Operating Instructions
For Muratec’s F-65 plain-paper fax machines
Muratec F-65 Quick Reference Guide
One-Touch Keys
Press
Program
“
“
To:
A
“
“
1
2
3
Enter
Enter
Enter
Enter a one-touch key
Erase a one-touch key
Print a list of one-touch keys
B
“
“
1
2
3
Enter
Enter
Enter
Enter a speed dial number
Erase a speed dial number
Print a list of speed dial numbers
Speed-Dial Numbers
Program
“
“
Programmable One-Touch Keys
Program
“
“
C
“
“
1
2
3
Enter
Enter
Enter
Enter a programmable key
Erase a programmable key
Print a list of programmable keys
D
“
“
1
2
3
Enter
Enter
Enter
Store a polling document
Erase a polling document
Print a polling document
E
“
“
“
1
2
3
4
Enter
Enter
Enter
Enter
Set up an F-Code box
Print a list of F-Code boxes
Print an F-Code document
Erase an F-Code box
F
“
1
2
Enter
Enter
Print a list of delayed commands
Print a document in memory
1
2
3
Enter
Enter
Enter
Turn the journal printout on or off
Print a journal of activity
Set up the TCR
Polling Documents
Program
“
“
F-Code Features
Program
“
“
“
Delayed Commands
Program
“
Activity Journal and Reports
Program
“
“
G
“
“
Cover Page
Program
“
“
H
“
“
1
2
3
Enter
Enter
Enter
Set up a cover page
Enter a cover page
Print a cover page
J
“
“
“
“
“
“
“
“
“
“
“
“
“
“
“
“
“
“
“
“
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Enter
Review / change your scan settings
Review / change your print settings
Review / change your copy settings
Set paper size
Set the dialing pause
Set # of rings before auto answer
Set the redial
Select ECM mode
Set a passcode
Create a closed network
Block junk fax
Set service mode
Select memory transmission
Set silent mode
Protect passcode
Set operation protection
Set PIN mode
Set DRD operation
Select primary tel/fax
Print Caller ID
Print your fax setting
K
“
1
2
Enter
Enter
Set security reception
Print memory reception document
Muratec America, Inc.
6400 International Parkway
Suite 1500
Plano, Texas 75093
http://www.muratec.com
User Settings
Program
“
“
“
“
“
“
“
“
“
“
“
“
“
“
“
“
“
“
“
“
Security Operations
Program
“
PC-to-Fax Operations
Program
L
1
Enter
Begin a PC-to-Fax scan
“
“
2
Enter
Set RS-232C
(PC-to-fax functions require optional serial cable and software. See inside for details.)
OMF65 Operating Instructions
MML item number: D82-90020-60
119820
Welcome …
As an ENERGY STAR® partner, Muratec America, Inc.,
has determined that this product meets
the ENERGY STAR guidelines for energy efficiency.
Copyright © 1998 by Muratec America, Inc.; all rights reserved.
Muratec, the Muratec logo and all Muratec fax product names contained herein are trademarks of Muratec America, Inc.
ENERGY STAR is a registered mark of the United States Environmental Protection Agency.
Welcome to your Muratec fax machine!
We’ve divided these operating instructions into three sections.
• “Getting started” (see page 1.1) covers only what you absolutely
have to know to use your machine immediately.
• “Beyond the basics” (see page 2.1) provides more details. When
you have time, look through it to learn more about your machine’s
many features, as well as fax in general.
Find your serial number and write it down
Before you go any further, please note that
your machine’s serial number is located on the
bar code label as shown on the drawing at
right. Please write this number in the box at
the bottom of the page before you set up your
IC and ID Labels
machine.
Bar cord label
• Finally, “Just in case … ” (see page 3.1) will help you decide what
to do if you ever have a problem with your machine. It also tells
you how to give it the kind of easy, sensible care that should help
keep troubles to a minimum.
The next two pages show the entire contents of these instructions.
Skim through them now if you’d like (they’ll prove more helpful as
time passes), or just go on past them to “Getting started” and, well,
get started!
And thanks for choosing Muratec.
Close up, the bar code label looks something
like this:
D1234567890123 *8CA
Important: This is not the exact number which appears on your machine’s label.
This only shows you how your label will look.
Please copy down your machine’s serial number below for future reference, and note
the machine’s model number.
My machine’s model number: F-65
My machine’s serial number: ________________________________________
What’s in these operating instructions
Note: Each section also contains its own (more abbreviated) table of contents, as well.
Getting started
What’s in this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1
A quick introduction to fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1
Take it out of the packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2
What are all the parts? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2
What do the keys do? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4
Setting up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6
Pick an installation spot before going ahead . . . . . . . . . . . . . . . . . . . . . . 1.6
Please heed these power-ful tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6
Loading paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6
Attach the paper-handling parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8
Plug in and power up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8
Setting the paper size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8
Adjust the monitor speaker’s volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.9
Installing / Changing the Ink Film . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.9
Attaching a second phone or an answering machine . . . . . . . . . . . . . . 1.11
Operating tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.11
EasyStart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12
Clearing settings before beginning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12
What do you want to do? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12
Using EasyStart to enter initial settings . . . . . . . . . . . . . . . . . . . . . . . . 1.12
Sending faxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.15
Some guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.15
How to insert a document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17
Using memory transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17
Sending . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17
Sending a fax with on-hook dialing or a handset . . . . . . . . . . . . . . . . . 1.18
If the call doesn’t go through: redialing . . . . . . . . . . . . . . . . . . . . . . . . . 1.19
Canceling sending a document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20
Receiving faxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21
So what’s the big deal, anyway?!? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21
Different ways to get the job done . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21
Tel Ready mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21
Fax Ready mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21
Tel/Fax Ready mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.22
Ans/Fax Ready mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.23
When the paper or ink film runs out . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.23
Making copies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.24
It’s a great phone, too . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.25
Beyond the basics
What’s in this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.1
Getting everything just the way you want it . . . . . . . . . . . . . . . . . . . . . . . . 2.2
Setting up for scans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.2
Setting the print parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3
Setting the copy parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4
Setting the number of rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4
Setting ECM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4
Setting silent mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.5
Setting the language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.6
Printing your settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.6
Printing a program list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.6
Autodialer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.7
Autodialer basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.7
Using one-touch numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.8
Using speed-dial numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.10
EasyDial directory dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.13
Delayed transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.14
Setting up a delayed transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.14
Reviewing or canceling delayed commands . . . . . . . . . . . . . . . . . . . . . . 2.15
Printing a delayed command list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.15
Printing a stored document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.15
Broadcasting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.16
The basics of broadcasting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.16
Delayed broadcasting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.16
Relay broadcast initiation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.17
Polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.19
Regular polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.19
Sequential polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.19
F-code polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.20
The other side of the coin; being polled . . . . . . . . . . . . . . . . . . . . . . . . . 2.20
Limiting polling access to your fax machine . . . . . . . . . . . . . . . . . . . . . 2.20
F-code communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21
F-code: an introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21
How sub-addressing works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21
Setting up the F-code boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21
Creating or modifying an F-code box . . . . . . . . . . . . . . . . . . . . . . . . . 2.21
Erasing an empty F-code box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.24
Printing a document received in an F-code box . . . . . . . . . . . . . . . . 2.25
F-code transmission and polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
F-code transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
F-code polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.25
2.25
2.26
Programmable one-touch keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.28
Using the power of programmable one-touch keys . . . . . . . . . . . . . . . . 2.28
Programming a delayed transmission . . . . . . . . . . . . . . . . . . . . . . . . . . 2.28
Programming a broadcast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.29
Programming a relay broadcast initiation . . . . . . . . . . . . . . . . . . . . . . . 2.30
Programming regular or sequential polling . . . . . . . . . . . . . . . . . . . . . . 2.31
Programming an F-code transmission . . . . . . . . . . . . . . . . . . . . . . . . . . 2.32
Programming an F-code polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.34
Erasing a programmable one-touch key . . . . . . . . . . . . . . . . . . . . . . . . . 2.36
Printing a list of your programmable one-touch keys . . . . . . . . . . . . . . 2.36
Programmable one-touch fax dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.36
Keeping things secure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.37
The key to it all: the passcode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.37
Operation protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.37
Security reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.38
Masking the PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.39
Setting for use of a closed network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.42
Setting Block Junk Fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.42
Special features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.44
Cover page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.44
Managing your fax with its journal and reports . . . . . . . . . . . . . . . . . . 2.45
OneLine + distinctive ring detection . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.46
Call request . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.47
Caller-ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.48
PC-FAX feature: fax/computer connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . 2.50
PC-FAX feature requirements for your computer . . . . . . . . . . . . . . . . . . 2.50
Making the PC-FAX connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.50
Creating the RS-232C settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.51
Scanning from your fax to your computer . . . . . . . . . . . . . . . . . . . . . . . . 2.51
Printing from your computer to your fax . . . . . . . . . . . . . . . . . . . . . . . . 2.52
Sending/receiving faxes with your computer . . . . . . . . . . . . . . . . . . . . . 2.52
RS-232C interface cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.52
Just in case …
What’s inside this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.1
We’re on-line to help you! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.1
Clearing paper jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2
If an original document jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2
If a printout jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2
Solving communications problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4
Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4
LCD error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4
Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.6
Caring for your fax machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.8
Cleaning tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.8
Keep the air vents clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.8
Corrective cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.9
Common questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.11
We’re online to help you! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.11
General questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.11
Sending faxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.11
Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.12
Receiving faxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.13
Polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.13
Working with your answering machine . . . . . . . . . . . . . . . . . . . . . . . . . 3.13
How your fax machine works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.13
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.15
Appendix and index
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Regulatory information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
United States of America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AI.1
AI.2
AI.2
AI.2
AI.3
AI.6
Getting started
A quick and friendly trip
through the basics
of your Muratec fax machine
Getting started
What’s inside this section
A quick introduction to fax in general . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1
A quick introduction to fax
Take it out of the packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2
What are all the parts? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2
What do the keys do? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4
Setting up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6
You are in control ! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.11
What’s a fax document?
Simply put, a fax document is anything a fax user wants to fax to someone else.
It can be just one page or as many pages as you need. It can be text, a drawing or
even a photograph.
What’s a fax number?
EasyStart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12
Because your fax operates on standard phone lines, a fax number is just a regular
phone number. And, because your fax is also a high-quality, full-featured telephone,
your fax number can even be your regular phone number.
Sending faxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.15
What are resolution and grayscale?
Receiving faxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21
Making copies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.24
It’s a great phone, too . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.25
Just as cars are measured by engine size, fax machines are measured by resolution
and grayscale.
Resolution refers to the sharpness of a fax transmission. It’s expressed in lines per
inch (lpi). There are three specific levels of resolution:
• Normal (203 horizontal × 98 vertical lpi)
• Fine (203 × 196 lpi)
• Superfine (203 × 392 lpi).
Grayscale levels — refers to the many shades of gray your fax machine sees on a
document it’s sending. It’s likely most of your fax documents will be dark text on
white paper. However, when you want to send photographs and other shaded items,
you can set your fax machine to transmit in 64-scale grayscale.
So why not set your fax machine to use superfine or grayscale for
all transmissions?
Setting your fax machine for superfine resolution and grayscale mode makes your
machine send more information, making transmissions last longer and driving up
your phone bills on long-distance calls. You’ll find that we’ve made it easy for you to
set your fax machine for the most efficient and truest transmission for the types of
documents you send!
1.1
Getting started
Take it out of the packaging
What are all the parts?
The drawing below shows what should be included in the packaging:
Document hopper
1
Ink film cartridge
2
*
3
4
12
5
11
Handset
Paper tary
Paper cassette
Document separator
AC power cord
*
Ferrite core
6
**
7
8
Operating instructions
Telephone line cord
* These parts are installed in the fax machine.
** This ferrite core will be used with an RS-232C cable if you decide to use the PCFAX feature (see page 2.50). The RS-232C cable is not included with this fax
machine.
Your fax machine comes with a pre-installed starter roll of ink film, which your
machine uses to print received faxes and copies. This starter roll is only 1/10 the size
of a normal roll. Please obtain a full-size replacement roll from your authorized
Muratec dealer.
For the best results and longest life from your fax machine, please use only Muratecbrand Ink Film, which is designed specifically for your model.
Save the packing materials for reshipment.
1.2
10
9
1
2
3
Document hopper — Supports the original document for straighter feeding
into the automatic document feeder (ADF).
4
5
Control panel — Use these keys to operate your machine. (See page 1.4 for
more details.)
Automatic document feeder (ADF) — Place your original document for faxing or copying in this slot. It holds up to 30 letter-sized pages.
Liquid crystal display (LCD) — This display (1-line × 16-character) shows
the machine’s status. It also shows you the fax numbers any any other information you enter into the machine.
Original document exit — Where the original document (what you put into
the ADF for faxing or copying) comes out.
Getting started
6
7
8
9
10
Document separator — Helps your printed documents stack easily.
11
12
Handset — A regular phone handset.
14
Paper tray — Supports printed documents discharged from the printed document exit. You can also slide it out to allow for larger documents.
13
Printed document exit — Where the printout (fax or copy) emerges.
Paper cassette — Holds the recording paper. Stores up to 300-sheets, either
letter- or legal-sized.
Control panel cover — When opened, it provides access to original document. (To prevent damage to your machine, open this panel to remove any
documents that have been partially fed into the machine.)
Document guides — Adjust these to fit the width of the original document
so it will feed properly into the ADF.
15
19
16
17
13
14
15
16
17
18
19
18
Top cover release — Push this to open the top cover (see next item).
Top cover — Opens for easy access to the inside of the machine for replacing
ink film or fixing occasional paper jams.
AC
power jack — Where you plug in the AC power cord.
jack — Where you plug in the telephone line cord. (The other end of the
cord plugs into the telephone jack in the wall.)
LINE
EXT. TEL
jack — If you connect a second telephone or answering machine to
your machine, this is where you plug in the cord.
jack — Where you plug in your fax machine’s handset. One end of
the curled handset cord goes into the HANDSET jack on your fax machine. The
other end of the curled cord plugs into the handset itself.
HANDSET
RS-232C
jack — Use this for the PC-FAX feature. If you want to use the PC-FAX
feature, you will need the RS-232C cable and software. (See page 2.50 for more
information.)
1.3
Getting started
What do the keys do?
Important: Some of the functions we’ll mention, here, are covered in the “Beyond
the basics” section, which begins on page 2.1.
1
Liquid crystal display (LCD) — The display (1-line × 16-character) which
shows the machine’s status and lets you see what you’re entering during various operations. (If the LCD is blank, the machine is off.)
2
COM-OPTIONS
3
1.4
— Use this key to choose from among six fax options:
Broadcast, delayed transmission, relay broadcast initiation, polling, F-code
transmission or F-code polling.
and — Use these keys to scroll through features and command options
as displayed on the LCD.
4
5
6
— Press this key and enter a function number to access your
machine’s programs.
PROGRAM
light — If glowing, indicates your fax machine is receiving
an incoming fax document into the machine’s electronic memory.
MEMORY RECEIVE
ENTER — ENTER is a “Go!” key. When pressed, it confirms user settings,
begins operations and moves through command levels.
RESOLUTION — When a document is in the document feeder, press this key to
toggle among the three resolution modes and the halftone (grayscale) mode.
When neither the S-FINE, FINE nor HALFTONE LED (light-emitting diode) is
glowing, your machine is set for normal resolution.
Getting started
7
CANCEL
— Press this key to delete characters on the LCD and cancel commands you have entered into the machine.
15
FLASH
— When a document is in the document feeder, press this key to
toggle among normal, dark or light contrast settings. When neither the DARK
nor LIGHT LED (light-emitting diode) is glowing, your machine is set for normal contrast.
16
HOLD
— When a document is in the document feeder, press this key to make
copies of a document.
17
MONITOR / CALL
18
RECEIVE — Press this key repeatedly to select the receive mode for your fax
machine. A glowing LED indicates the current receive mode. When neither the
TEL, TEL/FAX nor ANS/FAX LED is glowing, the machine is set for the “Fax
ready” mode.
19
SPEED DIAL / TEL INDEX
20
Status indication lights
CONTRAST
8
COPY
FILM — When the machine is in standby mode and there is no document in
the document feeder, press this key to indicate the amount of ink film
remaining in the machine.
Note: If using the pre-installed starter roll of ink film, the counter will not
accurately show the amount of ink film left in the roll.
9
10
E:
:F
= The ink film is full.
E:
:F
= Your machine is almost out of ink film.
— Press this key to review pending fax commands or view
a brief description of delayed commands.
REVIEW COMMANDS
START
— Press this key to begin a manual fax transmission or reception.
— If the REPORT light is glowing, your fax machine will print a
transmit confirmation report (TCR). You can override the default report setting one transmission at a time by pressing the START key. After completing
the communication, your machine will return to your default TCR print setting. (See page 2.46 for more information.)
REPORT
11
12
STOP
13
Numeric keypad — Just like the numeric keys on a regular telephone. In
addition to using these keys to dial phone and fax numbers, you can also use
these keys to enter settings for your fax machine.
14
REDIAL / PAUSE
— An all-purpose “Whoa!” key. Stops the current operation and ejects a
document from the document feeder.
— Press this key to quickly disconnect from one call and go right to the
next one without having to hang up the handset. Also, press this key to
exchange from PABX to PSTN.
— Press this key to either place a call on hold or take it off hold.
DIALING OPTIONS — Press this to insert special symbols into telephone numbers (see page 2.7).
— During on-hook dialing, pressing this key turns the monitor speaker off or on. When you’re sending a fax, this key activates the call
request feature.
— Press this key to begin a speed-dialing operation.
This key can also be used to display one-touch and speed-dial entries sorted
alphanumerically, as in a telephone directory.
light — If glowing, advises you the fax machine is
communicating with another one.
COMMUNICATION
light — If glowing, indicates your fax machine is ready to communicate using the PC-FAX feature (see page 2.50).
PC
light — If glowing, indicates a problem has occurred during
fax communication. It’s also accompanied by several beeps immediately after the problem occurs. The light stays on until the machine
prints a Check Message report.
ALARM
One-touch keys — The keys labeled A – O offer one-touch dialing convenience. You also can use the keys labeled P1–P5 for programmable functions:
With the se five program keys, you can teach your machine an advanced
multi-step function just once, then recall the function at any time by pressing
one of these keys.
— Redials the last number you dialed. In certain operations,
it also produces a special pause character which can be useful when dialing
long-distance numbers.
1.5
Getting started
Setting up
Pick an installation spot first
Where should you install your fax machine? The location should be:
• Clean — Dust buildup can damage your machine.
• In the open — Allow at least 12 inches of clearance around your machine.
Never cover the machine. Its vents must be able to “breathe.”
• Away from direct sunlight — This helps avoid overheating.
• Dry — Avoid any location where splatters or sprays of liquid could reach your
fax machine.
• Level, and vibration-free.
• Near a phone jack — Your fax machine uses a standard telephone jack, also
known as an RJ-11.
• Near an AC power outlet — Allow plenty of slack for your fax machine’s power
cord. It should never be stretch to its 5-foot limit.
Note: To turn off the power to your fax machine,you have to unplug the power
cord from the wall socket or remove the power cord from the rear of the
machine. For convenience, install the fax machine so that there is easy
access to the power outlet.
Voltage requirements:
Power consumption:
•
•
•
•
1.6
Use a standard three-pronged 120 VAC outlet.
Make sure the outlet isn’t controlled by a wall
switch. If it is, you will risk inadvertent shutoffs of your
machine, causing you to lose fax messages.
Don’t use an outlet which also is supplying power
to a large appliance, such a refrigerator or air conditioner. Such high-consumption appliances can cause
(temporary drops in the power available for other equipment which could damage your fax machine.
Use an electrical surge suppressor, which guards
both telephone and electrical lines. This device helps to
shield your fax machine from damaging high-voltage
electrical surges.
Copying
35.2W
Maximum
136.7W
Loading paper
You can use either letter-sized (8.5″ × 11″) or legal-sized (8.5″ × 14″) paper in your
fax machine. But do not mix the paper sizes together in the same tray.
The paper cassette holds up to 300 sheets of letter-sized paper.
1
Power tips
120 VAC ± 10%, 50–60% Hz.
Standby Transmission Reception
7.1W
18.6W
29.5W
Pull forward on the paper cassette to slide it out.
Getting started
2
3
4
5
Cassette cover
Take off the cover.
Push the paper plate
down until it locks into
position.
6
Insert the paper guide into the
holes corresponding to the paper
size you are installing.
7
Before you load paper into the
paper cassette, tap the ends of
the stack to make sure the edges
and sides of the stack are even.
8
Insert up to 300 sheets of plain
paper face down into the paper
cassette, placing the edges of the
top sheet under the metal tabs
on the right and left side of the
paper cassette. Do not stack the
paper above the paper level indicator located on the inside of the
paper cassette.
9
Put the cover back on the paper
cassette.
Paper plate
Adjust the paper setting to the
letter or legal position depending upon the size you are using.
When you use legal-sized paper,
pull the front part of the cassette toward you.
Turn the paper cassette upside
down. Remove the paper guide.
10
Paper
limit
Slide the paper cassette closed.
You will feel a click when it’s properly in place.
1.7
Getting started
Attaching the paper-handling parts
1
Attach the document hopper by
inserting its two pegs at a
slightly upward angle into the
appropriate holes.
2
Attach the document separator
into the appropriate holes, as
shown.
5
Plug the non-pronged end of the AC power cord into the AC power cord jack on
the rear side of the machine.
6
Plug the pronged end of the AC power cord into a 120 VAC electrical outlet (use
a surge suppressor, as mentioned on page 1.6).
Note: This will turn on your fax machine.
Plug in and power up
When you connect the power, the LCD will show:
01/01/1999
Handset cord
1
2
3
4
Plug the other end of the handset cord into the handset.
Place the telephone handset onto the handset cradle.
Plug one end of the telephone line cord into the LINE jack on the left side of
your machine. Plug the other end of the telephone line cord into a standard
telephone wall jack, just as you would plug in a phone.
(Day/Month/Year Time)
When the date and time are displayed on the LCD, the fax machine is in the
normal standby mode and ready for normal operation. If the machine beeps,
the ALARM light glows and the LCD shows an error message, this means there
is a problem. If this happens, consult “Just in case...,” beginning on page 3.1.
Telephone line cord
Plug one end of the curled handset cord into the HANDSET jack on the left side
of your machine.
0:00
Setting the paper size
Your machine’s paper cassette can hold either letter- or legal-sized paper. All you
have to do is tell the machine which size the cassette is using.
Important: If you use a different size from the one you set here, the machine will
not print. Change this setting whenever you load a different size.
1
Press PROGRAM, J, 0, 4, ENTER. The LCD shows the current paper size setting:
PaperSize:Letter
If the setting you see is acceptable, skip to step 3.
If not, go on to step 2.
1.8
Getting started
2
To change the setting, press or once or twice until the paper size you are
loading appears. In this example, we chose legal-sized paper.
PaperSize:Legal
3
Check Ink Film
Your fax machine uses Muratec’s Film Imaging system to provide high-quality fax
printouts and copies on plain paper. Film Imaging uses only clean, easy-to-handle
and easy-to-load ink film.
To adjust the volume of the monitor speaker:
Note: You cannot set the volume of the monitor while the fax machine is communicating.
Press MONITOR / CALL on the control panel. You now should hear a dial tone,
and the display will show:
**
Tel Mode
**
Important: If you don’t hear a dial tone, make sure your fax machine is
plugged into a working phone line.
2
3
4
Note: Your fax machine can’t print without ink film. If it runs out of ink film, the
machine beeps and displays:
Press ENTER to save the setting.
Adjust the monitor speaker’s volume
1
Installing / Changing the Ink Film
Note: The pre-installed starter roll of ink film is only 1/10 the size of a normal roll.
Please obtain a full-size replacement roll from your authorized Muratec
dealer, or call 1-800-543-4636 toll-free. For the best results and longest life
from your fax machine, please use only Muratec-brand ink film, which is
designed specifically for your fax model.
To change the ink film:
1
2
Remove the document hopper, if necessary.
3
Grab the handles on each side of
the ink film cartridge, and lift the
cartridge straight up out of the
machine.
Press the top cover release to open the top cover of the fax machine.
If the volume you hear is satisfactory, skip to step 4.
If not, go on to step 3.
Adjust the volume as you wish:
To turn the volume up, press . To turn the volume down, press
The LCD indicates the volume. The possible settings are:
Volume:
= Loudest setting.
Volume:
= Medium setting.
Volume:
= Lowest setting.
Press MONITOR/CALL again to hang up.
.
1.9
Getting started
4
Turn the ink film cartridge over and rest it upside down on its handles.
5
Grasp the cartridge frame firmly
and slide out the ink film rolls from
the cartridge.
9
10
6
Remove the gears from the ends
of the used film rolls.
Note: Please dispose of the
used rolls properly.
Snap the new rolls into the ink film
cartridge. The ink film cartridge
includes illustrations to help you
correctly install the rolls.
Turn the rolls as shown until only
the black ink film — and none of
the blue leader film — is showing.
You cannot print with the blue
leader film.
Blue leader film
1.10
7
Remove the new ink film roll
from its packing.
8
Insert the gears into the ends of
the new ink film rolls, making
sure to align the tab on the gears
with the slot on the ends of ink
film rolls.
11
Now you are ready to put the cartridge back in the machine. Turn
the cartridge right-side up again
and position the cartridge so that
its arrow mark is over the
machine’s arrow mark.
Note: The supply roll should be
in the front of the machine.
Gently put the cartridge back into
the machine. If you position it correctly, it will “drop” in smoothly.
Note: If the cartridge isn’t
inserted properly, your fax
machine won’t work .
12
Close the top cover of your fax
machine. You will feel a click when
it’s closed.
Note: Your fax machine won’t
work if the top cover isn’t
closed.
13
Re-attach the document hopper, if you removed it in step 1.
Getting started
When you install a new ink film
Important: Use this setting only when you are installing a new ink film.
Your fax machine indicates the ink film remaining by pressing FILM (see page 1.5)
to let you know when it needs to be replaced. So, whenever you install a new ink
film, you must “notify” the machine by resetting the film counter.
Installation complete!
Now, see how our EasyStart feature will have
you up and running within just minutes.
To reset the film counter:
Make sure there is no document in the feeder, and then press FILM, CANCEL, CANCEL
to reset the film counter.
Attaching a second phone or an answering machine
It’s easy to attach a second phone or answering machine to your fax machine.
If you do this, only your fax machine connects to the phone outlet in the wall. The
other device receives phone signals through your fax machine.
To attach a second phone or answering machine:
1
If your second phone or answering machine is already plugged into a phone
jack in the wall, disconnect it from that jack. Hold onto the phone plug; you
will need it in step 2.
2
Remove the modular cap on your fax machine. Then plug the line you disconnected from the wall jack in step 1 into the EXT. TEL jack on the left side of
your fax machine.
Operating Tips
Before using your fax machine, make sure you understand its basic operation.
To press: 0 (zero), 1, 2, 3, 4, 5, 6, 7, 8, 9, # or *
Use:
The numeric keypad.
Tip:
At no time within this manual will we refer to the letters printed below
the numeric keys, such as the letters abc found on the 2 key. These letters
are there only for your convenience when using your fax machine as a telephone.
To press: A, B, C, D or any other letter key
Use:
The one-touch key by that name.
Tip:
Don’t confuse the zero (0) with a letter O.
Here’s an example. If we say “press PROGRAM, J, ENTER, 0, 8, ENTER” …
… you’d press PROGRAM
… then J
… then ENTER
… then 0 (the numeric key zero)
… then 8
… and ENTER
Important: Do not enter commas or periods. Those characters appear in the
instructions for separation purposes only, and should not be entered
from your control panel.
For information on how to use either an answering machine or second telephone
with your fax machine, see “Receiving faxes,” beginning on page 1.21.
There is a function which requires commas, but we’ll explain later
how to enter them into your fax machine.
1.11
Getting started
EasyStart
EasyStart is already installed on your fax machine. Use it to guide you in entering
the bare-bones settings required for normal operation. If necessary, you can always
make changes to these settings later.
Important: Before beginning EasyStart, be sure you have correctly installed your
machine and loaded paper into it (see “Setting up,” beginning on page
1.6).
Using EasyStart to enter initial settings
Important: If you press STOP during EasyStart, your fax machine will return to
standby mode (its normal condition) but will retain the settings you
saved by pressing ENTER as described in these instructions.
1
Press PROGRAM, I.
User Install
Clearing settings before beginning
Before using EasyStart, clear your machine’s built-in user data memory, which
stores settings. This ensures the memory will hold only your settings.
2
Important: After you use EasyStart, please do not clear the memory again unless
an authorized technician asks you to do so.
To clear the machine’s memory:
1
’99 01/01 00:00
Note: Throughout these instructions, we will show the cursor as an underline. However, it really appears on the LCD as a blinking box over the
character.
Press PROGRAM, *, 2, ENTER. The LCD now asks whether you are sure about
clearing the memory:
Check Prog/Enter
3
Note: If you don’t want to proceed, just press PROGRAM or STOP.
2
Press ENTER.
The LCD displays the current setting of the fax’s built-in calendar/clock, with a
blinking cursor appearing over the first digit.
If you are sure, press ENTER to clear the memory.
Use the numeric keypad to enter the correct date and time, using a YYMMDD
format for the date and 24-hour (“military”) format for the time.
For example, to set 8:30 PM on September 11, 1999, press 9 9 0 9 1 1 2 0 3 0,
which results in the following:
’99 09/11 20:30
(Year, Day/Month, Time)
What do you want to do?
Note: Your fax machine automatically inserts the spaces and date-slash. All
you have to do is enter the digits.
Please determine the following before you proceed:
To change only one digit, press to move the cursor to the left, or to move
it to the right, to the digit you want to change. Then enter the correct digit.
1
2
The type of dialing your telephone system requires — Select either tone or
pulse (rotary) dialing.
The name and fax number you want to appear on your faxes —
Every fax page you send will arrive at the receiving machine with a single
line of text at the very top of the page, and will include a name and a fax
number. This name cannot be longer than 22 characters.
Note: The fax industry term for this text is Transmit Terminal Identifier
(TTI).
4
5
Press ENTER to save the clock setting and continue EasyStart.
The LCD now asks you to enter your fax number as you want it to appear on
other fax machines’ displays or printouts. The fax industry term for this number is Subscriber ID.
The LCD shows briefly:
Your Fax Number
then it will show:
1.12
Getting started
For example, pressing 8 several times would show these displays:
_
Use the numeric keypad to enter your fax number. To put in a dash for easier
reading, press DIALING OPTIONS once. The number may contain up to 20 characters (numbers and dashes).
972-555-5525_
Note: If you make a mistake, press CANCEL to erase to the left. Or, if you
want to change just one character in the number, press to move the
cursor to the left, or to move it to the right, to the character you
want to change. Press CANCEL to erase it. Then re-enter it until the
fax number is just as you want it.
6
7
_GHIJKL
>
_MNOPQR
>
_STUVWX
>
_YZ.
>
_abcdef
>
Press ENTER to save the number.
The LCD now asks you to enter the name you want to appear at the top of
faxes you send. The fax industry term for this name is TTI.
The LCD shows briefly:
Your Name
When you see the character you want:
• Press either 4 or 6 to move the cursor to the character you want.
then it will show the character set available, such as:
_ABCDEF
• Then press 5 to enter that character and move on to the next entry.
Note: If you make a mistake, just press CANCEL to erase to the left.
Then continue to enter the character(s) you want.
Note: As you enter characters, the LCD will scroll to the left so you can view
entries longer than five characters — for example, Sarah’s fax:
>
Use the numeric keypad to enter a name up to 22 characters in length.
If you need to insert a space in the name, one can be found before and after
each set of characters.
To find a different set of characters, press 2 or 8 repeatedly to scroll through
character sets until you see the one you want.
8
9
ghijkl
> Sarah
"#$:'
> arah'
stuvwx
> rah's
_stuvwx
> ah's
ABCDEF
> h's F
abcdef
stuvwx
> s Fax
> 's Fa
When the name is as you want it, press ENTER to save it and continue.
The LCD now indicates the type of dialing, tone or pulse, that is set for your
fax machine:
Phone Type:Tone
If the setting you see is acceptable, skip to step 11.
If not, go on to step 10.
1.13
Getting started
10
To change the setting, press or once or twice until the mode you want
appears. Here, we changed the setting to Pulse mode:
Phone Type:Pulse
11
Press ENTER to save the setting.
** Complete **
All done!
1.14
Getting started
Sending faxes
Some guidelines
How big — and small — your pages can be
You can fax a piece of paper as small as a notepad sheet or nearly 3 feet long!
To be precise, the acceptable dimensions (width × length) are:
SINGLE-SHEET TRANSMISSION
MULTIPLE-SHEET TRANSMISSION
Things not to put in your fax
To avoid paper jams and damage to your machine, do not insert:
• Folded, curled, torn, wrinkled or very thin pages
• Documents with staples, glue, tape, paper clips or still-wet correction fluid
• “Sticky notes” (or documents with “sticky notes” attached)
• Cardboard, newspaper or fabric
• Pages with duplicating carbon on either side
• Credit cards or similar small, thick items
Some thoughts on resolution, grayscale and contrast
Reviewing resolution and grayscale
Document thickness: 0.06 to 0.13 mm
Note: The maximum width of the scanned area is 8.2 inches. This means there
will be a 0.16-inch margin on each side of the page that your fax machine
will not scan.
• Normal resolution is suitable for most typed documents and simple drawings.
• Fine resolution is ideal for maps, floorplans or handwritten documents.
• Superfine resolution reproduces the detail of extremely complicated drawings
or line art.
• Grayscale mode (“HALFTONE” on the control panel) captures shades in photos and
drawings.
Note: If you send a fax in superfine, there are some machines that receive it only
in fine mode. However, you can send a fax in grayscale mode to virtually
any fax machine currently in use.
ENTER
To change the resolution setting, press RESOLUTION repeatedly. As noted
above, if neither the FINE, S-FINE nor HALFTONE LED (light-emitting
diode) is glowing, your fax is set for normal resolution. Otherwise, a
glowing LED indicates the fax is using that setting. For example, in the
drawing (left), the machine is set for fine resolution.
1.15
Getting started
Contrast
Setting the contrast allows you to compensate for any excessive lightness or darkness in the documents you send or copy.
You have three choices:
• Normal — Suited to most documents.
• Light — Lightens up overly dark, “muddy” original documents.
• Dark — Darkens weak, “washed-out” images.
2
Time (05-10): 05
If the setting you see is acceptable, skip to step 4.
If not, go on to step 3.
3
Note: To avoid confusion, remember that the LIGHT contrast setting lightens and
DARK contrast setting darkens.
To change the resolution, press CONTRAST repeatedly. A glowing LED
(light-emitting diode) indicates the fax is using that setting. For example, in the drawing at left, the machine is set for dark contrast. If neither
the LIGHT nor DARK LED is glowing, your fax is set for normal contrast.
CANCEL
Press ENTER.
Use the numeric keypad to enter the length you want for the dialing pause.
You can choose between five and 10 seconds.
Here, we chose nine seconds.
Time (05-10): 09
Note: The length setting requires two digits. Always enter a leading zero for
lengths other than 10 seconds.
4
Press ENTER to save the setting.
Potential problems with call-waiting and voice mail
Entering a pause character when dialing
Some long-distance systems require dialing pauses, and pauses may also be
required when dialing through special telephone exchanges.
To insert a pause character, just press REDIAL/PAUSE after you have dialed at least
one other character. The pause character ( -/ )will appear on the display.
Each pause entered lasts for a factory-set five seconds, but can be changed to last
for as long as 10 seconds. (See “Changing the pause length,” to change this setting.)
For example, assuming the pause is at the factory setting, pressing 9,
REDIAL/PAUSE, 19725552009 dials 9 [5-second pause] 1 9 7 2 5 5 5 2 0 0 9.
Important: Each pause uses two of the characters you are allowed in a number.
Changing the pause length
The pause is set by the factory to last five seconds, but you can set it to last as long
as ten seconds if necessary. If you find the five-second pause satisfactory with your
phone system, do not make this change. But if want to change it:
1
Press PROGRAM, J, 0, 5.
Set DialingPause
1.16
Telephone call-waiting signals can stop fax transmission and reception. And any
service — such as voice mail — which may intercept your calls can keep your fax
machine from getting fax calls.
If you must use only one phone line for both your phone and fax, consult your telephone company for information on how you can temporarily disable call-waiting or
voice mail while using the fax machine.
Getting started
How to insert a document
1
Adjust the document guides by sliding them to the left or right to fit the document(s) you are faxing. Your fax machine’s automatic document feeder (ADF)
will hold up to 30 pages.
2
If you are sending a multi-page document,
“fan” the pages slightly. The first sheet
should extend just slightly from the others.
3
Insert the document face down. The fax
machine will “grab” the first page of the document and position it for faxing. If needed,
readjust the document guides for the best
fit.
Note: Although it’s probably best to transmit from memory, please note there are
some documents that use up memory more quickly than others. They include
documents with many pages and documents with a lot of dark areas, since
darker pages create more data for your fax machine to “remember” and
send. When the machine’s memory supply is full, it can transmit only
through the document feeder.
To make memory transmission the default:
1
Set Memory Tx
2
On
If the setting you see is acceptable, skip to step 4.
If not, go on to step 3.
100%
Note: If the fax is set for non-memory transmission, the amount of memory
available is not shown:
Press ENTER.
Memory Tx :
The LCD now shows the amount of memory available:
Doc. Ready
Press PROGRAM, J, 1, 3.
3
To change the setting, press or once or twice until the mode you want
appears. In this example, we chose Off.
Memory Tx :
Off
Doc. Ready
4
Using memory transmission
Your fax machine has a great memory! Take advantage of it, and you could:
Save Time. By using your fax machine’s memory, you won’t have to wait for your
machine while it completes the transmission. Simply scan your document into your
fax machine’s memory, and you can walk away with your original in hand.
Save Money. Here’s a real money-saver on long-distance fax calls: if you’re transmitting to another memory-equipped Muratec fax machine, your machine will send
the document directly into the other machine’s memory and hang up! (The receiving
machine then prints out your message from its memory after the call has ended.)
This cuts your actual on-line time to a minimum.
Save Even More Money. Set up a delayed command (see pages 2.14–2.15) to send
your document to that other Muratec fax machine after hours, and you can save
more money, because the line charges will be cheaper.
You can set your fax to always transmit from memory as a default.
Press ENTER to save the setting.
Sending
Here’s how to fax a document:
1
Insert the document.
When a document is in the feeder, the LCD will show:
Doc. Ready
100%
Note: If the fax is set for non-memory transmission, the amount of available
memory is not shown.
2
Adjust resolution and contrast if necessary. If these are OK, skip to step 3.
Otherwise, press RESOLUTION to change the resolution and/or press CONTRAST
to change the contrast.
1.17
Getting started
3
4
5
Dial the fax number.
• Enter the fax number by using the numeric keypad and then press START.
… or …
• Use one-touch dialing (see page 2.8).
… or …
• Use speed-dial dialing (see page 2.10).
… or …
• Use the EasyDail directory (see page 2.13).
Now, everything is up to the machines — yours and the one you are dialing.
• If you set the fax to transmit from memory, your machine will first scan
the document into memory, then dial the other fax. When it makes contact, your machine transmits the stored document from memory.
• If the fax is set for non-memory transmission, your machine simply dials
the other fax. When it makes contact, your machine feeds the document
through, scanning and transmitting it as it goes.
Sending a fax with a handset or on-hook dialing
(Manual sending)
You also can fax a document by dialing using either the handset or the monitor
speaker. This is called “on-hook” dialing.
Here’s how:
1
2
Insert the document.
3
Obtain a dial tone. You can do this by either:
• Lifting a handset.
… or …
• Activating the monitor speaker (by pressing MONITOR/CALL)
Adjust resolution and contrast if necessary. If these are OK, skip to step 3.
If not, press RESOLUTION to change the resolution and/or press CONTRAST to
change the contrast.
In either case, the LCD shows:
Note: The more “stuff”, or black coverage, your machine “sees” on a page,
the more slowly the page scans it.Even if the page is relatively clean,
sending it in grayscale mode or certain resolution settings makes your
machine “see” more “stuff”.
The same is true if you set the contrast to Dark.
Note: What if the call fails? See “If the call doesn’t go through: redialing,”
next page.
4
Important: If you want to cancel a transmission in progress, you will need
to use the Review Commands function.
See “Canceling sending a document,” page 1.20.
5
**
Tel Mode
**
Enter the fax number by using the numeric keypad.
919725552009_
Enter access codes along with the number, just as for a regular phone call.
At the end of the operation, your fax machine beeps and displays:
When you hear fax tones from the remote unit, press START.
The LCD will show:
Transmit
** Complete **
Note: If a person answers the phone, use the handset to tell that person you
are sending a fax. When his/her machine sends you fax tones, then
press START.
6
If you are using the handset, hang up after pressing START.
7
At the end of the operation, your fax machine beeps and displays:
** Complete **
1.18
Getting started
If the call doesn’t go through: redialing
Automatic redialing
If you dialed without using either the monitor speaker or the handset and the fax
call fails, your machine automatically redials the call.
While your machine is waiting to redial, the LCD shows:
Auto Redial
While in this Auto Redial mode, the machine can receive faxes and make as many as 30
fax transmissions.
Your fax will continue to redial the number every few minutes until one of these happens first:
• It reaches the remote fax machine.
• It has automatically redialed the number for the last try (again, see “Making
redial settings,” next column).
Notes: If the last try fails, your machine may print (and/or display) error messages.
For more information, see pages 3.4–3.7.
Note: If you used either the speaker or a handset, redial manually (see below).
To redial a voice call manually by using the handset:
1
Lift the handset to get a dial tone. Make sure there is not document in the
document feeder.
2
Press REDIAL/PAUSE. When the other person answers, speak to him/her on the
handset.
Setting the redial
You can determine how many times the fax redials a number and how long it waits
during redials (this is called the redial interval). To set the redial:
1
Set # Of Redial
then it shows:
# (02-15):
2
You can always redial fax or voice calls manually. And if you dialed using the monitor speaker or the handset, you must redial manually.
1
2
Make sure the document is in the feeder and that the resolution and contrast
are set as you want it.
3
4
Press ENTER to save the setting.
The LCD now shows briefly:
then it shows:
Interval :
Make sure the document is in the feeder and that the resolution and contrast
are set as you want it.
3
The redial interval is shown in minutes. If the redial interval you see is acceptable, skip to step 6.
If not, go on to step 5.
Press either MONITOR/CALL or lift the handset to get a dial tone.
When you hear fax tones from the remote unit, press START.
Note: If a person answers the phone, use the handset to tell that person you
are sending a fax. When his/her machine sends you fax tones, then
press START.
03
Redial Interval
Press REDIAL/PAUSE, START.
Press REDIAL/PAUSE.
To change the setting, use the numeric keypad to enter the desired number of
redialing attempts, as few as two or as many as 15. In this example, we have
entered 3. Use a leading zero for numbers less than 10.
# (02-15):
To redial a fax call manually by using the monitor speaker or the handset:
1
2
3
4
02
If the number of redialing attempts you see is acceptable, skip to step 3.
If not, go on to step 2.
Redialing manually
To redial a fax call manually without using the monitor speaker or the handset:
Press PROGRAM, J, 0, 7, ENTER. The LCD shows briefly:
5
To change the setting, use the numeric keypad to enter the desired length.
You may enter 3, 4 or 5. In this example, we chose 4.
Interval :
6
4
Press ENTER to save the setting.
1.19
Getting started
Canceling a document while sending it
To cancel a transmission in progress:
1
Press STOP.
• If you are using a non-memory transmission, press STOP two or three times
until the machine returns to standby mode. The document will finish feeding through the ADF.
• If you are using a memory transmission, the LCD shows a command number in progress (see “An introduction to Review Commands,” below).
For example, the LCD shows:
C01:5552009
2
Press CANCEL twice to cancel the transmission.
Note: If either broadcasting or sequential polling in progress, you cannot cancel it
by pressing STOP. To cancel a broadcasting or sequential polling in progress,
press REVIEW COMMAND first and then press CANCEL twice.
An introduction to Review Commands
To cancel either an in-progress transmission or an automatic redial from memory,
use the Review Commands function.
A short explanation:
• Because your fax machine can store multiple transmission commands in memory,
it keeps track of each command by assigning it a command number — such as
“C01.”
• Delayed commands, redial attempts and current fax transmissions are all stored
in your fax machine’s memory and given a command number.
The Review Commands function gives you the power not only to check on each command pending in your machine’s memory but also to delete a command if you decide
not to send the document.
1
Press REVIEW COMMANDS.
The LCD shows the first command, indicated by its command number and the
phone number it will dial.
If a command is in progress, that will be the first command the LCD shows:
C01:5552009
2
3
1.20
If this is the command you want to cancel, skip to step 4.
If not, go on to step 3.
Press to continue to the next command in the command queue, then go
back to step 2.
4
Press CANCEL. The LCD shows:
Prog/Cancel
5
6
If you want to cancel this command, press CANCEL again.
The LCD now shows the next command.
If you want to cancel it go back to step 4.
If you don’t want to cancel this command but do want to review other commands in the queue, press or and go back to step 2.
If you don’t want to review any more commands, press STOP to return the
machine to standby mode.
This function gives you enormous control over your machine’s most powerful features.
For more information on the Review Commands function, please see page 2.15.
Getting started
Receiving faxes
Different ways to get the job done
Tel Ready mode
Reception modes
Use it if:
Your fax machine has four different reception modes — Tel Ready, Fax Ready,
Tel/Fax Ready and Ans/Fax Ready — each of which we’ll explain in a moment.
We’ll also give you an idea of which one you should use, depending upon your setup.
Answering calls manually — for all reception modes
In any reception mode, you always can answer calls manually. Just pick your
machine’s handset.
• You intend to use the same line for both fax and phone calls
. . . and . . .
• You are using, on that line, at least one other phone which is not
connected to your fax machine.
In this mode: Your fax machine never answers calls automatically; you must
answer each call as described in “Answering calls manually — for
all reception modes” (left column).
To select Tel Ready:
Press RECEIVE repeatedly until the TEL light comes on.
If you hear someone speaking to you, go ahead and
have a normal phone call.
If you hear fax tones (“beep — beep — beep —
beep”), press START and hang up the handset.
Your fax machine will begin receiving a fax.
Note: Don’t try to answer a call by pressing
MONITOR/CALL. The monitor function is
only for on-hook dialing. Your fax
machine does not have a speakerphone.
Fax Ready mode
Use it if:
You have your fax machine installed on a “dedicated” line (one it
doesn’t share with a second phone).
In this mode: Your fax machine answers each incoming call after a certain number of rings (see page 2.4) and attempts fax reception.
To select Fax Ready:
Press RECEIVE repeatedly until neither TEL, TEL/FAX nor ANS/FAX
light is glowing.
1.21
Getting started
Tel/Fax Ready mode
Use it if:
4
You use your machine not only as a fax but also as a telephone.
Press
or
to select the Fax Primary mode.
Fax Primary
In this mode: Your fax machine answers each incoming call after a certain number of rings (see page 2.4) and if you receive a voice call, alerts you
with a special ring.
The Tel/Fax Ready reception mode is a mix between the Tel Ready and Fax ready
modes.
Note: Turning on the fax primary mode on your fax machine won’t turn off ringers
on other telephones in your house or office. Similarly, other phones won’t
distinguish between fax and voice calls.
To select Fax Ready:
What if you answer a fax call?
Press RECEIVE repeatedly until TEL/FAX light comes on.
5
Press ENTER to save the setting.
With your fax machine in Tel/Fax Ready mode, you can easily use your fax machine
on the same line as other telephone(s) already in your home or office.
Now, let’s deal with the two possible ways your phone(s) and your fax can live happily together on one line:
• A phone connected directly (physically) to your fax machine (see page 1.11).
• A phone, connected elsewhere in your home or office.
Fax primary mode in Tel/Fax Ready mode
Use the fax primary mode if you want your fax machine to:
• Answer incoming call without ringing. (However, it beeps at the end of reception.
If you want to mute this beeping, use the silent mode, see page 2.5).
. . . but also . . .
• Alert you when a regular voice call comes in.
If a voice call comes in, your machine detects it and sounds a special ring for about
30 seconds. If you hear it, you will know you should answer.
To make your fax operate this way:
1
2
Using a phone connected to your fax machine
If you answer a connected phone and hear fax tones, simply press START and hang
up the handset. Your fax machine will receive the fax call.
Using a phone not connected to your fax machine
If you have another telephone connected to the same phone line as your fax
machine, but not connected directly to your fax machine, you can still receive an
incoming fax call using that phone. Here’s what to do if you answer that second
phone and hear fax tones:
1
Set your fax machine for Tel/Fax Ready, as described above.
Press PROGRAM, J, 1, 9.
3
Tel Primary
Note: In Tel primary mode, your fax machine answers each incoming call
after a certain number of rings.
1.22
• Put the telephone handset down without hanging it up
. . . or . . .
• If the telephone has a “hold” feature, put the phone on hold and then hang
up the handset.
Primary Tel/Fax
Press ENTER.
Don’t hang up the line! Instead:
2
3
4
5
Go to your fax machine.
Press MONITOR/CALL.
Press START.
Return to the telephone. If you didn’t put the phone on hold in step 1, hang
up its handset.
Getting started
Ans/Fax Ready mode
Use it if:
You are using an answering machine connected directly to your fax
machine.
In this mode: An answering machine externally connected to your fax machine
answers each incoming call. If a voice call comes in, the answering
machine will begin to record the incoming message. If the fax tone
starts, your fax machine will detect it and receive the fax message
automatically.
To select Ans/Fax Ready:
Press RECEIVE repeatedly until ANS/FAX light comes on.
Detection of “silent” fax machines
Some older fax machines don’t send fax tones when transmitting.
However, your fax machine can accommodate these “silent” machines without disrupting your answering machine operation. For more information, call your
authorized Muratec dealer.
When the paper or ink film runs out
Getting the word from your machine
When your fax machine runs out of paper or ink film, it beeps, the ALARM light
glows and the LCD displays Check Rx Paper or Check Ink Film message.
Receiving faxes when out of paper or ink film
If your machine runs out of paper or ink film, it stores up to 50 separate fax receptions in memory. This is called out-of-paper reception. When you replenish the
paper or ink film supply, the fax machine will print the stored messages automatically!
Using an answering machine with your fax machine
If you are connecting an answering machine to your fax machine:
1
Follow the steps on page 1.11 to connect an answering machine to your fax
machine.
2
3
4
On your fax machine, press RECEIVE until the ANS/FAX light comes on.
Set your answering machine to answer calls after no more than two rings.
(Consult the answering machine’s instructions if necessary).
Note: How many pages (as opposed to receptions) your fax machine can store for
out-of-paper reception will vary. It depends on your machine’s memory
capacity and the types of documents being sent to your machine. It also
depends on the resolution settings the remote fax uses when sending faxes
to your machine.
Note: During a power failure, all documents stored in memory will be backed-up
up to 72 hours*.
* The machine’s back-up battery requires about 1 day to reach full charge after to the fax
machine is restored.
Finally, use your answering machine to create a new outgoing message.
Here’s a suggested message:
Hello! You’ve reached [your name or telephone number]. To leave a voice message, please wait for the beep. To send a fax, press Start on your fax
machine. Thanks for calling!
Important: Your answering machine’s outgoing message must be no longer than
10 seconds.
1.23
Getting started
Making copies
You can make copies from your fax machine by using either the feeder or the
machine’s memory.
Copying from memory
Use this mode to make multiple copies or reduced copies. The copy reduction rate
can be set through the copy parameter settings (see page 2.4).
Copying from feeder
Use this mode to make a single copy.
Note: When you make a copy from the feeder, you cannot select the normal resolution.
To make a copy from feeder:
1
2
Note: Your machine automatically sorts multiple copies. For example, four copies
of the same two-page document will print as : 1,2 — 1,2 — 1,2 — 1,2.
To make a copy from memory:
1
2
Insert the document face down. Adjust the document guides for a correct fit.
Press COPY. The LCD shows:
No. of Copy = 01
Press COPY. The LCD shows:
If you want to make one copy of each page of the document from memory,
enter 0, 1 using numeric keypad, then skip to step 4.
If not, go on to step 3.
No. of Copy = 01
Note: If you enter the number of copies for each page, the machine automatically switches to memory copy mode (see next column).
3
Insert the document face down. Adjust the document guides for a correct fit.
3
Press COPY again to begin copying.
Use the numeric keypad to enter the desired number of copies for each page
in the document. You may choose one (“01”) to 99 copies.
Here, we chose three copies.
No. of Copy = 03
Note: The setting requires two digits. Always enter a leading zero for quantities below 10 copies.
4
Press COPY to begin the copying.
Note: In this mode, the documents are stored in the memory before copying.
If the memory of your machine becomes low, a “Memory Over Flow” message is displayed on the LCD and no more documents will be stored. If this
happens, press COPY to print the documents that are already stored in memory, or press CANCEL to clear all documents stored during this
operation.Dividing a large document into smaller batches will help you
avoid this error.
1.24
Getting started
It’s a great phone, too
Dialing a telephone number
1
2
3
Pick up the handset. You will hear a dial tone.
Dial the number by the using numeric keypad.
… or …
• Use the one-touch dialing. (See “One-touch phone dialing,” on page 2.8.)
… or …
• Use the speed-dial. (See “Phoning via speed-dial,” on page 2.10.)
… or …
• Use the EasyDail directory (see page 2.13.)
When the other person answers, speak to him or her.
Hold
You can put a call on hold during a conversation by pressing HOLD. The LCD shows:
**
On Hold
**
At this point, you can either hang up the handset or leave it off the hook.
To return to your conversation:
• If you hung up the handset, pick it up.
• If you didn’t hang up the handset, press HOLD again.
Note: After you’ve placed someone on hold, your machine beeps at one minute
intervals to remind you that someone is holding. If the conversation is on
hold for more than five minutes, the machine will disconnect the call automatically.
On-hook dialing
Flash
Because your machine has a monitor speaker, you can dial without picking up the
handset:
To quickly disconnect from one call and go right to the next one without having to
hang up the handset press FLASH.
1
Press MONITOR/CALL. You will hear a dial tone and the LCD will show:
**
2
Tel Mode
**
Dial the number you want. You may use either the numeric keypad, a onetouch key or a speed-dial number.
Note: Remember, your fax machine’s monitor speaker is not a speakerphone. Be
sure to pick up the handset if the other person answers!
Note: You can also dial a fax call using on-hook dialing if you want to hear the
other machine’s fax tones.
To do this, make sure there’s a document in the feeder and follow the steps
for on-hook dialing. When you hear those tones, press START to send the document.
Redial
Press REDIAL/PAUSE to redial the last number that the fax machine dialed.
Changing the dialing type
If your machine is set for “pulse” dialing, and you have to enter tones (“DTMF”) during a call, press #. This shows up on the LCD as the “–!” symbol. Your machine will
now “tone” dial subsequent numbers.
Note: Using this key enables tone transmission from the numeric keypad after the
call is connected. When you hang up the call, your machine will return to
“pulse” dialing for the next call.
1.25
Getting started
Call request
You can send or receive a fax message and have a regular phone conversation on
the same call.
For further information on how to use this function, see page 2.47.
Dialing during a power failure
You cannot make a telephone call or send a fax during a power failure or if your fax
is disconnected from its power source.
1.26
Beyond the basics
We’ve covered
the “musts.”
Now, let’s explore
the goodies.
Beyond the basics
What’s inside this section
Getting everything just the way you want it . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.2
Autodialer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.7
The time machine: delayed transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.14
Broadcasting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.16
Polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.19
F-code
communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21
Programmable one-touch keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.28
Keeping things secure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.37
Special features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.44
PC-FAX
feature: fax/ computer connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.50
2.1
Beyond the basics
Getting everything just the way you want it
The EasyStart feature guided you through the “just-gotta” settings on your machine.
In the next few pages, we will cover other settings in more detail.
Setting up for scans
You can set parameters for how your fax machine scans documents:
• Primary resolution mode — Gives you four ways to send faxes, either — normal, fine or superfine resolutions — or in grayscale mode.
• Primary contrast mode — Sets how light or dark you want faxed documents
to be when they arrive at their destinations.
1
Press PROGRAM, J, 0, 1. The LCD shows:
Scan Parameters
2
Press ENTER. The LCD asks which resolution you select:
Primary: Normal
If the setting you see is acceptable, skip to step 4.
If not, go on to step 3.
3
To change the setting, press or repeatedly until the mode you want
appears. In this example, we have chosen fine resolution.
Primary: Fine
4
Press ENTER to save the setting. The LCD asks which contrast setting you select:
Contrast: Normal
If the setting you see is acceptable, skip to step 6.
If not, go on to step 5.
2.2
5
To change the setting, press or repeatedly until the setting you want
appears. In this example, we have chosen light contrast.
Contrast: Light
6
Press ENTER to save the setting.
This section determines the resolution and contrast settings your fax will display
when you insert a document for transmission. If you choose “superfine” and “dark”
in steps 3 and 5, for example, these are the resolution and contrast settings you’ll
see the next time you put a document in the document feeder.
You can always change the resolution and contrast temporarily before sending.
To adjust the resolution and contrast:
• Press RESOLUTION to change the resolution.
• Press CONTRAST to change the contrast.
Beyond the basics
Setting the print parameters
Reduction margin
You can set two parameters for printing received fax messages:
• Print reduction rate
• Reduction margin
Your fax machine’s reduction margin is measured in millimeters (mm).
When a fax message enters your machine’s electronic brain, the machine measures
the message’s length and compares it to (a) the length of your selected paper plus
(b) the reduction margin you set. If the length of the incoming message is shorter
than the sum of (a) and (b), your machine prints the message on just one sheet;
otherwise, it prints the message on more than one sheet.
Print reduction rate
Print reduction lets you set the machine to reduce a large incoming document to a
size which will fit on your paper. Copy reduction lets you reduce the size of copies
made on your fax machine. Here are the options for both print reduction and copy
reduction settings:
Note: An Auto reduction setting and a reduction margin setting of 40mm will
print most incoming faxes as single pages. Try this combination first and
then, only if you have problems with it, select different settings.
Setting the print parameters
Setting
What it does
Auto
Automatically reduces printouts at variable rates down to a
minimum of 75%. Tries to reduce printout to fit on one sheet of
your selected paper size; if cannot, prints the image at 100% size
on two or more pages.
100%
Performs no reduction. (Due to the sender’s TTI, this may print two
pages when receiving a one-page fax document. See 97%, below.)
97%
Reduces an original so that the final printout of a one-page document (if the original is not larger than the paper in your machine)
will be only one page long, despite the TTI.
91%
Provides slightly more reduction.
81%
Provides even greater reduction. Helpful for certain international
stationery sizes, as well as special applications.
75%
Turns legal-sized originals into US letter-sized printed copies.
1
Press PROGRAM, J, 0, 2. The LCD shows:
Print Parameters
2
Press ENTER. The LCD shows the current set print reduction rate:
Reduc Rate :Auto
If the setting you see is acceptable, skip to step 4.
If not, go on to step 3.
3
To change the setting, press or
appears.
In this example, we chose 91%.
repeatedly until the setting you want
Reduc Rate : 91%
4
Press ENTER to save the setting. The LCD shows the current reduction margin:
Margin(0-85): 40
If the setting you see is acceptable, skip to step 6.
If not, go on to step 5.
For best results …
The printout may omit a small bit of the image at the page break if the
machine tries to reduce a legal-sized page onto letter-sized paper at any setting other than 75%. So whenever possible, load the correct paper size
before receiving a fax (or making a copy) of that size.
5
To change the setting, use the numeric keypad to enter the reduction margin
you want. If necessary, press or to move the cursor if you need.
In this example, we chose 38 mm.
Margin(0-85): 38
6
Press ENTER to save the setting.
2.3
Beyond the basics
Setting the copy parameters
Setting the number of rings
You can set two parameters for copying:
• Copy reduction rate — Works the same way as the print reduction rate (see page
2.3 for more details).
• Reduction margin — Serves the same purpose as the reduction margin for printing (see page 2.3 for more details).
You can set the number of times your fax machine will ring before answering a call.
Note: The same options are available for copy reduction as for print reduction. (If
necessary, review “Setting the print parameters,” on page 2.3.)
1
1
Set # Of Rings
2
Press ENTER. The LCD shows the current copy reduction rate:
3
To change the setting, press or repeatedly until the reduction setting
you want appears. In this example, we chose 75%.
:
2
If the setting you see is acceptable, skip to step 4.
If not, go on to step 3.
3
Reduc Rate :100%
If the setting you see is acceptable, skip to step 4.
If not, go on to step 3.
Press ENTER.
# (1-9)
Press PROGRAM, J, 0, 3. The LCD shows:
Copy Parameters
2
Press PROGRAM, J, 0, 6. The LCD shows:
To change the setting, use the numeric keypad to enter the number of rings
you want. You can choose from one to nine rings. Here, we chose four rings.
# (1-9)
4
:
4
Press ENTER to save the setting.
Note: If you enter 0 (zero), the machine will beep briefly to warn you that it
cannot accept that setting.
Reduc Rate : 75%
4
Press ENTER to save the setting. The LCD shows the current reduction margin:
Margin(0-85): 24
If the setting you see is acceptable, skip to step 6.
If not, go on to step 5.
5
To change the setting, use the numeric keypad to enter the reduction margin
you want. If necessary, press or to move the cursor.
In this example, we chose 00 mm.
Margin(0-85): 00
6
2.4
Press ENTER to save the setting.
Setting ECM
Static on a phone line during a call may ruin your attempts to communicate via fax.
This is because “line noise” can easily disrupt the flow of data from one fax machine
to another.
That’s why your fax machine gives you the chance of operating in Error Correction
Mode (ECM). When two fax machines communicate while running in ECM, the sending machine automatically checks the data, block by block, as it sends. If the
receiving fax machine cannot verify the transmission, the first machine will re-send
the information.
Note: While using ECM gives you a better chance of getting a fax document
through a troublesome phone line, it could also slow down the transmission
time. That’s why we let you turn ECM on or off as you require.
Note: Not all fax machines have ECM. If you have activated ECM and then transmit
to a fax machine not currently using ECM, there will no change in the fax
transmission from a usual, non-ECM transmission.
Beyond the basics
1
Press PROGRAM, J, 0, 8. The LCD shows:
5
Set ECM Mode
2
Press ENTER. The LCD shows the current ECM setting:
ECM Mode :
3
To change the setting, press or once or twice until the setting you want
appears. In this example, we chose Off.
ECM Mode :
4
For each: to toggle its displayed choice between off and on, press or
repeatedly until the mode you want appears. Then press ENTER to save the
mode and move on to the next setting.
On
If the setting you see is acceptable, skip to step 4.
If not, go on to step 3.
• Ringer silent — This mutes the ringer, including the special ring in Tel/Fax
ready mode (see page 1.22).
Ringer
Off
Press ENTER to save the setting.
Setting silent mode
1
Alarm
:
Off
If you want to silence all alarms, choice On. Otherwise, choose Off.
• Key-touch tone silent — This mutes the sounds and not-acknowledge your
machine makes when you press the keys on the control panel.
Key Buzzer: Off
If you want to silent the key-touch tone, choose On. Otherwise, choose Off.
Set Silent Mode
2
Off
• Alarm silent — This mutes the alarm your machine sounds when an error
occurs, the beep your machine makes after sending or receving a fax or making a
copy and the alarm and the beep your machine makes to remind you a caller is
waiting on hold.
Press PROGRAM, J, 1, 4. The LCD shows:
Press ENTER. The LCD shows your fax’s current setting:
:
If you want to silence the ringer, choose On. Otherwise, choose Off.
You can turn on your machine’s silent mode to mute the ringer, the alarm and the
key-touch tone, if you choose.
Note: If you use your fax machine as both a fax and phone (with the handset), you
may not want to use this feature.
Note: Turning on the silent mode on your fax machine won’t turn off ringers on
other telephones in your house or office.
The silent mode has three settings:
• Ringer silent (shown on the LCD as “Ringer”)
• Alarm silent (“Alarm”)
• Key-touch tone silent (“Key Buzzer”)
6
Press ENTER to complete setting the silent mode.
Silent Mode :Off
If the setting you see is acceptable, skip to step 4.
If not, go on to step 3.
3
To change the setting, press or once or twice until the setting you want
appears. In this example, we chose On.
Silent Mode :On
4
Press ENTER to save the setting.
2.5
Beyond the basics
Setting the language
Printing a program list
While English is the language which your machine initially uses to display messages
and print reports, you can set it to “speak” French or Spanish, too!
To make the change from one language to the next, press PROGRAM, #.
Your machine can also print a program list. This list gives a brief summary of
instructions available on your fax machine, organized in a “program tree” so you
can see which key combinations produce which instructions.
¿Qué es? — or, What is it?
Note: Please refer to the index at the end of these instructions to locate any setting you do not recognize or understand.
If you aren’t sure which language is showing after you’ve made a language change,
press PROGRAM once and decide based on what appears on the LCD:
To print a program list, press PROGRAM, *, 8. Your machine will print the list.
Num. Une-Touche
is French.
Núm. Una-Tecla
is Spanish.
If the language you see is the one you want, press STOP to return to standby mode.
If you want to change languages, press STOP to return to standby mode and then
press PROGRAM, # to go to the next language in the cycle.
Printing your settings
After you enter your settings, print a settings list.
With this list, you can quickly check all the settings without having to check them
on the machine.
Note: Please refer to the index at the end of these instructions to locate any setting you do not recognize or understand.
To print the settings list, press PROGRAM, J, 2, 1, ENTER.
2.6
Beyond the basics
Autodialer
Your fax machine’s autodialer stores your most frequently called phone and fax
numbers so you don’t have to remember them. The autodialer also makes it easy to
dial even the most complicated international calls!
Special dialing characters
There are two kinds of autodialer numbers. The difference between the two is how
you “call them up,”:
• One-touch — Pressing one of the keys, marked A–O on the control panel.
• Speed-dial — Pressing SPEED DIAL/TEL INDEX followed by a three-digit identifier,
from 01 to 85.
Which number do you find easier to read: 919725552009 or 9-1-972-555-2009?
Obviously, it’s the second one. The hyphen (or dash) character (“-”) separates the
numbers. In this example, a 9 is entered for outside-line access, a 1 is entered for
long-distance access, then the area code and the phone number are entered.
The hyphen can also be important if you have to use special long-distance access
codes or country codes for international calling.
Also, certain calls require special symbols besides just numerals. If you make calls
to other countries — or just have your fax machine on an unusual phone system —
you will want to be able to put the appropriate characters in the numbers you store.
That’s why your fax machine allows you to enter special dialing characters. Below is
a brief description of these characters, as well as how you can put them in the numbers you store in the autodialer:
How big is the vault?
Char. What it does
Autodialer basics
How do you autodial?
Your fax machine can store a total of 100 numbers — up to 15 one-touch numbers
and up to 85 speed-dial numbers.
Which number is which?
Your fax machine’s autodialer will hold both fax numbers and phone numbers.
This is possible because your fax machine first checks to see if there’s a document in
the feeder. If there is, the machine dials as a fax machine. If there isn’t, it dials as a
telephone.
EasyDial directory
— or, What the heck’s a Location ID?
Your machine also features a built-in EasyDial directory (see page 2.13) which acts
as a phone book for your fax and phone numbers. Just enter your fax/phone numbers along with their descriptive names in the EasyDial directory. (Your machine
calls this name a Location ID.) The autodialer sorts these alphabetically so, with
EasyDial, you can look them up by name as if you were using a phone book.
–
/
!
–/
–!
Keystroke(s)
Makes long numbers easier to read.
Does not change fax machine operation.
DIALING OPTIONS (once)
(Has no effect.)
DIALING OPTIONS (twice)
Tells your fax machine to pause until it
“hears” a dial tone.
DIALING OPTIONS (3 times)
Enters a pause when dialing
long-distance numbers or when you are
dialing through PABX. Each pause lasts five
seconds (or whatever length you set; see
page 1.16). Each pause uses two of
the characters you can store in one
phone number.
REDIAL/PAUSE
If your fax machine is set for pulse dialing,
DIALING OPTIONS (once), then
switches from pulse- to tone- (“DTMF”)
(once), then
dialing. Use after the actual phone number
DIALING OPTIONS (3 times),
but before any characters (such as long-then (once)
distance access codes) which must be in
DTMF tone. Do not use on a tone line. Each
uses two of the characters you can
store in one phone number.
–!
2.7
Beyond the basics
Note: To change a character you have already entered:
— Press to move the cursor to the left or to move it to the right,
to that character.
— Press CANCEL to erase the character.
— Enter the digit(s) you want.
Using one-touch numbers
As indicated previously, your fax machine will store up to 15 one-touch numbers by
using the keys marked A–O.
Entering or changing a one-touch number
Important: To erase a number, see “Erasing a one-touch number” (next page).
1
Press PROGRAM, A, 1.
7
8
then it will show either:
_ABCDEF
Press ENTER. Depending on whether you already have a number entered for
one-touch number A, the LCD shows:
A :No Number
Press the one-touch key in which you want to store a number or change a previously stored number. Here, we select B and the LCD shows either:
B :No Number
4
5
Press ENTER. Depending on whether you already have a number entered for
this one-touch number, the LCD now shows briefly:
then it will show either:
or 555-987-6543_
Use the numeric keypad to enter the number exactly as your machine should
dial it, including whatever access codes your phone system requires. (You
may want to review “Special dialing characters,” page 2.7.) The number can
be up to 40 characters in length:
9-1-555-9292039_
Note: Your display can show only 16 characters at a time. To view characters
beyond those 16 (such as with international long-distance number),
press to scroll to the left or to scroll to the right.
2.8
> Murat
If you do not want to enter or change this Location ID, skip to step 10.
If you do want to enter or change this number’s Location ID, go on to step 9.
9
A number’s Location ID may be up to 16 characters in length. Enter the
Location ID the same way you entered your fax name during EasyStart.
Let’s review the process:
On the LCD, you will see the character set currently available, such
as:
_ABCDEF
>
To find a different character,
press 2 or 8 over and over again
to scroll through character sets
until you see the one you want.
B :Fax Number
6
or _ABCDEF
or B :555-987-6543
If you change your mind and want to select a different one-touch key, just
press that key before going on step 5.
_
>
The machine is now prompting you for a name — a Location ID — so you will
be able to find it easily in the EasyDial directory (see page 2.13).
or A :555-345-6789
If A is the key you want to set, skip to step 4. However, our sample displays
from here on will say “B” rather than “A.”
3
The LCD now displays:
B :Name
Enter One-Touch
2
When the number is as you want it, press ENTER to store it.
If you need to type in a space, one
can be found before and after
each character set.
When you see the character you want:
• Press either 4 or 6 to move the cursor to the character you want.
• Then press 5 to enter that character and move on to the next entry.
Note: If you make a mistake, just press CANCEL to erase to the left. Then
continue to enter the character(s) you want.
Note: As you enter characters, the LCD will scroll to the left so you can view
entries longer than five characters.
Beyond the basics
10
Press ENTER to save the setting.
The LCD will display the next one-touch number.
If you do not want to enter any more one-touch numbers, press STOP to finish.
If you do want to enter another one-touch number, go back to step 3.
If you do want to enter this one-touch number, go back to step 5.
One-touch phone dialing
To dial a phone call using a one-touch number:
1
One-touch fax dialing
Now that you have stored a one-touch number or two, let’s discuss the ease of using
one-touch keys to make calls. To dial a fax call using a one-touch number:
1
2
3
**
2
Insert the document.
Tel Mode
**
Press the one-touch key in which you have stored the number. As the
machine dials, it shows the number on the LCD:
9-1-555-9292039_
Adjust resolution and contrast if necessary.
Press the one-touch key in which you have stored the number. As the fax
machine dials, the LCD shows the Location ID.
Muratec Office
Note: If the number does not have a Location ID, the fax number appears.
The machine handles the call from here. What happens next will depend upon
whether you specified transmission from memory or transmission from the feeder.
(To review memory transmission, see page 1.17)
If you specified transmission from memory:
• Your fax machine scans your document into memory first, then dials the other
fax machine.
• When the other machine answers, your fax will transmit the document directly
from memory.
If you specified transmission from the feeder:
• Your fax machine dials the other fax machine.
• When the other machine answers, your fax feeds the document through its scanner, transmitting as it goes.
4
Obtain a dial tone by doing one of the following:
• Lifting the handset
• Press MONITOR/CALL to use the monitor speaker.
At the end of the operation, your fax machine beeps and displays:
** Completed **
Note: Remember that your fax machine’s monitor speaker is not a speakerphone.
If you dial using the monitor speaker, pick up the handset to speak to the
person that answers the call.
Note: You can also use this method to dial a fax call if you want to hear the other
machine’s fax tones. If doing this, make sure there’s a document in the
feeder. When you hear the fax tones from the other machine, press START to
send the document in the feeder. If you lifted the handset to make the call,
hang it up at this point.
Erasing a one-touch number
1
Press PROGRAM, A, 2
Erase One-Touch
2
Press ENTER. The LCD shows:
A :No Number
or A :555-345-6789
If A is the key you want to erase, skip to step 4. (However, our examples from
here will say “B” rather than “A.”)
3
Press the key for the one-touch number you want to erase.
Here, we select B:
B :555-987-6543
4
If you change your mind and want to erase the number stored in a different
one-touch key, just press that key before going on step 5.
2.9
Beyond the basics
5
Press ENTER. The LCD shows:
2
Press ENTER. Depending on whether you already have a number entered for
speed-dial number 01, the LCD shows:
Check Prog/Enter
01:No Number
Important: If you want to quit without erasing the one-touch number you
have selected, press PROGRAM. The fax will return to step 3.
6
Press ENTER to erase the number.
** Complete **
If 01 is the speed-dial number you want to set, skip to step 4. (However, our
examples from here will say “05” rather than “01.”)
3
To erase another one-touch number, repeat steps 3–6. Or press STOP to return to
standby mode.
Printing a list of your one-touch numbers
If you forgot which number is stored in which one-touch key, just print a list of your
one-touch numbers. The list includes each key’s letter, the Location ID, number and
group number(s) you may have stored in the key.
To print the list, press PROGRAM, A, 3, ENTER.
or 01:555-584-6950
Use the numeric keypad to enter the desired speed-dial number’s two-digit
identifier code. Here, we enter 05 and the LCD shows either:
05:No Number
4
5
or 05:555-397-0123
If you change your mind and want to select a different speed-dial number,
just repeat step 3 until the number you want appears, then go on to step 5.
Press ENTER. Depending on whether you already have a number entered for
this speed-dial number, the LCD now shows briefly:
05:Fax Number
then it will show either:
_
6
Using speed-dial numbers
As we mentioned before, your fax machine will store up to 85 speed-dial numbers,
designated by two-digit identifier codes from 01 (the first number) through 85.
Note: Your display can show only 16 characters at a time. To view characters
beyond those 16 (such as with an international long-distance numbers), press to scroll to the left or to scroll to the right.
Note: To change a character you have already entered:
— Press to move the cursor to the left or to move it to the right,
to that character.
— Press CANCEL to erase the character.
— Enter the digit(s) you want.
Entering or changing a speed-dial number
Important: To erase a number, see “Erasing a speed-dial number” (page 2.10).
Press PROGRAM, B, 1.
Enter Speed-Dial
2.10
Use the numeric keypad to enter the number exactly as your machine should
dial it, including whatever access codes your phone system may require. (You
may want to review “Special dialing characters,” page 2.7.) The number can
be up to 40 characters in length:
9-1-555-9292039_
Important: Speed-dial numbers 1-9 require a leading zero when entering them
into the machine. For example, enter 01, not just 1.
Speed-dial numbers 10–85 do not require leading zeroes.
1
or 555-397-0123_
7
When the number is as you want it, press ENTER to store it.
Beyond the basics
8
Fax dialing via speed-dial
The LCD now displays:
To dial a fax call using a speed-dial number:
05:Name
then it will show either:
_ABCDEF
>
or _ABCDEF
> Murat
The machine is now prompting you for a name — a Location ID — so you will
be able to find it easily in the EasyDial directory (see page 2.13).
If you don’t want to enter or change this number’s Location ID, skip to step 10.
If you do want to enter or change this number’s Location ID, go on to step 9.
9
1
2
3
4
To find a different character,
press 2 or 8 over and over again to
scroll through character sets until
you see the one you want.
If you need to type in a space, one
can be found on each side of the
character set.
When you see the character you want:
• Press either 4 or 6 to move the cursor to the character you want.
• Then press 5 to enter that character and move on to the next entry.
Note: If you make a mistake, just press CANCEL to erase to the left. Then
continue to enter the character(s) you want.
Note: As you enter characters, the LCD will scroll to the left so you can view
entries longer than five characters.
10
Press ENTER to save the setting.
The LCD will display the next speed-dial number.
If you don’t want to enter any more speed-dial numbers, press STOP to finish.
If you do want to enter another speed-dial number, go back to step 3.
If you do want to enter this speed-dial number, go back to step 5.
Press SPEED DIAL/TEL INDEX once. The LCD shows:
Use the numeric keypad to enter the two-digit identifier (such as 05, in this
example) for the speed-dial number you want to dial. You will see a brief
Location ID then the speed-dial number:
Muratec Office
On the LCD, you will see the character set currently available, such
as:
>
Adjust resolution and contrast if necessary.
S_
A number’s Location ID may be up to 16 characters in length. You enter the
Location ID the same way you entered your fax name during EasyStart.
Let’s review the process.
_ABCDEF
Insert the document.
S05_
Note: If the speed-dial number does not have a Location ID, only the number
appears.
5
Press START.
The machine handles the call from here. What happens next will depend upon
whether you specified transmission from memory or transmission from the feeder
(To review memory transmission, see page 1.17):
If you specified transmission from memory:
• Your fax machine scans your document into memory first, then dials the other
fax machine.
• When the other machine answers, your fax will transmit the document directly
from memory.
If you specified transmission from the feeder:
• Your fax machine dials the other fax machine.
• When the other machine answers, your fax feeds the document through its scanner, transmitting as it goes.
6
At the end of the operation, your fax machine beeps and displays:
** Completed **
2.11
Beyond the basics
Phoning via speed-dial
To dial a phone call using a speed-dial number:
1
Obtain a dial tone by doing one of the following:
• Lifting the handset
• Press MONITOR/CALL to use the monitor speaker
**
2
Tel Mode
If you change your mind and want to erase a different speed-dial number,
repeat steps 3 through 5.
Press ENTER. The LCD shows:
Check Prog/Enter
Important: If you want to quit without erasing the speed-dial number you
have selected, press PROGRAM. The fax will return to step 3.
**
Press SPEED DIAL/TEL INDEX. The LCD shows:
6
Press ENTER to erase the number.
** Complete **
S_
3
4
5
Use the numeric keypad to enter the two-digit identifier (such as 05, in this
example) for the speed-dial number you want to dial. The LCD shows:
To erase another speed-dial number, repeat steps 3–6. Or press STOP to return to
the standby mode.
9-1-555-9292039_
Note: Remember that your fax machine’s monitor speaker is not a speakerphone.
If you dial by using the monitor speaker, pick up the handset to speak to the
person that answers the call.
Note: You can also use this method to dial a fax call if you want to hear the other
machine’s fax tones. To do this, make sure there is a document in the
feeder.) When you hear those tones over either your handset or the monitor
speaker, press START to send the document in the feeder. If you are using
the handset, hang it up at this point.
Erasing a speed-dial number
1
Press PROGRAM, B, 2.
Erase Speed-Dial
2
Press ENTER. The LCD shows:
01:No Number
or 01:555-584-6950
If 01 is the speed-dial number you want to erase, skip to step 4. (However,
our examples from here will say “05” rather than “01.”)
3
Use the numeric keypad to enter the two-digit identifier for the speed-dial
number you want to erase. Here, we select 05:
05:555-987-6543
2.12
Printing a list of your speed-dial numbers
You can easily print a list of your speed-dial numbers. The list includes each number’s
two-digit identifier, the Location ID, the phone or fax number and any group numbers you may have stored.
To print the list, press PROGRAM, B, 3, ENTER.
Beyond the basics
EasyDial directory dialing
The EasyDial directory dialing feature makes your autodialer even more like an
electronic phone book. EasyDial sorts and displays numbers alphabetically according to their Location IDs, so you can easily find them and dial them. When the name
you want appears, you just press START to begin a call (either phone or fax).
Your machine’s EasyDial directory alphabetizes in the following order:alphabet,
number and symbols.
5
When the LCD is showing the name you want to dial, press START.
• If there is a document in the feeder, your machine dials a fax call to the
autodialer number.
• If there is not a document in the feeder, your machine activates the monitor speaker and makes a regular phone call. At this point, you may either:
— Lift the handset
or
— Listen to the monitor speaker until you hear the other person answer,
and then lift the handset to speak.
1
If you want to use EasyDial to make a regular phone call, make sure there is
no document in the feeder and then skip to step 3.
If you want to use EasyDial to send a fax, insert the document.
2
3
Adjust resolution and contrast if necessary.
What if an EasyDial call does not go through?
Press SPEED DIAL/TEL INDEX twice. The LCD shows the first listing in your fax
machine’s EasyDial directory, in alphabetical order:
If an EasyDial call fails, what happens next depends upon the kind of call it was.
ABC Company
(If this listing is the one you want to dial, skip to step 6.)
Note: If your fax machine has caller-ID, the LCD shows the most recent
caller-ID information. (See page 2.48 for more information.)
To change to the EasyDial directory, press 2, 4, 6 or 8 on the numeric
keypad.
4
Scroll through the listings to find
the one you want.
• Press 2 or 8 to find the first
character of the Location ID.
“S”, for example.
• Press 4 or 6 to check the listings beginning with that
character. For example, Sarah,
Shaina or Stuart
If it was a fax call …
… Your fax machine automatically redials the number after the redial interval (see
page 1.19). It keeps trying until either of the following occurs:
• It successfully reaches the other number.
• It has automatically redialed the number for the last try (see page 1.19).
If it was a regular phone call …
… You will have to redial manually:
1
2
Obtain a dial tone by either lifting the handset or pressing MONITOR/CALL.
Press REDIAL/PAUSE.
Note: When you are press 2 or 8,
the LCD displays only characters with at least one entry.
Note: If there is only one listing for a displayed character, pressing 4 or 6
will cause the fax machine to beep at you briefly.
2.13
Beyond the basics
Delayed transmission
Take advantage of lower evening and weekend long-distance rates with delayed
transmission. Your fax machine can store up to 30 delayed commands, each of
which you can program up to 31 days in advance.
Important: If you program a full 30 delayed transmission commands, no further
memory transmission is possible until the machine completes at least
one of the delayed commands. (To review memory transmission, see
page 1.17.) However, you can always transmit from the feeder by using
on-hook dialing or an handset (see page 1.18).
5
_
6
Enter the fax number to which the delayed transmission should go. You may
either press a one-touch key, enter a speed-dial number or just use the
numeric keypad to enter the number.
Note: If you make a mistake, press CANCEL to erase to the left. Or, if you
want to change just one character in the number, press to move the
cursor to the left, or to move it to the right, to that character and
press CANCEL to erase it. Then re-enter the number until it is just as
you want it.
7
Press START. Your machine will return to its normal standby mode, while
showing this on the LCD:
Setting up a delayed transmission
Important: Your machine remembers only the day of the month when it’s supposed to perform a delayed transmission. It does not remember the
month itself. If you want your fax to do something at 5:05 PM on June
26, do not make that setting sooner than 5:06 PM on May 26.
To set up a delayed transmission:
1
2
Insert the document and make any necessary adjustments.
Press COM-OPTIONS twice. The LCD shows:
2.Delayed
3
Press ENTER. The LCD shows the current day of the month, followed by the
current time (in 24-hour format):
Time :
4
06/17:16
Use the numeric keypad to enter the day of the month and the time you want
the delayed transmission to occur.
Note: To move the cursor to a specific digit, press to move the cursor to
the left, or move it to the right, to that digit.
Here, we set the transmission to occur on the 11th at 11:05 PM:
Time :
2.14
11/23:05
When the date and time entry is as you want it, press ENTER to save the
delayed transmission. The LCD shows:
** Reserved **
This means your fax machine is “reserved” for the delayed transmission command you just programmed.
If you set the machine for transmission from memory, it will scan the delayed
command document into memory, and you can use the machine normally.
If you set the machine for transmission from the feeder, the machine can
receive faxes but cannot transmit until the delayed command is completed.
Important: If you have stored too much information in your machine’s memory, a
“Memory Overflow” message may appear on the LCD. This appears
because 1) too many pages have been stored in the memory, or 2) the
pages that are stored have too much information on them for your fax
machine to remember.
If this message appears, press START to tell your fax to keep as many
pages in memory as possible, or press CANCEL to delete from memory
all pages stored during this operation (but not previous operations).
Beyond the basics
Reviewing or canceling delayed commands
If you have stored a delayed command in your fax machine, it will hold it in memory until it either completes the command successfully or reaches its maximum
number of redial attempts (see page 1.19). Your machine can store up to 30 delayed
commands. It identifies each by a two-digit command number ranging from 01 to 30.
The same procedure lets you display your machine’s stored commands and gives
you a chance to cancel them, if necessary:
1
Press REVIEW COMMANDS.
• If your machine is currently holding no delayed commands — It
will beep briefly and display “No Command” on the LCD. To return to
standby mode, press STOP.
• But if there are commands in your machine’s memory, the LCD shows:
C01:9-555-2311
Here, you see command 01, followed by the phone number it is set to dial.
• If the command is to perform a broadcast or sequential polling,
“Broadcast” will appear instead of the phone number. (See “Broadcasting,”
pages 2.16–2.18.)
C01:Broadcast
• If the command is to perform a one-touch dial, a one-touch number will
appear instead of the phone number.
4
To keep this command but continue reviewing stored commands, press PROGRAM.
To keep this command and stop reviewing commands, press STOP to return
your machine to standby mode.
To cancel the command, press CANCEL again and return to step 2 to view
other commands.
Printing a delayed command list
Can’t remember the details about a delayed transmission command you set up? Or,
has someone in your office set up a delayed command and now you have no idea
why the machine is “reserved” and how long it will stay that way?
For situations like these, your machine can print a command list which tells you:
• The command’s identification number
• The phone number, one-touch number or speed-dial number
• The start time (which appears in the same DD,HH:MM format you saw in the previous instructions for actually setting up a delayed transmission command)
• A “Option” telling the fax communication options, such as delayed, broadcast,
polling, etc..
• A “note” shows group number if the command is a relay broadcast initiation operation (see page 2.17 for more information)
To print a delayed command list, press PROGRAM, F, 1, ENTER.
C01:[ A]
• If the command is to perform a speed-dial, a speed-dial number will
appear instead of the phone number.
C01:S01
Note: If your machine is attempting to perform a command now, it will
appear on the display.
To cancel this command, skip to step 3.
To review a different command, proceed to step 2.
2
3
If necessary, press
commands.
or
Printing a stored document
Your fax machine can produce a printout of each document stored for delayed transmission. You will need to know the document’s command number, which you can
confirm by either reviewing the commands (see left column) or printing a delayed
command list (see above).
1
Command No.: _
repeatedly to scroll through currently stored
2
If you want to cancel the command currently shown, press CANCEL.
The LCD shows:
Prog/Cancel
Press PROGRAM, F, 2, ENTER. The LCD shows:
Use the numeric keypad to enter the command’s identification number, 01–30.
For example, we could enter the following for the very first command, 01:
Command No.: 01_
3
Press ENTER. Your fax machine will print a copy of the stored document.
2.15
Beyond the basics
Broadcasting
The basics of broadcasting
Delayed broadcasting
The fastest way to fax one document to many recipients is broadcasting. You can
use broadcasting from any function requiring the entry of a fax number!
That means you can perform delayed broadcasting (see right column) and even
broadcasting to “hub” units for relay broadcast initiation (see next page).
In an ordinary broadcast, you send a fax as you normally would, except you add
more fax numbers. You can enter up to 120 numbers (20 normally dialed numbers,
plus 100 autodialer numbers).
What if you want the broadcast to happen later? That’s the purpose of setting up a
delayed broadcast.
Note: If you frequently broadcast a document to the same set of remote fax
machines, you can group these units’ phone numbers together under a programmable one-touch key (see page 2.28). In this way, you can initiate a
broadcast at the touch of just a single button.
We’ll assume you are familiar with regular fax transmission, and shorten the
instructions.
1
2
_
4
5
Enter the first fax number — a one-touch number, a speed-dial number or just
a regular number dialed from the numeric keypad.
To add each additional fax number, press ENTER between each one to insert a
comma, then enter the number as in step 3. You can include up to 120 numbers
for a broadcast (see first paragraph, above).
C,9-5551204,S05
Important: Do not insert a comma after the last fax number.
Note: If you enter characters by mistake, just press CANCEL to clear them
before proceeding.
6
2.16
3
Press START. Your fax machine will scan the document into memory and then
send it to each number you have entered.
Press COM-OPTIONS twice.
Press ENTER. The LCD shows the current date and time, such as:
Time :
4
Press COM-OPTIONS once.
Press ENTER. The LCD shows:
Follow steps 1-5 of “The basics of braodcasting” (left column).
2.Delayed
Insert the document and make any necessary adjustmentsl.
1.Broadcast
3
1
2
Use the numeric keypad to enter the day of the month and time you want the
fax broadcast to occur.
Here, we set it to occur at 10:15 PM on the 30th.
Time :
5
6
01/15:10
30/22:15
When finished, press ENTER to save the setting.
Now, press START. Your machine returns to its normal standby mode, while
showing this on the LCD:
** Reserved **
This means your fax machine is “reserved” for the delayed broadcast you
just programmed.
Beyond the basics
Relay broadcast initiation
Setting up, a relay broadcast initiation
Relay broadcasting is a powerful function that takes advantage of a remote “hub” to
reduce your total communication costs.
A “hub” fax machine is one to which you send a document, which in turn relays it to
other machines which you do not actually call. The “hub” performs a relay broadcast, and the machine which sends the original document to the “hub” has
performed a relay broadcast initiation.
Your fax machine does not have relay broadcast feature, but it does have relay
broadcast initiation.
For you to perform relay broadcast initiation, three things must be true:
• The remote fax machine must be a Muratec fax machine with “hub” capability.
Note: If you are not sure whether the unit to which you want to transmit is a
true “hub” unit, please consult your authorized Muratec dealer.
• The call group(s) must exist on the remote fax machine.
• You must know each call group’s identifier number.
To set up a relay broadcast initiation:
How it works
Let’s say you’re in Los Angeles and need to fax the same document to four locations
in the Chicago area. You could send fax transmissions to each location, but that
would be four long-distance calls. With relay broadcast initiation, you send the document once to your Chicago office’s “hub” fax, which then sends it on to each of the
four locations.
1
2
Insert the document and make any necessary adjustments.
Press COM-OPTIONS three times.
3.Relay Tx
3
Press ENTER.
Group No.
_
Relay transmission from Hub to destinations at lower rates
Final destination 1
Use the numeric keypad to enter the two-digit identifier of each call group you
want in the remote “hub” fax machine you will be calling. You can specify up
to 10 groups for each relay broadcast initiation. Do not press START.
To add a group after the first one, press COM-OPTIONS to add a comma.
Below, we have entered 2, COM-OPTIONS, 4.
Chicago
Final destination 3
ll
e ca
Hub
anc
dist
g
n
Final
destination
2
o
l
e
On
Group No.
Final destination 4
2,4_
Important: Do not insert a comma after the last fax number.
Note: If you enter characters by mistake, just press CANCEL to clear them
before proceeding.
Los
Angeles
Original sender
4
Press ENTER. The LCD shows:
_
What happens when you perform relay broadcast initiation:
• You use your fax machine to send a document to at least one call group in a
remote “hub” machine’s autodialer. This can occur either immediately or as a
delayed command (see pages 2.14–2.15).
• The remote “hub” unit receives your document and stores it in memory.
• The remote machine retransmits — relays — the document to each fax number
in each call group you specified. This is the relay broadcast you initiated.
5
Enter the fax number for the remote “hub” unit. You may either press a onetouch key, enter a speed-dial number or just use the numeric keypad to enter
the number. Do not press START.
6
What you do now depends upon when you want to begin initiating the
relay broadcast.
• If you want it to begin now, skip to step 9.
• If you want to delay it, press COM-OPTIONS, COM-OPTIONS, ENTER.
Note: For more information on delayed transmission, see pages 2.14–2.15.
2.17
Beyond the basics
7
Use the numeric keypad to enter the day of the month and time when you
want to begin initiating the relay broadcast.
Here we set the transmission to occur on the 14th at 2:00 PM:
Time :
8
9
14/14:00
When the entry is complete, press ENTER. The LCD shows the fax number you
entered in step 5.
Press START.
If, in step 6, you chose an immediate relay broadcast initiation, your fax machine
will begin dialing the remote “hub” machine. However, if you requested a delayed
command, the machine will display “Reserved” on the LCD. This means the command is in memory.
2.18
Beyond the basics
Polling
Polling allows someone to fax a document to you without the other person having to
make (and pay for) the call. Your machine can perform:
• Regular polling — Retrieves a document from the remote fax machine.
• Sequential polling — Retrieves a document from several remote fax machines.
• F-code polling — Retrieves a document from a fax machine that supports ITU-T subaddress transactions. (See “F-code polling,” on pages 2.26—2.27.)
Regular polling
To perform regular polling of a document from any remote fax machine:
1
2
Make sure that the document is ready to be polled from the remote fax. The
remote fax user may need to review his / her instructions.
Press COM-OPTIONS four times. The LCD shows:
4.Polling
6
Press COM-OPTIONS, COM-OPTIONS, ENTER. The LCD shows:
Time :
7
8
9
15/17:05
Use the numeric keypad to enter the date and time your machine should perform the delayed regular polling.
Press ENTER. The LCD shows the fax number you entered in step 4.
Press START.
When it performs the polling command, your machine will dial the number and,
upon making contact with the other machine, begin receiving the document as if the
other machine had placed the call.
Sequential polling
To perform sequential polling of a document from any remote fax machine:
3
Press ENTER. The LCD shows briefly:
Enter Fax Number
then it will show:
1
2
Enter the remote fax machine’s number by either pressing a one-touch key,
entering a speed-dial number or just dialing the number using the numeric
keypad.
5
To perform the regular polling now, skip to step 9.
To perform delayed regular polling, proceed to step 6.
Press COM-OPTIONS four times. The LCD shows:
4.Polling
_
4
Make sure that the document is ready to be polled from the remote fax. The
remote fax user may need to review his / her instructions.
3
Press ENTER. The LCD shows briefly:
Enter Fax Number
then it will show:
_
4
5
Enter the first fax number — a one-touch number, a speed-dial number or a
regular number dialed from the numeric keypad.
To add each additional fax number, press ENTER between each one to insert a
comma, then enter the number as in step 4. You can include up to 120 numbers
(see “Broadcasting”, page 2.16) for sequential polling.
2.19
Beyond the basics
C,9-5551204,S05
Important: Do not insert a comma after the last fax number.
Note: If you enter characters by mistake, just press CANCEL to clear them
before proceeding.
6
7
To perform the sequential polling now, skip to step 10.
To perform delayed sequential polling, proceed to step 7.
Press COM-OPTIONS, COM-OPTIONS, ENTER.
The LCD shows the current day and time:
Time:
8
9
10
15/17:05
Use the numeric keypad to enter the date and time your machine should perform the delayed sequential polling.
Press ENTER.
Press START.
When it performs the polling command, your machine will dial the number and,
upon making contact with the other machine, begin receiving the document as if the
other machine had placed the call.
5
Press ENTER. Your fax machine scans the document into memory and returns
to standby mode.
Note: If you were using another reception mode before step 1 and want to return
to it after the remote machine has polled your document, press RECEIVE to
select a new mode.
But do this only after you are sure the remote machine has polled
your document.
Erasing a stored polling document
To erase from your machine’s memory a document you’ve stored for regular or database polling by another machine:
1
Press PROGRAM, D, 2. The LCD shows:
Erase PollingDoc
2
Press ENTER. Your fax machine will erase the document from memory.
Printing a stored polling document
To print, without erasing, a document you’ve stored for regular polling:
1
Press PROGRAM, D, 3. The LCD shows:
Print PollingDoc
F-code polling
See pages 2.26–2.27.
2
Press ENTER. Your fax machine will print the document.
Being polled
Limiting polling access to your fax machine
Not only can you poll, you also can be polled. To set up a document for regular
polling by another machine:
Your machine’s closed network setting (see page 2.42) also works for polling.
When you set the passcode (see page 2.42), a calling fax that doesn’t “present” the
proper passcode, it cannot poll from your fax.
1
Press RECEIVE to change your fax machine to the Fax Ready mode. In the Fax
Ready mode, neither the TEL, TEL/FAX nor ANS/FAX light is glowing.
Important: Your machine cannot be polled if it’s in Tel Ready mode.
2
3
4
Insert the document.
Adjust resolution and contrast if necessary.
Press PROGRAM, D, 1. The LCD shows:
Store PollingDoc
2.20
Note: However, if you are using the Block Junk Fax feature (see pages 2.42–2.43),
even incoming calls which meet the passcode test must come from appropriate phone numbers.
Beyond the basics
F-code communication
F-code: an introduction
Creating or modifying an F-code box
The ITU-T, part of the United Nations agency that maintains international telecommunications standards (see the Glossary that begins on page 3.16), has now created
a fax industry standard for using sub-addressing and password-based communications with not only other Muratec fax machines but also other manufacturers’
machines. One name for this standard is F-Code, and that is what we’ll call it in
these instructions and on your machine’s display.
To use the F-code box, you must have the F-code boxes set up on your fax machine.
You may also want to modify existing F-code boxes (but, to do so, you must know the
each box’s I.D. code; see step 5 and step 14).
To create or modify an F-code box:
1
Press PROGRAM, E, 1.
Set F-Code Box
How sub-addressing works: think of a mailroom
If you are new to the concept of sub-addressing, think about how someone receives
mail addressed to a department within that person’s company. For example, mail
for Accounting gets to the mailroom for the entire company. The Mail Department
then routes the mail to Accounting.
That’s the idea behind sub-addressing. Once your fax and another F-Code-compatible fax begin their communication, they exchange special F-Code signals to indicate
just where the fax really should go. It’s as if the sending fax were saying, “Take this
one and deliver it to room 48” and the receiving fax were replying, “48? OK, will do.”
For greater security, you can set up an ITU-T-compatible sub-address and password
with F-Code, which lets you use secure transmission and polling in communication
with any other fax machine, so long as it, too, uses the F-Code standard from ITU-T.
To use ITU-T sub-addressing and password features, you must create F-Code boxes
in your machine. Your machine can use up to 10 of these boxes. You can store up to
30 documents (not pages) into each F-Code box.
2
Setting up the F-code boxes
4
If you decide you want to select a different F-code box, just use the numeric
keypad to enter the two-digit number for the box you want before going on to
step 5.
5
Press ENTER.
• If you are creating this F-code box for the first time, the following display
won’t appear. Skip to step 6.
• If you selected a previously created F-code box, the LCD shows:
Before you set up an F-code box, there are a few things you should know:
• The remote fax machine must support the ITU-T subaddress and password capabilities, and the remote fax users must be using it.
• Your machine’s F-code box works like a normal SecureMail mailbox except that
it accepts and stores ITU-T-standard F-code secure communication.
• The received documents are stored in the F-code box.
To print them, you have to enter an I.D. code.
(See “Print a document received in F-code box,” page 2.25.)
• Your machine can create up to 10 F-code boxes. Each box can receive up to 30
documents.
Press ENTER. Depending on whether you already have a name entered for
F-code box 01, the LCD shows briefly:
Select F-CodeBox
then it will show either:
01:No Number
or 01:Bookkeeping
If this is the F-code box you want to set, skip to step 4. (However, our samples
from here on will refer to F-code box 03, rather than 01.)
3
Use the numeric keypad to enter the two-digit number (01-10) of the F-code
box you want to create or modify. (Use a leading zero for numbers below 10.)
Here, we have entered 0, 3 and see:
03:No Number
I.D. Code
or 03:MuratecOffice
:****
To modify this previously created F-code box, enter the proper I.D. code using
the numeric keypad, then press ENTER.
2.21
Beyond the basics
Note: If you enter an invalid I.D. code, the fax machine will reject the
attempt and abort this operation.
6
8
The LCD now shows briefly:
03:Sub-Address#
01:Box Name
then it will show either:
then it will show either:
_ABCDEF
>
or _ABCDEF
> Murat
The machine is asking for this F-code box’s ITU-T subaddress.
You must enter a subaddress here in order to use this F-code box, and anyone
trying to fax to this F-code box must know it.
If you want to enter or change this F-code box’s name, proceed to step 7.
If you do not want to enter or change this box’s name, skip to step 8.
An F-code box’s name may be up to 16 characters in length. You enter the
name the same way you entered your fax name during EasyStart. We will
review the process, here.
To enter or change the subaddress number, proceed to step 9.
If you do not want to change an existing subaddress number, skip to step 10.
9
On the LCD, you will see the character set currently available, such
as:
_ABCDEF
>
If you need to insert a space, one
can be found before and after
each set of characters.
When you see the character you want:
• Press either 4 or 6 to move the cursor to the character you want.
• Then press 5 to enter that character and move on to the next entry.
Note: If you make a mistake, just press CANCEL to erase to the left. Then
continue to enter the character(s) you want.
Note: As you enter characters, the LCD will scroll to the left so you can view
entries longer than five characters.
Use the numeric keypad to enter the exact subaddress for this F-code box.
Note: The subaddress must be unique to this F-code box; i. e., no other
F-code box in this fax machine can have the same subaddress.
This ITU-T subaddress can be up to 20 characters in length and can include
any combination of numbers and the * and # symbols (but no other nonnumerical characters). In this example, we enter 6*54321#.
6*54321#_
To find a different character,
press 2 or 8 repeatedly to scroll
through character sets until you
see the one you want.
2.22
or 123456_
_
The machine is now prompting you for a name for this F-code box.
7
Press ENTER to save the box’s name.
The LCD shows briefly:
Note: To erase previously entered numbers, press CANCEL to erase to the
left. Or to change just one character in the number, press to move
the cursor to the left, or to move it to the right, to that character
Press CANCEL to erase it. Then re-enter the number until it is just as
you want it.
10
Press ENTER to store it.
Note: If you entered a sub-address number already being used by another
F-code box, the machine will beep and briefly display the following:
Sub-Addr. In Use
The machine now returns you to step 9. Enter a different number for
your F-code box’s subaddress.
Beyond the basics
11
Depending on whether you already have an ITU-T password entered for your
F-code box, the LCD shows briefly:
13
03:Password
Hold Time
then it will show either:
_
or 123456_
If you want to enter or change this box’s ITU-T password, proceed to step 12.
If you do not want to enter or change this box’s ITU-T password, skip to step 13.
:00
Use the numeric keypad to enter a two-digit number indicating how long, in
number of days (00-31), you want your fax machine to keep received documents in this F-code box. Here, we enter 0, 9, for nine days:
The machine is asking for your F-code box’s password.
This is the password for ITU-T-compatible F-code fax transactions. (It is not an
I.D. code for your machine. If you set the password, a caller must know and
use it in order to send a fax to you via F-code communication.
Note: You do not need a password to use the F-code box. However, using a
password will make your F-code communications much more secure.
12
Press ENTER. The machine then asks for the number of days you want to store
the document.
Hold time
:09
Note: Your fax machine can normally store incoming documents in F-code
boxes (up to the limits of its memory) as long as 31 days, after which
it automatically erases the documents. But if your machine has plenty
of memory, you may want to override the 31-day limit to keep the documents indefinitely. If so, enter 00.
14
Use the numeric keypad to enter this box’s ITU-T-compatible password.
This password can be up to 20 characters in length and can include any combination of numbers and the * and # symbols (but no other non-numerical
characters). Here, we enter 135*7#9.
Press ENTER to save the settings. The display now shows:
I.D. Code
:0000
The machine is asking for your F-code box’s four-digit security I.D. code.
After you set this I.D. code, you will have to enter it each time you want to
view or modify the settings for this F-code box (see step 5, page 2.21)
135*7#9_
You will also have to enter this I.D. code to print documents received in this Fcode box or to erase this F-code box.
Note: To erase previously entered numbers, press CANCEL to erase to the
left. Or to change just one character in the number, press to move
the cursor to the left, or to move it to the right, to that character
and press CANCEL to erase it. Then re-enter until the number is just
as you want it.
To enter or change this I.D. code, proceed to step 15.
If this is a previously created box and you do not want to change this I.D. code,
skip to step 17.
15
Decide upon a four-digit I.D. code (0001-9999) for this F-code box. Write this
code down, and put it in a safe place.
Note: You cannot use 0000 as an I.D. code.
16
Use the numeric keypad to enter the four-digit I.D. code for this F-code box.
Here we enter 2468:
I.D. Code
17
:2468
Press ENTER to save the information.
To create or modify another F-code box, repeat steps 4-17.
To finish, press STOP.
2.23
Beyond the basics
Erasing an empty F-code box
Important: You can only erase an empty F-code box. If the F-code box is holding
any documents, you must first clear each document from the box. You
can clear the F-code box by printing the documents it holds (see next
page).
To erase an empty F-code box:
1
7
Check Prog/Enter
Note: If you entered an invalid I.D. code in step 6, the fax machine will reject
the attempt and abort this operation.
Note: If you want to quit without erasing the F-code box you have selected,
press PROGRAM. The fax will return to step 3.
Note: If you want to quit without erasing any F-code box, press STOP.
The machine will return to standby mode.
Press PROGRAM, E, 4. The LCD shows:
Erase F-Code Box
2
Press ENTER. The LCD shows briefly:
Select F-CodeBox
or 01:Bookkeeping
If this is the box you want to erase, skip to step 4. (However, our examples
from here will refer to box 03 rather than box 01.)
3
Use the numeric keypad to enter the two-digit identifier number (01-10) of
the F-code box you want to erase. Here, we press 0, 3 and see:
03:Muratec Offic
4
If you change your mind and want to erase a different F-code box, just use the
numeric keypad to enter the desired box’s two-digit identifier number before
going on to step 5.
5
Press ENTER. If the F-code box is empty, the LCD shows:
I.D. Code
:****
Note: If you select an F-code box which is not empty, the machine beeps and,
before returning to step 3, briefly displays:
Box In Use
6
Use the numeric keypad to enter the proper four-digit I.D. code.
Here, we enter 2345:
I.D. code:
2.24
2345
8
Press ENTER to erase the F-code box.
**
then it will show either:
01:No Number
Press ENTER. The LCD shows:
Complete
**
To erase another F-code box, repeat steps 3-8.
To finish, press STOP.
Printing a list of your F-code boxes
You can easily print a list of your F-code boxes. The list includes each box’s identifier number, the box name, subaddress, password and document storage time.
To print the list, press PROGRAM, E, 2, ENTER.
Beyond the basics
Printing a document received in an F-code box
F-code transmission and polling
When your machine receives a document via ITU-T sub-addressing from another fax
machine, your machine will print a message alerting the person for whom the document is intended. Then the person has a certain number of days in which to print
out the message before your machine erases it. (see step 13, on page 2.23)
With F-code, your machine can send secure transmissions to other manufacturers’
machines, and perform polling from other makers’ machines, as well. You can do
this in one of two ways:
• Press a programmable one-touch key programmed for sub-address sending. (See
“Programmable one-touch key,” on pages 2.32-2.35)
. . . or . . .
• Enter the ITU-T subaddress and password directly, which is what we will now
describe.
Note: For this operation to work, two things must be true:
•You must know the F-code box’s two-digit number.
•You must know the four-digit I.D. code for the F-code box.
To print a received message from an F-code box:
1
Press PROGRAM, E, 3. The display shows:
Print F-Code Doc
2
Press ENTER.
01:Bookkeeping
3
If this box holds the document you want to print, skip to step 4.
If not, go on to step 3.
Use the numeric keypad to enter the two-digit number (01-10) of the F-code
box currently “holding” the document you want to print. We enter 03.
03:Muratec Offic
4
Press ENTER. The display will show:
I.D. Code
:****
Note: If the F-code box is holding no documents at this time, the LCD shows
this briefly before returning to step 3:
No Doc. Stored
5
F-code transmission
Sending a document with ITU-T subaddress / password
1
2
:2345
Press ENTER.
• If you enter the correct I.D. code, your fax machine will print all documents
in this F-code box and then erase them.
• If you enter an incorrect I.D. code, your fax machine will refuse to print the
document.
Insert the document. Adjust resolution and contrast if necessary.
Press COM-OPTIONS five times.
5.F-Code Tx
3
In step 3, be sure to select an F-code box that is holding at least one
document.
Use the numeric keypad to enter your F-code’s four-digit I.D. code.
Here we enter 2345:
I.D. Code
6
Note: For F-code communication to occur, three things must be true:
• The remote fax machine must support ITU-T sub-addressing (and password) capabilities.
• A mailbox (F-code box) with an ITU-T subaddress must exist on the remote
fax. (It does not have to have an ITU-T password.) If the other machine
doesn’t have not at least one box with a subaddress, F-code communication
will be impossible.
• You must know the ITU-T subaddress and (if applicable) password information for the mailbox (F-code box) on the remote machine.
Press ENTER. The LCD shows briefly:
Enter SubAddress
then it will show:
_
4
Use the numeric keypad to enter the appropriate subaddress number.
In this example, we enter 123456.
123456_
5
Press ENTER. The LCD shows briefly:
2.25
Beyond the basics
Enter Password
then it will show:
_
6
F-code polling
Press ENTER. The LCD shows briefly:
Enter Fax Number
then it will show:
_
8
9
Enter the fax number either by pressing a one-touch key, entering a speeddial number or dialing from the numeric keypad.
Do not press START.
What you do now depends upon when you want the transmission to begin.
• To have it begin now, skip to step 12.
• To delay it, proceed to step 10.
Polling with ITU-T subaddress / password:
1
Time:
15/17:05
Use the numeric keypad to enter the day and time when the transmission
should begin, then press ENTER.
Press START.
If you chose an immediate transmission in step 9, your fax machine will begin
dialing. If you chose a delayed command, the machine will display
“** Reserved **” on the LCD, indicating that the machine has stored the
command in memory and will perform it later.
Note: The ITU-T subaddress and password can be up to 20 characters in length and
can include any combination of numbers and the * and # symbols. Do not
include other non-numerical characters.
2.26
Press COM-OPTIONS six times.
6.F-Code Polling
2
Press ENTER. The LCD shows briefly:
Enter SubAddress
then it will show:
_
3
10 Press COM-OPTIONS, COM-OPTIONS, ENTER. The LCD shows:
11
12
to move it to the right, to
Note: If you know that this subaddress does not have a password, skip to
step 7.
Use the numeric keypad to enter the appropriate password.
In this example, we enter 654321.
654321_
7
Note: To change a number you have already entered:
—
Press to move the cursor to the left or
that character.
—
Press CANCEL to erase the character.
—
Enter the digit(s) you want.
Use the numeric keypad to enter the appropriate subaddress.
In this example, we enter 123456:
123456_
4
Press ENTER. The LCD shows briefly:
Enter Password
then it will show:
_
5
Use the numeric keypad to enter the appropriate password number.
In this example, we enter 654321.
654321_
Note: If you know that this sub-address does not have a password, skip to
step 6.
Beyond the basics
6
Press ENTER. The LCD shows briefly:
Enter Fax Number
then it will show:
_
7
8
Enter the fax number either by pressing a one-touch key, entering a speeddial number or dialing from the numeric keypad. Do not press START.
9
Press COM-OPTIONS, COM-OPTIONS, ENTER.
The LCD shows the current day and time:
What you do now depends upon when you want the transmission to begin.
• To have it begin now, skip to step 11.
• To delay it, proceed to step 9.
Time :
15/17:05
10
Use the numeric keypad to enter the day and time when the transmission
should begin, then press ENTER.
Note: If you make a mistake, press to move the cursor to the left, or to
move it to the right, to that character. Then re-enter until the number
is just as you want it.
11
Press START.
If you chose an immediate transmission in step 8, your fax machine will begin
dialing. If you chose a delayed command, the machine will display
“** Reserved **” on the LCD, indicating that the machine has stored the
command in memory and will perform it later.
Note: The ITU-T subaddress and password can be up to 20 characters in length and
can include any combination of numbers and the * and # symbols. Do not
include other non-numerical characters).
Note: To change a number you have already entered:
—
Press to move the cursor to the left or to move it to the right, to
that character.
—
Press CANCEL to erase the character.
—
Enter the digit(s) you want.
2.27
Beyond the basics
Programmable one-touch keys
Using the power of programmable one-touch keys
The programmable one-touch keys P1–P5 simplify complex fax operations, letting
you really tap into your machine’s power.
You can “teach” these keys the following multi-step operations for one-key press
convenience:
• Delayed transmission (pages 2.14–2.15)
• Broadcasting (page 2.16)
• Relay broadcast initiation (pages 2.17–2.18)
• Polling, regular or sequential (pages 2.19–2.20)
• F-code transmission (pages 2.25–2.27)
• F-code polling (pages 2.25–2.27)
Setup for each operation is very similar. Each time, you tell the machine four
things:
• How — The key you are programming
• Who — The number(s) the machine should dial
• What — The operation it should perform
• When — The date(s) and time(s) when you want it to perform the operation.
3
P3:No Number
4
5
2
_
6
P1:No Number
… or indicates a command is already programmed into this key.
If P1 is the key you want to program, skip to step 4. (However, our examples
from here will say “P3” rather than “P1.”)
2.28
or 9-555-8743_
Use the numeric keypad to enter the number exactly as your machine should
dial it, including whatever codes your phone system requires. The number
can be up to 40 characters in length:
9-555-0629_
Your display can show only 16 characters at a time. To view characters beyond
those 16, press to scroll to the left or to scroll to the right.
Important: Do not press ENTER.
Note: If you make a mistake or want to erase previously entered numbers,
press CANCEL to erase to the left. Or to change just one character in
the number, press to move the cursor to the left, or to move it to
the right, to that character. Press CANCEL to erase it. Then re-enter
the number until it is just as you want it.
Press PROGRAM, C, 1. The LCD shows:
Press ENTER. The LCD shows either:
Press ENTER. The LCD now shows briefly:
then it will show either:
Note: To erase a programmable one-touch key, refer to page 2.36.
To program a delayed transmission into a programmable one-touch key:
Enter P OneTouch
If you decide to select a different programmable one-touch key, go back to
step 3 before going on to step 5.
P3:Fax Number
Programming a delayed transmission
1
Select the key in which you want to program a command or change a previously stored command and then press it. Here, we have selected P3.
7
Now, while you still can see the fax number on the LCD, press COM-OPTIONS,
COM-OPTIONS. The LCD shows:
2.Delayed
Beyond the basics
8
Time :
9
If P1 is the key you want to program, skip to step 4. (However, our examples
from here will say “P3” rather than “P1.”)
11/20:30
Instruct your fax to carry out this delayed command in one of the following
ways:
Option 1:
Perform the command once at a certain time on a certain day of
the month. (For example, “Do this at 5:05 PM on the 30th.”)
To select this option, use the numeric keypad to enter the date
and time when the fax should perform the command:
Time :
Option 2:
30/17:05
3
00/17:05
Select the key in which you want to program a command or change a previously stored command and then press it. Here, we select P3.
P3:No Number
4
5
If you decide to select a different programmable one-touch key, go back to
step 3 before going on to step 5.
Press ENTER. The LCD now shows briefly:
P3:Fax Number
Perform the command at a certain time each day you press the
key. (For example, “Do this at 5:05 PM today.”)
To select this option, use the numeric keypad to enter 0, 0 (i. e.,
00), and then the time when the fax could perform the command:
Time :
10
11
… or indicates a command is already programmed into this key.
Press ENTER. The LCD shows the current day and time:
then it will show either:
_
6
Press ENTER, ENTER.
or 9-555-8743_
Use the numeric keypad to enter up to 120 fax numbers. These can include
all of your one-touch keys and speed-dial numbers and up to 20 numbers you
enter with the numeric keypad.
Important: Do not press ENTER.
The LCD now displays the next programmable one-touch key.
If you do not want to enter or change any other key’s programming, press STOP
to return your machine to its usual standby mode.
If you do want to enter or change another key’s programming, go back to step
4.
Between each number, press PROGRAM to enter a comma.
Important: Do not insert a comma after the last number.
To enter a speed-dial number, press SPEED DIAL/TEL INDEX and the number’s
two-digit identifier.
A,S02,9-555-2468
Programming a broadcast
Your display can show only 16 characters at a time. To view characters beyond
those 16, press to scroll to the left or to scroll to the right.
Note: If you make a mistake or want to erase previously entered numbers,
press CANCEL to erase to the left. Or to change just one character in
the number, press to move the cursor to the left, or to move it to
the right, to that character and press CANCEL to erase it. Then reenter until the number is just as you want it.
Note: To erase a programmable one-touch key, refer to page 2.36.
Programming a broadcast is very similar to programming a delayed transmission
But rather than specifying just one phone number, you set up multiple numbers for
the transmission.
To program a broadcast into a programmable one-touch key:
1
Press PROGRAM, C, 1. The LCD shows:
Enter P OneTouch
2
Press ENTER. The LCD shows either:
7
If you want the broadcast to begin immediately every time you press the key,
press ENTER and skip to step 10.
If you want to delay the broadcast (perhaps to take advantage of lower phone
rates), press COM-OPTIONS, COM-OPTIONS, ENTER.
P1:No Number
2.29
Beyond the basics
8
Option 1:
Perform the command once at a certain time on a certain day of
the month. (For example, “Do this at 5:05 PM on the 30th.”)
To select this option, use the numeric keypad to enter the date
and time when the fax should perform the command:
Time :
Option 2:
If P1 is the key you want to program, skip to step 4. (However, our examples
from here will say “P3” rather than “P1.”)
3
Select the key in which you want to program a command or change a previously stored command and then press it. Here, we select P3.
P3:No Number
30/17:05
Perform the command at a certain time each day you press the
key. (For example, “Do this at 5:05 PM today.”)
To select this option, use the numeric keypad to enter 0, 0 (i. e.,
00), and then the time when the fax could perform the command:
Time :
9
10
… or indicates a command is already programmed into this key.
Instruct your fax to carry out this delayed command in one of the following
ways:
4
5
Press ENTER. The LCD now shows briefly:
P3:Fax Number
00/17:05
then it will show either:
Press ENTER, ENTER.
The LCD now displays the next programmable one-touch key.
If you do not want to enter or change any other key’s programming, press STOP
to return your machine to its usual standby mode.
If you do want to enter or change this key’s programming, go back to step 4.
If you decide to select a different programmable one-touch key, go back to
step 3 before going on to step 5.
or 9-555-8743_
_
6
Use the numeric keypad to enter the “hub” machine’s number exactly as your
machine should dial it, including whatever codes your phone system requires.
The number can be up to 40 characters in length:
9-555-0629_
Your display can show only 16 characters at a time. To view characters beyond
those 16, press to scroll to the left or to scroll to the right.
Programming a relay broadcast initiation
Note: To erase a programmable one-touch key, refer to page 2.36.
Note: For this operation to work, three things must be true:
• The remote fax machine must be a Muratec fax machine with “hub”
capability.
• The call group(s) to which you are faxing must exist on the remote
machine.
• You must know the two-digit number for each call group that you are
faxing.
To program a relay broadcast initiation into a programmable one-touch key:
1
Press PROGRAM, C, 1. The LCD shows:
Enter P OneTouch
2
Press ENTER. The LCD either shows:
P1:No Number
2.30
Important: Do not press ENTER.
Note: If you make a mistake or want to erase previously entered numbers,
press CANCEL to erase to the left. Or to change just one character in
the number, press to move the cursor to the left, or to move it to
the right, to that character. Press CANCEL to erase it. Then re-enter
until the number is just as you want it.
7
Now, while you can still see the fax number on the LCD, press COM-OPTIONS
three times. The LCD shows:
3.Relay Tx
8
Press ENTER. The LCD shows:
Group No.
_
Beyond the basics
9
Use the numeric keypad to enter the two-digit identifier (01–32) for the first
call group. You can specify up to 10 separate groups for each relay broadcast
initiation. Between the entry of each new group, press COM-OPTIONS to insert
a comma. Do not insert a comma after the last group number.
For example, here, we enter 0, 4, COM-OPTIONS, 1, 1, COM-OPTIONS, 2, 4:
Group No.
1,24_
Programming regular polling or sequential polling
Note: To erase a programmable one-touch key, refer to page 2.36.
To program a polling operation into a programmable one-touch key:
1
Enter P OneTouch
Note: The LCD shows only four characters at a time.
Important: Again, do not insert a comma after the last group number.
2
11
If you want the transmission to begin immediately every time you press the
key, press ENTER and skip to step 13.
If you want to delay the transmission, press COM-OPTIONS, COM-OPTIONS,
ENTER.
Instruct your fax to carry out this delayed command in one of the following
ways:
Option 1:
Perform the command once at a certain time on a certain day of
the month. (For example, “Do this at 5:05 PM on the 30th.”)
To select this option, use the numeric keypad to enter the date
and time when the fax should perform the command:
Time :
Option 2:
12
13
30/17:05
… or indicates a command is already programmed into this key.
If P1 is the key you want to program, skip to step 4. (However, our examples
from here will say “P3” rather than “P1.”)
3
00/17:05
Press ENTER, ENTER.
The LCD now displays the next programmable one-touch key.
If you do not want to enter or change any other key’s programming, press STOP
to return your machine to its usual standby mode.
If you do want to enter or change another key’s programming, go back to step
4.
Select the key in which you want to program a command or change a previously stored command and then press it. Here, we select P3.
P3:No Number
4
5
If you decide to select a different programmable one-touch key, go back to
step 3 before going on to step 5.
Press ENTER. The LCD now shows briefly:
P3:Fax Number
Perform the command at a certain time each day you press the
key. (For example, “Do this at 5:05 PM today.”)
To select this option, use the numeric keypad to enter 0, 0 (i. e.,
00), and then the time when the fax could perform the command:
Time :
Press ENTER. The LCD shows either:
P1:No Number
When finished, press ENTER.
10
Press PROGRAM, C, 1. The LCD shows:
then it will show either:
_
6
or 9-555-7312_
Use the numeric keypad to enter the number exactly as your machine should
dial it, including whatever codes your phone system may require. The number can be up to 40 characters in length:
9-555-0629_
Important: Do not press ENTER.
If performing regular (not sequential) polling, skip to step 8.
If performing sequential polling, proceed to step 7.
2.31
Beyond the basics
Note: If you make a mistake or want to erase previously entered numbers,
press CANCEL to erase to the left. Or to change just one character in
the number, press to move the cursor to the left, or to move it to
the right, to that character. Press CANCEL to erase it. Then re-enter
until the number is just as you want it.
7
11
Instruct your fax to carry out this delayed command in one of the following
ways:
Option 1:
Use the numeric keypad to enter up to 120 fax numbers. These can be any
combination of other one-touch keys, speed-dial numbers and numbers you
enter with the numeric keypad.
Perform the command once at a certain time on a certain day of
the month. (For example, “Do this at 5:05 PM on the 30th.”)
To select this option, use the numeric keypad to enter the date
and time when the fax should perform the command:
Time:
Important: Do not press ENTER.
Option 2:
Between each number, press COM-OPTIONS, ENTER to enter a comma.
Important: Do not insert a comma after the last number.
9-555-0692,A,S01
Perform the command at a certain time each day you press the
key. (For example, “Do this at 5:05 PM today.”)
To select this option, use the numeric keypad to enter 0, 0 (i. e.,
00), and then the time when the fax could perform the command:
Time:
Your display can show only 16 characters at a time. To view characters beyond
those 16, press to scroll to the left or to scroll to the right.
Note: If you make a mistake or want to erase previously entered numbers,
press CANCEL to erase to the left. Or to change just one character in
the number, press to move the cursor to the left, or to move it to
the right, to that character and press CANCEL to erase it. Then reenter until the number is just as you want it.
8
press ENTER. The LCD shows:
Polling
10
Press ENTER, ENTER.
The LCD now displays the next programmable one-touch key.
If you do not want to enter or change any other key’s programming, press STOP
to return your machine to standby mode.
If you do want to enter or change another key’s programming, go back to step
4.
If you want the polling to begin immediately every time you press the key,
press ENTER and skip to step 13.
If you want to delay the polling, press COM-OPTIONS, COM-OPTIONS, ENTER.
Programming an F-code transmission
Note: To erase a programmable one-touch key, refer to page 2.36.
Note: For F-code transmission to occur, three things must be true:
• The remote fax machine must support ITU-T subaddress (and password)
capabilities.
• A mailbox(F-code box) with an ITU-T subaddress must exist on the remote
fax. (It does not have to have a ITU-T password.) If the other machine doesn’t have at least one box with a subaddress, F-code communication will be
impossible.
• You must know the ITU-T subaddress and (if applicable) password information for the mailbox (F-code box) on the remote machine.
To program an F-code transmission into a programmable one-touch key:
1
Press PROGRAM, C, 1. The LCD shows:
Enter P OneTouch
2.32
00/17:05
Now, while you still can see the fax number on the LCD, press COM-OPTIONS
four times. The LCD shows:
4.Polling
9
12
13
30/17:05
Beyond the basics
2
Press ENTER. The LCD either shows:
8
P1:No Number
Enter SubAddress
… or indicates a command is already programmed into this key.
If P1 is the key you want to program, skip to step 4. (However, our examples
from here will say “P3” rather than “P1.”)
3
_
9
Select the key in which you want to program a command or change a previously stored command and then press it. Here, we select P3.
P3:No Number
4
5
Press ENTER. The LCD shows briefly:
If you decide to select a different programmable one-touch key, go back to
step 3 before going on to step 5.
Press ENTER. The LCD now shows briefly:
Enter an ITU-T subaddress for the box to which you want to send the document. The ITU-T subaddress can be up to 20 characters in length and can
include any combination of numbers and the * and # symbols. Do not include
other non-numerical characters.
In this example, we enter 6*54321#.
6*54321#_
10
Press ENTER. The display will show briefly:
Enter Password
P3:Fax Number
_
then it will show either:
_
6
Note: If you know that this ITU-T subaddress does not have a ITU-T password, skip to step 12.
or 9-555-7312_
Use the numeric keypad to enter the number exactly as your machine should
dial it, including whatever codes your phone system requires. The number
can be up to 40 characters in length:
11
9-555-0629_
1*23456#1_
Important: Do not press ENTER.
Your display can show only 16 characters at a time. To view characters beyond
those 16, press to scroll to the left or to scroll to the right.
Note: If you make a mistake or want to erase previously entered numbers,
press CANCEL to erase to the left. Or to change just one character in
the number, press to move the cursor to the left, or to move it to
the right, to that character and press CANCEL to erase it. Then reenter until the number is just as you want it.
7
Enter a appropriate ITU-T password for the box. The ITU-T password can be up
to 20 characters in length and can include any combination of numbers and
the * and # symbols (but no other non-numerical characters). In this example,
we enter 1*23456#1.
Note: If you make a mistake, press CANCEL to back up, then enter the correct number.
When the entry is complete, press ENTER.
12
If you want the transmission to begin immediately every time you press the
key, press ENTER again and skip to step 15.
If you want to delay the transmission, press COM-OPTIONS, COM-OPTIONS,
ENTER.
Now, while you can still see the fax number on the LCD, press COM-OPTIONS
five times. The LCD shows:
5.F-Code Tx
2.33
Beyond the basics
13
Option 1:
Perform the command once at a certain time on a certain day of
the month (For example, “Do this at 5:05 PM on the 30th.”)
To select this option, use the numeric keypad to enter the date
and time when the fax should perform the command:
Time :
Option 2:
If P1 is the key you want to program, skip to step 4. (However, our examples
from here will say “P3” rather than “P1.”)
3
Select the key in which you want to program a command or change a previously stored command and then press it. Here, we select P3.
P3:No Number
30/17:05
Perform the command at a certain time each day you press the
key. (For example, “Do this at 5:05 PM today.”)
To select this option, use the numeric keypad to enter 0, 0 (i. e.,
00), and then the time when the fax could perform the command:
Time :
14
15
… or indicates a command is already programmed into this key.
Instruct your fax to carry out this delayed command in one of the following
ways:
4
5
Press ENTER. The LCD now shows briefly:
P3:Fax Number
then it will show either:
00/17:05
_
Press ENTER, ENTER.
The display now shows the next programmable one-touch key.
If you do not want to enter or change any other key’s programming, press
STOP to return your machine to its usual standby mode.
If you do want to enter or change another key’s programming, go back to step
4.
If you decide to select a different programmable one-touch key, go back to
step 3 before going on to step 5.
6
or 9-555-7312_
Use the numeric keypad to enter the number exactly as your machine should
dial it, including whatever codes your phone system may require. The number can be up to 40 characters in length:
9-555-0629_
Important: Do not press ENTER.
Your display can show only 16 characters at a time. To view characters beyond
those 16, press to scroll to the left or to scroll to the right.
Note: If you make a mistake or want to erase previously entered numbers,
press CANCEL to erase to the left. Or to change just one character in
the number, press to move the cursor to the left, or to move it to
the right, to that character and press CANCEL to erase it. Then reenter until the number is just as you want it.
Programming F-code polling
Note: To erase a programmable one-touch key, refer to page 2.36.
Note: For F-code polling to work, two things must be true:
• The document which you are polling must exist on the remote machine in
an F-code (ITU-T sub-addressing/password) box.
• You must know the remote fax’s ITU-T subaddress and (if applicable) password for each box you want to poll.
7
6.F-Code Polling
To program an F-code operation into a programmable one-touch key:
1
Press PROGRAM, C, 1. The LCD shows:
Enter P OneTouch
2
Press ENTER. The LCD either shows:
P1:No Number
2.34
Now, while you still can see the fax number on the display, press COMOPTIONS six times. The LCD shows:
8
Press ENTER. The LCD shows briefly:
Enter SubAddress
_
Beyond the basics
9
Option 2:
Enter an ITU-T subaddress for the box to which you want to send the document. The ITU-T subaddress can be up to 20 characters in length and can
include any combination of numbers and the * and # symbols. Do not include
other non-numerical characters.
In this example, we enter 6*54321#.
Time :
6*54321#_
10
Press ENTER. The LCD will show briefly:
Enter Password
_
Note: If you know that this ITU-T subaddress does not have an ITU-T password, skip to step 12.
11
Perform the command at a certain time each day you press the
key. (For example, “Do this at 5:05 PM today.”)
To select this option, use the numeric keypad to enter 0, 0 (i. e.,
00), and then the time when the fax could perform the command:
14
15
00/17:05
Press ENTER, ENTER.
The LCD now shows the next programmable one-touch key.
If you do not want to enter or change any other key’s programming, press
STOP to return your machine to its usual standby mode.
If you do want to enter or change another key’s programming, go back to step
4.
Enter an appropriate ITU-T password for the box. The ITU-T password can be
up to 20 characters in length and can include any combination of numbers
and the * and # symbols. Do not include other non-numerical characters). In
this example, we enter 1*23456#1.
1*23456#1_
Note: If you make a mistake, press CANCEL to back up, then enter the correct number.
When the entry is complete, press ENTER.
12
If you want the transmission to begin immediately every time you press the
key, press ENTER again and skip to step 15.
If you want to delay the transmission (perhaps to take advantage of lower
phone rates), press COM-OPTIONS, COM-OPTIONS, ENTER.
13
Instruct your fax to carry out this delayed command in one of the following
ways:
Option 1:
Perform the command once at a certain time on a certain day of
the month (For example, “Do this at 5:05 PM on the 30th.”)
To select this option, use the numeric keypad to enter the date
and time when the fax should perform the command:
Time :
30/17:05
2.35
Beyond the basics
Erasing a programmable one-touch key
1
Press PROGRAM, C, 2. The LCD shows:
Erase P OneTouch
2
Press ENTER. The LCD shows something like:
P1:Delayed
If P1 is the key you want to erase, skip to step 4. (However, our examples
from here will say “P3” rather than “P1.”)
3
Press the programmable one-touch key you want to erase.
Here, we select P3:
P3:Polling
4
5
If you decide to erase a different programmable one-touch key, just press that
key before going on step 5.
Press ENTER. The LCD shows:
Important: If you want to quit without erasing the programmable onetouch key you have selected, press PROGRAM. The fax will
return to step 3.
Press ENTER to erase the number.
**
Complete
**
To erase another programmable one-touch key, repeat steps 3–6. Or press STOP to
return to standby mode.
Printing a list of your programmable one-touch keys
You fax machine can print a list of the commands you have stored in your programmable one-touch keys. The list includes each key’s one-touch letter, the telephone
number, when the command should start, which command you have selected and —
if applicable — the selected call group(s) for relay broadcast initiation you have
stored in the key.
To print the list, press PROGRAM, C, 3, ENTER.
2.36
To dial a fax call using a programmable one-touch number:
1
2
3
Insert the document.
Adjust resolution and contrast if necessary.
Press the programmable one-touch key in which you have stored the number.
Your fax will perform the operation either now or at whatever other time you set.
Note: To review the details for each operation, please review the its instructions.
See page 2.28 for a list of where to find each operation.
If you programmed this key to delay its operation, the LCD will briefly show the
below and return to normal standby mode:
** Reserved **
Check Prog/Enter
6
Programmable one-touch fax dialing
However, if you programmed this key to perform the operation immediately after
the key press, the LCD shows the number:
9-1-972-555-4335
Beyond the basics
Keeping things secure
Your machine’s security features can help you keep private fax documents private,
avoid unwanted outside communication and even protect against unauthorized use
of your machine.
The key to it all: the passcode
Your machine has a protection passcode system which is central to the machine’s
security features. If you set the passcode to anything besides 0000, this passcode provides access to many other security features.
To set your machine’s passcode:
1
Decide upon the four-digit passcode (0001–9999) you want to use. Write the
passcode down, and put it in a safe place.
Important: Do not use 0000. This turns off passcode protection.
2
Activating operation protection
1
If you are creating the passcode, use the numeric keypad to enter 0000.
If you are modifying an existing passcode, enter the existing passcode.
Press ENTER.
Enter the desired four-digit passcode. Here, we enter 6296:
2
Press ENTER to save the passcode.
Press ENTER. The LCD shows:
Passcode
3
4
:****
Use the numeric keypad to enter the passcode. Here, we enter 6296:
Passcode
:6296
Press ENTER. The LCD shows:
Opr.Protect :Off
5
6
NewPasscode:6296
7
Press PROGRAM, J, 1, 6.
Set Opr. Protect
Press ENTER.
OldPasscode:****
4
5
6
Important: For this feature to work, you must have set the passcode, as described
in the left column.
When operation protection is activated on your machine, only users who enter the
proper passcode (see “The key to it all: the password,” left column) can use it.
Press PROGRAM, J, 1, 5.
Protect Passcode
3
Operation protection
If the setting you see is acceptable, skip to step 7.
If not, go on to step 6.
To change the setting, press or once or twice until the setting you want
appears. In this example, we chose “On.”
Opr. Protect:On
7
Press ENTER to save the setting.
Note: Anytime you want to turn off the passcode, repeat steps 1–7 and enter 0000
in step 6.
2.37
Beyond the basics
Using your fax machine during operation protection
1
When you press any key on your machine, the LCD shows:
Passcode
2
:****
Use the numeric keypad to enter the four-digit passcode (here, we enter the
passcode we set previously; see page 2.37).
Passcode
:6296
If you enter the correct four-digit passcode, the machine now will let you go
on to the next step in the fax operation.
Note: If you start an operation while the first is still underway, the machine will
again ask for the passcode before proceeding with your new request.
However, the first operation will proceed unaffected, even if you fail to enter
the correct passcode for the second entry.
Security reception
With your fax machine’s security reception, you can tell it to keep all received faxes
in memory and not to print them. Later, you instruct it to print out the saved faxes.
This is great if, for example, you have concerns about after-hours workers nosing
around in documents intended for your eyes only!
Important: For this feature to work, you must have preset the passcode (see page
2.37) to something besides 0000. You must also know the passcode.
Note: In the following instructions, your machine’s LCD shortens the word
Transmission to Tx and the word Receive to Rx.
Activating security reception
1
Press PROGRAM, K, 1.
Set Security Rx
2
Press ENTER. The LCD shows:
Passcode
3
Use the numeric keypad to enter the passcode. Here, we enter 6296:
Passcode
4
:****
:6296
Press ENTER. The LCD shows:
Security Rx: Off
5
6
If the setting you see is acceptable, skip to step 7.
If not, go on to step 6.
To change the setting, press or once or twice until the setting you want
appears. In this example, we chose “On.”
Security Rx: On
7
Press ENTER. The LCD shows the machine’s current clock setting:
Time :
8
2.38
15:42
If you want security reception to begin now (and at this same time every day),
skip to step 10.
If not, go on to step 9.
Beyond the basics
9
Use the numeric keypad to enter the time (24-hour format) when security
reception should begin every day. Type over the numerals displayed.
Here, we enter 17:35 (5:35 PM):
Time:
17:35
To change a digit, press to move to the left, or
that digit. Then, enter the correct digit.
10
to move to the right, to
Press ENTER to save the setting.
Printing from security reception and turning it off
When security reception is active, an incoming fax goes directly into your machine’s
memory and the MEMORY RECEIVE light comes on. The fax is not printed.
To retrieve the faxes received during security reception and to return your machine
to normal reception until the next time:
1
Press PROGRAM, K, 2.
Print Mem Rx Doc
2
Press ENTER. The LCD shows:
Passcode
3
Use the numeric keypad to enter the passcode. Here, we enter 6296:
Passcode
4
:****
Masking the PIN
To prevent unauthorized long-distance calls, some office telephone systems require
you to enter not only the phone number but also a personal identification number
(PIN) whenever you dial an outside number beginning with 1.
If that’s true for you, you’ll probably want to keep that PIN confidential, so unauthorized persons can’t use it. Fortunately, your fax’s PIN mask feature makes such
confidentiality possible. With the PIN mask activated, you can dial a fax number
plus a PIN, but the PIN will not appear in a journal, error message printout, delayed
command list or even TCR, where an unauthorized user might see it. The PIN may be
up to eight characters in length (it can include the * or # symbols, if necessary), and
can be entered from the numeric keypad.
Important: For this feature to work, the passcode (see page 2.37) must be something besides 0000. You must also know the passcode.
There are three possible settings for the PIN mask feature:
• Off — The feature is not working. Any PIN you enter will appear on any display
or printout which shows what you dial.
• Mode 1 — Each remote fax unit has a departmental PIN access code. This count
• Mode 2 — Each fax user has a departmental PIN access code. This counts the
number of telephone calls the user has made.
Note: If you select Mode 1 and you will use a one-touch or speed-dial number, you
must store the PIN access code for the remote unit within that number.
However, if you select Mode 2, this is not necessary. (See “Autodialing while
using the PIN mask,” page 2.40 for further details.)
:6296
Press ENTER.
• If you enter the correct passcode, your fax machine will print all documents in its memory and then erase them. It will also turn security
reception off until the next time it’s programmed to security receive.
• If you enter an incorrect code, your fax machine will refuse to print and
security reception remains active.
• If your fax machine has not received any documents, “No Doc. Stored”
message will show on the LCD and security reception remains active.
Activating the PIN mask
Important: For this feature to work, you must have preset the passcode to
something besides 0000. If necessary, review “The key to it all:
the passcode,” page 2.37.
1
Press PROGRAM, J, 1, 7.
Set PIN Mode
2
Press ENTER. The LCD shows:
Passcode
:****
2.39
Beyond the basics
3
_
Use the numeric keypad to enter the four-digit passcode. In our example
here, we enter 6296.
Passcode
:6296
4
Note: If you enter an invalid passcode, the machine’s security feature will
abort the operation.
4
If the setting you see is acceptable, skip to step 7.
If not, go on to step 6.
To change the setting, press or repeatedly until the setting you want
appears. In this example, we chose “Mode1.”
PIN Mode: Mode1
7
1057_
5
Press ENTER.
PIN Mode: Off
5
6
Press ENTER.
Press ENTER to save the PIN.
Note: If you press ENTER without entering the PIN, the fax machine beeps,
indicates “Invalid Number” on the LCD and then returns you to step 4.
Now you may autodial the number as usual.
Important: While in PIN Mode 1, any autodialer numbers you use must include
the PIN. This also applies to autodialer numbers used with
programmable one-touch keys (see pages 2.28–2.35).
If you specified “Mode 2”
In this mode, you do not have to add the PIN to the autodialer setting. Instead, you
enter the PIN manually each time you autodial:
Autodialing while using the PIN mask
Note: The following instructions presume you are familiar with how to set and use
your machine’s autodialer. If you need to review, see pages 2.7–2.13.
Note: If the PIN mask feature is off, you use the autodialer normally.
If you specified “Mode 1”
1
2
2
Passcode
3
:6296
Press ENTER. The LCD shows briefly:
Enter PIN Number
and then it shows:
2.40
and then it shows:
_
:****
Use the numeric keypad to enter the four-digit passcode. Here, we will use
our sample passcode again.
Press START. (If you used a one-touch key, you don’t need to press START.) The
LCD shows briefly:
Enter PIN Number
Use the EasyDial directory to enter a name.
The LCD shows:
Passcode
Enter a speed-dial number.
Here, we have enter speed-dial number 01:
S01_
In this mode, before autodialing a number for the first time, you must add the PIN to
its stored one-touch key or speed-dial number. Here’s how:
1
Use the numeric keypad (including either * or #, if necessary) to enter the
desired PIN, up to eight characters in length.
The machine now asks for the PIN.
3
Use the numeric keypad to enter the PIN.
1057_
4
Press ENTER. Your machine will dial the number.
Beyond the basics
Fax dialing from the numeric keypad while using the PIN mask
Note: If the PIN mask feature is off, dial normally.
Dialing with a handset or on-hook dialing while using the PIN
mask
If you have specified Mode 1 — use “star” power
Note: If the PIN mask feature is off, dial normally.
1
2
Insert the document in the feeder.
Adjust resolution and contrast if necessary.
Enter the fax number, then press the * (“star”) key and enter the PIN.
The PIN always goes last. For example, to dial 19725550911 with a PIN of
“1234”, enter 19725550911*1234:
If you specified Mode 1 and are dialing from the numeric keypad
1
2
19725550911*1234
3
Press START. The PIN disappears from the display, and your machine dials the
desired phone number.
If you specified Mode 2
1
2
Insert the document in the feeder.
Adjust resolution and contrast if necessary.
If you specified Mode 2 and are dialing from the numeric keypad or either
using a one-touch key or speed-dial number
1
2
3
Enter PIN Number
_
4
1234_
5
Press ENTER. Your machine will dial the number.
Press the * (“star”) key. (If you used either a one-touch key or speed-dial number, you don’t need to press * (“star”) key.) The LCD now shows briefly:
and then it shows:
_
Use the numeric keypad to enter the PIN.
Enter the phone number. Use either the numeric keypad, one-touch key or
speed-dial number.
Enter PIN Number
and then it shows:
4
Lift a handset or press MONITOR/CALL to turn on the monitor speaker).
19725550911_
19725550911_
3
Enter the phone number, then press the * (“star”) key and enter the PIN.
The PIN always goes last. For example, to dial 19725550911 with a PIN of
“1234”, enter 19725550911*1234:
19725550911*1234
Enter the fax number.
Press START. The LCD now shows briefly:
Lifting a handset or activating the monitor speaker (by pressing
MONITOR/CALL).
Use the numeric keypad to enter the PIN.
1234_
5
Press ENTER. Your machine will dial the number.
If you specified Mode 1 or Mode 2 and are dialing using either one-touch a key
or speed-dial number
See “Autodialing while using the pin mask,” page 2.40.
2.41
Beyond the basics
Setting for use with a closed network
For maximum communications security, use a closed network. This limits your
machine to faxing to and from only other Muratec fax machines with the proper
passcode.
Important: The passcode you use for closed network operation (and limiting polling
access; see page 2.20) is not the same as the protection passcode.
Once set for a closed network, your machine will disconnect calls coming in from
other machines.
To set your fax machine’s closed network password:
1
2
Decide upon the four-digit closed network passcode (0000–9999) you want to
use. Write it down, and put it in a safe place.
Press PROGRAM, J, 0, 9.
Set Passcode
3
Press ENTER.The LCD shows the current code:
Passcode
:0000
If the setting you see is acceptable, skip to step 5.
If not, go on to step 4.
4
Use the numeric keypad to enter the desired four-digit closed network passcode.
Passcode
5
:5627
Press ENTER to save the setting.
Note: To turn off the closed network passcode and return to normal fax reception,
change the code to 0000 by repeating steps 2–5 and entering 0000 in step 4.
3
Closed Net.: On
4
Press PROGRAM, J, 1, 0.
Your fax machine’s Block Junk Fax feature lets you bar the gates against unauthorized incoming faxes (“junk fax”). Before beginning, first understand how this
feature works, to determine if it’s right for you. There are four possible settings:
• Off — The feature is not activated.
• Mode 1 — Your fax machine checks whether any phone number in your autodialer matches the last four digits of the remote fax’s subscriber ID. If it doesn’t
find a match, your machine disconnects the call.
• Mode 2 — This mode rejects any call from a number whose last four digits match
any number in the blocked numbers list.
• Mode 3 — This rejects both numbers not in the autodialer and numbers that are
in the blocked numbers list. This lets you keep a number on your autodialer yet
still block its incoming calls by putting it in the blocked numbers list.
Before you activate the Block Junk Fax feature, consider:
• Not all fax machine owners enter their phone numbers in their Subscriber IDs. —
With this feature activated, your machine would reject faxes from such machines.
• Access codes can cause confusion. — If an autodialer entry ends with these longdistance or other codes, Block Junk Fax will block out calls from those faxes.
If you decide to activate Block Junk Fax, here’s how:
1
2
If the setting you see is acceptable, skip to step 4.
If not, go on to step 3.
2.42
Press ENTER. The LCD shows your fax’s current setting:
Block Junk:Off
If the setting you see is acceptable, skip to step 4.
If not, go on to step 3.
Press ENTER. The LCD shows your fax’s current setting:
Closed Net.: Off
Press PROGRAM, J, 1, 1.
Block Junk Fax
Closed Network
2
Press ENTER to save the setting.
Setting Block Junk Fax
To set your fax machine to operate in a closed network:
1
To change the setting, press or once or twice until your chosen setting
appears. In this example, we chose On.
3
To change the setting, press or once or twice until the setting you want
appears. In this example, we chose Mode2.
Block Junk:Mode2
Beyond the basics
4
Press ENTER to save the setting.
What you do next depends upon what you selected in step 2 or 3:
• If either Off or Mode1, the machine will return to standby mode.
• If either Mode2 or Mode3, proceed to step 5.
5
The LCD now asks if you want to enter a number:
BlockJunk Dial
11
Clearing a number from the blocked numbers list
To clear a number from the list:
1
If you want to enter or modify a number, press ENTER and proceed to step 6.
Otherwise, press PROGRAM and skip to step 11.
6
Depending on whether you already enter at least one number into the blocked
numbers list, the display shows one of the following:
01:_
8
If you want to modify an existing entry in the blocked numbers list, press
or repeatedly until you see the number you want to modify. Then press
ENTER.
… or …
If you want to enter a new number in an already-started blocked numbers
list, press or repeatedly until you find an empty position in the list.
Then press ENTER.
Use the numeric keypad to enter the last eight characters of a fax number you
want to block. For example, if you want to block a fax from someone with a
Subscriber ID of 972-555-3038, you should enter 5, 5, 5, -, 3, 0, 3, 8:
01:555-3038_
To change only a specific digit of an entry, press to move to the left or to
move to the right until the cursor is under the digit, then use the numeric
keypad to enter the correct digit.
Note: You can store up to 30 blocked numbers.
9
10
Press PROGRAM, J, 1, 1.
Block Junk Fax
2
Press ENTER. The LCD shows your fax’s current setting:
Block Junk
Off
or 01:555-2971
If you have not entered any numbers in the blocked numbers list, skip to step 8.
If not, go on to step 7.
7
If you do want to print the list, press ENTER.
If you do not want to print it, press STOP and your machine will return to its
normal standby mode.
Press ENTER to save the setting. The display will show the next “slot” in the
blocked numbers list.
If you do not want to enter or change a number for this slot, proceed to step 10.
If you do want to enter or change a number for this slot, repeat steps 6–9.
If your Block Junk Fax setting is either Mode2 or Mode3, skip to step 4.
If not, go on to step 3.
3
Press
or
until you see your preference, Mode2 or Mode3.
Block Junk Mode2
4
Press ENTER, ENTER. The display shows:
01:555-2971
If this is the number you want to clear, skip to step 6.
If not, go on to step 5.
5
6
Press
7
Press STOP. The LCD now asks if you want to print the blocked numbers list.
or
repeatedly until you see the number you want to clear.
Press CANCEL to clear the number.
To clear another number from the blocked numbers list, repeat steps 5–6.
If not, go on to step 7.
Print Junk Dial
If you do want to print the list, press ENTER.
If not, press STOP to return your machine to its normal standby mode.
Press STOP. The display now asks if you want to print the list.
Print Junk Dial
2.43
Beyond the basics
Special features
Your fax machine has a number of special features to make your communications easier. We will cover them here.
Toggling the cover page
1
Press PROGRAM, H, 1. The LCD shows:
Set Cover Page
Cover page
Your fax machine can store a cover page to send at the beginning of each outgoing
fax. This page includes the current date and time, your Location ID and your fax
number (as stored in the TTI) and a message of up to 40 characters in length. The
information appears in a box similar to this:
2
Cover Page:
3
Fax Message From:
And Sew It Goes Co.
Fax Number:
972-555-2009
We appreciate your business. Thank you!
Note: If you send to another plain-paper fax machine, that machine will print this
cover page as a full-sized page with the information box at the top, followed
by the actual document you are faxing.
If you send to a thermal-paper fax machine, the size of the bottom margin of
the cover page will vary from one model to the next.
On
Note: If you want to abort the operation so the cover page feature won’t
work, press or again so that “Off” appears. Press STOP.
4
Press ENTER to save the setting.
Now the cover page feature is working but your message line (shown in the example, left, as “We appreciate your business. Thank you!”) is blank. To enter that
message line:
Entering the cover page message
1
Press PROGRAM, H, 2.
Enter Cover Page
2
Press ENTER. The LCD shows briefly:
Cover Page
then it shows:
_ABCDEF >
2.44
Off
To tell the fax machine it should send a cover page before each document you
transmit, press or .
Cover Page:
Sep 27 1999 14:00
Name:
Press ENTER. The LCD shows:
Beyond the basics
3
Use the numeric keypad to enter a message for the cover page. The message
can be up to 40 characters in length. Enter the message the same way you
entered your fax name during EasyStart. Let’s review the process:
On the LCD, you will see the character set currently available, such
as:
_ABCDEF
>
To find a different character,
press 2 or 8 over and over again
to scroll through character sets
until you see the one you want.
If you need to include a space, one
can be found at the beginning and
end of each character set.
When you see the character you want:
• Press either 4 or 6 to move the cursor until it covers the desired character.
• Then press 5 to enter the character and move on to the next entry.
Note: If you make a mistake, just press CANCEL to erase to the left. Then
continue to enter the character(s) you want.
Note: As you enter characters, the LCD will scroll to the left so you can view
entries longer than five characters.
4
When the message is as you want it, press ENTER to save it.
Managing your fax with its journal and reports
Setting the activity journal
Just as a checkbook records your financial transactions, your fax machine keeps an
activity journal which records its 50 most recent fax transactions. The activity journal lists the following information for each fax transaction:
• Assigned number, starting each day at number 1
• Remote location called
• Resolution mode
• Starting date and time
• Duration, in minutes and seconds
• Length, in number of pages
• Result of the call — If preceded by an asterisk (*), this signifies an ECM communication (see page 2.4)
• Any special operations — For example, a fax call made using an handset will
appear as “Manual”
If you want, your fax machine will print the activity journal automatically after
50 transactions. To toggle this automatic printing on or off:
1
Press PROGRAM, G, 1. The LCD shows:
Journal On/Off
2
Press ENTER. The LCD shows the current setting:
Auto Print:
Printing the cover page
Off
If this setting you see is acceptable, skip to step 4.
If not, go on to step 3.
To print a sample cover page from your fax machine. Press PROGRAM, H, 3, ENTER.
3
To change the setting, press
appears. Here, we chose On.
Auto Print:
4
or
once or twice until the mode you want
On
Press ENTER to save the setting.
Printing an activity journal manually
To see an activity journal immediately, just print the journal manually at any time
by pressing PROGRAM, G, 2, ENTER.
2.45
Beyond the basics
Setting the Transmit confirmation reports: TCRs
Your fax machine can print a transmit confirmation report after sending a fax to any
Group 3 fax machine.
What the reports tell you
The TCR gives you the following information for each communication:
• Remote location called
• Resolution mode
• Starting date and time
• Duration, in minutes and seconds
• Length, in number of pages
• Result of the call
• Any special operations — For example, a fax call made using an handset will
appear as “Manual”
• Sample of the document — An image of the first page of the document
If an error occurs, the TCR tells you the remote location called and the error code and
error message (see pages 3.6–3.7).
Press PROGRAM, G, 3. The LCD shows:
Set TCR
2
Press ENTER. The LCD shows the current setting:
TCR
:
Off
Your machine is asking whether it should print the TCR automatically after
every fax you send.
If the print setting you want appears, skip to step 4.
If not, go on to step 3.
3
To toggle the print setting, press or
want appears. Here, we chose On.
TCR
4
2.46
:
On
Press ENTER to save the setting.
If you want to turn the TCR feature on or off for only this fax transmission while
scanning or transmitting the document:
• If you specified transmission from memory, press REPORT while the fax scans
your document into memory.
• If you specified transmission from the feeder, press REPORT while the fax
machine communicates to the other fax machine.
After you’ve sent that one transmission, your machine will return to the setting you
specified in steps 1-4.
OneLine + distinctive ring detection
To set your machine to print these reports:
1
To turn the transmit confirmation report on or off for only the next fax transmission, press REPORT.
What happens next will depend on the setting you made in steps 1-4:
• If you chose ON, and the report light glows:
Pressing the REPORT key will turn off the light and disable the TCR printing for
this transmission.
• If you chose OFF, and the report light does not glow:
Pressing the REPORT key will turn the REPORT light on and activate the TCR printing for this transmission.
once or twice until the setting you
It used to be that, to have two phone numbers, you had to have two phone lines,
along with the expensive phone equipment that goes with it. But many phone companies now offer their customers a special service which makes it possible for one
phone line to do the work of two.
With this service, you physically still have one phone line, but electronically, you
have two phone numbers. Your phone recognizes these different numbers and rings
differently for each one.
For example, this makes it easy for you to have both a business number and a home
number on one phone line, so you can answer one with “Jane Doe Consulting,” and
the other with “Hello.” You get the idea. This works because you can tell the difference between the distinctive patterns of the two rings.
Your fax machine, too, is smart enough to tell the difference between two different
numbers that is ringing it. All you have to do is give it a little help at the beginning
and begin to enjoy the benefits of its OneLine + distinctive ring detection (DRD) feature.
In order to use OneLine + DRD, your phone company must set up your distinctive
ring service. When it does, it will assign a ring pattern, expressed in time. For
example, the standard telephone ring is 2 seconds “on” (ringing) and 4 seconds “off”
(silent), after which it repeats itself (hence the term, ring pattern).
Beyond the basics
Some telephone companies provide only a very general description — for example,
“short-short-long” — of their DRD ring patterns. Fortunately, though, your fax has
eight possible distinctive ring patterns for use with OneLine + DRD. One of them
should work with your phone company’s DRD service. This chart lists the patterns:
Pattern
A
B
C
D
E
F
G
H
I
One complete ring pattern (seconds)
0.8 on, 0.4 off
0.5 on, 0.5 off, 0.5 on, 0.5 off, 1.0 on, 3.0 off
0.5 on, 0.5 off, 1.0 on, 0.5 off, 0.5 on, 3.0 off
0.4 on, 0.6 off, 0.4 on, 4.6 off
1.5 on, 0.5 off, 0.5 on, 3.5 off
2 on, 4 off
1
Contact your phone company and confirm that the phone company has set up
DRD service for you. If possible, also find out which distinctive ring pattern the
phone company has assigned you.
2
Press PROGRAM, J, 1, 8.
Set DRD
Press ENTER. The LCD shows:
If you see the setting you want, skip to step 5.
If not, go on to step 4.
To change the setting, press
appears. Here, we chose On.
DRD:On
If “A” is the pattern you want, skip to step 8.
If not, proceed to step 7.
Press or
here, “C”):
repeatedly until your desired pattern appears (in our example
Ring Pattern: C
8
Press ENTER to set your machine to the displayed ring pattern.
Important: If your telephone company gives you only very general ring pattern
specifications, or if you otherwise encounter a problem while trying to
use your machine’s DRD feature, please try ALL of the listed ring
patterns. (If you still have a problem after trying all of the patterns,
please call the Muratec Customer Support Center. From the United
States, call 972-364-3350; for the number to call from Canada, check
your in-box documentation).
Important: With your machine set for DRD, it won’t respond to any ring pattern
other than the one you selected above. To reset the fax so it will
respond once again to normal rings, repeat steps 2–4. But in step 3,
toggle it to “Off.” Your fax will now respond normally.
Call request
Wondering why your monitor speaker’s activation key is called MONITOR/CALL?
Now, we will explain the CALL part of the name. It may be hard to believe, but you
actually can send or receive a fax message and have a regular phone conversation
on the same call (although, obviously, not at the same time). This is called a call
request. It does not matter whether you are sending the fax or receiving it. You may
fax first and then talk, or talk first and then fax.
Important: For this feature to work, the remote fax machine must have a similar
call-request capability.
DRD:Off
4
6
7
0.3 on, 0.2 off, 1.0 on, 0.2 off, 0.3 on, 4.0 off
1.0 on, 0.5 off, 1.0 on, 3.5 ms off
Press ENTER.
Ring Pattern: A
0.4 on, 0.2 off, 0.4 on, 0.2 off, 0.8 on, 4.0 off
For example: pattern C is 0.3 seconds ringing, 0.2 seconds silent, 1 second ringing,
0.2 seconds silent, 0.3 seconds ringing and 4 seconds silent; then it goes back to the
first 0.3-second ring and starts over.
To use DRD on your fax machine:
3
5
or
once or twice until the mode you want
Faxing/receiving first, then talking
To send or receive a fax first and then talk:
1
2
While your fax machine is sending or receiving the fax, press MONITOR/CALL.
At the remote fax machine, the ringer will ring after that machine receives
each page.
2.47
Beyond the basics
3
If someone answers at the remote fax machine, your fax machine will ring
several times. If so, pick up the handset. In a few seconds, the line will open
and you can begin your conversation.
Talking first, then sending a fax
To talk first and then send a fax:
1
2
3
4
5
When your phone conversation is finished, do not hang up.
Insert the document you want to fax.
Adjust resolution and contrast if necessary.
Tell the person at the other fax machine to press START and to hang up
his/her handset. Don’t hang up your handset yet!
When you hear fax tones, press START and hang up your fax machine’s
optional handset. Your fax machine will send the document.
Talking first, then receiving a fax
To talk first and then receive a fax:
1
2
3
When your phone conversation is finished, do not hang up.
Tell the person at the other fax machine to press START and to hang up
his/her handset. Don’t hang up yours yet!
When you hear fax tones, press START and hang up your machine’s optional
handset. Your machine will receive and print out the document.
Responding to a call request
If someone requests a call from you during a fax communication, you will hear a
long ring after the receiving machine has received each page. To answer the call
request:
1
2
2.48
Lift your machine’s handset, and listen for a few seconds. You may hear a
brief series of fax tones.
Shortly, the line will open and the person at the other end of the line will
answer. You and the other person now can have a normal phone conversation.
Caller-ID
Caller-ID is your local telephone company’s service that allows you to see a display
of the caller’s phone (or fax) number or name before either your fax machine automatically receives the call or you pick up the handset.
If you order the caller-ID service from your local telephone company, the following
information will show on the LCD while your machine is ringing:
• The first 16 characters of the caller’s phone number or name on the LCD —
If both the caller’s phone number and name are received, only the name will
appear on the LCD.
. . . or . . .
• “Private”, meaning that the caller intentionally blocked the transmission of
his/her ID.
. . . or . . .
• “Out Of Area”, meaning that the call came from outside your caller-ID service
area.
Note: Your fax machine cannot receive the caller-ID in the following cases:
• While either the fax machine is communicating or you are making a telephone call.
• The number of rings is set to one ring.
Please set the number of rings to two or more rings to receive the caller-ID.
• The line condition is poor.
Note: For more information about caller-ID service, please contact your local telephone company.
Caller -ID directory dialing
Your fax machine saves the 10 most recent incoming caller-IDs. When the 11th call
is received the oldest caller-ID will be erased automatically.
Note: To use the caller-ID directory, at least one caller-ID must be received.
1
If you want to use the caller-ID directory to make a regular phone call, make
sure there is no document in the feeder and then skip to step 3.
If you want to use the caller-ID directory to send a fax, insert the document.
2
3
Adjust resolution and contrast if necessary.
Press SPEED DIAL/TEL INDEX twice. The LCD shows the latest caller-ID.
Note: If your machine doesn’t have any caller-IDs stored, it will show the
EasyDial directory (see page 2.13) on the LCD.
Beyond the basics
4
Scroll through the listings to find the one you want. You do this by pressing
SPEED DIAL/TEL INDEX.
Note: Do not press 2, 4, 6 or 8 on the numeric keypad. If you press 2, 4, 6 or
8, the fax machine will change to the EasyDial directory.
5
When the LCD is showing the caller-ID you want to dial, press START.
• If there is a document in the feeder, your machine will dial a fax call to the
selected number.
• If there isn’t a document in the feeder, your machine will activate the
monitor speaker and dial a regular phone call. At this point, you may
either.
— Lift the handset
or
— Listen to the monitor speaker until you hear the other person answer,
and then lift the handset.
Printing the caller-ID List
You can print a list of the caller-IDs for the 10 most recent receptions.
The list includes the caller’s name (if any), phone number and reception time.
To print the caller-ID list, press PROGRAM, J, 2, 0, ENTER.
2.49
Beyond the basics
PC-FAX feature: fax/computer connectivity
Thanks to its PC-FAX feature, your fax machine is not only a fax machine — it also
can be an image scanner, and allows you to send and receive fax messages from
within your favorite PC-based software applications.
PC-FAX feature requirements for your computer
To use the PC-FAX feature with your computer, you must have properly installed fax
software on your computer.
Note: If there is no fax software installed on your computer, this feature serves no
function. So, until you do install such software, you can skip making the
RS-232C settings (see right column).
We have tested this interface with the following software:
• BitWare Ver. 3.30
• BitWare Plus Ver. 4.0
• HydraFax Ver. 3.5 (34) [U.S. and Canada]
• LaserFax Ver. 3.5 [Except North America]
• WinFax PRO Ver. 4 for Windows 3.1 and Ver. 7 for Windows 95
Making the PC-FAX connection
To set up your fax machine for using PC-FAX feature.
1
2
3
Turn off your fax machine by unplugging its power cord.
Connect one end of the RS-232C cable to the RS-232C interface port on your fax
machine.
Note: Use the appropriate RS-232C cable for your machine. If you do not
know which cable you use, please contact your authorized Muratec
dealer or Muratec Customer Support Center (from the United States,
call 972-364-3350. For the number to call from Canada, check your inbox documentation).
Connect the other end of the RS-232C cable to your computer’s RS-232C port.
Note: If you do not know where your computer’s port is, check the computer’s operating instructions. Consult your fax software for specific
instructions for settings, if necessary.
Important: While this feature works with variety of Class 1-compatible fax software package, it does not work with every fax software package. If you
experience trouble, try the following (in this order):
• Please confirm that you are following the directions beginning in
the next column. Give it several more tries, strictly following our
instructions.
• If you still have trouble, please contact your fax software package’s
maker.
• If the advice from your fax software manufacturer doesn’t help,
then the PC-FAX feature may not work with your computer system.
Bitware is a trademark of Cheyenne Software, Inc., a division of Computer Associates International, Inc.
WinFax is a trademark of Symantec Corporation.
Windows and Windows 95 are registered trademarks of Microsoft Corporation.
HydraFax is a trademark of Wordcraft International Ltd.
2.50
Ferrite core
Note: If your RS-232C cable does not have a ferrite core already fitted, attach the
ferrite core included in your fax machine’s carton box (see page 1.2.)
Beyond the basics
Creating the RS-232C settings
Scanning from your fax to your computer
Note: If you choose the wrong RS-232C parameters, your fax machine cannot communicate your computer.
You can store logos, signatures, line art or even photographs onto your computer by
using the fax machine to scan to your computer:
1
Press PROGRAM, L, 2,
Set RS232C
2
Press ENTER. The LCD shows the fax’s RS-232C transmission speed (baud rate)
in bps (bits per second):
Speed : Variable
Note: This setting is just for the RS-232C port. It does not change the speed
at which your machine sends faxes.
3
If necessary, press or to choose the appropriate baud rate for your computer and software.
The settings are: Variable, or 600, 1200, 2400, 4800, 9600 or 19200 bps.
When you see your desired setting, press ENTER.
Note: If using any of the Muratec-tested packages other than either
HydraFax or LaserFax, select Variable.
4
The LCD shows:
Parity
:None
If necessary, press
and press ENTER.
5
or
to choose the data parity — None, Odd, or Even —
The LCD will show:
Stop Bit : 1bit
Your fax software now will “receive” the fax onto your computer.
To cancel scanning in progress, just press STOP.
(To cancel the command after scanning the document, consult your software’s
operating instructions.)
Printing from your computer to your fax
With the RS-232C interface installed, you can now team your fax machine with your
personal computer for direct printing of letters, graphics and other business correspondence from your computer’s hard disk drive:
1 Make sure your fax is connected to your computer.
your application — for example, a word-processing pro2 Computer: Use
gram — to send the document to your fax software, just as if
3
Fax machine: Make sure that you have stored your subscriber ID (your fax
number) on your machine.
Note: See pages 1.12–1.14, for more on how to enter the subscriber ID.
4
5
Computer:
When the fax software asks for the fax number to which you
are sending the document, enter your subscriber ID.
Computer:
Instruct your fax software to transmit. The fax machine will
begin to print.
The LCD shows:
Data Length:7bit
If necessary, press
7
PC-FAX Scan
you were actually going to fax the document.
If necessary, press or to toggle the stop bit between 1 bit or 2 bit.
When you see your desired setting, press ENTER.
6
1 Make sure your fax is connected to your computer.
the document. Adjust resolution and contrast if neces2 Fax machine: Insert
sary.
your fax software to receive. If necessary, consult your
3 Computer: Instruct
fax software’s instructions.
4 Fax machine: Press PROGRAM, L, 1, ENTER.
or
to toggle the data length between 7 bit or 8 bit.
When you see the setting you want, press enter.
** Complete **
Now you are set to scan, transmit, receive and print!
2.51
Beyond the basics
Sending/receiving faxes with your computer
“AT” commands
You can receive documents from another fax onto your computer, as well as transmit documents from your computer to other faxes. As with scanning, the exact
procedure for sending/receiving will vary depending upon how your computer’s fax
software works.
Note: This is a list of standard “AT” modem commands. For more information,
please consult your fax software’s instructions.
Note: Please consult your software’s operating instructions for more details.
1 Make sure your fax is connected to your computer (see page 2.50).
your fax software allows it, turn off Error Correction Mode
2 Computer: If(ECM
).
your fax software to send or receive.
3 Computer: Instruct
The fax machine will begin either transmitting or receiving.
Command Parameter Description
A
D
E
H
RS-232C interface cable
M
PIN assignment
Pin No. Signal code Signal name
1
RXD
Received data
Contents
The data sent to computer by your fax.
2
TXD
Transmitted data Data signal sent from computer to your fax.
3
CTS
Clear to send
Data Enable signal for data transmission
from your fax to your computer.
4
SG
Signal ground
Ground for signal.
5
RTS
Request to send
Signal for request to send data.
6
DTR
DTE
ready
Data Terminal Enable — ready to
communicate.
Signal direction
Your fax side:
Your computer side:
MINI DIN 6 pin
DB-9 pin
1 RxD
2 TxD
3 CTS
4 S.G.
5 RTS
6 DTR
1 N.C.
2 RxD
3 TxD
4 DTR
5 S.G.
6 DSR
7 RTS
8 CTS
9 N.C.
Note: Use the appropriate RS-232C cable for your machine. If you do not
know which cable you use, please contact your authorized Muratec
dealer.
2.52
none
0-9, *, #
P
T
,
0
1
0
1
0
1
+FRM=n
2
none
none
0
1
none
none
1
2
none
none
none
none
none
none
none
+FRS=n
+FTH=n
+FTM=n
none
none
none
+FTS=n
none
P
T
V
Z
&F
\Q
+FCLASS?
+FCLASS=?
+FCLASS=n
+FRH=n
+FLO=n
Call answer
Dial number
Pulse dial
Tone dial
Pause
Not echo command character
Echo command character
On Hook (Disconnect line)
Off Hook (Connect line)
Monitor speaker is always off
Monitor speaker is on until carrier is
detected
Monitor speaker is always on
Set pulse dial mode
Set tone dial mode
Short formed response code
Long formed response code
Reset modem
Initialize to factory setting
XON/XOFF flow control
RS/CS flow control
Indicate current service class
Indicate service class capability
Set service class
Receive HDLC frame (n=3:300bps)
XON/XOFF flow control (n=1)
RS/CS flow control (n=2)
Facsimile receive message
(14400/12000/9600/7200/4800/2400bps)
Detect silence for n × 10ms
Transmit HDLC frame (n=3:300bps)
Facsimile transmit message
(14400/12000/9600/7200/4800/2400bps)
Wait for n × 10ms
Default value
E0
M1
V1
\Q2
+FLO=2
Just in case …
Just in case …
Tips on how
to care for
your machine.
and suggestions
to follow
in case of trouble.
Also, a Glossary
explains fax terms.
Just in case …
What’s inside this section
Clearing paper jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2
Solving communications problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4
Caring for your fax machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.8
Common questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.11
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.14
We’re online to help you!
Before you try calling for help, first give the Muratec Information System a
try.
The Muratec Information System is available to you 24 hours a day, 7 days
a week. You can use your fax machine to call this “fax-on-demand” system
and receive printouts of information, such as the most common questions
asked about your machine. Often, this is the fastest way to find out the
answer to any question you may have. And it’s a free call!
To use the Muratec Information System:
1
2
3
On your fax machine, obtain a dial tone by pressing MONITOR/CALL.
Call 1-800-215-1698.
Follow the system’s voice instructions.
3.1
Just in case …
Clearing paper jams
We designed your fax machine to work reliably for years. However, you may occasionally experience a paper jam. Here’s what to do.
If a printout jams
To clear a printout jammed at the paper cassette:
If an original document jams
1
Open the control panel by placing your fingers on its upper left
and right corners and gently tilting the cover toward you. This
will release the original document.
Note: Open the control panel
until it stops.
2
Lift the original document from
your fax machine.
3
Gently close the control panel, making sure both sides are snapped down
securely. Then try the transmission again.
Note: If the original document has become wrinkled or torn, do not re-send
it.
1
Pull forward on the
paper cassette to slide it out.
2
Remove the jammed paper carefully by pulling it out.
To clear a printout jammed inside your fax machine:
1
3.2
Open your fax machine’s top
cover by pressing the top cover
release button.
Just in case …
2
Remove the ink film cartridge by
grabbing the handles on each
side of the cartridge and lifting
it straight up out of the
machine.
Note: The diagram (right)
shows a view from the
left side of the machine.
3
Gently pull the jammed printout
up and out.
4
Hold the cartridge over your fax
machine. Position the cartridge so
that its arrow mark is over the
machine’s arrow mark. (The supply
roll should be in the front of the
machine.)
5
Gently put the cartridge back into
the fax machine. If positioned correctly, it will “drop” in smoothly.
6
Gently close the top cover, pressing
firmly on both sides of it until you
hear it click.
Important: Your fax machine will
not work if the top
cover is not closed
properly.
Important: Your fax machine will
not work if the cartridge is not inserted
properly.
3.3
Just in case …
Solving communications problems
Occasionally during transmissions, your fax machine will encounter trouble in
transmission or reception. If it does, its alarm will sound. You can identify the problem with LCD messages, printed check messages and error reports.
What you see on the LCD
Comm. Error
Your fax machine will sound an alarm — a series of short beeps — if either of these
two problems occurs:
• It has trouble transmitting or receiving.
• It runs out of paper or ink film.
A communication error disrupted reception or
transmission. If you were transmitting, press
STOP to clear the error message and then try the
transmission again. If you were receiving a fax,
try to contact the other person and have him/her
try the transmission again.
Enter No.(0-32)
You entered an incorrect call group for relay
broadcast initiation. Your machine can maintain 32 call groups, numbered 1-32 (call group 0
covers all the groups.) Determine the correct call
group and re-enter its identifier number.
LCD error messages
Enter No.(1-99)
You requested “0” copies from your fax. You
must select from 1-99 copies of a document.
Select the correct quantity and re-enter it.
You tried to enter the same number that is
already stored in the block junk dial list.
Hang Up Phone
You tried to erase an F-code box which still has
documents in it. You must first clear the F-CODE
box by printing its documents (see page 2.25).
The handset is off the hook.
Hang it up, making sure the upper part of the
handset presses down on the “hook” button.
Insert Document
There was no document in the document feeder
when you tried to send a fax or make a copy.
Place a document in the feeder and try again.
Invalid I.D Code
The F-code box passcode you entered is not
valid. Try re-entering your F-code box passcode.
Invalid Number
You pressed a key which has no function during
the current operation.
Invalid Passcode
The protection passcode you entered is not valid.
Repeat the operation, entering the correct passcode.What you see on the LCD What it
means/What to do
Line Busy
You tried to use the PC-FAX scanning feature (see
page 2.51) when the machine is transmitting or
receiving a fax.
Wait until the machine completes the fax communication.
Alarm
What you see on the LCD
Already Stored
Box In Use
Check Ink Film
Check Rx Paper
3.4
What it means/What to do
What it means/What to do
Your fax machine is out of Film Imaging ink.
Change the ink film roll (see pages 1.9–1.10).
Your machine is out of paper.
Add paper to the paper cassette.
. . . or . . .
The paper cassette is not properly installed.
Slide the paper cassette into its closed position.
You will feel a click when it’s properly in place.
Close Cover
The top cover is open.
Close it.
Commands Full
Your fax machine has all of its 30 possible
delayed commands stored in memory and cannot accept another. Delete an existing command
by using REVIEW COMMANDS, or wait until your
fax has completed one of the delayed commands.
Just in case …
What you see on the LCD
What it means/What to do
Memory Full
You tried to scan the document into the memory
but the machine doesn’t have enough available
memory to complete the operation.
If the fax received documents in the memory,
print them to clear space.
Memory Over Flow
During transmission (or copying), you entered
more pages into memory than your fax could store.
Press START (or COPY) to tell your fax to keep as many
pages in memory as possible, or press CANCEL to
delete from memory all pages stored during this
operation (but not previous operations).
No Command
You pressed REVIEW COMMANDS to review upcoming commands, but your fax machine doesn’t have
any stored.
No Doc. Stored
You tried to print a document from memory, but
your fax machine doesn’t have any stored.
No Number
You selected an autodialer number that doesn’t
have a number assigned to it.
Either choose another autodialer number or dial
a phone number directly from the numeric keypad.
No Passcode
No PIN Number
What you see on the LCD
What it means/What to do
Polling In Use
You tried to store a polling document in your
fax, where one has already been stored.
Wait for the fax to complete the polling operation, then try again.
Printer In Use
The command you entered requires the use of
the printer, which is already in use. Wait for the
fax to finish printing, then try again.
Protect Doc Stor
A received document was in your fax’s memory
when you tried to turn off security reception or
erase the protection passcode.
Print the received document from your fax’s
memory, then try the desired operation again.
Remove Paper
A paper jam has occurred.
Remove the jammed paper (review pages 3.2–3.3
if necessary).
Reset Document
Your document was not inserted correctly, or
the fax to which you are sending cannot handle
the document’s page length.
Reset the page and try again.
Scanner In Use
You tried to protect an operation but there isn’t
protection passcode stored in your fax machine.
Store a protection passcode in your machine,
then try protecting the operation again.
The command you are entering requires the use
of the scanner, which is already in use. Wait for
the fax to complete the scan, then try again.
Sub-Addr. In Use
You selected “Mode1” in the PIN mask feature
and tried to use an autodialer number in which
no PIN has been entered.
Enter a PIN for that number, then try again.
You entered a sub-address number already
being used by another F-code box.
Enter a different number for your F-code box’s
subaddress.
Too Many Digits
You attempted to enter too many numbers or
characters for the current operation.
Press CANCEL to delete the extra characters, then
try again. You may want to review the operation’s instructions.What you see on the LCD
What it means/What to do
Too Many Loc.
You tried to enter too many group numbers for a
relay broadcast initiation. You can enter up to
10 group numbers.
Press CANCEL to delete the extra group numbers
and try again.
No Report
You requested an activity journal or confirmation report, but your machine has no record that
any fax jobs have occurred.
PC-FAX In Use
You tried to either transmit, copy or print the
document while the PC-FAX feature is busy.
Wait until the PC-FAX feature completes a job,
then try again.
Please Wait
Your machine’s thermal print head becomes
very hot.
Please wait a moment until the head cools down.
3.5
Just in case …
Errors
Specific errors
Your machine occasionally experiences communications errors, which may be caused
by anything from lightning to telephone line interference. The fax machine at the
other end of the line can also cause communication errors.
Trying your call may be all that’s necessary. However, if the problem persists regularly, call your local telephone company for help. If that call does not help and the
problem persists regularly, call your authorized Muratec dealer.
Some of the error codes you may see on an error report:
Error reports
D.0.2
When an error occurs, your fax machine prints an error report. Each fax error
report lists an error message which includes:
• A possible solution to the problem
• The sending location (if the remote fax stores a Location ID of its own)
• The result — which is a special error code.
• A sample of the document’s first page.
D.0.6, D.0.7 Either the remote fax unit did not respond, the call did not go through
or someone pressed STOP while the calling fax machine was dialing.
Call again.
Kinds of error codes
The error code listed in the “Result” column of the error report indicates the specific
problem encountered:
• “D” codes — Occur while dialing
• “R” codes — Occur during reception
• “T” codes — Occur during transmission
3.6
Dialing errors
D.0.3, D.0.8
The remote unit did not respond, the call could not be completed or
STOP was pressed while the unit was dialing.
Try the call again. If your machine repeats the message, call the
remote fax user to verify that the unit is operating properly.
The remote fax machine is busy. Call again.
Reception errors
R.1.1
The calling fax machine did not respond to your fax machine. This can
happen if someone dials a wrong number or if the remote machine
restricts access through use of a passcode.
R.1.2
The two fax machines were incompatible. Your fax machine sends and
receives only ITU-T Group 3 fax communication, the industry standard
since the early 1980s.
R.1.4
Someone pressed STOP at the receiving fax machine.
R.2.3
Poor phone line conditions made fax communication impossible.
Call someone at the remote machine.
R.3.1
The sending fax machine detected too many errors from the receiving
fax machine.
R.3.3
The sending fax machine is incompatible or had a document feeder
problem during transmission.
R.3.4
Poor phone line conditions may have prevented your fax machine
from properly printing some or all of the pages it received.
R.4.2
Either the line disconnected before transmission or the transmitting
fax machine needs maintenance.
R.4.4
The fax machine has reached its memory capacity.
R.5.1, R.5.2
ECM
reception failed.
Just in case …
Transmission errors
“Check Message” printouts
T.1.1
The remote fax machine did not respond to your machine.
Call someone at the remote machine.
T.1.4
Someone pressed STOP at the remote unit in the middle of the handshake (the very first part of the fax communication, when the two
units “agree” on the settings they will share).
T.2.1
Either the phone line disconnected during transmission or fax communication became impossible due to bad phone line conditions.
Re-try the call.
When your machine detects an error on a fax call, it produces an error printout
headed by the words “Check Message.” This printout lists the following information
about the transmission:
• The resulting error code
• A communications error message (see “What error messages can mean,” below)
• The phone number of the fax machine with which your machine had attempted
to communicate
T.2.2
The two fax machines were incompatible. Your fax machine sends and
receives only ITU-T Group 3 fax communication, the industry standard
since the early 1980s.
T.2.3
Bad phone line conditions made fax communication impossible.
Conditions can change rapidly, so try the call again later.
T.3.1
What error messages can mean
The error messages on Check Message printouts can mean a variety of things.
Here is a brief summary:
Error message
Possible meanings
During transmission, your machine’s bult-in page counter detected a
possible error in the document feeder.
Carefully put the document back into the feeder and try the call again.
Check condition of
remote fax.
• Remote machine malfunctioned
• No “handshake” signals from remote fax
• Wrong phone number reached
T.4.1
The telephone line disconnected during the transmission of a page
because of excessive modem errors or because the remote unit ran out
of paper. Try the call again.
Repeat transmission.
T.4.2
After transmission began, poor line conditions developed.
Try the call again.
• Poor phone line conditions
• No “handshake” signals from remote fax
• Document misfeed or miscount
• Unable to reach remote machine after
attempting specified number of redial tries
T.4.4
Poor line conditions prevented transmission.
Try the call again.
Line is busy.
• Remote machine’s line was busy
• Remote machine’s line did not answer
T.5.1, T.5.2
T.5.3
transmission failed.
Conditions can change rapidly, so Try the call again later.
Check received documents
• Remote confirmation signal not received
from remote fax
• Poor line conditions caused a poor image
Memory full.
• Remote fax’s memory capacity exceeded
Dialing number is not set.
• Stored phone number failed to dial properly
Stopped.
• Someone pressed STOP at the remote fax
in the middle of the “handshake”
ECM
3.7
Just in case …
Caring for your fax machine
With proper installation and a little maintenance, your fax machine should give you
dependable service for years to come.
Follow these suggestions to keep it in top form:
• Always make sure your fax machine is installed according to our specifications,
including using an electrical surge suppressor. (If necessary, review “Pick an
installation spot before going ahead,” page 1.6.)
• Always use good, copier-quality paper.
• Always clean your fax machine as needed (see “Cleaning tips,” below).
• Never install your fax machine where it can overheat, gather dust or get
splashed by any liquids (even water).
Cleaning tips
Some things to keep in mind about cleaning your fax machine:
• Do clean it! Dust and dirt, especially around the fax machine’s air vents (see
right column) can shorten your machine’s life.
• Always unplug the fax machine before you clean it.
• Never spray any cleaner DIRECTLY onto your fax machine. The drifting
spray could damage components inside.
• Never try to clean SEALED areas inside your fax machine. This will protect
your safety and the safety of the machine.
• For cleaning external surfaces, such as the cover and handset, use a mild
cleaning solution sprayed onto a lint-free towel or cloth.
• Always use a lint-free cloth (or swabs) moistened with alcohol to gently wipe
components inside your machine.
• In areas you cannot reach with swabs, always use dry, dust-free compressed air
to gently blow away dust and other material.
3.8
Keep the air vents clean
Never cover your machine, or it may overheat.
Clean your machine’s air vents periodically. When you do, use a vacuum
cleaner or brush. (Do not wipe the air vents with a damp cloth!)
The air vents are located on the machine’s upper rear and lower rear sections:
Air Vents
Just in case …
Corrective cleaning
Curing frequent jams in the document feeder
Here are some simple cleaning procedures for keeping your fax machine clean and
operating smoothly.
Before you clean your fax machine, print all document received in the memory.
If you are having trouble getting your original documents to feed properly, try this:
1
Get two soft, lint-free cloths and moisten them as follows:
• One with a cleaner suitable for use on rubber rollers
• The other with isopropyl alcohol
Unplug the power cord of your machine from the power source.
2
Unplug the power cord of your machine from the power source.
Remove the document hopper, if necessary.
Moisten a soft cloth with water and a small amount of diluted mild detergent.
3
Open the control panel by placing your fingers on its upper left and right corners and gently tilting the control panel toward you until it stops.
4
Use the cloth with the rollers
cleaner to clean the face of the
rollers and separator pad.
Rotate the rollers by hand to
allow cleaning of the entire
roller surface.
5
Use the cloth with the isopropyl alcohol to clean the
contact glass.
6
7
Gently close the control panel, making sure both sides are snapped down
securely.
Cleaning your fax machine
1
2
Important: To prevent damage to the surface of your fax machine, never use thinner, benzene, alcohol, acetone, or any other organic solvent to clean
your machine.
Plug the power cord of your fax machine at the power source.
Attach the document hopper if you removed it in step 2.
3.9
Just in case …
Fixing unsatisfactory printout quality
If you notice poor printout quality (whether on received faxes or on copies), here’s
what to do:
1
2
Unplug the power cord of your machine from the power source.
3
Open the top cover and lift the ink film cartridge straight up out of the
machine.
4
Use the cloth with the isopropyl alcohol to clean the
thermal print head.
Get two soft, lint-free cloths and moisten them as follows:
• One with a cleaner suitable for use on platen/rubber rollers
• The other with isopropyl alcohol
Thermal print head
Important: Do not touch the
thermal print
head directly
with your hand.
5
Use the cloth with platen/rubber roller cleaner to clean the
face of the rollers. Rotate the
rollers by hand to allow cleaning of the entire roller surface.
Platen roller
6
Hold the cartridge over your
fax machine. Position the cartridge so that its arrow mark
are over the machine’s arrow
mark. (The side with the supply roll should be over the
front of the machine.)
7
Gently put the cartridge back into the fax machine. If you have positioned it
correctly (see step 6), it will “drop” in smoothly.
Important: Your fax machine will not work if the cartridge is not inserted
properly.
8
Gently close the top cover, pressing firmly on both sides of the top cover until
you hear it click.
Important: Your fax machine will not work if the top cover is not closed.
3.10
Just in case …
Common questions
We’re online to help you!
Before you try calling for help, first please give the Muratec Information
System a try.
The Muratec Information System is available to you 24 hours a day, 7 days
a week. You can use your fax machine to call this “fax-on-demand” system
and receive printouts of information, such as the most common questions
asked about your machine. Often, this is the fastest way to find out the
answer to any question you may have. And it’s a free call!
To use the Muratec Information System:
1
2
3
On your fax machine, obtain a dial tone by pressing MONITOR/CALL.
Call 1-800-215-1698.
Follow the system’s voice instructions.
General questions
Q: Where do I add ink or toner to make my fax machine’s printouts darker?
A: Your fax machine dose not use ink or toner. Instead, it uses a special printing
technique called Film Imaging, also known as thermal-transfer printing. To
adjust the darkness of copies or transmissions, insert a document and press
CONTRAST repeatedly to adjust the contrast setting. “Dark” prints as the darkest setting. The machine will reset automatically to normal contrast after the
copying or sending.
Note: You can’t adjust the darkness of an incoming fax printout.
Q: When I unplug my machine or if the power goes off, will I lose the information
I have stored — such as my TTI, autodialer entries, the time and date, etc. —
and have to re-enter them?
A: No. Your machine has two special backup batteries.
One protects user settings for several days if power fails or if your machine is
disconnected from the power source. The second battery is rechargeable and
preserves data in the memory for up to 72 hours in case of a power loss This
battery requires about 1 day to reach full charge after power to the machine is
restored.
We advise you to restore power to the machine as soon as possible.
Q: Can I use a dust cover on my fax machine?
A: No! A dust cover blocks air circulation, which could cause your machine to
overheat. (See page 1.6 for other guidelines.)
Q: Can I re-use the ink film when I run out of it?
A: Yes, but only for an emergency. The quality of the printouts will be lowered,
because previous printouts will have used parts of the roll. Always try to have
at least one replacement roll of ink film, so as to avoid this situation.
Sending faxes
Q: Sometimes, I try to send a fax while using either the handset or the
MONITOR/CALL feature. But, when the other side answers, I hear a horrible
screeching sound, so I hang up. What’s happening?
A: That was the other fax machine trying to say “Hello” to your machine. You will
hear sounds like that any time you call a fax machine which is set to answer
automatically (as when you set your machine to Fax Ready mode). It’s by using
these tones that machines send faxes over ordinary phone lines. So, next time
you hear such tones, press START (and, if you are using the handset, hang up)
to send a fax.
Q: I just sent a fax. However, the number that appeared in my machine’s display
during the transmission was not the number I dialed. Why?
A: That number you saw is programmed into the remote fax machine by the user.
Some users prefer different numbers to appear than the ones they are really
using. And some people take over another person’s fax machines that has
already been programmed and don’t know how to change the original number.
Q: Can I transmit and receive at the same time?
A: No. Use the call request feature (see pages 2.47–2.48) to ask the person at the
remote fax machine if he or she wants to transmit or receive after your fax
communication is complete.
3.11
Just in case …
Q: Do I have to dial a 1 for a long-distance call?
A: Yes. Dialing a fax number is just like dialing any other phone number, so be
sure to include any special long-distance codes or dialing pauses when dialing.
Also, remember to include them when you set your autodialer numbers.
Q: How do I send a fax to an overseas telephone number?
A: Dialing requirements for international calls may vary depending on your local
telephone company’s requirements. For most international calls, call 00, then
the appropriate country code, city code and phone number. (You may find country and city codes in the front section of your telephone directory.)
Q: Can I transmit if my fax machine runs out of paper?
A: Yes. But a transmit confirmation report (see page 2.46) is not available when
you transmit without recording paper in your fax machine.
Q: Can I transmit a document that’s extra long?
A: Yes, if the receiving fax machine is equipped to handle long documents. Many
machines have a special setting which allows them to receive documents that
exceed the normal length.
Q: Can I transmit a page from a newspaper?
A: No. A newspaper page can jam in your document feeder. First, use a copy
machine to make a copy of the newspaper. Make sure the copy you make will
fit into the fax machine. Then transmit the copy.
Q: Can I transmit a page with correction fluid on it?
A: Yes, if the fluid is completely dry before you begin transmission.
Q: How can I be sure my fax was received?
A: Set your machine to print a confirmation report after each transmission (see
page 2.46).
Q: I don’t want to install a dedicated phone line for my fax machine, so I have connected the machine to a PBX phone system. When I get a fax call, all the phones
ring! How do I prevent this?
A: Call your PABX manufacturer or telephone company for assistance. Either may
be able to convert one of the PBX lines for use only by your fax machine.
Q: Sometimes when I dial a fax call by using either the handset or MONITOR/CALL,
I don’t hear the fax receiving tones from the other machine. Am I doing something wrong?
A: When this happens, try pressing START (and then hanging up the handset if
you are using it), as usual. It’s possible you are calling an older, non-standard
fax machine that doesn’t emit answering tones. Even a few Group 3 faxes (see
3.12
“Glossary,” page 3.15) on the market sound a sending tone but don’t sound a
receiving tone. After you transmit, call the person at the other fax machine to
see if he/she got your document.
Q: I inserted a document in the feeder and dialed a fax number, but my machine
did not transmit the document; instead, “* Auto Redial *” now appears on
my LCD. What does this mean?
A: The remote fax machine was busy, so your machine will try the call again,
automatically. As long as it hasn’t stored more than 30 delayed commands, your
machine should still accept commands from you. If it has exceeded this quantity
and will accept no more commands, try canceling one of the delayed commands
(see page 2.15). If the machine still won’t cooperate, keep canceling commands
until it does.
Q: The specifications (page AI.1) list an average per-page transmission time, but
when I transmit a page it can take much longer. Why?
A: We base this specification on transmission of an industry-standard test document called ITU-T Test Document 1 (sometimes also called the “Slerexe letter”).
Fax manufacturers use this method to test transmission speeds. However:
• The pages you send may be darker, or otherwise contain more information,
than ITU-T Test Document 1.
• The transmission time measured for test documents doesn’t include handshake time — the time during which two fax machines “introduce”
themselves to each other and “agree on” the parameters of the call.
• The specification time is based on the use of normal resolution mode. You
may be using fine, superfine or grayscale transmission, each of which takes
longer than normal mode.
Reports
Q: I called the number 00-555-555-1212, but not all of the digits appear on my
transmit confirmation report (TCR). Why didn’t the whole number appear? How
can I be sure my document went to the right location?
A: The numbers you enter using the fax keypad are temporarily stored in a memory “buffer.” It’s only the last part of the phone number that the buffer
“remembers.” An easy way to avoid getting incomplete telephone numbers on
your printouts is to store your most frequently used numbers as one-touch keys
or speed-dial numbers. These autodialer numbers will appear in their entirety
on your TCR.
Just in case …
Receiving faxes
Q: My fax never answers. What’s wrong?
A: Check to make sure your fax machine is properly connected to a working AC
power outlet and phone jack (see page 1.8). If you are using a second phone
with your machine, make sure it’s connected properly (page 1.11).
Q: Sometimes when I answer my machine with the handset, I hear a beeping
sound that repeats every few seconds. Is this a fax?
A: Yes. When you hear such fax tones, someone is trying to send you a fax. Next
time, press START and hang up the handset. Your fax will receive the message.
Q: Does my fax machine have to be plugged in to a power source just to receive a
message?
A: Yes. You can’t receive a fax unless your fax machine is plugged into both the
phone jack and the AC power jack. Make sure your fax machine is always
plugged in so you never miss an important fax message.
Q: Can I receive a fax if I’m using the phone on my machine?
A: You can receive a fax from the person to whom you are talking. When that person has a document ready in his/her machine’s feeder, press START. However,
like any regular one-line phone, your fax machine can handle only one call at a
time.
Polling
Q: What’s the purpose of polling?
A: Polling lets you automatically “pull” a document from another fax machine.
You can poll whenever you need to retrieve information and don’t want the
source to pay for the phone call. With polling, you pay for the call and get the
information you need.
Working with your answering machine
Q: People have complained that they call my fax machine and hear my answering
machine’s message, but are cut off before they can send a fax.
A: Any remote fax machine attempting to send a fax must “hear” responding fax
tones within 40 seconds of the person at that machine pressing the start key.
That 40 seconds includes getting the dial tone, dialing the number, “listening”
to the pause before the ringing starts and the remote fax machine answering
the ring. Only after that time does your message play
That’s why we urge you to make a short outgoing message. The shorter the
overall waiting period, the more likely it is that the remote fax machine will
proceed with the transmission. Please make an outgoing message that is no
longer than 10 seconds (see page 1.23 for a suggestion).
How your fax machine works
The concept of how a fax machine works is simple. Here’s a simple analogy. Let’s
say you want to mail a gift to a friend:
• You take the item, wrap it and send it.
• Days later, your friend receives the package, unwraps it and uses it.
Now, let’s apply that to fax communication.
You put a page into your fax machine’s feeder and call a fax number. Your machine
makes a connection with the other machine, and then …
• An image scanner in your fax machine examines the information on the page.
That’s how your machine takes the document.
• Your fax machine translates the scanned information into a numeric code and
compresses the code for the fastest possible transmission speed.
That’s how your machine wraps the document.
• Finally, your fax machine sends the compressed code.
That’s how your machine sends the document.
On the other end of the line …
• The remote fax machine receives the code.
• The remote fax machine uncompresses and deciphers the code, turning it into a
representation of the scan your machine made.
That’s how your machine unwraps the document.
• The remote fax machine prints the representation.
Now, the recipient can use the document.
… and that’s how fax works!
The only difference between a regular telephone call and a fax call is the content of
the transmission:
• On a regular call, your telephone sends your voice.
• On a fax call, your fax machine sends a coded image.
If your fax machine is in T/F Ready mode and you have other telephone extensions
on the same line, all the other phones will ring. In fact, there is no way to tell if an
incoming call is from a fax machine or from a person until you answer, or your fax
machine answers. You will know it’s a fax call if, upon answering, you hear a beeping sound that repeats every few seconds. This sound is each fax machine’s way of
identifying itself to a machine it calls. It’s much like tour making a voice call and
3.13
Just in case …
identifying yourself, “Hello, this is [your name].” When you press START, your fax
machine responds to these signals using other special tones (to us humans, they
sound a bit like screeches) which are its way of responding to the other machine’s
“greeting.” This communication is called handshaking.
The way fax machines work is regulated closely by international standards applied
by the International Telecommunications Union (ITU), an agency of the United
Nations. These standards ensure the compatibility of your fax machine with millions of other fax machines worldwide.
3.14
Just in case …
Glossary
A4, B4, A3 — Standard stationery sizes defined by the International Standards
Organization, an agency of the United Nations. See also Paper sizes.
Autodialing — Enables user to store preprogrammed telephone numbers in the
unit’s memory. Storage capability varies from unit to unit.
Automatic fallback — The ability of a fax machine to slow down (“fall back”),
when communicating with another fax which is communicating at a slower rate.
Automatic reduction — Many Muratec fax machines will automatically reduce
the size of documents being transmitted to accommodate the effective printing
width of the receiving unit. For example, this allows a fax machine with a 10″ scanning width to send an image 10″ wide to a unit with an 8.5″ print width. The
receiving fax machine will receive a reduced-size printout of the complete image.
Bit — The smallest unit of information in a computer. Some Muratec fax machines,
which are actually computers “dedicated” to telecommunications, allow users to
change bits of information to provide or cancel features through software settings.
The word “bit” is a contraction of the two words “binary digit.”
Bits per second — See bps.
Black density — Also called black coverage. The amount of non-white area on a
page. For example, most regular office correspondence has a black density well
under 10% due to the presence of margins, spaces between words, spaces between
lines and paragraphs and even spaces within letters. However, drawings and photographs have a much higher black density, sometimes approaching 100%. The
higher a page’s black density, the more slowly a fax machine sends it.
bps — Bits per second. Used to express the speed of transmission of data. Because
fax transmission treats a document as a graphic image rather than as a series of
alphabetic and numeric characters, bps does not correspond to the number of characters transmitted per second.
Byte — A group of digital elements, usually sent as eight bits to the byte.
Call reserve — Also called call request. An ITU-T standard fax feature which allows
a user to request voice communication prior to, during or after transmission.
Call-waiting service — An optional telephone company service that alerts you to
another incoming call when the phone is already in use. Call-waiting signals often
cause interruption of fax transmission or reception.
Caller ID — Optional service provided by your local telephone company that allows
you to see a display of the number (phone or fax) that is calling.
CCITT — See ITU-T.
CCD, CIS — Charged coupled device, contact image sensor. Two types of scanning
mechanisms used in some Muratec fax machines. The CCD “reads” fluorescent light
bouncing off a document. The CIS uses a flat bar of light-emitting diodes (LEDs).
Compatibility — The term “compatible” describes the ability of separate things to
function together. Your Muratec fax machine features ITU-T Group 3 compatibility,
the modern standard for worldwide communication.
Confidential transmission — See SecureMail.
Confirmation report — See TCR.
Copy mode — Allows your fax machine to be used as a convenience copier.
Cover page (automatic) — A small, user-created message which can be the first
page of every transmission.
Data compression — Used in digital fax machines to speed transmission. See also
Digital fax, MH and MSE, SMSE.
Default — The setting your machine will always refer to if no other action has been
programmed. For example, you can set the default for this machine to send a fax by
using its memory. If you set this action as the default, that’s how your machine will
always send a fax, until you tell it to do differently.
Delayed command — Transmission or polling operation set by the user to occur
later, automatically, at a predetermined time. Great for reducing costs by making
fax calls during times when telephone costs are lowest, such as late at night or on
weekends.
Digital — Using the binary system (which uses a combination of 0s or 1s) to
describe everything, so that 0 means off and 1 means on; digital fax machines convert the graphic image of your document into a series of zeros and ones by using the
binary system of transmission to encode black and white occurrences. This
increases transmission speed by passing over white spaces. See also White-line skip.
Digital fax — Unlike analog systems that scan every portion of a document, digital
fax machines survey a document’s overall picture content. Digital fax machines
scan a line and convert the information into a binary code of zeros and ones. The fax
machine takes this information and compresses it, providing high transmission
speeds. Many Muratec units offer proprietary methods for faster transmissions
between Muratec-manufactured units (see also MSE, SMSE).
DIP switches — Dual in-line package switch; a two-position on/off switch. Many
Muratec fax machines include DIP switches to control optional settings or features.
Effective printing width — The widest image that can be printed on a fax.
3.15
Just in case …
Effective scan width — The maximum width the scanner in a fax can scan
during transmission.
F-Code — The ITU-T has created a fax industry standard for using subaddressing/password-based communications with not only Muratec fax machines but
also other manufacturers’ fax machines.
Facsimile (or fax) — A form of communication involving the scanning and decoding
of a document into electrical signals and transmitting of the document, over telephone lines to another device. This device then reconstructs the signals to produce an
exact duplicate of the document. Also, a machine that performs such communication.
Fallback — Group 3 fax machines operate at the highest transmission speed possible on a given telephone line. Muratec systems offer automatic fallback; if line
quality drops during transmission, the fax machine will reduce speed to the fastest
possible level.
Fine resolution — 203H × 196V lpi. Also shown as G3F (“Group 3 fine”) on some fax
units.
Grayscale — Not a level of resolution, but a method of scanning and transmitting
halftone images. Fax machines with grayscale abilities interpret photographs in
levels of gray between white and black. The transmitting fax machine must have
grayscale ability to send a photographic image accurately, but the receiving
machine does not need it to print the image.
Group 3 — Refers to fax machines that use digital encoding. These units transmit
one page in less than one minute and produce resolution of 203 × 98, 203 × 196, or
203 × 392 lpi.
Halftone — See Grayscale.
Handshaking — An exchange of data between telecommunications and/or
computer equipment that “introduces” two systems to each other. For example,
faxes use a handshaking protocol to identify the ITU-T group of each unit and to
begin fax communication.
Hub — See Relay broadcasting.
Hz (or Hertz) — A measure of frequency equal to one cycle per second. Used in the
specifications for a fax machine, it identifies the AC power the unit requires.
ITU-T — International Telecommunications Union – Telecommunications Sector.
(Formerly known as CCITT, for Consultative Committee for International Telegraph
and Telephone.) A telecommunications forum for member countries of the United
Nations, whose Study Group XIV established the primary groups for fax equipment,
covering communication protocol and transmission. Muratec Group 3 fax machines
offer the fastest transmissions allowed by the ITU-T when communicating with other
Group 3 units.
3.16
ITU-T
Test Document 1 — Also called the Slerexe (“slehr-rehks”) letter; An ITU-T
standard document with a known black density which fax makers often use to test
transmission speeds of their fax machines. Published transmission speeds are also
based on this document.
ITU-T V.29 and V.27 ter. — A standard set of communication procedures allowing
fax machines to talk to all other units adhering to those standards.
Laser printing — A plain-paper printing system. Toner is attached to a charged
drum and an image is transferred onto plain paper through electrical currents, then
fused with heat and pressure to produce a dry, permanent printout.
LCD — Liquid crystal display. Used on some Muratec units for status displays.
Leased line — See Private line.
Load number — A number assigned to telecommunications equipment used in
Canada; designed to help prevent overloading on a telephone circuit. See also
Ringer equivalence number.
Location ID — See Station ID.
lpi — Lines per inch. The way fax image resolution is measured. (For example, see
Normal resolution.)
MH — Modified Huffman, the standard ITU-T Group 3 data compression method. A
one-dimensional coding scheme that compresses data in a horizontal direction only.
A feature of all Muratec fax machines, MH assures transmissions faster than one
page per minute when communicating with other Group 3 units, regardless of manufacturer. See also MR, MMR, MSE, SMSE.
Modem — Modulator-demodulator. A device that converts digital data, like information from a fax machine, into an analog signal for transmission over ordinary
telephone lines. A modem is included in a fax machine and allows it to be connected
directly to a PSTN telephone line.
MR — Modified Read, an ITU-T Group 3 standard data compression method. A twodimensional coding scheme that compresses data in both horizontal and vertical
directions and allows for faster transmission when communicating with other
Group 3 units, regardless of manufacturer. See also MH, MMR, MSE, SMSE.
MMR — Modified Modified Read, an ITU-T Group 3 standard data compression
method. A two-dimensional coding scheme that compresses data in both horizontal
and vertical directions and allows for faster transmission when communcating with
other Group 3 units, regardless of manufacturer. See also MH, MR, MSE, SMSE.
Monitor — A speaker in most Muratec fax machines which allows the user to hear
the dialing process. This is not a speakerphone, because it has no microphone for
speaking to the person being called. For regular two-way voice communication,
users must use the optional handset. See also On-hook dialing.
MSE, SMSE — Muratec’s proprietary data compression methods, allowing a Muratecmanufactured fax machine to transmit more quickly when communicating with
another Muratec-manufactured unit. MSE and SMSE are features on many Muratec
fax machines. See also MH, MR, MMR.
Just in case …
Normal resolution — Shown as “norm”; 203H × 98V lpi. The default resolution
mode for all Muratec fax machines.
One-touch dialing — Allows the fax user to store frequently used fax numbers for
dialing with the touch of one key. See also Autodialing and Speed-dialing.
On-hook dialing — Dialing numbers by using the keypad on the fax unit without
lifting a handset. On most Muratec fax models, the user can do this either silently
or by using the monitor. See also Monitor.
Original document size — The largest (or smallest) document that can be fed
safely through a fax machine.
Paper sizes — All are width × length:
Letter-sized = 8.5″ × 11.0″
Legal-sized = 8.5″ × 14.0″
A5 = 5.8″ × 8.3″
A4 = 8.3″ × 11.7″
A3 = 11.7″ × 16.5″
B5 = 7.2″ × 10.1″
B4 = 10.1″ × 17.0″
B3 = 14.3″ × 20.3″
Passcode — A four-digit code-number. On your fax machine, the protection passcode lets the user limit access to fax operations, as well as certain settings and even
documents readied for polling (in the case of polling, only calling machines whose
users enter the proper passcode will be able to poll the document.)
PBX (or PABX) — Private branch exchange; privately-owned telephone equipment
serving a particular building, business or area. Many PBX systems use digital transmission lines which, unlike more common PSTN lines, are not compatible with fax
machine use. The user should not connect a fax unit to a PBX without first checking
with the system manufacturer or service representative.
Polling — Automatic transmission to a calling remote fax, or reception of a document from a remote fax set for this operation. Polling is convenient whenever a
central unit must receive information from one or several remote faxes. The caller
bears all telephone charges and prevents several remote units from calling at the
same time. See also Secure polling.
Private line — (Or leased line.) A service offered by many telephone systems; provides an exclusive phone circuit between two geographic points. A Muratec fax does
not require a private line. See also PSTN.
Proprietary — Non-standard. In fax, refers to a fax feature which works only in
communications between fax machines that are the same brand.
PSTN — Public switched telephone network; the most common type of telephone
lines and service in use, in contrast to private or leased lines. A Muratec fax provides fast, reliable data transmission over a PSTN line, and does not need a special or
dedicated telephone line. See also Private line.
Receiver ID — See Station ID.
Redialing — The dialing again, either manually or automatically controlled, of the
most recently dialed fax or phone number. Automatic redialing follows an unsuccessful dialing attempt and can be done manually or automatically.
Relay broadcasting — Lets some Muratec fax machines store a document in
internal memory, transmit the document to the memory of a remote “hub” fax and
then instruct that unit to relay (re-transmit) the document to each fax in a call
group in the “hub” unit. This feature speeds extremely high-volume fax communication and allows a single command to initiate document transmission to hundreds of
preprogrammed fax locations. It also saves phone charges for the originating
machine. Your machine can initiate a relay broadcast.
Remote fax machine — The machine on the other “end” of a fax communication.
REN — See Ringer equivalence number.
Resolution — The resolution of documents transmitted or copied by fax machines
is measured by the number of horizontal (H) and vertical (V) lines per inch (lpi) the
unit can print. A Muratec unit may offer one or more of these resolution levels:
Normal
203H × 98V lpi
Fine
203H × 196V lpi
Superfine
203H × 392V lpi
Some Muratec units also offer grayscale transmission (see also Grayscale) for accurate reproduction of photographs and other shaded originals.
Ringer equivalence number — Also called REN. A number assigned to telecommunications equipment used in the United States; designed to prevent overloading
on a telephone circuit. See also Load number.
Scanning width — See Effective scanning width.
SecureMail — Allows a Muratec fax user to send a document to or or receive one
into (usually something confidential) an “electronic mail box.” The transmission is
protected at the receiving Muratec fax by an access code; the receiving fax prints
the document only when an authorized user enters the code.
Secure polling — Polling in which preset passcodes are checked between two
machines before polling is allowed to take place.
Speed-dialing — Allows the fax user to store frequently used fax numbers for dialing with the touch of three keys — an identifier key (either * or #) and then a
three-digit code — for each number. See also Autodialing and One-touch dialing.
Station ID — (Also called Location ID or Receiver ID.) An autodialer feature which
lets the fax user enter a descriptive name to correspond with the number in an
autodialer entry. For example, rather than entering only 1-972-555-3465, the user
can enter that number and a name, such as Dallas Branch Office. (Many Muratec
models with this feature allow entry of both upper-case and lower-case letters, for
greater ease of reading.)
Subscriber ID — A fax machine’s telephone number, as identified by a user setting. See TTI.
Superfine resolution — 203H × 392V lpi. Your Muratec fax machine’s superfine
transmission mode is Group-3-compatible, not the more limited proprietary version.
3.17
Just in case …
TCR — Transmit confirmation report; this provides proof that your Muratec fax did
send the document you set for transmission. Printed after transmission, the TCR
also identifies the telephone number to which the fax sent the document, plus the
actual time of transmission and how many pages the unit transmitted.
Thermal (paper) printing — A thermal head heats chemically treated, thermally
sensitive paper in patterns conforming to the image the machine has scanned, creating a printed image. Thermal paper’s tendency to discolor and fade, in addition to
its curliness and the usual difficulty in writing on it, have made this method considerably less popular than plain-paper fax printing — particularly as plain-paper fax
machines have dropped sharply in price.
TTI — Transmit terminal identifier. A user-programmable line of information sent
automatically with every page a fax machine sends; it appears at the top of each
page printed by the receiving unit.
Transmission speed — How fast a fax machine is sending a fax document. This
speed depends on the modem speed of each unit, the resolution setting, the content
of the document, the encoding technique and the condition of the phone line (clean,
noisy, etc.) Any change in any one of these five conditions will affect the speed,
sometimes significantly.
White-line skip — A technique used to speed up fax transmission by bypassing
redundant areas, such as white space.
3.18
Just in case …
3.19
Appendix and index
Appendix and index
Specifications
Type:
High-speed facsimile transmitter and receiver for
home and office use.
Phone line:
Normal Public Switched Telephone Line (PSTN) or
equivalent.
Modem speed:
14,400 bps with fallback to 12,000, 9,600, 7,200,
4,800 and 2,400 bps per ITU-T, V.17, V.29 and V.27
ter.
Compatibility:
ITU-T Group 3.
Data compression methods: ITU-T standard MH, MR, MMR and Muratec-proprietary MSE.
Transmission speed:
6 seconds per page.*
Printing speed:
2 ppm.
Scanning method:
Solid-state CIS.
Printing method:
Muratec Film Imaging (thermal-transfer) onto
plain paper.
Effective scanning width: 8.2″ (208 mm)
Printing width:
8.2″ (208 mm)
Resolution:
Normal, 203 × 98 lpi (8 dots/mm × 3.85 lines/mm)
(horizontal × vertical)
Fine, 203 × 196 lpi (8 dots/mm × 7.7 lines/mm)
Superfine, 203 × 392 lpi (8 dots/mm × 15.4 lines/mm)
Grayscale:
64-level.
Acceptable document size: Single sheet
(width × height)
Max. 8.5″ × 35.4″ (216 mm × 900 mm)
Min. 5.8″ × 4.1″ (148 mm × 105 mm)
Two or more sheets
Max. 8.5″ × 14.0″ (216 mm × 356 mm)
Min. 5.8″ × 5.8″ (148 mm × 148 mm)
Automatic document feeder 30 letter-sized pages or 20 legal-sized pages.
(ADF) capacity:
Recording paper size:
letter- or legal-sized.
Paper cassette capacity:
300 sheets.
Ink film roll size:
Standard roll
(width × length, yield)
8.7″ × 656.2′ (220 mm × 200 m), 700 sheets.**
Starter roll included with machine
8.7″ × 65.6′ (220 mm × 20 m), 60 sheets.**
LCD:
Memory:
Power:
Power consumption:
Dimensions:
(width × depth × height)
Weight:
Operating environment:
1 line, 16 characters
1.3 MB (114 pages**)
Power source: 120VAC ± 10%, 50–60 Hz.
Battery backup: 72 hours***
Standby: 7.1W
Maximum: 136.7 W
14.5″ × 14.8″ × 7.8″
(369 mm × 377 mm × 199 mm ).
15.6 lb. (7.1 Kg).
Temperature: 41ºF to 94.8ºF (5ºC to 35ºC)
Humidity: 10 to 80 %RH
*
Based on transmission of ITU-T Test Document 1 to a Muratec fax machine. Your transmission times will vary, but
your Muratec fax machine always will provide the fastest transmission speeds possible under ITU-T guidelines and
phone-line conditions.
**
Based on letter-sized sheets (width × length, 8.5″ × 11″ (216 mm × 279 mm)).
*** The backup battery preserves document data in the memory for up to 72 hours in case of a power loss is a
rechargeable battery, and it requires about 1 day to reach full charge after power to the machine is restored.
AI.1
Appendix and index
Regulatory information
United States of America
Federal Communications Commission (FCC) information
Ringer Equivalence Number (RENs): AC REN, 1.25B; DC REN, 2.4.
This facsimile machine has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against such interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment causes interference in radio or television reception (which can be determined by turning the equipment off and on), the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with Part 68 of the FCC rules. On the bottom of this equipment is a label that contains, among
other information, the FCC registration number and REN for this equipment. If so requested, you must provide this information to the telephone company.
An FCC-compliant telephone cord and modular plug are provided with this equipment. This equipment is designed to be
connected to the telephone network or premises wiring using a compatible modular jack which is Part-68-compliant.
Telephone company procedures
The goal of the telephone company is to provide you with the best service it can. In order to do this, it may occasionally
have to make changes in its equipment, operations or procedures. If these changes might affect your service or the operation of your equipment, the telephone company will give you notice, in writing, to allow you to make any changes
necessary to maintain uninterrupted service.
If you have any questions about your telephone line, such as how many pieces of equipment you can connect to it, the
telephone company will provide this information upon request.
In certain circumstances, it may be necessary for the telephone company to request information from you about the
equipment which you have connected to your telephone line. Upon request of the telephone company, provide the FCC
registration number and the Ringer Equivalence Number (REN) of the equipment which is connected to your line. Both
of these numbers are listed on the equipment label attached to your fax machine.
The sum of all RENS on your telephone line should be fewer than five (5) in order to assure proper service from the telephone company. Sometimes, a sum of five (5) may not be usable on a given telephone line.
Note:
This equipment is hearing-aid-compatible (HAC).
Notice: The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other
electronic device to send any message via a telephone fax machine unless such message clearly contains,
either in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the
date and time it was sent and an identification of the business or other identity, or other individual sending
the message and the telephone number of the sending machine or such business, entity or individual. For
instructions on programming this information (the “TTI”) into your fax machine, see pages 1.12–1.14.
Type of service
Your fax is designed for use on standard-device telephone lines. The fax connects to the telephone line with a standard
line called the USOC RJ-11. Connection to telephone-company-provided coin service (central-office-implemented systems).
Connection to party line service is subject to State tariffs.
AI.2
If problems arise
If any of your telephone equipment is not operating properly, you should immediately remote it from your telephone
line, as it may cause harm to the telephone network. If the telephone company notes a problem, they may temporarily
stop service. When practical, they will notify you before this disconnection. If advance notice is not feasible, you will be
notified as soon as possible. When you are notified, you will be given the opportunity to correct the problem and will be
informed of your right to file a complaint with the FCC.
In the event repairs are ever needed on your fax machine, they should be done by Muratec America, Inc., or an
authorized representative of Muratec America, Inc. For information, contact the Muratec Customer Support Center at
972-364-3350 (from the U. S. only).
Canada
Industry Canada (IC) regulations
Ringer Equivalence Number (REN): F-65, 0.4.
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the
interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of Communications.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de
Classe A prescrites dans la norme sur le matériel brouilleur: “Appareils Numériques,” NMB-003 édictée par le Ministre
des Communications.
Notice: The Canadian Department of Communications label identifies certified equipment. This certification means
the equipment meets certain telecommunications network protective, operational and safety requirements.
The Department does not guarantee the equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local
telecommunications company. The equipment must also be installed using an acceptable method of connection.
Sometimes, the company’s inside wiring associated with a single-line individual service may be extended with a certified connector assembly (telephone extension cord). The customer should be aware that compliance with these
conditions may not prevent degradation of service in some situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the
supplier. Any equipment malfunction, or repairs or alterations made by the user to this equipment, may give the
telecommunications company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines
and internal metallic water pipe system, if present, are connected. This precaution may be particularly important in
rural areas.
Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electric
inspection authority or electrician.
The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the maximum number
of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices does not exceed 5. The IC REN
for the F-65 is 0.4.
IC
Appendix and index
Index
A
D
Activity journal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.45
Alphanumeric directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . See EasyDial
Ans/Fax Ready mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.23
Answering machine (yours; not included with fax machine), attaching . . . . . . . . . . . . . . 1.11
Answering, setting number of rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4
Attaching (your) second phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.11
Autodialer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.7–2.13
Date and time, setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12–1.14
Delayed transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.14–2.15
Dialing mode (pulse or tone) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.14
Dialing during a power failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26
Directory dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . See EasyDial
Distinctive ring detection (DRD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.46–2.47
Document guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.15
Document, inserting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17
B
Block Junk Fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.42–2.43
Broadcasting, relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.16–2.18
C
Call request . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.47–2.48
Call-waiting, possible trouble with . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.16
Caller-ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.48–2.49
Canceling commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20, 2.15
Changing ink film . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.9–1.10
Cleaning your fax machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.8–3.10
Clearing jams
Document, original . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2
Printout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2–3.3
Clearing settings before using EasyStart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12
Closed network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.42
Communications problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4–3.7
Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4
“Check Message” printouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.7
Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4–3.6
Error codes, printouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.6–3.7
Confidential communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21–2.27
Confirmation reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.46
Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.16
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4–1.5
Copying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.23
Copy and print reduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3–2.4
Cover page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.44
E
EasyDial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.13
EasyStart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12–1.14
Electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6, AI.1
Electrical surge suppressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6
Entering date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12–1.14
Entering TTI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12–1.14
Error Correction Mode (ECM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4
Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . See Communications problems
F
F-code
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21–2.27
F-code
F-code
transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.25, 2.26
polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.26, 2.27
Fax Ready mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21
Fine resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1, 1.15, 2.2
G
Grayscale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1, 1.15, 2.2
H
Handset, summary of installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8
HOLD, using in telephone calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.25
AI.3
Appendix and index
I
P
I.D.
PABX,
code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21, 2.23–2.25
Inserting pages (for faxing or copying) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17
Installation
AC power line connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8
Answering machine (yours) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.11
Fax machine, location of . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6
Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8
Ink film . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.9
Phone line connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8
Power line connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8
Paper for printouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6–1.7
Paper-handling parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8
Page size setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8
Telephone (yours) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.11
ITU-T Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21 –2.27
ITU-T Subaddress . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21 –2.27
J
Jammed paper, removing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2–3.3
Journal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.45
“Junk fax,” blocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.42–2.43
L
Language, setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.6
Light contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.16
Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AI.6
Line connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . See Installation
Location ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.7, 2.8, 2.10, 2.11, 2.13
M
Making copies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.24
Memory transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17
Monitor speaker, setting volume of . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.9
N
Normal resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1, 1.15, 2.2
O
OneLine + distinctive ring detection (DRD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.46–2.47
One-touch numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.7, 2.8–2.10
See also Programmable one-touch keys
Operation protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.37–2.38
Out-of-paper reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.23
AI.4
using with . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.12
Paper cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6–1.7
Paper for printouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6–1.7
Passcode, protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.37
Pause character, entering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.16 , 2.7
PC-FAX feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.50 –2.52
Phone and electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6
PIN mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.39–2.41
Polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.19–2.20
Being polled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.20
F-code polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.26 –2.27
Passcode protection for . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.20
Regular polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.19
Sequential polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.19
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6, AI.1
Printing machine settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.6
Print and copy reduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3–2.4
Program list, printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.6
Programmable one-touch keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.28–2.36
Protection passcode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.37
R
Receiving faxes (basic instructions) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21
Redialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.19
Reduction, print and copy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3–2.4
Regulatory information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AI.2
Relay broadcasting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.17–2.18
Reports, confirmation (TCR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.46
Requirements, phone and electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6, AI.1
Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1, 1.15, 2.2
Review Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20, 2.15
Rings, setting number on which to answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4
S
Security reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.38–2.39
Sending faxes (basic instructions) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.15–1.20
Settings list, printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.6
Silent mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.5
Speaker, monitor, setting volume of . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.9
Special dialing characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.7
Special features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.44–2.49
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AI.1
Speed-dial numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.7, 2.10–2.12
Subscriber ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12–1.13
Superfine resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1, 1.15, 2.2
Surge suppressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6
T
TCRs (transmit confirmation reports) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.46
Telephone features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.24
Time and date, setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12
Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . See Sending faxes
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2–3.10
Transmit Terminal Identifier (TTI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12–1.13
U
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2
V
Voice mail, possible trouble with . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.16
Volume setting for monitor speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.9
Voltage requirements and power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6
W
Warranty, limited . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AI.6
AI.5
Limited warranty
This warranty is made by Muratec America, Inc. (hereafter referred to as “Muratec”). This warranty is
valid only on Muratec products purchased and used in the United States of America. This warranty
applies to the product only while owned and used by the original purchaser (“Customer”). If ownership of
the product is transferred, this warranty terminates. This warranty does not apply to any product in use
for rental purposes.
This Muratec product is warranted against defects in material and workmanship for ninety (90) days
commencing the date of original Customer purchase. If the product is defective in material and/or workmanship (normal wear and tear excepted) during the warranty period, Muratec or its authorized
representative will, during Muratec’s established service availability hours, make necessary adjustments
and repairs, including, at Muratec’s option, installation of replacement parts. Muratec’s service availability hours are 8:30 AM to 5:00 PM (Central time) Monday through Friday, excluding Muratec-recognized
holidays. Muratec will complete the necessary adjustments and repairs within a reasonable time period,
as dictated by the nature of the problem and by Muratec’s service schedule. Replacement parts may have
been used and/or reconditioned. Parts that have been replaced will remain the property of Muratec. This
warranty is subject to the OBLIGATIONS and EXCLUSIONS set forth.
Obligations
1. This warranty will be honored only on presentation of the original dated authorized Muratec bill of sale
or Muratec dealer bill of sale or sales slip to an authorized Muratec service representative or service
center. For the name of your authorized service center, contact Muratec (from the United States, call
1-972-364-3350; from Canada, check your in-box materials for the number to call).
2. During the warranty period, the Customer must notify Muratec by telephone of any defective product
material and/or workmanship.
3. Transportation (including prepayment of freight and insurance charges) of the product to and from an
authorized service center, designated by Muratec, is the responsibility of the Customer.
4. If Muratec provides maintenance or responds to a call which is outside the scope of this warranty, such
maintenance shall be billed to the Customer at Muratec’s then-current rates for maintenance and
parts and shall be due and payable in full upon receipt of invoice.
Exclusions
1. This warranty shall not cover a product with missing or altered original identification marks.
2. This warranty applies only to products that the purchaser has properly installed, adjusted and operated in accordance with the instructions set forth in or provided with product literature. This warranty
does not apply to any product which has been subjected to tampering, alteration, misuse, abuse,
neglect, improper installation or transportation damage. Nor does it apply to costs for any service
requested for demonstration or to confirm proper operation of this product.
3. The warranty shall not apply to adjustments, repairs or replacements necessitated by any cause
beyond the control of Muratec (whether foreseeable or not) including, but not limited to, any malfunction, defects or failure caused by or resulting from any of the following: improper unpacking or
installation, unauthorized service or parts, or improper maintenance or cleaning, modification or
repair by the Customer, accident (including, without limitation, unavoidable accidents), fire, flood or
other Acts of God, improper telephone or electrical power or surges thereof, interconnection with or use
of non-compatible equipment or supplies (including paper), or placement of the product in an area
which does not conform to Muratec space, electrical and/or environmental requirements.
4. Muratec will not be required to make adjustments, repairs or replacements if the product is installed
or used at a location deemed by Muratec to be hazardous to health or safety, or if Muratec is not provided with free and reasonable access to the product and a telephone during service availability hours,
or if the product location is not accessible by an authorized Muratec service vehicle.
AI.6
EXCEPT AS EXPRESSLY SET FORTH ABOVE, AND EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, MURATEC
MAKES NO OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND ANY WARRANTY ARISING FROM COURSE OF
DEALING OR USAGE OF TRADE), AND MURATEC EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED HEREIN. IN THE
EVENT THE PRODUCT IS NOT FREE FROM DEFECTS AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE
REPAIR OR REPLACEMENT AS PROVIDED ABOVE. UNDER NO CIRCUMSTANCES SHALL MURATEC BE LIABLE TO THE CUSTOMER , OR TO ANY USER , FOR ANY DAMAGES , INCLUDING ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES ,
EXPENSES, LOST PROFITS, LOST SAVINGS OR ANY OTHER DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE
THE MURATEC PRODUCT, EVEN IF MURATEC OR ITS REPRESENTATIVES HAVE BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES.
Some States do not allow the exclusion or limitation of incidental or consequential damages, and some
States do not allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other
rights which vary from State to State.
