High-Speed Document
Scanners Catalog
EFFICIENT AND AFFORDABLE DOCUMENT IMAGING
Canon DR-Series and ScanFront Scanners—the right
choice for workflow and budget optimization.
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
NETWORK SCANNERS
ScanFront 220/220P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ScanFront 220e/220eP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
PERSONAL SCANNERS
P-150M . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
P-150 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
WORKGROUP SCANNERS
DR-2020U . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
DR-2510M/2010M . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
DR-2510C/2010C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
DR-2580C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
DR-3010C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
DEPARTMENTAL SCANNERS
DR-4010C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
DR-5010C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
DR-6010C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
PRODUCTION SCANNERS
DR-6050C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
DR-7090C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
DR-9050C/7550C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
DR-X10C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
OPTIONAL ACCESSORIES/EXCHANGE PROGRAMS
Carrying Cases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Canon CarePAK® Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Canon CarePAK Extended Service Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Detachable Flatbed Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Additional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
HIGH-SPEED DOCUMENT SCANNERS
Capture, manage, and distribute information with greater speed, ease, and efficiency than ever
before with high-performance document scanning solutions from Canon.
Canon’s high-speed imageFORMULA DR-Series and ScanFront scanners are integral elements
of enterprise content management solutions. As front-end scan capture hardware components,
the scanners’ reliability, performance, and feature-rich functionality are critical for ensuring the
accuracy and overall effectiveness of any document management workflow.
The imageFORMULA scanners are built upon superior image quality and reliability drawn from
Canon’s high-precision optical and rotary microfilm technology expertise. They offer enhanced
sensor technology, a reliable feeding system, and unparalleled scanning speeds. The DR-Series
and ScanFront scanners are capable of handling high volumes of mixed paper sizes or other
challenging scan operations and offer exceptional image quality, capturing fine lines and intricate
image details with utmost precision and clarity_without sacrificing maximum scanning speeds.
High-Performance Scanning
High-Speed Scanning
With fast throughput, efficient paper handling, and intuitive
image processing functions, Canon document scanners
help manage documents in record speed.
Built-in ADF
A high-capacity Automatic Document Feeder
allows for fast, unattended scanning of batches
of documents in mixed sizes.
Simultaneous Double-Sided Scanning
Scan double-sided pages just as quickly as single-sided
pages. Each scanner is equipped with dual sensor
units to capture both sides of a page in one pass.
Advanced Scanning Features
Intelligent devices designed for tasks at
hand, loaded with the right mix of automatic
and customizable functions to enhance the
image capture process.
Unbeatable Price/ Performance
Fast, high-performance duplex document
scanners, feature rich, reliable, and durable
with an industry-leading combination of
price and performance.
User-Friendly Operation
Increased operator handling comfort through
ergonomic, compact, and lightweight designs. Plus,
easy maintenance with user-replaceable feed rollers
and quick access to routine scanning tasks through
programmable pre-registered Scan-to-Job buttons.
3
Advanced Image Processing
Technology
Correction*
3-Dimensional Color
Thanks to an incorporated color conversion chip,
the 3-Dimensional Color Correction achieves
unprecedented color accuracy that’s true to the
original. The end result is superior color quality plus
enhanced readability for OCR scanning applications.
Automatic Color Detection
This function automatically determines which
documents of a mixed batch should be scanned in
color, so it’s no longer necessary to separate blackand-white and color documents prior to scanning.
Deskew
If a document is fed into the scanner at an angle, this
function automatically straightens the scanned image.
Text Orientation Recognition
Perfect for scanning batches of documents that are
facing different directions, this feature recognizes the
text orientation of each fed document and rotates the
scanned images accordingly.
Text Enhancement
For clearer, more legible images from documents with
hard-to-scan elements such as light text or handwriting.
Color Dropout**
Red, green, or blue can be removed from document
images for improved readability in OCR applications.
Additionally, a range of specified colors can be dropped
out on certain scanners.
Auto Page Size Detection
Save the time and trouble of sorting batches by paper
size. This function automatically checks the size of
each fed document and ensures accurately cropped
images for each page.
Skip Blank Page
Useful for scanning batches that include single- and
double-sided documents, this feature automatically
removes unnecessary blank pages from the image file.
Advanced CMOS Contact Image Sensor***
Capture fine lines and intricate image details with
Canon’s advanced CMOS CIS technology. In addition
to providing superior image output, CIS technology
also helps reduce energy consumption and eliminates
warm-up time.
4
Superior Paper Handling
Reliable Paper Feeding
Canon’s revolutionary feeding mechanism with
separation roller achieves highly reliable page
separation, while preventing problems due to
partial double-feeding or dust damage.
s
Ultrasonic Double-Feed Detection
Ultrasonic sensors detect the gap between overlapping pages and prevent multiple pages from
being fed together, reliably ensuring that each
page of a document is scanned.
ss
U-turn/Straight Path Feeding
For enhanced efficiency and flexible scanning
of a range of document types, including plastic
cards and thick documents, select scanner models
feature a straight paper path in addition to the
standard U-turn path.
sss
Automatic Retry Feeding Mechanism
Upon double-feed detection, this mechanism will
reverse the documents and try to feed them again.
n
Staple Detection
Staple Detection sensors detect any irregular
document movement caused by staples and
stop the feeding in order to avoid any damage
to the document.
* Available
on the DR-X10C/9050C/7550C/6050C/6010C/5010C/4010C models, plus
DR-3010C/2510C/2510M/2010C/2010M/2020U/P-150/150M models, which feature
a 3-D Color Correction algorithm.
** Custom Color Dropout on the DR-X10C/9050C/7550C/7090C/6050C/6010C/5010C/
4010C models only.
*** All models, excluding DR-7090C, DR-2020U, and the flatbed options for DR-Series
Scanners which feature CCD technology.
s
Available on the DR-X10C/9050C/7550C/6050C/6010C/5010C/4010C/3010C/2580C/
2510C/2510M and ScanFront 220P/220eP models.
ss
Available on the DR-6010C/5010C/4010C/2580C models.
sss
Available on the DR-X10C only.
n
Available on the DR-X10C/9050C/7550C/6050C models.
SCAN TO SHARE THROUGH THE NETWORK
The Canon imageFORMULA ScanFront 220/220P network scanners are ideal for distributed, ad-hoc, and generalpurpose scanning. These compact, secure, and easy-to-use scanners feature direct network connectivity for fast and
easy installation, reducing the need for difficult-to-manage, power-hungry, dedicated PCs. The ScanFront 220/220P
scanners offer a user-friendly interface with full-color 8.5-inch touch-screen convenience plus state-of-the-art
imaging technology for superior scanning accuracy. They move capture closer to the point of origin within the
business process, eliminating complexity, reducing costs, and improving productivity and workflow efficiency.
Specifications
FEATURES
Type:
Network Scanner
•
8.5" Touch-Screen LCD
•
Error Diffusion
Document Feeding:
Automatic or Manual Sheetfed
•
Advanced Text Enhancement II
•
Fingerprint Reader (220P Only)
Network Functions:
Scan-to-E-mail, Scan-to-Folder,
Scan-to-FTP, Scan-to-USB Memory
•
Auto Page Size Detection
•
Skip Blank Page
•
Bleed-Through Reduction
•
Text Orientation Recognition
Network Protocols:
TCP/IP, SMTP, SMB, LDAP, NTP
•
Color Dropout/Enhance Color
•
File Formats:
PDF, Searchable and/or Encrypted PDF,
TIFF, JPEG
•
Deskew
Ultrasonic Double-Feed Detection
(220P Only)
Scanning Speeds*
B/ W:
Grayscale:
Color:**
Simplex
Up to 26 ppm
Up to 23 ppm
Up to 16 ppm
Scanning Element:
One-Line CMOS CIS
Duplex
Up to 35 ipm
Up to 23 ipm
Up to 16 ipm
Document Size
Width:
Length:
2" - 8.5"
2.1" - 14"
ADF Capacity:
50 Sheets
Interface:
2x USB 2.0, Ethernet, 2x PS/2
Dimensions (H x W x D):
6.2" x 12.2" x 9.2"
Weight:
7.5 lb.
OPTIONS
•
Exchange Roller Kit
•
Soft Carrying Case
•
One-Year CarePAK (Exchange Service)
•
Two-Year CarePAK (Exchange Service)
*
Examples based on typical settings, rated in pages/images per minute
with letter-sized documents at 200 dpi unless specified.
**
Examples based on typical settings, rated in pages/images per minute
with letter-sized documents at 150 dpi unless specified.
***
Calculation based on scanning speed and assumed daily use.
Suggested Daily Volume:*** 1,500 Scans
ScanFront 220P
ScanFront 220
5
SEAMLESS BUSINESS WORKFLOW INTEGRATION
The Canon imageFORMULA ScanFront 220e/220eP network scanners, powered by eCopy ShareScan, deliver
state-of-the-art image capture and intuitive document sharing through seamless integration with existing
networks, workflows, and applications.
These network scanners can help lower total cost of ownership through reduced requirements for hardware,
workspace, energy, and IT administration. Easy-to-use devices, the ScanFront 220e/220eP scanners are wellsuited for use in small- and medium-size businesses and large enterprises alike. They can seamlessly integrate
with existing networks and applications and are ideal for ECM, ERP, CRM, HRIS, and many more workflows.
Specifications
FEATURES
Type:
Network Scanner
•
8.5" Touch-Screen LCD
•
Skip Blank Page
Document Feeding:
Automatic or Manual Sheetfed
•
Automatic Page Size Detection
•
Text Orientation Recognition
Network Functions:
Scan-to-E-mail, Scan-to-Folder,
Scan-to-FTP, Scan-to-Print,
Scan-to-Fax, Scan-to-USB Memory,
Scan-to-WebDAV,† Scan-to-Database†
•
Bleed-Through Reduction
•
•
Color Dropout/Enhance Color
Ultrasonic Double-Feed Detection
(220eP Only)
•
Deskew
•
Bundled eCopy ShareScan
•
Fingerprint Reader (220eP Only)
•
Bundled eCopy Quick Connect
•
Halftone
•
Bundled eCopy Desktop
•
Indexing†
Network Protocols:
TCP/IP, SMTP, DHCP, SMB, LDAP
File Formats:
PDF, Searchable and/or Encrypted PDF,
TIFF, JPEG, PDF/A, eCopy
Scanning Speeds*
B/ W:
Grayscale:
Color:**
Simplex
Up to 24 ppm
Up to 16 ppm
Up to 11 ppm
Duplex
Up to 26 ipm
Up to 16 ipm
Up to 10 ipm
Scanning Element:
One-Line CMOS CIS
Document Size
Width:
Length:
2" - 8.5"
2.1" - 14"
ADF Capacity:
50 Sheets
Interface:
2x USB 2.0, Ethernet, 2x PS/2
Dimensions (H x W x D):
6.2" x 12.2" x 9.2"
Weight:
7.5 lb.
OPTIONS
•
Exchange Roller Kit
•
eCopy Connector–MS SharePoint
•
One-Year CarePAK
(Exchange Service)
•
eCopy Connector–OpenText RightFax
•
eCopy Connector–Interwoven Worksite
•
Soft Carrying Case
•
eCopy Connector–EMC Documentum
†
eCopy Quick Connect installation is required.
*
Examples based on typical settings, rated in pages/images per minute with
letter-sized documents at 200 dpi unless specified.
**
Examples based on typical settings, rated in pages/images per minute with
letter-sized documents at 150 dpi unless specified.
***
Calculated based on scanning speed and assumed daily use.
Suggested Daily Volume:*** 1,500 Scans
ScanFront 220e
6
ScanFront 220eP
PERSONAL DOCUMENT SCANNER FOR MAC® OS
The imageFORMULA P-150M Scan-tini personal document scanner is the next-generation of scanning
solutions for Mac OS environments. Easy-to-use scanning in a compact size, combined with broad
compatibility and advanced imaging features ensure an innovative yet simple approach to mobile and
portable capture, management, and storage of documents.
Specifications
FEATURES
Type:
Personal Scanners
•
Advanced Text Enhancement II
•
Skip Blank Page
Document Feeding:
Automatic or Manual Sheetfed
•
Automatic Color Detection
•
Text Orientation Recognition
•
Automatic Page Size Detection
•
TWAIN Drivers***
•
Bleed Through Prevention/
Background Removal
•
Bundled Canon
CaptureOnTouch Lite
•
Color Dropout/Enhance Color
•
Bundled Canon CaptureOnTouch
•
Deskew
•
Bundled Newsoft PaperPort
Scanning Speeds*
B/W:
Grayscale:
Color:
Simplex
Up to 15 ppm
Up to 15 ppm
Up to 10 ppm
Duplex
Up to 30 ipm
Up to 30 ipm
Up to 20 ipm
Scanning Element:
One-Line CMOS CIS
Document Size
Width:
Length:
•
Moiré Reduction
•
Bundled Presto! BizCard
2" x 8.5"
2.7" x 14"
•
Scan-to-Job Function
•
Bundled Evernote
ADF Capacity:
20 Sheets
OPTIONS
Interface:
Hi-Speed USB 2.0
•
A/C Adapter
Dimensions (H x W x D):
1.6" x 11" x 3.7"
•
Feed Roller
Weight:
2.1 lb.
•
Separation Pad
•
Soft Carrying Case
•
One-Year CarePAK (Exchange Service)
Suggested Daily Volume:** 500 Scans
* Examples based on typical settings, rated in pages/images per minute
with letter-sized documents at 200 dpi unless specified. Actual processing
speeds may vary based on PC performance and application software.
** Calculated based on scanning speed and assumed daily use.
*** Twain driver for Mac OS X 10.3.9 – 10.6
7
ULTIMATE MOBILITY
The imageFORMULA P-150 personal document scanner’s compact size, simple use, and advanced feature-set
liberate document capture by taking it beyond the walls of the office to the convenience of any user location.
The P-150 scanner combines practicality, productivity, and value in a sleek, mobile design.
Specifications
FEATURES
Type:
Personal Scanners
•
Advanced Text Enhancement II
•
Skip Blank Page
Document Feeding:
Automatic or Manual Sheetfed
•
Automatic Color Detection
•
Text Orientation Recognition
•
Automatic Page Size Detection
•
ISIS®/TWAIN Drivers
•
Bleed Through Prevention/
Background Removal
•
Bundled Canon
CaptureOnTouch Lite
•
Color Dropout/Enhance Color
•
Bundled Canon CaptureOnTouch
•
Deskew
•
Bundled Presto! BizCard
•
Moiré Reduction
•
Bundled Nuance PaperPort Standard
•
Scan-to-Job Function
Scanning Speeds*
B/W:
Grayscale:
Color:
Scanning Element:
Simplex
Up to 15 ppm
Up to 15 ppm
Up to 10 ppm
Duplex
Up to 30 ipm
Up to 30 ipm
Up to 20 ipm
One-Line CMOS CIS
Document Size
Width:
Length:
2" x 8.5"
2.7" x 14"
ADF Capacity:
20 Sheets
Interface:
Hi-Speed USB 2.0
Dimensions (H x W x D):
1.6" x 11" x 3.7"
Weight:
2.1 lb.
Suggested Daily Volume:** 500 Scans
* Examples based on typical settings, rated in pages/images per minute
with letter-sized documents at 200 dpi unless specified. Actual processing
speeds may vary based on PC performance and application software.
** Calculated based on scanning speed and assumed daily use.
8
OPTIONS
•
A/C Adapter
•
Feed Roller
•
Separation Pad
•
Soft Carrying Case
•
One-Year CarePAK (Exchange Service)
CLASS-LEADING FLATBED SCANNER
The imageFORMULA DR-2020U scanner enhances office productivity with reliable, versatile, three-way
scanning – ADF, flatbed, and dedicated business card scanning – plus rapid, one-pass duplex scanning.
This scanner’s simple, user-friendly design and bundled software package make it indispensable to any
office environment.
Specifications
FEATURES
Type:
Universal Workgroup Scanners
Document Feeding:
Automatic or Manual Sheetfed
Scanning Speeds*
B/W:
Grayscale:
Color:
Simplex
Up to 20 ppm
Up to 20 ppm
Up to 20 ppm
Scanning Element:
CCD (2)
Document Size
Width:
Length:
Flatbed:
Card Scanning:
5.5" x 8.5"
3.9" x 14"
Max. 8.5" x 11.7"
Width: 1.9" x 2.2"
ADF Capacity:
50 Sheets
Interface:
Duplex
Up to 40 ipm
Up to 40 ipm
Up to 40 ipm
Length: 3.3" x 3.6"
Hi-Speed USB 2.0
Dimensions (H x W x D):
7.1" x 17.3" x 15.8"
Weight:
17.2 lb.
•
Advanced Text Enhancement
(Two Types)
•
Text Orientation Recognition
•
Automatic Page Size Detection
•
ISIS/TWAIN Drivers
•
Border Removal
•
Bundled Canon CaptureOnTouch
•
Color Dropout/Enhance Color
•
Bundled Canon CapturePerfect
•
Deskew
•
Bundled Adobe® Acrobat® Standard
•
Punch Hole Removal
•
Bundled Nuance OmniPage SE
•
Scan-to-Job Function
•
Bundled Nuance PaperPort Standard
•
Skip Blank Page
•
Bundled Presto! BizCard
OPTIONS
•
Feed Roller
•
Separation Pad
•
One-Year CarePAK (Exchange Service)
Suggested Daily Volume:** 1,000 Scans
*
**
Examples based on typical settings, rated in pages/images per minute
with letter-sized documents at 200 dpi unless specified. Actual processing
speeds may vary based on PC performance and application software.
Calculation based on scanning speed and assumed daily use.
9
COMPACT COLOR DESKTOP SCANNER FOR MAC OS
The imageFORMULA DR-2510M and DR-2010M scanners are simple solutions for document capture needs in
Mac computer environments. With broad compatibility, high image quality, and fast scanning speeds – all in a
small footprint – the DR-2510M/2010M scanners reinvent the electronic content capture process.
Specifications
FEATURES
Type:
Workgroup Scanners
•
Advanced Text Enhancement II
•
Scan-to-Job Function
Document Feeding:
Automatic or Manual Sheetfed
•
Auto Color Detection
•
Skip Blank Page
•
Auto Page Size Detection
•
Text Orientation Recognition
•
Auto USB Power Switching
•
TWAIN Drivers***
•
Bleed-Through Prevention/
Background Removal
•
Ultrasonic Double Feed Detection
(DR-2510M only)
•
Color Dropout (RGB)/
Enhance Color (RED)
•
Bundled Canon CaptureOnTouch
•
Bundled Newsoft PageManager
•
Deskew
•
Bundled Presto! BizCard Reader
•
Moiré Reduction
Scanning Speeds*
DR-2510M
Simplex
Duplex
B/ W:
Up to 25 ppm Up to 50 ipm
Grayscale: Up to 25 ppm Up to 50 ipm
Color:
Up to 25 ppm Up to 50 ipm
Scanning Element:
DR-2010M
Simplex
Duplex
Up to 20 ppm Up to 40 ipm
Up to 20 ppm Up to 40 ipm
Up to 20 ppm Up to 40 ipm
One-Line CMOS CIS
Document Size
Width:
Length:
Long Doc. Mode:
2" x 8.5"
2.1" x 14"
Up to 39.4"
ADF Capacity:
50 Sheets
Interface:
Hi-Speed USB 2.0
Dimensions (H x W x D):
6.3" x 11.7" x 6.3"
Weight:
5.3 lb.
OPTIONS
•
Exchange Roller Kit
•
Soft Carrying Case
• One-Year CarePAK (Exchange Service)
Suggested Daily Volume:** 1,500 Scans
*
**
***
Examples based on typical settings, rated in pages/images per minute
with letter-sized documents at 200 dpi unless specified. Actual processing
speeds may vary based on PC performance and application software.
Calculation based on scanning speed and assumed daily use.
Twain driver for Mac OS X 10.3.9 - 10.6
DR-2510M
10
DR-2010M
COMPACT AND VERSATILE DOCUMENT SCANNING
The Canon imageFORMULA DR-2510C and DR-2010C color workgroup scanners deliver easy, high-quality
scanning in a versatile and space-saving design. Compact and flexible, the DR-2510C and DR-2010C
scanners can automatically and quickly scan multiple paper sizes and stocks, even plastic cards. Ideal
for all office scanning operations, these scanners provide reliable feeding, advanced image processing
functions, customizable Scan-to-Job buttons, and much more for any distributed imaging application.
Specifications
FEATURES
Type:
Workgroup Scanners
Document Feeding:
Automatic or Manual Sheetfed
Scanning Speeds*
DR-2510C
Simplex
Duplex
B/ W:
Up to 25 ppm Up to 50 ipm
Grayscale: Up to 25 ppm Up to 50 ipm
Color:
Up to 25 ppm Up to 50 ipm
DR-2010C
Simplex
Duplex
Up to 20 ppm Up to 40 ipm
Up to 20 ppm Up to 40 ipm
Up to 20 ppm Up to 40 ipm
•
Advanced Text Enhancement
(Two Types)
•
Ultrasonic Double-Feed Detection
(DR-2510C Only)
•
Auto Color Detection
•
ISIS/TWAIN Drivers
•
Auto Page Size Detection
•
Bundled Canon CaptureOnTouch
•
Auto USB Power Switching
•
Bundled Canon CapturePerfect
•
Bleed-Through Prevention/
Background Removal
•
Bundled Adobe Acrobat Standard
•
Color Dropout (RGB)/
Enhance Color (RED)
•
Bundled Nuance OmniPage SE
•
Deskew
•
Bundled Presto! BizCard Reader
•
Moiré Reduction
•
Bundled Nuance PaperPort Standard
•
Scan-to-Job Function
•
Bundled Kofax® VirtualReScan
(DR-2510C only)
Scanning Element:
One-line CMOS CIS
Document Size
Width:
Length:
Long Doc. Mode:
2" x 8.5"
2.1" x 14"
Up to 39.4"
ADF Capacity:
50 Sheets
•
Skip Blank Page
Interface:
Hi-Speed USB 2.0
•
Text Orientation Recognition
Dimensions (H x W x D):
6.3" x 11.7" x 6.3"
Weight:
5.3 lb.
Suggested Daily Volume:** 1,500 Scans
*
**
Examples based on typical settings, rated in pages/images per minute
with letter-sized documents at 200 dpi unless specified. Actual processing
speeds may vary based on PC performance and application software.
OPTIONS
•
Exchange Roller Kit
• One-Year CarePAK (Exchange Service)
•
Flatbed Scanner Unit 101
• Two-Year CarePAK (Exchange Service)
•
Soft Carrying Case
Calculation based on scanning speed and assumed daily use.
DR-2010C
DR-2510C
11
COMPACT, PORTABLE POWER
The Canon imageFORMULA DR-2580C color workgroup scanner is surprisingly compact and lightweight, so it can
be used on a desktop or taken on the road. This versatile scanner is loaded with advanced scanning technology
and easily handles a wide range of document types, including plastic cards. The DR-2580C scanner is not only
one of the smallest, but also one of the most easy-to-use scanners in its class. And adding the optional userinstallable flatbed unit allows you to scan books, passports, or fragile documents with simplicity.
Specifications
FEATURES
Type:
Workgroup Scanner
•
Advanced Text Enhancement
•
Three-Dimensional Color Correction
Document Feeding:
Automatic or Manual Sheetfed
•
Auto Page Size Detection
•
Ultrasonic Double Feed Detection
Scanning Speeds*
B/ W:
Grayscale:
Color:**
Simplex
Up to 25 ppm
Up to 25 ppm
Up to 17 ppm
•
Border Removal
•
ISIS/TWAIN Drivers
•
Color Dropout/Enhance Color
•
Bundled Canon CapturePerfect
•
Deskew
•
Bundled Adobe Acrobat Standard
Scanning Element:
One-line CMOS CIS
•
Dual Paper Path
•
Bundled Nuance OmniPage SE
•
Folio Mode
•
Bundled Presto! BizCard Reader
•
Scan-to-Job Function
•
Bundled Nuance PaperPort Standard
•
Skip Blank Page
•
Bundled Kofax VirtualReScan
•
Text Orientation Recognition
Duplex
Up to 50 ipm
Up to 50 ipm
Up to 32 ipm
Document Size
Width:
Length:
Long Doc. Mode:
2.1" x 8.5"
2.8" x 14"
Up to 39.4"
ADF Capacity:
50 Sheets
Interface:
Hi-Speed USB 2.0
Dimensions (H x W x D):
3.2" x 11.9" x 6.7"
Weight:
4.2 lb.
Suggested Daily Volume:*** 1,500 Scans
*
Examples based on typical settings, rated in pages/images per minute
with letter-sized documents at 200 dpi unless specified. Actual processing
speeds may vary based on PC performance and application software.
**
Examples based on typical settings, rated in pages/images per minute
with letter-sized documents at 150 dpi unless specified. Actual processing
speeds may vary based on PC performance and application software.
***
12
Calculation based on scanning speed and assumed daily use.
OPTIONS
•
Barcode Module III
•
Soft Carrying Case
•
Exchange Roller Kit
•
One-Year CarePAK (Exchange Service)
•
Full-Size Flatbed Unit
•
Two-Year CarePAK (Exchange Service)
•
Half-Size Flatbed Unit
SUPERIOR SPEED, RELIABILITY, AND EFFICIENCY
The imageFORMULA DR-3010C is Canon’s fastest and most reliable compact workgroup scanner, combining the
best features from the DR-Series scanners, delivering increased speed, high reliability, and maximum efficiency
and productivity. Bundled with the latest document imaging software packages, the DR-3010C becomes more
than just a scanner. It’s the package needed to infuse a busy, paper-intensive office with increased productivity
and more efficient workflow.
Specifications
FEATURES
Type:
Workgroup Scanner
Document Feeding:
Automatic or Manual Sheetfed
Scanning Speeds*
B/ W:
Grayscale:
Color:
Simplex
Up to 30 ppm
Up to 30 ppm
Up to 30 ppm
Scanning Element:
One-line CMOS CIS
Document Size
Width:
Length:
Long Doc. Mode:
2" x 8.5"
2.1" x 14"
Up to 39.4"
ADF Capacity:
50 Sheets
Interface:
Duplex
Up to 60 ipm
Up to 60 ipm
Up to 60 ipm
Hi-Speed USB 2.0
Dimensions (H x W x D):
7.8" x 12.2" x 11.5"
Weight:
6.4 lb.
Advanced Text Enhancement
(Two Types)
•
Skip Blank Page
•
Auto Color Detection
•
Ultrasonic Double Feed Detection
•
Auto Page Size Detection
•
User Registration
•
Auto USB Power Switching
•
ISIS/TWAIN Drivers
•
Batch Separation
•
Bundled Canon CapturePerfect
•
Bleed-Through Prevention/
Background Removal
•
Bundled Adobe Acrobat Standard
•
Color Dropout (RGB)/
Enhance Color (RED)
•
Bundled Nuance OmniPage SE
•
Deskew
•
Bundled Presto! BizCard Reader
•
Folio Mode
•
Bundled Nuance PaperPort Standard
•
Moiré Reduction
•
Bundled Kofax VirtualReScan
•
Scan-to-Job Function
•
Suggested Daily Volume:** 3,000 Scans
OPTIONS
*
**
Examples based on typical settings, rated in pages/images per minute with
letter-sized documents at 200 dpi unless specified. Actual processing speeds
may vary based on PC performance and application software.
Calculation based on scanning speed and assumed daily use.
•
Barcode Module III
•
Soft Carrying Case
•
Exchange Roller Kit
•
One-Year CarePAK (Exchange Service)
•
Flatbed Scanner Unit 101
•
Two-Year CarePAK (Exchange Service)
13
HIGH PERFORMANCE DEPARTMENTAL SCANNER
The Canon imageFORMULA DR-4010C color departmental scanner features state-of-the-art technology that
delivers exceptional image quality and speed. With features such as Advanced Text Enhancement, Automatic
Color Detection, and an advanced three-line CMOS sensor, fine lines and intricate image details are captured
with utmost precision and clarity.
This fast, reliable desktop color scanner packs top-of-the-line features into a compact, user-friendly unit.
Advanced image processing features, reliable document handling, and a compact design are delivered
without sacrificing image quality or speed.
Specifications
FEATURES
Type:
Departmental Scanner
Document Feeding:
Automatic or Manual Sheetfed
Scanning Speeds*
B/ W:
Grayscale:
Color:
Simplex
Up to 42 ppm
Up to 42 ppm
Up to 42 ppm
Scanning Element:
Duplex
Up to 84 ipm
Up to 84 ipm
Up to 84 ipm
Advanced Text Enhancement
(Three Types)
•
Moiré Reduction
•
Auto Color Detection
•
MultiStream
•
Auto Page Size Detection
•
Rapid Recovery System
•
Batch Separation
•
Skip Blank Page
•
Bleed-through Prevention/
•
Ultrasonic Double-Feed Detection
Background Removal
•
ISIS/TWAIN Drivers
•
Custom Color Dropout/Enhance Color
•
Bundled Canon CapturePerfect
•
Deskew
•
Bundled Adobe Acrobat Standard
•
Folio Mode
•
Bundled Kofax VirtualReScan
Three-Line CMOS CIS
Document Size
Width:
Length:
Long Doc. Mode:
2.1" x 8.6"
2.8" x 14"
Up to 39.4"
ADF Capacity:
100 Sheets
Interface:
USB 2.0, SCSI-III
OPTIONS
Dimensions (H x W x D):
7.3" x 12.5" x 10.9"
•
Barcode Module III
•
One-Year CarePAK (Exchange Service)
Weight:
14.1 lb.
•
Exchange Roller Kit
•
Two-Year CarePAK (Exchange Service)
•
Flatbed Scanner Unit 101
Suggested Daily Volume:** 5,000 Scans
*
**
14
•
Examples based on typical settings, rated in pages/images per minute
with letter-sized documents at 200 dpi unless specified. Actual processing
speeds may vary based on PC performance and application software.
Calculation based on scanning speed and assumed daily use.
FAST, FLEXIBLE DEPARTMENTAL SCANNING
Today’s document imaging requirements are more varied than ever. With this understanding, Canon designed
the imageFORMULA DR-5010C departmental scanner to be a versatile image processing machine. A robust
color scanner, the DR-5010C scanner is small enough to sit on a desktop, yet it’s ready to capture hard-to-handle
source materials for immediate work efficiency. It’s also ultra-fast, scanning color at the same rapid rate it
processes black and white. And this user-friendly machine is loaded with diverse automatic and customizable
functions that will change any image capture process.
Specifications
FEATURES
Type:
Departmental Scanner
Document Feeding:
Automatic or Manual Sheetfed
Scanning Speeds*
B/ W:
Grayscale:
Color:
Simplex
Up to 50 ppm
Up to 50 ppm
Up to 50 ppm
Duplex
Up to 100 ipm
Up to 100 ipm
Up to 100 ipm
•
Advanced Text Enhancement
(Three Types)
•
Moiré Reduction
•
Auto Color Detection
•
MultiStream
•
Auto Page Size Detection
•
Skip Blank Page
•
Batch Separation
•
Ultrasonic Double-Feed Detection
•
Bleed-through Prevention/
Background Removal
•
ISIS/TWAIN Drivers
•
Custom Color Dropout/Enhance Color
•
Bundled Canon CapturePerfect
•
Deskew
•
Bundled Adobe Acrobat Standard
•
Landscape Orientation Scanning
•
Bundled Kofax VirtualReScan
Scanning Element:
Three-Line CMOS CIS
Document Size
Width:
Length:
Long Doc. Mode:
2.1" x 11.8"
2.8" x 17"
Up to 39.4"
ADF Capacity:
100 Sheets
Interface:
Hi-Speed USB 2.0, SCSI-III
OPTIONS
Dimensions (H x W x D):
7.5" x 15.6" x 12.3"
•
Back Imprinter
•
Front Imprinter
Weight:
23 lb.
•
Barcode Module III
•
Nine-Month CarePAK (On-site Service)
•
Exchange Roller Kit
•
One-Year CarePAK (On-site Service)
Suggested Daily Volume:** 6,000 Scans
*
**
Examples based on typical settings, rated in pages/images per minute with letter-sized
landscape documents at 200 dpi unless specified. Actual processing speeds may vary
based on PC performance and application software.
Calculation based on scanning speed and assumed daily use.
15
HIGH SPEED DEPARTMENTAL SCANNING
The imageFORMULA DR-6010C color departmental scanner delivers high-speed, reliable document handling
and high-quality images in a small package. Flexibility, rich features, and ease of use help maximize return on
investment at all levels of the business system.
The DR-6010C was developed to offer another option for decentralized capture scanning needs. In combination
with its sister product, the imageFORMULA DR-4010C, these scanners offer competitive document imaging
platforms designed to increase efficiencies and workflows in decentralized scanning environments.
Specifications
FEATURES
Type:
Departmental Scanner
Document Feeding:
Automatic or Manual Sheetfed
Scanning Speeds*
B/ W:
Grayscale:
Color:
Simplex
Up to 60 ppm
Up to 60 ppm
Up to 60 ppm
Duplex
Up to 120 ipm
Up to 120 ipm
Up to 120 ipm
Advanced Text Enhancement
(Three Types)
•
MultiStream
•
Auto Color Detection
•
Rapid Recovery System
•
Auto Page Size Detection
•
Skip Blank Page
•
Batch Separation
•
Ultrasonic Double-Feed Detection
•
Bleed-through Prevention/
Background Removal
•
ISIS/TWAIN Drivers
•
Custom Color Dropout/Enhance Color
•
Bundled Canon CapturePerfect
•
Deskew
•
Bundled Adobe Acrobat Standard
•
Folio Mode
•
Bundled Kofax VirtualReScan
•
Moiré Reduction
Scanning Element:
Three-Line CMOS CIS
Document Size
Width:
Length:
Long Doc. Mode:
2.1" x 8.6"
2.8" x 14"
Up to 39.4"
ADF Capacity:
100 Sheets
Interface:
Hi-Speed USB 2.0, SCSI-III
Dimensions (H x W x D):
7.3" x 12.5" x 10.9"
OPTIONS
Weight:
14.3 lb.
•
Barcode Module III
•
One-Year CarePAK (Exchange Service)
•
Exchange Roller Kit
•
Two-Year CarePAK(Exchange Service)
•
Flatbed Scanner Unit 101
Suggested Daily Volume:** 7,500 Scans
*
**
16
•
Examples based on typical settings, rated in pages/images per minute with
letter-sized portrait documents at 200 dpi unless specified. Actual processing speeds
may vary based on PC performance and application software.
Calculation based on scanning speed and assumed daily use.
ULTIMATE SCANNING FLEXIBILITY AND IMAGE QUALITY
The Canon imageFORMULA DR-7090C universal production scanner delivers incredible flexibility, image
quality, and reliability, all at high scanning speeds, by leveraging the technologies from its award-winning
imageFORMULA and imageRUNNER product lines.
This combination flatbed/sheetfed color production scanner provides leading value that enables it to reduce
costs and increase scanning efficiencies in the production environment.
Specifications
FEATURES
Type:
Universal Production Scanner
Document Feeding:
Automatic Sheetfed, Manual Flatbed
Scanning Speeds*
B/ W:
Grayscale:
Color:
Simplex
Up to 70 ppm
Up to 70 ppm
Up to 70 ppm
Scanning Element
Front:
Back:
Duplex
Up to 88 ipm
Up to 88 ipm
Up to 88 ipm
CCD
Three-line CMOS CIS
Document Size
Width:
Length:
Long Doc. Mode:
5.5" x 12"
5" x 17"
Up to 24.8"
ADF Capacity:
100 Sheets
Interface:
Hi-Speed USB 2.0, SCSI-III
Dimensions (H x W x D):
12.5" x 24.3" x 23.7"
Weight:
90.4 lb.
•
Advanced Text Enhancement
(Two Types)
•
Punch Hole Removal
•
Bleed-through Prevention/
Background Removal
•
Scan-to-Job Buttons
•
Custom Color Dropout/Enhance Color
•
Skip Blank Page
•
Count Only Mode
•
Text Orientation Recognition
•
Deskew
•
ISIS/TWAIN Drivers
•
Error Diffusion
•
Bundled Canon CapturePerfect
•
MultiStream
•
Bundled Kofax VirtualReScan
OPTIONS
•
Exchange Roller Kit
•
Nine-Month CarePAK (On-site Service)
•
One-Year CarePAK (On-site Service)
Suggested Daily Volume:** 8,000 Scans
*
**
Examples based on typical settings, rated in pages/images per minute
with letter-sized landscape documents at 200 dpi unless specified.
Actual processing speeds may vary based on PC performance and
application software.
Calculation based on scanning speed and assumed daily use.
17
HIGH-SPEED, HIGH-QUALITY SCANNING FOR ULTIMATE
PRODUCTION EFFICIENCY
The Canon imageFORMULA DR-6050C production scanner delivers true high-speed scanning that provides
enterprises with reliable, high image quality and flexible scanning solutions to enhance any document
management system.
Physical handling, off-site storage and retrieval, and labor costs can be drastically reduced with efficient document
management systems. For mission-critical production scanning environments, the DR-6050C scanner’s winning
combination of leading value, increased scanning speed, reliability, and efficiencies can help companies reduce
their overhead costs associated with document management and retention.
Specifications
FEATURES
Type:
Production Scanner
Document Feeding:
Automatic or Manual Sheetfed
Scanning Speeds*
B/ W:
Grayscale:
Color:
Simplex
Up to 70 ppm
Up to 70 ppm
Up to 70 ppm
Scanning Element:
Three-Line CMOS CIS
Duplex
Up to 140 ipm
Up to 140 ipm
Up to 140 ipm
Advanced Text Enhancement
(Two Types)
•
Paper Feed Tray – Two Positions
•
Auto Color Detection
•
Rapid Recovery System
•
Auto Page Size Detection
•
Staple Detection
•
Bleed-through Prevention/
Background Removal
•
Ultrasonic Double-Feed Detection
•
Count Only Mode/Verify Scan
•
ISIS/TWAIN Drivers
•
Custom Color Dropout/Enhance Color
•
Bundled Canon CapturePerfect
•
Deskew
•
Bundled Kofax VirtualReScan
•
Folio Mode
Document Size
Width:
Length:
Long Doc. Mode:
2" x 12"
2.8" x 17"
Up to 118.1"
ADF Capacity:
300 Sheets
Interface:
Hi-Speed USB 2.0, SCSI-III
OPTIONS
Dimensions (H x W x D):
12.2" x 18.9" x 20.9"
•
Barcode Module III
•
Imprinter
Weight:
50 lb.
•
Batch Separation
•
Patchcode Decoder
•
Exchange Roller Kit
•
Nine-Month CarePAK (On-site Service)
•
Flatbed Scanner Unit 101
•
One-Year CarePAK (On-site Service)
Suggested Daily Volume:** 12,000 Scans
*
**
18
•
Examples based on typical settings, rated in pages/images per minute with lettersized landscape documents at 200 dpi unless specified. Actual processing speeds
may vary based on PC performance and application software.
Calculation based on scanning speed and assumed daily use.
HIGH-SPEED, HIGH-QUALITY SCANNING FOR ULTIMATE
PRODUCTION EFFICIENCY
The Canon imageFORMULA DR-9050C and DR-7550C production scanners deliver true high-speed scanning that
provide enterprises with reliable, high image quality and flexible scanning solutions to enhance any document
management system.
Physical handling, off-site storage and retrieval, and labor costs can be drastically reduced with efficient document
management systems. For mission-critical production scanning environments, the DR-9050C and DR-7550C
scanners’ winning combination of leading value, increased scanning speed, reliability, and efficiencies can help
companies reduce their overhead costs associated with document management and retention.
Specifications
FEATURES
Type:
Production Scanner
Document Feeding:
Automatic or Manual Sheetfed
Scanning Speeds*
DR-9050C
Simplex
Duplex
B/ W:
Up to 112 ppm Up to 225 ipm
Grayscale: Up to 112 ppm Up to 225 ipm
Color:
Up to 112 ppm Up to 225 ipm
DR-7550C
Simplex
Duplex
Up to 90 ppm Up to 180 ipm
Up to 90 ppm Up to 180 ipm
Up to 90 ppm Up to 180 ipm
Scanning Element:
Three-Line CMOS CIS
Document Size
Width:
Length:
Long Doc. Mode:
2" x 12"
2.8" x 17"
Up to 118.1"
ADF Capacity:
500 Sheets
Interface:
Hi-Speed USB 2.0, SCSI-III
Dimensions (H x W x D):
12.2" x 18.9" x 20.9"
Weight:
50 lb.
•
Advanced Text Enhancement
(Two Types)
•
Paper Feed Tray – Three Positions
•
Auto Color Detection
•
Rapid Recovery System
•
Auto Page Size Detection
•
Staple Detection
•
Bleed-through Prevention/
Background Removal
•
Ultrasonic Double-Feed Detection
•
Count Only Mode/Verify Scan
•
ISIS/TWAIN Drivers
•
Custom Color Dropout/Enhance Color
•
Bundled Canon CapturePerfect
•
Deskew
•
Bundled Kofax VirtualReScan
•
Folio Mode
OPTIONS
•
Barcode Module III
•
Imprinter
•
Batch Separation
•
Patchcode Decoder
•
Exchange Roller Kit
•
Nine-Month CarePAK (On-site Service)
•
Flatbed Scanner Unit 101
•
One-Year CarePAK (On-site Service)
Suggested Daily Volume:** DR-9050C: 18,000 Scans
DR-7550C: 15,000 Scans
*
**
Examples based on typical settings, rated in pages/images per minute with lettersized landscape documents at 200 dpi unless specified. Actual processing speeds
may vary based on PC performance and application software.
Calculation based on scanning speed and assumed daily use.
19
TAKING PRODUCTION SCANNING TO A NEW LEVEL
The Canon imageFORMULA DR-X10C color production scanner uses state-of-the-art technology to deliver
high-speed, high-quality image scanning, reliable document handling capabilities and superior durability.
The DR-X10C scanner offers enhanced sensor technology and a reliable feeding system to ensure that
high volumes of mixed paper sizes or other challenging scan operations are handled with minimal operator
intervention at maximum scanning speed. Plus, the robust, compact design, energy-saving performance,
and advanced functionality tackle the high demands of production-level environments.
Specifications
FEATURES
Type:
Production Scanner
Document Feeding:
Automatic or Manual Sheetfed
Scanning Speeds*
B/ W:
Grayscale:
Color:
Simplex
Duplex
Up to 128 ppm Up to 256 ipm
Up to 128 ppm Up to 256 ipm
Up to 128 ppm Up to 256 ipm
Scanning Element:
Advanced Text Enhancement
(Two Types)
•
Retry Feeding
•
Auto Color Detection
•
Selectable Background Color
•
Auto Page Size Detection
•
Skip Blank Page
•
Auto USB Power Switching
•
Staple Detection
•
Custom Color Dropout/Enhance Color
•
Three-Step Dust Prevention System
•
Deskew
•
•
MultiStream
Three Ultrasonic Double-Feed
Detection Sensors
•
Paper Feed Tray – Three Positions
•
ISIS/TWAIN Drivers
Rapid Recovery
•
Bundled Canon CapturePerfect
Three-Line CMOS CIS
Document Size
Width:
Length:
Long Doc. Mode:
2" x 12"
2.8" x 17"
Up to 39.4"
ADF Capacity:
500 Sheets
Interface:
USB 2.0, SCSI-III
OPTIONS
Dimensions (H x W x D):
14.8" x 20.8" x 22.2"
•
Batch Separation
•
Barcode Module III
Weight:
85.8 lb.
•
Exchange Roller Kit
•
Kofax CGA Board
•
Pre-Imprinter
•
Nine-Month CarePAK (On-site Service)
•
Post-Imprinter
•
One-Year CarePAK (On-site Service)
•
Patch Code Decoder
Suggested Daily Volume:** 60,000 Scans
*
**
20
•
Examples based on typical settings, rated in pages/images per minute
with letter-sized landscape documents at 200 dpi unless specified.
Actual processing speeds may vary based on PC performance and
application software.
Calculation based on scanning speed and assumed daily use.
•
OPTIONAL ACCESSORIES/EXCHANGE PROGRAM
Carrying Cases
P-150/150M
Soft Carrying Case
DR-2510C/2510M/2010C/2010M
Soft Carrying Case
Item Number:
4179B003
Dimensions (H x W x D): 3.0" x 11.8" x 4.1"
Weight:
2 lb. (Approx.)
Item Number:
1191V396
Dimensions (H x W x D): 12" x 6" x 7"
Weight:
2 lb. (Approx.)
DR-2580C
Soft Carrying Case
DR-3010C/ScanFront 220/220P/220e/220eP
Soft Carrying Case
Item Number:
0676V383
Dimensions (H x W x D): 2.7" x 14.5" x 7"
Weight:
4 lb. (Approx.)
Item Number:
1363V016
Dimensions (H x W x D): 8" x 12" x 15"
Weight:
2 lb. (Approx.)
Canon CarePAK Program
Canon CarePAK On-site Service
One-Year CarePAK (Exchange Program)
For DR-5010C
P-150:
4179B010
P-150M
4179B012
DR-2020U:
4048B003
DR-2010C:
2865B005
DR-2010M:
2865B007
DR-2510C:
2865B006
DR-2510M:
2865B008
DR-2580C:
0106B014
DR-3010C:
3395B002
DR-4010C:
1921B002
DR-6010C:
4082B002
ScanFront 220:
2445B006
ScanFront 220P:
2445B007
ScanFront 220e:
4090B001
ScanFront 220eP:
4090B002
Two-Year CarePAK (Exchange Program)
DR-2010C:
2865B002
DR-2510C:
2865B001
DR-2580C:
0106B005
DR-3010C:
3395B001
DR-4010C:
1921B003
DR-6010C:
4082B003
ScanFront 220:
2445B002
ScanFront 220P:
2445B003
For DR-6050C
For DR-7090C
For DR-7550C
For DR-9050C
For DR-X10C
Nine-Month:
0434B006
One-Year:
0434B004
Nine-Month:
4009B009
One-Year:
4009B010
Nine-Month:
3504B002
One-Year:
3504B003
Nine-Month:
4009B007
One-Year:
4009B008
Nine-Month:
4009B005
One-Year:
4009B006
Nine-Month:
2418B007
One-Year:
2418B008
21
OPTIONAL ACCESSORIES/EXCHANGE PROGRAM
Detachable Flatbed Units
Additional Accessories
Full-Size Flatbed Unit For DR-2580C
Feed Roller Unit for P-150/150M:
4179B002
Separation Pad for P-150/150M:
4179B001
Feed Roller Unit for DR-2020U:
4048B001
Separation Pad for DR-2020U:
4048B002
AC Adaptor for P-150/150M:
4179B004
Item Number:
0106B001
Dimensions (H x W x D): 3.2" x 12.4" x 21.5"
Weight:
8.4 lb. (Approx.)
Half-Size Flatbed Unit For DR-2580C
Item Number:
0106B003
Dimensions (H x W x D): 3.2" x 12.4" x 15.6"
Weight:
6.6 lb. (Approx.)
Flatbed Scanner Unit 101 For DR-9550C/7550C/
6050C/6010C/4010C/3010C/2510C/2010C
2445B001
Exchange Roller Kit for DR-2580C:
0106B002
Exchange Roller Kit for DR-3010C:
3335B001
Exchange Roller Kit for DR-6010C/4010C:
4082B001
Exchange Roller Kit for DR-5010C:
0434B002
Exchange Roller Kit for DR-7090C:
3504B001
Exchange Roller Kit for DR-9050C/7550C/6050C:
4009B001
Exchange Roller Kit for DR-X10C:
2418B001
Exchange Roller Kit for ScanFront 220/220P/220e/220eP:
2445B001
Pre-Imprinter for DR-X10C:
2418B003
Post-Imprinter for DR-X10C:
2418B004
Imprinter for DR-9050C/7550C/6050C:
4009B003
Front-Imprinter for DR-5010C:
0837B001
Connectors
Back-Imprinter for DR-5010C:
0837B002
eCopy Connectors for ScanFront 220e/220eP
Patch Code Decoder for DR-X10C:
2418B005
Patch Code Decoder for DR-9050C/7550C/6050C:
4009B002
2418B006
Item Number:
4101B002
Dimensions (H x W x D): 3.1" x 11.4" x 20.2"
Weight:
7.7 lb. (Approx.)
22
Exchange Roller Kit for DR-2510C/2510M/2010C/2010M:
eCopy Connector–MS SharePoint
1505V267
Kofax CGA Board for DR-X10C:
eCopy Connector–OpenText RightFax
1505V282
Barcode Module III for
eCopy Connector–Interwoven Worksite
1580V840
DR-X10C/9050C/7550C/6050C/6010C/5010C/4010C/3010C/2580C: 1922B001
eCopy Connector– EMC Documentum Content Server
1580V848
Cleaning Sheets for DR-X10C:
2418B002
23
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042
IMAGEFORMULA and CapturePerfect are registered trademarks of Canon Electronics
Inc. CANON and IMAGERUNNER are registered trademarks of Canon Inc. in the
United States and may also be registered trademarks or trademarks in other
countries. CAREPAK is a registered trademark of Canon U.S.A., Inc. IMAGEANYWARE
is a trademark of Canon. All other referenced product names and marks are
trademarks of their respective owners and are hereby acknowledged.
Specifications and availability subject to change without notice.
©2010 Canon U.S.A., Inc. All rights reserved.
0610-DR-FLB-PDF-SP
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
