Laminators
Trimmers & Cutters
Business Card Slitters
Creasing, Perf & Score
Folders
Joggers
Drills
Shrink Wrap
General Office Equipment
Shredders
Padding Press
Punch & Bind Systems
www.southwestbindings.com
1-877-285-7044
Of Canada Inc.
Print Finishing Equipment | Binding Supplies | Presentation & Branding Material
Hot & Cold Laminators
Southwest Bindings
has laminating
systems for any job.
From 13" to 65", 1 to
2 sided hot or cold
films and mounting
capabilities.
Southwest has the largest
selection of stock and
custom laminating films in
the market.
Call us today for our latest
price list.
VersaLam 2700HC 27" Hot & Cold Roll Laminator
Xyron Laminator
Features:
• 1-side & 2-side laminating
• Core sizes: 1” & 3”
• Take-up roller for cold lamination
• Max. mounting capacity: ¼” boards
Instantly apply laminate,
adhesive, without heat or
electricity with Xyron. Drop-in
cartridges allow quick and easy
application changes. There is no
smell, mess or waiting because
no power is required to operate
this machine.
• Max document thickness:
3.2mm
• Max finished document:
from 12” to 42”
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2
Middle de-curling bar
Back pull bar
On/off switch for bottom roller heat
Max. laminating width: 27”
Max. laminating thickness: 10mil
Max. laminating speed: 5’/min
Max. OD for top film: 11”
5 rear fans with on/off switch
Variable speed & temperature
control
Temperature conversion feature
Auto shut-off
Feed tray & front shield sensors
Includes its own stand
Rear film slitter
Guide plate for 8.5” x 11”
Heavy-duty, all-metal construction
1-877-285-7044
Roll Laminators
Fujipla LPE 3510
•
•
•
•
13” desktop laminator
Maximum 3mil film, 1” core
Hot shoe 194-300° F
Roll separator to avoid flat
spots
• 5 minute warm-up time
• Adjustable speed, heat
and tension
LamRite-2700 27” Roll Laminator
Engineered for productivity, the 27” LamRite-2700
Roll Laminator delivers superior results at laminating
speeds up to 8.8 ft / minute and can be used with
films up to 10 mil thick. Simple to operate and perfect
for Schools, Copy Shops and In-Plant centers. Standard
features include variable speed / temperature and
tension control for enhanced reliability.
• Film core size: 1”
• Max Speed: up to 8.8’/minute
RSH-380 15” Laminator
• New size, up to 15” actual laminating width
• Fast, up to 5m/min. ( 16.5ft/min.)
• Large film roll capacity up to 11”
diameter
• Accepts thick substrates up
to 6mm (0.24”)
• Stand-by function: power
saving and auto shut off
application
Pro Educator Laminator
•
•
•
•
•
25” maximum film width
1/8” maximum lamination thickness
Automatic cooling fan
Adjustable heat control
Laminate up to
5 mil film thickness
• Heat shoe
Super DH-1100
The DH-1100 roll laminator is solidly constructed,
simple to use, and will laminate documents in no time.
Included: back trimmer, big roll film bracket, machine
stand and take-up shaft.
• Max laminating width:
42" (1080mm)
• Max laminating thickness: 3/16" (5mm)
• Max laminating speed:
5 ¼ ft /min
• Max working temp:
284° F
• Rec. film thickness:
Up to 10 mil
• Dimensions (LxWxH):
45 ft x 17 ft x 38 ³⁄₈ ft
• Power requirements:
AC 100V; 110V; 220-240V;
50/
50/60Hz
RSL-2702-S
• Laminate digital and offset graphics, outdoor signage,
Inkjet & silk-screened posters, photo finishing, large
format material, flexible & rigid displays, decaling and
floor graphics
• Fast: Laminates thermal and pressure sensitive films up
to 27” wide at speeds up to
8.2’/min
• Versatile: Able to mount
boards up to 3/16” thick
and laminate up to 10 mil.
film
www.southwestbindings.com
3
Of Canada Inc.
Print Finishing Equipment | Binding Supplies | Presentation & Branding Material
Foliant One-Side Laminators
Why Foliant?
Foliant Laminators are the
world's #1 brand of single
sided laminators.
Laminating speeds from
23' to 164' per minute,
automatic feeding, automatic
jogger and pallet stackers
available on some models.
520HP
FOLIANT 520HP is a simple manual
feed laminating machine, designed
with an operating width of 20½
inches. It represents an ideal choice
for a professional in-house single
side lamination.
With 18 different models
we have a laminator for any
plant and job.
520T
The machine’s main feature is a small floor space, one single phase 220–240V
supply cable, a nice design and an easy machine operation. The Modular
Stand is supplied optionally.
4
720HP
Gemini C 400S
FOLIANT 720HP is a simple manual
feed laminating machine, designed
with an operating width of 720 mm.
It represents an ideal choice for a
professional in-house single side
lamination in small offset printing
shops printing and processing
sheets up to B1+ size.
FOLIANT Gemini C 400S is a
semiautomatic high pressure
laminating machine (laminator,
separator). The machine is
equipped with a pneumatic
system of laminating rollers
pressure with an easy thrust
control.
1-877-285-7044
ALM Automatic System
ALM Automatic System
Southwest Bindings is proud to
present the next generation in
fully automatic laminating of
digital prints. The ALM3222 will
automatically feed, laminate and
trim, freeing you to work on other
profitable tasks. When coupled
with our film, it becomes an
instant profit-generator!
ALM 3222 Specifications
Laminating Speed
• 20” - 72”/min.
Temperature Range
• 170-270°F
ALM3222
Fully Automatic Laminator
•
•
•
•
•
•
•
•
•
•
•
•
Warm-up time
• Approx. 5 min.
Small foot print - less than 4 sq. ft.
Portable - locking roller casters
115 Volt, 15 amp service with economy mode
Ultra quick warm up of less than 5 minutes
Virtually unattended operation
Digital sheet sizes: 13”x19”, 12”x18”, 11”x17”, 8.5”x11”
Operating with built in long mode allows sheets of infinite length to be
laminated
Automatically feeds up to 200 sheets
Laminates copy paper or as heavy as 130lb cover stock
Automatic two side or one side lamination
Automatic flush or sealed edge trim
Film thickness available: 1.2mil, 1.5mil, 3 mil, 5 mil
Thickness of objects
• 20lb bond - 130lb cover
Trimming methods
• 2 modes - flush trim or edge
seal for all 4 sides of the print
Operation panel
• LCD display for start, stop,
temperature, speed and trim
settings, leading and trailing
edge side cuts are adjustable
Other features
• Laminated sheet counter, film
tension control, roll gap lever,
paper thickness adjustment
lever, automatic stop at end
of film, power saving mode,
emergency stop function
Before Lamination
After Lamination
www.southwestbindings.com
Included Accessories
• Stand with film waste box,
printed operations manual
5
Of Canada Inc.
Print Finishing Equipment | Binding Supplies | Presentation & Branding Material
Trimmers
Roto Trimmers
Roll-A-Blade
Blade 64
• Max. Trim
m Length: 64
• Self-Sharpening
arpening Tungsten Rotary Blade
• Transparent Clamping Bar: Holds the trimming
material in place
• Trimming Capacity: Up to 2.0 mm thick
• Trimming Materials: Paper, newsprint, cardboard,
plastic films, vellum, aluminum foil, vinyl, pvc,
polyester, polypropylene, polyethylene, leather,
veneer, and more
• Metal Stand with heavy-duty locking wheels and
waste catcher (incl. with [email protected] 64 ONLY)
Evolution
• Available in: 64” - 84” - 104” - 124” - 144” cut lengths
The unique four piece cutter slideway and torsion
bar extrusion combines with all the new full length
base plate to create a cutting machine that will
meet the challenges of the most demanding jobs.
The integral lift and hold mechanism of the new
Evolution, operable from either end, ensures
consistent straightness even under flex, while the
swing-over and under-bench stowaway facility
provides maximum working convenience and space
efficiency.
Features also include:
• Single handed positioning, cutting, and clamping
• 1:15000 guaranteed
cutting straightness
• Cuts all flexible
materials, as well as
semi-rigid materials up to
13mm, and Acrylic/Plexiglas
Ask Us About the Proteus Work
Bench. Permanent work bench
mounting is required.
6
Excalibur 5000
The Excalibur 5000 features two cutting heads offering
four cutting tools mounted for instant selection. All
four blades will cut on the same line. The integral
counterbalance ensures an easy glide cutting action.
Adding to efficiency, the Turn and Lock ready mounted
tools provide instant action.
The Excalibur 5000 is equipped to cut Glass 6mm, PVC
Foam board 13mm, Foamcore 13mm, Cardboard, Acrylic
(Plexi) 6mm, Xanita 13mm, DiBond 3mm, Polycarbonate
and MDF 4mm. Call for a quote.
Excalibur 1000X - 63”
The Excalibur 1000X series vertical cutter features a
single sliding counter-balanced head with 3 cutting
and scoring tools ready for instant use. Equipped to cut
Glass, PVC Foamboard, Foamcore, Cardboard, Acrylic
(Plexi) and many more semi-rigid materials.
Other
sizes
available
Roll-A-Blade 18” & 36”
•
•
•
•
•
Self-sharpening Tungsten Blade
Extra wide work table with special grid ruler guide
Twin sliding poles guide the blade with extreme stability
Transparent clamping bar
Other sizes are available
1-877-285-7044
Pouch Laminators
Pouch Laminators
These machines use a
lamination pouch that is
sealed on one side.
The inside of the pouch
is coated with a heatactivated film that sticks
to the product once
it runs through the
machine for protection
of your documents. Call
Southwest Today!
PRO-330 Laminator
PROLAM Photo Laminator
The Pro-330 is a two roller heat
system for a more efficient
lamination at lower temperatures.
The two heated rollers allow a
balanced heat distribution during
laminating process providing a
crystal clear finish.
The PROLAM Photo laminator is a
heated six roller pouch laminator
designed for crystal clear lamination
on difficult to laminate print such as
photographs, color copies, and inkjet
prints.
Features
4” or 12”
Industrial
PRO-330
Laminator
Uses a two heated plate system.
Laminate from business card size
up to 12” x 18” from 3mil up to
10 mil film thickness. Adjustable
temperature control. Laminating
speed (9” x11-1/2”) approx. 30 secs.
Laminating Pouches
PRO LAM
Photo Laminator
Laminate up to 12x18 sheets
Yes
Yes
Yes
Laminate Speed (9” x 11-1/2”)
27 seconds
25 seconds
12-59 seconds
Photo Capabilities
No
Yes
Yes
Max. Lamination Thickness
10 Mil
10 Mil
10 Mil
Variable Speed Control
No
Yes
Yes
Warm-Up Time
Approx. 3-4 min.
Approx. 3-4 min.
Approx. 3-4 min.
Reverse Speed
No
Yes
Yes
Variable Heat Control
Yes
Yes
Yes
Light System to Start
Yes
Yes/Digital
Yes/Digital
Heat Source
Plate System
3 Hot Roller and
Heat Plate System
6 Hot Roller and
Cold Plate System
Cooling System
No
No
Yes
www.southwestbindings.com
4” & 12” Industrial
Laminator
• Guaranteed to work in all makes
and models of laminators
• Laminating pouches are
available in 3mil, 5mil, 7mil, and
10mil thickness
• Variety of widths and sizes
7
Of Canada Inc.
Print Finishing Equipment | Binding Supplies | Presentation & Branding Material
Heavy Duty Punches
SW Series
Heavy Duty Punches
General Features and Benefits
• All metal construction makes it sturdy
& gives this equipment a long life
• Punches up to 20-55 sheets for
increased productivity
• Easy Change Die System makes it
quick and convenient
SW-4012
012
SW-7650
650
• Vertical paper feed makes it easy to
align sheets
• Punches up to 30 sheets
• Paper sizes up to 12” length
• Punches up to 55 sheets
• Paper sizes up to 14” length
SW-7000
SW-7700
• Punches up to 40 sheets
• Paper sizes up to 14” length
• Punches up to 55 sheets
• Paper sizes up to 14” length
APES-14
PAL-14
• Ejects & stacks in one operation
• Increases productivity up to 50%
• Fits vertical SW series machines
• Increases productivity by up to 25%
• The Anti-Jam function makes it
reliable, and provides increased
productivity
• Foot pedal allows for hands free
punching
• Internal safety switch will
automatically cut the power off
when the lid is lifted open
• Removable pins allow proper
centering of the documents
• Binding modules available for
Plastikoil inserter, Wire-O Closer and
Plastic Binding Opener
We offer multiple punching die
patterns for SW series punching
machines. All dies
m
aare extremely
durable with
all-steel
construction.
Die
Patterns
3 Hole
Punch Pattern
Machine Rating
Not to Scale
Sheets of paper punch per hour*
2:1
3:1
SW-4012
22000
Punching Dies
4:1
4:1 Oval
5mm
SW-7000
25000
• Power on demand reduces wear &
tear on machine and noise level, plus
it saves you 75% on your energy cost
SW-7650
30000
SW-7700
30000
3:1 Thumb
Comb (9/16”)
Power
On Demand
Systems
Uses 75%
Less Energy
8
Adjustable
2:1
2:1
3:1
1-877-285-7044
Paper Cutters
Why Triumph Cutters?
For over half a century, Triumph has manufactured products to the highest standards of quality and
reliability to become the leading manufacturer of small format paper cutters in the world. Triumph cutters
and trimmers are world renown for their power, precision, and innovative safety features.
13 different models to choose from makes Triumph Cutters 'The Perfect Finish'
4305 Manual Cutter
4215 Semi-Automatic Cutter
ter
• Solid steel blade
• Adjustable steel blade guides
• Patented, lever-activated,
fast-action clamp
• Spindle back gauge
• Cutting width: 16-7/8”
• Cutting height: 1-1/2”
• Narrow cut: 1-5/16”
• Solid steel blade
• Adjustable steel blade guides
• Patented, lever activated, fastaction clamp
• Spindle back gauge
• Cutting width: 16-7/8”
• Cutting height: 1-1/2”
• Narrow cut: 1-5/16”
4810 D Semi-Automatic Cutter
TRIUMPH® 5560
• Solid steel blade carrier and adjustable blade guides
• Electric blade drive, 1.5 hp motor
• Dual side guides on front and
rear tables
• Spindle clamping system and
spindle-guided back gauge
• Cutting width: 18-7/8”
• Cutting height: 3”
• Narrow cut: 1-1/4”
• LED optical cutting line
• Stand with storage shelf
Programmable cutter with hydraulic blade and clamp
drive, power back gauge, digital touchpad, and IR safety
light beams on front table.
• Cutting width:
21-5/8”
• Cutting height:
3-3/4”
w/false clamp:
3-5/8”
Paper Cutters
• Narrow cut:
w/false clamp:
1-1/4”
3-5/8”
• Length
behind blade:
22-7/16”
Operation
Programmable
Back Gauge
-
Manual
No
6 ¼”
Manual
No
9”
Manual
No
17”
9”
Electric
No
17”
9”
Electric
No
1 ³⁄₁₆”
18 ¼”
8 ¹⁄₈”
Manual
No
1 ¼”
17 ¹¹⁄₁₆”
13 ⁵⁄₈”
Electric
No
3"
1 ¼”
17 ¹¹⁄₁₆”
13 ⁵⁄₈”
Electric
No
3"
1 ³⁄₈”
17 ¹¹⁄₁₆”
13 ⁵⁄₈”
Electric
Yes
3"
1”
20 ³⁄₈”
16”
Electric
Yes
3 ¾”
1 ¼”
22 ⁷⁄₁₆”
18”
Electric
Yes
3"
1”
24”
16 ¼”
Electric
Yes
25 ½”
3"
1”
24”
16 ¼”
Electric
Yes
28”
3"
¾”
28 ³⁄₈”
20 ⁷⁄₈”
Electric
Yes
Narrow Cut
Cutting Length
Behind Blade
Cutting Width
Cutting Height
Martin Yale 7000 E
12”
1 ½”
-
14”
Triumph 4300
16 ⁷⁄₈”
¾”
1 ½”
13 ½”
Triumph 4305
16 ⁷⁄₈”
1 ½”
1 ⁵⁄₁₆”
17”
Triumph 4315
16 ⁷⁄₈”
1 ½”
1 ³⁄₈”
Triumph 4350
16 ⁷⁄₈”
1 ½”
1 ³⁄₈”
Triumph 4705
18 ¾”
2 ¾”
Triumph 4810 D
18 ⁷⁄₈”
3"
Triumph 4850 D
18 ⁷⁄₈”
Triumph 4860 ET
18 ⁷⁄₈”
Triumph 5255
20 ³⁄₈”
Triumph 5560
21 ⁵⁄₈”
Triumph 6555
25 ½”
Triumph 6660
Triumph 7260
www.southwestbindings.com
Table Length in
Front of Blade
9
Of Canada Inc.
Print Finishing Equipment | Binding Supplies | Presentation & Branding Material
Business Card Slitters
Cardmate Manual BCS
• Fast Production: 60+ cards/min.
• Lightweight and Economical:
Easily moves from desk to desk
• Handles up to 110 index
• Safe: No open access to slitting
blades
• No power required
BC10
0
• Cuts 10 standard size business
cards per page
• Quick and easy set-up and
adjustment
• Self-sharpening blades
• Perforator and scorer are optional
BC-12
C-12
• Can be used for a wide variety of
jobs, including business cards, post
cards, digital photos, cheques, etc.
• Eliminates costly and time
consuming business card
production, cut to size in a single
pass
• Cuts 12 standard size business
cards per page
10
GC10 Business Card Slitter
GC210 Business Card Slitter
• Creates 2” x 3½” business cards in
one single pass
• Continuously feed stacks of up
to 40 sheets, creating up to 45
completed cards per minute
• Adjustable paper guides that allow
for easy customized set-up
• Self-sharpening blades made of
hardened steel for years of use
• Quickly produce business cards
with bleed edge design
• Fits securely on custom waste bin
for easy-of-use, maximizing run
time and no-mess production
• Easily converts 8½” x 11” sheets to
finished 2” x 3½” business cards
with a simple two pass operation
ZipA3-Programmable Cutter
Slitter
HS-3000 Gutter Cut
Designed to handle print-ondemand business cards, playing
cards, tickets, post cards, greeting
cards and others.
• Sheet size up to 12½” x 20”
• Inline rotary gutter-cut slitting,
scoring and perforating
capabilities
• Now you can slit FULL BLEED cards
with ease
• Semi self sharpening blades
• Fast, adjustable guide
• All weights of stock slit accurately
including raised letter
• No routine maintenance required
• Fast easy setup, user friendly
1-877-285-7044
Folders
93 Manual Folder
207M Manual Folder
• Compact size with feed and
exit table folding in for storage
• Performs 4 standard folds
and custom folds on paper
sizes up to 8½” x 14”
• Colour-coded fold plate
graphics for quick and easy set up
• Simple push button operation
and programmable counter
• Powered exit conveyor tray for folded sheets
• Easy set-up for standard
and custom folds
• 4 digit LED counter with
batch and total functions
• Test button folds 2 sheets for
inspection
• Extended exit tray for neat stacking of
folded sheets
• Auxiliary paper guide for cross folding
• Skew and micro-adjustment dials
2051 Smartfold Folder
307A Automatic Folder
• Handles paper weight from
18 lb. bond to 90 lb. index
• Variable speed ranges from
3,000 to 15,000 sheets per hour
• Handles sheet sizes from
2½" x 5 ¹³⁄₆₄" to 12" x 18"
• Feed table capacity can hold up to
500 sheets of 8½" x 11", 20 lb. bond
• High memory capacity with 7 preset
folds and 10 custom folds
• Preprogrammed with
6 standard folds
• Stores 18 custom folds
in memory
• Control panel includes LED 4 digit
counter with batch and total functions
• Test button folds 2 sheets for inspection
• Automatically senses & displays paper size
• Auxiliary paper guide for cross folding
• Skew and micro-adjustment dials
Paper Folders
Martin Yale P6400
Folding Speed
Sheets/hr.
Paper Size
min. to max.
Sheet
Capacity
Standard
Folds
Paper Weight
min. to max.
Programmable
Memory
Dimensions
(L x W x H)
2200
8 ½” x 11”
3 to 5
2
16lb. to 24lb. Bond
No
7” x 14” x 7”
Martin Yale P7200
4000
8 ½” x 11”
50
2
16lb. to 28lb. Bond
No
11” x 20” x 13”
Ideal MBM 93M
7200
4” x 5” to 8 ½” x 14”
150
4
16lb. to 80lb. Bond
Yes
14” x 24” x 32”
Martin Yale 1611
9000
3 ½” x 5” to 8 ½” x 14”
150
5
16lb. Bond to 70lb. Index
Yes
33” x 16” x 14”
Martin Yale 1217A
10,300
3 ½” x 4” to 11 ¾” x 18”
250
6
16lb. Bond to 126lb. Index
Yes
42” x 18” x 17”
Ideal MBM 207M
10,500
3” x 5” to 12” x 17 ½”
450
6
16lb. Bond to 80lb. Bond
Yes
21” x 41” x 20”
Martin Yale 1812
12,00
2 ½” x 5 ¹³⁄₆₄” to 12” x 18”
500
7
18lb. Bond to 90lb. Index
Yes
43” x 22” x 17”
Ideal MBM 307A
11,520
3 ½” x 5” to 11” x 17”
450
6
14lb. to 70lb. Bond
Yes
21” x 41” x 20”
Martin Yale 2051
15,000
2 ½” x 5 ¹³⁄₆₄” to 12” x 18”
500
7
18lb. Bond to 90lb. Index
Yes
43” x 22” x 18”
Ideal MBM 407A
11,520
3 ½” x 5” to 11” x 17”
450
6
14lb. to 70lb. Bond
Yes
21” x 41” x 20”
Ideal MBM 352F
22,000
2” x 2 ¾” to 14” x 21 ¼”
300
6
13lb. to 110lb. Bond
Yes
22” x 42” x 15”
Air Feed Folders
Mark VIII
35,000
3 ½” x 4 ¼” to 14” x 20”
350
6
16lb. Bond to 70lb. Index
Yes
43” x 25” x 17”
Ideal MBM 352S
30,000
3 ³⁄₈” x 4 ¾” to 12 ⁵⁄₈” x 17 ¾”
450
6
13lb. to 110lb. Bond
Yes
22” x 51” x 44”
www.southwestbindings.com
11
Of Canada Inc.
Print Finishing Equipment | Binding Supplies | Presentation & Branding Material
Cornering, Numbering & Perforating Machines
Auto Pro Plus - Numbering, Perforating & Scoring System
Rosback 218 Bobcat Table
Top Perforating and Scorers
The Rosback 218 Bobcat Table Top
Perforator and Scorer Features:
• Cycle speed of 15,000 feet per
hour
• Quiet and simple to operate
• Minimum sheet size of 2½” x 3”
up to a Maximum of 18” x 18”
CR-50P Round Corner
• Designed to handle paper and
plastic products
• Electric operation with foot
pedal activation for fast and
effortless cutting
• Can be operated up to 30
strokes per minute
• Table size: 17” x 17”
• Actual Weight: 70lbs
• Shipping Weight: 112 lbs
• Accepts Standard,,
Special and
Large size
Corner
rounder®
cutting
units
12
The Auto Pro Plus models I and
II offer 18" wide feed. Capable of
mounting up to four perf and/or
score wheel assemblies, the self
fanning automatic bottom friction
feed allows for continuous feeding.
• Quickly change from perf to score
in a matter of seconds
• Patented self inking disposable ink
cartridges: no re-inking required
for approx. 20,000 impressions per
cartridge
• Feed rail micro-lateral adjustment
for easy setup of number-perfscore locations
• Number single sheets or crash
number up through an 8 part
carbonless form
• Six speed modes: 3 numbering
speed modes and 3 perforating
speed modes
• Seven deluxe wheel Gothic reverse
numbering heads offer five repeat
sequences: 0, 1, 2, 3 & 6 plus three
drop-away zeros
• Perforating blade styles available:
5-1 (18 teeth), 9-1 (33 teeth), 12-1
(45 teeth), Micro Perf (185 teeth),
Micro Perf (96 teeth)
Numbering,
Perforating,
Scoring,
Micro-Perforating,
Digital Media
Scoring
Diamond-1 Corner Rounding Machine
• Capable of cutting all standard materials including:
PVC, Polyester, Leather, Paper, Polypropylene, etc.
• Designed to cut through multiple sheets at a time
• Interchangeable die system for various cutting jobs
• 1/4" corner rounder cutting die included with
machine
• Optional dies & accessories available
Optional Dies & Accessories
No: C15
Straight Knife
Size: Adjustable
No: D21
Semicircle Knife
Size: 13/16”
No: D6
Punch Knife
Size: 1/4” hole
No: R3.5
Radius Knife
Size: 1/8”
No: R10
Radius Knife
Size: 3/8”
Spare
Plastic
Pads
1-877-285-7044
Creasing & Scoring
iCrease Touch - Creaser
EZ Creaser
Touchscreen with Automatic
Distance Recognition. Perfect for the
short to medium run digitally printed
stock that needs creasing without
cracking the toner.
• The iCrease offers a 13” wide feed
- perfect for most digital print sizes
of 12” x18” or 13” x19”
• Manual feed allows for lower price
point
• Automated Distance Recognition
allows for auto setups of half crease
or tri-fold crease jobs
• Fixed rail plus magnetic rail helps
to guide the sheet for squareness
• Sheet size 4” x4” to 13” x13”
• Output speed: up to 2000 sph
ph
The affordable EZ Creaser has the
Ability to Micro-Perf, Rotary Score,
and Crease up to 12 times per sheet.
• Touch screen
• Friction top feed automatic
creasing
• Perforating and scoring machine
• Accurate rotary actuated creasing
• Linear perf/score capabilities,
including micro and laser perf
• Micro-lateral adjustable feed rails
• Batch and total counters
• Double Sheet Detection
• Ability to add Inline Folder
EC-460
Electric Creaser Perforator
Fastback Scoring
HS-100 Handi-Scor
• Transparent die guide lets you see
where each score goes
• Patented centering guide eliminates
any guesswork from the process
• Interchangeable dies let you choose
between single and double scores
• Ergonomic design, low resistance
lever, and a soft grip handle
• Score or perforate up to 12”
width
• Capable of handling light
bond to heavy card stock and
laminations
The EC-460 Creaser Perforator
Machine Features:
• Electric operation by foot pedal
• Has interchangeable dies: one for
creasing and one for perforating
• Creases up to 13.78” wide
• All metal construction
www.southwestbindings.com
Super 18” Creaser
• All Metal Construction for
exceptional durability
• Ideal for creasing short-run
digital printed coated stocks
• Twin stops with magnets and
screw
• Suited for either left or righthanded operation
• Bar and channel gives a
straight and consistent crease
across the full length of the
sheet
• 18” Maximum creasing width
• Lightweight, easily move and
store
off the work surface.
• Dimensions: 24” x 19½” x 5”
• Weight: 10kg
13
Of Canada Inc.
Print Finishing Equipment | Binding Supplies | Presentation & Branding Material
Case Making Print Finishing
Why Case Making
Print Finishing?
Perfect Binder
Personalized, custom printed
hard covers are no longer a
luxury; these are a necessity
in order to compete for your
customers.
Fastbind
Elite XT
Take your glossy or
non-glossy sheets and
custom
Hard Cover,
and perfect
bind your
book using
this
machine.
With Fastbind Case makers
you can make personalized
hard covers in minutes –
using your design, your
printer, your imagination!
Express Blank Cases
BooXter Duo
These pre-made Hard Covers join
together with the tacking sheets.
Staple your proposal/book together and then
use the guide to insert your sheets
into the Hard Cover, attach
the end sheets and
you have your
custom
book
complete.
BooXter 3030 Express Hand
Cover Maker
Use this machine to align the Blank
cases and Tacking sheet for a perfect
casemade cover.
BooXter Zero Max Binder
This machine staples your printed
photo sheets together for extra
security. The built in Hard Cover
guide allows you to put those sheets
into your previously made Hard
Cover.
FASTBIND Cover Tacking
Sheets
Print your own custom covers using
your digital laser or ink jet printer.
Casematic H32 Pro
Use the H32 Pro cover assembly guide
and corner cutter to turn your printed
tacking sheets and chipboards into a
customer hard cover.
14
1-877-285-7044
Paper Drills & Bookletmac
Bookletmac
The BookletMac Semi-Automatic
Booklet Maker is fast and easy
to use, allowing you to produce
up to 800 booklets per hour
of up to 80 pages. Its versatile
functions gives you the option of
Fold & Staple, Fold only or Staple
only. Side and corner stapling is
also available.
Makes books from:
Letter, A4, A3, Legal, and 11” x 17”
Flat Paper Size: 4¾” x 8¼” to 12½”
Finished Booklet Size: 4 1⁄8” x 4¾” to 8½” x 12””
Production Speed: Up to 800 booklets per hour
Max. # of Sheets: 20 sheets 20lb. bond or equivalent
uivalent
Staple Capacity: Maximum 4
Staple Type: Flat 26/6; Flat 26/8; Loop 26/6
Paper Drills
EBM-2 – Single Hole Drill
JF – Single Hole Drill
EH-3C – Three Hole Drill
Horse Power
¼”
Horse Power
¼”
Spindle Motor
1
Volts
115
Volts
115
Volts
208/18 amps
Table Size
13x24”
Table Size
13x24”
Table Size
19½”x31½”
Max. Throat Depth
1½”
Max. Throat Depth
1½”
Max. Drill Capacity
2½”
Table Travel
14”
Table Travel
14”
Floor Space Needed
36”x41½”
Table Height
3½”
Table Height
3½”
Table Height
37”
Base Footprint
12”x13½”
Base Footprint
12”x13½”
Overall Height
59¼”
Overall Height
26”
Overall Height
26”
Weight
520 lbs
Weight
77lbs
Weight
77lbs
Shipping Weight
570 lbs
Shipping Weight
94 lbs
Shipping Weight
94 lbs
Shipping Dimensions
32”x21”x22”
Shipping Dimensions
32”x21”x22”
Shipping Dimensions
32”x21”x22”
www.southwestbindings.com
Drill Sizes
Available:
2” Bits: 13 Sizes: 1/8” to ½”
2½” Bits: 4 Sizes: ¼” to ½”
15
Of Canada Inc.
Print Finishing Equipment | Binding Supplies | Presentation & Branding Material
Shrink Wrap Systems
Shrink Wrap Film
Made from Polyolefin. Available in
60 gauge - 4375 ft. per roll, 75 gauge
- 3500 ft per roll and a variety of
widths. Call for more information.
Shrinkwrap Machines
Affordable and easy to use portable shrink wrap systems provide security and
helps prevent damage, giving your products a professional appearance.
• Shrink wrap packages in seconds for less than 5¢
• Protects products from tampering, fingerprints, dirt, scratches, moisture, etc.
18˝ Industrial Shrink Wrap
System with Heat Gun
S4 Wrapper
The S4 Wrapper is a chamber type shrink packaging machine. It does the
sealing and shrinking in one operation using centre-folded shrink films, at
speeds of up to 5 per minute.
Standard features include:
• 3 operating modes – seal only, seal
and shrink, seal then shrink
• 16 programmable memories for
storing operating parameters
• Stainless Steel Product Loading
Table
• Teflon Coated sealing blade
• Touch pad controls
• Magnetic hold down
PP1519E
All-in-One Shrink System
This L’ Sealer and Tunnel
combination system is only 76” in
total length. New feature: Micro Knife
Seal Technology. The tunnel features
a fully re-circulating air chamber.
Economy series. 15” W x 19”L.
16
Compact and all-in-one design
dispenses, seals and trims film. This
kit includes the bar sealer and a
H-915 heat gun.
• Handles 1-2 packages/minute
• Works with shrink wrap bags,
tubing or film
• Heavy duty steel construction
Medium duty, heavy shrink gun for
use with portable bar sealing shrink
wrapping systems.
Features:
•
•
•
•
•
1.2 lbs
ps
120 volts, 10 amps
1200 watts
Hanging hook
Dual heat selection: 1000°F / 750°F
1-877-285-7044
Shredders
Heavy Duty Shredder Bags
Southwest has shredders ranging
from small single desk units, office
central units, Pharmacy/
Government grade units
and even CD and hard
drive destroyer units are
available. We also carry
shredder bags for all
the models we sell.
Keep it “CONFIDENTIAL” ... Shred it!
Comparison Chart
Strip Cut
Paper Shredders
Feed
Opening
2240
8¾”
3
2260
2270
Shred Size
Cross Cut
Sheet
Capacity
Shred
Size
Sheet
Capacity
10-12
1
5-6
8¾”
3
10-12
1
5-6
8¾”
3
10-12
1
9½”
3
2404
9½”
3
2503
10¼”
3
19-21
2604
10¼”
3
12”
3
3105
12”
1
3804
16”
1
16”
1
16”
1
4605
18”
3
4107
16”
2360
3104
4002
4005
/16” (4mm)
/16” (4mm)
/16” (4mm)
/16” (4mm)
/16” (4mm)
/16” (4mm)
/16” (4mm)
/16” (4mm)
/4” (6mm)
/4” (6mm)
/4” (6mm)
/4” (6mm)
3
/8” x 1”
/8” x 1”
/8” x 1”
5-6
12-14
3
5
6-8
19-22
3
5
/32” x /8”
9-11
3
/16” x 1½”
12-14
27-30
3
20-22
27-30
3
22-25
50-52
3
30-32
20-22
3
24-26
32-35
3
24-26
50-52
3
/16” x 2 /8”
50-60
½” (12mm)
120-140
/32” x /8”
/16” x 1½”
/16” x 1½”
/16” x 1½”
/16” x 1½”
/16” x 1½”
/16” x 1½”
3
5
/32” x /8”
3
/8”
2503 SHREDDER
30-32
32-37
105-125
2604 DESTROYIT
Cardboard & Packaging
Shredders
Feed
Opening
Intimus Pacmate
15”
Intimus Pacmaster
16¾” x 13/16”
Pharmacy Shredder
9 1/16”
Packing
Mat Grid
1
/8 ” x 1¼”
-
Shred
Size
Cutting
Capacity
Cutting
Speed
-
1 sheet 275lb. doublewall corrugate
27.5 ft/min
5
/32” x 4 3/8” (2) 2-ply boxes 35.4 ft/min
5
/32” x 1 ½”
10 sheets
10 ft/min
2230 SHREDDER
www.southwestbindings.com
17
Of Canada Inc.
Print Finishing Equipment | Binding Supplies | Presentation & Branding Material
Adhesive Coating, Staplers & Mail Room Supplies
Rapid 106 Electric Stapler
Both flat or saddle applications.
20lb bond: 40 sheets flat, 20 sheets
saddle.
• Front loading of staples
• Automatic work trip or foot pedal
allows actuated stapling
• When sight shield is raised the unit
will not operate
• Adjustable stapling power and
adjustable stapling depth up to
100mm
Martin Yale 1632
Automatic Letter Opener
Martin Yale 62001
High Speed Letter Opener
• Automatically feeds and opens
a stack of envelopes up to 1-3/4”
high, making it a hands-free
operation
• The machine operates at a speed
of up to 7,000 envelopes per hour
• The blades are fully enclosed to
protect fingers
• The catch tray folds for easy
storage when not in use
• Automatically feed, open, and
collect a stack of envelopes
at a speed of up to 17,500
envelopes/hour
• Stacks of envelopes up to 6” tall
and a ¼” thick can be opened
• The scrap width is adjustable
with a control knob on the side
of the machine
• A removable catch tray is
included
Longreach Skrebba Stapler
Requires no electricity and can staple 50-1755
sheets. Great for saddle stitching, booklets and
nd
photo books. Southwest also sells a wide range
nge
of staples.
Maxit Adhesive System
The Maxit Adhesive System combines motorized roller
coaters with a unique hot melt adhesive which provides
the following benefits:
• Sticks permanently to just about any surface including
plastic, wood and metal
• Applies a very thin, smooth coating (absolutely no
bumps)
• Motorized roller coaters apply the coating at 4 seconds
per ft
• Adhesive coating will not lose it’s tack, so you can
mount at any time
• Non toxic and non hazardous
18
1-877-285-7044
Padding Presses & Paper Joggers
Challenge Mini Padder
A low cost table top padder that offers
a convenient, portable, and simple
padding solution for those with low
volume padding needs. Weighing only
15 lbs, the Mini-Padder can easily be
stored in a cabinet when not in use. It
will accommodate a stack of paper up
to 5 ¾" high and 17 ¾" wide.
Martin Yale J1811
Padding Press
The Martin Yale J1811 Padding Press
is ideal for padding carbon-less
forms, note pads and scratch pads.
Padding capacity is 5 ¾” high and
17 ¾” wide. It is made of sturdy steel
construction.
Martin Yale J1824
Padding Press
The Martin Yale J1824 padding press
stacks material up to 19 ¾” high. Great for
creating your own note/scratch pads.
Challenge Paddy Wagon
Padding Press
Challenge Handy Padder
Padding Press
The Challenge Paddy Wagon is a well
proven product that is the answer to
all your padding needs. Forget using
home made padding presses or
weights and boards!! With a capacity of
15,000 sheets of 20lb bond the Paddy
Wagon makes short work of padding.
Because the Paddy Wagon is on
wheels it allows you to make your pads
and then place to one side for drying.
The Challenge Handy Padder design
provides a portable and compact
tabletop padding device for the
right price. The convenient turn style
base of the Challenge Handy Padder
allows the operator to load, clamp
and pad from a single position.
The Challenge Handy Padder has
an extended sheet metal stabilizer
designed to eliminate tipping.
Challenge Handy Jog Jogger
The Handy Jog is a low-cost highly effective jogger
that fits into the most cost conscious budget. High
power and quiet operation efficiently jogs paper
up to 11” x 17”. Unlike other joggers that have
motors, bearings and rubber couplings, the Handy
Jog has no moving parts that will wear or require
maintenance.
• Front side loading
• Three trays to choose from – standard (8½” X 11”),
check tray (9 ½” X 12”) and large tray (11” x 17”)
• Up to 11” x 17” stock tray
• Powerful jogging action
• Quiet operation
• Maintenance free drive mechanism
www.southwestbindings.com
You may also like:
Lassco LJ-4
Paper Jogger
Martin Yale
400 Jogger
Lassco LJ-8
Paper Jogger
Martin Yale 4200
Paper Jogger
gg
19
Print Finishing Equipment | Binding Supplies | Presentation & Branding Material
With over 25 account managers in 7 of Canada’s key cities,
we guarantee that help is always available
Email: [email protected]
www.southwestbindings.com
ACROSS CANADA
Toll Free: 1-877-285-7044
Table of Contents
Adhesive Coating ...............................................p. 18
ALM Automatic System ...................................p. 5
Bookletmac ...........................................................p. 15
Business Card Slitters ........................................p. 10
Case Making Print Finishing ..........................p. 14
Cornering Machines..........................................p. 12
Creasers...................................................................p. 13
Folders .....................................................................p. 11
Foliant One-Sided Laminators......................p. 4
Heavy Duty Punches.........................................p. 8
Hot & Cold Laminators .....................................p. 2
Mail Room Supplies...........................................p. 18
Numbering Machines ......................................p. 12
Padding Presses ..................................................p. 19
Paper Cutters ........................................................p. 9
Paper Drills.............................................................p. 15
Paper Joggers.......................................................p. 19
Perforating Machines .......................................p. 12
Pouch Laminators ..............................................p. 7
Roll Laminators....................................................p. 3
Scoring ....................................................................p. 13
Shredders ...............................................................p. 17
Shrink Wrap Systems ........................................p. 16
Staplers....................................................................p. 18
Trimmers.................................................................p. 6
SOUTHWEST BINDINGS SYSTEMS LTD.
20 Dovedale Court,
Toronto, Ontario, Canada M1S 5A7
Tel: (416) 285-7044
Fax: (416) 285-6721
ATLANTIC REGION
1888 Brunswick St., Suite 800
Halifax, NS B3J 3J8
Tel: (902) 477-0382
Fax: (902) 477-0321
QUEBEC REGION
133 Boul. Brunswick
Point-Claire, QC H9R 5N2
Tel: (514) 694-7741
Fax: (514) 694-1370
OTTAWA REGION
1010 Polytek Street, Unit 31
Gloucester, ON K1J 9J1
Tel: (613) 744-7004
Fax: (613) 744-7790
BRITISH COLUMBIA REGION
#204-19232 Enterprise Way,
Surrey, B.C. V3S 6J9
Tel: (604) 574-9508
Fax: (604) 574-3407
PRAIRIE REGION
#29, 4216 - 54th Avenue S.E.
Calgary, AB T2C 2E3
Tel: (403) 717-1707
Fax: (403) 717-1716
MISSISSAUGA REGION
6155 Tomken Road, Unit 10
Mississauga, ON L5T 1X3
Tel: (905) 564-8990
Fax: (905) 564-8991
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
