congratulations...
on your purchase of a Pyle Gear X Series amplifier.
This amplifier extends the Pyramid tradition into
a totally new series of amps, designed from the
ground up to deliver the power, performance and
flexibility the modern car audio enthusiast demands.
When you check the list of features offered by the
PLA-219, PLA-419, PLA-2150, PLA-2250, PLA-2350,
PLA-2450, PLA-2550, PLA-2650, PLA-2750, PLA2850, PLA-4150, PLA-4250, PLA-4350, PLA-4300D
you’ll know you made the right choice with a Pyle
Power amplifier.
table of contents
general features 2-6
features and specifications
PLA-219
PLA-419
PLA-2150/PLA-2250/PLA-2350
PLA-2450/PLA-2550/PLA-2650
PLA-2750/PLA-2850
PLA-4150/PLA-4250/PLA-4350
PLA-4300D
7-8
9-10
11-14
2/4 channel input connections
PLA-419 24-25
high level input connections
PLA-4150/PLA-4250/PLA-4350 27
mono input connections
PLA-4150/PLA-4250/PLA-4350 28
15-16
17-18
electrical connections
PLA-219/PLA-419/PLA-2150/PLA-2250 19-20
PLA-2350/PLA-2450/PLA-2550
PLA-2650/PLA-2750/PLA-2850
PLA-4150/PLA-4250/PLA-4350
PLA-4300D
stereo input connections
PLA-219/PLA-2150/PLA-2250/PLA-2350 21-22
PLA-2450/PLA-2550/PLA-2650
PLA-2750/PLA-2850
mono input connections
PLA-2150/PLA-2250/PLA-2350 23
PLA-2450/PLA-2550/PLA-2650
PLA-2750/PLA-2850
high level mono input connections
PLA-4150/PLA-4250/PLA-4350 29
system wiring 30
PLA-4300D
speaker connections
PLA-2150/PLA-2250/PLA-2350 31
PLA-2450/PLA-2550/PLA-2650
PLA-2750/PLA-2850
speaker connections
PLA-419/PLA-4150 32-33
PLA-4250/PLA-4350
mounting and installation 34
protection circuitry and troubleshooting 35
precautions 36
1
general features
PLA-219
PLA-419
PLA-2150
· 120 Watts x 2 Output
· 100 Watts x 4 Output
· 300 Watts x 2 Output
· Variable Input Level (Gain) Control
· Variable Input Level (Gain) Control
· 600 Watts x 1 Bridged Output
· Remote Turn On/Off
· Remote Turn On/Off
· Variable Hi/Lo Electronic Crossover Network
· Gold Plated RCA Inputs
· Gold Plated RCA Inputs
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· High Level MOLEX Input
· High Level MOLEX Input
· Variable Input Level (Gain) Control
· Power ON LED Indicator
· Power ON LED Indicator
· Remote Turn On/Off
· S/N Ratio: > 95 dB
· S/N Ratio: > 95 dB
· Gold Plated RCA Inputs
· THD: <0.04%
· THD: <0.04%
· High Level MOLEX Input
· Thermal Protection
· Thermal Protection
· Power ON LED Indicator
· Overload Protection
· Overload Protection
· LED Protection Indicator
· Short Circuit Protection
· Short Circuit Protection
· S/N Ratio: > 95 dB
· Anti-Thump Turn-On
· Anti-Thump Turn-On
· THD: <0.04%
High Performance 240 Watt 2 Channel Amplifier
High Performance 400 Watt 4 Channel Amplifier
High Performance 600 Watt 2 Channel
Bridgeable MOSFET Amplifier
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
2
general features
PLA-2250
PLA-2350
PLA-2450
· 500 Watts x 2 Output
· 600 Watts x 2 Output
· 700 Watts x 2 Output
· 1000W x 1 Bridged Output
· 1200W x 1 Bridged Output
· 1400W x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Hi/Lo Electronic Crossover Network
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Variable Input Level (Gain) Control
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Remote Turn On/Off
· Remote Turn On/Off
· Gold Plated RCA Inputs
· Gold Plated RCA Inputs
· Gold Plated RCA Inputs
· High Level MOLEX Inputs
· High Level MOLEX Inputs
· High Level MOLEX Inputs
· Power ON LED Indicator
· Power ON LED Indicator
· Power ON LED Indicator
· LED Protection Indicator
· LED Protection Indicator
· LED Protection Indicator
· Remote Bass Boost
· Remote Bass Boost
· Remote Bass Boost
· S/N Ratio: > 95 dB
· S/N Ratio: > 95 dB
· S/N Ratio: > 95 dB
· THD: <0.04%
· THD: <0.04%
· THD: <0.04%
· Thermal Protection
· Thermal Protection
· Thermal Protection
· Overload Protection
· Overload Protection
· Overload Protection
· Short Circuit Protection
· Short Circuit Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Anti-Thump Turn-On
· Anti-Thump Turn-On
High Performance 1000 Watt 2 Channel
Bridgeable MOSFET Amplifier
High Performance 1200 Watt 2 Channel
Bridgeable MOSFET Amplifier
High Performance 1400 Watt 2 Channel
Bridgeable MOSFET Amplifier
3
general features
PLA-2550
PLA-2650
PLA-2750
· 800 Watts x 2 Output
· 900 Watts x 2 Output
· 1200 Watts x 2 Output
· 1600 Watts x 1 Bridged Output
· 1800 Watts x 1 Bridged Output
· 2400 Watts x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Hi/Lo Electronic Crossover Network
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Variable Input Level (Gain) Control
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Remote Turn On/Off
· Remote Turn On/Off
· Gold Plated RCA Inputs
· Gold Plated RCA Inputs
· Gold Plated RCA Inputs
· High Level MOLEX Input
· High Level MOLEX Input
· High Level MOLEX Input
· Power ON LED Indicator
· Power ON LED Indicator
· Power ON LED Indicator
· LED Protection Indicator
· LED Protection Indicator
· LED Protection Indicator
· Remote Bass Boost
· Remote Bass Boost
· Remote Bass Boost
· S/N Ratio: > 95 dB
· S/N Ratio: > 95 dB
· S/N Ratio: > 95 dB
· THD: <0.04%
· THD: <0.04%
· THD: <0.04%
· Thermal Protection
· Thermal Protection
· Thermal Protection
· Overload Protection
· Overload Protection
· Overload Protection
· Short Circuit Protection
· Short Circuit Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Anti-Thump Turn-On
· Anti-Thump Turn-On
High Performance 1600 Watt 2 Channel
Bridgeable MOSFET Amplifier
High Performance 1800 Watt 2 Channel
Bridgeable MOSFET Amplifier
High Performance 2400 Watt 2 Channel
Bridgeable MOSFET Amplifier
4
general features
PLA-2850
PLA-4150
PLA-4250
· 2000 Watts x 2 Output
· 250 Watts x 4 Output
· 350 Watts x 4 Output
· 4000 Watts x 1 Bridged Output
· 500 Watts x 2 Bridged Output (250Wx2+500Wx1)
· 700 Watts x 2 Bridged Output (350Wx2+700Wx1)
· Variable Hi/Lo Electronic Crossover Network
· Dual Variable Hi/Lo Electronic Crossover Network
· Dual Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Dual Variable Bass Boost (0 - +18 dB @ 60Hz)
· Dual Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Variable Input Level (Gain) Control
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Remote Turn On/Off
· Remote Turn On/Off
· Gold Plated RCA Inputs
· Gold Plated RCA Inputs
· Gold Plated RCA Inputs
· High Level MOLEX Input
· High Level MOLEX Input
· High Level MOLEX Input
· Power ON LED Indicator
· Power ON LED Indicator
· Power ON LED Indicator
· LED Protection Indicator
· LED Protection Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Short Circuit Protection
· Anti-Thump Turn-On
· Tri-Mode Configurable
· Anti-Thump Turn-On
High Performance 4000 Watt 2 Channel
Bridgeable MOSFET Amplifier
High Performance 1000 Watt 4 Channel
Bridgeable MOSFET Amplifier
High Performance 1400 Watt 4 Channel
Bridgeable MOSFET Amplifier
· Tri-Mode Configurable
5
general features
PLA-4350
High Performance 2000 Watt 4 Channel
Bridgeable MOSFET Amplifier
4000W Mono Block MOSFET Amplifier
· 500 Watts x 4 Output
· Mono Block Subwoofer Amplifier
· 1000W x 2 Bridged Output (500W x 2+1000W x 1)
· 1 Ohm Stable
· Dual Variable Hi/Lo Electronic Crossover Network
· MOSFET Power Supply
· Dual Variable Bass Boost (0 - +18 dB @ 60Hz)
· PWM (Pulse-Width-Modulation) System
· Variable Input Level (Gain) Control
· Glass Epoxy PCB
· Remote Turn On/Off
· Gold Plated RCA Inputs for Line Input & Bypass Output.
· Gold Plated RCA Inputs
· Gold Plated Terminals for Speaker Output and Power Input.
· High Level MOLEX Inputs
· Thermal, Overload and Short Protection
· Power ON LED Indicator
· Variable Sub-sonic Filter (15Hz~40Hz, 24dB/Octave)
· LED Protection Indicator
· Variable Low-pass Filter (20Hz~250Hz, 24dB/Octave)
· Remote Bass Boost
· Phase Control 0-180 degree
· S/N Ratio: > 95 dB
· Remote Bass Control
· THD: <0.04%
· Input Impedance : 10K Ohms
· Thermal Protection
· Soft Turn On/Off
· Overload Protection
· Advanced Protection Circuitry
· Short Circuit Protection
· S/N Ratio:>90dB
· Anti-Thump Turn-On
· Heavy Duty Power Coated Heatsink
· Tri-Mode Configurable
PLA-4300D
6
features and controls
2 ch amp PLA-219
PLA-219
high level inputs
low level inputs
input level control
speaker connections
power LED
power terminals
power fuse
7
features and specifications
2 ch amp PLA-219
input level control use this control to match the outputs of your head unit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
the amp level control until distortion begins to occur, and reduce slightly
from this point.
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
Maximum Power Output
30 Watts x 2
120 Watts x 2
low level inputs this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
frequency response
15 Hz-30 KHz
high level inputs if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
input impedance
low level inputs
high level inputs
10K Ohms
100 Ohms
input sensitivity
low level inputs
high level inputs
250mV
2.5V
power LED this indicator is illuminated when power is applied.
power fuse the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
power terminals use these connectors to deliver power, ground and remote turn-on control
to the amplifier.
speaker connections these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
power supply voltage
matching speaker impedance
stereo mode
bridged mode
14.4V DC Neg. Ground (10.5-16V)
2-4 Ohms
maximum current draw
5A
dimensions (W x H x L)
mm
inches
281 x 59 x 209
11.06 x 2.32 x 8.25
8
features and controls
4 ch amp PLA-419
PLA-419
power LED
high level inputs
low level inputs
input level control
high level inputs
low level inputs
input level control
speaker connections
power terminals
power fuse
9
features and specifications
4 ch amp PLA-419
input level control use this control to match the outputs of your head unit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
the amp level control until distortion begins to occur, and reduce slightly
from this point.
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
Maximum Power Output
30 Watts x 4
100 Watts x 4
low level inputs this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
frequency response
15 Hz-30 KHz
high level inputs if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
input impedance
low level inputs
high level inputs
10K Ohms
100 Ohms
input sensitivity
low level inputs
high level inputs
250mV
2.5V
power LED this indicator is illuminated when power is applied.
power fuse the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
power terminals use these connectors to deliver power, ground and remote turn-on control
to the amplifier.
speaker connections these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
power supply voltage
matching speaker impedance
stereo mode
bridged mode
14.4V DC Neg. Ground (10.5-16V)
2-4 Ohms
maximum current draw
10A
dimensions (W x H x L)
mm
inches
281 x 59 x 235
11.06 x 2.32 x 9.25
10
features and controls
2 ch amp PLA-2150 • PLA-2250
PLA-2350 • PLA-2450
PLA-2150
power LED
PLA-2250
protection LED
PLA-2350
Remote Bass Boost
(PLA-2150 Without )
PLA-2450
high pass frequency control
low pass frequency control
bass boost level
crossover mode selector
high level inputs
low level inputs
input level control
speaker connections
power terminals
power fuse
11
features and specifications
2 ch amp PLA-2150 • PLA-2250
PLA-2350 • PLA-2450
crossover mode selector
when used with normal, full range systems, set this switch to “FULL.” If
you wish to use the internal crossover to power a driver of specific frequency
range, use the “LOWPASS” or “HIGHPASS” settings.
input level control
use this control to match the outputs of your head unit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
the amp level control until distortion begins to occur, and reduce slightly
from this point.
low pass frequency control
when the crossover selector switch is in “low pass” mode, this control
sets the upper frequency limit for audio program sent to the speakers.
high pass frequency control
when the crossover selector switch is in “high pass” mode, this control
sets the lower frequency limit for audio program sent to the speakers.
Remote Bass Boost
Plug in the Remote Bass Boost Control wire in here.(PLA-2150 without)
bass boost level control
this control permits adjustment of the bass level up to an increase of
approximately 18 dB.
low level inputs
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
high level inputs
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
power LED
this indicator is illuminated when power is applied.
protection LED
this indicator is illuminated when built-in protection circuitry is activated.
power fuse
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
power terminals
use these connectors to deliver power, ground and remote turn-on control
to the amplifier.
speaker connections
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
RMS Power @ 2 Ohms
Maximum Power Output
PLA-2150
40 Watts x 2
60 Watts x 2
300 Watts x 2
frequency response
PLA-2250
75 Watts x 2
125 Watts x 2
500 Watts x 2
PLA-2350
75 Watts x 2
125 Watts x 2
600 Watts x 2
15 Hz-30 KHz
input impedance
low level inputs
high level inputs
10K Ohms
100 Ohms
input sensitivity
low level inputs
high level inputs
250mV
2.5V
power supply voltage
12
14.4V DC Neg. Ground (10.5-16V)
matching speaker impedance
stereo mode
bridged mode
maximum current draw
PLA-2450
100 Watts x 2
175 Watts x 2
700 Watts x 2
2-4 Ohms
4-8 Ohms
15A
15A
20A
30A
dimensions (W x H x L)
mm 281 x 59 x 209
281 x 59 x 280 281 x 59 x 305 281 x 59 x 343
inches 11.06 x 2.32 x 8.25 11.06 x 2.32 x 11 11.06 x 2.32 x 12 11.06 x 2.32 x 13.5
features and controls
2 ch amp PLA-2550 • PLA-2650
PLA-2750 • PLA-2850
PLA-2550
power LED
protection LED
PLA-2650
PLA-2750
Remote Bass Boost
PLA-2850
high pass frequency control
low pass frequency control
bass boost level
crossover mode selector
high level inputs
low level inputs
input level control
speaker connections
power terminals
power fuse
13
features and specifications
2 ch amp PLA-2550 • PLA-2650
PLA-2750 • PLA-2850
crossover mode selectors
when used with normal, full range systems, set these switches to “FULL.”
If you wish to use the internal crossovers to power a driver of specific
frequency range, use the “LOWPASS” or “HIGHPASS” settings.
input level controls
use these controls to match the outputs of your head unit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
the amp level controls until distortion begins to occur, and reduce slightly
from this point.
low pass frequency controls
high pass frequency controls
Remote Bass Boost
bass boost level controls
when one or both of the crossover selector switches is in “low pass”
mode, one can set the upper frequency limit for audio program sent to
the speakers.
when the one or both of crossover selector switch is in “high pass” mode,
one can set the lower frequency limit for audio program sent to the
speakers.
Plug in the Remote Bass Boost Control wire in here.
this control permits adjustment of the bass level up to an increase of
approximately 18 dB in either or both pairs of channels.
low level inputs
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
high level inputs
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
power LED
this indicator is illuminated when power is applied.
protection LED
this indicator is illuminated when built-in protection circuitry is activated.
power fuse
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
power terminals
use these connectors to deliver power, ground and remote turn-on control
to the amplifier.
speaker connections
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
RMS Power @ 2 Ohms
Maximum Power Output
PLA-2550
125 Watts x 2
200 Watts x 2
800 Watts x 2
frequency response
PLA-2650
150 Watts x 2
225 Watts x 2
900 Watts x 2
PLA-2750
200 Watts x 2
290 Watts x 2
1200 Watts x 2
15 Hz-30 KHz
input impedance
low level inputs
high level inputs
10K Ohms
100 Ohms
input sensitivity
low level inputs
high level inputs
250mV
2.5V
power supply voltage
14
14.4V DC Neg. Ground (10.5-16V)
matching speaker impedance
stereo mode
bridged mode
maximum current draw
PLA-2850
300 Watts x 2
450 Watts x 2
2000 Watts x 2
2-4 Ohms
4-8 Ohms
20 A
20 A x 2
25 A x 2
30 A x 2
dimensions (W x H x L)
mm 281 x 59 x 381 281 x 59 x 432 281 x 59 x 482 281 x 59 x 532
inches 11.06 x 2.32 x 15 11.06 x 2.32 x 17 11.06 x 2.32 x 19 11.06 x 2.32 x 21
features and controls
4 ch amp PLA-4150 • PLA-4250 • PLA-4350
Remote Bass Boost
PLA-4150
(PLA-4150 without)
PLA-4250
PLA-4350
ch 3/4 input level control
ch 1/2 input level control
ch 3/4 high level inputs
ch 1/2 high level inputs
15
ch 3/4 low level inputs
ch 3/4 crossover mode selector switch
ch 3/4 bass boost level control
ch 3/4 low pass frequency control
ch 3/4 high pass frequency control
ch 1/2 low level inputs
ch 1/2 crossover mode selector switch
ch 1/2 bass boost level control
ch 1/2 low pass frequency control
ch 1/2 high pass frequency control
power LED
protection LED
speaker connections
power terminals
power fuse
features and specifications
4 ch amp PLA-4150 • PLA-4250 • PLA-4350
dual crossover mode selectors
when used with normal, full range systems, set these switches to “FULL.”
If you wish to use the internal crossovers to power a driver of specific
frequency range, use the “LOWPASS” or “HIGHPASS” settings.
dual input level controls
use these controls to match the outputs of your head unit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
the amp level controls until distortion begins to occur, and reduce slightly
from this point.
dual low pass frequency controls
dual high pass frequency controls
CH 3/4 Remote Bass Boost
dual bass boost level controls
when one or both of the crossover selector switches is in “low pass”
mode, one can set the upper frequency limit for audio program sent to
the speakers.
when the one or both of crossover selector switch is in “high pass” mode,
one can set the lower frequency limit for audio program sent to the
speakers.
Plug in the Remote Bass Boost Control wire in here.(PLA-4150 without)
this control permits adjustment of the bass level up to an increase of
approximately 18 dB in either or both pairs of channels.
low level inputs
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
high level inputs
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
power LED
this indicator is illuminated when power is applied.
protection LED
this indicator is illuminated when built-in protection circuitry is activated.
power fuse
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
power terminals
use these connectors to deliver power, ground and remote turn-on control
to the amplifier.
speaker connections
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
RMS Power @ 2 Ohms
Maximum Power Output
PLA-4150
35 Watts x 4
55 Watts x 4
250 Watts x 4
frequency response
PLA-4250
50 Watts x 4
75 Watts x 4
350 Watts x 4
15 Hz-30 KHz
input impedance
low level inputs
high level inputs
10K Ohms
100 Ohms
input sensitivity
low level inputs
high level inputs
250mV
2.5V
power supply voltage
16
14.4V DC Neg. Ground (10.5-16V)
matching speaker impedance
stereo mode
bridged mode
maximum current draw
PLA-4350
75 Watts x 4
115 Watts x 4
500 Watts x 4
2-4 Ohms
4-8 Ohms
20 A
30 A
dimensions (W x H x L)
mm 281 x 59 x 305
281 x 59 x 381
inches 11.06 x 2.32 x 12 11.06 x 2.32 x 15
20 A x 2
281 x 59 x 432
11.06 x 2.32 x 17
features and controls
Class-D MONO BLOCK AMPLIFIER PLA-4300D
PLA-4300D
power LED
protection LED
17
remote bass boost
low pass frequency control
speaker connections
power fuse
line level outputs
line level inputs
input level control
sub sonic control
phase shift switch
power terminals
features and specifications
Class-D MONO BLOCK AMPLIFIER PLA-4300D
Class-D design Low-frequency information for subwoofer only.High efficient power
power supplies Stiffly regulated PWM power supplies. MOSFET switches maintain
rated power over a wide range of battery voltages.
crossover low pass filter Adjustable from 20Hz to 250Hz with a slope of 24dB per octave.This
allows for the adjustment of the upper point of the frequency bandwidth
and the respective subwoofer.
high pass subsonic filter Adjustable from 15Hz to 40Hz with a slope of 24dB per octave.This allows
for the attenuation of frequencies that are mostly inaudible and cause
unnecessary strain on the amplifier.
protection circuitry Protection against thermal, overload and short circuit conditions.
remote dash-mount gain control This amplifier come complete with a compact remote GAIN CONTROLLER
which can be conveniently mounted on or under the dashboard of your
car.
output power @ 14.4v DC, 50Hz
RMS Power at @ 4 Ohms
RMS Power at @ 2 Ohms
RMS Power at @ 1.3 Ohms
Maximum Power Output
frequency response
PLA-4300D
400W MONO
700W MONO
1200W MONO
4000W MONO
20 Hz-250 Hz (-3dB)
input impedance
10K Ohms
input sensitivity
250mV~4V Adjustable
power supply voltage
min speaker lmpedance
T.H.D
S/N ration
fuse
dimensions (W x H x L)
mm
inches
14.4V DC Neg. Ground (10.5-16V)
1 Ohm
0.1%
>90dB
40A x 2
281 x 59 x 381
11.06 x 2.32 x 15
18
electrical
connections
2 ch amp PLA-219 • PLA-2150 • PLA-2250 • PLA-2350
PLA-2450 • PLA-2550 • PLA-2650 • PLA-2750
PLA-2850 • PLA-4300D
PLA-219
PLA-2150
PLA-2250
PLA-2350
19
PLA-2450
PLA-2550
PLA-2650
PLA-2750
12V battery
PLA-2850
head unit
PLA-4300D
to remote turn-on
+12V
electrical connections
4 ch amp PLA-419 • PLA-4150
PLA-4250 • PLA-4350
PLA-419
PLA-4150
PLA-4250
PLA-4350
20
12V battery
to remote turn-on
+12V
head unit
stereo input connections
2 ch amp PLA-219
using
low level inputs
PLA-2 1 9
head unit
L/R Audio
Outputs
using
PLEASE NOTE! If using high level
inputs, do not use the low level RCA
inputs at the same time!
high level inputs
head unit
L
L
R
from speaker terminals
R
wiring harness
21
stereo input connections
using
low level inputs
2 ch amp • PLA-2150 • PLA-2250 • PLA-2350
PLA-2450 • PLA-2550 • PLA-2650
PLA-2750 • PLA-2850
PLA-2 1 5 0
PLA-2250
PLA-2350
PLA-2450
head unit
PLA-2550
L/R Audio
Outputs
PLA-2650
PLA-2750
PLA-2850
using
high level inputs
head unit
L
L
R
from speaker terminals
R
22
PLEASE NOTE! If using high level
inputs, do not use the low level RCA
inputs at the same time!
mono input connections
using
low level inputs
2 ch amp • PLA-2150 • PLA-2250 • PLA-2350
PLA-2450 • PLA-2550 • PLA-2650
PLA-2750 • PLA-2850
PLA-2 1 5 0
PLA-2250
PLA-2350
head unit
PLA-2450
PLA-2550
PLA-2650
Y Adaptors
PLA-2750
PLA-2850
23
To a second amplifier
using
high level inputs
PLEASE NOTE! If using high level
inputs, do not use the low level RCA
inputs at the same time!
head unit
To a second amplifier
L
L
R
wiring harness
R
wiring harness
from speaker terminals
2/4 channel input connections
4 ch amp PLA-419
4 CH input connections using
low level inputs
PLA-4 1 9
L/R FRONT
Audio Outputs
L/R REAR
Audio Outputs
2 CH input connections using
low level inputs
L
Y adaptors
R
head unit
24
high level input connections
4 ch amp PLA-419
4 CH floating ground connections
PLA-4 1 9
25
4 CH harness wiring for common ground connections
CH 3/4
REAR
L
R
L
ORANGE
FRONT
ORANGE
BLACK
BLACK
BLACK
REAR
L
R
L
R
FRONT
BLACK
ORANGE
ORANGE
from speaker terminals
PLEASE NOTE! If using high level inputs,
do not use the low level RCA inputs at
the same time!
R
CH 1/2
ORANGE
ORANGE
BLACK
BLACK
BLACK
BLACK
ORANGE
ORANGE
from speaker terminals
Stereo input connections
4 ch amp PLA-4150 • PLA-4250 • PLA-4350
4 CH Stereo input connections using
low level inputs
PLA-4 1 5 0
PLA-4250
PLA-4350
L/R FRONT
Audio Outputs
L/R REAR
Audio Outputs
2 CH Stereo input connections using
low level inputs
R
Y adaptors
L
head unit
26
high level Stereo input connections
4 ch amp PLA-4150 • PLA-4250 • PLA-4350
4 CH floating ground connections
PLA-4 1 5 0
PLA-4250
PLA-4350
27
4 CH harness wiring for common ground connections
CH 3/4
REAR
L
R
L
ORANGE
FRONT
ORANGE
BLACK
BLACK
BLACK
REAR
L
R
L
R
FRONT
BLACK
ORANGE
ORANGE
from speaker terminals
PLEASE NOTE! If using high level inputs,
do not use the low level RCA inputs at
the same time!
R
CH 1/2
ORANGE
ORANGE
BLACK
BLACK
BLACK
BLACK
ORANGE
ORANGE
from speaker terminals
mono input connections
4 ch amp PLA-4150 • PLA-4250 • PLA-4350
4 CH mono input connections using
low level inputs
PLA-4 1 5 0
PLA-4250
PLA-4350
head unit
LEFT FRONT Audio Outputs
RIGHT FRONT Audio Outputs
LEFT REAR Audio Outputs
RIGHT REAR Audio Outputs
2 CH mono input connections using
low level inputs
L
Y adaptors
R
28
high level mono input connections
4 ch amp PLA-4150 • PLA-4250 • PLA-4350
4 CH floating ground connections
PLA-4150
PLA-4250
4 CH harness wiring
for common ground connections
PLA-4350
CH 3/4
29
CH 1/2
R
L
ORANGE
ORANGE
BLACK
BLACK
BLACK
BLACK
ORANGE
L
ORANGE
from speaker terminals
PLEASE NOTE! If using high level inputs,
do not use the low level RCA inputs at
the same time!
R
ORANGE
ORANGE
BLACK
BLACK
BLACK
BLACK
ORANGE
ORANGE
from speaker terminals
system wiring
Class-D MONO BLOCK AMPLIFIER PLA-4300D
PLA-4300D
L/R Audio
Outputs
head unit
TO SATELLITE AMPLIFIER
LINE INPUT
SPEAKER OUTPUT CONNECTION
subwoofer
M IN IM U M
SPEAKER
IM P E D A N CE
2~ 4 O H M S !
30
speaker
connections
2 ch amp PLA-219 • PLA-2150 • PLA-2250 • PLA-2350
PLA-2450 • PLA-2550 • PLA-2650 • PLA-2750
PLA-2850
Stereo Output Mode
PLA-219
PLA-2150
PLA-2250
PLA-2350
31
PLA-2450
PLA-2550
Bridged Mono Output Mode (PLA-219 WITHOUT)
PLA-2650
PLA-2750
LEFT speaker
RIGHT speaker
PLA-2850
speaker
MINIMUM
SPEAKER
IMPEDANCE
4 OHMS!
speaker connections
4 ch amp PLA-419 • PLA-4150
PLA-4250 • PLA-4350
4 CH Output Mode
PLA-4 1 9
PLA-4150
PLA-4250
PLA-4350
32
L
FRONT speakers
R
L
R
REAR speakers
Bridged Dual Mono Output Mode (PLA-419 WITHOUT)
MINIMUM
SPEAKER
IMPEDANCE
4 OHMS!
speakers
L
R
speaker connections
4 ch amp PLA-4150 • PLA-4250 • PLA-4350
pb-836GX
PLA-4150
pb-1036GX
PLA-4250
2 CH Bridged Output Mode with Subwoofer Output
PLA-4350
33
R
L
SUBWOOFER
SPEAKERS
MINIMUM
SPEAKER
IMPEDANCE
4 OHMS!
mounting and installation
mounting
Your new Pyle GearX Series amplifier comes complete with all required mounting hardware. When determining a suitable location in your vehicle for the amp, please remember
that it is a high-power electronic device capable of generating high heat.
For this reason, always choose a location in your vehicle which has low vibration, adequate ventilation, a minimum of dust, and no moisture. Be sure to
mount the amp in such a manner as to allow reasonable airflow over the cooling fins.
Mark the location for the mounting screw holes by positioning the amp where you wish to install it and use a scribe (or one of the mounting screws) inserted in each
of the mounting holes to mark the mounting surface. If the mounting surface is carpeted, measure the hole centers and mark with a felt tip pen.
Before attempting to drill the mounting holes, take note of any wires, lines or other devices in your vehicle which may be located behind the mounting
surface! Then drill pilot holes in the mounting surface for the mounting screws and insert them. Tighten the screws securely.
wiring tips
When making electrical connections to your amplifier, please observe the
following:
Use at least 8 gauge wire for power and ground connections.
Wire the amplifier directly to the car battery.
For the ground connection, use the shortest possible wire to a good chassis ground point.
Wire the Remote connection to the auto start lead of your head unit, equalizer or power antenna.
fuses
About power fuses:
Pyle GearX Series amplifiers feature built-in fuse systems. These fuses protect both the amplifier
and the electrical system in your vehicle from fault conditions. If you ever need to replace the
fuse in your Pyle GearX Series amp, use a fuse of exactly the same type and rating. A different
type or rating of fuse may result in damage or fire.
34
troubleshooting
protection
circuitry
The built-in protection circuitry in the Pyle GearX
Series amplifiers will disable the amplifier if it senses
an input overload, a speaker short circuit, or extreme
temperature conditions.
When the protection circuit is activated by any of
these conditions, the Protection LED will be
illuminated.
No output.
Confirm that all terminal strip connections are secure and tight.
Check both in-line and built-in fuses. Both the +12V and the Remote terminals must have +12v referenced to chassis
ground.
Confirm that the audio signal source (car radio, equalizer, etc.) is connected and is supplying output signal. To
check if the amp is supplying signal, unplug the cables from the signal source (but leave them plugged into the
amp). Briefly tap the center pin of each of the disconnected RCA plugs with your finger. This should produce a noise
(feedback) in your speakers.
Only one channel works.
Confirm that all terminal strip connections are secure and tight.
Check the Balance control on the head unit (or other source) to verify that it is set to its midpoint.
35
If this occurs, carefully inspect the system to
determine the source of the problem.
If you are using the Low Level RCA input, reverse the input plugs at the amplifier (i.e., switch the L with the R). If
the channels which is silent switches to the other side, the problem is either in the head unit/other source or the
connecting cables.
• If the shutdown was a result of a thermal overload
condition, allow the amplifier to cool down before
attempting to restart it.
Weak output.
Readjust the Input Level Control(s) to better suit the input signal.
• If the shutdown was a result of an input overload,
or speaker short circuit, be sure to correct the
condition before restarting.
The amplifier can be restarted by turning the remote
power OFF and then ON again.
Noise in the audio.
If the noise is a “whine” whose pitch follows the engine speed, confirm that the amplifier and any other signal
sources (head unit, etc.) are properly grounded.
If the noise is a “clicking” or “popping” noise whose rate follows the engine speed, this usually means that the
vehicle is equipped with resistor spark plugs and wires, or that the ignition is in need of service.
Check the rounting of the speaker and input wires to make sure they are not adjacent to wires which interconnect
lights and other accessories.
If the above steps fail to improve or clear noise interference, the system should be checked by a professional mobile
audio installer.
precautions
notes
Do not operate the amplifier when it is unmounted.
Attach all audio system components securely within
the automobile to prevent damage, especially in an
accident.
Do not mount this amplifier so that the wire
connections are unprotected, or in a pinched
condition, or likely to be damaged by nearby objects.
Before making or breaking power connections in
your system, disconnect the vehicle battery. Confirm
that your head unit or other equipment is turned off
while connecting the input jacks and speaker
terminals.
If you need to replace the power fuse, do so only
with a fuse identical to that supplied with the amplifier.
Using a fuse of a different type or rating may result
in damage that isn’t covered in the manufacturer’s
warranty.
36
limited warranty policy
amplifiers
All Pyle products are carefully constructed and thoroughly tested before
shipment. Products purchased in the USA are warranted to be free of defects
in material and workmanship for two (2) years from the date of purchase. This
warranty is limited to the original retail purchase.
Should the product fail due to factory defects in material or workmanship,
your unit will be repaired or replaced at the sole discretion of Pyle.
To obtain warranty service you must first call our Consumer Return Hotline
number at (718) 236-6948 to obtain a Return Authorization number. This
R.A.# must appear on the outside of your package and on all paperwork
relating to your return.
When returning a product to us for warranty service it must be carefully packed
and shipped prepaid to:
R.A.#
Pyle Service Center
1600 63rd Street
Brooklyn, NY 11204
You must also include the following items:
• A copy of your sales receipt or other proof of purchase
• A brief letter indicating the problem you are experiencing
• include in your letter your return address, daytime phone number,
and R.A. number
• also include a check or money order for $18.00 for return shipping,
handling, and insurance, or provide your Visa/MC number with
expiration date.
Our obligation under this warranty is limited to the repair or
replacement of the defective unit when it is returned to us prepaid.
This warranty will be considered void if the unit was tampered with,
improperly serviced, or subject to misuse, neglect, or accidental
damage.
www.pyleaudio.com
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
