter
Carrying Bag
Lens Cover and Strap for Lens Cover
● The specifications are subject to change without notice.
● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a
tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels.
45
APPENDIX
CONFIGURATIONS OF TERMINALS
RGB INPUT 1 / OUT TERMINAL (ANALOG)
Terminal : HDB15-PIN
Pin Configuration
4
5
10
15
14
2
3
9
8
13
1
7
12
1
2
3
4
5
6
7
8
6
11
Red Input
Green Input
Blue Input
Sense 2
Ground (Horiz.sync.)
Ground (Red)
Ground (Green)
Ground (Blue)
9
10
11
12
13
14
15
+5V Power
Ground (Vert.sync.)
Sense 0
DDC Data
Horiz. sync.
Vert. sync.
DDC Clock
9
10
11
12
13
14
15
16
T.M.D.S. Data1–
T.M.D.S. Data1+
T.M.D.S. Data1 Shield
No Connect
No Connect
+5V Power
Ground (for +5V)
Hot Plug Detect
RGB INPUT 2 TERMINAL (DIGITAL / ANALOG)
Terminal : DVI-I TERMINAL
Pin Configuration
C1 C2
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
C3 C4
C5
46
C1
C2
C3
C4
C5
Analog Red Input
Analog Green Input
Analog Blue Input
Analog Horiz. sync
Analog Ground (R/G/B)
1
2
3
4
5
6
7
8
T.M.D.S. Data2–
T.M.D.S. Data2+
T.M.D.S. Data2 Shield
No Connect
No Connect
DDC Clock
DDC Data
Analog Vert. sync
17
18
19
20
21
22
23
24
T.M.D.S. Data0–
T.M.D.S. Data0+
T.M.D.S. Data0 Shield
No Connect
No Connect
T.M.D.S. Clock Shield
T.M.D.S. Clock+
T.M.D.S. Clock–
APPENDIX
CONTROL PORT CONNECTOR
Terminal : Mini DIN 8-PIN
Pin Configuration
8
5
7 6
4 3
2 1
1
2
3
4
5
6
7
8
PS/2
----CLK
DATA
GND
--------GND
-----
1
2
3
4
Vcc
- Data
+ Data
Ground
Serial
RXD
--------GND
RTS / CTS
TXD
GND
GND
ADB
----ADB
----GND
------------GND
USB CONNECTOR (Series B)
Pin Configuration
2
1
3
4
OPTIONAL PARTS
The parts listed below are optionally supplied. When ordering those parts, give the name and Type No. to the sales dealer.
● Control Cable (Serial Port)
Type No. : LV-CA26
● Control Cable (ADB Port)
Type No. : LV-CA27
● MAC Adapter
Type No. : LV-AD02
● SCART-VGA Cable
Type No. : LV-CA31
(This cable is used for RGB Scart
21-Pin output of video equipment.)
47
