Owner’s
Manual
Thank You!
Thank you for purchasing the Unifier™
URC-100 Pre-Programmed and Learning Remote
Control. The Quick Setup DVD tutorial supplied
with the Unifier demonstrates the process of
setting up and automating a home entertainment
system. Watch the DVD first to familiarize
yourself with the capabilities of the Unifier and
the process of setup. This manual is designed to
assist you step-by-step as you setup the Unifier
to replace all of your remote controls and
automate your home entertainment system.
URC-100 Owner’s Manual © 2004 Universal Remote Control, Inc.
The information in this manual is copyright protected. No part of this manual may
be copied or reproduced in any form without prior written consent from Universal
Remote Control, Inc. UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE
LIABLE FOR OPERATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS
MADE IN THIS MANUAL. The information in this manual may be subject to
change without prior notice. Unifier is a registered trademark of Universal Remote
Control, Inc. Power of Simple is a trademark of Universal Remote Control, Inc.
DoubleTap learning is a trademark of Universal Remote Control, Inc. All other
brand or product names are trademarks or registered trademarks of their respective
companies or organizations.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
Table of Contents
Getting Started.......................................................... 2
Button Layout ........................................................... 3
Basic Operation ........................................................ 4
Basic Setup................................................................ 5
Pre-Programmed Method........................................... 5
Learning Method ....................................................... 8
Volume Control Punch Through ............................. 11
Advanced Setup ..................................................... 13
Own Two VCR’s? Set Aux to be VCR2 ..................... 13
Editing Device Names ............................................. 15
Macro Button Setup................................................. 17
Erasing Settings........................................................ 19
Recalling Pre-Programmed Settings ......................... 22
The Optional Expander ........................................... 23
Pre-Programmed Code Tables ................................. 25
Frequently Asked Questions.................................... 48
Specifications/Warranty.......................................... 50
1
The Unifier
Getting Started
Congratulations!
You’ve purchased one of the most advanced and easy
to setup remote controls ever made. The Unifier’s
built-in library includes thousands of different brands and
models of remote controls. In most systems, all you have
to do to setup the Unifier is enter which brands and
models you own. If you own a component too new to be
in the library, the Unifier uses advanced DoubleTapTM
learning technology to quickly set each Unifier button,
one at a time. Setting up your Unifier to replace all your
existing remote controls can be done in a few minutes.
Basic Setup is described on pages 5 to 12.
The Unifier’s exciting advanced features automate and
customize operation in many ways. You could use
Macro Setup to power on all of your components and
start the show with the press of one button! With the
Unifier’s unique macro capability you can automate the
most complex home theater system. Any of the names on
the display can be edited as you like. It is best to delay
any Advanced Setup (described on pages 13 to 22) until
after you finish Basic Setup.
Battery Installation
- +
Remove the battery compartment
cover by pressing up the cover
lock. Insert four AAA batteries into
the battery compartment as shown
in the diagram.
+ - +
+ -
2
URC-100
Button Layout
LIGHT
Button
DISPLAY
DEVICE
Buttons
SHIFT
Button
FUNCTION
Buttons
3
The Unifier
Selecting a New DEVICE Changes
All Button Commands Instantly
The Unifier can operate eight different devices even
though it is only one remote control. Let’s try it now!
Press the CABLE DEVICE button. The top of the screen
changes to CABLE. Now all of the buttons of the Unifier
operate a Cable box. To operate any of the other devices,
simply press one of the eight device buttons.
CABLE
DEVICE
Button
SHIFT
Button
The SHIFT Button
Press SHIFT to access a second command for each
button. While the Unifier is in SHIFT mode, the display
will blink. If you don’t press a button within ten
seconds, the Unifier will timeout and return to normal
operation. The orange button labels indicate some of
the commands available when you are in SHIFT mode.
Note: The AUDIO device has unique SHIFT functionality.
It can issue input commands to your A/V Surround Sound
receiver by pressing the DEVICE buttons after SHIFT is selected.
Light Button
Press the LIGHT button to backlight all the buttons. To
turn off the backlighting, press the LIGHT button again,
or just wait ten seconds (the backlighting automatically
shuts itself off).
LIGHT
Button
4
URC-100
Basic Setup
You can start setting up your Unifier using either the
Pre-Programmed Method or the Learning Method.
However, all the buttons of the Unifier are setup at once
with the Pre-Programmed Method, so it is usually faster
than the one-button-at-a-time Learning Method.
Pre-Programmed Method
1
Power on the A/V component you wish to setup, so that
you can test codes by sending power off commands.
2
Refer to the pre-programmed code tables on pages
25 - 46 and write down the code numbers listed
for your A/V component. The code numbers are
listed by categories of devices, then by brand. See
page 25 for a category list.
3
Press and hold both the SHIFT and ENT (Enter)
buttons for approximately three seconds. The top of
the display will blink “SET” then one of the eight
device names. You are in SETUP mode now.
Note: You have 30 seconds to perform a step while you are
in SETUP mode. If you don’t press a button within that time,
the Unifier will time out and return to normal operation.
SHIFT
Button
ENT
Button
5
The Unifier
4
Choose the name of the device you’d like to
setup. Use the cursor LEFT or RIGHT buttons to
change the flashing name.
For Example: I wanted to setup the TV Device button
first, so I pressed the cursor LEFT or RIGHT until “TV”
was flashing on the display.
LEFT
5
RIGHT
Point the Unifier at the component, then enter the
first three digit code number from your notes using
the numbered buttons. After you enter each three
digit code number, look at the component to see if
it turned off.
Using the
numbered
buttons,
enter the
3 digit code
number.
Continue to enter code numbers until the
component powers off.
For Example: I have a Sony TV. I found the code
numbers 070, 139,147, 126, 185, 194 and 085 under
Sony in the TV TABLE. Using the numbered buttons on
the Unifier, I entered 070 and looked at the TV. It
didn’t turn off, so I entered 139, then 147 and so on,
until I found the code that powered off the TV.
6
URC-100
Note: If your component fails to turn off after you have
entered all the code numbers listed for your brand, you can
scan through the other brands in the table by alternately pressing
the Channel Up(or Down) and Power Off buttons (there is a
chance that your component was actually manufactured by
another brand). However, most of the code tables are so
large that it is usually faster to use the Learning Method on Page 8.
Channel Up
and Down
scan code
numbers.
6
When the component turns off, save the code
number you entered by pressing the LIGHT button.
LIGHT
Button
The Unifier responds by flashing SAVED on the
display twice, then returns to normal operating
mode.
7
When the display shows a device name, you are
back in normal operating mode. Now it’s time to
test all the buttons. If some buttons don’t work, try
repeating steps 1-6 with the remaining code
numbers, to see if you can improve the match to
your component.
For Example: My Sony TV powered off with TV code
number 147. However the number buttons didn’t work
when I tested them. So, I repeated steps one to six, using
other code numbers and eventually discovered that when
code number 185 is set, all the buttons work perfectly.
8
Repeat steps one through seven for each of your
devices. In most systems, you can finish basic
setup in just a few minutes and put all your old
remote controls away.
7
The Unifier
Learning Method
The Unifier can learn commands from your old remote
controls one-button-at-a-time by following these simple
steps:
1
Line-up the Unifier with your old remote control,
head-to-head, one or two inches apart.
2
Press and hold both the desired DEVICE button
and the SELECT button for approximately three
seconds. The top of the display will show
“LEARN”. You are in LEARN mode now.
Note: You have 30 seconds to perform a step while you are
in LEARN mode. If you don’t press a button within that time,
the Unifier will time out and return to normal operation.
DEVICE
Buttons
SELECT
Button
8
URC-100
3
Press any button you want to teach a command to.
Press
any
Button.
Once you press a button, the top of the display will
change from “LEARN” to “READY”.
READY
SHIFT Functions: You can teach a second additional
command to a button by pressing the SHIFT button, then
pressing the button you want to teach. Additionally, using
the SHIFT button, you may teach commands to the
DEVICE buttons themselves (on AUDIO only). Select the
AUDIO device in Step 2, press SHIFT and then the Device
button you want to teach.
4
Press and hold the button on your old remote
control until the display changes to “RETRY”.
RETRY
9
The Unifier
5
Press and hold the same button on your old remote
control once again.
The Unifier’s unique DoubleTap learning technology
ensures compatibility with the widest variety of remote
controls ever!
6
Once you have taught the button twice, the display
will change to either “GOOD” or “FAILED”.
If the “GOOD” label appears on top of the display
and “SAVED” flashes on the bottom, you were
successful. Now, press the next button you wish to
teach (repeating steps 3 through 6 until you have
learned all the buttons you want).
If the “FAILED” label appears on top of the display,
try to teach the same button in Unifier once again
by repeating steps 3-6.
7
Once you completed teaching all the buttons, save
your work and return to normal operation by
pressing the LIGHT button. Test all your new
commands. If any of them don’t work, try learning
again using these notes:
Move to another room. Plasma TVs, sunlight, halogen or
quartz lighting can interfere with the learning process.
Although the old remote control seems to work fine,
change the batteries to fresh alkaline batteries.
Vary the distance between the remote controls
gradually. Try 1/4”, 1”, 2”and so on, up to 4 feet.
Tap the button on the original remote control instead of
pressing and holding it during the learning process.
10
URC-100
Volume Control Punch Through
In most home entertainment systems, the sound
volume is only controlled by one device. In some
systems, it is the TV speakers that make the sound, so
you would use the TV device on the Unifier to raise
and lower the volume. In another system, it might be a
surround sound receiver and speakers that control the
sound, so you would use the Unifier’s AUDIO device
to adjust the volume. Constantly switching the Unifier
to TV or AUDIO to adjust the volume is inconvenient
in daily life.
You can use Punch Through to set the Unifier’s
volume buttons to always control the sound in your
system. That way when the Unifier is set to VCR or
DVD, the volume up, down and mute buttons will
work perfectly without switching back to AUDIO or
TV. Here’s how:
1
Press and hold both the DEVICE button that
doesn’t have volume control commands yet and
the MUTE button for about three seconds.
For Example: You want to make the DVD volume buttons
control the sound. Press and hold DVD and MUTE.
DEVICE
Buttons
Mute
Button
Note: You have 30 seconds for each step, otherwise the
Unifier will time out automatically.
11
The Unifier
2
The Unifier displays SET in the display.
SET
3
Press the SHIFT button. The Unifier displays
PUNCH in the display.
PUNCH
4
Press the Volume Up button. The display confirms
by displaying “VOL”. This sets up the group of three
buttons (Volume Up, Volume Down and Mute) in
one action!
VOL
5
Press the Device button for the device that has the
Volume control commands you want (i.e.,TV for
systems using the TV speakers, AUDIO for systems
with surround sound receivers). The bottom of the
display will flash “SAVED”.
The Unifier will flash the device’s name twice and
return to operating mode.
6
Repeat steps 1-5 until all your other devices (VCR,
CABLE, CD, etc.) operate the volume perfectly.
Note: The Punch Through feature is not limited to
volume and can also be applied to other groups of
buttons. If you find yourself switching to a particular
device frequently to use a group of controls, consider
using Punch Through for another group, as listed here:
VOL - Volume Up, Volume Down and Mute
CH UP- Channel Up, Channel Down and Prev. Channel
PLAY - Play, Stop, Pause, Rewind and Fast Forward
GUIDE - Guide, Menu, Info, Exit, Up, Down, Left, Right, Sel
POWER On - Power On and Power Off
12
URC-100
Advanced Setup
After you’ve finished all your basic setup, you can
choose to make operation easier by customizing the
Unifier just the way you want, using the Advanced Setup
features described in this section.
Own Two VCR’s?
Set Aux to be VCR2
Any device button can be setup for ANY type of
component (for example, you can make the AUX device
button operate a second VCR). To setup a device button
for a different type of component, use these steps:
1
Power on the A/V component you wish to setup, so that
you can test codes by sending power off commands.
2
Refer to the pre-programmed code tables on pages
25 - 46 and write down the code numbers listed
for your A/V component.
3
Press and hold both the SHIFT and ENT (Enter)
buttons for approximately three seconds. The top
of the display will blink “SET” for a moment.
SHIFT
Button
ENT
Button
Note: You have 30 seconds for each step, otherwise the
Unifier will time out automatically.
13
The Unifier
4
In this step you choose the name of the device
you’d like to setup. Use the cursor LEFT or RIGHT
buttons to change the flashing name.
For Example: I want to setup AUX as my second VCR,
so I press the cursor LEFT or RIGHT until AUX appears
in the display.
LEFT
5
RIGHT
Press the MUTE button, then use the left and right
buttons to select the type of component you plan
to operate with this device button.
For Example: I want to operate a VCR, so I press the
cursor LEFT or RIGHT until VCR appears in the display.
Note: Each name that appears in the display may
include several types of components. For example, the
SAT category includes Digital Video Recorders like
those from TiVo and Replay. See page 25 for a list of
component types each Code Table contains.
6
Point the Unifier at the component, then enter the
first three digit code number from your notes
using the numbered buttons. After you enter each
three digit number, look at the component to see
if it turned off. Continue to enter code numbers
until the component powers off.
7
When the component powers off, save by pressing
the LIGHT button. The Unifier responds by
flashing SAVED on the display twice, then returns
to normal operating mode.
14
URC-100
Editing Device Names
The Unifier can display your own custom names for each
of the eight device buttons. For example, you can
rename AUX to “LIGHTS” or SAT to “DISH”, etc.
1
Press and hold both the device button you want to
rename and the ENT button for about three seconds.
Note: You have 30 seconds for each step, otherwise the
Unifier will time out automatically.
Device
Buttons
ENT
Button
The Unifier flashes EDIT in the display.
EDIT
2
Then the old device name appears, with the first
space/character blinking on and off:
AUDIO
15
The Unifier
3
4
Change the character by using any of the number
keys. Each press of the same number button
selects the next character of that number’s group,
as shown below.
A,B,C,1
D,E,F,2
G,H,I,3
J,K,L,4
M,N,O,5
P,Q,R,6
S,T,U,7
V,W,X,8
Y,Z,9
Once the character you want appears, move to the
next space by pressing the RIGHT cursor button.
LEFT Cursor
button
moves blinking
character left.
RIGHT Cursor
button
moves blinking
character right.
DOWN Cursor
button deletes the currently
blinking character.
5
Press the LIGHT button to save changes.
16
URC-100
Macro Button Setup
Imagine turning on your TV, your DVD player and
your surround sound receiver by pressing a single
button on your Unifier! What would normally take
three remotes and three button pushes, the Unifier can
accomplish with the press of one button. We call that a
“Macro”. Any of the Power On or the Power Off
buttons (on any Device) and all eight of the Device
buttons themselves can be set to be Macro buttons!
To setup a macro button, follow these easy steps:
1
Press and hold both the desired DEVICE button and
the MUTE button for three seconds.
For Example: If you want to make the DVD Power On
button a macro button, press and hold DVD and MUTE.
DEVICE
Buttons
Mute
Button
The Unifier displays SET in the display.
SET
Note: You have 30 seconds for each step, otherwise the
Unifier will time out automatically.
2
Press the button you want to be a macro. The
Unifier screen changes to the macro step display:
Number
of
Steps
ID
M1 ##
17
The Unifier
3
Navigate to the device that has a button you want in
your macro using the DEVICE buttons. Then press
the button with the command you want. Whenever
a button is pressed, another Macro step is counted
and displayed on the screen.
Don’t worry about the number of steps. Each
macro button can store up to 50 steps, so you are
not likely to run out of steps!
Note: You can program delays in between commands
by pressing the PAUSE button. Each press adds half a
second to the delay.
PAUSE
Button
4
Press the LIGHT button to save your macro. The
Unifier will flash SAVED twice in the display.
Advanced Options:
You can setup a DEVICE button to be a macro by pressing Audio and Mute for 3 seconds. Once the display says
SET, press the Device button you wish to set as Macro
button. Then follow steps 3 and 4 to setup the macro.
Another option for DEVICE button macros is to only send
the macro if the button is pressed and held. This is setup
by entering a delay as the first step of the macro. The
amount of delay determines how long the user must press
the button before the macro is sent. The advantage of this
option is that a normal press of the DEVICE button will
simply switch devices without issuing the macro.
18
URC-100
Overview of Erasing
You can erase an individual button with a learned
command, a macro or a favorite channel. You can
erase an entire Device’s learned command or macro
buttons. You can also erase ALL your learned
commands on all devices or all your macros or favorite
channels everywhere.
If you really want a fresh start, it is possible to reset
everything to the factory default condition.
Erasing One Learned Command
1
Press and hold both the device button where the
command is stored and the SELECT button for three
seconds.
Note: You have 30 seconds for each step, otherwise the
Unifier will time out automatically.
Device
Buttons
SELECT
Button
The Unifier display changes to:
LEARN
2
Press and hold the button you’d like to erase for two
seconds. The display will flash ERASE, CLEAR, then
return to LEARN.
3
Press the LIGHT button to save.
19
The Unifier
Erasing All Learned Commands in One Device
1
Press and hold both the Device button where the
command is stored and the SELECT button for three
seconds.
Note: You have 30 seconds for each step, otherwise the
Unifier will time out automatically.
Device
Buttons
SELECT
Button
The Unifier display changes to:
LEARN
2
Press and hold both the DEVICE button you’d like to
erase and the PAUSE button until the display flashes
ERASE nine times, followed by CLEAR, then release
the buttons and the Unifier returns to normal
operating mode.
DEVICE
Buttons
PAUSE
Button
20
URC-100
Erasing All Learned Commands in ALL Devices
Press and hold both the POWER ON and the STOP
button for ten seconds.
POWER
ON
Button
STOP
Button
After the display flashes ERASE ten times you can release
the buttons. The display will flash CLEAR and the Unifier
will return to normal operating mode.
Erasing a Macro
1
Press and hold both the DEVICE button and the
MUTE button (to erase Device buttons, use AUDIO
and MUTE). Release after SET appears on the display.
Note: You have 30 seconds for each step, otherwise the
Unifier will time out automatically.
DEVICE
Buttons
Mute
Button
2
Press the macro button you want to erase. The
display will flash “CLEAR” then “M ###”.
3
Press the LIGHT button to save.
21
The Unifier
Erasing All Settings
Should you wish to make a clean start, you can reset the
Unifier to its factory default settings by pressing and
holding both the POWER OFF button and the STOP
button for ten seconds. Continue to hold both buttons as
the display flashes ERASE nine times, then CLEAR.
POWER
OFF
Button
STOP
Button
The Unifier displays a self testing routine for a few
seconds, then returns to normal operating mode.
Recalling Pre-Programmed Settings
If you wish to recall a previously programmed code
number so that you can write it down, follow these steps:
1
Press and hold both the DEVICE button you want to
identify and the MUTE button. Keep holding them
down until the display says SET.
2
Press the INFO button.The Device Name will
appear (blink twice) followed by the three digit
number.
22
URC-100
The Optional Expander
You can use the Unifier as you would your other
remote controls. It transmits very powerful line-of-sight
output using infrared light commands (invisible to the
naked eye). When you point the Unifier at the
components, expect the range to be between 30 and
50 feet. When the remote is not pointed in the general
direction of the components, the range will vary
(depending on reflective surfaces, lighting, etc.).
However, the Unifier also sends radio signals in
every direction. By purchasing the optional Expander
(a radio receiver), you can operate your equipment
with the Unifier 50 to 100 feet away (through walls,
doors, cabinets, inside or outside). Since the
Expander picks up the Unifier's radio signals from
any direction, regardless of distance, the Unifier
doesn’t have to be pointed!
Nothing has to be done to the Unifier for this
feature to work. Every time you press a button on the
Unifier, it sends both a standard infrared command
AND a radio signal. If you install the Expander kit, the
MRF-100 will receive the Unifier’s radio signals and
translate them into the infrared commands that control
your components.
Note: The Unifier's radio signals will not control
components directly. You must have an Expander to
receive the Unifier's radio signals. Components
that came with "no pointing" radio remote controls cannot
be operated by the Unifier unless the component can
be switched to standard infrared control via its internal
menus. Some remote control ceiling fans are radio only and
cannot be operated by the Unifier.
23
The Unifier
The Unifier sends
radio signal to the
Expander, which is a
radio receiver.
The Expander converts radio signals to standard
infrared commands and sends them out via a
built-in front blaster to components in the same
cabinet space.
Self-adhesive “flashers” (included in the
Expander kit) affix to the front panels of
your components. The flashers relay
infrared commands to components outof-sight of the MRF-100 front blaster.
The flashers plug into the MRF-100 rear
flasher line output jacks. Each flasher
has a 10’ cable to easily reach components on nearby shelves.
24
URC-100
Pre-Programmed Code Tables
The Unifier’s Pre-Programmed code library is classified
by category (TV, VCR, AUX, etc.). Each category actually
includes many types of components. For example, the
SAT category includes satellite receivers and digital video
recorders like TiVo and Replay.
Within each category, the code numbers are listed in
rows by brand (Sony, Panasonic, B & K, etc.). Some
brands have more than one three digit code for you to
try. Just circle the correct row and refer to it while you
setup (step-by-step instructions for using Pre-Programmed
codes are found on page 5).
TV
TVs, Plasmas,
Projectors and Monitors
Pages 38-42
CABLE
Cable TV and Web TV
Pages 45-47
DVD
DVD Players
and Laser Disc Players
Pages 32-34
VCR
VCRs and TV/VCR Combo
Pages 42-45
AUDIO
Amps, Preamps
and A/V Receivers
Pages 26-29
SAT
Satellite Receivers, TiVo,
Replay and other DVR’s
Pages 36-38
CD
CD Players and Changers
Pages 29-31
AUX
Tape Decks, Lighting Controls,
Custom Installation Products
Pages 34-36
NOTE: Following each Code Table is a Command Locator.
Use the Command Locator to locate the additional
commands that are accessed via the SHIFT button.
25
AUDIO - Amps, Preamps and Receivers
BRAND
ADC
ADCOM
AIWA
AKAI
AMC
AMEND
AMX
ANGSTROM
ANTHEM
ARCAM
ATLANTIC TECHNOLOGY
AUDIO ACCESS
AUDIO ALCHEMY
AUDIO DESIGN
AUDIO EASE
AUDIO FILE
AUDIO MATRIX
AUDIO SOURCE
AUDIO TECHNICA
B&K
BOSE
BRYSTON
CARVER
CASIO
CHIRO
CINEMA SOUND
CITATION
CLARION
COMPAQ
CURTIS MATHES
DENON
EIGER
ELAN
ENLIGHTENED AUDIO
ESCIENT
FANFARE
FISHER
FLEXTRONICS
FOSGATE
FOSGATE AUDIONICS
GE
GOLDSTAR
HAFLER
HARMAN KARDON
HITACHI
IMERGE
INKEL
INTEGRA
JBL
JCPENNEY
JEFF ROWLAND
JENSEN
JVC
KENWOOD
KINERGETICS
KLH
THREE DIGIT SETUP NUMBERS
007
082 092 225 161 269 355 356 366
170 018 104 202 203 213 211 188
138 189
125 126 127 128 258 281 282 038
054
196
142
335 336 337 338 339
141
342
147
135
194 221 011
021 196 207
071
167
273
134
096 097
070 170 224 347
023
006 028 061 071 201 214 226 180 185 022 029 077 284
076
140
034 134
148 272
026
382
076
002 034 109 215 229 230 027 037 234 259 330 340 341 349 350
149
057 290
099 098
368
352
047 214 180 182 297
378
062 231
342
056 260
008
174
231 233 254 153 154 118 121 227 277 317 318 365
020
371
197
354
263
076 216
206
058
240 163 191 114 266 279 291
005 026 066 145 146 151 180 181 182 190 192 197 199 222 280
220 140
331
26
AUDIO (continued) - Amps, Preamps and Receivers
BRAND
KOSS
KRELL
KYOCERA
LEXICON
LINN
LUXMAN
LXI
MAGNAVOX
MARANTZ
MCINTOSH
MCS
MERIDIAN
MITSUBISHI
MONDIAL
MYRYAD
NAD
NAKAMICHI
NEC
NIRO
ONKYO
OPTIMUS
OUTLAW
PANASONIC
PARASOUND
PHAST
PHILIPS
PIONEER
POLKAUDIO
PROCEED
RCA
REALISTIC
REQUEST
REVOX
ROTEL
SAMSUNG
SANSUI
SANYO
SCOTT
SEARS
SHARP
SHERWOOD
SONY
SOUNDESIGN
SOUNDMATTERS
SOUNDSTREAM
SSI
SUMO
SUNFIRE
TAEKWANG
TEAC
TECHNICS
THETA DIGITAL
TOSHIBA
WARDS
YAMAHA
ZENITH
THREE DIGIT SETUP NUMBERS
216
150 072 376
007
120 235 236 237 357 358 359 360 361 362 363 364
124 377
137 139 052 165 115 004 009
076 056
086 164 152 208
006 028 031 040 063 185 186 251 265 119 289 296
238 286
076
100 012 013
242 243 204
157 158 042 043 081 112
276 293
186 113 283
111 244 245 172 183 287
176
343
017 046 064 107 108 187 079 080 090 179 209 270 275
026 041 138
342
032 195 219 177 292
129 130 132 261 294 295 333 334
196
249 250 251 063 119
014 033 039 044 045 050 069 159 168 116 035 078 198
029
144 268
010 048 117 156 067 288
019 056 073 075 095
351
162
074 083 085
016
040 048 110 119 065 228
047 059
019 091
076
026 094 131 175 181
024 038 055 102 103 105 106 051 030
018 093 223 247 248 160 166 015 101 184 218 271 353 369 372
036
375
084 088
068
171
344 345 346
138
005 019 049 111 212 217
122 176 193 219 178 177 200 257 262
136
060 087 198 278
180
026 253 169 067 173 205 264 232 089 264 274 285 332 373
143 210
27
AUDIO COMMAND LOCATIONS
COMMAND
Power/Off
Power/On
Vol+
VolMute
Preset+
PresetSCAN
BAND,FM/AM
MODE
DISPLAY
OSD
CLEAR
UP
DOWN
SELECT
LEFT
RIGHT
1
2
3
4
5
6
7
8
9
0
10
Enter
Mode+
Sub+
Center+
Rear+
ModeSubCenterRearTUNER Input
CD Input
DVD Input
AUX Input
Video 3 Input
Video 2 Input
Video 1 Input
TAPE Input
HALL
THEATER
CATHEDRAL
PARTY
NIGHT CLUB
CHURCH
JAZZ
DISCO
OPERA/ARENA
SLEEP
BUTTON LOCATION
OFF
ON
VOL+
VOLMUTE
CH+
CHPREV CH
T/V
MENU
GUIDE
INFO
EXIT
UP
DOWN
SELECT
LEFT
RIGHT
1 /SLEEP
2 /6.7 CH
3 / TEST
4/ THX
5 / DD
6 / DTS
7 / LOGIC
8 / ST
9 / SURR
0 / TAPE 2
+10 / VCR 4
ENTER / PH
MODE+
SUB+
CENTER+
REAR+
MODESUBCENTERREARPress SHIFT first, then press AUD button.
Press SHIFT first, then press CD button.
Press SHIFT first, then press DVD button.
Press SHIFT first, then press AUX button.
Press SHIFT first, then press SAT button.
Press SHIFT first, then press TV button.
Press SHIFT first, then press VCR button.
Press SHIFT first, then press CBL button.
Press SHIFT first, then press MENU button.
Press SHIFT first, then press GUIDE button.
Press SHIFT first, then press INFO button.
Press SHIFT first, then press EXIT button.
Press SHIFT first, then press UP button.
Press SHIFT first, then press DOWN button.
Press SHIFT first, then press SELECT button.
Press SHIFT first, then press LEFT button.
Press SHIFT first, then press RIGHT button.
Press SHIFT first, then press 1/SLEEP button.
28
AUDIO COMMAND LOCATIONS
COMMAND
5/6/7 CH
TEST
THX
DOLBY DIGITAL
DTS
LOGIC 7
STEREO
SURR
TAPE2 Input
Video 4 Input
PHONO Input
BASS+
TREBLE+
SURR+
DELAY+
BASSTREBLESURRDELAY-
BUTTON LOCATION
Press SHIFT first, then press 2/6.7CH button.
Press SHIFT first, then press 3/TEST button.
Press SHIFT first, then press 4/THX button.
Press SHIFT first, then press 5/DD button.
Press SHIFT first, then press 6/DTS button.
Press SHIFT first, then press 7/LOGIC button.
Press SHIFT first, then press 8/ST button.
Press SHIFT first, then press 9/SURR button.
Press SHIFT first, then press 0/TAPE2 button.
Press SHIFT first, then press +10/VCR4 button.
Press SHIFT first, then press ENT/PH button.
Press SHIFT first, then press MODE+ button.
Press SHIFT first, then press SUB+ button.
Press SHIFT first, then press CENTER+ button.
Press SHIFT first, then press REAR+ button.
Press SHIFT first, then press MODE- button.
Press SHIFT first, then press SUB- button.
Press SHIFT first, then press CENTER- button.
Press SHIFT first, then press REAR- button.
CD - CD Players and Changers
BRAND
ADCOM
AIWA
AKAI
AMC
AMEND
ARCAM
AUDIO ACCESS
AUDIO EASE
AUDIO TECHNICA
BSR
CALIFORNIA AUDIO
CAPETRONIC
CARRERA
CARVER
CASIO
CLARINETTE
CREEK
CROWN
DENON
EMERSON
FISHER
FRABA
GENEXXA
GOLDSTAR
HAITAI
HARMAN KARDON
HITACHI
INKEL
JCPENNEY
JENSEN
THREE DIGIT SETUP NUMBERS
062 042
059 065 088 089 105 122 170 187
085 195 202
231 232
118
238
119 147
165
046
037 057
103 008
063
057 080
185 041 044 050 086 107 130 134 135 138 139 203 204 167
111 182
182
159
035
002 123
042 069 102
050 185 134 008
111
010 069 102
080
093
018 033 047 208
042 175
130 143 144
014 061 092 141
158
29
CD (continued) - CD Players and Changers
BRAND
JVC
KENWOOD
KOSS
KRELL
KYOCERA
LOTTE
LUXMAN
LXI
MAGNAVOX
MARANTZ
MCINTOSH
MCS
MEMOREX
MISSION
MITSUBISHI
MITSUMI
MODULAIRE
MONDIAL
MYRYAD
NAD
NAKAMICHI
NEC
NIKKO
NSM
ONKYO
OPTIMUS
PANASONIC
PARASOUND
PHILIPS
PIONEER
PROCEED
PROTON
QUASAR
RADIO SHACK
RCA
REALISTIC
ROTEL
SAE
SANSUI
SANYO
SCOTT
SHARP
SHERWOOD
SIGNATURE
SONY
SOUNDESIGN
SUMO
SYLVANIA
SYMPHONIC
TAEKWANG
TANDY
TEAC
TECHNICS
TECHWOOD
THETA DIGITAL
TOSHIBA
THREE DIGIT SETUP NUMBERS
004 022 136 163 213 214 242 243
185 007 023 055 071 072 142 137 254
061
241
005
102
011 028 070 076 249 252
059
044 107
027 041 044 051 077 107 209 246
212 247
014 073 092
010
044 107
179
153
182
147
244 155
006 005 067 178
217 218 219 095
014 062
046
044 107
030 038 039 168 169
010 050 057 058 081 082 083 085 093 195
103 201 172 008 068 248
233 240
041 044 107 246 253
010 020 025 056 174 175 176
239
044 107 228
103 008
182
017 042 150
042 050 051 102 181 182 187
044 107 161 178 250
044 107
044 069 107 128 171 190 125
050
069 102
026 031 051 066
003 019 051 096 112 115 119 166
033
048 081 097 126 133 177 225 226 164
251
155
044 107
052 181
195 085
010
015 034 036 051 052 101 131 140 079
060 103 200 172 184 008 068
076
234 235
006 067 091 160 148
30
CD (continued) - CD Players and Changers
BRAND
VECTOR RESEARCH
VICTOR
WARDS
YAMAHA
YORX
THREE DIGIT SETUP NUMBERS
080
004 022 114 124
185 033
024 046 054 186 183 245
182
CD COMMAND LOCATIONS
COMMAND
BUTTON LOCATION
Power/Off
Power/On
Track+
TrackEJECT
RANDOM
EDIT
PROGRAM
DISPLAY
CLEAR
UP
DOWN
SELECT
LEFT
RIGHT
Scan- / REW
Scan+ / FF
Stop
Play
Pause
1
2
3
4
5
6
7
8
9
0
10
Enter
DISC1
DISC2
DISC3
DISK SKIP+
DISC4
DISC5
DISC6
DISK SKIPREPEAT
INTRO
DISC
TIME
OFF
ON
CH+
CHPREV CH
T/V
MENU
GUIDE
INFO
EXIT
UP
DOWN
SELECT
LEFT
RIGHT
REW
FF
STOP/REC
PLAY
PAUSE
1 /SLEEP
2 /6.7 CH
3 / TEST
4/ THX
5 / DD
6 / DTS
7 / LOGIC
8 / ST
9 / SURR
0 / TAPE 2
+10 / VCR 4
ENTER / PH
MODE+
SUB+
CENTER+
REAR+
MODESUBCENTERREARPress SHIFT first, then press 1/SLEEP button.
Press SHIFT first, then press 2/6.7CH button.
Press SHIFT first, then press 3/TEST button.
Press SHIFT first, then press 4/THX button.
31
DVD - DVD Players and Changers
BRAND
THREE DIGIT SETUP NUMBERS
AIWA
ALPINE
APEX DIGITAL
DENON
FUNAI
GE
GOVIDEO
HARMAN KARDON
HITACHI
INTEGRA
JVC
KENWOOD
KLH
KRELL
LEXICON
LG
MAGNAVOX
MARANTZ
MERIDIAN
MITSUBISHI
MYRYAD
NAD
NAKAMICHI
ONKYO
PANASONIC
PHILIPS
PIONEER
PROCEED
PROSCAN
RCA
SAMSUNG
SANSUI
SANYO
SHARP
SONY
SYLVANIA
SYMPHONIC
TATUNG
THOMPSON
TOSHIBA
VENTURER
YAMAHA
ZENITH
146
098
087 111 115
007 080
143
026 027
137
084 140
101
142
012
151
135
104
148
091 057 074
066 096
083 095
153
017
102 134
088
103
076 035
021 042 138 139 144 150
066 083 095 105
023 092 099 107 108 131
086
026 027
026 027
056 070 119
154
147
094
033 118 145
143
143
102
026 027
035 034 130 141
149
042 089
057 074 091
DVD (continued) - Laser Disc Players
BRAND
DENON
FUNAI
KENWOOD
MAGNAVOX
MARANTZ
MITSUBISHI
NAD
THREE DIGIT SETUP NUMBERS
206 207
120
152 013
032 121
211
121
121
32
DVD (continued) - Laser Disc Players
BRAND
OPTIMUS
PANASONIC
PHILIPS
PIONEER
RADIO SHACK
RCA
REALISTIC
RUNCO
SANYO
SHARP
SONY
TECHNICS
THETA DIGITAL
TOSHIBA
YAMAHA
THREE DIGIT SETUP NUMBERS
049 013
113
032
106 117 121
120
002
049
127
075
152 013
053 110
113
032
152 106
043 129
DVD COMMAND LOCATIONS
COMMAND
BUTTON LOCATION
Power/Off
Power/On
Skip+
SkipEJECT
MENU
PROGRAM
DISPLAY
CLEAR
Up
Down
Select
Left
Right
Scan- / REW
Scan+ / FF
Stop
Play
Pause
1
2
3
4
5
6
7
8
9
0
10
Enter
REPEAT
A/B REPEAT
RANDOM
RETURN
TITLE
OFF
ON
CH+
CHPREV CH
MENU
GUIDE
INFO
EXIT
UP
DOWN
SELECT
LEFT
RIGHT
REW
FF
STOP/REC
PLAY
PAUSE
1 /SLEEP
2 /6.7 CH
3 / TEST
4/ THX
5 / DD
6 / DTS
7 / LOGIC
8 / ST
9 / SURR
0 / TAPE 2
+10 / VCR 4
ENTER / PH
MODE+
SUB+
CENTER+
REAR+
MODE-
33
DVD COMMAND LOCATIONS
COMMAND
TIME
MEMO
AUDIO
STEP+
STEPTOP MENU
SETUP
SEARCH
SLOWSLOW+
REC
ANGLE
SUB ON/OFF
SUBTITLE
SURR
ZOOM
BUTTON LOCATION
SUBCENTERREARPress SHIFT first, then press CH+
Press SHIFT first, then press CHPress SHIFT first, then press MENU
Press SHIFT first, then press GUIDE
Press SHIFT first, then press INFO
Press SHIFT first, then press REW
Press SHIFT first, then press FF
Press SHIFT first, then press STOP/REC
Press SHIFT first, then press 1/SLEEP button.
Press SHIFT first, then press 2/6.7CH button.
Press SHIFT first, then press 3/TEST button.
Press SHIFT first, then press 4/THX button.
Press SHIFT first, then press 5/DD button.
Press SHIFT first, then press 6/DTS button.
AUX - Tape Decks
BRAND
AIWA
CARVER
DENON
FISHER
GOLDSTAR
HARMAN KARDON
JVC
KENWOOD
LINN
LUXMAN
MAGNAVOX
MARANTZ
MCINTOSH
MITSUBISHI
NAD
NAKAMICHI
ONKYO
OPTIMUS
PANASONIC
PHILIPS
PIONEER
QUASAR
SANSUI
SHARP
SHERWOOD
SONY
TEAC
TECHNICS
TOSHIBA
VICTOR
YAMAHA
THREE DIGIT SETUP NUMBERS
015 071 100 114
006 008 027 024 036
105 227 229
064
011
233
106 116 239 240
005 013 023 026 064 145 146 181 190
124
035 137 139
027
014 027 056 065 087
238
242 243
029 048
244 245 025
002 012 016 017 018 019 115
026 054 055
007 010 032 088 195
027 087
003 039 047 050 066 098 222
007 088
027 113 119 224
026 057 131 175 181
038 004 028 030 033 034
020 022 052 084 089
009 059 212
007 010 076 088 109 122 193
112
106
021 026 031 067 040
34
AUX (continued) - Lighting & Custom Products
BRAND
3M
AIWA
ARCHER
AURORA MULTIMEDIA
AUTON
CELADON
CRESTRON
DMX
DRAPER SCREEN
DREAMVISION
DWIN
EVERQUEST
EXTRON
FAROUDJA
FUJI
HUNTERDOUGLAS
JERROLD
JVC
KENWOOD
LITE-TOUCH
LUTRON
MAKITA
MINDPATH
NILES
NSM
PIANO DISC PLUS
POLKAUDIO
RUSSOUND
SCIENTIFIC ATLANTA
SIMA
SOLO ELECTRONICS
SOMFY
SONY
STARCOM
TURBOSCAN
VELODYNE
X-10
XANTECH
THREE DIGIT SETUP NUMBERS
152
164
155
220
191
221
213 214 215 216 217 218
156
204
097
080 253
206
151
184
209
219
153
185
185
208 257
158 159 077
186 201
205
160 187
161
085
162
081
163 156
082
207
078 079
164 165 166
153
167
203
183 093
168 169 170 171 172 188 189
AUX COMMAND LOCATIONS
COMMAND
BUTTON LOCATION
Power/Off
Power/On
VOL+
VOLMUTE
(A)REW
(A)FF
(A)STOP
(A)PLAY
(A)PAUSE
1
2
3
OFF
ON
VOL+
VOLMUTE
REW
FF
STOP/REC
PLAY
PAUSE
1 /SLEEP
2 /6.7 CH
3 / TEST
35
AUX COMMAND LOCATIONS
COMMAND
BUTTON LOCATION
4
5
6
7
8
9
0
10
Enter
(B)FF
(B)PLAY
(B)PLAY BACK
DECK A
(B)REW
(B)STOP
(B)REC
DECK B
(A)REC
(A)PLAY BACK
DIRECTION A
DIRECTION B
4/ THX
5 / DD
6 / DTS
7 / LOGIC
8 / ST
9 / SURR
0 / TAPE 2
+10 / VCR 4
ENT/PH
MODE+
SUB+
CENTER+
REAR+
MODESUBCENTERREARPress SHIFT first, then press STOP/REC
Press SHIFT first, then press PLAY
Press SHIFT first, then press REAR+
Press SHIFT first, then press REAR-
SAT - Satellite Receivers
BRAND
ALPHASTAR
AMPLICA
BIRDVIEW
BSR
CABLEVISION / VOOM
CAPETRONICS
CHANNEL MASTER
CHAPARRAL
CITOH
CURTIS MATHES
DRAKE
DX ANTENNA
ECHOSTAR / DISH
ELECTROHOME
EUROSAT
EXPRESSVU
FUJITSU
GENERAL ELECTRIC
GENERAL INSTRUMENT
GOI
HITACHI
HOME CABLE
HOUSTON TRACKER
HTS
HUGHES
HYTEK
HYUNDAI
ICR
JANIEL
JVC
THREE DIGIT SETUP NUMBERS
123
050
129 113 051 126
053
148
053
013 014 015 018 036 055
008 009 012 077
054
050
005 006 007 010 011 112 116 141 052
056 024 046 076
122 038 040 057 058 093 094 095 096 097 098 099 100
089
114
122
017 021 022 027 133 134
151 106 150
003 004 016 029 031 059 101 148
122
139 140
080 044 029
033 037 039 104 057 051
122
161 162 068 154 165 166
053
149
023
147
122
36
SAT (continued) - Satellite Receivers
BRAND
KATHREIN
LEGEND
LUTRON
LUXOR
MACOM
MAGNAVOX
MARANTZ
MEMOREX
MITSUBISHI
MOTOROLA
NEXT LEVEL
NEXTWAVE
NORSAT
PACE
PANASONIC
PANSAT
PAYSAT
PERSONAL CABLE
PHILIPS
PL
PRESIDENT
PRIMESTAR
PROSAT
PROSCAN
RADIOSHACK
RCA
REALISTIC
SAMSUNG
SATELLITE SERVICE
SKY
SONY
STARCAST
STAR CHOICE
SUPERGUIDE
TEECOM
TOSHIBA
TOWN & COUNTRY
UNIDEN
VIEWSTAR
WINEGARD
ZENITH
THREE DIGIT SETUP NUMBERS
108
057
132
144 062
059 010 063 064 065
136
152 153
057 136
068 154
148
148
028 124 125
069 070
143
142 160
121
136
117
152 153 156 068 154 136
023 026
019 102
110 030
072
151 106 150
148
151 106 150
043 074
123 155 163
028 035 047 085
164
103
041
148
020 124 125
023 026 075 087 088 090 107 130 137
127 068 154 157 158
023 026
016 025 042 043 044 045 048 049 078 079 080 086 101 135 136
115
128 146
159
SAT (continued) - PVR (TiVo, Replay etc.)
BRAND
ECHOSTAR / DISH
HUGHES
JVC
PHILIPS
RCA
REPLAY NETWORKS
SONY
TIVO
THREE DIGIT SETUP NUMBERS
122
205 207
122
205 202 207
206
201
203 204
202 207
37
SAT COMMAND LOCATIONS
COMMAND
BUTTON LOCATION
Power/Off
Power/On
Vol+
VolMute
Ch+
ChPREV CH
INPUT/ANT
Menu
Guide
Info
Exit
Up
Down
Select
Left
Right
REW
FF
STOP
PLAY
PAUSE
1
2
3
4
5
6
7
8
9
0
10
Enter
FAV
SEARCH
FETCH
VIDEO
ALT AUDIO
PROGRAM
HELP
INTERACTIVE
RECORD
OFF
ON
VOL+
VOLMUTE
CH+
CHPREV CH
TV/ VCR
MENU
GUIDE
INFO
EXIT
UP
DOWN
SELECT
LEFT
RIGHT
REW
FF
STOP/REC
PLAY
PAUSE
1 /SLEEP
2 /6.7 CH
3 / TEST
4/ THX
5 / DD
6 / DTS
7 / LOGIC
8 / ST
9 / SURR
0 / TAPE 2
+10 / VCR 4
ENTER / PH
MODE+
SUB+
CENTER+
REAR+
MODESUBCENTERREARPress SHIFT first, then press STOP/REC
TV - Televisions, Projectors, Monitors
BRAND
ADMIRAL
ADVENT
AKAI
A MARK
THREE DIGIT SETUP NUMBERS
072 081 161 160
247
197 146 248
112 143
38
TV (continued) - Televisions, Projectors, Monitors
BRAND
THREE DIGIT SETUP NUMBERS
AMPRO
AMSTRAD
ANAM
AOC
AUDIOVOX
BARCO
BLAUPUNKT
BROKSONIC
CAIRN
CANDLE
CAPEHART
CETRONIC
CITIZEN
CLASSIC
CONCERTO
CONTEC
CORONADO
CRAIG
CROWN
CURTIS MATHES
CXC
DAEWOO
DAYTRON
DREAMVISION
DWIN
DYNASTY
DYNATECH
EIKI
ELECTROHOME
EMERSON
FISHER
FUJITSU
FUNAI
FUTURETECH
GE
GOLDSTAR
HALL MARK
HITACHI
INFINITY
INFOCUS
JBL
JCPENNEY
JENSEN
JVC
KEC
KENWOOD
KLOSS
KMC
KTV
LG
LODGENET
LOEWE
LOGIK
LUXMAN
LXI
MAGNAVOX
167 073 157 183
052
043 054 056 080 112 131
197 004 112 058
076
233
088
238
201
197 002 003 004
058
043
197 002 003 004 043 101 103 143
043
004
043 050 051
143
043 054
043 143
197 101 004 143
043
004 016 043 044 076 103 114 125 127 143
004 143
235
177 257
043
062
187
143 024 076 196
028 048 043 155 005 197 004 047 050 051 076 096 143 151153 154
007 057
198 246
028 043
043
160 144 165 073 197 008 009 034 056 074 130 155 161 004 091 157 183
113 116 102 004 106 112 119 127 143
004
011 163 166 004 009 010 012 023 075 143 158 072
164
230
164
004 024 197 008 009 030 065 101 143 156 160
013
038 034 070 083 145 199 210 240 241
043
197 070
002 059
143
043 197 143 154
113 116 102 004 106 112 119 127 143
072
164
072
004
166 007 015 052 081 160 164
164 059 197 003 060 061 004 063 064 127 022 160 094 239 256
39
TV (continued) - Televisions, Projectors, Monitors
BRAND
MARANTZ
MATSUI
MEMOREX
METZ
MGA
MINERVA
MITSUBISHI
MTC
NAD
NEC
NIKEI
ONKING
ONWA
OPTONICA
ORION
PANASONIC
PHILCO
PHILIPS
PIONEER
PORTLAND
PROSCAN
PROTON
QUASAR
RADIO SHACK
RCA
REALISTIC
ROCTEC
RUNCO
SAMPO
SAMSUNG
SANYO
SCOTT
SEARS
SELECO
SHARP
SIEMENS
SIGNATURE
SOLE
SONY
SOUNDESIGN
SPECTRICON
SSS
SUPRE MACY
SYLVANIA
TANDY
TATUNG
TECHNICS
TECHWOOD
TEKNIKA
TELEFUNKEN
TELERENT
TERA
TMK
TOSHIBA
TOTEVISION
UNIVERSAL
THREE DIGIT SETUP NUMBERS
197 164 184
164
007 072 004
088
197 004 024 028 042
088
109 124 024 004 028 040 042 146 191
197 004 062 101
015 025
132 130 134 197 040 016 024 056 019 236 237
043
043
043
019 081
096
034 056 080 092 164 208
197 003 059 060 064 164 004 024 056 063
164 005 093 038 197 003 004 059 127 184 206 239
135 025 197 018 023 116 190 234
004 143
144 160 161 165 167
004 131 058 143 171 173 193
034 056 092
019 004 143 043 127
160 165 065 156 144 161 197 004 024 056 152 023 074
007 019 043 047
186
168 169 178 179 180 181 182 183 073 157
197 058 004 202
050 089 101 105 004 127 143 160 228 229
166 007 020 053 057 082 187
028 043 004 048 143
015 030 004 007 028 057 143 094 160 082 165 166
189 200 205 227
081 019 014 170 028 029 004 022 143 175
088
072
231 232
070 139 147 126 185 194 085
028 004 003 043
112
004 043
002
197 003 059 060 063 064 164 044 160 127
081
056 062
034 080
004
002 003 004 024 028 043 072 101 143
037 046 086 087
072
172
004
002 015 138 030 007 040 062 101
143
008 009
40
TV (continued) - Televisions, Projectors, Monitors
BRAND
VIDEO CONCEPTS
VIDIKRON
VIDTECH
WARDS
WESTING HOUSE
YAMAHA
YORK
YUPITERU
ZENITH
ZONDA
THREE DIGIT SETUP NUMBERS
146
174 184 188 192
004
004 008 009 019 028 060 061 063 064 072 074 143 164 034
076
197 004
004
043
073 072 095 103 157 183
112
TV COMMAND LOCATIONS
COMMAND
Power/Off
Power/On
Vol+
VolMute
Ch+
ChPREV CH
TV/VCR
Menu
CH GUIDE
DISPLAY
CANCEL
Up
Down
Select
Left
Right
1
2
3
4
5
6
7
8
9
0
10
Enter
PIP ON/OFF
PIP SWAP
PIP POSITION
PIP CH+
PIP OFF
PIP SIZE
PIP FREEZE
PIP CHINPUT/ANT
CAPTION
BUTTON LOCATION
OFF
ON
VOL+
VOLMUTE
CH+
CHPREV CH
T/V
MENU
GUIDE
INFO
EXIT
UP
DOWN
SELECT
LEFT
RIGHT
1 /SLEEP
2 /6.7 CH
3 / TEST
4/ THX
5 / DD
6 / DTS
7 / LOGIC
8 / ST
9 / SURR
0 / TAPE 2
+10 / VCR 4
ENTER / PH
MODE+
SUB+
CENTER+
REAR+
MODESUBCENTERREARPress SHIFT first, then press TV/VCR
Press SHIFT first, then press MENU
41
TV COMMAND LOCATIONS
COMMAND
AUTO CH
CC
RESET
ADD
DELETE
SLEEP
ASPECT
RGB Input
COMPONENT
MODE
WIDE/SIZE
S-VIDEO Input
VIDEO1 Input
VIDEO2 Input
BUTTON LOCATION
Press SHIFT first, then press GUIDE
Press SHIFT first, then press INFO
Press SHIFT first, then press EXIT
Press SHIFT first, then press UP
Press SHIFT first, then press DOWN
Press SHIFT first, then press 1 /SLEEP
Press SHIFT first, then press 2 /6.7 CH
Press SHIFT first, then press 3 / TEST
Press SHIFT first, then press 4/ THX
Press SHIFT first, then press 5 / DD
Press SHIFT first, then press 6 / DTS
Press SHIFT first, then press 7 / LOGIC
Press SHIFT first, then press 8 / ST
Press SHIFT first, then press 9 / SURR
VCR - Video Cassette Recorders
BRAND
AIWA
AKAI
AMPRO
ANAM
AUDIO DYNAMICS
BROOKSONIC
CANON
CAPEHART
CRAIG
CURTIS MATHES
DAEWOO
DAYTRON
DBX
DYNATECH
ELECTROHOME
EMERSON
FISHER
FUNAI
GE
GO VIDEO
GOLDSTAR
HARMAN KARDON
HITACHI
INSTANTREPLAY
JCL
JCPENNEY
JENSEN
JVC
KENWOOD
LG
LLOYD
LXI
MAGIN
MAGNAVOX
MARANTZ
MARTA
THREE DIGIT SETUP NUMBERS
034 161
016 146 043 046 124 125 142
072
031
012 023 039 043
035 037 129
028 031
108
003 040 135
031 041
111 116 117 119 005 007 010 065 108 110 112
108
012 023 039 043
034 053
059
006 029 035 017 025 027 031 034 036 037 046 101 129 131 138 153 162 116
003 010 008 009
034
031 072 147 063 107 109 144
132 136 155 040 115
101 106 114 013 020 012 123
012 045
004 026 150 018 034 043 063 137 160 013
031
031
012 013 015 040 066 101
043
048 043 130 150 055 060 012 031 050 152 166
014 048 034 047
101 106 114 013 020 012 123
034
034 003 009 017 106
040
067 031 034 068 041 156 164
067 069 012 031 156
101
42
VCR (continued) - Video Cassette Recorders
BRAND
MATSUI
MEI
MEMOREX
MGA
MINOLTA
MITSUBISHI
MTC
MULTITECH
NEC
NORDMENDE
OPTONICA
ORION
PANASONIC
PENTAX
PHILCO
PHILIPS
PILOT
PIONEER
PORTLAND
PULSAR
QUARTZ
QUASAR
RADIO SHACK
RCA
REALISTIC
RICO
RUNCO
SALORA
SAMSUNG
SANSUI
SANYO
SCOTT
SEARS
SHARP
SHINTOM
SIGNATURE
SONY
SOUNDESIGN
STS
SYLVANIA
SYMPHONIC
TANDY
TATUNG
TEAC
TECHNICS
TEKNIKA
THOMAS
TMK
TOSHIBA
TOTEVISION
UNITECH
VECTOR RESEARCH
VICTOR
VIDEO CONCEPTS
VIDEOSONIC
WARDS
THREE DIGIT SETUP NUMBERS
027 030
031
101 003 010 014 031 034 053 072 102 134 139
045 046 059
013 020
059 061 151 013 020 045 046 051 142 049 168
034 040
024 034
012 023 039 043 048
043
053 054
025
066 070 145 083 133 140 157 163 074 167
013 020 031 063
031 034 067
031 067 034 101 054 071 156
101
021 013 048
108
072
002 014
066 145 075
123
107 109 144 147 158 041 145 013 020 140 034 040
003 008 010 014 031 034 040 053 054 101
058
148
014
102 104 113 115 112 120 032 040 066 107 109 122 125
022 043 048 135
003 010 007 014 134 102
017 037 112 129 131
003 008 010 014 081 013 101 009 017 073 112
149 054 031 159 165
024
034
056 057 058 077 052 003 078 076 031 149 154
034
013
031 034 059 067
034
010 034
039 043
034 039 043
031 070
031 019 034 101
034
006
112 131 079 008 059 047 082 013 042 081
040 101
040
012
048
012 034 046 141
040
003 013 017 024 031 034 040 053 054 131
43
VCR (continued) - Video Cassette Recorders
BRAND
YAMAHA
ZENITH
THREE DIGIT SETUP NUMBERS
012 034 039 043
072 080 056 048 101 034 058
VCR COMMAND LOCATIONS
COMMAND
Power/Off
Power/On
Ch+
ChPREV CH
VCR/TV
Menu
GUIDE
DISPLAY
CANCEL
UP
DOWN
SELECT
LEFT
RIGHT
Rew
FF
Stop
Play
Pause
1
2
3
4
5
6
7
8
9
0
10
SLOW
SLOW+
TRK+
PROGRAM
AUTO TRK
SLOWTRKRESET
INPUT
Record
X2 PLAY
EJECT
SLEEP / TIMER
CLOCK/COUNT
RESET
AUTO CH
F.ADV
VCR PLUS
BUTTON LOCATION
OFF
ON
CH+
CHPREV CH
TV/VCR
MENU
GUIDE
INFO
EXIT
UP
DOWN
SELECT
LEFT
RIGHT
REW
FF
STOP/REC
PLAY
PAUSE
1 /SLEEP
2 /6.7 CH
3 / TEST
4/ THX
5 / DD
6 / DTS
7 / LOGIC
8 / ST
9 / SURR
0 / TAPE 2
+10 / VCR 4
MODE+
SUB+
CENTER+
REAR+
MODESUBCENTERREARPress SHIFT first, then press TV/VCR
Press SHIFT first, then press STOP/REC
Press SHIFT first, then press PLAY
Press SHIFT first, then press PAUSE
Press SHIFT first, then press 1/SLEEP button.
Press SHIFT first, then press 2/6.7CH button.
Press SHIFT first, then press 3/TEST button.
Press SHIFT first, then press 4/THX button.
Press SHIFT first, then press 5/DD button.
Press SHIFT first, then press 6/DTS button.
44
VCR COMMAND LOCATIONS
COMMAND
INDEX
ADD
DELETE
TAPE SPEED
BUTTON LOCATION
Press SHIFT first, then press 7/LOGIC button.
Press SHIFT first, then press 8/ST button.
Press SHIFT first, then press 9/SURR button.
Press SHIFT first, then press 0/TAPE2 button.
CBL - Cable TV and Web TV
BRAND
ABC
ADELPHIA
ADVANCED NEWHOUSE
ALTRIO
AMERICAST
ARCHER
ARMSTONG
AT&T BROADBAND
ATLANTIC BROADBAND
BELL SOUTH
BLUE RIDGE
BRESNAN
BUCKEYE COMM
CABLEVISION
CENTURION
CENTURY
CHARTER
CITIZEN
COGECO
COMBANO
COMCAST
COMSAT
COX DIGITAL
DIGICABLE
EAGLE
EASTERN
ECHOSTAR
ELECTRICORD
GEMINI
GENERAL ELECTRIC
GENERAL INSTRUMENT
GNC
GOLDEN CHANNEL
HAMLIN
HITACHI
INSIGHT
JERROLD
MAGNAVOX
MASSILLON
MEDIA ONE
MEDICOM
MEMOREX
MITSUBISHI
MOTOROLA
MOVIE TIME
NCTC
THREE DIGIT SETUP NUMBERS
004 103 003 039 042 046 053
043 074
043
043
099
005 007 014
074
074
043 074
099
043 074
074
074
043 074 108
092
007
043 074
007
074
080 081
043 074
074
043 074
101
020 030 040
057 066
106
032
008 054
072
074 103 104
099
030
049 050 055
103 055
074
074 004 103 002 003 008 009 010 069
010 012 064 079 095 094
074
107
074
052
102
074
028 032
074
45
CBL (continued) - Cable TV and Web TV
BRAND
THREE DIGIT SETUP NUMBERS
NSC
OAK
PACE
PANASONIC
PARAGON
PHILIPS
PIONEER
PRUCER
PULSAR
RCA
RCN
RECOTON
REGAL
REGENCY
RODGERS
SAMSUNG
SCIENTIFIC ATLANTA
SEREN
SERVICE ELECTRIC
SHAW
SIGECOM
SONY
SPRUCER
STARCOM
STARGATE
SUSQUEHANNA
TIME WARNER
TOCOM
TOSHIBA
UNITED CABLE
UNIVERSAL
VIDEOTRON
VIEWSTAR
Wide Open West
ZENITH
015 028 038 071
031 037 053
043 074
044 047
052
006 012 013 020 085 095
043 103 034 051 063 076 105
059
052
047
074
098
049 050
057
043
030
043 011 003 041 042 045 046
043
074
074
043
096 108
047 078
002 004 008 009
008 030 097 104
043 074
043 074
039 040 056
052
004 053
005 007 014 032 035
043
012 015 018 086 087 088 089
043 099
052 060 093 100
CABLE COMMAND LOCATIONS
COMMAND
BUTTON LOCATION
Power/Off
Power/On
Vol+
VolMute
Ch+
ChLAST
BYPASS
Menu
Guide
Info
Exit
UP
OFF
ON
VOL+
VOLMUTE
CH+
CHPREV CH
T/V
MENU
GUIDE
INFO
EXIT
UP
46
CABLE COMMAND LOCATIONS
COMMAND
DOWN
SELECT
LEFT
RIGHT
REW
FF
STOP
PLAY
PAUSE
1
2
3
4
5
6
7
8
9
0
10
Enter/MUSIC
FAV
DAY+
PAGE+
HELP
LOCK / PPV
DAYPAGESETTING
RECORD
A
B
C
BUTTON LOCATION
DOWN
SELECT
LEFT
RIGHT
REW
FF
STOP/REC
PLAY
PAUSE
1 /SLEEP
2 /6.7 CH
3 / TEST
4/ THX
5 / DD
6 / DTS
7 / LOGIC
8 / ST
9 / SURR
0 / TAPE 2
+10 / VCR 4
ENTER / PH
MODE+
SUB+
CENTER+
REAR+
MODESUBCENTERREARPress SHIFT first, then press STOP/REC.
Press SHIFT first, then press 1/SLEEP button.
Press SHIFT first, then press 2/6.7CH button.
Press SHIFT first, then press 3/TEST button.
47
URC-100
Frequently Asked Questions
Why does the display change whenever you
press the buttons at the top of the remote?
The Unifier is actually eight remote controls in one. The
LCD display shows you which of your components it is
currently set to control. When you press one of the
eight DEVICE buttons (those labeled AUDIO, CD,
DVD, etc.), the Unifier changes the functions of all of
other buttons to control that component.
Why does the display flash at me sometimes?
The Unifier has an extra “hidden” command (usually a
power user or hobbyist feature) on some of your
buttons. This command is issued instead of the normal
command if you press the SHIFT button first. Once you
have pressed the SHIFT button, the display will flash
for ten seconds. If you press it by accident, you can
stop the SHIFT flashing by pressing the SHIFT button or
the LIGHT button.
Can I program the Unifier on a computer?
No, the Unifier is only programmed by the methods
explained in this manual and the Quick Setup DVD
tutorial.
What is a “Macro”?
A “macro” is a very useful way to make a lot of things
happen with one button push. For example, in most
home theaters to watch television, the user must turn
on the TV, then turn on the Cable Box or the Satellite
Receiver, then turn on the Surround Sound system for
sound. Instead of pressing all of those buttons one at a
48
The Unifier
time, the Unifier enables you to “record” all of them to
play back with one button push. For more information
on how and why you should program macros, watch
the Quick Setup DVD tutorial or read pages 17-18.
If the batteries run out, will I lose my settings?
No. The Unifier stores all of your settings in non-volatile
FLASH memory. You could remove the batteries for
months, replace them at your convenience and the
Unifier would still remember your settings.
Who can I call for more answers?
The Universal Remote Control technical support and
customer service staff are ready to answer any
questions you might have.
Call us at 1-914-835-4484
Monday - Friday, 9AM to 6PM (EST)
49
URC-100
Warranty
The URC-100 is covered against any manufacturers
defects or workmanship for a period of one year from
the date of purchase if purchased from an authorized
Universal Remote Control dealer. Units purchased
from online auction sites or other unauthorized
resellers have no warranty. This warranty does not
cover the following items:
- Damage from misuse, neglect, or acts of nature.
- Products that have been modified or incorporated into
other products.
- Products purchased more than 12 months ago.
- Units purchased from unauthorized dealers or
companies.
Specifications
Learning Capability - 424 IR commands at standard
frequencies (15kHz to 100kHz)
Macro Capability - 24 Macros of up to 50 steps each
IR Range (Line of Sight via Infrared): 30-50 feet,
depending on the environment
RF Range (radio frequency): 50 to 100 feet, depending
upon the environment
RF Frequency: 418MHz
Weight: 8 oz. (with batteries)
Size: 8.5” x 2.5” x 1”
Batteries: Four AAA Alkaline batteries included
LCD Size: 1.26” x 0.4”
50
MEMO
MEMO
MEMO
OCE-0023A Rev. 05
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
