FIREFIGHTER
www.scottyfire.com
2
BRAVO BACKPACK SYSTEM
4000-BRAVO
•
Ultra comfortable method to carry liquids used during fire operations.
•
Backpack has a capacity of 6 gallon (22 L), dimensions (empty)
are 24” H x 20” W.
•
The BRAVO Backpack consists of an outer, high-visibility yellow,
shell with a replaceable inner bladder.
•
Fully padded and adjustable shoulder and sternum straps.
•
Features: 4” filling port and lid with retaining strap, replaceable
bladder, 3⁄4” GHT outlet.
•
Waist belts can be rolled up and stored in onboard pockets.
•
Spine protecting center padding.
•
Gear pocket on the left-hand side for easy storage of hand pumps
or shovels.
•
Equipment storage pocket with clear label window (display crew
name/number).
•
2" wide carry handle on top of the backpack.
•
Includes 4 foot pickup hose with Quick Connect Shut-Off and
Pump Service Kit (4000SERVDB).
•
4000-BRAVO comes with a 4000, WATER Hand Pump.
•
4000F-BRAVO comes with a 4000F, FOAM Hand Pump.
The BRAVO Backpack is pictured
with the Scotty 4000 Water Hand
Pump and 4062 Pick-Up Hose. To
order,
use complete product
code 4000-BRAVO.
To order the BRAVO System with a
foam hand pump (4000F) use the
complete product
code 4000F-BRAVO.
3
FORESTRY WATER PUMP & BACKPACK
•
Includes Hand Pump, 5 gallon (19 L) Backpack, 4 foot Pick-up Hose and
pressure nozzle.
•
Single action pump with a brass inner chamber and piston.
•
Incorporates easy to pump "Duckbill" checkvalve system.
•
Outer sleeve made of super tough, engineering-grade polymer making it
durable and lightweight.
•
No tools required for in-the-field disassembly for maintenance.
•
Includes 4 foot pick-up hose with Quick Connect Shut-Off and Pump
Service Kit (4000SERVDB).
4000-BP
4000-BP
4000
Water Hand Pump and Backpack
4002A
4062
Water/Foam Backpack only
Water Hand Pump only
4ft. Pick-up Hose
FORESTRY FOAM HAND
PUMP & BACKPACK
4000F-BP
4000-BP
•
All the components and features of the 4000-BP Hand Pump & Backpack
(above) with the addition of a foam eductor and air-aspirating nozzle (4003).
•
The 4000F-BP eliminates the need to batch mix when Class A foam is
required.
•
Each time pump draws water, foam concentrate is educted at 1% into the
pump chamber.
•
The 4003 air-aspirating nozzle generates foam when the pump is
discharged.
•
Includes 4 foot Pick-up Hose with Quick Connect Shut-Off and Pump Service
Kit (4000SERV-DB).
4000F
4002A
Water/Foam Backpack only
4062
4ft. Pick-up Hose
Foam Hand Pump only
4000SERV-DB
Service Kit with
Duckbill Valves
4
WATER VEST
•
4" Filler Port and ¾" GHT Outlet.
•
6 Gallon (22 L) capacity.
•
Three quick release buckles.
•
Bright Yellow color for high visibility.
•
Available as Vest only (4002V) or paired with a Water Hand Pump (4000-V)
or a Foam Hand Pump (4000F-V).
4002V
4000-V
Water Vest with Water Hand Pump
4000F-V
Water Vest with Foam Hand Pump
Water Vest only
4002V
DECON HAND PUMP & BACKPACK
•
Used for applying liquid de-contamination products batch mixed in
the Backpack.
•
Includes a Hand Pump, 5 gallon (19 L) Backpack, 4 foot Pick-up Hose
and 4003 Foam Nozzle.
•
4" Filler Port and ¾" GHT Outlet.
•
All parts come in Black to accommodate military users.
BACKPACK FILL STATION
•
Provides a quick and easy method to refill Backpacks.
•
Installs on any 1-½” water outlet.
•
Connects to the Pick-up Hose of any Scotty Backpack (¾" GHT).
•
Consists of a 1-½” Water Thief Tee, Double Female Connector (NHT or
NP), 4 foot Hose and Quick Connect Shut-Off.
4200-DECON
4002FILL-NPSH Fill Station with NPSH connector 4002FILL-NHT
Fill Station with NHT connector
4000SERV
Pump Maintenance Kit
(for older model hand
pumps.)
5
6
FOAM EDUCTOR BACKPACK SYSTEMS
With portable foam systems, every fire hose line becomes a foam line. For
versatility and flexibility, Scotty has eight different flow rates. All units include:
•
•
•
•
Backpack with 5 gallon capacity.
Foam Pick-up Hose with foam control Quick Connector.
Air Aspirating Nozzle with matching Foam Eductor.
D-Handle Shut-Off with Pistol Grip, 1-½" thread.
The first 4 digits correspond to the nozzle included; the last two digits indicate the
flow rate (GPM).
Systems available with NP, NHT(A) and BSP(B) threads.
(Please indicate threads when ordering from your distributor).
4020BP15
4025BP30
15 GPM - 57 l/min
4030BP50
4031SBP50
50 GPM - 190 l/min
4033BP70
4034SBP70
4035MBP70
70 GPM - 256 l/min
4037MBP
70 GPM - 256 l/min
4037FBP70
70 GPM - 256 l/min
30 GPM - 114 l/min
50 GPM - 190 l/min
70 GPM - 256 l/min
70 GPM - 256 l/min
Equipped with Fog/Straight stream nozzle tip.
S = Stubby Nozzle
M = Medium Expansion
4037FBP70
The illustration below shows a
Scotty Foam Backpack System
4030BP50
OPTIONAL VARIABLE CHECKVALVE
The Eductor Backpack systems can be fitted with the 4064 Variable
Checkvalve Foam Control Unit. This extra option gives the operator the
ability to control the foam percentage being educted. The presets are
OFF, .5%, 1% and 3%.
4064
For more information
please see Pg.16
7
8
ROLL & FOAM
MOBILE FOAM ATTACK SYSTEM
•
Self-contained unit can transform any pressurized fire hose, water
supply line or stand pipe into a fire fighting, foam generating, station.
•
The 4045A-30 System weighs 22 lb. (empty) and measures
34” H x 19” W x 15 ½” D.
•
Unit can be deployed and foam sprayed in under a minute.
•
Suitable for industrial sites and installations, warehouse storage
facilities, lumberyards, mines, shopping malls, schools, marinas,
harbors or aircraft hangars.
•
The 4045A-30 can be configured for Class B foam.
•
The system consists of a wheeled, 14 gallon capacity Supply Tank,
50' of flat hose, a 30 GPM Scotty Foam Eductor set at 1% for Class A
Foam and 30 GPM Air Aspirating Foam Nozzle with Pistol Grip Shut-Off.
•
The 4045 is designed for a nominal operating pressure of between
50 and 150 PSI.
•
The Supply Tank must be filled with foam concentrate prior
to deployment.
•
The threads on the swivel connector on the Eductor are standard
1-½” NP thread type.
•
A thread adapter is included to change to NHT(NST) thread.
•
The Eductor, Pistol Grip Shut-Off and base of the nozzle are made from
glass-reinforced engineering grade nylon, making it extremely durable
and resistant to corrosion.
4045A-30
9
10
FOAM FACTORY
•
Transforms any pressurized fire hose or water supply line into a fire
foam generating station.
•
A fire crew can arrive at an incident where a quick layer of foam is
required, such as a spill or haz-mat situation, attach a supply hose
and place the foam where it is needed.
•
The unit can be left unattended to create a blanket of foam over
a large area.
•
The system consists of a 15 GPM Scotty Foam Eductor set for
either 1% for Class A foam or 3% for Class B foam, a Fog Nozzle
with Medium Expansion Attachment, a bale Shut-Off with 1-½"
swivel connection mounted on a cap and a pick-up assembly for a
5 gallon pail.
•
The Foam Factory is designed for a nominal operating pressure of
between 50 and 100 PSI.
•
Please specify standard NHT or NPSH thread when ordering.
4039-15FFA
( 5 Gallon pail not
included.)
FIRE GEL APPLICATOR KITS
•
Applicators for all brands of aqueous fire fighting Gels, like
Barricade, Phos-Chek, Thermo-Gel and No-Char.
•
Scotty makes the most economical, effective and easy to use Gel
Delivery Systems available today.
•
Fire Gel concentrates consist of super absorbent polymers that
absorb and grow to hundreds, even thousands of times their size
when exposed to water.
•
The polymers, with all that extra water, provide an excellent
thermal barrier against fire. The clinging properties of Fire Gel
enable it to be applied precisely where it is needed.
•
Fire Gels can be applied to metal, glass, stucco and wood.
•
When properly applied, Fire Gels will remain hydrated and effective
for many hours.
4047-PP30
30 GPM
Gel Kit with pick-up tube
and hose. (5 gallon gel
pail not included.)
4047-3
3 GPM
Gel Kit
4075-GEL15
15 GPM
Gel Kit
11
FOAM APPLICATOR KIT
4075-15
4075-30
4075-50
4075-70
•
Designed as an "End-of-the-Line" hose attachment.
•
Provides fast and easy delivery of Class A or Class B (AFFF) foams.
•
Standard fixed eduction rates of 1% or 3% (if specified).
•
Ideal for applications in many environments; Fire Departments, Industrial
Facilities, Storage Facilities, Marinas, Aircraft Hangers, etc.
•
Manufactured from glass reinforced nylon for strength and durability.
•
If you require an extra 1.3 Gallon (5 L) foam container, please use
product code 4074. Comes with cap & seal.
4075-15V
4075-30V
4075-50V
4075-70V
4075-15
4075-30
15 GPM Foam Applicator Kit
1-½" hose lines
30 GPM Foam Applicator Kit
1-½" hose lines
4075-50
4075-70
50 GPM Foam Applicator Kit
1-½" hose lines
70 GPM Foam Applicator Kit
1-½" hose lines
FOAM APPLICATOR KIT WITH VARIABLE PERCENTAGE
•
As above with the added capability to change the foam percentage.
•
The Variable Checkvalve can be set to OFF, 0.5%, 1% or 3%.
4075-3
•
4075-15V
4075-30V
15 GPM Foam Applicator Kit
1-½" hose lines
30 GPM Foam Applicator Kit
1-½" hose lines
4075-50V
4075-70V
50 GPM Foam Applicator Kit
1-½" hose lines
70 GPM Foam Applicator Kit
1-½" hose lines
Custom settings are available. Please call for details!
FOAM APPLICATOR KITS FOR ¾" GHT HOSE LINE
4075-8
•
Ideal for economical use of water without sacrificing fire
fighting effectiveness.
•
Great for use in situations where there are water limitations.
•
Both 3 GPM and 8 GPM kits operate with a pressure of 40 PSI
or greater.
4075-3
4075-8
12
3 GPM Foam Applicator Kit
¾" forestry/garden hose
8 GPM Foam Applicator Kit
¾" forestry/garden hose
FOAM-FAST™ FOAM APPLICATORS
•
Simple and effective method of deploying Foam-Fast™ wetting agent
onto a fire scene.
•
To operate, open the inlet side of the mixing chamber, insert a
Foam-Fast™ cartridge, reseal the inlet end cap, attach to a supply
hose and spray Class A foam.
•
The foam cartridge will dilute into the water flow and emerge through
the Air Aspirating Nozzle.
•
Foam-Fast™ cartridges are produced by ICL Performance, makers of
Phos-Chek Foam.
•
Available in multiple flow rates (see chart below) for ¾" GHT and
1-½" NHT, NP or BSP threaded hose lines.
•
A 4010-MINI will convert a Scotty 4000 Water Hand Pump into a
foam generator. Comes with an Air Aspirating Nozzle and uses
3" long cartridges.
4010-MINI
4010-3
4010-3
Mixer, ¾" Shut-Off and 3 GPM nozzle, uses 6" cartridges ¾" GHT
4010-15
Mixer, 1-½" pistol grip bale and 15 GPM nozzle, uses 12" cartridges
1-½" NHT, NP or BSP
4010-30
Mixer, 1-½" pistol grip bale and 30 GPM nozzle, uses 12" cartridges
1-½" NHT, NP or BSP
4010-50
Mixer, 1-½" pistol grip bale and 50 GPM nozzle, uses 12" cartridges
1-½" NHT, NP or BSP
4010-MINI
Mixing unit for Scotty 4000 Water Hand Pump, includes 3 GPM
foam nozzle, uses 3" cartridges
¾" GHT
4010-15
4010-30
4010-50
13
"THROUGH-THE-PUMP"
FOAM EDUCTOR AND MIXER
4171
•
Educts foam concentrate into hose lines through a pump's
suction and discharge sides, also known as an
"Around-The-Pump" system.
•
Will educt concentrates at percentages of 0% to 3.75%
at flow rates from 15 to 125 GPM at 100 PSI.
•
Maximum operating pressure of 300 PSI.
•
Includes an 18" Pressure Hose and a 48" Foam Pick-up Hose.
•
Use stock code 4171KIT to include one 1-½" Cast Aluminum
Connecting Tee and one 2" Cast Aluminum Connecting Tee.
4171KIT
( 4171 shown mounted to
a Skid Unit )
14
Be sure to connect
with us on Facebook!
facebook.com/ScottyFire
FOAMCHECK PRO
FOAM CONCENTRATE METER
•
Displays real-time measurement of the percentage of Class A
foam concentrate in hose lines.
•
Senses foam concentration 60 times a second.
•
Calibration is a simple two step process.
•
Sealed, weather-proof housing is suitable for harsh environments.
•
Display Console measures 5.7" x 3.8" x 2.3".
•
Includes Display Console, 1-½" Sensor Tee with NHT or
NP threads with 5' long connection cable.
•
Self powered by 2 AA batteries (included).
•
Maximum operating pressure of 300 PSI.
•
Automatic power down after 30 min. to save battery life.
4070
15
MINI FOAM EDUCTOR / MIXER KIT
4072KIT
•
"Through-The-Pump" foam system for smaller portable water pumps.
•
Like the larger 4171, the unit is mounted between the discharge and
suction side of a pump.
•
The 4072KIT comes with two 1-½” NP cast aluminum swivel Tee’s.
•
Set for preset eduction ratios of: OFF - .2 - .5 - .7 and 1%.
•
The 4072 is available for flow rates of: 15 GPM (57 LPM), 30 GPM
(140 LPM), 50 GPM (225 LPM) and 70 GPM (315 LPM).
•
Please specify GPM rating when ordering.
FOAM EDUCTORS
•
Fits 1-½" hose lines and are available in 5 flow rates.
•
Comes with standard Checkvalve set for a fixed 1% eduction ratio.
•
Checkvalves are available, upon request, for 0.5% or 3% eduction rates.
•
Match to Scotty Air Aspirating Nozzles of the same flow rate.
•
Can be mounted at the pump or in "End-of-Line" position.
•
Maximum downstream hose length of 150 ft. when mounted at the pump.
4060-15
4060-30
15 GPM Foam Eductor
4060-50
4060-70
50 GPM Foam Eductor
4060-95
95 GPM Foam Eductor
30 GPM Foam Eductor
70 GPM Foam Eductor
VARIABLE PERCENTAGE CHECKVALVES
Designed to fit all Scotty 4060 Eductors. Controls the percentage of
foam concentrate.
•
Four control positions: Off - .5% - 1% and 3%.
•
Suitable for eduction of Class A and Class B (AFFF) foam
concentrates.
•
They can be retrofitted onto Scotty 4060 Eductors.
4064
4065
4064
4065
16
•
For use with ¾” GHT Foam Pick-up Hose
For attaching to 1.3 gallon jugs,
used in 4075 Foam Kits NOTE: When ordering checkvalves, the flow rate of the
eductors must be specified.
AIR ASPIRATING FOAM NOZZLES
•
Manufactured from engineering grade, composite polymers for
durability at the fire scene.
•
All 1-½” Scotty Air Aspirating Nozzles include a double female
connector, 4085 (NP) or 4086 (NHT).
•
See pages 18-19 for seperate product codes.
17
4003
4015
4020
4025
18
4030
4031 / 4031S
4033
4034 / 4034S
19
FOG/STRAIGHT STREAM NOZZLE
4035-HF
•
Scotty’s New Fog/Straight-Stream Nozzle is a durable, light weight,
maintenance free adjustable nozzle.
•
It creates a perfect, wide, fine mist in fog mode and has excellent
reach of stream, 80’ at 100 PSI in straight mode.
•
NP (Red)
4035-HFA
NHT (Orange)
( *4038 Nozzle series has
"twist to shut-off" capability.)
20
It is available in a High-Flow (50 GPM to 100 GPM) and a Low-Flow
(15-50 GPM) model. Nozzle shuts off past straight stream.
•
Both flow rates are available in 1.5” NP, NHT, or BSP female threads.
•
This Nozzle can be used with Foam or Gel products.
4035-HF
50 GPM to 100 GPM 1.5" NP
4035-HFA
50 GPM to 100 GPM 1.5" NHT
4035-LF
15 GPM to 50 GPM
1.5" NP
4035-LFA
15 GPM to 50 GPM 1.5" NHT
*4038-HF
50 GPM to 100 GPM 1.5" NP
*4038-HFA
50 GPM to 100 GPM 1.5" NHT
*4038-LF
15 GPM to 50 GPM
1.5" NP
*4038-LFA
15 GPM to 50 GPM 1.5" NHT
FOG/STRAIGHT STREAM NOZZLE
WITH D-HANDLE PISTOL GRIP SHUT-OFFS
•
Designed for use with In-Line Foam Eductors, these Nozzles cannot be
closed off.
•
Available in High-Flow (HF = 50 to 100 GPM) and Low-Flow
(LF = 15 to 50 GPM).
•
4037 units include a Pistol-grip, bale shut-off.
•
Suitable for Class A and Class B foams.
•
Comes with 1-½” NHT, NP or BSP swivel connections.
•
For the nozzle only (with no Shut-Off capability), use stock codes:
4035-HF and 4035-LF.
4037-HF
50 GPM to 100 GPM 1.5" NP
4037-HFA
50 GPM to 100 GPM 1.5" NHT
4037-LF
15 GPM to 50 GPM
1.5" NP
4037-LFA
15 GPM to 50 GPM 1.5" NHT
4037-LF
NP (Red)
4037-LFA
NHT (Orange)
(Shown with optional 4080
D-Handle Shut off)
PINCHER DUAL PATTERN NOZZLE
4006
MINI PINCHER DUAL PATTERN NOZZLE
4007
4007SO
Mini Pincher
paired with
optional Shut-Off
21
4039MX-HF
4039MX-LF
4039MX
22
MEDIUM EXPANSION (MX) FOAM ATTACHMENT
•
Designed to fit the Scotty 4035, 4037 and 4038 Fog Nozzles.
•
Also fits the UFS 1575 Fog Nozzle.
•
Generates a thick stream of medium expansion foam for car or
tire fires, haz-mat or any situation where a thick smothering foam blanket
is required.
•
Quickly lays down a foam firebreak for forest and grassland fires.
4039MX-HF
MX Foam Attachment with 4035-HF 4039MX-LF
MX Foam Attachment with 4035-LF PENETRATOR NOZZLE
•
¼" tip opening for penetrating deep into the forest duff.
•
Tip opening can be bored out for higher flow.
•
Includes double female fitting to provide female thread connection.
1-½" (38 mm) NHT, NP or BSP male threads.
•
Maximum operating pressure 150 PSI.
4005
(Shown with optional 4080
D-Handle Shut off)
SMOOTH BORE NOZZLES
•
Available in 50 GPM (190 LPM) and 100 GPM
(380 LPM) sizes.
•
Includes double female fitting to provide female
thread connection.
•
1-½" (38 mm) NHT, NP or BSP male threads.
•
Maximum operating pressure 150 PSI.
4032-50
4032-100
23
MINI MONITOR (BASE ONLY)
4049
•
Nozzle mounting system for trucks, ATVs or boats.
•
Includes mounting plate, full 360º rotating pedestal base
and adjustable nozzle tube.
•
Recommended for up to 1-½" hose lines, pressure of
50 to 150 PSI.
•
Angle of tube can be locked in one of seven positions.
•
ABS, Ny-Glass and Stainless Steel construction.
•
Extremely durable and impervious to corrosion.
MINI MONITOR SYSTEMS
4049-15
Mini Monitor with 15 GPM Foam Tube
1-½” NP
4049-15A
Mini Monitor with 15 GPM Foam Tube
1-½" NHT
4049-30
Mini Monitor with 30 GPM Low-Flow Fog Nozzle
1-½” NP
4049-30A
Mini Monitor with 30 GPM Low-Flow Fog Nozzle
1-½" NHT
4049-50
Mini Monitor with 50 GPM Foam Tube
1-½” NP
4049-50A
Mini Monitor with 50 GPM Foam Tube
1-½" NHT
4049-50SB
Mini Monitor with 50 GPM Smooth Bore Nozzle
1-½” NP
4049-50SBA
Mini Monitor with 50 GPM Smooth Bore Nozzle
1-½" NHT
4049-30
4049-50SB
4049-15
(Shown with optional
4039MX Foam Attachment)
24
Yellow 4044 for NP Thread
Orange 4044 for NHT Thread
REVOLVER MULTI-FLOW NOZZLE
•
Multi settings provide flow rates of 3, 6, 9 and 12 GPM.
•
Outer barrel rotates easily to desired flow setting.
•
Made from glass-reinforced, engineering grade polymer
making it lightweight, extremely durable and corrosion proof.
•
Suitable for Class A or Class B foams.
•
Comes with 1-½” female NHT or NP threads via a Double
Female or with a Quarter Turn Quick Connect (4044QC).
4044
PILLOW TANKS
•
Designed to carry and/or store water for use at fire scenes
and incident sites.
•
Available in capacities of 132 US gal (500 L) and 264 US gal
(1000 L).
•
Made from fabric reinforced materials.
•
Includes 2” NP ball valve, removable 5-½” wide cap,
fastened corner brackets for tie downs.
•
Not approved for potable water.
4550-500
500 L (132 US gal) 58” x 64” (Empty)
4035-HFA 1000 L (264 US gal)
58” x 106” (Empty)
4550-500
(4550-500 L (132 gallon) Tank
filled in a short box pick-up.)
25
SPANNER / GAS WRENCH
4577
26
The above sequence of photos shows the
4577 Wrench being used to crack open a
standard 5 gallon foam pail.
•
Used to tighten and loosen 1” (25 mm) to 3” (76 mm) hose
coupler fittings.
•
Made from tough Ny-Glass in a high visibility yellow color.
•
Opens standard 70 mm caps on 5 gallon foam concentrate containers.
•
Includes a municipal gas and Oxygen tank shut off.
•
Spark and corrosion proof, with quick release snap hook.
•
Weighs just 2-¾ oz (79 g) and is 7-½” (190 mm) long.
DRUM & PAIL WRENCH
•
Opens and closes the caps found on standard 5 gallon foam pails.
•
Works for the large and small bungs on 55 gallon drums.
•
Made of Ny-Glass in high visibility yellow and is spark and
corrosion proof.
•
Fits optional 4580 Mounting Bracket (below).
•
Weighs 6.5 oz (185 g) and is 10” (254 mm) long.
4578
SUPER SPANNER HYDRANT WRENCH
•
Operates standard 1-½” and 1-¼” pentagon fire hydrant nuts.
•
Opens large and small bungs on 55 gallon drums.
•
Fits hose couplers ranging from 3” (76 mm) up to 7” (178 mm).
•
4 and 5" Stortz fittings.
•
Opens standard 70 mm caps on 5 gallon foam concentrate containers.
•
Municipal gas cock shut off.
•
Oxygen tank shut-off and quick release snap hook.
•
Fits optional 4580 Mounting Bracket (below).
•
Weighs 14 oz (400 g) and is 17-3/4” (450 mm) long.
WRENCH BRACKET
•
Mounting Bracket for the Scotty 4578 and 4579 Wrenches.
•
Simple snap clip secures Wrench in place on a wall or
in a cabinet, etc.
•
Can be installed vertically, horizontally or at virtually any angle.
4579
4580
RESCUE ROPE BAG
•
50’ x 9/32" 550 lb test (15 m x 7 mm, 250 kg test).
•
Braided MFP Polypropylene floating rope.
•
Bright orange, self-draining rope bag with internal floatation.
•
Bag has 3M reflective safety band.
4093
27
4050
NP (Yellow)
4050A
NHT (Orange)
4050QC3
28
3-WAY VALVE
•
Light weight water distribution device.
•
New valve handle accepts Stortz adapters.
•
Durable construction, made of Ny-Glass.
•
Built in "weep" feature to help prevent silt blockage.
•
3 x 1-½” male NHT (Orange handle) or NP (Yellow handle) threads.
•
Available with Forestry Quarter Turn Quick Connects affixed, stock
code 4050QC3.
•
Rated for 300 PSI safe working pressure.
3/4" FORESTRY HOSE WINDER
•
Simple and effective tool used to recover and wind up 50' flat hose lines.
•
Drains and cleans debris off the hose as it is wound up.
•
Saves time by creating a tight roll, making hose delivery
and clean up a time-saving process.
4100
4040A
WATER THIEF
•
Fits onto 1-½” hose line to provide an extra ¾" GHT outlet.
•
Made of high-visibility, light-weight polyethylene.
•
Ideal for sprinkler and forestry mop-up operations.
NHT (Orange)
4040
NP (Yellow)
4040SO
WATER THIEF WITH SHUT-OFF
•
4040 Water Thief with the addition of a ¾" GHT Shut-Off.
•
Available with optional Quarter Turn Quick Connects.
3-WAY CONNECTOR
4040QC-SO
4040SO with
Quick Connects
4055
NP (Yellow)
•
As the 4050, without valve.
•
Ny-Glass construction, light weight.
•
3 x 1-½” male NHT (Orange cap) or NP (Yellow cap) threads.
•
Available with Forestry Quarter Turn Quick Connects affixed,
stock code 4055QC3.
•
Rated for 300 PSI safe working pressure.
4055A
NHT (Orange)
4056
SQUALL WALL™
•
Appliance for a pressured water line, creates a wall of water to help
wet and protect.
•
Can create a wall of water 40 feet wide and 20 feet high.
•
Secure with three screws or a single spike in the ground.
•
Three flow rates available: 15, 30 and 50 GPM.
•
Available with 1-½" male or with female threads
(with double female connector).
Spray Pattern
29
ADAPTERS
4084
4084
1-½" Female NP x 1-½" Male NHT
(38 mm F NP x 38 mm M NHT)
4084AC
1-½" Female NHT x 1.5" Male NP
DOUBLE FEMALE CONNECTORS
4085
4085
4086
1-½" NP x 1-½" NHT
4086AA
1-½" NHT x 1-½" NHT
1-½" NP x 1-½" NP
DOUBLE FEMALE SWIVEL CONNECTORS
4087
4088
4091
1-½" NP x 1-½" NP
1-½" NP x 1-½" NP
DOUBLE MALE CONNECTORS
4091
4091AA
1-½" NHT x 1-½" NHT
4091AC
1-½" NHT x 1-½" NP
1-½" NP x 1-½" NP
REDUCERS
4082
4076
4076-34
1-½" Female NP x 1" Male NHT
4076-34F
4077
1-½" Female NP x 3/4" Female GHT
4077-34
4077-34F
1-½" Female NHT x 3/4" Male GHT
1-½" Female NP x 3/4" Male GHT
1-½" Female NHT x 1" Male NHT
1-½" Female NHT x 3/4" Female GHT
4082
4082AC
1-½" Male NHT x 1" Female NHT
4083
1-½" Male NP x 1" Female NP
1-½" Male NHT x 1" Female NP
CONNECTING TEE
4051
30
4051
4051A
3 x 1-½" NP Threads
3 x 1-½" NHT Threads (Orange)
QUARTER TURN QUICK CONNECT
•
Used by Forestry Crews for decades to connect hose lays quickly.
•
Made of Ny-Glass, they are durable, lightweight and will never corrode
or seize like traditional aluminum QTQCs.
•
Eliminates problems associated with incompatible threads
and speeds the connecting of hoses, nozzles and appliances with its
instantaneous connection.
4089F
4089M
4089YF
4089YM
4089AF
4089AM
4089YM + 4089YF
Quick Connect x 1-½" Female NP (Black in color)
Quick Connect x 1-½" Male NP (Black in color)
Quick Connect x 1-½" Female NP (Yellow in color)
Quick Connect x 1-½" Male NP (Yellow in color)
Quick Connect x 1-½" Female NHT (Orange in color)
Quick Connect x 1-½" Male NHT (Orange in color)
4089AM + 4089AF
PISTOL GRIP BALE SHUT-OFF
•
Lightweight, easy-grip bale valve.
•
Finger grooved hand grips for better comfort.
•
Connects to 1-½” fire hose, or with a 4082/4083 reducer,
a 1” hose line.
•
Manufactured from tough, corrosion-free, glass-reinforced polymers.
•
Available in NHT(4080A), NP or BSP(4080B) threads.
•
Handle Grips for the 4080 are available in Black, Blue, Orange
and Yellow (eg. 4080GRPSBLUE, ORG, or YEL).
4080
4080A
4080
1-½" Female NP Inlet and 1-½" Male NP outlet
1-½" Female NHT Inlet and 1-½" Male NHT outlet
D-HANDLE SHUT-OFF
•
As the 4080 above, but without the pistol grip.
4081
4081A
4081
1-½" Female NP Inlet and 1-½" Male NP outlet
1-½" Female NHT Inlet and 1-½" Male NHT outlet
31
FIREFIGHTER
A Division of:
Scott Plastics Ltd.
2065 Henry Ave West
Sidney, BC, Canada
V8L 5Z6
1-800-214-0141
Email: [email protected]
www.scottyfire.com
Distributed by:
Manufactured in Canada
Printed in Canada
Edition 16
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
