2014 Catalog
14” Lightweight Upright
• Lightweight design (10 lbs).
• Constructed with polycarbonate resin for added durability and lightweight.
• Low profile lay-flat.
• Ergonomic frame and handle.
• Ametek 4.6 amp paramagnetic direct air motor with thermal overload protection.
• Ametek 3.23” impeller and impeller housing construct with Lexan resin.
• Life time belt with brush roll jam indicator and auto shut-off.
• Static pressure sensor bag fill indicator.
• Patented sealed filter bag system with bag safety design.
• 40’ power cord.
Specifications
Model:
Motor:
Motor Hood:
Handle:
Vacuum Width:
Weight:
Power Cord:
Brush Drive:
UPC:
BISSELL
BIGGREEN
COMMERCIAL
PCH Equipment
Solutions
100So.
Armstrong
249
Highway 101Road
#322 Suite 101
Plymouth,
MA
Solana Beach, Ca 92075 02360
BGU5500
4.6 amps
Gray
Ergonomic
14 inches
10 lbs.
40 feet
Belt
811827020009
1-800-242-1378
858-761-4183
PCHequipment.com
www.bissellcommercial.com
12” ProTough Upright
• Powerful 870-watt motor.
• Heat overload protection system.
• Reinforced fan. (Virtually Indestructible with life time warranty)
• Straight handle.
• Non-Stick cloth bag. (Shakeout)
ning area.
• 50 foot long power cord with cord strain relief allows for 100 feet of cleaning
• Aluminum roller brush with four bristle strips and double ball bearings.
• 12” cleaning path.
• Large rear wheels make transportation easy.
• 6 position manual carpet height adjustment.
• Painted black metal hood with “V” shaped motor vents.
• Reinforced see-thru fan chamber for fast cleaning.
• Metal on / off foot switch.
• Metal foot release pedal made from hardened steel.
• Metal bottom plate.
• 1 Year warranty.
Specifications
Model:
Motor:
Motor Hood:
Handle:
Vacuum Width:
Weight:
Power Cord:
Bag:
Roller Brush:
Brush Drive:
Carpet Height
Adjustment:
Magnet bar:
UPC:
BG100
870 watt
Black
Straight
12 inches
13.5 lbs.
50 feet
Non-Stick
Aluminum
Belt
Yes
No
011120164824
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
12” ProShake Upright
• Powerful 870-watt motor.
• Heat overload protection system.
• Reinforced fan (Virtually Indestructible with life time warranty).
• Comfort Grip handle for easy use.
• Non-Stick cloth bag. (Shakeout)
• 50 foot long power cord with cord strain relief allows for 100 feet of cleaning area.
• Aluminum roller brush with four bristle strips and double ball bearings.
• 12” cleaning path.
• Large rear wheels make transportation easy.
• 6 position manual carpet height adjustment.
• Chrome metal hood with “V” shaped motor vents.
• Reinforced see-thru fan chamber for fast cleaning.
• Metal on / off foot switch.
• Metal foot release pedal made from hardened steel.
• Metal bottom plate.
• Magnet bar.
• 1 Year warranty.
Specifications
Model:
Motor:
Motor Hood:
Handle:
Vacuum Width:
Weight:
Power Cord:
Bag:
Roller Brush:
Brush Drive:
Carpet Height
Adjustment:
Magnet Bar:
UPC:
BG101
870 watt
Chrome
Comfort Grip
12 inches
14.5 lbs.
50 feet
Non-Stick
Aluminum
Belt
Yes
Yes
011120157871
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
12” ProBag Upright
• Powerful 870-watt motor.
• Heat overload protection system.
• Reinforced fan (Virtually Indestructible with life time warranty).
• Comfort Grip handle for easy use.
• Top fill High Filtration disposable filter bag.
• 50 foot long power cord with cord strain relief allows for 100 feet of cleaning area.
• Aluminum roller brush with four bristle strips and double ball bearings.
• 12” cleaning path.
• Large rear wheels make transportation easy.
• 6 position manual carpet height adjustment.
• Chrome metal hood with “V” shaped motor vents.
• Reinforced see-thru fan chamber for fast cleaning.
• Metal on / off foot switch.
• Metal foot release pedal made from hardened steel.
• Metal bottom plate.
• Magnet bar.
• 1 Year warranty.
Specifications
Model:
Motor:
Motor Hood:
Handle:
Vacuum Width:
Weight:
Power Cord:
Filter Bag:
Roller Brush:
Brush Drive:
Carpet Height
Adjustment:
Magnet Bar:
UPC:
BG101H
870 watt
Chrome
Comfort Grip
12 inches
14.5 lbs.
50 feet
High Filtration
Aluminum
Belt
Yes
Yes
011120164732
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
12” DayClean /
Quiet Clean Upright
• Powerful 5.5 amp motor.
• Sound pressure 68 dBA
• Heat overload protection system.
• Reinforced fan (Virtually Indestructible with life time warranty).
• Comfort Grip handle for easy use.
• Top fill High Filtration disposable filter bag.
• 50 foot long power cord with cord strain relief allows for 100 feet of cleaning area.
• Aluminum roller brush with four bristle strips and double ball bearings.
• 12” cleaning path.
• Large rear wheels make transportation easy.
• 6 position manual carpet height adjustment.
• Chrome metal hood with “V” shaped motor vents.
• Reinforced see-thru fan chamber for fast cleaning.
• Metal on / off foot switch.
• Metal foot release pedal made from hardened steel.
• Metal bottom plate.
• Magnet bar.
• 1 Year warranty.
Specifications
Model:
Sound Pressure :
Motor:
Motor Hood:
Handle:
Vacuum Width:
Weight:
Power Cord:
Filter Bag:
Roller Brush:
Brush Drive:
Carpet Height
Adjustment:
Magnet Bar:
UPC:
BG107HQS
68dBA
5.5 amps
Chrome
Comfort Grip
12 inches
14.5 lbs.
50 feet
High Filtration
Aluminum
Belt
Yes
Yes
011120164718
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
12” ProCup Upright
• Powerful 870-watt motor.
• Heat overload protection system.
• Reinforced fan (Virtually Indestructible with life time warranty).
• Comfort Grip handle for easy use.
• Dirt cup design.
• 50 foot long power cord with cord strain relief allows for 100 feet of cleaning area.
• Aluminum roller brush with four bristle strips and double ball bearings.
• 12” cleaning path.
• Large rear wheels make transportation easy.
• 6 position manual carpet height adjustment.
• Chrome metal hood with “V” shaped motor vents.
• Reinforced see-thru fan chamber for fast cleaning.
• Metal on / off foot switch.
• Metal foot release pedal made from hardened steel.
• Metal bottom plate.
• Magnet bar.
• 1 Year Warranty.
Specifications
Model:
Motor:
Motor Hood:
Handle:
Vacuum Width:
Weight:
Power Cord:
Dirt Cup:
Roller Brush:
Brush Drive:
Carpet Height
Adjustment:
Magnet Bar:
UPC:
BG101DC
870 watt
Chrome
Comfort Grip
12 inches
14.5 lbs.
50 feet
Yes
Aluminum
Belt
Yes
Yes
011120164725
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
16” ProShake Upright
• Powerful 870-watt motor.
• Heat overload protection system.
• Reinforced fan (Virtually Indestructible with life time warranty).
• Comfort Grip handle for easy use.
• Non-Stick cloth bag. (Shakeout)
• 50 foot long power cord with cord strain relief allows for 100 feet of cleaning area.
• Aluminum roller brush with four bristle strips and double ball bearings.
• 16” cleaning path.
• Large rear wheels make transportation easy.
• 6 position manual carpet height adjustment.
• Chrome metal hood with “V” shaped motor vents.
• Reinforced see-thru fan chamber for fast cleaning.
• Metal on / off foot switch.
• Metal foot release pedal made from hardened steel.
• Metal bottom plate.
• Magnet bar.
• 1 Year warranty.
Specifications
Model:
Motor:
Motor Hood:
Handle:
Vacuum Width:
Weight:
Power Cord:
Bag:
Roller Brush:
Brush Drive:
Carpet Height
Adjustment:
Magnet Bar:
UPC:
BG102
870 watt
Chrome
Comfort Grip
16 inches
16.5 lbs.
50 feet
Non-Stick
Aluminum
Belt
Yes
Yes
011120164756
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
16” ProBag Upright
• Powerful 870-watt motor.
• Heat overload protection system.
• Reinforced fan (Virtually Indestructible with life time warranty).
• Comfort Grip handle for easy use.
• Top fill High Filtration disposable filter bag.
• 50 foot long power cord with cord strain relief allows for 100 feet of cleaning area.
• Aluminum roller brush with four bristle strips and double ball bearings.
• 16” cleaning path.
• Large rear wheels make transportation easy.
• 6 position manual carpet height adjustment.
• Chrome metal hood with “V” shaped motor vents.
• Reinforced see-thru fan chamber for fast cleaning.
• Metal on / off foot switch.
• Metal foot release pedal made from hardened steel.
• Metal bottom plate.
• Magnet bar.
• 1 year warranty
Specifications
Model:
Motor:
Motor Hood:
Handle:
Vacuum Width:
Weight:
Power Cord:
Filter Bag:
Roller Brush:
Brush Drive:
Carpet Height
Adjustment:
Magnet Bar:
UPC:
BG102H
870 watt
Chrome
Comfort Grip
16 inches
17 lbs.
50 feet
High Filtration
Aluminum
Belt
Yes
Yes
011120164749
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
16” DayClean /
Quiet Clean Upright
• Powerful 5.5 amp motor.
• Sound pressure 68 dBA
• Heat overload protection system.
• Reinforced fan (Virtually Indestructible with life time warranty).
• Comfort Grip handle for easy use.
• Top fill High Filtration disposable filter bag.
• 50 foot long power cord with cord strain relief allows for 100 feet of cleaning area.
• Aluminum roller brush with four bristle strips and double ball bearings.
• 16” cleaning path.
• Large rear wheels make transportation easy.
• 6 position manual carpet height adjustment.
• Chrome metal hood with “V” shaped motor vents.
• Reinforced see-thru fan chamber for fast cleaning.
• Metal on / off foot switch.
• Metal foot release pedal made from hardened steel.
• Metal bottom plate.
• Magnet bar.
• 1 Year warranty.
Specifications
Model:
Sound Pressure :
Motor:
Motor Hood:
Handle:
Vacuum Width:
Weight:
Power Cord:
Filter Bag:
Roller Brush:
Brush Drive:
Carpet Height
Adjustment:
Magnet Bar:
UPC:
BG107-16HQS
68dBA
5.5 amps
Chrome
Comfort Grip
16 inches
14.5 lbs.
50 feet
High Filtration
Aluminum
Belt
Yes
Yes
011120164596
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
16” ProCup Upright
• Powerful 870-watt motor.
• Heat overload protection system.
• Reinforced fan (Virtually Indestructible with life time warranty).
• Comfort Grip handle for easy use.
• Dirt cup design.
• 50 foot long power cord with cord strain relief allows for 100 feet of cleaning area.
• Aluminum roller brush with four bristle strips and double ball bearings.
• 16” cleaning path.
• Large rear wheels make transportation easy.
• 6 position manual carpet height adjustment.
• Chrome metal hood with “V” shaped motor vents.
• Reinforced see-thru fan chamber for fast cleaning.
• Metal on / off foot switch.
• Metal foot release pedal made from hardened steel.
• Metal bottom plate.
• Magnet bar.
• 1 year warranty
Specifications
Model:
Motor:
Motor Hood:
Handle:
Vacuum Width:
Weight:
Power Cord:
Dirt Cup:
Roller Brush:
Brush Drive:
Carpet Height
Adjustment:
Magnet Bar:
UPC:
BG102DC
870 watt
Chrome
Comfort Grip
16 inches
17.5 lbs.
50 feet
Yes
Aluminum
Belt
Yes
Yes
011120164701
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
ProTough, ProShake, ProBag
& ProCup Uprights
BG100
BG101
BG102 – 16”
BG101DC – 12”
BG102DC – 16”
BG101H – 12”
BG102H – 16”
• Powerful 870-watt motor .
• Heat overload protection system.
• Reinforced fan (Virtually Indestructible with life
time warranty).
• Straight or Comfort Grip handle.
• Non-Stick cloth bag (Shakeout),
High Filtration bag or Dirt Cup.
• 50 foot long power cord with cord strain relief
allows for 100 feet of cleaning area.
• Aluminum roller brush with four bristle strips
and double ball bearings.
• 12” or 16” cleaning path.
• Large rear wheels make transportation easy.
• 6 position manual carpet height adjustment.
• Painted black or chrome metal hood with “V”
shaped motor vents.
• Reinforced see-thru fan chamber for fast
cleaning.
• Metal on / off foot switch.
• Metal foot release pedal made from
hardened steel.
• Metal bottom plate.
• Magnet bar on OR101 and OR102.
Specifications
Model:
Motor:
Motor Hood:
Handle:
Vacuum
Width:
Weight:
Power Cord:
Bag:
Roller Brush:
Brush Drive:
Carpet Height
Adjustment:
Magnet Bar:
BG100
870 watt
Black
Straight
BG101
870 watt
Chrome
Comfort
Grip
BG101DC
870 watt
Chrome
Comfort
Grip
BG101H
870 watt
Chrome
Comfort
Grip
BG102
870 watt
Chrome
Comfort
Grip
BG102DC
870 watt
Chrome
Comfort
Grip
BG102H
870 watt
Chrome
Comfort
Grip
12 inches
13.5 lbs.
50 feet
Non-Stick
(Shake-out)
12 inches
14.5 lbs.
50 feet
Non-Stick
(Shake-out)
12 inches
15.5 lbs.
50 feet
Dirt Cup
16 inches
16.5 lbs.
50 feet
Non-Stick
16 inches
17.5 lbs.
50 feet
Dirt Cup
Aluminum
Belt
Aluminum
Belt
Aluminum
Belt
12 inches
15 lbs.
50 feet
High
Filtration
Disposable
Aluminum
Belt
Aluminum
Belt
Aluminum
Belt
16 inches
17 lbs.
50 feet
High
Filtration
Disposable
Aluminum
Belt
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
Single Motor Upright
with On-Board Tools
• Single motor unit with motor in brush roller base for low handle weight.
• Powerful 1,000-watt motor deep cleans in just one pass.
• Auto motor shutoff when machine is clogged.
• Body constructed out of high impact ABS.
• Belt driven brush roller.
• Manual brush roller height adjustment.
• Soft touch Comfort Grip® handle with height adjustment.
• Full set of attachment includes upholstery brush, dusting brush and
crevice tool.
• Attachment storage designed to store in back of vacuum.
• Telescopic wand and stretch hose extends more than 9
feet for convenient above-the-floor cleaning.
• 48-ft. long (quick change – no tools required) power cord
with cord strain relief allows for 96 feet of cleaning area.
2 YEAR
COMMERCIAL
WARRANTY
Specifications
BGUPRO 12T
Vacuum Width:
Weight:
Power Cord:
Sound:
CFM:
Water Lift:
Brush Drive:
Dust Bag Capacity:
Carpet Height Adjustment:
UPC:
12 inches
17 lbs.
48 feet
68 Db(A)
105
78.75”
Non-slip belt
6.44 Quarts
Yes
011120053043
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
14” or 18” Dual Motor Upright
with On-Board Tools
Durable Dual-Motor Complete Cleaning System
• Powerful 1000-watt dual motor deep cleans in just one pass.
• Full set of attachment includes upholstery brush, dusting brush and
crevice tool.
• Telescopic wand and stretch hose extends more than 9 feet for
convenient above-the-floor cleaning.
• Dual-wall disposable bag holds up to 6.16 quarts of dirt.
• 46-ft. long (quick change – no tools required) power cord with cord
strain relief allows for 92 feet of cleaning area.
• Roller brush motor automatically turns off protecting the carpet when
the tools are being used.
• 14” or 18” cleaning path for faster cleaning.
• Large rear wheels make transportation easy.
• Manual carpet height adjustment.
• Non-slip belt with overload protection.
• Electronic sensors detect a broken belt or blocked air flow.
• Convenient modular component system
requires no tools to disassemble. Easy to trouble shoot a blockage or repair.
• Balanced center of gravity prevents tipping when using accessories.
• High efficiency filtration includes motor
inlet filter and dual wall disposable bags.
2 YEAR COMMERCIAL
WARRANTY
Specifications
Model:
BGUPRO14T BGUPRO18T
CFM:
95
95
Water Lift:
115 inches
115 inches
Vacuum Width:
14 inches
18 inches
Weight:
19 lbs.
20 lbs.
Power Cord:
46 feet
46 feet
Dust Bag Capacity:
6.16 Quarts
6.16 Quarts
Sound:
67 Db(A)
67 Db(A)
Brush Drive:
Non-slip belt with overload protection
Carpet Height Adjustment:
Yes
Yes
UPC:
011120053005
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
15” Dual Motor Upright
with On-Board Tools
Durable Dual-Motor Complete Cleaning System
• Heavy-duty commercial vacuum
• Two-motor system
• 120V, 1080W, 9A
• 15-inch cleaning path – efficient, wide-path clean
• Sleek foot, cleans under furniture
• Comfort-clean handle
• 50-foot professional extension cord for 100 feet of cleaning reach
• Quick and easy cord change
• Plastic wand for longer reach
• Durable drive belt – built to last
• Reaches into corners and crevices with L-shaped head
• Vacuum head adjusts to suit flooring
• Comfortable handle for a comfortable clean
• Full handle detent – vacuum reaches under beds and furniture
• Wire-reinforced hose stretches up to 6 feet to maximize cleaning reach
• 2-in-1 upholstery tool
• Crevice tool for hard-to-reach cleaning
2 YEAR COMMERCIAL
WARRANTY
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
Specifications
Model:
BG1000
CFM:
95
Water Lift:
115 inches
Vacuum Width:
15 inches
Weight:
19 lbs.
Power Cord:
50 feet
Dust Bag Capacity:
4.75 Quarts
Sound:
67 Db(A)
Brush Speed:
5,000 RPM
Brush Drive:
Non-slip belt with overload protection
Carpet Height Adjustment: Yes
UPC:
01120167238
1-800-242-1378
www.bissellcommercial.com
6 or 10 Quart Backpack Vacuums
A commercial vacuum designed for all-around use.
The latest ergonomic design offering
the technical edge in cleaning.
• Lightweight only 10-12 lbs! More freedom of movement means an
increase in productivity and reduced labor cost.
• Perfect for casinos, hotels, motels, hospitals, offices, airports and
anywhere that calls for multi-use cleaning task.
• Shoulder strap support plus the added stability of an ergonomic waist
belt that helps balance the unit on operator’s hips.
• Long 50 ft. cord gives you more mobility over large areas.
• Static dissipating stretch molded vacuum hose.
• Lightweight aluminum wand connected to the backpack by a flexible
hose makes it easily maneuverable around furniture and other obstacles.
• 4-level filtration system reduces the dust and dirt from being exhausted
back into the room. Microlined paper filter lasts longer
and stays stronger under heavy use.
Our lightweight aluminum wand
makes overhead cleaning an ease.
Vents, ceiling fans and other
difficult places are no match
for the versatile PRO™ Backpack Vacuum.
Specifications:
Capacity:
Weight:
Height:
Contoured Ergonomic Backrest:
50’ Power Cord (16 gauge)Yes
Two-Stage Whisper Motor: Yes
Power (Watts):
Airflow (CFM):
UPC:
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
BGPRO10
10 quarts
12 lbs.
23”
Yes
Yes
Yes
1200
122
BGPRO6
6 quarts
10 lbs.
23”
Yes
Yes
Yes
1200
122
Weighs only 10 – 12
lbs. Lightweight
and ergonomic
support enables
the operator
greater mobility
leading to increased
production and
reduced labor cost.
1-800-242-1378
www.bissellcommercial.com
6 or 10 Quart Backpack Vacuums
A commercial vacuum designed for all-around use.
• Lightweight only 9.5 -10.5 lbs!
• Perfect for casinos, hotels, motels, hospitals, offices, airports and anywhere that
calls for multi-use cleaning task.
• Ametek motor with built in heat sensor.
• Patent pending adjustable shoulder strap & waist belt design so the
machine rests off your back.
• 50’ cord gives you more mobility over large areas.
• 1 ½” crushproof 4’ vacuum hose with swivel cuffs.
• Twist off lid.
• Lightweight aluminum wand connected to the backpack by a flexible hose
makes it easily maneuverable around
furniture and other obstacles.
• On/Off switch with power nozzle hook up for easy finger tip control.
• Switch & waist belt Velcro to each other for comfortable switch placement.
• High Filtration filter bags available.
Specifications:
BG1001
Capacity:
10 quarts
Weight:
10.5 lbs.
Height:
26”
50’ Power Cord (16 gauge)Yes
8 Piece Tool Kit:
Yes
Power (Watts):
1175
Amps:
10.2
Airflow (CFM):
120
Water Lift:
110-120
Warranty:
1 year
UPC:
011120167252
BG1006
6 quarts
9.5 lbs.
22”
Yes
Yes
1175
10.2
120
110-120
1 year
011120167245
Comes with 8 Piece Tool Kit
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
Power Nozzle for Backpack Vacuums
WORKS WITH BACKPACKS BG1006 & BG1001
The Power Nozzle has a geared belt for
long life, a circuit breaker to protect motor,
belt and roller from clogs and jams. A large
15 inch cleaning path for quicker clean
time. Quick disconnect lever on Power
Nozzle neck.
• Commercial geared 15 inch power nozzle
with upper Sheath assembly and lower wand
• 1 ½“ – 1 ¼” reducer handle that fits
on hose cuff
• Power cord assembly connects to switch
box on backpack
• Built-In storage ring for convenient
wall mounting
• Double row of bristles for rug and
floor cleaning
BGBPAK1
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
Canister Vacuum
Designed for commercial cleaning companies,
Salons, Spas, Barber Shops, Hotels, Schools,
Cafes, Restaurants and Healthcare professionals.
• Versatile machine – Cleans carpet, upholstery
and more
• On-board cleaning tools included:
crevice tool, upholstery tool, dusting brush,
combination floor tool, metal telescoping wand
• Combo floor tool – Control the brush height while
cleaning different floor types
• Suction power options Control at wand
• Quiet and lightweight
• Disposable 1.94-gallons capacity dirt bag
• 1200 watts
Optional Air
Driven
Brush Roller
Specification
Motor:
Water Lift:
CFM:
Bag Capacity:
Hose Length:
Power Cord:
Filtration:
Sound Level:
UPC:
BGCOMP 9
1.6 HP
Double Stage
98.4”
106
1.94 gallon
8 feet
50 feet
3 Stages
60 db
011120053036
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
Canister Vacuums
Powerful Small Canister Vacuum on Wheels
The “Little Hercules” compact design, powerful suction, and low maintenance disposal system provides
a great solution for when an extra vacuum is needed. The Little Hercules is a handheld canister with
wheels that puts dust busters to shame! It is ultra-portable and super-powerful. It has 5 foot extension
hose, and suction control provides versatility for all surface types. It also has 2-in-1 floor tool and two
extension wands for those hard to reach places and a 15 foot power cord and a carry handle for easy
use. Permanent wheels for easy maneuverability (2 rear wheels with a steering wheel).
Part Number
BGC2000
Motor
1000 watts
Power cord
15 feet
Sound Pressure
84 DBA
Replacement Filter
PETVACFILTS
FOB
Cookeville, TN
UPC Number
811827-
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
EXTRA WIDE VACUUM!
Designed to clean large areas quickly and efficiently.
Engineered for long service life under rugged conditions.
Powered by strong 8.5 amp motor. (2,000 hour motor brush life)
Saves you up to 80% of your time compared to using
conventional upright on the same job.
• Efficient grooming chevron brush
• Air velocity enhancer edge cleaning
• Floating brush barrier
• Balanced extruded brush roller
• Rugged 360° front swivel wheels for short turning radius’
• 5 position height adjustment
• Fold-down-handle
• Quick release filter mounting strap
• Dust retentive felt, heavy duty outer filter
• Welded steel frame in structural foam housing
• Industrial quality universal motor with cast metal fan
• Protective wrap-around bumper guards
• Top-fill system eliminates clogging at intake – assures
maximum pickup performance
• Multiple sizes 24” & 28”
• Warranty - 2 year on motor & fan, 1 year overall,
belt & brushes not covered under warranty
Specification
SKU Number: BGCC24
BGCC28
Cleaning Path: 24”
28”
Weight:
55 lbs.
57 lbs.
Length:
36”
36”
Width:
25”
29”
Height:
36 ½”
36 ½”
Motor:
5/8 HP
5/8 HP
AMPS:
8.5
8.5
CFM:
200
200
Brush RPM:
3,500
3,500
Brush Diameter: 3”
3”
Brush:
Chevron
Chevron
Height Settings: 5 Settings, 0 – 1.25”
Power Cord:
60’
60’
Sound:
70 Db(A)
78 Db(A)
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
NO
ELECTRICITY
NEEDED
Highly Efficient, Easy To Operate,
21” Wide, Dual Brush System Sweeper
The two brushes rotate in opposite directions grabbing the
debris directly in front of the sweeper then deposits the debris
into the easy to empty 6.6 gallon container.
• 21” wide
• 6.6 gallon debris container
• Sweeps fine & course dirt
• Sweeps wet & dry leaves
• Side rollers that make
sweeping along walls an ease
• Belt free system
• Light weight for easy use
• Stand up storage design
for easy storage
• Comes with lubricant spray
• 4 year warranty on brushes
• 2 year overall warranty
Specifications
Model:
BG255
Width:
21 inches
Weight:
13.2 lbs.
Container
Capacity:
6.6 Gallons
Roller Brush: Fiberglass
Height
Adjustment: Yes
Side Rollers: Yes
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
NO
ELECTRICITY
NEEDED
Deluxe Turbo Sweeper, Easy To Operate,
31” Wide, Triple Brush System Sweeper
The patented Turbo sweeping system sweeps twice with one move!
The two front brushes rotate in opposite directions grabbing the
debris directly in front of the sweeper while the brush roller on the
bottom picks up all the fine particles, all the debris is then deposited
into the large easy to empty 13.2 gallon container.
• 31” wide
• 13.2 gallon debris container
• Ergonomic push handle
• Sweeps fine & course dirt
• Sweeps wet & dry leaves
• Side rollers that make
sweeping along walls an ease
• Belt free system
• Light weight for easy use
• Stand up storage design
for easy storage
• Comes with lubricant spray
• 4 year warranty on brushes
• 2 year overall warranty
Specifications
Model:
BG477
Width:
31 inches
Weight:
38 lbs.
Container
Capacity:
13.2 Gallons
Roller Brush: Fiberglass
Height
Adjustment: Yes
Side Rollers: Yes
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
NO
ELECTRICITY
NEEDED
Deluxe Turbo Sweeper, Easy To Operate,
38” Wide, Triple Brush System Sweeper
The patented Turbo sweeping system sweeps twice with one move!
The two front brushes rotate in opposite directions grabbing the
debris directly in front of the sweeper while the brush roller on the
bottom picks up all the fine particles, all the debris is then deposited
into the large easy to empty 13.2 gallon container.
• 38” wide
• 13.2 gallon debris container
• Ergonomic push handle
• Sweeps fine & course dirt
• Sweeps wet & dry leaves
• Side rollers that make
sweeping along walls an ease
• Belt free system
• Light weight for easy use
• Stand up storage design
for easy storage
• Comes with lubricant spray
• 4 year warranty on brushes
• 2 year overall warranty
Specifications
Model:
BG477
Width:
31 inches
Weight:
43 lbs.
Container
Capacity:
13.2 Gallons
Roller Brush: Fiberglass
Height
Adjustment: Yes
Side Rollers: Yes
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
Battery
Powered
Highly Efficient, Battery Powered, Easy To
Operate, 31” Wide, Triple Brush System Sweeper
The two front brushes rotate in opposite directions grabbing the
debris directly in front of the sweeper while the brush roller on
the bottom picks up all the fine particles, all the debris is then
deposited into the large easy to empty 13.2 gallon container.
• 31” wide
• 13.2 gallon debris container
• Sweeps fine & course dirt
• Sweeps wet & dry leaves
• Side rollers that make
sweeping along walls an ease
• Maintenance free motor & battery
• Light weight for easy use
• Stand up storage design
for easy storage
• Comes with lubricant spray
• 4 year warranty on brushes
• 2 year overall warranty
Specifications
Model:
BG677
Width:
31 inches
Weight:
44 lbs.
Container
Capacity:
13.2 Gallons
Roller Brush: Fiberglass
Height
Adjustment: Yes
Side Rollers: Yes
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
Battery
Powered
Highly Efficient, Battery Powered, Easy To
Operate, 38” Wide, Triple Brush System Sweeper
The two front brushes rotate in opposite directions grabbing the
debris directly in front of the sweeper while the brush roller on
the bottom picks up all the fine particles, all the debris is then
deposited into the large easy to empty 13.2 gallon container.
• 38” wide
• 13.2 gallon debris container
• Sweeps fine & course dirt
• Sweeps wet & dry leaves
• Side rollers that make
sweeping along walls an ease
• Maintenance free motor & battery
• Light weight for easy use
• Stand up storage design
for easy storage
• Comes with lubricant spray
• 4 year warranty on brushes
• 2 year overall warranty
Specifications
Model:
BG697
Width:
31 inches
Weight:
44 lbs.
Container
Capacity:
13.2 Gallons
Roller Brush: Fiberglass
Height
Adjustment: Yes
Side Rollers: Yes
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
Extractor
Commercial Deep Cleaning…Done Right,
Done Fast, and for a Great Price
A Big Fix for a Big Mess
• 2 motors and DirtLifter® power brush
• 2 large capacity tanks
• Adjustable handle
• Easy-Clean brush roller
BG10® Works Hard
You Work Smart…
and Finish Strong.
Fewer Stops – Maximum Efficiency
• 25 foot Extension Cord – 50 foot Cleaning Reach
Easy Portability!
• Cleans forward and back
• Powerful edge-to-edge suction
1 Year
Warranty
UPC # 011120059021
Optional Accessory Pack 30G3
Hose & Upholstery Tool
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
Weighs 42 lbs
1-800-242-1378
www.bissellcommercial.com
19” Orbiting Pattern Floor Machine
with Optional Screen Sanding Kit.
• Powerful induction motor is totally enclosed. No brushes or
commutator to wear out – ever!
• Orbiting transmission runs at over 1725 orbits per minute. The random
orbital drive means no torque gouging, swirling or vibrations.
• A 19” apron with optional vacuum connections controls and collects
sanding dust to create a lightweight, high productivity screen sanding
machine.
• Vacuum “T” mounting on handle lets you collect sanding dust with a
backpack or canister vacuum.
• Safety enhanced non-conductive dual triggers eliminates shock potential.
Safety interlock switch prevents unexpected startups.
• 50 foot long power cord.
• Free-floating, 14 gauge chromed steel handle has an easy kick release
and automatic locking system.
• 5 inch, non-marring transport wheels.
• 5 year motor warranty. 1 year overall.
Easy to operate
No Torque
No Gouging
No Swirling
Specification
Pad Drive Size:
Cleaning Path:
Motor:
Power Cord:
Switch:
Handle:
Weight:
BGLB9000
16”
19” orbital path
115V, 10.8 amps, 60 Hz.
50 foot, 14/3 gauge
safety cord
Dual-powered trigger
14 gauge chrome steel,
free floating
74 lbs. with sanding kit
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
Accessories
Item #
12TV027
53269-010327
53304-01
82001
82002
82003
82004
82005
82006
82007
82009
82011
82010
LB17012
LB17036
LB17040
LB17060
SS17060
SS17080
SS17100
SS17120
SS17150
Description
Vacuum Kit
17” Pad Holder
17” Pad Holder Green Bristle
17” White Scrub Brush
17” Dry Shampoo Brush
17” Nylo Grit Brush, Green-Gray
17” Black Polish Pad
17” White Polish Pad
17” Brown Polish Pad
17” Red Polish Pad
17” Lambs Wool Bonnet
17” Beige Stone Care Pad
17” Union Mix Scrub Brush
17” - 12 Grit Loop Back
17” - 36 Grit Loop Back
17” - 40 Grit Loop Back
17” - 60 Grit Loop Back
17” - 60 Grit Sand Screen
17” - 80 Grit Sand Screen
17” - 100 Grit Sand Screen
17” - 120 Grit Sand Screen
17” - 150 Grit Sand Screen
1-800-242-1378
www.bissellcommercial.com
Floor Machine
FMU
Burnisher
• 1.5 HP, DC rectified motor eliminates brown-outs, low voltage and startup
torque problems.
• An adjustable handle makes operating easy and comfortable.
• The low profile drive apron makes reaching under counter coves and beds
hassle free.
•Safety enhanced non-conductive dual triggers eliminates shock potential.
•Non-marring full wrap bumpers protects walls and baseboards.
Specifications
Item # :
Size:
Speed:
Weight:
Motor:
Amp draw:
Chassis:
Power Cord:
Wheels:
Warranty:
BGDC-19
BGDC-21
19”
21”
1500 RPM
1500 RPM
84 lbs.
86 lbs.
1.5 HP DC rectified
13 – 15 amps
Polished aluminum
50 foot safety 14/3 gauge
6” non-marking operating, 4” transport
5 year motor
BGDC19-2000
19”
2000 RPM
87 lbs.
BGDC-21-2000
21”
2000 RPM
89 lbs.
PRO FMC series Heavy-Duty Floor
Machines with Interchangeable
Aprons 13”, 15”, 17”, 19” and 21”.
• Available in one or two speed.
•Triple-planetary high torque transmission, handles the most demanding applications.
• Safety enhanced interlock switch, both hands are conveniently in control.
• Safety enhanced non-conductive dual triggers, eliminates shock potential
• All metal chassis adds weight for faster results.
• Fully adjustable handle position makes operating easy and comfortable.
Specifications
Item # :
Brush Speed:
Motor:
Amp Draw:
Chassis:
Power Cord:
Weight:
Brush Drive:
Wheels:
Warranty:
Aprons
Item # :
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
13”
BGBA-13
BGC-1
BGC-2
175 RPM
175 / 300 RPM
1.5 HP AC 2 capacitor
1.5 HP DC rectified
13 – 15 amps
13 – 15 amps
Polished aluminum Polished aluminum
50 foot safety 14/3 gauge
50 foot safety 14/3 gauge
98 – 107 lbs. (depends on apron selection)
“B” style clutch
“B” style clutch
6” non-marking
6” non-marking
5 year motor and gearbox
5 year motor and gearbox
15”
17”
19”
21”
BGBA-15
BGBA-17
BGBA-19
BGBA-21
1-800-242-1378
www.bissellcommercial.com
Floor Machine
PRO FMT
Dual-Speed
• Dual speed 175 / 300 RPM, 1.5 HP motor.
•Triple-planetary high torque transmission, handles the most demanding applications.
• Safety enhanced interlock switch, both hands are conveniently in control.
• Safety enhanced non-conductive dual triggers, eliminates shock potential
• All metal chassis adds weight for faster results.
• Fully adjustable handle position makes operating easy and comfortable.
Two machines
in one, for
spray buffing,
bonnet cleaning,
scrubbing
and shampooing
Specifications
Item # :
Size:
Speed:
Weight:
Motor:
Amp draw:
Chassis:
Power Cord:
Brush Drive:
Wheels:
Warranty:
BGTS-17
BGTS-19
BGTS-21
17”
19”
21”
175 or 300 RPM – Motor mount switch
92 lbs.
93 lbs.
94 lbs.
1.5 HP DC rectified
13 – 15 amps
Polished aluminum
50 foot safety 14/3 gauge
“B” style clutch
6” non-marking
5 year motor and gearbox
PRO FMH Heavy-Duty Floor Machine
• Brush speed 175 RPM, 1.5 HP motor.
• Triple-planetary high torque transmission, handles the most demanding applications.
• Safety enhanced interlock switch, both hands are conveniently in control.
• Safety enhanced non-conductive dual triggers, eliminates shock potential
• All metal chassis adds weight for faster results.
• Fully adjustable handle position makes operating easy and comfortable.
• Non-marking full wrap bumpers, fully protects floors, walls and baseboards
Hospital quiet,
for spray buffing,
scrubbing, stripping, Specifications
Item # :
BGH15E
BGH-17E
BGH-19E
BGH-21E
shampooing, and
Size:
15”
17”
19”
21”
bonnet cleaning
Speed:
175 RPM
175 RPM
175 RPM
175 RPM
Weight:
Motor:
Amp draw:
Chassis:
Power Cord:
Drive:
Wheels:
Warranty:
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
104 lbs.
106 lbs.
1.5 HP
1.5 HP
13 – 15 amps
Polished aluminum
50 foot safety 14/3 gauge
“B” style clutch
6” non-marking
5 year motor and gearbox
107 lbs.
1.5 HP
108 lbs.
1.5 HP
1-800-242-1378
www.bissellcommercial.com
Cord-Free Electric Sweeper
Powerful One Motor Floor Sweeper
Rechargeable System with Revolving Agitator Brush and Geared Belt Drive for Superior
Quick Pickup Cleaning on all Surfaces.
A Clean Sweep. For those times when a vacuum is too inconvenient and a broom is too time
consuming, reach for the Bissell BigGreen Commercial Cordless Electric Sweeper! The
Cordless Electric Sweeper is surprisingly lightweight and powerful for its size. It employs a
Nickel-Metal-Hydride battery with a running time 90 minutes. The battery-powered roller
brush sweeps dirt and bulkier items into its dustpan, which is easily removed for emptying.
The Cordless Electric Sweeper comes with a wall mount for out of sight storage and includes
a compact power adapter for charging. Whether sweeping up crumbs from under a table,
tidying up after children or quickly cleaning before and during a party, the Cordless Electric
Sweeper will help you spend less time cleaning and more time doing the things you enjoy!
• Battery long life energy saving Nickel-Metal-Hydride
(running time 90 minutes)
• Extra long life, energy saving, geared motor
• Titanium bushings for brush roller
(will not wear out like brass bushing)
• Laser balanced brush roller & wheels for smooth &
even operation
• Non slip geared belt
• Telescoping handle that makes operating comfortable
• Virtually indestructible hi impact housing & hood
• See thru front housing to view any possible blockage
• Dust bin designed to seal dust from leaking into motor housing
• Dust bin capacity 17 ounces
• Weighs only 3.9 pounds
• One year limited warranty
• UPC: 811827020030
Includes
Special
Brush for
Removal
of Pet
Hair!
• Item Number BG9100NM - Nickel-Metal-Hydride Battery
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
1-800-242-1378
www.bissellcommercial.com
Manual Sweepers
Great for
Foodservice!
Our Commercial Line Shows...
No One Knows Sweepers Better than BISSELL
• Corner Brushes
• Floating head
• Easy-empty dirt bin
• Comfortable grip
• Soft rubber wheels conform
to a variety of floor surfaces
• For low pile carpet
and bare floors
• 7.5 – inch cleaning path
• Dual debris canisters with
viewing window
• Two rows of rubber rotors
• UPC: 011120053166
Dual Rubber Brushes
For Wet Messes
BISSELL BIGGREEN COMMERCIAL
100 Armstrong Road Suite 101
Plymouth, MA 02360
• Corner Brushes
• Floating head
• Easy-empty dirt bin
• Comfortable grip
• Soft rubber wheels conform
to a variety of floor surfaces
• For low pile carpet
and bare floors
• 7.5 – inch cleaning path
• Dual debris canisters
• UPC: 011120053197
• Corner Brushes
• Floating head
• Easy-empty dirt bin
• Comfortable grip
• Soft rubber wheels
conform to a variety of
floor surfaces
• For low pile carpet
and bare floors
• 6.5 – inch cleaning path
• UPC: 011120053210
Durable,
Threaded
Handles & Quiet
et
Motor-Free
Systems
Tufted & Twisted
Brushes
Tight-Spot Cleaning
1-800-242-1378
www.bissellcommercial.com
Professional-Strength Cleaning Formulas
2X ADVANCED
FORMULA
49G5-1 (52 oz)
49G5 (32 oz)
Triple-action Cleaning
BigGreen
COMPLETE®
FORMULA
2X OXY
FORMULA
31B6
85T6-1 (52 oz)
85T6 (32 oz)
Cleaner and Defoamer
Oxygen-boosted Cleaning
t0EPSOFVUSBMJ[FS
t1PXFSTPVUHSPVOEJO
EJSUBOETUBJOT
Features:
t%FFQDMFBOTBOEQSPUFDUT
XIJMFSFNPWJOHUPVHI
PEPST
t$BSQFUSFGSFTIFS
t4PJMBOETUBJOQSPUFDUPS
t$PMPSTBGFGPSDBSQFU
BOEVQIPMTUFSZ
2X Advanced Formula
BigGreen COMPLETE Formula
2X Oxy Formula
Model #: 49G5-1
Volume: 52 fl oz (1.625 qt) 1.53 L
Model #: 31B6
Volume: 128 fl oz (1 gal) 3.78 L
Model #: 85T6-1
Volume: 52 fl oz (1.625 qt) 1.53 L
t4DPUDIHBSE™QSPUFDUJPO
t,FFQTDBSQFUTMPPLJOH
HPPEGPSBMPOHFSUJNF
Product Specifications:
Model #: 49G5
Volume: 32 fl oz (1.0 qt) 946 mL
3
Model #: 85T6
Volume: 32 fl oz (1.0 qt) 946 mL
*Scotchgard is a trademark of 3M
Oxy Deep® Pro
PRECLEANER
SPOT & STAIN
REMOVER
STOMP ‘N GO®
19X6
97W7
77D1
Odor & Stain
Heavy Traffic®
REMOVER
45V1
Eliminates Stains
& Odors
Makes Deep
Cleaning Easier
Permanently Removes
Tough, Set-in Stains
Stain Lifting Pads
For Fresh & Set-in Stains
Features:
t &O[ZNFBDUJPOGPSNVMB
DBQUVSFTBOEEFTUSPZTPEPST
t 1
FOFUSBUFTDBSQFUUP
SFNPWFFNCFEEFEEJSU
t 3FNPWFTVSJOFWPNJU
BOECMPPETUBJOT
t 1FSGFDUGPSEFFQDMFBOJOH
t $MFBOTPJMZCBTFETUBJOTMFGU
CZGPPEPSNPUPSPJM
t 3FNPWFTTNPLFNPME
NJMEFXBOELJUDIFOPEPST
t -FBWFTDBSQFUGSFTI
t "
UUBDLTDPGGFFTUBJOT
JOIJHIUSBGåDBSFBT
t & BSUIGSJFOEMZGPSNVMB‰
EZFBOEQIPTQIBUFGSFF
t (SFBUGPSQFUTUBJOT
t 0
YZHFOBDUJWBUFETUBJO
SFNPWFSFBTJMZFMJNJOBUFT
EFFQEPXOTUBJOT
t 5 BLFTPVUSFEXJOFKVJDF
GPPEEJSUDPGGFFTUBJOT
BOENPSF
t 3
FNPWFTHBSMJDPOJPO
BOEåTIPEPST
t 0
OFTUPNQBOEZPVS
XPSLJTEPOF
t /PTDSVCCJOH
t 3
FNPWFTVSJOFXJOFGPPE
TUBJOTNVEBOENPSF
t -FBWFTDMFBOGSFTITDFOU
t 'BTUBDUJOH
t $BSQFUTBGF
Product Specifications:
Odor & Stain REMOVER
Heavy Traffic PRECLEANER
Model #: 45V1
Model #: 19X6
Volume: 32 fl oz (1.0 qt) 946 mL
Volume: 32 fl oz (1.0 qt) 946 mL
Oxy Deep Pro
SPOT & STAIN REMOVER
Model #: 97W7
Volume: 32 fl oz (1.0 qt) 946 mL
STOMP ‘N GO Stain Lifting Pads
Model #: 77D1
Quantity: 20 CT
4
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
